Samsung Electronics Co SGHX466 Dual-Band GSM Phone User Manual
Samsung Electronics Co Ltd Dual-Band GSM Phone Users Manual
Users Manual
* Some of the contents of this manual may differ from your phone,
depending on the software installed or your service provider.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-0xxxxA
English. 01/2005. Rev 1.0
SGH-X466
User’s Guide
Use road safety at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
Important safety precautions
1
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency call
Key in the emergency number for your present
location, then press [ ].
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories could
damage your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 53.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to
“Getting started.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful
attention to the subsequent information
regarding safety or phone features.
Indicates that you can get more
information on the referenced page.
→
Indicates that you need to press the
Navigation keys to scroll to the specified
option and then select it.
[key name] Indicates a key on the phone. For
example,
[]
<soft key> Indicates a soft key, whose function is
displayed on the phone screen. For
example, <
Menu
>
• Dual-band operation
Use your phone in worldwide GSM networks, in
any of 850, and 1900 bands.
Special
features of your phone
• Simple, compact design with Intenna
Samsung’s powerful intenna technology allows
the best call quality without an annoying
external antenna.
•WAP browser
Access the wireless web and
access various services and up-
to-the-minute information.
3
Special features of your phone
•Phone book
Store up to 1000 contact
numbers.
• Multimedia Message Service (MMS)
Send and receive MMS messages with a
combination of text, images, and sounds.
• Calendar and To do list
Keep track of your daily, weekly,
and monthly schedules and
tasks.
• Voice recorder
Record memos or sounds.
•Java
Enjoy Java
™
-based embedded
games and download new
games.
4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Buttons, features, and locations
Get started 7
First steps to operate your phone
Install and charge the phone ................................... 7
Power on or off...................................................... 8
Keys and display.................................................... 9
Access menu functions.......................................... 11
Customise your phone .......................................... 12
Make/answer calls................................................ 13
Step outside the phone 13
Begin with your WAP, messages, and other special features
Browse WAP........................................................ 13
Use Phone book................................................... 14
Send messages.................................................... 14
View messages .................................................... 16
Enter text 17
ABC, T9, Number, and Symbol mode
Call functions 19
Advanced calling features
Phone book menu 24
Menu functions 27
All menu options listed
Solve problems 51
Health and safety information 53
Index 78
5
Overview of menu functions
To access Menu mode, press <
Menu
> from the idle screen.
1 Text messages
p.27
1 Inbox
2 Outbox
3 Write new
4 Templates
5 Settings
6 Delete all
7 Memory status
8 Voice mail
9 Broadcast
p.27
p.27
p.28
p.28
p.29
p.29
p.29
p.30
p.30
2 Multimedia messages
p.30
1 Inbox
2 Outbox
3 Draft
4 Write new
5 Template
6 Delete all
7 Memory status
8 Setup
9 MMS profile
p.30
p.31
p.32
p.32
p.33
p.33
p.33
p.33
p.34
3 Call records
p.34
1 Missed calls
2 Received calls
3 Dialled calls
4 Delete all
5 Call time
6 Call cost*
p.34
p.34
p.34
p.35
p.35
p.35
4 Sound settings
p.36
1 Ring tone
2 Ring volume
3 Alert type
4 Keypad tone
5 Message tone
6 Alert on call
7 Folder tone
8 Power on/off
9 Extra tones
p.36
p.36
p.36
p.36
p.36
p.36
p.37
p.37
p.37
5 Phone settings
p.37
1 Display settings
2 Greeting message
3 Own number
4 Language
5 Security
6 Extra settings
7 Reset settings
p.37
p.38
p.38
p.38
p.38
p.39
p.40
6 Organizer
p.40
1 Alarm
2 Calendar
3 Time & Date
4 Calculator
5 To do list
6 Voice memo
7 Currency exchange
p.40
p.41
p.41
p.42
p.42
p.43
p.44
7 Network services
p.44
1 Call diverting
2 Call barring
3 Call waiting
4 Network selection
5 Caller ID
6 Closed user group
p.44
p.45
p.45
p.45
p.46
p.46
8 Funbox
p.46
1 WAP browser
2 Games
3 Sounds
4 Images
5 Delete all
6 Memory status
p.46
p.49
p.50
p.50
p.50
p.50
9 SIM AT
p.50
<
Name
>
Phonebook
p.24
1 Search
2 New entry
3 Group search
4 Edit group
5 Speed dial
6 Delete all
7 Memory status
p.24
p.24
p.25
p.25
p.25
p.26
p.26
* Shows only if supported by your
SIM card.
6
Unpack
Make sure you have each item
You can obtain various accessories from your local
Samsung dealer.
Phone Travel adapter
Battery User’s manual
The items supplied with your phone and the accessories
at your Samsung dealer may vary, depending on your
country or service provider.
Your phone
Buttons, features, and locations
Left soft key
Volume keys
Dial key
Special
function keys
Headset jack
Earpiece
Display
Power on/off/
Menu exit key
Alphanumeric
keys
Right soft key
Microphone
Navigation keys
(Up/Down/Left/
Right)
WAP access key
Cancel/Correct
key
7
Get started
Get started
First steps to operate your phone
SIM card information
When you subscribe to a cellular network, you receive
a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your
PIN, and available optional services.
Install and charge the phone
Remove the battery.
If the
phone is already
on, first turn it off by
holding [ ].
Insert the SIM card.
Make sure that the gold-
coloured contacts on the
card face down into the
phone.
1
➀➁
2
Install the battery. Plug the travel adapter
into the phone.
Plug the adapter into a standard AC wall outlet.
When the phone is completely charged (the battery
icon stops blinking), unplug the adapter from the
power outlet.
3 4
5
6
8
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon [ ] blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
Remove the adapter from the phone.
7
➀
➀
➁
Power on
Do not turn on
the phone when
mobile phone
use is prohibited.
1. Open the phone.
2. Press and hold [ ] to turn on
the phone.
3. If necessary, enter the phone
password and press <
OK
>.
4. If necessary, enter the PIN and
press <
OK
>.
Power off
1. Open the phone.
2. Press and hold [ ].
9
Get started
Keys and display
Key(s) Description
Perform the function indicated on the bottom
line of the display.
In Idle mode, access the following menus
respectively.
•Up:
Calendar
•Down:
Games
•Left:
Text messages
•Right:
Ring tone
In Menu mode, scroll through the menu
options.
In Idle mode, launch the Wireless Application
Protocol (WAP) browser.
Send or answer a call.
In Idle mode, retrieve the last number
dialled, missed, or received.
Key(s) Description
Delete characters from the display.
In Menu mode, return to the previous menu
level.
End a call.
Hold down to switch the phone on and off.
In Menu mode, cancel input and return the
phone to Idle mode.
Enter numbers, letters, and some special
characters.
In Idle mode, hold
[1]
down to access your
voicemail.
Enter special characters.
In Idle mode, hold
[]
down to activate or
deactivate Silent mode.
(on the left)
Adjust the volume of various sounds for the
phone.
In Idle mode, adjust the keypad tone
volume.
In Menu mode, scroll through menu options.
10
Get started
Display
Layout
The display has the three areas.
Icons
Received signal strength
Call in progress
Out of your service area; you
cannot send or receive calls
Call diverting feature is active
page 44
GPRS network
Roaming
Text and graphics
displays messages,
instructions, and
information you enter.
Soft key function
indicators
shows the current
functions assigned to the
two soft keys.
Icons
displays various icons.
Icons
(continued)
New text message
New voicemail message
New multimedia message
Alarm set
Mute mode is active
page 21
Active Silent mode or call ringer set
to vibrate
page 12, page 36
Battery power level
11
Get started
Access menu functions
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current role.
Press the left soft
key to access
Menu
mode.
Press the right soft
key to access the
Name
menu.
Menu Name
Select an
option
1. Press the appropriate soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press <
Select
> to confirm the
function displayed or option
highlighted.
4. To exit, choose either of the
following methods:
• Press < > or [
C
] to move
up one level.
• Press [ ] to return to Idle
mode.
Use shortcuts
Press the number key
corresponding to the option you
want.
12
Get started
Customise your phone
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Language
.
2. Select a language.
1. In Idle mode, press <
Menu
>
and select
Sound settings
→
Ring tone
.
2. Select a ringer melody.
You can set a wallpaper for the idle
screen using various pictures.
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Display settings
→
Wallpaper
→
Wallpaper list
.
2. Select an image.
3. Scroll to the image you want.
4. Press <
Select
>.
Display
language
Call ringer
melody
Idle mode
wallpaper
You can switch the phone to Silent
mode to avoid disturbing other
people with your phone sounds.
Press and hold [ ] in Idle mode.
You can protect the phone against
unauthorised use with a phone
password.
1. In Idle mode, press <
Menu
>
and select
Phone
settings
→
Security
→
Change
password
.
2. Enter the default password,
“00000000” and press <
OK
>.
3. Enter a new 4- to 8- digit
password and press <
OK
>.
4. Enter the new password again
and press <
OK
>.
Switch to
Silent mode
Phone lock
13
Make/answer calls
Step outside the phone
Begin with your WAP, messages, and other special
features
Browse WAP
Using a built-in WAP (Wireless Access Protocol)
browser, you can get easy access to the wireless web
to receive a variety of updated services and
information and to enjoy download of web contents.
5. Select
Phone lock
.
6. Select
Enable
.
7. Enter the password and press
<
OK
>.
1. Enter an area code and phone
number.
2. Press [ ].
3. To end the call, press [ ].
1. When the phone is ringing,
press [ ].
2. To end the call, press [ ].
Press [ / ].
Phone lock
Make a call
Answer a call
Adjust the
volume during
a call
In Idle mode, press [ ].
• To scroll through browser items,
press [Up] or [Down].
• To select an item, press [ ].
• To return to the previous page,
press [
C
].
• To return to the homepage,
press <
Menu
> and select
Home
.
Launch the
browser
Navigate the
browser
14
Step outside the phone
Use Phone book
Send messages
To the phone’s memory
1. In Idle mode, enter a phone
number and press <
Save
>.
2. Select a number type.
3. Select
Phone
.
4. Enter a name and press <
OK
>.
5. Select location and press <
OK
>
to save the entry.
To the SIM card
1. In Idle mode, enter a phone
number and press <
Save
>.
2. Select a number type.
3. Select
SIM
.
4. Enter a name and press <
OK
>.
5. Select location and press <
OK
>
to save the entry.
Add an entry
1. In Idle mode, press <
Name
>
and select
Search
.
2. Select an entry by pressing
<
View
>.
3. Select a number.
4. Press [ ] to dial, or
<
Options
> to access options.
1. In Idle mode, press <
Menu
>
and select
Text messages
→
Write new
.
2. Enter the message text.
3. Press <
Options
> and select
Save and send
or
Send only
.
4. If you selected
Save and send
,
select a memory location.
5. Enter a destination number and
press <
OK
>.
Find an entry
Send a text
message (SMS)
15
Step outside the phone
1. In Idle mode, press <
Menu
>
and select
Multimedia
messages
→
Write new
.
2. Enter the message subject
press <
OK
>.
3. Select
Add here
and add
message contents.
4. When you finish, press
<
Options
> and select
Send
.
5. Select a destination type.
6. Select one of
Phone number
,
E-mail
, or
Phone book
.
7. Enter a destination number or
an e-mail address, or select
from Phone book and press
<
OK
>.
Send a
multimedia
message
(MMS)
8. To add other destinations,
select
Add destination
and
repeat from step 6.
9. To add destinations of other
types, press < > and repeat
from step 5.
10.When you finish, select
Send
message
.
Send a
multimedia
message
(MMS)
16
Step outside the phone
View messages
When a notification appears:
Press <
View
>. The message
displays.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Text messages
→
Inbox
.
2. Select a message.
View a text
message
When a notification appears:
1. Press <
View
>.
2. Press <
Options
> and select
Retrieve
. The message
displays.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
Multimedia messages
→
Inbox
.
2. Select a message.
View a
multimedia
message
Enter text
17
Enter text
ABC, T9, Number, and Symbol mode
You can enter text for some features such as
messaging, Phone book, or Organizer, using ABC
mode, T9 mode, Number mode, and Symbol mode.
Changing the text input mode
The text input mode indicator displays when the
cursor is in a text field.
Press the right soft key to change the input mode.
Example
: Writing a text message
Using ABC mode
Press the appropriate key until the character you want
appears on the screen.
Tips for using ABC mode
• To enter the same letter twice or to enter a
different letter on the same key, wait for the cursor
to move to the right automatically or press [Right].
Then, enter the next letter.
• Press [ ] to insert a space.
Text input mode
indicator
ABC mode
T9 mode
Number mode
Symbol mode
None
Characters in order displayed
Key Upper case Lower case
space
18
Enter text
• Press [ ] to change case. Capital lock ( ), Lower
case ( ), and Initial capital ( ) are available.
• Press [Left] or [Right] to move the cursor.
• Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Using T9 mode
T9 is a predictive text input mode that allows you to
key in any character using single keystrokes.
Entering a word in T9 mode
1. Press [
2
] to [
9
]
to start entering a word. Press
each key once for each letter.
For example, press [
4
], [
3
], [
5
], [
5
], and [
6
] to
enter Hello in T9 mode.
T9 predicts the word that you are typing, and it
may change with each key that you press.
2. Enter the whole word before editing or deleting
characters.
3. When the word displays correctly, go to step 4.
Otherwise, press [
0
] to display alternative word
choices for the Of and Me use [
6
] and [
3
].
4. Press [ ] to insert a space and enter the next
word.
Tips for using T9 mode
• Press [
1
] to enter periods or apostrophes
automatically.
• Press [ ] to change case in T9 mode. Capital lock
( ), Lower case ( ), and Initial capital ( ) are
available.
• Press [Left] or [Right] to move the cursor.
• Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Adding a new word to the T9 dictionary
This feature may not be available for some languages.
1. Enter the word that you want to add.
2. Press [
0
] to display alternative words for your key
presses. When there are no more alternative
words,
Add
displays on the bottom line.
19
3. Press <
Add
>.
4. Enter the word you want using ABC mode and
press <
OK
>.
Using Number mode
Number mode enables you to enter numbers.
Press the keys corresponding to the digits you want.
Using Symbol mode
Symbol mode enables you to insert symbols.
Call functions
Advanced calling features
Making a call
1. In Idle mode, enter the area code and phone
number.
2. Press [ ].
Making an international call
1. In Idle mode, press and hold [
0
]. The
+
character
appears.
2. Enter the country code, area code, and phone
number, then press [ ].
Redialling recent numbers
1. In Idle mode, press [ ] to display the list of
recent numbers.
2. Scroll to the number you want and press [ ].
To Press
display more symbols [Up] or [Down].
select a symbol the corresponding
number key.
clear the symbol(s) [
C
].
insert the symbol(s) <
OK
>.
Press [
C
]
to clear the last digit or press and hold
[
C
] to clear the whole display. You can move the
cursor to edit an incorrect digit.
20
Call functions
Making a call from Phone book
Once you have stored a number in Phone book, you
can dial the number by selecting it from Phone
book.
p. 24
You can also use the speed dial feature to assign your
most frequently called numbers to specific number
keys.
p. 25
Dialling a number from the phone’s memory
1. In Idle mode, press and hold [
0
]. A + appears.
2. Enter the location number for the phone number
you want and press [ ].
3. Press [Up] or [Down] to scroll through other
numbers.
4. Press <
Dial
> or [ ] to dial the number you want.
Dialling a number from the SIM card
1. In Idle mode, enter the location number for the
phone number you want and press [ ].
2. Press [Up] or [Down] to scroll through other
numbers.
3. Press <
Dial
> or [ ] to dial the number you want.
Ending a call
Close the phone or press [ ].
Answering a call
When you receive an incoming call, the phone rings
and displays the incoming call image.
Press [ ] or <
Accept
> to answer the call.
Tips for answering a call
• When
Anykey
answer
in the
Extra
settings
menu is active, you can press any key to answer
a call, except for [ ] and <
Reject
>.
p. 40
• Press <
Reject
> or [ ] to reject a call.
• When
Active folder
is active, you can just open
the phone to answer a call.
Call functions
21
Viewing missed calls
If you have missed calls, the screen displays how
many calls you have missed.
1. Press <
View
>.
2. If necessary, scroll through the missed calls.
3. Press [ ] to dial the number you want.
Using the headset
Use the headset to make or answer calls without
holding the phone.
Connect the headset to the jack on the right side of
the phone.
The buttons on the headset work as listed below:
Options during a call
You can access a number of functions during a call.
Adjusting the volume during a call
Use [ / ] to adjust the earpiece volume during a call.
Press [ ] to increase the volume level and [ ] to
decrease the volume level.
Placing a call on hold/Retrieving
Press <
Hold
> or <
Unhold
> to place the call on hold
or retrieve the call.
Using the menu functions
Press <
Options
> and select
Menu
.
Switching off the microphone
(
Mute mode
)
You can temporarily switch off your phone’s
microphone so that the other person on the phone
cannot hear you.
Press <
Options
> and select
Mute
or
Unmute
.
To Press
redial the last call the button twice.
answer a call and hold the button.
end a call and hold the button.
22
Call functions
Muting or sending key tones
You can turn the key tones off or on.
Press <
Options
> and select
Mute keys
or
Send
keys
.
Sending a sequence of DTMF tones
Dual tone multi-frequency (DTMF) tones are the tones
used in phones for tone dialling.
You can send DTMF tones as a group after entering the
entire number you need to send or retrieving a
number from Phone book. This feature is helpful for
entering a password or an account number when you
call an automated system, like a banking service.
1. When connected with a teleservice system, press
<
Options
> and select
Send
DTMF
.
2. Enter the number you need to send and press
<
OK
>.
Using Phone book
You can access the
Phone book
menu to locate or
store entries.
p. 24
Press <
Options
> and select
Phone book
.
Answering a second call
You can answer an incoming call, if your network
supports it and you have activated the call waiting
feature.
p. 45
1. Press [ ] to answer the call. The first call is
automatically put on hold.
2. Press <
Swap
> to switch between the calls.
3. Press <
Options
> and select
End
held
call
to end
the call on hold.
4. To end the current call, press [ ].
Making a multi-party call
Use this feature to allow as many as six people to join
a multi-party call, or conference call.
Your service provider must support multi-party calls
for you to use this feature.
To communicate with answering machines or
computerised telephone systems,
Send keys
must
be selected.
Call functions
23
Setting up a multi-party call
1. Call the first participant.
2. Call the second participant. The first call is
automatically put on hold.
3. Press <
Options
> and select
Join
. The first
participant is added to the multi-party call.
4. If desired, call another person or answer an
incoming call.
5. Press <
Options
> and select
Join
.
6. Repeat steps 4 and 5 as desired.
Having a private conversation with one
participant
1. Press <
Options
> and select
Select one
.
2. Select a name or number from the participant list.
3. Select
Private
.
You can talk privately with that person, while the
other participants converse with each other.
4. To return to the multi-party call, press <
Options
>
and select
Join
.
Dropping one participant
1. Press <
Options
> and select
Select one
.
2. Select a name or number from the participant list.
3. Press [Down] and select
Remove
.
The participant is dropped from the call, but the
call continues with the other parties.
4. Close the phone or press [ ] to end the multi-
party call.
24
Phone book menu
You can store phone numbers on your SIM card and in
your phone’s memory. The SIM card and phone’s
memory are physically separate, but they are used as
a single entity called Phonebook.
To access this menu, press <
Menu
> in Idle mode.
Search
(Name 1)
Use this menu to search for numbers in Phonebook.
Finding an entry
1. Enter the first few letters of the name that you
want to find.
2. Select the name you want from the list and press
<
View
>.
3. Press [ ] to dial the number, or <
Options
> to
access the Phonebook options.
Using Phonebook options
While viewing an entry in Phonebook, press
<
Options
> to access the following options:
•
Paste
: paste the number into the normal dialling
mode.
•
Edit
: edit the entry information.
•
Delete
: delete the number from Phonebook.
•
Copy
: copy the number to the phone’s memory or
SIM card.
•
Caller group
: assign a caller group.
•
Add entry
: add a new entry.
New entry
(Name 2)
Use this menu to add a new entry to Phonebook.
Storing a number or an e-mail address in the
phone’s memory
1. Select a number type.
2. Select
Phone
.
3. Enter a name and press
<OK
>.
4. Enter a number or an e-mail address and press
<
Save
>.
5. Change the location number, if you want, and
press <
OK
>.
25
Storing a number on the SIM card
1. Select a number type.
2. Select
SIM
.
3. Enter a name and press <
OK
>.
4. Enter a number and press <
Save
>
5. Change the location number, if you want, and
press <
OK
>.
Group search
(Name 3)
Use this menu to search your entries in Phonebook in
caller groups.
1. Enter the first few letters of the group name.
2. Select a group and press <
View
>.
3. Select the name you want and press <
View
>.
4. Press [ ] to dial the number or <
Options
> to
access the Phonebook options.
Edit group
(Name 4)
Use this menu to edit your caller groups’ properties.
From the group list, press <
Options
> to access the
following options:
•
Call ring tone
: set a ring tone for incoming calls
from the group.
•
SMS tone
: set a ring tone for incoming messages
from the group.
•
Graphic
: set a graphic icon for incoming calls from
the group.
•
Group name
: assign a name to the group.
Speed dial
(Name 5)
Use this menu to assign speed dial numbers (2 to 9) to
eight of your most frequently called numbers.
Assigning speed dial entries
1. Select a key location from
2
to
9
. Key
1
is reserved
for your voice mail server. (This key allocation may
be variable depending on the service provider.)
2. Select the name you want from the Phonebook list.
3. Select the number you want.
Managing speed dial entries
While viewing the Speed dial screen, press
<
Options
> to access the following options:
26
Phone book menu
•
Change
: assign a different number to an assigned
key.
•
Delete
: delete the setting for the key.
•
Delete all
: delete the settings for all the keys.
•
Number
: view the number assigned to the key.
Dialling speed dial entries
Press and hold the appropriate key in Idle mode.
Delete all
(Name 6)
Use this menu to delete all of the entries from
Phonebook.
1. Press <
Mark
> to check the location(s) to be
cleared.
2. Press <
Delete
>.
3. Enter the phone password and press <
OK
>.
4. Press <
Yes
> twice to confirm the deletion.
Memory status
(Name 7)
Use this menu to check the total number of entries
you can store and the number of the entries you have
stored in Phonebook.
Menu functions
Text messages
(Menu 1)
27
Menu functions
All menu options listed
Text messages
(Menu 1)
Use the
Text messages
menu to send and receive
short messages. You can also use WAP push message,
Voice mail, and Cell broadcast message features.
To access this menu, press <
Menu
> in Idle mode and
select
Text messages
.
Short Message Service (SMS) allows you to send or
receive text messages including pictures, audio clips,
and animated images.
Inbox
(Menu 1.1)
You can view received text messages in this menu.
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Send
: forward the message.
•
Text reply
: reply to the sender.
•
Call
back
: call the sender.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Move to phone
: move the message from the SIM
card to the phone’s memory.
•
Move to SIM
: move the message from the
phone’s memory to the SIM card.
•
Select objects
: save images or sounds from the
message into your phone.
Outbox
(Menu 1.2)
You can view sent or saved text messages.
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Send
: forward the message.
The maximum number of characters allowed in a
short message varies by service provider. If your
message exceeds the maximum number of
characters, the phone will split the message.
28
Menu functions
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Move to phone
: move the message from the SIM
card to the phone’s memory.
•
Move to SIM
: move the message from the
phone’s memory to the SIM card.
•
Select objects
: save images or sounds from the
message into your phone.
Write new
(Menu 1.3)
You can create and send a text message.
1. Enter your message.
You can enter up to 918 standard characters, or
approximately 402 Unicode characters, such as ‘â’.
2. Press <
Options
> to access the following options:
•
Text formatting
: change the text attributes.
•
Add objects
: add a sound, melody, picture, or
animation to the message.
•
Add templates
: retrieve a text template.
•
Add from phonebook
: add a Phone book
entry.
•
Add from bookmark
: add a web page’s
address.
•
Language
: change the language used in T9
input mode.
3. Press <
Options
> and select
Save and send
or
Send only
.
4. If you select
Save and send
, select a memory
location.
5. Enter a destination number.
6. Press <
OK
>
to send the message.
Templates
(Menu 1.4)
You can preset the templates to write a text message.
While viewing the templates list, press <
Options
> to
access the following options:
•
Edit
: edit the template.
•
Send
: send the template as an SMS message.
•
Delete
: delete the template.
Menu functions
Text messages
(Menu 1)
29
Settings
(Menu 1.5)
Use this menu to customise the SMS settings.
•
Setting x
(where
x
is the setting group number):
each group has its own submenu.
Service centre
: store or changes the number of
your message centre.
Default destination
: store a default destination
number.
Default type
: set the default message type.
Default validity
: set the length of time your
messages are stored in the message centre while
the network attempts to deliver them.
Setting name
: change the name of the setting
group.
•
Common setting
: The following options are
available.
Reply path
: allow the recipient to reply to you
through your message centre.
Delivery reports
: set the network to inform you
when your message has been delivered.
Bearer selection
: select the
GSM
or
GPRS
preferred
bearer type.
Character support
: select a character encoding
type. If you select
Automatic
, the phone switches
the encoding type from GSM-alphabet to Unicode if
you enter a Unicode character. Use of Unicode
encoding will reduce the maximum number of
characters in a message to about half.
Delete all
(Menu 1.6)
Use this menu to delete all of the messages in each
message box.
1. Select a message type.
2. Press <
Mark
>to check the message box(es) to be
cleared.
3. Press <
Delete
>.
4. Press <
Yes
> twice to confirm the deletion.
Memory status
(Menu 1.7)
Use this menu to view the total number of messages
you can store and the number of messages you have
stored on the SIM card, in the phone’s memory, and in
the CB memory.
The setting options available in this menu may vary
depending on your service provider.
30
Menu functions
Voice mail
(Menu 1.8)
Use this menu to store the number of the voice mail
server and access your voice mails.
•
Connect to voice server
: connect to the voice
server to allow you to listen to your messages. You
can also connect to the voice mail server by
pressing and holding [
1
] in Idle mode.
•
Voice server number
: change the voice mail
server number.
Broadcast messages
(Menu 1.9)
The Cell Broadcast service delivers short messages on
various topics such as the weather or traffic.
Use this menu to change the settings for the service
and access broadcast messages.
•
Read
: open received messages.
The
Volatile
box saves network messages until
the phone is switched off.
The
Archive
box saves network messages
indefinitely. Press <
Options
> and select
Save
when a text notification appears. The message is
saved in the
Archive
box.
•
Receive
: enable or disable the reception of
broadcast messages.
•
Channel
list
: specify the channels from which you
receive broadcast messages.
•
Language
: select the language in which broadcast
messages display.
Please contact your service provider for details.
Multimedia messages
(Menu 2)
Multimedia Message Service (MMS) delivers messages
containing a combination of text, picture, and sound,
from phone to phone or from phone to e-mail.
Inbox
(Menu 2.1)
This menu displays MMS messages that you have
received. The following icons tell you the message
status:
• notification that you have read
You must enter the voice server number before you
can access your voice mails. Your service provider
can give the voice server number.
Menu functions
Multimedia messages
31
• notification that you have not read
• you are retrieving from the server
• the server is processing your request
• the server is failed to send
• you have read
• you have not read
While viewing a message, press <
Options
> to access
the following message options:
•
Delete
: delete the message.
•
Reply
: reply to the sender.
•
Callback
: call the sender.
•
Save
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Forward
: forward the message to another person.
•
Save picture
: save an image from the message
into the
Images
folder.
•
Save sound
: save a sound from the message into
the
Sounds
folder.
•
Properties
: view the message properties.
Outbox
(Menu 2.2)
This menu displays MMS messages that you have
sent. The following icons tell you the message status:
• currently being sent
• sent
• your phone couldn’t send
• to be sent
• deferred
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Send
: send or resends the message.
•
Edit message
: edit the message.
•
Properties
: view the message properties.
When you select a notification, you can access
Retrieve
to retrieve the message from the MMS
server.
32
Menu functions
Draft
(Menu 2.3)
After creating a multimedia message, you can store it
in this message box for sending later.
You can view a message and use the options the same
as in the Outbox.
Write new
(Menu 2.4)
You can create and send an MMS message.
1. Enter a message subject and press <
OK
>.
2. Press <
Options
> and add message contents using
one of the following options:
•
Add text
: add message text.
•
Add picture
: add pictures to the message.
•
Add sound
: add sounds to the message.
•
Send
: send the message.
•
Save
: save the message in the Draft or
Templates box.
•
Settings
: change the message settings.
•
Add destination
: enter destination numbers
or addresses.
•
Preview
: view the message you created.
3. If you want to change the added items, highlight
one and press <
Options
> to access the following
options:
•
Edit text
/
/
sound
: edit the text,
picture, or sound.
•
Add page
: add pages. Move to each page by
pressing the Left or Right key on the message
screen.
•
Delete
: delete the item from your message.
•
Duration
: set how long one page displays.
After the specified time, the display
automatically scrolls to the next page.
4. When you have finished, select
Send
from the
options.
5. Select a destination type (To, Cc, Bcc).
6. Select one of
Phone number
,
E-mail address
, or
Phone book
.
7. Enter a destination number or an e-mail address,
or select a number from Phone book.
8. To add more destinations, select
Add destination
and repeat from step 7.
Menu functions
Multimedia messages
33
9. To enter additional numbers or addresses to other
destination types, press and repeat steps 6
through 8.
10.When you have finished, select
Send message
.
Templates
(Menu 2.5)
This menu stores messages you saved as templates so
that you can use them to create new messages.
While viewing a message template, press <
Options
>
to access the following options:
•
Edit message
: send the message using the
template.
•
Delete
: delete the template.
Delete all
(Menu 2.6)
Use this menu to delete all of the messages in each
message box.
1. Select a message type.
2. Press <
Mark
>to check the message box(es) to be
cleared.
3. Press <
Delete
>.
4. Press <
Yes
> to confirm the deletion.
Memory status
(Menu 2.7)
Use this menu to view the total size of messages you
can store and the size of messages you have stored on
the phone’s memory.
Setup
(Menu 2.8)
You can customise the settings for sending and
receiving MMS messages.
•
Delivery report
: set the network to inform you
when your message has been delivered.
•
Read reply
: request a reply from the recipient.
•
Auto download
: set whether or not your phone
retrieves new incoming messages from the MMS
server without notifications.
•
Message acceptance
: select the category of
messages you want to receive.
•
Hide ID
: hide your phone number on the
recipient’s phone.
•
Expiry date
: set the length of time your messages
are stored in the message centre.
•
Delivery time
: set the time
delay before
messages are sent.
34
Menu functions
•
Priority
: set the priority level of your messages.
•
Report allowed
: send a delivery report from the
network to the sender.
•
Page duration
: set how long one page in your
outgoing messages displays. After a specified time,
the display automatically scrolls to the next page.
MMS profile
(Menu 2.9)
You can configure required network settings for MMS.
The last profile accessed is automatically activated for
sending or receiving subsequent messages.
•
Profile name
: assign a name to the MMS profile.
•
Connection URL
: enter the address of your MMS
server.
•
Security
: select a data transmission mode.
•
IP address
: enter the gateway address.
•
User name
: assign the user ID.
•
Password
: enter the password.
•
APN
: enter the access point name used for the
address of the MMS server.
Call records
(Menu 3)
Use this menu to view the calls you have dialled,
received, or missed, the length of your calls, and the
cost of your calls.
To access this menu, press <
Menu
> in Idle mode and
select
Call records
.
Missed calls
(Menu 3.1)
This menu displays the 20 most recently received calls
that you did not answer.
Received calls
(Menu 3.2)
This menu displays the 20 most recent calls you have
received.
Dialled calls
(Menu 3.3)
This menu displays the 20 most recent calls you have
dialled.
Check with your service provider before you change
any MMS settings on your phone.
Menu functions
Call records
(Menu 3)
35
Delete all
(Menu 3.4)
Use this menu to delete all of the records in each call
type.
1. Press <
Mark
> to check the call type(s) to be
cleared.
2. Press <
Delete
>.
3. Press <
Yes
> confirm the deletion.
Call time
(Menu 3.5)
This menu displays the time log for calls made and
received. The actual time invoiced by your service
provider will vary.
•
Last
call
time
: check the length of your last call.
•
Total
sent
: check the total length of all the calls
you have dialled.
•
Total
received
: check the total length of all the
calls you have received.
•
Reset
timers
: reset the call timers. You need to
enter the phone password.
Call cost
(Menu 3.6)
This network feature displays the cost of calls. This
menu is available only if your SIM card supports this
feature. Note that this is not intended to be used for
billing purposes.
•
Last
call
cost
: check the cost of your last call.
•
Total
cost
: check the total cost of all of your calls
since your last reset the cost counter. If the total
cost exceeds the maximum cost set in
Set
max
cost
, you must reset the counter before you can
make another call.
•
Max
cost
: check the maximum cost limit set in
Set
max
cost
.
•
Reset
counters
: reset the cost counters. You
need to enter your PIN2.
•
Set
max
cost
: set the maximum cost authorised
for your calls. You need to enter your PIN2.
•
Price/Unit
: set the price per unit that is applied
when the cost of your calls is calculated. You need
to enter your PIN2.
The password is preset to
00000000
. You can
change this password.
p. 39
36
Menu functions
Sound settings
(Menu 4)
Use this menu to customise various sound settings.
Ring tone
(Menu 4.1)
Use this menu to select a ring tone for the call ringer.
You can select one of the default ring melodies,
downloaded sounds.
Ring volume
(Menu 4.2)
Use this menu to adjust the ringer volume.
Alert type
(Menu 4.3)
Use this menu to specify how you are to be informed
of incoming calls.
•
Melody
: the phone rings using the selected ring
tone.
•
Vibration
: the phone vibrates but not rings.
•
Vibra+melody
: the phone vibrates three times
and then starts ringing.
Keypad tone
(Menu 4.4)
Use this menu to select the tone that the phone
sounds when you press a key.
Message tone
(Menu 4.5)
Use this menu to select a ring tone or alert type for
incoming messages.
•
SMS tone
: specify how you are informed of a new
SMS message.
•
SMS-CB tone
: specify how you are informed of a
new cell broadcast (CB) message.
•
MMS tone
: specify how you are informed of a new
MMS message.
Alert on call
(Menu 4.6)
Use this menu to select whether or not the phone
informs you when you receive a new message or when
the time for an alarm comes during a call.
You can adjust the keypad tone volume using
[/]
in Idle mode.
Menu functions
Phone settings
(Menu 5)
37
Folder tone
(Menu 4.7)
Use this menu to select the tone that the phone
sounds when you open or close the phone.
Power on/off
(Menu 4.8)
Use this menu to select the melody that the phone
sounds when it is switched on or off.
Extra tones
(Menu 4.9)
Use this menu to customise additional tones for the
phone.
•
Error tone
: set the phone to beep when you make
a mistake.
•
Minute
minder
: set the phone to beep every
minute during an outgoing call to keep you
informed of the length of your call.
•
Connect
tone
: set the phone to beep when it is
connected to the system.
Phone settings
(Menu 5)
Use this menu to customise your phone settings. You
can also reset the settings to their default values.
To access this menu, press <
Menu
> in Idle mode and
select
Phone settings
.
Display settings
(Menu 5.1)
Use this menu to change settings for the display and
light.
Wallpaper
(Menu 5.1.1)
You can change the background image and the
settings for the text of Idle mode.
•
Wallpaper list
: select a background image.
•
Text display
: determine the phone displays the
time and date.
•
Text color
: select a colour of the text
Menu style
(Menu 5.1.2)
You can select the menu display style.
38
Menu functions
Contrast
(Menu 5.1.3)
You can adjust the brightness of the display for
varying lighting conditions.
Back light
(Menu 5.1.4)
You can select the length of time the backlight and the
display stay.
Graphic logo
(Menu 5.1.5)
Use this menu to display your service provider’s logo
instead of its name.
Greeting message
(Menu 5.2)
Use this menu to enter the greeting that is displayed
briefly when the phone is switched on.
Own number
(Menu 5.3)
Use this feature to check your phone numbers, or to
assign a name to each of the numbers. Changes made
here do not affect the actual subscriber numbers on
your SIM card.
Language
(Menu 5.4)
Use this menu to select one of several languages for
the display text.
Security
(Menu 5.5)
Use this menu to protect the phone against
unauthorised use by managing the several access
codes of your phone and SIM card.
PIN check
(Menu 5.5.1)
The 4-to 8-digit PIN (Personal Identification Number)
protects your SIM card against unauthorised use.
When this feature is enabled, the phone requires your
PIN each time it is switched on.
Change PIN
(Menu 5.5.2)
Use this menu to change your PIN. The PIN Check
feature must be enabled to use this feature.
If you enter an incorrect PIN /PIN 2 three times in
succession, the SIM card is blocked. To unblock it
you need to enter your PUK/PUK2 (Personal
Unblocking Key). The codes are supplied by your
network operator.
Menu functions
Phone settings
(Menu 5)
39
Phone lock
(Menu 5.5.3)
The Phone lock feature locks the phone from
unauthorised use.
When this feature is enabled, you must enter a 4- to
8-digit phone password each time the phone is
switched on.
The password is preset to
00000000
. To change the
password, use the
Change password
menu.
Change password
(Menu 5.5.4)
Use this menu to change your phone password. The
password is preset to
00000000
.
Privacy
(Menu 5.5.5)
Use this menu to lock your media contents, including
MMS messages, voice memos, images, and sounds.
1. Press <
Mark
> to check the item(s) to be locked.
2. Press <
OK
> to lock the marked items.
3. Enter the phone password and press <
OK
>.
To access a locked item, you need to enter the phone
password.
SIM lock
(Menu 5.5.6)
The SIM lock feature allows your phone to work only
with the current SIM by assigning a SIM lock code. You
must enter the SIM lock code to use a different SIM
card.
FDN mode
(Menu 5.5.7)
If supported by your SIM card, Fixed Dialing Number
(FDN) mode restricts your outgoing calls to a limited
set of phone numbers. When this feature is enabled,
you can make calls only to phone numbers stored in
Phonebook. To use this feature, you must enter your
PIN2.
Change PIN2
(Menu 5.5.8)
If supported by your SIM card, the Change PIN2
feature changes your current PIN2.
Extra settings
(Menu 5.6)
You can turn the automatic redealing or answering
features on or off.
•
Auto redial
: make up to ten attempts to redeal a
phone number after an unsuccessful call.
40
Menu functions
•
Active folder
: answer an incoming call simply by
opening the phone.
•
Anykey
answer
: answer an incoming call by
pressing any key, except [ ] or <
Reject
>.
When this option is set to
Off
, you must press [ ]
or <
Accept
> to answer a call.
Reset settings
(Menu 5.7)
Use this menu to reset the phone to its default
settings.
Enter the 4- to 8-digit phone password and press
<
OK
>.
Organizer
(Menu 6)
The Organizer feature enables you to keep track of
your schedule and tasks, and to make a voice memo.
You can also set the time and date and use convenient
features, such as alarms, calculator, and currency
converter. To access this menu, press <
Menu
> in Idle
mode and select
Organizer
.
Alarm
(Menu 6.1)
Use this menu to set alarms to ring at a specific time.
Setting an alarm
1. Select the type of alarm.
2. Enter the time for the alarm to sound.
3. Select
AM
or
PM
in 12-hour time format.
4. If you selected
Morning call
in step 1, choose
Monday to friday
or
Monday to saturday
.
Stopping an alarm
When the alarm sounds, press <
Exit
> key.
To remove an alarm set, access it, press <
Options
>
and select
Remove alarm
.
To remove all alarm sets, select
Remove alarm
from
the
Alarm
menu.
Setting the alarm to ring even if the phone is off
From the Alarm screen, select
Autopower
→
Enable
.
If the phone is off when it is time for the alarm to ring,
the phone switches on and sounds the alarm.
The password is preset to
00000000
. You can
change this password.
p. 39
Your phone is preset to a 24-hour format. You
can change the time format.
p. 41
Menu functions
Organizer
(Menu 6)
41
Calendar
(Menu 6.2)
Use this menu to consult the calendar, write memos,
or set alarms to act as a reminder.
Writing a memo
1. Select a date on the calendar.
2. Enter your memo and press <
OK
>.
3. Press <
Yes
> to set an alarm to ring on the chosen
day.
Otherwise, press <
No
>.
4. Enter the time for the alarm.
To select an alarm melody, press <
Melody
>.
5. Select
AM
or
PM
in 12-hour format.
The colour of the date on the calendar changes to
green to indicate that a memo exists for that date.
Viewing a memo
On the calendar screen, press <
Options
> to access
the following options:
•
Search all
: view all of the memos you created.
•
Delete all
: delete all memos.
•
Go to date
: go to a specific date.
•
Exit
: exit the Calendar feature.
While viewing a memo, press <
Options
> to access
the following options:
•
Edit
: edit the memo.
•
Alarm
: set an alarm for the memo.
•
Delete
: delete the memo.
•
Copy to
: copy the memo to another date.
•
Move to
: change the date of the memo.
Time & Date
(Menu 6.3)
Use this menu to change the time and date displayed
on your phone. Before setting the time and date,
specify your time zone in
World time
.
Press
[/]
to move to the next or previous
month.
Your phone is set to a 24-hour format. You can
change the format.
p. 42
42
Menu functions
•
Set time
: enter the current time using the number
keys.
•
Set date
: enter the current date using the number
keys.
•
World time
: set your local time zone and find out
what time it is in another part of the world.
•
Time format
: select 12-hours or 24-hours time
format.
Calculator
(Menu 6.4)
Use this menu to perform basic arithmetic functions
such as addition, subtraction, multiplication, and
division.
1. Enter the first number.
Press the left soft key to insert a decimal point and
a bracket.
2. Press the Navigation keys to access the math
function you want.
3. Enter the second number.
4. Press [ ] to view the result.
To do list
(Menu 6.5)
Use this menu to create tasks and manage them.
Creating the To do list
1. Press <
New
>.
2. Enter the first task and press <
OK
>.
3. Select a priority level.
4. Enter your deadline and press <
OK
>.
Otherwise, press <
Skip
>.
Viewing the To do list
When you select the To do list menu, the tasks display
with a check mark, if the task has been done, and a
priority level indicator; for High, for Normal,
and for Low.
While viewing a task from the list or the details for the
task, press <
Options
> to access the following
options:
•
New
: add a new task.
•
Mark
: change the status of the task.
Press
[
] or [ ] to move the cursor.
To change the status of a specific task, press [
]
.
Menu functions
Organizer
(Menu 6)
43
•
Edit
: edit the task.
•
Sort
: sort the task by priority or status.
•
Copy
: copy the task.
•
Copy to calendar
: copy the task to the calendar
as a memo.
•
Delete
: delete the task.
•
Delete all
: delete all tasks.
•
Exit
: exit the
To do list
menu.
Voice memo
(Menu 6.6)
Use this menu to record voice memos. A voice memo
can be up to 30 seconds.
Record voice
(Menu 6.6.1)
1. Press <
Record
> to start recording.
2. Speak into the microphone.
3. When you press <
Stop
>, or if the recording time
expires, the following options display:
•
Replay
: play back your memo.
•
Re-record
: discard the memo and records
another one.
•
Save
: save the memo.
•
Quit
: cancel your recording and exits the
Record voice
menu.
4. Select
Save
to save the voice memo.
5. Enter a name of the voice memo and press <
OK
>.
Voice list
(Menu 6.6.2)
Use this menu to access the list of voice memos you
have recorded.
Press <
Options
> to access the following options:
•
Play
: play back your voice memo.
•
Send
: send the voice memo via MMS.
•
Rename
: change the name of the voice memo.
•
Properties
: view the properties of the voice
memo.
•
Delete
: delete the voice memo.
Delete all
(Menu 6.6.3)
Use this menu to delete all of the voice memos you
have recorded at one time.
44
Menu functions
Memory status
(Menu 6.6.4)
You can check the total amount of memory and the
amount of currently in use for voice memos.
Currency exchange
(Menu 6.7)
Use this menu to do currency conversions.
1. Enter the rate of foreign currency and press
<
OK
>.
2. Enter the amount of the source currency you want
to convert and press <
OK
>.
The amount you entered and its equivalent value
in the foreign currency display.
Network services
(Menu 7)
Use this menu to access network services. Please
contact your service provider to check their availability
and subscribe to them, if you wish.
To access this menu, press <
Menu
> in Idle mode and
select
Network services
.
Call diverting
(Menu 7.1)
This network service reroutes incoming calls to a
phone number that you specify.
1. Select a call diverting option:
•
Divert always
: divert all calls.
•
Busy
: diver calls when you are on another call.
•
No
reply
: divert calls when you do not answer
the phone.
•
Unreachable
: divert calls when you are not in
an area covered by your service provider or
when your phone is switched off.
•
Cancel
all
: cancel all call diverting options.
2. Select the type of calls to be diverted.
3. To activate call diverting, select
Activate
.
Otherwise, select
Remove
.
4. Enter the number to which calls are to be diverted
and press <
OK
>.
5. If you selected
No reply
, select the length of time
the network delays before diverting a call and
press <
Select
>.
Menu functions
Network services
(Menu
45
Call barring
(Menu 7.2)
This network service allows you to restrict your calls.
1. Select a call barring option:
•
All
outgoing
: prohibit all outgoing calls.
•
International
: prohibit international calls.
•
International
except
to
home
: only allows
calls to numbers within the current country
when you are abroad, and to your home
country, defined as where your home network
provider is located.
•
All
incoming
: prohibit incoming calls.
•
Incoming
while
abroad
: prohibit incoming
calls when you use your phone outside of your
home country.
•
Cancel
all
: cancel all call barring settings,
allowing calls to be sent and received normally.
•
Change barring password
: change the call
barring password obtained from your service
provider.
2. Select the type of calls to be barred.
3. Press <
Activate
>. To deactivate call barring,
press <
Deactivate
>.
4. Enter the call barring password supplied by your
service provider and press <
OK
>.
Call waiting
(Menu 7.3)
This network service informs you when someone is
trying to reach you while you are on another call.
1. Select the type of calls to which the call waiting
option will apply.
2. Press <
Activate
>. To deactivate call waiting,
press <
Deactivate
>.
Network selection
(Menu 7.4)
This network service allows you to either automatically
or manually select the network used when roaming
outside of your home area.
You can select a network other than your home
network only if there is a valid roaming agreement
between the two.
•
Automatic
: connect to the first available network
when roaming.
•
Manual
: select the network you want.
46
Menu functions
Caller ID
(Menu 7.5)
This network service allows you to prevent your phone
number from being displayed on the phone of the
person being called. However, some networks do not
allow the user to change this setting.
•
Default
: use the default setting provided by the
network.
•
Hide
number
: ensure your number does not
display on the other person’s phone.
•
Send
number
: send your number each time you
make a call.
Closed user group
(Menu 7.6)
Use this menu to set incoming and outgoing calls to be
restricted to a selected user group. For details about
how to create a closed user group, contact your
service provider.
•
Index list
: list, add, or delete CUG index
numbers. Press <
Options
> to access the options
for setting up an index list.
•
Outside access
: enable calls to numbers other
than those in the Closed user group. This feature
depends on the nature of your CUG subscription.
•
Default group
: enable the default CUG, if you
have set one with your service provider. When
making a call, you are given the option of using
your default CUG, instead of selecting one from the
list.
•
Deactivate
: deactivate the CUG function, if the
default group is enabled or a CUG index is
selected.
Funbox
(Menu 8)
The
Funbox
menu allows you to use the WAP browser,
play Java games, and access images and sounds
stored in the phone’s memory.
To access this menu, press <
Menu
> in Idle mode and
select
Funbox
.
WAP browser
(Menu 8.1)
The Wireless Application Protocol (WAP) browser on
your phone allows you to access the wireless web.
Menu functions
Funbox
(Menu 8)
47
Using the WAP browser, you can access updated
information and a wide variety of media content, such
as wallpapers and ring tones.
Home
(Menu 8.1.1)
Use this menu to connect your phone to the network
and load the homepage of the wireless web service
provider. You can also press [ ] in Idle mode.
Navigating with the WAP browser
Selecting and using browser menu options
1. Press <
Menu
> and select a menu.
2. Select one of the following browser options:
•
Reload
: reload the current page.
•
Home
: go back to the homepage.
•
Go to URL
: enter a URL address manually.
•
Show URL
: view the URL address of the
current web page.
•
Edit home
: change the URL address of
homepage .
•
Clear cache
: delete information stored in the
cache.
•
Inbox
: read messages received from a web
server.
Exiting the WAP browser
Press [ ] to exit the browser.
Favorite
(Menu 8.1.2)
Use this menu to save URL addresses to quickly access
a website.
Adding a bookmark
1. Select an empty location.
2. Enter a URL address and press <
Enter
>.
3. Enter a name for the bookmark and press
<
Enter
>.
To Press
scroll through browser items [Up] or [Down].
select a browser item [ ].
return to the previous page [
C
].
return to the homepage <
Menu
>
and
select
Home
.
48
Menu functions
Accessing a bookmarked page
Scroll to a bookmark item and press <
Select
> twice.
Using bookmark options
After saving an item, press <
Options
> to access the
following options:
•
Go
to URL
: access the website.
•
Edit
: edit the address and name of the bookmark.
•
Delete
: delete the bookmark.
http://
(Menu 8.1.3)
Use this menu to manually enter the URL address of a
website and access the website.
Settings
(Menu 8.1.4)
Use this menu to set up servers for the WAP browser.
Contact your service provider for details about your
settings options.
For each server, the following options are available:
•
Profile
name
: assign a name to the server profile.
•
Homepage
URL
: set the address of your
homepage.
•
Security
: select a data transmission mode.
•
Bearer
: select a bearer for each type of network
address accessed;
GPRS
or
Data
.
When the bearer is set to
GPRS
:
•
IP address
: enter the WAP gateway address.
•
User name
: enter the user ID.
•
Password
: enter the password.
•
APN
: enter the access point name of the GPRS
network gateway.
When the bearer is set to
Data
:
•
IP address
: enter the WAP gateway address.
•
Login name
: enter the User ID.
•
Password
: enter the password.
•
Dial-up number
: enter the PPP server phone
number.
•
Data call type
: select a data call type.
Clear cache
(Menu 8.1.5)
Menu functions
Funbox
(Menu 8)
49
Use this menu to clear the cache, which is the
temporary memory that stores the web pages you
have recently accessed.
Push message
(Menu 8.1.6)
Use this menu to access messages from the WAP
server.
•
Inbox
: display push messages you have received.
•
Receive
: determine whether or not your phone
receives push messages.
Never
: the phone rejects push messages.
Always
: the phone receives push messages from
the service centre set in this option.
•
Delete all
: delete all of push messages.
Games
(Menu 8.2)
You can download MIDlets (Java applications that run
on mobile phones) from various sources using the
WAP browser, and store them in your phone.
Launching a MIDlet
1. Select the MIDlet you want on the games list.
2. On the startup screen of the MIDlet, you can
access the following options:
•
START GAME
: start a new game.
•
CONTINUE
: continue the last game you
played.
•
HIGH SCORE
: view the high score table. This
option may not be available for some games.
•
HOW TO PLAY
: view how to play the game
and the key functions for the game.
•
OPTION
: switch on or off the game sound.
3. Press [ ] to confirm your selection.
Viewing MIDlet information
Scroll to the MIDlet you want and press <
Info
>.
DNS settings
You may need to change the DNS setting of the Java
server at your service provider’s instructions.
1. Select
Setting
on the Games list.
2. Enter the primary address and press <
OK
>.
3. Enter the secondary address and press <
OK
>.
Java services may not available, depending on your
service provider.
50
Menu functions
Sounds
(Menu 8.3)
This menu displays sounds downloaded from the
wireless web or received in messages.
While accessing a sound, press <
Options
> to access
the following options:
•
Rename
: change the name of the sound.
•
Delete
: delete the sound.
•
Set as ringtone
: set the sound as your ring tone.
Images
(Menu 8.4)
This menu displays images downloaded from the
wireless web or received in messages.
While accessing an image, press <
Options
> to access
the following options:
•
Rename
: change the name of the image.
•
Delete
: delete the image.
•
Set as wallpaper
: set the image as your
wallpaper for the idle screen.
Delete all
(Menu 8.5)
You can delete all of the downloaded items in the
Games
,
Sounds
, and
Images
folders.
1. Press <
Mark
> to check the folder(s) to be cleared.
2. Press <
Delete
>.
3. Press <
Yes
> to confirm the deletion.
Memory status
(Menu 8.6)
You can check the total amount of memory for media
items and the amount of memory currently in use in
each media box.
SIM AT
(Menu 9)
This menu is available if you use a SIM AT card that
provides additional services, such as news, weather,
sports, entertainment, and location services. Available
services may vary, depending on your service
provider’s plans.
For details, see your SIM card instructions or contact
your service provider.
Solve problems
51
Solve problems
To save the time and expense of an unnecessary service
call, perform the simple checks in this section before
contacting a service professional.
When you switch on your phone, the following
messages may appear:
“Insert SIM card”
• Be sure that the SIM card is correctly installed.
“Phone locked enter password”
• The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
“Enter PIN”
• You are using your phone for the first time. You
must enter the PIN supplied with the SIM card.
• The PIN Check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the
PIN check
menu.
“Enter PUK”
• The PIN code has been entered incorrectly three
times in succession, and the phone is now blocked.
Enter the PUK supplied by your service provider.
“No Service,” “Network Failure,” or “Not
Done” displays
• The network connection has been lost. You may be
in a weak signal area. Move and try again.
• You are trying to access an option for which you
have no subscription with your service provider.
Contact the service provider for further details.
You have entered a number but it was not
dialled
• Be sure that you have pressed [ ].
• Be sure you have accessed the right cellular
network.
• Be sure that you have not set an outgoing call
barring option.
52
Solve problems
Your correspondent cannot reach you
• Be sure your phone is switched on. ([ ] pressed
for more than one second.)
• Be sure you are accessing the correct cellular
network.
• Be sure that you have not set an outgoing call
barring option.
Your correspondent cannot hear you speaking
• Be sure you have switched off the microphone.
• Be sure you are holding the phone close enough to
your mouth. The microphone is located at the
bottom of the phone.
The phone starts beeping and “Battery low”
flashes on the display
• Your battery is insufficiently charged. Recharge the
battery.
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ). The number of bars indicates the signal
strength from strong ( ) to weak ( ).
• Try moving the phone slightly or moving closer to a
window if you are in a building.
No number is dialled when you re-call a
Contacts entry
• Use the Phonebook Search feature to ensure the
number has been stored correctly.
• Re-store the number, if necessary.
If the above guidelines do not help you to
solve the problem, take note of:
• The model and serial numbers of your phone
• Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung after-sales
service.
Health and safety information
53
Health and safety information
Exposure to Radio Frequency
(RF) Signals
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S.
Government. These limits are part of
comprehensive guidelines and establish
permitted levels of RF energy for the general
population. The guidelines are based on the
safety standards that were developed by
independent scientific organizations through
periodic and through evaluation of scientific
studies.
The standards include a substantial safety margin
designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless phones
employs a unit of measurement known as
Specific Absorption Rate (SAR). The SAR limit set
by the FCC is 1.6W/kg
*
.
*In the U.S. and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg)
averaged over one gram of tissue. The standard
incorporates a substantial margin of safety to give
additional protection for the public and to account for any
variations in measurements.
54
Health and safety
SAR tests are conducted using standard operating
positions specified by the FCC with the phone
transmitting at its highest certified power level in
all tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can
be well below the maximum value. This is because
the phone is designed to operate at multiple power
levels so as to use only the power required to reach
the network. In general, the closer you are to a
wireless base station antenna, the lower the power
output of the phone. Before a new model phone is
available for sale to the public, it must be tested
and certified to the FCC that it does not exceed the
limit established by the government-adopted
requirement for safe exposure. The tests are
performed in positions and locations (e.g., at the
ear and worn on the body) as required by the FCC
for each model. While there may be differences
between the SAR levels of various phones and at
various positions, they all meet the government
requirement.
The FCC has granted an Equipment Authorization
for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF
exposure guidelines. SAR information on this
model phone is on file with the FCC and can be
found under the Display Grant section of http://
www.fcc.gov/oet/fccid after searching on FCC ID
printed in the label on the phone.
FCC certification information for this model phone
is attached separation paper.
For Body Operation
To maintain compliance with FCC RF exposure require-
ments, use only belt-clips, holsters or similar accessories
that maintain a 1.5 cm. separation distance between
the user's body and the back of the phone, including
the antenna. The use of belt-clips, holsters and similar
accessories should not contain metallic components in
its assembly. The use of accessories that do not satisfy
Health and safety information
55
these requirements may not comply with FCC RF
exposure requirements, and should be avoided.
Non-compliance with the above onditions may
violate FCC RF exposure guidelines.
For more Information concerning exposure to radio
frequency signals, see the following websites:
Federal Communications Commission (FCC)
http://www.fcc.gov/rfsafety
Cellular Telecommunications Industry Association
(CTIA):
http://www.wow-com.com
U.S.Food and Drug Administration (FDA)
http://www.fda.gov/cdrh/consumer
World Health Organization (WHO)
http://www.who.int/peh-emf/en
Precautions When Using Batteries
• Never use any charger or battery that is
damaged in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and
charger used. The battery can be charged and
discharged hundreds of times, but it will
gradually wear out. When the operation time
(talk time and standby time) is noticeably
shorter than normal, it is time to buy a new
battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
disconnect it from the power source. Do not
56
Health and safety
leave the battery connected to a charger for
more than a week, since overcharging may
shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling
or warming first.
• Do not leave the battery in hot or cold places,
such as in a car in summer or winter conditions,
as you will reduce the capacity and lifetime of
the battery. Always try to keep the battery at
room temperature. A phone with a hot or cold
battery may temporarily not work, even when
the battery is fully charged. Li-ion batteries are
particularly affected by temperatures below 0
°ýC (32 °ýF).
• Do not short-circuit the battery. Accidental
shortcircuiting can occur when a metallic object
(coin, clip or pen) causes a direct connection
between the + and . terminals of the battery
(metal strips on the battery), for example when
you carry a spare battery in a pocket or bag.
Short-circuiting the terminals may damage the
battery or the object causing the short-circuiting.
• Dispose of used batteries in accordance with
local regulations. Always recycle. Do not dispose
of batteries in a fire.
Road Safety
Your wireless phone gives you the powerful ability
to communicate by voice, almost anywhere,
anytime. But an important responsibility
accompanies the benefits of wireless phones, one
that every user must uphold.
When driving a car, driving is your first
responsibility. When using your wireless phone
behind the wheel of a car, practice good common
sense and remember the following tips.
Health and safety information
57
1. Get to know your wireless phone and its
features, such as speed dial and redial. If
available, these features help you to place your
call without taking your attention off the road.
2. When available, use a hands-free device. If
possible, add an extra layer of convenience and
safety to your wireless phone with one of the
many hands-free accessories available today.
3. Position your wireless phone within easy reach.
Be able to access your wireless phone without
removing your eyes from the road. If you get
an incoming call at an inconvenient time, let
your voice mail answer it for you.
4. Let the person you are speaking with know you
are driving; if necessary, suspend the call in
heavy traffic or hazardous weather conditions.
Rain, sleet, snow, ice and even heavy traffic can
be hazardous.
5. Do not take notes or look up phone numbers
while driving. Jotting down a To Do list or
flipping through your phonebook takes your
attention away from your primary
responsibility, driving safely.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your
car will be stationary. If you need to make a call
while moving, dial only a few numbers, check
the road and your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make the
people with whom you are talking aware that
you are driving and suspend conversations that
have the potential to divert your attention from
the road.
58
Health and safety
8. Use your wireless phone to call for help. Dial
the emergency number in the case of fire,
traffic accident or medical emergencies.
Remember, it is a free call on your wireless
phone!
9. Use your wireless phone to help others in
emergencies. If you see a car accident, crime in
progress or other serious emergency where
lives are in danger, call the emergency number,
as you would want others to do for you.
10.Call roadside assistance or a special
nonemergency wireless assistance number
when necessary. If you see a broken-down
vehicle posing no serious hazard, a broken
traffic signal, a minor traffic accident where no
one appears injured, or a vehicle you know to
be stolen, call roadside assistance or any other
special nonemergency wireless number.
Operating Environment
Remember to follow any special regulations in
force in any area and always switch off your phone
whenever it is forbidden to use it, or when it may
cause interference or danger.
When connecting the phone or any accessory to
another device, read its user’s guide for detailed
safety instructions. Do not connect incompatible
products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory
operation of the equipment and for the safety of
personnel, it is recommended that the equipment
should only be used in the normal operating
position (held to your ear with the antenna
pointing over your shoulder).
Health and safety information
SIM AT
59
Electronic Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against
the RF signals from your wireless phone. Consult
the manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent
with the independent research and
recommendations of Wireless Technology
Research.
Persons with pacemakers:
• Should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone
is switched on
• Should not carry the phone in a breast pocket
• Should use the ear opposite the pacemaker to
minimize potential interference
If you have any reason to suspect that interference
is taking place, switch off your phone immediately.
Hearing Aids
Some digital wireless phones may interfere with
some hearing aids. In the event of such
interference, you may wish to consult your hearing
aid manufacturer to discuss alternatives. Other
Medical Devices If you use any other personal
medical devices, consult the manufacturer of your
device to determine if it is adequately shielded
from external RF energy. Your physician may be
able to assist you in obtaining this information.
Switch off your phone in health care facilities when
any regulations posted in these areas instruct you
to do so. Hospitals or health care facilities may be
using equipment that could be sensitive to external
RF energy.
60
Health and safety
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should
also consult the manufacturer of any equipment
that has been added to your vehicle.
Posted Facilities
Switch off your phone in any facility where posted
notices require you to do so.
Potentially Explosive Atmospheres
Switch off your phone when in any area with a
potentially explosive atmosphere and obey all
signs and instructions. Sparks in such areas could
cause an explosion or fire resulting in bodily injury
or even death. Users are advised to switch off the
phone while at a refueling point (service station).
Users are reminded of the need to observe
restrictions on the use of radio equipment in fuel
depots (fuel storage and distribution areas),
chemical plants or where blasting operations are in
progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas
(such as propane or butane), areas where the air
contains chemicals or particles, such as grain, dust
or metal powders, and any other area where you
would normally be advised to turn off your vehicle
engine.
Emergency calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks, as
well as user-programmed functions, which cannot
guarantee connection in all conditions. Therefore,
Health and safety information
SIM AT
61
you should never rely solely on any wireless phone
for essential communications (medical
emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not
be possible on all wireless phone networks or when
certain network services and/or phone features are
in use. Check with local service providers.
To make an emergency call, proceed as follows.
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 112 or any other official
emergency number). Emergency numbers vary
by location.
3. Press the key.
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular
service provider.
When making an emergency call, remember to
give all the necessary information as accurately as
possible. Remember that your phone may be the
only means of communication at the scene of an
accident; do not end the call until given permission
to do so.
Other important safety information
• Only qualified personnel should service the
phone or install the phone in a vehicle. Faulty
installation or service may be dangerous and
may invalidate any warranty applicable to the
device.
62
Health and safety
• Check regularly that all wireless phone
equipment in your vehicle is mounted and
operating properly.
• Do not store or carry flammable liquids, gases,
or explosive materials in the same compartment
as the phone, its parts, or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag
or in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
• Switch off your phone before boarding an
aircraft. The use of wireless phones in aircraft
may be dangerous to the operation of the
aircraft, and is illegal.
• Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
Care and maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children.
• Keep the phone dry. Precipitation, humidity, and
liquids contain minerals that will corrode
electronic circuits.
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage to
the phone.
• Do not use or store the phone in dusty, dirty
areas, as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
Health and safety information
SIM AT
63
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the
phone, which may damage the phone’s
electronic circuit boards.
• Do not drop, knock, or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents,
or strong detergents to clean the phone. Wipe it
with a soft cloth slightly dampened in a mild
soap-and-water solution.
• Do not paint the phone. Paint can clog the
device’s moving parts and prevent proper
operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove, or a radiator.
The phone may explode when overheated.
• Use only the supplied or an approved
replacement antenna. Unauthorised antennas or
modified accessories may damage the phone
and violate regulations governing radio devices.
• If the phone, battery, charger, or any accessory
is not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
Acknowledging Special Precautions and
the FCC and Industry Canada Notice
Cautions
Modifications not expressly approved by the party
responsible for compliance could void the user's
authority to operate the equipment.
FCC Compliance Information
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful
interference, and
64
Health and safety
2. This device must accept any interference
received.
Including interference that may cause undesired
operation.
Information to User
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/ TV
technician for help.
Appendix A: CERTIFICATION
INFORMATION (SAR)
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO
WAVES.
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radio
frequency(RF) energy set by the Federal
Health and safety information
SIM AT
65
Communications Commission of the U.S.
Government. These limits are part of
comprehensive guidelines and establish permitted
levels of RF energy for the general population. The
guidelines are based on safety standards that were
developed by independent scientific organizations
through periodic and thorough evaluation of
scientific studies. The standards include a
substantial safety margin designed to assure the
safety of all persons, regardless of age and health.
The exposure standard for wireless mobile phones
employs a unit of measurement known as the
Specific Absorption Rate(SAR). The SAR limit set
by the FCC is 1.6 W/kg. SAR Tests are conducted
using standard operating positions accepted by the
FCC with the phone transmitting at its highest
certified power level in all tested frequency bands.
Although the SAR is determined at the highest
certified power level, the actual SAR level of the
phone while operating can be well below the
maximum value. This is because the phone is
designed to operate at multiple power levels so as
to use only the power required to reach the
network. In general, the closer you are to a
wireless base station antenna, the lower the power
output.
Before a new model phone is available for sale to
the public, it must be tested and certified to the
FCC that it does not exceed the limit established by
the governmentadopted requirement for safe
exposure. The tests are performed in positions and
locations(e.g., at the ear and worn on the body) as
required by the FCC for each model.
The highest SAR values for this model phone as
reported to the FCC are Head: 0.888W/Kg (850)
0.582W/Kg (1900), Body worn: 0.418W/Kg(850),
0.188 W/Kg (1900).
66
Health and safety
The FCC has granted an Equipment Authorization
for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF exposure
guidelines. SAR information on this model phone
is on file with the FCC and can be found under the
Display Grant section of http://www.fcc.gov/oet/fccid
after searching on FCC ID A3LSGHX466.
Appendix B: Guide to Safe and Responsible
Wireless Phone Use
Cellular Telecommunications & Internet Association
“Safety is the most important call you will ever make.”
A Guide to Safe and Responsible Wireless
Phone Use
TENS OF MILLIONS OF PEOPLE IN THE U.S. TODAY
TAKE ADVANTAGE OF THE UNIQUE COMBINATION OF
CONVENIENCE, SAFETY AND VALUE DELIVERED BY
THE WIRELESS TELEPHONE. QUITE SIMPLY, THE
WIRELESS PHONE GIVES PEOPLE THE POWERFUL
ABILITY TO COMMUNICATE BY VOICE-ALMOST
ANYWHERE, ANYTIME-WITH THE BOSS, WITH A
CLIENT, WITH THE KIDS, WITH EMERGENCY
PERSONNEL OR EVEN WITH THE POLICE. EACH YEAR,
AMERICANS MAKE BILLIONS OF CALLS FROM THEIR
WIRELESS PHONES, AND THE NUMBERS ARE RAPIDLY
GROWING.
But an important responsibility accompanies those
benefits, one that every wireless phone user must
uphold. When driving a car, driving is your first
responsibility. A wireless phone can be an invaluable
tool, but good judgment must be exercised at all times
while driving a motor vehicle whether on the phone or
not.
The basic lessons are ones we all learned as
teenagers. Driving requires alertness, caution and
courtesy. It requires a heavy dose of basic common
Health and safety information
SIM AT
67
sense-keep your head up, keep your eyes on the road,
check your mirrors frequently and watch out for other
drivers. It requires obeying all traffic signs and signals
and staying within the speed limit. It means using seat
belts and requiring other passengers to do the same.
But with wireless phone use, driving safely means a
little more. This brochure is a call to wireless phone
users everywhere to make safety their first priority
when behind the wheel of a car. Wireless
telecommunications is keeping us in touch, simplifying
our lives, protecting us in emergencies and providing
opportunities to help others in need. When it comes to
the use of wireless phones, safety is your most
important call.
Wireless Phone “Safety Tips”
Below are safety tips to follow while driving and using
a wireless phone which should be easy to remember:
1. Get to know your wireless phone and its
features such as speed dial and redial. Carefully
read your instruction manual and learn to take
advantage of valuable features most phones
offer, including automatic redial and memory.
Also, work to memorize the phone keypad so
you can use the speed dial function without
taking your attention off the road.
2. When available, use a hands free device. A
number of hands free wireless phone
accessories are readily available today. Whether
you choose an installed mounted device for
your wireless phone or a speaker phone
accessory, take advantage of these devices if
available to you.
3. Position your wireless phone within easy reach.
Make sure you place your wireless phone within
easy reach and where you can grab it without
removing your eyes from the road. If you get
an incoming call at an inconvenient time, if
possible, let your voice mail answer it for you.
4. Suspend conversations during hazardous
driving conditions or situations. Let the person
68
Health and safety
you are speaking with know you are driving; if
necessary, suspend the call in heavy traffic or
hazardous weather conditions. Rain, sleet,
snow and ice can be hazardous, but so is heavy
traffic. As a driver, your first responsibility is to
pay attention to the road.
5. Do not take notes or look up phone numbers
while driving. If you are reading an address
book or business card, or writing a “to do” list
while driving a car, you are not watching where
you are going. It’s common sense. Don’t get
caught in a dangerous situation because you
are reading or writing and not paying attention
to the road or nearby vehicles.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan your calls before
you begin your trip or attempt to coincide your
calls with times you may be stopped at a stop
sign, red light or otherwise stationary. But if
you need to dial while driving, follow this simple
tip-dial only a few numbers, check the road and
your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Stressful
or emotional conversations and driving do not
mix-they are distracting and even dangerous
when you are behind the wheel of a car. Make
people you are talking with aware you are
driving and if necessary, suspend conversations
which have the potential to divert your
attention from the road.
8. Use your wireless phone to call for help. Your
wireless phone is one of the greatest tools you
can own to protect yourself and your family in
dangerous situations-with your phone at your
side, help is only three numbers away. Dial 9-1-
1 or other local emergency number in the case
of fire, traffic accident, road hazard or medical
emergency. Remember, it is a free call on your
wireless phone!
Health and safety information
SIM AT
69
9. Use your wireless phone to help others in
emergencies. Your wireless phone provides you
a perfect opportunity to be a “Good Samaritan”
in your community. If you see an auto accident,
crime in progress or other serious emergency
where lives are in danger, call 9-1-1 or other
local emergency number, as you would want
others to do for you.
10.Call roadside assistance or a special wireless
non emergency assistance number when
necessary. Certain situations you encounter
while driving may require attention, but are not
urgent enough to merit a call for emergency
services. But you still can use your wireless
phone to lend a hand. If you see a broken-down
vehicle posing no serious hazard, a broken
traffic signal, a minor traffic accident where no
one appears injured or a vehicle you know to be
stolen, call roadside assistance or other special
non-emergency wireless number.
Careless, distracted individuals and people driving
irresponsibly represent a hazard to everyone on the
road. Since 1984, the Cellular Telecommunications
Industry Association and the wireless industry have
conducted educational outreach to inform wireless
phone users of their responsibilities as safe drivers
and good citizens. As we approach a new century,
more and more of us will take advantage of the
benefits of wireless telephones. And, as we take to the
roads, we all have a responsibility to drive safely.
“The wireless industry reminds you to use your phone
safely when driving.”
Cellular Telecommunications & Internet Association
For more information, please call 1-888-901-SAFE.
For updates: http://www.wow-com.com/consumer/
issues/driving/articles.cfm?ID =85
70
Health and safety
Appendix C: Consumer Update on Wireless
Phones
U.S. Food and Drug Administration
1. What kinds of phones are the subject of this
update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called
cell, mobile, or PCS phones. These types of wireless
phones can expose the user to measurable radio
frequency energy (RF) because of the short distance
between the phone and the user s head. These RF
exposures are limited by Federal Communications
Commission safety guidelines that were developed
with the advice of FDA and other federal health and
safety agencies. When the phone is located at greater
distances from the user, the exposure to RF is
drastically lower because a person’s RF exposure
decreases rapidly with increasing distance from the
source. The so-called “cordless phones,” which have a
base unit connected to the telephone wiring in a
house, typically operate at far lower power levels, and
thus produce RF exposures well within the FCC’s
compliance limits.
2. Do wireless phones pose a health hazard?
The available scientific evidence does not show that
any health problems are associated with using
wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless phones
emit low levels of radio frequency energy (RF) in the
microwave range while being used. They also emit
very low levels of RF when in the stand-by mode.
Whereas high levels of RF can produce health effects
(by heating tissue), exposure to low level RF that does
not produce heating effects causes no known adverse
health effects. Many studies of low level RF exposures
have not found any biological effects. Some studies
have suggested that some biological effects may
occur, but such findings have not been confirmed by
additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
Health and safety information
SIM AT
71
3. What is FDA’s role concerning the safety of wireless
phones?
Under the law, FDA does not review the safety of
radiation emitting consumer products such as wireless
phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown
to emit radio frequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could
require the manufacturers of wireless phones to notify
users of the health hazard and to repair, replace or
recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
• Support needed research into possible biological
effects of RF of the type emitted by wireless
phones;
• Design wireless phones in a way that minimizes
any RF exposure to the user that is not
necessary for device function; and
• Cooperate in providing users of wireless phones
with the best possible information on possible
effects of wireless phone use on human health
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at
the federal level. The following agencies belong to this
working group:
• National Institute for Occupational Safety and
Health
• Environmental Protection Agency Federal
Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information
Administration
• The National Institutes of Health participates in
some interagency working group activities, as
well.
72
Health and safety
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission
(FCC). All phones that are sold in the United States
must comply with FCC safety guidelines that limit RF
exposure. FCC relies on FDA and other health agencies
for safety questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from
these base stations are typically thousands of times
lower than those they can get from wireless phones.
Base stations are thus not the primary subject of the
safety questions discussed in this document.
4. What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization International Electromagnetic Fields
(EMF) Project since its inception in 1996. An influential
result of this work has been the development of a
detailed agenda of research needs that has driven the
establishment of new research programs around the
world. The Project has also helped develop a series of
public information documents on EMF issues.
FDA and the Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative
Research and Development Agreement (CRADA) to do
research on wireless phone safety. FDA provides the
scientific oversight, obtaining input from experts in
government, industry, and academic organizations.
CTIA-funded research is conducted through contracts
to independent investigators. The initial research will
include both laboratory studies and studies of wireless
phone users. The CRADA will also include a broad
assessment of additional research needs in the
context of the latest research developments around
the world.
Health and safety information
SIM AT
73
5. What steps can I take to reduce my exposure to
radio frequency energy from my wireless phone?
If there is a risk from these products—and at this point
we do not know that there is—it is probably very
small. But if you are concerned about avoiding even
potential risks, you can take a few simple steps to
minimize your exposure to radio frequency energy
(RF). Since time is a key factor in how much exposure
a person receives, reducing the amount of time spent
using a wireless phone will reduce RF exposure.
If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of the RF,
since the exposure level drops off dramatically with
distance. For example, you could use a headset and
carry the wireless phone away from your body or use a
wireless phone connected to a remote antenna
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are concerned
about the RF exposure from these products, you can
use measures like those described above to reduce
your RF exposure from wireless phone use.
6. What about children using wireless phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower exposure
to radio frequency energy (RF), the measures
described above would apply to children and
teenagers using wireless phones. Reducing the time of
wireless phone use and increasing the distance
between the user and the RF source will reduce RF
exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at all. For
example, the government in the United Kingdom
distributed leaflets containing such a recommendation
in December 2000. They noted that no evidence exists
that using a wireless phone causes brain tumors or
other ill effects. Their recommendation to limit
wireless phone use by children was strictly
precautionary; it was not based on scientific evidence
that any health hazard exists.
74
Health and safety
7. Do hands-free kits for wireless phones reduce risks
from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free
kits can be used with wireless phones for convenience
and comfort. These systems reduce the absorption of
RF energy in the head because the phone, which is the
source of the RF emissions, will not be placed against
the head. On the other hand, if the phone is mounted
against the waist or other part of the body during use,
then that part of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are required to
meet safety requirements regardless of whether they
are used against the head or against the body. Either
configuration should result in compliance with the
safety limit.
8. Do wireless phone accessories that claim to shield
the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head
from those emissions reduce risks. Some products
that claim to shield the user from RF absorption use
special phone cases, while others involve nothing
more than a metallic accessory attached to the phone.
Studies have shown that these products generally do
not work as advertised. Unlike “hand-free” kits, these
so-called “shields” may interfere with proper operation
of the phone. The phone may be forced to boost its
power to compensate, leading to an increase in RF
absorption. In February 2002, the Federal trade
Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users
from radiation with making false and unsubstantiated
claims. According to FTC, these defendants lacked a
reasonable basis to substantiate their claim.
9. What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason,
FDA helped develop a detailed test method to measure
Health and safety information
SIM AT
75
electromagnetic interference (EMI) of implanted
cardiac pacemakers and defibrillators from wireless
telephones. This test method is now part of a standard
sponsored by the Association for the Advancement of
Medical instrumentation (AAMI). The final draft, a joint
effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This
standard will allow manufacturers to ensure that
cardiac pacemakers and defibrillators are safe from
wireless phone EMI.
FDA has tested hearing aids for interference from
handheld wireless phones and helped develop a
voluntary standard sponsored by the Institute of
Electrical and Electronic Engineers (IEEE). This
standard specifies test methods and performance
requirements for hearing aids and wireless phones so
that no interference occurs when a person uses a
compatible phone and a compatible hearing aid at the
same time. This standard was approved by the IEEE in
2000.
FDA continues to monitor the use of wireless phones
for possible interactions with other medical devices.
Should harmful interference be found to occur, FDA
will conduct testing to assess the interference and
work to resolve the problem.
10.What are the results of the research done already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in
their research methods. Animal experiments
investigating the effects of radio frequency energy
(RF) exposures characteristic of wireless phones have
yielded conflicting results that often cannot be
repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could
accelerate the development of cancer in laboratory
animals. However, many of the studies that showed
increased tumor development used animals that had
been genetically engineered or treated with cancer
causing chemicals so as to be pre-disposed to develop
cancer in the absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day.
These conditions are not similar to the conditions
under which people use wireless phones, so we don t
76
Health and safety
know with certainty what the results of such studies
mean for human health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use
of wireless phones and primary brain cancer, gioma,
meningioma, or acoustic neuroma, tumors of the brain
or salivary gland, leukemia, or other cancers. None of
the studies demonstrated the existence of any harmful
health effects from wireless phone RF exposures.
However, none of the studies can answer questions
about long-term exposures, since the average period
of phone use in these studies was around three years.
11.What research is needed to decide whether RF
exposure from wireless phones poses a health
risk?
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data that
are needed. Lifetime animal exposure studies could be
completed in a few years. However, very large
numbers of animals would be needed to provide
reliable proof of a cancer promoting effect if one
exists. Epidemiological studies can provide data that is
directly applicable to human populations, but 10 or
more years follow-up may be needed to provide
answers about some health effects, such as cancer.
This is because the interval between the time of
exposure to a cancer-causing agent and the time
tumors develop - if they do - may be many, many
years. The interpretation of epidemiological studies is
hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones.
Many factors affect this measurement, such as the
angle at which the phone is held, or which model of
phone is used.
12.Which other federal agencies have responsibilities
related to potential RF health effects?
Additional information on the safety of RF exposures
from various sources can be obtained from the
following organizations.
FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
Health and safety information
SIM AT
77
Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
Occupational Safety and Health Administration’s
(OSHA):
http://www.osha-slc.gov/SLTC/
radiofrequencyradiation/index.html
National Institute for Occupational Safety and Health
(NIOSH):
http://www.cdc.gov/niosh/emfpg.html
World health Organization (WHO):
http://www.who.int/peh-emf/
International Commission on Non-Ionizing Radiation
Protection:
http://www.icnirp.de
National Radiation Protection Board (UK):
http://www.nrpb.org.uk
*
*Updated 4/3/2002: US Food and Drug Administration
http://www.fda.gov/cellphones
78
Index
Index
A
ABC mode, text input • 17
Alarm • 40
Alert 36
Answering
call • 20
second call • 22
Anykey answer • 40
Auto redial • 39
B
Backlight time, set • 38
Barring, calls • 45
Battery
charging • 7
low indicator • 8
precautions • 54
Broadcast messages • 30
Browser, WAP • 46
C
Calculator • 42
Call 34
Call costs • 35
Call records
dialled • 34
missed • 34
received • 34
Call time • 35
Caller ID • 46
Calls answering • 20
barring • 45
emergency • 60
holding • 21
redialling • 19
rejecting • 20
waiting • 45
Care • 62
CB (Cell Broadcast) messages •
30
Characters, enter • 17
Closed 46
Connection tone • 37
D
Delete 35
Deleting
call records • 35
Delivery reports, message • 33
Dialled calls • 34
Display
settings • 37
DTMF tones, send • 22
E
Emergency calls • 60
F
FDN (Fixed Dial Number) mode
• 39
Funbox 46
G
Greeting message • 38
H
Holding, call • 21
I
Icons, description • 10
Images, downloaded • 50
International calls • 19
K
Keypad 36
Keypad tones
sending • 22
L
Language, select • 38
Last number, redial • 19
Locking
phone • 39
SIM card • 39
Low battery indicator • 8
M
Maintenance • 62
Memory status
downloaded items • 50
SMS message • 29
Message tone • 36
Messages
cell broadcast • 30
SMS • 27
voice • 30
Minute minder • 37
Missed calls • 34
MMS messages
creating/sending • 30
deleting • 31
setup • 33
viewing • 30, 31
Multi-party calls • 22
Muting
key tones • 22
microphone • 21
N
Names
entering • 17
searching • 24
79
Index
Network services • 44
O
Organizer • 40
Outbox, messages
MMS • 31
SMS • 27
Own number • 38
P
Password
call barring • 45
phone • 39
Phonedisplay • 10
icons • 10
locking • 39
switching on/off • 8
unpacking • 6
Phonebook
copying • 24
editing • 24
options • 24
speed-dialling • 25
PIN, change • 38
PIN2, change • 39
Power 37
Privacy • 39
R
Received calls • 34
Recording
voice memos • 43
Redialling
automatically • 39
manually • 19
Resetting phone • 40
S
Safety
information • 61
Security, calls • 38
Sent messages
MMS • 31
SMS • 27
SIM card
inserting • 7
locking • 39
SMS messages
creating/sending • 32
viewing • 27
Sound 36
Sound settings • 36
Sounds, downloaded • 50
Speed-dial • 25
Switching 21
Switching on/off
microphone • 21
phone • 8
T
Templates
MMS • 33
Text input mode, change • 17
Text, enter • 17
Tone alert on call • 36
alert type • 36
connect • 37
extra tones • 37
folder tone • 37
keypad • 36
message • 36
minute minder • 37
power on/off • 37
ring volume • 36
ringtone • 36
V
Voice mail • 30
Voice memos
recording • 43
Voicemail server • 30
W
Waiting call • 45
WAP browser
access • 46
cache, clear • 48
favorite • 47
World time • 42
