Users Manual

SGH-X520

User’s Guide

Important

safety

precautions

Failure to comply with the following

precautions may be dangerous or

illegal.

Drive safely at all times

Do not use a hand-held phone while driving.

Park the vehicle first.

Switch off the phone when refuelling

Do not use the phone at a refuelling point

(service station) or near fuels or chemicals.

Switch off in an aircraft

Wireless phones can cause interference. Using

them in an aircraft is both illegal and

dangerous.

Switch off the phone near all medical

equipment

Hospitals or health care facilities may be using

equipment that could be sensitive to external

radio frequency energy. Follow any regulations

or rules in force.

Interference

All wireless phones may be subject to

interference, which could affect their

performance.

Important safety precautions

Be aware of special regulations

Meet any special regulations in force in any

area and always switch off your phone

whenever it is forbidden to use it, or when it

may cause interference or danger.

Water resistance

Your phone is not water-resistant. Keep it

dry.

Sensible use

Use only in the normal position (held to the

ear). Avoid unnecessary contact with the

antenna when the phone is switched on.

Emergency calls

Key in the emergency number for your

present location, then press .

Keep your phone away from small

children

Keep the phone and all its parts, including

accessories, out of the reach of small

children.

Accessories and batteries

Use only Samsung-approved batteries and

accessories such as headsets and PC data

cables. Use of any unauthorised accessories

could damage you or your phone and may

be dangerous.

Qualified service

Only qualified service personnel may repair

your phone.

For more detailed safety information, see

"Health and safety information" on page 99.

• The phone could explode if the battery is

replaced with an incorrect type.

• Dispose of used batteries according to the

manufacturer’s instructions.

At very high volumes, prolonged

listening to a headset can damage

your hearing.

About this Guide

This User’s Guide provides you with

condensed information about how to use

your phone. To quickly learn the basics for

your phone, please refer to “Get started”

and “Step outside the phone.”

In this guide, the following instruction icons

appear:

Indicates that you need to pay

careful attention to the subsequent

information regarding safety or

phone features.



Indicates that you can get more

information on the referenced page.

→

Indicates that you need to press the

Navigation keys to scroll to the

specified option and then select it.

[ ]

Indicates a key on the phone. For

example,

[]

< >

Indicates a soft key, whose function

is displayed on the phone screen. For

example, <

• Camera and camcorder

Use the camera module

on your phone to take a

photo or record a video.

Special

features of your phone

•Image editor

Crop, resize, rotate, and

decorate your photos.

• Photo printing

Print your photos to

preserve your best

moments forever.

• File viewer

Open documents in

various formats on the

phone without corruption.

Special features of your phone

• Web browser

Access the wireless web

to get up-to-the-minute

information and a wide

variety of media content.

• Offline mode

Switch your phone to

offline to use its

non-wireless functions in

an airplane.

•E-mail

Send and receive e-mails

with image, video, and

audio attachments.

• Multimedia Message

Service (MMS)

Send and receive MMS

messages with a

combination of text,

image, video, and audio.

•Java

Enjoy Java

™

-based

embedded games and

download new games.

•Voice recorder

Record memos or sounds.

Contents

Unpack 6

Make sure you have each item

Your phone 6

Keys, features, and locations

Get started 7

First steps to operating your phone

Install and charge the phone ....................... 7

Power on or off.......................................... 8

Keys and display ....................................... 9

Access menu functions ............................. 12

Customise your phone.............................. 13

Make/Answer calls ................................... 16

Step outside the phone 16

Begin with your camera, the music player, the

web, and other special features

Use the camera ....................................... 16

Play music .............................................. 17

Browse the web ....................................... 19

Use Phonebook ........................................ 19

Use a memory card .................................. 25

Watch the phone display on a TV................ 27

Enter text 28

AB, T9, Number, and Symbol modes

Call functions 30

Advanced calling features

Menu functions 34

All menu options listed

Solve problems 97

Help and personal needs

Health and safety information 99

Index 120

Overview of menu functions

To access Menu mode, press <

> in Idle mode.

1 Call log



p. 34

1 Recent contacts

2 Missed calls

3 Dialled calls

4 Received calls

5 Delete all

6 Call time

7 Call costs



p. 34



p. 35



p. 35



p. 35



p. 35



p. 35



p. 36

2 Phonebook



p. 36

1 Contact list

2 Create contact

3 Group

4 Speed dial

5 My namecard

6 Own number

7 Management

8 Service number



p. 36



p. 37



p. 38



p. 38



p. 39



p. 39



p. 39



p. 40

3 Applications



p. 40

1 Voice recorder

2 Image editor

3 Java world

4 World clock

5 Alarm

6 Calculator

7 Converter

8 Timer



p. 43



p. 44



p. 45



p. 46



p. 47



p. 47



p. 48



p. 48

3 Applications

(continued)

9 Stopwatch

10 Key management

11 Memo

12 SIM AT



p. 48



p. 49



p. 49



p. 49

4 Browser



p. 50

1 Home

2 Enter URL

3 Bookmarks

4 Saved pages

5 History

6 Clear cache

7 Browser settings

8 Streaming settings



p. 50



p. 51



p. 51



p. 52



p. 52



p. 52



p. 52



p. 53

5 Messages



p. 53

1 Create message

2 My messages

3 Templates

4 Delete all

5 Settings

6 Memory status



p. 53



p. 57



p. 62



p. 62



p. 63



p. 68

6 My files



p. 69

1 Images

2 Videos

3 Music

4 Sounds



p. 69



p. 70



p. 72



p. 72

6 My files

(continued)

5 Other files

6 Memory card

7 Memory status



p. 73



p. 75



p. 75

7 Calendar



p. 75

8 Camera



p. 78

9 Settings



p. 84

1 Time and date

2 Phone settings

3 Display settings

4 Sound settings

5 Light settings

6 Network services

7 Security

8 Connection settings

9 Reset settings



p. 84



p. 85



p. 86



p. 87



p. 88



p. 91



p. 94



p. 95



p. 97

1. Shows only if supported by your

SIM card.

2. Show only if supported by your

service provider.

3. Shows only if a memory card is

inserted.

Unpack

Make sure you have each item

You can obtain various

accessories from your local

Samsung dealer.

Phone Travel Adapter

Battery User’s Guide

The items supplied with

your phone and the

accessories available at

your Samsung dealer may

vary, depending on your

country or service

provider.

Your phone

Keys, features, and locations

Earpiece

Main display

Volume keys

Dial key

Alphanumeric

keys

Web access/

Confirm key

Left soft key

Navigation keys

(Up/Down/

Left/Right)

Right soft key

Camera

lens

Adapter jack

Camera

key

Power on/off/Menu exit key

External

display

Delete key

Microphone

Headset

jack

Get started

First steps to operating your phone

SIM card information

When you subscribe to a cellular network,

you receive a plug-in SIM (Subscriber

Identity Module) card loaded with your

subscription details, such as your PIN, and

available optional services.

Install and charge the phone

Remove the

battery cover.

If the phone is

already on, first

turn it off by

pressing and

holding [ ].

Insert the SIM

card.

Make sure that the

gold-coloured

contacts on the

card are face down.

Install the battery. Reattach the

battery cover.

Plug the travel adapter into the phone.

Plug the adapter into a standard AC wall

outlet.

Get started

Low battery indicator

When the battery is low:

• a warning tone sounds,

• the low battery message displays, and

• the empty battery icon blinks.

If the battery level becomes too low, the

phone automatically turns off. Recharge

your battery.

Power on or off

When the phone is completely charged

(the battery icon becomes still), unplug

the adapter from the power outlet.

Remove the adapter from the phone.

Switch on

Do not turn

on the phone

when mobile

phone use is

prohibited.

1. Open the phone.

2. Press and hold [ ].

3. If necessary, enter the

PIN and press <

Switch off

1. Open the phone.

2. Press and hold [ ].

Get started

Offline mode

You can switch the phone to Offline mode, in

which the phone functions requiring network

connection are deactivated. This mode is

helpful when you want to use your phone in

a place where you are not allowed to use

mobile devices, such as in an airplane and at

a hospital.

To switch to Offline mode, press <

and select

Settings

→

Phone settings

→

Offline mode

→

In Offline mode, you can use non-wireless

functions, such as games, calendar, camera,

and music player.

Keys and display

Keys

Perform the function indicated

on the bottom line of the

display.

In Idle mode, access your

favourite menus directly.



p. 85

In Menu mode, scroll through

menu options.

In Idle mode, launch the web

browser.

In Menu mode, select the

highlighted menu option or

confirm input.

Make or answer a call.

In Idle mode, retrieve numbers

recently dialled, missed, or

received.

Get started

Delete characters from the

display, or items in an

application.

Press and hold to switch the

phone on or off.

End a call.

In Menu mode, cancel input and

return the phone to Idle mode.

Enter numbers, letters, and

some special characters.

In Idle mode, press and hold

[1]

to access your voicemail

server. Press and hold [

] to

enter an international call

prefix.

Enter special characters.

In Idle mode, press and hold

[ ] to activate or deactivate

Silent mode. Press and hold

[ ] to enter a pause between

numbers.

Adjust the phone volume.

In Idle mode, with the phone

open, adjust the key tone

volume. With the phone closed,

press and hold to turn on the

external display.

Get started

Display

Layout

Icons

Received signal strength

GPRS network

Connecting to GPRS

network

Transferring data in GPRS

network

EDGE network

Connecting to EDGE

network

Icons

display various

icons.

Menu Contacts

Text and graphics

display messages,

instructions, and

information you

enter.

Soft key function

indicators

show the current

functions assigned

to the soft keys.

Transferring data in EDGE

network

Call in progress

Out of your service area;

you cannot make or

receive calls

Connected to Internet

Connected to a secured

web page

Synchronised with PC

Call diverting feature

active



p. 89

Home Zone, if registered

for the appropriate service

Office Zone, if registered

for the appropriate service

Roaming network

SMS message

MMS message

E-mail

Voicemail

Get started

Access menu functions

Bluetooth hands-free

car

kit or headset connected



p. 92

Alarm set



p. 47

Silent mode (Vibration)

Silent mode (Mute)

Call ringer set to vibrate

Mute mode, during a call

Battery power level

1. Depending on your country or service

provider, the icons shown on the display

may vary.

Use the

soft keys

The roles of the soft keys vary

depending on the function

you are using. The bottom

line of the display indicates

their current role.

Press the left

soft key to select

the highlighted

option.

Press the right

soft key to return

to the previous

menu level.

ect Bac

Get started

Customise your phone

Select an

option

1. Press a desired soft key.

2. Press the Navigation

keys to move to the next

or previous option.

3. Press <

Select

> or [ ]

to confirm the function

displayed or option

highlighted.

4. To exit, choose either of

the following methods.

• Press <

Back

> to

move up one level.

• Press [ ] to return

to Idle mode.

Use

shortcuts

Press the number key

corresponding to the option

you want. For the menu

numbers 10, 11, and 12,

press [

], [ ] and [ ]

respectively.

1. In Idle mode, press

> and select

Settings

→

Phone

settings

→

Language

2. Select a language.

1. In Idle mode, press

> and select

Settings

→

Sound

settings

→

Incoming

call

→

Ringtone

2. Select a ringtone

category.

3. Select a ringtone.

4. Press <

Save

Display

language

Call ringer

melody

Get started

You can set wallpaper for the

idle screen on the main

display.

1. In Idle mode, press

> and select

Settings

→

Display

settings

→

Wallpaper

→

Main display

2. Select an image or a

video category.

3. Select an image or a

video clip.

4. Press <

Select

5. Press <

Save

You can change the colour for

the display components, such

as title bars and highlight

bars.

1. In Idle mode, press

> and select

Settings

→

Display

settings

→

Skin

2. Select a colour pattern.

Idle mode

wallpaper

Menu mode

skin colour

You can set the Navigation

keys to function as shortcuts

to access your favourite

menus.

1. In Idle mode, press

> and select

Settings

→

Phone

settings

→

Shortcuts

2. Select a key.

3. Select a menu to be

assigned to the key.

shortcuts

Get started

You can set up a menu of

your own favourite menu

items.

To set a My menu item:

1. In Idle mode, press

> and select

Settings

→

Phone

settings

→

My menu

2. Select an item to be

changed.

3. Select the menu item you

want.

To access a My menu item:

1. In Idle mode, press [Up].

2. Scroll to an item.

3. Press [ ].

You can switch the phone to

Silent mode to avoid

disturbing other people.

Press and hold [ ] in Idle

mode.

My Menu

Silent

mode

You can protect the phone

against unauthorised use with

a phone password. The phone

will require the password on

power-up.

1. In Idle mode, press

> and select

Settings

→

Security

→

Change password

2. Enter the default

password,

00000000

and press <

3. Enter a new 4- to 8-digit

password and press

4. Enter the new password

again and press <

5. Select

Phone lock

6. Select

Enable

7. Enter the password and

press <

Phone lock

Make/Answer calls

Step outside the phone

Begin with your camera, the music player, the

web, and other special features

Use the camera

1. In Idle mode, enter an

area code and phone

number.

2. Press [ ].

3. To end the call, press

[].

1. When the phone rings,

press [ ].

2. To end the call, press

[].

Press [ / ].

Make a call

Answer

a call

Adjust the

volume

during

a call

1. Open the phone.

2. In Idle mode, press

> and select

Camera

3. Aim the lens at the

subject and make any

desired adjustments.

4. Press [ ] to take a photo.

The photo is saved

automatically.

Pres

s <

Preview

> to

take

another photo.

Take a


Step outside the phone

1. In Idle mode, press

> and select

files

→

Images

→

photos

2. Select the photo you

want.

1. In Idle mode, press

> and select

Camera

2. Press [

] to switch to

Record mode.

3. Press [ ] to start

recording.

4. Press [ ] or < > to

stop recording. The video

is saved automatically.

5. Press <

Preview

> to

record another video.

View a


Record a

video

In Idle mode, press

> and select

files

→

Videos

→

video clips

2. Select the video you

want.

Play a

video

Step outside the phone

Browse the web

Using a built-in web browser, you can easily

access the wireless web to get a variety of

up-to-date services and information and to

download web content.

Use Phonebook

In Idle mode, press [ ].

• To scroll through browser

items, press [Up] or

[Down].

• To select an item, press

[].

• To return to the previous

page, press <

Back

• To move to the next page,

press <

Options

> and

select

→

Forward

• To access browser

options, press

Options

Launch

the web

browser

Navigate

the web

To the phone’s memory:

1. In Idle mode, enter a

phone number and press

Options

2. Select

Save contact

→

Phone

→

New

→

number type.

3. Specify contact

information: First name,

Last name, Mobile, Home,

Office, Fax, Other, Email,

Caller ID, Ringtone,

Group, and Note.

4. Press <

Save

> to save

the contact.

Add a

contact

Step outside the phone

To th e SIM card:

1. In Idle mode, enter a

phone number and press

Options

2. Select

Save contact

→

SIM

→

New

3. Enter a name.

4. Press <

Save

> to save the

contact.

1. In Idle mode, press

Contacts

2. Enter the first few letters

of the name you want.

3. Select a contact.

4. Scroll to a number and

press

[]

to dial, or

press [ ] to edit contact

information.

Add a

contact

Find a

contact

1. In Idle mode, press

> and select

Phonebook

→

namecard

2. Specify your contact

information.

3. Press <

Save

> to save

the name card.

4. To send the name card,

press <

Options

> and

select

Send via

→

sending method.

Create and

send a

name card

Step outside the phone

Send messages

1. In Idle mode, press

> and select

Messages

→

Create

message

→

Text

message

2. Enter the message text.

3. Press <

Options

> and

select

Save and send

Send only

4. Enter destination

numbers.

5. Press [ ] to send the

message.

1. In Idle mode, press

> and select

Messages

→

Create

message

→

Multimedia

message

2. Select

Subject

Send a text

message

(SMS)

Send a

multimedia

message

(MMS)

3. Enter the message

subject and press [ ].

4. Select

Image and video

Sound

5. For

Image and video

select

Add image

Add

video

and add an image

or a video clip.

For

Sound

, select

Add

sound

and add a sound

clip.

6. Select

Message

7. Enter the message text

and press [ ].

8. Press <

Options

> and

select

Send

9. Enter destination

numbers or addresses.

10. Press [ ] to send the

message.

Step outside the phone

View messages

1. In Idle mode, press

and select

Messages

→

Create

message

→

2. Select

Subject

3. Enter the e-mail subject

and press [ ].

4. Select

Message

5. Enter the e-mail text and

press [ ].

6. Select

File attached

7. Add image, video, sound,

music files, or document

files.

8. Press <

Options

> and

select

Send

9. Enter e-mail addresses.

10. Press [ ] to send the

e-mail.

Send an

e-mail

When a notification appears:

1. Press <

View

2. Select the message from

the Inbox.

From the Inbox:

1. In Idle mode, press

> and select

Messages

→

messages

→

Inbox

2. Select an SMS message

().

When a notification appears:

1. Press <

View

2. Press <

Options

> and

select

Retrieve

3. Select the message from

the Inbox.

View a text

message

View a

multimedia

message

Step outside the phone

From the Inbox:

1. In Idle mode, press

> and select

Messages

→

messages

→

Inbox

2. Select an MMS message

().

1. In Idle mode, press

> and select

Messages

→

messages

→

inbox

2. Select an account.

3. Press <

Yes

> to download

new e-mails or headers.

4. Select an e-mail or a

header.

5. If you selected a header,

press <

Options

> and

select

Retrieve

retrieve the body of the

e-mail.

View an

e-mail

Enter text

AB, T9, Number, and Symbol modes

You can enter text for some features, such

as Messages, Phonebook, or Calendar, using

AB mode, T9 mode, Number mode, and

Symbol mode.

Changing the text input mode

• Press and hold [ ] to switch between T9

mode ( ) and AB mode ( ).

Depending on your country, you may

also be able to access an input mode for

your specific language.

• Press [ ] to change case or switch to

Number mode ( ).

• Press and hold [ ] to switch to Symbol

mode.

Using AB mode

Press the appropriate key until the character

you want appears on the display.

(Creating an SMS message with GSM-Alphabet

encoding)

Other AB mode operations

• To enter the same letter twice or to enter

a different letter on the same key, wait

for the cursor to move to the right

automatically or press [Right]. Then,

enter the next letter.

• Press [ ] to insert a space.

• Press the Navigation keys to move the

cursor.

Characters in order displayed

Key U

er case Lower case

Enter text

• Press [

] to delete characters one by

one. Press and hold [

] to clear the

display.

Using T9 mode

T9 is a predictive text input mode that

allows you to key in any character using

single keystrokes.

Entering a word in T9 mode

1. Press [

] to [

]

to start entering a word.

Press each key once for each letter.

For example, press [

], [

and [

] to enter Hello in T9 mode.

T9 predicts the word that you are typing,

and it may change with each key that

you press.

2. Enter the whole word before editing or

deleting characters.

3. When the word displays correctly, go to

step 4. Otherwise, press [

] to display

alternative word choices for the keys

that you have pressed.

For example, Of and Me use [

] and [

4. Press [ ] to insert a space and enter the

next word.

Other T9 mode operations

• Press [

] to enter periods or apostrophes

automatically.

• Press [ ] to insert a space.

• Press the Navigation keys to move the

cursor.

• Press [

] to delete characters one by

one. Press and hold [

] to clear the

display.

Adding a new word to the T9

dictionary

This feature may not be available for some

languages.

1. Enter the word that you want to add.

2. Press [

] to display alternative words for

your key presses. When there are no

more alternative words,

Add

appears on

the bottom line.

3. Press <

Add

4. Enter the word you want using AB mode

and press <

Using Number mode

Number mode enables you to enter

numbers.

Press the keys corresponding to the digits

you want.

Using Symbol mode

Symbol mode enables you to insert symbols.

Call functions

Advanced calling features

Making a call

1. In Idle mode, enter the area code and

phone number.

2. Press [ ].

3. When you want to end the call, press

[].

Making an international call

1. In Idle mode, press and hold [

]. The

character appears.

2. Enter the country code, area code, and

phone number, then press [ ].

Redialling recent numbers

1. In Idle mode, press [ ] to display the

list of recent numbers.

To Press

scroll to a symbol set the Navigation

keys.

select a symbol the corresponding

number key.

clear the entered

symbols

[

insert the symbols <

• Press [

] to clear the last digit or

press and hold [

] to clear the whole

display.

• Press and hold

[]

to enter a pause

between numbers.

Call functions

2. Scroll to the number you want and press

[].

Making a call from Phonebook

Once you have stored a number in

Phonebook, you can dial the number by

selecting it from Phonebook.



p. 31

You can also use the speed dial feature to

assign your most frequently dialled numbers

to specific number keys.



p. 33

You can quickly dial a number from the SIM

card using its location number assigned

when stored.

1. In Idle mode, enter a location number

and press [ ].

2. Press [Left] or [Right] to scroll through

other numbers.

3. Press <

Dial

> or [ ] to dial the number

you want.

Answering a call

When you receive an incoming call, the

phone rings and displays the incoming call

image.

Press <

> or [ ] to answer the call.

Tips for answering a call

• When

Anykey

answer

is active, you can

press any key, except for <

Reject

> and

[].



p. 80

• When

Active flip

is active, you can

simply open the phone.



p. 80

• Press <

Reject

> or [ ] to reject a call.

• Press and hold [ / ] to reject a call or

mute the ringer, depending on the

Volume key

setting.



p. 80

Viewing missed calls

If you have missed calls, the screen displays

how many calls you have missed.

1. Press <

View

2. If necessary, scroll through the missed

calls.

3. Press [ ] to dial the number you want.

Call functions

Using the headset

Use the headset to make or answer calls

without holding the phone.

Connect the headset to the jack on the left

side of the phone. The button on the

headset works as follows:

Options during a call

You can access a number of functions during

a call.

Adjusting the volume during a call

Use [ / ] to adjust the earpiece volume

during a call.

Press [ ] to increase the volume level and

[ ] to decrease the volume level.

Placing a call on hold/Retrieving

Press <

Hold

> to place a call on hold, or

press <

Retrieve

> to retrieve the call.

Making a second call

You can make another call if your network

supports this function.

1. Press <

Hold

> to put the call on hold.

2. Make the second call in the normal way.

3. Press <

Swap

> to switch between the

calls.

4. Press <

Options

> and select

End

held

call

to end the call on hold.

5. To end the current call, press [ ].

Answering a second call

You can answer an incoming call while

already on the phone, if your network

supports this function and you have

activated the call waiting feature.



p. 84

1. Press [ ] to answer the call. The first

call is automatically put on hold.

2. Press <

Swap

> to switch between the

calls.

To Press

redial the last call the button twice.

answer a call the button.

end a call the button.

Call functions

3. Press <

Options

> and select

End

held

call

to end the call on hold.

4. To end the current call, press [ ].

Using the speakerphone feature

Use your phone as a speakerphone to talk

and listen with the phone a short distance

away.

Press [ ] and then <

Yes

> to activate the

speakerphone feature. Press [ ] again to

switch back to the earpiece.

Using In-call options

Press <

Options

> to access the following

options during a call:

•

Speaker on

Normal

: turn on the

speakerphone feature or switch back to

Normal mode.

•

Switch to headset

Switch to phone

transfer the call to a Bluetooth headset

or hands-free car kit, or back to the

phone.



p. 92

•

: access the phone's menu

functions.

•

Voice off

Voice on

: switch off the

phone's microphone so that the other

person on the phone cannot hear you, or

switch it back on.

•

Mute keys

Send keys

: switch the key

tones off or on.

•

Send DTMF

: send the DTMF (Dual tone

multi-frequency) tones as a group. The

DTMF tones are the tones used in phones

for tone dialling, sounding when you

press the number keys. This option is

helpful for entering a password or an

account number when you call an

automated system, like a banking

service.

•

Phonebook

: access the contact list.

•

SIM service

: access special services,

such as news, weather forecasts,

entertainment, and location services,

provided by your SIM card. This option is

available when you use a SIM card

supporting SIM Application Toolkit

menus.

To communicate with answering

machines or computerised telephone

systems,

Send keys

must be selected.

•

Join

: set up a multi-party call by adding

a caller on hold to a currently active call.

You can include up to 5 people on a

multi-party call.

•

Private

: have a private conversation

with one multi-party call participant. The

other participants can converse with

each other. After the private

conversation, select

Join

to return both

private participants to the multi-party

call.

•

Removed

: disconnect one multi-party

call participant.

Menu functions

All menu options listed

Call log

(Menu 1)

Use this menu to view the calls you have

dialled, received, or missed, and the length

of the calls. You can also check the cost of

your calls,

if your SIM card supports this

function.

To access this menu, press <

> in Idle

mode and select

Call log

Recent contacts

(Menu 1.1)

This menu displays the most recent calls

dialled, received, or missed.

Accessing a call log

1. Press [Left] or [Right] to move to

another call type.

2. Press [Up] or [Down] to scroll through

the call list.

3. Press [ ] to view the details of a call, or

press [ ] to dial a number.

Menu functions

Call log

(Menu 1)

Using call log options

While viewing call details, press <

Options

to access the following options:

•

Call

: edit the number and dial it.

•

Add to Phonebook

: save the number to

Phonebook.

•

Send

: send an SMS or MMS message to

the selected number.

•

Delete

: delete the selected call log or all

logs.

Missed calls

(Menu 1.2)

This menu displays the most recent calls you

did not answer.

Dialled calls

(Menu 1.3)

This menu displays the most recent calls you

have dialled.

Received calls

(Menu 1.4)

This menu displays the most recent calls you

have received.

Delete all

(Menu 1.5)

Use this menu to delete all of the records in

each call type.

1. Press [ ] to select the call types to be

cleared.

2. Press <

Delete

3. Press <

Yes

> to confirm the deletion.

Call time

(Menu 1.6)

This menu displays the time log for calls

made and received. The actual time invoiced

by your service provider will vary.

•

Last

call

time

: check the length of your

last call.

•

Total

dialled calls

: check the total

length of all the calls you have dialled.

•

Total

received calls

: check the total

length of all the calls you have received.

To reset the call timers, press <

Reset

>. You

need to enter the phone password.

The password is preset to

00000000

. You

can change this password.



p. 86

Menu functions

Call costs

(Menu 1.7)

This network feature displays the cost of

calls. This menu is available only if

supported by your SIM card. Note that this is

not intended to be used for billing purposes.

•

Last

call

cost

: check the cost of your

last call.

•

Total

cost

: check the total cost of all of

your calls. If the total cost exceeds the

maximum cost set in

Set

max.

cost

you must reset the counter before you

can make another call.

•

Max.

cost

: check the maximum cost

limit.

•

Reset

counters

: reset the cost

counters.

•

Set

max.

cost

: set the maximum cost

authorised for your calls.

•

Price/Unit

: set the price per unit that is

applied when the cost of your calls is

calculated.

Phonebook

(Menu 2)

You can store phone numbers on your SIM

card and in your phone’s memory. The SIM

card and phone’s memory are physically

separate, but they are used as a single

entity called Phonebook.

To access this menu, press <

> in Idle

mode and select

Phonebook

Contact list

(Menu 2.1)

Use this menu to search for contacts in

Phonebook.

Finding a contact

1. Enter the first few letters of the name

that you want to find.

2. Select a contact from the list.

3. Scroll to a number and press [ ] to

dial, or press [ ] to edit contact

information.

You can quickly access this menu by

pressing <

Contacts

> in Idle mode.

Menu functions

Phonebook

(Menu 2)

Finding a contact in Idle mode

You can find contacts in Idle mode, by the

spelling of a contact name. The phone

searches for the contact names starting with

the letters labelled on any of the keys you

pressed.

1. In Idle mode, press the number keys

containing the letters you want.

2. Press <

Options

> and select

Search as

spelling

The phone searches Phonebook for the

matching contacts and shows results.

Using Phonebook options

While viewing contact details, press

Options

> to access the following options:

•

Edit

: edit contact information.

•

Send message

: send an SMS or MMS

message to the selected number, or an

MMS message or e-mail to the selected

address.

•

Copy to

: copy the contact to the phone’s

memory or to the SIM card.

•

Send via

: send the contact via SMS,

MMS, e-mail, or Bluetooth.

•

Delete

: delete the selected contact.

Create contact

(Menu 2.2)

Use this menu to add a new contact to

Phonebook.

Storing a contact in the phone’s

memory

1. Select

Phone

2. Change the settings or enter information

about the contact.

•

First name

Last name

: assign a

name.

•

Mobile

Home

Office

Fax

Other

add a number in any type.

•

: assign an e-mail address.

•

Caller ID

: assign an image or a

video to alert you to a call from the

person.

•

Ringtone

: assign a ringtone to alert

you to a call from the person.

•

Group

: assign the number to a caller

group.

•

Note

: add a memo about the person.

3. Press <

Save

> to save the contact.

Menu functions

Storing a contact on the SIM card

1. Select

SIM

2. Enter information about the contact.

•

Name

: assign a name.

•

Phone number

: add a number.

•

Location

: assign a location number.

3. Press <

Save

> to save the contact.

Group

(Menu 2.3)

Use this menu to organise your contacts in

caller groups.

Creating a new caller group

1. Press <

Options

> and select

Create

group

2. Enter a name for the group.

3. Select the caller ID line and set an image

or a video clip.

4. Select the ringtone line and set a

ringtone.

5. Press <

Save

> to save the group.

Adding members to a caller group

1. Select a group.

2. Press <

Add

3. Press [ ] to select the contacts to be

added.

4. Press <

Select

Managing caller groups

While viewing the group list, press

Options

> to access the following options:

•

View

: display the members of the

selected group.

•

Create group

: add a new group.

•

Edit

: change the group properties.

•

Send message

: send an SMS, MMS, or

e-mail message to the group members

you want.

•

Delete

: delete the selected group or all

groups. Group members, however, will

not be deleted from Phonebook.

Speed dial

(Menu 2.4)

Use this menu to assign a speed dial number

(2 to 9) for 8 of your most frequently dialled

numbers.

STo assign a caller ID image or video,

ringtone, or group, the contact must be

saved to the phone’s memory.

Menu functions

Phonebook

(Menu 2)

Assigning speed dial numbers

1. Select a key location from

. Key

is reserved for your voicemail server.

2. Select a contact from the contact list.

3. Select a number, if the contact has more

than one number.

Managing speed dial entries

From the Speed dial screen, press

Options

> to access the following options:

•

Add

: assign a number to an unassigned

key.

•

View

: check the name and number

assigned to a key.

•

Change

: assign a different number to a

key.

•

Remove

: clear the speed dial setting for

a key.

Dialling speed dial numbers

In Idle mode, press and hold the appropriate

key.

My namecard

(Menu 2.5)

Use this menu to create a name card and

send it to other people.

Saving your name card

The procedure for creating your name card

is the same as the one for saving a phone

number in the phone’s memory.



p. 32

Using name card options

After saving your name card, press

Options

> to access the following options:

•

Edit

: edit the name card.

•

Send via

: send the name card via SMS,

MMS, e-mail, or Bluetooth.

•

Exchange namecard

: exchange name

cards with another person via Bluetooth.

•

Delete

: delete the name card.

Own number

(Menu 2.6)

Use this feature to check your phone

numbers, or to assign a name to each of the

numbers. Changes made here do not affect

the actual subscriber numbers on your SIM

card.

Management

(Menu 2.7)

Use this menu to manage contacts in

Phonebook.

Menu functions

•

Save new contact to

: select a default

memory location for saving contacts. If

you select

Always ask

, the phone will

ask you to select a memory location each

time you save a number.

•

Copy all to

: copy all of the contacts

stored on the SIM card to the phone’s

memory, or vice versa.

•

Delete all

: delete all of the contacts

from your phone’s memory, your SIM

card, or both.

•

Memory status

: check the number of

contacts you have stored in the phone’s

memory and on the SIM card.

Service number

(Menu 2.8)

Use this menu to view the list of Service

Dialling Numbers (SDN) assigned by your

service provider, including emergency

numbers and numbers for directory

enquiries. This menu is available if your SIM

card supports SDN.

1. Scroll to the number you want and press

View

2. Press <

Dial

> or [ ].

Applications

(Menu 3)

Use this menu to play music files or play

Java games. You can also use convenient

features, such as voice recorder, alarm

clock, calculator, converter, and stopwatch.

To access this menu, press <

> in Idle

mode and select

Applications

Voice recorder

(Menu 3.1)

Use this menu to record voice memos. A

voice memo can be up to one hour long.

Recording a voice memo

1. Press [ ] to start recording.

2. Speak into the microphone.

Press [ ] to pause or resume recording.

3. Press <

Stop

> or [Down] to end

recording. The voice memo is

automatically saved.

4. Press [ ] to review the voice memo, or

[Up] to record a new memo.

Menu functions

Applications

(Menu 3)

Playing a voice memo

1. From the Voice recorder screen, press

Options

> and select

Go to My voice

clips

2. Select a voice memo.

During playback, use the following keys:

Changing the recording mode

You can change the recording mode of the

voice recorder. The maximum recording time

is determined by this setting. Before

recording a memo, press <

Options

> and

select

Settings

→

a recording mode:

•

Limit for multimedia message

: You

can record a voice memo for adding to

an MMS message.

•

Limit for email

: You can record a voice

memo for adding to an e-mail.

•

Maximum 1 hour

: You can record a

voice memo of up to one hour.

Image editor

(Menu 3.2)

Use this menu to edit your photos using

various editing tools.

Applying an effect

1. Press <

Options

> and select

New


→

Open

Take photo

2. Select a photo or take a new photo.

3. Press <

Options

> and select

Effects

→

an effect option.

4. Press <

Done

5. Press <

Options

> and select

Save as

6. Enter a new file name and press <

Transforming

1. Select a photo or take a new photo.

2. Press <

Options

> and select

Transform

→

an option:

Key Function

Pauses or resumes playback.

Left Returns to the previous

memo. Moves backward in a

memo when held down.

Right Skips to the next memo.

Skips forward in a memo

when held down.

/ Adjusts the volume.

Down Stops playback.

Menu functions

•

Resize

: change the photo size.

•

Rotate

: rotate the photo 90 degrees.

•

Flip

: flip the photo.

3. Press <

Done

4. Press <

Options

> and select

Save as

5. Enter a new file name and press <

Cropping

1. Select a photo or take a new photo.

2. Press <

Options

> and select

Crop

3. Move the cropping frame to the area of

the image you want.

Press <

Options

> and select

Resize

change the frame size.

4. Press <

Options

> and select

Done

5. Press <

Options

> and select

Save as

6. Enter a new file name and press <

Adding visual features

You can decorate photos by adding a frame,

an image, or a note.

1. Select a photo or take a new photo.

2. Press <

Options

> and select

Insert

→

feature type.

3. Select an item, or enter text to be

inserted and press <

4. Adjust the position of the inserted item.

5. Press <

Done

>, or press <

Options

> and

select

Done

6. Press <

Options

> and select

Save as

7. Enter a new file name and press <

Merging a stamp effect

This editing tool allows you to make an

outline stamp of a photo and then merge it

with another photo. You can use this tool to

create your own photo postcard by taking a

photo of a handwritten message and

merging it with a photo.

1. Select a photo or take a new photo.

2. Press <

Options

> and select

Merge

stamp

. The background photo appears

in the image box next to .

3. Press <

Options

> and select

Add


4. Add a photo by selecting or taking a

photo. The added photo appears in the

image box next to . This will be the

stamp.

Menu functions

Applications

(Menu 3)

5. Press <

Options

> and select

Merge

. The

stamp photo is added to the background

photo as an outline.

6. Press <

Options

> to access the following

stamp edit options:

•

Resize

: change the stamp size.

•

Move

: change the position of the

stamp.

•

Rotate

: rotate the stamp.

•

Stamp colour

: change the stamp

colour.

•

Shadow on

: apply a shadow to the

stamp.

7. When you have finished, press

Options

> and select

Done

8. Press <

Options

> and select

Save as

9. Enter a new file name and press <

Java world

(Menu 3.3)

Use this menu to access the embedded Java

games and downloaded Java applications.

Accessing an embedded game

1. Select

My games

→

a game.

2. If necessary, press [ ].

Using Java application options

From the application list, press <

Options

to access the following options:

•

Start

: launch the selected application.

•

Move to

: move the application to

another folder.

•

Delete

: delete the selected application

or all applications, except for the

embedded games.

•

Protection

: lock the application to

protect it from being deleted, or unlock

the application.

•

Details

: access the application

properties.

•

Permissions

: set permission settings

for services charging you additional

costs, such as network access and SMS.

•

Upgrade

: upgrade the application to the

latest version.

•

Send information via Text message

send the URL containing the application

via SMS.

•

Memory status

: access memory

information for applications.

Menu functions

•

Settings

: select a connection profile to

be used for applications requiring

network access. You can also create or

edit a profile.



p. 88

World clock

(Menu 3.4)

Use this menu to set your local time zone

and find out the current time in another part

of the world.

Viewing world time

1. From the world map, press [Left] or

[Right] to scroll to the city you want. As

the time line moves, the time and date of

the given zone display.

2. Press [ ] to save the city as your local

time zone.

Applying daylight saving time

1. From the world map, press <

Options

and select

Apply daylight saving time

2. Press [ ] to select the time zones you

want.

3. Press <

Save

Alarm

(Menu 3.5)

Use this menu to set alarms. The alert type

for a normal alarm corresponds to the call

alert type settings. A wake-up alarm is not

affected by your sound settings.

Setting an alarm

1. Select the type of alarm.

2. Set each alarm option:

•

Alarm

: activate the alarm.

•

Alarm time

: enter the time for the

alarm to ring.

•

AM/PM

: set

in 12-hour

format.

•

Repeat

: select a repeat option.

•

Alarm tone

: select an alarm tone.

3. Press <

Save

Stopping an alarm

• For a non-wake-up alarm, press any key.

• For a wake-up alarm, press <

Confirm

or [ ].

Press any key, except for <

Confirm

and [ ], to cause it to sound again after

5 minutes. You can do this a maximum

of 5 times.

Menu functions

Applications

(Menu 3)

Deactivating an alarm

1. Select the alarm you want to deactivate.

2. Select

Off

on the

Alarm

line.

3. Press <

Save

Setting alarms to sound when the

phone is off

From the Alarm screen, select

Auto power

→

If the phone is off when it is time for the

alarm to sound, the phone switches on and

sounds the alarm.

Calculator

(Menu 3.7)

Use this menu to perform basic arithmetic

functions, such as addition, subtraction,

multiplication, and division.

1. Enter the first number.

• Press <

.()

> to insert a decimal point

or bracket.

• Press [ ] or [ ] to move the cursor.

2. Press one of the Navigation keys to

access the math function you want.

3. Enter the second number.

4. Press [ ] to view the result.

5. If necessary, repeat from step 2 to

continue the calculation.

Converter

(Menu 3.8)

Use this menu for common conversions,

such as currency and temperature.

1. Select a converter.

2. Press [Left] or [Right] to select the

original unit and press [Down].

3. Enter the value to be converted and

press [Down].

• Press [ ] to insert a decimal point.

• Press [ ] to change the temperature

to above zero (+) or below zero (-).

4. Press [Left] or [Right] to select the unit

to which you want to convert.

The equivalent value for the amount you

entered displays.

For the currency converter, you can view

and set currency rates by pressing <

View

rate

Menu functions

Timer

(Menu 3.9)

Use this menu to set a period of time for the

phone to count down. The phone sounds an

alarm when the specified period of time

expires.

Starting the timer

1. Press <

Set

2. Enter the length of time you want to

count down and press <

3. Press [ ] to start counting down.

Stopping the timer

• Press any key when the timer rings.

• Press [ ] on the Timer screen to stop the

timer before it rings.

Stopwatch

(Menu 3.10)

Use this menu to measure elapsed time. The

maximum time is 10 hours.

1. Press [ ] to start the stopwatch.

2. Press [ ] to check an interval. You can

repeat this step for a total of 4 intervals.

Key management

(Menu 3.11)

Use this menu to manage the licence keys

you have acquired to activate media

contents locked by DRM systems.

Press <

Options

> to access the following

options:

•

View

Play

: open the corresponding

media content.

•

Delete

: delete the selected licence key

or all licence keys.

•

Go to My messages

: access the

message that contains the

media

content.

•

Go to my item

access the

corresponding file folder.

•

Details

: access the properties of the

licence key.

Memo

(Menu 3.12)

Use this menu to make memos of important

things and manage them.

Creating a memo

1. Press <

Options

> and select

Create

Menu functions

Browser

(Menu 4)

2. Enter the memo text and press [ ].

Viewing a memo

Select the memo you want to view.

While viewing memo details, press

Options

> to access the following options:

•

Edit

: change the memo text.

•

Send via

: send the selected memo via

SMS, MMS, e-mail, or Bluetooth.

•

Delete

: delete the memo.

•

Memory status

: check how many

memos you have created.

SIM AT

(Menu 3.13)

This menu is available if you use a SIM AT

card that supports SIM Application Toolkit

menus and provides additional services,

such as news, weather, sports,

entertainment, and location services.

Available services may vary, depending on

your service provider’s plans. For details,

see your SIM card instructions or contact

your service provider.

Browser

(Menu 4)

The Wireless Application Protocol (WAP)

browser on your phone allows you to access

the wireless web. From the wireless web,

you can access up-to-date information and a

wide variety of media content, such as

games, wallpapers, ringtones, and music

files.

To access this menu, press <

> in Idle

mode and select

Browser

Home

(Menu 4.1)

Use this menu to connect your phone to the

network and load the homepage of the

wireless web service provider. You can also

press [ ] in Idle mode.

Navigating the web

To Press

scroll through

browser items

[Up] or [Down].

select a browser

item

[], or <

Options

and select

Go to

Menu functions

Using page options

From any web page, press <

Options

> to

access the following options:

•

Go to

: access the linked web page.

•

Go to homepage

: return to the

homepage.

•

Keys to buy

: send a request for buying

a licence key for a DRM file. This option

will be available only when you access

the web browser from a message

containing a DRM file.

•

Enter URL

: enter a URL address

manually.

•

: move backward or forward through

pages in history.

•

Reload

: reload the current page with

updated information.

•

Bookmarks

: bookmark the current

page or access the bookmark list.

•

Send URL

: send the URL of the current

page via SMS.

•

To SmartFit view

To Desktop view

change the display mode of the browser.

•

Save

: save the selected image or page.

•

Page details

: access the page

properties.

•

Browser options

: change the various

settings for the browser.

Cache

: change the cache mode or clear

the cache. The cache is a temporary

memory site that stores recently

accessed web pages.

: change the cookie acceptance

mode or delete cookies. Cookies are

pieces of personal information sent to a

web server while navigating the web.

return to the

Back

>, or

Options

> and

select

→

Back

move to the next

page

Options

> and

select

→

Forward

To Press

Menu functions

Browser

(Menu 4)

Preferences

: change the browser

display and sound settings.

Certificates

: access certificate

information.

About browser

: access version and

Exiting the browser

Press [ ] to end the network connection

and close the browser.

Enter URL

(Menu 4.2)

Use this menu to manually enter a URL

address and access the associated web

page.

You can add the entered URL to the

bookmark list by selecting

Add bookmark

Bookmarks

(Menu 4.3)

Use this menu to save URL addresses in

order to quickly access web pages.

Adding a bookmark

1. Press <

Add

>. If a bookmark has already

been saved, press <

Options

> and

select

Add bookmark

2. Enter a title for the bookmark and press

[Down].

3. Enter a URL address and press <

Save

Menu functions

Accessing a bookmarked page

Selecting a bookmark item launches the web

browser and accesses the associated web

page.

Using bookmark options

From the Bookmarks screen, press

Options

> to access the following options:

•

Go to

: access the bookmarked web

page.

•

Go to homepage

: access the

homepage.

•

Enter URL

: enter a URL address

manually.

•

Edit bookmark

: edit the URL address

and title of the bookmark.

•

Add bookmark

: add a new bookmark.

•

Send URL

: send the URL address of the

bookmark via SMS.

•

Delete

: delete the selected bookmark or

all bookmarks.

Saved pages

(Menu 4.4)

You can access the list of pages you have

saved while online.

If you select a link on the page, the phone

switches to online to access the linked page.

History

(Menu 4.5)

You can access the list of pages you have

accessed recently.

Select a URL from the list to access the

corresponding web page.

Clear cache

(Menu 4.6)

Use this menu to clear information stored in

the cache, a temporary memory site that

stores recently accessed web pages.

Browser settings

(Menu 4.7)

Use this menu to select a connection profile

to be used for accessing the wireless web.

You can also create or edit a profile.



p. 88

Menu functions

Messages

(Menu 5)

Streaming settings

(Menu 4.8)

Use this menu to select a connection profile

to be used for accessing your service

provider’s streaming service. This menu may

not be shown depending on your service

provider. You can also create or edit a

profile.



p. 88

Messages

(Menu 5)

Use the

Messages

menu to send and

receive text messages, multimedia

messages, and e-mails. You can also access

push messages and cell broadcast

messages.

To access this menu, press <

> in Idle

mode and select

Messages

Create message

(Menu 5.1)

Use this menu to create and send messages.

Text message

(Menu 5.1.1)

Short Message Service (SMS) allows you to

send or receive text messages that may

include simple pictures, animated images,

and melodies.

Creating and sending an SMS message

1. Enter your message and press [ ].

2. Enter a destination number.

To send the message to more than one

recipient, fill in additional destination

fields.

3. Press [ ] to send the message.

Using options while composing an SMS

message

While composing a message, press

Options

> to access the following options:

•

Send only

: just send the message.

•

Save and send

: send the message and

then save it in the

Sent box

folder.

• The maximum number of characters

allowed in a message varies by

service provider. If your message

exceeds the maximum number of

characters, the phone will split the

message.

• You can use various options by

pressing

Options



next section

Menu functions

•

Preview as vivid message

: view the

message in 3D view mode. The phone

converts message text to 3D vivid

graphics. This option is available only

when the message consists of a single

page.

•

Insert

: add a template, Phonebook

entry, or bookmark.

•

Add image

Add animation

Add

melody

: attach a simple image, an

animated image, or a melody.

•

Attach

: attach a Phonebook entry as a

name card or a calendar data as a data

format attachment.

•

Save in

: save the message in another

message folder.

•

Input language

: change the language

to be used in T9 input mode.

•

Text style

: change the text attributes.

•

Input method

: change the text input

mode.

Multimedia message

(Menu 5.1.2)

Multimedia Message Service (MMS) delivers

messages containing a combination of text,

image, video, and audio, from phone to

phone or from phone to e-mail.

Creating and sending an MMS message

1. Select the

Subject

line.

2. Enter the message subject and press

[].

3. Select the

Image and video

line.

4. Select

Add image

Add video

and

add an image or a video clip.

5. Select the

Sound

line.

6. Select

Add sound

and add a sound clip.

You can use various options by pressing

Options

in each field.



next section

• The maximum size allowed for a

message can differ, depending on

your service provider.

• Depending on the file type or DRM

(Digital Rights Management) system,

some files may not be able to be

forwarded.

Menu functions

Messages

(Menu 5)

7. Select the

Message

line.

8. Enter the message text and press [ ].

9. When you have finished, press

Options

> and select

Send

10. Enter a phone number or an e-mail

address.

To send the message to more than one

recipient, fill in additional destination

fields.

11. Press [ ] to send the message.

Using options while composing an MMS

message

While composing a message, press

Options

> to access the following options:

•

Add

: add the message subject or

message text.

•

Add image

Add video

Add sound

add a image, video clip, or sound clip.

•

Change image

Change video

Change

sound

: replace an added item.

•

Add memory card

: add a file stored on

a memory card, if inserted.

•

Edit

: edit the message subject or text.

•

Preview

: view the message as it will be

shown on the recipient’s phone.

•

View

: open the selected attachment.

•

Send

: send the message.

•

Save in

: save the message in another

message folder.

•

Add page

: add pages. Move to each

page by pressing [Left] or [Right].

•

Delete page

: delete an added page.

•

Edit page

: change the duration of page

display or move the page forward among

the other pages.

•

Attach

: attach a Phonebook entry as a

name card, a calender data as a data

format attachment, or a document file

stored in the

Other files

folder.

•

Remove subject

Remove message

Remove media

Remove sound

Remove

: remove an added item.

(Menu 5.1.3)

You can create and send e-mails that include

text, audio, and images.

Creating and sending an e-mail

Menu functions

1. Select the

Subject

line.

2. Enter the e-mail subject and press [ ].

3. Select the

Message

line.

4. Enter the e-mail text and press [ ].

5. Select the

File attached

line.

6. Add media files or document files stored

in the

Other files

folder.

7. When you have finished, press

Options

> and select

Send

8. Enter an e-mail address.

To send the e-mail to more than one

recipient, fill in additional destination

fields.

9. Press [ ] to send the e-mail.

Using options while composing an

e-mail

While composing an e-mail, press

Options

> to access the following options:

•

Add

: add the subject of your e-mail or

e-mail text.

•

Edit

: edit the subject or text.

•

Add image

Add video

Add sound

Add music

: add media files stored in

the phone’s memory.

•

Add other files

: add document files

stored in the

Other files

folder.

•

Memory card

: add files stored on a

memory card, if inserted.

•

View

Play

: open an attached file.

•

Send

: send the e-mail.

•

Save in

: save the e-mail in another

message folder.

•

Attach

: attach Phonebook entries as

name cards or calender data as data

format attachments.

You can use various options by pressing

Options

> in each field.



next section

Depending on the file type or DRM

(Digital Rights Management) system,

some files may not be able to be

forwarded.

Menu functions

Messages

(Menu 5)

•

Remove subject

Remove message

Remove attachment

: remove an

added item.

•

Remove all attachments

: delete all

attached files.

My messages

(Menu 5.2)

Use this menu to access messages you have

received, sent, or which have failed in

sending.

Inbox

(Menu 5.2.1)

This folder stores all of the messages you

have received, except for e-mails.

Viewing a message

The following icons may appear on the

message list to show the message type:

• SMS

• MMS

• MMS notification ( : Being

retrieved, : Failed to be

retrieved)

• Voicemail

• Push message from web servers or

• Configuration message, containing

network parameters from your

service provider

• CB (Cell broadcast) message from

your service provider

• Delivery report for your sent

messages

Using message options

While viewing a message, press <

Options

to access the following options:

SMS messages

•

Reply via text message

: reply to the

sender via SMS.

•

Reply via multimedia message to

reply to the sender via MMS.

• Depending on the DRM (Digital Rights

Management)

system, messages

having web content may not be

able

to be forwarded.

• A

icon next to a message means that

the message is of high priority. A

grey-coloured message icon indicates

low priority.

Menu functions

•

Forward

: forward the message to other

people.

•

Zoom view

: reduce the font size so that

you can view more text on one screen.

•

View as vivid message

View as

: view

the message in 3D view mode or switch

back to normal view mode. This option is

available only when the message

consists of a single page.

•

Delete

: delete the message.

•

Move to phone

Move to SIM

: move

the message between the SIM card and

the phone’s memory.

•

Cut address

: extract URL addresses,

e-mail addresses, or phone numbers

from the message.

•

Cut media

: save media content from

the message to your phone’s memory.

•

Lock

Unlock

: lock the message to

protect it from being deleted, or unlock

the message. You can protect only those

messages stored in the phone’s memory.

•

Add to Block list

: add the sender’s

number to the block list to reject the

messages from the sender.

MMS messages

•

Retrieve

: retrieve the MMS message

from the MMS server.

•

Reply via text message

: reply to the

sender via SMS.

•

Reply via multimedia message to

reply to the sender via MMS.

•

Forward

: forward the message to other

people.

•

Delete

: delete the message.

•

Cut address

: extract URL addresses,

e-mail addresses, or phone numbers

from the message.

•

Attached items

: save media content

from the message to your phone’s

memory.

•

Lock

Unlock

: lock the message to

protect it from being deleted, or unlock

the message.

•

Details

: access the message properties.

Configuration messages

•

Install

: apply the configuration specified

in the message to your phone.

•

Delete

: delete the message.

Menu functions

Messages

(Menu 5)

•

Lock

Unlock

: lock the message to

protect it from being deleted, or unlock

the message.

Push messages

•

Go to URL

: connect to the URL address

specified in the message.

•

Cut address

: extract URLs, e-mail

addresses, or phone numbers from the

message.

•

Delete

: delete the message.

•

Lock

Unlock

: lock the message to

protect it from being deleted, or unlock

the message.

Broadcast messages

•

Save

: save the message to the phone’s

memory.

•

Cut address

: extract URL addresses,

e-mail addresses, or phone numbers

from the message.

•

Delete

: delete the message.

Delivery reports

•

Cut address

: extract URL addresses,

e-mail addresses, or phone numbers

from the report.

•

Delete

: delete the report.

•

Lock

Unlock

: lock the report to protect

it from being deleted, or unlock the

report.

Drafts

(Menu 5.2.2)

This folder stores messages you have saved

to send at a later time.

When you select a message, it opens in Edit

mode so that you can edit and send the

message.

Outbox

(Menu 5.2.3)

This folder stores messages that the phone

is attempting to send or has failed to send.

The following icons are available to show the

message status:

• Being sent

• Failed to be sent

While viewing a message, press <

Options

to access the following options:

•

Send again

: retry sending the message.

•

Forward

: forward the message to other

people.

Menu functions

•

Zoom view

: reduce the font size so that

you can view more text on one screen.

•

Cut address

: extract URLs, e-mail

addresses, or phone numbers from the

message.

•

Delete

: delete the message.

•

Move to phone

Move to SIM

: move

the message between the SIM card and

the phone’s memory.

•

Lock

Unlock

: lock the message to

protect it from being deleted, or unlock

the message.

•

Details

: access the message properties.

Sentbox

(Menu 5.2.4)

This folder stores messages that you have

sent.

While viewing a message, press <

Options

to access the following options:

•

Forward

: forward the message to other

people.

•

Zoom view

: reduce the font size so that

you can view more text on one screen.

•

Cut address

: extract URLs, e-mail

addresses, or phone numbers from the

message.

•

Delete

: delete the message.

•

Move to phone

Move to SIM

: move

the message between the SIM card and

the phone’s memory.

•

Lock

Unlock

: lock the message to

protect it from being deleted, or unlock

the message.

•

Details

: access the message properties.

Email inbox

(Menu 5.2.5)

This folder stores e-mails that you have

received.

Viewing an e-mail

1. Select an e-mail account.

2. Press <

Yes

> when

Check for new

displays. The phone checks the

e-mail server and downloads new

e-mails.

The following icons may appear on the

list to show the e-mail status:

• Retrieved from the server

• Being retrieved

Menu functions

Messages

(Menu 5)

• Failed to be retrieved

3. Select an e-mail or a header.

4. Press [Left] or [Right] to view other

pages in the e-mail.

5. Press [ ] or [ ] to view the previous or

next e-mail.

Using e-mail options

While viewing the e-mail or header, press

Options

> to access the following options:

•

Retrieve

: retrieve the body of the

e-mail from the e-mail server.

•

View

Play

: open the selected

attachment.

•

Save to my files

: save the selected

attachment to the phone’s memory.

•

Reply to sender

: send a reply to the

sender.

•

to all

: send a reply to the sender,

or to the sender and all of the other

recipients.

•

Forward

: forward the e-mail to other

people.

•

Delete

: delete the e-mail.

icon next to a message means that

the message is of high priority. A grey-

coloured message icon indicates low

priority.

Menu functions

•

Add to filtering list

: add the sender’s

e-mail address or subject to the Block list

to reject e-mails from that address or

containing that subject.

•

Cut address

: extract URLs, e-mail

addresses, or phone numbers from the

e-mail.

•

Attached items

: save the attached files

from the e-mail to your phone’s memory.

•

Lock

Unlock

: lock the e-mail to protect

it from being deleted, or unlock the

e-mail.

•

Details

: access the e-mail properties.

My folders

(Menu 5.2.6)

Use this menu to create new folders and

organise your messages.

Creating a folder

1. Press <

Yes

2. Enter a folder name and press <

Using folder options

On the folder list, press <

Options

> to

access the following options:

•

Open

: open the selected folder.

•

Create folder

: add a new folder.

•

Rename folder

: change the folder

name.

•

Delete

: delete the selected folder.

Templates

(Menu 5.3)

Use this menu to make and use templates of

frequently used messages or passages.

Text message templates

(Menu 5.3.1)

You can create SMS templates with the

sentences you use frequently so that you

can retrieve and insert them when

composing an SMS message.

Creating a template

1. Select an empty location.

2. Enter a message and press <

Using template options

From the template list, press <

Options

> to

access the following options:

•

Edit

: edit the selected template.

•

Send message

: create and send a new

message using the selected template.

•

Delete

: delete the selected template.

•

Add new

: add a new template.

Menu functions

Messages

(Menu 5)

Multimedia message templates

(Menu 5.3.2)

You can access embedded MMS templates or

ones you have saved so that you can use

them when composing an MMS message.

From the template list, press <

Options

> to

access the following options:

•

View

: open the selected template.

•

Edit

: create and send a new message

using the selected template.

•

Send message

: send the selected

template.

•

Delete

: delete the selected template or

all templates, except for the embedded

ones.

Delete all

(Menu 5.4)

Use this menu to delete messages in each

message folder all at once.

1. Press [ ] to select the message folders

to be cleared.

Pressing the key twice displays the

message types so that you can specify

the ones to be cleared.

2. Press <

Delete

3. Press [ ] to select the check box to

delete protected messages, and then

press <

Yes

4. Press <

Yes

> to confirm the deletion.

Settings

(Menu 5.5)

Use this menu to set up various options for

using the messaging service.

Text messages

(Menu 5.5.1)

You can configure SMS settings.

•

Sending options

: set up the options for

sending SMS messages:

Reply path

: allow recipients to reply to

you through your SMS server.

Delivery report

: set the network to

inform you when your messages have

been delivered.

Character support

: select a character

encoding type. When you select

Automatic

, the phone switches the

encoding type from GSM-Alphabet to

UniCode if you enter a Unicode character.

Menu functions

Use of Unicode encoding will reduce the

maximum number of characters in a

message to about half. If this menu is

not shown, your phone provides

automatic character encoding by default.

Bearer selection

: select either

GSM

GPRS preferred

, depending on your

network.

•

Receiving options

: activate 3D view

mode for displaying received messages.

The phone will convert message text to

3D vivid graphics. This option is available

only when the message consists of a

single page.

•

Block list

: store the phone numbers

from which you want to reject messages.

•

Current profile

: check or select an SMS

setting profile.

•

Profile settings

: set the properties of

each profile.

Service centre

: store or change the

number of your SMS server.

Default destination

: enter the default

destination. It will be automatically

entered on the recipient list.

Default type

: set the default message

type. The network can convert the

messages into the selected format.

Default validity

: set the length of time

your messages are stored in the SMS

server.

Setting name

: enter a profile name.

Multimedia messages

(Menu 5.5.2)

You can configure MMS settings.

•

Sending options

: set up the options for

sending MMS messages:

Delivery report

: set the network to

inform you when your messages have

been delivered.

Hide address

: set your address to be

hidden from the recipient’s phone.

Read reply

: send a read-reply request

along with your messages.

Priority

: set the priority level of

messages.

Expiry date

: set the length of time

messages are stored in the MMS server.

Delivery time

: set a time delay before

messages are sent.

Menu functions

Messages

(Menu 5)

Outgoing message size

: select a

maximum size allowed for composing

messages.

•

Retrieving options

: set up the options

for receiving MMS messages:

Reject unknown senders

: reject

messages from unknown senders.

Allow adverts

: accept advertisements.

Allow information

: accept information

messages.

Allow report

: set the network to inform

the sender when a message has been

delivered to you.

Recep. in home network

: determine if

your phone retrieves new messages

automatically when you are in your

home service area.

Reception when abroad

: determine if

your phone retrieves new messages

automatically when you are roaming on

another network.

Reception within home network or

abroad has the following options:

Manual

: the phone displays

notifications. Use the

Retrieve

option

to manually download new messages.

Automatic

: the phone automatically

retrieves messages from the server.

Reject

: the phone rejects all

messages.

•

Block list

: store phone numbers and

e-mail addresses from which you want to

reject messages.

•

Multimedia message profiles

: select a

connection profile to be used for MMS.

You can also create or edit a profile.



p. 88

Emails

(Menu 5.5.3)

You can configure e-mail settings.

•

Sending options

: set up the options for

sending e-mails:

Keep a copy

: leave the copies of your

e-mails in the

Sentbox

folder after

sending.

You cannot change e-mail profile and

account settings while an e-mail is being

sent or retrieved.

Menu functions

Send delivery receipt

: set the network

to inform you when your e-mails have

been delivered.

Send read receipt

: send a read-reply

request along with e-mails.

Reply-To address

: set an e-mail

address to receive read-reply messages

from recipients.

Priority

: select the priority level of

e-mails.

Attach your vCard

: allow your contact

information to be attached to e-mails.

You must first create your name

card.



p. 34

Add signature

: attach your name,

phone number, a simple memo, or a tag

line to your e-mails.

Edit name

: edit the name in your

signature.

Edit number

: edit the phone number in

your signature.

Edit note

: edit the tag line in your

signature.

•

Receiving options

: set up the options

for receiving e-mails:

Check interval

: determine how often

the phone checks the server for incoming

e-mails. If you select

Do not notify

, use

the

Check for new email

option to

receive new e-mails manually.

Send read receipt

: determine whether

or not the phone sends a read-reply for

incoming e-mails. If you select

reminder

, the phone asks you to send a

read-reply.

Download limit

: determine the

maximum size for incoming e-mails. Your

phone will reject e-mails that exceed the

specified size.

Download method

: set whether the

phone downloads e-mail headers only or

e-mail headers and bodies both.

Keep in server

: leave copies of e-mails

on the e-mail server after retrieving.

Download email latest first

: set the

phone to download the most recent

e-mails first.

Menu functions

Messages

(Menu 5)

•

Block list

: specify e-mail addresses or

subjects you want to reject.

•

Email accounts

: set up an e-mail

account and select an account to be

used.

Current account

: check or select an

account.

Account settings

: configure e-mail

accounts using different e-mail servers.

Set the options for each account:

Account name

: enter a name for the

currently selected account.

User name

: enter a user name.

Email address

: enter your e-mail

address.

SMTP server

: enter the IP address or

host name of the outgoing e-mail

server.

SMTP port

: enter the SMTP port

number.

Connect to POP3

server first

Connect to IMAP4 server first

connect to the POP3 or IMAP4 server

before connecting to the SMTP server

to send e-mails.

Protocol type

: select the protocol for

the incoming e-mail server. The

remaining options depend on the

protocol type setting.

When the protocol type is

POP3

POP3 server

enter the IP address or

host name of the server that receives

your e-mail.

POP3 port

: enter the POP3 port

number.

User ID

: enter the POP3 user name.

Password

: enter the POP3 password.

Use SMTP authentication

: enable

SMTP authentication, which requires

the user to login before sending

e-mails.

Same as POP3

: select if you want the

SMTP server to have the same

parameters as the POP3 server.

Menu functions

SMTP user ID

: enter the SMTP user

name.

SMTP password

: enter the SMTP

password.

APOP login

: connect to the server by

using the APOP login scheme.

Email retrieval limit(1-100)

: set the

number of headers you will retrieve

from the server.

Secure connection

: use a secure

connection for the e-mail service.

When the protocol type is

IMAP4

IMAP4 server

: enter the IP address or

host name of the server that receives

your e-mail.

IMAP4 port

: enter the IMAP4 port

number.

User ID

: enter the IMAP4 user name.

Password

: enter the IMAP4 password.

Use SMTP authentication

: enable

SMTP authentication, which requires

the user to login before sending

e-mails.

Same as IMAP4

: select if you want

the SMTP server to have the same

parameters as the IMAP4 server.

SMTP user ID

: enter the SMTP user

name.

SMTP password

: enter the SMTP

password.

Include attachments

: select this

option to receive attachments with

e-mails.

Email retrieval limit(1-100)

: set the

number of headers you will retrieve

from the server.

Secure connection

: use a secured

connection for e-mail service.

•

Email profile

: select a connection

profile to be used for e-mail services. You

can also create or edit a profile.



p. 88

Push messages

(Menu 5.5.4)

You can change the settings for receiving

push messages from the wireless web

server.

Menu functions

My files

(Menu 6)

•

Receive

: set how your phone receives

push messages. If you select

Black list

the phone will not accept messages from

the specified addresses on the Black list.

•

Black list

: manage blocked server

addresses.

Broadcast messages

(Menu 5.5.5)

You can change the settings for receiving

broadcast messages.

•

Receive

: select to receive broadcast

messages, or not.

•

Channel list

: indicate the channels from

which you wish to receive broadcast

messages. Please contact your service

provider for further details.

•

Language

: select the preferred

languages in which broadcast messages

display.

Memory status

(Menu 5.6)

Use this menu to view the amount of

memory currently in use in each message

folder.

My files

(Menu 6)

The

My files

menu allows you to access

images, videos, music files, and sound files

stored in the phone’s memory or on a

memory card.

To access this menu, press <

> in Idle

mode and select

My files

Tips for Digital Rights Management

As a result of the Digital Rights Management

(DRM) system, some of the media items you

download from the Internet or receive by

MMS may require a licence key to access

them.

You can acquire the key from the website

which owns the rights to the content; use

the

Activate key

option.

Note the following icons on the list:

• : Forwardable item with a valid key.

• : Forwardable item without a valid

key.

• : Unforwardable item with a valid

key.

Menu functions

• : Unforwardable item without a valid

key.

Your service provider supports only count-

based or unlimited-access DRM files.

Images

(Menu 6.1)

This menu displays photos you have taken

and images you have downloaded, received

in messages, or imported from a computer.

Viewing an image

1. Select an image folder.

2. Select an image.

Viewing a slide show

You can view your photos as a slide show, a

sequential presentation of each photo in the

current folder.

1. Select

photos

2. Press <

Options

> and select

Slide

show

3. Select an interval option.

The slide show begins.

4. Press <

Stop

> to stop the slide show.

Using image options

While viewing an image, press <

Options

to access the following options:

•

List

: return to the image list.

•

Send via

: send the file via MMS, e-mail,

or Bluetooth.

•

Set as

: set the image as wallpaper for

the main display or as a caller ID image

for a Phonebook entry.

•

Edit

: edit the image using the Image

editor if it is a photo taken by the camera

on the phone.



p. 36

•

Activate key

: get a licence key when

the key for the selected DRM file expires.

•

Delete

: delete the file.

•

Rename

: change the file name.

•

Move to

: move the file to another folder

or to a memory card.

•

Copy to memory card

: copy the file to

a memory card.

•

Visible to Bluetooth

: share the file or

the files you want with other Bluetooth

devices.

Menu functions

My files

(Menu 6)

•

Lock

Unlock

: lock the file to protect it

from being deleted, or unlock the file.

•

Print via Bluetooth

: print the image by

connecting the phone to a printer via

Bluetooth. Some printers may not be

compatible with the phone.

•

Details

: access the file properties.

•

Key management

: manage the licence

keys you have acquired.

Videos

(Menu 6.2)

This menu displays video clips you have

recorded, downloaded, received in

messages, or imported from a computer.

Playing a video clip

1. Select a video folder.

2. Select a video clip.

During playback, use the following keys:

Using video options

After playback, press <

Options

> to access

the following options:

•

List

: return to the video list.

•

Send via

: send the file via MMS, e-mail,

or Bluetooth.

•

Set as

: set the video clip, if saved as a

3gp file, as wallpaper for the main

display or caller ID image for a

Phonebook entry.

•

Activate key

: get a new licence key

when the key for the selected DRM file

expires.

Video clips recorded on other devices, such

as camcorders, may not play correctly.

Key Function

Pauses or resumes

playback.

Left Returns to the previous file.

Moves backward in a file

when held down.

Right Skips to the next file. Moves

forward in a file when held

down.

/ Adjusts the volume.

Down Stops playback.

Key Function

Menu functions

•

Delete

: delete the file.

•

Rename

: change the file name.

•

Move to

: move the file to another folder

or to a memory card.

•

Copy to memory card

: copy the file to

a memory card.

•

Visible to Bluetooth

: share the

selected file or the files you want with

other Bluetooth devices.

•

Lock

Unlock

: lock the file to protect it

from being deleted, or unlock the file.

•

Details

: access the file properties.

•

Key management

: manage the licence

keys you have acquired.

Music

(Menu 6.3)

This menu displays music files you have

downloaded or imported from a computer.

Select a file. The music player opens.



p. 41

Sounds

(Menu 6.4)

This menu displays voice memos you have

recorded, and sound files you have

downloaded, received in messages, or

imported from a computer.

Playing a sound clip

1. Select a sound folder.

2. Select a sound clip. For a voice memo,

see

Voice recorder



p. 36

Using sound options

While playing a sound clip, press

Options

> to access the following options:

When you play a file from this menu,

without first adding it to the play list in the

music player, background play is not

supported.

Menu functions

My files

(Menu 6)

•

List

: return to the sound list.

•

Send via

: send the file via MMS, e-mail,

or Bluetooth.

•

Set as

: set the file as your ringtone or

as a ringtone for a Phonebook entry.

•

Activate key

: get a new licence key

when the key for the selected DRM file

expires.

•

Delete

: delete the file.

•

Rename

: change the file name.

•

Move to

: move the file to another folder

or to a memory card.

•

Copy to memory card

: copy the file to

a memory card.

•

Visible to Bluetooth

: share the

selected file or the files you want with

other Bluetooth devices.

•

Lock

Unlock

: lock the file to protect it

from being deleted, or unlock the file.

•

Details

: access the file properties.

•

Key management

: manage the licence

keys you have acquired.

Other files

(Menu 6.5)

Use this menu to view, without corruption,

various document files and files stored in the

phone’s memory. Available file formats are

*.doc, *.xls, *.ppt, *.pdf, and *.txt.

Viewing a document

Select a file. Picsel File Viewer runs to open

the document.

Use the following keys to view the

document:

• Depending on the file size or memory

capacity of

Picsel File Viewer, some files

may not open properly.

• If a document file contains languages

unsupported by Picsel File Viewer, the

content of

the document will not display

correctly.

Key Function

Up/Down/

Left/Right

Pans around the page.

Menu functions

Using document options

While viewing a document, press

Options

> or < > to access the following

options:

•

Full screen view

Normal view

: view

the document on a full screen, or return

to Normal view mode.

•

Show thumbnail

Hide thumbnail

display or hide the map of the current

page.

•

Zoom

: zoom in or out.

•

Fit to

: fit the document to the page size,

screen width, or screen height.

•

Go to

: move to another page of the

document.

•

Search word

: search for text in the

document.

•

Rotate

: rotate the document.

Fits the document to the

page size.

/ Zooms in or out.

Searches forward through

the document for the text

you want.

Returns to the first page.

Searches backward through

the document for the text

you want.

Returns to the previous

page.

Rotates the document.

Moves to the next page.

Moves to the last page.

Shows or hides the map of

the current page.

Key Function

Changes the display to Full

screen view or Normal

screen view.

Key Function

Menu functions

My files

(Menu 6)

•

Screen panning

Normal panning

change the panning mode to by screen

or by preset pixel.

•

Flow mode

: switch the screen to Flow

mode. The text is rearranged for easy

viewing in a text file (*.txt). You can

scroll through the text only by pressing

[Up] or [Down].

•

Hide controller

Show controller

: hide

or show the shortcut tool bar of the file

viewer.

•

Send via

: send the file via MMS, e-mail,

or Bluetooth.

•

Move to memory card

: move the file to

a memory card.

•

Copy to memory card

: copy the file to

a memory card.

•

Delete

: delete the selected file.

•

Rename

: change the file name.

•

Visible to Bluetooth

: share the file or

the files you want with other Bluetooth

devices.

•

Lock

Unlock

: lock the file to protect it

from being deleted, or unlock the file.

•

Details

: access the file properties.

Menu functions

•

Shortcuts

: view the functions of the

keys you can use in Picsel File Viewer.

Memory card

(Menu 6.6)

Use this menu to access the files stored on a

memory card. This menu is shown only

when a memory card is inserted into the

phone.

Memory status

(Menu 6.7)

Use this menu to view memory information

for media items in the phone’s memory or

on a memory card. For the phone’s memory,

press [Left] or [Right] to view the memory

status by size or number of items.

Calendar

(Menu 7)

The

Calendar

menu enables you to keep

track of your schedule.

To access this menu, press <

> in Idle

mode and select

Calendar

Selecting a day on the calendar

When you enter the

Calendar

menu, the

calendar in Month view appears with today’s

date indicated by a grey box.

• Press [Left] or [Right] to move by day.

• Press [Up] or [Down] to move by week.

• Press [ / ] to move by month.

Creating an item

You can store appointments, anniversaries,

and tasks on the calendar. More than one

item per day can be stored.

Entering an appointment

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

Appointment

Your phone is preset to use FAT16-formatted

memory cards. If you insert a FAT32-

formatted memory card, the phone will ask

you to reformat the memory card. If you do

not, you will not be able to access the card

from the phone.

Menu functions

Calendar

(Menu 7)

3. Enter information or change the settings:

•

Subject

: enter a title for the

appointment.

•

Details

: enter the appointment

details.

•

Start date

and

Start time

: enter

the starting date and time for the

appointment.

•

AM/PM

: select

in 12-hour

time format.

•

End date

and

End time

: enter the

ending date and time for the

appointment.

•

AM/PM

: select

in 12-hour

time format.

•

Location

: enter information about

the appointed location.

•

Alarm

: set an alarm for the

appointment.

•

Before

: set how long before the

appointment the alarm is to alert

you.

•

Alarm tone

: select an alarm tone.

•

Repeat

: set the appointment to

recur and select a repeat unit.

•

Until

: set the ending date, if the

appointment will recur.

4. Press <

Save

> to save the appointment.

Entering an anniversary

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

Anniversary

3. Enter information or change the settings:

•

Occasion

: enter information about

the anniversary.

•

Date

: enter the date.

•

Alarm

: select to set an alarm for the

anniversary.

•

Before

: set how long before the

anniversary the alarm is to alert you.

•

Alarm time

: enter the time for the

alarm to ring.

•

AM/PM

: select

in 12-hour

time format.

•

Alarm tone

: select an alarm tone.

•

Repeat every year

: set the phone

to remind you of the anniversary

every year.

4. Press <

Save

> to save the anniversary.

Menu functions

Entering a task

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

Task

3. Enter information or change the settings:

•

Task

: enter information about the

task.

•

Start date

: enter the starting date.

•

Due date

: enter the ending date.

•

Select priority

: select a priority

level.

4. Press <

Save

> to save the task.

Consulting the calendar

Once you have created items, the type icons

and the number of items for a specific day

appear at the bottom of the calendar.

• Appointment

•Anniversary

• Task

Viewing an item

1. Select a date on the calendar to display

the items for the day.

2. Select an item to view its details.

3. Press [Left] or [Right] to access the

other items scheduled for the selected

day.

While viewing an item, press <

Options

> to

access the following options:

•

Edit

: edit the item.

•

Create

: add a new item.

•

Send via

: send the item via SMS, MMS,

e-mail, or Bluetooth.

•

View by

: change the view mode of the

calendar.



p. 72

•

Delete

: delete the item.

•

Memory status

: access memory

information for the items stored on the

calendar.

Using calendar options

On the calendar, press <

Options

> to access

the following options:

•

View by

: change the view mode of the

calendar.



next section

•

Create

: add a new item.

•

Go to

: select today’s date or enter a

specific date.

Menu functions

Camera

(Menu 8)

•

Event list

: sort items by type of item.

•

Delete

: delete the items stored on the

calendar by using various deleting

options.

•

Missed alarm events

: view items

whose alarms you have missed.

•

Memory status

: access memory

information for the items stored on the

calendar.

Viewing items in a different mode

You can change the calendar display to Day

view or Week view. Press <

Options

> and

select

View by

→

a view mode.

Day view

You can view items for the selected date.

Select an item to view its details.

The following icons may display to indicate

the item status:

• Alarm set

• Recurring item

• Task priority (Red: high, Blue:

normal, Grey: low)

• Completed task

Week view

You can view items for the selected week. A

cell on the timetable indicates the presence

of a schedule item. Select a cell in the day

you want.

Camera

(Menu 8)

You can use the camera module embedded

in your phone to take photos and record

videos.

To access this menu, press <

> in Idle

mode and select

Camera

You can delete recurring items in Day

view only.

• Do not take photos of people without their

permission.

• Do not take photos in a place where

cameras are not allowed.

• Do not take photos in a place where you

may interfere with another person’s

privacy.

Menu functions

Taking a photo

You can take photos in various modes. The

camera produces JPEG photos.

Taking a photo

1. Access the

Camera

menu to turn on the

camera.

2. Make any desired adjustments.

• Press < > to access camera

options.



next section

• Use the keypad to change the camera

settings or switch to other

modes.



p. 74

3. Press [ ] to take a photo. The photo is

automatically saved in the

My photos

folder.

Using camera options in Capture

mode

In Capture mode, press < > to access the

following options:

•

Record video

: switch to Record mode.

•

Shooting mode

: take a photo in the

following modes:

Single shot

: take a photo in Normal

mode. You can select whether or not the

camera automatically saves a photo.

Multi-shot

: take a series of action stills.

You can select the number of photos the

camera will take and the shooting speed.

Mosaic shot

: take several stills and

save them in one frame. You can select

the layout.

•

Effects

: change the colour tone or apply

a special effect.

When you take a photo in direct sunlight or

in bright conditions, shadows may appear on

the photo.

To Press

access photo

options

Options



p. 75

send the photo by

MMS

[].



p. 47

delete the photo [

] and then

Yes

return to Capture

mode

Preview

> or

Back

To Press

Menu functions

Camera

(Menu 8)

•

Frames

: apply a decorative frame.

•

Timer

: set a time delay before the

camera takes a photo.

•

Go to My photos

: access the

photos

folder.

•

Camera settings

: change the default

settings for taking a photo.

Size

: select an image size.

Quality

: select an image quality setting.

Viewfinder

: select a preview screen.

Scene programs

: set whether or not to

use Night shot mode.

Shutter sound

: select the sound that

you hear when you press the shutter

release key, [ ].

Zoom sound

: turn the sound effect for

zooming on or off.

Brightness sound

: turn the sound

effect for brightness adjustment on or

off.

White balance

: adjust the colour

balance of the image. You can make your

photo appear warmer or cooler.

ISO

: change the ISO setting, which

controls the sensitivity of your camera.

For low light situations, select a higher

ISO number. The higher the ISO number,

the faster the camera shutter functions

and the more sensitive the camera is to

light. Higher ISO settings may bring

some distortion to an image.

•

Camera shortcuts

: view the functions

of the keys you can use in Capture

mode.

Using the keypad in Capture mode

You can use the keypad to customise your

camera settings in Capture mode.

Key Function

Left/Right Adjusts the brightness.

Up/Down Zooms in or out.

Flips the image vertically.

Shows the mirror image.

Switches to Record mode.



p. 75

Changes the image size.

Menu functions

Using photo options

After saving a photo, press <

Options

> to

access the following options:

•

View

: access one of the multi-shot

photos.

•

Viewfinder

: return to Capture mode.

•

Send via

: send the file via MMS, e-mail,

or Bluetooth.

•

Set as

: set the photo as wallpaper for

the main display or as a caller ID image

for a Phonebook entry.

•

Edit

: edit the photo using the Image

editor.



p. 36

•

Delete

: delete the file.

•

Rename

: change the file name.

•

Go to My photos

: access the

photos

folder.



p. 63

•

Lock

Unlock

: lock the file to protect it

from being deleted, or unlock the file.

•

Print via Bluetooth

: print the image by

connecting the phone to a printer via

Bluetooth. Some printers may not be

compatible with the phone.

•

Details

: access the file properties.

Recording a video

You can record a video of what is displayed

on the camera screen and save it.

Recording a video

Changes the image quality.

Changes the shooting mode.

Changes the colour tone or

applies a special effect.

Changes the white balance.

Selects a decorative frame.

Sets the timer.

Changes the ISO settings.

Sets whether or not to use

Night shot mode.

Goes to the

photos

folder.

Changes the preview screen.

Key Function

Menu functions

Camera

(Menu 8)

1. In Capture mode, press [

2. Make any desired adjustments.

• Press < > to access camera

options.



next section

• Use the keypad to change the camera

settings or switch to other

modes.



p. 77

3. Press [ ] to start recording.

4. Press [ ] or < >

to stop recording.

The video is automatically saved in the

My video clips

folder.

Using camera options in Record mode

In Record mode, press < > to access the

following options:

•

Take photo

: switch to Capture mode.

•

Effects

: change the colour tone or apply

a special effect.

•

Timer

: set a time delay before the

camera starts recording.

•

Go to My video clips

: access the

video clips

folder.

•

Camcorder settings

: change the

following settings for recording a video:

Recording mode

: select a video

recording mode.

Select

Normal

to record a video within

the limit of the currently available

memory. The video clip is saved in MP4

format.

Select

Limit for

multimedia

messages/wallpaper

to record a video

suitable for messaging or for setting as

wallpaper or caller ID image. The video

clip is saved in 3gp format.

Size

: select a frame size.

Quality

: select an image quality setting.

To Press

play back the video

clip

[].

access video

options

Options



p. 77

delete the video

clip

[

] and then <

Yes

return to Record

mode

Preview

Menu functions

Viewfinder

: select a preview screen.

Audio record

: record a video with

audio.

Zoom sound

: turn the sound effect for

zooming on or off.

Brightness sound

: turn the sound

effect for brightness adjustment on or

off.

White balance

: adjust the colour

balance of the image. You can make your

video appear warmer or cooler.

•

Camcorder shortcuts

: view the

functions of the keys you can use in

Record mode.

Using the keypad in Record mode

You can use the keypad to customise your

camera settings in Record mode.

Using video options

After saving a video clip, press <

Options

to access the following options:

Key Function

Left/Right Adjusts the brightness.

Up/Down Zooms in or out.

Flips the image vertically.

Shows the mirror image.

Switches to Capture

mode.



p. 73

Changes the frame size.

Changes the image quality.

Changes the video recording

mode.

Changes the colour tone or

applies a special effect.

Changes the white balance.

Mutes or unmutes audio.

Sets the timer.

Goes to the

My video clips

folder.

Changes the preview screen.

Key Function

Menu functions

Settings

(Menu 9)

•

Viewfinder

: return to Record mode.

•

Send via

: send the file via MMS, e-mail,

or Bluetooth.

•

Set as

: set the video clip, if saved as a

3gp file, as wallpaper for the main

display or a caller ID image for a

Phonebook entry.

•

Delete

: delete the file.

•

Rename

: change the file name.

•

Go to My video clips

: access the

video clips

folder.



p. 64

•

Lock

Unlock

: lock the file to protect it

from being deleted, or unlock the file.

•

Details

: access the file properties.

Settings

(Menu 9)

The

Settings

menu provides you with

various setting options to customise the

phone to your preferences and needs. You

can also reset the settings to their default

status.

To access this menu, press <

> in Idle

mode and select

Settings

Time and date

(Menu 9.1)

Use this menu to change the time and date

displayed on your phone. Before setting the

time and date, specify your time zone in the

World clock

menu.



p. 39

•

Time

: enter the current time.

•

AM/PM

: select

in 12-hour

time format.

•

Time format

: select a time format.

•

Date

: enter the current date.

•

Date format

: select a date format.

•

Calendar starting day

: set which day

of the week the calendar starts with.

•

Auto update

: activates the auto time

update feature. Your phone will read the

MCC (Mobile Country Code) from the

network and automatically update the

current time for the country that you are

in when you travel abroad.

Phone settings

(Menu 9.2)

Time information may not be updated

when you move to one time zone to

another within a country.

Menu functions

Many different features of your phone’s

system can be customised to suit your

preferences.

Language

(Menu 9.2.1)

Use this menu to select a language for the

display text. If you select

Automatic

, the

phone uses the same language as the SIM

card.

Greeting message

(Menu 9.2.2)

Use this menu to enter the greeting that is

displayed briefly when the phone is switched

on.

Shortcuts

(Menu 9.2.3)

You can use the Navigation keys as

shortcuts to access specific menus directly

from Idle mode. Use this menu to assign a

shortcut to a key. [Up] is fixed as a shortcut

to My Menu mode.

Assigning a shortcut menu

1. Select a key to be used as a shortcut

key.

2. Select a menu to be assigned to the key.

Using shortcut options

Press <

Options

> to access the following

options:

•

Change

: assign or change a shortcut

menu.

•

Remove

: deactivate the shortcut

assignment to the selected key.

•

Remove all

: deactivate all shortcut

assignments.

My menu

(Menu 9.2.4)

You can set up a menu of your own using

your favourite menu items, which can be

easily accessed by pressing [Up] in Idle

mode.

Setting up My menu item

1. Select an item to be changed.

2. Select the menu item you want.

Some menus may not be available,

depending on your service provider.

Menu functions

Settings

(Menu 9)

Using item options

Press

Options

> to access the following

options:

•

Assign

: assign an item.

•

Change

: change the selected item.

•

Remove

: remove the selected item.

•

Remove all

: remove all items.

Volume key

(Menu 9.2.5)

Use this menu to set whether the phone

mutes the call ringer or rejects a call if you

press and hold [ / ] when a call comes in.

Extra settings

(Menu 9.2.6)

You can turn the automatic redialling or

answering feature on or off.

•

Auto redial

: set the phone to make up

to ten attempts to redial a phone number

after an unsuccessful call.

•

Active flip

: answer an incoming call by

opening the phone.

•

Anykey

answer

: answer an incoming

call by pressing any key, except for

Reject

> and [ ].

Offline mode

(Menu 9.2.7)

Use this menu to switch the phone to Offline

mode or back to Online mode.

Display settings

(Menu 9.3)

Use this menu to change settings for the

display and backlight.

Wallpaper

(Menu 9.3.1)

You can set up the idle screen on the main

display.

•

Main display

: select an image or a

video clip to be displayed on the main

display.

•

Calendar wallpaper

: set the phone to

display the calendar.

•

Text position

: select a text position. If

you do not want to display text in Idle

mode, select

Off

•

Text mode

: select a font style.

•

Text colour

: select a font colour.

•

Graphic logo

: set the phone to display a

graphic icon instead of the service

Menu functions

provider’s logo on the idle screen. This is

only available if a graphic icon has been

received in a message.

Main menu style

(Menu 9.3.2)

You can select a display style for the main

menu screen.

Skin

(Menu 9.3.3)

You can select a skin colour pattern for Menu

mode.

Brightness

(Menu 9.3.4)

You can adjust the brightness of the display

for varying lighting conditions.

Dialing display

(Menu 9.3.5)

Use this menu to select a font type, and

colour and size for the numbers, and

background colour of the display while

dialling.

Show caller information

(Menu 9.3.6)

Use this menu to set the phone to display

missed call notifications with the most

recently missed caller’s information.

Sound settings

(Menu 9.4)

Use this menu to customise various sound

settings.

Incoming call

(Menu 9.4.1)

Use this menu to change the sound settings

for incoming calls.

•

Ringtone

: select a ringtone to be used

for the call ringer.

•

Volume

: select a ringtone volume.

•

Alert type

: specify how you are to be

informed of incoming calls.

Keypad tone

(Menu 9.4.2)

Use this menu to select the tone that the

phone sounds when you press a key.

Message tone

(Menu 9.4.3)

Use this menu to change the sound settings

for incoming SMS messages, MMS

messages, e-mails, and broadcast messages

individually.

•

Tone

: select one of several message

tones.

You can adjust the key tone volume using

[

] in Idle mode.

Menu functions

Settings

(Menu 9)

•

Alert type

: specify how you are to be

informed when a message comes in.

•

Repetition

: specify how often the phone

informs you of a new message.

Power on/off

(Menu 9.4.4)

Use this menu to select the melody that the

phone sounds when it is switched on or off.

Flip tone

(Menu 9.4.5)

Use this menu to select the tone that the

phone sounds when you open or close the

phone.

Silent mode

(Menu 9.4.6)

Use this menu to set how the phone acts to

alert you to a specific event while in Silent

mode.

Extra tones

(Menu 9.4.7)

Use this menu to customise additional tones

for the phone.

•

Minute

minder

: set the phone to beep

every minute during an outgoing call to

keep you informed of the length of your

call.

•

Connection

tone

: set the phone to

beep when an outgoing call connects to

the system.

•

Alert on call

: set the phone to beep

when you receive a new message or

when the time for an alarm comes during

a call.

•

Indicative

tone

: set the phone to beep

when a pop-up window displays.

Light settings

(Menu 9.5)

Use this menu to change the settings for the

light.

Backlight time

(Menu 9.5.1)

You can select the length of time the

backlight or display stays on.

•

Normal

: select the length of time the

backlight stays on.

•

Dimmed

: select the length of time the

display stays on in Dim mode after the

backlight turns off. After a specified time,

the display turns off.

•

Show cover indicators

: use this menu

to set whether or not the icons are

Menu functions

shown on the external display after the

display turns off.

Keypad light

(Menu 9.5.2)

Use this menu to set how the phone controls

the use of the keypad light. Select one of the

following options in the

Use at

line:

•

Any time

: the keypad light is always

used.

•

Night time

: the keypad light is used

only between 5:00 PM and 9:00 AM.

•

Custom time

: you can specify the time

period that the keypad light is used.

Network services

(Menu 9.6)

Use this menu to access network services.

Please contact your service provider to

check their availability and subscribe to

them, if you wish.

Call diverting

(Menu 9.6.1)

This network service reroutes incoming calls

to a phone number that you specify.

1. Select a call diverting option:

•

Divert always

: divert all calls.

•

Busy

: divert calls when you are on

another call.

•

: divert calls when you do

not answer the phone.

•

Unreachable

: divert calls when you

are not in your service area or when

your phone is switched off.

•

Cancel

all

: cancel all call diverting

options.

2. Select the type of calls to be diverted.

3. Select

Activate

. To deactivate call

diverting, select

Deactivate

4. Move to the

Divert to

line.

5. Enter the number to which calls are to be

diverted.

6. If you selected

No reply

, move to the

Seconds

line and select the length of

time the network delays before diverting

a call.

7. Press <

Select

Call barring

(Menu 9.6.2)

This network service allows you to restrict

your calls.

1. Select a call barring option:

•

All

outgoing calls

: prohibit all

outgoing calls.

Menu functions

Settings

(Menu 9)

•

International

: prohibit international

calls.

•

International except home

: only

allow calls to numbers within the

current country when you are

abroad, and to your home service

area.

•

All

incoming calls

: prohibit

incoming calls.

•

Incoming

while

abroad

: prohibit

incoming calls when you use your

phone outside of your home service

area.

•

Cancel

all

: cancel all call barring

settings, allowing calls to be sent and

received normally.

•

Change barring password

: change

the call barring password obtained

from your service provider.

2. Select the type of calls to be barred.

3. Select

Activate

. To deactivate call

barring, select

Deactivate

4. Enter the call barring password supplied

by your service provider and press

Select

Call waiting

(Menu 9.6.3)

This network service informs you when

someone is trying to reach you while you are

on another call.

1. Select the type of calls to which call

waiting option will apply.

2. Select

Activate

. To deactivate call

waiting, select

Deactivate

Network selection

(Menu 9.6.4)

This network service allows you to manually

select the network to be used while roaming

outside of your home area, or to let the

network be chosen automatically.

You can select a network other than your

home network only if there is a valid

roaming agreement between the two.

Caller ID

(Menu 9.6.5)

This network service allows you to hide your

phone number from the person you are

calling. If you select

Default

, the phone will

use the default setting provided by the

network.

Some networks may not allow you to

change this setting.

Menu functions

Voice mail server

(Menu 9.6.6)

Use this menu to store the number of the

voicemail server and access your voicemails.

•

Connect to voice server

: connect to

the voicemail server to listen to your

messages.

•

Voice server number

: enter the

voicemail server number.

Closed user group

(Menu 9.6.7)

Use this menu to set incoming and outgoing

calls to be restricted to a selected user

group. For details about how to create a

closed user group (CUG), contact your

service provider.

•

Index list

: add, delete, or activate CUG

index numbers.

•

Outside access

: enable calls to

numbers other than those in the closed

user group. This feature depends on the

nature of your CUG subscription.

•

Default group

: enable the default CUG,

if you have set one with your service

provider. When making a call, you are

given the option of using your default

CUG, instead of selecting one from the

list.

You must store the voicemail server number

before accessing the server. Your service

provider can give you the number.

Menu functions

Settings

(Menu 9)

Security

(Menu 9.7)

Use this menu to protect the phone against

unauthorised use by managing the several

access codes of your phone and SIM card.

PIN check

(Menu 9.8.1)

The 4- to 8-digit PIN (Personal Identification

Number) protects your SIM card against

unauthorised use. When this feature is

enabled, the phone requires your PIN each

time it is switched on.

Change PIN code

(Menu 9.8.2)

Use this menu to change your PIN. The PIN

check feature must be enabled to change

the PIN.

Phone lock

(Menu 9.8.3)

Use this menu to lock the phone from

unauthorised use.

When this feature is enabled, you must

enter a 4- to 8-digit phone password each

time the phone is switched on.

The password is preset to

00000000

. To

change the password, use the

Change

password

menu.

Change password

(Menu 9.8.4)

Use this menu to change your phone

password.

Privacy

(Menu 9.8.5)

Use this menu to lock access to messages,

media files, all menu functions on the

phone, except for call functions.

When a privacy option is enabled, you must

enter the phone password to access the

locked items or functions.

SIM lock

(Menu 9.8.6)

This menu allows your phone to work only

with the current SIM by assigning a SIM lock

code. You must enter the SIM lock code to

use a different SIM card.

Fixed dialling mode

(Menu 9.8.7)

If supported by your SIM card, Fixed Dialling

Number (FDN) mode restricts your outgoing

calls to a limited set of phone numbers.

When this feature is enabled, you can make

If you enter an incorrect PIN/PIN2 three

times, the SIM card is blocked. To unblock it,

you need to enter your PUK/PUK2 (Personal

Unblocking Key). The codes are supplied by

your service provider.

Menu functions

calls only to phone numbers stored on the

SIM card.

Change PIN2 code

(Menu 9.8.8)

If supported by your SIM card, use this

menu to change your current PIN2.

Mobile tracker

(Menu 9.8.9)

When someone tries to use your phone with

another SIM card, the phone will

automatically send the preset tracking

message to your family or friends. You can

check the phone number from which the

messages are sent and then track your

phone. This feature is useful when the phone

is stolen or lost.

1. Enter the phone password and press

2. Specify the following options:

•

Mobile tracker

: activate the Mobile

tracker feature.

•

Recipients

: specify phone numbers

to which you want to send the

tracking messages.

•

Sender

: enter the sender’s name.

•

Message

: check the preset tracking

message text.

3. When you have finished, press <

Save

Connection settings

(Menu 9.9)

Use this menu to create and customise the

profiles containing the settings for

connecting your phone to the network. You

need these settings to use the web browser

or send MMS messages or e-mails.

Sending of the tracking message will be

billed to the user of the unauthorised SIM

card. To use your phone with any other SIM

card, you must first deactivate the Mobile

tracker feature.

Your phone is set by default for connecting

to the network by default. If you change the

settings without first checking with your

service provider, the web browser, MMS, and

e-mail features may not work properly.

Menu functions

Settings

(Menu 9)

Creating a profile

1. Press <

New

>. If a profile has already

been saved, press <

Options

> and

select

Add new connection

2. Specify profile parameters:

•

Profile name

: enter a profile name.

•

Homepage URL

: enter the URL

address of the page to be used as

your homepage.

•

Proxy

: activate or deactivate the

proxy server.

•

IP address

: enter the IP address of

the proxy server.

•

Port

: enter the port number of the

proxy server.

•

Linger time

: set a time period after

which the network is disconnected if

there has been no new data traffic in

that time.

•

DNS

: activate or deactivate the DNS

(Domain Name Server) addresses.

•

DNS 1

and

DNS 2

: enter the primary

and secondary DNS addresses.

•

Bearer

: select the network bearer

type.

•

Advanced settings

: change the

advanced options. Depending on the

bearer setting, available options vary.

When the bearer is set to

GPRS

APN

: enter the access point name.

: enter the login ID.

Password

: enter the login

password.

When the bearer is set to

GSM

Dial number

: enter the PPP phone

number.

: enter the login ID.

Password

: enter the login

password.

Data call type

: select a call type for

data transmission.

3. Press <

Save

> to save the profile.

Using profile options

Press <

Options

> to access the following

options:

•

Edit

: edit the selected profile.

•

Delete

: delete the profile.

Solve problems

•

Add new connection

: add a new

profile.

Reset settings

(Menu 9.10)

Use this menu to reset the phone’s settings

you have changed.

1. Press [ ] to select the setting categories

to be reset.

2. Press <

Reset

3. Press <

> to confirm the reset.

4. Enter the phone password and press

Solve problems

Help and personal needs

To save the time and expense of an

unnecessary service call, perform the simple

checks in this section before contacting a

service professional.

When you switch on your phone, the

following messages may appear:

“Insert SIM card”

• Be sure that the SIM card is correctly

installed.

“Enter password”

• The automatic locking function has been

enabled. You must enter the phone’s

password before you can use the phone.

“Enter PIN”

• You are using your phone for the first

time. You must enter the PIN supplied

with the SIM card.

• The PIN check feature is enabled. Every

time the phone is switched on, the PIN

The password is preset to

00000000

You can change this password.



p. 86

Solve problems

Settings

(Menu 9)

has to be entered. To disable this

feature, use the

PIN check

menu.

“Enter PUK”

• The PIN has been entered incorrectly

three times, and the SIM card is now

blocked. Enter the PUK supplied by your

service provider.

“No service,” “Network failure,” or “Not

done” displays

• The network connection has been lost.

You may be in a weak signal area. Move

and try again.

• You are trying to access an option for

which you have no subscription with your

service provider. Contact the service

provider for further details.

You have entered a number but it was

not dialled

• Be sure that you have pressed [ ].

• Be sure that you have accessed the right

cellular network.

• Be sure that you have not set an

outgoing call barring option.

Your correspondent cannot reach you

• Be sure that your phone is switched on.

([ ] pressed for more than one

second.)

• Be sure that you are accessing the

correct cellular network.

• Be sure that you have not set an

incoming call barring option.

Your correspondent cannot hear you

speaking

• Be sure that you have switched on the

microphone.

• Be sure that you are holding the phone

close enough to your mouth. The

microphone is located at the bottom of

the phone.

The phone starts beeping and

“Warning. Low battery” flashes on the

display

• Your battery is insufficiently charged.

Recharge the battery.

The audio quality of the call is poor

Solve problems

• Check the signal strength indicator on

the display ( ). The number of bars

indicates the signal strength from strong

( ) to weak ( ).

• Try moving the phone slightly or moving

closer to a window if you are in a

building.

No number is dialled when you re-call a

Phonebook entry

•Use the

Contact list

menu to ensure the

number has been stored correctly.

• Re-store the number, if necessary.

The battery does not charge properly or

the phone sometimes turns itself off

• Wipe the charging contacts both on the

phone and on the battery with a clean

soft cloth.

If the above guidelines do not help you

to solve the problem, take note of:

• The model and serial numbers of your

phone

• Your warranty details

• A clear description of the problem

Then contact your local dealer or Samsung

after-sales service.

Health and safety

information

Exposure to Radio Frequency (RF)

Signals

Certification Information (SAR)

Your wireless phone is a radio transmitter

and receiver. It is designed and

manufactured not to exceed the exposure

limits for radio frequency (RF) energy set by

the Federal Communications Commission

(FCC) of the U.S. government. These FCC

exposure limits are derived from the

recommendations of two expert

organizations, the National Counsel on

Radiation Protection and Measurement

(NCRP) and the Institute of Electrical and

Electronics Engineers (IEEE). In both cases,

the recommendations were developed by

scientific and engineering experts drawn

from industry, government, and academia

after extensive reviews of the scientific

literature related to the biological effects of

RF energy.The exposure limit set by the FCC

for wireless mobile phones employs a unit of

measurement known as the Specific

Absorption Rate (SAR). The SAR is a

measure of the rate of absorption of RF

energy by the human body expressed in

units of watts per kilogram (W/kg). The FCC

requires wireless phones to comply with a

safety limit of 1.6 watts per kilogram (1.6

W/kg). The FCC exposure limit incorporates

a substantial margin of safety to give

additional protection to the public and to

account for any variations in

measurements.SAR tests are conducted

using standard operating positions accepted

by the FCC with the phone transmitting at its

highest certified power level in all tested

frequency bands. Although the SAR is

determined at the highest certified power

level, the actual SAR level of the phone while

operating can be well below the maximum

value. This is because the phone is designed

to operate at multiple power levels so as to

use only the power required to reach the

network. In general, the closer you are to a

wireless base station antenna, the lower the

power output.

Health and safety information

Before a new model phone is available for

sale to the public, it must be tested and

certified to the FCC that it does not exceed

the exposure limit established by the FCC.

Tests for each model phone are performed in

positions and locations (e.g. at the ear and

worn on the body) as required by the FCC.

Body-worn operations are restricted to

Samsung-supplied, approved, or non-

Samsung designated accessories that have

no metal and must provide at least 1.5 cm

separation between the device, including its

antenna (whether extended or retracted)

and the user's body. Non-compliance with

the above restrictions may result in violation

of FCC RF exposure guidelines.The FCC has

granted an Equipment Authorization for this

mobile phone with all reported SAR levels

evaluated as in compliance with the FCC RF

exposure guidelines. The maximum SAR

values for this model phone as reported to

the FCC are:

GSM 1900

• Head: 1.36 W/Kg.

• Body-worn: 0.243 W/Kg.

SAR information on this and other model

phones can be viewed on-line at

www.fcc.gov/oet/fccid. This site uses the

phone FCC ID number, A3LSGHS501i.

Sometimes it may be necessary to remove

the battery pack to find the number. Once

you have the FCC ID number for a particular

phone, follow the instructions on the website

and it should provide values for typical or

maximum SAR for a particular phone.

Additional product specific SAR information

can also be obtained at www.fcc.gov/cgb/

sar.

Consumer Information on Wireless

Phones

The U.S. Food and Drug Administration

(FDA) has published a series of Questions

and Answers for consumers relating to radio

frequency (RF) exposure from wireless

phones. The FDA publication includes the

following information:

What kinds of phones are the subject of

this update?

The term wireless phone refers here to

hand-held wireless phones with built-in

antennas, often called “cell”, ”mobile”, or

“PCS” phones. These types of wireless

phones can expose the user to measurable

radio frequency energy (RF) because of the

short distance between the phone and the

user's head. These RF exposures are limited

by Federal Communications Commission

safety guidelines that were developed with

the advice of FDA and other federal health

and safety agencies. When the phone is

located at greater distances from the user,

the exposure to RF is drastically lower

because a person's RF exposure decreases

rapidly with increasing distance from the

source. The so-called “cordless phones”,

which have a base unit connected to the

telephone wiring in a house, typically

operate at far lower power levels, and thus

produce RF exposures well within the FCC's

compliance limits.

Do wireless phones pose a health

hazard?

The available scientific evidence does not

show that any health problems are

associated with using wireless phones. There

is no proof, however, that wireless phones

are absolutely safe. Wireless phones emit

low levels of radio frequency energy (RF) in

the microwave range while being used. They

also emit very low levels of RF when in the

stand-by mode. Whereas high levels of RF

can produce health effects (by heating

tissue), exposure to low level RF that does

not produce heating effects causes no

known adverse health effects. Many studies

of low level RF exposures have not found

any biological effects. Some studies have

suggested that some biological effects may

occur, but such findings have not been

confirmed by additional research. In some

cases, other researchers have had difficulty

in reproducing those studies, or in

determining the reasons for inconsistent

results.

What is FDA's role concerning the

safety of wireless phones?

Under the law, FDA does not review the

safety of radiation-emitting consumer

products such as wireless phones before

they can be sold, as it does with new drugs

or medical devices. However, the agency has

authority to take action if wireless phones

are shown to emit radio frequency energy

(RF) at a level that is hazardous to the user.

Health and safety information

In such a case, FDA could require the

manufacturers of wireless phones to notify

users of the health hazard and to repair,

replace or recall the phones so that the

hazard no longer exists.Although the

existing scientific data do not justify FDA

regulatory actions, FDA has urged the

wireless phone industry to take a number of

steps, including the following:

• “Support needed research into possible

biological effects of RF of the type

emitted by wireless phones;

• “Design wireless phones in a way that

minimizes any RF exposure to the user

that is not necessary for device function;

and.

• “Cooperate in providing users of wireless

phones with the best possible

information on possible effects of

wireless phone use on human health.

FDA belongs to an interagency working

group of the federal agencies that have

responsibility for different aspects of RF

safety to ensure coordinated efforts at the

federal level. The following agencies belong

to this working group:

• “National Institute for Occupational

Safety and Health.

• “Environmental Protection Agency.

• ”Federal Communications Commission.

• “Occupational Safety and Health

Administration.

•“National Telecommunications and

Information Administration

The National Institutes of Health participates

in some interagency working group

activities, as well.FDA shares regulatory

responsibilities for wireless phones with the

Federal Communications Commission (FCC).

All phones that are sold in the United States

must comply with FCC safety guidelines that

limit RF exposure. FCC relies on FDA and

other health agencies for safety questions

about wireless phones.FCC also regulates

the base stations that the wireless phone

networks rely upon. While these base

stations operate at higher power than do the

wireless phones themselves, the RF

exposures that people get from these base

stations are typically thousands of times

lower than those they can get from wireless

phones. Base stations are thus not the

Health and safety information

primary subject of the safety questions

discussed in this document.

What are the results of the research

done already?

The research done thus far has produced

conflicting results, and many studies have

suffered from flaws in their research

methods. Animal experiments investigating

the effects of radio frequency energy (RF)

exposures characteristic of wireless phones

have yielded conflicting results that often

cannot be repeated in other laboratories. A

few animal studies, however, have

suggested that low levels of RF could

accelerate the development of cancer in

laboratory animals. However, many of the

studies that showed increased tumor

development used animals that had been

genetically engineered or treated with

cancer-causing chemicals so as to be pre-

disposed to develop cancer in absence of RF

exposure. Other studies exposed the

animals to RF for up to 22 hours per day.

These conditions are not similar to the

conditions under which people use wireless

phones, so we don't know with certainty

what the results of such studies mean for

human health.

Three large epidemiology studies have been

published since December 2000. Between

them, the studies investigated any possible

association between the use of wireless

phones and primary brain cancer, glioma,

meningioma, or acoustic neuroma, tumors

of the brain or salivary gland, leukemia, or

other cancers. None of the studies

demonstrated the existence of any harmful

health effects from wireless phones RF

exposures. However, none of the studies can

answer questions about long-term

exposures, since the average period of

phone use in these studies was around three

years.

What research is needed to decide

whether RF exposure from wireless

phones poses a health risk?

A combination of laboratory studies and

epidemiological studies of people actually

using wireless phones would provide some

of the data that are needed. Lifetime animal

exposure studies could be completed in a

few years. However, very large numbers of

Health and safety information

animals would be needed to provide reliable

proof of a cancer promoting effect if one

exists. Epidemiological studies can provide

data that is directly applicable to human

populations, but ten or more years' follow-

up may be needed to provide answers about

some health effects, such as cancer. This is

because the interval between the time of

exposure to a cancer-causing agent and the

time tumors develop - if they do - may be

many, many years. The interpretation of

epidemiological studies is hampered by

difficulties in measuring actual RF exposure

during day-to-day use of wireless phones.

Many factors affect this measurement, such

as the angle at which the phone is held, or

which model of phone is used.

What is FDA doing to find out more

about the possible health effects of

wireless phone RF?

FDA is working with the U.S. National

Toxicology Program and with groups of

investigators around the world to ensure

that high priority animal studies are

conducted to address important questions

about the effects of exposure to radio

frequency energy (RF).FDA has been a

leading participant in the World Health

Organization international Electromagnetic

Fields (EMF) Project since its inception in

1996. An influential result of this work has

been the development of a detailed agenda

of research needs that has driven the

establishment of new research programs

around the world. The Project has also

helped develop a series of public information

documents on EMF issues.FDA and Cellular

Telecommunications & Internet Association

(CTIA) have a formal Cooperative Research

and Development Agreement (CRADA) to do

research on wireless phone safety. FDA

provides the scientific oversight, obtaining

input from experts in government, industry,

and academic organizations. CTIA-funded

research is conducted through contracts to

independent investigators. The initial

research will include both laboratory studies

and studies of wireless phone users. The

CRADA will also include a broad assessment

of additional research needs in the context

of the latest research developments around

the world.

Health and safety information

What steps can I take to reduce my

exposure to radio frequency energy

from my wireless phone?

If there is a risk from these products - and

at this point we do not know that there is - it

is probably very small. But if you are

concerned about avoiding even potential

risks, you can take a few simple steps to

minimize your exposure to radio frequency

energy (RF). Since time is a key factor in

how much exposure a person receives,

reducing the amount of time spent using a

wireless phone will reduce RF exposure.

• “If you must conduct extended

conversations by wireless phone every

day, you could place more distance

between your body and the source of the

RF, since the exposure level drops off

dramatically with distance. For example,

you could use a headset and carry the

wireless phone away from your body or

use a wireless phone connected to a

remote antenna.

Again, the scientific data do not demonstrate

that wireless phones are harmful. But if you

are concerned about the RF exposure from

these products, you can use measures like

those described above to reduce your RF

exposure from wireless phone use.

What about children using wireless

phones?

The scientific evidence does not show a

danger to users of wireless phones,

including children and teenagers. If you

want to take steps to lower exposure to

radio frequency energy (RF), the measures

described above would apply to children and

teenagers using wireless phones. Reducing

the time of wireless phone use and

increasing the distance between the user

and the RF source will reduce RF exposure.

Some groups sponsored by other national

governments have advised that children be

discouraged from using wireless phones at

all. For example, the government in the

United Kingdom distributed leaflets

containing such a recommendation in

December 2000. They noted that no

evidence exists that using a wireless phone

causes brain tumors or other ill effects. Their

recommendation to limit wireless phone use

Health and safety information

by children was strictly precautionary; it was

not based on scientific evidence that any

health hazard exists.

Do hands-free kits for wireless phones

reduce risks from exposure to RF

emissions?

Since there are no known risks from

exposure to RF emissions from wireless

phones, there is no reason to believe that

hands-free kits reduce risks. Hands-free kits

can be used with wireless phones for

convenience and comfort. These systems

reduce the absorption of RF energy in the

head because the phone, which is the source

of the RF emissions, will not be placed

against the head. On the other hand, if the

phone is mounted against the waist or other

part of the body during use, then that part

of the body will absorb more RF energy.

Wireless phones marketed in the U.S. are

required to meet safety requirements

regardless of whether they are used against

the head or against the body. Either

configuration should result in compliance

with the safety limit.

Do wireless phone accessories that

claim to shield the head from RF

radiation work?

Since there are no known risks from

exposure to RF emissions from wireless

phones, there is no reason to believe that

accessories that claim to shield the head

from those emissions reduce risks. Some

products that claim to shield the user from

RF absorption use special phone cases, while

others involve nothing more than a metallic

accessory attached to the phone. Studies

have shown that these products generally do

not work as advertised. Unlike °×hand-

free°± kits, these so-called °×shields°±

may interfere with proper operation of the

phone. The phone may be forced to boost its

power to compensate, leading to an increase

in RF absorption. In February 2002, the

Federal trade Commission (FTC) charged

two companies that sold devices that

claimed to protect wireless phone users from

radiation with making false and

unsubstantiated claims. According to FTC,

these defendants lacked a reasonable basis

to substantiate their claim.

100

Health and safety information

What about wireless phone interference

with medical equipment?

Radio frequency energy (RF) from wireless

phones can interact with some electronic

devices. For this reason, FDA helped develop

a detailed test method to measure

electromagnetic interference (EMI) of

implanted cardiac pacemakers and

defibrillators from wireless telephones. This

test method is now part of a standard

Samsung Electronics Co SGHX520 Single-Band PCS GSM Phone User Manual FCC ducument X210218

Samsung Electronics Co Ltd Single-Band PCS GSM Phone FCC ducument X210218

Users Manual

Navigation menu

Namespaces

Views

Navigation
