Samsung Electronics Co SGHX530 Single-Band PCS GSM Phone User Manual
Samsung Electronics Co Ltd Single-Band PCS GSM Phone
Users Manual
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-XXXXXA
English(EU). 09/2006. Rev1.0
*
Depending on the software installed or your service provider or country,
some of the descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear
different from the illustrations in this guide.
SGH-X530
User’s Guide
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
Drive safely at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Interference
All wireless phones may be subject to interference,
which could affect their performance..
Important safety precautions
1
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved batteries and
accessories, such as headsets and PC data cables. Use
of any unauthorised accessories could damage you or
your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 61.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
At very high volumes, prolonged
listening to a headset can damage your
hearing.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful
attention to the subsequent information
regarding safety or phone features.
Indicates that you can get more information
on the referenced page.
→
Indicates that you need to press the
Navigation keys to scroll to the specified
option and then select it.
[ ]
Indicates a key on the phone. For example,
[]
< >
Indicates a soft key, whose function is
displayed on the phone screen. For example,
<
Menu
>
•Tri-band operation
Use your phone in worldwide GSM networks, in
any of 900, 1800, and 1900 bands.
Special
features of your phone
• Simple, compact design with Intenna
Samsung’s powerful intenna technology allows
the best call quality without an annoying
external antenna.
•IrDA
Send and receive Phonebook
entries via an infrared port.
3
Special features of your phone
•Web browser
Access the wireless web to get
current information and up-to-
the-minute a wide variety of
media content.
•Java
Enjoy Java
™
-based embedded
games and download new
games.
•Phonebook
Store home, office, or cellular
phone numbers for your
contacts.
• Multimedia Message Service (MMS)
Send and receive MMS messages with a
combination of text, images, and sounds.
• Calendar and to do list
Keep track of your daily and
monthly schedules and tasks.
•Alarm
Use your phone as an alarm
clock to wake you up in the
morning or notify you to an
event.
•Calculator
Perform basic calculations and
do currency conversions.
• Voice recorder
Record memos or sounds.
4
Contents
Unpack 6
Your phone 6
Buttons, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone..................................... 7
Power on or off........................................................ 8
Keys and display ..................................................... 9
Access menu functions ............................................ 11
Customise your phone............................................. 12
Make/Answer calls .................................................. 13
Step outside the phone 14
Begin with games, web, messages, and other special
features
Play games............................................................ 14
Browse the web...................................................... 14
Use Phonebook ...................................................... 15
Send messages...................................................... 16
View messages....................................................... 17
Enter text 18
Pinyin, Stroke, Quick English(T9), English, Number, and
Symbol modes
Call functions 24
Advanced calling features
Menu functions 28
All menu options listed
Solve problems 59
Help and personal needs
Health and safety information 61
5
Overview of menu functions
To access Menu mode, press <
Menu
> in Idle mode.
1 SIM AT
*
p. 28
2
2 Call records
p. 29
1 Missed calls
2 Received calls
3 Dialled calls
4 Delete all
5 Call time
6 Call cost
*
p. 29
p. 29
p. 29
p. 29
p. 29
p. 30
3 Network
services
p. 30
1 Call diverting
2 Call barring
3 Call waiting
4 Network selection
5 Caller ID
6 Closed user group
7 Band selection
p. 30
p. 31
p. 32
p. 32
p. 32
p. 32
p. 33
4 Sound settings
p. 33
1 Ring tone
2 Ring volume
3 Alert type
4 Keypad tone
5 Message tone
6 Ontime alarm
7 Alert on call
8 Folder tone
9 Power on/off
0 Extra tones
p. 33
p. 33
p. 33
p. 34
p. 34
p. 34
p. 34
p. 34
p. 34
p. 34
5 Messages
p. 35
1 Text messages
2 Multimedia
messages
3 Push messages
p. 35
p. 39
p. 42
6 Funbox
p. 43
1 WAP browser
2 Games
3 Sounds
4 Images
5 Delete all
6 Memory status
p. 43
p. 46
p. 46
p. 46
p. 47
p. 47
7 Organiser
p. 47
1 Alarm
2 Calendar
3 Time & Date
4 Calculator
5 To do list
6 Voice memo
7 Currency exchange
p. 47
p. 48
p. 49
p. 49
p. 49
p. 50
p. 51
8 Phonebook
p. 51
1 Search
2 New entry
3 Group search
4 Edit group
5 Speed dial
6 Delete all
7 Memory status
8 SDN*
p. 52
p. 52
p. 53
p. 53
p. 53
p. 54
p. 54
p. 54
9 Phone settings
p. 54
1 Infrared activate
2 Display settings
3 Greeting message
4 Own number
5 Language
6 Security
7 Extra settings
8 Short cut
9 Reset settings
p. 54
p. 56
p. 56
p. 57
p. 57
p. 57
p. 58
p. 58
p. 59
*Shows only if supported by your
SIM card.
6
Unpack
Make sure you have each item
• Phone
•Travel Adapter
• Battery
• User‘s Guide
You can obtain various accessories from your local
Samsung dealer.
Your phone
Buttons, features, and locations
The items supplied with your phone and the accessories
at your Samsung dealer may vary, depending on your
service provider.
Web access/
Confirm key
In Idle mode,
accesses the web
browser.
Selects the
h
ighlighted optionor
confirms input in a
menu mode.
Volume keys
n Idle mode, adjust
the keypad tone
volume.
S
end SOS messages
when pressed four
t
imes.
X
SOS mode
Dial key
Make and answer a
call. In Idle mode,
retrieve the most
recent calls.
Voicemail server key
Alphanumeric
keys
Power/End key
Turns the phone on or off
when pressed and held.
Also ends a call.
Cancel/Clear key
Deletes characters from
the display. Returns the
display to the previous
menu level.
Silent mode key
4-way navigation keys
In Menu mode, scroll
through menu options.
In Idle mode, access your
favourite menus directly.
Soft keys
Perform functions indicated
by the text above the key.
Infrared port
Alphanumeric keys
Voicemail server key
Dial key
Make and answer a
call. In Idle mode,
retrieve the most
recent calls.
Volume keys
In Idle mode, adjust the
keypad tone volume.
Send SOS messages
when pressed four
times.
X
SOS mode
Web access/
Confirm key
In Idle mode, accesses
the web browser.
Selects the highlighted
optionor confirms input
in a menu mode.
Alphanumeric keys
Voicemail server key
Dial key
Make and answer a
call. In Idle mode,
retrieve the most
recent calls.
Volume keys
In Idle mode, adjust the
keypad tone volume.
Send SOS messages
when pressed four
times.
X
SOS mode
Web access/
Confirm key
In Idle mode, accesses
the web browser.
Selects the highlighted
optionor confirms input
in a menu mode.
Alphanumeric keys
Voicemail server key
Dial key
Make and answer a
call. In Idle mode,
retrieve the most
recent calls.
Volume keys
In Idle mode, adjust the
keypad tone volume.
Send SOS messages
when pressed four
times.
X
SOS mode
Web access/
Confirm key
In Idle mode, accesses
the web browser.
Selects the highlighted
optionor confirms input
in a menu mode.
7
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you receive
a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your
PIN, and available optional services.
Install and charge the phone
Open the cover.
If the
phone is already
on, first turn it off by
holding [ ].
Insert the SIM card.
Make sure that the
gold-coloured contacts
on the card face down
into the phone.
Install the battery. Close the cover.
Plug the travel adapter into the phone.
When the phone is completely charged (the
battery icon becomes still), unplug the adapter
from the power outlet.
8
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
Remove the adapter from the phone.
Power on
Do not turn on
the phone when
mobile phone
use is prohibited.
1. Open the phone.
2. Press and hold [ ] to turn on
the phone.
3. If necessary, enter the PIN and
press <
OK
>.
Power off
1. Open the phone.
2. Press and hold [ ].
9
Get started
Keys and display
Keys
Perform the function indicated on the
bottom line of the display.
In Idle mode, access your favourite menus
directly.
p. 58
In Menu mode, scroll through menu
options.
In Idle mode, launch the web browser.
In Menu mode, select the highlighted
menu option or confirm input.
Make or answer a call.
In Idle mode, retrieve the recent numbers
dialled, missed, or received.
Delete characters from the display.
In Menu mode, return to the previous
menu level.
End a call.
Press and hold to switch the phone on or
off.
In Menu mode, cancel input and return the
phone to Idle mode.
Enter numbers, letters, and some special
characters.
In Idle mode, press and hold
[1]
to access
your voicemail server. Press and hold [
0
]
to enter an international call prefix.
Enter special characters.
In Idle mode, press and hold
[]
to
activate or deactivate Silent mode. Press
and hold [ ] to enter a pause between
numbers.
Adjust the phone volume.
In Idle mode, adjust the keypad tone
volume.
10
Get started
Display
Layout
Icons
Received signal strength
Call in progress
Out of your service area; you
cannot send or receive calls
IrDA feature active
Call diverting feature active
p. 30
Text and graphics
display messages,
instructions, and
information you enter.
Soft key function
indicators
show the current
functions assigned to
the two soft keys.
Icons
display various icons.
Menu Phonebook
GPRS network
Roaming
New text message
New voicemail message
New multimedia message
Active Silent mode or call ringer
set to vibrate
p. 13, p. 33
Mute mode
p. 27
Alarm set
Battery power level
11
Get started
Access menu functions
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current role.
Press the left soft
key to access
Menu mode.
Press the right soft
key to access the
Phonebook
menu.
Menu Phonebook
Select an
option
1. Press the appropriate soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press <
Select
>, <
OK
> or
[ ] to confirm the function
displayed or option highlighted.
4. To exit, choose either of the
following methods:
•Press <> or [
C
] to move
up one level.
• Press [ ] to return to Idle
mode.
Use shortcuts
Press the number key
corresponding to the option you
want.
12
Get started
Customise your phone
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Language
.
2. Select a language.
1. In Idle mode, press <
Menu
>
and select
Sound settings
→
Ring tone
.
2. Select a ringtone.
3. Select
Ring volume
.
4. Adjust the volume level.
5. Press <
OK
>.
Display
language
Call ringer
melody and
volume
You can set wallpaper for the idle
screen.
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Display settings
→
Wallpaper
→
Wallpaper list
.
2. Select the image you want.
3. Press <
Select
>.
You can set the Navigation keys as
shortcuts to access your favourite
menus.
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Short cut
.
2. Select a key.
3. Select a menu to be assign to
the key.
Idle mode
wallpaper
Menu
shortcuts
13
Get started
Make/Answer calls
You can switch the phone to Silent
mode to avoid disturbing other
people with your phone sounds.
Press and hold [ ] in Idle mode.
You can protect the phone against
unauthorised use with a phone
password. The phone will require
the password on power-up.
1. In Idle mode, press <
Menu
>
and select
Phone
settings
→
Security
→
Change
password
.
2. Enter the default password,
00000000
, and press <
OK
>.
3. Enter a new 4- to 8-digit
password and press <
OK
>.
4. Enter the new password again
and press <
OK
>.
Silent mode
Phone lock
5. Select
Phone lock
.
6. Select
Enable
.
7. Enter the password and press
<
OK
>.
1. Enter an area code and phone
number.
2. Press [ ].
3. To end the call, press [ ].
1. When the phone is ringing,
press [ ].
2. To end the call, press [ ].
Press [ / ].
Make a call
Answer a call
Adjust the
volume during
a call
14
Step outside the phone
Begin with games, web, messages, and other special
features
Play games
Browse the web
Using a built-in web browser, you can get easy access
to the wireless web to get a variety of up-to-date
services and information and to enjoy downloads of
web content.
1. In Idle mode, press <
Menu
>
and select
Funbox
→
Games
→
a game.
2. Select
START GAME
.
3. Select a game mode or press
[] or [
5
] to start the game.
1. Press the Navigation keys to
move the selection.
2. Press [
1
] or [
3
] to make a
horizontal or vertical line of
three identical bubbles.
Launch a game
Play
BubbleSmile
1. Press the Navigation keys to
move the selection to the
position you want to connect
the pipe.
2. Press [ ] or [
5
] to insert a
pipe.
3. Repeat until you complete the
pipeline.
In Idle mode, press and hold [ ].
Play Fun2Link
Launch the
web browser
15
Step outside the phone
Use Phonebook
• To scroll through browser items,
press [Up] or [Down].
• To select an item, press [ ].
• To return to the previous page,
press [
C
].
• To access browser options,
press
and hold [ ]
.
To the phone’s memory:
1. In Idle mode, enter a phone
number and press <
Save
>.
2. Select a number type.
3. Select
Phone
.
4. Enter a name and press <
OK
>
twice.
5. Press <
OK
> to save the entry.
Navigate
with the web
browser
Add an entry
To the SIM card:
1. In Idle mode, enter a phone
number and press <
Save
>.
2. Select a number type.
3. Select
SIM
.
4. Enter a name and press <
OK
>
twice.
5. Press <
OK
> to save the entry.
1. In Idle mode, press
<
Phonebook
>
and select
Search
.
2. Select an entry.
3. Scroll to a number and press
[] to dial, or <
Options
> to
access options.
Find an entry
16
Step outside the phone
Send messages
1. In Idle mode, press <
Menu
>
and select
Messages
→
Text
messages
→
Write new
.
2. Enter the message text.
3. Press <
Options
> and select
Save and send
or
Send only
.
4. If you selected
Save and send
,
select a memory location.
5. Enter a destination number and
press <
OK
>.
1. In Idle mode, press <
Menu
>
and select
Messages
→
Multimedia messages
→
Write new
.
2. Enter the message subject
press <
Next
>.
Send a text
message (SMS)
Send a
multimedia
message
(MMS)
3. Select
Add here
and add
message contents.
4. When you have finished, press
<
Options
> and select
Send
.
5. Select a destination type.
6. Select one of
Phone number
,
E-mail address
, or
Phonebook
.
7. Enter a destination number or
address, or select a number
from Phonebook and press
<
OK
>.
8. To add other destinations,
select
Add destination
and
repeat from step 6.
9. To add destinations of other
types, press < > and repeat
from step 5.
10.When you have finished, select
Send message
.
17
Step outside the phone
View messages
When a notification appears:
1. Press <
View
>.
2. Select a message from the
Inbox.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
Text
messages
→
Inbox
.
2. Select a message.
View a text
message
When a notification appears:
1. Press <
View
>.
2. Press <
Options
> and select
Retrieve
.
3. Select a message from the
Inbox.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
Multimedia messages
→
Inbox
.
2. Select a message.
View a
multimedia
message
18
Enter text
Pinyin, Stroke, Quick English, English, Number, and
Symbol modes
You can enter text for some features such as
messaging, Phonebook, or Calendar, using Pinyin and
Stroke modes for Chinese, and Quick English and
English modes for English. You can also use Number
mode and Symbol mode.
Changing the text input mode
The text input mode indicator appears when the cursor
is in a text field.
Example
: Writing a text message
Changing the text input mode
In a text input field, press the right soft key until the
input mode indicator you want appears:
•: T9 mode
•: ABC mode
• : Number mode
• None: Symbol mode
T9 mode
1. Press
2
to
9
to start entering a word. Press each
key once for one letter.
Example: To enter “Hello” in T9 mode, press
4
,
3
,
5
,
5
, and
6
.
T9 predicts the word that you are typing, and it
may change with each key that you press.
2. Enter the whole word before editing or deleting
characters.
Text input mode
indicator
Write new
Options
Enter text
19
3. When the word displays correctly, go to step 4.
Otherwise, press
0
to display alternative word
choices for the keys that you have pressed.
For example, Of and Me use
6
and
3
.
4. Press to insert a space and enter the next
word.
ABC mode
Press the keys labelled with the character you want:
- once for the first character
- twice for the second character
- and so on.
For example, press
2
three times to enter “C” and
5
two times to enter “K.”
Number mode
Press the keys corresponding to the digits you want.
Symbol mode
Press the number keys corresponding to the symbol
you want and press the
OK
soft key. You can press
Up
or
Down
to display more symbols.
Tips for entering text
• To move the cursor, press the Navigation keys.
• To delete characters one by one, press
C
. To clear
the display, press and hold
C
.
• To insert a space between characters, press .
• To change case in T9 mode or ABC mode, press .
• To enter punctuation marks in T9 mode or ABC
mode, press
1
.
20
Call functions
Call functions
Advanced calling features
Making a call
1. In Idle mode, enter the area code and phone
number.
2. Press [ ].
Making an international call
1. In Idle mode, press and hold [
0
]. The
+
character
appears.
2. Enter the country code, area code, and phone
number, then press [ ].
Redialling recent numbers
1. In Idle mode, press [ ] to display the list of
recent numbers.
2. Scroll to the number you want and press [ ].
Making a call from Phonebook
Once you have stored a number in Phonebook, you
can dial the number by selecting it from
Phonebook.
p. 52
You can also use the speed dial feature to assign your
most frequently called numbers to specific number
keys.
p. 53
Dialling a number from the phone’s memory
1. In Idle mode, press and hold [
0
]. A + appears.
2. Enter the location number for the phone number
you want and press [ ].
3. Press [Up] or [Down] to scroll through other
numbers.
Press <
Dial
> or [ ] to dial the number you want.
• Press [
C
] to clear the last digit or press and hold
[
C
] to clear the whole display. You can move the
cursor to edit an incorrect digit.
• Press and hold
[]
to enter a pause between
numbers.
Call functions
21
Dialling a number from the SIM card
1. In Idle mode, enter the location number for the
phone number you want and press [ ].
2. Press [Up] or [Down] to scroll through other
numbers.
3. Press <
Dial
> or [ ] to dial the number you want.
Ending a call
Close the phone or press [ ].
Answering a call
When you receive an incoming call, the phone rings.
Press <
Accept
> or [ ] to answer the call.
Tips for answering a call
• When
Anykey
answer
is active, you can press
any key to answer a call, except for <
Reject
> or
[].
p. 58
• When
Active folder
is active, you can simply open
the phone.
p. 58
•Press <
Reject
> or [ ] to reject a call.
Viewing missed calls
If you have missed calls, the screen displays how
many calls you have missed.
1. Press <
View
>.
2. If necessary, scroll through the missed calls.
3. Press [ ] to dial the number you want.
Using the headset
Use the headset to make or answer calls without
holding the phone.
Connect the headset to the jack on the left side of the
phone.
The button on the headset works as listed below:
To Press
redial the last call the button twice.
answer a call and hold the button.
end a call and hold the button.
22
Call functions
Options during a call
You can access a number of functions during a call.
Adjusting the volume during a call
Use [ / ] to adjust the earpiece volume during a call.
Press [ ] to increase the volume level and [ ] to
decrease the volume level.
Placing a call on hold/Retrieving
Press <
Hold
> or <
Unhold
> to place the call on hold
or retrieve the call.
Making a second call
You can make another call if your network supports it.
1. Press <
Hold
> to put the call on hold.
2. Make the second call in the normal way.
3. Press <
Swap
> to switch between the calls.
4. Press <
Options
> and select
End
held
call
to end
the call on hold.
5. To end the current call, press [ ].
Answering a second call
You can answer an incoming call, if your network
supports it and you have activated the call waiting
feature.
p. 32
1. Press [ ] to answer the call. The first call is
automatically put on hold.
2. Press <
Swap
> to switch between the calls.
3. Press <
Options
> and select
End
held
call
to end
the call on hold.
4. To end the current call, press [ ].
Using the Speakerphone feature
Use your phone as a speaker phone to talk and listen
with the phone a short distance away.
Press <
Options
> and select
Loud speaker ON
/
Loud
speaker OFF
.
Using the menu functions
Press <
Options
> and select
Menu
.
23
Switching off the microphone
(
Mute mode
)
You can temporarily switch off your phone’s
microphone so that the other person on the phone
cannot hear you.
Press <
Options
> and select
Mute
or
Unmute
.
Muting or sending key tones
You can turn the key tones off or on.
Press <
Options
> and select
Mute keys
or
Send
keys
.
Sending a sequence of DTMF tones
Dual tone multi-frequency (DTMF) tones are the tones
used in phones for tone dialling.
You can send DTMF tones as a group after entering the
entire number you need to send or retrieving a
number from Phonebook. This feature is helpful for
entering a password or an account number when you
call an automated system, like a banking service.
1. When connected with a teleservice system, press
<
Options
> and select
Send
DTMF
.
2. Enter the number you need to send and press
<
OK
>.
Using Phonebook
You can access the
Phonebook
menu to locate or
store entries.
p. 51
Press <
Options
> and select
Phonebook
.
Making a multi-party call
Use this feature to allow as many as six people to join
a multi-party call, or conference call.
Your service provider must support multi-party calls
for you to use this feature.
Setting up a multi-party call
1. Call the first participant.
To communicate with answering machines or
computerised telephone systems,
Send keys
must
be selected.
24
Call functions
2. Call the second participant. The first call is
automatically put on hold.
3. Press <
Options
> and select
Join
. The first
participant is added to the multi-party call.
4. If desired, call another person or answer an
incoming call.
5. Press <
Options
> and select
Join
.
6. Repeat steps 4 and 5 as desired.
Having a private conversation with one
participant
1. Press <
Options
> and select
Select one
.
2. Select a name or number from the participant list.
3. Select
Private
.
You can talk privately with that person, while the
other participants converse with each other.
4. To return to the multi-party call, press <
Options
>
and select
Join
.
Disconnecting one participant
1. Press <
Options
> and select
Select one
.
2. Select a name or number from the participant list.
3. Select
Remove
.
The participant is dropped from the call, but the
call continues with the other parties.
4. Press [ ] to end the multi-party call.
Menu functions
SIM AT
(Menu 1)
25
Menu functions
All menu options listed
SIM AT
(Menu 1)
This menu is available if you use a SIM AT card that
provides additional services, such as news, weather,
sports, entertainment, and location services. Available
services may vary, depending on your service
provider’s plans.
For details, see your SIM card instructions or contact
your service provider.
To access this menu, press <
Menu
> in Idle mode and
select
SIM AT
.
Call records
(Menu 2)
Use this menu to view the calls you have dialled,
received, or missed, the length of your calls, and the
cost of your calls.
To access this menu, press <
Menu
> in Idle mode and
select
Call records
.
Missed calls
(Menu 2.1)
This menu displays the most recently received calls
that you did not answer.
Accessing a call record
1. Select a call record.
2. Press [ ] to dial or <
Options
> to access call
record options.
Using call record options
While viewing call details, press <
Options
> to access
the following options:
•
Edit
: change the number of the selected call
record.
•
Delete
: delete the selected call record.
26
Menu functions
Received calls
(Menu 2.2)
This menu displays the most recent calls you have
received.
Dialled calls
(Menu 2.3)
This menu displays the most recent calls you have
dialled.
Delete all
(Menu 2.4)
Use this menu to delete all of the records in each call
type.
1. Press [ ] to select the call types to be cleared.
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
Call time
(Menu 2.5)
This menu displays the time log for calls made and
received. The actual time invoiced by your service
provider will vary.
•
Last
call
time
: check the length of your last call.
•
Total
sent
: check the total length of all the calls
you have dialled.
•
Total
received
: check the total length of all the
calls you have received.
•
Reset
timers
: reset the call timers. You need to
enter the phone password.
Call cost
(Menu 2.6)
This network feature displays the cost of calls. This
menu is available only if your SIM card supports this
feature. Note that this is not intended to be used for
billing purposes.
•
Last
call
cost
: check the cost of your last call.
•
Total
cost
: check the total cost of all of your calls.
If the total cost exceeds the maximum cost set in
Set
max
cost
, you must reset the counter before
you can make another call.
•
Max
cost
: check the maximum cost limit set in
Set
max
cost
.
The password is preset to
00000000
. You can
change this password.
p. 57
Menu functions
Network services
(Menu 3)
27
•
Reset
counters
: reset the cost counters.
•
Set
max
cost
: set the maximum cost authorised
for your calls.
•
Price/Unit
: set the price per unit that is applied
when the cost of your calls is calculated.
Network services
(Menu 3)
Use this menu to access network services. Please
contact your service provider to check their availability
and subscribe to them, if you wish.
To access this menu, press <
Menu
> in Idle mode and
select
Network services
.
Call diverting
(Menu 3.1)
This network service reroutes incoming calls to a
phone number that you specify.
1. Select a call diverting option:
•
Divert always
: divert all calls.
•
Busy
: divert calls when you are on another
call.
•
No
reply
: divert calls when you do not answer
the phone.
•
Unreachable
: divert calls when you are not in
an area covered by your service provider or
when your phone is switched off.
•
Cancel
all
: cancel all call diverting options.
2. Select the type of calls to be diverted.
3. To activate call diverting, press <
Activate
>.
Otherwise, press <
Options
> and select
Remove
or
Change
.
4. Enter the number to which calls are to be diverted
and press <
OK
>.
5. If you selected
No reply
, select the length of time
the network delays before diverting a call and
press <
Select
>.
Call barring
(Menu 3.2)
This network service allows you to restrict your calls.
1. Select a call barring option:
•
All
outgoing
: prohibit all outgoing calls.
•
International
: prohibit international calls.
28
•
International
except
home
: only allow calls
to numbers within the current country when
you are abroad, and to your home country.
•
All
incoming
: prohibit incoming calls.
•
Incoming
while
abroad
: prohibit incoming
calls when you use your phone outside of your
home country.
•
Cancel
all
: cancel all call barring settings,
allowing calls to be sent and received normally.
•
Change barring password
: change the call
barring password obtained from your service
provider.
2. Select the type of calls to be barred.
3. Press <
Activate
>. To deactivate call barring,
press <
Deactivate
>.
4. Enter the call barring password supplied by your
service provider and press <
OK
>.
Call waiting
(Menu 3.3)
This network service informs you when someone is
trying to reach you while you are on another call.
1. Select the type of calls to which the call waiting
option will apply.
2. Press <
Activate
>. To deactivate call waiting,
press <
Deactivate
>.
Network selection
(Menu 3.4)
This network service allows you to either automatically
or manually select the network used when roaming
outside of your home area.
You can select a network other than your home
network only if there is a valid roaming agreement
between the two.
•
Automatic
: connect to the first available network
when roaming.
•
Manual
: select the network you want.
Menu functions
Network services
(Menu 3)
29
Caller ID
(Menu 3.5)
This network service allows you to prevent your phone
number from being displayed on the phone of the
person being called. However, some networks do not
allow the user to change this setting.
•
Default
: use the default setting provided by the
network.
•
Hide
number
: ensure your number does not
display on the other person’s phone.
•
Send
number
: send your number each time you
make a call.
Closed user group (CUG)
(Menu 3.6)
Use this menu to set incoming and outgoing calls to be
restricted to a selected user group. For details about
how to create a closed user group, contact your
service provider.
•
Index list
: list, add, or delete CUG index
numbers. Press <
Options
> to access the options
for setting up an index list.
•
Outside access
: enable calls to numbers other
than those in the Closed user group. This feature
depends on the nature of your CUG subscription.
•
Default group
: enable the default CUG, if you
have set one with your service provider. When
making a call, you are given the option of using
your default CUG, instead of selecting one from the
list.
•
Deactivate
: deactivate the CUG function, if the
default group is enabled or a CUG index is
selected.
Band selection
(Menu 3.7)
For the phone to make and receive phone calls, it
must register with an available network. Your phone
can handle any of the following types of networks:
GSM 1900 and Combined GSM 900/1800.
The country where you purchased your phone
determines the default band that it uses. When you
travel abroad, you must remember to change to an
appropriate band.
30
Menu functions
Sound settings
(Menu 4)
Use this menu to customise various sound settings.
To access this menu, press <
Menu
> in Idle mode and
select
Sound settings
.
Ring tone
(Menu 4.1)
Use this menu to select a ringtone for the call ringer.
You can select one of the default ring melodies or
downloaded sounds.
Ring volume
(Menu 4.2)
Use this menu to adjust the ringtone volume.
Alert type
(Menu 4.3)
Use this menu to specify how you are to be informed
of incoming calls.
•
Light only
: the service light flashes; the phone
neither rings nor vibrates.
•
Melody
: the phone rings using the selected
ringtone.
•
Vibration
: the phone vibrates but not rings.
•
Vibra+melody
: the phone vibrates three times
and then starts ringing.
Keypad tone
(Menu 4.4)
Use this menu to select the tone that the phone
sounds when you press a key.
Message tone
(Menu 4.5)
Use this menu to change the sound settings for
incoming SMS messages, MMS messages, and CB
messages individually.
•
SMS tone
: specify how you are informed of new
SMS messages.
•
SMS-CB tone
: specify how you are informed of
new cell broadcast (CB) messages.
•
MMS tone
: specify how you are informed of new
MMS messages.
You can adjust the keypad tone volume using
[/]
in Idle mode.
Menu functions
Messages
(Menu 5)
31
•
Repetition
: set how often the phone informs you
of new messages.
Ontime alarm
(Menu 4.6)
Use this menu to set the phone to sound an alert
every hour on the hour.
Alert on call
(Menu 4.7)
Use this menu to select whether or not the phone
informs you when you receive a new message or when
the time for an alarm comes during a call.
Folder tone
(Menu 4.8)
Use this menu to select the tone that the phone
sounds when you open or close the phone.
Power on/off
(Menu 4.9)
Use this menu to select the melody that the phone
plays when it is switched on or off.
Extra tones
(Menu 4.0)
Use this menu to customise additional tones for the
phone.
•
Error tone
: set the phone to beep when you make
a mistake.
•
Minute
minder
: set the phone to beep every
minute during an outgoing call to keep you
informed of the length of your call.
•
Connect
tone
: set the phone to beep when it is
connected to the system.
Messages
(Menu 5)
Use the
Messages
menu to send and receive short
messages, and multimedia messages. You can also
use push message, voicemail, and cell broadcast
message features.
To access this menu, press <
Menu
> in Idle mode and
select
Messages
.
Text messages
(Menu 5.1)
32
Menu functions
Short Message Service (SMS) allows you to send or
receive text messages including simple pictures,
melodies, and animated images.
Inbox
(Menu 5.1.1)
Use this menu to view received text messages.
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Send
: forward the message to other people.
•
Text reply
: reply to the sender.
•
Call
back
: call the sender.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Move to phone
: move the message from the SIM
card to the phone’s memory.
•
Move to SIM
: move the message from the
phone’s memory to the SIM card.
•
Select objects
: save images or sounds from the
message into your phone.
Outbox
(Menu 5.1.2)
Use this menu to view sent or saved text messages.
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Send
: forward the message to other people.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Move to phone
: move the message from the SIM
card to the phone’s memory.
•
Move to SIM
: move the message from the
phone’s memory to the SIM card.
•
Select objects
: save images or sounds from the
message into your phone.
Write new
(Menu 5.1.3)
Use this menu to create and send text messages.
Menu functions
Messages
(Menu 5)
33
1. Enter your message.
2. Press <
Options
> to access the following options:
•
Add objects
: add a sound, melody, picture, or
animated image to the message.
•
Add templates
: add a text template.
•
Add emoticon
: add an emoticon.
•
Add phonebook
: add a Phonebook entry.
•
Add bookmark
: add a web page’s address.
3. Press <
Options
> and select
Send only
,
Save
and send
or
Save only
.
4. If you select
Save and send
or
Save only
, select
a memory location.
5. Enter a destination number.
6. Press <
OK
>
to send the message.
Templates
(Menu 5.1.4)
Use this menu to preset maximum 5 templates to
write a text message.
While viewing the templates list, press <
Options
> to
access the following options:
•
Edit
: edit the template.
•
Send message
: send the template as an SMS
message.
•
Delete
: delete the template.
The maximum number of characters allowed in
a short message varies by service provider. If
your message exceeds the maximum number of
characters, the phone will split the message.
34
Menu functions
Emoticon templates
(Menu 5.1.5)
Your phone provides preset emoticons so that you can
use when writing a message. Use this menu to create
or edit emoticons.
While viewing the emoticon list, press <
Options
> to
access the following options:
•
Add
: add a new emoticon.
•
Edit
: edit the selected emoticon.
•
Send
: send a message using the emoticon.
•
Delete
: delete the emoticon.
Settings
(Menu 5.1.6)
Use this menu to customise the SMS settings.
•
Setting x
(where
x
is the setting group number):
each group has its own submenu.
Service centre
: store or changes the number of
your message centre.
Default destination
: store a default destination
number.
Default type
: set the default message type.
Default validity
: set the length of time your
messages are stored in the SMS server.
Setting name
: change the name of the setting
group.
•
Common settings
: the following options are
available:
Reply path
: allow the recipient to reply to you
through your message centre.
Delivery reports
: set the network to inform you
when your message has been delivered.
Bearer selection
: select the
GSM
or
GPRS
preferred
bearer type.
Delete all
(Menu 5.1.7)
Use this menu to delete all of text messages in each
message box.
1. Press [ ] to select the message boxes to be
cleared.
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
Memory status
(Menu 5.1.8)
The setting options available in this menu may vary
depending on your service provider.
Menu functions
Messages
(Menu 5)
35
Use this menu to check the number of SMS messages
you have stored and total number of SMS messages
you can store in each message box.
Voice mail
(Menu 5.1.9)
Use this menu to store the number of the voicemail
server and access your voicemails.
•
Connect to voice server
: connect to the voice
server to allow you to listen to your messages. You
can also connect to the voicemail server by
pressing and holding [
1
] in Idle mode.
•
Voice server number
: change the voicemail
server name or number.
Broadcast
(Menu 5.1.0)
The Cell Broadcast service delivers short messages on
various topics such as the weather or traffic.
Use this menu to change the settings for the service
and access broadcast messages.
•
Read
: open received messages.
The
Volatile
box saves network messages until
the phone is switched off.
The
Archive
box saves network messages
indefinitely. Press <
Options
> and select
Save
when a text notification appears. The message is
saved in the
Archive
box.
•
Receive
: select to receive broadcast messages, or
not.
•
Channel
list
: specify the channels from which you
receive broadcast messages.
•
Language
: select the preferred languages in
which broadcast messages display.
Please contact your service provider for details.
You must enter the voice server number before you
can access your voicemails. Your service provider
can give the voice server number.
36
Menu functions
Multimedia messages
(Menu 5.2)
Multimedia Message Service (MMS) delivers messages
containing a combination of text, picture, and sound,
from phone to phone or from phone to e-mail.
Inbox
(Menu 5.2.1)
This menu displays MMS messages that you have
received. The following icons tell you the message
status:
• notification that you have read
• notification that you have not read
• you are retrieving from the server
• the server is processing your request
• the server is failed to send
• you have read
• you have not read
While viewing a message, press <
Options
> to access
the following message options:
•
Delete
: delete the message.
•
Reply
: reply to the sender.
•
Callback
: call the sender.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Forward
: forward the message to other people.
•
Save picture
: save an image from the message
into the
Images
folder.
•
Save sound
: save a sound from the message into
the
Sounds
folder.
•
Properties
: access the message properties.
Outbox
(Menu 5.2.2)
This menu displays MMS messages that you have
sent. The following icons tell you the message status:
• currently being sent
• sent
• your phone couldn’t send
• to be sent
While viewing a message, press <
Options
> to access
the following options:
When you select a notification, you can access
Retrieve
to retrieve the message from the MMS
server.
Menu functions
Messages
(Menu 5)
37
•
Delete
: delete the message.
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Send
: send or resend the message.
•
Edit message
: edit the message.
•
Properties
: access the message properties.
Draft
(Menu 5.2.3)
After creating a multimedia message, you can store it
in this message box for sending later.
You can view a message and use the options the same
as in
Outbox
.
Write new
(Menu 5.2.4)
You can create and send an MMS message.
1. Enter the message subject and press <
OK
>.
2. Press <
Options
> and add message contents using
one of the following options:
•
Add text
: add message text.
•
Add picture
: add a picture to the message.
•
Add sound
: add a sound clip to the message.
•
Send
: send the message.
•
Save
: save the message in the
Draft
or
Templates
box.
•
Settings
: change the message settings.
•
Add destination
: enter destination numbers
or addresses.
•
Preview
: view the message you created.
3. If you want to change the added items, highlight
one and press <
Options
> to access the following
options:
•
Edit text
/
Edit picture
/
Edit sound
: edit the
text, picture, or sound.
•
Add page
: add pages. Move to each page by
pressing [Left] or [Right] on the message
screen.
•
Delete
: delete the item from your message.
•
Duration
: set how long one page displays.
After the specified time, the display
automatically scrolls to the next page.
The maximum size allowed for a message can
differ, depending on your service provider.
38
Menu functions
4. When you have finished, select
Send
from the
options.
5. Select a destination type (To, Cc, Bcc).
6. Select one of
Phone number
,
E-mail address
, or
Phonebook
.
7. Enter a phone number or an e-mail address, or
select a number from Phonebook and press <
OK
>.
8. To add more destinations, select
Add destination
and repeat from step 6.
9. To enter additional numbers or addresses to other
destination types, press < >and repeat from step
5.
10.When you have finished, select
Send message
.
Templates
(Menu 5.2.5)
This menu stores messages you saved as templates so
that you can use them to create new messages.
While viewing a message template, press <
Options
>
to access the following options:
•
Edit message
: send the message using the
template.
•
Delete
: delete the template.
Delete all
(Menu 5.2.6)
Use this menu to delete all of the messages in each
message box.
1. Press [ ] to select the message boxes to be
cleared.
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
Memory status
(Menu 5.2.7)
Use this menu to view the amount of memory
available for MMS messages and memory currently in
use in each message box.
Settings
(Menu 5.2.8)
You can customise the settings for sending and
receiving MMS messages.
•
Delivery report
: set the network to inform you
when your message has been delivered.
•
Read reply
: request a reply from the recipient.
Menu functions
Messages
(Menu 5)
39
•
Auto download
: set whether or not your phone
retrieves new incoming messages from the MMS
server without notifications.
•
Message acceptance
: select the category of
messages you want to receive.
•
Hide ID
: hide your phone number on the
recipient’s phone.
•
Expiry date
: set the length of time your messages
are stored in the message centre.
•
Delivery time
: set the time
delay before
messages are sent.
•
Priority
: set the priority level of your messages.
•
Report allowed
: send a delivery report from the
network to the sender.
•
Page duration
: set how long one page in your
outgoing messages displays. After a specified time,
the display automatically scrolls to the next page.
MMS profile
(Menu 5.2.9)
You can configure required network settings for MMS.
The last profile accessed is automatically activated for
sending or receiving subsequent messages.
•
Profile name
: assign a name to the MMS profile.
•
Connection URL
: enter the address of your MMS
server.
•
Security
: select a data transmission mode.
•
IP address
: enter the gateway address.
•
User name
: enter the user ID.
•
Password
: enter the password.
•
APN
: enter the access point name used for the
address of the MMS server.
Push messages
(Menu 5.3)
Use this menu to access messages from the web
server.
•
Inbox
: view push messages you have received.
Check with your service provider before you change
any MMS settings on your phone.
40
Menu functions
•
Receive
: determine whether or not your phone
receives push messages.
Never
: the phone rejects push messages.
Always
: the phone receives all push messages.
•
Delete all
: delete all push messages.
Funbox
(Menu 6)
The
Funbox
menu allows you to use the web browser,
play Java games, and access images and sounds
stored in the phone’s memory.
To access this menu, press <
Menu
> in Idle mode and
select
Funbox
.
WAP browser
(Menu 6.1)
The Wireless Application Protocol (WAP) browser on
your phone allows you to access the wireless web.
From the wireless web, you can access up-to-date
information and a wide variety of media content, such
as wallpapers and ringtones.
Home
(Menu 6.1.1)
Use this menu to connect your phone to the network
and load the homepage of the wireless web service
provider. You can also press [ ] in Idle mode.
Navigating with the web browser
Using page options
From any web page, press and hold [ ] to access the
following browser options:
•
Reload
: reload the current page with updated
information.
•
Home
: return to the homepage.
•
Go to URL
: enter a URL address manually.
To Press
scroll through browser items [Up] or [Down].
select a browser item [ ].
return to the previous page [
C
].
Menu functions
Funbox
(Menu 6)
41
•
Show URL
: view the URL address of the current
web page.
•
Edit home
: change the page to be used for your
homepage.
•
Clear cache
: delete information stored in the
cache.
•
Inbox
: read messages received from a web
server.
Exiting the web browser
Press [ ] to exit the browser.
Bookmarks
(Menu 6.1.2)
Use this menu to save URL addresses in order to
quickly access web pages.
Adding a bookmark
1. Select an empty location.
2. Enter a URL address and press <
Enter
>.
3. Enter a title for the bookmark and press <
Enter
>.
Using bookmark options
After saving an item, press <
Options
> to access the
following options:
•
Go
to URL
: access the website.
•
Edit
: edit the URL address and title of the
bookmark.
•
Delete
: delete the bookmark.
http://
(Menu 6.1.3)
Use this menu to manually enter a URL address and
access the associated web page.
Settings
(Menu 6.1.4)
Use this menu to set up servers for the web browser.
Contact your service provider for details about your
settings options.
For each server, the following options are available:
•
Profile
name
: assign a name to the server profile.
•
Homepage
URL
: set the address of your
homepage.
•
Security
: select a data transmission mode.
42
Menu functions
•
Bearer
: select a bearer for each type of network
address accessed;
GPRS
or
Data
.
When the bearer is set to
GPRS
:
•
IP address
: enter the web gateway address.
•
User name
: enter the user ID.
•
Password
: enter the password.
•
APN
: enter the access point name of the GPRS
network gateway.
When the bearer is set to
Data
:
•
IP address
: enter the web gateway address.
•
Login name
: enter the user ID.
•
Password
: enter the password.
•
Dial-up number
: enter the PPP server phone
number.
•
Data call type
: select a data call type.
Clear cache
(Menu 6.1.5)
Use this menu to clear the cache, which is the
temporary memory that stores the web pages you
have recently accessed.
Fun club
(Menu 6.2)
Use this menu to access Samsung Fun Cub, the preset
web site providing Samsung mobile phone users with
attractive download services of updated ringtones and
wallpapers. You can download:
• 4-level greyscale and colour images.
• polyphonic melodies.
• information and electronic catalogues for Samsung
Electronics products.
SFC home
(Menu 6.2.1)
Selecting this menu loads the Samsung Fun Club
homepage.
When you access Samsung Fun Club for the first
time, please launch the web browser first, then
access Samsung Fun Club. This service requires
web subscription and may be unavailable depending
on your local system and services.
Menu functions
Funbox
(Menu 6)
43
Service area
(Menu 6.2.2)
Each time you move to HongKong or China, you need
to change this setting to use the SFC service,
according to the area where you are.
Games
(Menu 6.3)
You can download Java applications from various
sources using the web browser, and store them in your
phone.
Launching a game
1. Select the game you want on the Games list.
2. On the startup screen of the game, you can access
the following options:
•
START GAME
: start a new game.
•
CONTINUE
: continue the last game you
played.
•
HIGH SCORE
: view the high score table. This
option may not be available for some games.
•
HOW TO PLAY
: view how to play the game
and the key functions for the game.
•
OPTION
: switch on or off the game sound.
3. Press [ ] to confirm your selection.
Viewing game information
Scroll to the game you want and press <
Info
>.
Sounds
(Menu 6.4)
This menu displays sounds downloaded from the
wireless web or received in messages.
While accessing a sound, press <
Options
> to access
the following options:
•
Rename
: change the sound name.
•
Delete
: delete the sound.
•
Set as ringtone
: set the sound as your ringtone.
Images
(Menu 6.5)
This menu displays images downloaded from the
wireless web or received in messages.
Java services may not available, depending on your
service provider.
44
Menu functions
While accessing an image, press <
Options
> to access
the following options:
•
Rename
: change the image name.
•
Delete
: delete the image.
•
Set as wallpaper
: set the image as your
wallpaper for the idle screen.
Delete all
(Menu 6.6)
Use this menu to delete all of the downloaded items in
the
Games
,
Sounds
, and
Images
folders.
1. Press [ ] to select the folders to be cleared.
2. Press <
Delete
>.
3. Press <
Yes
> twice to confirm the deletion.
Memory status
(Menu 6.7)
Use this menu to check the total amount of memory
for media items and the amount of memory currently
in use in each media box.
Organiser
(Menu 7)
The Organiser feature enables you to keep track of
your schedule and tasks, and to record voice memos.
You can also set the time and date and use convenient
features, such as an alarm clock, a calculator, and a
currency converter.
To access this menu, press <
Menu
> in Idle mode and
select
Organiser
.
Alarm
(Menu 7.1)
Use this menu to set alarms to ring at a specific time.
Setting an alarm
1. Select the type of alarm.
2. Enter the time for the alarm to sound and press
[].
3. Select
AM
or
PM
in 12-hour time format.
4. If you selected
Morning call
in step 1, choose
Monday to friday
or
Monday to saturday
.
Menu functions
Organiser
(Menu 7)
45
Stopping an alarm
• When the alarm sounds, press any key.
• To remove an alarm set, access it, press
<
Options
> and select
Remove alarm
.
• To remove all alarm sets, select
Remove alarm
from the Alarm screen.
Setting the alarm to ring even if the phone is
off
From the Alarm screen, select
Auto power
→
Enable
.
If the phone is off when it is time for the alarm to ring,
the phone switches on and sounds the alarm.
Calendar
(Menu 7.2)
Use this menu to consult the calendar, write memos,
or set alarms to act as a reminder.
Writing a memo
1. Select a date on the calendar.
2. Enter your memo and press <
OK
>.
3. Press [ ] to set an alarm to ring on the chosen
day.
Otherwise, press <
Skip
>.
4. Enter the time for the alarm and press [ ].
To select an alarm melody, press <
Melody
>.
5. Select
AM
or
PM
in 12-hour format.
The colour of the date on the calendar changes to
pink to indicate that a memo exists for that date.
Viewing a memo
1. Select a date which has memos from the calendar.
2. Press [Up] or [Down] to view other memos
scheduled for that day.
Using calendar memo options
On the calendar screen, press <
Options
> to access
the following options:
•
Search all
: view all of the memos you created.
•
Delete all
: delete all memos.
•
Go to date
: go to a specific date.
46
Menu functions
•
Exit
: exit the
Calendar
menu.
While viewing a memo, press <
Options
> to access
the following options:
•
New
: add a new memo.
•
Edit
: edit the memo.
•
Alarm
: set an alarm for the memo.
•
Delete
: delete the memo.
•
Copy to
: copy the memo to another date.
•
Move to
: change the date of the memo.
Time & Date
(Menu 7.3)
Use this menu to change the time and date displayed
on your phone. Before setting the time and date,
specify your time zone in
World time
.
•
Set time
: enter the current time.
•
Set date
: enter the current date.
•
World time
: set your local time zone and find out
what time it is in another part of the world.
•
Time format
: select 12-hour or 24-hour time
format.
•
Date format
: select a date format.
Calculator
(Menu 7.4)
Use this menu to perform basic arithmetic functions
such as addition, subtraction, multiplication, and
division.
1. Enter the first number.
• Press left soft key to insert a decimal point or a
bracket.
•
Press
[
] or [ ] to move the cursor.
2. Press the Navigation keys to access the math
function you want.
3. Enter the second number.
4. Press [ ] to view the result.
5. If necessary, repeat from step 2 to continue the
calculation.
To do list
(Menu 7.5)
Use this menu to create tasks and manage them.
Creating a task
Menu functions
Organiser
(Menu 7)
47
1. Press <
New
>.
2. Enter the first task and press <
OK
>.
3. Select a priority level.
4. Enter your deadline and press [ ].
Viewing the task
When you select the To do list menu, the tasks display
with a check mark, if the task has been done, and a
priority level indicator; for High, for Normal,
and for Low.
While viewing a task or the task list, press <
Options
>
to access the following options:
•
New
: add a new task.
•
Mark
: change the status of the task.
•
Edit
: edit the task.
•
Sort
: sort the task by priority or status.
•
Copy
: copy the task.
•
Copy to calendar
: copy the task to the calendar
as a memo.
•
Delete
: delete the task.
•
Delete all
: delete all tasks.
•
Exit
: exit the
To do list
menu.
Voice memo
(Menu 7.6)
Use this menu to record voice memos. A voice memo
can be up to 30 seconds.
Voice record
(Menu 7.6.1)
1. Press <
Record
> to start recording.
2. Speak into the microphone.
3. When you press <
Stop
>, or if the recording time
expires, the following options display:
•
Replay
: play back your memo.
•
Re-record
: discard the memo and record
another one.
•
Save
: save the memo.
•
Quit
: cancel your recording and exit the
Voice
memo
menu.
To change the status of a specific task, press [ ].
48
Menu functions
4. Select
Save
to save the voice memo.
5. Enter a name of the voice memo and press <
OK
>.
Memo list
(Menu 7.6.2)
Use this menu to access the list of voice memos you
have recorded. Select a memo to play it.
Press <
Options
> to access the following options:
•
Play
: play back your voice memo.
•
Send
: send the voice memo via MMS.
•
Rename
: change the name of the voice memo.
•
Information
: access the properties of the voice
memo.
•
Delete
: delete the voice memo.
Delete all
(Menu 7.6.3)
Use this menu to delete all of the voice memos you
have recorded at one time.
Memory status
(Menu 7.6.4)
You can check the total amount of memory and the
amount of memory currently in use for voice memos.
Currency exchange
(Menu 7.7)
Use this menu to do currency conversions.
1. Enter the rate of foreign currency and press
<
OK
>.
2. Enter the amount of the source currency you want
to convert and press <
OK
>.
The amount you entered and its equivalent value
in the foreign currency display.
Phonebook
(Menu 8)
You can store phone numbers on your SIM card and in
your phone’s memory. The SIM card and phone’s
memory are physically separate, but they are used as
a single entity called Phonebook.
To access this menu, press <
Menu
> in Idle mode and
select
Phonebook
, or press <
Phonebook
>.
Menu functions
Phonebook
(Menu 8)
49
Search
(Menu 8.1)
Use this menu to search for numbers in Phonebook.
Finding an entry
1. Enter the first few letters of the name that you
want to find.
2. Select the name you want from the list.
3. Scroll to a number and press [ ] to dial, or
<
Options
> to access Phonebook options.
Using Phonebook options
While viewing an entry, press <
Options
> to access
the following options:
•
Paste
: paste the number into the normal dialling
mode.
•
Edit
: edit entry information.
•
Delete
: delete the number from Phonebook.
•
Copy
: copy the number to the phone’s memory or
SIM card.
•
Caller group
: assign a caller group.
•
Add entry
: add a new entry.
•
Send via IrDA
: send the entry via infrared port.
New entry
(Menu 8.2)
Use this menu to add a new entry to Phonebook.
Storing an entry in the phone’s memory
1. Select a number type.
2. Select
Phone
.
3. Enter a name and press <
OK
> twice.
4. Enter a number or an e-mail address and press
<
Save
>.
5. Change the location number, if you want, and
press <
OK
>.
Storing an entry on the SIM card
1. Select a number type.
2. Select
SIM
.
3. Enter a name and press <
OK
> twice.
4. Enter a number and press <
Save
>
5. Change the location number, if you want, and
press <
OK
>.
50
Menu functions
Group search
(Menu 8.3)
Use this menu to search your entries in Phonebook in
caller groups.
1. Enter the first few letters of the group name.
2. Select a group and press <
View
>.
3. Select the name you want.
4. Press [ ] to dial the number or <
Options
> to
access Phonebook options.
Edit group
(Menu 8.4)
Use this menu to edit your caller groups’ properties.
From the group list, press <
Options
> to access the
following options:
•
Call ring tone
: set a ringtone for incoming calls
from the group.
•
SMS tone
: set a ringtone for incoming messages
from the group.
•
Graphic
: set a graphic icon for incoming calls from
the group.
•
Group name
: assign a name to the group.
Speed dial
(Menu 8.5)
Use this menu to assign speed dial numbers (2 to 9) to
eight of your most frequently called numbers.
Assigning speed dial entries
1. Select a key location from
2
to
9
. Key
1
is reserved
for your voicemail server.
2. Select the name you want from the Phonebook list.
3. Select the number you want.
Managing speed dial entries
While viewing the Speed dial screen, press
<
Options
> to access the following options:
•
Change
: assign a different number to a key.
•
Delete
: delete the speed dial setting for a key.
•
Delete all
: delete the speed dial settings for all
keys.
•
Number
: check the name and number assigned to
a key.
Menu functions
Phonebook
(Menu 8)
51
Dialling speed dial entries
Press and hold the appropriate key in Idle mode.
Delete all
(Menu 8.6)
Use this menu to delete all of the entries from
Phonebook.
1. Press [ ] to select the locations to be cleared.
2. Press <
Delete
>.
3. Enter the phone password and press <
OK
>.
4. Press <
Yes
> twice to confirm the deletion.
Memory status
(Menu 8.7)
Use this menu to check the total number of entries
you can store and the number of the entries you have
stored in Phonebook.
SDN
(Menu 8.8)
This menu is available if your SIM card supports
Service Dialling Numbers (SDN). Use this menu to
view the list of SDNs assigned by your service
provider, including emergency numbers, directory
enquiries, and voicemail numbers.
Scroll to the number you want and press <
Dial
> or
[].
52
Menu functions
Phone settings
(Menu 9)
Use this menu to customise your phone settings. You
can also reset the settings to their default values.
To access this menu, press <
Menu
> in Idle mode and
select
Phone settings
.
Infrared activate
(Menu 9.1)
Use this menu to send or receive data to or from IrDA-
compatible computers or phones through the infrared
port.
With PC
(Menu 9.1.1)
Use this menu to use the infrared feature with a
computer.
To use an infrared connection, you must:
• configure and activate an IrDA-compliant infrared
port on your PC.
• activate the infrared feature on the phone; the
IrDA icon ( ) appears on the top line of the
display.
• align the IrDA port on the phone with the IrDA port
on your phone computer or another phone.
The connection is ready for data transmission.
If there is no communication between your phone and
the IrDA-compliant device within 30 seconds
activating the feature, it is automatically deactivated.
With other phone
(Menu 9.1.2)
Use this menu to send or receive Phonebook entries
from another compliant phone.
Receiving data from another phone
1. Align the IrDA ports on both phones with each
other.
2. When the list of the received data displays, select
one of the two options:
Menu functions
Phone settings
(Menu 9)
53
To save an individual item:
1. Select the item you want from the list.
2. Press <
Options
> and select
Save
to save the
data.
Otherwise, select
Discard
to delete the data.
To save all data:
1. From the item list, press <
Options
> to select
one of the following options:
•
Save all vCard
: save all Phonebook entries.
•
Discard all vCard
: delete all Phonebook
entries.
2. When FDN (Fixed Dialling Number) mode is
enabled on your phone, enter the PIN2 and
press <
OK
>.
3. Press <
Save
> to save the entries.
Sending your Phonebook
You can send Phonebook entries via IrDA connection.
Display settings
(Menu 9.2)
Use this menu to change settings for the display and
light.
Wallpaper
(Menu 9.2.1)
You can change the background image and the
settings for the text of Idle mode.
•
Wallpaper list
: select a background image.
•
Text display
: determine the phone displays the
time and date.
•
Text colour
: select a text colour.
Brightness
(Menu 9.2.2)
You can adjust the brightness of the display for
varying lighting conditions.
Contrast
(Menu 9.2.3)
You can adjust the contrast of the display for varying
lighting conditions.
Backlight
(Menu 9.2.4)
You can select the length of time the backlight and the
display stay on.
54
Menu functions
•
Backlight on
: select the length of time the
backlight stays on.
•
Backlight dim
: select the length of time the
display is in Dimming mode after the backlight
turns off. After a specified time, the display turns
off.
Service light
(Menu 9.2.5)
The service LED on the front of the phone indicates
when service is available on the phone. Use this menu
to select whether or not the service light is used.
Graphic logo
(Menu 9.2.6)
Use this menu to display your service provider’s logo
instead of its name.
Dialling font colour
(Menu 9.2.7)
Use this menu to select a font colour for the numbers
entered while dialling.
Greeting message
(Menu 9.3)
Use this menu to enter the greeting that is displayed
briefly when the phone is switched on.
Own number
(Menu 9.4)
Use this feature to check your phone numbers, or to
assign a name to each of the numbers. Changes made
here do not affect the actual subscriber numbers on
your SIM card.
Language
(Menu 9.5)
Use this menu to select one of several languages for
the display text.
Security
(Menu 9.6)
Use this menu to protect the phone against
unauthorised use by managing the several access
codes of your phone and SIM card.
If you enter an incorrect PIN/PIN2 three times in
succession, the SIM card is blocked. To unblock it
you need to enter your PUK/PUK2 (Personal
Unblocking Key). The codes are supplied by your
network operator.
Menu functions
Phone settings
(Menu 9)
55
PIN check
(Menu 9.6.1)
The 4-to 8-digit PIN (Personal Identification Number)
protects your SIM card against unauthorised use.
When this feature is enabled, the phone requires your
PIN each time it is switched on.
Change PIN
(Menu 9.6.2)
Use this menu to change your PIN. The PIN check
feature must be enabled to use this feature.
Phone lock
(Menu 9.6.3)
The Phone lock feature locks the phone from
unauthorised use.
When this feature is enabled, you must enter a 4- to
8-digit phone password each time the phone is
switched on.
The password is preset to
00000000
. To change the
password, use the
Change password
menu.
Change password
(Menu 9.6.4)
Use this menu to change your phone password.
Privacy
(Menu 9.6.5)
Use this menu to lock your media contents, including
MMS messages, voice memos, images, and sounds.
1. Press [ ] to select the items to be locked.
2. Press <
OK
> to lock the marked items.
3. Enter the phone password and press <
OK
>.
To access a locked item, you need to enter the phone
password.
SIM lock
(Menu 9.6.6)
The SIM lock feature allows your phone to work only
with the current SIM by assigning a SIM lock code. You
must enter the SIM lock code to use a different SIM
card.
FDN mode
(Menu 9.6.7)
If supported by your SIM card, Fixed Dialling Number
(FDN) mode restricts your outgoing calls to a limited
set of phone numbers. When this feature is enabled,
you can make calls only to phone numbers stored on
the SIM card.
56
Menu functions
Change PIN2
(Menu 9.6.8)
If supported by your SIM card, the Change PIN2
feature changes your current PIN2.
Extra settings
(Menu 9.7)
You can turn the automatic redialling or answering
feature on or off.
•
Auto redial
: set the phone to make up to ten
attempts to redial a phone number after an
unsuccessful call.
•
Active folder
: answer an incoming calls by
opening the phone.
•
Anykey
answer
: answer an incoming call by
pressing any key, except <
Reject
> or [ ].
Short cut
(Menu 9.8)
You can use the Navigation keys as shortcut keys to
access specific menus directly from Idle mode. Use
this menu to change the shortcut assignments for the
keys.
1. Select a key to be used as a shortcut key.
2. Select a menu that will be assigned to the key.
Reset settings
(Menu 9.9)
Use this menu to reset the phone to its default
settings.
Enter the 4- to 8-digit phone password and press
<
OK
>.
The password is preset to
00000000
. You can
change this password.
p. 57
Solve problems
Phone settings
(Menu 9)
57
Solve problems
Help and personal needs
To save the time and expense of an unnecessary service
call, perform the simple checks in this section before
contacting a service professional.
When you switch on your phone, the
following messages may appear:
“Insert SIM card”
• Be sure that the SIM card is correctly installed.
“Phone locked Enter password”
• The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
“Enter PIN”
• You are using your phone for the first time. You
must enter the PIN supplied with the SIM card.
• The PIN check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the
PIN check
menu.
“Enter PUK”
• The PIN code has been entered incorrectly three
times in succession, and the phone is now blocked.
Enter the PUK supplied by your service provider.
“No service,” “Network failure,” or “Not
done” displays
• The network connection has been lost. You may be
in a weak signal area. Move and try again.
• You are trying to access an option for which you
have no subscription with your service provider.
Contact the service provider for further details.
You have entered a number but it was not
dialled
• Be sure that you have pressed [ ].
• Be sure you have accessed the right cellular
network.
• Be sure that you have not set an outgoing call
barring option.
58
Solve problems
Your correspondent cannot reach you
• Be sure your phone is switched on. ([ ] pressed
for more than one second.)
• Be sure you are accessing the correct cellular
network.
• Be sure that you have not set an outgoing call
barring option.
Your correspondent cannot hear you speaking
• Be sure you have switched off the microphone.
• Be sure you are holding the phone close enough to
your mouth. The microphone is located at the
bottom of the phone.
The phone starts beeping and “Warning Low
battery” flashes on the display
• Your battery is insufficiently charged. Recharge the
battery.
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ). The number of bars indicates the signal
strength from strong ( ) to weak ( ).
• Try moving the phone slightly or moving closer to a
window if you are in a building.
No number is dialled when you re-call a
Contacts entry
• Use the Phonebook Search feature to ensure the
number has been stored correctly.
• Re-store the number, if necessary.
The battery doesn’t charge properly or the
phone sometimes turns itself off
• Wipe the charging contacts both on the phone and
on the battery with a clean soft cloth.
If the above guidelines do not help you to
solve the problem, take note of:
• The model and serial numbers of your phone
•Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung after-sales
service.
Health and safety information
Phone
59
Health and safety information
Exposure to Radio Frequency (RF) Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
exposure limits for radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the
U.S. government. These FCC exposure limits are
derived from the recommendations of two expert
organizations, the National Counsel on Radiation
Protection and Measurement (NCRP) and the Institute
of Electrical and Electronics Engineers (IEEE). In both
cases, the recommendations were developed by
scientific and engineering experts drawn from
industry, government, and academia after extensive
reviews of the scientific literature related to the
biological effects of RF energy.
The exposure limit set by the FCC for wireless mobile
phones employs a unit of measurement known as the
Specific Absorption Rate (SAR). The SAR is a measure
of the rate of absorption of RF energy by the human
body expressed in units of watts per kilogram (W/kg).
The FCC requires wireless phones to comply with a
safety limit of 1.6 watts per kilogram (1.6 W/kg). The
FCC exposure limit incorporates a substantial margin
of safety to give additional protection to the public and
to account for any variations in measurements.
SAR tests are conducted using standard operating
positions accepted by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels
so as to use only the power required to reach the
network. In general, the closer you are to a wireless
base station antenna, the lower the power output.
60
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that
it does not exceed the exposure limit established by
the FCC. Tests for each model phone are performed in
positions and locations (e.g. at the ear and worn on
the body) as required by the FCC.
The highest SAR values for this model phone as
reported to the FCC are:
GSM 1900 Mode(Part 24)
• Head: 0.222 W/Kg.
• Body-worn: 0.241 W/Kg.
For body worn operation, this model phone has been
tested and meets the FCC RF exposure guidelines
whenused with a Samsung accessory designated for
this product or when used with an accessory that
contains no metal and that positions the handset a
minimum of 1.5 cm from the body.
Non-compliance with the above restrictions may result
in violation of FCC RF exposure guidelines. SAR
information on this and other model phones can be
viewed on-line at www.fcc.gov/oet/fccid. This site uses
the phone FCC ID number, A3LSGHX530. Sometimes
it may be necessary to remove the battery pack to find
the number. Once you have the FCC ID number for a
particular phone, follow the instructions on the
website and it should provide values for typical or
maximum SAR for a particular phone. Additional
product specific SAR information can also be obtained
at www.fcc.gov/cgb/sar.
Consumer Information on Wireless Phones
The U.S. Food and Drug Administration (FDA) has
published a series of Questions and Answers for
consumers relating to radio frequency (RF) exposure
from wireless phones. The FDA publication includes
the following information:
61
Health and safety information
What kinds of phones are the subject of this
update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called
“cell,” “mobile,” or “PCS” phones. These types of
wireless phones can expose the user to measurable
radio frequency energy (RF) because of the short
distance between the phone and the user's head.
These RF exposures are limited by Federal
Communications Commission safety guidelines that
were developed with the advice of FDA and other
federal health and safety agencies. When the phone is
located at greater distances from the user, the
exposure to RF is drastically lower because a person's
RF exposure decreases rapidly with increasing
distance from the source. The so-called “cordless
phones,” which have a base unit connected to the
telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures
well within the FCC's compliance limits.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that
any health problems are associated with using
wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless phones
emit low levels of radio frequency energy (RF) in the
microwave range while being used. They also emit
very low levels of RF when in the stand-by mode.
Whereas high levels of RF can produce health effects
(by heating tissue), exposure to low level RF that does
not produce heating effects causes no known adverse
health effects. Many studies of low level RF exposures
have not found any biological effects. Some studies
have suggested that some biological effects may
occur, but such findings have not been confirmed by
additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
62
What is FDA's role concerning the safety of
wireless phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as wireless
phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown
to emit radio frequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could
require the manufacturers of wireless phones to notify
users of the health hazard and to repair, replace or
recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
• “Support needed research into possible biological
effects of RF of the type emitted by wireless
phones;
• “Design wireless phones in a way that minimizes
any RF exposure to the user that is not necessary
for device function; and
• “Cooperate in providing users of wireless phones
with the best possible information on possible
effects of wireless phone use on human health.
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at
the federal level. The following agencies belong to this
working group:
• “National Institute for Occupational Safety and
Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health Administration
• “National Telecommunications and Information
Administration
The National Institutes of Health participates in some
interagency working group activities, as well.
63
Health and safety information
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission
(FCC). All phones that are sold in the United States
must comply with FCC safety guidelines that limit RF
exposure. FCC relies on FDA and other health agencies
for safety questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from
these base stations are typically thousands of times
lower than those they can get from wireless phones.
Base stations are thus not the primary subject of the
safety questions discussed in this document.
What are the results of the research done
already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in
their research methods. Animal experiments
investigating the effects of radio frequency energy
(RF) exposures characteristic of wireless phones have
yielded conflicting results that often cannot be
repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could
accelerate the development of cancer in laboratory
animals. However, many of the studies that showed
increased tumor development used animals that had
been genetically engineered or treated with cancer-
causing chemicals so as to be pre-disposed to develop
cancer in absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day.
These conditions are not similar to the conditions
under which people use wireless phones, so we don't
know with certainty what the results of such studies
mean for human health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use
64
Health and safety information
of wireless phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors of the brain
or salivary gland, leukemia, or other cancers. None of
the studies demonstrated the existence of any harmful
health effects from wireless phones RF exposures.
However, none of the studies can answer questions
about long-term exposures, since the average period
of phone use in these studies was around three years.
What research is needed to decide whether
RF exposure from wireless phones poses a
health risk?
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data that
are needed. Lifetime animal exposure studies could be
completed in a few years. However, very large
numbers of animals would be needed to provide
reliable proof of a cancer promoting effect if one
exists. Epidemiological studies can provide data that is
directly applicable to human populations, but ten or
more years' follow-up may be needed to provide
answers about some health effects, such as cancer.
This is because the interval between the time of
exposure to a cancer-causing agent and the time
tumors develop - if they do - may be many, many
years. The interpretation of epidemiological studies is
hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones.
Many factors affect this measurement, such as the
angle at which the phone is held, or which model of
phone is used.
What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
65
Health and safety information
FDA has been a leading participant in the World Health
Organization international Electromagnetic Fields
(EMF) Project since its inception in 1996. An influential
result of this work has been the development of a
detailed agenda of research needs that has driven the
establishment of new research programs around the
world. The Project has also helped develop a series of
public information documents on EMF issues.
FDA and Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative
Research and Development Agreement (CRADA) to do
research on wireless phone safety. FDA provides the
scientific oversight, obtaining input from experts in
government, industry, and academic organizations.
CTIA-funded research is conducted through contracts
to independent investigators. The initial research will
include both laboratory studies and studies of wireless
phone users. The CRADA will also include a broad
assessment of additional research needs in the
context of the latest research developments around
the world.
What steps can I take to reduce my exposure
to radio frequency energy from my wireless
phone?
If there is a risk from these products - and at this
point we do not know that there is - it is probably very
small. But if you are concerned about avoiding even
potential risks, you can take a few simple steps to
minimize your exposure to radio frequency energy
(RF). Since time is a key factor in how much exposure
a person receives, reducing the amount of time spent
using a wireless phone will reduce RF exposure.
• “If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of the
RF, since the exposure level drops off dramatically
with distance. For example, you could use a
headset and carry the wireless phone away from
your body or use a wireless phone connected to a
remote antenna.
66
Health and safety information
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are concerned
about the RF exposure from these products, you can
use measures like those described above to reduce
your RF exposure from wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower exposure
to radio frequency energy (RF), the measures
described above would apply to children and
teenagers using wireless phones. Reducing the time of
wireless phone use and increasing the distance
between the user and the RF source will reduce RF
exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at all. For
example, the government in the United Kingdom
distributed leaflets containing such a recommendation
in December 2000. They noted that no evidence exists
that using a wireless phone causes brain tumors or
other ill effects. Their recommendation to limit
wireless phone use by children was strictly
precautionary; it was not based on scientific evidence
that any health hazard exists.
Do hands-free kits for wireless phones reduce
risks from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free
kits can be used with wireless phones for convenience
and comfort. These systems reduce the absorption of
RF energy in the head because the phone, which is the
source of the RF emissions, will not be placed against
the head. On the other hand, if the phone is mounted
against the waist or other part of the body during use,
then that part of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are required to
meet safety requirements regardless of whether they
are used against the head or against the body. Either
configuration should result in compliance with the
safety limit.
67
Health and safety information
Do wireless phone accessories that claim to
shield the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head
from those emissions reduce risks. Some products
that claim to shield the user from RF absorption use
special phone cases, while others involve nothing
more than a metallic accessory attached to the phone.
Studies have shown that these products generally do
not work as advertised. Unlike “hand-free” kits, these
so-called “shields” may interfere with proper operation
of the phone. The phone may be forced to boost its
power to compensate, leading to an increase in RF
absorption. In February 2002, the Federal trade
Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users
from radiation with making false and unsubstantiated
claims. According to FTC, these defendants lacked a
reasonable basis to substantiate their claim.
What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason,
FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted
cardiac pacemakers and defibrillators from wireless
telephones. This test method is now part of a standard
sponsored by the Association for the Advancement of
Medical instrumentation (AAMI). The final draft, a joint
effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This
standard will allow manufacturers to ensure that
cardiac pacemakers and defibrillators are safe from
wireless phone EMI. FDA has tested wireless phones
and helped develop a voluntary standard sponsored by
the Institute of Electrical and Electronic Engineers
(IEEE). This standard specifies test methods and
performance requirements for hearing aids and
wireless phones so that no interference occurs when a
person uses a compatible phone and a compatible
hearing aid at the same time. This standard was
approved by the IEEE in 2000.
68
Health and safety information
FDA continues to monitor the use of wireless phones
for possible interactions with other medical devices.
Should harmful interference be found to occur, FDA
will conduct testing to assess the interference and
work to resolve the problem.
Additional information on the safety of RF exposures
from various sources can be obtained from the
following organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health Administration's
(OSHA):
http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
• National institute for Occupational Safety and
Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-Ionizing
Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board (UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug
Administration
http://www.fda.gov/cellphones
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime.
But an important responsibility accompanies the
benefits of wireless phones, one that every user must
uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a
car, practice good common sense and remember the
following tips:
Health and safety information
Phone
69
1. Get to know your wireless phone and its features,
such as speed dial and redial. If available, these
features help you to place your call without taking
your attention off the road.
2. When available, use a hands-free device. If
possible, add an additional layer of convenience
and safety to your wireless phone with one of the
many hands free accessories available today.
3. Position your wireless phone within easy reach. Be
able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your
voice mail answer it for you.
4. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions. Rain,
sleet, snow, ice and even heavy traffic can be
hazardous.
5. Do not take notes or look up phone numbers while
driving. Jotting down a “to do” list or flipping
through your address book takes attention away
from your primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your car
will be stationary. If you need to make a call while
moving, dial only a few numbers, check the road
and your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make
people you are talking with aware you are driving
and suspend conversations that have the potential
to divert your attention from the road.
8. Use your wireless phone to call for help. Dial 9-1-1
or other local emergency number in the case of
fire, traffic accident or medical emergencies.
Remember, it is a free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto accident, crime in
progress or other serious emergency where lives
are in danger, call 9-1-1 or other local emergency
number, as you would want others to do for you.
10.Call roadside assistance or a special non-
emergency wireless assistance number when
70
Health and safety information
necessary. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a
minor traffic accident where no one appears
injured, or a vehicle you know to be stolen, call
roadside assistance or other special non-
emergency number.
“The wireless industry reminds you to use your
phone safely when driving.”
For more information, please call 1-888-901-SAFE, or
visit our web-site www.wow-com.com
Provided by the Cellular Telecommunications &
Internet Association
Operating Environment
Remember to follow any special regulations in force in
any area and always switch your phone off whenever it
is forbidden to use it, or when it may cause
interference or danger. When connecting the phone or
any accessory to another device, read its user's guide
for detailed safety instructions. Do not connect
incompatible products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation of
the equipment and for the safety of personnel, it is
recommended that the equipment should only be used
in the normal operating position (held to your ear with
the antenna pointing over your shoulder).
Using Your Phone Near Other Electronic
Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against the
RF signals from your wireless phone. Consult the
manufacturer to discuss alternatives.
Health and safety information
Phone
71
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be maintained
between a wireless phone and a pacemaker to avoid
potential interference with the pacemaker.
These recommendations are consistent with the
independent research and recommendations of
Wireless Technology Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone is
switched on.
• should not carry the phone in a breast pocket.
• should use the ear opposite the pacemaker to
minimize potential interference.
If you have any reason to suspect that interference is
taking place, switch your phone off immediately.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you
may wish to consult your hearing aid manufacturer to
discuss alternatives.
Other Medical Devices
If you use any other personal medical devices, consult
the manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
information. Switch your phone off in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to
external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should also
consult the manufacturer of any equipment that has
72
Health and safety information
been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where posted
notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even
death.
Users are advised to switch the phone off while at a
refueling point (service station). Users are reminded of
the need to observe restrictions on the use of radio
equipment in fuel depots (fuel storage and distribution
areas), chemical plants or where blasting operations
are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such
as propane or butane), areas where the air contains
chemicals or particles, such as grain, dust or metal
powders, and any other area where you would
normally be advised to turn off your vehicle engine.
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well as
user programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should
never rely solely on any wireless phone for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not be
possible on all wireless phone networks or when
certain network services and/or phone features are in
use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
Health and safety information
Phone
73
2. Key in the emergency number for your present
location (for example, 911 or other official
emergency number). Emergency numbers vary by
location.
3. Press .
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular service
provider.
When making an emergency call, remember to give all
the necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut
off the call until given permission to do so.
Restricting Children's access to your Phone
Your phone is not a toy. Children should not be allowed
to play with it because they could hurt themselves and
others, damage the phone or make calls that increase
your phone bill.
FCC Notice and Cautions
FCC Notice
• This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
• This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation.This equipment generates, uses and can
radiate radio frequency energy and,if not installed
and used in accordance with the instructions, may
cause harmful interference to radio
communications.
74
Health and safety information
The phone may cause TV or radio interference if used in
close proximity to receiving equipment. The FCC can
require you to stop using the phone if such interference
cannot be eliminated.
Vehicles using liquefied petroleum gas (such as
propane or butane) must comply with the National
Fire Protection Standard (NFPA-58). For a copy of
this standard, contact the National Fire Protection
Association, One Battery march Park, Quincy, MA
02269, Attn: Publication Sales Division.
Cautions
Changes or modifications made in the radio phone,
not expressly approved by Samsung, will void the
user’s authority to operate the equipment.
Only use approved batteries, antennas
andchargers.
The use of any unauthorized accessories may be
dangerous and void the phone warranty if said
accessories cause damage or a defect to the phone.
Although your phone is quite sturdy, it is a complex
piece of equipment and can be broken. Avoid
dropping, hitting, bending or sitting on it.
However, there is no guarantee that
interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the
equipment and receiver.
-Connect the equipment into an outlet on a
circuit different from that to which the
receiver is conected.
-Consult the dealer or an experienced radio/
TV technician for help
Health and safety information
Phone
75
Other Important Safety Information
• Only qualified personnel should service the phone
or install the phone in a vehicle. Faulty installation
or service may be dangerous and may invalidate
any warranty applicable to the device.
• Check regularly that all wireless phone equipment
in your vehicle is mounted and operating properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as
the phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or
in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
• Switch your phone off before boarding an aircraft.
The use of wireless phone in aircraft is illegal and
may be dangerous to the aircraft's operation.
• Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
Product Performance
Getting the Most Out of Your Signal Reception
The quality of each call you make or receive depends
on the signal strength in your area. Your phone
informs you of the current signal strength by
displaying a number of bars next to the signal strength
icon. The more bars displayed, the stronger the signal.
If you're inside a building, being near a window may
give you better reception.
76
Health and safety information
Understanding the Power Save Feature
If your phone is unable to find a signal after 15
minutes of searching, a Power Save feature is
automatically activated. If your phone is active, it
periodically rechecks service availability or you can
check it yourself by pressing any key.
Anytime the Power Save feature is activated, a
message displays on the screen. When a signal is
found, your phone returns to standby mode.
Understanding How Your Phone Operates
Your phone is basically a radio transmitter and
receiver. When it's turned on, it receives and transmits
radio frequency (RF) signals. When you use your
phone, the system handling your call controls the
power level. This power can range from 0.006 watts to
0.2 watts in digital mode.
Maintaining Your Phone's Peak Performance
For the best care of your phone, only authorized
personnel should service your phone and accessories.
Faulty service may void the warranty.
There are several simple guidelines to operating your
phone properly and maintaining safe, satisfactory
service.
• Hold the phone with the antenna raised, fully-
extended and over your shoulder.
• Try not to hold, bend or twist the phone's antenna.
• Don't use the phone if the antenna is damaged.
• Speak directly into the phone's receiver.
• Avoid exposing your phone and accessories to rain
or liquid spills. If your phone does get wet,
immediately turn the power off and remove the
battery. If it is inoperable, call Customer Care for
service.
Health and safety information
Phone
77
Availability of Various Features/Ring
Tones
Many services and features are network dependent
and may require additional subscription and/or usage
charges. Not all features are available for purchase or
use in all areas. Downloadable Ring Tones may be
available at an additional cost. Other conditions and
restrictions may apply. See your service provider for
additional information.
Battery Standby and Talk Time
Standby and talk times will vary depending on phone
usage patterns and conditions. Battery power
consumption depends on factors such as network
configuration, signal strength, operating temperature,
features selected, frequency of calls, and voice, data,
and other application usage patterns.
Battery Precautions
• Never use any charger or battery that is damaged
in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network's base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out.
When the operation time (talk time and standby
time) is noticeably shorter than normal, it is time
to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
78
Health and safety information
disconnect it from the power source. Do not leave
the battery connected to a charger for more than a
week, since overcharging may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
• Do not leave the battery in hot or cold places, such
as in a car in summer or winter conditions, as you
will reduce the capacity and lifetime of the battery.
Always try to keep the battery at room
temperature. A phone with a hot or cold battery
may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly
affected by temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between the
+ and - terminals of the battery (metal strips on
the battery), for example when you carry a spare
battery in a pocket or bag. Short-circuiting the
terminals may damage the battery or the object
causing the short-circuiting.
• Dispose of used batteries in accordance with local
regulations. In some areas, the disposal of
batteries in household or business trash may be
prohibited. For safe disposal options for Li-Ion
batteries, contact your nearest Samsung
authorized service center. Always recycle. Do not
dispose of batteries in a fire.
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode electronic
circuits.
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage to
the phone.
Health and safety information
Phone
79
• Do not use or store the phone in dusty, dirty areas,
as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the phone,
which may damage the phone's electronic circuit
boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it with
a soft cloth slightly dampened in a mild soap-and-
water solution.
• Do not paint the phone. Paint can clog the device's
moving parts and prevent proper operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• When the phone or battery gets wet, the label
indicating water damage inside the phone changes
color. In this case, phone repairs are no longer
guaranteed by the manufacturer's warranty, even
if the warranty for your phone has not expired.
• If your phone has a flash or light, do not use it too
close to the eyes of people or animals. This may
cause damage to their eyes.
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
