Samsung Electronics Co SGHX630 Single-Band PCS GSM/ EDGE Phone with Bluetooth User Manual
Samsung Electronics Co Ltd Single-Band PCS GSM/ EDGE Phone with Bluetooth Users Manual
Users Manual
Usermanual
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-xxxxxA
English. 02/2006. Rev 1.0.
* Depending on the software installed or your service provider or country,
some of the descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear
different from the illustrations in this guide.
SGH-X630
User’s Guide
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
Drive safely at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
1
Important safety precautions
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories could
damage your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 70.
• The phone could explode if the battery is replaced
with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful
attention to the subsequent information
regarding safety or phone features.
Indicates that you can get more
information on the referenced page.
→
Indicates that you need to press the
Navigation keys to scroll to the specified
option and then select it.
[ ]
Indicates a key on the phone. For example,
[]
< >
Indicates a soft key, whose function is
displayed on the phone screen. For
example, <
Menu
>
• Camera and camcorder
Use the camera module on your
phone to take a photo or record a
video.
Special
features of your phone
•IrDA
Send and receive Phonebook and
calendar data via an infrared port.
•Web browser
Access the wireless web to get
up-to-the-minute information and
a wide variety of media content.
3
Special features of your phone
• Get personal with photo caller
ID
See who’s calling you when their
very own photo displays.
•Name card
Create name cards with your
number and profile.
•
Multimedia Message Service (MMS)
Send and receive MMS messages with a
combination of text, image, video, and audio.
•Java
Enjoy Java
™
-based embedded
games and download new games.
•Calendar
Keep track of your daily, weekly,
and monthly schedule.
• Voice recorder
Record memos or sounds.
•Alarm
Use your phone as an alarm clock
to wake you up in the morning or
notify you of an impending event.
• Timer and Stopwatch
Count down to a specific event or
measure the time it takes to do
your exercise or work.
4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Buttons, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone..................................... 7
Power on or off........................................................ 8
Keys and display ..................................................... 9
Access menu functions ............................................ 11
Customise your phone............................................. 12
Make/Answer calls .................................................. 14
Step outside the phone 14
Begin with your camera, web, messaging, and other special
features
Use the camera ...................................................... 14
Browse the web...................................................... 15
Use Phonebook ...................................................... 16
Send messages...................................................... 17
View messages....................................................... 18
Enter text 19
AB, T9, Number, and Symbol mode
Call functions 21
Advanced calling features
Menu functions 25
All menu options listed
Solve problems 68
Help and personal needs
Health and safety information 70
Index 91
5
Overview of menu functions
To access Menu mode, press <
Menu
> in Idle mode.
1 Call log
p. 25
1 Recent contacts
2 Missed calls
3 Dialled calls
4 Received calls
5 Delete all
6 Call time
7 Call cost
*
p. 25
p. 26
p. 26
p. 26
p. 26
p. 26
p. 27
2 Phonebook
p. 27
1 Contact list
2 Add new contact
3 Group
4 Speed dial
5 My namecard
6 Own number
7 Management
8 Service number
*
p. 27
p. 28
p. 29
p. 29
p. 30
p. 30
p. 30
p. 31
3 Applications
p. 31
1 Java world
2 Voice recorder
3 World clock
4 Alarm
5 Calculator
6 Converter
7 Timer
8 Stopwatch
9 SIM AT
*
p. 31
p. 32
p. 33
p. 33
p. 34
p. 34
p. 35
p. 35
p. 35
4 Browser
p. 35
1 Home
2 Bookmarks
3 http://
4 WAP profile
5 Clear cache
p. 36
p. 37
p. 37
p. 37
p. 37
5 Messaging
p. 37
1 Create message
2 My messages
3 Templates
4 Delete all
5 Settings
6 Memory status
p. 38
p. 39
p. 43
p. 43
p. 43
p. 46
6 File manager
p. 46
1 Images
2 Videos
3 Sounds
4 Other files
5 Memory status
p. 46
p. 47
p. 48
p. 48
p. 49
7 Calendar
p. 49
8 Camera
p. 52
9 Settings
p. 57
1 Time and date
2 Phone settings
3 Display settings
4 Sound settings
5 Network services
6 Security
7 Connection settings
8 Reset settings
p. 57
p. 57
p. 60
p. 61
p. 63
p. 65
p. 67
p. 68
* Shows only if supported by your
SIM card.
6
Unpack
Make sure you have each item
You can obtain various accessories from
your local Samsung dealer.
Phone Travel Adapter
Battery User’s Guide
The items supplied with your phone
and the accessories available at your
Samsung dealer may vary, depending
on your country or service provider.
Your phone
Buttons, features, and locations
Special
function keys
Earpiece
Display
Power on/off/
Menu exit key
Microphone
Correct key
Left soft key
Headset jack
Volume keys
Dial key
Alphanumeric
keys
Right soft key
Web access/
Confirm key Camera key
Camera lens
Navigation keys
(Up/Down/
Left/Right)
Mirror
7
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you receive
a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your
PIN, and available optional services.
Install and charge the phone
Remove the battery
cover.
If the phone is already
on, first turn it off by
holding [ ].
Insert the SIM card.
Make sure that the
gold-coloured contacts
on the card face down
into the phone.
Install the battery.
Replace the cover.
Plug the travel adapter into the phone.
Plug the adapter into a standard AC wall outlet.
8
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the low battery message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
When the phone is completely charged (the
battery icon becomes still), unplug the adapter
from the power outlet.
Remove the adapter from the phone.
Switch on
Do not turn on
the phone when
mobile phone
use is prohibited.
1. Open the phone.
2. Press and hold [ ] to turn on
the phone.
3. If necessary, enter the PIN and
press <
OK
>.
Switch off
1. Open the phone.
2. Press and hold [ ].
9
Get started
Keys and display
Keys
Perform the function indicated on the
bottom line of the display.
In Idle mode, access your favourite menus
directly.
p. 59
In Menu mode, scroll through menu options.
In Idle mode, launch the web browser.
In Menu mode, select the highlighted menu
option or confirm input.
Make or answer a call.
In Idle mode, retrieve the recent numbers
dialled, missed, or received.
Delete characters from the display or an
item in an application.
End a call.
Press and hold to switch the phone on or off.
In Menu mode, cancel input and return the
phone to Idle mode.
Enter numbers, letters, and some special
characters.
In Idle mode, press and hold
[1]
to access
your voicemail server. Press and hold [
0
] to
enter an international call prefix.
Enter special characters.
In Idle mode, press and hold [ ] to activate
or deactivate Quiet mode. Press and hold
[ ] to enter a pause between numbers.
Adjust the phone volume.
In Idle mode, with the phone open, adjust
the keypad tone volume. With the phone
closed, press and hold to turn on the
external display.
In Idle mode, press and hold to turn on the
camera.
In Camera mode, take a photo or record a
video.
10
Get started
Display
Layout
Icons
*
Received signal strength
Call in progress
Out of your service area; you
cannot make or receive calls
GPRS network
Roaming network
Call diverting feature active
Text and graphics
display messages,
instructions, and
information you enter.
Soft key function
indicators
show the current functions
assigned to the soft keys.
Menu Contacts
Icons
display various icons.
Home Zone, if registered for the
appropriate service
Office Zone, if registered for the
appropriate service
Infrared port active
Call ringer set to vibrate
Quiet mode (Vibration)
Quiet mode (Mute)
Mute mode, during a call
New message
New voicemail
Alarm set
Battery power level
* Depending on your country or service provider, the icons
shown on the display may vary.
11
Get started
Access menu functions
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current role.
Press the left
soft key to select
the highlighted
option.
Press the right
soft key to return
to the previous
menu level.
Select Back
Select an
option
1. Press the appropriate soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press <
Select
> or [ ] to
confirm the function displayed
or option highlighted.
4. To exit, choose either of the
following methods.
•Press <
Back
> to move up
one level.
• Press [ ] to return to Idle
mode.
Use shortcuts
Press the number key
corresponding to the option you
want.
12
Get started
Customise your phone
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
settings
→
Language
.
2. Select a language.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Sound
settings
→
Incoming call
→
Ringtone
.
2. Select a ringtone category.
3. Select a ringtone.
4. Press <
Save
>.
Display
language
Call ringer
melody
You can set wallpaper for the idle
screen on the display.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display
settings
→
Wallpaper
→
Main
display
.
2. Select an image category.
3. Select an image.
4. Press <
Select
>.
5. Press <
Save
>.
You can change the colour for the
display components, such as title
bars and highlight bars.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display
settings
→
Skin
.
2. Select a colour pattern.
Idle mode
wallpaper
Menu mode
skin colour
13
Get started
You can set the Navigation keys as
shortcuts to access your favourite
menus.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
settings
→
Shortcuts
.
2. Select a key.
3. Select a menu to be assigned to
the key.
You can switch the phone to Quiet
mode to avoid disturbing other
people.
Press and hold [ ] in Idle mode.
Menu
shortcuts
Quiet mode
You can protect the phone against
unauthorised use with a phone
password. The phone will require
the password on power-up.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Security
→
Change
password
.
2. Enter the default password,
00000000
, and press <
OK
>.
3. Enter a new 4- to 8-digit
password and press <
OK
>.
4. Enter the new password again
and press <
OK
>.
5. Select
Phone lock
.
6. Select
Enable
.
7. Enter the password and press
<
OK
>.
Phone lock
14
Make/Answer calls
Step outside the phone
Begin with your camera, web, messaging, and other
special features
Use the camera
1. In Idle mode, enter an area
code and phone number.
2. Press [ ].
3. To end the call, press [ ].
1. When the phone is ringing,
press [ ].
2. To end the call, press [ ].
Press [ / ].
Make a call
Answer a call
Adjust the
volume during
a call
1. Open the phone.
2. In Idle mode, press and hold
[ ] to turn on the camera.
3. Adjust the image to be
captured.
4. Press [ ] to take a photo. The
photo is saved automatically.
5. Press <
Preview
> to take
another photo.
Take a photo
15
Step outside the phone
Browse the web
Using a built-in web browser, you can get easy access
to the wireless web to get a variety of up-to-date
services and information and to enjoy downloads of
web content.
1. In Idle mode, press <
Menu
>
and select
File manager
→
Images
→
Photos
.
2. Select the photo you want.
1. In Idle mode, press and hold
[
]
to turn on the camera.
2. Press [
1
] to switch to Record
mode.
3. Press [
]
to start recording.
4. Press [
]
to stop recording.
The video is saved
automatically.
5. Press <
Preview
> to record
another video.
1. In Idle mode, press <
Menu
>
and select
File manager
→
Videos
→
Video clips
.
2. Select the video you want.
View a photo
Record a video
Play a video
In Idle mode, press [ ].
• To scroll through browser items,
press [Up] or [Down].
• To select an item, press [ ].
• To return to the previous page,
press <
Options
> and select
Back
.
• To access browser options,
press <
Menu
>.
Launch the
web browser
Navigate the
web
16
Step outside the phone
Use Phonebook
To the phone’s memory:
1. In Idle mode, enter a phone
number and press <
Options
>.
2. Select
Save contact
→
Phone
→
a number type.
3. Specify contact information:
First name, Last name, Mobile,
Home, Office, Fax, Other, Email,
Caller ID, Ringtone, Group, and
Memo.
4. Press <
Save
> to save the entry.
To the SIM card:
1. In Idle mode, enter a phone
number and press <
Options
>.
2. Select
Save contact
→
SIM
.
3. Enter a name.
4. Press <
Save
> to save the entry.
Add an entry
1. In Idle mode, press
<
Contacts
>.
2. Select an entry.
3. Scroll to a number and press
[ ] to dial, or press [ ] to
edit contact information.
1. In Idle mode, press <
Menu
>
and select
Phonebook
→
My
namecard
.
2. Specify your contact
information.
3. Press <
Save
> to save the
name card.
4. To send the name card to other
people, press <
Options
> and
select
Send via
→
a sending
method.
Find an entry
Create and
send a name
card
17
Step outside the phone
Send messages
1. In Idle mode, press <
Menu
>
and select
Messaging
→
Create message
→
Text
message
.
2. Enter the message text.
3. Press <
Options
> and select
Save and send
or
Send only
.
4. Enter destination numbers.
5. Press [ ] to send the
message.
1. In Idle mode, press <
Menu
>
and select
Messaging
→
Create message
→
Multimedia message
.
2. Select
Subject
.
3. Enter the message subject and
press [ ].
Send a text
message (SMS)
Send a
multimedia
message
(MMS)
4. Select
Image and video
or
Sound
.
5. For
Image and video
, select
Add image
or
Add video
and
add an image or a video clip.
For
Sound
, select
Add sound
and add a sound clip.
6. Select
Message
.
7. Enter the message text and
press [ ].
8. Press <
Options
> and select
Send
.
9. Enter destination numbers or
addresses.
10.Press [ ] to send the
message.
18
Step outside the phone
View messages
When a notification appears:
1. Press <
View
>.
2. Select the message from the
Inbox.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messaging
→
My
messages
→
Inbox
.
2. Select an SMS message ( ).
View a text
message
When a notification appears:
1. Press <
View
>.
2. Press <
Options
> and select
Retrieve
.
3. Select the message from the
Inbox.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messaging
→
My
messages
→
Inbox
.
2. Select an MMS message ( ).
View a
multimedia
message
19
Enter text
AB, T9, Number, and Symbol mode
You can enter text for some features, such as
messaging, Phonebook, or Calendar, using AB mode,
T9 mode, Number mode, and Symbol mode.
Changing the text input mode
• Press and hold [ ] to switch between T9 mode
( ) and AB mode ( ). Depending on your
country, you may also be able to access an input
mode for your specific language.
• Press [ ] to change case or switch to Number
mode ( ).
• Press and hold [ ] to switch to Symbol mode.
Using AB mode
Press the appropriate key until the character you want
appears on the display.
(Creating an SMS message with GSM-Alphabet encoding)
Characters in order displayed
Key Upper case Lower case
20
Enter text
Tips for using AB mode
• To enter the same letter twice or to enter a
different letter on the same key, wait for the cursor
to move to the right automatically or press [Right].
Then, enter the next letter.
• Press [ ] to insert a space.
• Press the Navigation keys to move the cursor.
•Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Using T9 mode
T9 is a predictive text input mode that allows you to
key in any character using single keystrokes.
Entering a word in T9 mode
1. Press [
2
] to [
9
]
to start entering a word. Press
each key once for each letter.
For example, press [
4
], [
3
], [
5
], [
5
], and [
6
] to
enter Hello in T9 mode.
T9 predicts the word that you are typing, and it
may change with each key that you press.
2. Enter the whole word before editing or deleting
characters.
3. When the word displays correctly, go to step 4.
Otherwise, press [
0
] to display alternative word
choices for the keys that you have pressed.
For example, Of and Me use [
6
] and [
3
].
4. Press [ ] to insert a space and enter the next
word.
Tips for using T9 mode
• Press [
1
] to enter periods or apostrophes
automatically.
• Press [ ] to insert a space.
• Press the Navigation keys to move the cursor.
• Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Adding a new word to the T9 dictionary
This feature may not be available for some languages.
1. Enter the word that you want to add.
21
Call functions
2. Press [
0
] to display alternative words for your key
presses. When there are no more alternative
words,
Add
appears on the bottom line.
3. Press <
Add
>.
4. Enter the word you want using AB mode and press
<
OK
>.
Using Number mode
Number mode enables you to enter numbers.
Press the keys corresponding to the digits you want.
Using Symbol mode
Symbol mode enables you to insert symbols.
Call functions
Advanced calling features
Making a call
1. In Idle mode, enter the area code and phone
number.
2. Press [ ].
Making an international call
1. In Idle mode, press and hold [
0
]. The
+
character
appears.
2. Enter the country code, area code, and phone
number, then press [ ].
To Press
display more symbols [Up] or [Down].
select a symbol the corresponding
number key.
clear the entered symbols [
C
].
insert the symbols <
OK
>.
• Press [
C
] to clear the last digit or press and hold
[
C
] to clear the whole display. You can move the
cursor to edit an incorrect digit.
• Press and hold [ ] to enter a pause between
numbers.
22
Call functions
Redialling recent numbers
1. In Idle mode, press [ ] to display the list of
recent numbers.
2. Scroll to the number you want and press [ ].
Making a call from Phonebook
Once you have stored a number in Phonebook, you
can dial the number by selecting it from Phonebook.
p. 27
You can also use the speed dial feature to assign your
most frequently called numbers to specific number
keys.
p. 29
You can quickly dial a number from the SIM card using
its location number assigned when stored.
1. In Idle mode, enter a location number and press
[].
2. Press [Left] or [Right] to scroll through other
numbers.
3. Press <
Dial
> or [ ] to dial the number you want.
Ending a call
Close the phone or press [ ].
Answering a call
When you receive an incoming call, the phone rings
and displays the incoming call image.
Press <
Accept
> or [ ] to answer the call.
Tips for answering a call
• When
Anykey
answer
is active, you can press
any key, except for <
Reject
> and [ ].
p. 60
• When
Active flip
is active, you can simply open
the phone.
p. 60
• Press <
Reject
> or [ ] to reject a call.
• Press and hold [ / ] to reject a call or mute the
ringer, depending on the
Volume key
setting.
p. 60
23
Call functions
Viewing missed calls
If you have missed calls, the screen displays how
many calls you have missed.
1. Press <
View
>.
2. If necessary, scroll through the missed calls.
3. Press [ ] to dial the number you want.
Using the headset
Use the headset to make or answer calls without
holding the phone.
Connect the headset to the jack on the left side of the
phone. The button on the headset works as listed
below:
Options during a call
You can access a number of functions during a call.
Adjusting the volume during a call
Use [ / ] to adjust the earpiece volume during a call.
Press [ ] to increase the volume level and [ ] to
decrease the volume level.
Placing a call on hold/Retrieving
Press <
Hold
> or <
Retrieve
> to place a call on hold
or retrieve the call.
Making a second call
You can make another call if your network supports it.
1. Press <
Hold
> to put the call on hold.
2. Make the second call in the normal way.
3. Press <
Swap
> to switch between the calls.
4. Press <
Options
> and select
End
held
call
to end
the call on hold.
5. To end the current call, press [ ].
To Press
redial the last call and hold the button twice.
answer a call the button.
end a call the button.
24
Call functions
Answering a second call
You can answer an incoming call while already on the
phone, if your network supports it and you have
activated the call waiting feature.
p. 64
1. Press [ ] to answer the call. The first call is
automatically put on hold.
2. Press <
Swap
> to switch between the calls.
3. Press <
Options
> and select
End
held
call
to end
the call on hold.
4. To end the current call, press [ ].
Using the Speakerphone feature
Use your phone as a speaker phone to talk and listen
with the phone a short distance away.
Press [ ] and then <
Yes
> to activate the
Speakerphone feature. Press [ ] again to switch
back to the earpiece.
Using In-call options
Press <
Options
> to access the following options
during a call:
•
Speaker on
/
Normal
: turn on the Speakerphone
feature or switch back to Normal mode.
•
Menu
: access the phone's menu functions.
•
Voice on
/
Voice off
: switch off the phone's
microphone so that the other person on the phone
cannot hear you, or switch it back on.
•
Mute keys
/
Send keys
: switch the key tones on
or off.
•
Send DTMF
: send the DTMF (Dual tone multi-
frequency) tones as a group. The DTMF tones are
the tones used in phones for tone dialling,
sounding when you press the number keys. This
option is helpful for entering a password or an
account number when you call an automated
system, like a banking service.
To communicate with answering machines or
computerised telephone systems,
Send keys
must be selected.
25
•
Contacts
: access the contact list.
•
End held call
: disconnect the call currently on
hold.
•
Transfer
: transfer the currently active call to a
caller on hold. The two callers can talk to each
other, but you are disconnected from the call.
•
Join
: set up a multi-party call by adding a caller
on hold to a currently active call. You can include
up to 5 people on a multi-party call.
•
Select one
: select one of multi-party call
participants. You can then use the following
options:
Private
: have a private conversation with one
multi-party call participant. The other participants
can converse with each other. After the private
conversation, select
Join
to return to the
multi-party call.
Remove
: disconnect one multi-party call
participant.
Menu functions
All menu options listed
Call log
(Menu 1)
Use this menu to view the calls you have dialled,
received, or missed, and the length of calls. You can
also check the cost of your calls,
if your SIM card
supports this function.
To access this menu, press <
Menu
> in Idle mode and
select
Call log
.
Recent contacts
(Menu 1.1)
This menu displays the most recent calls dialled,
received, or missed.
Accessing a call record
1. Press [Left] or [Right] to move to another call
type.
2. Press [Up] or [Down] to scroll through the call list.
26
Menu functions
3. Press [ ] to view the details of a call, or [ ] to
dial a number.
Using call record options
While viewing call details, press <
Options
> to access
the following options:
•
Call
: edit the number and dial it.
•
Save contact
: save the number to Phonebook.
•
Send message
: send an SMS or MMS message to
the selected number.
•
Delete
: delete the selected call record or all
records.
Missed calls
(Menu 1.2)
This menu displays the most recent calls you did not
answer.
Dialled calls
(Menu 1.3)
This menu displays the most recent calls you have
dialled.
Received calls
(Menu 1.4)
This menu displays the most recent calls you have
received.
Delete all
(Menu 1.5)
Use this menu to delete all of the records in each call
type.
1. Press [ ] to select the call types to be cleared.
2. Press <
Delete
>.
3. Press <
Yes
> to confirm the deletion.
Call time
(Menu 1.6)
This menu displays the time log for calls made and
received. The actual time invoiced by your service
provider will vary.
•
Last
call
time
: check the length of your last call.
•
Total
dialled calls
: check the total length of all
the calls you have dialled.
•
Total
received calls
: check the total length of all
the calls you have received.
27
Menu functions
Phonebook
(Menu 2)
To reset the call timers, press <
Reset
>. You need to
enter the phone password.
Call cost
(Menu 1.7)
This network feature displays the cost of calls. This
menu is available only if supported by your SIM card.
Note that this is not intended to be used for billing
purposes.
•
Last
call
cost
: check the cost of your last call.
•
Total
cost
: check the total cost of all of your calls.
If the total cost exceeds the maximum cost set in
Set
max.
cost
, you must reset the counter before
you can make another call.
•
Max.
cost
: check the maximum cost limit set in
Set
max.
cost
.
•
Reset
counters
: reset the cost counters.
•
Set
max.
cost
: set the maximum cost authorised
for your calls.
•
Price/Unit
: set the price per unit that is applied
when the cost of your calls is calculated.
Phonebook
(Menu 2)
You can store phone numbers on your SIM card and in
your phone’s memory. The SIM card and phone’s
memory are physically separate, but they are used as
a single entity called Phonebook.
To access this menu, press <
Menu
> in Idle mode and
select
Phonebook
.
Contact list
(Menu 2.1)
Use this menu to search for numbers in Phonebook.
Finding an entry
1. Enter the first few letters of the name that you
want to find.
2. Select the name from the list.
3. Scroll to a number and press [ ] to dial, or press
[ ] to edit contact information.
The password is preset to
00000000
. You can
change this password.
p. 66
28
Menu functions
Using Phonebook options
While viewing contact details, press <
Options
> to
access the following options:
•
Edit
: edit contact information.
•
Send message
: send an SMS or MMS message to
the selected number.
•
Copy to
: copy the contact to the phone’s memory
or to the SIM card.
•
Send via
: send the contact via SMS, MMS, or
infrared port.
•
Delete
: delete the selected contact.
Add new contact
(Menu 2.2)
Use this menu to add a new contact to Phonebook.
Storing a number in the phone’s memory
1. Select
Phone
.
2. Change the settings or enter information about the
contact.
•
First name
/
Last name
: assign a name.
•
Mobile
/
Home
/
Office
/
Fax
/
Other
: add a
number in any type.
•
Email
: assign an e-mail address.
•
Caller ID
: assign an image to alert you to a
call from the person.
•
Ringtone
: assign a ringtone to alert you to a
call from the person.
•
Group
: assign the number to a caller group.
•
Memo
: add a memo about the person.
3. Press <
Save
> to save the contact.
Storing a number on the SIM card
1. Select
SIM
.
2. Enter information about the contact.
•
Name
: assign a name.
•
Phone number
: add a number.
•
Location
: assign a location number.
3. Press <
Save
> to save the contact.
To assign a caller ID image, ringtone, or group,
the contact must be saved to the phone’s
memory.
29
Menu functions
Phonebook
(Menu 2)
Group
(Menu 2.3)
Use this menu to organise your contacts in caller
groups.
Creating a new caller group
1. Press <
Options
> and select
Add
.
2. Enter a name for the group.
3. Select the caller ID line and set an image.
4. Select the ringtone line and set a melody.
5. Press <
Save
> to save the group.
Adding members to a caller group
1. Select a group.
2. Press <
Add
>.
3. Press [ ] to select the contacts to be added.
4. Press <
Select
>.
Managing caller groups
While viewing the group list, press <
Options
> to
access the following options:
•
View
: display the members of the selected group.
•
Add
: add a new group.
•
Edit
: change the group properties.
•
Send message
: send an SMS or MMS message to
the group members you want.
•
Delete
: delete the selected group or all groups.
Group members, however, will not be deleted from
Phonebook.
Speed dial
(Menu 2.4)
Use this menu to assign a speed dial number (2 to 9)
for 8 of your most frequently called numbers.
Assigning speed dial numbers
1. Select a key location from
2
to
9
. Key
1
is reserved
for your voicemail server.
2. Select a contact from the contact list.
3. Select a number, if the contact has more than one
number.
Managing speed dial entries
From the Speed dial screen, press <
Options
> to
access the following options:
•
Add
: assign a number to an unassigned key.
30
Menu functions
•
View
: check the name and number assigned to a
key.
•
Change
: assign a different number to a key.
•
Remove
: clear the speed dial setting for a key.
Dialling speed dial entries
In Idle mode, press and hold the appropriate key.
My namecard
(Menu 2.5)
Use this menu to create a name card and send it to
other people.
Saving your name card
The procedure for creating your name card is the
same as the one for saving a phone number in the
phone’s memory.
p. 28
Using name card options
After saving your name card, press <
Options
> to
access the following options:
•
Edit
: edit the name card.
•
Send via
: send the name card via SMS, MMS, or
infrared port.
•
Delete
: delete the name card.
Own number
(Menu 2.6)
Use this feature to check your phone numbers, or to
assign a name to each of the numbers. Changes made
here do not affect the actual subscriber numbers on
your SIM card.
Management
(Menu 2.7)
Use this menu to manage Phonebook entries.
•
Saving location
: select a default memory location
for saving contacts. If you select
Ask on saving
,
the phone will ask you to select a memory location
each time you save a number.
•
Copy all to phone
: copy all of the contacts stored
on the SIM card to the phone’s memory.
•
Delete all
: delete all of the contacts from your
phone’s memory, your SIM card, or both.
31
Menu functions
Applications
(Menu 3)
•
Memory status
: check the number of contacts
you have stored in the phone’s memory and on the
SIM card.
Service number
(Menu 2.8)
Use this menu to view the list of Service Dialling
Numbers (SDN) assigned by your service provider,
including emergency numbers and numbers for
directory enquiries. This menu is available if your SIM
card supports SDN.
1. Scroll to the number you want and press <
View
>.
2. Press <
Dial
> or [ ].
Applications
(Menu 3)
Use this menu to play Java games, record voice
memos, set time zone. You can also use convenient
features, such as an alarm clock, calculator, converter,
timer, and stopwatch.
To access this menu, press <
Menu
> in Idle mode and
select
Applications
.
Java world
(Menu 3.1)
Use this menu to access the embedded Java games
and downloaded Java applications.
Accessing an embedded game
1. From the Java world screen, select
Downloads
→
a game.
2. If necessary, press [ ].
Using Java application options
From the application list, press <
Options
> to access
the following options:
•
Launch
: launch the selected application.
•
Delete
: delete the selected application or all
applications
,
except for the standard games.
•
Details
: access the application properties.
•
Upgrade
: upgrade the application to the latest
version.
•
Protection
: lock the application to protect it from
being deleted, or unlock the application.
•
Send information
: send the URL containing the
application via SMS.
32
Menu functions
Changing Java settings
You can select a connection profile to be used for
applications requiring network access.
From the Java world screen, select
Settings
→
a
profile.
Checking memory status
You can view the amount of used and available
memory for Java games. You can also view the
number of downloaded games.
From the Java world screen, select
Memory status
.
Voice recorder
(Menu 3.2)
Use this menu to record voice memos.
Recording a voice memo
1. Press [ ] to start recording.
2. Speak into the microphone.
Press [ ] to pause or resume recording.
3. Press <
Stop
> or [Down] to end recording. The
voice memo is saved automatically.
Reviewing the voice memo
After recording a voice memo, press [ ] to review
the voice memo.
During playback, use the following keys:
Using voice memo options
After playback, press <
Options
> to access the
following options:
•
Play
: play back the voice memo.
•
Record
: record a new voice memo.
You can add or edit a profile using the
Connection
settings
menu.
p. 67
Key Function
Pauses or resumes playback.
Left Moves backward in a memo.
Right Moves forward in a memo.
/ Adjusts the volume.
Down Stops playback.
33
Menu functions
Applications
(Menu 3)
•
Go to voice recorder files
: access the
Voice
recording list
folder.
•
Send via MMS
: send the voice memo via MMS
message.
•
Delete
: delete the voice memo.
•
Rename
: change the name of the voice memo.
•
Protection
: protect the voice memo from being
deleted.
•
Details
: access the properties of the voice memo.
World clock
(Menu 3.3)
Use this menu to set your local time zone and find out
what time it is in another part of the world.
Viewing world time
1. From the world map, press [Left] or [Right] to
scroll to the city you want. As the time line moves,
the time and date of the given zone display.
2. Press [ ] to save the city as your local time
zone.
Applying daylight savings time
1. From the world map, press <
Options
> and select
Set daylight saving time
.
2. Press [ ] to select the time zones you want.
3. Press <
Save
>.
Alarm
(Menu 3.4)
Use this menu to set alarms. The alert type for a
normal alarm corresponds to the call alert type
settings. A wake-up alarm is not affected by your
sound settings.
Setting an alarm
1. Select the type of alarm.
2. Set each alarm option:
•
Alarm
: activate the alarm.
•
Alarm time
: enter the time for the alarm to
ring.
•
AM/PM
: select
AM
or
PM
in 12-hour format.
•
Repeat
: select a repeat option.
•
Alarm tone
: select an alarm tone.
3. Press <
Save
>.
34
Menu functions
Stopping an alarm
• For a non-wake-up alarm, press any key.
• For a wake-up alarm, press <
Confirm
> or [ ].
Press any key, except <
Confirm
> and [ ], to
cause it to sound again after 5 minutes. You can do
this a maximum of 5 times.
Setting the alarm to ring even if the phone is
off
From the Alarm screen, select
Auto power
→
On
.
If the phone is off when it is time for the alarm to ring,
the phone switches on and sounds the alarm.
Calculator
(Menu 3.5)
Use this menu to perform basic arithmetic functions,
such as addition, subtraction, multiplication, and
division.
1. Enter the first number.
•Press <
.()
> to insert a decimal point or
bracket.
• Press [ ] or [ ] to move the cursor.
2. Press one of the Navigation keys to access the
math function you want.
3. Enter the second number.
4. Press [ ] to view the result.
5. If necessary, repeat from step 2 to continue the
calculation.
Converter
(Menu 3.6)
Use this menu for common conversions, such as
currency and temperature.
1. Select a converter.
2. Press [Left] or [Right] to select the original unit
and press [Down].
3. Enter the value to be converted and press [Down].
• Press [ ] to insert a decimal point.
• Press [ ] to change the temperature to above
zero (+) or below zero (-).
4. Press [Left] or [Right] to select the unit to which
you want to convert.
The equivalent value for the amount you entered
displays.
35
Menu functions
Browser
(Menu 4)
Timer
(Menu 3.7)
Use this menu to set a period of time for the phone to
count down. The phone will sound an alarm when the
specified period of time has expired.
Starting the timer
1. Press <
Set
>.
2. Enter the length of time you want to count down
and press <
OK
>.
3. Press [ ] to start counting down.
Stopping the timer
• Press any key when the timer rings.
• Press [ ] on the Timer screen to stop the timer
before it rings.
Stopwatch
(Menu 3.8)
Use this menu to measure elapsed time. The
maximum time is 10 hours.
1. Press [ ] to start the stopwatch.
2. Press [ ] to check an interval. You can repeat
this step for a total of 4 intervals.
SIM AT
(Menu 3.9)
This menu is available if you use a SIM AT card that
supports SIM Application Tool kit menus and provides
additional services, such as news, weather, sports,
entertainment, and location services. Available
services may vary, depending on your service
provider’s plans. For details, see your SIM card
instructions or contact your service provider.
Browser
(Menu 4)
The Wireless Application Protocol (WAP) browser on
your phone allows you to access the wireless web.
From the wireless web, you can access up-to-date
information and a wide variety of media content, such
as games, wallpapers, ringtones, and music files.
To access this menu, press <
Menu
> in Idle mode and
select
Browser
.
For the currency converter, you can view and set
currency rates by pressing <
View rate
>.
36
Menu functions
Home
(Menu 4.1)
Use this menu to connect your phone to the network
and load the homepage of the wireless web service
provider. You can also press [ ] in Idle mode.
Navigating the web browser
Using page options
From any web page, press <
Menu
> to access the
following options:
•
Bookmarks
: bookmark the current page or access
the bookmark list.
•
Reload
: reload the current page with updated
information.
•
Home
: return to the homepage.
•
Go to URL
: enter a URL address manually.
•
Show URL
: display the URL address of the current
web page. You can also set the current page as the
homepage for the web browser or a bookmark.
•
Clear cache
: clear the cache. A cache is a
temporary memory that stores recently accessed
web pages.
•
Inbox
: access push messages in the web browser.
•
Show images
: display images on the current
page.
•
Certificates
: access certificate information.
Exiting the browser
Press [ ] to end the network connection and exit the
browser.
To Press
scroll through browser
items [Up] or [Down].
select a browser item <
Options
> and select
Select
.
return to the previous
page <
Options
> and select
Back
.
37
Menu functions
Messaging
(Menu 5)
Bookmarks
(Menu 4.2)
Use this menu to save URL addresses in order to
quickly access web pages.
Adding a bookmark
1. Select an empty location.
2. Enter a title for the bookmark and press [Down].
3. Enter a URL address and press <
Save
>.
Accessing a bookmarked page
Selecting a bookmark item launches the web browser
and accesses the associated web page.
Using bookmark options
After saving an item, press <
Options
> to access the
following options:
•
Go to URL
: access the bookmarked web page.
•
Edit
: edit the URL address and title of the
bookmark.
•
Delete
: delete the selected bookmark or all
bookmarks.
http://
(Menu 4.3)
Use this menu to manually enter a URL address and
access the associated web page.
WAP profile
(Menu 4.4)
Use this menu to select a connection profile to be used
for accessing the wireless web. You can also add or
edit a profile.
p. 67
Clear cache
(Menu 4.5)
Use this menu to clear information stored in the cache.
Messaging
(Menu 5)
Use the
Messaging
menu to send and receive text
messages and multimedia messages. You can also use
push message and cell broadcast message features.
To access this menu, press <
Menu
> in Idle mode and
select
Messaging
.
38
Menu functions
Create message
(Menu 5.1)
Use this menu to create and send messages.
Text message
(Menu 5.1.1)
Short Message Service (SMS) allows you to send or
receive text messages that may include simple
pictures, animated images, and melodies.
1. Enter your message.
2. Press <
Options
> to access the following options
for creating a message:
•
Insert
: add a template, Phonebook entry, or
bookmark.
•
Add image
/
Add animation
/
Add melody
:
attach a simple image, an animated image, or
a melody.
•
Attach
: attach a Phonebook entry as a name
card or calender data as a data format
attachment.
•
Text style
: change the text attributes.
3. When you have finished, press <
Options
> and
select
Save and send
or
Send only
.
4. Enter a phone number.
To send the message to more than one recipient,
fill in additional destination fields.
5. Press [ ] to send the message.
Multimedia message
(Menu 5.1.2)
Multimedia Message Service (MMS) delivers messages
containing a combination of text, image, video, and
audio, from phone to phone or from phone to e-mail.
1. Select the
Subject
line.
2. Enter the message subject and press [ ].
3. Select the
Image and video
or
Sound
line and
add an image, a video, or a sound file.
The maximum number of characters allowed in a
message varies by service provider. If your
message exceeds the maximum number of
characters, the phone will split the message.
• The maximum size allowed for a message can
differ, depending on your service provider.
• Depending on the file type or DRM (Digital
Rights Management) system, some files may
not be able to be forwarded.
39
Menu functions
Messaging
(Menu 5)
4. Select the
Message
line.
5. Enter the message text and press [ ].
6. Press <
Options
> to access the following options
for editing the message:
•
Edit
: edit the subject or text of your message.
•
Change image
/
Change video
/
Change
sound
: replace an added item.
•
Add page
: add pages. Move to each page by
pressing [Left] or [Right].
•
Delete page
: delete an added page.
•
Edit page
: change the duration of page display
or move the page forward among the other
pages.
•
Attach
: attach a Phonebook entry as a name
card or calender data as a data format
attachment.
•
Clear subject
/
Clear message
: clear the
subject or text.
•
Remove media
/
Remove sound
: remove an
added item.
7. When you have finished, press <
Options
> and
select
Send
.
8. Enter a phone number or an e-mail address.
To send the message to more than one recipient,
fill in additional destination fields.
9. Press [ ] to send the message.
My messages
(Menu 5.2)
Use this menu to access messages you have received,
sent, or which have failed in sending.
Inbox
(Menu 5.2.1)
This folder stores all of the messages you have
received.
Viewing a message
The following icons may appear on the message list to
show the message type:
• SMS
• MMS
• MMS notification ( : Being retrieved,
: Failed to retrieve)
• Voicemail
• Push message from web servers
40
Menu functions
• Configuration message, containing network
parameters from the service provider
• CB (Cell broadcast) message from your
service provider
• Delivery report for your sent messages
Using message options
While viewing a message, press <
Options
> to access
the following options:
SMS messages
•
Reply via
: reply to the sender via SMS or MMS.
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Move to phone
/
Move to SIM
: move the
message between the SIM card and the phone’s
memory.
•
Copy entry
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Copy media
: save media content from the
message to your phone’s memory.
•
Protection
: protect the message from being
deleted. You can protect only those messages
stored in the phone’s memory.
•
Block number
: add the sender’s number to the
Block list to reject the messages from the sender.
MMS messages/MMS notifications
•
Retrieve
: retrieve the MMS message from the
MMS server.
•
Reply via text message
: reply to the sender via
SMS.
•
Reply via multimedia message to
: reply to the
sender via MMS.
•
Forward
: forward the message to other people.
• Depending on the DRM (Digital Rights
Management) system, messages having web
content may not be able to be forwarded.
• A
!
icon next to a message means that the
message is of high priority. A grey-coloured
message icon indicates low priority.
41
Menu functions
Messaging
(Menu 5)
•
Delete
: delete the message.
•
Copy
entry
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Copy media
: save media content from the
message to your phone’s memory.
•
Protection
: protect the message from being
deleted.
•
Details
: access the message properties.
Configuration messages
•
Install
: apply the configuration specified in the
message to your phone.
•
Delete
: delete the message.
•
Protection
: protect the message from being
deleted.
Push messages
•
Go to URL
: connect to the URL specified in the
message.
•
Delete
: delete the message.
•
Copy entry
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Protection
: protect the message from being
deleted.
CB messages
•
Save
: save the message to the phone’s memory.
•
Delete
: delete the message.
•
Copy entry
: extract URLs, e-mail addresses, or
phone numbers from the message.
Delivery reports
•
Delete
: delete the report.
•
Copy entry
: extract URL, e-mail addresses, or
phone numbers from the report.
•
Protection
: protect the report from being deleted.
Drafts
(Menu 5.2.2)
This folder stores messages you have saved to send at
a later time.
Outbox
(Menu 5.2.3)
This folder stores messages that the phone is
attempting to send or has failed to send.
42
Menu functions
The following icons are available to show the message
status:
• Being sent
• Failed to send
While viewing a message, press <
Options
> to access
the following options:
•
Send again
: retry sending the message.
•
Forward
: forward the message to other people.
•
Copy entry
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Delete
: delete the message.
•
Protection
: protect the message from being
deleted.
•
Details
: access the message properties.
Sent messages
(Menu 5.2.4)
This folder stores messages that you have sent.
While viewing a message, press <
Options
> to access
the following options:
•
Forward
: forward the message to other people.
•
Copy entry
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Delete
: delete the message.
•
Protection
: protect the message from being
deleted.
•
Details
: access the message properties.
My folders
(Menu 5.2.5)
Use this menu to create new folders and organise your
messages.
Creating a new folder
1. Press <
Yes
>.
2. Enter a folder name and press <
OK
>.
Using folder options
On the folder list, press <
Options
> to access the
following options:
•
Open
: open the selected folder.
•
Add folder
: add a new folder.
•
Rename folder
: change the folder name.
•
Delete
: delete the selected folder.
43
Menu functions
Messaging
(Menu 5)
Templates
(Menu 5.3)
Use this menu to create SMS templates with the
sentences you use frequently so that you can retrieve
and insert them when composing an SMS message.
Creating a template
1. Select an empty location.
2. Enter a message and press <
OK
>.
Using template options
From the template list, press <
Options
> to access
the following options:
•
Edit
: edit the selected template.
•
Send message
: create and send a new message.
•
Delete
: delete the selected template.
•
Add new
: add a new template.
Delete all
(Menu 5.4)
Use this menu to delete messages in each message
folder all at once.
1. Press [ ] to select the message folders to be
cleared.
Pressing the key twice displays the message types
so that you can specify the ones to be cleared.
2. Press <
Delete
>.
3. Press [ ] to select the check box to delete
protected messages, and then press <
Yes
>.
4. Press <
Yes
> to confirm the deletion.
Settings
(Menu 5.5)
Use this menu to set up various options for using the
messaging service.
Text message
(Menu 5.5.1)
You can configure SMS settings.
•
Send settings
: set up the options for sending
SMS messages:
Reply path
: allow recipients to reply to you
through your SMS server.
Delivery report
: set the network to inform you
when your messages have been delivered.
44
Menu functions
Character support
: select a character encoding
type. If you select
Automatic
, the phone switches
the encoding type from GSM-Alphabet to Uni-Code
if you enter a Unicode character. Use of Unicode
encoding will reduce the maximum number of
characters in a message to about half. If this menu
is not shown, your phone provides automatic
character encoding by default.
Bearer selection
: select either
GSM
or
GPRS
preferred
, depending on your network.
•
Block number
: store the phone numbers from
which you want to reject messages.
•
Current profile
: select an SMS setting profile.
•
Profile settings
: set the properties of each
profile.
Service centre
: store or change the number of
your SMS server.
Default destination
: enter the default
destination.
Default type
: set the default message type. The
network can convert the messages into the
selected format.
Default validity
: set the length of time your
messages are stored in the SMS server.
Setting name
: enter a profile name.
Multimedia message
(Menu 5.5.2)
You can configure MMS settings.
•
Sending settings
: set up the options for sending
MMS messages:
Delivery report
: set the network to inform you
when your messages have been delivered.
Hide address
: set your address to be hidden from
the recipient’s phone.
Read reply
: send a read-reply request along with
your messages.
Priority
: set the priority level of messages.
Expiry date
: set the length of time messages are
stored in the MMS server.
Delivery time
: set a time delay before messages
are sent.
•
Retrieve settings
: set up the options for
receiving MMS messages:
45
Menu functions
Messaging
(Menu 5)
Reject unknown senders
: reject messages from
unknown senders.
Allow adverts
: accept advertisements.
Allow information
: accept information
messages.
Allow personal
: accept personal messages.
Allow reports
: set the network to inform the
sender when a message has been delivered to you.
Recep. in home network
: determine if your
phone retrieves new messages automatically when
you are in your home service area.
Reception when abroad
: determine if your
phone retrieves new messages automatically when
you are roaming on another network.
Reception within home network or abroad has the
following options:
-
Manual
: the phone displays notifications. Use
the
Retrieve
option to manually download new
messages.
-
Automatic
: the phone automatically retrieves
messages from the server.
-
Reject
: the phone rejects all messages.
•
Profile
: select a connection profile to be used for
MMS. You can also add or edit a profile.
p. 67
Push message
(Menu 5.5.3)
You can change the settings for receiving push
messages from the wireless web server.
•
Receive
: set how your phone receives push
messages.
•
Black list
: manage blocked server addresses.
Broadcast
(Menu 5.5.4)
You can change the settings for receiving CB
messages.
•
Receive
: select to receive CB messages, or not.
•
Channel list
: indicate the channels from which
you wish to receive CB messages. Please contact
your service provider for further details.
•
Language
: select the preferred languages in
which CB messages display.
46
Menu functions
Memory status
(Menu 5.6)
Use this menu to view the amount of memory
currently in use in each message folder.
File manager
(Menu 6)
The
File manager
menu allows you to access image,
video, and sound files stored in the phone’s memory.
To access this menu, press <
Menu
> in Idle mode and
select
File manager
.
Images
(Menu 6.1)
This menu displays photos you have taken and images
you have downloaded or received in messages.
Viewing an image
1. Select an image folder.
2. Select an image.
Viewing a slide show
You can view your photos as a slide show, a sequential
presentation of each photo in the current folder.
1. Select
Photos
.
2. Press <
Options
> and select
Slide show
.
3. Select an interval option.
The slide show begins.
4. Press <
Stop
> to stop the slide show.
Using image options
While viewing an image, press <
Options
> to access
the following options:
•
List
: return to the image list.
•
Send via MMS
: send the file via MMS message.
•
Set as
: set the image as wallpaper for the main
display or as a caller ID image for a Phonebook
entry.
According to the DRM (Digital Rights Management)
system, messages having web content may not be
able to be forwarded. They are indicated by the
icon.
47
Menu functions
File manager
(Menu 6)
•
Delete
: delete the file.
•
Rename
: change the file name.
•
Move to Favourite images
: move the file to the
Favourite images
folder.
•
Move to Downloaded images
: move the file to
the
Downloaded images
folder.
•
Move to Photos
: move the file to the
Photos
folder.
•
Protection
: protect the file from being deleted.
•
Details
: access the file properties.
Videos
(Menu 6.2)
This menu displays video clips you have recorded,
downloaded, or received in messages.
Playing a video clip
1. Select a video folder.
2. Select a video clip.
During playback, use the following keys:
Using video options
From a video screen, press <
Options
> to access the
following options:
•
List
: return to the video list.
•
Send via MMS
: send the file via MMS message.
•
Set as wallpaper
: set the video clip as wallpaper
for the main display.
•
Delete
: delete the file.
•
Rename
: change the file name.
•
Move to Favourite videos
: move the file to the
Favourite
videos
folder.
•
Move to Downloaded videos
: move the file to
the
Downloaded videos
folder.
Video clips recorded on other devices, such as
camcorders, may not play correctly.
Key Function
Pauses or resumes playback.
/ Adjusts the volume.
Down Stops playback.
48
Menu functions
•
Move to Video clips
: move the file to the
Video
clips
folder.
•
Protection
: protect the file from being deleted.
•
Details
: access the file properties.
Sounds
(Menu 6.3)
This menu displays voice memos you have recorded,
and sound files you have downloaded or received in
messages.
Playing a sound clip
1. Select a sound folder.
2. Select a sound clip. For a voice memo, see
Voice
recorder
.
p. 32
Using sound options
From a sound screen, press <
Options
> to access the
following options:
•
List
: return to the sound list.
•
Send via MMS
: send the file via MMS message.
•
Delete
: delete the file.
•
Rename
: change the file name.
•
Move to Favourite sounds
: move the file to the
Favourite sounds
folder.
•
Move to Downloaded sounds
: move the file to
the
Downloaded sounds
folder.
•
Move to Voice recorder files
: move the file to
the
Voice recording list
folder.
•
Protection
: protect the file from being deleted.
•
Details
: access the file properties.
Other files
(Menu 6.4)
Files that you have received but which are not
supported by your phone are stored in this folder. You
cannot open these files on the phone. Unsupported file
formats include *.doc, *.ppt, and *.txt.
While viewing the file list, press <
Options
> to access
the following options:
•
Delete
: delete the selected file or all files.
•
Rename
: change the file name.
•
Protection
: protect the file from being deleted.
•
Details
: access the file properties.
49
Menu functions
Calendar
(Menu 7)
Memory status
(Menu 6.5)
Use this menu to view memory information for media
items in each folder. Press [Left] or [Right] to view the
memory status by size or number of items.
Calendar
(Menu 7)
The
Calendar
menu enables you to keep track of your
schedule.
To access this menu, press <
Menu
> in Idle mode and
select
Calendar
.
Consulting the calendar
When you enter the
Calendar
menu, the calendar in
Month view appears with today’s date indicated by a
blue box.
Selecting a day
• Press [Left] or [Right] to move by day.
• Press [Up] or [Down] to move by week.
• Press [ / ] to move by month.
Using calendar options
Press <
Options
> to access the following options:
•
View mode
: change the view mode of the
calendar.
p. 52
•
Create
: add a new event.
next section
•
Go to
: select today’s date or enter a specific date.
•
Sort by
: sort items by type of event.
•
Delete
: delete the items stored on the calendar by
using various deleting options.
•
Missed alarm events
: view events whose alarms
you have missed.
•
Memory status
: access memory information for
the event items stored on the calendar.
Creating an event
You can store scheduled events, anniversaries,
memos, and To do items on the calendar. More than
one event per day can be stored.
You can delete recurring events in Day view
only.
50
Menu functions
Entering a new scheduled event
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
Schedule
.
3. Enter information or change the settings:
•
Subject
: enter a title for the event.
•
Details
: enter event details.
•
Start date
and
Start time
: enter the starting
date and time for the event.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
End date
and
End time
: enter the ending date
and time for the event.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
Location
: enter information about the event
location.
•
Alarm
: set an alarm for the event.
•
Before
: set how long before the event the
alarm is to alert you.
•
Alarm tone
: select an alarm tone.
•
Repeat
: set the event to recur and select a
repeat option.
•
Until
: set the ending date, if the event will
recur.
4. Press <
Save
> to save the event.
Entering a new anniversary
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
Anniversary
.
3. Enter information or change the settings:
•
Occasion
: enter information about the
anniversary.
•
Date
: enter the date.
•
Alarm
: select to set an alarm for the
anniversary.
•
Before
: set how long before the event the
alarm is to alert you.
•
Alarm time
: enter the time for the alarm to
ring.
51
Menu functions
Calendar
(Menu 7)
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
Alarm tone
: select an alarm tone.
•
Repeat every year
: set the phone to remind
you of the anniversary every year.
4. Press <
Save
> to save the event.
Entering a memo
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
Memo
.
3. Enter a memo and press <
Save
>.
Entering a To do item
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
To do
.
3. Enter information or change the settings:
•
To do
: enter information about the item.
•
Start date
: enter the starting date.
•
Due date
: enter the ending date.
•
Select priority
: select a priority level.
4. Press <
Save
> to save the event.
Viewing an event
Once you have scheduled events, the event icons and
the number of events for a specific day appears at the
bottom of the calendar.
Accessing an event
1. Select a date on the calendar to display the events
for the day.
2. Select an event to view its details.
3. Press [Left] or [Right] to access the other events
scheduled for the selected day.
Using event options
While viewing an event, press <
Options
> to access
the following options:
•
Edit
: edit the event.
•
Create
: add a new event.
•
Send via
: send the event via SMS, MMS, or
infrared port.
• Scheduled event • Anniversary
• To do item • Memo
52
Menu functions
•
View mode
: change the view mode of the
calendar.
•
Delete
: delete the event.
•
Memory status
: access memory information for
the events stored on the calendar.
Viewing an event in a different mode
You can change the calendar display to Day view or
Week view. Press <
Options
> and select
View mode
→
a view mode.
Day view
You can view events for the selected date. Select an
event to view its details.
The following icons may display to indicate the event
status:
• Alarm set
• Recurring event
• To do priority ( : high, : normal, : low)
• Completed To do item
Week view
You can view events for the selected week. A cell on
the timetable indicates the presence of a schedule
item. Select a cell in the day you want.
Camera
(Menu 8)
You can use the camera module embedded in your
phone to take photos and record videos.
To access this menu, press <
Menu
> in Idle mode and
select
Camera
, or press
and hold [ ] in Idle mode.
• Do not take photos of people without their
permission.
• Do not take photos in a place where cameras are
not allowed.
• Do not take photos in a place where you may
interfere with another person’s privacy.
53
Menu functions
Camera
(Menu 8)
Taking a photo
You can take photos in various modes. The camera
produces JPEG photos.
1. Access the
Camera
menu or press and hold [
]
to turn on the camera.
2. Adjust the image to be captured.
• Press < > to access camera options.
next section
• Use the keypad to change the camera settings
or switch to other modes.
p. 54
3. Press [
]
to take a photo. The photo is saved in
the
Photos
folder.
Using camera options in Capture mode
In Capture mode, press < > to access the following
options:
•
Record video
: switch to Record mode.
•
Shooting mode
: take a photo in the following
modes:
Single shot
: take a photo in normal mode. You
can select whether or not the camera automatically
saves a photo.
Multi-shot
: take a series of action stills. You can
select the number of photos the camera will take
and the shooting speed.
Mosaic shot
: take several stills and save them in
one frame. You can select the layout.
•
Effects
: change the colour tone or apply a special
effect.
•
Frames
: apply a decorative frame.
•
Timer
: set a time delay before the camera takes a
photo.
•
Go to photos
: access the
Photos
folder.
When you take a photo in direct sunlight or in bright
conditions, shadows may appear on the photo.
4.
To Press
access photo options <
Options
>.
p. 55
delete the photo [
C
] and then <
Yes
>.
return to Capture mode <
Preview
>.
54
Menu functions
•
Settings
: change the default settings for taking a
photo.
Size
: select an image size.
Quality
: select an image quality setting.
Viewfinder
: select a preview screen.
Shutter sound
: select the sound that you hear
when you press the shutter release, [
]
.
Zoom sound
: turn the sound effect for zooming
on or off.
Brightness sound
: turn the sound effect for
brightness adjustment on or off.
•
Shortcuts
: view the functions of the keys you can
use in Capture mode.
Using the keypad in Capture mode
You can use the keypad to customise your camera
settings in Capture mode.
Key Function
Left/Right Adjusts the image brightness.
Up/Down Zooms in or out.
Flips the image vertically.
Shows the mirror image.
1
Switches to Record mode.
p. 55
2
Changes the image size.
3
Changes the image quality.
4
Changes the shooting mode.
5
Changes the colour tone or applies a
special effect.
7
Selects a decorative frame.
8
Sets the timer.
9
Goes to the
Photos
folder.
Changes the preview screen.
Key Function
55
Menu functions
Camera
(Menu 8)
Using photo options
After saving a photo, press <
Options
> to access the
following options:
•
View
: access one of the multi-shot photos.
•
Take another
: return to Capture mode.
•
Send via MMS
: send the file via MMS message.
•
Set as
: set the photo as wallpaper for the main
display or as a caller ID image for a Phonebook
entry.
•
Delete
: delete the file.
•
Rename
: change the file name.
•
Go to photos
: access the
Photos
folder.
p. 46
•
Protection
: protect the file from being deleted.
•
Details
: access the file properties.
Taking a photo with the phone closed
1. Press and hold [
]
.
2. Press [ ] to flip the image vertically, or [ ] to view
the mirror image.
3. Press [
]
to take a photo. The photo is
automatically saved.
Recording a video
You can record a video of what is displayed on the
camera screen and save it.
1. In Capture mode, press [
1
].
2. Adjust the image to be captured.
• Press < > to access camera options.
next section
• Use the keypad to change the camera settings
or switch to other modes.
p. 56
3. Press [
]
to start recording.
4. Press [
]
or the
right soft key to stop recording.
The video is automatically saved in the
Video
clips
folder.
5.
To Press
play back the video clip [ ].
access video options <
Options
>.
p. 57
delete the video clip [
C
] and then <
Yes
>.
return to Record mode <
Preview
>.
56
Menu functions
Using camera options in Record mode
In Record mode, press < > to access the following
options:
•
Take photo
: switch to Capture mode.
•
Effects
: change the colour tone or apply a special
effect.
•
Timer
: set a time delay before the camera starts
recording.
•
Go to videos
: access the
Video clips
folder.
•
Settings
: change the following settings for
recording a video:
Size
: select a frame size.
Viewfinder
: select a preview screen.
Audio record
: record audio with a video clip.
Zoom sound
: turn the sound effect for zooming
on or off.
Brightness sound
: turn the sound effect for
brightness adjustment on or off.
•
Shortcuts
: view the functions of the keys you can
use in Record mode.
Using the keypad in Record mode
You can use the keypad to customise your camera
settings in Record mode:
Key Function
Left/Right Adjusts the image brightness.
Up/Down Zooms in or out.
Flips the image vertically.
Shows the mirror image.
1
Switches to Capture mode.
p. 53
2
Changes the frame size.
5
Changes the colour tone or applies a
special effect.
7
Mutes or unmutes audio.
8
Sets the timer.
9
Goes to the
Video clips
folder.
Changes the preview screen.
57
Menu functions
Settings
(Menu 9)
Using video options
After saving a video clip, press <
Options
> to access
the following options:
•
Record another
: return to Record mode.
•
Send via MMS
: send the file via MMS message.
•
Set as wallpaper
: set the video clip as wallpaper
for the main display.
•
Delete
: delete the file.
•
Rename
: change the file name.
•
Go to videos
: access the
Video clips
folder.
p. 47
•
Protection
: protect the file from being deleted.
•
Details
: access the file properties.
Settings
(Menu 9)
The
Settings
menu provides you with various setting
options to customise the phone to your preferences
and needs. You can also reset the settings to their
default status.
To access this menu, press <
Menu
> in Idle mode and
select
Settings
.
Time and date
(Menu 9.1)
Use this menu to change the time and date displayed
on your phone. Before setting the time and date,
specify your time zone in the
World clock
menu.
p. 33
•
Set time
: enter the current time.
•
AM/PM
: select
AM
or
PM
in 12-hour time format.
•
Time format
: select a time format.
•
Set date
: enter the current date.
•
Calendar starting day
: set which day of the
week the calendar starts with.
Phone settings
(Menu 9.2)
Many different features of your phone’s system can be
customised to suit your preferences.
58
Menu functions
Language
(Menu 9.2.1)
Use this menu to select one of several languages for
the display text.
Greeting message
(Menu 9.2.2)
Use this menu to enter the greeting that is displayed
briefly when the phone is switched on.
Activate infrared
(Menu 9.2.3)
Use this menu to send or receive data to or from
IrDA-compatible computers or phones through the
infrared port.
Connecting with a computer
Select
With PC
to use the IrDA feature with a
computer.
To use an IrDA connection, you must:
• configure and activate an IrDA-compliant infrared
port on your computer.
• activate the IrDA feature on the phone; the IrDA
icon ( ) appears on the top line of the display.
• align the infrared port on the phone with the
infrared port on your computer or another phone.
If there is no communication between your phone and
the IrDA-compliant device, it is automatically
deactivated.
Receiving data from another phone
1. Align the infrared ports on both phones with each
other.
2. Select
With other phone
from the
Activate
infrared
menu.
3. When the list of the received data displays, select
one of the two options:
You cannot use the IrDA feature while using
multimedia features such as voice recorder and
camera, or vice versa.
59
Menu functions
Settings
(Menu 9)
To save an individual item:
a. Select the item you want from the list.
b. Press <
Options
> and select
Save
to save the
data.
Otherwise, select
Discard
to delete the data.
To save all data:
a. From the item list, press <
Options
> to select
one of the following options:
•
Save all
: save all data.
•
Save all namecards
: save all Phonebook
entries.
•
Save all schedule items
: save all calendar
items.
•
Discard all
: delete all data.
•
Discard all namecards
: delete all
Phonebook entries.
•
Discard all schedule items
: delete all
calendar items.
b. Press <
Save
> to save the entries.
Sending your data to another phone
You can send Phonebook entries and calendar items
via IrDA connection.
1. Align the infrared ports on both phones with each
other.
2. Select
With other phone
from the
Activate
infrared
menu.
3. Select the item you want in the corresponding
menu.
4. Press <
Options
> and select
Send via
→
Infrared
.
Shortcuts
(Menu 9.2.4)
You can use the Navigation keys as shortcuts to access
specific menus directly from Idle mode. Use this menu
to assign a shortcut to a key.
Assigning a shortcut menu
1. Select a key to be used as a shortcut key.
2. Select a menu to be assigned to the key.
60
Menu functions
Using shortcut options
Press <
Options
> to access the following options:
•
Change
: assign or change a shortcut menu.
•
Remove
: deactivate the shortcut assignment to
the selected key.
•
Remove all
: deactivate all shortcut assignments.
Volume key
(Menu 9.2.5)
Use this menu to set whether the phone mutes the call
ringer or rejects a call if you press and hold [ / ]
when a call comes in.
Extra settings
(Menu 9.2.6)
You can turn the automatic redialling or answering
feature on or off.
•
Auto redial
: set the phone to make up to ten
attempts to redial a phone number after an
unsuccessful call.
•
Active flip
: answer an incoming call by opening
the phone.
•
Anykey
answer
: answer an incoming call by
pressing any key, except <
Reject
> and [ ].
Display settings
(Menu 9.3)
Use this menu to change settings for the display and
backlight.
Wallpaper
(Menu 9.3.1)
You can set up the idle screen on the display.
•
Main display
: select an image or video clip to be
displayed on the main display.
•
Text position
: select a text position. If you don’t
want to display text in Idle mode, select
Off
.
•
Text mode
: select a font style.
•
Text colour
: select a font colour.
•
Graphic logo
: set the phone to display a graphic
icon instead of the service provider’s logo on the
idle screen. This is only available if a graphic icon
has been received in a message.
Skin
(Menu 9.3.2)
You can select a skin colour pattern for Menu mode.
61
Menu functions
Settings
(Menu 9)
Brightness
(Menu 9.3.3)
You can adjust the brightness of the display for
varying lighting conditions.
Contrast
(Menu 9.3.4)
You can adjust the contrast of each display for varying
lighting conditions.
Back light
(Menu 9.3.5)
You can select the length of time the backlight stays
on or the length of time the display stays on in Dim
mode, in which the backlight is off.
•
Main display normal
: select the length of time
the backlight stays on.
•
Main display dim
: select the length of time the
display stays on in Dim mode after the backlight
turns off. After a specified time, the display turns
off.
Dialling display
(Menu 9.3.6)
Use this menu to select a font colour for the numbers
entered while dialling.
Show caller information
(Menu 9.3.7)
Use this menu to set the phone to display missed call
notifications with the most recently missed caller’s
information. To set the external display to show caller
information, select
With cover display
.
Sound settings
(Menu 9.4)
Use this menu to customise various sound settings.
Incoming call
(Menu 9.4.1)
Use this menu to change the sound settings for
incoming calls.
•
Ringtone
: select a ringtone to be used for the call
ringer.
•
Volume
: select a ringtone volume.
•
Alert type
: specify how you are to be informed of
incoming calls.
Keypad tone
(Menu 9.4.2)
Use this menu to select the tone that the phone
sounds when you press a key.
62
Menu functions
Message tone
(Menu 9.4.3)
Use this menu to change the sound settings for
incoming SMS messages, MMS messages, and CB
messages individually.
•
Tone
: select one of several message tones.
•
Alert type
: specify how you are to be informed
when a message comes in.
•
Repetition
: specify how often the phone informs
you of a new message.
Power on/off
(Menu 9.4.4)
Use this menu to select the melody that the phone
sounds when it is switched on or off.
Flip tone
(Menu 9.4.5)
Use this menu to select the tone that the phone
sounds when you open or close the phone.
Quiet mode
(Menu 9.4.6)
Use this menu to set how the phone acts to alert you
to a specific event while in Quiet mode.
Extra tones
(Menu 9.4.7)
Use this menu to customise additional tones for the
phone.
•
Minute
minder
: set the phone to beep every
minute during an outgoing call to keep you
informed of the length of your call.
•
Connection
tone
: set the phone to beep when an
outgoing call connects to the system.
•
Alert on call
: set the phone to beep when you
receive a new message or when the time for an
alarm comes during a call.
•
Indicative
tone
: set the phone to beep when you
have made a mistake or something wrong happens
on the phone.
You can adjust the keypad tone volume using [ / ]
in Idle mode.
63
Menu functions
Settings
(Menu 9)
Network services
(Menu 9.5)
Use this menu to access network services. Please
contact your service provider to check their availability
and subscribe to them, if you wish.
Call diverting
(Menu 9.5.1)
This network service reroutes incoming calls to a
phone number that you specify.
1. Select a call diverting option:
•
Divert always
: divert all calls.
•
Busy
: divert calls when you are on another
call.
•
No
reply
: divert calls when you do not answer
the phone.
•
Unreachable
: divert calls when you are not in
an area covered by your service provider or
when your phone is switched off.
•
Cancel
all
: cancel all call diverting options.
2. Select the type of calls to be diverted.
3. Select
Activate
. To deactivate call diverting, select
Deactivate
.
4. Move to the
Divert to
line.
5. Enter the number to which calls are to be diverted.
6. If you selected
No reply
, move to the
Seconds
line and select the length of time the network
delays before diverting a call.
7. Press <
Select
>.
Call barring
(Menu 9.5.2)
This network service allows you to restrict your calls.
1. Select a call barring option:
•
All
outgoing calls
: prohibit all outgoing calls.
•
International
: prohibit international calls.
•
International except home
: only allow calls
to numbers within the current country when
you are abroad, and to your home country.
•
All
incoming calls
: prohibit incoming calls.
•
Incoming
while
abroad
: prohibit incoming
calls when you use your phone outside of your
home country.
•
Cancel
all
: cancel all call barring settings,
allowing calls to be sent and received normally.
64
Menu functions
•
Change barring password
: change the call
barring password obtained from your service
provider.
2. Select the type of calls to be barred.
3. Select
Activate
. To deactivate call barring, select
Deactivate
.
4. Enter the call barring password supplied by your
service provider and press <
Select
>.
Call waiting
(Menu 9.5.3)
This network service informs you when someone is
trying to reach you while you are on another call.
1. Select the type of calls to which call waiting option
will apply.
2. Select
Activate
and press <
Select
>. To
deactivate call waiting, select
Deactivate
.
Network selection
(Menu 9.5.4)
This network service allows you to either automatically
or manually select the network to be used while
roaming outside of your home area. You can select a
network other than your home network only if there is
a valid roaming agreement between the two.
Caller ID
(Menu 9.5.5)
This network service allows you to prevent your phone
number from being displayed on the phone of the
person being called. If you select
Default
, the phone
will use the default setting provided by the network.
Voice mail server
(Menu 9.5.6)
Use this menu to store the number of the voicemail
server and access your voicemails.
•
Connect to voice server
: connect to the
voicemail server to listen to your messages.
•
Voice server number
: enter the voicemail server
number.
Some networks may not allow you to change this
setting.
You must store the voicemail server number before
accessing the server. Your service provider can give
you the number.
65
Menu functions
Settings
(Menu 9)
Closed user group
(Menu 9.5.7)
Use this menu to set incoming and outgoing calls to be
restricted to a selected user group. For details about
how to create a closed user group (CUG), contact your
service provider.
•
Index list
: add, delete, or activate CUG index
numbers.
•
Outside access
: enable calls to numbers other
than those in the closed user group. This feature
depends on the nature of your CUG subscription.
•
Default group
: enable the default CUG, if you
have set one with your service provider. When
making a call, you are given the option of using
your default CUG, instead of selecting one from the
list.
Band selection
(Menu 9.5.8)
For the phone to make and receive phone calls, it
must register with an available network. Your phone
can handle any of the following types of networks:
GSM 1900 and Combined GSM 900/1800.
The country where you purchased your phone
determines the default band that it uses. When you
travel abroad, you may need to change to an
appropriate band.
Security
(Menu 9.6)
Use this menu to protect the phone against
unauthorised use by managing the several access
codes of your phone and SIM card.
PIN check
(Menu 9.6.1)
The 4- to 8-digit PIN (Personal Identification Number)
protects your SIM card against unauthorised use.
When this feature is enabled, the phone requires your
PIN each time it is switched on.
If you enter an incorrect PIN/PIN2 three times in
succession, the SIM card is blocked. To unblock it
you need to enter your PUK/PUK2 (Personal
Unblocking Key). The codes are supplied by your
service provider.
66
Menu functions
Change PIN code
(Menu 9.6.2)
Use this menu to change your PIN. The PIN check
feature must be enabled to change the PIN.
Phone lock
(Menu 9.6.3)
Use this menu to lock the phone from unauthorised
use.
When this feature is enabled, you must enter a 4- to
8-digit phone password each time the phone is
switched on.
The password is preset to
00000000
. To change the
password, use the
Change password
menu.
Change password
(Menu 9.6.4)
Use this menu to change your phone password.
Privacy
(Menu 9.6.5)
Use this menu to lock access to messages, files, or all
menu functions on the phone, except for call
functions.
When a privacy option is enabled, you must enter the
phone password to access the locked items or
functions.
SIM lock
(Menu 9.6.6)
This menu allows your phone to work only with the
current SIM by assigning a SIM lock code. You must
enter the SIM lock code to use a different SIM card.
Fixed dialling mode
(Menu 9.6.7)
If supported by your SIM card, Fixed Dialling Number
(FDN) mode restricts your outgoing calls to a limited
set of phone numbers. When this feature is enabled,
you can make calls only to phone numbers stored on
the SIM card.
Change PIN2 code
(Menu 9.6.8)
If supported by your SIM card, use this menu to
change your current PIN2.
67
Menu functions
Settings
(Menu 9)
Connection settings
(Menu 9.7)
Use this menu to create and customise the profiles
containing the settings for connecting your phone to
the network. You need these settings to use the web
browser or send MMS messages.
Creating a profile
1. Press <
New
>. If a profile has already been saved,
press <
Options
> and select
Add new
connection
.
2. Specify each information:
•
Profile name
: enter a profile name.
•
Homepage URL
: enter the URL address of the
page to be used as your homepage.
•
Proxy
: activate or deactivate the proxy server.
•
IP address
: enter the IP address of the proxy
server.
•
Port
: enter the port number of the proxy
server.
•
DNS
: activate or deactivate the DNS (Domain
Name Server) addresses.
•
DNS1
and
DNS2
: enter the primary and
secondary DNS addresses.
•
Bearer
: select the network bearer type.
•
Advanced settings
: change the advanced
options. Depending on the bearer setting,
available options vary.
When the bearer is set to
GPRS
:
APN
: enter the access point name.
Login ID
: enter the login ID.
Password
: enter the login password.
When the bearer is set to
GSM
:
Dial number
: enter the PPP phone number.
Login ID
: enter the login ID.
Password
: enter the login password.
Data call type
: select a call type for data
transmission.
3. Press <
Save
> to save the profile.
Your phone is suited for connecting to the network
by default. If you change the settings without first
checking with your service provider, the web
browser, and MMS features may not work properly.
68
Using profile options
Press <
Options
> to access the following options:
•
Edit
: edit the selected profile.
•
Delete
: delete the profile.
•
Add new connection
: add a new profile.
Reset settings
(Menu 9.8)
Use this menu to reset the phone’s settings you have
changed.
1. Press [ ] to select the setting categories to be
reset.
2. Press <
Reset
>.
3. Press <
Yes
> to confirm the reset.
4. Enter the phone password and press <
OK
>.
Solve problems
Help and personal needs
To save the time and expense of an unnecessary
service call, perform the simple checks in this section
before contacting a service professional.
When you switch on your phone, the following
messages may appear:
“Insert SIM”
• Be sure that the SIM card is correctly installed.
“Enter password”
• The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
“Enter PIN”
• You are using your phone for the first time. You
must enter the PIN supplied with the SIM card.
• The PIN check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the
PIN check
menu.
The password is preset to
00000000
. You can
change this password.
p. 66
69
Solve problems
“Enter PUK”
• The PIN code has been entered incorrectly three
times in succession, and the phone is now blocked.
Enter the PUK supplied by your service provider.
“No service,” “Network failure,” or “Not done”
displays
• The network connection has been lost. You may be
in a weak signal area. Move and try again.
• You are trying to access an option for which you
have no subscription with your service provider.
Contact the service provider for further details.
You have entered a number but it was not dialled
• Be sure that you have pressed [ ].
• Be sure you have accessed the right cellular
network.
• Be sure that you have not set an outgoing call
barring option.
Your correspondent cannot reach you
• Be sure that your phone is switched on.
([ ] pressed for more than one second.)
• Be sure that you are accessing the correct cellular
network.
• Be sure that you have not set an incoming call
barring option.
Your correspondent cannot hear you speaking
• Be sure that you have switched on the
microphone.
• Be sure that you are holding the phone close
enough to your mouth. The microphone is located
at the bottom of the phone.
The phone starts beeping and “Warning. Low
battery” flashes on the display
• Your battery is insufficiently charged. Recharge the
battery.
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ). The number of bars indicates the signal
strength from strong ( ) to weak ( ).
• Try moving the phone slightly or moving closer to a
window if you are in a building.
70
No number is dialled when you re-call a
Phonebook entry
•Use the
Contact list
menu to ensure the number
has been stored correctly.
• Re-store the number, if necessary.
The battery doesn’t charge properly or the phone
sometimes turns itself off
• Wipe the charging contacts both on the phone and
on the battery with a clean soft cloth.
If the above guidelines do not help you to solve
the problem, take note of:
• The model and serial numbers of your phone
•Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung after-sales
service.
Health and safety information
Exposure to Radio Frequency (RF) Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
exposure limits for radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the
U.S. government. These FCC exposure limits are
derived from the recommendations of two expert
organizations, the National Counsel on Radiation
Protection and Measurement (NCRP) and the Institute
of Electrical and Electronics Engineers (IEEE). In both
cases, the recommendations were developed by
scientific and engineering experts drawn from
industry, government, and academia after extensive
reviews of the scientific literature related to the
biological effects of RF energy.
71
Health and safety information
The exposure limit set by the FCC for wireless mobile
phones employs a unit of measurement known as the
Specific Absorption Rate (SAR). The SAR is a measure
of the rate of absorption of RF energy by the human
body expressed in units of watts per kilogram (W/kg).
The FCC requires wireless phones to comply with a
safety limit of 1.6 watts per kilogram (1.6 W/kg). The
FCC exposure limit incorporates a substantial margin
of safety to give additional protection to the public and
to account for any variations in measurements.
SAR tests are conducted using standard operating
positions accepted by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels
so as to use only the power required to reach the
network. In general, the closer you are to a wireless
base station antenna, the lower the power output.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that
it does not exceed the exposure limit established by
the FCC. Tests for each model phone are performed in
positions and locations (e.g. at the ear and worn on
the body) as required by the FCC.
The highest SAR values for this model phone as
reported to the FCC are Head: 1.26W/Kg, Body-worn:
0.486W/Kg.
For body worn operations, this model phone has been
testde and meets the FCC exposure guidelines when
used with a Samsung accessory designated for this
product or when used with an accessroy that contains
no metal and that positons the handset a minimum
1.5 cm from the body.
Non-compliance with the above restrictions may result
in violation of FCC RF exposure guidelines.
SAR information on this and other model phones can
be viewed on-line at www.fcc.gov/oet/fccid. This site
uses the phone FCC ID number xxxxxxxxxx.
Sometimes it may be necessary to remove the battery
72
Health and safety information
pack to find the number. Once you have the FCC ID
number for a particular phone, follow the instructions
on the website and it should provide values for typical
or maximum SAR for a particular phone. Additional
product specific SAR information can also be obtained
at www.fcc.gov/cgb/sar.
Consumer Information on Wireless Phones
The U.S. Food and Drug Administration (FDA) has
published a series of Questions and Answers for
consumers relating to radio frequency (RF) exposure
from wireless phones. The FDA publication includes
the following information:
What kinds of phones are the subject of this
update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called
“cell,” “mobile,” or “PCS” phones. These types of
wireless phones can expose the user to measurable
radio frequency energy (RF) because of the short
distance between the phone and the user's head.
These RF exposures are limited by Federal
Communications Commission safety guidelines that
were developed with the advice of FDA and other
federal health and safety agencies. When the phone is
located at greater distances from the user, the
exposure to RF is drastically lower because a person's
RF exposure decreases rapidly with increasing
73
Health and safety information
distance from the source. The so-called “cordless
phones,” which have a base unit connected to the
telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures
well within the FCC's compliance limits.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that
any health problems are associated with using
wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless phones
emit low levels of radio frequency energy (RF) in the
microwave range while being used. They also emit
very low levels of RF when in the stand-by mode.
Whereas high levels of RF can produce health effects
(by heating tissue), exposure to low level RF that does
not produce heating effects causes no known adverse
health effects. Many studies of low level RF exposures
have not found any biological effects. Some studies
have suggested that some biological effects may
occur, but such findings have not been confirmed by
additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
74
Health and safety information
What is FDA's role concerning the safety of
wireless phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as wireless
phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown
to emit radio frequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could
require the manufacturers of wireless phones to notify
users of the health hazard and to repair, replace or
recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
• “Support needed research into possible biological
effects of RF of the type emitted by wireless
phones;
• “Design wireless phones in a way that minimizes
any RF exposure to the user that is not necessary
for device function; and
• “Cooperate in providing users of wireless phones
with the best possible information on possible
effects of wireless phone use on human health.
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at
the federal level. The following agencies belong to this
working group:
• “National Institute for Occupational Safety and
Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health Administration
• “National Telecommunications and Information
Administration
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission
(FCC). All phones that are sold in the United States
must comply with FCC safety guidelines that limit RF
75
Health and safety information
exposure. FCC relies on FDA and other health agencies
for safety questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from
these base stations are typically thousands of times
lower than those they can get from wireless phones.
Base stations are thus not the primary subject of the
safety questions discussed in this document.
What are the results of the research done
already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in
their research methods. Animal experiments
investigating the effects of radio frequency energy
(RF) exposures characteristic of wireless phones have
yielded conflicting results that often cannot be
repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could
accelerate the development of cancer in laboratory
animals. However, many of the studies that showed
increased tumor development used animals that had
been genetically engineered or treated with cancer-
causing chemicals so as to be pre-disposed to develop
cancer in absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day.
These conditions are not similar to the conditions
under which people use wireless phones, so we don't
know with certainty what the results of such studies
mean for human health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use
of wireless phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors of the brain
or salivary gland, leukemia, or other cancers. None of
the studies demonstrated the existence of any harmful
health effects from wireless phones RF exposures.
However, none of the studies can answer questions
about long-term exposures, since the average period
of phone use in these studies was around three years.
76
Health and safety information
What research is needed to decide whether RF
exposure from wireless phones poses a health
risk?
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data that
are needed. Lifetime animal exposure studies could be
completed in a few years. However, very large
numbers of animals would be needed to provide
reliable proof of a cancer promoting effect if one
exists. Epidemiological studies can provide data that is
directly applicable to human populations, but ten or
more years' follow-up may be needed to provide
answers about some health effects, such as cancer.
This is because the interval between the time of
exposure to a cancer-causing agent and the time
tumors develop - if they do - may be many, many
years. The interpretation of epidemiological studies is
hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones.
Many factors affect this measurement, such as the
angle at which the phone is held, or which model of
phone is used.
What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization international Electromagnetic Fields
(EMF) Project since its inception in 1996. An influential
result of this work has been the development of a
detailed agenda of research needs that has driven the
establishment of new research programs around the
world. The Project has also helped develop a series of
public information documents on EMF issues.
FDA and Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative
Research and Development Agreement (CRADA) to do
research on wireless phone safety. FDA provides the
77
Health and safety information
scientific oversight, obtaining input from experts in
government, industry, and academic organizations.
CTIA-funded research is conducted through contracts
to independent investigators. The initial research will
include both laboratory studies and studies of wireless
phone users. The CRADA will also include a broad
assessment of additional research needs in the
context of the latest research developments around
the world.
What steps can I take to reduce my exposure
to radio frequency energy from my wireless
phone?
If there is a risk from these products - and at this
point we do not know that there is - it is probably very
small. But if you are concerned about avoiding even
potential risks, you can take a few simple steps to
minimize your exposure to radio frequency energy
(RF). Since time is a key factor in how much exposure
a person receives, reducing the amount of time spent
using a wireless phone will reduce RF exposure.
• “If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of the
RF, since the exposure level drops off dramatically
with distance. For example, you could use a
headset and carry the wireless phone away from
your body or use a wireless phone connected to a
remote antenna.
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are concerned
about the RF exposure from these products, you can
use measures like those described above to reduce
your RF exposure from wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower exposure
to radio frequency energy (RF), the measures
described above would apply to children and
teenagers using wireless phones. Reducing the time of
wireless phone use and increasing the distance
between the user and the RF source will reduce RF
exposure.
78
Health and safety information
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at all. For
example, the government in the United Kingdom
distributed leaflets containing such a recommendation
in December 2000. They noted that no evidence exists
that using a wireless phone causes brain tumors or
other ill effects. Their recommendation to limit
wireless phone use by children was strictly
precautionary; it was not based on scientific evidence
that any health hazard exists.
Do hands-free kits for wireless phones reduce
risks from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free
kits can be used with wireless phones for convenience
and comfort. These systems reduce the absorption of
RF energy in the head because the phone, which is the
source of the RF emissions, will not be placed against
the head. On the other hand, if the phone is mounted
against the waist or other part of the body during use,
then that part of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are required to
meet safety requirements regardless of whether they
are used against the head or against the body. Either
configuration should result in compliance with the
safety limit.
Do wireless phone accessories that claim to
shield the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head
from those emissions reduce risks. Some products
that claim to shield the user from RF absorption use
special phone cases, while others involve nothing
more than a metallic accessory attached to the phone.
Studies have shown that these products generally do
not work as advertised. Unlike “hand-free” kits, these
so-called “shields” may interfere with proper operation
of the phone. The phone may be forced to boost its
power to compensate, leading to an increase in RF
absorption. In February 2002, the Federal trade
Commission (FTC) charged two companies that sold
79
Health and safety information
Settings
devices that claimed to protect wireless phone users
from radiation with making false and unsubstantiated
claims. According to FTC, these defendants lacked a
reasonable basis to substantiate their claim.
What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason,
FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted
cardiac pacemakers and defibrillators from wireless
telephones. This test method is now part of a standard
sponsored by the Association for the Advancement of
Medical instrumentation (AAMI). The final draft, a joint
effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This
standard will allow manufacturers to ensure that
cardiac pacemakers and defibrillators are safe from
wireless phone EMI. FDA has tested wireless phones
and helped develop a voluntary standard sponsored by
the Institute of Electrical and Electronic Engineers
(IEEE). This standard specifies test methods and
performance requirements for hearing aids and
wireless phones so that no interference occurs when a
person uses a compatible phone and a compatible
hearing aid at the same time. This standard was
approved by the IEEE in 2000.
FDA continues to monitor the use of wireless phones
for possible interactions with other medical devices.
Should harmful interference be found to occur, FDA
will conduct testing to assess the interference and
work to resolve the problem.
Additional information on the safety of RF exposures
from various sources can be obtained from the
following organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health Administration's
(OSHA):
http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
80
Health and safety information
• National institute for Occupational Safety and
Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-Ionizing
Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board (UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug
Administration
http://www.fda.gov/cellphones
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime.
But an important responsibility accompanies the
benefits of wireless phones, one that every user must
uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a
car, practice good common sense and remember the
following tips:
1. Get to know your wireless phone and its features,
such as speed dial and redial. If available, these
features help you to place your call without taking
your attention off the road.
2. When available, use a hands-free device. If
possible, add an additional layer of convenience
and safety to your wireless phone with one of the
many hands free accessories available today.
81
Health and safety information
Settings
3. Position your wireless phone within easy reach. Be
able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your
voice mail answer it for you.
4. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions. Rain,
sleet, snow, ice and even heavy traffic can be
hazardous.
5. Do not take notes or look up phone numbers while
driving. Jotting down a “to do” list or flipping
through your address book takes attention away
from your primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your car
will be stationary. If you need to make a call while
moving, dial only a few numbers, check the road
and your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make
people you are talking with aware you are driving
and suspend conversations that have the potential
to divert your attention from the road.
8. Use your wireless phone to call for help. Dial 9-1-1
or other local emergency number in the case of
fire, traffic accident or medical emergencies.
Remember, it is a free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto accident, crime in
progress or other serious emergency where lives
are in danger, call 9-1-1 or other local emergency
number, as you would want others to do for you.
10.Call roadside assistance or a special non-
emergency wireless assistance number when
necessary. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a
minor traffic accident where no one appears
injured, or a vehicle you know to be stolen, call
roadside assistance or other special non-
emergency number.
82
Health and safety information
“The wireless industry reminds you to use your
phone safely when driving.”
For more information, please call 1-888-901-SAFE, or
visit our web-site www.wow-com.com
Provided by the Cellular Telecommunications &
Internet Association
Operating Environment
Remember to follow any special regulations in force in
any area and always switch your phone off whenever it
is forbidden to use it, or when it may cause
interference or danger. When connecting the phone or
any accessory to another device, read its user's guide
for detailed safety instructions. Do not connect
incompatible products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation of
the equipment and for the safety of personnel, it is
recommended that the equipment should only be used
in the normal operating position (held to your ear with
the antenna pointing over your shoulder).
Using Your Phone Near Other Electronic
Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against the
RF signals from your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be maintained
between a wireless phone and a pacemaker to avoid
potential interference with the pacemaker.
These recommendations are consistent with the
independent research and recommendations of
Wireless Technology Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone is
switched on.
• should not carry the phone in a breast pocket.
83
Health and safety information
Settings
• should use the ear opposite the pacemaker to
minimize potential interference.
If you have any reason to suspect that interference is
taking place, switch your phone off immediately.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you
may wish to consult your hearing aid manufacturer to
discuss alternatives.
Other Medical Devices
If you use any other personal medical devices, consult
the manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
information. Switch your phone off in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to
external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should also
consult the manufacturer of any equipment that has
been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where posted
notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even
death.
Users are advised to switch the phone off while at a
refueling point (service station). Users are reminded of
the need to observe restrictions on the use of radio
equipment in fuel depots (fuel storage and distribution
84
Health and safety information
areas), chemical plants or where blasting operations
are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such
as propane or butane), areas where the air contains
chemicals or particles, such as grain, dust or metal
powders, and any other area where you would
normally be advised to turn off your vehicle engine.
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well as
user programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should
never rely solely on any wireless phone for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not be
possible on all wireless phone networks or when
certain network services and/or phone features are in
use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 911 or other official
emergency number). Emergency numbers vary by
location.
3. Press .
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular service
provider.
When making an emergency call, remember to give all
the necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut
off the call until given permission to do so.
Restricting Children's access to your Phone
85
Health and safety information
Settings
Your phone is not a toy. Children should not be allowed
to play with it because they could hurt themselves and
others, damage the phone or make calls that increase
your phone bill.
FCC Notice and Cautions
FCC Notice
The phone may cause TV or radio interference if used
in close proximity to receiving equipment. The FCC
can require you to stop using the phone if such
interference cannot be eliminated.
Vehicles using liquefied petroleum gas (such as
propane or butane) must comply with the National Fire
Protection Standard (NFPA-58). For a copy of this
standard, contact the National Fire Protection
Association, One Battery march Park, Quincy, MA
02269, Attn: Publication Sales Division.
Cautions
Changes or modifications made in the radio phone, not
expressly approved by Samsung, will void the user’s
authority to operate the equipment.
Only use approved batteries, antennas and chargers.
The use of any unauthorized accessories may be
dangerous and void the phone warranty if said
accessories cause damage or a defect to the phone.
Although your phone is quite sturdy, it is a complex
piece of equipment and can be broken. Avoid
dropping, hitting, bending or sitting on it.
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
86
Health and safety information
Other Important Safety Information
• Only qualified personnel should service the phone
or install the phone in a vehicle. Faulty installation
or service may be dangerous and may invalidate
any warranty applicable to the device.
• Check regularly that all wireless phone equipment
in your vehicle is mounted and operating properly.
• Do not store or carry flammable liquids, gases or
explosive materials in the same compartment as
the phone, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag or
in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
• Switch your phone off before boarding an aircraft.
The use of wireless phone in aircraft is illegal and
may be dangerous to the aircraft's operation.
• Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
87
Health and safety information
Settings
Product Performance
Getting the Most Out of Your Signal Reception
The quality of each call you make or receive depends
on the signal strength in your area. Your phone
informs you of the current signal strength by
displaying a number of bars next to the signal strength
icon. The more bars displayed, the stronger the signal.
If you're inside a building, being near a window may
give you better reception.
Understanding the Power Save Feature
If your phone is unable to find a signal after 15
minutes of searching, a Power Save feature is
automatically activated. If your phone is active, it
periodically rechecks service availability or you can
check it yourself by pressing any key.
Anytime the Power Save feature is activated, a
message displays on the screen. When a signal is
found, your phone returns to standby mode.
Understanding How Your Phone Operates
Your phone is basically a radio transmitter and
receiver. When it's turned on, it receives and transmits
radio frequency (RF) signals. When you use your
phone, the system handling your call controls the
power level. This power can range from 0.006 watts to
0.2 watts in digital mode.
Maintaining Your Phone's Peak Performance
For the best care of your phone, only authorized
personnel should service your phone and accessories.
Faulty service may void the warranty.
There are several simple guidelines to operating your
phone properly and maintaining safe, satisfactory
service.
• Hold the phone with the antenna raised, fully-
extended and over your shoulder.
• Try not to hold, bend or twist the phone's antenna.
• Don't use the phone if the antenna is damaged.
• Speak directly into the phone's receiver.
88
Health and safety information
• Avoid exposing your phone and accessories to rain
or liquid spills. If your phone does get wet,
immediately turn the power off and remove the
battery. If it is inoperable, call Customer Care for
service.
Availability of Various Features/Ring
Tones
Many services and features are network dependent
and may require additional subscription and/or usage
charges. Not all features are available for purchase or
use in all areas. Downloadable Ring Tones may be
available at an additional cost. Other conditions and
restrictions may apply. See your service provider for
additional information.
Battery Standby and Talk Time
Standby and talk times will vary depending on phone
usage patterns and conditions. Battery power
consumption depends on factors such as network
configuration, signal strength, operating temperature,
features selected, frequency of calls, and voice, data,
and other application usage patterns.
Battery Precautions
• Never use any charger or battery that is damaged
in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network's base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out.
When the operation time (talk time and standby
time) is noticeably shorter than normal, it is time
to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
89
Health and safety information
Settings
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
disconnect it from the power source. Do not leave
the battery connected to a charger for more than a
week, since overcharging may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
• Do not leave the battery in hot or cold places, such
as in a car in summer or winter conditions, as you
will reduce the capacity and lifetime of the battery.
Always try to keep the battery at room
temperature. A phone with a hot or cold battery
may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly
affected by temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between the
+ and - terminals of the battery (metal strips on
the battery), for example when you carry a spare
battery in a pocket or bag. Short-circuiting the
terminals may damage the battery or the object
causing the short-circuiting.
• Dispose of used batteries in accordance with local
regulations. In some areas, the disposal of
batteries in household or business trash may be
prohibited. For safe disposal options for Li-Ion
batteries, contact your nearest Samsung
authorized service center. Always recycle. Do not
dispose of batteries in a fire.
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode electronic
circuits.
90
Health and safety information
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage to
the phone.
• Do not use or store the phone in dusty, dirty areas,
as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the phone,
which may damage the phone's electronic circuit
boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it with
a soft cloth slightly dampened in a mild soap-and-
water solution.
• Do not paint the phone. Paint can clog the device's
moving parts and prevent proper operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• When the phone or battery gets wet, the label
indicating water damage inside the phone changes
color. In this case, phone repairs are no longer
guaranteed by the manufacturer's warranty, even
if the warranty for your phone has not expired.
• If your phone has a flash or light, do not use it too
close to the eyes of people or animals. This may
cause damage to their eyes.
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
91
Index
A
AB mode, text input • 19
Active flip • 60
Alarm • 33
Answering
call • 22
second call • 24
Anykey answer • 60
Auto redial • 60
B
Background image • 60
Backlight time, set • 61
Band selection • 65
Barring, calls • 63
Battery
charging • 7
low indicator • 8
precautions • 71
Broadcast messages • 41, 45
Browser, web • 35
C
Calculator • 34
Calendar • 49
Call cost • 27
Call log
dialled • 26
missed • 26
received • 26
Call time • 26
Caller groups • 29
Caller ID • 61, 64
Calls answering • 22
barring • 63
diverting • 63
holding • 23
redialling • 22
rejecting • 22
transferring • 25
waiting • 64
Camera
photos • 53
videos • 55
CB (Cell Broadcast) messages •
41, 45
Characters, enter • 19
Configuration messages • 40
Connection tone • 62
Converter • 34
Creating messages
MMS • 38
SMS • 38
CUG (Closed User Group) • 65
D
Date, set • 57
Deleting
call log • 26
events • 52
MMS • 41, 42, 43
phonebook • 28, 30
SMS • 40, 42, 43
Dialled calls • 26
Dialling display, set • 61
Display
backlight, set • 61
brightness • 61
contrast • 61
icons • 10
language • 58
layout • 10
settings • 60
Diverting, calls • 63
DRM (Digital Rights
Management) • 46
DTMF tones, send • 24
E
Emergency calls • 75
F
FDN (Fixed Dialling Number)
mode • 66
File manager • 46
Flip tone • 62
G
Games • 31
Greeting message • 58
H
Health and safety • 70
Holding, call • 23
I
Icons, description • 10
Images, downloaded • 46
Inbox, messages • 39
Infrared port • 58
92
Index
International calls • 21
Internet • 35
J
Java applications • 31
K
Keypad tones
selecting • 61
sending/muting • 24
volume • 62
L
Language, select • 58
Last number, redial • 22
Locking
menu functions • 66
phone • 66
SIM card • 66
Low battery indicator • 8
M
Memory status
downloaded items • 49
file manager • 49
messages • 46
phonebook 31
Message tone • 62
Messages
cell broadcast • 41, 45
configuration • 41
greeting • 58
MMS • 38, 40
push • 41, 45
SMS • 38
Minute minder • 62
Missed calls • 26
MMS messages
creating/sending • 38
deleting • 41
setting • 44
viewing • 39
Multiparty-call • 25
N
Name card • 30
Names
entering • 19
searching • 27
Network band, select • 65
Network selection • 64
Network services • 63
O
Outbox, messages • 41
P
Password
call barring • 64
phone • 66
Phonecare and maintenance •
76
display • 10
icons • 10
locking • 66
password • 66
resetting • 68
switching on/off • 8
unpacking • 6
Phonebook
adding • 28
deleting • 28, 30
finding • 27
managing • 30
options • 28
speed dialling • 29
Photos
taking • 52
viewing • 46
PIN, change • 66
PIN2, change • 66
Power on/off tone • 62
Privacy • 66
Problems, solve • 68
Push messages • 41, 45
Q
Quiet mode
entering • 13
setting • 62
R
Received calls • 26
Received messages • 39
Recording
videos • 55
voice memos • 32
Redialling
automatically • 60
manually • 22
Resetting phone • 68
Ringer
incoming calls • 61
messages • 62
Road safety • 72
Roaming • 64
93
Index
S
Safety
information • 70
precautions • 1
Security, calls • 65
Sent messages • 42
Shortcut • 59
SIM card
inserting • 7
locking • 66
Skin colour • 60
SMS messages
creating/sending • 38
deleting • 40
setting • 43
viewing • 39
Sound settings • 61
Sounds, downloaded • 48
Speakerphone • 24
Speed dial • 29
Stopwatch • 35
Switching on/off
microphone • 24
phone • 8
T
T9 mode, text input • 20
Templates, message • 43
Text, enter • 19
Time, set • 57
Timer • 35
V
Videos
playing • 47
recording • 55
Voice recorder
playing • 32
recording • 32
Voicemail server • 64
W
Waiting call • 64
Wallpaper • 60
Web browser
access • 35
bookmarks • 37
World time • 33
