Samsung Electronics Co SGHX656 Dual-Band GSM Phone User Manual
Samsung Electronics Co Ltd Dual-Band GSM Phone Users Manual
Users Manual
* Depending on the software installed or your service provider or country,
some of the descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear different
from the illustrations in this guide.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-10745A
English. 04/2006. Rev. 1.0
X656.book Page 1 Tuesday, May 2, 2006 11:18 AM
SGH-X656
User’s Guide
Please read this manual before operating your phone, and keep it
for future reference.
X656.book Page 2 Tuesday, May 2, 2006 11:18 AM
Drive safely at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using
them in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external
radio frequency energy. Follow any regulations or
rules in force.
Interference
All wireless phones may be subject to
interference, which could affect their performance.
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
X656.book Page 3 Tuesday, May 2, 2006 11:18 AM
1
Important safety precautions
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency call
Key in the emergency number for your present
location, then press
.
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved batteries and
accessories, such as headsets and PC data cables.
Useof any unauthorised accessories could damage you
or your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 69.
• The phone could explode if the battery is replaced with an
incorrect type.
• Dispose of used batteries according to the manufacturer’s
instructions.
At very high volumes, prolonged listening to a
headset can damage your hearing.
X656.book Page 1 Tuesday, May 2, 2006 11:18 AM
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside of the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful
attention to the subsequent information
regarding safety or phone features.
Indicates that you can get more information on
the referenced page.
→
Indicates that you need to press the
Navigation keys to scroll to the specified option
and then select it.
[
]
Indicates a key on the phone.
For example,
[]
<
>
Indicates a soft key, whose function is
displayed on the phone screen.
For example, <
Menu
>
• Camera
Use the camera module on your
phone to take a photo.
Special
features of your phone
•IrDA
Send and receive images, sounds,
other personal data via an infrared
port.
•Web browser
Access the wireless web to get up-
to-the-minute information and a
wide variety of media content.
X656.book Page 2 Tuesday, May 2, 2006 11:18 AM
3
Special features of your phone
• Phonebook
Store home, office, or cellular
phone numbers for your contacts.
• Multimedia Message Service (MMS)
Send and receive MMS messages with a
combination of text, images, and audio.
•FM radio
Listen to your favorite FM radio
stations anytime, anywhere.
• Java game
Enjoy Java
™
-based embedded
games and download new games.
•Calendar
Keep track of your daily, weekly,
and monthly schedule.
• Voice recorder
Record memos or sounds.
•Alarm
Use your phone as an alarm clock
to wake you up in the morning or
notify you of an impending event.
X656.book Page 3 Tuesday, May 2, 2006 11:18 AM
4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Keys, features, and locations
Get started 7
First steps to operate your phone
Install and charge the phone ................................... 7
Power on or off ...................................................... 8
Keys and display .................................................... 9
Access menu functions .......................................... 11
Customise your phone .......................................... 12
Make/Answer calls ................................................ 14
Step outside of the phone 15
Begin with your camera, the web, and other special features
Use the camera ................................................... 15
Listen to the FM radio ........................................... 15
Browse the web ................................................... 16
Use Phonebook .................................................... 17
Send messages .................................................... 18
View messages .................................................... 19
Use infrared ........................................................ 20
Manage your schedule .......................................... 21
Enter text 22
ABC, T9, Number, and Symbol modes
Call functions 25
Advanced calling features
Menu functions 29
All menu options listed
Solve problems 67
Help and personal needs
Health and safety information 69
Index 91
X656.book Page 4 Tuesday, May 2, 2006 11:18 AM
5
Overview of menu functions
To access Menu mode, press <
Menu
> in Idle mode.
1 SIM-AT MENU
p.32
2 Call records
p.33
1 Missed calls
2 Received calls
3 Dialled calls
4 Delete all
5 Call time
6 Call costs*
p.33
p.33
p.33
p.33
p.34
p.34
3 Network services
p.34
1 Call diverting
2 Call barring
3 Call waiting
4 Network selection
5 Caller ID
6 Band selection
7 Active line*
p.35
p.35
p.36
p.36
p.36
p.36
p.37
4 Sound settings
p.37
1 Incoming calls
2 Messages
3 Power on/off
4 Connection tone
5 Key tone
p.37
p.37
p.37
p.38
p.38
4 Sound settings
(continued)
6 Minute minder
7 Quiet mode
8 Alerts on call
p.38
p.38
p.38
5 Messages
p.38
1 Short messages
2 Multimedia messages
3 Push messages
4 Preset messages
5 Voice mail
6 Broadcast
7 Settings
8 Memory status
p.38
p.41
p.43
p.44
p.44
p.44
p.45
p.47
6 Fun box
p.47
1 WWW services
2 Media box
3 JAVA world
4 FM radio
p.47
p.50
p.52
p.53
7 Organiser
p.54
1 New memo
2 Calendar
3 To do list
p.54
p.55
p.56
7 Organiser
(continued)
4 Clock
5 Alarm
6 Voice recorder
7 Calculator
8 Conversion
9 Timer
10 Stopwatch
p.56
p.57
p.58
p.59
p.59
p.60
p.60
8 Camera
p.60
1 Take photos
2 My photos
3 My albums
4 Delete all
5 Settings
6 Memory status
p.60
p.63
p.63
p.63
p.63
p.63
9 Phone settings
p.64
1 Display
2 Greeting message
3 Language
4 Security
5 Auto redial
6 Voice clarity
p.64
p.65
p.65
p.65
p.66
p.66
Press <
Phonebook
> in Idle
mode.
Phonebook
p.29
1 Find name
2 Add entry
3 Speed-dial list
4 Copy all to phone
5 Delete all
6 Own number
7 Group setting
8 Memory status
9 Service directory
*
* Shows only if supported by your SIM
card.
p.29
p.29
p.30
p.31
p.31
p.31
p.31
p.32
p.32
9 Phone settings
(continued)
7 Anykey answer
8 Active folder
9 Side key
10 Infrared activation
11 Reset settings
p.66
p.66
p.67
p.67
p.67
X656.book Page 5 Tuesday, May 2, 2006 11:18 AM
6
Unpack
Make sure you have each item
You can obtain various accessories
from your local Samsung dealer.
Phone Travel Adapter
The items supplied with your phone
and the accessories at your
Samsung dealer may vary,
depending on your country or
service provider.
Battery User’s Guide
Your phone
Keys, features, and locations
Special
function keys
Dial key
Volume keys
Left soft key
Microphone
Right soft key
Alphanumeric
keys
Power on/off/
Menu exit key
Navigation keys
(Up/Down/Left/
Right)
Camera key
Camera
lens
Earpiece
Display
Infrared
port
Service light
Web access/
Confirm key
Headset jack
Cancel/Delete
key
X656.book Page 6 Tuesday, May 2, 2006 11:18 AM
7
Get started
First steps to operate your phone
SIM card information
When you subscribe to a cellular network, you receive
a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your
PIN, and available optional services.
Install and charge the phone
Remove the battery.
If the
phone is already
on, first turn it off by
pressing and holding
[].
Insert the SIM card.
Make sure that the gold-
coloured contacts on the
card are face down.
Reattach the battery. Plug the travel adapter
into the phone.
Plug the adapter into a standard AC wall outlet.
When the phone is completely charged (the
battery icon becomes still), unplug the adapter
from the power outlet.
X656.book Page 7 Tuesday, May 2, 2006 11:18 AM
8
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
Remove the adapter from the phone.
Switch on
Do not turn on the
phone when
mobile phone use
is prohibited.
1. Open the phone.
2. Press [ ].
3. If necessary, enter the PIN and
press <
OK
>.
Switch off
1. Open the phone.
2. Press and hold [ ].
X656.book Page 8 Tuesday, May 2, 2006 11:18 AM
9
Get started
Keys and display
Keys
Perform the function indicated on the
bottom line of the display.
In Idle mode, access the following menus
directly:
•Up:
Create
in
Multimedia
messages
•Down:
SIM-AT MENU
•Left:
FM radio
• Right:
JAVA world
In Menu mode, scroll through menu
options.
In Idle mode, launch the web browser.
Make or answer a call.
In Idle mode, retrieve numbers recently
dialled, received, or missed.
Delete characters from the display.
In Menu mode, return to the previous
menu level. In a text input field, press
and hold to return to the previous menu
level.
In Idle mode, enter the
New memo
menu when held down.
Press and hold to switch the phone on
and off.
End a call.
In Menu mode, cancel input and return
the phone to Idle mode.
Enter numbers, letters, and some special
characters.
In Idle mode, press and hold
[1]
to
access your voicemail server. Press and
hold [
0
] to enter an international call
prefix.
X656.book Page 9 Tuesday, May 2, 2006 11:18 AM
10
Get started
Display
Enter special characters.
In Idle mode, press and hold [ ] to
activate or deactivate Quiet mode. Press
and hold [ ] to enter a pause between
numbers.
Adjust the phone volume.
In Idle mode, with the phone open,
adjust the keypad tone volume.
In Idle mode, press and hold to turn on
the camera.
In Capture mode, take a photo.
Layout
Icons
*
Received signal strength
Call in progress
Out of your service area; you
cannot send or receive calls
GPRS network
Home Zone, if you have
registered for the appropriate
service
Text and graphics
display messages,
instructions, and
information you enter.
Soft key function
indicators
show the current functions
assigned to the soft keys.
Icons
display various icons.
Menu Phonebook
X656.book Page 10 Tuesday, May 2, 2006 11:18 AM
11
Get started
Access menu functions
Office Zone, if you have
registered for the appropriate
service
New SMS message
New MMS message
New voicemail
Alarm set
p. 57
Call diverting feature active
p. 35
Infrared port active
p. 67
Set to vibrate call ringer
p. 37
Quiet mode
p. 38
Battery power level
* Depending on your country or service provider, the icons
shown on the display may vary.
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current role.
Press the left
soft key to select
the highlighted
option.
Press the right
soft key to return
to the previous
menu level.
Select
X656.book Page 11 Tuesday, May 2, 2006 11:18 AM
12
Get started
Customise your phone
Select an
option
1. Press a desired soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press <
Select
> or
[]
to
confirm the function displayed
or option highlighted.
4. To exit, choose either of the
following methods:
• Press
<>
or [
C
] to move
up one level.
• Press
[]
to return to Idle
mode.
Use shortcuts
Press the number key
corresponding to the option you
want. For the index numbers 10 and
11, press [
0
] and [ ] respectively.
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Language
→ Text language
.
2. Select a language.
1. In Idle mode, press <
Menu
>
and select
Sound settings
→
Incoming calls
.
2. Select a ringtone category,
Default melodies
or
My
sounds
.
3. Select a ringtone.
Display
language
Call ringer
melody
X656.book Page 12 Tuesday, May 2, 2006 11:18 AM
13
Get started
You can set wallpaper for the idle
screen on the display.
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Display
→
Wallpaper
.
2. Select an image category,
Default wallpapers
,
Photos
,
or
Downloaded images
.
3. Select an image.
You can change the colour for the
display components, such as title
bars and highlight bars.
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Display
→
Skin
.
2. Select a colour pattern.
Idle mode
Wallpaper
Menu mode
Skin colour
You can switch the phone to Quiet
mode to avoid disturbing other
people with your phone sounds.
Press and hold
[]
in Idle mode.
You can protect the phone against
unauthorized use with a phone
password. The phone will require
the password on power-up.
1. In Idle mode, press <
Menu
>
and select
Phone settings
→
Security
→
Change
password
.
2. Enter the default password,
00000000
, and press <
OK
>.
3. Enter a new 4- to 8-digit
password and press <
OK
>.
Quiet mode
Phone lock
X656.book Page 13 Tuesday, May 2, 2006 11:18 AM
14
Make/Answer calls
4. Enter the new password again
and press <
OK
>.
5. Select
Phone lock
.
6. Select
Enable
.
7. Enter the password and press
<
OK
>.
Phone lock
(continued)
1. Enter an area code and phone
number.
2. Press
[]
.
3. To end the call, press
[]
.
1. When the phone rings, press
[]
.
2. To end the call, press
[]
.
Press [ / ].
Make a call
Answer a call
Adjust the
volume during
a call
X656.book Page 14 Tuesday, May 2, 2006 11:18 AM
15
Step outside of the phone
Step outside of the phone
Begin with your camera, the web, and other special
features
Use the camera
Listen to the FM radio
1. In Idle mode, press and hold
[ ] to turn on the camera.
2. Aim the lens at the subject and
make any desired adjustments.
3. Press
[],
the left soft key, or
[ ] to take a photo. The photo
is automatically saved.
4. Press [
C
] to take another
photo.
1. In Idle mode, press <
Menu
>
and select
Camera
→
My
photos
.
2. Select the photo you want.
Take a photo
View a photo
1. Plug the connector of the
supplied headset into the jack
on the left side of the phone.
2. In Idle mode, press [Left].
3. Press <
Options
> and select
Power on
.
4. Press [Left] or [Right] to find
available radio stations.
5. To turn off the radio, disconnect
the headset from the phone.
Listening to the
radio
X656.book Page 15 Tuesday, May 2, 2006 11:18 AM
16
Step outside of the phone
Browse the web
Using a built-in web browser, you can easily access the
wireless web to get a variety of up-to-date services
and information and to download web content.
1. Plug the connector of the
supplied headset into the jack
on the left side of the phone.
2. From the FM Radio screen,
press <
Options
> and select
Power on
.
3. Scroll to an empty location.
4. Press [Left] or [Right] to find
the radio station you want.
5. Press <
Options
> and select
Add
.
6. Enter the title of the station and
press <
OK
>.
7. Press <
OK
> when the
frequency for the selected radio
station displays.
Storing a radio
station
In Idle mode, press
[]
.
• To scroll through browser items,
press [Up] or [Down].
• To select an item, press < >.
• To return to the previous page,
press <
Back
> or [
C
].
• To use options, press [ ] or
select on the top of the
screen.
Launch the web
browser
Navigate the
web
X656.book Page 16 Tuesday, May 2, 2006 11:18 AM
17
Step outside of the phone
Use Phonebook
To the phone’s memory:
1. In Idle mode, enter a phone
number and press <
Save
>.
2. Select
Phone
→
a number type.
3. Enter a name and press <
OK
>
to save the contact.
To th e S IM ca rd:
1. In Idle mode, enter a phone
number and press <
Save
>.
2. Select
SIM
.
3. Enter a name and press <
OK
>.
4. If necessary, change a location
number.
5. Press <
OK
> to save the
contact.
Add a contact
1. In Idle mode, press
<
Phonebook
> and select
Find
name
.
2. Enter the first few letters of the
name you want.
3. Select a contact.
4. Scroll to a number and press
[]
to dial.
Find a contact
X656.book Page 17 Tuesday, May 2, 2006 11:18 AM
18
Step outside of the phone
Send messages
1. In Idle mode, press <
Menu
>
and select
Messages
→
Short
messages
→
Create
.
2. Enter the message text.
3. Press [ ].
4. Enter destination numbers and
press <
OK
>.
5. Press <
Send
> to send the
message.
1. In Idle mode, press [Up].
2. Select
Subject
.
3. Enter the message subject and
press <
OK
>.
Send a text
message (SMS)
Send a
multimedia
message (MMS)
4. Select
and add an
image file.
5. Select
Sound
and add a sound
file.
6. Select
Message
and enter the
message text.
7. Press <
Opt.
> and select
Done
.
8. When you have finished, press
<
Opt.
> and select
Send
.
9. Select an empty location.
10. Select
Number
or
E-mail
and
enter destination numbers or
addresses.
Otherwise, select
Phonebook
to retrieve one from your
Phonebook.
11. Press <
Send
> to send the
message.
X656.book Page 18 Tuesday, May 2, 2006 11:18 AM
19
Step outside of the phone
View messages
When a notification appears:
1. Press <
View
>.
2. Select the message from the
Inbox.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
Short
messages
→
Inbox
.
2. Select a message.
View a text
message
When a notification appears:
1. Press <
View
>.
2. Press <
Options
> and select
Retrieve
.
3. Select the message from the
Inbox.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
Multimedia messages
→
Inbox
.
2. Select a message.
1. Press and hold [
1
] in Idle
mode.
2. Follow the instructions from the
system.
View a
multimedia
message
Access a
voicemail
X656.book Page 19 Tuesday, May 2, 2006 11:18 AM
20
Step outside of the phone
Use infrared
Your phone has an infrared port that allows you to
send or receive data from different types of IrDA-
compliant devices.
1. Access an application,
Phonebook
,
Camera
, or
Media box
.
2. Select an item.
3. Press <
Options
> and select
Send via infrared
.
4. Align the infrared ports on the
phone and the other device.
Send data
1. Turn the infrared feature to
On
(the IrDA icon displays on
the top line).
2. Align the infrared port on your
phone, with the infrared port of
the device you want to share
information with.
3. When you have received data
from another device, you are
prompted to save the file.
4. Select
Yes
to save the file in
the corresponding folder.
Receive data
X656.book Page 20 Tuesday, May 2, 2006 11:18 AM
21
Step outside of the phone
Manage your schedule
1. In Idle mode, press and hold
[
C
].
2. Enter the memo contents and
press <
OK
>.
3. Select a memo type.
4. Select a date from the calendar.
5. For
Call
, enter a phone number
you need to dial and press
<
OK
>.
For
Anniversary
, skip to step
7.
6. Enter the time for the memo
and press <
OK
>.
7. Press <
Yes
> to set an alarm.
Create a memo
8. Enter the time for the alarm to
sound and press <
OK
>.
9. Select an alarm tone. The
memo is saved.
1. In Idle mode, press <
Menu
>
and select
Organiser
→
Calendar
.
2. Select a date.
3. Press [Left] or [Right] to access
the other items scheduled for
the selected day.
Access your
schedule
X656.book Page 21 Tuesday, May 2, 2006 11:18 AM
22
Enter text
ABC, T9, Number, and Symbol modes
You can enter text for some features such as
messaging, Phonebook, or Organiser, using ABC
mode, T9 mode, Number mode, and Symbol mode.
Changing the text input mode
• Press the right soft key and select the mode you
want.
• Press and hold the right soft key to switch between
T9 mode and ABC mode.
• Press and hold [ ] to switch to Number mode.
• Press and hold [ ] to switch to Symbol mode.
Using ABC mode
Press the appropriate key until the character you want
appears on the screen.
(Creating an SMS message with GSM-alphabet encoding)
Characters in order displayed
Key
Upper case Lower case
X656.book Page 22 Tuesday, May 2, 2006 11:18 AM
23
Enter text
Other ABC mode operations
• To enter the same letter twice or to enter a
different letter on the same key, wait for the cursor
to move to the right automatically or press [Right].
Then, enter the next letter.
• Press [ ] to change case. Lower case (No
indicator), Initial capital ( ), and Capital lock
( ) are available.
• Press [ ] to insert a space.
• Press [Left] or [Right] to move the cursor.
•Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Using T9 mode
T9 is a predictive text input mode that allows you to
key in any character using single keystrokes.
Entering a word in T9 mode
1. Press [
2
] to [
9
]
to start entering a word. Press
each key once for each letter.
For example, press [
4
], [
3
], [
5
], [
5
], and [
6
] to
enter HELLO in T9 mode.
T9 predicts the word that you are typing, and it
may change with each key that you press.
2. Enter the whole word before editing or deleting
characters.
3. When the word displays correctly, go to step 4.
Otherwise, press [
0
] to display alternative word
choices for the keys that you have pressed.
For example, OF and ME use [
6
] and [
3
].
4. Press [ ] to insert a space and enter the next
word.
Other T9 mode operations
• Press [
1
] to enter periods or apostrophes
automatically.
• Press [ ] to change case. Lower case (No
indicator), Initial capital ( ), and Capital lock
( ) are available.
• Press [ ] to insert a space.
X656.book Page 23 Tuesday, May 2, 2006 11:18 AM
24
Enter text
• Press [Left] or [Right] to move the cursor.
•Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Adding a new word to the T9 dictionary
This feature may not be available for some languages.
1. Enter the word that you want to add.
2. Press [
0
] to display alternative words for your key
presses. When there are no more alternative
words,
Spell
appears on the bottom line.
3. Press <
Spell
>.
4. Enter the word you want using ABC mode and
press <
OK
>.
Using Number mode
Number mode enables you to enter numbers.
Press the keys corresponding to the digits you want.
Using Symbol mode
Symbol mode enables you to insert symbols.
To Press
display more symbols [Up] or [Down].
select a symbol the corresponding
number key.
clear the symbol(s) [
C
].
insert the symbol(s) <
OK
>.
X656.book Page 24 Tuesday, May 2, 2006 11:18 AM
25
Call functions
Advanced calling features
Making a call
1. In Idle mode, enter the area code and phone
number.
2. Press
[]
.
3. When you want to end the call, press
[]
.
Making an international call
1. In Idle mode, press and hold
[
0
]
. The
+
character
appears.
2. Enter the country code, area code, and phone
number, then press
[]
.
Redialing recent numbers
1. In Idle mode, press
[]
to display the list of
recent numbers.
2. Scroll to the number you want and press
[]
.
Making a call from Phonebook
Once you have stored a number in Phonebook, you
can dial the number by selecting it from Phonebook.
p. 29
You can also use the speed dial feature to assign your
most frequently dialed numbers to specific number
keys.
p. 30
You can quickly dial a number from the SIM card using
its location number assigned when stored.
1. In Idle mode, enter a location number and press
[].
2. Scroll through other numbers, if necessary.
3. Press <
Dial
> or
[]
to dial the number you want.
• Press [
C
] to delete the last digit or press and
hold [
C
] to clear the whole display. You can
move the cursor to edit an incorrect digit.
• Press and hold [ ] to enter a pause between
numbers.
X656.book Page 25 Tuesday, May 2, 2006 11:18 AM
26
Call functions
Answering a call
When you receive an incoming call, the phone rings
and displays the incoming call image.
Press <
Accept
> or
[]
to answer the call.
Tips for answering a call
• When
Anykey
answer
is active, you can press
any key to answer a call, except for
[]
and
[/].
p. 66
• When
Active folder
is active, you can simply open
the phone.
p. 66
•Press
[]
to reject a call.
• Press and hold [ / ] to reject a call or mute the
ringer, depending on the
Side key
setting.
p. 67
Viewing missed calls
If you have missed calls, the screen displays how
many calls you have missed.
1. Press <
Missed
>.
2. If necessary, scroll through the missed calls.
3. Press
[]
to dial the number you want.
Using the headset
Use the headset to make or answer calls without
holding the phone.
Connect the headset to the jack on the left side of the
phone. The button on the headset works as follows:
Options during a call
You can access a number of functions during a call.
Adjusting the volume during a call
Use [ / ] to adjust the earpiece volume during a call.
To Press
redial the last call and hold the button twice.
answer a call and hold the button.
end a call and hold the button.
X656.book Page 26 Tuesday, May 2, 2006 11:18 AM
27
Call functions
Press [ ] to increase the volume level and [ ] to
decrease the volume level.
Making a second call
You can make another call if your network supports
this function.
1. Press <
Options
> and select
Hold
to put the call
on hold.
2. Make the second call in the normal way.
3. Press <
Options
> and select
Swap
to switch
between the calls.
4. Press <
Options
> and select
End
held
call
to end
the call on hold.
5. To end the current call, press
[]
.
Answering a second call
You can answer an incoming call while already on the
phone, if your network supports this function and you
have activated the call waiting feature.
p. 36
1. Press
[]
to answer the call. The first call is
automatically put on hold.
2. Press <
Options
> and select
Swap
to switch
between the calls.
3. Press <
Options
> and select
End
held
call
to end
the call on hold.
4. To end the current call, press
[]
.
Using In-call options
Press <
Options
> to access the following options
during a call:
•
Speaker on
/
Normal
: turn on the speakerphone
feature or switch back to Normal mode.
•
Voice clarity on
/
Voice clarity off
: remove
extraneous noise and increase call quality so that
the person with whom you are speaking can hear
you clearly event if you are in a noisy place.
•
Hold
/
Retrieve
: place the current call on hold, or
retrieve the call.
•
Swap
: switch between the current call and a call
on hold during a multi-party call.
X656.book Page 27 Tuesday, May 2, 2006 11:18 AM
28
Call functions
•
Join
: set up a multi-party call by adding a caller
on hold to a currently active call. You can include
up to 5 people on a multi-party call.
•
Split
: have a private conversation with one multi-
party call participant. The other participants can
converse with each other. After the private
conversation, select
Join
to return both private
participant to the multi-party call.
•
Mute
/
Unmute
: switch off the phone's microphone
so that the other person on the phone cannot hear
you, or switch it back on.
•
Mute keys
/
Send keys
: switch the key tones off
or on.
•
Phonebook
: access the contact list.
•
Send DTMF
: send the DTMF (Dual tone multi-
frequency) tones as a group. The DTMF tones are
the tones used in phones for tone dialing, sounding
when you press the number keys. This option is
helpful for entering a password or an account
number when you call an automated system, like a
banking service.
•
Message
: access SMS messages in the Inbox or
Outbox. You can also create and send a new SMS
message.
•
Conv. record
: record your conversation.
•
Transfer
: transfer the currently active call to a
caller on hold. The two callers can talk to each
other, but you are disconnected from the call.
•
End held call
: disconnect the call currently on
hold.
•
Remove
: remove one multi-party call participant.
•
SIM AT
: access additional services provided by
your SIM card, such as news, weather forecast,
sports, entertainment, and location services. This
option is available if you use a SIM card supporting
SIM Application Toolkit menus.
• To communicate with answering machines or
computerized telephone systems,
Send keys
must be selected.
• When you switch the key tones off, DTMF
tones are also switched off.
X656.book Page 28 Tuesday, May 2, 2006 11:18 AM
29
Menu functions
All menu options listed
Phonebook
You can store phone numbers on your SIM card and in
your phone’s memory. The SIM card and phone’s
memory are physically separate, but they are used as
a single entity called Phonebook.
To access this menu, press <
Phonebook
> in Idle
mode.
Find name
Use this menu to search for numbers in Phonebook.
Finding a contact
1. Enter the first few letters of the name that you
want to find.
2. Select the name from the list.
3. Scroll to a number and press [ ] to dial.
Using Phonebook options
While viewing contact details, press <
Options
> to
access the following options:
•
Edit number
: edit contact information.
•
Change name
: change the contact name.
•
Send message
: send an SMS message to the
selected number.
•
Copy
: copy the selected number to the phone’s
memory or SIM card.
•
Send via infrared
: send the contact via the
infrared port.
•
Delete entry
: delete the contact.
Add entry
Use this menu to add a new contact to Phonebook.
Storing a contact in the phone’s memory
1. Enter a phone number and press <
Save
>.
2. Select
Phone
→
a number type.
3. Enter a name and press <
OK
>.
X656.book Page 29 Tuesday, May 2, 2006 11:18 AM
30
Menu functions
4. To save additional information, press [Left] or
[Right] to scroll to the field you want.
5. Enter information or change settings.
•
Mobile
/
Home
/
Office
/
Fax
/
Other
: press
<
Options
> and select
Edit number
and add a
number in any category.
•
E-Mail
: press <
Edit
> and assign an e-mail
address.
•
Note
: press <
Edit
> and add a memo about
the person.
•
Group
: press <
Options
> and assign the
contact to a caller group.
•
Graphic
: press <
Options
> and assign an
image as a caller ID image to alert you to a call
from the person.
•
Alert
: press <
Options
> and assign a ringtone
to alert you to a call from the person.
6. Press <
OK
> or <
Select
>.
Storing a contact on the SIM card
1. Enter a phone number and press <
Save
>.
2. Select
SIM
.
3. Enter a name and press <
OK
>.
4. If necessary, change a location number.
5. Press <
OK
> to save the contact.
Speed-dial list
Use this menu to assign speed dial numbers (2 to 8)
*
for seven of your most frequently dialed numbers.
Assigning speed dial entries
1. Select a key location from
2
to
8
. Key
1
is reserved
for your voicemail server and key
9
for emergency
call number. (It may vary, depending on your
country or service provider.)
2. Select
Edit number
3. Enter a phone number or press <
Phonebook
> to
select one from Phonebook.
* The amount of memory available for speed dialing depends on the
carrier’s requirements.
X656.book Page 30 Tuesday, May 2, 2006 11:18 AM
31
Menu functions
Phonebook
4. Press <
OK
>.
Managing speed dial entries
From the Speed dial screen, press <
Select
> to access
the following options:
•
Edit number
: enter a number or assign a different
number to a key.
•
Change name
: change the contact name.
•
Delete
: clear the speed dial setting for a key.
Dialing speed dial numbers
In Idle mode, press and hold the appropriate key.
Copy all to phone
Use this menu to copy all of the contacts stored on the
SIM card to the phone’s memory.
Delete all
Use this menu to delete all contacts stored on the SIM
card or in the phone’s memory.
1. Press <
Select
> to select the memory locations to
be cleared.
2. Press <
OK
>.
3. Press <
Yes
> to confirm the deletion.
4. Enter the phone password and press <
OK
>.
Own number
Use this feature to check your phone numbers or to
assign a name to each of the numbers. Changes made
here do not affect the actual subscriber numbers on
your SIM card.
Group setting
Use this menu to change the properties of caller
groups.
From each caller group, the following options are
available:
•
Melody
: select a ringtone to alert you when a call
comes in from a member of the group.
•
Change name
: change the group name.
The password is preset to
00000000
. You can
change this password.
p. 65
X656.book Page 31 Tuesday, May 2, 2006 11:18 AM
32
Menu functions
•
View image
: check the group ID image to alert
you to a call from a member of the group.
Memory status
Use this menu to check the number of contacts you
have stored in the phone’s memory and on the SIM
card.
Service directory
Use this menu to view the list of Service Dialing
Numbers (SDN) assigned by your service provider,
including emergency numbers and numbers for
directory enquiries. This menu is available if your SIM
card supports SDN.
Scroll to the number you want and press <
Dial
> or
[]
.
SIM-AT MENU
(Menu 1)
This menu is available if you use a SIM-AT card that
provides additional services, such as news, weather,
sports, entertainment, and location services. Available
services may vary, depending on your service
provider’s plans.
For details, see your SIM card instructions or contact
your service provider.
To access this menu, press <
Menu
> in Idle mode and
select
SIM-AT MENU
,
or press [Down].
X656.book Page 32 Tuesday, May 2, 2006 11:18 AM
33
Menu functions
Call records
(Menu 2)
Call records
(Menu 2)
Use this menu to view the calls you have dialled,
received, or missed, and the length of the calls. You
can also check the cost of your calls, if your SIM card
supports this function.
To access this menu, press <
Menu
> in Idle mode and
select
Call records
.
Missed calls
(Menu 2.1)
This menu displays the most recent calls that you did
not answer.
Accessing a call record
1. Press [Up] or [Down] to scroll through the call list.
2. Press [ ] to view the details of a call, press
[]
to dial a number.
Using call record options
While viewing call details, press <
Options
> to access
the following options:
•
Call back
: dial the selected number.
•
Send message
: send an SMS or MMS message to
the selected number.
•
Edit
: edit the number.
•
Delete
: delete the selected number.
•
Delete all
: delete all call records.
Received calls
(Menu 2.2)
This menu displays the most recent calls you have
received.
Dialled calls
(Menu 2.3)
This menu displays the most recent calls you have
dialled.
Delete all
(Menu 2.4)
Use this menu to delete all of the records in each call
type.
1. Press <
Select
> to select the call types to be
cleared.
2. Press <
OK
>.
3. Press <
Yes
> to confirm the deletion.
X656.book Page 33 Tuesday, May 2, 2006 11:18 AM
34
Menu functions
Call time
(Menu 2.5)
This menu displays the time log for calls made and
received. The actual time invoiced by your service
provider will vary.
•
Last
call
time
: check the length of your last call.
•
Total
sent
: check the total length of all the calls
you have dialled.
•
Total
received
: check the total length of all the
calls you have received.
•
Reset
timers
: reset the call timers. You need to
enter the phone password.
Call costs
(Menu 2.6)
This network feature displays the cost of calls. This
menu is available only if supported by your SIM card.
Note that this is not intended to be used for billing
purposes.
•
Last
call
cost
: check the cost of your last call.
•
Total
cost
: check the total cost of all of your calls.
If the total cost exceeds the maximum cost set in
Set
max
cost
, you must reset the counter before
you can make another call.
•
Max
cost
: check the maximum cost limit set in
Set
max
cost
.
•
Reset
counters
: reset the cost counters.
•
Set
max
cost
: set the maximum cost authorized
for your calls.
•
Price/Unit
: set the price per unit that is applied
when the cost of your calls is calculated.
Network services
(Menu 3)
Use this menu to access network services. Please
contact your service provider to check their availability
and subscribe to them, if you wish.
To access this menu, press <
Menu
> in Idle mode and
select
Network services
.
The password is preset to
00000000
. You can
change this password.
p. 65
X656.book Page 34 Tuesday, May 2, 2006 11:18 AM
35
Menu functions
Network services
(Menu 3)
Call diverting
(Menu 3.1)
This network service reroutes incoming calls to a
phone number that you specify.
1. Select a call diverting option:
•
Divert always
: divert all calls.
•
Busy
: divert calls when you are on another
call.
•
No
reply
: divert calls when you do not answer
the phone.
•
Unreachable
: divert calls when you are not in
an area covered by your service provider or
when your phone is switched off.
•
Cancel
all
: cancel all call diverting options.
2. Select the type of calls to be diverted.
3. Press <
Activate
>. To deactivate call diverting,
press <
Remove
>.
4. Enter the number to which calls are to be diverted
and press <
OK
>.
5. If you selected
No reply
, select the length of time
the network delays before diverting a call and
press <
Select
>.
Call barring
(Menu 3.2)
This network service allows you to restrict your calls.
1. Select a call barring option:
•
All
outgoing
: prohibit all outgoing calls.
•
International
: prohibit international calls.
•
International
except
to
home
: only allow
calls to numbers within the current country
when you are abroad, and to your home
country.
•
All
incoming
: prohibit incoming calls.
•
Incoming
while
abroad
: prohibit incoming
calls when you use your phone outside of your
home service area.
•
Cancel
all
: cancel all call barring settings,
allowing to be sent and received normally.
•
Change barring password
: change the call
barring password obtained from your service
provider.
2. Select the type of calls to be barred.
3. Press <
Activate
>. To deactivate call barring,
press <
Deactivate
>.
X656.book Page 35 Tuesday, May 2, 2006 11:18 AM
36
Menu functions
4. Enter the call barring password supplied by your
service provider and press <
OK
>.
Call waiting
(Menu 3.3)
This network service informs you when someone is
trying to reach you while you are on another call.
1. Select the type of calls to which the call waiting
option will apply.
2. Press <
Activate
>. To deactivate call waiting,
press <
Deactivate
>.
Network selection
(Menu 3.4)
This network service allows you to manually select the
network to be used while roaming outside of your
home area, or to let the network be chosen
automatically.
You can select a network other than your home
network only if there is a valid roaming agreement
between the two.
Caller ID
(Menu 3.5)
This network service allows you to prevent your phone
number from being displayed on the phone of the
person being called. If you select
Default
, the phone
will use the default setting provided by the network.
Band selection
(Menu 3.6)
For the phone to make and receive phone calls, it
must register with an available network. Your phone
can handle any of the following types of networks:
GSM 1800, Combined GSM 850/1900, and Triple band
(GSM 850/1800/1900).
The country where you purchased your phone
determines the default band that it uses. When you
travel abroad, you may need to change to an
appropriate band.
Some networks may not allow you to change this
setting.
X656.book Page 36 Tuesday, May 2, 2006 11:18 AM
37
Menu functions
Sound settings
(Menu 4)
Active line
(Menu 3.7)
Some SIM cards may be used with two subscriber
numbers. If your SIM card supports this function, use
this menu to select the line that is used to make calls.
Calls can be answered on both lines, regardless of the
selected line.
Sound settings
(Menu 4)
Use this menu to customize various sound settings,
such as the call ringer, message ringer, and alert
sounds to be used in various situations.
To access this menu, press <
Menu
> in Idle mode and
select
Sound settings
.
Incoming calls
(Menu 4.1)
Use this menu to change the sound settings for
incoming calls.
•
Default melodies
: select one of the default
melodies to be used as your ringtone.
•
My sounds
: select a downloaded melody to be
used as your ringtone.
•
Ring volume
: select a ringtone volume.
•
Alert type
: specify how you are to be informed of
incoming calls.
Messages
(Menu 4.2)
Use this menu to change the sound settings for
incoming SMS messages or MMS messages.
•
Tone
: select one of the several message tones.
•
Alert type
: specify how you are to be informed of
any incoming messages.
•
Repetition
: specify how often the phone informs
you of a new message.
Power on/off
(Menu 4.3)
Use this menu to turn on or off the melody that the
phone sounds when it is switched on or off.
X656.book Page 37 Tuesday, May 2, 2006 11:18 AM
38
Menu functions
Connection tone
(Menu 4.4)
Use this menu to set the phone to beep when an
outgoing call is connected to the system.
Key tone
(Menu 4.5)
Use this menu to select the tone that the phone
sounds when you press a key.
Minute
minder
(Menu 4.6)
Use this menu to set the phone to beep every minute
during a call to keep you informed of the length of
your call.
Quiet mode
(Menu 4.7)
Use this menu to set how the phone acts to alert you
to a specific event while in Quiet mode.
Alerts on call
(Menu 4.8)
Use this menu to set the phone to beep when you
receive a new message or when the time for an alarm
comes during a call.
Messages
(Menu 5)
Use the
Messages
menu to send and receive text
messages or multimedia messages. You can also use
push message, voicemail, and broadcast message
features.
To access this menu, press <
Menu
> in Idle mode and
select
Messages
.
Short messages
(Menu 5.1)
Short Message Service (SMS) allows you to send or
receive text messages including pictures, audio clips,
and animated images.
You can adjust the keypad tone volume using
[/] in Idle mode.
X656.book Page 38 Tuesday, May 2, 2006 11:18 AM
39
Menu functions
Messages
(Menu 5)
Create
(Menu 5.1.1)
Use this menu to create and send an SMS message.
1. Enter your message.
2. Press <
Options
> to access the following options:
•
Send
: send the message.
•
Text
: change the text attributes.
•
Add media
/
Add emoticon
: add a picture,
animated image, a melody, or emoticon into
text.
•
Preset messages
: insert a text template into
text.
•
Save message
: save the message in the
Outbox.
3. When you have finished, press <
Options
> and
select
Send
.
4. Enter a destination number or press
<
Phonebook
> to select one from your
Phonebook, and press <
OK
>.
To send the message to more than one recipient,
fill in additional destination fields.
5. Press <
Send
> to send the message.
Inbox
(Menu 5.1.2)
Use this menu to access SMS messages you have
received.
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Message reply
: reply to the sender.
•
Call back
: dial the sender’s phone number.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Send
: forward the message to other people.
•
Edit
: edit the message.
•
Extract media
: save media items from the
message to your phone’s memory.
The maximum number of characters allowed in a
message varies by service provider. If your
message exceeds the maximum number of
characters, the phone will split the message.
X656.book Page 39 Tuesday, May 2, 2006 11:18 AM
40
Menu functions
•
Transfer
: move the message between the SIM
card and the phone’s memory.
Outbox
(Menu 5.1.3)
Use this menu to access SMS messages you have sent
or saved to send at a later time.
While viewing a message, press <
Options
> to access
the following options:
•
Delete
: delete the message.
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Send
: send or resend the message.
•
Edit
: edit the message.
•
Transfer
: move the message between the SIM
card and the phone’s memory.
Emoticon templates
(Menu 5.1.4)
Your phone provides preset emoticons so that you can
retrieve and insert them when composing an SMS
message. Use this menu to create or edit emoticons.
Creating an emoticon
1. Select
My emoticons
.
2. Scroll to an empty location and press <
Options
>
and select
Add
.
3. Enter an emoticon and press <
OK
>.
Using emoticon options
From the My emoticons screen, press <
Options
> to
access the following options:
•
Edit
: edit the emoticon.
•
Send
: create and send an SMS message using the
emoticon.
•
Delete
: delete the emoticon.
Delete all
(Menu 5.1.5)
Use this menu to delete all of your messages in each
message box.
1. Press <
Select
> to select the message boxes to be
cleared.
2. Press <
OK
>.
3. Press <
Yes
> to confirm the deletion.
X656.book Page 40 Tuesday, May 2, 2006 11:18 AM
41
Menu functions
Messages
(Menu 5)
Multimedia messages
(Menu 5.2)
Multimedia Message Service (MMS) delivers messages
containing a combination of text, image, and sound
from phone to phone or from phone to e-mail.
Create
(Menu 5.2.1)
Use this menu to create and send an MMS message.
1. Select the
Subject
line.
2. Enter the message subject and press <
OK
>.
3. Select the
or
Sound
line and add an
image or sound file.
4. Select the
Message
line and enter the message
text.
5. Press <
Opt.
> and select
Done
.
6. Press <
Opt.
> to access the following options:
•
Preview
: view the message as it will be shown
on the recipient’s phone.
•
Send
: send the message.
•
Add page
: add pages. Move to each page by
pressing [Left] or [Right] on the message
screen.
•
Page timing
: change the duration of page
display. After the specified time, the display
automatically scrolls to the next page.
•
Text effect
: change the text attributes.
•
Clear subject
/
Clear picture
/
Clear sound
/
Clear message
: remove an added item.
•
Delete page
: delete an added page.
•
Save message
: save the message in the
Draft
or
My folder
box.
7. When you have finished, press <
Opt.
> and select
Send
.
8. Select an empty destination field.
You can quickly access this menu by press [Up] in
Idle mode.
• The maximum size allowed for a message can
differ, depending on your service provider.
• Depending on the file type or DRM (Digital
Rights Management) system, some files may
not be able to be forwarded.
X656.book Page 41 Tuesday, May 2, 2006 11:18 AM
42
Menu functions
9. Select
Number
or
E-mail
to enter a phone
number or e-mail address. Otherwise, select
Phonebook
to select one from your Phonebook.
To send the message to more than one recipient,
fill in additional destination fields.
10. Press <
Send
> to send the message.
Inbox
(Menu 5.2.2)
Use this menu to access MMS messages that you have
received.
The following icons may appear on the message list to
show the message status:
• MMS notification
• MMS message
While viewing a message, press <
Opt.
> to access the
following options:
•
Delete
: delete the message.
•
Replay
: replay the message.
•
Reply
: reply to the sender.
•
Reply all
: send a reply to the sender and all of the
other recipients.
•
Forward
: forward the message to other people.
•
Call back
: dial the sender’s phone number.
•
Cut media
: save media items from the message
to your phone’s memory.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Properties
: access the message properties.
•
Move to My folder
: move the message to the
My
folder
box.
Outbox
(Menu 5.2.3)
Use this menu to access MMS messages that the
phone has sent or has failed to send.
The following icons are available to show the message
status:
• currently being sent
• sent
• retry sending
Depending on the DRM (Digital Rights Management)
system, messages having web content may not be
able to be forwarded.
X656.book Page 42 Tuesday, May 2, 2006 11:18 AM
43
Menu functions
Messages
(Menu 5)
• sending failed
• opened by the recipient
While viewing a message, press <
Opt.
> to access the
following options:
•
Delete
: delete the message.
•
Replay
: replay the message.
•
Send
: send or resend the message.
•
Properties
: access the message properties.
•
Move to My folder
: move the message to the
My folder
box.
Draft
(Menu 5.2.4)
Use this menu to access MMS messages you have
saved to send at a later time.
While viewing a message, press <
Opt.
> to access the
following options:
•
Send
: send the message.
•
Replay
: replay the message.
•
Delete
: delete the message.
•
Properties
: access the message properties.
My folder
(Menu 5.2.5)
Use this menu to access the messages you have saved
using the
Move to My folder
option while reading a
message.
Delete all
(Menu 5.2.6)
Use this menu to delete all of the messages in each
message box.
1. Press <
Select
> to check the message boxes to be
cleared.
2. Press <
OK
>.
3. Press <
Yes
> to confirm the deletion.
Push messages
(Menu 5.3)
Use this menu to access messages received from the
web server.
•
Inbox
: access push messages you have received.
•
Settings
: determine whether or not your phone
receives push messages.
Always
: the phone receives push messages.
Never
: the phone rejects push messages.
X656.book Page 43 Tuesday, May 2, 2006 11:18 AM
44
Menu functions
Optional
: the phone receives push messages from
the specified web server.
•
Delete all
: delete all of the push messages.
Preset messages
(Menu 5.4)
Use this menu to access text templates of frequently
used messages so that you can retrieve and insert
them when composing a message. You can also edit
the text templates.
Voice mail
(Menu 5.5)
Use this menu to set the number of the voicemail
server and access your voicemails.
•
Connect to voice mail
: connect to the voicemail
server to allow you to listen to your messages.
•
Voice server number
: change or delete the
voicemail server name and number.
Broadcast
(Menu 5.6)
The Cell Broadcast (CB) service delivers SMS
messages on various topics, such as the weather or
traffic.
Use this menu to change the settings for the service
and to access broadcast messages.
•
Read
: access broadcast messages you have
received.
The
Temporary
box saves network messages until
the phone is switched off. Press <
Options
> and
select
Save
when a text notification appears to
save to the
Archive
box.
The
Archive
box saves network messages
indefinitely.
•
Receive
: select to receive broadcast messages, or
not.
•
Channel
: indicate the channels from which you
wish to receive broadcast messages. Please
contact your service provider for further details.
•
Language
: select the preferred languages in
which broadcast messages display.
You must enter the voicemail server number before
you can access your voicemails. Your service
provider can give the voicemail server number.
X656.book Page 44 Tuesday, May 2, 2006 11:18 AM
45
Menu functions
Messages
(Menu 5)
Settings
(Menu 5.7)
Use this menu to set up various options for using
messaging services.
Short messages
(Menu 5.7.1)
You can configure SMS settings.
•
Service centre
: store or change the number of
your SMS server.
•
Validity period
: set the length of time your
messages are stored in the SMS server.
•
Message type
: set the default message type. The
network can convert the messages into the
selected format.
•
Reply path
: allow recipients to reply to you
through your SMS server.
•
Delivery report
: set the network to inform you
when your messages have been delivered.
•
Character support
: select a character encoding
type. When you select
Automatic
, the phone
switches the encoding type from GSM-alphabet to
Uni-code if you enter a Unicode character. Use of
Unicode encoding will reduce the maximum
number of characters in a message to about half. If
this menu is not shown, your phone provides
automatic character encoding by default.
Multimedia messages
(Menu 5.7.2)
You can configure MMS settings.
•
Send settings
: set up the options for sending
MMS messages:
Priority
: set the priority level of messages.
Validity period
: set the length of time messages
are stored in the MMS server.
Delivery after
: set a time delay before messages
are sent.
Address hiding
: set your address to be hidden
from the recipient’s phone.
X656.book Page 45 Tuesday, May 2, 2006 11:18 AM
46
Menu functions
Delivery report
: set the network to inform you
when your messages have been delivered.
Read reply
: send a read-reply request along with
your messages.
•
Receive settings
: set up the options for receiving
MMS messages.
Msg. reception
: set how you receive a message.
-
Manual
: the phone downloads new messages
from the MMS server by using the
Retrieve
option.
-
Automatic
: the phone automatically downloads
new messages from the MMS server.
-
Reject
: the phone rejects new messages.
Anonymous reject
: reject messages from
unknown senders.
Adverts reject
: reject advertisements.
Report allowed
: set the network to inform the
sender when a message has been delivered to you.
•
MMS profiles
: configure required network
settings for MMS.
Current profile
: select a profile.
Profile setting
: customize the options for each
profile:
-
Profile name
: assign a name to the MMS profile.
-
Server URL
: enter the address of your MMS
server.
-
Proxy use
: activate or deactivate the proxy
server.
-
GPRS setting
: customize the settings required
for connecting to the GPRS network.
When
Proxy use
is set to
Enable
:
IP address
: enter the gateway address.
IP port
: enter the port number.
APN
: enter the access point name of the GPRS
network gateway.
Check with your service provider before you
change any MMS settings on your phone.
X656.book Page 46 Tuesday, May 2, 2006 11:18 AM
47
Menu functions
Fun box
(Menu 6)
Login ID
: enter the user ID.
Password
: enter the password.
When
Proxy use
is set to
Disable
:
DNS1
: enter the primary DNS address.
DNS2
: enter the secondary DNS address.
APN
: enter the access point name of the GPRS
network gateway.
Login ID
: enter the user ID.
Password
: enter the password.
Memory status
(Menu 5.8)
Use this menu to access memory information for SMS
and MMS messages.
Fun box
(Menu 6)
The
Fun box
menu allows you to use the web
browser, play Java games, access images and sounds
stored in the phone’s memory, and listen to the FM
radio.
To access this menu, press <
Menu
> in Idle mode and
select
Fun box
.
WWW services
(Menu 6.1)
The Wireless Application Protocol (WAP) browser on
your phone allows you to access the wireless web.
From the wireless web, you can access up-to-date
information and a wide variety of media content, such
as games, wallpapers, and ringtones.
Home
(Menu 6.1.1)
Use this menu to connect your phone to the network
and load the homepage of the wireless web service
provider. You can also press [ ] in Idle mode.
X656.book Page 47 Tuesday, May 2, 2006 11:18 AM
48
Menu functions
Navigating the web browser
Using browser options
From any web, press [ ] or select on the top of the
screen to access the following options:
•
Back
: return to the previous page.
•
Home
: return to the homepage.
•
Exit
: exit the web browser.
•
Reload
: reload the current page with updated
information.
•
Show URL
: display the URL address of the current
web page. You can also set the current page as the
homepage for the web browser.
•
About...
: view version information for the web
browser.
Accessing other phone menus
From any web page, press [ ] to access the following
options:
•
Goto URL
: enter a URL address manually.
•
Bookmark
: switch to the
Bookmark
menu.
•
Messages
: access SMS messages in the Inbox or
Outbox. You can also create and send a new SMS
message.
•
Media box
: switch to the
Media box
menu.
Exiting the web browser
Press
[]
to end the network connection and exit the
browser.
Bookmark
(Menu 6.1.2)
Use this menu to save URL addresses in order to
quickly access web pages.
Adding a bookmark
1. Select an empty location.
2. Enter a URL address and press <
OK
>.
3. Enter a title for the bookmark and press <
OK
>.
To Press
scroll through browser items [Up] or [Down].
select a browser item < >.
return to the previous page <
Back
> or [
C
].
X656.book Page 48 Tuesday, May 2, 2006 11:18 AM
49
Menu functions
Fun box
(Menu 6)
Using bookmark options
After saving an item, press <
Select
> to access the
following options:
•
Go
: access the bookmarked web page.
•
Edit
: edit the URL address and title of the
bookmark.
•
Delete
: delete the bookmark.
Go to URL
(Menu 6.1.3)
Use this menu to manually enter a URL address and
access the associated web page.
Clear cache
(Menu 6.1.4)
Use this menu to clear the cache. A cache is a
temporary memory that stores recently accessed web
pages.
Proxy settings
(Menu 6.1.5)
Use this menu to set up connection profiles to be used
for the web browser.
For each server, set the following parameters:
•
Profile
name
: enter a profile name.
•
Home
URL
: enter the URL address of the page to
be used as your homepage.
•
Bearer
: select the network bearer type.
•
Proxy use
: activate or deactivate the proxy
server.
•
GPRS setting
: customize the following GPRS
network settings:
When
Proxy use
is set to
Enable
:
IP address
: enter the IP address of the proxy
server.
IP port
: enter the port number.
APN
: enter the access point name of the GPRS
network gateway.
Login ID
: enter the user ID.
Password
: enter the password.
When
Proxy use
is set to
Disable
:
DNS1
: enter the primary DNS address.
Check with your service provider before you change
any browser settings on your phone.
X656.book Page 49 Tuesday, May 2, 2006 11:18 AM
50
Menu functions
DNS2
: enter the secondary DNS address.
APN
: enter the access point name of the GPRS
network gateway.
Login ID
: enter the user ID.
Password
: enter the password.
•
GSM setting
: customize the following GSM
network settings:
When
Proxy use
is set to
Enable
:
IP address
: enter the IP address of the proxy
server.
IP port
: enter the port number.
Dial number
: enter the PPP phone number.
Login ID
: enter the user ID.
Password
: enter the password.
Data call type
: select a call type for data
transmission.
When
Proxy use
is set to
Disable
:
DNS1
: enter the primary DNS address.
DNS2
: enter the secondary DNS address.
Dial number
: enter the PPP phone number.
Login ID
: enter the user ID.
Password
: enter the password.
Data call type
: select a call type for data
transmission.
Current proxy
(Menu 6.1.6)
Use this menu to activate one of the proxy servers you
have set up.
Media box
(Menu 6.2)
Use this menu to access images, voice memos, and
sound clips stored in your phone’s memory.
Photos
(Menu 6.2.1)
Use this menu to access photos you have taken.
While reviewing a file, press <
Options
> to access the
following options:
•
Send
: send the file via MMS.
•
Send via infrared
: send the file via the infrared
port.
•
Rename
: change the file name.
•
Delete
: delete the file.
X656.book Page 50 Tuesday, May 2, 2006 11:18 AM
51
Menu functions
Fun box
(Menu 6)
•
Move to album
: move the file to one of the
My
albums
folder.
•
Set as
: set the image as wallpaper for the idle
screen or as a caller ID image for a Phonebook
entry.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Downloaded images
(Menu 6.2.2)
Use this menu to access images you have downloaded
from the wireless web or received in messages.
While reviewing a file, press <
Options
> to access the
following options:
•
Send
: send the file via MMS.
•
Send via infrared
: send the file via the infrared
port.
•
Rename
: change the file name.
•
Delete
: delete the file.
•
Set as wallpaper
: set the image as wallpaper for
the idle screen.
•
Properties
: access the file properties.
Sounds
(Menu 6.2.3)
Use this menu to access the embedded sounds, voice
memos you have recorded, or sound clips you have
downloaded from the wireless web or received in
messages.
While reviewing a file, press <
Options
> to access the
following options:
•
Send
: send the file via MMS.
•
Send via infrared
: send the file via the infrared
port.
•
Rename
: change the file name.
•
Delete
: delete the file.
•
Set as ringtone
: set the sound clip as your
ringtone.
•
Properties
: access the file properties.
Delete all
(Menu 6.2.4)
Use this menu to delete all media items in each media
box.
X656.book Page 51 Tuesday, May 2, 2006 11:18 AM
52
Menu functions
Memory status
(Menu 6.2.5)
Use this menu to check the total amount of memory
for media items and the amount of memory currently
in use in each media box.
JAVA world
(Menu 6.3)
Use this menu to access and play Java games and to
change the network setting required for accessing the
Java server.
Downloads
(Menu 6.3.1)
Use this menu to access the embedded Java games or
downloaded Java applications.
Accessing an embedded game
Select a game from the game list and follow the
onscreen instructions. The procedure may differ from
game to game.
Using Java application options
From the application list, press <
Options
> to access
the following options:
•
Launch
: launch the selected application.
•
Delete
: delete the selected application.
•
Properties
: access the application properties.
Internet settings
(Menu 6.3.2)
Use this menu to set up the network settings required
for accessing the Java server.
•
APN
: enter the access point name.
•
Login ID
: enter the user ID.
•
Password
: enter the password.
•
DNS settings
: enter a DNS address.
Memory status
(Menu 6.3.3)
Use this menu to check the amount of memory
currently being used and memory available for Java
applications.
You can quickly access this menu by pressing [Right]
in Idle mode.
X656.book Page 52 Tuesday, May 2, 2006 11:18 AM
53
Menu functions
Fun box
(Menu 6)
FM radio
(Menu 6.4)
Use this menu to listen to music or news via the FM
radio on your phone.
Turning on and listening to the radio
First, you must connect your phone with the headset,
which serves as a radio antenna.
1. Plug the connector of the supplied headset into the
jack on the left side of the phone.
2. From the FM Radio screen, press <
Options
> and
select
Power on
.
3. Press [Left] or [Right] to find the radio station you
want.
You can also press and hold [Left] or [Right] to
scan through available radio stations.
Setting up a radio station list
You can store your favorite radio stations to quickly
access them without searching through noisy
frequencies.
1. Plug the connector of the supplied headset into the
jack on the left side of the phone.
2. From the FM Radio screen, press <
Options
> and
select
Power on
.
3. Scroll to an empty location.
4. Press [Left] or [Right] to find the radio station you
want.
You can also press and hold [Left] or [Right] to
scan through available radio stations.
5. Press <
Options
> and select
Add
.
You can quickly access this menu by pressing [Left]
in Idle mode.
• Press [ / ] to adjust the volume.
• You can answer an incoming call or use other
phone functions while listening to the radio.
• The quality of the radio broadcast depends on
the radio station’s coverage in that particular
area.
X656.book Page 53 Tuesday, May 2, 2006 11:18 AM
54
Menu functions
6. Enter the title for the station and press <
OK
>.
7. Press <
OK
> when the frequency for the selected
radio station displays.
To listen to the stored stations, press [Up] or [Down]
from the FM Radio screen.
Turning off the radio
To turn off the radio, press <
Options
> from the radio
screen and select
Power off
or disconnect the
headset.
Using radio options
On the FM radio screen, press <
Options
> to access
the following options:
•
Power on
/
Power off
: turn the radio on or off.
•
Add
: add a radio station.
•
Edit
: edit the title or frequency for a saved radio
station.
•
Self tuning
: let the phone automatically scan
through and save available radio frequencies.
•
Remove
: remove the selected station or all
stations.
•
Speaker on
/
Earphone on
: change the audio
mode to the phone’s speaker or headset.
•
Volume
: select the radio volume.
Organiser
(Menu 7)
The Organizer feature enables you to keep track of
your schedule, make a list of tasks, or set alarms. You
can also use the phone as a voice recorder, world
clock, calculator, converter, and stopwatch.
To access this menu, press <
Menu
> in Idle mode and
select
Organiser
.
New memo
(Menu 7.1)
Use this menu to create a new item.
You can quickly access this menu by pressing and
holding [
C
] in Idle mode.
X656.book Page 54 Tuesday, May 2, 2006 11:18 AM
55
Menu functions
Organiser
(Menu 7)
1. Enter the content and press <
OK
>.
2. Select a memo type.
3. Select a date on the calendar.
4. For
Call
, enter a phone number you need to dial
and press <
OK
>.
For
Anniversary
, skip to step 6.
5. Enter the time for the memo and press <
OK
>.
6. Press <
Yes
> to set an alarm.
7. Enter the time for the alarm to sound and press
<
OK
>.
8. Select an alarm tone.
Calendar
(Menu 7.2)
Use this menu to keep track of your monthly schedule.
Consulting the calendar
When you access this menu, the calendar in Month
view appears with today’s date indicated by a blue
box.
Selecting a day
• Press [Left] or [Right] to move by day.
• Press [Up] or [Down] to move by week.
• Press and hold [Up] or [Down] to move by month.
• Press and hold [Left] or [Right] to move by year.
Using calendar options
From the calendar, press <
Options
> to access the
following options:
•
Add memo
: add a new item.
p. 54
•
Go to date
: enter the date you want to access.
•
View all
: view all items stored on the calendar.
Press [Left] or [Right] to scroll through the items.
•
Delete day
: delete the items stored for the
currently selected date.
•
Delete all
: delete all items on the calendar.
X656.book Page 55 Tuesday, May 2, 2006 11:18 AM
56
Menu functions
Viewing an item
Once you have scheduled items, the following icons
and the number of items for a specific day appear at
the bottom of the calendar.
Using options
While viewing an item, press <
Options
> to access
the following options:
•
Add
: add a new item.
•
Delete
: delete the item.
•
Edit
: edit the item.
•
Move
: move the item to a different date.
•
Copy
: copy the item to a different date.
To do list
(Menu 7.3)
Use this menu to access tasks (To to items) you have
created on the calendar.
The following icons on the list indicate the task status:
•Uncompleted task
•Completed task
While viewing a task, press <
Options
> to access the
following options:
•
Add
: add a new task.
•
Mark
: change the task status.
•
Edit
: edit the task.
•
Move
: move the task to a different date.
•
Copy
: copy the task to a different date.
•
Delete
: delete the task.
•
Delete all
: delete all tasks.
Clock
(Menu 7.4)
Use this menu to change the time and date displayed
on your phone. Before setting the time and date,
specify your time zone in
Set world time
.
•
Set time
: enter the current time.
•
Set date
: enter the current date.
• Schedule items • Tasks (To do items)
• Calls • Anniversaries
X656.book Page 56 Tuesday, May 2, 2006 11:18 AM
57
Menu functions
Organiser
(Menu 7)
•
Set world time
: set your local time zone and find
out what time it is in another part of the world.
•
Set format
: select time and date format.
•
Auto Update
: select to receive time information
from your network.
Alarm
(Menu 7.5)
Use this menu to set alarms. The alert type for a
normal alarm corresponds to the call alert type
settings. A wake-up alarm is not affected by your
sound profiles.
Setting an alarm
1. Select the type of alarm.
2. Press <
Options
> and select
Alarm day
.
3. Press <
Select
> to select the days on which the
alarm sounds and press <
OK
>.
4. Enter the time for the alarm to sound and press
<
OK
>.
5. Select
Alarm tone
and select an alarm tone.
Stopping an alarm
• For a non-wake-up alarm, press <
Confirm
>.
• For a wake-up alarm, press <
Confirm
>.
Press <
Snooze
> to cause it to sound again after 5
minutes. You can do this a maximum of 4 times.
Deactivating an alarm
1. Select the alarm you want to deactivate.
2. Press <
Options
> and select
Remove alarm
.
3. Press <
Yes
>.
Setting the alarm to sound even if the phone
is off
From the Alarm screen, select
Auto power
→
On
.
If the phone is off when it is time for the alarm to
sound, the phone switches on and sounds the alarm.
To apply daylight saving time to time zones,
press <
Set
> and select
Set DST
.
X656.book Page 57 Tuesday, May 2, 2006 11:18 AM
58
Menu functions
Voice recorder
(Menu 7.6)
Use this menu to record voice memos and review
them. A voice memo can be up to one hour long.
Record
(Menu 7.6.1)
Use this menu to record a voice memo.
1. Select to start recording.
2. Speak into the microphone.
• Select to pause the recording.
• Select to resume the recording.
3. When you have finished, select . The voice
memo is automatically saved.
4. Select to review the voice memo.
Voices
(Menu 7.6.2)
Use this menu to access the list of voice memos you
have recorded.
Playing a voice memo
From the list, select a voice memo.
During playback:
• Use the following buttons on the display:
• Press [ / ] to adjust the volume.
Delete all
(Menu 7.6.3)
Use this menu to delete all voice memos in the
phone’s memory.
Settings
(Menu 7.6.4)
Use this menu to configure settings for recording a
voice memos.
•
Recording time
: select a voice recording mode.
Buttons Function
Pauses playback.
Resumes playback.
Moves backward.
Moves forward.
Stops playback.
X656.book Page 58 Tuesday, May 2, 2006 11:18 AM
59
Menu functions
Organiser
(Menu 7)
Normal
: record a voice memo within the limit of
the currently available memory.
Limit size(for MMS)
: record a voice memo for
adding to an MMS message.
•
Volume
: select a volume level for recording a
voice memo.
•
Default name
: change the default prefix for file
names.
Memory status
(Menu 7.6.5)
You can access memory information for voice memos.
Calculator
(Menu 7.7)
Use this menu to perform basic arithmetic functions
such as addition, subtraction, multiplication, and
division.
1. Enter the first number.
Press [ ] to insert a decimal point or press [ ]
until a bracket displays.
2. Press [ ] to access the math function you want.
3. Enter the second number.
4. Press <
Equal
> to view the result.
5. If necessary, repeat from step 2 to confirm the
calculation.
Conversion
(Menu 7.8)
Use this menu for common conversions, such as
length and temperature.
1. Select a converter.
2. Enter the value to be converted and press [Down].
• Press [ ] to insert a decimal point.
• Press [ ] to change the temperature to above
zero (+) or below zero (-).
3. Press [Left] or [Right] to select the original unit
and press [Down].
4. Press [Left] or [Right] to select the unit to which
you want to convert.
5. Press <
OK
>.
The equivalent value for the amount you entered
displays.
X656.book Page 59 Tuesday, May 2, 2006 11:18 AM
60
Menu functions
Timer
(Menu 7.9)
Use this menu to set a period of time for the phone to
count down. The phone will sound an alarm when the
specified period of time has expired.
Starting the timer
1. Press <
Set
>.
2. Enter the length of time you want to count down
and press <
OK
>.
3. Press <
Start
> to start counting down.
Stopping the timer
• Press any key to stop the timer when it rings.
•Press <
Stop
> on the Timer screen to stop the
timer before it rings.
Stopwatch
(Menu 7.10)
Use this menu to measure elapsed time. The
maximum measurement time is 10 hours.
1. Press <
OK
> to start the timer.
2. Press <
OK
> to check an interval. You can repeat
this step for a total of 4 intervals.
Camera
(Menu 8)
You can use the camera module embedded in your
phone to take photos.
To access this menu, press <
Menu
> in Idle mode and
select
Camera
.
Take photos
(Menu 8.1)
You can take photos in various modes. The camera
produces JPEG photos.
• Do not take photos of people without their
permission.
• Do not take photos in a place where cameras are
not allowed.
• Do not take photos in a place where you may
interfere with another person’s privacy.
When you take a photo in direct sunlight or in bright
conditions, shadows may appear on the photo.
X656.book Page 60 Tuesday, May 2, 2006 11:18 AM
61
Menu functions
Camera
(Menu 8)
Taking a photo
1. Access the
Take photos
menu to turn on the
camera and switch the phone to Capture mode.
You can also press and hold [ ] in Idle mode.
2. Make any desired adjustments.
• Press < > to use camera options.
next
section
• Use the keypad to change the camera settings
or switch to other modes.
p. 62
3. Press
[],
the left soft key, or [ ] to take a
photo. The photo is saved in the
My photos
folder.
Using camera options in Capture mode
In Capture mode, press < > to access the following
options:
•
Mode
: take a photo in the following modes:
Normal shot
: take a photo in the normal mode.
Multi-shot
: take a series of action stills. Select
the number of photos the camera will take.
Night mode
: take a high quality photo in low
lighting conditions.
Capture only
: set the phone to automatically
return to Capture mode after taking a photo.
•
Effects
: change the color tone or apply a special
effect.
•
Rotation
: show the mirror image or flip the image
vertically.
•
Timer
: set a time delay before the camera takes a
photo.
•
Settings
: change the default settings for taking a
photo.
p. 63
4.
To Press
use photo options <
Options
>.
p. 62
delete the photo <
Delete
> and then
<
Yes
>.
return to Capture mode [
C
].
X656.book Page 61 Tuesday, May 2, 2006 11:18 AM
62
Menu functions
•
Help
: view the functions of the keys you can use
in Capture mode.
Using the keypad in Capture mode
You can use the keypad to customize your camera
settings in Capture mode.
Using photo options
After saving a photo, press <
Options
> to access the
following options:
•
Send
: send the photo via MMS.
•
Send via infrared
: send the photo via the
infrared port.
•
Rename
: change the photo name.
•
Go to my photos
: access the
My photos
folder.
p. 50
Key Function
Left/Right Adjusts the brightness.
Up/Down Zooms in or out.
Flips the image vertically.
Shows the mirror image.
1
Changes the preview screen.
2
Changes the image size.
3
Changes the image quality.
4
Changes the shooting mode.
5
Changes the color tone or applies a
special effect.
6
Changes the default camera settings.
p. 63
7
Sets the timer.
8
Accesses the
My photos
folder.
9
Shows the functions of the keys you can
use in Capture mode.
Key Function
X656.book Page 62 Tuesday, May 2, 2006 11:18 AM
63
Menu functions
Camera
(Menu 8)
•
Set as
: set the photo as wallpaper for the idle
screen or as a caller ID image for a Phonebook
entry.
•
Protection
: protect the photo from being deleted.
•
Properties
: access the photo properties.
My photos
(Menu 8.2)
Use this menu to access photos you have taken.
p. 50
My albums
(Menu 8.3)
Use this menu to organize your photos in a separate
album.
p. 50
Delete all
(Menu 8.4)
Use this menu to delete photos in each folder and all
photos at one time.
1. Press <
Select
> to select the photo categories to
be cleared.
2. Press <
OK
>.
3. Press <
Yes
> to confirm the deletion.
Settings
(Menu 8.5)
Use this menu to change the default settings for
taking a photo.
•
Photo size
: select an image size.
•
Photo quality
: select an image quality.
•
Shutter sound
: select the sound that you hear
when you press the shutter release.
•
Default name
: set the default prefix for file
names.
Memory status
(Menu 8.6)
Use this menu to check the amount of memory
currently being used and memory available for the
camera.
X656.book Page 63 Tuesday, May 2, 2006 11:18 AM
64
Menu functions
Phone settings
(Menu 9)
Use this menu to customize your phone settings. You
can also reset the settings to their default values.
To access this menu, press <
Menu
> in Idle mode and
select
Phone settings
.
Display
(Menu 9.1)
Use this menu to change settings for the display and
backlight.
Wallpaper
(Menu 9.1.1)
You can set up the idle screen on the display.
•
Default wallpapers
: select one of the default
images to be displayed.
•
Photos
: select one of the photos you have taken.
•
Downloaded images
: select a downloaded image
to be displayed.
•
Text position
: select a text position. If you do not
want text to display in Idle mode, select
Off
.
•
Text style
: select a font style or color.
Skin
(Menu 9.1.2)
You can select a skin color pattern for Menu mode.
Backlight time
(Menu 9.1.3)
You can select the length of time the backlight or
display stays on.
•
On
: select the length of time the backlight stays
on.
•
Dim
: select the length of time the display stays on
in Dim mode after the backlight turns off. After a
specified time, the display turns off.
LCD brightness
(Menu 9.1.4)
Use this menu to adjust the brightness of the display.
LCD contrast
(Menu 9.1.5)
Use this menu to adjust the contrast of the display.
Adjusting the contrast help you see the display clearly
in different lighting conditions.
Dialing font colour
(Menu 9.1.6)
Use this menu to select a font color for the numbers
entered while dialing.
X656.book Page 64 Tuesday, May 2, 2006 11:18 AM
65
Menu functions
Phone settings
(Menu 9)
Service light
(Menu 9.1.7)
Use this menu to activate or deactivate the use of the
service light on the front of the phone. The service
light blinks at regular intervals when your network is
available.
Greeting message
(Menu 9.2)
Use this menu to enter the greeting that is displayed
briefly when the phone is switched on.
Language
(Menu 9.3)
Use this menu to select one of several languages for
the display text and text input mode, separately.
Security
(Menu 9.4)
Use this menu to protect the phone against
unauthorized use by managing the several access
codes of your phone and SIM card.
PIN check
(Menu 9.4.1)
The 4- to 8-digit PIN (Personal Identification Number)
protects your SIM card against unauthorized use.
When this feature is enabled, the phone requires your
PIN each time it is switched on.
Change PIN
(Menu 9.4.2)
Use this menu to change your PIN. The PIN check
feature must be enabled to change the PIN.
Phone lock
(Menu 9.4.3)
Use this menu to lock the phone from unauthorized
use. When this feature is enabled, you must enter a 4-
to 8-digit phone password each time the phone is
switched on.
The password is preset to
00000000
. To change the
password, use the
Change password
menu.
Change password
(Menu 9.4.4)
Use this menu to change your phone password.
If you enter an incorrect PIN /PIN2 three times, the
SIM card is blocked. To unblock it you need to enter
your PUK/PUK2 (Personal Unblocking Key). The
codes are supplied by your network operator.
X656.book Page 65 Tuesday, May 2, 2006 11:18 AM
66
Menu functions
Privacy
(Menu 9.4.5)
Use this menu to lock access to MMS messages or
files. When a privacy option is enabled, you must
enter the phone password to access the locked items
or functions.
SIM lock
(Menu 9.4.6)
This menu allows your phone to work only with the
current SIM card by assigning a SIM lock code. You
must enter the SIM lock code to use a different SIM
card.
FDN mode
(Menu 9.4.7)
If supported by your SIM card, Fixed Dialing Number
(FDN) mode restricts your outgoing calls to a limited
set of phone numbers. When this feature is enabled,
you can make calls only to phone numbers stored on
the SIM card.
Change PIN2
(Menu 9.4.8)
If supported by your SIM card, use this menu to
change your current PIN2.
Auto redial
(Menu 9.5)
Use this menu to set the phone to make up to 10
attempts to redial a phone number after an
unsuccessful call.
Voice clarity
(Menu 9.6)
Use this menu to increase the microphone’s sensitivity
to allow the other person on the phone to hear your
voice clearly, even though you may be whispering.
Anykey answer
(Menu 9.7)
Use this menu to answer an incoming call by pressing
any key, except for
[]
. When this option is set to
Off
, you must press <
Accept
> or
[]
to answer a
call.
Active folder
(Menu 9.8)
Use this menu to answer an incoming call by opening
the phone.
X656.book Page 66 Tuesday, May 2, 2006 11:18 AM
67
Side key
(Menu 9.9)
Use this menu to set whether the phone mutes the call
ringer or rejects a call if you press and hold [ / ]
when a call comes in.
Infrared activation
(Menu 9.10)
Use this menu to activate the infrared port on your
phone to receive data from another IrDA-compatible
device.
Reset settings
(Menu 9.11)
Use this menu to reset the phone settings, and sound
settings individually. You can also reset all the settings
in your phone at the same time.
1. Press <
Select
> to select the setting categories to
be reset.
2. Press <
Yes
>.
3. Enter the phone password and press <
OK
>.
Solve problems
Help and personal needs
To save the time and expense of an unnecessary service
call, perform the simple checks in this section before
contacting a service professional.
When you switch on your phone, the following
messages may appear:
“Insert SIM”
• Be sure that the SIM card is correctly installed.
“Enter password”
• The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
“Enter PIN”
• You are using your phone for the first time. You
must enter the PIN supplied with the SIM card.
• The PIN check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the
PIN check
menu.
The password is preset to
00000000
. You can
change this password.
p. 65
X656.book Page 67 Tuesday, May 2, 2006 11:18 AM
68
Solve problems
“Enter PUK”
•The PIN has been entered incorrectly three times,
and the SIM card is now blocked. Enter the PUK
supplied by your service provider.
“No service,” “Network failure,” or “Not done”
displays
• The network connection has been lost. You may be
in a weak signal area. Move and try again.
• You are trying to access an option for which you
have no subscription with your service provider.
Contact the service provider for further details.
You have entered a number but it was not dialed
• Be sure that you have pressed [ ].
• Be sure that you have accessed the right cellular
network.
• Be sure that you have not set an outgoing call
barring option.
Your correspondent cannot reach you
• Be sure that your phone is switched on. ([ ]
pressed for more than one second.)
• Be sure that you are accessing the correct cellular
network.
• Be sure that you have not set an incoming call
barring option.
Your correspondent cannot hear you speaking
• Be sure that you have switched on the
microphone.
• Be sure that you are holding the phone close
enough to your mouth. The microphone is located
at the bottom of the phone.
The phone starts beeping and “Warning Battery
low” flashes on the display
• Your battery is insufficiently charged. Recharge the
battery.
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ). The number of bars indicates the signal
strength from strong ( ) to weak ( ).
• Try moving the phone slightly or moving closer to a
window if you are in a building.
X656.book Page 68 Tuesday, May 2, 2006 11:18 AM
69
No number is dialed when you re-call a
Phonebook entry
•Use the
Find name
menu to ensure the number
has been stored correctly.
• Re-store the number, if necessary.
The battery does not charge properly or the
phone sometimes turns itself off
• Wipe the charging contacts both on the phone and
on the battery with a clean soft cloth.
If the above guidelines do not help you to solve
the problem, take note of:
• The model and serial numbers of your phone
•Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung after-sales
service.
Health and safety information
Exposure to radio frequency (RF) signals
Your wireless phone is a radio transmitter and receiver. It
is designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the
U.S. Government. These limits are part of comprehensive
guidelines and establish permitted levels of RF energy for
the general population. The guidelines are based on the
safety standards that were developed by independent
scientific organizations through periodic and through
evaluation of scientific studies.
The standards include a substantial safety margin
designed to assure the safety of all persons, regardless of
age and health.
The exposure standard for wireless phones employs a unit
of measurement known as Specific Absorption Rate (SAR).
The SAR limit set by the FCC is 1.6W/kg
*
.
X656.book Page 69 Tuesday, May 2, 2006 11:18 AM
70
Health and safety information
SAR tests are conducted using standard operating
positions specified by the FCC with the phone transmitting
at its highest certified power level in all tested frequency
bands. Although the SAR is determined at the highest
certified power level, the actual SAR level of the phone
while operating can be well below the maximum value.
This is because the phone is designed to operate at
multiple power levels so as to use only the power required
to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power output
of the phone. Before a new model phone is available for
sale to the public, it must be tested and certified to the
FCC that it does not exceed the limit established by the
government-adopted requirement for safe exposure. The
tests are performed in positions and locations (e.g., at the
ear and worn on the body) as required by the FCC for each
model. While there may be differences between the SAR
levels of various phones and at various positions, they all
meet the government requirement.
The FCC has granted an Equipment Authorization for this
model phone with all reported SAR levels evaluated as in
compliance with the FCC RF exposure guidelines. SAR
information on this model phone is on file with the FCC
and can be found under the Display Grant section of http:/
/www.fcc.gov/oet/fccid after searching on FCC ID printed
in the label on the phone.
For body operation
For body worn operation, this model phone has been
tested and meets the FCC RF exposure guidelines when
used with a Samsung-supplied or approved accessory
designated for this product or when used with and
accessory that contains no metal and that positions the
handset a minimum from the body.
The minimum distance for this model phone is written in
the FCC certification information from the body. None
compliance with the above conditions may violate FCC RF
exposure guidelines.
For more Information concerning exposure to radio
frequency signals, see the following websites:
Federal Communications Commission (FCC)
http://www.fcc.gov
* In the U.S. and Canada, the SAR limit for mobile phones used by
the public is 1.6 watts/kg (W/kg) averaged over one gram of
tissue. The standard incorporates a substantial margin of safety
to give additional protection for the public and to account for any
variations in measurements.
X656.book Page 70 Tuesday, May 2, 2006 11:18 AM
71
Health and safety information
Cellular Telecommunications Industry Association (CTIA):
http://www.ctia.org
U.S.Food and Drug Administration (FDA)
http://www.fda.gov/cdrh/consumer
World Health Organization (WHO)
http://www.who.int/peh-emf/en
Precautions when using batteries
• Never use any charger or battery that is damaged in
any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base station,
it uses less power; talk and standby time are greatly
affected by the signal strength on the cellular network
and the parameters set by the network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out. When
the operation time (talk time and standby time) is
noticeably shorter than normal, it is time to buy a new
battery.
• If left unused, a fully charged battery will discharge
itself over time.
• Use only Samsung-approved batteries and recharge
your battery only with Samsung-approved chargers.
When a charger is not in use, disconnect it from the
power source. Do not leave the battery connected to a
charger for more than a week, since overcharging may
shorten its life.
• Extreme temperatures will affect the charging capacity
of your battery: it may require cooling or warming
first.
• Do not leave the battery in hot or cold places, such as
in a car in summer or winter conditions, as you will
reduce the capacity and lifetime of the battery. Always
try to keep the battery at room temperature. A phone
with a hot or cold battery may temporarily not work,
even when the battery is fully charged. Li-ion batteries
are particularly affected by temperatures below 0° C
(32° F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin, clip
or pen) causes a direct connection between the + and
-. terminals of the battery (metal strips on the
battery), for example when you carry a spare battery
in a pocket or bag. Short-circuiting the terminals may
damage the battery or the object causing the short-
circuiting.
X656.book Page 71 Tuesday, May 2, 2006 11:18 AM
72
Health and safety information
• Dispose of used batteries in accordance with local
regulations. Always recycle. Do not dispose of
batteries in a fire.
Road safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime. But an
important responsibility accompanies the benefits of
wireless phones, one that every user must uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a car,
practice good common sense and remember the following
tips.
1. Get to know your wireless phone and its features, such
as speed dial and redial. If available, these features
help you to place your call without taking your
attention off the road.
2. When available, use a hands-free device. If possible,
add an extra layer of convenience and safety to your
wireless phone with one of the many hands-free
accessories available today.
3. Position your wireless phone within easy reach. Be
able to access your wireless phone without removing
your eyes from the road. If you get an incoming call at
an inconvenient time, let your voicemail answer it for
you.
4. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy traffic
or hazardous weather conditions. Rain, sleet, snow, ice
and even heavy traffic can be hazardous.
5. Do not take notes or look up phone numbers while
driving. Jotting down a To Do list or flipping through
your phonebook takes your attention away from your
primary responsibility, driving safely.
6. Dial sensibly and assess the traffic; if possible, place
calls when you are not moving or before pulling into
traffic. Try to plan calls when your car will be
stationary. If you need to make a call while moving,
dial only a few numbers, check the road and your
mirrors, then continue.
7. Do not engage in stressful or emotional conversations
that may be distracting. Make the people with whom
you are talking aware that you are driving and
suspend conversations that have the potential to
divert your attention from the road.
X656.book Page 72 Tuesday, May 2, 2006 11:18 AM
73
Health and safety information
8. Use your wireless phone to call for help. Dial the
emergency number in the case of fire, traffic accident
or medical emergencies. Remember, it is a free call on
your wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see a car accident, crime in
progress or other serious emergency where lives are
in danger, call the emergency number, as you would
want others to do for you.
10. Call roadside assistance or a special nonemergency
wireless assistance number when necessary. If you
see a broken-down vehicle posing no serious hazard, a
broken traffic signal, a minor traffic accident where no
one appears injured, or a vehicle you know to be
stolen, call roadside assistance or any other special
nonemergency wireless number.
Operating environment
Remember to follow any special regulations in force in any
area and always switch off your phone whenever it is
forbidden to use it, or when it may cause interference or
danger.
When connecting the phone or any accessory to another
device, read its user’s guide for detailed safety
instructions. Do not connect incompatible products.
As with other mobile radio transmitting equipment, users
are advised that for the satisfactory operation of the
equipment and for the safety of personnel, it is
recommended that the equipment should only be used in
the normal operating position (held to your ear with the
antenna pointing over your shoulder).
Electronic devices
Most modern electronic equipment is shielded from radio
frequency (RF) signals. However, certain electronic
equipment may not be shielded against the RF signals
from your wireless phone. Consult the manufacturer to
discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a minimum
distance of 15 cm (6 inches) be maintained between a
wireless phone and a pacemaker to avoid potential
interference with the pacemaker. These recommendations
are consistent with the independent research and
recommendations of Wireless Technology Research.
X656.book Page 73 Tuesday, May 2, 2006 11:18 AM
74
Health and safety information
Persons with pacemakers:
• Should always keep the phone more than 15 cm (6
inches) from their pacemaker when the phone is
switched on
• Should not carry the phone in a breast pocket
• Should use the ear opposite the pacemaker to
minimize potential interference
If you have any reason to suspect that interference is
taking place, switch off your phone immediately.
Hearing aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you may
wish to consult your hearing aid manufacturer to discuss
alternatives. Other Medical Devices If you use any other
personal medical devices, consult the manufacturer of
your device to determine if it is adequately shielded from
external RF energy. Your physician may be able to assist
you in obtaining this information. Switch off your phone in
health care facilities when any regulations posted in these
areas instruct you to do so. Hospitals or health care
facilities may be using equipment that could be sensitive
to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check with
the manufacturer or its
representative regarding your vehicle. You should also
consult the manufacturer of any equipment that has been
added to your vehicle.
Posted facilities
Switch off your phone in any facility where posted notices
require you to do so.
Potentially explosive environments
Switch off your phone when in any area with a potentially
explosive atmosphere and obey all signs and instructions.
Sparks in such areas could cause an explosion or fire
resulting in bodily injury or even death. Users are advised
to switch off the phone while at a refueling point (service
station).
Users are reminded of the need to observe restrictions on
the use of radio equipment in fuel depots (fuel storage and
distribution areas), chemical plants or where blasting
operations are in progress.
X656.book Page 74 Tuesday, May 2, 2006 11:18 AM
75
Health and safety information
Areas with a potentially explosive atmosphere are often
but not always clearly marked. They include below deck on
boats, chemical transfer or storage facilities, vehicles
using liquefied petroleum gas (such as propane or
butane), areas where the air contains chemicals or
particles, such as grain, dust or metal powders, and any
other area where you would normally be advised to turn
off your vehicle engine.
Emergency calls
This phone, like any wireless phone, operates using radio
signals, wireless and landline networks, as well as user-
programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should never
rely solely on any wireless phone for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the phone must
be switched on and in a service area with adequate signal
strength. Emergency calls may not be possible on all
wireless phone networks or when certain network services
and/or phone features are in use. Check with local service
providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 911 or any other official
emergency number). Emergency numbers vary by
location.
3. Press [ ].
If certain features are in use (call barring, for example),
you may first need to deactivate those features before you
can make an emergency call. Consult this document and
your local cellular service provider.
When making an emergency call, remember to give all the
necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not end the
call until given permission to do so.
X656.book Page 75 Tuesday, May 2, 2006 11:18 AM
76
Health and safety information
FCC Notice and Cautions
FCC Notice
The phone may cause TV or radio interference if used in
close proximity to receiving equipment. The FCC can
require you to stop using the phone if such interference
cannot be eliminated.
Vehicles using liquefied petroleum gas (such as propane or
butane) must comply with the National Fire Protection
Standard (NFPA-58). For a copy of this standard, contact
the National Fire Protection Association, One Battery
march Park, Quincy, MA 02269, Attn: Publication Sales
Division.
• The device complies with Part 15 of the FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
• This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection
against harmful interference in a residential
installation. This equipment generates, uses and
can radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference to
radio communications. However, there is no
guarantee that interference will occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning the
equipment off and on, the user is encouraged
to try to correct the interference by one or more
of the following measures:
- Reorient or relocate the receiveing antenna.
- Increase the separation between the equipment
and receiver.
- Connect the equipment into an outlet on a
circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV
technician for help.
X656.book Page 76 Tuesday, May 2, 2006 11:18 AM
77
Health and safety information
Cautions
Changes or modifications made in the radio phone, not
expressly approved by Samsung, will void the user’s
authority to operate the equipment.
Only use approved batteries, antennas and chargers. The
use of any unauthorized accessories may be dangerous
and void the phone warranty if said accessories cause
damage or a defect to the phone.
Although your phone is quite sturdy, it is a complex piece
of equipment and can be broken. Avoid dropping, hitting,
bending or sitting on it.
Other important safety information
• Only qualified personnel should service the phone or
install the phone in a vehicle. Faulty installation or
service may be dangerous and may invalidate any
warranty applicable to the device.
• Check regularly that all wireless phone equipment in
your vehicle is mounted and operating properly.
• Do not store or carry flammable liquids, gases, or
explosive materials in the same compartment as the
phone, its parts, or accessories.
• For vehicles equipped with an air bag, remember that
an air bag inflates with great force. Do not place
objects, including both installed or portable wireless
equipment in the area over the air bag or in the air
bag deployment area. If wireless equipment is
improperly installed and the air bag inflates, serious
injury could result.
• Switch off your phone before boarding an aircraft. The
use of wireless phones in aircraft may be dangerous to
the operation of the aircraft, and is illegal.
• Failure to observe these instructions may lead to the
suspension or denial of telephone services to the
offender, or legal action, or both.
Care and maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for many
years.
• Keep your phone and all its parts and accessories out
of the reach of small children and pets. They may
accidentally damage these things or choke on small
parts.
X656.book Page 77 Tuesday, May 2, 2006 11:18 AM
78
Health and safety information
• Keep the phone dry. Precipitation, humidity, and
liquids contain minerals that will corrode electronic
circuits.
• Do not use the phone with a wet hand. Doing so may
cause an electric shock to you or damage to the
phone.
• Do not use or store the phone in dusty, dirty areas, as
its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt certain
plastics.
• Do not store the phone in cold areas. When the phone
warms up to its normal operating temperature,
moisture can form inside the phone, which may
damage the phone’s electronic circuit boards.
• Do not drop, knock, or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents, or
strong detergents to clean the phone. Wipe it with a
soft cloth slightly dampened in a mild soap-and-water
solution.
• Do not paint the phone. Paint can clog the device’s
moving parts and prevent proper operation.
• Do not put the phone in or on heating devices, such as
a microwave oven, a stove, or a radiator. The phone
may explode when overheated.
• When the phone or battery gets wet, the label
indicating water damage inside the phone changes
colour. In this case, phone repairs are no longer
guaranteed by the manufacturer's warranty, even if
the warranty for your phone has not expired.
• If your phone has a flash or light, do not use it too
close to the eyes of people or animals. This may cause
damage to their eyes.
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger, or any accessory is not
working properly, take it to your nearest qualified
service facility. The personnel there will assist you, and
if necessary, arrange for service.
X656.book Page 78 Tuesday, May 2, 2006 11:18 AM
79
Health and safety information
Acknowledging special precautions and the
FCC and Industry Canada Notice
Cautions
Modifications not expressly approved by the party
responsible for compliance could void the user's authority
to operate the equipment.
FCC compliance information
This device complies with Part 15 of FCC Rules. Operation
is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received,
including interference that may cause undesired
operation.
Information to user
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception, which
can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/ TV
technician for help.
X656.book Page 79 Tuesday, May 2, 2006 11:18 AM
80
Health and safety information
Appendix A: CERTIFICATION
INFORMATION (SAR)
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and receiver. It
is designed and manufactured not to exceed the emission
limits for exposure to radio frequency (RF) energy set by
the Federal Communications Commission of the U.S.
Government. These limits are
part of comprehensive
guidelines and establish permitted levels of RF energy
for the general population. The guidelines are based on
safety standards that were developed by independent
scientific organizations through periodic and thorough
evaluation of scientific studies. The standards include a
substantial safety margin designed to assure the safety
of all persons, regardless of age and health.
The exposure standard for wireless mobile phones
employs a unit of measurement known as the Specific
Absorption Rate (SAR). The SAR limit set by the FCC is 1.6
W/kg. SAR Tests are conducted using standard operating
positions accepted by the FCC with the phone transmitting
at its highest certified power level in all tested frequency
bands. Although the SAR is determined at the highest
certified power level, the actual SAR level of the phone
while operating can be well below the maximum value.
This is because the phone is designed to operate at
multiple power levels so as to use only the power required
to reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power
output.
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that it
does not exceed the exposure limit established by the
FCC. Tests for each model phone are performed in
positions and locations (e.g. at the ear and worn on the
body) as required by the FCC.
The highest SAR values for this model phone as reported
to the FCC are Head: 1.37W/Kg, Body-worn: 0.488W/Kg.
For body worn operations, this model phone has been
testde and meets the FCC exposure guidelines when used
with a Samsung accessory designated for this product or
when used with an accessroy that contains no metal and
that positons the handset a minimum 1.5 cm from the
body.
X656.book Page 80 Tuesday, May 2, 2006 11:18 AM
81
Health and safety information
Non-compliance with the above restrictions may result in
violation of FCC RF exposure guidelines.
SAR information on this and other model phones can be
viewed on-line at www.fcc.gov/oet/fccid. This site uses the
phone FCC ID number A3LSGHX656.
Appendix B: Guide to safe and responsible
wireless phone use
Cellular Telecommunications & Internet Association
“Safety is the most important call you will ever make.”
A guide to safe and responsible wireless
phone use
TENS OF MILLIONS OF PEOPLE IN THE U.S. TODAY TAKE
ADVANTAGE OF THE UNIQUE COMBINATION OF
CONVENIENCE, SAFETY AND VALUE DELIVERED BY THE
WIRELESS TELEPHONE. QUITE SIMPLY, THE WIRELESS
PHONE GIVES PEOPLE THE POWERFUL ABILITY TO
COMMUNICATE BY VOICE-ALMOST ANYWHERE, ANYTIME-
WITH THE BOSS, WITH A CLIENT, WITH THE KIDS, WITH
EMERGENCY PERSONNEL OR EVEN WITH THE POLICE.
EACH YEAR, AMERICANS MAKE BILLIONS OF CALLS FROM
THEIR WIRELESS PHONES, AND THE NUMBERS ARE
RAPIDLY GROWING.
But an important responsibility accompanies those
benefits, one that every wireless phone user must uphold.
When driving a car, driving is your first responsibility. A
wireless phone can be an invaluable tool, but good
judgment must be exercised at all times while driving a
motor vehicle whether on the phone or not.
The basic lessons are ones we all learned as teenagers.
Driving requires alertness, caution and courtesy. It
requires a heavy dose of basic common sense-keep your
head up, keep your eyes on the road, check your mirrors
frequently and watch out for other drivers. It requires
obeying all traffic signs and signals and staying within the
speed limit. It means using seat belts and requiring other
passengers to do the same.
But with wireless phone use, driving safely means a little
more. This brochure is a call to wireless phone users
everywhere to make safety their first priority when behind
the wheel of a car. Wireless telecommunications is keeping
us in touch, simplifying our lives, protecting us in
emergencies and providing opportunities to help others in
need. When it comes to the use of wireless phones, safety
is your most important call.
X656.book Page 81 Tuesday, May 2, 2006 11:18 AM
82
Health and safety information
Wireless phone “safety tips”
Below are safety tips to follow while driving and using a
wireless phone which should be easy to remember:
1. Get to know your wireless phone and its features such
as speed dial and redial. Carefully read your
instruction manual and learn to take advantage of
valuable features most phones offer, including
automatic redial and memory. Also, work to memorize
the phone keypad so you can use the speed dial
function without taking your attention off the road.
2. When available, use a hands free device. A number of
hands free wireless phone accessories are readily
available today. Whether you choose an installed
mounted device for your wireless phone or a speaker
phone accessory, take advantage of these devices if
available to you.
3. Position your wireless phone within easy reach. Make
sure you place your wireless phone within easy reach
and where you can grab it without removing your eyes
from the road. If you get an incoming call at an
inconvenient time, if possible, let your voicemail
answer it for you.
4. Suspend conversations during hazardous driving
conditions or situations. Let the person you are
speaking with know you are driving; if necessary,
suspend the call in heavy traffic or hazardous weather
conditions. Rain, sleet, snow and ice can be
hazardous, but so is heavy traffic. As a driver, your
first responsibility is to pay attention to the road.
5. Do not take notes or look up phone numbers while
driving. If you are reading an address book or
business card, or writing a “to do” list while driving a
car, you are not watching where you are going. It’s
common sense. Don’t get caught in a dangerous
situation because you are reading or writing and not
paying attention to the road or nearby vehicles.
6. Dial sensibly and assess the traffic; if possible, place
calls when you are not moving or before pulling into
traffic. Try to plan your calls before you begin your trip
or attempt to coincide your calls with times you may
be stopped at a stop sign, red light or otherwise
stationary. But if you need to dial while driving, follow
this simple tip-dial only a few numbers, check the road
and your mirrors, then continue.
X656.book Page 82 Tuesday, May 2, 2006 11:18 AM
83
Health and safety information
7. Do not engage in stressful or emotional conversations
that may be distracting. Stressful or emotional
conversations and driving do not mix-they are
distracting and even dangerous when you are behind
the wheel of a car. Make people you are talking with
aware you are driving and if necessary, suspend
conversations which have the potential to divert your
attention from the road.
8. Use your wireless phone to call for help. Your wireless
phone is one of the greatest tools you can own to
protect yourself and your family in dangerous
situations-with your phone at your side, help is only
three numbers away. Dial 9-1-1 or other local
emergency number in the case of fire, traffic accident,
road hazard or medical emergency. Remember, it is a
free call on your wireless phone!
9. Use your wireless phone to help others in
emergencies. Your wireless phone provides you a
perfect opportunity to be a “Good Samaritan” in your
community. If you see an auto accident, crime in
progress or other serious emergency where lives are
in danger, call 9-1-1 or other local emergency number,
as you would want others to do for you.
10. Call roadside assistance or a special wireless non
emergency assistance number when necessary.
Certain situations you encounter while driving may
require attention, but are not urgent enough to merit a
call for emergency services. But you still can use your
wireless phone to lend a hand. If you see a broken-
down vehicle posing no serious hazard, a broken traffic
signal, a minor traffic accident where no one appears
injured or a vehicle you know to be stolen, call
roadside assistance or other special non-emergency
wireless number.
Careless, distracted individuals and people driving
irresponsibly represent a hazard to everyone on the road.
Since 1984, the Cellular Telecommunications Industry
Association and the wireless industry have conducted
educational outreach to inform wireless phone users of
their responsibilities as safe drivers and good citizens. As
we approach a new century, more and more of us will take
advantage of the benefits of wireless telephones. And, as
we take to the roads, we all have a responsibility to drive
safely.
“The wireless industry reminds you to use your phone
safely when driving.”
Cellular Telecommunications & Internet Association For
more information, please call 1-888-901-SAFE.
For updates: http://www.ctia.org
X656.book Page 83 Tuesday, May 2, 2006 11:18 AM
84
Health and safety information
Appendix C: Consumer update on wireless
phones
U.S. Food and Drug Administration
1. What kinds of phones are the subject of this update?
The term wireless phone refers here to hand-held wireless
phones with built-in antennas, often called cell, mobile, or
PCS phones. These types of wireless phones can expose
the user to measurable radio frequency energy (RF)
because of the short distance between the phone and the
user s head. These RF exposures are limited by Federal
Communications Commission safety guidelines that were
developed with the advice of FDA and other federal health
and safety agencies. When the phone is located at greater
distances from the user, the exposure to RF is drastically
lower because a person’s RF exposure decreases rapidly
with increasing distance from the source. The so-called
“cordless phones,” which have a base unit connected to
the telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures well
within the FCC’s compliance limits.
2. Do wireless phones pose a health hazard?
The available scientific evidence does not show that any
health problems are associated with using wireless
phones. There is no proof, however, that wireless phones
are absolutely safe. Wireless phones emit low levels of
radio frequency energy (RF) in the microwave range while
being used. They also emit very low levels of RF when in
the stand-by mode. Whereas high levels of RF can produce
health effects (by heating tissue), exposure to low level RF
that does not produce heating effects causes no known
adverse health effects. Many studies of low level RF
exposures have not found any biological effects. Some
studies have suggested that some biological effects may
occur, but such findings have not been confirmed by
additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
X656.book Page 84 Tuesday, May 2, 2006 11:18 AM
85
Health and safety information
3. What is FDA’s role concerning the safety of wireless
phones?
Under the law, FDA does not review the safety of radiation
emitting consumer products such as wireless phones
before they can be sold, as it does with new drugs or
medical devices. However, the agency has authority to
take action if wireless phones are shown to emit radio
frequency energy (RF) at a level that is hazardous to the
user. In such a case, FDA could require the manufacturers
of wireless phones to notify users of the health hazard and
to repair, replace or recall the phones so that the hazard
no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
• Support needed research into possible biological
effects of RF of the type emitted by wireless phones;
• Design wireless phones in a way that minimizes any
RF exposure to the user that is not necessary for
device function; and
• Cooperate in providing users of wireless phones with
the best possible information on possible effects of
wireless phone use on human health
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at the
federal level. The following agencies belong to this
working group:
• National Institute for Occupational Safety and Health
• Environmental Protection Agency Federal
Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information
Administration
• The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless phones
with the Federal Communications Commission (FCC). All
phones that are sold in the United States must comply
with FCC safety guidelines that limit RF exposure. FCC
relies on FDA and other health agencies for safety
questions about wireless phones.
X656.book Page 85 Tuesday, May 2, 2006 11:18 AM
86
Health and safety information
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from these
base stations are typically thousands of times lower than
those they can get from wireless phones. Base stations
are thus not the primary subject of the safety questions
discussed in this document.
4. What is FDA doing to find out more about the possible
health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology Program
and with groups of investigators around the world to
ensure that high priority animal studies are conducted to
address important questions about the effects of exposure
to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization International Electromagnetic Fields (EMF)
Project since its inception in 1996. An influential result of
this work has been the development of a detailed agenda
of research needs that has driven the establishment of
new research programs around the world. The Project has
also helped develop a series of public information
documents on EMF issues.
FDA and the Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative Research
and Development Agreement (CRADA) to do research on
wireless phone safety. FDA provides the scientific
oversight, obtaining input from experts in government,
industry, and academic organizations. CTIA-funded
research is conducted through contracts to independent
investigators. The initial research will include both
laboratory studies and studies of wireless phone users.
The CRADA will also include a broad assessment of
additional research needs in the context of the latest
research developments around the world.
5. What steps can I take to reduce my exposure to radio
frequency energy from my wireless phone?
If there is a risk from these products—and at this point we
do not know that there is—it is probably very small. But if
you are concerned about avoiding even potential risks,
you can take a few simple steps to minimize your
exposure to radio frequency energy (RF). Since time is a
key factor in how much exposure a person receives,
reducing the amount of time spent using a wireless phone
will reduce RF exposure.
X656.book Page 86 Tuesday, May 2, 2006 11:18 AM
87
Health and safety information
If you must conduct extended conversations by wireless
phone every day, you could place more distance between
your body and the source of the RF, since the exposure
level drops off dramatically with distance. For example,
you could use a headset and carry the wireless phone
away from your body or use a wireless phone connected to
a remote antenna
Again, the scientific data do not demonstrate that wireless
phones are harmful. But if you are concerned about the RF
exposure from these products, you can use measures like
those described above to reduce your RF exposure from
wireless phone use.
6. What about children using wireless phones?
The scientific evidence does not show a danger to users of
wireless phones, including children and teenagers. If you
want to take steps to lower exposure to radio frequency
energy (RF), the measures described above would apply
to children and teenagers using wireless phones. Reducing
the time of wireless phone use and increasing the distance
between the user and the RF source will reduce RF
exposure.
Some groups sponsored by other national governments
have advised that children be discouraged from using
wireless phones at all. For example, the government in the
United Kingdom distributed leaflets containing such a
recommendation in December 2000. They noted that no
evidence exists that using a wireless phone causes brain
tumors or other ill effects. Their recommendation to limit
wireless phone use by children was strictly precautionary;
it was not based on scientific evidence that any health
hazard exists.
7. Do hands-free kits for wireless phones reduce risks
from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free kits
can be used with wireless phones for convenience and
comfort. These systems reduce the absorption of RF
energy in the head because the phone, which is the source
of the RF emissions, will not be placed against the head.
On the other hand, if the phone is mounted against the
waist or other part of the body during use, then that part
of the body will absorb more RF energy. Wireless phones
X656.book Page 87 Tuesday, May 2, 2006 11:18 AM
88
Health and safety information
marketed in the U.S. are required to meet safety
requirements regardless of whether they are used against
the head or against the body. Either configuration should
result in compliance with the safety limit.
8. Do wireless phone accessories that claim to shield the
head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head from
those emissions reduce risks. Some products that claim to
shield the user from RF absorption use special phone
cases, while others involve nothing more than a metallic
accessory attached to the phone. Studies have shown that
these products generally do not work as advertised. Unlike
“hand-free” kits, these so-called “shields” may interfere
with proper operation of the phone. The phone may be
forced to boost its power to compensate, leading to an
increase in RF absorption. In February 2002, the Federal
trade Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users from
radiation with making false and unsubstantiated claims.
According to FTC, these defendants lacked a reasonable
basis to substantiate their claim.
9. What about wireless phone interference with medical
equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason, FDA
helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted cardiac
pacemakers and defibrillators from wireless telephones.
This test method is now part of a standard sponsored by
the Association for the Advancement of Medical
instrumentation (AAMI). The final draft, a joint effort by
FDA, medical device manufacturers, and many other
groups, was completed in late 2000. This standard will
allow manufacturers to ensure that cardiac pacemakers
and defibrillators are safe from wireless phone EMI.
FDA has tested hearing aids for interference from
handheld wireless phones and helped develop a voluntary
standard sponsored by the Institute of Electrical and
Electronic Engineers (IEEE). This standard specifies test
methods and performance requirements for hearing aids
and wireless phones so that no interference occurs when a
person uses a compatible phone and a compatible hearing
aid at the same time. This standard was approved by the
IEEE in 2000.
X656.book Page 88 Tuesday, May 2, 2006 11:18 AM
89
Health and safety information
FDA continues to monitor the use of wireless phones for
possible interactions with other medical devices. Should
harmful interference be found to occur, FDA will conduct
testing to assess the interference and work to resolve the
problem.
10. What are the results of the research done already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in their
research methods. Animal experiments investigating the
effects of radio frequency energy (RF) exposures
characteristic of wireless phones have yielded conflicting
results that often cannot be repeated in other laboratories.
A few animal studies, however, have suggested that low
levels of RF could accelerate the development of cancer in
laboratory animals. However, many of the studies that
showed increased tumor development used animals that
had been genetically engineered or treated with cancer
causing chemicals so as to be pre-disposed to develop
cancer in the absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day.
These conditions are not similar to the conditions under
which people use wireless phones, so we don t know with
certainty what the results of such studies mean for human
health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use of
wireless phones and primary brain cancer, gioma,
meningioma, or acoustic neuroma, tumors of the brain or
salivary gland, leukemia, or other cancers. None of the
studies demonstrated the existence of any harmful health
effects from wireless phone RF exposures. However, none
of the studies can answer questions about long-term
exposures, since the average period of phone use in these
studies was around three years.
11. What research is needed to decide whether RF
exposure from wireless phones poses a health risk?
A combination of laboratory studies and epidemiological
studies of people actually using wireless phones would
provide some of the data that are needed. Lifetime animal
exposure studies could be completed in a few years.
However, very large numbers of animals would be needed
to provide reliable proof of a cancer promoting effect if
one exists. Epidemiological studies can provide data that
is directly applicable to human populations, but 10 or
more years follow-up may be needed to provide answers
about some health effects, such as cancer. This is because
the interval between the time of exposure to a cancer-
X656.book Page 89 Tuesday, May 2, 2006 11:18 AM
90
Health and safety information
causing agent and the time tumors develop - if they do -
may be many, many years. The interpretation of
epidemiological studies is hampered by difficulties in
measuring actual RF exposure during day-to-day use of
wireless phones. Many factors affect this measurement,
such as the angle at which the phone is held, or which
model of phone is used.
12. Which other federal agencies have responsibilities
related to potential RF health effects?
Additional information on the safety of RF exposures from
various sources can be obtained from the following
organizations.
FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
Occupational Safety and Health Administration’s (OSHA):
http://www.osha-slc.gov/SLTC/radiofrequencyradiation/
index.html
National Institute for Occupational Safety and Health
(NIOSH):
http://www.cdc.gov/niosh/topics/emf/
World health Organization (WHO):
http://www.who.int/peh-emf/
International Commission on Non-Ionizing Radiation
Protection:
http://www.icnirp.de
Health Protection Agency (UK)
http://www.hpa.org.uk/radiation/
*
* US Food and Drug Administration http://www.fda.gov/cellphones
X656.book Page 90 Tuesday, May 2, 2006 11:18 AM
Index
91
Index
A
ABC mode, text input •
22
Active folder •
66
Active line •
37
Alarm •
57
Answering
call •
26
second call •
27
Anykey answer •
66
Auto redial •
66
B
Background image •
64
Backlight time, set •
64
Band selection •
36
Barring, calls •
35
Battery
charging •
7
low indicator •
8
precautions •
71
Broadcast messages •
44
Browser, web •
47
C
Calculator •
59
Calendar •
55
Call cost •
34
Call records
dialed •
33
missed •
33
received •
33
Call time •
34
Caller ID •
36
Calls
answering •
26
barring •
35
diverting •
35
holding •
27
making •
25
redialing •
25
rejecting •
26
transferring •
28
waiting •
27
,
36
Camera •
60
CB (Cell Broadcast) messages •
44
Characters, enter •
22
Connection tone •
38
Converter •
59
D
Date, set •
56
Deleting
calendar data •
56
call records •
33
contacts •
29
,
31
MMS •
42
,
43
photos •
50
,
51
SMS •
39
,
40
sounds •
51
Delivery reports, message •
45
Dialed calls •
33
Display
backlight •
64
contrast •
64
icons •
10
language •
65
settings •
64
Diverting, calls •
35
DTMF tones, send •
28
E
Emergency calls •
75
F
FDN (Fixed Dialing Number)
mode •
66
FM radio •
53
Funbox •
47
G
Games •
52
Greeting message •
65
H
Health and safety •
69
Holding, call •
27
I
Icons, description •
10
Images, downloaded •
51
Inbox, messages
MMS •
42
SMS •
39
Infrared port, activate •
67
International calls •
25
Internet •
47
K
Keypad tones
selecting •
38
sending/muting •
28
volume •
38
X656.book Page 91 Tuesday, May 2, 2006 11:18 AM
Index
92
L
Language, select •
65
Last number, redial •
25
Locking
phone •
65
SIM card •
66
Low battery indicator •
8
M
Message tone •
37
Messages
broadcast •
44
greeting •
65
MMS •
41
push •
43
SMS •
38
voicemail •
44
Minute minder •
38
MMS messages
creating/sending •
41
deleting •
42
,
43
viewing •
42
Multiparty-call •
28
N
Names
entering •
22
searching •
29
Network selection •
36
Network services •
34
Numbers
searching •
29
storing •
29
O
Outbox, messages
MMS •
42
SMS •
40
P
Password
call barring •
35
phone •
65
Phone
care and maintenance •
77
display •
10
icons •
10
locking •
65
password •
65
resetting •
67
switching on/off •
8
unpacking •
6
Phonebook
adding •
29
copying •
29
deleting •
29
editing •
29
finding •
29
options •
29
speed-dialing •
30
taking •
61
viewing •
50
PIN, change •
65
PIN2, change •
66
Power on/off tone •
37
Privacy •
66
Problems, solve •
67
Q
Quiet mode
entering •
13
setting •
38
R
Received calls •
33
Received messages
MMS •
42
SMS •
39
Redialing
automatically •
66
manually •
25
Resetting phone •
67
Ringer
incoming calls •
37
messages •
37
Roaming •
36
S
Safety
information •
69
precautions •
1
Security, calls •
65
Sent messages •
40
,
42
Service light •
65
SIM card
inserting •
7
locking •
66
SMS messages
creating/sending •
39
deleting •
39
,
40
viewing •
39
Sound settings •
37
Sounds, downloaded •
51
Speed dial •
30
Stopwatch •
60
Switching on/off
microphone •
28
phone •
8
X656.book Page 92 Tuesday, May 2, 2006 11:18 AM
Index
93
T
T9 mode, text input •
23
Text, enter •
22
Time, set •
56
Timer •
60
V
Voice clarity feature •
66
Voice memos
deleting •
58
playing •
58
recording •
58
setting •
58
Voicemail server •
44
W
Waiting call •
36
Wallpaper •
64
Web browser
access •
47
bookmarks •
48
X656.book Page 93 Tuesday, May 2, 2006 11:18 AM
Declaration of Conformity (R&TTE)
For the following product:
GSM850/GSM1800/GSM1900
Portable Cellular Telephone
(Product description)
SGH-X656
(Model name)
Manufactured at:
Samsung Electronics Co., Ltd, 94-1 Imsu-Dong, Gumi City, Kyung Buk,
Korea, 730-350
(factory name, address
*
)
to which this declaration relates, is in conformity with the following
standards and/or other normative documents.
Safety :
EN 60950-1:2001
EMC :
EN 301 489-01 v1.4.1 (2002-08)
EN 301 489-07 v1.2.1 (2002-08)
:
EN 301 489-17 v1.2.1 (2002-08)
SAR :
EN 50360:2001
EN 50361:2001
Network:
EN 301 511 v9.0.2 (2003-03)
EN 300 328 v1.4.1 (2003-04)
We hereby declare the [all essential radio test suites have been
carried out and that] the above named product is in conformity to all
the essential requirements of Directive 1999/5/EC.
The conformity assessment procedure referred to in Article 10 and
detailed in Annex[
IV
] of Directive 1999/5/EC has been followed with
the involvement of the following Notified Body(ies):
BABT, Balfour House, Churchfield Road,
Walton-on-Thames, Surrey, KT12 2TD, UK
Identification mark: 0168
The technical documentation kept at:
Samsung Electonics Euro QA Lab.
which will be made available upon request.
(Representative in the EU)
Samsung Electronics Euro QA Lab.
Blackbushe Business Park, Saxony Way,
Yateley, Hampshire, GU46 6GG, UK
2005. 07.21
Yong-Sang Park / S. Manager
(place and date of issue) (name and signature of authorised person)
* It is not the address of Samsung Service Centre. For the address or the phone number
of Samsung Service Centre, see the warranty card or contact the retailer where you
purchased your phone.
