Users Manual

World Wide Web

http://www.samsungmobile.com

Printed in Korea

Code No.:GH68-XXXXXA

English. 01/2006. Rev. 1.0

* Depending on the software installed or your service provider or country,

some of the descriptions in this guide may not match your phone exactly.

* Depending on your country, your phone and accessories may appear

different from the illustrations in this guide.

SGH-X670

User’s Guide

Draft

2006. 01. 16

(Version:x670XAEL1)

Important

safety

precautions

Failure to comply with the following

precautions may be dangerous or illegal.

Drive safely at all times

Do not use a hand-held phone while driving. Park

the vehicle first.

Switch off the phone when refuelling

Do not use the phone at a refuelling point (service

station) or near fuels or chemicals.

Switch off in an aircraft

Wireless phones can cause interference. Using them

in an aircraft is both illegal and dangerous.

Switch off the phone near all medical

equipment

Hospitals or health care facilities may be using

equipment that could be sensitive to external radio

frequency energy. Follow any regulations or rules in

force.

Important safety precautions

Interference

All wireless phones may be subject to interference,

which could affect their performance.

Be aware of special regulations

Meet any special regulations in force in any area and

always switch off your phone whenever it is forbidden

to use it, or when it may cause interference or danger.

Water resistance

Your phone is not water-resistant. Keep it dry.

Sensible use

Use only in the normal position (held to the ear). Avoid

unnecessary contact with the antenna when the phone

is switched on.

Emergency calls

Key in the emergency number for your present

location, then press .

Keep your phone away from small children

Keep the phone and all its parts, including accessories,

out of the reach of small children.

Accessories and batteries

Use only Samsung-approved accessories and

batteries. Use of any unauthorised accessories could

damage your phone and may be dangerous.

Qualified service

Only qualified service personnel may repair your

phone.

For more detailed safety information, see "Health and

safety information" on page 87.

• The phone could explode if the battery is replaced

with an incorrect type.

• Dispose of used batteries according to the

manufacturer’s instructions.

About this Guide

This User’s Guide provides you with condensed

information about how to use your phone. To quickly

learn the basics for your phone, please refer to “Get

started” and “Step outside the phone.”

In this guide, the following instruction icons appear:

Indicates that you need to pay careful attention

to the subsequent information regarding safety

or phone features.



Indicates that you can get more information on

the referenced page.

→

Indicates that you need to press the Navigation

keys to scroll to the specified option and then

select it.

[ ]

Indicates a key on the phone. For example,

[].

< >

Indicates a soft key, whose function is displayed

on the phone screen. For example, <

• Camera and camcorder

Use the camera module on your

phone to take a photo or record a

video.

Special

features of your phone

•FM radio

Listen to your favourite radio

channels anytime, anywhere.

•Bluetooth

Transfer media files and personal

data and connect to other devices

using free, wireless Bluetooth

technology.

Special features of your phone

• Get personal with photo caller

See who’s calling you when their

very own photo displays.

•Name card

Create name cards with your

number and profile. Whenever

introducing yourself to others, use

this convenient electronic name

card.

•

Multimedia Message Service (MMS)

Send and receive MMS messages with a

combination of text, images, video, and audio.

•

E-mail

Send and receive e-mails with images, video, and

audio attachments.

• Printing via Bluetooth

Print images, messages, and

personal data directly from your

phone.

•Web browser

Access the wireless web to get up-

to-the-minute information and a

wide variety of media content.

•Java

Enjoy Java

™

-based embedded

games and download new games.

• Voice recorder

Record memos or sounds.

Contents

Unpack 6

Make sure you have each item

Your phone 6

Buttons, features, and locations

Get started 7

First steps to operating your phone

Install and charge the phone..................................... 7

Power on or off........................................................ 8

Keys and display ..................................................... 9

Access menu functions ............................................ 11

Customise your phone............................................. 12

Make/Answer calls .................................................. 15

Step outside the phone 15

Begin with your camera, FM radio, web, and other special

features

Use the camera ...................................................... 15

Listen to the FM radio.............................................. 16

Browse the web...................................................... 17

Use Phonebook ...................................................... 18

Send messages...................................................... 19

View messages....................................................... 20

Use Bluetooth ........................................................ 21

Quickly launch menus by number ............................. 22

Enter text 23

ABC, T9, Number, and Symbol mode

Call functions 25

Advanced calling features

Menu functions 29

All menu options listed

Solve problems 85

Help and personal needs

Health and safety information 88

Index 108

1 Call records



p. 29

1 Recent contacts

2 Missed calls

3 Dialled calls

4 Received calls

5 Delete all

6 Call time

7 Call costs



p. 29



p. 30



p. 30



p. 30



p. 30



p. 30



p. 31

2 Phonebook



p. 31

1 Contact list

2 FDN list

3 Add new contact

4 Group

5 Speed dial

6 My name card

7 Own number

8 Management

9 Service number



p. 31



p. 32



p. 32



p. 33



p. 34



p. 34



p. 35



p. 35



p. 35

3 Applications



p. 36

1 Voice recorder

2 Java world

3 FM radio

4 World time

5 Alarm

6 Calculator

7 Convertor

8 Timer

9 Stopwatch

10 SIM AT



p. 36



p. 37



p. 38



p. 39



p. 40



p. 40



p. 41



p. 41



p. 41



p. 42

4 Browser



p. 42

1 Home

1 Bookmarks

2 Goto URL

3 Clear cache

4 Profile settings

5 Current profile



p. 42



p. 43



p. 44



p. 44



p. 44



p. 45

5 Messages



p. 45

1 Create new message

2 My messages

3 Templates

4 Delete all

5 Settings

6 Broadcast messages

7 Memory status



p. 45



p. 48



p. 53



p. 54



p. 54



p. 60



p. 60

6 File manager



p. 61

1 Images

2 Videos

3 Music

4 Sounds

5 Other files

6 Memory status



p. 61



p. 62



p. 63



p. 64



p. 64



p. 64

7 Calendar



p. 65

8 Camera



p. 68

9 Settings



p. 74

1 Time & Date

2 Phone settings

3 Display settings

4 Sound settings

5 Light settings

6 Network services

7 Bluetooth

8 Security

9 Memory status

10 Reset settings



p. 74



p. 74



p. 76



p. 77



p. 78



p. 79



p. 81



p. 83



p. 85



p. 85

* Shows only if supported by your

SIM card.

Overview of menu functions

To access Menu mode, press <

> in Idle mode.

Unpack

Make sure you have each item

You can obtain various accessories from

your local Samsung dealer.

Phone Travel Adapter

Battery User’s Guide

The items supplied with your phone

and the accessories available at your

Samsung dealer may vary, depending

on your country or service provider.

Your phone

Buttons, features, and locations

Special

function keys

Earpiece

Display

Left soft key

Headset jack

Volume keys

Dial key

Alphanumeric

keys

Power on/off/

Menu exit key

Microphone

Right soft key

Navigation keys

(Up/Down/Left/

Right)

Web access/

Confirm key

Delete key

Camera key

Camera lens

External

display

Get started

First steps to operating your phone

SIM card information

When you subscribe to a cellular network, you receive

a plug-in SIM (Subscriber Identity Module) card

loaded with your subscription details, such as your

PIN, and available optional services.

Install and charge the phone

Remove the battery.

If the phone is already

on, first turn it off by

holding [ ].

Insert the SIM card.

Make sure that the gold-

coloured contacts on the

card face down into the

phone.

Install the battery. Plug the travel adapter

into the phone.

Plug the adapter into a standard AC wall outlet.

When the phone is completely charged (the

battery icon becomes still), unplug the adapter

from the power outlet.

Get started

Low battery indicator

When the battery is low:

• a warning tone sounds,

• the low battery message displays, and

• the empty battery icon blinks.

If the battery level becomes too low, the phone

automatically turns off. Recharge your battery.

Power on or off

Remove the adapter from the phone.

Switch on

Do not turn on

the phone when

mobile phone

use is prohibited.

1. Open the phone.

2. Press and hold [ ] to turn on

the phone.

3. If necessary, enter the PIN and

press <

Switch off

1. Open the phone.

2. Press and hold [ ].

Get started

Keys and display

Keys

Perform the function indicated on the bottom

line of the display.

In Idle mode, access your favourite menus

directly.



p. 74

In Menu mode, scroll through menu options.

In Idle mode, launch the web browser.

In Menu mode, select the highlighted menu

option or confirm input.

Make or answer a call.

In Idle mode, retrieve the recent numbers

dialled, missed, or received.

Delete characters from the display and

selected item in an application.

End a call.

Press and hold to switch the phone on or off.

In Menu mode, cancel input and return the

phone to Idle mode.

Enter numbers, letters, and some special

characters.

In Idle mode, press and hold

[1]

to access

your voicemail server. Press and hold [

] to

enter an international call prefix.

Enter special characters.

In Idle mode, press and hold [ ] to activate

or deactivate Quiet mode. Press and hold

[ ] to enter a pause between numbers.

Adjust the phone volume.

In Idle mode, with the phone open, adjust

the keypad tone volume. With the phone

closed, press and hold to activate the

backlight.

In Idle mode, press and hold to turn on the

camera.

In Camera mode, take a photo or record a

video.

Get started

Display

Layout

Icons

Received signal strength

Call in progress

Out of your service area; you

cannot make or receive calls

Alarm set



p. 40

New text message

New multimedia message

New e-mail

New voicemail

Text and graphics

display messages,

instructions, and

information you enter.

Soft key function

indicators

show the current functions

assigned to the soft keys.

Menu Contacts

Icons

display various icons.

One of the message Inboxes is full

Call diverting feature active



p. 79

Bluetooth active



p. 81

Connected with a computer via a

USB port

GPRS network

EDGE network

Home Zone, if registered for the

appropriate service

Office Zone, if registered for the

appropriate service

Ringer type



p. 77

•None: Melody

•: Vibration

• : Melody and vibration

• : Vibration then melody

• : Melody then vibration

Get started

Access menu functions

Quiet mode

Mute mode, during a call

Battery power level

* Depending on your country or service provider, the icons

shown on the display may vary.

Use the soft

keys

The roles of the soft keys vary

depending on the function you are

using. The bottom line of the

display indicates their current role.

Press the left

soft key to select

the highlighted

option.

Press the right

soft key to return

to the previous

menu level.

Select Back

Get started

Customise your phone

Select an

option

1. Press the appropriate soft key.

2. Press the Navigation keys to

move to the next or previous

option.

3. Press <

Select

> or [ ] to

confirm the function displayed

or option highlighted.

4. To exit, choose either of the

following methods.

• Press <

Back

> to move up

one level.

• Press [ ] to return to Idle

mode.

Use shortcuts

Press the number key

corresponding to the option you

want.

1. In Idle mode, press <

and select

Settings

→

Phone

settings

→

Language

2. Select a language.

1. In Idle mode, press <

and select

Settings

→

Sound

settings

→

Incoming call

→

Ring tone

2. Select a ringtone category.

3. Select a ringtone.

4. Press <

Save

Display

language

Call ringer

melody

Get started

You can set wallpaper for the idle

screen on each display.

For the main display:

1. In Idle mode, press <

and select

Settings

→

Display

settings

→

Wallpaper

→

Main

display

2. Select an image category.

3. Select an image.

For the external display:

1. In Idle mode, press <

and select

Settings

→

Display

settings

→

Wallpaper

→

Cover display

2. Select an image type.

Idle mode

wallpaper

3. For

Clock

, scroll to a clock type

and press <

Save

For

Cover title

, enter a

greeting and press [ ].

For

Wallpaper images

, select

an image category, scroll to an

image and press <

Save

You can change the colour for the

display components, such as title

bars and highlight bars.

1. In Idle mode, press <

and select

Settings

→

Display

settings

→

Skin

2. Select a colour pattern.

Menu mode

skin colour

You can set the Navigation keys to

function as shortcuts to access

your favourite menus.

1. In Idle mode, press <

and select

Settings

→

Phone

settings

→

Short cut

2. Select a menu to be assigned to

the key.

You can switch the phone to Quiet

mode to avoid disturbing other

people.

Press and hold [ ] in Idle mode.

shortcuts

Quiet mode

You can protect the phone against

unauthorised use with a phone

password. The phone will require

the password on power-up.

1. In Idle mode, press <

and select

Settings

→

Security

→

Change

password

2. Enter the default password,

00000000

, and press <

3. Enter a new 4- to 8-digit

password and press <

4. Enter the new password again

and press <

5. Select

Phone lock

6. Select

Enable

7. Enter the password and press

Phone lock

Step outside the phone

Make/Answer calls

Step outside the phone

Begin with your camera, FM radio, web, and other special

features

Use the camera

1. In Idle mode, enter an area

code and phone number.

2. Press [ ].

3. To end the call, press [ ].

1. When the phone is ringing,

press [ ].

2. To end the call, press [ ].

Press [ / ].

Make a call

Answer a call

Adjust the

volume during

a call

1. Open the phone.

2. In Idle mode, press and hold

[

]

to turn on the camera.

3. Aim the lens at the subject and

make any desired adjustments.

4. Press [ ] to take a photo. The

photo is saved automatically.

Pres

s <

Back

> to

take another

photo.

Take a photo

Step outside the phone

Listen to the FM radio

1. In Idle mode, press <

and select

File manager

→

Images

→

Photos

2. Select the photo you want.

1. In Idle mode, press and hold

[ ] to turn on the camera.

2. Press [

] to switch to Record

mode.

3. Press [ ] to start recording.

4. Press [ ] to stop recording.

The video is saved

automatically.

5. Press < > to record another

video.

View a photo

Record a video

In Idle mode, press <

and select

File manager

→

Videos

→

Videos

2. Select the video you want.

1. Plug the connector of the

headset into the jack on the left

side of the phone.

2. In Idle mode, press <

and select

Applications

→

radio

3. Press <

Options

> and select

FM radio on

4. Press [Left] or [Right] to find

available radio stations.

5. To turn off the radio, disconnect

the headset.

Play a video

Listening to the

radio

Step outside the phone

Browse the web

Using a built-in web browser, you can easily access the

wireless web to get a variety of up-to-date services

and information and to download web content.

1. From the FM radio screen, press

Options

> and select

Add

2. Enter the title of the station and

press [Down].

3. Enter the frequency of the

station and press <

Save

4. Select an empty location.

Storing a radio

station

In Idle mode, press [ ], or

press <

> and select

Browser

→

Home

• To scroll through browser items,

press [Up] or [Down].

• To select an item, press [ ].

• To return to the previous page,

press <

Back

> or [

• To access browser menu

options, press [ ] or select .

• To access web page options,

press [ ].

Launch the

web browser

Navigate the

web

Step outside the phone

Use Phonebook

To the phone’s memory:

1. In Idle mode, enter a phone

number and press <

Save

2. Select

Phone

→

a number type.

3. Specify contact information:

First name, Last name, Mobile,

Home, Office, Fax, Other, Email,

Graphic ID, Alert, Group, and

Notes.

4. Press <

Save

> to save the

entry.

To the SIM card:

1. In Idle mode, enter a phone

number and press <

Save

2. Select

SIM

3. Enter a name.

4. Press [ ] to save the entry.

Add an entry

1. In Idle mode, press

Contacts

2. Enter the first few letters of the

name you want.

3. Select an entry.

4. Scroll to a number and press

[]

to dial, or press [ ] to

edit contact information.

1. In Idle mode, press <

and select

Phonebook

→

name card

2. Specify your contact

information.

3. Press <

Save

> to save the

name card.

4. To send the name card, press

Options

> and select

Send

via

→

a sending method.

Find an entry

Create and

send a name

card

Step outside the phone

Send messages

1. In Idle mode, press <

and select

Messages

→

Create

new message

→

Text

message

2. Enter the message text.

3. Press <

Options

> and select

Save and send

Send only

4. Enter destination numbers.

5. Press [ ] to send the

message.

1. In Idle mode, press <

and select

Messages

→

Create

new message

→

Multimedia

message

2. Select

Subject

3. Enter the message subject and

press [ ].

Send a text

message (SMS)

Send a

multimedia

message

(MMS)

4. Select

Picture & Video

Sound

5. For

Picture & Video

, select

Add image

Add video

and

add an image or video clip.

For

Sound

, select

Add sound

and add a sound clip.

6. Select

Message

7. Enter the message text and

press [ ].

8. Press <

Options

> and select

Send

9. Enter destination numbers or

e-mail addresses.

10.Press [ ] to send the

message.

Step outside the phone

View messages

1. In Idle mode, press <

and select

Messages

→

Create

new message

→

2. Select

Subject

3. Enter the e-mail subject and

press [ ].

4. Select

Message

5. Enter the e-mail text and press

[].

6. Select

File attach

7. Add image, video, sound, music

files, or document files.

8. Press <

Options

> and select

Send

9. Enter e-mail addresses.

10.Press [ ] to send the e-mail.

Send an e-mail

When a notification appears:

1. Press <

View

2. Select the message from the

Inbox.

From the Inbox:

1. In Idle mode, press <

and select

Messages

→

messages

→

Inbox

2. Select an SMS message ( ).

When a notification appears:

1. Press <

View

2. Select the message from the

Inbox.

View a text

message

View a

multimedia

message

Step outside the phone

Use Bluetooth

Your phone is equipped with Bluetooth technology,

enabling you to connect the phone wirelessly to other

Bluetooth devices and exchange data with them, talk

hands-free, or control the phone remotely.

From the Inbox:

1. In Idle mode, press <

and select

Messages

→

messages

→

Inbox

2. Select an MMS message ( ).

1. In Idle mode, press <

and select

Messages

→

messages

→

Email box

2. Select

Check new mail

download new e-mails or

headers.

3. Select an e-mail or a header.

4. If you selected a header, press

Options

> and select

Retrieve

to view the body of

the e-mail.

View an e-mail

In Idle mode, press <

> and

select

Settings

→

Bluetooth

→

Activation

→

1. In Idle mode, press <

and select

Settings

→

Bluetooth

→

My devices

→

Search new device

2. Select a device.

3. Enter a Bluetooth PIN or the

other device’s Bluetooth PIN, if

it has one, and press <

When the owner of the other

device enters the same code,

pairing is complete.

Turn on

Bluetooth

Search for and

pair with a

Bluetooth

device

Step outside the phone

Quickly launch menus by number

1. Access an application,

Phonebook

File manager

, or

Calendar

2. Scroll to an item.

3. Press <

Options

> and select

Send via

→

Bluetooth

4. Select a device.

5. If necessary, enter the

Bluetooth PIN and press <

To receive data via Bluetooth, your

phone’s Bluetooth feature must be

active.

If necessary, press <

Yes

> to

confirm that you are willing to

receive.

Send data

Receive data

You can quickly access the text

message, alarm, calendar, and

convertor applications from the

dialling screen.



p. 75

1. For an alarm or scheduled item,

enter the time you want as 4-

digit in Idle mode.

For the convertor, enter the first

number you want to use.

2. Press one of the Navigation

keys.

You can access the following

applications:

Access

applications

Key Application

Up Alarm



p. 40

Down Convertor



p. 41

Left Text message



p. 45

Right Calendar



p. 65

Enter text

ABC, T9, Number, and Symbol mode

You can enter text in some features, such as

Messages, Phonebook, or Calendar, using ABC mode,

T9 mode, Number mode, and Symbol mode.

Changing the text input mode

• Press and hold [ ] to switch between T9 mode

() and ABC mode ().

• Press and hold [ ] to switch to Symbol mode

().

• Press [ ] to change case or switch to Number

mode ( ).

Using ABC mode

Press the appropriate key until the character you want

appears on the display.

(Creating an SMS message with GSM-alphabet encoding)

Characters in order displayed

Key Upper case Lower case

Enter text

Other ABC mode operations

• To enter the same letter twice or to enter a

different letter on the same key, wait for the cursor

to move to the right automatically or press [Right].

Then, enter the next letter.

• Press [ ] to insert a space.

• Press the Navigation keys to move the cursor.

•Press [

] to delete characters one by one. Press

and hold [

] to clear the display.

Using T9 mode

T9 is a predictive text input mode that allows you to

key in any character using single keystrokes.

Entering a word in T9 mode

1. Press [

] to [

]

to start entering a word. Press

each key once for each letter.

For example, press [

], [

], and [

] to

enter Hello in T9 mode.

T9 predicts the word that you are typing, and it

may change with each key that you press.

2. Enter the whole word before editing or deleting

characters.

3. When the word displays correctly, go to step 4.

Otherwise, press [

] to display alternative word

choices for the keys that you have pressed.

For example, Of and Me use [

] and [

4. Press [ ] to insert a space and enter the next

word.

Other T9 mode operations

• Press [

] to enter periods or apostrophes

automatically.

• Press [ ] to insert a space.

• Press the Navigation keys to move the cursor.

• Press [

] to delete characters one by one. Press

and hold [

] to clear the display.

Adding a new word to the T9 dictionary

This feature may not be available for some languages.

1. Enter the word that you want to add.

2. Press [

] to display alternative words for your key

presses. When there are no more alternative

words,

Spell

appears on the bottom line.

3. Press <

Spell

4. Enter the word you want using ABC mode and

press <

Add

Using Number mode

Number mode enables you to enter numbers.

Press the keys corresponding to the digits you want.

Using Symbol mode

Symbol mode enables you to insert symbols.

Call functions

Advanced calling features

Making a call

1. In Idle mode, enter the area code and phone

number.

2. Press [ ].

Making an international call

1. In Idle mode, press and hold [

]. The

character

appears.

2. Enter the country code, area code, and phone

number, then press [ ].

Redialling recent numbers

1. In Idle mode, press [ ] to display the list of

recent numbers.

2. Scroll to the number you want and press [ ].

To Press

display more symbols [Up] or [Down].

select a symbol the corresponding

number key.

clear the entered symbols [

insert the symbols <

• Press [

] to clear the last digit or press and hold

[

] to clear the whole display.

• Press and hold [ ] to enter a pause between

numbers.

Call functions

Making a call from Phonebook

Once you have stored a number in Phonebook, you

can dial the number by selecting it from Phonebook.



p. 31

You can also use the speed dial feature to assign your

most frequently called numbers to specific number

keys.



p. 34

You can quickly dial a number from the SIM card using

its location number assigned when stored.

1. In Idle mode, enter a location number and press

[].

2. Press [Left] or [Right] to scroll through other

numbers.

3. Press <

Dial

> or [ ] to dial the number you want.

Ending a call

Close the phone or press [ ].

Answering a call

When you receive an incoming call, the phone rings

and displays the incoming call image.

Press <

> or [ ] to answer the call.

Tips for answering a call

• When

Anykey

answer

is active, you can press

any key, except for <

Reject

> or [ ].



p. 76

• When

Active folder

is active, you can simply open

the phone.



p. 76

• Press <

Reject

> or [ ] to reject a call.

• Press and hold [ / ] to reject a call or mute the

ringer, depending on the

Volume key

setting.



p. 75

Viewing missed calls

If you have missed calls, the screen displays how

many calls you have missed.

1. Press <

View

2. If necessary, scroll through the missed calls.

3. Press [ ] to dial the number you want.

Call functions

Using the headset

Use the headset to make or answer calls without

holding the phone.

Connect the headset to the jack on the left side of the

phone. The button on the headset works as follows:

Options during a call

You can access a number of functions during a call.

Adjusting the volume during a call

Use [ / ] to adjust the earpiece volume during a call.

Press [ ] to increase the volume level and [ ] to

decrease the volume level.

Using the Speakerphone feature

Use the Speakerphone feature to talk and listen with

the phone a short distance away.

Press [ ] to activate the Speakerphone feature.

Press the key again to switch back to the earpiece.

Placing a call on hold/Retrieving

Press <

Hold

> or <

Retrieve

> to place a call on hold

or retrieve the call.

Making a second call

You can make another call if your network supports

this function.

1. Press <

Hold

> to put the call on hold.

2. Make the second call in the normal way.

3. Press <

Swap

> to switch between the calls.

4. Press <

Options

> and select

End

held

call

to end

the call on hold.

5. To end the current call, press [ ].

To Press

redial the last call the button and then press

and hold it again.

answer a call and hold the button.

end a call and hold the button.

Call functions

Answering a second call

You can answer an incoming call while already on the

phone, if your network supports this function and you

have activated the call waiting feature.



p. 80

1. Press [ ] to answer the call. The first call is

automatically put on hold.

2. Press <

Swap

> to switch between the calls.

3. Press <

Options

> and select

End

held

call

to end

the call on hold.

4. To end the current call, press [ ].

Using In-call options

Press <

Options

> to access the following options

during a call:

•

Voice clarity on

Voice clarity off

: remove

extraneous noise and increase call quality so that

the person with whom you are speaking can hear

you clearly even if you are in a noise place.

•

Mute

Unmute

: switch off the phone’s microphone

so that the other person on the phone cannot hear

you, or switch it back on.

•

Mute keys

Send keys

: switch the key tones on

or off.

•

Phonebook

: access the contact list.

•

Send DTMF

: send the DTMF (Dual tone multi-

frequency) tones as a group. The DTMF tones are

the tones used in phones for tone dialling,

sounding when you press the number keys. This

option is helpful for entering a password or an

account number when you call an automated

system, like a banking service.

•

Message

: create and send an SMS message or

access received messages.



p. 45

•

SIM service

: access special services, such as

news, weather forecasts, entertainment, and

location services, provided by your SIM card. This

option is available when you use a SIM card

supporting SIM AT menus.

If you are using the Speakerphone feature, you

must first deactivate it in order to use the Voice

Clarity feature.

To communicate with answering machines or

computerised telephone systems,

Send keys

must be selected.

•

Transfer

: transfer the currently active call to a

caller on hold. The two callers can talk to each

other, but you are disconnected from the call.

•

End held call

: disconnect the call currently on

hold.

•

Join

: set up a multi-party call by adding a caller

on hold to a currently active call. You can include

up to 5 people on a multi-party call.

•

Split

: have a private conversation with one multi-

party call participant. The other participants can

converse with each other. After the private

conversation, select

Join

to return both all private

participants to the multi-party call.

•

Remove

: disconnect one multi-party call

participant.

•

Switch to headset

Switch to phone

: switch the

call to a Bluetooth headset or hands-free car kit or

back to the phone.

Menu functions

All menu options listed

Call records

(Menu 1)

Use this menu to view the calls you have dialled,

received, or missed, and the length of calls. You can

also check the cost of your calls,

if your SIM card

supports this function.

To access this menu, press <

> in Idle mode and

select

Call records

Recent contacts

(Menu 1.1)

This menu displays the most recent calls dialled,

received, or missed.

Accessing a call record

1. Press [Left] or [Right] to move to another call

type.

2. Press [Up] or [Down] to scroll through the call list.

3. Press [ ] to view the details of a call, or [ ] to

dial a number.

Menu functions

Using call record options

While viewing call details, press <

Options

> to access

the following options:

•

Save as contacts

: save the number to

Phonebook.

•

Send message

: send an SMS or MMS message to

the selected number.

•

Delete

: delete the selected call record or all

records.

Missed calls

(Menu 1.2)

This menu displays the most recent calls you did not

answer.

Dialled calls

(Menu 1.3)

This menu displays the most recent calls you have

dialled.

Received calls

(Menu 1.4)

This menu displays the most recent calls you have

received.

Delete all

(Menu 1.5)

Use this menu to delete all of the records in each call

type.

1. Press [ ] to select the call types to be cleared.

2. Press <

Delete

3. Press <

Yes

> to confirm the deletion.

Call time

(Menu 1.6)

This menu displays the time log for calls made and

received. The actual time invoiced by your service

provider will vary.

•

Last

call

time

: check the length of your last call.

•

Total

sent

: check the total length of all the calls

you have dialled.

•

Total

received

: check the total length of all the

calls you have received.

•

Reset

timers

: reset the call timers. You need to

enter the phone password.

The password is preset to

00000000

. You can

change this password.



p. 84

Menu functions

Phonebook

(Menu 2)

Call costs

(Menu 1.7)

This network feature displays the cost of calls. This

menu is available only if supported by your SIM card.

Note that this is not intended to be used for billing

purposes.

•

Last

call

cost

: check the cost of your last call.

•

Total

cost

: check the total cost of all of your calls.

If the total cost exceeds the maximum cost set in

Set

max

cost

, you must reset the counter before

you can make another call.

•

Max

cost

: check the maximum cost limit set in

Set

max

cost

•

Reset

counters

: reset the cost counters.

•

Set

max

cost

: set the maximum cost authorised

for your calls.

•

Price/Unit

: set the price per unit that is applied

when the cost of your calls is calculated.

Phonebook

(Menu 2)

You can store phone numbers on your SIM card and in

your phone’s memory. The SIM card and phone’s

memory are physically separate, but they are used as

a single entity called Phonebook.

To access this menu, press <

> in Idle mode and

select

Phonebook

Contact list

(Menu 2.1)

Use this menu to search for numbers in Phonebook.

Finding an entry

1. Enter the first few letters of the name that you

want to find.

2. Select the name from the list.

3. Scroll to a number and press [ ] to dial, or press

[ ] to edit contact information.

Using Phonebook options

While viewing contact details, press <

Options

> to

access the following options:

•

Edit

: edit contact information.

Menu functions

•

Send message

: send an SMS or MMS message to

the selected number, or an e-mail to the selected

address.

•

Copy

: copy the contact to the phone’s memory, to

the SIM card, or the FDN list.

•

Send via

: send the contact via SMS, MMS, e-mail,

or Bluetooth.

•

Delete

: delete the selected contact.

•

Print via Bluetooth

: print the contact information

via a Bluetooth-compatible printer. Some printers

may not be compatible with the phone.

FDN list

(Menu 2.2)

Use this menu to create a list of contacts to be used in

FDN (Fixed Dialling Number) mode, in which the

phone allows outgoing calls only to the specified

phone numbers, if your SIM card supports this

feature. You can activate FDN mode in the

FDN mode

menu.



p. 84

Adding a contact

1. From the FDN list, press <

Options

> and select

Add

2. Enter your PIN2 and press <

3. Enter information about the contact:

•

Name

: assign a name.

•

Phone number

: add a number.

•

Location

: assign a location number.

4. Press <

Save

Using contact options

You can access contact options by pressing

Options

> in Contact list.

Add new contact

(Menu 2.3)

Use this menu to add a new contact to Phonebook.

Storing a number in the phone’s memory

1. Select

Phone

2. Change the settings or enter information about the

contact.

•

First name

Last name

: assign a name.

Menu functions

Phonebook

(Menu 2)

•

Mobile

Home

Office

Fax

Other

: add a

number in any type.

•

: assign an e-mail address.

•

Graphic ID

: assign an image to alert you to a

call from the person.

•

Alert

: assign a ringtone to alert you to a call

from the person.

•

Group

: assign the contact to a caller group.

•

Notes

: add a memo about the person.

3. Press <

Save

> to save the contact.

Storing a number on the SIM card

1. Select

SIM

2. Enter information about the contact.

•

Name

: assign a name.

•

Phone number

: add a number.

•

Location

: assign a location number.

3. Press <

Save

> to save the contact.

Group

(Menu 2.4)

Use this menu to organise your contacts in caller

groups.

Adding members to a caller group

1. Select a group.

2. Press <

Add

> and select a contact.

3. To add more contacts, press <

Options

> and

select

Add

→

a contact.

Managing caller groups

While viewing the group list, press <

Options

> to

access the following options:

•

View

: display the members of the selected group.

•

Add

: add a new group.

•

Edit

: change the group properties.

•

Send message

: send an SMS, MMS, or e-mail

message to the group members you want.

•

Delete

: delete the selected group. Group

members, however, will not be deleted from

Phonebook.

To assign a caller ID image, ringtone, or group,

the contact must be saved to the phone’s

memory.

Menu functions

Speed dial

(Menu 2.5)

Use this menu to assign a speed dial number (2 to 9)

for 8 of your most frequently called numbers.

Assigning speed dial numbers

1. Select a key location from

. Key

is reserved

for your voicemail server.

2. Select a contact from the contact list.

3. Select a number, if the contact has more than one

number.

Managing speed dial entries

From the Speed dial screen, press <

Options

> to

access the following options:

•

Add

: assign a number to an unassigned key.

•

View

: check the name and number assigned to a

key.

•

Change

: assign a different number to a key.

•

Remove

: clear the speed dial setting for a key.

Dialling speed dial entries

In Idle mode, press and hold the appropriate key.

My name card

(Menu 2.6)

Use this menu to create a name card and send it to

other people.

Saving your name card

The procedure for creating your name card is the

same as the one for saving a phone number in the

phone’s memory.



p. 32

Using name card options

After saving your name card, press <

Options

> to

access the following options:

•

Edit

: edit the name card.

•

Send via

: send the name card via SMS, MMS,

e-mail, or Bluetooth.

•

Exchange namecard

: exchange name cards with

another person via Bluetooth.

•

Remove

: delete the name card.

•

Print via Bluetooth

: print the name card

information via a Bluetooth-compatible printer.

Some printers may not be compatible with the

phone.

Menu functions

Phonebook

(Menu 2)

Own number

(Menu 2.7)

Use this menu to check your phone numbers, or to

assign a name to each of the numbers. Changes made

here do not affect the actual subscriber numbers on

your SIM card.

Management

(Menu 2.8)

Use this menu to manage Phonebook entries.

•

Default saving

: select a default memory location

for saving contacts. If you select

Ask on saving

the phone will ask you to select a memory location

each time you save a number.

•

Copy all

: copy all of the contacts stored on the

SIM card to the phone’s memory, or vice versa.

•

Sort by contacts

: sort your contacts by the first

name or last name.

•

Delete all

: delete all of the contacts from your

phone’s memory, your SIM card, or both.

•

Memory status

: check the number of contacts

you have stored in the phone’s memory and on the

SIM card.

Service number

(Menu 2.9)

Use this menu to view the list of Service Dialling

Numbers (SDN) assigned by your service provider,

including emergency numbers and numbers for

directory enquiries. This menu is available if your SIM

card supports SDN.

1. Scroll to the number you want and press <

View

2. Press <

Dial

> or [ ].

Menu functions

Applications

(Menu 3)

Use this menu to play Java games and listen to the FM

radio. You can also use convenient features, such as a

voice recorder, alarm clock, calculator, converter and

stopwatch.

To access this menu, press <

> in Idle mode and

select

Applications

Voice recorder

(Menu 3.1)

Use this menu to record voice memos. A voice memo

can be up to one hour long.

Recording a voice memo

1. Press [ ] to start recording.

2. Speak into the microphone.

Press [ ] to pause or resume recording.

3. Press <

Save

> or [Down] to end recording. The

voice memo is saved automatically.

4. Press [ ] to review the voice memo, or [Up] to

record a new memo.

Playing a voice memo

1. From the voice recorder screen, press <

Options

and select

Go to voice list

2. Select a voice memo.

During playback, use the following keys:

Using the voice recorder options

From the voice recorder screen, press <

Options

> to

access the following options:

•

Record

: record a new voice memo.

•

Settings

: customise the default settings for the

voice recorder.

Recording time

: select a recording time.

Key Function

Pauses or resumes playback.

Left Moves backward in a file.

Right Moves forward in a file.

/ Adjusts the volume.

Down Stops playback.

Menu functions

Applications

(Menu 3)

Volume

: select a volume level.

Default name

: change the default prefix of file

names.

•

Go to voice list

: access the voice list.

Java world

(Menu 3.2)

Use this menu to access the embedded Java games

and downloaded Java applications.

Playing a game

Select a game from the game list and follow the

onscreen instructions. The procedure may differ from

game to game.

Using Java application options

From the application list, press <

Options

> to access

the following options:

•

Start

: launch the selected application.

•

Delete

: delete the selected application.

•

Properties

: access the application properties.

•

Permission

: set permission settings for services

charging you additional costs, such as network

access and SMS.

•

Protection

: lock the application to protect it from

being deleted, or unlock the application.

•

Upgrade

: upgrade the application to the latest

version, except for embedded games.

•

Send information via SMS

: send the URL

containing the application via SMS, except for

embedded games.

•

Memory status

: access memory information for

applications.

•

Network settings

: customise a connection profile

to be used for applications requiring network

access. The following options are available:

APN

: enter the access point name of the network

gateway.

: enter the user ID.

Password

: enter the password.

Proxy

: select whether or not the phone uses a

proxy server to launch the web browser.

Proxy settings

: customise the following proxy

settings:

When the proxy is set to

Enable

Menu functions

IP address

: enter the gateway address.

Port

: enter the port number.

When the proxy is set to

Disable

DNS1

: enter the primary address.

DNS2

: enter the secondary address

FM radio

(Menu 3.3)

Use this menu to access the FM radio on your phone.

First, you must connect your phone with the headset,

which serves as a radio antenna.

Turning on and listening to the radio

1. Plug the connector of a headset into the jack on

the left side of the phone.

2. From the FM radio screen, press <

Options

> and

select

FM radio on

3. Press [Left] or [Right] to find the radio station you

want.

You can also press and hold [Left] or [Right] to

scan through available radio stations.

4. To exit the

FM radio

menu without turning off the

radio, press [

This enables you to access other functions while

listening to the radio.

Setting up a radio station list

1. Connect the headset to the phone and turn on the

radio.

2. Press <

Options

> and select

Add

3. Enter a title for the station you want and press

[Down].

4. Enter the frequency of the station and press

Save

5. Select an empty location.

6. Repeat from step 2 to store other stations.

To listen to the stored stations, press [Up] or

[Down] from the FM Radio screen.

Turning off the radio

To turn off the radio, press <

Options

> from the radio

screen and select

FM radio off

or disconnect the

headset.

When you listen to the FM radio with the phone

closed, you can lock

[ / ] to keep accidental

presses by pressing and holding [

Menu functions

Applications

(Menu 3)

Using radio options

On the FM radio screen, press <

Options

> to access

the following radio options:

•

FM radio on

FM radio off

: turn the radio on or

off.

•

Add

: add a radio station.

•

Edit

: edit the name or frequency for the station.

•

Self-tuning

: let the phone automatically scan

through and save available radio frequencies.

•

Remove

: remove the selected station or all

stations.

•

Pop-up alert

: set the phone to alert you to listen

to the radio at a specific time. When the pop-up

notification appears on the screen, press <

Listen

to turn on the specified radio station.

•

Speaker on

Earphone on

: change the audio

mode to the phone’s speaker or headset.

•

Settings

: select the radio volume.

World time

(Menu 3.4)

Use this menu to find out what time it is in another

part of the world.

Viewing world time

1. From the world map, press [Left] or [Right] to

scroll to the city you want on the upper line ( ).

As the time line moves, the time and date of the

given zone displays.

2. To set another time zone, press [Down] to move to

the lower line ( ).

3. Press [Left] or [Right] to scroll to the city you

want.

4. Press [ ] to save the time zone.

Applying daylight savings time

1. From the world map, press <

Options

> and select

Set daylight saving time

2. Press [ ] to select the time zones you want.

3. Press <

Save

Menu functions

Alarm

(Menu 3.5)

Use this menu to set alarms. The alert type for a

normal alarm corresponds to the call alert type

settings. A wake-up alarm is not affected by your

sound settings.

Setting an alarm

1. Select the type of alarm.

2. Set each alarm option:

•

Alarm

: activate the alarm.

•

Alarm time

: enter the time for the alarm to

ring.

•

AM/PM

: set

in 12-hour format.

•

Alarm day

: select the days for the alarm.

•

Alarm tone

: select an alarm tone.

3. Press <

Save

Stopping an alarm

• For a non-wake-up alarm, press any key.

• For a wake-up alarm, press <

> or [ ].

Press any key, except <

> and [ ], to cause

it to sound again after 5 minutes. You can do this a

maximum of 5 times.

Deactivating an alarm

1. Select the alarm you want to deactivate.

2. Select

Off

on the

Alarm

lines.

Setting the alarm to sound even if the phone

is off

From the Alarm screen, select

Auto power

→

If the phone is off when it is time for the alarm to

sound, the phone switches on and sounds the alarm.

Calculator

(Menu 3.6)

Use this menu to perform basic arithmetic functions,

such as addition, subtraction, multiplication, and

division.

1. Enter the first number.

•Press <

.()

> to insert a decimal point or

bracket.

•

Press

[] or []

to move the cursor.

2. Press one of the Navigation keys to access the

math function you want.

3. Enter the second number.

4. Press [ ] to view the result.

Menu functions

Applications

(Menu 3)

5. If necessary, repeat from step 2 to continue the

calculation.

Convertor

(Menu 3.7)

Use this menu for common conversions, such as

currency and temperature.

Performing a conversion

1. Select a converter.

2. Press [Left] or [Right] to select the original unit

and press [Down].

3. Enter the value to be converted and press [Down].

• Press [ ] to insert a decimal point.

• Press [ ] to change the temperature to above

zero (+) or below zero (-).

4. Press [Left] or [Right] to select the unit to which

you want to convert.

The equivalent value for the amount you entered

displays.

Using converter options

Press <

Options

> to access the following options:

•

Clear

: clear the current values.

•

Reverse

: reverse the conversion.

•

Currency rates

: edit the currency rate list.

Timer

(Menu 3.8)

Use this menu to set a period of time for the phone to

count down. The phone will sound an alarm when the

specified period of time has expired.

Starting the timer

1. Press <

Set

2. Enter the length of time you want to count down

and press <

3. Press [ ] to start counting down.

Stopping the timer

• Press any key when the timer rings.

• Press [ ] on the Timer screen to stop the timer

before it rings.

Stopwatch

(Menu 3.9)

Use this menu to measure elapsed time. The

maximum time is 10 hours.

1. Press [ ] to start the stopwatch.

Menu functions

2. Press [ ] to check an interval. You can repeat

this step for a total of 4 intervals.

SIM AT

(Menu 3.10)

This menu is available if you use a SIM AT card that

supports SIM Application Tool kit menus and provides

additional services, such as news, weather, sports,

entertainment, and location services. Available

services may vary, depending on your service

provider’s plans. For details, see your SIM card

instructions or contact your service provider.

Browser

(Menu 4)

The Wireless Application Protocol (WAP) browser on

your phone allows you to access the wireless web.

From the wireless web, you can access up-to-date

information and a wide variety of media content, such

as games, wallpapers, ringtones, and music files.

To access this menu, press <

> in Idle mode and

select

Browser

Home

(Menu 4.1)

Use this menu to connect your phone to the network

and load the homepage of the wireless web service

provider. You can also press [ ] in Idle mode.

Navigating the web browser

Using browser menu options

From the web page, press [ ] or select on the top

of screen.

•

Back

: go back to the previous page.

•

Home

: return to the homepage.

•

Exit

: exit the web browser.

To Press

scroll through browser

items [Up] or [Down].

select a browser item [ ] or < >.

return to the previous

page <

Back

> or [

return to the homepage and hold [

Menu functions

Browser

(Menu 4)

•

Reload

: reload the current page with updated

information.

•

Show URL

: display the URL address of the current

web page.

•

About...

: access version and copyright information

about the browser.

Using web page options

From any web page, press [ ] to access the following

options:

•

Goto URL

: enter a URL address manually.

•

Bookmarks

: switch to the

Bookmarks

menu.

•

Messages

: check the messages stored in the

Messages

folder. You can also create and send a

new SMS message.

•

File manager

: switch to the

File manager

menu.

Exiting the browser

Press [ ] to end the network connection and exit the

browser.

Bookmarks

(Menu 4.2)

Use this menu to save URL addresses in order to

quickly access web pages.

Adding a bookmark

1. Select an empty location.

2. Enter a title for the bookmark and press [Down].

3. Enter a URL address and press [ ].

Accessing a bookmarked page

Selecting a bookmark item launches the web browser

and accesses the associated web page.

Using bookmark options

After saving an item, press <

Options

> to access the

following options:

•

: access the bookmarked web page.

•

Edit

: edit the URL address and title of the

bookmark.

•

Delete

: delete the selected bookmark or all

bookmarks.

Menu functions

Goto URL

(Menu 4.3)

Use this menu to manually enter a URL address and

access the associated web page.

Clear cache

(Menu 4.4)

Use this menu to clear information stored in the cache,

which is the temporary memory that stores the web

pages you have recently accessed.

Profile settings

(Menu 4.5)

Use this menu to set up servers for the web browser.

Contact your service provider for details about your

setting options.

For each server, the following options are available:

•

Profile

name

: assign a name to the server profile.

•

Home

URL

: set the address of your homepage.

•

Bearer

: select a bearer for each type of network

address accessed.

•

Proxy

: select whether or not the phone uses a

proxy server to launch the web browser.

•

GPRS settings

: customise the following GPRS

network settings:

When the proxy is set to

Enable

Proxy IP

: enter the proxy IP address.

Proxy port

: enter the proxy port number.

APN

: enter the access point name of the GPRS

network gateway.

: enter the user ID.

Password

: enter the password.

When the proxy is set to

Disable

DNS1

: enter the primary address.

DNS2

: enter the secondary address

APN

: enter the access point name of the GPRS

network gateway.

: enter the user ID

Password

: enter the password

•

GSM settings

: customise the following GSM

network settings:

When the proxy is set to

Enable

Proxy IP

: enter the proxy IP address.

Menu functions

Messages

(Menu 5)

Proxy port

: enter the proxy port number.

Dial number

: enter the PPP server phone number.

: enter the user ID.

Password

: enter the password.

Data call type

: select a data call type.

When the proxy is set to

Disable

DNS1

: enter the primary address.

DNS2

: enter the secondary address.

Dial number

: enter the PPP server phone number.

: enter the user ID.

Password

: enter the password.

Data call type

: select a data call type.

Current profile

(Menu 4.6)

Use this menu to select a connection profile for

accessing the web browser.

Messages

(Menu 5)

Use the

Messages

menu to send and receive text

messages, multimedia messages, and e-mails. You

can also use push message and cell broadcast

message features.

To access this menu, press <

> in Idle mode and

select

Messages

Create new message

(Menu 5.1)

Use this menu to create and send messages.

Text message

(Menu 5.1.1)

Short Message Service (SMS) allows you to send or

receive text messages that may include simple

pictures, animated images, and melodies.

1. Enter your message.

The maximum number of characters allowed in a

message varies by service provider. If your

message exceeds the maximum number of

characters, the phone will split the message.

Menu functions

2. Press <

Options

> to access the following options

for creating a message:

•

Insert

: add a template, Phonebook entry, or

bookmark.

•

Add picture

Add animation

Add melody

attach a simple image, animated image, or

melody.

•

Attach

: attach a Phonebook entry as a name

card or calender data as a data format

attachment.

•

Save to

: save the message in another folder.

•

Language select

: change the language used

in T9 input mode.

•

Text style

: change the text attributes.

3. When you have finished, press <

Options

> and

select

Save and send

Send only

4. Enter a destination number.

To send the message to more than one recipient,

fill in additional destination fields.

5. Press [ ] to send the message.

Multimedia message

(Menu 5.1.2)

Multimedia Message Service (MMS) delivers messages

containing a combination of text, image, video, and

audio, from phone to phone or from phone to e-mail.

1. Select the

Subject

line.

2. Enter the message subject and press [ ].

3. Select the

Picture & Video

Sound

line and add

an image, a video, or a sound file.

4. Select the

Message

line.

5. Enter the message text.

Press <

Options

> to access the following options:

•

Insert

: add a template, Phonebook entry, or

bookmark.

•

Save to

: save the message in another folder.

• The maximum size allowed for a message can

differ, depending on your service provider.

• Depending on the file type or DRM (Digital

Rights Management) system, some files may

not be able to be forwarded.

Menu functions

Messages

(Menu 5)

•

Text style

: change the text attributes.

•

Language select

: change the language used

in T9 input mode.

6. When you have finished, press [ ].

7. After adding items, press <

Options

> to access

the following options for editing the message:

•

Edit

: edit the subject or text of your message.

•

Preview

: view the message as it will be shown

on the recipient’s phone.

•

Change image

Change video

Change

sound

: replace an added item.

•

Add page

: add pages. Move to each page by

pressing [Left] or [Right].

•

Delete page

: delete an added page.

•

Edit page

: change the duration of page display

or move the page to the next or previous page.

•

Attach

: attach name cards or calender data as

data format attachments.

•

Remove subject

Remove media

Remove

sound

Remove message

Remove

: remove

an added item.

8. When you have finished, press <

Options

> and

select

Send

9. Enter a phone number or e-mail address.

To send the message to more than one recipient,

fill in additional destination fields.

10.Press [ ] to send the message.

(Menu 5.1.3)

You can create and send e-mails that include text,

audio, and images. To use this feature, you need to

subscribe to an e-mail service and set up your e-mail

account and profile.



p. 58

1. Select the

Subject

line.

2. Enter the subject of your e-mail and press [ ].

3. Select the

Message

line.

4. Enter the e-mail text.

Press <

Options

> to access the following options:

•

Insert

: add a template, Phonebook entry, or

bookmark.

•

Save to

: save the message in another folder.

•

Language select

: change the language used

in T9 input mode.

Menu functions

5. When you have finished, press [ ].

6. Select the

File attach

line and select one of the

following options to add files:

•

Add image

Add videos

Add sounds

Add

music

: add media files stored in the phone’s

memory.

•

Other files

: add document files stored in the

Other files

folder.

•

Attach

: attach name cards or calender data as

data format attachments.

7. After adding items, press <

Options

> to access

the following options to edit the e-mail:

•

Edit

: edit the subject or text.

•

Remove subject

Remove message

: clear

the subject or text.

•

Remove

: delete the selected attachment or all

attachments.

•

Remove all attachments

: delete all

attachments.

8. When you have finished, press <

Options

> and

select

Send

9. Enter an e-mail address.

To send the e-mail to more than one recipient, fill

in additional destination fields.

10.Press [ ] to send the e-mail.

My messages

(Menu 5.2)

Use this menu to access messages you have received,

sent, saved, or which have failed in sending.

Inbox

(Menu 5.2.1)

This folder stores all of the messages you have

received, except for e-mails.

Viewing a message

The following icons may appear on the message list to

show the message type:

• SMS or delivery report for your sent messages

• MMS

• MMS notification ( : Being retrieved,

: Failed to retrieve)

Depending on the file type or DRM (Digital

Rights Management) system, some files may

not be able to be forwarded.

Menu functions

Messages

(Menu 5)

• Push message from web servers.

• Configuration message, containing network

parameters from your service provider.

Using message options

While viewing a message, press <

Options

> to access

the following options:

SMS messages

•

Reply via

: reply to the sender via SMS or MMS.

•

Forward

: forward the message to other people.

•

Delete

: delete the message.

•

Move to phone

Move to SIM

: move the

message between the SIM card and the phone’s

memory.

•

Add to block list

: add the sender’s number to the

Block list to reject the messages from the sender.

•

Cut address

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Cut media

: save media content from the message

to your phone’s memory.

•

Print via Bluetooth

: print the message via a

Bluetooth-compatible printer. Some printers may

not be compatible with the phone.

•

Protection

: protect the message from being

deleted.

MMS messages

MMS notifications

•

Retrieve

: retrieve the MMS message from the

MMS server.

•

Reply via SMS

: reply to the sender via SMS.

•

Reply via MMS to

: reply to the sender or all

recipients via MMS.

•

Forward

: forward the message to other people.

•

Delete

: delete the message.

•

Cut

address

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Cut media

: save media content from the message

to your phone’s memory.

• Depending on the DRM (Digital Rights

Management)

system, messages having web

content may not be

able to be forwarded.

• A

icon next to a message means that the

message is of high priority. A grey-coloured

message icon indicates low priority.

Menu functions

•

Properties

: access the message properties.

Delivery reports

•

Delete

: delete the report.

Configuration messages

•

Install

: apply the configuration specified in the

message to your phone.

•

Cut

address

: extract URLs, e-mail addresses, or

phone numbers from the message.

•

Delete

: delete the message.

•

Protection

: protect the message from being

deleted.

Push messages

•

Go to URL

: connect to the URL specified in the

message.

•

Delete

: delete the message.

•

Cut address

: extract URLs, e-mail addresses, or

phone numbers from the message.

Drafts

(Menu 5.2.2)

This folder stores messages you have saved to send at

a later time.

When you select an SMS or e-mail message, it opens

in Edit mode so that you can edit and/or send the

message.

When you select an MMS message, it opens in Preview

mode as would a message from the Inbox. To edit the

MMS message, press <

Options

> and select

Edit

Outbox

(Menu 5.2.3)

This folder stores messages that the phone is

attempting to send or has failed to send.

The following icons are available to show the message

status:

• SMS message failed to send

• MMS message being sent

• MMS message being retried

• MMS message failed to send

• E-mail being sent

• E-mail failed to send

Menu functions

Messages

(Menu 5)

While viewing a message, press <

Options

> to access

the following options:

•

Open file

: open the selected file.

•

Save file

: save the selected file.

•

Send again

: retry sending the message.

•

Forward

: forward the message to other people.

•

Delete

: delete the message.

•

Move to phone

Move to SIM

: move the

message between the SIM card and the phone’s

memory.

•

Print via Bluetooth

: print the message via a

Bluetooth-compatible printer. Some printers may

not be compatible with the phone.

•

Protection

: protect the message from being

deleted.

•

Properties

: access the message properties.

Sentbox

(Menu 5.2.4)

This folder stores messages that you have sent.

While viewing a message, press <

Options

> to access

the following options:

•

Open file

: open the selected file.

•

Save file

: save the selected file.

•

Forward

: forward the message to other people.

•

Delete

: delete the message.

•

Move to phone

Move to SIM

: move the

message between the SIM card and the phone’s

memory.

•

Print via Bluetooth

: print the message via a

Bluetooth-compatible printer. Some printers may

not be compatible with the phone.

•

Protection

: protect the message from being

deleted.

•

Properties

: access the message properties.

Email box

(Menu 5.2.5)

This folder stores e-mails that you have received.

Viewing an e-mail

1. Select an e-mail account.

2. Press <

Select

> when

Check new mail

displays,

or press <

Options

> and select

Retrieve

. The

phone checks the e-mail server and downloads

new e-mails.

Menu functions

The following icons may appear on the list to show

the e-mail status:

• Retrieved from the server

• Being retrieved

• Failed to retrieve

3. Select an e-mail or a header.

4. Press [ / ] to view other pages in the

e-mail.

Press and hold [ / ] to move to the first or last

page in the e-mail.

5. Press [ ] or [ ] to view the previous or next

e-mail.

Using e-mail options

While viewing the e-mail or header, press <

Options

to access the following options:

•

Retrieve

: retrieve the body of the e-mail from the

e-mail server.

•

Open file

: open the selected file.

•

Save file

: save the selected file.

•

Reply to

: send a reply to the sender or to the

sender and all other recipients.

•

Forward

: forward the e-mail to other people.

•

Delete

: delete the e-mail.

•

Add to block list

: add the sender’s e-mail

address or subject to the Block list to reject

e-mails from that address or containing that

subject.

•

Cut address

: extract URLs, e-mail addresses, or

phone numbers from the e-mail.

•

Cut attachment

: save the attached files from the

e-mail to your phone’s memory.

•

Print via Bluetooth

: print the e-mail via a

Bluetooth-compatible printer. Some printers may

not be compatible with the phone.

•

Protection

: protect the e-mail from being deleted.

•

Properties

: access the e-mail properties.

icon next to a message means that the

message is of high priority. A grey-coloured

message icon indicates low priority.

Menu functions

Messages

(Menu 5)

My folders

(Menu 5.2.6)

Use this menu to view the messages you have moved

to this folder using the

Move to my folder

option

while viewing a message list.

Templates

(Menu 5.3)

Use this menu to make and use templates of

frequently used messages.

Text template

(Menu 5.3.1)

You can create SMS templates with the sentences you

use frequently so that you can retrieve and insert

them when composing an SMS, MMS, or e-mail

message.

Creating a template

1. Select an empty location.

2. Enter a message and press [ ].

Using template options

From the template list, press <

Options

> to access

the following options:

•

Edit

: edit the selected template.

•

Send message

: create and send a new message.

•

Delete

: delete the selected template.

MMS template

(Menu 5.3.2)

You can access embedded MMS templates or ones you

have saved so that you can use them in composing an

MMS message.

Creating a template

1. Press <

Options

> and select

Add new

2. Create a template as you would when creating a

MMS message.

3. Press <

Options

> and select

Save to

→

Templates

Using template options

From the template list, press <

Options

> to access

the following options:

•

View

: open the selected template.

•

Send message

: send the selected message.

•

Edit

: edit the selected template.

•

Add new

: add a new template.

•

Delete

: delete the selected template or all

templates, except for the embedded ones.

Menu functions

Delete all

(Menu 5.4)

Use this menu to delete messages in each message

folder all at once.

1. Press [ ] to select the message folders to be

cleared.

2. Press <

Delete

3. Press <

Yes

> to confirm the deletion.

Settings

(Menu 5.5)

Use this menu to set up various options for using the

messaging service.

Text message

(Menu 5.5.1)

You can configure SMS settings.

•

Send settings

: set up the options for sending

SMS messages:

Reply path

: allow recipients to reply to you

through your SMS server.

Delivery report

: set the network to inform you

when your messages have been delivered.

Character support

: select a character encoding

type. If you select

Auto

, the phone switches the

encoding type from GSM-alphabet to Unicode if

you enter a Unicode character. Use of Unicode

encoding will reduce the maximum number of

characters in a message to about half. If this menu

is not shown, your phone provides automatic

character encoding by default.

Validity period

: set the length of time your

messages are stored in the SMS server.

Message type

: set the default message type. The

network can convert the messages into the

selected format.

Service centre

: store or change the number of

your SMS server.

•

Block number

: store the phone numbers from

which you want to reject messages.

Multimedia message

(Menu 5.5.2)

You can configure MMS settings.

•

Send settings

: set up the options for sending

MMS messages:

Menu functions

Messages

(Menu 5)

Delivery report

: set the network to inform you

when your messages have been delivered.

Address hiding

: set your address to be hidden

from the recipient’s phone.

Read reply

: send a read-reply request along with

your messages.

Priority

: set the priority level of messages.

Expiry date

: set the length of time messages are

stored in the MMS server.

Delivery after

: set a time delay before messages

are sent.

•

Receive settings

: set up the options for receiving

MMS messages:

Anonymous reject

: reject messages from

unknown senders.

Advert allowed

: accept advertisements.

Report allowed

: set the network to inform the

sender when a message has been delivered to you.

Home reception

: determine if your phone

retrieves new messages automatically when you

are in your home service area.

Roaming reception

: determine if your phone

retrieves new messages automatically when you

are roaming on another network.

Reception within home network or abroad has the

following options:

Automatic

: the phone automatically retrieves

messages from the server.

Reject

: the phone rejects all messages.

Manual

: the phone displays notifications. Use

the

Retrieve

option to manually download new

messages.

•

MMS profiles

: configure required network

settings for MMS.

Current profile

: select a profile.

Profile settings

: customise the options for each

profile:

Profile name

: assign a name to the MMS profile.

Server URL

: enter the address of your MMS

server.

Proxy

: connect to the GPRS network using the

proxy server.

Menu functions

GPRS settings

: customise the settings required

for connecting to the GPRS network.

when the proxy is set to

Enable

IP address

: enter the gateway address.

Port

: enter the port number.

APN

: enter the access point name used for the

address of the GPRS network.

: enter the user ID.

Password

: enter the password.

when the proxy is set to

Disable

DNS1

: enter the primary address.

DNS2

: enter the secondary address.

APN

: enter the access point name used for the

address of the GPRS network.

: enter the user ID.

Password

: enter the password.

Version

: select an available OMA version and

maximum size limit for sending or receiving

messages.

•

Block number

: set the Block number list to reject

MMS messages from specific phone numbers.

•

Message class

: set up the options creating MMS

messages:

Message class

: select the type of message

content you will add or how the message size.

Image basic

: you can add any type of item,

except for video, of up to 30 KB.

Image rich

: you can add any type of item,

except for video, of up to 100 KB.

Video basic

: you can add any type of item of up

to 100 KB.

Video rich

: you can add any type of items of up

to 300 KB.

Text

: you can add only text of up to 30 KB.

Depending on your service provider, it may not

be possible to support the maximum limit

300KB. In this case, try again after changing

the setting to 100KB.

Menu functions

Messages

(Menu 5)

Creation mode

: select an MMS creation mode.

Warning

: you can create a message with any

type of content and of any size, but the phone

will inform you when the content and size have

exceeded the maximum.

Free

: you can create a message with any type of

contents and of any size.

Restricted

: you can create a message with the

type of content and size specified in

Message

class

(Menu 5.5.3)

You can configure default e-mail settings.

•

Send settings

: set up the options for sending

e-mails:

Send copy to self

: send a copy of your e-mails to

your e-mail account.

Delivery confirm

: set the network to inform you

when your e-mails have been delivered.

Read confirm

: send a read-reply request along

with e-mails.

Priority

: select the priority level of e-mails.

Include signature

: attach your name, phone

number or a simple memo to your e-mails.

Edit name

: edit the name in your signature.

Edit telephone number

: edit the phone number

in your signature.

Edit note

: edit the tag line in your signature.

•

Receive settings

: set up the options for receiving

e-mails:

Check interval

: determine how often the phone

checks the server for incoming e-mails. If you

select

Not used

, use the

Check new mail

feature

to receive new e-mails manually.

Read reply

: determine whether or not the phone

sends a read-reply for incoming e-mails. If you

select

Announce

, the phone asks you to send a

read-reply.

Retrieve option

: set whether the phone

downloads e-mail headers only or e-mail headers

and bodies both.

You cannot change e-mail profile and account

settings while an e-mail is being sent or retrieved.

Menu functions

Delete option

: determine whether e-mails are

deleted immediately or the next time you connect

to the server.

Reject if over

: determine the maximum size for

incoming e-mails. Your phone will reject

e-mails that exceed the specified size.

Leave a copy of messages on the server

: leave

copies of e-mails on the e-mail server after

retrieving.

•

Email account

: set up an e-mail account and

select an account to be used.

Current account

: select an account.

Account settings

: configure e-mail accounts

using different e-mail servers. Press <

Options

and select

Create

In use

: select this option to use the account and

to display the account in the

Email box

folder.

Account name

: enter a name for the currently

selected account.

To access the following options, press [ ], or

press <

Options

> and select

User name

: enter a user name.

Email address

: enter your e-mail address.

Reply address

: enter your e-mail address to be

used when the recipient sends a reply.

To access the following options, press [ ], or

press <

Options

> and select

SMTP server

: enter the IP address or host name

of the outgoing e-mail server.

SMTP port

: enter the SMTP port number.

SMTP user ID

: enter the SMTP user ID.

SMTP password

: enter the SMTP password.

Retrieve server type

: select the protocol for

the incoming e-mail server. The remaining

options depend on the protocol type setting.

When the protocol type is

POP3

POP3 server

enter the IP address or host name

of the server that receives your e-mail.

POP3 port

: enter the POP3 port number.

Menu functions

Messages

(Menu 5)

Same ID and password

: select to use the same

SMTP user ID and password with incoming

server.

POP3 user ID

: enter the POP3 user ID.

POP3 password

: enter the POP3 password.

APOP login

: connect to the server by using the

APOP login scheme.

When the protocol type is

IMAP4

IMAP4 server

: enter the IP address or host

name of the server that receives your e-mail.

IMAP4 port

: enter the IMAP4 port number.

Same ID and password

: select to use the same

SMTP user ID and password with incoming

server.

IMAP4 user ID

: enter the IMAP4 user ID.

IMAP4 password

: enter the IMAP4 password.

Include attachments

: select this option to

receive attachments with e-mails.

Email retrieval limit

: set the number of

headers you will retrieve from the server.

When you have finished, press <

Options

> and

select

Save

or press [ ].

•

Email profile

: select a connection profile to be

used for e-mail services.

Current profile

: select a profile.

Profile settings

: configure up to five e-mail

profiles. For each profile, the options are required

to connect to the GPRS network:

Profile name

: enter a name for the e-mail

profile.

APN

: enter the access point name used for the

GPRS network address.

: enter the user ID.

Password

: enter the password.

DNS1

: enter the primary address.

DNS2

: enter the secondary address.

•

Block list

: specify e-mail addresses or subjects

you want to reject.

You cannot change e-mail profile settings while an

e-mail is being sent or retrieved.

Menu functions

Push message

(Menu 5.5.4)

You can change the settings for receiving push

messages from the wireless web server.

•

Receive

: set how your phone receives push

messages.

•

Service centre

: enter the address of the server

from which you want to receive push messages.

roadcast messages

(Menu 5.6)

The Cell Broadcast service delivers short messages on

various topics, such as weather, sports, or traffic.

Use this menu to change the settings for the service

and to access broadcast messages.

•

Read

: open received messages.

The

Temporary

box saves network messages until

the phone is switched off.

The

Archive

box when a text

notification appears.

•

Receive

: enable or disable the reception of

broadcast messages.

•

Channel

: specify the channels from which you

receive broadcast messages.

When you select

Respective channels

, you can

set up a list of active CB channels.

•

Language

: select the languages in which

broadcast messages display.

Please contact your service provider for details.

Memory status

(Menu 5.7)

Use this menu to view the amount of memory

currently in use in each folder.

Menu functions

File manager

(Menu 6)

File manager

(Menu 6)

The

File manager

menu allows you to access images,

videos, music files, and sound files stored in the

phone’s memory.

To access this menu, press <

> in Idle mode and

select

File manager

Images

(Menu 6.1)

This menu displays photos you have taken and images

you have downloaded, received in messages, or

imported from your computer.

Viewing an image

1. Select an image folder.

2. Select an image.

Viewing a slide show

You can view your photos as a slide show, a sequential

presentation of each photo in the current folder.

1. Select

Photos

2. Press <

Options

> and select

Slide show

3. Select an interval option. The slide show begins.

4. Press <

Cancel

> to stop the slide show.

Using image options

While viewing an image, press <

Options

> to access

the following options:

•

List

: return to the image list.

•

Send via

: send the file via MMS, e-mail, or

Bluetooth.

•

Set as

: set the image as wallpaper for the displays

or as a caller ID image for a Phonebook entry.

•

Edit

: decorate the photo by adding emoticons or

applying a frame or special effect.

•

Delete

: delete the file.

•

Rename

: change the file name.

As a result of the Digital Rights Management (DRM)

system, some of the media items you download from

the Internet or receive by MMS may require a license

key to access them.

Menu functions

•

Move to favourite images

Move to

: move the

file to another folder.

•

Slide show

: view all images as a slide show.

•

Share for Bluetooth

: share the file or all files

with other Bluetooth devices.

•

Print via Bluetooth

: print the image via a

Bluetooth-compatible printer. Some printers may

not be compatible with the phone.

•

Protection

: protect the file from being deleted.

•

Properties

: access the file properties.

Printing an image

You can print images via a Bluetooth connection.

1. Select an image.

2. Press <

Options

> and select

Print via Bluetooth

→

an printing option:

•

Image only

: print the image only.

•

With frame

: print the image with the image

information, such as file name, time and date,

and file properties.

3. Select a printer.



p. 82

4. Press <

> to print the image.

Videos

(Menu 6.2)

This menu displays video clips you have recorded,

downloaded, received in messages, or imported from

your computer.

Playing a video clip

1. Select a video folder.

2. Select a video clip.

• Some image formats may not be compatible with

the printer you use.

• Printing settings may vary depending on the

printer you use.

Video clips recorded on other devices, such as

camcorders, may not play correctly.

Menu functions

File manager

(Menu 6)

During playback, use the following keys:

Using video options

From a video screen, press < > to access the

following options:

•

Play

: play the file.

•

Send via

: send the file via MMS, e-mail, or

Bluetooth.

•

Delete

: delete the selected file.

•

Rename

: change the file name.

•

Move to favourite videos

Move to

: move the

file to another folder.

•

Share for Bluetooth

: share the file with other

Bluetooth devices.

•

Protection

: protect the file from being deleted.

•

Properties

: access the file properties.

Music

(Menu 6.3)

This menu displays MP3 files you have downloaded or

imported from your computer.

Select a file. The music player opens.

After playback, press <

Options

> to access the

following options:

•

List

: return to the file list.

•

Send via

: send the file via e-mail or Bluetooth.

•

Set as

: set the file as your ringtone, as a ringtone

for a Phonebook entry, or as a ringtone for alarms.

•

Rename

: change the file name.

•

Delete

: delete the file.

•

Share for Bluetooth

: share the file with other

Bluetooth devices.

•

Protection

: protect the file from being deleted.

Key Function

Pauses or resumes playback.

Left Moves backward in a file.

Right Skips forward in a file.

/ Adjusts the volume.

Down Stops playback.

Menu functions

•

Properties

: access the file properties.

Sounds

(Menu 6.4)

This menu displays voice memos you have recorded,

and sound files you have downloaded, received in

messages, or imported from your computer.

Playing a sound clip

1. Select a sound folder.

2. Select a sound clip. For a voice memo, see

Voice

recorder



p. 36

Using sound options

After playback, press <

Options

> to access the

following options:

•

List

: return to the sound list.

•

Send via

: send the file via MMS, e-mail, or

Bluetooth.

•

Set as

: set the file as your ringtone, as a ringtone

for a Phonebook entry, or as a ringtone for alarms.

•

Delete

: delete the file.

•

Rename

: change the file name.

•

Move to favourite

: move the file to another

folder.

•

Share for Bluetooth

: share the file with other

Bluetooth devices.

•

Protection

: protect the file from being deleted.

•

Properties

: access the file properties.

Other files

(Menu 6.5)

Files that you have received but which are not

supported by your phone are stored in this folder. You

cannot open these files on the phone. Unsupported file

formats include *.doc, *.ppt, and *.txt.

Memory status

(Menu 6.6)

Use this menu to view memory information for media

items in the phone’s memory.

Menu functions

Calendar

(Menu 7)

Calendar

(Menu 7)

The

Calendar

menu enables you to keep track of your

schedule.

To access this menu, press <

> in Idle mode and

select

Calendar

Consulting the calendar

When you enter the

Calendar

menu, the calendar in

Month view appears with today’s date indicated by a

blue box.

Selecting a day

• Press [Left] or [Right] to move by day.

• Press [Up] or [Down] to move by week.

• Press [ / ] to move by month.

Using calendar options

Press <

Options

> to access the following options:

•

View mode

: change the view mode of the

calendar.



p. 67

•

Create

: add a new item.



next section

•

Go to

: select today’s date or enter a specific date.

•

Sort by

: sort items by type of item.

•

Delete

: delete the items stored on the calendar by

using various deleting options.

•

Missed alarm events

: view items whose alarms

you have missed.

•

Memory status

: access memory information for

the items stored on the calendar.

Creating an item

You can store scheduled items, anniversaries,

miscellaneous items, and To do items on the calendar.

More than one item per day can be stored.

Entering a new scheduled item

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

Schedule

Miscellaneous

3. Enter information or change the settings:

•

Subject

: enter a title for the item.

•

Details

: enter item details.

Menu functions

•

Start date

and

Start time

: enter the starting

date and time for the item.

•

AM/PM

: select

in 12-hour time

format.

•

End date

and

End time

: enter the ending date

and time for the item.

•

AM/PM

: select

in 12-hour time

format.

•

Location

: (for

Schedule

) enter information

about the item location.

•

Alarm

: set an alarm for the item.

•

before

: set how long before the item the alarm

is to alert you.

•

Alarm tone

: select an alarm tone.

•

Repeat

: (for

Schedule

) set the item to recur

and select a repeat unit.

•

until

: (for

Schedule

) set the ending date, if

the item will recur.

4. Press <

Save

> to save the item.

Entering a new anniversary

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

Anniversary

3. Enter information or change the settings:

•

Occasion

: enter information about the

anniversary.

•

Date

: enter the date.

•

Alarm

: select to set an alarm for the

anniversary.

•

before

: set how long before the anniversary

the alarm is to alert you.

•

Alarm time

: enter the time for the alarm to

ring.

•

AM/PM

: select

in 12-hour time

format.

•

Alarm tone

: select an alarm tone.

•

Repeat every year

: set the phone to remind

you of the anniversary every year.

4. Press <

Save

> to save the anniversary.

Entering a To do item

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

To do

Menu functions

Calendar

(Menu 7)

3. Enter information or change the settings:

•

To do

: enter information about the To do item.

•

Start date

: enter the starting date.

•

Due date

: enter the ending date.

•

Priority

: select a priority level.

4. Press <

Save

> to save the To do item.

Viewing an item

Once you have scheduled things, the item icons and

the number of items for a specific day appears at the

bottom of the calendar.

Accessing an item

1. Select a date on the calendar to display the item

for the day.

2. Select an item to view its details.

3. Press [Left] or [Right] to access the other items

scheduled for the selected day.

Using options

While viewing an item, press <

Options

> to access

the following options:

•

Edit

: edit the item.

•

Create

: add a new item.

•

Send via

: send the item via SMS, MMS, e-mail, or

Bluetooth.

•

View mode

: change the view mode of the

calendar.

•

Done

Undone

: change the status of the to-do

item.

•

Delete

: delete the item.

•

Print via Bluetooth

: print the item details via a

Bluetooth-compatible printer. Some printers may

not be compatible with the phone.

Viewing an item in a different mode

You can change the calendar display to Day view or

Week view. Press <

Options

> and select

View mode

→

a view mode.

• Scheduled item • Anniversary

• To do item • Miscellaneous item

Menu functions

Day view

You can view items for the selected date. Select an

item to view its details.

The following icons may display to indicate the item

status:

• Alarm set

• Recurring item

• To do item priority (Red: high, Blue: normal,

Grey: low)

• Completed To do item

Week view

You can view items for the selected week. A cell on the

timetable indicates the presence of a schedule item.

Select a cell in the day you want.

Camera

(Menu 8)

You can use the camera module embedded in your

phone to take photos and record videos.

To access this menu, press <

> in Idle mode and

select

Camera

, or press and hold

[

]

Taking a photo

You can take photos in various modes. The camera

produces JPEG photos.

Taking a photo with the phone open

1. Access the

Camera

menu or press and hold [

]

to turn on the camera.

2. Make any desired adjustments.

• Do not take photos of people without their

permission.

• Do not take photos in a place where cameras are

not allowed.

• Do not take photos in a place where you may

interfere with another person’s privacy.

When you take a photo in direct sunlight or in bright

conditions, shadows may appear on the photo.

Menu functions

Camera

(Menu 8)

• Press < > to access camera options.



next section

• Use the keypad to change the camera settings

or switch to other modes.



p. 70

3. Press [

]

to take a photo. The photo is saved in

the

Photos

folder.

Using camera options in Capture mode

In Capture mode, press < > to access the following

options:

•

Record video

: switch to Record mode.

•

Shooting mode

: take a photo in the following

modes:

Single shot

: take a photo in normal mode. You

can select whether or not the camera automatically

saves a photo.

Multi shot

: take a series of action stills. You can

select the number of photos the camera will take

and the shooting speed.

•

Effects

: change the colour tone or apply a special

effect.

•

Frames

: apply a decorative frame.

•

Timer

: set a time delay before the camera takes a

photo.

•

Go to photos

: access the

Photos

folder.

•

Settings

: change the default settings for taking a

photo.

Size

: select an image size.

Quality

: select an image quality setting.

View finder

: select a preview screen.

Shutter sound

: select the sound that you hear

when you press the shutter release, [

]

Zoom sound

: turn the sound effect for zooming

on or off.

Brightness sound

: turn the sound effect for

brightness adjustment on or off.

To Press

access photo options <

Options



p. 70

delete the photo [

] and then <

Yes

return to Capture mode <

Back

Menu functions

Default name

: change the default prefix of file

names.

•

Camera short cuts

: view the functions of the

keys you can use in Capture mode.

Using the keypad in Capture mode

You can use the keypad to customise your camera

settings in Capture mode.

Using photo options

After saving a photo, press <

Options

> to access the

following options:

•

Take another

: return to Capture mode.

•

Send via

: send the file via MMS, e-mail, or

Bluetooth.

•

Set as

: set the photo as wallpaper for the displays

or as a caller ID image for a Phonebook entry.

•

Delete

: delete the file.

•

Multi shot delete all

: delete one of the

multi-shot photos.

Key Function

Left/Right Adjusts the image brightness.

Up/Down Zooms in or out.

Flips the image vertically.

Shows the mirror image.

Switches to Record mode.



p. 71

Changes the image size.

Changes the image quality.

Changes the shooting mode.

Changes the colour tone or applies a

special effect.

Selects a decorative frame.

Sets the timer.

Goes to the

Photos

folder.

Changes the preview screen.

Key Function

Menu functions

Camera

(Menu 8)

•

Rename

: change the file name.

•

Go to photos

: access the

Photos

folder.



p. 61

•

Share for Bluetooth

: share the selected file or all

files with other Bluetooth devices.

•

Print via Bluetooth

: print the image via a

Bluetooth-compatible printer. Some printers may

not be compatible with the phone.

•

Protection

: protect the file from being deleted.

•

Properties

: access the file properties.

Taking a photo with the phone closed

If you use Capture mode before exiting the Camera

mode, you can use Capture mode.

1. Press and hold [

]

2. Make any desired adjustments.

Press [ ] to flip the image vertically.

Press [ ] to show the mirror image.

3. Press [

]

to take a photo. The photo is

automatically saved.

Recording a video

You can record a video of what is displayed on the

camera screen and save it.

Recording a video with the phone open

1. In Capture mode, press [

2. Make any desired adjustment.

• Press < > to access camera options.



next section

• Use the keypad to change the camera settings

or switch to other modes.



p. 72

3. Press [

] or [

] to start recording.

4. Press [

]

or < > to stop recording. The video is

automatically saved in the

Videos

folder.

To Press

play back the video clip [ ].

access video options < >.



p. 73

delete the video clip [

] and then <

Yes

return to Record mode < >.

Menu functions

Using camera options in Record mode

In Record mode, press < > to access the following

options:

•

Take photo

: switch to Capture mode.

•

Effects

: change the colour tone or apply a special

effect.

•

Timer

: set a time delay before the camera starts

recording.

•

Go to videos

: access the

Videos

folder.

•

Settings

: change the following settings for

recording a video:

Recording mode

: select a video recording mode.

Select

Limit of Email

to record a video suitable

for e-mails.

Select

Limit of

MMS

to record a video suitable for

MMS messages.

Select

Normal

to record a video within the limit of

the currently available memory.

Size

: select a frame size.

Quality

: select an image quality setting.

Audio rec.

: record audio with a video clip.

Zoom sound

: turn the sound effect for zooming

on or off.

Brightness sound

: turn the sound effect for

brightness adjustment on or off.

Default name

: change the default prefix of file

names.

•

Camcorder short cuts

: view the functions of the

keys you can use in Record mode.

Using the keypad in Record mode

You can use the keypad to customise your camera

settings in Record mode:

Key Function

Left/Right Adjusts the image brightness.

Up/Down Zooms in or out.

Flips the image vertically.

Shows the mirror image.

Switches to Capture mode.



p. 68

Changes the frame size.

Menu functions

Camera

(Menu 8)

Using video options

After saving a video clip, press < > to access the

following options:

•

Record another

: return to Record mode.

•

Send via

: send the file via MMS, e-mail, or

Bluetooth.

•

Delete

: delete the file.

•

Rename

: change the file name.

•

Go to videos

: access the

Videos

folder.



p. 62

•

Share for bluetooth

: share the file with other

Bluetooth devices

•

Protection

: protect the file from being deleted.

•

Properties

: access the file properties.

Recording a video with the phone closed

If you use Record mode before exiting the Camera

mode, you can use Record mode.

1. Press and hold [

2. Make any desired adjustments.

Press [ ] to flip the image vertically.

Press [ ] to show the mirror image.

3. Press [

]

to record a video. The video clip is

automatically saved.

Changes the image quality.

Changes the video recording mode.

Changes the colour tone or applies a

special effect.

Mutes or unmutes audio.

Sets the timer.

Goes to the

Videos

folder.

Key Function

Menu functions

Settings

(Menu 9)

The

Settings

menu provides you with various setting

options to customise the phone to your preferences

and needs. You can also reset the settings to their

default status.

To access this menu, press <

> in Idle mode and

select

Settings

Time & Date

(Menu 9.1)

Use this menu to set the current time and date on

your phone.

•

Time

: enter the current time.

•

Home zone

: press [ ] and set the home time

zone. Select the city that corresponds to your

home zone. To set the daylight saving time, select

Set daylight saving time

•

AM/PM

: select

in 12-hour time format.

•

Time format

: select the time format.

•

Set date

: enter the current date.

•

Date format

: select the date format.

•

Week start day

: set which day of the week the

calendar starts with.

•

Auto update

: select to apply daylight savings

time to the current time, if

Set daylight saving

time

Home zone

is selected.

Phone settings

(Menu 9.2)

Many different features of your phone’s system can be

customised to suit your preferences.

Language

(Menu 9.2.1)

Use this menu to select one of several languages for

the display text.

Greeting message

(Menu 9.2.2)

Use this menu to enter the greeting that is displayed

briefly when the phone is switched on.

Short cut

(Menu 9.2.3)

You can use the Navigation keys as shortcuts to access

specific menus directly from Idle mode. Use this menu

to assign a shortcut to a key.

Menu functions

Settings

(Menu 9)

Assigning a shortcut menu

1. Select a key to be used as a shortcut key.

2. Select the menu to be assigned to the key.

Using shortcut options

Press <

Options

> to access the following options:

•

Change

: assign or change a shortcut menu.

•

Remove

: deactivate the shortcut assignment to

the selected key.

•

Remove all

: deactivate all shortcut assignments.

Advanced shortcut

(Menu 9.2.4)

Use this menu to activate the Advanced shortcut

feature. You can quickly access the text message,

alarm, calendar, and converter applications from the

dialling screen.

Activating the Advanced shortcut feature

1. On the Advanced screen, select

2. Press <

Save

Changing an Advanced shortcut key

1. Select the key to be changed as a shortcut key.

2. Select the menu that will be assigned to the key.

Using Advanced shortcut options

Press <

Options

> to access the following options:

•

Change

: assign or change a shortcut menu.

•

Remove

: deactivate the shortcut assignment to

the selected key.

•

Remove all

: deactivate all shortcut assignments.

Volume key

(Menu 9.2.5)

Use this menu to set whether the phone mutes the call

ringer or rejects a call if you press and hold [ / ]

when a call comes in.

Extra settings

(Menu 9.2.6)

You can turn the automatic redialling or answering

feature on or off.

•

Auto redial

: set the phone to make up to ten

attempts to redial a phone number after an

unsuccessful call.

Menu functions

•

Anykey

answer

: answer an incoming call by

pressing any key, except [ ] or <

Reject

•

Voice clarity

: remove extraneous noise and

increase call quality so that the person with whom

you are speaking can hear you clearly even if you

are in a noisy place.

•

Active folder

: answer an incoming call by opening

the phone.

Display settings

(Menu 9.3)

Use this menu to change settings for the display.

Wallpaper

(Menu 9.3.1)

You can set up the idle screen on both displays.

•

Main display

: select an image to be displayed on

the main display.

•

Cover display

: change the settings for the

external display:

Clock

: select a clock type.

Cover title

: set a message to be displayed on the

external display.

Wallpaper images

: change the wallpaper image

for the external display.

Text display

(Menu 9.3.2)

Use this menu to change the display settings for the

text displayed on the idle screen.

•

Text position

: select a text position. If you don’t

want to display text in Idle mode, select

Off

•

Text style

: select a font style.

•

Text colour

: select a font colour.

Dialling display

(Menu 9.3.3)

Use this menu to select a font colour and size for the

numbers entered and the background colour of the

display while dialling.

Calendar

(Menu 9.3.4)

Use this menu to display the calendar of the current

month on the idle screen.

Skin

(Menu 9.3.5)

You can select a skin colour pattern for Menu mode.

Menu functions

Settings

(Menu 9)

LCD brightness

(Menu 9.3.6)

You can adjust the brightness of the display for

varying lighting conditions.

LCD contrast

(Menu 9.3.7)

You can adjust the contrast of the main or external

display.

Show caller information

(Menu 9.3.8)

Use this menu to set the phone to display missed call

notifications with the most recently missed caller’s

information. To set the external display to show caller

information, select

With cover display

Sound settings

(Menu 9.4)

Use this menu to customise various sound settings.

Incoming call

(Menu 9.4.1)

Use this menu to change the sound settings for

incoming calls.

•

Alert type

: specify how you are to be informed of

incoming calls.

•

Ring tone

: select a ringtone to be used for the call

ringer.

•

Volume

: select a ringtone volume.

Keypad tone

(Menu 9.4.2)

Use this menu to select the tone that the phone

sounds when you press a key.

Message tone

(Menu 9.4.3)

Use this menu to change the sound settings for

incoming messages.

•

Tone

: select one of several message tones.

•

Alert type

: specify how you are to be informed

when a message comes in.

•

Repetition

: specify how often the phone informs

you of a new message.

You can adjust the keypad tone volume using

[ / ] in Idle mode.

Menu functions

Power on/off

(Menu 9.4.4)

Use this menu to select the melody that the phone

sounds when it is switched on or off.

Folder tone

(Menu 9.4.5)

Use this menu to select the tone that the phone

sounds when you open or close the phone.

Quiet mode

(Menu 9.4.6)

Use this menu to set how the phone acts to alert you

to a specific event while in Quiet mode.

Extra tones

(Menu 9.4.7)

Use this menu to customise additional tones for the

phone.

•

Minute

minder

: set the phone to beep every

minute during an outgoing call to keep you

informed of the length of your call.

•

Connection

tone

: set the phone to beep when an

outgoing call connects to the system.

•

Alerts on call

: set the phone to beep when you

receive a new message or when the time for an

alarm comes during a call.

•

Indicative

tones

: set the phone to beep when

you have made a mistake or something wrong

happens on the phone.

Light settings

(Menu 9.5)

Use this menu to change settings for the light.

Backlight

(Menu 9.5.1)

You can change the length of time the backlight or

display stays on in Dim mode.

•

Main LCD on

: select the length of time the

backlight stays on.

•

Main LCD dim

: select the length of time the

display stays on in Dim mode after the backlight

turns off.

Keypad light

(Menu 9.5.2)

You can set how the phone controls the use of the

keypad light.

•

Use at any time

: the keypad light is always used.

•

Use at night time

: the keypad light is used only

between 5:00 PM and 9:00 AM.

Menu functions

Settings

(Menu 9)

•

Use at custom time

: specify the time period that

the keypad light is used.

Network services

(Menu 9.6)

Use this menu to access network services. Please

contact your service provider to check their availability

and subscribe to them, if you wish.

Call diverting

(Menu 9.6.1)

This network service reroutes incoming calls to a

phone number that you specify.

1. Select a call diverting option:

•

Divert always

: divert all calls.

•

Busy

: divert calls when you are on another

call.

•

: divert calls when you do not answer

the phone.

•

Unreachable

: divert calls when you are not in

an area covered by your service provider or

when your phone is switched off.

•

Cancel

all

: cancel all call diverting options.

2. Select the type of calls to be diverted.

3. Select

Activate

. To deactivate call diverting, select

Deactivate

4. Move to the

Divert to

line.

5. Enter the number to which calls are to be diverted.

6. If you selected

No reply

, move to the

Seconds

line and select the length of time the network

delays before diverting a call.

7. Press <

Select

Call barring

(Menu 9.6.2)

This network service allows you to restrict your calls.

1. Select a call barring option:

•

All

outgoing

: prohibit all outgoing calls.

•

International

: prohibit international calls.

•

International except home

: only allow calls

to numbers within the current country when

you are abroad, and to your home country.

•

All

incoming

: prohibit incoming calls.

•

Incoming

while

abroad

: prohibit incoming

calls when you use your phone outside of your

home country.

Menu functions

•

Cancel

all

: cancel all call barring settings,

allowing calls to be sent and received normally.

•

Change barring password

: change the call

barring password obtained from your service

provider.

2. Select the type of calls to be barred.

3. Select

Activate

. To deactivate call barring, select

Deactivate

4. Enter the call barring password supplied by your

service provider and press <

Select

Call waiting

(Menu 9.6.3)

This network service informs you when someone is

trying to reach you while you are on another call.

1. Select the type of calls to which call waiting option

will apply.

2. Select

Activate

. To deactivate call waiting, select

Deactivate

Network selection

(Menu 9.6.4)

This network service allows you to manually select the

network to be used while roaming outside of your

home area, or to let the network be chosen

automatically. You can select a network other than

your home network only if there is a valid roaming

agreement between the two.

Caller ID

(Menu 9.6.5)

This network service allows you to prevent your phone

number from being displayed on the phone of the

person being called. If you select

Default

, the phone

will use the default setting provided by the network.

Voice mail server

(Menu 9.6.6)

Use this menu to store the number of the voicemail

server and access your voicemails.

Some networks may not allow you to change this

setting.

You must store the voicemail server number before

accessing the server. Your service provider can give

you the number.

Menu functions

Settings

(Menu 9)

•

Connect to voice mail

: connect to the voicemail

server to listen to your messages.

•

Voice server number

: enter the voicemail server

number.

Band selection

(Menu 9.6.7)

For the phone to make and receive phone calls, it

must register with an available network. Your phone

can handle any of the following types of networks:

GSM 1900, Combined GSM 900/1800, and GSM 900/

1800/1900.

The country where you purchased your phone

determines the default band that it uses. When you

travel abroad, you may need to change to an

appropriate band.

Bluetooth

(Menu 9.7)

Using the Bluetooth feature, you can connect the

phone wirelessly to other Bluetooth devices and

exchange data with them, talk hands-free, or control

the phone remotely.

Bluetooth technology allows free wireless connections

between all Bluetooth-compliant devices within a

range of 10 meters. Since the devices communicate

using radio waves, they do not need to be in line of

sight to each other.

Setting up the Bluetooth feature

The

Bluetooth

menu provides the following options:

•

Activation

: activate or deactivate the Bluetooth

feature.

•

My devices

: search for connectable Bluetooth

devices.

•

My phone’s visibility

: allow other Bluetooth

devices to search for your phone.

• If there are obstacles between the devices, the

operating distance may be reduced.

• It is recommended that you don’t use the

Bluetooth feature while using multimedia

features,

such as voice recorder and camera or vice versa,

for better performance.

• Some devices may not be compatible with your

phone.

Menu functions

•

My phone’s name

: assign a Bluetooth device

name to your phone, which is then displayed on

other devices.

•

Secure mode

: determine if the phone asks for

your confirmation when other devices access your

data.

•

Bluetooth services

: display available Bluetooth

services.

Searching for and pairing with a Bluetooth

device

1. From the Bluetooth setting options, select

devices

2. Select

Search new device

After searching, a list of devices to which you can

connect displays. The following icons indicate the

type of device:

The colour of the icon indicates the status of the

the device:

• Grey for unpaired devices

• Blue for paired devices

• Red for devices that are currently connected to

your phone

3. Select a device.

4. Enter a Bluetooth PIN and press <

>. This code

is used just once and you don’t need to memorise

it.

When the owner of the other device enters the

same code, pairing is complete.

Using device options

From the device list, press <

Options

> to access the

following options:

•

Connect

: connect to a headset or hands-free car

kit.

• Computer• Mobile phone

• Printer • Unknown device

• PDA • Headset/Hands-free car kit

Some devices, especially headsets or hands-free car

kits, may have a fixed Bluetooth PIN, such as

0000

If the other device has a code, you must enter it.

Menu functions

Settings

(Menu 9)

•

Disconnect

: end the connection with the

connected device.

•

Browse files

: search for data from the device and

import data directly to your phone.

•

Service list

: access the Bluetooth service list of

the device.

•

Rename

: rename the paired device.

•

Authorize device

Unauthorize device

determine whether or not the phone asks you to

permit connection when other devices try to

connect to your phone.

•

Delete

: remove the selected device or all devices

from the list.

Sending data via Bluetooth

1. Activate the Bluetooth feature.

2. Select the application in which the item you want

to send is stored.

3. Scroll to the item you want and press <

Options

4. Select

Send

via

→

Bluetooth

The phone searches for devices within range and

displays a list of available devices.

5. Select a device.

6. If necessary, enter the Bluetooth PIN needed for

pairing and press <

Receiving data via Bluetooth

To receive data via Bluetooth, your phone’s Bluetooth

feature must be active.

If an unauthorised Bluetooth device sends data to your

phone, the phone displays a confirmation message. To

receive data, press <

Yes

Security

(Menu 9.8)

Use this menu to protect the phone against

unauthorised use by managing the several access

codes of your phone and SIM card.

If you enter an incorrect PIN/PIN2 three times in

succession, the SIM card is blocked. To unblock it,

you need to enter your PUK/PUK2 (Personal

Unblocking Key). The codes are supplied by your

service provider.

PIN check

(Menu 9.8.1)

The 4- to 8-digit PIN (Personal Identification Number)

protects your SIM card against unauthorised use.

When this feature is enabled, the phone requires your

PIN each time it is switched on.

Change PIN

(Menu 9.8.2)

Use this menu to change your PIN. The PIN check

feature must be enabled to change the PIN.

Phone lock

(Menu 9.8.3)

Use this menu to lock the phone from unauthorised

use.

When this feature is enabled, you must enter a 4- to

8-digit phone password each time the phone is

switched on.

The password is preset to

00000000

. To change the

password, use the

Change password

menu.

Change password

(Menu 9.8.4)

Use this menu to change your phone password.

Privacy

(Menu 9.8.5)

Use this menu to lock access to your media contents,

including messages, media files, and document files.

When a privacy option is enabled, you must enter the

phone password to access the locked items.

SIM lock

(Menu 9.8.6)

This menu allows your phone to work only with the

current SIM by assigning a SIM lock code. You must

enter the SIM lock code to use a different SIM card.

FDN mode

(Menu 9.8.7)

If supported by your SIM card, Fixed Dialling Number

(FDN) mode restricts your outgoing calls to a limited

set of phone numbers. When this feature is enabled,

you can make calls only to phone numbers stored on

the SIM card.

Change PIN2

(Menu 9.8.8)

If supported by your SIM card, use this menu to

change your current PIN2.

Memory status

(Menu 9.9)

Use this menu to check the amount of memory being

used for storing data in Messages, File manager,

Calendar, Phonebook, and JAVA world. You can also

check the shared memory for MMS, Email, and File

manager.

Reset settings

(Menu 9.10)

Use this menu to reset the phone’s settings you have

changed.

1. Press [ ] to select the setting categories to be

reset.

2. Press <

Reset

3. Press <

Yes

> to confirm the reset.

4. Enter the phone password and press <

Solve problems

Help and personal needs

To save the time and expense of an unnecessary service

call, perform the simple checks in this section before

contacting a service professional.

When you switch on your phone, the following

messages may appear:

“Insert SIM”

• Be sure that the SIM card is correctly installed.

“Enter password”

• The automatic locking function has been enabled.

You must enter the phone’s password before you

can use the phone.

“Enter PIN”

• You are using your phone for the first time. You

must enter the PIN supplied with the SIM card.

• The PIN check feature is enabled. Every time the

phone is switched on, the PIN has to be entered.

To disable this feature, use the

PIN check

menu.

The password is preset to

00000000

. You can

change this password.



p. 84

“Enter PUK”

• The PIN has been entered incorrectly three times

in succession, and the SIM card is now blocked.

Enter the PUK supplied by your service provider.

“No service,” “Network failure,” or “Not done”

displays

• The network connection has been lost. You may be

in a weak signal area. Move and try again.

• You are trying to access an option for which you

have no subscription with your service provider.

Contact the service provider for further details.

You have entered a number but it was not dialled

• Be sure that you have pressed [ ].

• Be sure you have accessed the right cellular

network.

• Be sure that you have not set an outgoing call

barring option.

Your correspondent cannot reach you

• Be sure that your phone is switched on. ([ ]

pressed for more than one second.)

• Be sure that you are accessing the correct cellular

network.

• Be sure that you have not set an incoming call

barring option.

Your correspondent cannot hear you speaking

• Be sure that you have switched on the

microphone.

• Be sure that you are holding the phone close

enough to your mouth. The microphone is located

at the bottom of the phone.

The phone starts beeping and “Low battery”

flashes on the display

• Your battery is insufficiently charged. Recharge the

battery.

The audio quality of the call is poor

• Check the signal strength indicator on the display

( ). The number of bars indicates the signal

strength from strong ( ) to weak ( ).

• Try moving the phone slightly or moving closer to a

window if you are in a building.

No number is dialled when you re-call a

Phonebook entry

•Use the

Contact list

menu to ensure the number

has been stored correctly.

• Re-store the number, if necessary.

The battery doesn’t charge properly or the phone

sometimes turns itself off

• Wipe the charging contacts both on the phone and

on the battery with a clean soft cloth.

If the above guidelines do not help you to solve

the problem, take note of:

• The model and serial numbers of your phone

•Your warranty details

• A clear description of the problem

Then contact your local dealer or Samsung after-sales

service.

Health and safety information

Exposure to Radio Frequency (RF) Signals

Certification Information (SAR)

Your wireless phone is a radio transmitter and receiver.

It is designed and manufactured not to exceed the

exposure limits for radio frequency (RF) energy set by

the Federal Communications Commission (FCC) of the

U.S. government. These FCC exposure limits are

derived from the recommendations of two expert

organizations, the National Counsel on Radiation

Protection and Measurement (NCRP) and the Institute

of Electrical and Electronics Engineers (IEEE). In both

cases, the recommendations were developed by

scientific and engineering experts drawn from

industry, government, and academia after extensive

reviews of the scientific literature related to the

biological effects of RF energy.

The exposure limit set by the FCC for wireless mobile

phones employs a unit of measurement known as the

Specific Absorption Rate (SAR). The SAR is a measure

of the rate of absorption of RF energy by the human

body expressed in units of watts per kilogram (W/kg).

The FCC requires wireless phones to comply with a

safety limit of 1.6 watts per kilogram (1.6 W/kg). The

FCC exposure limit incorporates a substantial margin

of safety to give additional protection to the public and

to account for any variations in measurements.

SAR tests are conducted using standard operating

positions accepted by the FCC with the phone

transmitting at its highest certified power level in all

tested frequency bands. Although the SAR is

determined at the highest certified power level, the

actual SAR level of the phone while operating can be

well below the maximum value. This is because the

phone is designed to operate at multiple power levels

so as to use only the power required to reach the

network. In general, the closer you are to a wireless

base station antenna, the lower the power output.

NorthAmerica_Cingular_T-mobile.fm Page 9 Monday, September 26, 2005 2:42 AM

Health and safety information

Before a new model phone is available for sale to the

public, it must be tested and certified to the FCC that

it does not exceed the exposure limit established by

the FCC. Tests for each model phone are performed in

positions and locations (e.g. at the ear and worn on

the body) as required by the FCC.

The highest SAR values for this model phone as

reported to the FCC are Head: 0.683 W/Kg, Body-

worn: 0.383 W/Kg.

For body worn operation, this model phone has been

tested and meets the FCC RF exposure guidelines

whenused with a Samsung accessory designated for

this product or when used with an accessory that

contains no metal and that positions the handset a

minimum of 1.5 cm from the body.

Non-compliance with the above restrictions may result

in violation of FCC RF exposure guidelines.

SAR information on this and other model phones can

be viewed on-line at www.fcc.gov/oet/fccid. This site

uses the phone FCC ID number, A3LSGHX670.

Sometimes it may be necessary to remove the battery

pack to find the number. Once you have the FCC ID

number for a particular phone, follow the instructions

on the website and it should provide values for typical

or maximum SAR for a particular phone. Additional

product specific SAR information can also be obtained

at www.fcc.gov/cgb/sar.

NorthAmerica_Cingular_T-mobile.fm Page 10 Friday, January 20, 2006 10:07 AM

Health and safety information

Consumer Information on Wireless Phones

The U.S. Food and Drug Administration (FDA) has

published a series of Questions and Answers for

consumers relating to radio frequency (RF) exposure

from wireless phones. The FDA publication includes

the following information:

What kinds of phones are the subject of this

update?

The term wireless phone refers here to hand-held

wireless phones with built-in antennas, often called

“cell,” “mobile,” or “PCS” phones. These types of

wireless phones can expose the user to measurable

radio frequency energy (RF) because of the short

distance between the phone and the user's head.

These RF exposures are limited by Federal

Communications Commission safety guidelines that

were developed with the advice of FDA and other

federal health and safety agencies. When the phone is

located at greater distances from the user, the

exposure to RF is drastically lower because a person's

RF exposure decreases rapidly with increasing

distance from the source. The so-called “cordless

phones,” which have a base unit connected to the

telephone wiring in a house, typically operate at far

lower power levels, and thus produce RF exposures

well within the FCC's compliance limits.

Do wireless phones pose a health hazard?

The available scientific evidence does not show that

any health problems are associated with using

wireless phones. There is no proof, however, that

wireless phones are absolutely safe. Wireless phones

emit low levels of radio frequency energy (RF) in the

microwave range while being used. They also emit

very low levels of RF when in the stand-by mode.

Whereas high levels of RF can produce health effects

(by heating tissue), exposure to low level RF that does

not produce heating effects causes no known adverse

health effects. Many studies of low level RF exposures

have not found any biological effects. Some studies

have suggested that some biological effects may

occur, but such findings have not been confirmed by

additional research. In some cases, other researchers

have had difficulty in reproducing those studies, or in

determining the reasons for inconsistent results.

NorthAmerica_Cingular_T-mobile.fm Page 11 Monday, September 26, 2005 2:42 AM

Health and safety information

What is FDA's role concerning the safety of

wireless phones?

Under the law, FDA does not review the safety of

radiation-emitting consumer products such as wireless

phones before they can be sold, as it does with new

drugs or medical devices. However, the agency has

authority to take action if wireless phones are shown

to emit radio frequency energy (RF) at a level that is

hazardous to the user. In such a case, FDA could

require the manufacturers of wireless phones to notify

users of the health hazard and to repair, replace or

recall the phones so that the hazard no longer exists.

Although the existing scientific data do not justify FDA

regulatory actions, FDA has urged the wireless phone

industry to take a number of steps, including the

following:

• “Support needed research into possible biological

effects of RF of the type emitted by wireless

phones;

• “Design wireless phones in a way that minimizes

any RF exposure to the user that is not necessary

for device function; and

• “Cooperate in providing users of wireless phones

with the best possible information on possible

effects of wireless phone use on human health.

FDA belongs to an interagency working group of the

federal agencies that have responsibility for different

aspects of RF safety to ensure coordinated efforts at

the federal level. The following agencies belong to this

working group:

• “National Institute for Occupational Safety and

Health

• “Environmental Protection Agency

• “Federal Communications Commission

• “Occupational Safety and Health Administration

• “National Telecommunications and Information

Administration

The National Institutes of Health participates in some

interagency working group activities, as well.

FDA shares regulatory responsibilities for wireless

phones with the Federal Communications Commission

(FCC). All phones that are sold in the United States

must comply with FCC safety guidelines that limit RF

NorthAmerica_Cingular_T-mobile.fm Page 12 Monday, September 26, 2005 2:42 AM

Health and safety information

exposure. FCC relies on FDA and other health agencies

for safety questions about wireless phones.

FCC also regulates the base stations that the wireless

phone networks rely upon. While these base stations

operate at higher power than do the wireless phones

themselves, the RF exposures that people get from

these base stations are typically thousands of times

lower than those they can get from wireless phones.

Base stations are thus not the primary subject of the

safety questions discussed in this document.

What are the results of the research done

already?

The research done thus far has produced conflicting

results, and many studies have suffered from flaws in

their research methods. Animal experiments

investigating the effects of radio frequency energy

(RF) exposures characteristic of wireless phones have

yielded conflicting results that often cannot be

repeated in other laboratories. A few animal studies,

however, have suggested that low levels of RF could

accelerate the development of cancer in laboratory

animals. However, many of the studies that showed

increased tumor development used animals that had

been genetically engineered or treated with cancer-

causing chemicals so as to be pre-disposed to develop

cancer in absence of RF exposure. Other studies

exposed the animals to RF for up to 22 hours per day.

These conditions are not similar to the conditions

under which people use wireless phones, so we don't

know with certainty what the results of such studies

mean for human health.

Three large epidemiology studies have been published

since December 2000. Between them, the studies

investigated any possible association between the use

of wireless phones and primary brain cancer, glioma,

meningioma, or acoustic neuroma, tumors of the brain

or salivary gland, leukemia, or other cancers. None of

the studies demonstrated the existence of any harmful

health effects from wireless phones RF exposures.

However, none of the studies can answer questions

about long-term exposures, since the average period

of phone use in these studies was around three years.

NorthAmerica_Cingular_T-mobile.fm Page 13 Monday, September 26, 2005 2:42 AM

Health and safety information

What research is needed to decide whether RF

exposure from wireless phones poses a health

risk?

A combination of laboratory studies and

epidemiological studies of people actually using

wireless phones would provide some of the data that

are needed. Lifetime animal exposure studies could be

completed in a few years. However, very large

numbers of animals would be needed to provide

reliable proof of a cancer promoting effect if one

exists. Epidemiological studies can provide data that is

directly applicable to human populations, but ten or

more years' follow-up may be needed to provide

answers about some health effects, such as cancer.

This is because the interval between the time of

exposure to a cancer-causing agent and the time

tumors develop - if they do - may be many, many

years. The interpretation of epidemiological studies is

hampered by difficulties in measuring actual RF

exposure during day-to-day use of wireless phones.

Many factors affect this measurement, such as the

angle at which the phone is held, or which model of

phone is used.

What is FDA doing to find out more about the

possible health effects of wireless phone RF?

FDA is working with the U.S. National Toxicology

Program and with groups of investigators around the

world to ensure that high priority animal studies are

conducted to address important questions about the

effects of exposure to radio frequency energy (RF).

FDA has been a leading participant in the World Health

Organization international Electromagnetic Fields

(EMF) Project since its inception in 1996. An influential

result of this work has been the development of a

detailed agenda of research needs that has driven the

establishment of new research programs around the

world. The Project has also helped develop a series of

public information documents on EMF issues.

FDA and Cellular Telecommunications & Internet

Association (CTIA) have a formal Cooperative

Research and Development Agreement (CRADA) to do

research on wireless phone safety. FDA provides the

scientific oversight, obtaining input from experts in

government, industry, and academic organizations.

CTIA-funded research is conducted through contracts

NorthAmerica_Cingular_T-mobile.fm Page 14 Monday, September 26, 2005 2:42 AM

Health and safety information

to independent investigators. The initial research will

include both laboratory studies and studies of wireless

phone users. The CRADA will also include a broad

assessment of additional research needs in the

context of the latest research developments around

the world.

What steps can I take to reduce my exposure

to radio frequency energy from my wireless

phone?

If there is a risk from these products - and at this

point we do not know that there is - it is probably very

small. But if you are concerned about avoiding even

potential risks, you can take a few simple steps to

minimize your exposure to radio frequency energy

(RF). Since time is a key factor in how much exposure

a person receives, reducing the amount of time spent

using a wireless phone will reduce RF exposure.

• “If you must conduct extended conversations by

wireless phone every day, you could place more

distance between your body and the source of the

RF, since the exposure level drops off dramatically

with distance. For example, you could use a

headset and carry the wireless phone away from

your body or use a wireless phone connected to a

remote antenna.

Again, the scientific data do not demonstrate that

wireless phones are harmful. But if you are concerned

about the RF exposure from these products, you can

use measures like those described above to reduce

your RF exposure from wireless phone use.

What about children using wireless phones?

The scientific evidence does not show a danger to

users of wireless phones, including children and

teenagers. If you want to take steps to lower exposure

to radio frequency energy (RF), the measures

described above would apply to children and

teenagers using wireless phones. Reducing the time of

wireless phone use and increasing the distance

between the user and the RF source will reduce RF

exposure.

Some groups sponsored by other national

governments have advised that children be

discouraged from using wireless phones at all. For

NorthAmerica_Cingular_T-mobile.fm Page 15 Monday, September 26, 2005 2:42 AM

Health and safety information

example, the government in the United Kingdom

distributed leaflets containing such a recommendation

in December 2000. They noted that no evidence exists

that using a wireless phone causes brain tumors or

other ill effects. Their recommendation to limit

wireless phone use by children was strictly

precautionary; it was not based on scientific evidence

that any health hazard exists.

Do hands-free kits for wireless phones reduce

risks from exposure to RF emissions?

Since there are no known risks from exposure to RF

emissions from wireless phones, there is no reason to

believe that hands-free kits reduce risks. Hands-free

kits can be used with wireless phones for convenience

and comfort. These systems reduce the absorption of

RF energy in the head because the phone, which is the

source of the RF emissions, will not be placed against

the head. On the other hand, if the phone is mounted

against the waist or other part of the body during use,

then that part of the body will absorb more RF energy.

Wireless phones marketed in the U.S. are required to

meet safety requirements regardless of whether they

are used against the head or against the body. Either

configuration should result in compliance with the

safety limit.

Do wireless phone accessories that claim to

shield the head from RF radiation work?

Since there are no known risks from exposure to RF

emissions from wireless phones, there is no reason to

believe that accessories that claim to shield the head

from those emissions reduce risks. Some products

that claim to shield the user from RF absorption use

special phone cases, while others involve nothing

more than a metallic accessory attached to the phone.

Studies have shown that these products generally do

not work as advertised. Unlike “hand-free” kits, these

so-called “shields” may interfere with proper operation

of the phone. The phone may be forced to boost its

power to compensate, leading to an increase in RF

absorption. In February 2002, the Federal trade

Commission (FTC) charged two companies that sold

devices that claimed to protect wireless phone users

from radiation with making false and unsubstantiated

NorthAmerica_Cingular_T-mobile.fm Page 16 Monday, September 26, 2005 2:42 AM

Health and safety information

claims. According to FTC, these defendants lacked a

reasonable basis to substantiate their claim.

What about wireless phone interference with

medical equipment?

Radio frequency energy (RF) from wireless phones can

interact with some electronic devices. For this reason,

FDA helped develop a detailed test method to measure

electromagnetic interference (EMI) of implanted

cardiac pacemakers and defibrillators from wireless

telephones. This test method is now part of a standard

sponsored by the Association for the Advancement of

Medical instrumentation (AAMI). The final draft, a joint

effort by FDA, medical device manufacturers, and

many other groups, was completed in late 2000. This

standard will allow manufacturers to ensure that

cardiac pacemakers and defibrillators are safe from

wireless phone EMI. FDA has tested wireless phones

and helped develop a voluntary standard sponsored by

the Institute of Electrical and Electronic Engineers

(IEEE). This standard specifies test methods and

performance requirements for hearing aids and

wireless phones so that no interference occurs when a

person uses a compatible phone and a compatible

hearing aid at the same time. This standard was

approved by the IEEE in 2000.

FDA continues to monitor the use of wireless phones

for possible interactions with other medical devices.

Should harmful interference be found to occur, FDA

will conduct testing to assess the interference and

work to resolve the problem.

Additional information on the safety of RF exposures

from various sources can be obtained from the

following organizations:

• FCC RF Safety Program:

http://www.fcc.gov/oet/rfsafety/

• Environmental Protection Agency (EPA):

http://www.epa.gov/radiation/

• Occupational Safety and Health Administration's

(OSHA):

http://www.osha.gov/SLTC/

radiofrequencyradiation/index.html

NorthAmerica_Cingular_T-mobile.fm Page 17 Monday, September 26, 2005 2:42 AM

Health and safety information

• National institute for Occupational Safety and

Health (NIOSH):

http://www.cdc.gov/niosh/emfpg.html

• World health Organization (WHO):

http://www.who.int/peh-emf/

• International Commission on Non-Ionizing

Radiation Protection:

http://www.icnirp.de

• National Radiation Protection Board (UK):

http://www.nrpb.org.uk

• Updated 4/3/2002: US food and Drug

Administration

http://www.fda.gov/cellphones

Road Safety

Your wireless phone gives you the powerful ability to

communicate by voice, almost anywhere, anytime.

But an important responsibility accompanies the

benefits of wireless phones, one that every user must

uphold.

When driving a car, driving is your first responsibility.

When using your wireless phone behind the wheel of a

car, practice good common sense and remember the

following tips:

1. Get to know your wireless phone and its features,

such as speed dial and redial. If available, these

features help you to place your call without taking

your attention off the road.

2. When available, use a hands-free device. If

possible, add an additional layer of convenience

and safety to your wireless phone with one of the

many hands free accessories available today.

NorthAmerica_Cingular_T-mobile.fm Page 18 Monday, September 26, 2005 2:42 AM

Health and safety information

3. Position your wireless phone within easy reach. Be

able to access your wireless phone without

removing your eyes from the road. If you get an

incoming call at an inconvenient time, let your

voice mail answer it for you.

4. Let the person you are speaking with know you are

driving; if necessary, suspend the call in heavy

traffic or hazardous weather conditions. Rain,

sleet, snow, ice and even heavy traffic can be

hazardous.

5. Do not take notes or look up phone numbers while

driving. Jotting down a “to do” list or flipping

through your address book takes attention away

from your primary responsibility, driving safely.

6. Dial sensibly and assess the traffic; if possible,

place calls when you are not moving or before

pulling into traffic. Try to plan calls when your car

will be stationary. If you need to make a call while

moving, dial only a few numbers, check the road

and your mirrors, then continue.

7. Do not engage in stressful or emotional

conversations that may be distracting. Make

people you are talking with aware you are driving

and suspend conversations that have the potential

to divert your attention from the road.

8. Use your wireless phone to call for help. Dial 9-1-1

or other local emergency number in the case of

fire, traffic accident or medical emergencies.

Remember, it is a free call on your wireless phone!

9. Use your wireless phone to help others in

emergencies. If you see an auto accident, crime in

progress or other serious emergency where lives

are in danger, call 9-1-1 or other local emergency

number, as you would want others to do for you.

10.Call roadside assistance or a special non-

emergency wireless assistance number when

necessary. If you see a broken-down vehicle

posing no serious hazard, a broken traffic signal, a

minor traffic accident where no one appears

injured, or a vehicle you know to be stolen, call

roadside assistance or other special non-

emergency number.

NorthAmerica_Cingular_T-mobile.fm Page 19 Monday, September 26, 2005 2:42 AM

Health and safety information

“The wireless industry reminds you to use your

phone safely when driving.”

For more information, please call 1-888-901-SAFE, or

visit our web-site www.wow-com.com

Provided by the Cellular Telecommunications &

Internet Association

Operating Environment

Remember to follow any special regulations in force in

any area and always switch your phone off whenever it

is forbidden to use it, or when it may cause

interference or danger. When connecting the phone or

any accessory to another device, read its user's guide

for detailed safety instructions. Do not connect

incompatible products.

As with other mobile radio transmitting equipment,

users are advised that for the satisfactory operation of

the equipment and for the safety of personnel, it is

recommended that the equipment should only be used

in the normal operating position (held to your ear with

the antenna pointing over your shoulder).

Using Your Phone Near Other Electronic

Devices

Most modern electronic equipment is shielded from

radio frequency (RF) signals. However, certain

electronic equipment may not be shielded against the

RF signals from your wireless phone. Consult the

manufacturer to discuss alternatives.

Pacemakers

Pacemaker manufacturers recommend that a

minimum distance of 15 cm (6 inches) be maintained

between a wireless phone and a pacemaker to avoid

potential interference with the pacemaker.

These recommendations are consistent with the

independent research and recommendations of

Wireless Technology Research.

Persons with pacemakers:

• should always keep the phone more than 15 cm

(6 inches) from their pacemaker when the phone is

switched on.

• should not carry the phone in a breast pocket.

NorthAmerica_Cingular_T-mobile.fm Page 20 Monday, September 26, 2005 2:42 AM

100

Health and safety information

• should use the ear opposite the pacemaker to

minimize potential interference.

If you have any reason to suspect that interference is

taking place, switch your phone off immediately.

Hearing Aids

Some digital wireless phones may interfere with some

hearing aids. In the event of such interference, you

may wish to consult your hearing aid manufacturer to

discuss alternatives.

Other Medical Devices

If you use any other personal medical devices, consult

the manufacturer of your device to determine if it is

adequately shielded from external RF energy. Your

physician may be able to assist you in obtaining this

information. Switch your phone off in health care

facilities when any regulations posted in these areas

instruct you to do so. Hospitals or health care facilities

may be using equipment that could be sensitive to

external RF energy.

Vehicles

RF signals may affect improperly installed or

inadequately shielded electronic systems in motor

vehicles. Check with the manufacturer or its

representative regarding your vehicle. You should also

consult the manufacturer of any equipment that has

been added to your vehicle.

Posted Facilities

Switch your phone off in any facility where posted

notices require you to do so.

Potentially Explosive Environments

Switch your phone off when in any area with a

potentially explosive atmosphere and obey all signs

and instructions. Sparks in such areas could cause an

explosion or fire resulting in bodily injury or even

death.

Users are advised to switch the phone off while at a

refueling point (service station). Users are reminded of

the need to observe restrictions on the use of radio

equipment in fuel depots (fuel storage and distribution

NorthAmerica_Cingular_T-mobile.fm Page 21 Monday, September 26, 2005 2:42 AM

101

areas), chemical plants or where blasting operations

are in progress.

Areas with a potentially explosive atmosphere are

often but not always clearly marked. They include

below deck on boats, chemical transfer or storage

facilities, vehicles using liquefied petroleum gas (such

as propane or butane), areas where the air contains

chemicals or particles, such as grain, dust or metal

powders, and any other area where you would

normally be advised to turn off your vehicle engine.

Emergency Calls

This phone, like any wireless phone, operates using

radio signals, wireless and landline networks as well as

user programmed functions, which cannot guarantee

connection in all conditions. Therefore, you should

never rely solely on any wireless phone for essential

communications (medical emergencies, for example).

Remember, to make or receive any calls the phone

must be switched on and in a service area with

adequate signal strength. Emergency calls may not be

possible on all wireless phone networks or when

certain network services and/or phone features are in

use. Check with local service providers.

To make an emergency call:

1. If the phone is not on, switch it on.

2. Key in the emergency number for your present

location (for example, 911 or other official

emergency number). Emergency numbers vary by

location.

3. Press .

If certain features are in use (call barring, for

example), you may first need to deactivate those

features before you can make an emergency call.

Consult this document and your local cellular service

provider.

When making an emergency call, remember to give all

the necessary information as accurately as possible.

Remember that your phone may be the only means of

communication at the scene of an accident; do not cut

off the call until given permission to do so.

NorthAmerica_Cingular_T-mobile.fm Page 22 Monday, September 26, 2005 2:42 AM

102

Health and safety information

Restricting Children's access to your Phone

Your phone is not a toy. Children should not be allowed

to play with it because they could hurt themselves and

others, damage the phone or make calls that increase

your phone bill.

FCC Notice and Cautions

FCC Notice

The phone may cause TV or radio interference if used

in close proximity to receiving equipment. The FCC

can require you to stop using the phone if such

interference cannot be eliminated.

Vehicles using liquefied petroleum gas (such as

propane or butane) must comply with the National Fire

Protection Standard (NFPA-58). For a copy of this

standard, contact the National Fire Protection

Association, One Battery march Park, Quincy, MA

02269, Attn: Publication Sales Division.

Cautions

Changes or modifications made in the radio phone, not

expressly approved by Samsung, will void the user’s

authority to operate the equipment.

Only use approved batteries, antennas and chargers.

The use of any unauthorized accessories may be

dangerous and void the phone warranty if said

accessories cause damage or a defect to the phone.

Although your phone is quite sturdy, it is a complex

piece of equipment and can be broken. Avoid

dropping, hitting, bending or sitting on it.

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two

conditions: (1) this device may not cause harmful

interference, and (2) this device must accept any

interference received, including interference that

may cause undesired operation.

NorthAmerica_Cingular_T-mobile.fm Page 23 Monday, September 26, 2005 2:42 AM

103

Other Important Safety Information

• Only qualified personnel should service the phone

or install the phone in a vehicle. Faulty installation

or service may be dangerous and may invalidate

any warranty applicable to the device.

• Check regularly that all wireless phone equipment

in your vehicle is mounted and operating properly.

• Do not store or carry flammable liquids, gases or

explosive materials in the same compartment as

the phone, its parts or accessories.

• For vehicles equipped with an air bag, remember

that an air bag inflates with great force. Do not

place objects, including both installed or portable

wireless equipment in the area over the air bag or

in the air bag deployment area. If wireless

equipment is improperly installed and the air bag

inflates, serious injury could result.

• Switch your phone off before boarding an aircraft.

The use of wireless phone in aircraft is illegal and

may be dangerous to the aircraft's operation.

• Failure to observe these instructions may lead to

the suspension or denial of telephone services to

the offender, or legal action, or both.

Product Performance

Getting the Most Out of Your Signal Reception

The quality of each call you make or receive depends

on the signal strength in your area. Your phone

informs you of the current signal strength by

displaying a number of bars next to the signal strength

icon. The more bars displayed, the stronger the signal.

If you're inside a building, being near a window may

give you better reception.

Understanding the Power Save Feature

If your phone is unable to find a signal after 15

minutes of searching, a Power Save feature is

automatically activated. If your phone is active, it

periodically rechecks service availability or you can

check it yourself by pressing any key.

Anytime the Power Save feature is activated, a

message displays on the screen. When a signal is

found, your phone returns to standby mode.

NorthAmerica_Cingular_T-mobile.fm Page 24 Monday, September 26, 2005 2:42 AM

104

Health and safety information

Understanding How Your Phone Operates

Your phone is basically a radio transmitter and

receiver. When it's turned on, it receives and transmits

radio frequency (RF) signals. When you use your

phone, the system handling your call controls the

power level. This power can range from 0.006 watts to

0.2 watts in digital mode.

Maintaining Your Phone's Peak Performance

For the best care of your phone, only authorized

personnel should service your phone and accessories.

Faulty service may void the warranty.

There are several simple guidelines to operating your

phone properly and maintaining safe, satisfactory

service.

• Hold the phone with the antenna raised, fully-

extended and over your shoulder.

• Try not to hold, bend or twist the phone's antenna.

• Don't use the phone if the antenna is damaged.

• Speak directly into the phone's receiver.

• Avoid exposing your phone and accessories to rain

or liquid spills. If your phone does get wet,

immediately turn the power off and remove the

battery. If it is inoperable, call Customer Care for

service.

Availability of Various Features/Ring

Tones

Many services and features are network dependent

and may require additional subscription and/or usage

charges. Not all features are available for purchase or

use in all areas. Downloadable Ring Tones may be

available at an additional cost. Other conditions and

restrictions may apply. See your service provider for

additional information.

Battery Standby and Talk Time

Standby and talk times will vary depending on phone

usage patterns and conditions. Battery power

consumption depends on factors such as network

configuration, signal strength, operating temperature,

features selected, frequency of calls, and voice, data,

and other application usage patterns.

NorthAmerica_Cingular_T-mobile.fm Page 25 Monday, September 26, 2005 2:42 AM

Health and safety information

105

Battery Precautions

• Never use any charger or battery that is damaged

in any way.

• Use the battery only for its intended purpose.

• If you use the phone near the network's base

station, it uses less power; talk and standby time

are greatly affected by the signal strength on the

cellular network and the parameters set by the

network operator.

• Battery charging time depends on the remaining

battery charge and the type of battery and charger

used. The battery can be charged and discharged

hundreds of times, but it will gradually wear out.

When the operation time (talk time and standby

time) is noticeably shorter than normal, it is time

to buy a new battery.

• If left unused, a fully charged battery will

discharge itself over time.

• Use only Samsung-approved batteries and

recharge your battery only with Samsung-

approved chargers. When a charger is not in use,

disconnect it from the power source. Do not leave

the battery connected to a charger for more than a

week, since overcharging may shorten its life.

• Extreme temperatures will affect the charging

capacity of your battery: it may require cooling or

warming first.

• Do not leave the battery in hot or cold places, such

as in a car in summer or winter conditions, as you

will reduce the capacity and lifetime of the battery.

Always try to keep the battery at room

temperature. A phone with a hot or cold battery

may temporarily not work, even when the battery

is fully charged. Li-ion batteries are particularly

affected by temperatures below 0 °C (32 °F).

• Do not short-circuit the battery. Accidental short-

circuiting can occur when a metallic object (coin,

clip or pen) causes a direct connection between the

+ and - terminals of the battery (metal strips on

the battery), for example when you carry a spare

battery in a pocket or bag. Short-circuiting the

terminals may damage the battery or the object

causing the short-circuiting.

NorthAmerica_Cingular_T-mobile.fm Page 26 Monday, September 26, 2005 2:42 AM

106

Health and safety information

• Dispose of used batteries in accordance with local

regulations. In some areas, the disposal of

batteries in household or business trash may be

prohibited. For safe disposal options for Li-Ion

batteries, contact your nearest Samsung

authorized service center. Always recycle. Do not

dispose of batteries in a fire.

Care and Maintenance

Your phone is a product of superior design and

craftsmanship and should be treated with care. The

suggestions below will help you fulfill any warranty

obligations and allow you to enjoy this product for

many years.

• Keep the phone and all its parts and accessories

out of the reach of small children.

• Keep the phone dry. Precipitation, humidity and

liquids contain minerals that will corrode electronic

circuits.

• Do not use the phone with a wet hand. Doing so

may cause an electric shock to you or damage to

the phone.

• Do not use or store the phone in dusty, dirty areas,

as its moving parts may be damaged.

• Do not store the phone in hot areas. High

temperatures can shorten the life of electronic

devices, damage batteries, and warp or melt

certain plastics.

• Do not store the phone in cold areas. When the

phone warms up to its normal operating

temperature, moisture can form inside the phone,

which may damage the phone's electronic circuit

boards.

• Do not drop, knock or shake the phone. Rough

handling can break internal circuit boards.

• Do not use harsh chemicals, cleaning solvents or

strong detergents to clean the phone. Wipe it with

a soft cloth slightly dampened in a mild soap-and-

water solution.

NorthAmerica_Cingular_T-mobile.fm Page 27 Monday, September 26, 2005 2:42 AM

Health and safety information

107

• Do not paint the phone. Paint can clog the device's

moving parts and prevent proper operation.

• Do not put the phone in or on heating devices,

such as a microwave oven, a stove or a radiator.

The phone may explode when overheated.

• When the phone or battery gets wet, the label

indicating water damage inside the phone changes

color. In this case, phone repairs are no longer

guaranteed by the manufacturer's warranty, even

if the warranty for your phone has not expired.

• If your phone has a flash or light, do not use it too

close to the eyes of people or animals. This may

cause damage to their eyes.

• Use only the supplied or an approved replacement

antenna. Unauthorized antennas or modified

accessories may damage the phone and violate

regulations governing radio devices.

• If the phone, battery, charger or any accessory is

not working properly, take it to your nearest

qualified service facility. The personnel there will

assist you, and if necessary, arrange for service.

NorthAmerica_Cingular_T-mobile.fm Page 28 Monday, September 26, 2005 2:42 AM

108

Index

ABC mode, text input • 23

Active folder • 76

Alarm • 40

Answering

call • 26

second call • 28

Anykey answer • 76

Auto redial • 75

Background image • 76

Backlight time, set

display • 78

keypad • 78

Band selection • 81

Barring, calls • 79

Battery

charging • 7

low indicator • 8

precautions • 88

Bluetooth

receiving, data • 83

sending, data • 83

settings • 81

Broadcast messages • 60

Browser, web • 42

Calculator • 40

Calendar • 65

Call cost • 31

Call log

dialled • 30

missed • 30

received • 30

Call time • 30

Caller ID • 77, 80

Calls answering • 26

barring • 79

diverting • 79

holding • 27

redialling • 25

rejecting • 26

transferring • 29

waiting • 80

Camera

photos • 68

videos • 71

CB (Cell Broadcast) messages •

Characters, enter • 23

Configuration messages • 49

Connection tone • 78

Converter • 41

Creating messages

e-mail • 47

MMS • 46

SMS • 45

Deleting

call log • 30

e-mail • 51, 52, 54

events • 67

MMS • 49, 51, 54

phonebook • 32, 35

SMS • 49, 51, 54

Dialled calls • 30

Dialling display, set • 76

Display

backlight, set • 78

brightness • 77

icons • 10

language • 74

layout • 10

settings • 76

Diverting, calls • 79

DRM (Digital Rights

Management) • 61

DTMF tones, send • 28

E-mails

creating/sending • 47

deleting • 52

setting • 57

viewing • 51

Emergency calls • 91

FDN (Fixed Dialling Number)

mode • 84

File manager • 61

FM radio • 38

Folder tone • 78

Games • 37

Greeting message • 74

109

Index

Health and safety • 87

Holding, call • 27

Icons, description • 10

Images, downloaded • 61

Inbox, messages

e-mail • 51

MMS/SMS • 48

International calls • 25

Internet • 42

Java applications • 37

Keypad tones

selecting • 77

sending/muting • 28

volume • 77

Language, select • 74

Last number, redial • 25

Light settings • 78

Locking

menu functions • 84

phone • 84

SIM card • 84

Low battery indicator • 8

Memory status

downloaded items • 64

file manager • 64

messages • 60

phonebook 35

shared memory • 85

Message tone • 77

Messages

cell broadcast • 60

configuration • 50

e-mail • 47, 51

greeting • 74

MMS • 46, 49

push • 50, 60

SMS • 45, 49

Minute minder • 78

Missed calls • 30

MMS messages

creating/sending • 46

deleting • 49

setting • 54

viewing • 48

Multiparty-call • 29

Music, downloaded • 63

Name card • 34

Names

entering • 23

searching • 31

Network band, select • 81

Network selection • 80

Network services • 79

Numbers

searching • 31

storing • 32

Outbox, messages • 50

Password

call barring • 80

phone • 84

Phonecare and maintenance •

display • 10

icons • 10

locking • 84

password • 84

resetting • 85

switching on/off • 8

unpacking • 6

Phonebook

adding • 32

deleting • 32, 35

finding • 31

managing • 35

options • 31

speed dialling • 34

Photos

printing • 62

taking • 68

viewing • 61

PIN, change • 84

PIN2, change • 84

Power on/off tone • 78

Privacy • 84

Problems, solve • 85

Push messages • 50, 60

Quiet mode

entering • 14

setting • 78

Received calls • 30

Received messages

e-mail • 51

MMS/SMS • 48

110

Index

Recording

videos • 71

voice memos • 36

Redialling

automatically • 75

manually • 25

Resetting phone • 85

Ringer

incoming calls • 77

messages • 77

Road safety • 89

Roaming • 80

Safety

information • 87

precautions • 1

Security, calls • 83

Sent messages • 51

Shortcut • 74

SIM card

inserting • 7

locking • 84

Skin colour • 76

SMS messages

creating/sending • 45

deleting • 49

setting • 54

viewing • 48

Sound settings • 77

Sounds, downloaded • 64

Speed dial • 34

Stopwatch • 41

Switching on/off

microphone • 28

phone • 8

T9 mode, text input • 24

Templates, message • 53

Text, enter • 23

Timer • 41

Videos

playing • 62

recording • 71

Voice recorder

playing • 36

recording • 36

Voicemail server • 80

Waiting call • 80

Wallpaper • 76

Web browser

access • 42

bookmarks • 43

World time • 39

Samsung Electronics Co SGHX670 Single-Band PCS GSM/EDGE Phone with Bluetooth User Manual

Samsung Electronics Co Ltd Single-Band PCS GSM/EDGE Phone with Bluetooth Users Manual

Users Manual

Navigation menu

Namespaces

Views

Navigation
