Samsung Electronics Co SGHX700 Single-Band PCS GSM/ EDGE Phone with Bluetooth User Manual SGH X700 FCC
Samsung Electronics Co Ltd Single-Band PCS GSM/ EDGE Phone with Bluetooth SGH X700 FCC
Users Manual
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-XXXXXA
English. 08/2005. Rev 1.0
*
Depending on the software installed or your service provider or country,
some of the descriptions in this guide may not match your phone exactly.
* Depending on your country, your phone and accessories may appear
different from the illustrations in this guide.
SGH-X700
User’s Guide
Draft
2005. 08. 03
(Version:X700XAEG3)
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
Drive safely at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Important safety precautions
1
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories could
damage your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 87.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started” and “Step outside the phone.”
In this guide, the following instruction icons appear:
Indicates that you need to pay careful attention
to the subsequent information regarding safety
or phone features.
Indicates that you can get more information on
the referenced page.
→
Indicates that you need to press the Navigation
keys to scroll to the specified option and then
select it.
[ ]
Indicates a key on the phone. For example,
[].
< >
Indicates a soft key, whose function is displayed
on the phone screen. For example, <
Menu
>
• Camera and camcorder
Use the camera module on your
phone to take a photo or record a
video.
Special
features of your phone
•Bluetooth
Transfer media files and personal
data and connect to other devices
using free, wireless Bluetooth
technology.
•MP3 player
Play MP3 music files using your
phone as an MP3 player.
3
Special features of your phone
•FM radio
Listen to your favourite radio
channels anytime, anywhere.
• Get personal with photo caller
ID
See who’s calling you when their
very own photo displays.
•Name card
Create name cards with your
number and profile. Whenever
introducing yourself to others, use
this convenient electronic name
card.
• Multimedia Message Service (MMS)
Send and receive MMS messages with a
combination of text, images, video, and audio.
•E-mail
Send and receive e-mails with images, video,
and audio attachments.
•Web browser
Access the wireless web to get
current information and up-to-the-
minute a wide variety of media
content.
•Java
Enjoy Java
™
-based embedded
games and download new games.
•Calendar
Keep track of your daily, weekly,
and monthly schedule.
• Voice recorder
Record memos or sounds.
4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Buttons, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone ..................................... 7
Power on or off........................................................ 8
Keys and display ..................................................... 9
Access menu functions ............................................ 11
Customise your phone............................................. 12
Make/Answer calls .................................................. 14
Step outside the phone 14
Begin with your camera, music, web, and other special
features
Use camera............................................................ 14
Play MP3s .............................................................. 15
Listen to the FM radio ............................................. 17
Browse the web...................................................... 18
Use Phonebook ...................................................... 18
Send messages ...................................................... 19
View messages....................................................... 21
Use Bluetooth ........................................................ 22
Use a memory card................................................. 23
Enter text 24
ABC, T9, Number, and Symbol mode
Call functions 27
Advanced calling features
Menu functions 31
All menu options listed
Solve problems 85
Help and personal needs
Health and safety information 87
Index 94
5
Overview of menu functions
To access Menu mode, press <
Menu
> in Idle mode.
1 Call records
p.31
1 Recent contacts
2 Missed calls
3 Dialled calls
4 Received calls
5 Delete all
6 Call time
7 Call costs
*
p.31
p.31
p.31
p.32
p.32
p.32
p.32
2 Phonebook
p.33
1 Contact list
2 FDN list
3 Add new contact
4 Group
5 Speed dial
6 My name card
7 Own number
8 Management
9 Service number
*
p.33
p.33
p.34
p.35
p.35
p.36
p.36
p.37
p.37
3 Applications
p.37
1 MP3 Player
2 Voice recorder
3 Java world
4 FM radio
5 World time
6 Alarm
7 Calculator
8 Convertor
9 Timer
10 Stopwatch
11 SIM AT
*
p.38
p.40
p.41
p.42
p.43
p.43
p.44
p.44
p.45
p.45
p.45
4 Browser
p.46
1 Home
2 Bookmarks
3 Go to URL
4 Clear cache
5 Profile settings
6 Current profile
p.46
p.47
p.47
p.47
p.47
p.49
5 Messages
p.49
1 Create new message
2 My messages
3 Templates
4 Delete all
5 Settings
6 Broadcast messages
7 Memory status
p.49
p.52
p.55
p.56
p.56
p.62
p.62
6 File manager
p.62
1 Images
2 Videos
3 Music
4 Sounds
5 Other files
6 Memory card
**
7 Memory status
p.62
p.63
p.64
p.64
p.65
p.65
p.65
7 Calendar
p.65
8 Camera
p.69
9 Settings
p.74
1 Time & Date
2 Phone settings
3 Display settings
4 Sound settings
5 Light settings
6 Network services
7 Bluetooth
8 Security
9 Memory status
10 Reset settings
p.74
p.75
p.76
p.77
p.78
p.78
p.81
p.83
p.84
p.85
* Shows only if supported by your
SIM card.
** Shows only if a memory card is
installed.
6
Unpack
Make sure you have each item
You can obtain various accessories from
your local Samsung dealer.
Phone Travel Adapter
Battery User’s Guide
The items supplied with your phone
and the accessories at your Samsung
dealer may vary, depending on your
country or service provider.
Your phone
Buttons, features, and locations
Special
function keys
Earpiece
Display
Power on/off/
Menu exit key
Microphone
Cancel/
Correct key
Web access/
Confirm key
Alphanumeric
keys
Dial key
Right soft key
Navigation keys
(Up/Down/Left/
Right)
Volume key
Left soft key
External
speaker
Mirror
Headset
jack
Camera
Camera
key
Memory card slot
7
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you receive
a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your
PIN, and available optional services.
Install and charge the phone
Remove the battery.
If the
phone is already
on, first turn it off by
holding
[]
.
Insert the SIM card.
Make sure that the gold-
coloured contacts on the
card face down into the
phone.
Install the battery.
Plug the travel adapter
into the phone.
Plug the adapter into a standard AC wall outlet.
When the phone is completely charged (the
battery icon becomes still), unplug the adapter
from the power outlet.
8
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the low battery message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
Keypad lock
You can lock the keypad to prevent accidental key
presses from affecting phone operations.
In Idle mode, press and hold [ ]. To unlock the
keypad, press the left soft key and then [ ].
You can also set the phone to lock the keypad
automatically.
p. 76
Remove the adapter from the phone.
Switch on
Do not turn on
the phone when
mobile phone
use is prohibited.
1. Press and hold [ ] to turn on
the phone.
2. If necessary, enter the PIN and
press <
OK
>.
Switch off
Press and hold [ ].
9
Get started
Keys and display
Keys
Perform the function indicated on the bottom
line of the display.
In Idle mode, access your favourite menus
directly.
p. 75
In Menu mode, scroll through menu options.
In Idle mode, launch the web browser.
In Menu mode, select the highlighted menu
option or confirm input.
Make or answer a call.
In Idle mode, retrieve the recent numbers
dialled, missed, or received.
Delete characters from the display.
In Menu mode, return to the previous menu
level.
End a call.
Press and hold to switch the phone on or off.
In Menu mode, cancel input and return the
phone to Idle mode.
Enter numbers, letters, and some special
characters.
In Idle mode, press and hold
[1]
to access
your voicemail server. Press and hold [
0
] to
enter an international call prefix.
Enter special characters.
In Idle mode, press and hold [ ] to activate
or deactivate Quiet mode. Press and hold
[ ] to enter a pause between numbers.
Adjust the phone volume.
In Idle mode, adjust the keypad tone
volume.
In Idle mode, press and hold to turn on the
camera.
In Camera mode, take a photo or record a
video.
10
Get started
Display
Layout
Icons
*
Received signal strength
Call in progress
Out of your service area; you
cannot make or receive a call
Alarm set
New text message
New multimedia message
New e-mail
Text and graphics
display messages,
instructions, and
information you enter.
Soft key function
indicators
show the current functions
assigned to the soft keys.
Menu Contacts
Icons
display various icons.
One of the message Inboxes is full
New voicemail
Call diverting feature active
Bluetooth feature active
Connected to Bluetooth hand-free
kit or headset
Synchronised with PC
GPRS network
Roaming network
Home Zone, if registered for the
appropriate service
Office Zone, if registered for the
appropriate service
Memory card is inserted
Call ringer set to vibrate
Quiet mode
Battery power level
* Depending on your country or service provider, the
icons shown on the display may vary.
11
Get started
Access menu functions
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current role.
Press the left soft
key to select the
highlighted option.
Press the right soft
key to return to the
previous menu level.
Select Back
Select an
option
1. Press the appropriate soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press <
Select
>, <
OK
>, or [ ]
to confirm the function
displayed or option highlighted.
4. To exit, choose either of the
following methods.
•Press <
Back
> to [
C
] to
move up one level.
• Press [ ] to return to Idle
mode.
Use shortcuts
Press the number key
corresponding to the option you
want. For the index numbers 10 and
11, press [
0
] and [ ] respectively.
12
Get started
Customise your phone
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
settings
→
Language
.
2. Select a language.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Sound
settings
→
Incoming call
→
Ring tone
.
2. Select an ringtone category.
3. Select a ringtone.
4. Press <
Save
>.
Display
language
Call ringer
melody
You can set wallpaper for the idle
screen on the display.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display
settings
→
Wallpaper
.
2. Select an image category.
3. Select an image.
You can change the colour for the
display components, such as title
bars and highlight bars.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display
settings
→
Skin
.
2. Select a colour pattern.
Idle mode
wallpaper
Menu mode
skin colour
13
Get started
You can set the Navigation keys as
shortcuts to access your favourite
menus.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
settings
→
Short cut
.
2. Select a key.
3. Select a menu to be assigned to
the key.
You can switch the phone to Quiet
mode to avoid disturbing other
people.
Press and hold [ ] in Idle mode.
Menu
shortcuts
Quiet mode
You can protect the phone against
unauthorised use with a phone
password. The phone will require
the password on power-up.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Security
→
Change
password
.
2. Enter the default password,
00000000
, and press <
OK
>.
3. Enter a new 4- to 8-digit
password and press <
OK
>.
4. Enter the new password again
and press <
OK
>.
5. Select
Phone lock
.
6. Select
Enable
.
7. Enter the password and press
<
OK
>.
Phone lock
14
Make/Answer calls
Step outside the phone
Begin with your camera, music, web, and other special
features
Use camera
1. In Idle mode, enter an area
code and phone number.
2. Press [ ].
3. To end the call, press [ ].
1. When the phone is ringing,
press [ ].
2. To end the call, press [ ].
Press [ / ].
Make a call
Answer a call
Adjust the
volume during
a call
1. In Idle mode, press and hold
[
]
to turn on the camera.
2. Adjust the image to be
captured.
3. Press [ ] to take a photo. The
photo is saved automatically.
4.
Pres
s [ ] to
take another photo.
1. In Idle mode, press <
Menu
>
and select
File manager
→
Images
→
Photos
.
2. Select the photo you want.
Take a photo
View a photo
15
Step outside the phone
Play MP3s
1. In Idle mode, press and hold
[ ] to turn on the camera.
2. Press [
1
] to switch to Record
mode.
3. Press [ ] to start recording.
4. Press [ ] to stop recording.
The video is saved
automatically.
5. Press the right soft key to
record another video.
1.
In Idle mode, press <
Menu
>
and select
File manager
→
Videos
→
Videos
.
2. Select the video you want.
Record a video
Play a video
Use these methods:
• Download from the wireless
web
p. 46
• Download from a computer
using the optional Samsung PC
Studio
Samsung PC Studio
User’s Guide
• Receive via Bluetooth
p. 83
• Copy to a memory card and
insert the card into the phone.
p. 23
Copy MP3 files
to the phone
16
Step outside the phone
1. In Idle mode, press <
Menu
>
and select
Applications
→
MP3 Player
.
2. Press <
Options
> and select
Add to list
→
Add all
or
Add a
file
.
3. For
Add a file
, press [ ] to
select the files you want and
then <
Add
>.
4. Press <
Back
> to return to the
MP3 player screen.
Create a play
list
1. From the MP3 player screen,
press [ ].
2. During playback, use the
following keys:
• : pauses or resumes
playback.
• Left: moves back to the
previous file. Moves
backward in a file when held
down.
• Right: skips to the next file.
Skips forward in a file when
held down.
• Up: opens the play list.
•/: adjusts the volume.
• Down: stops playback.
Play MP3 files
17
Step outside the phone
Listen to the FM radio
1. Plug the connector of the
headset into the jack on the
right side of the phone.
2. In Idle mode, press <
Menu
>
and select
Applications
→
FM
radio
.
3. Press [ ] to turn on the radio.
4. Press and hold [Left] or [Right]
to automatically find available
radio frequencies.
5. Press <
Options
> and select
Add
.
6. Enter a name for the channel
and press [ ].
7. Select an empty location.
Finding and
setting radio
channels
1. Plug the connector of the
headset into the jack on the
right side of the phone.
2. In Idle mode, press <
Menu
>
and select
Applications
→
FM
radio
.
3. Press [ ] to turn on the radio.
4. Press [Up] or [Down] to scroll
to the channel you want.
5. To turn off the radio, disconnect
the headset.
Listening to the
radio
18
Step outside the phone
Browse the web
Using a built-in web browser, you can get easy access
to the wireless web to get a variety of up-to-date
services and information and to enjoy downloads of
web content.
Use Phonebook
In Idle mode, press [ ].
• To scroll through browser items,
press [Up] or [Down].
• To select an item, press [ ].
• To return to the previous page,
press <
Back
>.
• To return to the homepage,
press and hold [
C
].
• To access browser options,
press [ ] or select on the
top of the screen.
Launch the
web browser
Navigate with
the web
browser
To the phone’s memory:
1. In Idle mode, enter a phone
number and press <
Options
>.
2. Select
Save
→
Phone
→
a
number type.
3. Specify contact information:
First name, Last name, Mobile,
Home, Office, Fax, Other, Email,
Graphic ID, Alert, Group, and
Notes.
4. Press [ ] to save the entry.
To th e S I M c a r d :
1. In Idle mode, enter a phone
number and press <
Options
>.
2. Select
Save
→
SIM
.
3. Enter a name.
4. Press [ ] to save the entry.
Add an entry
19
Step outside the phone
Send messages
1. In Idle mode, press
<
Contacts
>.
2. Select an entry.
3. Scroll to a number and press
[]
to dial, or press [ ] to
edit contact information.
1. In Idle mode, press <
Menu
>
and select
Phonebook
→
My
name card
.
2. Specify your contact
information.
3. Press <
Save
> to save the
name card.
4. To send the name card to other
people, press <
Options
> and
select
Send via
→
a sending
method.
Find an entry
Create and
send a name
card
1. In Idle mode, press <
Menu
>
and select
Messages
→
Create
new message
→
Text
message
.
2. Enter the message text.
3. Press <
Options
> and select
Save and send
or
Send only
.
4. Enter destination numbers.
5. Press [ ] to send the message.
1. In Idle mode, press <
Menu
>
and select
Messages
→
Create
new message
→
Multimedia
message
.
2. Select
Subject
.
3. Enter the message subject and
press [ ].
Send a text
message (SMS)
Send a
multimedia
message
(MMS)
20
Step outside the phone
4. Select
Picture & Video
or
Sound
.
5. Add an image, a video, or a
sound file.
6. Select
Message
.
7. Enter the message text and
press [ ].
8. Press <
Options
> and select
Send
.
9. Enter destination numbers or
addresses.
10. Press [ ] to send the message.
Send a
multimedia
message
(MMS)
(continued)
1. In Idle mode, press <
Menu
>
and select
Messages
→
Create
new message
→
Email
.
2. Select
Subject
.
3. Enter the e-mail subject and
press [ ].
4. Select
Message
.
5. Enter the e-mail text and press
[].
6. Select
File attach
.
7. Add image, video, sound, music
files, or document files.
8. Press <
Options
> and select
Send
.
9. Enter e-mail addresses.
10. Press [ ] to send the e-mail.
Send an e-mail
21
Step outside the phone
View messages
When a notification appears:
1. Press <
View
>.
2. Select a message from the
Inbox.
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
My
messages
→
Inbox
.
2. Select an SMS message ( ).
When a notification appears:
1. Press <
View
>.
2. Select a message from the
Inbox.
View a text
message
View a
multimedia
message
From the Inbox:
1. In Idle mode, press <
Menu
>
and select
Messages
→
My
messages
→
Inbox
.
2. Select an MMS message ( ).
1. In Idle mode, press <
Menu
>
and select
Messages
→
My
messages
→
Email box
.
2. Select an account.
3. Press <
Yes
> to download new
e-mails or headers.
4. Select an e-mail or a header.
5. If you selected a header, press
<
Options
> and select
Retrieve
.
View an e-mail
22
Step outside the phone
Use Bluetooth
Your phone is equipped with Bluetooth technology
which enables you to connect the phone wirelessly to
other Bluetooth devices and exchange data with them,
talk hands-free, or control the phone remotely.
In Idle mode, press <
Menu
> and
select
Settings
→
Bluetooth
→
Activation
→
On
.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Bluetooth
→
My devices
→
Search new device
.
2. Select a device.
3. Enter a Bluetooth PIN code or
the other device’s Bluetooth PIN
code, if it has one, and press
<
OK
>.
When the owner of the other
device enters the same code,
pairing is complete.
Turn on
Bluetooth
Search for and
pair with a
Bluetooth
device
1. Access an application,
Phonebook
,
File manager
, or
Calendar
.
2. From the item list, press
<
Options
> and select
Send
via
→
Bluetooth
.
3. Press [ ] to select the items
you want and then <
Send
>.
4. Select a device.
5. If necessary, enter the
Bluetooth PIN and press <
OK
>.
To receive data via Bluetooth, your
phone’s Bluetooth feature must be
active.
If necessary, press <
Yes
> to
confirm the reception.
Send data
Receive data
23
Step outside the phone
Use a memory card
You can use a TransFlash memory card to enlarge your
phone’s memory capacity. The phone supports
memory cards with capacity of about 25MB.
• Frequent erasing and writing will
shorten a card’s lifespan.
• Do not remove a card from the
phone or turn off the phone while
data is being accessed or
transferred. This could result in
loss of data and/or damage to
the card or phone.
• Do not subject cards to strong
shocks.
• Do not touch card terminals with
your fingers or metal objects. If
dirty, wipe the card with a soft
cloth.
• Keep cards away from small
children or pets.
• Do not expose cards in a place
subject to electro static discharge
and/or electrical noise.
Important
memory card
information
1. Insert the card into the card
slot, with the label side face
down.
2. Push the card in with your
thumb until it locks into place.
You will hear the system sound.
Using a card adaptor and a USB
card reader/writer, you can read the
card on a PC.
1. Insert a memory card into a card
adaptor, and then the adaptor
into a card reader/writer.
2. Plug the USB connector of the
card reader/writer into the USB
port on your PC.
3. Access the appropriate memory
disk and copy to and from the
card.
Insert a
memory card
Use a card
adapter
24
Enter text
ABC, T9, Number, and Symbol mode
You can enter text for some features, such as
messaging, Phonebook, or Calendar, using ABC mode,
T9 mode, Number mode, and Symbol mode.
Changing the text input mode
• Press the right soft key to change the text input
mode. Or, press and hold the right soft key and
select the mode you want. ( : ABC mode,
: T9 mode, :Number mode,
: Symbol mode)
• Press and hold [ ] to switch between T9 and ABC
modes. Depending on your country, you may also
be able to access an input mode for your specific
language.
• Press and hold [ ] to switch to Symbol mode.
Using ABC mode
Press the appropriate key until the character you want
appears on the screen.
(Creating an SMS message in unicode encoding)
Characters in order displayed
Key Upper case Lower case
Enter text
25
Tips for using ABC mode
• To enter the same letter twice or to enter a
different letter on the same key, wait for the cursor
to move to the right automatically or press [Right].
Then, enter the next letter.
• Press [ ] to insert a space.
• Press [ ] to change case. Lower case (No
indicator), Initial capital ( ), and Capital lock ( )
are available.
• Press the Navigation keys to move the cursor.
•Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Using T9 mode
T9 is a predictive text input mode that allows you to
key in any character using single keystrokes.
Entering a word in T9 mode
1. Press [
2
] to [
9
]
to start entering a word. Press
each key once for each letter.
For example, press [
4
], [
3
], [
5
], [
5
], and [
6
] to
enter HELLO in T9 mode.
T9 predicts the word that you are typing, and it
may change with each key that you press.
2. Enter the whole word before editing or deleting
characters.
3. When the word displays correctly, go to step 4.
Otherwise, press [
0
] to display alternative word
choices for the keys that you have pressed.
For example, OF and ME use [
6
] and [
3
].
4. Press [ ] to insert a space and enter the next
word.
Tips for using T9 mode
• Press [
1
] to enter periods or apostrophes
automatically.
• Press [ ] to insert a space.
• Press [ ] to change case. Lower case (No
indicator), Initial capital ( ), and Capital lock ( )
are available.
26
Enter text
• Press the Navigation keys to move the cursor.
•Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Adding a new word to the T9 dictionary
This feature may not be available for some languages.
1. Enter the word that you want to add.
2. Press [
0
] to display alternative words for your key
presses. When there are no more alternative
words,
Spell
appears on the bottom line.
3. Press <
Spell
>.
4. Enter the word you want using AB mode and press
<
OK
>.
Using Number mode
Number mode enables you to enter numbers.
Press the keys corresponding to the digits you want.
Using Symbol mode
Symbol mode enables you to insert symbols.
To Press
display more symbols [Up] or [Down].
select a symbol the corresponding
number key.
clear the entered symbols [
C
].
insert the symbols <
OK
>.
27
Call functions
Advanced calling features
Making a call
1. In Idle mode, enter the area code and phone
number.
2. Press [ ].
Making an international call
1. In Idle mode, press and hold [
0
]. The
+
character
appears.
2. Enter the country code, area code, and phone
number, then press [ ].
Redialling recent numbers
1. In Idle mode, press [ ] to display the list of
recent numbers.
2. Scroll to the number you want and press [ ].
Making a call from Phonebook
Once you have stored a number in Phonebook, you
can dial the number by selecting it from Phonebook.
p. 33
You can also use the speed dial feature to assign your
most frequently called numbers to specific number
keys.
p. 35
You can quickly dial a number from the SIM card using
its location number assigned when stored.
1. In Idle mode, enter a location number and press
[].
2. Press [Left] or [Right] to scroll through other
numbers.
3. Press <
Dial
> or [ ] to dial the number you want.
Ending a call
Press [ ].
• Press [
C
] to clear the last digit or press and hold
[
C
] to clear the whole display. You can move the
cursor to edit an incorrect digit.
• Press and hold [ ] to enter a pause between
numbers.
28
Call functions
Answering a call
When you receive an incoming call, the phone rings
and displays the incoming call image.
Press <
Accept
> or [ ] to answer the call.
Tips for answering a call
• When
Anykey
answer
is active, you can press
any key, except for <
Reject
> or [ ].
p. 75
•Press <
Reject
> or [ ] to reject a call.
• Press and hold [ / ] to reject a call or mute the
ringer, depending on the
Volume key
setting.
p. 75
Viewing missed calls
If you have missed calls, the screen displays how
many calls you have missed.
1. Press <
View
>.
2. If necessary, scroll through the missed calls.
3. Press [ ] to dial the number you want.
Using the headset
Use the headset to make or answer calls without
holding the phone.
Connect the headset to the jack on the right side of
the phone. The button on the headset works as listed
below:
Options during a call
You can access a number of functions during a call.
Adjusting the volume during a call
Use [ / ] to adjust the earpiece volume during a call.
Press [ ] to increase the volume level and [ ] to
decrease the volume level.
To Press
redial the last call and hold the button twice.
answer a call the button.
end a call the button.
Call functions
29
Placing a call on hold/Retrieving
Press <
Hold
> or <
Retrieve
> to place a call on hold
or retrieve the call.
Making a second call
You can make another call if your network supports it.
1. Press <
Hold
> to put the call on hold.
2. Make the second call in the normal way.
3. Press <
Swap
> to switch between the calls.
4. Press <
Options
> and select
End
held
call
to end
the call on hold.
5. To end the current call, press [ ].
Answering a second call
You can answer an incoming call while already on the
phone, if your network supports it and you have
activated the call waiting feature.
p. 80
1. Press [ ] to answer the call. The first call is
automatically put on hold.
2. Press <
Swap
> to switch between the calls.
3. Press <
Options
> and select
End
held
call
to end
the call on hold.
4. To end the current call, press [ ].
Using the Speakerphone feature
Use the stereo speakers on the sides of the phone to
talk and listen with the phone a short distance away.
Press [ ] to activate the Speakerphone feature. Press
the key again to switch back to the earpiece.
Using In-call options
Press <
Options
> to access the following options
during a call:
•
Speaker on
/
Normal
: turn on the Speakerphone
feature or switch back to Normal mode.
•
Switch to headset
/
Switch to phone
: switch the
call to a Bluetooth headset or hands-free car kit or
back to the phone.
•
Menu
: access the phone's menu functions.
30
Call functions
•
End held call
: disconnect the call currently on
hold.
•
Transfer
: transfer the currently active call to a
caller on hold. The two callers can talk to each
other, but you are disconnected from the call.
•
Voice clarity on
/
Voice clarity off
: increases the
microphone’s sensitivity so that the other person
on the phone can hear you clearly even though you
may be whispering.
•
Mute
/
Unmute
: switch off the phone's microphone
so that the other person on the phone cannot hear
you, or switch it back on.
•
Mute keys
/
Send keys
: switch the key tones on
or off.
•
Phonebook
: access the contact list.
•
Send DTMF
: send the DTMF (Dual tone multi-
frequency) tones as a group. The DTMF tones are
the tones used in phones for tone dialling,
sounding when you press the number keys. This
option is helpful for entering a password or an
account number when you call an automated
system, like a banking service.
•
Message
: send an SMS message.
•
Join
: set up a multi-party call by adding a caller
on hold to a currently active call. You can include
up to 5 people on a multi-party call.
•
Private
: have a private conversation with one
multi-party call participant. The other participants
can converse with each other. After the private
conversation, select
Join
to return to the
multi-party call.
•
Remove
: disconnect one multi-party call
participant.
To communicate with answering machines or
computerised telephone systems,
Send keys
must be selected.
31
Menu functions
All menu options listed
Call records
(Menu 1)
Use this menu to view the calls you have dialled,
received, or missed, and the length of calls. You can
also check the cost of your calls,
if your SIM card
supports this function.
To access this menu, press <
Menu
> in Idle mode and
select
Call records
.
Recent contacts
(Menu 1.1)
This menu displays the most recent calls dialled,
received, or missed.
Accessing a call record
1. Press [Left] or [Right] to move to another call
type.
2. Press [Up] or [Down] to scroll through the call list.
3. Press [ ] to view the details of a call, or [ ] to
dial a number.
Using call record options
While viewing call details, press <
Options
> to access
the following options:
•
Save as contacts
: save the number to
Phonebook.
•
Send message
: send an SMS or MMS message to
the selected number.
•
Delete
: delete the selected call record or all
records.
Missed calls
(Menu 1.2)
This menu displays the most recent calls you did not
answer.
Dialled calls
(Menu 1.3)
This menu displays the most recent calls you have
dialled.
32
Menu functions
Received calls
(Menu 1.4)
This menu displays the most recent calls you have
received.
Delete all
(Menu 1.5)
Use this menu to delete all of the records in each call
type.
1. Press [ ] to select the call types to be cleared.
2. Press <
Delete
>.
3. Press <
Yes
> to confirm the deletion.
Call time
(Menu 1.6)
This menu displays the time log for calls made and
received. The actual time invoiced by your service
provider will vary.
•
Last
call
time
: check the length of your last call.
•
Total
sent
: check the total length of all the calls
you have dialled.
•
Total
received
: check the total length of all the
calls you have received.
•
Reset
timers
: reset the call timers. You need to
enter the phone password.
Call costs
(Menu 1.7)
This network feature displays the cost of calls. This
menu is available only if supported by your SIM card.
Note that this is not intended to be used for billing
purposes.
•
Last
call
cost
: check the cost of your last call.
•
Total
cost
: check the total cost of all of your calls.
If the total cost exceeds the maximum cost set in
Set
max
cost
, you must reset the counter before
you can make another call.
•
Max
cost
: check the maximum cost limit set in
Set
max
cost
.
•
Reset
counters
: reset the cost counters.
•
Set
max
cost
: set the maximum cost authorised
for your calls.
•
Price/Unit
: set the price per unit that is applied
when the cost of your calls is calculated.
The password is preset to
00000000
. You can
change this password.
p. 84
Menu functions
Phonebook
(Menu 2)
33
Phonebook
(Menu 2)
You can store phone numbers on your SIM card and in
your phone’s memory. The SIM card and phone’s
memory are physically separate, but they are used as
a single entity called Phonebook.
To access this menu, press <
Menu
> in Idle mode and
select
Phonebook
.
Contact list
(Menu 2.1)
Use this menu to search for numbers in Phonebook.
Finding an entry
1. Enter the first few letters of the name that you
want to find.
2. Select the name from the list.
3. Scroll to a number and press [ ] to dial, or press
[ ] to edit contact information.
Using Phonebook options
While viewing contact details, press <
Options
> to
access the following options:
•
Edit
: edit contact information.
•
Send message
: send an SMS or MMS message to
the selected number.
•
Copy
: copy the contact to the phone’s memory,
the SIM card, or the FDN list.
•
Send via
: send the contact via SMS, MMS, e-mail,
or Bluetooth.
•
Delete
: delete the selected contact.
•
Print via bluetooth
: print the contact by
connecting the phone to a printer via Bluetooth.
FDN list
(Menu 2.2)
Use this menu to create a list of contacts to be used in
FDN (Fixed Dialling Number) mode, in which the
phone allows outgoing calls only to the specified
phone numbers, if your SIM card supports this
feature. You can activate FDN mode in the
FDN mode
menu
.
p. 84
Adding a contact
1. Press <
Options
> and select
Add
.
2. Enter your PIN2 and press <
OK
>.
34
Menu functions
3. Enter a name and phone number, or press
<
Options
> and select
Contact list
to retrieve a
contact from Phonebook.
4. If necessary, change the location number.
5. Press <
Save
> to save the contact.
Using contact options
Scroll to a contact and press <
Options
> to access
options.
Using Phonebook options
Add new contact
(Menu 2.3)
Use this menu to add a new contact to Phonebook.
Storing a number in the phone’s memory
1. Select
Phone
.
2. Change the settings or enter information about the
contact.
•
First name
/
Last name
: assign a name.
•
Mobile
/
Home
/
Office
/
Fax
/
Other
: add a
number in any category.
•
Email
: assign an e-mail address.
•
Graphic ID
: assign an image to alert you to a
call from the person.
•
Alert
: assign a ringtone to alert you to a call
from the person.
•
Group
: assign the number to a caller group.
•
Notes
: add a memo about the person.
3. Press <
Save
> to save the contact.
Storing a number on the SIM card
1. Select
SIM
.
2. Enter a name and press [Down].
3. Enter a phone number and press [Down].
4. Change the location number, if necessary.
5. Press <
Save
> to save the contact.
To assign a caller ID image, ringtone, or group,
the contact must be saved to the phone’s
memory.
Menu functions
Phonebook
(Menu 2)
35
Group
(Menu 2.4)
Use this menu to organise your contacts in caller
groups.
Creating a new caller group
1. Press <
Options
> and select
Add
.
2. Enter a name for the group.
3. Select the Graphic ID line and set an image.
4. Select the Alert line and set a melody.
5. Press <
Save
> to save the group.
Adding members to a caller group
1. Select a group.
2. Press <
Add
>.
3. Select the contact you want.
4. To add more members, press <
Options
> and
select
Add
→
a contact. Repeat this as desired.
Managing caller groups
While viewing the group list, press <
Options
> to
access the following options:
•
View
: display the members of the selected group.
•
Add
: add a new group.
•
Edit
: change the group properties.
•
Send message
: send an SMS, MMS, or e-mail
message to the group members you want.
•
Delete
: delete the group. Group members,
however, will not be deleted from Phonebook.
Speed dial
(Menu 2.5)
Use this menu to assign a speed dial number (2 to 9)
for 8 of your most frequently called numbers.
Assigning speed dial numbers
1. Select a key location from
2
to
9
. Key
1
is reserved
for your voicemail server.
2. Select a contact from the contact list.
3. Select a number, if the contact has more than one
number.
36
Menu functions
Managing speed dial entries
From the Speed dial screen, press <
Options
> to
access the following options:
•
Add
: assign a number to an unassigned key.
•
View
: check the name and number assigned to a
key.
•
Change
: assign a different number to a key.
•
Remove
: clear the speed dial setting for a key.
Dialling speed dial entries
In Idle mode, press and hold the appropriate key.
My name card
(Menu 2.6)
Use this menu to create a name card and send it to
other people.
Saving your name card
The procedure for creating your name card is the
same as the one for saving a phone number in the
phone’s memory.
p. 34
Using name card options
After saving your name card, press <
Options
> to
access the following options:
•
Edit
: edit the name card.
•
Send via
: send the name card via SMS, MMS,
e-mail, or Bluetooth.
•
Exchange namecard
: exchange name cards with
another person via Bluetooth.
•
Remove
: delete the name card.
•
Print via bluetooth
: print the name card by
connecting the phone to a printer via Bluetooth.
Own number
(Menu 2.7)
Use this feature to check your phone numbers, or to
assign a name to each of the numbers. Changes made
here do not affect the actual subscriber numbers on
your SIM card.
Menu functions
Applications
(Menu 3)
37
Management
(Menu 2.8)
Use this menu to manage Phonebook entries.
•
Default saving
: select a default memory location
for saving contacts. If you select
Ask on saving
,
the phone will ask you to select a memory location
each time you save a number.
•
Copy all to phone
: copy all of the contacts stored
on the SIM card to the phone’s memory, or vice
versa.
•
Sort by contacts
: sort your contacts by the first
name or last name.
•
Delete all
: delete all of the contacts from your
phone’s memory, your SIM card, or the FDN list.
•
Memory status
: check the number of contacts
you have stored in the phone’s memory and on the
SIM card.
Service number
(Menu 2.9)
Use this menu to view the list of Service Dialling
Numbers (SDN) assigned by your service provider,
including emergency numbers and numbers for
directory enquiries. This menu is available if your SIM
card supports SDN.
Scroll to the number you want and press <
Dial
> or
[].
Applications
(Menu 3)
Use this menu to play Java games, play MP3 music
files, or listen to the FM radio. You can also use
convenient features, such as a voice recorder, alarm
clock, calculator, converter, and stopwatch.
To access this menu, press <
Menu
> in Idle mode and
select
Applications
.
38
Menu functions
MP3 Player
(Menu 3.1)
Use this menu to enjoy music. First, you need to save
MP3 files into your phone’s memory or on a memory
card. You can play MP3, AAC, and M4A files from the
phone’s memory, and MP3 files from the memory card.
To enjoy high quality music, you can use an optional
Bluetooth headset.
Downloading or receiving music files
Use these methods to save MP3 files to your phone’s
memory:
• Download from the wireless web
p. 46
• Download from a computer using the optional
Samsung PC Studio
Samsung PC Studio User’s
Guide
• Via an active Bluetooth connection
p. 83
• Copy to a memory card and insert the card into the
phone.
p. 23
The downloaded or received files are stored in the
Music
folder.
p. 64
Creating a play list
1. From the MP3 player screen, press <
Options
>
and select
Add to list
→
Add all
or
Add a file
.
2. For
Add a file
, press [ ] to select the files you
want and then <
Add
>.
3. Press <
Back
> to return to the MP3 player screen.
Playing music files
1. From the MP3 player screen, press <
Options
>
and select
Play via
.
2. Select
Phone
to use the phone speaker.
Select
A/V headset
to use a Bluetooth headset
and search for and connect to the headset.
During playback, use the following keys:
Normal headsets are not compatible with the MP3
player.
Key Function
Pauses or resumes playback.
Left Moves back to the previous file. Moves
backward in a file when held down.
Menu functions
Applications
(Menu 3)
39
Using MP3 player options
From the MP3 player screen, press <
Options
> to
access the following options:
•
Play via
: begin playback via phone or Bluetooth
headset.
•
Pause
: pause playback.
•
Transfer to A/V headset
: transfer playback via
Bluetooth headset.
•
Send via
: send the current file via e-mail or
Bluetooth.
•
Open play list
: access the current play list.
•
Set as
: set the file as your ringtone, alarm tone,
or as a ringtone for a Phonebook entry.
•
Delete
: remove the current file from the phone’s
memory.
•
Settings
: change the default settings for playing
music files.
Repeat mode
: select a repeat mode.
Shuffle
: set the MP3 player to play music at
random.
Visualization
: select an equalizer type.
Volume
: select a volume level.
•
Properties
: access the file properties.
Accessing the play list
From the MP3 player screen, press [Up].
Press <
Options
> to access the following options:
•
Play via
: begin playback via phone or Bluetooth
headset.
•
Add to list
: add files to the play list.
Right Skips to the next file. Skips forward in a
file when held down.
Up Opens the play list.
Down Stops playback.
/ Adjusts the volume level.
3
Changes the repeat mode.
6
Turns Shuffle mode on or off.
Key Function
40
Menu functions
•
Move list
: move the selected file to the position
you want within the play list.
•
Remove
: remove the selected file or all files from
the play list.
Voice recorder
(Menu 3.2)
Use this menu to record voice memos. A voice memo
can be up to one hour long.
Recording a voice memo
1. Press [ ] to start recording.
2. Speak into the microphone.
Press [ ] to pause or resume recording.
3. Press <
Stop
> or [Down] to end recording. The
voice memo is saved automatically.
4. Press [ ] to review the voice memo, or [Up] to
record a new memo.
Playing a voice memo
1. From the Voice recorder screen, press <
Options
>
and select
Go to voice list
.
2. Select a voice memo.
During playback, use the following keys:
Changing the recording mode
You can change the recording mode of the voice
recorder. The maximum recording time is determined
by this setting. Before recording a memo, press
<
Options
> and select
Settings
→
a recording mode:
•
Limit for multimedia message
: record a voice
memo for adding to an MMS message.
•
Limit for email
: record a voice memo for adding
to an e-mail.
Key Function
Pauses or resumes playback.
Left Moves backward in a memo.
Right Moves forward in a memo.
Up Returns to Record mode.
Down Stops playback.
/ Adjusts the volume.
Menu functions
Applications
(Menu 3)
41
•
Maximum 1 hour
: record a voice memo of up to
one hour.
Java world
(Menu 3.3)
Use this menu to access the standard Java games and
downloaded Java applications.
Playing a standard game
1. Select
Downloads
→
a game.
2. Press any key to start the game.
Using Java application options
Form the Java world screen, select
Downloads
and
press <
Options
> to access the following options:
•
Launch
: launch the selected application.
•
Application settings
: set the game to be
continued when a call comes in or an alarm sounds
during the game. You can also set the phone to
exchange game information with the network while
playing an online game or when you need to
connect to the Internet.
•
Delete
: delete the selected application.
•
Properties
: access the application properties.
Changing Java settings
You can change the settings for accessing Java
services.
1. From the Java world screen, select
Settings
.
2. Change the following settings:
•
APN
: enter the access point name.
•
Login ID
: enter the user ID.
•
Password
: enter the password.
•
Proxy
: select whether or not you use a proxy
server to access network services. Depending
on this setting, options in
Proxy settings
vary.
•
Proxy settings
: provide you with the following
options:
When the proxy is set to
Enable
:
IP address
: enter the HTTP proxy address.
Port
: enter the port number.
When the proxy is set to
Disable
:
DNS1
: enter the primary DNS address.
DNS2
: enter the secondary DNS address.
42
Menu functions
Checking memory status
You can view the amount of total and used memory for
Java games.
From the Java world screen, select
Memory status
.
FM radio
(Menu 3.4)
Use this menu to access the FM radio on your phone.
First, you must connect your phone with the headset,
which serves as a radio antenna.
Finding and setting radio channels
1. Press [ ] to turn on the radio.
2. Press [Left] or [Right] to move to the frequency of
a radio channel.
The frequency moves by 0.1 MHz increments.
Otherwise, press and hold [Left] or [Right] to
automatically find available radio frequencies.
3. Press <
Options
> and select
Add
.
4. Enter a name for the channel and press [ ].
5. Select an empty location.
Listening to the radio
1. From the FM radio screen, press [ ] to turn on the
radio.
2. Press [Up] or [Down] to scroll to the channel you
want.
Press [ / ] to adjust the volume.
3. To turn off the radio, press [ ] on the FM radio
screen or disconnect the headset.
Using radio options
On the FM radio screen, press <
Options
> to access
the following radio options:
•
FM radio on
/
FM radio off
: turn the radio on or
off.
•
Add
: add a radio channel. You can store up to 30
channels.
•
Edit
: edit the name or frequency for the channel.
• You can answer an incoming call or use other
phone functions while listening to the radio.
• The quality of the radio broadcast depends on
the radio station’s coverage in that particular
area.
Menu functions
Applications
(Menu 3)
43
•
Self-tuning
: let the phone automatically scan
through and save available radio frequencies.
•
Remove
: remove the selected channel or all
channels.
•
Pop-up alert
: set the phone to alert you to listen
to the radio at a specified time. When the pop-up
notification appears on the screen, press <
Listen
>
to turn on the specified radio channel.
•
Speaker on
/
Earphone on
: change the audio
mode to the phone’s speaker or headset.
•
Settings
: select the radio volume.
World time
(Menu 3.5)
Use this menu to set your local time zone and find out
what time it is in another part of the world.
Viewing world time
1. From the world map, press [Left] or [Right] to
scroll to the city you want. As the time line moves,
the time and date of the given zone display.
2. Press [ ] to save the city as your local time zone.
Applying daylight savings time
1. From the world map, press <
Options
> and select
Set daylight saving time
.
2. Press [ ] to select the time zones you want.
3. Press <
Save
>.
Alarm
(Menu 3.6)
Use this menu to set alarms. The alert type for a
normal alarm corresponds to the call alert type
settings. A wake-up alarm is not affected by your
sound settings.
Setting an alarm
1. Select the type of alarm.
2. Set each alarm option:
•
Alarm
: activate the alarm.
•
Alarm time
: enter the time for the alarm to
ring.
•
AM/PM
: select
AM
or
PM
in 12-hour format.
•
Alarm day
: select days of the week to ring the
alarm.
44
Menu functions
•
Alarm tone
: select an alarm tone.
3. Press <
Save
>.
Stopping an alarm
• For a non-wake-up alarm, press any key.
• For a wake-up alarm, press <
OK
> or [ ].
Press any key, except <
OK
> and [ ], to cause it
to sound again after 5 minutes. You can do this a
maximum of 5 times.
Setting the alarm to ring even if the phone is
off
From the Alarm screen, select
Auto power
→
On
.
If the phone is off when it is time for the alarm to ring,
the phone switches on and sounds the alarm.
Calculator
(Menu 3.7)
Use this menu to perform basic arithmetic functions,
such as addition, subtraction, multiplication, and
division.
1. Enter the first number.
•Press <
.()
> to insert a decimal point or
bracket.
•
Press
[] or []
to move the cursor.
2. Press one of the Navigation keys to access the
math function you want.
3. Enter the second number.
4. Press [ ] to view the result.
5. If necessary, repeat from step 2 to continue the
calculation.
Convertor
(Menu 3.8)
Use this menu for common conversions, such as
currency and temperature.
1. Select a converter.
2. Press [Left] or [Right] to select the original unit
and press [Down].
3. Enter the value to be converted and press [Down].
• Press [ ] to insert a decimal point.
• Press [ ] to change the temperature to above
zero (+) or below zero (-).
Menu functions
Applications
(Menu 3)
45
4. Press [Left] or [Right] to select the unit to which
you want to convert.
The equivalent value for the amount you entered
displays.
Using convertor options
Press <
Options
> to access the following options:
•
Clear
: clear the current values.
•
Reverse
: reverse the conversion.
•
Currency rates
: edit the currency rate list.
Timer
(Menu 3.9)
Use this menu to set a period of time for the phone to
count down. The phone will sound an alarm when the
specified period of time has expired.
Starting the timer
1. Press <
Set
>.
2. Enter the length of time you want to count down
and press <
OK
>.
3. Press [ ] to start counting down.
Stopping the timer
• Press any key when the timer rings.
• Press [ ] on the Timer screen to stop the timer
before it rings.
Stopwatch
(Menu 3.10)
Use this menu to measure elapsed time. The
maximum time is 10 hours.
1. Press [ ] to start the stopwatch.
2. Press [ ] to check an interval. You can repeat this
step for a total of 4 intervals.
SIM AT
(Menu 3.11)
This menu is available if you use a SIM-AT card that
supports SIM Application Tool kit menus and provides
additional services, such as news, weather, sports,
entertainment, and location services. Available
services may vary, depending on your service
provider’s plans. For details, see your SIM card
instructions or contact your service provider.
46
Menu functions
Browser
(Menu 4)
The Wireless Application protocol (WAP) browser on
your phone allows you to access the wireless web.
From the wireless web, you can access up-to-date
information and a wide variety of media content, such
as games, wallpapers, ringtones, and music files.
To access this menu, press <
Menu
> in Idle mode and
select
Browser
.
Home
(Menu 4.1)
Use this menu to connect your phone to the network
and load the homepage of the wireless web service
provider. You can also press [ ] in Idle mode.
Navigating the web browser
Using browser options
Press [ ] or select on the top of the screen to
access the following options:
•
Back
: go back to the previous page.
•
Home
: go back to the homepage.
•
Exit
: exit the web browser.
•
Reload
: reload the current page with updated
information.
•
Show URL
: display the URL address of the current
web page.
•
About ...
: access the properties of your web
browser.
Using page options
From any web page, press [ ] to access the following
options:
•
Go to URL
: enter a URL address manually.
•
Bookmarks
: bookmark the current page or access
the bookmark list.
•
Messages
: send SMS messages or view the
messages stored in the phone.
To Press
scroll through browser items [Up] or [Down].
select a browser item [ ] or [ ].
return to the previous page <
Back
> or [
C
].
return to the homepage and hold [
C
].
Menu functions
Browser
(Menu 4)
47
•
File manager
: access image, video, sound, and
music files stored in the phone’s memory.
Exiting the browser
Press [ ] to exit the browser.
Bookmarks
(Menu 4.2)
Use this menu to save URL addresses in order to
quickly access web pages.
Adding a bookmark
1. Select an empty location.
2. Enter a title for the bookmark and press [Down].
3. Enter a URL address and press [ ].
Accessing a bookmarked page
Selecting a bookmark item launches the web browser
and access the associated web page.
Using bookmark options
After saving an item, press <
Options
> to access the
following options:
•
Go
: access the bookmarked web page.
•
Edit
: edit the URL address and title of the
bookmark.
•
Delete
: delete the bookmark or all bookmarks.
Go to URL
(Menu 4.3)
Use this menu to manually enter a URL address and
access the associated web page.
Clear cache
(Menu 4.4)
Use this menu to clear information stored in the cache.
Profile settings
(Menu 4.5)
Use this menu to set up servers for the web browser.
Contact your service provider for details about your
settings options.
For each server, the following options are available:
•
Profile
name
: assign a name to the server profile.
•
Home
URL
: set the address of your homepage.
•
Bearer
: select a bearer for each type of network
address accessed.
48
Menu functions
•
Proxy
: select whether or not the phone uses a
proxy server to launch the web browser. Your
service provider can tell you if your network
requires a proxy server, and they can give you the
appropriate settings.
•
GPRS settings
: customise the following GPRS
network settings:
When the proxy is set to
Enable
:
Proxy IP
: enter the web gateway address.
Proxy port
: enter the port number.
APN
: enter the access point name of the GPRS
network gateway.
Login ID
: enter the user ID.
Password
: enter the password.
When the proxy is set to
Disable
:
DNS1
: enter the primary address.
DNS2
: enter the secondary address
.
APN
: enter the access point name of the GPRS
network gateway.
Login ID
: enter the user ID
.
Password
: enter the password
.
•
GSM settings
: customise the following GSM
network settings:
When the proxy is set to
Enable
:
Proxy IP
: enter the web gateway address.
Proxy port
: enter the port number.
Dial number
: enter the PPP server phone number.
Login ID
: enter the user ID.
Password
: enter the password.
Data call type
: select a data call type.
When the proxy is set to
Disable
:
DNS1
: enter the primary address.
DNS2
: enter the secondary address.
Dial number
: enter the PPP server phone number.
Login ID
: enter the user ID.
Password
: enter the password.
Data call type
: select a data call type.
Menu functions
Messages
(Menu 5)
49
Current profile
(Menu 4.6)
Use this menu to activate one of the proxy servers you
have set up.
Messages
(Menu 5)
Use the
Messages
menu to send and receive text
messages, multimedia messages, and e-mails. You
can also use push message and cell broadcast
message features.
To access this menu, press <
Menu
> in Idle mode and
select
Messages
.
Create new message
(Menu 5.1)
Use this menu to create and send messages.
Text message
(Menu 5.1.1)
Short Message Service (SMS) allows you to send or
receive text messages that may include simple
pictures, animated images, and melodies.
1. Enter your message.
2. Press <
Options
> to access the following options
for creating a message:
•
Insert
: add a template, Phonebook entry, or
bookmark.
•
Add picture
/
Add animation
/
Add melody
:
attach a simple image, animated image, or
melody.
•
Attach
: attach a name card or calender data
as a data format attachment.
•
Text style
: change the text attributes.
3. When you have finished, press <
Options
> and
select
Save and send
or
Send only
.
4. Enter a destination number.
To send the message to more than one recipient,
fill in additional destination fields.
5. Press [ ] to send the message.
The maximum number of characters allowed in a
message varies by service provider. If your
message exceeds the maximum number of
characters, the phone will split the message.
50
Menu functions
Multimedia message
(Menu 5.1.2)
Multimedia Message Service (MMS) delivers messages
containing a combination of text, image, video, and
audio, from phone to phone or from phone to e-mail.
1. Select the
Subject
line.
2. Enter the message subject and press [ ].
3. Select the
Picture & Video
or
Sound
line and add
an image, a video, or a sound file.
4. Select the
Message
line.
5. Enter the message text and press [ ].
6. Press <
Options
> to access the following options
for editing the message:
•
Edit
: edit the subject or text of your message.
•
Change image
/
Change video
/
Change
sound
: replace an added item.
•
Add page
: add pages. Move to each page by
pressing [Left] or [Right].
•
Delete page
: delete an added page.
•
Edit page
: change the duration of page display
or move the page forward among the other
pages.
•
Attach
: attach Phonebook entries as name
cards or calender data as data format
attachments.
•
Remove subject
/
Remove message
/
Remove media
/
Remove sound
: remove an
added item.
7. When you have finished, press <
Options
> and
select
Send
.
8. Enter a phone number or an e-mail address.
To send the message to more than one recipient,
fill in additional destination fields.
9. Press [ ] to send the message.
• The maximum size allowed for a message can
differ, depending on your service provider.
• Depending on the file type or DRM (Digital
Rights Management) system, some files may
not be able to be forwarded.
Menu functions
Messages
(Menu 5)
51
Email
(Menu 5.1.3)
You can create and send e-mails that include text,
audio, and images. To use this feature, you need to
subscribe to an e-mail service and set up your e-mail
account and profile.
p. 60
1. Select the
Subject
line.
2. Enter the subject of your e-mail and press [ ].
3. Select the
Message
line.
4. Enter the e-mail text and press [ ].
5. Select the
File attach
line and select one of the
following options to add files:
•
Add image
/
Add videos
/
Add sounds
/
Add
music
: add media files stored in the phone’s
memory.
•
Other files
: add document files stored in the
phone’s memory or on a memory card.
•
Memory card
: add files stored on a memory
card, if inserted.
•
Attach
: attach name cards or calender data as
data format attachments.
6. Press <
Options
> to access the following options
to edit the e-mail:
•
Edit
: edit the subject or text.
•
Remove subject
/
Remove message
: clear
the subject or text.
•
Remove
: delete the selected attachment or all
attachments.
•
Remove all attachments
: delete all
attachments.
7. When you have finished, press <
Options
> and
select
Send
.
8. Enter an e-mail address.
To send the e-mail to more than one recipient, fill
in additional destination fields.
9. Press [ ] to send the e-mail.
Depending on the file type or DRM (Digital
Rights Management) system, some files may
not be able to be forwarded.
52
Menu functions
My messages
(Menu 5.2)
Use this menu to access messages you have received,
sent, or which have failed in sending.
Inbox
(Menu 5.2.1)
This folder stores all of the messages you have
received, except for e-mails.
Viewing a message
The following icons may appear on the message list to
show the message type:
• SMS/Delivery report
• MMS
• MMS notification ( : Being retrieved,
: Failed to retrieve)
• Push message
Using message options
While viewing a message, press <
Options
> to access
the following options:
SMS messages
•
Reply via
: reply to the sender via SMS or MMS.
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Move to phone
/
Move to SIM
: move the
message between the SIM card and the phone’s
memory.
•
Add to block list
: add the sender’s number to the
Block number list.
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Cut media
: save media content from the message
to your phone’s memory.
•
Protection
: protect the message from being
deleted.
•
Print via bluetooth
: print the message by
connecting the phone to a printer via Bluetooth.
• Depending on the DRM (Digital Rights
Management)
system, messages having web
content may not be
able to be forwarded.
• A
!
icon next to a message means that the
message is of high priority. A grey-coloured
message icon indicates low priority.
Menu functions
Messages
(Menu 5)
53
MMS messages/MMS notifications
•
Retrieve
: retrieve the MMS message from the
MMS server.
•
Reply via SMS
: send a reply via SMS.
•
Reply via MMS to
: send a reply via MMS.
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Add to block list
: add the sender’s number to
Block number list.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Cut media
: save media content from the message
to your phone’s memory.
•
Properties
: access the message properties.
Push messages
•
Go to URL
: connect to the URL specified in the
message.
•
Delete
: delete the message.
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the message.
Delivery reports
•
Delete
: delete the report.
Draft
(Menu 5.2.2)
This folder stores messages you have saved to send at
a later time.
Outbox
(Menu 5.2.3)
This folder stores messages that the phone is
attempting to send or has failed to send.
The following icons are available to show the message
status:
• Being sent
• Failed to send
While viewing a message, press <
Options
> to access
the following options:
•
Cancel sending
: cansel sending the message, if
the message is being sent.
•
Open file
: open the selected file.
•
Save file
: save the selected file.
•
Send
again
: retry sending the message.
•
Forward
: forward the message to other people.
54
Menu functions
•
Delete
: delete the message.
•
Move to phone
/
Move to SIM
: move the SMS
message between the SIM card and the phone’s
memory.
•
Print via bluetooth
: print the message by
connecting the phone to a printer via Bluetooth.
•
Protection
: protect the message from being
deleted.
•
Properties
: access the message properties.
Sentbox
(Menu 5.2.4)
This folder stores messages that you have sent.
While viewing a message, press <
Options
> to access
the following options:
•
Open file
: open the selected file.
•
Save file
: save the selected file.
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Move to phone
/
Move to SIM
: move the SMS
message between the SIM card and the phone’s
memory.
•
Print via bluetooth
: print the selected message
by connecting the phone to a printer via Bluetooth.
•
Protection
: protect the message from being
deleted.
•
Properties
: access the message properties.
Email box
(Menu 5.2.5)
This folder stores e-mails that you have received.
Viewing an e-mail
1. Select an e-mail account.
2. Press <
Yes
> when
Check new mail
displays, or
press <
Options
> and select
Check new mail
.
The phone checks the e-mail server and downloads
new e-mails.
The following icons may appear on the list to show
the e-mail status:
• Retrieved from the server
• Being retrieved
• Failed to retrieve.
A
!
icon next to a message means that the
message is of high priority. A grey-coloured
message icon indicates low priority.
Menu functions
Messages
(Menu 5)
55
3. Select an e-mail or a header.
4. Press [ / ] to view other pages in the e-mail.
Press and hold [ / ] to move to the first or last
page.
5. Press [ ] or [ ] to view the previous or next
e-mail.
Using e-mail options
While viewing an e-mail or a header, press
<
Options
> to access the following options:
•
Retrieve
: retrieve the body of the e-mail from the
e-mail server.
•
Open file
: open the selected file.
•
Save file
: save the selected file.
•
Reply to
: send a reply to the sender or to the
sender and all of the other recipients.
•
Forward
: forward the e-mail to other people.
•
Delete
: delete the e-mail.
•
Add to block list
: add the sender’s e-mail
address or the e-mail subject to the Block list.
•
Cut address
: extract URLs, e-mail addresses, or
phone numbers from the e-mail.
•
Cut attachment
: save the attached files from the
e-mail to your phone’s memory.
•
Print via bluetooth
: print the message by
connecting the phone to a printer via Bluetooth.
•
Protection
: protect the e-mail from being deleted.
•
Properties
: access the e-mail properties.
My folder
(Menu 5.2.6)
Use this menu to view the messages you have moved
to this folder using the
Move to my folder
option
while viewing the messages list.
Templates
(Menu 5.3)
Use this menu to make and use templates of
frequently used messages.
Text template
(Menu 5.3.1)
You can create SMS templates with the sentences you
use frequently so that you can retrieve and insert
them when composing an SMS message.
56
Menu functions
Creating a template
1. Select an empty location.
2. Enter a message and press [ ].
Using template options
From the template list, press <
Options
> to access
the following options:
•
Edit
: edit the selected template.
•
Send message
: create and send an SMS, MMS, or
e-mail message using the template.
•
Delete
: delete the selected template.
MMS template
(Menu 5.3.2)
You can access default MMS templates or ones you
have saved so that you can use them in composing an
MMS message.
From the template list, press <
Options
> to access
the following options:
•
View
: open the selected template.
•
Send message
: create and send a new message.
•
Edit
: edit the template.
•
Add new
: add a new template.
•
Delete
: delete the selected template or all
templates.
Delete all
(Menu 5.4)
Use this menu to delete messages in each message
folder all at once.
1. Press [ ] to select the message folders to be
cleared.
2. Press <
Delete
>.
3. Press <
Yes
> to confirm the deletion.
Settings
(Menu 5.5)
Use this menu to set up various options for using the
messaging service.
Text message
(Menu 5.5.1)
You can configure SMS settings.
•
Send settings
: set up the options for sending
SMS messages:
Menu functions
Messages
(Menu 5)
57
Reply path
: allow recipients to reply to you
through your SMS server.
Delivery report
: set the network to inform you
when your messages have been delivered.
Character support
: select a character encoding
type. If you select
Auto
, the phone switches the
encoding type from GSM-alphabet to uni-code if
you enter a uni-code character. Use of uni-code
encoding will reduce the maximum number of
characters in a message to about half. If this menu
is not shown, your phone provides automatic
character encoding by default.
Validity period
: set the length of time your
messages are stored in the SMS server.
Message type
: set the default message type. The
network can convert the messages into the
selected format.
Service centre
: store or change the number of
your SMS server.
•
Block number
: specify phone numbers from
which messages will not be accepted.
Multimedia message
(Menu 5.5.2)
You can configure MMS settings.
•
Send settings
: set up the options for sending
MMS messages:
Delivery report
: set the network to inform you
when your messages have been delivered.
Address hiding
: set your address to be hidden
from the recipient’s phone.
Read reply
: send a read-reply request along with
your messages.
Priority
: set the priority level of messages.
Expiry date
: set the length of time messages are
stored in the MMS server.
Delivery after
: set a time delay before messages
are sent.
Send size
: select a maximum size of attached
items allowed for messages.
•
Receive settings
: set up the options for receiving
MMS messages:
Anonymous reject
: reject messages from
unknown senders.
58
Menu functions
Advert allowed
: accept advertisements.
Report allowed
: set the network to inform the
sender when a message has been delivered to you.
Home reception
: determine if your phone
retrieves new messages automatically when you
are in your home service area.
Roaming reception
: determine if your phone
retrieves new messages automatically when you
are roaming on another network.
Reception within home network or abroad has the
following options:
-
Automatic
: the phone automatically retrieves
messages from the server.
-
Reject
: the phone rejects all messages.
-
Manual
: the phone displays notifications. Use
the
Retrieve
option to manually download new
messages.
•
MMS profiles
: configure required network
settings for MMS. The last profile accessed is
automatically activated for sending or receiving
subsequent messages.
Current profile
: select a profile.
Profile settings
: customise the following options
for each profile:
Profile name
: assign a name to the MMS profile.
Server URL
: enter the address of your MMS
server.
Proxy
: connect to the GPRS network using the
proxy server.
GPRS settings
: customise the settings required
for connecting to the GPRS network:
When the proxy is set to
Enable
:
IP address
: enter the IP address.
Port
: enter the port number.
APN
: enter the access point name used for the
address of the GPRS network.
Login ID
: enter the user ID.
Password
: enter the password.
Check with your service provider before you
change any MMS settings on your phone.
Menu functions
Messages
(Menu 5)
59
When the proxy is set to
Disable
:
DNS1
: enter the primary address.
DNS2
: enter the secondary address.
APN
: enter the access point name used for the
address of the GPRS network.
Login ID
: enter the user ID.
Password
: enter the password.
Version
: select an available OMA version and
maximum size limit for sending or receiving
messages.
•
Block number
: specify phone numbers from
which messages will not be accepted.
Email
(Menu 5.5.3)
You can configure default e-mail settings.
•
Send settings
: set up the options for sending
e-mails:
Send copy to self
: send a copy of your e-mails to
your e-mail account.
Delivery confirm
: set the network to inform you
when your e-mails have been delivered.
Read confirm
: send a read-reply request along
with e-mails.
Priority
: select the priority level of e-mails.
Include signature
: attach your name, phone
number, a simple memo, or a tag line to your
e-mails.
Edit name
: edit the name in your signature.
Edit telephone number
: edit the phone number
in your signature.
Edit note
: edit the tag line in your signature.
•
Receive settings
: set up the options for receiving
e-mails:
Check interval
: determine how often the phone
checks the server for incoming e-mails. If you
select
Not used
, use the
Check new mail
option
to receive new e-mails manually.
Depending on your service provider, it may not
be possible to support the maximum limit
295KB. In this case, try again after changing the
setting to 100KB.
You cannot change e-mail profile and account
settings while an e-mail is being sent or retrieved.
60
Menu functions
Read reply
: determine whether or not the phone
sends a read-reply for incoming e-mails. If you
select
Announce
, the phone asks you to send a
read-reply.
Retrieve option
: set whether the phone
downloads e-mail headers only or e-mail headers
and bodies both.
Delete option
: determine whether e-mails are
deleted immediately or the next time you connect
to the server.
Reject if over
: determine the maximum size for
incoming e-mails. Your phone will reject e-mails
that exceed the specified size.
Leave a copy of messages on the server
: leave
copies of e-mails on the e-mail server after
retrieving.
•
Email account
: set up an e-mail account and
select an account to be used.
Current account
: select an account.
Account settings
: configure e-mail accounts
using different e-mail servers. Set the options for
each account:
In use
: select this option to use the account and
to display the account and to display the account in
Email box
.
Account name
: enter a name for the currently
selected account.
User name
: enter a user name.
Email address
: enter your e-mail address.
Reply address
: set an e-mail address to receive
read-reply messages from recipients.
User ID
: enter the user ID.
Password
: enter the password.
SMTP server
: enter the IP address or host name
of the outgoing e-mail server.
SMTP port
: enter the SMTP port number.
Protocol type
: select the protocol for the
incoming e-mail server. The remaining options
depend on the protocol type setting.
When the protocol type is
POP3
:
POP3 server
:
enter the IP address or host name
of the server that receives your e-mail.
Menu functions
Messages
(Menu 5)
61
POP3 port
: enter the POP3 port number.
APOP login
: connect to the server by using the
APOP login scheme.
Secure connection
: use a secure connection for
the e-mail service.
When the protocol type is
IMAP4
:
IMAP4 server
: enter the IP address or host name
of the server that receives your e-mail.
IMAP4 port
: enter the IMAP4 port number.
Include attachments
: select this option to
receive attachments with e-mails.
Max. Emails retrieved
: set the number of
headers you will retrieve from the server.
Secure connection
: use a secured connection for
e-mail service.
•
Email profile
: configure the network settings
required to send or receive e-mails.
Current profile
: select a profile.
Profile settings
: configure up to five e-mail
profiles. For each profile, the following options are
required to connect to the GPRS network:
Profile name
: enter a name for the e-mail profile.
APN
: enter the access point name used for the
GPRS network address.
Login ID
: enter the user ID.
Password
: enter the password.
DNS1
: enter the primary address.
DNS2
: enter the secondary address.
•
Block list
: specify e-mail addresses or subjects
you want to reject.
Push message
(Menu 5.5.4)
You can change the settings for receiving push
messages from the wireless web server.
•
Receive
: set how your phone receives push
messages.
•
Service centre
: specify the address of the server
from which you want to receive push messages, if
the
Receive
option is set to
SMS-C specific
.
You cannot change e-mail profile settings while
an e-mail is being sent or retrieved.
62
Menu functions
Broadcast messages
(Menu 5.6)
You can change the settings for receiving CB
messages.
•
Read
: open received CB messages.
The
Temporary
box saves network messages until
the phone is switched off.
The
Archive
box saves network messages
indefinitely. Press <
Options
> and select
Save
to
save messages to the
Archive
box when a text
notification appears.
•
Receive
: select to receive CB messages, or not.
•
Channel
: indicate the channels from which you
wish to receive CB messages. Please contact your
service provider for further details.
•
Language
: select the preferred languages in
which CB messages display.
Memory status
(Menu 5.7)
Use this menu to view the amount of memory
currently in use in each folder.
File manager
(Menu 6)
The
File manager
menu allows you to access images,
videos, music files, and sound files stored in the
phone’s memory or on a memory card.
To access this menu, press <
Menu
> in Idle mode and
select
File manager
.
Images
(Menu 6.1)
This menu displays photos you have taken and images
you have downloaded, received in messages, or
imported from your computer.
Viewing an image
1. Select an image folder.
2. Select an image.
Viewing a slide show
You can view your photos as a slide show, a sequential
presentation of each photo in the current folder.
According to the DRM (Digital Rights Management)
system, web content may not be able to be
forwarded. The content is indicated by the icon.
Menu functions
File manager
(Menu 6)
63
1. Select
Photos
.
2. Press <
Options
> and select
Slide show
.
3. Select an interval option.
The slide show begins.
4. Press <
Cancel
> to stop the slide show.
Using image options
While viewing an image, press <
Options
> to access
the following options:
•
List
: return to the image list.
•
Send via
: send the file via MMS, e-mail, or
Bluetooth.
•
Set as
: set the image as wallpaper for the display
or as a caller ID image for a Phonebook entry.
•
Edit
: add emoticons, frames, or effects to the
image.
•
Move to
: move the selected files to another folder
or to a memory card.
•
Copy to card
: copy the file to a memory card.
•
Delete
: delete the file.
•
Rename
: change the file name.
•
Share for Bluetooth
: share the file or all files
with other Bluetooth devices.
•
Print via
: print the file by connecting the phone to
a printer via USB cable or Bluetooth. Select
whether to print the image only or with the border.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Videos
(Menu 6.2)
This menu displays video clips you have recorded,
downloaded, received in messages, or imported from
your computer.
Playing a video clip
1. Select a video folder.
2. Select a video clip.
Video clips recorded on other devices, such as
camcorders, may not play correctly.
64
Menu functions
During playback, use the following keys:
Using video options
From a video screen, press < > to access the
following options:
•
Play
: begin playback.
•
Send via
: send the file via MMS, e-mail, or
Bluetooth.
•
Move to
: move the file to another folder or to a
memory card.
•
Copy to card
: copy the file to a memory card.
•
Delete
: delete the file or all files.
•
Rename
: change the file name.
•
Share for Bluetooth
: share the file or all files
with other Bluetooth devices.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Music
(Menu 6.3)
This menu displays MP3 files you have downloaded or
imported from your computer.
Select
Music
→
a file. The MP3 player opens.
p. 38
Sounds
(Menu 6.4)
This menu displays voice memos you have recorded,
and sound files you have downloaded, received in
messages, or imported from your computer.
Playing a sound clip
1. Select a sound folder.
2. Select a sound clip. For a voice memo, see
Voice
recorder
.
p. 40
Key Function
Pauses or resumes playback.
Left Moves backward in a file.
Right Skips forward in a file.
/ Adjusts the volume.
Down Stops playback.
Menu functions
Calendar
(Menu 7)
65
Using sound options
From a sound screen, press <
Options
> to access the
following options:
•
List
: return to the sound list.
•
Send via
: send the file via MMS, e-mail, or
Bluetooth.
•
Set as
: set the file as your ringtone, alarm tone,
or as a ringtone for a Phonebook entry.
•
Move to
/
Move to fovorite
: move the file to
another folder or to a memory card.
•
Copy
: copy the file to the phone’s memory or to a
memory card.
•
Delete
: delete the file.
•
Rename
: change the file name.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Other files
(Menu 6.5)
Files that you have received but which are not
supported by your phone are stored in this folder. You
cannot open these files on the phone.
Memory card
(Menu 6.6)
Use this menu to access the files stored on a memory
card. This menu is shown only when a memory card is
inserted into the phone.
Memory status
(Menu 6.7)
Use this menu to view memory information for media
items in each folder or on a memory card. Press [Left]
or [Right] to view the memory status by size or
number of items.
Calendar
(Menu 7)
The
Calendar
menu enables you to keep track of your
schedule.
To access this menu, press <
Menu
> in Idle mode and
select
Calendar
.
Consulting the calendar
When you enter the
Calendar
menu, the calendar in
Month view appears with today’s date indicated by a
red box.
66
Menu functions
Selecting a day
• Press [Left] or [Right] to move by day.
• Press [Up] or [Down] to move by week.
• Press [ / ] to move by month.
Using calendar options
Press <
Options
> to access the following options:
•
View mode
: change the view mode of the
calendar.
p. 68
•
Create
: add a new event.
next section
•
Go to
: select today’s date or enter a specific date.
•
Sort by
: sort items by type of event.
•
Delete
: delete the items stored on the calendar by
using various deleting options.
•
Missed alarm events
: view events whose alarms
you have missed.
•
Memory status
: access memory information for
the event items stored on the calendar.
Creating an event
You can store scheduled events, anniversaries, and To
do items on the calendar. More than one event per day
can be stored.
Entering a new scheduled event
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
Schedule
or
Miscellaneous
.
3. Enter information or change the settings:
•
Subject
: enter a title for the event.
•
Details
: enter event details.
•
Start date
and
Start time
: enter the starting
date and time for the event.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
End date
and
End time
: enter the ending date
and time for the event.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
You can delete recurring events in Day view only.
Menu functions
Calendar
(Menu 7)
67
•
Location
(for
Schedule
): enter information
about the event location.
•
Alarm
: set an alarm for the event.
•
before
: set how long before the event the
alarm is to alert you.
•
Alarm tone
: select an alarm tone.
•
Repeat
(for
Schedule
): set the event to recur
and select a repeat unit.
•
until
(for
Schedule
): set the ending date, if
the event will recur.
4. Press <
Save
> to save the event.
Entering a new anniversary
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
Anniversary
.
3. Enter information or change the settings:
•
Occasion
: enter information about the
anniversary.
•
Date
: enter the date.
•
Alarm
: select to set an alarm for the
anniversary.
•
before
: set how long before the event the
alarm is to alert you.
•
Alarm time
: enter the time for the alarm to
ring.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
Alarm tone
: select an alarm tone.
•
Repeat every year
: set the phone to remind
you of the anniversary every year.
4. Press <
Save
> to save the event.
Entering a To do item
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
To do
.
3. Enter information or change the settings:
•
To do
: enter information about the item.
•
Start date
: enter the starting date.
•
Due date
: enter the ending date.
•
Priority
: select a priority level.
4. Press <
Save
> to save the event.
68
Menu functions
Viewing an event
Once you have scheduled events, the event icons and
the number of events for a specific day appears at the
bottom of the calendar.
Accessing an event
1. Select a date on the calendar to display the events
for the day.
2. Select an event to view its details.
3. Press [Left] or [Right] to access the other events
scheduled for the selected day.
Using event options
While viewing an event, press <
Options
> to access
the following options:
•
Edit
: edit the event.
•
Create
: add a new event.
•
Send via
: send the event via SMS, MMS, e-mail,
or Bluetooth.
•
View mode
: change the view mode of the
calendar.
•
Done
/
Undone
: change the status of the selected
To do item.
•
Delete
: delete the event.
•
Print via bluetooth
:
print the event by
connecting the phone to a printer via Bluetooth.
Viewing an event in a different mode
You can change the calendar display to Day view or
Week view. Press <
Options
> and select
View mode
→
a view mode.
Day view
You can view events for the selected date. Select an
event to view its details.
The following icons may display to indicate the event
status:
• Alarm set
• Recurring event
• Schedule • Anniversary
• Miscellaneous • To do item
Menu functions
Camera
(Menu 8)
69
• To do item priority (Red: high, Blue: normal,
Grey: low)
• Completed To do item
Week view
You can view events for the selected week. A cell on
the timetable indicates the presence of a schedule
item. Select a cell in the day you want.
Camera
(Menu 8)
You can use the camera module embedded in your
phone to take photos and record videos.
To access this menu, press <
Menu
> in Idle mode and
select
Camera
, or press and hold
[
]
.
Taking a photo
You can take photos in various modes. The camera
produces JPEG photos.
1. Access the
Camera
menu or press and hold [
]
to turn on the camera.
2. Adjust the image to be captured.
• Press < > to access camera options.
next section
• Use the keypad to change the camera settings
or switch to other modes.
p. 71
3. Press [
]
to take a photo. The photo is saved in
the
Photos
folder.
• Do not take photos of people without their
permission.
• Do not take photos in a place where cameras are
not allowed.
• Do not take photos in a place where you may
interfere with another person’s privacy.
When you take a photo in direct sunlight or in bright
conditions, shadows may appear on the photo.
4.
To Press
access photo options <
Options
>.
p. 71
delete the photo <
Delete
> and then
<
Yes
>.
return to Capture mode [ ].
70
Menu functions
Using camera options in Capture mode
In Capture mode, press < > to access the following
options:
•
Record video
: switch to Record mode.
•
Shooting mode
: take a photo in the following
modes:
Single shot
: take a photo in normal mode. You
can select whether or not the camera automatically
saves a photo.
Multi shot
: take a series of action stills. You can
select the number of photos the camera will take
and the shutter speed.
Mosaic shot
: take several stills and save them in
one frame. You can select the layout.
•
Effects
: change the colour tone or apply a special
effect.
•
Frames
: apply a decorative frame.
•
Timer
: set a time delay before the camera takes a
photo.
•
Go to photos
: access the
Photos
folder.
•
Settings
: change the default settings for taking a
photo.
Size
: select an image size.
Quality
: select an image quality setting.
View finder
: select a preview screen.
ISO
: change the ISO setting, which controls the
sensitivity of your camera. For low light situations,
lower the ISO number to increase image quality.
The higher the ISO number, the faster the camera
shutter functions and the more sensitive the
camera is to light. Higher ISO settings may bring
some distortion to an image.
Spot focus
: adjust the exposure based on a
specific area of the image. Select
On
to display the
spot focus frame in the middle of the image, and
change the exposure according to the brightness of
the image fragment in the frame.
Shutter sound
: select the sound that you hear
when you press the shutter release, [
]
.
Zoom sound
: turn the sound effect for zooming
on or off.
Menu functions
Camera
(Menu 8)
71
Brightness sound
: turn the sound effect for
brightness adjustment on or off.
Default name
: change the default prefix of the
photo name.
•
Camera short cuts
: view the functions of the
keys you can use in Capture mode.
Using the keypad in Capture mode
You can use the keypad to customise your camera
settings in Capture mode.
Using photo options
After saving a photo, press <
Options
> to access the
following options:
•
Take another
: return to Capture mode.
•
Send via
: send the file via MMS, e-mail, or
Bluetooth.
Key Function
Left/Right Adjusts the image brightness.
Up/Down Zooms in or out.
Flips the image vertically.
Shows the mirror image.
1
Switches to Record mode.
p. 72
2
Changes the image size.
3
Changes the image quality.
4
Changes the shooting mode.
5
Changes the colour tone or applies a
special effect.
6
Reduces the distortion on the image to
maximise detail and sharpness.
7
Selects a decorative frame.
8
Sets the timer.
9
Goes to the
Photos
folder.
Changes the preview screen.
Key Function
72
Menu functions
•
Set as
: set the photo as wallpaper for the display
or as a caller ID image for a Phonebook entry.
•
Delete
: delete the file.
•
Rename
: change the file name.
•
Go to photos
: access the
Photos
folder.
p. 62
•
Share for Bluetooth
: share the file or all files
with other Bluetooth devices.
•
Print via bluetooth
: print the file by connecting
the phone to a printer via Bluetooth.
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Recording a video
You can record a video of what is displayed on the
camera screen and save it.
1. In Capture mode, press [
1
].
2. Adjust the image to be captured.
• Press < > to access camera options.
next section
• Use the keypad to change the camera settings
or switch to other modes.
p. 73
3. Press [
]
to start recording.
4. Press [
]
to stop recording. The video is
automatically saved in the
Videos
folder.
Using camera options in Record mode
In Record mode, press < > to access the following
options:
•
Take a photo
: switch to Capture mode.
•
Effects
: change the colour tone or apply a special
effect.
•
Timer
: set a time delay before the camera starts
recording.
•
Go to videos
: access the
Videos
folder.
5.
To Press
play back the video clip [ ].
access video options the left soft key.
p. 74
delete the video clip [
C
] and then <
Yes
>.
return to Record mode the right soft key.
Menu functions
Camera
(Menu 8)
73
•
Settings
: change the following settings for
recording a video:
Recording mode
: select a video recording mode.
Select
Limit of MMS
to record a video suitable for
messaging. The video clip is saved in 3GP format.
Select
Normal
to record a video within the limit of
the currently available memory. The video clip is
saved in MP4 format.
Size
: select a frame size.
Quality
: select an image quality setting.
Audio rec.
: record audio with a video clip.
Zoom sound
: turn the sound effect for zooming
on or off.
Brightness sound
: turn the sound effect for
brightness adjustment on or off.
Default name
: change the default prefix of the
video clip name.
•
Camcorder short cuts
: view the functions of the
keys you can use in Record mode.
Using the keypad in Record mode
You can use the keypad to customise your camera
settings in Record mode:
Key Function
Left/Right Adjusts the image brightness.
Up/Down Zooms in or out.
Flips the image vertically.
Shows the mirror image.
1
Switches to Capture mode.
p. 69
2
Changes the frame size.
3
Changes the image quality.
4
Changes the video recording mode.
5
Changes the colour tone or applies a
special effect.
6
Reduces the distortion on the image to
maximise detail and sharpness.
74
Menu functions
Using video options
After saving a video clip, press < > to access the
following options:
•
Record another
: return to Record mode.
•
Send via
: send the file via MMS, e-mail, or
Bluetooth.
•
Delete
: delete the file.
•
Rename
: change the file name.
•
Go to videos
: access the
Videos
folder.
p. 63
•
Protection
: protect the file from being deleted.
•
Properties
: access the file properties.
Settings
(Menu 9)
The Settings menu provides you with various setting
options to customise the phone to your preferences
and needs. You can also reset the settings to their
default values.
To access this menu, press <
Menu
> in Idle mode and
select
Settings
.
Time & Date
(Menu 9.1)
Use this menu to change the time and date displayed
on your phone. Before setting the time and date,
specify your time zone in the
World time
menu.
p. 43
•
Set time
: enter the current time.
•
AM/PM
: select
AM
or
PM
in 12-hour time format.
•
Time format
: select a time format.
•
Set date
: enter the current date.
•
Date format
: select a date format.
7
Mutes or unmutes the audio.
8
Sets the timer.
9
Goes to the
Videos
folder.
Changes the preview screen.
Key Function
Menu functions
Settings
(Menu 9)
75
Phone settings
(Menu 9.2)
Many different features of your phone’s system can be
customised to suit your preferences.
Language
(Menu 9.2.1)
Use this menu to select one of several languages for
the display text.
Greeting message
(Menu 9.2.2)
Use this menu to enter the greeting that is displayed
briefly when the phone is switched on.
Short cut
(Menu 9.2.3)
You can use the Navigation keys as shortcuts to access
specific menus directly from Idle mode. Use this menu
to assign a shortcut to a key.
Assigning a shortcut menu
1. Select a key to be used as a shortcut key.
2. Select a menu to be assigned to the key.
Using shortcut options
Press <
Options
> to access the following options:
•
Change
: assign or change a shortcut menu.
•
Remove
: deactivate the shortcut assignment to
the selected key.
•
Remove all
: deactivate all shortcut assignments.
Volume key
(Menu 9.2.4)
Use this menu to set whether the phone mutes the call
ringer or rejects a call if you press and hold [ / ]
when a call comes in.
Extra settings
(Menu 9.2.5)
You can turn on or off the automatic redialling or
answering feature, and the voice clarity feature. You
can also lock the keypad automatically.
•
Auto redial
: set the phone to make up to ten
attempts to redial a phone number after an
unsuccessful call.
•
Anykey
answer
: answer an incoming call by
pressing any key, except <
Reject
> or [ ].
76
Menu functions
•
Auto keylock
: set the phone to lock the keypad
automatically when the display turns off.
•
Voice clarity
: increase the microphone’s
sensitivity to allow the other person on the phone
to hear your voice clearly, even though you may be
whispering.
Display settings
(Menu 9.3)
Use this menu to change settings for the display and
backlight.
Wallpaper
(Menu 9.3.1)
You can change the background image that is
displayed in Idle mode.
Text display
(Menu 9.3.2)
You can customise the text appearance for the idle
screen.
•
Text position
: select a text position on the
display. If you don’t want to display text in Idle
mode, select
Off
.
•
Text style
: select a text style.
•
Text colour
: select a text colour.
Calendar
(Menu 9.3.3)
Use this menu to display the calendar of the current
month on the idle screen.
Skin
(Menu 9.3.4)
You can select a skin colour pattern for Menu mode.
LCD brightness
(Menu 9.3.5)
You can adjust the brightness of the display for
varying lighting conditions.
Dialing font colour
(Menu 9.3.6)
Use this menu to display numbers in colours when
entering a phone number for dialling.
Show caller information
(Menu 9.3.7)
Use this menu to set the phone to display missed call
notifications with the most recently missed caller’s
information.
Menu functions
Settings
(Menu 9)
77
Sound settings
(Menu 9.4)
Use this menu to customise various sound settings.
Incoming call
(Menu 9.4.1)
Use this menu to change the sound settings for
incoming calls.
•
Ring tone
: select a ringtone to be used for the call
ringer.
•
Volume
: select a ringer volume.
•
Alert type
: specify how you are to be informed of
incoming calls.
Keypad tone
(Menu 9.4.2)
Use this menu to select the tone that the phone
sounds when you press a key.
Message tone
(Menu 9.4.3)
Use this menu to change the sound settings for
incoming messages or e-mails.
•
Tone
: select one of several message tones.
•
Alert type
: specify how you are to be informed
when a message comes in.
•
Repetition
: specify how often the phone informs
you of a new message.
Power on/off
(Menu 9.4.4)
Use this menu to select the melody that the phone
sounds when it is switched on or off.
Quiet mode
(Menu 9.4.5)
Use this menu to set how the phone acts to alert you
to a specific event while in Quiet mode.
Extra tones
(Menu 9.4.6)
Use this menu to customise additional tones for the
phone.
•
Minute
minder
: set the phone to beep every
minute during an outgoing call to keep you
informed of the length of your call.
•
Connection
tone
: set the phone to beep when an
outgoing call connects to the system.
You can adjust the keypad tone volume using
[ / ] in Idle mode.
78
Menu functions
•
Alerts on call
: set the phone to beep when you
receive a new message or when the time for an
alarm comes during a call.
•
Indicative
tones
: set the phone to beep when
you have made a mistake or something wrong
happens on the phone.
Light settings
(Menu 9.5)
Use this menu to change settings for the light.
Backlight
(Menu 9.5.1)
You can select the length of time the backlight stays
on or the length of time the display stays on in Dim
mode, in which the backlight is off.
•
On
: select the length of time the backlight stays
on.
•
Dim
: select the length of time the display stays on
in Dim mode after the backlight turns off. After a
specified time, the display turns off.
Keypad light
(Menu 9.5.2)
Use this menu to set how the phone controls the use
of the keypad light.
•
Use at any time
: the keypad light is always used.
•
Use at night time
: the keypad light is used only
at night.
•
Use at custom time
: specify the time period that
the keypad light is used.
Network services
(Menu 9.6)
Use this menu to access network services. Please
contact your service provider to check their availability
and subscribe to them, if you wish.
Call diverting
(Menu 9.6.1)
This network service reroutes incoming calls to a
phone number that you specify.
1. Select a call diverting option:
•
Divert always
: divert all calls.
•
Busy
: divert calls when you are on another
call.
Menu functions
Settings
(Menu 9)
79
•
No
reply
: divert calls when you do not answer
the phone.
•
Unreachable
: divert calls when you are not in
an area covered by your service provider or
when your phone is switched off.
•
Cancel
all
: cancel all call diverting options.
2. Select the type of calls to be diverted.
3. Select
Activate
. To deactivate call diverting, select
Deactivate
.
4. Move to the
Divert to
line.
5. Enter the number to which calls are to be diverted.
6. If you selected
No reply
, move to the
Seconds
line and select the length of time the network
delays before diverting a call.
7. Press <
Select
>.
Call barring
(Menu 9.6.2)
This network service allows you to restrict your calls.
1. Select a call barring option:
•
All
outgoing
: prohibit outgoing calls.
•
International
: prohibit international calls.
•
International
except to home
: only allow
calls to numbers within the current country
when you are abroad, and to your home
country.
•
All
incoming
: prohibit incoming calls.
•
Incoming
while
abroad
: prohibit incoming
calls when you use your phone outside of your
home country.
•
Cancel
all
: cancel all call barring settings,
allowing calls to be sent and received normally.
•
Change barring password
: change the call
barring password obtained from your service
provider.
2. Select the type of calls to be barred.
3. Select
Activate
. To deactivate call barring, select
Deactivate
.
4. Enter the call barring password supplied by your
service provider and press <
Select
>.
80
Menu functions
Call waiting
(Menu 9.6.3)
This network service informs you when someone is
trying to reach you while you are on another call.
1. Select the type of calls to which call waiting option
will apply.
2. Select
Activate
and press <
Select
>. To
deactivate call waiting, select
Deactivate
.
Network selection
(Menu 9.6.4)
This network service allows you to either automatically
or manually select the network to be used while
roaming outside of your home area. You can select a
network other than your home network only if there is
a valid roaming agreement between the two.
Caller ID
(Menu 9.6.5)
This network service allows you to prevent your phone
number from being displayed on the phone of the
person being called. If you select
Default
, the phone
will use the default setting provided by the network.
Voice mail server
(Menu 9.6.6)
Use this menu to store the number of the voicemail
server and access your voicemails.
•
Connect to voice mail
: connect to the voicemail
server to listen to your messages.
•
Voice server number
: enter the voicemail server
number.
Band selection
(Menu 9.6.7)
For the phone to make and receive phone calls, it
must register with an available network. Your phone
can handle any of the following types of networks:
GSM 1900, Combined GSM 900/1800, and Tri band
(GSM 900/1800/1900).
The country where you purchased your phone
determines the default band that it uses. When you
travel abroad, you may need to change to an
appropriate band.
Some networks may not allow you to change this
setting.
You must store the voicemail server number before
accessing the server. Your service provider can give
you the number.
Menu functions
Settings
(Menu 9)
81
Bluetooth
(Menu 9.7)
Using the Bluetooth feature, you can connect the
phone wirelessly to other Bluetooth devices and
exchange data with them, talk hands-free, or control
the phone remotely.
Bluetooth technology allows free wireless connections
between all Bluetooth-compliant devices within a
range of 10 meters. Since the devices communicate
using radio waves, they do not need to be in line of
sight to each other.
Setting up the Bluetooth feature
The
Bluetooth
menu provides the following options:
•
Activation
: activate or deactivate the Bluetooth
feature.
•
My devices
: search for connectable Bluetooth
devices.
•
My phone’s visibility
: allow other Bluetooth
devices to search for your phone.
•
My phone’s name
: assign a Bluetooth device
name to your phone, which is then displayed on
other devices.
•
Secure mode
: determine if the phone asks for
your confirmation when other devices access your
data.
•
Bluetooth services
: display available Bluetooth
services.
Searching for and pairing with a Bluetooth
device
1. From the Bluetooth setting options, select
My
devices
.
• If there are obstacles between the devices, the
operating distance may be reduced.
• It is recommended that you don’t use the
Bluetooth feature while using multimedia
features, such as voice recorder, camera, and
music player, or vice versa, for better
performance.
• Some devices may not be compatible with your
phone.
82
Menu functions
2. Select
Search new device
.
After searching, a list of devices to which you can
connect displays. The following icons indicate the
type of device:
The colour of the icon indicates the status of the
the device:
• Grey for unpaired devices
• Blue for paired devices
• Red for devices that are currently connected to
your phone
3. Select a device.
4. Enter a Bluetooth PIN and press <
OK
>.
This code
is used just once and you don’t need to memorise it.
When the owner of the other device enters the
same code, pairing is complete.
Using device options
From the device list, press <
Options
> to access the
following options:
•
Connect
: connect to a headset or hands-free car
kit.
•
Disconnect
: end the connection with the
connected device.
•
Browse files
: search for data from the device and
import data directly to your phone.
•
Service list
: access the Bluetooth service list of
the device.
•
Rename
: rename the paired device.
•
Authorize device
/
Unauthorize device
:
determine whether or not the phone asks you to
permit connection when other devices try to
connect to your phone.
•
Delete
: remove the selected device or all devices
from the list.
• Stereo headset • Mobile phone
• Computer • PDA
• Printer • Unknown device
• Mono headset or Hands-free car kit
Some devices, especially headsets or hands-free car
kits, may have a fixed Bluetooth PIN, such as
0000
.
If the other device has a code, you must enter it.
Menu functions
Settings
(Menu 9)
83
Sending data via Bluetooth
1. Activate the Bluetooth feature.
2. Select the application in which the item you want
to send is stored.
3. From the item list, press <
Options
> and select
Send
via
→
Bluetooth
.
4. Press [ ] to select the files you want and then
<
Send
>.
The phone searches for devices within range and
displays a list of available devices.
5. Select a device.
6. If necessary, enter the Bluetooth PIN needed for
pairing and press <
OK
>.
Receiving data via Bluetooth
To receive data via Bluetooth, your phone’s Bluetooth
feature must be active.
1. If an unauthorised Bluetooth device sends data to
your phone, press <
Yes
> to allow the device to
access your phone.
2. Press <
Yes
> to receive data.
Security
(Menu 9.8)
Use this menu to protect the phone against
unauthorised use by managing the several access
codes of your phone and SIM card.
PIN check
(Menu 9.8.1)
The 4- to 8-digit PIN (Personal Identification Number)
protects your SIM card against unauthorised use.
When this feature is enabled, the phone requires your
PIN each time it is switched on.
Change PIN
(Menu 9.8.2)
Use this menu to change your PIN. The PIN check
feature must be enabled to use this feature.
If you enter an incorrect PIN/PIN2 three times in
succession, the SIM card is blocked. To unblock it
you need to enter your PUK/PUK2 (Personal
Unblocking Key). The codes are supplied by your
service provider.
84
Menu functions
Phone lock
(Menu 9.8.3)
Use this menu to lock the phone from unauthorised
use.
When this feature is enabled, you must enter a 4- to
8-digit phone password each time the phone is
switched on.
The password is preset to
00000000
. To change the
password, use the
Change password
menu.
Change password
(Menu 9.8.4)
Use this menu to change your phone password.
Privacy
(Menu 9.8.5)
Use this menu to lock access to messages, files, or all
menu functions on the phone, except for call
functions.
When a privacy option is enabled, you must enter the
phone password to access the locked items or
functions.
SIM lock
(Menu 9.8.6)
The SIM lock feature allows your phone to work only
with the current SIM by assigning a SIM lock code. You
must enter the SIM lock code to use a different SIM
card.
FDN mode
(Menu 9.8.7)
If supported by your SIM card, Fixed Dialling Number
(FDN) mode restricts your outgoing calls to a limited
set of phone numbers. When this feature is enabled,
you can make calls only to phone numbers specified in
the FDN list.
Change PIN2
(Menu 9.8.8)
If supported by your SIM card, use this feature to
change your current PIN2.
Memory status
(Menu 9.9)
Use this menu to check the amount of memory being
used for storing data in Messages, File manager,
Calendar, Phonebook, and Java world
items. You can
also view the amount of shared memory.
85
Reset settings
(Menu 9.10)
Use this menu to reset the phone’s settings you have
changed.
1. Press [ ] to select the setting categories to be
reset.
2. Press <
Reset
>.
3. Press <
Yes
> to confirm the reset.
4. Enter the phone password and press <
OK
>.
Solve problems
Help and personal needs
To save the time and expense of an unnecessary service
call, perform the simple checks in this section before
contacting a service professional.
When you switch on your phone, the following
messages may appear:
“Insert SIM”
• Be sure that the SIM card is correctly installed.
“Enter password”
• The automatic locking function has been enabled.
You must enter the phone’s password before you
can use the phone.
“Enter PIN”
• You are using your phone for the first time. You
must enter the PIN supplied with the SIM card.
• The PIN check feature is enabled. Every time the
phone is switched on, the PIN has to be entered.
To disable this feature, use the
PIN check
menu.
The password is preset to
00000000
. You can
change this password.
p. 84
86
Solve problems
“Enter PUK”
• The PIN code has been entered incorrectly three
times in succession, and the phone is now blocked.
Enter the PUK supplied by your service provider.
“No service,” “Network failure,” or “Not done”
displays
• The network connection has been lost. You may be
in a weak signal area. Move and try again.
• You are trying to access an option for which you
have no subscription with your service provider.
Contact the service provider for further details.
You have entered a number but it was not dialled
• Be sure that you have pressed [ ].
• Be sure you have accessed the right cellular
network.
• Be sure that you have not set an outgoing call
barring option.
Your correspondent cannot reach you
• Be sure that your phone is switched on. ([ ]
pressed for more than one second.)
• Be sure that you are accessing the correct cellular
network.
• Be sure that you have not set an incoming call
barring option.
Your correspondent cannot hear you speaking
• Be sure that you have switched on the
microphone.
• Be sure that you are holding the phone close
enough to your mouth. The microphone is located
at the bottom of the phone.
The phone starts beeping and “Battery low”
flashes on the display
• Your battery is insufficiently charged. Recharge the
battery.
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ). The number of bars indicates the signal
strength from strong ( ) to weak ( ).
• Try moving the phone slightly or moving closer to a
window if you are in a building.
87
No number is dialled when you re-call a
Phonebook entry
•Use the
Contacts list
menu to ensure the number
has been stored correctly.
• Re-store the number, if necessary.
The battery doesn’t charge properly or the phone
sometimes turns itself off
• Wipe the charging contacts both on the phone and
on the battery with a clean soft cloth.
If the above guidelines do not help you to solve
the problem, take note of:
• The model and serial numbers of your phone
•Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung after-sales
service.
Health and safety information
Exposure to Radio Frequency
(RF) Signals
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S.
Government. These limits are part of
comprehensive guidelines and establish
permitted levels of RF energy for the general
population. The guidelines are based on the
safety standards that were developed by
independent scientific organizations through
periodic and through evaluation of scientific
studies.
88
Health and safety information
The standards include a substantial safety margin
designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless phones
employs a unit of measurement known as
Specific Absorption Rate (SAR). The SAR limit set
by the FCC is 1.6W/kg
*
.
SAR tests are conducted using standard operating
positions specified by the FCC with the phone
transmitting at its highest certified power level in
all tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can
be well below the maximum value. This is because
the phone is designed to operate at multiple power
levels so as to use only the power required to reach
the network. In general, the closer you are to a
wireless base station antenna, the lower the power
output of the phone. Before a new model phone is
available for sale to the public, it must be tested
and certified to the FCC that it does not exceed the
limit established by the government-adopted
requirement for safe exposure. The tests are
performed in positions and locations (e.g., at the
ear and worn on the body) as required by the FCC
for each model. While there may be differences
between the SAR levels of various phones and at
*In the U.S. and Canada, the SAR limit for mobile phones
used by the public is 1.6 watts/kg (W/kg)
averaged over one gram of tissue. The standard
incorporates a substantial margin of safety to give
additional protection for the public and to account for any
variations in measurements.
89
Health and safety information
various positions, they all meet the government
requirement.
The FCC has granted an Equipment Authorization
for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF
exposure guidelines. SAR information on this
model phone is on file with the FCC and can be
found under the Display Grant section of http://
www.fcc.gov/oet/fccid after searching on FCC ID
printed in the label on the phone.
FCC certification information for this model phone
is attached separation paper.
For Body Operation
For body worn operation, this model phone has
been tested and meets the FCC RF exposure
guidelines when used with a Samsung-supplied or
approved accessory designated for this product or
when used with and accessory that contains no
metal and that positions the handset a minimum
from the body.
The minimum distance for this model phone is
written in the FCC certification information from
the body. None compliance with the above
conditions may violate FCC RF exposure guidelines.
For more Information concerning exposure to radio
frequency signals, see the following websites:
Federal Communications Commission (FCC)
http://www.fcc.gov/rfsafety
Cellular Telecommunications Industry Association
(CTIA):
http://www.wow-com.com
U.S.Food and Drug Administration (FDA)
http://www.fda.gov/cdrh/consumer
World Health Organization (WHO)
http://www.who.int/peh-emf/en
90
Health and safety information
Precautions When Using Batteries
• Never use any charger or battery that is
damaged in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and
charger used. The battery can be charged and
discharged hundreds of times, but it will
gradually wear out. When the operation time
(talk time and standby time) is noticeably
shorter than normal, it is time to buy a new
battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
disconnect it from the power source. Do not
leave the battery connected to a charger for
more than a week, since overcharging may
shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling
or warming first.
• Do not leave the battery in hot or cold places,
such as in a car in summer or winter conditions,
as you will reduce the capacity and lifetime of
the battery. Always try to keep the battery at
room temperature. A phone with a hot or cold
battery may temporarily not work, even when
the battery is fully charged. Li-ion batteries are
91
Health and safety information
particularly affected by temperatures below 0
°ýC (32 °ýF).
• Do not short-circuit the battery. Accidental
shortcircuiting can occur when a metallic object
(coin, clip or pen) causes a direct connection
between the + and . terminals of the battery
(metal strips on the battery), for example when
you carry a spare battery in a pocket or bag.
Short-circuiting the terminals may damage the
battery or the object causing the short-circuiting.
• Dispose of used batteries in accordance with
local regulations. Always recycle. Do not dispose
of batteries in a fire.
Road Safety
Your wireless phone gives you the powerful ability
to communicate by voice, almost anywhere,
anytime. But an important responsibility
accompanies the benefits of wireless phones, one
that every user must uphold.
When driving a car, driving is your first
responsibility. When using your wireless phone
behind the wheel of a car, practice good common
sense and remember the following tips.
1. Get to know your wireless phone and its
features, such as speed dial and redial. If
available, these features help you to place your
call without taking your attention off the road.
2. When available, use a hands-free device. If
possible, add an extra layer of convenience and
safety to your wireless phone with one of the
many hands-free accessories available today.
3. Position your wireless phone within easy reach.
Be able to access your wireless phone without
removing your eyes from the road. If you get
an incoming call at an inconvenient time, let
your voice mail answer it for you.
92
Health and safety information
4. Let the person you are speaking with know you
are driving; if necessary, suspend the call in
heavy traffic or hazardous weather conditions.
Rain, sleet, snow, ice and even heavy traffic can
be hazardous.
5. Do not take notes or look up phone numbers
while driving. Jotting down a To Do list or
flipping through your phonebook takes your
attention away from your primary
responsibility, driving safely.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your
car will be stationary. If you need to make a call
while moving, dial only a few numbers, check
the road and your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make the
people with whom you are talking aware that
you are driving and suspend conversations that
have the potential to divert your attention from
the road.
8. Use your wireless phone to call for help. Dial
the emergency number in the case of fire,
traffic accident or medical emergencies.
Remember, it is a free call on your wireless
phone!
9. Use your wireless phone to help others in
emergencies. If you see a car accident, crime in
progress or other serious emergency where
lives are in danger, call the emergency number,
as you would want others to do for you.
10.Call roadside assistance or a special
nonemergency wireless assistance number
when necessary. If you see a broken-down
vehicle posing no serious hazard, a broken
93
Health and safety information
traffic signal, a minor traffic accident where no
one appears injured, or a vehicle you know to
be stolen, call roadside assistance or any other
special nonemergency wireless number.
Operating Environment
Remember to follow any special regulations in
force in any area and always switch off your phone
whenever it is forbidden to use it, or when it may
cause interference or danger.
When connecting the phone or any accessory to
another device, read its user’s guide for detailed
safety instructions. Do not connect incompatible
products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory
operation of the equipment and for the safety of
personnel, it is recommended that the equipment
should only be used in the normal operating
position (held to your ear with the antenna
pointing over your shoulder).
Electronic Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against
the RF signals from your wireless phone. Consult
the manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference with the
pacemaker. These recommendations are consistent
with the independent research and
recommendations of Wireless Technology
Research.
94
Health and safety information
Persons with pacemakers:
• Should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone
is switched on
• Should not carry the phone in a breast pocket
• Should use the ear opposite the pacemaker to
minimize potential interference
If you have any reason to suspect that interference
is taking place, switch off your phone immediately.
Hearing Aids
Some digital wireless phones may interfere with
some hearing aids. In the event of such
interference, you may wish to consult your hearing
aid manufacturer to discuss alternatives. Other
Medical Devices If you use any other personal
medical devices, consult the manufacturer of your
device to determine if it is adequately shielded
from external RF energy. Your physician may be
able to assist you in obtaining this information.
Switch off your phone in health care facilities when
any regulations posted in these areas instruct you
to do so. Hospitals or health care facilities may be
using equipment that could be sensitive to external
RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should
also consult the manufacturer of any equipment
that has been added to your vehicle.
Posted Facilities
Switch off your phone in any facility where posted
notices require you to do so.
Health and safety information
Settings
95
Potentially Explosive Atmospheres
Switch off your phone when in any area with a
potentially explosive atmosphere and obey all
signs and instructions. Sparks in such areas could
cause an explosion or fire resulting in bodily injury
or even death. Users are advised to switch off the
phone while at a refueling point (service station).
Users are reminded of the need to observe
restrictions on the use of radio equipment in fuel
depots (fuel storage and distribution areas),
chemical plants or where blasting operations are in
progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas
(such as propane or butane), areas where the air
contains chemicals or particles, such as grain, dust
or metal powders, and any other area where you
would normally be advised to turn off your vehicle
engine.
Emergency calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks, as
well as user-programmed functions, which cannot
guarantee connection in all conditions. Therefore,
you should never rely solely on any wireless phone
for essential communications (medical
emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not
be possible on all wireless phone networks or when
certain network services and/or phone features are
in use. Check with local service providers.
96
Health and safety information
To make an emergency call, proceed as follows.
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 112 or any other official
emergency number). Emergency numbers vary
by location.
3. Press the key.
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular
service provider.
When making an emergency call, remember to
give all the necessary information as accurately as
possible. Remember that your phone may be the
only means of communication at the scene of an
accident; do not end the call until given permission
to do so.
Other important safety information
• Only qualified personnel should service the
phone or install the phone in a vehicle. Faulty
installation or service may be dangerous and
may invalidate any warranty applicable to the
device.
• Check regularly that all wireless phone
equipment in your vehicle is mounted and
operating properly.
• Do not store or carry flammable liquids, gases,
or explosive materials in the same compartment
as the phone, its parts, or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inflates with great force. Do not
place objects, including both installed or portable
wireless equipment in the area over the air bag
or in the air bag deployment area. If wireless
equipment is improperly installed and the air bag
inflates, serious injury could result.
Health and safety information
Settings
97
• Switch off your phone before boarding an
aircraft. The use of wireless phones in aircraft
may be dangerous to the operation of the
aircraft, and is illegal.
• Failure to observe these instructions may lead to
the suspension or denial of telephone services to
the offender, or legal action, or both.
Care and maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children.
• Keep the phone dry. Precipitation, humidity, and
liquids contain minerals that will corrode
electronic circuits.
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage to
the phone.
• Do not use or store the phone in dusty, dirty
areas, as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the
phone, which may damage the phone’s
electronic circuit boards.
• Do not drop, knock, or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents,
or strong detergents to clean the phone. Wipe it
98
Health and safety information
with a soft cloth slightly dampened in a mild
soap-and-water solution.
• Do not paint the phone. Paint can clog the
device’s moving parts and prevent proper
operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove, or a radiator.
The phone may explode when overheated.
• Use only the supplied or an approved
replacement antenna. Unauthorised antennas or
modified accessories may damage the phone
and violate regulations governing radio devices.
• If the phone, battery, charger, or any accessory
is not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
Acknowledging Special Precautions and
the FCC and Industry Canada Notice
Cautions
Modifications not expressly approved by the party
responsible for compliance could void the user's
authority to operate the equipment.
FCC Compliance Information
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause harmful
interference, and
2. This device must accept any interference
received.
Including interference that may cause undesired
operation.
Information to User
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to
Health and safety information
Settings
99
part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a circuit
different from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/ TV
technician for help.
Appendix A: CERTIFICATION
INFORMATION (SAR)
THIS MODEL PHONE MEETS THE GOVERNMENT’S
REQUIREMENTS FOR EXPOSURE TO RADIO
WAVES.
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radio
frequency(RF) energy set by the Federal
Communications Commission of the U.S.
Government. These limits are part of
comprehensive guidelines and establish permitted
levels of RF energy for the general population. The
guidelines are based on safety standards that were
developed by independent scientific organizations
through periodic and thorough evaluation of
100
Health and safety information
scientific studies. The standards include a
substantial safety margin designed to assure the
safety of all persons, regardless of age and health.
The exposure standard for wireless mobile phones
employs a unit of measurement known as the
Specific Absorption Rate(SAR). The SAR limit set
by the FCC is 1.6 W/kg. SAR Tests are conducted
using standard operating positions accepted by the
FCC with the phone transmitting at its highest
certified power level in all tested frequency bands.
Although the SAR is determined at the highest
certified power level, the actual SAR level of the
phone while operating can be well below the
maximum value. This is because the phone is
designed to operate at multiple power levels so as
to use only the power required to reach the
network. In general, the closer you are to a
wireless base station antenna, the lower the power
output.
Before a new model phone is available for sale to
the public, it must be tested and certified to the
FCC that it does not exceed the limit established by
the governmentadopted requirement for safe
exposure. The tests are performed in positions and
locations(e.g., at the ear and worn on the body) as
required by the FCC for each model.
The highest SAR values for this model phone as
reported to the FCC are Head: 0.499 W/Kg, Body-
worn: 0.566 W/Kg. Body-worn operations are
restricted to Samsungsupplied, approved or none
Samsung designated accessories that have no
metal and must provide at least 1.5 cm separation
between the device, including its antenna whether
extended or retracted, and the user’s body. None
compliance to the above restrictions may violate
FCC RF exposure guidelines
The FCC has granted an Equipment Authorization
for this model phone with all reported SAR levels
Health and safety information
Settings
101
evaluated as in compliance with the FCC RF
exposure guidelines. SAR information on this
model phone is on file with the FCC and can be
found under the Display Grant section of http://
www.fcc.gov/oet/fccid after searching on FCC ID
A3LSGHX700.
Appendix B: Guide to Safe and Responsible
Wireless Phone Use
Cellular Telecommunications & Internet Association
“Safety is the most important call you will ever make.”
A Guide to Safe and Responsible Wireless
Phone Use
TENS OF MILLIONS OF PEOPLE IN THE U.S. TODAY
TAKE ADVANTAGE OF THE UNIQUE COMBINATION OF
CONVENIENCE, SAFETY AND VALUE DELIVERED BY
THE WIRELESS TELEPHONE. QUITE SIMPLY, THE
WIRELESS PHONE GIVES PEOPLE THE POWERFUL
ABILITY TO COMMUNICATE BY VOICE-ALMOST
ANYWHERE, ANYTIME-WITH THE BOSS, WITH A
CLIENT, WITH THE KIDS, WITH EMERGENCY
PERSONNEL OR EVEN WITH THE POLICE. EACH YEAR,
AMERICANS MAKE BILLIONS OF CALLS FROM THEIR
WIRELESS PHONES, AND THE NUMBERS ARE RAPIDLY
GROWING.
But an important responsibility accompanies those
benefits, one that every wireless phone user must
uphold. When driving a car, driving is your first
responsibility. A wireless phone can be an invaluable
tool, but good judgment must be exercised at all times
while driving a motor vehicle whether on the phone or
not.
The basic lessons are ones we all learned as
teenagers. Driving requires alertness, caution and
courtesy. It requires a heavy dose of basic common
sense-keep your head up, keep your eyes on the road,
check your mirrors frequently and watch out for other
drivers. It requires obeying all traffic signs and signals
and staying within the speed limit. It means using seat
belts and requiring other passengers to do the same.
102
Health and safety information
But with wireless phone use, driving safely means a
little more. This brochure is a call to wireless phone
users everywhere to make safety their first priority
when behind the wheel of a car. Wireless
telecommunications is keeping us in touch, simplifying
our lives, protecting us in emergencies and providing
opportunities to help others in need. When it comes to
the use of wireless phones, safety is your most
important call.
Wireless Phone “Safety Tips”
Below are safety tips to follow while driving and using
a wireless phone which should be easy to remember:
1. Get to know your wireless phone and its
features such as speed dial and redial. Carefully
read your instruction manual and learn to take
advantage of valuable features most phones
offer, including automatic redial and memory.
Also, work to memorize the phone keypad so
you can use the speed dial function without
taking your attention off the road.
2. When available, use a hands free device. A
number of hands free wireless phone
accessories are readily available today. Whether
you choose an installed mounted device for
your wireless phone or a speaker phone
accessory, take advantage of these devices if
available to you.
3. Position your wireless phone within easy reach.
Make sure you place your wireless phone within
easy reach and where you can grab it without
removing your eyes from the road. If you get
an incoming call at an inconvenient time, if
possible, let your voice mail answer it for you.
4. Suspend conversations during hazardous
driving conditions or situations. Let the person
you are speaking with know you are driving; if
necessary, suspend the call in heavy traffic or
hazardous weather conditions. Rain, sleet,
snow and ice can be hazardous, but so is heavy
Health and safety information
Settings
103
traffic. As a driver, your first responsibility is to
pay attention to the road.
5. Do not take notes or look up phone numbers
while driving. If you are reading an address
book or business card, or writing a “to do” list
while driving a car, you are not watching where
you are going. It’s common sense. Don’t get
caught in a dangerous situation because you
are reading or writing and not paying attention
to the road or nearby vehicles.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan your calls before
you begin your trip or attempt to coincide your
calls with times you may be stopped at a stop
sign, red light or otherwise stationary. But if
you need to dial while driving, follow this simple
tip-dial only a few numbers, check the road and
your mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Stressful
or emotional conversations and driving do not
mix-they are distracting and even dangerous
when you are behind the wheel of a car. Make
people you are talking with aware you are
driving and if necessary, suspend conversations
which have the potential to divert your
attention from the road.
8. Use your wireless phone to call for help. Your
wireless phone is one of the greatest tools you
can own to protect yourself and your family in
dangerous situations-with your phone at your
side, help is only three numbers away. Dial 9-1-
1 or other local emergency number in the case
of fire, traffic accident, road hazard or medical
emergency. Remember, it is a free call on your
wireless phone!
104
Health and safety information
9. Use your wireless phone to help others in
emergencies. Your wireless phone provides you
a perfect opportunity to be a “Good Samaritan”
in your community. If you see an auto accident,
crime in progress or other serious emergency
where lives are in danger, call 9-1-1 or other
local emergency number, as you would want
others to do for you.
10.Call roadside assistance or a special wireless
non emergency assistance number when
necessary. Certain situations you encounter
while driving may require attention, but are not
urgent enough to merit a call for emergency
services. But you still can use your wireless
phone to lend a hand. If you see a broken-down
vehicle posing no serious hazard, a broken
traffic signal, a minor traffic accident where no
one appears injured or a vehicle you know to be
stolen, call roadside assistance or other special
non-emergency wireless number.
Careless, distracted individuals and people driving
irresponsibly represent a hazard to everyone on the
road. Since 1984, the Cellular Telecommunications
Industry Association and the wireless industry have
conducted educational outreach to inform wireless
phone users of their responsibilities as safe drivers
and good citizens. As we approach a new century,
more and more of us will take advantage of the
benefits of wireless telephones. And, as we take to the
roads, we all have a responsibility to drive safely.
“The wireless industry reminds you to use your phone
safely when driving.”
Cellular Telecommunications & Internet Association
For more information, please call 1-888-901-SAFE.
For updates: http://www.wow-com.com/consumer/
issues/driving/articles.cfm?ID =85
Appendix C: Consumer Update on Wireless
Phones
U.S. Food and Drug Administration
Health and safety information
Settings
105
1. What kinds of phones are the subject of this
update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called
cell, mobile, or PCS phones. These types of wireless
phones can expose the user to measurable radio
frequency energy (RF) because of the short distance
between the phone and the user s head. These RF
exposures are limited by Federal Communications
Commission safety guidelines that were developed
with the advice of FDA and other federal health and
safety agencies. When the phone is located at greater
distances from the user, the exposure to RF is
drastically lower because a person’s RF exposure
decreases rapidly with increasing distance from the
source. The so-called “cordless phones,” which have a
base unit connected to the telephone wiring in a
house, typically operate at far lower power levels, and
thus produce RF exposures well within the FCC’s
compliance limits.
2. Do wireless phones pose a health hazard?
The available scientific evidence does not show that
any health problems are associated with using
wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless phones
emit low levels of radio frequency energy (RF) in the
microwave range while being used. They also emit
very low levels of RF when in the stand-by mode.
Whereas high levels of RF can produce health effects
(by heating tissue), exposure to low level RF that does
not produce heating effects causes no known adverse
health effects. Many studies of low level RF exposures
have not found any biological effects. Some studies
have suggested that some biological effects may
occur, but such findings have not been confirmed by
additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
3. What is FDA’s role concerning the safety of wireless
phones?
Under the law, FDA does not review the safety of
radiation emitting consumer products such as wireless
phones before they can be sold, as it does with new
106
Health and safety information
drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown
to emit radio frequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could
require the manufacturers of wireless phones to notify
users of the health hazard and to repair, replace or
recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
• Support needed research into possible biological
effects of RF of the type emitted by wireless
phones;
• Design wireless phones in a way that minimizes
any RF exposure to the user that is not
necessary for device function; and
• Cooperate in providing users of wireless phones
with the best possible information on possible
effects of wireless phone use on human health
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at
the federal level. The following agencies belong to this
working group:
• National Institute for Occupational Safety and
Health
• Environmental Protection Agency Federal
Communications Commission
• Occupational Safety and Health Administration
• National Telecommunications and Information
Administration
• The National Institutes of Health participates in
some interagency working group activities, as
well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission
(FCC). All phones that are sold in the United States
must comply with FCC safety guidelines that limit RF
Health and safety information
Settings
107
exposure. FCC relies on FDA and other health agencies
for safety questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from
these base stations are typically thousands of times
lower than those they can get from wireless phones.
Base stations are thus not the primary subject of the
safety questions discussed in this document.
4. What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization International Electromagnetic Fields
(EMF) Project since its inception in 1996. An influential
result of this work has been the development of a
detailed agenda of research needs that has driven the
establishment of new research programs around the
world. The Project has also helped develop a series of
public information documents on EMF issues.
FDA and the Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative
Research and Development Agreement (CRADA) to do
research on wireless phone safety. FDA provides the
scientific oversight, obtaining input from experts in
government, industry, and academic organizations.
CTIA-funded research is conducted through contracts
to independent investigators. The initial research will
include both laboratory studies and studies of wireless
phone users. The CRADA will also include a broad
assessment of additional research needs in the
context of the latest research developments around
the world.
5. What steps can I take to reduce my exposure to
radio frequency energy from my wireless phone?
If there is a risk from these products—and at this point
we do not know that there is—it is probably very
small. But if you are concerned about avoiding even
108
Health and safety information
potential risks, you can take a few simple steps to
minimize your exposure to radio frequency energy
(RF). Since time is a key factor in how much exposure
a person receives, reducing the amount of time spent
using a wireless phone will reduce RF exposure.
If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of the RF,
since the exposure level drops off dramatically with
distance. For example, you could use a headset and
carry the wireless phone away from your body or use a
wireless phone connected to a remote antenna
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are concerned
about the RF exposure from these products, you can
use measures like those described above to reduce
your RF exposure from wireless phone use.
6. What about children using wireless phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower exposure
to radio frequency energy (RF), the measures
described above would apply to children and
teenagers using wireless phones. Reducing the time of
wireless phone use and increasing the distance
between the user and the RF source will reduce RF
exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at all. For
example, the government in the United Kingdom
distributed leaflets containing such a recommendation
in December 2000. They noted that no evidence exists
that using a wireless phone causes brain tumors or
other ill effects. Their recommendation to limit
wireless phone use by children was strictly
precautionary; it was not based on scientific evidence
that any health hazard exists.
7. Do hands-free kits for wireless phones reduce risks
from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free
Health and safety information
Settings
109
kits can be used with wireless phones for convenience
and comfort. These systems reduce the absorption of
RF energy in the head because the phone, which is the
source of the RF emissions, will not be placed against
the head. On the other hand, if the phone is mounted
against the waist or other part of the body during use,
then that part of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are required to
meet safety requirements regardless of whether they
are used against the head or against the body. Either
configuration should result in compliance with the
safety limit.
8. Do wireless phone accessories that claim to shield
the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head
from those emissions reduce risks. Some products
that claim to shield the user from RF absorption use
special phone cases, while others involve nothing
more than a metallic accessory attached to the phone.
Studies have shown that these products generally do
not work as advertised. Unlike “hand-free” kits, these
so-called “shields” may interfere with proper operation
of the phone. The phone may be forced to boost its
power to compensate, leading to an increase in RF
absorption. In February 2002, the Federal trade
Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users
from radiation with making false and unsubstantiated
claims. According to FTC, these defendants lacked a
reasonable basis to substantiate their claim.
9. What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason,
FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted
cardiac pacemakers and defibrillators from wireless
telephones. This test method is now part of a standard
sponsored by the Association for the Advancement of
Medical instrumentation (AAMI). The final draft, a joint
110
Health and safety information
effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This
standard will allow manufacturers to ensure that
cardiac pacemakers and defibrillators are safe from
wireless phone EMI.
FDA has tested hearing aids for interference from
handheld wireless phones and helped develop a
voluntary standard sponsored by the Institute of
Electrical and Electronic Engineers (IEEE). This
standard specifies test methods and performance
requirements for hearing aids and wireless phones so
that no interference occurs when a person uses a
compatible phone and a compatible hearing aid at the
same time. This standard was approved by the IEEE in
2000.
FDA continues to monitor the use of wireless phones
for possible interactions with other medical devices.
Should harmful interference be found to occur, FDA
will conduct testing to assess the interference and
work to resolve the problem.
10. What are the results of the research done already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in
their research methods. Animal experiments
investigating the effects of radio frequency energy
(RF) exposures characteristic of wireless phones have
yielded conflicting results that often cannot be
repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could
accelerate the development of cancer in laboratory
animals. However, many of the studies that showed
increased tumor development used animals that had
been genetically engineered or treated with cancer
causing chemicals so as to be pre-disposed to develop
cancer in the absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day.
These conditions are not similar to the conditions
under which people use wireless phones, so we don t
know with certainty what the results of such studies
mean for human health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use
Health and safety information
Settings
111
of wireless phones and primary brain cancer, gioma,
meningioma, or acoustic neuroma, tumors of the brain
or salivary gland, leukemia, or other cancers. None of
the studies demonstrated the existence of any harmful
health effects from wireless phone RF exposures.
However, none of the studies can answer questions
about long-term exposures, since the average period
of phone use in these studies was around three years.
11. What research is needed to decide whether RF
exposure from wireless phones poses a health
risk?
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data that
are needed. Lifetime animal exposure studies could be
completed in a few years. However, very large
numbers of animals would be needed to provide
reliable proof of a cancer promoting effect if one
exists. Epidemiological studies can provide data that is
directly applicable to human populations, but 10 or
more years follow-up may be needed to provide
answers about some health effects, such as cancer.
This is because the interval between the time of
exposure to a cancer-causing agent and the time
tumors develop - if they do - may be many, many
years. The interpretation of epidemiological studies is
hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones.
Many factors affect this measurement, such as the
angle at which the phone is held, or which model of
phone is used.
12. Which other federal agencies have responsibilities
related to potential RF health effects?
Additional information on the safety of RF exposures
from various sources can be obtained from the
following organizations.
FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
112
Health and safety information
Occupational Safety and Health Administration’s
(OSHA):
http://www.osha-slc.gov/SLTC/
radiofrequencyradiation/index.html
National Institute for Occupational Safety and Health
(NIOSH):
http://www.cdc.gov/niosh/emfpg.html
World health Organization (WHO):
http://www.who.int/peh-emf/
International Commission on Non-Ionizing Radiation
Protection:
http://www.icnirp.de
National Radiation Protection Board (UK):
http://www.nrpb.org.uk
*
•
* Updated 4/3/2002: US Food and Drug Administration
http://www.fda.gov/cellphones
113
Index
A
ABC mode, text input • 24
Alarm • 43
Answering
call • 28
second call • 29
Anykey answer • 75
Auto redial • 75
B
Background image • 76
Backlight time, set • 78
Band selection • 80
Barring, calls • 79
Battery
charging • 7
low indicator • 8
precautions • 88
Bluetooth
receiving, data • 83
sending, data • 83
settings • 81
Broadcast messages • 62
Browser, web • 46
C
Calculator • 44
Calendar • 65, 76
Call cost • 32
Call records
dialled • 31
missed • 31
received • 32
Call time • 32
Caller groups • 35
Caller ID • 76, 80
Calls
answering • 28
barring • 79
diverting • 78
holding • 29
redialling • 27
rejecting • 28
waiting • 80
Camera
photos • 69
videos • 72
Characters, enter • 24
Connection tone • 77
Converter • 44
Creating messages
e-mail • 51
MMS • 50
SMS • 49
D
Date, set • 74
Deleting
call records • 31
e-mail • 54, 55, 56
events • 68
MMS • 53, 54, 56
phonebook • 33, 37
SMS • 52, 54, 56
Dialled calls • 31
Dialling font, set • 76
Display
brightness • 76
icons • 10
language • 75
layout • 10
settings • 76
Diverting, calls • 78
DTMF tones, send • 30
E
E-mails
creating/sending • 51
deleting • 55
setting • 59
viewing • 54
Emergency calls • 91
F
FDN (Fixed Dialling Number)
mode • 84
File manager • 62
G
Games • 41
Greeting message • 75
H
Health and safety • 87
Holding, call • 29
I
Icons, description • 10
Images, downloaded • 62
Inbox, messages
e-mail • 54
MMS/SMS • 52
114
Index
International calls • 27
Internet • 46
J
Java applications • 41
K
Keypad light, set • 78
Keypad lock • 8, 76
Keypad tones
selecting • 77
sending/muting • 30
volume • 77
L
Language, select • 75
Last number, redial • 27
Light
backlight, set • 78
keypad light, set • 78
Locking
menu functions • 84
phone • 84
SIM card • 84
Low battery indicator • 8
M
Memory card
accessing files • 65
installing • 23
Memory status
downloaded items • 65
file manager • 65
messages • 62
phonebook 37
Message tone • 77
Messages
cell broadcast • 62
e-mail • 51, 54
greeting • 75
MMS • 50, 53
push • 53
SMS • 49, 52
Minute minder • 77
Missed calls • 31
MMS messages
creating/sending • 50
deleting • 53
setting • 57
viewing • 52
MP3 player • 38
Multiparty-call • 30
Music, downloaded • 64
N
Name card • 36
Names
entering • 24
searching • 33
Network band, select • 80
Network selection • 80
Network services • 78
O
Outbox, messages • 53
P
Password
call barring • 79
phone • 84
Phone
care and maintenance •
92
display • 10
icons • 10
locking • 84
password • 84
resetting • 85
switching on/off • 8
unpacking • 6
Phonebook
deleting • 33, 37
finding • 33
managing • 37
options • 33
speed dialling • 35
Photos
taking • 69
viewing • 62
PIN, change • 83
PIN2, change • 84
Power on/off tone • 77
Privacy • 84
Problems, solve • 85
Push messages • 53, 61
Q
Quiet mode
entering • 13
setting • 77
R
Received calls • 32
Received messages
e-mail • 54
MMS/SMS • 52
115
Index
Recording
videos • 72
voice memos • 40
Redialling
automatically • 75
manually • 27
Resetting phone • 85
Ringer
incoming calls • 77
messages • 77
Road safety • 89
Roaming • 80
S
Safety
information • 87
precautions • 1
Security, calls • 83
Sent messages • 54
Shortcut • 75
SIM card
inserting • 7
locking • 84
SMS messages
creating/sending • 49
deleting • 52
setting • 56
viewing • 52
Sound settings • 77
Sounds, downloaded • 64
Speakerphone • 29
Speed dial • 35
Stopwatch • 45
Switching on/off
microphone • 30
phone • 8
T
T9 mode, text input • 25
Templates, message • 55
Text, enter • 24
Time, set • 74
Timer • 45
V
Videos
playing • 63
recording • 72
Voice recorder
playing • 40
recording • 40
Voicemail server • 80
W
Waiting call • 80
Wallpaper • 76
Web browser
access • 46
bookmarks • 47
World time • 43
