Users Manual

SGH-Z370

User’s Guide

Draft

Important

safety

precautions

Failure to comply with the following

precautions may be dangerous or

illegal.

Drive safely at all times

Do not use a hand-held phone while driving.

Park the vehicle first.

Switch off the phone when refuelling

Do not use the phone at a refuelling point

(service station) or near fuels or chemicals.

Switch off in an aircraft

Wireless phones can cause interference. Using

them in an aircraft is both illegal and

dangerous.

Switch off the phone near all medical

equipment

Hospitals or health care facilities may be using

equipment that could be sensitive to external

radio frequency energy. Follow any regulations

or rules in force.

Interference

All wireless phones may be subject to

interference, which could affect their

performance.

Important safety precautions

Be aware of special regulations

Meet any special regulations in force in any

area and always switch off your phone

whenever it is forbidden to use it, or when it

may cause interference or danger.

Water resistance

Your phone is not water-resistant. Keep it

dry.

Sensible use

Use only in the normal position (held to the

ear). Avoid unnecessary contact with the

antenna when the phone is switched on.

Emergency calls

Key in the emergency number for your

present location, then press .

Keep your phone away from small

children

Keep the phone and all its parts, including

accessories, out of the reach of small

children.

Accessories and batteries

Use only Samsung-approved batteries and

accessories, such as headsets and PC data

cables. Use of any unauthorised accessories

could damage you or your phone and may

be dangerous.

Qualified service

Only qualified service personnel may repair

your phone.

For more detailed safety information, see

"Health and safety information" on page

102.

• The phone could explode if the battery is

replaced with an incorrect type.

• Dispose of used batteries according to the

manufacturer’s instructions.

At very high volumes, prolonged

listening to a headset can damage

your hearing.

About this Guide

This User’s Guide provides you with

condensed information about how to use

your phone. To quickly learn the basics for

your phone, please refer to “Get started”

and “Step outside the phone.”

In this guide, the following instruction icons

appear:

Indicates that you need to pay

careful attention to the subsequent

information regarding safety or

phone features.



Indicates that you can get more

information on the referenced page.

→

Indicates that you need to press the

Navigation keys to scroll to the

specified option and then select it.

[

]

Indicates a key on the phone. For

example, [ ]

Indicates a soft key, whose function

is displayed on the phone screen.

For example, <

•3G

Your phone is capable of

operating in a 3G

environment, allowing much

greater data transfer speed,

video streaming, and video

conferencing.

Special

features of your phone

• Camera and camcorder

Use the camera module on

your phone to take a photo

or record a video.

• Media player

Play media files on your

phone. You can enjoy high

quality videos and music.

• Photo printing

Print your photos to

preserve your best

moments forever.

Special features of your phone

•Bluetooth

Transfer media files and

personal data and connect

to other devices using free,

wireless Bluetooth

technology.

• File viewer

Open documents in various

formats on the phone

without corruption.

•Web browser

Access the wireless web to

get up-to-the-minute

information and a wide

variety of media content.

•Name card

Create name cards with

your number and profile.

Whenever introducing

yourself to others, use this

convenient electronic name

card.

• Multimedia Message

Service (MMS)

Send and receive MMS

messages with a

combination of text,

images, video, and audio.

•Email

Send and receive e-mails

with images, video, and

audio attachments.

•Java

Enjoy Java™-based

embedded games and

download new games.

•Calendar

Keep track of your daily,

weekly, and monthly

schedule.

• Voice recorder

Record memos or sounds.

Contents

Unpack 6

Make sure you have each item

Your phone 6

Keys, features, and locations

Get started 7

First steps to operating your phone

Install and charge the phone ...................... 7

Power on or off......................................... 8

Keys and display ...................................... 9

Access menu functions ............................ 12

Customise your phone............................. 13

Step outside the phone 16

Begin with your camera, the media player, the

web, and other special features

Use the camera ...................................... 16

Play music ............................................. 17

Browse the web...................................... 19

Use Phonebook....................................... 19

Send messages....................................... 21

View messages ....................................... 22

Use Bluetooth ......................................... 23

Switch applications .................................. 25

Use a memory card ................................. 25

Enter text 27

ABC, T9, Number, and Symbol modes

Call functions 29

Advanced calling features

Menu functions 35

All menu options listed

Solve problems 100

Help and personal needs

Health and safety information 102

Index 109

1 Call log



p. 35

2 Phonebook



p. 37

1 Search for contacts

2 Create contact

3 Groups

4 My namecard

5 Copy all

6 Service number

7 Phonebook settings

8 Memory status



p. 37



p. 38



p. 39



p. 40



p. 40



p. 41



p. 41



p. 42

3 Multimedia



p. 42

1 Media player

2 Voice recorder



p. 42



p. 46

4 Browser



p. 47

1 Home

2 Enter URL

3 Bookmarks

4 Saved pages

5 History

6 Advanced

7 Browser settings



p. 47



p. 49



p. 49



p. 50



p. 50



p. 50



p. 50

5 Messages



p. 50

1 Create message

2 Inbox

2 Email inbox

3 Drafts

4 Outbox

5 Sentbox

6 Templates

7 Voice mail

8 Delete all

0 Message settings

* Memory status



p. 51



p. 55



p. 57



p. 58



p. 58



p. 59



p. 59



p. 60



p. 60



p. 61



p. 66

6 My files



p. 66

Images

Videos

Sounds

Games & more

Other files

Memory card

Memory status



p. 67



p. 68



p. 69



p. 71



p. 72



p. 73



p. 73

7 Organiser



p. 73

1 Calendar

2 Applications

3 Alarms



p. 74



p. 76



p. 79

8 Camera



p. 80

9 Settings



p. 86

1 Phone settings

2 Display settings

3 Message settings

4 Call settings

5 Phonebook settings

6 Network settings

7 Bluetooth

8 Security

9 Memory settings

0 Master reset



p. 86



p. 89



p. 90



p. 90



p. 92



p. 92



p. 95



p. 97



p. 98



p. 99

* Shows only if supported by your

USIM/SIM card.

** Shows only if a memory card is

inserted into your phone.

Overview of menu functions

To access Menu mode, press <

> in Idle mode.

Unpack

Make sure you have each item

You can obtain various

accessories from your local

Samsung dealer.

Phone Travel Adapter

Battery User’s Guide

The items supplied with

your phone and the

accessories available at

your Samsung dealer may

vary, depending on your

country or service provider.

Your phone

Keys, features, and locations

Microphone

Alphanumeric

keys

Power on/off/ Menu exit key

Right soft key

Application switch key

Delete key

Special

function keys

Earpiece

Display

Left soft key

Headset/

Adapter jack

Dial key Navigation keys

(Up/Down/Left/Right)

Video call key

Front

camera lens

Menu access/

Confirm (Centre) key

Volume keys

Rear camera

lens

Camera

key

Memory

card slot

Get started

First steps to operating your phone

SIM card information

When you subscribe to a cellular network, you

receive a plug-in SIM (Subscriber Identity

Module) card loaded with your subscription

details, such as your PIN, and available optional

services. For 3G services, you can purchase a

USIM (Universal Subscriber Identity Module)

card.

Install and charge the phone

Remove the

battery cover.

If the phone is

already on, first turn

it off by pressing and

holding [ ].

Insert the USIM/

SIM card.

Make sure that the

gold-coloured

contacts on the

card are face down.

Install the battery. Reattach the

battery cover.

Plug the travel adapter into the phone.

Plug the adapter into a standard AC wall

outlet.

Get started

Low battery indicator

When the battery is low:

• a warning tone sounds,

• the low battery message displays, and

• the empty battery icon blinks.

If the battery level becomes too low, the

phone automatically turns off. Recharge

your battery.

Power on or off

Keypad lock

You can lock the keypad to prevent

accidental key presses from affecting phone

operations.

In Idle mode, press and hold [ ] and press

Yes

>. To unlock the keypad, press the left

soft key and then [ ].

When the phone is completely charged

(the battery icon becomes still), unplug

the adapter from the power outlet.

Remove the adapter from the phone.

Switch on

Do not turn on

the phone when

mobile phone

use is

prohibited.

1. Press and hold [ ].

2. If necessary, enter the

PIN and press

Confirm

Switch off

Press and hold [ ].

Get started

Keys and display

Keys

Perform the function indicated on

the bottom line of the display.

In Idle mode, access your

favourite menus directly.



p. 88

In Menu mode, scroll through

menu options.

In Idle mode, access Menu

mode.

In Menu mode, select the

highlighted menu option or

confirm input.

Make a video call.

Open the application switch

window to access other

applications without exiting the

current application.

Make or answer a call.

In Idle mode, retrieve numbers

recently dialled, missed, or

received.

Press and hold to switch the

phone on or off.

End a call.

In Menu mode, cancel input and

return the phone to Idle mode.

Delete characters from the

display or items in an application.

Enter numbers, letters, and some

special characters.

In Idle mode, press and hold

[1]

to access your voicemail server.

Press and hold [

] to enter an

international call prefix.

Enter special characters.

In Idle mode, press and hold [ ]

to activate or deactivate the

Silent profile. Press and hold [ ]

to enter a pause between

numbers.

Get started

Display

Adjust the phone volume.

In Idle mode, adjust the key tone

volume.

In Idle mode, press and hold to

turn on the camera.

In Camera mode, take a photo or

record a video.

Layout

Text and graphics

display messages,

instructions, and

information you enter.

Soft key function

indicators

show the current

functions assigned

to the soft keys.

Icons

display various icons.

enu

ontacts

Icons

Received signal strength

2.5G (GPRS) network

Accessing services in a

2.5G (GPRS) network;

when transferring data,

this icon animates

2.5G (GPRS) network

unavailable

3G (UMTS) network

Accessing services in a 3G

(UMTS) network; when

transferring data, this

icon animates

3G (UMTS) network

unavailable

Roaming network

Voice call in progress

Out of your service area;

you cannot make or

receive voice calls

Get started

Video call in progress

Bluetooth active



p. 95

Connected to Bluetooth

hands-free car kit or

headset

Connected to secured web

page

Browsing Internet on PC

using phone as modem

New message:

•: SMS

• : MMS

•: Email

•: Voicemail

•: Push

• : Configuration

message

Alarm set



p. 79

Sound profile setting



p. 86

•: Normal

• : Silent

•: Car

• : Meeting

• : Outdoor

• : Offline

Battery power level

* Depending on your country or service provider,

the icons shown on the display may vary.

Get started

Access menu functions

Use the

soft keys

The roles of the soft keys

vary depending on the

function you are using. The

bottom line of the display

indicates their current role.

Press the left

soft key to

select the

highlighted

option.

Press the right

soft key to

return to the

previous menu

level.

Select Back

Select an

option

1. Press a desired soft

key.

2. Press the Navigation

keys to move to the

next or previous option.

3. Press <

Select

> or

[Centre] to confirm the

function displayed or

option highlighted.

4. To exit, choose either of

the following methods.

•Press <

Back

> to

move up one level.

• Press [ ] to return

to Idle mode.

Use

shortcuts

Press the number key

corresponding to the option

you want.

Get started

Customise your phone

1. In Idle mode, press

> and select

Settings

→

Phone

settings

→

Language

→

Screen text

2. Select a language.

3. Press <

Save

You can change the call

ringer by changing the

properties of the currently

active sound profile.

To change the profile

properties:

1. In Idle mode, press

> and select

Settings

→

Phone

settings

→

Phone

profiles

2. Scroll to the sound profile

you are using.

Display

language

Call ringer

melody

3. Press <

Options

> and

select

Edit

4. Select

Voice call

ringtone

and select a

ringtone for voice calls.

5. Select

V-call ringtone

and select a ringtone for

video calls.

6. Press <

Options

> and

select

Save

To change the sound profile:

1. In Idle mode, press

> and select

Settings

→

Phone

settings

→

Phone

profiles

2. Select the profile you

want.

3. Press [Centre].

Get started

You can change the display

style of the main menu

screen.

1. In Idle menu, press

> and select

Settings

→

Display

settings

→

Main menu

style

2. Select the style you want.

You can set wallpaper for the

idle screen.

1. In Idle mode, press

> and select

Settings

→

Display

settings

→

Main display

→

Wallpaper

2. Scroll to an image folder.

3. Select an image and

press <

Set as

Menu style

Idle mode

wallpaper

You can set the Navigation

keys to function as shortcuts

to access your favourite

menus.

1. In Idle mode, press

> and select

Settings

→

Phone

settings

→

Shortcuts

2. Select a key.

3. Select a menu to be

assigned to the key.

4. Press <

Save

You can activate the Silent

profile to avoid disturbing

other people.

Press and hold [ ] in Idle

mode.

shortcuts

Silent

profile

Get started

Make/Answer calls

You can protect the phone

against unauthorised use

with a phone password. The

phone will require the

password on power-up.

1. In Idle mode, press

> and select

Settings

→

Security

→

Change phone

password

2. Enter the default

password,

00000000

and press <

Confirm

3. Enter a new 4- to 8-digit

password and press

Confirm

4. Enter the new password

again and press

Confirm

Phone lock

5. Select

Phone lock

6. Select

Enable

7. Enter the password and

press <

Confirm

To make a voice ca ll:

1. Enter an area code and

phone number.

2. Press [ ].

3. To end the call, press

[].

To make a vid eo cal l:

1. Enter an area code and

phone number.

2. Press [ ], and if their

phone is compatible, the

other person appears on

the screen.

Make a call

Step outside the phone

Begin with your camera, the media player, the

web, and other special features

Use the camera

1. When the phone rings,

press [ ].

2. For a video call, press

Show me

> to allow the

other person to see you.

3. To end the call, press

[].

Press [Volume].

Answer a

call

Adjust the

volume

during a

call

1. In Idle mode, press and

hold [Camera] to turn on

the camera.

2. Aim the lens at the

subject and make any

desired adjustments.

3. Press [Centre] or

[Camera] to take a photo.

The photo is saved

automatically.

4. Press [Centre] or < >

to take another photo.

1. In Idle mode, press

> and select

files

→

Images

2. Select the photo you want

from the

Photos

folder.

Take

a photo

View a


Step outside the phone

Play music

1. In Idle mode, press and

hold [Camera] to turn on

the camera.

2. Press [

] to switch to

Record mode.

3. Press [Centre] or

[Camera] to start

recording.

4. Press < > or [Camera]

to stop recording. The

video is saved

automatically.

5. Press <

Back

> to record

another video.

1. In Idle mode, press

> and select

files

→

Videos

2. Select the video clip you

want from the

My video

clips

folder.

Record a

video

Play a

video

Use these methods:

• Download from the

wireless web



p. 47

• Download from a

computer using the

optional Samsung PC

Studio



Samsung PC

Studio User’s Guide

•Receive via

Bluetooth



p. 95

• Copy files to a memory

card and insert the card

into the phone



p. 25

Copy music

files to the

phone

Step outside the phone

1. In Idle mode, press

> and select

Multimedia

→

Media

player

→

Music

2. Press <

Options

> and

select

Add to playlist

→

Selected

All

3. For

All

, select

Sounds

Memory card

, press

[Centre] to select the files

you want and press

Add

Then press <

Back

> to

return to the file list.

4. Press [Left] or [Right] to

access the play list.

1. From the Playlist screen,

press [Centre].

2. During playback, use the

following keys:

• Centre: pauses or

resumes playback.

Create a

play list

Play music

files

• Left: returns to the

previous file. Moves

backward in a file when

held down.

• Right: skips to the next

file. Skips forward in a

file when held down.

• Up: opens the play list.

•Down: changes the

repeat mode.

• Volume: adjusts the

volume.

3. Press <

Stop

> to stop

playback.

Step outside the phone

Browse the web

Using a built-in web browser, you can easily

access the wireless web to get a variety of

up-to-date services and information and to

download web content.

Use Phonebook

In Idle mode, press <

and select

Browser

→

Home

• To scroll through browser

items, press [Up] or

[Down].

• To select an item, press

[Centre].

• To return to the previous

page, press <

Back

• To move to the next page,

press <

Options

> and

select

→

Forward

• To access options, press

Options

Launch the

web

browser

Navigate

the web

To the phone’s memory:

1. In Idle mode, enter a

phone number and press

Options

2. Select

Add to

phonebook

→

Phone

→

New

→

a number type.

3. Specify contact

information: First name,

Last name, Mobile, Home,

Office, Fax number, Etc.,

Email, Group, URL, Note,

Birthday, Postal address

1/Postal address 2.

4. Press <

Options

> and

select

Save

to save the

contact.

Add a

contact

Step outside the phone

To the USIM/SIM card:

1. In Idle mode, enter a

phone number and press

Options

2. Select

Add to phonebook

→

SIM

→

New

3. Specify contact

information: Name,

Mobile, Group (for USIM),

and Location number.

4. Press <

Save

>, or press

Options

> and select

Save

to save the contact.

1. In Idle mode, press

Contacts

2. Enter the first few letters

of the name you want.

3. Select a contact.

4. Scroll to a number and

press

[]

to dial, or

press [Centre] to edit

contact information.

Add a

contact

(continued)

Find a

contact

1. In Idle mode, press

> and select

Phonebook

→

namecard

2. Specify your contact

information.

3. Press <

Options

> and

select

Save

to save the

name card.

4. To send the name card,

access

My namecard

again.

5. Press <

Options

> and

select

Send namecard

via

→

a sending method.

Create and

send a

name card

Step outside the phone

Send messages

1. In Idle mode, press

> and select

Messages

→

Create

message

→

Text

message

2. Enter the message text

and press [Centre].

3. Enter destination

numbers.

4. Press [Centre] to send the

message.

1. In Idle mode, press

> and select

Messages

→

Create

message

→

Multimedia

message

2. Enter the message

subject.

Send a text

message

(SMS)

Send a

multimedia

message

(MMS)

3. Select

Picture or video

Sound

4. Add an image, video clip,

or sound clip.

5. Select

Text

6. Enter the message text

and press [Centre].

7. Press <

Options

> and

select

Add file(s)

→

item type.

8. Press [Centre] to select

the items you want to be

attached.

9. Press <

Options

> and

select

Attach

10. Press [Centre].

11. Enter destination

numbers or addresses.

12. Press [Centre] to send

the message.

Step outside the phone

View messages

1. In Idle mode, press

and select

Messages

→

Create

message

→

2. Enter the e-mail subject.

3. Move to the

Message

field.

4. Enter the e-mail text.

5. Select

Attach file(s)

→

Add

→

an item type.

6. Press [Centre] to select

the items you want to be

attached.

7. Press <

Options

> and

select

Attach

8. Press [Centre].

9. Enter e-mail addresses.

10. Press [Centre] to send

the

e-mail.

Send an

e-mail

When a notification appears:

1. Press <

View

2. Select the message from

the Inbox.

From the Inbox:

1. In Idle mode, press

> and select

Messages

→

Inbox

2. Select an SMS message

().

When a notification appears:

1. Press <

View

2. Press <

Options

> and

select

Retrieve

3. Select the message from

the Inbox.

View a text

message

View a

multimedia

message

Step outside the phone

Use Bluetooth

Your phone is equipped with Bluetooth

technology, enabling you to connect the

phone wirelessly to other Bluetooth devices

and exchange data with them, talk hands-

free, or control the phone remotely.

From the Inbox:

1. In Idle mode, press

> and select

Messages

→

Inbox

2. Select an MMS message

().

1. In Idle mode, press

> and select

Messages

→

inbox

2. Press <

Options

> and

select

Download

download new e-mails or

headers.

3. Select an e-mail or a

header.

4. If you selected a header,

press <

Options

> and

select

Retrieve

to view

the body of the e-mail.

View an

e-mail

1. In Idle mode, press

> and select

Bluetooth

→

Activation

→

2. Select

My phone’s

visibility

→

to allow

other devices to find your

phone.

Turn on

Bluetooth

Step outside the phone

1. In Idle mode, press

> and select

Bluetooth

→

My devices

→

Search for new

devices

2. Select a device.

3. Enter a Bluetooth PIN or

the other device’s

Bluetooth PIN, if it has

one, and press <

When the owner of the

other device enters the

same code, pairing is

complete.

1. Access an application,

Phonebook

My files

Calendar

Task

, or

Memo

2. Scroll to an item.

Search for

and pair

with a

Bluetooth

device

Send data

3. Press <

Options

> and

select

Send namecard

via

Send via

→

Bluetooth

4. Select a device.

5. If necessary, enter the

Bluetooth PIN and press

1. When a device attempts

to access your phone,

press <

Yes

> to permit

the connection.

2. If necessary, press

Yes

> to confirm that

you are willing to receive.

Receive

data

Step outside the phone

Switch applications

You can switch to other applications from a

menu, without closing the menu screen you

were using.

Use a memory card

You can use an optional microSD memory

card to increase your phone’s memory

capacity.

1. While using a menu,

press

[]

2. Select an application.

•

Call

: opens the dialling

screen.

•

Messages

: accesses the

Messages

menu.

•

Browser

: accesses the

Browser

menu.

1. Press

[]

2. Scroll to

End all?

3. Press <

Yes

Switch to

application

Available

applications

Close all

running

applications

• Frequent erasing and

writing will shorten a

card’s lifespan.

• Do not remove a card

from the phone or turn off

the phone while data is

being accessed or

transferred. This could

result in loss of data and/

or damage to the card or

phone.

• Do not subject cards to

strong shocks.

• Do not touch card

terminals with your

fingers or metal objects.

If dirty, wipe the card with

a soft cloth.

Important

memory

card

information

Step outside the phone

• Keep cards away from

small children or pets.

• Do not expose cards in a

place subject to electro-

static discharge and/or

electrical noise.

1. Slide a memory card into

the card slot, with the

label side face down.

2. Press the card until it

locks into place.

Insert a

memory

card

1. Press the memory card so

that it is disengaged from

the phone.

2. Slide the card out of the

slot.

Using a card adapter and a

USB card reader/writer, you

can read the card on a PC.

1. Insert a memory card into

a card adapter, and then

the adapter into a card

reader/writer.

2. Plug the USB connecter of

the card reader/writer

into the USB port on your

PC.

3. Access the appropriate

memory disk and copy to

and from the card.

Remove

the

memory

card

Use a card

adapter

Enter text

ABC, T9, Number, and Symbol modes

You can enter text for some features, such

as Messages, Phonebook, or Calendar, using

ABC mode, T9 mode, Number mode, and

Symbol mode.

Changing the text input mode

• Press and hold [ ] to switch between T9

mode ( ) and ABC mode ( ).

Depending on your country, you may

also be able to access an input mode for

your specific language.

• Press [ ] to change case or switch to

Number mode ( ).

• Press and hold [ ] to switch to Symbol

mode ( ).

Using T9 mode

T9 is a predictive text input mode that

allows you to key in any character using

single keystrokes.

Entering a word in T9 mode

1. Press [

] to [

]

to start entering a word.

Press each key once for each letter.

For example, press [

], [

and [

] to enter Hello in T9 mode.

T9 predicts the word that you are typing,

and it may change with each key that

you press.

2. Enter the whole word before editing or

deleting characters.

3. When the word displays correctly, go to

step 4. Otherwise, press [

] to display

alternative word choices for the keys

that you have pressed.

For example, Of and Me use [

] and [

4. Press [ ] to insert a space and enter the

next word.

Enter text

Other T9 mode operations

•Press [

] to enter periods or apostrophes

automatically.

• Press [ ] to insert a space.

• Press the Navigation keys to move the

cursor.

•Press [

] to delete characters one by

one. Press and hold [

] to clear the

display.

Adding a new word to the T9

dictionary

This feature may not be available for some

languages.

1. Enter the word that you want to add.

2. Press [

] to display alternative words for

your key presses. When there are no

more alternative words,

Spell

appears

on the bottom line.

3. Press <

Spell

4. Enter the word you want using ABC

mode and press <

Add

Using ABC mode

Press the appropriate key until the character

you want appears on the display.

(Creating an SMS message with GSM alphabet

encoding)

Other ABC mode operations

• To enter the same letter twice or to enter

a different letter on the same key, wait

for the cursor to move to the right

automatically or press [Right]. Then,

enter the next letter.

aracters

n or

aye

Key

pper

case

ower

case

• Press [ ] to insert a space.

• Press the Navigation keys to move the

cursor.

•Press [

] to delete characters one by

one. Press and hold [

] to clear the

display.

Using Number mode

Number mode enables you to enter

numbers.

Press the keys corresponding to the digits

you want.

Using Symbol mode

Symbol mode enables you to insert symbols.

Call functions

Advanced calling features

Making a call

1. In Idle mode, enter the area code and

phone number.

2. Press [ ].

3. When you want to end the call, press

[].

Making an international call

1. In Idle mode, press and hold [

]. The

character appears.

2. Enter the country code, area code, and

phone number, then press [ ].

To Press

display more

symbols

[Up] or [Down].

select a symbol the corresponding

number key.

clear the entered

symbols

[

insert the symbols <

• Press [

] to clear the last digit or

press and hold [

] to clear the

whole display. You can move the

cursor to edit an incorrect digit.

• Press and hold [ ] to enter a pause

between numbers.

Call functions

Redialling recent numbers

1. In Idle mode, press [ ] to display the

list of recent numbers.

2. Scroll to the number you want and press

[].

Making a call from Phonebook

Once you have stored a number in

Phonebook, you can dial the number by

selecting it from Phonebook.



p. 37

You can also use the speed dial feature to

assign your most frequently dialled numbers

to specific number keys.



p. 41

You can quickly dial a number from the

USIM/SIM card using its location number

assigned when stored.

1. In Idle mode, enter a location number

and press [ ].

2. Scroll through other numbers, if

necessary.

3. Press <

Voice call

> or [ ] to make a

voice call.

Answering a call

When you receive an incoming call, the

phone rings and displays the incoming call

image.

Press <

> or [ ] to answer the call.

Tips for answering a call

• When

Any key

answer

is active, you

can press any key, except for <

Reject

and [ ].



p. 89

•Press <

Reject

> or [ ] to reject a call.

• Press and hold [Volume] to reject a call

or mute the ringer, depending on the

Volume key in incoming call

setting.



p. 89

Viewing missed calls

If you have missed calls, the screen displays

how many calls you have missed.

1. Press <

View

2. If necessary, scroll through the missed

calls.

3. Press [ ] to dial the number you want.

Call functions

Using the headset

Use the headset to make or answer calls

without holding the phone.

Connect the headset to the jack on the left

side of the phone. The button on the

headset works as follows:

Options during a call

You can access a number of functions during

a call.

Adjusting the volume during a call

Use [Volume] to adjust the earpiece volume

during a call.

Press [Volume up] to increase the volume

level and [Volume down] to decrease the

volume level.

Placing a call on hold/Retrieving

Press <

Hold

> to place a call on hold, or

press <

Retrieve

> or retrieve the call.

Making a second call

You can make another call if your network

supports this function.

1. Press <

Hold

> to put the call on hold.

2. Make the second call in the normal way.

3. Press <

Swap

> to switch between the

calls.

4. Press <

Options

> and select

End

→

Held call

to end the call on hold.

5. To end the current call, press [ ].

Answering a second call

You can answer an incoming call while

already on the phone, if your network

supports this function and you have

activated the call waiting feature.



p. 92

1. Press [ ] to answer the call. The first

call is automatically put on hold.

2. Press <

Swap

> to switch between the

calls.

To Press

redial the last call the button twice and

hold.

answer a call the button.

end a call the button.

Call functions

3. Press <

Options

> and select

End

→

Held call

to end the call on hold.

4. To end the current call, press [ ].

Using the speakerphone feature

Use the phone as a speakerphone to talk

and listen with the phone a short distance

away.

Press [Centre] and then <

Yes

> activate the

speakerphone feature. Press [Centre] to

switch back to the earpiece.

Using In-call options

Press <

Options

> to access the following

options during a call:

•

Speaker on

Normal

: turn on the

speakerphone feature or switch back to

Normal mode.

•

Switch to headset

Switch to phone

switch the call to a Bluetooth headset or

hands-free car kit or back to the

phone.To use this feature, you first need

to connect your headset to the phone.



p. 95

•

Join

: set up a multi-party call by adding

a caller on hold to a currently active call.

You can include up to 5 people on a

multi-party call.

•

Split

: have a private conversation with

one multi-party call participant. The

other participants can converse with

each other. After the private

conversation, select

Join

to return both

private participants to the multi-party

call.

•

Transfer

: transfer the currently active

call to a caller on hold. The two callers

can talk to each other, but you are

disconnected from the call.

•

Mute

Unmute

: switch off the phone's

microphone so that the other person on

the phone cannot hear you, or switch it

back on.

•

New call

: make a new call.

•

Phonebook

: access the contact list.

•

Add to phonebook

: add the other

person’s phone number to Phonebook.

Call functions

•

Create message

: create a new SMS

message.

•

Send DTMF

: send DTMF (Dual tone

multi-frequency) tones as a group. The

DTMF tones are the tones used in phones

for tone dialling, sounding when you

press the number keys. This option is

helpful for entering a password or an

account number when you call an

automated system, like a banking

service.

•

Memo

: create a memo.

•

SIM service

: access special services,

such as news, weather forecasts,

entertainment, and location services,

provided by your SIM card. This option is

available when you use a SIM card

supporting SIM Application Toolkit

menus, and may be differently displayed

depending on your service provider.

•

End call

: end a call.

•

End

: disconnect the call currently on

hold, active call, or all calls.

•

Send message

: send an SMS message

to the entered phone number.

•

Save as memo

: save the entered

number as a memo.

Using the video call feature

In a 3G (UMTS) service area, your phone

can make or receive a video call, allowing

you to see the other person on the screen

during a conversation. The other person’s

phone must support the video call feature.

Making a video call

1. In Idle mode, enter the area code and

phone number.

2. Press [ ].

Answering a video call

When you receive a video call, answer as

you would when receiving a voice call. Press

Show me

> to allow the caller to see you.

Call functions

Using video call options

During a video call, press <

Options

> to

access the following options:

•

Speaker on

Speaker off

: turn on the

speakerphone feature or switch back to

Normal mode.

•

Switch to headset

Switch to phone

switch the call to a Bluetooth headset or

hands-free car kit or back to the phone.

To use this feature, you first need to

connect your headset to the phone.



p. 95

•

Mute

: turn off the camera, microphone,

or key tone.

•

Display options

: change the camera

image settings.

Brightness

: display the brightness

control bar and adjust the brightness by

pressing [Left] or [Right].

Effects

: change the colour tone of the

image.

Quality

: change the image quality.

Zoom

: display the zoom control bar and

zoom in or out by pressing [Up] or

[Down].

Show caller ID

Hide caller ID

: display

or hide caller information.

•

More options

: access the following

options:

Phonebook

: access the contact list.

Create message

: send an SMS

message to the person with whom you

are talking.

View text message

: access the

received message list.

Send file

Send live

: show another

image instead of your camera image on

the other person’s phone, or restore the

display to the camera image.

Calendar

: access the calendar.

Memo

: create a memo.

•

End call

: end the video call.

Menu functions

All menu options listed

Call log

(Menu 1)

Use this menu to view the calls you have

dialled, received, or missed, and the length

of the calls. You can also check the cost of

your calls, if your USIM/SIM card supports

this function.

To access this menu, press <

> in Idle

mode and select

Call log

Accessing a call log

1. From the

Call log

menu, select a call

type.

2. Press [Left] or [Right] to move to

another call type.

3. Press [Up] or [Down] to scroll through

the call list.

4. Press [Centre] to view the details of a

call, or press [ ] to dial a number.

Using call log options

While viewing call details, press <

Options

to access the following options:

•

Voice call

: make a voice call to the

number.

•

Video call

: make a video call to the

number, if the 3G service is available.

•

Add to phonebook

: save the number to

Phonebook.

•

Create message

: send an SMS or MMS

message to the selected number.

•

Delete

: delete the selected call log or all

logs.

•

View contact details

: access contact

information, if the caller is saved in

Phonebook.

Viewing the data counter

From the call log list, press <

Options

> and

select

Call manager

→

Data counter

view the total amount of sent or received

data.

The following counters are available:

•

Total sent

: check the total amount of

data you have sent.

Menu functions

•

Total received

: check the total amount

of data you have received.

To reset a counter or all of the counters,

press <

Options

> and select

Reset

Reset all

Viewing call cost

From the call log list, press <

Options

> and

select

Call manager

→

Call costs

to view

the cost of calls. This option is available only

if supported by your USIM/SIM card. Note

that this is not intended to be used for billing

purposes.

The following counters are available:

•

Total

cost

: check the total cost of all

your calls. If the total cost exceeds the

maximum cost set in

Edit cost limit

you must reset the counter before you

can make another call.

•

Last

call

cost

: check the cost of your

last call.

•

Call limit

: check the maximum cost set.

Press <

Options

> to access the following

options:

•

Reset call

cost

: reset the cost counters.

•

Edit cost limit

: set the maximum cost

authorised for your calls.

•

Setup currency

: set the currency that

is applied when the cost of your call is

calculated.

Viewing call times

From the call log list, press <

Options

> and

select

Call manager

→

Call times

to view

the time log for calls made and received.

The actual time invoiced by your service

provider will vary.

The following counters are available:

•

Total dialled

: check the total length of

all the calls you have dialled.

•

Total received

: check the total length

of all the calls you have received.

•

Dialled voice calls

: check the total

length of voice calls dialled.

If the phone is locked, it will require the

password. The password is preset to

00000000

. You can change this

password.



p. 98

Menu functions

Phonebook

(Menu 2)

•

Dialled video calls

: check the total

length of video calls dialled.

•

Received voice calls

: check the total

length of voice calls received.

•

Received video calls

: check the total

length of video calls received.

To reset a counter or all of the counters,

press <

Options

> and select

Reset

Reset all

Phonebook

(Menu 2)

You can store phone numbers on your USIM/

SIM card and in your phone’s memory. The

USIM/SIM card and phone’s memory are

physically separate, but they are used as a

single entity called Phonebook.

To access this menu, press <

> in Idle

mode and select

Phonebook

Search for contacts

(Menu 2.1)

Use this menu to search for contacts in

Phonebook.

Finding a contact

1. Enter the first few letters of the name

that you want to find.

2. Select a contact from the list.

3. Scroll to a number and press [ ] to

dial, or press [Centre] to edit contact

information.

Using Phonebook options

While viewing contact details, press

Options

> to access the following options:

•

Edit

: edit contact information.

•

Voice call

: make a voice call to the

selected number.

•

Video call

: make a video call to the

number, if the 3G service is available.

If the phone is locked, it will require the

password. The password is preset to

00000000

. You can change this

password.



p. 98

You can quickly access this menu by

pressing <

Contacts

> in Idle mode.

Menu functions

•

Send message

: send an SMS or MMS

message to the selected number, or send

an MMS message or e-mail to the

selected e-mail address.

•

Duplicate

: make a copy of the contact.

•

Delete

: delete the contact.

•

Mark default number

: set the selected

number as the default for the contact.

•

Send namecard via

: send the contact

details via MMS, e-mail, or Bluetooth.

•

Special options

: set the following

options:

Caller image

: assign a caller ID image

to alert you to a call from the person.

Caller ringtone

: assign a ringtone to

alert you to a call from the person.

Msg.alert tone

: select a ringtone to

alert you to an incoming message from

the person.

•

Add to group

: add the number to a

caller group.

•

Add to speed dial

: set the selected

number as a speed dial entry.

•

Copy to SIM

Copy to phone

: copy the

contact from the phone’s memory to the

USIM/SIM card, or vice versa.

•

Print via Bluetooth

: print contact

information by connecting the phone to a

printer via Bluetooth. Some printers may

not be compatible with the phone.

Create contact

(Menu 2.2)

Use this menu to add a new contact to

Phonebook.

Storing a contact in the phone’s

memory

1. Select

Phone

2. Change the settings or enter information

about the contact.

•

First name

Last name

: assign a

name.

•

Mobile

Home

Office

Fax number

Etc.

: add a number in any type.

To mark an added number for making

video calls, press <

Options

> and

select

Mark video call

•

: assign an e-mail address.

Menu functions

Phonebook

(Menu 2)

•

Group

: assign the contact to a caller

group.

•

URL

: enter a homepage address.

•

Note

: add a memo about the person.

•

Birthday

: enter the person’s

birthday.

•

Postal address 1

Postal address

: enter the person’s postal address.

3. Press <

Options

> and select

Special

options

to add additional information:

•

Caller image

: assign a caller ID

image to alert you to a call from the

person.

•

Caller ringtone

: assign a ringtone

to alert you to a call from the person.

•

Msg. alert tone

: select a ringtone to

alert you to an incoming message

from the person.

4. Press <

Options

> and select

Save

save the contact.

Storing a contact on the USIM/SIM

card

1. Select

SIM

2. Enter information about the contact.

•

Name

: assign a name.

•

Mobile

: add a phone number.

•

Group

: (for USIM) assign a caller

group.

•

Location number

: enter a location

number.

3. If you are using a USIM card, press

Options

> to add additional

information:

•

Add item

: add a number type to the

contact.

•

Delete item

: remove the selected

category from the contact.

4. Press <

Save

>, or press <

Options

> and

select

Save

to save the contact.

Groups

(Menu 2.3)

Use this menu to organise your contacts in

caller groups.

Creating a caller group

1. Press <

Options

> and select

Create

group

2. Enter a name for the group.

3. Press <

Save

> to save the group.

Menu functions

Adding members to a caller group

1. Select a group.

2. Press [Centre] to select the contacts to

be added.

3. Press <

Save

Managing caller groups

While viewing the group list, press

Options

> to access the following options:

•

Add member

: add members to the

selected group, if the group does not

have any.

•

View members

: display the members

of the selected group.

•

Create group

: add a new group.

•

Delete

: delete the selected group or all

groups. Group members, however, will

not be deleted from Phonebook.

•

Rename group

: change the group

name.

My namecard

(Menu 2.4)

Use this menu to create a name card and

send it to other people.

Saving your name card

The procedure for creating your name card

is the same as the one for saving a phone

number in the phone’s memory.



p. 38

Using name card options

After saving your name card, press

Options

> to access the following options:

•

Edit

: edit the name card.

•

Send namecard via

: send the name

card via MMS, e-mail, or Bluetooth.

•

Delete

: delete the name card.

•

Exchange namecard

: exchange name

cards with another person via Bluetooth.

•

Print via Bluetooth

: print contact

information by connecting the phone to a

printer via Bluetooth. Some printers may

not be compatible with the phone.

Copy all

(Menu 2.5)

Use this menu to copy all of the contacts

stored on the USIM/SIM card to the phone’s

memory, or vice versa.

Menu functions

Phonebook

(Menu 2)

Service number

(Menu 2.6)

Use this menu to view the list of Service

Dialling Numbers (SDN) assigned by your

service provider, including emergency

numbers and numbers for directory

enquiries. This menu is available if your

USIM/SIM card supports SDN.

Scroll to the number you want and press

[].

Phonebook settings

(Menu 2.7)

Use this menu to change the default settings

for Phonebook.

Speed dial

(Menu 2.7.1)

Use this menu to assign a speed dial number

(2 to 9) for 8 of your most frequently dialled

numbers.

Assigning speed dial numbers

1. Select a key location from

. Key

is reserved for your voicemail server.

2. Select a contact from the contact list.

3. Select a number.

Managing speed dial entries

From the Speed dial screen, press

Options

> to access the following options:

•

Assign

: assign a number to an

unassigned key.

•

View

: check the name and number

assigned to a key.

•

Voice call

: make a voice call to the

number assigned to a key.

•

Video call

: make a video call to the

number assigned to a key, if the 3G

service is available.

•

Change

: assign a different number to a

key.

•

Remove

: clear the speed dial setting for

a key.

Dialling speed dial numbers

In Idle mode, press and hold the appropriate

key.

Sort contacts by

(Menu 2.7.2)

Use this menu to change the sort order of

the contact list.

Menu functions

Save new contacts to

(Menu 2.7.3)

Use this menu to select a default memory

location for saving contacts. If you select

Always ask

, the phone will ask you to

select a memory location each time you save

a number.

View contacts in

(Menu 2.7.4)

Use this menu to set the memory location

from which Phonebook shows entries.

Own number

(Menu 2.7.5)

Use this menu to check your phone

numbers, or to assign a name to each of the

numbers. Changes made here do not affect

the actual subscriber numbers on your

USIM/SIM card.

Memory status

(Menu 2.8)

Use this menu to check the number of

contacts you have stored in the phone’s

memory and on the USIM/SIM card.

Multimedia

(Menu 3)

This menu provides you with access to and

options for the media player and voice

recorder.

To access this menu, press <

> in Idle

mode and select

Multimedia

Media player

(Menu 3.1)

You can enjoy music and video files from the

phone’s memory. First, you need to save

files to your phone’s memory.

To enjoy high quality music, you can use an

optional Bluetooth stereo headset.

Downloading or receiving music or

video files

You can play the following types of files on

your phone.

• Music: *.mp3, *.aac, *.wma, *.m4a,

*.mmf

• Video: *.mp4, *.3gp

Use the following methods to save music or

video files to your phone’s memory:

• Download from the wireless web



p. 47

Menu functions

Multimedia

(Menu 3)

• Download from a computer using the

optional Samsung PC Studio



Samsung

PC Studio User’s Guide

• Receive via an active Bluetooth

connection



p. 97

• Copy files to a memory card and insert

the card info the phone



p. 25

Downloaded or received files are stored in

the

Music

folder in

Sounds

, or

Downloads

folder in

Videos

Music

(Menu 3.1.1)

Use this menu to arrange and play your

music. You need to add files to the play list.

Creating a play list

1. From the My music list, press

Options

> and select

Add to playlist

→

Selected

All

2. For

All

, select

Sounds

Memory card

press [Centre] to select the files you

want and press <

Add

3. Press <

Back

> to return to the file list.

4. Press [Left] or [Right] to access the play

list.

Playing music files

1. From the Playlist screen, press

Options

> and select

Play via

2. Select

Phone

to use the phone speaker.

Select

Bluetooth stereo headset

use a Bluetooth stereo headset and then

search for and connect the phone to the

headset.

During playback, use the following keys:

Key Function

Centre Pauses or resumes playback.

Left Returns to the previous file.

Moves backward in a file when

held down.

Right Skips to the next file. Skips

forward in a file when held

down.

Up Opens the play list.

Down Changes the repeat mode.

Volume Adjusts the volume.

Changes the playback

animation.

Menu functions

Using music player options

While playing a file, press <

Options

> to

access the following options:

•

Pause

Play

: pause or begin playback.

•

Bluetooth stereo headset

Transfer

to phone

: switch sound output to a

Bluetooth stereo headset or phone

speaker.

•

Stop

: stop playback.

•

Open playlist

: access the play list.

•

Show controller

Hide controller

display or hide the controller image. This

option may not be shown depending on

the playback animation setting.

•

Send via

: send the current file via MMS,

e-mail, or Bluetooth.

•

Set as

: set the file as your ringtone for

voice calls or video calls, or as a ringtone

for a Phonebook entry.

•

Activate

Reactivate

: get a new licence

key for the selected DRM files.

•

Details

: access the file properties.

•

Settings

: change the default settings for

playing music files.

Repeat mode

: select a repeat mode.

Shuffle

: set the music player to play

tracks in random order.

Visualisation

: change the playback

animation.

Backlight

: set whether or not the

display backlight stays on during

playback.

Hide controller

: set the music player to

hide the controller image.

Volume

: select a volume level.

•

Key management

: manage the licence

keys you have acquired.

Editing the play list

You can edit the play list by adding or

removing files or changing the play order.

1. From the My music list, press [Left] or

[Right] to access the play list.

2. Press <

Options

> to access the options

for editing the play list.

•

Add

: add new music files.

•

Move track in playlist

: move the

selected file to the position you want

within the play list.

Menu functions

Multimedia

(Menu 3)

•

Remove

: remove the selected file or

all files from the play list.

3. When you have finished, press

Options

> and select

Play via

→

sound output mode to begin playback.

Videos

(Menu 3.1.2)

Use this menu to access and play video files.

Playing video clips

Select a video file from the list. The video

player opens and the video plays.

During playback, use the following keys:

Using video player options

While playing a file, press <

Options

> to

access the following options:

•

Play

Pause

: begin or pause playback.

•

Stop

: stop playback.

•

Show controller

Hide controller

display or hide then controller image.

•

Send via

: send the current file via MMS,

e-mail, or Bluetooth.

•

Activate

Reactivate

: get a new licence

key for the selected DRM files.

•

Details

: access the file properties.

•

Settings

: change the default settings for

playing video files.

Repeat mode

: select a repeat mode.

Shuffle

: set the video player to play

tracks in random order.

Hide controller

: set the music player to

hide the controller image.

Volume

: select a volume level.

•

Streaming settings

: select a

connection profile to be used to access

streaming servers. You can also create or

edit a profile.



p. 93

Key Function

Centre Pauses or resumes playback.

Left Returns to the previous file.

Moves backward in a file when

held down.

Right Skips to the next file. Moves

forward in a file when held

down.

Up Opens the file list.

Down Changes the repeat mode.

Volume Adjusts the volume.

Menu functions

•

Key management

: manage the licence

keys you have acquired.

Voice recorder

(Menu 3.2)

Use this menu to record voice memos. A

voice memo can be up to 30 minutes long.

Recording a voice memo

1. Press [Centre] to start recording.

2. Speak into the microphone.

Press [Centre] to pause or resume

recording.

3. Press <

Stop

> or [Down] to end

recording. The voice memo is saved

automatically.

4. Press [Centre] to review the memo, or

press [Up] to record additional memos.

Playing a voice memo

1. From the voice recorder screen, press

Options

> and select

My voice clips

2. Select a voice memo from the

My voice

clips

folder. The memo plays.

During playback, use the following keys:

Using voice recorder options

After playback, press the <

Options

> to

access the following options:

•

Play

: play the selected voice memo in

Review mode.

•

Record

: record a new voice memo.

•

My voice clips

: access the voice memo

list.

Key Function

Centre Pauses or resumes playback.

Left Returns to the previous file.

Moves backward in a file when

held down.

Right Skips to the next file. Moves

forward in a file when held

down.

Volume Adjusts the volume.

Down Stops playback.

Menu functions

Browser

(Menu 4)

•

Send via

: send the file via MMS, e-mail,

or Bluetooth.

•

Settings

: customise the default settings

for the voice recorder.

Default name

: set the default prefix for

file names.

Recording time

: set the maximum

recording time.

Visualiser skin

: change the skin type of

the voice recorder.

Changing voice recorder settings

You can change the default settings for the

voice recorder. Before recording a voice

memo, press <

Options

> and select

Settings

to access the following options:

•

Default name

: set the default prefix for

file names.

•

Recording time

: set the maximum

recording time.

•

Visualiser skin

: change the skin type of

the voice recorder.

Browser

(Menu 4)

The web browser on your phone allows you

to access the wireless web. From the

wireless web, you can access up-to-date

information and a wide variety of media

content, such as games, wallpapers,

ringtones, and music files.

To access this menu, press <

> in Idle

mode and select

Browser

Home

(Menu 4.1)

Use this menu to connect your phone to the

network and load the homepage of the

wireless web service provider.

Navigating the web browser

To Press

scroll through

browser items

[Up] or [Down].

select a browser

item

[Centre], or

Options

> and select

Go to

Menu functions

Using browser options

From any web page, press <

Options

> to

access the following options:

•

Go to

: access the linked web page.

•

: move backward or forward through

pages in history.

•

Reload

: reload the current page with

updated information.

•

To DesktopView

To SmartFitView

change the display mode of the browser.

•

Go to homepage

: return to the

homepage.

•

Bookmarks

: bookmark the current

page or access the bookmark list.

•

Enter URL

: enter a URL address

manually.

•

Send URL

: send the URL of the current

page via SMS.

•

Save

: save the selected image or the

current page.

•

History

: access the list of web pages

you have accessed.

•

Advanced

: change the various settings

for the browser.

Empty cache

: clear the cache. The

cache is a temporary memory site that

stores recently accessed web pages.

Empty cookie

: delete cookies. Cookies

are pieces of personal information sent

to a web server while navigating the

web.

•

Cookies options

: set whether or not

cookies are stored. If you select

Prompt

, the phone will ask you to save

the cookies of the current page.

•

Preferences

: change the browser

display, sound, other settings.

•

Page details

: access the page

properties.

•

About browser

: access version and

return to the

Back

>, or

Options

> and select

→

Backward

move to the next

page

Options

> and select

→

Forward

To Press

Menu functions

Browser

(Menu 4)

Exiting the browser

Press [ ] to end the network connection

and exit the browser.

Enter URL

(Menu 4.2)

Use this menu to manually enter a URL

address and access the associated web

page.

You can add the entered URL address to the

bookmark list by selecting

Add bookmark

Bookmarks

(Menu 4.3)

Use this menu to save URL addresses in

order to quickly access web pages, or access

the preset bookmarks.

Adding a bookmark

1. Press <

Options

> and select

Add

bookmark

2. Enter a title for the bookmark and press

[Down].

3. Enter a URL address and press <

Save

Accessing a bookmarked page

Selecting a bookmark item launches the web

browser and accesses the associated web

page.

Using bookmark options

After saving an item, press <

Options

> to

access the following options:

•

Go to

: access the bookmarked web

page.

•

Go to homepage

: return to the

homepage.

•

Enter URL

: enter a URL address

manually.

•

Add bookmark

: add a new bookmark.

•

Bookmark

: add a new bookmark or edit

the URL address and title of the

bookmark, if you selected an added one.

•

Send URL

: send the URL address of the

bookmark via SMS.

•

Delete

: delete the selected bookmark or

all bookmarks, except for the preset

ones.

Menu functions

Saved pages

(Menu 4.4)

You can access the list of pages you have

saved while online.

If you select a link on the page, the phone

goes online to access the linked page.

History

(Menu 4.5)

You can access the list of pages you have

accessed recently.

Select a URL from the list to access the

corresponding web page.

Advanced

(Menu 4.6)

Use this menu to clear the cache or delete

cookies or to change the browser display

settings.

•

Empty cache

: clear the cache. The

cache is a temporary memory site that

stores recently accessed web pages.

•

Empty cookie

: delete cookies. Cookies

are pieces of personal information sent

to a web server while navigating the

web.

•

Cookies options

: set whether or not

cookies are stored. If you select

Prompt

, the phone will ask you to save

the cookies of the current page.

•

Preferences

: change the browser

display and sound settings.

•

About browser

: access version and

Browser settings

(Menu 4.7)

Use this menu to select a connection profile

to be used for accessing the wireless web.

You can also create or edit a profile.



p. 93

Messages

(Menu 5)

Use the

Messages

menu to send and

receive text messages, multimedia

messages, and e-mails. You can also send

postcards or access voicemails, push

messages, and broadcast messages.

To access this menu, press <

> in Idle

mode and select

Messages

Menu functions

Messages

(Menu 5)

Create message

(Menu 5.1)

Use this menu to create and send messages.

Text message

(Menu 5.1.1)

Short Message Service (SMS) allows you to

send or receive text messages.

Creating and sending an SMS message

1. Enter your message.

2. Press [Centre].

3. Enter a destination number.

To send the message to more than one

recipient, fill in additional destination

fields.

4. Press [Centre] to send the message.

Using options while composing an SMS

message

While composing a message, press

Options

> to access the following options:

•

Send

: send the message.

•

View by vivid message

: view the

message in 3D view mode. The phone

converts message text to 3D vivid

graphics. This option is available only

when the message consists of a single

page.

•

Input method

: change the text input

mode.

•

Input language

: change the language

to be used in T9 input mode.

•

Insert

: insert a text template,

Phonebook entry, or bookmarked URL

address into text.

•

Save to drafts

: save the message in the

Drafts

box.

• The maximum number of

characters allowed in a message

varies by service provider. If your

message exceeds the maximum

number of characters, the phone

will split the message.

• Depending on the file type or DRM

(Digital Rights Management)

system, some files may not be able

to be forwarded.

• You can use various by pressing

Options



next section

Menu functions

Multimedia message

(Menu 5.1.2)

Multimedia Message Service (MMS) delivers

messages containing a combination of text,

image, video, and audio, from phone to

phone or from phone to e-mail.

Creating and sending an MMS message

1. Enter the message subject.

2. Select

Picture or video

Sound

and

add an image, a video, or a sound file.

3. Select

Text

4. Enter the message text and press

[Centre].

5. Press <

Options

> and select

Add file(s)

→

an item type.

•

Business card

: add Phonebook

entries as name cards.

•

Appointment

Anniversary

Task

Memo

: add calendar items, tasks, or

memos.

•

Other files

: add a document file

stored in the

Other files

folder

6. Press [Centre] to select Phonebook

entries, calendar items, tasks, memos,

or document files.

7. Press <

Options

> and select

Attach

8. When you have finished, press [Centre],

or press <

Options

> and select

Send

9. Enter a phone number or e-mail address.

To send the message to more than one

recipient, fill in additional destination

fields.

10. Press [Centre] to send the message.

Using options while composing an MMS

message

While composing an MMS message, press

Options

> to access the following options:

•

Input

: enter the message text.

•

Send

: send the message.

•

Preview

: view the message as it will be

shown on the recipient’s phone.

•

Insert

: insert a text template,

Phonebook entry, or bookmarked URL

address into text.

• The maximum size allowed for a

message can differ, depending on

your service

provider.

• You can use various options by

pressing <

Options

> in each field.



next section

Menu functions

Messages

(Menu 5)

•

Input method

: change the text input

mode.

•

Input language

: change the language

to be used in T9 input mode.

•

Insert text template

: insert a text

template into text.

•

Add

: add an image, video, or sound clip.

•

Edit style

: set the page duration and

change the font colour and style for the

selected page or all pages.

•

Text on top

Image on top

: choose to

display the text or image at the

beginning of the message on the

recipient’s phone.

•

Change picture

Change sound

replace an added item.

•

Edit text

: edit the text of your message.

•

Remove picture

Remove sound

Remove text

: remove an added item.

•

Add page

: add pages. Move to each

page by pressing [Left] or [Right].

•

Delete page

: delete a page.

•

Move page forward

Move page

backward

: move the current page

forward or backward one page with the

message.

•

Save to drafts

: save the message in the

Drafts

box.

•

Save as multimedia message

template

: save the message as a

template.

•

Add file(s)

: attach a Phonebook entry

as a name card or calendar data as a

data format attachment, or a document

file stored in the

Other files

folder.

•

Attached file list

: access the list of the

files you attached.

(Menu 5.1.3)

You can create and send e-mails that include

text, audio, and images. To use this feature,

you need to subscribe to an e-mail service

and set up your e-mail account and

profile.



p. 64

Menu functions

Creating and sending an e-mail

1. Enter the subject of your e-mail.

2. Move to the

Message

field.

3. Enter the e-mail text.

4. Select the

Attach file(s)

line and select

Add

→

an item type.

•

File(s)

: add media or document

files.

•

Business card

: add Phonebook

entries as name cards.

•

Appointment

Anniversary

Task

Memo

: add calendar items, tasks, or

memos.

5. Press [Centre] to select the items to be

added.

6. Press <

Options

> and select

Attach

To review the files you have attached,

press <

Options

> and select

Attached

file list

7. When you have finished, press [Centre],

or press <

Options

> and select

Send

8. Enter an e-mail address.

To send the e-mail to more than one

recipient, fill in additional destination

fields.

9. Press [Centre] to send the e-mail.

Using options while composing an

e-mail

While composing an e-mail, press

Options

> to access the following options:

•

Send

: send the e-mail.

•

Preview

: view the e-mail as it will be

shown on the recipient’s phone.

•

Input method

: change the text input

mode.

•

Input language

: change the language

to be used in T9 input mode.

•

Insert text template

: insert a text

template into text.

•

Insert

: insert a text template,

Phonebook entry, or bookmarked URL

address into text.

Depending on the DRM (Digital Rights

Management) system, some files may

not be able to be forwarded.

Menu functions

Messages

(Menu 5)

•

Attached file list

: access the list of the

files you attached.

•

Add

: add an image, video, or sound clip.

•

Add file(s)

: attach a Phonebook entry

as a name card or calendar data as a

data format attachment, or a document

file stored in the

Other files

folder.

•

Save to drafts

: save the e-mail in the

Drafts

box.

Inbox

(Menu 5.2)

Use this menu to store all of the messages

you have received, except for e-mails.

Viewing a message

The following icons may appear on the

message list to show the message type:

• SMS

• MMS

• Push message from web servers.

• Configuration message, containing

network parameters from your

service provider.

• Broadcast message from your

service provider

Using message options

While viewing a message, press <

Options

to access the following options:

SMS messages

•

TEL/URL/Email focused option

: dial

the highlighted phone number or connect

to the URL in the message.

•

: reply to the sender via SMS or

MMS.

•

Forward

: forward the message to other

people.

•

View by vivid message

View BY

: view

the message in 3D view mode or switch

back to normal view mode. This option is

available only when the message

consists of a single page.

•

Delete

: delete the message.

• Depending on the DRM (Digital Rights

Management) system, messages having

web content may not be able to be

forwarded.

• A

icon next to a message means that

the

message is of high priority. A grey-

coloured message icon indicates low

priority.

Menu functions

•

Move to phone

Move to SIM

: move

the message between the USIM/SIM

card and the phone’s memory.

•

Add to phonebook

: save the sender's

phone number to Phonebook. If a phone

number, e-mail address, or URL address

within the message is selected, you can

also save it to Phonebook.

•

Print via Bluetooth

: print the message

by connecting the phone to a printer via

Bluetooth. Some printers may not be

compatible with the phone.

MMS messages

•

Retrieve

: retrieve the MMS message

from the MMS server.

•

Play

: play the message.

•

: reply to the sender via SMS or

MMS.

•

Reply to all

: reply to the sender and all

of the other recipients.

•

Forward

: forward the message to other

people.

•

Activate

Reactivate

: get a new licence

key for the selected DRM files.

•

Delete

: delete the message.

•

Save as template

: save the message

as a template.

•

Attached items

: save media content

from the message to your phone’s

memory.

•

Add to phonebook

: save the sender's

phone number to Phonebook. If a phone

number, e-mail address, or URL address

within the message is selected, you can

also save it to Phonebook.

•

Print via Bluetooth

: print the message

by connecting the phone to a printer via

Bluetooth. Some printers may not be

compatible with the phone.

•

Details

: access the message properties.

•

Key management

: manage the licence

keys you have acquired.

Configuration messages

•

Install

: apply the configuration specified

in the message to your phone.

•

Delete

: delete the message.

Menu functions

Messages

(Menu 5)

Push messages

•

TEL/Email focused option

: dial the

highlighted phone number or connect to

the URL in the message.

•

Go to URL

: connect to the URL specified

in the message.

•

Delete

: delete the message.

Broadcast messages

•

TEL/URL/Email focused option

: dial

the highlighted phone number or connect

to the URL in the message.

•

Save

: save the message to the phone’s

memory.

•

Delete

: delete the message.

Email inbox

(Menu 5.3)

Use this menu to store e-mails that you

have received.

Viewing an e-mail

1. Press <

Options

> and select

Download

The phone checks the e-mail server and

downloads new e-mails.

2. Select an e-mail or a header.

3. Press [Volume] to view other pages in

the e-mail.

4. Press [Left] or [Right] to view the

previous or next e-mail.

Using e-mail options

While viewing the e-mail or header, press

Options

> to access the following options:

•

TEL/URL/Email/Attachment focused

option

: dial the highlighted phone

number or connect to the URL in the

message.

•

Retrieve

: retrieve the body of the

e-mail from the e-mail server.

•

: send a reply to the sender.

•

Reply to all

: send a reply to the sender

and all of the other recipients.

•

Forward

: forward the e-mail to other

people.

Depending on the DRM (Digital Rights

Management) system, messages having

web content may not be able to be

forwarded.

Menu functions

•

Delete

: delete the e-mail only from the

phone’s memory, or both from the

phone’s memory and from the e-mail

server.

•

Attached items

: save the attached files

from the e-mail to your phone’s memory.

•

Activate

Reactivate

: get a new licence

key for the selected DRM files.

•

Add to Phonebook

: save the sender's

phone number to Phonebook. If a phone

number, e-mail address, or URL address

within the e-mail is selected, you can

also save it to Phonebook.

•

Print via Bluetooth

: print the message

by connecting the phone to a printer via

Bluetooth. Some printers may not be

compatible with the phone.

•

Block by

: add the sender’s e-mail

address or subject to the Block list to

reject e-mails from that address or

containing that subject.

•

Details

: access the e-mail properties.

•

Key management

: manage the licence

keys you have acquired.

Drafts

(Menu 5.4)

Use this menu to store messages you have

saved to send at a later time.

From the message list, press <

Options

> to

access the following options:

•

View

: open the selected MMS message.

•

Edit

: edit the selected message.

•

Send

: send the message.

•

Delete

: delete the selected message or

all messages.

•

Sort by

: change the sort order of the

message list.

•

Lock

Unlock

: lock the message to

prevent it from being deleted, or unlock

the message.

•

Details

: access the message properties.

Outbox

(Menu 5.5)

Use this menu to store messages the phone

is attempting to send or has failed to send.

The following icons are available to show the

message status:

• Being sent

• Failed to be sent

Menu functions

Messages

(Menu 5)

From the message list, press <

Options

> to

access the following options:

•

View

: open the selected MMS message.

•

Send again

: resend the message.

•

Edit

: edit the selected message.

•

Delete

: delete the message or all

messages.

•

Sort by

: change the sort order of the

message list.

•

Lock

Unlock

: lock the message to

prevent it from being deleted, or unlock

the message.

•

Details

: access the message properties.

Sentbox

(Menu 5.6)

Use this menu to store messages that you

have sent.

While viewing a message, press <

Options

to access the following options:

•

Open file

: open the selected file.

•

Save file

: save the selected file.

•

Call

: dial the selected number.

•

Go to

: access the selected web link.

•

Add bookmark

: add the selected web

link to your bookmark list.

•

Forward

: forward the message to other

people.

•

Move to phone

Move to SIM

: move

the message between the USIM/SIM

card and the phone’s memory.

•

Lock

Unlock

: lock the message to

prevent it from being deleted, or unlock

the message.

•

Delete

: delete the message.

•

Details

: access the message properties.

Templates

(Menu 5.7)

Use this menu to make and use templates of

frequently used messages or passages.

Text templates

(Menu 5.7.1)

You can create SMS templates with the

sentences you use frequently so that you

can retrieve and insert them when

composing an SMS message.

Creating a template

1. Press <

Add new

>, or press <

Options

and select

Add new

, if one has been

already stored.

Menu functions

2. Enter a message and press [Centre].

Using template options

From the template list, press <

Options

> to

access the following options:

•

Send

: create and send a new SMS or

MMS message or an e-mail using the

template.

•

Add new

: add a new template.

•

Edit

: edit the selected template.

•

Delete

: delete the selected template or

all templates.

MMS templates

(Menu 5.7.2)

You can create MMS templates so that you

can use them in composing an MMS

message.

Creating a template

1. Press <

Add new

>, or press <

Options

and select

Add new

, if one has been

already stored.

2. Create a template as you would when

creating an MMS message.

3. Press <

Options

> and select

Save as

multimedia message template

Using template options

From the template list, press <

Options

> to

access the following options:

•

View

: open the selected template.

•

Edit

: edit the selected template.

•

Send

: send a new message using the

template.

•

Add new

: add a new template.

•

Delete

: delete the selected template or

all templates.

Voice mail

(Menu 5.8)

Use this menu to connect to your voicemail

server and access your voicemails.

Delete all

(Menu 5.9)

Use this menu to delete messages in each

message type all at once.

1. Press [Centre] to select the message

types to be cleared.

You can quickly access the voicemail

server by pressing and holding [

] in Idle

mode.

Menu functions

Messages

(Menu 5)

2. Press <

Delete

3. Press <

Yes

> to confirm the deletion.

Message settings

(Menu 5.0)

Use this menu to set up various options for

using the messaging services.

Text message

(Menu 5.0.1)

You can configure SMS settings.

•

Settings x

(where

is the setting profile

number): set the properties of each

profile.

Centre address

: store or change the

number of your SMS server.

Expiration

: set the length of time your

messages are stored in the SMS server.

Default type

: set the default message

type. The network can convert messages

into the selected format.

Name

: enter a profile name.

•

Sending options

: set up the options for

sending SMS messages:

Reply path

: allow recipients to reply to

you through your SMS server.

Delivery report

: set the network to

inform you when your messages have

been delivered.

Network selection

: select either

only

(GSM) or

PS preferred

(GPRS),

depending on your network.

Keep a copy

: leave copies of your

messages in the

Sentbox

folder after

sending.

Character support

: select a character

encoding type. When you select

Automatic

, the phone switches the

encoding type from GSM alphabet to

Unicode if you enter a Unicode character.

Use of Unicode encoding will reduce the

maximum number of characters in a

message to about half. If this menu is

not shown, your phone provides

automatic character encoding by default.

Multimedia message

(Menu 5.0.2)

You can configure MMS settings.

•

Sending options

: set up the options for

sending MMS messages:

Priority

: set the priority level of

messages.

Menu functions

Validity period

: set the length of time

messages are stored in the MMS server.

Delivery time

: set a time delay before

messages are sent.

Hide address

: set your address to be

hidden from the recipient’s phone.

Delivery report

: set the network to

inform you when your messages have

been delivered.

Read report

: send a read-reply request

along with your messages.

Keep a copy

: leave copies of your

messages in the

Sentbox

folder after

sending.

•

Receiving options

: set up the options

for receiving MMS messages:

Home network

: determine if your

phone retrieves new messages

automatically when you are in your

home service area.

Roaming network

: determine if your

phone retrieves new messages

automatically when you are roaming on

another network.

Reception within your home network or

while roaming has the following options:

Autodownload

: the phone

automatically retrieves messages from

the server.

Manual

: the phone displays

notifications. Use the

Retrieve

option

to manually retrieve new messages.

Restricted

: the phone receives

notifications first from the server. When

you attempt to retrieve messages, the

phone informs you of additional

charges.

Delivery report

: set the network to

inform the sender when a message has

been delivered to you.

Read report

: determine whether or not

the phone sends a read-reply when an

incoming message has been read.

Anonymous reject

: reject messages

from unknown senders.

•

MMS profiles

: select a connection

profile to be used for MMS. You can also

create or edit a profile.



p. 93

Menu functions

Messages

(Menu 5)

•

Message class

: set up the options for

creating MMS messages:

Message class

: select the type of

message content you will add or the

message size.

Video rich

: you can add any type of

items of up to 300 KB.

Text

: you can add only text of up to 30

KB.

Image basic

: you can add any type of

item, except for video, of up to 30 KB.

Image rich

: you can add any type of

item, except for video, of up to 100 KB.

Video basic

: you can add any type of

item of up to 100 KB.

Creation mode

: select an MMS creation

mode.

Free

: you can create a message with

any type of contents and of any size.

Restricted

: you can create a message

with the type of content and size

specified in

Message class

Warning

: you can create a message

with any type of content and of any

size, but the phone will inform you

when the content and size have

exceeded the maximum.

•

Default style

: set the default page

properties, such as page duration, font

colour or style, or background colour.

(Menu 5.0.3)

You can configure e-mail settings.

•

Sending options

: set up the options for

sending e-mails:

From

: set the sender name.

Sending account

: select the default

e-mail account.

Priority

: select the priority level of

e-mails.

Keep a copy

: leave copies of your

e-mails in the

Sentbox

folder after

sending.

You cannot change e-mail profile and

account settings while e-mails are being

sent or retrieved.

Menu functions

Send confirmation

: set the network to

inform you when your e-mails have been

delivered.

Read reply

: send a read-reply request

along with e-mails.

Add my business card

: allow your

contact information to be attached to

e-mails.

Add signature

: attach a tag line to new

e-mails or all e-mails including replies.

•

Receiving options

: set up the options

for receiving e-mails:

Retrieving option

: set whether the

phone downloads e-mail headers only or

the complete e-mail.

Reject if over

: determine the maximum

size for incoming e-mails. Your phone

will reject e-mails that exceed the

specified size.

Check interval

: determine how often

the phone checks the server for incoming

e-mails. If you select

Do not use

, use

the

Download

option to receive new

e-mails manually.

Read reply

: determine whether or not

the phone sends a read-reply when an

incoming e-mail has been read.

Block address

: specify e-mail

addresses to reject e-mails from those

addresses, and activate or deactivate

mail blocking.

Block subject

: reject e-mails which

contain subjects you specify, and

activate or deactivate mail blocking.

•

Email profiles

: select a connection

profile to be used for e-mail services. You

can also create or edit a profile.



p. 93

•

Email accounts

: set up an e-mail

account and select an account to be

used. Press <

Options

> and select

Edit

to access the following options for

setting up an account:

Account name

: enter a name for the

currently selected account.

SMTP server

: enter the IP address or

host name of the outgoing e-mail server.

SMTP Port

: enter the SMTP port

number.

Menu functions

Messages

(Menu 5)

Use SSL

: activate the use of the SSL

(Secured Sockets Layer) protocol.

Retrieve server type

: select the

protocol for the incoming e-mail server.

The remaining options depend on the

protocol type setting.

Retrieve server

: enter the IP address

or host name of the POP3 or IMAP4

server.

Retrieve Port

: enter the POP3 or IMAP4

port number.

Use SSL

: activate the use of the SSL

(Secured Sockets Layer) protocol.

Retrieving option

: (IMAP4 protocol

only) set whether the phone retrieves

messages with attachments or not.

Retrieve count

: (IMAP4 protocol only)

set the number of e-mail headers the

phone retrieves from the server at any

one time.

Leave a copy of messages on the

server

: leave copies of e-mails on the

e-mail server after retrieving.

My address

set your e-mail address.

User name

: enter the POP3 or IMAP4

user name.

Password

: enter the POP3 or IMAP4

password.

POP3/IMAP4 before SMTP

: connect

to the POP3 or IMAP4 server for

authentication before connecting to the

SMTP server to send e-mails.

User SMTP authentication

: enable

SMTP authentication, which requires the

user to log in before sending e-mails.

Same as POP3/IMAP4

: select if you

want the SMTP server to have the same

parameters as the POP3 or IMAP4 server.

User name

: enter the SMTP user name.

Password

: enter the SMTP password.

Voice mail

(Menu 5.0.4)

Use this menu to set the number of your

voicemail server.

You must store the voicemail server

number before accessing the server. Your

service provider can give you the number.

Menu functions

Push message

(Menu 5.0.5)

You can change the settings for receiving

push messages from the wireless web

server.

•

Receive

: set how your phone receives

push messages.

•

Service centre

: specify the server from

which the phone receives push

messages, if you selected

Optional

the

Receive

option.

Broadcast

(Menu 5.0.6)

You can change the settings for receiving

broadcast messages.

•

Receive

: set whether or not to receive

broadcast messages.

•

Channel list

: indicate the channels from

which you wish to receive broadcast

messages. To add a new channel,

remove the check mark from

All

channels

and press <

Options

>. Select

New

and set the channel ID information.

Please contact your service provider for

further details.

•

Language

: select the preferred

languages in which broadcast messages

display.

Memory status

(Menu 5.*)

Use this menu to view the number of

messages or the amount of memory

currently in use for each message type in

each folder.

You can also access a message box by

selecting it from this menu.

My files

(Menu 6)

The

My files

menu allows you to access

images, videos, music files, sound files, and

documents stored in the phone’s memory

and on a memory card.

To access this menu, press <

> in Idle

mode and select

My files

Menu functions

My files

(Menu 6)

Tips for Digital Rights Management

As a result of the Digital Rights Management

(DRM) system, some of the media items you

download from the Internet or receive by

MMS may require a licence key to access

them. You can acquire the key from the

website which owns the rights to the

content; use the

Activate

option.

Note the following icons on the list:

• : Forwardable item with a valid key.

• : Forwardable item without a valid

key.

• : Unforwardable item with a valid

key.

• : Unforwardable item without a valid

key.

Your service provider supports only count-

based or unlimited-access DRM files.

Images

Use this menu to access photos you have

taken and images you have downloaded,

received in messages, or imported from your

computer.

Viewing an image

1. Scroll to an image folder.

2. Select an image.

Viewing a slide show

You can view your images as a slide show, a

sequential presentation of each image in the

current folder.

1. Select an image folder.

2. While viewing an image, press

Options

> and select

Slide show

3. Press <

Play

>. The slide show begins.

4. Press <

Stop

> to stop the slide show.

Editing a photo

1. Select a photo.

2. Press <

Options

> and select

Edit

3. Press <

Options

> and edit the photo

using the following options:

•

Resize

: change the image size.

•

Effects

: change the colour tone or

apply a special effect to the photo.

•

Insert

: add a decorative frame, an

image, or text.

Menu functions

•

Rotate

: rotate the photo clockwise

or counterclockwise.

•

Flip

: flip the photo vertically or

horizontally.

4. When you have finished, press <

Done

5. Press <

Options

> and select

Save as

6. Enter a photo name and press <

Save

Using image options

While viewing an image, press <

Options

to access the following options:

•

Send via

: send the file via MMS, e-mail,

or Bluetooth.

•

Set as

: set the image as wallpaper for

the display or as a caller ID image for a

Phonebook entry.

•

Activate

Reactivate

: get a new licence

key when the key for the selected DRM

file expires.

•

Slide show

: view all images as a slide

show.

•

Edit

: edit the image and save it as a

different name.

•

Delete

: delete the file or all files.

•

Rename

: change the file name.

•

Bluetooth visibility

: share the selected

file with other Bluetooth devices.

•

Print via

: print the image by connecting

the phone to a printer via Bluetooth.

Some printers may not be compatible

with the phone.

•

Lock

Unlock

: lock the file to prevent it

from being deleted, or unlock the file.

•

Details

: access the file properties.

•

Key management

: manage the licence

keys you have acquired.

Downloading images

1. Scroll to the

Downloads

folder.

2. Select

More photos

. You are connected

to the website preset by your service

provider.

3. Search for the file you want and follow

the onscreen instructions to download it.

Videos

Use this menu to access video clips you have

recorded, downloaded, received in

messages, or imported from your computer.

Menu functions

My files

(Menu 6)

Playing a video clip

1. Scroll to a video folder.

2. Select a video clip. The video player

opens and the video plays.



p. 45

Using video options

From the video list, press <

Options

> to

access the following options:

•

Play

: play the selected file.

•

Send via

: send the file via MMS, e-mail,

or Bluetooth.

•

Move

: move the selected file or all files

to another folder.

•

Activate

Reactivate

: get a new licence

key when the key for the selected DRM

file expires.

•

Delete

: delete the file or all files.

•

Rename

: change the file name.

•

Create folder

: add a new folder.

•

Bluetooth visibility

: share the selected

file or all of the files in the current folder

with other Bluetooth devices.

•

Lock

Unlock

: lock the file to prevent it

from being deleted, or unlock the file.

•

Details

: access the file properties.

•

Key management

: manage the licence

keys you have acquired.

Downloading video clips

1. Scroll to the

Downloads

folder.

2. Select

More videos

. You are connected

to the website preset by your service

provider.

3. Search for the file you want and follow

the onscreen instructions to download it.

Sounds

Use this menu to access voice memos you

have recorded, and ringtones and sound

files you have downloaded, received in

messages, or imported from your computer.

Playing a sound clip

1. Select a sound folder.

Video clips recorded on other devices,

such as camcorders, may not play

correctly.

Menu functions

2. Select a sound clip. The music player

opens and the selected sound plays.



p. 43

For a voice memo, see

Voice recorder



p. 46

Using sound options

While viewing a sound list, press

Options

> to access the following options:

•

Play via

: play the selected music file via

the phone speaker or a Bluetooth stereo

headset.

•

Play

: play the selected ringtone or voice

memo.

•

Send

via

: send the file via MMS, e-mail,

or Bluetooth.

•

Set as

: set the sound as your ringtone

for voice calls or video calls, or a

ringtone for a Phonebook entry.

•

Activate

Reactivate

: get a new licence

key when the key for the selected DRM

file expires.

•

Move

: move the selected file or all files

to another folder.

•

Delete

: delete the file or all files.

•

Add to playlist

: add the file to the

current play list.

•

Rename

: change the file name.

•

Create folder

: add a new folder.

•

Bluetooth visibility

: share the selected

file or all of the files in the current folder

with other Bluetooth devices.

•

Lock

Unlock

: lock the file to prevent it

from being deleted, or unlock the file.

•

Details

: access the file properties.

•

Key management

: manage the licence

keys you have acquired.

Downloading sound files

1. Scroll to the

Music

Ringtones

folder.

2. Select

More music

More ringtones

You are connected to the website preset

by your service provider.

3. Search for the file you want and follow

the onscreen instructions to download it.

Menu functions

My files

(Menu 6)

Games & more

Use this menu to access the embedded Java

games and downloaded Java applications.

Accessing a game

Select a game from the game list and follow

the onscreen instructions. The procedure

may differ from game to game.

Using Java application options

While viewing the application list, press

Options

> to access the following options:

•

Start

: launch the selected application.

•

Move

: move the application to another

folder.

•

Activate

Reactivate

: get a new licence

key when the key for the selected DRM

file expires.

•

Delete

: delete the selected application

or all applications, except for embedded

games.

•

Create folder

: add a new folder.

•

Lock

Unlock

: lock the application to

protect it from being deleted, or unlock

the application.

•

Details

: access the application

properties.

•

Permissions

: set the permission

settings for services charging you

additional costs, such as network access

and SMS.

•

Settings

: select a connection profile to

be used for applications requiring

network access. You can also create or

edit a profile.



p. 93

•

Key management

: manage the licence

keys you have acquired.

Downloading applications

1. Select

More games

. You are connected

to the website preset by your service

provider.

2. Search for the application you want and

follow the onscreen instructions to

download it.

Menu functions

Other files

Use this menu to access any other files than

image, video, music, and sound files. Your

phone provides you with Picsel File Viewer to

allow you to view, without corruption,

various document files. Available file formats

are *.doc, *.xls, *.ppt, *.pdf, and *.txt.

Viewing a document

1. Scroll to a document folder.

2. Select a file. Picsel File Viewer runs to

open the document.

Use the following keys to view the

document:

Using file options

While viewing a document, press

Options

> or < > to access the

following options:

•

Full screen view

Normal view

change the view mode.

•

Zoom

: zoom in or out.

• Depending on the file size or memory

capacity of Picsel File Viewer, some files

may

not open properly.

• If a document file contains languages

unsupported by Picsel File Viewer, the

content of the document will not display

correctly.

Key Function

Up/Down/

Left/Right

Pans around the page.

Volume Zooms in or out.

Centre Fits the document to the

page size.

Returns to the first page.

Returns to the previous

page.

Rotates the document.

Moves to the next page.

Moves to the last page.

Changes the display to Full

screen view or Normal

screen view.

Key Function

Menu functions

Organiser

(Menu 7)

•

Fit to

: fit the document to the page size,

screen width, or screen height.

•

Go to

: move to another page of the

document.

•

Rotate

: rotate the document.

•

Screen panning

Normal panning

change the panning mode to by screen

or by preset pixel.

•

Hide controller

Show controller

: hide

or display the shortcut tool bar in Full

screen view.

•

Send via

: send the file via MMS, e-mail,

or Bluetooth.

•

Delete

: delete the selected file.

•

Rename

: change the file name.

•

Bluetooth visibility

: share the file with

other Bluetooth devices.

•

Lock

Unlock

: lock the file to prevent it

from being deleted, or unlock the file.

•

Details

: access the file properties.

•

Shortcuts

: view the functions of the

keys you can use in Picsel File Viewer.

Memory card

Use this menu to access the files stored in a

memory card. This menu is shown only

when a memory card is inserted into the

phone.

Memory status

Use this menu to check the amount of

memory currently in use in each media

folder. You can also access a folder by

selecting it from this menu.

Organiser

(Menu 7)

The

Organiser

menu enables you to use

various convenient features.

To access this menu, press <

> in Idle

mode and select

Organiser

Your phone can recognise only the


Videos

Sounds

, and

Other

files

folders in a memory card.

Menu functions

Calendar

(Menu 7.1)

Use this menu to keep track of your

schedule.

Selecting a day on the calendar

When you enter the

Calendar

menu, the

calendar appears with today’s date indicated

by a black box.

• Press [Left] or [Right] to move by day.

• Press [Up] or [Down] to move by week.

• Press [Up] until the month field is

highlighted and then [Left] or [Right] to

move by month.

Creating an item

You can store appointments and

anniversaries on the calendar. More than one

item per day can be stored.

Entering an appointment

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

Appointment

3. Enter information or change the settings:

•

Title

: enter a title for the

appointment.

•

Details

: enter appointment details.

•

Start date

and

Start time

: enter

the starting time and date for the

appointment.

•

End date

and

End time

: enter the

ending date and time for the

appointment.

•

Location

: enter information about

the appointment location.

•

Alarm

: set an alarm for the

appointment.

•

before

: set how long before the

appointment the alarm is to alert

you.

•

Alarm tone

: select an alarm tone.

•

Repeat

: set the appointment to

recur and select a repeat option.

•

every

: set how often you are alerted

to the appointment.

•

Expiry

: set when the appointment

will be deleted from the calendar.

4. Press <

Options

> and select

Save

save the appointment.

Menu functions

Organiser

(Menu 7)

Entering an anniversary

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

Anniversary

3. Enter information or change the settings:

•

Title

: enter a title for the

anniversary.

•

Details

: enter information about the

anniversary.

•

Date

: enter the date for the

anniversary.

•

Alarm

: select to set an alarm for the

anniversary.

•

before

: set how long before the

anniversary the alarm is to alert you.

•

Alarm time

: enter the time for the

alarm to sound.

•

Alarm tone

: select an alarm tone.

•

Repeat every year

: set the phone

to remind you of the anniversary

every year.

4. Press <

Options

> and select

Save

save the anniversary.

Consulting the calendar

Once you have created items, the square

brackets appear on the corners of the date

box.

Viewing an item

1. Select a date on the calendar to display

the items for the day.

2. Select an item to view its details.

While viewing an item, press <

Options

> to

access the following options:

•

Edit

: access the items stored for the

selected date.

•

Send via

: send the item via MMS,

e-mail, Bluetooth.

•

Delete

: delete the selected item.

•

Settings

: change the display settings

for the calendar. You can set the starting

day of the week and the default view

mode.

•

Missed alarm events

: view events

whose alarms you have missed.

•

Memory status

: access memory

information for the events stored on the

calendar.

Menu functions

Using calendar options

From the calendar, press <

Options

> to

access the following options:

•

View

: display the items stored for the

selected date.

•

View by

: change the view mode of the

calendar.

•

Create

: create a new item.

•

Go to

: go to today’s date or enter the

specific date you want to access.

•

Event list

: sort items by type of item.

•

Delete

: delete the items stored for the

selected date or all items.

•

Settings

: change the display settings

for the calendar. You can set the starting

day of the week and the default view

mode.

•

Missed alarm events

: view events

whose alarms you have missed.

•

Memory status

: access memory

information for the items stored on the

calendar.

Viewing items in a different mode

You can change the calendar display to Day

view or Week view. On the calendar, press

Options

> and select

View by

→

a view

mode.

Day view

You can view items for the selected date.

The following icons may display to indicate

the type:

• Appointment

• Anniversary

If you have set the Repeat and Alarm

options, the and icons display. Select

an item to view its details.

Week view

You can view items for the selected week. A

cell on the timetable indicates the presence

of an appointment.

Select a cell for the date you want.

Applications

(Menu 7.2)

Use this menu to use your phone as a

calculator, converter, world clock, task list,

or memo pad.

Menu functions

Organiser

(Menu 7)

Calculator

(Menu 7.2.1)

Use this menu to perform basic arithmetic

functions, such as addition, subtraction,

multiplication, and division.

1. Enter the first number.

• Press <

.()

> to insert a decimal point

or bracket.

•

Press

[] or [ ]

to move the cursor.

2. Press one of the Navigation keys to

access the math function you want.

3. Enter the second number.

4. Press [Centre] to view the result.

5. If necessary, repeat from step 2 to

continue the calculation.

Converter

(Menu 7.2.2)

Use this menu for common conversions,

such as currency and temperature.

Performing a conversion

1. Select a converter.

2. Press [Left] or [Right] to select the

original unit and press [Down].

3. Enter the value to be converted and

press [Down].

• Press [ ] to insert a decimal point.

• Press [ ] to change the temperature

to above zero (+) or below zero (-).

4. Press [Left] or [Right] to select the unit

to which you want to convert.

The equivalent value for the amount you

entered displays.

Using converter options

Press <

Options

> to access the following

options:

•

Clear

: clear the current values.

•

Reverse

: reverse the conversion.

•

Currency rates

: display the currency

rate list.

World clock

(Menu 7.2.3)

Use this menu to set your local time zone

and find out the current time in another part

of the world.

Setting the local time zone

1. From the world map, press [Left] or

[Right] to scroll to the city you want on

the upper line ( ). As the time line

moves, the time and date of the given

zone display.

Menu functions

2. Press [Centre] to save the city as your

local time zone.

Viewing world time

1. From the world map, move to the lower

line ( ).

2. Press [Left] or [Right] to scroll to the city

you want.

3. Press [Centre] to save the time zone.

Applying daylight saving time

1. From the world map, press <

Options

and select

Daylight saving

2. Press [Centre] to select the time zones

you want.

3. Press <

Save

Task

(Menu 7.2.4)

You can create a list of tasks you need to

complete.

Entering a task

1. Press <

Options

> and select

Create

2. Enter information or change the settings:

•

Title

: enter a subject of the task.

•

Details

: enter information about the

task.

•

Start date

: enter the starting date.

•

Due date

: enter the ending date.

•

Priority

: select a priority level.

3. Press <

Save

> to save the task.

Viewing a task

From the task list, the triangle icons on the

right indicate the importance; the lower the

number on the icon, the higher the priority.

A check mark appears in the status check

box if the task has been completed.

Select a task from the list.

Using task options

From the task list, press <

Options

> to

access the following options:

•

View

: access the selected task.

•

Create

: add a new task.

•

Send via

: send the task as a data file

via MMS, e-mail, or Bluetooth.

•

Done

Not done

: change the status of

the task.

•

Delete

: delete the selected task or all

tasks.

Menu functions

Organiser

(Menu 7)

•

Memory status

: access memory

information for tasks and memos you

have stored.

Memo

(Menu 7.2.5)

You can create a list of memos.

Creating a memo

1. Press <

Options

> and select

Create

2. Enter the memo contents and press

Save

Viewing a memo

Select a memo from the list.

Using memo options

From the memo list, press <

Options

> to

access the following options:

•

View

: access the selected memo.

•

Create

: add a new memo.

•

Send via

: send the memo as a data file

via MMS, e-mail, or Bluetooth.

•

Delete

: delete the selected memo or all

memos.

•

Memory status

: access memory

information for tasks and memos you

have stored.

Memory status

(Menu 7.2.6)

You can access memory information for

tasks and memos you have stored.

SIM AT

(Menu 7.2.7)

This menu is available if you use a SIM AT

card that supports SIM Application Toolkit

menus and provides additional services,

such as news, weather, sports,

entertainment, and location services.

Available services may vary, depending on

your service provider’s plans. For details,

see your USIM/SIM card instructions or

contact your service provider.

Alarms

(Menu 7.3)

Use this menu to set alarms to sound at

specified times to remind you of important

events or wake you up in the morning.

Setting an alarm

1. Select an alarm. If necessary, press

Options

> and select

Create alarm

add a new alarm.

2. Set each alarm option:

•

Alarm name

: enter the alarm name.

Menu functions

•

Alarm activation

: activate the

alarm.

•

Alarm time

: enter the time for the

alarm to sound.

•

Alert tone

: select an alarm tone.

•

Recurrence

: select the days on

which you want the alarm to sound.

If you select

Once

only

, the alarm

sounds at the specified time and then

is deactivated.

•

Snooze

: set the alarm to sound

again after 5 minutes.

•

Auto power-up

: set the alarm to

sound when the phone is off.

3. Press <

Save

Stopping an alarm

When the time for an alarm comes and the

alarm sounds:

•Press any key.

• For the alarms with the snooze feature

enabled, press any key, except for <

and [Centre], to cause it to sound again

after 5 minutes.

Deactivating an alarm

1. Select the alarm you want to deactivate.

2. Select

Off

on the

Alarm activation

line

and press <

Save

Camera

(Menu 8)

You can use the camera module embedded

in your phone to take photos and record

videos.

To access this menu, press <

> in Idle

mode and select

Camera

, or press and hold

[Camera].

Taking a photo

You can take photos in various modes. The

camera produces JPEG photos.

• Do not take photos of people without

their permission.

• Do not take photos in a place where

cameras are not allowed.

• Do not take photos in a place where

you may interfere with another

person’s privacy.

Menu functions

Camera

(Menu 8)

1. Access the

Camera

menu to turn on the

camera and switch the display to Capture

mode. You can also press and hold

[Camera] in Idle mode.

2. Make any desired adjustments.

• Press < > to access camera

options.



next section

• Use the keypad to change the camera

settings or switch to other modes.



p. 82

3. Press [Centre] or [Camera] to take a

photo. The photo is automatically saved

in the

Photos

folder.

Using camera options in Capture

mode

In Capture mode, press < > to access the

following options:

•

Take photo

: return to Capture mode.

•

Record video

: switch to Record mode.

•

Switch camera

: switch between the

interior camera lens and the exterior

camera lens.

•

Shooting mode

: take a photo in the

following modes:

Single shot

: take a photo in normal

mode.

Multi-shot

: take a series of action stills.

You can select the number of photos the

camera will take.

Mosaic shot

: take several stills and

save them in one frame. You can select

the layout.

•

Effects

: change the colour tone or apply

a special effect.

•

Frames

: apply a decorative frame.

When you take a photo in direct sunlight

or in bright conditions, shadows may

appear on the photo.

To Press

use photo options < > or

Options



p. 83

delete the photo [

] and then <

Yes

return to Capture

mode

[Centre] or < >.

Menu functions

•

Timer

: set a time delay before the

camera takes a photo.

•

Zoom

: display the zoom control bar and

zoom in or out by pressing [Up] or

[Down].

•

Brightness

: display the brightness

control bar and adjust the brightness by

pressing [Left] or [Right].

•

Go to My photos

: access the

Photos

folder.

•

Settings

: change the default settings for

taking a photo. Press [Left] or [Right] to

scroll through the following setting

options:

Size

: select an image size.

Quality

: select an image quality setting.

Viewfinder

: select a preview screen.

Whit balance

: adjust the colour balance

of the image. You can make your photo

appear warmer or cooler.

Shutter sound

: select the sound that

you hear when you press the shutter

release.

Multi-shot speed

: select the shooting

speed in Multi Shot mode.

Zoom sound

: turn the sound effect for

zooming on or off.

Brightness sound

: turn the sound

effect for brightness adjustment on or

off.

Default storage

: select the memory

location to store photos, if a memory

card is inserted.

Default name

: set the default name

prefix for file names.

•

Camera shortcuts

: view the functions

of the keys you can use in Capture

mode.

Using the keypad in Capture mode

You can use the keypad to customise your

camera settings in Capture mode.

Key Function

Left/Right Adjusts the brightness.

Up/Down Zooms in or out.

Switches to Record mode.



p. 83

Changes the image size.

Menu functions

Camera

(Menu 8)

Using photo options

After saving a photo, press < > or

Options

> to access the following options:

•

Send via

: send the file via MMS, e-mail,

or Bluetooth.

•

Delete

: delete the file or all of the multi-

shot photos.

•

View

: access one of the multi-shot

photos.

•

Viewfinder

: return to Capture mode.

•

Set as

: set the photo as wallpaper for

the display or as a caller ID image for a

Phonebook entry.

•

Edit

: edit the photo by using various

tools.



p. 67

•

Rename

: change the file name.

•

Go to My photos

: access the

Photos

folder.



p. 67

•

Lock

Unlock

: lock the file to protect it

from being deleted, or unlock the file.

•

Bluetooth visibility

: share the file with

other Bluetooth devices.

•

Details

: access the file properties.

Recording a video

You can record a video of what is displayed

on the screen and save it.

1. Access the

Camera

menu to turn on the

camera and switch the display to Capture

mode. You can also press and hold

[Camera] in Idle mode.

Changes the image quality.

Changes the shooting mode.

Changes the colour tone or

applies a special effect.

Changes the white balance.

Adds a decorative frame.

Sets the timer.

Determines the use of the

flash.

Goes to the

Photos

folder.

Changes the preview screen.

Key Function

Menu functions

2. Press [

] to switch to Record mode.

3. Make any desired adjustments.

• Press < > to access camera

options.



next section

• Use the keypad to change the camera

settings or switch to other modes.



p. 85

4. Press [Centre] or [Camera] to start

recording.

5. Press < > or [Camera] to stop

recording. The video is automatically

saved in the

Videos

folder.

Using camcorder options in Record

mode

In Record mode, press < > to access the

following options:

•

Record video

: return to Record mode.

•

Take photo

: switch to Capture mode.

•

Switch camera

: switch between the

interior camera lens and the exterior

camera lens.

•

Effects

: change the colour tone or apply

a special effect.

•

Timer

: set a time delay before the

camera starts recording.

•

Zoom

: display the zoom control bar and

zoom in or out by pressing [Up] or

[Down].

•

Brightness

: display the brightness

control bar and adjust the brightness by

pressing [Left] or [Right].

•

Go to My video clips

: access the

Videos

folder.

•

Settings

: change the default settings for

recording a video. Press [Left] or [Right]

to scroll through the following settings

for recording a video:

To Press

play back the video

clip

[Centre].

use video options <

Options



p. 86

delete the video [

] and then

Yes

return to Record

mode

Back

Menu functions

Camera

(Menu 8)

Recording mode

: select a video

recording mode. Selecting

Limit for

MMS

allows you to record a video for

adding an MMS message.

Size

: select a frame size.

Quality

: select an image quality setting.

Whit balance

: adjust the colour balance

of the image. You can make your photo

appear warmer or cooler.

Record audio

: record a video with

audio.

Brightness sound

: turn the sound

effect for brightness adjustment on or

off.

Zoom sound

: turn the sound effect for

zooming on or off.

Default storage

: select the memory

location to store videos, if a memory

card is inserted.

Default name

: set the default name

prefix for file names.

•

Camcorder shortcuts

: view the

functions of the keys you can use in

Record mode.

Using the keypad in Record mode

You can use the keypad to customise your

camera settings in Record mode.

Key Function

Left/Right Adjusts the brightness.

Up/Down Zooms in or out.

Switches to Capture

mode.



p. 80

Changes the frame size.

Changes the image quality.

Changes the video recording

mode.

Changes the colour tone or

applies a special effect.

Changes the white balance.

Mutes or unmutes audio.

Sets the timer.

Determines the use of the

flash.

Goes to the

Videos

folder.

Changes the preview screen.

Menu functions

Using video options

After saving a video clip, press <

Options

to access the following options:

•

Play

: play back the video clip.

•

Send via

: send the file via MMS, e-mail,

or Bluetooth.

•

Delete

: delete the file.

•

Viewfinder

: return to Record mode.

•

Rename

: change the file name.

•

Go to My videos

: access the

Videos

folder.



p. 68

•

Lock

Unlock

: lock the file to protect it

from being deleted, or unlock the file.

•

Bluetooth visibility

: share the file with

other Bluetooth devices.

•

Details

: access the file properties.

Settings

(Menu 9)

The

Settings

menu provides you with

various setting options to customise the

phone to your preferences and needs. You

can also reset the settings to their default

status.

To access this menu, press <

> in Idle

mode and select

Settings

Phone settings

(Menu 9.1)

Many different features of your phone’s

system can be customised to suit your

preferences.

Phone profiles

(Menu 9.1.1)

Your phone provides you with sound profiles

that allow you to quickly and easily change

the sound settings of the phone for different

events or situations. Use this menu to adjust

the properties of each profile and activate

the profile you need.

Some menus may not be available,

depending on your service provider.

Menu functions

Settings

(Menu 9)

Editing a profile

1. Scroll to the profile you want.

2. Press <

Options

> and select

Edit

3. Change the sound settings:

•

Call alert type

: select an alert type

for the call ringer.

•

Voice call ringtone

: select a

ringtone for voice calls.

•

V-call ringtone

: select a ringtone

for video calls.

•

Tone volume

: adjust the volume for

the call ringer.

•

Msg.alert type

: select an alert type

for the message ringer.

•

Msg.alert tone

: select a ringtone for

the message ringer.

•

Msg.alert repetition

: select if the

phone repeatedly reminds you of a

new message.

•

Phone sounds

: turn the various

sounds on the phone on or off.

All

: enable all tones.

Popup box alerts

: set the phone to

beep when a pop-up window

displays.

Minute minder

: set the phone to

beep every minute during an

outgoing call to keep you informed of

the length of your call.

Call connect tone

: set the phone to

beep when an outgoing call is

connected to the system.

Call end tone

: set the phone to

beep when a call is disconnected by

the other person or due to a faded

signal.

Power on

: set the phone to beep

when you turn it on.

Sound effect

: cause the phone to

beep when you access Menu mode or

an option list.

Alerts on call

: set the phone to

beep when you receive a new

message or when the time for an

alarm comes during a call.

•

Keytones

: select a tone which

sounds when you press a key.

•

Keytone volume

: adjust the volume

of the key tones.

Menu functions

•

Call answer mode

: (for Car) select

how to answer an incoming call.

4. When you have finished, press <

Save

Changing the active profile

From the profile list, select the profile you

want and press [Centre].

Language

(Menu 9.1.2)

Use this menu to select one of several

languages for the display text and T9 input

mode, separately. If you select

Automatic

the phone uses the same language as the

USIM/SIM card.

Shortcuts

(Menu 9.1.3)

You can use the Navigation keys as

shortcuts to access specific menus directly

from Idle mode. Use this menu to assign a

shortcut to a key.

Assigning a shortcut menu

1. Select a key to be used as a shortcut

key.

2. Select a menu to be assigned to the key.

3. Press <

Save

Using shortcut options

Press <

Options

> to access the following

options:

•

Assign

: assign a shortcut menu.

•

Change

: change a shortcut menu

assignment.

•

Remove

: deactivate the shortcut

assignment to the selected key.

•

Remove all

: deactivate all shortcut

assignments.

Time & date

(Menu 9.1.4)

Use this menu to change the time and date

displayed on your phone. Before setting the

time and date, specify your time zone in the

World clock

menu.



p. 77

•

Date

: enter the current date.

•

Time

: enter the current time. To select

AM or PM for 12-hour time format, press

[Right].

•

Time format

: select a time format.

•

Date format

: select a date format.

•

Daylight saving

: select to apply

daylight saving time.

Menu functions

Settings

(Menu 9)

Auto redial

(Menu 9.1.5)

Use this menu to set the phone to make up

to ten attempts to redial a phone number

after an unsuccessful call.

Any key answer

(Menu 9.1.6)

Use this menu to answer an incoming call by

pressing any key, except for <

Reject

> and

[].

Volume key in incoming call

(Menu 9.1.7)

Use this menu to set whether the phone

mutes the call ringer or rejects a call if you

press and hold [Volume] when a call comes

in.

Display settings

(Menu 9.2)

Use this menu to change settings for the

display and backlight.

Main display

(Menu 9.2.1)

Use this menu to customise the properties of

the main display.

•

Greeting message

: enter the greeting

that is displayed briefly when the phone

is switched on.

•

Wallpaper

: select an image to be

displayed on the main display.

•

Brightness

: adjust the brightness of the

display for varying lighting conditions.

Backlight time

(Menu 9.2.2)

You can select the length of time the

backlight or display stays on.

•

: select the length of time the

backlight stays on.

•

Dim

: select the length of time the

display stays on in Dim mode after the

backlight turns off. After a specified time,

the display turns off.

Keypad light

(Menu 9.2.3)

Use this menu to select a keypad backlight

mode. Select one of the following options

from the top line:

•

Any time

: flash the backlight when you

press any key.

Menu functions

•

Night time

: use the backlight only

between 5:00 PM and 9:00 AM. Doing

this saves the battery power.

•

Custom time

: use the backlight during

the period of time you specify.

Dialling display

(Menu 9.2.4)

Use this menu to customise the settings for

the numbers entered and the background

colour of the display while dialling.

Main menu style

(Menu 9.2.5)

You can select a display style for the main

menu screen.

Show caller information

(Menu 9.2.6)

Use this menu to set the phone to display

missed call notifications with the most

recently missed caller’s information.

Message settings

(Menu 9.3)

Use this menu to change the default settings

for using the message services.



p. 61

Call settings

(Menu 9.4)

Use this menu to access network services.

Please contact your service provider to

check their availability and subscribe to

them, if you wish.

Show my number

(Menu 9.4.1)

This network service allows you to prevent

your phone number from being displayed on

the phone of the person being called. If you

select

By network

, the phone will use the

default setting provided by the network.

Diverts

(Menu 9.4.2)

This network service reroutes incoming calls

to a phone number that you specify.

1. Select the type of calls to be diverted.

2. Select a call diverting option:

•

Always

: divert all calls.

•

Busy

: divert calls when you are on

another call.

Some networks may not allow you to

change this setting.

Menu functions

Settings

(Menu 9)

•

: divert calls when you do

not answer the phone.

•

Not reachable

: divert calls when

you are not in your service area or

when your phone is switched off.

•

Cancel

all

: cancel all call diverting

options.

3. Enter the number to which calls are to be

diverted on the

Diverts to

line.

4. If you selected

No reply

, move to the

Waiting time

line and select the length

of time the network delays before

diverting a call.

5. Press <

Options

> and select

Activate

To deactivate call diverting, select

Deactivate

Barring

(Menu 9.4.3)

This network service allows you to restrict

your calls.

1. Select the type of calls to be barred.

2. Select a call barring option:

•

All

outgoing calls

: prohibit all

outgoing calls.

•

Outgoing int’l calls

: prohibit

international calls.

•

Int’l call exc. Home

: only allow

calls to numbers within the current

country when you are abroad, and to

your home country.

•

All

incoming calls

: prohibit

incoming calls.

•

Incoming

calls when roaming

prohibit incoming calls when you use

your phone outside of your home

service area.

•

Cancel

all

: cancel all call barring

settings, allowing calls to be sent and

received normally.

3. Enter the call barring password supplied

by your service provider.

4. Press <

Options

> and select

Activate

To deactivate call barring, select

Deactivate

You can change the call barring password

obtained from your service provider. Press

Options

> from the call type list and

select

Change password

Menu functions

Waiting

(Menu 9.4.4)

This network service informs you when

someone is trying to reach you while you are

on another call.

1. Select the type of calls to which call

waiting option will apply.

2. Press <

Options

> and select

Activate

To deactivate call waiting, select

Deactivate

Video call settings

(Menu 9.4.5)

Use this menu to change the default settings

for using the video call feature.

•

Show me

: change the video camera

settings for receipt of video calls.

Optionally

: you can select whether or

not the video camera is used each time

you answer a video call.

Always

: the camera is always used.

•

Retry with

: set what to do when a video

call does not connect.

Voice call

: the phone retries with a

voice call.

Video call

: the phone retries with a

video call.

Camera

: the phone turns on the camera

and switches to Record mode so that you

can record a video and send it as an MMS

message.

None

: the phone does not retry.

Phonebook settings

(Menu 9.5)

Use this menu to change the settings for

using Phonebook.



p. 41

Network settings

(Menu 9.6)

This menu allows you to customise settings

for connecting to a network.

Select network

(Menu 9.6.1)

This network service allows you to manually

select the network to be used while roaming

outside of your home area, or to let the

network be chosen automatically. You can

select a network other than your home

network only if there is a valid roaming

agreement between the two.

Menu functions

Settings

(Menu 9)

Network mode

(Menu 9.6.2)

Use this menu to select the network you

use.

•

Automatic

: the phone scans for

available networks.

•

GSM900/1800:

the phone operates in

the combined GSM 900/1800 network.

•

GSM1900

: the phone operates in the

GSM 1900 network. This option is only

available in the U.S.A.

•

UMTS

: the phone operates in UMTS (3G

network) networks. You can get a higher

speed connection than on lower

generation networks, and use advanced

data and information services, such as

video calls.

Connections

(Menu 9.6.3)

Use this menu to create and customise the

profiles containing the settings for

connecting your phone to the network. You

need these settings to use the web browser

or send MMS messages or e-mails.

Creating a profile

1. Press <

Options

> and select

New

2. Specify profile parameters:

•

Set name

: enter a profile name.

•

Access name

: edit the access point

name used for the address of the

GPRS network gateway.

•

Auth type

: choose the type of

authentication used.

•

User ID

: enter the user ID.

•

Password

: enter the user password.

•

Home URL

: enter the URL address

of the page to be used as your

homepage.

•

Gateway address

: (WAP only) enter

the gateway address of the proxy

server.

•

Proxy address

Port

: (HTTP only)

set the proxy server address and

port.

Your phone is set up by default connecting

to the network. If you change the settings

without first checking with your service

provider, the web browser, MMS, and

e-mail features may not work properly.

Menu functions

•

Secure connection

: (WAP only)

turn the secure mode on or off.

•

Linger time(sec.)

: set a time period

after which the network is

disconnected if there has been no

new data traffic in that time.

•

Advanced settings

provide you

with the following options:

Static IP

: specify if you want to

manually enter an IP address; see

the Local phone IP option. If you

want the IP address to be

automatically assigned by the server,

remove the check mark.

Local phone IP

: enter the IP

address obtained from the network

operator, if you checked the

Static

option.

Static DNS

: specify if you want to

manually enter the Domain Name

Server (DNS) address; see the

Server1

Server2

option.

If you want the address to be

automatically assigned by the server,

remove the check mark.

Server1

Server2

: enter the

Domain Name Server (DNS)

addresses.

Traffic class

: select the traffic class.

3. Press <

Save

> to save the profile.

Using profile options

From the profile list, press <

Options

> to

access the following options:

•

Edit

: edit the selected profile.

•

New

: add a new profile.

•

Rename

: change the profile name.

•

Delete

: delete the profile.

Browser settings

(Menu 9.6.4)

Use this menu to select a connection profile

to be used for accessing the Internet. You

can also create or edit a profile.



p. 93

Streaming settings

(Menu 9.6.5)

Use this menu to activate a connection

profile to be used for accessing streaming

servers. You can also create or edit a profile.



p. 93

Menu functions

Settings

(Menu 9)

Bluetooth

(Menu 9.7)

Using the Bluetooth feature, you can

connect the phone wirelessly to other

Bluetooth devices and exchange data with

them, talk hands-free, or control the phone

remotely.

Bluetooth technology allows free wireless

connections between all Bluetooth-compliant

devices within a range of 10 meters. Since

the devices communicate using radio waves,

they do not need to be in line of sight to

each other.

Setting up the Bluetooth feature

The

Bluetooth

menu provides the following

options:

•

Activation

: activate or deactivate the

Bluetooth feature.

•

My devices

: search for connectable

Bluetooth devices.

•

My phone’s visibility

: allow other

Bluetooth devices to locate your phone,

or not.

•

My phone’s name

: assign a Bluetooth

device name to your phone, which is

then displayed on other devices.

•

Secure mode

: determine if the phone

asks for your confirmation when other

devices access your data.

•

Bluetooth services

: display available

Bluetooth services.

Searching for and pairing with a

Bluetooth device

1. From the

Bluetooth

menu, select

devices

• If there are obstacles between the

devices,

the

operating distance may be

reduced.

• It is recommended that you don’t use

the

Bluetooth feature while using

multimedia

features, such as voice

recorder, camera,

and media player, or

vice versa, for better

performance.

• Some devices may not be compatible

with

your phone.

Menu functions

2. Select

Search for new devices

After searching, a list of devices to which

you can connect displays. The following

icons indicate the type of device:

The colour of the icon indicates the

status of the device:

• Grey for unpaired devices

• Blue for paired devices

• Red for devices that are currently

connected to your phone

3. Select a device.

4. Enter a Bluetooth PIN and press <

This code is used just once and you don’t

need to memorise it.

When the owner of the other device

enters the same code, pairing is

complete.

Using device options

From the device list, press <

Options

> to

access the following options:

•

Connect

: connect to a headset or

hands-free car kit.

•

Disconnect

: end the connection with

the connected device.

•

Browse files

: search for data from the

device and import data directly to your

phone.

•

Service list

: access the Bluetooth

service list of the device.

•

Rename

: rename the paired device.

•

Authorise device

Unauthorized

device

: determine whether or not the

phone asks you to permit connection

when other devices try to connect to

your phone.

•

Delete

: remove the selected device or

all devices from the list.

• Headset • Hands-free

car kit

• Computer • Printer

• Mobile phone• PDA

• Unknown device

Some devices, especially headsets or

hands-free car kits, may have a fixed

Bluetooth PIN, such as

0000

. If the other

device has a code, you must enter it.

Menu functions

Settings

(Menu 9)

Sending data via Bluetooth

1. Activate the Bluetooth feature.

2. Select the application in which the item

you want to send is stored.

3. Scroll to the item you want and press

Options

4. Select

Send namecard via

Send via

→

Bluetooth

The phone searches for devices within

range and displays a list of available

devices.

5. Select a device.

6. If necessary, enter the Bluetooth PIN

needed for pairing and press <

Receiving data via Bluetooth

To receive data via Bluetooth, your phone’s

Bluetooth feature must be active and its

visibility must be enabled.

1. If an unauthorised Bluetooth device

sends data to your phone, press <

Yes

to allow the device to access your phone.

2. Press <

Yes

> to receive data.

Security

(Menu 9.8)

Use this menu to protect the phone against

unauthorised use by managing the several

access codes of your phone and USIM/SIM

card.

Phone lock

(Menu 9.8.1)

Use this menu to protect the phone from

unauthorised use. When this feature is

enabled, you must enter a 4- to 8-digit

phone password each time the phone is

switched on.

The password is preset to

00000000

. To

change the password, use the

Change

phone password

menu.

If you enter an incorrect PIN/PIN2 three

times, the USIM/SIM card is blocked. To

unblock it you need to enter your PUK/

PUK2 (Personal Unblocking Key). The

codes are supplied by your service

provider.

Menu functions

SIM lock

(Menu 9.8.2)

This menu allows your phone to work only

with the current USIM/SIM by assigning a

SIM lock code. You must enter the SIM lock

code to use a different USIM/SIM card.

PIN lock

(Menu 9.8.3)

The 4- to 8-digit PIN (Personal Identification

Number) protects your USIM/SIM card

against unauthorised use. When this feature

is enabled, the phone requires your PIN each

time it is switched on.

Fixed dialling mode

(Menu 9.8.4)

If supported by your USIM/SIM card, Fixed

Dialling Number (FDN) mode restricts your

outgoing calls to a limited set of phone

numbers. When this feature is enabled, you

can make calls only to phone numbers

stored on the USIM/SIM card.

Change phone password

(Menu 9.8.5)

Use this menu to change your phone

password.

Privacy lock

(Menu 9.8.6)

Use this menu to lock access to messages,

media files, call logs, or Phonebook entries.

When a lock option is enabled, you must

enter the phone password to access the

locked items.

Change PIN code

(Menu 9.8.7)

Use this menu to change your PIN. The PIN

lock feature must be enabled to change the

PIN.

Change PIN2 code

(Menu 9.8.8)

If supported by your USIM/SIM card, use

this menu to change your current PIN2.

Memory settings

(Menu 9.9)

Use this menu to clear data or to view

memory information in your phone’s

memory. You can also manage the licence

keys you have acquired to activate media

contents locked by DRM systems.

Clear memory

(Menu 9.9.1)

You can delete messages, media contents,

contacts, and calendar items. You can also

delete all data at one time.

Menu functions

Settings

(Menu 9)

1. Press [Centre] to select the data you

want to delete.

2. Press <

Clear

3. Enter the phone password and press

Confirm

4. Press <

Yes

Key management

(Menu 9.9.2)

Use this menu to manage the licence keys

you have acquired to activate media

contents locked by DRM systems.

Press <

Options

> to access the following

options:

•

View

: open the corresponding item.

•

Delete

: delete the selected licence key.

•

Go to My Messages

: access the

message that contains the media

content.

•

Go to File manager

: access the

corresponding file folder.

•

Details

: access the properties of the

licence key.

Memory card

(Menu 9.9.3)

Use this menu to check the memory

information of the inserted memory card,

format the memory card, or change the

name.

Memory status

(Menu 9.9.4)

Use this menu to check the amount of

memory being used for storing data, such as

messages, media and document files,

calendar items, or Phonebook entries.

Master reset

(Menu 9.0)

You can reset the phone’s settings and clear

all data that you have added.

1. Enter the phone password and press

Confirm

2. Press <

Yes

>. The phone automatically

turns itself off and then back on.

The password is preset to

00000000

You can change this password.



p. 98

The password is preset to

00000000

You can change this password.



p. 98

100

Solve problems

Help and personal needs

To save the time and expense of an

unnecessary service call, perform the simple

checks in this section before contacting a

service professional.

When you switch on your phone, the

following messages may appear:

“Please insert SIM card”

• Be sure that the USIM/SIM card is

correctly installed.

“Phone lock Password”

• The automatic locking function has been

enabled. You must enter the phone’s

password before you can use the phone.

“PIN lock PIN code”

• You are using your phone for the first

time. You must enter the PIN supplied

with the USIM/SIM card.

• The PIN lock feature is enabled. Every

time the phone is switched on, the PIN

has to be entered. To disable this

feature, use the

PIN lock

menu.

“Enter PUK”

• The PIN has been entered incorrectly

three times, and the USIM/SIM card is

now blocked. Enter the PUK supplied by

your service provider.

“No service” or “Network failure”

displays

• The network connection has been lost.

You may be in a weak signal area. Move

and try again.

• You are trying to access an option for

which you have no subscription with your

service provider. Contact the service

provider for further details.

You have entered a number but it was

not dialled

• Be sure that you have pressed [ ].

• Be sure that you have accessed the right

cellular network.

• Be sure that you have not set an

outgoing call barring option.

101

Solve problems

Your correspondent cannot reach you

• Be sure that your phone is switched on.

([ ] pressed for more than one

second.)

• Be sure that you are accessing the

correct cellular network.

• Be sure that you have not set an

incoming call barring option.

Your correspondent cannot hear you

speaking

• Be sure that you have switched on the

microphone.

• Be sure that you are holding the phone

close enough to your mouth. The

microphone is located at the bottom of

the phone.

The phone starts beeping and “Low

battery” flashes on the display

• Your battery is insufficiently charged.

Recharge the battery.

The audio quality of the call is poor

• Check the signal strength indicator on

the display ( ). The number of bars

indicates the signal strength from strong

() to weak ().

• Try moving the phone slightly or moving

closer to a window if you are in a

building.

No number is dialled when you re-call a

Phonebook entry

•Use the

Search for contacts

menu to

ensure the number has been stored

correctly.

• Re-store the number, if necessary.

The battery does not charge properly or

the phone sometimes turns itself off

• Wipe the charging contacts both on the

phone and on the battery with a clean

soft cloth.

If the above guidelines do not help you

to solve the problem, take note of:

• The model and serial numbers of your

phone

•Your warranty details

• A clear description of the problem

Then contact your local dealer or Samsung

after-sales service.

102

Health and safety

information

Exposure to Radio Frequency (RF)

Signals

Certification Information (SAR)

Your wireless phone is a radio transmitter

and receiver. It is designed and

manufactured not to exceed the exposure

limits for radio frequency (RF) energy set by

the Federal Communications Commission

(FCC) of the U.S. government. These FCC

exposure limits are derived from the

recommendations of two expert

organizations, the National Counsel on

Radiation Protection and Measurement

(NCRP) and the Institute of Electrical and

Electronics Engineers (IEEE). In both cases,

the recommendations were developed by

scientific and engineering experts drawn

from industry, government, and academia

after extensive reviews of the scientific

literature related to the biological effects of

RF energy.

The exposure limit set by the FCC for

wireless mobile phones employs a unit of

measurement known as the Specific

Absorption Rate (SAR). The SAR is a

measure of the rate of absorption of RF

energy by the human body expressed in

units of watts per kilogram (W/kg). The FCC

requires wireless phones to comply with a

safety limit of 1.6 watts per kilogram (1.6

W/kg). The FCC exposure limit incorporates

a substantial margin of safety to give

additional protection to the public and to

account for any variations in measurements.

SAR tests are conducted using standard

operating positions accepted by the FCC with

the phone transmitting at its highest

certified power level in all tested frequency

bands. Although the SAR is determined at

the highest certified power level, the actual

SAR level of the phone while operating can

be well below the maximum value. This is

because the phone is designed to operate at

multiple power levels so as to use only the

power required to reach the network. In

general, the closer you are to a wireless

103

Health and safety information

base station antenna, the lower the power

output.

Before a new model phone is available for

sale to the public, it must be tested and

certified to the FCC that it does not exceed

the exposure limit established by the FCC.

Tests for each model phone are performed in

positions and locations (e.g. at the ear and

worn on the body) as required by the FCC.

The highest SAR values for this model phone

as reported to the FCC are: Head:1.390 W/

Kg, Body-worn: 0.951 W/Kg;

For body worn operation, this model phone

has been tested and meets the FCC RF

exposure guidelines whenused with a

Samsung accessory designated for this

product or when used with an accessory that

contains no metal and that positions the

handset a minimum of 1.5 cm from the

body.

Non-compliance with the above restrictions

may result in violation of FCC RF exposure

guidelines.

SAR information on this and other model

phones can be viewed on-line at

www.fcc.gov/oet/fccid. This site uses the

phone FCC ID number, A3LSGHZ370.

Sometimes it may be necessary to remove

the battery pack to find the number. Once

you have the FCC ID number for a particular

phone, follow the instructions on the website

and it should provide values for typical or

maximum SAR for a particular phone.

Additional product specific SAR information

can also be obtained at www.fcc.gov/cgb/

sar.

Consumer Information on Wireless

Phones

The U.S. Food and Drug Administration

(FDA) has published a series of Questions

and Answers for consumers relating to radio

frequency (RF) exposure from wireless

phones. The FDA publication includes the

following information:

What kinds of phones are the subject

of this update?

The term wireless phone refers here to

hand-held wireless phones with built-in

104

Health and safety information

antennas, often called “cell,” “mobile,” or

“PCS” phones. These types of wireless

phones can expose the user to measurable

radio frequency energy (RF) because of the

short distance between the phone and the

user's head. These RF exposures are limited

by Federal Communications Commission

safety guidelines that were developed with

the advice of FDA and other federal health

and safety agencies. When the phone is

located at greater distances from the user,

the exposure to RF is drastically lower

because a person's RF exposure decreases

rapidly with increasing distance from the

source. The so-called “cordless phones,”

which have a base unit connected to the

telephone wiring in a house, typically

operate at far lower power levels, and thus

produce RF exposures well within the FCC's

compliance limits.

Do wireless phones pose a health

hazard?

The available scientific evidence does not

show that any health problems are

associated with using wireless phones. There

is no proof, however, that wireless phones

are absolutely safe. Wireless phones emit

low levels of radio frequency energy (RF) in

the microwave range while being used. They

also emit very low levels of RF when in the

stand-by mode. Whereas high levels of RF

can produce health effects (by heating

tissue), exposure to low level RF that does

not produce heating effects causes no

known adverse health effects. Many studies

of low level RF exposures have not found

any biological effects. Some studies have

suggested that some biological effects may

occur, but such findings have not been

confirmed by additional research. In some

cases, other researchers have had difficulty

in reproducing those studies, or in

determining the reasons for inconsistent

results.

What is FDA's role concerning the

safety of wireless phones?

Under the law, FDA does not review the

safety of radiation-emitting consumer

products such as wireless phones before

they can be sold, as it does with new drugs

or medical devices. However, the agency has

authority to take action if wireless phones

105

Health and safety information

are shown to emit radio frequency energy

(RF) at a level that is hazardous to the user.

In such a case, FDA could require the

manufacturers of wireless phones to notify

users of the health hazard and to repair,

replace or recall the phones so that the

hazard no longer exists.

Although the existing scientific data do not

justify FDA regulatory actions, FDA has

urged the wireless phone industry to take a

number of steps, including the following:

• “Support needed research into possible

biological effects of RF of the type

emitted by wireless phones;

• “Design wireless phones in a way that

minimizes any RF exposure to the user

that is not necessary for device function;

and

• “Cooperate in providing users of wireless

phones with the best possible

information on possible effects of

wireless phone use on human health.

FDA belongs to an interagency working

group of the federal agencies that have

responsibility for different aspects of RF

safety to ensure coordinated efforts at the

federal level. The following agencies belong

to this working group:

•“National Institute for Occupational

Safety and Health

• “Environmental Protection Agency

• “Federal Communications Commission

• “Occupational Safety and Health

Administration

• “National Telecommunications and

Information Administration

The National Institutes of Health participates

in some interagency working group

activities, as well.

FDA shares regulatory responsibilities for

wireless phones with the Federal

Communications Commission (FCC). All

phones that are sold in the United States

must comply with FCC safety guidelines that

limit RF exposure. FCC relies on FDA and

other health agencies for safety questions

about wireless phones.

FCC also regulates the base stations that the

wireless phone networks rely upon. While

these base stations operate at higher power

than do the wireless phones themselves, the

106

Health and safety information

RF exposures that people get from these

base stations are typically thousands of

times lower than those they can get from

wireless phones. Base stations are thus not

the primary subject of the safety questions

discussed in this document.

What are the results of the research

done already?

The research done thus far has produced

conflicting results, and many studies have

suffered from flaws in their research

methods. Animal experiments investigating

the effects of radio frequency energy (RF)

exposures characteristic of wireless phones

have yielded conflicting results that often

cannot be repeated in other laboratories. A

few animal studies, however, have

suggested that low levels of RF could

accelerate the development of cancer in

laboratory animals. However, many of the

studies that showed increased tumor

development used animals that had been

genetically engineered or treated with

cancer-causing chemicals so as to be pre-

disposed to develop cancer in absence of RF

exposure. Other studies exposed the

animals to RF for up to 22 hours per day.

These conditions are not similar to the

conditions under which people use wireless

phones, so we don't know with certainty

what the results of such studies mean for

human health.

Three large epidemiology studies have been

published since December 2000. Between

them, the studies investigated any possible

association between the use of wireless

phones and primary brain cancer, glioma,

meningioma, or acoustic neuroma, tumors

of the brain or salivary gland, leukemia, or

other cancers. None of the studies

demonstrated the existence of any harmful

health effects from wireless phones RF

exposures. However, none of the studies can

answer questions about long-term

exposures, since the average period of

phone use in these studies was around three

years.

What research is needed to decide

whether RF exposure from wireless

phones poses a health risk?

112

Health and safety information

A combination of laboratory studies and

epidemiological studies of people actually

using wireless phones would provide some

of the data that are needed. Lifetime animal

exposure studies could be completed in a

few years. However, very large numbers of

animals would be needed to provide reliable

proof of a cancer promoting effect if one

exists. Epidemiological studies can provide

data that is directly applicable to human

populations, but ten or more years' follow-

up may be needed to provide answers about

some health effects, such as cancer. This is

because the interval between the time of

exposure to a cancer-causing agent and the

time tumors develop - if they do - may be

many, many years. The interpretation of

epidemiological studies is hampered by

difficulties in measuring actual RF exposure

during day-to-day use of wireless phones.

Many factors affect this measurement, such

as the angle at which the phone is held, or

which model of phone is used.

What is FDA doing to find out more

about the possible health effects of

wireless phone RF?

FDA is working with the U.S. National

Toxicology Program and with groups of

investigators around the world to ensure

that high priority animal studies are

conducted to address important questions

about the effects of exposure to radio

frequency energy (RF).

FDA has been a leading participant in the

World Health Organization international

Electromagnetic Fields (EMF) Project since

its inception in 1996. An influential result of

this work has been the development of a

detailed agenda of research needs that has

driven the establishment of new research

programs around the world. The Project has

also helped develop a series of public

information documents on EMF issues.

FDA and Cellular Telecommunications &

Internet Association (CTIA) have a formal

Cooperative Research and Development

Agreement (CRADA) to do research on

107

Health and safety information

wireless phone safety. FDA provides the

scientific oversight, obtaining input from

experts in government, industry, and

academic organizations. CTIA-funded

research is conducted through contracts to

independent investigators. The initial

research will include both laboratory studies

and studies of wireless phone users. The

CRADA will also include a broad assessment

of additional research needs in the context

of the latest research developments around

the world.

What steps can I take to reduce my

exposure to radio frequency energy

from my wireless phone?

If there is a risk from these products - and

at this point we do not know that there is - it

is probably very small. But if you are

concerned about avoiding even potential

risks, you can take a few simple steps to

minimize your exposure to radio frequency

energy (RF). Since time is a key factor in

how much exposure a person receives,

reducing the amount of time spent using a

wireless phone will reduce RF exposure.

• “If you must conduct extended

conversations by wireless phone every

day, you could place more distance

between your body and the source of the

RF, since the exposure level drops off

dramatically with distance. For example,

you could use a headset and carry the

wireless phone away from your body or

use a wireless phone connected to a

remote antenna.

Again, the scientific data do not demonstrate

that wireless phones are harmful. But if you

are concerned about the RF exposure from

these products, you can use measures like

those described above to reduce your RF

exposure from wireless phone use.

What about children using wireless

phones?

The scientific evidence does not show a

danger to users of wireless phones,

including children and teenagers. If you

108

Health and safety information

want to take steps to lower exposure to

radio frequency energy (RF), the measures

described above would apply to children and

teenagers using wireless phones. Reducing

the time of wireless phone use and

increasing the distance between the user

and the RF source will reduce RF exposure.

Some groups sponsored by other national

governments have advised that children be

discouraged from using wireless phones at

all. For example, the government in the

United Kingdom distributed leaflets

containing such a recommendation in

December 2000. They noted that no

evidence exists that using a wireless phone

causes brain tumors or other ill effects. Their

recommendation to limit wireless phone use

by children was strictly precautionary; it was

not based on scientific evidence that any

health hazard exists.

Do hands-free kits for wireless phones

reduce risks from exposure to RF

emissions?

Since there are no known risks from

exposure to RF emissions from wireless

phones, there is no reason to believe that

hands-free kits reduce risks. Hands-free kits

can be used with wireless phones for

convenience and comfort. These systems

reduce the absorption of RF energy in the

head because the phone, which is the source

of the RF emissions, will not be placed

against the head. On the other hand, if the

phone is mounted against the waist or other

part of the body during use, then that part

of the body will absorb more RF energy.

Wireless phones marketed in the U.S. are

required to meet safety requirements

regardless of whether they are used against

the head or against the body. Either

configuration should result in compliance

with the safety limit.

Do wireless phone accessories that

claim to shield the head from RF

radiation work?

Since there are no known risks from

exposure to RF emissions from wireless

phones, there is no reason to believe that

accessories that claim to shield the head

from those emissions reduce risks. Some

products that claim to shield the user from

109

Health and safety information

RF absorption use special phone cases, while

others involve nothing more than a metallic

accessory attached to the phone. Studies

have shown that these products generally do

not work as advertised. Unlike “hand-free”

kits, these so-called “shields” may interfere

with proper operation of the phone. The

phone may be forced to boost its power to

compensate, leading to an increase in RF

absorption. In February 2002, the Federal

trade Commission (FTC) charged two

companies that sold devices that claimed to

protect wireless phone users from radiation

with making false and unsubstantiated

claims. According to FTC, these defendants

lacked a reasonable basis to substantiate

their claim.

What about wireless phone

interference with medical equipment?

Radio frequency energy (RF) from wireless

phones can interact with some electronic

devices. For this reason, FDA helped develop

a detailed test method to measure

electromagnetic interference (EMI) of

implanted cardiac pacemakers and

defibrillators from wireless telephones. This

test method is now part of a standard

Samsung Electronics Co SGHZ370 Single-Band PCS GSM/ EDGE Phone with Bluetooth User Manual 1

Samsung Electronics Co Ltd Single-Band PCS GSM/ EDGE Phone with Bluetooth 1

Users Manual

Navigation menu

Namespaces

Views

Navigation
