Samsung Electronics Co SGHZ500 Single-Mode PCS GSM Phone w/ Bluetooth User Manual Z110VEng4Vodafone
Samsung Electronics Co Ltd Single-Mode PCS GSM Phone w/ Bluetooth Z110VEng4Vodafone
Users Manual
*
Some of the contents of this manual may differ from your phone, depending upon the software
installed or your service provider.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-0XXXXA
English. 01/2005. Rev. 1.0
Samsung SGH-Z500
User Manual
3
2
Welcome
Congratulations on choosing the Samsung
SGH-Z500.
Your new Samsung SGH-Z110V uses 3G (3rd
Generation) technology, also known as UMTS.
This technology allows fast data connections
similar to broadband speeds, enabling video
capture using its built-in camcorder, and sending
and receiving video, including video calls.
The SGH-Z110V features today’s most advanced
technology including a built-in rotating digital
camera of 1 Mega pixel resultion and high-
quality TFT colour screen that reproduces
260,000 different colour shades (four times more
than other colour screens). It also features 64
polyphonic stereophonic ringtones.
Most features are already enabled through the
Vodafone network.
Copyright © 2004 By Samsung. All rights reserved.
This User’s Guide is published by Samsung.
Some of the contents in this User’s Guide may differ
from your phone, depending on your service provider or
on the software installed.
Improvements and changes to this User’s Guide due to
typographical errors, inaccuracies of current
information, or improvement of software or hardware,
may be made by Samsung without notice.
3
Contents
Important safety precautions . . . . . . . . . . . 5
Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Your phone . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Phone layout. . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
External light . . . . . . . . . . . . . . . . . . . . . . . . . 12
Getting started . . . . . . . . . . . . . . . . . . . . . . 13
Inserting/Removing the SIM card . . . . . . . . . . . 13
Installing/Removing/Charging the battery . . . . . 14
Adding an expansion card. . . . . . . . . . . . . . . . . 17
Switching the phone on or off . . . . . . . . . . . . . . 17
Selecting functions and options . . . . . . . . . . . . . 18
Switching applications . . . . . . . . . . . . . . . . . . . 20
Call functions . . . . . . . . . . . . . . . . . . . . . . . 21
Making a call. . . . . . . . . . . . . . . . . . . . . . . . . . 21
Ending a call . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Answering a call . . . . . . . . . . . . . . . . . . . . . . . 23
Rejecting a call . . . . . . . . . . . . . . . . . . . . . . . . 23
Adjusting the volume . . . . . . . . . . . . . . . . . . . . 24
Accessing options during a call . . . . . . . . . . . . . 24
Using video call features. . . . . . . . . . . . . . . . . . 29
Using the headset . . . . . . . . . . . . . . . . . . . . . . 31
Entering text . . . . . . . . . . . . . . . . . . . . . . . 32
Changing the text input mode. . . . . . . . . . . . . . 32
Using T9 mode . . . . . . . . . . . . . . . . . . . . . . . . 33
Using ABC mode . . . . . . . . . . . . . . . . . . . . . . . 34
Using number mode. . . . . . . . . . . . . . . . . . . . . 36
Using symbol mode . . . . . . . . . . . . . . . . . . . . . 36
Using menu functions . . . . . . . . . . . . . . . . 37
Accessing a menu function by scrolling . . . . . . . . 37
Shortcuts to menu functions . . . . . . . . . . . . . . . 39
List of menu functions . . . . . . . . . . . . . . . . . . . 40
Game & More . . . . . . . . . . . . . . . . . . . . . . . 42
Vodafone live! . . . . . . . . . . . . . . . . . . . . . . 43
Navigating the browser. . . . . . . . . . . . . . . . . . . 43
Entering text in the browser . . . . . . . . . . . . . . . 43
Using the browser menus . . . . . . . . . . . . . . . . . 43
Using bookmarks . . . . . . . . . . . . . . . . . . . . . . . 44
Setting up the browser . . . . . . . . . . . . . . . . . . . 45
Applications . . . . . . . . . . . . . . . . . . . . . . . . 47
SIM-AT (SIM Application Toolkit) . . . . . . . . . . . . 47
Media player . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Voice recorder . . . . . . . . . . . . . . . . . . . . . . . . . 49
Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
World clock . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Messages . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Create message
(Menu 4-1)
. . . . . . . . . . . . . . . . 53
Inbox
(Menu 4-2)
. . . . . . . . . . . . . . . . . . . . . . . 59
Drafts
(Menu 4-3)
. . . . . . . . . . . . . . . . . . . . . . . 60
Sentbox
(Menu 4-4)
. . . . . . . . . . . . . . . . . . . . . 61
Email
(Menu 4-5)
. . . . . . . . . . . . . . . . . . . . . . . 61
Messenger
(Menu 4-6)
. . . . . . . . . . . . . . . . . . . . 62
Media album
(Menu 4-7)
. . . . . . . . . . . . . . . . . . 62
Call voicemail
(Menu 4-8)
. . . . . . . . . . . . . . . . . 62
Templates
(Menu 4-9)
. . . . . . . . . . . . . . . . . . . . 63
Contents
4
Delete all
(Menu 4-0)
. . . . . . . . . . . . . . . . . . . . 64
Settings
(Menu 4- )
. . . . . . . . . . . . . . . . . . . . 64
Memory status
(Menu 4- )
. . . . . . . . . . . . . . . . 68
Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Taking a picture . . . . . . . . . . . . . . . . . . . . . . . 69
Taking a video file . . . . . . . . . . . . . . . . . . . . . . 70
Camera mode options . . . . . . . . . . . . . . . . . . . 72
My items . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Exploring multimedia files. . . . . . . . . . . . . . . . . 74
Organiser . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Calendar
(Menu 7-1)
. . . . . . . . . . . . . . . . . . . . . 79
Week view
(Menu 7-2)
. . . . . . . . . . . . . . . . . . . 80
Today’s event
(Menu 7-3)
. . . . . . . . . . . . . . . . . 80
Schedule
(Menu 7-4)
. . . . . . . . . . . . . . . . . . . . 80
Anniversary
(Menu 7-5)
. . . . . . . . . . . . . . . . . . 81
Task list
(Menu 7-6)
. . . . . . . . . . . . . . . . . . . . . 82
Memo
(Menu 7-7)
. . . . . . . . . . . . . . . . . . . . . . . 83
Missed event alarm
(Menu 7-8)
. . . . . . . . . . . . . 83
Memory status
(Menu 7-9)
. . . . . . . . . . . . . . . . 83
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Search contact
(Menu 8-1)
. . . . . . . . . . . . . . . . 84
Add contact
(Menu 8-2)
. . . . . . . . . . . . . . . . . . 85
Call log
(Menu 8-3)
. . . . . . . . . . . . . . . . . . . . . . 88
Groups
(Menu 8-4)
. . . . . . . . . . . . . . . . . . . . . . 91
Speed dial
(Menu 8-5)
. . . . . . . . . . . . . . . . . . . 91
My contact details
(Menu 8-6)
. . . . . . . . . . . . . . 92
Copy all
(Menu 8-7)
. . . . . . . . . . . . . . . . . . . . . 92
Settings
(Menu 8-8)
. . . . . . . . . . . . . . . . . . . . . 93
Memory status
(Menu 8-9)
. . . . . . . . . . . . . . . . 93
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Phone profiles
(Menu 9-1)
. . . . . . . . . . . . . . . . . 94
Display settings
(Menu 9-2)
. . . . . . . . . . . . . . . . 96
Phone settings
(Menu 9-3)
. . . . . . . . . . . . . . . . . 97
Call settings
(Menu 9-4)
. . . . . . . . . . . . . . . . . . 99
Video call settings
(Menu 9-5)
. . . . . . . . . . . . . . 103
Time & date
(Menu 9-6)
. . . . . . . . . . . . . . . . . . 104
Network settings
(Menu 9-7)
. . . . . . . . . . . . . . . 104
Connections
(Menu 9-8)
. . . . . . . . . . . . . . . . . . 105
Security
(Menu 9-9)
. . . . . . . . . . . . . . . . . . . . . 107
Own number
(Menu 9-0)
. . . . . . . . . . . . . . . . . 109
Memory status
(Menu 9- )
. . . . . . . . . . . . . . . 110
Master reset
(Menu 9- )
. . . . . . . . . . . . . . . . . 110
Solving problems . . . . . . . . . . . . . . . . . . . 111
Access codes. . . . . . . . . . . . . . . . . . . . . . . 113
Phone password . . . . . . . . . . . . . . . . . . . . . . . 113
PIN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
PIN2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 113
PUK . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
PUK2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
Call barring password . . . . . . . . . . . . . . . . . . . 114
Health and safety
information . . . . . . . . . . . . . . . . . . . . . . . . 115
SAR certification information . . . . . . . . . . . . . . 115
Precautions when using batteries . . . . . . . . . . . 116
Road safety . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Operating environment . . . . . . . . . . . . . . . . . . 117
Electronic devices . . . . . . . . . . . . . . . . . . . . . . 117
Potentially explosive environments . . . . . . . . . . 118
Emergency calls . . . . . . . . . . . . . . . . . . . . . . . 119
Other important safety information. . . . . . . . . . 120
Care and maintenance . . . . . . . . . . . . . . . . . . 120
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . 125
5
Important safety precautions
Read these guidelines before using your wireless
phone. Failure to comply with them may be
dangerous or illegal.
Road safety at all times
Do not use a hand-held phone while driving;
park the vehicle first.
Switching off when refuelling
Do not use the phone at a refuelling point
(service station) or near fuels or chemicals.
Switching off in an aircraft
Wireless phones can cause interference. Using
them in an aircraft is both illegal and dangerous.
Switching off near all medical equipment
Switch off your phone near the medical
equipment. Hospitals or health care facilities may
be using equipment that could be sensitive to
external RF energy. Follow any regulations or
rules in force.
Interference
All wireless phones may be subject to
interference, which could affect their
performance.
Special regulations
Meet any special regulations in force in the area
you are in and always switch off your phone
whenever it is forbidden to use it, or when it may
cause interference or danger (in a hospital for
example).
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear).
Avoid unnecessary contact with the antenna
when the phone is switched on.
Important safety precautions
6
Emergency call
Key in the emergency number for your present
location, then press the key.
Give all the
necessary information as accurately as possible.
Do not cut off the call until given permission to do
so.
Keeping small children away from your
phone
Keep the phone and all its parts including
accessories out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries.
Qualified service
Only qualified service personnel may install or
repair your phone.
For more detailed safety information, see “Health
and safety information” on page 115.
CAUTION
RISK OF EXPLOSION IF A BATTERY IS REPLACED
BY AN INCORRECT TYPE.
DISPOSE USED BATTERIES ACCORDING TO THE
INSTRUCTIONS.
7
Unpacking
Your package contains the following items: In addition, you can obtain the following
accessories for your phone from your local
Samsung dealer. Accessories are also available
for you in all Vodafone shops.
• Standard / Extended battery
• Battery holder
•Travel charger
•Car charger
• Stylish handsfree car kit
• Car cradle
• Holster charger
• Headset
• PC data link kit
• MMC (Multi-Media Card), MMC adapter
•Hand strap
Notes
:
• Use only the supplied or an approved Headset for
the Z500 model. The device comes with two
batteries in the package. The larger battery has a
higher capacity.
• The items supplied with your phone and available
accessories may be different, depending on your
country.
Phone Travel charger
Batteries Software CD-ROM
Owner’s manual Data cable
Hand strap
T-Flash
8
Your phone
Phone layout
The following illustrations show the main
elements of your phone:
Closed
Open
Your phone
9
Key Description
(soft keys)
Performs the functions indicated by
the text above them, on the
bottom line of the display.
In menu mode: scrolls through the
menu options.
In idle mode: the navigation key,
Up, Down, Right, and Lift key, allow
you to access your favourite menu
options as shortcuts. For further
details about shortcuts, see
page 98.
In menu mode: selects the
highlighted menu or option.
In idle mode: enters the main
menu.
Makes or answers a call.
In idle mode: accesses call records.
Lets you open the Call, Messages,
or Vodafone live! applications
without quitting the current
application.
Makes a video call.
Deletes entered numbers or text.
Ends a call.
Switches the phone on and off
when held down.
In menu mode: exits the current
screen and takes you back to idle
mode.
Enters numbers, letters, and some
special characters.
Used for various purposes in
different functions.
The key inserts a pause when
held down while entering a number.
In idle mode: the key enters or
exits silent mode when held down.
Key Description
(continued)
Your phone
10
Display
Display layout
The display has three areas.
(on the left side of the phone)
During a call: adjusts the earpiece
volume.
In idle mode with the handset
open: adjusts the key volume.
In the idle mode with the handset
closed: turns on the external
display’s backlight when held down.
The volume keys on the left side of
the phone also turn the picture
upside down / mirror image while
in camera mode or during a video
telephone call.
(on the right side of the phone)
Rejects incoming calls when the
handset is closed.
Key Description
(continued)
Area Description
First line Displays various icons (see
page 11).
Middle Displays messages,
instructions, and any
information that you enter:
the number you are dialling,
for example.
Last line Shows the current functions
assigned to the two soft keys.
Icons
Text and
graphic area
Soft key
indicators
Your phone
11
Icons
Icon Description
Shows the received signal strength.
The greater the number of bars, the
better the signal.
Informs you which calling mode you
are in.
• : A call is in progress.
• : A call is impossible.
• : A video call is in progress.
• : A video call has been
disconnected.
Informs you whether you are in a 2.5G
or 3G (UMTS) network.
• : You are in a 3G (UMTS) network.
• : You are retrieving and sending
data in a 3G (UMTS) network.
This icon is animated.
• : You are calling in a 3G (UMTS)
network.
• : You are in a 2.5G network.
• : You are retrieving and sending
data in a 2.5G network. This
icon is animated.
• : You are calling in a 2.5G
network.
Appears when your phone is connected
to a PC running the internet wizard or
is synchronised with a PC.
• : You are connected to a PC.
• : This icon is animated while
browsing on the PC.
• : This icon is animated while
synchronising with a PC.
Appears when you set an alarm.
Appears when you are out of your
home area and have logged onto a
different network (i.e., when travelling
in other countries).
Informs you of the type of message
received.
• : Email message
• : Multimedia message
• : Configuration message
• : Text message
• : Voice mail
• : Wap push message
Informs you a MMC is inserted in your
phone.
Icon Description
(continued)
Your phone
12
External display
Your phone has an external display on the folder
cover. It indicates when you have an incoming
call or message, and alerts you at the specified
time when you set an alarm.
When you hold down one of the volume keys, the
external display backlight illuminates.
External light
The external light is at the front of the phone.
The light flashes when you are in a service area
and when you switch your phone on. It also
functions as a flash when you take photos.
Tells you your phone’s sound profile.
• : Car profile
• : Silent profile
• : Meeting profile
• : Outdoor profile
When your phone’s sound profile is set
to Normal profile, no profile icons will
display.
Appears when you access a secured
web page or when you are connected
to the network using a security
protocol while loading Java MIDlets.
Shows the level of your battery. The
more bars you see, the more power
you have left.
Icon Description
(continued)
13
Getting started
Inserting/Removing the SIM card
Your Vodafone SIM Card is already loaded with
your subscription details, such as your PIN.
• Keep SIM cards out of the reach of small chil-
dren.
• The SIM card and its contacts can easily be
damaged by scratches or bending, so be care-
ful when handling, inserting, or removing the
card.
• When installing the SIM card, always make
sure that the phone is switched off before you
remove the battery.
Inserting the SIM card
1. If necessary, remove the battery by referring
to page 15.
2. Insert and slide the SIM card under the two
tabs, ensuring that the notched corner is at
the top left and the gold contacts of the card
face down into the phone.
Getting started
14
Removing the SIM card
To remove the SIM card, slide the card out of the
holder, as shown.
Installing/Removing/Charging the
battery
Your phone is powered by a rechargeable Li-ion
battery. Use only approved batteries and
chargers. Ask your local Samsung dealer or
contact Vodafone for further details.
Note
: You must fully charge the battery before
using your phone for the first time. A
discharged standard battery is fully
recharged in approximately 100 minutes.
Installing the battery
1. Insert the teeth on the bottom of the battery
into the corresponding slots on the phone.
2. Press the battery against the back of the
phone until it clicks into place.
Make sure that the battery is properly
installed before switching the phone on.
Getting started
15
Removing the battery
1. If the phone is on, switch it off first by
pressing and holding the key until the
power-off animation is displayed.
2. To remove the battery, press and hold the
catch above the battery. Lift the battery away
from the phone.
Charging with the travel charger
Note
: The phone can be used while the battery is
being charged, but this causes the battery to
charge more slowly.
1. Plug the travel charger connector into the
bottom of the phone. Check that the arrow on
the connector is facing up, as is the phone.
2. Plug the charger into a standard AC wall
outlet.
Getting started
16
3. When charging is finished, unplug the charger
from the power outlet and from the phone by
pressing the grey buttons on both sides of the
connector and pulling the connector out.
Charging the Battery using the battery
Charger
1. Plug the travel charger connector into the
bottom of the battery charger.
2. Insert the teeth on the bottom of the battery
into the slot on the battery charger and press
the battery until it clicks into place.
3. Plug the travel charger into a standard AC
wall outlet.
4. Ensure that the charger has been
disconnected either from the charger or the
wall outlet before removing the battery. To
remove the battery, push and hold the catch
on the charger and lift the battery away.
Low battery indicator
When the battery is weak and only a few minutes
of talk time remain, the battery sensor informs
you in the following ways:
• An empty battery icon flashes ( ).
• You hear a warning tone.
• A message is briefly shown on the display.
After 5 minutes, the message is again briefly
shown. The message will appear one last time
just before the phone automatically switches
off.
When the battery becomes too weak for the
phone to operate, it switches off automatically.
Getting started
17
Adding an expansion card
An expansion card (sold separately) increased
the variety of tasks you can do and the amount
of space you have for storing software and data
on your phone. Your phone is compatible with
MMC (Multi Media Card) expansion cards.
Inserting a card
1. Insert the card into the expansion card slot
with the label side facing up.
2. Push the card in until it locks into place.
Removing a card
To remove a expansion card, Slide the card out of
the expansion card slot, as shown.
Switching the phone on or off
1. Open the phone.
2. Press and hold the key until the phone
switches on.
3. If the phone asks for a PIN, enter the PIN
code and press the
Confirm
soft key. For
further details, see page 124.
The phone begins searching for your network.
When it finds the network, you will see the
network operator’s name. You can make or
Getting started
18
receive a call only when connected to a
network.
Note
: To change the language, use the
Language
menu (
Menu 9-3-4
); for
further details, see page 97.
4. To switch the phone off, press and hold the
key until the power-off animation
displays.
Selecting functions and options
You can select different functions and option
menus using the two soft keys ( and ).
The roles of the soft keys vary according to the
phone feature you're using. To see what action
will occur or which menu will be accessed by
pressing them, look at the bottom line of the
display (just above each soft key).
Example
:
Press the left soft
key to access the
Messages main
menu.
Press the right
soft key to access
Vodafone live!.
Getting started
19
To view the various functions and options
available and to select the one you want:
1. Press the appropriate soft key.
In some functions, you may be asked for a PIN or
password. Enter the code and press the
Confirm
soft key or the
OK
key.
Using an option list
When you press the
Options
soft key in a
function, a list of available
options displays.
If the display cannot show
all of the available options,
an Up or Down arrow shows
that you can scroll through
the rest of the list.
2.
To Press the
select the:
• function displayed
• option highlighted
Select
/
Save
soft key
or the
OK
key.
If it is numbered, you
can press the
corresponding
number key.
scroll up or down
through the menus
or options
Up or Down scroll key.
scroll left or right
through the menus
or options
Left or Right scroll
key.
move back up one
level in the structure
Back
soft key.
return to idle mode
Back
soft key or the
key.
To Press the
scroll through the list Up or Down scroll key.
select the option
highlighted
OK
key,
Select
soft key
or the corresponding
number key.
exit the menu and
return to the
previous screen
Back
soft key.
Getting started
20
When an option has sub-options,
an arrow is shown on the right.
Press
the
Select
soft key or the
Right scroll key and the sub-
option list appears. You can use it
in the same way as a normal
option list.
To exit the sub-option list, press the Left scroll
key or the
Back
soft key.
Switching applications
When you press the
Application switch key ( ),
you can quickly switch to the
Call, Messages, or Vodafone
live! applications – without
losing your place in whatever
other application or menu
you're using at the time.
The coloured icon means an
application is running, and grey means it's not
running. Scroll through
Call
,
Messages
, and
Vodafone live!
using the Left and Right scroll
keys and press the
Select
soft key to launch the
application. Choose
End all?
to end the
applications.
For example, you can be making an entry in the
Organiser, then use the Application switch key to
open
Call
to make a phone call. When you've
finished, you can then choose
Back
to return to
your Organiser entry.
21
Call functions
Making a call
Using the number keypad
When the idle screen displays, enter the area
code and phone number, and press the key.
Correcting the number
Making an international call
1. Press and hold down the
0
key for the
international prefix. The + character appears.
2. Enter the country code, area code, and phone
number and press the key.
Using call records
Your phone stores records of dialled, received,
and missed calls chronologically. The last call is
saved in the first position.
To recall any of these numbers:
1. In idle mode, press the key.
2. Press the Left or Right scroll key to scroll to
the desired type of call; All calls, Missed,
Dialled, or received.
3. Use the Up and Down scroll keys to scroll
through the list until the number highlights.
4. To dial the number, press the key.
You can also use the
Call log
menu (
Menu 8.3
).
See page 89.
To clear the Press
last digit displayed the
C
key.
whole display and hold the
C
key for
more than one second.
Call functions
22
Making a call using contacts
You can store contact information, such as
names and phone numbers that you use
regularly, in the SIM card and the phone’s
memory. This information is stored in one list,
called Contacts. For more information about
adding contacts, see page 85.
1. Find the number you want to dial.
For further details about searching for a
number, see page 84.
2. To dial the number, press the key.
Viewing missed calls
The number of missed calls displays on the idle
screen immediately after a call is missed.
If you have a subscription that includes Caller
Line Identification (CLI) and you are unable to
answer a call for any reason, you can find out
who was calling you and then call the person
back.
To view the missed call immediately:
1. Open the folder. The pop-up window shows
that you have missed calls.
2. If there is more than one number, select the
number you want to phone back and press
the key.
To use the missed call options, see page 89.
Making a call using a pause
When you call automated systems, like banking
services, you are often required to enter a
password or account number. Instead of
manually entering the numbers each time, you
can enter them before dialling, separated by a
pause.
1. In idle mode, enter the first number of a
service, such as the bank’s teleservice
number.
2. Press and hold the key to insert a pause.
A “P” appears, meaning that a pause will
occur at that point in the dialling sequence.
Call functions
23
3. Enter the number that needs to follow the
pause, such as your account number.
4. Repeat steps 2 and 3 to add more pauses and
numbers, if necessary.
5. Press the key to dial.
6. When prompted, press the key to send the
DTMF (Dual Tone Multi-frequency) tones of
the number that follows the pause.
The number is sent to the system.
7. Repeat Step 6, as you are prompted.
Ending a call
When you want to finish your call, briefly press
the key, or close the handset, or press the
End call
option in the call options.
Answering a call
When someone calls you, the phone rings and an
incoming call box displays.
If the caller can be identified, the caller’s phone
number, or name if stored in Contacts, displays.
If the incoming call is a restricted call (the caller
has opted to not send his/her phone number for
identification), the display shows
Withheld
; if it
is unknown, the display shows
Anonymous
.
1. To answer a call, open the handset. If it is
already open, press the key, the
OK
key,
or the
Accept
soft key.
2. End the call by closing the handset or
pressing the key.
Note
: You can answer a call while using the menu
functions. The current operation is cancelled.
Rejecting a call
To reject an incoming call, press and hold the
key on the right side of the phone.
When the phone is open, you can also press the
Reject
soft key or the key.
Call functions
24
Adjusting the volume
If you wish to adjust the earpiece volume during
a call, use keys on the left side of the phone.
Press the key to increase the volume level and
the key to decrease the level.
Using these keys, you can also adjust the key
tone volume in idle mode with the handset open.
Note
: When a call comes in, you can mute the call
ringer by pressing and holding the
or
key.
Accessing options during a call
Your phone provides a number of control
functions that you can use during a call.
Using the loud speaker
You can speak and listen to the phone from a
short distance without holding the phone to your
ear.
Turn on / off the loudspeaker
1. Press the
Options
soft key.
2. Press the Up or Down key to highlight the
Loud speaker
/
Handset
option. Press the
Select
soft key.
CAUTIONS
: Do not hold the phone near to your
ear when you use the loudspeaker,
as the volume may be extremely
loud.
Putting a call on hold
You can place the current call on hold whenever
you want. You can make another call while you
Call functions
25
have a call in progress if your network supports
this service. Of these two calls, one is active and
the other is on hold and you can switch between
them.
To place a call on hold, simply press the
Hold
soft key. You can reactivate the call whenever
you want, by pressing the
Unhold
soft key.
Mute/Unmute key tones
You can turn the key tones off or on. If you select
Mute key tone
, your phone does not transmit
any key tones, which allows you to press keys
without hearing annoying key tones during a call.
Searching contacts
You can search for a number in Contacts during a
call.
1. Press the
Options
soft key.
2. Press the Up or Down scroll key to select
Contacts
and press the
OK
key.
3. Enter the first few letters of the name you
want to find.
For further details about entering text, see
page 32.
For further details of the Contacts feature, see
page 84.
Sending DTMF tones
You can send a number to the other person
during a call. The number sent will appear on the
display of the other person’s phone.
1. Press the
Options
soft key.
2. Press the Up or Down scroll key to select
Send
DTMF
and press the
OK
key.
3. Enter the number you want to send and press
the
Send
soft key.
Making a memo
You can make a memo during a normal call or
conference call.
1. Press the
Options
soft key.
2. Press the Up or Down scroll key to select
Memo
and press the
OK
key.
Call functions
26
3. Enter the memo. Use the Down scroll key to
move to the date field and then enter the
date.
4. When you finish entering the memo, press
the
Options
soft key and select the
Save
option or press the
OK
key.
Or,
1. Enter the number(s).
2. Press the
Options
soft key.
3. Press the Up or Down scroll key to select
Save
and press the
OK
key.
For further details about entering text, see
page 32.
Making a second call
To make a call while you have a call in progress:
1. Press the
Options
soft key.
2. Select
New call
and press the
OK
key.
3. Enter the phone number you want to dial and
press the key,
Call
soft key, or
OK
key to
make the second call.
The first call is automatically put on hold.
Note
: You can first enter a phone number and then
press the
Options
soft key. Then select the
New call
option.
Or alternatively:
1. Put the current call on hold by pressing the
Hold
soft key.
2. Make the second call in the normal way.
To switch between the two calls, simply press the
SWAP
soft key. The current call is placed on hold
and the call on hold is reactivated so that you can
continue conversing with the other person.
To end the current call, press the key. The call
on hold is still on hold. To reactivate this call
press the
Unhold
soft key.
To end both calls at one time, close the folder, or
press the
Options
soft key and select
End calls
.
Answering a waiting call
You can answer an incoming call while you have
a call in progress, if this service is supported by
the network and you have activated the
Waiting
menu option; see page 101. Your phone alerts
Call functions
27
you to an incoming call by sounding a call waiting
tone.
To answer a call while you have a call in
progress:
1. Press the
Accept
soft key.
2. In the select box, select
Accept
to answer
the incoming call. The first call is
automatically put on hold.
If you want to end the first call, select the
End active call
or
End held call
. And then
you can answer the incoming call.
3. To switch between the two calls, press the
SWAP
soft key.
To end the current call, press the key. The call
on hold is automatically reactivated.
To end both calls at one time, close the folder, or
press the
Options
soft key and select
End calls
.
Making a conference call
The Conference Call feature is a Vodafone service
that allows up to five people to take part
simultaneously in a call. You can make a
conference call by making or receiving another
call while you are on an active call.
Setting up the conference call
1. Call the first participant in the normal way.
2. Make a second call, referring to page 26.
Or,
Answer a waiting call, referring to page 26.
3. To join the first participant to the conference
call, press the
Options
soft key and select
Join
using the Up and Down scroll keys.
4. Press the
OK
key.
5. To add a new person to the conference call,
repeat steps 2 to 4, as needed.
Holding a private conversation with one
participant
To speak privately with one person during a
conference call:
1. Press the
Options
soft key and select
Split
.
Press the
OK
key.
2. Press the Up or Down scroll key to scroll to
the participant you want to split off and press
the
OK
key.
Call functions
28
Now you can talk privately to that person. The
other participants can continue to converse
with each other.
You can switch between the conference call
and the split call by pressing the
SWAP
soft
key.
3. To return to the conference call, press the
Options
soft key and select
Join
. Press the
OK
key.
All the conference call participants can now
hear each other.
Removing one participant
1. Press the
Options
soft key and select the
Drop
option. Press the
OK
key.
2. Press the Up or Down scroll key to scroll to
the participant you want to remove and press
the
OK
key.
The call ends with that participant, but you
can continue to talk to the other participants.
You can end the conference call by closing the
phone or pressing the key.
Sending a text message
You can send a text message during a normal call
or conference call. You can send the message to
other people as well as to your current call
participants.
1. Press the
Options
soft key.
2. Press the Up or Down scroll key to select
Send SMS
and press the
OK
key.
The list of all the call participants appears.
3. Scroll to the person to whom you want to
send the message and press the
OK
key.
A check mark appears in front of the selected
person. Repeat this step as needed.
4. When you have finished selecting recipients,
press the
Options
soft key and select the
Write
option. Then press the
OK
key.
5. Write your message and press the
Options
soft key and select the
Send
option. Then
press the
OK
key.
For further details about entering text, see
page 32.
Call functions
29
6. Enter any other phone number to which you
want to send the message.
If you want to add more numbers, press the
Down scroll key and enter a number. Repeat
as needed.
7. When you finish entering the numbers, press
the
Options
soft key and select the
Send
option. And then press the
OK
key.
For more information on the SMS feature, refer
to page 53.
Switching the microphone off (Mute)
You can temporarily switch your phone’s
microphone off, so that the person you are
talking to cannot hear you.
Example: You wish to say something to another
person in the room but do not want the
calling party to hear you.
To switch the microphone off temporarily:
1. Press the
Options
soft key.
2. Press the Up or Down scroll key to select
Mute
and press the
OK
key.
The Mute icon ( ) appears on the display and
your party can no longer hear you.
To switch the microphone back on:
1. Press the
Options
soft key.
2. Press the Up or Down scroll key to select
Unmute
and press the
OK
key.
The Mute icon disappears.
Using video call features
When in a 3G (UMTS) service area, your phone
can make or receive a video call which allows you
to see another person on the screen during a
conversation. The other person’s phone must
support the video call feature.
Note:
If the other person does not turn their
camera on, you will not be able to see him or
her. You can communicate only by voice.
Making a video call
1. In idle mode, enter a phone number to dial.
You can also use phone numbers in call
records.
Or,
Call functions
30
Turn on the camera by pressing the OK key
twice.
2. Press the
Options
soft key and select the
V-
Call
.
3. Use the
Options
soft key to mute the Voice,
Camera (Video), Voice-Video all, or Keytone.
Note
: The Video call service is a special feature of
the 3G (UMTS) network. You can make and
receive a video call when the 3G icon (
)
is displayed.
Receiving a video call
You can receive a video call the same as
receiving a normal call, except that you can see
the person on the screen. Use the
Show me
soft
key to show the image of yourself to the other
person.
See page 23 for details about answering a call.
Changing view options
You can change the screen mode for video calls
to PIP (Picture-in-Picture). In the PIP mode, the
display has a main and a sub-frame where you
can see yourself on the screen, as well as the
other person.
To change the screen mode during a video call,
press the
View
soft key until you see the desired
status. The following modes are available:
• See the other person only in the main frame
• See yourself only in the main frame
• See the other person in the main frame and
yourself in the sub-frame
• See yourself in the main frame and the other
person in the sub-frame
Turning your voice or video on or off
You can mute your voice or turn the video off
during a video call.
During a video call, press the
Options
soft key to
display the option list.
The following options are available:
Headset/Loud speaker
: allows you to choose a
listening methed. You can choose either Headset
Call functions
31
or Loud speaker. The default setting is Loud
speaker.
Mute camera
: turns the camera off. The other
person can hear you, but cannot see you.
Mute voice
: mutes your voice. The other person
can see you, but cannot hear you.
Mute camera & voice
: mutes your voice and
turns the camera off. The other person cannot
hear or see you.
Mute key tone
: mutes your key tones.
Quality control
: allows you to adjust the image
quality:
Normal
,
Macro
, or
Motion
.
Macro
emphasises the picture quality and
Motion
emphasises the frame count.
Zoom
: allows you to adjust the zoom ratio of the
video camera.
Show (Hide) brightness
: displays or hides the
brightness control bar.
Effects
: allows you to change the colour tone of
the picture.
Sepia
,
Black&White
,
Night
, and
Normal
are available.
Show (Hide) information
: shows or hides the
information bar on the screen which contains
information such as caller ID. This option is
preset at the factory to hide so that
Show
information
displays unless you change it.
End call
: ends the video call.
Using the headset
With the Headset, you can make or answer a call
without holding the phone.
When you connect the Headset to the jack on the
left side of the phone, the button on the Headset
works as listed below:
To Press
redial the last call the button twice in idle
mode.
answer a call and hold the button
when you receive the
call.
end a call and hold the button
when you have finished
the call.
32
Entering text
You may need to enter text, when storing a name
in Contacts, creating your personal greeting, or
scheduling events in your calendar.
Your phone has the following text input modes:
•
T9 mode
*
This mode allows you to enter words with only
one keystroke per letter. Each key on the
keypad has more than one letter. For example,
when you press the
5
key once, J, K, or L may
be displayed. The T9 mode automatically
compares your keystrokes with an internal
linguistic dictionary to determine the correct
word, thus requiring far fewer keystrokes than
the traditional ABC mode.
•
ABC mode
This mode allows you to enter letters by
pressing the key labelled with the letter you
want once, twice, three, or four times until the
letter is displayed.
•
Number mode
This mode allows you to enter numbers.
•
Symbol mode
This mode allows you to enter special
characters, like punctuation marks.
Changing the text input mode
When you are in a field that allows characters to
be entered, the text input mode indicator appears
at the bottom of the display.
Example: When you write a memo, the following
screen displays:
* is a registered trademark of Tegic Communications, Inc.
and is licensed under U.S. Patent 5,818,437/ 5,953,541/
6,011,554.
Text input mode
indicator
Entering text
33
Shortcuts to the text input modes
To switch between the T9 and ABC mode, press
and hold the key not in Number or Symbol
mode but in T9 or ABC mode.
Press the key briefly to switch input mode like
below in ABC mode.
> > > >
Press the key briefly to switch input mode like
below in T9 mode.
> > > >
To change the input mode to Symbol mode, press
and hold the key.
Using T9 mode
To enter a word in the T9 mode:
1. Start entering the word by pressing the keys
2
to
9
. Press each key only once for each
letter.
Example: To enter “hello” in the T9 mode,
press
4
,
3
,
5
,
5
and
6
.
The word you are entering appears on the
display. It may change with each key that you
press.
2. Enter the whole word before editing or
deleting any keystrokes.
3. If the word is correct, start entering the next
word. Otherwise, press the
0
key to display
alternative word choices for the keys that you
pressed.
Example: Both “of” and “me” have the
sequence of
6
and
3
. The phone
displays the most commonly used
choice first.
Entering text
34
4. Put a space between words by pressing the
key.
5. Continue entering any other words in T9
mode.
If
Spell
appears above the left soft key while you
are entering text, the word does not exist in the
T9 dictionary. To type words not found in the T9
mode, change the text input mode to ABC mode,
or proceed as follows:
1. Press the
Spell
soft key.
2. Enter the word you want to add using ABC
mode (see page 34) and press the
Add
soft
key.
The word is saved in the T9 dictionary and
inserted in the input field.
3. Continue entering other words in T9 mode.
Smart punctuation
To enter periods, hyphens, or apostrophes, press
the
1
key. T9 mode applies rules of grammar and
inserts the correct punctuation.
Changing the letter case
To change the letter case of the next letters that
you type, press the key. There are three cases:
• Initial Capital ( )
•Capital Lock ( )
•Lower Case ( )
Scrolling
To move the cursor to the left or right within the
text, press the Left or Right scroll key.
Clearing letters and words
To delete letters, press the
C
key when the cursor
is immediately to the right of the letter you want
to delete. Press and hold down the
C
key to clear
the display.
Using ABC mode
When entering letters in ABC mode, press the
key labelled with the letter you want:
- Once for the first letter
- Twice for the second letter
- And so on
Entering text
35
Example: To display the letter “c”, quickly press
the
2
key three times. To display the
letter “k”, press the
5
key twice. For
this reason, this method is called
Multi-tap typing.
The cursor moves to the right when you press a
different key. When entering the same letter
twice or a different letter on the same key, just
wait a few seconds for the cursor to
automatically move to the right, or press the
Right scroll key and then enter the next letter.
Refer to the table below for more information
about available characters.
Note
: When you write a text message and you
select the
GSM alphabet
option in
Character support
(see page 66), the
following GSM alphabet characters are
available:
Changing the letter case
To change the letter case of the next letters that
you type, press the key. There are three
cases:
• Initial Capital ( )
•Capital Lock ( )
•Lower Case ( )
Inserting a Space
To insert a space between words, press the
key.
Entering text
36
Scrolling
To move the cursor to the left or right within the
text, press the Left or Right scroll key.
Clearing letters and words
To delete letters, press the
C
key when the cursor
is immediately to the right of the letter you want
to delete. Press and hold the
C
key down to clear
the display.
Using number mode
You can enter numbers in Number mode. Press
the keys corresponding to the required digits.
Using symbol mode
You can insert symbols into a text message. The
text message you’ve entered is shown in the
symbol entering field. Move the cursor to where
you want to enter a symbol using the Left or
Right scroll key.
To Press the
display more
symbols
Up or Down scroll key.
select a symbol corresponding number
key. The selected symbol
displays in the input box.
clear a symbol from
the input box
C
key.
insert the edited
message in the
symbol entering
field into your text
OK
key.
37
Using menu functions
Your phone offers a range of functions that allow
you to tailor the phone to your needs. These
functions are arranged in menus and sub-menus.
The menus and sub-menus can be accessed by
scrolling using the scroll keys or by using the
shortcuts.
Accessing a menu function by
scrolling
1. In idle mode, press the
OK
key to access the
menu.
2. Scroll using the scroll keys to reach the
required application menu. Press the
OK
key
to enter the menu.
3. If the menu contains sub-menus, you can
access them by scrolling using the Up and
Down scroll keys and pressing the
Select
soft
key.
If the menu that you have selected contains
further options, repeat the same procedure.
4.
To Press the
scroll through
the menus
Up or Down scroll
key.
confirm the
chosen setting
Select
or
Save
soft
key or the
OK
key.
return to the
previous menu level
Back
soft key.
exit the menu without
changing
the settings
key or the
Back
soft key, if
available.
Using menu functions
38
Example: Changing the language
display
1. When the idle screen is displayed, press the
OK
key to access the menu.
The startup screen of the
Camera
menu is
displayed.
2. Scroll through the menus by pressing the
scroll keys until you reach the
Settings
menu. To access the
Settings
menu, press
the
OK
key.
3. To access the
Phone settings
menu, press
the
Select
soft key or
OK
key.
4. Scroll through the sub-menus by pressing the
Up or Down scroll key, then use either the
Select
soft key or the
OK
key to choose your
language.
Using menu functions
39
5. Press the
OK
key when Screen Text is
highlighted.
6. Scroll through the list of languages by
pressing the Up or Down scroll key until the
appropriate one is highlighted. Press the
Select
soft key or the
OK
key.
7. Press the
Save
soft key to save the setting in
the Language screen. Otherwise press the
Back
soft key.
8. Press the key to exit the menu.
Shortcuts to menu functions
Some menus, sub-menus, and options can be
quickly accessed by using their shortcut
numbers. Simply press the
OK
key and enter the
number.
Note
: The numbers assigned to each menu option
are indicated on the list on the following
pages. They may not match the menu
numbers on the phone, depending on the
services supported by your SIM card.
Example: Accessing the
Language
menu option.
1. Press the
OK
key.
2. Press for
Settings
.
3. Press for
Phone settings
.
4. Press for
Language
.
Using menu functions
40
List of menu functions
The following list shows the menu structure
available and indicates the:
• number assigned to each option
• page on which you can find a description of
each feature
1. Game & More
(see page 42)
2. Vodafone live!
(see page 43)
3. Applications
(see page 47)
4. Messages
(see page 53)
4.1 Create message
4.1.1 MMS
4.1.2 SMS
4.1.3 Email
4.2 Inbox
4.3 Drafts
4.4 Sentbox
4.5 Email
4.6 Call voicemail
4.7 Templates
4.8 Broadcast
4.9 Delete all
4.
0
Settings
4.
0
.1 MMS
4.
0
.2 SMS
4.
0
.3 Email
4.
0
.4 Voice mail
4.0.5 Push msg.
4. Memory status
5. Camera
(see page 69)
6. My Items
(see page 74)
7. Organiser
(see page 79)
7.1 Calendar
7.2 Week view
7.3 Today’s event
7.4 Schedule
7.5 Anniversary
7.6 Task list
7.7 Memo
7.8 Missed event alarm
7.9 Memory status
8. Contacts
(see page 84)
8.1 Search contact
8.2 Add contact
Using menu functions
41
8.3 Call log
8.3.1 Missed calls
8.3.2 Dialled calls
8.3.3 Received calls
8.3.4 All calls
8.3.5 Data counter
8.3.6 Calls cost
8.3.7 Calls time
8.4 Groups
8.5 Speed dial
8.6 My contact details
8.7 Copy all
8.8 Settings
8.9 Memory status
9. Settings
(see page 94)
9.1 Phone profiles
9.2 Display settings
9.2.1 Greeting message
9.2.2 Wallpaper
9.2.3 Sub LCD
9.3 Phone settings
9.3.1 LCD brightness
9.3.2 Backlight
9.3.3 Ext. light
9.3.4 Language
9.3.5 Infrared
9.3.6 Shortcuts
9.3.7 Active folder
9.3.8 Anykey answer
9.4 Call settings
9.4.1 Caller ID
9.4.2 Diverting
9.4.3 Barring
9.4.4 Waiting
9.4.5 Auto redial
9.4.6 Closed user group
9.5 Video call settings
9.6 Time & date
9.7 Network settings
9.7.1 Network selection
9.7.2 Network mode
9.8 Connections
9.9 Security
9.9.1 Phone lock
9.9.2 SIM lock
9.9.3 PIN lock
9.9.4 Fixed dialling mode
9.9.5 Change phone password
9.9.6 Privacy lock
9.9.7 Change PIN code
9.9.8 Change PIN2 code
9.0 Own number
9.
Memory status
9. Master reset
42
Game & More
In
Game & More
menu, you can play the games
which came pre-installed on your phone. You can
also download new games that are compatible
with your phone.
43
Vodafone live!
Your phone is equipped with a WAP (Wireless
Application Protocol) browser to allow you to
access and navigate the Wireless Web via your
phone.
Navigating the browser Entering text in the browser
When prompted, you can enter letters, numbers,
or symbols the same way as in phone mode. See
page 32 for more information about entering
characters.
Using the browser menus
In the browser, press the
Options
soft key to
use the following options:
Go to
: takes you back at any time to the
Vodafone live! homepage.
Reload page
: reloads the current page with
updated information.
Go to homepage
: sends you back to the home
page.
To Press the
scroll through
browser items
scroll keys.
scroll up or down
pages
volume keys
select the item
highlighted
OK
key.
select a numbered
item
corresponding numeric
key.
return to the
previous page
Back
soft key, or press
the
Options
soft key
and select
History
.
return to the startup
homepage
Options
soft key and
select
Go to
homepage
.
To Press the
Vodafone live!
44
Go to URL
: allows you to manually enter the
URL address of the web page you want to access.
Add bookmark
: allows you to add the current
page to your bookmark list.
View bookmarks
: shows you the bookmark list.
Send URL
: allows you to send the URL as a text
message, or as an e-mail.
Save image
: saves the image of the current
page.
Settings
: allows you to change the settings for
connecting to the Wireless Web. For further
details, see page 45.
Empty cache
: clears information stored in the
cache, which is the phone’s temporary memory
used to store the most recently accessed web
pages. After you have accessed confidential
information requiring passwords like your bank
account, you need to empty the cache. When a
warning message appears, press the
Yes
soft
key to clear the information.
Disconnect
: disconnects from the network.
History
: shows URLs previously visited.
Using bookmarks
Bookmarks save you time by reducing the
number of steps it takes to access a web page.
You can bookmark many individual pages for
easy access at a later time.
Bookmarking a web page
1. Go to the page that you want to bookmark
and press the
Options
soft key.
2. Scroll to
Add bookmark
and press the
OK
key.
3. Enter the title for the bookmark and press the
Save
soft key.
Accessing a bookmarked web page
1. Press the
Links
soft key on the startup screen
of the Vodafone live! menu.
Or,
Press the
Options
soft key on any web page.
Scroll to
View bookmarks
and press the
OK
key.
2. Scroll to a bookmark item and press the
OK
key.
Vodafone live!
45
Using bookmark options
On the bookmark list, press the
Options
soft key
to use the following options:
Go to
: allows you to access the corresponding
web page.
Go to homepage
: sends you back to the home
page.
Edit bookmark
: allows you to change the title
and/or URL address of the selected bookmark
item.
Add bookmark
: allows you to add a new
bookmark.
Send URL
: allows you to send the URL by short
message, multimedia message, or e-mail.
Delete
: deletes the selected bookmark.
Delete all
: deletes all bookmarks.
Settings
: allows you to change the settings for
connecting to the Wireless Web. For further
details, see below.
Advanced
: clears information stored in the
cache or cookie, which is the phone’s temporary
memory used to store the most recently
accessed web pages. After you have accessed
confidential information requiring passwords like
your bank account, you need to empty the cache.
When a warning message appears, press the
Yes
soft key to clear the information.
Setting up the browser
Note
: You do not need to change the settings
unless your network operator requests it. If
you change them without the operator’s
instructions, you may not be able to use the
browser.
Contact your service provider for details and
parameters for each option.
To change the WAP settings:
1. Press the
Options
soft key on any web page.
2. Scroll to
Settings
and press the
OK
key.
The access points display.
Note
: Some access points are not able to be
changed by the service provider.
Vodafone live!
46
3. Scroll to the access point that you want to use
and press the
OK
key to change current
access point.
To edit or make access points, select the setting
set you want at step 4 and then press the
Options
soft key to use the following options:
Select
: saves your changes.
Edit
/
New
: edits the selected Set or makes a
new Set. For more information, see “Connections
(Menu 9-8)
” on page 105.
Delete
: deletes the selected Set when it is not in
use.
Rename
: changes the name of the Set.
47
Applications
Using the
Applications
menu, you can use
several popular applications, such as a media
player, voice recorder, calculator, converter, world
clock, and alarms.
Using applications
1. Press the Left or Right scroll key to select an
application folder,
Applications
, or
Alarms
.
2. Press the Up or Down scroll key to select an
application.
3. Press the
OK
key to start the application.
SIM-AT (SIM Application Toolkit)
If you use a SIM card that provides additional
services, the SIM-AT menu displays. For further
details, see your SIM card instructions.
Shown only if it is supported by your SIM card.
Media player
Media Player
plays audio and video files you
download or stream to the phone. You can listen
to music or watch a movie with Media Player.
It is used when:
• you view a media file in the
My Items
menu.
• you want to play a sound file or a video in the
browser.
Applications
48
Playing a file using media player
1. On the screen of Media Player, the screen
displays showing files available in Media
Player.
2. Press the Up or Down scroll key to select the
file you want to play and press the
OK
key.
The selected audio or video file plays on
Media Player.
When the control bar is shown, you can scroll to
the different control buttons by pressing the Left
or Right scroll key and press the
OK
key to select
the button.
: plays or resumes (if paused).
: stops playing.
: pauses playing.
: fast rewinds while holding the
OK
key.
Plays when you release the
OK
key.
: fast forwards while holding the
OK
key.
Plays when you release the
OK
key.
When you press the
Options
soft key while a file
is playing, the following options are available:
Resume
: recommences playing.
Stop
: stops playing.
Send
:
•
As MMS
: allows you to send the video file as a
multimedia message. For further details about
sending multimedia messages, see page 53.
•
Via infrared
:allows you to send the video file
to another person via the infrared port. For
further details, see page 98.
Open play list
: allows you to open another file
or make a list of files you want to play.
My videos
: You can open stored video files.
Hide/Show controller
: hides or displays the
control bar of Media Player.
3.
To Press the
pause
OK
key.
resume playing
OK
key again.
adjust the volume
level
volume keys.
exit Media Player
Back
soft key.
Applications
49
Details
: allows you to see the information about
the Media Player file.
Player settings
: allows you to change the
settings of Media Player. For further details, see
below, “Setting up Media Player”.
VOD settings
: sets the network access point for
the VOD (Video On Demand) service.
Setting up Media Player
You can set several options for playing audio or
video files on Media Player.
1. On the Media Player screen, press the
Options
soft key.
2. Press the Up or Down scroll key to scroll to
Player settings
and press the
OK
key.
3. Press the Up or Down scroll key to scroll
through the options. You can select the
desired status using the Left and Right scroll
keys.
•
Repeat
: allows you to set Media Player to
repeatedly play all of the files or only one
file. Selecting
None
means that the file is
played just once.
•
Play order
: allows you to set the order to
Random
or
Normal
.
•
Volume
: allows you to adjust the volume
level. This option is available only when you
have already opened a file.
•
Hide controller
: hides the Media Player
control bar when you place a check mark
next to this option by pressing the
OK
key.
If you want the control bar to show again,
remove the check mark by pressing the
OK
key.
Voice recorder
You can record sound files or listen to recorded
sound files.
Press the Up or Down scroll key to control the
volume.
Press the Left or Right scroll key to move through
the buttons and press the
OK
key to select the
button.
Applications
50
: starts or resumes recording.
: pauses recording.
: stops recording and saves the file.
: plays the file.
: rewinds the file.
: forwards the file.
Press the
Options
soft key to use the following
options.
Play
: allows you to open the voice file you have
recorded.
Record
: starts recording.
My sounds
: opens a sound file.
Send
: allows you to send the sound file as a
multimedia message. For further details about
sending a message, see page 53.
Record settings
: allows you to set the
recording file name and maximum recording
time.
Calculator
You can use the phone as a 14-digit calculator.
The calculator performs basic mathematical
functions: additional, subtraction, multiplication,
and division.
1. Enter the first figure using the number keys.
To enter a decimal point, press the key. You
can make a number negative by pressing the
Left scroll key after entering the number.
2. Press the appropriate navigation key for your
calculation.
3. Enter the second figure.
4. Press the
OK
key to get the result.
Press the
Options
soft key to use the following
options:
Equal
: repeats the last calculation.
Last result
: shows the last calculation result.
Save to memory
: saves the current digit or
result to memory.
Recall memory
: recalls the saved digit.
Applications
51
Clear memory
: clears the memory.
Recall memory and Clear memory appear when
the memory has previous values stored.
Converter
You can convert one type of unit to another.
Scroll to the type of conversion to be performed
from
Currency
,
Length
,
Weight
,
Volume
,
Area
, and
Temperature
, and press the
OK
key.
1. Select the units to be converted by pressing
the Left or Right scroll key.
2. When you enter the value to be converted,
you can see the corresponding value of each
unit.
Note
: You can enter a decimal point (
.
) by
pressing the key. You can also enter
(-) by pressing the key, but only for
Temperature
.
On the conversion screen, press the
Options
soft
key to use the following options:
Clear
: clears the current values.
Reverse
: reverses the conversion.
In Currency converter menu,
Currency rates
option is available. you can set the currency
rates.
To change currency rates:
1. Select the base currency by pressing the Left
or Right scroll key.
2. Scroll to another currency by pressing the Up
or Down scroll key and edit the rates.
3. Press the
Options
soft key and select the
Save
option to save the rate.
To clear the rates for all currencies, select the
Clear all
option.
To return to the previous screen without
changing the rate, press the
Back
soft key.
World clock
You can check the time difference between your
city and a selected city.
1. Select the city corresponding to your time
zone by pressing the Left or Right scroll key.
The screen shows the current time and date
of several cities in the same time zone.
Applications
52
2. Press the Down key and select another city
and its corresponding time zone by pressing
the Left or Right scroll key.
Press the
Options
soft key to use the following
options.
Save
: allows you to save the setting.
Summer time
: allows you to use daylight saving
time.
Alarms
You can set alarms to ring at specific times.
To set an alarm:
1. Select the type of alarm choosing
Once
alarm
,
Daily alarm
, or
Wake up alarm
.
2. Set
On
by pressing the Left or Right scroll
key.
3. Move to the time field by pressing the Down
scroll key and enter the time for the alarm to
sound.
4. (Only for the Wake up alarm) Move to the
repeat field by pressing the Down scroll key
and select the repetition type between
None
,
Every day
,
Except weekend
, or
Except
Sunday
.
5. Move to the alert tone field by pressing the
Down scroll key. After pressing the
OK
key,
you can select an alarm melody
6. Press the
Save
soft key to save it.
To deactivate an alarm:
1. Select the type of alarm choosing
Once
alarm
,
Daily alarm
, or
Wake up alarm
.
2. Set
Off
by pressing the Left or Right scroll
key.
Press the
Save
soft key to save the change.
To turn off the Wake up alarm:
•Press the
OK
soft key or key.
• When the Wake up alarm tone sounds, press
the
Snooze
soft key to stop the alarm for five
minutes, after which it will resume. You can do
this a maximum of five times.
53
Messages
This menu allows you to create, send, read, and
save messages with the Short Message Service
(SMS), Multimedia Message Service (MMS), and
E-mail service.
SMS is a service which allows you to send or
receive text messages.
MMS is a messaging service very similar to SMS.
MMS enables you to send far longer text
messages than SMS - and to attach images,
graphics, voice, audio, and video clips-in any
combination, as a single multimedia message.
You can send MMS messages to phones with
MMS capability, and to any e-mail address.
You can send a photo which you have taken as a
normal postcard. Please note that this service is
not supported in all Vodafone networks.
Create message
(Menu 4-1)
In this menu, you can write and send a text
message, a multimedia message, or an e-mail.
Note:
You can also press the
Create
soft key from the
startup screen of the
Messages menu to write
a new message.
Writing and sending
multimedia messages
When you send an MMS message with an image,
a video, an audio file or text content, the entire
MMS message is shown on the recipient’s screen.
1. On the
Create message
screen, select
MMS
.
2. Enter the subject in the
Subject
text field.
To use a preset message template stored in
the
Text templates
menu, press the
Options
soft key and select the
Insert text
template
option.
3. To attach an image, video, or audio file, press
the scroll key to move to the
Picture or
Video
, or
Audio
field and press the
OK
key.
Select a file from the list and press the
Select
Messages
54
soft key or the
OK
key. You can also attach a
picture you have taken with the phone
camera.
If you want to exchange an attached image,
or audio file for another, you must first delete
the currently attached file. Press
Options
and
select
Remove picture/video/sound
. Press
OK
. Then attach the new file as detailed
above.
If you want to send the attached image or file
without an accompanying text message, after
you have attached the image or file, press
OK
. Proceed directly to step 7 below.
Notes
:
• If you want to add a video file to MMS, take a
video file first with the
Video recorder
feature. For more information, see page 71.
•
When you add a video file to a message, you
can not add an audio file or write a text
message. In this case you can add an audio
file or write a text message by adding another
page to your message. If
you want to send
lengthy video files of large capacity, the
Recording time
has to be set accordingly
in the
For message
option. See page 72.
• The maximum size allowed for a multimedia
message can differ depending upon the
country.
4. Enter your message into the
Text
field.
5. If you want to use the message options while
writing your message, press the
Options
soft
key. Select one of the following options:
•
Send
: allows you to send the message.
•
Preview
: shows your message as it will be
displayed on the recipient’s phone. Scroll
through the message by pressing the Up or
Down scroll key.
Press the
Stop
soft key and press the
Options
soft key to use the following
options:
Play: plays the preview.
Send: allows you to send the message.
Page duration: allows you to set how long
each page of a received message displays.
After the specified time, the display
automatically scrolls to the next page.
Edit colour & font: allows you to set the
Font colour
,
Font style
,
and
Background
colour
by pressing the Up or Down scroll
key.
Tex t/ Image on to p: allows you to change to
each contents oder.
Messages
55
•
Edit page
: allows you to use the following
options:
Page duration: allows you to set how long
each page of a received message displays.
After the specified time, the display
automatically scrolls to the next page.
Edit colour & font: allows you to chang the
text style.
Move pg forward: moves the current page
to the next page.
Move pg back: moves the current page to
the previous page.
•
Text/Image on top
: allows you to change
to each contents oder.
•
Input method
: selects an entering mode
you want to use.
•
Input language
: selects the language you
want to use.
•
Insert text template
: allows you to use
one of the preset message text templates
stored in the
Text templates
menu; for
further details, see page 62.
•
Edit text
: change the selected text
•
Change picture/video/sound
: change
the selected image, video, or sound.
•
Remove text/picture/video/sound
:
deletes the selected text, image, video, or
sound.
•
Save to Drafts
: saves the message as a
draft. You can access it later in the
Drafts
menu; for further details, see page 61.
•
Add page
: adds a new page.
•
Delete page
: deletes a selected page. This
option is only available if there is more than
one page.
•
Save as MMS template
: saves the
message as a template. You can access it
later in the
MMS
templates
menu, see
page 62.
6. When you finish creating the message, press
the
Options
soft key and select
Send
option.
7. Enter a destination number in the
To
input
box.
If you want to use the following options, press
the
Options
soft key.
•
Send
: allows you to send the message.
•
Contacts
: allows you to search Contacts for
a number. See page 84.
•
Change recipients
: allows you to set a
recipient as Cc or Bcc.
Messages
56
•
Save to Drafts
: saves the message as a
draft. You can access it later in the
Drafts
menu; for further details, see page 61.
•
Delete
: deletes the destination number.
•
Delete all
: deletes all destination number.
•
Sending options
: allows you to change the
setting for the message transmission. For
detailed information see page 64.
8. To send the message to more than one
person, press the Down scroll key to move to
another
To
input box.
When you want to return to the edit mode,
press the
Back
key.
9. When you finish setting the destination(s),
press the
Options
soft key and select the
Send
option to send the message.
Writing and sending text messages
1. On the
Create
screen, press the
Select
soft
key when
SMS
highlights.
2. Write your message.
For more information about entering
characters, see page 32.
3. If you want to use the message options while
entering your message, press the
Options
soft key. Select one of the following options:
•
Send
: allows you to send the message.
•
Input method
: selects an entering mode
you want to use.
•
Input language
: selects the language you
want to use.
•
Insert text template
: allows you to use
one of the preset message templates stored
in the
Text templates
menu; for further
details, see page 62.
•
Save to Drafts
: saves the message as a
draft. You can access it later in the
Drafts
menu; for further details, see page 61.
•
Insert contact number
: allows you to add
a contact to the message.
•
Insert bookmark
: allows you to add a URL
saved in the bookmark to the message.
4. When you finish writing the message, press
the
Options
soft key and select the
Send
option.
5. Enter a destination number in the
To
input
box.
Messages
57
If you want to use the following options, press
the
Options
soft key.
•
Send
: allows you to send the message.
•
Contacts
: allows you to search Contacts for
a number. See page 84.
•
Save to Drafts
: saves the message as a
draft. You can access it later in the
Drafts
menu; for further details, see page 61.
•
Delete
: deletes the destination number.
•
Delete all
: deletes all destination number.
•
Sending options
: allows you to change the
setting for the message transmission.
6. To send the message to more than one
person, press the Down scroll key to move to
another
To
input box.
When you want to return to edit mode, press
the
Back
key.
7. When you finish setting the destination(s),
press the
Options
soft key and select the
Send
option to send the message.
Writing and sending MMS postcards
Now you can send a photo from your phone as an
actual postcard. The photo will be printed on a
postcard and sent by mail to any postal address
you wish.
Note
: This menu may not be available depending
upon the country.
1. On the
Create
screen, press the
Select
soft
key when
MMS postcard
highlights.
2. When the
Text
field is highlighted, press the
OK
key. Enter your message.
For more information about entering
characters, see page 32.
If you want to use the message options while
entering your message, press the
Options
soft key. Select one of the following options:
•
OK
: saves the entered greeting text.
•
Input method
: selects an entering mode
you want to use.
•
Input language
: selects the language you
want to use.
•
Insert text template
: allows you to use
one of the preset message templates stored
in the
Text templates
menu; for further
details, see page 62.
•
Insert contact number
: allows you to add
a contact to the message.
Messages
58
•
Insert bookmark
: allows you to add a URL
saved in the bookmark to the message.
3. To attach an image file, press the scroll key to
move to the
field and press the
OK
key. Select a file from the list and press the
OK
key.
4. When you have finished creating the
message, press the
Options
soft key to use
the following options.
•
Send
: allows you to send the message.
Enter detailed information about the
recipient, such as name, additional
information, street, ZIP & city, state/
province, and country.
•
Preview
: shows your message as it will be
displayed on the recipient’s phone. Scroll
through the message by pressing the Up or
Down scroll key.
•
Edit text/Change picture
: edit a message
or chage a picture of a MMS postcard.
•
Remove text/picture
: delete a message
or picture of a MMS postcard.
•
Save to Drafts
: saves the message as a
draft. You can access it later in the
Drafts
menu; for further details, see page 61.
When you finish setting the destination(s),
press the
Options
soft key and select the
Send
option to send the message.
Writing and sending E-mails
1. On the
Create message
screen, press the
Select
soft key when
Email
highlights.
2. Enter your message in message box.
For more information about entering
characters, see page 32.
3. Press the Down scroll key to attach a media
file, if desired, and press the
OK
key. The My
Items screen displays.
4. Select a media file by pressing the scroll keys
and press the
OK
key to select it. A check
mark appears next to the selected file.
5. Repeat step 4 to add more files.
Note
: The maximum size allowed for files can
differ depending upon the country.
6. When you have finished selecting the files,
press the
Options
soft key and press the
OK
key when
Attach
highlights. You can cancel
your selection by choosing
Unmark all
.
Messages
59
7. Press the Down scroll key and enter your
message’s subject.
8. If you want to use the message options while
entering your message, press the
Options
soft key. Select one of the following options:
•
Send
: allows you to send the message.
•
Input method
: selects an entering mode
you want to use.
•
Input language
: selects the language you
want to use.
•
Insert text template
: allows you to use
one of the preset message templates stored
in the
Text templates
menu; for further
details, see page 62.
•
Save to Drafts
: saves the message as a
draft. You can access it later in the
Drafts
menu.
9. When you have finished composing your
message, press the
Options
soft key and
select the
Send
option to send the message.
10.Enter a destination e-mail address in the
To
input box.
If you want to use the following options, press
the
Options
soft key.
•
Send
: allows you to send the message.
•
Contacts
: allows you to search Contacts for
an e-mail address. See page 84.
•
Change recipients
: allows you to set a
recipient as Cc or Bcc.
•
Save to Drafts
: saves the message as a
draft. You can access it later in the
Drafts
menu; for further details, see page 61.
•
Sending options
: allows you to change the
setting for the message transmission.
•
Delete
: deletes the destination number.
•
Delete all
: deletes all destination number.
11.To send the message to more than one
person, press the Down scroll key to move to
another
To
input box.
When you want to return to edit mode, press
the
Back
key.
12.When you have finished setting the
destination(s), press the
Options
soft key
and select the
Send
option to send the
message.
Messages
60
Inbox
(Menu 4-2)
When you receive a new message, the new
message icon displays, corresponding to the type
of message.
•: Text message
•: Text message
• : MMS message
• : MMS notification message
• : Email message
• : WAP push message
• : Voice message
• : Network configuration information
message. For this configuration
message, see Configuration Message on
page 60.
When you access the
Inbox
menu, the list of
messages received displays with the message
size, sender’s address, and message subject.
Press the
Options
soft key to use the following
options; the options may be different depending
on the selected message type:
View
: shows the message, or retrieves MMS
data if the message is an MMS notification
message.
Reply
: allows you to reply to the sender with a
text or multimedia message.
Forward
: allows you to send the message to
other people.
Delete
: deletes the message.
Delete all
: deletes all messages in
Inbox
.
Configuration Messages
You may sometimes receive a configuration
message containing information about the
network setting for MMS or the browser from
your server. When you open a configuration
message, you will see the detailed information.
When you press the
OK
key, or the
Options
soft
key and select the
Install
option, a popup
message appears to ask you if you want to install
the setting on your phone. Press the
Yes
soft key
to update your phone’s network configuration.
You can check the new setting in the MMS or
browser setting menus.
Note
: The GSM setting is not supported.
Messages
61
Drafts
(Menu 4-3)
In this menu, you can read, edit, and send the
messages you saved as drafts.
When you access the
Drafts
menu, the list of
messages you have saved displays with the
recipient’s address, message subject, if you
entered it, and message size.
Scroll to the message you want to view and press
the
OK
key. The message contents display.
Press the
Options
soft key to use options. The
options may be different depending on the
message type.
Sentbox
(Menu 4-4)
Messages that you have sent can be accessed via
this menu.
When you access the
Sentbox
menu, the list of
messages you have sent displays with the
message subject, recipient’s address, and
message size.
Press the
Options
soft key to use the following
options; the options may be different depending
on the selected message type:
View
: shows the message.
Forward
: allows you to send the message to
other people.
Delete
: deletes the message.
Delete all
: deletes all of the messages in
Sentbox
.
Details
: shows detailed information about the
message you sent.
Email
(Menu 4-5)
When you receive an e-mail message, the new
message icon displays.
• : E-mail
• : E-mail with attachment
When you access the
Email
menu, the list of
messages received displays with the message
size, sender’s address, and message subject.
Messages
62
Scroll to the message you want to view and press
the
OK
key. The message displays.
Press the
Options
soft key to use the following
options; the options may be different depending
on the selected message type:
View
: shows the e-mail message.
Reply
: allows you to send a reply message to
the sender.
Reply to all
: allows you to reply message to the
sender and all other (if any) recipients.
Forward
: allows you to send the e-mail
message to other people.
Download
: downloads new e-mail messages to
your phone.
Delete from phone
: deletes the e-mail
message.
Delete all
: deletes all of the e-mail messages
from your phone.
Delete permanently
: deletes the e-mail
message from the phone and server.
Details
: shows detailed information about the e-
mail message.
Call voicemail
(Menu 4-6)
This menu provides you with a way of accessing
your voice mailbox, if your network supports this
service.
You can quickly connect to the voice server by
pressing and holding the
1
key in idle mode.
Templates
(Menu 4-7)
In this menu, you can read, edit, and send MMS
templates and text templates.
When you access the
MMS templates
or
Text
templates
menu in the
Templates
menu, the
list of MMS templates or Text templates displays.
MMS templates
1. On the
Messages
screen, scroll to the
Templates
menu and press the
Select
soft
key. Press the
Select
soft key when
MMS
templates
highlights.
2. Select an MMS message template.
Messages
63
3. Press the
Options
soft key to use the
following options:
•
View
: shows the message.
•
Send
: send the selected MMS template as a
multimedia message.
•
Add new
: creata new MMS templates.
•
Edit
: edits the selected MMS template the
same way you edit an MMS message. After
you edit it, you can send it the same way
you send an MMS message. See page 58.
•
Delete
: deletes the message.
•
Delete all
: deletes all of the message.
Text templates
After you have created new text template
messages, you can add them to your message.
Scroll to the message you want to use by
pressing the Up or Down scroll key and press the
OK
key. You can change the message. For more
information about entering characters, see
page 32.
Press the
Options
soft key to use the following
options:
Send
: allows you to send the message. For
further details about sending a message, see
page 53.
Add new
: allows you to add a new text template
message.
Edit
: allows you to change the message.
Delete
: deletes the message.
Delete all
: deletes all of the message.
Broadcast
(Menu 4-8)
Delete all
(Menu 4-9)
This menu option allows you to delete all of the
messages in each message box separately. You
can also delete all of your messages at one time.
1. Scroll to a message type and place a check
mark next to it by pressing the
OK
key.
Selecting
All
messages
places check marks
on all of the message boxes.
2. If necessary, repeat step 1 to check another
type.
Messages
64
3. When you have finished checking, press the
Delete
soft key.
4. When a confirming message appears, press
the
Yes
soft key to delete all of the messages
in the type(s).
Otherwise, press the
No
soft key.
Settings
(Menu 4-
0
)
In this menu, you can set up default information
for using the messaging features.
Press the Up or Down scroll key to scroll to a
message type and press the
Select
soft key.
MMS settings
You can change the settings for sending or
receiving MMS messages.
Sending options
Priority
: allows you to change the priority level
of your messages.
Expiration
: allows you to specify how long your
MMS centre stores your messages after sending
them.
Delivery
: allows you to set when a message will
be sent.
Hide address
: allows you to prevent your
address from displaying on a recipient’s phone.
Delivery report
: allows you to request
notification from each recipient as to whether or
not your message has been delivered.
Read report
: allows you to request a report
from each recipient as to when your message
was read by the recipient.
Keep a copy
: allows you to leave a copy of your
message in
Sentbox
after sending it.
Receiving options
Home network/Roaming network
: allows you
to set how to receive a message in each network.
•
Autodownload
: you receive multimedia
messages automatically.
•
Manual
:
you receive a notification message
first. Then, if you choose, you can download
the multimedia message.
•
Restricted
(only for Roaming network): If you
select this notification, there may be a possible
additional charge, depending on whether you
download the message or not.
Messages
65
Delivery report
: allows the network to inform
the sender whether or not a message has been
delivered to you.
Read report
: allows your phone to send a
message to the sender to let them know when
the message was read.
Anonymous reject
: allows your phone to reject
messages from callers without a caller ID.
MMS profiles
You can set up information about your MMS
network and select a network connection profile.
In most cases, you don’t need to change the
settings. In case of problems, please contact
your local Vodafone customer service.
Note
: If you change these settings without the
network operator’s instructions, you may not
be able to send or receive multimedia
messages.
You can have several network settings. You can
make changes or rename each setting by
pressing the
Options
soft key, but only one
setting can be active as your network setting. For
more information, see “Connections
(Menu 9-8)
”
on page 105.
Message size
You can set up the maximum file size of MMS
attachment such as 30k, 100k, or 300k. This file
size may differ depending on your country.
Slide interval
You can set how long each smil player page
displays such as 2sec, 5sec, 10sec, or custom
time. After the specified time, the display
automatically scroll to the next page.
SMS settings
You can have several settings. Each setting has
the following options:
Centre address
: allows you to view the number
of your SMS centre. This number is required
when sending messages.
Expiration
: allows you to set the length of time
your text messages are stored at the message
server while attempts are made to deliver them.
Default type
: allows you to set the default
message type.
Name
: allows you to set the setting’s name.
Messages
66
The following options are in the
Sending
options
menu:
Reply path
: allows you to set your SMS centre
number as a reply path, so that the recipient can
send a reply through it. The charge is billed to
you.
Delivery report
: the network informs you
whether or not your message has been delivered.
Network selection
: allows you to select a
preferred data transmission method.
Keep a copy
: your phone leaves a copy of your
message in
Sentbox
after sending it.
Character support
: allows you to select a
character set when editing and sending
messages.
GSM alphabet: you can compose a message
using GSM characters.
Unicode: you can compose a message using
Unicode characters. All GSM characters are
included in the Unicode character set. However,
when using Unicode, the maximum number of
characters which can be entered in a message is
reduced by half.
For details on the GSM and Unicode alphabets,
see the tables on page 35.
Automatic: if you select
Automatic
, the phone
selects the character set depending on whether
you use Unicode characters or not.
Email settings
You can change the settings for sending or
receiving e-mail messages.
Sending options
The following options are available:
From
: allows you to set the alias name.
Sending account
: allows you to select the
default account that is required when you send
e-mail messages.
Priority
: allows you to change the priority level
of your messages.
Keep a copy
: allows your phone to keep a copy
of your message in
Sentbox
after sending it.
Add my contact details
: allows your contact
information to be attached to your message.
Messages
67
Add signature
: allow your signature text to be
attached to the end of your message. You can
enter text using up to 128 characters.
Receiving options
The following options are available:
Receiving option
: allows you to set how to
receive a message.
•
Subject only
: you receive only the subjects of
e-mails. You can read the contents after
downloading.
•
Normal
: you receive the full e-mail.
Set download limit
: allows you to set the
maximum size of an incoming e-mail and rejects
e-mails when they are over the size limit.
Block address
: allows you to block e-mails from
particular addresses.
Block subject
: allows you to block e-mails
which contain the subjects you set.
E-mail profiles
You can set up information about your network
and select a network connection profile. In most
cases, you don’t need to change the settings. In
case of problems, please contact your local
Vodafone customer services.
Note
: If you change these settings without the
network operator’s instructions, you may not
be able to send or receive multimedia
messages.
You can have several network settings. You can
make changes or rename each setting by
pressing the
Options
soft key, but only one
setting can be active as your network setting. For
more information, see “Connections
(Menu 9-8)
”
on page 105.
Email accounts
You can have 3 e-mail accounts. You can select
and edit the accounts.
Scroll to one of the accounts by pressing the Up
and Down scroll key and press the
Options
soft
key. Select the
Edit
option to change the
following options:
Account name
: edit the access name.
SMTP server
: set the SMTP (Simple Mail
Transfer Protocol) server address.
POP3 server
: set the POP3 server address.
Messages
68
My Address
: enter the e-mail address you want
replies to be sent to.
User name
: set the login name of the server.
Password
: set the login password of the server.
Use SMTP Authentication
: set the SMTP
authentication. This option is used with for SMTP
servers that require this.
Same as POP3
: set the SMTP server address
same as POP3.
Voice mail settings
You can change the number of the voice mail
service centre. When you press the
1
key to
access your voice messages, your phone dials
this number.
Memory status
(Menu 4- )
You can check the memory status of each
message box in your phone memory or in your
SIM card.
69
Camera
Using the camera module built into your phone,
you can take pictures or record videos of people
or events. Additionally, you can send the images
to other people in a multimedia message.
When the camera turns on, you can dial a
number to make a video call; for further details
about using the video call feature, see page 29.
Taking a picture
1. To turn on your camera, press the
OK
key
twice in idle mode to select the
Camera
menu and push up you camera module if
necessary.
You can see the picture to be taken on the
display.
2. Point the camera at the subject.
To flip the picture, press the Up or Down
volume key on the left side of the phone. Up
volume key flips the picture upside down,
while Down volume key flips the picture left
to right, as a mirror image.
3. To take a picture, press the
OK
key. Or, press
the
Options
soft key and press the
OK
key
when
Take photo
is highlighted.
Camera
70
4. The photo is saved automatically and then
When you press the
Options
soft key in Step 4,
the following options are available:
Send
:
•
As MMS
: allows you to send the picture as a
multimedia message. For further details about
sending multimedia messages, see page 53.
•
To Album
: allows you to upload the video file
to its server.
•
As MMS postcard
: allows you to send the
picture as a Postcard. This option may not be
available depending upon the country.
•
Via infrared
:allows you to send the photo to
another person via the infrared port. For
further details, see page 98.
Delete
: delete the picture you have taken.
Set as wallpaper
: allows you to set the picture
as wallpaper.
Set as caller ID
: allows you to use the image as
a caller ID indicator to be displayed when a call
comes in from a contact.
My photos
: allows you to move to the
Photos
folder in
My Items
. You can see the picture in
the
Photos
folder; see page 75.
Rename
: allows you to change the image file’s
name. For more information about entering
characters, see page 32.
Taking a video file
You can use your phone just like a camcorder to
record what is currently displayed on the camera
screen and save it as a video file.
To Press the
use the options
Options
soft key.
For details about the
options, see below.
delete the image file
Delete
option.
return to capture
mode
Back
soft key.
turn the camera off
and return to idle
mode
key.
The photo is saved
automatically.
Camera
71
1. To turn on your camera, press the
OK
key
twice in idle mode to select the
Camera
menu and push up you camera module if
necessary.
2. When you are in camera mode, press the
Options
soft key and then select
Record
video
.
You can see the picture to be recorded on the
display.
3. Press
OK
( )key to start recording. Or, press
the
Options
soft key, select
Record
by
pressing the Up or Down scroll key, and press
the
OK
key.
4. Your phone starts recording. Recording file
size can be set for up to 95KB by default.
5. While recording video:
6. When the recording time expires, the phone
automatically saves the video in the
Videos
folder in
My Items
; see page 76.
When you press the
Options
soft key after the
video is saved in your phone, the following
options are available:
Play
: allows to open a video file you have taken.
Delete
: delete the video file you have taken.
Send
:
•
As MMS
: allows you to send the video as part
of a multimedia message.
•
To Album
: allows you to upload the video file
to its server.
To Press the
pause recording
Pause
soft key.
resume paused
recording
OK
() key.
stop recording
OK
( ) key. The
video is automatically
saved in the
Videos
folder.
delete the video file
Cancel
soft key.
turn the camera off
and return to idle
mode
key.
To Press the
Camera
72
Viewfinder
: switches the screen to view finder
mode to allow you to take another video.
My videos
: You can open stored video files.
Rename
: allows you to change the image file’s
name.
Video Mode Options
Press the
Options
soft key in the video mode:
Record
: records a video.
Take photo
: turns to camera mode.
My videos
: You can open stored video files.
Zoom
: adjusts the zoom ratio of the video
camera.
Brightness
: adjusts the brightness of the video.
Video settings
: allows you to define the
Default name
of your choice and to adjust the
quality from
Very low
,
Normal
,
High
, or
Very
high
. It also allows you to set the
Recording
time
. If you select the
For message
option in
the
Recording time
box, you can send video
files of large capacity and the quality is fixed at
Normal
.
Camera mode options
Press the
Options
soft key in camera mode:
Take photo
: takes a picture.
Record video
: turns to video recording mode.
V-call:
allows you to use the Voice call feature.
For more information about the Voice call, see
page 29.
My photos
: allows you to move to the
Photos
folder in
My Items
.
Zoom
: allows you to set the camera zoom. Press
the Up or Down key in the key to adjust the
camera zoom.
Multi shot
: takes a rapid series of pictures (from
3 -10).
Timer
: sets the phone to take a picture at a
predefined time. Once you set the time, the timer
icon appears at the bottom of the screen. When
you press the
OK
key, the phone takes a picture
after the predefined time.
Flash
: set the camera flash on or off.
Camera
73
Effects
: allows you to change the colour tone of
the picture.
Sepia
,
Mono
,
Night
, and
Normal
are available.
Brightness
: adjusts the brightness of the
picture.
Camera settings
: allows you to set several
camera settings. You can define the
Default
name
of your picture and adjust the
Capture
quality
between
Low
,
Normal
,
Fine
, or
Super
fine
. You can also select
Image size
(1152*864
,
640*480
,
320*240
,
160*120)
,
Viewfinder
,
Multi shot speed
, and
Flash
mode
allows you to set the camera flash to be
used automatically or not.
74
My items
You can enjoy various multimedia files, such as
Pictures, videos, Ringtones, and sounds, using
My Items
.
Exploring multimedia files
You can use up to 5 categories of multimedia
files:
Pictures
,
Videos
,
Ringtones
,
Sounds
,
and
Other files
.
When you press the
OK
key and the
Select
soft
key, the list of the files in the selected category
displays.
Using multimedia options
On the file list in any category, you can use the
following options by pressing the
Options
soft
key:
View/Play/Take photo/Record video/
Record sound
: shows or plays the selected file.
Or, create a new file.
Send
:
•
As MMS
: allows you to send a multimedia
message using the multimedia file. For further
details about sending multimedia messages,
see page 53.
•
As MMS postcard
: allows you to send a
Postcard using the multimedia file. This option
may not be available depending upon the
country.
•
Via infrared
:allows you to send the
multimedia file to another person via the
infrared port. For further details, see page 98.
Move to live! Studio
: allows you to move the
selected file to your live! Studio page. This option
may not be available depending upon the
country. For more information, see page 62.
Note
: This term is used only in the United
Kingdom. Other countries use “Move to
Album”.
Set as:
•
Set as wallpaper
(available in the
Pictures
category): allows you to use the image as the
background for the sub LCD.
My items
75
•
Set as ringtone
(available in the
Sounds
category): allows you to use the sound as your
ringtone for voice or video calls.
•
Set as caller ID
: allows you to use the image
or sound as a caller ID indicator to be
displayed or played when a call comes in from
a contact.
Move
: allows you to move the selected file to
another folder.
Delete
: allows you to select
File
,
Folder
, or
All
files
option to delete files.
Rename
: allows you to change the file or folder
name. For further details about entering
characters, see page 32.
Create folder
: allows you to make a new folder
for storing multimedia files.
Download
: allows you to download new files
from the web server.
Lock/Unlock
: allows you to protect the picture
from deletion, or not.
Details
:
shows detailed information about the
selected file.
Memory status
: shows you the amount of
memory used in the current category and the
remaining memory.
Using picture files
You can use bmp, wbmp, gif, animated gif, png,
or jpg image files.
Viewing an picture
1. Press the Up or Down scroll key to select the
Pictures
category. The image list displays.
2. Press the Up or Down scroll key to select an
image and press the
OK
key.
3. The image viewer shows the selected file.
Press the Left or Right scroll key to load the
previous or next image file.
When viewing an image, you can use the
following options by pressing the
Options
soft
key:
Send
: allows you to send the selected file. For
more information, see
Send
on page 74.
Set as
:
•
Set as wallpaper
: allows you to use the
image as your wallpaper image, i.e., as the
background for your idle screen.
•
Set for sub LCD
: allows you to use the image
as the background for the sub LCD.
My items
76
•
Set as caller ID
: allows you to use the image
as a caller ID indicator to be displayed when a
call comes in from a particular contact.
Move
: allows you to move the selected file to
another folder.
Real size
: shows you the selected image in its
own saved size. You can scroll through the image
by pressing the navigation keys.
Slide show
: allows you to view all of the images
in the selected folder using the slide show
feature, which shows the images one by one on
full screen at 3-second intervals.
Resize
: allows you to change the image size.
Retouch
: allows you to apply special effect on
images.
Frame
: allows you to apply special frame over
images.
Delete
: deletes the selected file.
Rename
: renames the file.
Details
: shows detailed information about the
file, such as file name, size, type, and many
other things.
Creating a new image
From the file list of the folder, select
Take photo
and press the
OK
key or use the
Camera
application.
For further details about using the camera, refer
to page 69.
Using video files
Your phone can play video files in mp4 or 3gp
format.
Playing a video file
1. Press the Up or Down scroll key to select
Videos
. The video list displays.
2. Press the Up or Down scroll key to select a
video file and press the
OK
key.
3. Media Player plays the selected file.
My items
77
For further details about using Media Player,
see page 48.
Creating a video
From the file list in
Videos
, select
Record video
and press the
OK
key, or use the
Camera
application.
For further details about recording a video, refer
to page 74.
Using music files
Your phone can play music files in mp4 and 3gp
format.
Playing a music file
1. Press the Up or Down scroll key to select
Music
. The music list displays.
2. Press the Up or Down scroll key to select a
music file and press the
OK
key.
3. The music plays.
For further details about using Media Player,
see page 48.
Using ringtones
You can use 64 polyphonic stereophonic melodies
or ringtones.
1. Press the Up or Down scroll key to select
Ringtones
.
2. Press the Up or Down scroll key to select a file
and press the
OK
key.
3. The Tone melody plays.
Press the Up or Down scroll key or volume
key to control the volume.
Press the Left or Right scroll key to load the
previous or next file.
While playing a sound, you can use the following
options by pressing the
Options
soft key:
Send
: allows you to send the selected file. For
more information, see
Send
on page 74.
Set as ringtone
: allows you to use the melody
as your ringtone for voice or video calls.
Set as caller ID
: allows you to use the sound as
a caller ID indicator to be played when a call
comes in from a particular contact.
My items
78
Details
: shows detailed information about the
file, such as file name, size, type, and many
other things.
Using sounds
You can use the Voice memo feature in this
menu.
1. Press the Up or Down scroll key to select
Sounds
.
2. Press the Up or Down scroll key to select a file
and press the
OK
key.
3. The Sound plays.
Press the Up or Down scroll key or volume
key to control the volume.
While playing a sound, you can use the following
options by pressing the
Options
soft key:
Record settings
: allows you to set the default
name and recording time.
Creating a Sound
From the
Sounds
category, select the
Record
sound
. Press the
OK
key or use the
Voice
memo
application. The Voice memo screen
displays.
For further details about using the Voice memo
screen, see page 52.
79
Organiser
The Organiser feature allows you to view the
current month as well as past or future months
in calendar format. You can schedule up to 100
events in total. You can also make up to 50
anniversary, 20 task, and 20 memo notices.
Calendar
(Menu 7-1)
The calendar displays the
current month and highlights
the current day.
Days with events scheduled
are marked with a coloured
symbol: green for scheduled
items, red for anniversaries,
blue for tasks, and orange for
memos.
To scroll through the calendar:
• Press the Up or Down scroll key to move to the
previous or next week.
• Press the Left or Right scroll key to move to
the previous or next day.
• Press the volume keys to move to the previous
or next month. You can also press the Left,
Right, or Up scroll key when the title bar
showing the month and year highlights.
• Press the
OK
key to access the highlighted
date.
You can use the following options by pressing the
Options
soft key:
View
: shows you the schedule for the selected
day.
Add new
: allows you to make a new
Schedule
,
Anniversary
,
Task
,
or
Memo
.
Week view
: shows the present week’s calendar.
Go to today
: shows today’s calendar.
Go to date
: enter a date to which you want to
go and press the
Go
soft key.
Starting day
: allows you to select the start day
of week as Sunday or Monday.
Delete
: deletes the events in the period you
specify.
Delete all
: deletes all of the events in your
calendar.
Organiser
80
Week view
(Menu 7-2)
Week view shows the calendar of your events for
an entire week. You can use this view to quickly
review your appointments and available time
slots.
Today’s event
(Menu 7-3)
When you press the
Options
soft key, the
following options are available; these may be
different depending on the selected event type:
View
: shows you details of the event.
Add new
: allows you to make a new
Schedule
,
Anniversary
,
Task
, or
Memo
.
Completed
: when you have completed a task,
select
Completed
to insert a check mark next to
the item.
Note
: If you want to remove the check mark, select
the item and press the
Options
soft key.
Then select
To do
.
Month view
: returns to the calendar screen.
Change date
: allows you to change an
anniversary date.
Reschedule
: allows you to change the date of
an event easily. When the calendar displays,
move to a new start date using the scroll keys
and press the
OK
key.
Change due date
: allows you to change the
task’s due date.
Delete
: deletes the event.
Delete all
: deletes all of the events for that day.
Send schedule
: allows you to send the
scheduled event by e-mail or via infrared.
Send task
: allows you to send the task by e-
mail or via infrared.
Send memo
: allows you to send the memo by
text message.
Schedule
(Menu 7-4)
Press the
Options
soft key and select the
Add
new
option to make a new event. See page 80
for other options.
Organiser
81
1. Scroll through the entry fields by pressing the
Up or Down scroll key. Enter information or
select the settings you want.
•
Title
: enter the title of the event. See
page 32 for more information about
entering characters.
•
Details
: enter the event details.
•
Start
: enter the start time of the event.
You can move the cursor using the Left and
Right scroll keys.
•
End
: enter the end time of the event the
same way as you would enter a start time.
•
Start date
: enter the start date. You can
move the cursor using the Left and Right
scroll keys.
•
End date
: enter the end date the same way
as you would enter a start date.
•
Location
: enter information about the
event location.
•
Alarm
: press the
OK
key to set an alarm to
remind you of the event. Then set when the
alarm will alert you: enter the number and
select a unit,
min.
,
hour
, or
day
, using the
Left and Right scroll keys. You can move
from the number box to the time box by
using the Down scroll key.
•
Repeat
: if you are entering a recurring
event, press the
OK
key and select the
repeat option using the Left and Right scroll
keys. Then enter the date that you wish the
event to cease recurring.
•
Expiry
: select how long the event is to be
stored in your calendar.
2. When you have finished entering the event,
press the
Save
soft key.
Anniversary
(Menu 7-5)
Press the
Options
soft key and select the
Add
new
option to make a new anniversary. See
page 80 for the other options.
1. Scroll through the entry fields by pressing the
Up or Down scroll key. Enter information or
select the settings you want.
•
Occasion
: enter the information about the
occasion. See page 32 for more information
about entering characters.
Organiser
82
•
Date
: enter the date. You can move the
cursor using the Left and Right scroll keys.
•
Alarm
: press the
OK
key to set an alarm to
remind you of the event. To set an alarm
ahead of the day required, enter the desired
number of days before the event, and the
time on that day that you want to be
alerted. You can move the cursor using the
Left and Right scroll keys.
•
Repeat every year
: press the
OK
key to
mark or unmark this option.
2. When you have finished entering the
anniversary details, press the
Save
soft key.
Task list
(Menu 7-6)
Press the
Options
soft key and select
Add new
to make a new item for the Task list.
1. Scroll through the entry fields by pressing the
Up or Down scroll key. Enter information or
select the settings you want.
•
Task
: enter the information about the
occasion. See page 32 for more information
about entering characters.
•
Start date
: enter the start date. You can
move the cursor using the Left and Right
scroll keys.
•
Due date
: enter the due date.
•
Priority
: enter the priority, choosing 1, 2 or
3. 1 is the highest priority.
2. When you have finished entering the Task,
press the
Save
soft key.
When you have completed a task from the Task
list, select the item and press the
Options
soft
key. Then select
Completed
to insert a check
mark next to the item.
Note
: When you want to remove the check mark,
select the item and press the
Options
soft
key. Then select
To do
.
Organiser
83
Memo
(Menu 7-7)
Press the
Options
soft key and select the
Add
new
option to create a new memo. See page 80
for other options.
1. Scroll through the entry fields by pressing the
Up or Down scroll key. Enter information or
select the settings you want.
•
Memo
: enter the memo details.
•
Date
: enter the date.
2. When you have finished entering the memo,
press the
OK
key.
Missed event alarm
(Menu 7-8)
When the alarm sounds, you must press the
OK
soft key in the reminder window within one
minute. Otherwise, the missed event alarm
window will be displayed.
You can view missed events in the
Missed Event
Alarm
menu.
Press the
Options
soft key to use the following
options:
View
: allows you to view the selected event
alarm details.
Delete
: allows you to delete the selected event
alarm in the list.
Delete all
: allows you to delete all event alarms
in the list.
Memory status
(Menu 7-9)
You can check the memory staus for schedule,
anniversary, Task list, and memo in
Organiser
.
The display shows the total and used space, and
the number of objects you saved.
84
Contacts
You can create a phonebook by saving phone
numbers and names. Your phone gives you an
easy way to make calls by using the phonebook
numbers and names.
Search contact
(Menu 8-1)
When you access this menu, the Search contact
screen displays.
Enter the first few letters of the name you want
to search for. The contact entries are listed
alphabetically, starting with those that most
closely match your input.
1. If necessary, press the Up or Down scroll key
to find the contact you want.
When you press the
Options
soft key from the
Contacts list, the following options are available:
View
: shows detailed information about the
contact.
Edit
: allows you to edit the name or number of
the contact.
Call
: allows you to dial to the number.
V-call
: makes a video call to the person. For
further details, see page 29.
Add new contact
: adds a new contact to the
phone or SIM. For more information about
adding a contact, see page 85.
Add new contact
: allows you to add the contact
number to speed dial list
Delete
: deletes the selected contact.
Search groups
: searches groups, see page 91.
Delete all
: displays the memory locations,
Phone & SIM, Phone, and SIM to delete all.
Select the
Yes
soft key to delete the selected
memory, otherwise select the
No
soft key.
2.
To Press the
dial the number key.
view details of the
contact.
OK
key.
Contacts
85
Add contact
(Menu 8-2)
You can add to your phonebook by saving phone
numbers and the corresponding names in the
memories of your SIM card and phone. You can
save up to 1000 names in the phone’s memory.
Each name can have up to five numbers, and
other personal information.
When you add a new contact, you have to select
the memory location by pressing the Up and
Down scroll key in the input box.
Adding a contact to the phone’s
memory
When you access this menu, you will see the
startup screen of the Add contact menu. You can
also access this screen by pressing the
Add
soft
key in main menu mode.
1. Press the Up or Down scroll key to scroll
through the input boxes and enter the
corresponding information you want to save:
•
First Name
/
Last Name
: enter the first and
the last name of the contact. For further
details about entering characters, see
page 32.
•
Mobile
()/
Home
()/
Work
()/
Fax
()/
Etc.
( ): enter the number you
want to add. The icons at the left side of
each input box tell what type of number it
is.
•
Email 1/2
: enter the person’s e-mail
address.
•
Group
: press the
OK
key to add the person
to a group.
•
Homepage
( ): enter the URL address of
the person’s home page.
•
Memo
: enter information you need to
remember about the person.
•
Birthday
( ): enter the birthday of the
contact.
•
Postal address 1/2
: Press the
OK
key to
enter the person’s postal address.
2. When you have entered the information you
want, press the
Options
soft key and select
the
Save
option.
Adding a contact to the USIM card
1. Press the Up or Down scroll key to scroll
through the input boxes and enter the
corresponding information you want to save:
Contacts
86
•
Name
: enter the name of the contact. For
further details about entering characters,
see page 32.
•
Phone number
: enter a phone number you
want to add.
•
Email
: enter the person’s e-mail address.
•
Group
: press the
OK
key to add the person
to a group.
2. Press the Down scroll key to move to the
location number input box and modify a
number, if you want.
3. Press the
Options
soft key and select
Save
option.
Adding a contact to the SIM card
1. Enter the name of the contact.
2. Press the Down scroll key to move to the
Phone number
input box and enter a
number.
3. Press the Down scroll key to move to the
location number input box and modify a
number, if you want.
4. Press the
Save
soft key.
Adding a contact from idle mode
1. In idle mode, enter the number to be stored.
2. Press the
Options
soft key and press the
OK
key when
Save contact to
highlights.
3. Press the Up or Down scroll key to scroll
through the input boxes and enter the
corresponding information you want to save.
The input boxes depend on the memory type
you select in the memory setting. Refer to the
previous pages for subsequent steps.
Other options for phone memory type
when adding contacts list
When you press the
Options
soft key from the
editing view, the following options are available:
Save
: saves a contact.
Special options
: you can set a distinctive image
and sound for a contact. Press the Up or Down
scroll key to move to each field.
Contacts
87
•
: allows you to select an image to be
displayed when a call or message comes in
from a contact. Press the
OK
key. You can
select from icon, animation, and photo, and
then choose a file from
My Items
.
•
Ring tone
: allows you to set a sound to be
played when a call comes in from a contact.
Press the
OK
key and select an audio file from
My Items
.
•
Msg. alert tone
: allows you to select a sound
to be played when a message comes in from a
contact. Press the
OK
key and select a sound
file from
My Items
.
After changing the options, press the
Options
soft key and select
Save
. If you want to decline
the changes and return to the default settings,
select
Reset
.
Add item
: allows you to add another contact
number. Select one of the types, then add the
number.
Delete item
: deletes the selected contact item
which you’ve added using the
Add item
option.
Change type
: changes the contact type of the
selected contact item. Select one of the types.
Mark/Unmark video call
: activates or
deactivates a video call to the selected contact
number item.
Viewing contact information
You can access the details of a
contact in the phone’s memory
and SIM by pressing the
OK
key on the Contact list.
To Press the
enter
OK
key
scroll through the
items
Up or Down scroll key.
dial the selected
number
key.
save changes after
editing information
OK
key after editing each
item.
return to the
Contacts list
Back
soft key.
Contacts
88
When you press the
Options
soft key, the
following options are available:
Edit
: allows you to edit the selected number and
name.
Call
: allows you to make a call to the person.
V-call
: allows you to make a video call to the
person. For further details, see page 29.
Send message
: allows you to send a message
to the contact. You can write a text message,
create a multimedia message, write a message
to which you attach a media file, or you can send
MMS postcard. For more information about
sending a message, see page 53.
Special options
: you can set a distinctive image
and sound for the contact. Press the Up or Down
scroll key to move to each field.
Add to speed dial
: allows you to add the
contact number to speed dial list.
Copy to SIM/phone
: copies the contact to the
SIM or to the phone.
Send contact details
: allows you to send your
contact details as a an email or via infrared.
Set as default
: makes the selected phone
number as a default number for a contact.
Duplicate
: allows you to duplicate the contact.
Paste
: allows you to paste the selected number
into the normal dialling mode.
Delete
: deletes the selected contact.
Call log
(Menu 8-3)
In this menu, you can view:
• missed, dialled, received calls, or all calls
• cost of your calls
• length of time of calls you have made or
received
Notes:
• You can access the all calls list by pressing the
key in idle mode.
• When you are not calling, but using an Headset
and the phone is closed, you can see the call
log on the sub LCD by pressing the button of
the Headset. You can also scroll through the
log by pressing the volume keys on the left
side of the phone.
Contacts
89
Missed, Dialled, Received, or All Calls
1. From the Call log screen, press the Left or
Right scroll key to scroll to the type of calls
you want to view.
Each time you press the key, a list of the
various call records appears. Your phone
records up to the last 20 calls in each log.
If the number is saved in Contacts, the
corresponding name displays.
2. Press the Up or Down scroll key to select the
call you want to view.
When you press the
Options
soft key in the call
log list, the following options are available:
View
: shows detailed information about the call.
Call
: allows you to dial to the number.
V-call
: allows you to make a video call to the
person. For further details, see page 29.
Save contact to
: allows you to save the number
in Contacts.
Send message
: allows you to send a text
message, multimedia message, or message with
media attached to the number.
Delete
: deletes the call.
Delete all
: deletes all of the call records stored
in the current call log.
Data counter
You can see the total size of sent and received
data calls. Data calls include:
• sending and receiving multimedia messages
• sending and receiving e-mail
• browsing WAP pages
• downloading MIDlets (Java applications
running on mobile phones)
• using your phone as a modem.
Press the
Options
soft key to use the following
options:
Reset
: clears the selected data call log.
Reset all
: clears all of the data call log.
3.
To Press the
dial the number key.
return to idle mode key.
Contacts
90
Calls cost
This feature lets you view the cost of calls.
Notes
:
• This feature may not be shown depending on your
SIM card.
• This feature is not intended to be used for billing
purposes.
• AOC (Advice Of Charge) information may display
on call, depending on your SIM card or service
provider.
1. The Call Costs screen shows you the total
cost, last call costs, and cost limit.
2. While viewing the call costs, press the
Options
soft key to use the following options:
•
Reset call costs
: allows you to reset the
cost counter; first, you must enter your
PIN2 code (see page 113) and then press
the
Confirm
soft key.
•
Edit cost limit
: allows you to enter the
maximum cost that you authorise for your
calls; first, you must enter your PIN2 code
(see page 113) and then press the
Confirm
soft key.
•
Setup currency
: allows you to set the
currency of the call cost; first, you must
enter your PIN2 code (see page 113) and
then press the
Confirm
soft key.
Calls time
1. Press the Up or Down scroll key to scroll
through the call timer for each call type.
•
Total dialled
: total time of the voice
calls you have dialled.
•
Total received
: total time of the voice
calls you have received.
•
Total dialled
: total time of the video
calls you have dialled.
•
Total received
: total time of the video
calls you have received.
2. While viewing the call time, press the
Options
soft key to use the following options:
•
Reset
: resets the call timer.
•
Reset all
: resets all of the call timers.
Note
: The actual time invoiced for calls by your
service provider may vary, depending on
network features, rounding-off for billing
purposes, and other factors.
Contacts
91
Groups
(Menu 8-4)
You can manage groups. The contacts stored in
the phone’s memory or supplied by the USIM
card can be assigned to contact groups.
Editing groups from the group list
1. When the Group list displays, if necessary
press the Up or Down scroll key to scroll
through the Group list to the Group you want.
2. Press the
Options
soft key from the Group
list to access the following options:
•
Add member
: allows you to add member
or members to the selected group.
•
View members
: views the Contacts list
saved for this group.
•
Add group
: you can enter a group name
for a new group. You can see the new group
name in the Group list.
•
Rename group
: allows you to change the
group name.
•
Delete group
: deletes the selected group.
•
Delete all groups
: deletes all of the
groups.
Editing group item
1. When you select a group, you can see the list
of names enrolled in the group.
2. If necessary press the Up or Down scroll key
to scroll through the name list.
3. Press the
Options
soft key to access the
Edit
group
option. This feature allows you to
change members in the group. Mark and
unmark names you want to add or delete
using the
OK
key and press the
Save
soft
key.
Speed dial
(Menu 8-5)
You can set up to eight speed dial numbers and
then dial them simply by pressing the associated
number key.
Editing speed dial from the speed dial
list
1. When the Speed Dial list displays, highlight
one of the Speed dial numbers you want to
edit by pressing the scroll key.
Contacts
92
2. Press the
Options
soft key to access the
following options:
•
Assign
: allows you to add a speed dial
number at an empty slot.
•
View
: allows you to view detailed
information about the selected speed dial
entry.
•
Call
: allows you to dial to the number.
•
V- call
: allows you to make a video call to
the number.
•
Change
: allows you to change one entry
into another.
•
Remove
: allows you to clear the selected
speed dial number.
My contact details
(Menu 8-6)
You can store personal information, such as your
first and last name, wireless phone number,
home number, office number, f a x n u m b e r, e - m a i l ,
URL, memos, etc.
Press the
Options
soft key to access the
following options:
Save
: saves your information.
Add item
: allows you to add another contact
number. Select one of the types then add the
number.
Delete item
: deletes the contact item which
you’ve added using the
Add item
option.
Change type
: changes the selected contact
item’s type. Select one of the types.
If you have saved one or more your contact
details you will see the below optons when you
press the
Options
soft key.
Edit
: changes the selected contact item’s
information.
Send contact details
: allows you to send your
contact details as a an email or via infrared.
Delete
: deletes the contact item which you’ve
added using the
Add item
option.
Copy all
(Menu 8-7)
You can copy all of the contacts stored in the SIM
card to the phone memory and vice versa. When
a confirming message appears, press the
Yes
soft key to copy. Otherwise, press the
No
soft
key.
Contacts
93
Settings
(Menu 8-8)
This menu option allows you to set options for
contact list. Below options are available:
Viewing settings
:
•
By first name
: displays contacts as the first
name comes first.
•
By last name
: displays contacts as the last
name comes first.
Default storage settings
:
•
Optionally
: allows you to choose where to
store.
•
Phone
: stores contact in the phone memory.
•
SIM
: stores contact in the SIM card.
Memory status
(Menu 8-9)
You can check how many contact items are
stored in the phone or SIM memory.
You can see the number of existing and
remaining available entries in the SIM card or
phone memory.
94
Settings
Many different features of your phone can be
customised to suit your preferences in the
Settings
menu.
Phone profiles
(Menu 9-1)
In
Profiles
, you can adjust and customise the
phone tones for different events or situations.
There are five preset profiles:
Normal
,
Meeting
,
Car
,
Silent
, and
Outdoor
, which you
can customise to meet your needs.
Changing the profiles
On the Profiles screen, select a profile by
pressing the Up or Down scroll key and press the
OK
soft key.
Note
: You can quickly change to silent mode by
holding
the key
down when
in idle mode.
To change back to the previous profile
mode, hold the key down again.
Customising the profiles
1. To modify a profile, scroll to the profile on the
Profiles list by pressing the Up or Down scroll
key, and then press the
Option
and
Edit
key.
A list of profile settings opens. The available
setting options vary depending on the
selected profile.
2. Scroll to the setting you want to change by
pressing the Up or Down scroll key, and then
change the setting using the Left or Right
scroll keys, or the
OK
key.
The following options are available:
•
Call alert type
: allows you to select the
alert type for the call ringer. You can choose
from
Melody
,
Vibration
,
Mute (Light
only)
, and
Vibration & melody
.
•
Voice call/V-Call ringtone
: enables you
to select a melody or tone to be used when
you select
Melody
or
Vib & melody
in the
Call alert type
option. Press the
OK
key
and select a sound from the alert tone list.
Settings
95
•
Tone volume
: allows you to adjust the
volume level of the voice call, video call,
ringtone, and message alert tone.
•
Msg. alert type
: allows you to select the
alert type for the message ringer.
•
Msg. alert tone
: allows you to select the
melody or tone to be used if you select
Melody
or
Vib & melody
in the
Msg. alert
type
option.
The last item on the list of tone choices is
Special tone
. If you select
Special tone
,
you will see a list of tones that have been
downloaded, and you can select one of
those tones for your
Msg. alert tone
.
•
Msg. alert repetition
: allows you to
specify how often the phone informs you of
a new message. You can choose either
Once
or
Periodic
.
•
Phone sounds
: allows you to turn the
following alert sounds on or off:
All on: enables all tones.
Popup box alerts: sets the phone to inform
you of the status.
Minute minder: lets you set the phone to
beep every minute during an outgoing call to
keep you informed of the length of your call.
Call connect tone: sets the phone to beep
when the person you are calling answers
the phone.
Call end tone: sets the phone to beep when
your call ends.
Power on: sets the phone to beep when the
phone is switched on.
Sound effects: sets the phone to beep when
you access the menu.
Folder open/close: sets the phone to beep
when you open or close the phone.
Alerts on call: sets the phone to all alerts
while calling.
All off: disables all tones.
To enable an effect tone(s), press the
OK
key to place a check mark next to the
tone(s) you want. To remove a check mark,
press the
OK
key again. Then press the
Done
soft key to save the settings.
•
Key tones
: allows you to select a tone
which sounds when you press a key.
•
Key tone volume
: allows you to adjust the
volume level of the key tones.
3. When you finish setting the options, press the
Save
soft key.
Settings
96
Display settings
(Menu 9-2)
This menu allows you to customise the main
display screen by setting a greeting message,
setting a wallpaper image, or changing the Sub
LCD style.
Greeting message
You can set a greeting message to be displayed
briefly when you switch the phone on.
1. When
Greeting message
highlights in the
Display menu, press the
Select
soft key.
2. Select one between
Main LCD
and
Sub LCD
.
The current message displays.
3. Press down the
C
key to clear the message.
4. Enter a new message.
For more information about entering
characters, see page 32.
5. When you have finished entering the
message, press the
Save
soft key.
Wallpaper
You can select a background image (wallpaper)
to be displayed on the idle screen.
1. Select
Wallpaper
in the
Display settings
menu using the Up or Down scroll key, and
press the
Select
soft key.
The
Pictures
folder from
My Items
opens.
2. Press the Up or Down scroll key to scroll to
the image you want to use.
3. Press the
Select
soft key or
OK
key to see
the image.
4. Press the
Set
soft key or
OK
key to change
the wallpaper.
Sub LCD
You can choose one of the following options:
Clock
: a clock showing the current time and date
appears on the screen.
Sub title
: you can enter a sub LCD’s greeting
message. For more information about entering
characters, see page 32.
Wallpaper
: you can select an image. You can
also adjust the size and position of the image.
Settings
97
Phone settings
(Menu 9-3)
In this menu, you can set options for the phone.
LCD brightness
You can adjust the brightness of the screen.
Press the Left or Right scroll key to make the
screen darker or brighter and then press the
Save
soft key.
Backlight
You can set the timer to go to dimming mode
when there is no input, which consumes less
battery power. You can select the length of time
the phone waits before it dims the screen after
the last key is pressed. Once the phone goes to
dimming mode, the screen will turn off after 30
seconds.
When your phone is in another dimming mode or
the screen is off, you can wake it up by pressing
any key.
Ext. light
This menu allows you to select whether or not
the external light is used and what colour it is.
The external light is a service availability
indicator. When you set the
Service light
to
On
,
the light flashes when you are in a service area.
If the phone is not in a service area, the light
doesn't flash.
If you do not wish to use the service light, select
Off
.
Language
You can select a different language for the
display text and the text input mode.
1. Press the
OK
key in the
Screen Text
field.
2. Press the Up or Down scroll key to select a
language for the display text, e.g., menu
names and warning or confirming messages,
and press the
Select
soft key.
Note
: The SIM card determines the display
language when the
Screen Text
option is
set to
Automatic
.
3. Press the Down scroll key to move to the
Input T9
field and press the
OK
key.
4. Press the Up or Down scroll key to select a
language for the T9 input mode and press the
Select
soft key.
Settings
98
5. Press the
Save
soft key.
Infrared
In this menu, you can activate or deactivate the
infrared port.
The following options are available:
On
: activates the infrared feature on the phone.
Off
: deactivates the infrared feature on the
phone.
If there is no communication between your
phone and an IrDA-compliant device within 2
minute of activating the feature, it is
automatically deactivated.
Shortcuts
You can set the Left, Right, Up, and Down scroll
keys to be used as shortcut keys to the menu
functions you use most frequently. In idle mode,
this will allow you to access specific menu options
directly.
1. Press the Left or Right scroll key to check the
current function assigned, and select the
scroll key whose function you want to change.
2. Press the
Options
soft key to use the
following options:
•
Change
: assigns or changes the function of
the selected scroll key.
Select a function from the function list and
press the
Select
soft key to select it.
•
Remove
: removes the menu function of the
selected navigating key.
•
Remove all
: removes all functions assigned
to the scroll keys.
Active folder
When this option is set to
On
, you can answer a
call by opening the phone.
When it is set to
Off
, you must first flip the phone
open and press a key, depending on the setting
of the
Anykey Answer
option.
Press the Up or Down scroll key to select
On
or
Off
, and press the
Save
soft key.
Anykey answer
Settings
99
When this option is set to
On
, you can answer an
incoming call by pressing any key except the
key and the
Reject
soft key.
When this option is set to
Off
, you can only
answer by pressing the key or the
Accept
soft
key.
Press the Up or Down scroll key to select
On
or
Off
, and press the
Save
soft key.
Call settings
(Menu 9-4)
In this menu, you can set options for a call.
Caller ID
You can prevent your phone number from being
displayed on the phone of the person being
called.
Note
: Some networks do not allow the user to
change this setting.
The following options are available:
By network
: the default setting provided by the
network is used.
Send
: your number is sent each time you make
a call.
Hide
: your number is not displayed on the other
person’s phone.
Diverting
This network service enables incoming calls to be
rerouted to the number that you specify, for
example, to your voicemail box.
To set your call diverting options:
1. From
Voice call
,
Data call
,
and
Video call
,
select the type of call to be diverted by
pressing the Up or Down scroll key, and then
press the
OK
key.
2. Select when the calls should be diverted by
pressing the Up or Down scroll key, and then
press the
OK
key.
•
Always
: all calls are diverted.
•
Busy
: calls are diverted if you are already
engaged on a call.
•
No reply
: calls are diverted if you do not
answer the phone.
Settings
100
•
Not reachable
: calls are diverted if you are
not in an area covered by your service
provider.
•
Cancel all
: all call diverting options are
cancelled.
3. Press the
Option
soft key to select one of the
following options:
•
Contacts
: allows you to select call number
diverted from contact list.
•
Activate
: your network has the number
already registered, but it is not activated.
This option activates the number.
•
Deactivate
: the selected call diverting
option is currently active. This option
deactivates the setting.
4. Press the Down scroll key and enter or
change the number to which you want your
calls diverted. Or, press the
Option
soft key
and select the
Contacts
to select a stored
number.
5. Press the
Option
soft key and select
Activate
option.
The phone sends your settings to the network
and the network’s acknowledgement displays.
Barring
The call barring network service allows you to
restrict your calls.
To set your call barring options:
1. From
Voice call
,
Data call
,
and
Video call
,
select the type of call to be barred by pressing
the Up or Down scroll key, and then press the
OK
key.
2. Select which calls should be barred by
pressing the Up or Down scroll key, and then
press the
OK
key.
•
All outgoing calls
: calls cannot be made.
•
Outgoing int’l calls
: international calls
cannot be made.
•
Int’l calls exc. home
: when abroad, calls
can be made only to numbers within the
current country and to your home country,
which is the country where your home
network operator is located.
•
All incoming
calls
: calls cannot be
received.
•
Incoming calls when roaming
: calls
cannot be received when you are using your
phone outside of your home service area.
Settings
101
•
Cancel all
: all call barring options are
cancelled.
The phone dials your network to find whether
call barring is possible or not.
After a few minutes, the current status
displays.
3. Press the Left or Right scroll key to select one
of the following options.
•
Activate
: The selected call barring option is
not activated. Selecting this option activates
your setting.
•
Deactivate
: The selected call barring
option is currently active. Selecting this
option deactivates your setting.
4. Press the Down scroll key and enter the call
barring password supplied by your service
provider.
5. Press the
OK
key.
The phone sends your settings to the network
and the network’s acknowledgement displays.
Changing the barring password
You can change the call barring password
obtained from your service provider.
1. From the barring menu screen, press the
Options
soft key and select the
Change
password
option.
2. Enter the current password in the
Old
input
box.
3. Press the Down scroll key and enter a new
password.
4. Press the Down scroll key and enter the new
password again to confirm it.
5. Press the
Confirm
soft key.
Waiting
This network service informs you when someone
is trying to reach you when you are busy with
another call.
To set your call waiting options:
1. From
Voice call
and
Data call
, select the
type of call by pressing the Up or Down scroll
key, and then press the
OK
key.
Settings
102
The phone dials your network to find whether
call waiting is possible or not.
After a few minutes, the current status
displays.
2. Press the Left or Right scroll key to select one
of the following options.
•
Check status
: your phone dials your
network to find whether call diverting is
possible or not. After a few minutes, the
current status displays.
•
Activate
: The selected call waiting option is
not activated. Selecting this option activates
your setting.
•
Deactivate
: The selected call waiting
option is currently active. Selecting this
option deactivates your setting.
3. Press the
Req.
soft key.
The phone sends your settings to the network
and the network’s acknowledgement displays.
Auto redial
With this feature, the phone makes up to ten
attempts to redial a phone number when an
outgoing call fails.
Closed User Group (CUG)
This network service allows incoming and
outgoing calls to be restricted to a selected user
group. You can ctrate up to ten user groups.
Example
: A company lends SIM cards to its
employees and wants to restrict outgoing
calls to members of the same team.
Activating a closed user group
1. Press the
OK
key to put a check mark on the
Use user group
field.
2. Press the Down scroll key to move to the
Outside access
or
Default group
field. Use
the
OK
key to enable or disable calls to
numbers other than those in the Closed User
Group.
This feature depends on the nature of your
CUG subscription. Please check with your
service provider.
3. Press the Down scroll key to move to the
Group index
field and select the CUG index
you want to activate.
4. Press the
Save
soft key.
Settings
103
Now, you can select the number from the
Index field.
Managing the index list
You can add a new index and change or delete an
existing index.
1. On the Closed User Group screen, press the
Down scroll key to move to the
Group index
field.
2. Press the
OK
key to see the Group index list.
3. Press the Up or Down scroll key to select an
index and press the
Options
soft key.
The following options are available:
•
Select
: saves the current index list.
•
New index
: enter a new index name and
press the
Save
soft key.
•
Edit index
: allows you to change the
selected index.
•
Delete index
: deletes the selected index.
Video call settings
(Menu 9-5)
This menu allows you to select whether or not
the video camera is used when a video call is
received, or when you retry a failed or
interrupted video call (for example, when back
within 3G (UMTS) reception).
Show me
: allows you to set the video camera
use parameters when receiving an incoming
video call.
•
Always
: allows you to use the video camera
always.
•
Optionally
: allows you to select whether or
not the video camera is used.
Retry with
: allows you to set how to retry.
•
Voice call
: allows you to retry by voice call.
•
Camera
: allows you to send a multimedia
message using video footage.
•
None
: no retry.
Time & date
(Menu 9-6)
This menu allows you to set the current time and
date to display on the idle screen.
Settings
104
You can scroll through the clock options by
pressing the Up or Down scroll key. Set the
following options:
Time
: enter the current time. You can move the
cursor using the Left and Right scroll keys.
Highlight AM or PM (in 12 hour mode) and
change by pressing any of the number keys.
You can change the time format in the
Time
format
option below.
Date
: enter today’s date. You can move the
cursor back and forth between the input boxes
using the Left and Right scroll keys.
You can change the date format in the
Date
format
option below.
Time format
: select the time format using the
Left and Right scroll keys. You can choose from
12H
and
24H
.
Date format
: select the date format using the
Left and Right scroll keys. You can choose from:
- DD/MM/YYYY (day/month/year)
- MM/DD/YYYY (month/day/year)
- YYYY/DD/MM (year/day/month)
- YYYY/MM/DD (year/month/day)
Summer time
: allows you to activate daylight
savings time.
Network settings
(Menu 9-7)
In this menu, you can set options for Network of
your phone.
Network selection
The Network Selection feature enables you to
automatically or manually select the network
used when roaming outside of your home
network.
Note
: You can select a network other than your
home network only if it has a valid roaming
agreement with your home network.
Press the Up or Down scroll key until the
appropriate option highlights and then press the
Select
soft key.
If you select
Automatic
, you are connected to
the first available network when roaming.
If you select
Manual
, the phone scans for
available networks. Press the Up or Down scroll
Settings
105
key until the preferred network highlights and
then press the
Select
soft key. You are
connected to that network.
Network mode
The Network mode feature enables you to select
the network you use.
Press the Up or Down scroll key until the
appropriate option highlights and then press the
Select
soft key.
Automatic
,
GSM
, and
UMTS
are available.
If you select
Automatic
, the phone scans for
available networks.
If you select
GSM
, you can use the GSM
network.
If you select
UMTS
(3G network), you can get a
higher speech quality than on lower generation
networks, and use advanced data and
information services, such as video calls.
Otherwise you can’t use UMTS (3G network)
services.
Connections
(Menu 9-8)
You can set up information about your network
connection. In most cases, you don’t need to
change the settings. In case of problems, please
contact Vodafone customer service.
You can have several network settings. You can
make changes or rename each setting by
pressing the
Options
soft key.
When the
New
or
Edit
option is highlighted,
press the
OK
key to edit following options:
Set name
: allows you to edit the name of the
network setting.
Access name
: allows you to edit the access
point name used for the address of the GPRS
network gateway.
Auth type
: allows you to choose the type of
authentication used.
User ID
: allows you to edit the server login ID.
Password
: allows you to edit the server
password.
Protocol
: allows you to select the protocol from
among WAP, HTTP, and Other.
Settings
106
Home URL
: allows you to edit the MMS server
address.
Gateway address
(available only with the WAP
protocol): allows you to set the gateway address.
Proxy address/Port
(available only with the
HTTP protocol): allows you to set the proxy
server address and port.
Secure connection
(available only with the WAP
protocol): allows you to select On or Off.
Linger time
: allows you to set a time period
after which the network is disconnected if there
has been no new data traffic in that time.
Advanced settings
Static IP: you can specify if you want to manually
enter an IP address; see the Local phone IP
option. If you want the IP address to be
automatically assigned by the server, remove the
check mark.
Local phone IP: enter the IP address obtained
from the network operator, if you checked the
Static IP option.
Static DNS: you can specify if you want to
manually enter the DNS (Domain Name Server)
address; see the Server 1/2 option. If you want
the address to be automatically assigned by the
server, remove the check mark.
Server 1/2: enter the Domain Name Server
addresses.
Traffic class: select the traffic class, if you
selected the PS network.
Managing connections
You can add a new connection and edit or delete
an existing connection.
On the list of connections, press the Up or Down
key to select a connection and press the
Options
soft key.
The following options are available.
Edit
: allows you to edit the selected connection.
New
: allows you to add a new connection.
Rename
: allows you to change the name of the
selected connection.
Delete
: deletes the selected connection.
Settings
107
Security
(Menu 9-9)
The Security feature enables you to restrict the
use of your phone:
• to the people of your choice
• to certain types of calls
Various codes and passwords are used to protect
the features of your phone. They are described in
the following sections; see also pages 113 to
114.
Phone lock
When the Phone lock feature is enabled, the
phone is locked and you must enter a phone
password of between 4 and 8 digits each time
you switch the phone on.
Press the Up or Down scroll key to select
Enabled
or
Disabled
and press the
Save
soft
key.
When you select
Enabled
, the display asks you
to enter the phone password. Enter your
password and press the
Confirm
soft key.
To change the password, refer to the
Change
phone password
menu on page 108.
SIM lock
When the SIM lock feature is enabled, your
phone only works with the current SIM card. To
use another SIM card in your phone, you must
enter the SIM lock password set when you lock
the card.
Press the Up or Down scroll key to select
Enabled
or
Disabled
and press the
Save
soft
key.
When you select
Enabled
, the display asks you
to set a new password. Enter a password using
four to eight digits and press the
Confirm
soft
key.
PIN lock
When the PIN lock feature is enabled, you must
enter your PIN each time you switch the phone
on. Consequently, any person who does not have
your PIN cannot use your phone without your
approval.
Press the Up or Down scroll key to select
Enabled
or
Disabled
and press the
Save
soft
key.
Settings
108
When you select
Enabled
, the display asks you
to enter the PIN code. Enter your PIN code and
press the
Confirm
soft key.
The PIN code is supplied with your SIM card. To
change your PIN, refer to the
Change PIN
code
menu on page 109.
Fixed dialling mode
If the fixed dialling mode is supported by your
SIM card, you can restrict your outgoing calls to
the FDN (Fixed Dial Number) stored in the SIM
card memory.
Press the Up or Down scroll key to select
Enabled
or
Disabled
and press the
OK
soft key.
When you select
Enabled
, the display asks you
to enter the PIN2 code. Enter your PIN2 code and
press the
Confirm
soft key.
The PIN2 code is supplied with your SIM card. To
change your PIN2, refer to the
Change PIN2
code
menu on page 109.
Note
: Not all SIM cards have a PIN2. If your SIM
card does not, this menu option does not
display.
Change phone password
Using this menu option, you can change your
phone password to a new one.
1. Enter the current password and press the
Confirm
soft key.
2. Enter a new password and press the
Confirm
soft key.
3. Enter the new password again to confirm it
and press the
Confirm
soft key.
Privacy lock
This feature allows you to lock or unlock the
usage of the contents, such as messages,
pictures, and sounds.
1. Scroll to an item and place a check mark next
to it by pressing the
OK
key.
Selecting
All lock
places check marks on all
of the items except
All unlock
. Or, selecting
All unlock
removes all check marks except
All lock
.
2. If necessary, repeat step 1 to check another
item.
Settings
109
3. When you have finished checking, press the
Save
soft key.
4. When a confirming message appears, enter
your phone password and press the
Confirm
soft key to lock the content(s) selected.
Otherwise, press the
Back
soft key.
Change PIN code
This feature allows you to change your current
PIN to a new one, provided that the PIN lock
feature is enabled.
1. Enter the current PIN code and press the
Confirm
soft key.
2. Enter a new PIN code and press the
Confirm
soft key.
3. Enter the new code again to confirm it and
press the
Confirm
soft key.
Change PIN2 code
The Change PIN2 code feature allows you to
change your current PIN2 to a new one.
1. Enter the current PIN2 code and press the
Confirm
soft key.
2. Enter a new PIN2 code and press the
Confirm
soft key.
3. Enter the new code again to confirm it and
press the
Confirm
soft key.
Note
: Not all SIM cards have a PIN2. If your SIM
card does not, this menu does not display.
Own number
(Menu 9-0)
You can store your own phone number(s) with a
name in your SIM card.
1. Scroll to a number and press the
Select
soft
key.
2. Edit your name and number.
3. Press the
Save
soft key to save it.
If you want to cancel the setting, scroll to the
number field and press the
Back
soft key.
Settings
110
Memory status
(Menu 9- )
You can check the status of the memory in your
phone or your SIM card.
You can see the available memory space. You can
also check the memory used by several
applications.
Master reset
(Menu 9- )
This menu option allows you to reset your phone
to its default configuration.
1. When the display asks you to enter the phone
password, enter it and press the
Confirm
soft
key.
2. When you are asked to confirm your choice,
press the
Yes
soft key.
To exit the function without resetting the
settings, press the
No
soft key.
Your phone automatically turns off and then
back on.
111
Solving problems
Before contacting after-sales service, perform
the following simple checks. It may save you the
time and expense of an unnecessary service call.
When you switch your phone on, the
following messages may appear:
Insert SIM card
• Check that the SIM card is correctly installed.
Phone lock
• The Phone lock feature is enabled. You must
enter the phone password each time you
switch the phone on. To disable this feature,
use the
Phone lock
menu (Menu 9-7-1).
PIN lock
• You are using your phone for the first time.
You must enter the Personal Identification
Number supplied with the SIM card.
• The PIN lock feature is enabled. You must
enter the PIN each time you switch the phone
on. To disable this feature, use the
PIN lock
menu (Menu 9-7-3).
PUK lock
• The PIN was entered incorrectly three times in
succession and the phone is now blocked.
Enter the PUK provided by your network
operator (you may need to ask them for this).
No service
• The network connection has been lost. You
may be in a weak reception area (in a tunnel
or surrounded by buildings). Move and try
again.
• You are trying to access an option for which
you have not taken out a subscription with
your service provider. Contact the service
provider for further details.
You have entered a number but it was
not dialled
• Have you pressed the key?
• Are you accessing the right cellular network?
• You may have set an outgoing call barring
option.
Solving problems
112
The person calling cannot reach you
• Is your phone switched on (the key
pressed for more than one second)?
• Are you accessing the right cellular network?
• You may have set an incoming call barring
option.
The person calling cannot hear you
speaking
• Have you switched off the microphone (the
Mute icon ( ) appears)?
• Are you holding the phone close enough to
your mouth? The microphone is located at the
bottom of the phone.
The phone starts beeping and “Battery
Low” flashes on the display
• The battery is insufficiently charged. Recharge
it. See page 14.
The audio quality of the call is poor
• Check the signal strength indicator on the
display ( ); the number of bars indicates
the signal strength, from strong ( ) to
weak ( ).
• Try moving the phone slightly or moving closer
to a window if you are in a building.
No number is dialled when you recall a
contacts entry
• Check that the number has been stored
correctly, by using the Search contact feature.
• Edit and re-store the number, if necessary.
If the above guidelines do not help you to solve
the problem, take note of:
• The model and serial numbers of your phone
• Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung
after-sales service.
113
Access codes
There are several access codes that are used by
your phone and its SIM card. These codes help
you protect the phone against unauthorised use.
The access codes (except for the PUK and PUK2
codes) can be changed using the
Security
menu
(Menu 9-7). See page 107 for further details.
Phone password
The phone password can be used to avoid
unauthorised use of your phone. The default
password “00000000” (8 zeros) is usually
supplied with the phone. Change the password
before you start using your phone. Keep the new
password secret and in a safe place, separate
from the phone.
PIN
The PIN (Personal Identification Number)
protects your SIM card against unauthorised use.
It is usually supplied with the SIM card. When
the PIN lock feature is enabled (see page 107),
you must enter the PIN each time you switch on
the phone.
If you enter an incorrect PIN three times in
succession, enter the PUK obtained from your
network operator and press the
Confirm
soft
key to unlock the phone. Enter a new PIN and
press the
Confirm
soft key. Enter the new PIN
again and press the
Confirm
soft key.
PIN2
The PIN2, supplied with some SIM cards, is
required to access some functions, such as
charging unit counters. These functions are only
available if supported by your SIM card.
If you enter an incorrect PIN2 three times in
succession, enter the PUK2 and press the
Confirm
soft key to unlock the phone. Enter a
new PIN2 and press the
Confirm
soft key. Enter
the new PIN2 again and press the
Confirm
soft
key.
Access codes
114
PUK
The PUK (PIN Unblocking Key) is required to
change a blocked PIN. The PUK may be supplied
with the SIM card. If not, contact your local
service provider.
If you enter an incorrect PUK ten times in
succession, the SIM card cannot be used
anymore.
Contact your service provider for a new card.
You cannot change the PUK. If you lose the code,
contact your service provider.
PUK2
The PUK2, supplied with some SIM cards, is
required to change a blocked PIN2.
If you enter an incorrect PUK2 ten times in
succession, you cannot use the functions
requiring the PIN2. Contact your service provider
for a new card.
You cannot change the PUK2. If you lose the
code, contact your service provider.
Call barring password
The 4-digit call barring password is required
when you use the Call barring function. You
obtain the password from your service provider
when you subscribe to this function.
115
Health and safety
information
Exposure to Radio Frequency (RF)
Signals
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radio
frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S.
Government. These limits are part of
comprehensive guidelines and establish
permitted levels of RF energy for the general
population. The guidelines are based on the
safety standards that were developed by
independent scientific organizations through
periodic and through evaluation of scientific
studies.
The standards include a substantial safety
margin designed to assure the safety of all
persons, regardless of age and health.
The exposure standard for wireless phones
employs a unit of measurement known as
Specific Absorption Rate (SAR). The SAR limit set
by the FCC is 1.6W/kg
*
.
SAR tests are conducted using standard
operating positions specified by the FCC with the
phone transmitting at its highest certified power
level in all tested frequency bands. Although the
SAR is determined at the highest certified power
level, the actual SAR level of the phone while
operating can be well below the maximum value.
This is because the phone is designed to operate
at multiple power levels so as to use only the
power required to reach the network. In general,
the closer you are to a wireless base station
antenna, the lower the power output of the
phone.
Before a new model phone is available for sale to
the public, it must be tested and certified to the
FCC that it does not exceed the limit established
by the government-adopted requirement for safe
exposure. The tests are performed in positions
and locations (e.g., at the ear and worn on the
body) as required by the FCC for each model.
*In the U.S. and Canada, the SAR limit for mobile phones used
by the public is 1.6 watts/kg (W/kg)
averaged over one gram of tissue. The standard incorporates a
substantial margin of safety to give
additional protection for the public and to account for any
variations in measurements.
Health and safety information
116
While there may be differences between the SAR
levels of various phones and at various positions,
they all meet the government requirement.
The FCC has granted an Equipment Authorization
for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF
exposure guidelines. SAR information on this
model phone is on file with the FCC and can be
found under the Display Grant section of http://
www.fcc.gov/oet/fccid after searching on FCC ID
printed in the label on the phone.
FCC certification information for this model
phone is attached separation paper.
For Body Operation
To maintain compliance with FCC RF exposure
requirements, use only belt-clips, holsters or
similar accessories that maintain a 1.5 cm.
separation distance between the user's body and
the back of the phone, including the antenna.
The use of belt-clips, holsters and similar
accessories should not contain metallic components
in its assembly. The use of accessories that
do not satisfy these requirements may not
comply with FCC RF exposure requirements,
and should be avoided.
For more Information concerning exposure to
radio frequency signals, see the following
websites:
Federal Communications Commission (FCC)
http://www.fcc.gov/rfsafety
Cellular Telecommunications Industry Association
(CTIA):
http://www.wow-com.com
U.S.Food and Drug Administration (FDA)
http://www.fda.gov/cdrh/consumer
World Health Organization (WHO)
http://www.who.int/peh-emf/en
Precautions When Using Batteries
• Never use any charger or battery that is
damaged in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network’s base
station, it uses less power; talk and standby
time are greatly affected by the signal strength
Health and safety information
117
on the cellular network and the parameters set
by the network operator.
• Battery charging time depends on the
remaining battery charge and the type of
battery and charger used. The battery can be
charged and discharged hundreds of times, but
it will gradually wear out. When the operation
time (talk time and standby time) is noticeably
shorter than normal, it is time to buy a new
battery.
• If left unused, a fully charged battery will
discharge itself over time. Use only Samsung-
approved batteries and recharge your battery
only with Samsung-approved chargers. When
a charger is not in use, disconnect it from the
power source. Do not leave the battery
connected to a charger for more than a week,
since overcharging may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling
or warming first.
• Do not leave the battery in hot or cold places,
such as in a car in summer or winter
conditions, as you will reduce the capacity and
lifetime of the battery. Always try to keep the
battery at room temperature. A phone with a
hot or cold battery may temporarily not work,
even when the battery is fully charged. Li-ion
batteries are particularly affected by
temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental
shortcircuiting can occur when a metallic
object (coin, clip or pen) causes a direct
connection between the + and . terminals of
the battery (metal strips on the battery), for
example when you carry a spare battery in a
pocket or bag. Short-circuiting the terminals
may damage the battery or the object causing
the short-circuiting.
• Dispose of used batteries in accordance with
local regulations. Always recycle. Do not
dispose of batteries in a fire.
Road Safety
Your wireless phone gives you the powerful
ability to communicate by voice, almost
anywhere, anytime. But an important
responsibility accompanies the benefits of
wireless phones, one that every user must
uphold.
Health and safety information
118
When driving a car, driving is your first
responsibility. When using your wireless phone
behind the wheel of a car, practice good common
sense and remember the following tips.
1. Get to know your wireless phone and its
features, such as speed dial and redial. If
available, these features help you to place
your call without taking your attention off the
road.
2. When available, use a hands-free device. If
possible, add an extra layer of convenience
and safety to your wireless phone with one of
the many hands-free accessories available
today.
3. Position your wireless phone within easy
reach. Be able to access your wireless phone
without removing your eyes from the road. If
you get an incoming call at an inconvenient
time, let your voice mail answer it for you.
4. Let the person you are speaking with know
you are driving; if necessary, suspend the call
in heavy traffic or hazardous weather
conditions. Rain, sleet, snow, ice and even
heavy traffic can be hazardous.
5. Do not take notes or look up phone numbers
while driving. Jotting down a To Do list or
flipping through your phonebook takes your
attention away from your primary
responsibility, driving safely.
6. Dial sensibly and assess the traffic; if
possible, place calls when you are not moving
or before pulling into traffic. Try to plan calls
when your car will be stationary. If you need
to make a call while moving, dial only a few
numbers, check the road and your mirrors,
then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Make
the people with whom you are talking aware
that you are driving and suspend
conversations that have the potential to divert
your attention from the road.
8. Use your wireless phone to call for help. Dial
the emergency number in the case of fire,
traffic accident or medical emergencies.
Remember, it is a free call on your wireless
phone!
9. Use your wireless phone to help others in
emergencies. If you see a car accident, crime
Health and safety information
119
in progress or other serious emergency where
lives are in danger, call the emergency
number, as you would want others to do for
you.
10. Call roadside assistance or a special
nonemergency wireless assistance number
when necessary. If you see a broken-down
vehicle posing no serious hazard, a broken
traffic signal, a minor traffic accident where
no one appears injured, or a vehicle you know
to be stolen, call roadside assistance or any
other special nonemergency wireless number.
Operating Environment
Remember to follow any special regulations in
force in any area and always switch off your
phone whenever it is forbidden to use it, or when
it may cause interference or danger.
When connecting the phone or any accessory to
another device, read its user°Øs guide for
detailed safety instructions. Do not connect
incompatible products.
As with other mobile radio transmitting
equipment, users are advised that for the
satisfactory operation of the equipment and for
the safety of personnel, it is recommended that
the equipment should only be used in the normal
operating position (held to your ear with the
antenna pointing over your shoulder).
Electronic Devices
Most modern electronic equipment is shielded
from radio frequency (RF) signals. However,
certain electronic equipment may not be shielded
against the RF signals from your wireless phone.
Consult the manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference with
the pacemaker. These recommendations are
consistent with the independent research and
recommendations of Wireless Technology
Research.
Persons with pacemakers:
• Should always keep the phone more than 15
cm (6 inches) from their pacemaker when the
phone is switched on
Health and safety information
120
• Should not carry the phone in a breast pocket
• Should use the ear opposite the pacemaker to
minimize potential interference
If you have any reason to suspect that
interference is taking place, switch off your
phone immediately.
Hearing Aids
Some digital wireless phones may interfere with
some hearing aids. In the event of such
interference, you may wish to consult your
hearing aid manufacturer to discuss alternatives.
Other Medical Devices
If you use any other personal medical devices,
consult the manufacturer of your device to
determine if it is adequately shielded from
external RF energy. Your physician may be able
to assist you in obtaining this information. Switch
off your phone in health care facilities when any
regulations posted in these areas instruct you to
do so. Hospitals or health care facilities may be
using equipment that could be sensitive to
external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in
motor vehicles. Check with the manufacturer or
its representative regarding your vehicle. You
should also consult the manufacturer of any
equipment that has been added to your vehicle.
Posted Facilities
Switch off your phone in any facility where
posted notices require you to do so.
Potentially Explosive Atmospheres
Switch off your phone when in any area with a
potentially explosive atmosphere and obey all
signs and instructions. Sparks in such areas
could cause an explosion or fire resulting in
bodily injury or even death.
Users are advised to switch off the phone while
at a refueling point (service station). Users are
reminded of the need to observe restrictions on
the use of radio equipment in fuel depots (fuel
storage and distribution areas), chemical plants
or where blasting operations are in progress.
Health and safety information
121
Areas with a potentially explosive atmosphere
are often but not always clearly marked. They
include below deck on boats, chemical transfer or
storage facilities, vehicles using liquefied
petroleum gas (such as propane or butane),
areas where the air contains chemicals or
particles, such as grain, dust or metal powders,
and any other area where you would normally be
advised to turn off your vehicle engine.
Emergency Calls
This phone, like any wireless phone, operates
using radio signals, wireless and landline
networks as well as user-programmed functions,
which cannot guarantee connection in all
conditions. Therefore, you should never rely
solely on any wireless phone for essential
communications (medical emergencies, for
example).
Remember, to make or receive any calls the
phone must be switched on and in a service area
with adequate signal strength. Emergency calls
may not be possible on all wireless phone
networks or when certain network services and/
or phone features are in use. Check with local
service providers.
To make an emergency call, proceed as follows.
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location. Emergency numbers vary by location.
3. Press the <SEND> key.
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular
service provider.
When making an emergency call, remember to
give all the necessary information as accurately
as possible. Remember that your phone may be
the only means of communication at the scene of
an accident; do not cut off the call until given
permission to do so.
Other Important Safety
Information
• Only qualified personnel should service the
phone or install the phone in a vehicle. Faulty
installation or service may be dangerous and
may invalidate any warranty applicable to the
device.
Health and safety information
122
• Check regularly that all wireless phone
equipment in your vehicle is mounted and
operating properly.
• Do not store or carry flammable liquids, gases
or explosive materials in the same
compartment as the phone, its parts or
accessories.
• For vehicles equipped with an air bag,
remember that an air bag inflates with great
force. Do not place objects, including both
installed or portable wireless equipment in the
area over the air bag or in the air bag
deployment area. If wireless equipment is
improperly installed and the air bag inflates,
serious injury could result.
• Switch off your phone before boarding an
aircraft. The use of wireless phones in aircraft
may be dangerous to the operation of the
aircraft, and is illegal.
• Failure to observe these instructions may lead
to the suspension or denial of telephone
services to the offender, or legal action, or
both.
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care.
The suggestions below will help you fulfill any
warranty obligations and allow you to enjoy this
product for many years.
• Keep the phone and all its parts and
accessories out of the reach of small children’s.
• Keep the phone dry. Precipitation, humidity
and liquids contain minerals that will corrode
electronic circuits.
• Do not touch the phone with a wet hand while
it is charging. Doing so may cause an electric
shock to you or damage to the phone.
• Do not use or store the phone in dusty, dirty
areas, as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the
phone, which may damage the phone°Øs
electronic circuit board.
Health and safety information
123
• Do not drop, knock or shake the phone.
Roughhandling can break internal circuit
boards.
• Do not use harsh chemicals, cleaning solvents
or strong detergents to clean the phone. Wipe
it with a soft cloth slightly dampened in a mild
soap-and-water solution.
• Do not paint it. Paint can clog the device’s
moving parts and prevent proper operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a
radiator. The phone may explode when
overheated.
• Use only the supplied or an approved
replacement antenna. Unauthorized antennas
or modified accessories may damage the
phone and violate regulations governing radio
devices.
• If the phone, battery, charger or any accessory
is not working properly, take it to your nearest
qualified service facility. The personnel there
will assist you, and if necessary, arrange for
service.
Acknowledging Special Precautions
and the FCC and Industry Canada
Notice
Cautions
Modifications not expressly approved by the
party responsible for compliance could void the
user's authority to operate the equipment.
FCC
Compliance Information
.
This device complies with Part 15 of FCC Rules.
Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and
(2) This device must accept any interference
received.
Including interference that may cause undesired
operation.
Information to User
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable
protection against harmful interference in a
Health and safety information
124
residential installation.
This equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of
the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/ TV
technician for help.
125
Appendix
Appendix A: CERTIFICATION
INFORMATION (SAR)
THIS MODEL PHONE MEETS THE
GOVERNMENT’S REQUIREMENTS FOR
EXPOSURE TO RADIO WAVES.
Your wireless phone is a radio transmitter and
receiver. It is designed and manufactured not to
exceed the emission limits for exposure to radio
frequency(RF) energy set by the Federal
Communications Commission of the U.S.
Government. These limits are part of
comprehensive guidelines and establish
permitted levels of RF energy for the general
population. The guidelines are based on safety
standards that were developed by independent
scientific organizations through periodic and
thorough evaluation of scientific studies. The
standards include a substantial safety margin
designed to assure the safety of all persons,
regardless of age and health.
The exposure standard for wireless mobile
phones employs a unit of measurement known
as the Specific Absorption Rate(SAR). The SAR
limit set by the FCC is 1.6 W/kg
**
. SAR Tests are
conducted using standard operating positions
accepted by the FCC with the phone transmitting
at its highest certified power level in all tested
frequency bands. Although the SAR is
determined at the highest certified power level,
the actual SAR level of the phone while operating
can be well below the maximum value. This is
because the phone is designed to operate at
multiple power levels so as to use only the power
required to reach the network. In general, the
closer you are to a wireless base station
antenna, the lower the power output.
Before a new model phone is available for sale to
the public, it must be tested and certified to the
FCC that it does not exceed the limit established
by the governmentadopted requirement for safe
exposure. The tests are performed in positions
**In the United States and Canada, the SAR limit for
mobile phones used by the public is 1.6 watts/kilogram(W/kg)
averaged over one gram of tissue.
The standard incorporates a substantial margin of safety
to give additional protection for the public and to
account for any variations in measurements.
Appendix
126
and locations(e.g., at the ear and worn on the
body) as required by the FCC for each model.
The highest SAR values for this model phone as
reported to the FCC are Head: 0.648W/Kg, Body-
worn: 0.509W/Kg.
The FCC has granted an Equipment Authorization
for this model phone with all reported SAR levels
evaluated as in compliance with the FCC RF
exposure guidelines. SAR information on this
model phone is on file with the FCC and can be
found under the Display Grant section of http://
www.fcc.gov/oet/fccid after searching on FCC ID
A3LSGHZ500.
Appendix B: Guide to Safe and
Responsible Wireless Phone Use
Cellular Telecommunications & Internet
Association “Safety is the most important call
you will ever make.” A Guide to Safe and
Responsible Wireless Phone Use
TENS OF MILLIONS OF PEOPLE IN THE U.S.
TODAY TAKE ADVANTAGE OF THE UNIQUE
COMBINATION OF CONVENIENCE, SAFETY AND
VALUE DELIVERED BY THE WIRELESS
TELEPHONE. QUITE SIMPLY, THE WIRELESS
PHONE GIVES PEOPLE THE POWERFUL ABILITY
TO COMMUNICATE BY VOICE-ALMOST
ANYWHERE, ANYTIME-WITH THE BOSS, WITH A
CLIENT, WITH THE KIDS, WITH EMERGENCY
PERSONNEL OR EVEN WITH THE POLICE. EACH
YEAR, AMERICANS MAKE BILLIONS OF CALLS
FROM THEIR WIRELESS PHONES, AND THE
NUMBERS ARE RAPIDLY GROWING.
But an important responsibility accompanies
those benefits, one that every wireless phone
user must uphold. When driving a car, driving is
your first responsibility. A wireless phone can be
an invaluable tool, but good judgment must be
exercised at all times while driving a motor
vehicle-whether on the phone or not.
Appendix
127
The basic lessons are ones we all learned as
teenagers. Driving requires alertness, caution
and courtesy. It requires a heavy dose of basic
common sense-keep your head up, keep your
eyes on the road, check your mirrors frequently
and watch out for other drivers. It requires
obeying all traffic signs and signals and staying
within the speed limit. It means using seatbelts
and requiring other passengers to do the same.
But with wireless phone use, driving safely
means a little more. This brochure is a call to
wireless phone users everywhere to make safety
their first priority when behind the wheel of a car.
Wireless telecommunications is keeping us in
touch, simplifying our lives, protecting us in
emergencies and providing opportunities to help
others in need. When it comes to the use of
wireless phones, safety is your most important
call.
Wireless Phone “Safety Tips”
Below are safety tips to follow while driving and
using a wireless phone which should be easy to
remember.
1. Get to know your wireless phone and its
features such as speed dial and redial. Carefully
read your instruction manual and learn to take
advantage of valuable features most phones
offer, including automatic redial and memory.
Also, work to memorize the phone keypad so you
can use the speed dial function without taking
your attention off the road.
2. When available, use a hands free device. A
number of hands free wireless phone accessories
are readily available today. Whether you choose
an installed mounted device for your wireless
phone or a speaker phone accessory, take
advantage of these devices if available to you.
3. Position your wireless phone within easy
reach. Make sure you place your wireless phone
within easy reach and where you can grab it
without removing your eyes from the road. If you
get an incoming call at an inconvenient time, if
possible, let your voice mail answer it for you.
4. Suspend conversations during hazardous
driving conditions or situations. Let the person
you are speaking with know you are driving; if
necessary, suspend the call in heavy traffic or
hazardous weather conditions. Rain, sleet, snow
and ice can be hazardous, but so is heavy traffic.
As a driver, your first responsibility is to pay
attention to the road.
Appendix
128
5. Do not take notes or look up phone numbers
while driving. If you are reading an address book
or business card, or writing a “to do” list while
driving a car, you are not watching where you are
going. It’s common sense. Don’t get caught in a
dangerous situation because you are reading or
writing and not paying attention to the road or
nearby vehicles.
6. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan your calls before
you begin your trip or attempt to coincide your
calls with times you may be stopped at a stop
sign, red light or otherwise stationary. But if you
need to dial while driving, follow this simple tip-
dial only a few numbers, check the road and your
mirrors, then continue.
7. Do not engage in stressful or emotional
conversations that may be distracting. Stressful
or emotional conversations and driving do not
mix-they are distracting and even dangerous
when you are behind the wheel of a car. Make
people you are talking with aware you are driving
and if necessary, suspend conversations which
have the potential to divert your attention from
the road.
8. Use your wireless phone to call for help. Your
wireless phone is one of the greatest tools you
can own to protect yourself and your family in
dangerous situationswith your phone at your
side, help is only three numbers away. Dial 9-1-1
or other local emergency number in the case of
fire, traffic accident, road hazard or medical
emergency. Remember, it is a free call on your
wireless phone!
9. Use your wireless phone to help others in
emergencies. Your wireless phone provides you a
perfect opportunity to be a “Good Samaritan” in
your community. If you see an auto accident,
crime in progress or other serious emergency
where lives are in danger, call 9-1-1 or other
local emergency number, as you would want
others to do for you.
10. Call roadside assistance or a special wireless
nonemergency assistance number when
necessary. Certain situations you encounter while
driving may require attention, but are not urgent
enough to merit a call for emergency services.
But you still can use your wireless phone to lend
a hand. If you see a broken-down vehicle posing
no serious hazard, a broken traffic signal, a
minor traffic accident where no one appears
injured or a vehicle you know to be stolen, call
Appendix
129
roadside assistance or other special non-
emergency wireless number. Careless, distracted
individuals and people driving irresponsibly
represent a hazard to everyone on the road.
Since 1984, the Cellular Telecommunications
Industry Association and the wireless industry
have conducted educational outreach to inform
wireless phone users of their responsibilities as
safe drivers and good citizens. As we approach a
new century, more and more of us will take
advantage of the benefits of wireless telephones.
And, as we take to the roads, we all have a
responsibility to drive safely.
“The wireless industry reminds you to use your
phone safely when driving.”
Cellular Telecommunications & Internet
Association For more information, please call 1-
888-901-SAFE.
For updates: http://www.wowcom.com/
consumer/issues/driving/articles.cfm?ID=85
Appendix C: Consumer Update on
Wireless Phones
U.S. Food and Drug Administration
1. What kinds of phones are the subject of this
update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often
called cell, mobile, or PCS phones. These types of
wireless phones can expose the user to
measurable radiofrequency energy (RF) because
of the short distance between the phone and the
user s head. These RF exposures are limited by
Federal Communications Commission safety
guidelines that were developed with the advice of
FDA and other federal health and safety
agencies. When the phone is located at greater
distances from the user, the exposure to RF is
drastically lower because a person’s RF exposure
decreases rapidly with increasing distance from
the source. The so-called “cordless phones,”
which have a base unit connected to the
telephone wiring in a house, typically operate at
far lower power levels, and thus produce RF
Appendix
130
exposures well within the FCC’s compliance
limits.
2. Do wireless phones pose a health hazard?
The available scientific evidence does not show
that any health problems are associated with
using wireless phones. There is no proof,
however, that wireless phones are absolutely
safe. Wireless phones emit low levels of
radiofrequency energy (RF) in the microwave
range while being used. They also emit very low
levels of RF when in the stand-by mode. Whereas
high levels of RF can produce health effects (by
heating tissue), exposure to low level RF that
does not produce heating effects causes no
known adverse health effects. Many studies of
low level RF exposures have not found any
biological effects. Some studies have suggested
that some biological effects may occur, but such
findings have not been confirmed by additional
research. In some cases, other researchers have
had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
3. What is FDA’s role concerning the safety of
wireless phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as
wireless phones before they can be sold, as it
does with new drugs or medical devices.
However, the agency has authority to take action
if wireless phones are shown to emit
radiofrequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could
require the manufacturers of wireless phones to
notify users of the health hazard and to repair,
replace or recall the phones so that the hazard
no longer exists.
Although the existing scientific data do not justify
FDA regulatory actions, FDA has urged the
wireless phone industry to take a number of
steps, including the following:
Support needed research into possible biological
effects of RF of the type emitted by wireless
phones; Design wireless phones in a way that
minimizes any RF exposure to the user that is not
necessary for device function; and Cooperate in
providing users of wireless phones with the best
possible information on possible effects of
wireless phone use on human health FDA belongs
to an interagency working group of the federal
agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts
at the federal level. The following agencies
belong to this working group:
Appendix
131
National Institute for Occupational Safety and
Health Environmental Protection Agency Federal
Communications Commission Occupational
Safety and Health Administration National
Telecommunications and Information
Administration
The National Institutes of Health participates in
some interagency working group activities, as
well.
FDA shares regulatory responsibilities for
wireless phones with the Federal
Communications Commission (FCC). All phones
that are sold in the United States must comply
with FCC safety guidelines that limit RF exposure.
FCC relies on FDA and other health agencies for
safety questions about wireless phones.
FCC also regulates the base stations that the
wireless phone networks rely upon. While these
base stations operate at higher power than do
the wireless phones themselves, the RF
exposures that people get from these base
stations are typically thousands of times lower
than those they can get from wireless phones.
Base stations are thus not the primary subject of
the safety questions discussed in this document.
4. What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around
the world to ensure that high priority animal
studies are conducted to address important
questions about the effects of exposure to
radiofrequency energy (RF). FDA has been a
leading participant in the World Health
Organization International Electromagnetic Fields
(EMF) Project since its inception in 1996. An
influential result of this work has been the
development of a detailed agenda of research
needs that has driven the establishment of new
research programs around the world. The Project
has also helped develop a series of public
information documents on EMF issues.
FDA and the Cellular Telecommunications &
Internet Association (CTIA) have a formal
Cooperative Research and Development
Agreement (CRADA) to do research on wireless
phone safety. FDA provides the scientific
oversight, obtaining input from experts in
government, industry, and academic
organizations. CTIA-funded research is
conducted through contracts to independent
Appendix
132
investigators. The initial research will include
both laboratory studies and studies of wireless
phone users. The CRADA will also include a broad
assessment of additional research needs in the
context of the latest research developments
around the world.
5. What steps can I take to reduce my exposure
to radiofrequency energy from my wireless
phone?
If there is a risk from these products.and at this
point we do not know that there is.it is probably
very small. But if you are concerned about
avoiding even potential risks, you can take a few
simple steps to minimize your exposure to
radiofrequency energy (RF). Since time is a key
factor in how much exposure a person receives,
reducing the amount of time spent using a
wireless phone will reduce RF exposure.
If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of
the RF, since the exposure level drops off
dramatically with distance. For example, you
could use a headset and carry the wireless phone
away from your body or use a wireless phone
connected to a remote antenna.
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are
concerned about the RF exposure from these
products, you can use measures like those
described above to reduce your RF exposure
from wireless phone use.
6. What about children using wireless phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower
exposure to radiofrequency energy (RF), the
measures described above would apply to
children and teenagers using wireless phones.
Reducing the time of wireless phone use and
increasing the distance between the user and the
RF source will reduce RF exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at all.
For example, the government in the United
Kingdom distributed leaflets containing such a
recommendation in December 2000. They noted
that no evidence exists that using a wireless
phone causes brain tumors or other ill effects.
Their recommendation to limit wireless phone
use by children was strictly precautionary; it was
Appendix
133
not based on scientific evidence that any health
hazard exists.
7. Do hands-free kits for wireless phones reduce
risks from exposure to RF emissions?
Since there are no known risks from exposure to
RF emissions from wireless phones, there is no
reason to believe that hands-free kits reduce
risks. Hands-free kits can be used with wireless
phones for convenience and comfort. These
systems reduce the absorption of RF energy in
the head because the phone, which is the source
of the RF emissions, will not be placed against
the head. On the other hand, if the phone is
mounted against the waist or other part of the
body during use, then that part of the body will
absorb more RF energy. Wireless phones
marketed in the U.S. are required to meet safety
requirements regardless of whether they are
used against the head or against the body. Either
configuration should result in compliance with
the safety limit.
8. Do wireless phone accessories that claim to
shield the head from RF radiation work?
Since there are no known risks from exposure to
RF emissions from wireless phones, there is no
reason to believe that accessories that claim to
shield the head from those emissions reduce
risks. Some products that claim to shield the user
from RF absorption use special phone cases,
while others involve nothing more than a metallic
accessory attached to the phone. Studies have
shown that these products generally do not work
as advertised. Unlike “hand-free” kits, these so-
called “shields” may interfere with proper
operation of the phone. The phone may be forced
to boost its power to compensate, leading to an
increase in RF absorption. In February 2002, the
Federal trade Commission (FTC) charged two
companies that sold devices that claimed to
protect wireless phone users from radiation with
making false and unsubstantiated claims.
According to FTC, these defendants lacked a
reasonable basis to substantiate their claim.
9. What about wireless phone interference with
medical equipment?
Radiofrequency energy (RF) from wireless
phones can interact with some electronic devices.
For this reason, FDA helped develop a detailed
test method to measure electromagnetic
interference (EMI) of implanted cardiac
pacemakers and defibrillators from wireless
Appendix
134
telephones. This test method is now part of a
standard sponsored by the Association for the
Advancement of Medical instrumentation (AAMI).
The final draft, a joint effort by FDA, medical
device manufacturers, and many other groups,
was completed in late 2000. This standard will
allow manufacturers to ensure that cardiac
pacemakers and defibrillators are safe from
wireless phone EMI.
FDA has tested hearing aids for interference from
handheld wireless phones and helped develop a
voluntary standard sponsored by the Institute of
Electrical and Electronic Engineers (IEEE). This
standard specifies test methods and performance
requirements for hearing aids and wireless
phones so that that no interference occurs when
a person uses a compatible phone and a
compatible hearing aid at the same time. This
standard was approved by the IEEE in 2000. FDA
continues to monitor the use of wireless phones
for possible interactions with other medical
devices. Should harmful interference be found to
occur, FDA will conduct testing to assess the
interference and work to resolve the problem.
10. What are the results of the research done
already?
The research done thus far has produced
conflicting results, and many studies have
suffered from flaws in their research methods.
Animal experiments investigating the effects of
radiofrequency energy (RF) exposures
characteristic of wireless phones have yielded
conflicting results that often cannot be repeated
in other laboratories. A few animal studies,
however, have suggested that low levels of RF
could accelerate the development of cancer in
laboratory animals. However, many of the studies
that showed increased tumor development used
animals that had been genetically engineered or
treated with cancer-causing chemicals so as to
be pre-disposed to develop cancer in the absence
of RF exposure. Other studies exposed the
animals to RF for up to 22 hours per day. These
conditions are not similar to the conditions under
which people use wireless phones, so we don t
know with certainty what the results of such
studies mean for human health.
Three large epidemiology studies have been
published since December 2000. Between them,
the studies investigated any possible association
between the use of wireless phones and primary
brain cancer, glioma, meningioma, or acoustic
neuroma, tumors of the brain or salivary gland,
leukemia, or other cancers. None of the studies
Appendix
135
demonstrated the existence of any harmful
health effects from wireless phone RF exposures.
However, none of the studies can answer
questions about long-term exposures, since the
average period of phone use in these studies was
around three years.
11. What research is needed to decide whether
RF exposure from wireless phones poses a health
risk?
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data
that are needed. Lifetime animal exposure
studies could be completed in a few years.
However, very large numbers of animals would
be needed to provide reliable proof of a cancer
promoting effect if one exists. Epidemiological
studies can provide data that is directly
applicable to human populations, but 10 or more
years follow-up may be needed to provide
answers about some health effects, such as
cancer. This is because the interval between the
time of exposure to a cancer-causing agent and
the time tumors develop - if they do - may be
many, many years. The interpretation of
epidemiological studies is hampered by
difficulties in measuring actual RF exposure
during day-to-day use of wireless phones. Many
factors affect this measurement, such as the
angle at which the phone is held, or which model
of phone is used.
12. Which other federal agencies have
responsibilities related to potential RF health
effects?
Additional information on the safety of RF
exposures from various sources can be obtained
from the following organizations.
FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
Occupational Safety and Health Administration’s
(OSHA):
http://www.oshaslc.gov/SLTC/
radiofrequencyradiation/index.html
National Institute for Occupational Safety and
Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
Appendix
136
World health Organization (WHO):
http://www.who.int/peh-emf/
International Commission on Non-Ionizing
Radiation Protection:
http://www.icnirp.de
National Radiation Protection Board (UK):
http://www.nrpb.org.uk
***
***Updated 4/3/2002: US Food and Drug Administration
http://www.fda.gov/cellphones
137
Index
A
ABC mode, text input 32, 34
Access codes 113
Active folder 98
Alarm 52
Alert tone
call 94
effect 95
feedback 95
message 95
Alert type
call 94
message 95
Anniversary 81
Answering a call 23
Anykey answer 98
Applications
downloading 88
memory status 110
switching 20
Auto redial 102
B
Background image 96
Backlight 97
Barring password 114
Barring, calls 100
Battery
charging 15
installing 14
low battery indicator 16
precautions 116
removing 15
Battery charger 16
Bookmark 44
Brightness
LCD 97
picture 73
video 72
Browser
menus 43
navigating 43
C
Calculator 52
Calendar 79
Call costs 90
Call log
all 89
dialled 89
missed 89
received 89
Call times 90
Caller ID 99
Calls
answering 23
barring 100
diverting 99
ending 23
holding 24
making 21
rejecting 23
waiting 101
Camera 69
camera mode, set 72
recording videos 70
taking pictures 69
video mode, set 72
Characters, enter 32
Charging a battery 15
Clock
digital clock 96
world clock 52
Closed user group (CUG) 102
Conference call 27
Contacts
adding 85
groups 91
memory status 110
searching 84
viewing 87
Converter 47
CUG 102
Index
138
D
Deleting
calendar event 79
call log 89
contact 84
E-mail 62
image file 76
melody/tone 77
message 60
multimedia files 75
picture 70
today’s event 80
video 71
Dialled calls 89
Display
brightness 97
external 12
icons 11
layout 10
settings 96
Diverting, calls 99
Drafts 60
DTMF tones 25
E
Effect tones 95
Email 61
Emergency call 6, 119
Ending a call 23
External display 12
setting 96
External light 12
F
FDN mode 108
Forwarding
e-mail 61
messages 60
G
Greeting message 96
Groups, contacts 91
H
Health and safety 115
Holding, calls 24
I
Icons, description 11
Image files 75
Inbox 59
International call 21
K
Key tone 24
Keys
description 9
location 8
L
Language 97
Locking
Phone 107
PIN 107
privacy 108
SIM 107
Low battery indicator 16
M
Maintenance 120
Media Album 62
Media player 47
Memo 83
Menu style 97
Menus
accessing 37
list 40
Messages 53
creating 53
drafts 60
Email 58
inbox 59
memory status 68
MMS templates 58
multimedia 53
outbox 61
postcard 57
settings 64
Index
139
templates 63
text 53
Microphone, mute 29
Missed calls 89
MMS (Multimedia Message
Service) 53
MMS postcard 57
Multimedia files 74
Multimedia message 53
My contact detail 92
My items 74
N
Names
searching/dialling 84
storing 85
Number mode, text input 32, 36
Numbers, phone
searching/dialling 84
storing 85
O
On/Off switch 17
Organiser 79
Own number 109
P
Password
barring 101, 114
phone 108, 113
Phone
care and mainenance 120
display 10
icons 11
keys 9
layout 8
locking 107
master reset 110
password 108, 113
safety information 115
switching on/off 17
unpacking 7
Pictures, take 69
PIN 109, 113
PIN lock 107
PIN2 109, 113
Problems, solve 110
Profiles 94
PUK 114
PUK2 114
R
Received calls 89
Rejecting a call 23
Reset settings 110
Resetting phone 110
Ringtone 94
Ringtones files 77
Road safety 117
S
Safety
information 115
precautions 5
road 117
SAT 47
Schedule 80
Security 107
Sendbox 61
Settings 94
browser 45
call 99
capture mode 73
date & time 104
display 96
media player 49
message 64
network 104
phone 97
record mode 72
security 107
sounds 94
Short cuts 98
SIM card
inserting 13
locking 107
removing 14
SIM-AT 47
SMS (Short Message Service) 53
Solving problems 110
Index
140
Sound mode 94
Speed dial 91
Swiching on/off
microphone 29
phone 17
Symbol mode, text input 32, 36
T
T9 mode, text input 32, 33
Task list 82
Template message 63
Text input modes 32
Text message 56
Text, enter 32
Time, set 104
Today’s event 80
Tone volume 95
Tones
call connect tone 95
call end tone 95
effect sounds 95
folder open/close 95
key tones 95
minute minder 95
popup box alerts 95
power on 95
ringtone 94
Travel charger 15
U
Unpacking 7
V
Video call 29
making 29
options 30
PIP 30
receiving 30
Video files 76
Videos, record 70
Vodafone messenger 62
Voice mail 68
Volume, adjust
alert tones 95
earpiece 24
key tone 24, 95
W
Waiting call 26
Wake up alarm 52
Wallpaper 96
WAP browser
setting 45
