SGHZ720 User Manual HTML Version

Users Manual

World Wide Web

http://www.samsungmobile.com

Printed in Korea

Code No.:GH68-xxxxxA

English (EU). 09/2006. Rev. 1.0

* Depending on the software installed or your service provider or country, some of the

descriptions in this guide may not match your phone exactly.

* Depending on your country, your phone and accessories may appear different from the

illustrations in this guide.

SGH-Z720

User’s Guide

Draft 03

2006.09.11

Version : Z720XAFH2

Important

safety

precautions

Failure to comply with the following

precautions may be dangerous or

illegal.

Use road safety at all times

Do not use a hand-held phone while driving.

Park the vehicle first.

Switch off the phone when refuelling

Do not use the phone at a refuelling point

(service station) or near fuels or chemicals.

Switch off in an aircraft

Wireless phones can cause interference.

Using them in an aircraft is both illegal and

dangerous.

Switch off the phone near all medical

equipment

Hospitals or health care facilities may be

using equipment that could be sensitive to

external radio frequency energy. Follow any

regulations or rules in force.

Interference

All wireless phones may be subject to

interference, which could affect their

performance.

Important safety precautions

Be aware of special regulations

Meet any special regulations in force in any

area and always switch off your phone

whenever it is forbidden to use it, or when it

may cause interference or danger.

Water resistance

Your phone is not water-resistant. Keep it

dry.

Sensible use

Use only in the normal position (held to the

ear). Avoid unnecessary contact with the

antenna when the phone is switched on.

Emergency calls

Key in the emergency number for your

present location, then press .

Keep your phone away from small

children

Keep the phone and all its parts, including

accessories, out of the reach of small

children.

Accessories and batteries

Use only Samsung-approved batteries and

accessories, such as headsets and PC data

cables. Use of any unauthorised accessories

could damage you or your phone and may

be dangerous.

Qualified service

Only qualified service personnel may repair

your phone.

For more detailed safety information, see

"Health and safety information" on page

114.

• The phone could explode if the battery is

replaced with an incorrect type.

• Dispose of used batteries according to the

manufacturer’s instructions.

At very high volume, prolonged

listening to a headset can damage

your hearing.

About this Guide

This User’s Guide provides you with

condensed information about how to use

your phone. To quickly learn the basics for

your phone, please refer to “Get started”

and “Step outside the phone.”

In this guide, the following instruction icons

appear:

Indicates that you need to pay

careful attention to the subsequent

information regarding safety or

phone features.



Indicates that you can get more

information on the referenced page.

→

Indicates that you need to press the

Navigation keys to scroll to the

specified option and then select it.

[

] Indicates a key on the phone.

For example,

[]

> Indicates a soft key, whose function

is displayed on the phone screen.

For example, <

Select

•3G

Your phone is capable of

operating in a 3G

environment, allowing

much greater data transfer

speed, video streaming,

and video conferencing.

Special

features of your phone

• Camera and camcorder

Use the camera module on

your phone to take a photo

or record a video.

• Media player

Play media files on your

phone. You can enjoy high

quality videos and music.

Special features of your phone

•Bluetooth

Transfer media files and

personal data and connect

to other devices using free,

wireless Bluetooth

technology.

•Web browser

Access the wireless web to

get up-to-the-minute

information and a wide

variety of media content.

• Get personal with photo

caller ID

See who’s calling you with

their very own photo

displays.

• Name card

Create name cards with

your number and profile.

Whenever introducing

yourself to others, use this

convenient electronic name

card.

• File viewer

Open documents in various

formats on the phone

without corruption.

• Multimedia Message

Service (MMS)

Send and receive MMS

messages with a

combination of text,

images, video, and audio.

•E-mail

Send and receive e-mails

with image, video, and

audio attachments.

•Java

Enjoy Java

™

-based

embedded games and

download new games.

•Calendar

Keep track of your daily,

weekly, and monthly

schedule.

Contents

Unpack 6

Make sure you have each item

Your phone 6

Keys, features, and locations

Get started 7

First steps to operating your phone

Install and charge the phone ...................... 7

Power on or off......................................... 8

Keys and display ...................................... 9

Access menu functions ............................ 12

Customise your phone............................. 13

Make/Answer calls .................................. 15

Step outside the phone 16

Begin with your camera, the media player, the

web, and other special features

Use the camera ...................................... 16

Play music ............................................. 17

Browse the web...................................... 18

Use Contacts.......................................... 19

Send messages ...................................... 20

View messages....................................... 22

Use Bluetooth ......................................... 23

Switch applications .................................. 24

Use a memory card ................................. 25

Enter text 27

ABC, T9, Number, and Symbol modes

Call functions 29

Advanced calling features

Menu functions 35

All menu options listed

Solve problems 112

Help and personal needs

Health and safety information 114

Index 136

1 Call log



p. 35

2 Contacts



p. 37

3 Media player



p. 42

4 Browser



p. 48

1 Go to Homepage

2 Enter URL

3 Bookmarks

4 Saved pages

5 History

6 Advanced

7 Browser Settings



p. 48



p. 50



p. 50



p. 51



p. 51



p. 51



p. 52

5 Messaging



p. 52

1 Create New Message

2 Inbox

3 Email inbox

4 Drafts

5 Outbox

6 Sentbox

7 My folder

8 Templates

9 Delete all

0 Messaging settings

* Memory status



p. 52



p. 56



p. 59



p. 60



p. 61



p. 61



p. 62



p. 62



p. 63



p. 63



p. 69

6 My files



p. 69

Images

Videos

Sounds

Games and more

Other files

Memory status

Memory card



p. 70



p. 72



p. 73



p. 74



p. 75



p. 78



p. 78

7 Calendar



p. 78

8 Camera



p. 82

9 Bluetooth



p. 88

* Applications



p. 90

1 Memo

2 Tasks

3 Voice recorder

4 World clock

5 Calculator

6 Converter

7 Timer

8 Stopwatch

9 SAT



p. 90



p. 91



p. 92



p. 94



p. 94



p. 94



p. 95



p. 95



p. 95

0 Alarms



p. 96

# Settings



p. 97

1 Phone profiles

2 Time & date

3 Display settings

4 Phone settings

5 Call settings

6 Security

7 Application settings

8 Network settings

9 Operator settings

0 Master reset



p. 97



p. 98



p. 99



p. 99



p. 101



p. 104



p. 106



p. 109



p. 112



p. 112

1. Shows only if a memory card is

inserted.

2. Shows only if supported by your

SIM/USIM card.

3. Shows only if supported by your

service provider.

Overview of menu functions

To access Menu mode, press [

] in Idle mode.

Your phone

Keys, features, and locations

Headset/

Adapter jack

Left soft key

Special

function keys

Camera lens

Power on/off/

Menu exit key

Alphanumeric

keys

Right soft key

Menu access/

Confirm key

Navigation keys

(Up/Down/Left/

Right)

Delete key

Dial key

Display

Earpiece

Memory card

slot

Volume keys

Camera/

Video call key

Microphone

Application

switch key

Unpack

Make sure you have each item

• Phone

•Travel Adapter

• Battery

• PC Data Cable

• PC Link CD

•User’s Guide

You can obtain various

accessories from your local

Samsung dealer.

The items supplied with

your phone and the

accessories at your

Samsung dealer may vary,

depending on your country

or service provider.

Get started

First steps to operating your phone

USIM/SIM card information

When you subscribe to a cellular network,

you receive a plug-in SIM (Subscriber

Identity Module) card loaded with your

subscription details, such as your PIN, and

available optional services. For 3G services,

you can purchase a USIM (Universal

Subscriber Identity Module) card.

Install and charge the phone

Remove the

battery cover.

If the phone is

already on, first turn

it off by pressing and

holding [ ].

Insert the USIM/

SIM card.

Make sure that the

gold-coloured

contacts on the card

are face down.

Install the battery. Reattach the

battery cover.

Plug the travel adapter into the phone.

Plug the adapter into a standard AC wall

outlet.

When the phone is completely charged

(the battery icon becomes still), unplug

the adapter from the power outlet.

Get started

Low battery indicator

When the battery is low:

• a warning tone sounds,

• the battery low message displays, and

• the empty battery icon blinks.

If the battery level becomes too low, the

phone automatically turns off. Recharge

your battery.

Power on or off

Keypad lock

When you close the phone, the keypad lock

feature locks the exposed keys so that

nothing will happen if the keys are

accidentally pressed.

To unlock the keypad, press <

Unlock

> and

then press <

Remove the adapter from the phone.

Switch on

Do not turn on

the phone

when mobile

phone use is

prohibited.

1. Open the phone.

2. Press and hold [ ].

3. If necessary, enter the

PIN and press

Confirm

Switch off

1. Open the phone.

2. Press and hold [ ].

Get started

Keys and display

Keys

Perform the function indicated

on the bottom line of the display.

In Idle mode, access your

favourite menus directly.



p. 100

In Menu mode, scroll through

menu options.

In Idle mode, access Menu

mode.

In Menu mode, select a

highlighted menu option or

confirm input.

Make or answer a call.

In Idle mode, retrieve numbers

recently dialled, missed, or

received.

Delete characters from the

display or items in an

application.

Press and hold to switch the

phone on or off.

End a call.

In Menu mode, cancel input and

return the phone to Idle mode.

Enter numbers, letters, and

some special characters.

In Idle mode, press and hold [

]

to access your voicemail server.

Press and hold [

] to enter an

international call prefix.

Enter special characters.

Press and hold [ ] to activate or

deactivate the Silent profile.

Press and hold [ ] to enter a

pause between numbers.

Adjust the phone volume.

In Idle mode, adjust the key

tone volume. With the phone

closed, press and hold to turn on

the display.

Get started

Display

Open the application switch

window to access other

applications without exiting the

current application.

In Idle mode, press and hold to

turn on the camera or make a

video call, depending on the

Camera key

setting.



p. 100

In Camera mode, take a photo

or record a video.

In the dialling screen, make a

video call.

Layout

Text and graphics

display messages,

instructions, and

information you

enter.

Soft key function

indicators

show the current

functions assigned

to the soft keys.

Icons

display various

icons.

Select Back

Icons

Received signal strength

Accessing services in a

2.5G (GPRS) network;

when transferring data,

this icon animates

Accessing services in an

EDGE network; when

transferring data, this icon

animates

Accessing services in a 3G

(UMTS) network; when

transferring data, this icon

animates

Accessing services in a

3G+ (HSDPA) network;

when transferring data,

this icon animates

Roaming network

Voice call in progress

Out of your service area;

you cannot make or

receive voice calls

Video call in progress

Get started

Out of your service area;

you cannot make or

receive video call

Memory card inserted



p. 25

Bluetooth active; When

transferring data, this icon

blinks red and blue



p. 88

Connected with PC via a

USB port

Browsing Internet on PC

using the phone as modem

Connected to secured web

page

New message:

• : SMS

• : MMS

• : E-mail

• : Voicemail

• : Push

• : Configuration

message

Inbox full:

• : SMS

• : MMS

• : E-mail

• : Voicemail

• : Push

• : Configuration

message

Profile setting



p. 98

• : Normal

• : Meeting

• : Car

• : Silent

• : Outdoor

• : Offline

Battery power level

1. Depending on your country or service provider,

the icons shown on the display may vary.

Get started

Access menu functions

Use the

soft keys

The roles of the soft keys

vary depending on the

function you are using. The

bottom line of the display

indicates their current role.

Press the left

soft key to select

the highlighted

option.

Press the right

soft key to

return to the

menu level.

Select

Back

Select an

option

1. Press a desired soft key.

2. Press the Navigation

keys to move to the

next or previous option.

3. Press <

Select

> or [

]

to confirm the function

displayed or option

highlighted.

4. To exit, choose either of

the following methods:

• Press <

Back

> to

move up one level.

• Press [ ] to return

to Idle mode.

Use

shortcuts

Press the number key

corresponding to the option

you want.

Get started

Customise your phone

1. In Idle mode, press [

]

and select

Settings

→

Phone settings

→

Language

→

Screen

text

2. Select a language.

3. Press <

Save

You can change the call

ringer by changing the

properties of the currently

active sound profile.

To cha n g e the p r o fil e

properties:

1. In Idle mode, press [

]

and select

Settings

→

Phone profiles

2. Scroll to the sound profile

you are using.

3. Press <

Options

> and

select

Edit

Display

language

Call ringer

melody

4. Select

Voice call

ringtone

and select a

ringtone for voice calls.

5. Select

Video call

ringtone

and select a

ringtone for video calls.

6. Press <

Options

> and

select

Save

To change the sound profile:

1. In Idle mode, press [

]

and select

Settings

→

Phone profiles

2. Select the profile you

want.

Get started

You can set a wallpaper for

the idle screen.

1. In Idle mode, press [

]

and select

Settings

→

Display settings

→

Display settings

→

Wallpaper

→

Pictures

→

Images

2. Scroll to an image folder

3. Select an image.

4. Press <

Set

You can set the Navigation

keys to function as shortcuts

to access your favourite

menus.

1. In Idle mode, press [

]

and select

Settings

→

Phone settings

→

Shortcuts

2. Select a key.

3. Select a menu to be

assigned to the key.

Idle mode

Wallpaper

shortcuts

You can activate the Silent

profile to avoid disturbing

other people.

Press and hold [ ] in Idle

mode.

You can protect the phone

against unauthorised use

with a phone password. The

phone will require the

password on power-up.

1. In Idle mode, press [

]

and select

Settings

→

Security

→

Change

phone password

2. Enter the default

password,

00000000

and press <

Confirm

3. Enter a new 4- to 8-digit

password and press

Confirm

Silent

profile

Phone lock

Get started

Make/Answer calls

4. Enter the new password

again and press

Confirm

5. Select

Phone lock

6. Select

7. Enter the password and

press <

Confirm

To make a voice call:

1. Enter an area code and

phone number.

2. Press [ ].

3. To end the call, press

[].

To make a v i deo ca l l :

1. Enter an area code and

phone number.

2. Press [ ].

3. To end the call, press

[].

Make a call

1. When the phone rings,

press [ ].

2. For a video call, when a

“Allow own image to be

shown?” message

appears, select

Yes

allow the other person to

see you.

3. To end the call, press

[].

Press [

Answer

a call

Adjust the

volume

during a call

Step outside the phone

Begin with your camera, the media player, the

web, and other special features

Use the camera

1. Open the phone.

2. In Idle mode, press and

hold [ ] to turn on the

camera.

3. Aim the lens at the

subject and make any

desired adjustments.

4. Press [

] or [ ] to

take a photo. The photo

is saved automatically.

5. Press <

Back

> or < >

to take another photo.

1. In Idle mode, press [

]

and select

My files

2. Select the photo you

want.

Take a


View a


1. In Idle mode, press and

hold [ ] to turn on the

camera.

2. Press [

] to switch to

Record mode.

3. Press [

] or [ ] to

start recording.

4. Press [

] or [ ] to

stop recording. The video

is saved automatically.

5. Press <

Back

to record

another video.

1. In Idle mode, press [

]

and select

My files

2. Select the video you

want.

Record a

video

Play a video

Step outside the phone

Play music

Use these methods:

• Download from the

wireless web



p. 48

• Download from a

computer using the

optional Samsung PC

Studio



Samsung PC

Studio User’s Guide

• Receive via Bluetooth



p. 90

•Copy to a memory card

and insert the card into

the phone



p. 25

Copy media

files to the

phone

1. In Idle mode, press [

]

and select

Media player

2. Scroll to the

Music

tab.

3. Press <

Options

> and

select

Create playlist

4. Enter the name for the

play list and press

Save

5. Select the play list you

just created.

6. Press <

Options

> and

select

Add

→

Playlist

Files

7. Scroll to the play list you

want, or press [

] to

select the files you want.

8. Press <

Select

> or

Add

Create a

play list

Step outside the phone

Browse the web

Using a built-in web browser, you can easily

access the wireless web to get a variety of

up-to-date services and information and to

download web content.

1. Select the file you want

to play.

2. During playback, use the

following keys:

•

: pauses or

resumes playback.

• Up: opens the play

list.

• Left: returns to the

previous file. Moves

backward in a file

when held down.

• Right: skips to the

next file. Skips

forward in a file when

held down.

•

: adjusts the

volume.

3. Press [Down] to stop

playback.

Play music

files

In Idle mode, press [

]

and select

Browser

→

Go to

Homepage

• To scroll through browser

items, press [Up] or

[Down].

• To select an item, press

Select

> or [

• To return to the previous

page, press <

Back

• To access options, press

Options

Launch the

web

browser

Navigate

the web

Step outside the phone

Use Contacts

To the phone’s memory:

1. In Idle mode, enter a

phone number.

2. Press <

Options

> and

select

Add to Contacts

→

Phone

→

New

→

number type.

3. Specify contact

information: First name,

Last name, Display

name, Mobile-private,

Landline-private, Email,

Group, Caller ID,

Ringtone, and More

information.

4. Press [

] to save the

contact.

Add a

contact

To the USIM/SIM card:

1. In Idle mode, enter a

phone number.

2. Press <

Options

> and

select

Add to Contacts

→

SIM

→

New

3. Specify contact

information: Name,

Phone number, Group

(for USIM), and Location

number.

4. Press <

Save

>, or press

Options

> and select

Save

to save the contact.

1. In Idle mode, press

Contacts

2. Enter the first few letters

of the name you want.

Find a

contact

Step outside the phone

Send messages

3. Select a contact from the

Contacts list.

4. Scroll to a number and

press [ ] to dial, or

press [

] to edit

contact information.

1. In Idle mode, press

Contacts

2. Press <

Options

> and

select

My contact

details

3. Specify your contact

information.

4. Press [

] to save the

name card.

5. To send the name card,

press <

Options

> and

select

My contact

details

6. Press <

Options

> and

select

Send my contact

details

→

a sending

method.

Find a

contact

(continued)

Create and

send a

name card

1. In Idle mode, press

and select

Create

New Message

→

Message

2. Enter your message.

3. Press [UP] to move to the

recipient field.

4. Enter a destination

number.

To send the message to

more than one recipient,

press [Right] and enter

additional destination

numbers.

5. Press <

Options

> and

select

Send

to send the

message.

Send a text

message

(SMS)

Step outside the phone

1. In Idle mode, press

and select

Create

New Message

→

Message

2. Enter your message.

3. Press <

Options

> and

select

Add subject

4. Press <

5. Enter the message

subject and press [Down]

to move to the text field.

6. Press <

Options

> and

select

Add item

Create

item

, or

Add

attachment

7. Add a media file,

Contacts entry, calendar

item, or bookmark item.

8. Press [Up] until the

recipient field highlights.

Send a

multimedia

message

(MMS)

9. Enter destination

numbers or e-mail

addresses.

To send the message to

more than one recipient,

press [Right] and enter

additional numbers or

e-mail addresses.

10. Press <

Options

> and

select

Send

to send the

message.

Step outside the phone

View messages

1. In Idle mode, press

and select

Create

New Message

→

2. Enter the e-mail text.

3. Press <

Options

> and

select

Add subject

4. Enter the subject of the

e-mail.

5. Press <

Options

> and

select

Add item

Create item

6. Add a media file,

Contacts entry, calendar

item, or bookmark item.

7. Press [Up] until the

recipient field highlights.

Send an

e-mail

8. Enter destination e-mail

addresses.

To send the e-mail to

more than one recipient,

press [Right] and enter

additional e-mail

addresses.

9. Press <

Options

> and

select

Send

to send the

e-mail.

When a notification appears:

1. Press <

View

2. Select the message from

the Inbox.

From the Inbox:

1. In Idle mode, press

<> and select

Inbox

2. Select an SMS message

().

View a text

message

Step outside the phone

Use Bluetooth

Your phone is equipped with Bluetooth

technology, enabling you to connect the

phone wirelessly to other Bluetooth devices

and exchange data with them, talk hands-

free, or control the phone remotely.

When a notification appears:

1. Press <

View

2. Select the message from

the Inbox.

From the Inbox:

1. In Idle mode, press

< > and select

Inbox

2. Select an MMS message

().

1. In Idle mode, press

< > and select

inbox

2. Press <

Downld.

3. Select an e-mail or

header.

4. If you selected a header,

press <

Options

> and

select

Retrieve

to view

the body of the e-mail.

View a

multimedia

message

View an

e-mail

1. In Idle mode, press [

]

and select

Bluetooth

→

Activation

→

2. Select

My phone’s

visibility

→

to allow

other devices to find your

phone.

1. In Idle mode, press [

]

and select

Bluetooth

→

My devices

→

new device

2. Select a device.

3. Enter a Bluetooth PIN or

the other device’s

Bluetooth PIN, if it has

one, and press <

Turn on

Bluetooth

Search for

and pair

with a

Bluetooth

device

Step outside the phone

Switch applications

You can switch to other applications from a

menu, without closing the menu screen you

were using.

When the owner of the

other device enters the

same code, pairing is

complete.

1. Access an application,

Contacts

My files

Calendar

Memo

, or

Tasks

2. Select the item you want

to send.

3. Press <

Options

> and

select

Send contact

details

Send

Send via

→

Via bluetooth

Bluetooth

4. Select a device.

5. If necessary, enter the

Bluetooth PIN and press

Send data

1. When a device attempts

to access your phone,

press <

Yes

> to confirm

that you are willing to

receive.

2. If necessary, press

Yes

> to confirm that

you are willing to receive.

1. While using a menu,

press

[]

2. Select an application.

•

Call

: opens the dialling

screen.

•

Messaging

: accesses the

Messaging

menu.

•

Internet

: launches the

web browser.

Receive

data

Switch to an

application

Available

applications

Step outside the phone

Use a memory card

You can use an optional microSD memory

card to increase your phone’s memory

capacity.

1. Press

[]

2. Scroll to

End all?

3. Press <

Yes

• Frequent erasing and

writing will shorten a

card’s lifespan.

• Do not remove a card

from the phone or turn

off the phone while data

is being accessed or

transferred. This could

result in loss of data and/

or damage to the card or

phone.

Close all

running

applications

Important

memory

card

information

• Do not subject cards to

strong shocks.

• Do not touch card

terminals with your

fingers or metal objects.

If dirty, wipe the card

with a soft cloth.

•Keep cards away from

small children or pets.

• Do not expose cards in a

place subject to electro-

static discharge and/or

electrical noise.

1. Insert a memory card

into the card slot, with

the label side face up.

2. Press the card until it

locks into place.

Insert a

memory

card

Step outside the phone

1. Press the memory card

so that it is disengaged

from the phone.

2. Remove the card from

the slot.

Using a card adapter and a

USB card reader/writer, you

can read the card on a PC.

1. Insert a memory card

into a card adapter, and

then the adapter into a

card reader/writer.

2. Plug the USB connecter

of the card reader/writer

into the USB port on your

PC.

3. Access the appropriate

memory disk and copy to

and from the card.

Remove the

memory

card

Use a card

adapter

Enter text

ABC, T9, Number, and Symbol modes

You can enter text for some features such as

Messaging, Contacts, or Calendar, using ABC

mode, T9 mode, Number mode, and Symbol

mode.

Changing the text input mode

• Press and hold [ ] to switch between T9

( ) and ABC ( ) modes.

• Press [ ] to change case or to switch to

Number mode ( ).

• Press and hold [ ] to switch to Symbol

mode ( ).

Using ABC mode

Press the appropriate key until the character

you want appears on the screen.

(Creating an SMS message with GSM alphabet

encoding)

Other ABC mode operations

• To enter the same letter twice or to enter

a different letter on the same key, wait

for the cursor to move to the right

automatically or press [Right]. Then,

enter the next letter.

• Press [ ] to insert a space.

• Press the Navigation keys to move the

cursor.

Upper case Lower case

Key

aracters

aye

Enter text

•Press [

] to delete characters one by

one. Press and hold [

] to clear the

entire display.

Using T9 mode

T9 is a predictive text input mode that

allows you to enter any character using

single keystrokes.

Entering a word in T9 mode

1. Press [

] to [

] to start entering a word.

Press each key once for each letter.

For example, press [

], [

and [

] to enter Hello in T9 mode.

T9 predicts the word that you are typing,

and it may change with each key that

you press.

2. Enter the whole word before editing or

deleting characters.

3. When the word displays correctly, go to

step 4. Otherwise, press [

] to display

alternative word choices for the keys

that you have pressed.

For example, Of and Me use [

] and [

4. Press [ ] to insert a space and enter the

next word.

Other T9 mode operations

•Press [

] to enter periods or apostrophes

automatically.

• Press [ ] to insert a space.

• Press the Navigation keys to move the

cursor.

•Press [

] to delete characters one by

one. Press and hold [

] to clear the

entire display.

Adding a new word to the T9

dictionary

This feature may not be available for some

languages.

1. Enter the word that you want to add.

2. Press [

] to display alternative words for

your key presses. When there are no

more alternative words,

Spell

displays

on the bottom line.

3. Press <

Spell

4. Enter the word you want using ABC

mode and press <

Add

Using Number mode

Number mode enables you to enter

numbers. Press the keys corresponding to

the digits you want.

Using Symbol mode

Symbol mode enables you to insert symbols.

Call functions

Advanced calling features

Making a call

1. In Idle mode, enter the area code and

phone number.

2. Press [ ].

3. When you want to end the call, press

[

Making an international call

1. In Idle mode, press and hold [

]. The

character appears.

2. Enter the country code, area code, and

phone number, then press [ ].

Redialling recent numbers

1. In Idle mode, press [ ] to display the

list of recent numbers.

2. Scroll to the number you want and press

[].

To Press

scroll to a symbol set the Navigation

keys

select a symbol the corresponding

number key.

clear the entered

symbols

[

insert the symbols <

• Press [

] to clear the last digit or press

and hold [

] to clear the whole display.

• Press and hold [ ] to enter a pause

between numbers.

Call functions

Making a call from Contacts

Once you have stored a number in Contacts,

you can dial the number by selecting it from

Contacts.



p. 39

You can also use the speed dial feature to

assign your most frequently dialled numbers

to specific number keys.



p. 106

You can quickly dial a number from the

USIM/SIM card using its location number

assigned when stored.

1. In Idle mode, enter a location number

and press [ ].

2. Scroll through other numbers, if

necessary.

3. Press <

Call

> or [ ] to make a voice

call, or <

V-Call

> or [ ] to make a

video call.

Answering a call

When you receive an incoming call, the

phone rings and displays the incoming call

image.

Press <

> or [ ] to answer the call.

Tips for answering a call

• When

Slide up

Slide settings

is set

Accept call

, you can simply open the

phone.



p. 100

•Press <

Reject

> or [ ] to reject a call.

• Press and hold [

] to reject a call or

mute the ringer, depending on the

Volume key

setting.



p. 100

Viewing missed calls

If you have missed calls, the screen displays

how many calls you have missed.

1. Press <

View

2. If necessary, scroll through the missed

calls.

3. Press [ ] to dial the number you want.

Call functions

Using the headset

Use the headset to make or answer calls

without holding the phone.

Connect the headset to the jack on the right

side of the phone. The button on the

headset works as follows:

Options during a call

You can access a number of functions during

a call.

Adjusting the volume during a call

Use [

] to adjust the earpiece volume

during a call.

Press [ ] to increase the volume level and

press [ ] to decrease the volume level.

Placing a call on hold/Retrieving

Press <

Hold

> to place a call on hold, or

press <

Retrieve

> to retrieve the call.

Making a second call

You can make another call if your network

supports this function.

1. Press <

Hold

> to put the call on hold.

2. Make the second call in the normal way.

3. Press <

Swap

> to switch between the

calls.

4. Press <

Options

> and select

End

→

Held

call

to end the call on hold.

5. To end the current call, press [ ].

Answering a second call

You can answer an incoming call while

already on the phone, if your network

supports this function and you have

activated the call waiting feature.



p. 103

1. Press [ ] to answer the call. The first

call is automatically put on hold.

2. Press <

Swap

> to switch between the

calls.

To Press

redial the last call and hold the button,

twice.

answer a call the button.

end a call and hold the button.

Call functions

3. Press <

Options

> and select

End

→

Held

call

to end the call on hold.

4. To end the current call, press [ ].

Using the speakerphone feature

Use the phone as a speakerphone to talk

and listen with the phone a short distance

away.

Press [

] and then <

Yes

> to activate the

speakerphone feature. Press [

] again to

switch back to the earpiece.

Using In-call options

During a call, press <

Options

> to access

the following options:

•

Speaker on

Normal

: turn on the

speakerphone feature or switch back to

Normal mode.

•

Switch to headset

Switch to phone

switch the call to a Bluetooth headset or

hands-free car kit or back to the phone.

To use this feature, you first need to

connect your headset or car kit to the

phone.



p. 88

•

Whisper mode on

Whisper mode off

turn on or off Whisper mode. Whisper

mode automatically increases the

microphone's sensitivity to allow the

other person to hear your voice even

though you may be whispering.

•

Join

: set up a multi-party call by adding

a caller on hold to a currently active call.

You can include up to 5 people on a

multi-party call.

•

Split

: have a private conversation with

one multi-party call participant. The

other participants can converse with

each other. After the private

conversation, select

Join

to return both

private participants to the multi-party

call.

•

Swap

: switch between calls, if a call is

on hold.

•

Transfer

: transfer the currently active

call to a caller on hold. The two callers

can talk to each other, but you are

disconnected from the call.

•

Hold

Retrieve

: place a call on hold or

retrieve the call.

Call functions

•

Mute

: access the following muting

options:

Voice

: switch off the phone's

microphone so that the other person on

the phone cannot hear you, or switch it

back on.

Keypad tones

: turn the key tones off or

on.

•

New call

: make a new voice call.

•

Create message

: create a new SMS or

MMS message.

•

Contacts

: locate or store contacts in

Contacts.

•

Add to Contacts

: add the sender’s

number to Contacts.

•

View contact details

: access the

contact information, if the caller is saved

in Contacts.

•

Send DTMF

: send DTMF (Dual tone

multi-frequency) tones as a group. The

DTMF tones are the tones used in phones

for tone dialling, sounding when you

press the number keys. This option is

helpful for entering a password or an

account number when you call an

automated system, like a banking

service.

•

Memo

: create a memo.

•

Switch to video call

: switch to a video

call.

•

End call

End

: disconnect the call

currently on hold, active call, or all calls.

Using the video call feature

In a 3G (UMTS) service area, your phone

can make or receive a video call, allowing

you to see another person on the screen

during a conversation. The other person’s

phone must support the video call feature.

Making a video call

1. In Idle mode, enter the area code and

phone number.

2. Press [ ].

To communicate with answering

machines or computerised telephone

systems,

Keypad tones

must be

deactivated.

Call functions

Answering a video call

When you receive a video call, answer a

video call as receiving a voice call. When a

“Allow own image to be shown?” message

appears, select

Yes

to allow the caller to see

you via the camera.

Using video call options

During a video call, press <

Options

> to

access the following options:

•

Normal

Speaker

: turn off or on the

speakerphone feature.

•

Switch to headset

Switch to phone

switch the call to a Bluetooth headset or

hands-free car kit, or back to the phone.

To use this feature, you first need to

connect your headset or car kit to the

phone.



p. 88

•

Whisper mode on

Whisper mode off

turn on or off Whisper mode. Whisper

mode automatically increases the

microphone's sensitivity to allow the

other person to hear your voice even

though you may be whispering.

•

Outgoing image

: set an image to be

displayed on other person’s phone.

•

Mute

: turn off the microphone, or key

tones.

•

Record video call

Stop recording

start recording the current video call and

stop recording.

•

External camera

Internal camera

switch between the front camera lens

and the rear camera lens.

•

Capture image

: capture the image that

is displayed on the screen.

•

Display options

: access the camera

settings for the video call.

Brightness

: display the brightness

control bar.

Effects

: change the colour tone of the

image.

Quality

: change the image quality.

View mode

: select a view mode.

Zoom

: display the zoom control bar and

zoom in or out by pressing [Up] or

[Down].

Hide caller ID

Show caller ID

: hide or

display the caller’s phone number, or

name if saved in Contacts.

•

More options

: access the following

options:

Contacts

: locate or store contacts in

Contacts.

Create message

: create a new SMS or

MMS message.

Message inbox

: access the received

message list.

Show my file

: show an image or video

clip that is stored in your phone instead

of your camera image.

Send DTMF

: send Dual tone multi-

frequency (DTMF) tones as a group after

entering the entire number you need to

send or retrieving a number from

Contacts.

Calendar

: access the calendar to check

your schedule or enter new

appointments.

Memo

: create a memo.

•

Switch to voice call

: switch to a voice

call.

•

Settings

: change the default settings for

the video call feature.



p. 104

Menu functions

All menu options listed

Call log

(Menu 1)

Use this menu to view the calls you have

dialled, received, or missed, the length of

the calls. You can also check the cost of your

calls, if your USIM/SIM card supports this

function.

To access this menu, press [

] in Idle

mode and select

Call log

Accessing a call log

You can access the most recent calls dialled,

received, or missed.

1. Press [Left] or [Right] to move to

another call type.

2. Press [Up] or [Down] to scroll through

the call list.

3. Press [

] to view the details of a call,

or press [ ] to dial a number.

Menu functions

Using call log options

While viewing call details, press <

Options

to access the following options:

•

Voice call

: make a voice call to the

number.

•

Video call

: make a video call to the

number, if the 3G service is available.

•

Save contact to

: save the number to

Contacts.

•

Copy to dialling screen

: paste the

number to the dialling screen.

•

Create message

: send an SMS or MMS

message to the selected number.

•

Delete

: delete the selected call log or all

logs.

•

Add to reject list

: add the number to

the Auto reject list so that you can reject

calls from that number.

Viewing the data counter

From the call log list, press <

Options

> and

select

Call manager

→

Data counter

view the total amount of sent or received

data.

The following counters are available:

•

Total sent

: check the total amount of

data you have sent.

•

Total received

: check the total amount

of data you have received.

To reset a counter or all of the counters,

press <

Options

> and select

Reset

Reset all

Viewing call cost

From the call log list, press <

Options

> and

select

Call manager

→

Call costs

to view

the cost of calls. This option is available only

if supported by your USIM/SIM card. Note

that this is not intended to be used for billing

purposes.

The following counters are available:

•

Total

costs

: check the total cost of all

your calls. If the total cost exceeds the

maximum cost set in

Edit cost limit

you must reset the counter before you

can make another call.

If the phone is locked, it will require the

password. The password is preset to

00000000

. You can change this password.



p. 105

Menu functions

Contacts

(Menu 2)

•

Last

call

cost

: check the cost of your

last call.

•

Call limit

: check the maximum cost set.

Press <

Options

> to access the following

options:

•

Reset call

cost

: reset the cost counters.

•

Edit cost limit

: set the maximum cost

authorised for your calls.

•

Setup currency

: set the currency that

is applied when the cost of your call is

calculated.

Viewing call time

From the call log list, press <

Options

> and

select

Call manager

→

Call times

to view

the time log for calls made and received.

The actual time invoiced by your service

provider will vary.

The following counters are available:

•

Total dialled

: check the total length of

voice calls dialled.

•

Total received

: check the total length

of voice calls received.

•

Total video calls dialled

: check the

total length of video calls dialled.

•

Total video calls received

: check the

total length of video calls received.

To reset a counter or all of the counters,

press <

Options

> and select

Reset

Reset all

Contacts

(Menu 2)

You can store phone numbers on your USIM/

SIM card and in your phone’s memory. The

USIM/SIM card and phone’s memory are

physically separate, but they are used as a

single entity called Contacts.

To access this menu, press [

] in Idle

mode and select

Contacts

If the phone is locked, it will require the

password. The password is preset to

00000000

. You can change this password.



p. 105

You can quickly access this menu by press

Contacts

> in Idle mode.

Menu functions

Storing a new contact

You can add a new contact to Contacts.

Storing a contact in the phone’s

memory

1. Scroll to the

Contacts

tab.

2. Press <

Options

> and select

Add

contact

→

Phone

3. Change the settings or enter information

about the contact.

•

First name

Last name

: assign a

name.

•

Display name

: assign a display

name.

•

Mobile-private

: add a phone

number.

•

Landline-private

: enter a fixed

phone number.

•

: assign an e-mail address.

•

Group

: assign a caller group.

•

Caller ID

: assign a caller ID image.

•

Ringtone

: assign a ringtone to alert

you to a call from the person.

•

More information

: enter the

additional note of the person.

4. If necessary, press <

Options

> to access

the following options:

•

Change type

: change the selected

number type.

•

Add more fields

: add an additional

category to the contact.

•

Delete field

: remove the selected

category from the contact.

5. Press <

Options

> and select

Save

save the contact.

Storing a contact on the USIM/SIM

card

1. Scroll to the

Contacts

tab.

2. Press <

Options

> and select

Add

contact

→

SIM

3. Change the settings or enter information

about the contact.

•

Name

: assign a name.

•

Phone number

: enter a phone

number.

•

Group

: (for USIM) assign a caller

group.

•

Location number

: assign a location

number.

Menu functions

Contacts

(Menu 2)

4. If you are using a USIM card, press

Options

> to add additional

information:

•

Add more fields

: add an additional

category to the contact.

•

Delete field

: remove the selected

category from the contact.

5. Press <

Save

>, or press <

Options

> and

select

Save

to save the contact.

Adding a contact to the FDN list

You can create a list of contacts to be used

in FDN (Fixed Dialling Number) mode, in

which the phone allows outgoing calls only

to the specified phone numbers, if your

USIM/SIM card supports this feature.

1. Scroll to the

FDN

tab, or press

Options

> and select

FDN contacts

2. Press <

Options

> and select

Create

FDN contact

3. Enter the PUK2 and press <

Confirm

4. Change the settings or enter information

about the contact:

•

Name

: assign a name.

•

Phone number

: enter a phone

number.

•

Location number

: assign a location

number.

5. Press <

Options

> and select

Save

save the contact.

Finding a contact

You can search for numbers in Contacts.

1. Scroll to the

Contacts

tab.

2. Enter the first few letters of the name

that you want to find.

3. Select the contact you want from the

Contacts list.

4. Scroll to a number and press [ ] to dial

or [

] to edit the contact information.

Using contact options

While viewing the contact list, press

Options

> to access the following options:

•

View

: access contact information.

•

Add contact

: add a new contact in

Contacts.

•

Voice call

: make a voice call.

You can add ? in a place where number is

not fixed by pressing <

Options

> and

selecting

Enter Wildcard

Menu functions

•

Video call

: make a video call.

•

Create message

: send an SMS

message or e-mail.

•

Edit

: edit contact information.

•

Synchronise

: synchronise Contacts with

the web server you have specified.



p. 41

•

Duplicate

: make a copy of the contact.

•

Delete

: delete the currently selected

contact or the contacts you want.

•

Save to My files

: save the contact as a

name card format in the

Other files

folder.

•

Send contact details

: send the contact

details via SMS, e-mail, or Bluetooth.

•

My contact details

: access your name

card.

•

Assign speed dial

: assign a speed dial

number. If the selected contact has more

than one phone number, the speed dial

number is assigned to the first saved

number by default.

•

Copy to phone

Copy to SIM

: copy the

selected contact or all contacts to the

phone’s memory or the USIM/SIM card.

•

Move to phone

Move to SIM

: move

the selected contact or all contacts to the

phone’s memory or the USIM/SIM card.

•

Service number

: display the list of

Service Dialling Numbers (SDN) assigned

by your service provider, including

emergency numbers, directory enquiries,

and voicemail server number. This option

is available only when supported by your

USIM/SIM card.

•

FDN contacts

: display the FDN contact

list.

•

Copy to FDN contacts

: copy the

selected contact to the FDN contact list.

•

Print via Bluetooth

: print contact

information via a Bluetooth-compatible

printer. Some printers may not be

compatible with the phone.

•

Contact settings

: change the default

settings for Contacts.



p. 106

•

Memory status

: check the number of

contacts you have stored in the phone’s

memory and on the USIM/SIM card.

Menu functions

Contacts

(Menu 2)

Organising contacts in a group

You can organise your contacts in caller

groups.

Creating a caller group

1. Scroll to the

Groups

tab.

2. Press <

Options

> and select

Create

group

3. If you are using a USIM card, select a

location.

4. Enter a name for the group and press

Save

Adding members to a caller group

1. Select a group.

2. Press <

Options

> and select

Add

member

3. Press [

] to select the contacts you

want and then <

Add

Managing caller groups

While viewing the group list, press

Options

> to access the following options:

•

View

: display the members of the

selected group.

•

Create group

: add a new group.

•

Create message

: send an SMS or MMS

message or e-mail.

•

Delete

: delete the selected group.

Group members, however, will not be

deleted from Contacts.

•

Rename

: change the group name.

•

Group settings

: assign an image and

ringtone to the selected group in the

phone’s memory.

Synchronising contacts

You can synchronise your Contacts with the

web server you have specified. First, you

need to set up the profile to be used for

synchronisation.

Creating a synchronisation profile

1. From the Contacts list, press <

Options

and select

Synchronise

2. Press <

Add

3. Specify profile parameters:

•

Profile name

: enter a name for the

profile.

Menu functions

•

Sync category

: select the

applications you want to synchronise

with the server.

•

Sync type

: select a synchronisation

type.

•

Sync server

: enter the web server

address, or login ID and password.

•

Network profile

: select a

connection profile to be used for

connecting to the web server. You can

also create or edit a profile.



p. 110

4. Press <

Save

> to save the profile.

Starting synchronisation

1. From the Contacts list, press <

Options

and select

Synchronise

2. Press <

Options

> and select

Start sync

3. Press <

Continue

> to start

synchronisation with the web server you

have specified.

Using synchronisation options

From the PIM sync screen, press

Options

> to access the following options:

•

Start sync

: start a synchronisation for

the selected profile.

•

View result

: show the result of the last

synchronisation.

•

New sync profile

: add a new profile.

•

Edit sync profile

: change the properties

of the profile.

•

Delete

: delete the selected profile or all

profiles.

Media player

(Menu 3)

You can play music and video files.

To access this menu, press [

] in Idle

mode and select

Media player

Downloading or receiving music or

video files

You can play the following types of files on

your phone.

• Music: MP3, AAC, WAV, 3GA, M4A

• Video: 3GP, MP4

Use the following methods to save music or

video files to your phone’s memory or a

memory card:

• Download from the wireless web



p. 48

Menu functions

Media player

(Menu 3)

• Download from a computer using

Samsung PC Studio



Samsung PC

Studio User’s Guide

• Receive via an active Bluetooth

connection



p. 90

• Copy to a memory card and insert the

card into the phone



p. 25

Playing music files

Using the Media player, play music files. To

enjoy high quality music, you can use an

optional Bluetooth stereo headset.

Creating a music play list

1. Scroll to the

Music

tab.

2. Press <

Options

> and select

Create

playlist

3. Enter a name for the play list and press

Save

4. Select the play list you just created.

5. Press <

Options

> and select

Add

→

Playlist

Files

6. For

Playlist

, select the play list you

want.

For

Files

, press

[

] to select the files

you want and press <

Add

Playing a music file

1. From the play list screen, press

Options

> and select

Play via

2. Select

Phone

to use the phone speaker.

Select

Bluetooth stereo headset

use a Bluetooth stereo headset, and then

search for and connect the phone to the

headset.

During playback, use the following keys:

Normal headsets and Bluetooth mono

headsets are not compatible with the media

player.

Key Function

Pauses or resumes playback.

Up Opens the play list.

Left Returns to the previous file. Moves

backward in a file when held

down.

Right Skips to the next file. Skips

forward in a file when held down.

Down Stops playback.

Menu functions

Using music player options

From the music player screen, press

Options

> to access the following options:

•

Pause

Resume

: pause or resume

playback.

•

Stop

: stop playback.

•

Play via

: play the selected file via the

phone speaker or a Bluetooth stereo

headset.

•

Play via Bluetooth stereo headset

Play via

speaker

: play the selected file

via the phone speaker or a Bluetooth

stereo headset.

•

Add bookmark

: save the current

streaming page as a bookmark.

•

View bookmark

: display the URLs you

have bookmarked for streaming media

files.

•

View history

: display the URLs from

which you have received streaming

media services.

•

Open playlist

: open the play list.

•

Jump to track time

: specify a point in a

file you would like to move to.

•

Details

: access the file properties.

•

Settings

: change the default settings for

playing music files:

Repeat

: select a repeat mode.

Shuffle

: set the music player to play

tracks in random order.

Equalizer type

: select an equaliser

mode.

3D sound

: turn 3D sound on or off.

Visualization Type

: select a playback

animation.

Volume

: select a volume level.

/ Adjusts the volume.

Turns 3D sound on or off.

Changes the repeat mode.

Changes the equaliser mode.

Set the music player to play tracks

in random order.

Key Function

Menu functions

Media player

(Menu 3)

Using play list options

On the Media player screen, press

Options

> to access the following options:

•

Open

: open the selected play list.

•

Play via

: play the music files stored in

the selected play list via the phone

speaker or a Bluetooth stereo headset.

•

Create playlist

: add a new play list.

•

Rename

: change the name of the play

list.

•

Delete

: delete the selected play list or

all play lists.

•

Player settings

: change the default

settings for playing music files:

Repeat

: select a repeat mode.

Shuffle

: set the music player to play

tracks in random order.

Equalizer type

: select an equaliser

mode.

3D sound

: turn 3D sound on or off.

Visualization Type

: select a playback

animation.

Volume

: select a volume level.

Show controller

: set the music player

to display or hide the controller.

•

VOD settings

: select a connection

profile to be used for accessing a video

streaming server. You can also create or

edit a profile.



p. 110

Using music file options

1. On the Media player screen, select a play

list.

2. Press <

Options

> to access the following

options:

•

Play via

: play the selected file via

the phone speaker or a Bluetooth

stereo headset.

•

Add bookmark

: save the current

streaming page as a bookmark.

•

View bookmark

: display URLs you

have bookmarked for streaming

media files.

•

View history

: display the URLs from

which you have received streaming

media services.

•

Add

: add a new play list or music

files to the play list.

Menu functions

•

Move track in playlist

: move the

selected file to the position you want

within the play list.

•

Add to playlist

: add the selected file

or the files you want to another play

list.

•

List by

: change the sort order of the

list.

•

Send via

: send the file via MMS,

e-mail, or Bluetooth.

•

Set as

: set the file as a ringtone for a

voice call or video call, or as a

ringtone for a Contacts entry.

•

Lock

Unlock

: lock the file to prevent

it from being moved, deleted, and

renamed or unlock the file.

•

Remove

: remove the selected file or

all files from the play list.

•

Details

: access the file properties.

Downloading music files

1. Select

All music

2. Select

More music

. You car connected

to the preset website by your service

provider.

3. Search for the file you want and follow

the onscreen instructions to download it.

Playing video clips

Using the Media player, you can play video

clips.

Playing a video clip

1. From the Media player screen, scroll to

the

Video

tab.

2. Select a file. The video player opens and

the video plays.

During playback, use the following keys:

Key Function

Pauses or resumes playback.

Left Returns to the previous file.

Moves backward in a file when

held down.

Right Skips to the next file. Skips

forward in a file when held

down.

Adjusts the volume.

Down Stops playback.

Menu functions

Media player

(Menu 3)

Using video player options

From the video player screen, press

Options

> to access the following options:

•

Pause

Resume

: pause or resume

playback.

•

Stop

: stop playback.

•

Play

: play the file.

•

Add bookmark

: save the current

streaming page as a bookmark.

•

View bookmark

: display the URLs you

have bookmarked for streaming media

files.

•

View history

: display the URLs from

which you have received streaming

media services.

•

Jump to track time

: specify a point in a

file you would like to move to.

•

Show controller

Hide controller

: set

the video player to display or hide the

controller.

•

Details

: access the file properties.

•

Settings

: change the default settings for

playing video files:

Repeat

: select a repeat mode.

Shuffle

: set the video player to play files

in random order.

Equalizer type

: select an equaliser

mode.

3D sound

: turn 3D sound on or off.

Visualization Type

: select a playback

animation.

Volume

: select a volume level.

Show controller

: set the video player

to display or hide the controller.

Using video file options

From the file list, press <

Options

> to

access the following options:

•

Play

: play the selected file.

•

Add bookmark

: save the current

streaming page as a bookmark.

•

View bookmark

: display the URLs you

have bookmarked for streaming media

files.

•

View history

: display the URLs from

which you have received streaming

media services.

Menu functions

•

Send via

: send the file via MMS, e-mail,

or Bluetooth.

•

Lock

Unlock

: lock the file to prevent it

from being moved, deleted, and

renamed or unlock the file.

•

Details

: access the file properties.

Downloading video files

1. Select

More videos

. You are connected

to the website preset by your service

provider.

3. Search for the file you want and follow

the onscreen instructions to download it.

Sounds

Use this menu to access voice memos you

have recorded, and sound clips you have

downloaded, received in messages, or

imported from your computer.

Playing a sound clip

1. Scroll to a sound folder.

2. Select a sound clip. The media player

opens.



p. 43

For a voice memo, see

Voice recorder



p. 92

Using sound options

From the sound list, press <

Options

> to

access the following options:

•

Play

: play the selected file.

•

Send via

: send the file via MMS, e-mail,

or Bluetooth.

•

Set as

: set the sound as your ringtone

for a voice call or video call, or as a

ringtone for a Contacts entry.

•

Move

: move the selected file or the files

you want to another folder.

•

Copy

: copy the selected file or the files

you want to another folder.

•

Activate key

: get a new licence key

when the key for the selected DRM file

expires.

Menu functions

•

Reactivate key

: get another licence key

even when the key for the selected DRM

file has not expired.

•

Delete

: delete the selected file or the

files you want.

•

Rename

: change the file name.

•

Add to playlist

(for music files): add

the selected file to the play list.

•

Record audio

(for ring tone or voice

memos): record a new voice memo.

•

Create Folder

: add a new folder.

•

List by

: change the sort order of the list.

•

Bluetooth visibility

: share the selected

file or the files you want with other

Bluetooth devices.

•

Lock

Unlock

: lock the file to prevent it

from being moved, deleted, and

renamed or unlock the file.

•

Details

: access the file properties.

Downloading sound clips

1. Select the

Music

Ringtones

folder.

2. Select

More sounds

. You are connected

to the preset website by your service

provider.

3. Search for the file you want and follow

the onscreen instructions to download it.

Games and more

Use this menu to access the embedded Java

games and download Java applications.

Accessing a game

Select a game from the game list and follow

the onscreen instructions. The procedure

may differ from game to game.

Using Java game options

From the application list, press <

Options

to access the following options:

•

Start

: launch the selected game.

•

Activate key

: get a new licence key

when the key for the selected DRM file

expires.

•

Reactivate key

: get another licence key

even when the key for the selected DRM

file has not expired.

•

Delete

: delete the selected game or the

games you want.

•

Rename

: change the game name.

Menu functions

My files

(Menu 6)

•

Lock

Unlock

: lock the file to prevent it

from being moved, deleted, and

renamed or unlock the file.

•

Advanced

: access the following options:

Certificates

: access the root certificates

for the operator and trusted third

parties.

Permissions

: set permission settings

for services that charge you additional

costs, such as network acess and SMS.

Connections

: select a connection profile

to be used for accessing an application

server. You can also create or edit a

profile.



p. 110

•

Details

: access the game properties.

Downloading new games

1. Select

More games

. You are connected

to the website preset by your service

provider.

2. Search for the application you want and

follow the onscreen instructions to

download it.

Other files

Use this menu to access any other files than

image, video, music and sound files. Your

phone provides you with Picsel File Viewer to

allow you to view, without corruption,

various document files. Available file formats

are *.swf, *.svg, *.doc, *. xls, *.ppt, *.pdf,

and *.txt.

Viewing a document

Select a file. Picsel File Viewer runs and

opens the document.

Use the following keys to view the

document:

• Depending on the file size or memory

capacity of Picsel File Viewer, some files

may not open properly.

• If a document file contains languages

unsupported by Picsel File Viewer, the

content of the document will not display

correctly.

Key Function

Up/Down/ Scrolls through pages.

Left/Right Pans the page

Menu functions

Using document options

While viewing a document, press

Options

> or < > to access the

following options:

•

Full screen view

Normal view

change the view mode.

•

Zoom

: zoom in or out.

•

Fit to screen

: fit the file to the page

size, screen width, or screen height.

•

Go to

: move to another page of the

document.

•

Rotate

: Rotates the file 90 degrees

clockwise or counterclockwise.

•

Screen panning

Normal panning

change the page scroll mode. You can

scroll by screen size or scrolling by

preset pixel.

•

Hide controller

Show controller

: hide

or display the shortcut tool bar in Full

screen view.

•

: search for text in the document.

•

Send via

: send the file via e-mail or

Bluetooth.

•

Delete

: delete the selected file.

Zooms in or out.

Fits the file to the page size.

Searches backward through

the file for the text entered in

the

option.

Returns to the first page.

Searches forward through the

file for the text entered in the

option.

Returns to the previous page.

Rotates the file 90 degrees

clockwise or counterclockwise.

Moves to the next page.

Moves to the last page.

Changes the display to Full

screen view or Normal screen

view.

Key Function

Menu functions

My files

(Menu 6)

•

Bluetooth visibility

: share the selected

file or the files you want with other

Bluetooth devices.

•

Lock

Unlock

: lock the file to prevent it

from being moved, deleted, and

renamed or unlock the file.

•

Properties

: access the file properties.

•

FileViewer shortcuts

: view the

functions of the keys you can use in

Picsel File Viewer.

Viewing a calendar item, name card,

or bookmark item

After saving items in this folder, you can use

them.

On the Other files screen, select one of the

calendar items, name cards, and bookmark

items.

Using file options

You can access the following options by

pressing <

Options

> on the Other files

screen:

•

View

: open the selected file.

•

: register the

selected name card to a Contacts entry.

•

: register the

selected calendar item to the Calendar.

•

: register the

selected bookmark item to the Bookmark

list.

•

Send via

: send the file via MMS, e-mail,

or Bluetooth.

•

Move

: move the selected file or the files

you want to another folder.

•

Copy

: copy the selected file or the files

you want to another folder.

•

Delete

: delete the selected file or the

files you want.

•

Rename

: change the file name.

•

Create Folder

: add a new folder.

•

List by

: change the sort order of the file

list.

•

Bluetooth visibility

: share the selected

file or the files you want with other

Bluetooth devices.

•

Lock

Unlock

: lock the file to protect it

from being moved, deleted, and

renamed or unlock the file.

•

Details

: access the file properties.

Menu functions

Memory status

This menu displays the amount of memory

currently in use in each media folder. You

can also delete a media file by selecting it

from this menu and pressing <

Delete

Memory card

Use this menu to access the files stored on

the memory card. This option is only

available when you insert a memory card

into the phone.

For details about using files, see the

corresponding menu.

Calendar

(Menu 7)

The Calendar feature enables you to keep

track of your schedule.

To access this menu, press [

] in Idle

mode and select

Calendar

Selecting a day on the calendar

When you enter the

Calendar

menu, the

calendar appears with today’s date indicated

by an orange box.

• Press [Left] or [Right] to move by day.

• Press [Up] or [Down] to move by week.

•Press [

] to move by month.

Creating a new item

You can store scheduled items,

anniversaries, holiday items, private items,

and important items.

Entering a scheduled item

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

Appointment

Important

, or

Private

3. Enter information or change the settings:

•

Title

: enter the title of the item.

•

Details

: enter item details.

•

Start date

and

Start time

: enter

the starting date and time for the

item.

•

End date

and

End time

: enter the

ending date and time for the item.

•

Location

: enter information about

the item location.

•

Alarm

: select to set an alarm for the

item.

Menu functions

Calendar

(Menu 7)

•

Before

: set how long before the item

the alarm is to alert.

•

Alarm tone

: select an alarm tone.

•

Repeat

: select to set the item to

recur and select a time format for an

item to recur.

•

every

: set a repeat interval.

•

By date

: select a specific date of the

month for an item to recur.

•

By day

: select a specific day of the

month for an item to recur.

•

Except weekends

: select to set the

alarm to sound except for weekends.

•

Expiry

: change the expiry setting.

4. Press <

Options

> and select

Save

save the item.

Entering an anniversary

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

Anniversary

3. Enter information or change the settings:

•

Occasion

: enter information about the

anniversary.

•

Date

: enter the date.

•

Alarm

: select to set an alarm for the

anniversary.

•

Before

: set how long before the item

the alarm is to alert.

•

Alarm time

: enter the alarm time.

•

Alarm tone

: select an alarm tone.

•

Repeat every year

: select to set the

phone to remind you of the anniversary

every year.

4. Press <

Options

> and select

Save

save the anniversary.

Entering a holiday

1. Select a date on the calendar.

2. Press <

Options

> and select

Create

→

Holiday

3. Enter information or change the settings:

•

Occasion

: enter information about

the holiday.

You can retrieve person’s birthday

information from Contacts by pressing

Options

> and selecting

Birthday from

Contacts

Menu functions

•

Date

: enter the date.

•

Repeat every year

: select to set the

phone to remind you of the holiday

every year.

4. Press <

Options

> and select

Save

save the holiday.

Consulting the calendar

Once you have scheduled items, the square

brackets appear on the corner of the date

box.

Viewing an item

1. Select a date on the calendar to display

the items for that day. The list of items

displays.

2. Select an item to view its details.

From the item list, press <

Options

> to

access the following options:

•

View

: access the selected item.

•

Create

: add a new item.

•

Send

: send the item via MMS, e-mail, or

Bluetooth.

•

View mode

: change the calendar view

mode.



p. 81

•

Event list

: display all items of the

selected item type.

•

Delete

: delete the selected item or all of

the items for the selected day.

•

Save to My files

: save the selected item

as a data file in the

Other files

folder.

•

Print via Bluetooth

: print the item

details via a Bluetooth-compatible

printer. Some printers may not be

compatible with the phone.

•

Settings

change the default calendar

settings:

Starting day

: select which day of the

week the calendar starts with.

Default view mode

: select the default

calendar view mode.

•

Missed alarm

event

: access the missed

event alarms.

•

Memory status

: access memory

information for the items stored on the

calendar, as well as for tasks and

memos. You can also delete an item by

selecting it from this menu and pressing

Delete

Menu functions

Calendar

(Menu 7)

Using calendar options

On the calendar, press <

Options

> to access

the following options:

•

View

: display the items stored for the

selected date.

•

View mode

: change the calendar view

mode.



p. 81

•

Create

: add a new item.

•

Go to

go to today’s date or enter a

specific date.

•

Event list

: display all items of the

selected item type.

•

Delete

: delete the selected item or the

items for the specific period.

•

Settings

change the default calendar

settings:

Starting day

: select which day of the

week the calendar starts with.

Default view mode

: select the default

calendar view mode.

•

Missed alarm event

: access the missed

event alarms.

•

Memory status

: access memory

information for the items stored on the

calendar, as well as for tasks and

memos. You can also delete an item by

selecting it from this menu and pressing

Delete

Viewing a different mode

By default, the calendar appears in Monthly

view mode. You can change the calendar

display to Weekly view mode or Daily view

mode.

Press <

Options

> and select

View mode

→

a view mode.

Daily view

You can view items for the selected date.

The following icons may display to indicate

the type:

If you have set the Repeat and Alarm

options, the and icon display.

Select an item to view its details.

• Appointments • Anniversaries

• Holidays, Private and Important items

Menu functions

Weekly view

You can view items for the selected week. A

cell on the timetable indicates the presence

of a schedule item. Press [ / ] to access

another week.

Select a cell for the date you want.

Camera

(Menu 8)

You can use the camera module embedded

in your phone to take photos and record

videos.

To access this menu, press [

] in Idle

mode and select

Camera

, or press and hold

[].

Taking a photo

You can take photos in various modes. The

camera produces JPEG photos.

Taking a photo with the phone open

1. Access the

Camera

menu to turn on the

camera. You can also press and hold

[ ] in Idle mode.

2. Make any desired adjustments.

• Press < > to use camera options.



next section

• Use the keypad to change the camera

settings or switch to other

modes.



p. 84

3. Press [

] or [ ] to take a photo.

The photo is saved in the

My photos

folder.

• Do not take photos or record videos of

people without their

permission.

• Do not take photos or record videos in a

place where cameras are not allowed.

• Do not take photos or record videos in a

place where you may interfere with

another person’s privacy.

When you take a photo in direct sunlight or

in bright conditions, shadows may appear on

the photo.

To Press

use photo options <

Options

> or

<>.



p. 85

delete the photo [

] and then <

Yes

Menu functions

Camera

(Menu 8)

Using camera options in Capture

mode

In Capture mode, press < > to access the

following options:

•

Take photo

: take a photo.

•

Switch camera

: switch between the

front camera lens and rear camera lens.

•

Shooting mode

: take a photo in the

following modes:

Single shot

: take a photo in Normal

mode. You can select whether the

camera automatically saves a photo.

Multi-shot

: take a series of action stills.

You can select the number of photos the

camera will take.

Mosaic style

: take several stills and

save them in one frame. You can select

the layout.

•

Effects

: change the colour tone or apply

a special effect.

•

Frames

: apply a decorative frame.

•

Timer

: set a time delay before the

camera takes a photo.

•

Record video

: switch to Record mode.

•

Go to Images

: access the

My files

folder.

•

Camera settings

: change the default

settings for taking a photo. Press [Left]

or [Right] to scroll through the following

setting options:

Size

: select an image size.

Quality

: select an image quality.

Display

select a preview screen.

Scene program

: set whether to use

Night shot mode.

Focus mode

: select a focus mode.

Spot metering

: adjust the exposure

based on a specific area of the image.

Select

to display the spot focus frame

in the middle of the image, and change

the exposure according to the brightness

of the image fragment in the frame.

send the photo

via MMS

[



p. 53

return to Capture

mode

Back

> or < >.

To Press

Menu functions

Shutter sound

: select a camera shutter

sound.

Multi-shot speed

: select the shooting

speed in Multi Shot mode.

Single shot mode

: select whether the

camera automatically saves a photo.

White balance

: adjust the colour

balance of the image. You can make your

photo appear warmer or cooler.

Default storage

: select the memory

location to store photos, if a memory

card is inserted.

Default name

: change the default

prefix for file names.

•

Camera shortcuts

: view the functions

of the keys you can use in Capture

mode.

Using the keypad in Capture mode

You can use the keypad to customise your

camera settings in Capture mode.

Key Function

Left/

Right

Adjusts the brightness.

Up/

Down

Zooms in or out. (Not available for

the maximum size)

Flips the image vertically.

Shows the mirror image.

Switches to Record mode.



p. 85

Changes the image size.

Changes the image quality.

Changes the shooting mode.

Changes the colour tone or

applies a special effects.

Changes the white balance

setting.

Adds a decorative frame.

Sets the timer.

Goes to the

My files

folder.



p. 69

Changes a preview screen.

Key Function

Menu functions

Camera

(Menu 8)

Using photo options

After saving a photo, press < > or

Options

> to access the following options:

•

View

: access one of the multi-shot

photos.

•

Send

: send the file via MMS, or

Bluetooth.

•

Delete

: delete the selected file, the files

you want, or all files.

•

Viewfinder

: return to Capture mode.

•

Set as

set the photo as your wallpaper

for display, or as a caller ID image for a

Contacts entry.

•

Edit

: edit the photo by using various

tools.



p. 70

•

Rename

change the file name.

•

Go to Images

: access the

My files

folder.

•

Lock

Unlock

: lock the file to prevent it

from being deleted, and renamed, or

unlock the file.

•

Bluetooth visibility

: share the file with

other Bluetooth devices.

•

Details

: access the file properties.

Recording a video

You can record a video of what is displayed

on the camera screen and save it.

Recording a video

1. Access the

Camera

menu to turn on the

camera. You can also press and hold

[ ] in Idle mode.

2. Press [

] to switch to Record mode.

3. Make any desired adjustments.

• Press < > to use camera options.



next section

• Use the keypad to change the camera

settings or switch to other

modes.



p. 86

4. Press [

] or [ ] to start recording.

5. Press [

] or [ ] to stop recording.

The video is saved in the

My video clips

folder.

To Press

use video options <

Options



p. 87

delete the video

clip

[

] and then

Yes

Menu functions

Using camera options in Record mode

In Record mode, press < > to access the

following options:

•

Record video

: start recording.

•

Switch camera

: switch between the

front camera lens and rear camera lens.

•

Effects

change the colour tone or apply

a special effect.

•

Timer

: set a time delay before the

camera starts recording.

•

Take photo

: switch to Capture mode.

•

Go to Videos

: access the

My files

folder.

•

Camcorder settings

: change the

following settings for recording a video.

Press [Left] or [Right] to scroll through

the following setting options:

Recording mode

: select a video

recording mode. If you select

Limit for

MMS

, you can record a video suitable for

an MMS message.

Size

: select a frame size.

Quality

: select an image quality.

Audio recording

: record audio with a

video clip.

Default storage

: select the memory

location to store videos, if a memory

card is inserted.

Default name

: change the default

prefix for file names.

•

Camcorder shortcuts

: view the

functions of the keys you can use in

Record mode.

Using the keypad in Record mode

You can use the keypad to customise your

camera settings in Record mode.

play back the

video clip

[

return to Record

mode

Back

To Press

Key Function

Left/

Right

Adjusts the brightness.

Menu functions

Camera

(Menu 8)

Using video options

After saving a video clip, press <

Options

to access the following options:

•

Play

play back the video clip.

•

Delete

: delete the file.

•

Viewfinder

: return to Record mode.

•

Rename

: change the file name.

•

Go to videos

: access the

My files

folder.

•

Lock

Unlock

: lock the file to prevent it

from being deleted and renamed, or

unlock the file.

•

Bluetooth visibility

: share the file with

other Bluetooth devices.

•

Show controller

Hide controller

: set

the video player to display or hide the

controller.

•

Details

: access the file properties.

•

Settings

: change the default settings for

playing video files:

Equalizer type

: select an equaliser

mode.

3D sound

: turn 3D sound on or off.

Visualization Type

: select a playback

animation.

Volume

: select a volume level.

Show controller

: set the video player

to display or hide the controller.

Up/

Down

Zooms in or out.

Flips the image vertically.

Shows the mirror image.

Switches to Capture mode.



p. 82

Changes the frame size.

Changes the image quality.

Changes the video recording

mode.

Changes the colour tone or

applies a special effect.

Mutes or unmutes audio.

Sets the timer.

Goes to the

My files

folder.



p. 69

Key Function

Menu functions

Bluetooth

(Menu 9)

Using Bluetooth wireless, you can connect

the phone wirelessly to other Bluetooth

devices and exchange data with them, talk

hands-free, or control the phone remotely.

Bluetooth technology allows free wireless

connections between all Bluetooth-compliant

devices within a range of 10 metres. Since

the devices communicate using radio waves,

they do not need to be in line of sight to

each other.

To access this menu, press [

] in Idle

mode and select

Bluetooth

Setting up the Bluetooth feature

The

Bluetooth

menu provides the following

options:

•

Activation

: activate or deactivate the

Bluetooth feature.

•

My devices

search for connectable

Bluetooth devices.

•

My phone’s visibility

: allow other

Bluetooth devices to locate your phone,

or not.

•

My phone’s name

: assign a Bluetooth

device name to your phone, which is

then displayed on other devices.

•

Secure mode

: determine if the phone

asks for your confirmation when other

devices access your data.

•

Bluetooth service

: display available

Bluetooth services.

Searching for and pairing with a

Bluetooth device

1. From the

Bluetooth

menu, select

devices

2. Select

Search new device

• If there are obstacles between the

devices,

the

operating distance may be

reduced.

• It is recommended that you do not use the

Bluetooth feature while using multimedia

features, such as voice recorder, camera,

and media player, or vice versa, for the

better performance.

• Some devices, especially those that are

not tested or approved by SIG, may be

incompatible with your phone.

Menu functions

Bluetooth

(Menu 9)

After searching, a list of devices to which

you can connect displays. The following

icons indicate the type of device:

• Hands-free car kit or headset

• Mobile phone

• Computer

• PDA

• Unknown device

• Printer

The colour of the icon indicates the

status of the device:

• Grey for unpaired devices

• Blue for paired devices

• Red for devices that are currently

connected to your phone

3. Select a device.

4. Enter a Bluetooth PIN and press <

This code is used just once and you do

not need to memorise it.

When the owner of the other device

enters the same code, pairing is

complete.

Using device options

From the device list, press <

Options

> to

access the following options:

•

Connect

: connect to a headset or

hands-free car kit.

•

Disconnect

: end the connection with

the connected device.

•

Browse device

: search for data from

the device and import data directly to

your phone.

•

Service list

: access the Bluetooth

service list of the device.

•

Authorise device

Unauthorise

device

: determine whether the phone

asks you to permit connection when

other devices try to connect to your

phone.

•

Delete

: remove the selected device or

all devices from the list.

•

Rename

: rename the selected device.

Sending data via Bluetooth

1. Activate the Bluetooth feature.

2. Select the application in which the item

you want to send is stored.

Some devices, especially headsets or hands-

free car kits, may have a fixed Bluetooth

PIN, such as

0000

. If the other device has

one, you must enter the code.

Menu functions

3. Scroll to the item you want and press

Options

4. Select

Send contact details

Send

Send via

→

Via

bluetooth

Bluetooth

5. Select

Search new device

The phone searches for devices within

range and displays a list of available

devices.

6. Select a device.

7. If necessary, enter the Bluetooth PIN

needed for pairing and press <

Receiving data via Bluetooth

To receive data via Bluetooth, your phone’s

Bluetooth feature must be active and its

visibility must be enabled.

1. If an unauthorised Bluetooth device

sends data to your phone, press <

Yes

to allow the device to access your phone.

2. Press <

Yes

> to receive data.

Applications

(Menu *)

You can use convenient features, such as a

voice recorder, world clock, calculator,

converter, timer, and stopwatch.

To access this menu, press [

] in Idle

mode and select

Applications

Memo

(Menu *.1)

You can create a list of memos.

Creating a memo

1. Press <

Options

> and select

Create

2. Enter the memo contents and press

[

Viewing a memo

Select a memo from the list.

Using memo options

From the memo list, press <

Options

> to

access the following options:

•

View

: access the selected memo.

•

Create

: add a new memo.

Menu functions

Applications

(Menu *)

•

Send

: send the memo as a data file via

MMS, e-mail, or Bluetooth.

•

Delete

: delete the selected memo or all

memos.

•

Save to My files

: save the selected

memo as a data file in the

Other files

folder.

•

Print via Bluetooth

: print the memo

details via a Bluetooth-compatible

printer. Some printers may not be

compatible with the phone.

•

Memory status

: access memory

information for the items stored on the

calendar, as well as for tasks and

memos. You can also delete an item by

selecting it from this menu and pressing

Delete

Tasks

(Menu *.2)

You can create a list of tasks you need to

complete.

Entering a task

1. Press <

Options

> and select

Create

2. Enter information or change the settings:

•

Title

: enter the title for the task.

•

Task

: enter task details.

•

Start date

: enter the starting date.

•

Due date

: enter the ending date.

•

Alarm

: select to set an alarm for the

task.

•

before

: set how long before the task

the alarm is to alert.

•

Alarm time

: enter the alarm time.

•

Alarm tone

: select an alarm tone.

•

Priority

: select a priority level.

3. Press <

Options

> and select

Save

save the task.

Viewing a task

A check mark appears in the status check

box if the task has been completed. If you

have set the Alarm option, the icon

displays.

Select a task from the list.

Using task options

From the task list, press <

Options

> to

access the following options:

•

View

: access the selected task.

Menu functions

•

Create

: add a new task.

•

Send

: send the task as a data file via

MMS, e-mail, or Bluetooth.

•

Done

Not done

: change the status of

the task.

•

Sort by

: change the sort order of the

list.

•

Delete

: delete the selected task, all

tasks, or finished tasks.

•

Save to My files

: save the selected task

as a data file in the

Other files

folder.

•

Print via Bluetooth

: print the task

details via a Bluetooth-compatible

printer. Some printers may not be

compatible with the phone.

•

Missed alarm event

: access the missed

event alarms.

•

Memory status

: access memory

information for the items stored on the

calendar, as well as for tasks and

memos. You can also delete an item by

selecting it from this menu and pressing

Delete

Voice recorder

(Menu *.3)

Use this menu to record voice memos. A

voice memo can be up to one hour long.

Recording a voice memo

1. Press [

] to start recording.

2. Speak into the microphone.

Press [

] to pause or resume the

recording.

3. Press [Down]. The voice memo is saved

automatically.

4. Press [

] to review the memo, or press

[Up] to record additional memos.

Playing a voice memo

1. From the voice recorder screen, press

Options

> and select

My voice clips

→

Sounds

2. Select a voice memo.

During playback, use the following keys:

Key Function

Pauses or resumes playback.

Menu functions

Applications

(Menu *)

Using voice recorder options

After playback, press <

Options

> to access

the following options:

•

Play

: play the selected voice memo in

Review mode.

•

Record

: record a new voice memo.

•

My voice clips

: access the

My files

folder.

•

Send

: send the file via MMS, e-mail, or

Bluetooth.

•

Activate key

: get a new licence key

when the key for the selected DRM file

expires.

•

Reactivate key

: get another licence key

even when the key for the selected DRM

file has not expired.

•

Set as

: set the sound as your ringtone

for a voice call or video call, or as a

ringtone for a Contacts entry.

•

Delete

: delete the file.

•

Rename

: change the file name.

•

Bluetooth visibility

: share the selected

file with other Bluetooth devices.

•

Lock

Unlock

: lock the file to prevent it

from being deleted and renamed, or

unlock the file.

•

Details

: access the file properties.

•

Record settings

: customise the default

settings for the voice recorder:

Default name

: change the default

prefix of file names.

Recording time

select a maximum

recording time.

Left Moves backward in a file.

Right Moves forward in a file.

Adjusts the volume.

Down Stops playback.

Up Switch to Record mode ( ) or

Review mode ( ).

Key Function

Menu functions

World clock

(Menu *.4)

Use this menu to find out the current time in

another part of the world.

Viewing world time

1. Press [Left] or [Right] to scroll to the city

you want on the upper line or lower line.

As the time line moves, the time and

date of the given zone display.

2. Press [

] to save the time zone.

Applying daylight saving time

1. From the world map, press <

Options

and select

Daylight saving

2. Press [

] to select the time zones you

want.

3. Press <

Done

4. Press <

Options

> and select

Save

Calculator

(Menu *.5)

Use this menu to perform basic arithmetic

functions such as addition, subtraction,

multiplication, and division.

Performing a calculation

1. Enter the first number.

• Press [ ] or [ ] to include a decimal

point or brackets.

• Press [ ] or [ ] to move the cursor.

2. Enter the operation for your calculation

by pressing the Navigation keys.

3. Enter the second number.

4. Press [

] to view the result.

5. If necessary, repeat from step 2 to

continue the calculation.

Converter

(Menu *.6)

Use this menu for common conversions,

such as currency and temperature.

Performing a calculation

1. Select the converter type you want.

2. Press [Left] or [Right] to select the

original unit and press [Down].

3. Enter the value to be converted and

press [Down].

• Press [ ] to insert a decimal point.

• Press [ ] to change the temperature

to above zero (+) or below zero (-).

You can access the Converter feature by

pressing <

Converter

Menu functions

Applications

(Menu *)

4. Press [Left] or [Right] to select the unit

you want to convert to.

The equivalent value for the amount you

entered displays.

Using converter options

Press <

Options

> to access the following

options:

•

View Rate

: display the currency rate

list. You can edit the rate or add more

currency rates.

•

Clear

: clear the current values.

•

Reverse

: reverse the conversion.

Timer

(Menu *.7)

Use this menu to set a period of time for the

phone to count down. The phone sounds an

alarm when the specified period of time has

expired.

Starting the timer

1. Press <

Set

2. Enter the length of time you want to

count down and press <

3. Press [

] to start counting down.

Stopping the timer

• Press any key to stop the timer when it

rings.

•Press [

] on the Timer screen to stop

the timer before it rings.

Stopwatch

(Menu *.8)

Use this menu to measure elapsed time. The

maximum time is 24 hours.

1. Press [

] to start the stopwatch.

2. Press [

] to select an interval. You can

repeat this step for a total of 50

intervals.

3. To reset the stopwatch, press <

Reset

SAT

(Menu *.9)

This menu is available if you use a USIM/SIM

card that supports SIM Application Toolkit

menus and provides additional services,

such as news, weather, sports,

entertainment, and location services.

Available services may vary, depending on

your service provider’s plans.

For details, see your

USIM/

SIM card

instructions or contact your service provider.

Menu functions

Alarms

(Menu 0)

Use this menu to set alarms to sound at

specific times. The alert type for a normal

alarm corresponds to the call alert type

settings in the currently selected profile. A

wake-up alarm is not affected by your profile

setting.

To access this menu, press [

] in Idle

mode and select

Alarms

Setting an alarm

1. Select the type of alarm.

2. Specify the following alarm settings:

•

Name

: (for a normal alarm) enter a

name for the alarm.

•

Alarm activation

: activate the

alarm.

•

Alarm time

: enter the alarm time.

•

Alarm type

: select an alert type for

the alarm.

•

Alert tone

: select an alarm tone.

•

Alarm volume

: select the volume

for the alarm melody.

•

Recurrence

: select the days for the

alarm.

•

Snooze

: set the snooze interval you

want.

•

Repeat

: set a repeat option.

3. Press [

] to save the alarm.

Stopping an alarm

When the time for an alarm comes and the

alarm sounds:

• For a non-wake-up alarm, press any key.

• For a wake-up alarm, press <

> or

[

]. Press any key, except for <

and [

], to cause it to sound again

after the specified minutes.

Deactivating an alarm

1. Select the alarm you want to deactivate.

2. Select

Off

on the

Alarm activation

line.

3. Press [

Setting alarms to sound when the

phone is off

From the Alarms screen, select

Auto power

→

Menu functions

Settings

(Menu #)

If the phone is off when it is time for the

alarm to sound, the phone switches on and

sounds the alarm.

Settings

(Menu #)

The

Settings

menu provides you with

various setting options to customise the

phone to your preferences and needs. You

can also reset the settings to their default

status.

To access this menu, press [

] in Idle

mode and select

Settings

Phone profiles

(Menu #.1)

Your phone provides you with sound profiles

that allow you to quickly and easily change

the sound settings of the phone for different

events or situations. Use this menu to adjust

the properties of each profile and activate

the profile you need.

Editing a profile

1. Scroll to the profile you want.

2. Press <

Options

> and select

Edit

3. Change the sound settings. Press [Left]

or [Right] to access the options in other

tabs:

•

Call alert type

: select an alert type

for the call ringer.

•

Voice call ringtone

: select a

ringtone for the call ringer of voice

calls.

•

Video call ringtone

: select a

ringtone for the call ringer of video

calls.

•

Ringtone volume

: adjust the

volume for the call ringer.

•

Auto reply

: set the phone to send a

reply message automatically.

•

Call answer mode

(for Car) select

how to answer an incoming call.

•

Message alert type

: select an alert

type for the message ringer.

•

Message alert tone

: select a

ringtone for the message ringer.

•

Message alert repetition

: select if

the phone repeats reminding you of a

new message.

•

Alert tone volume

: adjust the

volume for the message ringer.

Menu functions

•

Keypad tones

: select a tone which

sounds when you press a key

•

Power on type

: select an alert type

for the power-on ringer.

•

Power off type

: select an alert type

for the power-off ringer.

•

Slide tone

: cause the phone to

sound when you open or close the

phone.

•

Volume, phone sounds

: adjust the

phone volume for keytones and

sound effect tones.

4. When you have finished, press

Options

> and select

Save

Changing an active profile

From the profile list, select the profile you

want.

Time & date

(

#.2)

Use this menu to change the time and date

displayed on your phone.

•

Time set mode

: select one of the

following options:

Manual update

: your phone will read

the MCC (Mobile Country Code) from the

network and automatically update the

current time for the country that you are

in when you travel abroad.

Auto time update

: your phone will

receive time information from the

network.

User set

: you can set the time and date

manually.

•

Home zone

: select your home time

zone. You can view the time difference

between your home time zone and Green

witch Mean Time (GMT). If you want to

apply Daylight Saving Time (DST) to

your time zone, select

Daylight saving

•

Time

: enter the current time. To select

AM or PM for 12-hour time format, press

[Right].

•

Date

enter the current date.

•

Time format

: select a time format.

•

Date format

select a date format.

Time information may not be updated

when you move to one time zone to

another within a country.

Menu functions

Settings

(Menu #)

Display settings

(Menu #.3)

Use this menu to change settings for the

display and the light.

Display settings

(Menu #.3.1)

Use this menu to change settings for the

display.

•

Wallpaper

: you can change the

background image that is displayed on

the display. You can select one of the

images in the

Images

folder.

•

Greeting message

: use this menu to

enter the greeting that is displayed

briefly when the phone is switched on.

•

LCD brightness

: use this menu to

adjust the brightness of the display.

•

Dialling display

: use this menu to

customise the settings for the numbers

entered and the background colour of

the display while dialling.

Light settings

(Menu #.3.2)

Use this menu to change settings for the

light.

•

Backlight time

: you can select the

length of time the backlight or display

stays on when the phone is not used.

: select the length of time the

backlight stays on.

Dim

: select the length of time the

display stays on in Dim mode after the

backlight turns off. After a specified time,

the display turns off.

•

Keypad light

: you can set how the

phone controls the use of the keypad

light.

Use at any time

: the keypad light is

always used.

Use at custom time

: the keypad light is

used at a specified time period.

Phone settings

(Menu #.4)

Many different features of your phone’s

system can be customised to suit your

preferences.

100

Menu functions

Language

(Menu #.4.1)

Use this menu to select a language for the

display text or T9 input mode. If you select

Automatic

, the phone uses the same

language as the USIM/SIM card.

Shortcuts

(Menu #.4.2)

You can use the Navigation keys as shortcut

keys to access specific menus directly from

Idle mode. Use this menu to assign these

shortcut assignments to a key.

Assigning a shortcut menu

1. Select a key to be used as a shortcut

key.

2. Select the menu that will be assigned to

the key.

Using shortcut options

On the Shortcuts screen, press <

Options

to access the following options:

•

Assign

: assign a shortcut menu.

•

Change

: change a shortcut menu

assignment.

•

Remove

: deactivate the shortcut

assignment to the selected key.

•

Remove all

: deactivate all shortcut

assignments.

Own number

(Menu #.4.3)

Use this menu to check your phone

numbers, or to assign a name to each of the

numbers. Changes made here do not affect

the actual subscriber numbers on your

USIM/SIM card.

Volume key

(Menu #.4.4)

Use this menu to set whether the phone

mutes the call ringer or rejects a call if you

press and hold [

] when a call comes in.

Camera key

(Menu #.4.5)

Use this menu to set a default function for

[]. If you select

Always ask

, the phone

will ask you to select the function each time

you press and hold [ ] in Idle mode.

Slide settings

(Menu #.4.6)

Use this menu to set how the phone reacts

when you open it for an incoming call, and

when you close it while using a function.

•

Slide up

: set whether or not to answer a

call by opening the phone.

Menu functions

Settings

(Menu #)

101

•

Slide down

: set whether or not the

phone maintains the menu you are using

when you close the phone.

Call settings

(Menu #.5)

Use this menu to set options for call

functions.

All calls

(Menu #.5.1)

Use this menu to change the default settings

for voice calls, video calls, and data calls.

•

Show my number

: prevent your phone

number from being displayed on the

phone of the person being called. If you

select

By network

, the phone will use

the default setting provided by the

network.

•

Closed user group

: set incoming and

outgoing calls to be restricted to a

selected user group. For details about

how to create a closed user group,

please contact your service provider:

Use this user group

: activate Closed

User Group (CUG) index numbers.

Outside access

: enable calls to

numbers other than those in the Closed

user group. This feature depends on the

nature of your CUG subscription.

Default group

: enable the default CUG,

if you have set one with your service

provider. When making a call, you are

given the option of using your default

CUG, instead of selecting one from the

list.

Group index

: add, delete, or activate

CUG index numbers.

•

Auto reject

: activate the Auto reject

feature. You can also set the phone to

reject a call from the unknown or

specified numbers.

•

Answering mode

: set how to answer

incoming calls.

When you set

Slide down

Continue

operation

, the keypad lock works just in

Idle mode or after the display turns off.

Some networks do not allow the user to

change this setting.

102

Menu functions

•

Show caller ID

: set the phone to

display missed call notifications with the

most recently missed caller’s

information.

•

Call status tones

: select the various

tones on the phone you want to turn on

or off:

Call connect tone

: cause the phone to

beep when a call is connected to the

system.

Minute minder

: cause the phone to

beep every minute during an outgoing

call to keep you informed of the length of

your call.

Call end tone

: cause the phone to beep

when a call is disconnected by the other

person or the faded signal.

•

Alerts on call

: set the phone to beep

when you receive a new message or

when the time for an alarm comes during

a call.

Voice call

(Menu #.5.2)

Use this menu to access network services for

voice calls.

Setting a call diverting option

This network service reroutes incoming calls

to a different phone number that you

specify.

1. From the Voice call screen, select

Call

diverting

2. Select a call diverting option:

•

Always

: divert all calls.

•

If busy

: divert calls when you are on

another call.

•

If no

: divert calls when you do

not answer the phone.

•

If out of reach

: divert calls when

you are not in an area covered by

your service provider or when your

phone is switched off.

•

Cancel

all

: cancel all call diverting

options.

3. Enter the number to which the calls will

be diverted in the

Divert to

line.

Menu functions

Settings

(Menu #)

103

4. If you select

no reply

, move to the

Waiting time

line and select the length

of time the network delays before

diverting a call.

5. Press <

Options

> and select

Activate

To deactivate the call diverting, select

Deactivate

Setting a call barring option

This network service allows you to restrict

your calls.

1. From the Voice call screen, select

Call

barring

2. Select a call barring option:

•

All

outgoing calls

: prohibit

outgoing calls.

•

Outgoing international calls

prohibit international calls.

•

International calls except

home

only allow calls to numbers within the

current country when you are

abroad, and to your home country.

•

All

incoming calls

: prohibit

incoming calls.

•

Incoming when roaming

: prohibit

incoming calls when you use your

phone outside of your home country.

•

Cancel

all

: cancel all call barring

settings, allowing calls to be sent and

received normally.

3. Enter the call barring password supplied

by your service provider.

4. Press <

Options

> and select

Activate

To deactivate the call barring, select

Deactivate

Setting a call waiting option

This network service informs you when

someone is trying to reach you while you are

on another call.

1. From the Voice call screen, select

Call

waiting

2. Press <

Options

> and select

Activate

To deactivate the call waiting, select

Deactivate

You can change the call barring password

obtained from your service provider. On the

Restrict calls screen, press <

Options

> and

select

Change password

104

Menu functions

Setting an auto redial option

This service allows you to set the phone to

make up to ten attempts to redial a phone

number after an unsuccessful call.

1. From the Voice call screen, select

Auto

redial

2. Select

Video call

(Menu #.5.3)

Use this menu to change the default settings

for using the video call feature.

•

Select my image

: select an image to be

displayed on the other’s phone if you will

not show your image via the camera.

•

Use call fail options

: set the phone to

retry when a voice call does not connect.

•

Call diverting

: reroute incoming video

calls to a different phone number that

you specify.



p. 102

•

Call barring

: restrict video calls.



p. 103

•

Auto redial

: set the phone to make up

to ten attempts to redial a phone number

after an unsuccessful call.

Data call

(Menu #.5.4)

Use this menu to change the default settings

for using the data call feature.

•

Call diverting

: reroute incoming data

calls to a different phone number that

you specify.



p. 102

•

Call barring

: restrict data calls.



p. 103

•

Waiting

: set the network to inform you

when someone is trying to reach you

while on another call.



p. 103

Security

(Menu #.6)

Use this menu to protect the phone against

unauthorised use by managing the several

access codes of your phone and USIM/SIM

card.

If you enter an incorrect PIN/PIN2 three

times, the USIM/SIM card is blocked. To

unblock it, you need to enter your PUK/

PUK2 (Personal Unblocking Key). The codes

are supplied by your network operator.

Menu functions

Settings

(Menu #)

105

Phone lock

(Menu #.6.1)

Use this menu to protect the phone from

unauthorised use. When this feature is

enabled, you must enter a 4- to 8-digit

phone password each time the phone is

switched on.

The password is preset to

00000000

. To

change the password, use the

Change

phone password

menu.

SIM lock

(Menu #.6.2)

This menu allows your phone to work only

with the current USIM/SIM by assigning a

SIM password. You must enter the SIM

password to use a different USIM/SIM card.

PIN lock

(Menu #.6.3)

The 4- to 8-digit PIN (Personal Identification

Number) protects your USIM/SIM card

against unauthorised use. When this feature

is enabled, the phone requires your PIN each

time it is switched on.

Privacy lock

(Menu #.6.4)

Use this menu to lock access to messages,

media files, call logs, Contacts entries,

calendar data, memos, or tasks. When a

privacy option is enabled, you must enter

the phone password to access the locked

items.

Fixed dialling mode

(Menu #.6.5)

If supported by your USIM/SIM card, Fixed

Dialling Number (FDN) mode restricts your

outgoing calls to a limited set of phone

numbers. When this feature is enabled, you

can make calls only to phone numbers

stored on the USIM/SIM card.

Change phone password

(Menu #.6.6)

Use this menu to change your phone

password.

Change PIN code

(Menu #.6.7)

Use this menu to change your PIN. The PIN

lock feature must be enabled to change the

PIN.

106

Menu functions

Change PIN2 code

(Menu #.6.8)

If supported by your USIM/SIM card, use

this menu to change your current PIN2.

Mobile tracker

(Menu #.6.9)

When someone tries to use your phone with

another USIM/SIM card, the phone will

automatically send the preset tracking

message to your family or friends. You can

check the phone number from which the

messages are sent and then track your

phone. This feature is useful when the phone

is stolen or lost.

1. Enter the phone password and press

Confirm

2. Specify the following options:

•

Activation

: activate or deactivate

the Mobile tracker feature.

•

Recipients

: specify phone numbers

to which you want to send the

tracking messages.

•

Sender

: enter the sender’s name.

•

Messages

: check the preset tracking

message text.

3. When you have finished, press <

Save

4. Press <

> if you agree to the

terms and conditions of service listed on

the screen.

Application settings

(Menu #.7)

You can customise the settings for using

applications available on the phone.

Contact settings

(Menu #.7.1)

Use this menu to set up the default contact

settings.

Speed dial

(Menu #.7.1.1)

Use this menu to assign speed dial numbers

(2 to 9) to eight of your most frequently

called numbers.

Sending of the tracking message will be

billed to the user of the unauthorised USIM/

SIM card. To use your phone with any other

USIM/SIM card, you must first deactivate the

Mobile tracker feature.

Menu functions

Settings

(Menu #)

107

Assigning speed dial entries

1. Scroll to a key location from

. Key

is reserved for your voicemail server.

2. Press <

Options

> and select

Assign

→

Contacts

FDN contacts

3. Select the contact you want from the

contact list.

4. Select a number, if the contact has more

than one number.

Managing speed dial entries

From the Speed dial screen, press

Options

> to access the following options:

•

Assign

: assign a number to an

unassigned key.

•

View

: check the name and number

assigned to a key.

•

Change

: assign a different number to a

key.

•

Remove

: clear the speed dial setting for

a key.

•

Voice call

: make a voice call.

•

Video call

: make a video call.

Dialling speed dial numbers

In Idle mode, press and hold the appropriate

key.

Save new contacts to

(Menu #.7.1.2)

Use this menu to select the default memory

location for saving contacts. If you select

Always ask

, the phone will ask you to

select a memory location each time you save

a number.

View contacts from

(Menu #.7.1.3)

Use this menu to set the memory location

from which Contacts shows entries.

Own number

(Menu #.7.1.4)

Use this menu to check your phone

numbers, or to assign a name to each of the

numbers. Changes made here do not affect

the actual subscriber numbers on your

USIM/SIM card.

Messaging settings

(Menu #.7.2)

Use this menu to change the default settings

for using the messaging services.



p. 63

108

Menu functions

Calendar settings

(Menu #.7.3)

Use this menu to change the default settings

for the calendar.

•

Starting day

: select which day of the

week the calendar starts with.

•

Default view mode

: select the default

calendar view mode.

Camera settings

(Menu #.7.4)

Use this menu to change the default settings

for taking photos.



p. 83

Media player

(Menu #.7.5)

Use this menu to change the default settings

for playing media files in the media

player.



p. 45

Browser settings

(Menu #.7.6)

Use this menu to select a connection profile

to be used for accessing the Internet. You

can also create or edit a profile.



p. 110

Memory settings

(Menu #.7.7)

Use this menu to manage your phone’s

memory or a memory card.

Deleting data

You can delete media files, messages,

contacts, calendar items, and DRM

activation keys.

1. On the Memory settings screen, select

Clear memory

2. Press [

] to select the data type you

want and then <

3. Enter the password and press

Confirm

4. Press <

Yes

> to confirm the deleting.

Checking memory status

You can check the amount of memory being

used for storing data, such as Messaging, My

files, Calendar, and Contacts. You can also

view the amount of shared memory.

1. On the Memory settings screen, select

Memory status

2. Select the item you want to check.

The password is preset to

00000000

You can change this password.



p. 105

Menu functions

Settings

(Menu #)

109

Network settings

(Menu #.8)

Use this menu to change the settings for

connecting to your cellular network.

Network selection

(Menu #.8.1)

Use this menu to select to either manually

select the network to be used when roaming

outside of your home area, or to let the

network be chosen automatically. You can

select a network other than your home

network only if there is a valid roaming

agreement between the two.

Network mode

(Menu #.8.2)

Use this menu to select the network you

use:

•

Automatic

: the phone scans for

available networks.

•

GSM 900/1800

: the phone operates in

the combined GSM 900/1800 network.

•

GSM 1900

: the phone operates in the

GSM 1900 network. This option is only

available in the U.S.A.

•

UMTS

: the phone operates in UMTS (3G

network) networks. You can get a higher

speed quality than on lower generation

networks, and use advanced data and

information services, such as video calls.

Preferred networks

(Menu #.8.3)

Use this menu to add a new network to your

preferred network list, if your USIM/SIM

card supports it.

Adding a network from the network list

1. From the network list, press <

Options

and select

Insert

Add

→

Network

list

2. Scroll to the network you want and press

Insert

> or <

Add

Creating a network

1. From the network list, press <

Options

2. Select

Insert

Add

→

New network

3. Specify network parameters:

•

Country code

: enter the country

code.

•

Network code

: enter the network

code provided by the network

operator.

110

Menu functions

•

Network name

: enter the name for

the network.

•

Network type

: select a network

type.

4. Press <

Insert

> or <

Add

> to add the

network.

Connections

(Menu #.8.4)

Use this menu to create and customise the

profiles containing the settings for

connecting your phone to the network. You

need these settings to use the web browser

or send MMS messages or e-mails.

Creating a profile

1. Press <

Options

> and select

New

2. Specify profile parameters:

•

Set name

: enter a profile name.

•

Access name

: edit the access point

name used for the address of the

GPRS network gateway.

•

Auth type

: choose the type of

authentication used.

•

User ID

: enter the user ID.

•

Password

: enter the user password.

•

Protocol

: select the protocol from

among

WAP

HTTP

, and

Other

•

Home URL

: enter the URL address

of the page to be used as your

homepage.

•

Gateway address

: (WAP only) enter

the gateway address of the proxy

server.

•

Proxy address

Port

: (HTTP only)

set the proxy server address and

port.

•

Secure connection

: (WAP only)

turn the secure mode on or off.

•

Linger time (sec.)

: set a time

period after which the network is

disconnected if there has been no

new data traffic in that time.

Your phone is set up by default for

connecting to the network. If you change the

settings without first checking with your

service provider, the web browser, MMS, and

e-mail features may not work properly.

Menu functions

Settings

(Menu #)

111

•

Advanced settings

provide you

with the following options:

Static IP

: specify if you want to

manually enter an IP address; see

the

Local phone IP

option. If you

want the IP address to be

automatically assigned by the server,

remove the check mark.

Local phone IP

: enter the IP

address obtained from the network

operator, if you selected the

Static

option.

Static DNS

: specify if you want to

manually enter the Domain Name

Server (DNS) address; see the

Server 1

Server 2

option.

If you want the address to be

automatically assigned by the server,

remove the check mark.

Server 1

Server 2

: enter the

Domain Name Server (DNS)

addresses.

Traffic class

: select the traffic class.

3. Press <

Save

> to save the profile.

Using profile options

From the profile list, press <

Options

> to

access the following options:

•

View

: view the properties of the

selected profile.

•

Edit

: edit the selected profile.

•

New

: add a new profile.

•

Rename

: change the profile name.

•

Delete

: delete the profile.

•

Restore

: restore the changed settings

to the default status.

Operator settings

(Menu #.9)

Use this menu to set a service provider

according to the USIM/SIM card you are

using. When you select a service provider,

the phone will automatically turn itself off

and then back on. You can then see the

profiles corresponding to the service

provider in the connection menus.

This menu may not be shown depending on

your service provider.

You cannot edit or delete the default

connection profile.

112

Master reset

(Menu #.0)

Use this menu to reset the phone’s settings

you have changed and clear all data you

have added.

1. Press [

] to select data you want to

reset.

2. Press <

3. Enter the phone password and press

Confirm

4. Press <

Yes

>. The phone automatically

turns itself off and then back on.

Solve problems

Help and personal needs

To save the time and expense of an

unnecessary service call, perform the simple

checks in this section before contacting a

service professional.

When you switch on your phone, the

following messages may appear:

“Please insert SIM card”

• Be sure that the USIM/SIM card is

correctly installed.

“Phone lock”

• The automatic locking function has been

enabled. You must enter the phone’s

password before you can use the phone.

“PIN lock”

• You are using your phone for the first

time. You must enter the PIN supplied

with the USIM/SIM card.

• The PIN lock feature is enabled. Every

time the phone is switched on, the PIN

has to be entered. To disable this

feature, use the

PIN lock

menu.

The password is preset to

00000000

You can change this password.



p. 105

113

Solve problems

“PUK lock”

• The PIN code was entered incorrectly

three times, and the USIM/SIM card is

now blocked. Enter the PUK supplied by

your service provider.

“No service,” “Network failure,” or “Not

done” displays

• The network connection has been lost.

You may be in a weak signal area. Move

and try again.

• You are trying to access an option for

which you have no subscription with your

service provider. Contact the service

provider for further details.

You have entered a number but it was

not dialled

• Be sure that you have pressed [ ].

• Be sure that you have accessed the right

cellular network.

• Be sure that you have not set an

outgoing call barring option.

Your correspondent cannot reach you

• Be sure that your phone is switched on.

([ ] pressed for more than one

second.)

• Be sure that you are accessing the right

cellular network.

• Be sure that you have not set an

incoming call barring option.

Your correspondent cannot hear you

speaking

• Be sure that you have switched on the

microphone.

• Be sure that you are holding the phone

close enough to your mouth. The

microphone is located at the bottom of

the phone.

The phone starts beeping and “Low

battery” flashes on the display

• Your battery is insufficiently charged.

Recharge the battery.

The audio quality of the call is poor

• Check the signal strength indicator on

the display ( ). The number of bars

indicates the signal strength from strong

() to weak ().

114

• Try moving the phone slightly or moving

closer to a window if you are in a

building.

No number is dialled when you re-call a

Contacts entry

• Use the Contacts feature to ensure the

number has been stored correctly.

• Re-store the number, if necessary.

The battery does not charge properly or

the phone sometimes turns itself off

• Wipe the charging contacts both on the

phone and on the battery with a clean

soft cloth.

If the above guidelines do not help you

to solve the problem, take note of:

• The model and serial numbers of your

phone

•Your warranty details

• A clear description of the problem

Then contact your local dealer or Samsung

after-sales service.

Health and safety

information

Exposure to Radio Frequency (RF)

Signals

Certification Information (SAR)

Your wireless phone is a radio transmitter

and receiver. It is designed and

manufactured not to exceed the exposure

limits for radio frequency (RF) energy set by

the Federal Communications Commission

(FCC) of the U.S. government. These FCC

exposure limits are derived from the

recommendations of two expert

organizations, the National Counsel on

Radiation Protection and Measurement

(NCRP) and the Institute of Electrical and

Electronics Engineers (IEEE). In both cases,

the recommendations were developed by

scientific and engineering experts drawn

from industry, government, and academia

after extensive reviews of the scientific

literature related to the biological effects of

RF energy.

115

Health and safety information

The exposure limit set by the FCC for

wireless mobile phones employs a unit of

measurement known as the Specific

Absorption Rate (SAR). The SAR is a

measure of the rate of absorption of RF

energy by the human body expressed in

units of watts per kilogram (W/kg). The FCC

requires wireless phones to comply with a

safety limit of 1.6 watts per kilogram (1.6

W/kg). The FCC exposure limit incorporates

a substantial margin of safety to give

additional protection to the public and to

account for any variations in measurements.

SAR tests are conducted using standard

operating positions accepted by the FCC with

the phone transmitting at its highest

certified power level in all tested frequency

bands. Although the SAR is determined at

the highest certified power level, the actual

SAR level of the phone while operating can

be well below the maximum value. This is

because the phone is designed to operate at

multiple power levels so as to use only the

power required to reach the network. In

general, the closer you are to a wireless

base station antenna, the lower the power

output.

Before a new model phone is available for

sale to the public, it must be tested and

certified to the FCC that it does not exceed

the exposure limit established by the FCC.

Tests for each model phone are performed in

positions and locations (e.g. at the ear and

worn on the body) as required by the FCC.

The highest SAR values for this model phone

as reported to the FCC are:

GSM1900 Head: 0.102 W/Kg, Body-worn:

0.100 W/Kg.

For body worn operation, this model phone

has been tested and meets the FCC RF

exposure guidelines whenused with a

Samsung accessory designated for this

product or when used with an accessory that

contains no metal and that positions the

handset a minimum of 1.5 cm from the

body.

Non-compliance with the above restrictions

may result in violation of FCC RF exposure

guidelines.

SAR information on this and other model

phones can be viewed on-line at

www.fcc.gov/oet/fccid. This site uses the

phone FCC ID number, A3LSGHZ720.

116

Health and safety information

Sometimes it may be necessary to remove

the battery pack to find the number. Once

you have the FCC ID number for a particular

phone, follow the instructions on the website

and it should provide values for typical or

maximum SAR for a particular phone.

Additional product specific SAR information

can also be obtained at www.fcc.gov/cgb/

sar.

Consumer Information on Wireless

Phones

The U.S. Food and Drug Administration

(FDA) has published a series of Questions

and Answers for consumers relating to radio

frequency (RF) exposure from wireless

phones. The FDA publication includes the

following information:

What kinds of phones are the subject

of this update?

The term wireless phone refers here to

hand-held wireless phones with built-in

antennas, often called “cell,” “mobile,” or

“PCS” phones. These types of wireless

phones can expose the user to measurable

radio frequency energy (RF) because of the

short distance between the phone and the

user's head. These RF exposures are limited

by Federal Communications Commission

safety guidelines that were developed with

the advice of FDA and other federal health

and safety agencies. When the phone is

located at greater distances from the user,

the exposure to RF is drastically lower

because a person's RF exposure decreases

rapidly with increasing distance from the

source. The so-called “cordless phones,”

which have a base unit connected to the

telephone wiring in a house, typically

operate at far lower power levels, and thus

produce RF exposures well within the FCC's

compliance limits.

Do wireless phones pose a health

hazard?

The available scientific evidence does not

show that any health problems are

associated with using wireless phones. There

is no proof, however, that wireless phones

are absolutely safe. Wireless phones emit

low levels of radio frequency energy (RF) in

the microwave range while being used. They

117

Health and safety information

also emit very low levels of RF when in the

stand-by mode. Whereas high levels of RF

can produce health effects (by heating

tissue), exposure to low level RF that does

not produce heating effects causes no

known adverse health effects. Many studies

of low level RF exposures have not found

any biological effects. Some studies have

suggested that some biological effects may

occur, but such findings have not been

confirmed by additional research. In some

cases, other researchers have had difficulty

in reproducing those studies, or in

determining the reasons for inconsistent

results.

What is FDA's role concerning the

safety of wireless phones?

Under the law, FDA does not review the

safety of radiation-emitting consumer

products such as wireless phones before

they can be sold, as it does with new drugs

or medical devices. However, the agency has

authority to take action if wireless phones

are shown to emit radio frequency energy

(RF) at a level that is hazardous to the user.

In such a case, FDA could require the

manufacturers of wireless phones to notify

users of the health hazard and to repair,

replace or recall the phones so that the

hazard no longer exists.

Although the existing scientific data do not

justify FDA regulatory actions, FDA has

urged the wireless phone industry to take a

number of steps, including the following:

• “Support needed research into possible

biological effects of RF of the type

emitted by wireless phones;

• “Design wireless phones in a way that

minimizes any RF exposure to the user

that is not necessary for device function;

and

• “Cooperate in providing users of wireless

phones with the best possible

information on possible effects of

wireless phone use on human health.

FDA belongs to an interagency working

group of the federal agencies that have

responsibility for different aspects of RF

safety to ensure coordinated efforts at the

federal level. The following agencies belong

to this working group:

118

Health and safety information

• “National Institute for Occupational

Safety and Health

• “Environmental Protection Agency

• “Federal Communications Commission

• “Occupational Safety and Health

Administration

• “National Telecommunications and

Information Administration

The National Institutes of Health participates

in some interagency working group

activities, as well.

FDA shares regulatory responsibilities for

wireless phones with the Federal

Communications Commission (FCC). All

phones that are sold in the United States

must comply with FCC safety guidelines that

limit RF exposure. FCC relies on FDA and

other health agencies for safety questions

about wireless phones.

FCC also regulates the base stations that the

wireless phone networks rely upon. While

these base stations operate at higher power

than do the wireless phones themselves, the

RF exposures that people get from these

base stations are typically thousands of

times lower than those they can get from

wireless phones. Base stations are thus not

the primary subject of the safety questions

discussed in this document.

What are the results of the research

done already?

The research done thus far has produced

conflicting results, and many studies have

suffered from flaws in their research

methods. Animal experiments investigating

the effects of radio frequency energy (RF)

exposures characteristic of wireless phones

have yielded conflicting results that often

cannot be repeated in other laboratories. A

few animal studies, however, have

suggested that low levels of RF could

accelerate the development of cancer in

laboratory animals. However, many of the

studies that showed increased tumor

development used animals that had been

genetically engineered or treated with

cancer-causing chemicals so as to be pre-

disposed to develop cancer in absence of RF

exposure. Other studies exposed the

animals to RF for up to 22 hours per day.

These conditions are not similar to the

119

Health and safety information

conditions under which people use wireless

phones, so we don't know with certainty

what the results of such studies mean for

human health.

Three large epidemiology studies have been

published since December 2000. Between

them, the studies investigated any possible

association between the use of wireless

phones and primary brain cancer, glioma,

meningioma, or acoustic neuroma, tumors

of the brain or salivary gland, leukemia, or

other cancers. None of the studies

demonstrated the existence of any harmful

health effects from wireless phones RF

exposures. However, none of the studies can

answer questions about long-term

exposures, since the average period of

phone use in these studies was around three

years.

What research is needed to decide

whether RF exposure from wireless

phones poses a health risk?

A combination of laboratory studies and

epidemiological studies of people actually

using wireless phones would provide some

of the data that are needed. Lifetime animal

exposure studies could be completed in a

few years. However, very large numbers of

animals would be needed to provide reliable

proof of a cancer promoting effect if one

exists. Epidemiological studies can provide

data that is directly applicable to human

populations, but ten or more years' follow-

up may be needed to provide answers about

some health effects, such as cancer. This is

because the interval between the time of

exposure to a cancer-causing agent and the

time tumors develop - if they do - may be

many, many years. The interpretation of

epidemiological studies is hampered by

difficulties in measuring actual RF exposure

during day-to-day use of wireless phones.

Many factors affect this measurement, such

as the angle at which the phone is held, or

which model of phone is used.

What is FDA doing to find out more

about the possible health effects of

wireless phone RF?

FDA is working with the U.S. National

Toxicology Program and with groups of

investigators around the world to ensure

that high priority animal studies are

conducted to address important questions

120

Health and safety information

about the effects of exposure to radio

frequency energy (RF).

FDA has been a leading participant in the

World Health Organization international

Electromagnetic Fields (EMF) Project since

its inception in 1996. An influential result of

this work has been the development of a

detailed agenda of research needs that has

driven the establishment of new research

programs around the world. The Project has

also helped develop a series of public

information documents on EMF issues.

FDA and Cellular Telecommunications &

Internet Association (CTIA) have a formal

Cooperative Research and Development

Agreement (CRADA) to do research on

wireless phone safety. FDA provides the

scientific oversight, obtaining input from

experts in government, industry, and

academic organizations. CTIA-funded

research is conducted through contracts to

independent investigators. The initial

research will include both laboratory studies

and studies of wireless phone users. The

CRADA will also include a broad assessment

of additional research needs in the context

of the latest research developments around

the world.

What steps can I take to reduce my

exposure to radio frequency energy

from my wireless phone?

If there is a risk from these products - and

at this point we do not know that there is - it

is probably very small. But if you are

concerned about avoiding even potential

risks, you can take a few simple steps to

minimize your exposure to radio frequency

energy (RF). Since time is a key factor in

how much exposure a person receives,

reducing the amount of time spent using a

wireless phone will reduce RF exposure.

• “If you must conduct extended

conversations by wireless phone every

day, you could place more distance

between your body and the source of the

RF, since the exposure level drops off

dramatically with distance. For example,

you could use a headset and carry the

wireless phone away from your body or

use a wireless phone connected to a

remote antenna.

121

Health and safety information

Again, the scientific data do not demonstrate

that wireless phones are harmful. But if you

are concerned about the RF exposure from

these products, you can use measures like

those described above to reduce your RF

exposure from wireless phone use.

What about children using wireless

phones?

The scientific evidence does not show a

danger to users of wireless phones,

including children and teenagers. If you

want to take steps to lower exposure to

radio frequency energy (RF), the measures

described above would apply to children and

teenagers using wireless phones. Reducing

the time of wireless phone use and

increasing the distance between the user

and the RF source will reduce RF exposure.

Some groups sponsored by other national

governments have advised that children be

discouraged from using wireless phones at

all. For example, the government in the

United Kingdom distributed leaflets

containing such a recommendation in

December 2000. They noted that no

evidence exists that using a wireless phone

causes brain tumors or other ill effects. Their

recommendation to limit wireless phone use

by children was strictly precautionary; it was

not based on scientific evidence that any

health hazard exists.

Do hands-free kits for wireless phones

reduce risks from exposure to RF

emissions?

Since there are no known risks from

exposure to RF emissions from wireless

phones, there is no reason to believe that

hands-free kits reduce risks. Hands-free kits

can be used with wireless phones for

convenience and comfort. These systems

reduce the absorption of RF energy in the

head because the phone, which is the source

of the RF emissions, will not be placed

against the head. On the other hand, if the

phone is mounted against the waist or other

part of the body during use, then that part

of the body will absorb more RF energy.

Wireless phones marketed in the U.S. are

required to meet safety requirements

regardless of whether they are used against

the head or against the body. Either

122

Health and safety information

configuration should result in compliance

with the safety limit.

Do wireless phone accessories that

claim to shield the head from RF

radiation work?

Since there are no known risks from

exposure to RF emissions from wireless

phones, there is no reason to believe that

accessories that claim to shield the head

from those emissions reduce risks. Some

products that claim to shield the user from

RF absorption use special phone cases, while

others involve nothing more than a metallic

accessory attached to the phone. Studies

have shown that these products generally do

not work as advertised. Unlike “hand-free”

kits, these so-called “shields” may interfere

with proper operation of the phone. The

phone may be forced to boost its power to

compensate, leading to an increase in RF

absorption. In February 2002, the Federal

trade Commission (FTC) charged two

companies that sold devices that claimed to

protect wireless phone users from radiation

with making false and unsubstantiated

claims. According to FTC, these defendants

lacked a reasonable basis to substantiate

their claim.

What about wireless phone

interference with medical equipment?

Radio frequency energy (RF) from wireless

phones can interact with some electronic

devices. For this reason, FDA helped develop

a detailed test method to measure

electromagnetic interference (EMI) of

implanted cardiac pacemakers and

defibrillators from wireless telephones. This

test method is now part of a standard

Samsung Electronics Co SGHZ720 Single-Band PCS GSM/ EDGE Phone with Bluetooth User Manual SGH Z720 FCC

Samsung Electronics Co Ltd Single-Band PCS GSM/ EDGE Phone with Bluetooth SGH Z720 FCC

Users Manual

Navigation menu

Namespaces

Views

Navigation
