Samsung Electronics Co SGHZX20 Dual-Band Dual-Mode GSM/ EDGE/ WCDMA Phone with BT User Manual C0CCB8A7BEF8C0BD31
Samsung Electronics Co Ltd Dual-Band Dual-Mode GSM/ EDGE/ WCDMA Phone with BT C0CCB8A7BEF8C0BD31
Users Manual
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-0xxxxA
English. 12/2005. Draft02
SAMSUNG ELECTRONICS
* Depending on the software installed or your service provider, some of the
description in this manual may differ from your phone.
* Depending on your country, your phone and accessories may appear
different from the illustrations in this manual.
SGH-ZX20
User’s Manual
Important
safety
precautions
Failure to comply with the following
precautions may be dangerous or illegal.
Use road safety at all times
Do not use a hand-held phone while driving. Park
the vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using them
in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Important safety precautions
1
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Be aware of special regulations
Meet any special regulations in force in any area and
always switch off your phone whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to the ear). Avoid
unnecessary contact with the antenna when the phone
is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved accessories and
batteries. Use of any unauthorised accessories could
damage your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health and
safety information" on page 75.
• The phone could explode if the battery is
replaced with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone. To quickly
learn the basics for your phone, please refer to “Get
started”.
In this guide, the following instruction icons appear:
Indicates that you need to pay careful
attention to the subsequent information
regarding safety or phone features.
Indicates that you can get more information
on the referenced page.
→
Indicates that you need to press the
Navigation keys to scroll to the specified
option and then select it.
[ ] Indicates a key on the phone. For example,
[]
< > Indicates a soft key, whose function is
displayed on the phone screen. For example,
<
Menu
>
Important safety precautions
3
4
Contents
Unpack 6
Make sure you have each item
Your phone 6
Buttons, features, and locations
Get started 7
First steps to operating your phone
Install and charge the phone ................................... 7
Power on or off ...................................................... 8
Keys and display .................................................... 9
Access menu functions.......................................... 11
Customise your phone .......................................... 12
Make/Answer calls................................................ 14
Enter text 15
ABC, T9, Number, and Symbolic mode
Call functions 18
Advanced calling features
Menu functions 23
All menu options listed
Slove problems 73
Help and personal needs
Health and safety information 75
5
Overview of menu functions
To access Menu mode, press
<
Menu
> in Idle mode.
1 IM
p.23
2 Messaging
p.23
1 IM
2 Create New Message
3 Inbox
4 Sent
5 Outbox
6 Drafts
7 Email Inbox
8 Chat
9 Templates
10 Broadcast
11 Delete All
12 Settings
13 Memory Status
p.23
p.26
p.29
p.31
p.33
p.34
p.35
p.38
p.38
p.38
p.39
p.39
p.41
3 Recent Calls
p.42
1 Missed Calls
2 Calls Made
3 Calls Received
4 Voice Mail
5 Speed Dial List
6 Delete All
7 Call Time
8 Data Volume
9 Data Call Time
10 Address Book
p.42
p.42
p.42
p.42
p.42
p.42
p.42
p.42
p.43
p.43
4 MEdia Net
p.43
1 MEdia Net Home
2 Favorites
3 Enter URL
4 Browser Profiles
5 Clear Cache
p.43
p.43
p.43
p.43
p.43
5 Cingular Mall
p.43
1 Shop Tones
2 Shop Games
3 Shop Graphics
4 Shop Multimedia
5 Shop Applications
6 MEdia Net Home
p.43
p.43
p.43
p.43
p.43
p.43
6 Cingular Videos
p.43
7 My Stuff
p.43
1 My MEdia
2 Games
3 Applications
p.44
p.44
p.44
8 Address Book
p.60
1 Contact List
2 Add New Contact
3 Groups
4 Speed Dial
5 My Name Card
6 Copy All
7 Own Number
8 Settings
9 Memory Status
p.60
p.61
p.62
p.63
p.63
p.64
p.64
p.64
p.64
9 Settings
p.65
1 Time & Date
2 Profiles
3 Phone Settings
4 Display Settings
5 Call
6 Connectivity
7 Software Update
8 Application Settings
9 Security
10 Memory status
11 Reset settings
p.65
p.65
p.65
p.66
p.67
p.69
p.71
p.71
p.71
p.72
p.73
6
Unpack
Make sure you have each item
You can obtain the following accessories from
your local Samsung dealer:
•Car Adapter
• Headset
• Data Link KIT
• Stylish Handfree Car Kit
Phone Travel Adapter
The items supplied with your phone and the
accessories at your Samsung dealer may vary,
depending on your country or service provider.
Battery User’s Manual
Your phone
Buttons, features, and locations
Special
function keys
Camera key
Earpiece/
Speaker
Display
Power on/off/
Menu exit key
Soft key (right)
Microphone
Navigation keys
(Up/Down/Left/
Right)
WAP access/
Confirm key
Cancel/Correct
key
Camera
External
display
Soft key (left)
Volume keys
Dial key
Alphanumeric
keys
Headset
jack
Application
switch key Flash
Video call key
7
Get started
First steps to operating your phone
SIM card information
When you subscribe to a cellular network, you receive
a plug-in SIM (Subscriber Identity Module) card
loaded with your subscription details, such as your
PIN, and available optional services.
Install and charge the phone
Remove the battery.
If the
phone is already
on, first turn it off by
holding
[]
.
Insert the SIM card.
Make sure that the gold-
coloured contacts on the
card face down into the
phone.
1 2
Install the battery.
Plug the travel adapter
into the phone.
Plug the adapter into a standard AC wall outlet.
When the phone is completely charged (the battery
icon stops blinking), unplug the adapter from the
power outlet.
34
5
6
8
Get started
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon blinks.
If the battery level becomes too low, the phone
automatically turns off. Recharge your battery.
Power on or off
Remove the adapter from the phone.
7
Switch on
Do not turn on
the phone when
mobile phone
use is prohibited.
1. Open the phone.
2. Press and hold [ ] to turn on
the phone.
3. If necessary, enter the PIN and
press <
OK
>.
Switch off
1. Open the phone.
2. Press and hold [ ].
9
Get started
Keys and display
Key(s) Description
Perform the function indicated on the bottom
line of the display.
In Idle mode, access your favourite menus,
directly.
p. 65
In Menu mode, scroll through the menu
options.
In Idle mode, launch the Wireless
Application Protocol (WAP) browser.
In Menu mode, select the highlighted menu
option.
Delete characters from the display.
In Menu mode, return to the previous menu
level.
Send or answer a call.
In Idle mode, retrieve the recent numbers
dialled, missed, or received.
End a call.
Hold down to switch the phone on and off.
In Menu mode, cancel input and return the
phone to Idle mode.
Enter numbers, letters, and some special
characters.
In Idle mode, hold
[1]
down to access your
voice mail server. Hold [
0
] down to enter the
international call prefix.
Enter special characters.
Hold [
]
down to activate or deactivate
Quiet mode.
(on the left)
Adjust the phone volume.
In Idle mode, with the phone open, adjust
the keypad tone volume. With the phone
closed, hold down to turn on the backlight.
(on the right)
In Idle mode, hold down to turn on the
camera.
In Camera mode, take a photo or record a
video.
10
Get started
Display
Layout
Icons
*
Received signal strength
Call in progress
Out of your service area; you cannot
send or receive calls
Alarm set
New text message
New multimedia message
New voicemail message
Text and graphics
display messages,
instructions, and
information you enter.
Soft key function indicators
show the current functions
assigned to the two soft
keys.
Menu Addres
s
Icons
display various icons.
Icons
(continued)
New e-mail received or being sent
One of the message Inboxes is full
Call diverting feature is active
Bluetooth feature is active
GPRS network
Home Zone, if you have registered
for the appropriate service
Office Zone, if you have registered
for the appropriate service
Call ringer set to vibrate
Quiet mode is active
Battery power level
* The icons shown on the display may vary, depending
on your country or service provider.
11
Get started
Access menu functions
Use the soft
keys
The roles of the soft keys vary
depending on the function you are
using. The bottom line of the
display indicates their current role.
Press the left soft
key to access
Menu
mode.
Press the right soft
key to access
Options
.
Menu Contacts
Select an
option
1. Press the appropriate soft key.
2. Press the Navigation keys to
move to the next or previous
option.
3. Press <
Select
> or [ ] to
confirm the function displayed
or option highlighted.
4. To exit, choose either of the
following methods.
•Press <
Back
> or <
C
> to
move up one level.
• Press [ ] to return to
Idle mode.
Use shortcuts
Press the number key
corresponding to the option you
want.
12
Get started
Customise your phone
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
settings
→
Language
.
2. Select a language.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Sound
settings
→
Incoming call
→
Ring tone
.
2. Press [Left] or [Right] to select
a ringer category.
3. Press [Up] or [Down] to scroll
through ringer melodies.
4. Select a ringer melody you
want.
5. Press <
Save
>.
Display
language
Call ringer
melody
You can set your wallpaper for the
main or external display.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display
settings
→
Wallpaper
→
Main
display
or
Cover display
.
2. Select an image category and
then an image.
For
Cover display
, you can
select
Cover title
to enter text
to be displayed on the external
display.
3. Press [ ].
Idle mode
wallpaper
13
Get started
You can change the colour for the
display components, such as title
bars and highlight bars.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Display
settings
→
Skin
.
2. Select a colour pattern.
You can switch to Quiet mode to
avoid disturbing other people with
your phone sound.
Press and hold
[
]
in Idle mode.
Menu mode
skin colour
Quiet mode
You can use the Navigation keys as
shortcut keys to access specific
menus directly from Idle mode.
To assign a menu to a key:
1. In Idle mode, press <
Menu
>
and select
Settings
→
Phone
settings
→
Short cut
.
2. Select a key.
3. Press <
Options
> and select
Change
.
4. Scroll to a menu to be assigned
to the key.
5. Press <
Save
>.
Menu
shortcuts
14
Make/Answer calls
You can protect the phone against
unauthorised use with a phone
password. The phone will require
the password on powerup.
1. In Idle mode, press <
Menu
>
and select
Settings
→
Security
→
Change
password
.
2. Enter the default password,
“00000000” and press <
OK
>.
3. Enter a new 4- to 8- digit
password and press <
OK
>.
4. Enter the new password again
and press <
OK
>.
5. Select
Phone lock
.
6. Select
Enable
.
7. Enter the password and press
<
OK
>.
Phone lock
1. In Idle mode, enter an area code
and phone number.
2. Press
[]
.
3. To end the call, press
[]
.
1. When the phone is ringing, press
[]
.
2. To end the call, press
[]
.
Press [ / ].
Make a call
Answer a call
Adjust the
volume during
a call
15
Enter text
ABC, T9, Number, and Symbolic mode
You can enter text for some features such as
messaging, Phonebook, or Calendar, using ABC mode,
T9 mode, Number mode, and Symbolic mode.
Changing the text input mode
The text input mode indicator appears when the cursor
is in a text field.
• Press the right soft key to change the text input
mode. ( : T9 mode, : ABC mode, :
Number mode, and : Symbolic mode)
• Press and hold [ ] to switch to Symbolic mode.
Using ABC mode
Press the appropriate key until the character you want
appears on the screen.
Tips for using ABC mode
• To enter the same letter twice or to enter a
different letter on the same key, wait for the cursor
to move to the right automatically or press [Right].
Then, enter the next letter.
Key Characters in order displayed
Upper case Lower case
1
. , - ? ! ’ @ : 1
2
A B C 2 a b c 2
3
D E F 3 d e f 3
4
G H I 4 g h i 4
5
J K L 5 j k l 5
6
M N O 6 m n o 6
7
P Q R S 7 p q r s 7
8
T U V 8 t u v 8
9
W X Y Z 9 w x y z 9
0
0
16
Enter text
• Press [ ] to change case. Lower case (No
indicator), Initial capital ( ), and Capital lock ( )
are available.
• Press [ ] to insert a space.
• Press the Navigation keys to move the cursor.
•Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
• Depending on your country, you may be able to
access an input mode for your specific language by
holding the [ ] key.
Using T9 mode
T9 is a predictive text input mode that allows you to
key in any character using single keystrokes.
Entering a word in T9 mode
1. Press [
2
] to [
9
]
to start entering a word. Press
each key once for each letter.
For example, press [
4
], [
3
], [
5
], [
5
], and [
6
] to
enter HELLO in T9 mode.
T9 predicts the word that you are typing, and it
may change with each key that you press.
2. Enter the whole word before editing or deleting
characters.
3. When the word displays correctly, go to step 4.
Otherwise, press [
0
] to display alternative word
choices for the keys that you have pressed.
For example, OF and ME use [
6
] and [
3
].
4. Press [ ] to insert a space and enter the next
word.
Tips for using T9 mode
• Press [
1
] to enter periods or apostrophes
automatically.
• Press [ ] to change case. Lower case (No
indicator), Initial capital ( ), and Capital lock ( )
are available.
• Press [ ] to insert a space.
• Press the Navigation keys to move the cursor.
• Press [
C
] to delete characters one by one. Press
and hold [
C
] to clear the display.
Enter text
17
Adding a new word to the T9 dictionary
This feature may not be available for some languages.
1. Enter the word that you want to add.
2. Press [
0
] to display alternative words for your key
presses. When there are no more alternative
words,
Spell
appears on the bottom line.
3. Press <
Spell
>.
4. Enter the word you want using ABC mode and
press <
OK
>.
Using Number mode
Number mode enables you to enter numbers.
Press the keys corresponding to the digits you want.
Using Symbolic mode
Symbolic mode enables you to insert symbols.
To Press
display more symbols [Up] or [Down].
select a symbol the corresponding
number key.
clear the entered symbol(s) [
C
].
insert the symbol(s) <
OK
>.
To Press
18
Call functions
Advanced calling features
Making a call
1. In Idle mode, enter the area code and phone
number.
2. Press [ ].
Making an international call
1. In Idle mode, press and hold [
0
]. The
+
character
appears.
2. Enter the country code, area code, and phone
number, then press [ ].
Redialling recent numbers
1. In Idle mode, press [ ] to display the list of
recent numbers.
2. Scroll to the number you want and press [ ].
Making a call from Phonebook
Once you have stored a number in Phonebook, you
can dial the number by selecting it from Phonebook.
You can also use the speed dial feature to assign your
most frequently called numbers to specific number
keys.
Dialling a number from the SIM card
1. In Idle mode, enter the location number for the
phone number you want and press [ ].
2. Press [Left] or [Right] to scroll through other
numbers.
3. Press <
Dial
> or [ ] to dial the number you want.
Ending a call
Close the phone or press [ ].
Press
[
C
]
to clear the last digit or press and hold
[
C
]
to clear the whole display. You can move the
cursor to edit an incorrect digit.
Call functions
19
Answering a call
When you receive an incoming call, the phone rings
and displays the incoming call image.
Press <
Accept
> or [ ] to answer the call.
Tips for answering a call
• When
Anykey
answer
in the
Extra
settings
menu is active, you can press any key, except for
<
Reject
>, [ ], or [ / ].
p. 66
• When
Active folder
in the
Extra
settings
menu
is active, you can simply open the phone.
p. 66
•Press <
Reject
> or [ ] to reject a call.
• Depending on the setting in the
Side key
menu,
press and hold [ / ] to mute a call ringer or
reject a call.
Viewing missed calls
If you have missed calls, the screen displays how
many calls you have missed.
1. Press <
View
>.
2. If necessary, scroll through the missed calls.
3. Press [ ] to dial the number you want.
Using the headset
Use the headset to make or answer calls without
holding the phone.
Connect the headset to the jack on the left side of the
phone.
The buttons on the headset work as listed below:
Options during a call
You can access a number of functions during a call.
Adjusting the volume during a call
Use [ / ] to adjust the earpiece volume during a call.
To Press
redial the last call and hold the button twice.
answer a call the button.
end a call the button.
20
Call functions
Press [ ] to increase the volume level and [ ] to
decrease the volume level.
Using the external speaker
Use the optional external speaker to talk and listen
with the phone a short distance away. First, you must
plug the speaker into the phone.
1. During a call, press [ ] to listen and talk to the
other person hands-free. The icon appears.
2. Press [ ] again to return to normal phone
mode. The icon appears.
Placing a call on hold/Retrieving
Press <
Hold
> or <
Retrieve
> to place a call on hold
or retrieve the call.
Making a second call
You can make another call if your network supports it.
1. Press <
Hold
> to put the call on hold.
2. Make the second call in the normal way.
3. Press <
Swap
> to switch between the calls.
4. Press <
Options
> and select
End
held
call
to end
the call on hold.
5. To end the current call, press [ ].
Answering a second call
You can answer an incoming call while already on the
phone, if your network supports it and you have
activated the call waiting feature.
1. Press [ ] to answer the call. The first call is
automatically put on hold.
2. Press <
Swap
> to switch between the calls.
3. Press <
Options
> and select
End
held
call
to end
the call on hold.
4. To end the current call, press [ ].
Transferring a call
You can transfer the currently active call to a caller on
hold, if your network supports it. With this option, the
two callers can talk to each other, but you are
disconnected from the call.
Press <
Options
> and select
Transfer
.
Call functions
21
Using a Bluetooth headset
Use an optional Bluetooth headset to talk on the
phone without holding the phone to your ear. To use
this feature, you first need to register your headset
and connect it to the phone.
Press <
Options
> and select
Switch to headset
or
Switch to phone
.
Using the voice clarity feature
This feature increases the microphone’s sensitivity so
that the person with when you are speaking can hear
you clearly even though you may be whispering.
Press <
Options
> and select
Voice clarity on
or
Voice clarity off
.
Switching off the microphone
(Mute mode)
You can temporarily switch off your phone’s
microphone so that the person on the phone cannot
hear you.
Press <
Options
> and select
Mute
or
Unmute
.
Muting or sending key tones
You can turn the key tones off or on.
Press <
Options
> and select
Mute keys
or
Send
keys
.
Sending a sequence of DTMF tones
Dual tone multi-frequency (DTMF) tones are the tones
used in phones for tone dialling.
You can send DTMF tones as a group after entering the
entire number you need to send or retrieving a
number from Phonebook. This feature is helpful for
entering a password or an account number when you
call an automated system, like a banking service.
1. When connected with a teleservice system, press
<
Options
> and select
Send DTMF
.
2. Enter the number you need to send and press
<
OK
>.
To communicate with answering machines or
computerised telephone systems,
Send keys
must
be selected.
22
Call functions
Using Phonebook
You can access the
Phonebook
menu to locate or
store entries.
Press <
Options
> and select
Phonebook
.
Using SIM services
The
SIM service
menu is available if you use a SIM
card in your phone. A SIM card provides services such
as news, weather, sports, entertainment, and location
services.
For details, see your SIM card instructions or contact
your service provider.
Making a multi-party call
Use this feature to allow as many as six people to join
a multi-party call, or conference call.
Your service provider must support multi-party calls
for you to use this feature.
Setting up a multi-party call
1. Call the first participant.
2. Call the second participant. The first call is
automatically put on hold.
3. Press <
Options
> and select
Join
. The first
participant is added to the multi-party call.
4. If desired, call another person or answer an
incoming call.
5. Press <
Options
> and select
Join
.
6. Repeat steps 4 and 5 as desired.
Having a private conversation with one
participant
1. Press <
Options
> and select
Private
.
2. Select a name or number from the participant list.
You can talk privately with that person, while the
other participants converse with each other.
3. To return to the multi-party call, press <
Options
>
and select
Join
.
Dropping one participant
1. Press <
Options
> and select
Remove
.
2. Select a name or number from the participant list.
The participant is dropped from the call, but the
call continues with the other parties.
3. Close the phone or press [ ] to end the multi-
party call.
23
Menu functions
All menu options listed
IM
(Menu 1)
Messaging
(Menu 2)
Use the
Messaging
menu to send and receive text
messages, multimedia messages, and e-mails. You
can also use WAP push message and cell broadcast
message features.
To access this menu, press <
Menu
> in Idle mode and
select
Messaging
.
IM
(menu 2.1)
The Wireless Application Protocol (WAP) browser on
your phone allows you to access the wireless web.
Using the WAP browser, you can access up-to-date
information and a wide variety of media content, such
as wallpapers, ring tones, and music files.
To access this menu, press <
Menu
> in Idle mode and
select
Browser
.
Home
Use this menu to connect your phone to the network
and load the home page of the wireless web service
provider. You can also press [ ] in Idle mode.
Navigating with the WAP browser
Selecting and using the browser menu options
Press [ ] or select on the top of the screen.
•
Back
: go back to the previous page.
•
Home
: go back to the home page.
•
Exit
: exit the WAP browser.
•
Reload
: reload the current page.
To Press
scroll through browser items [Up] or [Down].
select a browser item < >.
return to the previous page <
Back
> or [
C
].
return to the home page and hold [
C
].
24
Menu functions
•
Show URL
: display the URL address of the current
web page. You can also set the current page as the
home page for the WAP browser.
•
About
: view the WAP browser certificate and
version information.
Using WAP page options
From any WAP page, press [ ] to access the following
options:
•
Go to URL
: enter a URL address manually.
•
Bookmarks
: switch to the
Bookmarks
menu.
Menu 6.2
•
Messages
: check the
Inbox
,
Outbox
, and
Draft
box in the
My messages
menu. You can also
create and send a new SMS message.
•
File manager
: switch to the
File manger
menu.
Exiting the WAP browser
Press [ ] to exit the browser.
Bookmarks
Use this menu to save URL addresses in order to
quickly access websites.
Adding a bookmark
1. Select an empty location.
2. Enter a name for the bookmark.
3. Enter a URL address and press [ ].
Accessing a bookmarked page
Scroll to a bookmark item and press [ ].
Using bookmark options
Scroll to a bookmark and press <
Options
> to access
the following options:
•
Go
: access the bookmarked website.
•
Edit
: edit the address and name of the bookmark.
•
Delete
: delete the selected bookmark.
Go to URL
Use this menu to manually enter the URL address of a
website and access the website.
Clear cache
Use this menu to clear the cache, a temporary
memory that stores recently accessed web pages.
Menu functions
Messaging
(Menu 2)
25
Profile settings
Use this menu to set up servers for the WAP browser.
Contact your service provider for details about your
setting options.
For each server, the following options are available:
•
Profile
name
: assign a name to the server profile.
•
Home
URL
: set the address of your home page.
•
Bearer
: select a bearer for each type of network
address accessed.
•
Proxy
: select whether or not the phone uses a
proxy server to launch the WAP browser. Your
service provider can tell you if your network
requires a proxy server, and they can give you the
appropriate settings.
•
GPRS settings
: customise the following GPRS
network settings:
When the proxy is set to
Enable
:
Proxy IP
: enter the proxy IP address.
Proxy port
: enter the proxy port number.
APN
: enter the access point name of the GPRS
network gateway.
Login ID
: enter the user ID.
Password
: enter the password.
When the proxy is set to
Disable
:
DNS 1
: enter the primary address.
DNS 2
: enter the secondary address
.
APN
: enter the access point name of the GPRS
network gateway.
Login ID
: enter the user ID
.
Password
: enter the password
.
•
GSM settings
: customise the following GSM
network settings:
When the proxy is set to
Enable
:
Proxy IP
: enter the proxy IP address.
Proxy port
: enter the proxy port number.
Dial number
: enter the PPP server phone number.
Login ID
: enter the user ID.
Password
: enter the password.
Data call type
: select a data call type.
When the proxy is set to
Disable
:
DNS 1
: enter the primary address.
26
Menu functions
DNS 2
: enter the secondary address.
Dial number
: enter the PPP server phone number.
Login ID
: enter the user ID.
Password
: enter the password.
Data call type
: select a data call type.
Current profile
Use this menu to select a connection profile for
accessing the WAP browser.
Create New Message
(Menu 2.2)
Use this menu to create and send SMS, MMS, or
e-mail messages.
Text Message
(Menu 2.2.1)
Short Message Service (SMS) allows you to send or
receive text messages that may include pictures,
animated images, and melodies.
1. Enter your message.
2. Press <
Options
> to access one of the following
options:
•
Save and send
: both save a copy of the
message and send the message.
•
Send only
: send the message.
•
Insert
: add a template, Phonebook entry, or
bookmark.
•
Add picture
/
Add animation
/
Add melody
:
attach a picture, animated image, or melody.
•
Save to
: save the message in the
Draft
or
My
folder
box.
•
Language select
: change the language used
in the text input mode.
•
Text style
: change the text attributes.
3. When you have finished, press <
Options
> and
select
Save and send
or
Send only
.
4. Enter a destination number.
To send the message to more than one recipient,
press [Down] and fill in additional destination
fields.
5. Press [ ] to send the message.
The maximum number of characters allowed in a
text message varies by service provider. If your
message exceeds the maximum number of
characters, the phone will split the message.
Menu functions
Messaging
(Menu 2)
27
Multimedia message
(Menu 2.2.2)
Multimedia Message Service (MMS) allows you to send
or receive multimedia messages containing a
combination of text, image, video, and audio, from
phone to phone or from phone to e-mail.
1. Select the
Subject
line.
2. Enter the message subject and press [ ].
3. Select the
Picture & Video
line.
4. Select
or
Video
and select a category.
5. Select a photo and press <
Add
>, or a video clip
and press the left soft key.
6. Select the
Sound
line.
7. Select a category and a sound file, and press
<
Add
>Select the
Message
line.
8. Enter the message text and press [ ].
9. While composing the message, press <
Options
>
to access the following options:
•
Add
: add a message subject or text.
•
Edit
: edit the message subject or text.
•
Add image
/
Add video
/
Add sound
: add a
photo, video, or sound.
Depending on the file
type or DRM (Digital Rights Management) system,
some files may not be able to be forwarded
.
•
Preview
: display the message you have
created.
•
Send
: send the message.
•
Save to
: save the message in the
Draft
or
My
folder
box. You can also save the message as
an MMS template.
•
Add page
: add pages. Move to each page by
pressing [Left] or [Right] on the message
screen.
•
Delete page
: delete an added page.
•
Edit page
: change the duration of page display
or move the page forward.
•
Attach
: attach a name card or calender data.
•
Remove subject
/
Remove message
: clear
the subject or text.
•
Remove picture
/
Remove video
/
Remove
sound
: remove an added photo, video, or
sound.
Depending on the field status or selected field,
available options vary.
28
Menu functions
10. When you have finished, press <
Options
> and
select
Send
.
11. Enter a phone number or e-mail address.
To send the message to more than one recipient,
press [Down] and fill in additional destination
fields.
12. Press [ ] to send the message.
Email
(Menu 2.2.3)
You can send e-mails that include text and media files,
such as images, videos, and audio. To use this feature,
you need to subscribe to an e-mail service and set up
your e-mail account and profile.
p. 36, p. 37
1. Select the
Subject
line.
2. Enter the subject of your e-mail and press [ ].
3. Select the
Message
line.
4. Enter the e-mail text and press [ ].
5. Select the
File attach
line.
6. Press <
Options
> and add media files to your
e-mail by using the following options:
•
Add image
/
Add videos
/
Add sounds
/
Add
music
: add photos, videos, or sounds.
Depending on the file type or DRM (Digital Rights
Management) system, some files may not be able
to be forwarded
.
•
Other files
: add files in unsupported format.
•
Attach
: add name cards or calendar data.
7. While composing the e-mail, press <
Options
> to
access the following options:
•
Edit
: edit the subject or text.
•
View
: open the attached file.
•
Send
: send the e-mail.
•
Save to
: save the e-mail in the
Draft
or
My
folder
box.
•
Remove subject
/
Remove message
: clear
the subject or text.
•
Remove
: delete the selected attachment or all
attachments.
•
Remove all attachments
: delete all
attachments.
8. When you have finished, press <
Options
> and
select
Send
.
9. Enter an e-mail address.
Menu functions
Messaging
(Menu 2)
29
To send the e-mail to more than one recipient,
press [Down] and fill in additional destination
fields.
10. Press [ ] to send the e-mail.
Inbox
(Menu 2.3)
Use this menu to store all of the messages you have
received, sent, failed to send, or saved to send it later.
Inbox
(Menu2.3.1)
This folder stores all of the messages you have
received, except for e-mails and CB messages.
Viewing a message at the time of its receipt
When a message has been received, the phone alerts
you by:
• Displaying a message icon with text notification
• Sounding a tone or vibrating, depending on the
message alert setting.
To read a message immediately, press <
View
> and
select a message from the Inbox.
For an MMS message, press <
Options
> and select
Retrieve
. The message is downloaded from the MMS
server to the phone’s memory.
Viewing a message in the Inbox
The following icons may appear on the message list;
depending on the message type or status, icons may
vary:
• SMS
• MMS
• MMS notification
• Configuration messages, which are sent from
your service provider
• WAP push messages
• Delivery report for your sent messages
• Depending on the DRM (Digital Rights
Management, you may not be able to forward
some messages. They are indicated by the
icon.
•
An
!
icon next to a message icon indicates high
priority. A grey-coloured message icon
indicates low priority.
30
Menu functions
While viewing the message list, press <
Options
> to
access the following options:
•
View
: open the message.
•
Retrieve
: retrieve the MMS message from the
server.
•
Delete
: delete the selected message or all
messages.
•
Move to my folder
: move the message to the
My
folder
box.
•
Move to phone
/
SIM
: move the SMS message to
the phone’s memory or the SIM card.
•
Sort by
: change the sort order of the messages.
•
Protection
: protect the message from being
deleted.
•
Properties
: view the message properties.
Using message options
While viewing a message, press <
Options
> to access
the following options:
SMS messages
•
Reply via
: send a reply message via SMS or MMS.
•
Forward
: forward the message to other people.
•
Delete
: delete the message.
•
Move to phone
/
SIM
: move the SMS message to
the phone’s memory or the SIM card.
•
Add to block list
: add the sender’s number to the
Block number
list.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Cut media
: save media content from the message
into your phone’s memory.
•
Protection
: protect the message from being
deleted.
•
Print via bluetooth
: print the selected message
by connecting the phone to a printer via Bluetooth.
MMS messages
•
Reply via SMS
: send a reply message via SMS.
•
Reply via MMS to
: send a reply message via
MMS.
•
Forward
: forward the message to another person.
Menu functions
Messaging
(Menu 2)
31
•
Delete
: delete the selected message or all
messages.
•
Cut
address
: extract URLs, e-mail addresses, or
phone numbers from the message.
•
Cut media
: save media content from the message
into your phone’s memory.
•
Properties
: view the message properties.
Configuration messages
•
Install
: apply the configuration specified in the
message to your phone.
•
Delete
: delete the message.
•
Properties
: view the message properties.
WAP push messages
•
Go to URL
: connect to the URL from which the
message is sent.
•
Cut address
: extract URL, e-mail addresses, or
phone numbers from the message.
•
Delete
: delete the message.
•
Protection
: protect the message from being
deleted.
Delivery report messages
•
Cut address
: extract URL, e-mail addresses, or
phone numbers from the message.
•
Delete
: delete the message.
•
Protection
: protect the message from being
deleted.
Sent
(Menu 2.4)
Sentbox
(Menu 2.3.4)
This folder stores messages that you have sent.
While viewing a message or from the message list,
press <
Options
> to access the following options:
•
View
: display the message.
•
Forward
: forward the message to other people.
•
Delete
: delete the selected message or all
messages.
•
Move to my folder
: move the message to the
My
folders
box.
•
Move to phone
/
SIM
: move the SMS message to
the phone’s memory or the SIM card.
•
Sort by
: change the sort order of the messages.
32
Menu functions
•
Print via bluetooth
: print the selected message
by connecting the phone to a printer via Bluetooth.
•
Protection
: protect the message from being
deleted.
•
Properties
: view the message properties.
Email Inbox
(Menu 2.3.5)
This folder stores e-mails that you have received.
1. Select an e-mail account.
2. Press <
Yes
> when
Check New Mail
is displayed
to get new mails from the server.
The phone checks for new e-mails and retrieves
received e-mails.
The following icons may appear on the message
list; depending on the e-mail states, icons may
vary:
• has been read
• has not been read
• is being retrieved from the server
• has not been retrieved
3. Scroll to an e-mail or header and press [ ].
4. If the e-mail has more than one page, press [ / ]
to scroll through pages one by one.
Press and hold [ / ] to move to the first or last
page.
5. Select an attached file to view or play it.
6. Press [ ] or [ ] to move to the previous or next
e-mail.
While viewing the e-mail content or e-mail list, press
<
Options
> to access the following options:
•
View
: display the e-mail.
•
Retrieve
: retrieve one or all e-mails from the
e-mail server.
•
Reply to
: send a reply message to the sender or
to all of the other recipients.
An
!
icon next to a message icon indicates
high priority. A grey-coloured message icon
indicates low priority.
Options may vary depending on the status of the
e-mail.
Menu functions
Messaging
(Menu 2)
33
•
Forward
: forward the e-mail.
•
Mark as read
: mark the e-mail as read.
•
Delete selection
: delete the selected e-mail.
•
Delete all
: delete all e-mails.
•
Move to my folder
: move the retrieved e-mail to
the
My folder
box.
•
Sort by
: sort the e-mails by size, subject, data, or
senders’ e-mail addresses.
•
Protection
: protect the e-mail from being deleted.
•
Properties
: view the e-mail properties.
While viewing a header or e-mail, press <
Options
> to
access the following options:
•
Retrieve
: retrieve one or all e-mails.
•
Open file
: open the attached file.
•
Save file
: save the attached file in the phone’s
memory.
•
Reply to
: send a reply message to the sender or
to the sender and all of the other recipients.
•
Forward
: forward the e-mail.
•
Delete
: delete the e-mail.
•
Add to block list
: add the sender’s e-mail
address or the e-mail subject to the
Block list
.
•
Cut address
: extract e-mail addresses, URLs, and
phone numbers from the e-mail.
•
Cut attachment
: save the selected attachment or
all attachments from the e-mail into your phone’s
memory.
•
Print via bluetooth
: print the selected e-mail by
connecting the phone to a printer via Bluetooth.
•
Protection
: protect the e-mail from being deleted.
•
Properties
: view the e-mail properties.
Out Box
(Menu 2.5)
This folder stores messages that the phone is
attempting to send or has failed to send.
In this folder, the following icons are available:
• Messages that the phone is sending
• Messages that the phone has failed to send
34
Menu functions
While viewing a message or the message list, press
<
Options
> to access the following options:
•
Cancel sending
: cancel sending the message, if
the message is being sent.
•
View
: display the message.
•
Send again
: send the message.
•
Delete
: delete the selected message or all
messages.
•
Move to my folder
: move the message to the
My
folder
box.
•
Move to phone
/
SIM
: move the SMS message to
the phone’s memory or the SIM card.
•
Sort by
: change the sort order of the messages.
•
Print via bluetooth
: print the selected message
by connecting the phone to a printer via Bluetooth.
•
Protection
: protect the message from being
deleted.
•
Properties
: view the message properties.
Draft
(Menu 2.6)
This folder stores messages you have saved to send at
a later time.
Press <
Options
> to access the following options:
•
Edit
: edit the message.
•
Delete
: delete the selected message or all
messages.
•
Move to my folder
: move the message to the
My
folder
box.
•
Move to phone
/
SIM
: move the SMS message to
the phone’s memory or the SIM card.
•
Sort by
: change the sort order of the messages.
•
Protection
: protect the message from being
deleted.
•
Properties
: view the message properties.
My folder
Use this menu to store and manage your messages.
Press <
Options
> to access the following options:
•
View
: display the message.
•
Send
: send the message.
Menu functions
Messaging
(Menu 2)
35
•
Edit
: edit the message.
•
Delete
: delete the selected message or all
messages.
•
Sort by
: change the sort order of messages.
•
Protection
: protect the message from being
deleted.
•
Properties
: view the message properties.
Email Inbox
(Menu 2.7)
You can configure the default network settings that
are required to send or receive e-mails.
Send settings
: set up the following options for
sending e-mails.
•
Send copy to self
: send a copy of your e-mail to
your own e-mail address.
•
Delivery confirm
: set the network to inform you
when your e-mail has been delivered.
•
Read confirm
: send a request for a reply along
with your e-mail.
•
Priority
: select the priority level of your outgoing
e-mail.
•
Include signature
: select to attach your name,
phone number, or a simple memo to your e-mail
using the
Edit name
,
Edit telephone number
,
and
Edit note
options.
•
Edit name
: enter your name.
•
Edit telephone number
: enter your phone
number.
•
Edit note
: enter a simple memo.
Receive settings
: set up the following options for
receiving e-mails.
•
Check interval
: determine how often the phone
checks the server for incoming e-mails.
If you set this option to
Not used
, you can use the
Check new mail
feature to check your e-mail
manually.
•
Read reply
: determine whether or not the phone
sends a read-reply request.
When this option is set to
Announce
, the phone
reminds you to send a read-reply request with
your e-mail address.
You cannot change e-mail profile settings while an
e-mail is being sent or retrieved.
36
Menu functions
•
Retrieve option
: determine whether the phone
retrieves headers only or the entire e-mail.
•
Delete option
: determine whether e-mails are
deleted immediately or the next time you connect
to the server.
•
Reject if over
: determine the maximum size for
incoming e-mails. Your phone will reject e-mails
that exceed the specified size.
•
Leave a copy of messages on the server
: leave
copies of e-mails after retrieving.
Block list
: specify e-mail addresses from which
messages will not be accepted. You can also specify
message subjects that you will not accept.
Email account
: set up your e-mail account(s) and
select the one to be used:
•
Current account
: select an account.
•
Account settings
: configure up to five e-mail
accounts using different e-mail servers.
The following options are available for each
account:
In use
: select this option to use the account and
to display the account in the
Inbox
.
Account name
: enter a name for the currently
selected account.
User name
: enter a name to be displayed as the
sender’s name in your outgoing e-mails.
Email address
: enter your e-mail address.
Reply address
: enter the e-mail address to which
you want recipients to send reply messages.
User ID
: enter your e-mail ID.
Password
: enter your e-mail password.
SMTP server
: enter the IP address or domain
name of the outgoing e-mail server.
SMTP port
: enter the SMTP port number.
Protocol type
: select the protocol for the
incoming e-mail server. The remaining options
depend on the protocol type setting.
You cannot change e-mail account settings while an
e-mail is being sent or retrieved. Your e-mail
service provider can give you the information
needed for the below settings.
Menu functions
Messaging
(Menu 2)
37
When the protocol type is
POP3
:
POP3 server
:
enter the IP address or domain
name of the server that receives your e-mail.
POP3 port
: enter the POP3 port number.
APOP login
: connect to the server by using the
APOP login scheme when this option is selected.
When the protocol type is
IMAP4
:
IMAP4 server
: enter the IP address or domain
name of the server that receives your e-mail.
IMAP4 port
: enter the IMAP4 port number.
Include attachments
: select this option to
receive attachments with e-mails.
Max. Emails retrieved
: set the number of
headers you will retrieve from the server.
Email profile
: configure the network settings
required to send or receive e-mails.
•
Current profile
: select a profile.
•
Profile settings
: configure up to five e-mail
profiles. For each profile, the following options are
required to connect to the GPRS network:
Profile name
: enter a name for the e-mail profile.
APN
: enter the access point name used for the
GPRS network address.
Login ID
: enter the user ID.
Password
: enter the password.
DNS1
: enter the primary address.
DNS2
: enter the secondary address.
Push Message
You can change the settings for receiving WAP push
messages from the wireless web server. The following
options are available:
•
Receive
: set how your phone receives WAP push
messages.
•
Service centre
: specify the address of the server
from which you want to receive WAP push
messages, the
Receive
option is set to
SMS-C
specific
.
You cannot change e-mail profile settings while an
e-mail is being sent or retrieved.
38
Menu functions
Predictive Text Mode
Chat
(menu 2.8)
Templates
(Menu 2.9)
Use this menu to create, edit, or send text or
multimedia templates.
Text template
(Menu 2.4.1)
Use this menu to preset frequently used text
messages.
1. Select an empty location.
2. Enter a message and press [ ].
3. Press <
Options
> to access the following options:
•
Edit
: edit the template.
•
Send message
: send a new message using
the template.
•
Delete
: delete the template.
MMS template
(Menu 2.4.2)
Your phone has 11 preset MMS messages. You can
create a new MMS template and send the template.
Scroll to an MMS template and press [ ] to display
the template.
While viewing a message, press <
Options
> to access
the following options:
•
Replay
: replay the template.
•
Send
: send the template.
•
Edit
: edit the template.
•
Delete
: delete the template.
While viewing the template list, press <
Options
> to
access the following options:
•
View
: display the template.
•
Send
: send the template.
•
Edit
: edit the template.
•
New
: add a new template.
•
Delete
: delete the template.
Broadcast
(Menu 2.10)
The Cell Broadcast service delivers short messages on
various topics, such as weather, sports, or traffic.
Menu functions
Messaging
(Menu 2)
39
Use this menu to change the settings for the service
and to access broadcast messages.
•
Read
: open received messages.
The
Temporary
box saves network messages until
the phone is switched off.
The
Archive
box saves network messages
indefinitely. Press <
Options
> and select
Save
to
save messages to the
Archive
box when a text
notification appears.
•
Receive
: enable or disable the reception of
broadcast messages.
•
Channel
: specify the channels from which you
receive broadcast messages.
•
Language
: select the language in which broadcast
messages display.
Please contact your service provider for details.
Delete All
(Menu 2.11)
Use this menu to delete messages in each message
folder one by one, or all at once. You can also delete
all messages in all folders at one time.
Settings
(Menu 2.12)
Use this menu to set up various options for using the
messaging service.
Text message
You can configure the default SMS settings for sending
messages.
Send settings
: set up the following options:
•
Reply path
: allow the recipient to reply to you
through your message centre.
•
Delivery report
: set the network to inform you
when your message has been delivered.
•
Message type
: set the default message type. The
network can convert the messages into the
selected format.
Current Profile
Profile Settings
Multimedia message
You can configure the default MMS settings for sending
or receiving messages.
40
Menu functions
Send settings:
set up the following options for
sending multimedia messages:
•
Priority
: set the priority level of your outgoing
messages.
•
Validity period
: set the length of time your
messages are stored in the MMS centre.
•
Delivery after
: set a time delay before messages
are sent.
•
Address hiding
: set your address to be hidden
from the recipient’s phone.
•
Delivery report
: set the network to inform you
when your message has been delivered.
•
Read reply
: determine whether or not the phone
sends a read-reply request.
Receive settings
: set up the following options for
receiving multimedia messages:
•
Home reception
: determine if your phone
retrieves new messages automatically when you
are in your home service area.
•
Roaming reception
: determine if your phone
retrieves new messages automatically when you
are roaming in another network.
Home reception
and
Roaming reception
have
the following options:
Automatic
: the phone automatically retrieves
messages from the server.
Reject
: the phone rejects all messages.
Manual
: the phone displays notifications. Use the
Retrieve
option to manually download new
messages.
•
Anonymous reject
: reject messages from
anonymous senders.
•
Adverts reject
: reject advertisements.
•
Report allowed
: send a delivery report from the
network to the sender.
Block number
: specify phone numbers from which
messages will not be accepted.
MMS profiles
: configure required network settings for
MMS. The last profile accessed is automatically
activated for sending or receiving subsequent
messages.
Check with your service provider before you change
any MMS settings on your phone.
Menu functions
Messaging
(Menu 2)
41
•
Current profile
: select a profile.
•
Profile settings
: customise the following options
for each profile:
Profile name
: assign a name to the MMS profile.
Server URL
: enter the address of your MMS
server.
Proxy
: connect to the GPRS network using the
proxy server.
GPRS settings
: customise the settings required
for connecting to the GPRS network.
-
IP address
: (when the proxy is set to
Enable
)
enter the IP address.
-
Port
: (when the proxy is set to
Enable
) enter
the port number.
-
DNS1
: (when the proxy is set to
Disable
) enter
the primary address.
-
DNS2
: (when the proxy is set to
Disable
) enter
the secondary address.
-
APN
: enter the access point name used for the
address of the GPRS network.
-
Login ID
: enter the user ID.
-
Password
: enter the password.
Version
: select an available OMA version and
maximum size limit for sending or receiving
messages.
Memory Status
(Menu 2.13)
Use this menu to view the maximum memory and
available memory for each message type. You can also
view the memory currently in use in each folder.
Depending on your service provider, it may not
be possible to support the maximum limit
295KB. In this case, try again after changing
the setting to 100KB.
42
Menu functions
Recent Calls
(Menu 3)
Use this menu to view the calls you have dialled,
received, or missed, and the length of your calls.
To access this menu, press <
Menu
> in Idle mode and
select
Recent Calls
.
Missed Calls
(Menu 3.1)
This menu displays the most recent calls that you did
not answer.
Calls Made
(Menu 3.2)
This menu displays the most recent calls you have
received.
Calls Received
(Menu 3.3)
This menu displays the most recent calls you have
dialled.
Voice Mail
(Menu 3.4)
Speed Dial List
(Menu 3.5)
Delete All
(Menu 3.6)
Call Time
(Menu 3.7)
This menu displays the time log for calls made and
received. The actual time invoiced by your service
provider will vary.
•
Last
call
time
: check the length of your last call.
•
Total
sent
: check the total length of all the calls
you have dialled.
•
Total
received
: check the total length of all the
calls you have received.
•
Reset timers
: reset the call timers. You need to
enter the phone password.
Data Volume
(Menu 3.8)
• Recent Volume
•Total Volume
• Reset Volume
The password is preset to
00000000
. You can
change this password.
p. 72
Menu functions
MEdia Net
(Menu 4)
43
Data Call Time
(Menu 3.9)
•Recent Time
•Total Time
•Reset Timers
Address Book
(Menu 3.0)
MEdia Net
(Menu 4)
MEdia Net stores file downloads for the following:
MEdia Net Home
(Menu 4.1)
Favorites
(Menu 4.2)
Enter URL
(Menu 4.3)
Browser Profiles
(Menu 4.4)
Clear Cache
(Menu 4.5)
Cingular Mall
(Menu 5)
Shop Tones
(Menu 5.1)
Shop Games
(Menu 5.2)
Shop Graphics
(Menu 5.3)
Shop Multimedia
(Menu 5.4)
Shop Applications
(Menu 5.5)
MEdia Net Home
(Menu 5.6)
Cingular Video
(Menu 6)
Cingular Video
allows you to view video clips of
news, sports and entertainment.
My Stuff
(Menu 7)
The
File manager
menu allows you to access images,
videos, music files, and sound files stored in the
phone’s memory.
To access this menu, press <
Menu
> in Idle mode and
select
File manager
.
According to the DRM (Digital Rights Management)
system, web content may not be able to be
forwarded. The content is indicated by the
icon
.
44
Menu functions
My MEdia
(Menu 7.1)
This menu displays photos you have taken and images
downloaded or received in messages.
Viewing an image
1. Select an image folder.
2. Scroll to an image and press [ ].
Using image options
While viewing an image or the image list, press
<
Options
> to access options.
p. 47
Games
(Menu 7.2)
Use this menu to play Java games, to play music files,
to record a voice memo, to set time zones and alarms,
or to use your phone as a calculator, timer, convertor,
or stopwatch. You can also use the phone as an FM
radio.
To access this menu, press <
Menu
> in Idle mode and
select Games &
Applications
.
Application
(Menu 7.3)
You can use the camera module embedded in your
phone to take photos and record videos.
To access this menu, press <
Menu
> in Idle mode and
select
Camera
, or press and hold
[
]
.
Taking a photo
You can take photos in various modes using the
phone. The camera produces JPEG photos.
Taking a photo with the phone open
1. Access the
Camera
menu to turn on the camera.
The image to be captured appears on the display.
• Do not take photos of people without their
permission.
• Do not take photos in a place where cameras are
not allowed.
• Do not take photos in a place where you may
interfere with another person’s privacy.
When you take a photo in direct sunlight or in bright
conditions, shadows may appear on the photo.
Menu functions
My Stuff
(Menu 7)
45
2. Adjust the image by aiming the camera lens at the
subject.
• Press the left soft key to access camera
options.
• Use the keypad to change camera settings or
switch to other modes.
p. 46
3. Press [
]
to take a photo. The photo is saved in
the
Photos
folder.
Using camera options in Capture mode
In Capture mode, press the left soft key to access the
following options:
•
Record video
: switch to Record mode.
p. 48
•
Shooting mode
: take a photo in the following
modes:
Single shot
: take a photo in normal mode.
Multi shot
: take a series of action stills. Select the
number of photos the camera will take and the rate
at which the photos are taken.
Mosaic shot
: take several stills and save them in
one frame. Select the number of still images the
camera will take.
•
Effects
: change the colour tone or apply a special
effect to the photo.
•
Frames
: apply a decorative frame to the photo.
•
Flash
: determine the flash use.
•
Timer
: set a time delay before the camera takes a
photo.
•
Go to photos
: go to the
Photos
folder.
•
Settings
: change the default settings for taking a
photo.
Size
: select an image size.
Quality
: select an image quality setting.
View finder
: select a preview screen.
4.
To Press
use photo options <
Options
>.
p. 47
delete the photo <
Delete
> and then
<
Yes
>.
return to Capture mode [ ].
46
Menu functions
ISO
: change the ISO setting, which controls the
sensitivity of your camera. For low light situations,
lower the ISO number to increase the quality.
The higher the ISO number, the faster the camera
shutter functions and the more sensitive the
camera is to light. Higher ISO settings may bring
some distortion to an image.
Spot focus
: adjust the exposure based on a
specific area of the image. Select
On
to display the
spot focus frame in the middle of the image, and
change the exposure according to the brightness of
the image fragment in the frame.
Shutter sound
: select the sound that you hear
when you press the shutter release, [
]
.
Zoom sound
: turn on or off the sound that you
hear when zooming in.
Brightness sound
: turn on or off the sound that
you hear when adjusting the image brightness.
Default name
: change the default prefix of the
photo name.
•
Camera short cuts
: view the functions of the
keys you can use.
Using the keypad in Capture mode
You can use the keypad to customise your camera
settings in Capture mode.
Keys Function
Flips the image vertically.
Shows the mirror image.
Left/Right Adjusts the brightness of the image.
Up/Down Zooms in or out.
1
Switches to Record mode.
p. 48
2
Changes the image size.
3
Changes the image quality.
4
Changes the camera mode.
5
Changes the colour tone or applies a
special effect to the photo.
6
Reduces the distortion on the image to
maximise detail and sharpness.
Menu functions
My Stuff
(Menu 7)
47
Using photo options
After taking a photo, press <
Options
> to access the
following options:
•
Take another
: return to Capture mode to take
another photo.
•
Send via
: send the photo via MMS, e-mail, or
Bluetooth.
•
Set as
: set the photo as your wallpaper for the
displays or as a caller ID image for a Phonebook
entry.
•
Delete
: delete the photo.
•
Rename
: change the name of the photo.
•
Go to photos
: go to the
Photos
folder.
•
Share for Bluetooth
: set whether or not to
prevent the photo from being accessed from other
Bluetooth devices.
•
Print via
: print the selected photo by connecting
the phone to a printer via USB or Bluetooth.
•
Protection
: protect the photo from being deleted.
•
Properties
: view the photo properties.
Viewing a photo
1. In Capture mode, press the left soft key and select
Go to photos
.
2. Scroll to a photo and press [ ].
While viewing a photo or the photo list, press
<
Options
> to access the following options:
•
List
: return to the photo list.
•
View
: view the photo on the full screen.
•
Send via
: send the photo via MMS, e-mail, or
Bluetooth.
•
Set as
: set the photo as your wallpaper for the
displays or as a caller ID image for a Phonebook
entry.
7
Selects a decorative frame.
8
Sets the timer.
9
Goes to the
Photos
folder
0
Determines the flash use.
Changes the preview screen.
Keys Function
48
Menu functions
•
Edit
: decorate the photo by adding emoticons or
applying a frame or special effect.
•
Delete
: delete the photo.
•
Rename
: change the name of the photo.
•
Move to favourite images
: move the photo to
the
Favourite images
folder.
•
Slide show
: display all photos in turn as a slide
show. Select the length of time for which each
photo is displayed.
•
Share for Bluetooth
: set whether or not to
prevent the photo from being accessed from other
Bluetooth devices.
•
Print via
: print the selected photo by connecting
the phone to a printer via USB or Bluetooth.
•
Protection
: protect the photo from being deleted.
•
Properties
: view the photo properties.
Taking a photo with the phone closed
1. Press and hold [
]
.
2. If necessary, press [ ] to display .
3. Adjust the image by aiming the camera lens at the
subject.
5. Press [
]
to take a photo. The photo is
automatically saved in the
Photos
folder.
Recording a video
You can record a video of what is displayed on the
camera screen and save it.
Recording a video with the phone open
1. In Capture mode, press [
1
] to switch to Record
mode.
2. Adjust the image by aiming the camera lens at the
subject.
• Press the left soft key to access camera
options.
4.
To Press
flip the image vertically [ ].
show the mirror image [ ].
adjust the brightness of
the image
[].
zoom in [ ].
Menu functions
My Stuff
(Menu 7)
49
• Use the keypad to change camera settings or
switch to other modes.
p. 50
3. Press [
]
to start recording.
4. Press [
]
or the right soft key to stop recording.
The video is automatically saved in the
Videos
folder.
Using camera options in Record mode
In Record mode, press the left soft key to access the
following options:
•
Take a photo
: switch to Capture mode.
p. 44
•
Effects
: change the colour tone or apply a special
effect to a video.
•
Flash
: determine the flash use.
•
Timer
: set a time delay before the camera starts
recording.
•
Go to videos
: go to the
Videos
folder.
•
Settings
: change the following settings for
recording a video:
Recording mode
: select a video recording mode.
Select
Limit for
MMS
to record a video suitable
for an MMS message. The video clip is saved in
3GP format.
Select
Normal
to record a video within the limit of
the currently available memory.
Size
: select a frame size.
Quality
: select an image quality setting.
Audio rec.
: record audio with a video clip.
Zoom sound
: turn on or off the sound that you
hear when zooming in.
Brightness sound
: turn on or off the sound that
you hear when adjusting the video image
brightness.
Default name
: change the default prefix of the
video clip name.
5.
To Press
play back the video clip [ ].
use video options the left soft key.
p. 50
delete the video clip [
C
] and then <
Yes
>.
return to Record mode the right soft key.
50
Menu functions
•
Camcorder short cuts
: view the functions of the
keys you can use.
Using the keypad in Record mode
You can use the keypad to customise your camera
settings in Record mode:
Using video options
After recording a video clip, press the left soft key to
access the following options:
•
Record another
: return to Record mode.
•
Send via
: send the video clip via MMS, e-mail, or
Bluetooth.
•
Delete
: delete the video clip.
•
Rename
: change the name of the video clip.
•
Go to videos
: go to the
Videos
folder.
Keys Function
Flips the image vertically.
Shows the mirror image.
Left/
Right
Adjusts the brightness of the image.
Up/
Down
Zooms in or out.
1
Switches to Capture mode.
p. 44
2
Changes the frame size.
3
Changes the image quality.
4
Changes the video recording mode.
5
Changes the colour tone or applies a special
effect to the video image.
6
Reduces the distortion on the image to
maximise detail and sharpness.
7
Mutes or unmutes the audio.
8
Sets the timer.
9
Goes to the
Videos
folder.
0
Determines the flash use.
Keys Function
Menu functions
My Stuff
(Menu 7)
51
•
Protection
: protect the video clip from being
deleted.
•
Properties
: view the video clip properties.
Playing a video clip
1. In Record mode, press the left soft key and select
Go to videos
.
2. Scroll to a video clip and press [ ].
During playback, use the following buttons on the
display:
After playing back the video clip, press the left soft key
to access the following options:
•
Play
: play the video clip.
•
Send via
: send the video clip via MMS, e-mail, or
Bluetooth.
•
Delete
: delete the video clip.
•
Rename
: change the name of the video clip.
•
Move to favourite videos
: move the video clip to
the
Favourite videos
folder.
•
Share for Bluetooth
: set whether or not to
prevent the video clip from being accessed from
other Bluetooth devices.
•
Protection
: protect the video clip from being
deleted.
•
Properties
: view the video clip properties.
Recording a video with the phone closed
1. Press and hold [
]
.
2. If necessary, press [ ] to display .
3. Adjust the image by aiming the camera lens at the
subject.
Keys Function
Pauses or resumes playback.
Down Stops playback.
Left Skips backward through a file.
Right Skips forward through a file.
/ Adjusts the volume.
4.
To Press
flip the image vertically [ ].
52
Menu functions
5. Press [
]
to start recording.
6. Press [
]
to stop recording. The video clip is
automatically saved in the
Videos
folder.
Alarm
Use this menu to set alarms to sound at specific times.
Setting an alarm
1. Select the type of alarm.
2. Press [Left] or [Right] to select
On
and press
[Down].
3. Enter the time for the alarm to sound and press
[Down].
4. Press [Left] or [Right] to select
AM
or
PM
in 12-
hour time format and press [Down].
5. Select a repeat option.
6. Select the
Alarm tone
line and select an alarm
melody.
7. Press <
Save
> and then <
Yes
> to set the alarm.
Stopping an alarm
• When an alarm sounds, press <
OK
> or any key.
• When a wake-up call alarm sounds, press <
OK
> or
[] to stop the alarm.
Otherwise, press <
Snooze
> or any key to stop
the alarm and cause it to sound again after 5
minutes. You can do this a maximum of five times.
Setting the alarm to ring even if the phone is
off
From the Alarm screen, select
Auto power
→
On
.
If the phone is off when it is time for the alarm to ring,
the phone is switched on and sounds the alarm.
Calendar
The calendar feature enables you to keep track of your
schedule and to-do list, and to view missed alarm
events.
show the mirror image [ ].
adjust the brightness of
the image
[].
zoom in [ ].
4.
To Press
Menu functions
My Stuff
(Menu 7)
53
To access this menu, press <
Menu
> in Idle mode and
select
Calendar
.
Consulting the calendar
When you enter the
Calendar
menu, the calendar in
Month view appears with today’s date highlighted.
The number of events for the specific day appears at
the bottom of the calendar. The following icons
indicate the type of event:
Press <
Options
> to access the following options:
•
View mode
: change the view mode of the
calendar.
•
Create
: add a new event.
•
Go to
: go to the current date or enter a specific
date.
•
Sort by
: sort items by the type of event.
•
Delete
: delete the event(s).
•
Missed alarm events
: view events whose alarms
you have missed.
•
Memory status
: view the memory status for
items stored in the phone’s memory.
Creating an event
You can schedule events on the calendar.
Entering a new scheduled event
1. Scroll to a date on the calendar.
2. Press <
Options
> and select
Create
→
Schedule
.
3. Enter information or change the settings in the
following entry fields:
•
Subject
: enter the event subject.
•
Details
: enter event details.
•
Start date
and
Start time
: enter the starting
date and time for the event.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
End date
and
End time
: enter the ending date
and time for the event.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
Location
: enter information about the event
location.
• Scheduled event • Anniversary
• To-do item • Miscellaneous
54
Menu functions
•
Alarm
: select to set an alarm for the event.
•
Before
: set how long before the event the
alarm is to alert you.
•
Alarm tone
: select an alarm tone.
•
Repeat
: select to set the event to recur and a
repeat unit.
•
Until
: if the event will recur, set the ending
date.
4. Press <
Save
> to save the event.
Entering a new anniversary
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
Anniversary
.
3. Enter information or change the settings in the
following entry fields:
•
Occasion
: enter information about the
anniversary.
•
Date
: enter the date.
•
Alarm
: select to set an alarm for the
anniversary.
•
Before
: set how long before the event the
alarm is to alert you.
•
Alarm time
: enter the time for the alarm to
sound.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
Alarm tone
: select an alarm tone.
•
Repeat every year
: select to set the phone to
remind you of the anniversary every year.
4. Press <
Save
> to save the event.
Entering a new
Miscellaneous
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
Miscellaneous
.
3. Enter information or change the settings in the
following entry fields:
•
Subject
: enter the title of the event.
•
Details
: enter event details.
•
Start date
and
Start time
: enter the starting
date and time for the event.
Menu functions
My Stuff
(Menu 7)
55
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
End date
and
End time
: enter the ending date
and time for the event.
•
AM/PM
: select
AM
or
PM
in 12-hour time
format.
•
Alarm
: set an alarm for the event.
•
Before
: set the time for the alarm.
•
Alarm tone
: select an alarm tone.
4. Press <
Save
> to save the event.
Entering a to-do item
1. Select a date on the calendar.
2. Press <
Options
> and select
Create
→
To do
.
3. Enter information or change the settings in the
following entry fields:
•
To do
: enter information about the task.
•
Start date
: enter the starting date.
•
Due date
: enter the ending date.
•
Priority
: select a priority level of the task.
4. Press <
Save
> to save the event.
Viewing an event
Square brackets on a calendar date indicate the
following type of events scheduled for that day:
1. Select a date on the calendar to display the events
for the day.
2. Select an event to view its details.
While viewing an event or the event list, press
<
Options
> to access the following options:
•
View
: display the event details.
•
Edit
: edit the event.
•
Create
: add a new event.
•
Send via
: send the event via SMS, MMS,
e-mail, or Bluetooth.
•
View mode
: change the view mode of the
calendar.
•
Done
/
Undone
: mark the to-do item as done, or
not.
•
Sort by
: sort items by the type of event.
•
Delete
: delete the event(s).
• Blue: Scheduled event • Orange: Anniversary
• Red: To-do item • Green: Miscellaneous
56
Menu functions
•
Print via bluetooth
: print the selected event by
connecting the phone to a printer via Bluetooth.
•
Missed alarm events
: view events whose alarms
you have missed.
•
Memory status
: view the memory status for
items stored in the phone’s memory.
Viewing an event in different mode
By default, the calendar appears in Month view mode.
Press <
Options
> and select
View mode
to change
the mode.
Day view
You can view events for the selected date. Select an
event to view its details.
The following icons will be displayed according to the
event’s type and status:
• Alarm set
• Recurring event
• Completed to-do item
• To-do priority; its colour indicates the priority
level (Red: high, Blue: normal, and Grey: low)
Week view
You can view miscellaneous and scheduled events for
the selected week.
A cell on the timetable indicates the presence of event
information. Select the cell that contains the event you
want.
Viewing a
missed alarm event
When you are unable to acknowledge an alarm, the
phone displays a missed alarm notification.
• Press <
View
> to view the corresponding event.
• Press <
Exit
>.
Accessing missed alarm events
1. Press <
Options
> and select
Missed alarm
events
.
2. Select an event.
Using missed alarm options
From the event list, press <
Options
> to access the
following options:
•
View
: display the event details.
•
Delete
: delete the event.
Menu functions
My Stuff
(Menu 7)
57
•
Delete all
: delete all events.
Calculator
Use this menu to perform basic arithmetic functions,
such as addition, subtraction, multiplication, and
division.
1. Enter the first number.
Press the left soft key to insert a decimal point or
brackets.
2. Select the operation for your calculation by
pressing one of the Navigation keys according to
the illustration on the display.
3. Enter the second number.
4. Press [ ] to view the result.
Record Audio
Use this menu to record voice memos. A voice memo
can be up to one hour long.
Recording a voice memo
1. Press [ ] to start recording.
2. Speak into the microphone.
Press [ ] to pause or resume the recording.
3. When you finish, press <
Stop
>. The voice memo
is saved automatically.
4. Press [Up] to record another voice memo, or press
<
Options
> to access the following options:
•
Play
: play back your voice memo.
•
Send via
: send the voice memo via MMS,
e-mail, or Bluetooth.
•
Set as
: set the voice memo as your ring tone,
alarm melody, or a caller alert melody for a
Phonebook entry.
•
Delete
: delete the voice memo.
•
Rename
: change the name of the voice memo.
•
Move to favourite sounds
: move the voice
memo to the
Favourite sounds
folder.
•
Share for Bluetooth
: set whether or not to
prevent this voice memo from being accessed
by other Bluetooth devices.
•
Protection
: protect the voice memo from
being deleted.
•
Properties
: view the voice memo properties.
Press [ ] or [ ] to move the cursor
.
58
Menu functions
Playing a voice memo
1. From the Voice record screen, press <
Options
>
and select
Go to voice list
.
2. Select a voice memo. The memo plays.
During playback, use the following keys:
Using voice memo options
From the Voice record screen, press <
Options
> to
access the following options:
•
Record
: record a new voice memo.
•
Settings
: configure the following settings for a
voice memo:
Recording time
: select the recording time.
Volume
: select the voice memo volume to be
used during playback.
Default name
: specify a default saving prefix for
the voice memo.
•
Go to voice list
: go to the list of voice memos you
have recorded.
Unit Conversion
Use this menu for common conversions, such as
currency and temperature.
Performing a conversion
1. Select the convertor type you want.
2. Press [Left] or [Right] to select the original unit
and press [Down].
3. Enter the value to be converted.
• Press [ ] to insert a decimal point.
• Press [ ] to change the temperature to above
zero (+) or below zero (-).
Keys Function
Pauses or resumes playback.
Left Moves backward.
Right Moves forward.
Up Returns to Record mode.
Down Stops playback.
/ Adjusts the volume.
Menu functions
My Stuff
(Menu 7)
59
4. Press [Down].
5. Press [Left] or [Right] to select the unit you want
to convert to.
The equivalent value for the amount you entered
displays.
Using convertor options
Press <
Options
> to access the following options:
•
Clear
: clear the current values.
•
Reverse
: reverse the conversion.
•
Currency rates
: access and edit the currency rate
list.
Timer
Use this menu to set a period of time for the phone to
count down. The phone will sound an alarm when the
specified period of time has expired.
Starting the timer
1. Press <
Set
>.
2. Enter the length of time you want to count down
and press <
OK
>.
3. Press [ ] to start counting down.
Stopping the timer
• Press <
Back
> or any key when the timer rings.
• Press [ ] on the Timer screen to stop the timer
before it rings.
Stopwatch
Use this menu to measure elapsed time. The precision
of the stopwatch is one one-hundredth of a second.
The maximum measurement time is 10 hours.
1. Press [ ] to start the stopwatch.
2. Press [ ] to check an interval. You can repeat
this step for a total of 4 intervals.
3. To reset the stopwatch, press <
Reset
>.
World Time
Use this menu to set your local time zone and find out
what time it is in another part of the world.
Setting your local time zone
1. From the world map, press [Left] or [Right] to
select the city that corresponds to your home time
zone. As the time line moves, the time and date of
the given zone display.
60
Menu functions
2. Press [ ] to save the time zone.
Viewing and setting a foreign time zone
1. From the world map, press [Down].
2. Press [Left] or [Right] to select the foreign time
zone you want.
3. Press [ ] to save the time zone.
Applying Daylight Savings Time (DST)
1. From the world map, press <
Options
> and select
Set daylight saving time
.
2. Press [ ] to check the time zone(s) you want.
3. Press <
Save
>.
PIM Sync
Address Book
(Menu 8)
You can store phone numbers on your SIM card and in
your phone’s memory. The SIM card and phone’s
memory are physically separate, but they are used as
a single entity called Phonebook.
To access this menu, press <
Menu
> in Idle mode and
select
Phonebook
.
Contact list
(Menu 8.1)
Use this menu to search for numbers in Phonebook.
Finding an entry
1. Enter the first few letters of the name that you
want to find.
2. Select the name you want from the list.
3. Press [ ] to dial the number, or <
Options
> to
access Phonebook options.
Press <
Contacts
> in Idle mode to quickly access
this menu.
Menu functions
Address Book
(Menu 8)
61
Using Phonebook options
While viewing the contact details, press <
Options
> to
access the following options:
•
Edit
: edit the contact information.
•
Send message
: send an SMS, MMS, or e-mail
message.
•
Copy
: copy the selected number to the phone’s
memory, the SIM card, or the FDN list.
•
Send via
: send the contact via SMS, MMS, e-mail,
or Bluetooth.
•
Delete
: delete the selected contact.
•
Print via bluetooth
: print the contact information
by connecting the phone to a printer via Bluetooth.
While viewing the contact list, press <
Options
> to
access the following options:
•
View
: display details about the contact.
•
Send message
: send an SMS, MMS, or e-mail
message.
•
Add new contact
: add a new contact to
Phonebook.
•
Delete
: delete the selected contact or all contacts.
•
Language select
: select a language to be used in
the text input mode.
Add new contact
(Menu 8.2)
Use this menu to add a new contact to Phonebook.
Storing a number in the phone’s memory
1. Select
Phone
.
2. Change the settings or enter information about the
contact.
•
Last name
/
First name
: assign a name.
•
Mobile
/
Home
/
Office
/
Fax
/
Other
: add a
number in any category.
•
Email
: assign an e-mail address.
•
Graphic ID
: assign an image as a caller ID
image to alert you to a call from the person.
62
Menu functions
•
Alert
: assign a ringer melody to alert you to a
call from the person.
•
Group
: assign the person to a caller group.
•
Notes
: add a memo about the person.
3. Press [ ] to save the contact.
Storing a number on the SIM card
1. Select
SIM
.
2. Enter a name and a phone number.
3. If necessary, change the location number.
4. Press [ ] to save the contact.
Groups
(Menu 8.3)
Use this menu to organise your contacts in caller
groups.
Creating a new caller group
1. Press <
Options
> and select
Add
.
2. Enter a name for the group.
3. Select the
Graphic ID
line to assign an image.
4. Select the
Alert
line to assign a ringer melody.
5. Press <
Save
> to save the group.
Adding members to a caller group
1. Select a group.
2. Press <
Add
>. The list of contacts stored in your
phone’s memory is displayed.
3. Select a contact you want to add to the selected
group.
4. To add more members, press <
Options
> and
select
Add
→
a contact. Repeat this as desired.
Managing caller groups
While viewing the group list, press <
Options
> to
access the following options:
•
View
: display the members of the selected group.
•
Add
: add a new group.
•
Edit
: edit the properties of the selected group.
•
Send message
: send an SMS, MMS, or e-mail
message to the member(s) you want.
The settings specified in
Graphic ID
and
Alert
are given priority over group settings.
Menu functions
Address Book
(Menu 8)
63
•
Delete
: delete the selected group. Group
members, however, are not deleted from
Phonebook.
Speed dial
(Menu 8.4)
Use this menu to assign a speed dial number (2 to 9)
for eight of your most frequently called numbers.
Assigning speed dial numbers
1. Select a key location from
2
to
9
. [
1
] is reserved
for your voice mail server.
2. Select a contact you want.
3. If the contact has more than one number, select
the number you want.
Managing speed dial entries
From the Speed dial screen, press <
Options
> to
access the following options:
•
Add
: assign a number to an unassigned key. You
can select a contact from Phonebook or the FDN
list.
•
View
: display the number assigned to the key.
•
Change
: assign a different number to the
assigned key.
•
Remove
: clear the speed dial setting.
Dialling speed dial entries
Press and hold the appropriate key in Idle mode.
My name card
(Menu 8.5)
Use this menu to create a name card and send it to
other people.
Saving your name card
The procedure for creating your name card is the
same as the one for saving a phone number in the
phone’s memory.
p. 61
Using name card options
After saving your name card, press <
Options
> to
access the following options:
•
Edit
: edit the name card.
•
Send via
: send the name card via SMS, MMS,
e-mail, or Bluetooth.
64
Menu functions
•
Exchange namecard
: exchange name cards with
another person via Bluetooth.
•
Remove
: delete the name card.
•
Print via bluetooth
: print the name card by
connecting the phone to a printer via Bluetooth.
Copy All
(Menu 8.6)
Own number
(Menu 8.7)
Use this feature to check your phone numbers, or to
assign a name to each of the numbers. Changes made
here do not affect the actual subscriber numbers in
your SIM card.
Settings
(Menu 8.8)
Use this menu to manage Phonebook.
•
Default saving
: select a default memory location
to save contacts.
If you select
Ask on saving
, the phone will ask
you to select a memory location when saving a
number.
•
Copy all to phone
: copy all of the contacts stored
in the SIM card to the phone’s memory.
•
Sort by contacts
: sort your contacts by the first
name or last name.
•
Delete all
: delete all of the contacts from your
phone’s memory, your SIM card, or the FDN list.
1.Press [ ] to check the location(s) to be
cleared.
If you select
FDN
, you need to enter the PIN2
and password.
2.Press <
Delete
> and then <
Yes
>.
3.Enter the phone password and press <
OK
>.
•
Memory status
: display the number of contacts
you have stored in Phonebook.
Memory Status
(Menu 8.9)
You can check the total amount of memory for media
items and the amount of memory currently in use in
each media box.
The password is preset to
00000000
. You
can change this password.
p. 72
Menu functions
Settings
(Menu 9)
65
Settings
(Menu 9)
Use this menu to customise your phone settings. You
can also reset the settings to their default values.
To access this menu, press <
Menu
> in Idle mode and
select
Settings
.
Time & Date
(Menu 9.1)
Use this menu to set the current time and date on
your phone. Before setting the time and date, specify
your time zone in the
World time
menu.
p. 59
•
Set time
: enter the current time.
•
AM/PM
: select
AM
or
PM
in 12-hour time format.
•
Time format
: select the time format.
•
Set date
: enter the current date.
•
Date format
: select the date format.
Profiles
(Menu 9.2)
Phone Settings
(Menu 9.3)
Many different features of your phone’s system can be
customised to suit your preferences.
Language
(Menu 9.3.1)
Use this menu to select one of several languages for
the display text.
Greeting message
(Menu 9.3.2)
Use this menu to enter the greeting that is displayed
briefly when the phone is switched on.
Short cut
(Menu 9.3.3)
You can use the Navigation keys as shortcut keys to
access specific menus directly from Idle mode. Use
this menu to assign a shortcut menu to a key.
Assigning a menu to a key
1. Select a key to be used as a shortcut key.
2. Press <
Options
> and select
Change
.
3. Scroll to a menu to be assigned to the key.
4. Press <
Save
>.
66
Menu functions
Using shortcut options
Press <
Options
> to access the following options:
•
Change
: assign or change a shortcut menu.
•
Remove
: deactivate the shortcut assignment.
•
Remove all
: deactivate all shortcut assignments.
Extra settings
(Menu 9.3.4)
You can turn the automatic redialling or answering
feature on or off, and lock the exposed keys.
•
Auto redial
: set the phone to make up to ten
attempts to redial a phone number after an
unsuccessful call.
•
Anykey
answer
: answer an incoming call by
pressing any key, except [ ], <
Reject
>,
and [ / ].
When this option is not selected, you must press
[] or <
Accept
> to answer a call.
•
Voice clarity
: increase the microphone’s
sensitivity to allow the other person on the phone
to hear your voice clearly, even though you may be
whispering.
•
Active folder
: answer an incoming call by opening
the phone.
•
Cover keylock
: lock the exposed keys to keep
accidental presses from affecting performance
while listening to the radio or playing music files.
Display Settings
(Menu 9.4)
Use this menu to change settings for the display and
light.
Wallpaper
(Menu 9.4.1)
You can set up the idle screen on both displays.
•
Main display
: select an image to be displayed on
the main display.
•
Cover display
: select an image or enter text to be
displayed on the external display.
Text display
(Menu 9.4.2)
You can customise the text appearance for the idle
screen.
•
Text position
: select a text position on the
display. If you don’t want to display text in Idle
mode, select
Off
.
Menu functions
Settings
(Menu 9)
67
•
Text style
: select a text style.
•
Text colour
: select a text colour.
Skin
(Menu 9.3.3)
You can select a skin colour for Menu mode.
LCD brightness
(Menu 9.4.4)
You can adjust the brightness of the display for
varying lighting conditions.
Backlight
(Menu 9.4.5)
You can select the length of time the backlight stays
on and the display is on in Dim mode, in which the
backlight is off.
•
Main LCD on
: select the length of time the
backlight is on.
•
Main LCD dim
: select the length of time the
display is in Dim mode after the backlight turns off.
After a specified time, the display turns off.
•
Show cover indicators
: set whether or not the
cover display icons are shown on the external
display.
Call
(Menu 9.5)
Use this menu to customise various sound settings.
Incoming call
Use this menu to select a volume and alert type for
incoming calls.
•
Ring tone
: select a ring tone for the call ringer.
•
Volume
: select a ringer volume.
•
Alert type
: specify how you are to be informed of
incoming calls.
Melody
: the phone rings using the selected ring
tone.
Vibration
: the phone vibrates but not rings.
Vibration then melody
: the phone vibrates three
times and then starts ringing.
Keypad tone
Use this menu to select the tone that the phone
sounds when you press a key.
You can adjust the keypad tone volume using
[/]
in Idle mode.
68
Menu functions
Message tone
Use this menu to set up the ringer for incoming
messages and e-mails.
•
Tone
: select one of several message tones.
•
Alert type
: specify how you are to be informed of
any incoming messages.
•
Repetition
: specify how often the phone informs
you of a new message.
Power on/off
Use this menu to select the melody that the phone
sounds when it is switched on or off.
Folder tone
Use this menu to select the tone that the phone
sounds when you open or close the phone.
Quiet mode
Use this menu to set how the phone acts to alert you
to a specific event in Quiet mode, instead of making
sounds.
•
Vibration
: set the phone to vibrate.
•
Mute
: mute all sound settings.
Extra tones
Use this menu to customise additional tones for the
phone.
•
Minute
minder
: set the phone to beep every
minute during an outgoing call to keep you
informed of the length of your call.
•
Connection
tone
: set the phone to beep when it
is connected to the system.
•
Alerts on call
: set the phone to beep when you
receive a new message or when the time for an
alarm comes during a call.
•
Indicative tones
: set the phone to beep when a
pop-up window appears to indicate that your
phone has completed an operation or that an error
occurs.
Menu functions
Settings
(Menu 9)
69
Connectivity
(Menu 9.6)
Use this menu to activate the Bluetooth feature.
Using the Bluetooth feature, you can connect the
phone wirelessly to other Bluetooth devices and
exchange data with them, talk hands-free, or control
the phone remotely.
Bluetooth technology allows free wireless connections
between all Bluetooth-compliant devices within a
range of 10 meters. Since the devices communicate
using radio waves, they do not need to be in line of
sight to each other.
Setting up the Bluetooth feature
The
Bluetooth
menu provides the following options:
•
Activation
: activate or deactivate the Bluetooth
feature.
•
My devices
: search for connectable Bluetooth
devices.
•
My phone’s visibility
: allow other Bluetooth
devices to search for your phone.
•
My phone’s name
: assign a Bluetooth device
name to your phone, which is then displayed on
other devices.
•
Secure mode
: determine if the phone asks for
your confirmation when other devices access your
data.
•
Bluetooth services
: display available Bluetooth
services.
Searching for and pairing with a Bluetooth
device
1. From the Bluetooth setting options, select
My
devices
.
2. Select
Search new device
.
If you have searched for devices before, the phone
displays
More devices
along with the devices you
have searched for previously. To search for new
devices, select
More devices
.
• You cannot use the Bluetooth feature while using
multimedia features such as voice recorder,
camera, and MP3 player, or vice versa.
• Some devices may not be compatible with your
phone.
70
Menu functions
After searching, a list of devices to which you can
connect displays. The following icons indicate the
kind of device:
The colour of the icon indicates the status of the
the device:
• Grey for unpaired devices
• Blue for paired devices
• Red for devices that are currently connected to
your phone
3. Select a device.
4. Enter a Bluetooth PIN code and press <
OK
>.
This
code is used just once and you don’t need to
memorise it.
When the owner of the other device enters the
same code, pairing is complete.
Using device options
From the device list, press <
Options
> to access the
following options:
•
Connect
: connect to the currently selected device.
•
Disconnect
: end the connection with the device.
•
Browse files
: search for data from the device and
import data directly to your phone.
•
Service list
: display available Bluetooth services
for the selected device.
•
Rename
: rename the paired device.
•
Authorize device
/
Unauthorize device
:
determine whether or not the phone asks you to
permit connection when the device tries to connect
to your phone.
•
Delete
: remove the selected device or all
displayed devices from the device list.
• Hands-free or
headset
• Mobile phone
• Computer • PDA
• Printer • Unknown device
Some devices, especially headsets or hands-free
car kits, may have a fixed Bluetooth PIN, such as
0000
. If the other device has a code, you must
enter it.
Options may vary depending on the paired device.
Menu functions
Settings
(Menu 9)
71
Sending data via Bluetooth
1. Activate the Bluetooth feature.
2. Select the application in which the item you want
to send is stored.
3. Scroll to the item you want and press <
Options
>.
4. Select
Send
via
→
Bluetooth
.
The phone searches for devices within range and
displays a list of available devices.
5. Select a device.
6. If necessary, enter the Bluetooth PIN needed for
pairing and press <
OK
>.
Receiving data via Bluetooth
To receive data via Bluetooth, your phone’s Bluetooth
feature must be active.
If an unauthorised Bluetooth device sends data to your
phone, the phone displays a confirmation message. To
receive data, press <
Yes
>.
Software Update
(Menu 9.7)
Application Settings
(Menu 9.8)
Security
(Menu 9.9)
Use this menu to protect the phone against
unauthorised use by managing the several access
codes of your phone and SIM card.
PIN check
(Menu 9.9.1)
The 4- to 8-digit PIN (Personal Identification Number)
protects your SIM card against unauthorised use.
When this feature is enabled, the phone requires your
PIN each time it is switched on.
Change PIN
(Menu 9.9.2)
Use this menu to change your PIN. The PIN check
feature must be enabled to use this feature.
Phone lock
(Menu 9.9.3)
This feature locks the phone from unauthorised use.
If you enter an incorrect PIN /PIN 2 three times in
succession, the SIM card is blocked. To unblock it
you need to enter your PUK/PUK2 (Personal
Unblocking Key). The codes are supplied by your
network operator.
72
Menu functions
When this feature is enabled, you must enter a 4- to
8-digit phone password each time the phone is
switched on.
The password is preset to
00000000
. To change the
password, use the
Change password
menu.
Change password
(Menu 9.9.4)
Use this menu to change your phone password. The
password is preset to
00000000
.
Privacy
(Menu 9.9.5)
Use this menu to lock your media contents, including
MMS messages, e-mails, images, videos, music files,
and sounds.
1. Press [ ] to check the item(s) to lock.
2. Press <
Save
> to lock the marked items.
3. Enter the phone password and press <
OK
>.
To access a locked item, you need to enter the phone
password. The password is preset to
00000000
.
SIM lock
(Menu 9.9.6)
The SIM lock feature allows your phone to work only
with the current SIM by assigning a SIM lock code. You
must enter the SIM lock code to use a different SIM
card.
FDN mode
(Menu 9.9.7)
If supported by your SIM card, Fixed Dialling Number
(FDN) mode restricts your outgoing calls to a limited
set of phone numbers. When this feature is enabled,
you can make calls only to phone numbers specified in
the FDN list.
p. 61
To activate this feature, you must enter your PIN2.
Change PIN2
(Menu 9.9.8)
If supported by your SIM card, the change PIN2
feature changes your current PIN2.
Memory status
(Menu 9.10)
Use this menu to check the amount of memory being
used for storing data in
Messages
,
File manager
,
Calendar
,
Phonebook
, and
Java world
. You can
also check
Shared memory
for MMS, Email, and File
manager.
Slove problems
Settings
(Menu 9)
73
Reset Settings
(Menu 9.11)
Use this menu to reset the phone settings, display
settings, and sound settings individually. You can also
reset all of the settings in your phone at the same
time.
1. Press [ ] to check the setting category(ies) to
be reset.
2. Press <
Reset
> to reset the marked items.
3. Press <
Yes
> to confirm the reset.
4. Enter the phone password and press <
OK
>.l
Slove problems
Help and personal needs
To save the time and expense of an unnecessary service
call, perform the simple checks in this section before
contacting a service professional.
When you switch on your phone, the following
messages may appear:
“Insert SIM card”
• Be sure that the SIM card is correctly installed.
“Phone lock”
• The automatic locking function has been enabled. You
must enter the phone’s password before you can use
the phone.
“Enter PIN”
• You are using your phone for the first time. You must
enter the PIN supplied with the SIM card.
• The PIN check feature is enabled. Every time the
phone is switched on, the PIN has to be entered. To
disable this feature, use the
PIN check
menu.
“Enter PUK”
• The PIN code has been entered incorrectly three times
in succession, and the phone is now blocked. Enter the
PUK supplied by your service provider.
The password is preset to
00000000
. To
change the password, use the
Change
password
menu.
p. 72
74
Slove problems
“No service,” “Network failure,” or “Not done”
displays
• The network connection has been lost. You may be in a
weak signal area. Move and try again.
• You are trying to access an option for which you have
no subscription with your service provider. Contact the
service provider for further details.
You have entered a number but it was not dialled
• Be sure that you have pressed [ ].
• Be sure that you have accessed the right cellular
network.
• Be sure that you have not set an outgoing call barring
option.
Your correspondent cannot reach you
• Be sure that your phone is switched on. ([ ] pressed
for more than one second.)
• Be sure that you are accessing the correct cellular
network.
• Be sure that you have not set an incoming call barring
option.
Your correspondent cannot hear you speaking
• Be sure that you have switched on the microphone.
• Be sure that you are holding the phone close enough
to your mouth. The microphone is located at the
bottom of the phone.
The phone starts beeping and “Battery low”
flashes on the display
• Your battery is insufficiently charged. Recharge the
battery.
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ). The number of bars indicates the signal
strength from strong ( ) to weak ( ).
• Try moving the phone slightly or moving closer to a
window if you are in a building.
No number is dialled when you re-call a
Phonebook entry
• Use the Contact list feature to ensure the number has
been stored correctly.
• Re-store the number, if necessary.
If the above guidelines do not help you to solve
the problem, take note of:
• The model and serial numbers of your phone
• Your warranty details
• A clear description of the problem
Then contact your local dealer or Samsung after-sales
service.
Health and safety information
Mobile
7
75
Health and safety information
Exposure to Radio Frequency (RF) Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
exposure limits for radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the
U.S. government. These FCC exposure limits are
derived from the recommendations of two expert
organizations, the National Counsel on Radiation
Protection and Measurement (NCRP) and the Institute
of Electrical and Electronics Engineers (IEEE). In both
cases, the recommendations were developed by
scientific and engineering experts drawn from
industry, government, and academia after extensive
reviews of the scientific literature related to the
biological effects of RF energy.
The exposure limit set by the FCC for wireless mobile
phones employs a unit of measurement known as the
Specific Absorption Rate (SAR). The SAR is a measure
of the rate of absorption of RF energy by the human
body expressed in units of watts per kilogram (W/kg).
The FCC requires wireless phones to comply with a
safety limit of 1.6 watts per kilogram (1.6 W/kg). The
FCC exposure limit incorporates a substantial margin
of safety to give additional protection to the public and
to account for any variations in measurements.
SAR tests are conducted using standard operating
positions accepted by the FCC with the phone
transmitting at its highest certified power level in all
tested frequency bands. Although the SAR is
determined at the highest certified power level, the
actual SAR level of the phone while operating can be
well below the maximum value. This is because the
phone is designed to operate at multiple power levels
so as to use only the power required to reach the
network. In general, the closer you are to a wireless
base station antenna, the lower the power output.
A120.book Page 9 Thursday, October 6, 2005 9:34 AM
76
Health and safety
A120.book Page 10 Thursday, October 6, 2005 9:34 AM
Before a new model phone is available for sale to the
public, it must be tested and certified to the FCC that
it does not exceed the exposure limit established by
the FCC. Tests for each model phone are performed in
positions and locations (e.g. at the ear and worn on
the body) as required by the FCC.
The highest SAR values for this model phone has
reported to the FCC are head xxxxW/Kg,
Body-worn: xxxxW/Kg.
For Body-worn operations, this model phone has been
tested and meets the FCC RF exposure guidelines when
used with a Samsung accessory designated for
this product or when used with an accessory that
contains no metal and that positions the handset
a minimum 1.8 cm from the body.
Non-compliance with the above restrictions may result
in violation of FCC RF exposure guidelines.
SAR information on this and other model phones can
be viewed on-line at www.fcc.gov/oet/fccid. This site
uses the phone FCC ID number, A3LSGHZX20.
Sometimes it may be necessary to remove then
battery pack to find the number. Once you have the
FCC ID number for a particular phone, follow the
instructions on the website and it should provide
values for typical or maximum SAR for a particular
phone. Additional product specific SAR information
can also be obtained at www.fcc.gov/cgb/sar.
Health and safety information
77
Consumer Information on Wireless Phones
The U.S. Food and Drug Administration (FDA) has
published a series of Questions and Answers for
consumers relating to radio frequency (RF) exposure
from wireless phones. The FDA publication includes
the following information:
What kinds of phones are the subject of this
update?
The term wireless phone refers here to hand-held
wireless phones with built-in antennas, often called
“cell,” “mobile,” or “PCS” phones. These types of
wireless phones can expose the user to measurable
radio frequency energy (RF) because of the short
distance between the phone and the user's head.
These RF exposures are limited by Federal
Communications Commission safety guidelines that
were developed with the advice of FDA and other
federal health and safety agencies. When the phone is
located at greater distances from the user, the
exposure to RF is drastically lower because a person's
RF exposure decreases rapidly with increasing
distance from the source. The so-called “cordless
phones,” which have a base unit connected to the
telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures
well within the FCC's compliance limits.
Do wireless phones pose a health hazard?
The available scientific evidence does not show that
any health problems are associated with using
wireless phones. There is no proof, however, that
wireless phones are absolutely safe. Wireless phones
emit low levels of radio frequency energy (RF) in the
microwave range while being used. They also emit
very low levels of RF when in the stand-by mode.
Whereas high levels of RF can produce health effects
(by heating tissue), exposure to low level RF that does
not produce heating effects causes no known adverse
health effects. Many studies of low level RF exposures
have not found any biological effects. Some studies
have suggested that some biological effects may
occur, but such findings have not been confirmed by
additional research. In some cases, other researchers
have had difficulty in reproducing those studies, or in
determining the reasons for inconsistent results.
A120.book Page 11 Thursday, October 6, 2005 9:34 AM
78
Health and safety
What is FDA's role concerning the safety of
wireless phones?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as wireless
phones before they can be sold, as it does with new
drugs or medical devices. However, the agency has
authority to take action if wireless phones are shown
to emit radio frequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could
require the manufacturers of wireless phones to notify
users of the health hazard and to repair, replace or
recall the phones so that the hazard no longer exists.
Although the existing scientific data do not justify FDA
regulatory actions, FDA has urged the wireless phone
industry to take a number of steps, including the
following:
• “Support needed research into possible biological
effects of RF of the type emitted by wireless
phones;
• “Design wireless phones in a way that minimizes
any RF exposure to the user that is not necessary
for device function; and
• “Cooperate in providing users of wireless phones
with the best possible information on possible
effects of wireless phone use on human health.
FDA belongs to an interagency working group of the
federal agencies that have responsibility for different
aspects of RF safety to ensure coordinated efforts at
the federal level. The following agencies belong to this
working group:
• “National Institute for Occupational Safety and
Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health Administration
• “National Telecommunications and Information
Administration
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
phones with the Federal Communications Commission
(FCC). All phones that are sold in the United States
must comply with FCC safety guidelines that limit RF
A120.book Page 12 Thursday, October 6, 2005 9:34 AM
Health and safety information
79
exposure. FCC relies on FDA and other health agencies
for safety questions about wireless phones.
FCC also regulates the base stations that the wireless
phone networks rely upon. While these base stations
operate at higher power than do the wireless phones
themselves, the RF exposures that people get from
these base stations are typically thousands of times
lower than those they can get from wireless phones.
Base stations are thus not the primary subject of the
safety questions discussed in this document.
What are the results of the research done
already?
The research done thus far has produced conflicting
results, and many studies have suffered from flaws in
their research methods. Animal experiments
investigating the effects of radio frequency energy
(RF) exposures characteristic of wireless phones have
yielded conflicting results that often cannot be
repeated in other laboratories. A few animal studies,
however, have suggested that low levels of RF could
accelerate the development of cancer in laboratory
animals. However, many of the studies that showed
increased tumor development used animals that had
been genetically engineered or treated with cancer-
causing chemicals so as to be pre-disposed to develop
cancer in absence of RF exposure. Other studies
exposed the animals to RF for up to 22 hours per day.
These conditions are not similar to the conditions
under which people use wireless phones, so we don't
know with certainty what the results of such studies
mean for human health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use
of wireless phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors of the brain
or salivary gland, leukemia, or other cancers. None of
the studies demonstrated the existence of any harmful
health effects from wireless phones RF exposures.
However, none of the studies can answer questions
about long-term exposures, since the average period
of phone use in these studies was around three years.
A120.book Page 13 Thursday, October 6, 2005 9:34 AM
80
Health and safety
What research is needed to decide whether RF
exposure from wireless phones poses a health
risk?
A combination of laboratory studies and
epidemiological studies of people actually using
wireless phones would provide some of the data that
are needed. Lifetime animal exposure studies could be
completed in a few years. However, very large
numbers of animals would be needed to provide
reliable proof of a cancer promoting effect if one
exists. Epidemiological studies can provide data that is
directly applicable to human populations, but ten or
more years' follow-up may be needed to provide
answers about some health effects, such as cancer.
This is because the interval between the time of
exposure to a cancer-causing agent and the time
tumors develop - if they do - may be many, many
years. The interpretation of epidemiological studies is
hampered by difficulties in measuring actual RF
exposure during day-to-day use of wireless phones.
Many factors affect this measurement, such as the
angle at which the phone is held, or which model of
phone is used.
What is FDA doing to find out more about the
possible health effects of wireless phone RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
effects of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization international Electromagnetic Fields
(EMF) Project since its inception in 1996. An influential
result of this work has been the development of a
detailed agenda of research needs that has driven the
establishment of new research programs around the
world. The Project has also helped develop a series of
public information documents on EMF issues.
FDA and Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative
Research and Development Agreement (CRADA) to do
research on wireless phone safety. FDA provides the
scientific oversight, obtaining input from experts in
government, industry, and academic organizations.
CTIA-funded research is conducted through contracts
A120.book Page 14 Thursday, October 6, 2005 9:34 AM
Health and safety information
81
to independent investigators. The initial research will
include both laboratory studies and studies of wireless
phone users. The CRADA will also include a broad
assessment of additional research needs in the
context of the latest research developments around
the world.
What steps can I take to reduce my exposure
to radio frequency energy from my wireless
phone?
If there is a risk from these products - and at this
point we do not know that there is - it is probably very
small. But if you are concerned about avoiding even
potential risks, you can take a few simple steps to
minimize your exposure to radio frequency energy
(RF). Since time is a key factor in how much exposure
a person receives, reducing the amount of time spent
using a wireless phone will reduce RF exposure.
• “If you must conduct extended conversations by
wireless phone every day, you could place more
distance between your body and the source of the
RF, since the exposure level drops off dramatically
with distance. For example, you could use a
headset and carry the wireless phone away from
your body or use a wireless phone connected to a
remote antenna.
Again, the scientific data do not demonstrate that
wireless phones are harmful. But if you are concerned
about the RF exposure from these products, you can
use measures like those described above to reduce
your RF exposure from wireless phone use.
What about children using wireless phones?
The scientific evidence does not show a danger to
users of wireless phones, including children and
teenagers. If you want to take steps to lower exposure
to radio frequency energy (RF), the measures
described above would apply to children and
teenagers using wireless phones. Reducing the time of
wireless phone use and increasing the distance
between the user and the RF source will reduce RF
exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at all. For
A120.book Page 15 Thursday, October 6, 2005 9:34 AM
82
Health and safety
example, the government in the United Kingdom
distributed leaflets containing such a recommendation
in December 2000. They noted that no evidence exists
that using a wireless phone causes brain tumors or
other ill effects. Their recommendation to limit
wireless phone use by children was strictly
precautionary; it was not based on scientific evidence
that any health hazard exists.
Do hands-free kits for wireless phones reduce
risks from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that hands-free kits reduce risks. Hands-free
kits can be used with wireless phones for convenience
and comfort. These systems reduce the absorption of
RF energy in the head because the phone, which is the
source of the RF emissions, will not be placed against
the head. On the other hand, if the phone is mounted
against the waist or other part of the body during use,
then that part of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are required to
meet safety requirements regardless of whether they
are used against the head or against the body. Either
configuration should result in compliance with the
safety limit.
Do wireless phone accessories that claim to
shield the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless phones, there is no reason to
believe that accessories that claim to shield the head
from those emissions reduce risks. Some products
that claim to shield the user from RF absorption use
special phone cases, while others involve nothing
more than a metallic accessory attached to the phone.
Studies have shown that these products generally do
not work as advertised. Unlike “hand-free” kits, these
so-called “shields” may interfere with proper operation
of the phone. The phone may be forced to boost its
power to compensate, leading to an increase in RF
absorption. In February 2002, the Federal trade
Commission (FTC) charged two companies that sold
devices that claimed to protect wireless phone users
from radiation with making false and unsubstantiated
A120.book Page 16 Thursday, October 6, 2005 9:34 AM
Health and safety information
83
claims. According to FTC, these defendants lacked a
reasonable basis to substantiate their claim.
What about wireless phone interference with
medical equipment?
Radio frequency energy (RF) from wireless phones can
interact with some electronic devices. For this reason,
FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted
cardiac pacemakers and defibrillators from wireless
telephones. This test method is now part of a standard
sponsored by the Association for the Advancement of
Medical instrumentation (AAMI). The final draft, a joint
effort by FDA, medical device manufacturers, and
many other groups, was completed in late 2000. This
standard will allow manufacturers to ensure that
cardiac pacemakers and defibrillators are safe from
wireless phone EMI. FDA has tested wireless phones
and helped develop a voluntary standard sponsored by
the Institute of Electrical and Electronic Engineers
(IEEE). This standard specifies test methods and
performance requirements for hearing aids and
wireless phones so that no interference occurs when a
person uses a compatible phone and a compatible
hearing aid at the same time. This standard was
approved by the IEEE in 2000.
FDA continues to monitor the use of wireless phones
for possible interactions with other medical devices.
Should harmful interference be found to occur, FDA
will conduct testing to assess the interference and
work to resolve the problem.
Additional information on the safety of RF exposures
from various sources can be obtained from the
following organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health Administration's
(OSHA):
http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
A120.book Page 17 Thursday, October 6, 2005 9:34 AM
84
Health and safety
• National institute for Occupational Safety and
Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-Ionizing
Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board (UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug
Administration
http://www.fda.gov/cellphones
Road Safety
Your wireless phone gives you the powerful ability to
communicate by voice, almost anywhere, anytime.
But an important responsibility accompanies the
benefits of wireless phones, one that every user must
uphold.
When driving a car, driving is your first responsibility.
When using your wireless phone behind the wheel of a
car, practice good common sense and remember the
following tips:
1. Get to know your wireless phone and its features,
such as speed dial and redial. If available, these
features help you to place your call without taking
your attention off the road.
2. When available, use a hands-free device. If
possible, add an additional layer of convenience
and safety to your wireless phone with one of the
many hands free accessories available today.
A120.book Page 18 Thursday, October 6, 2005 9:34 AM
Health and safety information
85
1. Position your wireless phone within easy reach. Be
able to access your wireless phone without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your
voice mail answer it for you.
2. Let the person you are speaking with know you are
driving; if necessary, suspend the call in heavy
traffic or hazardous weather conditions. Rain,
sleet, snow, ice and even heavy traffic can be
hazardous.
3. Do not take notes or look up phone numbers while
driving. Jotting down a “to do” list or flipping
through your address book takes attention away
from your primary responsibility, driving safely.
4. Dial sensibly and assess the traffic; if possible,
place calls when you are not moving or before
pulling into traffic. Try to plan calls when your car
will be stationary. If you need to make a call while
moving, dial only a few numbers, check the road
and your mirrors, then continue.
5. Do not engage in stressful or emotional
conversations that may be distracting. Make
people you are talking with aware you are driving
and suspend conversations that have the potential
to divert your attention from the road.
6. Use your wireless phone to call for help. Dial 9-1-1
or other local emergency number in the case of
fire, traffic accident or medical emergencies.
Remember, it is a free call on your wireless phone!
7. Use your wireless phone to help others in
emergencies. If you see an auto accident, crime in
progress or other serious emergency where lives
are in danger, call 9-1-1 or other local emergency
number, as you would want others to do for you.
8. Call roadside assistance or a special non-
emergency wireless assistance number when
necessary. If you see a broken-down vehicle
posing no serious hazard, a broken traffic signal, a
minor traffic accident where no one appears
injured, or a vehicle you know to be stolen, call
roadside assistance or other special non-
emergency number.
A120.book Page 19 Thursday, October 6, 2005 9:34 AM
86
Health and safety
“The wireless industry reminds you to use your
phone safely when driving.”
For more information, please call 1-888-901-SAFE, or
visit our web-site www.wow-com.com
Provided by the Cellular Telecommunications &
Internet Association
Operating Environment
Remember to follow any special regulations in force in
any area and always switch your phone off whenever it
is forbidden to use it, or when it may cause
interference or danger. When connecting the phone or
any accessory to another device, read its user's guide
for detailed safety instructions. Do not connect
incompatible products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation of
the equipment and for the safety of personnel, it is
recommended that the equipment should only be used
in the normal operating position (held to your ear with
the antenna pointing over your shoulder).
Using Your Phone Near Other Electronic
Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain
electronic equipment may not be shielded against the
RF signals from your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be maintained
between a wireless phone and a pacemaker to avoid
potential interference with the pacemaker.
These recommendations are consistent with the
independent research and recommendations of
Wireless Technology Research.
Persons with pacemakers:
• should always keep the phone more than 15 cm
(6 inches) from their pacemaker when the phone is
switched on.
• should not carry the phone in a breast pocket.
A120.book Page 20 Thursday, October 6, 2005 9:34 AM
Health and safety information
87
• should use the ear opposite the pacemaker to
minimize potential interference.
If you have any reason to suspect that interference is
taking place, switch your phone off immediately.
Hearing Aids
Some digital wireless phones may interfere with some
hearing aids. In the event of such interference, you
may wish to consult your hearing aid manufacturer to
discuss alternatives.
Other Medical Devices
If you use any other personal medical devices, consult
the manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
information. Switch your phone off in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to
external RF energy.
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in motor
vehicles. Check with the manufacturer or its
representative regarding your vehicle. You should also
consult the manufacturer of any equipment that has
been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where posted
notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause an
explosion or fire resulting in bodily injury or even
death.
Users are advised to switch the phone off while at a
refueling point (service station). Users are reminded of
the need to observe restrictions on the use of radio
equipment in fuel depots (fuel storage and distribution
A120.book Page 21 Thursday, October 6, 2005 9:34 AM
88
Health and safety
areas), chemical plants or where blasting operations
are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such
as propane or butane), areas where the air contains
chemicals or particles, such as grain, dust or metal
powders, and any other area where you would
normally be advised to turn off your vehicle engine.
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well as
user programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should
never rely solely on any wireless phone for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not be
possible on all wireless phone networks or when
certain network services and/or phone features are in
use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 911 or other official
emergency number). Emergency numbers vary by
location.
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular service
provider.
When making an emergency call, remember to give all
the necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut
off the call until given permission to do so.
A120.book Page 22 Thursday, October 6, 2005 9:34 AM
Health and safety information
23
Restricting Children's access to your Phone
Your phone is not a toy. Children should not be allowed
to play with it because they could hurt themselves and
others, damage the phone or make calls that increase
your phone bill.
FCC Notice and Cautions
FCC Notice
The phone may cause TV or radio interference if used
in close proximity to receiving equipment. The FCC
can require you to stop using the phone if such
interference cannot be eliminated.
Vehicles using liquefied petroleum gas (such as
propane or butane) must comply with the National Fire
Protection Standard (NFPA-58). For a copy of this
standard, contact the National Fire Protection
Association, One Battery march Park, Quincy, MA
02269, Attn: Publication Sales Division.
Cautions
Changes or modifications made in the radio phone, not
expressly approved by Samsung, will void the user’s
authority to operate the equipment.
Only use approved batteries, antennas and chargers.
The use of any unauthorized accessories may be
dangerous and void the phone warranty if said
accessories cause damage or a defect to the phone.
Although your phone is quite sturdy, it is a complex
piece of equipment and can be broken. Avoid
dropping, hitting, bending or sitting on it.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two
conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any
interference received, including interference that
may cause undesired operation.
A120.book Page 23 Thursday, October 6, 2005 9:34 AM
88
Health and safety
areas), chemical plants or where blasting operations
are in progress.
Areas with a potentially explosive atmosphere are
often but not always clearly marked. They include
below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such
as propane or butane), areas where the air contains
chemicals or particles, such as grain, dust or metal
powders, and any other area where you would
normally be advised to turn off your vehicle engine.
Emergency Calls
This phone, like any wireless phone, operates using
radio signals, wireless and landline networks as well as
user programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should
never rely solely on any wireless phone for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the phone
must be switched on and in a service area with
adequate signal strength. Emergency calls may not be
possible on all wireless phone networks or when
certain network services and/or phone features are in
use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your present
location (for example, 911 or other official
emergency number). Emergency numbers vary by
location.
If certain features are in use (call barring, for
example), you may first need to deactivate those
features before you can make an emergency call.
Consult this document and your local cellular service
provider.
When making an emergency call, remember to give all
the necessary information as accurately as possible.
Remember that your phone may be the only means of
communication at the scene of an accident; do not cut
off the call until given permission to do so.
A120.book Page 22 Thursday, October 6, 2005 9:34 AM
Health and safety information
89
Understanding How Your Phone Operates
Your phone is basically a radio transmitter and
receiver. When it's turned on, it receives and transmits
radio frequency (RF) signals. When you use your
phone, the system handling your call controls the
power level. This power can range from 0.006 watts to
0.2 watts in digital mode.
Maintaining Your Phone's Peak Performance
For the best care of your phone, only authorized
personnel should service your phone and accessories.
Faulty service may void the warranty.
There are several simple guidelines to operating your
phone properly and maintaining safe, satisfactory
service.
• Hold the phone with the antenna raised, fully-
extended and over your shoulder.
• Try not to hold, bend or twist the phone's antenna.
• Don't use the phone if the antenna is damaged.
• Speak directly into the phone's receiver.
• Avoid exposing your phone and accessories to rain
or liquid spills. If your phone does get wet,
immediately turn the power off and remove the
battery. If it is inoperable, call Customer Care for
service.
Availability of Various Features/Ring
Tones
Many services and features are network dependent
and may require additional subscription and/or usage
charges. Not all features are available for purchase or
use in all areas. Downloadable Ring Tones may be
available at an additional cost. Other conditions and
restrictions may apply. See your service provider for
additional information.
Battery Standby and Talk Time
Standby and talk times will vary depending on phone
usage patterns and conditions. Battery power
consumption depends on factors such as network
configuration, signal strength, operating temperature,
features selected, frequency of calls, and voice, data,
and other application usage patterns.
A120.book Page 25 Thursday, October 6, 2005 9:34 AM
90
Health and safety
Battery Precautions
• Never use any charger or battery that is damaged
in any way.
• Use the battery only for its intended purpose.
• If you use the phone near the network's base
station, it uses less power; talk and standby time
are greatly affected by the signal strength on the
cellular network and the parameters set by the
network operator.
• Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out.
When the operation time (talk time and standby
time) is noticeably shorter than normal, it is time
to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries and
recharge your battery only with Samsung-
approved chargers. When a charger is not in use,
disconnect it from the power source. Do not leave
the battery connected to a charger for more than a
week, since overcharging may shorten its life.
• Extreme temperatures will affect the charging
capacity of your battery: it may require cooling or
warming first.
• Do not leave the battery in hot or cold places, such
as in a car in summer or winter conditions, as you
will reduce the capacity and lifetime of the battery.
Always try to keep the battery at room
temperature. A phone with a hot or cold battery
may temporarily not work, even when the battery
is fully charged. Li-ion batteries are particularly
affected by temperatures below 0 °C (32 °F).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin,
clip or pen) causes a direct connection between the
+ and - terminals of the battery (metal strips on
the battery), for example when you carry a spare
battery in a pocket or bag. Short-circuiting the
terminals may damage the battery or the object
causing the short-circuiting.
A120.book Page 26 Thursday, October 6, 2005 9:34 AM
Health and safety information
91
• Dispose of used batteries in accordance with local
regulations. In some areas, the disposal of
batteries in household or business trash may be
prohibited. For safe disposal options for Li-Ion
batteries, contact your nearest Samsung
authorized service center. Always recycle. Do not
dispose of batteries in a fire.
Care and Maintenance
Your phone is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the phone and all its parts and accessories
out of the reach of small children.
• Keep the phone dry. Precipitation, humidity and
liquids contain minerals that will corrode electronic
circuits.
• Do not use the phone with a wet hand. Doing so
may cause an electric shock to you or damage to
the phone.
• Do not use or store the phone in dusty, dirty areas,
as its moving parts may be damaged.
• Do not store the phone in hot areas. High
temperatures can shorten the life of electronic
devices, damage batteries, and warp or melt
certain plastics.
• Do not store the phone in cold areas. When the
phone warms up to its normal operating
temperature, moisture can form inside the phone,
which may damage the phone's electronic circuit
boards.
• Do not drop, knock or shake the phone. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the phone. Wipe it with
a soft cloth slightly dampened in a mild soap-and-
water solution.
A120.book Page 27 Thursday, October 6, 2005 9:34 AM
92
Health and safety
• Do not paint the phone. Paint can clog the device's
moving parts and prevent proper operation.
• Do not put the phone in or on heating devices,
such as a microwave oven, a stove or a radiator.
The phone may explode when overheated.
• When the phone or battery gets wet, the label
indicating water damage inside the phone changes
color. In this case, phone repairs are no longer
guaranteed by the manufacturer's warranty, even
if the warranty for your phone has not expired.
• If your phone has a flash or light, do not use it too
close to the eyes of people or animals. This may
cause damage to their eyes.
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
A120.book Page 28 Thursday, October 6, 2005 9:34 AM
