Samsung Electronics Co SH100B Digital Camera User Manual 1 of 3
Samsung Electronics Co Ltd Digital Camera 1 of 3
User manual 1 of 3
This user manual includes detailed usage
instructions for your camera. Please read
this manual thoroughly.
Ä Click a topic
Common questions
Quick reference
Contents
Basic functions
Extended functions
Shooting options
Playback/Editing
Wireless network
Settings
Appendixes
Index
User Manual
SH100
1
Health and safety information
Always comply with the following precautions and usage tips to avoid dangerous situations and ensure peak performance of your camera.
Warning—situations that could cause injury to yourself or
others
Caution—situations that could cause damage to your
camera or other equipment
Note—notes, usage tips, or additional information
Safety warnings
Do not use your camera near flammable or explosive
gases and liquids
Do not use your camera near fuels, combustibles, or flammable
chemicals. Do not store or carry flammable liquids, gases, or
explosive materials in the same compartment as the camera or its
accessories.
Keep your camera away from small children and pets
Keep your camera and all accessories out of the reach of small
children and animals. Small parts may cause choking or serious
injury if swallowed. Moving parts and accessories may present
physical dangers as well.
Prevent damage to subjects’ eyesight
Do not use the flash in close proximity (closer than 1 m/3 ft) to
people or animals. Using the flash too close to your subject’s
eyes can cause temporary or permanent damage.
Handle and dispose of batteries and chargers with care
Use only Samsung-approved batteries and chargers. t
Incompatible batteries and chargers can cause serious injuries
or damage to your camera.
Never dispose of batteries in a fire. Follow all local regulations t
when disposing of used batteries.
Never place batteries or cameras on or in heating devices, t
such as microwave ovens, stoves, or radiators. Batteries may
explode when overheated.
Do not use a damaged power supply cord, plug, or loose t
outlet when charging batteries. This may cause a fire or electric
shock.
Avoid interference with pacemakers
Maintain a minimum of 15 cm (6 inches) between cameras and
pacemakers to avoid potential interference, as recommended by
manufacturers and the independent research group, Wireless
Technology Research. If you have any reason to suspect that your
camera is interfering with a pacemaker or other medical device,
turn off the camera immediately and contact the manufacturer of
the pacemaker or medical device for guidance.
2
Health and safety information
Do not swing your camera by the strap. This may cause injury t
to yourself or others.
Do not paint your camera, as paint can clog moving parts and t
prevent proper operation.
Paint or metal on the outside of the camera may cause t
allergies, itchy skin, eczema, or swelling for people with
sensitive skin. If you have experience any of these symptoms,
stop using the camera immediately and consult a doctor.
Protect batteries, chargers, and memory cards from
damage
Avoid exposing batteries or memory cards to very cold or very t
hot temperatures (below 0º C/32º F or above 40º C/104º F).
Extreme temperatures can reduce the charging capacity of your
batteries and can cause memory cards to malfunction.
Prevent batteries from making contact with metal objects, as t
this can create a connection between the + and – terminals
of your battery and lead to temporary or permanent battery
damage. Also, this may cause a fire or electric shock.
Prevent memory cards from making contact with liquids, dirt, or t
foreign substances. If dirty, wipe the memory card clean with a
soft cloth before inserting in your camera.
Do not allow liquids, dirt, or foreign substances to come in t
contact with the memory card slot. Doing so may cause the
camera to malfunction.
Insert a memory card in the correct direction. Inserting a t
memory card in the wrong direction may damage your camera
and memory card.
Safety precautions
Handle and store your camera carefully and sensibly
Do not allow your camera to get wet—liquids can cause serious t
damage. Do not handle your camera with wet hands. Water
damage to your camera can void your manufacturer’s warranty.
Do not expose the camera to direct sunlight or high t
temperatures for an extended period of time. Prolonged
exposure to sunlight or extreme temperatures can cause
permanent damage to your camera’s internal components.
Avoid using or storing your camera in dusty, dirty, humid, or t
poorly-ventilated areas to prevent damage to moving parts and
internal components.
Remove the batteries from your camera when storing it for an t
extended period of time. Installed batteries may leak or corrode
over time and cause serious damage to your camera.
Protect your camera from sand and dirt when using it on t
beaches or in other similar areas.
Protect your camera and the display from impact, rough t
handling, and excessive vibration to avoid serious damage.
Exercise caution when connecting cables or adapters and t
installing batteries and memory cards. Forcing the connectors,
improperly connecting cables, or improperly installing batteries
and memory cards can damage ports, connectors, and
accessories.
Do not insert foreign objects into any of your camera’s t
compartments, slots, or access points. Damage due to
improper use may not be covered by your warranty.
3
Health and safety information
Use only Samsung-approved accessories
Using incompatible accessories may damage your camera,
cause injury, or void your warranty.
Protect your camera’s lens
Do not expose the lens to direct sunlight, as this may discolor t
the image sensor or cause it to malfunction.
Protect your lens from fingerprints and scratches. Clean your t
lens with a soft, clean, debris-free lens cloth.
Follow all safety warnings and regulations
Comply with any regulations that restrict the use of a camera in a
certain area.
Turn off the camera near medical equipment
Your camera can interfere with medical equipment in hospitals or
health care facilities. Follow all regulations, posted warnings, and
directions from medical personnel.
Turn off the camera when in an aircraft
Your camera can cause interference with aircraft equipment.
Follow all airline regulations and turn off your camera when
directed by airline personnel.
Turn off the camera when inserting or removing the memory t
card.
Do not bend, drop, or subject memory cards to heavy impact t
or pressure.
Do not use memory cards that have been formatted by other t
cameras or by a computer. Reformat the memory card with
your camera.
Never use a damaged charger, battery, or memory card.t
When carrying a memory card, use a case to protect the card t
from electrostatic.
Transfer important data to other media, such as a hard disk or t
CD/DVD.
When using the camera for an extended period, the memory t
card may become warm; this is normal and not a malfunction.
When the lifespan of a memory card has expired, you cannot t
store any more photos on the card. Use a new memory card.
Do not remove the memory card or turn off your camera while t
the lamp is blinking, as this may damage your data.
4
Exercise caution when using the camera in humid
environments
When transferring the camera from a cold environment to a warm
and humid one, condensation can form on the delicate electronic
circuitry and memory card. In this situation, wait for at least 1 hour
until all moisture has evaporated before using the camera.
Check that the camera is operating properly before use
The manufacturer takes no responsibility for any loss of files or
damage that may result from camera malfunction or improper
use.
Use your camera in the normal position
Avoid contact with your camera’s internal antenna.
Data transferred via WLAN could be leaked, so avoid t
transferring sensitive data in public areas or on open
networks.
The camera manufacturer is not liable for any data transfers t
that infringe on copyrights, trademarks, intellectual property
laws, or public decency ordnances.
Avoid interference with other electronic devices
Your camera emits radio frequency (RF) signals that may interfere
with unshielded or improperly shielded electronic equipment,
such as pacemakers, hearing aids, medical devices, and
other electronic devices in homes or vehicles. Consult the
manufacturers of your electronic devices to solve any interference
problems you experience.
Important usage information
Allow only qualified personnel to service your camera
Do not allow unqualified personnel to service the camera or
attempt to service the camera yourself. Any damage that results
from unqualified service is not covered by your warranty.
Ensure maximum battery and charger life
Overcharging batteries may shorten battery life. After charging is t
finished, disconnect the cable from your camera.
Over time, unused batteries will discharge and must be t
recharged before use.
Disconnect chargers from power sources when not in use.t
Use batteries only for their intended purpose.t
Health and safety information
5
Copyright information
Microsoft Windows and the Windows logo are t
registered trademarks of the Microsoft Corporation.
Mac is a registered trademark of the Apple Corporation.t
Wi-Fit ®, the Wi-Fi CERTIFIED logo, and the Wi-Fi logo are
registered trademarks of the Wi-Fi Alliance.
Camera specifications or contents of this manual may t
be changed without prior notice due to upgrade of
camera functions.
We recommend using your camera within a country t
where you purchase it.
For Open Source License information, refer to the t
“OpenSourceInfo.pdf” in the provided CD-ROM.
Organization of the user manual
Basic functions 13
Learn about your camera’s layout, icons, and basic
functions for shooting.
Extended functions 30
Learn how to take a photo by selecting a mode and
how to record a video or voice memo.
Shooting options 40
Learn about the options you can set in Shooting mode.
Playback/Editing 64
Learn how to play back photos, videos, or voice
memos and edit photos or videos. Also, learn how to
connect your camera to your computer, photo printer
or TV.
Wireless network 91
Learn to use several functions that use wireless local
area networks (WLANs) feature.
Settings 106
Refer to options to configure your camera’s settings.
Appendixes 112
Refer to error messages, specifications, and
maintenance tips.
6
Indications used in this manual
Shooting mode Indication
Smart Auto
S
Auto
a
Program
p
Scene
s
Smart Scene Detection
D
Movie
v
Shooting mode icons
These icons indicate that a function is available in the
corresponding modes. The s mode may not support
functions for all scenes.
For example:
Available in Program
and Movie modes.
Icons used in this manual
Icon Function
Additional information
Safety warnings and precautions
[] Camera buttons; For example: [Shutter] represents the
shutter button
() Page number of related information
The order of options or menus you must select to perform
a step; for example: Select
>
(represents Select
>
, and then )
*Annotation
Abbreviations used in this manual
Abbreviation Definition
ACB Auto Contrast Balance
AEB Auto Exposure Bracket
AF Auto Focus
AP Access Point
DIS Digital Image Stabilization
DPOF Digital Print Order Format
EV Exposure Value
WB White Balance
7
Pressing the shutter
Half-press [t Shutter]: press the shutter halfway down
Press [t Shutter]: press the shutter all the way down
Half-press [Shutter] Press [Shutter]
Subject, background, and composition
Subjectt : the main object of a scene, such as a person, animal,
or still life
Backgroundt : the objects around the subject
Compositiont : the combination of a subject and background
Subject
Background
Composition
Expressions used in this manual
Exposure (Brightness)
The amount of light that enters your camera determines the
exposure. You can alter the exposure with shutter speed,
aperture value, and ISO speed. By altering the exposure, your
photos will be darker or lighter.
Normal exposure Overexposure (too bright)
8
Common questions
You can get answers to common questions. Solve problems easily by setting shooting options.
The subject's eyes
appear red.
This is caused by a reflection from the camera flash.
Set the flash option to t Red-eye or Red-eye Fix. (p. 45)
If the photo has already been taken, select t Red-eye Fix in the edit menu. (p. 80)
Photos have dust spots. Dust particles floating in the air may be captured in photos when you use the flash.
Turn off the flash or avoid taking photos in a dusty place.t
Set t
ISO
speed options. (p. 46)
Photos are blurred. This may be caused by taking photos in low light conditions or holding the camera incorrectly.
Press [t Shutter] halfway down to make sure the subject is focused. (p. 28)
Photos are blurred when
shooting at night.
As the camera tries to let in more light, the shutter speed slows.
This can make it difficult to steady the camera and may result in camera shake.
Select t Night in
s
mode. (p. 34)
Turn on the flash. (p. t 45)
Set t
ISO
speed options. (p. 46)
Use a tripod to prevent your camera from shaking.t
Subjects come out
too dark because of
backlighting.
When the light source is behind the subject or when there is a high contrast between the light and dark
areas, the subject may come out too dark.
Avoid shooting in front of the sun.t
Select t Backlight in
s
mode. (p. 32)
Set the flash option to t Fill in. (p. 45)
Adjust the exposure. (p. t 54)
Set the Auto Contrast Balance (t ACB) option. (p. 55)
Set the metering option to t Spot if a bright subject is in the center of the frame. (p. 56)
9
Quick reference
Taking photos of people
s
t mode > Beauty Shot, Portrait, Children
f
32
Red-eyet , Red-eye Fix
(to prevent or correct red-eye)
f
45
Face Detectiont
f
50
Taking photos at night or in the dark
s
t mode > Night, Dawn, Fireworks
f
32
Flash options t
f
45
ISO speed (to adjust the sensitivity to light) t
f
46
Taking action photos
Continuoust , Motion Capture
f
59
Taking photos of text, insects, or
flowers
s
t mode > Close Up, Text
f
32
Macrot , Auto Macro (to take close-up photos)
f
47
White Balancet (to change the color tone)
f
57
Adjusting the exposure (brightness)
ISO speed (to adjust the sensitivity to light) t
f
46
EVt (to adjust exposure)
f
54
ACBt (to compensate for subjects against bright
backgrounds)
f
55
Meteringt
f
56
AEBt (to take 3 photos of the same scene with
different exposures)
f
59
Applying a different effect
Photo styles (to apply tones) t
f
60
Smart Filtert effects
f
61
Image adjustment (to adjust saturation, sharpness, t
or contrast)
f
62
Reducing camera shake
Digital Image Stabilization (DIS) t
f
27
Viewing files by category in t
Smart Album
f
69
Deleting all files on the t
memory card
f
71
Viewing files as a slide show t
f
72
Viewing files on a TV t
f
82
Connecting your camera to a t
computer
f
83
Adjusting sound and volume t
f
108
Adjusting the brightness of t
the display
f
109
Changing the display t
language
f
109
Setting the date and time t
f
109
Formatting the memory card t
f
109
Troubleshooting t
f
119
10
Contents
Extended functions
........................................................ 30
Shooting modes ................................................................ 31
Using the Smart Auto mode ................................................. 31
Using the Scene mode ........................................................ 32
Using the Beauty Shot mode ................................................ 33
Using the frame guide .......................................................... 34
Adjusting the exposure in the Night mode .............................. 34
Using the Program mode ..................................................... 35
Recording a video ............................................................... 36
Using the Smart Scene Detection mode ................................ 37
Recording voice memos ................................................... 39
Recording a voice memo ..................................................... 39
Adding a voice memo to a photo .......................................... 39
Shooting options
............................................................ 40
Selecting a resolution and quality ...................................... 41
Selecting a resolution ........................................................... 41
Selecting image quality ........................................................ 42
Using the timer .................................................................. 43
Basic functions
............................................................... 13
Unpacking ......................................................................... 14
Camera layout ................................................................... 15
Inserting the battery and memory card .............................. 17
Charging the battery and turning your camera on ............. 18
Charging the battery ............................................................ 18
Turning on your camera ........................................................ 18
Performing the initial setup ................................................ 19
Learning icons ................................................................... 20
Using the touch screen ..................................................... 21
Selecting a shooting mode ................................................ 22
Selecting a shooting mode using motion recognition .............. 23
Setting the touch screen and sound ................................. 24
Setting the display type for the touch screen .......................... 24
Setting the sound ................................................................ 24
Taking photos .................................................................... 25
Zooming ............................................................................. 26
Reducing camera shake (DIS) .............................................. 27
Tips for getting a clearer photo .......................................... 28
11
Contents
Shooting in the dark .......................................................... 45
Preventing red-eye .............................................................. 45
Using the flash .................................................................... 45
Adjusting the ISO speed ...................................................... 46
Changing the camera’s focus ............................................ 47
Using macro ....................................................................... 47
Using auto focus ................................................................. 47
Using smart touch focus ...................................................... 48
Using one touch shooting .................................................... 49
Adjusting the focus area ....................................................... 49
Using face detection ......................................................... 50
Detecting faces ................................................................... 50
Taking a self portrait shot ...................................................... 51
Taking a smile shot .............................................................. 51
Detecting eye blinking .......................................................... 52
Using smart face recognition ................................................ 52
Registering faces as your favorites (My Star) .......................... 53
Adjusting brightness and color .......................................... 54
Adjusting the exposure manually (EV) .................................... 54
Compensating for backlighting (ACB) .................................... 55
Changing the metering option ............................................... 56
Selecting a light source (White balance) ................................. 57
Using burst modes ............................................................ 59
Improving your photos ...................................................... 60
Applying photo styles ........................................................... 60
Applying smart filter effects ................................................... 61
Adjusting your photos .......................................................... 62
Playback/Editing
............................................................. 64
Playing back ...................................................................... 65
Starting Playback mode ....................................................... 65
Playing a video .................................................................... 73
Playing a voice memo .......................................................... 74
Editing a photo .................................................................. 76
Rotating a photo .................................................................. 76
Resizing photos .................................................................. 76
Using Smart crop ................................................................ 77
Applying photo styles ........................................................... 77
Applying smart filter effects ................................................... 78
Applying a special effect ...................................................... 79
Adjusting photo ................................................................... 80
Creating a print order (DPOF) ................................................ 80
Viewing files on a TV ......................................................... 82
12
Sending photos via email ................................................ 100
Viewing photos or videos on the allshare devices ........... 101
Viewing photos or videos on a TV screen ............................ 101
Viewing photos or videos on another device (renderer) ......... 102
Sending or receiving photos or videos with a camera ..... 104
Sending photos or videos to another camera ....................... 104
Receiving photos or videos from another camera ................. 104
Settings
......................................................................... 106
Settings menu ................................................................. 107
Accessing the settings menu .............................................. 107
Sound settings .................................................................. 108
Display settings ................................................................. 108
Camera settings ................................................................ 109
Appendixes
................................................................... 112
Error messages ............................................................... 113
Camera maintenance ...................................................... 114
Cleaning your camera ........................................................ 114
About memory cards ......................................................... 115
About the battery ............................................................... 116
Before contacting a service center .................................. 119
Camera specifications ..................................................... 122
FCC notice ...................................................................... 126
Index ............................................................................... 130
Transferring files to your computer (for Windows) .............. 83
Transferring files using Intelli-studio ........................................ 84
Transferring files by connecting the camera as a removable
disk .................................................................................... 86
Disconnecting the camera (for Windows XP) .......................... 87
Transferring files to your computer (for Mac) ...................... 88
Printing photos with a photo printer (PictBridge) ............... 89
Wireless network
............................................................ 91
Connecting to a WLAN and configuring network settings . 92
Connecting to a WLAN automatically .................................... 92
Setting network options ....................................................... 93
Setting IP manually .............................................................. 93
Network connection tips ...................................................... 94
Storing your information ....................................................... 95
Storing email addresses ....................................................... 95
Setting the file size to share .................................................. 96
Setting a password ............................................................. 96
Changing the password ....................................................... 96
Checking information ........................................................... 97
Entering text ........................................................................ 97
Using photo or video sharing websites .............................. 98
Accessing a website ............................................................ 98
Uploading photos or videos .................................................. 99
Contents
Unpacking
………………………………… 14
Camera layout
……………………………… 15
Inserting the battery and memory card
… 17
Charging the battery and turning your
camera on
…………………………………… 18
Charging the battery
………………………… 18
Turning on your camera
……………………… 18
Performing the initial setup
……………… 19
Learning icons
……………………………… 20
Using the touch screen
…………………… 21
Selecting a shooting mode
……………… 22
Selecting a shooting mode using motion
recognition
…………………………………… 23
Setting the touch screen and sound
…… 24
Setting the display type for the touch screen
24
Setting the sound
…………………………… 24
Taking photos
……………………………… 25
Zooming
……………………………………… 26
Reducing camera shake (DIS)
……………… 27
Tips for getting a clearer photo
…………… 28
Basic functions
Learn about your camera’s layout, icons, and basic functions for shooting.
Basic functions
14
Unpacking
Check your product box for the following items.
The illustrations may differ from your actual items.
Camera AC adapter/
USB cable
Rechargeable battery
Strap Touch pen User Manual CD-ROM
Quick Start Manual
Optional accessories
Camera case A/V cable
Memory card
(microSDTM)
Battery charger
Basic functions
15
Camera layout
Before you start, familiarize yourself with your camera's parts and their functions.
Battery chamber cover
Insert a memory card and battery
Tripod mount
Flash
Lens
Zoom button
Zoom in or outt
Zoom in on part of a photo or view t
files as thumbnails
AF lamp/timer lamp
Internal antenna*
* Avoid contact with the
internal antenna while using
the wireless network.
Basic functions
16
Camera layout
USB and A/V port
Accepts USB cable or A/V cable
Playback button
Touch screen
Speaker
Shutter button
POWER button
Home button
12
Microphone
Basic functions
17
Inserting the battery and memory card
Learn to insert the battery and an optional memory card into the camera.
Removing the battery and memory card
Push gently until the card
disengages from the
camera and then pull it out
of the slot.
Push the lock up to release
the battery.
The internal memory can be used as a temporary storage device when the
memory card is not inserted.
Memory card
Battery
Battery lock
Insert a memory card with
the gold-colored contacts
facing up.
Insert the battery with the
Samsung logo facing down.
Basic functions
18
Charging the battery and turning your camera on
Turning on your camera
Press [POWER] to turn your camera on or off.
The initial setup screen appears when you turn on the camera t
for the first time. (p. 19)
Turning on your camera in Playback mode
Press [Playback]. The camera turns on and accesses Playback
mode immediately.
Charging the battery
Before using the camera for the first time, you must charge the
battery. Attach the USB cable to the AC adapter, and then plug
the end of cable with the indicator light into your camera.
Indicator light
Redt : Charging
Greent : Fully charged
Basic functions
19
Performing the initial setup
When the initial setup screen appears, follow the steps below to configure the camera's basic settings.
Set the date and time, and select
6
.
Date/Time Set
Select
7
Touch Calibration.
Tap the target on the screen with your touch pen.
8
Touch Calibration
Tap directly in the center of the target for optimal performance.
Select
9
to switch to Shooting mode.
Select
1
Language.
Select a language.
2
Select
3
Time Zone.
Select a time zone and select
4
.
To set the daylight-saving time, select t .
Time Zone
London
Select
5
Date/Time Set.
Basic functions
20
Icon Description
l
t : Motion recognition
N
t : Network menus
M
t : Shooting options and
settings menu
f
Image setting options
t : Exposure value
t : White balance
t : ISO speed
t : Face tone
t : Face retouch
t : Focus area option
t : Face detection option
t : Photo resolution
t : Video resolution
t : Photo quality
t : Frame rate
t : Exposure with ACB
t : Metering option
t : Burst type
t : Photo styles
t : Smart filter effect
t : Image adjustment (sharpness,
contrast, saturation)
t : Long time shutter
t : Digital Image Stabilization (DIS)
t : Audio recording
<>
t : Another row of options
Learning icons
The icons displayed will change according to the mode you select or the options you set.
1
Status icons
Icon Description
p
Shooting mode
Aperture and shutter speed
Photo resolution
Video resolution
Metering
Digital Image Stabilization (DIS)
Frame rate
Exposure value
ISO speed
White balance
Face detection
Burst mode
Image adjustment (sharpness,
contrast, saturation)
Photo styles
Icon Description
Smart filter effect
Available number of photos
Available recording time
Internal memory
Memory card inserted
t : Fully charged
t : Partially charged
t : Charging needed
Zoom ratio
Voice memo
Auto focus frame
Camera shake
Option set 1 (of 3)
Current date and time
Grid lines
2
Option icons (touch)
Icon Description
Flash option
Auto focus option
Timer option
Display type
Touch screen lock
1
2
Basic functions
21
Using the touch screen
Learn basic actions to use the touch screen. Use the supplied touch pen to touch or drag on the screen.
Touching
Touch an icon to select a menu or option.
Dragging
Drag left or right to scroll horizontally.
-2 -1 0 +2-2 -
1
0
0
+
2+1
EV
Do not use other sharp objects, such as pens or pencils, to touch the screen.
Doing so may damage the screen.
When you touch or drag on the screen, discolorations may occur. It t
is not a malfunction but a characteristic of the touch screen. Touch or
drag lightly to reduce these effects.
The touch screen may not recognize your touches correctly when:t
you touch multiple items at the same time -
you use the camera in high humidity environments -
you use the camera with an LCD protection film or another LCD -
accessory
If you touch the screen with your finger, the screen may not recognize t
your input.
Depending on the viewing angle, the screen may appear darker. t
Adjust the brightness or angle.
Basic functions
22
Selecting a shooting mode
Learn how to select a shooting mode. Your camera provides you with various modes for shooting.
Mode Description
S
Smart Auto: Take a photo by letting the camera select
a scene mode as it detects. (p. 31)
a
Auto: Take a photo quickly and easily with minimal
settings. (p. 25)
p
Program: Take a photo by setting options. (p. 35)
s
Scene: Take a photo with options preset for a specific
scene. (p. 32)
D
Smart Scene Detection: Record a video by letting
the camera select a scene mode as it detects. (p. 37)
v
Movie: Record a video. (p. 36)
Select the mode icon.
1
Select a mode.
2
Basic functions
23
Selecting a shooting mode
Selecting a shooting mode using motion
recognition
Your camera features a built-in motion sensor that allows you to
quickly switch the shooting mode by tilting the camera.
In Shooting mode, tilt the camera while touching and
holding .
Motion recognition may not work well if you hold the camera parallel to the
ground, as shown below.
Basic functions
24
Setting the touch screen and sound
Learn how to change the basic settings for the touch screen and sound according to your preferences.
Option Description
Hide: Hide icons on the screen if you perform no
operations for 3 seconds (touch the screen to display
icons again).
Guide Line: Display grid lines. The grid lines are
helpful for getting the photo aligned with a surface,
such as the horizon or the edges of buildings. This
option is available only in Shooting mode.
Setting the sound
Set whether your camera emits a specified sound when you
operate your camera.
In Shooting or Playback mode, select
1
M
.
Select
2
Beep Sound.
Select an option.
3
Option Description
Off The camera does not emit any sounds.
On The camera emits sounds.
Select
4
to return to the previous mode.
Setting the display type for the touch screen
In Shooting mode, select
1
.
(In Playback mode, select .)
Select an option.
2
Full
Option Description
Touch Lock: The touch screen is locked during
shooting. (Tap and hold until reaches to
unlock the touch screen).
Full: In Shooting mode, always display icons on
the screen. In Playback mode, display icons and
information.
Basic: In Playback mode, always display icons on
the screen.
Basic functions
25
Taking photos
Learn basic actions to take photos easily and quickly in Auto mode.
Make sure that the camera is in
1
a
mode (Auto),
the camera’s default shooting mode.
If not, select the mode icon t
a
.
Align your subject in the frame.
2
Half-press [
3
Shutter] to focus.
A green frame means the subject in focus.t
A red frame means the subjects is out of focus. t
Press [
4
Shutter] to take a photo.
See page 28 for tips to get clearer photos.
Basic functions
26
Taking photos
Zooming
You can shoot close-up photos by adjusting the zoom. Your
camera has a 3X optical zoom and 3X digital zoom. By using
both, you can zoom in up to 9 times.
Rotate [Zoom] right to zoom in on your subject. Rotate [Zoom]
left to zoom out.
Zoom ratio
Zoom in
Zoom out
The zoom ratio available for videos differs.
Digital zoom
If the zoom indicator is in the digital range, your camera is using
the digital zoom. The picture quality may deteriorate when you
use the digital zoom.
Optical range
Zoom indicator
Digital range
The digital zoom is not available when using t
S
,
s
(in some
scenes),
D
, and
v
modes and when used with Face Detection,
and Smart Filter.
It may take longer to save a photo when using the digital zoom.t
Basic functions
27
Taking photos
DIS may not function properly when:t
you move your camera to follow a moving subject -
you use digital zoom -
there is too much camera shake -
the shutter speed is slow (e.g., when you select - Night in
s
mode)
the battery is low -
you take a close-up shot -
In some scene modes, the DIS function is unavailable.t
If the camera is impacted, the display will be blurry. In this case, turn t
off the camera and turn it on again to use the DIS function correctly.
Reducing camera shake (DIS)
Reduce camera shake digitally in Shooting mode.
Before correction After correction
In Shooting mode, select
1
f
>
.
Select an option.
2
Option Description
Off: Deactivate the DIS function.
On: Activate the DIS function.
ps
Basic functions
28
Holding your camera correctly
Make sure nothing is
blocking the lens.
Half-pressing the shutter button
Half-press [Shutter] and adjust the
focus. Focus and exposure will be
adjusted automatically.
The aperture value and shutter
speed are automatically set.
Focus frame
Press [t Shutter] to take the
photo if displayed in green.
Change the frame and t
half-press [Shutter] again if
displayed in red.
Reducing camera shake
Set the Digital Image Stabilization option to
reduce camera shake. (p. 27)
When
h
is displayed
Camera shake
When shooting in the dark, avoid setting the flash option to Slow
Sync or Off. The aperture remains open longer and it may be harder
to hold the camera still.
Use a tripod or set the flash option to t Fill in. (p. 45)
Set ISO speed options. (p. t 46)
Tips for getting a clearer photo
Basic functions
29
Preventing your subject from being out of focus
It may be difficult to get your subject in focus when:
there is little contrast between the subject and background -
(When your subject is wearing a color of clothing that is similar to the
background)
the light source behind the subject is too bright
-
the subject is shiny -
the subject includes horizontal patterns, such as blinds -
the subject is not positioned in the center of the frame -
Use the focus lock
Half-press [Shutter] to focus. When the subject is in focus,
you can reposition the frame to change the composition.
When you are ready, press [Shutter] to take your photo.
When you take photos in low lightt
Turn on the flash.
(p. 45)
When subjects are moving fastt
Use the continuous
or motion capture
function. (p. 59)
Shooting modes
………………………………………… 31
Using the Smart Auto mode
…………………………… 31
Using the Scene mode
………………………………… 32
Using the Beauty Shot mode
…………………………… 33
Using the frame guide
………………………………… 34
Adjusting the exposure in the Night mode
……………… 34
Using the Program mode
……………………………… 35
Recording a video
……………………………………… 36
Using the Smart Scene Detection mode
……………… 37
Recording voice memos
……………………………… 39
Recording a voice memo
……………………………… 39
Adding a voice memo to a photo
……………………… 39
Extended functions
Learn how to take a photo by selecting a mode and how to
record a video or voice memo.
Extended functions
31
Shooting modes
Take photos or record videos by selecting the best shooting mode for the conditions.
Icon Description
Appears when taking portraits at night.
Appears when taking photos of landscapes with
backlighting.
Appears when taking portraits with backlighting.
Appears when taking portraits.
Appears when taking close-up photos of objects.
Appears when taking close-up photos of text.
Appears when taking photos of sunsets.
Appears when taking photos of clear skies.
Appears when taking photos of forested areas.
Appears when taking close-up photos of colorful
subjects.
Appears when taking close-up portraits of people.
Appears when the camera and subject are stable for
a while. This is available only when you are shooting
in the dark.
Appears when taking photos of actively moving
subjects.
Appears when taking photos of fireworks. This is
available only when you use a tripod.
Using the Smart Auto mode
In this mode, your camera automatically chooses the appropriate
camera settings based on a detected type of scene. The mode is
helpful if you are not familiar with the camera settings for various
scenes.
In Shooting mode, select
1
a
S
.
Align your subject in the frame.
2
The camera selects a scene automatically. An appropriate t
mode icon will appear at the top left of the screen.
Icon Description
Appears when taking photos of landscapes.
Appears when taking photos of bright white
backgrounds.
Appears when taking photos of landscapes at night.
This is available only when the flash is off.
Extended functions
32
Shooting modes
Using the Scene mode
Take a photo with options preset for a specific scene.
In Shooting mode, select
1
a
s
.
Select a scene.
2
Scene
This mode allows you to choose an appropriate scene for
a variety of situations.
For the Beauty Shot mode, see “t Using the Beauty Shot
mode” on page 33.
For the Frame Guide mode, see “t Using the frame guide” on
page 34.
For the Night mode, see “t Adjusting the exposure in the Night
mode” on page 34.
Align your subject in the frame and half-press [
3
Shutter]
to focus.
Press [
4
Shutter] to take the photo.
Half-press [
3
Shutter] to focus.
Press [
4
Shutter] to take the photo.
If the camera does not recognize a proper scene mode, t
S
will not
change and the default settings will be used.
Even if there is a face detected, the camera may not select a portrait t
mode depending on the subject's position or lighting.
The camera may not select the correct scene depending on shooting t
environments, such as camera shake, lighting and distance to the
subject.
Even if you use a tripod, t mode may not be detected depending on
the subject's movement.
Extended functions
33
Shooting modes
To hide facial imperfections, select
3
an option.
Select a higher setting to hide a greater number of t
imperfections.
Level 3
Align your subject in the frame and half-press [
4
Shutter]
to focus.
Press [
5
Shutter] to take the photo.
The focus distance will be set to Auto Macro.
Using the Beauty Shot mode
Take a photo of a person with options to hide facial imperfections.
In Shooting mode, select
1
a
s
.
To make the subject's skin tone appear lighter (face
2
only), select
f
an option.
Select a higher setting to make skin tone appear lighter.t
Level 2
Extended functions
34
Shooting modes
Adjusting the exposure in the Night mode
In Night mode, you can catch brief flashes of light as curved
streaks by extending the exposure. Use a slow shutter speed
to extend the time until the shutter closes. Increase the aperture
value to prevent overexposure.
In Shooting mode, select
1
a
s
.
Select
2
f
Aperture.
Aperture Shutter
Speed
Select an option.
3
Using the frame guide
When you want another person to take a photo of you, you can
compose the scene with the frame guide feature. The frame
guide will help the other person take a photo of you by showing
the part of the pre-composed scene.
In Shooting mode, select
1
a
s
.
Align your subject in the frame and press [
2
Shutter].
Transparent guides will appear on the left and right of the t
frame.
Cancel Frame: Back
Ask another person to take a photo.
3
The person must align the subject in the frame by using the t
guides, and then press [Shutter] to take the photo.
To cancel the guide, select
4
.
Extended functions
35
Shooting modes
Using the Program mode
Set various options (except for shutter speed and aperture value)
in Program mode.
In Shooting mode, select
1
a
p
.
Set options. (For a list of options, refer to “
2
Shooting
options.”)
Align your subject in the frame and half-press [
3
Shutter]
to focus.
Press [
4
Shutter] to take the photo.
Select
4
Shutter Speed.
Shutter
Speed
Aperture
Select a value to adjust the shutter speed and select
5
.
Align your subject in the frame and half-press [
6
Shutter]
to focus.
Press [
7
Shutter] to take the photo.
Use a tripod to prevent your photos from blurring.
Extended functions
36
Shooting modes
Select
3
>
a sound option.
Option Description
Off: Record a video without sound.
On: Record a video with sound.
Zoom Mute: Record a video without sound while
zooming.
Set other options as desired. (For options, refer to
4
“Shooting options.”)
Press [
5
Shutter] to start recording.
Press [
6
Shutter] again to stop recording.
Recording a video
Record videos of up to 20 minutes in length in high definition. The
recorded video is saved as an MP4 (H.264) file.
H.264 (MPEG-4 part10/AVC) is a high-compression video format t
established by international standard organizations ISO-IEC and ITU-T.
The zoom sound may be recorded if you use the zoom while t
recording a video.
Some memory cards may not support high definition recording. In this t
case, set a lower resolution.
Memory cards with slow writing speed will not support high-resolution t
videos and high-speed videos. To record high-resolution or high-
speed videos, use memory cards with fast writing speed.
In Shooting mode, select
1
a
v
.
Select
2
f
a frame rate (the number of frames
per second).
As the number of frames increases, action appears more t
natural, but the file size is increased.
30 FPS
is available only when the video resolution is 320 X 240.
Extended functions
37
Shooting modes
Using the Smart Scene Detection mode
In this mode, your camera automatically chooses the appropriate
camera settings based on a detected type of scene.
In Shooting mode, select
1
a
D
.
Align your subject in the frame.
2
The camera selects a scene automatically. An appropriate t
mode icon will appear at the top left of the screen.
Icon Description
Appears when recording videos of landscapes.
Appears when recording videos of clear skies.
Appears when recording videos of forested areas.
Appears when recording videos of sunsets.
To pause recording
The camera allows you to pause temporarily while recording a
video. With this function, you can record your favorite scenes as
a single video.
Select to pause while recording. Select to resume.
Stop: Shutter
Extended functions
38
Shooting modes
Press [
3
Shutter] to start recording.
Press [
4
Shutter] again to stop recording.
If the camera does not recognize a proper scene mode, t
D
will not
change and the default settings will be used.
The camera may not select the correct scene depending on shooting t
environments, such as camera shake, lighting and distance to the
subject.
In Smart Scene Detection mode, you cannot set smart filter effects t
and photo styles.
Extended functions
39
Recording voice memos
Learn how to record a voice memo that you can play back at any time. You can add a voice memo to a photo as a short reminder of
shooting conditions.
You will get the best sound quality when recording 40 cm away from the camera.
aps
Adding a voice memo to a photo
In Shooting mode, select
1
f
.
(In some modes, select
f
>
(Twice) .)
Memo
Align your subject in the frame and take a photo.
2
The camera begins to record a voice memo right after you t
take the photo.
Recording automatically stared (10 seconds maximum).
3
Press [t Shutter] to stop recording a voice memo.
Recording a voice memo
In Shooting mode, select
1
f
.
(In some modes, select
f
>
(Twice) .)
Record
Press [
2
Shutter] to record.
Select t to pause and to resume.
Once recording begins, the available recording time displayed t
at the top of the screen will be changed to reflect file number.
You can record voice memos of up to 10 hours in length.t
Press [
3
Shutter] to stop.
Select
4
to switch to Shooting mode.
Selecting a resolution and quality
………… 41
Selecting a resolution
………………………… 41
Selecting image quality
……………………… 42
Using the timer
……………………………… 43
Shooting in the dark
……………………… 45
Preventing red-eye
…………………………… 45
Using the flash
……………………………… 45
Adjusting the ISO speed
…………………… 46
Changing the camera’s focus
…………… 47
Using macro
………………………………… 47
Using auto focus
…………………………… 47
Using smart touch focus
…………………… 48
Using one touch shooting
…………………… 49
Adjusting the focus area
……………………… 49
Using face detection
……………………… 50
Detecting faces
……………………………… 50
Taking a self portrait shot
…………………… 51
Taking a smile shot
…………………………… 51
Detecting eye blinking
……………………… 52
Using smart face recognition
………………… 52
Registering faces as your favorites (My Star)
… 53
Adjusting brightness and color
…………… 54
Adjusting the exposure manually (EV)
……… 54
Compensating for backlighting (ACB)
……… 55
Changing the metering option
……………… 56
Selecting a light source (White balance)
…… 57
Using burst modes
………………………… 59
Improving your photos
…………………… 60
Applying photo styles
………………………… 60
Applying smart filter effects
………………… 61
Adjusting your photos
……………………… 62
Shooting options
Learn about the options you can set in Shooting mode.
Shooting options
41
Selecting a resolution and quality
Learn how to change the image resolution and quality settings.
Option Description
4320 X 3240: Print on A1 paper.
4000 X 3000: Print on A1 paper.
4320 X 2880: Print on A1 paper in wide ratio (3:2).
4320 X 2432: Print on A2 paper in panorama ratio
(16:9) or play back on an HDTV.
3264 X 2448: Print on A3 paper.
2560 X 1920: Print on A4 paper.
2048 X 1536: Print on A5 paper.
1920 X 1080: Print on A5 paper in panorama ratio
(16:9) or play back on an HDTV.
1024 X 768: Attach to an email.
Selecting a resolution
As you increase the resolution, your photo or video will include
more pixels, so it can be printed on larger paper or displayed on
a larger screen. When you use a high resolution, the file size will
also increase.
When taking a photo:
In Shooting mode, select
1
f
.
Select an option.
2
4320 X 2432
SapsDv
Shooting options
42
Selecting a resolution and quality
When recording a video:
In
1
D
and
v
modes, select
f
.
Select an option.
2
1280 X 720 HQ
Option Description
1280 X 720 HQ: Play back high-quality files on an
HDTV.
1280 X 720: Play back on an HDTV.
640 X 480: Play back on a general TV.
320 X 240: Post on a web page.
For Sharing: Post on a website using the wireless
network (30 seconds maximum).
Selecting image quality
Photos you take are compressed and saved in JPEG format.
Higher quality images will result in larger sizes.
In Shooting mode, select
1
f
.
Select an option.
2
Fine
Option Description
Super Fine
Fine
Normal
aps
Shooting options
43
Using the timer
Learn how to set the timer to delay shooting.
SapsDv
Press [
3
Shutter] to start the timer.
The AF lamp/timer lamp blinks. The camera will automatically t
take a photo at the specified time.
Select the timer icon or press [t Shutter] to cancel the timer.
Depending on the selected face defection option, the timer is not t
available or some timer options are not available.
In Shooting mode, select
1
.
Select an option.
2
Off
Option Description
Off: The timer is not active.
10 Sec: Take a photo in 10 seconds.
2 Sec: Take a photo in 2 seconds.
Double: Take a photo in 10 seconds and take another
in 2 seconds.
Motion Timer: Detect your movement and then take
a photo. (p. 44)
The options may differ depending on the shooting mode.
Shooting options
44
Using the timer
Pose for your photo while the AF-lamp/timer lamp is
5
blinking.
The AF-lamp/timer lamp will stop blinking just before the t
camera automatically takes a photo.
The motion timer may not work when:
you are more than 3 m away from the camerat
your movements are too subtlet
there is too much light or backlightt
the subject is close enough to reflect the AF lightt
Using the motion timer
In Shooting mode, select
1
.
Press [
2
Shutter].
Stand within 3 m from the camera within 6 seconds after
3
pressing [Shutter].
Make a motion, such as waving your arms, to activate
4
the timer.
The AF lamp/timer lamp will start to blink rapidly when the t
camera detects you.
The detection range of
the motion timer
Shooting options
45
Shooting in the dark
Learn how to take photos at night or in low light conditions.
Using the flash
Use the flash when taking photos in the dark or when you need
more light on your photos.
In Shooting mode, select
1
.
Select an option.
2
Auto
Option Description
Off:
The flash will not fire.t
Camera shake warning (t ) will be displayed when
shooting in low light.
Auto: The camera will select a proper flash setting for
the detected scene in
S
mode.
Auto: The flash fires automatically when the subject or
background is dark.
Saps
Preventing red-eye
If the flash fires when you take a photo of a person in the dark, a
red glow may appear in the eyes. To prevent this, select Red-eye
or Red-eye Fix. Refer to flash options in “Using the flash.”
This option is available in some scene modes.
ap
Shooting options
46
Shooting in the dark
Adjusting the ISO speed
The ISO speed is the measure of a film’s sensitivity to light as
defined by the International Organization for Standardization (ISO).
The higher ISO speed you select, the more sensitive to light your
camera becomes. With a higher ISO speed, you can get a better
photo without using the flash.
In Shooting mode, select
1
f
.
Select an option.
2
Select t to use an appropriate ISO speed based on the
brightness of the subject and lighting.
Auto
The higher ISO speed you select, the more image noise you may get.
p
Option Description
Red-eye*:
The flash fires when the subject or background is t
dark.
The camera reduces red-eyes.t
Fill in:
The flash always fires.t
Light intensity is adjusted automatically.t
Slow Sync:
The flash fires and the shutter stays open longer.t
Select this when you want to capture ambient light t
to reveal more details in the background.
Use a tripod to prevent your photos from blurring.t
Red-eye Fix*:
The flash fires when the subject or background is t
dark.
The camera corrects red-eyes through its advanced t
software analysis.
The options may differ depending on the shooting mode.
* There is an interval between two bursts of the flash. Do not move until
the flash fires a second time.
Flash options are not available if you set burst options or select t Blink
Detection or Self-Portrait.
Make sure that your subjects are within the recommended distance t
from the flash. (p. 122)
If there is reflected light or much dust in the air, tiny spots may appear t
on your photo.
Shooting options
47
Changing the camera’s focus
Learn how to adjust the camera's focus according to your subjects.
Using auto focus
To take sharp photos, select the appropriate focus according to
your distance from the subject.
In Shooting mode, select
1
.
Select an option.
2
Normal (AF)
Option Description
Normal (AF): Focus on a subject farther than 80 cm.
Auto Macro: Focus on a subject farther than 10 cm
(farther than 50 cm when using zoom).
Macro: Focus on a subject 10 - 80 cm (50 - 80 cm
when using zoom).
The options may differ depending on the shooting mode.
apDv
Using macro
Use macro to take close-up photos of subjects, such as flowers
or insects. Refer to macro options in “Using auto focus.”
Try to hold the camera very still to prevent blurry photos.t
Turn off the flash if the distance to the subject is less than 40 cm.t
pDv
Shooting options
48
Changing the camera’s focus
If you do not touch any area on the screen, the focus frame will t
appear in the center of the screen.
Tracking a subject may fail when:t
the subject is too small or the subject moves excessively. -
the subject is backlit or you are shooting in a dark place -
colors or patterns on the subject and the background are the same -
the camera shakes excessively -
In these cases, the focus frame will appear as a white single-line
frame.
If the camera fails to track the subject, you must reselect the subject t
to track.
If the camera fails to fix the focus, the focus frame will change to a red t
single-line frame.
If you use this function, you cannot set face detection, photo style t
options, and smart filter effects.
Using smart touch focus
Smart Touch AF allows you to track and auto focus on your
subject, even when you are moving.
In Shooting mode, select
1
f
.
Touch the subject you want to track in the touch area
2
(indicated by a frame).
A focus frame will appear on the subject and will follow the t
subject as you move the camera.
The white frame means that your camera is tracking the t
subject.
The green frame means that your subject is in focus when you t
half-press [Shutter].
aps
Shooting options
49
Changing the camera’s focus
Adjusting the focus area
You can get clearer photos by selecting an appropriate focus
area according to your subject’s location in the scene.
In Shooting mode, select
1
f
.
Select an option.
2
Center AF
Option Description
Center AF: Focus on the center (suitable when
subjects are located in the center).
Multi AF: Focus on one or more of 9 possible areas.
One Touch Shooting: Focus on the subject by
touching the image on the screen. Touch and hold the
subject to take the photo.
Smart Touch AF: Focus on and track the subject that
you touch on the screen. (p. 48)
The options may differ depending on the shooting mode.
aps
Using one touch shooting
You can focus on your subject and take a photo with a touch of
your finger.
In Shooting mode, select
1
f
.
Touch a subject to focus.
2
Touch and hold the subject to take the photo.
3
Touch and hold until the level indicator fills up. t
If you touch and hold any other area, the frame to detect faces will t
change to a normal frame.
If you use this function, you cannot set burst options, photo style t
options, and smart filter effects.
aps
Shooting options
50
Using face detection
If you use face detection options, your camera can automatically detect a human face. When you focus on a human face, the camera
adjusts the exposure automatically. Take photos quickly and easily by using Blink Detection to detect closed eyes or Smile Shot to
capture a smiling face. You can also use Smart Face Recognition to register faces and prioritize the focus on them.
aps
Detecting faces
Your camera automatically detects human faces (up to 10 human
faces).
In Shooting mode, select f . The nearest face
appears in a white focus frame and the rest of the faces appear in
gray focus frames.
The closer you are to the subject, the quicker your camera will detect t
faces.
If you want to focus faces in gray focus frames, touch them to focus.t
When you use the burst option, the detected faces may not be t
registered.
In some scene modes, face detection is unavailable.t
Face detection may not be effective when:t
the subject is far from the camera (The focus frame will appear -
orange for Smile Shot and Blink Detection)
it is too bright or too dark -
the subject is not facing the camera -
the subject is wearing sunglasses or a mask -
the subject is in backlighting or the lighting condition is unstable -
the subject’s facial expression changes remarkably -
Face detection is not available when using a photo style, a smart filter t
effect, or smart touch AF.
When you use the face detection option, the digital zoom will not t
work.
Depending on the selected face detection option, the timer is not t
available or some timer options are not available.
Depending on the selected face detection option, some burst options t
are not available.
When you take photos of detected faces, they will be registered in t
the face list.
You can view registered faces in order of priority in Playback mode. t
(p. 68) Even though faces are registered successfully, they may not be
classified in Playback mode.
The detected face in Shooting mode may not appear in the face list t
or Smart Album.
