Users Manual
9. User’s Manual
* Some of the contents of this manual may differ from your GALAXY Tab,
depending on the software installed or your service provider.
World Wide Web
http://www.anycall.com
SCH-M180S
User’s Guide
1
Be aware of special regulations
Meet any special regulations in force in any area and
always switch o your GALAXY whenever it is forbidden
to use it, or when it may cause interference or danger.
Water resistance
Your GALAXY is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to your ear). Avoid
unnecessary contact with the antenna when the GALAXY
is switched on.
Emergency calls
Key in the emergency number for your present location,
then press [ ].
Keep your GALAXY away from small children
Keep the GALAXY and all its parts, including accessories,
out of the reach of small children.
Accessories and batteries
Use only Samsung-approved batteries and accessories,
such as headsets and PC data cables. Use of any
unauthorised accessories could damage you or your GALAXY
and may be dangerous.
Qualied service
Only qualied service personnel may repair your GALAXY.
For more detailed safety information, see “Health and
safety information” on page 20.
Drive safely at all times
Do not use a hand-held GALAXY while driving. Park your
vehicle rst.
Switch o the GALAXY when refuelling
Do not use the GALAXY at a refuelling point (service
station) or near fuels or chemicals.
Switch o in an aircraft
Wireless GALAXYs can cause interference. Using them in
an aircraft is both illegal and dangerous.
Switch o the GALAXY near all medical equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy.
Follow any regulations or rules in force.
Interference
All wireless GALAXYs may be subject to interference,
which could aect their performance.
Failure to comply with the following
precautions may be dangerous or illegal.
Copyright information
Bluetooth? is a registered trademark of
the Bluetooth SIG, Inc. worldwide.
JavaTM is a trademark or registered
trademark of Sun Microsystems, Inc.
Picsel and Picsel ViewerTM are
trademarks of Picsel Technologies, Inc.
At very high volumes, prolonged listening
to a headset can damage your hearing.
Important safety precautions
• The GALAXY could explode if the battery is replaced
with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
2
3
Contents
Make sure you have each item
• GALAXY
• Adapter
• Stereo headset
• PC data cable
• User’s manual
You can obtain the following accessories for your GALAXY
from your local Samsung dealer.
• Multi adapter
• Travel charger
• Car charger
• PC data cable
• Portable battery kit
• Portable PC data cable
• Music controller
• Bluetooth mono/ stereop headset kit
Unpack
Unpack .............................................................. 3
Make sure you have each item
Get started ....................................................... 4
First steps to operate your GALAXY
Solve problems .............................................. 8
Help and personal needs
Health and safety information ............... 10
4
5
Power on or o
Power on
Do not turn on the GALAXY when mobile GALAXY use is
prohibited.
1Open the GALAXY.
2Press and hold [ ] to turn on the GALAXY.
3If necessary, enter the PIN and press [확인].
Power on
1Open the GALAXY.
2Press and hold [ ].
Keys and display
Key(s) Description
Softkeys Perform the function indicated on
the bottom line of the display.
Navigation keys In Standby mode, access menu
options directly.
In Menu mode, scroll through the
menu options.
확인 key In Idle mode, enters Menu mode.
In Menu mode, selects the
highlighted menu option.
key Sends or answers a call.
In Standby mode, retrieves the last
number dialed, missed, or received.
Install and charge the GALAXY
1Install the battery:
2Plug the adapter into the GALAXY.
3Plug the adapter into a standard AC wall outlet.
4When the GALAXY is completely charged (the battery
icon stops blinking), unplug the adapter from the
power outlet.
5Remove the adapter from the GALAXY.
Low battery indicator
When the battery is low:
• a warning tone sounds,
• the battery low message displays, and
• the empty battery icon [ ] blinks.
If the battery level becomes too low, the GALAXY
automatically turns o. Recharge your battery.
Get started
First steps to operate your GALAXY
To remove the battery, slide the
battery catch toward the top of the GALAXY
and hold it.
6
7
Get started
Key(s) Description
취소 key Deletes characters from the display.
In Menu mode, returns to the
previous menu level.
key Ends a call. Hold down to switch
the GALAXY on and o.
In Menu mode, cancels input and
returns the GALAXY to Idle mode.
Numeric keys Enter numbers, letters, and some
special characters.
*/# key Enter special characters.
Use for some special functions.
Key(s) Description
Volume keys
(on the left)
Adjusts the GALAXY volume.
In Standby mode, with the GALAXY
open, adjusts the master volume.
With the GALAXY closed, hold down
to turn on the display.
In Menu mode, scrolls through the
menu options.
Camera key In Standby mode, with the GALAXY
open, turns on the camera. With the
GALAXY closed, hold down to turn
on the camera.
In Capture mode, takes a photo.
MEMO
8
9
To save the time and expense of an unnecessary service
call, perform the simple checks in this section before
contacting a service professional.
When you switch on your GALAXY, the following
messages may appear:
“Insert USIM card”
• Be sure that the USIM card is correctly installed.
“GALAXY locked Enter password”
• The automatic locking function has been enabled. You
must enter the GALAXY’s password before you can use
the GALAXY.
“Enter PIN1”
• You are using your GALAXY for the rst time. You must
enter the PIN1 supplied with the USIM card.
• The PIN1 Check feature is enabled. Every time the
GALAXY is switched on, the PIN1 has to be entered. To
disable this feature, use the PIN check menu.
“Enter PUK”
• The PIN1 code has been entered incorrectly three times
in succession, and the GALAXY is now blocked. Enter the
PUK1 supplied by your service provider.
“No Service,” “Network Failure,” or “Not Done”
displays
• The network connection has been lost. You may be in a
weak signal area. Move and try again.
• You are trying to access an option for which you have
no subscription with your service provider. Contact the
service provider for further details.
You have entered a number but it was not dialled
• Be sure that you have pressed [ ].
• Be sure you have accessed the right cellular network.
• Be sure that you have not set an outgoing call barring
option.
Your correspondent cannot reach you
• Be sure your GALAXY is switched on. ( [ ] pressed for
more than one second.)
• Be sure you are accessing the correct cellular network.
• Be sure that you have not set an outgoing call barring
option.
Your correspondent cannot hear you speaking
• Be sure you have switched o the microphone.
• Be sure you are holding the GALAXY close enough to
your mouth. The microphone is located at the bottom
of the GALAXY.
The GALAXY starts beeping and “LOW BATTERY “
ashes on the display
• Your battery is insuciently charged. Recharge the
battery.
The audio quality of the call is poor
• Check the signal strength indicator on the display
( ). The number of bars indicates the signal
strength from strong ( ) to weak ( ).
• Try moving the GALAXY slightly or moving closer to a
window if you are in a building.
No number is dialled when you re-call a Contacts
entry
• Use the Contact Search feature to ensure the number
has been stored correctly.
• Re-store the number, if necessary.
If the above guidelines do not help you to solve the
problem, take note of:
• The model and serial numbers of your GALAXY
•Your warranty details
•A clear description of the problem
Then contact your local dealer or Samsung after-sales
service.
Solve problems
Help and personal needs
10
11
Exposure to Radio Frequency (RF) Signals
Certication Information (SAR)
Your wireless GALAXY is a radio transmitter and receiver.
It is designed and manufactured not to exceed the
exposure limits for radio frequency (RF) energy set by
the Federal Communications Commission (FCC) of the
U.S. government. These FCC exposure limits are derived
from the recommendations of two expert organizations,
the National Counsel on Radiation Protection and
Measurement (NCRP) and the Institute of Electrical
and Electronics Engineers (IEEE). In both cases, the
recommendations were developed by scientic and
engineering experts drawn from industry, government,
and academia after extensive reviews of the scientic
literature related to the biological eects of RF energy.
The exposure limit set by the FCC for wireless mobile
GALAXYs employs a unit of measurement known as the
Specic Absorption Rate (SAR). The SAR is a measure of
the rate of absorption of RF energy by the human body
expressed in units of watts per kilogram (W/kg). The FCC
requires wireless GALAXYs to comply with a safety limit
of 1.6 watts per kilogram (1.6 W/kg). The FCC exposure
limit incorporates a substantial margin of safety to give
additional protection to the public and to account for
any variations in measurements.
SAR tests are conducted using standard operating
positions accepted by the FCC with the GALAXY
transmitting at its highest certied power level in all
tested frequency bands. Although the SAR is determined
at the highest certied power level, the actual SAR level
of the GALAXY while operating can be well below the
maximum value. This is because the GALAXY is designed
to operate at multiple power levels so as to use only the
power required to reach the network. In general, the
closer you are to a wireless base station antenna, the
lower the power output.
Before a new model GALAXY is available for sale to the
public, it must be tested and certied to the FCC that
it does not exceed the exposure limit established by
the FCC. Tests for each model GALAXY are performed in
positions and locations (e.g. at the ear and worn on the
body) as required by the FCC.
Health and safety information
For body worn operations, this model GALAXY has been
testde and meets the FCC exposure guidelines when
used with a Samsung accessory designated for this
product or when used with an accessroy that contains
no metal and that positons the handset a minimum 0.5
cm from the body.
Non-compliance with the above restrictions may result
in violation of FCC RF exposure guidelines.
SAR information on this and other model GALAXYs can
be viewed on-line at http://www.fcc.gov/oet/ea/fccid/.
This site uses the GALAXY FCC ID number A3LSHWM180S.
Sometimes it may be necessary to dial “*#737456#” to
nd the number. Once you have the FCC ID number for a
particular GALAXY, follow the instructions on the website
and it should provide values for typical or maximum
SAR for a particular GALAXY. Additional product specic
SAR information can also be obtained at www.fcc.gov/
cgb/sar.
Consumer Information on
Wireless GALAXY
The U.S. Food and Drug Administration (FDA) has
published a series of Questions and Answers for
consumers relating to radio frequency (RF) exposure
from wireless GALAXYs. The FDA publication includes
the following information:
What kinds of GALAXYs are the subject of this update?
The term wireless GALAXY refers here to hand-held
wireless GALAXYs with built-in antennas, often called
“cell,” “mobile,” or “PCS” GALAXYs. These types of wireless
GALAXYs can expose the user to measurable radio
frequency energy (RF) because of the short distance
between the GALAXY and the user’s body. These RF
exposures are limited by Federal Communications
Commission safety guidelines that were developed
with the advice of FDA and other federal health and
safety agencies. When the GALAXY is located at greater
distances from the user, the exposure to RF is drastically
lower because a person’s RF exposure decreases rapidly
12
13
with increasing distance from the source. The so-called
“cordless GALAXYs,” which have a base unit connected to
the telephone wiring in a house, typically operate at far
lower power levels, and thus produce RF exposures well
within the FCC’s compliance limits.
Do wireless GALAXYs pose a health hazard?
The available scientic evidence does not show that
any health problems are associated with using wireless
GALAXYs. There is no proof, however, that wireless GALAXYs
are absolutely safe. Wireless GALAXYs emit low levels of
radio frequency energy (RF) in the microwave range while
being used. They also emit very low levels of RF when
in the stand-by mode. Whereas high levels of RF can
produce health eects (by heating tissue), exposure to
low level RF that does not produce heating eects causes
no known adverse health eects. Many studies of low
level RF exposures have not found any biological eects.
Some studies have suggested that some biological eects
may occur, but such ndings have not been conrmed
by additional research. In some cases, other researchers
have had diculty in reproducing those studies, or in
determining the reasons for inconsistent results.
What is FDA’s role concerning the safety of wireless
GALAXYs?
Under the law, FDA does not review the safety of
radiation-emitting consumer products such as wireless
GALAXYs before they can be sold, as it does with new
drugs or medical devices. However, the agency has
authority to take action if wireless GALAXYs are shown
to emit radio frequency energy (RF) at a level that is
hazardous to the user. In such a case, FDA could require
the manufacturers of wireless GALAXYs to notify users
of the health hazard and to repair, replace or recall the
GALAXYs so that the hazard no longer exists.
Although the existing scientic data do not justify FDA
regulatory actions, FDA has urged the wireless GALAXY
industry to take a number of steps, including the
following:
• “Support needed research into possible biological
eects of RF of the type emitted by wireless GALAXYs;
• “Design wireless GALAXYs in a way that minimizes any
RF exposure to the user that is not necessary for device
function; and
Health and safety information
• “Cooperate in providing users of wireless GALAXYs with
the best possible information on possible eects of
wireless GALAXY use on human health.
FDA belongs to an interagency working group of the
federal agencies that have responsibility for dierent
aspects of RF safety to ensure coordinated eorts at
the federal level. The following agencies belong to this
working group:
• “National Institute for Occupational Safety and Health
• “Environmental Protection Agency
• “Federal Communications Commission
•“Occupational Safety and Health Administration
• “National Telecommunications and Information
Administration
The National Institutes of Health participates in some
interagency working group activities, as well.
FDA shares regulatory responsibilities for wireless
GALAXYs with the Federal Communications Commission
(FCC). All GALAXYs that are sold in the United States
must comply with FCC safety guidelines that limit RF
exposure. FCC relies on FDA and other health agencies
for safety questions about wireless GALAXYs.
FCC also regulates the base stations that the wireless
GALAXYs networks rely upon. While these base stations
operate at higher power than do the wireless GALAXYs
themselves, the RF exposures that people get from
these base stations are typically thousands of times
lower than those they can get from wireless GALAXYs.
Base stations are thus not the primary subject of the
safety questions discussed in this document.
14
15
What are the results of the research done already?
The research done thus far has produced conicting
results, and many studies have suered from aws
in their research methods. Animal experiments
investigating the eects of radio frequency energy (RF)
exposures characteristic of wireless GALAXYs have yielded
conicting results that often cannot be repeated in
other laboratories. A few animal studies, however, have
suggested that low levels of RF could accelerate the
development of cancer in laboratory animals. However,
many of the studies that showed increased tumor
development used animals that had been genetically
engineered or treated with cancer-causing chemicals
so as to be pre-disposed to develop cancer in absence
of RF exposure. Other studies exposed the animals to
RF for up to 22 hours per day. These conditions are
not similar to the conditions under which people use
wireless GALAXYs, so we don’t know with certainty what
the results of such studies mean for human health.
Three large epidemiology studies have been published
since December 2000. Between them, the studies
investigated any possible association between the use
of wireless GALAXYs and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors of the brain
or salivary gland, leukemia, or other cancers. None of
the studies demonstrated the existence of any harmful
health eects from wireless GALAXYs RF exposures.
However, none of the studies can answer questions
about long-term exposures, since the average period of
GALAXY use in these studies was around three years.
What research is needed to decide whether RF
exposure from wireless GALAXYs poses a health risk?
A combination of laboratory studies and epidemiological
studies of people actually using wireless GALAXYs would
provide some of the data that are needed. Lifetime
animal exposure studies could be completed in a
few years. However, very large numbers of animals
would be needed to provide reliable proof of a cancer
promoting eect if one exists. Epidemiological studies
can provide data that is directly applicable to human
populations, but ten or more years’ follow-up may be
needed to provide answers about some health eects,
Health and safety information
such as cancer. This is because the interval between
the time of exposure to a cancer-causing agent and
the time tumors develop - if they do - may be many,
many years. The interpretation of epidemiological
studies is hampered by diculties in measuring actual
RF exposure during day-to-day use of wireless GALAXYs.
Many factors aect this measurement, such as the
angle at which the GALAXY is held, or which model of
GALAXY is used.
What is FDA doing to nd out more about the
possible health eects of wireless GALAXY RF?
FDA is working with the U.S. National Toxicology
Program and with groups of investigators around the
world to ensure that high priority animal studies are
conducted to address important questions about the
eects of exposure to radio frequency energy (RF).
FDA has been a leading participant in the World Health
Organization international Electromagnetic Fields
(EMF) Project since its inception in 1996. An inuential
result of this work has been the development of a
detailed agenda of research needs that has driven the
establishment of new research programs around the
world. The Project has also helped develop a series of
public information documents on EMF issues.
FDA and Cellular Telecommunications & Internet
Association (CTIA) have a formal Cooperative
Research and Development Agreement (CRADA) to
do research on wireless GALAXY safety. FDA provides
the scientic oversight, obtaining input from experts
in government, industry, and academic organizations.
CTIA-funded research is conducted through contracts
to independent investigators. The initial research will
include both laboratory studies and studies of wireless
GALAXY users. The CRADA will also include a broad
assessment of additional research needs in the context
of the latest research developments around the world.
16
17
What steps can I take to reduce my exposure to radio
frequency energy from my wireless GALAXY?
If there is a risk from these products - and at this point
we do not know that there is - it is probably very small.
But if you are concerned about avoiding even potential
risks, you can take a few simple steps to minimize your
exposure to radio frequency energy (RF). Since time is
a key factor in how much exposure a person receives,
reducing the amount of time spent using a wireless
GALAXY will reduce RF exposure.
• “If you must conduct extended conversations by
wireless GALAXY every day, you could place more
distance between your body and the source of the RF,
since the exposure level drops o dramatically with
distance. For example, you could use a headset and
carry the wireless GALAXY away from your body or use a
wireless GALAXY connected to a remote antenna.
Again, the scientic data do not demonstrate that
wireless GALAXYs are harmful. But if you are concerned
about the RF exposure from these products, you can
use measures like those described above to reduce your
RF exposure from wireless GALAXY use.
What about children using wireless GALAXYs?
The scientic evidence does not show a danger to users
of wireless GALAXYs, including children and teenagers.
If you want to take steps to lower exposure to radio
frequency energy (RF), the measures described above
would apply to children and teenagers using wireless
GALAXYs. Reducing the time of wireless GALAXY use and
increasing the distance between the user and the RF
source will reduce RF exposure.
Some groups sponsored by other national governments
have advised that children be discouraged from using
wireless GALAXYs at all. For example, the government in
the United Kingdom distributed leaets containing such
a recommendation in December 2000. They noted that
no evidence exists that using a wireless GALAXY causes
brain tumors or other ill eects. Their recommendation
to limit wireless GALAXY use by children was strictly
precautionary; it was not based on scientic evidence
that any health hazard exists.
Health and safety information
Do hands-free kits for wireless GALAXYs reduce risks
from exposure to RF emissions?
Since there are no known risks from exposure to RF
emissions from wireless GALAXYs, there is no reason to
believe that hands-free kits reduce risks. Hands-free
kits can be used with wireless GALAXYs for convenience
and comfort. These systems reduce the absorption of
RF energy in the body because the GALAXY, which is the
source of the RF emissions, will not be placed against
the body. Wireless GALAXYs marketed in the U.S. are
required to meet safety requirements regardless of
whether they are used against the head or against the
body. Either conguration should result in compliance
with the safety limit.
Do wireless GALAXY accessories that claim to shield
the head from RF radiation work?
Since there are no known risks from exposure to RF
emissions from wireless GALAXYs, there is no reason to
believe that accessories that claim to shield the head
from those emissions reduce risks. Some products that
claim to shield the user from RF absorption use special
GALAXY cases, while others involve nothing more than
a metallic accessory attached to the GALAXY. Studies
have shown that these products generally do not work
as advertised. Unlike “hand-free” kits, these so-called
“shields” may interfere with proper operation of the
GALAXY. The GALAXY may be forced to boost its power to
compensate, leading to an increase in RF absorption.
In February 2002, the Federal trade Commission (FTC)
charged two companies that sold devices that claimed
to protect wireless GALAXY users from radiation with
making false and unsubstantiated claims. According
to FTC, these defendants lacked a reasonable basis to
substantiate their claim.
18
19
What about wireless GALAXY interference with
medical equipment?
Radio frequency energy (RF) from wireless GALAXYs can
interact with some electronic devices. For this reason,
FDA helped develop a detailed test method to measure
electromagnetic interference (EMI) of implanted cardiac
pacemakers and debrillators from wireless telephones.
This test method is now part of a standard sponsored
by the Association for the Advancement of Medical
instrumentation (AAMI). The nal draft, a joint eort by
FDA, medical device manufacturers, and many other
groups, was completed in late 2000. This standard will
allow manufacturers to ensure that cardiac pacemakers
and debrillators are safe from wireless GALAXY EMI.
FDA has tested wireless GALAXYs and helped develop
a voluntary standard sponsored by the Institute of
Electrical and Electronic Engineers (IEEE). This standard
species test methods and performance requirements
for hearing aids and wireless GALAXYs so that no
interference occurs when a person uses a compatible
GALAXY and a compatible hearing aid at the same time.
This standard was approved by the IEEE in 2000.
FDA continues to monitor the use of wireless GALAXYs
for possible interactions with other medical devices.
Should harmful interference be found to occur, FDA will
conduct testing to assess the interference and work to
resolve the problem.
Additional information on the safety of RF exposures
from various sources can be obtained from the
following organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health Administration’s
(OSHA) : http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
• National institute for Occupational Safety and Health
(NIOSH) : http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO): http://www.who.
int/peh-emf/
Health and safety information
• International Commission on Non-Ionizing Radiation
Protection: http://www.icnirp.de
• National Radiation Protection Board (UK): http://
www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug Administration
http://www.fda.gov/Radiation-EmittingProducts/
RadiationEmittingProductsandProcedures/
HomeBusinessandEntertainment/CellPhones/
default.htm
Road Safety
Your wireless GALAXY gives you the powerful ability to
communicate by voice, almost anywhere, anytime. But
an important responsibility accompanies the benets
of wireless GALAXYs, one that every user must uphold.
When driving a car, driving is your rst responsibility.
When using your wireless GALAXY behind the wheel of
a car, practice good common sense and remember the
following tips:
1 Get to know your wireless GALAXY and its features,
such as speed dial and redial. If available, these
features help you to place your call without taking
your attention o the road.
2 When available, use a hands-free device. If possible,
add an additional layer of convenience and safety
to your wireless GALAXY with one of the many hands
free accessories available today.
3 Position your wireless GALAXY within easy reach.
Be able to access your wireless GALAXY without
removing your eyes from the road. If you get an
incoming call at an inconvenient time, let your
voice mail answer it for you.
4 Let the person you are speaking with know you
are driving; if necessary, suspend the call in heavy
trac or hazardous weather conditions. Rain, sleet,
snow, ice and even heavy trac can be hazardous.
5
Do not take notes or look up GALAXY numbers
while driving. Jotting down a “to do” list or ipping
through your address book takes attention away
from your primary responsibility, driving safely.
20
21
6 Dial sensibly and assess the trac; if possible, place
calls when you are not moving or before pulling
into trac. Try to plan calls when your car will be
stationary. If you need to make a call while moving,
dial only a few numbers, check the road and your
mirrors, then continue.
7 Do not engage in stressful or emotional
conversations that may be distracting. Make people
you are talking with aware you are driving and
suspend conversations that have the potential to
divert your attention from the road.
8
Use your wireless GALAXY to call for help. Dial 9-1-1
or other local emergency number in the case of re,
trac accident or medical emergencies. Remember,
it is a free call on your wireless GALAXY!
9 Use your wireless GALAX to help others in
emergencies. If you see an auto accident, crime in
progress or other serious emergency where lives
are in danger, call 9-1-1 or other local emergency
number, as you would want others to do for you.
10
Call roadside assistance or a special non-emergency
wireless assistance number when necessary. If
you see a broken-down vehicle posing no serious
hazard, a broken trac signal, a minor trac
accident where no one appears injured, or a vehicle
you know to be stolen, call roadside assistance or
other special non-emergency number.
“The wireless industry reminds you to use your
GALAXY safely when driving.”
For more information, please call 1-888-901-SAFE, or
visit our web-site www.wow-com.com
Provided by the Cellular Telecommunications & Internet
Association
Health and safety information
Operating Environment
Remember to follow any special regulations in force in
any area and always switch your GALAXY o whenever it is
forbidden to use it, or when it may cause interference or
danger. When connecting the GALAXY or any accessory to
another device, read its user’s guide for detailed safety
instructions. Do not connect incompatible products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation
of the equipment and for the safety of personnel, it is
recommended that the equipment should only be used
in the normal operating position (held to your ear with
the antenna pointing over your shoulder).
Using Your GALAXY Near Other
Electronic Devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain electronic
equipment may not be shielded against the RF signals
from your wireless GALAXY. Consult the manufacturer to
discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a minimum
distance of 15 cm (6 inches) be maintained between
a wireless GALAXY and a pacemaker to avoid potential
interference with the pacemaker.
These recommendations are consistent with the
independent research and recommendations of
Wireless Technology Research.
22
23
Persons with pacemakers:
• should always keep the GALAXY more than 15 cm
(6 inches) from their pacemaker when the GALAXY is
switched on.
•should not carry the GALAXY in a breast pocket.
•should use the ear opposite the pacemaker to minimize
potential interference.
If you have any reason to suspect that interference is
taking place, switch your GALAXY o immediately.
Hearing Aids
Some digital wireless GALAXYs may interfere with some
hearing aids. In the event of such interference, you
may wish to consult your hearing aid manufacturer to
discuss alternatives.
Other Medical Devices
If you use any other personal medical devices, consult
the manufacturer of your device to determine if it is
adequately shielded from external RF energy. Your
physician may be able to assist you in obtaining this
information. Switch your GALAXY o in health care
facilities when any regulations posted in these areas
instruct you to do so. Hospitals or health care facilities
may be using equipment that could be sensitive to
external RF energy.
Vehicles
RF signals may aect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check
with the manufacturer or its representative regarding
your vehicle. You should also consult the manufacturer
of any equipment that has been added to your vehicle.
Posted Facilities
Switch your GALAXY o in any facility where posted
notices require you to do so.
Health and safety information
Potentially Explosive Environments
Switch your GALAXY o when in any area with a
potentially explosive atmosphere and obey all signs
and instructions. Sparks in such areas could cause
an explosion or re resulting in bodily injury or even
death.
Users are advised to switch the GALAXY o while at a
refueling point (service station). Users are reminded
of the need to observe restrictions on the use of radio
equipment in fuel depots (fuel storage and distribution
areas), chemical plants or where blasting operations are
in progress.
Areas with a potentially explosive atmosphere are often
but not always clearly marked. They include below deck
on boats, chemical transfer or storage facilities, vehicles
using liqueed petroleum gas (such as propane or
butane), areas where the air contains chemicals or
particles, such as grain, dust or metal powders, and any
other area where you would normally be advised to
turn o your vehicle engine.
Emergency Calls
This GALAXY, like any wireless GALAXY, operates using
radio signals, wireless and landline networks as well as
user programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should
never rely solely on any wireless GALAXY for essential
communications (medical emergencies, for example).
Remember, to make or receive any calls the GALAXY must
be switched on and in a service area with adequate
signal strength. Emergency calls may not be possible
on all wireless GALAXY networks or when certain network
services and/or GALAXY features are in use. Check with
local service providers.
To make an emergency call:
1 If the GALAXY is not on, switch it on.
2 Key in the emergency number for your present
location (for example, 911 or other ocial
emergency number). Emergency numbers vary by
24
25
location.
3 Press [ ].
If certain features are in use (call barring, for example),
you may rst need to deactivate those features before
you can make an emergency call. Consult this document
and your local cellular service provider.
When making an emergency call, remember to give
all the necessary information as accurately as possible.
Remember that your GALAXY may be the only means of
communication at the scene of an accident; do not cut
o the call until given permission to do so.
Restricting Children’s access to your GALAXY
Your GALAXY is not a toy. Children should not be allowed
to play with it because they could hurt themselves and
others, damage the GALAXY or make calls that increase
your GALAXY bill.
FCC Notice and Cautions
FCC Notice
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and,f not installed and used in
accordance with the instructions, may cause harmful
Health and safety information
interference to radio communications.However, there
is no guarantee that interference will not occur in a
particular installation.If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment o
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna. -Increase
the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
The GALAXY may cause TV or radio interference if used
in close proximity to receiving equipment. The FCC can
require you to stop using theGALAXY if such interference
cannot be eliminated.
Vehicles using liqueed petroleum gas (such as propane
or butane) must comply with the National Fire Protection
Standard (NFPA-58). For a copy of this standard, contact
the National Fire Protection Association, One Battery
march Park, Quincy, MA 02269, Attn: Publication Sales
Division.
WLAN USE
This device will be restricted to indoor operations in
the 5.15-5.25 GHz band to reduce any potential for
harmful interference to co-channel MSS operations.
And this device shall automatically discontinue
transmission in case of either absence of information
to transmie or operational failure. These provisions are
not intended to preclude the transmission of control
or signalling information or the use of repetitive codes
used by certain digital technologies to complete frame
or burst intervals.
26
27
Cautions
Changes or modications made in the radio GALAXY, not
expressly approved by Samsung, will void the user’s
authority to operate the equipment.
Only use approved batteries, antennas and chargers. The
use of any unauthorized accessories may be dangerous
and void the GALAXY warranty if said accessories cause
damage or a defect to the GALAXY.
Although your GALAXY is quite sturdy, it is a complex
piece of equipment and can be broken. Avoid dropping,
hitting, bending or sitting on it.
Other Important Safety Information
• Only qualied personnel should service the GALAXY
or install the GALAXY in a vehicle. Faulty installation
or service may be dangerous and may invalidate any
warranty applicable to the device.
• Check regularly that all wireless GALAXY equipment in
your vehicle is mounted and operating properly.
• Do not store or carry ammable liquids, gases or
explosive materials in the same compartment as the
GALAXY, its parts or accessories.
• For vehicles equipped with an air bag, remember
that an air bag inates with great force. Do not place
objects, including both installed or portable wireless
equipment in the area over the air bag or in the air bag
deployment area. If wireless equipment is improperly
installed and the air bag inates, serious injury could
result.
• Switch your GALAXY o before boarding an aircraft. The
use of wireless GALAXY in aircraft is illegal and may be
dangerous to the aircraft’s operation.
• Failure to observe these instructions may lead to the
suspension or denial of telephone services to the
oender, or legal action, or both.
Health and safety information
Product Performance
Getting the Most Out of Your Signal Reception
The quality of each call you make or receive depends on
the signal strength in your area. Your GALAXY informs you
of the current signal strength by displaying a number
of bars next to the signal strength icon. The more bars
displayed, the stronger the signal.
If you’re inside a building, being near a window may
give you better reception.
Understanding the Power Save Feature
If your GALAXY is unable to nd a signal after 15 minutes
of searching, a Power Save feature is automatically
activated. If your GALAXY is active, it periodically
rechecks service availability or you can check it yourself
by pressing any key.
Anytime the Power Save feature is activated, a message
displays on the screen. When a signal is found, your
GALAXY returns to standby mode.
Understanding How Your GALAXY Operates
Your GALAXY is basically a radio transmitter and receiver.
When it’s turned on, it receives and transmits radio
frequency (RF) signals. When you use your GALAXY, the
system handling your call controls the power level. This
power can range from 0.006 watts to 0.2 watts in digital
mode.
Maintaining Your GALAXY’s Peak Performance
For the best care of your GALAXY, only authorized
personnel should service your GALAXY and accessories.
Faulty service may void the warranty.
There are several simple guidelines to operating your
GALAXY properly and maintaining safe, satisfactory
service.
• Place the mobile GALAXY’s acoustic output next to your
ear for proper orientation.
• Do not tamper or alter the GALAXY’s antenna.
• Don’t use the GALAXY if the antenna is damaged.
• Speak directly into the GALAXY’s receiver.
28
29
• Avoid exposin your GALAXY and accessories to rain or
liquid spills. If your GALAXY does get wet, immediately
thrn the power o and remove the battery. If it is
inoperable, call Customer Care for service.
Availability of Various Features/Ring Tones
Many services and features are network dependent
and may require additional subscription and/or usage
charges. Not all features are available for purchase
or use in all areas. Downloadable Ring Tones may be
available at an additional cost. Other conditions and
restrictions may apply. See your service provider for
additional information.
Battery Standby and Talk Time
Standby and talk times will vary depending on
GALAXY usage patterns and conditions. Battery power
consumption depends on factors such as network
conguration, signal strength, operating temperature,
features selected, frequency of calls, and voice, data,
and other application usage patterns.
Battery Precautions
• Never use any charger or battery that is damaged in
any way.
• Use the battery only for its intended purpose.
• If you use the GALAXY near the network’s base station,
it uses less power; talk and standby time are greatly
aected by the signal strength on the cellular network
and the parameters set by the network operator.
Health and safety information
• Battery charging time depends on the remaining
battery charge and the type of battery and charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out.
When the operation time (talk time and standby time)
is noticeably shorter than normal, it is time to buy a
new battery.
• If left unused, a fully charged battery will discharge
itself over time.
• Use only Samsung-approved batteries and recharge
your battery only with Samsung-approved chargers.
When a charger is not in use, disconnect it from the
power source. Do not leave the battery connected to a
charger for more than a week, since overcharging may
shorten its life.
• Extreme temperatures will aect the charging capacity
of your battery: it may require cooling or warming
rst.
• Do not leave the battery in hot or cold places, such
as in a car in summer or winter conditions, as you
will reduce the capacity and lifetime of the battery.
Always try to keep the battery at room temperature.
A GALAXY with a hot or cold battery may temporarily
not work, even when the battery is fully charged. Li-
ion batteries are particularly aected by temperatures
below 0℃(32 ℉).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object (coin, clip
or pen) causes a direct connection between the + and
- terminals of the battery (metal strips on the battery),
for example when you carry a spare battery in a pocket
or bag. Short-circuiting the terminals may damage the
battery or the object causing the short-circuiting.
• Dispose of used batteries in accordance with local
regulations. In some areas, the disposal of batteries
in household or business trash may be prohibited. For
safe disposal options for Li-Ion batteries, contact your
nearest Samsung authorized service center. Always
recycle. Do not dispose of batteries in a re.
30
31
Care and Maintenance
Your GALAXY is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulll any warranty
obligations and allow you to enjoy this product for
many years.
• Keep the GALAXY and all its parts and accessories out of
the reach of small children.
• Keep the GALAXY dry. Precipitation, humidity and
liquids contain minerals that will corrode electronic
circuits.
• Do not use the GALAXY with a wet hand. Doing so
may cause an electric shock to you or damage to the
GALAXY.
• Do not use or store the GALAXY in dusty, dirty areas, as
its moving parts may be damaged.
• Do not store the GALAXY in hot areas. High temperatures
can shorten the life of electronic devices, damage
batteries, and warp or melt certain plastics.
• Do not store the GALAXY in cold areas. When the
GALAXY warms up to its normal operating temperature,
moisture can form inside the GALAXY, which may
damage the GALAXY’s electronic circuit boards.
• Do not drop, knock or shake the GALAXY. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents or
strong detergents to clean the GALAXY. Wipe it with a
soft cloth slightly dampened in a mild soap-and-water
solution.
• Do not paint the GALAXY. Paint can clog the device’s
moving parts and prevent proper operation.
• Do not put the GALAXY in or on heating devices, such
as a microwave oven, a stove or a radiator. The GALAXY
may explode when overheated.
• When the GALAXY or battery gets wet, the label
indicating water damage inside the GALAXY changes
color. In this case, GALAXY repairs are no longer
guaranteed by the manufacturer’s warranty, even if
the warranty for your GALAXY has not expired.
Health and safety information
• If your GALAXY has a ash or light, do not use it too
close to the eyes of people or animals. This may cause
damage to their eyes.
• Use only the supplied or an approved replacement
antenna. Unauthorized antennas or modied
accessories may damage the GALAXY and violate
regulations governing radio devices.
• If the GALAXY, battery, charger or any accessory is not
working properly, take it to your nearest qualied
service facility. The personnel there will assist you, and
if necessary, arrange for service.
• When the GALAXY or battery gets wet, the label
indicating water damage inside the GALAXY changes
colour. In this case, GALAXY repairs are no longer
guaranteed by the manufacturer’s warranty, even if
the warranty for your GALAXY has not expired.
• If your GALAXY has a ash or light, do not use it too
close to the eyes of people or animals. This may cause
damage to their eyes.
• Use only the supplied or an approved replacement
antenna. Unauthorised antennas or modied
accessories may damage the GALAXY and violate
regulations governing radio devices.
• If the GALAXY, battery, charger, or any accessory is not
working properly, take it to your nearest qualied
service facility. The personnel there will assist you,
and if necessary, arrange for service.Precautions when
using batteries
• Never use a charger or battery that is damaged in any way.
• Use the battery only for its intended purpose.
• If you use the GALAXY near the network’s base station,
it uses less power. Talk and standby time are greatly
aected by the signal strength on the cellular network
and the parameters set by the service provider.
• Battery charging time depends on the remaining
battery charge, the type of battery, and the charger
used. The battery can be charged and discharged
hundreds of times, but it will gradually wear out. When
the operation time is noticeably shorter than normal,
it is time to buy a new battery.
32 33
• If left unused, a fully charged battery will discharge
itself over time.
• Use only Samsung-approved batteries, and recharge your
battery only with Samsung-approved chargers.
Disconnect the charger from the power source when
it is not in use. Do not leave the battery connected to a
charger for more than a week, since overcharging may
shorten its life.
• Extreme temperatures will aect the charging capacity of
your battery: it may require cooling or warming rst.
• Do not leave the battery in hot or cold places because
the capacity and lifetime of the battery will be reduced.
Try to keep the battery at room temperature. A GALAXY
with a hot or cold battery may not work temporarily,
even when the battery is fully charged. Li-ion batteries
are particularly affected by temperatures below 0℃(32 ℉).
• Do not short-circuit the battery. Accidental short-
circuiting can occur when a metallic object like a coin,
clip or pen causes a direct connection between the
+ and - terminals of the battery (metal strips on the
battery). For example, do not carry a spare battery in
a pocket or bag where the battery may contact metal
objects. Short-circuiting the terminals may damage
the battery or the object causing the short-circuiting.
• Dispose of used batteries in accordance with local
regulations. Always recycle. Do not dispose of batteries
in a re.
Road safety
Your wireless GALAXY gives you the powerful ability to
communicate by voice, almost anywhere, anytime. But
an important responsibility accompanies the benets
of wireless GALAXYs, one that every user must uphold.
When you are driving a car, driving is your rst
responsibility. When using your wireless GALAXY while
driving, follow local regulations in the country or region
you are in.
Operating environment
Remember to follow any special regulations in force in
the area you are in, and always switch o your GALAXY
whenever it is forbidden to use it, or when it may cause
interference or danger.
When connecting the GALAXY or any accessory to
another device, read its user’s guide for detailed safety
instructions. Do not connect incompatible products.
As with other mobile radio transmitting equipment,
users are advised that for the satisfactory operation
of the equipment and for the safety of personnel, it is
recommended that the equipment should only be used
in the normal operating position (held to your ear with
the antenna pointing over your shoulder).
Electronic devices
Most modern electronic equipment is shielded from
radio frequency (RF) signals. However, certain electronic
equipment may not be shielded against the RF signals
from your wireless GALAXY. Consult the manufacturer to
discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that a
minimum distance of 15 cm (6 inches) be maintained
between a wireless GALAXY and a pacemaker to avoid
potential interference with the pacemaker. These
recommendations are consistent with the independent
research and recommendations of Wireless Technology
Research. If you have any reason to suspect that
interference is taking place, switch o your GALAXY
immediately.
Hearing aids
Some digital wireless GALAXYs may interfere with some
hearing aids. In the event of such interference, you
may wish to consult your hearing aid manufacturer to
discuss alternatives.
Health and safety information
34 35
Other medical devices
If you use any other personal medical devices, consult
the manufacturer of your device to determine if it is
adequately shielded from external RF energy.
Your physician may be able to assist you in obtaining
this information.
Switch o your GALAXY in health care facilities when
regulations posted in these areas instruct you to do so.
Vehicles
RF signals may aect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check
with the manufacturer or its representative regarding
your vehicle.
You should also consult the manufacturer of any
equipment that has been added to your vehicle.
Posted facilities
Switch o your GALAXY in any facility where posted
notices require you to do so.
Potentially explosive environments
Switch o your GALAXY when in any area with a
potentially explosive atmosphere, and obey all signs
and instructions. Sparks in such areas could cause
an explosion or re resulting in bodily injury or even
death.
Users are advised to switch o the GALAXY while at a
refuelling point (service station). Users are reminded
of the need to observe restrictions on the use of radio
equipment in fuel depots (fuel storage and distribution
areas), chemical plants, or where blasting operations
are in progress.
Areas with a potentially explosive atmosphere are often
but not always clearly marked. They include the areas
below decks on boats, chemical transfer or storage
facilities, vehicles using liqueed petroleum gas, such
as propane or butane, areas where the air contains
chemicals or particles, such as grain, dust or metal
powders, and any other area where you would normally
be advised to turn o your vehicle engine.
Emergency calls
This GALAXY, like any wireless GALAXY, operates using
radio signals, wireless, and landline networks as well as
user-programmed functions, which cannot guarantee
connection in all conditions. Therefore, you should
never rely solely on any wireless GALAXY for essential
communications like medical emergencies.
To make or receive calls, the GALAXY must be switched
on and in a service area with adequate signal strength.
Emergency calls may not be possible on all wireless
GALAXY networks or when certain network services and/
or GALAXY features are in use. Check with local service
providers.
To make an emergency call:
1 Switch on the GALAXY.
2 Key in the emergency number for your present
location. Emergency numbers vary by location.
3 Press [ ].
Certain features like Call Barring may need to be
deactivated before you can make an emergency call.
Consult this document and your local cellular service
provider.
Other important safety information
• Only qualied personnel should service the GALAXY
or install the GALAXY in a vehicle. Faulty installation
or service may be dangerous and may invalidate any
warranty applicable to the device.
• Check regularly that all wireless GALAXY equipment in
your vehicle is mounted and operating properly.
Health and safety information
36 37
• Do not store or carry ammable liquids, gases, or
explosive materials in the same compartment as the
GALAXY, its parts, or accessories.
• For vehicles equipped with an air bag, remember that
an air bag inates with great force. Do not place objects,
including installed or portable wireless equipment, in
the area over the air bag or in the air bag deployment
area. Improperly installed wireless equipment could
result in serious injury if the air bag inates.
• Switch o your GALAXY before boarding an aircraft. It
is dangerous and illegal to use wireless GALAXYs in an
aircraft because they can interfere with the operation
of the aircraft.
• Failure to observe these instructions may lead to the
suspension or denial of telephone services to the
oender, or legal action, or both.
Care and maintenance
Your GALAXY is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulll any warranty
obligations and allow you to enjoy this product for
many years.
• Keep your GALAXY and all its parts and accessories
out of the reach of small children and pets. They may
accidentally damage these things or choke on small
parts.
• Keep the GALAXY dry. Precipitation, humidity, and liquids
contain minerals that corrode electronic circuits.
• Do not use the GALAXY with a wet hand. Doing so
may cause an electric shock to you or damage to the
GALAXY.
• Do not use or store the GALAXY in dusty, dirty areas, as
its moving parts may be damaged.
• Do not store the GALAXY in hot areas. High temperatures
can shorten the life of electronic devices, damage
batteries, and warp or melt certain plastics.
• Do not store the GALAXY in cold areas. When the
GALAXY warms up to its normal operating temperature,
moisture can form inside the GALAXY, which may
damage the GALAXY’s electronic circuit boards.
• Do not drop, knock, or shake the GALAXY. Rough
handling can break internal circuit boards.
• Do not use harsh chemicals, cleaning solvents, or
strong detergents to clean the GALAXY. Wipe it with a
soft cloth.
• Do not paint the GALAXY. Paint can clog the device’s
moving parts and prevent proper operation.
• Do not put the GALAXY in or on heating devices, such as
a microwave oven, stove, or radiator. The GALAXY may
explode when overheated.
• When the GALAXY or battery gets wet, the label
indicating water damage inside the GALAXY changes
colour. In this case, GALAXY repairs are no longer
guaranteed by the manufacturer’s warranty, even if
the warranty for your GALAXY has not expired.
• If your GALAXY has a ash or light, do not use it too
close to the eyes of people or animals. This may cause
damage to their eyes.
• Use only the supplied or an approved replacement
antenna. Unauthorised antennas or modied
accessories may damage the GALAXY and violate
regulations governing radio devices.
• If the GALAXY, battery, charger, or any accessory is not
working properly, take it to your nearest qualied
service facility. The personnel there will assist you, and
if necessary, arrange for service.
Health and safety information
