Notices for using Bluetooth
•
Toavoidproblemswhenconnectingyour
devicetoanothermobiledevice,placethe
devicesclosetoeachother.
•
Ensurethatyourdeviceandtheother
BluetoothdevicearewithintheBluetooth
connectionrange(10m).Thedistancemay
varydependingontheenvironmentthe
devicesareusedin.
•
Ensurethattherearenoobstaclesbetween
yourheadsetandaconnecteddevice,
includinghumanbodies,walls,corners,or
fences.
•
DonottouchtheBluetoothantennaofa
connecteddevice.
•
Bluetoothusesthesamefrequencyassome
industrial,scientific,medical,andlowpower
productsandinterferencemayoccurwhen
makingconnectionsnearthesetypesof
products.
•
Somedevices,especiallythosethatarenot
testedorapprovedbytheBluetoothSIG,may
beincompatiblewiththeheadset.
Charging the battery
ChargethebatterybeforeusingtheCircleforthe
firsttime.
Openthechargerportcoverandplugthesmall
endofthechargerintothechargerportofthe
Circle.
•
Tosaveenergy,unplugthechargerwhen
notinuse.Thechargerdoesnothavea
powerswitch,soyoumustunplugthe
chargerfromtheelectricsocketwhen
notinusetoavoidwastingpower.The
chargershouldremainclosetothe
electricsocketandeasilyaccessiblewhile
charging.
•
Thesocket-outletshallbeinstalled
neartheequipmentandshallbeeasily
accessible.
Reconnecting the devices
TheconnectionbetweentheCircleandthe
connecteddevicemaydisconnectwhenusing
thedevicesoverlongdistances.Whenthe
connectionisended,theCirclewillbeepand
vibrate.
PlacetheCircleneartheconnecteddeviceto
reconnect.Whenthedevicesarereconnected,
theCirclewillbeepandvibrate.
Iftheconnectionislostduetoaproblemwith
thedevice,pressthePlay/TalkkeyontheCircle
oraccesstheBluetoothmenuonthedevice.If
theearphonesareconnected,separatethemand
reconnectthedevices.
Disconnecting the devices
TurnofftheCircleordeactivatetheBluetooth
featureontheconnecteddevice.
•
TheSamsungGearappisavailablefor
Samsungsmartphonesthathavemore
than1GBofmemoryandrunAndroid
4.2.2orhigher.
•
PlacetheCircleneartothedeviceto
connect.
•
IftheCircledoesnotenterBluetooth
pairingmode,separatetheearphones
andpressandholdthePlay/Talkkeyfor
3seconds.
•
ThemethodforconnectingviaBluetooth
mayvarydependingontheconnected
devices.Formoreinformation,referto
theusermanualoftheconnecteddevice.
Connecting to two devices
TheCirclecanconnecttotwoBluetooth-enabled
devicesatthesametime.
AfterpairingtheCirclewithanotherdevice,enter
Bluetoothpairingmodeagaintoconnecttoa
seconddevice.Then,reconnecttothefirstdevice.
TheCircleisnowconnectedtotwodevices.
6 Other device Readandagreetotheterms
andconditions,andthentapFinish.
Whenthedevicesareconnectedproperly,the
Circlewillbeepandvibrate.
Connecting devices via Bluetooth
1 Circle TurnontheCircle.
WhenyouturnontheCircleforthefirsttime,
theCircleautomaticallyentersBluetooth
pairingmode.Thestatusindicatorflashes
green,blue,andthenredfor3minutes.
2 Other device TurnontheBluetoothfeature.
3 Other device AccesstheBluetoothmenu
andsearchforBluetoothdevices.
4 Other device Fromthesearchresults,tap
Gear Circle.
Whenthedevicesareconnectedproperly,the
Circlewillbeepandvibrate.
3 Circle TurnontheCircle.
WhenyouturnontheCircleforthefirsttime,
theCircleautomaticallyentersBluetooth
pairingmode.Thestatusindicatorflashes
green,blue,andthenredfor3minutes.
4 Other device OntheAppsscreen,tap
Samsung Gear.
5 Other device Fromthesearchresults,tap
Gear Circle.
Connecting to other devices
TousetheCircle,youmustpairitwithanother
device.Afterpairingwithadevice,theCirclewill
automaticallyconnecttothedeviceinthefuture.
YoucanconnecttheCircletootherdevicesusing
theSamsungGearapporviaBluetooth.
Connecting devices using the
Samsung Gear app
InstalltheSamsungGearappontheotherdevice
andconnecttheCircletothedevice.
1 Other device DownloadtheSamsungGear
appfromGALAXY Apps.Youcanalsovisit
apps.samsung.com/gear
todownloadthe
SamsungGearapp.
2 Other device TurnontheBluetoothfeature.
Charging indicator
•
Charging:Red
•
Fullycharged:Green
Checktheproductboxforthedevice,
earbudtips(3pairs,S/M/L),neckguides(for
outdooractivities,S/M/L),acharger,andthe
quickstartguide.Theitemssuppliedwith
thedeviceandavailableaccessoriesmay
varydependingontheregion.
Charger port
Magnet sensor
Neckband (Vibration
notification/Charging area)
Play/Talk key
Volume control touch pad
Charging indicator
Left earphone
Power switch
Microphone
Status indicator
Right earphone
Controls functions
•
Powerswitch:Slideupordowntoturnthe
Circleonoroff.
•
Play/Talkkey:Presstoanswerorendacall.
Presstoplaymusicorpauseplayback.Press
andholdfor3secondstoenterBluetooth
pairingmode.
•
Volumecontroltouchpad:
–
Swipeupwardsordownwardstoadjustthe
volumeduringmediaplaybackoracall.
–
Swipeupwardsordownwardstostopthe
Circlevibrationwhenacallcomesin.
Status indicator
•
Bluetoothpairingmode:Blinkinggreen,blue,
andred
•
Poweron:Blinkingblue3times
•
Poweroff:Blinkingred3times
•
Incomingcall:Blinkingblue
About Gear Circle
WiththisBluetoothheadset(alsoreferredtoasCircle),youcanconnectwithBluetooth-enableddevices,
suchassmartphonesandtablets.Youcananswercallsandplaymusicfromtheconnecteddevices.
SM-R130
Quick Start Guide
Copyright©2014SamsungElectronics
PrintedinKorea
GH68-42256ARev.1.0
English(EU).09/2014
www.samsung.com
•
Thisquickstartguideisdesignedto
providebasicinformationaboutusing
theBluetoothheadsetanddescribes
somespecificfeatures.Youcanfind
moreinformationintheusermanualat
www.samsung.com
.Youcanalsoviewthe
usermanualintheconnecteddevice.Open
theAppsscreenoftheconnecteddevice
andtapSamsung Gear
→
User manual.
•
Tolearnhowtoremovethebatteryfrom
theCircle,refertotheusermanual.
Turning the Circle on or off
SlidethePowerswitchupordowntoturnthe
Circleonoroff.
On Off
21
15
22
16
23
17
24 25
18 19 2014
Pausing and resuming playback
PressthePlay/Talkkeyorconnecttheearphones
topauseplayback.
Toresumeplayback,separatetheearphonesand
pressthePlay/Talkkey.
Skipping to the next song
PressthePlay/Talkkeytwicetoskiptothenext
songwhileplayingmusic.
Launching S Voice
WhileyouarewearingtheCircle,pressandhold
thePlay/Talkkeyfor1second.
IftheconnecteddevicesupportS Voice,youcan
usetheappviatheCircle.
Switching sound output
Usetherelatedmenuontheconnecteddeviceto
switchsoundoutputbetweentheCircleandthe
connecteddevice.
Whentheearphonesareconnected,youcan
automaticallyswitchthesoundoutputtothe
Circlebyseparatingtheearphones.
Ending a call
PressthePlay/Talkkeyorreconnectthe
earphones.
Playing music
PressthePlay/Talkkey.
Themostrecently-playedmusicfilewillplay
automaticallyinthedefaultmusicappinstalled
ontheconnecteddevice.
Using the Circle
Answering a call
While wearing the Circle
Whenacallcomes,theCirclewillbeepand
vibrate.PressthePlay/Talkkey.
While the earphones are connected
Whenacallcomes,theCirclewillvibrate.
Separatetheearphonesandputtheminyour
ears.Whenyouseparatetheearphones,thecall
willbereceived.
Rejecting a call
Whenacallcomesin,pressandholdthePlay/
Talkkeyfor1secondorconnecttheearphones.
2
Adjusting the volume
SwipeupwardsordownwardsontheVolume
controltouchpadtoadjustthevolume.
•
Donotpullonanypartofthedeviceexcessively.
•
Usecautionwhentakingoffthedevice.The
headsetcablemaytanglearoundyourneck.
•
Usecautionwhenusingthedevicewhileyouare
walkingormoving.Thedevicemayfalloffofyour
neck.
•
Usecautionwhenyouwearthedevicewithother
accessories,suchasanecklace.
•
Turnoffthedeviceinpotentiallyexplosive
environments.
•
Complywithallsafetywarningsandregulations
regardingmobiledeviceusagewhileoperating
avehicle.
•
Leavethedeviceinadryplace.Ifthedeviceis
exposedtofreshwater,dryitthoroughlywitha
clean,softclothandtakeittoaSamsungService
centre.
•
Donotstoreyourdeviceinveryhotorverycold
areas.Itisrecommendedtouseyourdeviceat
temperaturesfrom5°Cto35°C.
•
Donotusethedevicewhiledriving.Usingthe
devicemaytakeattentionawayfromyourprimary
responsibilityofdrivingsafely.
Connecting the earphones
Using the neck guide
1
•
Donotexposethedevicetophysicalimpactor
damage.
•
Donotstoreyourdevicenearorinheaters,
microwaves,cookingequipment,orhighpressure
containers.
•
Donotuseorstoreyourdeviceinareaswithhigh
concentrationsofdustorairbornematerials.
•
Donotallowchildrenoranimalstocheworsuck
thedevice.
•
Donotpokeeyes,ears,orotherbodypartswith
thedeviceorinsertthedeviceintothemouth.
Caution
•
Followallpostedwarningsanddirectionsfrom
authorisedpersonnelinareaswheretheuseof
wirelessdevicesisrestricted,suchasaeroplanes
andhospitals.
•
Donotstoreyourdevicenearmagneticfields.
Magneticstripecards,includingcreditcards,
phonecards,passbooks,andboardingpasses,
maybedamagedbymagneticfields.
•
Donotusethedeviceforanythingotherthanits
intendedpurposes.
Wearing the Circle
Covertheearphoneswiththeprovidedearbud
tipsandcorrectlyweartheearphones.The
earphonescontainmagnetssothattheycanbe
attached.WearingtheCircleusingtheneckguide
(foroutdooractivities)willpreventtheneckband
fromfallingoffofyourneck.
Wearing the Circle
Safety information
Topreventinjury,fire,orexplosion,readandadhere
toallsafetyinformationbeforeusingthedevice.
Warning
•
TheGearCirclecontainsmagnetsinitsearbuds.
TheAmericanHeartAssociation(US)andthe
MedicinesandHealthcareProductsRegulatory
Agency(UK)bothwarnthatmagnetscan
affecttheoperationofimplantedpacemakers,
cardioverters,defibrillators,insulinpumpsorother
electromedicaldevices(collectively,“Medical
Device”)withintherangeof15cm(6inches).If
youareauserofanyoftheseMedicalDevices,
DONOTUSETHEGEARCIRCLEUNLESSYOUHAVE
CONSULTEDWITHYOURPHYSICIAN.
•
Donottouchthepowercordwithwethandsor
disconnectthechargerbypullingthecord.
•
Donotuseyourdeviceoutdoorduringa
thunderstorm.
•
Usemanufacturer-approvedaccessoriesand
supplies.
Using the Samsung Gear app
IftheCircleandtheotherdeviceareconnected
usingtheSamsungGearapp,youcanaccess
additionalfeatures,suchasadjustingthesound
effectorsettingthenotificationfeature.
Ontheconnecteddevice,opentheAppsscreen
andtapSamsung Geartolaunchit.
Gear SoundAlive
Selectasoundeffectoradjustthesoundeffect
manually.
OntheSamsungGearmainscreen,tapGear
SoundAlive.
Notifications
Setthedevicetonotifyyouofmissedcallsand
newmessagesviaavoicenotificationtothe
Circle.
OntheSamsungGearmainscreen,tap
Notifications,taptheNotificationsswitchto
activateit,andthenselectapps.
Using the earbud tips
Covertheearphoneswiththeprovidedearbud
tipsthatbestfityourears.
•
Donotputtheearphonesinyourears
withoutearbudtips.
•
Donotpulltheearbudtipexcessively.
Theearbudtipmaytear.
•
Anychangesormodificationstoyourdevicecan
voidyourmanufacturer’swarranty.Ifyourdevice
needsservicing,takeyourdevicetoaSamsung
ServiceCentre.
Topreventpossiblehearingdamage
whenusingaheadset,donotlistento
soundathighvolumeforlongperiods.
Correct disposal
Thismarkingontheproduct,accessories
orliteratureindicatesthattheproduct
anditselectronicaccessories(e.g.charger,
headset,USBcable)shouldnotbe
disposedofwithotherhouseholdwaste.
ThisproductisRoHScompliant.
Thismarkingonthebattery,manualor
packagingindicatesthatthebatteriesin
thisproductshouldnotbedisposedof
withotherhouseholdwaste.
Federal Communications Commission
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:(1)
This device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired operation.
The device and its antenna must not be co-located or
operating in conjunction with any other antenna or
transmitter. Users are not permitted to make changes or
modify the device in any way. Changes or modifications
not expressly approved by Samsung will void the user’s
authority to operate the equipment.
RF Exposure Statement (2.1091)
FCC RF Radiation Exposure Statement: FCC RF Radiation
Exposure Statement: This equipment complies with FCC RF
Radiation exposure limits set forth for an uncontrolled
environment. This device and its antenna must not be co-
located or operating in conjunction with any other
antenna or transmitter.
Industry Canada
Operation is subject to the following two conditions: (1) This
device may not cause interference and (2) this device must
accept any interference, including interference that may
cause undesired operation of the device. The term “IC:”
before the certification/registration number only signifies
that registration was performed based on a Declaration of
Conformity indicating that Industry Canada technical
specifications were met. It does not imply that Industry
Canada approved the equipment.
Le présent appareil est conforme aux CNR d'Industrie
Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible
d'en compromettre le fonctionnement.
Industry Canada RF Radiation Exposure Statement
This equipment complies with Industry Canada RF Radiation
exposure limits set forth for an uncontrolled environment.
This device and its antenna must not be co-located or
operating in conjunction with any other antenna or
transmitter.
RF de l'Industrie Canada d'exposition aux radiations: Cet
équipement est conforme à l'exposition de l'Industrie
Canada rayonnements RF limites établies pour un
environnement non contrôlé. L’antenne pour ce
transmetteur ne doit pas être meme endroit avec d’autres
émetteurs sauf conformément à l'Industrie Canada
procedures de produits Multi-émetteur.

Navigation menu
