Users Manual

Printed in Korea

Code No. : GH68-xxxxxA

English. 10/2000. Rev. 1.0

ELECTRONICS

World Wide Web

http://www.samsungmobile.com

TDMA MOBILE

TELEPHONE

STH-N270

Draft Version

Contents

Important Safety Precautions . . . . . . . . . . . . . . . . . . . 5

Unpacking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Phone Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Service Light . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Getting Started . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Installing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Charging a Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

Switching the Phone On/Off . . . . . . . . . . . . . . . . . . . . . . . 18

Locking Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

General Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Making a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Answering a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22

Viewing Missed Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Quick-switching to Silent Mode . . . . . . . . . . . . . . . . . . . . . . 25

Recording a Voice Memo . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Selecting Functions and Options . . . . . . . . . . . . . . . . 28

Example: Setting the Display Language . . . . . . . . . . . . . . 30

Phonebook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32

Storing a Phone Number with a Name . . . . . . . . . . . . . . 32

Speed Dialing by Memory Location . . . . . . . . . . . . . . . . . 34

Phonebook Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Searching for and Dialing a Number in the Phonebook . . . 37

Name Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

FCC RF EXPOSURE INFORMATION

In August 1996 the Federal Communications Commission (FCC) of the

United States with its action in Report and Order FCC 96-326 adopted an

updated safety standard for human exposure to radio frequency

electromagnetic energy emitted by FCC regulated transmitters.

Those guidelines are consistent with the safety standard previously set by

both U.S. and international standards bodies. The design of this phone

complies with the FCC guidelines and these international standards.

Use only the supplied or an approved antenna. Unauthorized antennas,

modifications, or attachments could impair call quality, damage the

phone, or result in violation of FCC regulations.

Do not use the phone with a damaged antenna. If a damaged antenna

comes into contact with the skin, a minor burn may result. Please contact

your local dealer for replacement antenna.

Body-worn Operation

This device was tested for typical body-worn operations using the

optional belt-clip/holster placed 0.7 inches (1.8cm) from the body.

To comply with FCC RF exposure requirements, a minimum separation

distance of 0.7 inches (1.8cm) must be maintained between the user’s

body and the phone, including the antenna, whether extended or retract-

ed. The use of third-party belt-clips/ holsters with no metallic components

that provide the minimum separation distance of 0.7 inches (1.8cm) can

be used to satisfy FCC RF exposure requirements. The use of non-tested

accessories or other body-worn operations may not comply with FCC RF

exposure requirements and should be avoided. Contact your local dealer

for optional accessory items.

Vehicle Mounted External Antenna (optional, if available.)

A minimum separation distance of 7.9 inches (20cm) must be maintained

Between a person and the vehicle mounted external antenna to satisfy

FCC RF exposure requirements.

For more information about RF exposure, please visit the FCC website at

www.fcc.gov

In-Call Options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Putting a Call on Hold . . . . . . . . . . . . . . . . . . . . . . . . . . . 41

Switching the Microphone Off (Mute) . . . . . . . . . . . . . . . 42

Muting/Sending Key Tones . . . . . . . . . . . . . . . . . . . . . . . 43

Searching for a Number in the Phonebook . . . . . . . . . . . . 43

Using the SMS Service . . . . . . . . . . . . . . . . . . . . . . . . . . 44

Answering a Second Call . . . . . . . . . . . . . . . . . . . . . . . . . 44

Making a Conference Call . . . . . . . . . . . . . . . . . . . . . . . . 45

Using the Menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Accessing a Menu Function by scrolling . . . . . . . . . . . . . 46

Accessing a Menu Function by Using its Shortcut . . . . . . 47

List of Menu Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Call Records . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Missed Calls (Menu 1.1) . . . . . . . . . . . . . . . . . . . . . . . . . . 52

Received Calls (Menu 1.2) . . . . . . . . . . . . . . . . . . . . . . . . 52

Dialed Calls (Menu 1.3) . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Call Time (Menu 1.4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53

Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Voice Mail (Menu 2.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . 54

Read Messages (Menu 2.2) . . . . . . . . . . . . . . . . . . . . . . . 55

Write Messages (Menu 2.3) . . . . . . . . . . . . . . . . . . . . . . . 57

Preset Message List (Menu 2.4) . . . . . . . . . . . . . . . . . . . . 58

Setup (Menu 2.5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58

Sound Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Ring Volume (Menu 3.1) . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Ring Tone (Menu 3.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60

Alert Type (Menu 3.3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Keypad Tone (Menu 3.4) . . . . . . . . . . . . . . . . . . . . . . . . . . 61

Message Tone (Menu 3.5) . . . . . . . . . . . . . . . . . . . . . . . . 62

Error Tone (Menu 3.6) . . . . . . . . . . . . . . . . . . . . . . . . . . . 62

Sound Settings (continued)

Minute Minder (Menu 3.7) . . . . . . . . . . . . . . . . . . . . . . . . 63

Connect Tone (Menu 3.8) . . . . . . . . . . . . . . . . . . . . . . . . . 63

Melody Composer (Menu 3.9) . . . . . . . . . . . . . . . . . . . . . 63

Phone Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66

Infrared Activate (Menu 4.1) . . . . . . . . . . . . . . . . . . . . . . 66

Greeting Message (Menu 4.2) . . . . . . . . . . . . . . . . . . . . . 67

Calling Card (Menu 4.3) . . . . . . . . . . . . . . . . . . . . . . . . . . 67

Backlight (Menu 4.4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70

Service Light (Menu 4.5) . . . . . . . . . . . . . . . . . . . . . . . . . 70

Auto Redial (Menu 4.6) . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Active Flip (Menu 4.7) . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Contrast (Menu 4.8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Slide Menu (Menu 4.9) . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Language (Menu 4.10) . . . . . . . . . . . . . . . . . . . . . . . . . . . 72

Reset Settings (Menu 4.11) . . . . . . . . . . . . . . . . . . . . . . . 72

Organizer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Calendar (Menu 5.1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

To Do List (Menu 5.2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Time & Date (Menu 5.3) . . . . . . . . . . . . . . . . . . . . . . . . . . 77

Alarm (Menu 5.4) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79

Calculator (Menu 5.5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

Security . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81

Change Lock code (Menu 6.1) . . . . . . . . . . . . . . . . . . . . . 81

Change Security code (Menu 6.2) . . . . . . . . . . . . . . . . . . 81

Call Restriction (Menu 6.3) . . . . . . . . . . . . . . . . . . . . . . . . 82

SOS Call List (Menu 6.4) . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Important Safety Precautions

Read these simple guidelines. Failure to comply with

them may be dangerous or illegal.

For more detailed safety information, see Safety

Information on page 96.

Road safety comes first

Do not use a hand-held phone while driving; park the

vehicle first. Remember that in some countries, it is

illegal to use a hand-held phone while driving.

Switch off when refueling

Do not use the phone at a refueling point (service station)

or near fuels or chemicals.

Switch off in aircraft

Mobile phones can cause interference. Using them on

aircraft is both illegal and dangerous.

Respect special regulations

Follow any special regulations in force in any area and

always switch off your phone whenever it is forbidden to

use it, or when it may cause interference or danger (in a

hospital for example).

Interference

All mobile phones may be subject to radio interference,

which may affect their performance.

Network Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84

Call Diverting (Menu 7.1) . . . . . . . . . . . . . . . . . . . . . . . . . 84

Call Waiting (Menu 7.2) . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Network Selection (Menu 7.3) . . . . . . . . . . . . . . . . . . . . . 85

Voice Privacy (Menu 7.4) . . . . . . . . . . . . . . . . . . . . . . . . . 87

Send ID(Menu 7.5) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

NAM Selection(Menu 7.6) . . . . . . . . . . . . . . . . . . . . . . . . 89

Set Service Code(Menu 7.7) . . . . . . . . . . . . . . . . . . . . . . . 89

Games . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90

Solving Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92

Using the Batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94

Precautions When Using Batteries . . . . . . . . . . . . . . . . . 94

Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Road Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Operating Environment . . . . . . . . . . . . . . . . . . . . . . . . . . 96

Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . 98

Emergency Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99

Glossary of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103

Quick Reference Card . . . . . . . . . . . . . . . . . . . . . . . . . 107

In addition, you can obtain the following accessories for

your phone from your local SAMSUNG dealer:

• Desktop charger

• Hands-free kit

• Standard battery

• Cigarette lighter adapter

• Earphone

• Leather case

Travel Charger

Handset

User’s Manual

Qualified service

Only qualified service personnel should repair cellular

equipment. Use only approved accessories and batteries.

Use sensibly

Use only in the normal position (held to the ear).

Avoid unnecessary contact with the antenna when the

phone is switched on.

Emergency calls

Ensure the phone is switched on and in service.

Enter the emergency number (112 or other official

emergency number) and press the key. Give your

location. Do not end the call until given permission to do

so. End the call by closing the flip cover or pressing the

key.

IMPORTANT! Use only SAMSUNG-approved

accessories.

The use of any other power accessory will invalidate any

approval or warranty applying to the phone, and may be

dangerous.

When you disconnect the power cord of any accessory,

grasp and pull the connector, not the cord.

Unpacking

Your package contains the following items.

Battery Hand Strap

Key Description

Perform the functions indicated by the text

above them (in the bottom line of the display).

In the menu facility, scroll through the menu

options and phonebook memory.

When held down in idle mode, enters the Read

Message menu (2.2).

Deletes characters from the display.

In the menu facility, returns to the previous

menu level.

When held down for more than two seconds in

idle mode, quickly enters or exit the Silent

mode.

Makes or answers a call.

In idle mode, recalls the last number dialed.

In the menu facility, selects a menu function or

stores information that you have entered (such

as a name) in the phone.

Ends a call. Also switches the phone on and off

when pressed and held.

In the menu facility, returns to the idle mode

and cancels your input.

YYoouurr PPhhoonnee

Earpiece

Service light

Soft key (left)

Volume/menu

browse keys

Navigation key

Display

Soft key (right)

Cancel/

correction key

Power on/off key

Alphanumeric

keys

Special function

keys

Dial/menu

confirmation key

Earphone jack

Microphone

Antenna

Infrared port

(see page 66)

(soft keys)

Your Phone

Phone Layout

The following illustrations show the main elements of

your phone.

Flip cover

Voice Memo key

Display

Display Layout

The display comprises three areas.

Area Description

First line Displays various icons (see page 12).

Middle lines Display messages, instructions and

any information that you enter (number to

be dialed, for example).

Last line Shows the functions currently assigned to

the two soft keys.

YYoouurr PPhhoonneeYYoouurr PPhhoonnee

Key Description

Enter numbers, letters and some special

characters.

Enter special dial characters. Also use these

keys for various purposes in different functions.

(on the side of the phone)

In idle mode, records a voice memo when

pressed and held down.

(on the side of the phone)

During a call, adjust the earpiece volume.

In idle mode with the flip cover open, adjust the

key volume.

In the menu facility, scroll through the menu

options and phonebook memory.

WXYZ

Icons

Text and

graphic area

Soft key indications

Menu Name

YYoouurr PPhhoonnee

Icons

Icon Description

Shows the received signal strength. The greater

the number of bars, the better the signal strength.

Appears when a call is in progress.

Appears when you are out of service area.

Appears when you are out of your home area

and have registered with a different network

(when travelling in other cities and countries,

for example).

Appears when a new text message has been

received.

Appears when the phone is in digital mode.

Appears when the silent mode is active.

Shows the level of your battery. The more bars

you see, the more power you have left.

Indicates that you have activated the Infrared

feature to communicate with an IrDA-compliant

device to send or receive data/fax (for further

details, see page 66).

Appears when a new voice mail message has

been received.

Appears when you set the mute mode.

Backlight

The display is illuminated by a backlight. When you press

any key, the backlight illuminates. It turns off if no key is

pressed within a given period of time, depending on the

Backlight option set in the Phone Settings menu.

To specify the length of time for which the backlight is

active, set the Backlight menu option (4.4); see page 70

for further details.

Service Light

The service light is in the top right-hand corner of the

phone. It flashes when services are available on the

phone.

To activate or deactivate use of the service light, set the

Service Light menu option (4.5); see page 70 for further

details.

Service light

YYoouurr PPhhoonnee

14 15

GGeettttiinngg SSttaarrtteedd

Getting Started

Installing the Battery

To Install the Battery

1. Place the battery on the back of the phone with the

top of the battery about a quarter of an inch from

the catch so that the battery engages with the

slots molded into the body.

2. With the catch pressed and held down, push the

battery toward the top of the phone until it snaps

into place.

To Remove the Battery

1. If necessary, switch off the phone by holding

down the key until the the power off graphic

begins to play.

2. Remove the battery. To do so:

➀Push and hold down the catch above the

battery on the back of the phone and

➁slide the battery down and lift it away.

➀

➁

Catch

16 17

GGeettttiinngg SSttaarrtteeddGGeettttiinngg SSttaarrtteedd

Charging a Battery

Your phone is powered by a rechargeable Li-Ion

battery. A travel charger is provided with your phone.

Use only approved batteries and chargers. Ask your

local SAMSUNG dealer for further details.

The phone can be used while the battery is charging.

Note: You must fully charge the battery before using

your phone for the first time. A discharged

battery is fully recharged in approximately

200 minutes.

Charging a Battery by a Travel Charger

1. With the battery in position on the phone, connect

the lead from the travel charger to the jack on the

bottom of the phone.

2. Connect the charger to a standard AC wall outlet.

3. When charging is finished, disconnect the charger

from the power outlet and remove it from the

phone by squeezing the two tabs on the lead (➀)

and unplug the lead(➁).

Low Battery Indicator

When the battery is weak and only a few minutes of

talk time remain, you will hear a warning tone and a

message will be repeated at regular intervals on the

display:

When the battery becomes too weak for the phone

to operate, it switches off automatically.

**Warning**

Low Battery

➀

➁

18 19

GGeettttiinngg SSttaarrtteeddGGeettttiinngg SSttaarrtteedd

Switching the Phone On/Off

1. Open the flip cover.

2. Hold down the key for more than one second

to switch the phone on.

3. The phone searches for your network and when

it finds it, the idle screen, illustrated below, is

displayed.

Note: The display language is factory set to English.

To change the language, use the Language

menu option (4.10); for further details, refer to

page 72.

When you wish to switch the phone off, hold down

the key for more than two seconds.

Sat 14 Mar 12:57

Menu Name

Locking Your Phone

You can lock your phone to protect the phone against

unauthorized use. When the phone is locked, you

cannot operate the phone until you enter the lock

code.

To lock your phone:

Press and hold down the key for more than two

seconds. “Phone Locked” appears on the idle screen.

To unlock the phone:

Press the Unlock soft key and enter the lock code,

then press the OK soft key. Your phone’s lock code is

preset at the factory to 00000000. For further details

on the lock code, see page 81.

Even when the phone is locked, you can place an

SOS call to one of the emergency numbers stored in

the SOS Call List (6.4). See page 83 for further

details.

To place an SOS call, press the SOS soft key, select

the desired emergency number using the key

and press the Yes soft key.

Sat 14 Mar 12:57

Phone Locked

Unlock SOS

20 21

GGeenneerraall FFuunnccttiioonnss

Making a Call from the Phonebook

You can store the names and phone numbers called

regularly in the phone memory, called the phonebook.

You then simply select the required name to recall

the associated number. For further details on the

Phonebook feature, refer to page 32.

Redialing the Last Number

The phone stores the last 10 numbers dialed. To

recall any of these numbers, proceed as follows.

1. If you have typed any characters on the display,

clear the display by holding down the Ckey for

more than one second.

Press the key to display the last number dialed.

3. Use the key to scroll through the numbers

until the required number is displayed.

4. To... Then...

Dial the number Press the key.

displayed

Edit the number • Press the Edit soft key.

displayed •

Change the number as

required, referring to

Correcting the Number for

further details (see

opposite).

General Functions

Making a Call

When the idle screen is displayed, key in the area

code and phone number and press the key.

Note:

If you have set the Auto Redial menu option (4.6)

to ON (see page 71) and the person called does

not answer or is already on the phone, the

number is redialed automatically up to ten times.

If the network answers the call after ten rings,

the phone does not redial.

Making International Calls

1. Press and hold down the 0key.

The + character appears.

2. Key in the country code, area code and phone

number and press the key.

Correcting the Number

To clear... Then...

The last digit Press the Ckey.

displayed

The whole display Hold down the Ckey for more

than one second.

Ending a Call

When you have finished your call, briefly press the

key.

If the caller can be identified, the caller’s phone

number (or name if stored in your phonebook) is

displayed. If the caller cannot be identified, only the

phone animation plays

1. If necessary, open the phone. Press the key or

the Accept soft key to answer the incoming call.

Notes:

• To reject an incoming call, press the Reject soft

key.

• If the Active Flip menu option (4.7) is set to

Enable, you do not need to press any key.

You can answer the call simply by opening the

phone (see page 71).

2. End the call by closing the phone or pressing the

key.

Note: You can answer a call while using the

phonebook or menu features.

Viewing Missed Calls

If you are unable to answer a call for any reason, you

can find out who was calling you, provided that this

service is available. In this way, you can call the

person back, if necessary.

The number of missed calls is displayed on the idle

screen immediately after the call was missed.

To view the missed call immediately, proceed as

follows.

1. If the phone is closed, open the flip cover.

22 23

GGeenneerraall FFuunnccttiioonnssGGeenneerraall FFuunnccttiioonnss

Adjusting the Volume

During a call, if you want to adjust the earpiece

volume, use the „and keys on the left side of

the phone. Press „to increase and to decrease

the volume.

Answering a Call

When somebody calls you, the phone rings and the

phone animation plays in the middle of the screen.

In idle mode with the phone open, you can adjust the

key volume using the „and keys .

Caller’s name or

number

nnnnn

(( ))

Accept Reject

24 25

GGeenneerraall FFuunnccttiioonnssGGeenneerraall FFuunnccttiioonnss

Deleting a Missed Call

1. Press the Options soft key.

2. If necessary, press the key to highlight the

Delete option.

3. Press the Select soft key.

You can press the key at any time to exit the

Missed Call feature.

Note: You can access the Missed Call feature at

any time by selecting the Missed Calls menu

option (1.1); for further details, see page 52.

Quick-switching to Silent Mode

You can quickly switch your phone to silent mode

with a touch of a key. Press and hold the Ckey until

the icon and Silent Mode appears in display.

Your phone goes to silent mode immediately.

In silent mode, your phone switches the sound

settings as following:

alert type vibration

keypad tone off

message tone light only

error tone off

Press and hold the Ckey again to exit silent mode.

This feature is convenient when you are in a hurry to

mute the phone sound, such as when in a theater.

2. Press the View soft key.

The number corresponding to the most recent

missed call is displayed, if available.

3. To... Then press the...

Scroll through the key.

missed calls

Call the number displayed key.

Edit or delete a missed Options soft key

call number (see opposite).

Editing a Missed Call Number

Note: If the number corresponding to the missed

call is not available, the Edit option is not

displayed.

1. Press the Options soft key.

2. If necessary, press the key to highlight the

Edit Number option.

3. Press the Select soft key.

4. Change the number as required.

5. To... Then press the...

Call the number key.

Store the number Save soft key and enter

the name and location

required (for further

details, refer to page 32).

GGeenneerraall FFuunnccttiioonnss

Recording a Voice Memo (???)

Your phone can record up to 5 voice memos. Each

voice memo can be up to one minute in length.

When recording, a 60-second timer displays and an

alert sounds to indicate when recording time expires.

To Record a Voice Memo

To record a voice memo, press and hold the key

on the left side of the phone. The message

“Recording” displays, along with the timer.

To stop recording, press the key again.

The following options for the current voice memo

becomes available:

Add Label: allows you to add a label for the memo

you have just recorded. Enter a proper name up to 12

digits using the keypad. If you do not add a label, the

recorded date and time will be used to identify the

memo. If you make a call and record the

conversation, the phone number is saved as the label

when you do not add a label. If you record the

conversation which is held by someone’s calling and

do not enter a label, No Label is saved as the label.

Continue: allows you to continue recording the

memo.

Erase: allows you to erase the memo you have just

recorded.

To Review a Voice Memo

To review the voice memo you recorded, press the

key on the left side of the phone in idle mode.

Your phone plays back all memos recorded, starting

with the latest memo. The screen displays the label

if you have entered one. If not, the screen displays

the date and time when the memo was recorded, the

phone number or No Label. For more details, see

‘Add Label’ above. While the memos display, the

following options are available.

Replay: plays the current memo once again.

Erase: erases the memo currently being played.

Next Memo: skips to the next memo.

Prev Memo: skips to the previous memo.

To view the various functions/options available and

select the one required, proceed as follows.

1. Press the appropriate soft key.

2. To... Then press the...

Select the: Select soft key.

• Function displayed

• Option highlighted

View the next function key or key on

or highlight the next the left side of the

option in a list phone.

Move back to the „key on previous

function or the left side of the

option in a list phone.

Move back up one soft key or C key.

level in the structure

Exit the structure key.

without changing

the settings

In some functions, you may be asked for a lock code

or security code. Enter the required code and press

the OK soft key.

Note: When you access a list of options, your phone

highlights the current option. If, however, there

are only two options, such as On/Off or

Enable/Disable, your phone highlights the

option that is not currently active, so that you

can select it directly.

28 29

SSeelleeccttiinngg FFuunnccttiioonnss aanndd OOppttiioonnss

Selecting Functions

and Options

Your phone offers a set of functions that allow

you to customize your phone. These functions are

arranged in menus and sub-menus, accessed via the

two soft keys marked . Each menu and sub-menu

allows you to view and alter the settings of a

particular function.

The roles of the soft keys vary according to the

current context; the label on the bottom line of the

display just above each key indicates its current role.

Example:

Press the left soft

key to save the

name entered.

Press the right soft key

to switch between upper

case, lower case and

numeric characters.

Enter Name

Infrared

Activate

Select 4. 1

Phone Settings

Select 4

30 31

SSeelleeccttiinngg FFuunnccttiioonnss aanndd OOppttiioonnssSSeelleeccttiinngg FFuunnccttiioonnss aanndd OOppttiioonnss

Example: Setting the Display Language

1. When the idle screen is displayed, press the

Menu soft key to enter the menu facility.

Fri 15 May 10:30

Menu Name

2. Scroll through the menus until you reach the

Phone Settings menu, by pressing the key.

4. Scroll through the sub-menus until you reach the

Language sub-menu, by pressing the key.

5. To view the languages available, press the

Select soft key. The current setting is

highlighted.

6. Scroll through the list of languages until the

appropriate one is highlighted, by pressing the

key.

7. Press the Select soft key to confirm your

selection.

8. Press the Cor soft key twice to exit the menu

structure.

3. To select the Phone Settings menu, press the

Select soft key.

Current

language

Language

English

Select 4.10

Current

language

Français

Español

Select 4.10.1

English

6. Enter your preferred location by pressing the

number keys.

7. Press OK to store the name and number.

8. Press the key to return to the idle screen.

If you want to make a call to the number, press

the Call soft key. And if you want to access the

Phonebook options, press the Options soft key.

Entering a Name

1. To select... Then press the

soft key until...

Upper case characters is displayed.

Lower case characters is displayed.

Numbers only is displayed.

2. Press the key labeled with the required letter:

• Once for the first letter

• Twice for the second letter

• And so on

32 33

PPhhoonneebbooookk

Phonebook

The Phonebook allows you to store frequently used

phone numbers and the associated names in your

phone to make it easy for you to make a call without

having to remember or enter the phone number. You

can store up to 250 (1 ~ 250) numbers.

Storing a Phone Number with a Name

As soon as you start to enter a number, Save appears

above the left soft key to allow you to store the

number in the phonebook.

1. Key in the number to be stored.

Note: If you make a mistake while entering a

number, correct it using the Ckey. For

further details, refer to page 20.

2. When you are sure that it is correct, press the

Save soft key.

3. Select a label by pressing the key, and press

the Save soft key.

The available labels are: Home, Office, Mobile,

Pager, Fax and No type.

4. Enter the corresponding name. For information on

how to enter a name, see opposite.

5. When you are satisfied, press the OK soft key.

The phone now prompts you to select a location in

the phone memory for you to save the number and

name.

Key

.1!?&i¿§

ABC2ÄÅÆÇΓ

DEF3É∆Φ

GHI 4ΘΨ

JKL5Λ

MNO6ÑØÖö

PQRS7ΠΣ Ξ

TUV8Üü

WXYZ9Ω

0,:;‘“/=

%@ £$¥¤§

abc2àäåæΓ

def3èéΦ

ghi 4ì Ψ

jkl5Λ

mno6ñøòö

pqrs7ßΣΞ

†uv8ùü

wx y z 9 Ω

-+()*#<>

Characters in the Order Displayed

Upper Case Lower Case

Space Space

34 35

PPhhoonneebbooookkPPhhoonneebbooookk

3. Select the other letters in the same way.

Note: The cursor moves to the right when you

press a different key. When entering the

same letter twice (or a different letter on

the same key), just wait for a few seconds

for the cursor to move right automatically,

and then select the next letter.

Speed Dialing by Memory Location

Once you have stored phone numbers in the phone

book memory, you can dial easily whenever you

want.

To speed dial the desired number:

For the 1-digit memory location number (1 through 9),

press and hold down the appropriate digit.

For the 2 or more-digit memory location number (10

through 250), press first digit(s) briefly and hold

down the last digit.

Note: If you enter the location number, then press

the key, your phone displays the details on

the entry, such as name, number, location

number and label. If you have stored more

than one number for a name, scroll through

the entry by pressing the key repeatedly.

Phonebook Options

When storing or viewing a number in the phonebook,

Options appears above the left soft key to allow you

to access the phonebook options, described in the

following paragraphs.

Accessing the Options

To access the various phonebook options, proceed as

follows.

1. Press the Options soft key. The first available

option is highlighted.

2. To... Then press the...

Select the Select soft key.

highlighted option

Highlight a key one or more

different option times until the required

option is highlighted.

Add Number

This option allows you to place more than one

number in one Phonebook location labeling each of

the numbers. Note that you can only use each label

one time for each stored name. For example, you can

only have one number labeled Work for a name entry.

New Name

This option allows you to store a phone number with

a new name. For information on storing a number,

see page 32.

Change Name

This option allows you to change the name for the

number. Clear the old name pressing the Ckey and

enter a new name. For information on entering a

name, see page 33.

Change Number

This option allow you to change the number. Clear

the old number by pressing the C key and enter a

new number.

Change Type

This option allows you to change the label type of a

stored number. Note that you can only use each label

one time for each stored name. For example, you can

only have one number labeled Work for a name entry.

Erase Number

This option allows you to erase a stored number. If

you saved two numbers in a name, only the currently

selected number will be erased. You are asked to

confirm that you wish to erase the number by

pressing the OK soft key.

Erase Name

This option allows you to erase a name stored in the

phonebook so that all numbers in the name is

erased. You are asked to confirm that you wish to

erase the name by pressing the OK soft key.

Move

This option allows you to move a phonebook number

to another location. When prompted, enter the

location number which you are moving the number to,

and press the OK soft key.

Caller Group

This option allows you to set the number as a

member of the caller group. For more details on

Caller Group, see page 39.

Set Key Number

This option allows you to set the selected number as

a speed dial number for the entry if it has more than

one number.

Searching for and Dialing a Number in

the Phonebook

1. When the idle screen is displayed, press the

Name soft key. You are asked to enter a name.

2. Enter the start of the name that you want to find

and press the Search soft key.

Note: You can also scroll through the phonebook

from the beginning by pressing the Search

soft key directly.

The phonebook entries are listed, starting with

the first entry matching your input. This entry is

also highlighted.

36 37

PPhhoonneebbooookkPPhhoonneebbooookk

PPhhoonneebbooookk

3. To... Then press the...

View the View soft key.

highlighted entry

Select a key one or more

different entry times until the required

entry is highlighted.

Look for a name Key labeled with the

starting with a required letter.

different letter

4. Once you have found the required entry, press the

key to dial the number.

Name Options

While entering a name for searching, you can see

the Option soft key with the Search soft key. This

key allows you to enter the various options. See next

page for details on each of the options.

Accessing the Options

To access the various phonebook options, proceed as

follows.

1. Press the Options soft key. The first available

option is highlighted.

2. To... Then press the...

Select the Select soft key.

highlighted option

Highlight a key one or more

different option times until the required

option is highlighted.

New Name

This option allows you to create a new entry in the

Phonebook. For details on storing a phone number,

see page 32.

Caller Group

You can set the phone to ring in a specific way and

display a preselected graphic icon when a particular

person calls you. To do so, you must:

• Define your caller groups

• Assign the numbers in the phonebook to the

appropriate group

Defining a caller group

Select the group to be defined and set the

appropriate options. The following options are

available.

Call ring tone: allows you to select the ring tone to

be used when you receive a voice phone call from a

person in the group.

SMS tone: allows you to select the ring tone to be

used when you receive a text message from a person

in the group.

Graphic: allows you to select the graphic icon to be

displayed when you receive a call from a person in

the group.

Group Name: allows you to assign a name to the

group; for further details on how to enter characters,

refer to page 33.

4140

PPhhoonneebbooookk

Assigning numbers to a group

1. View the required number in the phonebook.

2. Press the Options soft key.

3. Select the Caller Group option.

4. Select the required group.

To remove a number from a group, select the No

Group option.

Own Number

This feature allows you to:

• Assign a name to your own phone number

• Edit the names and numbers

This function is a memory aid, which you can use to

check your own phone number if you need to do so.

To save your own phone number:

1. Press the View, then Edit soft key.

2. Enter the name you desire, then press OK soft key.

For details on entering a name, see page 33.

3. Enter your phone number, then press OK soft key.

Memory Status

You can check how many names and numbers are

stored in the Phonebook .

Erase All

This option allows you to erase all of the Phonebook

entries.

When a confirmation appears, press the Yes soft key

to erase all Phonebook entries. If you do not want to

erase, press the Cancel soft key.

In-Call Options

Your phone provides a number of control functions

that you can use during a call.

Putting a Call on Hold

You can make another call while you have a call in

progress if this service is supported by the network.

Of these two calls, one is active and the other is on

hold and you can swap between the calls.

To make a call while you have a call in progress,

proceed as follows.

1. Key in the phone number that you wish to dial or

look it up in the phonebook.

2. Press the key to dial the second call.

The first call is automatically put on hold.

To swap between the two calls, simply press the

Swap soft key.

When you have finished, end each call normally by

pressing the key.

42 43

IInn--CCaallll OOppttiioonnss

Switching the Microphone Off (Mute)

You can temporarily switch your phone’s microphone

off, so that the other party cannot hear you.

Example: You wish to say something to another

person in the room but do not want the

other party to hear you.

To switch the microphone off temporarily, proceed as

follows.

1. Press the Options soft key.

2. If necessary, press the key to highlight the

Mute option.

3. Press the OK soft key.

Your correspondent can no longer hear you.

To switch the microphone back on, proceed as

follows.

1. Press the Options soft key.

2. If necessary, press the key to highlight the

Unmute option.

3. Press the OK soft key.

Your correspondent can hear you again.

Muting/Sending Key Tones

These options allow you to turn the key tones off or

on. If the Mute keys option is selected, your phone

does not transmit the key tones. It allows you to press

keys without hearing annoying key tones during a call.

Note: To communicate with answering machines or

computerized telephony systems, the Send

keys option must be selected.

Searching for a Number in the Phonebook

You can search for a number in the phonebook during

a call.

1. Press the Options soft key.

2. Press the key to highlight the Phonebook

option.

3. Press the OK soft key.

The phonebook entries are listed.

4. Enter the name that you wish to find.

If you enter the start of the name, the phonebook

entries are listed, starting with the first entry

matching your input. The entry is also highlighted.

5. To view the highlighted entry, press the View soft

key.

For a more detailed description of the Phonebook

feature, refer to page 32.

Making a Conference Call

You can conduct conference calls with two separate

parties at the same time. A conference call is a

network service. For more information, contact your

service provider.

Setting up the Conference Call

1. Call the first participant in the normal way.

2. Press the Options soft key and select the Join

option. Then, call the second participant by the

normal way.

3. When the second person answer, press the

key to merge the calls.

Note: The first call remains held until you press

the key

4. End the conference call by closing the phone or

pressing the

key

44 45

PPhhoonneeBBooookkPPhhoonneeBBooookkIInn--CCaallll OOppttiioonnssIInn--CCaallll OOppttiioonnss

Using the SMS Service

If you receive an SMS (Short Message Service)

message during a call, the message icon ( )

flashes in the display. The SMS Service option

enables you to use this feature.

Read Messages: allows you to read the messages

that you have received.

Write Messages: allows you to write a message.

For further details on the SMS service, refer to

page 54.

Answering a Second Call

You can answer an incoming call while you have a

call in progress, if this service is supported by the

network and you have set the Call Waiting menu

option (7.2) to Activate (see page 85). You will be

notified of an incoming call by a call waiting tone.

To answer a call while you have a call in progress,

proceed as follows.

1. Press the key to answer the incoming call.

The first call is automatically put on hold.

2. To switch between the two calls, press the Swap

soft key.

To end a held call, press the Options soft key and

select the End Held Call option.

3. To end the current call, press the key.

Accessing a Menu Function by Using its

Shortcut

The menu items (menu, submenus and setting

options) are numbered and can be accessed quickly

by using their shortcut number. The shortcut number

is shown in the right-bottom next to the soft key

on the display..

1. In idle mode, press the Menu soft key.

2. Within three seconds, key in the first digit of the

shortcut number. Repeat this for each digit of the

shortcut number.

Example: Setting the Backlight option to Short

Press the Menu soft key, and key in 4, 4, 2.

Menu for entering the menu, 4for Phone

Settings, 4for Backlight, 2 for Short .

Note: The numbers assigned to each menu function

are indicated on the list on page 48. They may

not match the menu number on the phone.

46 47

Using the Menus

The phone offers a range of functions that allows

you to tailor the phone to your needs. These

functions are arranged in menus and submenus.

The menus and submenus can be accessed by

scrolling or by using the shortcuts.

Accessing a Menu Function by Scrolling

1. In idle mode, press the Menu soft key to access

the menu facility. Scroll with the key (or the

or „keys on the left side of the phone) to

reach the desired main menu, e.g. Phone

Settings. Press the Select soft key to enter the

menu.

2. If the menu contains any submenus: for example,

Backlight, find the one you want by scrolling

with the key (or the or „keys on the left

side of the phone). Press the Select soft key to

enter the submenu.

If the menu you selected has submenus, repeat

this step.

3. Scroll with the key (or the or „keys on

the left side of the phone) to find the setting of

your choice. Press the OK soft key to confirm the

chosen setting.

Notes:

• You can return the previous menu level by pressing

the Ckey.

• You can exit the menu without changing the menu

settings by pressing the key.

UUssiinngg tthhee MMeennuuss

Shortcut number

Backlight

Short

Select 4.4

48 49

PPhhoonneeBBooookkUUssiinngg tthhee MMeennuussUUssiinngg tthhee MMeennuuss

List of Menu Functions

The following illustration shows the menu structure

available and indicates the:

• Number assigned to each option

• Page on which you can find a description of each

feature

1.1 Missed Calls

1.2 Received Calls

1.3 Dialed Calls

1.4 Call Time

1.4.1 Last Call Time

1.4.2 Total Call Time

1.4.3 Reset Timers

1. Call Records

Page 52

2. Messages

2.1 Voice Mail

2.1.1 Connect to

Voice Server

2.1.2 Voice Server

Number

2.2 Read Messages

2.2.1 New Inbox

2.2.2 Old Inbox

2.2.3 Outbox

2.3 Write Messages

2.4 Preset Message List

2.5 Setup

Page 54

3. Sound Settings

3.1 Ring Volume

3.2 Ring Tone

3.3 Alert Type

3.4 Keypad Tone

3.5 Message Tone

3.6 Error Tone

3.7 Minute Minder

3.8 Connect Tone

3.9 Melody Composer

4. Phone Settings

4.1 Infrared Activate

4.2 Greeting Message

4.3 Calling Card

4.4 Backlight

4.5 Service Light

4.6 Auto Redial

4.7 Active Flip

4.8 Contrast

4.9 Slide Menu

4.0 Language

4. Reset Settings

Page 60

Page 66

50 51

UUssiinngg tthhee MMeennuussUUssiinngg tthhee MMeennuuss

5. Organizer

6. Security

6.1 Change Lock code

6.2 Change Security code

6.3 Call Restriction

6.3.1 restrict all

outgoing call

6.3.2 restrict all

incoming call

6.3.3 restrict

outgoing call

6.4 SOS Call List

5.1 Calendar

5.2 To Do List

5.3 Time & Date

5.3.1 Set Time

5.3.2 Set Date

5.3.3 World Time

5.3.4 Format

5.4 Alarm

5.4.1 Once Alarm

5.4.2 Daily Alarm

5.4.3 Weekly Alarm

5.4.4 Remove Alarm

5.4.5 Autopower

5.5 Calculator

Page 73

Page 81

7. Network Services

7.1 Call Diverting

7.1.1 Divert Always

7.1.2 Busy

7.1.3 No Reply

7.1.4 Unreachable

7.1.5 Cancel All

7.2 Call Waiting

7.3 Network Selection

7.3.1 Automatic

7.3.2 Manual

7.3.3 New Search

7.4 Voice Privacy

7.5 Send ID

7.6 NAM Selection

7.7 Set Service Code

7.7.1 Call Diverting

7.7.2 Call Waiting

8. Games

8.1 Casino

8.2 Roulette

8.3 Black Jack

8.4 Sniper

8.5 Snake

8.6 Mole

8.7 Othello

Page 84

Page 90

Call Records

Via this menu, you can view the phone calls:

• Missed

• Received

• Dialed

The number and name (if available) are given,

together with the date and time at which the call was

made.

Note: Your phone can keep up to ten numbers in

these lists.

Missed Calls Menu 1.1

This option lets you view the last 10 unanswered

calls. You can also:

• Edit the number if available and dial it or save it in

the phonebook

• Delete the number from the list

Received Calls Menu 1.2

This option lets you view the last 10 phone calls

received. You can also:

• Edit the number if available and dial it or save it in

the phonebook

• Delete the number from the list

CCaallll RReeccoorrddss

Dialed Calls Menu 1.3

This option lets you view the last 10 numbers dialed.

You can also:

• Delete the number

• Edit the number and save it in the phonebook

Call Time Menu 1.4

This option lets you view the timers for calls made

and received. The following timers are available.

Last Call Time: length of the last call.

Total Call Time: total length of all calls made from

or received to your phone since the timer was last

reset.

Reset Timers: option used to reset the call timers;

you must first enter the phone’s lock code (see

page 81) and then press the OK soft key.

Note: The actual time invoiced for calls by your

service provider may vary, depending on

network features, rounding-off for billing

purposes and so forth.

5554

Voice Server Number: allows you to change the

voice mail server number.

To... Then press the...

Enter the server number Corresponding numeric

keys.

Correct a digit Ckey.

Save the entered number OK soft key

Note: You can recall the number needed from the

Phonebook memory by pressing the

Phonebook soft key.

Read Messages Menu 2.2

Three message boxes are available:

New Inbox: used to store the messages that you

have received but not read.

Old Inbox: used to store the messages that you have

received and read.

Outbox: used to store the messages that you have

already sent or will send.

Select the required box. The header of the first

message in the box is displayed:

• Message number

• Message status: New, Old, Not Sent, Sent

(If you have set the Delivery Ack menu option to

ON, the report is also shown; see page 63 for

further details.)

•

Date and time at which the message was received

(inbox only)

Messages

The SMS (Short Message Service) function is a

network service and may not be supported by your

network. Messages can be sent by text, E-mail and

paging messaging systems, provided that these

services are supported by your network. To send text

messages by phone, you must obtain the number of

the SMS center from your service provider.

When the icon appears, you have received new

text messages. If the message memory is full, an error

message is displayed and you cannot receive any new

messages. Use the Delete option in the Read

Messages menu (2.2) to delete obsolete messages.

Voice Mail Menu 2.1

This menu provides you with a quick way of accessing

your voice mailbox (if provided by your network).

Note: Voice Mail is a network feature. Please

contact your service provider for more

information.

Connect to Voice Server: Before using this

feature, you must enter the voice server number

obtained from your service provider (see menu

option 2.1.2). You can then select this option and

simply press the OK soft key to listen to your

messages.

Note: You can recall the number needed from the

Phonebook memory by pressing the

Phonebook soft key.

MMeessssaaggeess

Write Messages Menu 2.3

Via this menu, you can write text messages of up to

160 alphanumeric characters. For further information

on how to enter the characters in your message,

refer to page 33.

Note: While writing a message, pressing the key

inserts a carriage return.

After you complete the message and press the OK

key, you can select the following options.

Send Only: Enter the destination and select a

setting group in which you set up default information

on the SMS feature via the Setup menu (see the

following page).

Save and Send: allows you to save a copy of the

message and then send the message to the required

destination. You are also required to select a setting

group. You can read the message in your outbox using

the Read Messages option. Sent is displayed when

you read the message to indicate the message status.

Save Only: allows you to save the message so that

it can be sent later. When you read the message in

your outbox, Not sent is displayed.

To view this message, press the View soft key. The

screen shows the:

• Sender’s phone number (if sent with the message)

or recipient’s phone number

• Message text

To scroll through the message, press the key.

You can choose the following options, by pressing

the Options soft key.

Delete: allows you to delete obsolete messages.

Text Reply: allows you to reply by sending a text

message. You can also change the SMS center

number (if required).

Call Back: allows you to call the sender back.

Cut Number: allows you to extract a number from

the message text, so that you can call the number or

save it in the phonebook.

Send: allows you to send a message that you have

received or saved. You can:

• Send the message

• Save and send the message

• Save but not send the message

Edit Message: allows you to edit a message.

Note: The available options may vary, depending on

the message status (New/Old, Not Sent or

Sent for example).

MMeessssaaggeess

Setting Name: allows you to give a name to the

setting group currently being defined.

Callback Number: allows you to set the phone

number to which the recipient of your SMS message

may send you a reply message via your message

center, if the service is provided by the network.

Manual Ack: allows you to activate or deactivate

the manual acknowledgement function. When this

function is activated, the recipient can send you an

answer to your message by one touch of a number

key.

Delivery Ack: allows you to activate or deactivate

the delivery acknowledgement function. When this

function is activated, the network informs you

whether your message has been read or not by the

recipient.

Privacy: allows you to set the restriction feature.

When this option is set to Restricted, the recipient

must have the password which you have set when

writing a message to see the message. If you do not

want to use the feature, select Not Restricted.

Urgency: allows you to set the urgent status of the

messages. Bulk, Normal, Urgent, and Very Urgent

are available.

Type: allows you to set the type of messages. Text

and E-mail are available.

Preset Message List Menu 2.4

Using this menu, you can preset up to five messages

that you use most frequently. This menu shows the

preset message list. Scroll through the list using the

key. When the required message number

appears, press the Options soft key.

Edit: allows you to write a new message or edit the

selected preset message.

Note: For further information on how to enter the

characters in your message, refer to page 35.

Send Message: allows you to recall the selected

message. Once you have completed the message, you

can send, save and send, or simply save it.

Delete: allows you to delete the selected message.

Setup Menu 2.5

Via this menu, you can set up default information for

the SMS feature. A setting group is a collection of

settings required to send messages. Five setting

groups are available.

Select the desired number using the key, press

the Select soft key and then set up the options for

the group. The available options are:

Service Center: allows you to store or change the

number of your SMS center required when sending

messages. You must obtain this number from your

service provider.

6160

Alert Type Menu 3.3

This option allows you to indicate how you are to be

informed of any incoming calls. The following options

are available.

Light only: only the backlight is switched on; the

phone neither rings nor vibrates.

Melody: the phone rings using the ringing tone

selected via the Ring Tone menu option (3.2).

Vibration: the phone vibrates but does not ring.

Note: In idle mode, you can set the phone to vibrate

only (silent mode) or to start ringing again,

simply by pressing the Ckey (for further

details, see page 20).

Vibra+Melody: the phone first vibrates three times

and then starts ringing.

Keypad Tone Menu 3.4

This option allows you to select the tone that the

keypad generates when you press a key. The

following options are available.

OFF: the keys do not make any sound.

Tone: each key, when pressed, makes a different

sound.

Beep: each key, when pressed, makes the same

sound.

Sound Settings

You can use the Sound Settings feature to customize

various settings, such as the:

• Ringing tone or melody, volume and type

• Sounds made when you press a key, make an

error or receive a message

Ring Volume Menu 3.1

This option allows you to adjust the ringing volume

to one of five levels.

Press the „key to increase and the key to

decrease the volume. The greater the number of

bars, the greater the volume.

Ring Tone Menu 3.2

This option allows you to select the required ringing

tone. You can choose between 20 different tones.

Each time you select a tone, it is played for a few

seconds. Tones 19 and 20 correspond to the melodies

that you can compose, using the Melody Composer

menu option (3.9).

SSoouunndd SSeettttiinnggss

SSoouunndd SSeettttiinnggssSSoouunndd SSeettttiinnggss

Minute Minder Menu 3.7

This option allows you to specify whether the phone

must beep every minute during an outgoing call to

keep you informed of the length of your call.

The following options are available.

OFF: the phone does not beep.

ON: the phone beeps every minute.

Connect Tone Menu 3.8

You can set your phone to beep when the person you

are calling answers the phone.

The following options are available.

OFF: the phone does not beep.

ON: the phone beeps when your call is accepted.

Melody Composer Menu 3.9

This option allows you to compose your own melody

to be used as the ring tone.

Three octaves are available. A maximum of 100

notes can be entered. You can adjust the length of

the notes and add rests, as required.

Message Tone Menu 3.5

This option allows you to select how the phone

informs you that a new message has been received.

The following options are available.

Light Only: the service light in the top right-hand

corner of the phone flashes.

Single Beep: the phone beeps once.

SMS Tone1~10: the phone uses an SMS tone. You

are provided with ten SMS tones.

Error Tone Menu 3.6

This option allows you to select how the phone

informs you that you have made a mistake.

The following options are available.

OFF: the phone does not beep.

ON: the phone beeps to indicate an invalid entry.

SSoouunndd SSeettttiinnggss

Saving a Melody

When you are satisfied with your melody, you can

save it and indicate that you wish to use it as the

ring tone.

1. Press the Save soft key.

2. Enter a title for the melody.

Note: For further details on how to enter

characters, refer to page 33.

You are asked if the melody is to become the ring

tone.

3. To use the melody as the ring tone, press the Yes

soft key.

The melody is saved and is played each time your

phone rings. You can also select the melodies

composed via the Ring Tone menu option (3.2);

they are tones 19 and 20 respectively.

Otherwise, press the No soft key. The melody is

saved only.

Composing a Melody

You can compose two melodies. When you access

the menu, the names of any melodies created are

displayed. Otherwise, Melody 1 and Melody 2 appear.

Select the melody that you wish to create or edit.

To... Then press the...

Compose a Edit soft key.

melody

Insert a note Next soft key.

Move a note a 2key.

semitone up

Move a note a 8key.

semitone down

Change the 4

key one or more times until

length of a note the note is of the required length.

Delete a note Ckey.

Enter a rest 6key and hold it down for the

required length of time.

Listen to your Listen soft key.

melody

Modify your Modify soft key.

melody

6766

Greeting Message Menu 4.2

This option allows you to set a greeting message to

be displayed briefly when the phone is switched on.

The current message is displayed.

To... Then press the...

Clear the existing Ckey and hold it down until

message the message is cleared.

Enter a new message Appropriate alphanumeric

keys.

For further details on how to enter characters, refer to

page 33.

Calling Card Menu 4.3

If you wish to use a calling card for long distance

calls, you must first store your calling card

information into your phone using this menu. Your

phone can store up to four calling cards (Card A ~ D).

When you are attempting to access this menu, you

are required to enter the phone’s lock code.

Storing Calling Card Information

1. Select the calling card and press the Options soft

key. The following options are available.

• Select: selects the highlighted card. Once you

select the card, you can use it for dialing by

pressing and holding down the key.

• Dialing Sequence: allows you to select the

dialing sequence.

Phone Settings

Many different features of your phone can be

customized to suit your preferences. All of these

features are accessed via the Phone Settings menu.

Infrared Activate Menu 4.1

This feature allows you to send or receive data/fax

through the infrared port. To use an infrared

connection, you must:

• Install the modem driver for receiving or sending

data/fax

• Install the network dial-up software supplied by

your service provider or a fax application program

for a fax call on your PC

• Configure and activate an IrDA-compliant infrared

port on your PC

• Activate the Infrared feature on the phone;

the symbol appears on the bottom line of the

display

• Dial the network service number given to you by

the service provider

If there is no communication between your phone and

the IrDA-compliant device within 30 seconds of

activating the feature, it is automatically deactivated.

For further details, contact your service provider.

PPhhoonnee SSeettttiinnggss

* These calling cards are frequently used with these

dialing sequences. However, they may vary and are

subject to change at the phone company’s

discretion.

Choosing a Calling Card

1. Select the calling card and press the Options soft

key.

2. Select Dialing Sequence using the key and

press Select.

Making Calling Card calls

1. Enter the phone number, including any prefix (such

as 0 or 1) that your calling card may require when

you make a calling card call. See your calling card

for instructions.

2. Press and hold down the key until your phone

displays “Card Call.”

3. Your phone displays “Wait for tone, then press

OK.” When you hear the tone from your calling

card call, press OK.

4. When you hear another tone from your calling card

call, press OK.

Note: This procedure may not apply to all calling

card options programmed into your phone.

Please look at the back of your calling card or

contact your long distance company for more

information.

• Change Name: changes the name of the calling

card.

• Erase: erases the calling card.

2. Select Dialing Sequence using the key and

press Select.

3. Select the dialing sequence your card uses (see the

table below) using the key and press Select.

4. Enter the number when prompted for the calling

card’s access number(usually the 1-800 number

listed on the back of the calling card), and press

OK.

5. Enter card number when prompted to enter the

calling card number, and press OK.

Dialing

Sequence

Access no.

+ phone no.

+ card no.

Dial 1-800 access

number, phone

number, then card

number

Dial 1-800 access

number, card number,

then phone number

Dial the prefix (any

numbers that must

precede the phone

number) phone

number, then card

number

MCI, AT&T True

Choice, Sprint

Canada, Unitel

network MCI,

WorldPhone MCI

GTE, PacBell,

AT&T, Stentor

Access no.

+ card no.

+ phone no.

Prefix

+ phone no.

+ card no.

Use for cards that

require you to Card using this

sequence*

Dialing Sequence

PPhhoonnee SSeettttiinnggss

Auto Redial Menu 4.6

With the Auto Redial function, the phone makes up

to ten attempts to redial a phone number after an

unsuccessful call.

Note: The interval between two call attempts varies.

The following options are available.

OFF: the number is not redialed.

ON: the number is redialed automatically.

Active Flip Menu 4.7

This option allows you to answer a call simply by

opening the flip.The following options are available.

Disable: to answer a call, you must open the flip and

press any key except C, , and the Reject soft

key.

Enable: to answer a call, you simply open the flip.

Contrast Menu 4.8

This option allows you to adjust the contrast of the

LCD screen by pressing the „or key. Each time

you press the key, you can see the LCD screen

changing according to the current value.

Backlight Menu 4.4

You can select whether or not the phone uses the

backlight. A marginal increase in standby/talk time

can be achieved by turning the backlight off.

The following options are available.

OFF: the backlight is not used.

Short: the backlight comes on when you press a key

or receive a call and switches off 10 seconds after

the last key is pressed.

Long: the backlight comes on when you press a key

or receive a call and switches off 20 seconds after

the last key is pressed.

Service Light Menu 4.5

This option allows you to select whether or not the

service light in the top right-hand corner of the phone

is used.

The following options are available.

OFF: the service light is not used.

ON: the service light flashes when the phone is ready

for use.

7372

Organizer

The Organizer feature enables you to:

• View the calendar and organize your schedule

• Define a list of things to do

• Set the current date and time

•

Set the alarm so that the phone rings at a specific

time (to remind you of an appointment for example)

• Use the phone as a calculator

• Assign functions to the navigation keys so that

they can be used as shortcuts giving direct access

to your favorite menus

Calendar Menu 5.1

With the Calendar feature, you can:

• Consult the calendar

• Write memos to keep a track of your schedule and

trigger an alarm if necessary

Consulting the Calendar

When you select the Calendar menu option (5.1), the

calendar is displayed. The following options are

available when you press the Options soft key.

Search all: displays all memos set, regardless of the

day and starting with the oldest. To scroll through the

memos, press the key.

Delete all: allows you to delete all memos. You are

asked to confirm your action.

Go to date: allows you to jump to a specific date.

Slide Menu Menu 4.9

With the Slide Menu feature, you can determine

how the menus are displayed. If the feature is

enabled, the menus seem to slide into position from

the top, bottom, left or right, as applicable.

Language Menu 4.10

You can select a display language. The available

language options are: English,French, Spanish, and

Portuguese.

Reset Settings Menu 4.11

You can easily reset your phone to its default

configuration.

Enter the 8-digit phone lock code and press the OK

soft key. The phone resets all settings to default.

Note: The lock code is preset to 00000000. To change

this code, refer to page 81.

PPhhoonnee SSeettttiinnggss

OOrrggaanniizzeerrOOrrggaanniizzeerr

Once you have finished editing the memo, press the

OK soft key. The following options are then available

when you press the Options soft key.

Alarm: allows you to set the alarm to ring on the

chosen day.

Erase: allows you to delete the memo.

Copy to: allows you to copy the memo to another

date.

Move to: allows you to change the date and time of

the memo.

To Do List Menu 5.2

This feature allows you to:

• Draw up a list of tasks to be done

• Assign a priority and deadline to each task

• Sort the tasks by priority and status mark ( for

tasks to be done, ✓for completed tasks)

Creating the To Do List

To create the To Do List, proceed as follows.

1. Press the New soft key.

2. Enter the first task.

Note: You can enter up to 48 characters. For

further details on how to enter characters,

see page 33.

3. Press the OK soft key.

Writing a Memo

To write or edit a memo on a specific date, proceed

as follows.

1. Select the required date in the calendar, using the

navigation keys.

Note: To skip to the previous or next month,

press the or „keys on the left side of

the phone.

2. Press the Select soft key.

An empty memo screen is displayed to allow you

to enter your memo.

3. Enter your memo and then press the OK soft key.

Note: For further details on how to enter

characters, refer to page 33.

You are asked if you wish to set the alarm.

4. If you want the alarm to ring on the chosen day,

press the Yes soft key.

Otherwise, press the No soft key.

5. If you pressed Yes, set the time for the alarm and

press OK.

A check mark is displayed in front of the date in

the calendar to indicate that a memo exists.

Editing a Memo

If you select a day for which a memo already exists,

you can press the Edit soft key to edit the memo

displayed.

Note: For further details on how to enter characters,

refer to page 33.

OOrrggaanniizzeerr

To... Then...

Sort the existing • Press the Options soft key.

tasks by priority • Select the Sort option.

or status • Select the sort criterion (high,

low, done, undo).

Copy a task • Highlight the task.

• Press the Options soft key.

• Select the Copy option.

• Change the text, priority and

deadline for the task as

required.

Delete a task • Highlight the task.

• Press the Options soft key.

• Select the Delete option.

Delete all tasks • Press the Options soft key.

• Select the Delete all option.

• Confirm the deletion by

pressing OK.

Time & Date Menu 5.3

This option allows you to change the current time

and date displayed. You can also check the current

time for Greenwich Mean Time (GMT) and 21 major

cities around the world.

Set Time: allows you to enter the current time. You

can choose the time format via the Format menu

option (5.3.4).

Note: Before setting the time, you must specify your

time zone, via the World Time menu option

(5.3.3).

Select high or low priority using the key and

the Select soft key.

5. Enter your deadline.

6. Press the OK soft key.

Editing the To Do List

If tasks are already defined in the To Do List when you

select the To Do List menu option (5.2), the current

contents are displayed with the associated priority

and status mark. The following options are available.

To... Then...

View the details • Highlight the task.

for a specific task • Press the View soft key.

• Press the *key to mark the

task as completed as of the

current date and time.

Change the status • Highlight the task.

of a specific task • Press the *key.

( or ✓)or

• Highlight the task.

• Press the Options soft key.

• Select the Mark option.

• Select the appropriate status.

Create a new task • Press the Options soft key.

• Select the New option.

• Enter the text, priority and

deadline for the task.

Edit an existing • Highlight the task.

task • Press the Options soft key.

• Select the Edit option.

• Change the text, priority and

deadline for the task.

OOrrggaanniizzeerr

Alarm Menu 5.4

This feature allows you to:

• Set the alarm to ring at a specific time

• Set the phone to switch on automatically and ring

the alarm if the specified time is reached while

the phone is switched off (Autopower menu

option set to Enable)

In the Alarm menu, the following options are

available.

Once Alarm: the alarm rings only once and is then

deactivated.

Daily Alarm: the alarm rings every day at the same

time.

Weekly Alarm: the alarm rings every week on the

same day and at the same time.

To set the alarm, proceed as follows.

1. Choose the alarm frequency option.

Enter the required time and day of the week (if

applicable).

To stop the alarm when it rings, open the flip and

press the Exit soft key.

Remove Alarm: deactivates the alarm.

Autopower: if set to Enable, switches the phone

on automatically when the alarm rings. You are then

asked if you wish to leave the phone switched on.

Set Date: allows you to enter the day, month and

year. You can change the date format via the Format

menu option (5.3.4).

World Time: allows you to check the current time

for Greenwich Mean Time (GMT) and 21 major cities

around the world, using the key.

The screen shows the:

• City name

• Current date and time

• Time difference between the selected city and

your city if you have set the local time (see below

for further details) or GMT (by default)

To select the time zone in which you are located,

proceed as follows.

1. Select the city corresponding to your time zone by

pressing the key one or more times.

The local date and time are displayed.

2. Press the Set soft key.

Format: allows you to change the time and date

formats.

Time format: 24 hours

12 hours

Date format: YYYY/MM/DD (year/month/day)

DD/MM/YYYY (day/month/year)

MM/DD/YYYY (month/day/year)

To... Then...

Leave the phone on Hold down the key.

Switch the phone Press the Exit soft key or

off again any other key.

If the menu option is set to Disable and the phone

is switched off at the specified time, the alarm will

not ring.

Calculator Menu 5.5

Using this feature, you can use the phone as a

calculator. The calculator provides the basic arithmetic

functions: addition, subtraction, multiplication and

division.

Using the Calculator

1. Enter the first number using the numeric keys.

2. Press the right soft key until the required

arithmetic symbol appears: +(add), -(subtract),

*(multiply), /(divide).

3. Enter the second number.

4. Repeat Steps 1 to 3 as many times as required.

Notes:

• To erase any mistakes and clear the display,

press the Ckey.

•

To include a decimal point or a bracket, press the

left soft key until the required symbol is displayed.

5. To calculate the result, press the key.

8180

OOrrggaanniizzeerrSecurity

The Security feature enables you to restrict the use

of your phone to:

• The people of your choice

• The types of calls of your choice

Change Lock code Menu 6.1

The lock code is a password for locking or unlocking

the phone. This feature allows you to change your

current lock code to a new one. You must enter the

current code before you can specify a new one.

The lock code is factory set to 00000000.Once you

have entered a new lock code, you are asked to

confirm it by entering it again.

Change Security code Menu 6.2

The security code is used for restriction of the use of

your phone. This menu allows you to change your

current security code to a new one. You must enter

the current code before you can specify a new one.

The security code is factory set to 00000000. Once

you have entered a new password, you are asked to

confirm it by entering it again.

8382

SSeeccuurriittyySSeeccuurriittyy

2. Enter your security code and press OK.

3. Select the location by pressingthe key and

press Options.

4. Select Edit, then the OK soft key. If a number has

already been saved, this option allows you to edit

the number.

If you want to erase a saved number, select

Erase, When a confirmation displays, press Yes.

5. Enter the phone number and press OK. The phone

number is saved and now you cannot make a call

to the number.

SOS Call List Menu 6.4

Your phone provides the option of storing emergency

numbers for SOS calls. All three numbers can

manually be dialed at any time even when the phone

is locked. Each number can be up to 18 digits long.

This can be a useful feature for controlling the

numbers which can be dialed from your phone when

the phone is locked.

To store an SOS call number, select a location for the

number, and press the Edit soft key. Then enter the

desired number and press the OK soft key.

To make an SOS call when the phone is locked, press

the SOS soft key, select the desired number saved in

the SOS call list, and then press the Yes soft key.

Call Restriction Menu 6.3

The call restriction feature allows you to restrict your

calls.

Call restriction can be set up in the following ways.

Restrict all outgoing call: calls cannot be made.

Restrict all Incoming call: calls cannot be

received.

Restrict outgoing call: calls to the phone numbers

which you have specified cannot be made. You can

save up to 10 phone numbers.

To restrict the all outgoing or incoming calls, proceed

as follows.

1. Select Restrict all outgoing call or Restrict all

incoming call by pressing the key until the

appropriate option is highlighted and then press

Select .

2. Select Enable to the feature on, and press

Select.

If you want to set the restriction off, select

Disable.

3. Enter your security code and press OK.

To save the phone numbers to be restricted, proceed

as follows.

1. Select Restrict outgoing call by pressing the

key, and then press Select .

8584

NNeettwwoorrkk SSeerrvviicceess

The following options are available.

Activate: activates the Call Diverting feature.

Cancel: deactivates the Call Diverting feature.

You can deactivate all call diverting settings by

selecting the Cancel All option.

Call Waiting Menu 7.2

This network service enables you to be informed when

someone is trying to reach you during another call.

Note: For using the Call Waiting service, you must

set the service code for it. For details, see

page 89.

The following options are available.

Activate: activates the Call Waiting feature. You can

answer an incoming call while you have a call in

progress. See page 44 for answering a waiting call.

Cancel: deactivates the Call Waiting feature.

Network Selection Menu 7.3

The Network Selection feature enables you to

indicate whether the network used when roaming

(outside your home area) is selected automatically

or manually.

Note: You can select a network other than your

home network only if it has a valid roaming

agreement with your home network.

Network Services

These menu functions are network services.

Please contact your service provider to check their

availability and subscribe to them, if you so wish.

Call Diverting Menu 7.1

This network service enables incoming calls to be

rerouted to the number that you specify.

Example: You may wish to divert your business calls

to a colleague while you are on holiday.

Note: For using the Call Diverting service, you must

set the service code for it. For details, see

page 89.

Call diverting can be set up in the following ways.

• Divert Always: all calls are diverted.

• Busy: calls are diverted if you are already making

another call.

• No Reply: calls are diverted if you do not answer

the phone.

• Unreachable: calls are diverted if you are not in

an area covered by your service provider.

• Cancel All: all call diverting options are cancelled.

To indicate whether the network is to be selected

automatically or manually when roaming, proceed as

follows.

1. When Network Selection is displayed, press the

Select soft key.

2. Press the key until the appropriate option is

highlighted and then press the OK soft key.

• If you select Automatic, your phone

automatically searches for a network available

to you and chooses the appropriate one. Every

time you switch your phone on, it resets this

menu to Automatic.

• If you select Manual, your phone searches for a

network, then begins displaying them. Press the

key until the preferred network is

highlighted and then press the OK soft key.

• If you select New Search, your phone begins a

new search for new Private and Residential

systems. When finding the best new system, the

phone displays it. Then you can confirm by

pressing Select or start another search by

pressing Next.

3. You are connected to that network.

8786

NNeettwwoorrkk SSeerrvviicceessNNeettwwoorrkk SSeerrvviicceess

Voice Privacy Menu 7.4

Used only in digital networks, Voice Privacy encrypts

the voice channel so that people cannot eavesdrop

on your conversation. If you turn this feature on and

voice privacy becomes inactive for any reason your

phone displays “Voice privacy not active” and beeps.

The following options are available.

Activate: turns this feature on.

Deactivate: turns this feature off.

Note: This feature may not be available in all areas.

Contact your service provider for details and

availability.

Send ID Menu 7.5

In most service areas, when you call someone, your

name is presented to his/her caller ID. Using this

feature, you can prevent your phone number from

being displayed on the phone of the person being

called. This feature is only effective when calling to

a number that is equipped with Caller ID.

Note: This feature may not be available in some

network. Contact your service provider.

The following options are available.

Hide Number: your phone number is not displayed

on the recipient's phone.

Send Number: your phone number is sent each time

you make a call.

NAM Selection Menu 7.6

The service provider programs your phone with the

phone number and system information into your

phone’s memory when your phone is first activated.

This is called a Number Assignment Module (NAM).

For example, your phone can be activated in up to 4

different service areas each giving your phone a

different phone number or account.

Only one number can be active at a time. When you

select a phone number, you’re also selecting which

system you’re using as your home system. The first

phone number displayed with this menu is the

currently selected number.

Notes:

• It may not be necessary to have four NAMs for

your phone if your service provider has service or

roaming agreements for each area in which you

wish to use your phone. Contact your service

provider for details.

• You need at least one active number to make a

call. You cannot change from one NAM to another

during a call.

8988

NNeettwwoorrkk SSeerrvviicceess

Set Service Code Menu 7.7

For using the network services, such as the Call

Diverging and Call Waiting, you must set the service

codes supplied by your service provider with this

menu. For more information on the service code,

contact your service provider.

Call Diverting: allows you to set the codes for using

each of the options (Divert Always, Busy, No

Reply, Unreachable and Cancel All) in the Call

Diverting.

Call Waiting: allows you to set the codes for using

each of the options (Activate and Cancel ) in the

Call Waiting.

NNeettwwoorrkk SSeerrvviicceess

Games

Using this feature, you can play seven different

games with the phone:

• Casino

• Roulette

• Black Jack

• Sniper

• Snake

• Mole

• Othello

Once you have selected a game, the following

options are available.

Play: allows you to start a game.

Level: allows you to select the level of difficulty.

Select the required level using the key

and press

the OK soft key. This option is only available

in games

with several levels (Sniper, Snake).

Configuration: allows you to configure the phone

for the chosen game (backlight and sound settings).

To adjust each setting, highlight the Backlight or

Sound option by pressing the key and then

toggle between ON and OFF by pressing the On/Off

soft key.

Instructions: describes the buttons used by the

game. If necessary, press the right soft key to see a

more detailed description.

9190

High Score: enables you to view the highest score

recorded for the selected game. You can also reset

this score by pressing the Reset soft key.

If you break the current record for the game, the

phone displays the High Score screen.

To stop playing a game, press the Cor key.

GGaammee

9392

Your correspondent cannot hear you speaking

• Have you switched off the microphone?

• Are you holding the phone close enough to your

mouth? The microphone is located in the bottom

center of the phone.

The phone starts beeping and “**Warning**

Low Battery” flashes in the display

• The battery is insufficiently charged. Replace the

battery and recharge it.

The audio quality of the call is poor

• Check the signal strength indicator in the display

( ); the number of bars after it indicates the

signal strength from strong ( ) to weak ( ).

• Try moving the phone slightly or moving closer to a

window if you are in a building.

No number is dialed when you recall a phonebook

entry

• Check that the numbers have been stored

correctly, by using the Phonebook Search feature.

• Re-store them, if necessary.

If the above guidelines do not enable you to solve

the problem, take a note of:

• The model and serial numbers of your phone

• Your warranty details

• A clear description of the problem

Then contact your local dealer or SAMSUNG

after-sales service.

Solving Problems

Before contacting the after-sales service, perform the

following simple checks. They may save you the time

and expense of an unnecessary service call.

“No service”, “Network failure” or “Not done”

is displayed

• The network connection was lost. You may be in a

weak reception area (in a tunnel or surrounded by

buildings). Move and try again.

• You are trying to access an option for which you

have not taken out a subscription with your

service provider. Contact the service provider for

further details.

You have entered a number but it was not dialed

• Have you pressed the key?

• Are you accessing the right cellular network?

• You may have set an outgoing call barring option.

Your correspondent cannot reach you

• Is your phone switched on ( pressed for more

than one second)?

• Are you accessing the right cellular network?

• You may have set an incoming call barring option.

SSoollvviinngg PPrroobblleemmss

9594

• Use only Samsung-approved batteries and

recharge your battery only with Samsung-approved

chargers. When a charger is not in use, disconnect

it from the power source. Do not leave the battery

connected to a charger for more than a week,

since overcharging may shorten its life.

• Extreme temperatures will affect the charging

capacity of your battery: it may require cooling or

warming first.

• Do not leave the battery in hot or cold places, such

as in a car in summer or winter conditions, as you

will reduce the capacity and life-time of the

battery. Always try to keep the battery at room

temperature. A phone with a hot or cold battery

may temporarily not work, even when the battery

is fully charged. Li-ion batteries are particularly

affected by temperatures below 0 °C (32 °F).

• Do not short-circuit the battery. Accidental short

circuiting can occur when a metallic object (coin,

clip or pen) causes a direct connection between

the + and – terminals of the battery (metal strips

on the battery), for example when you carry a

spare battery in a pocket or bag. Short-circuiting

the terminals may damage the battery or the

object causing the short-circuit.

• Dispose of used batteries in accordance with local

regulations. Always recycle. Do not dispose of

batteries in a fire.

SSoollvviinngg PPrroobblleemmss

Using the Batteries

Your phone is powered by a rechargeable Li-ion

standard battery.

Precautions When Using Batteries

• Never use any charger or battery that is damaged

in any way.

• Use the battery only for its intended purpose.

• If you use the phone near the network’s base

station, it uses less power; talk and standby times

are greatly affected by the signal strength on the

cellular network and the parameters set by the

network operator.

• Battery charging times depend on the remaining

battery charge and the type of battery and charger

used. The battery can be charged and discharged

hundreds of times, but it will gradually wear out.

When the operation time (talk time and standby

time) is noticeably shorter than normal, it is time

to buy a new battery.

• If left unused, a fully charged battery will

discharge itself over time.

SSaaffeettyy IInnffoorrmmaattiioonn

• Operation of any radio-transmitting equipment,

including cellular phones, may interfere with

inadequately protected medical devices. Consult

a doctor or the manufacturer of the medical

device if you have any questions. Other electronic

equipment may also be subject to interference.

• As with other mobile radio-transmitting equipment,

you are advised that for satisfactory operations

and personal safety, the equipment should only be

used in the normal operating position.

• Always switch off the phone when at a refuelling

point (service station). You are reminded of the

need to observe restrictions on the use of radio

equipment in fuel depots (fuel storage and

distribution areas), chemical plants or where

blasting operations are in progress.

• Do not store or carry flammable liquids, gases or

explosive materials in the same compartment as

the phone, its parts or accessories.

• Switch off your cellular phone when in an aircraft.

The use of cellular phones in an aircraft is illegal

and may be dangerous to the operation of the

aircraft or disrupt the cellular network. Failure

to observe these instructions may lead to the

suspension or denial of cellular telephone services

to the offender, legal action or both.

Safety Information

Road Safety

• Remember, road safety always comes first!

• Do not use a hand-held phone while driving a

vehicle. Always park the vehicle before having a

conversation.

• Make sure that the phone is stored safely and will

not fall or be broken in the event of a collision or

emergency stop.

• The use of an alert device to operate a vehicle’s

lights or horn on public roads is not permitted.

• Only qualified personnel should install or service

the phone in a vehicle. Faulty installation or service

may be dangerous and may invalidate any warranty

applicable to the unit.

• Electronic fuel injection, anti-skid braking,

electronic cruise control or any other electronic

systems may malfunction due to the lack of

protection from radio signals. Check regularly that

all cellular phone equipment in your vehicle is

mounted and operating correctly.

Operating Environment

• Remember to follow any special regulations in

force in any area and always switch off your

phone whenever it is forbidden to use it, or when

it may cause interference or danger (in a hospital

for example).

SSaaffeettyy IInnffoorrmmaattiioonn

• Do not use harsh chemicals, cleaning solvents or

strong detergents to clean the phone. Wipe it with

a soft cloth slightly dampened in mild, soapy water.

• If the phone or any of its accessories are not

working properly, take them to your nearest

qualified service centre. The personnel there will

assist you, and if necessary, arrange for the phone

to be repaired.

Emergency Calls

Important! This phone, like any cellular phone, uses

radio signals, cellular and landline

networks, as well as user-programmed

functions that cannot guarantee

connection in all conditions. Therefore,

you should never rely solely on any

cellular phone for essential communi-

cations (medical emergencies for

example).

Remember, to make or receive any calls, the phone

must be switched on and in a service area with

adequate cellular signal strength.

Emergency calls may not be possible on all cellular

phone networks or when certain network services

and/or phone features are in use. Check with local

cellular service providers.

SSaaffeettyy IInnffoorrmmaattiioonn

Care and Maintenance

Your phone is a product of superior design and

craftsmanship and should be treated with care. The

suggestions below will help you fulfill the warranty

obligations and enjoy this product for many years.

• Keep the phone and all its parts and accessories

out of the reach of small children.

• Keep the phone dry. Precipitation, humidity and

liquids containing minerals will corrode the

electronic circuits.

• Do not use or store the phone in dusty, dirty areas

as its components may be damaged.

• Do not store the phone in hot areas. High

temperatures can shorten the life of electronic

devices, damage batteries and warp or melt

certain plastics.

• Do not store the phone in cold areas. When the

phone warms up to its normal temperature,

moisture can form inside the phone, which may

damage the electronic circuits.

• Do not attempt to open the phone’s casing.

Non-expert handling of the phone may damage it.

• Do not drop or knock the phone. Rough handling

may damage the internal circuits.

101

GGlloossssaarryy ooff TTeerrmmss

Conference Calling

Ability to establish a conference call involving up to

five additional parties.

Line Identification Services

Services allowing subscribers to view or block the

telephone numbers of callers.

Phone Password

Lock code used to unlock the phone when you have

selected the option to lock it automatically each time

it switches on, and security code used to restrict the

use of your phone.

Roaming

Use of your phone when you are outside your home

area (when travelling for example).

SMS (Short Message Service)

Network service sending and receiving messages to

and from another subscriber without having to speak

to the correspondent. The message created or received

(up to 160 characters long) can be displayed, received,

edited or sent.

100

Glossary of Terms

To help you understand the main technical terms and

abbreviations used in this booklet and take full

advantage of the features on your mobile phone,

here are a few definitions.

Active Flip

Ability to answer a call simply by opening the phone.

Call Barring

Ability to restrict outgoing and incoming calls.

Call Diverting

Ability to reroute calls to another mobile or fixed

line.

Call Holding

Ability to put one call on standby while answering or

making another call; you can then switch between

the two calls, as required.

Call Waiting

Ability to inform users that they have an incoming

call when engaged on another call.

103102

GGlloossssaarryy ooff TTeerrmmss

Soft Keys

Keys marked ... on the phone, the purpose of which:

• Varies according to the function that you are

currently using

• Is indicated on the bottom line of the display just

above the corresponding key

Voice Mail

Computerized answering service that automatically

answers your calls when you are not available, plays

a greeting (optionally in your own voice) and records

a message.

Index

Accessories • 7

Active Flip (4.7) • 71

Adjusting volume • 22

Alarm (5.4) • 79

Alert Type (3.3) • 61

Answering

a call • 22

a second call • 42

Auto Redial (4.6) • 71

Autopower • 79

Backlight • 13; 70

contrast • 71

Batteries

charging • 16

installing • 14

low battery indicator • 17

precautions • 94

removing • 15

Calculator (5.5) • 80

Calendar (5.1) • 73

Caller

group • 39

ID • 23

Calling card (4.3)• 67

Calls

answering • 22

a second call • 44

conference • 45

dialed (1.3) • 53

diverting (7.1) • 84

ending • 21

holding • 41

international • 20

making • 20

missed • 23; 52

received (1.2) • 52

records (1) • 53

redialing automatically • 71

restriction (6.3) • 82

SOS (6.4)• 83

time (1.4) • 53

via the phonebook • 21

waiting (7.3) • 85

Care • 98

Changing

lock code

(6.1)

• 81

security code (6.2) • 81

Characters

entering • 33

Charging batteries • 16

Composer

Melody (3.9) • 63

Conference calls • 45

Connect

to Voice Mail (2.1) • 54

tone (3.8) • 63

Contrast (4.8) • 71

Correcting numbers • 20

Date

format (5.3.4) • 78

setting (5.3.2) • 77

Deleting

memos • 75

missed calls • 25

phonebook numbers • 36

tasks • 77

Dialed Calls (1.3) • 53

Display • 11

contrast • 71

icons • 12

setting the

language (4.10) • 72

Diverting calls (7.1) • 84

Earphone • 7

Earpiece

adjusting the volume • 22

Editing

memos • 74

messages • 56

missed calls• 24

phonebook numbers • 36

To Do List • 76

Erasing

memos • 75

missed calls• 25

phonebook numbers • 36

tasks • 77

Error Tone (3.6) • 62

Functions

selecting • 28

Games (8) • 90

Greeting Message (4.2) • 67

Groups

caller • 39

Holding calls • 41

Icons

description • 12

ID Caller • 23

Sending • 87

Identifying a caller • 23

Infrared Activate (4.1) • 66

IrDA port • 66

Key tones

adjusting the volume • 22

muting • 43

selecting • 61

sending • 43

Keypad Tone (3.4) • 61

Keys

description • 9

location • 8

navigation • 29

Language (4.10) • 72

Last number redialing • 21

Length of calls • 53

Letters

entering • 33

Light

backlight • 13; 70

service • 13; 70

Lock code • 82

Locking phone • 19

Low battery indicator • 17

Maintenance • 98

Melody Composer (3.9) • 63

Memory status • 40

Memos

editing • 74

writing • 74

Menus

by scrolling • 46

by shortcut • 47

display mode • 72

list • 48

using • 46

Message Tone (3.5) • 62

Messages

greeting (4.2) • 67

preset (2.4) • 58

reading (2.2) • 55

setup (2.5) • 58

voice mail (2.1) • 54

writing (2.3) • 57

105

IInnddeexxIInnddeexx

104

(continued)

Microphone mute • 42

Minute Minder (3.7) • 63

Missed calls (1.1) • 52

deleting • 25

editing the number • 24

viewing • 23; 52

Mute

key tones • 43

microphone • 42

Names

entering • 33

options • 38

searching/dialing • 37

storing in the

phonebook • 32

Network Selection (7.3) • 85

Network Services (7) • 84

Number

correcting • 20

editing

missed call • 24; 52

phonebook • 36

erasing phonebook • 36

moving phonebook • 37

own • 40

redialing • 21

automatically • 71

searching/dialing •

storing in the

phonebook • 32

Options

selecting • 28

Organizer (5) • 73

Own Number • 40

Phone

locking • 19

Settings (4) • 64

switching on/off • 18

Phonebook • 32

dialing • 37

editing numbers • 36

erasing numbers • 34

making calls • 20

moving numbers • 37

options • 35

searching • 37; 43

storing numbers/names • 32

Portinfrared • 66

Preset Message List (2.4) • 58

Problem solving • 92

Read Messages (2.2) • 54

Received Calls (1.2) • 52

Redialing

automatically • 71

last number • 21

Reset Settings (4.11) • 72

Restriction, call • 82

Ring

Tone (3.2) • 60

type • 61

Volume (3.1) • 60

Roaming • 85

Safety

batteries • 94

information • 96

precautions • 5

Security (6) • 81

Schedule • 73

Searching for names/numbers

• 37; 43

Security code • 81

Selecting functions/options

• 28

Send ID (7.5) • 87

Sending

ID • 87

key tones • 43

messages • 57

Service code (7.7) • 89

Service light • 13; 70

(continued)

Setting

alarm (5.4) • 79

date (5.3.2) • 77

display language • 72

time (5.3.1) • 78

Settings

resetting (4.11) • 72

Setup (2.5) • 58

Silent mode • 25

Slide Menu (4.9) • 72

SMS

setup (2.5) • 58

text message icon • 54

using • 44; 54

Solving problems • 92

Sound Settings (3) • 60

Speed Dialing • 34

Switching on/off

microphone • 42

phone • 18

Tasks

defining • 75

deleting • 77

editing • 76

sorting • 77

Text messages • 54

icon • 54

preset (2.4) • 58

reading (2.2) • 55

setup (2.5) • 58

writing (2.3) • 57

Time

calls (1.4) • 53; 63

format (5.3.4) • 78

setting (5.3.1) • 77

world (5.3.3) • 78

To Do List (5.2) • 75

Tone

connect (3.8) • 63

error (3.6) • 62

keypad (3.4) • 61

melody •60

message (3.5) • 62

ring (3.2) • 60

Travel charger • 16

Vibration • 61

Voice mail (2.1) • 54

Voice memo • 26

Voice privacy (7.4) • 87

Voice Server Number

(2.1.2) • 53

Volume

adjusting • 22

selecting the ring (3.1) • 58

Waiting

call • 44; 85

World Time (5.3.3) • 78

Write Messages (2.3) • 57

Writing memos • 74

106

IInnddeexx

107

TDMA Mobile Telephone STH-N270

Quick Reference Card

Press and hold .

Switch On/Off

➀Key in the number.

➁Press the key.

Make a Call

➀Open the phone and

press the View soft

key.

➁Scroll with the key

through the missed

calls.

➂To return the call, press

the key.

End a Call

View Missed

Calls

Briefly press the

key.

➀Press the Menu soft key.

➁Scroll with the key

through the list of menus

until you reach the

required menu.

➂Press the Select soft

key.

➃Scroll with the key

through the list of

options until the required

one is selected.

➄Press the Select soft key

to confirm.

Access

the Menu

Function

• Each of the two soft keys ( )

performs the function indicated by the

text above it (bottom line in the display).

108

➀Key in the number.

➁Press the Save soft key.

➂Enter the name.

➃Press the OK soft key.

➄If necessary, change the

location.

➅Press the OK soft key.

Store

Numbers

in the

Phonebook

➀Press the Name soft key.

➁Enter the start of the

name.

➂

Press the Search soft key.

➃To scroll through the

names, press the

key.

➄To make a call, press the

Search for

a Number

in the

Phonebook

Press the „or key.

Adjust the

Volume

➀Select the Alert Type

menu option (3.3).

➁Select an option:

Light only,Melody,

Vibration,Vibra+

Melody.

➂Press the Select soft

key to confirm.

Choose the

Alert Type

Open the phone

Press the key.

Answer a

Call

Samsung Electronics Co STHN270 Dual-Mode Cellular Phone (AMPS/TDMA) User Manual

Samsung Electronics Co Ltd Dual-Mode Cellular Phone (AMPS/TDMA) Users Manual

Users Manual

Navigation menu

Namespaces

Views

Navigation
