Users Manual

Some of the contents in this manual may differ from your phone depending on the software of the phone or your

service provider.

World Wide Web

http://www.samsungmobile.com

Printed in Korea

Code No.:GH68-xxxxxA

English (EU). 09/2008. Rev. 1.0

Samsung S3030_Q

user manual

Draft

using this

manual

This user manual has been specially designed to

guide you through the functions and features of your

mobile phone. To get started quickly,

refer to “introducing your mobile phone,”

“assembling and preparing your mobile phone,”

and “using basic functions.”

Instructional icons

Before you start, familiarise yourself with the icons

you will see in this manual:

Warning

—situations that could cause

injury to yourself or others

Caution

—situations that could cause

damage to your phone or other equipment

Note

—notes, usage tips, or additional

information

Refer to

—pages with related information;

for example:

p. 12 (represents “see

page 12”)

using this manual

iii

Rights to all technologies and products that

comprise this device are the property of their

respective owners:

•Bluetooth

® is a registered trademark of the

Bluetooth SIG, Inc. worldwide—Bluetooth QD

ID: B014488.

• Java™ is a trademark of Sun Microsystems, Inc.

→

Followed by

—the order of options or

menus you must select to perform a step;

for example: Press <Menu> → Messages

→ Create message (represents Menu

followed by Messages, followed by

Create message)

[ ]

Square brackets

—phone keys; for

example: [ ] (represents the Power/

Menu exit key)

< >

Angled brackets

—softkeys that control

different functions at each screen; for

example: <OK> (represents the OK

softkey)

contents

safety and usage information 2

Safety warnings .......................................... 2

Safety precautions ...................................... 4

Important usage information ....................... 7

introducing your mobile phone 11

Unpack ..................................................... 11

Phone layout .............................................12

Keys .........................................................13

Display ......................................................14

Icons ......................................................... 15

assembling and preparing your mobile

phone 17

Install the SIM card and battery ................. 17

Charge the battery .................................... 19

Insert a memory card (optional) ................. 20

Change the photo on the battery cover .....20

contents

using basic functions 21

Turn your phone on and off ....................... 21

Access menus .......................................... 22

Customise your phone .............................. 22

Use basic call functions ............................ 24

Send and view messages ......................... 25

Add and find contacts ............................... 27

Use basic camera functions ...................... 28

Listen to music ......................................... 29

Browse the web ........................................ 30

using advanced functions 32

Use advanced call functions ..................... 32

Use advanced Phonebook functions ......... 35

Use advanced messaging functions ..........36

Use advanced music functions ................. 37

using tools and applications 40

Use the Bluetooth wireless feature ............ 40

Activate and send an SOS message ......... 41

Activate the mobile tracker ........................ 42

Make fake calls ......................................... 43

Record and play voice memos .................. 44

Use Java-powered games and

applications .............................................. 44

Create and view world clocks ................... 45

Set and use alarms ................................... 46

Use the calculator ..................................... 47

Convert currencies or measurements .......47

Set a countdown timer ............................. 48

Use the stopwatch .................................... 48

Create a text memo .................................. 48

Manage your calendar .............................. 49

troubleshooting a

index d

safety and

usage

information

Comply with the following precautions to avoid

dangerous or illegal situations and ensure peak

performance of your mobile phone.

Keep your phone away from small

children and pets

Keep your phone and all accessories out of the

reach of small children or animals. Small parts may

cause choking or serious injury if swallowed.

Protect your hearing

Safety warnings

Listening to a headset at high volumes

can damage your hearing. Use only the

minimum volume setting necessary to

hear your conversation or music.

safety and usage information

Install mobile phones and equipment

with caution

Ensure that any mobile phones or related equipment

installed in your vehicle are securely mounted. Avoid

placing your phone and accessories near or in an air

bag deployment area. Improperly installed wireless

equipment can cause serious injury when air bags

inflate rapidly.

Handle and dispose of batteries and

chargers with care

• Use only Samsung-approved batteries and

chargers specifically designed for your phone.

Incompatible batteries and chargers can cause

serious injuries or damage to your phone.

• Never dispose of batteries in a fire. Follow all local

regulations when disposing used batteries.

• Never place batteries or phones on or in heating

devices, such as microwave ovens, stoves, or

radiators. Batteries may explode when

overheated.

• Never crush or puncture the battery. Avoid

exposing the battery to high external pressure,

which can lead to an internal short circuit and

overheating.

Avoid interference with pacemakers

Maintain a minimum of 15 cm (6 inches) between

mobile phones and pacemakers to avoid potential

interference, as recommended by manufacturers

and the independent research group, Wireless

Technology Research. If you have any reason to

suspect that your phone is interfering with a

pacemaker or other medical device, turn off the

phone immediately and contact the manufacturer of

the pacemaker or medical device for guidance.

safety and usage information

Turn off the phone in potentially

explosive environments

Do not use your phone at refuelling points (service

stations) or near fuels or chemicals. Turn off your

phone whenever directed by warning signs or

instructions. Your phone could cause explosions or

fire in and around fuel or chemical storage and

transfer areas or blasting areas. Do not store or carry

flammable liquids, gases, or explosive materials in

the same compartment as the phone, its parts, or

accessories.

Reduce the risk of repetitive motion

injuries

When sending text messages or playing games on

your phone, hold the phone with a relaxed grip,

press the keys lightly, use special features that

reduce the number of keys you have to press (such

as templates and predictive text), and take frequent

breaks.

Drive safely at all times

Avoid using your phone while driving and obey all

regulations that restrict the use of mobile phones

while driving. Use hands-free accessories to

increase your safety when possible.

Follow all safety warnings and

regulations

Comply with any regulations that restrict the use of a

mobile phone in a certain area.

Use only Samsung-approved

accessories

Using incompatible accessories may damage your

phone or cause injury.

Safety precautions

Health and safety

information

Exposure to Radio Frequency (RF)

Signals

Certification Information (SAR)

Your wireless phone is a radio transmitter

and receiver. It is designed and

manufactured not to exceed the exposure

limits for radio frequency (RF) energy set by

the Federal Communications Commission

(FCC) of the U.S. government. These FCC

exposure limits are derived from the

recommendations of two expert

organizations, the National Counsel on

Radiation Protection and Measurement

(NCRP) and the Institute of Electrical and

Electronics Engineers (IEEE). In both cases,

Menription

E840-2.fm Page 41 Monday, May 14, 2007 9:04 AM

Health and safety information

the recommendations were developed by

scientific and engineering experts drawn

from industry, government, and academia

after extensive reviews of the scientific

literature related to the biological effects of

RF energy.

The exposure limit set by the FCC for

wireless mobile phones employs a unit of

measurement known as the Specific

Absorption Rate (SAR). The SAR is a

measure of the rate of absorption of RF

energy by the human body expressed in

units of watts per kilogram (W/kg). The FCC

requires wireless phones to comply with a

safety limit of 1.6 watts per kilogram (1.6

W/kg). The FCC exposure limit incorporates

a substantial margin of safety to give

additional protection to the public and to

account for any variations in measurements.

SAR tests are conducted using standard

operating positions accepted by the FCC with

the phone transmitting at its highest

certified power level in all tested frequency

bands. Although the SAR is determined at

the highest certified power level, the actual

SAR level of the phone while operating can

be well below the maximum value. This is

because the phone is designed to operate at

E840-2.fm Page 42 Monday, May 14, 2007 9:04 AM

E840-2.fm Page 43 Monday, May 14, 2007 9:04 AM

For body worn operations, this model phone

has been testde and meets the FCC

exposure guidelines when used with a

Samsung accessory designated for this

product or when used with an accessroy that

contains no metal and that positons the

handset a minimum 1.5 cm from the body.

Non-compliance with the above restrictions

may result in violation of FCC RF exposure

guidelines.

SAR information on this and other model

phones can be viewed on-line at

www.fcc.gov/oet/fccid. This site uses the

phone FCC ID number A3LSWDS3030Q.

Sometimes it may be necessary to remove

the battery pack to find the number. Once

you have the FCC ID number for a particular

phone, follow the instructions on the website

and it should provide values for typical or

maximum SAR for a particular phone.

Additional product specific SAR information

can also be obtained at www.fcc.gov/cgb/

sar.

multiple power levels so as to use only the

power required to reach the network. In

general, the closer you are to a wireless

base station antenna, the lower the power

output.

Before a new model phone is available for

sale to the public, it must be tested and

certified to the FCC that it does not exceed

the exposure limit established by the FCC.

Tests for each model phone are performed in

positions and locations (e.g. at the ear and

worn on the body) as required by the FCC.

The highest SAR values for this model phone

as reported to the FCC are : GSM850

Mode Head: 0.261W/Kg, Body-worn:0

.381W/Kg. GSM1900 Mode

Head: 0.336W/Kg, Body-worn:0.258W/Kg.

Health and safety information

Consumer Information on Wireless

Phones

The U.S. Food and Drug Administration

(FDA) has published a series of Questions

and Answers for consumers relating to radio

frequency (RF) exposure from wireless

phones. The FDA publication includes the

following information:

What kinds of phones are the subject

of this update?

The term wireless phone refers here to

hand-held wireless phones with built-in

antennas, often called “cell,” “mobile,” or

“PCS” phones. These types of wireless

phones can expose the user to measurable

radio frequency energy (RF) because of the

short distance between the phone and the

user's head. These RF exposures are limited

by Federal Communications Commission

safety guidelines that were developed with

the advice of FDA and other federal health

and safety agencies. When the phone is

located at greater distances from the user,

the exposure to RF is drastically lower

because a person's RF exposure decreases

rapidly with increasing distance from the

source. The so-called “cordless phones,”

which have a base unit connected to the

telephone wiring in a house, typically

operate at far lower power levels, and thus

produce RF exposures well within the FCC's

compliance limits.

Do wireless phones pose a health

hazard?

The available scientific evidence does not

show that any health problems are

associated with using wireless phones. There

is no proof, however, that wireless phones

are absolutely safe. Wireless phones emit

low levels of radio frequency energy (RF) in

the microwave range while being used. They

E840-2.fm Page 44 Monday, May 14, 2007 9:04 AM

also emit very low levels of RF when in the

stand-by mode. Whereas high levels of RF

can produce health effects (by heating

tissue), exposure to low level RF that does

not produce heating effects causes no

known adverse health effects. Many studies

of low level RF exposures have not found

any biological effects. Some studies have

suggested that some biological effects may

occur, but such findings have not been

confirmed by additional research. In some

cases, other researchers have had difficulty

in reproducing those studies, or in

determining the reasons for inconsistent

results.

What is FDA's role concerning the

safety of wireless phones?

Under the law, FDA does not review the

safety of radiation-emitting consumer

products such as wireless phones before

they can be sold, as it does with new drugs

or medical devices. However, the agency has

authority to take action if wireless phones

are shown to emit radio frequency energy

(RF) at a level that is hazardous to the user.

In such a case, FDA could require the

manufacturers of wireless phones to notify

users of the health hazard and to repair,

replace or recall the phones so that the

hazard no longer exists.

Although the existing scientific data do not

justify FDA regulatory actions, FDA has

urged the wireless phone industry to take a

number of steps, including the following:

E840-2.fm Page 45 Monday, May 14, 2007 9:04 AM

Health and safety information

• “Support needed research into possible

biological effects of RF of the type

emitted by wireless phones;

• “Design wireless phones in a way that

minimizes any RF exposure to the user

that is not necessary for device function;

and

• “Cooperate in providing users of wireless

phones with the best possible

information on possible effects of

wireless phone use on human health.

FDA belongs to an interagency working

group of the federal agencies that have

responsibility for different aspects of RF

safety to ensure coordinated efforts at the

federal level. The following agencies belong

to this working group:

• “National Institute for Occupational

Safety and Health

• “Environmental Protection Agency

• “Federal Communications Commission

• “Occupational Safety and Health

Administration

• “National Telecommunications and

Information Administration

The National Institutes of Health participates

in some interagency working group

activities, as well.

FDA shares regulatory responsibilities for

wireless phones with the Federal

Communications Commission (FCC). All

phones that are sold in the United States

must comply with FCC safety guidelines that

limit RF exposure. FCC relies on FDA and

other health agencies for safety questions

about wireless phones.

FCC also regulates the base stations that the

wireless phone networks rely upon. While

these base stations operate at higher power

E840-2.fm Page 46 Monday, May 14, 2007 9:04 AM

than do the wireless phones themselves, the

RF exposures that people get from these

base stations are typically thousands of

times lower than those they can get from

wireless phones. Base stations are thus not

the primary subject of the safety questions

discussed in this document.

What are the results of the research

done already?

The research done thus far has produced

conflicting results, and many studies have

suffered from flaws in their research

methods. Animal experiments investigating

the effects of radio frequency energy (RF)

exposures characteristic of wireless phones

have yielded conflicting results that often

cannot be repeated in other laboratories. A

few animal studies, however, have

suggested that low levels of RF could

accelerate the development of cancer in

laboratory animals. However, many of the

studies that showed increased tumor

development used animals that had been

genetically engineered or treated with

cancer-causing chemicals so as to be pre-

disposed to develop cancer in absence of RF

exposure. Other studies exposed the

animals to RF for up to 22 hours per day.

These conditions are not similar to the

conditions under which people use wireless

phones, so we don't know with certainty

what the results of such studies mean for

human health.

Three large epidemiology studies have been

published since December 2000. Between

them, the studies investigated any possible

association between the use of wireless

phones and primary brain cancer, glioma,

meningioma, or acoustic neuroma, tumors

E840-2.fm Page 47 Monday, May 14, 2007 9:04 AM

Health and safety information

of the brain or salivary gland, leukemia, or

other cancers. None of the studies

demonstrated the existence of any harmful

health effects from wireless phones RF

exposures. However, none of the studies can

answer questions about long-term

exposures, since the average period of

phone use in these studies was around three

years.

What research is needed to decide

whether RF exposure from wireless

phones poses a health risk?

A combination of laboratory studies and

epidemiological studies of people actually

using wireless phones would provide some

of the data that are needed. Lifetime animal

exposure studies could be completed in a

few years. However, very large numbers of

animals would be needed to provide reliable

proof of a cancer promoting effect if one

exists. Epidemiological studies can provide

data that is directly applicable to human

populations, but ten or more years' follow-

up may be needed to provide answers about

some health effects, such as cancer. This is

because the interval between the time of

exposure to a cancer-causing agent and the

time tumors develop - if they do - may be

many, many years. The interpretation of

epidemiological studies is hampered by

difficulties in measuring actual RF exposure

during day-to-day use of wireless phones.

Many factors affect this measurement, such

as the angle at which the phone is held, or

which model of phone is used.

What is FDA doing to find out more

about the possible health effects of

wireless phone RF?

E840-2.fm Page 48 Monday, May 14, 2007 9:04 AM

FDA is working with the U.S. National

Toxicology Program and with groups of

investigators around the world to ensure

that high priority animal studies are

conducted to address important questions

about the effects of exposure to radio

frequency energy (RF).

FDA has been a leading participant in the

World Health Organization international

Electromagnetic Fields (EMF) Project since

its inception in 1996. An influential result of

this work has been the development of a

detailed agenda of research needs that has

driven the establishment of new research

programs around the world. The Project has

also helped develop a series of public

information documents on EMF issues.

FDA and Cellular Telecommunications &

Internet Association (CTIA) have a formal

Cooperative Research and Development

Agreement (CRADA) to do research on

wireless phone safety. FDA provides the

scientific oversight, obtaining input from

experts in government, industry, and

academic organizations. CTIA-funded

research is conducted through contracts to

independent investigators. The initial

research will include both laboratory studies

and studies of wireless phone users. The

CRADA will also include a broad assessment

of additional research needs in the context

of the latest research developments around

the world.

What steps can I take to reduce my

exposure to radio frequency energy

from my wireless phone?

If there is a risk from these products - and

at this point we do not know that there is - it

E840-2.fm Page 49 Monday, May 14, 2007 9:04 AM

Health and safety information

is probably very small. But if you are

concerned about avoiding even potential

risks, you can take a few simple steps to

minimize your exposure to radio frequency

energy (RF). Since time is a key factor in

how much exposure a person receives,

reducing the amount of time spent using a

wireless phone will reduce RF exposure.

• “If you must conduct extended

conversations by wireless phone every

day, you could place more distance

between your body and the source of the

RF, since the exposure level drops off

dramatically with distance. For example,

you could use a headset and carry the

wireless phone away from your body or

use a wireless phone connected to a

remote antenna.

Again, the scientific data do not demonstrate

that wireless phones are harmful. But if you

are concerned about the RF exposure from

these products, you can use measures like

those described above to reduce your RF

exposure from wireless phone use.

What about children using wireless

phones?

The scientific evidence does not show a

danger to users of wireless phones,

including children and teenagers. If you

want to take steps to lower exposure to

radio frequency energy (RF), the measures

described above would apply to children and

teenagers using wireless phones. Reducing

the time of wireless phone use and

increasing the distance between the user

and the RF source will reduce RF exposure.

Some groups sponsored by other national

governments have advised that children be

discouraged from using wireless phones at

all. For example, the government in the

E840-2.fm Page 50 Monday, May 14, 2007 9:04 AM

United Kingdom distributed leaflets

containing such a recommendation in

December 2000. They noted that no

evidence exists that using a wireless phone

causes brain tumors or other ill effects. Their

recommendation to limit wireless phone use

by children was strictly precautionary; it was

not based on scientific evidence that any

health hazard exists.

Do hands-free kits for wireless phones

reduce risks from exposure to RF

emissions?

Since there are no known risks from

exposure to RF emissions from wireless

phones, there is no reason to believe that

hands-free kits reduce risks. Hands-free kits

can be used with wireless phones for

convenience and comfort. These systems

reduce the absorption of RF energy in the

head because the phone, which is the source

of the RF emissions, will not be placed

against the head. On the other hand, if the

phone is mounted against the waist or other

part of the body during use, then that part

of the body will absorb more RF energy.

Wireless phones marketed in the U.S. are

required to meet safety requirements

regardless of whether they are used against

the head or against the body. Either

configuration should result in compliance

with the safety limit.

Do wireless phone accessories that

claim to shield the head from RF

radiation work?

Since there are no known risks from

exposure to RF emissions from wireless

phones, there is no reason to believe that

accessories that claim to shield the head

from those emissions reduce risks. Some

products that claim to shield the user from

E840-2.fm Page 51 Monday, May 14, 2007 9:04 AM

Health and safety information

RF absorption use special phone cases, while

others involve nothing more than a metallic

accessory attached to the phone. Studies

have shown that these products generally do

not work as advertised. Unlike “hand-free”

kits, these so-called “shields” may interfere

with proper operation of the phone. The

phone may be forced to boost its power to

compensate, leading to an increase in RF

absorption. In February 2002, the Federal

trade Commission (FTC) charged two

companies that sold devices that claimed to

protect wireless phone users from radiation

with making false and unsubstantiated

claims. According to FTC, these defendants

lacked a reasonable basis to substantiate

their claim.

What about wireless phone

interference with medical equipment?

Radio frequency energy (RF) from wireless

phones can interact with some electronic

devices. For this reason, FDA helped develop

a detailed test method to measure

electromagnetic interference (EMI) of

implanted cardiac pacemakers and

defibrillators from wireless telephones. This

test method is now part of a standard

sponsored by the Association for the

Advancement of Medical instrumentation

(AAMI). The final draft, a joint effort by FDA,

medical device manufacturers, and many

other groups, was completed in late 2000.

This standard will allow manufacturers to

ensure that cardiac pacemakers and

defibrillators are safe from wireless phone

EMI. FDA has tested wireless phones and

helped develop a voluntary standard

sponsored by the Institute of Electrical and

Electronic Engineers (IEEE). This standard

specifies test methods and performance

E840-2.fm Page 52 Monday, May 14, 2007 9:04 AM

requirements for hearing aids and wireless

phones so that no interference occurs when

a person uses a compatible phone and a

compatible hearing aid at the same time.

This standard was approved by the IEEE in

2000.

FDA continues to monitor the use of wireless

phones for possible interactions with other

medical devices. Should harmful

interference be found to occur, FDA will

conduct testing to assess the interference

and work to resolve the problem.

Additional information on the safety of RF

exposures from various sources can be

obtained from the following organizations:

• FCC RF Safety Program:

http://www.fcc.gov/oet/rfsafety/

• Environmental Protection Agency (EPA):

http://www.epa.gov/radiation/

• Occupational Safety and Health

Administration's (OSHA):

http://www.osha.gov/SLTC/

radiofrequencyradiation/index.html

• National institute for Occupational Safety

and Health (NIOSH):

http://www.cdc.gov/niosh/emfpg.html

• World health Organization (WHO):

http://www.who.int/peh-emf/

• International Commission on Non-

Ionizing Radiation Protection:

http://www.icnirp.de

• National Radiation Protection Board

(UK):

http://www.nrpb.org.uk

• Updated 4/3/2002: US food and Drug

Administration

http://www.fda.gov/cellphones

E840-2.fm Page 53 Monday, May 14, 2007 9:04 AM

Health and safety information

Road Safety

Your wireless phone gives you the powerful

ability to communicate by voice, almost

anywhere, anytime. But an important

responsibility accompanies the benefits of

wireless phones, one that every user must

uphold.

When driving a car, driving is your first

responsibility. When using your wireless

phone behind the wheel of a car, practice

good common sense and remember the

following tips:

1. Get to know your wireless phone and its

features, such as speed dial and redial. If

available, these features help you to

place your call without taking your

attention off the road.

2. When available, use a hands-free device.

If possible, add an additional layer of

convenience and safety to your wireless

phone with one of the many hands free

accessories available today.

E840-2.fm Page 54 Monday, May 14, 2007 9:04 AM

3. Position your wireless phone within easy

reach. Be able to access your wireless

phone without removing your eyes from

the road. If you get an incoming call at

an inconvenient time, let your voice mail

answer it for you.

4. Let the person you are speaking with

know you are driving; if necessary,

suspend the call in heavy traffic or

hazardous weather conditions. Rain,

sleet, snow, ice and even heavy traffic

can be hazardous.

5. Do not take notes or look up phone

numbers while driving. Jotting down a

“to do” list or flipping through your

address book takes attention away from

your primary responsibility, driving

safely.

6. Dial sensibly and assess the traffic; if

possible, place calls when you are not

moving or before pulling into traffic. Try

to plan calls when your car will be

stationary. If you need to make a call

while moving, dial only a few numbers,

check the road and your mirrors, then

continue.

E840-2.fm Page 55 Monday, May 14, 2007 9:04 AM

Health and safety information

7. Do not engage in stressful or emotional

conversations that may be distracting.

Make people you are talking with aware

you are driving and suspend

conversations that have the potential to

divert your attention from the road.

8. Use your wireless phone to call for help.

Dial 9-1-1 or other local emergency

number in the case of fire, traffic

accident or medical emergencies.

Remember, it is a free call on your

wireless phone!

9. Use your wireless phone to help others in

emergencies. If you see an auto

accident, crime in progress or other

serious emergency where lives are in

danger, call 9-1-1 or other local

emergency number, as you would want

others to do for you.

10. Call roadside assistance or a special non-

emergency wireless assistance number

when necessary. If you see a broken-

down vehicle posing no serious hazard, a

broken traffic signal, a minor traffic

accident where no one appears injured,

or a vehicle you know to be stolen, call

roadside assistance or other special non-

emergency number.

“The wireless industry reminds you to

use your phone safely when driving.”

For more information, please call 1-888-

901-SAFE, or visit our web-site www.wow-

com.com

Provided by the Cellular Telecommunications

& Internet Association

Operating Environment

E840-2.fm Page 56 Monday, May 14, 2007 9:04 AM

Remember to follow any special regulations

in force in any area and always switch your

phone off whenever it is forbidden to use it,

or when it may cause interference or danger.

When connecting the phone or any

accessory to another device, read its user's

guide for detailed safety instructions. Do not

connect incompatible products.

As with other mobile radio transmitting

equipment, users are advised that for the

satisfactory operation of the equipment and

for the safety of personnel, it is

recommended that the equipment should

only be used in the normal operating

position (held to your ear with the antenna

pointing over your shoulder).

Using Your Phone Near Other

Electronic Devices

Most modern electronic equipment is

shielded from radio frequency (RF) signals.

However, certain electronic equipment may

not be shielded against the RF signals from

your wireless phone. Consult the

manufacturer to discuss alternatives.

Pacemakers

Pacemaker manufacturers recommend that

a minimum distance of 15 cm (6 inches) be

maintained between a wireless phone and a

pacemaker to avoid potential interference

with the pacemaker.

These recommendations are consistent with

the independent research and

recommendations of Wireless Technology

Research.

Persons with pacemakers:

E840-2.fm Page 57 Monday, May 14, 2007 9:04 AM

Health and safety information

• should always keep the phone more than

15 cm

(6 inches) from their pacemaker when

the phone is switched on.

• should not carry the phone in a breast

pocket.

• should use the ear opposite the

pacemaker to minimize potential

interference.

If you have any reason to suspect that

interference is taking place, switch your

phone off immediately.

Hearing Aids

Some digital wireless phones may interfere

with some hearing aids. In the event of such

interference, you may wish to consult your

hearing aid manufacturer to discuss

alternatives.

Other Medical Devices

If you use any other personal medical

devices, consult the manufacturer of your

device to determine if it is adequately

shielded from external RF energy. Your

physician may be able to assist you in

obtaining this information. Switch your

phone off in health care facilities when any

regulations posted in these areas instruct

you to do so. Hospitals or health care

facilities may be using equipment that could

be sensitive to external RF energy.

E840-2.fm Page 58 Monday, May 14, 2007 9:04 AM

Vehicles

RF signals may affect improperly installed or

inadequately shielded electronic systems in

motor vehicles. Check with the

manufacturer or its representative regarding

your vehicle. You should also consult the

manufacturer of any equipment that has

been added to your vehicle.

Posted Facilities

Switch your phone off in any facility where

posted notices require you to do so.

Potentially Explosive Environments

Switch your phone off when in any area with

a potentially explosive atmosphere and obey

all signs and instructions. Sparks in such

areas could cause an explosion or fire

resulting in bodily injury or even death.

Users are advised to switch the phone off

while at a refueling point (service station).

Users are reminded of the need to observe

restrictions on the use of radio equipment in

fuel depots (fuel storage and distribution

areas), chemical plants or where blasting

operations are in progress.

Areas with a potentially explosive

atmosphere are often but not always clearly

marked. They include below deck on boats,

chemical transfer or storage facilities,

vehicles using liquefied petroleum gas (such

as propane or butane), areas where the air

contains chemicals or particles, such as

grain, dust or metal powders, and any other

E840-2.fm Page 59 Monday, May 14, 2007 9:04 AM

Health and safety information

area where you would normally be advised

to turn off your vehicle engine.

Emergency Calls

This phone, like any wireless phone,

operates using radio signals, wireless and

landline networks as well as user

programmed functions, which cannot

guarantee connection in all conditions.

Therefore, you should never rely solely on

any wireless phone for essential

communications (medical emergencies, for

example).

Remember, to make or receive any calls the

phone must be switched on and in a service

area with adequate signal strength.

Emergency calls may not be possible on all

wireless phone networks or when certain

network services and/or phone features are

in use. Check with local service providers.

To make an emergency call:

1. If the phone is not on, switch it on.

2. Key in the emergency number for your

present location (for example, 911 or

other official emergency number).

Emergency numbers vary by location.

3. Press .

If certain features are in use (call barring,

for example), you may first need to

deactivate those features before you can

make an emergency call. Consult this

document and your local cellular service

provider.

When making an emergency call, remember

to give all the necessary information as

accurately as possible. Remember that your

E840-2.fm Page 60 Monday, May 14, 2007 9:04 AM

phone may be the only means of

communication at the scene of an accident;

do not cut off the call until given permission

to do so.

Restricting Children's access to your

Phone

Your phone is not a toy. Children should not

be allowed to play with it because they could

hurt themselves and others, damage the

phone or make calls that increase your

phone bill.

FCC Notice and Cautions

FCC Notice

• This device complies with Part 15 of the

FCC Rules. Operation is subject to the

following two conditions: (1) this device

may not cause harmful interference, and

(2) this device must accept any

interference received, including

interference that may cause undesired

operation.

• This equipment has been tested and found

to comply with the limits for a Class B

digital device, pursuant to part 15 of the

FCC Rules. These limits are designed to

provide reasonable protection against

harmful interference in a residential

installation.This equipment generates, uses

and can radiate radio frequency energy

and,f not installed and used in accordance

with the instructions, may cause harmful

interference to radio communications

E840-2.fm Page 61 Monday, May 14, 2007 9:04 AM

Health and safety information

The phone may cause TV or radio

interference if used in close proximity to

receiving equipment. The FCC can require

you to stop using the phone if such

interference cannot be eliminated.

Vehicles using liquefied petroleum gas (such

as propane or butane) must comply with the

National Fire Protection Standard (NFPA-58).

For a copy of this standard, contact the

National Fire Protection Association, One

Battery march Park, Quincy, MA 02269,

Attn: Publication Sales Division.

Cautions

Changes or modifications made in the radio

phone, not expressly approved by Samsung,

will void the user’s authority to operate the

equipment.

Only use approved batteries, antennas and

chargers. The use of any unauthorized

accessories may be dangerous and void the

phone warranty if said accessories cause

damage or a defect to the phone.

Although your phone is quite sturdy, it is a

complex piece of equipment and can be

broken. Avoid dropping, hitting, bending or

sitting on it.

However, there is no guarantee that

interference will not occur in a particular

installation.If this equipment does cause

harmful interference to radio or television

reception, which can be determined by turning

the equipment off and on, the user is

encouraged to try to correct theinterference

by one or more of the following measures:-

Reorient or relocate the receiving antenna. -

Increase the separation between the

equipment and receiver.-Connect the

equipment into an outlet on a circuit different

from that to which the receiver is connected. -

Consult the dealer or an experienced radio/TV

technician for help.

E840-2.fm Page 62 Monday, May 14, 2007 9:04 AM

Other Important Safety

Information

• Only qualified personnel should service

the phone or install the phone in a

vehicle. Faulty installation or service may

be dangerous and may invalidate any

warranty applicable to the device.

• Check regularly that all wireless phone

equipment in your vehicle is mounted

and operating properly.

• Do not store or carry flammable liquids,

gases or explosive materials in the same

compartment as the phone, its parts or

accessories.

• For vehicles equipped with an air bag,

remember that an air bag inflates with

great force. Do not place objects,

including both installed or portable

wireless equipment in the area over the

air bag or in the air bag deployment

area. If wireless equipment is improperly

installed and the air bag inflates, serious

injury could result.

• Switch your phone off before boarding an

aircraft. The use of wireless phone in

aircraft is illegal and may be dangerous

to the aircraft's operation.

• Failure to observe these instructions may

lead to the suspension or denial of

telephone services to the offender, or

legal action, or both.

E840-2.fm Page 63 Monday, May 14, 2007 9:04 AM

Health and safety information

Product Performance

Getting the Most Out of Your Signal

Reception

The quality of each call you make or receive

depends on the signal strength in your area.

Your phone informs you of the current signal

strength by displaying a number of bars next

to the signal strength icon. The more bars

displayed, the stronger the signal.

If you're inside a building, being near a

window may give you better reception.

Understanding the Power Save

Feature

If your phone is unable to find a signal after

15 minutes of searching, a Power Save

feature is automatically activated. If your

phone is active, it periodically rechecks

service availability or you can check it

yourself by pressing any key.

Anytime the Power Save feature is activated,

a message displays on the screen. When a

signal is found, your phone returns to

standby mode.

Maintaining Your Phone's Peak

Performance

For the best care of your phone, only

authorized personnel should service your

phone and accessories. Faulty service may

void the warranty.

There are several simple guidelines to

operating your phone properly and

maintaining safe, satisfactory service.

• Hold the phone with the antenna raised,

fully-extended and over your shoulder.

E840-2.fm Page 64 Monday, May 14, 2007 9:04 AM

• Try not to hold, bend or twist the phone's

antenna.

• Don't use the phone if the antenna is

damaged.

• Speak directly into the phone's receiver.

• Avoid exposing your phone and

accessories to rain or liquid spills. If your

phone does get wet, immediately turn

the power off and remove the battery. If

it is inoperable, call Customer Care for

service.

Availability of Various Features/

Ring Tones

Many services and features are network

dependent and may require additional

subscription and/or usage charges. Not all

features are available for purchase or use in

all areas. Downloadable Ring Tones may be

available at an additional cost. Other

conditions and restrictions may apply. See

your service provider for additional

information.

E840-2.fm Page 65 Monday, May 14, 2007 9:04 AM

Health and safety information

Battery Standby and Talk Time

Standby and talk times will vary depending

on phone usage patterns and conditions.

Battery power consumption depends on

factors such as network configuration, signal

strength, operating temperature, features

selected, frequency of calls, and voice, data,

and other application usage patterns.

Battery Precautions

• Never use any charger or battery that is

damaged in any way.

• Use the battery only for its intended

purpose.

• If you use the phone near the network's

base station, it uses less power; talk and

standby time are greatly affected by the

signal strength on the cellular network

and the parameters set by the network

operator.

• Battery charging time depends on the

remaining battery charge and the type of

battery and charger used. The battery

can be charged and discharged hundreds

of times, but it will gradually wear out.

When the operation time (talk time and

standby time) is noticeably shorter than

normal, it is time to buy a new battery.

• If left unused, a fully charged battery will

discharge itself over time.

• Use only Samsung-approved batteries

and recharge your battery only with

Samsung-approved chargers. When a

charger is not in use, disconnect it from

the power source. Do not leave the

battery connected to a charger for more

E840-2.fm Page 66 Monday, May 14, 2007 9:04 AM

than a week, since overcharging may

shorten its life.

• Extreme temperatures will affect the

charging capacity of your battery: it may

require cooling or warming first.

• Do not leave the battery in hot or cold

places, such as in a car in summer or

winter conditions, as you will reduce the

capacity and lifetime of the battery.

Always try to keep the battery at room

temperature. A phone with a hot or cold

battery may temporarily not work, even

when the battery is fully charged. Li-ion

batteries are particularly affected by

temperatures below 0 °C (32 °F).

• Do not short-circuit the battery.

Accidental short- circuiting can occur

when a metallic object (coin, clip or pen)

causes a direct connection between the

+ and - terminals of the battery (metal

strips on the battery), for example when

you carry a spare battery in a pocket or

bag. Short-circuiting the terminals may

damage the battery or the object causing

the short-circuiting.

• Dispose of used batteries in accordance

with local regulations. In some areas, the

disposal of batteries in household or

business trash may be prohibited. For

safe disposal options for Li-Ion batteries,

contact your nearest Samsung

authorized service center. Always

recycle. Do not dispose of batteries in a

fire.

Care and Maintenance

Your phone is a product of superior design

and craftsmanship and should be treated

E840-2.fm Page 67 Monday, May 14, 2007 9:04 AM

Health and safety information

with care. The suggestions below will help

you fulfill any warranty obligations and allow

you to enjoy this product for many years.

• Keep the phone and all its parts and

accessories out of the reach of small

children.

• Keep the phone dry. Precipitation,

humidity and liquids contain minerals

that will corrode electronic circuits.

• Do not use the phone with a wet hand.

Doing so may cause an electric shock to

you or damage to the phone.

• Do not use or store the phone in dusty,

dirty areas, as its moving parts may be

damaged.

• Do not store the phone in hot areas.

High temperatures can shorten the life of

electronic devices, damage batteries,

and warp or melt certain plastics.

• Do not store the phone in cold areas.

When the phone warms up to its normal

operating temperature, moisture can

form inside the phone, which may

damage the phone's electronic circuit

boards.

• Do not drop, knock or shake the phone.

Rough handling can break internal circuit

boards.

• Do not use harsh chemicals, cleaning

solvents or strong detergents to clean

the phone. Wipe it with a soft cloth

slightly dampened in a mild soap-and-

water solution.

• Do not paint the phone. Paint can clog

the device's moving parts and prevent

proper operation.

• Do not put the phone in or on heating

devices, such as a microwave oven, a

E840-2.fm Page 68 Monday, May 14, 2007 9:04 AM

stove or a radiator. The phone may

explode when overheated.

• When the phone or battery gets wet, the

label indicating water damage inside the

phone changes color. In this case, phone

repairs are no longer guaranteed by the

manufacturer's warranty, even if the

warranty for your phone has not expired.

• If your phone has a flash or light, do not

use it too close to the eyes of people or

animals. This may cause damage to their

eyes.

• Use only the supplied or an approved

replacement antenna. Unauthorized

antennas or modified accessories may

damage the phone and violate

regulations governing radio devices.

• If the phone, battery, charger or any

accessory is not working properly, take it

to your nearest qualified service facility.

The personnel there will assist you, and

if necessary, arrange for service.

E840-2.fm Page 69 Monday, May 14, 2007 9:04 AM

Health and safety information

• When the phone or battery gets wet, the label

indicating water damage inside the phone

changes colour. In this case, phone repairs are

no longer guaranteed by the manufacturer's

warranty, even if the warranty for your phone

has not expired.

• If your phone has a flash or light, do not use it

too close to the eyes of people or animals. This

may cause damage to their eyes.

• Use only the supplied or an approved

replacement antenna. Unauthorised antennas or

modified accessories may damage the phone

and violate regulations governing radio devices.

• If the phone, battery, charger, or any accessory

is not working properly, take it to your nearest

qualified service facility. The personnel there will

assist you, and if necessary, arrange for service.

E840-2.fm Page 70 Monday, May 14, 2007 9:04 AM

• When the phone or battery gets wet, the label

indicating water damage inside the phone changes

colour. In this case, phone repairs are no longer

guaranteed by the manufacturer's warranty, even if

the warranty for your phone has not expired.

• If your phone has a flash or light, do not use it too

close to the eyes of people or animals. This may

cause damage to their eyes.

• Use only the supplied or an approved replacement

antenna. Unauthorised antennas or modified

accessories may damage the phone and violate

regulations governing radio devices.

• If the phone, battery, charger, or any accessory is

not working properly, take it to your nearest

qualified service facility. The personnel there will

assist you, and if necessary, arrange for service.

safety and usage information

Correct disposal of this product

(Waste Electrical & Electronic Equipment)

(Applicable in the European Union and

other European countries with separate

collection systems)

This marking shown on the product or its

literature, indicates that it should not be

disposed with other household wastes at the end of

its working life. To prevent possible harm to the

environment or human health from uncontrolled

waste disposal, please separate this from other

types of wastes and recycle it responsibly to

promote the sustainable reuse of material resources.

Household users should contact either the retailer

where they purchased this product, or their local

government office, for details of where and how they

can take this item for environmentally safe recycling.

Business users should contact their supplier and

check the terms and conditions of the purchase

contract. This product should not be mixed with

other commercial wastes for disposal.

safety and usage information

Correct disposal of batteries in this

product

(Applicable in the European Union and

other European countries with separate

battery return systems)

This marking on the battery, manual or

packaging indicates that the batteries in this product

should not be disposed of with other household

waste at the end of their working life. Where marked,

the chemical symbols Hg, Cd or Pb indicate that the

battery contains mercury, cadmium or lead above

the reference levels in EC Directive 2006/66. If

batteries are not properly disposed of, these

substances can cause harm to human health or the

environment.

To protect natural resources and to promote material

reuse, please separate batteries from other types of

waste and recycle them through your local, free

battery return system.

introducing your

mobile phone

In this section, learn about your mobile phone’s

layout, keys, display, and icons.

Unpack

Check your product box for the following items:

• Mobile phone

• Battery

• Travel adapter (charger)

• User manual

The items supplied with your phone may vary

depending on the software and accessories

available in your region or offered by your

service provider.

You can obtain additional accessories from

your local Samsung dealer.

introducing your mobile phone

Phone layout

The front of your phone includes the following keys

and features:

The rear of your phone includes the following keys

and features:

Power/Menu

exit key

Volume key

Dial key

Right softkey

Earpiece

Display

Alphanumeric

keys

Web access/

Confirm key

4-way

navigation key

Special

function keys

Left softkey

Music player key

Delete key

Mouthpiece

Closing the phone automatically locks the

exposed keys to prevent you from accidentally

pressing them. To unlock these keys, press

Battery cover

Camera key

SOS call key

Internal antenna

Camera lens

Mirror

Speaker

Multifunction jack

introducing your mobile phone

Keys

Key Function

Softkeys Perform actions indicated at the

bottom of the display

Music

player

In Idle mode, launch the music

player

Delete Delete characters or items in an

application

4-way

navigation

In Idle mode, access My menu

mode (up) or user-defined menus

(left/right/down); In Menu mode,

scroll through menu options

Web

access/

Confirm

In Idle mode, launch the web

browser; In Menu mode, select the

highlighted menu option or confirm

an input

Dial

Make or answer a call; In Idle mode,

retrieve recently dialled, missed, or

received numbers

Power/

Menu exit

Turn the phone on and off (press

and hold); End a call; In Menu

mode, cancel input and return to

Idle mode

Alpha-

numeric

Enter numbers, letters and special

characters; In Idle mode, press and

hold [1] to access voice mails and

[0] to enter an international call prefix

Special

function

Enter special characters or perform

special functions; In Idle mode,

press and hold [ ] for the Silent

profile; In Idle mode, press and hold

[ ] to enter a pause between

numbers

Key Function

introducing your mobile phone

Display

Your phone’s display consists of three areas:

Volume Adjust the phone’s volume

SOS call Access the SOS contact menu;

Make an SOS call (press and hold)

Camera

In Idle mode, turn on the camera

(press and hold); In Camera mode,

take a photo or record a video

Key Function

Icon line

Displays various icons

Text and graphic area

Displays messages,

instructions, and

information you enter

Softkey line

Displays the current actions

assigned to each softkey

Select Back

introducing your mobile phone

Icons

Learn about the icons that appear on your display.

Icon Definition

Signal strength

GPRS network connected

Transferring data via GPRS network

EDGE network connected

Transferring data via EDGE network

Call in progress

SOS message feature activated

Bluetooth hands-free car kit or headset

connected

Bluetooth activated

Alarm activated

Browsing the web

Connecting to secured web page

Call diverting active

Roaming (outside of normal service area)

In Home Zone service area

New text message (SMS)

New multimedia message (MMS)

New voice mail message

New configuration message

Text m essag e full

Multimedia message full

Voice mail message full

Configuration message full

Icon Definition

introducing your mobile phone

Memory card inserted

FM radio on

FM radio suspended

Normal profile activated

Silent profile activated

Driving profile activated

Meeting profile activated

Outdoor profile activated

Offline profile activated

User created profile activated

Battery power level

Current time

Icon Definition

assembling and

preparing your

mobile phone

Get started by assembling and setting up

your mobile phone for its first use.

Install the SIM card and battery

When you subscribe to a cellular service, you will

receive a Subscriber Identity Module, or SIM card,

with subscription details, such as your personal

identification number (PIN) and optional services.

To install the SIM card and battery,

1. Remove the battery cover.

If the phone is on, press and hold [ ] to turn

it off.

assembling and preparing your mobile phone

2. Insert the SIM card. 3. Insert the battery.

4. Replace the battery cover.

Place the SIM card in the phone with the gold-

coloured contacts facing down.

assembling and preparing your mobile phone

Charge the battery

Before using the phone for the first time, you must

charge the battery.

1. Open the cover to the multifunction jack and plug

the small end of the travel adapter.

2. Plug the large end of the travel adapter into a

power outlet.

3. When the battery is fully charged (the icon is

no longer moving), unplug the travel adapter from

the power outlet.

4. Unplug the travel adapter from the phone.

5. Close the cover to the multifunction jack.

Improperly connecting the travel adapter can

cause serious damage to the phone. Any

damages by misuse are not covered by the

warranty.

With the triangle

facing up

About the low battery indicator

When your battery is low, the phone will emit a

warning tone and a low battery message. The

battery icon will also be empty and blinking. If

the battery level becomes too low, the phone

will automatically power off. Recharge your

battery to continue using your phone.

assembling and preparing your mobile phone

Insert a memory card (optional)

To store additional multimedia files, you must insert a

memory card. Your phone accepts microSD™

memory cards up to 8 GB (depending on memory

card manufacturer and type).

1. Remove the battery cover.

2. Insert a memory card with the label side facing

up.

Change the photo on the battery

cover

1. Remove the battery cover.

2. Replace the image with your photo on the

battery cover.

using basic

functions

Learn how to perform basic operations and use the

main features of your mobile phone.

Turn your phone on and off

To turn your phone on,

1. Slide open the phone.

2. Press and hold [ ].

3. Enter your PIN and press <OK> (if necessary).

4. When the setup wizard opens, customise your

phone as desired by following the screen.

To turn your phone off, repeat steps 1 and 2 above.

Switch to the Offline profile

By switching to the Offline profile, you can use your

phone’s non-network services in areas where

wireless devices are prohibited, such as aeroplane

and hospitals.

using basic functions

To switch to the Offline profile, press <Menu> →

Settings → Phone profiles → Offline.

Access menus

To access your phone’s menus,

1. Press a softkey for the menu you want.

2. Use the navigation key to scroll to a menu or

option.

3. Press [OK], <Select>, or <OK> to confirm the

highlighted option.

4. Press <Back> to move up one level; Press [ ]

to return to Idle mode.

Customise your phone

Get more from your phone by customising it to

match your preferences.

Adjust the volume of the key tones

In Idle mode, press [ / ] to adjust the key tone

volume.

Switch to or from the Silent profile

In Idle mode, press and hold [ ] to silence or

unsilence your phone.

Change your ringtone

1. In Idle mode, press <Menu> → Settings →

Phone profiles.

2. Scroll to the profile you are using.

3. Press <Options> → Edit → Voice call ringtone.

Follow all posted warnings and directions from

official personnel when in areas where wireless

devices are prohibited.

using basic functions

4. Select a ringtone category → a ringtone.

5. Press <Options> → Save profile.

To switch to another profile, select it from the list.

Create a phone profile

1. In Idle mode, press <Menu> → Settings →

Phone profiles.

2. Press <Options> → Create.

3. Enter a name for the profile and press <Save>.

4. Customise the sound settings as desired.

5. When you are finished, press <Options> →

Save profile.

Select a wallpaper (Idle mode)

1. In Idle mode, press <Menu> → Settings →

Display and light settings → Home screen.

2. Scroll left or right to Images.

3. Select Main display.

4. Select an image category → an image.

5. Press <Save>.

Select a theme for the display

1. In Idle mode, press <Menu> → Settings →

Display and light settings → My theme.

2. Scroll left or right to a theme and press <OK>.

Set menu shortcuts

1. In Idle mode, press <Menu> → Settings →

Phone settings → Shortcuts.

2. Select a key to use as a shortcut.

3. Select a menu to assign to the shortcut key.

using basic functions

Lock your phone

1. In Idle mode, press <Menu> → Settings →

Security → Phone lock → On.

2. Enter a new 4- to 8-digit password and press

<OK>.

3. Enter the new password again and press <OK>.

Use basic call functions

Learn to make or answer calls and use basic call

functions.

Make a call

1. In Idle mode, enter an area code and a phone

number.

2. Press [ ] to dial the number.

3. To end the call, press [ ].

Answer a call

1. When a call comes in, press [ ].

2. To end the call, press [ ].

Adjust the volume

To adjust the volume during a call, press [ / ].

Use the speakerphone feature

1. During a call, press [OK] to activate the speaker.

2. To switch back to the earpiece, press [OK]

again.

In noisy environment, you may have difficulty

hearing the calls while using the speakerphone

feature. For better performance, use the normal

phone mode.

using basic functions

Record a conversation

1. During a call, press <Options> → Voice

Recorder.

2. Press [OK] to start recording.

3. Press the navigation key down to stop recording.

Use the headset

By plugging the supplied headset into the

multifunction jack, you can make and answer calls:

• To redial the last call, press the headset button

twice.

• To answer a call, press and hold the headset

button.

• To end a call, press and hold the headset button.

Send and view messages

Learn to send or view text (SMS) or multimedia

(MMS) messages.

Send a text message

1. In Idle mode, press <Menu> → Messages →

Create message → Text message.

2. Enter your message text and press [OK].

p. 26

3. Enter a destination number.

4. Press [OK] to send the message.

Send a multimedia message

1. In Idle mode, press <Menu> → Messages →

Create message → Multimedia message.

2. Select Subject.

3. Enter a subject and press [OK].

This feature may not be available depending on

your region or service provider.

using basic functions

4. Scroll down to Image or video or Sound and

press [OK].

5. Add the item you want.

6. Scroll down to Text and press [OK].

7. Enter your message text and press [OK].

8. Press <Options> → Send.

9. Enter a destination number or an email address.

10. Press [OK] to send the message.

Enter text

When entering text, you can change the text input

mode:

• Press and hold [ ] to switch between T9 and

ABC modes. Depending on your region, you may

be able to access an input mode for your specific

language.

• Press [ ] to change case or switch to Number

mode.

• Press and hold [ ] to switch to Symbol mode.

Enter text in one of the following modes:

Mode Function

ABC

Press the appropriate alphanumeric key until

the character you want appears on the

display.

1. Press the appropriate alphanumeric

keys to enter an entire word.

2. When the word displays correctly, press

[ ] to insert a space. If the correct word

does not display, press [

] to select an

alternate word.

Number

Press the appropriate alphanumeric key to

enter a number.

Symbol

Press the appropriate alphanumeric key to

select a symbol.

using basic functions

View text or multimedia messages

1. In Idle mode, press <Menu> → Messages →

My messages → Inbox.

2. Select a text or multimedia message.

Add and find contacts

Learn the basics of using the Phonebook feature.

Add a new contact

1. In Idle mode, enter a phone number and press

<Options>.

2. Select Save contact → a memory location

(phone or SIM) → New.

3. Select a number type (if necessary).

4. Enter contact information.

5. Press <Save> to add the contact to memory.

Find a contact

1. In Idle mode, press <Menu> → Phonebook.

You can also press <Phonebook> in Idle mode.

2. Enter the first few letters of the name you want to

find.

3. Select the contact’s name from the search list.

Once you have found a contact, you can:

• call the contact by pressing

[]

• edit the contact information by pressing [

]

using basic functions

Use basic camera functions

Learn the basics to capture and view photos and

videos.

Capture photos

1. In Idle mode, press and hold [ ] to turn on the

camera.

2. Rotate the phone anti-clockwise to landscape

view.

3. Aim the lens at the subject and make any

adjustments.

4. Press [ ] or [OK] to take a photo.

The photo is saved automatically.

5. Press [ ] or < > to take another photo (step

3).

View photos

In Idle mode, press <Menu> → My files → Images

→ My photos → a photo file.

Capture videos

1. In Idle mode, press and hold [ ] to turn on the

camera.

2. Rotate the phone anti-clockwise to landscape

view.

3. Press [1] to switch to Recording mode.

4. Aim the lens at the subject and make any

adjustments.

5. Press [ ] or [OK] to start recording.

6. Press [ ], [OK], or < > to stop recording.

The video is saved automatically.

7. Press [ ] or < > to record another video (step

4).

using basic functions

View videos

In Idle mode, press <Menu> → My files → Videos

→ My video clips → a video file.

Listen to music

Learn how to listen to music via the music player or

FM radio.

Listen to the FM radio

1. Plug the supplied headset.

2. In Idle mode, press <Menu> → Multimedia →

FM radio.

3. Press [OK] to turn on the FM radio.

4. Press <Yes> to start automatic tuning.

The radio scans and saves available stations

automatically.

5. Scroll up or down to a radio station.

6. To turn off the FM radio, press [OK].

Listen to music files

Start by transferring files to your phone or memory

card:

• Download from the wireless web.

p. 30

• Download from a PC with the optional Samsung

PC Studio.

p. 37

• Receive via Bluetooth.

p. 41

• Copy to your memory card.

p. 38

After transferring music files to your phone or

memory card,

1. In Idle mode, press [ ].

2. Select a music category → a music file.

The first time you access the FM radio, you will

be prompted to start automatic tuning.

using basic functions

3. Control playback using the following keys: Browse the web

Learn to access and bookmark your favourite web

pages.

Browse web pages

1. In Idle mode, press [OK] to launch your service

provider’s homepage.

2. Navigate web pages using the following keys:

Key Function

Pause or resume playback

Adjust the volume up or down

Navigation

• Left: Restart playback; Skip

backward (press within 3

seconds); Scan backward in a

file (press and hold)

• Right: Skip forward; Scan

forward in a file (press and hold)

• Up: Open the playlist

• Down: Stop playback

Key Function

Navigation

Scroll up or down on a web page

Select an item

Back

Return to the previous page

Options

Access a list of browser options

using basic functions

Bookmark your favourite web pages

1. In Idle mode, press <Menu> → Browser →

Bookmarks.

2. Press <Add>.

3. Enter a page title and a web address (URL).

4. Press <Save>.

using advanced

functions

Learn how to perform advanced operations and use

additional features of your mobile phone.

Use advanced call functions

Learn about your phone’s additional calling

capabilities.

View and dial missed calls

Your phone will display calls you have missed on the

display. To dial the number of a missed call,

1. Press <View>.

2. Scroll to the missed call you want to dial.

3. Press [ ] to dial.

Call a recently dialled number

1. In Idle mode, press [ ] to display a list of

recent numbers.

2. Scroll to the number you want and press [ ] to

dial.

using advanced functions

Hold a call or retrieve a held call

Press <Hold> to place a call on hold or press

<Retrieve> to retrieve a held call.

Dial a second call

If your network supports this function, you can dial

another number during a call:

1. Press <Hold> to place the first call on hold.

2. Enter the second number to dial and press

[].

3. Press <Swap> to switch between the two calls.

4. To end the call on hold, press <Options> → End

held call.

5. To end the current call, press [ ].

Answer a second call

If your network supports this function, you can

answer a second incoming call:

1. Press [ ] to answer the second call.

The first call is automatically placed on hold.

2. Press <Swap> to switch between the calls.

Make a multiparty call (conference call)

1. Call the first party you want to add to the

multiparty call.

2. While connected to the first party, call the

second party.

The first party is automatically placed on hold.

3. When connected to the second party, press

<Options> → Join.

4. Repeat steps 2 and 3 to add more parties (if

necessary).

5. To end the multiparty call, press [ ].

using advanced functions

Call an international number

1. In Idle mode, press and hold [0] to insert the +

character.

2. Enter the complete number you want to dial

(country code, area code, and phone number),

and then press [ ] to dial.

Call a contact from Phonebook

You can call numbers directly from Phonebook

using stored contacts.

p. 27

1. In Idle mode, press <Menu> → Phonebook.

You can also press <Phonebook> in Idle mode.

2. Scroll to the number you want to dial and press

[ ] to dial.

Make an SOS call

When you have an emergency, you can make an

SOS call asking for help.

1. In Idle mode, press <Menu> → Settings → SOS

settings → SOS call.

2. Scroll left or right to On.

3. Scroll down and press [OK] to open the recipient

list.

4. Press [OK] to open your contact list.

5. Scroll to a contact and press [OK].

6. Select a number (if necessary).

7. When you are finished selecting contacts, press

<Select> to return to the recipient list.

8. Press [OK] to save the recipients.

9. Press <Save>.

To make an SOS call, press and hold [SOS] in Idle

mode. You can also press [SOS] and select a

contact in Idle mode.

using advanced functions

Use advanced Phonebook functions

Learn to create namecards, set speed dial numbers,

and create groups of contacts.

Create a namecard

1. In Idle mode, press <Menu> → Phonebook.

You can also press <Phonebook> in Idle mode.

2. Press <Options> → My namecard.

3. Enter your personal details and press <Save>.

Set speed dial numbers

1. In Idle mode, press <Menu> → Phonebook.

You can also press <Phonebook> in Idle mode.

2. Press <Options> → Management→ Speed

dial.

3. Scroll to a number you want to set (2-9) and

press [OK].

4. Select a contact → a number (if necessary) to

assign to the number.

The contact is saved to the speed dial number.

Create a group of contacts

By creating groups of contacts, you can assign

ringtones and caller ID photos to each group or send

messages to an entire group. Start by creating a

group:

1. In Idle mode, press <Menu> → Phonebook.

You can also press <Phonebook> in Idle mode.

2. Scroll left or right to Group.

3. Press <Options> → Create group.

You can send your namecard by attaching it to

a message or transferring it via the Bluetooth

wireless feature.

You can now call this contact from Idle mode

by pressing and holding the assigned speed

dial number.

using advanced functions

4. Enter a group name.

5. To set the caller ID image, scroll down and press

[OK] → an image category → an image.

6. To set a group ringtone, scroll down and press

[OK] → a ringtone category → a ringtone.

7. Press <Save>.

Use advanced messaging functions

Learn to create templates, use templates to create

new messages, and use the messenger.

Create a text template

1. In Idle mode, press <Menu> → Messages →

Templates → Text message templates.

2. Select an empty location to open a new template

window.

3. Enter your text and press [OK] to save the

template.

Create a multimedia template

1. In Idle mode, press <Menu> → Messages →

Create message → Multimedia message.

2. Create a multimedia message, with a subject

and desired attachments, to use as your

template.

p. 25

3. Press <Options> → Save in → Templates to

save the template.

Insert text templates in new messages

1. To start a new message, press <Menu> →

Messages → Create message → a message

type.

2. In the text field, press <Options> → Insert →

Text template → a template.

using advanced functions

Create a message from a multimedia

template

1. In Idle mode, press <Menu> → Messages →

Templates → Multimedia message templates.

2. Scroll to the template you want and press

<Options> → Edit.

Your template opens as a new multimedia

message.

Use the Bluetooth messenger

Learn to chat with your family or friends instantly via

the Bluetooth wireless feature.

1. In Idle mode, press <Menu> → Messages →

Bluetooth messenger.

2. Press <Yes> to turn on the Bluetooth wireless

feature.

3. Press <Options> → Search Bluetooth contact

→ Search for new devices.

4. Scroll to a device and press <Select>.

5. Enter a PIN for the Bluetooth wireless feature or

the other device’s Bluetooth PIN, if it has one,

and press <OK>.

When the owner of the other device enters the

same code or accepts the connection, pairing is

complete.

6. Enter your message and press [OK].

Use advanced music functions

Learn to prepare music files, create playlists, and

store radio stations.

Copy music files via Samsung PC Studio

1. Using an optional PC data cable, connect the

multifunction jack on your phone to a PC.

using advanced functions

2. Run Samsung PC Studio and copy files from the

PC to the phone.

Refer to the Samsung PC Studio help for more

information.

Copy music files to a memory card

1. Insert a memory card.

2. Using an optional PC data cable, connect the

multifunction jack on your phone to a PC.

When connected, a pop-up window will appear

on the PC.

3. Select Open folder to view files in the pop-up

window on the PC.

4. Copy files from the PC to the memory card.

Create a playlist

1. In Idle mode, press [ ] → Playlists.

2. Press <Options> → Create playlist.

3. Enter a title for your new playlist and press [OK].

4. Select the new playlist.

5. Press <Options> → Add → Tracks.

6. Select the files you want to include and press

<Add>.

Customise your music player settings

Learn to adjust the playback and sound settings for

your music player.

1. In Idle mode, press [ ].

2. Press <Options> → Player settings.

3. Adjust the settings to customise your music

player.

4. Press <Save>.

using advanced functions

Store radio stations automatically

1. Plug the supplied headset.

2. In Idle mode, press <Menu> → Multimedia →

FM radio.

3. Press [OK] to start the FM radio.

4. Press <Options> → Self-tuning.

5. Press <Yes> to confirm (if necessary).

The radio scans and saves available stations

automatically.

using tools and

applications

Learn how to work with your mobile phone’s tools

and additional applications.

Use the Bluetooth wireless feature

Learn about your phone’s ability to connect to other

wireless devices for exchanging data and using

hands-free features.

Turn on the Bluetooth wireless feature

1. In Idle mode, press <Menu>

→

Bluetooth

→

Activation

→

On.

2. To allow other devices to locate your phone,

select My phone’s visibility

→

On.

Find and pair with other Bluetooth-

enabled devices

1. In Idle mode, press <Menu>

→

Bluetooth

→

devices

→

Search for new devices.

2. Scroll to a device and press <Select>.

using tools and applications

3. Enter a PIN for the Bluetooth wireless feature or

the other device’s Bluetooth PIN, if it has one,

and press <OK>.

When the owner of the other device enters the

same code or accepts the connection, pairing is

complete.

Send data using the Bluetooth wireless

feature

1. Select the file or item from one of your phone’s

applications that you want to send.

2. Press <Options> → Send via → Bluetooth

(when sending contact data, specify which data

to send).

Receive data using the Bluetooth

wireless feature

1. Enter the PIN for the Bluetooth wireless feature

and press <OK> (if necessary).

2. Press <Yes> to confirm that you are willing to

receive data from the device (if necessary).

Activate and send an SOS message

When you have an emergency, you can send an

SOS message asking for help.

1. In Idle mode, press <Menu> → Settings → SOS

settings → SOS messages → Sending

options.

2. Scroll left or right to On.

3. Scroll down and press [OK] to open the recipient

list.

4. Press [OK] to open your contact list.

5. Scroll to a contact and press [OK].

6. Select a number (if necessary).

This feature may not be available depending on

your region or service provider.

using tools and applications

7. When you are finished selecting contacts, press

<Select> to return to the recipient list.

8. Press [OK] to save the recipients.

9. Scroll down and set the number of times to

repeat the SOS message.

10. Press <Save> → <Yes>.

To send an SOS message, the phone must be

closed and the keys locked. Press [ / ] four times.

Activate the mobile tracker

When someone inserts a new SIM card in your

phone, the mobile tracker feature will automatically

send the contact number to two recipients to help

you locate and recover your phone.

To activate the mobile tracker,

1. In Idle mode, press <Menu> → Settings →

Security → Mobile tracker.

2. Enter your password and press <OK>.

3. Scroll left or right to On.

4. Scroll down and press [OK] to open the recipient

list.

5. Press <Options> → Phonebook to open your

contact list.

6. Scroll to a contact and press [OK].

7. Select a number (if necessary).

8. When you are finished selecting contacts, press

<Select> to return to the recipient list.

9. Press [OK] to save the recipients.

10.Scroll down and enter the sender’s name.

11.Press <Save> → <Accept>.

Once you send an SOS message, all phone

functions will be suspended until you press

[]

using tools and applications

Make fake calls

You can simulate fake incoming calls when you want

to get out of meetings or unwanted conversations.

You can also make it appear as if you are talking on

the phone by playing back a recorded voice.

To activate the fake call feature,

1. In Idle mode, press <Menu> → Settings →

Phone settings → Shortcuts and set a shortcut

key for Fake call.

2. Press [B-end] to return to Idle mode.

3. Press <Menu> → Settings → Application

settings → Fake call → Fake call voice.

To record a voice,

1. Press <Menu> → Settings → Application

settings → Fake call.

2. Scroll to Fake call voice.

3. Press <Options> → Edit.

4. Press <Record> to start recording.

5. Speak into the microphone.

6. When you are finished speaking, press the

navigation key down.

7. Press <Set> to set the recording as a response

for the fake call.

To make a fake call,

• press and hold the shortcut key in Idle mode

• press the shortcut key four times when the phone

is closed

using tools and applications

Record and play voice memos

Learn to operate your phone’s voice recorder.

Record a voice memo

1. In Idle mode, press <Menu> → Multimedia →

Voice recorder.

2. Press [OK] to start recording.

3. Speak your memo into the microphone.

4. When you are finished speaking, press the

navigation key down.

Play a voice memo

1. From the voice recorder screen, press

<Options> → My voice clips.

2. Select a file.

3. Control the playback using the following keys:

Use Java-powered games and

applications

Learn to use games and applications powered by

award-winning Java technology.

Play games

1. In Idle mode, press <Menu> → Applications →

Games and more → My games.

Key Function

Pause or resume playback

Adjust the volume up or down

Navigation

• Left: Scan backward in a file

• Right: Scan forward in a file

• Down: Stop playback

using tools and applications

2. Select a game from the list and follow the on-

screen instructions.

Launch applications

1. In Idle mode, press <Menu> → Applications →

Games and more → an application.

2. Press <Options> to access a list of various

options and settings for your application.

Create and view world clocks

Learn to view the time in another city and set world

clocks to appear on your display.

Create a world clock

1. In Idle mode, press <Menu> → Applications →

World clock.

2. Press <Options> → Add.

3. Scroll left or right to a time zone.

4. To set daylight saving time, scroll down and

press [OK].

5. Press <Save> to create your world clock.

The world clock is set as the second clock.

6. To add more world clocks, repeat steps 2-5

above.

Available games may vary, depending on your

region or service provider. Game controls and

options may vary.

using tools and applications

Add a world clock to your display

In Dual Clock Display mode, you can view clocks

with two different time zones on your display.

After you have created world clocks,

1. In Idle mode, press <Menu> → Applications →

World clock.

2. Scroll to the world clock you want to add and

press <Options> → Set as second clock.

3. Press <Options> → Clock display setting.

4. Scroll left or right to Dual.

5. Scroll down, and then scroll left or right to select

a dual clock style.

6. Press <Save>.

Set and use alarms

Learn to set and control alarms for important events.

Set a new alarm

1. In Idle mode, press <Menu> → Alarms.

2. Scroll to an empty alarm location and press [OK].

3. Set alarm details.

You can set either the FM radio or a sound for

the alarm tone.

4. Press <Save>.

Clock display setting

is deactivated, set

your wallpaper to


p. 23

The auto power-up feature sets the phone to

automatically turn on and sound the alarm at

the designated time if the phone is turned off.

using tools and applications

Stop an alarm

When the alarm sounds,

• Press <Exit> or any key to stop an alarm without

snooze.

• Press <Confirm> or [OK] to stop an alarm with

snooze, or press <Snooze> or any key to silence

the alarm for the snooze period.

Deactivate an alarm

1. In Idle mode, press <Menu> → Alarms.

2. Scroll to the alarm you want to deactivate and

press [OK].

3. Scroll down (if necessary).

4. Scroll left or right to Off.

5. Press <Save>.

Use the calculator

1. In Idle mode, press <Menu> → Applications →

Calculator.

2. Use the keys that correspond to the calculator

display to perform basic mathematical

operations.

Convert currencies or

measurements

1. In Idle mode, press <Menu> → Applications →

Convertor → a conversion type.

2. Enter the currencies or measurements and units

in the appropriate fields.

using tools and applications

Set a countdown timer

1. In Idle mode, press <Menu> → Applications →

Timer.

2. Press <Set>.

3. Enter the length of time to count down and press

<OK>.

4. Press [OK] to begin or pause the countdown.

5. When the timer expires, press <Exit> to stop the

alert.

Use the stopwatch

1. In Idle mode, press <Menu> → Applications →

Stopwatch.

2. Press [OK] to begin and record lap times.

3. Press <Reset> to clear recorded times.

Create a text memo

1. In Idle mode, press <Menu> → Applications →

Memo.

2. Press <Options> → Create.

3. Enter your memo text.

4. Press [OK].

using tools and applications

Manage your calendar

Learn to change the calendar view and create

events.

Change the calendar view

1. In Idle mode, press <Menu> → Calendar.

2. Press <Options> → View by → Day or Week.

Create an event

1. In Idle mode, press <Menu> → Calendar.

2. Press <Options> → Create → an event type.

3. Enter the details of the event as required.

4. Press <Save>.

troubleshooting

If you are having trouble with your mobile phone, try these troubleshooting procedures before contacting a service

professional.

While using your phone, the following messages

may appear:

Message Try this to solve the problem:

Insert SIM

card

Ensure that the SIM card is installed

correctly.

Phone lock

When the phone lock feature is

enabled, you must enter the password

you set for the phone.

PIN lock

When using the phone for the first time

or when the PIN requirement is

enabled, you must enter the PIN

supplied with the SIM card. You can

disable this feature by using the

lock

menu.

PUK lock

Your SIM card is blocked, usually as a

result of entering your PIN incorrectly

several times. You must enter the PUK

supplied by your service provider.

Message Try this to solve the problem:

troubleshooting

Your phone displays “Service unavailable” or

“Not done.”

• When you are in areas with weak signals or poor

reception, you may lose reception. Move to

another area and try again.

• You cannot access some options without a

subscription. Contact your service provider for

more details.

You enter a number, but the call is not dialled.

• Ensure that you have pressed the Dial key: [ ].

• Ensure that you have accessed the right cellular

network.

• Ensure that you have not set call barring for the

phone number.

Another caller cannot reach you.

• Ensure that your phone is turned on.

• Ensure that you have accessed the right cellular

network.

• Ensure that you have not set call barring for the

phone number.

Another caller cannot hear you speaking.

• Ensure that you are not covering the built-in

microphone.

• Ensure that the microphone is close to your

mouth.

• If using a headset, ensure that it is properly

connected.

The phone beeps and the battery icon flashes.

Your battery is low. Recharge or replace the battery to

continue using the phone.

troubleshooting

The audio quality of the call is poor.

• Ensure that you are not blocking the phone’s

internal antenna.

• When you are in areas with weak signals or poor

reception, you may lose reception. Move to

another area and try again.

You select a contact to call, but the call is not

dialled.

• Ensure that the correct number is stored in the

contact list.

• Re-enter and save the number, if necessary.

The battery does not charge properly or

sometimes the phone turns itself off.

• The battery terminals may be dirty. Wipe both

gold-coloured contacts with a clean, soft cloth

and try charging the battery again.

• If the battery will no longer charge completely,

dispose of the old battery properly and replace it

with a new battery.

Your phone is hot to the touch.

When you use several applications at once, your

phone requires more power and may heat up.

This is normal and should not affect your phone’s

lifespan or performance.

index

alarms

creating, 46

deactivating, 47

stopping, 47

battery

charging, 19

installing, 17

low battery indicator, 19

Bluetooth

activating, 40

receiving data, 41

sending data, 41

Bluetooth messenger 37

browser

see web browser

calculator

see tools, calculator

calendar

see tools, calendar

calls

advanced functions, 32

answering additional calls, 33

answering, 24

basic functions, 24

dialling additional calls, 33

dialling missed calls, 32

from Phonebook, 34

international numbers, 34

making fake calls, 43

making SOS calls, 34

making, 24

multiparty, 33

placing on hold, 33

recently dialled, 32

recording conversations, 25

retrieving held calls, 33

viewing missed, 32

conference calls

see calls, multiparty

contacts

adding, 27

creating groups, 35

finding, 27

index

convertor

see tools, convertor

countdown timer

see tools, countdown timer

fake calls

see calls, making fake calls

FM radio

listening to, 29

storing stations, 39

headset 25

internet

see web browser

Java

accessing applications, 45

launching games, 44

key tones 22

lock

see phone lock

memo

see text or voice memos

memory card 20

messages

sending instant (Bluetooth

messenger), 37

sending multimedia, 25

sending text, 25

viewing multimedia, 27

viewing text, 27

mobile tracker 42

multimedia

see messages

music player

creating playlists, 38

customising, 38

listening to music, 29

namecards 35

offline profile 21

phone lock 24

photos

capturing, 28

viewing, 28

radio

see FM radio

ringtone 22

Samsung PC Studio 37

shortcut keys

see shortcuts

shortcuts 23

index

silent profile 22

SIM card 17

SOS call

see calls, making SOS calls

SOS message 41

stopwatch

see tools, stopwatch

templates

inserting, 36

multimedia, 36

text, 36

text

creating memos, 48

entering, 26

messages, 25

timer

see tools, countdown timer

tools

alarm, 46

calculator, 47

calendar, 49

convertor, 47

countdown timer, 48

stopwatch, 48

videos

capturing, 28

viewing, 29

voice memos

playing, 44

recording, 44

volume

call volume, 24

key tone volume, 22

wallpaper 23

web browser

adding bookmarks, 31

launching homepage, 30

world clock

creating, 45

setting dual display, 46

Samsung Electronics Co SWDS3030Q Cellular/PCS GSM Phone with Bluetooth User Manual S3030

Samsung Electronics Co Ltd Cellular/PCS GSM Phone with Bluetooth S3030

Users Manual

Navigation menu

Namespaces

Views

Navigation
