Samsung Electronics Co SWDS7330 Cellular/PCS GSM/EDGE Phone with Bluetooth User Manual
Samsung Electronics Co Ltd Cellular/PCS GSM/EDGE Phone with Bluetooth Users Manual
Users Manual
* Depending on the software installed or your service provider or country, some of the descriptions in this guide
may not match your phone exactly.
* Depending on your country, your phone and accessories may appear different from the illustrations in this guide.
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-XXXXXA
English (EU). 05/2008. Rev. 1.0
Samsung S7330
User’s Guide
Important safety
precautions
Drive safely at all times
Do not use a hand-held phone while driving. Park
your vehicle first.
Switch off the phone when refuelling
Do not use the phone at a refuelling point (service
station) or near fuels or chemicals.
Switch off in an aircraft
Wireless phones can cause interference. Using
them in an aircraft is both illegal and dangerous.
Switch off the phone near all medical
equipment
Hospitals or health care facilities may be using
equipment that could be sensitive to external radio
frequency energy. Follow any regulations or rules in
force.
Interference
All wireless phones may be subject to interference,
which could affect their performance.
Failure to comply with the following
precautions may be dangerous or illegal.
Copyright information
• Bluetooth
®
is a registered trademark of
the Bluetooth SIG, Inc. worldwide.
Bluetooth QD ID: B0XXXXX
•Java
TM
is a trademark or registered
trademark of Sun Microsystems, Inc.
• Windows Media Player
®
is a registered
trademark of Microsoft Corporation.
S7330-Cover.fm Page 3 Monday, May 19, 2008 9:41 AM
1
Be aware of special regulations
Meet any special regulations in force in any area
and always switch off your phone whenever it is
forbidden to use it, or when it may cause
interference or danger.
Water resistance
Your phone is not water-resistant. Keep it dry.
Sensible use
Use only in the normal position (held to your ear).
Avoid unnecessary contact with the antenna when
the phone is switched on.
Emergency calls
Key in the emergency number for your present
location, then press .
Keep your phone away from small children
Keep the phone and all its parts, including
accessories, out of the reach of small children.
Accessories and batteries
Use only Samsung-approved batteries and
accessories, such as headsets and PC data cables.
Use of any unauthorised accessories could damage
you or your phone and may be dangerous.
Qualified service
Only qualified service personnel may repair your
phone.
For more detailed safety information, see "Health
and safety information" on page 43.
• The phone could explode if the battery is replaced
with an incorrect type.
• Dispose of used batteries according to the
manufacturer’s instructions.
At very high volumes, prolonged listening
to a headset can damage your hearing.
2
About this Guide
This User’s Guide provides you with condensed
information about how to use your phone.
In this guide, the following instruction icons
appear:.
Indicates that you need to pay careful
attention to the subsequent information
regarding safety or phone features.
→
Indicates that you need to press the
touch panel to scroll to the specified
option and then select it.
[ ] Indicates a key on the phone.
For example, [ ]
< > Indicates a soft key, whose function is
displayed on the phone screen. For
example, <
Select
>
•3G
Your phone is capable of
operating in a 3G environment,
allowing much greater data
transfer speed, video streaming,
and video conferencing.
Special
features of your phone
• User created theme
Create your own theme using
your favourite background
images and colours.
• MobileBlog
Share your photos and videos on
photo sharing websites and
blogs.
3
• RSS reader
Use RSS reader to get the latest
news from your favourite
websites.
• Camera and camcorder
Use the camera module on your
phone to take a photo or record
a video.
• Synchronisation with
Windows Media Player
Transfer music files to your
phone directly from Windows
Media Player.
•Music player
Play music files on your phone.
You can use other phone
functions while listening to
music.
•FM radio
Listen to your favourite radio
stations anytime, anywhere.
• Digital data printing
Print images, messages, and
personal data directly from your
phone.
•Bluetooth
Transfer media files and
personal data, and connect to
other devices using wireless
Bluetooth technology.
•Web browser
Access the wireless web to get
up-to-the-minute information
and a wide variety of media
content.
4
Contents
Unpack 6
Make sure you have each item
Get started 6
First steps to operating your phone
Assemble and charge the phone ...................... 6
Power on or off.............................................. 7
Phone layout ................................................. 7
Keys and icons .............................................. 8
Access menu functions .................................. 12
Enter text .................................................... 12
Customise your phone................................... 14
Step outside the phone 18
Begin with call functions, camera, music player, web
browser, and other special features
Make or answer calls ..................................... 18
Use the camera............................................ 20
Upload photos and videos to the web .............. 21
Play music................................................... 22
Listen to the FM radio ................................... 25
Browse the web ........................................... 26
Use Phonebook ............................................ 27
Send messages............................................ 28
View messages ............................................ 30
Use Bluetooth .............................................. 31
Menu functions 33
All menu options listed
Health and safety information 43
5
1 Call log
2 Phonebook
3 Multimedia
1 Music player
2 FM radio
3 Voice recorder
4 Browser1
1 Go to homepage
2 Enter URL
3 Bookmarks
4 Saved pages
5 History
6 Advanced
7 Browser settings
5 Messages
1 Create message
2 Inbox
5 Messages
3 Email inbox
4 Drafts
5 Outbox
6 Sentbox
7 My folders
8 Templates
9 Delete by folders
10 Settings
11 Memory status
6 My files2
Camera album
Images
Videos
Sounds
Games and more
Other files
Memory status
7 Calendar
8 Camera
9 Entertainment
1 Games and more
2 Image editor
3 Video editor
* Applications
1 Bluetooth
2 RSS reader
3 Memo
4 Task
5 World clock
6 Calculator
7 Convertor
8 Timer
9 Stopwatch
10 SIM application toolkit
3
0 Alarms
# Settings
1 Phone profiles
2 Time & date
3 Display & light settings
4 Phone settings
5 Call settings
6 Security
7 Application settings
8 Network settings
9 Memory settings
10 Master reset
11 Setup wizard
1. Labelled differently
depending on your service
provider.
2. Additional folders will be
available if you insert a
memory card.
3. Available only if supported
by your USIM or SIM card.
Overview of menu functions
To access Menu mode, press <
Menu
> in Idle mode.
6
Unpack
Make sure you have each item
• Phone
•Travel adapter
•Battery
• User’s Guide
You can obtain various accessories from your
local Samsung dealer.
Get started
First steps to operating your phone
Assemble and charge the phone
The items supplied with your phone and the
accessories available at your Samsung dealer
may vary, depending on your country or service
provider.
To AC pow e r outlet
7
Removing the battery cover
Power on or off
Phone layout
Front view
Switch on
1. Open the phone.
2. Press and hold [ ].
3. If necessary, enter the PIN
and press <
Confirm
>.
4. When the setup wizard opens,
customise your phone
according to your preferences.
Switch off
1. Open the phone.
2. Press and hold [ ].
Earpiece
Video call key
Dial key Power/
Menu exit key
Right soft key
Front camera
lens
Special
function keys
Multi-function
Jack
Delete key
Volume keys
Mouthpiece
Left soft key
Organiser key
Display
Touch panel
Alphanumeric
keys
Get started
8
Rear view
Keys and icons
Keys
When you close the phone, it locks the exposed
keys and the touch panel to prevent any
unwanted phone operations, from accidentally
pressing any of the keys. To unlock the keypad,
press <
Unlock
> and then <
OK
>.
Rear camera
lens
Camera key
Flashbulb
Memory card slot
Mirror
Perform the function indicated on the
bottom line of the display.
In Idle mode, press to access the
following menus directly:
• Centre: Simplified menus
• Up/Down/Left/Right: your
favourite menus (Depending on
the service provider, you can
access the Google service
directly.)
In Menu mode, scroll through menu
options ( / / / ), or select the
highlighted menu option or confirm
input (
OK
).
9
Make or answer a call.
In Idle mode, retrieve the numbers
recently dialled, missed, or received.
Press and hold to switch the phone
on or off.
End a call.
In Menu mode, cancel input and
return the phone to Idle mode.
In Idle mode, open the dialling
screen for video calls.
In the dialling screen, make a video
call.
Delete characters from the display or
items in an application.
In Idle mode, access Organiser
applications, such as Calendar,
Memo, Task, Alarms, and World
clock.
Enter numbers, letters, and some
special characters.
In Idle mode, press and hold [
1
] to
access your voicemail server. Press
and hold [
0
] to enter an international
call prefix.
Enter special characters or perform
special functions.
In Idle mode, press and hold [ ] to
activate or deactivate the Silent
profile. Press and hold [ ] to enter a
pause between numbers.
Get started
10
Icons
The following icons may appear on the top line
of the screen to indicate your phone’s status.
Depending on your country or service provider,
the icons shown on the display may vary.
Adjust the phone volume.
In Idle mode, press and hold to turn
on the camera.
In Camera mode, take a photo or
record a video.
Signal strength
Connecting to GPRS (2.5G)
network or transferring data in
GPRS (2.5G) network
Connecting to EDGE network or
transferring data in EDGE network
Connecting to UMTS (3G) network
or transferring data in UMTS (3G)
network
Connecting to HSDPA (3G+)
network or transferring data in
HSDPA (3G+) network
Voice call in progress
Video call in progress
Connected with PC via USB port
Browsing Internet
Connected to secured web page
Music playback in progress
11
Music playback paused
Music playback stopped
FM radio status:
•: On
•: Off
Bluetooth headset or hands-free
car kit connected
Bluetooth active
Alarm set
New message:
•: Text message
• : Multimedia message
•: Email
•: Voicemail
• : Push message
• : Configuration message
Memory card inserted
Profile setting:
•: Normal
• : Silent
• : Driving
• : Meeting
•: Outdoor
•: Offline
Get started
12
Access menu functions Enter text
Battery power level
Current time
Select an
option
1. Press a desired soft key.
2. Press the touch panel to
move to the next or previous
option.
3. Press <
Select
>, <
OK
>, or
[
OK
] to confirm the function
displayed or option
highlighted.
4. Press <
Back
> to move up
one level.
Press [ ] to return to Idle
mode.
Use menu
numbers
Press the number key
corresponding to the option you
want.
Change the
text input
mode
• Press and hold [ ] to switch
between T9 mode and ABC
mode.
• Press [ ] to change case or
switch to Number mode.
• Press and hold [ ] to switch
to Symbol mode.
ABC mode
To e nt e r a w or d:
Press the appropriate key until
the character you want appears
on the display.
13
T9 mode
To e nt e r a w or d:
1. Press [
2
] to [
9
]
to start
entering a word.
2. Enter the whole word before
editing or deleting
characters.
3. When the word displays
correctly, press [ ] to insert
a space.
Otherwise, press [
0
] to
display alternate word
choices.
Number
mode
Press the keys corresponding to
the digits you want.
Symbol
mode
Press the keys corresponding to
the symbols you want.
Other
operations
• Press [
1
] to enter
punctuation marks or special
characters.
• Press [ ] to insert a space.
• Press the touch panel to
move the cursor.
• Press [
C
] to delete
characters one by one.
• Press and hold [
C
] to clear
the entire display.
Get started
14
Customise your phone
1. In Idle mode, press
<
Menu
> and select
Settings
→
Phone
settings
→
Language
→
Screen text
.
2. Select a language.
3. Press <
Save
>.
To change the profile
properties:
1. In Idle mode, press
<
Menu
> and select
Settings
→
Phone
profiles
.
2. Scroll to the sound profile
you are using.
Display
language
Call ringer
melody
3. Press <
Options
> and
select
Edit
.
4. Select
Voice call ringtone
→
a category
→
a ringtone.
5. Select
Video call ringtone
→
a category
→
a ringtone.
6. Press <
Options
> and
select
Save
.
To change the sound profile:
1. In Idle mode, press
<
Menu
> and select
Settings
→
Phone
profiles
.
2. Select the profile you want.
3. Press [ ].
15
In Idle mode, press [ / ] to
adjust the key tone volume.
1. In Idle mode, press
<
Menu
> and select
Settings
→
Display &
light settings
→
Display
→
Wallpaper
→
Images
.
2. Select an image category.
3. Select an image.
4. Press <
Set
>.
Key tone
volume
Idle mode
wallpaper
To create a theme:
1. In Idle mode, press
<
Menu
> and select
Settings
→
Display &
light settings
→
Display
→
My theme
.
2. Press <
Options
> and
select
Create
→
Easy
or
Expert
.
3. Customise the theme as
desired by following the
screen.
4. When you have finished,
enter a name for the theme
and press <
Save
>.
5. Press <
Yes
> to apply the
theme.
Themes for
the display
Get started
16
To apply a theme:
1. In Idle mode, press
<
Menu
> and select
Settings
→
Display &
light settings
→
Display
→
My theme
.
2. Select a theme.
3. Press <
Save
>.
To restore the default theme quickly, enter [ ],
[], [
8
], [
2
], [
7
], and [ ] in Idle mode. Your
phone restarts automatically and uses the
default theme.
1. In Idle mode, press
<
Menu
> and select
Settings
→
Phone
settings
→
Shortcuts
.
2. Select a direction.
3. Select a menu to be
assigned to the direction.
4. Press <
Save
>.
Menu
shortcuts
17
To set up Simplified menu
items:
1. In Idle mode, press [ ].
2. Press <
Options
> and
select
Customise menu
.
3. Select your favourite
menus.
4. Press <
Options
> and
select
Save
.
To access an item from the
Simplified menus:
1. In Idle mode, press [ ].
2. Scroll to the menu item you
want and press [
OK
].
Simplified
menus
You can activate the Silent
profile to avoid disturbing
other people. In Idle mode,
press and hold [ ].
1. In Idle mode, press
<
Menu
> and select
Settings
→
Security
→
Phone lock
.
2. Select
On
.
3. Press <
Save
>.
4. Enter a new 4- to 8-digit
password and press
<
Confirm
>.
5. Enter the new password
again and press
<
Confirm
>.
Silent profile
Phone lock
18
Step outside the phone
Begin with call functions, camera, music player,
web browser, and other special features
Make or answer calls
To make a voice call:
1. In Idle mode, enter an
area code and phone
number.
2. Press [ ].
Press [ / ] to adjust the
volume.
3. Press [ ] to end the call.
Make a call
To make a video call:
1. In Idle mode, enter an
area code and phone
number.
2. Press [ ].
3. Press [ ] to end the call.
1. When the phone rings,
open the phone. If the
phone is already open,
press [ ].
If it is a video call, press
<
Show me
> to allow the
caller to see you via the
camera.
2. Press [ ] to end the call.
Answer a call
19
During a voice call, press [ ]
and then <
Yes
> to activate
the speaker.
Press [ ] again to switch back
to the earpiece.
1. During a call, call the
second participant.
The first call is put on
hold.
2. Press <
Options
> and
select
Conference call
.
3. Repeat step 1 and 2 to
add more participants.
Use the
speakerphone
feature
Make a
multi-party
call
4. During a multi-party call:
• Press <
Options
> and
select
Private call
to
have a private
conversation with one
participant.
• Press <
Options
> and
select
End
→
Select
participant
→
a
participant
→
Drop
to
drop one participant.
5. Press [ ] to end the
multi-party call.
Step outside the phone
20
Use the camera
1. In Idle mode, press and
hold [ ].
2. Rotate the phone to the
left for landscape view.
3. Aim the lens at the subject
and make any desired
adjustments.
4. Press [ ] to take a photo.
The photo is saved
automatically.
5. Press < > or [ ] to take
another photo.
Take a photo
1. In Idle mode, press
<
Menu
> and select
My
files
→
Camera album
.
2. Select the photo you want.
1. In Idle mode, press and hold
[].
2. Press [
1
] repeatedly to
switch to Record mode.
3. Rotate the phone to the left
for landscape view.
4. Press [ ] to start recording.
5. Press < > or [ ] to stop
recording. The video is
saved automatically.
6. Press < > or [ ] to
record another video.
View a photo
Record
a video
21
Upload photos and videos to the
web
1. In Idle mode, press
<
Menu
> and select
My
files
→
Camera album
.
2. Select the video you want.
1. In Idle mode, press
<
Menu
> and select
Settings
→ Application
settings → MobileBlog
settings → ShoZu
activation
.
2. Select
On
.
3. Follow the onscreen
instructions to activate the
account.
View a video
Activate the
ShoZu
account
1. In Idle mode, press
<
Menu
> and select
Settings
→ Application
settings → MobileBlog
settings → Destinations.
2. Press <
Options
> and
select
Create new
.
3. Follow the onscreen
instructions to add a new
destination site.
1. Access an application, such
as
My files
or
Camera
.
2. Select or capture a photo or
video.
3. Press <
Options
> and
select
Upload to web
.
Set a
destination
site
Upload a file
Step outside the phone
22
Play music
4. Select a destination.
5. Enter the title and
description, and select a
tag.
6. Press <
Upload
>.
Use these methods:
• Download from the wireless
web.
• Download from a PC using
the optional Samsung PC
Studio. See Samsung PC
Studio User’s Guide.
• Receive via Bluetooth.
Prepare
music files
• Copy to a memory card.
See the next section.
• Synchronise music files with
Windows Media Player. See
page 23.
• Your phone accepts microSD™ memory cards
up to 8 GB (depending on memory card
manufacturer and type).
• When inserting a memory card with a large
amount of files, your phone might work rather
slowly for a few minutes while database
updates. This may also affect some phone
functions. This problem is temporary and is
not a phone defect.
23
1. Insert a memory card into
the phone.
2. In Idle mode, press
<
Menu
> and select
Settings
→
Phone
settings
→
PC
connections
→
Mass
storage
.
3. Press <
Save
>.
4. Press [ ] to return to Idle
mode.
5. Connect your phone and PC
with an optional PC data
cable.
6. Select
Open folder to
view files
when a pop-up
window appears on your PC.
Copy music
files to a
memory card
7. Copy files from the PC to
the memory card.
8. When you have finished,
disconnect the phone from
the PC.
You can copy music files to
your phone by synchronising
with Windows Media Player 11.
1. In Idle mode, press
<
Menu
> and select
Settings
→
Phone
settings
→
PC
connections
→
Media
player
.
2. Press <
Save
>.
3. Press [ ] to return to Idle
mode.
Synchronise
with Windows
Media Player
Step outside the phone
24
4. Connect your phone and PC
with an optional PC data
cable.
5. Select
Sync digital media
files to this device
when
a pop-up window appears
on your PC.
6. Enter the name of your
phone and click
Finish
.
7. Select and drag the music
files you want to the sync
list.
8. Click
Start Sync
.
9. When synchronisation is
finished, disconnect the
phone from the PC.
1. In Idle mode, press <
Menu
>
and select
Multimedia
→
Music player
.
2. Select a music category
→
a
music file.
3. During playback, use the
following keys:
•/: pause or resume
playback.
• : return to the previous
file. Press and hold to
scan backward in a file.
• : skip to the next file.
Press and hold to scan
forward in a file.
• : open the playlist.
•/: adjust the volume.
4. Press [ ] to stop playback.
Play music
files
25
Listen to the FM radio
1. From the music player
screen, press <
Options
>
and select
Open playlist
→
All
→
Playlists
.
2. Press <
Options
> and
select
Create playlist
.
3. Enter the title of the
playlist and press [
OK
].
4. Select the added playlist.
5. Press <
Options
> and
select
Add
→
a source.
6. Select a playlist, or select
the files you want and
press <
OK
>.
7. Press [
OK
] to play music.
Create a
playlist
1. Plug the connecter of the
supplied headset into the
multi-function jack on the
phone.
2. In Idle mode, press
<
Menu
> and select
Multimedia
→
FM radio
.
3. When you turn on the FM
radio for the first time,
press <
Yes
> to start
automatic tuning.
Available radio stations are
automatically saved.
Listen to
the radio
Step outside the phone
26
Browse the web
4.Press [] or [] to find
available radio stations.
Alternatively, press [ ] or
[ ] to select a stored radio
station.
5. Press [ ] to turn off the
radio.
By automatic tuning:
1. From the radio screen,
press <
Options
> and
select
Self-tuning
.
2. Press <
Yes
> to confirm.
Available radio stations are
automatically saved.
Store radio
stations
By manual setup:
1. From the radio screen,
press [ ] or [ ] to select
the radio station you
want.
2. Press <
Options
> and
select
Add to
Favourites
.
In Idle mode, press <
Menu
>
and select
Browser
→
Go to
homepage
. The homepage of
your service provider opens.
Launch the
web browser
27
Use Phonebook
• To scroll through browser
items, press [ ] or [ ].
• To select an item, press
[
OK
].
• To return to the previous
page, press <
Back
>.
• To access browser options,
press <
Options
>.
1. In Idle mode, enter a phone
number and press
<
Options
>.
2. Select
Add to Phonebook
→
a memory location
→
New
.
Navigate
the web
Add a contact
3. For
Phone
, select a number
type.
4. Specify contact information.
5. Press [ ], or press
<
Options
> and select
Save
to save the contact.
1. In Idle mode, press
<
Contacts
>.
2. Enter the first few letters of
the name you want.
3. Select a contact.
4. Scroll to a number and
press [ ] to dial, or press
<
Options
> and select
Edit
to edit contact information.
Find a contact
Step outside the phone
28
Send messages
1. In Idle mode, press
<
Menu
> and select
Messages
→
Create
message
→
Message
.
2. Enter the message text.
3. Press [ ] to move to the
recipient field.
4. Enter destination numbers.
5. Press <
Options
> and
select
Send
to send the
message.
Send a text
message
1. In Idle mode, press
<
Menu
> and select
Messages
→
Create
message
→
Message
.
2. Enter the message text.
3. Press <
Options
> and
select
Add item
,
Create
item
, or
Add attachment
.
4. Add a media file, contact,
calendar item, or bookmark
item.
5. Press <
Options
> and
select
Add subject
.
6. Enter the message subject.
7. Press [ ] to move to the
recipient field.
Send a
multimedia
message
29
8. Enter destination numbers
or email addresses.
9. Press <
Options
> and
select
Send
to send the
message.
1. In Idle mode, press
<
Menu
> and select
Messages
→
Create
message
→
Email
.
2. Enter the email text.
3. Press <
Options
> and
select
Add attachment
or
Create item
.
4. Add a media file, contact,
calendar item, or bookmark
item.
Send an email
5. Press [ ] to move to the
subject field.
6. Enter the email subject.
7. Press [ ] to move to the
recipient field.
8. Enter email addresses.
9. Press <
Options
> and
select
Send
to send the
email.
Step outside the phone
30
View messages
1. In Idle mode, press
<
Menu
> and select
Messages
→
Inbox
.
2. Select a text message.
1. In Idle mode, press
<
Menu
> and select
Messages
→
Inbox
.
2. Select a multimedia
message.
View a text
message
View a
multimedia
message
1. In Idle mode, press
<
Menu
> and select
Messages
→
Email inbox
.
2. Press <
Options
> and
select
Download
.
3. Select an email or a header.
4. If you selected a header,
press <
Options
> and
select
Retrieve
to view the
body of the email.
View an email
31
Use Bluetooth
Your phone is equipped with Bluetooth
technology, enabling you to connect the phone
wirelessly to other Bluetooth devices and
exchange data with them, talk hands-free, or
control the phone remotely.
1. In Idle mode, press
<
Menu
> and select
Applications
→
Bluetooth
→
Activation
→
On
.
2. Select
My phone’s
visibility
→
On
to allow
other devices to locate your
phone.
Turn on
Bluetooth
1. In Idle mode, press
<
Menu
> and select
Applications
→
Bluetooth
→
My devices
→
Search
for new device
.
2. Select a device.
3. Enter a Bluetooth PIN or the
other device’s Bluetooth
PIN, if it has one, and press
<
OK
>.
When the owner of the
other device enters the
same code, pairing is
complete.
Search for
and pair with
a Bluetooth
device
Step outside the phone
32
1. Access an application, such
as
Phonebook
,
My files
,
Calendar
,
Memo
, or
Task
.
2. Select an item.
3. Press <
Options
> and
select
Send namecard
via
or
Send via
→
Bluetooth
.
4. Search for and select a
device.
5. If necessary, enter the
Bluetooth PIN and press
<
OK
>.
Send data
1. If necessary, enter the
Bluetooth PIN and press
<
OK
>.
2. Press <
Yes
> to confirm
that you are willing to
receive.
Receive data
33
Menu functions
All menu options listed
This section provides brief explanations of
menu functions on your phone.
Call log
Check the most recent calls dialled, received, or
missed.
Phonebook
Search for contact information stored in
Phonebook.
Multimedia
Menu Description
Music player Access and listen to all
music files sorted by
criteria. You can also make
your own music playlists.
FM radio Listen to music or news via
the FM radio on your
phone.
Voice recorder Record voice memos and
any other sounds.
Menu functions
34
Browser
Menu Description
Go to homepage Connect your phone to the
network and load the
homepage of the wireless
web service provider.
Enter URL Enter a URL address and
access the associated web
page.
Bookmarks Save URL addresses in
order to quickly access
web pages.
Saved pages Access the list of pages
you have saved while
online.
History Access the list of pages
you have accessed
recently.
Advanced Clear the cache. Delete
cookies or set whether or
not they are stored.
Change the settings for the
web browser and access
version and copyright
information about it.
Browser settings Select a connection profile
to be used for accessing
the wireless web.
Menu Description
35
Messages
Menu Description
Create message Create and send text,
multimedia, or email
messages.
Inbox Access messages that you
have received.
Email inbox Access emails that you
have received.
Drafts Access messages that you
have saved to send at a
later time.
Outbox Access messages that the
phone is attempting to
send or has failed to send.
Sentbox Access messages that you
have sent.
My folders Create new folders and
organise your messages.
Templates Make and use templates of
frequently used messages
or passages.
Delete by folders Delete messages in each
message folder all at once.
Settings Set up various options for
using the messaging
services.
Memory status Check information about
the memory currently in
use.
Menu Description
Menu functions
36
My files Calendar
Keep track of your schedule.
Camera
Use the camera embedded in your phone to
take photos and record videos.
Entertainment
Menu Description
Camera album Access the list of photos
and videos you have taken
and recorded.
Images, Videos,
Sounds, Other
files
Access media files and
other files stored in the
phone’s memory.
Games and more Access and download Java
contents.
Memory status Check information about
the memory currently in
use.
Additional folders will be available if you insert a
memory card.
Menu Description
Games and more Access the embedded Java
games and download Java
contents.
Image editor Edit your images using
various editing tools.
37
Applications
Video editor Edit your videos by
combining photos or
videos.
Menu Description
Bluetooth Connect the phone
wirelessly to other
Bluetooth devices.
RSS reader Save your favourite news
channels or blogs to
libraries and get the latest
news and updated
information from them
whenever you want.
Menu Description
Memo Make memos for things
that are important and
manage them.
Task Make a list of tasks you
need to complete.
World clock Set your local time zone
and find out the current
time in another part of the
world.
Calculator Perform arithmetic
functions.
Convertor Do conversions, such as
length and temperature.
Timer Set a period of time for the
phone to count down.
Menu Description
Menu functions
38
Alarms
Set a wake-up alarm to wake you up in the
morning or an alarm to alert you to an event at
a specific time.
Settings
Stopwatch Measure elapsed time.
SIM application
toolkit
Use a variety of additional
services offered by your
service provider.
Depending on your USIM
or SIM card, this menu
may be available but
labelled differently.
Menu Description
Menu Description
Phone profiles Change the sound settings
of the phone for different
events or situations.
Time & date Change the time and date
displayed on your phone.
Display & light
settings
→
Display
→
Home
screen
Change the background
image that is displayed in
Idle mode.
Display & light
settings
→
Display
→
My
theme
Select or create a theme
for the phone display.
39
Display & light
settings
→
Display
→
Greeting
message
Enter the greeting that is
displayed briefly when the
phone is switched on.
Display & light
settings
→
Display
→
Dialling display
Customise the settings for
the display while dialling.
Display & light
settings
→
Touch
panel
Change the colour of the
touch panel for your
presses.
Display & light
settings
→
Light
→
LCD
brightness
Adjust the brightness of
the display for varying
lighting conditions.
Menu Description
Display & light
settings
→
Light
→
Backlight time
Select the length of time
the backlight or display
stays on when the phone is
not used.
Display & light
settings
→
Light
→
Keypad light
Set how the phone
controls the use of the
keypad light.
Phone settings
→
Language
Select a language to be
used for the display text or
T9 input mode.
Phone settings
→
Shortcuts
Use the touch panel as
shortcuts to access specific
menus directly from Idle
mode.
Phone settings
→
Own numbers
Check your phone
numbers or assign a name
to each of the numbers.
Menu Description
Menu functions
40
Phone settings
→
Volume key
function
Set how the phone reacts
if you press and hold [ / ]
when a call comes in.
Phone settings
→
Slide settings
Set how the phone reacts
when you open it for an
incoming call, and when
you close it while using a
function.
Phone settings
→
Touch sensitivity
Adjust the sensitivity level
of the touch panel to
better recognise your
press.
Phone settings
→
Vibration
feedback
Set the phone to vibrate
when you press the touch
panel.
Menu Description
Phone settings
→
PC connections
Select a USB mode that
will be used when you
connect your phone to a
PC via USB interface.
Call settings Set options for call
functions.
Security
→
Phone
lock
Activate your phone
password to protect your
phone against
unauthorised use.
Security
→
SIM
lock
Set the phone to work only
with the current USIM or
SIM card by assigning a
SIM lock password.
Menu Description
41
Security
→
PIN
lock
Activate your PIN to
protect your USIM or SIM
card against unauthorised
use.
Security
→
Privacy lock
Lock access to messages,
files, call logs, contacts,
calendar, memos, or tasks.
Security
→
Fixed
dialling mode
Set the phone to restrict
calls to a limited set of
phone numbers, if
supported by your USIM or
SIM card.
Security
→
Change phone
password
Change the phone
password.
Security
→
Change PIN code
Change the PIN.
Menu Description
Security
→
Change PIN2
code
Change the PIN2.
Security
→
Mobile tracker
Set the phone to send the
preset tracking message to
your family or friends
when someone tries to use
your phone with another
USIM or SIM card. This
feature may be unavailable
due to certain features
supported by your service
provider.
Application
settings
Customise the settings for
using applications
available on the phone.
Menu Description
Menu functions
42
Network settings
→
Network
selection
Select the network to be
used while roaming
outside of your home area,
or let the network be
chosen automatically.
Network settings
→
Network mode
Change to an appropriate
band when you travel
abroad.
Network settings
→
Preferred
networks
Add a new network to your
preferred network list, if
your USIM or SIM card
supports it.
Network settings
→
Connections
Create and customise the
profiles containing the
settings for connecting
your phone to the
network.
Menu Description
Memory settings Check information about
the memory currently in
use. You can also clear the
memory.
Master reset Reset the phone’s settings
you have changed.
Setup wizard Quickly customise basic
settings of your phone.
Select the option you want
for each setting by
following the onscreen
instructions.
Menu Description
43
Health and safety information
SAR certification information
This phone meets European Union (EU) requirements
concerning exposure to radio waves.
Your mobile phone is a radio transmitter and receiver. It
is designed and manufactured to not exceed the limits
for exposure to radio-frequency (RF) energy, as
recommended by the EU Council. These limits are part
of comprehensive guidelines and establish permitted
levels of RF energy for the general population. The
guidelines were developed by independent scientific
organisations through the periodic and thorough
evaluation of scientific studies. The limits include a
substantial safety margin designed to ensure the safety
of all persons, regardless of age and health.
The exposure standard for mobile phones employs a
unit of measurement known as Specific Absorption Rate
(SAR). The SAR limit recommended by the EU Council is
2.0 W/kg.
1
The highest SAR value for this model phone was 0.XXX
W/kg.
SAR tests are conducted using standard operating
positions with the phone transmitting at its highest
certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified
power level, the actual SAR level of the phone while
operating can be well below the maximum value. This is
because the phone is designed to operate at multiple
power levels so as to use only the power required to
reach the network. In general, the closer you are to a
base station, the lower the power output of the phone.
Before a new model phone is available for sale to the
public, compliance with the European R&TTE Directive
must be shown. This directive includes as one of its
essential requirements the protection of the health and
safety of the user and any other person.
1. The SAR limit for mobile phones used by the public is 2.0
watts/kilogram (W/kg) averaged over ten grams of body
tissue. The limit incorporates a substantial margin of safety to
give additional protection for the public and to account for any
variations in measurements. The SAR values may vary,
depending on national reporting requirements and the
network band.
41
Health and safety
information
Exposure to Radio Frequency (RF)
Signals
Certification Information (SAR)
Your wireless phone is a radio transmitter
and receiver. It is designed and
manufactured not to exceed the exposure
limits for radio frequency (RF) energy set by
the Federal Communications Commission
(FCC) of the U.S. government. These FCC
exposure limits are derived from the
recommendations of two expert
organizations, the National Counsel on
Radiation Protection and Measurement
(NCRP) and the Institute of Electrical and
Electronics Engineers (IEEE). In both cases,
Memory status Check memory information
for each items in the
phone’s memory or on a
memory card.
Reset settings Reset the phone’s settings
you have changed.
Key
management
Manage the licence keys
you have acquired to
activate media files locked
by DRM systems.
Menu Description
E840-2.fm Page 41 Monday, May 14, 2007 9:04 AM
Health and safety information
42
the recommendations were developed by
scientific and engineering experts drawn
from industry, government, and academia
after extensive reviews of the scientific
literature related to the biological effects of
RF energy.
The exposure limit set by the FCC for
wireless mobile phones employs a unit of
measurement known as the Specific
Absorption Rate (SAR). The SAR is a
measure of the rate of absorption of RF
energy by the human body expressed in
units of watts per kilogram (W/kg). The FCC
requires wireless phones to comply with a
safety limit of 1.6 watts per kilogram (1.6
W/kg). The FCC exposure limit incorporates
a substantial margin of safety to give
additional protection to the public and to
account for any variations in measurements.
SAR tests are conducted using standard
operating positions accepted by the FCC with
the phone transmitting at its highest
certified power level in all tested frequency
bands. Although the SAR is determined at
the highest certified power level, the actual
SAR level of the phone while operating can
be well below the maximum value. This is
because the phone is designed to operate at
E840-2.fm Page 42 Monday, May 14, 2007 9:04 AM
E840-2.fm Page 43 Monday, May 14, 2007 9:04 AM
43
For body worn operations, this model phone
has been testde and meets the FCC
exposure guidelines when used with a
Samsung accessory designated for this
product or when used with an accessroy that
contains no metal and that positons the
handset a minimum 1.5 cm from the body.
Non-compliance with the above restrictions
may result in violation of FCC RF exposure
guidelines.
SAR information on this and other model
phones can be viewed on-line at
www.fcc.gov/oet/fccid. This site uses the
phone FCC ID number A3LSWDS7330.
Sometimes it may be necessary to remove
the battery pack to find the number. Once
you have the FCC ID number for a particular
phone, follow the instructions on the website
and it should provide values for typical or
maximum SAR for a particular phone.
Additional product specific SAR information
can also be obtained at www.fcc.gov/cgb/
sar.
43
multiple power levels so as to use only the
power required to reach the network. In
general, the closer you are to a wireless
base station antenna, the lower the power
output.
Before a new model phone is available for
sale to the public, it must be tested and
certified to the FCC that it does not exceed
the exposure limit established by the FCC.
Tests for each model phone are performed in
positions and locations (e.g. at the ear and
worn on the body) as required by the FCC.
The highest SAR values for this model phone
as reported to the FCC are : GSM850
Mode Head: 0.447W/Kg, Body-worn:1
.05W/Kg. GSM1900 Mode
Head: 0.375W/Kg, Body-worn:0.587W/Kg.
Health and safety information
44
Consumer Information on Wireless
Phones
The U.S. Food and Drug Administration
(FDA) has published a series of Questions
and Answers for consumers relating to radio
frequency (RF) exposure from wireless
phones. The FDA publication includes the
following information:
What kinds of phones are the subject
of this update?
The term wireless phone refers here to
hand-held wireless phones with built-in
antennas, often called “cell,” “mobile,” or
“PCS” phones. These types of wireless
phones can expose the user to measurable
radio frequency energy (RF) because of the
short distance between the phone and the
user's head. These RF exposures are limited
by Federal Communications Commission
safety guidelines that were developed with
the advice of FDA and other federal health
and safety agencies. When the phone is
located at greater distances from the user,
the exposure to RF is drastically lower
because a person's RF exposure decreases
rapidly with increasing distance from the
source. The so-called “cordless phones,”
which have a base unit connected to the
telephone wiring in a house, typically
operate at far lower power levels, and thus
produce RF exposures well within the FCC's
compliance limits.
Do wireless phones pose a health
hazard?
The available scientific evidence does not
show that any health problems are
associated with using wireless phones. There
is no proof, however, that wireless phones
are absolutely safe. Wireless phones emit
low levels of radio frequency energy (RF) in
the microwave range while being used. They
E840-2.fm Page 44 Monday, May 14, 2007 9:04 AM
45
also emit very low levels of RF when in the
stand-by mode. Whereas high levels of RF
can produce health effects (by heating
tissue), exposure to low level RF that does
not produce heating effects causes no
known adverse health effects. Many studies
of low level RF exposures have not found
any biological effects. Some studies have
suggested that some biological effects may
occur, but such findings have not been
confirmed by additional research. In some
cases, other researchers have had difficulty
in reproducing those studies, or in
determining the reasons for inconsistent
results.
What is FDA's role concerning the
safety of wireless phones?
Under the law, FDA does not review the
safety of radiation-emitting consumer
products such as wireless phones before
they can be sold, as it does with new drugs
or medical devices. However, the agency has
authority to take action if wireless phones
are shown to emit radio frequency energy
(RF) at a level that is hazardous to the user.
In such a case, FDA could require the
manufacturers of wireless phones to notify
users of the health hazard and to repair,
replace or recall the phones so that the
hazard no longer exists.
Although the existing scientific data do not
justify FDA regulatory actions, FDA has
urged the wireless phone industry to take a
number of steps, including the following:
E840-2.fm Page 45 Monday, May 14, 2007 9:04 AM
Health and safety information
46
• “Support needed research into possible
biological effects of RF of the type
emitted by wireless phones;
• “Design wireless phones in a way that
minimizes any RF exposure to the user
that is not necessary for device function;
and
• “Cooperate in providing users of wireless
phones with the best possible
information on possible effects of
wireless phone use on human health.
FDA belongs to an interagency working
group of the federal agencies that have
responsibility for different aspects of RF
safety to ensure coordinated efforts at the
federal level. The following agencies belong
to this working group:
• “National Institute for Occupational
Safety and Health
• “Environmental Protection Agency
• “Federal Communications Commission
• “Occupational Safety and Health
Administration
• “National Telecommunications and
Information Administration
The National Institutes of Health participates
in some interagency working group
activities, as well.
FDA shares regulatory responsibilities for
wireless phones with the Federal
Communications Commission (FCC). All
phones that are sold in the United States
must comply with FCC safety guidelines that
limit RF exposure. FCC relies on FDA and
other health agencies for safety questions
about wireless phones.
FCC also regulates the base stations that the
wireless phone networks rely upon. While
these base stations operate at higher power
E840-2.fm Page 46 Monday, May 14, 2007 9:04 AM
47
than do the wireless phones themselves, the
RF exposures that people get from these
base stations are typically thousands of
times lower than those they can get from
wireless phones. Base stations are thus not
the primary subject of the safety questions
discussed in this document.
What are the results of the research
done already?
The research done thus far has produced
conflicting results, and many studies have
suffered from flaws in their research
methods. Animal experiments investigating
the effects of radio frequency energy (RF)
exposures characteristic of wireless phones
have yielded conflicting results that often
cannot be repeated in other laboratories. A
few animal studies, however, have
suggested that low levels of RF could
accelerate the development of cancer in
laboratory animals. However, many of the
studies that showed increased tumor
development used animals that had been
genetically engineered or treated with
cancer-causing chemicals so as to be pre-
disposed to develop cancer in absence of RF
exposure. Other studies exposed the
animals to RF for up to 22 hours per day.
These conditions are not similar to the
conditions under which people use wireless
phones, so we don't know with certainty
what the results of such studies mean for
human health.
Three large epidemiology studies have been
published since December 2000. Between
them, the studies investigated any possible
association between the use of wireless
phones and primary brain cancer, glioma,
meningioma, or acoustic neuroma, tumors
E840-2.fm Page 47 Monday, May 14, 2007 9:04 AM
Health and safety information
48
of the brain or salivary gland, leukemia, or
other cancers. None of the studies
demonstrated the existence of any harmful
health effects from wireless phones RF
exposures. However, none of the studies can
answer questions about long-term
exposures, since the average period of
phone use in these studies was around three
years.
What research is needed to decide
whether RF exposure from wireless
phones poses a health risk?
A combination of laboratory studies and
epidemiological studies of people actually
using wireless phones would provide some
of the data that are needed. Lifetime animal
exposure studies could be completed in a
few years. However, very large numbers of
animals would be needed to provide reliable
proof of a cancer promoting effect if one
exists. Epidemiological studies can provide
data that is directly applicable to human
populations, but ten or more years' follow-
up may be needed to provide answers about
some health effects, such as cancer. This is
because the interval between the time of
exposure to a cancer-causing agent and the
time tumors develop - if they do - may be
many, many years. The interpretation of
epidemiological studies is hampered by
difficulties in measuring actual RF exposure
during day-to-day use of wireless phones.
Many factors affect this measurement, such
as the angle at which the phone is held, or
which model of phone is used.
What is FDA doing to find out more
about the possible health effects of
wireless phone RF?
E840-2.fm Page 48 Monday, May 14, 2007 9:04 AM
49
FDA is working with the U.S. National
Toxicology Program and with groups of
investigators around the world to ensure
that high priority animal studies are
conducted to address important questions
about the effects of exposure to radio
frequency energy (RF).
FDA has been a leading participant in the
World Health Organization international
Electromagnetic Fields (EMF) Project since
its inception in 1996. An influential result of
this work has been the development of a
detailed agenda of research needs that has
driven the establishment of new research
programs around the world. The Project has
also helped develop a series of public
information documents on EMF issues.
FDA and Cellular Telecommunications &
Internet Association (CTIA) have a formal
Cooperative Research and Development
Agreement (CRADA) to do research on
wireless phone safety. FDA provides the
scientific oversight, obtaining input from
experts in government, industry, and
academic organizations. CTIA-funded
research is conducted through contracts to
independent investigators. The initial
research will include both laboratory studies
and studies of wireless phone users. The
CRADA will also include a broad assessment
of additional research needs in the context
of the latest research developments around
the world.
What steps can I take to reduce my
exposure to radio frequency energy
from my wireless phone?
If there is a risk from these products - and
at this point we do not know that there is - it
E840-2.fm Page 49 Monday, May 14, 2007 9:04 AM
Health and safety information
50
is probably very small. But if you are
concerned about avoiding even potential
risks, you can take a few simple steps to
minimize your exposure to radio frequency
energy (RF). Since time is a key factor in
how much exposure a person receives,
reducing the amount of time spent using a
wireless phone will reduce RF exposure.
• “If you must conduct extended
conversations by wireless phone every
day, you could place more distance
between your body and the source of the
RF, since the exposure level drops off
dramatically with distance. For example,
you could use a headset and carry the
wireless phone away from your body or
use a wireless phone connected to a
remote antenna.
Again, the scientific data do not demonstrate
that wireless phones are harmful. But if you
are concerned about the RF exposure from
these products, you can use measures like
those described above to reduce your RF
exposure from wireless phone use.
What about children using wireless
phones?
The scientific evidence does not show a
danger to users of wireless phones,
including children and teenagers. If you
want to take steps to lower exposure to
radio frequency energy (RF), the measures
described above would apply to children and
teenagers using wireless phones. Reducing
the time of wireless phone use and
increasing the distance between the user
and the RF source will reduce RF exposure.
Some groups sponsored by other national
governments have advised that children be
discouraged from using wireless phones at
all. For example, the government in the
E840-2.fm Page 50 Monday, May 14, 2007 9:04 AM
51
United Kingdom distributed leaflets
containing such a recommendation in
December 2000. They noted that no
evidence exists that using a wireless phone
causes brain tumors or other ill effects. Their
recommendation to limit wireless phone use
by children was strictly precautionary; it was
not based on scientific evidence that any
health hazard exists.
Do hands-free kits for wireless phones
reduce risks from exposure to RF
emissions?
Since there are no known risks from
exposure to RF emissions from wireless
phones, there is no reason to believe that
hands-free kits reduce risks. Hands-free kits
can be used with wireless phones for
convenience and comfort. These systems
reduce the absorption of RF energy in the
head because the phone, which is the source
of the RF emissions, will not be placed
against the head. On the other hand, if the
phone is mounted against the waist or other
part of the body during use, then that part
of the body will absorb more RF energy.
Wireless phones marketed in the U.S. are
required to meet safety requirements
regardless of whether they are used against
the head or against the body. Either
configuration should result in compliance
with the safety limit.
Do wireless phone accessories that
claim to shield the head from RF
radiation work?
Since there are no known risks from
exposure to RF emissions from wireless
phones, there is no reason to believe that
accessories that claim to shield the head
from those emissions reduce risks. Some
products that claim to shield the user from
E840-2.fm Page 51 Monday, May 14, 2007 9:04 AM
Health and safety information
52
RF absorption use special phone cases, while
others involve nothing more than a metallic
accessory attached to the phone. Studies
have shown that these products generally do
not work as advertised. Unlike “hand-free”
kits, these so-called “shields” may interfere
with proper operation of the phone. The
phone may be forced to boost its power to
compensate, leading to an increase in RF
absorption. In February 2002, the Federal
trade Commission (FTC) charged two
companies that sold devices that claimed to
protect wireless phone users from radiation
with making false and unsubstantiated
claims. According to FTC, these defendants
lacked a reasonable basis to substantiate
their claim.
What about wireless phone
interference with medical equipment?
Radio frequency energy (RF) from wireless
phones can interact with some electronic
devices. For this reason, FDA helped develop
a detailed test method to measure
electromagnetic interference (EMI) of
implanted cardiac pacemakers and
defibrillators from wireless telephones. This
test method is now part of a standard
sponsored by the Association for the
Advancement of Medical instrumentation
(AAMI). The final draft, a joint effort by FDA,
medical device manufacturers, and many
other groups, was completed in late 2000.
This standard will allow manufacturers to
ensure that cardiac pacemakers and
defibrillators are safe from wireless phone
EMI. FDA has tested wireless phones and
helped develop a voluntary standard
sponsored by the Institute of Electrical and
Electronic Engineers (IEEE). This standard
specifies test methods and performance
E840-2.fm Page 52 Monday, May 14, 2007 9:04 AM
53
requirements for hearing aids and wireless
phones so that no interference occurs when
a person uses a compatible phone and a
compatible hearing aid at the same time.
This standard was approved by the IEEE in
2000.
FDA continues to monitor the use of wireless
phones for possible interactions with other
medical devices. Should harmful
interference be found to occur, FDA will
conduct testing to assess the interference
and work to resolve the problem.
Additional information on the safety of RF
exposures from various sources can be
obtained from the following organizations:
• FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/
• Environmental Protection Agency (EPA):
http://www.epa.gov/radiation/
• Occupational Safety and Health
Administration's (OSHA):
http://www.osha.gov/SLTC/
radiofrequencyradiation/index.html
• National institute for Occupational Safety
and Health (NIOSH):
http://www.cdc.gov/niosh/emfpg.html
• World health Organization (WHO):
http://www.who.int/peh-emf/
• International Commission on Non-
Ionizing Radiation Protection:
http://www.icnirp.de
• National Radiation Protection Board
(UK):
http://www.nrpb.org.uk
• Updated 4/3/2002: US food and Drug
Administration
http://www.fda.gov/cellphones
E840-2.fm Page 53 Monday, May 14, 2007 9:04 AM
Health and safety information
54
Road Safety
Your wireless phone gives you the powerful
ability to communicate by voice, almost
anywhere, anytime. But an important
responsibility accompanies the benefits of
wireless phones, one that every user must
uphold.
When driving a car, driving is your first
responsibility. When using your wireless
phone behind the wheel of a car, practice
good common sense and remember the
following tips:
1. Get to know your wireless phone and its
features, such as speed dial and redial. If
available, these features help you to
place your call without taking your
attention off the road.
2. When available, use a hands-free device.
If possible, add an additional layer of
convenience and safety to your wireless
phone with one of the many hands free
accessories available today.
E840-2.fm Page 54 Monday, May 14, 2007 9:04 AM
55
3. Position your wireless phone within easy
reach. Be able to access your wireless
phone without removing your eyes from
the road. If you get an incoming call at
an inconvenient time, let your voice mail
answer it for you.
4. Let the person you are speaking with
know you are driving; if necessary,
suspend the call in heavy traffic or
hazardous weather conditions. Rain,
sleet, snow, ice and even heavy traffic
can be hazardous.
5. Do not take notes or look up phone
numbers while driving. Jotting down a
“to do” list or flipping through your
address book takes attention away from
your primary responsibility, driving
safely.
6. Dial sensibly and assess the traffic; if
possible, place calls when you are not
moving or before pulling into traffic. Try
to plan calls when your car will be
stationary. If you need to make a call
while moving, dial only a few numbers,
check the road and your mirrors, then
continue.
E840-2.fm Page 55 Monday, May 14, 2007 9:04 AM
Health and safety information
56
7. Do not engage in stressful or emotional
conversations that may be distracting.
Make people you are talking with aware
you are driving and suspend
conversations that have the potential to
divert your attention from the road.
8. Use your wireless phone to call for help.
Dial 9-1-1 or other local emergency
number in the case of fire, traffic
accident or medical emergencies.
Remember, it is a free call on your
wireless phone!
9. Use your wireless phone to help others in
emergencies. If you see an auto
accident, crime in progress or other
serious emergency where lives are in
danger, call 9-1-1 or other local
emergency number, as you would want
others to do for you.
10. Call roadside assistance or a special non-
emergency wireless assistance number
when necessary. If you see a broken-
down vehicle posing no serious hazard, a
broken traffic signal, a minor traffic
accident where no one appears injured,
or a vehicle you know to be stolen, call
roadside assistance or other special non-
emergency number.
“The wireless industry reminds you to
use your phone safely when driving.”
For more information, please call 1-888-
901-SAFE, or visit our web-site www.wow-
com.com
Provided by the Cellular Telecommunications
& Internet Association
Operating Environment
E840-2.fm Page 56 Monday, May 14, 2007 9:04 AM
57
Remember to follow any special regulations
in force in any area and always switch your
phone off whenever it is forbidden to use it,
or when it may cause interference or danger.
When connecting the phone or any
accessory to another device, read its user's
guide for detailed safety instructions. Do not
connect incompatible products.
As with other mobile radio transmitting
equipment, users are advised that for the
satisfactory operation of the equipment and
for the safety of personnel, it is
recommended that the equipment should
only be used in the normal operating
position (held to your ear with the antenna
pointing over your shoulder).
Using Your Phone Near Other
Electronic Devices
Most modern electronic equipment is
shielded from radio frequency (RF) signals.
However, certain electronic equipment may
not be shielded against the RF signals from
your wireless phone. Consult the
manufacturer to discuss alternatives.
Pacemakers
Pacemaker manufacturers recommend that
a minimum distance of 15 cm (6 inches) be
maintained between a wireless phone and a
pacemaker to avoid potential interference
with the pacemaker.
These recommendations are consistent with
the independent research and
recommendations of Wireless Technology
Research.
Persons with pacemakers:
E840-2.fm Page 57 Monday, May 14, 2007 9:04 AM
Health and safety information
58
• should always keep the phone more than
15 cm
(6 inches) from their pacemaker when
the phone is switched on.
• should not carry the phone in a breast
pocket.
• should use the ear opposite the
pacemaker to minimize potential
interference.
If you have any reason to suspect that
interference is taking place, switch your
phone off immediately.
Hearing Aids
Some digital wireless phones may interfere
with some hearing aids. In the event of such
interference, you may wish to consult your
hearing aid manufacturer to discuss
alternatives.
Other Medical Devices
If you use any other personal medical
devices, consult the manufacturer of your
device to determine if it is adequately
shielded from external RF energy. Your
physician may be able to assist you in
obtaining this information. Switch your
phone off in health care facilities when any
regulations posted in these areas instruct
you to do so. Hospitals or health care
facilities may be using equipment that could
be sensitive to external RF energy.
E840-2.fm Page 58 Monday, May 14, 2007 9:04 AM
59
Vehicles
RF signals may affect improperly installed or
inadequately shielded electronic systems in
motor vehicles. Check with the
manufacturer or its representative regarding
your vehicle. You should also consult the
manufacturer of any equipment that has
been added to your vehicle.
Posted Facilities
Switch your phone off in any facility where
posted notices require you to do so.
Potentially Explosive Environments
Switch your phone off when in any area with
a potentially explosive atmosphere and obey
all signs and instructions. Sparks in such
areas could cause an explosion or fire
resulting in bodily injury or even death.
Users are advised to switch the phone off
while at a refueling point (service station).
Users are reminded of the need to observe
restrictions on the use of radio equipment in
fuel depots (fuel storage and distribution
areas), chemical plants or where blasting
operations are in progress.
Areas with a potentially explosive
atmosphere are often but not always clearly
marked. They include below deck on boats,
chemical transfer or storage facilities,
vehicles using liquefied petroleum gas (such
as propane or butane), areas where the air
contains chemicals or particles, such as
grain, dust or metal powders, and any other
E840-2.fm Page 59 Monday, May 14, 2007 9:04 AM
Health and safety information
60
area where you would normally be advised
to turn off your vehicle engine.
Emergency Calls
This phone, like any wireless phone,
operates using radio signals, wireless and
landline networks as well as user
programmed functions, which cannot
guarantee connection in all conditions.
Therefore, you should never rely solely on
any wireless phone for essential
communications (medical emergencies, for
example).
Remember, to make or receive any calls the
phone must be switched on and in a service
area with adequate signal strength.
Emergency calls may not be possible on all
wireless phone networks or when certain
network services and/or phone features are
in use. Check with local service providers.
To make an emergency call:
1. If the phone is not on, switch it on.
2. Key in the emergency number for your
present location (for example, 911 or
other official emergency number).
Emergency numbers vary by location.
3. Press .
If certain features are in use (call barring,
for example), you may first need to
deactivate those features before you can
make an emergency call. Consult this
document and your local cellular service
provider.
When making an emergency call, remember
to give all the necessary information as
accurately as possible. Remember that your
E840-2.fm Page 60 Monday, May 14, 2007 9:04 AM
61
phone may be the only means of
communication at the scene of an accident;
do not cut off the call until given permission
to do so.
Restricting Children's access to your
Phone
Your phone is not a toy. Children should not
be allowed to play with it because they could
hurt themselves and others, damage the
phone or make calls that increase your
phone bill.
FCC Notice and Cautions
FCC Notice
• This device complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) this device
may not cause harmful interference, and
(2) this device must accept any
interference received, including
interference that may cause undesired
operation.
• This equipment has been tested and found
to comply with the limits for a Class B
digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation.This equipment generates, uses
and can radiate radio frequency energy
and,f not installed and used in accordance
with the instructions, may cause harmful
interference to radio communications
E840-2.fm Page 61 Monday, May 14, 2007 9:04 AM
Health and safety information
62
The phone may cause TV or radio
interference if used in close proximity to
receiving equipment. The FCC can require
you to stop using the phone if such
interference cannot be eliminated.
Vehicles using liquefied petroleum gas (such
as propane or butane) must comply with the
National Fire Protection Standard (NFPA-58).
For a copy of this standard, contact the
National Fire Protection Association, One
Battery march Park, Quincy, MA 02269,
Attn: Publication Sales Division.
Cautions
Changes or modifications made in the radio
phone, not expressly approved by Samsung,
will void the user’s authority to operate the
equipment.
Only use approved batteries, antennas and
chargers. The use of any unauthorized
accessories may be dangerous and void the
phone warranty if said accessories cause
damage or a defect to the phone.
Although your phone is quite sturdy, it is a
complex piece of equipment and can be
broken. Avoid dropping, hitting, bending or
sitting on it.
However, there is no guarantee that
interference will not occur in a particular
installation.If this equipment does cause
harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is
encouraged to try to correct theinterference
by one or more of the following measures:-
Reorient or relocate the receiving antenna. -
Increase the separation between the
equipment and receiver.-Connect the
equipment into an outlet on a circuit different
from that to which the receiver is connected. -
Consult the dealer or an experienced radio/TV
technician for help.
E840-2.fm Page 62 Monday, May 14, 2007 9:04 AM
63
Other Important Safety
Information
• Only qualified personnel should service
the phone or install the phone in a
vehicle. Faulty installation or service may
be dangerous and may invalidate any
warranty applicable to the device.
• Check regularly that all wireless phone
equipment in your vehicle is mounted
and operating properly.
• Do not store or carry flammable liquids,
gases or explosive materials in the same
compartment as the phone, its parts or
accessories.
• For vehicles equipped with an air bag,
remember that an air bag inflates with
great force. Do not place objects,
including both installed or portable
wireless equipment in the area over the
air bag or in the air bag deployment
area. If wireless equipment is improperly
installed and the air bag inflates, serious
injury could result.
• Switch your phone off before boarding an
aircraft. The use of wireless phone in
aircraft is illegal and may be dangerous
to the aircraft's operation.
• Failure to observe these instructions may
lead to the suspension or denial of
telephone services to the offender, or
legal action, or both.
E840-2.fm Page 63 Monday, May 14, 2007 9:04 AM
Health and safety information
64
Product Performance
Getting the Most Out of Your Signal
Reception
The quality of each call you make or receive
depends on the signal strength in your area.
Your phone informs you of the current signal
strength by displaying a number of bars next
to the signal strength icon. The more bars
displayed, the stronger the signal.
If you're inside a building, being near a
window may give you better reception.
Understanding the Power Save
Feature
If your phone is unable to find a signal after
15 minutes of searching, a Power Save
feature is automatically activated. If your
phone is active, it periodically rechecks
service availability or you can check it
yourself by pressing any key.
Anytime the Power Save feature is activated,
a message displays on the screen. When a
signal is found, your phone returns to
standby mode.
Maintaining Your Phone's Peak
Performance
For the best care of your phone, only
authorized personnel should service your
phone and accessories. Faulty service may
void the warranty.
There are several simple guidelines to
operating your phone properly and
maintaining safe, satisfactory service.
• Hold the phone with the antenna raised,
fully-extended and over your shoulder.
E840-2.fm Page 64 Monday, May 14, 2007 9:04 AM
65
• Try not to hold, bend or twist the phone's
antenna.
• Don't use the phone if the antenna is
damaged.
• Speak directly into the phone's receiver.
• Avoid exposing your phone and
accessories to rain or liquid spills. If your
phone does get wet, immediately turn
the power off and remove the battery. If
it is inoperable, call Customer Care for
service.
Availability of Various Features/
Ring Tones
Many services and features are network
dependent and may require additional
subscription and/or usage charges. Not all
features are available for purchase or use in
all areas. Downloadable Ring Tones may be
available at an additional cost. Other
conditions and restrictions may apply. See
your service provider for additional
information.
E840-2.fm Page 65 Monday, May 14, 2007 9:04 AM
Health and safety information
66
Battery Standby and Talk Time
Standby and talk times will vary depending
on phone usage patterns and conditions.
Battery power consumption depends on
factors such as network configuration, signal
strength, operating temperature, features
selected, frequency of calls, and voice, data,
and other application usage patterns.
Battery Precautions
• Never use any charger or battery that is
damaged in any way.
• Use the battery only for its intended
purpose.
• If you use the phone near the network's
base station, it uses less power; talk and
standby time are greatly affected by the
signal strength on the cellular network
and the parameters set by the network
operator.
• Battery charging time depends on the
remaining battery charge and the type of
battery and charger used. The battery
can be charged and discharged hundreds
of times, but it will gradually wear out.
When the operation time (talk time and
standby time) is noticeably shorter than
normal, it is time to buy a new battery.
• If left unused, a fully charged battery will
discharge itself over time.
• Use only Samsung-approved batteries
and recharge your battery only with
Samsung-approved chargers. When a
charger is not in use, disconnect it from
the power source. Do not leave the
battery connected to a charger for more
E840-2.fm Page 66 Monday, May 14, 2007 9:04 AM
67
than a week, since overcharging may
shorten its life.
• Extreme temperatures will affect the
charging capacity of your battery: it may
require cooling or warming first.
• Do not leave the battery in hot or cold
places, such as in a car in summer or
winter conditions, as you will reduce the
capacity and lifetime of the battery.
Always try to keep the battery at room
temperature. A phone with a hot or cold
battery may temporarily not work, even
when the battery is fully charged. Li-ion
batteries are particularly affected by
temperatures below 0 °C (32 °F).
• Do not short-circuit the battery.
Accidental short- circuiting can occur
when a metallic object (coin, clip or pen)
causes a direct connection between the
+ and - terminals of the battery (metal
strips on the battery), for example when
you carry a spare battery in a pocket or
bag. Short-circuiting the terminals may
damage the battery or the object causing
the short-circuiting.
• Dispose of used batteries in accordance
with local regulations. In some areas, the
disposal of batteries in household or
business trash may be prohibited. For
safe disposal options for Li-Ion batteries,
contact your nearest Samsung
authorized service center. Always
recycle. Do not dispose of batteries in a
fire.
Care and Maintenance
Your phone is a product of superior design
and craftsmanship and should be treated
E840-2.fm Page 67 Monday, May 14, 2007 9:04 AM
Health and safety information
68
with care. The suggestions below will help
you fulfill any warranty obligations and allow
you to enjoy this product for many years.
• Keep the phone and all its parts and
accessories out of the reach of small
children.
• Keep the phone dry. Precipitation,
humidity and liquids contain minerals
that will corrode electronic circuits.
• Do not use the phone with a wet hand.
Doing so may cause an electric shock to
you or damage to the phone.
• Do not use or store the phone in dusty,
dirty areas, as its moving parts may be
damaged.
• Do not store the phone in hot areas.
High temperatures can shorten the life of
electronic devices, damage batteries,
and warp or melt certain plastics.
• Do not store the phone in cold areas.
When the phone warms up to its normal
operating temperature, moisture can
form inside the phone, which may
damage the phone's electronic circuit
boards.
• Do not drop, knock or shake the phone.
Rough handling can break internal circuit
boards.
• Do not use harsh chemicals, cleaning
solvents or strong detergents to clean
the phone. Wipe it with a soft cloth
slightly dampened in a mild soap-and-
water solution.
• Do not paint the phone. Paint can clog
the device's moving parts and prevent
proper operation.
• Do not put the phone in or on heating
devices, such as a microwave oven, a
E840-2.fm Page 68 Monday, May 14, 2007 9:04 AM
69
stove or a radiator. The phone may
explode when overheated.
• When the phone or battery gets wet, the
label indicating water damage inside the
phone changes color. In this case, phone
repairs are no longer guaranteed by the
manufacturer's warranty, even if the
warranty for your phone has not expired.
• If your phone has a flash or light, do not
use it too close to the eyes of people or
animals. This may cause damage to their
eyes.
• Use only the supplied or an approved
replacement antenna. Unauthorized
antennas or modified accessories may
damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger or any
accessory is not working properly, take it
to your nearest qualified service facility.
The personnel there will assist you, and
if necessary, arrange for service.
E840-2.fm Page 69 Monday, May 14, 2007 9:04 AM
Health and safety information
70
• When the phone or battery gets wet, the label
indicating water damage inside the phone
changes colour. In this case, phone repairs are
no longer guaranteed by the manufacturer's
warranty, even if the warranty for your phone
has not expired.
• If your phone has a flash or light, do not use it
too close to the eyes of people or animals. This
may cause damage to their eyes.
• Use only the supplied or an approved
replacement antenna. Unauthorised antennas or
modified accessories may damage the phone
and violate regulations governing radio devices.
• If the phone, battery, charger, or any accessory
is not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
E840-2.fm Page 70 Monday, May 14, 2007 9:04 AM
49
• When the phone or battery gets wet, the label
indicating water damage inside the phone changes
colour. In this case, phone repairs are no longer
guaranteed by the manufacturer's warranty, even if
the warranty for your phone has not expired.
• If your phone has a flash or light, do not use it too
close to the eyes of people or animals. This may
cause damage to their eyes.
• Use only the supplied or an approved replacement
antenna. Unauthorised antennas or modified
accessories may damage the phone and violate
regulations governing radio devices.
• If the phone, battery, charger, or any accessory is
not working properly, take it to your nearest
qualified service facility. The personnel there will
assist you, and if necessary, arrange for service.
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other
European countries with separate collection
systems)
This marking shown on the product or its
literature, indicates that it should not be
disposed with other household wastes at the
end of its working life. To prevent possible harm to the
environment or human health from uncontrolled waste
disposal, please separate this from other types of
wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer
where they purchased this product, or their local
government office, for details of where and how they
can take this item for environmentally safe recycling.
Business users should contact their supplier and check
the terms and conditions of the purchase contract. This
product should not be mixed with other commercial
wastes for disposal.
