Users Manual
English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1
English
Contents
BEFORE USING YOUR HEADSET
Checking phone compatibility....................................................3
Checking the accessories..........................................................3
Your headset overview .............................................................4
Charging the headset...............................................................5
Storage of the headset.............................................................6
BASIC OPERATIONS
Turning the headset on/off........................................................7
Pairing with your Bluetooth phone..............................................8
Wearing the headset ..............................................................10
Making a call.........................................................................11
Ending a call.........................................................................11
Answering a call ....................................................................12
Adjusting the volume .............................................................12
Switching on or off the microphone..........................................12
Transferring a call from the phone to the headset.......................13
Turning the indicator light on or off ..........................................13
Using enhanced features ........................................................13
APPENDIX
Frequently asked questions.....................................................15
Safety approvals....................................................................17
UL certified travel adapter.......................................................19
Cautions...............................................................................20
Warranty and parts replacement..............................................21
Correct disposal of this product ...............................................23
2
Thank you for purchasing the Samsung Bluetooth Mono
Headset WEP410. We hope you will be delighted with its
operation.
Please read this user’s guide to get started, and to make the
best use of the headset’s many features.
Copyright information
Bluetooth
®
is a registered trademark of the Bluetooth SIC,
Inc. worldwide.
Driving safety
• When you are driving a car, driving is your first
responsibility.
• When using your headset while driving, follow local
regulations in the country or region you are in.
3
English
BEFORE USING YOUR HEADSET
Your headset is compatible with most Bluetooth phones that are
compliant with Bluetooth version 1.1 or higher and support the
Headset and/or Hands-free profile(s). Ensure that your phone
has Bluetooth capability by visiting your phone manufacturer’s
web site.
Make sure you have the following items with your headset:
Set 1: Charging case, Adapter, User’s Guide, 2 earpiece covers
Set 2: Charging case, User’s Guide, 2 earpiece covers
For Set 2, use your phone charger as a power source for
recharging.
Checking phone compatibility
Some devices, especially those that are not tested or
approved by SIG, may be incompatible with your headset.
Checking the accessories
The items supplied with your headset may vary,
depending on your country or service provider.
4
Your headset overview
Volume down
button
Indicator light
Microphone Earpiece
Charging
contact
Multi-Function
button
Volume up
button
5
English
Your headset uses a rechargeable battery. You must charge the
battery fully before using the headset for the first time.
1
Put the headset in the supplied charging case and close the
cover.
2
Plug the adapter into the case’s charging socket.
3
Plug the adapter into the electrical outlet.
• For Set 1, use the adapter provided.
• Charge the headset until the red light on the headset
turns to blue.
• The headset will be fully charged in approximately 2
hours.
Charging the headset
6
4
Remove the adapter from the case.
• Always store the headset with the power off and make sure
it is safely protected.
• Avoid storage at high temperatures (above 50° C / 122° F),
such as in a hot vehicle or in direct sunlight. Storage at high
temperatures can damage performance and reduce battery
life.
• Do not expose the headset or any of its supplied parts to
rain or other liquids.
Do not attempt to charge the headset with anything other
than the adapter provided. Using unauthorized adapter
may damage the headset.
For connection to an electrical supply not located in the
U.S., you must use an adapter of the proper configuration
for the power outlet. Use of the wrong adapter could
damage your headset and void your warranty.
The headset is not able to operate while charging. Try
connecting after charging is completed.
Storage of the headset
7
English
BASIC OPERATIONS
Meaning of the indicator light
Turning the headset on/off
To Press and hold You will hear You will see
turn the
headset on the Multi-Function
button for 4 seconds
until you see
4 blue
flashes
on the
indicator light.
a tone. the indicator light
flashes while the
power is on (see
Meaning of the
indicator light
).
turn the
headset off the Multi-Function
button for 4 seconds
until you see
blue
and red flashes
on
the indicator light.
series of 2
tones. the indicator light
stops flashing.
Light Tone Status
Flashes in
blue every 8
seconds.
Quick series of 2
tones.
(Active mode starts.)
• The headset is in Active mode.
• The headset has an active call in
progress.
• You can talk up to 4 hours.
*
8
Pairing will create a unique and encrypted wireless link between
two Bluetooth enabled devices, such as your Bluetooth phone
and Bluetooth headset.
1
Make sure that the headset is off (see
Turning the headset
on/off
).
Flashes in
blue every 3
seconds.
Quick series of 2
tones.
(Standby mode
starts.)
• The headset is in Standby mode.
• The headset is waiting for a call.
• The headset can be in Standby
mode up to 70 hours.
*
Flashes in
red. 5 tones every 20
seconds. The battery of the headset is low.
• There is less than 10% of battery
power left. Recharge the battery.
* Depending on the phone type and usage, the actual time may vary.
Pairing with your Bluetooth phone
When you turn on your headset for the first time, the
headset proceeds into Pairing mode so that you can
immediately pair it with other devices.
Light Tone Status
9
English
2
Press and hold the Multi-Function button until the indicator
light turns blue (approximately 8 seconds).
3
Set your Bluetooth phone to discover the headset by
following your phone’s guide.
Typically, the steps involve going to a ‘Settings,’
‘Connection’, or ‘Bluetooth’ menu on your phone and then
selecting the option to discover Bluetooth devices.
4
Your phone will find the Samsung WEP410 headset and ask
if you want to pair with it. Confirm this by pressing the
Yes
or
OK
key.
5
Enter a passkey or PIN, 0000 (4 zeros), then press the
Yes
or
OK
key.
Only half of the light will turn blue.
10
Wear the headset on your ear. In
general, you will get better performance
when there are no obstructions
(including parts of your body) between
the headset and the phone.
• If pairing was successful, the indicator light will flash in
blue 10 times rapidly before going to flashing every 3
seconds. If unsuccessful, the light remains on, and you
will need to re-attempt pairing.
• When you turn on your headset after pairing with the
phone, the headset is automatically connected to the
phone.
• When you turn on your phone after pairing with the
headset, the phone is connected to the headset by
pressing the Multi-Function button.
Wearing the headset
You are supplied with three different earpiece covers.
Choose one that is most comfortable for you.
11
English
Making a voice activated call
If the voice recognition feature is on, you can make a voice
activated call.
1
Press and hold the Multi-Function button. You will hear the
voice-activation tone.
2
Say the name of the person you wish to call.
Depending on your phone, this feature may not be supported.
Redialing the last number
Press the Multi-Function button. When you release the button,
the phone dials the last dialed or received number.
Depending on your phone, how to redial the last number may
vary.
Press the Multi-Function button.
Making a call
Ending a call
12
When a call comes in, the headset sounds series of 2 tones and
flashes the blue indicator twice. Press the Multi-Function
button.
Press [
+
]
on the side of the headset to increase the volume
level and [
-
] to decrease the volume level.
Press and hold [
+
] or [
-
] to switch off the headset's
microphone. To switch it back on, press and hold either one
again.
Answering a call
Do not hold the Multi-Function button down too long when
making a call with your voice, ending, or answering a call.
This should only be a quick tap.
Adjusting the volume
At very high volumes, prolonged listening to the
headset can damage your hearing.
Switching on or off the microphone
13
English
If you answer the call with your phone, you can transfer the call
to the headset by pressing the Multi-Function button.
You can deactivate the use of the indicator light in Standby
mode and in Active mode.
Press and hold [
+
] and [
-
] at the same time to turn the
indicator light on or off.
Enhanced features are available for phones that support the
Hands-free profile and enhanced features.
•
Rejecting a call
When you receive a call, press and hold the Multi-Function
button to reject the call.
Depending on your phone’s setting or type, you may only be
able to mute the ringer or this feature may not be
supported.
Transferring a call from the phone to the
headset
Turning the indicator light on or off
Using enhanced features
14
•
Placing a call on hold
While you are on a call, press and hold the Multi-Function
button.
To retrieve the call, press and hold the Multi-Function button
again.
Depending on your phone, this feature may not be
supported.
•
Answering a second call
When your phone notifies you of another incoming call while
you are on a call, press and hold the Multi-Function button
to place the call on hold. Then press the Multi-Function
button to answer the second call.
You can switch between calls by pressing and holding it.
Depending on your phone, this feature may not be
supported.
15
English
APPENDIX
Frequently asked questions
How far away from
my phone will the
headset work?
The operating range is typically up to 30 feet
(10 meters).
Will the headset
work with my
cordless phone at
home?
The headset is not designed for use with
cordless phones.
Will the headset
work with laptops,
PCs, and PDAs?
The headset will work with devices that are
compliant with Bluetooth version 1.1 or higher
and support the headset and/or hands-free
profile(s).
Will anything cause
interference with my
conversation when
I’m using the
headset?
Appliances such as cordless phones and
wireless networking equipment may cause
interference with your conversation. To reduce
any interference, keep the headset away from
other devices that use or produce radio waves.
16
Will the headset
interfere with my
car’s electronics,
radio, or computer?
The headset produces significantly less power
than a typical mobile phone. It also only emits
signals that are in compliance with the
international Bluetooth standard. Therefore,
you should not expect any interference with
standard consumer-grade electronics
equipment.
Can other Bluetooth
phone users hear my
conversation?
When you pair the headset to your Bluetooth
phone, you are creating a private link between
only these two Bluetooth devices. The wireless
Bluetooth technology used in the headset is
not easily monitored by third parties, because
Bluetooth wireless signals are significantly
lower in radio frequency power than those
produced by a typical mobile phone.
How do I take care
of the headset?
To clean the headset, use a clean, soft cloth
that is slightly damp.
17
English
FCC
FCC ID: A3LWEP410
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
The device and its antenna must not be co-located or operating
in conjunction with any other antenna or transmitter.
Users are not permitted to make changes or modify the device
in any way.
Changes or modifications not expressly approved by Samsung
will void the user’s authority to operate the equipment.
Safety approvals
18
Industry Canada
IC ID: 649E-WEP410
Operation is subject to the following two conditions: (1) This
device may not cause interference and (2) This device must
accept any interference, including interference that may cause
undesired operation of the device.
19
English
The term “IC:” before the certification/registration number only
signifies that registration was performed based on a Declaration
of Conformity indicating that Industry Canada technical
specifications were met. It does not imply that Industry Canada
approved the equipment.
Bluetooth
The Bluetooth
®
word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by Samsung is
under license. Other trademarks and trade names are those of
their respective owners.
The travel adapter for this headset has met UL 1310 safety
requirements. Please adhere to the following safety instructions
per UL guidelines.
FAILURE TO FOLLOW THE INSTRUCTIONS OUTLINED MAY LEAD
TO SERIOUS PERSONAL INJURY AND POSSIBLE PROPERTY
DAMAGE.
IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE
INSTRUCTIONS.
UL certified travel adapter
20
DANGER - TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
CAREFULLY FOLLOW THESE INSTRUCTIONS.
FOR CONNECTION TO A SUPPLY NOT IN THE U.S.A., USE AN
ATTACHMENT PLUG ADAPTOR OF THE PROPER CONFIGURATION
FOR THE POWER OUTLET.
Cautions
Changes or modifications made in the radio phone, not
expressly approved by Samsung, will void the user’s authority
to operate the equipment.Only use approved batteries,
antennas and chargers. The use of any unauthorized
accessories may be dangerous and void the phone warranty if
said accessories cause damage or a defect to the phone.
Although your phone is quite sturdy, it is a complex piece of
equipment and can be broken. Avoid dropping, hitting, bending
or sitting on it.
Cautions
21
English
Samsung warrants this product as free of defects in material,
design and workmanship for the period of one year from the
original date of purchase.
If during the period of warranty this product proves defective
under normal use and service you should return the product to
the retailer from whom it was originally purchased or qualified
service center. The liability of Samsung and its appointed
maintenance company is limited to the cost of repair and/or
replacement of the unit under warranty.
• The warranty is limited to the original purchaser
• A copy of your receipt or other proof of purchase is required
for a proper warranty service
• The warranty is void if the serial number, date code label or
product label is removed, or if the product has been subject
to physical abuse, improper installation modification, or
repair by unauthorized third parties
• The responsibility of Samsung products shall be limited to
the repair or replacement of the product at its sole discretion
• Specifically exempt from any warranty are limited-life
consumable components such as batteries and other
accessories
Warranty and parts replacement
22
• Samsung is not liable to for any incidental or consequential
damages arising from the use or misuse of any Samsung
product
• This warranty gives you specific rights and you may have
other rights which vary from area to area
• Unless otherwise instructed in the User Guide, the user may
not, under any circumstances, attempt to perform service,
adjustments or repairs on the unit, whether in or out of
warranty. It must be returned to the purchase point, factory
or authorized service agency for all such work
• Samsung will not assume any responsibility for any loss or
damage incurred in shipping. All repair work on Samsung
products by unauthorized third parties voids any warranty
23
English
(Waste Electrical & Electronic Equipment)
This marking shown on the product or its literature,
indicates that it should not be disposed with other
household wastes at the end of its working life.
To prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate this from
other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they
purchased this product, or their local government office, for
details of where and how they can take this item for
environmentally safe recycling.
Business users should contact their supplier and check the
terms and conditions of the purchase contract. This product
should not be mixed with other commercial wastes for disposal.
Correct disposal of this product
World Wide Web
http://www.samsungmobileusa.com
http://www.samsungmobile.com
http://www.samsung.com/ca
http://www.samsung.com.br
Printed in Korea
Code No.:GH68-xxxxxA
09/2006. Rev. 1.0
