Samsung Electronics Co WEP700 Bluetooth Headset User Manual WEP700 Dtype
Samsung Electronics Co Ltd Bluetooth Headset WEP700 Dtype
Users Manual
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-xxxxxA
01/2008. Draft
English
English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1
E
ng
li
s
h
Contents
Safety and usage information....................................................2
Your headset overview .............................................................3
Charging the headset...............................................................4
Turning the headset on or off ....................................................4
Understanding various modes....................................................5
Pairing with your Bluetooth phone..............................................5
Wearing the headset................................................................6
Warranty and parts replacement................................................8
Correct disposal of this product .................................................9
Specifications........................................................................10
2
Bluetooth
®
is a registered trademark of the Bluetooth SIG, Inc.
worldwide. Bluetooth QD ID: B012977
• Never disassemble or modify your headset for any reason.
Doing this may cause the headset to malfunction or become
combustible. Bring the headset to an authorised service
centre to repair it or replace the battery.
• When using your headset while driving, follow local
regulations in the country or region you are in.
• Avoid storage at high temperatures (above 50° C/122° F),
such as in a hot vehicle or in direct sunlight, as this can
damage performance and reduce battery life.
• Do not expose the headset or any of its supplied parts to
rain or other liquids.
Safety and usage information
At very high volumes, prolonged listening to the
headset can damage your hearing.
3
E
ng
li
s
h
Your headset overview
If your headset responds slowly, stops responding, or
freezes, press the reset button on the back of the
headset with a pointed tool.
Multi-function
button
Indicator
light
Earpiece
Volume down
button
Earhook
Microphone
Microphone
4
Put the adapter into the jack on the headset
and into the electrical outlet.
Charge the headset until the red indicator
light turns blue.
To turn the headset on, press and hold the Multi-function
button until the blue indicator light flashes 4 times.
To turn the headset off, press and hold the Multi-function
button until both blue and red indicator lights flash.
Charging the headset
Do not attempt to charge the headset with anything
other than the adapter provided.
The headset is available while charging. However, we
recommand you to use the headset after charging is
complete.
Turning the headset on or off
5
E
ng
li
s
h
•
Standby mode
: The headset is waiting for a call. The blue
indicator light flashes every 3 seconds.
•
Active mode
: The headset has a call in progress. The blue
indicator light flashes every 8 seconds.
•
Pairing mode
: The blue indicator light stays lit. You can
discover and connect to your headset on your phone.
•
Low battery mode
: There is less than 10% of battery
power left. The red indicator light flashes. You must
recharge the battery.
1 Enter Pairing mode.
• Turn off your headset and press and hold the Multi-
function button until the blue indicator light remains lit
after blinking.
• If you turn it on for the first time, it proceeds into Pairing
mode immediately.
2 Search for and pair with your phone according to your
phone’s user guide. (Bluetooth PIN: 0000, 4 zeros)
Understanding various modes
Pairing with your Bluetooth phone
6
• If the pairing is successful, the blue indicator light will
flash 10 times rapidly before entering Standby mode.
• If the blue indicator light remains lit, retry pairing.
Wear the headset on your ear. In
general, you will get better performance
when there are no obstructions
(including parts of your body) between
the headset and the phone.
When the headset and the phone are paired, the
headset attempts to reconnect automatically each
time it turns on. Otherwise, press the Multi-function
button to reconnect.
Wearing the headset
7
E
ng
li
s
h
Depending on what ear you are going to wear the headset,
simply adjust the ear hook accordingly.
Some features may not be supported by your phone.
In Standby mode
Press the Multi-function button to:
• Answer an incoming call
• Redial the last number called
Press and hold Multi-function button to:
• Make a voice-activated call
• Reject an incoming call
Press and hold [+] and [-] at the same time to turn the
indicator light on or off.
Using call features
Left Right
8
In Active mode
Press the Multi-function button to:
• End a call
• Transfer a call from the phone to the headset
Press and hold Multi-function button to:
• Place a call on hold
• Answer a second call
• Retrieve a call on hold
Press [+] or [-] to adjust the volume.
Press and hold [+] or [-] to turn the microphone off or on.
Samsung warrants this product as free of defects in material, design
and workmanship for the period of one year from the original date of
purchase. (Depending on your country, the length of warranty may
vary.)
If during the period of warranty this product proves defective under
normal use and service you should return the product to the retailer
from whom it was originally purchased or qualified service center.
The liability of Samsung and its appointed maintenance company is
limited to the cost of repair and/or replacement of the unit under
warranty.
Warranty and parts replacement
9
E
ng
li
s
h
• The warranty is limited to the original purchaser
• A copy of your receipt or other proof of purchase is required for a
proper warranty service
• The warranty is void if the serial number, date code label or
product label is removed, or if the product has been subject to
physical abuse, improper installation modification, or repair by
unauthorised third parties
• Specifically exempt from any warranty are limited-life
consumable components such as batteries and other accessories
• Samsung will not assume any responsibility for any loss or
damage incurred in shipping. All repair work on Samsung
products by unauthorised third parties voids any warranty
(Waste Electrical & Electronic Equipment)
This marking shown on the product or its literature,
indicates that it should not be disposed with other
household wastes at the end of its working life.
To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate this from other types of
wastes and recycle it responsibly to promote the sustainable reuse
of material resources.
Correct disposal of this product
10
Household users should contact either the retailer where they
purchased this product, or their local government office, for details
of where and how they can take this item for environmentally safe
recycling.
Business users should contact their supplier and check the terms
and conditions of the purchase contract. This product should not be
mixed with other commercial wastes for disposal.
Specifications
Item Specifications and description
Version Bluetooth 2.0 or earlier
Profile Headset Profile, Hands-Free Profile
Operating range Up to 30 feet (10 metres)
Maximum Standby time Up to 80 hours*
Maximum Active time Up to 5 hours
*
* Depending on the phone type and usage, the actual time may
vary.
11
English
FCC
FCC ID: A3LWEP700
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
The device and its antenna must not be co-located or operating
in conjunction with any other antenna or transmitter.
Users are not permitted to make changes or modify the device
in any way.
Changes or modifications not expressly approved by Samsung
will void the user’s authority to operate the equipment.
Safety approvals
12
Industry Canada
IC ID: 649E-WEP700
Operation is subject to the following two conditions: (1) This
device may not cause interference and (2) This device must
accept any interference, including interference that may cause
undesired operation of the device.
13
English
The term “IC:” before the certification/registration number only
signifies that registration was performed based on a Declaration
of Conformity indicating that Industry Canada technical
specifications were met. It does not imply that Industry Canada
approved the equipment.
Bluetooth
The Bluetooth
®
word mark and logos are owned by the
Bluetooth SIG, Inc. and any use of such marks by Samsung is
under license. Other trademarks and trade names are those of
their respective owners.
The travel adapter for this headset has met UL 1310 safety
requirements. Please adhere to the following safety instructions
per UL guidelines.
FAILURE TO FOLLOW THE INSTRUCTIONS OUTLINED MAY LEAD
TO SERIOUS PERSONAL INJURY AND POSSIBLE PROPERTY
DAMAGE.
IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE
INSTRUCTIONS.
UL certified travel adapter
14
DANGER - TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
CAREFULLY FOLLOW THESE INSTRUCTIONS.
FOR CONNECTION TO A SUPPLY NOT IN THE U.S.A., USE AN
ATTACHMENT PLUG ADAPTOR OF THE PROPER CONFIGURATION
FOR THE POWER OUTLET.
Cautions
Changes or modifications made in the radio phone, not
expressly approved by Samsung, will void the user’s authority
to operate the equipment.Only use approved batteries,
antennas and chargers. The use of any unauthorized
accessories may be dangerous and void the phone warranty if
said accessories cause damage or a defect to the phone.
Although your phone is quite sturdy, it is a complex piece of
equipment and can be broken. Avoid dropping, hitting, bending
or sitting on it.
Cautions
15
English
Samsung warrants this product as free of defects in material,
design and workmanship for the period of one year from the
original date of purchase.
If during the period of warranty this product proves defective
under normal use and service you should return the product to
the retailer from whom it was originally purchased or qualified
service center. The liability of Samsung and its appointed
maintenance company is limited to the cost of repair and/or
replacement of the unit under warranty.
• The warranty is limited to the original purchaser
• A copy of your receipt or other proof of purchase is required
for a proper warranty service
• The warranty is void if the serial number, date code label or
product label is removed, or if the product has been subject
to physical abuse, improper installation modification, or
repair by unauthorized third parties
• The responsibility of Samsung products shall be limited to
the repair or replacement of the product at its sole discretion
• Specifically exempt from any warranty are limited-life
consumable components such as batteries and other
accessories
Warranty and parts replacement
16
• Samsung is not liable to for any incidental or consequential
damages arising from the use or misuse of any Samsung
product
• This warranty gives you specific rights and you may have
other rights which vary from area to area
• Unless otherwise instructed in the User Guide, the user may
not, under any circumstances, attempt to perform service,
adjustments or repairs on the unit, whether in or out of
warranty. It must be returned to the purchase point, factory
or authorized service agency for all such work
• Samsung will not assume any responsibility for any loss or
damage incurred in shipping. All repair work on Samsung
products by unauthorized third parties voids any warranty
17
English
(Waste Electrical & Electronic Equipment)
This marking shown on the product or its literature,
indicates that it should not be disposed with other
household wastes at the end of its working life.
To prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate this from
other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they
purchased this product, or their local government office, for
details of where and how they can take this item for
environmentally safe recycling.
Business users should contact their supplier and check the
terms and conditions of the purchase contract. This product
should not be mixed with other commercial wastes for disposal.
Correct disposal of this product
