Samsung Electronics Co WEP900 Bluetooth Mono Headset User Manual
Samsung Electronics Co Ltd Bluetooth Mono Headset
User manual
World Wide Web
http://www.samsungmobile.com
Printed in Korea
Code No.:GH68-XXXXXA
EU A. XX/2008. Rev. 1.0
English ............................................................. 1
Français ......................................................... 18
Deutsch .......................................................... 37
Nederlands ..................................................... 56
English
1
Contents
Getting started
Your headset overview ....................................................3
Button functions .............................................................4
Charging the headset ......................................................5
Wearing on the headset ...................................................9
Using your headset
Turning the headset on or off ......................................... 10
Pairing and connecting the headset ................................. 11
Using call functions ....................................................... 13
Connecting the headset with other devices ....................... 15
Appendix
Frequently asked questions ............................................ 17
Warranty and parts replacement ..................................... 19
Correct disposal of this product ...................................... 20
Correct disposal of batteries in this product ...................... 21
Specications ............................................................... 22
2
Take the time to read through this user guide before you start to use
WEP900 Bluetooth Headset.
Bluetooth® is a registered trademark of the Bluetooth SIG, Inc.
worldwide—Bluetooth QD ID: Bxxxxxx
More information about Bluetooth is available at www.bluetooth.com.
Safety precautions
Never disassemble or modify your headset for any reason. Doing this
may cause the headset to malfunction or become combustible. Bring
the headset to an authorised service centre to repair it or replace the
battery.
When using your headset while driving, follow local regulations in the
country or region you are in.
Avoid storage at high temperatures (above 50° C/122° F), such as in
a hot vehicle or in direct sunlight, as this can damage performance
and reduce battery life.
Do not expose the headset or any of its supplied parts to rain or other
liquids.
At very high volumes, prolonged listening to the headset can damage
your hearing.
•
•
•
•
English
3
Getting started
This section explains what to remember for the proper use of your
Bluetooth headset.
Your headset overview
Make sure you have the following items with your headset :
Charger, User guide, Leather case.
The items supplied with your headset may vary depending on your region.
Earpiece
Volume down
button
Indicator light
Ear hook
Volume up
button
Talk button
Charger jack
Microphone
Power button
4
Button functions
Power button
Press and hold to turn the headset on or off.
Talk button
Press to make or answer a call.
Press to end a call.
Press and hold to enter Pairing mode.
Volume up/down buttons (touch buttons)
Press to adjust the volume.
Press and hold both buttons at the same time to turn the indicator
light on or off.
Press and hold to turn the microphone on or off.
You can hear a beep when the volume level of the headset reaches to
the lowest or highest level.
Do not use the headset in humid places or with wet hands.
•
•
•
•
•
•
•
•
•
English
5
Charging the headset
This headset has a rechargeable internal battery which is non-
removable. Ensure that you fully charge the battery before using the
headset for the rst time.
Using the charger
1 Plug the charger into the charger jack on the headset.
2 Plug the charger into a power outlet.
During charging, the indicator light of the headset will turn red.
If charging does not begin, unplug the charger and plug it in again.
3 When the headset is fully charged, the indicator light of the headset
changes to blue. Unplug the charger from the power outlet and the
headset.
6
Using the leather case
1 Put the headset into place of the leather case which allows you to
charge the headset when on the move.
2 Slide right the lock key.
During charging, the indicator light of the headset will turn red.
English
7
If you use the leather case to store the headset, slide left the lock
key.
3 When the headset is fully charged, the indicator light of the headset
changes to blue. Remove the headset from the leather case.
Using the leather case and charger
1 Put the headset into place of the leather case.
2 Slide right the lock key.
If you use the leather case to store the headset, slide left the lock
key.
3 Plug the charger into the charger jack on the leather case.
8
4 Plug the charger into a power outlet.
During charging, the indicator light of the headset will turn red.
5 When the headset is fully charged, the indicator light of the headset
changes to blue. Unplug the charger from the power outlet and the
leather case.
If you need to charge the leather case for later use, keep plugging
the charger. The leather case will be charged and the indicator
light of the leather case will turn red. When the leather case is fully
charged, the indicator light of the leather case changes to blue.
Use only a Samsung-approved charger. Unauthorised chargers may
cause an explosion or damage to the headset.
The battery will gradually wear out while charging or discharging because
it is a consumable part.
You cannot use the headset while charging the battery.
•
•
•
When the battery power is low
The headset beeps and the indicator light ashes red. Recharge
the battery. If the headsets powers off during a call, the call will be
automatically transferred to the phone.
English
9
Wearing the headset
Place the headset on your ear.
Depending on what ear you are going to wear the
headset, simply adjust the earpiece and microphone
accordingly.
Left Right
10
Using your headset
This section explains how to turn the headset on, pair and connect with
the phone, and use various functions.
Activated functions and features may differ depending on the types of
your phone.
Some devices, especially those that are not tested or approved by
Bluetooth SIG, may be incompatible with your headset.
•
•
Turning the headset on or off
To turn the headset on, press and hold the power button until the
blue indicator light ashes 4 times.
To turn the headset off, press and hold the power button until both
blue and red indicator lights ash.
•
•
English
11
Pairing and connecting the headset
Pairing will create a unique and encrypted wireless link between two
Bluetooth enabled devices, such as a Bluetooth phone and a Bluetooth
headset. To use the headset with other Bluetooth devices, both devices
must be paired. When trying to pair the two devices, keep the headset
and the phone reasonably close together. After pairing, you can connect
the two devices.
Pairing and connecting the headset with a phone
1 Enter Pairing mode.
Press and hold the talk button until the indicator light turns blue
after ashing.
When you turn on the headset for the rst time, it automatically
enters Pairing mode.
2 Activate the Bluetooth feature on your phone and search for the
headset (see your phone's user guide).
3 Select the headset (Samsung WEP900) from the list of devices found
by your phone.
12
4 Enter the Bluetooth PIN (0000, 4 zeros) to pair and connect the
headset to your phone.
Your headset supports the Simple Pairing feature which allows the headset
to be paired with a phone without requesting a PIN. This feature is
available when the phone is compliant with Bluetooth version 2.1 or higher.
Disconnecting the headset
To disconnect the headset from your phone,
Turn off the headset.
Use the Bluetooth menu of your phone.
Reconnecting the headset
When the headset is paired with a phone, it will attempt to automatically
reconnect each time you turn it on.
If the headset does not attempt to automatically reconnect,
Press the talk button.
Use the Bluetooth menu of your phone.
•
•
•
•
English
13
Using call functions
Making a call
Redialling the last number
Press and hold the talk button to redial the last number.
For some phones, pressing the key opens the call log list. Press the talk
button to dial the selected number.
Dialling a number by voice
Press the talk button to dial a number by voice, and say a name.
Answering a call
Press the talk button to answer a call when you hear incoming call tones.
Ending a call
Press the talk button to end a call.
14
Rejecting a call
Press and hold the talk button to reject a call when a call comes in.
Using options during a call
You can use the following functions to control your call during a call.
Transferring a call from the phone to the headset
Press the talk button to transfer a call from the phone to the headset.
Placing a call on hold
Press and hold the talk button to place the current call on hold.
Answering a second call
Press the talk button to end the rst call and answer a second call when
you hear call waiting tones.
Press and hold the talk button to place the rst call on hold and answer
a second call when you hear waiting tones.
To switch between the current call and the held call, press and hold the
talk button.
English
15
Connecting the headset with a music device
You can separately pair and connect your headset with the phone and a
Bluetooth device that plays music les.
1 Pair the headset with a phone. See page 11.
2 If successful, press and hold the talk button. The indicator light turns
on blue after ashing blue twice.
3 Search for, pair, and connect with the music device you want
according to the device's user guide.
4 Press the talk button to connect with the paired phone.
5 When the phone and the device are successfully connected with the
headset, you can make or answer a call while you are listening to
music.
You can start, pause, and resume playback, and scan backward and forward
in a music le only in the connected music device.
16
Answering a call while listening to music
When a call comes in while listening to music, your headset will alert you
so that you can answer the call.
1 When the headset sounds incoming call tones and the indicator light
ashes blue twice, press the talk button.
The music stops and you are connected with the caller.
2 When you have nished the conversation, press the talk button.
Your phone automatically begin playback after the call.
English
17
Appendix
Frequently asked questions
Will my headset
work with laptops,
PCs, and PDAs?
Your headset will work with devices that
support your headset’s Bluetooth version and
proles. For specications, see page 22.
Will anything cause
interference with
my conversation
when I am using
my headset?
Appliances such as cordless phones and
wireless networking equipment may cause
interference with your conversation, usually
adding a crackling noise. To reduce any
interference, keep the headset away from
other devices that use or produce radio waves.
Will my headset
interfere with my
car’s electronics,
radio, or
computer?
Your headset produces signicantly less power
than a typical mobile phone. It also only
emits signals that are in compliance with the
international Bluetooth standard. Therefore,
you should not expect any interference
with standard consumer-grade electronics
equipment.
18
Can other
Bluetooth phone
users hear my
conversation?
When you pair your headset to your Bluetooth
phone, you are creating a private link between
only these two Bluetooth devices. The wireless
Bluetooth technology used in your headset is
not easily monitored by third parties because
Bluetooth wireless signals are signicantly
lower in radio frequency power than those
produced by a typical mobile phone.
The sound is
echoing while
talking.
Adjust the speaker volume, or move to another
area and try again.
How do I take care
of my headset?
Wipe it with a soft dry cloth.
The headset does
not fully charge.
The headset and the charger may not have
been connected properly.
Separate the headset from the charger,
reconnect, and charge the headset.
English
19
Warranty and parts replacement
Samsung warrants this product as free of defects in material, design
and workmanship for the period of one year from the original date of
purchase.(Depending on your country, the length of warranty may vary.)
If during the period of warranty this product proves defective under
normal use and service you should return the product to the retailer
from whom it was originally purchased or qualied service centre. The
liability of Samsung and its appointed maintenance company is limited
to the cost of repair and/or replacement of the unit under warranty.
The warranty is limited to the original purchaser
A copy of your receipt or other proof of purchase is required for a
proper warranty service
The warranty is void if the serial number, date code label or product
label is removed, or if the product has been subject to physical abuse,
improper installation, modication, or repair by unauthorised third
parties
Specically exempt from any warranty are limited-life consumable
components such as batteries and other accessories
Samsung will not assume any responsibility for any loss or damage
incurred in shipping. All repair work on Samsung products by
unauthorised third parties voids any warranty
•
•
•
•
•
20
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
This marking shown on the product or its literature, indicates
that it should not be disposed with other household wastes at
the end of its working life.
To prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate this from
other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where
they purchased this product, or their local government ofce,
for details of where and how they can take this item for
environmentally safe recycling.
Business users should contact their supplier and check the
terms and conditions of the purchase contract. This product
should not be mixed with other commercial wastes for disposal.
English
21
Correct disposal of batteries in this product
(Applicable in the European Union and other European countries
with separate battery return systems)
This marking on the battery, manual or packaging indicates
that the batteries in this product should not be disposed of with
other household waste at the end of their working life. Where
marked, the chemical symbols Hg, Cd or Pb indicate that the
battery contains mercury, cadmium or lead above the reference
levels in EC Directive 2006/66. If batteries are not properly
disposed of, these substances can cause harm to human health
or the environment.
To protect natural resources and to promote material reuse,
please separate batteries from other types of waste and recycle
them through your local, free battery return system.
The rechargeable battery incorporated in this product is not
user replaceable. For information on its replacement, please
contact your service provider.
22
Specications
Item Specications and description
Bluetooth version 2.1+EDR
Support prole Headset Prole, Hands-Free Prole,
Advanced Audio Distribution Prole
Operating range Up to 30 feet (10 metres)
Standby time Up to xxx hours*
Talk time Up to x hours*
Charging time Approximately x hours*
* Depending on the phone type and usage, the actual time may vary.
8
FCC
FCC ID: A3LWEP900
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
The device and its antenna must not be co-located or operating
in conjunction with any other antenna or transmitter.
Users are not permitted to make changes or modify the device
in any way.
Changes or modifications not expressly approved by Samsung
will void the user’s authority to operate the equipment.
Industry Canada
IC ID: 649E-WEP900
Operation is subject to the following two conditions: (1) This
device may not cause interference and (2) This device must
Safety approvals
9
E
ng
li
s
h
accept any interference, including interference that may cause
undesired operation of the device.
The term “IC:” before the certification/registration number only
signifies that registration was performed based on a Declaration
of Conformity indicating that Industry Canada technical
specifications were met. It does not imply that Industry Canada
approved the equipment.
English
23
Declaration of Conformity (R&TTE)
We, Samsung Electronics
declare under our sole responsibility that the product
Bluetooth Headset : WEP900
to which this declaration relates, is in conformity with the following standards and/or other
normative documents.
SAFETY EN
EMC EN
EN
EN
EN
RADIO EN
We hereby declare that [all essential radio test suites have been carried out and that] the above
named product is in conformity to all the essential requirements of Directive 1999/5/EC.
which will be made available upon request.
(Representative in the EU)
Samsung Electronics Euro QA Lab.
Blackbushe Business Park, Saxony Way,
Yateley, Hampshire, GU46 6GG, UK*
2008.xx.xx Yong-Sang Park / S. Manager
(place and date of issue) (name and signature of authorised person)
* It is not the address of Samsung Service Centre. For the address or the phone number of Samsung
Service Centre, see the warranty card or contact the retailer where you purchased your product.
