Samsung Electronics Co WIS09ABGN2 Wireless LAN adapter User Manual
Samsung Electronics Co Ltd Wireless LAN adapter
User Manual
English-1
2009 Wireless LAN Adapter
WIS09ABGN2
Features
• Compatible with IEEE 802.11a/b/g and 802.11n draft 2.0
• Supports USB 2.0
• Compact and Lightweight Pocket-Sized Design
• Supports 2009 SAMSUNG TVs with Internet@TV
(For compatible TV models, refer to the information printed on the product box.)
• Supports 2009 SAMSUNG Blu-ray Disc Players / Home Theater Systems
(For more information, please refer to the Blu-ray Disc Players / Home Theater
Systems User Manual.)
Accessory
• USB right angle adapter (only for Blu-ray Disc Players / Home Theater Systems)
Installing the Adapter
• Insert the Wireless LAN Adapter into the TVs / Blu-ray Disc Players / Home Theater
Systems’ USB port.
• For installation precautions and instructions, refer to the TVs / Blu-ray Disc Players /
Home Theater Systems User Manual.
- TV: “Network Connection → Wireless” section
- Blu-ray Disc Player / Home Theater System:
“Network Setup → Wireless Network” section
Safety Precautions
• Do not let children swallow the product or play with the plastic bag. Keep the
product and the plastic bag out of the reach of children.
• Do not let water or other liquids come into contact with the product, as it may result
in damage.
• Keep the product away from direct sunlight, re or a heat source such as a heater.
This may reduce the product lifetime or result in re.
Warranty: 1 Year
• If the product is not working properly due to a performance defect that appears
under normal circumstances within the warranty period, please visit the retailer
where you purchased it. (Please contact Samsung service center in Argentina,
Brazil, Chile, Colombia, Mexico and Panama.)
FCC
This device complies with part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Changes or modications not expressly approved
by the party responsible for compliance could void
the user’s authority to operate the equipment.
To comply with the FCC RF exposure compliance
requirements, this device and its antenna must not
be co-located or operated in conjunction with any
other antenna or transmitter.
Specications (WIS09ABGN2)
Standard IEEE 802.11 a/b/g/n ( n : draft 2.0)
Host Interface USB 2.0
Frequency Range 2.412 ~ 2.4835GHz
5.15 ~ 5.850GHz
Security 64/128bit WEP, WPA /WPA2, 802.1x, WPS
Output Power
802.11a: 18dBm at 6Mbps
802.11b: 18dBm at 11, 5.5, 2, and 1Mbps
802.11g: 17dBm at 6Mbps
802.11n(2.4GHz): 18dBm (20MHz) / 17dBm (40MHz)
802.11n(5GHz): 21dBm (20MHz) / 21dBm (40MHz)
Data Rate
802.11a/g: 54,48,36,24,18,12,9 and 6Mbps
802.11b: 11,5.5,2 and 1Mbps
802.11n: up to 300Mbps (40MHz / spatial streams: 2)
Sensitivity
802.11a: –68dBm at 54Mbps
802.11b: –84dBm at 11Mbps
802.11g: –68dBm at 54Mbps
802.11n: –68dBm (20MHz) / –65dBm (40MHz)
Power consumption TX: 500mA at continuous transmit mode (2 Tx chains on )
RX: 300mA at continuous receive mode (2 Rx chains on )
Supported Models
2009 SAMSUNG LED TV Series : UN**B6*** (USA / Canada only),
UN**B7*** / B8*** / B9***
2009 SAMSUNG LCD TV Series : LN**B6** / B7** / B8**
2009 SAMSUNG PDP TV Series : PN**B6** / B8**
2009 SAMSUNG Blu-ray Disc Players : BD-P1590 / P16** / P36** / P46**
2009 SAMSUNG Home Theater Systems : HT-BD12** / BD32** / BD72** /
BD8200
* In TV series above, only the TVs with Internet@TV logo are supported.
Dimensions (L X W X D) 3.3 X 1.047 X 0.63 inches (84 X 26.6 X 16 mm)
Ideal For 802.11n (5GHz) 802.11n (2.4GHz) 802.11 a/b/g
streaming HD video
recommended
not recommended not recommended
recommended recommended
streaming SD video
music, photo
- Network conditions and environmental factors (including but not limited) volume of network trafc, building
materials and construction, may lower actual data throughput rate.
- Environmental conditions will affect wireless signal coverage.
- Video clips with lower than 20Mbps bit-rates are recommended for the wireless video streaming.
English-2
2009 Wireless LAN Adapter
WIS09ABGN2
Caractéristiques
• Compatible avec IEEE 802.11a/b/g et 802.11n draft 2.0
• Compatible avec USB 2.0
• Appareil de poche compact et léger
• Est compatible avec les téléviseurs SAMSUNG 2009 dotés de l’option
Internet@TV (Pour les modèles de téléviseurs compatibles, consulter
l’information imprimée sur la boîte du produit.)
• Compatible avec les lecteurs Blu-ray ou systèmes de cinéma maison
SAMSUNG 2009 (Pour de plus amples renseignements, consultez le manuel
d’utilisation du lecteurs Blu-ray ou du systèmes de cinéma maison.)
Accessoire
• Adaptateur à angle droit pour clé USB (seulement pour les lecteurs Blu-ray ou
systèmes de cinéma maison)
Installation de l’adaptateur
• Insérez l’adaptateur LAN sans l dans le port USB du téléviseur, du lecteurs
Blu-ray ou du systèmes de cinéma maison.
• Pour obtenir les précautions et les instructions pour l’installation, consultez
le manuel d’utilisation du téléviseur, du lecteurs Blu-ray ou du systèmes de
cinéma maison.
- Téléviseur : Section « Connexion réseau → Sans l »
- Lecteur Blu-ray ou système de cinéma maison :
Section « Conguration du réseau - Réseau sans l »
Mesures de précaution
• Ne pas laisser les enfants jouer avec l’emballage en plastique et veiller à ce
qu’ils ne portent pas le produit à la bouche. Conserver le produit et l’emballage
en plastique hors de la portée des enfants.
• Éviter que le produit n’entre en contact avec de l’eau ou des substances
étrangères. Cela risque d’endommager le produit.
• Ne pas exposer le produit directement à la lumière du soleil, à une amme ou
à une source de chaleur comme un appareil de chauffage. Cela peut réduire la
durée de vie du produit ou causer un incendie.
Garantie : un an
• Si le produit ne fonctionne pas correctement en raison d’une défectuosité qui
se manifeste, dans des circonstances normales, pendant la durée de validité
de la garantie, veuillez vous rendre au détaillant où vous avez effectué l’achat.
Spécications (WIS09ABGN2)
Norme IEEE 802.11 a/b/g/n ( n : draft 2.0)
Interface de l’ordinateur
central USB 2.0
Plage de fréquences 2,412 ~ 2,4835 GHz
5,15 ~ 5,850 GHz
Sécurité 64/128 bits WEP, WPA /WPA2, 802.1x, WPS
Puissance de sortie
802.11a : 18 dBm à 6 Mbps
802.11b : 18 dBm à 11, 5,5, 2 et 1 Mbps
802.11g : 17 dBm à 6 Mbps
802.11n (2,4 GHz) : 18 dBm (20 MHz) / 17 dBm (40 MHz)
802.11n (5 GHz) : 21 dBm (20 MHz) / 21 dBm (40 MHz)
Débit des données
802.11a/g : 54, 48, 36, 24, 18, 12, 9 et 6 Mbps
802.11b : 11, 5,5, 2 et 1 Mbps
802.11n : jusqu’à 300 Mbps (40 MHz / ux spatiaux : 2)
Sensibilité
802.11a : – 68 dBm à 54 Mbps
802.11b : – 84 dBm à 11 Mbps
802.11g : – 68 dBm à 54 Mbps
802.11n : – 68 dBm (20 MHz) / – 65 dBm (40 MHz)
Consommation Émission : 500 mA en mode de transmission continue (2 chaînes d’émission)
Réception : 300 mA en mode de réception continue (2 chaînes de réception)
Modèles compatibles
TÉLÉVISEURS DEL SAMSUNG 2009 SÉRIE : UN**B6***
(États-Unis / Canada uniquement),
UN**B7*** / B8*** / B9***
TÉLÉVISEURS ACL SAMSUNG 2009 SÉRIE : LN**B6** / B7** / B8**
TÉLÉVISEURS À ÉCRAN PLASMA SAMSUNG 2009 SÉRIE : PN**B6** / B8**
Lecteurs Blu-ray SAMSUNG 2009 : BD-P1590 / P16** / P36** / P46**
Systèmes de cinéma maison SAMSUNG 2009 : HT-BD12** / BD32** / BD72** /
BD8200
* Parmi les modèles ci-dessus, ne sont compatibles que les téléviseurs ayant le logo
Internet@TV.
Dimensions (L X L X P) 84 X 26,6 X 16 mm (3,3 X 1,047 X 0,63 po)
Ideal For 802.11n (5 GHz) 802.11n (2,4 GHz) 802.11 a/b/g
vidéo HD en continu
recommandé
non recommandé non recommandé
recommandé recommandé
vidéo en SD en continu
musique, photos
- L’état du réseau et les facteurs environnementaux, y compris, mais sans s’y limiter, le volume du
trac sur le réseau, les matériaux de construction et les constructions peuvent réduire le ot de
données réel.
- Les conditions ambiantes auront une incidence sur la couverture des signaux des réseaux sans l.
- Les vidéoclips ayant un débit binaire inférieurs à 20 mbps sont recommandés pour la lecture en
transit de chiers visuels sans l.
Français-1 Français-2
WIS09ABGN-L03��-A4.indd 1 2009-07-29 ¿ÀÈÄ 1:41:31
Español-1
2009 Wireless LAN Adapter
WIS09ABGN2
Características
• Compatible con IEEE 802.11a/b/g y 802.11n, draft 2.0
• Admite USB 2.0
• Diseño compacto y ligero tamaño bolsillo
• Admite televisores SAMSUNG 2009 con Internet@TV (Para saber los modelos de TV
compatibles, consulte la información impresa en la caja del producto.)
• Admite reproductores de disco Blu-ray / sistemas Home Theater de SAMSUNG
2009 (Para obtener más información consulte los manuales del usuario de los
reproductores de discos Blu-ray / sistemas Home Theater.)
Accesorios
• Adaptador USB en ángulo recto (sólo para los reproductores de discos Blu-ray /
sistemas Home Theater)
Instalación del adaptador
• Inserte el adaptador LAN inalámbrico en el puerto USB de televisores / reproductores
de discos Blu-ray / sistemas Home Theater.
• Para conocer las instrucciones y precauciones de instalación consulte los manuales
del usuario de televisores / reproductores de discos Blu-ray / sistemas Home Theater.
- TV: Sección “Conexión de la red → Inalámbrica”
- Reproductor de discos Blu-ray / sistema Home Theater: Sección “Conguración de
la red → inalámbrica”
Precauciones de seguridad
• Tenga cuidado que los niños no se traguen el producto ni jueguen con la bolsa de
plástico. Mantenga el producto y la bolsa de plástico lejos de los niños.
• No permita que el agua o cualquier otro líquido entren en contacto con el producto, ya
que podría ocasionar daños.
• Mantenga el producto apartado de la luz directa del sol, del fuego o de una fuente
de calor, como un calentador. Esto podría reducir la vida del producto o causar un
incendio.
Garantía: 1 año
• Si el producto no funciona correctamente debido a un defecto de rendimiento que
aparece en circunstancias normales dentro del periodo de garantía, póngase en
contacto con su distribuidor local. (Póngase en contacto con el centro de servicio
técnico de Samsung en Argentina, Brasil, Chile, Colombia, México y Panamá.)
Especicaciones (WIS09ABGN2)
Estándar IEEE 802.11 a/b/g/n (n: draft 2.0)
Interfaz del sistema USB 2.0
Rango de frecuencias 2,412 ~ 2,4835GHz
5,15 ~ 5,850GHz
Seguridad 64/128 bits WEP, WPA /WPA2, 802.1x, WPS
Potencia de salida
802.11a: 18dBm a 6 Mbps
802.11b: 18 dBm a 11, 5,5, 2 y 1 Mbps
802.11g: 17 dBm a 6 Mbps
802.11n (2,4 GHz): 18 dBm (20 MHz) / 17 dBm (40 MHz)
802.11n (5GHz): 21 dBm (20 MHz) / 21 dBm (40 MHz)
Velocidad de datos
802.11a/g: 54, 48, 36, 24,18, 12, 9 y 6 Mbps
802.11b: 11, 5,5, 2 y 1Mbps
802.11n: hasta 300 Mbps (40MHz / transmisiones espaciales: 2)
Sensibilidad
802.11a: –68 dBm a 54 Mbps
802.11b: –84 dBm a 11 Mbps
802.11g: –68 dBm a 54 Mbps
802.11n: –68 dBm (20 MHz) / –65 dBm (40 MHz)
Consumo de energía TX : 500mA en modo de transmisión continua (2 Tx cadenas activadas )
RX : 300 mA en modo de recepción continua (2 Rx cadenas activadas )
Modelos admitidos
TV LED SAMSUNG 2009 Serie: UN**B6*** (EE.UU./ Canadá solamente),
UN**B7*** / B8*** / B9***
TV LCD SAMSUNG 2009 Serie: LN**B6** / B7** / B8**
TV PDP SAMSUNG 2009 Serie: PL**B6** / B8**
Reproductores de discos Blu-ray SAMSUNG 2009: BD-P16** / P36** / P46**
Sistemas de Home Theater SAMSUNG 2009: HT-BD12** / BD32** / BD72** / BD8200
* En las series TV anteriores, sólo se admiten los televisores con logotipo Internet@TV.
Dimensiones (Al x An x Pr) 3,3 x 1,047 x 0,63 pulgadas (84 x 26,6 x 16 mm)
Ideal For 802.11n (5 GHz) 802.11n (2,4GHz) 802.11 a/b/g
transmisión vídeo HD
recomendado
no recomendado no recomendado
recomendado recomendado
transmisión vídeo SD
música, fotos
- Las condiciones de la red y los factores ambientales (incluidos pero sin limitación), el volumen del tráco
en la red, los materiales de construcción y las edicaciones pueden reducir la velocidad de transmisión de
datos real.
- Las condiciones ambientales afectarán a la recepción de la señal inalámbrica.
- En la transmisión de vídeo inalámbrico se recomiendan los clips de vídeo con tasa de bits inferiores a 20
Mbps.
Español-2
2009 Wireless LAN Adapter
WIS09ABGN2
Características
• Compatível com a norma IEEE 802.11a/b/g e 802.11n preliminar 2.0
• Suporta USB 2.0
• Design portátil, compacto e leve.
• Suporta TVs SAMSUNG de 2009 com Internet@TV (Para conhecer os modelos
de TV compatíveis, consulte as informações contidas na caixa do produto.)
• Compatível com Blu-ray Disc Player / Sistemas de Home Theater da SAMSUNG
2009 (para mais informações, consulte o Manual do Usuário do Blu-ray Disc
Player / Sistemas de Home Theater.)
Acessórios
• Adaptador USB a 90º (apenas para Blu-ray Disc Player / Sistemas de Home
Theater)
Instalação do adaptador
• Insira o adaptador de rede sem o na porta USB da TV / Blu-ray Disc Player /
Sistemas de Home Theater
• Para precauções e instruções na instalação, consulte o Manual do Usuário da TV
/ Blu-ray Disc Player / Sistemas de Home Theater
- TV: Seção “conexão de rede → Wireless” (“Conexão de rede → Sem o”)
- Blu-ray Disc Player / Sistemas de Home Theater: Seção “conguração de rede
→ Wireless” (“Conguração de rede → Rede sem o”)
Cuidados de segurança
• Não permita que as crianças engulam o produto ou brinquem com a embalagem
plástica. Mantenha o produto e a embalagem plástica fora do alcance de crianças.
• Não deixe que água ou outros líquidos entrem em contato com o produto, pois
isso, poderá resultar em danos.
• Mantenha o produto longe de luz solar direta, fogo ou fonte de calor, como
aquecedores, por exemplo, pois pode haver redução da vida útil do produto ou
incêndio.
Garantia: 1 ano
• Se o produto não estiver funcionando apropriadamente devido a um defeito de
execução que venha a aparecer em circunstâncias normais durante o período
de garantia, procure a loja onde você adquiriu o produto. (Entre em contato com
o centro de serviço Samsung em: Argentina, Brasil, Chile, Colômbia, México e
Panamá.)
Português-1
Português-2
Especicações (WIS09ABGN2)
IEEE 802.11 a/b/g/n ( n : draft 2.0) padrão
Interface do host USB 2.0
Área de freqüência 2,412 ~ 2,4835 GHz
5,15 ~ 5,850 GHz
Segurança 64/128 bits WEP, WPA /WPA2, 802.1x, WPS
Saída de força
802.11a: 18 dBm a 6 Mbps
802.11b: 18 dBm a 11; 5,5; 2 e 1 Mbps
802.11g: 17 dBm a 6 Mbps
802.11n (2,4 GHz): 18 dBm (20 MHz) / 17 dBm (40 MHz)
802.11n (5 GHz): 21 dBm (20 MHz) / 21 dBm (40 MHz)
Taxa de dados
802.11a/g: 54; 48; 36; 24; 18; 12; 9 e 6 Mbps
802.11b: 11; 5,5; 2 e 1 Mbps
802.11n: até 300 Mbps (40 MHz / spatial streams: 2)
Sensibilidade
802.11a: –68 dBm a 54 Mbps
802.11b: –84 dBm a 11 Mbps
802.11g: –68 dBm a 54 Mbps
802.11n: –68 dBm (20 MHz) / –65 dBm (40 MHz)
Consumo de energia TX: 500 mA no modo de transmissão contínua (2 cadeias Tx ligadas)
RX: 300 mA no modo de recepção contínua (2 cadeias Rx ligadas)
Modelos suportados
TV LED SAMSUNG 2009 Séries: UN**B7*** / B8*** / B9***
TV LCD SAMSUNG 2009 Séries: LN**B6** / B7** / B8**
TV PDP SAMSUNG 2009 Séries: PL**B6** / B8**
Disc Players Blu-ray SAMSUNG 2009: BD-P16** / P36** / P46**
Sistemas de Home Theater da SAMSUNG 2009: HT-BD12** / BD32** /
BD72** / BD8200
* Nas séries das TVs acima, são suportados apenas os modelos com o
logótipo Internet@TV.
Dimensões (C x L x A) 3,3” x 1,047” x 0,63” (84 mm x 26,6 mm x 16 mm)
Ideal para 802.11n (5 GHz): 802.11n (2,4 GHz) 802.11 a/b/g
vídeo streaming em HD
recomendado
não recomendado não recomendado
recomendado recomendado
vídeo streaming em SD
música, fotos
- As condições de rede e os fatores ambientais, incluindo, mas não se limitando a, volume de tráfego de
rede, materiais de construção e construção, podem ocasionar uma taxa real de transferência de dados
menor.
- As condições ambientais afetarão o alcance do sinal sem o.
- Vídeo clipes com menos de 20 Mbps de taxa de bits são recomendados para o vídeo streaming sem o.
WIS09ABGN-L03��-A4.indd 2 2009-07-29 ¿ÀÈÄ 1:41:31
Regulatory Compliance Information
FCC Compliance Statement
This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions:
(1) This device may not cause harmful
interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
Interference
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there
is no guarantee that interference will not
occur in a particular installation. If this
equipment does cause harmful interference
to radio or television reception, which can be
determined by turning the equipment off and
on, the user is encouraged to try to correct
the interference by one of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.
Wireless Radio
For product available in the USA/Canada
market, only channel 1~11 can be operated.
Selection of other channels is not possible.
This device is going to be operated in
5.15~5.25GHz frequency range, it is
restricted in indoor environment only.
Important: Changes or modications not
expressly approved by the party responsible
for compliance could void the user’s
authority to operate the equipment.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This equipment should be
installed and operated with minimum
distance 20cm between the radiator & your
body.
Industry Canada Statement
This Class B digital apparatus complies with
Canadian ICES-003.
Cet appareil numérique de la classe B est
conforme à la norme NMB-003 du Canada.
Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
This device and its antenna(s) must not be
colocated or operation in conjunction with any
other antenna or transmitter.
Wireless Radio
For product available in the USA/Canada
market, only channel 1~11 can be operated.
Selection of other channels is not possible.
The device could automatically discontinue
transmission in case of absence of
information to transmit, or operational
failure. Note that this is not intended to
prohibit transmission of control or signaling
information or the use of repetitive codes
where required by the technology.
Important: Changes or modications not
expressly approved by the party responsible
for compliance could void the user’s
authority to operate the equipment.
IC Radiation Exposure Statement:
This equipment complies with IC RSS-102
radiation exposure limits set forth for an
uncontrolled environment. This equipment
should be installed and operated with
minimum distance 20cm betw
een the
radiator & your body.
Korea Statements
1)
당해 무선설비는 운용 중 전파혼신 가능성이 있음.
2)
당해 무선설비는 전파혼신 가능성이 있으므로
인명안전과 관련된 서비스는 할 수 없음.
Regulatory Compliance Informatio1 1 2009-03-27 ¿ÀÈÄ 4:20:27
