Samsung Electronics Co YPG70 Mobile Internet Device User Manual
Samsung Electronics Co Ltd Mobile Internet Device
User manual
Some of the contents in this manual may dier from your device depending on the software of the device or your service
provider.
www.samsungmobile.com English (EU). 03/2011. Rev. 1.0
To install Kies (PC Sync)
Download the latest version of Kies from the Samsung 1.
website (www.samsung.com/kies) and install it on
your PC.
Using a PC data cable, connect your device to your PC.2.
Refer to the Kies help for more information.
YP-G70
user manual
Using this manual
2
Using this manual
Thank you for purchasing this Samsung YP-G70. This
device will provide you with entertainment based on
Samsung’s exceptional technology and high standards.
This user manual has been specially designed to guide you
through the functions and features of your device.
Read me rst
Please read all safety precautions and this manual •
carefully before using your device to ensure safe and
proper use.
The descriptions in this manual are based on the default
•
settings of your device.
Images and screenshots used in this user manual may
•
dier in appearance from the actual product.
Content in this user manual may dier from the product,
•
or from software provided by service providers or
carriers, and is subject to change without prior notice.
Refer to www.samsungmobile.com for the latest version
of the user manual.
Available features and additional services may vary by
•
device, software, or service provider.
Formatting and delivery of this user manual is based
•
on Google Android operating systems and may vary
depending on the user’s operating system.
Applications and their functions may vary by country,
•
region, or hardware specications. Samsung is not
liable for performance issues caused by third-party
applications.
Samsung is not liable for performance issues or
•
incompatibilities caused by user editing of registry
settings.
You may upgrade your mobile device’s software by
•
accessing www.samsungmobile.com.
Using this manual
3
Note—notes, usage tips, or additional
information
►Refer to—pages with related information; for
example: ► p.12 (represents “see page 12”)
→
Followed by—the order of options or menus
you must select to perform a step; for example:
In Idle mode, open the application list and select
Settings
→
About device (represents Settings,
followed by About device)
[ ] Square brackets—device keys; for example:
[] (represents the Power/Lock key)
Sound sources, wallpapers, and images provided in this
•
device are licenced for limited use between Samsung
and their respective owners. Extracting and using
these materials for commercial or other purposes is an
infringement of copyright laws. Samsung is not liable for
such copyright infringement by the user.
Please keep this manual for future reference.
•
Instructional icons
Before you start, familiarise yourself with the icons you will
see in this manual:
Warning—situations that could cause injury to
yourself or others
Caution—situations that could cause damage to
your device or other equipment
Using this manual
4
Trademarks
SAMSUNG and the SAMSUNG logo are registered •
trademarks of Samsung Electronics.
The Android logo, Google Search
• ™, Google Maps™,
Google Mail™, YouTube™, Android Market™, and
Google Talk™ are trademarks of Google, Inc.
Bluetooth
• ® is a registered trademark of the Bluetooth
SIG, Inc. worldwide.
Oracle and Java are registered trademarks of Oracle and/
•
or its aliates. Other names may be trademarks of their
respective owners.
Wi-Fi
• ®, the Wi-Fi CERTIFIED logo, and the Wi-Fi logo are
registered trademarks of the Wi-Fi Alliance.
Copyright
Copyright © 2011 Samsung Electronics
This user manual is protected under international
copyright laws.
No part of this user manual may be reproduced,
distributed, translated, or transmitted in any form or by any
means, electronic or mechanical, including photocopying,
recording, or storing in any information storage and
retrieval system, without the prior written permission of
Samsung Electronics.
Using this manual
5
ABOUT DIVX VIDEO
DivX® is a digital video format created by DivX, Inc. This is
an ocial DivX Certied® device that plays DivX video. Visit
www.divx.com for more information and software tools to
convert your les into DivX video.
DivX Certied® to play DivX® video up to HD 720p,
including premium content.
ABOUT DIVX VIDEO-ON-DEMAND
This DivX Certied® device must be registered in order to
play purchased DivX Video-on-Demand (VOD) movies. To
obtain your registration code, locate the DivX VOD section
in your device setup menu. Go to vod.divx.com for more
information on how to complete your registration.
DivX
• ®, DivX Certied®,
and associated logos are
trademarks of DivX, Inc. and
are used under licence.
All other trademarks and copyrights are the property of
•
their respective owners
Contents
6
Contents
Assembling ........................................... 10
Unpack ................................................................ 10
Charge the battery ........................................... 11
Insert a memory card (optional) ................... 13
Getting started ..................................... 16
Turn your device on and o ........................... 16
Get to know your device ................................. 16
Use the touch screen ........................................ 19
Lock or unlock the touch screen and keys . . 20
Get to know the idle screen ........................... 20
Access applications .......................................... 22
Customise your device .................................... 24
Enter text ............................................................ 27
Download applications from Android
Market ................................................................. 30
Download les from the web ........................ 31
Synchronise data .............................................. 31
Communication ................................... 33
Qik Video ............................................................. 33
Google Mail ........................................................ 33
Email .................................................................... 35
Talk ....................................................................... 37
Contents
7
Web ........................................................ 61
Internet ............................................................... 61
Maps .................................................................... 64
Latitude ............................................................... 66
Places ................................................................... 67
Navigation .......................................................... 67
Google Search ................................................... 68
YouTube .............................................................. 68
Samsung Apps .................................................. 70
Market ................................................................. 70
Connectivity ......................................... 71
Bluetooth ............................................................ 71
Wi-Fi ..................................................................... 73
Entertainment ...................................... 38
Camera ................................................................ 38
Video .................................................................... 47
Gallery ................................................................. 48
Music .................................................................... 49
FM radio .............................................................. 52
Personal information .......................... 55
Contacts .............................................................. 55
Calendar .............................................................. 58
Memo ................................................................... 59
Voice Recorder ................................................... 60
Contents
8
Settings .................................................. 88
Access the Settings menu ............................... 88
Wireless and network ...................................... 88
Sound .................................................................. 89
Display ................................................................. 89
Location and security ...................................... 91
Applications ....................................................... 92
Accounts and sync ............................................ 92
Privacy ................................................................. 93
SD card and device storage ............................ 93
Locale and text .................................................. 93
Voice input and output ................................... 94
AllShare ............................................................... 75
PC connections .................................................. 77
VPN connections ............................................... 78
Tools ....................................................... 81
Alarm/Clock ........................................................ 81
Calculator ............................................................ 83
Mini Diary ........................................................... 83
My Files ................................................................ 84
Task manager .................................................... 85
ThinkFree Oce ................................................ 86
Voice Search ....................................................... 87
Contents
9
Accessibility ........................................................ 95
Date and time .................................................... 96
About device ...................................................... 96
Troubleshooting .................................. 97
Safety precautions ............................. 101
Index .................................................... 110
Assembling
10
Assembling
Unpack
Check your product box for the following items:
Mobile device
•
Travel adapter (charger)•
PC data cable•
Headset•
Quick start guide•
Use only Samsung-approved software. Pirated or
illegal software may cause damage or malfunctions
that are not covered by your manufacturer's
warranty.
The items supplied with your device may vary •
depending on the software and accessories
available in your region or oered by your service
provider.
You can obtain additional accessories from your
•
local Samsung dealer.
The supplied accessories perform best for your
•
device.
Accessories other than the supplied ones may not
•
be compatible with your device.
Assembling
11
Charge with the travel adapter
›
Plug the small end of the travel adapter into the
1
multifunction jack.
Connecting the travel adapter improperly may
cause serious damage to the device. Any damage
caused by misuse is not covered by the warranty.
Charge the battery
Before using the device for the rst time, you must charge
the battery.
You can charge the device with the provided travel adapter
or by connecting the device to a PC with a PC data cable.
Use only Samsung-approved chargers and cables.
Unauthorised chargers or cables can cause batteries
to explode or damage your device.
When your battery is low, the device will emit a
warning tone and display a low battery message.
The battery icon will also be empty. If the
battery level becomes too low, the device will
automatically power o. Recharge your battery to
continue using your device.
Assembling
12
When the battery is fully charged (the battery icon is
3
no longer moving), unplug the travel adapter from the
device and then from the power outlet.
To save energy, unplug the travel adapter when not
in use. The travel adapter does not have a power
switch, so you must unplug the travel adapter from
the outlet to interrupt the power supply. The travel
adapter should remain close to the socket when
in use.
Charge with the PC data cable
›
Before charging, ensure that your PC is turned on.
Plug one end (micro-USB) of the PC data cable into the
1
multifunction jack.
Plug the large end of the travel adapter into a power
2
outlet.
You can use the device while it is charging, but it •
may take longer to fully charge the battery.
While the device is charging, the touch screen may
•
not function due to an unstable power supply. If
this happens, unplug the travel adapter from the
device.
While charging, the device may heat up. This
•
is normal and should not aect your device’s
lifespan or performance.
If your device is not charging properly, bring your
•
device and the charger to a Samsung Service
Centre.
Assembling
13
Samsung uses approved industry standards for
memory cards, but some brands may not be fully
compatible with your device. Using an incompatible
memory card may damage your device or the
memory card and can corrupt data stored on the
card.
Your device supports only the FAT le structure for •
memory cards. If you insert a card formatted with
a dierent le structure, your device will ask you to
reformat the memory card.
Frequent writing and erasing of data will shorten
•
the lifespan of memory cards.
When you insert a memory card in your device,
•
the le directory of the memory card will appear
in the mnt/sdcard/external_sd folder.
Plug the other end of the PC data cable into a USB port
2
on a PC.
Depending on the type of PC data cable you are
using, it may take some time before charging
begins.
When the battery is fully charged (the battery icon is
3
no longer moving), unplug the PC data cable from the
device and then from the PC.
Insert a memory card (optional)
To store additional multimedia les, you must insert
a memory card. Your device accepts microSD™ or
microSDHC™ memory cards with maximum capacities
of 32 GB (depending on memory card manufacturer and
type).
Assembling
14
Remove the memory card
›
Before removing a memory card, rst unmount it for safe
removal.
In Idle mode, select
1
Applications
→
Settings
→
SD
card and device storage
→
Unmount SD card.
Open the cover to the memory card slot on the top of
2
the device.
Push the memory card gently until it disengages from
3
the device.
Pull the memory card out of the memory card slot.
4
Remove the memory card.
5
Close the memory card cover.
6
Do not remove a memory card while the device is
transferring or accessing information, as this could
result in loss of data or damage to the memory card
or device.
Open the cover to the memory card slot on the top of
1
the device.
Insert a memory card with the gold-coloured contacts
2
facing down.
Push the memory card in the memory card slot until it
3
locks in place.
Close the memory card cover.
4
Assembling
15
Format the memory card
›
Formatting your memory card on a PC may cause
incompatibilities with your device. Format the memory
card only on the device.
In Idle mode, select Applications
→
Settings
→
SD card
and device storage
→
Unmount SD card
→
Format SD
Card
→
Format SD card
→
Erase everything.
Before formatting the memory card, remember to
make backup copies of all important data stored on
your device. The manufacturer’s warranty does not
cover loss of data resulting from user actions.
Getting started
16
Getting started
Turn your device on and o
To turn on your device,
Press and hold [
1
].
If you turn on your device for the rst time, follow the
2
on-screen instructions to set up your device.
To turn o your device, press and hold [ ] and select
Power o.
Follow all posted warnings and directions from •
ocial personnel when in areas where the use of
wireless devices is restricted, such as aeroplanes
and hospitals.
To use your device's non-network services only,
•
switch to Flight mode. Press and hold [ ] and
select Flight mode.
Get to know your device
Device layout
›
Home key
Menu key
Touch screen
Back key
Earpiece
Front camera lens
Memory card slot
Getting started
17
Keys
›
Key Function
Power/
Lock
Turn on the device (press and
hold); Access the quick menus
(press and hold); Lock the touch
screen.
Menu
Open a list of options available on
the current screen; Open the quick
search bar (press and hold).
Home
Return to the idle screen; Open
the list of recent applications
(press and hold).
Back Return to the previous screen.
Volume Adjust the device’s volume.
Back cover
Speaker
Multifunction jack
Mouthpiece
Speaker
Headset jack
Power/Lock key
Volume key
Rear camera lens
Flashbulb
Getting started
18
Icon Denition
Alarm activated
Event notication
Silent mode activated
Flight mode activated
Vibration mode activated
Music playback in progress
Music playback paused
FM radio turned on in the background
Error occurred or caution required
Battery power level
10:00
Current time
Indicator icons
›
Icons shown on the display may vary depending on
your region or service provider.
Icon Denition
WLAN activated
Bluetooth activated
Bluetooth headset connected
GPS activated
Synchronised with the web
Uploading data
Downloading data
Connected to PC
New email message
Getting started
19
For optimal use of the touch screen, remove the •
screen protection lm before using your device.
Your touch screen has a layer that detects small
•
electrical charges emitted by the human body.
For best performance, tap the touch screen with
your ngertip. The touch screen will not react to
touches of sharp tools, such as a stylus or pen.
Control your touch screen with the following actions:
Tap: Touch once with your nger to select or launch a
•
menu, option, or application.
Tap and hold: Tap an item and hold it for more than 2
•
seconds to open a pop-up option list.
Drag: Tap and drag your nger up, down, left, or right to
•
move to items on lists.
Drag and drop: Tap and hold your nger on an item, and
•
then drag your nger to move the item.
Double-tap: Tap twice quickly with your nger to zoom
•
in or out while viewing photos or web pages.
Use the touch screen
Your device’s touch screen lets you easily select items or
perform functions. Learn basic actions to use the touch
screen.
To avoid scratching the touch screen, do not use •
sharp tools.
Do not allow the touch screen to come into
•
contact with other electrical devices. Electrostatic
discharges can cause the touch screen to
malfunction.
Do not allow the touch screen to come into
•
contact with water. The touch screen may
malfunction in humid conditions or when
exposed to water.
Getting started
20
Get to know the idle screen
When the device is in Idle mode, you will see the idle
screen. From the idle screen, you can view your device’s
status and access applications.
The idle screen has multiple panels. Scroll left or right to a
panel of the idle screen.
›
Add items to the idle screen
You can customise the idle screen by adding shortcuts to
applications or items in applications, widgets, or folders. To
add items to the idle screen,
Press [
1
]
→
Add or tap and hold the empty area on
the idle screen.
Select the item category
2
→
an item:
Widgets
• : Add widgets. Widgets are small
applications that provide convenient functions and
information on your idle screen.
Your device turns o the touch screen when you •
do not use the device for a specied period.
You can adjust the backlight time. In Idle mode,
•
open the application list and select Settings
→
Display
→
Screen timeout.
Lock or unlock the touch screen
and keys
You can lock the touch screen and keys to prevent any
unwanted device operations.
To lock, press [ ]. To unlock, turn on the screen by
pressing [ ] or the Home key and then ick the grey
window with your nger.
Getting started
21
Use the shortcuts panel
›
In Idle mode or while using an application, tap the
indicator icons area and drag your nger down to open
the shortcuts panel. You can activate or deactivate wireless
connection features and access a list of notications, such
as new email messages, upcoming events, and processing
status. To hide the list, drag the bottom of the list up.
From the shortcuts panel, you can use the following
options:
Wi-Fi
• : Activate or deactivate the WLAN connection
feature. ► p. 73
Bluetooth
• : Activate or deactivate the Bluetooth wireless
connection feature. ► p. 71
GPS
• : Activate or deactivate the GPS feature.
Sound
• : Activate or deactivate Silent mode.
Auto rotation
• : Activate or deactivate the auto rotation.
Available options may vary depending on your
region or service provider.
Shortcuts
• : Add shortcuts to items, such as
applications, bookmarks, and contacts.
Folders
• : Create a new folder or add folders for your
contacts.
Wallpapers
• : Set a background image.
Move items on the idle screen
›
Tap and hold an item to move until the item appears
1
grey.
Drag the item to the location you want.
2
Remove items from the idle screen
›
Tap and hold an item to remove.
1
The trash bin appears at the bottom of the idle screen.
Drag the item to the trash bin.
2
When the item turns red, release the item.
3
Getting started
22
Access applications
To access your device’s applications,
In Idle mode, select
1
Applications to access the
application list.
Scroll left or right to another application screen.
2
Select an application.
3
When you use applications provided by Google, •
you must have a Google account. If you do not
have a Google account, sign up for a Google
account.
You can add a shortcut to an application by
•
tapping and holding the application icon from
the application list. You can move the icon to the
location you want on the idle screen.
›
Add or remove panels to the idle screen
You can add or remove panels of the idle screen to
organise widgets according to your preferences and needs.
In Idle mode, press [
1
]
→
Edit.
You can also place your two ngers on the screen and
pinch to switch to Edit mode.
Add or remove panels by using the following features:
2
To remove a panel, tap and hold the thumbnail of a •
panel and drag it to the trash bin at the bottom of
the screen.
To change the order of the panels, tap and hold the
•
thumbnail of a panel and drag it to the location you
want.
When you are nished, press [
3
].
Getting started
23
Drag the application icon to the location you want.
3
You can move an application icon to another main
menu screen.
Press [
4
]
→
Save.
To change the order of the main menu screens,
In the application list, place your two ngers on the
1
screen and pinch.
Tap and hold the thumbnail of a screen and drag it to
2
the location you want.
Access recent applications
›
Press and hold the Home key to open the list of
1
applications you have accessed recently.
Select an application to access.
2
Press [
4
] to return to the previous screen; Press the
Home key to return to the idle screen.
Your device has a built-in motion sensor that detects
its orientation. If you rotate the device while using
some features, the interface will automatically
switch to landscape view. To set the interface to
keep the orientation when you rotate the device,
select Settings
→
Display
→
Auto-rotate screen.
Organise applications
›
You can reorganise the applications in the application list
by changing their order or grouping them into categories
to suit your preferences and needs.
In the application list, press [
1
]
→
Edit.
Tap and hold an application.
2
Getting started
24
Customise your device
Get more from your device by customising it to match your
preferences.
Set the current time and date
›
In Idle mode, open the application list and select
1
Settings
→
Date and time.
Set the time and date and change other options.
2
Turn on or o the touch tone
›
In Idle mode, open the application list and select Settings
→
Sound
→
Audible selection.
Use the task manager
›
Your device is a multitasking device. It can run more than
one application at the same time. However, multitasking
may cause hang-ups, freezing, memory problems, or
additional power consumption. To avoid these problems,
end unnecessary programs using the task manager.
In Idle mode, open the application list and select
1
Task
manager
→
Active applications.
The list of all the applications currently running on
your device appears.
To close an application, select
2
End.
To close all active applications, select End all.
Getting started
25
Activate animation for switching
›
windows
In Idle mode, open the application list and select Settings
→
Display
→
Animation
→
Some animations or All
animations.
Select a wallpaper for the idle screen
›
In Idle mode, press [
1
]
→
Wallpaper
→
an option.
Select an image.
2
Select
3
Save or Set wallpaper.
Samsung is not responsible for any use of default
images or wallpapers provided on your device.
Adjust the brightness of the display
›
In Idle mode, open the application list and select
1
Settings
→
Display
→
Brightness.
Adjust the volume of the device
›
Press the Volume key up or down to adjust the device
volume.
Switch to Silent mode
›
To mute or unmute your device, do one of the following:
Open the shortcuts panel from the top of the screen and
•
select Sound.
Press and hold [
• ] and select Silent mode.
You can set the device to alert you to various events
in Silent mode. In Idle mode, open the application
list and select Settings
→
Sound
→
Vibrate
→
Always or Only in silent mode. When you switch to
Silent mode, will appear in place of .
Getting started
26
Set an unlock pattern
In Idle mode, open the application list and select
1
Settings
→
Location and security
→
Set screen lock
→
Pattern.
See the on-screen instructions and example patterns
2
and select Next (if necessary).
Draw a pattern by dragging your nger to connect at
3
least 4 dots.
Select
4
Continue.
Draw the pattern again to conrm.
5
Select
6
Conrm.
Drag the slider
2
to adjust the level of brightness.
Select
3
OK.
The brightness level of the display will aect how
quickly the device consumes battery power.
Set a screen lock
›
You can lock the touch screen with an unlock pattern or
password to prevent unauthorised people from using the
device without your permission.
Once you set a screen lock, your device will require •
an unlock code each time you turn it on or unlock
the touch screen.
If you forget your pattern or password, bring your
•
device to a Samsung Service Centre to reset it.
Samsung is not responsible for any loss of security
•
codes or private information or other damages
caused by illegal software.
Getting started
27
Change the keyboard type
›
You can change the keyboard type. Tap and hold the text
input eld and select Input method
→
a keyboard type.
Enter text using the Samsung keypad
›
Select
1
→
Portrait keypad types and select a text
input method.
You can select one of key input methods (QWERTY or
3x4 keypads) or handwriting input methods.
Enter text by selecting alphanumeric keys or writing
2
on the screen.
Set an unlock password
In Idle mode, open the application list and select
1
Settings
→
Location and security
→
Set screen lock
→
Password.
Enter a new password (alphanumeric) and select
2
Continue.
Enter the password again and select
3
OK.
Enter text
You can enter text by selecting characters on the virtual
keypad or by inputting handwriting on the screen.
You cannot enter text in some languages. To enter
text, you should change the writing language to one
of the supported languages. ► p. 93
Getting started
28
Number Function
3
Enter text by voice; This icon is available only
when you activate the voice input feature
for the Samsung keypad.
This feature is available only when •
the wireless connection is active.
This feature may be unavailable
•
depending on the selected input
language.
4
Clear your input.
5
Start a new line.
6
Access the keypad settings; Change the text
input method (tap and hold).
7
Insert a space; Insert a period (double-tap);
Change the input language (scroll left or
right).
Functions of this key may vary
depending on your service provider.
You can also use the following keys:
1
2 5
4
6
7
3
Number Function
1
Change case.
2
Switch between Number/Symbol mode and
ABC mode.
Getting started
29
Place the cursor where you want to start.
1
Tap and hold the text input eld.
2
Select
3
Select text from the option list.
Tap on the place where you want to end.
4
Tap and hold the highlighted text.
5
Select
6
Copy to copy, or Cut to cut the text onto the
clipboard.
In another application, tap and hold the text input
7
eld.
Select
8
Paste to insert the text from the clipboard into
the text eld.
In the handwriting modes, you can use the following
gestures:
Function Gesture
Space
Enter
Backspace
If you have text input keyboards downloaded from
the web, you can change the keypad type. Tap and
hold the text input eld and select Input method
→
a keypad type.
Copy and paste text
›
While you are entering text, you can use the copy and
paste feature to use text in other applications.
Getting started
30
Select an item category
3
→
an item.
Select
4
Install (for free items) or Buy.
If you select Install, select OK to download the item
immediately.
If you select Buy, you need to enter your credit card
information. Follow the on-screen instructions.
Uninstall an application
›
From the Android Market home screen, press [
1
]
→
My apps.
Select the item you want to delete.
2
Select
3
Uninstall
→
OK.
Download applications from
Android Market
Based on the Android platform, your device’s functionality
can be extended by installing additional applications.
Android Market provides you an easy and quick way to
shop for games and mobile applications.
This feature may be unavailable depending on •
your region or service provider.
Your device will save user les from downloaded
•
applications to the internal memory.
Install an application
›
In Idle mode, open the application list and select
1
Market.
Select
2
Accept when the terms and conditions appear.
Getting started
31
To install applications downloaded from websites other
than Android Market, you must select Settings
→
Applications
→
Unknown sources.
Synchronise data
You can synchronise data with various web servers and
back up or restore your data.
Once the synchronisation is completed, your device stays
connected to the web. If any change is made on the web,
the updated information will appear on your device and
will automatically begin synchronisation, and vice versa.
This feature may be unavailable depending on your
region or service provider.
Download les from the web
When you download les or web applications from the
web, your device saves them in a memory card.
Files you download from the web can include
viruses that will damage your device. To lessen your
risk, only download les from sources you trust.
Some media les include Digital Rights
Management to protect copyrights. This protection
may prevent you from downloading, copying,
modifying, or transferring some les.
To download les from the web,
In Idle mode, open the application list and select
1
Internet.
Search for a le or application and download it.
2
Getting started
32
Select the applications you want to synchronise.
4
To exclude applications from automatic synchronisation,
clear the check boxes next to the applications you want.
Synchronise data manually
›
In Idle mode, open the application list and select
1
Settings
→
Accounts and sync.
Select an account.
2
Press [
3
]
→
Sync now. Your device will start
synchronising the data you set for synchronisation.
Set up a server account
›
In Idle mode, open the application list and select
1
Settings
→
Accounts and sync.
Select
2
Add account
→
an account type.
Follow the on-screen instructions to complete the
3
account setup.
For online community services, such as Facebook or
MySpace, enter your user name and password and
select Log in.
Activate automatic sync
›
In Idle mode, open the application list and select
1
Settings
→
Accounts and sync.
Select
2
Auto-sync.
Select an account.
3
Communication
33
Communication
Qik Video
You can make live video calls and share your videos with
others online or by video mail. You can also save videos to
show them to your friends and family later.
You cannot make a call when a Bluetooth headset
is connected.
In Menu mode, select
1
Qik Video
→
Log in.
Enter your user name and password and select
2
Log in.
Make a video call or share your videos.
3
Google Mail
You can retrieve new email messages from Google Mail™
to your Inbox. When you access this application, the Inbox
screen appears. The total number of unread messages
displays in the title bar and unread messages display in
bold. If you have labelled a message, its label appears in a
coloured rectangle on the message.
This feature may be unavailable depending on •
your region or service provider.
This Google Mail menu may be labelled dierently
•
depending on your service provider.
Send an email message
›
In Idle mode, open the application list and select
1
Google Mail.
Press [
2
]
→
Compose.
Communication
34
To add a star to the message, select • .
To view an attachment, select
• Preview. To save it to your
memory card, select Download.
To archive the message, select
• Archive.
To delete the message, select
• Delete.
To move to the previous or next message, select
•
or .
Organise email by labels
›
You can organise your email by labelling your messages
or adding stars to mark important messages. You can sort
messages by label lter.
Add a label to a message
From the Inbox screen, tap and hold a message.
1
Select
2
Change labels.
Select a label to add and select
3
OK.
Enter a name or address in the recipient eld.
3
Enter a subject and message.
4
To attach an image le, press [
5
]
→
Attach
→
a le.
Select
6
to send the message.
View email messages
›
In Idle mode, open the application list and select
1
Google Mail.
Select an email message.
2
From the message view, use the following options:
To reply to the message, select
• .
To reply to the message including all recipients, select
•
→
Reply all.
To forward the message to other people, select
•
→
Forward.
Communication
35
Enter your email address and password.
2
Select
3
Next (for general email accounts) or Manual
setup (for other company email accounts).
Follow the on-screen instructions.
4
When you are nished setting up the email account, the
email messages are downloaded to your device. If you
have created more than two accounts, you can switch
between email accounts; Press [ ]
→
Accounts and
select one you want to retrieve messages from.
Send an email message
›
1
In Idle mode, open the application list and select Email
→
an email account.
Press [
2
]
→
Compose.
Add a star to a message
From the Inbox screen, tap and hold a message.
1
Select
2
Add star. The star icon next to the message is
activated.
Filter messages
From the Inbox screen, press [
1
]
→
Go to labels.
Select the label of the messages you want to view.
2
Email
Learn to send or view email messages via your personal or
company email account.
Set up an email account
›
1
In Idle mode, open the application list and select
Email.
Communication
36
View an email message
›
When you open an email account, you can view previously
retrieved emails oine or connect to the email server to
view new messages. After retrieving email messages, you
can view them oine.
In Idle mode, open the application list and select
1
Email
→
an email account.
Press [
2
]
→
Refresh to update the message list.
Select an email message.
3
From the message view, use the following options:
To reply to the message, press [
• ]
→
Reply.
To forward the message to other people, press [
• ]
→
Forward.
To delete the message, press [
• ]
→
Delete.
To move the message to another folder, press [
• ]
→
Move to.
Select
3
Contacts.
You can enter an email address manually or select one
from the logs or contact groups by selecting another
option.
Select contacts and select
4
Done.
Select the Cc/Bcc eld and add more recipients.
5
Select the subject eld and enter a subject.
6
Select the text input eld and enter your email text.
7
Select
8
Attach and attach a le.
You can select a le from the le list or create a new
photo, video, or sound.
Select
9
Send to send the message.
If you are oine, the message will be held in the
message thread list until you are online.
Communication
37
Enter an email address of the friend and select
3
Send
invitation.
When your friend accepts the invitation, the friend is
added to your friend list.
Start a chat
›
In Idle mode, open the application list and select
1
Talk.
Select a friend from the friend list. The chat screen
2
opens.
Enter your message and select
3
Send.
To insert emoticons, press [ ]
→
More
→
Insert
smiley.
To switch between active chats, press [
4
]
→
Switch
chats.
To end the chat, press [
5
]
→
End chat.
To load images from the message, press [
• ]
→
Show
pictures.
To view an attachment, select the attachment item. To
•
save it to your memory card, select .
Talk
Learn to chat with friends and family via Google Talk™.
This feature may be unavailable depending on your
region or service provider.
Add friends to your friend list
›
In Idle mode, open the application list and select
1
Talk.
The friend list shows all of your Google Talk contacts
at a glance.
Press [
2
]
→
Add friend.
Entertainment
38
Entertainment
Camera
Learn how to capture and view photos and videos. You
can take photos at resolutions up to 2048 x 1536 pixels
(3.2 megapixels) and videos at resolutions up to 720 x 480
pixels.
The camera interface appears only in the •
landscape orientation.
Tap the screen to hide or display icons in the
•
viewnder.
The camera automatically turns o when you do
•
not use it for a specied period.
The memory capacity may dier depending on
•
the shooting scene or shooting conditions.
Capture a photo
›
1
In Idle mode, open the application list and select
Camera.
Rotate the device anti-clockwise to landscape view.
2
Aim the lens at the subject and make any necessary
3
adjustments.
7
8
9
2
3
4
5
6
1
Entertainment
39
Number Function
6
Change the camera settings.
7
Switch to the camcorder.
8
Capture a photo.
9
View the photo you captured last.
Select
4
to take a photo.
The photo is saved automatically.
After taking photos, select to view the taken photos.
To view more photos, scroll left or right.
•
To zoom in or out, tap the screen and select • or .
You can also double-tap the screen to zoom in or out.
To send a photo to others, select
• Share.
To set a photo as wallpaper or an ID image for a contact,
•
select Set as.
To delete a photo, select
• Delete.
Number Function
1
Check the camera status and settings.
• : Resolution
• : Exposure metre type
• : GPS activated
• : Number of photos you can
take (according to available memory)
• : Storage location
2
Change the ash setting; You can
manually turn the ash on or o or set
the camera to automatically use the ash
when needed.
3
Switch between the front and rear
camera lenses.
4
Change the shooting mode.
5
Adjust the exposure value; Select + to
increase or - to decrease.
Entertainment
40
Capture a photo in Smile shot mode
›
Your camera can recognise people’s faces and help you
take photos of their smiling faces.
In Idle mode, open the application list and select
1
Camera.
Rotate the device anti-clockwise to landscape view.
2
Select
3
→
Smile shot.
Make any necessary adjustments.
4
Select
5
.
Aim the camera lens at your subject.
6
Your device recognises people in an image and detects
their smiles. When the subject smiles, the device
automatically takes a photo.
Capture a photo by using preset
›
options for various scenes
Your camera provides you with predened settings for
various scenes. You can simply select the proper mode for
your shooting condition and subjects.
For example, when you take photos at night, select the
night mode that uses an extended exposure.
In Idle mode, open the application list and select
1
Camera.
Rotate the device anti-clockwise to landscape view.
2
Select
3
→
→
Scene mode
→
None
→ascene
→
.
Make any necessary adjustments.
4
Select
5
to take a photo.
Entertainment
41
Capture a panoramic photo
›
You can take wide panoramic photos using Panorama
shooting mode. This mode is convenient for
photographing landscapes.
In Idle mode, open the application list and select
1
Camera.
Rotate the device anti-clockwise to landscape view.
2
Select
3
→
Panorama.
Make any necessary adjustments.
4
Select
5
to take the rst photo.
Slowly move the device in any direction and align the
6
green frame with the viewnder.
When you have aligned the green frame and
viewnder, the camera will automatically take the next
photo.
Repeat step 6 to complete the panoramic photo.
7
Capture a series of photos
›
You can easily take a series of photos of moving subjects.
This is useful when you are photographing children at play
or a sporting event.
In Idle mode, open the application list and select
1
Camera.
Rotate the device anti-clockwise to landscape view.
2
Select
3
→
Continuous.
Make any necessary adjustments.
4
Tap and hold
5
. The camera will continue to take
photos until you release the key.
Entertainment
42
Make any necessary adjustments with the aid of the
7
guide.
Select
8
to take the second photo.
The device will automatically combine the half of the
rst photo and the other half of the second photo into
one photo.
Capture a photo of action
›
You can capture shots of a moving subject and then
combine them into a single photo that shows the action.
In Idle mode, open the application list and select
1
Camera.
Rotate the device anti-clockwise to landscape view.
2
Select
3
→
Action shot.
Make any necessary adjustments.
4
Select
5
to capture the rst photo.
Capture a combined photo
›
You can take two photos with the same background and
then combine the left and right halves of each photo into
one photo. This feature is helpful when you want to take
a photo with a friend but there is no one available to take
the photo for you.
In Idle mode, open the application list and select
1
Camera.
Rotate the device anti-clockwise to landscape view.
2
Select
3
→
Add me.
Make any necessary adjustments.
4
Tap the left or right side you want to take a photo rst.
5
Select
6
to take the rst photo.
The half of the rst photo appears as a transparent
guide for the next photo.
Entertainment
43
Customise camera settings
›
Before taking a photo, select
→
to access the
following options:
Option Function
Outdoor
visibility
Activate Outdoor visibility to select
an appropriate lighting condition.
Macro Activate Macro mode to take close-
up photos.
Scene mode Change the scene mode.
Timer Select the length of the delay before
the camera takes a photo.
Resolution Change the resolution option.
White balance Adjust the colour balance according
to lighting conditions.
Eects Apply a special eect, such as sepia
or black and white tones.
Move the device to follow the moving subject.
6
The device automatically captures the next photos.
Continue to follow the subject until the device has
7
captured all the shots necessary for the action photo.
Capture a photo in Self shot mode
›
You can take photos of yourself conveniently using the
front camera lens.
In Idle mode, open the application list and select
1
Camera.
Rotate the device anti-clockwise to landscape view.
2
Select
3
.
Make any necessary adjustments.
4
Select
5
to take a photo
Entertainment
44
Setting Function
Shutter sound Set the camera shutter to make a
sound when capturing a photo.
Storage Select a memory location for storing
captured photos.
Reset Reset menus and shooting options.
Record a video
›
1
In Idle mode, open the application list and select
Camera.
Rotate the device anti-clockwise to landscape view.
2
Select
3
to switch to the camcorder.
Option Function
ISO Adjust the sensitivity of the camera
imaging sensor.
Metering Select a type of exposure metre.
Image quality Set the quality level for your photos.
Adjust Adjust contrast, saturation, and
sharpness.
Before taking a photo, select
→
to access the
following settings:
Setting Function
Guidelines Display the guidelines on the
preview screen.
Review Set the camera to display the taken
image.
Entertainment
45
Number Function
2
Turn the ash on or o.
3
Adjust the exposure value.
4
Select the length of the delay before the
camera starts recording a video.
5
Change the resolution option.
6
Change the camcorder settings.
7
Switch to the camera.
8
Record a video.
9
View the video you recorded last.
Select
5
to start recording.
Select
6
to stop recording.
The video is saved automatically.
The camera may not be able to properly record
videos to a memory card with a slow transfer speed.
Aim the lens at the subject and make any necessary
4
adjustments.
7
8
9
3
2
4
5
6
1
Number Function
1
Check the camcorder status and
settings.
• : Length of video that can
be recorded (according to available
memory)
• : Storage location
Entertainment
46
Option Function
Video quality Set the quality level for your videos.
Adjust Adjust contrast, saturation, and
sharpness.
Before recording a video, select
→
to access the
following settings:
Setting Function
Guidelines Display the guidelines on the
preview screen.
Audio recording Turn the audio on or o.
Review Set the camera to display the
recorded video.
Storage Select a memory location for storing
recorded videos.
Reset Reset menus and shooting options.
After recording videos, select to view the recorded
videos.
To view more videos, scroll left or right.
•
To send a video to others, select • Share.
To play a video, select
• Play.
To delete a video, select
• Delete.
Customise camcorder settings
›
Before recording a video, select
→
to access the
following options:
Option Function
Outdoor
visibility
Activate Outdoor visibility to select
an appropriate lighting condition.
White balance Adjust the colour balance according
to lighting conditions.
Eects Apply a special eect, such as sepia
or black and white tones.
Entertainment
47
Control playback with the following icons:
4
Icon Function
Change a ratio of the video screen.
Adjust the display brightness.
Skip backward; Scan backward in a le
(tap and hold).
Pause playback; Select to resume
playback.
Skip forward; Scan forward in a le (tap
and hold).
Adjust the volume.
Stop playback and return to the playlist.
Video
Learn to use the video player to play various kinds of
videos. The video player supports the following le
formats: 3gp, mp4, avi, wmv/asf, v, mkv (Video Codec:
MPEG-4, H.263, Sorenson Spark, H.264, VC-1, WMV 7/8,
DivX/XviD; Audio Codec: MP3, AC3, AAC, WMA).
Some le formats are not supported depending •
on the software of the device.
If the le size exceeds the available memory, an
•
error can occur when you open les.
In Idle mode, open the application list and select
1
Video.
Select a video to play.
2
Rotate the device anti-clockwise to landscape view.
3
Entertainment
48
View a photo
›
1
In Idle mode, open the application list and select
Gallery.
Select a folder.
2
To change the view mode, select
3
or at the top
right of the screen.
Select a photo (with no icon) to view.
4
While viewing a photo, use the following options:
To view more photos, scroll left or right.
•
To zoom in or out, select • or . You can also tap the
screen with two ngers and spread them apart (move
your ngers closer together to zoom out).
To start a slideshow in the selected folder, select
•
Slideshow. Tap the screen to stop the slideshow.
To send a photo to others, select
• Menu
→
Share
→
an
option.
Gallery
Learn to view photos and play videos saved on your
memory card.
Supported le formats
›
Type Format
Image Extension: bmp, gif, jpg, png
Video
Extension: 3gp, mp4, avi, wmv/asf,
•
v, mkv
Video Codec: MPEG-4, H.263,
•
Sorenson Spark, H.264, VC-1 (WMV9),
WMV 7/8, DivX/XviD
Audio Codec: MP3, AC3, AAC, WMA
•
Some le formats are not supported depending •
on the software of the device.
If the le size exceeds the available memory, an
•
error can occur when you open les.
Entertainment
49
Share images or videos
›
In Idle mode, open the application list and select
1
Gallery.
Select a folder.
2
Select an image or video le.
3
Press [
4
]
→
Share or Share video
→
a sharing option.
Music
Learn to listen to your favourite music while on the go with
the music player. The music player supports the following
le formats: mp3, ogg, aac, wma, wav, ac.
To delete a photo, select
• Menu
→
Delete.
To use additional features, select
• Menu
→
More and
select one of the following options:
Details
- : View photo details.
Set as
- : Set a photo as wallpaper or a caller image for
a contact.
Crop
- : Crop an image from a photo.
Rotate left
- : Rotate a photo anti-clockwise.
Rotate right
- : Rotate a photo clockwise.
Play a video
›
1
In Idle mode, open the application list and select
Gallery.
Select a video (with the
2
icon) to play.
Rotate the device anti-clockwise to landscape view.
3
Control playback with the virtual keys.
4
Entertainment
50
Play music
›
After transferring music les to your device or memory
card,
In Idle mode, open the application list and select
1
Music.
Select a music category
2
→
a music le.
Control playback with the following keys:
3
Icon Function
Select a sound eect.
Adjust the volume.
Activate Shue mode.
Select a section you want to repeat.
Change the repeat mode (o, repeating
all les, or repeating a le).
1
1
1
Some le formats are not supported depending •
on the software of the device.
If the le size exceeds the available memory, an
•
error can occur when you open les.
Add music les to your memory card
›
Start by transferring les to your memory card:
Download from the wireless web.
• ► p. 61
Download from a PC with the optional Samsung Kies.
•
► p. 77
Receive via Bluetooth.
• ► p. 72
Copy to your memory card.
• ► p. 78
Entertainment
51
Create a playlist
›
In Idle mode, open the application list and select
1
Music.
Select a category
2
→
a music le.
Press [
3
]
→
Add to playlist
→
Create playlist.
Enter a title for your new playlist and select
4
Save.
To add more music les to the playlist, play a le and
5
press [ ]
→
Add to playlist
→
the new playlist.
Customise music player settings
›
In Idle mode, open the application list and select
1
Music.
Press [
2
]
→
Settings.
Icon Function
Skip backwards; Scan backward in a le
(tap and hold).
Pause playback; Select to resume
playback.
Skip forward; Scan forward in a le (tap
and hold).
1. These icons are shown when you tap the player screen.
You can control playback with a headset: Press the
headset button to play or pause playback. You can
also press and hold the headset button to launch
the music player.
Entertainment
52
Adjust the following settings to customise your music
3
player:
Option Function
SoundAlive Select a sound eect.
Play speed Set the playback speed of a music
le.
Master EQ Set the master equaliser.
Music menu Select music categories to display
on the music library screen.
Music play
screen
Select a visualisation to be
displayed during playback.
FM radio
Learn to listen to music and news on the FM radio. To listen
to the FM radio, you must connect a headset, which serves
as the radio antenna.
Listen to the FM radio
›
Plug a headset into the device.
1
In Idle mode, open the application list and select
2
FM
radio.
Select your region
3
→
Yes.
The FM radio scans and saves available stations
automatically.
The rst time you turn on the FM radio, you will be
prompted to start automatic tuning.
Select the radio station you want from the all station
4
list.
Entertainment
53
Number Function
4
Add the current radio station to the
favourites list.
5
Turn o or on the FM radio.
6
Open the list of saved radio stations.
Save a radio station automatically
›
Plug a headset into the device.
1
In Idle mode, open the application list and select
2
FM
radio.
Press [
3
]
→
Scan
→
Scan.
The FM radio scans and saves available stations
automatically.
Control the FM radio with the following keys:
5
3
5
6
1
4
3
2
Number Function
1
Change the sound output (headset or
device's speaker).
2
Fine-tune the frequency.
3
Search for an available radio station.
Entertainment
54
Add a radio station to the favourites list
›
Plug a headset into the device.
1
In Idle mode, open the application list and select
2
FM
radio.
Scroll to the radio station you want.
3
Select + to add to the favourites list.
4
Personal information
55
Personal information
Contacts
Learn to create and manage a list of your personal or
business contacts. You can save names, mobile phone
numbers, home phone numbers, email addresses,
birthdays and more for your contacts.
›
Create a contact
In Idle mode, open the application list and select
1
Contacts.
Select
2
.
Select a memory location.
3
If you have more than one account, select an account
to which you want to add the contact.
Enter contact information.
4
To add a new item, select . To delete an item,
select .
Select
5
Save to add the contact to memory.
Find a contact
›
1
In Idle mode, open the application list and select
Contacts.
Scroll up or down on the contact list.
2
Select a contact’s name.
3
Once you nd a contact, you can:
send an email message by selecting an email address.
•
edit the contact information by pressing [• ]
→
Edit.
Personal information
56
In Idle mode, open the application list and select
1
Contacts.
Press [
2
]
→
Get friends.
Select an account.
3
Create a group of contacts
›
By creating groups of contacts, you can manage multiple
contacts and send email to an entire group. Start by
creating a group.
In Idle mode, open the application list and select
1
Contacts
→
Groups.
Press [
2
]
→
Create.
Enter a name.
3
Select
4
Save.
Create your namecard
›
In Idle mode, open the application list and select
1
Contacts.
Press [
2
]
→
My prole.
Enter your own personal details.
3
Select
4
Save.
You can send your namecard by attaching it to an
email or transferring it via the Bluetooth wireless
feature.
Retrieve contacts from your community
›
accounts
You can view the list of community website accounts and
select an account to add a contact from the website to
your device contacts.
Personal information
57
To export contacts from your device to a memory card,
In Idle mode, open the application list and select
1
Contacts.
Press [
2
]
→
Import/Export
→
Export to Internal
Memory.
Select
3
OK to conrm.
View social network activities
›
You can view the recent activities of contacts in social
network services, such as Facebook, MySpace, and Twitter.
In Idle mode, open the application list and select Contacts
→
Activities.
Import or export contacts
›
To import contact les (in vcf format) from a memory card
to your device,
In Idle mode, open the application list and select
1
Contacts.
Press [
2
]
→
Import/Export
→
Import from Internal
Memory.
Select a memory location.
3
If you have more than one account, select an account
to which you want to add the contact.
Select an option for importing a single contact le,
4
multiple contact les, or all contact les, and select OK.
Select contact les to import and select
5
OK.
Personal information
58
View events
›
To change the calendar view,
In Idle mode, open the application list and select
1
Calendar.
Select a view mode from the top of the calendar.
2
To view events of a specic date,
In Idle mode, open the application list and select
1
Calendar.
Select a date on the calendar. In month view, days with
2
scheduled events are indicated by a small triangle.
To move to a specic day by entering a date manually,
press [ ]
→
Go to, enter the date by selecting + or -,
and select Set.
To select today's date, press [ ]
→
Today.
Calendar
Learn to create and manage daily, weekly or monthly
events, and set alarms to remind yourself of important
events.
To use the calendar application, you need to sign in
to your Google account.
Create an event
›
In Idle mode, open the application list and select
1
Calendar.
Press [
2
]
→
Create.
Enter the details of the event as required.
3
Select
4
Save.
Personal information
59
Memo
Learn to record important information to save and view at
a later date.
Create a memo
›
In Idle mode, open the application list and select
1
Memo.
Select
2
Create memo or press [ ]
→
Create.
Enter your memo text.
3
Press [
4
] to hide the keypad.
Select a colour to change a background colour.
5
Select
6
Save.
Select an event to view its details.
3
You can send the event to others by pressing [ ]
→
Send via
→
an option.
Stop an event alarm
›
If you set an alarm for a calendar event, the event alarm
icon will appear at the specied time.
Open the shortcuts panel from the top of the screen.
1
Select a reminder to view more details about the
2
event.
To snooze or dismiss the reminder, select
3
Snooze all
or Dismiss all.
Personal information
60
Speak into the microphone.
3
When you are nished recording a memo, select
4
Stop.
Your memo is saved automatically.
To record more voice memos, select
5
Record from the
bottom of the screen.
Play a voice memo
›
In Idle mode, open the application list and select
1
Voice
Recorder.
Select
2
List.
Select a voice memo to play.
3
You can send the voice memo to others by pressing
[]
→
Share.
View memos
›
In Idle mode, open the application list and select
1
Memo.
Select a memo to view its details.
2
You can send the memo to others by tapping and
holding the memo and selecting Send via
→
an
option.
Voice Recorder
Learn to operate your device's voice recorder.
Record a voice memo
›
In Idle mode, open the application list and select
1
Voice
Recorder.
Select
2
Record to start recording.
Web
61
Web
Web services require a data connection. Contact your
operator to choose the best data plan.
Internet
Learn to access and bookmark your favourite web pages.
The web browser menu may be labelled •
dierently depending on your service provider.
Available icons may vary depending on your
•
region or service provider.
›
Browse web pages
In Idle mode, open the application list and select
1
Internet to launch a specied homepage.
To access a specic web page, select the URL input
eld, enter the web address of the web page, and
select .
Navigate web pages with the following keys:
2
2
1
Web
62
To adjust the brightness of the screen, press [• ]
→
Brightness setting. This feature may be unavailable
depending on your region.
To reload the current web page, press [
• ]
→
Refresh.
To go to the next page in history, press [
• ]
→
Forward.
To bookmark the current web page, press [
• ]
→
More
→
Add bookmark.
To add a shortcut to the current web page to the idle
•
screen, press [ ]
→
More
→
Add shortcut to Home.
To add the RSS feed, press [
• ]
→
More
→
Add RSS
feeds.
To search for text on the web page, press [
• ]
→
More
→
Find on page.
To view web page details, press [
• ]
→
More
→
Page
info.
To send the web address of the web page to others,
•
press [ ]
→
More
→
Share page.
Number Function
1
Enter the web address of a web page
to access.
2
Open a list of saved bookmarks,
frequently visited pages and recent
internet history.
The screen may dier depending on your region or
service provider.
While browsing the web page, use the following options:
To zoom in or out, double-tap the screen. You can also
•
use the two nger zoom; Place your two ngers on the
screen and slowly pinch or spread apart.
To open a new window, press [
• ]
→
New window.
To view the currently active windows, press [
• ]
→
Windows. You can open multiple pages and switch back
and forth between them.
Web
63
From the bookmark list, tap and hold a bookmark and use
the following options:
To open the web page in the current window, select
•
Open.
To open the web page in a new window, select
• Open in
new window.
To edit the bookmark details, select
• Edit bookmark.
To add the bookmark shortcut to the idle screen, select
•
Add shortcut to Home.
To send the web address of the web page to others,
•
select Share link.
To copy the web address of the web page, select
• Copy
link URL.
To delete the bookmark, select
• Delete bookmark.
To use the web page as your homepage of the browser,
•
select Set as homepage.
To view the download history, press [
• ]
→
More
→
Downloads.
To customise browser settings, press [
• ]
→
More
→
Settings.
Bookmark your favourite web pages
›
If you know the web address of a web page, you can
manually add a bookmark. To add a bookmark,
In Idle mode, open the application list and select
1
Internet.
Select
2
→
Bookmarks.
Select
3
Add or press [ ]
→
Bookmark last-viewed
page.
Enter a page title and a web address.
4
Select
5
OK.
Web
64
between buildings, in tunnels or underground passages, •
or inside buildings
in poor weather
•
around high voltage or electromagnetic elds•
Do not touch the internal antenna area or cover this
area with your hands or other objects while using
the GPS functions.
This feature may be unavailable depending on •
your region or service provider.
Before using location services, ensure that the
•
wireless connection is active.
Activate location services to use with
›
Google Maps
You must activate location services to nd your location
and search the map.
Access the frequently visited pages or
›
the recent history
In Idle mode, open the application list and select
1
Internet.
Select
2
→
Most visited or History.
Select a web page to access.
3
You can add a web page to the bookmark list by
selecting the star icon on the right.
Maps
Learn to use Google Maps™ to nd your location, search
the map for streets, cities, or countries, and get directions.
To receive better GPS signals, avoid using your device in
the following conditions:
Web
65
Search for a specic location
›
In Idle mode, open the application list and select
1
Maps.
The map will display your current location.
If you are launching this application for the rst time,
2
select OK to conrm.
Press [
3
]
→
Search or select .
Enter a keyword for the location and select
4
.
To search for a place around you, select
• .
To zoom in or out, select
• or .
To add layers to the map, select
• .
To view your current location, select
• .
To add a star to the location, select the balloon of
the location name
→
.
In Idle mode, open the application list and select
1
Settings
→
Location and security.
Adjust the following settings to activate location
2
services:
Option Function
Use wireless
networks
Set to use WLAN and/or mobile
networks for nding your
location.
Use GPS
satellites
Set to use the GPS satellite for
nding your location.
Use sensor
aiding
Use sensors to enhance
pedestrian positioning when
the GPS signal is obstructed.
There may be variations
between the sensor estimates
and your actual location.
Web
66
Latitude
Learn to share your location with your friends and view
friends’ locations via Google Latitude™.
This feature may be unavailable depending on •
your region or service provider.
Before using location services, ensure that the
•
wireless connection is active.
In Idle mode, open the application list and select
1
Latitude.
The device automatically joins Latitude.
Press [
2
]
→
Add friends
→
Select from Contacts or
Add via email address.
Select friends you want to add or enter an email
3
address, and select Add friends
→
Yes .
When your friend accepts your invitation, you can
share locations.
Get directions to a specic destination
›
In Idle mode, open the application list and select
1
Maps.
Press [
2
]
→
Directions.
Enter the addresses of the starting location and the
3
ending location.
To enter an address from your contact list or point the
location on the map, select
→
Contacts or Point
on map.
Select a travel method (car, bus, or walk) and select
4
Go.
Select a travel route to view details of your trip (if
5
necessary).
Select
6
Show on map.
When you are nished, press [
7
]
→
Clear Map.
Web
67
Select a place name to view its details.
3
To view the place on the map, select .
Navigation
Learn to use the GPS navigation system to nd and show
your destination with voice guidance.
This feature may be unavailable depending on •
your region or service provider.
Before using location services, ensure that the
•
wireless connection is active.
In Idle mode, open the application list and select
1
Navigation.
If you are launching this application for the rst time,
2
select Accept.
Press [
4
]
→
See map.
Your friends' locations are marked with their photos
on the map.
Places
Learn to search for a place around you.
This feature may be unavailable depending on •
your region or service provider.
Before using location services, ensure that the
•
wireless connection is active.
In Idle mode, open the application list and select
1
Places.
Select a category.
2
Your device searches for places around your current
location that are related to the category.
Web
68
Google Search
You can search for applications in your device and specic
data on the web.
In Idle mode, open the application list and select
1
Google Search.
Enter a letter or a word of the data to search.
2
Select the item's name you want to access.
3
YouTube
Learn to view and upload videos via YouTube.
This feature may be unavailable depending on your
region or service provider.
Enter your destination by using one of the following
3
methods:
Speak Destination
• : Speak your destination such as
"Navigate to
destination
."
Type Destination
• : Enter your destination with the
virtual keypad.
Contacts
• : Select your destination from addresses of
your contacts.
Starred Places
• : Select your destination from the list
of your starred places.
Select
4
Install to use voice-guided navigation.
To end the navigation, press [
5
]
→
Exit Navigation.
Web
69
Watch videos
›
In Idle mode, open the application list and select
1
YouTube.
Select
2
Accept to conrm, if you are launching this
application for the rst time.
Select a video from the list.
3
Rotate the device anti-clockwise to landscape view.
4
Control playback with the following keys:
5
2
1
Number Function
1
Move to a point of the le by dragging
the bar.
2
Change the quality of the display.
Upload videos
›
In Idle mode, open the application list and select
1
YouTube.
Press [
2
]
→
Upload and select a video. Skip to 8.
If you want to upload new videos, select to turn on
the camera.
Rotate the device anti-clockwise to landscape view.
3
Aim the lens at the subject and make any adjustments.
4
Select
5
to start recording.
Web
70
Select
6
to stop recording.
Select
7
Save to upload the video that you have
recorded.
Enter your user name and password and select
8
Sign in.
Samsung Apps
Samsung Apps allows you to simply and easily download
an abundance of applications directly to your device.
Featuring a wealth of games, news, reference, social
networking, navigation, health related applications and
more, Samsung Apps gives you instant access to a huge
choice of mobile experience.
Your device gets smarter with fully optimised applications
from Samsung Apps. Explore amazing applications and
make your mobile life even better.
The feature may be unavailable depending on •
your region or service provider.
For details, please visit www.samsungapps.com.
•
In Idle mode, open the application list and select
1
Samsung Apps.
Search for and download applications as desired.
2
Market
You can download games or other applications from the
Android Market.
This feature may be unavailable depending on your
region or service provider.
In Idle mode, open the application list and select
1
Market.
Search for a le and download it to the device.
2
►p. 30
Connectivity
71
Connectivity
Bluetooth
Bluetooth is a short-range wireless communications
technology capable of exchanging information over
a distance of about 10 m without requiring a physical
connection.
You do not need to line up the devices to beam
information with Bluetooth. If the devices are within range
of one another, you can exchange information between
them even if they are located in dierent rooms.
Samsung is not responsible for the loss, •
interception, or misuse of data sent or received via
the Bluetooth wireless feature.
Always ensure that you share and receive data
•
with devices that are trusted and properly secured.
If there are obstacles between the devices, the
operating distance may be reduced.
Some devices, especially those that are not
•
tested or approved by Bluetooth SIG, may be
incompatible with your device.
›
Turn on the Bluetooth wireless feature
In Idle mode, open the application list and select
1
Settings
→
Wireless and network
→
Bluetooth
settings.
Select
2
Bluetooth to turn on the Bluetooth wireless
feature.
Connectivity
72
Send data using the Bluetooth wireless
›
feature
Select a le or item, such as a contact, memo, or media
1
le, from an appropriate application or My Files.
Press [
2
]
→
Share, Send via, or Send namecard via
→
Bluetooth.
Search for and pair with a Bluetooth-enabled device.
3
›
Receive data using the Bluetooth
wireless feature
In Idle mode, open the application list and select
1
Settings
→
Wireless and network
→
Bluetooth
settings
→
Visible.
Your device is visible to other Bluetooth devices for
120 seconds.
Find and pair with other Bluetooth-
›
enabled devices
In Idle mode, open the application list and select
1
Settings
→
Wireless and network
→
Bluetooth
settings
→
Scan devices.
Select a device.
2
Enter a PIN for the Bluetooth wireless feature or the
3
other device’s Bluetooth PIN, if it has one, and select
OK. Alternatively, select Accept to match the PIN
between your device and the device.
When the owner of the other device enters the same
PIN or accepts the connection, pairing is complete. If
the pairing is successful, the device will automatically
search for available services.
Some devices, especially headsets or hands-free car
kits, may have a xed Bluetooth PIN, such as 0000. If
the other device has a PIN, you must enter it.
Connectivity
73
›
Activate the WLAN feature
In Idle mode, open the application list and select Settings
→
Wireless and network
→
Wi-Fi settings
→
Wi-Fi.
An active WLAN running in the background will
consume battery power. To preserve battery power,
activate the WLAN only when needed.
Find and connect to a WLAN
›
In Idle mode, open the application list and select
1
Settings
→
Wireless and network
→
Wi-Fi settings.
The device will automatically search for available
WLANs.
Select a network under
2
Wi-Fi networks.
Enter a password for the network (if necessary).
3
Select
4
Connect.
When prompted, enter the PIN for the Bluetooth
2
wireless feature and select OK (if necessary).
Select
3
Accept to conrm that you are willing to receive
data from the device (if necessary).
Received data is saved to the bluetooth folder.
Wi-Fi
Learn to use your device’s wireless networking capabilities
to activate and connect to any wireless local area network
(WLAN) compatible with the IEEE 802.11 b/g/n standards.
You can connect to the internet or other network devices
anywhere an access point or wireless hotspot is available.
Your device uses non-harmonised frequency and
is intended for use in all European countries. The
WLAN can be operated in the EU without restriction
indoors, but cannot be operated outdoors in France.
Connectivity
74
In Idle mode, open the application list and select
1
Settings
→
Wireless and network
→
Wi-Fi settings.
Select
2
WPS button connection.
Press a WPS button on the access point within 2
3
minutes.
To connect to a WLAN with a WPS PIN,
In Idle mode, open the application list and select
1
Settings
→
Wireless and network
→
Wi-Fi settings.
Select a network indicated by the WPS icon and select
2
WPS PIN.
On the access point, enter the PIN and press the start
3
button.
Add a WLAN manually
›
In Idle mode, open the application list and select
1
Settings
→
Wireless and network
→
Wi-Fi settings
→
Add Wi-Fi network.
Enter the SSID for the network and select the security
2
type.
Set the security settings depending on the selected
3
security type.
Select
4
Save.
Connect to a WLAN using a Wi-Fi
›
Protected Setup (WPS)
Using WPS, you can connect to a secured network.
To connect to a WLAN with a WPS button,
Connectivity
75
Adjust the following settings to customise the DLNA
3
feature:
Option Function
Media server
name
Enter a name for your device as
a media server.
Share media
Turn on video sharing, image
sharing or music sharing with
other DLNA-enabled devices.
Access point
network
Select a connection prole to
use for DLNA connections.
Upload from
other devices
Set whether or not to accept the
upload from other devices.
Default memory
Select the default memory
location for saving downloaded
media les.
AllShare
Learn to use the Digital Living Network Alliance (DLNA)
service that enables you to share media les between
DLNA-enabled devices in your home over a WLAN.
You must rst activate the WLAN feature and add a WLAN
prole. ► p. 73
Customise DLNA settings for sharing
›
media les
To allow other DLNA-enabled devices to access media les
on your device, you must activate media sharing.
Some les may not play on the DLNA-enabled
devices depending on the devices.
In Idle mode, open the application list and select
1
AllShare.
Select
2
Settings.
Connectivity
76
Play others’ les on your device
›
In Idle mode, open the application list and select
1
AllShare.
Select
2
Play le from server on my device.
Your device automatically searches for DLNA-enabled
devices.
Select a device as the media server—the one that
3
contains media les.
Select a media category and a le.
4
Select
5
Add to playlist.
Control playback using icons of your device.
6
Play your les on another DLNA-
›
enabled device
In Idle mode, open the application list and select
1
AllShare.
Select
2
Play le from my device on another player.
Select a media category
3
→
a le.
Select
4
Add to playlist.
Select a player—the one that will play the media le.
5
Playback begins at the selected player.
Control playback using icons of your device.
6
Playback may be buered, depending on the
network connection and the connected server.
Connectivity
77
PC connections
Learn to connect your device to a PC with a PC data cable
in various USB connection modes. By connecting the
device to a PC, you can transfer data to and from your
device directly and use the Samsung Kies program.
›
Connect with Samsung Kies
Ensure that Samsung Kies is installed on your PC. You can
download the program from the Samsung website
(www.samsung.com/kies).
Using a PC data cable, connect the multifunction jack
1
on your device to a PC.
Samsung Kies will launch automatically.
If Samsung Kies does not automatically launch,
double-click the Samsung Kies icon on your PC.
Copy les from the PC to the device.
2
Refer to the Samsung Kies help for more information.
Play les of one device on the other
›
device
In Idle mode, open the application list and select
1
AllShare.
Select
2
Play le from server on another player via
my device.
Your device automatically searches for DLNA-enabled
devices.
Select a device as the media server—the one that
3
contains media les.
Select a media category and a le.
4
Select
5
Add to playlist.
Select a player—the one that will play the media le.
6
Playback begins at the selected player.
Control playback using icons of your device.
7
Connectivity
78
When you are nished, select
6
Turn O.
To disconnect the device from the PC, click the
USB device icon on the Windows task bar and
click the option to safely remove the mass storage
device. Then remove the PC data cable from the PC.
Otherwise, you may lose data stored on the memory
card or damage the memory card.
VPN connections
You can create virtual private networks (VPN) and connect
to your private network securely through a public network,
such as the internet.
Your device should already be congured with
internet access. If you have trouble accessing the
internet, you need to edit connections. If you are not
sure about the connection information to enter, ask
your service provider.
›
Connect as a mass storage device
You can connect your device to a PC as a removable disk
and access the le directory. If you insert a memory card
in the device, you can also access the le directory of the
memory card by using the device as a memory card reader.
The le directory of the memory card will appear
as a removable disk, separate from the internal
memory.
If you want to transfer les from or to a memory card,
1
insert a memory card into the device.
Using a PC data cable, connect the multifunction jack
2
on your device to a PC.
When connected, select
3
Connect USB storage.
Open the folder to view les.
4
Copy les from the PC to the device or memory card.
5
Connectivity
79
Option Function
Enable L2TP
secret
Set to use the L2TP secret
password.
Set L2TP secret Enter the L2TP secret password.
Set user
certicate
Select a user certicate that the
VPN server uses to identify you.
You can import certicates from
the VPN server or download from
the web.
Set CA
certicate
Select a certicate authority (CA)
certicate that the VPN server uses
to identify you. You can import
certicates from the VPN server or
download from the web.
DNS search
domains
Enter the domain name server
(DNS) address.
Press [
4
]
→
Save.
Set up VPN connections
›
In Idle mode, open the application list and select
1
Settings
→
Wireless and network
→
VPN settings
→
Add VPN.
Select a VPN type.
2
Customise the connection information.
3
Available options may vary depending on the VPN
type.
Option Function
VPN name Enter a name of the VPN server.
Set VPN server Enter the IP address of the VPN
server.
Enable
Encryption Set to encrypt the VPN server.
Set IPsec pre-
shared key Enter a pre-shared key.
Connectivity
80
Connect to a private network
›
In Idle mode, open the application list and select
1
Settings
→
Wireless and network
→
VPN settings.
Select a private network to connect.
2
Enter the user name and password and select
3
Connect.
Tools
81
Tools
Alarm/Clock
Learn to set and control alarms, and world clocks. You can
also use the stopwatch and count-down timer.
Set a new alarm
›
In Idle mode, open the application list and select
1
Alarm/Clock
→
Alarm.
Select
2
Create alarm or press [ ]
→
Create.
Set alarm details.
3
When you are nished, select
4
Save.
Stop an alarm
›
When the alarm sounds,
To stop the alarm, drag
• right until it reaches the dot.
To repeat the alarm after a specied length of time, drag
•
left until it reaches the dot.
Delete an alarm
›
In Idle mode, open the application list and select
1
Alarm/Clock
→
Alarm.
Press [
2
]
→
Delete.
Select alarms to delete.
3
Select
4
Delete.
Tools
82
Select
3
Lap to record lap times.
When you are nished, select
4
Stop.
Select
5
Reset to clear recorded times.
Use the count-down timer
›
In Idle mode, open the application list and select
1
Alarm/Clock
→
Timer.
Set the length of time to count down.
2
Select
3
Start to begin the countdown.
You can now use other functions with the timer
counting down in the background. Press the Home key
or [ ] and access another application.
When the timer expires, drag
4
right until it reaches
the dot.
Create a world clock
›
In Idle mode, open the application list and select
1
Alarm/Clock
→
World clock.
Select
2
Add city or press [ ]
→
Add.
Enter a city name or select one from the city list.
3
To select a city in the world map view, select .
To add more world clocks, repeat steps 2-3.
4
To apply the summer time to the clocks, tap and
hold a clock and select DST settings.
Use the stopwatch
›
In Idle mode, open the application list and select
1
Alarm/Clock
→
Stopwatch.
Select
2
Start to begin the stopwatch.
Tools
83
View the calculation history
›
In Idle mode, open the application list and select
1
Calculator.
Perform the calculation.
2
Select
3
to close the calculator keypad.
The calculation history appears.
To clear the history, press [
4
]
→
Clear history.
Mini Diary
Learn to keep a photo diary.
Calculator
Learn to perform mathematical calculations directly on
your device like a typical hand-held or desktop calculator.
Perform the calculation
›
In Idle mode, open the application list and select
1
Calculator.
Use the keys that correspond to the calculator display
2
to perform basic mathematical operations.
Rotate the device anti-clockwise to landscape view
to use the scientic calculator. If you deactivate the
auto rotation, press [ ]
→
Scientic calculator.
Tools
84
View a Mini diary
›
In Idle mode, open the application list and select
1
Mini
Diary.
Select a diary.
2
To upload a mini diary to your community website,
press [ ]
→
Publish.
My Files
Learn to quickly and easily access all of your images,
videos, music, sound clips, and other types of les stored in
your device and memory card.
In Idle mode, open the application list and select
1
My
Files.
Create a Mini diary
›
In Idle mode, open the application list and select
1
Mini
Diary.
If there is a diary saved, select
2
Create diary to create
a new entry.
Change the today’s date and set the weather (if
3
necessary).
Select
4
Tap to add photo and add an image or capture
a photo.
Select
5
Tap to create memo, enter text, and select
Done.
Select
6
Save.
Tools
85
Task manager
With the task manager, you can view currently running
applications, package size of applications, and memory
information, and monitor the RAM memory.
In Idle mode, open the application list and select
1
Task
manager.
Use the following options:
2
Active applications• : View the list of all the
applications currently running on your device.
Downloaded
• : View the total amount of memory
used for applications installed on your device.
RAM
• : Check and manage the RAM memory for your
device.
Storage
• : View the used and available memory on
your device and memory card.
Help
• : View help information about extending
battery life.
Select a folder.
2
To move up one level in the le directory, select • Up.
To return to the Home directory, select
• Home.
Select a le to open.
3
In a folder, press [ ] to use the following options:
To send a le to others via email or the Bluetooth
•
wireless feature, select Share.
To create a new folder, select
• Create folder.
To delete les or folders, select
• Delete.
To change the view mode, select
• View by.
To sort les or folders, select
• List by.
To use additional features using a le, such as moving,
•
copying or renaming option, select More.
Tools
86
Enter a name for the document and select
6
OK.
Enter contents in the document by using the tools at
7
the bottom of the screen.
When you are nished editing, select
8
on the toolbar
or press [ ]
→
File
→
Save.
View and edit a document on your
›
device
In Idle mode, open the application list and select
1
ThinkFree Oce.
Select
2
My Docs
→
a document.
View and edit the document as desired.
3
To zoom in or out, use the two nger zoom; Place •
your two ngers on the screen and slowly pinch or
spread apart.
ThinkFree Oce
Learn to create and view document les on your device. If
you have an account with the ThinkFree web service, you
can manage documents online. This application supports
the following le formats: txt, doc, docx, xls, xlsx, ppt, pptx,
pdf.
Create a new document
›
In Idle mode, open the application list and select
1
ThinkFree Oce.
Select
2
Accept to conrm, if you are launching this
application for the rst time.
Select
3
Activate now
→
Close to activate ThinkFree
Oce.
Select
4
My Docs.
Press [
5
]
→
New
→
a document type.
Tools
87
Voice Search
Learn to use the voice command feature to search for
locations and information by voice.
This feature may be unavailable depending on your
region or service provider.
In Idle mode, open the application list and select
1
Voice
Search.
Select
2
Speak now.
Say a command into the microphone.
3
To watch the video tutorial, select Watch a video
from the help screen.
To open the toolbar to edit the document (word,
•
text, or excel le), press [ ]
→
Edit.
To search for text in the document, press [
• ]
→
Find.
When you are nished editing, save the document.
4
Manage documents online
›
In Idle mode, open the application list and select
1
ThinkFree Oce.
Select
2
Online.
Enter your user name and password to access your
3
account, and then select Sign in.
View and manage your documents on the server as
4
desired.
Settings
88
Settings
Access the Settings menu
In Idle mode, open the application list and select
1
Settings.
Select a setting category and select an option.
2
Wireless and network
Change the settings for wireless network connections.
Flight mode
›
Disable all wireless functions on your device. You can use
only non-network services.
Wi-Fi settings
›
Wi-Fi• : Turn the WLAN feature on or o. ► p. 73
Network notication
• : Set the device to notify you when
an open network is available.
WPS button connection
• : Connect to a WLAN using a
Wi-Fi Protected Setup (WPS) button.
Add Wi-Fi network
• : Add WLAN APs manually.
Bluetooth settings
›
Bluetooth• : Turn the Bluetooth wireless feature on or o.
► p. 71
Device name
• : Set a Bluetooth name for your device.
Visible
• : Set your device to be visible to other Bluetooth
devices.
Scan devices
• : Search for available Bluetooth devices.
Settings
89
Audible selection• : Set the device to sound when you
select an application or option.
Screen lock sounds
• : Set the device to sound when you
lock or unlock the touch screen.
Display
Change the settings for the display.
Font style
• : Change the font type for the display text. You
can download fonts from Android Market by selecting
Get fonts online.
Brightness
• : Set the brightness of the display.
VPN settings
›
Set up and connect to virtual private networks (VPNs).
► p. 78
Sound
Change the settings for various sounds on your device.
Silent mode
• : Activate the silent mode to mute all
sounds except media sounds and alarm ringtones.
Level optimizer
• : Set the volume of media les to even
level.
Vibrate
• : Set when the device will vibrate for various
events.
Volume
• : Adjust the volume level for call ringtones, music
and videos, system sound, and notication ringtones.
Notication sound
• : Select a ringtone to alert you to
events, such as incoming messages and calendar events.
Settings
90
Keep the touch screen or keypad facing up during •
calibration.
Calibration may take some time, depending on
•
your location or other circumstances.
Calibration may not be possible in areas with
•
strong magnetic elds. If the calibration fails, move
to another area and try again.
If you enter an area with strong magnetic elds
•
after calibration, your device will automatically
attempt to recalibrate the geomagnetic sensor.
The geomagnetic sensor in your device does
•
not support the bird’s-eye view, which xes the
directions. Therefore, a small error may occur in
measuring angles and cause a map to be turned
upside-down.
Auto-rotate screen
• : Set whether or not to rotate the
content automatically when the device is rotated.
Animation
• : Set the device to display animation when
you switch between windows.
Screen timeout
• : Set the length of time the device waits
before turning o the display's backlight.
Power saving mode
• : Activate Power saving mode. In
Power saving mode, the device saves power by adjusting
the white balance on the display and the brightness
level.
Horizontal calibration
• : Calibrate the accelerometer to
adjust the horizontal axis of the device for better motion
recognition.
Settings
91
Visible passwords• : Set the device to display your
password as you enter.
Select device administrators
• : View device
administrators installed on your device. You can activate
device administrators to apply new policies to your
device.
Use secure credentials
• : Use certicates and credentials
to ensure secure use of various applications.
Install encrypted certicates from SD card
• : Install
encrypted certicates that are stored on a memory card.
Set password
• : Create and conrm a password for
accessing credentials.
Clear storage
• : Erase the credential contents from the
device and reset the password.
Location and security
Change the settings for securing your device and GPS
functionality.
Use wireless networks
• : Set to use WLAN for nding
your location.
Use GPS satellites
• : Set to use the GPS satellite for
nding your location.
Use sensor aiding
• : Set to use sensors to enhance
pedestrian positioning when the GPS signal is
obstructed. There may be variations between the sensor
estimates and your actual location.
Set screen lock
• : Set the unlock security code. When
you have set your security code, this option changes to
Change screen lock.
None
- : Disable the screen lock.
Pattern
- : Set an unlock pattern to unlock the screen.
Password
- : Set a password (alphanumeric) to unlock
the screen.
Settings
92
Samsung Apps• : Set to receive notications for new
applications from Samsung Apps.
This feature may be unavailable depending on your
region or service provider.
Accounts and sync
Change the settings for the auto sync feature or manage
accounts for synchronisation.
Background data
• : Select this setting to use the auto
sync feature. The auto sync will run in the background
without opening applications and synchronise data.
Auto-sync
• : Set the device to synchronise contact,
calendar, and email data automatically.
Applications
Change the settings for managing installed applications.
Unknown sources
• : Select to download applications
from any source. If you do not select this option, you can
download applications only from Android Market.
Manage applications
• : Access the list of the applications
installed on the device and check the application
information.
Running services
• : View the services you are using and
access them to manage.
Development
• :
USB debugging
- : Select to connect your device into
a PC by using a PC data cable. This is for application
development.
Allow mock locations
- : Allow mock locations and
service information to be sent to a Location Manager
service for testing. This is for application development.
Settings
93
Locale and text
Change the settings for text input.
›
Select locale
Select a display language for all menus and applications.
Select input method
›
Select a default keyboard type for text input.
Samsung keypad
›
Portrait keypad types• : Select the default input
method, such as the QWERTY keyboard, 3x4 keypad, or
handwriting screen.
Input languages
• : Select languages for text input.
You cannot enter text in some languages. To enter
text, you should change the writing language to one
of the supported languages.
Privacy
Change the settings for managing your settings and data.
Back up my data
• : Back up your device’s settings to the
Google server.
Automatic restore
• : Set the device to restore
applications' data you backed up when they are installed
in your device.
Factory data reset
• : Reset your settings to the factory
default values and delete all your data.
SD card and device storage
Check memory information of memory cards and your
device, and format a memory card.
Settings
94
Voice input• : Activate the voice input feature to enter
text by voice on the Samsung keypad.
Auto-full stop
• : Set the device to insert a period when
you double-tap the space bar.
Tutorial
• : Learn how to enter text with the Samsung
keypad.
Voice input and output
Change the settings for the voice recogniser and the text-
to-speech feature.
Voice recognition settings
›
Language• : Select a language for the Google voice
recognition.
SafeSearch
• : Set the device to lter explicit text and/or
images from voice search results.
XT9
• : Activate XT9 mode to enter text using Predictive
input mode.
XT9 advanced settings
• : Activate the advanced features
of XT9 mode, such as auto completion, auto correction,
or auto substitution, and set up your own word list.
Keypad sweeping
• : Enable or disable the keypad
sweeping feature for the text input mode. You can switch
between input modes by scrolling left or right on the
keypad.
Auto-capitalization
• : Set the device to automatically
capitalise the rst letter after a nal punctuation mark,
such as a period, question mark, or exclamation mark.
Handwriting settings
• : Customise the recognition time
in Handwriting mode.
Settings
95
Speech rate• : Select a speed for the text-to-speech
feature.
Language
• : Select a language for the text-to-speech
feature.
Engines
• : View the text-to-speech engines downloaded
from Android Market.
Accessibility
Change the settings for accessibility features.
Accessibility
• : Activate an accessibility application you
have downloaded, such as Talkback or Kickback, which
provides voice, melody, or vibration feedback.
Block oensive words
• : Hide oensive words your
device recognised from voice search results.
Show hints
• : Set to show a suggested term or phrase for
the voice search feature.
Text-to-speech settings
›
Listen to an example• : Listen to the spoken text for an
example. Install voice data for using the text-to-speech
feature.
Always use my settings
• : Set the device to use the
settings you specify in applications rather than the
default settings.
Default engine
• : Set the speech synthesis engine to be
used for spoken text.
Install voice data
• : Download and install voice data for
the text-to-speech feature.
Settings
96
Date and time
Access and alter the following settings to control how time
and date are displayed on your device:
Set date
• : Set the current date manually.
Select time zone
• : Set your home time zone.
Set time
• : Set the current time manually.
Use 24-hour format
• : Set to the time to be displayed in
24-hour format.
Select date format
• : Select a date format.
About device
Access information about your device and check the
device’s status.
Troubleshooting
97
Troubleshooting
Your device displays network or service error
messages
When you are in areas with weak signals or poor •
reception, you may lose reception. Move to another area
and try again.
You cannot access some options without a subscription.
•
Contact your service provider for more details.
The touch screen responds slowly or
improperly
If your device has a touch screen and the touch screen is
not responding properly, try the following:
Remove any protective covers from the touch screen.
•
Protective covers may prevent the device from
recognising your inputs and are not recommended for
touch screen devices.
Ensure that your hands are clean and dry when tapping
•
the touch screen.
Restart your device to clear any temporary software
•
bugs.
Ensure that your device software is upgraded to the
•
latest version.
If the touch screen is scratched or damaged, take it to
•
your local Samsung Service Centre.
Your device freezes or has fatal errors
If your device freezes or hangs, you may need to close
programs or reset the device to regain functionality. If your
device is frozen and unresponsive, press and hold [ ] for
8-10 seconds. The device will reboot automatically.
If this does not solve the problem, perform a factory data
reset. In Idle mode, open the application list and select
Settings
→
Privacy
→
Factory data reset
→
Device Reset
→
Erase everything.
Troubleshooting
98
Your device is hot to the touch
When you use applications that require more power or use
applications on your device for an extended period of time,
your device may feel hot to the touch. This is normal and
should not aect your device's lifespan or performance.
Error messages appear when launching the
camera
Your Samsung mobile device must have sucient
available memory and battery power to operate the
camera application. If you receive error messages when
launching the camera, try the following:
Charge the battery or replace it with a battery that is fully
•
charged.
Free some memory by transferring les to a PC or
•
deleting les from your device.
Restart the device. If you are still having trouble with
•
the camera application after trying these tips, contact a
Samsung Service Centre.
The device beeps and the battery icon ashes
Your battery is low. Recharge or replace the battery to
continue using the device.
The battery does not charge properly or the
device turns o
The battery terminals may be dirty. Wipe both gold-•
coloured contacts with a clean, soft cloth and try
charging the battery again.
If the battery will no longer charge completely, dispose
•
of the old battery properly and replace it with a new
battery (refer to your local ordinances for proper disposal
instructions).
Troubleshooting
99
Error messages appear when opening music
les
Some music les may not play on your Samsung mobile
device for a variety of reasons. If you receive error
messages when opening music les on your device, try the
following:
Free some memory by transferring les to a PC or
•
deleting les from your device.
Ensure that the music le is not Digital Rights
•
Management (DRM)-protected. If the le is DRM-
protected, ensure that you have the appropriate license
or key to play the le.
Ensure that your device supports the le type.
•
Error messages appear when launching the FM
radio
The FM radio application on your Samsung mobile device
uses the headset cable as an antenna. Without a headset
connected, the FM radio will be unable to receive radio
stations. To use the FM radio, rst ensure that the headset
is properly connected. Next, scan for and save the available
radio stations.
If you still cannot use the FM radio after performing these
steps, try accessing your desired station with another radio
receiver. If you can hear the station with another receiver,
your device may require service. Contact a Samsung
Service Centre.
Troubleshooting
100
Another Bluetooth device is not located
Ensure that the Bluetooth wireless feature is activated on •
your device.
Ensure that the Bluetooth wireless feature is activated on
•
the device you wish to connect to, if necessary.
Ensure that your device and the other Bluetooth device
•
are within the maximum Bluetooth range (10 m).
If the tips above do not solve the problem, contact a
Samsung Service Centre.
A connection is not established when you
connect the device to a PC
Ensure that the PC data cable you are using is compatible •
with your device.
Ensure that you have the proper drivers installed and
•
updated on your PC.
Safety precautions
101
Safety precautions
To prevent injury to yourself and others or damage to your device, read all
of the following information before using your device.
Warning: Prevent electric shock, re, and
explosion
Do not use damaged power cords or plugs, or loose
electrical sockets
Do not touch the power cord with wet hands, or disconnect
the charger by pulling on the cord
Do not bend or damage the power cord
Do not use your device while charging or touch your device
with wet hands
Do not short-circuit the charger or the battery
Do not drop or cause an impact to the charger or the
battery
Do not charge the battery with chargers that are not
approved by the manufacturer
Do not use your device during a thunderstorm
Your device may malfunction and your risk of electric shock is increased.
Do not handle a damaged or leaking Lithium Ion (Li-Ion)
battery
For safe disposal of your Li-Ion batteries, contact your nearest authorised
service centre.
Handle and dispose of batteries and chargers with care
Use only Samsung-approved batteries and chargers specically •
designed for your device. Incompatible batteries and chargers can
cause serious injuries or damage to your device.
Never dispose of batteries or devices in a re. Follow all local
•
regulations when disposing of used batteries or devices.
Never place batteries or devices on or in heating devices, such as
•
microwave ovens, stoves, or radiators. Batteries may explode when
overheated.
Never crush or puncture the battery. Avoid exposing the battery to
•
high external pressure, which can lead to an internal short circuit and
overheating.
Safety precautions
102
Do not use your device near a pacemaker
Avoid using your device within a 15 cm range of a pacemaker if •
possible, as your device can interfere with the pacemaker.
If you must use your device, keep at least 15 cm away from the
•
pacemaker.
To minimise the possible interference with a pacemaker, use your
•
device on the opposite side of your body from the pacemaker.
Do not use your device in a hospital or near medical
equipment that can be interfered with by radio frequency
If you personally use any medical equipment, contact the manufacturer
of the equipment to ensure the safety of your equipment from radio
frequency.
If you are using a hearing aid, contact the manufacturer for
information about radio interference
Some hearing aids may be interfered with by the radio frequency of your
device. Contact the manufacturer to ensure the safety of your hearing aid.
Turn o the device in potentially explosive environments
Turn o your device in potentially explosive environments instead of •
removing the battery.
Always comply with regulations, instructions and signs in potentially
•
explosive environments.
Protect the device, batteries, and chargers from damage
Avoid exposing your device and batteries to very cold or very hot •
temperatures.
Extreme temperatures can cause the deformation of the device and
•
reduce the charging capacity and life of your device and batteries.
Prevent batteries from contacting metal objects, as this can create a
•
connection between the + and – terminals of your batteries and lead to
temporary or permanent battery damage.
Never use a damaged charger or battery.
•
Caution: Follow all safety warnings and
regulations when using your device in
restricted areas
Turn o your device where prohibited
Comply with all regulations that restrict the use of a mobile device in a
particular area.
Do not use your device near other electronic devices
Most electronic devices use radio frequency signals. Your device may
interfere with other electronic devices.
Safety precautions
103
Do not take notes or look up phone numbers. Jotting down a “to do” •
list or ipping through your address book takes attention away from
your primary responsibility of driving safely.
Proper care and use of your mobile device
Keep your device dry
Humidity and all types of liquids may damage device parts or •
electronic circuits.
When wet, remove the battery without turning on your device. Dry
•
your device with a towel and take it to a service centre.
Liquids will change the colour of the label that indicates water
•
damage inside the device. Water damage to your device can void your
manufacturer’s warranty.
Do not use or store your device in dusty, dirty areas
Dust can cause your device to malfunction.
Do not store your device on slopes
If your device falls, it can be damaged.
Do not use your device at refuelling points (service stations), near fuels
•
or chemicals, and at blasting areas.
Do not store or carry ammable liquids, gases, or explosive materials in
•
the same compartment as the device, its parts, or accessories.
Turn o your device when in an aircraft
Using your device in an aircraft is illegal. Your device may interfere with
the electronic navigation instruments of the aircraft.
Electronic devices in a motor vehicle may malfunction due
to the radio frequency of your device
Electronic devices in your car may malfunction due to radio frequency of
your device. Contact the manufacturer for more information.
Comply with all safety warnings and
regulations regarding mobile device usage
while operating a vehicle
While driving, safely operating the vehicle is your rst responsibility.
Never use your mobile device while driving, if it is prohibited by law. For
your safety and the safety of others, practice good common sense and
remember the following tips:
Use a hands-free device.
•
Safety precautions
104
Do not store your device near or in heaters, microwaves,
hot cooking equipment, or high pressure containers
The battery may leak.•
Your device may overheat and cause a re.•
Do not drop your device or cause impacts to your device
The screen of your device may be damaged.•
If bent or deformed, your device may be damaged or parts may •
malfunction.
Do not use a ash close to the eyes of people or animals
Using a ash close to the eyes may cause temporary loss of vision or
damage to the eyes.
Ensure maximum battery and charger life
Avoid charging batteries for more than a week, as overcharging may •
shorten battery life.
Over time, unused batteries will discharge and must be recharged
•
before use.
Disconnect chargers from power sources when not in use.
•
Use batteries only for their intended purposes.•
Do not store your device in hot or cold areas. Use your
device at -20 °C to 50 °C
Your device can explode if left inside a closed vehicle, as the inside •
temperature can reach up to 80 °C.
Do not expose your device to direct sunlight for extended periods of
•
time (such as on the dashboard of a car).
Store the battery at 0 °C to 40 °C.
•
Do not store your device with such metal objects as coins,
keys and necklaces
Your device may become deformed or malfunction.•
If the battery terminals are in contact with metal objects, it may cause •
a re.
Do not store your device near magnetic elds
Your device may malfunction or the battery may discharge from •
exposure to magnetic elds.
Magnetic stripe cards, including credit cards, phone cards, passbooks,
•
and boarding passes, may be damaged by magnetic elds.
Do not use carrying cases or accessories with magnetic closures or
•
allow your device to come in contact with magnetic elds for extended
periods of time.
Safety precautions
105
Protect your hearing
Excessive exposure to loud sounds can cause hearing •
damage.
Exposure to loud sounds while driving may distract your
•
attention and cause an accident.
Always turn the volume down before plugging the
•
earphones into an audio source and use only the
minimum volume setting necessary to hear your
conversation or music.
Use caution when using the device while walking or
moving
Always be aware of your surroundings to avoid injury to yourself or
others.
Do not carry your device in your back pockets or around
your waist
You can be injured or damage the device if you fall.
Use manufacturer-approved batteries, chargers,
accessories and supplies
Using generic batteries or chargers may shorten the life of your device •
or cause the device to malfunction.
Samsung cannot be responsible for the user’s safety when using
•
accessories or supplies that are not approved by Samsung.
Do not bite or suck on the device or the battery
Doing so may damage the device or cause explosion.•
If children use the device, make sure that they use the device properly.•
When using the device:
Speak directly into the mouthpiece.•
Avoid contact with your device’s internal antenna. Touching the •
antenna may cause the device to transmit more radio frequency than
necessary.
Hold the device with a relaxed grip, press the keys lightly, use special
•
features that reduce the number of keys you have to press (such as
predictive text), and take frequent breaks.
Safety precautions
106
Do not use the device for anything other than its intended
use
Avoid disturbing others when using the device in public
Do not allow children to use your device
Your device is not a toy. Do not allow children to play with it as they could
hurt themselves and others, or damage the device.
Install mobile devices and equipment with caution
Ensure that any mobile devices or related equipment installed in your •
vehicle are securely mounted.
Avoid placing your device and accessories near or in an air bag
•
deployment area. Improperly installed wireless equipment can cause
serious injury when air bags inate rapidly.
Allow only qualied personnel to service your device
Allowing unqualied personnel to service your device may result in
damage to your device and will void your manufacturer’s warranty.
Do not disassemble, modify, or repair your device
Any changes or modications to your device can void your •
manufacturer’s warranty. For service, take your device to a Samsung
Service Centre.
Do not disassemble or puncture the battery, as this can cause
•
explosion or re.
Do not paint or put stickers on your device
Paint and stickers can clog moving parts and prevent proper operation.
If you are allergic to paint or metal parts of the product, you may
experience itching, eczema, or swelling of the skin. When this happens,
stop using the product and consult your physician.
When cleaning your device:
Wipe your device or charger with a towel or a rubber.•
Clean the terminals of the battery with a cotton ball or a towel.•
Do not use chemicals or detergents.•
Do not use the device if the screen is cracked or broken
Broken glass or acrylic could cause injury to your hands and face. Take the
device to a Samsung Service Centre to have it repaired.
Safety precautions
107
Specic Absorption Rate (SAR) certication
information
Your device conforms to European Union (EU) standards that limit
human exposure to radio frequency (RF) energy emitted by radio and
telecommunications equipment. These standards prevent the sale of
mobile devices that exceed a maximum exposure level (known as the
Specic Absorption Rate, or SAR) of 2.0 W/kg.
During testing, the maximum SAR recorded for this model was
0.150 W/kg. In normal use, the actual SAR is likely to be much lower, as
the device has been designed to emit only the RF energy necessary to
transmit a signal to the nearest base station. By automatically emitting
lower levels when possible, your device reduces your overall exposure
to RF energy.
The Declaration of Conformity statement at the back of this manual
demonstrates your device’s compliance with the European Radio &
Terminal Telecommunications Equipment (R&TTE) directive. For more
information about the SAR and related EU standards, visit the Samsung
website.
Handle memory cards with care
Do not remove a card while the device is transferring or accessing •
information, as this could result in loss of data and/or damage to the
card or device.
Protect cards from strong shocks, static electricity, and electrical noise
•
from other devices.
Do not touch gold-coloured contacts or terminals with your ngers or
•
metal objects. If dirty, wipe the card with a soft cloth.
Be sure to back up important data
Samsung is not responsible for data loss.
Do not distribute copyright-protected material
Do not distribute copyright-protected material that you have recorded
to others without the permission of the content owners. Doing this may
violate copyright laws. The manufacturer is not liable for any legal issues
caused by the user’s illegal use of copyrighted material.
Safety precautions
108
Correct disposal of batteries in this product
(Applicable in the European Union and other European
countries with separate battery return systems)
This marking on the battery, manual or packaging indicates
that the batteries in this product should not be disposed
of with other household waste at the end of their working
life. Where marked, the chemical symbols Hg, Cd or Pb indicate that the
battery contains mercury, cadmium or lead above the reference levels
in EC Directive 2006/66. If batteries are not properly disposed of, these
substances can cause harm to human health or the environment.
To protect natural resources and to promote material reuse, please
separate batteries from other types of waste and recycle them through
your local, free battery return system.
Correct disposal of this product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European
countries with separate collection systems)
This marking on the product, accessories or literature indicates
that the product and its electronic accessories (e.g. charger,
headset, USB cable) should not be disposed of with other
household waste at the end of their working life.
To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate these items from other
types of waste and recycle them responsibly to promote the sustainable
reuse of material resources.
Household users should contact either the retailer where they purchased
this product, or their local government oce, for details of where and
how they can take these items for environmentally safe recycling.
Business users should contact their supplier and check the terms and
conditions of the purchase contract. This product and its electronic
accessories should not be mixed with other commercial wastes for
disposal.
This EEE is compliant with RoHS.
Safety precautions
109
CONNECTION WITH, ANY INFORMATION CONTAINED IN, OR AS A RESULT
OF THE USE OF ANY CONTENT OR SERVICE BY YOU OR ANY THIRD PARTY,
EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.”
Third party services may be terminated or interrupted at any time,
and Samsung makes no representation or warranty that any content
or service will remain available for any period of time. Content and
services are transmitted by third parties by means of networks and
transmission facilities over which Samsung has no control. Without
limiting the generality of this disclaimer, Samsung expressly disclaims any
responsibility or liability for any interruption or suspension of any content
or service made available through this device.
Samsung is neither responsible nor liable for customer service related to
the content and services. Any question or request for service relating to
the content or services should be made directly to the respective content
and service providers.
Disclaimer
Some content and services accessible through this device belong to third
parties and are protected by copyright, patent, trademark and/or other
intellectual property laws. Such content and services are provided solely
for your personal noncommercial use. You may not use any content or
services in a manner that has not been authorised by the content owner
or service provider. Without limiting the foregoing, unless expressly
authorised by the applicable content owner or service provider, you may
not modify, copy, republish, upload, post, transmit, translate, sell, create
derivative works, exploit, or distribute in any manner or medium any
content or services displayed through this device.
“THIRD PARTY CONTENT AND SERVICES ARE PROVIDED “AS IS.” SAMSUNG
DOES NOT WARRANT CONTENT OR SERVICES SO PROVIDED, EITHER
EXPRESSLY OR IMPLIEDLY, FOR ANY PURPOSE. SAMSUNG EXPRESSLY
DISCLAIMS ANY IMPLIED WARRANTIES, INCLUDING BUT NOT LIMITED
TO, WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR
PURPOSE. SAMSUNG DOES NOT GUARANTEE THE ACCURACY, VALIDITY,
TIMELINESS, LEGALITY, OR COMPLETENESS OF ANY CONTENT OR
SERVICE MADE AVAILABLE THROUGH THIS DEVICE AND UNDER NO
CIRCUMSTANCES, INCLUDING NEGLIGENCE, SHALL SAMSUNG BE
LIABLE, WHETHER IN CONTRACT OR TORT, FOR ANY DIRECT, INDIRECT,
INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, ATTORNEY
FEES, EXPENSES, OR ANY OTHER DAMAGES ARISING OUT OF, OR IN
Index
110
Index
alarms
creating 81
deactivating 81
stopping 81
AllShare 75
battery
charging 11
Bluetooth
activating 71
nding and pairing with
devices 72
receiving data 72
sending data 72
brightness, display 25
calculator 83
calendar
creating events 58
viewing events 58
camera
capturing photos 38
capturing videos 44
customising camcorder 46
customising camera 43
connections
Bluetooth 71
DLNA 75
PC 77
WLAN 73
contacts
creating 55
nding 55
importing 57
device
customising 24
indicator icons 18
keys 17
layout 16
settings 88
shortcuts panel 21
turning on or o 16
DLNA
see AllShare
Index
111
menu screen
accessing 22
organising applications 23
messages
sending email 35
setting email accounts 35
mini diary 83
music player
adding les 50
creating playlists 51
playing music 50
PC connections
mass storage 78
Samsung Kies 77
phonebook
creating contacts 55
creating groups 56
Google Maps 64
Google Search 68
Google Talk 37
idle screen
adding items 20
adding panels 22
internet
see web browser
latitude 66
memory card
formatting 15
inserting 13
removing 14
memos
creating 59
viewing 60
downloads
applications 30
les 31
email
sending 35
setting accounts 35
viewing 36
le manager 84
ight mode 16
FM radio
listening to 52
saving stations 53
gallery
le formats 48
playing videos 49
viewing photos 48
Google Mail 33
Index
112
timer 82
touch screen
locking 20
using 19
unpack 10
video player 47, 49
videos
capturing 44
playing 47, 49
voice recorder
playing 60
recording 60
VPN connections
connecting to 80
creating 79
applications 92
date and time 96
locale and text 93
location & security 91
privacy 93
SD card & device storage 93
wireless & network 88
silent mode 25
stopwatch 82
synchronisation
with web accounts 31
task manager 85
text input 27
text memos 59
ThinkFree Oce 86
time and date, set 24
creating your namecard 56
nding contacts 55
photos
capturing 38
capturing action 42
capturing a series 41
capturing by scene 40
capturing in smile shot 40
capturing panoramic 41
capturing yourself 43
viewing 48
qik video 33
Samsung Apps 70
Samsung Kies 77
settings
accessibility 95
accounts and sync 92
ETSI EN 301 489-1 V1.8.1:2008
ETSI EN 301 489-17 V2.1.1:2009
ETSI EN 300 328 V1.7.1 WLAN
ETSI EN 300 328 V1.7.1 BT
EN 50360:2001
EN 62209-1:2006
EN 55022:2006/A1:2007
EN 55024:1998/A1:2001/A2:2003
EN 60950-1:2006+A11:2009
EN 62311:2008
Date of rst axing CE Mark : 2011
Representative in the EU
Representative in the EU:
Samsung Electronics Euro QA Lab.
Blackbushe Business Park
Saxony Way, Yateley, Hampshire
GU46 6GG, UK
10 March 2011 Joong-Hoon Choi / Lab Manager
(Place and date of issue) (Name and signature of authorised person)
* It is not the address of Samsung Service Centre. For the address or the phone
number of Samsung Service Centre, see the warranty card or contact the retailer
where you purchased your product.
Declaration of Conformity
Product details
For the following
Product : Mobile Internet Device (MID)
Model(s) : YP-G70(Variant Model : YP-G70**, YP-G70***)
(The mark “*” means the memory capacity and color of product)
Manufactured at:
F1: Samsung Electronics Co., Ltd.
416, Maetan 3 Dong, Yeongtong-Gu, Suwon-city, Gyeonggi-Do, Korea
F2: Samsung Electronics Co., Ltd.
#94-1, Imsoo-dong, Gumi-city, Gyeongsangbuk-do, Korea
F3: Samsung Electronics Huizhou Co., Ltd.
Industrial Complex, Chenjiang Town, Huizhou City,
Guangdong Province China
F4: P.T. Samsung Electronics Indonesia
Cikarang Industrial Estate JI, Jababeka Raya Blok F29-33 Cikarang,
Bekasi 17530, Indonesia
(Factories name and address)
Declaration & Applicable standards
We hereby declare, that the product above is in compliance with the essential
requirements of the R&TTE Directive (1995/5/EC), the Low Voltage Directive
(2006/95/EC) and the Electromagnetic Compatibility Directive (2004/108/EC)
by application of:
FCC ID: A3LYPG70
FCC Part 15.19
This device complies with part 15 of the FCC Rules. Operation is subject to The following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
FCC Part 15.21
Any changes or modifications (including the antennas) made to this device that are not expressly approved by the manufacturer may void the user's
authority to operate the equipment.
RF Exposure Statement
FCC RF Radiation Exposure Statement: This equipment complies with FCC RF Radiation exposure limits set forth for an uncontrolled environment.
This device and its antenna must not be co-located or operating in conjunction with any other antenna or transmitter.
This equipmentshould be installed and operated with a minimum distance of 1.5 centimeters between the radiator and your body.
And it is restricted to use with belt-clips, holsters or similar accessories that have no metallic components.
Part 15.105 (B)
Note : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference in a residential installation This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications, However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Modifications not expressly approved by the manufacturer could void the user’s authority to operated the equipment under FCC rules.
IC: 649E-YPG70
Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation est autorisée aux
deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit accepter tout brouillage
radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Rapport d'exposition de rayonnement de la IC rf : Cet équipement est conforme aux limites d'exposition de rayonnement de la IC rf déterminées pour
un environnement non contrôlé. Ce dispositif et son antenne ne doivent pas n'être coïmplantés ou opération en même temps qu'aucune autre antenne ou émetteur.
Cet equipmentshould soit installé et actionné avec une distance minimum de 1.5 centimètre entre le radiateur et votre corps. Et il est limité pour employer avec les
ceinture-agrafes, les étuis ou les accessoires semblables qui n'ont aucun composant métallique
