Code No.:DE68-02579B

MICROWAVE OVEN

Owner’s Instructions and Cooking Guide

PG3210

Quick Look-up Guide .................................................................. 2

Oven............................................................................................ 3

Accessories................................................................................. 3

Control Panel .............................................................................. 4

Using this Instruction Booklet...................................................... 4

Safety Precautions...................................................................... 5

Installing Your Microwave oven .................................................. 7

Setting the Time.......................................................................... 7

What to Do if You are in Doubt or Have a Problem .................... 8

Cooking / Reheating.................................................................... 8

Power Levels............................................................................... 9

Stopping the Cooking.................................................................. 9

Adjusting the Cooking Time ........................................................ 9

Using the Auto Reheat Feature................................................. 10

Using the Auto Cook Feature.................................................... 11

Using the Power Defrost Feature.............................................. 12

Power Defrost Feature.............................................................. 12

Choosing the Heating Element Position of Lower Heater......... 13

Accessory positions .................................................................. 13

Choosing the Accessories......................................................... 13

Using the Top Grill..................................................................... 14

Power Grilling............................................................................ 14

Combining Microwaves and the Top Grill ................................. 15

Combining Microwaves and the Power Grill ............................. 16

Using the Power Grill Auto Cook Features ............................... 17

Using the Power Grill Auto Reheat Features ............................ 18

Using the Deodorization Feature .............................................. 19

Switching the Beeper Off .......................................................... 20

Safety-Locking Your Microwave Oven...................................... 20

Using the Easy Clean button..................................................... 20

Cookware Guide ....................................................................... 21

Cooking Guide .......................................................................... 22

Cleaning Your Microwave Oven ............................................... 31

Storing and Repairing Your Microwave Oven........................... 31

Technical Specifications............................................................ 32

wnZYXWohjvUGGwGXGGmSGtGX[SGYWWZGGXXaZWGht

Quick Look-up Guide

If you want to cook some food

If you want to defrost some food

If you want to add an extra minute

If you want to power grill some food

1. Place the food in the oven.

Select the power level by pressing the button once or

more times.

2. Select the cooking time by pressing the 10min.1min or

10s button as required.

3. Press the button.

Result : Cooking starts.

The oven beeps four times when cooking is

over.

1. Place the frozen food in the oven.

Press the Power ( ) button once or more times

according to the type of food to be defrosted.

2. Select the weight by pressing the kg and gbuttons as

required.

3. Press the button.

Leave the food in the oven.

Press +30s once or more times for each extra 30 seconds

thatyouwishtoadd.

1. Place the food on the rack in the oven.

Press the Power Grill button.

2. Select the Power Grill ( ) mode by turning the Grill

Mode Knob.

3. Select the grilling time by pressing the 10min.1min and

10s button.

4. Press the button.

wnZYXWohjvUGGwGYGGmSGtGX[SGYWWZGGXXaZWGht

Oven Accessories

Depending on the model that you have purchased, you are supplied

with several accessories that can be used in a variety of ways.

☛DO NOT operate the microwave oven without the roller ring and

turntable.

VENTILATION HOLES

DOOR LATCHES

DOOR

TURNTABLE

COUPLER

ROLLER RING SAFETY INTERLOCK

HOLES

LIGHT

DISPLAY

CONTROL PANEL

HANDLE

UPPER

HEATER

LOWER

HEATER

1. Coupler, already placed over the motor shaft in the

base of the oven.

Purpose The coupler rotates the turntable.

2. Roller ring,tobeplacedinthecentreoftheoven.

Purpose The roller ring supports the turntable.

3. Turntable,tobeplacedontherollerringwiththecentre

fitting to the coupler.

Purpose The turntable serves as the main cooking

surface; it can be easily removed for

cleaning.

4. Metal rack

Purpose Themetalrackcanbeusedingrilland

combination and power grill cooking.

5. Metal tray

Purpose The Metal tray is used to broun food better

in the grill Combination Cooking Mode and

keep pastry and pizza dough crisp

6. Heat-resistant gloves

Purpose Use the safety gloves when taking out

metal rack or turntable or dishes from the

oven after cooking.

wnZYXWohjvUGGwGZGGmSGtGX[SGYWWZGGXXaZWGht

Control Panel Using this Instruction Booklet

You have just purchased a SAMSUNG microwave oven. Your Owner’s

Instructions contain much valuable information on cooking with your

microwave oven:

• Safety precautions

• Suitable accessories and cookware

• Useful cooking tips

Inside the cover you will find a quick look-up guide explaining four

basic cooking operations:

• Cooking food

• Defrosting food

• Power grilling food

• Adding extra cooking time

At the front of the booklet you will find illustrations of the oven, and

more importantly the control panel, so that you can find the buttons

more easily.

The step-by-step procedures use three different symbols.

1. GRILL SETTING

2. POWER GRILL MODE

3. GRILL MODE KNOB

4. CLOCK SETTING BUTTON

5. POWER GRILL AUTO COOK

SELECTION

6. POWER GRILL AUTO REHEAT

SELECTION

7. POWER DEFROST FEATURE

SELECTION

8. WEIGHT SELECTION

9. MICROWAVE POWER LEVEL

MODE SETTING

10. TIME SETTING

11. STOP/CANCEL BUTTON

12. POWER GRILL + MWO COMBI

MODE

13. GRILL MODE

14. TOP GRILL COMBI MODE

15. EASY CLEAN BUTTON

16. AUTO REHEAT

17. AUTO COOK

18. SERVING SIZE

19. MORE/LESS BUTTON

20. DEODORIZATION BUTTON

21. START BUTTON

11 21

☛✉❋

Important Note Caution

wnZYXWohjvUGGwG[GGmSGtGX[SGYWWZGGXXaZWGht

Using this Instruction Booklet (continued)

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO

EXCESSIVE MICROWAVE ENERGY

Failure to observe the following safety precautions may result in harmful exposure to

microwave energy.

(a) Under no circumstances should any attempt be made to operate the oven with

the door open or to tamper with the safety interlocks (door latches) or to insert

anything into the safety interlock holes.

(b) Do not place any object between the oven door and front face or allow food or

cleaner residues to accumulate on sealing surfaces. Ensure that the door and

door sealing surfaces are kept clean by wiping after use first with a damp cloth

and then with a soft dry cloth.

qualified microwave service technician trained by the manufacturer.

It is particularly important that the oven door closes properly and that there is

no damage to the:

(1) Door, door seals and sealing surfaces

(2) Door hinges (broken or loose)

(3) Power cable

(d) The oven should not be adjusted or repaired by anyone other than a properly

qualified microwave service technician trained by the manufacturer.

Safety Precautions

Important Safety Instructions.

Read Carefully and keep for future reference.

Before cooking food or liquids in your microwave oven, please check

that the following safety precautions are taken.

1. DO NOT use any metallic cookware in the microwave oven:

• Metallic containers

• Dinnerware with gold or silver trimmings

• Skewers, forks, etc.

Reason: Electric arcing or sparking may occur and may damage the oven.

2. DO NOT heat:

• Airtight or vacuum-sealed bottles, jars, containers

Ex) Baby food jars

• Airtight food.

Ex) Eggs, nuts in shells, tomatoes

Reason: The increase in pressure may cause them to explode.

Tip: Remove lids and pierce skins, bags, etc.

3. DO NOT operate the microwave oven when it is empty.

Reason: Theovenwallsmaybedamaged.

Tip: Leave a glass of water inside the oven at all times.

The water will absorb the microwaves if you accidentally set the

oven going when it is empty.

4. DO NOT cover the rear ventilation slots with cloths or paper.

Reason: The cloths or paper may catch fire as hot air is evacuated from the

oven.

5. ALWAYS use oven gloves when removing a dish from the oven.

Reason: Some dishes absorb microwaves and heat is always transferred

from the food to the dish. The dishes are therefore hot.

6. DO NOT touch interior oven walls.

Reason: These walls may be hot enough to burn even after cooking has

finished, even though they do not appear to be so. Do not allow

inflammable materials to come into contact with any interior area of

the oven. Let the oven cool down first.

wnZYXWohjvUGGwG\GGmSGtGX[SGYWWZGGXXaZWGht

Safety Precautions (continued)

7. Toreducetheriskoffireintheovencavity:

• Do not store flammable materials in the oven

• Remove wire twist ties from paper or plastic bags

• Do not use your microwave oven to dry newspapers.

• If smoke is observed, keep the oven door closed and switch off or

disconnect the oven from the power supply

8. Take particular care when heating liquids and baby foods.

• ALWAYS allow a standing time of at least 20 seconds after the oven has

been switched off so that the temperature can equalize.Stir during

heating, if necessary, and ALWAYS stir after heating.

• Take care when handling the container after heating. You may burn

yourself if the container is too hot.

• A risk of delayed eruptive boiling exists.

• To prevent delayed boiling and possible scalding, you should put a plastic

spoon or glass stick into the beverages and stir before, during and after

heating.

Reason: During the heating of liquids the boiling point can be delayed;

this means that eruptive boiling can start after the container is

removed from the oven. You may scald yourself.

• In the event of scalding, follow these FIRST AID instructions:

* Immerse the scalded area in cold water for at least 10 minutes.

* Cover with a clean, dry dressing.

* Do not apply any creams, oils or lotions.

•NEVER fill the container to the top and choose a container that is wider at

the top than at the bottom to prevent the liquid from boiling over. Bottles

with narrow necks may also explode if overheated.

•ALWAYS check the temperature of baby food or milk before giving it to

the baby.

•NEVER heat a baby’s bottle with the teat on, as the bottle may explode if

overheated.

9. Be careful not to damage the power cable.

• Do not immerse the power cable or plug in water and keep the power

cable away from heated surfaces.

• Do not operate this appliance if it has a damaged power cable or plug.

10. Stand at arm’s length from the oven when opening the door.

Reason: The hot air or steam released may cause scalding.

11. Keep the inside of the oven clean.

Reason: Food particles or spattered oils stuck to oven walls or floor can

cause paint damage and reduce the efficiency of the oven.

12. You may notice a “Clicking” sound during operation(especially when the oven

is in defrosting).

Reason:This sound is normal when the electrical power output is changing.

13. When the microwave oven is operating without any load, the power will be cut

off automatically for safety. You can operate normally after letting it stand for

over 30 minutes.

IMPORTANT SAFETY INSTRUCTIONS

During cooking, you should look into the oven from time to time when food is being

heated or cooked in disposable containers of plastic, paper or other combustible

materials.

IMPORTANT

Young children should

NEVER

be allowed to use or play with the microwave oven. Nor

should they be left unattended near the microwave oven when it is in use. Items of

interest to children should not be stored or hidden just above the oven.

wnZYXWohjvUGGwG]GGmSGtGX[SGYWWZGGXXaZWGht

Installing Your Microwave oven

Place the oven on a flat, level surface that strong enough to safely bear

the weight of the oven.

❋Never block the air vents as the oven may overheat and

automatically switch itself off. It will remain inoperable until it has

cooled sufficiently.

❋For your personal safety, plug the cable into a 3-pin, 230 Volt, 50Hz,

AC earthed socket. If the power cable of this appliance is damaged, it

must be replaced by the manufacturer or its service agent or a

similarly qualified person in order to avoid a hazard.

❋Do not install the microwave oven in hot or damp surroundings like

next to a traditional oven or radiator. The power supply specifications

of the oven must be respected and any extension cable used must be

of the same standard as the power cable supplied with the oven. Wipe

the interior and the door seal with a damp cloth before using your

microwave oven for the first time.

Setting the Time

Your microwave oven has an inbuilt clock. The time can be displayed

in either the 24-hour or 12-hour notation. You must set the clock:

• When you first install your microwave oven

• After a power failure

✉Do not forget to reset the clock when you switch to and from summer

and winter time.

1. When you install your oven, make sure there is adequate

ventilation for your oven by leaving at least 10 cm (4

inches) of space behind, and on the sides of the oven

and 20 cm (8 inches) of space above the oven and 85 cm

(33 inches) of the floor.

2. Remove all packing materials inside the oven.

Install the roller ring and turntable.

Check that the turntable rotates freely.

3. This microwave oven has to be positioned so that plug is

accessible.

20 cm

above 10 cm

behind

10 cm on

the side

85 cm of

the floor

1. To display the time in the... Then press the button...

24-hour notation Once

12-hour notation Twice

2. Set the hour with the hbutton and the minutes with the

min button.

3. When the right time is displayed, press the button

againtostarttheclock.

Result : The time is displayed whenever you are not

using the microwave oven.

wnZYXWohjvUGGwG^GGmSGtGX[SGYWWZGGXXaZWGht

What to Do if You are in Doubt or Have a

Problem

If you have any of the problems listed below try the solutions given.

◆This is normal.

• Condensation inside the oven

• Air flow around the door and outer casing

• Light reflection around the door and outer casing

• Steam escaping from around the door or vents

◆The oven does not start when you press the button.

• Is the door completely closed?

◆The food is not cooked at all

• Have you set the timer correctly and/or pressed the button?

• Is the door closed?

• Have you overloaded the electric circuit and caused a fuse to blow or a

breaker to be triggered?

◆The food is either overcooked or undercooked

• Was the appropriate cooking length set for the type of food?

• Was an appropriate power level chosen?

◆Sparking and cracking occur inside the oven (arcing)

• Have you used a dish with metal trimmings?

• Have you left a fork or other metal utensil inside the oven?

• Is aluminium foil too close to the inside walls?

◆The oven causes interference with radios or televisions

• Slight interference may be observed on televisions or radios when the

oven is operating. This is normal.To solve this problem, install the oven

away from televisions, radios and aerials.

• If interference is detected by the oven’s microprocessor, the display may

be reset. To solve this problem, disconnect the power plug and reconnect

it. Reset the time.

✉If the above guidelines do not enable you to solve the problem,

contact your local dealer or SAMSUNG after-sales service.

Cooking / Reheating

The following procedure explains how to cook or reheat food.

ALWAYS check your cooking settings before leaving the oven

unattended.

First, place the food in the center of the turntable. Then, close the

door.

☛Never switch the microwave oven on when it is empty.

✉The oven must be plugged into an appropriate wall socket. The

turntable must be in position in the oven. If a power level other than

the maximum is used, the water takes longer to boil.

✉If you wish to heat a dish for a short period of time at maximum power

(900W), simply press the +30s button once for each 30 seconds of

cooking time. The oven starts immediately.

1. Press the button.

Result : The 900W (maximum cooking power)

indications are displayed:

Select the appropriate power level by

pressing the button again until the

corresponding wattage is displayed. Refer to

the power level table on the next page.

2. Set the cooking time by pressing the 10min. 1min and

10s button.

3. Press the button.

Result : Theovenlightcomesonandtheturntable

starts rotating.

(1) Cooking starts and when it has finished the

oven beeps four times.

(2) The end reminder signal will beep 3 times

(once every minute).

(3) The current time is displayed again.

wnZYXWohjvUGGwG_GGmSGtGX[SGYWWZGGXXaZWGht

Power Levels

You can choose among the power levels below.

✉If you select higher power level, the cooking time must be decreased.

If you select lower power level, the cooking time must be increased.

Stopping the Cooking

You can stop cooking at any time to check the food.

☛You can cancel any setting before starting cooking by simply pressing

Cancel().

Adjusting the Cooking Time

You can increase the cooking time by pressing the +30s button once

for each 30 seconds to be added.

✉You can not adjust the time during cooking when Auto modes are

selected.

Power Level

Output

MWO TOP GRILL

(Upper Heater)

POWER GRILL

(Upper + Lower Heater)

HIGH

MEDIUM HIGH

MEDIUM

MEDIUM LOW

DEFROST( )

LOW/KEEP WARM

GRILL

COMBI I

COMBI II

COMBI III

900 W

600 W

450 W

300 W

180 W

100 W

300 W

450 W

600 W

900 W

1850 W

1. To stop temporarily;

Open the door.

Result : Cooking stops. To resume cooking, close

the door and press again.

2. To stop Completely;

Press the button.

Result : The cooking stops.

If you wish to cancel the cooking settings,

press the Cancel( ) button again.

Press the

+30s

button once for each 30 seconds to be added.

wnZYXWohjvUGGwG`GGmSGtGX[SGYWWZGGXXaZWGht

Using the Auto Reheat Feature

With the Auto Reheat feature, the cooking time is set automatically.

You can adjust the pressing the weight range of serving by appropriate

Auto Reheat button the required number of times.

First, place the food in the center of the turntable. Then, close the

door.

✉Use only recipients that are microwave-safe.

The following table presents 3 Auto Reheat Programmes and the

quantities, standing times and appropriate recommendations.

These programes are runing with microwave only.

1. Press the Auto( ) button which you want the required

number of times.

2. Select the serving size by pressing button

3. Increase or decrease the cooking time, if necessary, by

pressing the MORE/LESS()button.

4. Press button

Result : When it has finished:

(1) The oven beeps four times.

(2) The end reminder signal will beep 3 times.

(once every minute)

(3) The current time is displayed again.

Code Food Serving Size Standing

Time Recommendations

1 Ready Meal

(chilled) 300-350 g

400-450 g 3min Putonaceramicplateandcover

with microwave cling film. This

programme is suitable for meals

consisting of 3 components (e.g.

meat with sauce, vegetables and a

side dish like potatoes, rice or

pasta).

2 Soup/Stew

(chilled) 300-350 ml

400-450 ml

500-550 ml

3min Pourthesouporsauceintoadeep

ceramic soup plate or bowl. Cover

during heating and standing time.

Stir before and after standing time.

3Drinks

(coffee, milk,

tea, water

with room

temperature)

150 ml

(1 cup)

300 ml

(2 cups)

450 ml

(3 cups)

600 ml

(4 cups)

1-2 min Pour the liquid into ceramic cups

and reheat uncovered. Place one

cup in the center, 2 cups opposite to

each other and 3 or 4 cups in a

circle.

Leave them to stand in the

microwave oven. Stir drinks before

and after standing time.

Be careful while taking the cups out

(see safety instructions for liquids).

wnZYXWohjvUGGwGXWGGmSGtGX[SGYWWZGGXXaZWGht

Using the Auto Cook Feature

With the Auto Cook feature, the cooking time is set automatically. You

can adjust the pressing the serving size(or weight range of serving) by

appropriate Auto Cook button the required number of times.

First, place the food in the center of the turntable. Then, close the

door.

✉Use only recipients that are microwave-safe.

The following table presents 3 Auto Cook Programmes and the

quantities, standing times and appropriate recommendations.

These programes are runing with microwave only.

1. Press the Auto( ) button which you want the required

number of times.

2. Select the serving size by pressing button

3. Increase or decrease the cooking time, if necessary, by

pressing the MORE/LESS()button.

4. Press button

Result : When it has finished:

(1) The oven beeps four times.

(2) The end reminder signal will beep 3 times.

(once every minute)

(3) The current time is displayed again.

Code Food Serving

Size

Standing

Time Recommendations

Vegetables

200-250 g

300-350 g

400-450 g

500-550 g

3 mins Weigh the vegetables after washing,

cleaning and cutting into similar size. Put

them into a glass bowl with lid.

Add 30 ml (2tablespoons) water when

cooking for 200-250 g, add 45ml

( 3 tablespoons) for 300-450 g and add

60 ml (4 tablespoons) for 500-550 g. Stir

after cooking. When cooking higher

quantities stir once during cooking.

Frozen

Vegetables

200-250 g

300-350 g

400-450 g

500-550 g

4 mins Weigh the frozen vegetables (-18°C)

and put them in a suitable sized glass

pyrex bowl with lid. When cooking 200-

350 g add 15 ml

(1 tablespoon) water for 400-550 g add

30 ml (2 tablespoons).

Stir after cooking and befor serving. This

programme is suitable for peas, sweet

corn, broccoli, cauliflower and mixed

vegetables such as peas, carrots and

cauliflower.

3 Potatoes 300-350 g

400-450 g

500-550 g

600-650 g

3 min Weigh the potatoes after peeling,

washing and cutting into a similar size.

Putthemintoaglassbowelwithlid.

Add 45 ml (3 tablespoons) water when

cooking 300-450 g, add 60 ml

(4 tablespoons) for cooking 500-650g.

wnZYXWohjvUGGwGXXGGmSGtGX[SGYWWZGGXXaZWGht

Using the Power Defrost Feature

With the Power Defrost feature you can easily defrost meat, poultry,

fish or Bread/cake. The defrost time and power level are set

automatically. You simply select the programme and the weight.

✉Use only dishes that are microwave-safe.

First, place the food in the centre of the turntable. Then, close the

door..

✉You can also defrost food manually. To do so, select the microwave

cooking/reheating function with a power level of 180W. Refer to the

section entitled “ Cooking/Reheating” on page 8 for further details.

Power Defrost Feature

The following table presents the various Power Defrost programmes,

quantities, standing times and appropriate recommendations.

Remove all kinds of package material before defrosting. Place meat,

poultry and fish on a ceramic plate.

1. Press the Power ()button.

Press the Power ( ) button one or more times according

tothenumberof typeoffoodtobedefrosted.Refertothe

table for further details.

2. Select the food weight by pressing the kg and gbutton.

3. Press button.

Result :

◆Defrosting begins.

◆The oven beeps halfway through

defrosting to remind you to turn the food

over.

◆Press again to finish defrosting. When

it has finished.

(1) The oven beeps four times.

(2) The end reminder signal will beep 3 times

(once every minute).

(3) The current time is displayed again.

Code Food Serving

Size

Standing

Time Recommendations

1 Meat 200-2000g 20-90min Shield the edges with aluminium foil. Turn

the meat over, when the oven beeps. This

programme is suitable for beef, lamb, pork,

steaks, chops, minced meat.

2 Poultry 200-2000g 20-90min Shield the leg and wing tips with aluminium

foil. Turn the poultry over, when the oven

beeps. This programme is suitable for whole

chicken as well as for chicken portions.

3 Fish 200-2000g 20-80min Shield the tail of a whole fish with aluminium

foil. Turn the fish over, when the oven beeps.

This programme is suitable for whole fishes

as well as for fish fillets.

4Bread/

cake 125- 1000g 10-60min Put bread on a piece of kitchen paper and

turn over, as soon as the oven beeps. Place

cake on a ceramic plate and if possible, turn

over, as soon as the oven beeps. (Oven

keeps operating and is stopped, when you

open the door. This programme is suitable

for all kinds of bread, sliced or whole, as well

as for bread rolls and baguettes. Arrange

breadrollsinacircle.Thisprogrammeis

suitable for all kinds of yeast cake, biscuit,

cheese cake and puff pastry. It is not,

suitable for short/crust pastry, fruit and

cream cakes as well as for cake with

chocolate topping.

wnZYXWohjvUGGwGXYGGmSGtGX[SGYWWZGGXXaZWGht

Choosing the Heating Element Position of Lower

Heater

The heating element is used when Power grilling. It can be placed in

one of two positions:

• Horizontal position for Power grilling, or combined

microwave + power grill cooking

• Vertical position for microwave cooking, grilling or

combined microwave + grill cooking. With upper heater only.

☛If you want to reheat the heater, cool down it first after it is heated.

(Minimum 10 minutes)

Accessory positions

When using the rack and the metal tray at the same time, do not

position them in one direction.

i.g.) If the metal tray is placed in the lower part, the rack should not be

placed in the same area.

Choosing the Accessories

Use microwave-safe recipients; do not use plastic containers, dishes,

paper cups, towels, etc.

✉For further details on suitable cookware and utensils, refer to the

CookwareGuideonpage21.

If you place food in the heater and select Power Grill or

Super Combi, the lower heater will be set in the horizontal

position automatically.

(X) (X)

(X)

If you wish to select the combined cooking mode (grill and

microwave), use only dishes that are microwave-safe and oven-

proof. Metallic cookware or utensils may damage your oven.

wnZYXWohjvUGGwGXZGGmSGtGX[SGYWWZGGXXaZWGht

Using the Top Grill

The top grill enables you to heat and brown food quickly, without

using microwaves. To this aim, a grill rack(metal rack) is supplied with

your microwave oven.

☛Always use oven gloves when touching the dishes in the oven, as

they will be very hot.

☛Do not worry if The heater turns off and on during grilling.

This system is designed to prevent overheating oven.

✉When 5 seconds remains, you can’t +30s button to add time.

Power Grilling

The power grill enables you to heat and brown food very quickly,

without using microwaves. To this aim, a grill rack(metal rack) is

supplied with your microwave oven.

✉If you select Power Grill, two lower heaters will be set in the horizontal

position automatically.

✉The lower heater will move vertically 5 seconds before the cooking

process ends.

☛Always use oven gloves when touching the dishes in the oven, as

they will be very hot.

✉When 5 seconds remains, you can’t +30s button to add time.

1. Open the door and place the food on the metal rack.

2. Press the Power Grill button.

3. Select the Grill ( ) mode by turning the Grill Mode

Knob.

Result : The display show :

4. Select the cooking time by pressing the 10min,1min and

10s buttons.

(The maximun grilling time is 60 minutes.)

Result : The following indication displayed.

5. Press the button.

Result : The oven light comes on and the turntable

starts rotating.

(1) Cooking starts and when it has finished the

oven beeps four times.

(2) The end reminder signal will beep 3 times

(once every minute).

(3) The current time is displayed again.

1. Open the door and place the food on the metal rack.

2. Press the Power Grill button.

3. Select the Power Grill ( ) Mode by turning the Grill

Mode Knob.

Result : The display show :

4. Select the cooking time by pressing the 10min,1min and

10s buttons.

(Themaximungrillingtimeis60minutes.)

Result : The following indication is displayed:

5. Press the button.

Result : The oven light comes on and the turntable

starts rotating.

(1) Cooking starts and when it has finished the

oven beeps four times.

(2) The end reminder signal will beep 3 times

(once every minute).

(3) The current time is displayed again.

wnZYXWohjvUGGwGX[GGmSGtGX[SGYWWZGGXXaZWGht

:Combining Microwaves and the Top Grill

This cooking mode combines the radiant heat that is coming from the

grill with the speed of microwave cooking. It operates only while the

door is closed. The turnble will keep rotating.

Three combination modes with Top grill are available with this model:

600 W + Top grill, 450 W + Top grill and 300 W + Top grill.

☛ALWAYS use microwave-safe and oven-proof cookware. Glass or

ceramic dishes are ideal as they allow the microwaves to penetrate

thefoodevenly.

☛ALWAYS use oven gloves when touching the recipients in the oven,

as they will be very hot.

✉When 5 seconds remains, you can’t +30s button to add time.

☛Always use oven gloves when touching the dishes in the oven, as

they will be very hot.

1. Place the food on the rack and the rack in the high stage or

low stage. Close the door.

2. Press the Power Grill button.

3. Select the Mwo + Grill Combi ( , , ) Mode by

turning the Grill Mode Knob.

Result : The display show :

Grille + MWO (300W)

Grille + MWO (450W)

Grille + MWO (600W)

Result : You cannot set the temperature of the grill.

4. Set the cooking time by pressing the 10min,1min and 10s

buttons.Themaximumcookingtimeis60minutes.

5. Press the button.

Result : Combination cooking starts. When it has

finished.

(1) The oven beeps four times.

(2) The end reminder signal will beep 3 times

(once every minute).

(3) The current time is displayed again.

wnZYXWohjvUGGwGX\GGmSGtGX[SGYWWZGGXXaZWGht

Combining Microwaves and the Power Grill

This cooking mode combines the radiant heat that is coming from the

grill with the speed of microwave cooking. It operates only while the

door is closed and the turntable is rotating. Due to upper and lower

heaters are operating the food will browned on top side and bottom

side. You do not need to . You do not need to turnover the food. Insert

food in the high stage. Three combination modes with Power Grill are

available with this model:

600 W + Power Grill, 450 W + Power Grill and 300 W + Power Grill.

☛ALWAYS use microwave-safe and oven-proof cookware. Glass or

ceramic dishes are ideal as they allow the microwaves to penetrate

thefoodevenly.

☛ALWAYS use oven gloves when touching the recipients in the oven,

as they will be very hot.

✉When 5 seconds remains, you can’t+30s button to add time.

☛Always use oven gloves when touching the dishes in the oven, as

they will be very hot.

1. Place the food on the rack and the rack in the high stage.

Close the door.

2. Press the Power Grill button.

3. Select the Mwo + Power Grill Combi (,,)Mode

by turning the Grill Mode Knob.

Result : The display show :

Power Grill + MWO (300W)

Power Grill+ MWO (450W)

Power Grill + MWO (600W)

Result : You cannot set the temperature of the grill.

4. Set the cooking time by pressing the 10min,1min and 10s

buttons.Themaximumcookingtimeis60minutes.

5. Press the button.

Result : Combination cooking starts. When it has

finished.

(1) The oven beeps four times.

(2) The end reminder signal will beep 3 times

(once every minute).

(3) The current time is displayed again.

wnZYXWohjvUGGwGX]GGmSGtGX[SGYWWZGGXXaZWGht

Using the Power Grill Auto Cook Features

With the power grill auto cook feature, the cooking time is set

automatically. You can adjust the serving size pressing the appropriate

power grill auto cook button the required number of times.

☛ALWAYS use microwave-safe and oven-proof cookware. Glass or

ceramic dishes are ideal as they allow the microwaves to penetrate

thefoodevenly.

☛ALWAYS use oven gloves when touching the recipients in the oven,

as they will be very hot.

First, place the food on the rack and insert rack in the high stage.

Then, close the door.

✉Use only recipients that are microwave-safe.

The following table presents the various Power Grill Auto

Programmes for Roast Meat, Roast Poultry and Roast Fish and the

quantities, standing times and appropriate recommendations.The

steaks programme is running with Power Grill only. The following

programmes are running with a combination of microwaves and

power grill.

1. Press the Power Grill Auto Cook button one or more

times according to number of type of food.

Refer to the table for further details.

The number will be shown in display.

2. Select the food serving size by pressing button.

3. Increase or decrease the cooking time, if necessary, by

pressing the MORE/LESS()button.

4. Press button.

Result : When it has finished.

(1) The oven beeps four times.

(2) he end reminder signal will beep 3 times

(once every minute).

(3) The current time is displayed again.

5. The lower heaters will be set in the horizontal position

automatically.

Icon Code Food Serving Size Standin

gTime Recommendations

1 Steaks 350-400 g

(2 pcs)

450-500 g

(2-3 pcs)

- Brush the beef steaks or lamb

steaks with oil and spices. Put

them in side by side in the centre

of the square rack. Insert rack in

high stage, metal tray on low

stage.

2 Kebab

Spits/

Shashilik

Spits

400 g

(2-4 spits)

600 g

(4-6 spits)

1-2 min. Prepare fresh meat cubes of pork,

beef or lamb with pieces of

vegetables on skewer and spice it.

(Do not marinate meat in vinegar.)

Put the ready prepared kebab

spitssidebysideontherack.

Insert rack in high stage, metal

tray on low stage.

1 Chicken

Pieces 200-300 g

(1 pc)

400-500 g

(2 pcs)

600-700 g

(3 pcs)

2min Brushthechickenpieceswithoil

and spice them with pepper, salt

and paprika. Put them in a circle

on the rack with the skin-side up.

Insert rack in high stage, metal

tray on low stage.

2 Chicken

Breast 300 g

(1-2 pcs)

400 g

(2 pcs)

500 g

(2-3 pcs)

- Marinate chicken breast. Put

breastsinacircleontherack.

Insert rack in high stage, metal

tray on low stage. This programme

canbeusedforchickenbreast

filletsaswellasturkeybreast

fillets.

wnZYXWohjvUGGwGX^GGmSGtGX[SGYWWZGGXXaZWGht

Using the Power Grill Auto Cook Features

(continued) Using the Power Grill Auto Reheat Features

With the power grill auto reheat features, the cooking time is set

automatically. You can adjust the serving size/portion pressing the

appropriate power grill auto reheat button the required number of

times.

☛ALWAYS use microwave-safe and oven-proof cookware. Glass or

ceramic dishes are ideal as they allow the microwaves to penetrate

thefoodevenly.

☛ALWAYS use oven gloves when touching the recipients in the oven,

as they will be very hot.

First, place the food on the rack and put the rack in the high stage.

Then, close the door.

✉Use only recipients that are microwave-safe.

Icon Code Food Serving

Size Standing

Time Recommendations

1Roast

Fish 300 g

(1pc)

600 g

(2pcs)

3-4 min. Brush skin of whole fish with oil and

salt. Add herbs and spices inside

fish. Put one fish widthways in the

center on rack, put two fishes

widthways side by side, head to tail

on the rack. Insert rack in high stage,

metal tray on low stage. This

programme is suitable for whole fish

like trout, carp, dorade or zander.

2Fish

Fillets 200-300 g

(1 pc)

400-500 g

(2 pcs)

3-4 min. Put fish fillets side by side in the

center of rack. Insert rack in high

stage, metal tray on low stage. This

programme is suitable for fish fillets

like salmon, pollack or rose-fish

fillets.

1. Press the Power Grill Auto Reheat button and select

serving size by pussing several time.

Refer to the table on the next page for further details.

2. Increase or decrease the cooking time, if necessary, by

pressing the MORE/LESS( ) button.

3. Press button.

Result : When it has finished.

(1) The oven beeps four times.

(2) he end reminder signal will beep 3 times

(once every minute).

(3) The current time is displayed again.

4. The lower heater will be set in the horizontal position

automatically.

wnZYXWohjvUGGwGX_GGmSGtGX[SGYWWZGGXXaZWGht

Using the Power Grill Auto Reheat Features

(continued)

The following table presents the Power Grill Auto Programmes for

Toast Hawaii and Frozen Pizza and the quantities, standing times and

appropriate recommendations.

These programmes are running with a combination of microwaves

and power grill.

Using the Deodorization Feature

Use this feature after cooking odorous food or when there is a lot of

smoke in the oven interior.

First clean the oven interior.

✉The deodorization time has been specified as 5 minutes. It increases

by 30 seconds whenever the +30s button is pressed.

✉The maximum deodorization time is 15 minutes.

Icon Food Serving Size Standing

Time Recommendations

Toast

Hawaii 250-300 g

(2 pcs)

500-550 g

(4 pcs)

1-2 min. Take 2 or 4 slices of toast and put

e.g. slice of ham, pineapple and

cheese on top of each toast slice. Put

the prepared cheese toasts side by

side on the square rack and insert

rack in high stage.

Frozen

Pizza 300 g

400 g

500 g

- Put the frozen pizza on the square

rack and insert it in high stage.

Press the Deodorization( ) button after you have

finished cleaning. you will hear four beeps.

wnZYXWohjvUGGwGX`GGmSGtGX[SGYWWZGGXXaZWGht

Switching the Beeper Off

You can switch the beeper off whenever you want.

Safety-Locking Your Microwave Oven

Your microwave oven is fitted with a special Child Safety programme,

which enables the oven to be “locked” so that children or anyone

unfamiliar with it cannot operate it accidentally.

The oven can be locked at any time.

Using the Easy Clean button

The function rotates the Lower Heaters for Convenient inside

cleaning.

☛Operates only when door is opened.

1. Press the and buttons at the same time.

Result : The oven will not beep each time you press a

button.

2. To switch the beeper back on, press the and

buttons again at the same time.

Result : The oven operates with the beeper on again.

1. Press the and buttons at the same time.

Result : The oven is locked (no functions can be

selected).

2. To unlock the oven, press the and buttons again

atthesametime.

Result : The oven can be used normally.

Press the

Easy Clean

button.

lower Heaters rotate into a horizontal position.

After cleaning.

Press

Easy Clean

button or

stop/cancel

button.

wnZYXWohjvUGGwGYWGGmSGtGX[SGYWWZGGXXaZWGht

Cookware Guide

To cook food in the microwave oven, the microwaves must be able to

penetrate the food, without being reflected or absorbed by the dish

used.

Care must therefore be taken when choosing the cookware. If the

cookware is marked microwave-safe, you do not need to worry.

The following table lists various types of cookware and indicates

whether and how they should be used in a microwave oven.

✓:Recommended

✓✗:Use Caution

✗:Unsafe

Cookware Microwave-

Safe Comments

Aluminium foil

✓ ✗

Canbeusedinsmallquantitiestoprotect

areas against overcooking. Arcing can

occur if the foil is too close to the oven

wall or if too much foil is used.

Browning plate ✓

Do not preheat for more than eight

minutes.

China and earthenware

✓

Porcelain, pottery, glazed earthenware

andbonechinaareusuallysuitable,

unless decorated with a metal trim.

Disposable polyester

cardboard dishes

✓

Some frozen foods are packaged in these

dishes.

Fast-food packaging

•Polystyrene cups

containers

•Paper bags or

newspaper

•Recycled paper or

metal trims

✓

✗

Canbeusedtowarmfood.Overheating

may cause the polystyrene to melt.

May catch fire.

May cause arcing.

Glassware

•Oven-to-table ware

•Fine glassware

•Glass jars

✓

Canbeused,unlessdecoratedwitha

metal trim.

Canbeusedtowarmfoodsorliquids.

Delicate glass may break or crack if

heated suddenly.

Must remove the lid. Suitable for warming

only.

Metal

•Dishes

•Freezer bag twist

ties

✗

May cause arcing or fire.

Paper

•Plates, cups,

napkins and Kitchen

paper

•Recycled paper

✓

✗

For short cooking times and warming.

Also to absorb excess moisture.

May cause arcing.

Plastic

•Containers

•Cling film

•Freezer bags

✓

✓ ✗

Particularly if heat-resistant

thermoplastic. Some other plastics may

warp or discolour at high temperatures.

Do not use Melamine plastic.

Canbeusedtoretainmoisture.Should

not touch the food. Take care when

removing the film as hot steam will

escape.

Only if boilable or oven-proof. Should not

be airtight. Prick with a fork, if necessary.

Wax or grease-proof paper

✓

Canbeusedtoretainmoistureand

prevent spattering.

wnZYXWohjvUGGwGYXGGmSGtGX[SGYWWZGGXXaZWGht

Cooking Guide

MICROWAVES

Microwave energy actually penetrates food, attracted and absorbed by its water, fat

and sugar content.

The microwaves cause the molecules in the food to move rapidly. The rapid movement

of these molecules creates friction and the resulting heat cooks the food.

COOKING

Cookware for microwave cooking:

Cookware must allow microwave energy to pass through it for maximum efficiency.

Microwaves are reflected by metal, such as stainless steel, aluminium and copper, but

they can penetrate through ceramic, glass, porcelain and plastic as well as paper and

wood. So food must never be cooked in metal containers.

Food suitable for microwave cooking:

Many kinds of food are suitable for microwave cooking, including fresh or frozen

vegetables, fruit, pasta, rice, grains, beans, fish, and meat. Sauces, custard, soups,

steamed puddings, preserves, and chutneys can also be cooked in a microwave oven.

Generally speaking, microwave cooking is ideal for any food that would normally be

prepared on a hob. Melting butter or chocolate, for example (see the chapter with tips,

techniques and hints).

Covering during cooking

To cover the food during cooking is very important, as the evaporated water rises as

steam and contributes to cooking process. Food can be covered in different ways: e.g.

with a ceramic plate, plastic cover or microwave suitable cling film.

Standing times

After cooking is over, standing time for the food is important to allow the temperature to

even outwithinthe food.

Cooking Guide for frozen vegetables

Use a suitable glass pyrex bowl with lid. Cook covered for the minimum time - see

table. Continue cooking to get the result you prefer. Stir twice during cooking and once

after cooking. Add salt, herbs or butter after cooking. Cover during standing time.

Cooking Guide for rice and pasta

Rice: Use a large glass pyrex bowl with lid - rice doubles in volume during

cooking. Cook covered.

After the cooking time is over, stir before standing time and salt or

add herbs and butter.

Remark: the rice may not have absorbed all water after the cooking

time is finished.

Pasta: Use a large glass pyrex bowl. Add boiling water, a pinch of salt and

stir well. Cook uncovered.

Stir occasionally during and after cooking. Cover during standing

time and drain thoroughly afterwards.

Food Portion Power Time

(min.) Standing

Time(min.) Instructions

Spinach 150g 600W 5-6 2-3 Add 15 ml (1 tablespoon)

cold water.

Broccoli 300g 600W 8-9 2-3 Add30ml(2tbsp.)cold

water.

Peas 300g 600W 7-8 2-3 Add 15 ml (1 tbsp.) cold

water.

Green Beans 300g 600W 7½-8½2-3 2-3 Add 30 ml (2 tbsp.)

cold water.

Mixed

Vegetables

(carrots/peas/

corn)

300g 600W 7-8 2-3 Add 15 ml (1 tbsp.) cold

water.

Mixed

Vegetables

(Chinese style)

300g 600W 7½-8½2-3 Add15ml(1tbsp.)cold

water.

Food Portion Power Time

(min.) Standing

Time(min.) Instructions

White Rice

(parboiled) 250g

375g 900W 15-16

17½-18½5 Add 500 ml cold water.

Add 750 ml cold water.

Brown Rice

(parboiled) 250g

375g 900W 20-21

22-23 5Add 500 ml cold water.

Add 750 ml cold water.

Mixed Rice

(rice + wild rice) 250g 900W 16-17 5 Add 500 ml cold water.

Mixed Corn

(rice + grain) 250g 900W 17-18 5Add 400 ml cold water.

Pasta 250g 900W 10-11 5 Add 1000 ml hot water.

Food Portion Power Time

(min.) Standing

Time(min.) Instructions

wnZYXWohjvUGGwGYYGGmSGtGX[SGYWWZGGXXaZWGht

Cooking Guide (continued)

Cooking Guide for fresh vegetables

Use a suitable glass pyrex bowl with lid. Add 30-45 ml cold water (2-3 tbsp.) for every

250 g unless another water quantity is recommended - see table. Cook covered for the

minimum time - see table. Continue cooking to get the result you prefer. Stir once

during and once after cooking. Add salt, herbs or butter after cooking. Cover during a

standingtimeof3minutes.

Hint: Cut the fresh vegetables into even sized pieces. The smaller they

are cut, the quicker they will cook.

All fresh vegetables should be cooked using full microwave power (900 W).

Food Portion Time

(min.) Standing

Time (min.) Instructions

Broccoli 250g

500g 4½-5

7-8 3 Prepare even sized florets.

Arrange the stems to the centre.

Brussels

Sprouts 250g 6-6½3Add 60-75 ml (5-6 tbsp.) water.

Carrots 250g 4½-5 3 Cut carrots into even sized slices.

Cauliflower 250g

500g 5-5½

7½-8½3Prepare even sized florets. Cut big

florets into halves.

Arrange stems to the centre.

Courgettes 250g 4-4½3 Cut courgettes into slices.

Add 30 ml (2 tbsp.) water or a knob

of butter.

Cook until just tender.

Egg Plants 250g 3½-4 3Cut egg plants into small slices

and sprinkle with 1 tablespoon

lemon juice.

Leeks 250g 4-4½3 Cut leeks into thick slices.

Mushrooms 125g

250g 1½-2

2½-3 3Prepare small whole or sliced

mushrooms.

Do not add any water. Sprinkle

with lemon juice.

Spice with salt and pepper. Drain

before serving.

Onions 250g 5-5½3 Cut onions into slices or halves.

Addonly15ml(1tbsp.)water.

Pepper 250g 4½-5 3Cut pepper into small slices.

Potatoes 250g

500g 4-5

7-8 3 Weigh the peeled potatoes and cut

them into similar sized halves or

quarters.

Turnip

Cabbage 250g 5½-6 3Cut turnip cabbage into small

cubes.

Food Portion Time

(min.) Standing

Time (min.) Instructions

wnZYXWohjvUGGwGYZGGmSGtGX[SGYWWZGGXXaZWGht

Cooking Guide (continued)

REHEATING

Your microwave oven will reheat food in a fraction of the time that conventional ovens

hobs normally take.

Use the power levels and reheating times in the following chart as a guide. The times in

the chart consider liquids with a room temperature of about +18 to +20°C or a chilled

food with a temperature of about +5 to +7°C.

Arranging and covering

Avoid reheating large items such as joint of meat - they tend to overcook and dry out

before the centre is piping hot. Reheating small pieces will be more successful.

Power levels and stirring

Some foods can be reheated using 900 W power while others should be reheated

using 600 W, 450 W or even 300 W.

Check the tables for guidance. In general, it is better to reheat food using a lower

power level, if the food is delicate, in large quantities, or if it is likely to heat up very

quickly (mince pies, for example).

Stir well or turn food over during reheating for best results. When possible, stir again

before serving.

Take particular care when heating liquids and baby foods. To prevent eruptive boiling

of liquids and possible scalding , stir before, during and after heating. Keep them in the

microwave oven during standing time. We recommend putting a plastic spoon or glass

stick into the liquids. Avoid overheating (and therefore spoiling) the food.

It is preferable to underestimate cooking time and add extra heating time, if necessary.

Heating and standing times

When reheating food for the first time, it is helpful to make a note of the time taken - for

future reference.

Always make sure that the reheated food is piping hot throughout.

Allow food to stand for a short time after reheating - to let the temperature even out.

The recommended standing time after reheating is 2-4 minutes, unless another time is

recommended in the chart.

Take particular care when heating liquids and baby food. See also the chapter with the

safety precautions.

REHEATING LIQUIDS

Always allow a standing time of at least 20 seconds after the oven has been switched

off to allow the temperature to even out. Stir during heating, if necessary, and ALWAYS

stir after heating. To prevent eruptive boiling and possible scalding, you should put a

plastic spoon or glass stick into the beverages and stir before, during and after heating.

REHEATING BABY FOOD

BABY FOOD:

Empty into a deep ceramic plate. Cover with plastic lid. Stir well after reheating! Let

stand for 2-3 minutes before serving. Stir again and check the temperature.

Recommended serving temperature: between 30-40°C.

BABY MILK:

Pour milk into a sterilised glass bottle. Reheat uncovered. Never heat a baby's bottle

with teat on, as the bottle may explode if overheated. Shake well before standing time

and again before serving ! Always carefully check the temperature of baby milk or food

before giving it to the baby. Recommended serving temperature: ca. 37°C.

REMARK:

Baby food particularly needs to be checked carefully before serving to prevent burns.

Use the power levels and times in the next table as a guide lines for reheating.

wnZYXWohjvUGGwGY[GGmSGtGX[SGYWWZGGXXaZWGht

Cooking Guide (continued)

Reheating Baby Food and Milk

Use the power levels and times in this table as guide lines for reheating.

Reheating Liquids and Food

Use the power levels and times in this table as a guide lines for reheating.

Food Portion Power Time Standing

Time

(min.)

Instructions

Baby food

(vegetables

+meat)

190g 600W 30sec. 2-3 Empty into ceramic deep

plate. Cook covered. Stir

after cooking time. Stand

for 2-3 minutes. Before

serving, stir well and check

the temperature carefully.

Baby

porridge

(grain +milk

+fruit)

190g 600W 20sec. 2-3 Empty into ceramic deep

plate. Cook covered. Stir

after cooking time. Stand

for 2-3 minutes. Before

serving, stir well and check

the temperature carefully.

Baby milk 100ml

200ml

300W 30-40sec.

1min.to

1min.10sec.

2-3 Stir or shake well and pour

into a sterilised glass

bottle. Place into the centre

of turn-table. Cook

uncovered. Shake well and

stand for at least 3 minutes.

Before serving, shake well

and check the temperature

carefully.

Food Portion Power Time

(min.) Standing

Time (min.) Instructions

Drinks

(coffee, tea.

and water)

150ml

(1 cup)

300ml

(2 cups)

450ml

(3 cups)

600ml

(4 cups)

900W 1-1½

2-2½

3-3½

3½-4

1-2 Pour into cups and reheat

uncovered:

1 cup in the centre, 2 cups

opposite of each other, 3

cups in a circle. Keep in

microwave oven during

standing time and stir well.

Soup (chilled) 350g

450g 900W 3-3½

3½-4 2-3 Pour into a deep ceramic

plate or deep ceramic

bowl.

Cover with plastic lid.

Stir well after reheating.

Stir again before serving.

Stew (chilled) 350g 600W 4½-5½2-3 Put stew in a deep ceramic

plate.

Cover with plastic lid.

Stir occasionally during

reheating and again before

standing and serving.

Pasta with

sauce

(chilled)

350g 600W 3½-4½3Put pasta (e.g. spaghetti or

egg noodles) on a flat

ceramic plate. Cover with

microwave cling film. Stir

before serving.

Filled pasta

with sauce

(chilled)

350g 600W 4-5 3 Put filled pasta (e.g. ravioli,

tortellini) in a deep ceramic

plate. Cover with plastic lid.

Stir occasionally during

reheating and again before

standing and serving.

Plated Meal

(chilled) 350g

450g 600W 4½-5½

5½-6½3Plate a meal of 2-3 chilled

components on a ceramic

dish.

Cover with microwave

cling-film.

wnZYXWohjvUGGwGY\GGmSGtGX[SGYWWZGGXXaZWGht

Cooking Guide (continued)

DEFROSTING

Microwaves are an excellent way of defrosting frozen food. Microwaves gently defrost

frozen food in a short period of time. This can be of great advantage, if unexpected

guests suddenly show up.

Frozen poultry must be thoroughly thawed before cooking. Remove any metal ties and

take it out of any wrapping to allow thawed liquid to drain away.

Put the frozen food on a dish without cover. Turn over half way, drain off any liquid and

remove any giblets as soon as possible.

Check the food occasionally to make sure that it does not feel warm.

If smaller and thinner parts of the frozen food start to warm up, they can be shield by

wrapping very small strips of aluminium foil around them during defrosting.

Should poultry start to warm up on the outer surface, stop thawing and allow it to stand

for 20 minutes before continuing.

Leave the fish, meat and poultry to stand in order to complete defrosting. The standing

time for complete defrosting will vary depending on the quantity defrosted. Please refer

to the table below.

Hint: Flat food defrosts better than thick and smaller quantities need less

time than bigger ones. Remember this hint while freezing and

defrosting food.

For defrosting of frozen food with a temperature of about -18 to - 20 °C, use the

following table as a guide.

All frozen food should be defrosted using defrosting power level (180 W).

Food Portion Time

(min.) Standing

Time

(min.)

Instructions

Meat

Minced

beef

Pork steaks

250g

500g

250g

6-7

10-12

7-8

15-30 Place the meat on a flat ceramic

plate.

Shield thinner edges with

aluminium foil.

Turn over after half of defrosting

time!

Poultry

Chicken

pieces

Whole

chicken

500g

(2 pcs)

1200g

14-15

30-34

15-60 First, put chicken pieces first skin-

side down, whole chicken first

breast-side-down on a flat

ceramic plate. Shield the thinner

parts like wings and ends with

aluminium foil. Turn over after half

of defrosting time!

Fish

Fish fillets

Whole fish

200g

400g

5-7

11-13

10-25 Put frozen fish in the middle of a

flat ceramic plate.

Arrange the thinner parts under

the thicker parts.

Shield narrow ends with

aluminium foil.

Turn over after half of defrosting

time!

Fruits

Berries

300g 6-7 5-10 Spread fruit on a flat, round glass

dish (with a large diameter).

Bread

Bread rolls

(eachabout

50 g)

Toast/

Sandwich

German

bread

(wheat+

rye flour)

2pcs

4pcs

250g

500g

1-1½

2½-3

4-4½

7-9

5 - 20 Arrange rolls in a circle or bread

horizontally on kitchen paper in

the middle of turntable.

Turn over after half of defrosting

time!

wnZYXWohjvUGGwGY]GGmSGtGX[SGYWWZGGXXaZWGht

Cooking Guide (continued)

POWER GRILL

The upper grill-heating element is located underneath the ceiling and two lower

movable heating-elements are located at the sides, while fixed at the back of cavity.

They operate while the door is closed. When using power grill modes the two side

heating-elements will move in horizontal position automatically. When using power grill

function all three elements will heat up and the food will be browned from top-side and

bottom-side. The advantage of power grill function is that you do not have to turnover

food (see power grill Guide).

Preheating the grill elements for 3 minutes will make the food brown more quickly.

Cookware for grilling:

Should be flameproof and may include metal. Do not use any type of plastic cookware,

as it can melt.

Food suitable for grilling:

Chicken pieces, chops, sausages, steaks, hamburgers, bacon and gammon rashers,

thin fish portions, sandwiches and all kinds of toast with toppings.

Important remark:

Whenever the power grill function is used, make sure that the side-grill-heating

elements are able to move in horizontal position.

Please remember that food must be placed on the rack or tray, insert it on the high

stage, between the upper heating-element and the two movable heating-elements

below

MICROWAVE+POWERGRILL

This cooking mode combines the radiant heat that is coming from the grill with the

speed of microwave cooking. It operates only while the door is closed. Due to the food

is placed on high stage on rack, the food browns on top side and bottom side. You do

not need to turnover the food. Three combination modes with Power Grill are available

with this model:

600 W + Power Grill, 450 W + Power Grill and 300 W + Power Grill.

Important remark:

Whenever the combination mode (microwave + power grill) is used, make sure that the

movable heating-elements can move in horizontal position automatically. The food

should be placed on the rack, unless another instruction is recommended. Please refer

to the instructions in the following chart.

TOP GRILL

The upper heater can be used without lower heaters if you want to brown top side of

food (see Grill Guide for Top Grill).

The food should be placed on the rack and can be inserted on the high stage or

low stage, unless another instruction is recommended.

MICROWAVE + TOP GRILL

This cooking mode combines the radiant heat that is coming from the Top grill with the

speed of microwave cooking. It operates only while the door is closed. Three

combination modes with Top Grill are available with this model:

600 W + Top Grill, 450 W + Top Grill and 300 W + Top Grill.

Important remark:

Whenever the combination mode (microwave +Top grill) is used, make sure that the

side heaters are placed at the side of cavity in vertical position. The food should be

placed on the rack, inserted on high or low stage, unless another instruction is

recommended.

Cookware for cooking with microwave + grill

Please use cookware that microwaves can pass through. Cookware should be

flameproof. Do not use metal cookware with combination mode. Do not use any type of

plastic cookware, as it can melt.

Food suitable for microwave + grill cooking:

Food suitable for combination mode cooking include all kinds of cooked food which

need heating and browning (e.g. baked pasta), as well as foods which require a short

cooking time to brown the top of the food. Also, the power grill modes can be used for

food portions that benefit from a browned and crispy top side and bottom side (e.g.

chicken pieces). Please refer to the grill charts for further details.

wnZYXWohjvUGGwGY^GGmSGtGX[SGYWWZGGXXaZWGht

Cooking Guide (continued)

Power Grill Guide for toasts, pastries and vegetables

Use the Power levels and times in this table as guide lines for grilling.

Use oven gloves while taking food out. Do not touch the hot heaters directly after

grilling keep care while they are moving.

Food Portion Preheating

Time(min.)

Power Grill

Power Time

(min.) Instructions

Toast Slices 4-6 pcs - Power

Grill

only

5-7 Put toast slices side by side

inthemiddleonrack.Insert

rack in high stage.

Tomato-

Cheese-Toast 2pcs

(250 g) -300 W +

Power

Grill

3-4 Take a slice of toast bread

and put a slice of ham,

tomato, cheese on top of

each toast slice. Put toasts

on rack and insert in high

stage.

Toast Hawaii

(ham,

pineapple,

cheese slices)

4pcs

(500 g) -300W+

Power

Grill

5½-

6½Put the toasts with topping

(ham, pinapple, cheese

slice) side by side in the

middle on the rack. Insert

rack in high stage.

After cooking stand 2 min.

Puff Pastry

(fruit filling) 300 g

(4pcs) -Power

Grill

only

5-7 Fill fresh puff pastry with

e.g. apricots.

Put 4 filled pastries side by

side on baking paper on the

tray and insert in high stage.

Brush pastries with stirred

egg.

Puff Pastry

(fish filling) 500 g

(8pcs) -Power

Grill

only

6-8 Fill fresh puff pastry with

minced fish and spices. Put

pastries on baking paper in

themiddleontrayandinsert

in high stage. Brush

pastries with stirred egg.

Pancake Rolls

'russian style' 400 g

(6pcs) -Power

Grill

only

5-6 Put the pancake rolls filled

with minced meat (ready

cooked)sidebysideontray.

Insert tray in high stage.

Omelette 250 g - 300 W +

Power

Grill

6-7 Stir 2 eggs, 2 tbsp. milk and

add spices.

Fill into a greased, flat glass

pyrex dish and put some

cheese on top. Put dish on

rack.

Insert rack in high stage

Vegetable

Spits 200 g

(2 spits) 3Power

Grill

only

8-10 Cut vegetables e.g.

courgettes, pepper,

mushroomsintopiecesand

put on a skewer. Put oil and

spice on vegetables and set

spitssidebysideonrack.

Insert rack in high stage.

Baked

Aubergines 300 g 3 Power

Grill

only

8-10 Put 6-8 slices of aubergines

on the preheated tray.

Put topping of minced

tomatoes, sour cream,

spices and grated cheese

on top.

Insert rack in high stage.

Baked

Potatoes 500 g 3600W +

Power

Grill

6-8 Put the potatoes (4-5 pcs) in

themiddleonrack.Insert

rack in high stage.

Frozen Pizza 300-

400g -450W+

Power

Grill

6-8 Put the pizza on rack and

insert rack in high stage.

Food Portion Preheating

Time(min.)

Power Grill

Power Time

(min.) Instructions

wnZYXWohjvUGGwGY_GGmSGtGX[SGYWWZGGXXaZWGht

Cooking Guide (continued)

Power Grill Guide for meat, poultry and fish

Use the Power levels and times in this table as guide lines for grilling.

Use oven gloves while taking out food. Do not touch the hot heaters directly after

grilling, keep care while they are moving.

Fresh Food Portion Preheating

Time(min.)

Power Grill

Power Time

(min.) Instructions

Beef Steaks

(medium) 300-400g

(4 pcs) 3Power

Grill only 11-12 Brush beef steaks or lamb

steaks with oil and spices.

Put them side by side on

the rack.

Insert rack in high stage

thay in low stage.

Kebab Spits/

Shashlik Spits 600 g

(4-6 pcs) 3300 W +

Power

Grill

8-10 Put fresh meat cubes of

pork, beef, or lamb with

pieces of vegetables and

spices on skewer. Do not

marinate meat in vinegar.

Put the ready prepared

kebab spits side by side

on rack. Insert rack in high

stage, tray in low stage.

Chicken Kebab

‘chineese style’400 g

(4-5 pcs) 3Power

Grill

only

9-11 Put fresh meat cubes of

chicken on skewer.

Coat them with mixture of

soy sauce, starch, oil and

garlic. Put the ready

prepared kebab spits side

by on preheated tray.

Insert tray in high stage.

Minced Meat

Rolls on Spits 300 g

(2 pcs) 3Power

Grill

only

6-8 Prepare minced meat, add

herbs and spices. Put it

on two wooden spits and

set on preheated tray.

Insert tray in high stage.

Stand for 1-2 minutes after

grilling.

Chicken Pieces 400-500g - 300 W +

Power

Grill

11-13 Brush chicken pieces with

oil and spices.

Put them opposite to each

other in the middle on

rack. Insert rack in high

stage, tray in low stage.

Stand for 2-3 minutes.

Chicken Breast

Fillets 400 g

(2 pcs) -300 W +

Power

Grill

9-11 Marinate fillets of chicken

breast or turkey breast

and put side by side in the

middle on rack. Insert rack

in high stage, tray in low

stage.

Roast Fish 300 g

(1 fish)

600 g

(2 fishes)

-300W+

Power

Grill

7-8

11-13

Brushskinofe.g.troutor

dorade with oil and salt.

Add herbs and spices

inside of fish. Put fishes

side by side, head to tail

on rack. Insert rack in

high stage, tray in low

stage. Stand for 2-3

minutes after grilling.

Salmon Fillets 400-500g

(2 pcs) -300 W +

Power

Grill

11-12 Put fish fillet in the centre

on rack. Put rack in high

stage, tray in low stage.

Stand for 2-3 min. after

grilling.

Fresh Food Portion Preheating

Time(min.)

Power Grill

Power Time

(min.) Instructions

wnZYXWohjvUGGwGY`GGmSGtGX[SGYWWZGGXXaZWGht

Cooking Guide (continued)

Grill Guide for Top Grill

Preheat the Top grill with the only-grill-function for 3 minutes.

Use the power levels and times in this table as guide lines for grilling.

SPECIAL HINTS

MELTING BUTTER

Put 50 g butter into a small deep glass dish. Cover with plastic lid.

Heat for 30-40 seconds using 900 W, until butter is melted.

MELTING CHOCOLATE

Put100gchocolateintoasmalldeepglassdish.

Heat for 3-5 minutes, using 450 W until chocolate is melted.

Stir once or twice during melting. Use oven gloves while taking out!

MELTING CRYSTALLIZED HONEY

Put 20 g crystallized honey into a small deep glass dish.

Heat for 20-30 seconds using 300 W, until honey is melted.

MELTING GELATINE

Lay dry gelatine sheets (10 g) for 5 minutes into cold water.

Put drained gelatine into a small glass pyrex bowl.

Heat for 1 minute using 300 W.

Stir after melting.

COOKING GLAZE/ICING (FOR CAKE AND GATEAUX)

Mix instant glaze (approximately 14 g) with 40 g sugar and 250 ml cold water.

Cook uncovered in a glass pyrex bowl for 3 ½to4½minutes using 900 W,

until glaze/icing is transparent. Stir twice during cooking.

COOKING JAM

Put 600 g fruits (for example mixed berries) in a suitable sized glass

pyrex bowl with lid. Add 300 g preserving sugar and stir well.

Cook covered for 10-12 minutes using 900 W.

Stir several times during cooking. Empty directly into small jam

glasses with twist-off lids. Stand on lid for 5 minutes.

COOKING PUDDING

Mix pudding powder with sugar and milk (500 ml) by following the

manufacturers instructions and stir well. Use a suitable sized glass pyrex

bowl with lid. Cook covered for 6 ½to7½minutes using 900 W.

Stir several times well during cooking.

BROWNING ALMOND SLICES

Spread 30 g sliced almonds evenly on a medium sized ceramic plate.

Stir several times during browning for 3 ½to4½minutes using 600 W.

Let it stand for 2-3 minutes in the oven. Use oven gloves while taking out!

Food Portion Power 1. Side

Time

(min.)

2. Side

Time

(min.)

Instructions

Grilled

Tomatoes 200 g

(2pcs) 300 W +

Grill 3-4 --- Cut tomatoes into halves. Put

some cheese on top. Arrange

inacircleinaflatglasspyrex

dish. Place it on rack an insert

on high stage.

Stand for 2-3 minutes.

Baked

Apples 3 apple

(ca.400g)

6apples

(ca.800g)

300 W +

Grill 7-8

13-15

---- Core the apples and fill them

with raisins and jam. Put

some almond slices on top.

Put apples on a flat glass

pyrex dish. Place the dish

directly on the turntable.

Stand for 2-3 min after

cooking.

Fresh

Gratin

(Chilled)

450-500 g 600 W +

Grill 10-12 --- Put the fresh pasta gratin into

a small glass pyrex dish. Put

thedishontheturntable.

After cooking stand for 2-3

min.

wnZYXWohjvUGGwGZWGGmSGtGX[SGYWWZGGXXaZWGht

Cleaning Your Microwave Oven

The following parts of your microwave oven should be cleaned

regularly to prevent grease and food particles from building up:

• Inside and outside surfaces

• Door and door seals

• Turntable and Roller rings

☛ALWAYS ensure that the door seals are clean and the door closes

properly.

1. Clean the outside surfaces with a soft cloth and warm, soapy water. Rinse and

dry.

2. Remove any splashes or stains on the inside surfaces or on the roller ring with

a soapy cloth. Rinse and dry.

3. To loosen hardened food particles and remove smells, place a cup of diluted

lemon juice on the turntable and heat for ten minutes at maximum power.

4. Wash the dishwasher-safe plate whenever necessary.

✉DO NOT spill water in the vents. NEVER use any abrasive products

or chemical solvents. Take particular care when cleaning the door

seals to ensure that no particles:

•Accumulate

•Prevent the door from closing correctly

✉Clean the microwave oven cavity right ofter each use with a mild

detergent solution, but let the microwave oven cool down before

cleaning in order to avoid injury.

Storing and Repairing Your Microwave Oven

A few simple precautions should be taken when storing or having your

microwave oven serviced.

The oven must not be used if the door or door seals are damaged:

• Broken hinge

• Deteriorated seals

• Distorted or bent oven casing

Only a qualified microwave service technician should perform repair.

☛NEVER remove the outer casing from the oven. If the oven is faulty

and needs servicing or you are in doubt about its condition:

•Unplug it from the wall socket

•Contact the nearest after-sales service centre

✉If you wish to store your oven away temporarily, choose a dry, dust-

free place.

Reason:Dust and damp may adversely affect the working parts in the

oven.

✉This microwave oven is not intended for commercial use.

wnZYXWohjvUGGwGZXGGmSGtGX[SGYWWZGGXXaZWGht

Technical Specifications

SAMSUNG strives to improve its products at all times. Both the design

specifications and these user instructions are thus subject to change

without notice.

Note

Model PG3210

Power source

230V ~ 50 Hz

Power consumption

Maximum power

Microwave

Top Grill

Power Grill

3250 W

1400 W

900 W

1850 W

Output power

100 W / 900 W (IEC-705)

Operating frequency

2450 MHz

Magnetron

OM75P(31)

Cooling method

Cooling fan motor

Dimensions

(WxHxD)

Outside

Oven cavity

529 x 350 x 481 mm

344 x 240 x 345 mm

Volume

30 liter

Weight

Net

21 kg approx

wnZYXWohjvUGGwGZYGGmSGtGX[SGYWWZGGXXaZWGht

Note

wnZYXWohjvUGGwGZZGGmSGtGX[SGYWWZGGXXaZWGht

Note

wnZYXWohjvUGGwGZ[GGmSGtGX[SGYWWZGGXXaZWGht

Note

wnZYXWohjvUGGwGZ\GGmSGtGX[SGYWWZGGXXaZWGht

wnZYXWohjvUGGwGZ]GGmSGtGX[SGYWWZGGXXaZWGht

Samsung PG3210 20030401084205281 HACO

Navigation menu

Versions of this User Manual:

Views

Navigation
