User Manual: Samsung CE2714 Samsung CE2714 user manual - Introduction (ver.1.0) - COMMON (AUSTRIA, BULGARIA, CHILE, UNITED KINGDOM, CROATIA, SLOVENIA)

Open the PDF directly: View PDF PDF.
Page Count: 36

Code No.: DE68-01790D
MICROWAVE OVEN
Owner’s Instructions & Cooking Guide
CE2774N / CE2774NT
CE2714N / CE2714NT
Quick Look-up Guide..............................................................................2
Oven...................................................................................................... 4
Accessories ........................................................................................... 4
Control Panel..........................................................................................5
Using this Instruction Booklet.................................................................6
Safety Precautions .................................................................................7
Installing Your Microwave Oven............................................................ 8
Setting the Time (CE2774N/CE2774NT) .............................................. 8
How a Microwave Oven Work............................................................... 9
Checking that Your Oven is Operating Correctly .................................. 9
What to Do if You are in Doubt or Have a Problem ............................ 10
Cooking / Reheating............................................................................ 10
Power Levels....................................................................................... 11
Stopping the Cooking.......................................................................... 12
Adjusting the Cooking Time ................................................................ 12
Using the Auto Reheat/Cook Feature (CE2774N/CE2774NT) ........... 13
Auto Reheat / Cook Settings(CE2774N/CE2774NT).......................... 13
Using the Instant Reheat/Cook Feature (CE2714N/CE2714NT)........ 14
Instant Reheat/Cook Setting(CE2714N/CE2714NT) .......................... 14
Using the Auto Defrost Feature (CE2774N/CE2774NT)..................... 15
Auto Defrost Settings(CE2774N/CE2774NT) ..................................... 15
Manual Defrosting Food(CE2714N/CE2714NT)................................. 16
Using the Crusty Plate (CE2774NT/CE2714NT) ................................ 16
Crusty Plate Setting (CE2774NT/CE2714NT) .....................................17
Choosing the Heating Element Position.............................................. 18
Choosing the Accessories................................................................... 18
Grilling ..................................................................................................19
Combining Microwaves and the Grill....................................................20
Switching the Beeper Off (CE2774N/CE2774NT) .............................. 21
Safety-Locking Your Microwave Oven (CE2774N/CE2774NT)...........21
Remembering Function (CE2774N/CE2774NT)................................. 21
Cookware Guide...................................................................................22
Cooking Guide......................................................................................23
Cleaning Your Microwave Oven.......................................................... 30
Storing and Repairing Your Microwave Oven..................................... 31
Technical Specification........................................................................ 31
CE2774-BOL.fm Page 1 Tuesday, July 10, 2001 6:01 PM
2
GB
Quick Look-up Guide
Model : CE2774N/CE2774NT
If you want to cook some food
If you want to defrost some food
If you want to add an extra minute
If you want to grill some food
✉Check that the heating element is in the horizontal position.
1. Place the food in the oven.
Turn the Cooking Control knob to Manual Cook()
symbol.
Select the power level by pressing the button once or
more times.
2. Select the cooking time by turning the dial knob as
required.
3. Press the button.
Result: Cooking starts.
The oven beeps four times when cooking is
over.
1. Place the frozen food in the oven.
Turn the Cooking Control knob to Manual Cook()
symbol.
Select the defrost( , , ) by turning the cooking
control knob.
2. Select the cooking time by turning the dial knob as
required.
3. Press the button.
Leave the food in the oven.
Turn the Cooking Control knob to Manual Cook()
symbol. Press +30s once or more times for each extra 30
seconds that you wish to add.
1. Place the food in the oven.
Turn the Cooking Control knob to Manual Cook()
symbol.
2. Press the button.
3. Select the cooking time by turning the dial knob.
4. Press the button.
CE2774-BOL.fm Page 2 Tuesday, July 10, 2001 6:01 PM
3
GB
Quick Look-up Guide(Continued)
Model : CE2714N/CE2714NT
If you want to cook some food
If you want to defrost some food
If you want to adjust the cooking time
If you want to grill some food
1. Place the food in the oven.
Select the power level by rotating the COOKING POWER
CONTROL knob.
2. Select the cooking time by rotating the TIMER knob.
1. Turn the COOKING POWER CONTROL knob to defrost
( ) symbol.
2. Turn the TIMER knob to select the appropriate time.
Leave the food in the oven.
Turn the TIMER knob to desired time.
1. Turn the COOKING POWER CONTROL knob to
Grill( ) symbol.
2. Turn the TIMER knob to select the appropriate time.
CE2774-BOL.fm Page 3 Tuesday, July 10, 2001 6:01 PM
4
GB
Oven
Model : CE2774N/CE2774NT
Model : CE2714N/CE2714NT
Accessories
Depending on the model that you have purchased, you are supplied
with several accessories that can be used in a variety of ways.
☛DO NOT operate the microwave oven without the roller ring and
turntable.
VENTILATION HOLES
DOOR LATCHES
DOOR
TURNTABLE
COUPLER
ROLLERRING
SAFETY INTERLOCK
HOLES
LIGHT
HANDLE DISPLAY
CONTROL PANEL
GRILL
VENTILATION HOLES
DOOR LATCHES
DOOR
TURNTABLE
COUPLER
ROLLERRING
SAFETY INTERLOCK
HOLES
LIGHT
HANDLE
VARIABLE
COOKING POWER
CONTROL KNOB
GRILL
TIMER KNOB
1. Coupler, already placed over the motor shaft in the base
of the oven.
Purpose: The coupler rotates the turntable.
2. Roller ring,tobeplacedinthecentreoftheoven.
Purpose: The roller ring supports the turntable.
3. Turntable, to be placed on the roller ring with the centre
fitting to the coupler.
Purpose: The turntable serves as the main cooking
surface; it can be easily removed for cleaning.
4. Metal rack,tobeplacedontheturntable.
Purpose: Themetalrackcanbeusedingrilland
combination cooking.
5. Crusty plate(CE2774NT/CE2714NT only), see page 16.
Purpose: The crusty plate is used to brown food better in
the microwave or grill combination cooking
modes. It helps keep pasty and pizza dough
crisp.
CE2774-BOL.fm Page 4 Tuesday, July 10, 2001 6:01 PM
5
GB
Control Panel
Model : CE2774N/CE2774NT Model : CE2714N/CE2714NT
1. AUTO DEFROST SELECTION
2. MANUAL COOK SELECTION
3. AUTO REHEAT SELECTION
4. AUTO COOK SELECTION
5. COOKING CONTROL KNOB
6. DISPLAY
7. MICROWAVE/POWER LEVEL
MODE SELECTION
8. COMBI MODE SELECTION
9. GRILL MODE SELECTION
10. CLOCK SETTING
11. STOP/CANCEL BUTTON
12. START BUTTON/DIAL KNOB
(cook time, weight and serving
size)
1
9
3
11
7
8
12
10
4
2
5
6
1. DEFROST
2. TIMER KNOB
3. VARIABLE COOKING
POWER CONTROL KNOB
4. INSTANT REHEAT
4
1
2
3
CE2774-BOL.fm Page 5 Tuesday, July 10, 2001 6:01 PM
6
GB
Using this Instruction Booklet
You have just purchased a SAMSUNG microwave oven. Your Owner’s
Instructions contain much valuable information on cooking with your
microwave oven:
• Safety precautions
• Suitable accessories and cookware
• Useful cooking tips
Inside the cover you will find a quick look-up guide explaining four
basic cooking operations:
• Cooking food
• Defrosting food
• Grilling food
• Adding extra cooking time
At the front of the booklet you will find illustrations of the oven, and
more importantly the control panel, so that you can find the buttons
more easily.
The step-by-step procedures use four different symbols.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY
Failure to observe the following safety precautions may result in harmful
exposure to microwave energy.
(a) Under no circumstances should any attempt be made to operate the oven with
the door open or to tamper with the safety interlocks (door latches) or to insert
anything into the safety interlock holes.
(b) Do not place any object between the oven door and front face or allow food or
cleaner residues to accumulate on sealing surfaces. Ensure that the door and
door sealing surfaces are kept clean by wiping after use first with a damp cloth
and then with a soft dry cloth.
(c) Do not operate the oven if it is damaged until it has been repaired by a
qualified microwave service technician trained by the manufacturer.
It is particularly important that the oven door closes properly and that there is
no damage to the:
(1) Door, door seals and sealing surfaces
(2) Door hinges (broken or loose)
(3) Power cable
(d) The oven should not be adjusted or repaired by anyone other than a properly
qualified microwave service technician trained by the manufacturer.
☛✉ ❉
Important Note Caution Turn
CE2774-BOL.fm Page 6 Tuesday, July 10, 2001 6:01 PM
7
GB
Safety Precautions
Important Safety Instructions.
Read Carefully and keep for future reference.
Before cooking food or liquids in your microwave oven, please check
that the following safety precautions are taken.
1. DO NOT use any metallic cookware in the microwave oven:
• Metallic containers
• Dinnerware with gold or silver trimmings
• Skewers, forks, etc.
Reason: Electric arcing or sparking may occur and may damage the oven.
2. DO NOT heat:
• Airtight or vacuum-sealed bottles, jars, containers.
Ex) Baby food jars
• Airtight food.
Ex) Eggs, nuts in shells, tomatoes
Reason: The increase in pressure may cause them to explode.
Tip: Remove lids and pierce skins, bags, etc.
3. DO NOT operate the microwave oven when it is empty.
Reason: Theovenwallsmaybedamaged.
Tip: Leave a glass of water inside the oven at all times.
The water will absorb the microwaves if you accidentally set the
oven going when it is empty.
4. DO NOT cover the rear ventilation slots with cloths or paper.
Reason: The cloths or paper may catch fire as hot air is evacuated from the
oven.
5. ALWAYS useovengloveswhenremovingadishfromtheoven.
Reason: Some dishes absorb microwaves and heat is always transferred
from the food to the dish.The dishes are therefore hot.
6. DO NOT touch heating elements or interior oven walls.
Reason: These walls may be hot enough to burn even after cooking has
finished, even though they do not appear to be so. Do not allow
inflammable materials to come into contact with any interior area of
the oven. Let the oven cool down first.
7. Toreducetheriskoffireintheovencavity:
• Do not store flammable materials in the oven
• Remove wire twist ties from paper or plastic bags
• Do not use your microwave oven to dry newspapers
• If smoke is observed, keep the oven door closed and switch off or
disconnect the oven from the power supply
8. Take particular care when heating liquids and baby foods.
• ALWAYS allow a standing time of at least 20 seconds after the oven has
been switched off so that the temperature can equalize.
• Stir during heating, if necessary, and ALWAYS stir after heating.
• Take care when handling the container after heating. You may burn
yourself if the container is too hot.
• A risk of delayed eruptive boiling exists.
• To prevent delayed boiling and possible scalding, you should put a plastic
spoon or glass stick into the beverages and stir before, during and after
heating.
Reason: During the heating of liquids the boiling point can be delayed;
this means that eruptive boiling can start after the container is
removed from the oven. You may scald yourself.
• In the event of scalding, follow these FIRST AID instructions:
* Immerse the scalded area in cold water for at least 10 minutes.
* Cover with a clean, dry dressing.
* Do not apply any creams, oils or lotions.
•NEVER fill the container to the top and choose a container that is wider at
the top than at the bottom to prevent the liquid from boiling over. Bottles
with narrow necks may also explode if overheated.
•ALWAYS check the temperature of baby food or milk before giving it to
the baby.
•NEVER heat a baby’s bottle with the teat on, as the bottle may explode if
overheated.
9. Be careful not to damage the power cable.
• Do not immerse the power cable or plug in water and keep the power
cableawayfromheatedsurfaces.
• Do not operate this appliance if it has a damaged power cable or plug.
10. Stand at arm’s length from the oven when opening the door.
Reason: The hot air or steam released may cause scalding.
11. Keep the inside of the oven clean.
Reason: Food particles or spattered oils stuck to oven walls or floor can
cause paint damage and reduce the efficiency of the oven.
12. You may notice a “Clicking” sound during operation(especially when the oven
is in defrosting).
Reason:This sound is normal when the electrical power output is changing.
13. When the microwave oven is operating without any load, the power will be cut
off automatically for safety. You can operate the oven normally after letting it
stand for over 30 minutes.
IMPORTANT SAFETY INSTRUCTIONS
During cooking, you should look into the oven from time to time when food is
being heated or cooked in disposable containers of plastic, paper or other
combustible materials.
IMPORTANT
Young children should NEVER be allowed to use or play with the microwave
oven. Nor should they be left unattended near the microwave oven when it is in
use. Items of interest to children should not be stored or hidden just above the
oven.
CE2774-BOL.fm Page 7 Tuesday, July 10, 2001 6:01 PM
8
GB
Installing Your Microwave Oven
Place the oven on a flat, level surface that strong enough to safely bear
the weight of the oven.
❉Never block the air vents as the oven may overheat and automatically
switch itself off. It will remain inoperable until it has cooled sufficiently.
❉For your personal safety, plug the cable into a 3-pin, 230 Volt, 50Hz,
AC earthed socket. If the power cable of this appliance is damaged, it
must be replaced by the manufacturer or its service agent or a
similarly qualified person in order to avoid a hazard.
❉Do not install the microwave oven in hot or damp surroundings like
next to a traditional oven or radiator. The power supply specifications
of the oven must be respected and any extension cable used must be
of the same standard as the power cable supplied with the oven. Wipe
the interior and the door seal with a damp cloth before using your
microwave oven for the first time.
Setting the Time (CE2774N/CE2774NT)
Your microwave oven has an inbuilt clock. The time can be displayed
in either the 24-hour or 12-hour notation. You must set the clock:
• When you first install your microwave oven
• After a power failure
✉Do not forget to reset the clock when you switch to and from summer
and winter time.
1. When you install your oven, make sure there is adequate
ventilation for your oven by leaving at least 10 cm (4
inches) of space behind, and on the sides of the oven
and 20 cm (8 inches) of space above the oven and 85 cm
(33 inches) of the floor.
2. Remove all packing materials inside the oven.
Install the roller ring and turntable.
Check that the turntable rotates freely.
3. This microwave oven has to be positioned so that plug is
accessible.
20 cm
above 10 cm
behind
10 cm
on the side
85 cm of
the floor
1. To display the Then press the
time in the.. button( )..
24-hour notation Once
12-hour notation Twice
2. Turn the dial knob to set hour.
3. Press the button.
4. Turn the dial knob to set minute.
5. Press the button.
CE2774-BOL.fm Page 8 Tuesday, July 10, 2001 6:01 PM
9
GB
How a Microwave Oven Work
Microwaves are high-frequency electromagnetic waves; the energy
released enables food to be cooked or reheated without changing
either the form or the colour.
You can use your microwave oven to:
• Defrost
• Auto Reheat/Cook
•Cook
Cooking Principle
☛As the centre of the food is cooked by heat dissipation, cooking
continues even when you have taken the food out of the oven.
Standing times specified in recipes and in this booklet must therefore
be respected to ensure:
• Even cooking of the food right to the centre
• The same temperature throughout the food
Checking that Your Oven is Operating Correctly
The following simple procedure enables you to check that your oven is
working correctly at all times.
Open the oven door by pulling on the handle on the right side of the
door. Place a glass of water on the turntable. Then, close the door.
Model : CE2774N/CE2774NT
Model : CE2714N/CE2714NT
✉The oven must be plugged into an appropriate wall socket. The
turntable must be in position in the oven. If a power level other than
the maximum is used, the water takes longer to boil.
1. The microwaves generated by the magnetron are
distributed uniformly as the food rotates on the
turntable. The food is thus cooked evenly.
2. Themicrowavesareabsorbedbythefooduptoa
depth of about 1 inch (2.5 cm). Cooking then
continues as the heat is dissipated within the food.
3. Cooking times vary according to the recipient used
and the properties of the food:
• Quantity and density
• Water content
• Initial temperature (refrigerated or not)
1. Turn the Cooking Control knob to Manual Cook()
symbol.
2. Press the button.
3. Set the time to 4-5 minutes by turning the dial knob as
requried.
4. Press button.
Result: Theovenheatsthewaterfor4to5minutes.
The water should then be boiling.
1. Set the power level to maximum by turning COOKING
POWER CONTROL knob.
2. Set the time 4 to 5 minutes by turning the TIMER knob.
CE2774-BOL.fm Page 9 Tuesday, July 10, 2001 6:01 PM
10
GB
What to Do if You are in Doubt or Have a
Problem
If you have any of the problems listed below, try the solutions given.
◆This is normal.
• Condensation inside the oven
• Air flow around the door and outer casing
• Light reflection around the door and outer casing
• Steam escaping from around the door or vents
◆The oven does not start when you press the button(CE2774N/CE2774NT).
• Is the door completely closed?
◆TheovendoesnotstartwhenyouturntheTIMER knob
(CE2714N/CE2714NT).
• Is the door completely closed?
◆The food is not cooked at all
• Have you set the timer correctly and/or pressed the button?
(CE2774N/CE2774NT)
• Have you set the timer correctly? (CE2714N/CE2714NT)
• Is the door closed?
• Have you overloaded the electric circuit and caused a fuse to blow or a
breaker to be triggered?
◆The food is either overcooked or undercooked
• Was the appropriate cooking length set for the type of food?
• Was an appropriate power level chosen?
◆Sparking and cracking occur inside the oven (arcing)
• Have you used a dish with metal trimmings?
• Have you left a fork or other metal utensil inside the oven?
• Is aluminium foil too close to the inside walls?
◆The oven causes interference with radios or televisions
• Slight interference may be observed on televisions or radios when the
oven is operating. This is normal.To solve this problem, install the oven
away from televisions, radios and aerials.
• If interference is detected by the oven’s microprocessor, the display may
be reset.To solve this problem, disconnect the power plug and reconnect
it. Reset the time.(CE2774N/CE2774NT)
✉If the above guidelines do not enable you to solve the problem,
contact your local dealer or SAMSUNG after-sales service.
Cooking / Reheating
The following procedure explains how to cook or reheat food.
ALWAYS check your cooking settings before leaving the oven
unattended.
First, place the food in the centre of the turntable. Close the door .
Model : CE2774N/CE2774NT
☛Never switch the microwave oven on when it is empty.
✉If you wish to heat a dish for a short period of time at maximum
power(850W), simply press the +30s button once for each 30
seconds of cooking time. The oven starts immediately.
1. Turn the Cooking Control knob to Manual Cook()
symbol.
2. Press the button.
Result: The 850W (maximum cooking power)
indications are displayed:
Select the appropriate power level by pressing
the button again until the corresponding
wattage is displayed. Refer to the power level
table on the next page.
3. Set the cooking time by turning the dial knob.
4. Press the button.
Result: The oven light comes on and the turntable starts
rotating.
1) Cooking starts and when it has finished the
oven beeps four times.
2) The end reminder signal will beep 3 times
(once every minute).
3) The current time is displayed again.
CE2774-BOL.fm Page 10 Tuesday, July 10, 2001 6:01 PM
11
GB
Cooking / Reheating(Cautinued)
Model : CE2714N/CE2714NT
☛Never switch the microwave oven on when it is empty.
✉You can change the power level during cooking by turning the
COOKING POWER CONTROL knob.
Power Levels
You can choose among the power levels below.
✉If you select higher power level, the cooking time must be decreased.
✉If you select lower power level, the cooking time must be increased.
If you want to add the cooking time by turning dial knob.
(CE2774N/CE2774NT)
1. Set the power level to maximum by turning COOKING
POWER CONTROL knob.
(MAXIMUM POWER : 850 W)
2. Set the time by turning TIMER knob.
Result: The oven light comes on and the turntable starts
rotating.
Power Level Output
CE2714N/CE2714NT CE2774N/CE2774NT
MWO GRILL MWO GRILL
HIGH
REHEAT
MEDIUM HIGH
MEDIUM
MEDIUM LOW
DEFROST( )
LOW/KEEP WARM
GRILL
COMBI I
COMBI II
COMBI III
850 W
700 W
600 W
450 W
300 W
180 W
100 W
-
300 W( )
450 W( )
600 W( )
1100 W
1100 W
1100 W
1100 W
850 W
-
600 W
450 W
300 W
180 W
100 W
-
600 W
450 W
300 W
1100 W
1100 W
1100 W
1100 W
Time Increasing Time Time Increasing Time
upto1min
1-3min
3-10min
5 sec. unit
10 sec. unit
30 sec. unit
10 - 20 min
20 - 40 min
40 - 99 min
1 min unit
2 min unit
5 min unit
CE2774-BOL.fm Page 11 Tuesday, July 10, 2001 6:01 PM
12
GB
Stopping the Cooking
You can stop cooking at any time to check the food.
Model : CE2774N/CE2774NT
☛You can also cancel any setting before starting by simply pressing
Cancel .
Model : CE2714N/CE2714NT
Adjusting the Cooking Time
Model : CE2774N/CE2774NT
You can increase the cooking time by pressing the +30s button once
for each 30 seconds to be added.
✉You can only adjust the time during cooking when the microwave,
Auto reheat/cook, Gill and Combi modes are selected.
Model : CE2714N/CE2714NT
1. To stop temporarily;
Open the door.
Result: Cooking stops. To resume cooking, close the
door and press again.
2. To stop completely;
Press the button.
Result: The cooking stops.
If you wish to cancel the cooking settings, press
the Cancel( ) button again.
1. To stop temporarily;
Open the door.
Result: Cooking stops. To resume cooking, close the
door.
2. To stop completely;
Turn the TIMER knob to “0”.
Press the +30s button once for each 30 seconds to be added.
During the cooking to increase or decrease the cooking time
of your food, turn the dial knob right or left.
Adjust the remaining cooking time by rotating the TIMER
knob.
CE2774-BOL.fm Page 12 Tuesday, July 10, 2001 6:01 PM
13
GB
Using the Auto Reheat/Cook Feature
(CE2774N/CE2774NT)
The Auto Reheat/Cook feature has six pre-programmed cooking time,
you do not need to set either the cooking time or power level. You can
adjust the number of servings by turning the dial knob.
First, place the food in the centre of the turntable and close the door.
✉Use only recipients that are microwave-safe.
Auto Reheat / Cook Settings
(CE2774N/CE2774NT)
The following table presents the various Instant Reheat & Cook
Programmes, quantities, standing times and appropriate
recommendations.
1. Turn the Cooking Control knob to Auto Reheat/Cook
( , , , )symbol.
2. Select the size of the serving by turning the dial knob.
(Refer to the table on the opposite page for further details)
3. Press button.
Result: Cooking starts. When it has finished:
1) The oven beeps four times.
2) The end reminder signal will beep 3 times
(once every minute).
3) The current time is displayed again.
Symbol Button Serving Type Portion Standing
Time Recommendations
Ready Meal
(Chilled)
300-350 g 3 mins Put on a ceramic plate and
cover with microwave cling
film. This programme is
suitable for meals
consisting of 3
components (e.g. meat
with sauce, vegetables and
asidedishlikepotatoes,
rice or pasta).
Drinks
(Coffee, milk,
tea, water with
room
temperature)
150 ml
(1 cup)
250 ml
(1 mug)
1-2 mins Pour in to a ceramic cup
and reheat uncovered.
Place cup (150ml) or mug
(250ml) in the centre of
turntable, Stir carefully
before and after standing
time.
Pasta Gratin
(frozen) 200 g
400 g 2-3 mins
Put the frozen pasta gratin
into a suitable size glass
pyrex dish. Put the dish on
the rack. This programme is
suitable for frozen pasta
gratin such as lasagne,
cannelloni or macaroni.
Mini-Quiches/
Mini-Pizzas
(frozen)
150 g
(4-6pcs)
250 g
(7-9pcs)
-
Put the frozen mini-quiches
or mini-pizzas evenly on the
rack
CE2774-BOL.fm Page 13 Tuesday, July 10, 2001 6:01 PM
14
GB
Using the Instant Reheat/Cook Feature
(CE2714N/CE2714NT)
First, place the food in the centre of the turntable and close the door.
✉Use only recipients that are microwave-safe.
Instant Reheat/Cook Setting
(CE2714N/CE2714NT)
Here are a few tips and recommendations to be followed when cooking
or reheating food with the Instant Reheat and Cook Feature.
1. Turn the COOKING POWER CONTROL knob to Max.
Power.
2. Turn the TIMER knob to select Instant Reheat.
(drinks, soup/sauce or fresh vegetables).
Symbol Serving Type Power Portion Cooking Time Standing
Time
Drinks 850W 150ml 1min15sec 1-2mins
Soup/Sauce
(chilled) 850 W 200-250 ml 2 min 50 sec 2-3 mins
Fresh
vegetables 850 W 300-350 g 5 min 30 sec 3 mins
CE2774-BOL.fm Page 14 Tuesday, July 10, 2001 6:01 PM
15
GB
Using the Auto Defrost Feature
(CE2774N/CE2774NT)
The Auto Defrost feature enables you to defrost meat, poultry, fish.
The defrost time and power level are set automatically. You simply
select the programme and the weight.
✉Use only dishes that are microwave-safe.
First, place the frozen food in the centre of the turntable and close the
door.
✉You can also defrost food manually. To do so, select the microwave
cooking/reheating function with a power level of 180W. Refer to the
section entitled “ Cooking/Reheating” on page 10 for further details.
Auto Defrost Settings(CE2774N/CE2774NT)
The following table presents the various Auto Defrost programmes,
quantities, standing times and appropriate recommendations.
Remove all kinds of package material before defrosting. Place meat,
poultry and fish on a turntable.
1. Turn the Cooking Control knob to Defrost(,,
) symbol.
Result: The following indication is displayed:
Turning the Cooking Control knob accordingtothetype
of food to be defrost. Refer to the table on the opposite
page for further details.
2. Select the food weight by turning the dial knob.
3. Press the button.
Result:
◆Defrosting begins.
◆The oven beeps halfway through defrosting
toremindyoutoturnthefoodover.
◆Press again to finish defrosting
Food Portion Standing
Time Recommendation
Meat 200 - 1500 g 20-60mins Shield the edges with aluminium foil.
Turn the meat over when the oven
beeps. This programme is suitable for
beef, lamb, pork, steaks, chops and
minced meat.
Poultry 200 - 1500 g 20-60mins Shield the leg and wing tips with
aluminium foil. Turn the poultry over
when the oven beeps. This programme
is suitable for whole chicken and
chicken portions.
Fish 200 - 1500 g 20-50mins Shield the tail of the whole fish with
aluminium foil. Turn the fish over when
the oven beeps. This programme is
suitable for whole fishes and fish fillets.
CE2774-BOL.fm Page 15 Tuesday, July 10, 2001 6:01 PM
16
GB
Manual Defrosting Food(CE2714N/CE2714NT)
The Defrost feature enables you to defrost meat, poultry, fish.
First, place the frozen food in the centre of the turntable and close the
door.
✉Use only recipients that are microwave-safe.
Using the Crusty Plate (CE2774NT/CE2714NT)
Your Samsung microwave oven has a crusty plate as an additional
accessory. This crusty plate allows you to brown food not only on the
top with the grill, but also the bottom of the food turns crispy and
brown due to the high temperature of the crusty plate. Several items
which you can prepare on the crusty plate can be found in the chart
(see next page).
The crusty plate can also be used for bacon, eggs, sausages, etc.
✉How to clean the Crusty Plate
Clean the crusty plate with warm water and detergent and rinse
off with clean water.
✉Do not use a scrubbing brush or a hard sponge otherwise the top
layer will be damaged.
❉Please Note
The crusty plate is not dishwasher-safe.
1. Turn the COOKING POWER CONTROL knob to .
2. Turn the TIMER knob to select the appropriate time.
Result: Defrosting begins.
1. Place the crusty plate directly on the turntable and preheat
it with highest Microwave-Grill-Combination[600W+Grill
( )] by following the times and instructions in the chart.
☛Alwaysuseovenglovestotakeoutthecrusty
plate, as will become very hot.
2. Brushtheplatewithoilifyouarecookingfood,suchas
bacon and eggs, in order to brown the food nicely.
❉Please note that the crusty plate has a teflon layer
which is not scratch-resistant. Do not use any
sharpobjectslikeaknifetocutonthecrustyplate.
❉Use plastic accessories to avoid scratches on the
surface of the crusty plate or remove the food from
the plate before cutting
3. Place the food on the crusty plate.
☛Do not place any objects on the crusty plate that
are not heat-resistant; e.g. plastic bowels.
☛Never place the crusty plate in the oven without
turntable.
4. Place the crusty plate on the metal rack(or turntable) in the
microwave.
5. Select the appropriate cooking time and power.
Refer to the table on the next page.
CE2774-BOL.fm Page 16 Tuesday, July 10, 2001 6:01 PM
17
GB
Crusty Plate Setting (CE2774NT/CE2714NT)
We recommend to preheat the crust plate directly on the turntable.
Preheat the crusty plate with 600 W + Grill( ) function and follow
the times and instructions in the table.
Food Portion Preheaing
Time Power Cooking
Time Recommendations
Bacon
4Slices
(80g) 3 min 600W+
Grill
()
3-3½ min Preheat crusty plate.
Put slices side by side
on crusty plate. Put
crusty plate on the
rack.
Grilled
Tomatoes
200 g
(2pcs) 3 min 450W+
Grill
()
4-4½ min Preheat crusty plate.
Cut tomatoes in
halves. Put some
cheese on top.
Arrangeinacircleon
crusty plate. Put crusty
plateontherack.
Burger
(frozen)
2pieces
(125g) 3 min 600W+
Grill
()
6½-7 min Preheat crusty plate.
Put frozen burger in a
circle on crusty plate.
Put crusty plate on the
rack.
Turn over after 4- 5
min.
Baguettes
(frozen)
200-250 g
(2pcs) 4 min 450W+
Grill
()
7-8 min Preheat crusty plate.
Put one baguette
beside the centre, 2
baguettes side by side
on the plate. Put crusty
plateonrack.
Pizza
(frozen)
300 - 350 g 4 min 600W+
Grill
()
8-9 min Preheat crusty plate.
Put the frozen pizza on
the crusty plate.
Put crusty plate on the
rack.
Baked
Potatoes
250 g
500 g
3 min 600W+
Grill
()
5-6 min
8-9 min
Preheat crusty plate.
Cut potatoes in halves.
Put them on the crusty
platewiththecutside
to the bottom. Arrange
in a circle. Put the plate
on the rack.
Fish
Fingers
(frozen)
150 g
(5pcs)
300 g
(10 pcs)
4 min 600W+
Grill
()
6½-7 min
9-9½ min
Preheat crusty plate.
Brush plate with 1
tbsp. Put fish fingers in
acircleontheplate.
Turn over after 3½ min
(5 pcs) or after 5 min
(10 pcs).
Chicken
Nuggets
(frozen)
125 g
250 g 4 min 600W+
Grill
()
4½ -5 min
7-7½ min Preheat crusty plate.
Brush plate with 1
tbsp. Put chicken
nuggets on the plate.
Put crusty plate on the
rack.Turnoverafter3
min (125g) or 5 min
(250g).
Pizza
(chilled)
300 - 350 g 4 min 450W+
Grill
()
5½-6½ min Preheat crust plate.
Put the chilled pizza
pieces in a circle on
the plate. Put crust
plate on rack.
CE2774-BOL.fm Page 17 Tuesday, July 10, 2001 6:01 PM
18
GB
Choosing the Heating Element Position
The heating element is used when grilling. It can be placed in one of
two positions:
• Horizontal position for grilling or combined microwave +grill
cooking
☛Only change the position of the heating element when it is cold and do
not apply excessive force when placing it in the vertical position.
Choosing the Accessories
Use microwave-safe recipients; do not use plastic containers, dishes,
paper cups, towels, etc.
✉For further details on suitable cookware and utensils, refer to the
CookwareGuideonpage22.
To set the heating element
to the... Then...
Horizontal position (grill or
combined microwave +
grill)
◆Pull the heating element
towards you
◆Push it upwards until it is
parallel with the oof of the
oven
When cleaning the upper part inside the cavity, it will be
convenient to turn heater downward by 45° and clean it.
If you wish to select the combined cooking mode (grill and
microwave), use only dishes that are microwave-safe and
oven-proof. Metallic cookware or utensils may damage your
oven.
CE2774-BOL.fm Page 18 Tuesday, July 10, 2001 6:01 PM
19
GB
Grilling
The grill enables you to heat and brown food quickly, without using
microwaves. To this aim, a grill rack is supplied with your microwave
oven.
Model : CE2774N/CE2774NT
Model : CE2714N/CE2714NT
✉Do not worry if the heater turns off and on while grilling. This system is
designed to prevent overheating of the oven.
☛Always use oven gloves when touching the dishes in the oven, as
they will be very hot.
Check that the heating element is in the horizontal position.
1. Turn the Cooking Control knob to Manual Cook()
symbol.
2. Preheat the grill to the required temperature, by pressing
the button and set the preheat time by turning the dial
knob.
3. Press the button.
4. Open the door and place the food on the rack.
5. Press the button.
Result: The follwing indications are displayed :
6. Set the Grilling time by turning the dial knob.
The maximum grilling time is 60 minute.
7. Press the button.
Result: Grilling cooking starts. When it has finished.
1) The oven beeps four times.
2) The end reminder signal will beep 3 times
(once every minute).
3) The current time is displayed again.
1. Preheat the grill to the required temperature, by the turning
the cooking power control knob to grill symbol( ) and
turning the timer knob to the appropriate.
2. Open the door and place the food on the rack.
3. Select the appropriate cooking time.
CE2774-BOL.fm Page 19 Tuesday, July 10, 2001 6:01 PM
20
GB
Combining Microwaves and the Grill
You can also combine microwave cooking with the grill, to cook
quickly and brown at the same time.
☛ALWAYS use microwave-safe and oven-proof cookware. Glass or
ceramic dishes are ideal as they allow the microwaves to penetrate
thefoodevenly.
☛ALWAYS use oven gloves when touching the recipients in the oven,
as they will be very hot.
Model : CE2774N/CE2774NT
✉The maximum microwave power for the combined microwave and grill
mode is 600W.
Model : CE2714N/CE2714NT
✉The maximum microwave power for the combined microwave and grill
mode is 600W.
1. Make sure that the heating element is in the horizontal
position; refer to page 18 for further details.
2. Open the oven door. Place the food on the rack and the
rack on the turntable. Close the door.
3. Turn the Cooking Control knob to Manual Cook()
symbol.
4. Press the Combi ( ) button.
Result: The following indications are displayed:
I (one-stage cooking)
(microwave and grill mode)
600W (out power)
✉Select the appropriate power level by pressing the
Combi ( ) button again until the
corresponding power level is displayed.
☛You cannot set the temperature of the grill.
5. Set the cooking time by turning the dial knob.
The maximum grilling time is 60 minute.
6. Press the button.
Result: Combination cooking starts. When it has
finished.
1) The oven beeps four times.
2) The end reminder signal will beep 3 times
(once every minute).
3) The current time is displayed again.
1. Make sure that the heating element is in the horizontal
position; refer to page 18 for further details.
2. Open the oven door. Place the food on the rack and the
rack on the turntable. Close the door.
3. Turn the Cooking Power Control knob to the appropriate
power Level ( , , ).
4. Turn the Timer knob to select the appropriate time.
(Example : 60 minutes)
Result: Cooking starts.
CE2774-BOL.fm Page 20 Tuesday, July 10, 2001 6:01 PM
21
GB
Switching the Beeper Off (CE2774N/CE2774NT)
You can switch the beeper off whenever you want.
Safety-Locking Your Microwave Oven
(CE2774N/CE2774NT)
Your microwave oven is fitted with a special Child Safety programme,
which enables the oven to be “locked” so that children or anyone
unfamiliar with it cannot operate it accidentally.
The oven can be locked at any time.
Remembering Function (CE2774N/CE2774NT)
This oven remembers the last cooking mode for your convenience.
✉
1) When cooking is over, the end reminder signal will beep 3
times.(Chime bell per 1min). And then, cooking mode will be
“RESET” and the oven will forget the last cooking mode.
2) If there’s no operation after the door is opened and closed
once, the cooking mode will be “RESET” after 30 seconds.
3) Press the Cancel( ) button and then cooking mode will be
“RESET”.
1. Press the and buttons at the same time.
Result: The following indication is displayed.
The oven does not beep each time you press a
button or cooking ends.
2. To switch the beeper back on, press the and
buttons again at the same time.
Result: The following indication is displayed.
The oven operates with the beeper on again.
1. Press the and buttons at the same time.
Result: The oven is locked (no funtions can be
selected).
The display shows “L”.
2. To unlock the oven, press the and buttons again at
thesametime.
Result: The oven can be used normally.
1. Set the add some cooking time by turning the dial knob.
2. Press the button.
CE2774-BOL.fm Page 21 Tuesday, July 10, 2001 6:01 PM
22
GB
Cookware Guide
To cook food in the microwave oven, the microwaves must be able to
penetrate the food, without being reflected or absorbed by the dish
used.
Care must therefore be taken when choosing the cookware. If the
cookware is marked microwave-safe, you do not need to worry.
The following table lists various types of cookware and indicates
whether and how they should be used in a microwave oven.
Cookware Microwave-
Safe Comments
Aluminium foil
✓ ✗ Can be used in small quantities to
protect areas against overcooking.
Arcing can occur if the foil is too close
to the oven wall or if too much foil is
used.
Browning plate
✓Do not preheat for more than eight
minutes.
China and earthenware
✓Porcelain, pottery, glazed earthenware
and bone china are usually suitable,
unless decorated with a metal trim.
Disposable polyester
cardboard dishes
✓Some frozen foods are packaged in
these dishes.
Fast-food packaging
• Polystyrene cups
containers
• Paper bags or
newspaper
• Recycled paper or
metal trims
✓
✗
✗
Canbeusedtowarmfood.
Overheating may cause the
polystyrene to melt.
May catch fire.
May cause arcing.
Glassware
• Oven-to-table ware
• Fine glassware
• Glass jars
✓
✓
✓
Can be used, unless decorated with a
metal trim.
Can be used to warm foods or liquids.
Delicate glass may break or crack if
heated suddenly.
Must remove the lid. Suitable for
warming only.
Metal
•Dishes
• Freezer bag twist
ties
✗
✗May cause arcing or fire.
Paper
• Plates, cups,
napkins and Kitchen
paper
• Recycled paper
✓
✗
For short cooking times and warming.
Also to absorb excess moisture.
May cause arcing.
Plastic
• Containers
• Cling film
• Freezer bags
✓
✓
✓ ✗
Particularly if heat-resistant
thermoplastic. Some other plastics
may warp or discolour at high
temperatures. Do not use Melamine
plastic.
Can be used to retain moisture. Should
not touch the food. Take care when
removing the film as hot steam will
escape.
Only if boilable or oven-proof. Should
not be airtight. Prick with a fork, if
necessary.
Wax or grease-proof paper
✓Canbeusedtoretainmoistureand
prevent spattering.
CE2774-BOL.fm Page 22 Tuesday, July 10, 2001 6:01 PM
23
GB
Cooking Guide
MICROWAVES
Microwave energy actually penetrates food, attracted and absorbed by its water,
fat and sugar content. The microwaves cause the molecules in the food to move
rapidly. The rapid movement of these molecules creates friction and the resulting
heat cooks the food.
COOKING
Cookware for microwave cooking:
Cookware must allow microwave energy to pass through it for maximum
efficiency.
Microwaves are reflected by metal, such as stainless steel, aluminium and
copper, but they can penetrate through ceramic, glass, porcelain and plastic as
well as paper and wood. So food must never be cooked in metal containers.
Foods suitable for microwave cooking:
Many kinds of food are suitable for microwave cooking, including fresh or frozen
vegetables, fruit, pasta, rice, grains, beans, fish, and meat. Sauces, custard,
soups, steamed puddings, preserves, and chutneys can also be cooked in a
microwave oven. Generally speaking, microwave cooking is ideal for any food
that would normally be prepared on a hob. Melting butter or chocolate, for
example (see the chapter with tips, techniques and hints).
Covering during cooking
It is very important to cover the food during cooking because evaporated water
rises as steam and contributes to the cooking process. Food can be covered in
different ways: e.g. with a ceramic plate, plastic cover or microwave suitable cling
film.
Standing times
It is important to allow standing time when you have finished cooking the food in
order to allow the temperature within the food to even out.
Cooking Guide for frozen vegetables
Use a suitable glass pyrex bowl with lid. Cook covered for the minimum time - see
table. Continue cooking to get the result you prefer.
Stir twice during cooking and once after cooking. Add salt, herbs or butter after
cooking. Cover during standing time.
Food Portion Power Time
(min.) Standing
Time
(min.)
Instructions
Spinach 150 g 600W 4½-5½ 2-3 Add 15 ml (1 tablespoon)
cold water.
Broccoli 300 g 600W 9-10 2-3 Add30ml(2tbsp.)
cold water.
Peas 300g 600W 7½-8½ 2-3 Add15ml(1tbsp.)
cold water.
Green Beans 300 g 600W 8-9 2-3 Add30ml(2tbsp.)
cold water.
Mixed
Vegetables
(carrots/
peas/corn)
300g 600W 7½-8½ 2-3 Add15ml(1tbsp.)
cold water.
Mixed
Vegetables
(Chinese
style)
300 g 600W 8-9 2-3 Add15ml(1tbsp.)
cold water.
CE2774-BOL.fm Page 23 Tuesday, July 10, 2001 6:01 PM
24
GB
Cooking Guide (continued)
Cooking Guide for fresh vegetables
Use a suitable glass pyrex bowl with lid. Add 30-45 ml cold water (2-3 tbsp.) for
every 250 g unless another water quantity is recommended - see table. Cook
covered for the minimum time - see table. Continue cooking to get the result you
prefer. Stir once during and once after cooking. Add salt, herbs or butter after
cooking. Cover during a standing time of 3 minutes.
Hint: Cut the fresh vegetables into even sized pieces. The smaller they
are cut, the quicker they will cook.
All fresh vegetables should be cooked using full microwave power(850W).
Cooking Guide for rice and pasta
Rice : Use a large glass pyrex bowl with lid - rice doubles in volume during
cooking. Cook covered.
After the cooking time is over, stir before standing time and salt or
add herbs and butter.
Remark: the rice may not have absorbed all water after the cooking
time is finished.
Pasta : Use a large glass pyrex bowl. Add boiling water, a pinch of salt and
stir well. Cook uncovered.
Stir occasionally during and after cooking. Cover during standing
time and drain thoroughly afterwards.
Food Portion Time
(min.) Standing
Time
(min.)
Instructions
Broccoli 250g
500g 4-4½
8-8½ 3 Prepare even sized florets.
Arrange the stems to the centre.
Brussels
Sprouts 250g 5½-6½ 3 Add 60-75 ml (5-6 tbsp.) water.
Carrots 250g 4½-5 3 Cut carrots into even sized slices.
Cauliflower 250g
500g 5-5½
8½-9 3Prepare even sized florets.
Cut big florets into halves.
Arrange stems to the centre.
Courgettes 250g 3½-4 3 Cut courgettes into slices. Add
30 ml (2 tbsp.) water or a knob of
butter. Cook until just tender.
Egg Plants 250g 3½-4 3Cut egg plants into small slices
and sprinkle with 1 tablespoon
lemon juice.
Leeks 250g 4½-5 3 Cut leeks into thick slices.
Mushrooms 125g
250g 1½-2
3-3½ 3Prepare small whole or sliced
mushrooms.
Do not add any water.
Sprinkle with lemon juice.
Spice with salt and pepper.
Drain before serving.
Onions 250g 5½-6 3 Cut onions into slices or halves.
Add only 15 ml (1 tbsp.) water.
Pepper 250g 4½-5 3Cut pepper into small slices.
Potatoes 250g
500g 4-5
7½-8½ 3 Weigh the peeled potatoes and
cut them into similar sized halves
or quarters.
Turnip
Cabbage 250g 5-5½ 3Cut turnip cabbage into small
cubes.
Food Portion Power Time
(min.) Standing
Time
(min.)
Instructions
White Rice
(parboiled) 250g 850W 16-17 5 Add 500 ml cold water.
Brown Rice
(parboiled) 250g 850W 21-22 5Add 500 ml cold water.
Mixed Rice
(rice + wild
rice)
250g 850W 17-18 5 Add 500 ml cold water.
Mixed Corn
(rice + grain) 250g 850W 18-19 5Add 400 ml cold water.
Pasta 250g 850W 11-12 5 Add 1000 ml hot water.
CE2774-BOL.fm Page 24 Tuesday, July 10, 2001 6:01 PM
25
GB
Cooking Guide (continued)
REHEATING
Your microwave oven will reheat food in a fraction of the time that conventional
ovens hobs normally take.
Use the power levels and reheating times in the following chart as a guide.
The times in the chart consider liquids with a room temperature of about +18 to
+20°C or a chilled food with a temperature of about +5 to +7°C.
Arranging and covering
Avoid reheating large items such as joint of meat - they tend to overcook and dry
out before the centre is piping hot. Reheating small pieces will be more
successful.
Power levels and stirring
Some foods can be reheated using 850 W power while others should be reheated
using 600 W, 450 W or even 300 W.
Check the tables for guidance. In general, it is better to reheat food using a lower
power level, if the food is delicate, in large quantities, or if it is likely to heat up
very quickly (mince pies, for example).
Stir well or turn food over during reheating for best results. When possible, stir
again before serving.
Take particular care when heating liquids and baby foods. To prevent eruptive
boiling of liquids and possible scalding , stir before, during and after heating.
Keep them in the microwave oven during standing time. We recommend putting a
plastic spoon or glass stick into the liquids. Avoid overheating (and therefore
spoiling) the food.
It is preferable to underestimate cooking time and add extra heating time, if
necessary.
Heating and standing times
When reheating food for the first time, it is helpful to make a note of the time
taken - for future reference.
Always make sure that the reheated food is piping hot throughout.
Allow food to stand for a short time after reheating - to let the temperature even
out. The recommended standing time after reheating is 2-4 minutes, unless
another time is recommended in the chart.
Take particular care when heating liquids and baby food. See also the chapter
with the safety precautions.
REHEATING LIQUIDS
Always allow a standing time of at least 20 seconds after the oven has been
switched off to allow the temperature to even out. Stir during heating, if
necessary, and ALWAYS stir after heating. To prevent eruptive boiling and
possible scalding, you should put a spoon or glass stick into the beverages and
stir before, during and after heating.
REHEATING BABY FOOD
BABY FOOD:
Empty into a deep ceramic plate. Cover with plastic lid. Stir well after reheating!
Let stand for 2-3 minutes before serving. Stir again and check the temperature.
Recommended serving temperature: between 30-40°C.
BABY MILK:
Pour milk into a sterilised glass bottle. Reheat uncovered. Never heat a baby’s
bottle with teat on, as the bottle may explode if overheated.
Shake well before standing time and again before serving ! Always carefully
check the temperature of baby milk or food before giving it to the baby.
Recommended serving temperature: ca. 37°C.
REMARK:
Baby food particularly needs to be checked carefully before serving to prevent
burns. Use the power levels and times in the next table as a guide lines for
reheating.
CE2774-BOL.fm Page 25 Tuesday, July 10, 2001 6:01 PM
26
GB
Cooking Guide (continued)
Reheating Liquids and Food
Use the power levels and times in this table as guide lines for reheating. Reheating Baby Food and Milk
Use the power levels and times in this table as guide lines for reheating.
Food Portion Power Time
(min.) Standing
Time
(min.)
Instructions
Drinks
(coffee, milk,
tea water
with room
temperature)
150ml
(1 cup)
250ml
(1 mug)
850W 1-1 ½
1½ -2
1-2 Pour in to a ceramic cup and
reheat uncovered. Place cup
(150ml) or mug (250ml) in the
centre of turntable, Stir
carefully before and after
standing time.
Soup
(chilled) 250g 850W 2½-3 2-3 Pour into a deep ceramic plate
or deep ceramic bowl.
Cover with plastic lid. Stir well
after reheating.
Stir again before serving.
Stew
(chilled) 350g 600W 5½-6½ 2-3 Put stew in a deep ceramic
plate.
Cover with plastic lid.
Stir occasionally during
reheating and again before
standing and serving.
Pasta with
sauce
(chilled)
350g 600W 4½-5½ 3Put pasta (e.g. spaghetti or
egg noodles) on a flat ceramic
plate. Cover with microwave
cling film.
Stir before serving.
Filled pasta
with sauce
(chilled)
350g 600W 5-6 3 Put filled pasta (e.g. ravioli,
tortellini) in a deep ceramic
plate.
Cover with plastic lid.
Stir occasionally during
reheating and again before
standing and serving.
Plated Meal
(chilled) 350g 600W 5½-6½ 3Plate a ready-to heat meal of
2-3 chilled on a ceramic dish.
Cover with microwave cling-
film.
Food Portion Power Time Standing
Time
(min.)
Instructions
Baby
food
(veget-
ables +
meat)
190g 600W 30sec 2-3 Empty into ceramic deep plate.
Cook covered. Stir after cooking
time.
Stand for 2-3 minutes.
Before serving, stir well and
check the temperature carefully.
Baby
porridge
(grain +
milk +
fruit)
190g 600W 20sec 2-3 Empty into ceramic deep plate.
Cook covered.
Stir after cooking time.
Stand for 2-3 minutes.
Before serving, stir well and
check the tem-perature carefully.
Baby
milk 100ml
200ml
300W 30-40 sec
50 sec to
1min
2-3 Stir or shake well and pour into a
sterilised glass bottle. Place into
the centre of turntable.
Cook uncovered. Shake well and
stand for at least 3 minutes.
Before serving, shake well and
check the temperature
carefully.
CE2774-BOL.fm Page 26 Tuesday, July 10, 2001 6:01 PM
27
GB
Cooking Guide (continued)
DEFROSTING
Microwaves are an excellent way of defrosting frozen food. Microwaves gently
defrost frozen food in a short period of time. This can be of great advantage, if
unexpected guests suddenly show up.
Frozen poultry must be thoroughly thawed before cooking. Remove any metal
ties and take it out of any wrapping to allow thawed liquid to drain away.
Put the frozen food on a dish without cover. Turn over halfway, drain off any liquid
and remove any giblets as soon as possible.
Check the food occasionally to make sure that it does not feel warm.
If smaller and thinner parts of the frozen food start to warm up, they can be
shielded by wrapping very small strips of aluminium foil around them during
defrosting.
Should poultry start to warm up on the outer surface, stop thawing and allow it to
stand for 20 minutes before continuing.
Leave the fish, meat and poultry to stand in order to complete defrosting. The
standing time for complete defrosting will vary depending on the quantity
defrosted. Please refer to the table below.
Hint: Flat food defrosts better than thick and smaller quantities need less
time than bigger ones. Remember this hint while freezing and
defrosting food.
For defrosting of frozen food with a temperature of about -18 to - 20 °C, use the
following table as a guide.
All frozen food should be defrosted using the defrosting power level
(180 W, ).
Food Portion Time
(min.) Standing
Time
(min.)
Instructions
Meat
Minced beef
Pork steaks
250g
500g
250g
6-7
13-14
7½-8½
5-25 Place the meat on a flat
ceramic plate.
Shield thinner edges with
aluminium foil.
Turn over after half of
defrosting time!
Poultry
Chicken
pieces
Whole
chicken
500g
(2pcs)
900g
14½-15½
28-30
15-40 First, put chicken pieces skin-
side down, whole chicken
breast-side-down on a flat
ceramic plate. Shield the
thinner parts like wings and
ends with aluminium foil. Turn
over after half of defrosting
time!
FishFish fillets/
Whole fish 200g
(2pcs)
400g
(4pcs)
6-7
12-13
5-15 Putfrozenfishinthemiddleof
a flat ceramic plate.
Arrange the thinner parts
under the thicker parts.
Shield narrow ends of fillets
and tail whole fish with
aluminium foil. Turn over after
half of defrosting time!
Fruits
Berries 250g 6-7 5-10 Distribute fruits on a flat, round
glass dish (with a large
diameter).
Bread
Bread rolls
(each
ca. 50 g)
Toast/
Sandwich
German
bread (wheat
+ ryeflour)
2pcs
4pcs
250 g
500 g
½-1
2-2½
4½-5
8-10
5-20 Arrange rolls in a circle or
bread horizontally on kitchen
paper in the middle of
turntable.
Turn over after half of
defrosting time!
CE2774-BOL.fm Page 27 Tuesday, July 10, 2001 6:01 PM
28
GB
Cooking Guide (continued)
GRILL
The grill-heating element is located underneath the ceiling of the cavity. It
operates
while the door is closed and the turntable is rotating. The turntable’s rotation
makes the food brown more evenly. Preheating the grill for 4 minutes will make
the food brown more quickly.
Cookware for grilling:
Should be flameproof and may include metal. Do not use any type of plastic
cookware, as it can melt.
Food suitable for grilling:
Chops, sausages, steaks, hamburgers, bacon and gammon rashers, thin fish
portions, sandwiches and all kinds of toast with toppings.
IMPORTANT REMARK:
Whenever the grill only mode is used, make sure that the grill-heating element is
under the ceiling in the horizontal position and not on the back-wall in the vertical
position. Please remember that food must be placed on the high rack, unless
another instruction is recommended.
MICROWAVE + GRILL
This cooking mode combines the radiant heat that is coming from the grill with the
speed of microwave cooking. It operates only while the door is closed and the
turntable is rotating. Due to the rotation of the turntable, the food browns evenly.
Three combina-tion modes are available with this model:
600 W + Grill, 450 W + Grill and 300 W + Grill.
Cookware for cooking with microwave + grill
Please use cookware that microwaves can pass through. Cookware should be
flame-proof. Do not use metal cookware with combination mode. Do not use any
type of plastic cookware, as it can melt.
Food suitable for microwave + grill cooking:
Food suitable for combination mode cooking include all kinds of cooked food
which needs reheating and browning (e.g. baked pasta), as well as foods which
require a short cooking time to brown the top of the food.
Also, this mode can be used for thick food portions that benefit from a browned
and crispy top (e.g. chicken pieces, turning them over half way through cooking).
Please refer to the grill table for further details.
IMPORTANT REMARK:
Whenever the combination mode (microwave + grill) is used, make sure that the
grill heating element is under the ceiling in the horizontal position and not on the
back-wall in the vertical position. The food should be placed on the high rack,
unless another instruction is recommended.
Otherwise it has to be placed directly on the turntable.
Please refer to the instructions in the following chart.
The food must be turned over, if it is to be browned on both sides.
Grill Guide for frozen food
Use the power levels and times in this table as guide lines for grilling
Fresh Food Portion Power 1. Side
Time
(min)
2. Side
Time
(min.)
Instructions
Bread Rolls
(each ca. 50 g)
2pcs
4pcs
MW+
Grill
300W+
Grill
1-1½
2-2½
Grill
only
1-2
1-2
Arrangerollsinacircleon
rack. Grill the second of
the rolls up to the crisp you
prefer. Stand for 2-5
minutes.
Baguettes +
topping
(tomatos,
cheese, ham,
mushrooms)
250-300 g
(2pcs)
450 W
+Grill
7-8 -- Put frozen baguette in the
centre of the rack. Put 2
and 3 frozen baguettes
side by side on the rack.
After grilling stand for 2-3
minutes.
Gratin
(vegetables or
potatoes)
400 g 450 W
+Grill
13-14 -- Put frozen gratin into a
small, round glass pyrex
dish. Put the dish on the
rack. After cooking stand
for 2-3 minutes.
Pasta
(Cannelloni,
Macaroni,
Lasagne)
400 g 600 W
+Grill
14-15 -- Put frozen pasta into a
small flat rec tangular
glass pyrex dish. Put the
dish directly on the
turntable. After cooking
stand for 2-3 minutes.
Chicken
Nuggets 250 g 450 W
+Grill
5-5½ 3-3½ Put chicken nuggets on
the rack.
Oven Chips 250 g 450 W
+Grill
9-11 4-5 Put oven chips evenly on
baking paper on the rack.
CE2774-BOL.fm Page 28 Tuesday, July 10, 2001 6:01 PM
29
GB
Cooking Guide (continued)
Grill Guide for fresh food
Preheat the grill with the grill-function for 4 minutes.
Use the power levels and times in this table as guide lines for grilling.
Fresh Food Portion Power 1. Side
Time
(min)
2. Side
Time
(min.)
Instructions
Toast
Slices 4pcs
(each 25g) Grill
only
3½-4½ 3-4 Put the toast slices side by
side on the rack.
Bread Rolls
(already
baked)
2-4 pieces Grill
only 2-3 1-2 Put bread rolls first with the
bottomsideupinacircle
directly on the turntable.
Grilled
Tomatoes 200 g
(2pcs)
400 g
(4pcs)
300 W
+Grill 3½-4½
6-7
-- Cut tomatoes into halves.
Put some cheese on top.
Arrange in a circle in a flat
glass pyrex dish. Place it on
the rack.
Toast
Hawaii
(pineapple,
ham,
cheese
slices)
2pcs
(300 g) 450 W
+Grill 3½-4 -- Toast the bread slices first.
Put the toast with topping on
the rack.
Put 2 toasts opposite directly
on the rack. Stand for 2-3
minutes.
Baked
Potatoes 250 g
500 g 600 W
+Grill 4½-5½
8-9 -- Cut potatoes into halves.
Puttheminacircleonthe
rack with the cut side to the
grill.
Chicken
Pieces 450 - 500 g
(2 pcs) 300 W
+Grill 8-9 9-10 Prepare chicken pieces with
oil and spices.
Puttheminacirclewiththe
bones to the middle. Put one
chicken piece not into the
centre of the rack. Stand for
2-3 minutes.
Lamb
Chops
(medium)
400 g
(4pcs) Grill
only 11-13 8-9 Brush the lamb chops with
oil and spices.
Lay them in a circle on the
rack.After grilling stand for 2-
3 minutes.
Pork Steaks
250 g
(2pcs)
MW
+Grill (300W
+Grill)
7-8
(Grill
only)
6-7
Brush the pork steaks with
oil and spices. Lay them in a
circle on the rack. After
grilling stand for 2-3
minutes.
Baked
Apples 1 apple
(ca. 200g)
2 apples
(ca. 400g)
300 W
+Grill 4-4½
6-7
-- Core the apples and fill them
with raisins and jam. Put
some almond slices on top.
Put apples on a flat glass
pyrex dish. Place the dish
directly on the turntable.
Fresh Food Portion Power 1. Side
Time
(min)
2. Side
Time
(min.)
Instructions
CE2774-BOL.fm Page 29 Tuesday, July 10, 2001 6:01 PM
30
GB
Cooking Guide (continued)
SPECIAL HINTS
MELTING BUTTER
Put 50 g butter into a small deep glass dish. Cover with plastic lid.
Heat for 30-40 seconds using 850 W, until butter is melted.
MELTING CHOCOLATE
Put 100 g chocolate into a small deep glass dish.
Heat for 3-5 minutes, using 450W until chocolate is melted.
Stir once or twice during melting. Use oven gloves while taking out!
MELTNG CRYSTALLIZED HONEY
Put 20 g crystallized honey into a small deep glass dish.
Heat for 20-30 seconds using 300 W, until honey is melted.
MELTING GELATINE
Lay dry gelatine sheets (10 g) for 5 minutes into cold water.
Put drained gelatine into a small glass pyrex bowl.
Heat for 1 minute using 300 W.
Stir after melting.
COOKING GLAZE/ICING (FOR CAKE AND GATEAUX)
Mix instant glaze (approximately 14 g) with 40 g sugar and 250 ml cold water.
Cook uncovered in a glass pyrex bowl for 3 ½ to 4 ½ minutes using 850 W,
until glaze/icing is transparent. Stir twice during cooking.
COOKING JAM
Put 600 g fruits (for example mixed berries) in a suitable sized glass
pyrex bowl with lid. Add 300 g preserving sugar and stir well.
Cook covered for 10-12 minutes using 850 W.
Stir several times during cooking. Empty directly into small jam
glasses with twist-off lids. Stand on lid for 5 minutes.
COOKING PUDDING
Mix pudding powder with sugar and milk (500 ml) by following the
manufacturers instructions and stir well. Use a suitable sized glass pyrex
bowl with lid. Cook covered for 6 ½ to 7 ½ minutes using 850 W.
Stir several times well during cooking.
BROWNING ALMOND SLICES
Spread 30 g sliced almonds evenly on a medium sized ceramic plate.
Stir several times during browning for 3 ½ to 4 ½ minutes using 600 W.
Let it stand for 2-3 minutes in the oven. Use oven gloves while taking out!
Cleaning Your Microwave Oven
The following parts of your microwave oven should be cleaned
regularly to prevent grease and food particles from building up:
• Inside and outside surfaces
• Dooranddoorseals
• Turntable and Roller rings
☛ALWAYS ensure that the door seals are clean and the door closes
properly.
1. Clean the outside surfaces with a soft cloth and warm, soapy water. Rinse and
dry.
2. Remove any splashes or stains on the inside surfaces or on the roller ring with
a soapy cloth. Rinse and dry.
3. To loosen hardened food particles and remove smells, place a cup of diluted
lemon juice on the turntable and heat for ten minutes at maximum power.
4. Wash the dishwasher-safe plate whenever necessary.
✉DO NOT spill water in the vents. NEVER use any abrasive products or
chemical solvents.Take particular care when cleaning the door seals
to ensure that no particles:
• Accumulate
• Prevent the door from closing correctly
✉Clean the microwaveovencavityrightaftereachusewithamild
detergent solution, but let the microwave oven cool down before
cleaning in order to avoid injury.
When cleaning the upper part inside the cavity, it will be
convenient to turn heater downward by 45° and clean it.
CE2774-BOL.fm Page 30 Tuesday, July 10, 2001 6:01 PM
31
GB
Storing and Repairing Your Microwave Oven
A few simple precautions should be taken when storing or having your
microwave oven serviced.
The oven must not be used if the door or door seals are damaged:
• Broken hinge
• Deteriorated seals
• Distorted or bent oven casing
Only a qualified microwave service technician should perform repair.
☛NEVER remove the outer casing from the oven. If the oven is faulty
and needs servicing or you are in doubt about its condition:
• Unplug it from the wall socket
• Contact the nearest after-sales service centre
✉If you wish to store your oven away temporarily, choose a dry, dust-
free place.
•Reason: Dust and damp may adversely affect the working
parts in the oven.
✉This microwave oven is not intended for commercial use.
Technical Specification
SAMSUNG strives to improve its products at all times. Both the design
specifications and these user instructions are thus subject to change
without notice.
Model CE2774N/CE2774NT/CE2714N/CE2714NT
Power source 230V ~ 50 Hz
Power consumption
Microwave
Grill
Combined mode
1300 W
1100 W
2400 W
Output power 100 W / 850 W (IEC-705)
Operating frequency 2450 MHz
Magnetron OM75P(31)
Cooling method Cooling fan motor
Dimensions (WxHxD)
Outside
Oven cavity 489 x 275 x 388 mm
306 x 211 x 320 mm
Volume 0.7 cubic feet
Weight
Net 15 kg approx
CE2774-BOL.fm Page 31 Tuesday, July 10, 2001 6:01 PM
32
GB
Note
CE2774-BOL.fm Page 32 Tuesday, July 10, 2001 6:01 PM
33
GB
Note
CE2774-BOL.fm Page 33 Tuesday, July 10, 2001 6:01 PM
34
GB
Note
CE2774-BOL.fm Page 34 Tuesday, July 10, 2001 6:01 PM
35
GB
Note
CE2774-BOL.fm Page 35 Tuesday, July 10, 2001 6:01 PM
CE2774-BOL.fm Page 36 Tuesday, July 10, 2001 6:01 PM

Navigation menu
