Owner’s Instructions

HP-R4252

HP-R5052

This device is a Class B digital apparatus.

BN68-00835A-00(cover) 4/6/05 8:18 PM Page 3

Important Warranty Information

Regarding Television Format Viewing

Wide screen format PDP Displays (16:9, the aspect ratio of the screen width to height) are primarily

designed to view wide screen format full-motion video. The images displayed on them should primarily

be in the wide screen 16:9 ratio format, or expanded to fill the screen if your model offers this feature

and the images are constantly moving. Displaying stationary graphics and images on screen, such as

the dark side-bars on nonexpanded standard format television video and programming, should be

limited to no more than 5% of the total television viewing per week.

Additionally, viewing other stationary images and text such as stock market reports, video game

displays, station logos, web sites or computer graphics and patterns, should be limited as described

above for all televisions. Displaying stationary images that exceed the above guidelines

can cause uneven aging of PDP Displays that leave subtle, but permanent burned-in

ghost images in the PDP picture. To avoid this, vary the programming and images,

and primarily display full screen moving images, not stationary patterns or dark

bars.

On PDP models that offer picture sizing features, use these controls to view different formats as a full

screen picture.

Be careful in the selection and duration of television formats used for viewing. Uneven PDP aging as a

result of format selection and use, as well as burned-in images, are not covered by your Samsung

limited warranty.

U.S.A Only

Other countries

The product unit accompanying this user manual is licensed under certain intellectual property

rights of certain third parties. In particular, this product is licensed under the following US patents:

5,991,715, 5,740,317, 4,972,484, 5,214,678, 5,323,396, 5,539,829, 5,606,618,

5,530,655, 5,777,992, 6,289,308, 5,610,985, 5,481,643, 5,544,247, 5,960,037,

6,023,490, 5,878,080, and under US Published Patent Application No. 2001-44713-A1.

This license is limited to private non-commercial use by end-user consumers for licensed contents.

No rights are granted for commercial use. The license does not cover any product unit other than

this product unit and the license does not extend to any unlicensed product unit or process

conforming to ISO/IEC 11172-3 or ISO/IEC 13818-3 used or sold in combination with this

product unit. The license only covers the use of this product unit to encode and/or decode audio

files conforming to the ISO/IEC 11172-3 or ISO/IEC 13818-3. No rights are granted under this

license for product features or functions that do not conform to the ISO/IEC 11172-3 or ISO/IEC

13818-3.

The product unit accompanying this user manual is licensed under certain intellectual property

rights of certain third parties. This license is limited to private non-commercial use by end-user

consumers for licensed contents. No rights are granted for commercial use. The license does not

cover any product unit other than this product unit and the license does not extend to any

unlicensed product unit or process conforming to ISO/IEC 11172-3 or ISO/IEC 13818-3 used or

sold in combination with this product unit. The license only covers the use of this product unit to

encode and/or decode audio files conforming to the ISO/IEC 11172-3 or ISO/IEC 13818-3.

No rights are granted under this license for product features or functions that do not conform to the

ISO/IEC 11172-3 or ISO/IEC 13818-3.

BN68-00835A-00(002~035) 4/6/05 8:18 PM Page 2

User Instructions

Screen Image retention

Do not display a still image (such as on a video game) on the plasma display panel for more than

several minutes as it can cause screen image retention. This image retention is also known as

“screen burn”. To avoid such image retention, refer to page 53 of this manual to reduce the

degree of brightness and contrast of the screen when displaying a still image.

Altitude

The PDP will not operate normally at altitudes above 6500 ft.

Heat on the top of the PDP TV

The top side of the product may be hot after long periods of use as heat dissipates from the panel

through the vent hole in the upper part of the product.

This is normal and does not indicate any defect or operation failure of the product.

However, children should be prevented from touching the upper part of the product.

The product is making a ‘cracking’ noise.

A ‘cracking’ noise may occur when the product contracts or expands due to a change of

surrounding environment such as temperature or humidity. This is normal and not a defect of the

unit.

Cell Defects

The PDP uses a panel consisting of 1,230,000(SD-level) to 3,150,000(HD-level) pixels which

require sophisticated technology to produce. However, there may be few bright or dark pixels on

the screen. These pixels will have no impact on the performance of the product.

Avoid operating the TV at temperatures below 5°C(41°F)

A still image displayed too long may cause permanent damage to the PDP Panel.

Watching the PDP TV in 4:3 format for a long period of time may leave

traces of borders displayed on the left, right and center of the screen caused

by the difference of light emission on the screen.

Playing a DVD or a game console may cause similar effect to the screen.

Damages caused by the above effect are not covered by the Warranty.

Afterimage on the Screen.

Displaying still images from Video games and PC for longer than a certain period of time may

produce partial afterimages.

To prevent this effect, reduce the ‘brightness’ and ‘contrast’ when displaying still images for a

long time.

Warranty

Warranty does not cover any damage caused by image retention.

Burn-in is not covered by the warranty.

Installation

Be sure to contact an authorized service center when installing your set in a location with heavy

dust, high or low temperatures, high humidity, and chemical substances, or where it will be

operated for 24 hours continuously such as an airport, train station, etc.

Failure to do so may cause serious damage to your set. 3

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 3

CableCARD and Digital Cable Ready TVs

CableCARD and Digital Cable Ready TVs are the products of a new digital cable standard.

This new standard is called OpenCable and it is a concerted effort to standardize the digital cable

service network interface in North America. For more information, please refer to www.cablelabs.com.

Digital Cable Ready TVs are equipped with a proper digital cable tuner to receive digital cable signals

from your local cable service provider. They are also designed to work with digital CableCARD

modules (PCMCIA card modules called CableCARDs). These PCMCIA card modules or CableCARDs

will be provided by your local cable service provider after a proper subscription process.

The provided CableCARD from your local cable service provider needs to be inserted into the

CableCARD slot of a Digital Cable Ready TV. Please refer to page 25 for how to insert the

CableCARD.

A digital set-top box which used to be provided by the cable service provider is no longer needed

with Digital Cable Ready TVs and CableCARDs.

When the CableCARD is inserted into the slot, the TV screen will show a message that CableCARD

is inserted and necessary data such as channel information or subscription information will be

downloaded from your digital cable service provider. When you insert CableCARD for the first time,

this process may take few minutes depending on the amount of data your cable provider needs to send.

During this process, the digital cable service provider or CableCARD may display messages

on the TV screen to help or give you further information.

Please contact your local cable provider for more information on service availability and how to

acquire a CableCARD.

Notes

•This television receiver supports the copy protection system regulated by DTLA (Digital Transmission

Licensing Administrator). It should be noted that copy protected content may not be viewable

depending on your particular connections.

•Some channels may be scrambled depending on your cable service provider.

When you tune to these channels, no screen or a still screen may appear. In order to view the

screen properly, you have to go through a subscription process after contacting your service

provider. It will take several minutes to update the channel information depending on your cable

service provider.

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 4

1. Is the antenna I use for existing TV reception good enough for DTV?

Over-the-air (OTA) digital TV broadcasting uses the same channels as analog TV and works well with

many existing TV antennas. However, DTV broadcast channel assignments are different than analog

channels. You should find out whether your local DTV broadcasts are on VHF (channels 2-13) or UHF

(channels 14-69) to see if you need a different antenna.

If your DTV channels are on UHF and you already get good UHF reception, your present antenna may

work fine. The same holds true for VHF DTV reception. Note that in some markets, both VHF and UHF

channels are used for DTV broadcasts.

You can find out the latest DTV channel assignments for your area by browsing selected Internet web

sites such as www.titantv.com, www.10000watts.com, and www.fcc.gov.

2. How difficult is it to receive DTV signals indoors?

This depends on whether your local DTV stations are running full power or not and how close your

location is to the transmission tower. DTV receivers do not require as much signal as analog TV

receivers to produce high-quality images and sound.

Once the DTV signal level exceeds a certain threshold at the receiver, the digital video and audio data

is decoded at the same quality it was originally encoded for broadcast. This is a big advantage for

DTV over analog TV - there is no noise, ghosting, static, or scratchy audio.

3. How can I connect an antenna in my townhouse, co-operative apartment, condominium, or

apartment?

The Federal Communications Commission's OTARD Rule (part of the Telecommunications Act of 1996)

allows residents of condominiums, townhouse, or members of neighborhood associations to put up

outside antennas for reception of broadcast TV signals as long as those antennas are not located in

common areas and are no more than 12' in height.

Residents of rental units (apartments, etc.) are not covered by the OTARD rules and will have to use

indoor antennas to receive DTV broadcasts. It is possible that the landlord of an apartment complex

can provide broadcast DTV signals via a master TV antenna system to each apartment.

4. Can I connect my DTV set-top receiver to my cable TV service?

Cable TV systems use a different method for transmitting digital TV programs that is currently

incompatible with broadcast DTV set-top receivers. So you will still need to use an outdoor or indoor

antenna to receive OTA broadcast DTV programs.

The good news is that you won't have to pay a monthly or per-program charge to watch OTA DTV and

HDTV programs. They're free, unlike subscription satellite TV or premium cable TV. All you need is an

antenna and a DTV set-top receiver to enjoy clear, sharp widescreen images and high-quality audio.

Q&A

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 5

Table of Contents

General Information

Your New Plasma Display Panel....................10

Remote Control Buttons ................................13

Wall Installation Instructions..........................15

How to assemble the Stand-Base ..................19

Connections

Connecting VHF and UHF Antennas ..............22

Connecting Cable TV ..................................23

Connecting CableCARD ..............................25

Connecting a VCR ......................................26

Connecting a Camcorder ............................27

Connecting a DVD Player ............................28

Connecting a DTV Receiver ..........................29

Connecting to HDMI (High Definition

Multimedia Interface) ..................................30

Connecting a Digital TV Set-Top Box..............31

Connecting a Digital Audio System ..............32

Connecting to an Analog Amplifier ..............33

Operation

Turning the TV On and Off ..........................36

Viewing the Menus and Displays ..................40

Memorizing the Channels ............................41

Adding and Erasing Channels ......................44

Setting Up Your Remote Control ....................47

Viewing an External Signal Source................49

Picture Control

Changing the Picture Standard ....................52

Customizing the Picture Settings ....................53

Viewing the DNIe Demonstration ..................55

Changing the Screen Size ............................56

Viewing the Picture-in-Picture.........................58

Selecting the Sound Source .........................64

Setting the My Color Control Mode ...............65

Sound Control

Customizing the Sound ..............................70

Using Automatic Sound Settings ...................71

Setting the TruSurround XT............................72

Choosing a Multi-Channel Sound (MTS) track

- Digital ......................................................73

Choosing a Multi-Channel Sound (MTS) track

- Analog ....................................................74

Using the Auto Volume ................................75

Choosing a Digital Sound Format..................76

Setting the On/Off Melody ..........................77

Selecting the Internal Mute ..........................78

Channel Control

Selecting the Antenna ..................................80

Selecting Your Favorite Channels ..................81

Labeling the Channels..................................82

Viewing the Channel Lists ............................83

Editing the Channel Lists ..............................84

Fine Tuning Analog Channels ......................85

Checking the Digital-Signal Strength ..............86

LNA (Low Noise Amplifier) ..........................87

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 6

Connecting a PC and Operation

Connecting a PC ........................................90

Changing the Position of the Image ..............94

Picture Quality Adjustment............................95

Image Reset ................................................98

Time Setting

Setting the Clock ......................................100

Setting the On/Off Timer............................102

Setting the Sleep Timer ..............................103

Function Description

Selecting a Menu Language ......................106

Digital Noise Reduction..............................107

Selecting the Film Mode ............................108

Setting the Blue Screen ..............................109

Using the Color Weakness Enhancement

Option ....................................................110

Viewing Closed Captions (On-Screen

Text Messages) - Analog ............................111

Viewing Closed Captions (On-Screen

Text Messages) - Digital..............................112

Menu Transparency Level ..........................114

Using the Energy Saving feature ................115

Preventing Screen Burn-in ..........................116

Reducing the Effects of Screen Burn ............117

Setting the Function Help............................118

Using the V-Chip ......................................119

Electronic Program Guide ..........................125

Reminder List ............................................129

Using the CableCARD................................131

Using the CableCARD Setup Function ..........132

Appendix

Troubleshooting ........................................136

Care and Maintenance ..............................137

Specifications............................................138

Dimensions (HP-R4252)..............................139

Dimensions (HP-R5052)..............................141

Note

•The information contained in this User’s

Manual is subject to change without prior

notice for improvement, and may vary

depending on the version of the TV’s software

and the regional conditions.

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 7

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 8

PLASMA DISPLAY PANEL

General Information

Your New Plasma Display Panel ....................................................10

Remote Control Buttons ................................................................13

Wall Installation Instructions ..........................................................15

How to assemble the Stand-Base....................................................19

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 9

Your New Plasma Display Panel

Front Panel

ŒSOURCE button

Press to display all of the available video

sources (TV, AV, S-Video, Component1,

Component2, PC, and HDMI).

´MENU button

Displays the main on-screen menu.

ˇVOL +,

buttons

Press to increase or decrease the volume.

Also used to select or adjust items on the

on-screen menu.

¨CH( , ) buttons

Press CH or CH to change channels.

Also used to move up or down in the on-screen

menu.

ˆ(Enter) button

Press to confirm a selection.

ØPower button

Press to turn the TV on and off.

Power indicator

- Power Off : Blue

- Power On : Off

∏Remote Control Sensor

Aim the remote control towards this spot on

the TV.

”

Speakers

”∏Ø

BN68-00835A-00(002~035) 4/15/05 7:13 PM Page 10

Checking Accessories

Power Cord

(3903-000144)

Antenna Cable

Anynet Cable

(BN39-00518A)

Component Cables (RCA)

HDMI/DVI cable

Owner’s Instructions Remote Control (BN59-00462A) /

AAA Batteries

S-VIDEO Cable HDMI Cable

The following parts are sold separately and are available at most electronics stores.

Once you have unpacked your TV, check to make sure that you have all the parts shown here.

If any piece is missing or broken, call your dealer.

PC Cable PC Audio Cable Optical Cable Coaxial Cable

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 11

Rear Panel

ŒPOWER IN

Connect the supplied power cord.

´SERVICE ONLY

Connector for service only.

ˇHDMI/DVI IN

Connect to the HDMI jack of a device with

HDMI output. These inputs can also be used

as a DVI connection with separate analog

audio inputs. An optional HDMI/DVI cable

will be necessary to make this connection.

When using the optional HDMI/DVI adapter,

the DVI analog audio inputs on your TV allow

you to receive left and right audio from your

DVI device. (Not compatible with PC)

¨DVI AUDIO IN (L-AUDIO-R)

Connect to the DVI audio output jack of an

external device.

ˆPC IN

Connect to the video output jack on your PC.

ØPC AUDIO IN

Connect to the audio output jack on your PC.

∏OPTICAL DIGITAL AUDIO OUT

Connect to a Digital Audio component.

”COAXIAL DIGITAL AUDIO OUT

Connect to a Digital Audio component.

’Anynet

Please refer to the Anynet Owner’s

Instruction. This jack is for connecting to

other Samsung Anynet-enabled devices.

˝COMPONENT IN 1, 2

Video (Y/PB/PR) and audio (L-AUDIO-R)

component inputs.

ÔCableCARDTM

Insert the CableCARD into the slot.

ANT (75Ω)

75ΩCoaxial connector for Antenna/Cable

Network.

ÒAV IN (L-AUDIO-R)

Audio inputs for external devices, such as

a camcorder or VCR.

ÚVIDEO

Video input for external devices, such as

a camcorder or VCR.

ÆS-VIDEO

Video input for external devices with an

S-Video output, such as a camcorder or VCR.

ıAUDIO OUT

Audio outputs for external devices.

Note

•Please be sure to match the color coded input terminals and cable jacks.

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 12

Remote Control Buttons

ŒPOWER button

Turns the TV on and off.

´GUIDE button

Press to display the on-screen Electronic Program Guide (EPG).

ˇANTENNA button

Press to select “Air” or “Cable”.

¨Number buttons

button

Press to select additional channels (digital and analog)

being broadcast by the same station. For example, to select channel

“54-3”, press “54”, then press “

” and “3”.

ØMUTE button

Press to mute the TV sound.

∏VOL (Volume) buttons

Use it to adjust volume.

”Anynet button

Runs the Anynet view functions and sets up Anynet devices.

’MENU button

Displays the main on-screen menu.

˝ENTER button

Confirms a selection.

ÔFAV.CH button

Press to switch to your favorite channels.

CH LIST button

Displays the channel list.

ÒMODE button

Selects a target device to be controlled by the Samsung remote control

(i.e., TV, STB, VCR, CABLE, or DVD).

ÚPRE-CH button

Tunes to the previous channel.

ÆSOURCE button

Press to display all of the available video sources

(TV, AV, S-VIDEO,

COMPONENT1, COMPONENT2, PC, and HDMI).

ıCH (Channel) buttons

Use it to switch channels.

˜INFO button

Press to display information on the TV screen.

¯EXIT button

Press to exit the menu.

˘Up/Down/Left/Right buttons

Control the cursor in the menu. Continued...

Remote Control

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 13

¿P.MODE button

Adjust the TV picture by selecting one of the preset factory settings (or

select your personal, customized picture settings).

¸S.MODE button

Select Sound effect.

˛E.SAVING button

Press to adjust screen brightness according to surrounding environment.

(Refer to page 115)

◊P.SIZE button

Select Picture size.

±DNIe button

Activates DNIe (Digital Natural Image engine).

≠MTS button

Press to choose stereo, mono or Separate Audio Program

(SAP broadcast).

–SET button

Used during set up of this Samsung remote control, so that it will work

compatibly with other devices (VCR, Cable Box and DVD).

—PIP button

Activates picture in picture.

÷PIP control buttons

: Displays the available channels in sequence.

(These buttons change channels in the PIP window only.)

®CAPTION button

Controls the caption decoder.

∑VCR, DVD control buttons

Controls VCR tape or DVD disc functions: Stop, Rewind, Play/Pause,

and Fast Forward.

µRESET button

If your remote control is not functioning properly, take out the batteries

and press the reset button for about 2~3 seconds.

Re-insert the batteries and try using the remote control again.

Installing the Batteries in Your Remote Control

1Slide the back cover to

open the battery

compartment of the remote

control.

3Slide the cover back into

place.

2Install two AAA size

batteries. Make sure to

match the “+” and “-” ends

of the batteries with the

diagram inside the

compartment.

Remote Control Operation Range

You can use your remote control within a distance of 23 feet and an angle of 30 degrees

from the left and right sides of the TV’s remote control receiver.

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 14

Wall Installation Instructions

Refer to the correct installation guide according to your wall bracket.

1Contact a technician for installing the wall bracket.

2Samsung Electronics is not responsible for any damage to the product or injury to yourself

or others if you elect to perform the wall installation.

3This product is for installing on cement walls. The product may not stay in place when

installed on plaster or wood.

Installation Notes

Parts (Wall attachment panel is sold separately. Check with your dealer.)

Only use the components and accessories shipped with the panel.

Plastic Hanger : 4 Screw : 11

Screw : 4 Anchor : 111Left : 1 Right : 1

Wall Bracket Hinge Accessories

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 15

1 Insert and tighten the Captive Screw in the direction of the arrow.

When done, mount the wall bracket on the wall.

2Before drilling into the wall, check if the

length between the two locking holes at

the back of the product is correct. If the

length is too short or long, loosen all or

some of the 4 screws on the wall

bracket to adjust the length.

How to assemble the Wall Mount Bracket

3Check the installation diagram and

mark the drill points on the wall.

Use the 5.0 mm bit to drill holes deeper

than 35 mm. Fix each anchor in the

corresponding hole. Match each of the

brackets and hinge holes to the

corresponding anchor holes and insert

and tighten the 11 screws .

Captive Screw

Wall Bracket

Hinge (Right)

There are two hinges

(left and right). Use the

correct one.

Hinge (Left)

Length between the

two locking holes

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 16

1 Remove the 4 screws on the back of the product.

2 Insert the screw into the plastic hanger. (See the figure below)

Fixing the TV panel to the wall attachment panel bracket

The shape of the product may vary depending on the model. (The assemblies of the plastic

hanger and the screw are the same)

3Tighten the 4 screws in step 2 (plastic

hanger + screw ) to the rear holes of

the product. 4Remove safety pin (#) and insert the 4

product holders into the corresponding

bracket holes (!). Then place the

product (@) so that it is firmly fixed to

the bracket. Make sure to reinsert and

tighten the safety pin (#) to securely

hold the product to the bracket.

PDP

Wall Bracket Wall

• Mount the product on the wall bracket and make sure it is properly fixed to the left and

right plastic hangers.

• Be careful when installing the product on the bracket as fingers can be caught in the holes.

• Make sure the wall bracket is securely fixed to the wall, or the product may not stay in

place after installation.

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 17

How to Adjust Mounting Angle

Note

Note : Adjust the bracket angle to

2° before installing it on the wall.

Make sure to use the top center,

and not the left or the right side of

the product to adjust the angle.

1. Fix the product to the wall bracket.

2. Hold the product at the top in the center and pull it

forward (direction of the arrow) to adjust the angle.

(See the figure to the right)

3. You can adjust the bracket angle between

2° and 15°.

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 18

How to assemble the Stand-Base

➤

Two or more people should carry the TV. Never lay the TV on the floor because of possible damage to the screen.

Always store the TV upright.

1Using the 4 screws for securing the stand pegs and the monitor, firmly attach the monitor

to the stand pegs. (The exterior of the set may be different than the picture.)

Warning

Firmly secure the stand to

the TV before moving it,

as the stand may fall and

could cause serious injury.

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 19

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 20

PLASMA DISPLAY PANEL

Connections

Connecting VHF and UHF Antennas ..............................................22

Connecting Cable TV....................................................................23

Connecting CableCARD................................................................25

Connecting a VCR........................................................................26

Connecting a Camcorder..............................................................27

Connecting a DVD Player..............................................................28

Connecting a DTV Receiver ..........................................................29

Connecting to HDMI (High Definition Multimedia Interface) ..............30

Connecting a Digital TV Set-Top Box ..............................................31

Connecting a Digital Audio System ................................................32

Connecting to an Analog Amplifier ................................................33

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 21

Connecting VHF and UHF Antennas

Antennas with 75-ohm Round Leads

If your antenna looks like this: it has 75-ohm round leads.

1Plug the antenna lead into the ANT 2 IN (AIR IN)

on the TV.

Use an antenna cable. (Sold Separately)

BN68-00835A-00(002~035) 4/15/05 7:14 PM Page 22

Connecting Cable TV

You can connect different cable systems to your TV, including cable without a Cable box, and cable

with a Cable box that descrambles some or all channels.

Cable without a Cable Box

1Plug the incoming cable into the ANT 1 IN (CABLE IN)

on the TV.

Use an antenna cable. (Sold Separately)

Cable with a Cable Box that Descrambles All Channels

1Find the cable connected to the ANTENNA OUT

terminal on your Cable box. This terminal might be

labeled “ANT OUT”, “VHF OUT” or simply “OUT”.

2Connect the cable to the ANT 1 IN (CABLE IN) on

the TV.

Use an antenna cable. (Sold Separately)

BN68-00835A-00(002~035) 4/15/05 7:14 PM Page 23

Cable with a Cable Box that Descrambles Some (But Not All) Channels

To complete this connection you will need a two-way splitter, an RF (A/B) switch, and four coaxial

cables (which you can buy from your Samsung dealer or any electronics store).

1Find and disconnect the cable that is

connected to the ANTENNA IN terminal

of your Cable box. This terminal might

be labeled “ANT IN”, “VHF IN” or

simply, “IN”. Connect this cable to a

two-way splitter.

2Connect a coaxial cable between an

OUT terminal of the splitter and the

IN terminal of the Cable box.

3Connect a coaxial cable between the

ANTENNA OUT terminal of the Cable

box and the B-IN terminal of the RF

(A/B) switch.

4Connect a coaxial cable between the

other OUT terminal of the Cable box

and the A-IN terminal of the RF (A/B)

switch.

5Connect the last coaxial cable between

the OUT terminal of the RF (A/B)

switch and the ANT 1 IN (CABLE IN)

on the TV.

After you've made this connection, set the A/B switch to the “A” position for normal viewing.

Set the A/B switch to the “B” position to view scrambled channels. (When you set the A/B switch to

“B”, you will need to tune your Set-Top Box to the Cable box's output channel, which is usually

channel 3 or 4.)

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 24

Connecting CableCARD

You must obtain a CableCARD from a local cable service provider.

Insert the CableCARD into the “CableCARD” slot and the message “CableCARD Inserted”

is displayed on the screen. If the channel information does not exist, the message “Updating

Channel List” is displayed during channel information configuration.

It could take several minutes to update the channel information depending on your cable

service provider.

The pairing information containing a telephone number, CableCARD ID, Host ID, and other

information will be displayed in about 2~3 minutes. If an error message is displayed, please

contact your service provider.

When the channel information configuration has finished, the message “Updating Completed”

is displayed, indicating that the channel list is now updated.

The Channel list can now be displayed by pressing CH LIST button.

Notes

•Once the channel list has been updated, only the channels on the channel list can be

selected.

•Remove the CableCARD by carefully pulling it out with your hands since dropping the

CableCARD may cause damage to it.

How to Connect

Power cord

From cable TV

Please insert the card as shown.

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 25

Connecting a VCR

Connecting a VCR to the Video or S-Video/Audio jack

Connect the Video/Audio cables between the VIDEO or S-VIDEO/AUDIO input jacks on the

TV and VIDEO or S-VIDEO/AUDIO output jacks on the VCR.

(Note: For better video, use an S-Video cable.)

Note

•Please be sure to match the color coded input terminals and cable jacks.

Videotape Playback:

1. Turn on your TV.

2. Press the SOURCE button to select “AV” or “S-Video”.

3. Turn on your VCR, insert a videotape and press the Play button.

How to Connect

S-Video cable

Audio cable

Video cable

VCR

Power cord

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 26

Connecting a Camcorder

S-Video cable

Audio cable

Video cable

Camcorder

Connect a Video/Audio cable between the VIDEO or S-VIDEO/AUDIO input jacks on the TV

and the VIDEO or S-VIDEO/AUDIO output jacks on the camcorder.

(Note: For better video, use an S-VIDEO cable.)

Note

•Please be sure to match the color coded input terminals and cable jacks.

Viewing Tapes

1. Turn on your TV.

2. Press the SOURCE button to select “AV” or “S-Video”.

3. Turn on your camcorder and set it to video mode. (For details, refer to your camcorder

owner’s instructions.)

4. Insert the tape into the camcorder and press the Play button.

How to Connect

Viewing camcorder tapes

Power cord

BN68-00835A-00(002~035) 4/7/05 4:46 PM Page 27

Connecting a DVD Player (480i, 480p)

Playing DVD

Connect the Y, PB, PR(COMPONENT1, 2) input jacks on the TV to the Y, PB, PRoutput jacks

on the DVD player using a component cable.

Connect the AUDIO L/R (COMPONENT1, 2) input jacks on the TV to the AUDIO output

jacks on the DVD player using a audio cable.

Note

•Please be sure to match the color coded input terminals and cable jacks.

To Play DVD:

1. Turn on your TV.

2. Press the SOURCE button to select “Component 1” or “Component 2”.

3. Turn on your DVD player, insert a DVD disc and press the Play button.

• For an explanation of component video, see your DVD player’s owner’s instructions.

How to Connect

Audio cable

Component cable

DVD Player

Power cord

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 28

Connecting a DTV Receiver (480p, 720p, 1080i)

This TV displays the optimum picture in 720p mode.

Watching DTV

Connect the cable or antenna to the antenna input jack on the DTV.

Connect the Y, PB, PR(COMPONENT1, 2) or HDMI input jack on the TV to the Y, PB, PRor

DVI output jacks on the DTV receiver using a component or HDMI/DVI cable.

Connect the AUDIO L/R (COMPONENT1, 2 or DVI AUDIO IN) input jacks on the TV with

the AUDIO output jacks on the DTV receiver using an audio cable.

Note

•Please be sure to match the color coded input terminals and cable jacks.

To Watch DTV:

1. Turn on your TV.

2. Turn on your DTV receiver.

• For an explanation of component video, see your DTV receiver owner’s instructions.

3. Press the SOURCE button to select “Component1”, “Component2” or “HDMI”.

How to Connect

DTV Receiver

HDMI/DVI cable

Audio cable

Component cable

Power cord

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 29

Connecting to HDMI (High Definition

Multimedia Interface) (480p, 720p, 1080i)

Watching DTV

Connect the cable or antenna to the antenna input jack on the DTV.

Connect the HDMI input jack on the TV with the HDMI output jack on the DTV Set-Top Box

using an HDMI cable.

Note

•Please make sure the HDMI source’s power is on before selecting HDMI from the “Source List”

on the TV.

To Watch DTV:

1. Turn on your TV.

2. Turn on your DTV receiver.

• For an explanation of HDMI video, see your DTV receiver owner’s instructions.

3. Press the SOURCE button to select “HDMI”.

How to Connect

DTV Set-Top Box

HDMI cable

Power cord

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 30

Connecting a Digital TV Set-Top Box

(480p, 720p, 1080i)

By inputting a high-bandwidth digital content protection High-Definition picture source

to the HDMI input jack on the TV, High-Definition pictures can be displayed on the

screen in their digital form.

Connecting to HDMI (High Definition Multimedia Interface)/DVI Compatible

Connect the DVI AUDIO (L, R) input jacks on the TV with the AUDIO output jacks on the

Set-Top Box using an audio cable.

Connect the HDMI input jack on the TV and the VIDEO output jack on the Set-Top Box

using an HDMI/DVI cable.

How to Connect

Audio cable

HDMI/DVI cable

From cable

or Antenna

Power cord DTV Set-Top Box

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 31

Connecting a Digital Audio System

There are many types of digital audio systems on the market today.

A simplified illustration of an audio system is shown below. For more information, see your

audio system owner’s manual.

If your audio system has a coaxial digital audio input, connect to the “COAXIAL” output jack

on the TV.

If your audio system has a optical digital audio input, connect to the “OPTICAL“ output jack

on the TV.

Be certain to remove the black cover from the optical output before inserting the cable.

If your system has both coaxial and optical digital audio inputs, SAMSUNG recommends

you use the optical digital output on the TV.

Do not connect both optical and coaxial cables. This may damage your audio system.

• OPTICAL: converts the electric signal into an optical light signal, and transmits it through

glass fibers.

• COAXIAL: The digital audio signal is received through a coaxial copper cable.

How to Connect

Digital Audio System

Optical cable

Coaxial cable

Power cord

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 32

Connecting to an Analog Amplifier

The “AUDIO OUT (AUDIO L/R)” terminals cannot be used for external speakers.

You must hook them up to an amplifier.

When an audio amplifier is connected to the “AUDIO OUT (AUDIO L/R)” terminals:

Decrease the gain (volume) of the audio amplifier, turn the TV’s internal mute on and adjust

the volume level with the volume control of the amplifier.

How to Connect

Analog Amplifier

Audio cable

Power cord

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 33

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 34

PLASMA DISPLAY PANEL

Operation

Turning the TV On and Off............................................................36

Viewing the Menus and Displays ..................................................40

Memorizing the Channels ............................................................41

Adding and Erasing Channels ......................................................44

Setting Up Your Remote Control ....................................................47

Viewing an External Signal Source ................................................49

BN68-00835A-00(002~035) 4/6/05 8:19 PM Page 35

Turning the TV On and Off

Press the POWER button on the remote control.

The TV will be turned on and you will be able to use its features.

You can also use the Power button on the front of the TV.

Note

•If your TV isn’t turned on when the POWER button is pressed:

Press the

MODE

button to check if the TV mode has been

chosen.

Plug & Play Feature

When the TV is initially powered On, basic customer settings proceed automatically and subsequently:

Setting the language, checking the antenna input, memorizing the channels, and setting the time.

Note

•The Plug & Play function operates after plugging in the TV for the first time.

1Press the POWER button on the remote control.

The message “Menu language, Channels and Time

will be set.” is displayed.

Press the ENTER button, then “Select the language of

the OSD.” menu is automatically displayed.

2Press the ENTER button to enter the language.

Press the ▲or ▼button to select language, then

the ENTER button. “Select the antennas to

memorize.” menu is automatically displayed.

Menu language, Channels

and Time will be set.

Start

Select the language of the OSD.

Menu Language : English

Plug & Play

Enter Skip

English

Spanish

French

Move

BN68-00835A-00(036~049) 4/6/05 8:21 PM Page 36

3Press the ▲or ▼button to memorize the channels of

the selected connection.

Press the ENTER button to select “Start”.

Notes

• If the antenna is connected to ANT 1 IN (CABLE IN),

select “Cable” and if it is connected to ANT 2 IN

(AIR IN), select “Air”.

• If both ANT 1 IN and ANT 2 IN are connected,

select the “Air + Cable”.

•If the CableCARD is inserted into the “CableCARD”

slot on the rear panel, “Cable” and “Air + Cable”

are not available.

When selecting Cable TV :

Press the ▲or ▼button to select “Cable” or “Air + Cable”,

then press the ENTER button.

Press the ▲or ▼button to select “Digital Channel”, then

press the ENTER button.

Press the ▲or ▼button to select “STD”, “HRC”, or “IRC”,

press the ENTER button.

Press the ▲or ▼button to select “Analog Channel”, then

press the ENTER button.

Press the ▲or ▼button to select “STD”, “HRC”, or “IRC”,

press the ENTER button.

Press the ▲or ▼button to select “Start”, then press the

ENTER button to memorize the channels.

Note

•STD, HRC, and IRC identify various types of cable

TV systems. Contact your local cable company to

identify the type of cable system that exists in your

particular area. At this point the signal source has

been selected. Proceed to “Storing Channels in

Memory” on page 43. 37

Select the antennas to memorize.

Air

Cable

Air + Cable

Plug & Play

Enter SkipMove

Start

Select the cable system.

Digital Channel : STD √

Analog Channel : STD √

Start

Plug & Play

Enter Skip

Move

Select the cable system.

Digital Channel : STD √

Analog Channel : STD √

Start

Plug & Play

Enter Skip

Move

Select the cable system.

Digital Channel : STD √

Analog Channel : STD √

Start

Plug & Play

Enter Skip

Move

STD

HRC

IRC

Select the cable system.

Digital Channel : STD √

Analog Channel : STD √

Start

Plug & Play

Enter SkipMove

STD

HRC

IRC

Start

BN68-00835A-00(036~049) 4/6/05 8:21 PM Page 37

4The TV will begin memorizing all of the available

channels. After all the available channels are stored,

the Auto program menu reappears.

Press the ENTER button to select OK when channel

memorization is complete.

“Set to daylight savings time.” menu is automatically

displayed.

Press the ENTER button at any time to interrupt the

memorization process.

5Press the ENTER button. Press the ▲or ▼button to

select “Yes” or “No”, then the ENTER button.

“Select the time zone in which you live” menu is

automatically displayed.

6Press the ▲or ▼button to highlight the time zone

for your local area (and to move the highlight to the

appropriate time zone on the map of the United States).

Press the ENTER button.

If you have received a digital signal, the time will

be set automatically. If not, see page 100 to set the

clock.

7The message “Completed. Time will be updated

automatically.” is displayed.

When you have finished, press the ENTER button.

•The message will automatically disappear after a few

seconds, even if the ENTER button is not pressed.

Plug & Play

Enter Skip

Auto Program in progress.

Cable Channel 67

Stop

Plug & Play

Enter Skip

Auto Program is completed.

14 Channels were memorized.

Air : 9, Cable : 5.

Set to daylight savings time.

Daylight Savings Time : English

Plug & Play

Enter Skip

Yes

Move

Select the time zone in which you live.

Plug & Play

Eastern

Central

Mountain

Pacific

Alaska

Hawaii

Enter SkipMove

Completed. Time will

be updated automatically.

BN68-00835A-00(036~049) 4/6/05 8:21 PM Page 38

If you want to reset this feature...

1Press the MENU button. Press the ▲or ▼button to select

“Setup”, then press the ENTER button.

2Press the ENTER button to select “Plug & Play”.

3For further details on setting up options, refer to the

previous page.

Note

•Plug and Play can only be accessed in the TV mode.

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

Menu language, Channels

and Time will be set.

Start

BN68-00835A-00(036~049) 4/6/05 8:21 PM Page 39

Viewing the Menus and Displays

Your TV has a simple, easy-to-use menu system that appears on the TV screen.

This system makes it convenient and fast to use features on the TV.

Your TV also lets you display the status of many of your TV’s features.

Viewing the Menus

1With the power on, press the MENU button on the

remote control. The main menu appears on the

screen. The Input menu is selected.

2Press the ▲or ▼button to move to items in the menu.

Press the œ/√/ENTER buttons to display,

change, or use the selected items.

Press the ENTER button to enter items in the menu.

On screen menus disappear from the screen

automatically after about two minutes or you can press

the MENU or EXIT button on your remote control to exit

the menu.

Displaying Status Information

Press the INFO button on the remote control.

The TV will display the Picture Mode, Sound Mode, MTS,

V-Chip, and Current Time.

Source List : TV

√

Edit Name

√

Anynet

√

Input

Move Enter Return

Air 28

Picture Mode : Dynamic

Sound Mode : Custom

MTS : Stereo

V-Chip : Off

12 : 00 am

Mono

BN68-00835A-00(036~049) 4/6/05 8:21 PM Page 40

Memorizing the Channels

Your TV can memorize and store all of the available channels for both “off-air” (antenna) and cable

channels. After the available channels are memorized, use the CH and CH buttons to scan

through the channels. This eliminates the need to change channels by entering the channel digits.

There are three steps for memorizing channels: selecting a broadcast source, memorizing the

channels (automatic) and adding and deleting channels (manual).

Selecting a broadcast source

Before your television can begin memorizing the available channels, you must specify the type of signal

source that is connected to the TV (i.e., an antenna or a cable system).

1Press the MENU button. Press the ▲or ▼button to select

“Channel”, then press the ENTER button.

2Press the ▲or ▼button to select “Auto Program”, then

press the ENTER button.

3Press the ▲or ▼button to select the antenna connection,

then press the ENTER button.

Notes

• Air : “Air” antenna signal.

• Cable : “Cable” antenna signal.

• Air + Cable : “Air” and “Cable” antenna signals.

If the CableCARD is inserted into the “CableCARD”

slot on the rear panel, “Cable” and “Air + Cable”

are not available.

Antenna : Air

√

Auto Program

√

Add / Delete

√

Favorite Channels

√

Name

√

Fine Tune

√

†

Channel

Move Enter Return

Antenna : Air

√

Auto Program

√

Add / Delete

√

Favorite Channels

√

Name

√

Fine Tune

√

†

Channel

Move Enter Return

Auto Program

Move Enter Return

Select the antennas to memorize.

Air

Cable

Air + Cable

Start

Auto Program

Move Enter Return

Select the antennas to memorize.

Air

Cable

Air + Cable

Start

BN68-00835A-00(036~049) 4/6/05 8:21 PM Page 41

When selecting Cable TV system :

Press the ▲or ▼button to select “Cable” or “Air + Cable”,

then press the ENTER button.

Press the ▲or ▼button to select “Digital Channel”, then

press the ENTER button.

Press the ▲or ▼button to select “STD”, “HRC”, or “IRC”,

press the ENTER button.

Press the ▲or ▼button to select “Analog Channel”, then

press the ENTER button.

Press the ▲or ▼button to select “STD”, “HRC”, or “IRC”,

press the ENTER button.

Press the ▲or ▼button to select “Start”, then press the

ENTER button to memorize the channels.

Note

•STD, HRC, and IRC identify various types of cable

TV systems. Contact your local cable company to

identify the type of cable system that exists in your

particular area. At this point the signal source has

been selected. Proceed to “Storing Channels in

Memory” on page 43.

Auto Program

Move Enter Return

Select the cable system.

Digital Channel : STD √

Analog Channel : STD √

Start

Auto Program

Move Enter Return

Select the cable system.

Digital Channel : STD √

Analog Channel : STD √

Start

Auto Program

Move Enter Return

Select the cable system.

Digital Channel : STD

Analog Channel : STD

Start

STD

HRC

IRC

Auto Program

Move Enter Return

Select the cable system.

Digital Channel : STD

Analog Channel : STD

Start

STD

HRC

IRC

Auto Program

Enter Return

Auto Program in progress.

Cable Channel 67

Stop

BN68-00835A-00(036~049) 4/6/05 8:21 PM Page 42

Storing Channels in Memory

4Press the ▲or ▼button to select the antennas to

memorize. Press the ENTER button to select “Start”.

5In Air, press the ENTER button to start the auto program.

In Cable or Air + Cable, press the ENTER button to

select the cable system.

Press the ▲or ▼button to select “Digital Channel or

Analog Channel”, then select the cable system.

Press the ▲or ▼button to select “Start” and press

the ENTER button to start the auto program.

6The TV begins memorizing all available stations.

Press the ENTER button at any time to interrupt the

memorization process.

Press the EXIT button to exit.

Note

•The TV must be connected to an antenna in

order to receive digital TV signals.

Even if a particular channel is deleted from the

memory, you can always tune to that channel

directly by using the number buttons on the

remote control.

Notes

•All available DTV and analog channels are automatically stored in memory when channels are

selected by directly accessing channels.

•It takes approximately 3 to 10 minutes to memorize channels.

Auto Program

Move Enter Return

Select the cable system.

Digital Channel : STD √

Analog Channel : STD √

Start

Auto Program

Enter Return

Auto Program in progress.

Air Channel 67

Stop

Auto Program

Move Enter Return

Select the antennas to memorize.

Air

Cable

Air + Cable

Start

BN68-00835A-00(036~049) 4/6/05 8:21 PM Page 43

1Press the MENU button.

Press the ▲or ▼button to select “Channel”, then

press the ENTER button.

2Press the ▲or ▼button to select “Add/Delete”, then

press the ENTER button.

3Repeatedly pressing the ENTER button will alternate

between add channel and delete channel.

Press the CH or CH button to switch to the

appropriate channel, then repeat above.

Press the EXIT button to exit.

Adding and Erasing Channels

To add channels that were not memorized (or to delete unwanted channels from memory):

Antenna : Air

√

Auto Program

√

Add / Delete

√

Favorite Channels

√

Name

√

Fine Tune

√

†More

Channel

Move Enter Return

Antenna : Air

√

Auto Program

√

Add / Delete

√

Favorite Channels

√

Name

√

Fine Tune

√

†More

Channel

Move Enter Return

Add / Delete

Enter Return

Air 16 Not in memory

Press ENTER to add the channel.

Add

Change

Add / Delete

Enter Return

Air 16 In memory

Press ENTER to delete the channel.

Delete

Change

BN68-00835A-00(036~049) 4/6/05 8:22 PM Page 44

Changing Channels

Using the Channel Buttons

Press the CH or CH button to change channels.

When you press the CH or CH button, the TV changes channels

in sequence. You will see all the channels that the TV has memorized.

(The TV must have memorized at least three channels.)

You will not see channels that were either erased or not memorized.

Directly Accessing Channels

Press the number buttons to go directly to a channel. For example, to select

channel 27, press “2” then “7”.

When you use the number buttons, you can directly select channels that

were either erased or not memorized. To change to single-digit channels

(0~9) faster, press “0” before the single digit. (For channel “4” press “0”,

then “4”.)

Notes

•For quick channel change, press the number buttons and then press

ENTER button.

•After the process of updating the channel information using CableCARD

has been completed, only the number of channels on the channel list can

be directly accessed.

Using the PRE-CH button to select the previous channel

Press the PRE-CH button. The TV will switch to the last channel viewed.

To quickly switch between two channels that are far apart, tune to one

channel, then use the number button to select the second channel. Then,

use the PRE-CH button to quickly alternate between them.

Adjusting the Volume

Using the Volume Buttons

Press the VOL or VOL button to increase or decrease the volume.

Using Mute

Using the MUTE Button

At any time, you can temporarily cut off the sound using the MUTE button.

Press the MUTE button and the sound cuts off. The word “MUTE” will

appear in the lower-left corner of the screen.

To turn mute off, press the MUTE button again, or simply press the

VOL or VOL button.

MUTE

BN68-00835A-00(036~049) 4/6/05 8:22 PM Page 45

Using the “

”Button

The “

” button is used to select stations that broadcast both a digital and analog signal.

For example, for Channel 7

1 (digital), press “7”, then “

”,

then “1”.

For channel 7

2 (analog), press “7”, then “

”, then “2”.

Notes

•HD indicates the TV is receiving a Digital High Definition signal.

SD indicates the TV is receiving a Standard Definition signal.

•For quick channel change, press the number buttons, then press the ENTER button.

DTV Cable

7 - 1

KYW-HD

DTV Cable

7 - 2

Multi

BN68-00835A-00(036~049) 4/6/05 8:22 PM Page 46

Setting Up Your Remote Control

Your TV comes equipped with a universal remote control. In addition to controlling the TV, the universal

remote control can also operate a VCR, Cable box, DVD, and Set-Top Box (even if your VCR,

Cable box and DVD are made by manufacturers other than Samsung).

Note :

●

The remote control might not be compatible with all DVD Players, VCRs, Cable boxes,

and Set-Top Boxes.

Setting Up the Remote to Operate Your VCR, Cable box or DVD player

1 Turn off your VCR (or Cable box, DVD player).

2Press the MODE button. The Mode is changed whenever

MODE button is pressed.

3 Press the SET button on your TV's remote control.

4Using the number buttons on your remote control, enter

three digits of the VCR (or Cable box, DVD player) code

listed on page 48 of this manual for your brand of VCR (or

Cable box, DVD). Make sure you enter three digits of the

code, even if the first digit is a “0”. (If more than one code

is listed, try the first one.)

5Press the POWER button on the remote control. Your VCR

(or Cable box, DVD) should turn on if your remote is set up

correctly. If your VCR (or Cable box, DVD) does not turn on

after setup, repeat steps 2, 3, and 4, but try one of the

other codes listed for your brand of VCR (or Cable box,

DVD). If no other codes are listed, try each code, 000

through 089 (or Cable box: 000 through 077, DVD player:

000 through 008).

Note

•When your remote control is in “VCR”, “CABLE”, or “DVD” mode, the VCR control buttons (STOP,

REW, PLAY/PAUSE, and FF) still operate your VCR.

BN68-00835A-00(036~049) 4/15/05 7:10 PM Page 47

Remote Control Codes

VCR Codes

DVD Codes

Cable Box Codes

BN68-00835A-00(036~049) 4/6/05 8:22 PM Page 48

Viewing an External Signal Source

Use the remote control to switch between viewing signals from connected equipment, such as

VCR, DVD, Set-Top Box, and the TV source (broadcast or cable).

Setting the Signal Source

1Press the MENU button.

Press the ENTER button to select “Input”.

2Press the ENTER button to select “Source List”.

3Press the ▲or ▼button to select signal source, then

press the ENTER button.

4 Press the MENU button to exit.

Notes

•When you connect equipment to the TV, you can choose between the following sets of jacks:

AV, S-VIDEO, COMPONENT 1, COMPONENT 2, PC, or HDMI on the TV’s rear panel.

•HDMI input can only be selected when the external device is turned on.

➤

Quick way to access viewing an external signal source :

Just press the “SOURCE” button on the remote control.

Source List : TV

√

Edit Name

√

Anynet

√

Input

Move Enter Return

AV :

----

S-Video :

----

Component 1 :

----

Component 2 :

----

PC :

----

HDMI :

----

Source List

Move Enter Return

AV :

----

S-Video :

----

Component 1 :

----

Component 2 :

----

PC :

----

HDMI :

----

Source List

Move Enter Return

BN68-00835A-00(036~049) 4/6/05 8:22 PM Page 49

Assigning Names to External input mode

1Press the MENU button.

Press the ENTER button to select “Input”.

2Press the ▲or ▼button to select “Edit Name”, then

press the ENTER button.

3Press the ENTER button.

Press the ▲or ▼button to select external device,

then press the ENTER button.

• You can select the VCR, DVD, D-VHS, Cable STB,

HD STB, Satellite STB, PVR STB, AV Receiver,

DVD Receiver, GAME, Camcorder, DVD Combo,

PC, VOD STB, or TV.

• Set other signal sources (S-Video, Component 1,

Component 2, PC, or HDMI) using the same method

as listed above.

4Press the MENU button to exit.

Source List : TV

√

Edit Name

√

Anynet

√

Input

Move Enter Return

AV :

----

√

S-Video :

----

√

Component 1 :

----

√

Component 2 :

----

√

PC :

----

√

HDMI :

----

√

Edit Name

Move Enter Return

AV :

----

S-Video :

----

Component 1 :

----

Component 2 :

----

PC :

----

HDMI :

----

Edit Name

Move Enter Return

†

----

VCR

DVD

D-VHS

Cable STB

HD STB

Satellite STB

PVR STB

BN68-00835A-00(050~067) 4/7/05 8:56 AM Page 50

PLASMA DISPLAY PANEL

Picture Control

Changing the Picture Standard ......................................................52

Customizing the Picture Settings ....................................................53

Viewing the DNIe Demonstration ..................................................55

Changing the Screen Size ............................................................56

Viewing the Picture-in-Picture..........................................................58

Selecting the Sound Source ..........................................................64

Setting the My Color Control Mode................................................65

BN68-00835A-00(050~067) 4/7/05 8:56 AM Page 51

Changing the Picture Standard

You can select the type of picture which best corresponds to your viewing requirements.

1Press the MENU button. Press the ▲or ▼button to select

“Picture”, then press the ENTER button.

2Press the ENTER button again to select “Mode”.

3Press the ENTER button.

Press the ▲or ▼ button to select the desired picture

mode (Dynamic, Standard, Movie, Custom), then press

the ENTER button.

4Press the MENU button to exit.

•Choose Dynamic for viewing the TV during the day or when there is bright light in the room.

•Choose Standard for the standard factory settings.

•Choose Movie when viewing the movie.

•Choose Custom if you want to adjust the settings according to personal preference

(see “Customizing the Picture Settings”, page 53).

Mode : Dynamic

√

Size : 16:9

√

Digital NR : On

√

DNIe Demo : Off

√

My Color Control

√

Film Mode : Off

√

†


Move Enter Return

Mode

Move Enter Return

Mode : Dynamic

√

Contrast 100

Brightness 45

Sharpness 75

Color 55

Tint G 50 R 50

Color Tone : Cool2

√

Reset

Mode : Dynamic

Contrast 100

Brightness 45

Sharpness 75

Color 55

Tint G 50 R 50

Color Tone : Cool2

Reset

Mode

Move Enter Return

Dynamic

Standard

Movie

Custom

BN68-00835A-00(050~067) 4/7/05 8:56 AM Page 52

1Press the MENU button. Press the ▲or ▼button to select

“Picture”, then press the ENTER button.

2Press the ENTER button to select “Mode”.

3Press the ENTER button.

Press the ▲or ▼ button to select the desired picture

mode (Dynamic, Standard, Movie, Custom), then press

the ENTER button.

4Press the ▲or ▼button to select a particular option

(Contrast, Brightness, Sharpness, Color, or Tint), then

press the ENTER button.

Press the œor √button to decrease or increase the

value of a particular item.

• You can also select these options (Contrast,

Brightness, Sharpness, Color, or Tint) by pressing

the ▲or ▼button.

Notes

•“Tint” doesn’t operate in HDMI or 480p Component or higher modes.

•The Tint cannot be adjusted while watching Digital TV.

Customizing the Picture Settings

You can use the on-screen menus to change the “Contrast”, “Brightness”, “Sharpness”, “Color”,

“Tint”, and “Color Tone” according to personal preference. You can select “Standard” which

automatically recalls your personalized picture settings.

Mode

Move Enter Return

Mode : Dynamic

√

Contrast 100

Brightness 45

Sharpness 75

Color 55

Tint G 50 R 50

Color Tone : Cool2

√

Reset

Mode

Move Enter Return

Mode : Custom

√

Contrast 80

Brightness 50

Sharpness 50

Color 50

Tint G 50 R 50

Color Tone : Normal

√

Reset

Mode : Dynamic

√

Size : 16:9

√

Digital NR : On

√

DNIe Demo : Off

√

My Color Control

√

Film Mode : Off

√

†


Move Enter Return

Mode : Dynamic

Contrast 100

Brightness 45

Sharpness 75

Color 55

Tint G 50 R 50

Color Tone : Cool2

Reset

Mode

Move Enter Return

Dynamic

Standard

Movie

Custom

➤

Quick way to access the picture setting: Just press the “P.MODE”

button on the remote control.

Contrast

BN68-00835A-00(050~067) 4/7/05 8:56 AM Page 53

5Press the ENTER button to return to “Mode”.

Press the ▲or ▼button to select “Color Tone”, then

press the ENTER button.

6Press the ▲or ▼button to select a particular option

(Cool2, Cool1, Normal, Warm1, or Warm2), then press

the ENTER button.

Press the MENU button to exit.

Resetting the Picture Settings to the Factory Defaults

7To return the factory defaults, select “Reset” by pressing

the ▲or ▼button.

Press the ENTER button.

•The previously adjusted settings will be reset to the

factory defaults.

Mode

Move Enter Return

Mode : Custom

√

Contrast 80

Brightness 50

Sharpness 50

Color 50

Tint G 50 R 50

Color Tone : Normal

√

Reset

Mode

Move Enter Return

Mode : Custom

√

Contrast 80

Brightness 50

Sharpness 50

Color 50

Tint G 50 R 50

Color Tone : Normal

√

Reset

Mode

Move Enter Return

Mode : Custom

Contrast 80

Brightness 50

Sharpness 50

Color 50

Tint G 50 R 50

Color Tone : Cool1

Reset

Cool2

Cool1

Normal

Warm1

Warm2

BN68-00835A-00(050~067) 4/7/05 8:56 AM Page 54

Viewing the DNIe Demonstration

This TV includes the DNIe function so as to provide a high visual quality.

If you set DNIe Demo to On, you can view the applied DNIe and normal pictures on the screen,

for demonstration purposes. Using this function, you can view the difference in the visual quality.

1Press the MENU button. Press the ▲or ▼button to select

“Picture”, then press the ENTER button.

2Press the ▲or ▼button to select “DNIe Demo”, then

press the ENTER button.

3Press the ▲or ▼button to select “Off” or “On”, then

press the ENTER button.

•Off : Switches off the DNIe Demo mode.

•On : Switches on the DNIe Demo mode.

4Press the MENU button to exit.

Note

•DNIeTM (Digital Natural Image engine)

This feature brings you more a detailed image with 3D noise reduction and detail,

contrast and white enhancement.

➤

Quick way to select DNIe: Simply press the “DNIe” button under the

cover of the remote control.

Mode : Dynamic

√

Size : 16:9

√

Digital NR : On

√

DNIe Demo : Off

√

My Color Control

√

Film Mode : Off

√

†


Move Enter Return

Mode : Dynamic

Size : 16:9

Digital NR : On

DNIe Demo : Off

My Color Control

Film Mode : Off

†


Move Enter Return

Mode : Dynamic

Size : 16:9

Digital NR : On

DNIe Demo : Off

My Color Control

Film Mode : Off

†


Move Enter Return

Off

DNIe Demo

Off On

BN68-00835A-00(050~067) 4/7/05 8:56 AM Page 55

Changing the Screen Size

Screen size selection depends on the type of video input.

1Press the MENU button. Press the ▲or ▼button to

select “Picture”, then press the ENTER button.

2Press the ▲or ▼button to select “Size”, then press the

ENTER button.

3Press the œor √button to select the screen size you

want, then press the ENTER button.

4 Press the MENU button to exit.

•16:9 : Sets the picture to 16:9 wide mode.

•Panorama : Use this mode for the wide aspect ratio of a panoramic picture.

•Zoom1 : Magnifies the size of the picture on the screen.

•Zoom2 : Expands the Zoom1 format picture.

•4:3 : Sets the picture to 4:3 normal mode.

➤

Quick way to change the Screen size: Simply press the P.SIZE button

under the cover of the remote control.

Mode : Dynamic

√

Size : 16:9

√

Digital NR : On

√

DNIe Demo : Off

√

My Color Control

√

Film Mode : Off

√

†


Move Enter Return

Mode : Dynamic

√

Size : 16:9

√

Digital NR : On

√

DNIe Demo : Off

√

My Color Control

√

Film Mode : Off

√

†


Move Enter Return

Size

Move Enter Return

16:9 Panorama Zoom1 Zoom2 4:3

BN68-00835A-00(050~067) 4/7/05 8:56 AM Page 56

When you press the P.SIZE button under the cover of the remote control, the TV’s screen mode should

appear in sequence. The screen displays in this order: 16:9, Panorama, Zoom1, Zoom2, 4:3.

Note

•If you watch a still image or the 4:3 mode for a long time (over 2 hours), an image may be burned

onto the screen. View the TV in 16:9 or Panorama mode as much as possible.

16:9

Sets the picture to 16:9 wide mode.

Panorama

Converts regular 4:3 aspect ratio screen to

wide screen.

Zoom1

The screen size when Wide screen is

vertically enlarged.

Zoom2

The screen size when the Zoom1 screen is

vertically enlarged.

4:3

Sets the picture to 4:3 normal mode.

Notes

•In TV, VIDEO, S-VIDEO, and COMPONENT(480i, 480p) modes, all screen modes can be selected.

(16:9

➞

Panorama

➞

Zoom1

➞

Zoom2

➞

4:3).

•In TV(DTV), COMPONENT(720p, 1080i), PC, HDMI modes, only 16:9 & 4:3 modes can be selected.

•In Zoom1, Zoom2 modes, you can move the picture on screen by pressing the ▲or ▼button.

(All screen modes)

•Picture size will not change when PIP size is Double.

16:9

Panorama 4:3

Zoom2 Move

Zoom1 Move

BN68-00835A-00(050~067) 4/7/05 8:56 AM Page 57

Viewing the Picture-in-Picture

PIP screen

Main screen TV

Analog Digital

(ATSC)

AV(A) S-Video(A) Component(A)

HDMI(D)

Analog

Digital

(ATSC)

AV(A)

S-Video(A)

Component(A)

HDMI(D)

Selecting the PIP Screen

1Press the MENU button. Press the ▲or ▼button to select

“Picture”, then press the ENTER button.

2Press the ▲or ▼button to select “PIP”, then press the

ENTER button.

3Press the ENTER button, then press the ▲or ▼

button to select “On”. The PIP image will appear in

the corner of the screen.

•Pressing the ▲or ▼button will alternate between

“On” and “Off”.

Note

•If the PIP On/Off will not function, check if the

V-Chip Lock (refer to page 120) is On. PIP does

not function when the V-Chip Lock is set to On.

Change the setting to Off and try it again.

4 Press the MENU button to exit.

PIP Settings

Note

•This TV has only one tuner and does not allow you to watch one TV channel in the main screen and

another channel in the PIP screen.

Mode : Dynamic

√

Size : 16:9

√

Digital NR : On

√

DNIe Demo : Off

√

My Color Control

√

Film Mode : Off

√

†


Move Enter Return

PIP : Off

√

Source : TV

√

Swap

Size :

√

Position :

√

PIP Channel : Air 3

√

PIP

Enter Return

➤

Quick way to access the PIP mode: Simply press the “PIP” button under

the cover of the remote control.

PIP : On

√

Source : TV

√

Swap

Size :

√

Position :

√

PIP Channel : DTV Air 3 - 0

√

PIP

Move Enter Return

O : PIP and swap operate

X : PIP doesn’t operate

A : Analog

D : Digital

BN68-00835A-00(050~067) 4/7/05 8:56 AM Page 58

Selecting an External Signal

You can use PIP to view a signal from an external source, such as a VCR.

1Press the MENU button. Press the ▲or ▼button to select

“Picture”, then press the ENTER button.

2Press the ▲or ▼button to select “PIP”, then press the

ENTER button.

3 Press the ▲or ▼button to select “Source”, then press

the ENTER button.

4Press the ▲or ▼button to cycle through all of the

available signal sources:

“TV”, “AV”, “S-Video”, “Component1”, “Component2”,

or “HDMI”.

The signal from these inputs will not appear if you

have not connected any equipment to the TV's

respective input jacks.

5 Press the MENU button to exit.

Notes

•The same Source can not be selected on both the main screen and subscreen.

•PC is not available in PIP picture.

Mode : Dynamic

√

Size : 16:9

√

Digital NR : On

√

DNIe Demo : Off

√

My Color Control

√

Film Mode : Off

√

†


Move Enter Return

PIP : On

Source : TV

Swap

Size :

Position :

PIP Channel : DTV Air 3 - 0

PIP

Move Enter Return

PIP : On

√

Source : TV

√

Swap

Size :

√

Position :

√

PIP Channel : DTV Air 3 - 0

√

PIP

Move Enter Return

S-Video

Component 1

Component 2

HDMI

BN68-00835A-00(050~067) 4/7/05 8:56 AM Page 59

Swapping the Contents of the PIP and Main Image

1 Press the MENU button. Press the ▲or ▼button to select

“Picture”, then press the ENTER button.

2Press the ▲or ▼button to select “PIP”, then press the

ENTER button.

3Press the ▲or ▼button to select “Swap”, then press the

ENTER button.

• The image in the PIP window will appear on the

main screen, and vice versa. (Refer to page 58)

Note

•If main picture is in PC mode, Swap is not

available.

4 Press the MENU button to exit.

Mode : Dynamic

√

Size : 16:9

√

Digital NR : On

√

DNIe Demo : Off

√

My Color Control

√

Film Mode : Off

√

†


Move Enter Return

PIP : On

√

Source : TV

√

Swap

Size :

√

Position :

√

PIP Channel : DTV Air 3 - 0

√

PIP

Move Enter Return

PIP : On

√

Source : TV

√

Swap

Size :

√

Position :

√

PIP Channel : DTV Air 3 - 0

√

PIP

Move Enter Return

BN68-00835A-00(050~067) 4/7/05 8:56 AM Page 60

Changing the Size of the PIP Window

1 Press the MENU button. Press the ▲or ▼button to select

“Picture”, then press the ENTER button.

2Press the ▲or ▼button to select “PIP”, then press the

ENTER button.

3Press the ▲or ▼button to select “Size”, then press the

ENTER button.

4Press the ▲or ▼button to select option you want, then

press the ENTER button.

5Press the MENU button to exit.

PIP : On

Source : TV

Swap

Size :

Position :

PIP Channel : DTV Air 3 - 0

PIP

Move Enter Return

PIP : On

Source : TV

Swap

Size :

Position :

PIP Channel : DTV Air 3 - 0

PIP

Move Enter Return

Mode : Dynamic

√

Size : 16:9

√

Digital NR : On

√

DNIe Demo : Off

√

My Color Control

√

Film Mode : Off

√

†


Move Enter Return

PIP : On

√

Source : TV

√

Swap

Size :

√

Position :

√

PIP Channel : DTV Air 3 - 0

√

PIP

Move Enter Return

BN68-00835A-00(050~067) 4/7/05 8:56 AM Page 61

Changing the Location of the PIP Image

1 Press the MENU button. Press the ▲or ▼button to select

“Picture”, then press the ENTER button.

2Press the ▲or ▼button to select “PIP”, then press the

ENTER button.

3 Press the ▲or ▼button to select “Position”, then press

the ENTER button.

4 Press the ▲or ▼button to select the PIP position you

want, then press the ENTER button.

5 Press the MENU button to exit.

Note

•The Double1 ( ) and Double2 ( ) mode cannot be selected in Position.

Mode : Dynamic

√

Size : 16:9

√

Digital NR : On

√

DNIe Demo : Off

√

My Color Control

√

Film Mode : Off

√

†


Move Enter Return

PIP : On

√

Source : TV

√

Swap

Size :

√

Position :

√

PIP Channel : DTV Air 3 - 0

√

PIP

Move Enter Return

PIP : On

Source : TV

Swap

Size :

Position :

PIP Channel : DTV Air 3 - 0

PIP

Move Enter Return

PIP : On

Source : TV

Swap

Size :

Position :

PIP Channel : DTV Air 3 - 0

PIP

Move Enter Return

BN68-00835A-00(050~067) 4/7/05 8:56 AM Page 62

Changing the PIP Channel

1Press the MENU button. Press the ▲or ▼button to select

“Picture”, then press the ENTER button.

2Press the ▲or ▼button to select “PIP”, then press the

ENTER button.

3Press the ▲or ▼button to select “PIP Channel”, then

press the ENTER button.

4 Press the ▲or ▼button to change the channel that

appears in the PIP window.

5 Press the MENU button to exit.

➤

Quick way to change the PIP channel: Just press the “CH “ or

“CH ” button under the cover of the remote control.

Mode : Dynamic

√

Size : 16:9

√

Digital NR : On

√

DNIe Demo : Off

√

My Color Control

√

Film Mode : Off

√

†


Move Enter Return

PIP : On

√

Source : TV

√

Swap

Size :

√

Position :

√

PIP Channel : DTV Air 3 - 0

√

PIP

Move Enter Return

PIP : On

Source : TV

Swap

Size :

Position :

PIP Channel : DTV AIR 3 - 0

PIP

Move Enter Return

DTV Air 3 - 0

▲

PIP : On

Source : TV

Swap

Size :

Position :

PIP Channel : DTV AIR 3 - 0

PIP

Move Enter Return

DTV Air 4 - 0

▲

BN68-00835A-00(050~067) 4/7/05 8:56 AM Page 63

Selecting the Sound Source

You can use this feature to hear sound from the main or sub (PIP) picture.

1Press the MENU button. Press the ▲or ▼button to

select “Sound”, then press the ENTER button.

2Press the ▲or ▼button to select “Sound Select”, then

press the ENTER button.

3Press the ▲or ▼button to select “Main” or “Sub”, then

press the ENTER button.

4 Press the MENU button to exit.

Mode : Custom

√

Equalizer

√

SRS TruSurround XT : Off

√

Multi-Track Options

√

Auto Volume : Off

√

Internal Mute : Off

√

†

Sound

Move Enter Return

…

Digital Output : Dolby Digital

Melody : On

Sound Select : Main

Sound

Move Enter Return

Main

Sub

BN68-00835A-00(050~067) 4/7/05 8:56 AM Page 64

Using the My Color Control Function in the Easy Control Menu

Skin, sky and grass tones are easily adjustable to suit your preferences.

1 Press the MENU button. Press the ▲or ▼button to select

“Picture”, then press the ENTER button.

2Press the ▲or ▼button to select “My Color Control”,

then press the ENTER button.

Press the

ENTER

button to select “Easy Control”.

Press

the œor √button to select the setting among the

various picture settings. The original picture (before

adjustment) is shown on the left side, while the selected

mode is shown on the right side.

Press the MENU button to exit the menu.

Note

•Pressing the ENTER button on the remote control for 3 seconds when there is no OSD on the

screen will display the My Color Control menu.

Setting the My Color Control Mode

My Color Control allows you to adjust colors according to your preference, by adjusting skin, sky,

and grass tones using the predefined settings (Standard, Custom, Red, Green, Blue, Yellow, Pink,

White) without affecting other colors on the screen.

➤

There are eight My Color Control modes: Standard, Custom, Red, Green,

Blue, Yellow, Pink, White.

Easy Control : Custom

√

Detail Control

√

My Color Control

Move Enter Return

Easy Control

Standard

White

Pink Custom

√

Original Custom

Move Enter Return

Easy Control

Blue

Green

Red Yellow

√

Original Red

Mode : Dynamic

√

Size : 16:9

√

Digital NR : On

√

DNIe Demo : Off

√

My Color Control

√

Film Mode : Off

√

†


Move Enter Return

BN68-00835A-00(050~067) 4/7/05 8:56 AM Page 65

My Color Control Mode Characteristics

Using My Color Control mode, you can enjoy vivid colors as shown below.

Note

•Images shown above may differ from the actual adjustment on the screen.

These images are presented for illustrative purposes.

➤

Standard Picture.

➤

Emphasizes Reds.

➤

Emphasizes Clear Blues.

➤

Emphasizes Yellows.

➤

Emphasizes Warm Skin Colors.

Red

Standard Green

White

Blue Yellow Pink

➤

Emphasizes Mild Greens.

➤

Emphasizes Whites.

BN68-00835A-00(050~067) 4/7/05 8:56 AM Page 66

My Color Control Custom Settings

Users can adjust the 6 My Color Control colors (Red, Green, Blue, Yellow, Pink, and White).

1Press the MENU button. Press the ▲or ▼button to select

“Picture”, then press the ENTER button.

2 Press the ▲or ▼button to select “My Color Control”,

then press the ENTER button.

3Press the ▲or ▼button to select “Detail Control”, then

press the ENTER button.

4Press the ▲or ▼button to select the desired color and

then press the ENTER or √ button.

5Press the œor √button to adjust the settings.

• Press the ▲or ▼button to select other colors.

6Press the ENTER or MENU button to confirm the changes

and return to the previous menu.

➤

The original picture (before adjustment) is shown on the left side,

while the picture after adjustment is shown on the right side, and an

adjustment bar on the bottom of the screen.

Detail Control

Move Enter Return

Red 50

Green 50

Blue 50

Yellow 50

Pink 60

White 50

Reset

Easy Control : Custom

√

Detail Control

√

My Color Control

Move Enter Return

Mode : Dynamic

√

Size : 16:9

√

Digital NR : On

√

DNIe Demo : Off

√

My Color Control

√

Film Mode : Off

√

†


Move Enter Return

Move Adjust Return

Detail Control

Original Adjusted

Red

BN68-00835A-00(050~067) 4/7/05 8:56 AM Page 67

Resetting the My Color Control Colors to the Factory Defaults

To return to the factory default settings for My Color Control colors, use the Reset function.

1 Press the MENU button. Press the ▲or ▼button to select

“Picture”, then press the ENTER button.

2 Press the ▲or ▼button to select “My Color Control”,

then press the ENTER button.

Press the

▲or ▼

button to select “Detail Control”, then

press the ENTER button.

Press the

▲or ▼

button to select “Reset” and press the

ENTER button.

The previously adjusted My Color Control Colors will be

reset to the factory defaults.

Press the MENU button to exit the menu.

Detail Control

Move Enter Return

Red 50

Green 50

Blue 50

Yellow 50

Pink 60

White 50

Reset

Detail Control

Move Enter Return

Red 50

Green 50

Blue 50

Yellow 50

Pink 60

White 50

Reset

Easy Control : Custom

√

Detail Control

√

My Color Control

Move Enter Return

Mode : Dynamic

√

Size : 16:9

√

Digital NR : On

√

DNIe Demo : Off

√

My Color Control

√

Film Mode : Off

√

†


Move Enter Return

BN68-00835A-00(068~077) 4/6/05 8:27 PM Page 68

PLASMA DISPLAY PANEL

Sound Control

Customizing the Sound ................................................................70

Using Automatic Sound Settings ....................................................71

Setting the TruSurround XT ............................................................72

Choosing a Multi-Channel Sound (MTS) track - Digital......................73

Choosing a Multi-Channel Sound (MTS) track - Analog ....................74

Using the Auto Volume..................................................................75

Choosing a Digital Sound Format ..................................................76

Setting the On/Off Melody ..........................................................77

Selecting the Internal Mute ............................................................78

BN68-00835A-00(068~077) 4/6/05 8:27 PM Page 69

Customizing the Sound

The sound settings can be adjusted to suit your personal preferences.

(Alternatively, you can use one of the “automatic” settings. See next page.)

1Press the MENU button. Press the ▲or ▼button to select

“Sound”, then press the ENTER button.

2Press the ▲or ▼button to select “Equalizer”, then

press the ENTER button.

3Press the œor √button to select a particular frequency

to adjust. Press the ▲or ▼button to increase or

decrease the level of the particular frequency.

4 Press the MENU button to exit.

Notes

•If you make any changes to the equalizer settings, the sound mode is automatically switched

to the custom mode.

•

L/R Sound Balance Adjustment

To adjust the sound balance of the L/R speakers.

•

Bandwidth Adjustment (100, 300, 1K, 3K, 10K)

To adjust the level of different bandwidth frequencies.

Equalizer

Move Adjust Return

Balance 100Hz 300Hz 1K 3K 10K

Mode : Custom

√

Equalizer

√

SRS TruSurround XT : Off

√

Multi-Track Options

√

Auto Volume : Off

√

Internal Mute : Off

√

†

Sound

Move Enter Return

BN68-00835A-00(068~077) 4/6/05 8:27 PM Page 70

1 Press the MENU button. Press the ▲or ▼button to

select “Sound”, then press the ENTER button.

2Press the ENTER button to select “Mode”.

3Press the ▲or ▼button to select “Standard”, “Music”,

“Movie”, “Speech”, or “Custom” sound setting,

then press the ENTER button.

4 Press the MENU button to exit.

•Choose Standard for the standard factory settings.

•Choose Music when watching music videos or concerts.

•Choose Movie when watching movies.

•Choose Speech when watching a show that is mostly dialog (i.e., news).

• Choose Custom to recall your personalized settings (see “Customizing the Sound”, page 70).

Using Automatic Sound Settings

Your TV has automatic sound settings (“Standard”, “Music”, “Movie”, and “Speech”) that are

preset at the factory. Or, you can select “Custom,” which automatically recalls your personalized

sound settings.

➤

Quick way to access the picture setting: Just press the “S.MODE”

button on the remote control.

Mode : Custom

√

Equalizer

√

SRS TruSurround XT : Off

√

Multi-Track Options

√

Auto Volume : Off

√

Internal Mute : Off

√

†

Sound

Move Enter Return

Mode : Custom

Equalizer

SRS TruSurround XT : Off

Multi-Track Options

Auto Volume : Off

Internal Mute : Off

†

Sound

Move Enter Return

Standard

Music

Movie

Speech

Custom

Mode : Custom

Equalizer

SRS TruSurround XT : Off

Multi-Track Options

Auto Volume : Off

Internal Mute : Off

†

Sound

Move Enter Return

Standard

Music

Movie

Speech

Custom

BN68-00835A-00(068~077) 4/6/05 8:27 PM Page 71

1 Press the MENU button. Press the ▲or ▼button to select

“Sound”, then press the ENTER button.

2Press the ▲or ▼button to select “SRS TruSurround XT”,

then press the ENTER button.

3Press the ▲or ▼button to change the setting (Off, 3D

Mono, or Stereo), then press the ENTER button.

4 Press the MENU button to exit.

Setting the TruSurround XT

TruSurround XT is a patented SRS technology that solves the problem of playing 5.1 multichannel

content over two speakers. TruSurround delivers a compelling, virtual surround sound experience

through any two-speaker playback system, including internal television speakers. It is fully

compatible with all multichannel formats.

Mode : Custom

Equalizer

SRS TruSurround XT : Off

Multi-Track Options

Auto Volume : Off

Internal Mute : Off

†

Sound

Move Enter Return

Off

3D Mono

Stereo

Mode : Custom

Equalizer

SRS TruSurround XT : Off

Multi-Track Options

Auto Volume : Off

Internal Mute : Off

†

Sound

Move Enter Return

Off

3D Mono

Stereo

Mode : Custom

√

Equalizer

√

SRS TruSurround XT : Off

√

Multi-Track Options

√

Auto Volume : Off

√

Internal Mute : Off

√

†

Sound

Move Enter Return

BN68-00835A-00(068~077) 4/6/05 8:27 PM Page 72

Choosing a Multi-Channel

Sound (MTS) track - Digital

The digital-TV transmission system is capable of simultaneous transmission of many audio tracks (for

example, simultaneous translations of the program into foreign languages). The availability of these

additional “multitracks” depends upon the program.

1Press the MENU button. Press the ▲or ▼button to

select “Sound”, then press the ENTER button.

2Press the ▲or ▼button to select “Multi-Track

Options”, then press the ENTER button.

3Press the ENTER button to select “Preferred

Language”. Press the ▲or ▼button to choose the

language (English, Spanish, or French) you want,

then press the ENTER button.

4Press the MENU button to exit.

➤

Quick way to access the MTS menu: Just press the “MTS” button

on the remote control. You can listen in a language other than the

favorite language by pressing the MTS button.

Preferred Language : English

√

Multi-Track Sound : Stereo

√

Multi-Track Options

Enter Return

Preferred Language : English

Multi-Track Sound : Stereo

Multi-Track Options

Move Enter Return

English

Spanish

French

Mode : Custom

√

Equalizer

√

SRS TruSurround XT : Off

√

Multi-Track Options

√

Auto Volume : Off

√

Internal Mute : Off

√

†

Sound

Move Enter Return

BN68-00835A-00(068~077) 4/6/05 8:27 PM Page 73

1 Press the MENU button. Press the ▲or ▼button to select

“Sound”, then press the ENTER button.

2Press the ▲or ▼button to select “Multi-Track Options”,

then press the ENTER button.

3Press the ENTER button to select “Multi-Track Sound”.

Press the ▲or ▼button to select a setting you want,

then press the ENTER button.

4 Press the MENU button to exit.

•Choose “Mono” for channels that are broadcasting in mono, or if you are having difficulty

receiving a stereo signal.

•Choose “Stereo” for channels that are broadcasting in stereo.

•Choose “SAP” to listen to the Separate Audio Program, which is usually a foreign-language

translation.

Choosing a Multi-Channel

Sound (MTS) track - Analog

Depending on the particular program being broadcast, you can listen to Mono, Stereo or SAP.

➤

Quick way to access the MTS menu: Just press the “MTS” button

on the remote control repeatedly to select one of the settings.

Preferred Language : English

√

Multi-Track Sound : Stereo

√

Multi-Track Options

Move Enter Return

Preferred Language : English

Multi-Track Sound : Stereo

Multi-Track Options

Move Enter Return

Mono

Stereo

SAP

Mode : Custom

√

Equalizer

√

SRS TruSurround XT : Off

√

Multi-Track Options

√

Auto Volume : Off

√

Internal Mute : Off

√

†

Sound

Move Enter Return

BN68-00835A-00(068~077) 4/6/05 8:27 PM Page 74

Using the Auto Volume

Each broadcasting station has its own signal conditions, which can make it necessary to adjust the

volume every time the channel is changed. “Auto Volume” lets you automatically adjust the volume

of the desired channel by lowering the sound output when the modulation signal is high or by

raising the sound output when the modulation signal is low.

1 Press the MENU button. Press the ▲or ▼button to select

“Sound”, then press the ENTER button.

2Press the ▲or ▼button to select “Auto Volume”, then

press the ENTER button.

3Press the ▲or ▼button to select “On”, then press the

ENTER button.

• Pressing the ▲or ▼button will alternate

between “On” and “Off”.

4 Press the MENU button to exit.

Mode : Custom

Equalizer

SRS TruSurround XT : Off

Multi-Track Options

Auto Volume : Off

Internal Mute : On

†

Sound

Move Enter Return

Mode : Custom

Equalizer

SRS TruSurround XT : Off

Multi-Track Options

Auto Volume : Off

Internal Mute : On

†

Sound

Move Enter Return

Mode : Custom

√

Equalizer

√

SRS TruSurround XT : Off

√

Multi-Track Options

√

Auto Volume : Off

√

Internal Mute : Off

√

†

Sound

Move Enter Return

Off

BN68-00835A-00(068~077) 4/6/05 8:27 PM Page 75

1 Press the MENU button. Press the ▲or ▼button to select

“Sound”, then press the ENTER button.

2Press the ▲or ▼button to select “Digital Output”, then

press the ENTER button.

Press the ▲or ▼button to select “Dolby Digital” or

“PCM”, then press the ENTER button.

3Press the MENU button to exit.

Choosing a Digital Sound Format

Digital sound can be output from the rear panel connector on your TV. The digital sound outputs

are connectors labeled “Optical” and “Coaxial”. After connecting a digital-audio component, you

must specify the transmission format (Dolby or PCM, as appropriate to your digital audio

component).

…

Digital Output : PCM

Melody : On

Sound Select : Main

Sound

Move Enter Return

Manufactured under license from Dolby Laboratories.

“Dolby” and the double-D symbol are trademarks of Dolby

Laboratories.

Mode : Custom

√

Equalizer

√

SRS TruSurround XT : Off

√

Multi-Track Options

√

Auto Volume : Off

√

Internal Mute : Off

√

†

Sound

Move Enter Return

Dolby Digital

PCM

BN68-00835A-00(068~077) 4/6/05 8:27 PM Page 76

1 Press the MENU button. Press the ▲or ▼button to

select “Sound”, then press the ENTER button.

2Press the ▲or ▼button to select “Melody”, then press

the ENTER button. Press the ▲or ▼button to

select “On” or “Off”, then press the ENTER button.

3 Press the MENU button to exit.

Setting the On/Off Melody

A melody sound can be set to come on when the TV is powered On or Off.

…

Digital Output : Dolby Digital

Melody : On

Sound Select : Main

Sound

Move Enter Return

Mode : Custom

√

Equalizer

√

SRS TruSurround XT : Off

√

Multi-Track Options

√

Auto Volume : Off

√

Internal Mute : Off

√

†

Sound

Move Enter Return

Off

BN68-00835A-00(068~077) 4/6/05 8:27 PM Page 77

Selecting the Internal Mute

Sound output from the TV speakers is muted.

1 Press the MENU button. Press the ▲or ▼button to select

“Sound”, then press the ENTER button.

2Press the ▲or ▼button to select “Internal Mute”, then

press the ENTER button.

3Press the ▲or ▼button to select “On”, then press the

ENTER button.

• Pressing the ▲or ▼button will alternate between

“On” and “Off”.

4 Press the MENU button to exit.

Notes

•When Internal Mute is set to “On”, Sound menus except Multi-Track Options and Digital Output

cannot be adjusted.

•The monitor and digital audio outputs (Optical, Coaxial) remain enabled.

•The VOL +, VOL - and Mute buttons do not operate when the Internal Mute is set to On.

Mode : Custom

Equalizer

SRS TruSurround XT : Off

Multi-Track Options

Auto Volume : Off

Internal Mute : On

†

Sound

Move Enter Return

Mode : Custom

Equalizer

SRS TruSurround XT : Off

Multi-Track Options

Auto Volume : Off

Internal Mute : On

†

Sound

Move Enter Return

Mode : Custom

√

Equalizer

√

SRS TruSurround XT : Off

√

Multi-Track Options

√

Auto Volume : Off

√

Internal Mute : Off

√

†

Sound

Move Enter Return

Off

BN68-00835A-00(078~087) 4/6/05 8:28 PM Page 78

PLASMA DISPLAY PANEL

Channel Control

Selecting the Antenna ..................................................................80

Selecting Your Favorite Channels ..................................................81

Labeling the Channels ..................................................................82

Viewing the Channel Lists..............................................................83

Editing the Channel Lists ..............................................................84

Fine Tuning Analog Channels ........................................................85

Checking the Digital-Signal Strength ..............................................86

LNA (Low Noise Amplifier)............................................................87

BN68-00835A-00(078~087) 4/6/05 8:28 PM Page 79

Selecting the Antenna

1Press the MENU button. Press the ▲or ▼button to select

“Channel”, then press the ENTER button.

2Press the ENTER button to select “Antenna”.

Press the ▲or ▼button to select “Air” or “Cable”,

then press the ENTER button.

Notes

•If the antenna is connected to ANT 1 IN

(CABLE IN), select “CABLE” and if it is

connected to ANT 2 IN (AIR IN), select “Air”.

•If both ANT 1 IN and ANT 2 IN are connected,

select the antenna input you want.

If the antenna input is not selected properly,

noise may appear on the screen.

Antenna : Air

Auto Program

Add / Delete

Favorite Channels

Name

Fine Tune

†

Channel

Move Enter Return

Antenna : Air

√

Auto Program

√

Add / Delete

√

Favorite Channels

√

Name

√

Fine Tune

√

†

Channel

Move Enter Return

Air

Cable

BN68-00835A-00(078~087) 4/6/05 8:28 PM Page 80

8181

Selecting Your Favorite Channels

You can store your favorite channels for each available input source (such as TV and Cable box).

Then, when you press the FAV.CH button on the remote control, the TV displays only the favorite

channels you previously stored, allowing you to quickly and easily find frequently watched channels.

To Store Your Favorite Channels:

1Press the MENU button.

Press the ▲or ▼button to select “Channel”, then

press the ENTER button.

2Press the ▲or ▼button to select “Favorite Channels”,

then press the ENTER button.

Press the ▲or ▼button to select a channel as

a favorite channel, then press the ENTER button.

Press the ENTER button again to deselect the

selected channel.

3Press the MENU button to exit.

Notes

•Only memorized channels can be set as favorite channels.

•Select All : Press to select all channels.

Clear All : Press to clear all channels.

To View Your Favorite Channels:

Press the FAV.CH button repeatedly to jump from one

favorite channel to another.

Antenna : Air

√

Auto Program

√

Add / Delete

√

Favorite Channels

√

Name

√

Fine Tune

√

†

Channel

Move Enter Return

Favorite Channels

Move Enter Return

Favorite Channels

Move Enter Return

Air 6

Air 7

Air 9

Air 11

Air 13

Air 14

Air 16

†

Select All

Clear All

Air 6

Air 7

Air 9

Air 11

Air 13

Air 14

Air 16

†

Select All

Clear All

BN68-00835A-00(078~087) 4/6/05 8:28 PM Page 81

Labeling the Channels

Use this feature to assign an easy-to-remember label to any channel (i.e., “CBS”, “ESPN”, “PBS2”,

“CNN1”, etc.) A label consists of five fields, where each field is a letter, a number or a blank.

When the INFO button is pressed, the channel label will appear next to the channel number.

1Press the MENU button.

Press the ▲or ▼button to select “Channel”, then

press the ENTER button.

2Press the ▲or ▼button to select “Name”, then press the

ENTER button.

Press the ▲or ▼button to select the channel to be

assigned to a new name, then press the ENTER button.

Press the ▲or ▼button to select a letter, a number

or a blank (Results in this sequence: A...Z, 0...9,

, *, /, blank).

Press the √button to switch to the next field, which

will be selected.

Select a second letter or digit by pressing the ▲or

▼button, as above.

Repeat the process to select the last three digits.

When you have finished, press the ENTER button

to assign the new name.

• To clear the entered channel name, move to “Clear”

by using the œ/√button and press the ENTER.

3Press the MENU button to exit.

Notes

•The names of digital broadcasting channels are automatically assigned and thus cannot be

assigned by users.

•When you use CableCARD to watch cable broadcasting, it might take some time for a channel

name to be displayed due to data-receiving time.

Name

Move Enter Return

Antenna : Air

√

Auto Program

√

Add / Delete

√

Favorite Channels

√

Name

√

Fine Tune

√

†

Channel

Move Enter Return

Air 6

Air 7

Air 9

Air 11

Air 13

†

Clear

Name

Move Adjust Return

Clear

…

†

Air 6 A

Air 7

Air 9

Air 11

Air 13

†

BN68-00835A-00(078~087) 4/6/05 8:28 PM Page 82

Viewing the Channel Lists

You can display a list of all channels or your favorite channels.

1Press the MENU button.

Press the ▲or ▼button to select “Channel”, then press

the ENTER button.

2Press the ▲or ▼button to select “Channel List”, then

press the ENTER button.

3Press the ▲or ▼button to select “All” or “Favorite”, then

press the ENTER button.

To toggle between your favorite channels or all channels,

use the yellow button on the remote control.

• Red button : Press to display the previous channel

list page.

Green button : Press to display the next channel

Yellow button : Press to toggle between your favorite

channels or all channels.

Blue or EXIT button : Press to exit.

Alternate method :

Press the CH LIST button on the remote control to display a list

of channels.

➤

Quick way to view the Channel Lists: Just press the “CH LIST”

button on the remote control.

All

√

Edit

√

Favorite

√

Channel List

Move Enter Return

All

2-1

13-1 TV #1

13-2 TV #1

13-3 TV #3

13-4 TV #4

32-10

69-98 NCAM-H..

Channel List

Favorite Exit

Move Watch Return

Antenna : Air

√

Auto Program

√

Add / Delete

√

Favorite Channels

√

Name

√

Fine Tune

√

†

Channel

Move Enter Return

BN68-00835A-00(078~087) 4/6/05 8:28 PM Page 83

Editing the Channel Lists

You can edit channels to be added or deleted.

1Press the MENU button.

Press the ▲or ▼button to select “Channel”, then press

the ENTER button.

2Press the ▲or ▼button to select “Channel List”, then

press the ENTER button.

3Press the ▲or ▼button to select “Edit”, then press the

ENTER button.

4Press the ▲, ▼,œor √button to select channel, then

press the ENTER button. Then, the channel can be

deleted or added. The deleted channel will be dim in

the channel list.

• Red button : Press to display the previous channel

list page.

Green button : Press to display the next channel

Yellow button : Press to toggle between your favorite

channels or all channels.

Blue or EXIT button : Press to exit.

5 Press the MENU button to exit.

All

√

Edit

√

Favorite

√

Channel List

Move Enter Return

Edit

2-1

13-1 TV #1

13-2 TV #1

13-3 TV #3

13-4 TV #4

32-10

69-98 NCAM-H..

Channel List

Add All Delete All

Move Delete Return

Edit

2-1

13-1 TV #1

13-2 TV #1

13-3 TV #3

13-4 TV #4

32-10

69-98 NCAM-H..

Channel List

Add All Delete All

Move Add Return

Antenna : Air

√

Auto Program

√

Add / Delete

√

Favorite Channels

√

Name

√

Fine Tune

√

†

Channel

Move Enter Return

BN68-00835A-00(078~087) 4/6/05 8:44 PM Page 84

Fine Tuning Analog Channels

Use fine tuning to manually adjust a particular channel for optimal reception.

1Press the MENU button. Press the ▲or ▼button to select

“Channel”, then press the ENTER button.

2Press the ▲or ▼button to select “Fine Tune”, then press

the ENTER button.

3Press the œ or √ button to adjust the fine tuning.

To store the fine tuning setting in the TV’s memory, press

the ENTER button.

4To reset the fine tuning setting, press the ▼button

to select “Reset”, then press the ENTER button.

5 Press the MENU button to exit.

Notes

•Only analog TV channels can be fine tuned.

•“*” will appear next to the name of fine-tuned channels.

Fine Tune

AIR 4 Fine Tuned

Reset

Adjust Save Return

Fine Tune

AIR 4

Reset

Move Enter Return

Antenna : Air

√

Auto Program

√

Add / Delete

√

Favorite Channels

√

Name

√

Fine Tune

√

†

Channel

Move Enter Return

Fine Tune

AIR 4

Reset

Adjust Save Return

BN68-00835A-00(078~087) 4/6/05 8:28 PM Page 85

Checking the Digital-Signal Strength

Unlike analog channels, which can vary in reception quality from “snowy” to clear, digital (HDTV)

channels have either perfect reception quality or you will not receive them at all. So, unlike analog

channels, you cannot fine tune a digital channel. You can, however, adjust your antenna to improve

the reception of available digital channels.

1Press the MENU button.

Press the ▲or ▼button to select “Channel”, then press

the ENTER button.

2Press the ▲or ▼button to select “Signal Strength”,

then press the ENTER button.

If the signal strength meter indicates that the signal

is weak, physically adjust your antenna to increase

the signal strength.

Continue to adjust the antenna until you find the

best position with the strongest signal.

3Press the MENU button to exit.

Signal Strength

Return

Antenna : Air

√

Auto Program

√

Add / Delete

√

Favorite Channels

√

Name

√

Fine Tune

√

†

Channel

Move Enter Return

BN68-00835A-00(078~087) 4/6/05 8:28 PM Page 86

LNA (Low Noise Amplifier)

If the TV is operating in a weak-signal area, sometimes the LNA function can improve the reception

(a low-noise preamplifier boosts the incoming signal).

1Press the MENU button. Press the ▲or ▼button to select

“Channel”, then press the ENTER button.

2Press the ▲or ▼button to select “LNA”, then press the

ENTER button.

3Press the ▲or ▼button to select “On” or “Off”, then

press the ENTER button.

4 Press the MENU button to exit.

Notes

•LNA functions only when antenna is set to AIR and the settings will be stored separately in

each channel. (See “Selecting the Antenna” on page 80.)

•If the picture is noisy with the LNA set to On, select Off.

•The LNA setting must be made separately for each channel.

Channel

Move Enter Return

…

Channel List

Signal Strength

LNA : Off

…

Channel List

Signal Strength

LNA : Off

Channel

Move Enter Return

Antenna : Air

√

Auto Program

√

Add / Delete

√

Favorite Channels

√

Name

√

Fine Tune

√

†

Channel

Move Enter Return

Off

BN68-00835A-00(078~087) 4/6/05 8:29 PM Page 87

BN68-00835A-00(088~097) 4/6/05 8:30 PM Page 88

PLASMA DISPLAY PANEL

Connecting a PC and Operation

Connecting a PC..........................................................................90

Changing the Position of the Image................................................94

Picture Quality Adjustment ............................................................95

Image Reset ................................................................................98

BN68-00835A-00(088~097) 4/6/05 8:30 PM Page 89

Connecting a PC

Connection to a Macintosh computer may require an adapter.

Audio cable

PC cable

Connecting a PC (15p D-SUB) to the TV

Connect a PC cable between the PC Output jack on the PC and the RGB input jack (PC IN)

on the TV.

Connect a Audio cable between the Audio jack on the PC and the Audio input jacks (PC AUDIO IN)

on the TV.

Notes

•Please be sure to match the color coded input terminals and cable jacks.

•A PC will not operate when connected with a HDMI/DVI cable.

To watch the PC screen:

1. Turn on your TV.

2. Press the SOURCE button on the remote control or SOURCE button on the front panel

to select “PC”.

3. Turn on your PC and check for PC system requirements. (Refer to pages 92 and 93 for PC

system requirements.)

4. Adjust the PC screen. (Refer to pages 94 - 96.)

Power cord

BN68-00835A-00(088~097) 4/6/05 8:30 PM Page 90

9191

Setting up Your TV (Plug and Play)

Our adoption of the new VESAPlug and Play solution eliminates complicated and time consuming

setup. It allows you to install your monitor in a Plug and Play compatible system, without the usual setup

hassles and confusion. Your PC system can easily identify and configure itself for use with your TV.

This TV automatically tells the PC system its Extended Display Identification data (EDID) using Display

Data Channel (DDC) protocols.

BN68-00835A-00(088~097) 4/6/05 8:30 PM Page 91

How to Set up Your PC Software (Windows only)

The Windows display-settings for a typical computer are shown below. But the actual screens on your

PC will probably be different, depending upon your particular version of Windows and your particular

video card. But even if your actual screens look different, the same, basic set-up information will apply

in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.)

Right click the mouse on the Windows

Desktop, then click on Properties.

The Display Dialog-Box will be displayed.

Click on Settings, then set the Display Mode

with reference to the Display Modes Table.

You do not need to change the Colors settings.

Click on Advanced. A new settings dialog box

will be displayed.

Click on the Monitor tab, then set the

Screen Refresh Rate with reference to the

Display Modes Table. Set the Vertical

Frequency and Horizontal Frequency

individually if you can do so instead of setting

the Screen Refresh Rate.

Press the OK button, close the window, then

press the OK button on the Display Registration

Information window. Automatic re-booting may

commence at this moment.

Shutdown the PC, and connect it to your TV.

(See page 90)

• The actual screens on your PC may look

different, depending on your particular

version of Windows and the type of your PC.

• When you use your TV as a PC monitor, it

supports Colors up to 32 bits.

• In this case, the display on the TV may look

different depending on your particular version

of Windows or the PC manufacturer.

• When connecting a PC (including the DVI

connection), you must set it to the display

settings that are supported by the TV.

Otherwise, the message Out of input

range will be displayed.

Continued...

BN68-00835A-00(088~097) 4/6/05 8:30 PM Page 92

Note

Both screen position and size will vary, depending on the type of PC monitor and its resolution.

The table below shows all of the display modes that are supported:

•The interlace mode is not supported.

•The TV operates abnormally if a non-standard video format is selected.

•The table above conforms to IBM/VESA regulations and is based on using the Analog Input.

•A “

✔

” mark means that this mode can be supported.

Notes

•The PC text quality of HP-R4252 is optimum in XGA mode (1024 x 768@60Hz).

•The PC text quality of HP-R5052 is optimum in WXGA mode (1360 x 768@60Hz).

•When this TV is used as a PC display, 32-bit color is supported.

•Depending on the manufacturer, your PC display screen might appear different.

(and depending on your particular version of Windows.)

Check your PC instruction book for information about connecting your PC to a TV.

•If a vertical and horizontal frequency-select mode exists, select 60Hz (vertical) and 48.4KHz (horizontal).

•In some cases, abnormal signals (such as stripes) might appear on the TV screen when the PC power

is turned off (or if the PC is disconnected). If so, press the SOURCE button on the remote control or

SOURCE button on the front panel to enter the VIDEO mode. Also, make sure that the PC is connected.

•Connect only a PC monitor to the monitor output port while viewing the PC screen.

(Otherwise, random signals might appear).

Video Signal

IBM PC / AT

Compatible

Resolution

(Dot X Line)

Vertical

Frequency (Hz)

640 X 350

720 X 400

640 X 480

800 X 600

1024 X 768

1280 X 720

1360 X 768

70.086

70.087

59.940

70.000

72.809

75.000

56.250

60.317

70.000

72.188

75.000

60.004

70.069

72.000

75.029

59.855

60.015

Horizontal

Frequency (KHz)

31.469

35.000

37.861

37.500

35.156

37.879

43.750

48.077

46.875

48.363

56.476

57.672

60.023

44.772

47.712

Vertical

Polarity

N/P

Horizontal

Polarity HP-R5052HP-R4252

N/P

✔

BN68-00835A-00(088~097) 4/6/05 8:30 PM Page 93

After connecting the TV to your PC, adjust the position of the screen if it is not well-aligned.

Preset:

• Press the SOURCE button to select “PC.”

1Press the MENU button. Press the ▲or ▼button to select

“Setup”, then press the ENTER button.

2Press the ▲or ▼button to select “PC”, then press the

ENTER button.

3Press the ▲or ▼button to select “Position”, then press

the ENTER button.

4 Adjust the position of screen by pressing the

▲/▼/œ/√button.

5 Press the MENU button to exit.

Changing the Position of the Image

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

Image Lock

√

Position

√

Auto Adjustment

Image Reset

Move Enter Return

Position

Move Enter Return

Position

Move Enter Return

BN68-00835A-00(088~097) 4/6/05 8:30 PM Page 94

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

Picture Quality Adjustment

Picture Automatic Adjustment

Preset:

•Press the SOURCE button to select “PC”.

1Press the MENU button. Press the ▲or ▼button to select

“Setup”, then press the ENTER button.

2Press the ▲or ▼button to select “PC”, then press the

ENTER button.

3Press the ▲or ▼button to select “Auto Adjustment”,

then press the ENTER button.

The message “Auto Adjustment in progress. Please wait.”

appears on the screen and the picture adjustments are

automatically activated.

Image Lock

√

Position

√

Auto Adjustment

Image Reset

Move Enter Return

Auto Adjustment in progress. Please wait.

BN68-00835A-00(088~097) 4/6/05 8:30 PM Page 95

Coarse Adjustment

Preset:

•Press the SOURCE button to select “PC”.

1Press the MENU button. Press the ▲or ▼button to select

“Setup”, then press the ENTER button.

2Press the ▲or ▼button to select “PC”, then press the

ENTER button.

3Press the ENTER button to select “Image Lock”.

4Press the ENTER button again to select “Coarse”.

Remove picture noise (vertical stripes) on the screen

by pressing the œ or √button. (If Coarse is not set

properly, vertical stripes will appear on the screen.)

• Press the ▲or ▼button to select another item.

5 Press the MENU button to exit.

Image Lock

√

Position

√

Auto Adjustment

Image Reset

Move Enter Return

Coarse 50

Fine 0

Image Lock

Move Enter Return

Coarse

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

BN68-00835A-00(088~097) 4/6/05 8:30 PM Page 96

Fine Tuning (Fine)

Preset:

•Press the SOURCE button to select “PC”.

1Press the MENU button. Press the ▲or ▼button to select

“Setup”, then press the ENTER button.

2Press the ▲or ▼button to select “PC”, then press the

ENTER button.

3Press the ENTER button to select “Image Lock”.

4Press the ▲or ▼button to select “Fine”, then press the

ENTER button.

Remove picture noise on the screen by pressing the

œ or √button. (If Fine is not set properly, noise will

appear on the screen.)

• Press the ▲or ▼button to select another item.

5 Press the MENU button to exit.

Image Lock

√

Position

√

Auto Adjustment

Image Reset

Move Enter Return

Coarse 50

Fine 0

Image Lock

Move Enter Return

Fine

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

BN68-00835A-00(088~097) 4/6/05 8:30 PM Page 97

Image Reset

Preset:

•Press the SOURCE button to select “PC”.

1Press the MENU button. Press the ▲or ▼button to select

“Setup”, then press the ENTER button.

2Press the ▲or ▼button to select “PC”, then press the

ENTER button.

3Press the ▲or ▼button to select “Image Reset”, then

press the ENTER button.

The message “Image Reset is completed.” appears on

the screen.

• The previously adjusted settings will be reset to the

factory defaults.

Image Lock

√

Position

√

Auto Adjustment

Image Reset

Move Enter Return

Image Reset is completed.

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

BN68-00835A-00(098~103) 4/6/05 8:31 PM Page 98

PLASMA DISPLAY PANEL

Time Setting

Setting the Clock.....................................................................100

Setting the On/Off Timer .........................................................102

Setting the Sleep Timer ............................................................103

BN68-00835A-00(098~103) 4/6/05 8:31 PM Page 99

Setting the Clock

Setting the clock is necessary in order to use the various timer features of the TV.

Also, you can check the time while watching the TV. (Just press the INFO button.)

100

Option 1: Setting the Clock Manually

1Press the MENU button. Press the ▲or ▼button to select

“Setup”, then press the ENTER button.

2Press the ▲or ▼button to select “Time”, then press the

ENTER button. Press the ENTER button to select “Clock”.

3Press the ENTER button to select “Clock Mode”. Press the

▲or ▼button to select “Manual”, then press the ENTER

button.

4Press the ▲or ▼button to select “Clock Set”, then press

the ENTER button.

5Press the œor √button to move to “Month”, “Day”,

“Year”, “Hour”, “Minute”, or “am/pm”.

Set the clock you want by pressing the ▲or ▼button,

then press the ENTER button.

6Press the MENU button to exit.

Notes

•The current time will appear every time you press the INFO button.

•You can set the Month, Day, Year, Hour and Minute directly by pressing the number buttons on the

remote control.

----

-- --

Clock

√

Sleep Timer : Off

√

On Timer : Off

√

Off Timer : Off

√

Time

Move Enter Return

Clock Mode : Manual

√

Clock Set

√

Time Zone

√

DST : No

√

Clock

Move Enter Return

Set current date and time.

Clock Set

Move Adjust Return

Month Day Year

Hour Minute am/pm

…

†

-- -- ----

-- -- --

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

BN68-00835A-00(098~103) 4/6/05 8:31 PM Page 100

101

Option 2: Setting the Clock Automatically

The Clock can be set automatically if you are receiving a digital signal.

1Press the MENU button.

Press the ▲or ▼button to select “Setup”, then press

the ENTER button.

2Press the ▲or ▼button to select “Time”, then press the

ENTER button.

Press the ENTER button to select “Clock”.

3Press the ENTER button to select “Clock Mode”.

Press the ▲or ▼button to select “Auto”, then press

the ENTER button.

4Press the ▲or ▼button to select “Time Zone”, then

press the ENTER button.

Press the ▲or ▼button to highlight the time zone for

your local area (and to move the highlight to the

appropriate time zone on the map of the United States),

then press the enter button.

5Press the ▲or ▼button to select “DST” (Daylight Saving

Time), then press the ENTER button.

Press the ▲or ▼button to select “Yes” or “No”, then

press the ENTER button.

6Press the MENU button to exit.

Note

•Depending on the broadcast station and signal,

the auto time may not be set correctly. If this occurs,

set the time manually.

101

----

-- --

Clock

√

Sleep Timer : Off

√

On Timer : Off

√

Off Timer : Off

√

Time

Move Enter Return

Clock Mode : Auto

√

Clock Set

√

Time Zone

√

DST : No

√

Clock

Move Enter Return

Clock

Move Enter Return

Time Zone

Move Enter Return

Select the time zone in which you live.

Eastern

Central

Mountain

Pacific

Alaska

Hawaii

Clock Mode : Auto

Clock Set

Time Zone

DST : No

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

Yes

BN68-00835A-00(098~103) 4/6/05 8:31 PM Page 101

1Press the MENU button.

Press the ▲or ▼button to select “Setup”, then press

the ENTER button.

2Press the ▲or ▼button to select “Time”, then press the

ENTER button.

Press the ▲or ▼button to select “On Timer”, then

press the ENTER button.

Press the ▲or ▼button to adjust “Hour”, then press

the √button to move to the next step.

Set other items using the same method as above.

To activate “On Timer” with the setting entered, set

Activation to “Yes” by pressing …or † button.

When finished, press the MENU button to return.

• The current time will appear every time you press

the INFO button.

• You can set the hour, minute, channel and volume

directly by pressing the number buttons on the

remote control.

3Press the ▲or ▼button to select “Off Timer”, then press

the ENTER button.

Press the ▲or ▼button to adjust “Hour”, then press

the √button to move to the next step.

Set other items using the same method as above.

To activate “Off Timer” with the setting entered, set

Activation to “Yes” by pressing …or † button.

When finished, press the ENTER button.

4Press the MENU button to exit.

Note

•Auto Power Off

When you set the timer “On”, the television will eventually turn off, if no controls are operated for

3 hours after the TV was turned on by the timer.

This function is only available in timer “On” mode and prevents overheating or leakage, which

may occur if a TV is on for too long (when you are on vacation, for example).

Setting the On/Off Timer

2005

00 am

Clock

√

Sleep Timer : Off

√

On Timer : Off

√

Off Timer : Off

√

Time

Move Enter Return

Set on timer.

On Timer

Move Adjust Return

Set off timer.

Off Timer

Move Adjust Return

Hour Minute am/pm Antenna

Channel Volume Activation

…

†

12 00

am Air

310No

Hour Minute am/pm Activation

…

†

am No

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

102

BN68-00835A-00(098~103) 4/6/05 8:31 PM Page 102

103

1Press the MENU button. Press the ▲or ▼button to select

“Setup”, then press the ENTER button.

2Press the ▲or ▼button to select “Time”, then press the

ENTER button.

Press the ▲or ▼button to select “Sleep Timer”, then

press the ENTER button.

3Press the ▲or ▼button to adjust “Minute”.

• Setting the Timer sets the Activation to “Yes”

automatically.

4To cancel the set sleep timer:

Press the √button to select “Activation”.

Press the ▲or ▼button to select “No”, then press

the ENTER button.

5Press the MENU button to exit.

Setting the Sleep Timer

The sleep timer automatically shuts off the TV after a preset time (from 30 to 180 minutes).

Set sleep timer.

Sleep Timer

Move Adjust Return

Set sleep timer.

Sleep Timer

Move Adjust Return

Minute Activation

…

†

---

Minute Activation

…

†

30 Yes

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

----

-- --

Clock

√

Sleep Timer : Off

√

On Timer : Off

√

Off Timer : Off

√

Time

Move Enter Return

BN68-00835A-00(098~103) 4/6/05 8:31 PM Page 103

BN68-00835A-00(104~115) 4/7/05 8:58 AM Page 104

PLASMA DISPLAY PANEL

Function Description

Selecting a Menu Language ...................................................106

Digital Noise Reduction .........................................................107

Selecting the Film Mode.........................................................108

Setting the Blue Screen ..........................................................109

Using the Color Weakness Enhancement Option ......................110

Viewing Closed Captions (On-Screen Text Messages) - Analog...111

Viewing Closed Captions (On-Screen Text Messages) - Digital....112

Menu Transparency Level.......................................................114

Using the Energy Saving feature .............................................115

Preventing Screen Burn-in.......................................................116

Reducing the Effects of Screen Burn.........................................117

Setting the Function Help .......................................................118

Using the V-Chip ...................................................................119

Electronic Program Guide ......................................................125

Reminder List ........................................................................129

Using the CableCARD ...........................................................131

Using the CableCARD Setup Function......................................132

BN68-00835A-00(104~115) 4/7/05 8:58 AM Page 105

Selecting a Menu Language

106

1Press the MENU button. Press the ▲or ▼button to select

“Setup”, then press the ENTER button.

2 Press the ENTER button to select “Language”.

3Press the ▲or ▼button to select the appropriate

language: “English”, “Spanish”, or “French”.

Press the ENTER button.

4 Press the MENU button to exit.

Plug&Play

√

Idioma : Español

√

Tiempo

√

V-Chip

√

Subtítulo

√

Transpar. del menú : Medio

√

†

Más

Configuración

Mover Ingresar Regresar

Plug & Play

Language : English

Time

V-Chip

Caption

Menu Transparency : Medium

†

Setup

Move Enter Return

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

English

Spanish

French

BN68-00835A-00(104~115) 4/7/05 8:58 AM Page 106

107107

Digital Noise Reduction

If the broadcast signal received by your TV is weak, you can activate the Digital Noise Reduction

feature to help reduce any static and ghosting that may appear on the screen.

1Press the MENU button. Press the ▲or ▼button to select

“Picture”, then press the ENTER button.

2Press the ▲or ▼button to select “Digital NR”, then

press the ENTER button.

3Press the ▲or ▼button to select “On” or “Off”, then

press the ENTER button.

4Press the MENU button to exit.

Note

•The Digital NR function is available in all modes except PC.

Mode : Dynamic

√

Size : 16:9

√

Digital NR : On

√

DNIe Demo : Off

√

My Color Control

√

Film Mode : Off

√

†


Move Enter Return

Mode : Dynamic

Size : 16:9

Digital NR : On

DNIe Demo : Off

My Color Control

Film Mode : Off

†


Move Enter Return

Off

Mode : Dynamic

Size : 16:9

Digital NR : On

DNIe Demo : Off

My Color Control

Film Mode : Off

†


Move Enter Return

Off

BN68-00835A-00(104~115) 4/15/05 7:11 PM Page 107

108

Selecting the Film Mode

On: Automatically senses and processes film signals from all sources and adjusts the picture for

optimum quality.

Off: Switches off the Film mode.

1Press the MENU button. Press the ▲or ▼button to select

“Picture”, then press the ENTER button.

2Press the ▲or ▼button to select “Film Mode”, then

press the ENTER button.

3Press the ▲or ▼button to select “On” or “Off”, then

press the ENTER button.

4 Press the MENU button to exit.

Note

•Film Mode is supported in TV, VIDEO, S-VIDEO and COMPONENT 480i.

Mode : Dynamic

Size : 16:9

Digital NR : On

DNIe Demo : Off

My Color Control

Film Mode : Off

†


Move Enter Return

Mode : Dynamic

Size : 16:9

Digital NR : On

DNIe Demo : Off

My Color Control

Film Mode : Off

†


Move Enter Return

Mode : Dynamic

√

Size : 16:9

√

Digital NR : On

√

DNIe Demo : Off

√

My Color Control

√

Film Mode : Off

√

†


Move Enter Return

Off

BN68-00835A-00(104~115) 4/15/05 7:11 PM Page 108

109

Setting the Blue Screen

If no signal is being received or the signal is very weak, a blue screen automatically replaces

the noisy picture background. If you wish to continue viewing the poor picture, you must set the

“Blue Screen“ mode to “Off“.

1Press the MENU button. Press the ▲or ▼button to select

“Picture”, then press the ENTER button.

2Press the ▲or ▼button to select “Blue Screen”, then

press the ENTER button.

3Press the ▲or ▼button to select “On” or “Off”, then

press the ENTER button.

4 Press the MENU button to exit.

…

Blue Screen : Off

Color Weakness : Off

PIP


Move Enter Return

…

Blue Screen : Off

Color Weakness : Off

PIP


Move Enter Return

➤

Blue Screen is displayed when there is no signal from an external

device in the External Mode, regardless of the Blue Screen Setting.

Mode : Dynamic

√

Size : 16:9

√

Digital NR : On

√

DNIe Demo : Off

√

My Color Control

√

Film Mode : Off

√

†


Move Enter Return

Off

BN68-00835A-00(104~115) 4/15/05 7:11 PM Page 109

110

1Press the MENU button. Press the ▲or ▼button to select

“Picture”, then press the ENTER button.

2Press the ▲or ▼button to select “Color Weakness”,

then press the ENTER button.

3Press the ENTER button. Press the ▲or ▼button to select

“On”, then press the ENTER button.

You will also see the items “Red“, “Green“, and

“Blue“.

• Pressing the ▲or ▼button will alternate between

“On” and “Off”.

4Press the ▲or ▼button to select the item you wish to

change, then press the ENTER button.

Press the œor √button to change the value of

the item, then press the ENTER button.

Press the ▲or ▼button to select other items.

5Press the MENU button to exit.

Using the Color Weakness

Enhancement Option

This option adjusts the Red, Blue or Green color to enhance the image according to the user's

particular color weakness.

Color Weakness

Enter Return

Color Weakness : Off

√

Red 0

Green 0

Blue 0

Color Weakness : On

√

Red 0

Green 0

Blue 0

Color Weakness

Move Enter Return

Move Adjust Return

Color Weakness

Red 0

Mode : Dynamic

√

Size : 16:9

√

Digital NR : On

√

DNIe Demo : Off

√

My Color Control

√

Film Mode : Off

√

†


Move Enter Return

BN68-00835A-00(104~115) 4/15/05 7:11 PM Page 110

111

1Press the Menu button. Press the ▲or ▼button to select

“Setup”, then press the ENTER button.

2Press the ▲or ▼button to select “Caption”, then press

the ENTER button.

3Press the ENTER button to select “Caption”.

Press the ▲or ▼button to select “On”, then press the

ENTER button.

4Press the ▲or ▼button to select “Caption Mode”, then

press the ENTER button.

Press the ▲or ▼button to select submenu

(CC1~CC4 or Text1~Text4) you want, the press

the ENTER button.

• The default is “CC1”.

CC1 : The Primary Synchronous Caption Service.

These are captions in the primary language

that must be in sync with the sound, preferably

matched to a specific frame.

CC2 : The Special Non-Synchronous Use Captions.

This channel carries data that is intended to

augment information carried in the program.

CC3 : Secondary Synchronous Caption Service.

Alternate program-related caption data,

typically second language captions.

CC4 : Special Non-Synchronous Use Captions.

Similar to CC2.

Text1 : First Text Service. This may be various

non-program related data.

Text2 : Second Text Service. Additional data, usually

not program related.

Text3/Text4 : Third and Fourth Text Services. These

data channels should be used only if

Text1 and Text2 data bandwidths are

not sufficient.

5Press the MENU button to exit.

Notes

•The Caption feature doesn’t work in COMPONENT(480p, 720p, 1080i), PC, HDMI (DVI) modes.

•The availability of captions depends on the program being broadcast.

Viewing Closed Captions (On-Screen

Text Messages) - Analog

The Analog Caption function operates in either analog RF channel mode or external signal mode.

➤

Quick way to select Caption: Simply press the “CAPTION” button

under the cover of the remote control.

Caption : On

√

Caption Mode : Default

√

Caption Options

√

Caption

Move Enter Return

Caption : Off

√

Caption Mode : Default

√

Caption Options

√

Caption

Enter Return

Caption : On

Caption Mode : Default

Caption Options

Caption

Move Enter Return

Default

CC1

CC2

CC3

CC4

Text 1

Text 2

Text 3

Text 4

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

BN68-00835A-00(104~115) 4/15/05 7:11 PM Page 111

112

Viewing Closed Captions (On-Screen

Text Messages) - Digital

The Digital Captions function operates on digital channels.

1Press the MENU button.

Press the ▲or ▼button to select “Setup”, then press

the ENTER button.

2Press the ▲or ▼button to select “Caption”, then press

the ENTER button.

3Press the ENTER button to select “Caption”.

Press the ▲or ▼button to select “On”, then press

the ENTER button.

4Press the ▲or ▼button to select “Caption Mode”, then

press the ENTER button.

Press the ▲or ▼button to select submenu

(Service1~Service6, CC1~CC4 or Text1~Text4) you

want, then press the ENTER button.

5Press the ▲or ▼button to select “Caption Options”,

then press the ENTER button.

Notes

•“Caption Options” are available only when

“Service1~Service6” can be selected in “Caption Mode”.

•Service1~6 in digital caption mode may not be

available according to the broadcasting type.

Caption : On

√

Caption Mode : Default

√

Caption Options

√

Caption

Move Enter Return

Caption : On

√

Caption Mode : Service1

√

Caption Options

√

Caption

Move Enter Return

Caption : Off

√

Caption Mode : Default

√

Caption Options

√

Caption

Enter Return

Caption : On

Caption Mode : Default

Caption Options

Caption

Move Enter Return

†

Default

Service1

Service2

Service3

Service4

Service5

Service6

CC1

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

BN68-00835A-00(104~115) 4/7/05 8:58 AM Page 112

113

6Press the ▲or ▼button to select “Size”, then press the

ENTER button.

Press the ▲or ▼button to select the desired Caption

option, then press the ENTER button.

Press the ▲or ▼button to select the desired

sub-menu options(see options below), then press ENTER.

Notes

•The availability of captions depends on the

program being broadcast.

•“Default” means to return to the original caption

options set by the broadcaster.

7 Press the MENU button to exit.

•Size

This option consists of “Default”, “Small”, “Standard”, and “Large”. The default is “Standard”.

•Font Style

This option consists of “Default”, “Style 0 ~ Style 7”. You can change the font you want.

The default is “Style 0”.

•Foreground Color

This option consists of “Default”, “White”, “Black”, “Red”, “Green”, “Blue”, “Yellow”, “Magenta”,

and “Cyan”. You can change the color of the letter. The default is “White”.

•Background Color

This option consists of “Default”, “White”, “Black”, “Red”, “Green”, “Blue”, “Yellow”, “Magenta”,

and “Cyan”. You can change the background color of the caption. The default is “Black”.

•Foreground Opacity

This option consists of “Default”, “Transparent”, “Translucent”, “Solid”, and “Flashing”.

You can change the opacity of the letter.

•Background Opacity

This option consists of “Default”, “Transparent”, “Translucent”, “Solid”, and “Flashing”.

You can change the background opacity of the caption.

•Return to Default

This option sets each of “Size”, “Font Style”, “Foreground Color”, “Background color”,

“Foreground Opacity”, and “Background Opacity” to its default.

Alternate method:

Press the CAPTION button on the remote control repeatedly to

select “On” or “Off”.

Size : Default

√

Font Style : Default

√

Foreground Color : Default

√

Background Color : Default

√

Foreground Opacity : Default

√

Background Opacity : Default

√

Return to Default

√

Caption Options

Move Enter Return

Caption : On

BN68-00835A-00(104~115) 4/7/05 8:58 AM Page 113

Menu Transparency Level

Adjusts the transparency of the menu screen.

114

1Press the MENU button.

Press the ▲or ▼button to select “Setup”, then press

the ENTER button.

2Press the ▲or ▼button to select “Menu Transparency”,

then press the ENTER button.

Press the ▲or ▼button to select level, then press

the ENTER button.

3Press the MENU button to exit.

Plug & Play

Language : English

Time

V-Chip

Caption

Menu Transparency : Medium

†

Setup

Move Enter Return

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

High

Medium

Low

Opaque

BN68-00835A-00(104~115) 4/7/05 8:58 AM Page 114

115

1Press the MENU button. Press the ▲or ▼button to select

“Setup”, then press the ENTER button.

2Press the ▲or ▼button to select “Energy Saving”, then

press the ENTER button.

3Press the ▲or ▼button to select submenu (Standard,

Auto Saving, or Super Saving) you want, then press the

ENTER button.

• Standard : Operates in standard mode regardless of

the surrounding illumination.

• Auto Saving : Automatically adjusts to the surrounding

illumination.

• Super Saving : Enters maximum power saving mode

regardless of the surrounding

illumination.

4 Press the MENU button to exit.

Using the Energy Saving Feature

This feature adjusts the screen brightness automatically depending on the surrounding lighting

conditions.

…

Energy Saving : Standard

Screen Burn Protection

Function Help : Off

CableCARD

Setup

Move Enter Return

…

Energy Saving : Standard

Screen Burn Protection

Function Help : Off

CableCARD

Setup

Move Enter Return

➤

Quick way to select Energy Saving: Simply press the “E.SAVING”

button under the cover of the remote control.

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

Standard

Auto Saving

Super Saving

Standard

Auto Saving

Super Saving

BN68-00835A-00(104~115) 4/7/05 8:58 AM Page 115

Preventing Screen Burn-in

To reduce the possibility of screen burn, this unit is equipped with screen burn prevention

technology. This technology enables you to set picture movement up/down (Vertical Line) and side

to side (Horizontal Dot). The Time setting allows you to program the time between movement of the

picture in minutes.

116

1Press the MENU button.

Press the ▲or ▼button to select “Setup”, then press

the ENTER button.

2Press the ▲or ▼button to select “Screen Burn

Protection”, then press the ENTER button.

3Press the ENTER button to select “Pixel Shift”, then press

the ENTER button.

• Pressing the ▲or ▼button will alternate between

“On” and “Off”.

You will also see the items “Horizontal Dot”,

“Vertical Line” and “Time”.

• Pixel Shift: Using this function, you can minutely

move pixels on the PDP in horizontal or

vertical direction to prevent after image

on the screen.

4Press the ▲or ▼button to select the item you wish to

change, then press the ENTER button.

Press the ▲or ▼button to change the value of the item,

then press the ENTER button.

• Optimum condition for pixel shift;

Pixel Shift

√

All White

√

Signal Pattern

√

Screen Burn Protection

Move Enter Return

Pixel Shift : On

Horizontal Dot : 2

Vertical Line : 2

Time : 2

Pixel Shift

Move Enter Return

Pixel Shift : On

Horizontal Dot : 2

Vertical Line : 4

Time : 4

Pixel Shift

Move Enter Return

Horizontal Dot

Vertical Line

Time

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

Off

BN68-00835A-00(116~133) 4/6/05 8:34 PM Page 116

117

1Press the MENU button.

Press the ▲or ▼button to select “Setup”, then press

the ENTER button.

2Press the ▲or ▼button to select “Screen Burn

Protection”, then press the ENTER button.

3Press the ▲or ▼button to select “All White” or “Signal

Pattern”, then press the ENTER button.

• All White: This function removes after-images on the

screen by changing the color of pixels to

white. Use this function when there are

remaining after-images or symbols on the

screen especially when you displayed a

still image on the screen for a long time.

• Signal Pattern: This function removes after-images on

the screen by moving all the pixels on

the PDP according to a pattern. Use

this function when there are remaining

after-images or symbols on the screen

especially when you displayed a still

image on the screen for a long time.

4Press the MENU button to exit.

Notes

•To remove after-images on the screen, use either the “All White” or “Signal Pattern” function.

Although both functions remove after-images on the screen, “Signal Pattern” is more effective.

•The after-image removal function has to be executed for a long time (approximately 1 hour) to

effectively remove after-images on the screen. If the after-image is not removed after performing

the function, repeat the function again.

Reducing the Effects of Screen Burn

If screen burn has occurred, you can select a white screen or signal pattern (rolling screen) to help

remove screen burn artifacts.

Pixel Shift

√

All White

√

Signal Pattern

√

Screen Burn Protection

Move Enter Return

Pixel Shift

√

All White

√

Signal Pattern

√

Screen Burn Protection

Move Enter Return

Pixel Shift

√

All White

√

Signal Pattern

√

Screen Burn Protection

Move Enter Return

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

BN68-00835A-00(116~133) 4/6/05 8:34 PM Page 117

1Press the MENU button.

Press the ▲or ▼button to select “Setup”, then press

the ENTER button.

2 Press the ▲or ▼button to select “Function Help”, then

press the ENTER button.

3Press the ▼button to select “On”, then press the ENTER

button.

4 Press the MENU button to exit.

Setting the Function Help

Displays help on the menu functions.

118

…

Energy Saving : Standard

Screen Burn Protection

Function Help : Off

CableCARD

Setup

Move Enter Return

…

Energy Saving : Standard

Screen Burn Protection

Function Help : Off

CableCARD

Setup

Move Enter Return

Switches the Function Help on.

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

Off

BN68-00835A-00(116~133) 4/6/05 8:34 PM Page 118

119

Using the V-Chip

The V-Chip feature automatically locks out programs that are deemed inappropriate for children.

The user must enter a PIN (personal ID number) before any of the V-Chip restrictions are set up or

changed.

Notes : ●When the V-chip feature is activated, the PIP features do not function.

●The V-Chip does not work if the input is DTV (HD or SD).

Setting Up Your Personal ID Number (PIN)

1Press the MENU button. Press the ▲or ▼button to select

“Setup”, then press the ENTER button.

2Press the ▲or ▼button to select “V-Chip”, then press

the ENTER button.

The message “Enter PIN” will appear.

Enter your 4 digit PIN number.

Note

•The default PIN number of a new TV set is “0-0-0-0”.

3The “V-Chip” screen will appear. Press the ▲or ▼

button to select “Change PIN”, then press the ENTER

button.

4The Change PIN screen will appear.

Choose any 4 digits for your PIN and enter them.

As soon as the 4 digits are entered, the “Confirm

new PIN” screen appears. Re-enter the same 4 digits.

When the Confirm screen disappears, your PIN has

been memorized.

5 Press the MENU button to exit.

Note

•If you forget the PIN, press the remote-control buttons in the following sequence, which resets the

pin to 0-0-0-0 : Power Off. ➔ Mute ➔8 ➔2 ➔4 ➔Power On.

V-Chip

0~9 Enter PIN Return

Enter PIN

* * * *

Change PIN

0~9 Enter PIN Return

Enter New PIN

Confirm New PIN

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

BN68-00835A-00(116~133) 4/6/05 8:34 PM Page 119

How to Enable/Disable the V-Chip

1Press the MENU button. Press the ▲or ▼button to select

“Setup”, then press the ENTER button.

2Press the ▲or ▼button to select “V-Chip”, then press the

ENTER button.

The message “Enter PIN” will appear.

Enter your 4 digit PIN number.

3The “V-Chip” screen will appear. To enable the V-Chip

feature, press the ENTER button so that the “V-Chip Lock”

field is “On”. (Pressing the ▲or ▼button will alternate

between “On” and “Off”.)

Press the ENTER button.

4 Press the MENU button to exit.

120

V-Chip Lock : English

TV Parental Guidelines

MPAA Rating

Change PIN

V-Chip

Move Enter Return

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

Off

V-Chip

0~9 Enter PIN Return

Enter PIN

* * * *

BN68-00835A-00(116~133) 4/6/05 8:34 PM Page 120

121

How to Set up Restrictions using the “TV Parental Guidelines”

First, set up a personal identification number (PIN), and enable the V-Chip. (See previous section.)

Parental restrictions can be set up using either of two methods: The TV guidelines or the MPAA rating.

1Press the MENU button. Press the ▲or ▼button to select

“Setup”, then press the ENTER button.

2Press the ▲or ▼button to select “V-Chip”, then press

the ENTER button.

The message “Enter PIN” will appear.

Enter your 4 digit PIN number.

3The “V-Chip” screen will appear. Press the ▲or ▼

button to select “TV Parental Guidelines”, then press

the ENTER button.

4The “TV Parental Guidelines” screen will appear.

Press the ▲or ▼button to select one of the six ages

based categories:

TV-Y Young children

TV-Y7 Children 7 and over

TV-G General audience

TV-PG Parental guidance

TV-14 Viewers 14 and over

TV-MA Mature audience

TV Parental Guidelines

Move Enter Return

Allow All

Block All

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

V-Chip

0~9 Enter PIN Return

Enter PIN

* * * *

BN68-00835A-00(116~133) 4/6/05 8:34 PM Page 121

5At this point, one of the TV-Ratings is selected.

Press the ENTER button. Depending on your existing

setup, a symbol will be selected.

(Blank = Unblocked, = Blocked)

While “ ” is selected, press the ENTER button to

block or unblock the category.

To select a different TV-Rating, press the ▲or ▼

button and then repeat the process.

Note 1: The TV-Y, TV-Y7, TV-G, TV-PG, TV-14 and TV-MA have additional options.

See the next step to change any of the following sub-ratings:

FV: Fantasy violence

D: Sexually Suggestive Dialog

L: Adult Language

S: Sexual situation

V: Violence

Note 2: The V-Chip will automatically block certain categories that are “more restrictive”.

For example, if you block “TV-Y” category, then TV-Y7 will automatically be blocked.

Similarly, if you block the TV-G category, then all the categories in the “young adult” group will

be blocked (TV-Y, TV-Y7, TV-G, TV-PG, TV-14, and TV-MA). The sub-ratings (D, L, S, V) work

together similarly. (See next section.)

6How to set the FV, D, L, S and V sub-ratings.

First, select one of these TV-Ratings: TV-Y, TV-Y7, TV-G, TV-PG, TV-14, or TV-MA (See Step 4,

on previous page), and press the √button.

A symbol “ ” will be displayed for each sub-rating.

While “ ” is selected, press the ENTER button to go to a sub rating.

Press ENTER to block the sub rating. To select a different TV-Rating, press the ▲or ▼button

and then repeat the process.

Note: The V-chip will automatically block certain categories that are “More restrictive”.

For example, if you block “L” sub-rating in TV-PG, then the “L” sub-ratings in TV-14 and TV-MA

will automatically be blocked.

7Press the MENU button to clear all the screens. (Or proceed to the next section, and set up

additional restrictions based on the MPAA codes.)

Note

•These categories consist of two separate groups: TV-Y and TV-Y7 (young children through

age 7), and TV-G through TV-MA (everybody else).

The restrictions for these two groups work independently: If a household includes very young

children as well as young adults, the TV guidelines must be set up separately for each age group.

(See next step.)

122

TV Parental Guidelines

Move Enter Return

Allow All

Block All

BN68-00835A-00(116~133) 4/6/05 8:34 PM Page 122

123

How to Set up Restrictions using the MPAA Ratings: G, PG, PG-13, R, NC-17, X, NR

The MPAA rating system uses the Motion Picture Association of America (MPAA) system, and its main

application is for movies. When the V-Chip lock is on, the TV will automatically block any programs

that are coded with objectionable ratings (either MPAA or TV-Ratings).

1Press the MENU button. Press the ▲or ▼button to select

“Setup”, then press the ENTER button.

2Press the ▲or ▼button to select “V-Chip”, then press

the ENTER button.

The message “Enter PIN” will appear.

Enter your 4 digit PIN number.

3The “V-Chip” screen will appear.

Press the ▲or ▼button to select “MPAA Rating”, then

press the ENTER button.

4The “MPAA Rating” screen will appear.

Repeatedly press the ▲or ▼button to select a particular

MPAA category.

Pressing the ▲or ▼button will cycle through the MPAA

categories:

While a particular category is selected, press the ENTER button to activate it.

A selected symbol “ ” will be displayed.

Press the ENTER button to block or unblock the category.

Note: The V-Chip will automatically block any category that is “more restrictive”. For example, if

you block the “PG-13” category, then “R”, “NC-17” and “X” will automatically be blocked also.

GGeneral audience (no restrictions).

PG Parental guidance suggested.

PG-13 PG-13 (Parents strongly cautioned).

R (Restricted. Children under 17 should be accompanied by an adult).

NC-17 No children under age 17.

XX (Adults only).

NR Not rated.

MPAA Rating

Move Enter Return

Allow All

Block All

MPAA Rating

Move Enter Return

Allow All

Block All

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

V-Chip

0~9 Enter PIN Return

Enter PIN

* * * *

BN68-00835A-00(116~133) 4/6/05 8:34 PM Page 123

How to Reset the TV after the V-Chip Blocks a Channel (“Emergency Escape”)

If the TV is tuned to a restricted channel, the V-Chip will block it. The screen will go blank and the

following message will appear:

1Enter your PIN number.

To resume normal viewing, tune to a different channel using CH or CH button.

Under certain conditions (depending on the rating of the local TV programs) the V-Chip might lock out

all the channels. In this case, use the V-Chip function for an “emergency escape”:

1Press the MENU button. Press the ▲or ▼button to select “Setup”, then press the ENTER button.

2Press the ▲or ▼button to select “V-Chip”, then press the ENTER button.

3Enter your PIN number, and press the ▲or ▼button to temporarily disable the V-Chip Lock.

124

Channel Is Locked by

TV-PG[ S ]

Use the NUMBER buttons to enter your

pin number to unlock all channels.

Press EXIT to clear PIN.

Press MENU for main menu.

Channel Is Locked by

TV-PG[ L ]

Use the NUMBER buttons to enter your

pin number to unlock all channels.

Press EXIT to clear PIN.

Press MENU for main menu.

BN68-00835A-00(116~133) 4/6/05 8:34 PM Page 124

125

Electronic Program Guide

Your TV has an “Electronic Program Guide” to help you

navigate through all the possible viewing options.

The EPG supplies information, such as program lists,

start and end times of all available channels.

In addition, detailed information about the program is

often available in the EPG. (The availability and the

amount of program details will vary depending on the

broadcaster.)

Viewing the Electronic Program Guide

ADisplays which channel is currently selected to show program information in the Channel Guide.

BPress to view detailed information for the selected digital program.

CSwitches to the mini program guide. The mini guide shows the titles of the available programs of

one channel. Press the Red button on the remote control. The set default guide is Mini Guide.

DScrolls backwards quickly (2 hours). Press the Green button on the remote control.

EDisplays titles and other details about upcoming programs of particular channels. Highlight the

program and press the INFO button to see additional and detailed information. (The availability

of additional details depends on the broadcaster.) Use the ▲/▼/œ/√buttons to search

information about another channel.

FScrolls forward quickly (2 hours). Press the Yellow button on the remote control and repeatedly

press the ENTER button the appropriate time is displayed.

GExits from the Program Guide and returns to normal viewing mode. Press the Blue button on the

remote control.

HDisplays the program times (arranged in 1 hour time blocks).

IDisplays the current time and date.

Note

•You can use the GUIDE button on the remote control to display the Electronic Program Guide.

The EPG begins its list with the channel that is currently active.

The EPG will only work when you are receiving digital channels.

EB C D F G

BN68-00835A-00(116~133) 4/6/05 8:34 PM Page 125

126

Using the Electronic Program Guide

1Press the MENU button.

Press the ▲or ▼button to select “Guide”, then

press the ENTER button.

2Press the ▲or ▼button to select “Default Guide”, then

press the ENTER button.

3Press the ▲or ▼button to select “Mini Guide” or “Full

Guide”, then press the ENTER button.

• Mini Guide : Displays the guide for one channel.

• Full Guide : Displays the guide for all channels.

4Press the MENU button to exit.

Mini Guide

√

Full Guide

√

Reminder List

√

Default Guide : Mini Guide

√

Guide

Move Enter Return

Mini Guide

Full Guide

Reminder List

Default Guide : Mini Guide

Guide

Move Enter Return

Mini Guide

Full Guide

Mini Guide

Full Guide

Reminder List

Default Guide : Mini Guide

Guide

Move Enter Return

Mini Guide

Full Guide

BN68-00835A-00(116~133) 4/6/05 8:34 PM Page 126

127

Viewing Information about a Single Channel

1Press the MENU button.

Press the ▲or ▼button to select “Guide”, then

press the ENTER button.

2Press the ENTER button to select “Mini Guide”.

Press the ▲or ▼buttons to view information about

one channel by time.

You can switch between Full Guide mode and Mini

Guide mode by pressing the Red button repeatedly.

Select the program you want by pressing the ▲or

▼buttons and press the INFO button on the remote

control.

• ENTER button : Press to watch the current program

or to add the program to reminder list.

• Red button : Press to switch to the program

guide for all channels.

Press again to switch to the program information for

the selected channel.

• Blue button : Press to exit.

• INFO button : Press to view detailed information

for the selected digital program.

3Press the Blue button or EXIT button to exit.

Notes

•You can also view information about a single channel by pressing the GUIDE button on the remote

control. (The EPG should be pre-set in Mini Guide mode.)

•Press the INFO button on the remote control to view the program information for the current channel.

Mini Guide

Program 1

Program 2

Program 3

Program 4

Program 5

Program 6

5:00 pm

7:30 pm

8:00 pm

9:30 pm

10:00 pm

11:30 pm

Prog Info

INFO

ExitFull Guide

4:30 pm Fri May 31

Mini Guide

√

Full Guide

√

Reminder List

√

Default Guide : Mini Guide

√

Guide

Move Enter Return

Watch

BN68-00835A-00(116~133) 4/6/05 8:34 PM Page 127

Viewing Information about Channels

Displays the program time and content for all channels.

This function is available only when the program is digital.

1Press the MENU button.

Press the ▲or ▼button to select “Guide”, then

press the ENTER button.

2Press the ▲or ▼button to select “Full Guide”, then press

the ENTER button.

3Press the Green button to activate “-2 Hours” and the

Yellow button to activate “+2 Hours”.

• INFO button : Displays detailed information for

the selected digital program.

• ▲/▼button : Displays program information for

each channel, based on the time. Select your

desired program using the ▲/▼button, and then

press the INFO button to view the program

information for the selected program.

• Red button : Each press switches between program

information for one channel and all channels.

• Green button : Press to view the program

information from two hours ago.

• Yellow button : Press to view the program

information for two hours from now.

• Blue button : Press to exit.

• ENTER button : Press to watch the current program

or to add the program to reminder list.

4You may now:

• Jump to a channel directly : Use the ▲or ▼

buttons to highlight the program in the √column

and press the enter button.

• Obtain additional program details : Highlight the

title of a program using the ▲, ▼, œ, or √buttons

and press the INFO button.

• Exit from the Program Guide and return to normal

viewing mode : Press the Blue button or the EXIT

button.

Notes

•The current time displayed on the program information is subject to the time information sent from

the broadcasting station, so it may differ from the actual time.

•Press the GUIDE button on the remote control to view the program information for all channels.

However, this function is available only when the default program guide setting is set to “Full Guide”.

128

Mini Guide

√

Full Guide

√

Reminder List

√

Default Guide : Mini Guide

√

Guide

Move Enter Return

BN68-00835A-00(116~133) 4/6/05 8:34 PM Page 128

129

Viewing the Reminder List

If you have made a scheduled viewing list of programs you would like to see, the channel will be

automatically switched to the scheduled program at the scheduled time even if you are watching

another program.

1Press the MENU button.

Press the ▲or ▼button to select “Guide”, then

press the ENTER button.

2Press the ENTER button to select “Full Guide”.

Press the ▲or ▼button to select programs you would

like to see, then press the enter button.

The symbol “

✔

” will be displayed.

Each press of the enter button will switch between

“Remind” and “Del Remind” (Del = Delete).

3Press the MENU button to exit.

Note

•Up to 8 programs can be reminded.

Reminder List

Mini Guide

√

Full Guide

√

Reminder List

√

Default Guide : Mini Guide

√

Guide

Move Enter Return

Mini Guide

Program 1

Program 2

Program 3

Program 4

Program 5

Program 6

5:00 pm

7:30 pm

8:00 pm

9:30 pm

10:00 pm

11:30 pm

Prog Info

INFO

ExitFull Guide

4:30 pm Fri May 31

Reminder List

Watch

BN68-00835A-00(116~133) 4/15/05 7:12 PM Page 129

130

To view the Reminder List

1Press the MENU button.

Press the ▲or ▼button to select “Guide”, then

press the ENTER button.

2Press the ▲or ▼button to select “Reminder List”, then

press the ENTER button.

To remove the scheduled programs

1Press the ▲or ▼button to select a program to be

removed, then press the ENTER button.

To remove all programs, press the œor √button to

select “Cancel All”, then press the ENTER button.

2Press the MENU button to exit.

Mini Guide

√

Full Guide

√

Reminder List

√

Default Guide : Mini Guide

√

Guide

Move Enter Return

Mini Guide

√

Full Guide

√

Reminder List

√

Default Guide : Mini Guide

√

Guide

Move Enter Return

Reminder List

Enter Return

Cancel AllMON 1.17 1:56am-2:05am

11-1 MBC MBC

MON 1.17 3:15am-3:28am

11-1 MBC

MON 1.17 3:28am-3:29am

11-1 MBC

Move

BN68-00835A-00(116~133) 4/6/05 8:34 PM Page 130

131

Using the CableCARD

This menu works with a CableCARD provided by a local cable service provider.

Prior to accessing this menu, a CableCARD should be connected to the rear panel of the TV.

For detailed connection instructions refer to the “Connecting CableCARD” section of this manual.

Displaying CableCARD related information

Accessing information on Status, Pairing, Network Setup of the CableCARD provided by the service

provider in CableCARD menu.

1Make sure the Cablecard is inserted.

Press the MENU button. Press the ▲or ▼button to select

“Setup”, then press the ENTER button.

2Press the ▲or ▼button to select “CableCARDTM”, then

press the ENTER button.

3Press the EXIT button to exit.

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

…

Energy Saving : Standard

√

Screen Burn Protection

√

Function Help : Off

√

CableCARD

√

CableCARD

Setup

√

Setup

Move Enter Return

BN68-00835A-00(116~133) 4/6/05 8:34 PM Page 131

132

CableCARD Reset

Resets CableCARD when the channels provided by CableCARD are not available.

1Press the MENU button.

Press the ▲or ▼button to select “Setup”, then

press the ENTER button.

2Press the ▲or ▼button to select “CableCARDTM Setup”,

then press the ENTER button.

3Press the ENTER button to select “CableCARDTM Reset”.

Using the CableCARD Setup Function

Sets up the relevant options for CableCARD.

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

…

Energy Saving : Standard

√

Screen Burn Protection

√

Function Help : Off

√

CableCARD

√

CableCARD

Setup

√

Setup

Move Enter Return

CableCARD

Reset

Channel List Reorganization

CableCARD

Setup

Move Enter Return

BN68-00835A-00(116~133) 4/6/05 8:34 PM Page 132

133

Channel List Reorganization

Deletes and reorganizes the channel list provided by CableCARD.

This feature should be used if you change or upgrade your CableCARD service.

1Press the MENU button. Press the ▲or ▼button to select

“Setup”, then press the ENTER button.

2Press the ▲or ▼button to select “CableCARDTM Setup”,

then press the ENTER button.

Press the ENTER button to select “Channel List

Reorganization”.

Plug & Play

√

Language : English

√

Time

√

V-Chip

√

Caption

√

Menu Transparency : Medium

√

†

Setup

Move Enter Return

…

Energy Saving : Standard

√

Screen Burn Protection

√

Function Help : Off

√

CableCARD

√

CableCARD

Setup

√

Setup

Move Enter Return

CableCARD

Reset

Channel List Reorganization

CableCARD

Setup

Move Enter Return

BN68-00835A-00(116~133) 4/6/05 8:34 PM Page 133

BN68-00835A-00(134~145) 4/6/05 8:35 PM Page 134

PLASMA DISPLAY PANEL

Appendix

Troubleshooting..........................................................................136

Care and Maintenance ..............................................................137

Specifications ............................................................................138

Dimensions (HP-R4252) ..............................................................139

Dimensions (HP-R5052) ..............................................................141

BN68-00835A-00(134~145) 4/6/05 8:35 PM Page 135

Troubleshooting

136

Problem

Poor picture.

No picture or sound.

Poor sound quality.

Your remote control does not

operate the TV.

The TV won’t turn on.

There is no screen image.

The image is too light or

too dark.

The image is too large or

too small.

Digital broadcasting screen

problem.

Screen is black and power

indicator light blinks steadily.

If the TV seems to have a problem, first try this list of possible problems and solutions.

If none of these troubleshooting tips apply, then call your nearest service center.

Possible Solution

Check all wire connections.

Try another channel. Press the SOURCE button.

Make sure the TV is plugged in.

Check the antenna connections.

Check that the Mute feature is Off.

Try another channel.

Adjust the volume.

Press the “MODE” button to put your remote control in

the “TV” mode.

Check the battery charge of the remote control.

Check if the power plug is connected.

Check to see that both the TV and the source are

plugged in and turned on.

Adjust the Brightness or Contrast settings.

Adjust the Size settings.

Please check the digital signal strength and input

antenna.

On your computer check; Power, Signal Cable.

The TV is using its power management system.

Move the computer’s mouse or press any key on the

keyboard.

On your equipment check (STB, DVD, etc) ; Power,

Signal Cable.

The TV is using its power management system.

Press the Source button on the panel or remote control.

Turn the TV off and on.

BN68-00835A-00(134~145) 4/6/05 8:35 PM Page 136

137

With proper care, your TV will give you many years of service. Please follow these guidelines to get the

maximum performance from your TV.

Identifying Problems

•Do not put the TV near extremely hot, cold, humid or dusty places.

•Do not put the TV near appliances that create magnetic fields.

•Keep the ventilation openings clear.

•Do not place the TV on a rough and slanted surface, such as cloth or paper.

Liquids

•Do not place liquids near or on the TV.

Cabinet

•Never open the cabinet or touch the parts inside.

•Wipe your TV with a clean, dry cloth. Never use water, cleaning fluids, wax, or chemicals.

•Do not put heavy objects on top of the cabinet.

Temperature

•If your TV is suddenly moved from a cold to a warm place, unplug the power cord for at least two

hours so that moisture that may have formed inside the unit can dry completely.

Care and Maintenance

BN68-00835A-00(134~145) 4/6/05 8:35 PM Page 137

Specifications

138

Exterior design and product specifications are subject to change without prior notice to improve

the performance of this product.

AC 110

120V~, 60Hz

ANT 1 - CABLE IN (Cable QAM)

ANT 2 - AIR IN (ATSC)

75Ωunbalanced

S-VIDEO

COMPONENT1 - 480i/480p/720p/1080i

COMPONENT2 - 480i/480p/720p/1080i

HDMI (DVI Compatible)

S-VIDEO

COMPONENT1 - 480i/480p/720p/1080i

COMPONENT2 - 480i/480p/720p/1080i

DVI

AUDIO (L/R)

OPTICAL (DIGITAL OUT)

COAXIAL (DIGITAL OUT)

15W + 15W (8Ω)

HP-R4252

41.7 (W) x 29.1 (H) x 3.88 (D) inches (Without Stand)

41.7 (W) x 30.7 (H) x 13.4 (D) inches (With Stand)

39.8 Kg / 87.74 lbs (Without Stand)

44.5 Kg / 98.10 lbs (With Stand)

HP-R5052

48.43 (W) x 32.52 (H) x 3.72 (D) inches (Without Stand)

48.43 (W) x 34.47 (H) x 13.18 (D) inches (With Stand)

46.8Kg / 103.17 lbs (Without Stand)

53.5Kg / 117.95 lbs (With Stand)

380 W

1024 (H) x 768 (V)

42 inches

420 W

1366 (H) x 768 (V)

50 inches

Model

Dimensions Display

Weight Display

Voltage

Power Consumption

Number of Pixels

Screen Size

ANTENNA input

VIDEO input

AUDIO input

Sound Output

Audio Output

Speaker Output

BN68-00835A-00(134~145) 4/15/05 7:12 PM Page 138

139

Dimensions (HP-R4252)

JACK PANEL DETAIL 2 1/4"H x 18 3/4"W @ 5 3/4" UP FROM BOTTOM

BN68-00835A-00(134~145) 4/6/05 8:35 PM Page 139

140

BN68-00835A-00(134~145) 4/6/05 8:35 PM Page 140

141

Dimensions (HP-R5052)

JACK PANEL DETAIL 2 1/4"H x 18 3/4"W @ 5 3/4" UP FROM BOTTOM

BN68-00835A-00(134~145) 4/6/05 8:35 PM Page 141

142

BN68-00835A-00(134~145) 4/6/05 8:36 PM Page 142

143

Memo

BN68-00835A-00(134~145) 4/6/05 8:36 PM Page 143

Memo

BN68-00835A-00(134~145) 4/6/05 8:36 PM Page 144

Memo

BN68-00835A-00(134~145) 4/6/05 8:36 PM Page 145

1-800-SAMSUNG (1-800-726-7864)

Samsung Electronics America

Service Division

400 Valley Road, Suite 201

Mount Arlington, NJ 07856

www.samsung.com

Samsung Electronics Canada Inc.

Samsung Customer Care

7037 Financial Drive

Mississauga, Ontario

L5N 6R3

www.samsung.ca

BN68-00835A-00

BN68-00835A-00(cover) 4/6/05 8:18 PM Page 2

Samsung BN68 00835A 00(002~035) HP R4252 20050711211503468 00Eng

Navigation menu

Versions of this User Manual:

Views

Navigation
