imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service,
please register your product at
www.samsung.com/register
5.1CH Blu-ray™
Home Entertainment System
user manual
HT-H6500WM
This Nanum Gothic Eco font is provided by NAVER.
- English
Safety Information
~The slots and openings in the cabinet and in
the back or bottom are provided for necessary
ventilation. To ensure reliable operation of this
apparatus, and to protect it from overheating,
these slots and openings must never be blocked or
covered.
-Do not place this apparatus in a confined space,
such as a bookcase, or built-in cabinet, unless
proper ventilation is provided.
-Do not place this apparatus near or over a
radiator or heat register, or where it is exposed
to direct sunlight.
-Do not place vessels (vases etc.) containing
water on this apparatus. A water spill can cause
a fire or electric shock.
~Do not expose this apparatus to rain or place it
near water (near a bathtub, washbowl, kitchen
sink, or laundry tub, in a wet basement, or near a
swimming pool, etc.). If this apparatus accidentally
gets wet, unplug it and contact an authorized
dealer immediately.
~This apparatus uses batteries. In your community,
there might be environmental regulations that
require you to dispose of these batteries properly.
Please contact your local authorities for disposal or
recycling information.
~Do not overload wall outlets, extension cords or
adaptors beyond their capacity, since this can result
in fire or electric shock.
~Route power-supply cords so that they are not
likely to be walked on or pinched by items placed
on or against them. Pay particular attention to
cords at the plug end, at wall outlets, and the point
where they exit from the apparatus.
~To protect this apparatus from a lightning storm,
or when it is left unattended and unused for long
periods of time, unplug it from the wall outlet and
disconnect the antenna or cable system. This will
prevent damage to the set due to lightning and
power line surges.
~Before connecting the AC power cord to the DC
adaptor outlet, make sure the voltage designation
of the DC adaptor corresponds to the local
electrical supply.
~Never insert anything metallic into the open parts
of this apparatus. Doing so may create a danger of
electric shock.
~To avoid electric shock, never touch the inside of
this apparatus. Only a qualified technician should
open this apparatus.
~Make sure to plug the power cord in until it is
firmly seated. When unplugging the power cord
from a wall outlet, always pull on the power cord's
plug. Never unplug by pulling on the power cord.
Do not touch the power cord with wet hands.
~If this apparatus does not operate normally - in
particular, if there are any unusual sounds or smells
coming from it - unplug it immediately and contact
an authorized dealer or service center.
~Maintenance of Cabinet.
-Before connecting other components to this
product, be sure to turn them off.
-If you move your product suddenly from a cold
place to a warm place, condensation may occur
on the operating parts and lens and cause
abnormal disc playback. If this occurs, unplug the
product, wait for two hours, and then connect
the plug to the power outlet. Then, insert the
disc, and try to play back again.
~Be sure to pull the power plug out of the outlet
if the product is to remain unused or if you are
leaving the house for an extended period of time
(especially when children, elderly, or disabled
people will be left alone in the house).
-Accumulated dust can cause an electric shock,
an electric leakage, or a fire by causing the
power cord to generate sparks and heat or the
insulation to deteriorate.
~Contact an authorized service center for
information if you intend to install your product
in a location with heavy dust, high or low
temperatures, high humidity, chemical substances,
or where it will operate 24 hours a day such as in
an airport, a train station, etc. Failing to do so may
lead to serious damage of your product.
~Use only a properly grounded plug and wall outlet.
-An improper ground may cause electric shock or
equipment damage. (Class l Equipment only.)
~To turn this apparatus off completely, you must
disconnect it from the wall outlet. Consequently,
the wall outlet and power plug must be readily
accessible at all times.
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO
NOT REMOVE THE COVER (OR BACK). THERE ARE NO
USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO
QUALIFIED PERSONNEL.
This symbol indicates that high voltage
is present inside. It is dangerous to
make any kind of contact with any
internal part of this product.
This symbol indicates that important
literature concerning operation and
maintenance has been included with
this product.
- English
~Do not allow children to hang on the product.
~Store the accessories (battery, etc.) in a location
safely out of the reach of children.
~Do not install the product in an unstable location
such as a shaky self, a slanted floor, or a location
exposed to vibration.
~Do not drop or strike the product. If the product is
damaged, disconnect the power cord and contact
a service center.
~To clean this apparatus, unplug the power cord
from the wall outlet and wipe the product using
a soft, dry cloth. Do not use any chemicals such
as wax, benzene, alcohol, thinners, insecticide,
air fresheners, lubricants, or detergent. These
chemicals can damage the appearance of the
product or erase the printing on the product.
~Do not expose this apparatus to dripping or
splashing. Do not put objects filled with liquids,
such as vases on the apparatus.
~Do not dispose of batteries in a fire.
~Do not plug multiple electric devices into the same
wall socket. Overloading a socket can cause it to
overheat, resulting in a fire.
~There is danger of an explosion if you replace
the batteries used in the remote with the wrong
type of battery. Replace only with the same or
equivalent type.
~TO PREVENT THE SPREAD OF FIRE,
KEEP CANDLES AND OTHER ITEMS
WITH OPEN FLAMES AWAY FROM
THIS PRODUCT AT ALL TIMES.
~This product contains chemicals known to the State
of California to cause cancer and reproductive
toxicity.
~To reduce the risk of fire or electric shock, do not
expose this appliance to rain or moisture.
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio or television reception, which
can be determined by turning the equipment off and
on.
If interference is present, the user is encouraged to
try to correct the interference by one or more of the
following measures:
~Reorient or relocate the receiving antenna.
~Increase the separation between the equipment
and receiver.
~Connect this equipment to an outlet on a circuit
that the receiver is not connected to.
~Consult the dealer or an experienced radio/TV
technician for help.
This class B digital product meets all requirements
of the Canadian Interference - Causing Equipment
Regulations.
This product is classified as a CLASS 1 LASER product.
Use of controls, adjustments or performance of
procedures other than those specified herein may
result in hazardous radiation exposure.
Complies with 21CFR 1040.10 except for deviations
pursuant to Laser Notice No. 50, dated June 24,
2007.
~VISIBLE AND INVISIBLE LASER RADIATION WHEN
OPEN. AVOID DIRECT EXPOSURE TO BEAM.
(FDA 21 CFR)
~CLASS 3B VISIBLE AND INVISIBLE LASER
RADIATION WHEN OPEN. AVOID EXPOSURE TO
THE BEAM (IEC 60825-1)
~THIS PRODUCT UTILIZES A LASER. USE OF
CONTROLS OR ADJUSTMENTS OR PERFORMANCE
OF PROCEDURES OTHER THAN THOSE SPECIFIED
HEREIN MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE. DO NOT OPEN THE COVER. DO
NOT REPAIR THE PRODUCT YOURSELF. REFER
SERVICING TO QUALIFIED PERSONNEL.
CLASS 1 LASER PRODUCT
KLASSE 1 LASER PRODUKT
LUOKAN 1 LASER LAITE
KLASS 1 LASER APPARAT
PRODUCTO LÁSER CLASE 1
Important Safety Instructions
Read these operating instructions carefully before
using the unit. Follow all the safety instructions listed
below. Keep these operating instructions handy for
future reference.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with a dry cloth.
Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
- English
Safety Information
Do not install near any heat sources such
as radiators, heat registers, stoves, or other
apparatus (including AV receivers) that produce
heat.
Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade or
the third prong are provided for your safety. If
the provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where it exits the
apparatus.
Only use attachments/accessories specified by
the manufacturer.
Use only with the cart,
stand, tripod, bracket,
or table specified by the
manufacturer, or sold with
the apparatus. When a cart
is used, use caution when
moving the cart/apparatus
combination to avoid injury from tip-over.
Unplug this apparatus during lightning storms
or when unused for long periods of time.
Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as when the
power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or
has been dropped.
3D Precautions
IMPORTANT HEALTH AND SAFETY INFORMATION
FOR 3D PICTURES.
Read and understand the following safety
information before using the 3D function.
~Some viewers may experience discomfort while
viewing 3D TV such as dizziness, nausea, and
headaches. If you experience any such symptom,
stop viewing 3D TV, remove the 3D Active Glasses,
and rest.
~Watching 3D images for an extended period of
time may cause eye strain. If you feel eye strain,
stop viewing 3D TV, remove your 3D Active
Glasses, and rest.
~
A responsible adult should frequently check on
children who are using the 3D function. If there are
any reports of tired eyes, headaches, dizziness, or
nausea, have the child stop viewing 3D TV and rest.
~Do not use the 3D Active Glasses for other
purposes (such as general eyeglasses, sunglasses,
protective goggles, etc.)
~Do not use the 3D function or 3D Active Glasses
while walking or moving around. Using the 3D
function or 3D Active Glasses while moving around
may cause you to bump into objects, trip, and/or
fall, and cause serious injury.
~If you want to enjoy 3D content, connect a 3D
device (3D compliant AV receiver or TV) to the
product’s HDMI OUT port using a high-speed HDMI
cable. Put on 3D glasses before playing the 3D
content.
~The product outputs 3D signals only through an
HDMI cable connected to the HDMI OUT port.
~The video resolution in 3D play mode is fixed to
the resolution of the original 3D video. You can not
change the resolution.
~Some functions such as BD Wise, screen size
adjustment, and resolution adjustment may not
operate properly in 3D play mode.
~You must use a high-speed HDMI cable for proper
output of the 3D signal.
~Stay at least three times the width of the screen
from the TV when watching 3D images. For
example, if you have a 46 inch screen, stay 138
inches (11.5 feet) from the screen.
~Place the 3D video screen at eye level for the best
3D picture.
~When the product is connected to some 3D
devices, the 3D effect may not function properly.
~This product does not convert 2D content into 3D.
~“Blu-ray 3D” and “Blu-ray 3D” logo are trademarks
of the Blu-ray Disc Association.
- English
Contents
Accessories
Speaker Components
Front Panel
Rear Panel
Remote Control
Connecting the Speakers
Attaching the Toroidal Ferrite Core to the
Power Cord of the Wireless Receiver Module
(SWA-6000)
Connecting to a TV and External Devices
Connecting to a Network Router
The Initial Settings Procedure
The Home Screen at a Glance
Accessing the Settings Screen
Settings Menu Functions
Network Setup
Wi-Fi Direct
Upgrading Software
Playing Commercial Discs
Playing Multimedia Files
Controlling Video Playback
Controlling Music Playback
Using Bluetooth
Playing Photo Contents
Listening to the Radio
Using the Special Effects Remote Control
Buttons
Logging In to Your Samsung Account
Adding a Credit Card
Before Using MOVIES & TV SHOWS or
SAMSUNG APPS
Using MOVIES & TV SHOWS
Using SAMSUNG APPS
Screen Mirroring
Using the Web Browser
Linking your Internet Service Accounts to the
Product
BD-LIVE™
Additional Information
Disk and Format Compatibility
Troubleshooting
Specifications
Licenses
`
- English
Getting Started
Check the box for the accessories and speaker components listed or shown below.
Accessories
~ (AH59-02630A)
~ (4301-001042)
~ (AH68-02684A)
(For Power cord)
(3903-000598)
(AH42-00021A)
(3301-000144)
(BN63-02368B)
Speaker Components
(SWA-
6000)
- English
Front Panel
5V 0.5A
✎When the product is on, do not let children touch the product's surface. It will be hot.
✎To upgrade the product's software through the USB jack, you must use a USB flash drive.
✎When the product displays a Blu-ray Disc menu, you cannot start the movie by pressing the
5V 0.5A
MIC 2MIC 1
/p
button on the product or the remote. To play the movie, you must select Play Movie or Start in the
disc menu, and then press the button.
✎If you are using the Internet or are playing content from a USB device on your TV through the home
theater, you cannot select the mode with the button. To select the mode,
exit the Internet or stop the content you are playing on the TV, and then select the mode.
Rear Panel
HDMI OUT
LAN
POWER
AUX IN FM ANT
OPTICAL
DIGITAL
AUDIO IN
L
R
HDMI IN
SPEAKERS OUT
CENTER
SUBWOOFER
FRONT
L
FRONT
R
IMPEDANCE : 3Ω
Connect the supplied FM antenna to the FM ANT Jack.
Slowly move the antenna wire around until you find a location where reception is good, then fasten
it to a wall or other rigid surface.
✎Maintain a minimum of 4 inches of clear space on all sides of the home theater to ensure adequate
ventilation.
Do not obstruct the cooling fan or ventilation holes.
✎This product does not receive AM broadcasts.
- English
Getting Started
Remote Control
Use a coin to turn the remote
control cover anti-clockwise to
remove it as shown in the figure
above.
Insert a 3V lithium battery. Keep
the positive (+) pole upward
when inserting the battery. Put
the battery cover on and align
the '●' marks side by side as
shown in the figure above.
Use a coin to turn the cover
clockwise as far as it will go to
fix it in place.
Turn the product on and off.
Adjust the volume.
Press to move to the Home screen.
Press to skip backwards([) or
forwards(])
or
Press and hold to search
backwards(() or forwards()).
Select on-screen menu items and
change menu values.
,. : Search for active FM stations
and to change channels.
Return to the previous menu.
Use to enter the Popup menu/Title
menu.
Press to apply sound effects.
Press to apply the DTS Neo:Fusion II
or 3D sound effect.
These buttons are used both for
menus on the product and also
several Blu-ray Disc functions.
Press to select MANUAL/PRESET in
the Tuner function.
Cut off the sound temporarily.
Press to play disc or files.
or
Press to pause playing.
Press to select the Home Theater's
mode (HDMI, AUX, BD/DVD, etc.).
Press to use the Tools menu.
or
To display the number keypad (may
include function keys when
applicable) on the screen, press and
hold the button.
Press to stop the disc playing or to
exist the menu.
Use to display the playback
information when playing a Blu-
ray/DVD disc or files.
Use to set a preset radio
frequency.
Press to view the disc menu.
Set a Sleep time to shut off the
product.
Press to open and close the disc tray.
Select STEREO or MONO for radio
broadcasts.
✎While playing multimedia content in , press and hold 5 button on the remote to
pause playback. To stop playback, press and hold e () button on the remote.
- English
This section describes various methods of connecting the product to other external components.
Before moving or installing the product, be sure to turn off the power and disconnect the power cord.
Connecting the Speakers
Place it on a stand or cabinet shelf,
or under the TV stand.
The listening position should be
located about 2.5 to 3 times the
TV's screen size away from the TV.
For example, if you have a 46 inch
screen, locate the listening position
115 to 138 inches (9.6 to 11.5 feet)
from the screen.
Place these speakers in front of your listening position, facing inwards
(about 45°) toward you. Place the front speakers so that their tweeters
will be at the same height as your ear. Align the front face of the front
speakers with the front face of the center speaker or place them slightly in
front of the center speakers.
It is best to install the Center Speaker at the same height as the front
speakers. You can also install it directly over or under the TV.
Place these speakers to the side of your listening position. If there isn't
enough room, place these speakers so they face each other. Position them
about 2 to 3 feet (60 to 90cm) above your ear, facing slightly downward.
* Unlike the front and center speakers, the surround speakers are used
mainly for sound effects. Sound will not come from them all the time.
The position of the subwoofer is not so critical. Place it anywhere you like.
Connections
- English
Connections
Match each speaker cable bundle to the correct speaker by matching the color coded plug on each
bundle to the colored sticker on the bottom or back of each speaker.
Connect the speaker wire plugs from each speaker to the back of the product by matching the
colors of the speaker plugs to the colors of the speaker jacks.
HDMI OUT
LAN
POWER
AUX IN FM ANT
OPTICAL
DIGITAL
AUDIO IN
L
R
HDMI IN
SPEAKERS OUT
CENTER
SUBWOOFER
FRONT
L
FRONT
R
IMPEDANCE : 3Ω
SPEAKERS OUT
CENTER
SUBWOOFER
FRONT
L
FRONT
R
IMPEDANCE : 3Ω
Front Speaker (R)
Subwoofer
Center Speaker
Wireless Receiver Module
Surround
Speaker (L)
Front Speaker (L)
Surround
Speaker (R)
* This product should be connected with the SWA-6000 only.
✎ If you place a speaker near your TV set, the screen color may be distorted because of the magnetic
field.
✎Place the wireless receiver module at the rear of the listening position. If the wireless receiver module
is too close to the product, sound from the speakers may be disrupted because of interference.
✎If you use a device such as a microwave oven, wireless LAN Card, Bluetooth device, or any other
device that uses the 2.4/5.8GHz frequencies near the product, sound from the speakers may be
disrupted because of interference.
✎The maximum transmission distance from the product to the wireless receiver module is about 33
feet (10m), but may vary depending on your operating environment. If a steel-concrete wall or
metallic wall is between the product and the wireless receiver module, the system may not operate
at all, because the radio waves cannot penetrate metal.
✎If the product doesn't make a wireless connection, you need to run an ID Set between the product
and wireless receiver module. With the product turned off, press and hold (mute) button on the
remote control for 5 seconds. Turn on the wireless receiver module. Then, press and hold the "
" button on the back of the wireless receiver module for 5 seconds, and then turn the product
on.
- English
▶ If you want to install the speakers on the wall, fasten screws or nails (not provided) firmly to the wall
wherever you want to hang a speaker, and then, using the hole in the rear of each speaker, carefully
hang each speaker on a screw or nail.
▶ Do not let children play with or near the speakers. They could get hurt if a speaker falls.
▶ When connecting the speaker wires to the speakers, make sure that the polarity (+/ –) is correct.
▶ Keep the subwoofer speaker out of reach of children to prevent children from inserting their hands
or alien substances into the duct (hole) of the subwoofer speaker.
▶ Do not hang the subwoofer on the wall using the duct (hole).
▶ The wireless receiving antenna is built into the wireless receiver module. Keep it away from water
and moisture.
▶ For optimal listening performance, make sure that the area around the wireless receiver module
location is clear of any obstructions.
▶ In 2-CH mode, you will hear no sound from the wireless surround speakers.
Attaching the Toroidal Ferrite Core to the Power Cord of the Wireless
Receiver Module (SWA-6000)
If you attach a Toroidal ferrite core to the power cord of the
wireless receiver module, it will help prevent RF interference from
radio signals.
Pull the fixing tab of the Toroidal ferrite core to open it.
Make two loops in the wireless receiver module power cord.
Attach the Toroidal ferrite core to the wireless receiver
module's power cord as shown in the figure on the right, and
then close it by pressing it until it clicks.
~Attach the ferrite core as close to the Wireless Receiver
Module as possible.
- English
Connections
Connecting to a TV and External Devices
HDMI OUT
LAN
AUX IN FM ANT
OPTICAL
DIGITAL
AUDIO IN
L
R
HDMI IN
HDMI OUT HDMI IN
AUDIO OUT OPTICAL OUT
HDMI OUT
LAN
POWER
AUX IN FM ANT
OPTICAL
DIGITAL
AUDIO IN
L
R
HDMI IN
SPEAKERS OUT
CENTER
SUBWOOFER
FRONT
L
FRONT
R
IMPEDANCE : 3Ω
R
W
Connect an HDMI cable (not supplied) from the HDMI OUT jack on the back of the product to the HDMI
IN jack on your TV. If the TV supports ARC, you can hear the audio from your TV through the home
theater with only this cable connected. See page 17 in this manual and the section on ARC in your
TV's user's manual for details.
Using an RCA audio cable (not supplied), connect the AUDIO In jack on the product to the AUDIO Out
jack on the external analog component. Select the mode.
~ Be sure to match the colors on the cable plugs to the colors on the input and output jacks.
Use to connect the digital audio output of digital signal components such as Cable Boxes and Satellite
Receivers (Set-Top-Boxes) to the home theater. Using a digital optical cable (not supplied), connect the
Optical Digital Audio In jack on the product to the Digital Optical Out jack of the external digital device
using a digital optical cable. Select the mode.
Connect an HDMI cable (not supplied) from the HDMI IN jack on the back of the product to the HDMI
OUT jack on your digital device. Select the mode.
✎To see video from your Cable Box/Satellite receiver, you must connect its video output directly to your TV.
✎This system supports Digital sampling frequencies of 32 kHz or higher from external digital components.
✎This system supports only DTS and Dolby Digital audio. MPEG audio, a bitstream format, is not supported.
To select an external device after you have connected it, press the button. Each time you press
the button, the mode changes in this order : ;;;;;
- English
Connecting to a Network Router
You can connect your product to your network
router using one of the methods illustrated
below.
HDMI OUT
LAN
POWER
AUX IN FM ANT
OPTICAL
DIGITAL
AUDIO IN
L
R
HDMI IN
SPEAKERS OUT
CENTER
SUBWOOFER
FRONT
L
FRONT
R
IMPEDANCE : 3Ω
✎Your router or your Internet Service Provider's
policies may prevent the product from
accessing Samsung's software update server.
If this occurs, contact your Internet Service
Provider (ISP) for more information.
✎ DSL users, please use a router to make a
network connection.
✎ To use the DLNA function, you must connect
your PC to your network as shown in the
illustrations above.
The connection can be wired or wireless.
✎ If your wireless IP router supports DHCP, this
product can use a DHCP or static IP address to
connect to the wireless network.
✎ Set your wireless IP router to Infrastructure
mode. Ad-hoc mode is not supported.
✎ The product supports only the following
wireless security key protocols:
-WEP (OPEN/SHARED), WPA-PSK (TKIP/
AES), WPA2-PSK (TKIP/AES)
✎ Select a channel on the wireless IP router that
is not currently being used. If the channel set
for the wireless IP router is currently being
used by another device nearby, it will result in
interference and communication failure.
✎In compliance with the newest Wi-Fi
certification specifications, Samsung home
theaters do not support WEP, TKIP, or TKIP-
AES (WPS2 Mixed) security encryption in
networks running in the 802.11n mode.
✎ Wireless LAN, by its nature, may cause
interference, depending on the operating
conditions (AP performance, distance,
obstacles, interference by other radio devices,
etc).
- English
Settings
The Initial Settings Procedure
~The Home menu will not appear if you do
not configure the initial settings.
~The OSD (On Screen Display) may change in
this product after you upgrade the software
version.
~The access steps may differ depending on
the menu you selected.
After you have finished connecting the home
theater to your TV, turn on the TV, and then turn
on the home theater. The first initial setup screen
appears. The setup screens appear in this order:
Language, Network Configuration, Terms and
Conditions, Screen Resolution (Aspect Ratio),
and Speaker Layout. Depending on the software
version installed on your home theater, you may
also see the Software Update screen. Follow the
instructions displayed on each screen, which will
guide you through the easy setup procedure.
If you are not ready to set up the network
configuration or it is problematic, you can select
and set it up later.
(See page 20)
✎To edit your settings after the initial setup,
select > > in the Home
screen or select the option. (See page
20)
The Home Screen at a Glance
PLAY DISC
App 1 App 2 App 3 App 4 App 5 App 6
Screen Mirroring
Function Settings
MOVIES & TV SHOWS
MULTIMEDIA
SAMSUNG APPS
No Disc
1 2 3 4
5 6 8 97
RECOMMENDED MY APPS
1
Displays information about the disc currently in
the disc tray. Press to start playing the disc.
2
Download movies and TV Shows from the
Internet.
✎Depending on your country, this menu
function may not be supported.
3
Play photos, videos, or music content from
Discs, USB devices, PCs, mobile devices, or
cloud services.
4
Download/Access various for pay or free-of-
charge applications.
5
A list of useful and popular apps we
recommend you download.
6
Displays downloaded and installed apps. You
can change the display order. (See page 43)
7
Set up the wireless mirroring function between
the home theater and a smart phone or tablet.
✎Depending on your country, this menu
function may not be supported.
8
Use to switch between external devices
connected to Digital In, AUX, or HDMI IN, to
switch to the Tuner, or to switch to a connected
Bluetooth device. You can also use the remote's
button or the main unit's button.
9
Set various functions to suit your personal
preferences.
`Selecting an Option on the Home Screen
To select an option on the Home screen,
move the cursor using the ,. buttons
until it highlights the option of your choice,
and then press the button.
✎If you leave the product in the stop mode for
more than 5 minutes without using it, a screen
saver will appear on your TV. If the product is
left in the screen saver mode for more than 20
minutes, the power will automatically turn off.
- English
Accessing the Settings Screen
Select on the Home screen, and
then press . The screen appears.
To access the menus, sub-menus, and
options on the Settings screen, please refer
to the remote control illustration below.
24
1
3
1
Button : Press to move to the
Home screen.
2
' () Button : Press to return to
the previous menu.
3
/ Button :
~Press ,. to move the cursor or
select an item.
~Press the button to activate the
currently selected item or confirm a
setting.
4
e () Button : Press to exit the
current menu.
Each function, menu item, and individual
option is explained in detail on-screen. To view an
explanation, use the ,. buttons to select
the function, menu item, or option. The
explanation will usually appear on the right of the
screen.
A short description of each function starts
below. Additional information on some of the
functions is also in the Appendix of this manual.
Settings Menu Functions
Set up the 3D related functions.
: Select whether
to play a Blu-ray Disc with 3D contents in 3D
Mode. If you move to the Home or Smart Hub
Home menu while in 3D mode, the product will
switch to 2D automatically.
: Enter the size of the TV attached
to the product. The product will automatically
adjust the 3D output to the screen size of the
T V.
✎Carefully read the health and safety
information before viewing
3D content. (See
page 4)
Lets you adjust the output of the product to
the screen size of your TV. (See page 49)
is Samsung’s latest inter-connectivity
feature.
When you connect a Samsung product and a
Samsung TV with to each other via
HDMI, and is on in both the product
and TV, the product outputs video at the video
resolution and frame rate of the Blu-ray/DVD
Disc.
Lets you set the output resolution of the HDMI
video signal to , , , ,
, . The number indicates the number
of lines of video per frame. The i and p indicate
interlaced and progressive scan, respectively.
The more lines, the higher quality.
- English
Settings
Setting the feature to
lets the product adjust its HDMI output to 24
frames per second automatically for improved
picture quality if attached to a 24Fs compatible TV.
~
You can enjoy the feature
only on a TV supporting this frame rate.
~Movie Frame is only available when the
product is in the HDMI 1080p output
resolution modes.
Converts DVD playback to 24 frames per
second and outputs it via HDMI. This option is
only available when is set
to on.
Lets you select the optimal size for the Smart
Hub or screen.
Lets you set the color space format for the
HDMI output to match the capabilities of the
connected device (TV, monitor, etc).
Lets you set the product to output video
from the HDMI OUT jack with Deep Color.
Deep Color provides more accurate color
reproduction with greater color depth.
Lets you improve picture quality when viewing
DVDs.
Lets you configure the settings of the speakers
you have connected to obtain the best possible
surround sound.
: Select if you have set up your
speakers in the recommended speaker layout
with the surround speakers next to or behind
the listening positions.
: Select if you have put your
surround speakers in front of the listening
position. Downmixes the front sound to the
surround sound speakers.
✎SFE, Virtual 7.1 will not operate when the
simple mode is on.
: Lets you select which speakers
are active, either the TV's speakers or the home
theater's speakers.
: Lets you
adjust the following speaker settings and
turn the test tone on and off so you can test
the speakers.
- : Lets you adjust the relative
loudness of each speaker from 6dB to -6dB. For
example, if you like deep bass, you can increase
the loudness of the subwoofer by 6dB.
-
:
Lets you adjust the relative
distance of each speaker from the listening
position up to 30 feet. The farther the
distance, the louder the speaker will be.
-
:
Begins a test to set the best
surround sound configuration. Press
to stop the test while it is in progress.
: You can enjoy
sound through a remote speaker that is
connected to the home theater through your
home network. To use the network speaker,
select . If there is a network
speaker available, it will appear on the screen.
- : The network speaker is not used.
- : The network speaker outputs
audio. All network speakers output the
same audio regardless of channel using the
PCM format only.
✎ and are not
applied if is set to on.
✎The network speaker is not available when
is active.
✎For further details, refer to the Multiroom
Link manual from the web site.
www.samsung.com > Support > Search for the
product name > Multiroom Link > Download PDF
Sound Customizer lets you calibrate the home
theater for the optimal sound quality based on
your hearing level and the ambient conditions.
To create a Custom Sound Profile, follow these
steps:
In the Menu, select
.
On the next screen, select . The
screen appears.
Select to preview the Test Sound.
Select , and then press to continue.
- English
A 6-step test will start. During each stage,
the TV will sound a test tone at a different
frequency. The tone will begin softly and
increase in volume. Select when you
can hear the test tone. If you want to
listen to it again, select . Each time
you select , the TV will move on to the
next tone. Once the test is complete, a
screen appears that lets you compare the
original sound to the calibrated sound.
Select , and then press the button
to continue. The on-screen keyboard
appears with a default profile name.
Enter a name for the calibrated sound
profile or accept the default name, select
, and then press the button.
Select on the next screen, and
then press the button. The
screen reappears.
: Select a Sound Profile
you created to activate it. Or select
, a Custom Sound Profile especially
composed of large sounds for those with
hearing disorders.
✎If there are more than 3 Custom Sounds
registered, mode will be activated
which is composed of the average value of all
registered profiles.
: Create and add a new
. See the instructions
above.
: Choose a
to modify it. Follow the same steps
you used when creating a sound profile. This
function is only available if you have added
a using
. (See above.)
: Rename or delete
Custom Sound Profiles. This function is only
available if you have added a
using . To select a
profile, highlight the check box to the right of
the profile, and then select or .
Lets you configure the settings
manually.
Lets you set the product so that the volume
remains stable when a scene change occurs or
when you change the channel.
(ARC)
Lets you direct the sound from the TV to the
Home Theater speakers. Requires an HDMI
connection and an (ARC)
compatible TV.
~If is set to and
you are using an HDMI cable to connect
the product to the TV, digital optical input is
disabled.
~If is set to and
you are using an HDMI cable to connect
the product to the TV, ARC or digital optical
input is selected automatically.
Lets you set the to match the
capabilities of the AV receiver you’ve connected to
the product. For more details, please refer to the
digital output selection table. (See page 55)
Lets you apply dynamic range control to Dolby
Digital, Dolby Digital Plus, and Dolby TrueHD
audio.
: Automatically controls the dynamic
range of Dolby TrueHD audio, based on
information in the Dolby TrueHD soundtrack.
Also turns dynamic range control off for
Dolby Digital and Dolby Digital Plus.
: Leaves the dynamic range
uncompressed, letting you hear the original
sound.
: Turns dynamic range control on for all
three Dolby formats. Quieter sounds are
made louder and the volume of loud sounds
is reduced.
Lets you select the multi-channel downmix
method that is compatible with your stereo
system. You can choose to have the product
downmix to or to
.
When the product is attached to a digital TV,
lets you adjust the audio delay so that the
audio syncs with the video. You can set the
delay between 0 and 300 milliseconds.
✎The function in is guaranteed
to work only with a Samsung TV that supports
the ARC function (the Anynet+ function).
- English
Settings
Lets you check the current network and
Internet status.
Lets you configure the network connection so
you can enjoy various features such as Internet
services or AllShare Wi-Fi functionality, and
perform software upgrades.
Lets you connect a device to the
product using a peer-to-peer network, without
the need for a wireless router. Note that if the
product is connected to a wireless network,
it may be disconnected when you use
. (See page 23)
✎Text files, such as files with a .TXT or .DOC
extension, will not display when you are using
the function.
Allow other devices on your network, such as
smart phones and tablets, to share content with
your product.
Lets you assign an identifying name to the
product. You use this name to identify the
product when you are connecting external Wi-
Fi devices (smart phones, tablets, etc.) to it.
Lets you set various BD-Live functions. BD-Live
allows you to access extra features available on
some Blu-ray Discs if you are connected to the
Internet.
: Lets you fully
allow, partly allow, or prohibit a BD-Live
Internet connection.
: Manage BD data
downloaded from a BD-Live service or Blu-ray
Disc.
✎To use BD-Live, you must insert a USB
storage device into the home theater's USB
port.
Lets you lock access to Video on Demand
(VOD) content based on its rating. To use, you
must enter the security PIN.
Press and hold the
button until the Num pad appears on the
screen. When the Num pad appears, select a
number using the
,.
button and then press
the
button.
✎The default security PIN is 0000.
✎Depending on your country, this menu
function may not be supported.
Use to modify captions on VOD playback that
supports closed captions. Lets you change
displayed caption's font color and size.
✎The function does not work with
VOD services that don't support closed
captions. For some VOD services that do
support closed captions, the functions
settings may not be applied.
✎Depending on your country, this menu
function may not be supported.
You can view the terms of use and privacy
policy for Smart Hub, Samsung accounts, and
various other services
Resets all Smart Hub settings to their default
settings. To use, you must enter the security
PIN.
Press and hold the button until the Num
pad appears on the screen. When the Num pad
appears, select a number using the
,.
button and then press the
button.
✎The default security PIN is 0000.
- English
Lets you re-run the Initial Settings procedure.
Refer to the descriptions displayed on the screen.
Lets you set the player to turn on quickly by
decreasing the boot time.
✎If this function is set to , Standby power
consumption will increase. (About 12W ~
20W)
Lets you select the language you prefer for the
on-screen menu, disc menu, audio, subtitles, etc.
~The language you select for the disc menu,
disc audio, or subtitles will only appear if it is
supported on the disc.
Lets you connect a wireless USB keyboard or
mouse to the USB port on the front of the
product.
Lets you configure a wireless
USB keyboard connected to the product.
✎You can use the keyboard only when a
keyboard screen or window
appears in the Web Browser.
Lets you configure a wireless
USB mouse connected to the product. You
can use the mouse in the product's menu in
the same way you use a mouse on your PC.
`To use a mouse with the product's menu:
Connect the USB mouse to the
product
.
Click the primary button you selected
in . The Simple Menu
appears.
Click the menu options you want.
✎Some USB HID keyboards and mice may not
be compatible with your product.
✎Some HID keyboard keys may not work.
✎Wired USB keyboards are not supported.
✎Some applications may not be supported.
✎If a wireless HID Keyboard does not operate
because of interference, move the keyboard
closer to the
product.
Press and hold the button until the Num pad
appears on the screen. When the Num pad
appears, select a number using the
,.
button and then press the
button.
The
default security PIN is 0000. Enter the default
PIN to access the security function if you
haven't created your own PIN.
:
Prevents playback of
Blu-ray Discs with a rating equal to or above
a specific age rating you have set unless you
enter the PIN.
: Prevents playback of
DVDs with a rating above a specific numerical
rating you have set unless you enter the PIN.
: Lets you change the 4-digit PIN
used to access security functions.
`If you forget your PIN
Remove any disc or USB storage device.
Press and hold the @ button on the front
panel for 5 seconds or more.
All settings will revert to the factory
default settings.
✎When the factory default settings are restored,
all the user stored BD data is deleted.
Lets you specify the display brightness and time
zone.
:Lets you change the brightness of
the front panel.
:You can specify the time zone that
is applicable to your area.
:Lets you adjust the
transparency of the menu box.
Anynet+ is a convenient function that offers
linked operations with other Samsung products
that have the Anynet+ feature, and lets you
control those products with one Samsung TV
remote. To operate this function, you must
connect this product to an Anynet+ Samsung
TV using an HDMI cable.
To use an function,
follow the instructions below.
1) Connect the product to an
-compliant Samsung TV using
HDMI Cable.
- English
Settings
2) Set the feature to
in both the TV and the product.
3) Search for and then select the product
in the TV's list. For
more exact instructions, see the Anynet+
section of the TV's user's manual.
When activated, lets Samsung Call Center
agents diagnose and fix problems with the
product remotely. Requires an active Internet
connection. service
might not be available in some countries.
For more information about the
function, see "Upgrading Software" on
page 24.
Lets you set the . If you are using the
home theater at home, always select
. is for retail display settings
only.
Provides contact information for assistance
with your product.
Reverts all settings to their defaults except for
the network and Smart Hub settings. Requires
that you enter your security PIN.
Press and hold
the button until the Num pad appears on the
screen. When the Num pad appears, select a
number using the
,.
button and then press
the
button.
The default security PIN is 0000.
Network Setup
When you connect this product to a network,
you can use network based applications and
functions such as Smart Hub and BD-LIVE, and
upgrade the product's software through the
network connection. For more information about
accessing and using Internet services, see the
Network Services chapter of this manual on pages
41~48. Instructions for configuring the network
connection start below.
If you didn't configure your network connection
during the initial settings procedure or you need
to reset the network connection, follow the
directions below.
Before you begin, contact your Internet Service
Provider to find out if your IP address is static or
dynamic. If it is dynamic, and you have a wired
or wireless network, we recommend using the
Automatic configuration procedures described
below.
If you are connecting to a wired network, connect
the product to your router using a LAN cable
before you start the configuration procedure.
To begin configuring your network connection,
follow these steps:
In the Home screen, select , and then
press the button.
Select , and then press the
button.
Select , and then press the
button.
Go to the instructions for Wired networks
starting below or the instructions for Wireless
networks starting on page 21.
Ğ
After following Steps 1 to 3 above:
In the screen, change
to . Then, select
and press the button. The product
detects the wired connection, verifies the
network connection, and then connects to
the network.
When it is done, highlight , and then
press button.
- English
Ğ
If you have a static IP address or the automatic
procedure does not work, you'll need to set the
values manually.
After following Steps 1 to 3 above:
In the screen, change
to . Then, select
and press the button.
The product searches for a network, and
then displays the connection failed message.
✎If it is possible to connect the home theater
to your network wirelessly, select
at this point, change the
to , and then go to the
instructions for wireless networks on this
page.
Use the buttons to select ,
and then press the button. The
screen appears.
Select the field, and then set it to
.
Select a parameter to enter (, for
example), and then press . Use the ,.
buttons on the remote control to enter the
numbers for the parameter.
Or use the Num
keypad to enter a parameter number.
Press and
hold the button until the Num pad appears
on the screen. When the Num pad appears,
select a number using the
,.
button and
then press the
button.
Use the
buttons on the remote control to move from
entry field to entry field within a parameter.
When done with one parameter, press the
button.
Press the , or . button to move to another
parameter, and then enter the numbers for
that parameter following the instructions in
Step 4.
Repeat Steps 4 and 5 until you have filled in
all parameters.
✎You can get the network parameter values
from your Internet provider.
When finished entering all the parameter
values, select , and then press the
button. The home theater verifies the
network connection and then connects to
the network.
You can set up a wireless network connection in
three ways:
-Wireless Automatic
-Wireless Manual
-WPS(PBC)
Before you configure the wireless network
connection, disconnect any wireless network
devices currently connected to the product
or, if applicable, the product's current wired
connection.
Ğ
After following Steps 1 to 3 in "Configuring Your
Network Connection" on page 20:
In the screen, change
to . The product
searches for and then displays a list of the
available networks.
Select the desired network, and then press
the button.
On the Security screen, enter your network's
security code or pass phrase.
Enter letters by selecting a letter with ,.
buttons, and then pressing button.
When finished, select , and then press
the button. The product verifies the
network connection and then connects to
the network.
- English
Settings
✎You should be able to find the security code or
pass phrase on one of the set up screens you
used to set up your router or modem.
Ğ
If you have a static IP address or the Automatic
procedure does not work, you'll need to set the
Network Settings values manually.
After following Steps 1 to 3 in "Configuring Your
Network Connection" on page 20:
In the screen, change
to . The product
searches for and then displays a list of the
available networks.
Scroll through the list, select the desired
network or , and then press the
button.
If you selected a network in Step 2, go to
Step 6.
If you selected , go to Step 4.
Enter your wireless network or wireless
router's name.
~Enter letters by selecting a letter with the
,. buttons, and then pressing the
button.
~To display capital letters (or redisplay lower
case letters if capital letters are displayed),
select , and then press the button.
~To display symbols and punctuation, select
, and then press the button. To
redisplay letters, select , and then
press the button.
When finished, select , and then press
the button.
On the screen that appears,
use the ,. buttons to select the network's
, and then press the button.
On the next screen, enter your network's
security code or pass phrase.
~Enter letters by selecting a letter with the
,. buttons, and then pressing the
button.
When finished, select , and then press
the button. The product searches for the
network.
The Network connection fail screen appears.
Use buttons to select , and
then press the button.
Select the field, and then set it to
.
Select a network parameter to enter (
, for example), and then press
button. Use the ,. buttons on the remote
control to enter the numbers for the
parameter.
Or use the Num keypad to enter a
parameter number.
Press and hold the
button until the Num pad appears on the
screen. When the Num pad appears, select a
number using the
,.
button and then
press the
button.
Use the buttons on
the remote control to move from entry field
to entry field within a parameter. When done
with one value, press the button.
Press the , or . button to move to another
parameter, and then enter the numbers for
that parameter following the instructions in
Step 8.
Repeat Steps 8 and 9 until you have filled in
all parameters.
✎You can get the Network parameter values
from your Internet provider.
When finished, select , and then press the
button. The Security screen appears.
On the Security screen, enter your network's
security code or pass phrase. Enter letters by
selecting a letter with the ,. buttons,
and then pressing the button.
When finished, select at the right of
the screen, and then press the button.
The product verifies the network connection
and then connects to the network.
After the home theater verifies the network,
select , and then press the button.
✎You can also begin the Manual Network setup
by going to
.
Ğ
One of the easiest ways to set up the wireless
network connection is using the
function. If your wireless router has a WPS(PBC)
button, follow these steps:
After following Steps 1 to 3 in "Configuring Your
Network Connection" on page 20:
In the screen, change
to . The product
searches for and then displays a list of the
available networks.
- English
Scroll the list down, select , and
then press the button.
Press the button on your
router within two minutes. Your product
automatically acquires all the network
settings values it needs and connects to your
network after the network connection is
verified.
When it is done, highlight , and then
press the button.
✎For a WPS connection, set your wireless
router’s security encryption to AES. WEP
security encryption does not support a WPS
connection.
Wi-Fi Direct
The function allows you to connect
devices to the product and each other
using a peer-to-peer network, without a wireless
router.
✎Some devices may not support
the AllShare function if connected via
. If this is the case, change the network
connection method you used to connect the
device to the home theater.
✎ transmissions can interfere
with Bluetooth signals. Before you use the
Bluetooth function, we strongly recommend
that you turn off the function on
any device in which it is currently on.
Turn on the device and activate
its function.
In the Home screen, select , and then
press the button.
Select , and then press the
button.
Select , and then press the
button.
The devices that you can connect
the home theater to appear.
AndroidXXXXXXX Disconnected
You have three ways to complete the Wi-Fi
connection:
~Through the Wi-Fi device.
~Through the product using PBC.
~Through the product using a PIN.
Each is covered below.
On the Wi-Fi device, follow the device's
procedure for connecting to another
device. See the device's user manual
for instructions.
When you have completed the procedure,
you should see a pop-up on your TV screen
saying that a device that supports
has requested to connect. Select ,
and then press the button to accept.
The Connecting pop-up appears, followed
by the Connected pop-up. When it closes,
you should see the device listed on the
screen as connected.
~The PBC and PIN procedures connect devices
automatically.
Select the device you want to
connect to this product, and then press the
button.
The Connecting pop-up appears, followed
by the Connected pop-up. When it closes,
you should see the device listed on the
screen as connected.
Select the device you want to
connect to this product, and then press the
button.
The PIN pop-up appears.
Note the PIN code in the pop-up, and then
enter it into the appropriate field in the
device you want to connect.
The Connecting pop-up appears, followed
by the Connected pop-up. When it closes,
you should see the device listed on the
screen as connected.
✎The current wired or wireless network
connection will be disconnected when you use
the function.
- English
Settings
✎Text files, such as files with a .TXT or .DOC
extension, will not display when you are using
the function.
Upgrading Software
The menu allows you to
upgrade the product’s software for performance
improvements or additional services.
~Never turn the product off or back on
manually during the update process.
In the Home menu, select , and then
press the button.
Select , and then press the
button.
Select , and then press the
button.
To download update software and update
now, select , and then press the
button. See "Update now" on this page
for details.
To let the product download update software
automatically when available, select
, and then press the button. (See
page 24)
✎The upgrade is complete when the product
turns off, and then turns on again by itself.
✎Samsung Electronics takes no legal
responsibility for product malfunction
caused by an unstable Internet connection
or consumer negligence during a software
upgrade.
✎If you want to cancel the upgrade while the
upgrade software is downloading, press the
button.
✎When a system upgrade is in progress,
"UPDATE" is displayed on the front panel.
You can use to update the software
through your network connection or by using
a USB flash drive. The network instructions are
below. The USB flash drive instructions are on the
next page.
Select , and then press the
button.The Update now pop-up appears.
The product searches on line for the latest
software version.
If it does not find an update, the "There are
no new updates for you at the moment."
pop-up appears. Press the button to exit.
If it finds a new version, the Update Request
pop-up appears.
Select . The product upgrades the
software, turns off, and then turns on
automatically.
If you do not select or in one
minute, the product stores the new upgrade
software. You can upgrade the software later
using .
If you select , the product cancels the
upgrade.
✎When the system upgrade is done, check the
software details in the Product Information
section of the Contact Samsung screen.
✎Do not turn off the product during the
Software Upgrade. It may cause the product
to malfunction.
You can set the function so that the
product downloads new upgrade software when
it is in mode.
In mode, the product is on, but
its Internet connection is active. This allows
the product to download upgrade software
automatically, when you are not using it.
Press the ,. buttons to select
mode, and then press the button.
Select or .
If you select , the product will
automatically download new upgrade
software when it is in Auto Update mode
with the power on. If it downloads new
upgrade software, the product will ask you
if you want to install it when you turn the
product on.
✎To use the function, your product
must be connected to the Internet.
- English
Visit www.samsung.com.
Click on the top right of the page.
Enter the product's model number into the
search field. As you enter the model number,
a drop down will display products that match
the model number.
Left click your product's model number in the
drop down list.
On the page that appears, scroll down to and
then click .
Click in the center of the page.
Click the button in the File column on the
right side of the page.
Click in the first pop-up that appears.
Click in the second pop-up to download
and save the firmware file to your PC.
Unzip the zip archive to your computer. You
should have a single folder with the same
name as the zip file.
Copy the folder to a USB flash drive.
Make sure no disc is inserted in the product,
and then insert the USB flash drive into the
USB port of the product.
In the product’s menu, go to
.
Select .
The product searches for the software on the
USB drive. When it finds the software, the
Update Request pop-up appears.
Select . The product upgrades the
software, turns off, and then turns on
automatically.
✎There should be no disc in the product when
you upgrade the software using the USB jack.
✎When the system upgrade is done, check the
software details in the Product Information
section of the Contact Samsung screen.
✎Do not turn off the product during the
software upgrade. It may cause the product to
malfunction.
✎Software upgrades using the USB jack must
be performed with a USB flash drive only.
- English
Playing Content
Your home theater can play content located on
Blu-ray/DVD/CD discs, USB devices, PCs, smart
phones, tablets, and on the Web.
To play content located on your PC or a mobile
device, you must connect the PC or mobile device
and the product to your network. To play content
on your PC, you must also download and install
AllShare network software or already have DLNA
network software on your PC.
✎PCs running Windows 7 and Windows 8 have
DLNA software (Play To) built in.
Playing Commercial Discs
Press the ^ button to open the disc tray.
Place a disc gently into the disc tray with the
disc’s label facing up.
Press the ^ button to close the disc tray.
Playback starts automatically.
If playback does not start automatically, press
the p button on the remote.
~Holding Discs
-Fingerprints or scratches on
a disc may reduce sound and
picture quality or cause skipping.
-Avoid touching the surface of a disc where
data has been recorded.
-Hold the disc by the edges so that fingerprints
will not get on the surface.
-Do not stick paper or tape on the disc.
~Cleaning Discs
-If you get fingerprints or dirt
on a disc, clean it with a mild
detergent diluted in water and
wipe with a soft cloth.
-When cleaning, wipe gently from the inside
to the outside of the disc.
-Disc Storage
`Do not keep in direct sunlight.
`Keep in a cool ventilated area.
`Keep in a clean protective jacket and
store vertically.
Playing Multimedia Files
In the Home screen, select ,
and then press the button. The Recently
Played screen appears.
Select , ,or
at the bottom of the screen.
~ - Displays storage devices
connected to the product.
~ - Displays mobile devices,
PCs, tablets, and similar devices connected
through the network.
~ - Displays the cloud
services you are logged in to.
✎When you select an item, information about
the item scrolls across the bottom of the item's
listing window.
Select an item or device, and then press
the button. A screen appears listing the
contents of the item or device. Depending
on how the contents are arranged, you will
see either folders, individual files, or both.
If necessary, use the ,. buttons to
select a folder, and then press the button.
Use the ,. buttons to select a file to
view or play, and then press the button.
The selected file plays.
Press the ' () button to exit a folder
or the e () button to return to the
Home screen.
Go to pages 28~39 for instructions that
explain how to control playback of videos,
music, and pictures on a storage device.
✎To list only one type of media file, use the
function in the top-right corner of
the item or device screen.
✎In the drop down, select ,
, or .
✎Even though the product will display folders
that contain all content types, it will only
display files of the content type you selected
For example, if you selected , you will
only be able to see music files.
- English
Turn the product on.
Follow the directions in “Playing Multimedia
Files” on page 26. In Step 2, select
.
Connect the storage device to the product.
(a recorded CD, a USB device, etc.) The "
" pop-up appears. If two or
more storage devices are connected, use the
buttons to switch between devices.
PLAY DISC
App 1 App 2 App 3 App 4 App 5 App 6
Screen Mirroring
Function Settings
MOVIES & TV SHOWS
MULTIMEDIA
SAMSUNG APPS
No Disc
RECOMMENDED MY APPS
New device connected.
USB Flash Disk
All Content
Photos
Videos
Music
✎If the pop-up does not appear, go to Method
1.
Use the ,. buttons to select
, or , and then press the
button. Depending on how the contents
are arranged, you will see either folders,
individual files, or both.
✎To list only one type of media file, use the
function in the top-right corner of
the item or device screen.
✎In the drop down, select ,
, or .
✎Even though the product will display folders
that contain all content types, it will only
display files of the content type you selected
For example, if you selected , you will
only be able to see music files.
If necessary, use the ,. buttons to
select a folder, and then press the button.
Select a file to view or play, and then press
the button.
Press the ' () button to exit a folder
or the e () button to return to the
Home screen.
Go to pages 28~39 for instructions that
explain how to control playback of videos,
music, and pictures on a storage device.
✎If you insert a disc when playing a USB device
or phone, the device mode changes to "Disc"
automatically.
✎If your cellular phone is DLNA compatible, you
can play contents without connecting a USB
cable.
You can play media content on the Home theater
that is stored on a computer or mobile device
connected to the same network as the Home
theater.
✎Samsung Link software must be installed on
the computer that contains the content you
want to play on the Home theater. The mobile
device must support Samsung Link. For more
information, visit Samsung’s content and
service portal at http://link.samsung.com.
✎You may experience compatibility issues when
attempting to play media files via a third-party
DLNA server.
✎The content shared by a computer or a
mobile device may not play depending on the
encoding type and file format of the content.
In addition, some functions may not be
available.
✎The media content may not play smoothly
depending on the network status. If this
occurs, use a USB storage device.
In the Home screen, select , and
then press the button.
Select at the bottom of
the screen, and then press the button.
Storages devices connected to the same
network as the Home theater are listed.
Select a storage device, and then press the
button. The folders and files shared by
the selected storage device are listed.
If necessary, use the ,. buttons to
select a folder, and then press the button.
- English
Playing Content
Select a file to view or play, and then press
the button.
Press the ' () button to exit a folder
or the e () button to return to the Home
screen.
Go to pages 28~39 for instructions that
explain how to control playback of videos,
music, and pictures on a storage device.
✎To list only one type of media file, use the
function in the top-right corner of
the item or device screen.
✎In the drop down, select ,
, or .
✎Even though the product will display folders
that contain all content types, it will only
display files of the content type you selected
For example, if you selected , you will
only be able to see music files.
✎Alternatively, move to the media content
to play and press the button to play the
content.
Dropbox and SkyDrive and other cloud services
save user content such as photos, videos,
and music files on a remote server accessible
through the Internet. When your home theater
is connected to the Internet, you can view or
play the media content saved in a cloud service
through the home theater.
✎To play the content in a cloud service, you
must log into your Samsung account and link
the Samsung account to the cloud service
account. For the information about linking
your Samsung account to a cloud service
account, refer to the "Logging In to Your
Samsung Account" section.
In the Home screen, move to
and press button.
Select at the bottom of the
screen.
The cloud services linked with your Samsung
account appear.
Select a cloud service. The folders and files in
the selected cloud service are listed.
If necessary, use the ,. buttons to
select a folder, and then press the button.
Select a file to view or play, and then press
the button.
Press the ' () button to exit a folder
or the e () button to return to the Home
screen.
Go to pages 28~39 for instructions that
explain how to control playback of videos,
music, and pictures located in a
.
Controlling Video Playback
You can control the playback of video content
located on a Blu-ray/DVD disc, USB device, mobile
device, or PC. Depending on the disc or contents,
some of the functions described in this manual
may not be available.
1
2
1
During playback, press this button to display
the Disc menu.
During playback, press this button to display
the Title menu or Popup menu.
~If your disc has a playlist, press the
button to go to the playlist.
2
The product does not play sound in Search, or
Slow mode.
~To return to normal speed playback, press the
p button.
- English
pStarts/Pauses playback.
e ()Stops playback.
During playback, press and hold
the [ or ] button.
Each time you press and hold
the [ or ] button, the
playback speed will change.
In pause mode, press and hold
the ] button.
Each time you press and hold
the ] button, the playback
speed will change.
During playback, press the [
or ] button.
Each time you press the [ or
] button, the disc moves to
the previous or next chapter or
file.
During playback, press the button.
During playback, press the button.
Use the buttons to select
T
in the
upper right corner, and then press the button.
Select to return to the beginning of the movie,
and then press the button.
Use menu to select the or
option if the 3D content currently
playing does not appear properly in 3D mode.
✎Use menu for 3D content only. If you
apply the
or format
to 2D content, it will not be displayed
properly.
You can use the function during
playback to view or start a movie from the
scene of your choice.
✎If the index information in the file is
damaged or the file does not support
indexing, you will not be able to use the
Select Scene function.
✎If you are using the DLNA function after
connecting to a computer through
your network, Select Scene may not be
supported.
If there is more than one
movie on the disc or device, select to start a
different title.
Select , and then press the
button.
Use the ,. buttons to select a title,
and then press the button.
Select to play the chapter of
your choice.
Select , and then press
the button.
Use the ,. buttons to select a chapter,
and then press the button.
Select to play the movie
from a selected time point.
Select , and then press
the button.
Press and hold the button until the
Num pad appears on the screen. When
the Num pad appears, select a number
using the ,. button and then
press the button.
✎You can also
use the buttons to
advance or rewind the movie. The movie
advances or rewinds one minute each time
you press the buttons.
Lets you repeat a title, chapter, or specific
section.
- : Select to return to normal playback.
- : Choose to repeat a selected title.
- : Choose to repeat a specific chapter.
- : Choose to repeat a specific
section.
Press the button at the point where
you want repeat play to start (A).
Press the button at the point where
you want repeat play to stop (B).
- English
Playing Content
✎Depending on the disc, the screen may not
display all repeat options.
✎, , and appear
only when you play a video recorded as a
digital file.
✎The screen may not display or
immediately. Continue to press the
,. buttons until your choice is inside the
applicable field.
✎The screen may not display
immediately. Continue to press the ,.
buttons until is inside the
applicable field.
✎You must set point (B) at least 5 seconds of
playing time after point (A).
Lets you set the .
- : Increases sharpness and
brightness.
- : Choose this setting for most
viewing applications.
- : The best setting for watching movies.
- : Lets you adjust the sharpness and
noise reduction function respectively.
✎When you use the function, this
menu will not appear.
Set Equalizer Mode on to use the equalizer.
Lets you set the equalizer.
✎Equalizer Settings only appears when
is .
Select to set the desired audio language.
In some cases when the product is connected
to a digital TV, the audio signal may not
synchronize with the video signal. If this occurs,
use Audio Sync to adjust the audio delay time
to match the video signal.
Lets you set the desired subtitle language.
Lets you set the desired subtitle options.
To view a scene from another angle. The
option displays the number of angles available
to view (1/1, 1/2, 1/3, etc.).
Lets you set the desired Bonusview option.
You can rotate the screen clockwise or
counterclockwise by 90 degrees.
Lets you set the size of the video image.
Choose , (larger), or
(largest).
Select to view video file information.
✎Depending on the disc or storage device, the
Tools menu may differ.
✎Video files with high bitrates of 20Mbps or
more strain the product’s capabilities and may
stop playing during playback.
- English
Select the function, and then to
display videos only.
✎Even though the product will display folders
that contain all content types, it will only
display files of the content type you selected
For example, if you selected , you will
only be able to see video files.
On the screen that lists the video files, use the
,. buttons to select or in
the upper right, and then press the button.
`
Displays all the folders with videos by date. If
you select a folder, and then press button,
displays all the video files in the folder by date.
`
Displays all the video files on the media or
storage device by title.
`
Displays all the folders on the media or
storage device.
`
lets you create a playlist by
selecting specific files to play. It works
essentially the same way for all media. See
"Using Play Selected with a Commercial CD"
on page 34.
`
Select to upload selected files to on-line
sites (Picasa, Facebook, etc.) or to devices.To
use , you need to
establish an account with the on-line site,
and then log in using the Log In function.
works essentially the same way for
music, photos, and videos. For general
instructions, see "Using the Send Function"
on page 39.
✎Depending on the disc or storage device, the
All
options may not be displayed.
✎The and menus are usually
available when you are viewing video files on
a USB flash drive, a PC, a disc you recorded
yourself, or a mobile device. They are usually
not available if you are viewing a commercial
Blu-ray, DVD, or CD disc.
Controlling Music Playback
You can control the playback of music content
located on a DVD, CD, USB, mobile device, or PC.
Depending on the disc or contents, some of the
functions described in this manual may not be
available.
1
4
3
2
1[ ] buttons : Move to the previous/
next track.
2e () button : Stops a track.
3
During playback, press and hold the [
or ] button.
Each time you press and hold the [
or ] button, the playback speed will
change.
4p button : Plays/Pauses a track.
- English
Playing Content
00:00/00:00
TRACK 001 00:43
TRACK 002 03:56
TRACK 003 04:41
TRACK 004 04:02
TRACK 005 03:43
TRACK 006 03:40
TRACK 007 04:06
TRACK 008 03:52
TRACK 009 03:04
TRACK 010 04:02
TRACK 001
The Track List screen appears initially, and the
first track begins to play. If you are playing a
commercially recorded disk and don't press a
button on the remote momentarily, the Playback
screen appears. To return to the Track List screen,
press the ' () button.
00:00:40 00:03:35
TRACK 001
On the Track List screen, use ,. buttons to
move the highlight to the track you want. Press
the button to play the track.
1
Pause a track.
1
Play a track.
1
Move to the previous track.
1
Move to the next track.
1
Rewind the track.
1
Advance the track.
1
,
1
Repeat one track or all tracks.
1
Play tracks in random order.
Display the Equalizer.
On the
Music List
screen only.
: Adjust the
equalizer manually. (Available
only when is on)
:
lets
you select specific files to play.
It works essentially the same
way for all media. See "Using
Play Selected with Self-Recorded
Media (CDs, USB Devices, etc.)"
on page
34
.
:
The Ripping function
converts CD audio to the
mp3 format and saves the
converted files on a USB device
or a mobile device connected
to the product. See Ripping on
page 36.
:
Shows the track
information.
To access the controls, play a track, and then use
the
,.
buttons to move to the control of
your choice.
✎The music screen controls are only accessible
when a track is playing.
✎All controls do not appear at the same time.
✎For file-based contents, the available
options will differ.
Select the function, and then to
display music files only.
✎Even though the product will display folders
that contain all content types, it will only
display files of the content type you selected
For example, if you selected , you will
only be able to see music files.
On the screen that lists the music files, use the
,. buttons to select or in
the upper right, and then press the button.
- English
`
Displays all the music tracks on the media or
storage device.
`
Displays all the music on the media or
storage device by album.
`
Displays all the music files on the media or
storage device by artist
`
Displays all music on the media or storage
device by genre.
`
Displays all the folders on the media or storage
device.
`
lets you select specific files to
play. It works essentially the same way for
all media. See "Using Play Selected with a
Commercial CD" on page 34 and "Using
Play Selected with Self-Recorded Media (CDs,
USB Devices, etc.) on page 34.
`
Select to upload selected files to on line
sites (Picasa, Facebook, etc.) or to devices.
To use with an on line site, you need
to establish an account with the on-line site,
and then log in using the Log In function.
works essentially the same way for
music, photos, and videos. For general
instructions, see "Using the Send Function"
on page 39.
`
Select to manage the text encoding options.
`
Lets you modify the name of a playlist.
`
Lets you delete a playlist.
`
Lets you add additional files to a playlist.
✎Depending on the disc or storage device, the
menu may differ. All options may not
be displayed.
✎ and appear only
if a playlist exists.
You can set the product to repeat tracks on an
audio CD (CD-DA/MP3).
On the Track List screen during playback, use
the ,. buttons to select
1
in the
lower left corner of the screen, and then
press the button.
Use the ,. to select the Repeat mode you
want - , , or - and then press
the button.
00:00/00:00
TRACK 001 00:43
TRACK 002 03:56
TRACK 003 04:41
TRACK 004 04:02
TRACK 005 03:43
TRACK 006 03:40
TRACK 007 04:06
TRACK 008 03:52
TRACK 009 03:04
TRACK 010 04:02
TRACK 001
00:00:40 00:03:35
TRACK 001
Press the ' () button on the remote to
return to the Track List screen.
- English
Playing Content
You can set the product to play tracks on an audio
CD (CD-DA/MP3) at random.
During playback, use the ,. buttons to
select
1
in the lower left corner of the
screen, and then press the button.
Use the ,. to set the mode or
, and then press the button.
On the Track List screen, select
on the bottom left, and then press the
button. The menu appears.
Select , and then press the
button. The screen appears.
Use the ,. buttons to select a track, and
then press the button. A check appears
to the left of the track.
Repeat Step 3 to select and check additional
tracks.
To remove a track from the list, move to the
track, and then press the button again.
The check on the track is removed.
When done, select on the bottom
left, and then press the button. The
Track List screen reappears listing only the
tracks you checked. The selected tracks play
automatically.
To cancel the list, select
on the bottom left of the Track list
screen. On the Settings menu select
. The Track List screen reappears with all
tracks on the CD listed.
✎You can select up to 99 tracks from an Audio
CD (CD-DA) using Play Selected.
✎On the screen, you can also
choose , , and .
- Use to select all tracks. This cancels
your individual track selections. When you
press the ' () button on your remote
or select and then press the button,
all tracks will appear on the Track List screen,
and the product will begin to play all tracks
from Track 001.
- Use to deselect all selected
tracks at once. Then, select individual tracks
or use to select all the tracks, and
then press the ' () button on your
remote or select and then press the
button. If you do not use or select
individual tracks, the list will
not change.
- cancels any changes you made on the
screen. When you return to the
Track List screen, the list will be
unchanged.
Insert a self-recorded CD or USB device with
self-recorded files into the home theater. The
pop-up appears.
Select , and then press the button
on your remote. The File List screen appears
displaying icons for tracks, folders, or both.
If necessary, use the ,. buttons to
select a folder, and then press the button.
When the tracks you want to play are
displayed, select in the upper right,
and then press the button.
Select , and then press the
button. Check boxes appear on the upper
left sides of the track icons.
Use the ,. buttons to select a track,
and then press the button. A check
appears in the check box.
Repeat Step 6 to check and select additional
tracks.
To remove a track from the list, move to the
track, and then press the button again.
The check on the track is removed.
When done, select , and then press the
button. The Track List screen appears
listing only the tracks you checked. The
selected tracks play automatically.
To cancel the list, press the '
() button or the e () button. If
you press ' (), you return to the File
List screen. If you press e (), you go to
the Home screen.
✎If you want to use to watch
videos, use the function to select
instead of .
- English
✎Select or depending
on the media you are using.
- If you selected , the Track List
screen appears. Use the function
to select , and then follow the
directions starting at Step 3 above.
- If you selected , select
or on the
screen. Then, select your storage media on
the screen or device on the
screen. The File List screen appears.
Use the function to select ,
and then follow the directions starting at
Step 3 above.
Connect a USB device with stored music to
the home theater's USB jack, and then turn
on the home theater.
On the Home screen, select ,
and then press the button.
On the screen, select ,
and then press the button.
Select the USB device, and then press the
button.
At the top of the screen, select ;
.
After the screen re-displays, select
; .
On the next screen, select an existing playlist,
and then press the button.
Select , and then press the
button. If you selected an existing playlist, go
to Step 9. If you selected , go to
Step 8.
On the on-screen keyboard, accept the
default name for the new playlist or enter
a new name. When finished, select ,
press , and then go to Step 9.
Navigate to the screen that displays the
music you want to put into the playlist.
Use the ,. buttons to select a track,
and then press the button. A check
appears in the check box on the left side of
the track icon.
Repeat Step 10 to check and select additional
tracks.
To remove a track from the list, move to the
track, and then press the button again.
The check on the track is removed.
When finished, select at the top of the
screen, and then press the button. The
playlist is saved to the USB device and the
Added pop-up appears. Press the button.
Connect the USB device with the playlist to
the home theater's USB port.
Navigate to the playlist (Home screen ;
; ; USB device ;
playlist).
Select the playlist, and then press . The
Track List screen appears and the first track
of the playlist starts to play.
While playing a playlist, select
; at the bottom-left corner of
the Track List screen.
Use the ,. buttons to select a track,
and then press the button. A check mark
appears next to the track.
To cancel a selection, select the track again,
and then press the button.
✎To select all tracks at once, use . To
cancel all selections at once, use .
When finished, select at the bottom
left of the screen, and then press the
button.
A confirmation pop-up appears.
Select , and then press the button.
✎Deleting all files included in a playlist will
delete the playlist itself, too.
✎You can save up to 5 playlists.
- English
Playing Content
Insert a USB device into the USB jack on the
front of the product. This is the device you
will rip the files to.
Put a music CD into the home theater. In a
few moments, the Track List screen appears.
On the Track List screen, select
on the lower left of the screen, and then press
the button. The Settings menu appears.
Use the ,. buttons to select , and
then press the button. The Ripping screen
appears.
Use the ,. buttons to select a track, and
then press the button. A check appears
to the left of the track.
Repeat Step 5 to select and check additional
tracks.
✎To select all tracks at once, select on
the bottom left of the screen, and then press
the button.
To remove a track from the list, move to the
track, and then press the button again.
The check on the track is removed.
When done, select the button using the
,. buttons, and then press the button.
The Rip pop-up appears.
Use the ,. buttons to select the device to
store the ripped files to, and then press the
button. Ripping begins.
✎Do not disconnect the device while ripping is
in progress.
If you want to cancel ripping after ripping
has begun, press the button and then
select . Select to continue ripping.
When ripping is complete, the "
" message appears. Press the
button. The Track List screen reappears.
Using Bluetooth
You can use a Bluetooth device to enjoy music
with high quality stereo sound, all without wires!
Bluetooth is a technology that enables Bluetooth-
compliant devices to interconnect with each other
easily using a short, wireless connection.
~A Bluetooth device may hum or malfunction:
-When a part of your body is in contact with
the receiving/transmitting system of the
Bluetooth device or the Home Theater.
-When it is subject to electrical variation from
obstructions caused by a wall, corner, or
office partitioning.
-When it is exposed to electrical interference
from same frequency-band devices including
medical equipment, microwave ovens, and
wireless LANs.
~Pair the Home Theater with the Bluetooth
device while the two are close together.
~The further the distance is between the Home
Theater and the Bluetooth device, the worse
the quality is.
If the distance exceeds the Bluetooth
operational range, the connection is lost.
~In poor reception areas, the Bluetooth
connection may not work properly.
~The Home Theater has an effective reception
range of up to 32.8 feet in all directions if
there are no obstacles. The connection will be
automatically cut off if the device is out of this
range. Even within this range, the sound quality
may be degraded by obstacles such as walls or
doors.
~This wireless device may cause electrical
interference. during its operation.
- English
Before you begin, confirm that the Bluetooth
device supports the Bluetooth compliant stereo
headset function.
Press the button on the remote
control to display the message.
Select the Bluetooth menu on the Bluetooth
device you want to connect. For instructions,
refer to the Bluetooth device's manual.
Select the Stereo headset menu on the
Bluetooth device.
~You will see a list of devices.
Select "" from the searched list.
~When the Home Theater is connected to
the Bluetooth device, the device name of
the connected Bluetooth device, followed
by the name of home theater will appear
on the front display of home theater.
Play music on the connected device.
~You can listen to the music playing on the
connected Bluetooth device over the Home
Theater system.
✎The Home Theater only supports Middle
Quality SBC data (up to 237kbps@48kHz),
and does not support High Quality SBC data
(328kbps@44.1kHz).
✎The AVRCP feature is supported. It's
functionality will differ, depending on the
specifications of the connected device.
✎Connect only to a Bluetooth device that
supports the A2DP Profile.
✎Only one Bluetooth device can be paired at a
time.
✎The search or connection functions may not
work properly in the following cases:
-If there a strong electric field near or around
the home theater.
-If several Bluetooth devices are simultaneously
paired with product.
-If the Bluetooth device is turned off, not in
place, or malfunctions.
-Note that such devices as microwave ovens,
wireless LAN adapters, fluorescent lights, and
gas stoves use the same frequency range as
the Bluetooth device, and can cause electric
interference.
✎For a more reliable connection to a Bluetooth
device or to other devices such as a smart
phone, we recommend you update the
device's software to the most current version.
You can disconnect the Bluetooth device from
the Home Theater. For instructions, refer to the
Bluetooth device's manual.
~When the Home Theater is disconnected from
the Bluetooth device, the Home Theater will
display on the front display.
Press the ( ) button on the front panel of the
Home Theater to switch from to another mode
or turn off the Home Theater.
~Except when you disconnect the Home Theater
by changing functions, the connected Bluetooth
device will wait a certain time for a response
from the Home Theater before terminating the
connection. (Disconnection time may differ,
depending on the Bluetooth device.)
✎In Bluetooth connection mode, the Bluetooth
connection will be lost if the distance between
the Home Theater System and the Bluetooth
device exceeds 32.8 feet. When the Bluetooth
device comes back into effective range or
you restart the Bluetooth device, you have
to pair the device and home theater again to
reconnect.
- English
Playing Content
✎In Bluetooth mode, the screen saver will start
if the Bluetooth device stays in the Ready state
for 5 minutes. To reconnect the Bluetooth
device, turn off the screen saver, and then
connect the device. To turn off the screen
saver, press any button on the remote control
(the Volume button, an ,. buttons, etc.)
When the home theater is turned off, connecting
a previously connected smart device to the
product via a Bluetooth connection can turn the
home theater on.
✎The home theater must be plugged in for
to work.
✎To use this function, set > >
to .
✎To use this function, the Bluetooth connection
between the Home theater and your smart
device must have been established previously,
and the Home theater must be on your smart
phone's list of known Bluetooth devices.
Connect your previously connected smart
device to the product via Bluetooth. (For
information on Bluetooth connections, refer
to your smart device’s manual.)
Once connected, the home theater turns
itself on automatically in BT mode.
~Select the desired music to play on your
smart device.
Playing Photo Contents
You can play photo contents located on a DVD,
USB, mobile device, or PC.
While displaying a photo, press the button
on the remote.
Select
T
in the upper right corner of
the screen, and then press the button. The
Tools menu drop down list appears.
` : Select to set a slide show's speed.
` : Select to set a slide show's special
effects.
Select to rotate the picture. (This will rotate the
picture either clockwise or counter clockwise.)
Select to enlarge the current picture. (Enlarge
up to 4 times)
` : Choose to increase sharpness.
` : Choose for most viewing
applications.
` : This is the best setting for watching
movies.
` : Lets you adjust the sharpness and
noise reduction function respectively.
Select to listen to music while viewing a slide
show.
Set to to use the equalizer. Customize your
own personal sound preferences using the
equalizer settings.
This function is only available when
is .
Select to upload selected files to on-line
sites (Picasa, Facebook, etc.) or to devices.
To use with an on-line site, you need to
establish an account with the on-line site, and
then log in using the Log In function.
works essentially the same way for music,
photos, and videos. For general instructions,
see "Using the Send Function" on page 39.
Displays the picture information.
✎Depending on the disc or storage device, the
menu may differ. All options may not
be displayed.
✎To enable the function, the
photo file must be in the same storage media
as the music file. However, the sound quality
can be affected by the bitrate of the MP3
file, the size of the photo, and the encoding
method.
✎You can't enlarge the subtitle and PG graphic
in the full screen mode.
- English
Select the function, and then to
display photos only.
✎Even though the product will display folders
that contain all content types, it will only
display files of the content type you selected
For example, if you selected , you will
only be able to see photo files.
On the screen that lists the photo files, use the
,. buttons to select or in
the upper right, and then press the button.
`
Groups all the photo files on the media or
storage device by date. Click a group to see
the photos in that group.
`
Displays all the photo files on the media or
storage device by title.
`
Displays all the folders on the media or
storage device.
`
Starts the slide show. Shows all the files in
the current folder, one after another. If you
want to create a slide show with a selected
group of photos, see Play Selected below.
`
lets you select specific files to
play. It works essentially the same way for all
media. See "Using Play Selected with Self-
Recorded Media (CDs, USB Devices, etc.)" on
page 34.
`
Select to upload selected files to on line
sites (Picasa, Facebook, etc.) or to devices.
To use with an on-line site, you need
to establish an account with the on-line site,
and then log in using the Log In function.
✎Depending on the disc or storage device, the
menu may differ. All options may not
be displayed.
Use the ,. buttons to select , and
then press the button. The Selection
screen appears.
Use the ,. buttons to select a picture, and
then press the button. A check appears
to the left of the picture.
Repeat Step 2 to select and check additional
pictures.
To remove a picture from the list, move to
the picture, and then press the button
again. The check on the picture is removed.
When done, press the ,. button to select
, and then press the button. The
Send pop-up appears listing the on-line sites
(Picasa, Facebook, etc.) or devices that you
can send the photos to.
Select a destination, and then press the
button.
If you are sending the photos to an on-line site,
the site starts. Log in and follow the directions
on the screen.
✎To send photos to an on-line site, you must
have an account with that site.
Listening to the Radio
~To listen to the radio, you must connect the
supplied FM antenna.
Press the button to select .
Tune to the desired station.
~Preset Tuning 1 : Press the button
to select , and then press the ,.
buttons to select a preset station.
-Before you can tune to preset stations,
you must add preset stations to the
product's memory.
~Manual Tuning : Press the button
to select , and then press the
,. buttons to tune to a lower or higher
frequency.
~Automatic Tuning : Press the
button to select , and then press
and hold the ,. buttons to automatically
search the band.
- English
Playing Content
Press the button.
~Each time you press the button, the sound
switches between and .
~In a poor reception area, select for a
clear, interference-free broadcast.
Example : Presetting FM 89.10 into memory.
Press the button to select .
Press the ,. buttons to select <89.10>.
Press the button.
~NUMBER flashes on the display.
Press the button again.
~Press the button before
NUMBER disappears from the display on its
own.
~After you press the button,
NUMBER disappears from the display and
the station is stored in memory.
To preset another station, repeat steps 2 to 4.
~To tune to a preset station, press the
button to select , and then
press the ,. buttons to select the preset
station.
Using the Special Effects Remote
Control Buttons
Lets you select a mode that optimizes the
sound.
Press the button.
Press the ,. buttons to select the
desired mode: , ,
, or .
Press the buttons to select the
desired sound effect.
Ğ
z: Helps enhance your sound
experience (ex. mp3 music). You can
upscale your MP3 level sound (24 kHz, 8bit)
to CD level sound (44.1 kHz, 16bit).
z: Increases the volume level of
bass tones and provides thudding sound
effects.
z: Creates a virtual 7.1 CH sound
using the 5.1 CH speaker system.
z: Select for normal listening.
Ğ
You can set a two-channel input source to
produce sound in 5.1 channel surround mode.
Ğ
z: Provides
a clear vocal as if listening in a concert hall.
z:
Also provides a clear vocal as if listening in a
concert hall, but less powerful than HALL1.
z: Recommended setting
for Jazz.
z: Gives the feel of being in a
grand church.
z: Recommended
setting for Rock.
z: Select for normal listening.
Ğ
z: Emphasizes the commentator's
voice during a sports game to increase your
absorption in the game.
z: Emphasizes spectators' cheering
during a sports game to add immediacy.
z: Select for normal listening.
You can enjoy more natural and vivid surround
sound with enriched tones by adjusting the
depth of sound using the level options.
~:
~:
✎ is not available in mode.
✎The is displayed only if you
selected >
.
- English
You can enjoy various network services such as
streaming video or on-line apps by connecting the
product to your network.
To use network services, you must first:
Connect the product to a network.
(See page 13)
Configure the network settings.
(See pages 20~23)
Logging In to Your Samsung
Account
Before you access or
, we suggest you log in to your
Samsung account.
✎If you do not have a Samsung account, create
one by selecting .
To create a Samsung account, follow these steps:
With the Home screen displayed, press the
button. The screen appears.
Select the ID field, and then press the
button. The keyboard pop-up appears.
Using the keyboard, enter your e-mail
address. When finished, select the
button, and then press the button. The
screen re-appears.
Select the Password field, and then press the
button. The keyboard pop-up appears.
Using the keyboard, enter your password.
When finished, select the button, and
then press the button. The screen
re-appears.
To make the log in process easier next time,
select , and then
press the button.
Select , and then press the
button.
The
screen appears.
Select , and then press the
button.
Select an image you want to use to identify
your account, and then press the button.
Select .
✎If you selected ,
the next time you log in, the product will
automatically enter your e-mail and password.
All you need to do is select .
✎If you press the button after you have
logged in, the screen appears. You
can select , ,
, and .
Adding a Credit Card
To add a credit card to your account, follow these
steps:
Select the in the upper right of the Home
Screen, and then press the button. The
Account screen appears.
Sign in to your account if you are not signed
in. The Home Screen reappears. If you are
already signed in, go to Step 4.
Select the again, and then press the
button. The Account screen appears.
On the Account screen, select
, and then press the button. The
on-screen keyboard appears.
Enter your account password. When finished,
select , and then press the button.
The screen appears.
Select , and then press the
button. The Add Card pop-up appears.
Read the Add Card text, and then press the
button. The screen appears.
Enter the requested credit card information.
When done, select , and then press the
button.
Before Using MOVIES & TV SHOWS
or SAMSUNG APPS
If you haven’t set up Smart Hub, when you use
or for the
first time, the product will ask you to perform the
Smart Hub set up procedure.
On the Home screen, select either
or , and then press
the
button.
If you selected , the
Smart Hub pop-up appears asking if you
want to set up Smart Hub. Select , and
then press the button. The Welcome
screen appears.
Select , and then press the button.
The screen
appears.
Network Services
- English
Network Services
On the
screen, you must review and agree to both
the Smart Hub Terms and Conditions and the
Privacy Policy to use Smart Hub.
Scroll down, and then click the
buttons to review the full documents.
✎You do not need to consent to the
Supplemental Privacy Notice, but one or more
Smart TV features or functionalities may not
be available if you do not.
Select , and then press the
button. The Setup Complete screen appears.
Press the button.
Using MOVIES & TV SHOWS
Through the screen, you
can stream movies and TV shows and watch them
on your TV.
To stream and watch most movies and TV shows,
you need a Samsung account with a registered
credit card. To register a card, see page 41.
✎Depending on your country, this menu
function may not be supported.
MOVIES & TV SHOWS
NEWLY ADDED
Featured Movies TV Shows Trailers TrendingFavorites
On the Home screen, select
, and then press the button.
Select one of the Recommended Movies or
TV Shows, and then press the button. The
Information screen for that movie appears.
✎As you highlight each movie or TV show, the
icons for the apps you can use to stream the
movie or show appear at the bottom of each
movie or show selection icon.
. Alternately, select , ,
, or and
then press the button.
On the page that appears, use the ,.
buttons to select a show, movie, or trailer,
and then press the button.
On the or screen, you can
also select or to see
more available shows or films. On the
screen, use the ,. buttons to select a
genre, and then press the button.
To make a selection on a page displaying
movies or TV shows, use the ,.
buttons to make a selection, and then press
the button.
If you have downloaded and installed one of
the video streaming apps that you can use
to stream the movie or show, select
, and then press the button. The
app launches. Follow the directions on the
screen to watch the movie or show you have
chosen. If you have not downloaded one of
the apps, go to Step 4.
If you have not downloaded one of the video
streaming apps, appears on the
screen instead of . Select one
of the video streaming apps to the right of
, and then press the Button.
You will be asked if you want to install the
app now. Select , press the button,
and then follow the directions on the screen
to install the app. You can also select
to view information about the app.
The screen lets you download
the app as well.
Once the app is installed, select , and
then press to launch the app. Alternately,
you can press the ' () button to go
back to the screen,
select the show or movie again, and then
follow the directions in Step 3 to watch the
movie or show.
✎Contents items and the corresponding bottom
menu in differ between
countries.
✎On the each movie or show information
screen, the button is displayed
only after you have download one of the video
streaming apps you can use to stream that
particular movie or show. appears if
you have not downloaded the necessary video
streaming app. To the right of is a
listing of the video streaming apps you can use
to stream the movie or show. Select an app
icon to download and install the app.
✎ will not appear unless you have
tagged one or more films or TV shows as a
favorite. To tag a movie or show as a favorite,
select the show. The Detail screen appears.
Select the heart symbol, and then press the
button.
- English
Using SAMSUNG APPS
Through the screen, you can
download applications from the Internet, and
launch and run downloaded applications on your
TV. To access some applications, you need to have
a Samsung account.
✎While playing multimedia content in
, press and hold 5 button on the remote
to pause playback. To stop playback, press and
hold e () button on the remote.
2
2
3
3
4
4
5
5 6 7 98 10
1
WebBrowser
1 2
3
Most Popular What's new Categories
RECOMMENDED
MY APPS
SAMSUNG APPS
1
: Displays recommended
contents managed by Samsung. You
cannot delete Recommended Apps.
2
: Displays your personal gallery
of applications modifiable on the
screen.
3
and
: Select to view and download additional
apps.
The first time you open the
screen, the Home theater automatically downloads
a group of free apps. Once these apps have been
downloaded, they appear on the
screen. To see additional apps, select
, , or on the bottom
of the screen, and then press the button.
displays the most popular apps,
the newest. displays a
series of icons representing categories such as
, , and . Select a category
icon, and then press the button. The Home
theater displays the apps in that category.
Select , , or
, and then press the button.
If you selected , select a category
icon, and then press the
button.
Otherwise, go to Step 3.
✎On the , , and
screens, a green arrow is displayed
on apps you have already downloaded.
Select an app you want to download,
and then press the
button. The Detail
Information screen for the App appears.
Select the button on the screen,
and then press the button.
changes to and the app begins to
download.
If you want to cancel the download, select
, and then press the button.
When the download is complete,
changes to . Select , and then press
the button to start the application.
Alternately, press the ' () button
until the screen reappears.
The app you downloaded will be displayed
on the App screen under .
Select on the Home screen,
and then press the button.
On the screen, use the
,. buttons to select an app, and then
press the button. The app starts.
The Option menu lets you add apps to and delete
apps from . It also lets you change the
position of an app in and update apps.
On the screen, select the app you
want to move, and then press the button
for 3 seconds. The Option menu appears.
Select , and then press the
button.
Use the ,. buttons to move the app.
When the app is where you want it, press the
or e () button.
- English
Network Services
On the screen, select the app you
want to delete, and then press the button
for 3 seconds. The Option menu appears.
Select , and then press the button .
Use the buttons to select , and then
press the button.
On the screen, select an app you
want to delete and then press the button
for 3 seconds. The Options menu appears.
Select the , and then press the
button.
Use the ,. buttons to select apps you
want to delete, and then press the
button.
Use the . button to select , and then
press the button.
On the screen, select the app you
want to see detailed information for, and
then press the button for 3 seconds. The
Option menu appears.
Select , and then press the
button.
On the screen, select an app, and
then press the button for 3 seconds. The
Option menu appears.
Select , and then press the
button. If the current view is Most Played,
you will be asked if you want to change to
Custom View. If the current view is Custom
View, you will be asked if you want to
change the view to Most Played. Most Played
sorts the apps by the number of times you
ran each app. Custom View lets you arrange
the apps to your liking.
Select , and then press the button to
change the view.
Locking an app makes it more difficult to delete
accidently.
On the screen, select the app you
want to lock, and then press the button
for 3 seconds. The Option menu appears.
Select , and then press the
button.
The PIN input pop-up appears. Enter your
PIN.
Press and hold the button until the
Num pad appears on the screen. When the
Num pad appears, select a number using the
,.
button and then press the
button.
If you haven't set a PIN, enter the default
PIN: 0000.
A checkbox appears on each app icon. Use
the ,. button to move to the app you
want to lock, and then press the button to
select it. A check mark appears on the icon.
Repeat Step 4 to select other apps. Use
or on the bottom of
the screen to select or deselect all apps at
once. To deselect individual apps, select the
app again, and then press the button.
The check mark disappears.
When you have finished marking your
selections, move to on the bottom of
the screen, and then press the button.
A lock mark appears on the selected app’s
icon. You will be prompted to enter the PIN
number to delete or unlock a locked app.
On the screen, select any app, and
then press the button for 3 seconds. The
Option menu appears.
Select , and then press the
button.
The screens lists all the apps
that have updates available. Select each app
you want to update, and then press the
button. You can also choose to
update all the apps listed.
Select , and then press the button.
Screen Mirroring
The function lets you view the
screen of your smart phone or android tablet on
the TV you have connected to the product.
In the Home screen, select ,
and then press the button.
Launch or on
your device.
On your device, find the name of the product
in the list of available devices and then select it.
- English
The TV displays a connecting message (for
example, Connecting to Android_92gb...)
and then displays the connected message.
In a few moments, the screen of your device
appears on the TV screen.
To stop , press the e
() or ' () button on the remote
control, or exit the function
on your smart phone.
✎You can connect to a device that supports
AllShare Cast. Note that all devices that have
AllShare Cast may not be fully supported,
depending on the manufacturer. For further
information on mobile connection support,
refer to the manufacturer’s web site.
✎When you are using the
function, video stuttering or audio dropouts
may occur, depending on your environment.
✎Bluetooth transmissions can interfere with
the signal. Before using
the function, we strongly
recommend that you turn off the Bluetooth
function on your smart phone or smart device
(tablet, etc.).
Using the Web Browser
You can access the Internet using the Web
Browser application.
Select on the Home screen
and then press the button.
On the screen, select
, and then press the button.
✎When you run the Web Browser with the
product connected by HDMI to a
compatible TV - and is on - the
browser is maximized to fill the screen and the
TV's resolution is set to the optimal resolution
automatically.
✎The Web Browser is not compatible with Java
applications.
✎If you attempt to download a file, and the file
cannot be saved, an error message will appear.
✎E-commerce (purchasing produc ts online) is
not supported.
✎ActiveX is not supported.
✎Access may be blocked to some websites or to
web browsers operated by certain businesses.
The Web Browser provides two types of browsing,
Pointer Browsing and Link Browsing. When you
launch the browser for the first time, Pointer
Browsing is active. If you are using a mouse to
navigate in the Web Browser, we recommend
leaving Pointer Browsing active. With Pointer
Browsing, you move the pointer using the
directional arrow keys on your remote. The pointer
moves freely around the screen, much like the
pointer on a computer when you use a mouse.
With Link Browsing, you use the directional arrow
keys to move a highlight from one link, button, or
entry field to the next. The highlight is restricted
to the links, buttons, and entry fields.
To activate Link Browsing, follow these steps:
Use the ,. buttons on your remote to
move the pointer to the Link Browser icon on
the top right of the screen. The Link Browser
icon is the third icon from the right.
The pointer will be in the correct position if
the icon turns blue and the words “Link
Browsing” appear on the screen.
Press the button. Link Browsing is
activated and will remain active whenever
you bring up the Web Browser or until you
change to Pointer Browsing.
The Control Panel, which runs across the top
of the screen, has a series of icons which start
a number of useful functions. The icons are
described below, starting with the icon on the far
left of the screen.
http://www.samsung.com
100%
- English
Network Services
~
http://www.samsung.com 100%
: Moves to the previous page.
~
http://www.samsung.com 100%
: Moves to the next web page.
~
http://www.samsung.com 100%
: Displays the Bookmarks and History
screen. You can bookmark the current page,
select an existing bookmark, and edit and
delete bookmarks. You can also view your
browsing history and select a page to revisit.
~
http://www.samsung.com 100%
: Moves to the Home screen of the Web
Browser.
~
http://www.samsung.com 100%
: Lets you enter a page
address manually using the keyboard pop-
up.
~
http://www.samsung.com 100%
: Reloads the current page so that it is
refreshed on the screen.
~
http://www.samsung.com 100%
: Adds the current page to your
bookmarks.
~
http://www.samsung.com 100%
: Lets you search for
information by entering words or characters
using the keyboard pop-up. See Using the
Keyboard Popup on this page.
~
http://www.samsung.com 100%
: Lets you enlarge or shrink the screen
by various percentages.
~ / : Lets you switch between Pointer
Browsing and Link Browsing.
~
http://www.samsung.com 100%
: Lets you configure the Browser’s settings.
See Using the Setting Menu on page 47.
~
http://www.samsung.com 100%
: Closes the Web Browser.
When you click the
http://www.samsung.com 100%
, the
http://www.samsung.com 100%
or access a data or text entry
field, and then press the button, the keyboard
pop-up appears.
To use the keyboard pop-up with your remote,
follow these steps:
http://www.samsung.com
As you enter characters, recommended text will be shown.
Caps 1 2 3 4 5 6 7 8 9 0 : Clear
q w e r t y u i o p ^ *
123#& a s
d
f
g
h
j
k
l
~
@ !
Done
z x c v b n m , . ? -
Cancel
100%
ENG
www.
.com
/
Use the ,. buttons on your remote to
move the highlight to a letter or number of
your choice.
Press the button to enter the letter or
number into the entry field.
To access capital letters, move the highlight
to the key on the top left, and then
press the button. Press the button
again with the key highlighted to access
small letters again.
To access symbols and additional punctuation
marks, highlight the button on the
left, and then press the button.
To delete a character you entered, move the
highlight to the : button, and then press the
button.
To delete all the characters you entered,
move the highlight to the button, and
then press the button.
When finished entering, move the highlight
to the button, and then press the
button.
✎If you have a wireless keyboard connected
to your product, you can use the wireless
keyboard to enter letters, numbers, symbols,
and punctuation. Note that the wireless
keyboard will work only when the keyboard
popup appears and can only be used to enter
letters, numbers, symbols, and punctuation.
To access the keyboard pop-up options, highlight
the
http://www.samsung.com 100%
button on the bottom left of the keyboard,
and then press the button.
Select the language for the keyboard. You can
select English, French, Russian, etc.
The keyboard suggests recommended words as
you enter text. You can turn this function or
.
Reset erases the Samsung Keyboard's memory.
Select to erase everything that the Samsung
Keyboard has learned about your writing style,
including any new words you have used.
- English
The keyboard will predict the next letter as you
enter letters. The predictions appear in a ring
around the letter you have just entered. You
can select a predicted letter or move to another
letter. You can turn this function or .
Select if you want to type letters with accent
marks.
The menu contains functions that control
how the Browser operates and Browser security
functions. To open the menu, highlight
the
http://www.samsung.com 100%
icon in the Control Panel, and then press
the button. To select an option in the
menu, highlight the option, and then press the
button.
http://www.samsung.com
Enable Grabbing
Approved Sites
Private Browsing On
Set Search Engine
Web Browser Setting
Help
Close
100%
Turns the Grabber function on and off. When
the Grabber function is on, you can move a
web page up and down without dragging the
scroll bar. The Grabber function is only available
in Pointer Browsing.
Lets you restrict your children’s access to
inappropriate web pages by allowing access
only to the web sites you have registered.
Every time you access this function, the PIN
screen appears. Press and hold the button
until the Num pad appears on the screen.
When the Num pad appears, select a number
using the ,. button and then press the
button. The first time you access this
function, enter the default PIN, 0000.
You can change the PIN using the Reset
password for the function. See
below.
` : Turns the
function on or off.
` : Change
the Approved Sites password.
` : Lets you add the currently
displayed web site to the Approved Sites list.
` : Lets you key in
URLs to add to the Approved Sites List and
delete sites from the Approved Sites list. If
you turn this function on and have not added
any sites to the Approved Sites list, you will
not be able to access any Internet sites.
Enable or disable the Privacy mode. When the
Privacy mode is enabled, the browser does not
retain the URLs of sites you visit. If you want to
enable Privacy mode, select .
If the Privacy mode is running, the “Stop” icon
appears in front of the URL at the top of the
screen. To disable Privacy mode, select it again
when Privacy mode is enabled.
You can set the desired Search Engine.
` : You can set the Browser's
home page.
` : Turns the Pop-up Block on
and off.
` : You can determine whether to
block advertisements and select the URLs for
which advertisements are blocked.
` : You can delete personal
information such as website history and
browsing data (cookies, etc.), and reset
all web browser settings to their factory
defaults. You can also set the .
✎Set the to to avoid
accessing malicious/phishing sites and
prevent malicious code from running.
` : You can set the Encoding setting
for web pages to Automatic or select the
encoding format manually from a list.
- English
Network Services
` : You can set the speed of the cursor
when the cursor is set to Pointer Browsing.
` : Displays the version
number and copyright information for the
Web Browser.
Provides basic information about the operation
of the Web Browser.
✎Depending on the web site, some of the
functions may not be
activated. Functions that are not activated are
greyed out and cannot be used.
Linking your Internet Service
Accounts to the Product
The Link Accounts function lets you link your
product to your accounts with Internet services
such as Pandora so that the product can log you
in to the service automatically when you start the
app for that service.
To create a service account link, follow these
steps:
On the Home screen, select the button in
the upper right corner, and then press the
button to log in to your Samsung Account.
After you have logged in, select the
button again, and then press the button.
Select in the My Account
screen, and then press the button.
On the screen, select the
service you want to link to the product, and
then press the button.
In the ID and Password screen, enter the ID
you use to log in to the service you selected
using the pop-up keyboard. When finished,
select , and then press the button.
Repeat the same process for the password.
When finished select , and then press
the button.
Select , and then press the button.
BD-LIVE™
Once the product is connected to your network,
you can enjoy various movie-related service
contents available on BD-LIVE compliant discs.
Attach a USB flash memory to the USB jack
on the front of the product, and then check
its remaining memory. The memory device
must have at least 1GB of free space to
accommodate the BD-LIVE services.
Select on the Home screen, and
then press the button.
Select , and then press the
button.
Select , and then press the
button.
Select , and then press
the button.
Select , and then press the
button.
Select USB device, and then press the
button.
Insert a Blu-ray Disc that supports BD-LIVE.
Select an item from the list of BD-LIVE service
contents provided by the disc manufacturer.
✎The way you use BD-LIVE and the provided
contents may differ, depending on the disc
manufacturer.
- English
Additional Information
~Certain HDMI output resolutions may not work,
depending on your TV.
~You must have an HDMI connection to enjoy
videos with 3D technology.
~A long HDMI cable may cause screen noise. If
this occurs, set to in the
menu.
~For some 3D discs, to stop a movie during 3D
playback, press the e () button once. The
movie stops and the 3D mode option is de-
activated.
To change a 3D option selection when you are
playing a 3D movie, press the e () button
once. The Blu-ray menu appears. Press the e
() button again, then select in
the Blu-ray menu.
~Depending on the content and the position
of the picture on your TV screen, you may see
vertical black bars on the left side, right side, or
both sides.
~Depending on the disc type, some aspect ratios
may not be available.
~If you select an aspect ratio and option which is
different than the aspect ratio of your TV screen,
the picture might appear to be distorted.
~If you select , your TV may display
(black bars on the sides of the
picture).
~When is , the setting
automatically defaults to and
appears in the menu.
~If the product is connected to a device that does
not support , you cannot use the
function.
~For proper operation of , set the
option in both the product and the TV to
.
~Be sure to select the correct or
you will hear no sound or just loud noise.
~If the HDMI device (AV receiver, TV) is not
compatible with compressed formats (Dolby
Digital, DTS), the audio signal outputs as PCM.
~Regular DVDs do not have BONUSVIEW audio
and Navigation Sound Effects.
~Some Blu-ray Discs do not have BONUSVIEW
audio and Navigation Sound Effects.
~This setup does not affect the
analog (L/R) audio or HDMI audio output to
your TV.
It affects the optical and HDMI audio output
when your product is connected to an AV
receiver.
~If you play MPEG audio soundtracks, the audio
signal outputs as PCM regardless of your
selections (PCM or Bitstream).
~ can be activated when
is set to .
~The Internet connection may be restricted while
you are using BD-LIVE contents.
~Depending on your TV, certain HDMI output
resolutions may not work. Please refer to the
user manual of your TV.
~This function is not available if the HDMI cable
does not support CEC.
~If your Samsung TV has an Anynet+ logo, then it
supports the Anynet+ function.
~In the external memory mode, disc playback may
be stopped if you disconnect the USB device in
the middle of playback.
~Only those USB devices formatted in the FAT file
system (DOS 8.3 volume label) are supported.
We recommend you use USB devices that
support the USB 2.0 protocol with 4 MB/sec or
faster read/write speeds.
~The Resume Play function may not work after
you format the storage device.
~The total memory available to
may differ, depending on
conditions.
~You cannot change the brightness of the
button and the , button.
Appendix
- English
Appendix
~When is set to , audio
is produced by the TV speakers.
~When HDMI audio is output to the TV speakers,
it is automatically down-mixed to 2 channels.
~When is , the
function is not available.
~Using an HDMI cable not certified for
ARC (Audio Return Channel) may cause a
compatibility problem.
~The ARC function is only available if an ARC-
compliant TV is connected.
~Video files with high bitrates of 20Mbps or more
strain the product’s capabilities and may stop
playing during playback.
~The ., indicator will not appear on the screen
if the BONUSVIEW section does not contain any
BONUSVIEW audio settings.
~The languages available through the Audio
Language function depend on the languages
that are encoded on the disc. This function or
certain languages may not be available.
~Some Blu-ray Discs may allow you to select
either the PCM or Dolby Digital audio English
soundtrack.
~Depending on the Blu-ray Disc/DVD, you may be
able to change the subtitle language in the Disc
Menu. Press the button.
~This function depends on the selection of
subtitles that are encoded on the disc and may
not be available on all Blu-ray Discs/DVDs.
~Information about the main feature BONUSVIEW
mode will also appear if the Blu-ray Disc has a
BONUSVIEW section.
~This function changes both the primary and
secondary subtitles at the same time.
~The total number of primary and secondary
subtitles, respectively, is displayed.
~You can’t enlarge the subtitle and PG graphics in
the full screen mode.
~If the home theater is connected to a BD Wise
compliant TV that has , the
Settings menu will not appear.
~The function will not work
unless the music file and the photo file are
located on the same storage media. Also, sound
quality can be impacted by the bitrate of the
MP3 music file, the size of the photos, and the
encoding method.
Disk and Format Compatibility
VIDEO
Blu-ray Disc
3D Blu-ray Disc
BD-ROM or BD-RE/-R
disc recorded in the BD-
RE format.
DVD-VIDEO,
DVD-RW,
DVD-R,
DVD+RW,
DVD+R
DVD-VIDEO, recorded
DVD+RW/DVD-
RW(V)/DVD-R/+R
discs that have been
recorded and finalized,
or a USB storage media
containing MKV, MP4
contents.
MUSIC
CD-RW/-R,
DVD-RW/-R,
BD-RE/-R
Music recorded on CD-
RW/-R, DVD-RW/-R,
BD-RE/-R discs or a
USB storage media
containing MP3 or WMA
contents.
CD-RW/-R,
DVD-RW/-R,
BD-RE/-R
Photos recorded on
CD-RW/-R, DVD-
RW/-R, BD-RE/-R
discs or a USB storage
media containing JPEG
contents.
- English
✎The product may not play certain CD-RW/-R and
DVD-R because of the disc type or recording
conditions.
✎If a DVD-RW/-R disc has not been recorded
properly in DVD video format, it will not be
playable.
✎Your product will not play content that has been
recorded on a DVD-R at a bitrate that exceeds 10
Mbps.
✎Your product will not play content that has been
recorded on a BD-R or USB device at a bitrate that
exceeds 30 Mbps.
✎Playback may not work for some types of discs, or
when you use specific operations, such as angle
change and aspect ratio adjustment. Information
about the discs is written in detail on the disc box.
Please refer to this if necessary.
✎When you play a BD-J title, loading may take longer
than a normal title or some functions may perform
slowly.
~HD DVD
~DVD-ROM/PD/MV-Disc,
etc
~DVD-RW(VR mode)
~CVD/CD-ROM/CDV/
CD-G/CD-I/LD
(CD-Gs play audio only,
not graphics.)
~DVD-RAM
~Super Audio CD
(except CD layer)
~3.9 GB DVD-R Disc for
Authoring.
✎This product may not respond to all operating
commands because some Blu-ray Disc, DVD, and
CD discs allow specific or limited operation and
provide only certain features during playback.
Please note that this is not a defect in the
product.
✎Samsung cannot guarantee that this product
will play every disc bearing the Blu-ray Disc,
DVD, or CD logo because disc formats evolve,
and problems and errors may occur during the
creation of Blu-ray Disc, DVD, and CD software
and/or the manufacture of discs.
✎Please contact the SAMSUNG Customer Care
Center at 1-800-726-7864 if you have questions
or encounter difficulty when playing Blu-ray Discs,
DVD, or CD discs in this product. Also, refer to the
rest of this user manual for additional information
on playback restrictions.
✎Some commercial discs and DVD discs purchased
outside your region may not play on this product.
Blu-ray Disc 3D Blu-ray Disc
BD-LIVE Dolby
DTS
Java
NTSC broadcast system
in U.S.A, Canada, Korea,
Japan
Both products and discs are coded by region. These
regional codes must match for a disc to play. If the
codes do not match, the disc will not play.
The Region Number for this product is displayed on
the rear panel of the product.
A
North America, Central
America, South America,
Korea, Japan, Taiwan, Hong
Kong and South East Asia.
b
Europe, Greenland, French
territories, Middle East, Africa,
Australia and New Zealand.
C
India, China, Russia, Central
and South Asia.
- English
Appendix
1
The U.S., U.S. territories and
Canada
2
Europe, Japan, the Middle
East, Egypt, Africa, Greenland
3
Taiwan, Korea, the
Philippines, Indonesia, Hong
Kong
4
Mexico, South America,
Central America, Australia,
New Zealand, Pacific Islands,
Caribbean
5
Russia, Eastern Europe, India,
North Korea, Mongolia
6
China
✎If the Region number of a Blu-ray Disc/DVD
does not correspond to the Region number of
this product, the product cannot play the disc.
~This product can play back AVCHD format discs.
These discs are normally recorded and used in
camcorders.
~The AVCHD format is a high definition digital video
camera format.
~The MPEG-4 AVC/H.264 format compresses images
with greater efficiency than the conventional
image compressing format.
~Some AVCHD discs use the “x.v.Color” format. This
product can play back AVCHD discs that use the
“x.v.Color” format.
~“x.v.Color” is a trademark of Sony Corporation.
~“AVCHD” and the AVCHD logo are trademarks of
Matsushita Electronic Industrial Co., Ltd. and Sony
Corporation.
✎Some AVCHD format discs may not play,
depending on the recording conditions.
✎AVCHD format discs need to be finalized.
✎“x.v.Color” offers a wider color range than normal
DVD camcorder discs.
✎Some MKV and MP4 format discs may not play,
depending on their video resolution and frame
rate.
~Your product supports USB storage media, MP3
players, digital cameras, and USB card readers.
~The product does not support folder or file names
longer than 128 characters.
~Some USB/digital camera devices may not be
compatible with the product.
~Your product supports the FAT 16, FAT 32, and
NTFS file systems.
~Connect USB devices directly to the product’s USB
port. Connecting through a USB cable may cause
compatibility problems.
~Inserting more than one memory device into a
multi-card reader may cause the reader to operate
improperly.
~The product does not support the PTP (Peer to
Peer) protocol.
~Do not disconnect a USB device while it is
transferring or recording data.
~The bigger the image resolution, the longer the
image takes to display.
~This product cannot play MP3 files with DRM
(Digital Rights Management) downloaded from
commercial sites.
~Your product only supports video that is under
30fps (frame rate).
~Your product only supports USB Mass Storage Class
(MSC) devices such as thumb drives and USB HDD.
(HUB is not supported.)
~Certain USB HDD Devices, multi-card readers and
thumb drives may not be compatible with this
product.
~If some USB devices require excessive power, they
may be limited by the circuit safety device.
~If playback from a USB HDD is unstable, provide
additional power by plugging the HDD into a wall
socket. If the problem continues, contact the USB
HDD manufacturer.
~SAMSUNG is not responsible for any data file
damage or data loss.
- English
*.avi
*.mkv
*.asf
*.wmv
*.mp4
*.mov
*.3gp
*.vro
*.mpg
*.mpeg
*.ts
*.tp
*.trp
*.mov
*.flv
*.vob
*.svi
*.m2ts
*.mts
*.divx
*.ps
AVI
MKV
ASF
MP4
3GP
MOV
FLV
VRO
VOB
PS
TS
SVAF
MVC
1920x1080
24/25/30 60
AC3
LPCM
ADPCM
(IMA, MS)
AAC
HE-AAC
WMA
DD+
MPEG(MP3)
DTS
(Core, LBR)
Motion JPEG
FHD :
MAX 30
HD :
MAX 60
30
H.264 BP/MP/HP
Divx 3.11 / 4 / 5 / 6
MPEG4 SP/ASP
Window Media Video
v9(VC1)
AVS
MPEG2
MPEG1
Microsoft MPEG-4 v3
1280x720
MAX 30
Window Media Video
v7(WMV1), v8(WMV2)
H 263 Sorrenson
720x576
Microsoft MPEG-4 v1, v2
VP6 640x480 6~30 4
*.webm WebM VP8 1920x1080 6~30 20 Vorbis
*.rmvb RMVB RV8/9/10 (RV30/40) 1920x1080 6~30 20 RealAudio 6
`
-Files are not supported if there are some issues
with contents among the supported codecs listed
above.
-Normal playback is not guaranteed if the file's
container information is wrong or the file itself is
corrupted.
-Sound or video play may cutoff for contents with
bitrate/frame rates that are above standard.
-The seek (skip) function is not available if the file's
index table is damaged.
-Depending on your network status, play may
become disrupted when playing contents from the
network.
-Some USB/Digital camera devices may not be
compatible with the product.
-RMVB format is supported in China and Hong
Kong only
-AVS codec is supported for contents for China only
-*.ps extension is supported for contents for China
only
-DivX codec is not supported for contents in the US
`
-Supports up to H.264 Level 4.1 (except for
FMO/ASO/RS)
-Does not support VC1 AP L4
-Except for WMV v7, v8, MSMPEG4 v3, MVC, VP6
Below 1280 X 720: 60 frame max
Above 1280 X 720: 30 frame max
-Does not support GMC 2 or higher
-Supports SVAF Top/Bottom, Side by Side, Left/Right
view sequence type(2 ES) Only
-Supports BD MVC Spec Only
`
-Supports WMA 10 Pro (Up to 5.1)
-Does not support WMA lossless audio.
-Supports M2 profile
-ReadlAudio 10 lossless is not supported for
contents for China and Hong Kong
-Does not support QCELP, AMR NB/WB
-vorbis : Supported up to 5.1 channel
-DD+ : Supported up to 7.1ch
-DTS LBR codec is supported in MKV/MP4/TS
containers only
- English
Appendix
*.mp3 MPEG MPEG1 Audio Layer 3 -
*.m4a
*.mpa
*.aac
MPEG4 AAC -
*.flac FLAC FLAC Supports up to 2ch
*.ogg OGG Vorbis Supports up to 2ch
*.wma WMA WMA
Supports WMA 10 Pro (Up to 5.1)
Does not support WMA lossless audio
Supports up to M2 profile
*.wav wav wav -
*.mid
*.midi midi midi
type 0 and type 1
Seek not supported
Supported on USB only
*.ape ape ape NonSmart not supported
*.aif
*.aiff AIFF AIFF -
*.m4a ALAC ALAC -
*.jpeg JPEG 15360x8640 -
*.png PNG 4096x4096 -
*.bmp BMP 4096x4096 -
*.mpo MPO 15360x8640 -
- English
Audio
Stream on
Blu-ray Disc
PCM Up to PCM 7.1ch PCM
DTS re-encoded Re-encoded
Dolby Digital *
Dolby
Digital Up to PCM 5.1ch Dolby Digital
Dolby
Digital Plus
Up to PCM 7.1ch
Dolby Digital Plus
Dolby
TrueHD Dolby TrueHD
DTS DTS
DTS-
HD High
Resolution
Audio
DTS-HD High
Resolution Audio
DTS-HD
Master
Audio
DTS-HD Master
Audio
Audio
Stream on
DVD
PCM PCM 2ch
Dolby
Digital Up to PCM 5.1ch Dolby Digital
DTS Up to PCM 7.1ch DTS
Definition
for Blu-ray
Disc
Any
Decodes the main
feature audio
and BONUSVIEW
audio stream
together into PCM
audio and adds
Navigation Sound
Effects.
Outputs only the
main feature audio
stream so that your
AV receiver can
decode the audio
bitstream.
You will not hear
BONUSVIEW audio
or Navigation
Sound Effects.
Decodes the main
feature audio
and BONUSVIEW
audio stream
together into PCM
audio and adds
Navigation Sound
Effects, then re-
encodes the PCM
audio into DTS
bitstream.
Decodes the main
feature audio
and BONUSVIEW
audio stream
together into PCM
audio and adds
Navigation Sound
Effects, then re-
encodes the PCM
audio into Dolby
Digital bitstream or
PCM.
`If the Source Stream is 2ch or mono, “Re-encoded Dolby D” Setting are not applied. Output will be PCM 2ch.
Blu-ray Discs may include three audio streams :
-Main Feature Audio : The audio soundtrack of the main feature.
-BONUSVIEW audio : An additional soundtrack such as the director or actor’s commentary.
-Navigation Sound Effects : When you choose some menu navigation options, Navigation Sound Effects may
sound. Navigation Sound Effects are different on each Blu-ray Disc.
- English
Appendix
BD Wise Resolution of Blu-ray
Disc 1080p@60F 480i
Auto Max. Resolution of TV input Max. Resolution of TV input
1080p@60F 1080p@60F 1080p@60F
Movie Frame : Auto (24Fs) 1080p@24F -
1080i 1080i 1080i
720p 720p 720p
480p 480p 480p
✎If the TV you connected to the product does not support Movie Frame or the resolution you selected, the
message "If no pictures are shown after selecting 'Yes', please wait for 15 seconds to return to the previous
resolution. Do you want to change the resolution?" appears. If you select Yes, the TV's screen will go to
blank for 15 seconds, and then the resolution will revert to the previous resolution automatically.
✎If the screen stays blank after you have changed the resolution, remove all discs, and then press and hold
the @ button on the top of the product for more than 5 seconds. All settings are restored to the factory
default. Run the Initial Settings procedure again. Then, go to > > in the Menu,
and select the correct resolution for your TV.
✎When you run the Initial Settings procedure, re-select the language and aspect ratio (screen size and format)
only. Resetting does not affect your network settings, so you should be able to skip Network Setup and
Software Update.
✎When the factory default settings are restored, all stored user BD data will be deleted.
✎The Blu-ray Disc must have the 24 frame feature for the product to use the Movie Frame (24Fs) mode.
Troubleshooting
Refer to the table below when this product does not function properly. If the problem you are experiencing is
not listed below or if the instructions below do not help, turn off the product, disconnect the power cord, and
contact Samsung Electronics at 1-800-SAMSUNG (1-800-726-7864).
~Is the power cord plugged securely into the outlet?
~Turn off the power, and then turn it back on.
~Check the region number of the Blu-ray/DVD disc.
Blu-ray/DVD disc purchased from abroad may not be playable.
~CD-ROMs and DVD-ROMs cannot be played on this product.
~Make sure that the rating level is correct.
- English
p
~Are you using a deformed disc or a disc with scratches on the surface?
~Wipe the disc clean.
~The home theater does not play sound during fast playback, slow playback,
and step motion playback.
~Are the speakers connected properly? Is the speaker setup correctly
customized?
~Is the disc severely damaged?
~On certain Blu-ray/DVD discs, sound is output from the front speakers only.
~Check if the speakers are connected properly.
~Adjust the volume.
~When playing audio from a CD, the radio, or a TV, the unit outputs sound to
the front speakers only.
~Is there "Dolby Digital 5.1 CH" marked on the disc? Dolby Digital 5.1 CH
Surround Sound is produced only if the disc is recorded with 5.1 channel
sound.
~Is the audio language correctly set to Dolby Digital 5.1-CH in the information
display?
~Are you operating the remote within its operational range and within the
proper angle relative to the sensor?
~Are the batteries drained?
~
~
~Is the TV power on?
~Are the video cables connected properly?
~Is the disc dirty or damaged?
~A poorly manufactured disc may not be playable.
~The Audio Language and subtitle functions will not work if the disc does not
contain them.
~Are you using a disc that does not contain menus?
~You can play 16:9 Blu-ray/DVD discs in 16:9 Full mode, 4:3 Letter Box
mode, or 4:3 Pan-Scan mode, but 4:3 Blu-ray/DVD discs are played in 4:3
mode only. Refer to the Blu-ray Disc jacket, and then select the appropriate
function.
~
~
~Press and hold the remote control's e () button for 5 seconds in
STANDBY mode. This will reset the unit.
-Using the RESET function will erase all stored settings.
Do not use this function unless necessary.
- English
Appendix
~With no disc in the product, press and hold the product's @ button for
longer than 5 seconds. appears on the display and all settings will return
to their default values.
-Using the RESET function will erase all stored settings.
Do not use this function unless necessary.
~Is the antenna connected properly?
~If the antenna's input signal is weak, install an external FM antenna in an
area with good reception.
~If you press the ^ button while listening to TV audio using the
D. IN or AUX functions, the Blu-ray/DVD disc functions are turned on and
the TV audio is muted.
~The features or action cannot be completed at this time because:
1. The Blu-ray/DVD disc's software restricts it.
2. The Blu-ray/DVD disc's software doesn’t support the feature (e.g., angles)
3. The feature is not available at the moment.
4. You’ve requested a title or chapter number or search time that is out of
range.
~Press and hold the @ button on front panel for more than 5 seconds with no
disc in the product. All settings will revert to their factory settings.
~Check the connection between the TV and the HDMI jack of the product.
~Check if your TV supports 480p/720p/1080i/1080p HDMI input resolution.
~If random noise appears on the screen, it means that TV does not support
HDCP (High-bandwidth Digital Content Protection).
~AllShare only shows Video, Photo, and Music files. Other types of files are
not displayed.
~Check if the network is stable.
~ Check if the network cable is properly connected and if the network is
overloaded.
~The wireless connection between the DLNA compatible device and the
product is unstable.
Check the connection.
- English
~IP addresses under the same subnetwork should be unique, otherwise IP
collision can results in such a phenomenon.
~ Check if you have a firewall enabled.
If so, disable the firewall function.
~Test whether the network connection is active by using the Network Status
function.
~ Check whether a USB memory device is connected to the product.
~The memory device must have at least 1GB of free space to accommodate
the BD-LIVE service.
You can check the available size in . (See page 49)
~See if the option is set to .
~If all above fails, contact the contents provider or update to the latest
firmware.
~The USB memory device must have at least 1GB of free space to
accommodate the BD-LIVE service.
You can check the available size in . (See page 49)
✎When the factory default settings are restored, all stored user BD data is deleted.
If you contact us to repair your product, an administration fee may be charged if either:
An engineer is called out to your home at your request and there is no defect in the product.
You bring the unit to a repair center and there is no defect in the product.
We will provide you with the amount of the administration fee before we make a home visit or begin any work
on your product.
We recommend you read this manually thoroughly, search for a solution on line at www.samsung.
com, or contact Samsung Customer Care at 1-800-SAMSUNG (726-7864) before seeking to repair your
product.
- English
Appendix
Specifications
General
Power Requirements AC 110-120V ~ 50/60Hz
Power Consumption 72.5 W
Weight 5.1 Ibs
Dimensions 16.9 (W) x 2.2 (H) x 9.9 (D) inches
Operating Temperature Range +41°F to +95°F
Operating Humidity Range 10 % to 75 %
FM Tuner
Signal/noise ratio 55 dB
Usable sensitivity 12 dB
Total harmonic distortion 0.5 %
HDMI Video 1080p, 1080i, 720p, 480p
Audio PCM multichannel audio, Bitstream audio, PCM audio
Amplifier
Front speaker output 165W x 2 (3Ω)
Center speaker output 170W (3Ω)
Surround speaker output 165W x 2 (3Ω)
Subwoofer speaker output 170W (3Ω)
Frequency response Analog input : 20Hz~20kHz (±3dB)
Digital input : 20Hz~40kHz (±4dB)
S/N Ratio 70dB
Channel separation 60dB
Input sensitivity (AUX) 500mV
Speaker (5.1ch speaker system)
Speaker
system Impedance Frequency range
Output
sound
pressure level
Rated
input
Maximum
input
Dimensions
(W x H x D) (inches)
Weights
(Ibs)
Front
3 Ω 140Hz~ 20kHz 87dB/W/M 165W 330W 3.7 x 11.0 x 4.0 3.85
Surround 3.7 x 5.9 x 4.0 1.41
Center 170W 340W 12.6 x 3.2 x 4.0 2.25
Subwoofer 40Hz ~ 160Hz 88dB/W/M 6.6 x 13.8 x 11.4 7.52
~Samsung Electronics Co., Ltd reserves the right to change the specifications without notice.
~Weight and dimensions are approximate.
~Design and specifications are subject to change without prior notice.
~Dispose unwanted electronics through an approved recycler.
To find the nearest recycling location, go to our website: www.samsung.com/recyclingdirect or call, (877)
278 - 0799
Ğ
Power Requirements AC 120V ~60Hz
Power Consumption 50 W
Weight 2.52 lbs
Dimensions (W x H x D)
inches 3.0 x 9.0 x 6.0
Operating Temperature Range +41°F to +95°F
Operating Humidity Range 10% ~ 75%
Output 165W x 2 CH
Frequency range 20Hz~20KHz
S/N Ratio 65dB
- English
Licenses
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are
trademarks of Dolby Laboratories.
For DTS patents, see http://patents.dts.com. Manufactured
under license from DTS Licensing Limited. DTS, DTS-HD,
the Symbol, DTS and the Symbol together, & DTS-HD and
the Symbol together are registered trademarks of DTS, Inc. DTS-HD Master Audio | Essential and DTS Neo:Fusion
II are trademarks of DTS, Inc. © DTS, Inc. All Rights Reserved.
The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo
are trademarks or registered trademarks of HDMI Licensing LLC in the United States
and other countries.
Oracle and Java are registered trademarks of Oracle and/or its affiliates. Other names may be
trademarks of their respective owners.
This item incorporates copy protection technology that is protected by U.S. patents and other intellectual
property rights of Rovi Corporation. Reverse engineering and disassembly are prohibited.
Blu-ray Disc™, Blu-ray™, and the logos are trademarks of Blu-ray Disc Association.
This product uses Cinavia technology to limit the use of unauthorized copies of some commercially-produced
film and videos and their soundtracks. When a prohibited use of an unauthorized copy is detected, a message
will be displayed and playback or copying will be interrupted.
More information about Cinavia technology is provided at the Cinavia Online Consumer Information Center at
http://www.cinavia.com. To request additional information about Cinavia by mail, send a postcard with your
mailing address to: Cinavia Consumer Information Center, P.O. Box 86851, San Diego, CA, 92138, USA."
This product incorporates proprietary technology under license from Verance Corporation and is protected
by U.S. Patent 7,369,677 and other U.S. and worldwide patents issued and pending as well as copyright and
trade secret protection for certain aspects of such technology. Cinavia is a trademark of Verance Corporation.
Copyright 2004-2010 Verance Corporation. All rights reserved by Verance. Reverse engineering or disassembly
is prohibited.
- Open Source License Notice
In the case of using open source software, Open Source Licenses are available on the product menu.
LIMITED WARRANTY TO ORIGINAL PURCHASER
This SAMSUNG brand product, as supplied and distributed by SAMSUNG and delivered new, in the original
carton to the original consumer purchaser, is warranted by SAMSUNG against manufacturing defects in
materials and workmanship for a limited warranty period of:
This limited warranty begins on the original date of purchase, and is valid only on products purchased and
used in the United States. To receive warranty service, the purchaser must contact SAMSUNG for problem
determination and service procedures. Warranty service can only be performed by a SAMSUNG authorized
service center. The original dated bill of sale must be presented upon request as proof of purchase to SAMSUNG
or SAMSUNG's authorized service center. Transportation of the product to and from the service center is the
responsibility of the purchaser.
SAMSUNG will repair or replace this product, at our option and at no charge as stipulated herein, with new or
reconditioned parts or products if found to be defective during the limited warranty period specified above.
All replaced parts and products become the property of SAMSUNG and must be returned to SAMSUNG.
Replacement parts and products assume the remaining original warranty, or ninety (90) days, whichever is
longer.
SAMSUNG’s obligations with respect to software products distributed by SAMSUNG under the SAMSUNG
brand name are set forth in the applicable end user license agreement. Non-SAMSUNG hardware and software
products, if provided, are on an "AS IS" basis.
Non-SAMSUNG manufacturers, suppliers, publishers, and service providers may provide their own warranties.
This limited warranty covers manufacturing defects in materials and workmanship encountered in normal, and
except to the extent otherwise expressly provided for in this statement, noncommercial use of this product, and
shall not apply to the following, including, but not limited to: damage which occurs in shipment; delivery and
installation; applications and uses for which this product was not intended; altered product or serial numbers;
cosmetic damage or exterior finish; accidents, abuse, neglect, fire, water, lightning or other acts of nature;
use of products, equipment, systems, utilities, services, parts, supplies, accessories, applications, installations,
repairs, external wiring or connectors not supplied and authorized by SAMSUNG, or which damage this product
or result in service problems; incorrect electrical line voltage, fluctuations and surges; customer adjustments and
failure to follow operating instructions, cleaning, maintenance and environmental instructions that are covered
and prescribed in the instruction book; product removal or reinstallation; reception problems and distortion
related to noise, echo, interference or other signal transmission and delivery problems. SAMSUNG does not
warrant uninterrupted or error-free operation of the product.
THERE ARE NO EXPRESS WARRANTIES OTHER THAN THOSE LISTED AND DESCRIBED ABOVE, AND NO
WARRANTIES WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTIES
OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY AFTER THE EXPRESS
WARRANTY PERIODS STATED ABOVE, AND NO OTHER EXPRESS WARRANTY OR GUARANTY GIVEN BY ANY
PERSON, FIRM OR CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON SAMSUNG.
SAMSUNG SHALL NOT BE LIABLE FOR LOSS OF REVENUE OR PROFITS, FAILURE TO REALIZE SAVINGS OR
OTHER BENEFITS, OR ANY OTHER SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES CAUSED BY THE
USE, MISUSE OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE
CLAIM IS BASED, AND EVEN IF SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR
SHALL RECOVERY OF ANY KIND AGAINST SAMSUNG BE GREATER IN AMOUNT THAN THE PURCHASE PRICE
OF THE PRODUCT SOLD BY SAMSUNG AND CAUSING THE ALLEGED DAMAGE. WITHOUT LIMITING THE
FOREGOING, PURCHASER ASSUMES ALL RISK AND LIABILITY FOR LOSS, DAMAGE OR INJURY TO PURCHASER
AND PURCHASER’S PROPERTY AND TO OTHERS AND THEIR PROPERTY ARISING OUT OF THE USE, MISUSE
OR INABILITY TO USE THIS PRODUCT SOLD BY SAMSUNG NOT CAUSED DIRECTLY BY THE NEGLIGENCE
OF SAMSUNG. THIS LIMITED WARRANTY SHALL NOT EXTEND TO ANYONE OTHER THAN THE ORIGINAL
PURCHASER OF THIS PRODUCT, IS NONTRANSFERABLE AND STATES YOUR EXCLUSIVE REMEDY.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of
incidental or consequential damages, so the above limitations or exclusions may not apply to you. This warranty
gives you specific legal rights, and you may also have other rights which vary from state to state.
To obtain warranty service, please contact SAMSUNG customer care center.
The benefits of this Limited Warranty extend only to the original purchaser of Samsung products from an
authorized Samsung reseller. THIS LIMITED WARRANTY SHALL NOT APPLY TO ANY SAMSUNG PRODUCTS
PURCHASED FROM UNAUTHORIZED RESELLERS OR RETAILERS, EXCEPT IN STATES WHERE SUCH RESTRICTION
MAY BE PROHIBITED. For a list of Samsung authorized retailers, please go to: http://www.samsung.com/us/
peaceofmind/authorized_resellers.html.
©
QUESTIONS OR COMMENTS?
IN THE US 1-800-SAMSUNG
(726-7864)
www.samsung.com/us/
support
Samsung Electronics America, Inc. 85
Challenger Road Ridgefield Park, NJ
07660
