ANDROID TABLET
User Manual
Please read this manual before operating your
device and keep it for future reference.
SM-T2105_UM_English_MI5_CH_092713_F2
Intellectual Property
All Intellectual Property, as defined below, owned by or which is otherwise the property of Samsung or its respective suppliers
relating to the SAMSUNG Galaxy Tab, including but not limited to, accessories, parts, or software relating there to (the “Galaxy Tab
System”), is proprietary to Samsung and protected under federal laws, state laws, and international treaty provisions. Intellectual
Property includes, but is not limited to, inventions (patentable or unpatentable), patents, trade secrets, copyrights, software,
computer programs, and related documentation and other works of authorship. You may not infringe or otherwise violate the
rights secured by the Intellectual Property. Moreover, you agree that you will not (and will not attempt to) modify, prepare
derivative works of, reverse engineer, decompile, disassemble, or otherwise attempt to create source code from the software. No
title to or ownership in the Intellectual Property is transferred to you. All applicable rights of the Intellectual Property shall remain
with SAMSUNG and its suppliers.
Open Source Software
Some software components of this product incorporate source code covered under GNU General Public License (GPL), GNU Lesser
General Public License (LGPL), OpenSSL License, BSD License and other open source licenses. To obtain the source code covered
under the open source licenses, please visit:
http://opensource.samsung.com
.
Disclaimer of Warranties; Exclusion of Liability
EXCEPT AS SET FORTH IN THE EXPRESS WARRANTY CONTAINED ON THE WARRANTY PAGE ENCLOSED WITH THE PRODUCT, THE
PURCHASER TAKES THE PRODUCT "AS IS", AND SAMSUNG MAKES NO EXPRESS OR IMPLIED WARRANTY OF ANY KIND
WHATSOEVER WITH RESPECT TO THE PRODUCT, INCLUDING BUT NOT LIMITED TO THE MERCHANTABILITY OF THE PRODUCT OR
ITS FITNESS FOR ANY PARTICULAR PURPOSE OR USE; THE DESIGN, CONDITION OR QUALITY OF THE PRODUCT; THE
PERFORMANCE OF THE PRODUCT; THE WORKMANSHIP OF THE PRODUCT OR THE COMPONENTS CONTAINED THEREIN; OR
COMPLIANCE OF THE PRODUCT WITH THE REQUIREMENTS OF ANY LAW, RULE, SPECIFICATION OR CONTRACT PERTAINING
THERETO. NOTHING CONTAINED IN THE INSTRUCTION MANUAL SHALL BE CONSTRUED TO CREATE AN EXPRESS OR IMPLIED
WARRANTY OF ANY KIND WHATSOEVER WITH RESPECT TO THE PRODUCT. IN ADDITION, SAMSUNG SHALL NOT BE LIABLE FOR
ANY DAMAGES OF ANY KIND RESULTING FROM THE PURCHASE OR USE OF THE PRODUCT OR ARISING FROM THE BREACH OF
THE EXPRESS WARRANTY, INCLUDING INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS OF ANTICIPATED PROFITS
OR BENEFITS.
Modification of Software
SAMSUNG IS NOT LIABLE FOR PERFORMANCE ISSUES OR INCOMPATIBILITIES CAUSED BY YOUR EDITING OF REGISTRY SETTINGS,
OR YOUR MODIFICATION OF OPERATING SYSTEM SOFTWARE.
USING CUSTOM OPERATING SYSTEM SOFTWARE MAY CAUSE YOUR DEVICE AND APPLICATIONS TO WORK IMPROPERLY. YOUR
CARRIER MAY NOT PERMIT USERS TO DOWNLOAD CERTAIN SOFTWARE, SUCH AS CUSTOM OS.
Samsung Electronics America (SEA), Inc
Address:
85 Challenger Road
Ridgefield Park,
New Jersey
07660
Toll Free
Telephone:
1-800-SAMSUNG
Internet
Address:
http://www.samsung.com
©2013 Samsung Electronics America, Inc. All rights reserved.
Do you have questions about your Samsung Mobile Device?
For 24 hour information and assistance, we offer a new FAQ/ARS System (Automated Response System) at:
www.samsung.com/us/support
Nuance®, VSuite™, T9® Text Input, XT9® Smart Input, and the Nuance logo are trademarks or registered trademarks of Nuance
Communications, Inc., or its affiliates in the United States and/or other countries.
The Bluetooth® word mark, figure mark (stylized “B Design”), and combination mark (Bluetooth word mark and “B Design”) are
registered trademarks and are wholly owned by the Bluetooth SIG.
microSDTM, microSDHCTM, and the microSD logo are Trademarks of the SD Card Association.
Google, the Google logo, Android, the Android logo, Google Play, Gmail, Google Latitude, Google Local, Google Maps, Google Play
Books, Google Play Magazines, Google Play Movies & TV, Google Play Music, Google Talk, Hangout, Picasa, and YouTube and other
marks are trademarks of Google Inc.
Wi-Fi is a registered trademark of the Wireless Fidelity Alliance, Inc.
Polaris Office and the Polaris Office logo are marks owned by Infraware and may be trademarks or registered trademarks.
DivX®, DivX Certified® and associated logos are trademarks of Rovi Corporation or its subsidiaries and are used under license.
DivX Certified® to play DivX® video up to HD 720p, including premium content.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation. This is an official DivX
Certified® device that has passed rigorous testing to verify that it plays DivX video. Visit divx.com for more information and
software tools to convert your files into DivX videos. Visit
www.divx.com
for more information and software tools to convert your
files into DivX videos.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play purchased DivX Video-on-
Demand (VOD) movies. To obtain your registration code, locate the DivX VOD section in your device setup menu. (
Apps > Settings
> About device > Legal information > License settings > DivX® VOD > Register
). Go to
vod.divx.com
for more information on how to
complete your registration.
1
Table of Contents
Section 1: Getting Started ...........................5
Understanding This User Manual . . . . . . . . . . . .5
Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Memory Card . . . . . . . . . . . . . . . . . . . . . . . . . .8
Turning Your Device On and Off . . . . . . . . . . . . .9
Initial Device Configuration . . . . . . . . . . . . . . . 10
Standard Mode Instructions . . . . . . . . . . . . . . . 11
Galaxy Tab Accessories . . . . . . . . . . . . . . . . . . 12
Securing Your Device . . . . . . . . . . . . . . . . . . .12
Section 2: Understanding Your Device .....14
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Section 3: Kids Mode ................................17
Getting Started in Kids Mode . . . . . . . . . . . . . . 17
Kids Mode Home Screen . . . . . . . . . . . . . . . . . 17
Navigating the Device . . . . . . . . . . . . . . . . . . . 18
Date and Time . . . . . . . . . . . . . . . . . . . . . . . . .19
Primary Shortcuts . . . . . . . . . . . . . . . . . . . . . .19
Accessing Kids Mode Applications . . . . . . . . . . 20
Kids Mode Applications . . . . . . . . . . . . . . . . . . 21
Create! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Dolphin Readers . . . . . . . . . . . . . . . . . . . . . . .22
Fruit Ninja . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Hair Salon 2 . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Inventions . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Inventions 2 . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Kids Camera . . . . . . . . . . . . . . . . . . . . . . . . . .23
Kids Gallery . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Kids Planet Discovery . . . . . . . . . . . . . . . . . . .24
Kids' Store . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Kids Video . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Kids World . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Ocean! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Toca Train . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
Toy story Smash It . . . . . . . . . . . . . . . . . . . . . .26
Where's My Perry? . . . . . . . . . . . . . . . . . . . . .26
Wipeout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Kids Mode Settings . . . . . . . . . . . . . . . . . . . . .27
Quick Settings . . . . . . . . . . . . . . . . . . . . . . . . .27
Volume Settings . . . . . . . . . . . . . . . . . . . . . . .28
Configure the Home screen . . . . . . . . . . . . . . .29
Edit cards . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Passwords . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
2
Parental Controls . . . . . . . . . . . . . . . . . . . . . . 31
Section 4: Standard Mode ........................ 35
Home Screen . . . . . . . . . . . . . . . . . . . . . . . . . 35
Navigating Your Device . . . . . . . . . . . . . . . . . 38
Notifications . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Status Details . . . . . . . . . . . . . . . . . . . . . . . . 40
Quick Settings . . . . . . . . . . . . . . . . . . . . . . . . 40
Status Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Primary Shortcuts . . . . . . . . . . . . . . . . . . . . . 44
Other App Shortcuts . . . . . . . . . . . . . . . . . . . . 44
Widgets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
App Shortcuts . . . . . . . . . . . . . . . . . . . . . . . . 46
Folders . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Wallpapers . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Apps Screen . . . . . . . . . . . . . . . . . . . . . . . . . 49
Entering Text . . . . . . . . . . . . . . . . . . . . . . . . . 50
Using Google Voice Typing . . . . . . . . . . . . . . . 54
Task Manager . . . . . . . . . . . . . . . . . . . . . . . . 55
Contacts and Accounts . . . . . . . . . . . . . . . . . 56
Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Favorites . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Messaging . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Types of Messages . . . . . . . . . . . . . . . . . . . . 64
Gmail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Google+ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Hangouts . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Messenger . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Internet and Social Networking . . . . . . . . . . . . 67
Using the Chrome Browser . . . . . . . . . . . . . . . 67
Google Search . . . . . . . . . . . . . . . . . . . . . . . . 67
Google+ . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Play Books . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Play Magazines . . . . . . . . . . . . . . . . . . . . . . . 70
YouTube . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Music . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Listening to Music . . . . . . . . . . . . . . . . . . . . . 71
Play Music App . . . . . . . . . . . . . . . . . . . . . . . 71
Music Player . . . . . . . . . . . . . . . . . . . . . . . . . 74
Photos and Video . . . . . . . . . . . . . . . . . . . . . . 79
Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Camcorder . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Video Player . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Gallery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
3
Wi-Fi Direct . . . . . . . . . . . . . . . . . . . . . . . . . . .95
Bluetooth . . . . . . . . . . . . . . . . . . . . . . . . . . . .96
Managing Downloads . . . . . . . . . . . . . . . . . . . 98
Kies Via Wi-Fi . . . . . . . . . . . . . . . . . . . . . . . .100
Memory Card . . . . . . . . . . . . . . . . . . . . . . . .101
Synchronizing with Windows Media Player . . 102
Connecting as a Mass Storage Device . . . . . . 102
Applications . . . . . . . . . . . . . . . . . . . . . . . . . 103
Updating Applications . . . . . . . . . . . . . . . . . . 103
Accessing Applications . . . . . . . . . . . . . . . . .104
Applications . . . . . . . . . . . . . . . . . . . . . . . . . 104
Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .104
Calculator . . . . . . . . . . . . . . . . . . . . . . . . . . .106
Calendar . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Camera . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109
Chrome . . . . . . . . . . . . . . . . . . . . . . . . . . . . .109
Contacts . . . . . . . . . . . . . . . . . . . . . . . . . . . .110
Downloads . . . . . . . . . . . . . . . . . . . . . . . . . .110
Dropbox . . . . . . . . . . . . . . . . . . . . . . . . . . . .111
Gallery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
Gmail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
Google . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .112
Google Settings . . . . . . . . . . . . . . . . . . . . . . .112
Google+ . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Hangouts . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
Kids Mode . . . . . . . . . . . . . . . . . . . . . . . . . . .113
Maps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .113
Messenger . . . . . . . . . . . . . . . . . . . . . . . . . .113
Music Player . . . . . . . . . . . . . . . . . . . . . . . . .113
My Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . .114
Play Books . . . . . . . . . . . . . . . . . . . . . . . . . . .115
Play Games . . . . . . . . . . . . . . . . . . . . . . . . . .115
Play Magazines . . . . . . . . . . . . . . . . . . . . . . .115
Play Movies & TV . . . . . . . . . . . . . . . . . . . . . .116
Play Music . . . . . . . . . . . . . . . . . . . . . . . . . . .116
Play Store . . . . . . . . . . . . . . . . . . . . . . . . . . .116
Samsung Apps . . . . . . . . . . . . . . . . . . . . . . .117
Screen Saver . . . . . . . . . . . . . . . . . . . . . . . . .117
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
Video Player . . . . . . . . . . . . . . . . . . . . . . . . . .118
Voice Search . . . . . . . . . . . . . . . . . . . . . . . . .118
YouTube . . . . . . . . . . . . . . . . . . . . . . . . . . . .118
Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . .119
Accessing Settings . . . . . . . . . . . . . . . . . . . .119
Wireless and Network . . . . . . . . . . . . . . . . . .119
Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .127
Personal . . . . . . . . . . . . . . . . . . . . . . . . . . . .134
Accounts . . . . . . . . . . . . . . . . . . . . . . . . . . . .142
4
System . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
About Device . . . . . . . . . . . . . . . . . . . . . . . . 148
Section 5: Health and Safety
Information ........................................... 149
Exposure to Radio Frequency (RF) Signals . . 149
Specific Absorption Rate (SAR) Certification
Information . . . . . . . . . . . . . . . . . . . . . . . . 154
FCC Part 15 Information to User . . . . . . . . . . 156
Smart Practices While Driving . . . . . . . . . . . 156
Battery Use and Safety . . . . . . . . . . . . . . . . . 157
Samsung Mobile Products and Recycling . . . 159
UL Certified Travel Charger . . . . . . . . . . . . . 159
Display / Touch-Screen . . . . . . . . . . . . . . . . 159
GPS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 160
Care and Maintenance . . . . . . . . . . . . . . . . . 161
Responsible Listening . . . . . . . . . . . . . . . . . 162
Operating Environment . . . . . . . . . . . . . . . . 164
Children's Access to this Mobile Device . . . . 166
FCC Notice and Cautions . . . . . . . . . . . . . . . 166
Other Important Safety Information . . . . . . . 166
Section 6: Warranty Information ............ 169
Standard Limited Warranty . . . . . . . . . . . . . . 169
End User License Agreement for Software . . 174
Index ........................................................ 182
5
Section 1: Getting Started
This section helps you to quickly start using your device.
Understanding This User Manual
The sections of this manual generally follow the features of
your device. A robust index for features begins on page 182.
Also included is important Warranty information, beginning
on page 169, that you should know before using your device.
This manual gives navigation instructions according to the
default display settings. If you select other settings,
navigation steps may be different.
Unless otherwise specified, all instructions in this manual
assume that you are starting from a Home screen. To get to a
Home screen, you may need to unlock the device. For more
information, refer to “Securing Your Device” on page 12.
Note:
Instructions in this manual are based on default settings
and may vary from your device depending on the
software version on your device and any changes to the
device’s settings.
Note:
Unless stated otherwise, instructions in this user manual
start with the device unlocked, at the Home screen.
All screen images in this manual are simulated. Actual
displays may vary depending on the software version of
your device and any changes to the device’s settings.
Special Text
In this manual, some text is set apart from the rest. This
special text is intended to point out important information,
share quick methods for activating features, define terms,
and more. The definitions for these methods are as follows:
•
Notes
: Presents alternative options for the current feature, menu,
or sub-menu.
•
Tips
: Provides quick or innovative methods or useful shortcuts.
•
Important
: Points out important information about the current
feature that could affect performance.
•
Warning
: Brings important information to your attention that can
help to prevent loss of data or functionality or damage to your
device.
Getting Started 6
Text Conventions
This manual provides condensed information about how to
use your device. To make this possible, the following text
conventions are used to represent often-used steps:
Battery
Your device is powered by a rechargeable, standard Li-Ion
battery. A Wall/USB Charger (Charging Head and USB cable)
are included with the device for charging the battery.
Warning!
Use only approved charging devices. Approved
accessories are designed to maximize battery life.
Using other accessories may invalidate your
warranty and may cause damage.
Battery Indicator
The Battery icon in the Status Bar shows the battery
power level. When battery power is 15% or less, your device
prompts you to charge the battery. If you continue to operate
the device without charging, the device powers off. For
battery use information, see “About Device” on page 148.
Tip:
Touch the Time field to display battery charge status.
Charging the Battery
Your device comes with a Wall/USB Charger (Outlet
Connector, Charging Head, and USB cable) to charge your
device from any standard AC power outlet.
Note:
The battery comes partially charged. You must fully
charge the battery before using your device for the first
time.
After the first charge, you can use the device while
charging.
➔
Arrows are used to represent the sequence of selecting
successive options in longer, or repetitive, procedures. For
example:
From a Home screen, touch
Apps
➔
Settings
➔
Display
➔
Screen timeout
.
7
1. Insert the USB cable into the Charging Head.
2. Insert the USB cable into the device’s Charger/
Accessory Port.
Warning!
While the device is charging, if the touch screen
does not function due to an unstable power supply,
unplug the USB power adapter from the power outlet
or unplug the USB cable from the device.
3. Plug the Charging Head into a standard AC power
outlet.
Note:
You cannot charge the battery using the USB cable and
your PC.
4. When charging is complete, unplug the Charging Head
from the power outlet and remove the USB cable from
the device.
Note:
If the battery is completely discharged, you cannot turn
on the device, even with the USB power adapter
connected. Allow a depleted battery to charge for a few
minutes before you try to turn on the device.
Getting Started 8
Memory Card
Your device supports removable microSD or microSDHC
memory cards with maximum capacities of 64 GB
(depending on the memory card manufacturer and type).
Memory cards are used to store music, photos, videos, and
other files.
Note:
You can only store music files that you own (from a CD
or purchased with the device) on a memory card.
Installing a Memory Card
1. Open the Memory Card Slot cover and turn to expose
the slot.
2. With the gold contacts facing down, carefully slide the
memory card into the slot, pushing gently until it clicks
into place.
3. Replace the Memory Card Slot cover.
9
Removing a Memory Card
Important!
To prevent damage to information stored on the
memory card, unmount the card before removing it
from the device.
1. From a Home screen, touch
Apps
➔
Settings
➔
Storage
.
2. Under
SD card
, touch
Unmount SD card
and then
touch
OK
.
3. Open the Memory Card Slot cover and turn to expose
the slot.
4. Gently press down on the memory card, so that it pops
out from the slot, and carefully pull the card out.
5. Replace the Memory Card Slot cover.
For more information, refer to “Memory Card” on page 101.
Turning Your Device On and Off
Turning Your Device On
Press and hold the
Power/Lock
Key
.
For more information, refer
to “Locking and Unlocking
the Device” on page 13.
Note: Note
: Your device’s internal antenna is located along the
top back of the device. Do not block the antenna; doing
so may affect signal quality and may cause the device to
operate at a higher power level than is necessary.
Getting Started 10
Turning Your Device Off
1. Press and hold the
Power/Lock
Key
.
2. At the
Device options
prompt, touch
Power off
.
3. At the
Power off
prompt, touch
OK
.
Initial Device Configuration
When you first turn on your device, you are asked to set up a
few things. To complete setup, read and follow the
instructions on the screen. You can touch
Skip
on some
screens, while others require reading or other information
(touch
Next
). Touch
Back
to re-display the information. Some
screens display depending on the options you choose.
Welcome!
1. Select a language and tap
Next
.
2. If required, touch
Accessibility
to change the
accessibility settings.
3. Tap the ON/OFF slider to activate Wi-Fi and tap
Next
.
4. If prompted, assign the
Date and time
settings and tap
Next
.
5. Understand and agree to the terms and conditions of
the EULA and tap
Next
.
6. At the Samsung account screen, select
Sign in account
,
Create new account
, or tap
Skip
.
7. Tap
Yes
at the
Got Google?
screen to login, or
No
to
continue.
8. At the
Make it Google
screen, select either
Get an
account
or
Not now
to continue.
9. Select
Google & location
services and tap
Next
.
10. Enter a
First
and
Last
name and tap
Next
.
11. At the
Dropbox
screen, select
Create account
,
Sign in
,
Disclaimer
, or tap
Skip
.
12. Tap to select
Kids mode
or
Standard mode
and tap
Finish
.
11
Standard Mode Instructions
If you selected Kids mode after initial setup, change the Kids
default password, see “Getting Started in Kids Mode” on
page 17; otherwise continue to “Understanding Your Device”
page 14 and “Standard mode” page 35.
Important!
If you selected Kids Mode, we recommend you
change the default password to protect your child's
safety. Otherwise, your child could use the default
password to access the Standard Mode features
and apps, as well as the Parental Control settings,
and could purchase applications from the Kids
Store. For more information, refer to “Changing the
Password” on page 31.
Wi-Fi
Make sure the Wi-Fi OFF / ON icon is set to ON and
choose one of the following options:
1. Touch
Add Wi-Fi network
to enter a Network SSID that
is not listed.
2. Touch
Scan
to make sure you have an accurate list of
Wi-Fi networks.
3. Touch one of the Wi-Fi networks in the list, enter the
password, and touch
Connect
. Touch and connect to
another Wi-Fi network or touch Next to continue.
4. Touch
Next
to perform this task later.
Samsung Account
Sign in to your Samsung account to use Samsung services.
1. Touch
variety of services
to learn more.
2. Touch
Create new account
to create a Samsung
account.
3. Touch
Sign in
if you already have a Samsung account.
Touch
Restore
and
Auto backup
, if desired. Touch
Next
.
4. Touch
Skip
to perform this task later.
Getting Started 12
Galaxy Tab Accessories
To find accessories for your Galaxy Tab:
1. Go to
http://www.samsung.com/us/mobile/galaxy-tab-
accessories
.
Galaxy Tab accessories display.
2. Use your model number to find compatible
accessories.
Securing Your Device
By default, the device locks automatically when the screen
times out or you can lock it manually. You can unlock the
device using one of the default Unlock screens or, for
increased security, use a personal screen unlock pattern.
For more information about creating and enabling a Screen
unlock pattern, see “Lock Screen” on page 134.
For other settings related to securing your device, see
“Location Services” on page 134.
Note:
Unless stated otherwise, instructions in this User Manual
start with the device unlocked, at the Home screen.
13
Locking and Unlocking the Device
1. Press the
Power/Lock Key
once to display the Lock
screen.
The Lock screen displays.
2. Swipe your finger across the screen in any direction to
unlock it.
The last screen accessed displays.
3. Press the
Power/Lock Key
again to lock the screen.
Note:
You can customize the Lock screen and set the type of
Screen Unlock you want to use (Face unlock, Pattern,
PIN, or Password). For more information, refer to “Lock
Screen” on page 134.
Understanding Your Device 14
Section 2: Understanding Your Device
This section outlines key features on the device on the Kids
tablet tat are easy to use and kid friendly. It also describes
the screen and the icons that display when the device is in
use.
Features
•
7.0-inch WSVGA (1024x600) TFT (PLS) LCD touch screen
•
Android Version 4.1.2
•
Wi-Fi, 1.2 GHz dual-core processor
•
Android Chrome browser
•
Bluetooth 3.0 Wireless technology. For more information, refer to
“Bluetooth”
on page 96.
•
Built-in Wi-Fi technology (802.11 a/b/g/n)
•
3 megapixel camera and camcorder, plus 1.3 megapixel
forward-facing camera for video chat
•
Full integration of Google applications (Gmail, YouTube,
Google Maps, and Voice Search)
•
Photo gallery that supports BMP, GIF, JPEG, PNG, and WBMP
formats
•
Messaging Features:
–
Gmail
–
Google Talk
(Instant Messaging and Video Chat)
•
HD Video Player (1080p)
–
Codec: H.263, H.264, and MPEG4
–
Format: MP4
•
DivX Certified
®
to play DivX
®
video up
to HD 720p
, including
premium content
•
Music playback supporting the following formats: AAC, AAC+,
AMR, AMR-NB, MP3, and WMA
•
Support for microSD and microSDHC
memory cards
•
Preloaded applications such as Samsung Apps: Alarm, Calculator,
Camera, Chrome, Contacts, Dropbox, Gallery, Music Player,
My Files, Calendar, Samsung Apps, Settings, Video Player.
Warning!
This device does not support some USB storage
media devices. For more information, refer to
“Galaxy Tab Accessories” on page 12.
15
Front View
The following items can be found on the front of your device
as illustrated.
1.
Light Sensor
: Used to control screen brightness
automatically when taking photos with the front-facing
Camera.
2.
Front-facing Camera Lens
: Used when taking photos or
recording videos.
3.
Display Screen
: The orientation of the display screen
rotates with the tablet as you turn it. You can turn this
feature on and off. For more information, refer to
“System” on page 128.
4.
Back
: Return to the previous screen or option.
5.
Home
: Display the central Home screen. Press and hold
to display recent apps that have been accessed.
6.
Menu
: Display a list of options.
7.
External Speakers
: Used in music or video playback,
notification tones, and for other sounds.
1
7
4
12
3
5
6
Understanding Your Device 16
Back View
1.
3.5mm Headset Jack
: Plug in for headphones.
2.
Front Facing Camera Lens
: Used when taking photos or
recording videos.
3.
Power/Lock Key
: Press and hold to turn the device on or
off. Press to lock the device or to wake the screen for
unlocking.
4.
Volume Key
: From a Home screen, press to adjust
Master Volume. During music playback, press
to adjust
volume.
5.
Charger/Accessory Port
: Plug in a USB cable for
charging or to sync music and files.
6.
Memory Card Slot
: Install a memory card for storage of
files.
4
1
2
3
5
6
17
Section 3: Kids Mode
This section introduces you to the Kids mode tablet and all
it’s functions.
Getting Started in Kids Mode
Kids Mode Home Screen
The Kids Mode Home screen is the starting point for using
the device in Kids mode.
Note:
Unless stated otherwise, instructions in this user manual
start with the device unlocked, at the Kids Mode Home
screen.
1.
Name
: Tap to personalize your tablet with a name and
photo.
2.
Menu icon
: Tap to display Settings and Parental
controls.
3.
Primary Shortcuts
: These are shortcuts that the
applications and features from the Kids Mode Home
screen. For more information, refer to “Primary
Shortcuts” on page 19.
4.
Apps
: Displays the Apps panel.
5.
Date and Time
: The current time and date display.
For more information, refer to “Date and Time” on
page 144.
Enter your name
Menu
Primary
Shortcuts
Apps
Date &
Time
Kids Mode 18
Navigating the Device
Use command buttons and the touch screen to navigate.
Command Buttons
Back
Touch
Back
to return to the previous screen or option.
Home
Touch
Home
to display the Kids Mode Home screen.
Menu
The menu key is not active in Kids Mode.
Screen Capture
Touch and hold the
Power/Lock Key
and
Home
to capture and save an image of the current screen.
Note:
A copy of the screenshot is automatically saved to the
clipboard. In Kids Mode a screenshot cannot be used for
any of the Kids applications.
To view the screen shots:
1. Switch to Standard mode. Touch
Menu
➔
Parental controls
.
2. Enter your password then touch
Standard home screen
.
3. From a Standard Mode Home screen, touch
Apps
➔
My Files
.
4. Touch
sdcard0
➔
Pictures
➔
Screenshots
.
5. Touch a screen capture file to display it.
19
Screen Navigation
Tap / Touch
Tap or touch items to select or launch them.
For example:
Tap / Touch a card on the Kids Mode Home screen to
open the application.
Date and Time
The current time and date displays in the upper-right portion
of the Kids Mode Home Screen but is not configurable from
this mode. You can modify the time and date from Standard
Mode in the Settings menu. For more information, refer to
“Date and Time” on page 144.
Primary Shortcuts
Primary Shortcuts are the cards that display in the middle of
the Kids Mode Home screen.
Touch and slide a card left or right to view additional cards.
Touch and Hold a card to open the application associated
with this card.
Adding Cards to the Kids Mode Home screen
1. From the Kids Mode Home screen, touch
Menu
➔
Settings
➔
Edit cards
.
2. Touch
Add card
.
3. Tap the card to add to the Home screen and then touch
the
Accept
icon.
Kids Mode 20
Removing Cards from the Kids Mode Home
Screen
1. From the Kids Mode Home screen, touch
Menu
➔
Settings
➔
Edit cards
.
2. Touch the
Remove
icon in the upper-right corner
of a card to remove the card from the Kids Mode Home
screen.
Note:
This action does not actually delete the Card, it just
removes it from the current Home screen.
Accessing Kids Mode Applications
The
Apps
screen displays all applications installed for
children on your wireless device. Applications that you
download and install from the Kids Store are also referred to
as Cards and display on both the Apps and Home screens.
1. From the Home screen, tap a preloaded App.
– or –
Touch
Apps
to display the Applications screen.
Touch
to
display
Apps
21
2. Touch the application icon to open it.
– or –
From the Home screen, touch
Apps
➔
<App icon>
.
Note:
The instructions on the following page begin access to
each App from the Apps screen, and not the Home page.
Kids Mode Applications
The following are the applications that display when you
touch
Apps
from the Kids Mode Home screen.
You can activate other Kids apps to display on the Home
screen. For more information, refer to “Application manager”
on page 34.
Create!
Filimundus Creative corner is a powerful drawing application
where kids use their own creative skills to combine
drawings, add stickers and create cutouts.
The free version contains 8 black-and-white pictures,
18 stickers and a several papers to cut.
From the Home screen, touch
Apps
➔
Create!
.
Tap
an icon
to
open
Kids Mode 22
Dolphin Readers
Dolphins are interactive books designed for different grades
of reading and are designed to make developing language
skills fun for younger learners.
Dolphin Reader display full-color illustrations and cross-
curricular content that keep your childs interest and
attention, while English introduces them to new language
points in a fun context.
There are integrated activities for every page of story text
that encourage students to practise new language skills.
From the Home screen, touch
Apps
➔
Dolphin Readers
.
Fruit Ninja
Fruit Ninja is a juicy action game with squishy, splatty and
satisfying fruit carnage! Become the ultimate bringer of
sweet, tasty destruction with every slash.
Fruit Ninja features Classic, Zen and the amazing new Arcade
mode, along with online multi-player for Game Center-
enabled devices! It also has awesome global leader boards
and achievements to unlock.
From the Home screen, touch
Apps
➔
Fruit Ninja
.
Hair Salon 2
Cut, curl, color and style – any way you want! This version
offers new characters, new tools, new accessories and even
more hairstyling fun!
From the Home screen, touch
Apps
➔
Hair Salon 2
.
23
Inventions
Help old man Pettson build challenging inventions. Figure out
which items to use and where they fit while you drag and
drop parts to their right spot and watch the invention as it’s
created.
From the Home screen, touch
Apps
➔
Inventions
.
Inventions 2
Help old man Pettson and his cat Findus build 37 different
inventions. Figure out which items to use and where they fit
while you drag and drop parts to their right spot and watch
the invention being created. As usual, there’s a secret to
unlock for those who manage to complete everything. This
app teaches logic and stimulates creativity.
From the Home screen, touch
Apps
➔
Inventions 2
.
Kids Camera
Take pictures, using the front or back camera. Apply stickers
such as a hat, bowtie, crown, sunglasses, silly faces, and
other items that make your child look like they wearing those
items in their picture.Then view your fun and creative
pictures from the Kids Gallery.
From the Home screen, touch
Apps
➔
Kids Camera
.
Kids Gallery
Your child can view the photos and videos they took from the
Kid’s Gallery.
From the Home screen, touch
Apps
➔
Kids gallery
.
Kids Mode 24
Kids Planet Discovery
This app challenges critical thinking skills through puzzles
and games that teach about different continents, music,
animals, and videos about the world and different cultures.
From the Home screen, touch
Apps
➔
Kids Planet Discovery
.
Kids' Store
Download paid or free apps and games for learning, play,
stories, and other types of apps.
Important!
During initial configuration by changing the 4-digit
PIN code, you can restrict a child or other user
(using the tablet in Kids mode) from purchasing
paid applications. To do this, change the default
PIN code.
From the Home screen, touch
Apps
➔
Kids’ Store
.
Kids Video
Your child can record a video that automatically saves to the
Kid’s Gallery.
From the Home screen, touch
Apps
➔
Kids
video
.
25
Kids World
Kids World is a Multimedia app portal that has Korean and
international characters where children are entertained and
learn through interactive play.
1. From the Home screen, touch
Apps
➔
Kids World
.
2. Touch a region,
USA
,
UK
, or
Korea
.
Important!
You can only set the region once during initial
setup. After setup you must reset the device if you
want to change the region.
3. Touch
Yes
at the prompt if this is the region you want to
use.
4. Read the Kids world Service User Agreement, touch
I
Agree
, and then touch
OK
.
5. Begin playing.
Ocean!
Match pairs of ocean animals quickly and with the least
mistakes to achieve the highest score.
From the Home screen, touch
Apps
➔
Ocean!
.
Toca Train
Your child plays the train driver in this fun and friendly train
simulator. The controls are intuitive and there are no written
instructions. Just pull the levers, push the buttons and start
exploring the island with your train!
From the Home screen, touch
Apps
➔
Toca Train
.
Kids Mode 26
Toy story Smash It
Toy Story: Smash it!” is an all-new, 3D physics-based puzzle
game featuring your favorite “Toy Story” characters. The free
version offers levels not found in the full game.
From the Home screen, touch
Apps
➔
Toy story Smash It
.
Where's My Perry?
Help Agent P get to headquarters for mission briefing by
guiding water or steam to power his secret transportation
tubes! Transform water in cool forms like ice, steam and
solids to solve all sorts of mind-bending puzzles!
From the Home screen, touch
Apps
➔
Where’s My Perry?
.
Wipeout
In this game your player has to reach the finish line in the
shortest period of time. You can control your hero using
gestures and make your hero run, jump, retreat, or bend
down. If you fail during the game, the new game starts
where you stopped. Earn reward money and spend it to
purchase costumes or other protective gear.
From the Home screen, touch
Apps
➔
Wipeout
.
27
Kids Mode Settings
This section explains Settings for customizing your device.
Accessing Kids Mode Settings
To access Settings:
From the Kids Mode Home screen, touch
Menu
➔
Settings
.
The Settings Screen
The Settings screen displays the Quick settings menu, as
well as the brightness, Lock screen, Home screen, and Edit
cards options.
Quick Settings
You can activate Wi-Fi, Bluetooth, Screen rotation, Sound,
and Power saving from the Kids’ settings screen. You can
also lock the screen, set a new wallpaper for the Home
screen, or edit cards from this menu. These features are all
referred to as Quick Settings.
1. From the Kids Home screen, touch
Menu
➔
Settings
.
The Quick Settings display.
Note:
This screen displays both Status Details and Quick
Settings and is referred to by both names in this manual.
2. Tap one of the Quick Settings to turn it on or off.
Quick
Settings
Kids Mode 28
3. The Quick Settings are:
•Wi-Fi
: Touch to enable or disable Wi-Fi. For more information,
refer to
“Wi-Fi”
on page 93.
• Bluetooth
: Touch to enable or disable Bluetooth. For more
information, refer to
“Wi-Fi”
on page 93.
• Screen rotation
: When On the screen rotates automatically
from landscape to portrait and vice versa. When Off the screen
is fixed in the current mode, either portrait or landscape. For
more information, refer to
“System”
on page 145.
• Sound
: Touch to enable or disable sound mode.
• Power saving
: When enabled, your device automatically
analyzes the screen and adjusts the brightness to conserve
battery power. For more information, refer to
“System”
on
page 145.
4. Touch the
Brightness
slider and drag it right or left to set
the brightness or touch
Auto
to allow the device to
automatically set the brightness based on available
light and battery charge status. For more information,
refer to “Brightness” on page 129.
5. Touch
Lock screen
,
Home screen
, or
Edit cards
.
For more information, refer to “Configure the Home
screen” on page 29.
6.
Edit cards
Add or remove cards from the Kids mode
Home screen. See “Adding Cards to the Kids Mode
Home screen” on page 19 or see “Removing Cards
from the Kids Mode Home Screen” on page 20.
Volume Settings
Any time you need to increase or decrease the volume while
in Kids mode:
1. Navigate to the Kids Mode Home screen.
2. Touch the
Volume
icon.
3. Slide the Volume slider left to decrease or right to
increase volume.
29
Configure the Home screen
Changing the Lock Screen Wallpaper
1. Navigate to the Kids Mode Home screen.
2. Touch
Menu
➔
Settings
.
3. Touch
Lock screen
and then touch the source of the
wallpaper (Kids gallery or Wallpapers).
4. Touch a photo or wallpaper, then touch and hold a blue
diamond in the corner and drag the blue box to crop
the area of the photo or wallpaper you want to display
on the screen.
5. Touch the
Accept
icon
when the screen is cropped
the way you want it.
This photo or wallpaper displays on the Home screen.
Changing Wallpaper on the Kids Mode Home
screen
1. Navigate to the Kids Mode Home screen.
2. Touch
Menu
➔
Settings
.
3. Touch
Home screen
then touch the
Background
tab.
4. Touch a background to select it or touch the
+
to add a
background from the Kids gallery or Kids camera
folder.
A red check mark displays on the right upper corner of
the selected background.
5. Touch the
Frames
tab, and then touch a frame that
surrounds the background (if desired).
6. Touch a photo or wallpaper, then touch and hold a blue
diamond in the corner and drag the blue box to crop
the area of the photo or wallpaper you want to display
on the screen.
7. Touch the
Accept
icon
when the screen is cropped
the way you want it.
This photo or wallpaper displays on the Lock screen.
Kids Mode 30
Inserting Frames
You can change the frames that surround the Cards
displayed on the Kids mode Home screen.
1. Navigate to the Kids Mode Home screen.
2. Touch
Menu
➔
Settings
.
3. Touch
Home screen
then touch the
Frames
tab.
4. Touch a frame to view a sample of what the cards look
like using this frame selection.
5. Press
Back
or the Home key icon until the cards
display using the newly selected frame.
Edit cards
The Edit cards option allows you to add or remove cards from
the Kids mode Home screen.
Adding and Removing Cards
1. From the Kids Mode Home screen, touch
Menu
➔
Settings
➔
Edit cards
.
2. Touch
Add card
and touch a card name to add.
3. Touch the red
X
in the upper-right corner of a card to
remove the card from the Kids Mode Home screen.
Important!
Removing a card from the Kids Mode Home screen
does not permanent delete the application from the
tablet.
Passwords
Default Password
The default password for Kids Mode is set to 0000. This
password allows you to access the Parental Controls screen,
where you can change the password for Kids Mode. You can
use the Parental Controls to keep your child safe.
Changing the default password for the Kids Mode can
prevent your child from using the default password to access
the Parental Controls settings and the features and apps in
the Standard Mode, and from purchasing paid applications.
31
Changing the Password
1. From the Kids Mode Home screen, touch
Menu
➔
Parental controls
.
2. Enter the default 4-digit password (PIN code) and then
tap
Change PIN
.
3. Enter the 4-digit password again to confirm.
4. Enter the new password.
5. Enter the new password to confirm.
Note:
Once the password is changed, you must enter this new
password to access parental controls or purchase paid
applications from the Kids Store.
Parental Controls
Parental controls allow adults to protect their children by
selecting the folders of media content you want shared with
your child, blocking menus or keys in Kids mode, and
whether new applications are automatically downloaded to
the Kids apps section. You can also restrict the amount of
time children can use the tablet, and applications they can
access.
Kids Mode 32
Settings
1. From the Kids Mode Home screen, touch
Menu
➔
Parental controls
.
2. Enter the password.
3. Tap
Settings
.
4. Tap
Kids content
, then tap the checkbox on the top
right of each type of content to allow in Kids mode.
A green checkmark displays when selected.
5. Tap the
Accept
icon to confirm your selections.
6. Tap
Block keys
to block the menu and back keys in
Kids mode.
7. Tap
Add apps to Kids mode
if you want to automatically
add all downloaded apps to the Kids mode.
Note:
If
Add apps to Kids mode
is not selected you must
manually add each app.
33
Time manager
Use the Time manager to set limits on the amount of time
your child uses the tablet. You can set limits in ten minute
increments, set a time period for use, or select No time limit
for unlimited use.
1. From the Kids Mode Home screen, touch
Menu
➔
Parental controls
.
2. Enter the password.
3. Tap
Time manager
.
4. Tap one of the following options’ radio buttons:
• Always lock
: automatically locks the Kids mode and requires
you to enter the password before use.
• Set time limits for use
: tap one space for each ten minute
increment up to 1 hour and 20 minutes of use.
• Set time period for use
: enter the starting time and ending
time use.
• No time limit
: the tablet operates without time restrictions.
Kids Mode 34
Application manager
The Application manager controls the apps that display on
the Apps screen.
When you first access this screen, the apps that display a red
check mark in the upper-right corner of the app are enabled
and display on the Apps screen.
To add additional Apps to the Kids Mode Home screen:
1. From the Kids Mode Home screen, touch
Menu
➔
Parental controls
.
2. Enter the password.
3. Tap
Application manager
.
4. Tap each app that you want to display on the
Kids mode Apps screen, then tap the
Accept
icon
to confirm your selection(s).
5. Tap an app with a check mark displayed to deselect
the app. This app will not display on the Kids mode
Apps screen until selected again.
Switching to Standard Home Screen Mode
1. From the Kids Mode Home screen, touch
Menu
➔
Parental controls
.
2. Enter the 4-digit password.
3. Tap
Standard home screen
.
35
Section 4: Standard Mode
This section outlines key features of your device and
describes the screen and the icons that appear when the
device is in use. It also shows how to navigate through the
device.
Home Screen
The Home screen is the starting point for using your device.
Note:
Unless stated otherwise, instructions in this user manual
start with the device unlocked, at the Home screen.
1.
System Bar
: The area along the bottom of the Home
screen where you can find navigation buttons and
icons that show notifications, battery power, and
connection details.
2.
Status Icons
: Indicate the status of your tablet. Touch
the Time / Status Icons area to display the Status
Details panel. For more information, refer to “Status
Bar” on page 43.
3.
Time
: The current time. For more information, refer to
“Date and Time” on page 144.
4.
Apps
: Display the Apps screen.
5.
Primary Shortcuts
: Shortcuts to common features.
These shortcuts are found on all Home screens by
default. For more information, refer to “Primary
Shortcuts” on page 44.
6.
Current screen
: Indicates which Home screen is being
displayed. For more information, refer to “Extended
Home Screen” on page 36.
Standard Mode 36
7.
Current screen
: Indicates which Home screen is being
displayed.
8.
Home screen
: The starting point for using your device.
Place shortcuts, widgets, and other items to customize
your device to your needs.
9.
Google Search
: Search the web by typing or speaking.
For more information, refer to “Google Search” on
page 67.
10.
Widgets
: Applications that run on the Home screen.
Some widgets are found on the Home screen by
default. For more information, refer to “Widgets” on
page 45.
Extended Home Screen
The Home screen consists of the Home panel plus additional
panels that extend beyond the display width to provide more
space for adding shortcuts and widgets. For more
information, refer to “Adding and Removing Home Screen
Panels” on page 37.
Slide your finger horizontally across the screen to scroll to
the left or right side panels. As you scroll, the indicator at the
top of the display shows your current position.
Note:
The center panel displays when you touch
Home
.
4
3
2
5
7
8
9
1
6
37
Customizing the Home Screens
To customize the Home screens to suit your preferences:
1. Navigate to one of the Home screen panels.
2. Touch and hold on the screen until the
Home screen
pop-up displays.
3. Touch
Set wallpaper
to change the Home screen
wallpaper. For more information, refer to “Wallpapers”
on page 48.
– or –
Under
Add to Home screen
touch:
• Apps and widgets
to add app or widget shortcuts on the
Home screen.
•Folder
to add a folder on a Home screen. For more
information, refer to
“Folders”
on page 47.
•Page
to add a Home screen.
Display Settings
You can customize display screen settings to your
preferences. For more information, refer to “Display” on
page 129.
Adding and Removing Home Screen Panels
Your device comes with seven Home screen panels. You can
customize the Home screen by removing or adding panels.
Note:
The panel in the center position displays when you touch
Home
.
From a Home screen, pinch the screen from the left
and right side to the center to display the editing
screen.
Tip:
Touch and hold on the screen until the
Home screen
pop-up displays. Under
Add to Home screen
, touch
Page
to
add a Home screen.
Use these controls to configure panels:
1.
Default Home Page
: Touch the Home icon on a panel to
set it as the default home screen.
2.
Add
: Touch to add a new panel, up to a total of seven.
This option is available when less than seven panels
have been added.
3.
Remove
: Touch and drag a panel to the Trash Can to
remove the panel from the Home screen.
Standard Mode 38
To rearrange the order of panels:
Touch and drag a panel to a new location.
To return to the Home screen:
Touch
Back
.
Navigating Your Device
Use command buttons and the touch screen to navigate.
Command Buttons
Back
Touch
Back
to return to the previous screen, option, or
step.
Home
Touch
Home
to display the center Home screen.
Touch and hold to open a list of thumbnail images of apps
you have worked with recently. Touch an App to open it.
Touch to display the Task Manager.
To launch Google Search, touch .
Touch to clear all thumbnail images.
Context-Sensitive Menus
Context-sensitive menus offer options for features or
screens. To access context-sensitive menus:
• Touch
Menu
to display a list of options.
• Touch an option in the list.
3
2
1
39
Screen Capture
Touch and hold the
Power/Lock Key
and
Home
to capture and save an image of the current screen.
Note:
A copy of the screenshot is automatically saved to the
clipboard.
To view the screen shots:
1. From a Home screen, touch
Apps
➔
My Files
.
2. Touch
storage
➔
sdcard0
➔
Pictures
➔
Screenshots
.
3. Touch a screen capture file to display it.
Application Bar
The Application Bar is the area along the top of various
application screens. It usually contains the Search and Menu
icons, as well as other icons that are used to display options
and settings.
Screen Navigation
Touch
Touch items to select or launch them. For example:
•
Touch the on-screen keyboard to enter characters or text.
•
Touch a menu item to select it.
•
Touch an application’s icon to launch the application.
Touch and Hold
Activate on-screen items. For example:
•
Touch and hold a widget on the Home screen to move it.
•
Touch and hold on a field to display a pop-up menu of options.
Swipe, Flick, or Slide
Swipe, flick, or slide your finger vertically or horizontally
across the screen. For example:
•
Unlocking the screen.
•
Scrolling the Home screens or a menu.
Pinch
Use two fingers, such as your index finger
and thumb, to make an inward pinch
motion on the screen, as if you are picking
something up, or an outward motion by
sweeping your fingers out.
Standard Mode 40
For example:
•
Pinch a photo in Gallery to zoom in.
•
Pinch a webpage to zoom in or out.
Notifications
When you receive a notification, the Notification icon displays
in the System Bar, to the left of the Time. Notifications
indicate the arrival of Gmail, alarms, and more.
Status Details
To display the current date and time, battery status, and
Wi-Fi connectivity status, open Status Details.
1. Touch the top of the screen and swipe downward.
The Status Details screen displays. If you have any
current notifications, their summaries are listed below
the Notifications title.
2. Touch a notification summary to respond to it.
3. Press
Home
,
press
Back
, or swipe up to
close the Status Details screen.
Quick Settings
To view and control the most common settings for your
tablet, as well as accessing the complete Settings
application, open the Quick Settings panel.
1. Touch the top of the screen and swipe downward.
The Quick Settings screen displays.
Note:
This screen displays both Status Details and Quick
Settings and is referred to by both names in this manual.
41
2. The Quick Settings are:
•Wi-Fi
: Touch to enable or disable Wi-Fi. For more information,
refer to
“Wi-Fi”
on page 93.
•Sound / Mute
: Touch to enable or disable sound mode.
• Screen rotation
: When On the screen rotates automatically
from landscape to portrait and vice versa. When Off the screen
is fixed in the current mode, either portrait or landscape. For
more information, refer to
“System”
on page 145.
•Bluetooth
: Touch to enable or disable Bluetooth. For more
information, refer to
“Bluetooth”
on page 96.
• Power saving
: When enabled, your device automatically
analyzes the screen and adjusts the brightness to conserve
battery power. For more information, refer to
“System”
on
page 145.
Sweep the pop-up to the left to see additional settings.
• Blocking mode
: When enabled, notifications for selected
features will be disabled.
•Sync
: Synchronizes your device with the network.
Synchronizes contacts, time, and a variety of accounts.
• Driving mode
: New notifications are read aloud when enabled.
• Airplane mode
: All wireless communications are disabled.
3. Touch
Settings
to open the Settings application.
For more information, refer to “Settings” on page 119.
4. Touch the
Brightness
slider and drag it to set the
brightness or touch
Auto
to allow the device to set
brightness automatically based on available light and
battery charge status. For more information, refer to
“Brightness” on page 129.
5.
Notifications
displays system notifications. Touch a
notification entry to display the details. Touch
Clear
to
remove Notification Icons from the System Bar.
For more information, refer to “Notifications” on
page 40.
6. Touch
Home
,
Back
, or swipe up to close
the Status Details screen.
Standard Mode 42
Notifications display in the System Bar and, in some cases,
under the Notifications heading in the Quick Settings to alert
you to activity on the tablet such as new messages,
application downloads, software updates, and more. The
following table lists those icons.
System Alert
: Check under the Notifications heading
in the Quick Settings for alerts.
Download
: An application or file is being
downloaded or has been downloaded to the device.
Download Successful
: A recent application download
or update completed successfully.
New Gmail Message
: You have new Gmail. Touch the
icon for additional information.
Hangouts Invitation
: Someone has invited you to
chat using Google Hangouts. For more information,
refer to “Hangouts” on page 66.
Music player
: Music is playing. Display the Status
Details to see the song title and music player
controls. For more information, refer to “Music
Player” on page 74.
Music App
: A song is playing in the Music app.
Touch the Music icon or touch the Status Details to
see the song title and music player controls. For
more information, refer to “Play Music App” on
page 71.
GPS Active
: Displays when GPS is active.
Software update
: There may be a software update
available for this device. For more information, refer
to “Software Update” on page 148.
Updates Available
: Updates to the applications you
have downloaded are available.
Choose input method
: When the keyboard is being
displayed, open the Quick Settings screen to display
a menu of quick keyboard settings. For more
information, refer to “Text Input Methods” on
page 50.
Wi-Fi Direct
: Displays when Wi-Fi Direct is active
and your tablet is connected to another device. For
more information, refer to “Wi-Fi Direct” on
page 95.
43
Status Bar
The Status Bar is part of the System Bar and displays icons
to show network status, battery power, and other details.
Screenshot Captured
: A screenshot has been
captured.
Nearby Devices
: The Nearby devices setting is
enabled. For more information, refer to “Nearby
Devices” on page 126.
Blocking Mode
: Notifications for selected features
are disabled. For more information, refer to
“Blocking Mode” on page 127.
Event
: This is a notification for one or more events.
For more information, refer to “Creating an Event or
Task” on page 108.
Navigation Active
: The Navigation App is active.
USB Connected
: Device is connected to a computer
using a USB cable.
Battery Level
: Shown fully charged.
Charging Indicator
: Battery is charging.
Device Power Critical
: Battery has only three percent
power remaining. At about 15 percent power
remaining, a pop-up is displayed to remind you to
charge immediately.
USB Connection Indicator
: The device is connected
to a computer using a USB cable, but it is not
charging. The battery is only charged while
connected to a computer, if the device is turned off.
When the device is off, press the Power/Lock key to
see the battery charging indicator.
Standard Mode 44
Primary Shortcuts
Primary Shortcuts display at the bottom of the Home
screens.
Tip:
The main Home screen is usually the center Home screen.
The default Primary Shortcuts are: Contacts, Calendar,
Camera, Settings, and Apps.
Other App Shortcuts
There are also other application shortcuts on the Home
screens, such as Kids mode, Alarm, Gallery, Dropbox,
Samsung Apps, and Play Store.
For more information, refer to “More Application Information”
on page 50.
Application shortcuts can be added to any Home screen. For
more information, refer to “App Shortcuts” on page 46.
Battery Fully Charged
: When the battery is fully
charged, this indicator is displayed.
Airplane Mode
: Indicates that the Airplane Mode is
active, which allows you to use many of your
device’s features, but it cannot access online
information or applications.
Bluetooth Active
: Bluetooth is turned on. For more
information, refer to “Bluetooth” on page 96.
Wi-Fi Active
: Wi-Fi is connected, active, and
communicating with a Wireless Access Point (WAP).
Alarm Set
: Displays when you set an alarm to ring at
a specified time. For more information, refer to
“Alarm” on page 104.
45
Widgets
When you first turn on your tablet, there are various widgets
on the center Home screen. They can also appear on the
Home screens to the left and right of the center Home
screen.
Widgets are self-contained applications that you can place
on the Home screens to access your favorite features.
For more information, refer to “Applications” on page 103.
Adding Widgets to a Home screen
1. Navigate to the Home screen on which you want to
place the Widget and touch
Apps
.
2. Touch the
Widgets
tab.
Note:
Swipe across the screen horizontally to view all Widgets.
3. Touch and hold the widget’s icon until the Home screen
displays, then slide your finger where you want to
place the icon and release it.
Note:
There must be room on the screen where you want to
place the widget, otherwise the widget will not add to
the Home screen.
Removing Widgets
Touch and hold the Widget until the
Remove
icon
displays, then drag the widget to the
Remove
icon.
Note:
This action does not actually delete the Widget, it just
removes it from the current Home screen.
Standard Mode 46
App Shortcuts
Use App Shortcuts for quick access to applications or
features.
1. Navigate to the Home screen on which you want to
place the App Shortcut.
2. Touch
Apps
.
– or –
Touch and hold on the screen until the
Home screen
options pop-up displays and then touch
Apps and
widgets
.
3. Touch the
Apps
tab.
4. Touch and hold the application icon until the Home
screen displays, then slide your finger where you want
to place the icon and release it.
For more information, refer to “Apps Screen” on
page 49.
5. Touch and hold the App Shortcut and then drag the
application icon to reposition it on the Home screen.
Removing App Shortcuts
Touch and hold the App Shortcut until
Remove
displays, then drag the App Shortcut to the
Remove
icon.
47
Folders
Place Folders on a Home screen to organize items together.
Adding Folders
To create a folder on a Home page:
1. Navigate to the desired Home screen.
2. Touch and hold on the screen until the
Home screen
pop-up displays and then touch
Folder
.
The Create folder pop-up displays.
3. Touch the
Unnamed folder
field, use the keyboard to
enter a name for the folder, and touch
OK
.
A new folder displays on the Home screen.
Managing Folders
To rename a folder:
Touch the folder, touch the current name, and use the
keyboard to enter a new name for the folder.
To add an App shortcut to a folder:
1. Add the App shortcut to the Home screen that the
folder is on.
2. Touch and hold the App shortcut, drag it to the folder,
and drop it.
To remove an App shortcut from a folder:
1. Touch the folder to view the contents.
2. Touch the App shortcut, drag it out of the folder, and
drop it on the Home screen.
Removing a Folder
Touch and hold the folder until the
Remove
icon
displays, then drag the folder to the
Remove
icon.
Note:
Any App shortcuts in the folder are also removed.
Standard Mode 48
Wallpapers
You can choose a picture to display on the Home Screen,
Lock screen, or on both the Home and Lock screens. Choose
from preloaded wallpaper images or select a photo you have
downloaded or taken with the Camera.
1. From a Home screen, touch and hold on the screen.
The
Home screen
options pop-up displays.
2. Touch
Set wallpaper
.
The Set wallpaper pop-up displays.
3. Touch
Home screen
,
Lock screen
, or
Home and lock
screens
.
The
Select wallpaper from
pop-up displays the
following options:
•Gallery
: Access the Gallery to select a photo. Touch a photo to
select it. Crop and resize the picture, if desired. Touch
Done
to
save the picture as wallpaper. Touch
Cancel
to cancel.
• Live wallpapers
: Choose from pre-loaded interactive animated
wallpapers. Touch a wallpaper to see an example. If available,
touch
Settings
to view options for the selection. Touch
Set
wallpaper
to save your choice. Touch
Back
to return to
the Live wallpapers menu.
• Wallpapers
: Choose from pre-loaded wallpaper images. Touch
an image to view it. Touch
Set wallpaper
to save it as
wallpaper. Touch
Back
to return to the Home screen.
Note:
Live wallpapers is not available for the Lock screen.
49
Apps Screen
The
Apps
screen displays all applications installed on your
wireless device. Applications that you download and install
from Google Play or from the web are also added to a Home
screen.
The Apps icons are arranged in a customizable grid. To
arrange the Apps icons in alphabetical order:
1. From a Home screen, touch
Apps
.
2. Touch
Menu
➔
View type
.
3. Touch
Alphabetical grid
.
To manually change the order of the icons on the Apps
screen:
1. From a Home screen, touch
Apps
.
2. Touch
Menu
➔
Edit
.
3. Touch and hold an icon and drag it to a new position.
4. Touch
Save
to save the changes.
You can place shortcuts to applications on the Home screen
for quick access to the application. For more information,
refer to “App Shortcuts” on page 46.
To view your downloaded applications:
1. From a Home screen, touch
Apps
.
2. Touch
Downloaded applications
to view
downloaded apps.
3. Touch an icon on the
Downloaded applications
screen
to launch the application.
– or –
Add an App Shortcut to a Home screen by dragging the
App icon onto the Home Screen. For more information,
refer to “App Shortcuts” on page 46.
Standard Mode 50
Application Information
To view information about an App, such as the amount of
storage it uses, force the App to stop, uninstall updates, and
clear data:
1. From a Home screen, touch
Apps
➔
Settings
➔
Application manager
.
2. Touch the
All
tab, scroll through the apps list, and
touch the app to open a screen with details about the
App.
More Application Information
For more information, refer to “Applications” on page 103.
In that section, each application that is available on the
Applications screen is listed and described. If the application
is also described in another section of this user manual, then
a cross reference to that particular section is provided.
Various widgets are also described.
Entering Text
This section describes how to select the desired text input
method when entering characters into your tablet. This
section also describes the predictive text entry system that
reduces the amount of key strokes associated with entering
text.
Your tablet comes equipped with an orientation detector that
can tell if the tablet is being held in an upright (Portrait) or
sideways (Landscape) orientation. This is useful when
entering text.
Text Input Methods
Your device offers two text input methods.
•
Google voice typing and
•
Samsung keyboard.
You can set a default text entry method in Settings. For more
information, refer to “Keyboards and Input Methods” on
page 138.
51
To choose a text input method while entering text:
1. Touch the top of the screen and swipe downward.
The Quick Settings screen displays.
Touch
Choose input method
.
The Choose input method pop-up displays.
2. Touch an input method to activate it.
For more information, refer to “Keyboards and Input
Methods” on page 138.
Using the Samsung Keyboard
The Samsung keyboard is a custom virtual QWERTY
keyboard, featuring optional predictive text or continuous
input. Input characters by touching the on-screen keys with
your finger or use speech recognition.
You can enable predictive text, to have the Samsung
keyboard match your key touches to common words and
displays them. The Personalization option learns from GMail,
Facebook, and Twitter. Log into these applications to enable
the Samsung keyboard to learn from your text input.
Keyboard Types
In addition to the default QWERTY keyboard, there is also a
Floating keyboard.
To change the keyboard type:
1. Access the QWERTY keyboard.
2. Touch and hold on the keyboard and then select
from the pop-up menu
.
3. Touch the tab at the top of the Floating keyboard to
move it.
Configuring the Samsung Keyboard
You can configure the Samsung keyboard to your
preferences. While entering text:
Touch and hold
Options
on the keyboard and then
touch
Settings
.
The Samsung keyboard settings screen displays.
For more information, refer to “Configuring the Samsung
Keyboard” on page 138.
Standard Mode 52
Entering Upper and Lower Case Letters
The default case is lower case (abc). Enter upper and lower
case alphabet letters by touching the Shift key to toggle
the case, before touching the letter key(s).
•
Touch once to switch from abc to Abc mode.
•
Touch twice to switch to ABC mode. When ABC mode is enabled,
the Shift key background turns blue.
Entering Symbols and Numbers
The number keys are displayed at the top of the keyboard
and are always available.
To enter common symbols, touch to switch to symbol
mode, then touch the corresponding key.
There are two pages of symbols. Touch to switch to the
next page.
Touch and hold a vowel key (A, E, I, O, U, or Y) or the C, N, or
S key to open a small window where you can chose an
accented vowel or other alternate letter. Slide to the letter
until it is highlighted, and release.
Touch and hold the Period key ( . ) to open a small window
with a set of common symbols.
Using Predictive Text
By using Predictive text, you can have next-letter prediction
and regional error correction, which compensates for
touching the wrong keys on the QWERTY keyboard.
Note:
Enable Predictive text in Samsung keyboard settings.
For more information, refer to “Configuring the Samsung
Keyboard” on page 138.
While entering characters, potential word matches display in
the Predictive text area above the keyboard.
Touch a word to insert it into your text.
Tip:
Touch to display more words.
Using Google Voice Typing from the Samsung
Keyboard
When you enable the Google voice typing setting, you can
use your voice to enter text instead of the keyboard.
For more information about enabling Voice input, see “Using
Google Voice Typing” on page 54.
53
Editing Text
You can edit the text you enter in text fields by cutting,
copying, or pasting text. These operations can be performed
within and across apps. However, some apps do not support
editing some or all of the text displayed while others may
offer their own way to select text.
Editing Existing Text
To edit text that you have entered:
1. Touch the text at the point you want to edit.
The
Cursor
displays at the point you touched.
2. Touch and drag the
Cursor
to a better position, if
necessary.
3. Enter additional text or delete text by repeatedly
touching the
Delete
key.
Copying, Deleting, or Replacing Text
To select and copy, delete, or replace text:
1. Touch and hold the text or word you want to select.
The selected text is highlighted with a tab at
each end of the selection.
2. Touch and drag either tab to select more or less text.
Tip:
Touch
Select all
in the Application bar to select all text in
the field. Touch on another area of the screen or touch
Done
to deselect the text.
3. Depending on the action you want to take for the
selected text, in the Application bar touch:
•Select all
to highlight all text in the field.
•Cut
to remove the selected text.
•Copy
to save the selected text to the clipboard.
•
Touch
More options
to display:
–
Paste
to paste previously copied text.
– or –
Enter text by typing or speaking to replace the
selection with what you type.
– or –
Touch the
Delete
key to delete the selected text.
Standard Mode 54
Pasting Text
To paste previously copied text:
1. Touch the text at the point you want to paste the copied
text.
The
Cursor
displays at the point you touched.
2. Touch the Cursor.
A pop-up displays.
3. Touch
Paste
in the pop-up.
To paste text directly from the clipboard:
1. Touch the
Clipboard
key to display the text saved
to the clipboard.
2. Touch a text block to paste that text where the
Cursor
is
positioned.
Closing the Keyboard
To close the keyboard:
Touch
Close Keyboard
.
Using Google Voice Typing
You can use your voice to enter text using the Google voice
typing feature.
While entering text:
1. Touch on the keyboard.
For more information, refer to “Keyboards and Input
Methods” on page 138.
2. At the
Tap to speak
prompt, touch and speak
clearly and distinctly into the microphone.
The software converts your voice to text, which is
displayed in the message.
3. Keep speaking to add more text.
4. Touch to display the Samsung keyboard.
55
Task Manager
Your device can run applications simultaneously and some
applications run in the background.
Use Task Manager to see which applications are running on
your device and to end running applications to extend battery
life. You can also uninstall applications from your device and
see how much memory is used by applications.
Task Manager Application
The Task Manager application provides information about
applications, including
Active applications
,
Downloaded
,
RAM manager
,
Storage
, and
Help
.
To access the Task Manager:
1. Add the Active apps manager widget to a Home screen
and then touch
Active applications
on the Active apps
manager widget. For more information, refer to
“Widgets” on page 45.
– or –
Press and hold the
Home
key, and then touch the
Task manager
icon.
2. Touch
Active applications
to view applications running
on your device. Touch
End
to end an application or
End all
to end all running applications.
3. Touch
Downloaded
to view applications installed from
Google Play. Touch
Uninstall
to remove an application
from your device.
4. Touch
RAM manager
to display the amount of Random
Access Memory (RAM) currently in use. Touch
Clear
memory
to clear inactive and background processes.
5. Touch
Storage
to view internal (System storage) and
external (SD card) storage memory statistics.
6. Touch
Help
to view useful tips for extending battery life.
For more information, refer to “Apps Screen” on page 49.
Standard Mode 56
Contacts and Accounts
This section explains how to manage contacts and accounts.
Accounts
Your device can synchronize with a variety of accounts. With
synchronization, information on your device is updated with
any information that changes in your accounts.
•
Samsung account
: Add your Samsung account. For more
information, refer to
“Signing In to your Samsung Account”
on page 143.
•
Dropbox
: Add your Dropbox account. For more information, refer
to
“Dropbox”
on page 111.
•
Facebook
: Add your Facebook account to sync Contacts.
•
Google
: Add your Google account to sync your Contacts, Calendar,
and Gmail. For more information, refer to
“Gmail”
on page 64.
•
Server
: Add a server to sync and access your data.
Setting Up Your Accounts
Set up and manage your synchronized accounts with the
Accounts
setting.
1. From a Home screen, touch
Apps
➔
Settings
➔
Add account
.
2. Touch the account type.
3. Follow the prompts to enter your account credentials to
complete the set-up process.
Your tablet communicates with the appropriate account
servers to set up your account. When complete, your
account displays in the
Accounts
area of the Settings
screen.
57
Contacts
Store contact information for your friends, family, and
colleagues to quickly access information or to send a
message.
To access Contacts:
From a Home screen, touch
Apps
➔
Contacts
.
Creating Contacts
1. Touch
Contacts
➔
Create
.
The Save contact to pop-up displays.
2. Touch
Device
or an account.
– or –
Touch Add new account to add a different account. For
more information, refer to “Setting Up Your Accounts”
on page 56.
3. Touch the
Contact photo to set up a photo to identify
the contact.
4. Touch contact fields to display the keyboard and enter
information:
•
Some fields have preset values. Touch the field and touch the
desired value. For example, touch the Label tab and
touch a label for the field.
•
Other fields have to be input. Touch the field and use the
on-screen keyboard to input information.
•
Touching the check box next to some fields may make
additional fields available.
•
Touch to add additional fields.Touch to remove an
unused field. Also, touch
Add another field
to add other fields.
•
Touch the screen and swipe up or down to display additional
fields or touch
Next
on the keyboard to move to the next field.
5. Touch
Back
to remove the keyboard.
6. When you finish entering information, touch
Save
.
– or –
Touch
Cancel
➔
OK
to cancel and discard
changes.
Tip:
Display a contact’s record and touch the
Address
field to
display the address on a map, or the
Website
field to link
to the website.
Standard Mode 58
Updating Contacts
To update an existing contact:
1. Touch
Contacts
.
2. Touch a contact in the Contacts list to view its
information.
3. Touch
Edit
.
4. Continue entering contact information.
Deleting Contacts
To delete a contact:
1. Touch
Contacts
.
2. Touch a contact in the
Contacts
list to view its
information.
3. Touch
Delete
.
4. At the prompt, touch
OK
.
Managing Photo IDs
To remove or update a contact’s Photo ID:
1. Touch
Contacts
.
2. Touch a contact in the
Contacts
list to view its
information.
3. Touch
Edit
.
4. Touch the Contact photo, then touch
Remove
,
,
Take picture
, or
Pictures by people
.
Contacts Display Options
There are various ways to display your Contacts and general
Contacts settings.
1. Touch
Contacts
.
2. Touch
Groups
,
Favorites
, or
Contacts
, above the
Contacts List, to view contacts various ways:
•Groups
: Displays the possible Groups, such as Not assigned,
Co-workers, Family, Friends, and so on. The number of
contacts in the group is displayed next to the group name.
Touch a group name to show only contacts in that group. For
more information, refer to
“Creating a New Group”
on
page 61.
•Favorites
: Show only your favorite, or starred, contacts. For
more information, refer to
“Favorites”
on page 63.
•Contacts
: Show all your contacts. Touch the
Search
field and
enter a keyword to list contacts that contain that keyword.
59
3. From the
Groups
,
Favorites
, or
Contacts
list, touch
Menu
to display the options for each grouping.
4. From the
Contacts
list, touch
Menu
➔
Settings
to
display and manage Contacts settings.
Linked Contacts
Your device can synchronize with multiple accounts,
including your Samsung account, Google, or the Server.
When you synchronize contacts from these accounts with
your device, you may have multiple contacts for one person.
Linking, or joining, imported contact records allows you to
see all the contact’s numbers and addresses together in one
contact entry. Linking also helps you keep your contacts
updated, because any changes that your contacts make to
their information in the respective accounts is automatically
updated the next time you synchronize with the account.
Joining Contacts
1. Touch
Contacts
.
2. Touch a contact in the
Contacts
list to view its
information.
3. Touch
Menu
➔
Join contact.
4. Touch the contact you want to Join.
The joined contact’s information is displayed with the
original contact’s information.
5. Repeat Steps 3 and 4 to join other contacts.
Separating Contacts
1. Touch
Contacts
.
2. Touch a contact in the
Contacts
list to view its
information.
3. Touch
Menu
➔
Separate contact
.
A list of Joined contacts displays.
4. Touch ➔
OK
to separate a joined contact.
The contact is removed from the list.
Standard Mode 60
Sharing Contact Information
You can send a contact’s information by way of Bluetooth to
other Bluetooth devices or in Gmail as an attachment.
Note:
Not all Bluetooth devices accept contacts and not all
devices support transfers of multiple contacts. Check
the target device’s documentation.
1. Touch
Contacts
.
2. Touch
Menu
➔
Share namecard via
.
Tip:
Set up a contact record for yourself to share your
information with others.
3. At the prompt, choose a sending method such as
Bluetooth.
4. Follow the prompts to send the contact information.
Importing and Exporting Contacts
To back up and restore your contacts information, you can
export your contacts list to a storage device, such as a PC, or
import your contacts list (previously exported) from a storage
device.
1. Use the USB cable to connect your device to the
storage device.
2. Touch
Contacts
.
3. Touch
Menu
➔
Import/Export
.
The Import/Export contacts pop-up displays.
4. Touch an option and then follow the prompts to
complete the operation.
61
Groups
Assign contacts to Groups to make searching for contacts
faster or to quickly send messages to group members.
Creating a New Group
Create a new group when you add or edit a contact.
1. Touch
Contacts
.
2. Touch
Groups
above the Contacts List.
3. Touch
Create
.
4. Touch the
Group name
field and use the keyboard to
enter a new Group name.
5. Touch
Save
to save the new group name.
Tip:
Contacts can belong to more than one group. Just touch
the contact’s
Groups
field and touch each group.
Once you create a new group, the Contacts List can be set to
display only the contacts in that group. For more information,
refer to “Contacts Display Options” on page 58.
Renaming a Group
To rename a group that you created:
1. Touch
Contacts
.
2. Touch
Groups
and then touch the group you want to
rename.
3. Touch
Menu
➔
Edit
.
4. Touch the
Group name
field and use the keyboard to
enter a new Group name.
5. Touch
Save
to save the new group name.
Deleting Groups
To delete a group that you created:
1. Touch
Contacts
.
2. Touch
Groups
and then touch any group you want to
delete.
3. Touch
Delete groups
.
The groups that can be deleted display.
4. Touch
Select all
or the name of each group to delete.
5. Touch Delete to delete the groups. Choose from
Group only or Group and group members.
Standard Mode 62
Adding Group Members
To add a contact to a group, just Edit a contact’s Group field.
For more information, refer to “Updating Contacts” on
page 58.
To add multiple contacts to a group:
1. Touch
Contacts
.
2. Touch
Groups
and then touch the group to which you
want to add members.
3. Touch
Menu
➔
Add member
.
The contacts that can be added display.
4. Touch
Select all
or the name of each contact to add.
5. Touch Done to add the contacts to the group.
Removing Group Members
To remove contacts from a group:
1. Touch
Contacts
.
2. Touch
Groups
and then touch the group from which you
want to remove members.
3. Touch
Menu
➔
Remove member
.
4. Touch
Select all
or the name of each contact to remove.
5. Touch Done to remove the contacts.
Contacts are removed from the group and the group
name is removed from each contact’s
Group
field.
63
Favorites
Mark contact records with a gold star to identify them
as favorites.
Adding Favorites
To add a contact to the Favorites list:
1. Touch
Contacts
.
2. Touch a contact to display it.
3. Touch the
Star
next to the contact name so
that it turns gold .
Tip:
You do not have to edit the contact to change the Starred
status.
Accessing Favorites
You can view your favorites two ways for fast viewing or
messaging.
To view your favorites list:
1. Touch
Contacts
.
2. Touch
Favorites
above the Contacts List.
Only your starred contacts display.
Note:
Touch
Groups
above the Contacts List and then touch
Starred in Android
to list the Favorites that are being
saved on your Google account.
Removing Favorites
To remove one or more contacts from your favorites list:
1. Touch
Contacts
.
2. Touch
Favorites
above the Contacts List.
3. Touch
Menu
➔
Remove from favorites
.
4. Touch
Select all
or the name of each contact to remove.
5. Touch Done to remove the contacts.
To remove one contact from your favorites list:
1. Touch
Contacts
.
2. Touch a contact to display it.
3. Touch the
Star
next to the contact’s name so
that it is no longer gold .
Standard Mode 64
Messaging
This section describes how to send and receive messages
and other features associated with messaging.
Types of Messages
Your device supports these types of messages:
•
Gmail Messages
•
Google Hangouts
•
Google+
•
Google Messenger
Note:
Your Wi-Fi-only device does NOT support voice calling
and messaging services. Please disregard any “dial”
and “message” related menus because some Gmail
options are identically set in all Android devices.
Gmail
Send and receive email with Gmail, Google’s web-based
email.
To access Gmail:
From a Home screen, touch
Apps
➔
Gmail
.
Setting Up Your Gmail Account
If you did not set up a Google account during the initial
configuration, the first time you launch Gmail, your device
prompts you to set up your Google account.
1. Touch
Gmail
.
The Add a Google Account screen displays.
2. Follow the prompts to sign in or create a new account.
The device communicates with the Google server to set
up your account and synchronize your email. When
complete, your Gmail displays in the Inbox.
Note:
You can use more than one Google account on your
device. To add another account, touch
Menu
➔
Settings
➔
ADD ACCOUNT
.
65
Refreshing Your Gmail Account
Refresh your account to update your device from the Gmail
servers.
1. Touch
Gmail
.
2. Touch
Menu
➔
Refresh
.
Gmail Settings
Use the Gmail Settings to configure your Gmail preferences.
1. Touch
Gmail
.
2. Touch
Menu
➔
Settings
for settings.
Tip:
Touch
Menu
➔
Help
for more information.
Composing and Sending Gmail
1. Touch
Gmail
.
2. Touch
Compose
, then touch fields to compose
the message. While composing a message, touch
Menu
for options.
3. Touch
SEND
to send this message.
– or –
Touch
Menu
➔
Save draft
to save a draft of this
message.
Google+
Google+ makes messaging and sharing with your friends a
lot easier. You can set up Circles of friends, visit the Stream
to get updates from your Circles, use Messenger for fast
messaging with everyone in your Circles, or use Instant
Upload to automatically upload videos and photos to your
own private album on Google+.
1. Sign in to your Google account. For more information,
refer to “Setting Up Your Gmail Account” on page 64.
2. From a Home screen, touch
Apps
➔
Google+
.
3. Follow the on-screen instructions to use Google+.
4. Touch
Menu
➔
Settings
to configure your
Google+ preferences.
5. Touch
Menu
➔
Help
to display additional help
information.
Standard Mode 66
Hangouts
Hangouts is Google’s instant messaging and audio and video
chat service. You can use it to communicate, in real time,
with other people who also use Hangouts on another Android
tablet or phone or on a computer.
Tip:
Hangouts requires that you have a Google account. To set
up your Google account on your device use
Accounts
settings. For more information, refer to “Accounts” on
page 142.
Open Hangouts and Sign In
1. From a Home screen, touch
Apps
➔
Hangouts
.
If you are not signed in to a Google account, the Add a
Google Account screen displays.
Note:
If you have already set up your Google account, you are
automatically logged in. Just touch the account.
Once sign in is complete, the Hangouts main screen
displays.
Messenger
With Google Messenger, you can bring groups of friends
together into a simple group conversation, putting everyone
on the same page. When you get a new conversation in
Messenger, Google+ sends an update to your device.
To get started:
1. Login to your Google account.
For more information, refer
to
“Gmail” on page 64.
2. From a Home screen, touch
Apps
➔
Messenger
.
The Messenger screen displays.
3. Touch Add to invite friends to connect.
You can invite anyone with a Google Account to
become your friend in Google Hangouts, so you can
chat with each other and view each other’s online
status.
67
Internet and Social Networking
This section describes the various Internet and social
networking applications available on your device such as
Google and Voice Search, Google+, Maps, Google Play
Books, Play Magazines, and YouTube.
Using the Chrome Browser
Use Chrome to browse the internet and bring your open tabs,
bookmarks and omnibox data from your computer to your
device.
1. From a Home screen, touch
Apps
➔
Chrome
.
2. Follow the on-screen instructions.
Google Search
Search the internet using the Google search engine.
Tip:
The Google Search widget displays by default on the main
Home screen. For information about displaying widgets on
the Home screen, see “Adding Widgets to a Home screen”
on page 45.
1. From the main Home screen, touch
.
– or –
From a Home screen, touch
Apps
➔
Google
.
Standard Mode 68
2. Use the keyboard to enter search criteria to display
matching searches.
– or –
Touch and speak the search criteria slowly and
clearly. Google searches for the information and
displays results.
Suggestions display below the text entry area.
3. Touch a suggestion to search for that term.
– or –
Touch on the keyboard to start the search.
A browser window displays the search results.
To use Voice Search directly:
1. From a Home screen, touch
Apps
➔
Voice Search
.
2. Speak the search criteria slowly and clearly. Google
searches for the information and displays results or
displays
Retry
. Touch the to retry speaking the
search words.
Google+
Share updates and see what is going on around you with
Google+ for mobile.
To get started:
1. From a Home screen, touch
Apps
➔
Google+
.
2. For more information, refer to “Google+” on page 65.
Maps
Use Google Maps to find your current location, get directions,
and other location-based information.
Note:
You must enable location services to use Maps. Some
features require Standalone or Google location services.
For more information, refer to “Location Services” on
page 134.
From a Home screen, touch
Apps
➔
Maps
.
69
Navigating the Map
Zooming
•
Double-tap on the screen to zoom in.
•
Use two fingers, such as your index finger and
thumb, to zoom out by making an inward pinch
motion on the screen. To zoom in, make an
outward motion by sweeping your fingers out.
Tip:
Rotate the device to landscape mode for convenient
browsing.
Scrolling
•
Touch and drag on the screen to reposition the map in the display.
Touch
•
Touch an icon on the map to display information about the
location. For example, your location is indicated by a flashing
icon.
Play Books
Use the Play Books app to read eBooks from the Internet-
based Google Play Books service. Google eBooks is a new
way to discover, buy, and enjoy your favorite books online
and offline.
From a Home screen, touch
Apps
➔
Play Books
.
The Google Play Books main screen displays.
Note:
You may be asked to create or sign on to your Google
account. For more information, refer to “Setting Up Your
Gmail Account” on page 64.
Play Books Menu
From the Play Books main screen:
Touch
Menu
for options.
To configure Play Books settings:
Touch
Menu
➔
Settings
.
Follow the on-screen instructions.
For more information touch
Menu
➔
Help
.
Standard Mode 70
Play Magazines
Google Play Magazines helps you subscribe to your favorite
magazines so you can have them available to read on your
tablet at your leisure.
Play Magazines requires that you log on to your Google
account. For more information, refer to “Accounts” on
page 142.
From a Home screen, touch
Apps
➔
Play Magazines
.
The Play Magazines Welcome screen displays.
Play Magazines Menu
From the Play Magazines main screen:
Touch
Menu
for options.
To configure Play Magazines settings:
Touch
Menu
➔
Settings
.
Follow the on-screen instructions.
For more information touch
Menu
➔
Help
.
YouTube
View and upload YouTube videos right from your device.
From a Home screen, touch
Apps
➔
YouTube
.
Note:
After initial access to YouTube the icon displays as .
To find a YouTube video.
Touch
Search
and use the keyboard to enter a
keyword or phrase. Touch on the keyboard to
initiate the search.
YouTube Menu
From the YouTube main screen:
Touch
Menu
for options.
To configure YouTube settings:
Touch
Menu
➔
Settings
.
Follow the on-screen instructions.
For more information touch
Menu
➔
Help
.
71
Music
This section explains how to use the music features of your
device including the Music app, the Music Player, and the
Music Hub.
Listening to Music
You can listen to music by using your device’s built-in
speakers, through a wired headset, or through a wireless
Bluetooth stereo headset.
For more information, refer to “Bluetooth” on page 96.
Press the
Volume Key
on the side of the device to activate on-
screen volume control, then touch and drag on the scale to
set volume. You can also press the Volume Key to adjust
playback volume.
Play Music App
The Play Music app contains a music player that plays
music
and other audio files that you copy from your computer or store
online.
Note:
Some options described in this manual may not be
available until you sign in to your Google account.
Google Play Music
Google Play Music is a new service from Google that gives
you instant access to your personal music collection on the
Internet and your compatible Android devices without the
hassle of wires or syncing. For more information, visit
music.google.com
.
Accessing the Music App
1. From a Home screen, touch
Apps
➔
Play Music
.
2. Follow the prompts to set up the application.
The Play Music app searches your online library and
your device’s internal storage for music and playlists.
This can take from a few seconds to several minutes,
depending on the amount of new music added since
you last opened the application.
The screen displays Listen Now, My Library, Playlists,
Instant Mixes, and Shop.
Standard Mode 72
Changing Library View
You can change the way you view the contents of your
library.
1. Touch
Play Music
.
2. Touch an option to set how you view your library.
The choices are:
GENRES
,
ARTISTS
,
ALBUMS
, or
SONGS
.
Play Music Menu
While viewing a Play Music main screen:
Touch
Menu
and follow the on-screen instructions
to use the following options:
•Refresh
: Refreshes the screen.
•Settings
: Configure Play Music settings.
•Help
: Get more information about the Play Music app.
Play Music Options
Options are available for playing songs, albums, or playlists:
1. Touch
Play Music
.
2. Touch an album or song.
3. Touch
Menu
to display options:
Options display depending on the item view.
To play a song:
1. Touch
Play Music
.
2. Touch
Menu
and select
All music
or
On device
.
3. Touch a song in your library to listen to it.
73
Shopping for Music at the Play Store
To visit the Google Play Store where you can find and buy
music:
1. From a Home screen, touch
Apps
➔
Play Store
.
2. Touch
Music
.
The Google Play Store music section displays.
To view information about finding and buying music:
1. Touch
Play Music
.
2. Touch
Menu
➔
Help
.
The Google Play Music help screen displays.
Making Online Music Available Offline
In addition to playing the music that you add to your online
library, you can play music stored on your device’s internal
storage. Then you can listen to music when you have no
Internet connection. To do this, make some of your online
music available offline.
Tip:
You can also copy music directly from your computer to
your device. For more information, refer to “Synchronizing
with Windows Media Player” on page 102.
To make your online music available offline on your device:
1. Touch
Play Music
.
2. If you have signed in to your Google account, touch
Menu
➔
On device
and touch the album or playlist
you want to make available offline.
3. Touch
Menu
➔
Help
to view information about
listening to music offline.
Standard Mode 74
Music Player
Music Player plays songs stored on your tablet or an installed
memory card.
To access Music Player:
1. From a Home screen, touch
Apps
➔
Music Player
.
The Music Player application searches your device’s
internal storage or on an installed memory card for
music and playlists. This can take from a few seconds
to several minutes, depending on the amount of new
music added since you last opened the application. It
then displays your music in several ways.
2. Touch a tab, such as
Songs
,
Playlists
,
Albums
, and so
on, to change the way you view the contents of your
library.
3. Touch the Music application icon at the top-left of
the Application bar to return to the previous Music
screen.
Searching for Music
To find music in your library:
1. Touch
Music Player
.
2. Touch
Search
and use the keyboard to type the
name of an artist, album, or song.
Music Player Options and Settings
To use Music Player options and configure settings:
1. Touch
Music Player
.
2. Touch
Menu
to display the following options:
• Delete
: Delete a song, an album, or every song or album.
• Set as alarm tone
: Choose a song and touch
Set
to use the
song as an alarm tone.
• Scan for nearby devices
: Discover and connect directly to
nearby devices.
75
• Settings
: The following settings display:
Advanced
–
SoundAlive
: View and set SoundAlive options.
–
Play speed
: Decrease or increase play speed.
–
Lyrics
: Display the lyrics of the song, if available.
–
Music auto off
: Set the option Off or set your music to turn off
automatically by touching one of the time values.
Music menu
–
Music menu
: Enable or disable the music display options that
appear on the main music screen. A check mark
next to
an option means that it is enabled.
•End
: Close the Music Player app.
Managing Playlists
To create, manage, or delete a playlist:
Touch
Music Player
.
Creating a Playlist
Touch
Add to playlist
➔
Create playlist
and use the
keyboard to enter a name for the playlist.
Renaming a Playlist
1. Touch the
Playlists
tab.
2. Touch a playlist, touch
Menu
➔
Rename playlist
and use the keyboard to enter a new name for the
playlist.
Adding Songs to or Removing Songs from Playlists
1. Touch
Add to playlist
and touch a playlist.
– or –
Touch
Playlists
, touch a playlist, and then touch
Add music
(landscape mode) or
Menu
➔
Add music
(portrait mode).
All songs are displayed.
2. Touch
next to each song you want to add or next
to
Add all
to add all songs to the playlist.
– or –
Touch
to remove a song from the playlist.
3. Touch
Done
to save the playlist.
Standard Mode 76
Changing the Order of a Playlist
1. Touch the
Playlists
tab and touch a playlist.
2. Touch
Change order
(landscape mode) or
Menu
➔
Change order
(portrait mode).
3. Touch the grid for an entry and drag the entry to a
new position in the list.
4. Touch
Done
to change the order and save the playlist.
Playing a Playlist
1. Touch the
Playlists
tab.
2. Touch
Favorites
,
Most played
, or
Recently added
, or
touch a playlist title that you created.
3. Touch a song to start playing the playlist at that song.
Deleting a Playlist
1. Touch the
Playlists
tab and touch a playlist.
2. Touch
Remove
in the Application bar.
3. Touch the box next to a playlist title, touch
Remove
, and then touch
OK
.
Playing Music
To play a song:
1. Touch
Music Player
.
2. Touch a song or touch an album or genre and then
touch a song in the list of songs on the album.
The song you touch starts to play. The tracks in the
current list play in order until you reach the end of the
list (unless you choose a repeat option). Otherwise,
playback stops only if you stop it, even when you
switch applications.
Accessing the Music Player
If you navigate away from the Music Player application and
music is playing, the Music notification icon is displayed
in the System Bar.
You can change songs or easily return to the Music Player:
1. Touch the top of the screen and swipe downward.
The Status Details screen displays.
2. Touch the song thumbnail to display the Music Player.
You can also pause and resume playback and skip to
the next or previous song in the panel. For more
information, refer to “Notifications” on page 40.
77
Music Player Controls
When a song is playing, the Music Player screen displays
and
various controls are available.
1. Touch
Music Player
.
2. Touch a song or playlist to begin playback.
The music player displays below (portrait mode) or to
the right (landscape mode) of the music listing.
3. Touch the song thumbnail to enlarge the music player.
Music Player Screen
During playback, use the sound and playlist controls:
1.
Volume
: Touch to toggle Silent and Sound mode, then
touch and drag on the scale to set volume. You can
also press the Volume Key on the side of the device to
adjust playback volume.
2.
Info
: Touch to view information about the current song.
3.
List
Mode
: Touch to switch to the list of songs.
4.
SoundAlive
: Touch to view and set SoundAlive options.
5.
Repeat
: Touch to repeat the current song, repeat all
songs, or disable repeat mode.
6.
Time Indicators
: Indicates elapsed time and total song
length in minutes and seconds.
7.
Playback Controls
: These buttons control the playback
of songs:
•
Touch to advance to the next song. Touch and hold
to scan forward through the current song.
•
Touch to go back to the previous song. Touch and hold
to scan backward through the current song.
•
Touch to pause playback. Touch to resume
playback.
Standard Mode 78
8.
Shuffle
: When enabled, songs play in random order.
When disabled, songs play in the order they appear in
List view.
9.
Progress Bar
: Touch and drag the end of the progress
bar to scan forward or backward through the current
song.
10.
Song Title
/
Artist
/
Album
: Identifies the song, artist,
and album.
11.
Favorite
: Touch the star to mark the current song
as a favorite.
Options While Playing a Song
There are various options and controls available while a song
is playing:
1. Touch
Music Player
, touch a song or an album,
and then a song.
2. Touch the music player to enlarge it.
9
8
76
5
4
3
12
11
10
79
3. Touch
Menu
to display the following options:
• Add to playlist
: Add the song to a new playlist or an existing
playlist.
• Via Bluetooth
: Play the current song by using a Bluetooth
device.
• Set as alarm tone
: Use the current song as an alarm tone.
• Scan for nearby devices
: Discover and connect directly to
nearby devices.
• Settings
: Displays Music Player settings. For more information,
refer to
“Music Player Options and Settings”
on
page 74.
•End
: This option returns you to the home screen.
Photos and Video
This section explains how to use your device’s built-in
camera and camcorder, the Video Player app to view and
manage videos, and the Gallery app to view, capture, and
manage photos and videos. It also contains an overview of
the Video Player and Gallery apps.
Camera
Use your device’s built-in camera and camcorder to take
photos and record videos.
To access the Camera:
1. From a Home screen, touch
Apps
➔
Camera
.
If a memory card is inserted, the Storage location
pop-up displays.
2. Touch
OK
to change the storage location to memory
card.
– or –
Touch
Cancel
to use the device storage for storing
pictures and videos.
Note:
If memory card storage is used, photos are stored in the
/storage/extSdcard0/DCIM/Camera folder as jpg files.
For more information, refer to “My Files” on page 114.
The Camera screen displays.
Standard Mode 80
Camera Screen
The following items can be found on the Camera screen as
illustrated:
1. Settings Shortcuts
2. GPS Active (displays when connected to the computer)
3. Storage Indicator
4. Mode
5. Camera Button
6. Image Viewer
7. Settings
Taking Photos
To take a photo:
1. Touch
Camera
.
2. Using the display as a viewfinder, compose your photo
by aiming the lens at the subject.
To configure settings, see “Camera Settings” on
page 81.
3. To take the photo, touch the
Camera
button.
4. Touch
Back
to leave the Camera and display the
previous screen.
Important!
Do not take photos of people without their
permission.
Do not take photos in places where cameras are
not allowed.
Do not take photos in places where you may
interfere with another person’s privacy.
7
1
6
5
4
23
81
Camera Settings
Before you start taking photos, use the camera settings to
configure the camera for best results. Camera settings are
represented by icons on the left side of the screen.
Editing Camera Settings Shortcuts
The first five icons are actually shortcuts to camera settings.
These five shortcuts can be customized to fit your
preference.
Self-portrait
,
Shooting mode
,
Timer
Effects
, and
Brightness
are default settings
shortcuts.
To customize these shortcuts:
1. Touch
Settings
➔
Edit shortcuts
.
– or –
Touch and hold any of the shortcut icons to edit them.
2. Touch and hold a setting, then drag and drop it on one
of the five settings shortcuts to the left. The replaced
setting shortcut displays in the edit list.
Configuring Camera Settings
To configure Camera settings:
While in Camera mode, touch a settings shortcut or
touch
Settings
to configure the following camera
settings:
• Edit shortcuts
: Customize your settings shortcuts. For more
information, refer to
“Editing Camera Settings
Shortcuts”
on page 81.
•Self-portrait
: Touch to switch to the front-facing camera lens
and take a photo of yourself.
Warning!
If the battery is low, the flash is not available. For
more information, refer to “Charging the Battery” on
page 6.
• Shooting mode
: Choose an automatic shooting mode, from:
–
Single shot
: Take a single photo.
–
Panorama
: Touch the Camera button to take a photo, then use
the on-screen guideline to move the viewfinder and take the
next 7 shots automatically.
–
Share shot
: Share photos with other users via Wi-Fi Direct. A
Wi-Fi Direct connection is required.
Standard Mode 82
–
Smile shot
: Touch the Camera button to automatically focus on
the subject’s face and take the photo.
• Effects
: Apply an effect to photos.
•Scene mode
: Choose a mode to match the kind of pictures
you want to take.
•Brightness
: Use the slider to set the brightness value.
•Timer
: Set a delay time to wait between touching the Camera
button and taking a photo.
•Resolution
: Choose a size for the photo.
• White balance
: Set the light source.
• Metering
: Select a method for measuring light.
• Guidelines
: Enable or disable an on-screen grid to aid in photo
composition.
• Image quality
: Choose a quality setting for photos.
•Storage
: Set whether to store your photos on your device or on
your memory card, if one is installed.
• Reset
: Set all Camera settings to the defaults.
Camcorder
Use your device’s built-in Camcorder to record high-
definition video in 1080p resolution.
1. Touch
Camera
.
2. Slide the
Mode
button to the
Camcorder
setting.
The Camcorder screen displays.
83
Camcorder Screen
The following items can be found on the Camcorder screen
as illustrated:
1. Settings Shortcuts
2. GPS Active (displays when connected to the computer)
3. Storage Indicator
4. Camcorder mode
5. Record Button
6. Image Viewer
7. Settings
Recording Videos
1. Touch
Camera
.
2. Slide the
Mode
button to the
Camcorder
setting.
3. Using the display as a viewfinder, compose your shot
by aiming the lens at the subject.
To configure settings, see “Camcorder Settings” on
page 84.
4. To start recording, touch
Record
.
During recording, the
Recording Indicator
flashes.
5. To pause recording, touch
Pause.
6. To stop recording, touch
Stop
.
7. Touch
Back
to leave the Camcorder and display
the previous screen.
Important!
Do not take videos of people without their
permission.
Do not take videos in places where cameras are
not allowed.
Do not take videos in places where you may
interfere with another person’s privacy.
7
1
6
5
4
23
Standard Mode 84
Camcorder Settings
Before you start taking videos, use the camcorder settings to
configure the camcorder for best results. Camcorder settings
are represented by icons on the left side of the screen.
Editing Camcorder Settings Shortcuts
As with the camera, the first five icons are actually shortcuts
to camcorder settings. These five shortcuts can be
customized to fit your preference.
Self-recording
,
Recording mode
,
Timer
Effects
, and
Brightness
are default settings
shortcuts.
To customize these shortcuts, see “Editing Camera Settings
Shortcuts” on page 81.
Configuring Camcorder Settings
To configure Camcorder settings:
While in Camcorder mode, touch a settings shortcut or
touch
Settings
to configure the following
Camcorder settings:
• Edit shortcuts
: Customize your settings shortcuts. For more
information, refer to
“Editing Camera Settings
Shortcuts”
on page 81.
• Self-recording
: Touch to switch to the front-facing camera
lens and record a video of yourself.
• Recording mode
: Set a recording mode. Options are:
Normal and Limit for email, which limits the size of the video to
50 megabytes.
• Effects
: Apply an effect to videos.
•Brightness
: Use the slider to set the brightness value.
•Timer
: Set a delay to wait between touching Record and
starting recording.
•Resolution
: Set a size for the video.
• White balance
: Set the light source.
• Guidelines
: Enable or disable an on-screen grid to aid in video
composition.
• Video quality
: Choose a quality setting for videos.
•Storage
: Set whether to store your videos on your device or on
your memory card.
• Reset
: Set all Camera settings to the defaults.
85
Using the Image Viewer
After taking a photo or recording a video, use the Image
Viewer to view or play, share, delete, or edit your photos and
videos.
1. Touch
Image Viewer
to view the photo and videos.
2. Touch the screen to show or hide Image Viewer
options.
3. For photos, touch the screen with two fingers or
double-tap on the screen to zoom all the way in or out.
For more information, refer to “Pinch” on page 39.
4. Sweep across the screen to display the next or
previous photo or video. (Videos are indicated by the
Play
button.)
Tip:
The current photo or video is outlined in the thumbnails at
the bottom of the screen. Touch a thumbnail to view the
photo or video it represents.
5. To set the photo or video as a favorite, touch
Favorites
.
6. Touch
Share
to share the photo or video. Touch an
option, such as Bluetooth, and follow the on-screen
instructions. After using this option, the most recent
Share option is displayed in the Application Bar.
7. Touch
Slideshow
to display a slide show of the
available pictures and videos.
8. To delete the photo or the video being displayed, touch
Delete
.
9. Touch
Menu
to select
Set as
to assign a photo as a
Contact photo or a Home screen, Lock screen, or Home
and lock screens wallpaper.
For more information, refer to “Viewing Photos and
Videos” on page 90.
Note:
Photos and videos are stored in the /storage/sdcard0/
DCIM/Camera folder as jpg and mp4 files. For more
information, refer to “My Files” on page 114.
Standard Mode 86
10. To play a video, touch
Play
. Touch
Pause
to
pause the video and touch
Resume
to resume
playing the video.
Touch the icon ( , , or ) in the lower left
corner of the display screen while the video is playing
to change the Display Mode from original size to full
screen in ratio or full screen.
Touch and drag the white dot on the progress
bar to fast forward or rewind the video. Touch the left
end of the progress bar to restart the video. Touch the
right end of the progress bar to end the video playback.
– or –
Touch
Rewind
to restart the video or
Fast Forward
to end the video.
11. Touch
Pop up play
to play a video as a small
pop-up while viewing another screen. Touch and drag
the pop-up video to the desired location on the screen.
Double-tap the pop-up to return to full screen mode.
12. While the video is playing, touch
Bookmark
to
mark your favorite areas of the video. A yellow mark
displays on the progress bar.
13. Touch
Back
to return to the Camera or Camcorder
screen.
87
Video Player
Use Video Player to view and manage videos stored on your
tablet.
1. From a Home screen, touch
Apps
➔
Video Player
.
2. Touch the
Thumbnails
,
List
, or
Folders
tab.
3. Touch
Search
and use the keyboard to enter a
search term. The current folder is searched and results
are displayed. Touch
X
to clear the search field.
4. While viewing the list, touch
Menu
for options:
•List by
: Display videos by Name (default), Date, Size, or Type.
•Share via
: Share the video. Touch an option, such as
Bluetooth, and follow the on-screen instructions.
•Delete
: Touch videos to select them for deletion or touch
Select all
to delete all videos.
• Auto play next
: Touch to enable or disable automatic playing of
videos in the order they appear.
• Scan for nearby devices
: Discover and connect directly to
nearby devices.
5. Touch a video to play it. While playing a video, touch
the screen to display or hide on-screen playback
controls.
6. Touch the icon ( , , or ) in the lower left
corner of the display screen while the video is playing
to change the Display Mode from original size to full
screen in ratio or full screen.
7. Touch
Pop up play
to play a video as a small
pop-up while viewing another screen. Touch and drag
the pop-up video to the desired location on the screen.
Double-tap the pop-up to return to full screen mode.
8. While the video is playing, touch
Bookmark
to
mark your favorite areas of the video. A yellow mark
displays on the progress bar.
Standard Mode 88
9. During playback, touch
Menu
for options:
•Share via
: Share the video. Touch an option, such as
Bluetooth, and follow the on-screen instructions.
•Trim
: Use the sliders at the bottom of the screen to trim the
video.
• Via Bluetooth
: Turn Bluetooth on to use Bluetooth services.
• Video auto off
: Set the option Off or set your video to turn off
automatically by touching one of the time values.
• Scan for nearby devices
: Discover and connect directly to
nearby devices.
•Settings
: Touch this option to view the following:
–
Play speed
: Touch and drag the slider to decrease or increase
play speed.
–
Subtitles
: View subtitles for the video, if available.
–
Auto play next
: Enable or disable auto play of the next video.
–
Capture
: Captures a frame of the video and saves it as a photo.
•Details
: Provides details about the video, such as Name, Size,
Resolution, and so on.
For more information, refer to “Playing Videos” on page 92.
Gallery
Use Gallery to view, capture, and manage photos and videos.
Note:
Photos and videos are stored in the /storage/sdcard0/
DCIM/Camera folder, photos as jpg files and videos as
mp4 files. For more information, refer to “My Files” on
page 114.
To access Gallery:
From a Home screen, touch
Apps
➔
Gallery
.
Selecting Photos and Videos to View
1. Touch
Gallery
.
All albums display.
2. Choose items to display by making selections from the
menus in the Application bar:
Albums
,
Time
,
Person
,
Group
, and
Favorites
.
3. To launch the Camera app, touch
Camera
.
4. Touch the icon next to Camera to change the way your
albums are displayed (
Grid
,
Timeline
, or
Spiral
).
89
5. Touch
Menu
to display the following options:
•Slideshow
: View a slideshow of the available pictures and
videos.
•New album
: Create a new album. Use the keyboard to enter a
name for the album.
•Hidden Items
: Touch this icon to show items that have been
hidden.
•View by
: View content from all sources or set a single source,
such as in your device.
• Select album:
Touch one or more albums or groups that you
want to share, share, or delete.
• Scan for nearby devices
: Discover and connect directly to
nearby devices.
• Settings
: Set your account sync settings.
Viewing Groups of Photos and Videos
1. Touch
Gallery
.
2. Touch a category and then a group to view it.
Thumbnails for each photo and video in the group
display.
3. To launch the Camera app, touch
Camera
.
4. Touch
Slideshow
to view a slideshow of the
available pictures and videos.
5. Touch
New album
to create a new album. Use the
keyboard to enter a name for the album.
6. Touch
Menu
for these options:
• Select item:
Touch one or more items that you want to share,
delete, or use for a slideshow.
• Hidden items
: View hidden photos or videos.
Standard Mode 90
Viewing Photos and Videos
1. Touch
Gallery
.
2. Touch a category and then a group to view it, and then
touch a photo or video thumbnail.
3. Touch the screen to show or hide Gallery options.
4. Sweep across the screen to display the next or
previous photo or video. (Videos are indicated by the
Play
button.)
Tip:
The current photo or video is outlined in the thumbnails at
the bottom of the screen. Touch a thumbnail to view the
photo or video it represents.
5. Touch to assign this photo or video as a Favorite.
6. Touch
Share via
to share the photo or video. Touch
an option, such as Bluetooth, and follow the on-screen
instructions.
7. Touch the to choose from Start slideshow and
Slideshow settings.
8. To delete the photo or video being displayed, touch
Delete
.
9. Touch
Menu
to display the following options for
photos:
• Face tag
: Set whether to look for a face in this picture.
•Copy to clipboard
: Copy the current photo to the clipboard.
•Rotate left
: Allows you to rotate the photo counterclockwise
90 degrees.
•Rotate right
: Allows you to rotate the photo clockwise
90 degrees.
•Crop
: Allows you to crop the image. Touch and drag the crop
box or the sides or corners of the crop box to create the crop
area, then touch
Done
. Touch
X
to stop without cropping the
photo.
•Edit
: Use Photo Editor or Paper Artist to edit your photo.
•Set as
: Assign the photo as a Contact photo or a Home screen,
Lock screen, or Home and lock screens wallpaper.
•Print
: Print the current photo to a Samsung printer.
•Rename
: Enter an new file name.
• Scan for nearby devices
: Discover and connect directly to
nearby devices.
•Details
: Provides details about the photo, such as title, time
taken, size, and so on.
91
The options for videos that are not playing are:
•Rename
: Enter an new file name.
• Scan for nearby devices
: Discover and connect directly to
nearby devices.
•Details
: Provides details about the video such as Title, Time,
Duration, and so on.
For menu options while a video is playing and other
video options, see “Video Player” on page 87.
10. Touch
Back
to return to the category screen.
Setting a Picture As
You can use the photos you take as a contact’s photo or as
wallpaper for the Home or Lock screen:
1. Touch
Gallery
.
2. Touch a category and then a group to view it, and then
touch a photo to select it.
3. Touch
Menu
➔
Set as
.
4. Touch
Contact photo
and then touch a contact entry.
– or –
Touch
Home screen
,
Lock screen,
or
Home and lock
screen
.
A crop photo screen displays.
5. Touch and drag the crop box or the sides or corners of
the crop box to create the crop area, then touch
Done
to save the cropped photo as the contact’s icon or
wallpaper. Touch
Cancel
to stop without cropping the
photo.
Tip:
To remove a contact photo, see “Updating Contacts” on
page 58.
To change wallpaper, see “Wallpapers” on page 48.
Standard Mode 92
Playing Videos
1. Touch
Gallery
.
2. Touch a category and then a group to view it, and then
touch a video thumbnail to play the video.
Note:
Videos are marked with a
Play
button.
3. Touch
Pause
to pause the video.
4. To resume playing the video, touch
Resume
.
5. To fast forward or rewind the video, touch and drag the
white dot on the progress bar. To restart the
video, touch the left end of the progress bar. To end the
video playback, touch the right end of the progress bar.
– or –
To restart the video, touch
Rewind
or to end the
video touch
Fast Forward
.
For more information, refer to “Video Player” on
page 87.
Sharing Photos and Videos
Share photos and videos with your friends.
1. Touch
Gallery
.
2. Touch a category and then a group to display
thumbnails.
3. Touch
Menu
➔
Select item
.
4. Touch one or more photos and videos to highlight them
for sharing.
5. Touch
Share via
.
6. Touch an option, such as Gmail, and follow the
on-screen instructions.
93
Connections
Your device includes features to connect to the internet and
to other devices by using Wi-Fi, Bluetooth, or a USB cable.
Wi-Fi
Wi-Fi is a wireless networking technology that provides
access to local area networks. Use your device’s Wi-Fi
feature to:
•
Access the internet for browsing or to send and receive email.
•
Access your corporate network.
•
Use hotspots provided by hotels or airports while traveling.
Wi-Fi communication requires access to an existing Wireless
Access Point (WAP). WAPs can be Open (unsecured, as with
most hotspots) or Secured (requiring you to provide login
credentials). Your device supports the 802.11 a/b/g/n
Wi-Fi protocol.
Configuring Wi-Fi Settings
For more information about configuring your device’s
Wi-Fi settings, see “Wi-Fi” on page 119.
Finding Wi-Fi Networks
You can have your device automatically notify you of
available networks. For more information, refer to “Advanced
Settings” on page 120.
Turning Wi-Fi On or Off
Turn your device’s Wi-Fi service on or off. When you turn
Wi-Fi service on, your device automatically searches for
available, in-range WAPs (Wireless Access Points).
Turning Wi-Fi On
1. From any screen, touch the top of the screen and
swipe downward.
The Status Details screen displays.
2. Touch
Wi-Fi
to turn Wi-Fi On.
Turning Wi-Fi Off
1. From any screen, touch the top of the screen and
swipe downward.
The Status Details screen displays.
2. Touch
Wi-Fi
to turn Wi-Fi Off.
Standard Mode 94
Scanning and Connecting to a Wi-Fi Network
When you turn on Wi-Fi, your device searches for available
Wi-Fi connections, then displays them on screen.
1. From any screen, touch the top of the screen and
swipe downward.
The Status Details screen displays.
2. Touch
Wi-Fi
to turn Wi-Fi On. Your device automatically
scans for available Wireless Access Points.
3. When the scan is complete, touch a Wi-Fi network to
connect. If the Wi-Fi network is open, your device
automatically connects. If the Wi-Fi network is
secured, enter the password at the prompt to connect.
Adding a Wi-Fi Network Manually
1. From a Home screen, touch
Apps
➔
Settings.
2. Under
Wireless and network
, on the Wi-Fi tab, touch the
OFF / ON
icon to turn Wi-Fi on.
3. Touch
Add Wi-Fi network
, then enter network
information:
• Network SSID
: Enter the name of the Wi-Fi Wireless Access
Point (WAP).
•Security
: Select the type of security used by the WAP.
Note:
Depending on the Security protocol used by the WAP,
additional network information may be required, such as
a Password.
•Password
: If the WAP is secured, enter the password or hex
key.
4. Touch
Save
to save the settings.
95
Wi-Fi Direct
Wi-Fi Direct allows device-to-device connections so you can
transfer large amounts of data over a Wi-Fi connection.
1. From a Home screen, touch
Apps
➔
Settings
➔
Wi-Fi
.
2. Touch the
OFF / ON
icon to turn Wi-Fi on.
3. Touch
Wi-Fi Direct
to display available devices.
Your device begins to search for other devices enabled
with Wi-Fi direct connections.
4. Enable Wi-Fi Direct (similar to Steps 1, 2, and 3) on the
device to which you want to connect.
5. Once the device you want to connect to is displayed,
touch on it.
An Invitation to connect displays on the device to which
you want to connect.
6. On that device, touch
Accept
.
You have 30 seconds to touch
Accept
on the device to
which you want to connect for the connection to be
made.
Once connected, the other device will show as
Connected
in your list of Wi-Fi Direct devices and the
icon will display in the System Bar.
Standard Mode 96
Sharing Information with Connected Device
To share videos, photos, or other information with the
connected device, follow these steps:
1. View the information that you want to share. For
example, if you want to share a photo, find the photo in
your camera viewer or
My Files
folder, then touch the
Share,
Share via,
or
Send via
option.
2. Touch the
Wi-Fi Direct
option.
The Wi-Fi Direct settings screen displays, Wi-Fi Direct
is turned on, and your device scans for other devices.
3. Touch a connected device name. For example,
Android_XXXX.
4. The other device displays a pop-up that indicates it is
receiving the file.
The file is transferred and can be found in
My Files
in
the ShareViaWifi folder.
Note:
Depending on the other device model, the prompts and
shared folder information may differ.
Bluetooth
Bluetooth is a short-range wireless communications
technology for exchanging information over a distance of
about 30 feet.
You do not need to line up the devices to send information
with Bluetooth. If the devices are in range, you can exchange
information between them, even if they are in different
rooms.
Configuring Bluetooth Settings
Configure your device’s Bluetooth settings. For more
information, refer to “Bluetooth” on page 122.
Turning Bluetooth On or Off
To turn Bluetooth on or off:
1. From a Home screen, touch
Apps
➔
Settings
.
2. Under
Wireless and network
, on the Bluetooth tab,
touch the
OFF / ON
icon to turn Bluetooth on or
off.
Note:
When Bluetooth is on, the
Bluetooth
icon displays in
the Status Bar.
97
Pairing with a Bluetooth Device
Search for a Bluetooth device and pair with it, to exchange
information between your device and the target device.
Tip:
After pairing, your device and the target device recognize
each other and exchange information without having to
enter a passcode or PIN.
1. From a Home screen, touch
Apps
➔
Settings
.
2. On the Bluetooth tab, touch the
OFF / ON
icon
to turn Bluetooth on.
3. Enable the target device’s discoverable or visible
mode.
4. Touch the
Bluetooth
tab and then touch
Scan
. Touch
Stop
at any time to stop scanning.
5. From the list of found devices, touch the target device,
then follow the prompts to complete the pairing:
•
If the target device requires a PIN, enter a PIN for the target
device and touch
OK
. When prompted, enter the PIN on the
target device.
•
If the device allows automatic or smart pairing, your device
attempts to pair with the device automatically. Follow the
prompts on your device and the target device to complete the
pairing.
Sharing Data with a Bluetooth Device
To send data to a Bluetooth device:
1. Select a file or item from an appropriate application.
2. Select an option for sharing data with the Bluetooth
feature.
Note:
The method for selecting an option may vary by data
type.
3. Search for and pair with a Bluetooth device. For more
information, refer to “Pairing with a Bluetooth Device”
on page 97.
Standard Mode 98
Receiving Data from a Bluetooth Device
To receive data from a Bluetooth device:
1. Turn Bluetooth on. For more information, refer to
“Turning Bluetooth On or Off” on page 96.
Note:
To select the length of time that your device will be
visible, select
Menu
➔
Visibility timeout
.
2. Pair with the Bluetooth device from which you want to
receive data. For more information, refer to “Pairing
with a Bluetooth Device” on page 97.
A Bluetooth authorization request pop-up displays
when a Bluetooth device sends data to your device.
3. Select
Accept
to confirm that you are willing to receive
data.
A File received message displays.
Received data is saved to the Bluetooth folder. If you receive
a contact, it is saved to your contacts automatically.
Managing Downloads
Files, apps, and other items you download in Internet, Gmail,
or in other ways, are stored on your tablet’s internal storage.
You can use the Downloads app to view, reopen, or delete
what you have downloaded.
To manage the demands on their networks or to help you
avoid unexpected charges, some mobile networks place
restrictions on the size of the files you can download. When
you are connected to such networks, and you try to
download an oversized-file, you are asked or required to
delay downloading the file until the next time you are
connected to a Wi-Fi network. At that time, the download
resumes automatically. The Downloads app can also be used
to view and manage these queued files.
Downloaded files are stored in the Download directory in
your tablet’s internal storage. You can view and copy files
from this directory when connected to a computer with a
USB cable.
99
Uninstalling an App
Apps come pre-installed on your device and you can
download additional apps from Google Play. If you decide to,
you can uninstall apps you downloaded from Google Play and
other sources.
There are several ways to uninstall an app:
1. From a Home screen, touch
Apps
➔
Settings
➔
Application manager
.
2. Touch the
DOWNLOADED
tab.
3. Touch the app you want to uninstall.
4. Touch the
Uninstall
button.
A pop-up displays the message
Application will be
uninstalled.
5. Touch
OK
to confirm you want to uninstall the app.
You can also use Google Play to uninstall apps you
downloaded from there (see “Play Store” on page 116).
Tip:
To uninstall updates to pre-installed apps, touch the app
and touch
Uninstall updates
. A pop-up displays the
message
All updates to this Android system app will be
uninstalled
. Touch
OK
to uninstall the updates.
To uninstall an app from the Apps screen:
1. From a Home screen, touch
Apps
.
2. Touch
Menu
➔
Uninstall
to display the Uninstall
screen.
– or –
Touch
Downloaded
and then touch
Menu
➔
Uninstall
.
A appears on Apps that can be uninstalled.
3. Touch an app’s icon and then touch
OK
to uninstall and
remove the app from your tablet.
Note:
You cannot uninstall the apps that are included with
Android. You can only uninstall the apps you have
downloaded.
Standard Mode 100
Kies Via Wi-Fi
Samsung Kies is a software that enables you to update your
device firmware, synchronize files, and transfer data to and
from your device directly by connecting to the PC.
Note:
Some features will be supported through the System
Updates feature in the future. For more information,
refer to “Software Update” on page 148.
To learn more about Samsung Kies and Samsung
applications, browse featured applications and download
Kies at:
http://www.samsung.com/us/support/downloads
.
Note:
Samsung Kies works on both PC and Macintosh
computers.
Connecting With Samsung Kies
1. Install Samsung Kies software on your PC.
Warning!
Close any running applications before connecting
your device to a PC.
2. Run Samsung Kies.
3. From a Home screen, touch
Apps
➔
Settings
.
4. Touch
More settings
➔
Kies via Wi-Fi
.
Select the source of the Wi-Fi connection for Kies air.
5. Follow the prompts from Kies to update your device
firmware.
6. Refer to Samsung Kies Help for more information.
101
Memory Card
Your device supports removable microSD or microSDHC
memory cards for storing music, photos, videos, and files.
Installing and Removing a Memory Card
For more information about installing and removing a
memory card, see “Memory Card” on page 8.
Important!
To prevent damage to information stored on the
memory card, always unmount the card before
removing it from the device.
Formatting a Memory Card
Formatting erases all content from the memory card and
prepares it for use with your device.
Formatting a Memory Card Using Your Device
1. From a Home screen, touch
Apps
➔
Settings
➔
Storage
.
2. After mounting the SD card, touch
Format SD card
.
3. Follow the prompts to confirm the formatting of
the card.
Formatting a Memory Card Using Your Computer
Consult your computer and/or memory card reader
documentation for information about formatting
memory cards.
Standard Mode 102
Synchronizing with Windows Media
Player
Ensure that Windows Media Player is installed on your PC.
1. Attach your device to the computer with the USB cable.
Your computer recognizes the connection and displays
the AutoPlay screen.
2. Click the option to
Sync digital media files to this device
to synchronize music files.
3. Select and drag the music files you want to the sync
list and begin synchronizing.
4. When finished, exit Windows Media Player and
disconnect the USB cable.
Connecting as a Mass Storage Device
You can connect your device to a PC as a removable disk and
access the file directory. If you insert a memory card in the
device, you can also access the files directory from the
memory card by using the device as a memory card reader.
Note:
The file directory of the memory card displays as
Card
,
separate from the internal memory, which is
Tablet
.
103
1. Insert a memory card into the device to transfer files
from or to the memory card.
2. Attach your device to the computer with the USB cable.
Your computer recognizes the connection and displays
the AutoPlay screen.
3. Click the option to
Open device to view files
.
You should see a Card and a Tablet folder.
4. Copy files from the PC to the memory card
(Card folder).
5. When finished, close the PC folder and disconnect the
USB cable.
Applications
This section contains a description of each application that is
available on the Apps screen, its function, and how to
navigate through that particular application. If the application
is already described in another section of this user manual,
then a cross reference to that particular section is provided.
Updating Applications
Once you have registered your device (see “Software
Update” on page 148) and signed into your Google account
(see “Setting Up Your Gmail Account” on page 64), you may
see the
Updates Available
notification in the Status Bar if
there is a new version of one or more apps available or, when
you open an application that is preloaded on your device, an
Update Available
message may be displayed.
To update the applications:
1. Touch the top of the screen and swipe downward.
The Status Details screen displays.
2. Touch
Updates available
.
For more information, refer to “Updates to Downloaded
Apps” on page 117.
Standard Mode 104
Accessing Applications
The
Apps
screen displays all applications installed on your
wireless device. Applications that you download and install
from Google Play or from the web are also added to a Home
screen.
To access applications:
From Kids mode, Locate the application’s icon and
touch it to launch the application.
Tip:
To open applications quickly, add the icons of frequently-
used applications to one of the Home screens, if it is not
there by default. For details, see “App Shortcuts” on
page 46.
Applications
Following are the preinstalled applications that display when
using Standard mode.
Alarm
Set alarms for reminders or for wake-up times.
Adding and Configuring Alarms
1. From a Home screen, touch
Apps
➔
Alarm
.
2. To display the Create alarm screen, touch
Create
.
– or –
Touch an existing alarm to display the Edit alarm
screen.
105
3. Touch fields on the screen to configure the alarm.
•
Some fields have preset values. Touch the field and touch the
desired value.
•
Other fields have to be input. Touch the field and use the
on-screen keyboard to input information.
•
Touching the check box next to some fields may make
additional fields available.
4. Touch
Save
to save the alarm.
The main Alarm screen displays showing the new or
updated alarm.
Activating Alarms
1. From a Home screen, touch
Apps
➔
Alarm
.
2. To activate or deactivate the alarm, touch
Turn
alarm on
. A gray alarm means the alarm is deactivated.
3. Touch an alarm to change any of its settings and then
touch
Save
to save the updates.
Editing and Deleting Alarms
1. Touch
Alarm
.
2. Touch and hold an alarm and then touch one of the
following options:
•Edit
: Edit the alarm. For more information, refer to
“Adding
and Configuring Alarms”
on page 104.
•Delete
: Delete the alarm.
– or –
Touch
Delete,
touch the existing alarms you want
to delete or touch
Select all
, and then touch
Delete
.
Turning Off an Alarm
When the alarm sounds, to turn off the alarm:
Touch and drag to the right.
Setting the Snooze Feature
To activate the Snooze feature after an alarm sounds:
Touch and slide to the left. Snooze must first be
set in the alarm settings.
Standard Mode 106
Calculator
The Calculator provides the basic arithmetic functions to
solve simple arithmetic problems and advanced operators to
solve more complex problems.
1. From a Home screen, touch
Apps
➔
Calculator
.
2. Enter the first number using the numeric keys.
3. Enter the operation for your calculation by touching the
+
(add),
-
(subtract),
×
(multiply), or
÷
(divide) key.
4. Enter the next number.
5. To view the result, touch the
=
(equals) key.
6. Repeat Steps 3 through 5 as many times as required.
7. Touch to clear the result.
8. For more advanced problems, rotate your device to
landscape mode and use the advanced operators
sin
,
ln
,
cos
,
log
,
tan
, and so on, just as you would on a
pocket calculator.
9. Touch and hold entries in the Calculator's display field
to copy or cut the contents of the display.
The and displays. Use the icons to select the
content to Cut or Copy, and then select ➔
Clipboard
to review the Clipboard.
Calendar
Your device includes a powerful planner to help you organize
your schedules more conveniently and effectively. Learn to
create and manage events and tasks, and set alarms to
remind yourself of important events and tasks.
1. Touch
Calendar
.
2. Touch a tab to choose a calendar view:
•Year
: Display all twelve months of this year. Sweep across the
years at the bottom of the screen to display another year.
•Month
: Display the current month. Touch a month and year at
the bottom of the screen to display another month.
• Week
: Display the current week. Touch a week at the bottom of
the screen to display another week.
•Day
: Display today’s schedule by hour. Touch day at the bottom
of the screen to display another day.
107
•List
: Display only event and task names and dates for a
selected year. Touch a year at the bottom of the screen to
display another year. Touch a date to hide or show the event or
task name.
•Task
: Display your list of tasks. Touch the sort field to change
how your tasks are sorted. Tasks can be sorted by due date,
priority, date, week, month, or group.
3. Swipe left or right across the screen to view other days
or other weeks. Swipe up or down the screen to view
other events.
4. To find an event or task, touch
Search
.
•
Use the on-screen keyboard to enter a search term. Possible
events display as you type.
•
Touch to display the keyboard.
•
Touch an event to send, edit, or delete the event.
5. Touch
Add new
and then touch
Save
to add a new
event to your calendar. For more information, refer to
“Creating an Event or Task” on page 108.
6. Touch
Menu
to select from the following options:
•Go to
: Use this option to go directly to a different date using the
calendar function.
• Delete
: Use this option to delete an event.
•Sync
: Use this option to synchronize the calendar with other
devices.
• Settings
: Use this setting to View settings and their options,
Event notification and their options, Sync settings, and the
associated email accounts attached to this calendar.
7. Customize the calendar. For more information, refer to
“Calendar Settings” on page 109.
8. Touch
Today
to return to the current date.
9. Touch
Calendars
to configure which events to display.
Touch
Add account
to add additional accounts from
which calendar events can be synced.
Standard Mode 108
Creating an Event or Task
To create an event or task:
1. Touch
Calendar
.
2. Double-tap the date for which you want to enter an all
day event or task.
– or –
Touch the date for which you want to enter an event or
task and touch .
3. Touch the
Add event
or
Add task
tab.
4. Enter the event or task information.
5. Touch
Save
.
Managing Events
You can delete, send, and edit events on your mobile device:
1. Touch
Calendar
.
2. Touch an event.
A pop-up displays event information.
3. Touch
Menu
for these options:
•Forward
: Launches email for you to forward the event.
•Share via
: Allows you to share the event or task via Bluetooth,
Dropbox, Gmail, or Wi-Fi Direct.
4. Touch
Delete
to delete events for the year, month,
week, day, week, month, before today, or all events,
depending on the Calendar view.
5. Touch
Edit
to edit the task.
Add Additional Calendar Accounts
To add additional accounts:
1. Touch
Calendar
➔
Calendars
➔
Add account
.
– or –
Touch
Settings
➔
Add account
.
The Add account screen displays.
2.
Touch an account type and enter your account information.
109
Calendar Settings
To set up Calendar preferences:
1. From a Home screen, touch
Apps
➔
Calendar
.
2. Touch
Menu
➔
Settings
.
3. On the left side of the screen touch
View settings
,
Event notification
, or one of your accounts.
Options display on the right side of the screen.
4. Touch fields on the screen to configure the Calendar.
•
Some fields have preset values. Touch the field and touch the
desired value.
•
Other fields have to be input. Touch the field and use the
on-screen keyboard to input information.
•
Touching the check box next to some fields may make
additional fields available.
From a Home screen, touch
Apps
➔
Calendar
.
Camera
Take photos and record video with your device’s built in
Camera.
For more information, refer to “Camera” on page 79.
From a Home screen, touch
Apps
➔
Camera
.
Chrome
Use Chrome to browse the internet and bring your open tabs,
bookmarks and omnibox data from your computer to your
phone or tablet.
From a Home screen, touch
Apps
➔
Chrome
.
Follow the on-screen instructions.
Standard Mode 110
Contacts
Store contact information for your friends, family and
colleagues, to quickly access information or to send a
message.
For more information, refer to “Contacts” on page 57.
From a Home screen, touch
Contacts
.
Downloads
Files, apps, and other items you download in Internet, Gmail,
or in other ways, are stored on your tablet’s internal storage.
Use the Downloads app to view, reopen, or delete what you
have downloaded.
1. From a Home screen, touch
Apps
➔
Downloads
.
2. Touch an item to open it.
3. Touch headings for earlier downloads to view them.
4. Touch items you want to send, to check them, and then
touch
Share
. Touch an option to share the item.
5. Touch items you want to delete, to check them, and
then touch
Delete
.
The items are deleted from your tablet.
6. Touch
Sort by size
or
Sort by date
, at the bottom of the
Downloads pop-up, to switch back and forth. Touch
Clear list
to cancel the download and clear the
download history.
111
Dropbox
Dropbox provides access to your personal computer files
directly from your device. It allows you to take your files with
you when you are on the go, edit files in your Dropbox from
your device, upload photos and videos to Dropbox, and share
your selected files freely with family and friends.
The in-device application works together with a partner
program placed on a target computer using an active Internet
connection.
Dropbox creates a folder that automatically synchronizes its
contents across all of your connected devices on your
account. Update a file to your dropbox on your computer, and
it is automatically updated to the same folder on your other
devices.
Download the Desktop Application
1. Use your computer’s browser to navigate to:
http://www.dropbox.com/.
2. Follow the on-screen instructions to install this
application on your target computer containing the
desired files.
Important!
The computer application must be installed on the
computer containing the desired files and that
computer must have an active Internet connection.
Note:
It might be necessary to configure your router’s firewall
settings to allow this application to gain access to the
Internet.
Accessing Dropbox On Your Device
1. From a Home screen, touch
Apps
➔
Dropbox
.
2. Follow the on-screen instructions.
Standard Mode 112
Gallery
Use Gallery to view, capture, and manage photos and videos.
For more information, refer to “Gallery” on page 88.
From a Home screen, touch
Apps
➔
Gallery
.
Gmail
Send and receive email with Gmail, Google’s web-based
email. For more information, refer to “Gmail” on page 64.
From a Home screen, touch
Apps
➔
Gmail
.
Google
Search the internet using the Google search engine. For more
information, refer to “Google Search” on page 67.
From the main Home screen, touch
.
– or –
Touch
Apps
➔
Google
.
Google Settings
Use this app to manage your Google settings.
From a Home screen, touch
Apps
➔
Google Settings
.
Google+
Share updates and see what is going on around you with
Google+ for mobile.
For more information, refer to “Google+” on page 68.
From a Home screen, touch
Apps
➔
Google+
.
113
Hangouts
Previously known as Google Talk™, is an updated place to
hangout, share photos, and even video calls. This is a free
web-based application for instant messaging offered by
Google.
From a Home screen, touch
Apps
➔
Hangouts
.
Kids Mode
Requires additional Information.
From a Home screen, touch
Apps
➔
Kids Mode
.
Maps
Use Google Maps to find your current location, get directions,
and other location-based information. For more information,
refer to “Maps” on page 68.
From a Home screen, touch
Apps
➔
Maps
.
Note:
You must enable location services to use Maps. Some
features require Stand-alone or Google location
services. For more information, refer to “Location
Services” on page 134.
Messenger
With Google Messenger, you can bring groups of friends
together into a simple group conversation.
For more information, refer to “Messenger” on page 66.
From a Home screen, touch
Apps
➔
Messenger
.
Music Player
Play music and other audio files that you copy from your computer.
For more information, refer to “Music Player” on page 74.
From a Home screen, touch
Apps
➔
Music
Player
.
Standard Mode 114
My Files
Find, view, and manage folders and files, such as music files,
photo files, video files, and so on, stored on your tablet. If the
file is associated with an application on your device, you can
launch the file in the application.
1. From a Home screen, touch
Apps
➔
My
Files
.
2. Touch a folder and scroll down or up until you locate
afile.
Note:
You may have to touch one or more subfolders before
you encounter files.
3. Touch a file to launch it in the associated application, if
the file is associated with an application.
4. While browsing files, use these controls: 5. To view a photo file:
•
Touch the file.
The Gallery app is used to open the photo. For more information,
refer to
“Viewing Photos and Videos”
on page 90.
6. To view a video file:
•
Touch the file.
The Video Player is launched and plays the video. For more
information, refer to
“Video Player”
on page 87.
Up
: Display a higher directory.
Search
: Use the keyboard to enter a search
term. The current folder is searched and
results are displayed. Touch
X
to remove the
search field.
Display mode
: Enable thumbnails for each file.
– or –
Enable list mode.
Home
: Display the root directory.
Create folder:
Create a new folder in the current
folder.
Mark files
: Touch the box to the left of each file
or next to the folder to select all files in the
folder. Then touch copy, cut, delete, or send via
in the Application bar.
115
Play Books
Google eBooks is a new way to discover, buy, and enjoy your
favorite books online and offline.
For more information, refer to “Play Books” on page 69.
From a Home screen, touch
Apps
➔
Play
Books
.
Play Games
This application displays the Play Store Games area where
you can purchase games.
From a Home screen, touch
Apps
➔
Play Games
.
Play Magazines
Google Play Magazines helps you subscribe to your favorite
magazines so you can have them available to read on your
tablet at your leisure.
1. From a Home screen, touch
Apps
➔
Play Magazines
.
Note:
If you are not already logged in with your Google
account, see “Setting Up Your Gmail Account” on
page 64.
2. For more information touch
Menu
➔
Help
.
Standard Mode 116
Play Movies & TV
Any movie you rent from the Google Play Store can be
downloaded for offline viewing through this application. In
addition, the Play Movies app can be used to stream your
Google Play movie rentals as well as play any of your
personal videos stored on your tablet.
1. From a Home screen, touch
Apps
➔
Play Movies & TV
.
Note:
If you are not already logged in with your Google
account, see “Setting Up Your Gmail Account” on
page 64.
2. For more information touch
Menu
➔
Help
.
Play Music
Play music and other audio files that you copy from your computer.
For more information, refer to “Play Music App” on page 71.
From a Home screen, touch
Apps
➔
Play Music
.
Play Store
Google Play Store provides access to downloadable
applications and games to install on your device. It also
allows you to provide feedback and comments about an
application, or flag an application that might be incompatible
with your device.
1. From a Home screen, touch
Apps
➔
Play Store
.
Note:
If you are not already logged in with your Google
account, see “Setting Up Your Gmail Account” on
page 64.
2. To get help for using Google Play, touch
Menu
➔
Help
.
117
Updates to Downloaded Apps
You can check for new versions of applications by visiting the
Google Play Store. Items that have a new version available
will say
Update
.
You can also select apps that you would like to be updated
automatically. To do this:
1. From a Home screen, touch
Apps
➔
Play
Store
and then touch
Installed Apps
.
2. Touch the
INSTALLED
tab to list the Play Store apps
installed on your device.
Update is displayed if there is an update available for
the app.
3. Touch an app and then touch
Menu
➔
Auto-update
to enable automatic updating. When
enabled, a check mark appears in the check box.
4. Touch
Open
to open the app on your device.
5. Touch
Update
to immediately update the app on your
device.
Samsung Apps
Connect to Samsung Apps and make your smart device even
smarter. Simply and easily download an abundance of
applications to your tablet such as games, news, reference,
social networking, navigation, and more.
From a Home screen, touch
Apps
➔
Samsung Apps
.
Screen Saver
When your tablet screen automatically times out, instead of a
blank screen, enable the Galaxy Note Screen Saver, which is
actually an action-packed video tour of all the fantastic
features that you will find on your Galaxy Tab.
1. From a Home screen, touch
Apps
➔
Screen Saver
.
2. Follow the prompts to set up Screen Saver.
Standard Mode 118
Settings
Configure your device to your preferences.
For more information, refer to “Settings” on page 119.
From a Home screen, touch
Apps
➔
Settings
.
Video Player
View and manage videos stored on your tablet.
For more information, refer to “Video Player” on page 87.
From a Home screen, touch
Apps
➔
Video
Player
.
Voice Search
To use Voice Search:
From a Home screen, touch
Apps
➔
Voice Search
.
Touch and speak the search criteria slowly and clearly.
Google searches for the information and displays results or
displays
Retry
.
YouTube
View and upload YouTube videos, right from your device.
For more information, refer to “YouTube” on page 70.
From a Home screen, touch
Apps
➔
YouTube
.
119
Settings
This section explains Settings for customizing your device.
Accessing Settings
To access Settings:
From a Home screen, touch
Apps
➔
Settings
.
– or –
From any screen, touch the top of the screen and
swipe downward, to display the Quick Settings, and
then touch
Settings
. For more information, refer to
“Quick Settings” on page 40.
The Settings screen displays.
The Settings Screen
The Settings screen has tabs on the left side of the screen.
Information related to the tabs displays on the right side of
the screen. There are four major groups of settings: Wireless
and network, Device, Personal, Accounts, and System.
Wireless and Network
Control your device’s wireless connections.
Wi-Fi
Your device supports Wi-Fi a/b/g/n. Use Wi-Fi settings to
manage your device’s Wi-Fi connections.
For more information about using your device’s Wi-Fi
features, see “Wi-Fi” on page 93.
Turning Wi-Fi On or Off
When you turn Wi-Fi service on, your device automatically
searches for available, in-range Wireless Access Points
(WAPs).
From any screen, touch the top of the screen and
swipe downward, to display the Quick Settings, and
then touch
Wi-Fi
in the Quick Settings menu.
For more information, refer to “Quick Settings” on
page 40.
– or –
Touch
Settings
.
On the Wi-Fi tab, touch the
OFF / ON
icon to
turn Wi-Fi on or off.
Standard Mode 120
Scan for Wi-Fi Networks
To make sure you have an accurate list of Wi-Fi networks.
Touch
Settings
➔
Wi-Fi
, and then touch
Scan
.
Add Wi-Fi Network
To open a dialog where you can add a Wi-Fi network by
entering its Network SSID (the name it broadcasts), security
type, and other properties:
1. Touch
Settings
➔
Wi-Fi
, and then touch
Add
Wi-Fi network
.
2. Use the keyboard to enter
Network SSID
.
3. Touch the
Security
field and then touch a security type.
Note:
Depending on the Security protocol used by the WAP,
additional network information may be required, such as
a Password.
4. If necessary, touch
Password
and enter the password or
hex key.
5. Touch
Save
.
Advanced Settings
Set up and manage wireless access points.
1. Touch
Settings
➔
Wi-Fi
.
2. Touch
Menu
➔
Advanced
.
The following options display:
• Network notification
: Have your device alert you to new
Wireless Access Points (WAPs). Touch
Network notification
to
turn notifications On or Off. When enabled, a check mark
appears in the check box.
• Keep Wi-Fi on during sleep
: Specify when to disconnect from
Wi-Fi.
• Wi-Fi timer
: Specify the
Starting time
and the
Ending time
for Wi-Fi to be connected.
•MAC address
: View your device’s MAC address, which is
required when connecting to some secured networks (not
configurable).
•IP address
: View your device’s IP address.
121
WPS Push Button
The WPS (Wi-Fi Protected Setup) feature (sometimes
associated with a physical or on-screen button on most
WAPs) allows you to pair your device and WAP without the
need for entering a passcode. This process is similar to Wi-Fi
Direct pairing.
In this case, once the WPS feature is active on your WAP,
your device can then detect it and then immediately pair to it.
Note:
WPS-capable routers display in the Wi-Fi list of available
devices with the term (
WPS available
) below their name.
To pair your device using WPS:
1. Follow the WPS activation instructions specific to your
Wireless Access Point.
1. Touch
Settings
➔
Wi-Fi
.
2. Touch
Menu
➔
WPS push button
.
3. Once the connection is complete, confirm that the
external router displays in the Wi-Fi list as connected.
WPS PIN Entry
If a WPS Push Button does not work, there is an alternative
WPS connection method where you would use a device
generated PIN number to establish the connection. This
number is then entered into your WAP’s WPS client PIN field
to complete the connection.
To pair your device using WPS PIN:
1. Touch
Settings
➔
Wi-Fi
.
2. Touch
Menu
➔
WPS PIN entry
.
3. Write down the generate PIN number and enter it into
your Wi-Fi Router’s client PIN field.
4. Once the connection is complete, confirm the external
router now appears in the Wi-Fi list as connected.
Wi-Fi Direct Settings
You can configure your device to connect directly with other
Wi-Fi capable devices. This is an easy way to transfer data
between devices. These devices must be enabled for Wi-Fi
Direct communication. This connection is direct and not via a
hot spot or WAP.
Standard Mode 122
1. Touch
Settings
➔
Wi-Fi
.
2. Touch the
OFF / ON
icon to turn Wi-Fi on.
3. Touch
Wi-Fi Direct
to display Available devices.
Your device begins to search for other devices enabled
with Wi-Fi direct connections.
4. When scanning is complete, touch a device name to
begin the connection process to another Wi-Fi Direct
compatible device.
Note:
The target device must also have Wi-Fi Direct service
active and running before it is detected by your device.
The direct connection establishes, the status field
displays “Connected”, and your connected device is
displayed in the Wi-Fi Direct devices listing.
5. Touch
End connection
➔
OK
to end the Wi-Fi Direct
connection.
For more information, refer to “Wi-Fi Direct” on page 95.
Bluetooth
Use Bluetooth settings to manage Bluetooth connections, set
your device’s name, and control your device’s visibility.
Turning Bluetooth On or Off
To turn your device’s Bluetooth service On or Off:
From any screen, touch the top of the screen and
swipe downward, to display the Quick Settings, and
then touch
Bluetooth
in the Quick Settings menu.
For more information, refer to “Quick Settings” on
page 40.
– or –
Touch
Settings
.
On the Bluetooth tab, touch the
OFF / ON
icon
to turn Bluetooth on or off.
For more information about using Bluetooth to exchange
information with other Bluetooth devices, see “Bluetooth” on
page 96.
123
Additional Bluetooth Settings
When Bluetooth is on, additional settings are available.
1. Touch
Settings
➔
Bluetooth
.
2. Touch
Scan
to scan for nearby discoverable devices.
After searching, touch a device to pair with it. For more
information, refer to “Pairing with a Bluetooth Device”
on page 97.
3. Touch
Menu
and select a Bluetooth setting to
configure:
• Rename device
: Your device’s default name displays on
screen. Touch to change the device name. Available when
Bluetooth is turned On.
• Visibility timeout
: Use this setting to control when to
automatically turn off the Discoverable option.
• Received files
: Show the list of files received by using
Bluetooth.
Data Usage
From this screen you can view the Wi-Fi or Ethernet data
usage.
1. Touch
Settings
➔
Data usage
.
2. Touch the
Data usage cycle
drop-down menu and
select a date.
The data usage displays as a visual (chart) and also
displays a list of each application with a breakdown of
data usage by application.
Note:
Data is measured by your device. Your service provider
may account for data usage differently.
3. Touch
Menu
and the following options display:
• Auto sync data
: Enable or Disable this option to automatically
sync data. Disable auto sync will reduce data usage and
conserve battery power, but notifications and updates will need
to be manually synchronized.
• Mobile hotspots
: Use this setting to display all Mobile
hotspots near you.
Standard Mode 124
More Settings
This tab displays additional wireless and network
information.
Touch
Settings
➔
More settings
.
Options display for Airplane mode, VPN, Nearby
devices, and Kies via Wi-Fi.
Airplane Mode
Airplane mode allows you to use many of your tablet’s
features, such as Camera, Games, and more, when you are
in an airplane or in any other area where accessing data is
prohibited.
Important!
When your tablet is in Airplane Mode, it cannot
access online information or applications.
Press and hold the
Power/Lock
Key
then touch
Airplane mode
.
– or –
Touch the top of the screen and swipe downward, to
display the Quick Settings, and then touch
Airplane
mode
.
For more information, refer to “Quick Settings” on
page 40.
– or –
Touch
Settings
➔
More settings
➔
Airplane mode
,
touch the check box, and then touch
OK
to turn on
Airplane mode.
A check mark appears in the check box when
Airplane mode is On.
125
VPN
The VPN settings menu allows you to set up and manage
Virtual Private Networks (VPNs).
Important!
Before you can use a VPN you must establish and
configure one.
Adding a VPN
Before you add a VPN you must determine which VPN
protocol to use: PPTP, L2TP/IPSec PSK, L2TP/IPSec RSA,
IPSec Xauth PSK, IPSec Xauth RSA, or IPSec Hybrid RSA.
Note:
You must also set a screen unlock PIN or password
before you can use credential storage. For more
information, refer to “Screen Lock” on page 134.
1. Touch
Settings
➔
More settings
➔
VPN
.
2. Touch
Add VPN
network
.
3. In the form that appears, fill in the information provided
by your network administrator.
4. Touch
Save
to save your VPN settings.
Connecting To a VPN
1. Touch
Settings
➔
More settings
➔
VPN
.
2. Touch the VPN to which you want to connect.
3. In the pop-up that opens, enter any requested
credentials.
4. Touch
Connect
.
Edit or Delete a VPN
1. Touch
Settings
➔
More settings
➔
VPN
.
2. Touch and hold the VPN that you want to edit or delete.
3. In the pop-up that opens, touch:
• Edit network
, make the desired VPN setting changes, and
touch
Save
.
– or –
• Delete network
to delete the VPN.
Standard Mode 126
Nearby Devices
This option allows you to share your media files with nearby
DLNA (Digital Living Network Alliance) enabled devices.
Warning!
If file sharing is enabled, other devices can access
your data. Use the Wi-Fi network and this option with
care.
To configure this option:
1. Touch
Settings
➔
More settings
➔
Nearby devices
.
2. Touch
File sharing
to turn File sharing on.
A check mark appears in the check box when File
sharing is On.
3. In the Advanced section, set the following options:
• Shared contents
: Select the content to share. Choices are:
Videos, Photos, and Music.
•Device name
: Enter the name for your device. The default is
the model number: SM-T2105.
• Allowed devices list
: Indicate the devices accessible to your
device.
• Not-allowed devices list
: Indicate the devices not accessible
to your device.
• Download to
: Set whether to download data to Device or SD
card.
• Upload from other devices
: If a nearby device attempts to
upload data, this setting indicates the response. Options are:
Always accept, Always ask, and Always reject.
Kies via Wi-Fi
Kies via Wi-Fi allows you to sync your PC wirelessly with your
tablet provided they are both on the same Wi-Fi network. You
can view and share videos, photos, music, ringtones, and
more.
1. Touch
Settings
➔
More settings
➔
Kies via Wi-Fi
.
2. Select the source of the Wi-Fi connection for Kies air.
For more information, refer to “Kies Via Wi-Fi” on page 100.
127
Device
This section of the Settings screen contains settings for your
device.
Home screen mode
Select your home screen layout from this screen.
1. Touch
Settings
➔
Home screen mode
.
2. Select your home screen layout by selecting:
•Basic mode
: also known as Standard mode. The Standard
mode Home screen and Apps display.
•Kids mode
: the Kids mode Home screen and Apps display.
Blocking Mode
When enabled, notifications for selected features are
disabled.
1. Touch
Settings
➔
Blocking mode
.
2. Touch the
OFF / ON
icon to turn Blocking
mode
ON
.
3. Touch
Turn off notifications
to enable this feature.
A check mark appears in the check box when Turn
off notifications is enabled.
4. The
Set time
option allows you to set Blocking mode for
a specific time range or
Always
.
Touch the
Always
field to disable it and configure the
From
and
To
time fields.
Note:
When this option is enabled, displays in the
Status Bar.
Standard Mode 128
Sound
Volume
Set the volume level for all types of sounds.
1. Touch
Settings
➔
Sound
➔
Volume
.
2. Touch and drag the sliders to set the volume for:
•Music
,
video
,
games
,
and other media
: Sounds made by
music apps, video apps, and more.
• Notifications
: Sounds for alerts to new messages and other
events.
• System
: Application sounds and other sounds made by your
device.
Tip:
You can also set System volume from a Home screen by
pressing the Volume Key.
3. Touch
OK
to save your settings.
Notifications
Select a default ringtone for message, alarm, and other
notifications.
1. Touch
Settings
➔
Sound
➔
Default notifications
.
2. Touch a ringtone to hear a sample and select it.
3. Touch
OK
to save the setting.
System
You can activate or deactivate both touch and screen lock
sounds.
1. Touch
Settings
➔
Sound
.
2. Touch the check box next to either of the following
options to activate the feature:
• Touch sounds
: Makes a sound when you touch the screen.
• Screen lock sound
: Makes a sound when your screen is
locked or unlocked.
A check mark appears in the check box when the
feature is enabled.
129
Display
Wallpaper
You can choose a picture to display on the Home Screen,
Lock screen, or to both the Home and lock screens. Choose
from preloaded wallpaper images or select a photo you have
downloaded or taken with the Camera.
1. Touch
Settings
➔
Display
➔
Wallpaper
.
2. Touch
Home screen
,
Lock screen
, or
Home and lock
screens
.
The Select wallpaper from screen displays the
following options:
Gallery
,
Live wallpapers
, and
Wallpapers
.
For more information, refer to “Wallpapers” on page 48.
Notification Panel
Customize the Notification panel.
1. Touch
Settings
➔
Display
➔
Notification panel
.
2. Touch
Brightness adjustment
to adjust the screen
brightness from the Notification panel.
3. To customize which quick setting buttons appear at the
top of the notifications panel, touch and drag buttons to
reorder them.
Brightness
Set the default screen brightness.
1. Touch
Settings
➔
Display
➔
Brightness
.
2. Touch and drag the slider to set the brightness or touch
Automatic brightness
.
3. Touch
OK
to save the setting.
Screen Timeout
Set the length of delay between the last key press or screen
touch and the automatic screen timeout (dim and lock).
1. Touch
Settings
➔
Display
.
2. Touch
Screen timeout
and select the screen delay time.
The screen delays shutting off after inactivity for the
selected period of time.
Standard Mode 130
Font Style and Size
Set the font for screen displays and the size you want it to
display.
1. Touch
Settings
➔
Display
.
2. Touch
Font style
then touch a font or touch
Get fonts
online
to browse and download a new font.
3. Touch
Font size
and select a font size.
More Display Settings
An additional display setting is available.
1. Touch
Settings
➔
Display
.
2. Under
More settings
, touch
Show battery percentage
to
display the device battery status next to the battery
icon. A check mark appears in the check box.
Storage
From this menu you can view the device memory or mount,
unmount, or format an SD card.
Device Memory
Touch
Settings
➔
Storage
.
The Device memory displays as Total space,
Applications, Pictures, videos, Audio, Downloads,
Miscellaneous files, and Available space.
SD Card
Once a memory card has been installed in your device,
the SD card memory displays as Total space and
Available space.
Mounting an SD Card
1. Install an SD card. For more information, refer to
“Installing a Memory Card” on page 8.
2. Touch
Settings
➔
Storage
.
3. Touch
Mount SD card
.
Unmounting an SD Card
1. Touch
Settings
➔
Storage
.
2. Touch
Unmount SD card
.
131
3. At the prompt, select
OK
to safely unmount the memory
card.
4. Remove the SD card from the slot. For more
information, refer to “Removing a Memory Card” on
page 9.
Note:
Unmounting an SD card will stop some applications
from functioning. Applications may not be available until
you mount the SD card again.
Formatting an SD Card
When formatting an SD card you will want to backup your
music and photo files that are stored on the card because
formatting the SD card deletes all the stored data.
1. Touch
Settings
➔
Storage
.
2. Touch
Format SD card
and then touch
Format SD card
again on the warning screen.
3. Touch
Delete all
.
Power Saving Mode
When enabled, your device automatically analyzes the
screen and adjusts the brightness to conserve battery power.
1. Touch
Settings
➔
Power saving mode
.
2. Touch the
OFF / ON
icon to turn Power saving
on or off.
3. Turn Power saving on and touch the Power saving
mode settings (
CPU power saving
or
Screen power
saving
) to enable or disable them.
4. Touch
Learn about Power saving mode
to display more
information about saving power mode.
Battery
See how much battery power is used for device activities.
1. Touch
Settings
➔
Battery
.
The battery level displays in percentage. The amount
of time the battery was used also displays. Battery
usage displays in percentages per application.
2. Touch
Screen
,
Android OS
,
or
Android System
to view
how the display and the Android system are affecting
battery use.
Note:
Other applications may be running that affect battery
use.
Standard Mode 132
Application Manager
You can download and install applications from Google Play
or create applications using the Android SDK and install them
on your device. Use Application manager settings to manage
applications.
Warning!
Because this device can be configured with system
software not provided by or supported by Google or
any other company, end-users operate these devices
at their own risk.
Memory Usage
See how memory is being used by Downloaded or Running
applications.
1. Touch
Settings
➔
Application manager
.
2. Touch
DOWNLOADED
,
RUNNING
,
or
ALL
to display
memory usage for that category of applications.
The graph at the bottom of the DOWNLOADED tab
shows used and free device memory. The graph at the
bottom of the RUNNING tab shows used and free RAM.
Downloaded
Displays apps you have downloaded onto your device.
1. Touch
Settings
➔
Application manager
.
2. Touch
DOWNLOADED
to view a list of all the
downloaded applications on your device.
3. To switch the order of the lists displayed in the
DOWNLOADED tabs, touch
Menu
➔
Sort by size
or
Sort by name
.
4. To reset your application preferences, touch
Menu
➔
Reset app preferences
.
133
5. Touch an application to view and update information
about the application, including memory usage, default
settings, and permissions.
The following options are displayed:
• Force stop
: Stops an app that is misbehaving. Restart your
device if stopping an app, process, or service causes your
device to stop working correctly.
• Uninstall
: Deletes the application from the tablet.
For more information, refer to
“Uninstalling an App”
on
page 99.
• Clear data
: Clears application data from memory.
•Clear cache
: If the app stores data in a temporary area of the
device's memory, and the amount of information stored is
displayed, touch this button to clearing the temporary storage.
• Clear defaults
: If you have configured an app to launch
certain file types by default, clear that setting.
•Permissions
: Lists the kinds of information about your device
and data to which the app has access.
Running Services
View and control services running on your device.
1. Touch
Settings
➔
Application manager
.
2. Touch the
RUNNING
tab.
All the applications that are currently running on the
device display.
3. Touch
Show cached processes
to display all the cached
processes that are running. Touch
Show services in use
to switch back.
4.
Touch one of the applications to view application information.
The following options display:
•Stop
: Stops the application from running on the device. This is
usually done prior to uninstalling the application.
Warning!
Not all services can be stopped. Stopping services
may have undesirable consequences on the
application or Android System.
•Report
: Report failure and other application information.
Note:
Options vary by application.
Standard Mode 134
Personal
This section of the Settings screen lets you manage the
personal settings for your device.
Location Services
You value your privacy. So, by default, your device only
acquires your location when you allow it. To use
Location-Based Services, you must first enable location
services on your device.
Before you use applications such as Google Maps and find
your location or search for places of interest, you must
enable the Use wireless networks option or enable the GPS
satellites.
1. Touch
Settings
➔
Location services
.
2. Touch
Use wireless networks
to enable location
information using the wireless network.
3. Touch
Location and Google search
to use your location
data for improved Google Search results and other
Google services.
Lock Screen
Screen Lock
Choose settings for unlocking your screen. For more
information about using the lock and unlock features, see
“Securing Your Device” on page 12.
1. Touch
Settings
➔
Lock screen
.
2. Touch
Screen lock
for these settings:
•Swipe
: Swipe the screen to unlock it.
• Face unlock
: Look at your tablet to unlock it. Follow the
on-screen instructions to set up Face unlock.
•Pattern
: A screen unlock pattern is a touch gesture you create
and use to unlock your device. Follow the prompts to create or
change your screen unlock pattern.
•PIN
: Select a PIN to use for unlocking the screen.
•Password
: Create a password for unlocking the screen.
•None
: No pattern, PIN, or password is required.
Note:
Additional options are available based on the
Screen lock
setting.
135
Lock Screen Options
You can customize the Lock screen with the lock screen
options.
Note:
This option activates when you select the With swipe
lock option.
1. Touch
Settings
➔
Lock screen
.
2. Touch
Lock screen options
and set the following
options:
•Clock
: Activate or deactivate the Lock screen clock. When
enabled, a check mark appears in the check box.
• Weather
: Touch the
OFF / ON
icon to turn this option
on or off, which causes weather information to be displayed on
the lock screen. This option requires a Wi-Fi connection.
•Help text
: Display help text on the lock screen. When enabled,
a check mark appears in the check box.
3. Touch
Lock automatically
so the screen will lock
5 seconds after the screen automatically turns off.
4. Touch
Lock instantly with power key
so you can
instantly lock the screen when you press the power
key.
Owner Information
Use this option to enable or disable whether to show owner
information on the lock screen.
1. Touch
Settings
➔
Lock screen
.
2. Touch
Owner information
and then touch
Show owner
info on lock screen
to enable or disable the option.
3. Touch the text field and use the keyboard to enter the
text to display on the lock screen.
4. Touch OK to confirm.
Standard Mode 136
Security
Encryption
To require a numeric PIN or password to decrypt your tablet
each time you power it on or encrypt the data on your SD
card each time it is connected:
1. Touch
Settings
➔
Security
.
2. Touch
Encrypt device
. For more information, read the
displayed help screen.
3. Touch
Encrypt external SD card
to enable the encryption
on SD card data that requires a password be entered
each time the microSD card is connected.
Tip:
Make sure your battery is charged more than 80 percent.
Encryption takes an hour or more.
Passwords
When enabled, password characters display briefly as you
touch them while entering passwords.
1. Touch
Settings
➔
Security
.
2. Touch
Make passwords visible
to enable or disable brief
displays of password characters.
When enabled, a check mark appears in the check
box.
Device Administration
To add or remove device administrators:
1. Touch
Settings
➔
Security
.
2. Touch
Device administrators
.
Enable or disable installation of non-Google Play
applications.
1. Touch
Settings
➔
Security
.
2. Touch
Unknown sources
.
An informational pop-up displays.
3. Read the message and touch
OK
to allow installation of
non-Google Play applications.
When enabled, a check mark appears in the
check box.
Warning!
Enabling this option causes your tablet and personal
data to be more vulnerable to attack by applications
from unknown sources.
137
Credential Storage
Trusted Credentials
If a certificate authority (CA) certificate gets compromised or
for some other reason you do not trust it, you can disable or
remove it.
1. Touch
Settings
➔
Security
.
2. Touch
Trusted credentials
.
The trusted credentials screen has two tabs:
• System
: Displays CA certificates that are permanently installed
in the ROM of your device.
•User
: Displays any CA certificates that you installed, for
example, in the process of installing a client certificate.
3. Touch a CA certificate to examine its details.
A scrolling screen displays the details.
4. Scroll to the bottom of the details screen and touch
Turn off
to disable a System certificate.
Caution!
When you disable a system CA certificate, the
Turn off
button changes to
Turn on
, so you can
enable the certificate again, if necessary.
5. Touch
OK
to return to the certificate list.
When enabled, a check mark appears in the check
box.
Install from Device Storage
Install encrypted certificates from an installed memory card.
Note:
You must have installed a memory card containing
encrypted certificates to use this feature.
1. Touch
Settings
➔
Security
.
2. Touch
Install from device storage
, then choose a
certificate and follow the prompts to install.
Clear Credentials
Clear stored credentials.
Note:
This setting only appears if you have installed encrypted
certificates.
1. Touch
Settings
➔
Security
.
2. Touch
Clear credentials
to remove all certificates.
Standard Mode 138
Language and Input
Language
Set the language used by your device.
1. Touch
Settings
➔
Language and input
➔
Language
.
2. Touch a language / locale from the list.
Keyboards and Input Methods
Set the keyboard used by your device.
1. Touch
Settings
➔
Language and input
.
2. Touch
Default
and select a keyboard.
Samsung keyboard is the only selection available for
this device.
3. Touch
Set up input methods
.
4. Touch
Google voice typing
to automatically use Google
voice typing.
5. Touch next to Google voice typing.
The following options are available:
• Choose input languages
: Touch
Automatic
to use the local
language or select a language from the list.
• Block offensive words
: Enable or disable blocking of
recognized offensive words from the results of your voice-input
Google searches.
When enabled, a check mark appears in the check box.
• Download offline speech recognition
: Enable voice input
while offline. Touch the
All
tab to download speech recognition
for other languages.
Configuring the Samsung Keyboard
To configure the Samsung keyboard:
Touch next to Samsung keyboard to display the
following options:
• Input languages
: Used to set a default text entry language.
Touch this field, scroll through the options, and touch the
desired input language. When activated, a check appears in
the box.
139
•Predictive text
: Enable or disable XT9 predictive text. When
enabled the system suggests words matching your text entries,
and, optionally, completes common words automatically.
When XT9 is enabled, touch the
Predictive text
field to set the
following options:
–
Personalized data
: Enter personalized data to improve
prediction results.
–
Learn from Facebook
: Log in to let your device learn your
Facebook style.
–
Learn from Gmail
: Log in to let your device learn your Gmail
style.
–
Learn from Twitter
: Log in to let your device learn your Twitter
style.
–
Learn from Contacts
: Allow your device to learn your Contacts
style.
–
Clear remote data
: Delete your anonymous data stored on the
personalization server.
–
Clear personal data
: Remove all personalized data entered.
• Continuous input
: Enable or disable the Continuous input
feature. When enabled, you can enter text by sliding your finger
across the keyboard.
• Cursor control
: Enable or disable. When enabled you can
move the cursor by sliding your finger across the keyboard.
• Advanced
displays the following advanced options:
–
Auto capitalization
automatically capitalizes the first letter of
the first word in each sentence (standard English style).
–
Auto spacing:
automatically inserts spaces between words.
–
Auto-punctuate
automatically inserts a full stop in a sentence
by touching the space bar twice when using the on-screen
QWERTY keyboard.
–
Character preview
provides an automatic preview of the
current character selection within the text string. This is helpful
when multiple characters are available within one key.
–
Key-tap sound
enables auditory feedback when you touch an
on-screen key.
•Tutorial
: Displays help for using the Samsung keyboard and
XT9 predictive text.
• Reset settings
: Reset keyboard settings except XT9 my words
and auto-substitution.
Standard Mode 140
Speech
Set the speech settings for Voice search.
1. Touch
Settings
➔
Language and input
.
2. Touch
Voice search
to configure:
• Language
: Choose a language for your voice input.
• Speech output
: Always provides audible readout of text, or
only when using Hands-free functions.
• Block offensive words
: Enable or disable blocking of
recognized offensive words from the results of your voice-input
Google searches.
• Hotword detection
: When enabled, saying the word Google
launches voice search.
• Download offline speech recognition
: Enable voice input
while offline. Touch the
All
tab to download speech recognition
for other languages.
• Bluetooth headset
: Record audio through a Bluetooth
headset, if available.
Voice output provides audible readout of text, for example,
the contents of email messages.
1. Touch
Settings
➔
Language and input
.
2. Touch
Text-to-speech output
and select the preferred
TTS engine.
3. Touch next to the preferred TTS engine and
configure.
4. Under General, configure the following:
• Speech rate
: Set the speed at which the text is spoken.
• Listen to an example
: Play a sample of speech synthesis
(available if voice data is installed).
• Driving mode
: New notifications are read aloud when enabled.
Touch the
OFF / ON
icon to enable, then touch
Driving mode
to display the Driving mode settings: Alarm,
Schedule, and Unlock screen.
Mouse/trackpad
This option sets your Pointer speed.
1. Touch
Settings
➔
Language and input
.
2. Touch
Pointer speed
then drag the slider to the right to
go faster or to the left to go slower.
3. Touch
OK
to save your setting.
141
Back Up and Reset
You can also back up your data to the Google server and
reset your device to its factory defaults.
Backup and Restore
To enable or disable backup of your information to the
Google server.
1. Touch
Settings
➔
Backup and reset
.
2. Touch
Back up my data
to enable or disable back up of
application data, Wi-Fi passwords, and other settings
to the Google server.
Once the
Back up my data
option is enabled, then the
Backup account
and the
Automatic restore
options are
available.
3. Touch
Backup account
and touch your Google Gmail
account or touch
Add account
to set your Google Gmail
account to be backed up to the Google server.
4. Touch
Automatic restore
to enable automatic
restoration of settings from the Google server. When
enabled, backed-up settings are restored when you
reinstall an application.
Factory Data Reset
Use Factory data reset to return your device to its factory
defaults. This setting erases all data from the device,
including Google or other account settings, system and
application data and settings, and downloaded applications,
as well as your music, photos, videos, and other files. If you
reset the tablet in this way, the next time you turn on your
tablet you are prompted to reenter the same kind of
information as when you first started Android.
1. Touch
Settings
➔
Backup and reset
.
2. Touch
Factory data reset
.
The Factory data reset screen displays reset
information.
3. Touch
Reset device
, then follow the prompts to perform
the reset.
Standard Mode 142
Accounts
Set up and manage accounts, including your Google and
Samsung accounts.
Your device provides the ability to synchronize information
from a variety of accounts, including Facebook, Google, and
your Samsung account. Depending on the account, you can
choose to synchronize your calendar, contacts, and other
types of content.
With synchronization, you can ensure that the information on
your device is updated with any information that changes in
your accounts.
Managing Accounts
To view the accounts you have added:
1. Touch
Settings
➔
(account).
The (account) is either Google, Samsung account, or
some other account you have added.
Each of your accounts (Google, Samsung, and so on)
are listed under Accounts.
2. Touch
Sync all
to synchronize all accounts listed. Touch
Cancel sync
to stop the synchronization.
3. Touch an account to view the sync settings for that
account.
•
Touch
Sync now
to synchronize all data for the selected
account.
– or –
Touch the account data to synchronize, such as, Calendar,
Contacts, and so on.
•
To remove the account, touch
Remove account
and then
touch
Remove account
at the prompt to remove the account
and delete all its messages, contacts, and other data.
4. For Google accounts, touch one of the items listed
under Privacy to view various settings for that item.
– or –
For Samsung accounts, touch
Account settings
to
manage Samsung account settings or
Device backup
to
set Samsung account back up and restore options.
143
Adding an Account
To add a new account:
1. Touch
Settings
➔
Add account
.
2. Touch one of the account types.
3. Use the keyboard and follow the prompts to enter your
credentials and set up the account.
Tip:
For more information about the types of accounts that you
can add, see “Accounts” on page 56.
Signing In to your Samsung Account
Several applications and options require that you create and
sign in to a Samsung Account.
To sign in to your Samsung account:
1. Touch
Settings
➔
Add account
.
2. Touch
Samsung account
.
The Samsung account sign in screen displays.
3. Touch
variety of services
to display information about
Samsung services that are available.
4. If you have no Samsung account, touch
Create new
account
.
– or –
If you do have a Samsung account, touch
Sign in
.
The Samsung account screen displays.
5. Use the keyboard to enter the required information and
touch
Sign up
or
Sign in
.
Tip:
The password is for your Samsung account, not the
password you use for the email address you are entering.
Plus, you can use only letters, numbers, !, @, $, %, &, ^,
and * for your Samsung account password.
6. If you are creating a new account, the Terms and
Conditions screen displays. Read the Terms and
conditions, Special terms, and Privacy policy and touch
I accept all the terms above
.
The Settings screen displays with Samsung account
listed under Accounts.
Standard Mode 144
System
Accessory
Dock
To enable your tablet to play sounds when inserting and
removing the device from the dock:
Touch
Settings
➔
Accessory
.
•Dock sound
: The tablet will not play sounds when inserting
and removing the device from the dock when enabled.
When enabled, a check mark appears in the check box.
• Audio output mode
: Select Stereo or Surround to choose the
audio output mode while the device is docked.
When enabled, a check mark appears in the check box.
Date and Time
By default, your device receives date and time information
from the wireless network. When you are outside network
coverage, you may want to set date and time information
manually using the Date & time settings.
1. Touch
Settings
➔
Date and time
.
2. Configure the following settings:
•Set date
: Enter the current date (only available when the
Automatic setting is disabled).
•Set time
: Enter the current time (only available when the
Automatic setting is disabled).
• Select time zone
: Choose your local time zone (only available
when the Automatic setting is disabled).
• Use 24-hour format
: Set the format for time displays.
• Select date format
: Set the format for date displays.
145
Accessibility
Accessibility services are special features to make using the
device easier for those with certain physical disabilities. Use
the Accessibility settings to activate these services.
Note:
You can download accessibility applications from
Google Play and manage their use here.
System
1. Touch
Settings
➔
Accessibility
.
2. Configure the following settings:
• Auto-rotate screen
: When this option is checked, the screen
orientation changes when you rotate the device. When this
option is not checked, the screen orientation locks in the
current orientation (landscape or portrait) and the orientation
does not change when you rotate the device.
Tip:
From any screen, touch the top of the screen and swipe
downward, to display the Quick Settings screen. Touch
Screen rotation
to enable or disable the auto-rotate
feature. For more information, refer to “Quick Settings” on
page 40.
• Screen timeout
: Select the screen delay time the screen
delays shutting off after inactivity for the selected period of
time.
•Lock automatically
: The screen will lock 5 seconds after the
screen automatically turns off.
• Speak passwords
: Speaks passwords to enter them.
•Show shortcut
: Set this option to display an Accessibility
shortcut on the Device options pop-up when you press and
hold the power key.
Standard Mode 146
Services
Enable or disable accessibility services.
Note:
You must activate
Accessibility
before enabling services.
1. Touch
Settings
➔
Accessibility
.
2. Touch
TalkBack
.
Note:
TalkBack, when installed and enabled, speaks feedback
to help blind and low-vision users.
3. Touch the
OFF / ON
icon to turn TalkBack on.
4. Touch
Settings
to configure TalkBack.
Important!
TalkBack can collect all of the text you enter,
except passwords, including personal data and
credit card numbers. It may also log your user
interface interactions with the device.
Vision
To set vision options:
1. Touch
Settings
➔
Accessibility
.
2. Configure the following settings:
•Font size
: Set the font size.
• Text-to-speech output
: To set voice output settings, touch
Text-to-speech output
and select the preferred TTS engine.
For more information, refer to
“Speech”
on page 140.
Touch
Speech rate
to set the speed at which the text is spoken.
Touch
Listen to an example
to play a short speech
demonstration.
Touch
Driving mode
to read new notifications aloud. Touch the
OFF / ON
icon to enable, then touch
Driving mode
to
display the Driving mode settings: Alarm, Schedule, and Unlock
screen.
• Enhance web accessibility
: Set this option to allow apps to
install scripts from Google that make their Web content more
accessible:
147
Hearing
To set hearing options:
1. Touch
Settings
➔
Accessibility
.
2. Configure the following settings:
• Mono Audio
: When Mono audio is enabled, you can listen
through one earphone to mono audio sound. When enabled, a
check mark appears in the check box.
• Turn off all sounds
: Turn off all sounds including receiver
voice. When enabled, a check mark appears in the check
box.
Mobility
To set mobility options:
1. Touch
Settings
➔
Accessibility
.
2. Touch
Press and hold delay
, and then touch a delay
time.
Developer Options
Set options for application development.
Caution!
These settings are intended for development use
only. They can cause errors to occur on your device
and with the applications on your device.
1. Touch
Settings
➔
Developer options
.
2. Touch the
OFF / ON
icon at the top of the
screen to activate developer options.
3. Touch an option to enable it. When enabled, a check
mark appears in the check box.
4. To display and select options, touch .
Standard Mode 148
About Device
View information about your device, including status, legal
information, hardware and software versions, and battery
use.
1. Touch
Settings
➔
About device
.
2. Touch items to view details:
• Software update
: Connect to the network and download new
software. For more information, refer to
“Software Update”
on page 148.
• Status
: View Battery status, Battery level, IP address, Wi-Fi
MAC address, Bluetooth address, Serial number, Up time, and
Device status.
• Legal information
: Touch an option to display open source
licenses, Google and Samsung legal information, Privacy Alert,
and license settings.
Tip:
To find your device’s DivX® registration code and
information about registering your device to play DivX
protected video, touch
License settings
➔
DivX
®
VOD
.
• Model number
: Display your device’s model number.
• Android version
: Display the firmware version of your device.
•Kernel version
: Display the kernel version of your device.
• Build number
: Display your device’s build number.
Software Update
The Software Update feature enables you to use your device
to connect to the network and download any new software
directly to your device. The device automatically updates
with the latest available software when you access this
option.
Software Update Options
To register your device and check for a software update:
1. Touch
Settings
➔
About device
➔
Software
update
.
2. Touch
Update
.
Your device is connected to the server and a search is
performed for a software update.
3. Touch
Auto update
to check for updates automatically.
When enabled, a check mark appears in the
check box.
149
Section 5: Health and Safety Information
This device is capable of operating in Wi-Fi
™
mode in the
2.4 and 5 GHz bands. The FCC requires that devices
operating within 5.15-5.25 GHz may only be used indoors,
not outside, in order to avoid interference with Mobile
Satellite Services (MSS). Therefore, this device is restricted
from being used outdoors when operating in frequencies
between 5.15-5.25 GHz.
This section outlines the safety precautions associated with
using your Galaxy Tab. The terms “GALAXY” or “mobile
device” are used in this section to refer to your Galaxy Tab.
Read this information before using your mobile device.
Exposure to Radio Frequency (RF)
Signals
Although GALAXY is not a cell phone, it can operate on the
same network as cell phones and can use the same Radio
Frequency (RF) signals to communicate with the network as
a cell phone. Therefore, although the following information
refers specifically to RF exposure from wireless phones, it
may apply similarly to GALAXY when it is being used on a cell
phone network.
The U.S. Food and Drug Administration (FDA) has published
information for consumers relating to Radio Frequency (RF)
exposure from wireless phones. The FDA publication
includes the following information:
Do cell phones pose a health hazard?
Many people are concerned that cell phone radiation will
cause cancer or other serious health hazards. The weight of
scientific evidence has not linked cell phones with any health
problems.
Cell phones emit low levels of Radio Frequency (RF) energy.
Over the past 15 years, scientists have conducted hundreds
of studies looking at the biological effects of the radio
frequency energy emitted by cell phones. While some
researchers have reported biological changes associated
with RF energy, these studies have failed to be replicated.
The majority of studies published have failed to show an
association between exposure to radio frequency from a cell
phone and health problems.
The low levels of RF cell phones emit while in use are in the
microwave frequency range. They also emit RF at
substantially reduced time intervals when in the stand-by
Health and Safety Information 150
mode. Whereas high levels of RF can produce health effects
(by heating tissue), exposure to low level RF that does not
produce heating effects causes no known adverse health
effects.
The biological effects of radio frequency energy should not
be confused with the effects from other types of
electromagnetic energy.
Very high levels of electromagnetic energy, such as is found
in X-rays and gamma rays, can ionize biological tissues.
Ionization is a process where electrons are stripped away
from their normal locations in atoms and molecules. It can
permanently damage biological tissues including DNA, the
genetic material.
The energy levels associated with radio frequency energy,
including both radio waves and microwaves, are not great
enough to cause ionization of atoms and molecules.
Therefore, RF energy is a type of non-ionizing radiation.
Other types of non-ionizing radiation include visible light,
infrared radiation (heat), and other forms of electromagnetic
radiation with relatively low frequencies.
While RF energy does not ionize particles, large amounts can
increase body temperatures and cause tissue damage. Two
areas of the body, the eyes and the testes, are particularly
vulnerable to RF heating because there is relatively little
blood flow in them to carry away excess heat.
Research Results to Date: Is there a connection
between RF and certain health problems?
The results of most studies conducted to date say no. In
addition, attempts to replicate and confirm the few studies
that have shown a connection have failed.
The scientific community at large therefore believes that the
weight of scientific evidence does not show an association
between exposure to Radio Frequency (RF) from cell phones
and adverse health outcomes. Still the scientific community
has supported additional research to address gaps in
knowledge. Some of these studies are described below.
Interphone Study
Interphone is a large international study designed to
determine whether cell phones increase the risk of head and
neck cancer. A report published in the International Journal
of Epidemiology (June, 2010) compared cell phone usage for
more than 5,000 people with brain tumors (glioma and
meningioma) and a similar number of healthy controls.
151
Results of this study did NOT show that cell phones caused
brain cancer. In this study, most people had no increased risk
of brain cancer from using cell phones. For people with the
heaviest use of cell phones (an average of more than ½ hour
per day, every day, for over 10 years) the study suggested a
slight increase in brain cancer. However, the authors
determined that biases and errors prevented any conclusions
being drawn from this data. Additional information about
Interphone can be found at
http://www.iarc.fr/en/media-centre/pr/2010/pdfs/pr200_E.pdf.
Interphone is the largest cell phone study to date, but it did
not answer all questions about cell phone safety. Additional
research is being conducted around the world, and the FDA
continues to monitor developments in this field.
International Cohort Study on Mobile Phone Users
(COSMOS)
The COSMOS study aims to conduct long-term health
monitoring of a large group of people to determine if there
are any health issues linked to long-term exposure to radio
frequency energy from cell phone use. The COSMOS study
will follow approximately 300,000 adult cell phone users in
Europe for 20 to 30 years. Additional information about the
COSMOS study can be found at
http://www.ukcosmos.org/index.html
.
Risk of Brain Cancer from Exposure to Radio
Frequency Fields in Childhood and Adolescence
(MOBI-KIDS)
MOBI-KIDS is an international study investigating the
relationship between exposure to radio frequency energy
from communication technologies including cell phones and
brain cancer in young people. This is an international
multi-center study involving 14 European and non-European
countries. Additional information about MOBI-KIDS can be
found at
http://www.creal.cat/programes-recerca/en_projectes-creal/
view.php?ID=39.
Surveillance, Epidemiology, and End Results (SEER)
Program of the National Cancer Institute
The National Cancer Institute (NCI) actively follows cancer
statistics in the United States to detect any change in rates of
new cases for brain cancer. If cell phones play a role in risk
for brain cancer, rates should go up, because heavy cell
phone use has been common for quite some time in the U.S.
Between 1987 and 2005, the overall age-adjusted incidence
of brain cancer did not increase. Additional information about
SEER can be found at
http://seer.cancer.gov/
.
Health and Safety Information 152
Cell Phone Industry Actions
Although the existing scientific data do not justify FDA
regulatory actions, the FDA has urged the cell phone industry
to take a number of steps, including the following:
•
Support-needed research on possible biological effects of RF
for the type of signal emitted by cell phones;
•
Design cell phones in a way that minimizes any RF exposure to
the user; and
•
Cooperate in providing users of cell phones with the current
information on cell phone use and human health concerns.
The FDA also is working with voluntary standard-setting
bodies such as the Institute of Electrical and Electronics
Engineers (IEEE), the International Commission on
Non-Ionizing Radiation Protection (ICNIRP), and others to
assure that safety standards continue to adequately protect
the public.
Reducing Exposure: Hands-Free Kits and Other
Accessories
Steps to Reduce Exposure to Radio Frequency Energy
If there is a risk from being exposed to radio frequency
energy (RF) from cell phones - and at this point we do not
know that there is - it is probably very small. But, if you are
concerned about avoiding even potential risks, you can take
a few simple steps to minimize your RF exposure.
•
Reduce the amount of time spent using your cell phone;
•
Use speaker mode or a headset to place more distance between
your head and the cell phone.
Hands-Free Kits
Hands-free kits may include audio or Bluetooth® headsets
and various types of body-worn accessories such as
belt-clips and holsters. Combinations of these can be used to
reduce RF energy absorption from cell phones.
Headsets can substantially reduce exposure because the
phone is held away from the head in the user's hand or in
approved body-worn accessories. Cell phones marketed in
the U.S. are required to meet RF exposure compliance
requirements when used against the head and against the
body.
153
Because there are no known risks from exposure to RF
emissions from cell phones, there is no reason to believe that
hands-free kits reduce risks. Hands-free kits can be used for
convenience and comfort. They are also required by law in
many states if you want to use your phone while driving.
Cell Phone Accessories that Claim to Shield the Head
from RF Radiation
Because there are no known risks from exposure to RF
emissions from cell phones, there is no reason to believe that
accessories which claim to shield the head from those
emissions reduce risks. Some products that claim to shield
the user from RF absorption use special phone cases, while
others involve nothing more than a metallic accessory
attached to the phone. Studies have shown that these
products generally do not work as advertised. Unlike
“hands-free” kits, these so-called “shields” may interfere
with proper operation of the phone. The phone may be forced
to boost its power to compensate, leading to an increase in
RF absorption.
Children and Cell Phones
The scientific evidence does not show a danger to any users
of cell phones from RF exposure, including children and
teenagers. The steps adults can take to reduce RF exposure
apply to children and teenagers as well.
•
Reduce the amount of time spent on the cell phone;
•
Use speaker mode or a headset to place more distance between
the head and the cell phone.
Some groups sponsored by other national governments have
advised that children be discouraged from using cell phones
at all. For example, The Stewart Report from the United
Kingdom made such a recommendation in December 2000.
In this report, a group of independent experts noted that no
evidence exists that using a cell phone causes brain tumors
or other ill effects. Their recommendation to limit cell phone
use by children was strictly precautionary; it was not based
on scientific evidence that any health hazard exists.
Additional information on the safety of RF exposures from
various sources can be obtained from the following
organizations (updated 10/1/2010):
•
FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/.
Health and Safety Information 154
•
Environmental Protection Agency (EPA):
http://www.epa.gov/radtown/wireless-tech.html.
•
Occupational Safety and Health Administration (OSHA):
http://www.osha.gov/SLTC/radiofrequencyradiation/.
(Note: This web address is case sensitive.)
•
National Institute for Occupational Safety and Health (NIOSH):
http://www.cdc.gov/niosh/.
•
World Health Organization (WHO):
http://www.who.int/peh-emf/en/.
•
International Commission on Non-Ionizing Radiation Protection:
http://www.icnirp.de.
•
Health Protection Agency:
http://www.hpa.org.uk/Topics/Radiation/.
•
US Food and Drug Administration:
http://www.fda.gov/Radiation-EmittingProducts/
RadiationEmittingProductsandProcedures/
HomeBusinessandEntertainment/CellPhones/default.htm.
Specific Absorption Rate (SAR)
Certification Information
Your wireless mobile device is a radio transmitter and
receiver. It is designed and manufactured not to exceed the
exposure limits for Radio Frequency (RF) energy set by the
Federal Communications Commission (FCC) of the U.S.
Government.
These FCC RF exposure limits are derived from the
recommendations of two expert organizations: the National
Council on Radiation Protection and Measurement (NCRP)
and the Institute of Electrical and Electronics Engineers
(IEEE). In both cases, the recommendations were developed
by scientific and engineering experts drawn from industry,
government, and academia after extensive reviews of the
scientific literature related to the biological effects of RF
energy.
The RF exposure limit set by the FCC for wireless mobile
devices employs a unit of measurement known as the
Specific Absorption Rate (SAR). The SAR is a measure of the
rate of absorption of RF energy by the human body
expressed in units of watts per kilogram (W/kg). The FCC
requires wireless devices to comply with a safety limit of 1.6
watts per kilogram (1.6 W/kg).
155
The FCC SAR limit incorporates a substantial margin of safety
to give additional protection to the public and to account for
any variations in measurements.
SAR tests are conducted using standard operating positions
accepted by the FCC with the mobile device transmitting at
its highest certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified
power level, the actual SAR level of the mobile device while
operating can be well below the maximum reported value.
This is because the mobile device is designed to operate at
multiple power levels so as to use only the power required to
reach the network. In general, the closer you are to a
wireless base station antenna, the lower the power output of
the mobile device.
Before a new model mobile device is available for sale to the
public, it must be tested and certified to the FCC that it does
not exceed the SAR limit established by the FCC. Tests for
each model mobile device are performed in positions and
locations (e.g. near the body) as required by the FCC.
For typical operations, this mobile device has been tested
and meets FCC SAR guidelines.
Use of other accessories may not ensure compliance with
FCC RF exposure guidelines. The FCC has granted an
Equipment Authorization for this mobile device with all
reported SAR levels evaluated as in compliance with the FCC
RF exposure guidelines.
This tablet has a FCC ID number: A3LSMT2105 [Model
Number:
SM-T2105] and the specific SAR levels for this tablet can be
found at the following FCC website:
http://www.fcc.gov/oet/ea/
.
The SAR information for this device can also be found on
Samsung’s website:
http://www.samsung.com/sar
.
SAR information on this and other model mobile devices can
be accessed online on the FCC's website through
http://
transition.fcc.gov/oet/rfsafety/sar.html
. To find information that
pertains to a particular model mobile device, this site uses
the mobile device FCC ID number, which is usually printed
somewhere on the case of the mobile device.
Once you have the FCC ID number for a particular mobile
device, follow the instructions on the website and it should
provide values for typical or maximum SAR for a particular
mobile device. Additional SAR information can also be
Health and Safety Information 156
obtained at
http://www.fcc.gov/encyclopedia/specific-absorption-rate-sar-
cellular-telephones.
FCC Part 15 Information to User
Pursuant to part 15.21 of the FCC Rules, you are cautioned
that changes or modifications not expressly approved by
Samsung could void your authority to operate the device.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more
of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
Smart Practices While Driving
On the Road - Off the Tablet
The primary responsibility of every driver is the safe
operation of his or her vehicle.
Responsible drivers understand that no secondary task
should be performed while driving whether it be eating,
drinking, talking to passengers, or using a mobile device -
unless the driver has assessed the driving conditions and is
confident that the secondary task will not interfere with their
primary responsibility.
Do not engage in any activity while
driving a moving vehicle which may cause you to take your
eyes off the road or become so absorbed in the activity that
157
your ability to concentrate on the act of driving becomes
impaired
. Samsung is committed to promoting responsible
driving and giving drivers the tools they need to understand
and address distractions.
Check the laws and regulations on the use of mobile devices
and their accessories in the areas where you drive. Always
obey them. The use of these devices may be prohibited or
restricted in certain areas. For example, only hands-free use
may be permitted in certain areas.
Before using your device to chat with friends, consider your
circumstances. Let the chat wait when driving conditions
require. Remember, driving comes first, nothing else!
If you consider a chat necessary and appropriate, follow
these tips:
•
Use a hands-free device;
•
Secure your mobile device within easy reach;
•
Chat when you are not moving;
•
Plan chats when your car will be stationary;
•
Do not engage in stressful or emotional conversations;
•
Let the person with whom you are speaking know that you are
driving and will suspend the chat if necessary;
•
Do not take notes or look up information while driving;
Notice regarding legal restrictions on mounting this device in
an automobile:
Laws in some states may prohibit mounting this device on or
near the windshield of an automobile. In other states, the law
may permit mounting this device only in specific locations in
the automobile. Be sure to consult the state and local laws or
ordinances where you drive before mounting this device in
an automobile. Failure to comply with these restrictions could
result in fines, penalties, or other damages.
Never mount this device in a manner that will obstruct the
driver’s clear view of the street and traffic.
Never use wireless data services such as Web browsing or
e-mail while operating a vehicle.
Never watch videos, such as a movie or clip, or play video
games while operating a vehicle.
For more information, go to
http://www.ctia.org
.
Battery Use and Safety
The battery in GALAXY is not intended to be replaced by the
consumer. If you believe the battery is damaged or needs to
be replaced, take the GALAXY to a service center for
inspection and replacement.
Health and Safety Information 158
•
Do not let the GALAXY or battery come in contact with
liquids
. Liquids can get into the GALAXY’s circuits, leading to
corrosion. Even when the GALAXY appears to be dry and appears
to operate normally, the circuitry could slowly corrode and pose a
safety hazard. If the GALAXY and/or battery get wet, have them
checked by your service provider or contact Samsung, even if
they appear to be working properly.
•
Do not place your battery in or near a heat source
. Excessive
heating can damage the GALAXY or the battery and could cause
the GALAXY or the battery to explode. Do not dry a wet or damp
battery with an appliance or heat source such as a microwave
oven, hair dryer, iron, or radiator. Avoid leaving your GALAXY in
your car in high temperatures.
•
Do not dispose of the GALAXY or the battery in a fire
. The
GALAXY or the battery may explode when overheated.
•
Avoid dropping the GALAXY
. Dropping the GALAXY, especially on
a hard surface, can potentially cause damage to the GALAXY. If
you suspect damage to the GALAXY or battery, take it to a service
center for inspection.
•
Never use any charger or battery that is damaged in any way
.
Important!
Use only Samsung-approved batteries, and
recharge your battery only with
Samsung-approved chargers which are specifically
designed for your GALAXY.
WARNING!
Use of a non-Samsung-approved battery or charger may
present a risk of fire, explosion, leakage, or other hazard
.
Samsung's warranty does not cover damage to the GALAXY
caused by non-Samsung-approved batteries and/or
chargers.
•
Do not use incompatible batteries and chargers
. Some
websites and second-hand dealers not associated with reputable
manufacturers and carriers, might be selling incompatible or even
counterfeit batteries and chargers. Consumers should purchase
manufacturer or carrier-recommended products and accessories.
If unsure about whether a replacement battery or charger is
compatible, contact the manufacturer of the battery or charger.
•
Misuse or use of incompatible batteries and charging
devices could result in damage to the equipment and a
possible risk of fire, explosion, or leakage, leading to serious
injuries, damages to your phone, or other serious hazard
.
159
Samsung Mobile Products and
Recycling
Samsung cares for the environment and encourages its
customers to recycle Samsung mobile devices and genuine
Samsung accessories.
Proper disposal of your mobile device and its battery is not
only important for safety, it benefits the environment.
Batteries must be recycled or disposed of properly.
For more information about recycling your GALAXY, go to:
http://mobile.samsungusa.com/recycling/index.jsp
or call
1-800-822-8837 for more information.
To find the nearest recycling location, go to:
www.samsung.com/recyclingdirect
or call 1-877-278-0799.
Warning!
Never dispose of batteries in a fire because they may
explode.
UL Certified Travel Charger
The Travel Charger for this mobile device has met applicable
UL safety requirements. Please adhere to the following safety
instructions per UL guidelines:
FAILURE TO FOLLOW THE INSTRUCTIONS OUTLINED MAY
LEAD TO SERIOUS PERSONAL INJURY AND POSSIBLE
PROPERTY DAMAGE.
IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE
INSTRUCTIONS.
DANGER - TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, CAREFULLY FOLLOW THESE
INSTRUCTIONS.
FOR CONNECTION TO A SUPPLY NOT IN NORTH
AMERICA, USE AN ATTACHMENT PLUG ADAPTOR
OF THE PROPER CONFIGURATION FOR THE
POWER OUTLET.
THIS POWER UNIT IS INTENDED TO BE
CORRECTLY ORIENTED IN A VERTICAL OR
HORIZONTAL OR FLOOR MOUNT POSITION.
Display / Touch-Screen
Please note the following information when using your
mobile device:
WARNING REGARDING DISPLAY
Health and Safety Information 160
The display on your mobile device is made of glass or
acrylic and could break if your mobile device is
dropped or if it receives significant impact. Do not use
if screen is broken or cracked as this could cause
injury to you.
WARRANTY DISCLAIMER: PROPER USE OF A
TOUCH-SCREEN MOBILE DEVICE
If your mobile device has a touch-screen display,
please note that a touch-screen responds best to a
light touch from the pad of your finger or a non-metallic
stylus. Using excessive force or a metallic object when
pressing on the touch-screen may damage the
tempered glass surface and void the warranty. For
more information, please refer to the “Standard
Limited Warranty”.
GPS
GALAXY can use a Global Positioning System (GPS) signal for
location-based applications. A GPS uses satellites controlled
by the U.S. Government that are subject to changes
implemented in accordance with the Department of Defense
policy and the 2008 Federal Radio navigation Plan (FRP).
Changes may affect the performance of location-based
technology on your mobile device.
Your Location
Location-based information includes information that can be
used to determine the approximate location of a mobile
device. Mobile devices which are connected to a wireless
network transmit location-based information. Additionally, if
you use applications that require location-based information
(e.g. driving directions), such applications transmit
location-based information. The location-based information
may be shared with third-parties, including your wireless
service provider, applications providers, Samsung, and other
third-parties providing services.
Navigation
Maps, directions, and other navigation-data, including data
relating to your current location, may contain inaccurate or
incomplete data, and circumstances can and do change over
time. In some areas, complete information may not be
available. Therefore,
you should always visually confirm that
the navigational instructions are consistent with what you see
161
before following them. All users should pay attention to road
conditions, closures, traffic, and all other factors that may
impact safe driving or walking. Always obey posted road signs
.
Emergency Communication
GALAXY should not be relied upon for essential
communications (medical emergencies, calls to 911, or
communications to emergency services). GALAXY is not
designed or intended to be used for such communications.
Voice Over Internet Protocol (VOIP) services which may be
used on GALAXY to make phone calls do not support 911
calls and are only intended for talking with friends.
Care and Maintenance
Your mobile device is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for many
years:
Keep your Samsung Mobile Device away from:
Liquids of any kind
Keep the mobile device dry. Precipitation, humidity, and
liquids contain minerals that will corrode electronic
circuits.
If the mobile device does get wet, do not accelerate
drying with the use of an oven, microwave, or dryer,
because this may damage the mobile device and could
cause a fire or explosion. Do not use the mobile device
with a wet hand. Doing so may cause an electric shock to
you or damage to the mobile device.
Extreme heat or cold
Avoid temperatures below 0°C / 32°F or above 45°C /
113°F.
Microwaves
Do not try to dry your mobile device in a microwave oven.
Doing so may cause a fire or explosion.
Dust and Dirt
Do not expose your mobile device to dust, dirt, or sand.
Cleaning solutions
Do not use harsh chemicals, cleaning solvents, or strong
detergents to clean the mobile device. Wipe it with a soft
cloth slightly dampened in a mild soap-and-water
solution.
Shock or vibration
Do not drop, knock, or shake the mobile device. Rough
handling can break internal circuit boards.
Health and Safety Information 162
Paint
Do not paint the mobile device. Paint can clog the
device’s moving parts or ventilation openings and prevent
proper operation.
Responsible Listening
Caution! Avoid potential hearing loss
.
Damage to hearing occurs when a person is exposed to loud
sounds over time. The risk of hearing loss increases as
sound is played louder and for longer durations.
Prolonged exposure to loud sounds (including music) is the
most common cause of preventable hearing loss. Some
scientific research suggests that using portable audio
devices, such as portable music players and cell phones, at
high volume settings for long durations may lead to
permanent noise-induced hearing loss. This includes the use
of headphones (including headsets, earbuds, and Bluetooth®
or other wireless devices).
Exposure to very loud sound has also been associated in
some studies with tinnitus (a ringing in the ear),
hypersensitivity to sound, and distorted hearing. Individual
susceptibility to noise-induced hearing loss and potential
hearing problem varies. Additionally, the amount of sound
produced by a portable audio device varies depending on the
nature of the sound, the device settings, and the headphones
that are used. As a result, there is no single volume setting
that is appropriate for everyone or for every combination of
sound, settings, and equipment.
You should follow some common sense recommendations
when using any portable audio device:
•
Always turn the volume down before plugging the earphones into
an audio source.
•
Set the volume in a quiet environment and select the lowest
volume at which you can hear adequately.
•
Be aware that you can adapt to higher volume settings over time,
not realizing that the higher volume may be harmful to your
hearing.
•
When using headphones, turn the volume down if you cannot
hear the people speaking near you or if the person sitting next to
you can hear what you are listening to.
163
•
Do not turn the volume up to block out noisy surroundings. If you
choose to listen to your portable device in a noisy environment,
use noise-cancelling headphones to block out background
environmental noise. By blocking background environment noise,
noise cancelling headphones should allow you to hear the music
at lower volumes than when using earbuds.
•
Limit the amount of time you listen. As the volume increases, less
time is required before you hearing could be affected.
•
Avoid using headphones after exposure to extremely loud noises,
such as rock concerts, that might cause temporary hearing loss.
Temporary hearing loss might cause unsafe volumes to sound
normal.
•
Do not listen at any volume that causes you discomfort. If you
experience ringing in your ears, hear muffled speech, or
experience any temporary hearing difficulty after listening to your
portable audio device, discontinue use and consult your doctor.
You can obtain additional information on this subject from the
following sources:
American Academy of Audiology
11730 Plaza American Drive, Suite 300
Reston, VA 20190
Voice: (800) 222-2336
Email: info@audiology.org
Internet:
http://www.audiology.org/Pages/
default.aspx
National Institute on Deafness and Other
Communication Disorders
National Institutes of Health
31 Center Drive, MSC 2320
Bethesda, MD 20892-2320
Email: nidcdinfo@nih.gov
Internet:
http://www.nidcd.nih.gov/
Health and Safety Information 164
Operating Environment
Remember to follow any special regulations in force in any
area, and always switch your mobile device off whenever it is
forbidden to use it, or when it may cause interference or
danger. When connecting the mobile device or any accessory
to another device, read its user's guide for detailed safety
instructions. Do not connect incompatible products.
Using Your Mobile Device Near Other Electronic
Devices
Most modern electronic equipment is shielded from Radio
Frequency (RF) signals. However, certain electronic
equipment may not be shielded against the RF signals from
your wireless mobile device. Consult the manufacturer to
discuss alternatives.
Implantable Medical Devices
A minimum separation of six (6) inches should be maintained
between a handheld wireless mobile device and an
implantable medical device, such as a pacemaker or
implantable cardioverter defibrillator, to avoid potential
interference with the device.
Persons who have such devices:
•
Should ALWAYS keep the mobile device more than six (6) inches
from their implantable medical device when the mobile device is
turned ON;
•
Should not carry the mobile device in a breast pocket;
•
Should use the ear opposite the implantable medical device to
minimize the potential for interference;
•
Should turn the mobile device OFF immediately if there is any
reason to suspect that interference is taking place;
National Institute for Occupational Safety
and Health (NIOSH)
395 E Street, S.W., Suite 9200
Patriots Plaza Building
Washington, DC 20201
Voice: 1-800-35-NIOSH
(1-800-356-4674)
1-800-CDC-INFO (1-800-232-4636)
Outside the U.S. 513-533-8328
Email: cdcinfo@cdc.gov
Internet:
http://www.cdc.gov/niosh/topics/noise/
default.html
1-888-232-6348 TTY
165
•
Should read and follow the directions from the manufacturer of
your implantable medical device. If you have any questions about
using your wireless mobile device with an implantable medical
device, consult your health care provider.
For more information see:
http://www.fcc.gov/oet/rfsafety/rf-
faqs.html#
.
Other Medical Devices
If you use any other personal medical devices, consult the
manufacturer of your device to determine if it is adequately
shielded from external RF energy. Your physician may be able
to assist you in obtaining this information. Switch your
mobile device off in health care facilities when any
regulations posted in these areas instruct you to do so.
Hospitals or health care facilities may be using equipment
that could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check with
the manufacturer or its representative regarding your vehicle
before using your mobile device in a motor vehicle. You
should also consult the manufacturer of any equipment that
has been added to your vehicle.
Posted Facilities
Switch your mobile device off in any facility where posted
notices require you to do so.
Potentially Explosive Environments
Switch your mobile device off when in any area with a
potentially explosive atmosphere and obey all signs and
instructions. Sparks in such areas could cause an explosion
or fire resulting in bodily injury or even death. Users are
advised to switch the mobile device off while at a refueling
point (service station).
Users are reminded of the need to observe restrictions on the
use of radio equipment in fuel depots (fuel storage and
distribution areas), chemical plants, or where blasting
operations are in progress. Areas with a potentially explosive
atmosphere are often, but not always, clearly marked. They
include below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such as
propane or butane), areas where the air contains chemicals
or particles, such as grain, dust, or metal powders, and any
other area where you would normally be advised to turn off
your vehicle engine. Vehicles using liquefied petroleum gas
Health and Safety Information 166
(such as propane or butane) must comply with the National
Fire Protection Standard (NFPA-58). For a copy of this
standard, contact the National Fire Protection Association.
When your Device is Wet
Do not turn on your device if it is wet. If your device is
already on, turn it off and remove the battery immediately, if
applicable (if the device will not turn off or you cannot
remove the battery, leave it as-is). Then, dry the device with
a towel and take it to a service center.
Children's Access to this Mobile
Device
This mobile device is designed for use by children 3 and
older. Please make sure to review the instructions for care
provided in this manual. Parents should make sure that
there is adequate supervision of children while using the
mobile device. Parental control settings should be enabled to
ensure that children do not have access to services not
approved by the parent.
Routinely check this mobile device to ensure that the device
is working properly and is safe for children to use.
FCC Notice and Cautions
FCC Notice
The mobile device may cause TV or radio interference if used
in close proximity to receiving equipment. The FCC can
require you to stop using the mobile device if such
interference cannot be eliminated.
Cautions
Any changes or modifications to your mobile device not
expressly approved by Samsung could void your warranty for
this equipment and void your authority to operate this
equipment. Only use approved batteries, antennas, and
chargers.
The use of any unauthorized accessories may be dangerous
and void the mobile device warranty if said accessories
cause damage or a defect to the mobile device. Although
your mobile device is quite sturdy, it is a complex piece of
equipment and can be broken. Avoid dropping, hitting,
bending, or sitting on it.
Other Important Safety Information
•
Not recommended for children under three years of age.
167
•
Only qualified personnel should service the mobile device. Faulty
service may be dangerous and may invalidate any warranty
applicable to the device.
•
Ensure that any mobile devices or related equipment used in your
vehicle are securely mounted.
•
Check regularly that all wireless mobile device equipment in your
vehicle is mounted and operating properly.
•
When using a headset in dry environments, static electricity can
build up in the headset and cause a small quick static electrical
shock. To minimize the risk of electrostatic discharge from the
headset avoid using the headset in extremely dry environments or
touch a grounded unpainted metal object to discharge static
electricity before inserting the headset.
•
Do not store or carry flammable liquids, gases, or explosive
materials in the same compartment as the mobile device, its
parts, or accessories.
•
For vehicles equipped with an air bag, remember that an air bag
inflates with great force. Do not place objects, including installed
or portable wireless equipment near or in the area over the air
bag or in the air bag deployment area. If wireless equipment is
improperly installed and the air bag inflates, serious injury could
result.
•
Switch your mobile device off before boarding an aircraft. The use
of wireless mobile devices in aircraft is illegal and may be
dangerous to the aircraft's operation. Check with appropriate
authorities before using any function of a mobile device while on
an aircraft.
•
Failure to observe these instructions may lead to the suspension
or denial of network services to the offender, or legal action, or
both.
•
While using your device, leave some lights on in the room and do
not hold the screen too close to your eyes.
•
Seizures or blackouts can occur when you are exposed to flashing
lights while watching videos or playing games for extended
periods. If you feel any discomfort, stop using the device
immediately.
Health and Safety Information 168
•
Reduce risk of repetitive motion injuries. When you repetitively
perform actions, such as pressing keys, drawing characters on a
touch screen with your fingers, or playing games, you may
experience occasional discomfort in your hands, neck, shoulders,
or other parts of your body. When using your device for extended
periods, hold the device with a relaxed grip, press the keys lightly,
and take frequent breaks. If you continue to have discomfort
during or after such use, stop use and see a physician.
•
If your device has a camera flash or light, do not use the flash or
light close to the eyes of people or pets. [122011]
169
Section 6: Warranty Information
Standard Limited Warranty
What is covered and for how long?
SAMSUNG ELECTRONICS AMERICA, INC. (“SAMSUNG”)
warrants that SAMSUNG’s devices and accessories
(“Products”) are free from defects in material and
workmanship under normal use and service for the period
commencing upon the date of purchase by the first
consumer purchaser and continuing for the following
specified period of time after that date:
What is not covered?
This Limited Warranty is conditioned upon proper use of
Product by Purchaser.
This Limited Warranty does not cover: (a) defects or damage
resulting from accident, misuse, abnormal use, abnormal
conditions, improper storage, exposure to liquid, moisture,
dampness, sand or dirt, neglect, or unusual physical,
electrical or electromechanical stress; (b) scratches, dents
and cosmetic damage, unless caused by SAMSUNG;
(c) defects or damage resulting from excessive force or use
of a metallic object when pressing on a touch screen;
(d) equipment that has the serial number or the
enhancement data code removed, defaced, damaged,
altered or made illegible; (e) ordinary wear and tear;
(f) defects or damage resulting from the use of Product in
conjunction or connection with accessories, products, or
ancillary/peripheral equipment not furnished or approved by
SAMSUNG; (g) defects or damage resulting from improper
testing, operation, maintenance, installation, service, or
adjustment not furnished or approved by SAMSUNG;
(h) defects or damage resulting from external causes such as
collision with an object, fire, flooding, dirt, windstorm,
lightning, earthquake, exposure to weather conditions, theft,
blown fuse, or improper use of any electrical source;
(i) defects or damage resulting from cellular signal reception
Tablet 1 Year
Batteries (Including
Internal Batteries)
1 Year
Case 90 Days
Other Tablet Accessories 1 Year
Warranty Information 170
or transmission, or viruses or other software problems
introduced into the Product; or (j) Product used or purchased
outside the United States. This Limited Warranty covers
batteries only if battery capacity falls below 80% of rated
capacity or the battery leaks, and this Limited Warranty does
not cover any battery if (i) the battery has been charged by a
battery charger not specified or approved by SAMSUNG for
charging the battery; (ii) any of the seals on the battery are
broken or show evidence of tampering; or (iii) the battery has
been used in equipment other than the SAMSUNG Tablet for
which it is specified.
What are SAMSUNG's obligations?
During the applicable warranty period, provided the Product
is returned in accordance with the terms of this Limited
Warranty, SAMSUNG will repair or replace the Product,
without charge to Purchaser, or at SAMSUNG's sole option,
refund the purchase price.
SAMSUNG may, at SAMSUNG's sole option, use rebuilt,
reconditioned, or new parts or components when repairing
any Product, or may replace Product with a rebuilt,
reconditioned or new Product. Repaired/replaced cases will
be warranted for a period of ninety (90) days. All other
repaired/replaced Products will be warranted for a period
equal to the remainder of the original Limited Warranty on
the original Product or for ninety (90) days, whichever is
longer. All replaced Products, parts, components, boards and
equipment shall become the property of SAMSUNG. This
Limited Warranty is extended to the Purchaser and is not
transferable or assignable to any other person or entity.
What must you do to obtain warranty service?
To obtain service under this Limited Warranty, Purchaser
must return the Product to an authorized Tablet service
facility in an adequate container for shipping, accompanied
by the sales receipt or comparable proof of sale showing the
original date of purchase, the serial number of the Product
and the seller's name and address.
To obtain assistance on where to deliver the Product, please
call SAMSUNG Customer Care at 1-800-SAMSUNG. If
SAMSUNG determines that any Product is not covered by this
Limited Warranty, Purchaser must pay all parts, shipping,
and labor charges for the repair or return of such Product.
Purchaser should keep a separate backup copy of any
contents of the Product before delivering the Product to
SAMSUNG for warranty service, as some or all of the
contents may be deleted or reformatted during the course of
warranty service.
171
What are the limits on SAMSUNG's liability?
THIS LIMITED WARRANTY SETS OUT THE FULL EXTENT OF
SAMSUNG'S RESPONSIBILITIES, AND THE EXCLUSIVE
REMEDY REGARDING THE PRODUCTS. ALL IMPLIED
WARRANTIES, INCLUDING WITHOUT LIMITATION, IMPLIED
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE, ARE LIMITED TO THE DURATION OF
THIS LIMITED WARRANTY.
IN NO EVENT SHALL SAMSUNG BE LIABLE FOR DAMAGES IN
EXCESS OF THE PURCHASE PRICE OF THE PRODUCT OR FOR,
WITHOUT LIMITATION, COMMERCIAL LOSS OF ANY SORT;
LOSS OF USE, TIME, DATA, REPUTATION, OPPORTUNITY,
GOODWILL, PROFITS OR SAVINGS; INCONVENIENCE;
INCIDENTAL, SPECIAL, CONSEQUENTIAL OR PUNITIVE
DAMAGES; OR DAMAGES ARISING FROM THE USE OR
INABILITY TO USE THE PRODUCT. SOME STATES AND
JURISDICTIONS DO NOT ALLOW LIMITATIONS ON HOW LONG
AN IMPLIED WARRANTY LASTS, OR THE DISCLAIMER OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES,
SO THE ABOVE LIMITATIONS AND DISCLAIMERS MAY NOT
APPLY TO YOU.
SAMSUNG MAKES NO WARRANTIES OR REPRESENTATIONS,
EXPRESS OR IMPLIED, STATUTORY OR OTHERWISE, AS TO
THE QUALITY, CAPABILITIES, OPERATIONS, PERFORMANCE
OR SUITABILITY OF ANY THIRD-PARTY SOFTWARE OR
EQUIPMENT USED IN CONJUNCTION WITH THE PRODUCT, OR
THE ABILITY TO INTEGRATE ANY SUCH SOFTWARE OR
EQUIPMENT WITH THE PRODUCT, WHETHER SUCH
THIRD-PARTY SOFTWARE OR EQUIPMENT IS INCLUDED WITH
THE PRODUCT DISTRIBUTED BY SAMSUNG OR OTHERWISE.
RESPONSIBILITY FOR THE QUALITY, CAPABILITIES,
OPERATIONS, PERFORMANCE AND SUITABILITY OF ANY
SUCH THIRD-PARTY SOFTWARE OR EQUIPMENT RESTS
SOLELY WITH THE PURCHASER AND THE DIRECT VENDOR,
OWNER OR SUPPLIER OF SUCH THIRD-PARTY SOFTWARE OR
EQUIPMENT.
Nothing in the Product instructions or information shall be
construed to create an express warranty of any kind with
respect to the Products. No agent, employee, dealer,
representative or reseller is authorized to modify or extend
this Limited Warranty or to make binding representations or
claims, whether in advertising, presentations or otherwise,
on behalf of SAMSUNG regarding the Products or this Limited
Warranty.
Warranty Information 172
This Limited Warranty gives you specific legal rights, and you
may also have other rights that vary from state to state.
What is the procedure for resolving disputes?
ALL DISPUTES WITH SAMSUNG ARISING IN ANY WAY FROM
THIS LIMITED WARRANTY OR THE SALE, CONDITION OR
PERFORMANCE OF THE PRODUCTS SHALL BE RESOLVED
EXCLUSIVELY THROUGH FINAL AND BINDING ARBITRATION,
AND NOT BY A COURT OR JURY.
Any such dispute shall not be combined or consolidated with
a dispute involving any other person's or entity's Product or
claim, and specifically, without limitation of the foregoing,
shall not under any circumstances proceed as part of a class
action. The arbitration shall be conducted before a single
arbitrator, whose award may not exceed, in form or amount,
the relief allowed by the applicable law. The arbitration shall
be conducted according to the American Arbitration
Association (AAA) Commercial Arbitration Rules applicable to
consumer disputes. This arbitration provision is entered
pursuant to the Federal Arbitration Act. The laws of the State
of Texas, without reference to its choice of laws principles,
shall govern the interpretation of the Limited Warranty and all
disputes that are subject to this arbitration provision. The
arbitrator shall decide all issues of interpretation and
application of this arbitration provision and the Limited
Warranty.
For any arbitration in which your total damage claims,
exclusive of attorney fees and expert witness fees, are
$5,000.00 or less (“Small Claim”), the arbitrator may, if you
prevail, award your reasonable attorney fees, expert witness
fees and costs as part of any award, but may not grant
SAMSUNG its attorney fees, expert witness fees or costs
unless it is determined that the claim was brought in bad
faith. In a Small Claim case, you shall be required to pay no
more than half of the total administrative, facility and
arbitrator fees, or $50.00 of such fees, whichever is less, and
SAMSUNG shall pay the remainder of such fees.
Administrative, facility and arbitrator fees for arbitrations in
which your total damage claims, exclusive of attorney fees
and expert witness fees, exceed $5,000.00 (“Large Claim”)
shall be determined according to AAA rules. In a Large Claim
case, the arbitrator may grant to the prevailing party, or
apportion among the parties, reasonable attorney fees,
expert witness fees and costs. Judgment may be entered on
the arbitrator’s award in any court of competent jurisdiction.
173
This arbitration provision also applies to claims against
SAMSUNG’s employees, representatives and affiliates if any
such claim arises from the Product’s sale, condition or
performance.
You may opt out of this dispute resolution procedure by
providing notice to SAMSUNG no later than 30 calendar days
from the date of the first consumer purchaser’s purchase of the
Product. To opt out, you must send notice by e-mail to
optout@sta.samsung.com, with the subject line: “Arbitration
Opt Out.” You must include in the opt out e-mail (a) your name
and address; (b) the date on which the Product was purchased;
(c) the Product model name or model number; and (d) the IMEI
or MEID or Serial Number, as applicable, if you have it (the IMEI
or MEID or Serial Number can be found (i) on the Product box;
(ii) on the Product information screen, which can be found
under “Settings;” (iii) on a label on the back of the Product
beneath the battery, if the battery is removable; and (iv) on the
outside of the Product if the battery is not removable).
Alternatively, you may opt out by calling 1-888-987-4357 no
later than 30 calendar days from the date of the first consumer
purchaser’s purchase of the Product and providing the same
information. These are the only two forms of notice that will be
effective to opt out of this dispute resolution procedure. Opting
out of this dispute resolution procedure will not affect the
coverage of the Limited Warranty in any way, and you will
continue to enjoy the benefits of the Limited Warranty.
Severability
If any portion of this Limited Warranty is held to be illegal or
unenforceable, such partial illegality or unenforceability shall
not affect the enforceability of the remainder of the Limited
Warranty.
Precautions for Transfer and Disposal
If data stored on this device is deleted or reformatted using
the standard methods, the data only appears to be removed
on a superficial level, and it may be possible for someone to
retrieve and reuse the data by means of special software.
To avoid unintended information leaks and other problems of
this sort, it is recommended that the device be returned to
Samsung’s Customer Care Center for an Extended File
System (EFS) Clear which will eliminate all user memory and
return all settings to default settings. Please contact the
Samsung Customer Care Center
for details.
Warranty Information 174
Important!
Please provide warranty information (proof of
purchase) to Samsung’s Customer Care Center in
order to provide this service at no charge. If the
warranty has expired on the device, charges may
apply.
Samsung Electronics America, Inc.
85 Challenger Road
Ridgefield Park, New Jersey 07660
Phone: 1-800-SAMSUNG
No reproduction in whole or in part allowed without prior
written approval. Specifications and availability subject to
change without notice. [111611]
End User License Agreement for
Software
IMPORTANT. READ CAREFULLY: This End User License
Agreement ("EULA") is a legal agreement between you
(either an individual or a single entity) and Samsung
Electronics Co., Ltd. ("Samsung") for software, owned by
Samsung and its affiliated companies and its third party
suppliers and licensors, that accompanies this EULA, which
includes computer software and may include associated
media, printed materials, "online" or electronic
documentation in connection with your use of this device
("Software").
This device requires the use of preloaded software in its
normal operation. BY USING THE DEVICE OR ITS PRELOADED
SOFTWARE, YOU ACCEPT THE TERMS OF THIS EULA. IF YOU
DO NOT ACCEPT THESE TERMS, DO NOT USE THE DEVICE OR
THE SOFTWARE.
1.
GRANT OF LICENSE
. Samsung grants you the following
rights provided that you comply with all terms and conditions
of this EULA: You may install, use, access, display and run
one copy of the Software on the local hard disk(s) or other
permanent storage media of one computer and use the
Software on a single computer or a mobile device at a time,
and you may not make the Software available over a network
where it could be used by multiple computers at the same
time. You may make one copy of the Software in machine
readable form for backup purposes only; provided that the
backup copy must include all copyright or other proprietary
notices contained on the original.
175
Certain items of the Software may be subject to open source
licenses. The open source license provisions may override
some of the terms of this EULA. We make the applicable
open source licenses available to you on the Legal Notices
section of the Settings menu of your device.
2.
RESERVATION OF RIGHTS AND OWNERSHIP
. Samsung
reserves all rights not expressly granted to you in this EULA.
The Software is protected by copyright and other intellectual
property laws and treaties. Samsung or its suppliers own the
title, copyright and other intellectual property rights in the
Software. The Software is licensed, not sold.
3.
LIMITATIONS ON END USER RIGHTS
. You may not reverse
engineer, decompile, disassemble, or otherwise attempt to
discover the source code or algorithms of, the Software
(except and only to the extent that such activity is expressly
permitted by applicable law not withstanding this limitation),
or modify, or disable any features of, the Software, or create
derivative works based on the Software. You may not rent,
lease, lend, sublicense or provide commercial hosting
services with the Software.
4.
CONSENT TO USE OF DATA
. You agree that Samsung and its
affiliates may collect and use technical information gathered
as part of the product support services related to the
Software provided to you, if any, such as IMEI (your device’s
unique identification number), device number, model name,
customer code, access recording, your device’s current SW
version, MCC (Mobile Country Code), MNC (Mobile Network
Code). Samsung and its affiliates may use this information
solely to improve their products or to provide customized
services or technologies to you and will not disclose this
information in a form that personally identifies you. At all
times your information will be treated in accordance with
Samsung’s Privacy Policy, which can be viewed at:
http://account.samsung.com/membership/pp
.
5.
SOFTWARE UPDATES
. Samsung may provide to you or
make available to you updates, upgrades, supplements and
add-on components (if any) of the Software, including bug
fixes, service upgrades (parts or whole), products or devices,
and updates and enhancements to any software previously
installed (including entirely new versions), (collectively
“Update”) after the date you obtain your initial copy of the
Software to improve the Software and ultimately enhance
your user experience with your device. This EULA applies to
all and any component of the Update that Samsung may
provide to you or make available to you after the date you
obtain your initial copy of the Software, unless we provide
other terms along with such Update. To use Software
Warranty Information 176
provided through Update, you must first be licensed for the
Software identified by Samsung as eligible for the Update.
After the Update, you may no longer use the Software that
formed the basis for your Update eligibility. The updated
Software version may add new functions and, in some
limited cases, may delete existing functions.
While the Update will be generally available, in some limited
circumstances, the Software updates will only be offered by
your network carrier, and such Software updates will be
governed by your contractual relationship with your network
carrier.
With the “Automatic Update” function enabled (as in the
default setting in the System Update menu in the Setting),
your device downloads some Updates automatically from
time to time. Your device will, however, ask for your consent
before installing any Update If you choose to disable the
“Automatic Update” function, then you can check the
availability of new Updates by clicking on the “Check
Update” menu in the Setting. We recommend that you check
availability of any new Updates periodically for optimal use of
your device. If you want to avoid any use of network data for
the Update downloads, then you should choose the “Wi-Fi
Only” option in the Setting. (Regardless of the option you
choose, the “Automatic Update” function downloads Updates
only through Wi-Fi connection.)
6. Some features of the Software may require your device to
have access to the internet and may be subject to
restrictions imposed by your network or internet provider.
Unless your device is connected to the internet through Wi-Fi
connection, the Software will access through your mobile
network, which may result in additional charges depending
on your payment plan. In addition, your enjoyment of some
features of the Software may be affected by the suitability
and performance of your device hardware or data access.
7.
SOFTWARE TRANSFER
. You may not transfer this EULA or
the rights to the Software granted herein to any third party
unless it is in connection with the sale of the mobile device
which the Software accompanied. In such event, the transfer
must include all of the Software (including all component
parts, the media and printed materials, any upgrades, this
EULA) and you may not retain any copies of the Software.
The transfer may not be an indirect transfer, such as a
consignment. Prior to the transfer, the end user receiving the
Software must agree to all the EULA terms.
177
8.
EXPORT RESTRICTIONS
. You acknowledge that the
Software is subject to export restrictions of various countries.
You agree to comply with all applicable international and
national laws that apply to the Software, including all the
applicable export restriction laws and regulations.
9.
TERMINATION
. This EULA is effective until terminated. Your
rights under this License will terminate automatically without
notice from Samsung if you fail to comply with any of the
terms and conditions of this EULA. Upon termination of this
EULA, you must cease all use of the Software and destroy all
copies, full or partial, of the Software.
10.
DISCLAIMER OF WARRANTY
. UNLESS SEPARATELY STATED
IN A WRITTEN EXPRESS LIMITED WARRANTY
ACCOMPANYING YOUR DEVICE, ALL SOFTWARE PROVIDED
BY SAMSUNG WITH THIS MOBILE DEVICE (WHETHER
INCLUDED WITH THE DEVICE, DOWNLOADED, OR
OTHERWISE OBTAINED) IS PROVIDED "AS IS" AND ON AN
"AS AVAILABLE" BASIS, WITHOUT WARRANTIES OF ANY KIND
FROM SAMSUNG, EITHER EXPRESS OR IMPLIED. TO THE
FULLEST EXTENT POSSIBLE PURSUANT TO APPLICABLE
LAW, SAMSUNG DISCLAIMS ALL WARRANTIES EXPRESS,
IMPLIED, OR STATUTORY, INCLUDING, BUT NOT LIMITED TO,
IMPLIED WARRANTIES OF MERCHANTABILITY, SATISFACTORY
QUALITY OR WORKMANLIKE EFFORT, FITNESS FOR A
PARTICULAR PURPOSE, RELIABILITY OR AVAILABILITY,
ACCURACY, LACK OF VIRUSES, QUIET ENJOYMENT, NON
INFRINGEMENT OF THIRD PARTY RIGHTS OR OTHER
VIOLATION OF RIGHTS. SOME JURISDICTIONS DO NOT
ALLOW EXCLUSIONS OR LIMITATIONS OF IMPLIED
WARRANTIES, SO THE ABOVE EXCLUSIONS OR LIMITATIONS
MAY NOT APPLY TO YOU. NO ADVICE OR INFORMATION,
WHETHER ORAL OR WRITTEN, OBTAINED BY YOU FROM
SAMSUNG OR ITS AFFILIATES SHALL BE DEEMED TO ALTER
THIS DISCLAIMER BY SAMSUNG OF WARRANTY REGARDING
THE SOFTWARE, OR TO CREATE ANY WARRANTY OF ANY
SORT FROM SAMSUNG.
11.
THIRD-PARTY APPLICATIONS
. Certain third party
applications may be included with, or downloaded to this
mobile device. Samsung makes no representations
whatsoever about any of these applications. Since Samsung
has no control over such applications, you acknowledge and
agree that Samsung is not responsible for the availability of
such applications and is not responsible or liable for any
content, advertising, products, services, or other materials
on or available from such applications. You expressly
acknowledge and agree that use of third party applications is
at your sole risk and that the entire risk of unsatisfactory
quality, performance, accuracy and effort is with you. It is up
Warranty Information 178
to you to take precautions to ensure that whatever you select
to use is free of such items as viruses, worms, Trojan horses,
and other items of a destructive nature. References on this
mobile device to any names, marks, products, or services of
any third-parties are provided solely as a convenience to you,
and do not constitute or imply an endorsement, sponsorship,
or recommendation of, or affiliation with the third party or its
products and services. You agree that Samsung shall not be
responsible or liable, directly or indirectly, for any damage or
loss, including but not limited to any damage to the mobile
device or loss of data, caused or alleged to be caused by, or
in connection with, use of or reliance on any such third party
content, products, or services available on or through any
such application. You acknowledge and agree that the use of
any third-party application is governed by such third party
application provider's Terms of Use, License Agreement,
Privacy Policy, or other such agreement and that any
information or personal data you provide, whether knowingly
or unknowingly, to such third-party application provider, will
be subject to such third party application provider's privacy
policy, if such a policy exists. SAMSUNG DISCLAIMS ANY
RESPONSIBILITY FOR ANY DISCLOSURE OF INFORMATION OR
ANY OTHER PRACTICES OF ANY THIRD PARTY APPLICATION
PROVIDER. SAMSUNG EXPRESSLY DISCLAIMS ANY
WARRANTY REGARDING WHETHER YOUR PERSONAL
INFORMATION IS CAPTURED BY ANY THIRD PARTY
APPLICATION PROVIDER OR THE USE TO WHICH SUCH
PERSONAL INFORMATION MAY BE PUT BY SUCH THIRD
PARTY APPLICATION PROVIDER.
12.
SAMSUNG APPLICATIONS
. Certain Samsung applications
and services may be included with, or downloaded to, this
mobile device. Many of them require Samsung Services
membership registration (“Samsung Account”), and your
rights and obligations will be set forth in separate Samsung
Account terms and conditions and privacy policies. There are
non-Samsung Account applications and services that require
your consent to their separate terms and conditions and
privacy policies. You expressly acknowledge and agree that
your use of such applications and services will be subject to
the applicable terms and conditions and privacy policies.
13.
LIMITATION OF LIABILITY
. SAMSUNG WILL NOT BE LIABLE
FOR ANY DAMAGES OF ANY KIND ARISING OUT OF OR
RELATING TO THE USE OR THE INABILITY TO USE THE
SOFTWARE OR ANY THIRD PARTY APPLICATION, ITS
CONTENT OR FUNCTIONALITY, INCLUDING BUT NOT LIMITED
TO DAMAGES CAUSED BY OR RELATED TO ERRORS,
OMISSIONS, INTERRUPTIONS, DEFECTS, DELAY IN
OPERATION OR TRANSMISSION, COMPUTER VIRUS, FAILURE
179
TO CONNECT, NETWORK CHARGES, IN-APP PURCHASES,
AND ALL OTHER DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
EXEMPLARY, OR CONSEQUENTIAL DAMAGES EVEN IF
SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. SOME JURISDICTIONS DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSIONS OR
LIMITATIONS MAY NOT APPLY TO YOU. NOTWITHSTANDING
THE FOREGOING, SAMSUNG ELECTRONIC CO.'S TOTAL
LIABILITY TO YOU FOR ALL LOSSES, DAMAGES, CAUSES OF
ACTION, INCLUDING BUT NOT LIMITED TO THOSE BASED ON
CONTRACT, TORT, OR OTHERWISE, ARISING OUT OF YOUR
USE OF THE SOFTWARE OR THIRD PARTY APPLICATIONS ON
THIS MOBILE DEVICE, OR ANY OTHER PROVISION OF THIS
EULA, SHALL NOT EXCEED THE AMOUNT PURCHASER PAID
SPECIFICALLY FOR THIS MOBILE DEVICE OR ANY SUCH
THIRD PARTY APPLICATION THAT WAS INCLUDED WITH THIS
MOBILE DEVICE. THE FOREGOING LIMITATIONS,
EXCLUSIONS, AND DISCLAIMERS (INCLUDING SECTIONS 10,
11, 12 AND 13) SHALL APPLY TO THE MAXIMUM EXTENT
PERMITTED BY APPLICABLE LAW, EVEN IF ANY REMEDY
FAILS ITS ESSENTIAL PURPOSE.
14.
U.S. GOVERNMENT END USERS RESTRICTED RIGHTS
. The
Software is licensed only with "restricted rights" and as
"commercial items" consisting of "commercial software"
and "commercial software documentation" with only those
rights as are granted to all other end users pursuant to the
terms and conditions herein. All Products are provided only
with "restricted rights" with only those rights as are granted
to all other end users pursuant to the terms and conditions
herein. All Software and Products are provided subject to
Federal Acquisition Regulation (FAR) 52.227.19.
15.
APPLICABLE LAW
. This EULA is governed by the laws of
the jurisdiction where you are a resident or, if a resident of
the United States, by the laws of the state of Texas, without
regard to its conflict of law provisions. This EULA shall not be
governed by the UN Convention on Contracts for the
International Sale of Goods, the application of which is
expressly excluded.
16.
DISPUTE RESOLUTION
.
(a) Non-United States residents. If a dispute, controversy or
difference arising in any way from this EULA or your use of
the Software is not amicably settled, it shall be subject to the
non-exclusive jurisdiction of the courts of the jurisdiction
Warranty Information 180
where you are a resident. Notwithstanding the foregoing,
Samsung may apply for injunctive remedies (or an equivalent
type of urgent legal relief) in any jurisdiction.
(b) United States residents. ALL DISPUTES WITH SAMSUNG
ARISING IN ANY WAY FROM THIS EULA OR YOUR USE OF THE
SOFTWARE SHALL BE RESOLVED EXCLUSIVELY THROUGH
FINAL AND BINDING ARBITRATION, AND NOT BY A COURT OR
JURY. Any such dispute shall not be combined or
consolidated with any other person’s or entity’s claim or
dispute, and specifically, without limitation of the foregoing,
shall not under any circumstances proceed as part of a class
action. The arbitration shall be conducted before a single
arbitrator, whose award may not exceed, in form or amount,
the relief allowed by the applicable law. The arbitration shall
be conducted according to the American Arbitration
Association (AAA) Commercial Arbitration Rules applicable to
consumer disputes. This arbitration provision is entered
pursuant to the Federal Arbitration Act. The laws of the State
of Texas, without reference to its choice of laws principles,
shall govern the interpretation of the EULA and all disputes
that are subject to this arbitration provision. The arbitrator
shall decide all issues of interpretation and application of this
arbitration provision and the EULA. For any arbitration in
which your total damage claims, exclusive of attorney fees
and expert witness fees, are $5,000.00 or less ("Small
Claim"), the arbitrator may, if you prevail, award your
reasonable attorney fees, expert witness fees and costs as
part of any award, but may not grant Samsung its attorney
fees, expert witness fees or costs unless it is determined that
the claim was brought in bad faith. In a Small Claim case,
you shall be required to pay no more than half of the total
administrative, facility and arbitrator fees, or $50.00 of such
fees, whichever is less, and Samsung shall pay the
remainder of such fees. Administrative, facility and arbitrator
fees for arbitrations in which your total damage claims,
exclusive of attorney fees and expert witness fees, exceed
$5,000.00 ("Large Claim") shall be determined according to
AAA rules. In a Large Claim case, the arbitrator may grant to
the prevailing party, or apportion among the parties,
reasonable attorney fees, expert witness fees and costs.
Judgment may be entered on the arbitrator's award in any
court of competent jurisdiction. This arbitration provision also
applies to claims against Samsung’s employees,
representatives and affiliates if any such claim arises from
the licensing or use of the Software. You may opt out of this
dispute resolution procedure by providing notice to Samsung
no later than 30 calendar days from the date of the first
consumer purchaser’s purchase of this device. To opt out,
181
you must send notice by e-mail to
optout@sta.samsung.com, with the subject line: "Arbitration
Opt Out." You must include in the opt out e-mail (a) your
name and address; (b) the date on which the device was
purchased; (c) the device model name or model number; and
(d) the IMEI or MEID or Serial Number, as applicable, if you
have it (the IMEI or MEID or Serial Number can be found (i) on
the device box; (ii) on the device information screen, which
can be found under "Settings;" (iii) on a label on the back of
the device beneath the battery, if the battery is removable;
and (iv) on the outside of the device if the battery is not
removable). Alternatively, you may opt out by calling
1-888-987-4357 no later than 30 calendar days from the
date of the first consumer purchaser's purchase of the
device and providing the same information. These are the
only two forms of notice that will be effective to opt out of
this dispute resolution procedure. Opting out of this dispute
resolution procedure will not affect your use of the device or
its preloaded Software, and you will continue to enjoy the
benefits of this license.
17.
ENTIRE AGREEMENT; SEVERABILITY
. This EULA is the
entire agreement between you and Samsung relating to the
Software and supersedes all prior or contemporaneous oral
or written communications, proposals and representations
with respect to the Software or any other subject matter
covered by this EULA. If any provision of this EULA is held to
be void, invalid, unenforceable or illegal, the other provisions
shall continue in full force and effect. [050113]
182
Index
A
Accounts
setting up 56
Alarm
Turning Off 105
Android keyboard
configuring 51
App Shortcuts 46
Application Bar 39
Application Manager settings
downloaded apps 132
running services 133
Applications 49
downloading new 116
B
Back button 18, 38
Battery
charging 6
indicator 6
installing and removing 6
Battery Use & Safety 157
Bluetooth
pairing with a device 97
settings 122
turning on or off 96
C
Camcorder
recording video 83
settings 84
Camera
settings 81
taking photos 80
Care and Maintenance 161
Children and Cell Phones 153
Contacts
creating 57
display options 58
exporting and importing 60
groups 61
joining 59
linking 59
namecards 60
separating joined 59
setting a photo as contact icon 91
starred contacts 63
updating 58
D
Display / Touch-Screen 159
Display settings
brightness 129
font style and size 130
timeout 129
DivX®
registration code 148
Do cell phones pose a health
hazard? 149
Downloads
managing 98
Dropbox
Desktop Application
Download 111
E
Exposure to Radio Frequency (RF)
Signals 149
183
F
FCC Notice and Cautions 166
Firmware Update 100
G
Gallery 88
sharing photos and video 92
viewing photos and video 90
Gmail
account settings 65
composing and sending 65
refreshing your account 65
setting up your account 64
Google
Gmail 64
Maps 68
Play Store 116
Search 67
YouTube 70, 118
Google Messenger 66
Google Play 116
Google Search 112
Google+ 68
GPS 160
Groups
creating 61
H
Health and Safety Information 149
Home screen 17, 35
adding widgets 19, 45
folders 47
primary shortcuts 19, 44
wallpaper 48
I
Icons
Status Bar 43
K
Kies 100
via Wi-Fi 126
L
Language and input settings
select language 138
Location Services Settings 134
M
Maps 68, 113
Memory Card
formatting 101
installing 8
removing 9
Messages
Gmail 64
types 64
Messenger 66
Music
creating a playlist 75
Music Player 74
Music Player 74
N
Namecards
sending 60
Navigation 18, 38
command keys 19, 44
primary Shortcuts 19, 44
screen 19, 39
Nearby Devices
settings 126
status 43
Notification Panel 40
Notifications 40
184
O
Operating Environment 164
Other Important Safety
Information 166
P
Pairing with Bluetooth 97
Photo ID
setting 91
Photos
Gallery 88
sharing 92
taking 80
Play Music app 71
Play Store 116
Playlists
creating 75
Powering On and Off 9
Predictive Text 139
Privacy settings
factory data reset 141
R
Reducing Exposure
Hands-Free Kits and Other
Accessories 152
Reset
factory data 141
Responsible Listening 162
S
Samsung Account
signing in 143
Samsung Keyboard
entering text 51
Samsung Kies 100
Samsung Mobile Products and
Recycling 159
Securing your device
locking and unlocking 12
Security
locking and unlocking 12
locking your device 13
Security settings
device administration 136
passwords 136
trusted credentials 137
Settings 27, 119
developer options 147
Location Services 134
Shortcuts 46
Smart Practices While Driving 156
Snooze 105
Software Update 148
Sound settings
notifications 128
volume 128
Specific Absorption Rate (SAR)
Certification Information 154
Standard Limited Warranty 169
Status Bar 43
T
Text
entering 50
input methods 50
Turning Your Device On and Off 9
U
UL Certified Travel Charger 159
Updating Applications 103
USB connections
as a mass storage device 102
185
USB settings
as a mass storage device 102
mass storage device 102
Windows Media Player 102
V
Videos
Gallery 88
recording 83
sharing 92
Voice Search 68, 118
Volume Key 16
W
Warranty Information 169
Widgets 45
Wi-Fi
adding a connection manually 94
direct settings 121
scanning and connecting 94
settings 119
turning on or off 93, 119
WiFi (see Wi-Fi) 93
Wi-Fi Direct 42, 95
Windows Media Player
synchronizing with 102
Wireless Networking
Bluetooth 96
Wi-Fi 93
WPS PIN
Pairing 121
WPS Push Button
Connect 121
Pairing 121
X
XT9 Predictive Text 139
Y
YouTube 70, 118

Navigation menu
