About the User’s Guides

Provides information you need for setting up your machine and installing the supplied software.

It also provides all of the detailed instructions for using your machine as a printer, a scanner

and a copier and information for maintaining and troubleshooting the machine.

Also, provides the basic description about using the multi-function application. Samsung

SmarThru allows you to scan and edit images, and to scan for copying, and sending an e-mail

on your computer.

This manual is provided for information purposes only. All information included herein is

subject to change without notice. Samsung Electronics is not responsible for any changes,

direct or indirect, arising from or related to the use of this manual.

© 2004 Samsung Electronics Co., Ltd. All rights reserved.

• SCX-4100 and Samsung logo are trademarks of Samsung Electronics Co., Ltd.

• PCL and PCL 6 are trademarks of Hewlett-Packard Company.

• Microsoft, Windows, Windows 9x, Window Me, Windows 2000, Windows NT 4.0

and Windows XP are registered trademarks of Microsoft Corporation.

• PostScript 3, Adobe Acrobat Reader, Adobe PhotoDeluxe and Adobe Photoshop are

trademarks of Adobe System, Inc.

• All other brand or product names are trademarks of their respective companies or

organizations.

2

CONTENTS

Chapter 1:

GETTING STARTED

Unpacking .................................................................... 1.2

Selecting a Location ................................................. 1.3

Understanding the Component Location ........................... 1.4

Front View .............................................................. 1.4

Rear View ............................................................... 1.4

Control Panel Functions ............................................ 1.5

Installing the Toner Cartridge ........................................ 1.6

Loading Paper .............................................................. 1.8

Changing the Paper Size in the Paper Tray .................. 1.9

Making Connections .................................................... 1.11

Turning the Machine On ............................................... 1.13

About Samsung Software ............................................. 1.14

Printer Driver Features ........................................... 1.15

Installing Samsung Software in Windows ....................... 1.16

System Requirements ............................................ 1.16

Installing Samsung Software ................................... 1.17

Installing Samsung SmarThru ................................. 1.20

Repairing Software ...................................................... 1.22

Removing Software ..................................................... 1.23

Uninstalling the MFP Driver ..................................... 1.23

Uninstalling Samsung SmarThru .............................. 1.24

Changing the Display Language .................................... 1.25

Setting the Paper Size and Type ................................... 1.26

Using the Save Modes ................................................. 1.27

Toner Save Mode .................................................. 1.27

Power Save Mode .................................................. 1.27

Chapter 2:

PAPER HANDLING

Selecting Print Materials ................................................. 2.2

Type, Input Sources and Capacities ........................... 2.2

Guidelines for Paper and Special Materials .................. 2.3

Selecting an Output Location .......................................... 2.4

Printing to the Front Output Tray (Face down) ............. 2.5

Printing to the Rear Output Slot (Face up) .................. 2.6

Loading Paper in the Paper Tray ...................................... 2.8

Using the Manual Feeder ................................................ 2.9

Setting the Paper Type and Size for the Manual Feeder 2.11

3

Chapter 3:

PRINTING

Printing a Document in Windows ..................................... 3.2

Canceling a Print Job ................................................ 3.5

Using a Favorite Setting ........................................... 3.6

Using Help .............................................................. 3.6

Setting Paper Properties ................................................ 3.7

Setting Graphic Properties .............................................. 3.8

Printing Multiple Pages on One Sheet of the Paper ........... 3.10

Printing a Reduced or Enlarged Document ...................... 3.12

Fitting Your Document to a Selected Paper Size .............. 3.13

Printing Posters .......................................................... 3.14

Using Watermarks ...................................................... 3.15

Using an Existing Watermark .................................. 3.15

Creating a Watermark ............................................ 3.16

Editing a Watermark .............................................. 3.17

Deleting a Watermark ............................................ 3.17

Using Overlays ........................................................... 3.18

What is an Overlay? ............................................... 3.18

Creating a New Page Overlay .................................. 3.18

Using a Page Overlay ............................................. 3.20

Deleting a Page Overlay ......................................... 3.21

Setting Up the Locally Shared Printer ............................. 3.22

In Windows 9x/Me ................................................. 3.22

In Windows NT 4.0/2000/XP ................................... 3.23

Chapter 4:

COPYING

Loading Paper for Copying ............................................. 4.2

Preparing a Document ................................................... 4.2

Making a Copy .............................................................. 4.3

Setting Copy Options ..................................................... 4.5

Darkness ................................................................ 4.5

Number of Copies .................................................... 4.5

Reduced/Enlarged Copying ....................................... 4.6

Original Type .......................................................... 4.7

Using Special Copy Features ........................................... 4.8

Clone Copying ......................................................... 4.8

Auto Fit Copying ...................................................... 4.9

2 sided in 1 page Copying ....................................... 4.10

2-up Copying ........................................................ 4.11

Poster Copying ...................................................... 4.12

Changing the Default Settings ...................................... 4.13

Setting the Time Out Option ......................................... 4.14

4

Chapter 5:

SCANNING

Scanning Basics ............................................................ 5.2

Scanning Using Samsung SmarThru ................................ 5.2

To use on-line help file ............................................. 5.5

Scanning Process with TWAIN-enabled Software ............... 5.6

Chapter 6:

USING YOUR PRINTER IN LINUX

Getting Started ............................................................. 6.2

Installing the MFP Driver ................................................ 6.3

System Requirements .............................................. 6.3

Installing the MFP Driver .......................................... 6.4

Uninstalling the MFP Driver ....................................... 6.6

Using the MFP Configurator ............................................ 6.7

Opening the MFP Configurator ................................... 6.7

Printers Configuration .............................................. 6.8

Scanners Configuration ............................................ 6.9

MFP Ports Configuration ......................................... 6.10

Configuring Printer Properties ....................................... 6.11

Printing a Document .................................................... 6.12

Printing from Applications ....................................... 6.12

Printing Files ......................................................... 6.13

Scanning a Document .................................................. 6.14

Using the Image Editor .......................................... 6.18

Chapter 7:

MAINTENANCE

Printing the System Data List ......................................... 7.2

Clearing the Memory ..................................................... 7.2

Cleaning Your Machine ................................................... 7.3

Cleaning the Outside ................................................ 7.3

Cleaning the Inside .................................................. 7.3

Cleaning the Document Glass .................................... 7.5

Maintaining the Toner Cartridge ...................................... 7.6

Redistributing Toner ................................................ 7.7

Replacing the Toner Cartridge ................................... 7.8

Cleaning the Drum .................................................. 7.9

Consumables and Replacement Parts ............................... 7.9

Using the Remote Control Panel .................................... 7.10

5

Chapter 8:

TROUBLESHOOTING

Clearing Paper Jams ...................................................... 8.2

In the Paper Tray .................................................... 8.2

In the Paper Exit Area .............................................. 8.3

In the Fuser Area or Around the Toner Cartridge .......... 8.5

In the Manual Feeder ............................................... 8.6

Tips for Avoiding Paper Jams ..................................... 8.6

Clearing LCD Error Messages .......................................... 8.8

Solving Problems .......................................................... 8.9

Paper Feeding Problems ........................................... 8.9

Printing Problems .................................................. 8.10

Printing Quality Problems ....................................... 8.13

Copying Problems .................................................. 8.18

Scanning Problems ................................................ 8.19

Common Linux Problems ........................................ 8.20

Appendix A:

SPECIFICATIONS

General Specifications ................................................... A.2

Scanner and Copier Specifications ................................... A.3

Printer Specifications ..................................................... A.4

Paper Specifications ...................................................... A.5

Overview ................................................................ A.5

Supported Sizes of Paper .......................................... A.6

Guidelines for Using Paper ........................................ A.7

Paper Specifications ................................................. A.8

Paper Output Capacity ............................................. A.8

Paper Storage Environment ...................................... A.9

Envelopes ............................................................. A.10

Labels .................................................................. A.12

Transparencies ...................................................... A.12

6

Important Precautions and Safety Information

When using this machine, these basic safety precautions should always be followed

to reduce risk of fire, electric shock, and injury to people:

1. Read and understand all instructions.

2. Use common sense whenever operating electrical appliances.

3. Follow all warnings and instructions marked on the machine and in the literature

accompanying the machine.

4. If an operating instruction appears to conflict with safety information, heed the

safety information. You may have misunderstood the operating instruction. If you

cannot resolve the conflict, contact your sales or service representative for

assistance.

5. Unplug the machine from the AC wall socket before cleaning. Do not use liquid or

aerosol cleaners. Use only a damp cloth for cleaning.

6. Do not place the machine on an unstable cart, stand or table. It may fall, causing

serious damage.

7. Your machine should never be placed on, near or over a radiator, heater, air

conditioner or ventilation duct.

8. Do not allow anything to rest on the power cable. Do not locate your machine

where the cords will be abused by persons walking on them.

9. Do not overload wall outlets and extension cords. This can diminish performance,

and may result in the risk of fire or electric shock.

10. Do not allow pets to chew on the AC power, or PC interface cords.

11. Never push objects of any kind into the machine through case or cabinet

openings. They may touch dangerous voltage points, creating a risk of fire or

shock. Never spill liquid of any kind onto or into the machine.

12. You machine may have a heavy cover for optimal pressure on the document for

the best scanning. In this case, replace the cover after placing document on the

scan glass, by holding and moving it down slowly until it seats on its location.

13. To reduce the risk of electric shock, do not disassemble the machine. Take it to

a qualified service technician when repair work is required. Opening or removing

covers may expose you to dangerous voltages or other risks. Incorrect

reassembly could cause electric shock when the unit is subsequently used.

7

14. Unplug the machine from the, PC and AC wall outlet, and refer servicing to

qualified service personnel under the following conditions:

• When any part of the power cord, plug, or connecting cable is damaged or

frayed.

• If liquid has been spilled into the machine.

• If the machine has been exposed to rain or water.

• If the machine does not operate properly after instructions have been followed.

• If the machine has been dropped, or the cabinet appears damaged.

• If the machine exhibits a sudden and distinct change in performance.

15. Adjust only those controls covered by the operating instructions. Improper

adjustment of other controls may result in damage, and may require extensive

work by a qualified service technician to restore the machine to normal operation.

16. Avoid using this machine during a lightning storm. There may be a remote risk

of electric shock from lightning. If possible, unplug the AC power cord for the

duration of the lightning storm.

17. If you print large amount of copies, the surface of the output tray may become

hot. Be careful not to touch the surface, and keep children away from the surface.

18. SAVE THESE INSTRUCTIONS.

8

Laser Safety Statement

The printer is certified in the U.S. to conform to the requirements of DHHS 21 CFR,

chapter 1 Subchapter J for Class I(1) laser products, and elsewhere is certified as a

Class I laser product conforming to the requirements of IEC 825.

Class I laser products are not considered to be hazardous. The laser system and

printer are designed so there is never any human access to laser radiation above a

Class I level during normal operation, user maintenance, or prescribed service

condition.

WARNING

Never operate or service the printer with the protective cover removed from Laser/

Scanner assembly. The reflected beam, although invisible, can damage your eyes.

When using this product, these basic safety precautions should always be followed to

reduce risk of fire, electric shock, and injury to persons:

9

Ozone Safety

During normal operation, this machine produces ozone.

The ozone produced does not present a hazard to the

operator. However, it is advisable that the machine be

operated in a well ventilated area.

If you need additional information about ozone, please

request your nearest Samsung dealer.

Power Saver

This machine contains advanced energy conservation

technology that reduces power consumption when it is not

in active use.

When the machine does not receive data for an extended

period of time, power consumption is automatically

lowered.

The energy star emblem does not represent EPA

endorsement of any machine or service.

Recycling

Please recycle or dispose of the packaging material for this

product in an environmentally responsible manner.

10

Radio Frequency Emissions

FCC Information to the User

This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates, uses, and can radiate radio frequency energy

and, if not installed and used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is no guarantee that

interference will not occur in a particular installation. If this equipment does cause

harmful interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct the

interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

• Consult the dealer or experienced radio/ TV technician for help.

C

AUTION

:

Change or modifications not expressly approved by the manufacturer

responsible for compliance could void the user's authority to operate the equipment.

Canadian Radio Interference Regulations

This digital apparatus does not exceed the Class B limits for radio noise emissions

from digital apparatus as set out in the interference-causing equipment standard

entitled “Digital Apparatus”, ICES-003 of the Industry and Science Canada.

Cet appareil numérique respecte les limites de bruits radioélectriques applicables aux

appareils numériques de Classe B prescrites dans la norme sur le matériel brouilleur:

“Appareils Numériques”, ICES-003 édictée par l’Industrie et Sciences Canada.

11

Declaration of Conformity (European Countries)

Approvals and Certifications

The CE marking applied to this product symbolizes Samsung

Electronics Co., Ltd. Declaration of Conformity with the following

applicable 93/68/EEC Directives of the European Union as of the

dates indicated:

January 1, 1995

: Council Directive 73/23/EEC Approximation of the laws of the

member states related to low voltage equipment.

January 1, 1996

: Council Directive 89/336/EEC (92/31/EEC), approximation of the

laws of the Member States related to electromagnetic compatibility.

March 9, 1999

: Council Directive 1999/5/EC on radio equipment and

telecommunications terminal equipment and the mutual recognition of their

conformity.

A full declaration, defining the relevant Directives and referenced standards can be

obtained from your Samsung Electronics Co., Ltd. representative.

EC Certification

Certification to 1999/5/EC Radio Equipment & Telecommunications

Terminal Equipment Directive (FAX)

This Samsung product has been self-certified by Samsung for pan-European single

terminal connection to the analogue public switched telephone network (PSTN) in

accordance with Directive 1999/5/EC. The product has been designed to work with

the national PSTNs and compatible PBXs of European countries.

In the event of problems, you should contact the Euro QA Lab of Samsung Electronics

Co., Ltd. in the first instance.

The product has been tested against TBR21 and/or TBR38. To assist in the use and

application of terminal equipment which complies with this standard, the European

Telecommunication Standards Institute (ETSI) has issued an advisory document (EG

201 121) which contains notes and additional requirements to ensure network

compatibility of TBR21 terminals. The product has been designed against, and is fully

compliant with, all of the relevant advisory notes contained in this document.

12

Replacing the Fitted Plug (for UK Only)

I

MPORTANT

The mains lead for this machine is fitted with a standard (BS 1363) 13 amp plug and

has a 13 amp fuse. When you change or examine the fuse, you must re-fit the correct

13 amp fuse. You then need to replace the fuse cover. If you have lost the fuse cover,

do not use the plug until you have another fuse cover.

Please contact the company from where the machine was purchased.

The 13 amp plug is the most widely used type in the UK and should be suitable.

However, some buildings (mainly old ones) do not have normal 13 amp plug sockets.

You need to buy a suitable plug adaptor. Do not remove the moulded plug.

W

ARNING

If you cut off the moulded plug, get rid of it straight away.

You cannot rewire the plug and you may receive an electric shock if you plug

it into a socket.

I

MPORTANT

WARNING

: You must earth this machine.

The wires in the mains lead have the following color code:

• Green and Yellow: Earth

• Blue: Neutral

• Brown: Live

If the wires in the mains lead do not match the colors marked in your plug, do the

following:

You must connect the green and yellow wire to the pin marked by the letter “E” or by

the safety `Earth symbol' or colored green and yellow or green.

You must connect the blue wire to the pin which is marked with the letter “N” or

colored black.

You must connect the brown wire to the pin which is marked with the letter “L” or

colored red.

You must have a 13 amp fuse in the plug, adaptor, or at the distribution board.

13

14

Differences Between British and American English

British English American English

Cancelling Canceling

Favourite Favorite

Colour Color

Colours Colors

Coloured Colored

Centre Center

Grey Gray

Greyscale Grayscale

Millimetres Millimeters

Discolour Discolor

Fibre Fiber

Emphasise Emphasize

Recognise Recognize

Organise Organize

Authorise Authorize

Customise Customize

Labelling Labeling

1GETTING STARTED

Thank you for purchasing this multifunctional product.

Your machine provides you with printing, copying, and

scanning functions!

This chapter gives you step-by-step instructions for

setting up your machine.

This chapter includes:

• Unpacking

• Understanding the Component Location

• Installing the Toner Cartridge

• Loading Paper

• Making Connections

• Turning the Machine On

Installing Software

• About Samsung Software

• Installing Samsung Software in Windows

•Repairing Software

• Removing Software

Setting Up the Machine System

• Changing the Display Language

• Setting the Paper Size and Type

• Using the Save Modes

G

ETTING

S

TARTED

1.2

Unpacking

Remove the machine and all accessories from the packing

carton. Make sure that the machine has been packed with the

following items. If there is a missing item, contact the retailer

where you bought the machine:

Remove the packing tape from the front, back and sides of the

machine.

Starter Toner Cartridge

*

*The 1,000 pages and 3,000 pages toner cartridges have different

shapes.

AC Power Cord

**

** The appearance of the power cord may differ according to your

country’s specifications.

Quick Install Guide CD-ROM

***

*** The CD-ROM contains the MFP driver, SmarThru software, the

user’s guides and the Adobe Acrobat Reader program. SmarThru

software provides the tools for scanning, copying, printing, and

many other facilities.

N

OTES

:

• The power cord must be plugged into a grounded power socket.

• Components may differ from one country to another.

Ta p e

G

ETTING

S

TARTED

1.3

1

Selecting a Location

Select a level, stable place with adequate space for air

circulation. Allow extra space for opening covers and trays.

The area should be well-ventilated and away from direct sunlight

or sources of heat, cold and humidity. Do not set the machine

close to the edge of your desk or table.

Clearance Space

•

Front

: 482.6 mm

(enough space so that the paper trays can be

removed)

•

Back

: 100 mm (enough space for ventilation)

•

Right

: 100 mm

•

Left

: 100 mm (enough space for ventilation)

G

ETTING

S

TARTED

1.4

Understanding the Component

Location

These are the main components of your machine:

Front View

Rear View

Front Output Tray

(Face down)

Control Panel

(see the page 1.5)

Manual

Feeder

Manual Feeder

Guides

Front Paper

Output

Extension

Toner Cartridge

Document Cover

Front Cover

Jam Cover

Paper Tray

Document Glass

Parallel Connector

USB Connector

Rear Cover

AC Power Cord Connector

Rear Output Slot

(Face up)

Power Switch

Paper Length Guide

G

ETTING

S

TARTED

1.5

1

Control Panel Functions

1

C

O

P

Y

Adjusts the brightness of the documents for

the current copy job.

Selects the number of copies.

2

Displays the current status and prompts

during an operation.

3

Scrolls through the options available for the

selected menu item.

Enters Menu mode and scrolls through the

menus available and sends you back to

Standby mode.

4

Stops an operation at any time.

In Standby mode, clears/cancels the copy

options, such as the darkness and the number

of copies.

5

Confirms the selection on the display and

starts a job.

G

ETTING

S

TARTED

1.6

Installing the Toner Cartridge

1

Open the front cover.

2

Remove the starter toner cartridge from its bag. Don’t use

a knife or other sharp object as it might scratch the drum of

the cartridge.

3

Gently roll the cartridge 5 or 6 times to distribute the toner

evenly inside the cartridge.

Thoroughly rolling the cartridge will assure the maximum

copies per cartridge.

C

AUTIONS

:

• To prevent damage, do not expose the toner cartridge to light for

more than a few minutes. Cover it with a piece of paper if left

exposed for more than a few minutes, and keep it flat and clean

place.

• If toner gets on your clothing, wipe it off with a dry cloth and

wash clothing in cold water. Hot water sets toner into the fabric.

G

ETTING

S

TARTED

1.7

1

4

Slide the toner cartridge into the machine until it locks into

place completely.

5

Close the front cover. Make sure that the cover is securely

closed.

N

OTE

: When printing text at 5% coverage, you can expect a toner

cartridge life of approximately 3,000 pages. (1,000 pages for the

toner cartridge that is shipped with the printer.)

G

ETTING

S

TARTED

1.8

Loading Paper

You can load approximately 250 sheets.

To load a stack of Letter-sized paper:

1

Pull open the paper tray and remove it from the machine.

2

Fan the edges of the paper stack to separate the pages.

Then tap the stack on a flat surface to even it up.

3

Insert the paper stack into the paper tray with the side you

want to print on

facing down

.

You can load previously printed paper. The printed side

should be facing up with an uncurled edge on top. If you

experience problems with paper feed, turn the paper

around.

G

ETTING

S

TARTED

1.9

1

4

Pay attention to the paper limit mark on the left inside wall

of the tray. Paper overloading may cause paper jams.

5

Insert and slide the paper tray back into the machine.

N

OTE

: After you load the paper, you need to set up your machine

for the paper type and size you loaded. See page 1.26 for copying,

or page 3.7 for PC-printing.

Changing the Paper Size in the Paper Tray

To load longer sizes of paper, such as Legal-sized paper, you

need to adjust the paper guides to extend the paper tray.

1

After pressing and unlatching the guide lock, slide the

paper length guide outward as far as it will go. This extends

the length of the tray.

G

ETTING

S

TARTED

1.10

2

After inserting paper into the tray, slide in the guide until it

lightly touches the end of the paper stack. For paper

smaller than letter, adjust the paper length guide

accordingly.

3

Pinching the paper width guide as shown, move it toward

the stack of paper until it lightly touches the side of the

stack.

N

OTES

:

• Do not push the paper width guide far enough to cause the

materials to warp.

• If you do not adjust the paper width guide, it may cause paper

jams.

G

ETTING

S

TARTED

1.11

1

Making Connections

To print from your computer, you need to connect your printer

to your computer with either a parallel interface cable or a

Universal Serial Bus (USB) cable.

Using a Parallel Cable (Windows only)

N

OTE

: To connect the printer to the parallel port of the computer

requires a certified parallel cable. You will need to buy a IEEE1284

compliant cable.

1

Make sure that both the printer and the computer are

turned off.

2

Plug the parallel printer cable into the connector on the

back of the printer.

Push the metal clips down to fit inside the notches on the

cable plug.

3

Connect the other end of the cable to the parallel interface

port on your computer, and tighten the screws.

See your computer User’s Guide if you need help.

Using a USB Cable

N

OTE

: Connecting the printer to the USB port of the computer

requires a certified USB cable. You will need to buy a USB 1.1

compliant cable that is within 3m in length.

1

Make sure that both the printer and the computer are

turned off.

To the

parallel

port on

your

computer

G

ETTING

S

TARTED

1.12

2

Plug the USB printer cable into the connector on the back of

the printer.

3

Connect the other end of the cable to the USB port on your

computer.

See your computer User’s Guide if you need help.

N

OTES

:

• For using a USB cable, you must be running Windows 98/Me/

2000/XP.

• When using the USB connection, your machine provides two USB

modes; Fast and Slow. Fast is the default mode. Some PC users

may experience poor USB function in the default mode. If this

occurs, select the Slow mode to achieve successful results. For

details about changing the USB mode, see page 8.12.

To th e

USB port

on your

computer

G

ETTING

S

TARTED

1.13

1

Turning the Machine On

1

Plug one end of the supplied three-pronged electrical type

cord into the AC socket on the machine and the other end

into a properly grounded AC outlet.

2

Press the power switch to turn the machine on. “Warming

Up Please Wait” appears on the display indicating that the

machine is now on.

To view your display text in another language, see

page 1.25.

C

AUTIONS

:

• The fusing area inside the rear part of your machine becomes hot

once the machine is turned on. Be careful when you access this

area.

• Do not disassemble the machine when it is turned on as it may

give you an electric shock.

‹

To the AC outlet

G

ETTING

S

TARTED

1.14

Installing Software

About Samsung Software

You must install software using the supplied CD-ROM after you

have set up your machine and connected it to your computer.

The CD-ROM includes:

• Samsung software

• User’s Guides

• Adobe Acrobat Reader

The CD-ROM provides you with the following software:

Windows GDI Driver

To use your machine as a printer and scanner in Windows, you

must install the GDI driver. For information about installing the

GDI driver in Windows, see page 1.16.

Linux Driver

You can print and scan in Linux using your machine. For

information about installing the printer driver in Linux, see

Chapter 6 "Using Your Printer in Linux".

SmarThru Software

SmarThru is the accompanying Windows-based software for

your multifunctional machine. SmarThru contains a powerful

image editor that allows you to edit images in many ways and

also includes powerful Internet mail client software. With

SmarThru, you can save the scanned images in a dedicated

storage area for subsequent editing, sending via e-mail, printing

and processing by other programs of your choice.

Remote Control Panel

This Window-based program is automatically installed when you

install the GDI driver. For information about using the program,

see page 7.10.

G

ETTING

S

TARTED

1.15

1

Printer Driver Features

Your printer drivers support the following standard features:

• Paper source selection

• Paper size, orientation and media type

• number of copies

The following table lists a general overview of features

supported by your printer drivers.

Feature

Printer Driver

Win9x/Me Win2000/XP WinNT4.0 Linux

Toner Sa ve Y Y Y Y

Print quality option Y Y Y Y

Poster printing Y Y Y N

Multiple pages per sheet (N-up) Y Y Y Y(2,4)

Fit to page printing Y Y Y Y

Scale printing Y Y Y Y

Watermark Y Y Y N

Overlay Y Y Y N

G

ETTING

S

TARTED

1.16

Installing Samsung Software in

Windows

System Requirements

Before you begin, ensure that your system meets the minimum

requirements.

Verify the following:

N

OTES

:

• For Windows NT 4.0/2000/XP, the system administrator should

install the software.

• Windows 95 versions prior to OSR2 are not recommended due to

incompatibility with OLE/COM libraries.

Item Requirements

Operating system

Windows 95/98/Me/NT 4.0/2000/XP

CPU

95/98/Me/NT

4.0/2000 Pentium II 400 or higher

XP

Pentium II 933 Ghz or higher

RAM

95/98/Me/NT

4.0/2000 64 MB or higher

XP 128 MB or higher

Free disk space

95/98/Me/NT

4.0/2000 300 MB or higher

XP 1 GB or higher

At least Internet Explorer 5.0

G

ETTING

S

TARTED

1.17

1

Installing Samsung Software

N

OTES

:

•Cancel the “

New Hardware Found

” window when your

computer boots up.

• Make sure that your machine is turned on and connected to your

computer’s parallel port or USB port

before installing

software

. Windows 95 and Windows NT 4.0 do not support the

USB connection.

1

Insert the supplied CD-ROM into your CD-ROM drive.

The CD-ROM should automatically run and an installation

window appears.

If the installation window does not appear, click

Start

and

then

Run

. Type

X:\Setup.exe

, replacing “

X

” with the

letter of your drive and click

OK

.

2

When the following window opens, connect your machine to

the computer and turn the printer on. Then click

Next

.

If the machine is already connected and turned on, this

screen does not appear. Skip to the next step.

N

OTE

: If you click

Next

and the machine is not connected to the

computer, an alert message window appears. After connecting the

machine and turning it on, click

Yes

. Or, if you want to install the

software without the machine, Click

No

.

G

ETTING

S

TARTED

1.18

3

Choose the installation type.

•

Typical

: Installs the common software for your printer,

such as printer driver, Twain driver, Remote Control Panel.

This is Recommended for most users.

•

Custom

: Allows you to choose the language of the

software and the components you want to install. After

selecting the language and the component(s), click

Next

.

•

Install SmarThru

: Installs the SmarThru program. If you

select to install SmarThru on this screen, follow from step

3 on page 1.20.

•

View User’s Guide

: Allows you to view this User’s Guide.

If your computer doesn’t have Adobe Acrobat, click on this

option and it will automatically install Adobe Acrobat for

you.

4

After the installation is finished, the window asking you to

print a test page appears. If you choose to print a test

page, select the check box and click

Next

.

Otherwise, Skip to step 6.

G

ETTING

S

TARTED

1.19

1

5

When the test page prints out correctly, click

Yes

.

If not, click

No

to reprint it.

6

To register yourself as a user of Samsung Printers, select

the check box and click

Finish

. You are now accessed to the

Samsung web site.

Otherwise, just click

Finish

.

N

OTES

:

• When you want to use your machine with the parallel cable,

remove the USB cable and connect the parallel cable. Then

reinstall the printer driver; select

Start

→

Programs

→

Samsung SCX-4100 Series

→

Maintenance

→

Repair

→

Printer

. If you have replaced the parallel cable with the USB

cable, do the same to reinstall the driver.

• If your printer doesn’t work properly, reinstall the printer driver.

G

ETTING

S

TARTED

1.20

Installing Samsung SmarThru

N

OTE

: SmarThru 4 does not support Windows 95.

1

Insert the supplied CD-ROM into your CD-ROM drive.

2

Click

Install SmarThru

.

3

Click

Next

.

4

Follow the on-screen instructions and click

Next

.

5

Click

Next

.

6

Select the installation type and click

Next

.

G

ETTING

S

TARTED

1.21

1

The software installation supports two types of setup:

•

Typical

: Program will be installed with the most common

options and is recommended for most users.

•

Custom

: You may choose the options you want to install.

7

Follow the on-screen instructions to complete the

installation.

If you select the Custom installation, you may choose the

components you want to install.

•

Basic SmarThru components

: to use the

basic SmarThru 4 applications and core

service.

•

Scan

components

: to scan the original

document and save it in an application or

folder, email it, or publish it on a web site.

•


components

: to edit an images you

have saved as a graphic file.

•

Copy

components

: to produce professional

quality copies.

•

Print

components

: to print images you have

saved.

G

ETTING

S

TARTED

1.22

8

When the installation is finished, click

Finish

.

Repairing Software

Repairing is required if your installation fails or the software

does not work properly. This Repairing procedure does not

repair SmarThru software.

1

You can select

Start

→

Programs

→

Samsung SCX-4100

Series

→

Maintenance

.

Otherwise, Insert the supplied CD-ROM into your CD-ROM

drive.

2

Click

Repair

.

N

OTE

: If your machine is not connected to the computer, the

Connect Samsung SCX-4100 Series window opens. After

connecting the machine, click

Next

.

3

Select the components you want to reinstall and click

Next

.

If you choose to repair the printer software, the window

asking you to print a test page appears. Do as follows:

a. To print a test page, select the check box and click

Next

.

b. When the test page prints out correctly, click

Yes

.

If not, click

No

to reprint it.

4

When the reinstallation is done, click

Finish

.

G

ETTING

S

TARTED

1.23

1

Removing Software

Uninstall is required if you are upgrading the software or if your

installation fails. You can uninstall the item you want using the

Windows uninstallShield.

Uninstalling the MFP Driver

1

You can select

Start

→

Programs

→

Samsung SCX-4100

Series

→

Maintenance

.

Otherwise, Insert the supplied CD-ROM into your CD-ROM

drive.

2

Click

Remove

.

Then you will see a component list so that you can remove

any of them individually.

If you want to uninstall the printer driver, check

Printer

.

If you want to uninstall the twain driver, check

Twain

.

If you want to uninstall the Remote Control Panel, check

Remote Control Panel

.

3

After selecting items you wish to remove, click

Next

.

4

When your computer asks you to confirm your selection,

click

Yes

.

The selected driver and all of its components are removed

from your computer.

5

When the uninstallation is done, click

Finish

.

G

ETTING

S

TARTED

1.24

Uninstalling Samsung SmarThru

N

OTE

: Before beginning uninstallation, ensure that all applications

are closed on your computer. A system reboot is required after the

software is uninstalled.

1

From the

Start

menu, select

Programs

.

2

Select

SmarThru 4

, and then select

Uninstall

SmarThru 4

.

3

When your computer asks you to confirm, click

OK

.

4

Click

Finish

.

When your computer doesn’t shut down and restart

automatically, you must shut it down manually and restart

it before the changes are saved.

G

ETTING

S

TARTED

1.25

1

Setting Up the Machine

System

Changing the Display Language

To change the language that displays on the display of the

control panel, follow these steps:

1

Press

Menu/Exit

until "Machine Setup" appears on the top

line of the display.

2

Press

the scroll button (



or



) until "Language" appears

on the bottom line of the display.

3

Press

Start/Enter

. The current setting appears on the

bottom line of the display.

4

Press

the scroll button (



or



)

until the language you want

appears on the display.

5

Press

Start/Enter

to save the selection.

6

To return to Standby mode, press

Stop/Clear

.

G

ETTING

S

TARTED

1.26

Setting the Paper Size and Type

After loading paper in the paper tray, you need to set the paper

type and size using the control panel buttons. These settings will

apply to Copy modes. For PC-printing, you need to select the

paper type and size in the application program you use.

To set the paper size for the paper tray:

1

Press

Menu/Exit

until "Paper Setting"

appears on the top

line.

The first menu item, "Paper Size", appears on the bottom

line.

2

Press

Start/Enter

to access the menu item.

3

Press

Start/Enter

when "Tray Paper" displays on the

bottom line.

4

Use

the scroll button (



or



)

to find the paper size you are

using and press

Start/Enter

to save it.

5

To return to Standby mode, press

Stop/Clear

.

To set the paper type for the paper tray:

1

Press

Menu/Exit

until "Paper Setting"

appears on the top

line.

2

Press the



button to display "Paper Type" on the bottom

line and press

Start/Enter

to access the menu item.

3

Use

the scroll button (



or



)

to find the paper type you

are using and press

Start/Enter

to save it.

4

To return to Standby mode, press

Stop/Clear

.

G

ETTING

S

TARTED

1.27

1

Using the Save Modes

Toner Save Mode

Toner Save mode allows your machine to use less toner on each

page. Activating this mode extends the life of the toner cartridge

longer than normal, but it reduces the print quality.

To turn the toner save mode on or off:

1

Press

Menu/Exit

until "Toner Save" appears on top line of

the display.

2

Press the scroll button (



or



) to display "On" on the

bottom line and press

Start/Enter

.

Selecting "Off" means that toner save mode turns off.

N

OTE

: For PC-printing, you can also turn toner save mode on or

off, in the printer properties. See page 3.9.

Power Save Mode

Power Save mode allows your machine to reduce power

consumption when it is not in actual use. You can turn this mode

on by selecting the length of time for which the machine waits

after a job is printed before it switches to a reduced power state.

1

Press

Menu/Exit

until "Machine Setup" appears on top line

of the display.

2

Press the scroll button (



or



)

until "Power Save" appears

on the bottom line. Press

Start/Enter

.

3

Press the scroll button (



or



) to display "On" on the

bottom line and press

Start/Enter

.

Selecting "Off" means that Power Save mode turns off.

4

Press the scroll button (



or



) until the time settings you

want appears.

The available options are 5, 10, 15, 30 and 45 (minutes).

5

Press

Start/Enter

to save the selection.

6

To return to Standby mode, press

Stop/Clear

.

G

ETTING

S

TARTED

1.28

M

EMO

2PAPER HANDLING

This chapter introduces you to the basics of selecting

print materials and loading them into your machine.

This chapter includes:

• Selecting Print Materials

• Selecting an Output Location

• Loading Paper in the Paper Tray

• Using the Manual Feeder

P

APER

H

ANDLING

2.2

Selecting Print Materials

You can print on a variety of print materials, such as plain paper,

envelopes, labels, transparencies, and so on. Always use print

materials that meet the guidelines for use with this machine.

See “Paper Specifications” on page A.5. To get the best possible

print quality, use only high-quality copier-grade paper.

When you choose print materials, consider the following:

• Desired outcome: The paper you choose should be

appropriate for your project.

• Size: You can use any size paper that fits easily within the

paper adjusters of the paper tray.

• Weight: Your machine supports paper weights as follows:

- 16 ~ 24 lbs (60 ~ 90 g/m

2

) bond for the paper tray

- 16 ~ 43 lbs (60 ~ 163 g/m

2

) bond for the manual feeder

• Brightness: Some papers are whiter than others and produce

sharper, more vibrant images.

• Surface smoothness: The smoothness of the paper affects

how crisp the printing looks on the paper.

C

AUTION

: Using print materials that does not conform to the

specifications listed “Paper Specifications” on page A.5 may

cause problems that may require service. This service is not

covered by the warranty or service agreements.

Type, Input Sources and Capacities

Paper Type Input Source/Capacity

*

*

Maximum capacity may be reduced depending on the paper thickness.

Paper Tray Manual Feeder

Plain paper

250 1

Envelopes

- 1

Labels

**

** If you experience excessive jamming, load one sheet at a time through the

manual feeder.

- 1

Transparency films

**

-

1

Card stocks

**

-

1

P

APER

H

ANDLING

2.3

2

Guidelines for Paper and Special Materials

When selecting or loading paper, envelopes, or other special

material, keep these guidelines in mind:

• Always use paper and other materials that conform with the

specifications listed under “Paper Specifications” on page A.5.

• Attempting to print on damp, curled, wrinkled, or torn paper

can cause paper jams and the poor print quality.

• Use only high quality copier grade paper for the best print

quality.

• Avoid paper with embossed lettering, perforations, or a

texture that is too smooth or too rough. Paper jams may

occur.

• Store paper in its ream wrapper until you are ready to use.

Place cartons on pallets or shelves, not on the floor. Do not

place heavy objects on top of the paper, whether it is

packaged or unpackaged. Keep it away from moisture, or

other conditions that can cause it to wrinkle or curl.

• Store unused materials at temperatures between 15

o

C and

30

o

C (59

o

F to 86

o

F). The relative humidity should be

between 10 % and 70 %.

• During storage, you should use moisture-proof wrap, such as

any plastic container or bag, to prevent dust and moisture

from contaminating your paper.

• Load special paper types one sheet at a time.

• Only use materials specifically recommended for use in laser

printers.

• To prevent special materials, such as transparencies and

label sheets from sticking together, remove them as they

prints out.

•For envelopes:

- Use only well-constructed envelopes with sharp, well

creased folds.

- Do not use envelopes with clasps and snaps.

- Do not use envelopes with windows, coated lining, self-

adhesive seals, or other synthetic materials.

- Do not use damaged or poorly made envelopes.

• For transparencies:

- Place them on a flat surface after removing them from the

machine.

- Do not leave them in the paper tray for long periods of time.

Dust and dirt may accumulate on them resulting in spotty

printing.

P

APER

H

ANDLING

2.4

- To avoid smudging caused by fingerprints, handle them and

coated paper carefully.

- To avoid fading, do not expose the printed transparencies to

prolonged sunlight.

•For labels:

- Verify that their adhesive material can tolerate fusing

temperature of 208

o

C (406.4

o

F) for 0.1 second.

- Make sure that there is no exposed adhesive material

between them. Exposed areas can cause labels to peel off

during printing, which can cause paper jams. Exposed

adhesive can also cause damage to machine components.

- Do not load a sheet of them through the machine more than

once. The adhesive backing is designed for one pass

through the machine.

- Do not use labels that are separating from the backing

sheet or are wrinkled, bubbled, or otherwise damaged.

• Do not use

Carbonless

paper and

Tracing

paper. Use of

these types of paper could result in chemical smells and could

damage your printer.

Selecting an Output Location

The machine has two output locations; the rear output slot (face

up) and the front output tray (face down).

To use the front output tray, make sure that the rear cover is

closed. To use the rear output slot, open the rear cover.

N

OTES

:

• If paper coming out of the front output tray has problems, such

as excessive curl, try printing to the rear output slot.

• To avoid paper jams, do not open or close the rear cover while

the machine is printing.

P

APER

H

ANDLING

2.5

2

Printing to the Front Output Tray

(Face down)

The front output tray collects printed paper face-down in the

order in which it was printed. The tray should be used for most

print jobs.

If you use paper which is not long enough to reach the front

output tray, use the jam cover.

To u se the jam c over :

1

Lift the jam cover. A tab automatically springs up to

support the cover.

2

Take the paper out manually.

P

APER

H

ANDLING

2.6

3

Close the jam cover. In order to close the cover, push the

tab to the left and hold it down. Then lower the cover

carefully until the cover is holding down the tab. Then you

can move your hand and finish lowering the cover.

Be careful not to pinch your fingers!

N

OTE

:

• If you continuously print many pages, the surface of the output

tray may become hot. Be careful not to touch the surface, and

especially keep children away from the surface.

• The front output tray can hold up to 50 sheets of paper. Remove

the pages so that the tray is not overloaded.

Printing to the Rear Output Slot

(Face up)

Using the rear output slot, paper comes out of the machine face

up.

Printing from the manual feeder to the rear output slot provides

a

straight paper path

. Using the rear output slot might

improve the output quality with the following:

• envelopes • labels

• small custom-sized paper • postcards

• transparencies

P

APER

H

ANDLING

2.7

2

To use the rear output slot:

1

Open the rear cover by pulling it upward.

C

AUTION

: The fusing area inside the rear part of your machine

becomes hot once the machine is turned on. Be careful when you

access this area.

2

If you do not want to use the rear output slot, close the

rear cover. The pages stack on the front output tray.

P

APER

H

ANDLING

2.8

Loading Paper in the Paper Tray

The paper tray can hold a maximum of 250 sheets of 20 lb(75g/

m

2

) plain paper. For copying, you can use A4-, Letter- or Legal-

sized paper only. For PC-printing, you can use many different

sizes of paper; see page A.6.

To load paper, pull open the paper tray and load paper with the

print side

face down

.

You can load letterhead paper with the design side face down.

The top edge of the sheet with the logo should be placed at the

front side of the tray.

For details about loading paper in the paper tray, see “Loading

Paper” on page 1.8.

N

OTES

:

• If you experience problems with paper feed, place the paper in

the manual feeder.

• You can load previously printed paper. The printed side should

be facing up with an uncurled edge on top. If you experience

problems with paper feed, turn the paper around. Note that the

print quality is not guaranteed.

P

APER

H

ANDLING

2.9

2

Using the Manual Feeder

Use the manual feeder to print transparencies, labels, envelopes

or postcards in addition to making quick runs of paper types or

sizes that are not currently loaded in the paper tray.

Postcards, 3.5 by 5.83 in.(index) cards and other custom-sized

materials can be printed with this printer. The minimum size is

76 by 127 mm (3.0 by 5.0 in.) and the maximum size is 216 by

356 mm (8.5 by 14 in.).

Acceptable print materials are plain paper with sizes ranging

from 100 x 148 mm (3.9 x 5.8 in.) to Legal, 216 x 356 mm (8.5

x 14 in.), the largest size acceptable, and weighing between 16

lb and 32 lb.

N

OTES

:

• Always load only the print materials specified in the

Specifications on page A.5 to avoid paper jams and print quality

problems.

• Flatten any curl on postcards, envelopes and labels before

loading them into the manual feeder.

• When you print on 76 mm X 127 mm (3 X 5 in.) sized media with

loading into the tray, open the rear output tray.

1

Load a sheet of the print material with the print side

face

up

into the center of the manual feeder.

For envelopes, load a sheet with the flap side face down

and with the stamp area on the top left side.

For transparencies, hold them by the edges and avoid

touching the print side. Oils from your fingers can cause

print quality problems.

For letterhead, load a sheet with the design face up, top

edge towards the printer.

P

APER

H

ANDLING

2.10

C

AUTION

: You must open the rear output slot when you print on

transparencies. If not, they may tear while exiting the machine.

2

Adjust the paper guide to the width of the print material.

N

OTE

: When printing on previously printed paper from the

manual feeder, the printed side should be facing down with an

uncurled edge to the machine. If you experience problems with

paper feed, turn the paper around.

3

Open the rear cover to use the rear output slot.

4

After printing, close the rear cover.

P

APER

H

ANDLING

2.11

2

Setting the Paper Type and Size for the

Manual Feeder

After loading paper in the manual feeder, you need to set the

correct paper type and size using the control panel buttons.

These settings will apply to Copy mode. For PC-printing, you

need to select the paper size in the application program you use.

To set the paper size for the manual feeder:

1

Press

Menu/Exit

until "Paper Setting" appears on the top

line of the display.

The first item, "Paper Size", displays on the bottom line.

2

Press

Start/Enter

to access the menu item.

3

Use

the scroll button (



or



)

to display "Manual Feed" on

the bottom line. Press

Start/Enter

to access the menu

item.

4

Use

the scroll button (



or



)

to find the paper size you are

using and press

Start/Enter

to save it.

5

To return to Standby mode, press

Stop/Clear

.

To set the paper type for the manual feeder:

1

Press

Menu/Exit

until "Paper Setting" appears on the top

line of the display.

2

Press the



button to display "Paper Type" on the bottom

line and press

Start/Enter

to access the menu item.

3

Use

the scroll button (



or



)

to find the paper type you

are using and press

Start/Enter

to save it.

4

To return to Standby mode, press

Stop/Clear

.

P

APER

H

ANDLING

2.12

M

EMO

3PRINTING

This chapter explains how to print your documents in

Windows and how to use the print settings.

This chapter includes:

• Printing a Document in Windows

• Setting Paper Properties

• Setting Graphic Properties

• Printing Multiple Pages on One Sheet of the Paper

• Printing a Reduced or Enlarged Document

• Fitting Your Document to a Selected Paper Size

•Printing Posters

•Using Watermarks

• Using Overlays

• Setting Up the Locally Shared Printer

P

RINTING

3.2

Printing a Document in Windows

The following procedure describes the general steps required for

printing from various Windows applications. The exact steps for

printing a document may vary depending on the application

program you are using. Refer to your software application’s

user’s guide for the exact printing procedure.

1

Open the document you want to print.

2

Select

Print

from the

File

menu.

The Print window opens. It may look slightly different

depending on your application.

You can select the basic print settings within the Print

window. These settings include the number of copies and

the print range.

3

To take advantage of the printer features provided by your

machine, click

Properties

or

Preferences

in the

application’s print window and go to step 4.

If you see a

Setup

,

Printer

or

Options

button, click it

instead. Then click

Properties

on the next screen.



Windows 98

Make sure that your

machine is selected.

P

RINTING

3.3

3

4

Now you see the Samsung SCX-4100 Series Properties

window, which allows you to access all of information you

need when using your machine.

The

Layout

tab first displays.

If necessary, select the

Orientation

option.

The

Orientation

option allows you to select the direction in

which information is printed on a page.

•

Portrait

prints across the width of the page, letter style.

•

Landscape

prints across the length of the page,

spreadsheet style.

•

If you want to turn the page upside down, select

180

from

the

Rotate

drop-down list.

5

From the

Paper

tab, select the paper source, size and type.

For further details, see page 3.7.

The preview image

shows the sample page

with the settings you

specified.



Landscape



Portrait

P

RINTING

3.4

6

If necessary, you can set the sequence for the pages to

print from the

Extras

tab. Select the print order you want

to use from the

Printer Order

drop-down list.

•

Normal

: Your machine prints from the first page to the

last page.

•

Reverse All Pages

: Your machine prints from the last

page to the first page.

•

Print Odd Pages

: Your machine prints only the odd

pages of the document.

•

Print Even Pages

: Your machine prints only the even

pages of the document.

7

Click other tabs on the top of the Samsung SCX-4100

Series Properties window to access other features, if

needed.

8

When you finish setting the properties, click

OK

until the

Print window displays.

9

Click

OK

to start printing.

The printer’s Properties window may differ, depending on your

operating system. This User’s Guide shows the Properties

window on windows 98.

N

OTES

:

• Most Windows applications overrides the settings you specified in

the printer driver. Change all of the print settings available in the

software application first, and change any remaining settings

using the printer driver.

• The settings you change remain in effect only while you are

using the current program. To make your changes permanent,

make them in the

Printers

folder. Follow these steps:

1. Click the Windows

Start

menu.

2. For Windows 95/98/Me/NT 4.0/2000, select

Settings

and then

Printers

.

For Windows XP, select

Printers and Faxes

.

3. Select the

Samsung SCX-4100 Series

printer.

4. Click the right mouse button on the printer icon and:

• For Windows 95/98/Me, select

Properties

.

• For Windows 2000/XP, select

Printing Preferences

.

• For Windows NT 4.0, select

Document Default

.

5. Change the settings on each tab and click

OK

.

P

RINTING

3.5

3

Canceling a Print Job

There are two ways to cancel a print job:

To stop a print job from the control panel:

Press the

Stop/Clear

button.

Your machine finishes printing the page that is moving through

the machine and deletes the rest of the print job. Pressing the

button cancels only the current job. If more than one print job

is in the machine’s memory, you need to press the button once

for each job.

To stop a print job from the Printers folder:

If the print job is waiting in a print queue or print spooler, such

as the Printer group in Windows, delete the job as follows:

1

Click the Windows

Start

menu.

2

For Windows 9x/NT4.0/2000/Me, Select

Settings

and then

Printers

.

For Windows XP, select

Printers and Faxes

.

3

Double-click the

Samsung SCX-4100 Series

icon.

4

From the

Document

menu:

For Windows 9x/Me, select

Cancel Printing

.

For Windows NT4.0/2000/XP, select

Cancel

.

N

OTE

: You can access this window simply by double-clicking the

printer icon at the bottom right corner of the Windows desktop.



Windows 98

P

RINTING

3.6

Using a Favorite Setting

The

Favorites

option, which is visible on each tab, allows you

to save the current properties settings for future use.

To save a Favorites item:

1

Change the settings on each tab, as needed.

2

Enter a name for the item in the

Favorites

input box.

3

Click

Save

.

To use a saved setting, select it from the

Favorites

drop-down

list.

To delete a favorite setting item, select it from the list and click

Delete

.

You can also restore the printer driver’s default settings by

selecting

<Printer Default>

from the list.

Using Help

Your machine has a help screen that can be activated using the

Help

button in the printer’s Properties window. The help screen

gives detailed information about the printer features provided

by the printer driver.

You can also click in the upper right hand corner, and then

click on any setting.

P

RINTING

3.7

3

Setting Paper Properties

Use the following options for paper handling. See page 3.2 for

more information about accessing printer’s Properties.

Click the

Paper

tab to access many paper properties.

Property Description

Copies

Copies

allows you to choose the number of

copies to be printed. You can enter up to 999.

Size

Size

allows you to choose the size of the paper

loaded in the tray.

If the required size is not listed in the Size box,

click

Add Custom

. When the Custom Page

Size window appears, set the size and click

Ok

.

The setting appears on the list so that you can

select it.

1

2

3

4

1

2

Enter the custom

name you want to

use.

Enter the paper

size.

P

RINTING

3.8

Setting Graphic Properties

Use the following graphic options to adjust the print quality for

your specific printing needs. See page 3.2 for more information

about accessing printer properties.

Click the

Graphics

tab to display the properties shown below.

Source

Make sure that

Source

is set to the

corresponding paper tray.

Use the

Manual Feed

source when printing to

special material. You need to load one sheet at

a time into the manual feeder. See page 2.9.

If the paper source is set to

Auto Select

, the

machine automatically picks up print material in

the following order: the manual feeder and the

paper tray.

Type

Make sure that

Type

is set to

Printer

Default

. If you load a different type of print

material, select the corresponding paper type.

For more information about print materials, see

Chapter 2, Paper Handling.

If you use cotton paper, set the paper type to

Thick

for the best printing.

To use recycled paper, which weighs from 75g/

m

2

to 90g/m

2

(20lb to 24lb), or colored paper,

select

Color Paper

.

Property Description

3

4

1

3

2

P

RINTING

3.9

3

Property Description

Resolution

You can select the printing resolution by

choosing from

600 dpi (Normal)

or

300

dpi (Draft)

. The higher the setting, the

sharper the printed characters and graphics.

Higher settings may increase the time it takes

to print a document.

Toner Save

Selecting this option extends the life of your

toner cartridge and reduces your cost per page

without a significant reduction in the print

quality.

•

Printer Setting

: When you select this

option, the Toner Save feature is

determined by the setting you’ve made

on the control panel of the machine.

•

On

: Select this option to allow the

machine to use less toner on each page.

•

Off

: When you do not need to save toner

to print a document, select this option.

Advanced

Options

You can make advanced settings by clicking

the

Advanced Options

button.

1

2

3

Darkness

Use this option to lighten or darken the

image appearance in your print.

•

Normal

: This setting is for normal

documents.

•

Light

: This setting is for bolder line widths

or darker grayscale images.

•

Dark

: This setting is for finer line width,

higher definition in graphics and lighter

grayscale images.

When the

Darken Text

option is checked, all

text in your document prints darker than

normal.

P

RINTING

3.10

Printing Multiple Pages on One

Sheet of the Paper

You can select the number of pages to print on a single sheet of

paper. To print more than one page per sheet, the pages are

smaller and arranged in the order you specified on the sheet.

You can print up to 16 pages on one sheet.

1

To change the print settings from your software

application, access the printer’s Properties. See page 3.2.

2

From the

Layout

tab, choose

Multiple Pages per Side

from the

Type

drop-down list.

Advanced

Options

(continued)

Property Description

3

True Type Options

This option determines what the driver tells

the machine about how to image the text in

your document. Select the appropriate

setting according to the status of your

document. This option is available only on

Window 9x, Me.

•

Download as Bit Image

: When this

option is selected, the driver downloads

the font data as bitmap images.

Documents with complicated fonts, such as

Korean or Chinese, or various types of

fonts print faster in this setting.

•

Print as Graphics

: When this option is

selected, the driver downloads any fonts as

graphics. When printing documents with

high graphic content and relatively few

TrueType fonts, printing performance

Print All Text Black

When the

Print All Text Black

option is

checked, all text in your document prints in

solid black, regardless of the color it appears

on the screen. When it is not checked,

colored text prints in shades of gray.

P

RINTING

3.11

3

3

Select the number of pages you want to print per sheet (1,

2, 4, 9 or 16) on the

Pages per Side

drop-down list.

4

Select the page order on the

Page Order

drop-down list, if

necessary.

Check

Print Page Border

to print a border around each

page on the sheet.

N

OTE

:

Page Order

and

Print Page Border

are enabled only

when the number of pages per side is 2, 4, 9 or 16.

5

Click the

Paper

tab and select the paper source, size, and

type.

6

Click

OK

and print the document.

Preview


Right, Then

Down

Down, Then

Right

Left, Then

Down

Down, Then

Left

P

RINTING

3.12

Printing a Reduced or Enlarged

Document

You can scale your print job on a page.

1

When you change the print settings from your software

application, access the printer’s Properties. See page 3.2.

2

From the

Layout

tab, select

Reduce/Enlarge

on the

Type

drop-down list.

3

Enter the scaling rate in the

Percentage

input box.

You can also click the



or



button.

4

Click the

Paper

tab and select the paper source, size and

type.

5

Click

OK

and print the document.

Preview


P

RINTING

3.13

3

Fitting Your Document to a Selected

Paper Size

You can scale your print job to any paper size regardless of the

digital document size. This can be useful when you want to

check the fine details on a small document.

1

To change the print settings from your software

application, access the printer’s Properties. See page 3.2.

2

From the

Layout

tab, select

Fit to Page

on the

Type

drop-

down list.

3

Select the correct size from the

Target Page

drop-down

list.

4

Click the

Paper

tab and select the paper source and type.

5

Click

OK

and print the document.

A

Preview


P

RINTING

3.14

Printing Posters

You can print a single-page document onto 4, 9 or 16 sheets of

paper, for the purpose of pasting the sheets together to form

one poster-sized document.

1

To change the print settings from your software

application, access the printer’s Properties. See page 3.2.

2

From the

Layout

tab, select

Poster

on the

Type

drop-

down list.

3

Configure the poster option:

You can select the page layout from

2x2

,

3x3

or

4x4

. If

you select

2x2

, the image is automatically stretched to

cover 4 physical pages.

Specify an overlap in millimeters or inches to make it easier

to reconstruct the resulting poster.

Preview




2 x 2



3 x 3

0.15 inches

0.15 inches

P

RINTING

3.15

3

4

Click the

Paper

tab and select the paper source, size and

type.

5

Click

OK

and print the document. You can complete the

poster by posting the sheets together.

Using Watermarks

The Watermark option allows you to print text over an existing

document. For example, you may want to have large gray

letters reading “DRAFT” or “CONFIDENTIAL” printed diagonally

across the first page or all of the pages of a document.

There are several predefined watermarks that come with your

machine, and they can be modified or you can add new ones to

the list.

Using an Existing Watermark

1

To change the print settings from your software

application, access the printer’s Properties. See page 3.2.

2

Click the

Extras

tab and select a watermark on the

Watermark

drop-down list. It appears in the preview

image window.

3

Click

Ok

and start printing.

Preview


P

RINTING

3.16

Creating a Watermark

1

To change the print settings from your software

application, access the printer’s Properties. See page 3.2.

2

Click the

Extras

tab and click

Edit

in the

Watermark

section. The Edit Watermarks window appears.

3

Enter text message you want to print in the

Watermark

Message

box.

The message displays in the preview image window.

When the

First Page Only

box is checked, the watermark

prints on the

first page

only

.

4

Select the watermark options.

You can select the font name, style, and size, and gray

scale level from the

Font Attributes

section and set the

angle of the watermark from the

Message Angle

section.

5

Click

Add

to add a new watermark to the list.

6

When you finish creating, click

Ok

and start printing.

To stop printing the watermark, select

<No Watermark>

on

the

Watermark

drop-down list.

P

RINTING

3.17

3

Editing a Watermark

1

To change the print settings from your software

application, access the printer properties. See page 3.2.

2

Click the

Extras

tab and click

Edit

in the

Watermark

section. The Edit Watermarks window appears.

3

Select the watermark you want to edit on the

Current

Watermarks

list, to change the watermark message and

the options. Refer to page 3.16.

4

Click

Update

to save the changes.

5

Click

Ok

.

Deleting a Watermark

1

To change the print settings from your software

application, access the printer’s Properties. See page 3.2.

2

From the

Extras

tab, click

Edit

in the

Watermark

section.

The Edit Watermarks window appears.

3

Select the watermark you want to delete on the

Current

Watermarks

list and click

Delete

.

4

When a confirming message window appears, click

Yes

.

5

Click

Ok

.

P

RINTING

3.18

Using Overlays

What is an Overlay?

An overlay is text and/or images stored on the computer hard

disk drive (HDD) as a special file format that can be printed on

any document. Overlays are often used to take the place of pre-

printed forms and letterhead paper. Rather than using

preprinted letterhead, you can create an overlay containing the

exact same information that is currently on your letterhead. To

print a letter with your company’s letterhead, you need only tell

the machine to print the letterhead overlay on your document.

Creating a New Page Overlay

To use a page overlay, you must create a new page overlay

containing your logo or image.

1

Create or open a document containing text or an image for

use in a new page overlay. Position the items exactly as

you wish them to appear when printed as an overlay. If

needed, save the file for later use.

2

To change the print settings from your software

application, access the printer’s Properties. See page 3.2.

3

Click the

Extras

tab and click

Edit

in the

Overlay

section.

WORLD BEST

Dear ABC

Regards

P

RINTING

3.19

3

4

In the Edit Overlays window, click

Create Overlay

.

5

In the Create Overlay window, type a name of up to eight

characters in the

File name

box. Select the destination

path, if necessary. (The default is C:\Formover).

6

Click

Save

. The name appears on the Overlay List.

7

Click

Ok

or

Yes

to finish creating.

The file is not printed out. Instead it is stored in your

computer HDD disk.

N

OTE

: The overlay document size must be the same as the

documents you print with the overlay. Do not create an overlay

with a watermark.

P

RINTING

3.20

Using a Page Overlay

After an overlay has been created, it is ready to be printed with

your document. To print an overlay with a document:

1

Create or open the document you want to print.

2

To change the print settings from your software

application, access the printer’s Properties. See page 3.2.

3

Click the

Extras

tab.

4

Select the overlay you want to print from the

Overlay

drop-down list box.

5

When the overlay file you want doesn’t appear on the

Overlay List, click

Edit

and

Load Overlay

, and select the

overlay file.

If you have stored the overlay file you want to use in an

external source, you can also load the file when you access

this Load Overlay window.

After you select the file, click

Open

. The file appears on the

Overlay List and is available for printing. Select the overlay

from the

Overlay List

box.

P

RINTING

3.21

3

6

If necessary, click

Confirm Page Overlay When

Printing

. When this box is checked, a message window

appears each time you submit a document for printing,

asking you to confirm your wish to print an overlay on your

document.

Answering

Yes

to the window means that the selected

overlay prints with your document. Answering

No

to the

window cancels overlay printing.

If this box is empty and an overlay has been selected, the

overlay will be automatically printed with your document.

7

Click

OK

or

Yes

until the printing starts.

The overlay downloads with your print job and prints on

your document.

N

OTE

: The resolution of the overlay document must be the same

as that of the document you will print with the overlay.

Deleting a Page Overlay

You can delete page overlays that you no longer use.

1

In the printer’s properties window, click the

Extras

tab.

2

Click

Edit

in the Overlay section.

3

Select the overlay you want to delete from the Overlay List

box.

4

Click

Delete Overlay

.

5

When a confirming message window appears, click

Yes

.

6

Click

OK

until you exit the Print window.

P

RINTING

3.22

Setting Up the Locally Shared Printer

You can connect the machine directly to a selected computer,

which is called “host computer,” on the network. Your machine

can be shared by other users on the network through a Windows

9x, Me, 2000, XP or NT 4.0 network printer connection.

N

OTE

:

Whether the printer is locally connected or network-

connected, you need to install the printer software on each

computer that will print documents to the printer.

In Windows 9x/Me

Setting Up the Host Computer

1

Start Windows.

2

From the

Start

menu, select

Control Panel

and

double-click on the

Network

icon.

3

Check the

File and Print Sharing

box and click

OK

.

4

Click

Start

and select

Printers

from

Settings

. Double-

click your printer icon.

5

Select

Properties

in the

Printer

menu.

6

Click the

Sharing

tab and check the

Shared As

box. Fill in

the

Share Name

field and then click

OK

.

P

RINTING

3.23

3

Setting Up the Client Computer

1

Right-click

Start

and select

Explorer

.

2

Open your network folder in the left column.

3

Right-click the shared name and select

Capture Printer

Port

.

4

Select the port you want, check the

Reconnect at log on

box and then click

OK

.

5

From the

Start

menu, select

Settings

and then

Printers

.

6

Double-click your printer icon.

7

From the

Printer

menu, select

Properties

.

8

From the

Details

tab, select the printer port and click

OK

.

In Windows NT 4.0/2000/XP

Setting Up the Host Computer

1

Start Windows.

2

For Windows NT 4.0/2000, from the

Start

menu, select

Settings

and then

Printers

.

For Windows XP, from the

Start

menu, select

Printers

and Faxes

.

3

Double-click your printer icon.

4

From the

Printer

menu, select

Sharing

.

5

For Windows NT 4.0, check the

Shared

box.

For Windows 2000, check the

Shared As

box.

For Windows XP, check the

Share this printer

box.

6

For Windows NT 4.0, fill in the

Share Name

field and click

OK

.

For Windows 2000/XP, fill in the

Shared Name

field and

click

OK

.

P

RINTING

3.24

Setting Up the Client Computer

1

Right-click

Start

and select

Explorer

.

2

Open your network folder in the left column.

3

Click the shared name.

4

For Windows NT 4.0/2000, from the

Start

menu, select

Settings

and

Printers

.

For Windows XP,

from the

Start

menu, select

Printers

and Faxes

.

5

Double-click your printer icon.

6

From the

Printer

menu, select

Properties

.

7

Press the

Ports

tab and click

Add Port

.

8

Select

Local Port

and click

New Port

.

9

Fill in the

Enter a port name

field and enter the shared

name.

10

Click

OK

and click

Close

.

11

For Windows NT 4.0, click

OK

.

For Windows 2000/XP, click

Apply

and click

OK

.

4COPYING

This chapter gives you step-by-step instructions for copying

documents.

This chapter includes:

• Loading Paper for Copying

• Preparing a Document

• Making a Copy

• Setting Copy Options

• Using Special Copy Features

• Changing the Default Settings

• Setting the Time Out Option

C

OPYING

4.2

Loading Paper for Copying

The instructions for loading print materials are the same

whether you are printing, or copying. For copying, you can use

Letter-, A4-sized print materials. For further details, see

page 1.8 for loading in the paper tray and page 2.9 for loading

in the manual feeder.

Preparing a Document

You can use an original document for copying and scanning on

the document glass.

Load booklet, pamphlet, or documents having unusual

characteristics on the document glass one sheet at a time. On

the document glass, you can load the following types of

documents:

• Thick paper

• Document with uneven surface

• Photographs

• Small documents (e.g. business cards, postcards)

• Special types of paper

C

OPYING

4.3

4

Making a Copy

1

Lift and open the document cover.

2

Place the document

face down

on the document glass.

3

Align it with the registration guide on the top left corner of

the glass.

4

Close the document cover. Be careful not to move the

document.

C

OPYING

4.4

N

OTES

:

• Leaving the cover open while copying may affect the copy quality

and toner consumption.

• If you are copying a page from a book or magazine which is

thicker than 30 mm, start copying with the cover open.

5

Customize the copy settings including number of copies,

copy size, darkness and original type by using the control

panel buttons. See “Setting Copy Options” on page 4.5.

To clear the settings, use the

Stop/Clear

button.

6

Press

Start/Enter

to begin copying. The display shows the

copy processing.

N

OTES

:

• You can cancel the copy job during an operation. Press

Stop/

Clear

, and the copying will stop.

• Dust on the document glass may cause black spots on the

printout. Keep it always clean.

C

OPYING

4.5

4

Setting Copy Options

The buttons on the control panel let you make all the basic copy

options; darkness, number of copies, copy size and document

type. Set the following options for the current copy job before

pressing

Start/Enter

to make copies.

N

OTE

: If you press

Stop/Clear

while you set the copy options, all

of the options you have set for the current copy job will be

canceled and return to their default status. Or, they will

automatically return to their default status after the machine

completes the copy.

Darkness

If you have an original document containing faint markings and

dark images, you can adjust the brightness to make a copy that

is easier to read.

To adjust the contrast, press

Darkness

.

You can choose from the following contrast modes:

•

Light

: works well with dark print.

•

Normal

: works well with standard typed or printed

documents.

•

Dark

: works well with light print or faint pencil markings.

Number of Copies

Using the

No. of Copies

button, you can select the number of

copies from 1 to 99.

1

Press

No. of Copies

.

2

Press the scroll button (



or



) until the number you want

appears on the display.

Pressing and holding the buttons allows you to quickly

increase and decrease in increments of 5.

3

Press

Start/Enter

to save the selection.

C

OPYING

4.6

Reduced/Enlarged Copying

N

OTE

: When you set Original Type to Photo while using paper

larger than A4 size and setting an enlargement rate of more than

100%, Text/Photo will be automatically selected.

You can reduce or enlarge the size of a copied image from 50%

to 200%.

To select from the predefined copy sizes:

1

Press

Menu/Exit

on the control panel.

"Reduce/Enlarge" appears on the top line of the display.

2

Press the scroll button (



or



) to find the size setting you

want.

3

Press

Start/Enter

to save the selection.

To fine-tune the size of copies:

1

Press

Menu/Exit

on the control panel.

"Reduce/Enlarge" appears on the top line of the display.

2

Press the scroll button (



or



) until "Custom:50-200%"

displays on the bottom line. Press

Start/Enter

.

3

Press the scroll button (



or



) until the copy size you want

appears on the display.

Pressing and holding the buttons allows you to quickly

increase and decrease in increments of 5.

4

Press

Start/Enter

to save the selection.

N

OTE

: When you make a reduced copy, black lines may appear at

the bottom of your copy.

C

OPYING

4.7

4

Original Type

The Original Type setting is used to improve the copy quality by

selecting the document for the current copy job.

To select the document type:

1

Press

Menu/Exit

on the control panel until "Original Type"

appears on the top line of the display

2

Press

Start/Enter

to access the menu item.

3

Press the scroll button (



or



) to scroll through the

document type.

You can choose from the following image modes:

•

Text

: Use for documents containing mostly text.

•

Text/Photo

: Use for documents with mixed text and

graphics.

•


: Use when the originals are photographs.

N

OTE

: When you copy a document containing color on the

background, such as a newspaper or a catalog, you can get the

background on your copy. If you want to reduce the background,

change the

Darkness

setting to

Light

and/or the

Original Type

setting to

Text

.

C

OPYING

4.8

Using Special Copy Features

N

OTE

: When you set Original Type to Photo while using paper

larger than A4 size, Text/Photo will be automatically selected.

You can use the following copy features using the "Special Copy"

menu:

•

Off

: Prints in normal mode.

•

Clone

:

Prints multiple image copies from the original

document on a single page. The number of images is

automatically determined by the original image and paper

size. See page 4.8.

•

Auto Fit

: A

utomatically reduces or enlarges the original

image to fit on the paper currently loaded in the machine.

See page 4.9.

•

2 Sides in 1 pg

:

Prints 2-sided original document on one

sheet of paper. See page 4.10.

•

2

UP

: Prints 2 original images reduced to fit onto one

sheet of paper. See page 4.11.

•

Poster

: Prints an image onto 9 sheets of paper (3x3). You

can paste the printed pages together to make one poster-

size document. See page 4.12.

Clone Copying

1

Load the document to be copied on the document glass,

and close the cover.

2

Press

Menu/Exit

until "Special Copy" appears on the top

line of the display.

3

Press the scroll button (



or



) until "Clone" displays on

the bottom line.

4

Press

Start/Enter

to save the selection.

5

Customize the copy settings including number of copies,

copy size, darkness and original type by using the control

panel buttons. See “Setting Copy Options” on page 4.5.

N

OTE

: You cannot adjust the copy size using the "Reduce/

Enlarge" feature while making a clone copy.

6

Press

Start/Enter

to begin copying.

C

OPYING

4.9

4

Auto Fit Copying

N

OTE

: When the size of the document you want to copy is not

same as the size of the paper loaded, this function automatically

adjusts the size of the document to fit the paper. You can not

adjust the copy size manually.

1

Load the document to be copied on the document glass,

and close the cover.

2

Press

Menu/Exit

until "Special Copy" appears on the top

line of the display.

3

Press the scroll button (



or



) until "Auto Fit" appears on

the bottom line.

4

Press

Start/Enter

to save the selection.

5

Customize the copy settings including number of copies,

copy size, darkness and original type by using the control

panel buttons. See “Setting Copy Options” on page 4.5.

N

OTE

: You cannot adjust the copy size using the "Reduce/

Enlarge" feature while the Auto Fit copying is enabled.

6

Press

Start/Enter

to begin copying.

A

C

OPYING

4.10

2 sided in 1 page Copying

You can copy a 2-sided document on one page of A4, or Letter

-sized paper.

When you copy using this feature, the machine prints one side

on the upper half of the paper and the other side on the lower

half. This feature is helpful for copying a small-sized document,

such as a name card.

If the original document is larger than the printable area, some

portions may not be printed.

1

Load the document to be copied on the document glass,

and close the cover.

2

Press

Menu/Exit

until "Special Copy" appears on the top

line of the display.

3

Press the scroll button (



or



) until "2 Sides in 1 pg"

displays on the bottom line.

4

Press

Start/Enter

to save the selection.

5

Customize the copy settings including number of copies,

copy size, darkness and original type by using the control

panel buttons. See “Setting Copy Options” on page 4.5.

6

Press

Start/Enter

to begin copying.

Your machine begins scanning the front side.

7

When "Set Backside" displays on the bottom line, open the

document cover and flip the document over. Close the

cover.

N

OTE

: If you press the

Stop/Clear

button or if no buttons are

pressed for about 30 seconds, the machine cancels the copy job

and returns to Standby Mode.

8

Press

Start/Enter

again.

N

OTE

: You can adjust the copy size using the "Reduce/Enlarge"

feature for making a 2-side Copying.

C

OPYING

4.11

4

2-up Copying

N

OTE

:2-up lets you copy two original documents on one sheet of

paper. The documents are reduced 50 % to allow them to fit on

paper the same size as the original documents. You can not adjust

the copy size to fit on a different size of paper.

1

Load the document to be copied on the document glass,

and close the cover.

2

Press

Menu/Exit

until "Special Copy" appears on the top

line of the display.

3

Press the scroll button (



or



) until "2 UP" displays on the

bottom line.

4

Press

Start/Enter

to save the selection.

5

Customize the copy settings including number of copies,

copy size, darkness and original type by using the control

panel buttons. See “Setting Copy Options” on page 4.5.

N

OTE

: You cannot adjust the copy size using the "Reduce/

Enlarge" feature for making a 2-up copy.

6

Press

Start/Enter

to begin copying.

7

When "Set Next Page Press Start" displays, open the

document cover and remove the first document.

8

Load the second document to be copied on the document

glass, and close the cover.

9

Press

Start/Enter

to begin copying.

N

OTE

: 2-up copy reduces your original document by 50%.

2-up copying

The

second

docu-

ment

The

first

docu-

ment

C

OPYING

4.12

Poster Copying

1

Load the documents to be copied on the document glass

and close the cover.

2

Press

Menu/Exit

until "Special Copy" appears on the top

line of the display.

3

Press the scroll button (



or



) until "Poster" displays on

the bottom line.

4

Press

Start/Enter

to save the selection.

5

Customize the copy settings including number of copies,

copy size, darkness and original type by using the control

panel buttons. See “Setting Copy Options” on page 4.5.

N

OTE

: You cannot adjust the copy size using the "Reduce/

Enlarge" feature for making a poster.

6

Press

Start/Enter

to begin copying.

Your original document is divided into 9

portions. Each portion is scanned and

printed one by one in the following order:

C

OPYING

4.13

4

Changing the Default Settings

Copy options, including darkness, original type, copy size and

number of copies, can be set to the most frequently used

modes. When you copy a document, the default settings are

used unless they are changed by using the corresponding

buttons on the control panel.

To create your own default settings:

1

Press

Menu/Exit

on the control panel until "Copy Setup"

appears on the top line of the display.

The first menu item, "Default-Change", appears on the

bottom line.

2

Press

Start/Enter

to access the menu item. The first setup

option, "Darkness", appears on the bottom line.

3

Press the scroll button (



or



) to scroll through the setup

options.

4

When the option you want to set appears, press

Start/

Enter

to access the option.

5

Change the setting using the scroll button (



or



).

6

Press

Start/Enter

to save the selection.

7

Repeat steps 3 through 6, as needed.

8

To return to Standby mode, press

Stop/Clear

.

N

OTE

: While you set copy options, pressing

Stop/Clear

cancels

the changed settings and restores their default status.

C

OPYING

4.14

Setting the Time Out Option

You can set the time the machine waits before it restores the

default copy settings, if you do not start copying after changing

them on the control panel.

1

Press

Menu/Exit

on the control panel until "Copy Setup"

appears on the top line of the display.

2

Press the scroll button (



or



) to display "Timeout" on the

bottom line.

3

Press

Start/Enter

to access the menu item.

4

Press the scroll button (



or



) until the status you want

appears on the display.

You can select from 15, 30, 60 and 180 (seconds).

Selecting "Off" means that the machine does not restore

the default settings until you press

Start/Enter

to start

copying, or

Stop/Clear

to cancel.

5

Press

Start/Enter

to save the selection.

6

To return to Standby mode, press

Stop/Clear

.

5SCANNING

Scanning with your machine lets you turn pictures and

text into digital files on your computer. Then you can e-

mail the files, display them on your web site or use them

to create projects that you can print using Samsung

SmarThru software.

This chapter includes:

•Scanning Basics

• Scanning Using Samsung SmarThru

• Scanning Process with TWAIN-enabled Software

S

CANNING

5.2

Scanning Basics

Your machine offers two ways to scan:

• From the Samsung SmarThru software: Launch Samsung

SmarThru and open the Scan To to begin scanning. See

below.

• From TWAIN-compliant software: You can use other software

including Adobe PhotoDeluxe and Adobe Photoshop. See

page 5.6.

N

OTES

:

• To scan with your machine, you must install the MFP driver.

• Scanning is done through the same LPT or USB port currently

assigned for your printer port.

Scanning Using Samsung SmarThru

Samsung SmarThru is the accompanying software for your

machine. With the SmarThru, scanning becomes a pleasure.

Follow these steps to start scanning using the SmarThru:

1

Make sure that your machine and computer are turned on

and properly connected to each other.

2

Lift the document cover.

S

CANNING

5.3

5

3

Load the document to be scanned

face down

on the glass

and align it with document guides on the left top corner of

the glass.

4

Close the document cover.

5

Once you have installed Samsung SmarThru, you will see the

SmarThru 4

icon on your desktop. Double-click the

SmarThru

4

icon.

The SmarThru 4 window opens.

•

Scan To

Allows you to scan an image and save it in an application

or folder, email it, or publish it on a web site.

Double-click this icon.

S

CANNING

5.4

•


Allows you to edit an image you have saved as a graphic file

and send it to a selected application or folder, email it, or

publish it on a web site.

•

Copy

Allows you to produce professional quality copies. You can

make black and white or color copying of an image if your

machine supports it, and customize the copy settings.

•

Print

Allows you to print images you have saved. You can print

images in black and white or color mode if your machine

supports it, and customize the print settings.

6

Click

Scan To

. The

Scan To

menu bar appears on the

SmarThru 4 window.

Scan To

lets you use the following services:

•

Application

Scanning an image and placing it in an application. Allows

you to scan an image, preview it, and place it in an

application you choose.

•

Email

Scanning an image and emailing it. Allows you to scan an

image, preview it, and email it.

•

Folder

Scanning an image and saving it to a folder. Allows you

to scan an image, preview it, and save to a folder you

choose.

Adjust the

scan

settings.

Click to see

on-line

help.

S

CANNING

5.5

5

•

OCR

Scanning an image and performing text recognition.

Allows you to scan an image, preview it, and send it to

the OCR program for text recognition.

- Recommended Scan Option for OCR

- Resolution: 200 or 300 dpi

- Image Type: Mono (Black & White)

•

Web

Scanning an image, previewing it, and publish it on a web

site using the specified file format for the picture you

want to publish.

•

Setting

Customizing settings of

Scan To

basic functions. Allows

you to customize settings for

Application

,

Email

,

OCR

,

and

Web

functions.

7

Click the service icon according to your job.

8

The

SmarThru 4

opens for the selected service. Adjust the

scan settings.

9

To start scanning, click

Scan

.

N

OTE

: If you want to cancel the scan job, press the

Stop/Clear

button on the control panel.

To use on-line help file

For more information about SmarThru, click the button.

SmarThru Help window opens and allows you to see on-line

help.

S

CANNING

5.6

Scanning Process with TWAIN-

enabled Software

If you want to scan documents using other software, you will

need to use TWAIN-compliant software, such as Adobe

PhotoDeluxe or Adobe Photoshop. The first time you scan with

your machine, select it as your TWAIN source in the application

you use.

The basic scanning process involves a number of steps:

• Place your photograph or page on the document glass. See

page 5.2.

• Open an application, such as PhotoDeluxe or Photoshop.

• Open the TWAIN window and set the scan options.

• Scan and save your scanned image.

You need to follow the program’s instructions for acquiring an

image. Please refer to the user’s guide of the application.

6

USING YOUR PRINTER IN

LINUX

This chapter gives you information about how to use your

machine in the Linux system.

This chapter includes:

• Getting Started

• Installing the MFP Driver

• Using the MFP Configurator

• Configuring Printer Properties

• Printing a Document

•Scanning a Document

U

SING

Y

OUR

P

RINTER

IN

L

INUX

6.2

Getting Started

The supplied CD-ROM provides you with Samsung’s MFP driver

package for using your machine with a Linux computer.

Samsung’s MFP driver package contains printer and scanner

drivers, providing the ability to print documents and scan

images. The package also delivers powerful applications for

configuring your machine and further processing of the scanned

documents.

After the driver is installed on your Linux system, the driver

package allows you to monitor a number of MFP devices. The

acquired documents can then be edited, printed on the same

local MFP or network printers, sent by e-mail, uploaded to a FTP

site or transferred to an external OCR system.

The MFP driver package is supplied with a smart and flexible

installation program. You don't need to search for additional

components that might be necessary for the MFP software: all

required packages will be carried onto your system and installed

automatically; this is possible on a wide set of the most popular

Linux clones.

U

SING

Y

OUR

P

RINTER

IN

L

INUX

6.3

6

Installing the MFP Driver

System Requirements

Supported OS

Various Linux OS (via USB interface only)

• Redhat 7.1 and above

• Linux Mandrake 8.0 and above

• SuSE 7.1 and above

• Caldera OpenLinux 3.1 and above

• Turbo Linux 7.0 and above

• Slackware 8.1 and above

Recommended Hardware Requirements

• Pentium IV 1 GHz or higher

• RAM 256 MB or higher

• HDD 1GB or higher

N

OTES

:

• It’s also necessary to claim swap partition of 300 MB or larger for

working with large scanned images.

• The Linux scanner driver supports the optional resolution at

maximum. see “Scanner and Copier Specifications” on page A.3.

Software

• Linux Kernel 2.4 or higher

• Glibc 2.2 or higher

•CUPS

•SANE

U

SING

Y

OUR

P

RINTER

IN

L

INUX

6.4

Installing the MFP Driver

1

Make sure that you connect your machine to your computer.

Turn both the computer and the machine on.

2

When the Administrator Login window appears, type in

root

in the Login field and enter the system password.

N

OTE

: You must log in as a super user (root) to install the printer

software. If you are not a super user, ask your system

administrator.

3

Insert the printer software CD-ROM. The CD-ROM will

automatically run.

If the CD-ROM does not automatically run, click the icon

at the bottom of the desktop. When the Terminal screen

appears, type in:

[root@localhost root]#cd /mnt/cdrom/Linux

[root@localhost root]#./install.sh

N

OTE

: The installation program runs automatically if you have an

autorun software package installed and configured.

4

Click

Install

.

5

When the welcome screen appears, click

Next

.

U

SING

Y

OUR

P

RINTER

IN

L

INUX

6.5

6

6

When the installation is completed, click

Finish

.

The installation program has added the MFP Configurator

desktop icon and Samsung MFP group to the system menu

for your convenience. If you have any difficulties, consult

the on-line help that is available through your system menu

or can otherwise be called from the driver package windows

applications, such as MFP Configurator or Image Editor.

U

SING

Y

OUR

P

RINTER

IN

L

INUX

6.6

Uninstalling the MFP Driver

1

When the Administrator Login window appears, type in

root

in the Login field and enter the system password.

N

OTE

: You must log in as a super user (root) to install the printer

software. If you are not a super user, ask your system

administrator.

2

Insert the printer software CD-ROM. The CD-ROM will

automatically run.

If the CD-ROM does not automatically run, click the icon

at the bottom of the desktop. When the Terminal screen

appears, type in:

[root@localhost root]#cd /mnt/cdrom/Linux

[root@localhost root]#./install.sh

N

OTE

: The installation program runs automatically if you have an

autorun software package installed and configured.

3

Click

Uninstall

.

4

Click

Next

.

5

Click

Finish

.

U

SING

Y

OUR

P

RINTER

IN

L

INUX

6.7

6

Using the MFP Configurator

MFP Configurator is a tool primarily intended for configuring MFP

devices. Since an MFP device combines the printer and scanner,

the MFP Configurator provides options logically grouped for

printer and scanner functions. There is also a special MFP port

option responsible for the regulation of access to an MFP printer

and scanner via a single I/O channel.

After installing the MFP driver (see page 6.3), the MFP

Configurator icon will automatically be created on your desktop.

Opening the MFP Configurator

1

Double-click

MFP Configurator

on the desktop.

You can also click the Startup Menu icon and select

Samsung MFP

and then

MFP Configurator

.

2

Press each button on the Modules pane to switch to the

corresponding configuration window.

You can use the on-line help by clicking

Help

.

3

After changing the configurations, click

Exit

to close the

MFP Configurator.

Printers Configuration

button

Scanners Configuration

button

MFP Ports Configuration

button

U

SING

Y

OUR

P

RINTER

IN

L

INUX

6.8

Printers Configuration

Printers Configuration has the two tabs;

Printers

and

Classes

.

Printers Tab

You can see the current system’s printer configuration by

clicking on the printer icon button on the left side of MFP

Configurator window.

You can use the following printer control buttons:

•

Refresh

: renews the available printers list.

•

Add Printer

: allows you to add a new printer.

•

Remove Printer

: removes the selected printer.

•

Set as Default

: sets the current printer as a default printer.

•

Stop/Start

: stops/starts the printer.

•

Test

: allows you to print a test page to check if the machine

is working properly.

•

Properties

: allows you to view and change the printer

properties. For details, see page 6.11.

Printer control

buttons. See

below.

Shows all of the

installed printer.

Switches to Printer

configuration.

Shows the status,

model name and

URI of your printer.

U

SING

Y

OUR

P

RINTER

IN

L

INUX

6.9

6

Classes Tab

The Classes tab shows the list of the available printer classes.

Scanners Configuration

In this window, you can monitor activity of scanner devices,

view the list of installed Samsung MFP devices, change device

properties, and scan images.

Shows all of the

printer classes.

Shows the status of the

class and the number of

printers in the class.

Renews the classes

list.

Allows you to add a

new printer class.

Removes the

selected printer

class.

Allows you to

monitor the

activity of the

scan drivers.

Allows you to change

the scan properties

and scan a

document. See

page 6.14.

Shows all of the

installed scanners.

Switches to

Scanners

configuration.

Shows the vendor,

model name and type of

your scanner.

U

SING

Y

OUR

P

RINTER

IN

L

INUX

6.10

MFP Ports Configuration

In this window, you can view the list of available MFP ports,

check the status of each port and release a port that is stalled

in busy state when its owner is terminated for any reason.

Sharing Ports Between Printers and Scanners

Your machine may be connected to a host computer via the USB

port. Since the MFP device contains more than one device

(printer and scanner), it is necessary to organize proper access

of “consumer” applications to these devices via the single I/O

port.

The Samsung MFP driver package provides an appropriate port

sharing mechanism that is used by Samsung printer and

scanner drivers. The drivers address their devices via so-called

MFP ports. The current status of any MFP port can be viewed via

the MFP Ports Configuration. The port sharing prevents you from

accessing one functional block of the MFP device, while another

block is in use.

When you install a new MFP printer onto your system, it is

strongly recommended you do this with the assistance of an MFP

Configurator. In this case you will be asked to choose I/O port

for the new device. This choice will provide the most suitable

configuration for MFP’s functionality. For MFP scanners I/O ports

are being chosen by scanner drivers automatically, so proper

settings are applied by default.

Releases the selected

port.

Renews the

available ports list.

Shows all of the

available ports.

Switches to

MPF ports

configuration.

Shows the port type,

device connected to

the port and status

U

SING

Y

OUR

P

RINTER

IN

L

INUX

6.11

6

Configuring Printer Properties

Using the properties window provided by the Printers

configuration, you can change the various properties for your

machine as a printer.

1

Open the MFP Configurator.

If necessary, switch to Printers configuration.

2

Select your machine on the available printers list and click

Properties

.

3

The Printer Properties window opens.

The following five tabs display at the top of the window:

•

General

: allows you to change the printer location and

name. The name entered in this tab displays on the

printer list in Printers configuration.

•

Connection

: allows you to view or select another port.

•

Driver

: allows you to view or select another printer

driver. By clicking

Options

, you can set the default

device options.

•

Jobs

: shows the list of print jobs. Click

Cancel job

to

cancel the selected job and select the

Show completed

jobs

check box to see previous jobs on the job list.

•

Classes

: shows the class that your printer is in. Click

Add to Class

to add your printer to a specific class or

click

Remove from Class

to remove the printer from the

selected class.

4

Click

OK

to apply the changes and close the Printer

Properties Window.

U

SING

Y

OUR

P

RINTER

IN

L

INUX

6.12

Printing a Document

Printing from Applications

There are a lot of Linux applications that you are allowed to print

from using Common UNIX Printing System(CUPS). You can print

on your machine from any such application.

1

From the application you are using, select

Print

from the

File

menu.

2

Select

Print

directly using

lpr

.

3

In the Samsung LPR window, select the model name of

your machine from the Printer list and click

Properties

.

4

Change the printer and print job properties.

Click

U

SING

Y

OUR

P

RINTER

IN

L

INUX

6.13

6

The following four tabs display at the top of the window.

•

General

- allows you to change the paper size, the paper

type and the orientation of the documents, enables the

duplex feature, adds start and end banners and changes

the number of pages per sheet.

•

Text

- allows you to specify the page margins and set the

text options, such as spacing or colums.

•

Graphics

- allows you to set image options that are used

when printing images/files, such as color options, image

size or image position.

•

Device

: allows you to set the print resolution, paper

source and destination.

5

Click

OK

to apply the changes and close the SCX-4100

Properties window.

6

Click

OK

in the Samsung LPR window to start printing.

7

The Printing window appears to allow you to monitor the

status of your print job.

To abort the current job, click

Cancel

.

Printing Files

You can print many different types of files on the Samsung MFP

device using the standard CUPS way - directly from the

command line interface. The CUPS lpr utility allows you do that.

But the drivers package replaces the standard lpr tool by a much

more user-friendly Samsung LPR program.

To print any document file:

1

Typ e

lpr <file_name>

from the Linux shell command line

and press

Enter

. The Samsung LPR window appears.

When you type only

lpr

and press

Enter

, the Select file(s)

to print window appears first. Just select any files you want

to print and click

Open

.

2

In the Samsung LPR window, select your printer from the

list, and change the printer and print job properties.

For details about the properties window, see page 6.12.

3

Click

OK

to start printing.

U

SING

Y

OUR

P

RINTER

IN

L

INUX

6.14

Scanning a Document

You can scan a document using the MFP Configurator window.

1

Double-click the MFP Configurator on your desktop.

2

Click the button to switch to Scanners Configuration.

3

Select the scanner on the list.

When you have only one MFP device and it is connected to

the computer and turned on, your scanner appears on the

list and is automatically selected.

If you have two or more scanners attached to your

computer, you can select any scanner to work at any time.

For example, while acquisition is in progress on the first

scanner, you may select the second scanner, set the device

options and start the image acquisition simultaneously.

N

OTE

: The scanner name shown in Scanners configuration can be

different from the device name.

4

Click

Properties

.

Click your

scanner.

U

SING

Y

OUR

P

RINTER

IN

L

INUX

6.15

6

5

Load the document to be scanned

face down

on the

document glass.

6

Click

Preview

in the Scanner Properties window.

The document is scanned and the image preview appears in

the Preview Pane

.

Drag the pointer to

set the image area

to be scanned.

U

SING

Y

OUR

P

RINTER

IN

L

INUX

6.16

7

Change the scan options in the Image Quality and Scan

Area sections.

•

Image Quality

: allows you to select the color

composition and the scan resolution for the image.

•

Scan Area

: allows you to select the page size. The

Advanced

button enables you to set the page size

manually.

If you want to use one of the preset scan option settings,

select from the Job Type drop-down list. For details about

the preset Job Type settings, see page 6.17.

You can restore the default setting for the scan options by

clicking

Default

.

8

When you have finished, press

Scan

to start scanning.

The status bar appears on the bottom left of the window to

show you the scanning progress. To cancel scanning, press

Cancel

.

9

The scanned image appears in the new Image Editor

window.

If you want to edit the scanned image, use the toolbar. For

further details about editing the image, see page 6.18.

10

When you are finished, click

Save

on the toolbar.

11

Select the file directory where you want to save the image

and enter the file name.

12

Click

Save

.

U

SING

Y

OUR

P

RINTER

IN

L

INUX

6.17

6

Using Preset Job Type Settings

You can save your scan option settings to retrieve for a later

scanning.

To save a new Job Type setting:

1

Change the options from the Scanner Properties window.

2

Click

Save As

.

3

Enter the name for your setting.

4

Click

OK

.

Your setting is added to the Saved Settings drop-down list.

To save a Job Type setting for the next scan job:

1

Select the setting you want to use from the Job Type drop-

down list.

2

Click

Save

.

The next time you open the Scanner Properties window, the

saved setting is automatically selected for the scan job.

To delete a Job Type setting:

1

Select the setting you want to delete from the Job Type

drop-down list.

2

Click

Delete

.

The setting is deleted from the list.

U

SING

Y

OUR

P

RINTER

IN

L

INUX

6.18

Using the Image Editor

The Image Editor window provides you with menu commands

and tools to edit your scanned image.

You can use the following tools to edit the image:

Use these tools to

edit the image.

Tools Function

Saves the image.

Cancels your last action.

Restores the action you canceled.

Allows you to scroll through the image.

Crops the selected image area.

Zooms the image out.

Zooms the image in.

U

SING

Y

OUR

P

RINTER

IN

L

INUX

6.19

6

For further details about the Image Editor program, refer to the

on-line help.

Allows you to scale the image size; you can enter

the size manually, or set the rate to scale

proportionally, vertically or horizontally.

Allows you to rotate the image; you can select the

number of degrees from the drop-down list.

Allows you to flip the image vertically or

horizontally.

Allows you to adjust the brightness or contrast of

the image, or to invert the image.

Shows the properties of the image.

Tools Function

U

SING

Y

OUR

P

RINTER

IN

L

INUX

6.20

M

EMO

7MAINTENANCE

This chapter provides information for maintaining your

machine and the toner cartridge.

This chapter includes:

• Printing the System Data List

• Clearing the Memory

• Cleaning Your Machine

• Maintaining the Toner Cartridge

• Consumables and Replacement Parts

• Using the Remote Control Panel

M

AINTENANCE

7.2

Printing the System Data List

Your machine can print the system data report shows the status

of the user-selectable options. You may print this list to confirm

your changes after changing any settings.

To print the system data list:

1

Press

Menu/Exit

until "Report" appears on the top line of

the display.

"System Data" appears on the bottom line.

2

Press

Start/Enter

.

The system data list prints out.

Clearing the Memory

You can selectively clear information stored in your machine’s

memory.

1

Press

Menu/Exit

on the control panel until "Maintenance"

appears on the top line of the display.

2

Press the scroll button (



or



) until you see "Clear

Settings" on the bottom line and press

Start/Enter

.

The first available menu item, “Paper Setting” displays on

the bottom line.

3

Press the scroll button (



or



) until you see the item you

want to clear.

• Paper Setting: Restores all of the Paper Setting options to

the factory default.

• Copy Setup: Restores all of the Copy Setup options to the

factory default.

• All Settings: Resets all of your settings to the factory default.

• Machine Setup: Resets all of the system settings, such as

the display language and save modes, to the factory default.

4

Press

Start/Enter

. The selected memory is cleared and

the display asks you to continue clearing the next item.

5

To clear another item, press

Start/Enter

and repeat steps 3

and 4

. Or, to return to Standby mode, press

Stop/Clear

.

M

AINTENANCE

7.3

7

Cleaning Your Machine

To maintain print quality, follow the cleaning procedures below

each time the toner cartridge is replaced or if print quality

problems occur.

N

OTES

:

• While cleaning the inside of the machine, be careful not to touch

the transfer roller, located underneath the toner cartridge. Oil

from your fingers can cause print quality problems.

• Cleaning the cabinet of your machine with products containing

large amounts of alcohol, solvent, or other strong substances

can discolor or crack the cabinet.

Cleaning the Outside

Clean the cabinet of the machine with a soft lint-free cloth. You

can dampen the cloth slightly with water, but be careful not to

let any water drip onto or inside the machine.

Cleaning the Inside

During the printing process, paper, toner and dust particles can

accumulate inside the machine. This build-up can cause print

quality problems, such as toner specks or smearing. Cleaning

the inside of the machine clears or reduces these problems.

1

Turn the machine off and unplug the power cord. Wait for

the machine to cool down.

2

Open the front cover and pull the toner cartridge out,

lightly pushing it down.

M

AINTENANCE

7.4

3

With a dry lint-free cloth, wipe away any dust and spilled

toner from the toner cartridge area and the toner cartridge

cavity.

C

AUTION

: To preve

nt damage to the toner cartridge, do not expose

it to light for more than a few minutes. Cover it with a piece of paper,

if necessary. Do not touch the black transfer roller inside the machine.

4

Locate the long strip of glass (LSU) inside the top of the

cartridge compartment, and gently swab the glass to see if

dirt turns the white cotton black.

5

Reinsert the toner cartridge and close the cover.

6

Plug in the power cord and turn the machine on.

M

AINTENANCE

7.5

7

Cleaning the Document Glass

Keeping the document glass clean helps ensure the best

possible copies. We suggest that you clean the document glass

at the start of each day and during the day, as needed.

1

Slightly dampen a soft lint-free cloth or paper towel with

water.

2

Lift the document glass.

3

Wipe the surface of the document glass until it is clean and

dry.

4

Wipe the underside of the white document cover until it is

clean and dry.

5

Close the document cover.

M

AINTENANCE

7.6

Maintaining the Toner Cartridge

Toner Cartridge Storage

To get the most from the toner cartridge, keep the following

guidelines in mind:

• Do not remove the toner cartridge from its package until

ready for use.

• Do not refill the toner cartridge.

The machine warranty

does not cover damage caused by using a refilled

cartridge.

• Store toner cartridges in the same environment as your

machine.

• To prevent damage to the toner cartridge, do not expose it to

light for more than a few minutes.

Saving Toner

To save toner, use the Toner Save feature; see page 1.27. Using

this feature extends the life of the toner cartridge and reduces

your cost per page, but it also reduces the print quality.

Expected Cartridge Life

The life of the toner cartridge depends on the amount of toner

that print jobs require. When printing text at ISO 19752 5%

coverage, a new toner cartridge lasts an average of 3,000

pages. (The original toner cartridge supplied with the machine

lasts an average of 1,000 pages.) The actual number may be

different depending on the print density of the page you print.

If you print a lot of graphics, you may need to change the

cartridge more often.

N

OTE

: The 1,000 pages and 3,000 pages toner cartridges have

different shapes.

M

AINTENANCE

7.7

7

Redistributing Toner

When the toner cartridge is near the end of its life, white streaks

or light print occurs. You can temporarily re-establish the print

quality by redistributing the remaining toner in the cartridge.

1

Open the front cover.

2

Pull the toner cartridge out and gently roll the cartridge 5 or

6 times to distribute the toner evenly inside the cartridge.

N

OTE

: If toner gets on your clothing, wipe it off with a dry cloth

and wash clothing in cold water. Hot water sets the toner into

fabric.

3

Reinstall the cartridge and close the front cover.

M

AINTENANCE

7.8

Replacing the Toner Cartridge

When the toner eventually runs out, only blank pages print when a

print job is sent. At this stage, the toner cartridge needs to be

replaced. The machine stops printing.

1

Open the front cover.

2

Lightly pushing the used cartridge down, pull it out.

3

Unpack the new toner cartridge and gently roll it

horizontally four or five times to distribute the toner evenly

inside the cartridge.

Save the box and the Plastic bag for shipping.

4

Slide the new toner cartridge in until it locks into place.

5

Close the front cover.

M

AINTENANCE

7.9

7

Cleaning the Drum

If there are streaks or spots on your print, the OPC drum of the

cartridge may require cleaning.

1

Before setting the cleaning procedure, make sure that

paper is loaded in the machine.

2

Press

Menu/Exit

on the control panel until "Maintenance"

appears on the top line of the display.

The first available menu item, "Clean Drum", displays on

the bottom line.

3

Press

Start/Enter

.

4

When the display asks you to confirm your selection, press

Start/Enter

.

The machine prints a cleaning page. Toner particles on the

drum surface are affixed to the paper.

5

If the problem remains, repeat steps 1 through 4.

Consumables and Replacement

Parts

From time to time, you needs to replace the toner cartridge,

roller, and fuser unit to maintain top performance and to avoid

print quality problems and paper feed problems resulting from

worn parts.

The following items should be replaced after you have printed a

specified number of pages:

To purchase consumables and replacement parts, contact your

Samsung dealer or the retailer where you bought your machine.

We strongly recommend that items be installed by trained

service professional, except for the toner cartridge.

Items Yield (Average)

Paper feeding roller Approx. 60,000 pages

Transfer roller Approx. 60,000 pages

Fuser unit Approx. 60,000 pages

M

AINTENANCE

7.10

Using the Remote Control Panel

Using the Remote Control Panel, you can update the

firmware program of your machine on the desktop of your

computer.

When you install the Samsung Software, the Remote Control

Panel program is automatically installed.

To open the Remote Control Panel:

1

Start Windows.

2

From the

Start

menu, select

Programs

.

3

Select

Samsung SCX-4100 Series

and then

Remote

Control Panel

.

The Remote Control Panel program is opened.

4

The Remote Control Panel window provides the

Firmware

Update

tab.

To exit, click the

Exit

button at the bottom of tab.

For further details, click the

Help

button at the bottom of

tab.

This feature should be used by an authorized technician.

Please consult with the purchase point.

8TROUBLESHOOTING

This chapter gives helpful information for what to do if you

encounter an error.

This chapter includes:

• Clearing Paper Jams

• Clearing LCD Error Messages

• Solving Problems

T

ROUBLESHOOTING

8.2

Clearing Paper Jams

When a paper jam occurs, "Paper Jam" appears on the display.

Refer to the table below to locate and clear the paper jam.

To avoid tearing the paper, pull the jammed paper out gently

and slowly. Follow the steps on the next pages to clear the jam.

In the Paper Tray

1

Open and close the front cover. The jammed paper

automatically exits the machine.

If the paper does not exit, continue to step 2.

2

Pull the paper tray open.

3

Remove the jammed paper by gently pulling it straight out.

If there is any resistance and the paper does not move

when you pull or if you cannot see the paper in this area,

skip to the fuser area around the toner cartridge. See

page 8.5.

Message Location of Jam Go to

Paper Jam 0

Open/Close Door

In the paper tray

page 8.2

Paper Jam 1

Open/Close Door

In the fuser area or

around the toner

cartridge

In the Manual Feeder

page 8.5

page 8.6

Paper Jam 2

Check Inside

In the paper exit area

page 8.3

T

ROUBLESHOOTING

8.3

8

4

Insert the paper tray into the machine until it snaps into

place.

5

Open and close the front cover to resume printing.

In the Paper Exit Area

1

Open and close the front cover. The jammed paper

automatically exits the machine.

If the paper does not exit, continue to step 2.

2

Gently pull the paper out of the front output tray. Skip to

step 9.

If you cannot see the jammed paper in the front output

tray, continue to step 3.

3

Open the jam cover.

4

Pull the paper out gently.

T

ROUBLESHOOTING

8.4

5

Close the jam cover by pushing a tab to the left and hold it

down and lowering the cover carefully until the cover is

holding down the tab.

If there is any resistance and the paper does not move

when you pull or if you cannot see the paper in the jam

cover, continue to step 6.

6

Open the rear cover.

7

Remove the jammed paper by gently pulling it straight out.

8

Close the rear cover.

9

Open and close the front cover to resume printing.

T

ROUBLESHOOTING

8.5

8

In the Fuser Area or Around the Toner

Cartridge

N

OTE

: The fuser area is hot. Take care when removing paper from

the machine.

1

Open the front cover and pull the toner cartridge out,

lightly pushing it down.

2

Remove the jammed paper by gently pulling it straight out.

3

Replace the toner cartridge and close the front cover.

Printing automatically resumes.

T

ROUBLESHOOTING

8.6

In the Manual Feeder

“

Paper Jam 1 Open/Close Door

” appears on the display when you try to

print using the manual feeder and the machine does not detect

paper, due to no paper or improper paper loading.

The error message may also occur when the paper is not

properly fed into the machine through the manual feeder. In that

case, pull the paper out of the machine.

Tips for Avoiding Paper Jams

By selecting the correct paper types, most paper jams can be

avoided. When a paper jam occurs, follow the steps outlined in

page 8.2.

• Follow the procedures on page 1.8 when you load paper.

Ensure that the adjustable guides are positioned correctly.

• Do not overload the paper tray. Ensure that the paper is

below the paper capacity mark on the inside wall of the paper

tray.

• Do not remove the paper from the tray while your machine is

printing.

• Flex, fan, and straighten the paper before loading.

• Do not use creased, damp, or highly curled paper.

• Do not mix paper types in the paper tray.

• Use only recommended print materials. See “Paper

Specifications” on page A.5.

T

ROUBLESHOOTING

8.7

8

• Ensure that the print side of print materials is facing down in

the paper tray and facing up in the manual feeder.

• If paper jams frequently occur when you print on the A5-

sized paper:

- Load the paper into the tray as shown below.

- Open the Samsung SCX-4100 Series Properties window, set

the paper size to

A5(5.8x8.3 in.)

from the

Paper

tab.

- From the

Orientation

option of the

Layout

tab, set the

Rotate

option to

90º

.

Select 90 degrees.

Click.

T

ROUBLESHOOTING

8.8

Clearing LCD Error Messages

Messages appears on the display to indicate the control panel to

indicate the machine’s status or errors. Refer to the following

table to understand the message’s meaning and correct the

problem, if necessary. Messages and their meanings are listed

in alphabetical order.

Display Meaning Suggested solutions

Door Open

The front or rear cover is not

securely latched.

Close the cover until it locks

into place.

[JAM 1] or

[No Cartridge]

The toner cartrige is not

installed.

Install the toner cartridge. See

page 1.6

.

Low Heat Error

There is a problem in the

fuser unit.

Unplug the power cord and

plug it back in. If the problem

persists, please call for

service.

Open Heat Error

[Over Heat]

[LSU Error]

A problem has occurred in

the LSU (Laser Scanning

Unit).

Unplug the power cord and

plug it back in. If the problem

persists, please call for

service.

No Paper

[Add Paper]

The paper tray has run out

of paper.

Load paper in the paper tray.

See page 1.8.

Paper Jam 0

Open/Close Door

Paper has jammed in the

feeding area of the paper

tray.

Clear the jam. See page 8.2.

Paper Jam 1

Open/Close Door

• Paper has jammed in the

fuser area.

• A paper jam has occurred

in the manual feeder or

the machine detects non-

feeding from the manual

feeder.

• Clear the jam. See page 8.5.

• Clear the jam. See page 8.6

Paper Jam 2

Check Inside

Paper has jammed in the

paper exit area.

Clear the jam. See page 8.3.

T

ROUBLESHOOTING

8.9

8

Solving Problems

The following chart lists some conditions that may occur and the

recommended solutions. Follow the suggested solutions until

the problem is corrected. If the problem persists, please call for

service.

Paper Feeding Problems

Condition Suggested solutions

Paper is jammed during

printing.

Clear the paper jam. See page 8.2.

Paper sticks together.

• Ensure that there is not too much paper in the paper tray.

The paper tray can hold up to 250 sheets of paper,

depending on the thickness of your paper.

• Make sure that you are using the correct type of paper. See

“Paper Specifications” on page A.5.

• Remove paper from the paper tray and flex or fan the paper.

• Humid conditions may cause some paper to stick together.

Multiple sheets of paper

do not feed.

• Different types of paper may be stacked in the paper tray.

Load the paper of only one type, size and weight.

• If multiple sheets have caused a paper jam, clear the paper

jam. See page 8.2.

Paper does not feed into

the machine.

• Remove any obstructions inside the machine.

• Paper has not been loaded correctly. Remove paper from the

tray and reload it correctly.

• There is too much paper in the paper tray. Remove excess

paper from the tray.

• The paper is too thick. Use only paper that meets the

specifications required by the machine. See “Paper

Specifications” on page A.5.

The paper keeps

jamming.

• There is too much paper in the paper tray. Remove excess

paper from the tray.

• An incorrect type of paper is being used. Use only paper that

meets the specifications required by the machine. See

“Paper Specifications” on page A.5. If you are printing on

special materials, use the manual feeder.

• There may be debris inside the machine. Open the front

cover and remove the debris.

Transparencies stick

together in the paper

exit.

Use only the transparencies specifically designed for a laser

printer. Remove each transparency as it exits from the

machine.

Envelopes skew or fail

to feed correctly.

Ensure that the paper guides are against both sides of the

envelopes.

T

ROUBLESHOOTING

8.10

Printing Problems

Condition Possible cause Suggested solutions

The machine

does not print.

The machine is not

receiving power.

Check the power cord connections. Check

the power switch and the power source.

The machine is not

selected as the default

printer.

Select

Samsung SCX-4100 Series

as

your default printer in your Windows.

Check the machine for

the following:

• The front or rear

cover is not closed.

• Paper is jammed.

• No paper is loaded.

• The toner cartridge

is not installed.

After locating the problem, clear it.

• Close the cover.

• Clear the paper jam. See page 8.2.

• Load paper. See page 1.8.

• Install the toner cartridge. See page 1.6.

If a printer system error occurs, contact

your service representative.

The connection cable

between the computer

and the machine is not

connected properly.

Disconnect the printer cable and

reconnect it.

The connection cable

between the computer

and the machine is

defective.

If possible, attach the cable to another

computer that is working properly and

print a document. You can also try using a

different printer cable.

The port setting is

incorrect.

Check the Windows printer setting to

make sure that the print job is sent to the

correct port, for example, LPT1. If the

computer has more than one port, make

sure that the machine is attached to the

correct one.

The machine may be

configured incorrectly.

Check the printer properties to ensure

that all of the print settings are correct.

The printer driver may

be incorrectly

installed.

Remove the printer driver and then

reinstall it; see page 1.16 and page 1.16

respectively.

The machine is

malfunctioning. Check the display message on the control

panel to see if the machine is indicating a

system error.

T

ROUBLESHOOTING

8.11

8

The machine

selects print

materials from

the wrong

paper source.

The paper source

selection in the printer

properties may be

incorrect.

For many software applications, the paper

source selection is found under the

Paper

tab within the printer properties.

Select the correct paper source. See

page 3.8.

A print job is

extremely

slow.

The job may be very

complex.

Reduce the complexity of the page or try

adjusting the print quality settings.

The maximum print speed of your

machine is 15 PPM for Letter-sized paper

14 PPM for A4-sized paper.

If you are using

Windows 9x/Me, the

Spooling Setting may

be set incorrectly.

From the

Start

menu, choose

Settings

and

Printers

. Right-click the

Samsung

SCX-4100 Series

printer icon, choose

Properties

, click the

Details

tab, and

then choose the

Spool Settings

button.

Select the spool setting you want.

Half the page

is blank.

The page orientation

setting may be

incorrect.

Change the page orientation in your

application. See page 3.3.

The paper size and the

paper size settings do

not match.

Ensure that the paper size in the printer

driver settings matches the paper in the

tray.

The machine

prints, but the

text is wrong,

garbled, or

incomplete.

The printer cable is

loose or defective.

Disconnect the printer cable and

reconnect. Try a print job that you have

already printed successfully. If possible,

attach the cable and the machine to

another computer and try a print job that

you know works. Finally, try a new printer

cable.

The wrong printer

driver was selected.

Check the application’s printer selection

menu to ensure that your machine is

selected.

The software

application is

malfunctioning.

Try printing a job from another

application.

The operating system

is malfunctioning.

Exit Windows and reboot the computer.

Turn the machine off and then back on

again.

Condition Possible cause Suggested solutions

T

ROUBLESHOOTING

8.12

Pages print,

but are blank.

The toner cartridge is

defective or out of

toner.

Redistribute the toner. if necessary. See

“Redistributing Toner” on page 7.7

.

If necessary, replace the toner cartridge.

The file may have

blank pages.

Check the file to ensure that it does not

contain blank pages.

Some parts, such as

the controller or the

board, may be

defective.

Contact a service representative.

The

illustrations

print

incorrectly in

Adobe

Illustrator.

The setting in the

software application is

wrong.

Select

Download as Bit Image

in the

Advanced Options

window of the

Graphic properties and print the

document.

An error occurs

repeatedly

when you are

printing with

the USB

connection.

When the USB mode

is set to "Fast", some

PC users may

experience poor USB

communication.

Change the USB mode to "Slow". To do

so, follow these steps:

1. Press

Menu/Exit

on the control panel

until "Machine Setup" appears on the

top line of the display.

2. Press the scroll button (



or



) until

"USB Mode" appears on the bottom

line, and press

Start/Enter

.

3. Press the scroll button (



or



) to

select "Slow".

4. Press

Start/Enter

to save the

selection.

5. Press

Stop/Clear

to return to

Standby Mode.

Condition Possible cause Suggested solutions

T

ROUBLESHOOTING

8.13

8

Printing Quality Problems

If the inside of the printer is dirty, or paper is improperly loaded, print quality maybe

reduced. See the table below to clear the problem.

Condition Suggested solutions

Light or faded

print

If a vertical white streak or faded area appears on the page:

• The toner supply is low. You may be able to temporarily

extend the toner cartridge life. See “Redistributing Toner” on

page 7.7. If this does not improve the print quality, install a

new toner cartridge.

• The paper may not meet paper specifications; for example,

the paper is too moist or too rough. See “Paper

Specifications” on page A.5.

• If the entire page is light, the print resolution setting is too

low or Toner Save mode is on. Adjust the print resolution and

turn Toner Save mode off. See page 3.8 and page 1.27

respectively.

• A combination of faded or smeared defects may indicate that

the toner cartridge needs cleaning. See “Cleaning the Drum”

on page 7.9.

• The surface of the document glass may be dirty. Clean the

document glass. See page 7.5.

• The surface of the LSU may be dirty. Clean the LSU. See

page 7.4.

Toner specks

• The paper may not meet specifications; for example, the

paper is too moist or too rough. See “Paper Specifications” on

page A.5.

• The transfer roller or paper path may be dirty. Clean the

inside of your machine and the drum. See page 7.3 and

page 7.9.

Dropouts

If generally rounded faded areas, occur randomly on the

page:

• A single sheet of paper may be defective. Try reprinting the

job.

• The moisture content of the paper is uneven or the paper has

moist spots on its surface. Try a different brand of paper. See

“Paper Specifications” on page A.5.

• The paper lot is bad. The manufacturing process can cause

some areas to reject toner. Try a different kind or brand of

paper.

• The toner cartridge may be defective.

Vertical repetitive

defects

on the next page.

• If these steps do not correct the problems, contact a service

representative.

T

ROUBLESHOOTING

8.14

Vertical lines

If black vertical streaks appear on the page:

• The drum inside the toner cartridge has probably been

scratched. Remove the toner cartridge and install a new one.

See “Replacing the Toner Cartridge” on page 7.8.

If white vertical streaks appear on the page:

• The surface of the LSU part inside the machine may be dirty.

Clean the LSU (Clean the LSU. See page 7.4.

Gray background

If the amount of background shading becomes

unacceptable:

• Change to a lighter weight pages. See “Paper Specifications”

on page A.5.

• Check the machine’s environment; very dry (low humidity) or

high humidity (higher than 80% RH) conditions can increase

the amount of background shading.

• Remove the old toner cartridge and install a new one. See

“Replacing the Toner Cartridge” on page 7.8.

Toner smear

• Clean the inside of the machine. See page 7.3.

• Check the paper type and quality. See “Paper Specifications”

on page A.5.

• Remove the toner cartridge and install a new one. See

“Replacing the Toner Cartridge” on page 7.8.

Vertical repetitive

defects

If marks repeatedly appear on the printed side of the page

at even intervals:

• The toner cartridge may be damaged. If a repetitive mark

occurs on the page, print a cleaning sheet several times to

clean the cartridge; see “Cleaning the Drum” on page 7.9.

After the printout, if you still have the same problems,

remove the toner cartridge and install a new one. See

“Replacing the Toner Cartridge” on page 7.8

.

• Parts of the machine may have toner on them. If the

defects occur on the back of the page, the problem will

likely correct itself after a few more pages.

• The fusing assembly may be damaged. Contact a service

representative.

Condition Suggested solutions

T

ROUBLESHOOTING

8.15

8

Background

scatter

Background scatter results from bits of toner distributed on

the printed page.

• The paper may be too damp. Try printing with a different

batch of paper. Do not open packages of paper until

necessary so that the paper does not absorb too much

moisture.

• If background scatter occurs on an envelope, change the

printing layout to avoid printing over areas that have

overlapping seams on the reverse side. Printing on seams can

cause problems.

• If background scatter covers the entire surface area of a

printed page, adjust the print resolution through your

software application or the printer properties.

Miss-formed

characters

• If characters are improperly formed and producing hollow

images, the paper stock may be too slick. Try a different

paper. See “Paper Specifications” on page A.5.

• If characters are improperly formed and producing a wavy

effect, the scanner unit may need service. For service,

contact a service representative.

Page skew

• Ensure that the paper is loaded properly.

• Check the paper type and quality. See “Paper Specifications”

on page A.5.

• Ensure that the paper or other material is loaded correctly

and the guides are not too tight or too loose against the

paper stack.

Curl or wave

• Ensure that the paper is loaded properly.

• Check the paper type and quality. Both high temperature and

humidity can cause paper curl. See “Paper Specifications” on

page A.5.

• Turn the stack of paper over in the paper tray. Also try

rotating the paper 180° in the tray.

• Try printing to the rear output slot.

Condition Suggested solutions

T

ROUBLESHOOTING

8.16

Wrinkles or

creases

• Ensure that the paper is loaded properly.

• Check the paper type and quality. See “Paper Specifications”

on page A.5.

• Turn the stack of paper over in the paper tray. Also try

rotating the paper 180° in the tray.

• Try printing to the rear output slot.

Back of printouts

are dirty

Check for leaking toner. Clean the inside of the machine.

See page 7.3.

Black pages

• The toner cartridge may not be installed properly. Remove

the cartridge and reinsert.

• The toner cartridge may be defective and need replacing.

Remove the toner cartridge and install a new one. See

“Replacing the Toner Cartridge” on page 7.8.

• The machine may require repair. Contact a service

representative.

Loose toner

• Clean the inside of the machine. See page 7.3.

• Check the paper type and quality. See “Paper Specifications”

on page A.5.

• Remove the toner cartridge and install a new one. See

“Replacing the Toner Cartridge” on page 7.8.

• If the problem persists, the machine may require repair.

Contact a service representative.

Condition Suggested solutions

A

T

ROUBLESHOOTING

8.17

8

Character Voids

Character voids are white areas within the parts of

characters that should be solid black:

• If you are using transparencies, try another type of

transparency. Due to the composition of the transparency,

some character voids are normal.

• You may be printing on the wrong side of the paper. Remove

the paper and turn it around.

• The paper may not meet paper specifications. See “Paper

Specifications” on page A.5.

Horizontal stripes

If horizontally aligned black streaks or smears appear:

• The toner cartridge may be installed improperly. Remove and

reinsert the cartridge.

• The toner cartridge may be defective. Remove the toner

cartridge and install a new one. See “Replacing the Toner

Cartridge” on page 7.8.

• If the problem persists, the machine may require repair.

Contact a service representative.

Curl

If the printed paper is curl or paper does not feed into the

printer:

• Turn the stack of paper over in the paper tray. Also try

rotating the paper 180° in the paper tray.

• Try printing to the rear output slot.

Condition Suggested solutions

T

ROUBLESHOOTING

8.18

Copying Problems

Condition Suggested solutions

Copies are too light or too

dark.

Use the "Darkness" feature to darken or lighten the

background of the copies.

Smears, lines, marks or

spots appears on copies.

• If defects are on the original document, use the

"Darkness"

feature

to lighten the background of your

copies.

• If no defects are on the original document, clean the

document glass and underside of the document cover.

See page 7.5.

Copy image is skewed.

• Ensure that the original document is positioned

correctly on the document glass.

• Check that the copy paper is loaded correctly.

Blank copies print out. Ensure that the original document is face down on

the document glass.

Image rubs off the copy

easily.

• Replace the paper in the paper tray with paper from a

new package.

• In high humidity areas, do not leave paper in the

machine for the extended periods of time.

Frequent copy paper jams

occurs.

• Fan the stack of paper, then turn it over in the paper

tray. Replace the paper in the tray with a fresh supply.

Check/adjust the paper guides, if necessary.

• Ensure that the paper is the proper paper weight.

75g/m

2

(20 lb) bond paper is recommended.

• Check for copy paper or pieces of copy paper

remaining in the machine after a paper jam has been

cleared.

Fewer copies from the toner

cartridge than expected

prints out.

• Your original documents may contain pictures, solids

or heavy lines. For example, they may be forms,

newsletters, books or other documents that use more

toner.

• The machine may be turned frequently on and off.

• The document cover may be left open while copies are

being made.

T

ROUBLESHOOTING

8.19

8

Scanning Problems

Condition Suggested solutions

The scanner does not work.

• Make sure that you place the document to be scanned

face down on the document glass.

• There may not be enough available memory to hold

the document you want to scan. Try the Prescan

function to see if that works. Try lowering the scan

resolution rate.

• Check that the USB or parallel cable is connected

properly.

• Make sure that the USB or parallel cable is not

defective. Switch the cable with a known good cable.

If necessary, replace the cable.

• If you are using a parallel cable, ensure that it is

compliant with the IEEE 1284 standard.

• Check that the scanner is configured correctly. Check

scan setting in the SmarThru Configuration or the

application you want to use to make certain that the

scanner job is being sent to the correct port, for

example, LPT1.

The unit scans very slowly.

• Check if the machine is printing received data. Scan

the document after the current job is completed.

• Graphics are scanned more slowly than text.

• Communication speed becomes slow in scan mode

because of the large amount of memory required to

analyze and reproduce the scanned image. Set your

computer to the ECP printer mode through BIOS

setting. It will help to increase the speed. For details

about how to set BIOS, refer to your computer user’s

guide.

Message appears on your

computer screen:

• “Device can't be set to the

H/W mode you want.”

• “Port is being used by

another program.”

•“Port is Disabled.”

• “Scanner is busy receiving

or printing data. When the

current job is completed,

try again.”

• “Invalid handle.”

• “Scanning has failed.”

• There may be a copying or printing job in progress.

When the current job is complete, try the job again.

• The selected port is currently being used. Restart your

computer and try again.

• The printer cable may be improperly connected or the

power may be off. You must use a USB 1.1 compliant

cable or a parallel cable that supports IEEE-1284 bi-

directional communications.

• The scanner driver is not installed or an operating

environment is not set up properly.

• Ensure that port is properly connected and power is

on, and then restart your computer.

• Do not use the parallel and the USB cables at the

same time.

T

ROUBLESHOOTING

8.20

Common Linux Problems

Problem Possible Cause and Solution

The machine doesn't print

• Check if the printer driver is installed in your system.

Open MFP configurator and switch to the Printers tab in

Printers configuration window to look at the list of

available printers. Make sure that your machine is

displayed on the list. If not, please, invoke Add new

printer wizard to set up your device.

• Check if the printer is started. Open Printers

configuration and select your machine on the printers list.

Look at the description in the Selected printer pane. If its

status contains "(stopped)" string, please, press the Start

button. After that normal operation of the printer should

be restored. The "stopped" status might be activated

when some problems in printing occurred. For instance,

this could be an attempt to print document when MFP

port is claimed by a scanning application.

• Check if the MFP port is not busy. Since functional

components of MFP (printer and scanner) share the same

I/O interface (MFP port), the situation of simultaneous

access of different "consumer" application to the same

MFP port is possible. To avoid possible conflicts, only one

of them at a time is allowed to gain control over the

device. The other "consumer" will encounter "device

busy" response. You should open MFP ports configuration

and select the port assigned to your printer. In the

Selected port pane you can see if the port is occupied by

some other application. If this is the case, you should

wait for completion of the current job or should press

Release port button, if you are sure that the present

owner is not functioning properly.

• Check if your application has special print option such as

"-oraw". If "-oraw" is specified in the command line

parameter then remove it to print properly. For Gimp

front-end, select "print" -> "Setup printer" and edit

command line parameter in the command item.

The machine does not

appear on the scanners list

• Check if your machine is attached to your computer.

Make sure that it is connected properly via the USB port

and is turned on.

• Check if the scanner driver for you machine is installed in

your system. Open MFP Configurator, switch to Scanners

configuration, then press

Drivers

. Make sure that driver

with a name corresponding to your machine's name is

listed in the window.

T

ROUBLESHOOTING

8.21

8

The machine does not

appear on the scanners

list (continued)

• Check if the MFP port is not busy. Since functional

components of MFP (printer and scanner) share the same

I/O interface (MFP port), the situation of simultaneous

access of different "consumer" application to the same

MFP port is possible. To avoid possible conflicts, only one

of them at a time is allowed to gain control over the

device. The other "consumer" will encounter "device

busy" response. This can usually happen while starting

scan procedure, and appropriate message box displays.

To identify the source of the problem, you should open

MFP ports configuration and select the port assigned to

your scanner. MFP port's symbol /dev/mfp0 corresponds

to LP:0 designation displayed in the scanners' options, /

dev/mfp1 relates to LP:1 and so on. USB ports start at /

dev/mfp4, so scanner on USB:0 relates to /dev/mfp4

respectively and so forth sequentially. In the Selected

port pane you can see if the port is occupied by some

other application. If this is the case, you should wait for

completion of the current job or should press Release

port button, if you are sure that the present port's owner

is not functioning properly.

The machine doesn't scan

• Check if a document is loaded into the machine.

• Check if your machine is connected to the computer.

Make sure if it is connected properly if I/O error is

reported while scanning.

• Check if MFP port is not busy. Since functional

components of MFP (printer and scanner) share the same

I/O interface (MFP port), the situation of simultaneous

access of different "consumer" application to the same

MFP port is possible. To avoid possible conflicts, only one

of them at a time is allowed to gain control over the

device. The other "consumer" will encounter "device

busy" response. This can usually happen while starting

scan procedure, and appropriate message box will be

displayed.

To identify the source of the problem, you should open

MFP ports configuration and select the port assigned to

your scanner. MFP port's symbol /dev/mfp0 corresponds

to LP:0 designation displayed in the scanners' options, /

dev/mfp1 relates to LP:1 and so on. USB ports start at /

dev/mfp4, so scanner on USB:0 relates to /dev/mfp4

respectively and so forth sequentially. In the Selected

port pane you can see if the port is occupied by some

other application. If this is the case, you should wait for

completion of the current job or should press Release

port button, if you are sure that the present port's owner

is not functioning properly

.

Problem Possible Cause and Solution

T

ROUBLESHOOTING

8.22

I can't print when I

installed both Linux

Print Package (LPP) and

MFP driver on the same

machine

simultaneously.

• Since both Linux Printer Package and MFP driver make

a symbolic link to "lpr" printing command, which is

commonly used on Unix clones, it is not recommended

to use both package on the same machine.

• If you still want to use both packages simultaneously,

please install the LPP first.

• If you want to uninstall only one of them, please

uninstall both packages and install that one you want

to use again.

• If you don't want to uninstall MFP driver and install it

again, you may make the necessary symbolic link

yourself. Please, log in as root user and invoke the

following command:

ln -sf /usr/local/bin/samsung/slpr /usr/bin/lpr

Can't scan via Gimp

Front-end.

• Check if Gimp Front-end has "Xsane:Device dialog.." on

the "Acquire" menu. If not, you should install Xsane plug-

in for Gimp on the your computer. You can find Xsane

plug-in package for Gimp on Linux distribution CD or

Gimp home page. For the detail information, refer to the

Help for Linux distribution CD or Gimp Front-end

application.

If you wish to use other kind of scan application, refer to

the Help for application.

I encounter error “Cannot

open MFP port device file”

when printing a

document.

• Please avoid changing print job parameters (via SLPR

utility, for example) while a print job is in progress.

Known versions of CUPS server break the print job

whenever print options are changed and then try to

restart the job from the beginning. Since Linux MFP

driver locks MFP port while printing, the abrupt

termination of the driver keeps the port locked and

therefore unavailable for subsequent print jobs. If this

situation occurred, please, try to release the MFP port.

Problem Possible Cause and Solution

ASPECIFICATIONS

This chapter includes:

• General Specifications

• Scanner and Copier Specifications

• Printer Specifications

• Paper Specifications

A.2

General Specifications

Item Description

Paper input capacity Paper tray: 250 sheets (weight: 75 g/m

2

, 20 lb)

Manual feeder: 1 sheet (weight: 75 g/m

2

, 20 lb)

Paper output capacity Front output tray: 50 sheets (face down)

Rear output slot: 1 sheet (face up)

Paper type Paper tray: Plain paper (60 ~ 90 g/m

2

, 16 ~ 24 lb)

Manual feeder: Plain paper, Transparencies, Labels, Card

stock, Thick, Thin, Bond, Preprinted, Colored, Envelopes (60

~ 163 g/m

2

, 16 ~ 43 lb)

Power requirements 110 ~ 127 VAC, 50/60 Hz, 4.0 A

220 ~ 240 VAC, 50/60 Hz, 2.5 A

Power consumption Sleep mode: 10W

Standby mode: 85W

Average: 300 W

Noise

*

Warm-up: Less than 42 dB

Standby mode: Less than 38 dB

Scanning / Printing: Less than 49 dB

Warm-up Time 42 seconds

Operating conditions Tem pe ratur e: 5 0

o

F to 89

o

F (10

o

C to 32

o

C)

Humidity: 20 % to 80 % RH

LCD 16 characters x 2 lines

Duty Cycle Monthly: Up to 10,000 pages (Print)

Monthly: Up to 2,000 pages (Scan)

Consumables Single Cartridge

Toner cartridge life

**

3,000 pages at ISO 19752 5 % coverage

(Ships with 1,000 pages Starter Toner Cartridge)

SET dimension (W x D x H) 422 x 400 x 239 mm (16.6 x 15.8 x 9.4 inch)

Weight Net: 8.85 Kg (including consumables)

Gross: 12.05 Kg(26.55 lb)

(including consumables, accessories and package)

Package Weight Paper: 2.5 Kg

Plastic: 0.7 Kg

A.3

A

Scanner and Copier Specifications

Interface USB 1.1 (Compatible with USB 2.0),

IEEE 1284 Parallel(ECP Only)

OS Compatibility

***

•

Windows 95/98/Me/NT 4.0/2000/XP

•

Various Linux OS (via USB interface only) including

RedHat, Caldera, Mandrake, Slackware, SuSE and

Turbo Linux

* Sound Pressure Level, ISO7779.

** May be affected by operating environment, printing interval, media type, media size and

color/black.

*** Please visit www.samsungprinter.com to download the latest software version.

Item Description

Compatibility TWAIN standard

Scan method Color CIS

Scan resolution 600 X 600 dpi (optical)

Scan length Maximum: 11.7 inches (297 mm)

Scan width Maximum: 8.5 inches (216 mm)

Effective: 8.2 inches (208 mm)

Color bit depth 8 bit, 24 bit

Mono bit depth 1 bit for Text mode

8 bit for Gray mode

Scan speed 27 seconds (Lineart)

72 seconds (Gray Scale)

150 seconds (Color 300dpi)

Copy speed

*

* Copy Speed is based on Single Document Multiple Copy.

Up to 14 cpm in A4 (15 cpm in Letter)

Copy resolution 600 x 600 dpi

Zoom rate 50 ~ 200 %

Multiple copies 99 pages

Halftone 256 levels

Item Description

A.4

Printer Specifications

Item Description

Print method Laser Beam Printing

Print speed

*

* Print speed will be affected by Operating system used, computing performance, application

software, connecting method, media type, media size and job complexity.

Up to 14 ppm in A4 (15 ppm in Letter)

Paper size Paper tray: Letter, A4, Legal, Folio, A5, A6, B5

Manual feeder: Letter, A4, Legal, Folio, Executive, A5, B5,

Post Card 4x6, Envelope 10, Envelope DL, Envelope C5,

Envelope C6, Envelope Monarch, Envelope B5

* Min.: 76 x 127 mm (3 x 5 in.)

Max.: 216 x 356 mm (8.5 x 14 in.)

Print resolution 600 x 600 dpi

Emulation SPL (Samsung Printer Language)

Memory 8MB (Max. 8MB)

First printing time Standby mode: 12 seconds

A.5

A

Paper Specifications

Overview

Your machine accepts a variety of print materials, such as cut-sheet paper, including

up to 100% recycled fiber content paper, envelopes, labels, transparencies, and

custom-size paper. Properties, such as weight, composition, grain, and moisture

content, are important factors affecting the machine’s performance and the output

quality. Paper that does not meet the guidelines outlined in this user’s guide can

cause the following problems:

•

Poor print quality

•

Increased paper jams

•

Premature wear on the machine.

N

OTES

:

• Some paper may meet all of the guidelines in this guide and still not produce

satisfactory results. This may be the result of improper handling, unacceptable

temperature and humidity levels or other variables over which Samsung has no

control.

• Before purchasing large quantities of paper, insure the paper meets the requirements

specified in this user’s guide.

C

AUTION

: Using paper that does not meet these specifications may cause problems,

requiring repairs. These repairs are not covered by the Samsung warranty or service

agreements.

A.6

Supported Sizes of Paper

N

OTE

: You may experience jams when using print materials with a length of less than

127 mm (5 in.). For optimum performance, ensure that you are storing and handling the

paper correctly. Please refer to “Paper Storage Environment” on page A.9.

Size (mm/in.) Weight Capacity

*

* Capacity may vary depending on print materials’ weight and thickness, and environmental

conditions.

Plain paper

Letter (216 x 279/8.5 x 11)

Legal (216 x 356/8.5 x 14)

Executive (184 x 267/7.2 x 10.5)

A4 (210 x 297/8.3 x 11.7)

A5 (148 x 210/5.8 x 8.3)

A6 (105 x 148/4.1 x 5.8)

Folio (216 x 330/8.5 x 13)

•60 to 90 g/m

2

bond (16 to 24

lb) for the paper

tray

• 60 to 163 g/m

2

bond (16 to 43

lb) for the

manual feeder

• 250 sheets of 75

g/m

2

bond (20 lb)

paper for the

paper tray

•1 sheet of paper

for the manual

feeder

Envelopes

JIS B5 (182 x 257/7.2 x 10.1)

No.10 (105 x 241/4.1 x 9.5)

DL (110 x 220/4.3 x 8.7)

C5 (162 x 229/6.4 x 9)

C6 (114 x 162/4.5 x 6.4)

ISO B5 (176 x 250/6.9 x 9.8)

Monarch (98 x 191/3.9 x 7.5)

75 to 90 g/m

2

1 sheet of paper for the

manual feeder

Labels

Letter (216 x 279/8.5 x 11)

A4 (210 x 297/8.3 x 11.7)

120 to 150 g/m

2

1 sheet of paper for the

manual feeder

Transparency films

Letter (216 x 279/8.5 x 11)

A4 (210 x 297/8.3 x 11.7)

138 to 146 g/m

2

Card stocks

Post Card (101.6 x 152.4/4 x 6)

90 to 163 g/m

2

Minimum size (custom) 60 to 120 g/m

2

bond

(16 to 32 lb)

Maximum size (Legal)

A.7

A

Guidelines for Using Paper

For the best result, use conventional 75 g/m

2

(20 lb) paper. Ensure that the paper is

of good quality, and free of cuts, nicks, tears, spots, loose particles, dust, wrinkles,

voids, and curled or bent edges.

If you are unsure of what type of paper you are loading, such as bond or recycled

paper, check the label on the package.

The following problems may cause print quality deviations, jamming, or even damage

to the machine:

N

OTES

:

• Do not use letterhead paper printed with low-temperature inks, such as those used in

some types of thermography.

• Do not use raised or embossed letterhead.

• The machine uses heat and pressure to fuse toner to the paper. Insure that any

colored paper or preprinted forms use inks that are compatible with this fusing

temperature (189 °C or 372.2 °F for 0.1 second).

Symptom Problem with Paper Solution

Poor print quality or toner

adhesion, problems with

feeding

Too moist, too rough, too

smooth, or embossed;

faulty paper lot

Try another kind of paper,

between 100 ~ 400 Sheffield, 4

~ 5 % moisture content.

Dropout, jamming, curl Stored improperly Store paper flat in its moisture-

proof wrapping.

Increased gray background

shading/machine wear

Too heavy Use lighter paper, use the rear

output slot.

Excessive curl problems

with feeding

Too moist, wrong grai n

direction, or short-grain

construction

• Use the rear output slot.

• Use long-grain paper.

Jamming, damage to

machine

Cut-outs or perforations Do not use paper with cutouts

or perforations.

Problems with feeding Ragged edges Use good quality paper.

A.8

Paper Specifications

Paper Output Capacity

Category Specifications

Acid Content 5.5 pH or lower

Caliper 0.094 ~ 0.18 mm (3.0 ~ 7.0 mils)

Curl in Ream Flat within 5 mm (0.02 in.)

Cut Edge Conditions Cut with sharp blades with no visible fray.

Fusing Compatibility Must not scorch, melt, offset or release hazardous

emissions when heated to 200 °C (392 °F) for 0.1

second.

Grain Long Grain

Moisture Content 4 % ~ 6 % by weight

Smoothness 100 ~ 400 Sheffield

Output Location Capacity

Face-down output tray 50 sheets of 75 g/m

2

bond (20 lb) paper

Face-up output slot 1 sheet of 75 g/m

2

bond (20 lb) paper

A.9

A

Paper Storage Environment

Paper storage environment conditions directly affect the feed operation.

Ideally, the machine and paper storage environment should be at or near room

temperature, and not too dry or humid. Remember that paper is hygroscopic; it

absorbs and loses moisture rapidly.

Heat works with humidity to damage paper. Heat causes the moisture in paper to

evaporate, while cold causes it to condense on the sheets. Heating systems and air

conditioners remove most of the humidity from a room. As paper is opened and used,

it loses moisture, causing streaks and smudging. Humid weather or water coolers can

cause the humidity to increase in a room. As paper is opened and used it absorbs any

excess moisture, causing light print and dropouts. Also, as paper loses and gains

moisture it can become distorted. This can cause paper jams.

Care should be taken not to purchase more paper than can be used in a short time

(about 3 months). Paper stored for long periods may experience heat and moisture

extremes, which can cause damage. Planning is important to prevent damage to

large supplies of paper.

Unopened paper in sealed reams can remain stable for several months before use.

Opened packages of paper have more potential for environment damage, especially

if they are not wrapped with a moisture-proof barrier.

The paper storage environment should be properly maintained to ensure optimum

performance. The optimum condition is 20 to 24 °C (68 to 75 °F), with a relative

humidity of 45 % to 55 %. The following guidelines should be considered when

evaluating the paper’s storage environment:

•

Paper should be stored at or near room temperature.

•

The air should not be too dry or too humid.

•

The best way to store an opened ream of paper is to rewrap it tightly in its moisture-

proof wrapping. If the machine environment is subject to extremes, unwrap only the

amount of paper to be used during the day’s operation to prevent unwanted moisture

changes.

A.10

Envelopes

Envelope construction is critical. Envelope fold lines can vary considerably, not only

between manufacturers, but also within a box from the same manufacturer.

Successful printing on envelopes depends upon the quality of the envelopes. When

selecting envelopes, consider the following components:

•

Weight: The weight of the envelope paper should not exceed 90g/m

2

(24lb) or

jamming may occur.

•

Construction: Prior to printing, envelopes should lie flat with less than 6mm (0.25in.)

curl, and should not contain air.

•

Condition: Envelopes should not be wrinkled, nicked or otherwise damaged.

•

Temperature: You should use envelopes that are compatible with the heat and

pressure of the machine.

•

Size: You should only use envelopes within the following size ranges

N

OTES

:

• Use only the manual feeder to print envelopes.

• You may experience some paper jams when using any media with a length less than

140 mm

(

5.5 in.). This may be caused by paper that has been affected by

environmental conditions. For optimum performance, make sure you are storing and

handling the paper correctly. Please refer to “Paper Storage Environment” on page A.9.

Envelopes with Double Side Seams

Double side-seam construction has vertical seams at both ends of the envelope

rather than diagonal seams. This style may be more likely to wrinkle. Be sure the

seam extends all the way to the corner of the envelope as illustrated below.

Correct

Incorrect

A.11

A

Envelopes with Adhesive Strips or Flaps

Envelopes with a peel-off adhesive strip or with more than one flap that folds over to

seal must use adhesives compatible with the heat and pressure in the machine. The

extra flaps and strips might cause wrinkling, creasing or even jams and may even

damage the fuser.

Envelope Margins

The following gives typical address margins for a commercial #10 or DL envelope.

N

OTES

:

• For the best print quality, position margins no closer than 15 mm (0.6 in.) from the

edges of the envelope.

• Avoid printing over the area where the envelope’s seams meet.

Envelope Storage

Proper storage of envelopes helps contribute to print quality. Envelopes should be

stored flat. If air is trapped in an envelope, creating an air bubble, then the envelope

may wrinkle during printing.

Type of Address Minimum Maximum

Return address 15 mm (0.6 in.) 51 mm (2 in.)

Delivery address 51 mm (2 in.) 90 mm (3.5 in.)

A.12

Labels

C

AUTIONS

:

• To avoid damaging the machine, use only labels recommended for laser printers.

• To prevent serious jams, always use the manual feeder to print labels and always use

the rear output tray.

• Never print on the same sheet of labels more than once and never print on a partial

sheet of labels.

When selecting labels, consider the quality of each component:

•

Adhesives: The adhesive material should be stable at 208°C (406.4°F), the machine’s

fusing temperature.

•

Arrangement: Only use labels with no exposed backing between them. Labels can

peel off sheets with spaces between the labels, causing serious jams.

•

Curl: Prior to printing, labels must lie flat with no more than 13mm (5in.) of curl in

any direction.

•

Condition: Do not use labels with wrinkles, bubbles or other indications of separation.

Transparencies

Transparencies used in the machine must be able to withstand 165°C (329°F), the

machine’s fusing temperature.

C

AUTION

: To avoid damaging the machine, use only transparencies recommended for

use in laser printers.

INDEX

Numerics

2-side, special copy

4.10

2-up, special copy

4.11

A

auto fit, special copy

4.9

C

canceling

copy

4.4

print

3.5

scan

5.5

cleaning

document glass

7.5

drum

7.9

inside

7.3

outside

7.3

clone, special copy

4.8

connect

parallel cable

1.11

USB cable

1.11

connection

AC power

1.13

consumables

7.9

control panel

1.5

copying

4.3

darkness, set

4.5

default setting, change

4.13

number of pages

4.5

original type

4.7

size

4.6

special features

4.8

time out, set

4.14

D

Darkness

4.5

display language, change

1.25

document

loading

1.8

preparing

4.2

document glass

clean

7.5

load

4.3

drum, clean

7.9

E

error messages

8.8

F

Favorite setting, use

3.6

fitting to page

copy

4.9

print

3.13

front output tray, use

2.5

G

Getting

6.2

graphic properties, set

3.8

H

help, use

3.6

I

installing

Linux software

6.3

SmarThru

1.20

toner cartridge

1.6

J

jam, clear

paper

8.2

L

Linux

common problems

8.20

driver, install

6.4

printing

6.12

scanning

6.14

M

memory, clear

7.2

MFP driver, install

Linux

6.4

N

network printer, set

3.22

n-up (multiple pages per sheet)

copy

4.11

O

orientation, print

3.3

,

6.13

output location, select

2.4

overlay, use

3.18

P

paper guidelines

2.3

paper jam, clear

8.2

paper load

in manual feeder

2.9

in paper tray

1.8

paper load capacity

2.2

paper properties, set

3.7

paper size, set

manual feeder

2.11

paper tray

1.26

print

3.7

,

6.13

paper source, set

3.8

,

6.13

paper type

2.2

paper type, set

manual feeder

2.11

paper tray

1.26

print

3.8

,

6.13

poster

copy

4.12

print

3.14

power save mode, use

1.27

print order, set

3.4

print resolution

3.9

print,system data

7.2

printer driver, install

Linux

6.4

printer properties

Linux

6.12

windows

3.2

printing

fitting to a selected paper size

3.13

from Linux

6.12

from Windows

3.2

multiple pages on one sheet

3.10

posters

3.14

reduced or enlarged document

3.12

using overlays

3.18

watermarks

3.15

problems, solve

copying

8.18

error messages

8.8

Linux

8.20

paper feeding

8.9

printing

8.10

printing quality

8.13

scanning

8.19

R

rear output slot, use

2.6

reduced/enlarged

copy

4.6

print

3.12

resolution

print

3.9

S

scanning

Linux

6.14

Windows

5.2

sharing printer, set

3.22

SmarThru

install

1.20

uninstall

1.24

specifications

general

A.2

paper

A.5

printer

A.4

scanner and copier

A.3

system requirements

Linux

6.3

Windows

1.16

T

toner cartridge

install

1.6

life

7.6

redistribute

7.7

replace

7.8

toner save mode, use

1.27

TWAIN, scan

5.6

U

uninstalling

MFP driver

Linux

6.6

Windows

1.23

Remote Control Panel

1.23

SmarThru

1.24

USB

mode, change

8.12

W

watermarks, use

3.15
