LCD TV

user manual

imagine the possibilities

Thank you for purchasing this Samsung product.

To receive more complete service, please register

your product at

www.samsung.com/register

Model Serial No.

Contact SAMSUNG WORLDWIDE

If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center.

Comuníquese con SAMSUNG WORLDWIDE

Si desea formular alguna pregunta o comentario en relación con los productos de Samsung, comuníquese con el centro de

atención al cliente de SAMSUNG.

Country Customer Care Center

Web Site Address

CANADA 1-800-SAMSUNG(726-7864) www.samsung.com

Samsung Electronics Canada Inc., Customer

Service 55 Standish Court Mississauga,

Ontario L5R 4B2 Canada

Samsung Electronique Canada Inc.,

Service à la Clientèle 55 Standish Court

Mississauga, Ontario L5R 4B2 Canada

U.S.A 1-800-SAMSUNG(726-7864) www.samsung.com

Samsung Electronics America, Inc.

105 Challenger Road

Ridgefield Park, NJ 07660-0511

BN68-02604A-04

BN68-02604A_Eng.indb 1 2010-06-29 �� 10:39:51

English

Figures and illustrations in this User Manual are provided for reference only and may differ from actual product appearance.

Product design and speciﬁcations may be changed without notice.

Important Warranty Information Regarding Television Format Viewing

See the warranty card for more information on warranty terms.

✎

Wide screen format LCD Displays (16:9, the aspect ratio of the screen width to height) are primarily designed to view wide screen format full-

motion video. The images displayed on them should primarily be in the wide screen 16:9 ratio format, or expanded to ﬁll the screen if your model

offers this feature and the images are constantly moving. Displaying stationary graphics and images on screen, such as the dark sidebars on

nonexpanded standard format television video and programming, should be limited to no more than 5% of the total television viewing per week.

Additionally, viewing other stationary images and text such as stock market reports, video game displays, station logos, web sites or computer

graphics and patterns, should be limited as described above for all televisions. Displaying stationary images that exceed the above guidelines

can cause uneven aging of LCD Displays that leave subtle, but permanent burned-in ghost images in the LCD picture. To avoid this, vary the

programming and images, and primarily display full screen moving images, not stationary patterns or dark bars. On LCD models that offer picture

sizing features, use these controls to view different formats as a full screen picture.

Be careful in the selection and duration of television formats used for viewing. Uneven LCD aging as a result of format selection and use, as well as

burned-in images, are not covered by your Samsung limited warranty.

SAMSUNG ELECTRONICS NORTH AMERICAN LIMITED WARRANTY STATEMENT•

Subject to the requirements, conditions, exclusions and limitations of the original Limited Warranty supplied with Samsung Electronics

(SAMSUNG) products, and the requirements, conditions, exclusions and limitations contained herein, SAMSUNG will additionally provide

Warranty Repair Service in the United States on SAMSUNG products purchased in Canada, and in Canada on SAMSUNG products

purchased in the United States, for the warranty period originally speciﬁed, and to the Original Purchaser only.

The above described warranty repairs must be performed by a SAMSUNG Authorized Service Center. Along with this Statement, the Original

Limited Warranty Statement and a dated Bill of Sale as Proof of Purchase must be presented to the Service Center. Transportation to and

from the Service Center is the responsibility of the purchaser. Conditions covered are limited only to manufacturing defects in material or

workmanship, and only those encountered in normal use of the product.

Excluded, but not limited to, are any originally speciﬁed provisions for, in-home or on-site services, minimum or maximum repair times,

exchanges or replacements, accessories, options, upgrades, or consumables.

For the location of a SAMSUNG Authorized Service Center, please call toll-free:

In the United States : 1-800-SAMSUNG (1-800-726-7864) –

In Canada : 1-800-SAMSUNG –

Still image warning

Avoid displaying still images (such as jpeg picture ﬁles) or still image elements (such as TV channel logos, panorama or 4:3 image format, stock

or news bars at screen bottom etc.) on the screen. Constant displaying of still pictures can cause ghosting of LCD screen, which will affect image

quality. To reduce risk of this effect, please follow below recommendations:

Avoid displaying the same TV channel for long periods.•

Always try to display any image on full screen, use TV set picture format menu for best possible match.•

Reduce brightness and contrast values to minimum required to achieve desired picture quality, exceeded values may speed up the burnout •

process.

Frequently use all TV features designed to reduce image retention and screen burnout, refer to proper user manual section for details.•

Securing the Installation Space

Keep the required distances between the product and other objects (e.g. walls) to ensure proper ventilation.

Failing to do so may result in ﬁre or a problem with the product due to an increase in the internal temperature of the product.

When using a stand or wall-mount, use parts provided by Samsung Electronics only.

✎

If you use parts provided by another manufacturer, it may result in a problem with the product or an injury due to the product falling.

The appearance may differ depending on the product.

✎

Installation with a stand. Installation with a wall-mount.

4inches

BN68-02604A_Eng.indb 2 2010-06-29 �� 10:39:51

Contents

English

ENGLISH

Getting Started

List of Features y ......................................................... 4

Accessories y .............................................................. 4

Installing the LCD TV Stand y ...................................... 4

Viewing the Control Panel y ......................................... 5

Viewing the Remote Control y ...................................... 6

Connecting to an Antenna y ........................................ 7

Plug & Play (Initial Setup) y ........................................... 7

Connections

Connecting to an AV Device y ...................................... 8

Connecting to an Audio Device y ................................. 9

Connecting to a PC y .................................................. 9

Changing the Input source y ...................................... 11

Basic Features

How to Navigate Menus y .......................................... 11

Channel Menu y ........................................................ 12

Seeing Channels 12

Using Favorite Channels 12

Memorizing channels 12

Editing channels 13

Other Features 13

Picture Menu y .......................................................... 14

Changing the Preset Picture Mode 14

Adjusting picture settings 14

Economical Solutions 14

Setting up the TV with your PC 14

Changing the Picture Options 15

Sound Menu y ........................................................... 16

Changing the Preset Sound Mode 16

Adjusting sound settings 16

Sound Settings 16

Setup Menu y ............................................................ 17

Setting the Time 17

Using the Sleep Timer 18

Setting the On/Off Timer 18

Locking Programs 18

Other Features 20

Picture In Picture (PIP) 21

Support Menu y ......................................................... 21

Advanced Features

Network Connection y ............................................... 23

Connecting to a Wired Network 23

Connecting to a Wireless Network 25

Media Play y .............................................................. 29

Connecting a USB Device 29

Connecting to the PC through network 29

Screen Display 31

Playing Multiple Files 34

Media Play - Additional Functions 34

Anynet+ y ................................................................. 36

Setting Up Anynet+ 37

Switching between Anynet+ Devices 37

Recording 37

Listening through a Receiver 38

Troubleshooting for Anynet+ 38

AllShare y .................................................................. 39

About AllShare 39

Setting Up AllShare 39

Other Information

Assembling the Cables y ........................................... 41

Anti-theft Kensington Lock y ...................................... 41

Installing the Wall Mount y ......................................... 41

Securing the TV to the Wall y ..................................... 43

Troubleshooting y ...................................................... 44

Speciﬁcations y ......................................................... 47

License 47

Dimensions y ............................................................. 48

Index y ...................................................................... 49

Check the Symbol!

t✎O

This function can be used by pressing the

TOOLS button on the remote control.

Note :

Important information

Step by step guide :

Informs you how to access

the menu.

POWER

F A V . CH

CHLIST

MEDIA.P

P . MODE

S.MODE

P . SIZE

MTS

INFO

TOOLS

BN68-02604A_Eng.indb 3 2010-06-29 �� 10:39:51

Getting Started

English

List of Features

Excellent Digital Interface & Networking: With a built-in HD digital tuner, nonsubscription HD broadcasts can be viewed y

without a cable box / STB (Set-Top-Box) satellite receiver.

Media Play y: Allows you to play music ﬁles, pictures, and movies saved on a USB device. (P. 29)

AllShare y: Allows you to conﬁgure a mobile message server media render. (P. 39)

Self Diagnosis y:You can check picture and sound operation. (P. 21)

Accessories

Please make sure the following items are included with your LCD TV. If any items are missing, contact your dealer.

✎

The items' colors and shapes may vary depending on the models.

✎

Remote Control y(BN59-01041A) & Batteries (AAA x 2)

Owner’s Instructions y

Warranty Card / Safety Guide / Quick Setup Guide y

Cleaning Cloth (BN63-01798B) y

Power Cord y

(46inch TV)

Blanking Bracket (BN63-06339A) y

(LN32C550: BN63-06389A) Cable Tie (BN61-05596A) yHolder-Ring (4ea) y

(BN61-04529A)

Installing the LCD TV Stand

Components

When installing the stand, use the provided components and parts.

Stand (1 EA) Guide Stand (1 EA) Screws

A B C

9EA (M4 X L12)

Top View

4EA

1EA

Front

Rear

BN68-02604A_Eng.indb 4 2010-06-29 �� 10:39:53

01 Getting Started

English

Make sure to distinguish between the front and back of the Stand and Guide Stand when assembling them.

✎

Make sure that at least two persons lift and move the LCD TV.

✎

Stand the product up and fasten the screws. If you fasten the screws with the LCD TV placed down, it may lean to one

✎

side.

Viewing the Control Panel

The product color and shape may vary depending on the model.

✎

(Power) Turns the TV on or off.

Remote control sensor Aim the remote control towards this spot on the TV.

SOURCE

Toggles between all the available input sources. In the on-screen menu, use this

button as you would use the ENTER

button on the remote control.

MENU Displays an on-screen menu, the OSD (on screen display), of your TV’s features.

Adjusts the volume. In the OSD, use the

buttons as you would use the ◄

and ► buttons on the remote control.

Changes the channels. In the OSD, use the

buttons as you would use the

▼ and ▲ buttons on the remote control.

Power Indicator Blinks and turns off when the power is on and lights up in standby mode.

Standby mode

Do not leave your TV in standby mode for long periods of time (when you are away on a holiday, for example). A small amount

of electric power is still consumed even when the power button is turned off. It is best to unplug the power cord.

Speakers

Power IndicatorRemote control sensor

4EA

Bottom View

BN68-02604A_Eng.indb 5 2010-06-29 �� 10:39:53

Getting Started

English

Viewing the Remote Control

This is a special remote control for the visually impaired persons and has Braille points on the Power, Channel, Volume

✎

buttons.

Installing batteries (Battery size: AAA)

NOTE

✎

Use the remote control within 23 feet from the TV.

Bright light may affect the performance of the remote

control. Avoid use when nearby fluorescent lights or neon

signs.

The color and shape may vary depending on the model.

Press to display information on the TV screen.

(P. 17)

Changes channels.

Returns to the previous channel.

Turns the remote control light on and off.

When on, the buttons become illuminated for a

moment when pressed.

(Using the remote control with this button set to

off will reduce the battery usage time.)

Cut off the sound temporarily.

Displays the main on-screen menu.

Exit the menu.

Buttons used in the Channel list, Media Play

menu, etc.

S.MODE: Selects the sound mode. (P. 16)

SLEEP: Automatically shuts off the TV at a

preset time. (P. 18)

MTS: Press to choose stereo, mono or Separate

Audio Program (SAP broadcast). (P. 17)

P.MODE: Selects picture mode. (P. 14)

P.SIZE: Choose the picture size. (P. 15)

CC: Controls the caption decoder. (P. 20)

Displays Favorite Channel Lists on the screen.

(P. 12)

Returns to the previous menu.

Quickly select frequently used functions.

Selects the on-screen menu items and

changes the values seen on the menu.

Views Media Play. (P. 29)

Displays the channel list on the screen. (P. 12)

Press to select additional channels (digital)

being broadcast by the same station. For

example, to select channel ‘54-3’, press

‘54’, then press ‘-’ and ‘3’.

Adjusts the volume.

Displays and selects the available video

sources. (P. 11)

Turns the TV on and off.

Use these buttons in Media Play and

Anynet+ modes.

(: controls recording on Samsung

recorders with the Anynet+ feature)

Press to directly access to channels.

PRE-CH

VOL

MUTE

RETURN

CH LIST

EXIT

ABCD

MEDIA.P FAV. CH

P . MODE

S.MODE

SLEEP

P.SIZE

MTS

TOOLS

INFO

BN68-02604A_Eng.indb 6 2010-06-29 �� 10:39:54

01 Getting Started

English

Connecting to an Antenna

When the TV is initially powered on, basic settings proceed automatically.

Connecting the power cord and antenna.

✎

Plug & Play (Initial Setup)

When the TV is initially powered on, a sequence of on-screen prompts will assist in conﬁguring basic settings. Press the

POWER

button. Plug & Play is available only when the Input source is set to TV.

To return to the previous step, press the red button.

✎

1Selecting a language Press the ▲ or ▼ button, then press the ENTER

button.

Select the desired OSD (On Screen Display) language.

POWER

FAV . CH

CHLIST

MEDIA.P

P . MODE

S.MODE

P . SIZE

MTS

INFO

SLEEP

2Selecting Store Demo

or Home Use

Press the ◄ or ► button, then press the ENTER

button.

Select the yHome Use mode. Store Demo Mode is for retail

environments.

To return the unit’s settings from yStore Demo to Home Use

(standard): Press the volume button on the TV. When you see the

volume in the OSD, press and hold MENU for 5 sec.

3Selecting an antenna Press the ▲ or ▼ button, then press the ENTER

button. Select Air, Cable or Auto.

✎

Cable mode, you can select the correct signal source among STD, HRC, and IRC

by pressing the ▲, ▼, ◄ or ► button, then press the ENTER

button.

4Selecting a channel The channel search will start automatically.

For more information, refer to Channel → Auto Program. (P. 12)

Press the

✎

ENTER

button at any time to interrupt the memorization process.

5Setting the Clock

Mode

Set the Clock Mode automatically or manually.

If you select the

✎

Auto, set the daylight saving time.

Select the time zone where you live.

6Viewing the HD

Connection Guide

The connection method for the best HD screen quality is displayed.

7Enjoy your TV. Press the ENTER

button.

If You Want to Reset This Feature...

→ Setup → Plug & Play → ENTER

Cable

R-AUDIO-L PRPBY

ANT OUT

VHF/UHF Antenna

Power Input

Plug & Play

Time

Menu Language : English

Caption : On

Security

Network

General

PIP : Off

Setup

BN68-02604A_Eng.indb 7 2010-06-29 �� 10:39:55

English

ConnectionsConnections

Connecting to an AV Device

Using an HDMI / DVI Cable: HD connection (up to 1080p)

We recommend using the HDMI connection for the best quality HD picture.

Available devices: DVD, Blu-ray player, HD cable box, HD satellite receiver (STB).

HDMI IN 1(DVI)

✎

, 2, 3, 4 / PC/DVI AUDIO IN

When using an HDMI/DVI cable connection, you must use the

HDMI IN 1(DVI) jack for video. A DVD, Blu-ray

player, HD cable box, HD STB satellite receiver, cable box, or STB satellite receiver may require a DVI-HDMI (DVI

to HDMI) cable or DVI-HDMI (DVI to HDMI) adapter. The PC/DVI AUDIO IN jack is required for audio.

The picture may not display normally (if at all) or the audio may not work if an external device that uses an older

version of HDMI mode is connected to the TV. If such a problem occurs, ask the manufacturer of the external

device about the HDMI version and, if out of date, request an upgrade.

Be sure to purchase a certiﬁed HDMI cable. Otherwise, the picture may not display or a connection error may

occur.

Using a Component (up to 1080p), Using an Audio/Video Cable (480i only)

Available devices: DVD, Blu-ray player, cable box, STB satellite receiver, VCR

Device

R-AUDIO-L PRPBY

DVI OUT

BD/DVD player/

HD cable/Sat. box

R-AUDIO-L PRPBY

HDMI OUT

R-AUDIO-L PRPBY

AUDIO OUT

R-AUDIO-L PRPBY

COMPONENT OUT

R-AUDIO-L PRPBY

AUDIO OUT

Blu-ray player

R-AUDIO-L PRPBY

VIDEO OUT

VCR

R-AUDIO-L PRPBY

AUDIO OUT

When connecting to

✎

AV IN 1, the

color of the AV IN 1 [Y/VIDEO] jack

(Green) does not match the color of

the video cable (Yellow).

For better picture quality,

✎

the Component connection

is recommended over the A/V

connection.

W W BG

Yellow Red White Red Blue Green

Red White

W W BG

BN68-02604A_B_Eng.indd 8 2010-06-29 �� 2:39:38

English

02 Connections

Connecting to an Audio Device

Using an Optical (Digital) or Audio (Analog) Cable Connection

Available devices: Digital Audio System, Ampliﬁer, Home Theater

DIGITAL AUDIO OUT (OPTICAL)

✎

When a Digital Audio System is connected to the

DIGITAL AUDIO OUT (OPTICAL) jack, decrease the volume

of both the TV and the system.

5.1 CH (channel) audio is available when the TV is connected to an external device supporting 5.1 CH.

When the receiver (home theater) is set to on, you can hear sound output from the TV’s optical jack. When the

TV is receiving a DTV signal, the TV will send 5.1 CH sound to the home theater receiver. When the source is

a digital component such as a DVD / Blu-ray player / cable box / STB (Set-Top-Box) satellite receiver and is

connected to the TV via HDMI, only 2 CH audio will be heard from the home theater receiver. If you want to

hear 5.1 CH audio, connect the digital audio out jack from your DVD / Blu-ray player / cable box / STB satellite

receiver directly to an amplifier or home theater.

AUDIO OUT

✎

: Connects to the audio input jacks on your amplifier/home theater.

When connecting, use the appropriate connector (sold separately).

When an audio amplifier is connected to the

AUDIO OUT jacks: Decrease the volume of the TV and adjust the

volume level with the amplifier’s volume control.

Connecting to a PC

Using an HDMI/DVI Cable / a D-sub Cable

R-AUDIO-L PRPBY

AUDIO OUT

R-AUDIO-L PRPBY

AUDIO OUT

DVD

Home Theater

R-AUDIO-L PRPBY

OPTICAL

R-AUDIO-L PRPBY

AUDIO IN

Red White

W W BG

Digital audio system

R-AUDIO-L PRPBY

DVI OUT

R-AUDIO-L PRPBY

PC OUT

BN68-02604A_Eng.indb 9 2010-06-29 �� 10:40:00

English

Connections

Display Modes (D-Sub and HDMI/DVI Input)

Optimal resolution is 1920X1080@60Hz.

Mode Resolution Horizontal Frequency (KHz) Vertical Frequency (Hz) Pixel Clock Frequency (MHz) Sync Polarity (H / V)

IBM 640 x 350 31.469 70.086 25.175 +/-

720 x 400 31.469 70.087 28.322 -/+

MAC

640 x 480 35.000 66.667 30.240 -/-

832 x 624 49.726 74.551 57.284 -/-

1152 x 870 68.681 75.062 100.000 -/-

VESA CVT

720 x 576 35.910 59.950 32.750 -/+

1152 x 864 53.783 59.959 81.750 -/+

1280 x 720 56.456 74.777 95.750 -/+

1280 x 960 75.231 74.857 130.000 -/+

VESA DMT

640 x 480 31.469 59.940 25.175 -/-

640 x 480 37.861 72.809 31.500 -/-

640 x 480 37.500 75.000 31.500 -/-

800 x 600 37.879 60.317 40.000 +/+

800 x 600 48.077 72.188 50.000 +/+

800 x 600 46.875 75.000 49.500 +/+

1024 x 768 48.363 60.004 65.000 -/-

1024 x 768 56.476 70.069 75.000 -/-

1024 x 768 60.023 75.029 78.750 +/+

1152 x 864 67.500 75.000 108.000 +/+

1280 x 1024 63.981 60.020 108.000 +/+

1280 x 1024 79.976 75.025 135.000 +/+

1280 x 800 49.702 59.810 83.500 -/+

1280 x 800 62.795 74.934 106.500 -/+

1280 x 960 60.000 60.000 108.000 +/+

1280 x 720 45.000 60.000 74.250 +/+

1360 x 768 47.712 60.015 85.500 +/+

1440 x 900 55.935 59.887 106.500 -/+

1440 x 900 70.635 74.984 136.750 -/+

1680 x 1050 65.290 59.954 146.250 -/+

VESA GTF 1280 x 720 52.500 70.000 89.040 -/+

1280 x 1024 74.620 70.000 128.943 -/-

VESA DMT / DTV CEA 1920 x 1080p 67.500 60.000 148.500 +/+

NOTE

✎✎

For HDMI/DVI cable connection, you must use the

HDMI IN 1(DVI) jack.

The interlace mode is not supported.

The set might operate abnormally if a non-standard video format is selected.

Separate and Composite modes are supported. SOG(Sync On Green) is not supported.

EX-LINK

Connector for service only.

Input Cables (Sold Separately)

HDMI HDMI-DVI Component Composite (AV) Coaxial (RF) VGA

BN68-02604A_Eng.indb 10 2010-06-29 �� 10:40:02

English

02 Connections

How to Navigate Menus

Before using the TV, follow the steps below to learn how to

navigate the menu and select and adjust different functions.

PRE-

AV .CH

RETURN

HLI

EXIT

MEDIA

P . M

1 MENU button: Displays the main on-screen menu.

2 ENTER

/ Direction button: Move the cursor and

select an item. Conﬁrm the setting.

3 RETURN button: Returns to the previous menu.

4 EXIT button: Exits the on-screen menu.

How to Operate the OSD (On Screen Display)

The access step may differ depending on the selected menu.

1MENU

The main menu options appear on

the screen:

Picture, Sound, Channel, Setup,

Input, Application, Support.

2▲ / ▼ Select an icon with the ▲ or ▼

button.

3ENTER

Press ENTER

to access the

sub-menu

4▲ / ▼ Select the desired submenu with

the ▲ or ▼ button.

5◄ / ► Adjust the value of an item with the

◄ or ► button. The adjustment in

the OSD may differ depending on

the selected menu.

6ENTER

Press ENTER

to conﬁ rm the

selection.

7EXIT

Press EXIT.

Basic Features

Changing the Input source

Source List

→ Input → Source List →

ENTER

Use to select TV or an external input sources

such as a DVD / Blu-ray player / cable box /

STB satellite receiver.

TV / AV1 / AV2 / Component1 / ■

Component2 / PC / HDMI1/DVI /

HDMI2 / HDMI3 / HDMI4 / USB

You can only choose external devices that

✎

are connected to the TV. In the Source List,

connected inputs will be highlighted.

✎

always stay activated.

Edit Name

→ Input → Edit Name → ENTER

VCR / DVD / Cable STB / Satellite STB / PVR STB / ■

AV Receiver / Game / Camcorder / PC / DVI PC /

DVI Devices / TV / IPTV / Blu-ray / HD DVD / DMA:

Name the device connected to the input jacks to make

your input source selection easier.

When a PC with a resolution of 1920 x 1080 @

✎

60Hz is connected to the HDMI IN 1(DVI) port,

you should set to DVI PC mode under Edit Name.

When connecting an HDMI/DVI cable to the

✎

HDMI IN 1(DVI) port, you should set to DVI PC or

DVI Devices mode under Edit Name.

POWER

FAV . CH

CHLIST

MEDIA.P

P . MODE

S.MODE

P . SIZE

MTS

INFO

SLEEP

BN68-02604A_Eng.indb 11 2010-06-29 �� 10:40:02

English

Basic Features

Channel Menu

Seeing Channels ¦

Channel List

→ Channel → Channel List → ENTER

Add, delete or set Favorite channels and use

the program guide for digital broadcasts.

Select a channel in the All Channels, Added

Channels, Favorite or Programmed screen

by pressing the ▲ / ▼ buttons, and pressing

the ENTER

button. Then you can watch

the selected channel.

■ All Channels: Shows all currently available

channels.

■ Added Channels: Shows all added channels.

■

Favorite: Shows all favorite channels.

■ Programmed: Shows all currently reserved programs.

Using the color buttons with the

✎

Channel List

ABCD

Red (Antenna): Switches to Air or Cable.

ABCD

Green (Zoom): Enlarges or shrinks a channel

number.

ABCD

Yellow (Select): Selects multiple channel lists.

Select desired channels and press the Yellow button

to set all the selected channels at the same time. The

mark appears to the left of the selected channels.

(Page): Move to next or previous page.

(Tools): Displays the Channel List option menu.

(The Options menus may differ depending on the

situation.)

Channel Status Display Icons

Icons Operations

A channel selected.

A channel set as a Favorite.

)

A reserved program.

(

A program currently being broadcast.

Using Favorite Channels ¦

→ Channel → Channel List → ENTER

Add to Favorite / Delete from Favorite

Set channels you watch frequently as

Favorites.

1. Select a channel and press the TOOLS

button.

2. Add or delete a channel using the Add to

Favorite or Delete from Favorite menu

respectively.

Memorizing channels ¦

→ Channel

→

ENTER

Antenna (Air / Cable)

Before your television can begin memorizing the available

channels, you must specify the type of signal source that is

connected to the TV (i.e. an Air or a Cable system).

Auto Program

Air ■: Air antenna signal.

Cable ■: Cable antenna signal.

Auto ■: Air and Cable antenna.

NOTE

✎

When selecting the Cable TV system: Selects the

cable system. STD, HRC and IRC identify various

types of cable TV systems. Contact your local cable

company to identify the type of cable system that

exists in your particular area. At this point, the signal

source has been selected.

After all the available channels are stored, it starts

to remove scrambled channels. The Auto program

menu then reappears.

Added Channels

6 Air

6-1 ♥ TV #6

7 Air

8 Air

9 Air

9-1 ♥ TV #9

10 Air

10-1 ♥ TV #10

11-1 ♥ TV #11

Air

Antenna

Zoom

Select Page T Tools

Delete

Add to Favorite

Timer Viewing

Channel Name Edit

Select All

POWER

FAV . CH

CHLIST

MEDIA.P

P . MODE

S.MODE

P . SIZE

MTS

INFO

SLEEP

POWER

FAV . CH

CHLIST

MEDIA.P

P . MODE

S.MODE

P . SIZE

MTS

INFO

SLEEP

Added Channels

6 Air

6-1 ♥ TV #6

7 Air

8 Air

9 Air

9-1 ♥ TV #9

10 Air

10-1 ♥ TV #10

11-1 ♥ TV #11

Air

Antenna

Zoom

Select Page T Tools

BN68-02604A_Eng.indb 12 2010-06-29 �� 10:40:03

English

03 Basic Features

How to Stop Auto Programming

1. Press the ENTER

button.

2. A message will ask Stop Auto Program? Select Yes by

pressing the ◄ or ► button.

3. Press the ENTER

button.

Editing channels ¦

→ Channel → Channel List → ENTER

Channel Name Edit

1. Select a channel and press the TOOLS button.

2. Edit the channel name using the Channel Name Edit

menu.

Channel Name Edit ■ (analog channels only): Assign your

own channel name.

Other Features ¦

→ Channel → ENTER

Clear Scrambled Channel

This function is used to ﬁlter out scrambled channels after

Auto Program is completed. This process may take up to

20~30 minutes.

How to Stop Searching Scrambled Channels

1. Press the ENTER

button to select Stop.

2. Press the ◄ button to select Yes.

3. Press the ENTER

button.

This function is only available in

✎

Cable mode.

Channel List

→ Channel → Channel List → ENTER

Channel List Option Menu

Set each channel using the Channel List menu options (Add

/ Delete, Timer Viewing, Select All, Deselect All). Option

menu items may differ depending on the channel status.

1. Select a channel and press the TOOLS button.

2. Select a function and change its settings.

Add / Delete ■: Delete or add a channel to display the

channels you want.

NOTE

✎

All deleted channels will be shown on the

All

Channels menu.

A gray-colored channel indicates the channel

has been deleted.

The

Add menu only appears for deleted

channels.

Delete a channel from the

Added Channels or

Favorite menu in the same manner.

Timer Viewing ■: You can set a desired channel to be

displayed automatically at the set time; even when you

are watching another channel. Set the current time ﬁrst

to use this function. (P. 17)

1. Press the ◄ / ► /▲ / ▼ buttons to select the

desired channel in Channel List.

2. Press the TOOLS button, then select Timer Viewing.

3. Scroll up or down to adjust the settings in the box,

or use the numeric buttons on your remote for

entering the date and time.

If you selected

✎

Once, Every Week or Every Day

in Repeat, you can enter the date you want.

Select OK, then press the ENTERE button when done.

NOTE

✎

Only memorized channels can be reserved.

Reserved programs will be displayed in the

Programmed menu.

When a digital channel is selected, press the

► button to view the digital program.

Select All ■: Select all the channels in the channel list.

Deselect All ■: Deselect all the selected channels.

You can only select

✎

Deselect All when one or

more channels are selected.

Programmed

(in Channel List)

You can view, modify or delete a show you have reserved to

watch.

1. Press the

ENTERE

button to select Channel List.

2. Press the ◄ and ▼ button move to the Programmed

menu.

Change Info ■: Change a show you have reserved to

watch.

Cancel Schedules ■: Cancel a show you have reserved

to watch.

Information ■: Display a show you have reserved

to watch. (You can also change the reservation

Information.)

Select All / Deselect All: ■ You can select or deselect all

channels in the channel list.

Fine Tune

(analog channels only)

If the reception is clear, you do not have to ﬁne tune the

channel, as this is done automatically during the search and

store operation. If the signal is weak or distorted, ﬁne tune

the channel manually.

Select yFine Tune in the Channel menu.

Fine tuned channels that have been saved are marked

✎

with an asterisk “*” on the right-hand side of the

channel number in the channel banner.

To reset the fine-tuning, select

✎

Reset.

BN68-02604A_Eng.indb 13 2010-06-29 �� 10:40:04

English

Basic Features

Picture Menu

Changing the Preset Picture Mode ¦

→ Picture → Mode → ENTER

Mode

Select your preferred picture type by

pressing the P.MODE button.

Dynamic

■: Suitable for a bright room.

Standard

■: Suitable for a normal

environment.

Natural

■: Suitable for an eye comfortable display.

Natural

✎

is not available in PC mode.

Movie

■: Suitable for watching movies in a dark room.

Adjusting picture settings ¦

→ Picture → Backlight → ENTER

Backlight / Contrast / Brightness /

Sharpness / Color / Tint (G/R)

Your television has several setting options for picture quality

control.

NOTE

✎

When you make changes to

Backlight, Contrast,

Brightness, Sharpness, Color or Tint (G/R), the

OSD will be adjusted accordingly.

In PC mode, you can only make changes to

Backlight, Contrast and Brightness.

Settings can be adjusted and stored for each

external device connected to the TV.

Lowering picture brightness reduces power

consumption.

Economical Solutions ¦

ECO Solution

→ Picture → ECO Solution → ENTER

Energy Saving (Off / Low / Medium / High / Picture ■

Off / Auto): This adjust the brightness of the TV in order

to reduce power consumption. If you select Picture

Off, the screen is turned off , but the sound remains on.

Press any button to turn on the screen again.

Eco Sensor (Off / On) ■: To enhance your power savings;

the picture settings will automatically adapt to the light

in the room.

If you adjust the

✎

Backlight, the Eco Sensor will

be set to Off.

Min Backlight: When ECO Sensor is On, the minimum

screen brightness can be adjusted manually.

✎

Eco Sensor is On, the display brightness may

change (become slightly darker in most cases)

depending on the surrounding light intensity.

No Signal Power Off (Off / 15 min. / 30 min. / 60 min.)

■:

Sets how quickly the TV switches to standby mode, if no

picture is being received.

Disabled when the PC is in power saving mode.

✎

Setting up the TV with your PC ¦

Set the input source to PC.

Auto Adjustment

→ Picture → Auto Adjustment →

ENTER

Adjust frequency values/positions and ﬁne tune the settings

automatically.

Not available when connecting through HDMI/DVI

✎

cable.

Screen

Coarse / Fine ■: Removes or reduces picture noise. If the

noise is not removed by Fine-tuning alone, then adjust

the frequency as best as possible (Coarse) and Fine-

tune again. After the noise has been reduced, readjust

the picture so that it is aligned to the center of screen.

Position

■: Adjust the PC’s screen positioning if it does

not ﬁt the TV screen. Press the ▲ or ▼ button to adjust

the Vertical-Position. Press the ◄ or ► button to adjust

the Horizontal-Position.

Image Reset

■: Resets the image to default settings.

Using Your TV as a Computer (PC) Display

Setting Up Your PC Software (Based on Windows XP)

Depending on the version of Windows and the video card,

the actual screens on your PC will probably look different, but

the same basic set-up information will apply in most cases.

(If not, contact your computer manufacturer or Samsung

Dealer.)

1. Click on “Control Panel” on the Windows start menu.

2. Click on “Appearance and Themes” in the “Control

Panel” window and a display dialog-box will appear.

3. Click on “Display” and a display dialog box will appear.

POWER

FAV . CH

CHLIST

MEDIA.P

P . MODE

S.MODE

P . SIZE

MTS

INFO

SLEEP

BN68-02604A_B_Eng.indd 14 2010-06-29 �� 3:56:59

English

03 Basic Features

4. Navigate to the “Settings” tab on the display dialog-box.

The correct size setting (resolution) y

[Optimum: 1920 X 1080 pixels]

If a vertical-frequency option exists on your display y

settings dialog box, the correct value is ‘60’ or ‘60 Hz’.

Otherwise, just click ‘OK’ and exit the dialog box.

Changing the Picture Options ¦

Advanced Settings

→ Picture → Advanced Settings →

ENTER

(available in Standard / Movie mode)

Compared to previous models, new Samsung TVs have

more precise pictures.

In PC mode, you can only make changes to

✎

Dynamic

Contrast, Gamma and White Balance.

Bla ■ck Tone (Off / Dark / Darker / Darkest): Select the

black level to adjust the screen depth.

Dynamic Contrast (Off / Low / Medium / High) ■:

Adjust the screen contrast.

Shadow Detail ■: Increase the brightness of dark images.

Disabled under PC mode.

✎

G ■amma: Adjust the primary color intensity.

RGB Only Mode (Off / Red / Green / Blue) ■: Displays

the Red, Green and Blue color for making ﬁne

adjustments to the hue and saturation.

Color Space (Auto / Native) ■: Adjust the range of colors

available to create the image.

White Balance ■: Adjust the color temperature for a more

natural picture.

R-Offset / G-Offset / B-Offset: Adjust each color's

(red, green, blue) darkness.

R-Gain / G-Gain / B-Gain: Adjust each color's (red,

green, blue) brightness.

Reset: Resets the White Balance to it's default

settings.

Flesh Tone ■: Emphasize pink "flesh tone".

Edge Enhancement (Off / On) ■: Emphasize object

boundaries.

Picture Options

→ Picture → Picture Options →

ENTER

In PC mode, you can only make changes to the

✎

Color

Tone, Size and Auto Protection Time.

Color Tone (Cool / Normal / Warm1 / Warm2) ■

Warm1

✎

or Warm2 will be deactivated when the

picture mode is Dynamic.

Settings can be adjusted and stored for each

✎

external device connected to an input on the TV.

Size ■: Your cable box/satellite receiver

may have its own set of screen sizes as

well. However, we highly recommend

you use 16:9 mode most of the time.

16:9: Sets the picture to 16:9 wide mode.

Zoom1: Use for moderate magniﬁcation.

Zoom2: Use for a stronger magniﬁcation.

Wide Fit: Enlarges the aspect ratio of the picture to ﬁt

the entire screen.

4:3: Sets the picture to basic (4:3) mode.

Do not watch in 4:3 format for a long time. Traces

✎

of borders displayed on the left, right and center

of the screen may cause image retention (screen

burn) which are not covered by the warranty.

Screen Fit: Displays the full image without any cut-off

when HDMI (720p / 1080i / 1080p) or Component

(1080i / 1080p) signals are input.

NOTE

✎

After selecting

Zoom1, Zoom2 or Wide Fit:

1. Press the ► button to select Position.

2. Press the ENTER

button.

3. Press the ▲ or ▼ button to move the picture up

or down.

4. Press the ENTER

button.

5. Press the ► button to select Reset.

6. Press the ENTER

button to reset the picture

to its default position.

Advanced Settings

Black Tone : Off ►

Dynamic Contrast : Medium

Shadow Detail : 0

Gamma : 0

RGB Only Mode : Off

Color Space : Native

White Balance

▼

U Move E Enter R Return

Picture Options

Color Tone : Normal ►

Size : 16:9

Digital Noise Filter : Auto

MPEG Noise Filter : Auto

HDMI Black Level : Normal

Film Mode : Off

Auto Protection Time : 2 hours

U Move E Enter R Return

POWER

FAV . CH

CHLIST

MEDIA.P

P . MODE

S.MODE

P . SIZE

MTS

INFO

SLEEP

BN68-02604A_Eng.indb 15 2010-06-29 �� 10:40:04

English

Basic Features

After selecting

Screen Fit in HDMI (1080i/1080p) or

Component (1080i/1080p) mode, you may need to

center the picture:

1. Press the ◄ or ► button to select Position.

2. Press the ENTER

button.

3. Press the ▲, ▼, ◄ or ► button to move the

picture.

4. Press the ENTER

button.

5. Press the ◄ or ► button to select Reset.

6. Press the ENTER

button.

HD (High Definition): 16:9 - 1080i/1080p (1920x1080),

720p (1280x720)

Settings can be adjusted and stored for each

external device you have connected to an input on

the TV.

Input Source Picture Size

ATV, AV,

Component (480i, 480p)

16:9, Zoom1,

Zoom2, 4:3

DTV(1080i),

Component (1080i, 1080p),

HDMI (720p, 1080i, 1080p)

16:9, 4:3, Wide Fit,

Screen Fit

PC 16:9, 4:3

Digital Noise Filter (Off / Low / Medium / High / Auto ■

/ Auto Visualization): If the broadcast signal received

by your TV is weak, you can activate the Digital Noise

Filter feature to reduce any static and ghosting that may

appear on the screen.

When the signal is weak, try other options until the

✎

best picture is displayed.

Auto Visualization: When changing analog channels,

displays signal strength.

Only available for analog channels.

✎

When bar is green, you are receiving the best

✎

possible signal.

MPEG Noise Filter (Off / Low / Medium / High / ■

Auto): Reduces MPEG noise to provide an improved

picture quality.

Disabled under PC mode.

✎

HDMI Black Level (Normal / Low) ■: Selects the black

level on the screen to adjust the screen depth.

Available only in HDMI mode (RGB signals).

✎

Film Mode (Off / Auto1 / Auto2) ■: Sets the TV to

automatically sense and process ﬁlm signals from all

sources and adjusts the picture for optimum quality.

Available in TV, AV, COMPONENT (480i / 1080i)

✎

and HDMI (480i / 1080i).

Auto Protection Time (2 hours / 4 hours / 8 hours ■

/ 10 hours / Off): If the screen remains idle with a still

image for a certain period of time deﬁned by the user,

the screen saver is activated to prevent the formation of

ghost images on the screen.

Picture Reset (OK / Cancel)

Resets your current picture mode to its default settings.

Sound Menu

Changing the Preset Sound Mode ¦

→ Sound → Mode → ENTER

Mode

Standard ■: Selects the normal sound

mode.

Music ■: Emphasizes music over voices.

Movie ■: Provides the best sound for

movies.

Clear Voice ■: Emphasizes voices over

other sounds.

Amplify ■: Increase the intensity of high-frequency sound

to allow a better listening experience for the hearing

impaired.

Adjusting sound settings ¦

→ Sound → Equalizer → ENTER

Equalizer

Adjusts the sound mode.

Balance L/R ■: Adjusts the balance between the right and

left speaker.

100Hz / 300Hz / 1KHz / 3KHz / 10KHz ■ (Bandwidth

Adjustment): Adjusts the level of speciﬁc bandwidth

frequencies.

Reset ■: Resets the equalizer to its default settings.

Sound Settings ¦

→ Sound → ENTER

Virtual Surround (Off / On)

(standard sound mode only)

This function provides a virtual 5.1 channel surround sound

experience through a pair of speakers or headphones using

HRTF (Head Related Transfer Function) technology.

✎

Speaker Select is set to External Speaker, Virtual

Surround is disabled.

POWER

FAV . CH

CHLIST

MEDIA.P

P . MODE

S.MODE

P . SIZE

MTS

INFO

SLEEP

BN68-02604A_Eng.indb 16 2010-06-29 �� 10:40:04

English

03 Basic Features

Dialog Clarity (Off / On)

(standard sound mode only)

Dialog Clarity emphasizes voice while maintaining the

background sound level.

Preferred Language

(digital channels only)

Digital-TV broadcasts are capable of

simultaneous transmission of many

audio tracks (for example, simultaneous

translations of the program into foreign

languages).

You can only select a language among the ones being

✎

broadcasted.

Multi-Track Sound (MTS)

(analog channels only)

Mono ■: Choose for channels that are

broadcasting in mono or if you are

having difﬁculty receiving a stereo signal.

Stereo ■: Choose for channels that are

broadcasting in stereo.

SAP ■: Choose to listen to the Separate Audio Program,

which is usually a foreign-language translation.

Depending on the particular program being broadcast,

✎

you can listen to Mono, Stereo or SAP.

Auto Volume (Off / Normal / Night)

To equalize the volume level on each channel, set to Normal.

Night ■: This mode provides an improved sound

experience compared to Normal mode, making almost

no noise. It is useful at night.

Speaker Select

(External Speaker / TV Speaker)

A sound echo may occur due to a difference in decoding

speed between the main speaker and the audio receiver. In

this case, set the TV to External Speaker.

When

✎

Speaker Select is set to External Speaker, the

volume and MUTE buttons will not operate and the

sound settings will be limited.

When

✎

Speaker Select is set to External Speaker, you

should use these settings.

TV Speaker: Off, External Speaker: On

When

✎

Speaker Select is set to TV Speaker, you

should use these settings.

TV Speaker: On, External Speaker: On

If there is no video signal, both speakers will be mute.

✎

SPDIF Output

SPDIF (Sony Philips Digital Interface) is used to provide digital

sound, reducing interference going to speakers and various

digital devices such as a DVD player.

Audio Format ■: During the reception of a digital TV

broadcast, you can select the Digital Audio output

(SPDIF) format from the options PCM or Dolby Digital.

By connecting to 5.1ch speakers in a dolby

✎

digital setup, maximize your interactive 3D sound

experience.

Audio Delay ■: Correct audio-video mismatch, when

watching TV or video, and listening to digital audio

output using an external device such as an AV receiver

(0ms ~ 250ms).

Sound Reset

Reset all sound settings to the factory defaults.

Setup Menu

Setting the Time ¦

→ Setup → Time → ENTER

Time

The current time will appear every time you press the

✎

INFO button.

Clock ■: Setting the clock is for using various timer

features of the TV.

If you disconnect the power cord, you have to set

✎

the clock again.

Clock Mode: Set up the current time manually or

automatically.

Auto – : Set the current time automatically using the

time from a digital channel.

The antenna must be connected in order to set

✎

the time automatically.

Manual – : Set the current time manually.

Depending on the broadcast station and signal,

✎

the auto time set up may not be correct. In this

case, set the time manually.

POWER

FAV . CH

CHLIST

MEDIA.P

P . MODE

S.MODE

P . SIZE

MTS

INFO

SLEEP

POWER

FAV . CH

CHLIST

MEDIA.P

P . MODE

S.MODE

P . SIZE

MTS

INFO

SLEEP

BN68-02604A_Eng.indb 17 2010-06-29 �� 10:40:05

English

Basic Features

Clock Set: Set the Month, Day, Year, Hour, Minute

and am/pm.

Available only when

✎

Clock Mode is set to

Manual.

You can set the

✎

Month, Day, Year, Hour and

Minute directly by pressing the number buttons

on the remote control.

DST (Off / On): Switches the DST(Daylight Saving Time)

function on or off.

This function is only available when the

✎

Clock

Mode is set to Auto.

Time Zone: Select your time zone.

This function is only available when the

✎

Clock

Mode is set to Auto.

Using the Sleep Timer ¦

→ Setup → Time → Sleep Timer →

ENTER

Sleep Timer ■

: Automatically

shuts off the TV after a preset period

of time. (30, 60, 90, 120, 150 and 180

minutes).

To cancel the

✎

Sleep Timer, select

Off.

Setting the On/Off Timer ¦

→ Setup → Time → Timer 1 →

ENTER

Timer 1 / Timer 2 / Timer 3 ■: Three different on / off

timer settings can be made. You must set the clock ﬁrst.

On Time / Off Time: Set the hour, minute, am/pm

and activate / inactivate. (To activate the timer with the

setting you have chosen, set to Activate.)

Volume: Set the desired volume level.

Source: Select TV or USB content to be played when

the TV is turned on automatically. (USB can be selected

only when a USB device is connected to the TV)

Antenna (when the Source is set to TV): Select Air or

Cable.

Channel (when the Source is set to TV): Select the

desired channel.

Contents (when the Source is set to USB): Select a

folder in the USB device containing music or photo ﬁles

to be played when the TV is turned on automatically.

If there is no music file on the USB device or the

✎

folder containing a music file is not selected, the

Timer function does not operate correctly.

When there is only one photo file in the USB, the

✎

Slide Show will not play.

A folder with too long of a name cannot be

✎

selected.

Each USB you use is assigned its own folder.

✎

When using more than one of the same type of

USB, make sure the folders assigned to each USB

have different names.

Repeat: Select Once, Everyday, Mon~Fri, Mon~Sat,

Sat~Sun or Manual to set at you convenience. If you

select Manual, you can set up the day you want to

activate the timer.

The

✎c

mark indicates the day is selected.

Auto Power Off (available only when the TV is turned

✎

on by the Timer): The TV will be automatically turned off

after 3 hours of being left idle to prevent overheating.

Locking Programs ¦

→ Setup → Security → ENTER

Security

The PIN input screen appears, Enter your 4 digit PIN number.

V-Chip ■: The V-Chip feature automatically locks out

programs that are deemed inappropriate for children.

The user must enter a PIN (personal identiﬁcation

number) before any of the V-Chip restrictions are set up

or changed.

NOTE

✎

V-Chip

is not available in HDMI, Component

or PC mode.

The default PIN number of a new TV set is

“0-0-0-0”.

Allow all

: Press to unlock all TV ratings.

Block all

: Press to lock all TV ratings.

V-Chip Lock (Off / On): You can block rated TV

Programs.

POWER

FAV . CH

CHLIST

MEDIA.P

P . MODE

S.MODE

P . SIZE

MTS

INFO

SLEEP

Timer 1

L Move U Adjust E Enter R Return

On Time

Off Time

Volume Source Antenna Channel

Repeat Sun Mon Tue Wed Thu Fri Sat

Inactivate 12 00 am

10 TV Air 3

Once

▲

▼

BN68-02604A_Eng.indb 18 2010-06-29 �� 10:40:05

English

03 Basic Features

TV Parental Guidelines: You can block TV programs

depending on their rating. This function allows you to

control what your children are watching.

TV-Y – : Young children / TV-Y7: Children 7 and over /

TV-G: General audience / TV-PG: Parental guidance /

TV-14: Viewers 14 and over / TV-MA: Mature

audience

ALL – : Lock all TV ratings. / FV: Fantasy violence /

V: Violence / S: Sexual situation / L: Adult Language /

D: Sexually Suggestive Dialog

The V-Chip will automatically block certain

✎

categories dealing with more sensitive material.

For example, if you block the T V-Y category,

then TV-Y7 will automatically be blocked.

Similarly, if you block the TV-G category, then

all the categories in the young adult group will

be blocked (TV-G, TV-PG, TV-14 and TV-MA).

The sub-ratings (D, L, S, V) work similarly. So,

if you block the L sub-rating in TV-PG, then

the L sub-ratings in TV-14 and TV-MA will

automatically be blocked.

MPAA Rating: You can block movies depending on

their MPAA rating. The Motion Picture Association of

America(MPAA) has implemented a rating system that

provides parents or guardians with advanced information

on which ﬁlms are appropriate for children.

G – : General audience (no restrictions). / PG: Parental

guidance suggested. / PG-13: Parents strongly

cautioned. / R: Restricted. Children under 17 should

be accompanied by an adult. / NC-17: No children

under age 17. / X: Adults only. / NR: Not rated.

The

✎

V-Chip will automatically block any

category that deals with more sensitive material.

For example, if you block the PG-13 category,

then R, NC-17 and X will automatically be

blocked.

Canadian English: You can block TV programs

depending on their Anglophone Canadian.

C – : Programming intended for children under age 8. /

C8+: Programming generally considered acceptable

for children 8 years and over to watch on their own. /

G: General programming, suitable for all audiences. /

PG: Parental Guidance. / 14+: Programming

contains themes or content which may not be

suitable for viewers under the age of 14. / 18+: Adult

programming.

The

✎

V-Chip will automatically block any

category that deals with more sensitive material.

For example, if you block the G category, then

PG, 14+ and 18+ will automatically be blocked.

Canadian French: You can block TV programs

depending on their French Canadian rating.

G – : General / 8 ans+: Programming generally

considered acceptable for children 8 years and over

to watch on their own. / 13 ans+: Programming may

not be suitable for children under the age of 13. /

16 ans+: Programming is not suitable for children

under the age of 16. / 18 ans+: Programming

restricted to adults.

The

✎

V-Chip will automatically block any

category that deals with more sensitive material.

For example, if you block the 8 ans+ category,

then 13 ans+, 16 ans+ and 18 ans+ will

automatically be blocked also.

Downloadable U.S. Rating: Parental restriction

information can be used while watching DTV channels.

NOTE

✎

If information is not downloaded from the

broadcasting station, the Downloadable U.S.

Rating menu is deactivated.

Parental restriction information is automatically

downloaded while watching DTV channels. It

may take several seconds.

The

Downloadable U.S. Rating menu

is available for use after information is

downloaded from the broadcasting station.

However, depending on the information from

the broadcasting station, it may not be available

for use.

Parental restriction levels differ depending on

the broadcasting station. The default menu

name and Downloadable U.S. Rating change

depending on the downloaded information.

Even if you set the on-screen display to another

language, the Downloadable U.S. Rating

menu will appear in English only.

The rating will automatically block certain

categories that deal with more sensitive

material.

The rating titles (For example: Humor Level..etc)

and TV ratings (For example: DH, MH, H..etc)

may differ depending on the broadcasting

station.

Change PIN ■: The Change PIN screen will appear.

Choose any 4 digits for your PIN and enter them. As

soon as the 4 digits are entered, the Conﬁrm New

PIN screen appears. Re-enter the same 4 digits. When

the Conﬁrm screen disappears, your PIN has been

memorized.

BN68-02604A_Eng.indb 19 2010-06-29 �� 10:40:05

English

Basic Features

How to watch a restricted channel

If the TV is tuned to a restricted channel, the V-Chip

will block it. The screen will go blank and the following

message will appear:

This channel is blocked by V-Chip. Please enter the

PIN to unblock.

If you forget the PIN, press the remote-control

✎

buttons in the following sequence, which resets

the pin to “0-0-0-0” : POWER (off) → MUTE →

8 → 2 → 4 → POWER (on)

Other Features ¦

→ Setup → ENTER

Menu Language

Set the menu language.

1. Select Menu Language and press the ENTER

button.

2. Choose desired language and press the ENTER

button.

Choose between

✎

English, Español and Français.

Caption

(On-Screen Text Messages)

Captio ■n (Off / On): You can switch the

caption function on or off. If captions are

not available, they will not be displayed

on the screen.

The Caption feature does not

✎

work in Component, HDMI or PC

modes.

Caption Mode ■: You can select the desired caption

mode.

The availability of captions depends on the

✎

program being broadcasted.

Default / CC1~CC4 / Text1~Text4: (analog channels

only) The Analog Caption function operates in either

analog TV channel mode or when a signal is supplied

from an external device to the TV. (Depending on the

broadcasting signal, the Analog Caption function may or

may not work with digital channels.)

Default / Service1~Service6 / CC1~CC4 /

Text1~Text4: (digital channels only) The Digital Captions

function works with digital channels.

Ser vice1~6

✎

may not be available in digital caption

mode depending on the broadcast.

Digital Cap ■tion Options: (digital channels only)

Size: Options include Default, Small, Standard and

Large. The default is Standard.

Font Style: Options include Default and Styles 0 to 7.

The default is Style 0.

Foreground Color: Options include Default, White,

Black, Red, Green, Blue, Yellow, Magenta and Cyan. You

can change the color of the letter. The default is White.

Background Color: Options include Default, White,

Black, Red, Green, Blue, Yellow, Magenta and Cyan.

You can change the background color of the caption.

The default is Black.

Foreground Opacity: This adjusts the opacity of text.

Options include Default, Transparent, Translucent, Solid

and Flashing.

Background Opacity: This adjusts the opacity of

the caption background. Options include Default,

Transparent, Translucent, Solid and Flashing.

Return to Default: This option sets each Size, Font

Style, Foreground Color, Background Color, Foreground

Opacity and Background Opacity to its default.

NOTE

✎

Digital Caption Options

are available only

when Default and Service1 ~ Service6 can be

selected in Caption Mode.

The availability of captions depends on the

program being broadcasted.

The

Default setting follow the standards set by

the broadcaster.

The Foreground and Background cannot be set

to have the same color.

You cannot set both the

Foreground Opacity

and the Background Opacity to Transparent.

Network (Network Type / Network Setup

/ Network Test )

For details on set up options, refer to the “Network

Connection” instructions. (P. 23~28)

General

Game Mode (Off / On) ■: When connecting to a game

console such as PlayStation™ or Xbox™, you can enjoy

a more realistic gaming experience selecting the game

menu.

NOTE

✎

Precautions and limitations for game mode

To disconnect the game console and connect –

another external device, set Game Mode to Off in

the setup menu.

If you display the TV menu in – Game Mode, the

screen shakes slightly.

Game Mode

is not available when the input source

is set to TV or PC.

After connecting the game console, set

Game Mode

to On. Unfortunately, you may notice reduced picture

quality.

Game Mode is On:

Picture – mode is set to Standard and Sound mode

is set to Movie.

Equalizer – is not available.

POWER

FAV . CH

CHLIST

MEDIA.P

P . MODE

S.MODE

P . SIZE

MTS

INFO

SLEEP

BN68-02604A_Eng.indb 20 2010-06-29 �� 10:40:06

English

03 Basic Features

Menu Transparency (Bright / Dark) ■: Set the

Transparency of the menu.

Melody (Off / Low / Medium / High) ■: Set so that a

melody plays when the TV is turned on or off.

NOTE

✎

Only available when the Input source is set to TV.

To turn the melody off, set Melody to Off.

The

Melody does not play.

When no sound is output from the TV because the –

MUTE button has been pressed.

When no sound is output from the TV because the –

volume has been reduced to minimum with the

VOL – button.

When the TV is turned off by – Sleep Timer function.

Picture In Picture (PIP) ¦

PIP

→ Setup → PIP → ENTER

You can watch the TV tuner and one external video source

simultaneously. PIP (Picture-in-Picture) does not function in

the same mode.

NOTE

✎

For PIP sound, refer to the

Sound Select

instructions.

If you turn the TV off while watching in PIP mode, the

PIP window will disappear.

You may notice that the picture in the PIP window

becomes slightly unnatural when you use the main

screen to view a game or karaoke.

While

V-Chip operation, the PIP function cannot be

used.

PIP Settings

Main picture Sub picture

Component1, Component2,

HDMI1/DVI, HDMI2, HDMI3,

HDMI4, PC

PIP (Off / On) ■: Activate or deactivate the PIP function.

Air/ Cable (Air / Cable) ■: Select either Air or Cable as

the input source for the sub-screen.

Channel ■: Select the channel for the sub-screen.

Size ( ■

): Select a size for the sub-picture.

Position ( ■

–

—

): Select a position for the

sub-picture.

Sound Select (Main / Sub) ■: You can choose the

desired sound (Main or Sub) in PIP mode.

Support Menu

→ Support → ENTER

Self Diagnosis

Picture Test ■: Use to check for picture problems. If the

problem continues to occur, check the Color pattern.

Yes: If the test pattern does not appear or there is

noise in the test pattern, select Yes. There may be a

problem with the TV. Contact Samsung’s Call Center for

assistance (1-800-SAMSUNG).

No: If the test pattern is properly displayed, select No.

There may be a problem with your external equipment.

Please check your connections. If the problem persists,

refer to the external device’s user manual.

Sound Test ■: Use the built-in melody sound to check for

sound problems.

If you hear no sound from the TV’s speakers,

✎

before performing the sound test, make sure

Speaker Select is set to TV speaker in the

Sound menu.

The melody will be heard during the test even if

✎

Speaker Select is set to External Speaker or the

sound is muted by pressing the MUTE button.

Yes: If you can hear sound only from one speaker or not

at all during the sound test, select Yes. There may be a

problem with the TV. Contact Samsung’s Call Center for

assistance (1-800-SAMSUNG).

No: If you can hear sound from the speakers, select No.

There may be a problem with your external equipment.

Please check your connections. If the problem persists,

refer to the external device’s user manual.

Signal Information ■ (digital channels only): An HD

channel’s reception quality is either perfect or the

channels are unavailable. Adjust your antenna to

increase signal strength.

Troubleshooting ■: If the TV seems to have a problem,

refer to this description.

If none of these troubleshooting tips apply, contact

✎

the Samsung customer service center.

BN68-02604A_Eng.indb 21 2010-06-29 �� 10:40:06

English

Basic Features

Software Upgrade

Software Upgrade can be performed can be performed by

network connection or downloading the latest ﬁrmware from

“www.samsung.com,” to a USB memory device.

Current Version - the software already installed in the TV.

Software is represented as ‘Year/Month/Day_Version’.

✎

Installing the Latest Version

By USB ■: Insert a USB drive

containing the ﬁrmware

upgrade ﬁle, downloaded

from www.samsung.com,

into the TV. Please be careful

not to disconnect the power

or remove the USB drive until

upgrades are complete. The

TV will be turned off and on

automatically after completing

the ﬁrmware upgrade. When

software is upgraded, video

and audio settings you have made will return to their

default settings. We advise you to write down your

settings so that you can easily reset them after the

upgrade.

By Online ■: Upgrade the software using the Internet.

First, configure your network. For detailed

✎

procedures on using the Network Setup, refer to

the “Network Connection” instructions.

If the Internet connection does not operate

✎

properly, the connection may be broken. Please

retry downloading. If the problem persists,

download by USB and upgrade.

Alternative Software ■ (backup): Displays the Software

version downloaded through By Online. During the

software upgrading, When the Upgrade will discontinue

from last step, this function be activated.

HD Connection Guide

Refer to this information when connecting external devices

to the TV.

Contact Samsung

View this information when your TV does not work properly

or when you want to upgrade the software. You can ﬁnd

information regarding our call centers and how to download

products and software.

Software Upgrade

U Move E Enter R Return

By USB ►

By Online

Alternative Software

----

-----

Current Version 2010/01/18 000001

TV Side Panel

TV Rear Panel

USB Drive

BN68-02604A_Eng.indb 22 2010-06-29 �� 10:40:06

English

04 Advanced Features

Network Connection

You can set up your TV so that it can access the Internet through your local area network (LAN) using a wired or wireless

connection.

Connecting to a Wired Network ¦

You can attach your TV to your LAN using cable in three ways:

You can attach your TV to your LAN by connecting the LAN port on the back of your TV to an external modem using a Cat y

5 cable. See the diagram below.

You can attach your TV to your LAN by connecting the LAN port on the back of your TV to a IP Sharer which is connected y

to an external modem. Use Cat 5 cable for the connection. See the diagram below.

Depending on how your network is conﬁgured, you may be able to attach your TV to your LAN by connecting the LAN y

port on the back of your TV directly to a network wall outlet using a Cat 5 cable. See the diagram below. Note that the wall

outlet is attached to a modem or router elsewhere in your house.

If you have a Dynamic Network, you should use an ADSL modem or router that supports Dynamic Host Configuration

Protocol (DHCP). Modems and routers that support DHCP automatically provide the IP address, subnet mask, gateway,

and DNS values your TV needs to access the Internet so you do not have to enter them manually. Most home networks

are Dynamic Networks.

Some networks require a Static IP address. If your network requires a Static IP address, you must enter the IP address,

subnet mask, gateway, and DNS values manually on your TV’s Cable Setup Screen when you set up the network

connection. To get the IP address, subnet mask, gateway, and DNS values, contact your Internet Service Provider (ISP).

If you have a Windows computer, you can also get these values through your computer.

You can use ADSL modems that support DHCP if your network requires a Static IP address. ADSL modems that

✎

support DHCP also let you use Static IP addresses.

The Modem Port on the Wall

External Modem

(ADSL / VDSL / Cable TV)

TV Rear Panel

LAN CableModem Cable

The Modem Port on the Wall

External Modem

(ADSL / VDSL / Cable TV)

TV Rear Panel

LAN Cable

Modem Cable

The LAN Port on the Wall

TV Rear Panel

LAN Cable

IP Sharer

(having DHCP server)

Advanced Features

BN68-02604A_Eng.indb 23 2010-06-29 �� 10:40:07

English

Advanced Features

Network Setup (Auto)

Use the Automatic Network Setup when connecting your

TV to a network that supports DHCP. To set up your TV’s

cable network connection automatically, follow these steps:

How to set up automatically

1. Connect your TV to your LAN as described in the

previous section.

2. Turn on your TV, press the MENU button on your

remote, use the ▲ or ▼ button to select Setup, and

then press the ENTER

button.

3. Use the ▲ or ▼ button to select Network in the Setup

menu, and then press the ENTER

button. The

Network screen appears.

4. On the Network screen, select Network Type.

5. Set Network Type to Wired.

6. Select Network Setup. The Network Setup screen

appears.

7. Set Internet Protocol Setup to Auto.

8. Auto acquires and enters the needed Internet values

automatically.

9. Wait two minutes, and then press the RETURN button

on your remote.

10. If the Network Function has not acquired the network

connection values, go to the directions for Manual.

Network Setup (Manual)

Use the Manual Network Setup when connecting your TV to

a network that requires a Static IP address.

Getting the Network Connection Values

To get the Network connection values on most Windows

computers, follow these steps:

1. Right click the Network icon on the bottom right of the

screen.

2. In the pop-up menu that appears, click Status.

3. On the dialog that appears, click the Support tab.

4. On the Support Tab, click the Details button. The

Network connection values are displayed.

How to set up manually

To set up your TV’s cable network connection manually,

follow these steps:

1. Follow Steps 1 through 6 in the “How to set up

automatically” procedure.

2. Set Internet Protocol Setup to Manual.

3. Press the ▼ button on your remote to go to the ﬁrst

entry ﬁeld.

4. Enter the IP Address, Subnet Mask, Gateway, and

DNS Server values. Use the number buttons on your

remote to enter numbers and the arrow buttons to move

from one entry ﬁeld to another.

5. When done, press the RETURN button on your remote.

6. Select Network Test to check the Internet connectivity.

Network

Network Type : Wired ►

Network Setup

Network test

U Move E Enter R Return

Network Setup

Internet Protocol Setup : Auto ►

IP Address :

Subnet Mask :

Gateway :

DNS : Auto

DNS Server :

U Move E Enter R Return

BN68-02604A_Eng.indb 24 2010-06-29 �� 10:40:07

English

04 Advanced Features

Connecting to a Wireless Network ¦

To connect your TV to your network wireless, you need a wireless router or modem and a Samsung Wireless LAN Adapter

(WIS09ABGN, WIS09ABGN2, WIS10ABGN) , which you connect to your TV’s back or side panel USB jack. See the illustration below.

Samsung’s Wireless LAN adapter is sold separately and is offered by select retailers, Ecommerce sites and Samsungparts.

com. Samsung’s Wireless LAN adapter supports the IEEE 802.11A/B/G and N communication protocols. Samsung

recommends using IEEE 802.11N. When you play video over a IEEE 802.11B/G connection, the video may not play smoothly.

NOTE

✎

You must use the

“Samsung Wireless LAN Adapter” (WIS09ABGN, WIS09ABGN2, WIS10ABGN) to use a wireless

network.

Samsung Wireless LAN Adapter and The USB extension Cable are sold separately and are offered by select retailers,

Ecommerce sites and Samsungparts.com.

To use a wireless network, your TV must be connected to a wireless IP sharer (either a router or a modem). If the

wireless IP sharer supports DHCP, your TV can use a DHCP or static IP address to connect to the wireless network.

Select a channel for the wireless IP sharer that is not currently being used. If the channel set for the wireless IP sharer

is currently being used by another device nearby, this will result in interference and communication failure.

If you apply a security system other than the systems listed below, it will not work with the TV.

If Pure High-throughput (Greenfield) 802.11n mode is selected and the Encryption type is set to WEP, TKIP or

TKIPAES (WPS2Mixed) for your AP, Samsung TVs will not support a connection in compliance with new Wi-Fi

certification specifications.

If your AP supports WPS (Wi-Fi Protected Setup), you can connect to the network via PBC (Push Button

Configuration) or PIN (Personal Identification Number). WPS will automatically configure the SSID and WPA key in

either mode.

Keep the Samsung Wireless LAN Adapter at a distance from the TV. If you watch the TV with the Adapter connected

nearby, images may appear corrupted for some channels.

If your router, modem, or device is not certified, it may not connect to the TV via the “Samsung Wireless LAN

Adapter.”

Connection Methods

: You can setup the wireless network connecti

on on four ways.

PBC(WPS) –

Auto Setup (Using the Auto Network Search function) –

Manual Setup –

Ad-Hoc –

The Samsung Wireless LAN Adapter may not be recognized when using a connection via a USB hub or via a USB

extension cable other than the cable supplied.

The LAN Port on

the Wall

LAN Cable

Wireless IP sharer

(AP having DHCP Server)

Samsung Wireless

LAN Adapter

TV Side Panel

TV Rear Panel

BN68-02604A_Eng.indb 25 2010-06-29 �� 10:40:08

English

Advanced Features

Notice

The picture may appear corrupted or have static for some

channels when the TV is connected to the Samsung Wireless

LAN Adapter. In such a case, establish a connection using one

of the following methods or connect the Samsung Wireless LAN

Adapter using a USB cable in a place that is not affected by

radio interference.

Method 1

Connect using the USB right angle adapter

To connect the Samsung Wireless LAN Adapter using the

USB right angle adapter, follow these steps:

1. Connect the USB right angle adapter to the Samsung

Wireless LAN Adapter.

2. Connect the other end of the right angle adapter to the

USB 1 (HDD) port.

Method 2

Connect via an extension cable

To reconnect the Samsung Wireless LAN Adapter using the

extension cable, follow these steps:

1. Connect the extension cable to the USB 1 (HDD) port.

2. Connect the extension cable and Samsung Wireless LAN

Adapter.

3. Attach the Samsung Wireless LAN Adapter to the back of

the TV near the top, using double-sided adhesive tape.

Network Setup (PBC (WPS))

How to set up using PBC (WPS)

If your router has a PBC (WPS) button, follow these steps:

1. Connect your TV to your LAN as described in the

previous section.

2. Turn on your TV, press the MENU button on your

remote, use the ▲ or ▼ button to select Setup, and

then press the ENTER

button.

3. Use the ▲ or ▼ button to select Network in the Setup

menu, and then press the ENTER

button.

4. On the Network screen, select Network Type.

5. Set Network Type to Wireless.

6. Select Network Setup. The Network Setup screen

appears.

7. Press the Red button on your remote.

8. Press the PBC (WPS) button on your router within 2

minutes. Your TV player automatically acquires all the

network setting values it needs and connects to your

network.

9. After the network connection is set up, press the

RETURN button to exit the Network Setup screen.

Network Setup (Auto)

Most wireless networks have an optional security system

that requires devices that access the network to transmit

an encrypted security code called an Access or Security

Key. The Security Key is based on a Pass Phrase, typically

a word or a series of letters and numbers of a speciﬁed

length you were asked to enter when you set up security for

your wireless network. If you use this method of setting up

the network connection, and have a Security Key for your

wireless network, you will have to enter the Pass Phrase

during the setup process.

Network Setup

Select a network : Not Selected ►

Internet Protocol Setup : Auto

IP Address :

Subnet Mask :

Gateway :

DNS : Auto

DNS Server :

PBC(WPS) U Move E Enter R Return

BN68-02604A_Eng.indb 26 2010-06-29 �� 10:40:09

English

04 Advanced Features

How to set up automatically

To set up the wireless connection automatically, follow these

steps:

1. Follow Steps 1 through 6 in the “How to set up using

PBC (WPS)”. (P. 26)

2. Press the ▼ button to select Internet Protocol Setup,

and then press the ENTER

button. Press the ▲ or

▼ button to select Auto, and then press the ENTER

button.

3. Press the ▲ button to go to Select a Network, and

then press the ENTER

button. The Network function

searches for available wireless networks. When done, it

displays a list of the available networks.

4. In the list of networks, press the ▲ or ▼ button to select

a network, and then press the ENTER

button.

If the AP is set to Hidden (Invisible), you have

✎

to select Add Network and enter the correct

Network Name (SSID) and Security Key to

establish the connection.

5. If the Security/PIN pop-up appears, go to Step 6. If the

Network Connecting Screen appears, go to Step 10.

6. Press the ▲ or ▼ button to select Security or PIN. For

most home networks, you would select Security (for

Security Key). The Security Screen appears.

7. On the Security screen, enter your network’s Pass

Phrase.

You should be able to find the Pass Phrase on

✎

one of the set up screens you used to set up your

router or modem.

8. To enter the Pass Phrase, follow these general

directions:

Press the number buttons on your remote to enter –

numbers.

Use the direction buttons on your remote to move –

from button to button on the Security Key screen.

Press the Red button to change case or display –

symbols/characters.

To a enter letter or symbol, move to the letter or –

symbol, and then press the ENTER

button.

To delete the last letter or number you entered, –

press the Green button on your remote.

9. When done, press the Blue button on your remote. The

Network Connecting screen appears.

10. Wait until the connection conﬁrmation message is

displayed, and then press the ENTER

button. The

Network Setup screen re-appears.

11. To test the connection, press the RETURN button to

select Network Test, and then press the ENTER

button.

Network Setup (Ad-Hoc)

You can connect to a mobile device without an access point

through the “Samsung Wireless LAN Adapter” by using a

peer to peer network.

How to connect to new Ad-hoc

1. Follow Steps 1 through 6 in the “How to set up using

PBC(WPS)”. (P. 26)

2. Choose Select a network. A list of devices/networks

appears.

3. While in the device list, press the Blue button on the

remote.

The message

✎

"Ad-hoc is a direct WI-Fi

connection with cellphone or PC. The existing

network system may have limited functionality.

Do you want to change the network

connection?" is displayed.

4. Input the generated Network Name (SSID) and

Security Key into the device you want to connect.

How to connect an existing Ad-hoc device

1. Follow Steps 1 through 6 in the “How to set up using

PBC(WPS)”. (P. 26)

2. Choose Select a network. Then, the device list will be

displayed.

3. Select the device you want in the Device list.

4. If security key was applied, input the security key.

If network does not operate normally, check

✎

the Network Name (SSID) and Security Key

again. An incorrect Security Key may cause a

malfunction.

A B C D E F G

H I J K L M N

O P Q R S T U

V W X Y Z

0~9

Security Key

0 entered

Number

Lower case

Delete

Space

Select a network

n Move E Enter R Return

BN68-02604A_Eng.indb 27 2010-06-29 �� 10:40:09

English

Advanced Features

Network Setup (Manual)

If the other methods do not work, you need to enter the

Network setting values manually.

Getting the Network Connection Values

To get the Network setting values on most Windows

computers, follow these steps:

1. Right click the Network icon on the bottom right of the

screen.

2. In the pop-up menu, click Status.

3. On the dialog that appears, click the Support tab.

4. On the Support tab, click the Details button. The

Network settings are displayed.

How to set up manually

To enter the Network connection values manually, follow

these steps:

1. Follow Steps 1 through 6 in the “How to set up using

PBC (WPS)”. (P. 26)

2. Press the ▼ button to select Internet Protocol Setup,

and then press ENTER

button. Press the ▲ or ▼

button to select Manual, and then press ENTER

button.

3. Press the ▼ button to go to the ﬁrst entry ﬁeld (IP

Address).

4. Use the number buttons to enter numbers.

5. When done with each ﬁeld, use the ► button to move

successively to the next ﬁeld. You can also use the other

arrow buttons to move up, down, and back.

6. Enter the IP Address, Subnet Mask, and Gateway

values.

7. Press the ▲ or ▼ button to go to DNS.

8. Press the ▼ button to go to the ﬁrst DNS entry ﬁeld.

Enter the numbers as above.

9. When done, press the ▲ button to go to Select

a Network. Select your network, and then press

ENTER

button.

10. Go to Step 4 in the "How to set up automatically" (P. 27),

and follow the directions from that point on.

If Your TV Fails to Connect to the Internet

Your TV may not be able to connect to the Internet

because your ISP has permanently registered the

MAC address (a unique identifying number) of your

PC or modem, which it then authenticates each time

you connect to the Internet as a way of preventing

unauthorized access. As your TV has a different MAC

address, your ISP can not authenticate its MAC address,

and your TV can not connect.

To resolve this problem, ask your ISP about the procedures

required to connect devices other than a PC (such as your

TV) to the Internet.

If your Internet service provider requires an ID or password

to connect to the Internet, your TV may not be able to

connect to the Internet. If this is the case, you must enter

your ID or password when connecting to the Internet.

The internet connection may fail because of a ﬁrewall

problem. If this is the case, contact your Internet service

provider.

If you cannot connect to the Internet even after you have

followed the procedures of your Internet service provider,

please contact Samsung Electronics at 1-800-SAMSUNG.

BN68-02604A_Eng.indb 28 2010-06-29 �� 10:40:10

English

04 Advanced Features

Media Play

Connecting a USB Device ¦

1. Turn on your TV.

2. Connect a USB device containing photo, music and/or movie ﬁles to the

USB 1 (HDD) or USB 2 jack on the side or rear of the TV.

3. When USB is connected to the TV, popup window appears. Then you can select

Media Play.

Connecting to the PC through network ¦

You can play pictures, music and videos saved on your PC or on your TV through a network connection in the Media Play

mode.

I f you want to use

✎

Media Play to play files saved on your PC over your TV, you should download “PC Share Manager”

and users manual from “www.samsung.com.”

1. For more information on how to conﬁgure your network, refer to ‘Network Connection’.

You are recommended to locate both TV and PC in same subnet. The ﬁrst 3 parts of the subnet address of the TV and –

the PC IP addresses should be the same and only the last part (the host address) should be changed. (e.g. IP Address:

123.456.789.**)

2. Using a LAN cable, connect between the external modem and the PC onto which the Samsung PC Share Manager

program will be installed.

You can connect the TV to the PC directly without connecting it through a Sharer (Router). –

Enjoy photos, music and/or movie ﬁles saved on

a USB Mass Storage Class (MSC) device and/or

your PC.

→ Application → Media Play

→ ENTER

External Modem

(ADSL/VDSL/Cable TV)

LAN Cable

Wireless IP

sharer

TV Side Panel

Samsung

Wireless

LAN

Adapter

LAN

TV Rear Panel

POWER

FAV . CH

CHLIST

MEDIA.P

P . MODE

S.MODE

P . SIZE

MTS

INFO

SLEEP

TV Side Panel

TV Rear Panel

USB Drive

SUM

Change Device View Devices

Enter

Return

MediaPlay

Videos

BN68-02604A_Eng.indb 29 2010-06-29 �� 10:40:11

English

Advanced Features

Functions that are not supported when connecting to a PC through a network:

✎

The

Background Music and Background Music Setting functions.

Sorting files by preference in the

Photos, Music, and Videos folders.

The

x

(REW) or

(FF) button while a movie is playing.

The Divx DRM, Multi-audio, embedded caption does not supported.

✎

Samsung PC Share manager should be permitted by the firewall program on your PC.

✎

When you use

✎

Media Play mode through a network connection, According to functions of the provided server:

The sorting method may vary.

The scene search function may not be supported.

The

Play Continuously function, which resumes playing of a video, may not be supported.

The – Play Continuously function does not support multiple users. (It will have only memorized the point where the

most recent user stopped playing.)

The

x

(REW),

(FF) or



(Pause) buttons may not work depending on the content information.

If you experience any file stuttering issue while playing a video over a wireless network, we recommend using a wired

✎

network.

It might not work properly with unlicensed multimedia files.

✎

Need-to-Know List before using

✎

Media Play

MTP (Media Transfer Protocol) is not supported.

The file system supports FAT16, FAT32 and NTFS.

Certain types of USB Digital camera and audio devices may not be compatible with this TV.

Media Play

only supports USB Mass Storage Class (MSC) devices. MSC is a Mass Storage Class Bulk-Only

Transport device. Examples of MSC are Thumb drives, Flash Card Readers and USB HDD (USB HUB are not

supported). Devices should be connected directly to the TV’s USB port.

Before connecting your device to the TV, please back up your files to prevent them from damage or loss of data.

SAMSUNG is not responsible for any data file damage or data loss.

Connect a USB HDD to the dedicated port,

USB 1 (HDD) port.

Do not disconnect the USB device while it is loading.

The higher the resolution of the image, the longer it takes to display on the screen.

The maximum supported JPEG resolution is 15360X8640 pixels.

For unsupported or corrupted files, the “Not Supported File Format” message is displayed.

If the files are sorted by Basic View, up to 1000 files can be displayed in each folder.

MP3 files with DRM that have been downloaded from a non-free site cannot be played. Digital Rights Management

(DRM) is a technology that supports the creation, distribution and management of the content in an integrated and

comprehensive way, including the protection of the rights and interests of the content providers, the prevention of the

illegal copying of contents, as well as managing billings and settlements.

If more than 2 PTP devices are connected, you can only use one at a time.

If more than two MSC devices are connected, some of them may not be recognized. A USB device that requires high

power (more than 500mA or 5V) may not be supported.

If an over-power warning message is displayed while you are connecting or using a USB device, the device may not

be recognized or may malfunction.

If the TV has been no input during time set in

Auto Protection Time, the Screensaver will run.

The power-saving mode of some external hard disk drives may be released automatically when connected to the TV.

If a USB extension cable is used, the USB device may not be recognized or the files on the device may not be read.

If a USB device connected to the TV is not recognized, the list of files on the device is corrupted or a file in the list is

not played, connect the USB device to the PC, format the device and check the connection.

If a file deleted from the PC is still found when Media Play is run, use the “Empty the Recycle Bin” function on the PC

to permanently delete the file.

BN68-02604A_Eng.indb 30 2010-06-29 �� 10:40:11

English

04 Advanced Features

Jan.10.2010

/Movie 01.avi 1/1

Movie 01.avi

SUM

Movie 03.avi

Movie 05.avi

Movie 07.avi

Movie 09.avi

Movie 02.avi

Movie 04.avi

Movie 06.avi

Movie 08.avi

Movie 10.avi

Select

Sorting

Tools

Videos

Page

Change Device

Screen Display ¦

Move to the desired ﬁle using the up/down/right/left buttons and then press the ENTER



(Play) button. The ﬁle is

played.

Supports the

✎

View Devices and Contents Mode in Media Play homepage.

Videos

Playing Video

1. Press the ◄ or ► button to select Videos, then press the ENTER

button in the Media Play menu.

2. Press the ◄/►/▲/▼ button to select the desired video in the ﬁle list.

3. Press the ENTER

button or



(Play) button.

The selected ﬁle is displayed on the top with its playing time. –

If video time information is unknown, play time and progress bar are not displayed. –

During video playback, you can search using –◄ and ► button.

In this mode, you can enjoy movie clips contained on a Game,

✎

but you cannot play the Game itself.

Supported Subtitle Formats y

Name File extension Format

MPEG-4 time-based text .ttxt XML

SAMI .smi HTML

SubRip .srt string-based

SubViewer .sub string-based

Micro DVD .sub or .txt string-based

Movie 01.avi

00:04:03 / 00:07:38 1/1

SUM

E Pause L Jump T Tools R Return

Information:

You can ascertain the selected

ﬁle name and the number of

ﬁles and page.

Sort List Section:

Displays the sorting standard.

The sorting standard is

✎

different depending on

the contents.

Operation Buttons

Red (Change Device): Selects a connected device.

Green (Preference): Sets the ﬁle preference. (not supported in Basic view)

Yellow (Select): Selects multiple ﬁles from ﬁle list. Selected ﬁles are marked with a symbol.

Blue (Sorting): Selects the sort list.

Tools: Displays the option menu.

Using the

✎

button, ﬁle list can move to next or previous page.

File List Section:

You can conﬁrm the ﬁles

and groups that are sorted

by category.

BN68-02604A_Eng.indb 31 2010-06-29 �� 10:40:13

English

Advanced Features

Supported Video Formats y

File Extention Container Video Codec Resolution Frame rate

(fps)

Bit rate

(Mbps ) Audio Codec

*.avi

*.mkv

AVI

MKV

Divx 3.11 / 4.x / 5.1 / 6.0 1920x1080 6 ~ 30 8

MP3 / AC3 / LPCM /

ADPCM / DTS Core

XviD 1920x1080 6 ~ 30 8

H.264 BP / MP / HP 1920x1080 6 ~ 30 25

MPEG4 SP / ASP 1920x1080 6 ~ 30 8

*.asf ASF

Divx 3.11 / 4.x / 5.1 / 6.0 1920x1080 6 ~ 30 8

MP3 / AC3 / LPCM /

ADPCM / WMA

XviD 1920x1080 6 ~ 30 8

H.264 BP / MP / HP 1920x1080 6 ~ 30 25

MPEG4 SP / ASP 1920x1080 6 ~ 30 8

*.wmv ASF Window Media Video v9 1920x1080 6 ~ 30 25 WMA

*.mp4 MP4

H.264 BP / MP / HP 1920x1080 6 ~ 30 25

MP3 / ADPCM / AAC

MPEG4 SP / ASP 1920x1080 6 ~ 30 8

XVID 1920x1080 6 ~ 30 8

*.3gp 3GPP H.264 BP / MP / HP 1920x1080 6 ~ 30 25 ADPCM / AAC / HE-AAC

MPEG4 SP / ASP 1920x1080 6 ~ 30 8

*.vro VRO

VOB

MPEG1 1920x1080 24 / 25 / 30 30 AC3 / MPEG / LPCM

MPEG2 1920x1080 24 / 25 / 30 30

*.mpg

*.mpeg PS

MPEG1 1920x1080 24 / 25 / 30 30

AC3 / MPEG / LPCM / AACMPEG2 1920x1080 24 / 25 / 30 30

H.264 1920x1080 6 ~ 30 25

*.ts

*.tp

*.trp

MPEG2 1920x1080 24 / 25 / 30 30

AC3 / AAC / MP3 / DD+ /

HE-AAC

H.264 1920x1080 6 ~ 30 25

VC1 1920x1080 6 ~ 30 25

Other Restrictions

NOTE

✎

If there are problems with the contents of a codec, the codec will not be supported.

If the information for a Container is incorrect and the file is in error, the Container will not be able to play

correctly.

Sound or video may not work if the contents have a standard bitrate/frame rate above the compatible Frame/sec

listed in the table above.

Video Decoder Audio Decoder

Supports up to H.264, Level 4.1•

H.264 FMO / ASO / RS, VC1 SP / MP / AP L4 and AVCHD are •

not supported.

H.263 is not supported.•

GMC 2 is not support.•

Supports up to WMA 7, 8, 9, STD•

WMA 9 PRO does not support 2 channel excess multi •

channel or lossless audio.

WMA sampling rate 22050Hz mono is not supported.•

BN68-02604A_Eng.indb 32 2010-06-29 �� 10:40:13

English

04 Advanced Features

Playing movie continuously (Resume Play)

If you exit the playing movie function, the movie can be played later from the point where it was stopped.

1. Select the movie ﬁle you want to play continuously by pressing

the ◄ or ► button to select it from the ﬁle list section.

2. Press the



(Play) / ENTER

button.

3. Select Play Continuously (Resume Play) by pressing the Blue

button. The Movie will begin to play from where it was stopped.

The Blue button is available when resuming play.

✎

If the

✎

Continuous Movie Play Help function is set to On

in the Settings menu, a pop-up message will appear

when you resume play a movie file.

Music

Playing Music

1. Press the ◄ or ► button to select Music, then press the

ENTER

button in the Media Play menu.

2. Press the ◄/►/▲/▼ button to select the desired Music in the

ﬁle list.

3. Press the ENTER

button or



(Play) button.

During music playback, you can search using –◄ and ►

button.

 – (REW) and µ (FF) buttons do not function during play.

Only displays the files with MP3 and PCM file extension. Other

✎

file extensions are not displayed, even if they are saved on the

same USB device.

If the sound is abnormal when playing MP3 files, adjust the

✎

Equalizer in the Sound menu. (An over-modulated MP3 file

may cause a sound problem.)

Photos

Viewing a Photo (or Slide Show)

1. Press the ◄ or ► button to select Photos, then press the

ENTER

button in the Media Play menu.

2. Press the ◄/►/▲/▼ button to select the desired photo in the

ﬁle list.

3. Press the ENTER

button or



(Play) button.

While a photo list is displayed, press the –



(Play) /

ENTER

button on the remote control to start the slide

show.

All ﬁles in the ﬁle list section will be displayed in the slide show. –

During the slide show, ﬁles are displayed in order. –

Music files can be automatically played during the Slide Show if

✎

the Background Music is set to On.

The

✎

BGM Mode cannot be changed until the BGM has finished

Movie 01.avi

00:04:03 / 00:07:38 1/1

SUM

Play continuously

Pause

Jump

Tools

Return

Resumes playing from the last viewed

scene.

Play continuously

3/15

I Love you

Jhon

Music 1

No Singer

Music 2

No Singer

Music 3

No Singer

Music 4

No Singer

Music 5

No Singer

I Love You

Jhon

1st Album

Pop

2010

4.2MB

01:10 / 04:02

SUM

Pause

Jump

Tools

Return

Playlist

Image1024.jpg 1024x768 2010/2/1 3/15

SUM

Pause

Previous/Next

Tools

Return

Normal

BN68-02604A_Eng.indb 33 2010-06-29 �� 10:40:16

English

Advanced Features

Playing Multiple Files ¦

Playing selected video/music/photo ﬁles

1. Press the Yellow button in the ﬁle list to select the desired ﬁle.

2. Repeat the above operation to select multiple ﬁles.

NOTE

✎

The

mark appears to the left of the selected files.

To cancel a selection, press the Yellow button again.

To deselect all selected files, press the

TOOLS button

and select Deselect All.

3. Press the TOOLS button and select Play Selected Contents.

Playing the video/music/photo ﬁle group

1. While a ﬁle list is displayed, move to any ﬁle in desired group.

2. Press the TOOLS button and select Play Current Group.

Media Play - Additional Functions ¦

Sorting the ﬁle list

Press the Blue button in the ﬁle list to sort the ﬁles.

Category

Operation Videos Music Photos

Title You can move the other ﬁle directly.

Repeat Mode You can play movie and music ﬁles repeatedly.

c c

Picture Size

(Mode1 / Mode2 /

Original)

You can adjust the picture size to your preference.

Picture Setting You can adjust the picture setting. (p. 14, 15, 16)

c c

Sound Setting You can adjust the sound setting. (p. 16, 17)

c c c

Subtitle Setting You can play the video with Subtitles. This function only works if the subtitles are the

same ﬁle name as the video.

Audio You can enjoy video in one of supported languages as required. The function is only

enabled when stream-type ﬁles which support multiple audio formats are played.

Stop Slide Show /

Start Slide Show

You can start or stop a Slide Show.

Slide Show Speed You can select the slide show speed during the slide show.

Background Music You can set and select background music when watching a Slide Show.

Zoom You can zoom into images in full screen mode.

Rotate You can rotate images in full screen mode.

Information You can see detailed information about the played ﬁle.

c c c

Settings

Using the Setup Menu

Continuous Movie Play Help (Resume Play) (On / Off) ■: Select to display the help pop-up message for continuous movie

playback.

Get DivX® VOD registration code ■: Shows the registration code authorized for the TV. If you connect to the DivX web site

and register, you can download the VOD registration ﬁle. If you play the VOD registration using Media Play, the registration

is completed.

For more information on DivX® VOD, visit “www.DivX.com.”

✎

Get DivX® VOD deactivation code ■: When DivX® VOD is not registered, the registration deactivation code is displayed. If

you execute this function when DivX® VOD is registered, the current DivX® VOD registration is deactivated.

Information ■: Select to view information about the connected device.

BN68-02604A_Eng.indb 35 2010-06-29 �� 10:40:18

English

Advanced Features

Anynet+

What is Anynet+?

Anynet+ is a function that enables you to control all connected Samsung devices that support Anynet+ with your Samsung

TV’s remote. The Anynet+ system can be used only with Samsung devices that have the Anynet+ feature. To be sure your

Samsung device has this feature, check if there is an Anynet+ logo on it.

To connect to a Samsung Home Theater

1. Connect the HDMI IN (1(DVI), 2, 3 or 4) jack on the TV and the HDMI OUT jack of the corresponding Anynet+ device

using an HDMI cable.

2. Connect the HDMI IN jack of the home theater and the HDMI OUT jack of the corresponding Anynet+ device using an

HDMI cable.

NOTE

✎

Connect the Optical cable between the

DIGITAL AUDIO OUT (OPTICAL) jack on your TV and the Digital Audio Input

on the Home Theater.

When following the connection above, the Optical jack only outputs 2 channel audio. You will only hear sound from

the Home Theater’s Front Left and Right speakers and the subwoofer. If you want to hear 5.1 channel audio, connect

the DIGITAL AUDIO OUT (OPTICAL) jack on the DVD / Satellite Box (i.e. Anynet Device 1 or 2) directly to the

Amplifier or Home Theater, not the TV.

Only one Home Theater can be connected.

You can connect an Anynet+ device using the HDMI 1.3 cable. Some HDMI cables may not support Anynet+

functions.

Anynet+ works when the AV device supporting Anynet+ is in the standby or on status.

Anynet+ supports up to 12 AV devices in total. Note that you can connect up to 3 devices of the same type.

Anynet+

Device 1

HDMI Cable

Optical

Cable

Home Theater

Anynet+

Device 2, 3, 4

BN68-02604A_Eng.indb 36 2010-06-29 �� 10:40:18

English

04 Advanced Features

Anynet+ Menu

The Anynet+ menu changes depending on the type and status of the Anynet+ devices connected to the TV.

Anynet+ Menu Description

View TV Changes Anynet+ mode to TV broadcast mode.

Device List Shows the Anynet+ device list.

(device_name) MENU Shows the connected device menus. E.g. If a DVD recorder is connected, the disc menu of

the DVD recorder will appear.

(device_name) INFO Shows the play menu of the connected device. E.g. If a DVD recorder is connected, the

play menu of the DVD recorder will appear.

Recording: (*recorder) Starts recording immediately using the recorder. (This is only available for devices that

support the recording function.)

Stop Recording: (*recorder) Stops recording.

Receiver Sound is played through the receiver.

If more than one recording device is connected, they are displayed as (*recorder) and if only one recording device is

connected, it will be represented as (*device_name).

Setting Up Anynet+ ¦

→ Application → Anynet+ (HDMI-CEC) → ENTER

Setup ■

Anynet+ (HDMI-CEC) (Off / On): To use the Anynet+ Function, Anynet+ (HDMI-CEC) must be set to On.

When the

✎

Anynet+ (HDMI-CEC) function is disabled, all the Anynet+ related operations are deactivated.

Auto Turn Off (No / Yes): Setting an Anynet+ Device to turn off automatically when the TV is turned off.

✎

Auto Turn Off is set to Yes, running external devices will turn off at the same time as the TV powers off.

However, a device may not turn off if recording is in progress.

May not be enabled depending on the device.

✎

Switching between Anynet+ Devices ¦

1. Anynet+ devices connected to the TV are listed.

If you cannot find a device you want, press the red button to refresh the list.

✎

2. Select a device and press the ENTER

button. You can switch to the selected device.

Only when you set

✎

Anynet+ (HDMI-CEC) to On in the Application menu, the Device List menu appears.

Switching to the selected device may take up to 2 minutes. You cannot cancel the operation during the switching

operation.

If you have selected external input mode by pressing the

SOURCE button, you cannot use the Anynet+ function.

Make sure to switch to an Anynet+ device by using the Device List.

Recording ¦

You can make a recording of a TV Program using a Samsung recorder.

1. Select Recording.

When there are more than two recording devices

✎

When multiple recording devices are connected, the recording devices are listed. Select one recording device in

the Device List.

When the recording device is not displayed, select

✎

Device List and press the Red button to search devices.

2. Press the EXIT button to exit.

You can record the source streams by selecting

✎

Recording: (device_name).

Pressing the

✎

(REC) button will record whatever you are currently watching. If you are watching video from

another device, the video from the device is recorded.

Before recording, check whether the antenna jack is properly connected to the recording device. To properly

✎

connect an antenna to a recording device, refer to the recording device’s users manual.

BN68-02604A_Eng.indb 37 2010-06-29 �� 10:40:18

English

Advanced Features

Listening through a Receiver ¦

You can listen to sound through a receiver (i.e Home Theater) instead of the TV speaker.

1. Select Receiver and set to On.

2. Press the EXIT button to exit.

If your receiver supports audio only, it may not appear in the device list.

✎

The receiver will work when you have properly connected the optical in jack of the receiver to the

✎

DIGITAL AUDIO

OUT (OPTICAL) jack of the TV.

When the receiver (i.e Home Theater) is set to

✎

On, you can hear sound output from the TV’s Optical jack. When

the TV is displaying a DTV (air) signal, the TV will send out 5.1 channel sound to the receiver. When the source is a

digital component such as a DVD and is connected to the TV via HDMI, only 2 channel sound will be heard from

the receiver.

NOTE

✎

You can only control Anynet+ devices using the TV remote control, not the buttons on the TV.

The TV remote control may not work under certain conditions. If this occurs, reselect the Anynet+ device.

The Anynet+ functions do not operate with other manufacturers’ products.

Troubleshooting for Anynet+ ¦

Problem Possible Solution

Anynet+ does not work. Check if the device is an Anynet+ device. The Anynet+ system supports Anynet+ devices only.•

Only one receiver (home theater) can be connected.•

Check if the Anynet+ device power cord is properly connected.•

Check the Anynet+ device’s Video/Audio/HDMI cable connections.•

Check whether • Anynet+ (HDMI-CEC) is set to On in the Anynet+ setup menu.

Check whether the TV remote control is in TV mode.•

Check whether the remote control is Anynet+ compatible.•

Anynet+ does not work in certain situations. (Searching channels, operating • Media Play or Plug & Play

(initial setup), etc.)

When connecting or removing the HDMI cable, please make sure to search devices again or turn your •

TV off and on again.

Check if the Anynet+ Function of Anynet+ device is set on.•

I want to start Anynet+. Check if the Anynet+ device is properly connected to the TV and check if the • Anynet+ (HDMI-CEC) is

set to On in the Anynet+ Setup menu.

Press the • TOOLS button to display the Anynet+ menu and select a menu you want.

I want to exit Anynet+. Select • View TV in the Anynet+ menu.

Press the • SOURCE button on the TV remote control and select a device other than Anynet+ devices.

Press • > CH <, CH LIST, PRE-CH, and FAV.CH to change the TV mode. (Note that the channel

button operates only when a tuner-embedded Anynet+ device is not connected.)

The message ‘Connecting to

Anynet+ device...’ appears on

the screen.

You cannot use the remote control when you are conﬁguring Anynet+ or switching to a view mode.•

Use the remote control when the Anynet+ setting or switching to view mode is complete.•

The Anynet+ device does not

play.

You cannot use the play function when • Plug & Play (initial setup) is in progress.

The connected device is not

displayed.

Check whether or not the device supports Anynet+ functions.•

Check whether or not the HDMI cable is properly connected.•

Check whether • Anynet+ (HDMI-CEC) is set to On in the Anynet+ setup menu.

Search Anynet+ devices again.•

You can connect an Anynet+ device using the HDMI cable only. Some HDMI cables may not support •

Anynet+ functions.

If it is terminated by an abnormal situation such as disconnecting the HDMI cable or power cord or a •

power failure, please repeat the device scan.

The TV Program cannot be

recorded.

Check whether the antenna jack on the recording device is properly connected.•

The TV sound is not output

through the receiver.

Connect the optical cable between TV and the receiver.•

BN68-02604A_Eng.indb 38 2010-06-29 �� 10:40:19

English

04 Advanced Features

AllShare

→ Application → AllShare → ENTER

About AllShare ¦

AllShare connects your TV and compatible Samsung mobile

phones / devices through a network. On your TV, you can

view call arrivals, SMS messages and schedules set on your

mobile phones. In addition, you can play media contents

including videos, photos and music saved on your mobile

phones or the other devices (such as your PC) by controlling

them on the TV via the network. Additionally, you can use

your TV for browsing web pages in your mobile phones.

For more information, visit “www.samsung.com” or

✎

contact the Samsung call center. Mobile devices may

need additional software installation. For details, refer to

each device’s user’s guide.

Setting Up AllShare ¦

Setup

Message (On / Off) ■: Enables or disables the message

function (for call arrivals SMS messages and schedules

set on your mobile phones).

Media (On / Off) ■: Enables or disables the media

function. When the media function is on, it plays videos,

photos and music from a mobile phone or other device

that supports AllShare.

ScreenShare (On / Off) ■: Enables or disables the

ScreenShare function for using mobile phone as a

remote control.

TV name ■: Sets the TV name so you can ﬁnd it easily on

a mobile device.

If you select

✎

User Input, you can type on the TV

using the OSK (On Screen Keyboard).

Message / Media / ScreenShare

Shows a list of mobile phones or connected devices which

have been set up with this TV for using the Message,

Media, or ScreenShare function.

The

✎

Media function is available in all mobile devices

which support AllShare.

Allowed / Denied ■: Allows/Blocks the mobile phone.

Delete ■: Deletes the mobile phone from the list.

This function only deletes the name of the mobile

✎

from the list. If the deleted mobile device is turned

on or trieds to connect to the TV, it may appear on

the list again.

Using the Message Function

Using this function, you view call arrivals, SMS messages

and schedules set on the mobile phone through the alarm

window while watching TV.

NOTE

✎

To disable the alarm window, set

Message to Off in

Setup of AllShare.

OK is selected, or if OK is not selected after the

message has appeared three times, the message

will be deleted. The message is not deleted from the

mobile phone.

The alarm window can be displayed while using

some applications such as Media Play etc. To view

the contents of a message, switch to TV viewing

mode.

When a message from an unknown mobile phone is

displayed, select the mobile phone on the message

menu in AllShare and select Denied to block the

phone.

Message View

If a new SMS message arrives while you are watching

TV, the alarm window appears. If you click the OK

button, the contents of the message are displayed.

You can configure the viewing settings for SMS

✎

messages on your mobile phones. For the

procedures, refer to the mobile phone manual.

Some types of characters may be displayed as

✎

blank or broken characters.

AllShare

3/7

Select R Return e Exit

Setup R Return

Messange

Media

ScreenShare

Messange : On

Media : On

ScreenShare : On

TV name : Home TV

Setup

BN68-02604A_Eng.indb 39 2010-06-29 �� 10:40:19

English

Advanced Features

Call Arrival Alarm

If a call arrives while you are watching TV, the alarm

window appears.

Schedule Alarm

While you are watching TV, the alarm window appears to

display the registered event.

You can configure viewing settings for schedule

✎

contents on your mobile phones. For the

procedures, refer to the mobile phone manual.

Some special characters may be displayed as

✎

blank or broken characters.

Using the Media Function

An alarm window appears informing the user that the media

contents (videos, photos, music) sent from a mobile phone

will be displayed on your TV. The contents are played

automatically 3 seconds after the alarm window appears.

If you press the RETURN or EXIT button when the alarm

window appears, the media contents are not played.

NOTE

✎

If the media function executes for the first time,

the warning popup windows appears. Press the

ENTER

button to select Allow, then you can use

Media function on that device.

To turn off the media contents transmission from

the mobile phone, set Media to Off in the AllShare

setup.

Contents may not be played on your TV depending

on their resolution and format.

The

ENTER

and ◄ / ► buttons may not work

depending on the type of media content.

Using the mobile device, you can control the media

playing. For details, refer to each mobile’s user’s

guide.

When you want to play media contents from

your PC, select the PC icon on the main display

of AllShare. Then the TV’s Media Play menu

automatically changes. For more detail information,

refer to “Media Play”. (P. 29)

Using ScreenShare Function

Using ScreenShare, you can browse various web contents

provided by the mobile phone. For example, the image

below displays an access page for contents on a mobile.

You can read the mobile’s ﬁles and view the phone book and

calendar on the TV. Also, in the phone book, you can make a

call to another person, or send to SMS.

NOTE

✎

You must have ScreenShare installed on your

Samsung Mobile phone/device to use this feature.

Doc Viewer

can read files in doc format, but cannot

modify them.

The screen display may differ depending on the

connected device.

Using your Samsung Phone to Operate Your TV

Before you can use this feature, you must connect to

a Samsung mobile phone that supports ScreenShare

functions. When operating the TV with your mobile phone,

only the POWER,

and MUTE buttons

are supported.

Even if you keep pressing down on a control button

✎

(channel or volume) on the mobile phone the value will

only go up or down by one unit.

My Mobile

Contacts Calendar Doc viewer

E Select

Return

"Unknown Device 0" is requesting that the media ﬁle be allowed to play.

If you wish to allow the media ﬁle to be played at your device, please press

"Allow", otherwise press "Deny".

You can also change the setting (or resetting) of this feature at "AllShare

Setup".

Warning: Please note that if your device is connected to unsecured or

unfamiliar network, unwanted or inappropriate contents might be played.

If you are not sure about the network's identity or content's

appropriateness, we strongly recommend that you do not "Allow" the

request to play.

Allow Deny

BN68-02604A_Eng.indb 40 2010-06-29 �� 10:40:19

English

05 Other Information

Assembling the Cables

Enclose the cables in the Cable tie so that the cables are not visible through the

transparent stand.

Overly rigid or thick cables can damage input jacks over long term use.

Cable tie

Anti-theft Kensington Lock

The Kensington Lock is not supplied by Samsung. It is a device used to physically ﬁx the system when using it in a public

place. The appearance and locking method may differ from the illustration depending on the manufacturer. Refer to the manual

provided with the Kensington Lock for additional information on proper use.

Please find a “

✎

K” icon on the rear of the TV. A kensington slot is beside the “K” icon.

To lock the product, follow these steps:

1. Wrap the Kensington lock cable around a large, stationary object such

as desk or chair.

2. Slide the end of the cable with the lock attached through the looped end

of the Kensington lock cable.

3. Insert the locking device into the Kensington slot on the product (1).

4. Lock the lock.

These are general instructions. For exact instructions, see the User

✎

manual supplied with the locking device.

The locking device has to be purchased separately.

✎

The location of the Kensington slot may be different depending on the TV model.

✎

Installing the Wall Mount

Assembling the Blanking Bracket

When installing the TV onto a wall, attach the Blanking Bracket as shown.

Blanking Bracket

Preparing before installing Wall-Mount (46inch TV)

To install a wall-mount from another manufacturer, use the Holder-Ring.

Other Information

BN68-02604A_Eng.indb 41 2010-06-29 �� 10:40:20

English

Other Information

Installing the Wall Mount Kit

The wall mount kit (sold separately) allows you to mount the TV on the wall.

For detailed information on installing the wall mount, see the instructions provided with the wall mount items. Contact a

technician for assistance when installing the wall mount bracket. Samsung Electronics is not responsible for any damage to the

product or injury to yourself or others if you elect to install the TV on your own.

Wall Mount Kit Speciﬁcations (VESA)

The wall mount kit is not supplied, but sold separately.

✎

Install your wall mount on a solid wall perpendicular to the ﬂoor. When attaching to other building materials, please contact

your nearest dealer. If installed on a ceiling or slanted wall, it may fall and result in severe personal injury.

NOTE

✎

Standard dimensions for wall mount kits are shown in the table below.

When purchasing our wall mount kit, a detailed installation manual and all parts necessary for assembly are provided.

Do not use screws that do not comply with the VESA standard screw specifications.

Do not use screws that are longer than the standard dimension or do not comply with the VESA standard screw

specifications. Screws that are too long may cause damage to the inside of the TV set.

For wall mounts that do not comply with the VESA standard screw specifications, the length of the screws may differ

depending on the wall mount specifications.

Do not fasten the screws too strongly; this may damage the product or cause the product to fall, leading to personal

injury. Samsung is not liable for these kinds of accidents.

Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or

the consumer fails to follow the product installation instructions.

Do not mount the TV at more than a 15 degree tilt.

Always use two people to mount the TV to a wall.

Product Family inches VESA Spec. (A * B) Standard Screw Quantity

LCD-TV

19~22 75 X 75

100 X 100 M4

23~29 200 X 100

30~40 200 X 200 M6

46~55 400 X 400

57~65 600 X 400

70~80 800 X 400

80~ 1400 X 800

Do not install your Wall Mount Kit while your TV is turned on. It may result in personal injury due to

electric shock.

BN68-02604A_Eng.indb 42 2010-06-29 �� 10:40:21

English

05 Other Information

Securing the TV to the Wall

Caution: Pulling, pushing, or climbing on the TV may cause the TV to fall. In particular, ensure your children do

not hang over or destabilize the TV. Doing so may cause the TV to tip over, causing serious injuries or death.

Follow all safety precautions provided in the Safety Flyer included with your TV. For added stability and safety,

you can purchase and install the anti-fall device as described below.

The TV-Holder Kit (Sold Separately)

The parts below are included in the TV Holder kit. In addition, you need to provide a wood screw, screw and molly, or other screw

appropriate for the wall or cabinet you intend to secure the TV-Holder string to. We recommend a size M4xL20 wood screw.

(M6 X L16 : 32 ~ 40 inch TVs) (M8 X L19 : 46 inch TV)

TV-Holder (BN96-15753A) Screw 1Screw 2

Installing the TV-Holder

1. Remove the screw attached to the back of your TV, and then connect the TV-Holder to the TV with the screw included in

the TV Holder Kit (

)

that is designated for your TV.

Make sure to use only the appropriate supplied screw. If you use a different screw, you can damage your TV.

✎

2. Firmly fasten the screw you provided (size M4xL20 or similar) to the wall or cabinet where the TV is to be installed.

If you fasten the screw to the wall, we recommend you drive the screw into a stud. If that is not possible, use a

✎

molly to anchor the screw.

3. Tie the TV-Holder cord to the screw fastened to the wall or cabinet so that the TV is ﬁxed. See the illustrations below.

Install the TV close to the wall so that it does not fall.

✎

When attaching the TV Holder cord to the wall, tie the cord level with the ground or slanted downwards for safety purposes.

✎

Check the cord occasionally to make sure it is secure.

✎

Before moving the TV, separate the connected cord first.

✎

4. Verify all connections are properly secured. Periodically check the connections for any sign of fatigue or failure. If you have

any doubt about the security of your connections, contact a professional installer.

To purchase the TV-Holder Kit, contact Samsung Customer Care

– In the United States: 1-800-Samsung (1-800-726-7864)

– In Canada: 1-800-Samsung (1-800-726-7864)

Wall

BN68-02604A_Eng.indb 43 2010-06-29 �� 10:40:21

English

Other Information

Troubleshooting

If the TV seems to have a problem, ﬁrst try this list of possible problems and solutions. If none of these troubleshooting tips

apply, visit samsung.com, then click on Support, or call Samsung customer service at 1-800-SAMSUNG.

Issues Solutions and Explanations

Poor picture First of all, please perform the Picture Test and conﬁrm that your TV is properly displaying the test

image.

go to • MENU - Support - Self Diagnosis - Picture Test (P. 21)

If the test image is properly displayed, the poor picture may be caused by the source or signal.

The TV image does not look as good as

it did in the store.

If you have an analog cable/satellite box, upgrade to a digital set top box. Use HDMI or •

Component cables to deliver HD (high deﬁnition) picture quality.

Cable/Satellite subscribers: Try HD stations from the channel line up.•

Air/Cable Antenna connection: Try HD stations after performing Auto program.•

Many HD channels are upscaled from SD(Standard Deﬁnition) contents.

✎

Adjust the Cable/Sat box video output resolution to 1080i or 720p.•

The picture is distorted: macroblock

error, small block, dots, pixelization.

Compression of video contents may cause picture distortion, especially in fast moving pictures •

such as sports and action movies.

Low signal level can cause picture distortion. This is not a TV problem.•

Mobile phones used close to the TV (up to 3.3 ft) may cause noise in picture on analog and •

digital TV.

Color is wrong or missing. If you’re using Component connection, make sure the component cables are connected to the •

correct jacks. Incorrect or loose connections may cause color problems or a blank screen.

There is poor color or brightness. Adjust the Picture options in the TV menu. •

(go to Picture mode / Color / Brightness / Sharpness) (P. 14)

Adjust • Energy Saving option in the TV menu (go to MENU - Picture - ECO Solution - Energy

Saving) (P. 14)

Try resetting the picture to view the default picture setting. •

(go to MENU - Picture - Picture Reset) (P. 16)

There is a dotted line on the edge of

the screen.

If the picture size is set to • Screen Fit, change it to 16:9.

Change cable/satellite box resolution.•

The picture is black and white. If you are using an AV composite input, connect the video cable (yellow) to the Green jack of •

component input 1 on the TV.

When changing channels, the picture

freezes or is distorted or delayed.

If connected to a cable box, please try to reset it. (reconnect the AC cord and wait until the •

cable box reboots. It may take up to 20 minutes)

Set output resolution of the cable box to 1080i or 720p.•

Sound Problem First of all, please perform the Sound Test to conﬁrm that your TV audio is properly operating.

go to • MENU - Support - Self Diagnosis - Sound Test (P. 21)

If the audio is OK, the sound problem may caused by the source or signal.

There is no sound or the sound is too

low at maximum volume.

Please check the volume of the device (Cable/Sat Box, DVD, Blu-ray etc) connected to your TV. •

The picture is good but there is no

sound.

Set the • Speaker Select option to TV speaker in the Sound menu. (P. 17)

If you are using an external device, check the device’s audio output option (ex. you may need to •

change your cable box’s audio option to HDMI when you have a HDMI connected to your TV).

If you are using a DVI to HDMI cable, a separate audio cable is required.•

Reboot the connected device by reconnecting the device’s power cable.•

The speakers are making an

inappropriate noise.

Check the cable connections. Make sure a video cable is not connected to an audio input.•

For Antenna or Cable connections, check the signal information. Low signal level may cause •

sound distortion.

Perform the • Sound Test as explained above.

BN68-02604A_Eng.indb 44 2010-06-29 �� 10:40:22

English

05 Other Information

Issues Solutions and Explanations

No Picture, No Video

The TV will not turn on. Make sure the AC power cord is securely plugged into the wall outlet and the TV.•

Make sure the wall outlet is working.•

Try pressing the • POWER button on the TV to make sure the problem is not the remote.

If the TV turns on, refer to ‘Remote control does not work’ below.

The TV turns off automatically. Ensure the • Sleep Timer is set to Off in the Setup menu. (P. 18)

If your PC is connected to the TV, check your PC power settings.•

Make sure the AC power cord is plugged in securely to the wall outlet and the TV.•

When watching TV from an antenna or cable connection, the TV will turn off after 10 - 15 •

minutes if there is no signal.

There is no picture/video Check cable connections. (remove and reconnect all cables connected to the TV and external •

devices).

Set your external device’s (Cable/Sat Box, DVD, Blu-ray etc) video outputs to match the •

connections to the TV input. For example, if an external device’s output is HDMI, it should be

connected to an HDMI input on the TV.

Make sure your connected devices are powered on.•

Be sure to select the TV’s correct source by pressing the • SOURCE button on the remote

control.

Reboot the connected device by reconnecting the device’s power cable.•

RF(Cable/Antenna) Connection

The TV is not receiving all channels. Make sure the coaxial cable is connected securely.•

Please try • Auto Program to add available channels to the channel list.

go to MENU - Channel - Auto Program then select Auto and make sure the correct Cable TV

signal type is set in the menu. There are 3 options. (STD, HRC and IRC) (P. 12)

Verify the Antenna is positioned correctly.•

No Caption on digital channels. Check Caption Setup menu. Try changing • Caption Mode Service 1 to CC1. (P. 20)

Some channels may not have caption data.•

The picture is distorted: macroblock,

error, small block, dots, pixelization.

Compression of video contents may cause picture distortion. especially on fast moving pictures •

such as sports and action movies.

A low signal can cause picture distortion. This is not a TV problem.•

PC Connection

A “Mode Not Supported” message

appears.

Set your PC’s output resolution so it matches the resolutions supported by the TV.•

“PC” is always shown on the source list,

even if a PC is not connected.

This is normal; “PC” is always shown on the source list, regardless of whether a PC is •

connected.

The video is OK but there is no audio. If you are using a HDMI connection, check the audio output setting on your PC.•

Network Connection

The wireless network connection failed. Samsung Wireless USB dongle is required to use a wireless network.•

Make sure the Network Connection is set to • Wireless. (P. 25)

Make sure the TV is connected to a wireless IP sharer (Router).•

Software Upgrade over the network

fails.

Try network test in • Setup menu. (P. 26)

If you have latest SW version, SW upgrade will not proceed.•

BN68-02604A_Eng.indb 45 2010-06-29 �� 10:40:22

English

Other Information

Issues Solutions and Explanations

Others

Purple/green rolling horizontal bars and

buzzing noise from the TV speakers

with Component cable connection.

Remove the left and right audio connections from the set-top-box. If the buzzing stops, this •

indicates that the set-top-box has a grounding issue. Replace the Component video cables

with an HDMI connection.

The picture will not display in full screen. HD channels will have black bars on either side of the screen when displaying upscaled SD •

(4:3) contents.

Black bars on Top & Bottom will be shown on movies that have aspect ratios different from your •

T V.

Adjust picture size option on your external device or TV to full screen.•

The remote control does not work. Replace the remote control batteries with correct polarity (+/–).•

Clean the transmission window located on the top of the remote.•

Try pointing the remote directly at the TV from 5~6 feet away.•

The cable/set top box remote control

does not turn the TV on or off, or adjust

the volume.

Program the Cable/Sat remote control to the operate the TV. Refer to the Cable/Sat user •

manual for SAMSUNG TV code.

A “Mode Not Supported” message

appears.

Check the supported resolution of the TV and adjust the external device’s output resolution •

accordingly. Refer to resolution settings in this manual.

Caption on TV menu is greyed out. Caption• can not be selected in the TV menu when connected via HDMI or Component.

Caption• must be activated on the external device.

There is a plastic smell from the TV. This smell is normal and will dissipate over time.•

TV Signal Information is unavailable in

the Self Diagnosis Test menu.

This function is only available with digital channels from an Antenna / RF/Coax connection. •

(P. 21)

TV is tilted to the right or left side. Remove the stand base from the TV and reassemble it.•

The Channel menu is grey out

(unavailable).

The • Channel menu is only available when the TV source is selected.

Your settings are lost after 30 minutes

or every time the TV is turned off.

If TV is in the • Store Demo mode, it will reset audio and picture settings every 30 minutes.

Please change from Store Demo mode to Home Use mode in the Plug & Play procedure.

Press the SOURCE button to select TV mode, go to MENU → Setup → Plug & Play →

ENTERE.

You have intermittent loss of audio or

video.

Check the cable connections and reconnect them.•

Loss of audio or video can be caused by using overly rigid or thick cables. Make sure the •

cables are ﬂexible enough for long term use. mounting the TV to the wall, we recommend using

cables with 90 degree connectors.

The PIP menu is not available. PIP• functionality is only available when you are using a HDMI, PC or components source.

You see small particles when you look

closely at the edge of the frame of the

T V.

This is part of the product’s design and is not a defect.•

POP (TV’s internal banner ad) appears

on the screen.

Select • Home Use under Plug & Play mode.

For details, refer to Plug & Play (Initial Setup) (P. 7)

This TFT LCD panel uses a panel consisting of sub pixels which require sophisticated technology to produce. However,

✎

there may be a few bright or dark pixels on the screen. These pixels will have no impact on the performance of the

product.

BN68-02604A_Eng.indb 46 2010-06-29 �� 10:40:22

English

05 Other Information

Speciﬁcations

Display Resolution

1920 x 1080

Environmental Considerations

Operating Temperature

Operating Humidity

Storage Temperature

Storage Humidity

10°C to 40°C (50°F to 104°F)

10% to 80%, non-condensing

-20°C to 45°C (-4°F to 113°F)

5% to 95%, non-condensing

Stand Swivel

(Left / Right)

-20˚ ~ 20˚

Model Name

LN32C550 LN37C550 LN40C550 LN46C550

Screen Size

(Diagonal)

32 inches

(31.5 inches measured

diagonally)

37 inches

(37.0 inches measured

diagonally)

40 inches

(40.0 inches measured

diagonally)

46 inches

(45.9 inches measured

diagonally)

Sound

Output

10 W X 2

Dimensions (WxDxH)

Body

With stand

31.2 X 3.1 X 19.5 inches

(793.7 X 78 X 494.3 (mm))

31.2 X 9.4 X 21.9 inches

(793.7 X 239 X 557.5 (mm))

35.9 X 3 X 22 inches

(911.6 X 78.2 X 559.4 (mm))

35.9 X 10 X 24.5 inches

(911.6 X 255 X 622.8 (mm))

38.6 X 3.2 X 23.5 inches

(980.2 X 80.3 X 597 (mm))

38.6 X 10 X 26 inches

(980.2 X 255 X 660.9 (mm))

43.8 X 3.2 X 26.5 inches

(1112.5 X 80.3 X 672.5 (mm))

43.8 X 10.8 X 29 inches

(1112.5 X 275 X 736 (mm))

Weight

Without Stand

With Stand

20.7 Ibs (9.4 kg)

26.7 Ibs (12.1 kg)

26.5 Ibs (12 kg)

34 Ibs (15.4 kg)

32.6 Ibs (14.8 kg)

40.8 Ibs (18.5 kg)

38.1 Ibs (17.3 kg)

48.3 Ibs (21.9 kg)

Design and specifications a

✎

re subject to change without prior notice.

This device is a Class B digital apparatus.

✎

For information about power supply, an

✎

d more about power consumption, refer to the label attached to the product.

License ¦

Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are

trademarks of Dolby Laboratories.

DivX Certiﬁed to play DivX video up to HD 1080p, including premium content.

ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX,Inc. This is an ofﬁcial DivX Certiﬁed device that

plays DivX video. Visit www.divx.com for more information and software tools to convert your ﬁles into DivX video.

ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certiﬁed® device must be registered in order to play DivX Video-on-

Demand (VOD) content. To generate the registration code, locate the DivX VOD section in the device setup menu.

Go to vod.divx.com with this code to complete the registration process and learn more about DivX VOD.

Pat. 7,295,673; 7,460,688; 7,519,274

Manufactured under license under U.S. Patent #’s: 5,451,942; 5,956,674; 5,974,380; 5,978,762;

6,487,535 & other U.S. and worldwide patents issued & pending. DTS and the Symbol are

registered trademarks, & DTS 2.0+ Digital Out and the DTS logos are trademarks of DTS, Inc.

Open source license notice

In the case of using open source software, Open Source Licenses are available on the product menu.

BN68-02604A_Eng.indb 47 2010-06-29 �� 10:40:23

English

Other Information

Dimensions

Front view / side view ■

(Unit: inches)

Model name 12345678

LN32C550 31.2 27.5 15.5 17.5 19.5 21.9 3.1 9.4

LN37C550 35.9 32.3 18.2 20.5 22 24.5 3 10

LN40C550 38.6 35 19.7 20.5 23.5 26 3.2 10

LN46C550 43.8 40.1 22.6 21.7 26.5 29 3.2 10.8

Jack panel detail / rear view ■

(Unit: inches)

Model name 1 2 3 4 5 6

LN32C550 9.3 2.0 3.8 20.9 7.9 7.9

LN37C550 12.4 3.2 3.3 24.6 7.9 7.9

LN40C550 13.2 3.7 4.0 27.6 7.9 7.9

LN46C550 16.1 3.7 4.0 31.8 15.7 15.7

NOTE: All drawings are not necessarily to scale. Some dimensions are subject to change without prior notice. Refer to the

dimensions prior to performing installation of your TV. Not responsible for typographical or printed errors.

BN68-02604A_Eng.indb 48 2010-06-29 �� 10:40:24

English

05 Other Information

Index

AllShare 39

Antenna 7

Anynet+ 36

AUDIO OUT 9

Auto Adjustment 14

Auto Program 12

Blanking Bracket 41

Balance 16

Cables 10

Cable Tie 41

Caption 20

Clear Scrambled Channel 13

Clear Voice 16

Component 8

Composite 10

Device List 37

DIGITAL AUDIO OUT 9, 36

DST (Daylight Saving Time) 18

D-sub 9, 10

Dynamic Contrast 15

Energy Saving 14

Equalizer 16

External Speaker 17

FAV.CH button 6, 12

Favorite Channel 12

HD 16

HDMI 8

Home theater 9, 35

Internet Protocol Setup 24

License 47

Media Play 29

Melody 21

Menu Language 20

MP3 Play 33

MTS 6, 17

Network Connection 23

Network Setup 24

ON/OFF button 6

Optimal resolution 10

Photo view 33

Picture Reset 16

PIN number 18

PIP 21

Position 21

Power Indicator 5

Remote Control 6

RGB 15

Screen Fit 15

Sleep Timer 18

Slide Show 33

Software Upgrade 22

Source List 11

Speaker Select 17

Standby mode 5

Supported Subtitle Formats 31

Supported Video Formats 32

Timer 18

Video play 31

Virtual Surround 16

Volume 5, 6, 18

Wall Mount 41

White Balance 15

Wide Fit 15

Wireless 25

BN68-02604A_Eng.indb 49 2010-06-29 �� 10:40:24

This page is intention-

ally left blank.

BN68-02604A_Eng.indb 50 2010-06-29 �� 10:40:24

Samsung Ln37C550 Users Manual

LN40C550 to the manual 150fb8e3-198f-46f8-8d75-0ea5632feef0

Navigation menu

Versions of this User Manual:

Views

Navigation
