E-MANUAL
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/register
Model______________ Serial No.______________
Channel Menu
Managing Channels
and Channel Functions 1
Memorizing Channels 41
Other Features 46
Basic Feature
Changing the Preset Picture Mode 50
Adjusting Picture Settings 53
Changing the Picture Size 58
Changing the Picture Options 67
Using the TV with Your PC 86
Changing the Preset Sound Mode 90
Adjusting Sound Settings 92
Preference Feature
Connecting to the Network 104
Setting up a Wired Network 115
Setting up a Wireless Network 126
Managing the
Network Connected Devices 152
Setting the Time 163
Blocking Programs 180
Economical Solutions 201
Picture In Picture (PIP) 205
Using the TV with a
Keyboard and a Mouse 210
Connecting to the TV
with a Samsung Audio Device 218
Other Features 221
Support Menu 243
Contents
Advanced Features
Using the 3D function 267
Smart Hub 281
Customizing the Home Screen 307
Using Samsung Apps 338
Search 348
Your Video 356
Family Story 373
Fitness 426
Kids 437
Web Browser 452
Skype 482
Samsung Link 485
Using the Samsung Link 508
My List (In Samsung Link) 512
Videos (In Samsung Link) 525
Photos (In Samsung Link) 543
Music (In Samsung Link) 559
Using the AllShare Function 573
Anynet+ (HDMI-CEC) 584
Other Information
Troubleshooting 601
Picture (Troubleshooting) 613
Sound (Troubleshooting) 620
Antenna (Air / Cable)
Connection (Troubleshooting) 624
PC Connection (Troubleshooting) 627
Network Connection
(Troubleshooting) 628
Others (Troubleshooting) 629
3D (Troubleshooting) 639
Anynet+ (HDMI-CEC)
(Troubleshooting) 641
Samsung Link (Troubleshooting) 648
Smart Hub (Troubleshooting) 649
Supported Subtitle and
Samsung Link file formats 659
Anti-theft Kensington Lock 668
Licenses 672
Managing Channels and Channel Functions
You can manage channels, access
channel functions, and schedule
channel and program viewing through
the Channel and Schedule Manager
functions. Both Channel and Schedule
Manager are located on the Smart Hub
screen.
To access Smart Hub, press the ²
button on your remote. The Smart Hub
screen appears.
Channel Menu
Select Channel to start the Channel
function. Select Schedule Manager to
start the Schedule Manager function.
You can also access the Smart Hub
screen through the Menu:
MenuSupportSmart Hub
Channel
² Channel
Using this function, you can add
channels to or delete channels from the
different Category channel lists on the
Channel screen, set favorite channels,
view and access recently viewed and
mostly viewed channels, and edit the
channel names of analog channels.
NThe American Academy of Pediatrics
discourages television viewing for
children younger than two years of
age.
Category Options (on the left side of the
Channel screen)
All
Shows all channels.
Added Ch.
Shows all added channels. This is the
list of channels your TV memorized
during the initial setup, less any
channels you have deleted. These
channels appear when you select CH
List.
Favorites 1Favorites 5
Lets you arrange and display favorite
channels in up to five groups. Each
group is independent of the other
groups and can contain the same
channels as other groups, different
channels, or a combination of both.
NThe TV displays Favorites only if
you have added favorites using Edit
Favorites in the Tools menu.
NIf you highlight the name of a
favorite group on the left side of
the screen, you can change the
name of the group by pressing b
on your remote, and then entering a
new name using the keyboard that
appears.
Recently Viewed
Shows the most recently viewed
channels.
Mostly Viewed
Shows the most frequently viewed
channels.
Using the colored and function buttons
with Channel
When the highlight is located in a
category on the left side, you can use
these options:
a Air / Cable
Switches the mode and display
between Air and Cable.
NAppears only if your TV stored
both Air and Cable channels.
R Return
Returns to the previous menu.
When the highlight is located in the
channel list, you can use these options:
a Air / Cable
Switches the mode and display
between Air and Cable.
NAppears only if your TV stored
both Air and Cable channels.
b Delete
Deletes the selected channel(s) from
a category list (except the favorites
lists).
` Information
Displays details of the selected
channel.
k Page
Scrolls the channel list to the next or
previous page.
NThese correspond to the Channel
buttons on the remote.
E Select / Deselect
Selects or deselects a channel.
T Tools
Displays the option menu.
R Return
Returns to the previous menu.
Using the Tools menu with Channel
Add / Delete
Delete a channel from or add a channel
to a Category list on the Channel list
screen.
To delete a channel from a Category
list on the Channel screen, follow these
steps:
1. Select a category that contains the
channel you want to delete.
2. Select a channel in the category list.
A c mark appears to the left of the
channel.
NYou can select more than one
channel.
NIf you re-select a channel you
selected, the c mark disappears.
3. Open the Tools menu using your
remote.
4. Select Delete. The message "Deleted
the selected channel(s)." appears.
Select OK.
NYou can delete the selected channel
immediately by selecting b using
your remote.
NWhen you delete a channel in the All
or Added Ch. lists, you are deleting
the channel from the Added Ch. list.
This means that when you press the
Channel buttons on your remote, the
channel will not longer appear. The
channel will, however, remain in the
All list, grayed out. You can add it
back to the Added Ch. list whenever
you like.
NWhen you delete a channel in the
Recently Viewed or Mostly Viewed
category, the channel will disappear
from that category list, but it is not
deleted from any of the other lists.
To add a channel to the Added Ch. list
on the Channel screen, follow these
steps:
1. On the Channel screen, select the All
category.
2. Select a grayed out channel in the All
category. A c mark appears to the
left of the channel.
NYou can select more than one
channel.
NIf you re-select a channel you
selected, the c mark disappears.
NA gray colored channel indicates
the channel has been deleted from
the Added Ch. list.
3. Open the Tools menu using your
remote.
4. Select the Add. The message Added
the selected channel(s). appears, and
then select OK.
NThe Add menu option only appears
when you select channels you have
deleted from Added Ch..
NAll deleted channels will be shown
in the All category. You add channels
back to the Added Ch. category on
the All category.
Edit Favorites
Lets you assign channels you watch
frequently to a favorites group and
remove channels from a favorites
group. You access Edit Favorites on the
Tools menu.
To set channels as favorites, follow
these steps:
1. Select the All or Added Ch. category.
2. Select a channel. A c mark appears
to the left of the channel.
NYou can select more than one
channel.
NIf you re-select a channel you
selected, the c mark disappears.
3. Open the Tools menu using your
remote.
4. Select Edit Favorites. The Edit
Favorites screen appears.
5. If you want, change to another
favorites group by selecting } using
your remote. Each time you select },
the favorites group changes.
6. Select a using your remote. The
selected channel will appear in the
favorite group you chose.
NYou can also select a channel on
the Edit Favorites screen from the
list of Added Ch. that is displayed
on the left of the screen.
7. When done, select OK on the right
side. The channel is made a favorite
and is assigned to the favorites
group you selected.
8. Edit completed. appears on the
screen. Select OK.
NThe TV displays the “ ” symbol
next to the channel, indicating it
is a favorite.
Using the colored and function buttons
with Edit Favorites
On the Edit Favorites screen, you can
use these functions buttons:
a Add
Add selected channels to the
favorites group.
} Change Fav.
Change the favorites group.
Each time you select } using
your remote, the favorites group
changes.
Ÿ Go To
When you press a number, the
highlight jumps to the first
channel that has that number. For
example, if I select 2, the highlight
can jump to 2-1 or 21-1.
R Return
Return to the previous menu.
When you highlight a favorite
channel in a favorites group on the
Edit Favorites screen, you can use
these options:
a Delete
Delete the selected channel.
b Change order
Change the favorites group list
order.
{ Copy
Copy a selected channel to other
favorites groups.
} Change Fav.
Change the favorites group.
Each time you select } using
your remote, the favorites group
changes.
Ÿ Go To
When you press a number, the
highlight jumps to the first
channel that has that number. For
example, if I select 2, the highlight
can jump to 2-1 or 21-1.
R Return
Return to the previous menu.
To remove a channel from a favorites
group, follow these steps:
1. Select the favorites group category.
2. Select a channel in the favorites
group. A c mark appears to the left
of the channel.
NYou can select more than one
channel.
NIf you re-select a selected channel,
the c mark disappears.
3. Open the Tools menu using your
remote.
4. Select Delete. The message Do you
want to delete the selected item(s)?
appears.
5. Select OK. The Deleted the selected
item(s). message appears.
Rename Channel
(Appears only if you have selected an
analog channel.)
Lets you assign a name of up to five
characters to an analog channel. For
example, Food, Golf, etc. This makes it
easier to find and select a channel.
Select All / Deselect All
Select all channels in the list. / Deselect
all channels you selected.
Display Icons Used in the Channel screens
: An analog channel.
: A favorite channel.
: A locked channel.
Schedule Manager
² Schedule Manager
Using this function, you can set
the TV to display a desired channel
automatically on a day and at a time of
your choice.
NYou must set the current time first
using the Time Clock function
in the System menu to use this
function.
To use Schedule Viewing, follow these
steps:
1. Select Schedule Manager on the
Smart Hub screen.
2. On the Schedule Manager screen,
select a using your remote.
3. Set Antenna, Channel, Repeat, and
Start Time.
Antenna
Select Antenna to see the source
selections, and then select the signal
source: DTV Air, Cable, etc. If your
TV receives digital broadcasts, you
can change the source from analog
to digital.
Channel
Select Channel to view the channel
numbers. Select the desired channel.
NYou can only select memorized
channels.
NYou can also enter the channel
number directly using the number
buttons on the standard remote.
Repeat
Select Once, Manual, Sat~Sun,
Mon~Fri or Everyday. If you select
Manual, you can set the day you
want.
NThe c mark indicates a day you’
ve selected.
Date: You can set a desired date.
NDate is available only when you
select Once in Repeat.
Start Time
You can set the start time you want.
3. When done, select OK. The selected
channel is scheduled for viewing.
NOn the Schedule Manager screen,
you can view a list of Schedule
Viewings.
To delete an item in a list of scheduled
viewings, follow these step:
1. On the Schedule Manager screen,
Highlight an item you want to delete.
2. Open the Tools menu using your
remote.
3. Select Cancel Schedule. The Cancel
selected list(s)? message appears.
4. Select Yes. The selected schedule is
canceled.
NIf you press the INFO button after
Highlighting an item, the Information
screen appears. On the Information
screen, you can change or cancel the
Schedule Viewing.
Cancel Schedule: Cancel the
Schedule Viewing.
Edit Schedule: Change the Schedule
Viewing.
Return: Return to the previous
screen.
Channel List
Using this function, you can view the
channel list, program information, and
favorite channels, select channels to
watch, and use Schedule Viewing on
digital channels.
1. Press the CH LIST button. The
Channel List screen is displayed
immediately.
2. Change a channel or channel list
mode.
Added Ch.
Shows all added channels.
Favorites 1Favorites 5
Shows all favorite channels, in up
to five groups. Each group has a
separate screen.
NThe TV displays favorite groups
only if you have added favorites
using Edit Favorites.
Using the colored and function buttons
with the Channel List
NIf you press the INFO button, the
TV displays details of the selected
program.
a Antenna
Switches the mode and display
between Air and Cable.
NAppears only if your TV has stored
both Air and Cable channels.
{ Program View / Channel View
For digital channels, switches the
display between Program View and
Channel View.
When you select a digital channel in
Channel List, select { once to display a
list of programs on that channel. Select
again to re-display the Channel View.
lr CH Mode / Channel
On the Channel View screen, toggles
between the Favorites lists (if you have
added favorites using Edit Favorites)
and the Added Ch. list. / On the Program
View screen, displays the programs for
the next or previous channel.
E Watch / Information
Displays the channel you selected. /
Displays details of the selected channel.
k Page
Scrolls the Channel List to the next or
previous page.
NThese correspond to the channel
buttons on your remote.
Display Icons Used in the Channel List
screens
: An analog channel.
: A reserved program.
: A locked channel.
Using Schedule Viewing in Channel List
(digital channels only)
You can use Schedule Viewing in
Channel List to schedule a digital
channel program for viewing. The TV
will turn on and display the digital
channel program when the program
begins.
1. Press the CH LIST button. The
Channel List screen appears.
2. Select a desired digital channel.
3. Select { using your remote. The
TV displays the program list of the
selected channel.
4. Select a desired program in the
program list, and then select
Information using your remote.
5. On the Information screen, select
Schedule Viewing. The selected
program is scheduled.
NIf you want to cancel the Schedule
Viewing, follow Steps 1 through 4,
and then select Cancel Schedule.
Memorizing Channels
Antenna
Menu Channel Antenna
Before your television can memorize
the available channels, you must select
your TV's signal source, Air (using
an antenna) or Cable. After you have
selected the signal source, go on to the
Auto Program function.
NSelecting the signal source using the
Antenna function also determines
the signal source the TV is tuned to.
For example, if you receive your TV
signal over the air, and you select
Cable, you will see only snow. You
must select Air to see a picture.
Auto Program
Menu Channel Auto Program
The Auto Program function memorizes
all channels that are available over the
air or through your cable system and
adds them to the Channel list.
To start the Auto Program, follow these
steps:
1. Go to the Auto Program menu.
2. Select Air or Cable or both, and then
select Next. A c mark appears in
the check box.
NIf you selected Air or Cable in the
Antenna menu, your choice will
already be selected.
3. If you selected Cable, the cable
system screen appears. Select Digital
Cable System.
NIf you selected Air only, the Auto
Program starts.
4. Select the correct cable signal format
- STD, HRC or IRC.
NMost cable systems use STD
(Standard).
5. Repeat for Analog Cable System.
6. Select Next. The Auto Program
starts.
NAfter all the available channels are
stored, the Auto Program removes
scrambled channels. When done,
the Auto Program menu then
reappears. This process can take
up to 30 minutes.
Other Features
Clear Scrambled Channel
Menu Channel Clear Scrambled
Channel
This function filters out scrambled
channels after the Auto Program is
completed. This process may take up
to 30 minutes.
NThis function is only available in
Cable mode.
How to Stop the Clear Scrambled Channel
function
1. To stop the Clear Scrambled Channel
function, select Stop.
2. The message Stop searching for
scrambled channels? appears. Select
Yes.
3. The Clear Scrambled Channel
function stops.
Fine Tune
Menu Channel Fine Tune
(analog channels only)
If the reception is clear, you do not
have to fine tune the channel, as this is
done automatically during the search
and store operation. If the signal is
weak or distorted, fine tune the channel
manually. Scroll to the left or right until
the image is clear.
NSelect the channel, and then select
Fine Tune.
NFine tuned channels that have been
saved are marked with an asterisk “*”
on the right-hand side of the channel
number in the channel banner.
NTo reset fine-tuning, select the
channel, select Fine Tune, and then
select Reset on the Fine Tune screen.
Changing the Preset Picture Mode
Picture Mode
Menu Picture Picture Mode
Picture modes apply preset adjustments
to the picture.
NWhen your TV is connected to a PC
via an HDMI to DVI cable, you can
only select Entertain and Standard.
Dynamic
Brightens the screen. Suitable for a
bright room.
Basic Feature
Standard
Suitable for a normal environment.
Natural for LED TV / Relax for PDP 6500
Series and above
Suitable for reducing eye strain.
Movie
Darkens the screen, making it less
glary. Suitable for watching movies in a
darkened room.
Entertain
Sharpens the picture. Suitable for
games.
NOnly available when the TV is
connected to a PC via an HDMI to
DVI and an HDMI to HDMI cables.
Adjusting Picture Settings
Backlight for LED TV / Cell Light for PDP TV
Menu Picture Backlight / Cell Light
Adjusts the brightness of the screen
by adjusting the brightness of the
individual pixels.
Contrast
Menu Picture Contrast
Increases or decreases the contrast
between dark and light areas of the
picture.
Brightness
Menu Picture Brightness
Adjusts the brightness of the screen.
Not as effective as Backlight / Cell
Light.
Sharpness
Menu Picture Sharpness
Sharpens or dulls the edges of objects.
Color
Menu Picture Color
Adjusts the color saturation. The higher
the Color setting, the more intense the
color. Low settings remove color and
the picture becomes black, white, and
gray.
Tint (G/R)
Menu Picture Tint (G/R)
Adjusts the amount of green and red in
the picture. As you increase the amount
of green, the amount of red decreases
and vice versa.
To adjust picture quality, follow these steps:
1. Select an option you want to adjust.
When you select an option, a slider
screen appears.
2. Adjust the option value using your
remote.
NWhen you change an option value,
the change will affect the OSD menu
also.
NWhen your TV is connected to a PC
via an HDMI to DVI cable, Color and
Tint (G/R) are not available.
NYou can adjust and store settings for
each external device connected to
the TV.
NLowering picture brightness reduces
power consumption.
Changing the Picture Size
Screen Adjustment
Menu Picture Screen Adjustment
Using this function, you can select
various picture size and aspect ratio
options.
Picture Size
If you have a cable box or satellite
receiver, it may have its own set of
screen sizes as well. However, we
highly recommend you use your TV's
16:9 mode most of the time.
16:9: Sets the picture to the 16:9 wide
screen format.
Zoom1: Provides moderate
magnification of the picture. Sides, top,
and bottom are cut off.
Zoom2: Provides larger magnification
of the picture. Sides, top, and bottom
are cut off.
Wide Fit: Enlarges the aspect ratio of
the picture so it fits the entire screen.
NAvailable with HD 1080i / 720p
signals in 16:9 mode.
4:3: Sets the picture to basic (4:3)
mode.
NDo not set your TV to 4:3 format for
a long time. The borders displayed
on the left and right, or top and
bottom of the screen may cause
image retention (screen burn) which
is not covered by the warranty.
Screen Fit: When your TV inputs HDMI
(720p / 1080i / 1080p) or Component
(1080i / 1080p) signals, displays the full
image without any cut-off.
Smart View 1: Reduces the 16:9 picture
by 50%. for LED TV
Smart View 2: Reduces the 16:9 picture
by 25%. for LED TV
NSmart View 1 is enabled only in
HDMI mode.
NSmart View 2 is enabled only in
HDMI or DTV mode.
NThe picture size can vary when
you play content from Videos in
Samsung Link depending on the
input resolution.
Position
Adjusts the picture position. Position
is only available if Picture Size is set to
Zoom1, Zoom2, Wide Fit, or Screen Fit.
NIn DTV mode, Position is not
available when Picture Size is set to
Screen Fit.
To use the Position function after
selecting Zoom1, Zoom2, Wide Fit or
Screen Fit, follow these steps:
1. Select Position.
2. On the Position screen, select
Position, and then move the picture
to the position you want using your
remote.
3. When done, select Position again,
and then select Close.
NTo reset the picture position,
select Reset.
Picture Sizes available by Input Source:
ATV, AV: 16:9, Zoom1, Zoom2, 4:3
Component (480i, 480p): 16:9,
Zoom1, Zoom2, 4:3
DTV (720p): 16:9, Wide Fit, 4:3,
Smart View 2 for LED TV
DTV (1080i, 1080p): 16:9, Wide Fit,
4:3, Screen Fit, Smart View 2 for LED
TV
Component(720p): 16:9, Wide Fit, 4:3
Component(1080i, 1080p): 16:9, Wide
Fit, 4:3, Screen Fit
HDMI (720p, 1080i, 1080p): 16:9,
Wide Fit, 4:3, Screen Fit, Smart View
1 for LED TV , Smart View 2 for LED TV
NDepending on the input source, the
picture size options may vary.
NThe available items may differ
depending on the selected mode.
NHD (High Definition): 16:9 -
1080i/1080p (1920x1080), 720p
(1280x720)
NYou can adjust and store settings
for each external device you have
connected to an input on the TV.
Select the Source, and then adjust
the settings.
Changing the Picture Options
Advanced Settings
Menu Picture Advanced Settings
Using this function, you can configure
advanced picture settings to create
your preferred picture.
NAdvanced Settings is available only
when the Picture Mode is set to
Standard or Movie mode.
NWhen connecting a PC using an
HDMI to DVI cable, you can only
make changes to White Balance and
Gamma.
Dynamic Contrast
Adjusts the screen contrast.
Black Tone
Darker settings make blacks look
darker.
Flesh Tone
Adjusts the amount of red in skin
tones.
RGB Only Mode
Displays the Red, Green and Blue colors
so you can make fine adjustments to
hue and saturation.
Color Space
Adjusts the range and variety of colors
(the color space) available to create
images.
N for LED 6100 ― 6600, 6900, 7003, 7100, 7150
Series and PDP 6500 Series (US) / for LED
6100 ― 6850, 6900, 7003, 7100, 7150 Series
and PDP 6500 Series (Canada, Mexico) To
adjust Color, Red, Green, Blue and
Reset, set the Color Space to Custom.
White Balance
Adjusts the color temperature of the
picture so that white objects look white
(instead of, for example, slightly pink or
slightly yellow) and the overall color of
the picture looks natural.
R-Offset / G-Offset / B-Offset: Adjusts
each color’s (red, green, blue) darkness.
R-Gain / G-Gain / B-Gain: Adjusts each
color’s (red, green, blue) brightness.
Reset: Resets the White Balance to it’s
default settings.
10p White Balance
for LED 6100 ― 7150 Series and PDP 6500 Series
Lets you control the white balance
by adjusting the red, green, and blue
brightness in 10 point intervals.
NAvailable when the Picture Mode is
set to Movie. Available for all video
sources.
NSome external devices may not
support this function.
Interval: Select the interval to adjust.
Red: Adjusts the red level.
Green: Adjusts the green level.
Blue: Adjusts the blue level.
Reset: Resets the 10p White Balance to
its default settings.
Gamma
Adjusts the primary color intensity.
Expert Pattern
for LED 6100 ― 7150 Series and PDP 6500 Series
Use the Expert Pattern function to
calibrate the picture. If the OSD menu
disappears or a menu other than the
Picture menu is opened, the TV saves
the calibration and the Expert Pattern
screen disappears.
Off: Turns the Expert Pattern function
of f.
Pattern1: This test screen demonstrates
the effect of your display settings on
shades of grey and black.
Pattern2: This test screen demonstrates
the effect of your display settings on
colors.
NAfter selecting Pattern1 or Pattern2,
you can adjust any of the advanced
settings for the effect you desire.
NWhile the Expert Pattern is running,
the TV does not output sound.
NOnly enabled in DTV, Component,
and HDMI modes.
xvYCC
for LED 6100 ― 7150 Series and PDP 6500 Series
Setting xvYCC on increases picture
detail and enlarges the color space
when you are watching movies input
from an external device (e.g. BD/DVD
player) connected to the TV’s HDMI or
Component IN jacks.
NAvailable only when you set
the Picture Mode to Movie and
the external input to HDMI or
Component.
NSome external devices may not
support this function.
Motion Lighting
When on, the TV automatically
adjusts the brightness of the screen in
response to the brightness of the room.
In bright light, the screen brightens. In
dim light, the screen dims.
NOnly available in Standard mode.
NThis feature is not supported in 3D
mode.
NWhen you change the Backlight
for LED TV / Cell Light for PDP TV ,
Contrast, or Brightness, the TV sets
Motion Lighting to Off.
Picture Options
Menu Picture Picture Options
Using this function, you can configure
additional picture settings to suit your
preference.
NWhen your TV is connected to a PC
via an HDMI to DVI cable, you can
only make changes to Color Tone.
Color Tone
Cool makes the picture bluer (cooler).
Warm1 and Warm2 make the picture
redder (warmer).
NWarm1 and Warm2 are deactivated
when the Picture Mode is set to
Dynamic.
NYou can adjust and store settings for
each external device connected to an
input on the TV. Select the Source
and then adjust the settings.
Digital Noise Filter
If the broadcast signal received by your
TV is weak, you can activate the Digital
Noise Filter feature to reduce any static
and ghosting that may appear on the
screen.
Auto Visualization: When changing
analog channels, displays signal
strength.
NWhen the signal is weak, try all the
options until the TV displays the best
picture.
NOnly available for analog channels.
NWhen the bar is green, you are
receiving the best possible signal.
MPEG Noise Filter
Reduces MPEG noise to provide
improved picture quality.
HDMI Black Level
Lets you adjust the screen depth by
selecting a black level.
NAvailable only in HDMI mode.
Film Mode
Sets the TV so that it senses and then
processes film signals from all sources
automatically and adjusts the picture
for optimum quality.
for PDP TV The Cinema Smooth function
is only active when the TV inputs an
HDMI 24Hz signal.
NAvailable in TV, AV, Component (480i
/ 1080i) and HDMI (1080i).
Auto Motion Plus
for LED 6100 Series and above
Removes blur and judder from scenes
with larger amounts of rapid movement
to provide a clearer picture.
Blur Reduction: Adjusts the blur
reduction level for signals input from
all video sources.
Judder Reduction: Adjusts the Judder
reduction level for signals input from
a video source through which you are
playing a movie.
Reset: Reset the custom settings to the
factory defaults.
NThe info screen on your TV displays
the resolution and frequency of
the incoming video signal (60 Hz).
This displayed frequency is not the
frequency of the picture the TV is
displaying when you have Auto
Motion Plus on.
NIf noise occurs on the screen, please
set Auto Motion Plus to Off. If Auto
Motion Plus is set to Custom, you
can control Blur Reduction and
Judder Reduction manually and use
Reset to reset both to their default
settings.
NIf Auto Motion Plus is set to Demo,
you can compare the difference
between a picture with Auto Motion
Plus On and Auto Motion Plus Off.
LED Motion Plus for LED TV
Removes blur and judder from scenes
with large amounts of rapid movement
to provide a clearer picture.
Reset Picture
Menu Picture Reset Picture
Resets your current picture mode to its
default settings.
Using the TV with Your PC
Using Your TV as a Computer (PC)
Display
Entering the Video Settings (Based on
Windows 7)
For your TV to work properly as a
computer display, you must enter the
correct video settings after you have
connected the TV to your PC.
NDepending on your version of
Windows and your video card, the
procedure on your PC will probably
differ slightly from the procedure
presented here.
NHowever, the same basic information
will apply in most cases. (If not,
contact your computer manufacturer
or Samsung Dealer.)
1. Click “Control Panel” on the
Windows start menu.
2. Click “Appearance and Themes”
in the “Control Panel” window. A
display dialog box appears.
3. Click “Display”. Another display
dialog box appears.
4. Click the “Settings” tab on the
display dialog box.
On the Settings tab, set the
correct resolution (screen size).
The optimal resolution for this TV
is 1920 x 1080.
If a vertical-frequency option
exists on your display settings
dialog box, select “60” or “60 Hz”.
Otherwise, just click “OK” and exit
the dialog box.
Changing the Preset Sound Mode
Sound Mode
Menu Sound Sound Mode
Sound modes apply preset adjustments
to the sound.
NIf Speaker Select is set to External
Speaker, Sound Mode is disabled.
Standard
Selects the normal sound mode.
Music
Emphasizes music over voices.
Movie
Provides the best sound for movies.
Clear Voice
Emphasizes voices over other sounds.
Amplify
Increase the intensity of high-frequency
sound to provide a better listening
experience for the hearing impaired.
Adjusting Sound Settings
Sound Effect
Menu Sound Sound Effect
NIf Speaker Select is set to External
Speaker, Sound Effect is disabled.
NAvailable only when the Sound Mode
is set to Standard.
SRS TruSurround HD
This function provides a virtual 5.1
channel surround sound experience
through a pair of speakers using HRTF
(Head Related Transfer Function)
technology.
SRS TruDialog
This function allows you to increase
the intensity of voices over background
music or sound effects so that dialog
can be heard more clearly.
Equalizer
The Equalizer displays a series of
sliders. Use the arrow buttons to select
a slider, and then change the slider’s
value. To Reset the Equalizer, select
Reset. A pop-up appears asking if you
want to reset. Select Yes. To exit, select
Close.
Balance L/R: Adjusts the balance
between the left and right speaker.
100Hz / 300Hz / 1kHz / 3kHz / 10kHz
(Bandwidth Adjustment): Adjusts
the loudness of specific bandwidth
frequencies.
Reset: Resets the equalizer to its default
settings.
Broadcast Audio Options
Menu Sound Broadcast Audio Options
Preferred Language
(digital channels only)
Digital-TV broadcasts can
simultaneously transmit many audio
tracks (for example, simultaneous
translations of a program into numerous
foreign languages). You can only select
a language from among the ones being
broadcasted.
Multi-Track Sound
The broadcasts can transmit one or
more audio tracks. You can select an
audio track you want to listen from
among the ones being broadcasted.
NWhile watching TV, you can open the
Tools menu using your remote, and
then select the Multi-Track Sound
function in Tools menu immediately.
NMulti-Track Sound options may
differ depending on the program
being broadcast or the broadcast
signal.
SPDIF Output
Menu Sound SPDIF Output
SPDIF (Sony Philips Digital Interface)
provides digital audio output to speakers
and various digital devices such as A/V
Receivers and Home Theaters which
reduces interference and distortion.
Audio Format
You can select the Digital Audio output
(SPDIF) format. The available Digital
Audio output (SPDIF) format may differ
depending on the input source.
Audio Delay
Lets you correct timing mismatches
between the audio track and the video
when you are watching the TV and
listening to digital audio output from
the TV through an external device such
as an AV receiver. When you select the
Audio Delay function, a slider screen
appears. Adjust the option value using
your remote (0ms ~ 250ms).
Speaker Settings
Menu Sound Speaker Settings
Speaker Select
If you are listening to the sound track
of a broadcast or movie through an
external receiver, you may hear a
sound echo caused by the difference
in decoding speed between the TV’s
speakers and the speakers attached to
your audio receiver. If this occurs, set
the TV to External Speaker.
NWhen Speaker Select is set to
External Speaker, the TV’s speakers
are turned off. You will hear sound
through the external speakers only.
When the Speaker Select is set to TV
Speaker, both the TV’s speakers and
the external speakers are on. You
will hear sound through both.
NWhen the Speaker Select is set to
External Speaker, the volume buttons
and mute functions will not operate
and the sound settings will be
limited.
NIf there is no video signal, both
the TV’s speakers and the external
speakers will be mute.
Auto Volume
Because each station has its own
broadcasting conditions, the volume
may fluctuate each time you change
the channel. This feature automatically
adjusts the volume of a channel by
lowering the sound output when the
modulation signal is high or by raising
the sound output when the modulation
signal is low.
NTo use the volume control of a
connected source device, set Auto
Volume to Off. If Auto Volume is
set to Normal or Night, adjusting
the volume control of a connected
source device may have no effect.
Reset Sound
Menu Sound Reset Sound
Reset all sound settings to the factory
defaults.
Connecting to the Network
The Wired Network Connection
There are three ways to attach your TV
to your LAN using cable:
NFor illustrations of the three kinds of
wired network connections, see your
paper user's manual.
You can attach your TV to your
LAN by connecting the LAN port on
the back of your TV to an external
modem using a LAN cable.
Preference Feature
You can attach your TV to your LAN
by connecting the LAN port on the
back of your TV to a router which
is connected to an external modem.
Use LAN cable for the connection.
You may be able to attach your TV
to your LAN by connecting the LAN
port on the back of your TV directly
to a network wall outlet using a
LAN cable. Note that the wall outlet
is attached to a modem or router
elsewhere in your house.
NIf your network requires a Dynamic
IP address, you should use an ADSL
modem or router that supports the
Dynamic Host Configuration Protocol
(DHCP). Modems and routers that
support DHCP automatically provide
the IP address, subnet mask,
gateway, and DNS values your TV
needs to access the Internet so you
do not have to enter them manually.
Most home networks use a Dynamic
IP address.
NSome networks require a Static IP
address. If your network requires a
Static IP address, you must enter the
IP address, subnet mask, gateway,
and DNS values manually when you
set up the network connection. To
get the IP address, subnet mask,
gateway, and DNS values, contact
your Internet Service Provider (ISP). If
you have a Windows computer, you
can also get these values through
your computer.
NYou can use ADSL modems that
support DHCP if your network
requires a Static IP address. ADSL
modems that support DHCP also let
you use Static IP addresses.
The Wireless Network Connection
NFor an illustration of the wireless
network connection, see your paper
user's manual.
You can connect your TV to your LAN
through a standard wireless router or
modem.
This TV supports the IEEE 802.11a/b/g
and n communication protocols.
Samsung recommends using IEEE
802.11n. When you play video over a
network connection using IEEE 802.11
a/b or g, the video may not play
smoothly.
NTo use a wireless network, your TV
must be connected to a wireless
router or modem. If the wireless
router or modem supports DHCP,
your TV can use a DHCP or static IP
address to connect to the wireless
network.
NSelect a channel on the wireless
router or modem that is not currently
being used. If the channel set for
the router or modem is currently
being used by another device nearby,
this will result in interference and
communication failure.
NYour TV supports only the following
wireless network security protocols:
Authentication Mode : WEP,
WPAPSK, WPA2PSK
Encryption Type : WEP, TKIP, AES
NIf you select the Pure High-
throughput (Greenfield) 802.11n
mode and the Encryption type is set
to WEP or TKIP on your AP (access
point) or wireless router, Samsung
TVs will not support a connection
in compliance with new Wi-Fi
certification specifications.
NIf your wireless router or modem
supports WPS (Wi-Fi Protected
Setup), you can connect to the
network via PBC (Push Button
Configuration) or a PIN (Personal
Identification Number). WPS will
automatically configure the SSID and
WPA key in either mode.
NIf your router, modem, or device is
not certified, it may not connect to
the TV.
NConnection Methods: You can set up
the wireless network connection in
four ways:
Using Auto Setup (with the Auto
Network Search function)
Using Manual Setup
Using WPS(PBC)
Using Plug & Access
Setting up a Wired Network
Network Settings
Menu Network Network Settings
Set up the wired network connection so
you can use various Internet services
such as Smart Hub and Samsung Link
and perform software upgrades.
Automatic Wired Network Setup
You can configure your TV's wired
network connection automatically when
connecting your TV to a network that
supports DHCP.
NIf you have connected a LAN cable,
the wired network set up screen
appears automatically.
To set up your TV’s wired network
connection automatically, follow these
steps:
1. Go to the Network Settings screen.
(Network Network Settings)
2. Select Start. The network test screen
appears and verifies the network
connection.
3. When the connection has been
verified, the "You are connected
to the Internet. If you have any
problems using online services,
please contact your Internet Service
Provider." message appears. Select
OK.
NIf the connection process fails, check
the LAN port connection.
NIf the automatic process cannot find
the network connection values or
if you want to set the connection
manually, go to the next section,
"Manual Network Setup."
Manual Wired Network Setup
You can configure your TV's wired
network connection manually when
connecting your TV to a network that
requires a Static IP address.
NTo get the IP address, subnet mask,
gateway, and DNS values, contact
your Internet Service Provider (ISP).
To set up your TV's wired network
connection manually, follow these
steps:
1. Go to the Network Settings screen.
(Network Network Settings)
2. Select Start. The network connection
screen appears and the verification
process starts.
3. Select Stop. The verification process
stops. Select IP Settings on the
network connection screen. The IP
Settings screen appears.
4. Select the IP Setting, and then set
the IP Setting to Enter manually.
5. Go to the IP Address entry field, and
then select the IP Address using the
remote.
6. Enter the first portion of the IP
Address (for example, 105) into the
first entry field using your remote.
When done, go to the next field.
7. Enter the next portion of the IP
Address. When done, go to the next
field.
8. Repeat the entry process for each
field in the IP Address.
NIf you make a mistake when
entering a number, re-enter the
number to correct it.
9. When done, go to the Subnet Mask
fields.
10. Repeat the same entry process for
Subnet Mask, Gateway, and DNS
Server.
11. When done, select OK. The network
test screen appears and the
verification process starts. When the
connection has been verified, the
"You are connected to the Internet. If
you have any problems using online
services, please contact your Internet
Service Provider." message appears.
Select OK.
Network Status
Menu Network Network Status
You can check the current network and
Internet status.
If the wired network connection failed...
∫∫No network cable found.
Check if your network cable is plugged
in. If it is connected, make sure that
the router is turned on. If it is on, try
turning if off and on again.
IP auto setting failed.
Try the following to set your IP address
automatically or set your IP address
manually by selecting IP Settings.
1.) Ensure that DHCP server is enabled
on the router. 2) Unplug and re-plug-
in the router. 3) Contact your Internet
Service Provider for more information.
Unable to connect to the network.
Try the following: check if your IP
address is set correctly in IP Settings.
Contact your Internet Service Provider
for more information.
Connected to your local network, but
cannot connect to the Internet.
Check the DNS settings in IP Settings
or contact your Internet Service
Provider to access the Internet.
Network setup complete, but cannot
connect to the Internet.
Contact your Internet Service Provider
to access the Internet.
Setting up a Wireless Network
Network Settings
Menu Network Network Settings
Set up the wireless network connection
so you can use various Internet services
such as Smart Hub and Samsung Link
and perform software upgrades.
Automatic Wireless Network Setup
Most wireless networks have an
optional security system that requires
devices that access the network to
transmit an encrypted security code
called an Access or Security Key. The
Security Key is based on a Pass Phrase,
typically a word or a series of letters
and numbers of a specified length
you were asked to enter when you set
up wireless security for your wireless
network.
If you use this method of setting up
the network connection, and have a
Security Key for your wireless network,
you will have to enter the Pass Phrase
during the automatic or manual setup
process.
NDepending on your router or modem,
you may be able to use a WPS PIN
instead.
To set up your TV’s wireless network
connection automatically, follow these
steps:
1. Go to the Network Settings screen.
(Network Network Settings)
2. Select Start. The network function
searches for available wireless
networks. When done, it displays a
list of the available networks.
3. In the list of networks, select a
network you want to connect to, and
then select Next.
NIf the wireless router is set to
Hidden (Invisible), you have to
select Add Network and enter
the correct Network Name (SSID)
and Security Key to establish the
connection.
4. If the Enter security key screen
appears, go to step 5. If you selected
a wireless router that does not have
wireless security, go to step 7.
5. To set up wireless security, enter the
Security Key or a WPS PIN using the
keyboard on the Enter security key
screen.
NTo enter letters, highlight and
select each letter. To enter
numbers, highlight and select
each number or press the number
buttons on your remote.
NTo shift to capital letters (or from
capital letters to lower case),
select the Caps or Shift button.
NTo display symbols and
punctuation, select 1 . To
redisplay letters, select 1 again.
NYou should be able to find the
Pass Phrase on one of the set up
screens you used to set up your
router or modem.
6. When done, select Next if you
entered a Security Key or WPS PIN
if you entered a PIN. The network
connection screen appears and the
verification process starts.
7. When the connection has been
verified, the "You are connected
to the Internet. If you have any
problems using online services,
please contact your Internet Service
Provider." message appears. Select
OK.
NIf the network does not accept the
Security Key or PIN, select Retry
or select IP Settings to enter the
settings manually.
NIf you want to set up the connection
manually, select IP Settings. Then, go
to the next section, “Manual Network
Setup”.
Manual Wireless Network Setup
You can configure your TV's wireless
network connection manually when
connecting your TV to a network that
requires a Static IP address or if the
automatic connection process has
failed.
NTo get the IP address, subnet mask,
gateway, and DNS values, contact
your Internet Service Provider (ISP).
To set up your TV's wireless network
connection manually, follow these
steps:
1. Go to the Network Settings screen.
(Network Network Settings)
2. Select Start. The network function
searches for available wireless
networks. When done, it displays a
list of the available networks.
3. In the list of networks, select a
network you want to connect to, and
then select Next.
NIf the wireless router is set to
Hidden (Invisible), you have to
select Add Network and enter
the correct Network Name (SSID)
and Security Key to establish the
connection.
4. If the Enter security key screen
appears, go to step 5. If you select
a wireless router that does not have
wireless security, go to step 7.
5. To set up wireless security, enter the
Security Key or a WPS PIN using the
keyboard on the Enter security key
screen.
NTo enter letters, highlight and
select each letter. To enter
numbers, highlight and select
each number or press the number
buttons on your remote.
NTo shift to capital letters (or from
capital letters to lower case),
select the Caps or Shift button.
NTo display symbols and
punctuation, select 1 . To
redisplay letters, select 1 again.
NYou should be able to find the
Pass Phrase on one of the set up
screens you used to set up your
router or modem.
6. When done, select Next if you
entered a Security Key or WPS PIN
if you entered a PIN. The network
connection screen appears and the
verification process starts.
7. Select Stop. The verification process
stops. Select IP Settings on the
network connection screen. The IP
Settings screen appears.
8. Select IP Setting, and then set the IP
Setting to Enter manually.
9. Go to the IP Address entry field, and
then select the IP Address using the
remote.
10. Enter the first portion of the IP
Address (for example, 105) into the
first entry field using your remote.
When done, go to the next field.
11. Enter the next portion of the IP
Address. When done, go to the next
field.
12. Repeat the entry process for each
field in the IP Address.
NIf you make a mistake when
entering a number, re-enter the
number to correct it.
13. When done, go to the Subnet Mask
fields.
14. Repeat the same entry process for
Subnet Mask, Gateway, and DNS
Server.
15. When done, select OK. The network
connection screen appears and the
verification process starts. When the
connection has been verified, the
"You are connected to the Internet. If
you have any problems using online
services, please contact your Internet
Service Provider." message appears.
Select OK.
WPS(PBC) Network Setup
If your router has a WPS(PBC)
button, you can configure your TV's
wireless network connection using the
WPS(PBC) button quickly and easily.
To set up your TV's wireless network
connection using WPS(PBC), follow
these steps:
1. Go to Network Settings screen.
(Network Network Settings)
2. Select Start. The network function
searches for available wireless
networks. When done, it displays a
list of the available networks.
3. Select WPS(PBC).
4. Press the WPS(PBC) button on your
router within 2 minutes. Your TV
automatically acquires all the network
setting values it needs and connects
to your network.
5. The network connection screen
appears, and network setup is done.
Plug & Access Network Setup
The Plug & Access function lets you
easily connect your Samsung TV to
your Samsung wireless router by using
a USB memory stick to transfer the
setup information from the router to
the TV. If your non-Samsung wireless
router does not support Plug & Access,
you must connect using one of the
other methods.
NYou can check for equipment that
supports Plug & Access on www.
samsung. com.
To set up your TV's wireless network
connection using Plug & Access, follow
these steps:
1. Turn on the Samsung wireless router
and your TV.
2. Insert a USB memory stick into the
USB port in your Samsung wireless
router. Check the router’s LED’s to
make sure it is on (Blinking on).
3. Take the USB memory stick out of
the router, and then insert it into
a USB port on your Samsung TV.
The memory stick downloads the
connection information.
4. Wait until the connection is
automatically established.
NIf Plug & Access does not connect
your TV to your wireless router,
a popup screen appears on the
screen notifying you of the failure.
If you want to try using Plug &
Access again, disconnect the USB
memory stick, reset the router, and
then try again from Step 1. You
can also choose one of the other
connection setup methods.
5. The network connection screen
appears, and the network setup is
done.
NIf the wireless router’s settings
change or you install a new wireless
router, you must perform the Plug &
Access procedure again, beginning
from Step 1.
Network Status
Menu Network Network Status
You can check the current network and
Internet status.
If the wireless network connection failed...
∫∫Wireless network connection failed.
No wireless router selected. Go to
Network Settings to select your router.
∫∫Unable to connect to wireless router.
Try the following: check if the router
is turned on, and if it is, try turning it
off and on again. Check if you need to
enter a security key to use the router.
IP auto setting failed.
Try the following to set your IP address
automatically or set your IP address
manually by selecting IP Settings.
1.) Ensure that DHCP server is enabled
on the router. 2.) Unplug and re-plug-
in the router. 3.) Contact your Internet
Service Provider for more information.
Unable to connect to the network.
Try the following: check if your IP
address is set correctly in IP Settings.
Contact your Internet Service Provider
for more information.
Connected to your local network, but
cannot connect to the Internet.
Check the DNS settings in IP Settings,
or contact your Internet Service
Provider to access the Internet.
Network setup complete, but cannot
connect to the Internet.
Contact your Internet Service Provider
to access the Internet.
Managing the Network Connected Devices
Wi-Fi Direct
Menu Network Wi-Fi Direct
Set to connect the TV to wireless
mobile devices. Using this function, you
can connect wireless mobile devices to
your TV directly without a router.
NTo use this function, your mobile
device should be supported by the
Wi-Fi Direct.
To connect your mobile device with
your TV using Wi-Fi Direct, follow
these steps:
1. Turn on the Wi-Fi Direct device and
activate its Wi-Fi Direct function.
2. Go to the Wi-Fi Direct screen
(Network Wi-Fi Direct). The TV
starts to search for devices, and then
displays the devices on the Wi-Fi
Direct screen.
3. Select the desired Wi-Fi device.
4. On the Wi-Fi device:
For PBC: Press the WPS(PBC)
button on your Wi-Fi device
within 2 minutes. The Connecting
popup appears, followed by
the Connected pop-up. When it
closes, you should see the device
listed on the Wi-Fi Direct screen
as connected.
For PIN: Input the displayed PIN
on your device. The Connecting
popup appears, followed by
the Connected pop-up. When it
closes, you should see the device
listed on the Wi-Fi Direct screen
as connected.
NIf you want to disconnect the device,
select the connected Wi-Fi device,
and then select Disconnect.
Soft AP
Menu Network Soft AP
Using this function, you can connect
the TV to your mobile devices if your
mobile devices do not support Wi-Fi
Direct.
The Soft AP screen lets you set the
options for connecting Wi-Fi devices.
Soft AP
Turns Soft AP on or off. When Soft AP
is set to On, your mobile devices can
find the TV's network name in their Wi-
Fi connection list.
Security key
Enter a Security key at least 9
characters long using the remote
control. Select Done when finished.
If the security key is not at least
9 characters long, Done is not
available.
To connect a mobile device to the
TV, you must input the security key
into the device.
If the network does not operate
correctly, check the security key
again. An incorrect security key may
cause a malfunction.
AllShare Settings
Menu Network AllShare Settings
Samsung Link lets you play Videos,
Photos, or Music located on your PC or
your AllShare compatible device on the
TV using a network connection. It also
lets you control the TV through these
devices.
The AllShare Settings screen lists your
network connected AllShare devices
and their IP addresses. Through this
screen, you can allow a device to
access the TV, deny access, or delete
the device from the AllShare list.
The AllShare Settings screen only
displays devices if you have established
networked connections to AllShare
devices. Otherwise, it will be empty.
To use the AllShare network function,
you must install the AllShare network
software on your PC. For details on set
up options, refer to "Using the AllShare
Function".
Device Name
Menu Network Device Name
Enter a name for this TV. This name
will be shown on network remote
controls and devices using Samsung
Link.
NA keyboard appears on the screen.
Key in a name for your TV using
your remote control. When finished,
select Done.
NTo enter letters, highlight and select
each letter. To enter numbers,
highlight and select each number or
press the number buttons on your
remote.
NTo shift to capital letters (or from
capital letters to lower case), select
the Caps or Shift button.
NTo display symbols and punctuation,
select 1 . To redisplay letters, select
1 again.
Setting the Time
Time
Menu System Time
NThe time you set will appear when you
press the INFO button.
Clock
Set the clock to use the various timer
features of the TV.
NIf you disconnect the power cord,
you have to set the clock again.
To set the clock, follow these steps:
1. Go to Clock screen (System Time
Clock).
2. Select Auto or Manual.
If you selected Auto:
The TV will automatically download
the correct time from a digital
channel.
Select Time Zone, and then select
your Time Zone.
Select DST (Daylight Savings
Time). Select On if you want to
turn the DST adjustment on and
off manually. Select Off to turn off
the DST adjustment.
NDST and Time Zone function are
only available when the Clock
Mode is set to Auto.
If you selected Manual:
The Clock Set screen appears. Set
the Date and Time manually. You
can set the current date and time
using your remote.
NAvailable only when Clock Mode
is set to Manual.
Sleep Timer
Automatically shuts off the TV after a
preset period of time. (30, 60, 90, 120,
150, or 180 minutes).
NSelect a period of time using your
remote. To cancel the Sleep Timer,
select Off.
On Timer
Set On Timer so that your TV turns on
automatically at a time and on a day
of your choosing. You can set up three
separate On Timer configurations (On
Timer 1, On Timer 2, On Timer 3) and
select the source of the content the TV
plays when it turns on: an air or cable
channel, a USB device, or a set-top box
connected to one of the TV's inputs
(HDMI1, AV1, etc.).
NYou must set the clock before you
can use the On Timer function.
Setup: Select Off, Once, Everyday,
Mon~Fri, Mon~Sat, Sat~Sun or Manual.
If you select Manual, you can select the
days you want to activate the timer.
NThe c mark indicates days you’ve
selected.
Time: Set the time that the TV turns on
automatically.
Volume: Set the desired loudness.
Source: To select the source of the
content that will play when the TV
turns on. You can:
Select TV and have the TV display a
specific air or cable channel.
Select USB and have the TV play
back photo or audio files from a USB
device.
Select a source on your TV (HDMI1,
HDMI2, Component, etc.) that you
have connected a set-top box to, and
have the TV display a channel from
the set-top box.
NThe USB device must be connected
to your TV before you can select
USB.
NIf you select a source other than TV
or USB, you must:
Have a cable or satellite set-top
box attached to that source.
Set the set-top box to the
channel you want to watch when
the TV goes on.
Leave the set-top box turned on.
NWhen you select a source other than
TV or USB, the Antenna and Channel
options will disappear.
Antenna (when the Source is set to
TV): Select Air or Cable.
Channel (when the Source is set to TV):
Select the desired channel.
Music / Photo (when the Source is
set to USB): Select a folder in a USB
device that contains music that you
want played when the TV turns on
automatically or a folder that contains
music and a folder that contains photo
files. If you select both, the TV will
display the photos you selected as it
plays the music you selected.
To select folders on a USB device,
follow these steps:
1. Select Music. The TV displays
types or names of the attached USB
devices. If you have more than one
USB device attached, the TV lists all
the devices.
2. Select the type or name of the device
you want to play. A list of folders on
the selected device appears.
NIf there are no folders on your
device, highlight and select the
Select button to the right of the
device name. The Timer screen
re-appears with the name of the
device in the Music field. Go to
Step 4.
3. Highlight a folder that contains
music, and then highlight and select
the Select button next to it. The
Timer screen re-appears with the
folder name in the Music field.
4. If you want the TV to display photos
as the music you chose plays, select
Photos, and then repeat the same
process.
5. When done, select the Close at the
bottom of the screen.
NYou must select a music file. You
cannot select only a photo file.
NIf there is no music file on the USB
device or you don’t select a folder
containing a music file, the Timer
function does not operate correctly.
NIf there is only one photo file in the
USB, the slide show will not play.
NIf a folder name is too long, the
folder cannot be selected.
NEach USB you use is assigned its
own folder. When using more than
one of the same type of USB, make
sure the folders assigned to each
USB have different names.
NWe recommend that you use a USB
memory stick and a multi card reader
when using the On Timer.
NThe On Timer function may not work
with USB devices that have a built-
in battery, or with MP3 players or
PMPs made by some manufacturers
because the TV can take too long to
recognize these devices.
NIf you set the On Timer to play a file
saved on a USB HDD, it may take
up to 40 seconds or more to start
playing the file after the TV is turned
on.
Off Timer
Set Off Timer so that your TV turns off
automatically at a time and on a day
of your choosing. You can set up three
separate Off Timer configurations. (Off
Timer 1, Off Timer 2, Off Timer 3)
NYou must set the clock before you
can use the Off Timer.
Setup: Select Off, Once, Everyday,
Mon~Fri, Mon~Sat, Sat~Sun or Manual.
If you select Manual, you can choose
the days you want Off Timer to turn off
your TV.
NThe c mark indicates days you’ve
selected.
Time: Set the time that the TV turns off
automatically.
Blocking Programs
Security
Menu System Security
Using this function, you can configure
program related security options.
When you access the Security functions
for the first time, the PIN input screen
appears. Enter the default 4 digit PIN:
0-0-0-0. The PIN screen closes and the
Security Menu appears. Every time you
access the Security functions, the PIN
screen appears and you must enter a
PIN.
NThe default PIN number for a new TV
set is “0-0-0-0”. You can change the
PIN using the Change PIN function.
Program Rating Lock
The Program Rating Lock feature lets
you block programs you've determined
are inappropriate for your children
based on their ratings. To access the
Program Rating Lock feature and make
any changes, you must enter a PIN
(personal identification number). To
watch a blocked program, you must
also enter the same PIN.
NThe Program Rating Lock is not
available in HDMI or Component
mode.
TV Rating: You can block TV programs
based on their ratings. This function
allows you to control what your
children can watch.
TV Rating displays a grid with locks.
The following categories are on the left
side:
TV-Y: Young children
TV-Y7: Children 7 and over
TV-G: General audience
TV-PG: Parental guidance
TV-14: Viewers 14 and over
TV-MA: Mature audience
The following categories are on top:
ALL: Lock all TV ratings.
FV: Fantasy violence
V: Violence
S: Sexual situation
L: Adult Language
D: Sexually Suggestive Dialog
To block certain content, select a lock.
(That is, “click it”.). For example, click
the lock at the intersection of V and
TV-MA, and you block all programs
that are rated violent and for mature
adults. The rating categories are also
grouped so that clicking one category
blocks all the categories a parent would
block along with it. For example, if
you click TV-G under ALL, then all the
categories associated with TV-G will be
blocked (TV-G, TV-PG, TV-14 and TV-
MA). The sub-ratings (D, L, S, V) work
similarly. So, if you block the L sub-
rating in TV-PG, then the L sub-ratings
in TV-14 and TV-MA will automatically
be blocked.
NTo unblock a category, click the lock
icon. To unblock all the categories in
a row, click the lock under ALL.
NTo watch a blocked program, you
must enter the PIN code when
requested.
Movie Rating (MPAA): You can block
movies based on their MPAA rating.
The Motion Picture Association of
America (MPAA) has implemented a
rating system that provides parents or
guardians with advanced information
on which films are appropriate for
children.
Movie Rating (MPAA) displays a
column with locks and the following
ratings categories:
G: General audience (no restrictions).
PG: Parental guidance suggested.
PG-13: Parents strongly cautioned.
R: Restricted. Children under 17
should be accompanied by an adult.
NC-17: No children under age 17.
X: Adults only.
NR: Not rated.
To block certain content, select an
entry field to lock (That is, “click it”.).
For example, click the X lock and you
block all X-rated movies.
The rating categories are also grouped
so that clicking one category blocks
all the categories a parent would block
along with it. For example, if you block
the PG-13 category, then R, NC-17 and
X will automatically be blocked also.
NTo unblock a category, click the lock
icon.
Canadian English Rating: You can
block TV programs based on their
Anglophone Canadian ratings.
Canadian English Rating displays a
column with locks and the following
ratings categories:
C: Programming intended for children
under age 8.
C8+: Programming generally
considered acceptable for children
8 years and over to watch on their
own.
G: General programming, suitable for
all audiences.
PG: Parental Guidance.
14+: Programming contains themes
or content which may not be suitable
for viewers under the age of 14.
18+: Adult programming.
To block certain content, select an
entry field to lock (That is, “click it”.).
For example, click the 18+ lock and you
block all TV programs rated 18+.
The rating categories are also grouped
so that clicking one category blocks
all the categories a parent would block
along with it. For example, if you block
the G category, then PG, 14+ and 18+
will automatically be blocked.
NTo unblock a category, click the lock
icon.
Canadian French Rating: You can block
TV programs based on their French
Canadian ratings.
Canadian French Rating displays a
column with locks and the following
ratings categories:
G: General
8 ans+: Programming generally
considered acceptable for children
8 years and over to watch on their
own.
13 ans+: Programming may not be
suitable for children under the age of
13.
16 ans+: Programming is not suitable
for children under the age of 16.
18 ans+: Programming restricted to
adults.
To block certain content, select an
entry field to lock (That is, “click it”.).
For example, click the 18 ans+ lock
and you block all TV programs rated 18
ans+.
The rating categories are also grouped
so that clicking one category blocks
all the categories a parent would block
along with it. For example, if you block
the 8 ans+ category, then 13 ans+, 16
ans+ and 18 ans+ will automatically be
blocked also.
NTo unblock a category, click the lock
icon.
Downloadable U.S. Rating: Parental
restriction information you can use
while watching DTV channels.
NIf information is not downloaded
from the broadcasting station, the
Downloadable U.S. Rating menu is
deactivated.
NParental restriction information is
automatically downloaded while you
watch DTV channels. It may take
several seconds.
NThe Downloadable U.S. Rating menu
is available for use after information
is downloaded from the broadcasting
station. However, depending on the
information from the broadcasting
station, it may not be available for
use.
NParental restriction levels differ
depending on the broadcasting
station. The default menu name and
the Downloadable U.S. Rating change
depending on the downloaded
information.
NEven if you set the on-screen
display to another language, the
Downloadable U.S. Rating menu will
appear in English only.
NBlocking one rating level will
automatically block other categories
that deal with more sensitive
material.
NThe rating titles (For example:
Humor Level..etc) and TV ratings
(For example: DH, MH, H..etc) may
differ depending on the broadcasting
station.
Change PIN
The Change PIN screen will appear.
Choose any 4 digits for your PIN
and enter them in the Enter New PIN
fields. Re-enter the same 4 digits in
the Confirm New PIN fields. When
the Confirm screen disappears, select
Close. The TV has memorized your new
PIN.
How to watch a restricted program or
movie
If the TV is tuned to a restricted
program or movie, the Program Rating
Lock will block it.
The screen will go blank and a pop-
up message appears. Enter the PIN to
unblock the program or movie using
your remote.
NIf you forget the PIN code, press
the remote control buttons in the
following sequence in Standby
mode: MUTEM 8 2 4 P
(power on). This resets the PIN to “0-
0-0-0”.
Economical Solutions
Eco Solution
Menu System Eco Solution
Energy Saving
Lets you adjusts the brightness of
the TV in order to reduce power
consumption. If you select Picture Off,
the screen is turned off, but the sound
remains on. Press any button except
the volume button to turn on the
screen.
Eco Sensor
To enhance power savings, the picture
settings will automatically adapt to the
light in the room.
NThis function is not available for LED
6200 series.
NIf you adjust Backlight for LED TV /
Cell Light for PDP TV in the Picture
menu, the Eco Sensor is set to Off
automatically.
Min. Backlight for LED TV / Min Cell
Light for PDP TV : When the Eco Sensor
is set to On, you can manually adjust
the minimum screen brightness.
NIf the Eco Sensor is set to On, the
display brightness may change
(become slightly darker or brighter)
depending on the light intensity
in your room. You can control the
screen’s minimum brightness with
the Min. Backlight / Min Cell Light
function.
No Signal Power Off
To avoid unnecessary energy
consumption, you can set how long
you want the TV to remain on if it’s not
receiving a signal.
Auto Power Off
The TV will automatically turn off when
no user operation is detected for 4
hours.
Picture In Picture (PIP)
PIP
Menu System PIP
You can watch a program whose signal
has passed through the TV’s tuner and
watch video from one external video
source simultaneously.
For example, if you have a cable box
connected to the Cable In jack, you can
use PIP to watch programs from the
cable box and a movie from a Blu-ray
player attached to the HDMI In jack.
NWhile Smart Hub or Program Rating
Lock is on, you cannot use PIP.
PIP
Activate or deactivate the PIP function.
Air/Cable
Select either Air or Cable as the input
source for the sub-picture screen.
Channel
Select the channel for the sub-picture
screen.
Size
Select a size for the sub-picture screen.
Position
Select a position for the sub-picture
screen.
Sound Select
You can choose to listen to the sound
from the main picture or the sub
picture.
NIf you turn the TV off while watching
in the PIP mode, the PIP function is
reset to Off. When you turn your TV
on, you must turn PIP on again to
watch in the PIP mode.
NYou may notice that the picture in
the PIP screen becomes slightly
unnatural when you use the main
screen to view a game or karaoke.
NPIP does not work when the 3D
function is active.
NPIP Settings: The picture from the
external video source will be in the
main screen and the picture from
the TV’s tuner will be in the PIP sub-
picture screen.
Main picture: Component, HDMI
Sub picture: TV
Using the TV with a Keyboard and a Mouse
Device Manager
Menu System Device Manager
Using this function, you can set up
a keyboard or mouse to use with the
TV. You can view your device lists and
adjust keyboard or mouse settings in
this menu.
NDepending on the model of the USB
HID keyboard and mouse may not be
compatible with your TV.
NYou can connect a keyboard and
mouse at the same time.
Keyboard Settings
Lets you use a USB or Bluetooth
keyboard with your TV. If you want to
use a USB keyboard, connect it to the
USB port.
for LED 6500 Series and above, PDP TV If
you want to use a Bluetooth keyboard,
connect it using the Bluetooth function.
NYou can use the keyboard only
when the QWERTY keyboard screen
appears in the Web Browser.
Select Keyboard
Select which keyboard to use from your
keyboard list. You can only use one
keyboard at a time, even if several are
connected.
Add Bluetooth Keyboard
for LED 6500 Series and above, PDP TV You
can add a Bluetooth keyboard.
Keyboard Options
Sets the default options for the
keyboard language and type.
Keyboard Language: Set a language
for your keyboard.
Keyboard Type: Set the type of
keyboard you're using to enter text.
Switch Input Language: Select a key
sequence that switches the input
language.
Mouse Settings
Lets you use a USB or Bluetooth mouse
with your TV. If you want to use a USB
mouse, connect it to the USB port.
for LED 6500 Series and above, PDP TV If
you want to use a Bluetooth mouse,
connect it using the Bluetooth function.
You can use a mouse in the TV's menu
in the same way you use a mouse on
your PC.
Select Mouse
Select which mouse to use from your
mouse list. You can only use one
mouse at a time, even if several are
connected.
Add Bluetooth Mouse
for LED 6500 Series and above, PDP TV You
can add a Bluetooth mouse.
Mouse Options
Sets the default options for the mouse
buttons.
Primary Button: Select the main
button you want to use to click and
select on screen.
Pointer Size: Set the size of the on-
screen mouse pointer.
Pointer Speed: Select the speed of
the mouse pointer.
Using the TV's menu with a mouse
1. Connect a USB or Bluetooth mouse
on your TV.
2. Click the primary button you
selected. The Go To pop-up appears.
3. Select Smart Hub or Menu in Go To.
4. Use the mouse the same way
you would use a mouse on your
computer. For example, to open
Channel on the Smart Hub screen,
click the Channel icon.
NTo exit an entry field that does not
close, click R Return.
NTo exit a menu or the Smart Hub
screen, click R Return.
NTo hide the mouse pointer, move it
slightly off the bottom of the screen.
Connecting to the TV with a Samsung
Audio Device
for LED 6500 ― 7150 Series and PDP TV
SoundShare Settings
Menu System Device Manager
SoundShare Settings
Lets you use a Samsung Audio Device
with your TV. If you want to use a
Samsung Audio Device, connect it
using the Bluetooth function.
Using your TV with Samsung Audio
Device, you can experience TV sound
more loudly and clearly.
Add New Device
Turns the SoundShare function on or
off. When the Add New Device is set to
Off, the connection signals from new
devices are ignored.
Samsung Audio Device List
Use / Don't Use: Allows/Blocks the
devices.
Delete from the list: Deletes the devices
from the list.
Supported Samsung Audio Device models
DA-E650 / E651 / E660 / E661 / E670
/ E680 / E750 / E751 / E760 / E761
NFor more detailed information about the
Pairing instructions with your TV, visit
Samsung homepage (www.samsung.
com).
NDepending on the region, the Samsung
Audio Device may not be sold.
Other Features
Menu Language
Menu System Menu Language
Set the menu language.
1. Select Menu Language.
2. Choose a language you want to use.
Caption
(On-Screen Text Dialogue)
Menu System Caption
Caption
You can switch the caption function on
or off. If captions are not available, they
will not be displayed on the screen.
NThe Caption feature does not work
with devices connected to the TV
through the Component or HDMI
jacks.
Caption Mode
You can select the desired caption
mode.
NThe availability of captions depends
on the program being broadcast.
Default / CC1 CC4 / Text1 Text4:
(analog channels only) The analog
caption function operates in either
analog TV channel mode or when a
signal is supplied from an external
device to the TV. (Depending on the
broadcasting signal, the analog caption
function may or may not work with
digital channels.)
Default / Service1 Service6 / CC1
CC4 / Text1 Text4: (Digital channels
only) The digital caption function
works with digital channels.
NService1 Service6 may not be
available in digital caption mode
depending on the broadcast.
Digital Caption Options
(Digital channels only)
Lets you adjust each option.
Size: Options include Default, Small,
Standard, and Large. The default is
Standard.
Font Style: Options include Default and
Style0 to Style7. The default is Style0.
Font Color: You can change the color
of the letters.
Options include Default, White, Black,
Red, Green, Blue, Yellow, Magenta and
Cyan. The default is White.
Background Color: You can change
the background color of the captions.
Options include Default, White, Black,
Red, Green, Blue, Yellow, Magenta and
Cyan. The default is Black.
Font Opacity: This adjusts the opacity
of text. Options include Default,
Transparent, Translucent, Solid and
Flashing.
Background Opacity: This adjusts the
opacity of the caption background.
Options include Default, Transparent,
Translucent, Solid and Flashing.
Return to Default: This option sets the
Size, Font Style, Font Color, Background
Color, Font Opacity and Background
Opacity settings to their defaults.
NDigital Caption Options are available
only when you can select Service1
Service6 in Caption Mode.
NThe availability of captions depends
on the program being broadcast.
NThe Default setting follows the
standards set by the broadcaster.
NYou cannot set both the Font Color
and the Background Color to the
same color.
NYou cannot set both the Font Opacity
and the Background Opacity to the
same setting.
Screen Burn Protection for PDP TV
To reduce the possibility of screen
burn, this unit is equipped with Pixel
Shift screen burn prevention technology.
Pixel Shift moves the picture slightly on
the screen.
The Pixel Shift Time setting allows
you to program the time between
movements of the picture in minutes.
Your TV has the following screen burn
protection functions:
Pixel Shift
Auto Protection Time
Scrolling
Side Gray
Pixel Shift
Using this function, you can set the
TV to move pixels minutely on the
PDP screen in a horizontal or vertical
direction to minimize after images on
the screen.
Available Pixel Shift settings and
optimum settings:
Horizontal
Available Settings: 0 – 4 (pixels)
Optimum settings for TV/AV/
Component/HDMI: 4
Vertical
Available Settings: 0 – 4 (pixels)
Optimum settings for TV/AV/
Component/HDMI: 4
Time (minutes)
Available Settings: 1 – 4 min
Optimum settings for TV/AV/
Component/HDMI: 4 min
NThe Pixel Shift value may differ
depending on the monitor size (in
inches) and mode.
NThis function is not available in the
Screen Fit mode.
Auto Protection Time
If the screen displays a still image for
a certain period of time you define, the
TV activates the screen saver to prevent
the formation of burnt in ghost images
on the screen.
Scrolling
This function removes after-images on
the screen by illuminating all the pixels
on the screen according to a pattern.
Use this function when there are after
images or symbols on the screen,
especially after you displayed a still
image on the screen for a long time.
NThe after-image removal function
has to be executed for a long time
(approximately 1 hour) to effectively
remove after-images on the screen.
If the after-image is not removed
after you apply the function, repeat
the function.
NPress any button to cancel this
feature.
Side Gray
Lets you select the color of the
sidebars your TV displays when you set
the screen size to 4:3.
Auto Protection Time for LED TV
If the screen displays a still image for
a certain period of time you define, the
TV activates the screen saver to prevent
the formation of burnt in ghost images
on the screen.
General
Menu System General
Game Mode
When you have connected a game
console such as a PlayStation™ or
Xbox™ to the TV, you can enjoy a
more realistic gaming experience by
turning on the Game Mode function.
Precautions and limitations for Game
Mode
Before you disconnect the game
console and connect another external
device, set Game Mode to Off.
If you display the TV menu in Game
Mode, the screen shakes slightly.
NGame Mode is not available when
the input source is set to TV.
NSet Game Mode to On only after
connecting a game console. If you
turn Game Mode on before you have
attached the game console, you
may notice slightly reduced picture
quality.
NIf Game Mode is set to On, Picture
Mode is set to Standard and Sound
Mode is set to Movie automatically.
BD Wise
Provides the optimal picture quality
for Samsung DVD, Blu-ray, and Home
Theater products which support BD
Wise. When BD Wise is set to On, the
picture mode is automatically changed
to the optimal resolution.
NAvailable when you connect
Samsung products that support BD
Wise through an HDMI cable to the
TV.
Menu Transparency
Lets you adjust the transparency of the
menu box.
Sound Feedback
Your TV provides sound feedback when
you use it (clicks, etc.). Sound Feedback
is enabled by default. You can turn off
Sound Feedback or adjust its volume.
Panel Lock
Lock or unlock all the keys on the front
panel at once. When Panel Lock is on,
none of the keys on the front panel
operate.
Boot Logo
Displays the Samsung logo when the
TV is turned on.
Light Effect for LED 7003, 7100 and 7150
Series
You can turn the LED on the TV’s front
panel on or off. Turn it off to save
power or if the LED is too bright for
you.
NSet the Light Effect to Off to reduce
the power consumption.
NThe color of light may vary
depending on the model.
Anynet+ (HDMI-CEC)
Menu System Anynet+ (HDMI-CEC)
Allows you to control all connected
Samsung devices that support Anynet+
with your Samsung TV’s remote. For
details on set up options, refer to the
“Anynet+ (HDMI-CEC)” instructions.
DivX® Video On Demand
Menu System DivX® Video On
Demand
Shows the registration code authorized
for the TV. If you connect to the DivX
web site and register with 10-digit
registration code, you can download
the VOD activation file. Once you play
it using Samsung Link, the registration
is completed.
NFor more information on DivX(R)
VOD, visit http://vod.divx.com.
Support Menu
e-Manual
Menu Support e-Manual
The e-Manual is built into your TV.
Open the e-Manual to learn how to use
your TV’s many features.
NFor the detailed information about
the e-Manual Screen, refer to “How
to view the e-Manual” in the User's
Manual.
Self Diagnosis
Menu Support Self Diagnosis
Picture Test
Use to check for picture problems.
Picture Test displays a high definition
picture that you can examine for flaws
or faults.
Yes: Select Yes if the test picture
does not appear or there is noise or
distortion in the test picture. There
may be a problem with the TV. Contact
Samsung’s Call Center for assistance.
No: Select No if the test picture
displays properly. There may be a
problem with your external equipment.
Please check your connections. If the
problem persists, refer to the external
device’s user manual.
Sound Test
Use the built-in melody to check for
sound problems.
NIf you hear no sound from the TV
speakers, before performing the
sound test, make sure Speaker Select
is set to TV Speaker in the Sound
menu, and then try the speakers
again.
NYou will hear the melody during the
test even if you have set Speaker
Select to External Speaker or have
muted the sound.
Yes: Select Yes if you can hear sound
from only one speaker or from neither
speaker during the sound test. There
may be a problem with the TV. Contact
Samsung’s Call Center for assistance.
No: Select No if you can hear sound
from the speakers. There may be a
problem with your external equipment.
Please check your connections. If the
problem persists, refer to the external
device’s user manual.
Signal Information
(digital channels only)
The reception quality of over-the-
air HD channels is either perfect or
the channels are unavailable. Signal
Information displays HD channel
signal strength so you can adjust your
antenna to increase signal strength and
receive HD channels.
Reset
Reset all settings to factory defaults
except for your network settings.
To reset your TV to its default settings,
follow these steps:
1. Go to the Reset menu. (Support
Self Diagnosis Reset)
2. The PIN input screen appears. Enter
the four digit security PIN using your
remote.
NIf you have not changed the PIN,
enter the default PIN, 0-0-0-0.
You can change the PIN using the
Change PIN option.(System
SecurityChange PIN)
3. When done, the PIN screen disappear.
The message "All the settings will
return to factory defaults." appears.
4. Select Yes. All settings are reset.
The TV will turn off and on again
automatically. The Setup screen
appears. For more information about
Setup, see the paper user manual.
Troubleshooting
If your TV seems to be having a
problem, access the troubleshooting
guide for a solution.
Software Update
Menu Support Software Update
The Software Update menu lets you
upgrade your TV’s software to the
latest version.
Current Version: This is the software
version already installed in the TV.
Upgrading to the Latest Version
You can upgrade in four ways:
By USB
Online
Alternative Software
Standby Mode Upgrade
The four methods are explained in the
following pages.
NBe careful not to turn off the power
until the upgrade is complete. The
TV will turn off and on automatically
after completing the software
upgrade. When you upgrade
software, all video and audio
settings you have made will return to
their default settings. We advise you
to write down your settings so that
you can easily reset them after the
upgrade.
By USB
To upgrade using By USB, follow these
steps:
1. Visit www.samsung.com.
2. Click Support at the top of the page.
3. On the Support page, enter your
model number in the Find Your
Product field, and then press Enter or
click Find Product.
4. Under Downloads on the left side,
click Get downloads. The Download
Center screen appears.
5. Click Firmware on the left side of the
page.
6. On the Firmware tab, click the file
icon on the right, and then click Save
File on the pop-up that appears.
7. Extracts the exe archive to your
computer. You should have a single
folder with the same name as the
exe file.
8. Copy the folder to a USB flash drive.
9. Turn on the TV, and then insert the
USB flash drive into the USB port of
the TV.
10. In the TV’s menu, go to Support
Software Update.
11. Select By USB.
NPlease be careful not to remove
the USB drive until the upgrade is
complete.
Online
The Online function lets you download
the upgrade software directly from the
Internet into your TV and then upgrade
the software in one operation. To use
Online, you must have configured your
TV to connect to your network and the
TV must be connected to the Internet.
See the "Setting up the Wired or
Wireless Network" instructions.
To upgrade using Online, follow these
steps:
1. Select Online. The Connecting to
Server message appears.
2. If there is a download available,
the Download pop-up appears with
a progress bar and the download
starts.
3. When the download is complete,
the Upgrade Query screen appears
with three choices: Upgrade Now,
Upgrade Later, or Don't Upgrade.
If you select Upgrade Now, the TV
upgrades the software, turns off,
and then turns on automatically.
If you do not make a selection
in one minute or select Upgrade
Later, the TV stores the new
upgrade software. You can
upgrade the software later using
the Alternative Software function.
If you select Don't Upgrade, the
TV cancels the upgrade.
Alternative Software
The Alternative Software option
lets you upgrade using a file the TV
downloaded earlier, but you decided
not to install immediately, or a file
downloaded by the TV in Standby
Mode (See Standby Mode Upgrade in
the next section).
To upgrade using Alternative Software,
follow these steps:
1. If upgrade software has been
downloaded, you will see the
software version number to the right
of Alternative Software.
2. Select Alternative Software.
3. The TV displays a message asking if
you want to upgrade. Select Yes. The
TV begins the upgrade.
4. When the upgrade is complete, the
TV turns off automatically, and then
turns on.
Standby Mode Upgrade
You can set the Standby Mode Upgrade
function so that the TV downloads new
upgrade software when it is in Standby
mode.
In Standby mode, the TV is off, but
its Internet connection is active. This
allows the TV to download upgrade
software automatically, when you are
not using it. Because the TV is turned
on internally, the screen may glow
slightly. This phenomenon may continue
for more than 1 hour until the software
download is complete.
To set Standby Mode Upgrade, follow
these steps:
1. Select Standby Mode Upgrade.
2. Select On or Off.
Off: If you select Off, the TV will
notify you with a pop up message
when new upgrade software is
available.
On: If you select On, the TV will
automatically download new
upgrade software when it is in
Standby mode with the power
off. If it downloads new upgrade
software, the TV will ask you if
you want to install it when you
turn the TV on.
NTo use the Standby Mode Upgrade
function, your TV must be connected
to the Internet.
Contact Samsung
Menu Support Contact Samsung
View this information when your TV
does not work properly or when you
want to upgrade the software. You
can find information regarding our call
centers and how to download products
and software.
Remote Management
Menu Support Remote Management
Remote Management lets our Call
Center access and control your
Samsung product remotely to
troubleshoot a problem. Use Remote
Management only when you have a
problem, and contact our Call Center
first, before you activate Remote
Management.
You can find the current number of
our Call Center on the Support page
at www.samsung.com under Contact
support.
Smart Hub
Menu Support Smart Hub
Smart Hub lets you connect to the
Internet and enjoy a variety of Internet
and multimedia contents. For more
information on how to use Smart Hub,
see “Smart Hub” in the e-Manual.
Using the 3D function
for LED 6500 ― 7150 Series and PDP TV
3D
Menu Picture 3D
This exciting new feature enables you
to view 3D content. To fully enjoy this
feature, you need a pair of Samsung 3D
Active Glasses to view 3D video.
NFULL HD 3D support is determined
by the quality of the content.
IMPORTANT HEALTH AND SAFETY
Advanced Features
INFORMATION FOR 3D PICTURES.
Read and understand the following safety
information before using the TV’s 3D function.
[Warning
Some viewers may experience
discomfort while viewing 3D TV such
as dizziness, nausea, and headaches.
If you experience any such symptom,
stop viewing 3D TV, remove the 3D
Active Glasses, and rest.
Watching 3D images for an extended
period of time may cause eye strain.
If you feel eye strain, stop viewing
3D TV, remove your 3D Active
Glasses, and rest.
A responsible adult should frequently
check on children who are using the
3D function. If there are any reports
of tired eyes, headaches, dizziness, or
nausea, have the child stop viewing
3D TV and rest.
Do not use the 3D Active Glasses
for other purposes (such as general
eyeglasses, sunglasses, protective
goggles, etc.)
Do not use the 3D function or 3D
Active Glasses while walking or
moving around. If you use the 3D
function or 3D Active Glasses while
walking or moving around you
can injure yourself by running into
objects, tripping, or falling.
3D Mode
Select the 3D input format.
NIf you want to experience the 3D
effect fully, put the 3D Active Glasses
on first, and then select the 3D Mode
from the list below that provides the
best 3D viewing experience.
Of
f
Of
f
: Turns the 3D function off.
: Changes a 2D image to 3D.
: Displays two images next to each
other.
: Displays one image above another.
NThe 3D Mode may differ depending
on the input signal.
NSome file formats may not support
.
3D Perspective
Adjusts the overall 3D perspective of
the on-screen image.
Depth
Adjusts the overall depth.
L/R Change
Swaps the left and right pictures.
3D → 2D
Displays the image for the left eye only.
NThis function is deactivated when the
3D Mode set to or
Of
f
Of
f
.
3D Optimize for LED TV
Automatically adjusts the picture
overall to provide an optimal 3D effect.
3D - Supported resolutions (16:9 only)
HDMI
3D Format Resolution Frequency (Hz)
/
1280 x 720p 59.94 / 60 Hz
1920 x 1080i 59.94 / 60 Hz
1920 x 1080p 23.98 / 24 / 29.97 /
30 / 59.94 / 60 Hz
Frame Packing
1280 x 720p 59.94 / 60 Hz
1920 x 1080i 59.94 / 60 Hz
1920 x 1080p 23.98 / 24 / 29.97 / 30 Hz
Component
Resolution Frequency (Hz)
1280 x 720p 59.94 / 60 Hz
1920 x 1080i 59.94 / 60 Hz
1920 x 1080p 23.98 / 24 / 29.97 / 30 / 59.94 / 60 Hz
DTV
Resolution Frequency (Hz)
1280 x 720p 59.94 / 60 Hz
1920 x 1080i 59.94 / 60 Hz
Videos / Photos (In Samsung Link)
NRefer to "Supported Subtitle and
Samsung Link file formats" in the
Other Information section.
How to watch the 3D images
Some 3D modes may not be available
depending on the format of the image
source.
To watch in 3D, you must wear 3D
Active Glasses and turn the glasses on
by pressing the power button.
1. Go to the 3D screen. (Picture 3D)
2. Select the 3D Mode. The 3D Mode
screen appears.
3. Select the 3D Mode option for the
image you want to view. The screen
goes blank for a moment, and then
reappears in the 3D mode you
selected.
NYou can also access the 3D mode
by pressing the X button on your
remote.
Read These Notes Before Using the 3D
Function...
The 3D Mode is set to Off
automatically when you access
Smart Hub function.
The 3D Mode is set to its memorized
configuration value automatically
when you change the input source.
Some Picture functions are disabled
in 3D mode.
PIP is not supported in 3D mode.
3D Active Glasses from Samsung’s
previous IR type 3D products and 3D
glass from other manufacturers are
not supported.
When the TV is initially powered on,
it may take some time until the 3D
display is optimized.
The 3D Active Glasses may not work
properly if there is any other 3D
product or electronic devices turned
on near the glasses or TV. If there
is a problem, keep other electronic
devices as far away as possible from
the 3D Active Glasses.
Be sure to stay within the viewing
angle and optimum TV viewing
distance when watching 3D pictures.
Otherwise, you may not be able to
see 3D effects properly.
The ideal 3D viewing distance is
three times or more the height of the
screen. For example, if your screen
is two feet high, you should sit at
least six feet from the screen. We
recommend sitting so that your eyes
are level with the screen.
Smart Hub
Menu Support Smart Hub
Using Smart Hub, you can stream
movies, videos, and music from the
Internet, access various for pay or free-
of-charge applications and view them
on your TV.
Application content includes news,
sports, weather forecasts, stock market
quotes, maps, photos, and games.
NYou can also start this function by
pressing the ² button on the remote
control.
Notice
Samsung Electronics takes no legal
responsibility for any interruption of
the Smart Hub service caused by the
service provider for any reason.
Application services may be provided
in English only and the contents
available may vary, depending on
your area.
For more information about a Smart
Hub service, visit the web site of the
applicable service provider.
The Smart Hub service downloads
and processes data via the Internet
so that you can enjoy the Internet
contents on your TV screen. If the
Internet connection is unstable,
the service may be delayed or
interrupted. Furthermore, the TV may
turn off automatically in response
to conditions on the Internet. If this
occurs, check the Internet connection
and try again.
The services provided are subject
to change by the Smart Hub service
provider without notice.
The Smart Hub service contents
may differ depending on the TV’s
firmware version.
For-pay DivX contents with copy
protection can only be played
through a composite, component, or
HDMI cable.
To start Smart Hub for the first time, follow
these steps:
1. Press the ² button.
2. The Smart Hub screen appears. In
a few cases, the Country screen
appears immediately after.
3. If the Country screen has appeared,
select your country using your
remote.
NSome applications are available
only in certain countries.
4. The General Disclaimer screen
appears. Select Agree.
NScreens can take a few seconds
to appear.
5. The Samsung Service Privacy Policy
screen appears. Select Agree.
6. The Update Pop-up appears. Select
OK.
7. The Service Update screen appears
and installs a number of services and
applications. When done, it closes.
The Smart Hub screen displays
the downloaded applications and
services. This may take some time.
NSmart Hub may close momentarily
during the installation process.
NA number of screens may appear
after installation. You can close
them or let them close on their
own.
8. To start an application, select an
application using your remote.
Using the Keypads and Keyboards
A number of Smart Hub applications
display a numeric keypad or a QWERTY
keyboard so you can enter account
names, passwords, and other data.
In most applications, you can toggle
between the numeric keypad and the
QWERTY keyboard by selecting the b
button.
Using the Numeric Keypad
When the keypad is displayed, you
can use your remote to enter letters
in lower or upper case, numbers,
punctuation, and symbols.
There are two ways to enter characters,
in the ABC mode and in the XT9 mode.
Method 1: Using the keypad in ABC
mode.
Example: Inputting “105Chang”.
1. Select the - key three times using
your remote to change the input
mode from lower case to numbers.
3. Select 1, 0, and 5 in numerical order
on your remote.
4. Select the - key three times using
your remote to change the input
mode from numbers to upper case.
5. Select 2 three times using your
remote to input C.
6. Select the - key three times using
your remote to change the input
mode from upper case to lower case.
7. Input the rest of “Chang” using your
remote in the same way. When done,
select OK.
Method 2: Using the Keypad in XT9
mode.
To change to XT9 mode, follow these
steps:
A. With the Numerical keypad displayed,
open the Tools menu using your
remote.
B. On the Tools menu, select XT9 Text
Input.
C. Select On, and then select OK.
Example: Inputting“105Chang”.
1. Select the key three times using
your remote to change the input
mode from lower case to numbers.
3. Select 1, 0, and 5 in numerical order
on your remote.
4. Select the key three times using
your remote to change the input
mode from numbers to capitalized
case.
5. Select in sequence: 2, 4, 2, 6, 4. A
thin ribbon appears at the top of
the screen displaying a list of words
you can enter. Select “Chang” from
the list by selecting } using your
remote.
NIf “Chang” is not displayed in the
list, select + to create your own
dictionary. Add your own word to
your dictionary.
Using the QWERTY Keypad
If you have a USB or Bluetooth for LED
6500 Series and above, PDP TV keyboard
attached to the TV, and the screen is
displaying the QWERTY keyboard, you
can use the attached keyboard just like
a regular keyboard. Type a character
and the character appears on the
screen.
If you don't have a USB or Bluetooth
keyboard attached and the QWERTY
keyboard is displayed, use your remote
to highlight and then select letters,
numbers, and symbols on the keyboard
one at a time.
NSelect the Caps or Shift button to
display Capital letters. Select again
to re-display lower case.
NSelect the 1 button to display
symbols and icons. Select again to
re-display letters.
NIf XT9 Text Input is On, words will
appear in a ribbon at the top of the
page. Select the } button to select a
word in the ribbon.
Using the colored and function buttons
with the QWERTY Keypad
a Delete All
Deletes all inputted characters.
b Numeric / QWERTY
Toggles the keypad mode between
Numeric keypad mode and QWERTY
mode.
NWhen the keypad is set to
QWERTY mode, you can input
characters using a USB or
Bluetooth keyboard connected to
the TV.
T Settings
Displays the options menu.
Input Language: Select an input
language.
XT9 Text Input: Turns the XT9 word
function on or off. Available in both
Numeric Keypad and QWERTY mode
when you use the remote or a mouse
to select and enter characters.
E Enter
Enter the selected character.
R Return
Return to the previous menu.
π Prev Page
Display the previous set of symbols/
icons.
NAvailable only when the keypad
screen is in symbol/icon mode( ).
µ Next Page
Display the next set of symbols/
icons.
NAvailable only when the keypad
screen is in symbol/icon mode( ).
Creating an Account
To establish your own, exclusive
configuration of Smart Hub, create your
own Samsung account.
NYou must use an e-mail address as
an ID.
NYou can register up to 10 User
Accounts.
NYou do not need an account to use
Smart Hub.
To create an account, follow these
steps:
1. On the Smart Hub screen, select a
using your remote. The Login screen
appears.
2. Select Create Account using your
remote. The Create Account screen
appears.
3. Select Samsung Account. An entry
screen and keypad appear.
4. Use the keypad to enter your e-mail
address. This will serve as your ID.
NIf you have a Bluetooth or USB
keyboard attached to the TV, use the
keyboard to enter the e-mail address.
Then, in Steps 6 through 10, use
the keyboard to enter the required
password. Note that after you type
in the e-mail address and password,
you will need to use your remote to
continue.
5. When done, select OK. The Login
screen reappears.
6. Select Password. The Password
screen and a keypad appear.
7. Use the keypad to enter a password.
The password can be any
combination of letters, numbers, and
symbols.
NSelect a using your remote to
display or hide the password as
you enter it.
8. When done, select OK.
9. Select Confirm password. The
Password screen and a keypad re-
appear.
10. Repeat Steps 7 and 8.
11. When done, select Create Account.
The Confirmation window appears.
12. Select OK. The Continue to register
service ID window appears.
13. Select OK.
NIf you don’t have existing provider
accounts or do not want to
register existing accounts at this
time, select Cancel. You can also
let the window close on its own
in about a minute.
14. The Register Service Account
window appears.
NIf you have existing accounts
with any of the listed providers,
you can associate the provider
account and the provider account
password with your Samsung
account. Registration makes it
easier to access the providers web
site. For registration instructions,
go to Step 2 in Account Manager
under Settings in the “Configuring
Smart Hub with the Settings
Menu” section of this manual.
Customizing the Home Screen
a Login / Logout
To log in to your Samsung account,
follow these steps:
1. With the Smart Hub main screen
displayed on your TV, select a
using your remote. The Login screen
appears.
2. Select the ^ next to the Samsung
Account entry field. A drop down list
appears.
NIf you want to input your Samsung
Account name manually, select
the Samsung Account entry field.
A keypad screen appears. Input
your Samsung Account manually.
When done, go to Step 4.
3. Select your ID from the list that
appears. The Login screen re-
appears.
4. Select Password. The Password
window and a keypad appears.
5. Enter your password using your
remote. When done, select OK.
NIf you want Smart Hub to enter
your password automatically, select
Remember my password after you
have entered your password. A c
mark appears. Smart Hub will now
enter your password automatically
when you select or enter your ID.
NIf you forget your Samsung account
password, you can reset it. Select b
using your remote. A popup message
appears. Select OK. Smart Hub will
send a written guide to your e-mail
address that explains how to reset
your password.
b Wallpaper
You can change the background image
on the Smart Hub home screen.
{ Account Manager
Lets you register your service provider
accounts, delete or deactivate
your Samsung account. For more
information about Account Manager,
see "Configuring Smart Hub with the
Settings Menu" in this section.
NAvailable only when you have logged
in to Smart Hub.
Using the Tools menu with Smart Hub
NDepending on the icons and folders
displayed on the Smart Hub screen,
some of the functions listed below may
not appear.
Login / Logout
Log in to or log out of your Samsung
account.
Wallpaper
You can change the background image
on the Smart Hub home screen.
Move
The Move function lets you change the
screen position of an application or a
folder.
To use the Move function, follow these
steps:
1. Select an application icon or a folder,
and then open the Tools menu using
your remote.
2. Select Move. A position change
screen appears.
3. Move the icon using your remote.
When the icon is in the position of
your choice, select the icon. The
application icon moves to its new
location.
New Folder
The New Folder function lets you create
and name new folders. You can move
applications into the folders you have
created.
To use the New Folder function, follow
these steps:
1. Open the Tools menu using your
remote.
2. Select New Folder in the menu. The
New Folder pop-up and a keyboard
screen appears.
3. Using the keyboard and your remote,
enter a name for the folder.
4. When done, select OK at the bottom
of the screen. The New Folder screen
closes and the New Folder appears
on the Smart Hub screen.
Move to Folder
The Move to Folder function lets you
move an application to a folder.
To use the Move to Folder function,
follow these steps:
1. Select an application, and then open
the Tools menu using your remote.
2. Select Move to Folder. The Move to
Folder window opens.
3. Select a folder using your remote.
A move finished message appears.
Select OK. The message window
closes. The application has been
moved to the folder.
NIf you select an application in a
folder, you can use the Move to
Folder to move the application to the
Smart Hub screen.
To access an application in a Folder
1. On the Smart Hub screen, select a
folder. The folder opens.
2. Select an application you want to
execute. The application service
starts.
Delete
The Delete function lets you delete
applications from Smart Hub.
To use the Delete function, follow these
steps:
1. Select an application, and then open
the Tools menu using your remote.
2. Select Delete. The message Do you
want to delete selected item(s)?
appears.
3. Select OK. The application is deleted.
Rename Folder
The Rename Folder function lets you
rename folders.
To use the Rename Folder function,
follow these steps:
1. Select a folder, and then open the
Tools menu using your remote.
2. Select Rename Folder. The Rename
Folder window and a keypad screen
appears.
3. Enter a new name using your remote
or edit the old name.
4. When done, select OK. The Rename
Folder window closes and the new
or revised name appears below the
folder.
Lock
The Lock function lets you lock some
applications in Smart Hub so they
cannot be opened without entering your
security PIN.
NDepending on the application, this
function may not be supported.
To use the Lock function, follow these
steps:
1. Select an application, and then open
the Tools menu using your remote.
2. Select Lock. The Security window
appears.
3. Enter your security PIN using the
remote. If you have not created a
PIN, enter “0-0-0-0”.
4. A confirmation message screen
appears. Select OK. The message
screen closes and a lock symbol
appears to left of the application.
Unlock
NDepending on the application, this
function may not be supported.
To use the Unlock function, follow
these steps:
1. Select a locked application, and then
open the Tools menu using your
remote.
2. Select Unlock. The Security window
appears.
3. Enter your security PIN using the
remote. If you have not created a
PIN, enter “0-0-0-0”.
4. A confirmation message screen
appears. Select OK. The message
screen closes and the lock symbol to
left of the application disappears.
Information
You can view detailed information
about the selected application.
NDepending on the application,
you can also lock or unlock
the application on the Detailed
Information screen.
Reinstall
If an application is not installed
properly, reinstall it.
NThe reinstall feature is only available
for an application that has not been
installed properly.
Reinstalling an application
1. Select an application and then select
Tools.
2. Select Reinstall. The application
reinstalls.
3. When the application has installed
successfully, a message appears
notifying the user that installation is
complete.
Configuring Smart Hub with the Settings
Menu
The Settings menu gives you access to
the Account Manager, Service Manager,
Reset, and About Smart Hub functions.
To use these functions, you must be
logged into your Samsung Smart Hub
account.
To access the Settings menu, and then
select a menu item, follow these steps:
1. Open the Tools menu using your
remote.
2. Select Settings. The Settings window
appears.
3. Select a menu item using your
remote.
Account Manager
The Account Manager menu contains
functions that let you register your
service provider accounts, and delete or
deactivate your Samsung account.
Link to other accounts: If you have
existing accounts with any of the
providers listed by the Link to other
accounts function, you can associate
the provider account and the provider
account password with your Samsung
account. If you associate the account,
you will be able to log onto the
account through Smart Hub easily,
without entering your account name or
password.
NBefore you register an account you
have with a provider, you must install
the provider's application in Smart
Hub.
To use the Link to other accounts
function, follow these steps:
1. In the Account Manager menu, select
Link to other accounts. The Link to
other accounts window appears.
2. Select an application you want
to associate with your Samsung
account.
3. In the pop-up that appears, select
Register.
4. In the Link to other accounts entry
screen, enter your site ID and
password using your remote. When
done, select OK.
NThis is the ID and password you
normally use to access your
account on this application.
5. If you have entered the ID and
password correctly, the Registered
successfully. message appears.
6. If want to add another service
application, repeat Steps 2 through
4 to associate another service
application.
7. When done, select OK.
Remove from TV Account List: Cancels
all the currently registered Service
Accounts that appear on the Register
Service Account screen.
Deactivate Account: Deactivates your
Samsung Account and deletes it and
all your account settings entirely from
Smart Hub.
Service Manager
Auto Ticker: You can set Auto Ticker to
come on when the TV powers.
NThe Ticker application provides
useful News, Weather, and Stock
Market information. Before you
can set Auto Ticker on, you must
download the Ticker application into
Smart Hub.
NDepending on your country, the
Ticker application may have a
different service or not be supported.
Push Notification Settings: When on,
Push Notification displays a notification
message when an event takes place in
an application installed on Smart Hub.
The TV will display the notification
message and allow you to view details
of the event even while you are viewing
TV.
Reset
The Reset function initializes all
downloaded applications, erases all
user accounts and settings from the TV,
and resets all Smart Hub settings to the
factory default settings. It then restarts
Smart Hub as if it were starting for the
first time.
Your account, however, remains on
the Smart Hub server. To log into your
account, enter your ID and password
on the Login screen.
To use the Reset function, follow these
steps:
1. In the Settings menu, select Reset.
The Reset screen appears.
2. Enter your security PIN using your
remote.
NThe default password set is “0-0-
0-0.”
NIf you forget the PIN code, press
the remote control buttons in the
following sequence in Standby
mode: MUTEM 8 2 4
P (Power on). This resets the PIN
to “0-0-0-0”
3. After a few moments, Smart Hub
automatically resets. The screen
may go black, then Smart Hub re-
appears. In a few moments, it starts
the reinitialization procedure.
4. To complete the re-initialization, go
to Step 2 in "To start Smart Hub for
the first time, follow these steps:"
section of this manual.
About Smart Hub
The About Smart Hub menu contains
functions that display information
about Smart Hub.
Detail: Lists information about Smart
Hub including version number, memory
usage, and the unique product ID.
Terms of Service Agreement: Display
the Terms of Service Agreement.
Using Samsung Apps
Samsung Apps
² Samsung Apps
NDepending on the version of an
application, the instructions may
differ. In this case, please follow the
instructions on the screen.
Samsung Apps is a store from which
you can download applications to use
on Samsung TV/AV equipment.
You can enjoy a variety of contents
such as videos, music, photos, games,
useful information etc. using the
downloaded applications.
New applications are added regularly.
Using the colored and function buttons
with Samsung Apps
a Login / Logout
Log in to or log out of your Samsung
account.
b Filter by Price
To toggle the view between All, Paid,
and Free.
{ Sort
To sort the applications by
Recommended, Name, Date, or
Downloaded.
NYou can sort all categories except
Most Popular.
} View Mode
Each time you select } using your
remote, the View Mode toggles
between basic mode and thumbnail
mode.
πµ Scroll
Move to next or previous page.
T Tools
Displays the option menu.
R Return
Moves to previous menu.
Using Samsung Apps by category
The following categories are available:
What's New
User can easily find newly (the latest)
registered applications.
Most Popular
Displays the most popular applications
for users.
Videos
Includes apps that provide video media
such as movies, TV shows, and short
length videos.
Games
Includes various game apps such as
sudoku and chess.
Sports
Includes apps that provide sports
content such as game results, images,
and short length video.
Lifestyle
Includes apps that provide lifestyle
media services such as music, personal
photo management tools, and social
networking such as Facebook and
Twitter.
Information
Includes apps that provide information
content such as news, financial
information, stock quotes, weather, etc.
Education
Includes apps that provide educational
content such as story books, dictionary,
VOD (Video on Demand) for kids etc.
My Account
My Account provides information about
your available App cash coupon and
information about the apps you have
already purchased or installed on your
TV.
NYou can purchase App cash that you
can use to buy applications through
tv.samsungapps.com.
Help
If you have questions about Samsung
Apps, check this section first.
To search for an application in Samsung
Apps, follow these steps:
1. On the Samsung Apps screen, select
Search Samsung Apps. The Search
window and keyboard appears.
2. Enter a keyword using your remote.
The keyword should be part of the
name of an application. For example,
enter f-a-c-e to search for Facebook.
3. When done, select OK at the bottom
of the keyboard.
4. Wait until the search result screen
displays. After Samsung Apps
displays the results, you can select
an application you want in the search
result screen.
NYou can use a keyword in the search
history If you have searched using
that keyword before.
NIf you have a keyboard and/or a
mouse connected to your TV, you
can use the mouse to select the
Search Samsung Apps field and the
keyboard to type in the keyword.
Search
² Search
(May not be available, depending on your
country.)
NDepending on the version of an
application, the instructions may
differ. In this case, please follow the
instructions on the screen.
Easily search for and access content
from diverse sources (e.g. applications,
Your Video, Samsung Link)
1. On the Smart Hub screen, select
Search at the top of the screen or
press the SEARCH button on your
remote.
2. If you want to input a search term
directly, select the Enter search
keyword. entry field. A keypad
screen appears. Enter the search
term using your remote.
NIf you want to search by category,
select a category below the field
using your remote.
Using the Search function by category
Your Video
Personalize your movie-watching with
a customized video on demand (VOD)
recommendation service.
Most Searched
You can search by selecting a key word
in the key word list. The key word list
displays words you frequently use for
searches.
Top Application
You can search applications and
services in the application list. The
application list displays apps that users
download frequently.
Search History
You can find a keyword in the search
history list if you have searched using
that keyword before.
Using the colored and function buttons
with Search
b Refresh
Refresh the Search function.
T Tools
You can set general parameters for the
Search function or delete the search
history.
R Return
Return to the previous menu.
Using the Tools menu with Search
General Settings
Keyword Recommendation: Turns the
Keyword Recommendation function on
or off.
Search Scope: Sets a search scope.
The default is to use all the applications
listed on the Scope page.
To customize a search scope, follow
these steps:
1. On the Search screen, open the
Tools menu using your remote.
2. Select General Settings.
3. Select an application in the Search
Scope. The c mark disappears from
the check box on its left.
NWhen you remove the c mark,
you remove that application from
the search scope. Only checked
applications are included.
4. When done, press the RETURNR
button.
Search History
Lets you delete previously used
keywords from the the search history
list. Also, If you select Delete All, you
can delete all your search history.
To delete a search history keyword,
follow these steps:
1. On the Search screen, open the
Tools menu using your remote.
2. Select Search History.
3. Select a keyword in the Keyword list.
4. Press E on the remote. The keyword
disappears from the list.
Your Video
² Your Video
(May not be available, depending on your
country.)
NDepending on the version of an
application, the instructions may
differ. In this case, please follow the
instructions on the screen.
Using this service from Smart Hub, you
can get video recommendation, search
for movies from multiple providers, and
stream or purchase movies. To stream
or purchase movies, you must have the
vendors app installed in Smart Hub.
Depending on the vendor, you may also
need a vendor account.
Using the Your Video Search Tab
1. On the Smart Hub screen, select
Your Video.
2. If this is the first time you have
accessed Your Video, the Privacy
Notice appears. Read the notice, and
then select Agree.
3. When the Your Video screen appears,
it displays a list of recommended
movies with Recommended at the
top of the screen highlighted. Move
the highlight from the top of the
screen down to the first movie, and
then scroll the movies to the right to
view all the movies in the list.
4. To see additional lists of movies,
move the highlight back to the top
of the screen. You can select - in
addition to Recommended - New
Releases, Top 20 Movies, Top 20 TV
Shows, and From Friends.
5. To select a movie, highlight it, and
then press the E button on the
remote. The movie's Data screen
appears. On this screen you can view
Basic Information, Director/Cast,
Photos, Awards, and Related Movies.
6. To watch the movie, select Watch. A
list of online vendors that have the
movie available for rent or purchase
appears. Renting usually means you
can stream the movie for a certain
number of hours or days.
NTo go to a vendor's web site,
you must have that vendor's app
installed in Smart Hub. To install
apps, access Samsung Apps on
the main Smart Hub screen.
7. You can search for a particular
movie. To search, select { with your
remote. The Search Entry screen and
a keyboard appear.
8. Enter the name of the movie into
the Search field. As you enter
characters, the Search function will
display suggestions below. You can
either continue entering characters,
or, if your movie appears, move the
highlight down and select it. The
movie's Data screen appears (See
Steps 5 and 6).
NIf you are entering using a
keyboard, you can either press
Enter or you can move the
highlight down using the down
arrow key.
Using the Function and Colored Buttons
on the Search Tab
a Login / Logout
To log in to your Smart Hub account
or log out.
{ Search
To search for movies or videos (Steps
7 and 8 on the previous page).
T My Page
Displays your My Video Bookmarks,
Likes/Shares (if you have a Facebook
or Twitter account registered in
Smart Hub), and lets you establish
certain Preferences.
R Return
Return to the previous menu.
Using Function and Colored Buttons on
a Movie's Data Page
a Login / Logout
To log in to your Smart Hub account
or log out.
b Bookmark / Unbookmark
To bookmark a movie or video or
to remove the bookmark. When you
bookmark, Bookmark appears on the
left side of the screen. Bookmarked
movies or videos are listed on My
Page.
{ Search
To search for movies or videos (Steps
7 and 8 above).
} Home
To go to the My Video Home screen.
T My Page
Displays your My Video Bookmarks,
Likes/Shares (if you have a Facebook
or Twitter account registered in
Smart Hub), and lets you establish
certain Preferences.
R Return
Return to the previous page or menu.
Using the Your Video Genre Tab
When you start Your Video, the Your
Video screen displays the Search tab.
You can also display the Genres tab
which sorts movies and videos by
genre.
1. On the Your Video Search tab, move
the highlight to the bottom of the
screen, and then select Genres. The
Genres tab appears.
2. On the Genres tab, select either
Movies or TV Show on the left side
of the screen
3. On the right side of the screen,
select the genre (Action/adventure,
Animated, etc.). Your Video displays
the Genre Movie or TV Show List
screen with the movies or TV shows
in the genre you selected.
4. Highlight a movie or TV show and
then select it. The Data screen for
that movie or TV show appears.
Using the Function and Colored Buttons
on a Genre Movie or TV Show List
Screen
a Login / Logout
To log in to your Smart Hub account
or log out.
b Genre
To re-display the Genres tab.
{ Search
To search for movies or videos.
} Sort
To sort movies or videos by Ratings,
Year, or Title.
T My Page
Displays your My Video Bookmarks,
Likes/Shares (if you have a Facebook
or Twitter account registered in
Smart Hub), and lets you establish
certain Preferences.
R Return
Return to the previous page or menu.
Using My Page
My Page displays your My Video
Bookmarks, Likes/Shares (if you
have a Facebook or Twitter account
registered in Smart Hub), and lets you
establish certain Preferences. When the
T My Page icon is displayed at the
bottom of a screen, select T Tools.
My Page appears displaying your
bookmarked movies and videos. Select
a bookmarked movie or video, access
your Likes/Shares, or view or change
your Preferences.
Using the Function and Colored Buttons
on the My Video Screen
a Login / Logout
To log in to your Smart Hub account
or log out.
{ Search
To search for movies or videos.
} Home
To go to the My Video Home screen.
R Return
Return to the previous page or menu.
Family Story
² Family Story
NDepending on the version of an
application, the instructions may
differ. In this case, please follow the
instructions on the screen.
Family Story allows you to share
photos, messages, and events with
your family.
Create Group
If you are starting Family Story for
the first time, you can create a family
group and invite members to join.
Invite Members
After creating a group, you can invite
the family members who you want to
share your family's photos and events
with to join.
Join Group
If you were invited to join a family
group by a family member, you can
select Join Group to enjoy Family Story
services.
NYou must be logged into your Smart Hub
account to create a family group, access
your group, or use Family Story.
To create a family group, follow these
steps:
1. On the Smart Hub screen, select
Family Story. The Family Story
screen appears.
2. Select Create Group. The Create and
Invite pop-up appears.
3. Select OK. The Family Story
agreement appears. Read the
agreement, and then select Accept.
NYou must agree with the terms
prior to using Family Story.
4. Enter a Group Name, Your Name, and
Your Phone Number without dashes
using your remote.
NIf you want to add a group image,
select an image box. (An external
device containing photos must be
connected to your TV via USB.)
N* Fields marked with an asterisk
are required.
5. When done, select Done. The group
creation is complete.
NIf you want to invite members to
your group, select Invite Members.
If you want to go your Family
Story, select Go to Family Story. If
you selected Invite Members, go
to Step 4 in the procedure below.
To invite members to your Family Story
group, follow these steps:
1. From the starting menu in Family
Story, open the Tools menu using
your remote, and then select Group
Members. The Group Members
screen appears.
2. Select Invite Members. The Invite
pop-up appears.
3. Select OK. The Invite Members
screen appears.
4. Select Select to enter message.. The
keypad screen appears.
5. Enter a message using your remote.
When finished, select OK on the
bottom of the keyboard, and then
select Done.
6. Select Phone number or Samsung
account ID. The keypad screen re-
appears.
7. Enter the prospective member's
phone number or Samsung account
ID using your remote. When finished,
select OK on the bottom of the
keyboard, and then, select Done.
NIf you want to add more
prospective members, select
Add member, and repeat Steps 4
through 7.
8. When finished adding members,
select Done. The Member Invitation
Completed screen appears.
9. If invited by phone number, a 4-digit
invite code will be generated.
You need to share the code with
the prospective member. If the
prospective member will be notified
about the invitation via e-mail. Select
OK to finish.
To join a group using the received invite
code, follow these steps:
1. Start Family Story and accept the
terms.
2. You will see a pop-up message
asking about invitation type. If
you were invited by phone number,
please select Invite Code. If you were
invited by Samsung account, please
select Samsung Account.
3. If joining by Samsung Account, a
list of invitations from your family
groups will be displayed. Select
Accept to join. You can select Deny
if you don't want to join the inviting
group.
4. If joining by Invite Code, first enter
your phone number using your
remote. When done, select Done.
Then you will see a list of invitations
from your family groups. Select
Accept to join. You can select Deny
if you don't want to join the inviting
group. Enter the 4-digit invite code
shared by your family member, and
then select Done to finish.
5. Select OK. The process is complete.
Creating an Album
You can upload pictures from a USB
device and create a picture album
which other group members can view
and add to.
To create a picture album, follow these
steps:
1. Attach a USB device to your TV
containing the pictures you want to
upload to the picture album.
2. Log into your Smart Hub account,
and then start Family Story.
3. Highlight and select the "create
album" display on the left side of
the Family Story screen or select b
using your remote. The Create screen
appears.
4. Highlight and select Add on the
Album tab. The File Browser screen
appears.
5. Highlight and select the USB device.
The device opens, displaying either
folders or picture files.
6. If picture files are displayed,
highlight and select each file you
want to upload. A check appears on
each file.
7. If folders are displayed, highlight and
select the folder that contains the
pictures you want to upload. Then,
select each file you want to upload.
A check appears on each file.
NYour can highlight and select the
Select All button on the right side
if you want to select all displayed
pictures.
8 When finished, highlight and select
the OK button on the right side. The
Create screen re-appears displaying
some or all the photos you want to
upload.
NTo delete a photo from the
upload queue, select T Tools.
In the Tools menu, select Delete
Photos. Either highlight and select
individual photos or select Delete
All. When done, select the Delete
button on the bottom of the page.
A pop-up appears asking whether
you want to delete the photos.
Select Yes.
9. Highlight and select the Done button
on the bottom of the screen. The
photos are uploaded, and then the
Story of the Day screen appears,
displaying the photos.
10. Select R Return. The Cover Story
(Main Family Story) screen appears
displaying the photos.
NThe Cover Story screen runs a
continuous slide show of photos
you uploaded. It also displays
some of the photos on a "shelf"
below the slide show area.
Deleting a Picture
To delete a picture, follow these steps:
1. On the Cover Story screen, highlight
and select the strip of photos on the
bottom left. The Story of the Day
screen appears.
2. Highlight and select the photo you
want to delete.
3. Select T Tools.
4. In the Tools menu, select Delete. A
message appears asking if you want
to delete the photo.
5. Select OK. The picture is deleted.
Editing a Picture
The Edit function lets you add a memo
to a picture or add the picture to an
event.
To edit a picture, follow these steps:
1. On the Cover Story screen, highlight
and select the strip of photos on the
bottom left. The Story of the Day
screen appears.
2. Highlight and select the photo you
want to edit.
3. Select T Tools.
4. In the Tools menu, select Edit. The
Edit screen appears.
5. To add a memo, highlight and select
the "enter Memo" field. The Enter
Memo screen and keyboard appear.
6. To add the picture to an event,
highlight and select Find event.
The Event List screen appears. Use
the left and right arrow buttons to
change the month. Use the up and
down arrow buttons to select an
event. Press E when done.
7. After you have added a memo or
added the photo to an event, highlight
and select Done on the bottom of the
screen.
Creating a Memo
You can create a memo that all group
members can see.
To create a memo, follow these steps:
1 Log into your Smart Hub account,
and then start Family Story.
2. Highlight and select the "create
memo" display on the right side of
the Family Story screen or select b
using your remote. The Create screen
appears.
3. On the Memo tab, highlight and
select the "enter Memo" area. The
Enter memo screen and keyboard
appear.
4. Use your remote to highlight and
select letters. If you have a USB
or Bluetooth keyboard attached to
the TV, use the Keyboard to type in
letters.
5. When done, select OK on the on-
screen keyboard or press E on the
remote. If you are using a physical
keyboard, press the Enter key on the
key board. The Create screen re-
appears displaying the memo.
NTo edit the memo, highlight and
select the "enter Memo' area
again. The Enter memo screen
and key board re-appear.
6. Highlight and select the Done button
on the bottom of the screen. The
Story of the Day screen appears
displaying the memo.
7. Select R Return to go back to the
main Family Story screen.
Deleting a Memo
To delete a memo, follow these steps:
1. On the Cover Story screen, highlight
and select the memos on the right
side of the screen. The Story of the
Day screen appears.
2. Highlight and select the memo you
want to delete.
3. Select T Tools.
4. In the Tools menu, select Delete. A
message appears asking if you want
to delete the memo.
5. Select OK. The memo is deleted.
Editing a Memo
To edit a memo, follow these steps:
1. On the Cover Story screen, highlight
and select the memos on the right
side of the screen. The Story of the
Day screen appears.
2. Highlight and select the memo you
want to edit.
3. Select T Tools.
4. In the Tools menu, select Edit. The
Edit screen appears.
5. Highlight and select the Edit field.
The Memo screen and keyboard
appears. Edit the memo, and then
press E when done.
6. The Edit screen re-appears. Highlight
and select Done on the bottom of the
screen.
Creating an Event
You can create a record of an event,
such as a birthday party or a wedding,
with pictures, that all group members
can see. You can also create a record
for a future event.
To create an event, follow these steps:
1. Attach a USB device containing the
pictures of the event that you want
to upload to your Family Story.
2. Log into your Smart Hub account,
and then start Family Story.
3. Highlight and select the "create
event" display on the right side of
the Family Story screen or select b
using your remote. The Create screen
appears.
4. On the Event tab, highlight and select
the Event Title field. The Event Title
screen and keyboard appear.
5. Use your remote to highlight and
select letters. If you have a USB
or Bluetooth keyboard attached to
the TV, use the keyboard to type in
letters.
6. When done, select OK on the on-
screen keyboard or press E on the
remote. If you are using a physical
keyboard, press Enter on the
keyboard.
7. Highlight and select Done on the
Event Title screen with your remote.
The Event Tab reappears.
8. Use your remote to highlight and
select the enter description field.
The Enter Description screen and
keyboard appear.
9. Enter a description of the event the
same way you entered the Event
Title in Step 5. When done, close
the Enter Description screen the
same way you closed the Event Title
screen in Steps 6 and 7.
10. Highlight and select the From field.
The Time Setting screen appears.
Use the up and down arrow buttons
on your remote to change the values
in each field. Use the left and right
arrow buttons to move from field to
field. Press E when done.
11. Highlight and select the To field. The
Time Setting screen appears. Set the
To time the same way you set the
From time in Step 10.
12. To define the Event Type, highlight
and select the Change button. The
Event Type list appears.
13. Use the up and down arrow buttons
on your remote to select an event
type. When done, press E on the
remote. The Event Tab re-appears.
14. To add photos, highlight and select
the Add button. The File Browser
appears.
15. Highlight and select the USB device.
The device opens, displaying either
folders or picture files.
16. If picture files are displayed,
highlight and select each file you
want to upload. A check appears on
each file.
17. If folders are displayed, highlight and
select the folder that contains the
pictures you want to upload. Then,
select each file you want to upload.
A check appears on each file.
NYour can highlight and select the
Select All button on the right side
if you want to select all displayed
pictures.
18. When finished, highlight and select
the OK button on the right side. The
Event tab re-appears displaying
some or all the photos you want to
upload.
NTo delete a photo from the
upload queue, select T Tools.
In the Tools menu, select Delete
Photos. Either highlight and select
individual photos or select Delete
All. When done, select the Delete
button on the bottom of the page.
A pop-up appears asking whether
you want to delete the photos.
Select Yes.
19. When done entering all information
and selecting all photos, highlight
and select the Done button at the
bottom of the Event tab. Family Story
uploads the photos you selected and
then displays the Story of the Day
screen.
20. Select R Return to go back to the
main Family Story screen.
Deleting an Event
To delete an event, follow these steps:
1. On the Cover Story screen, highlight
and select the events on the bottom
right side of the screen. The Story of
the Day screen appears.
2. Highlight and select the event you
want to delete.
3. Select T Tools.
4. In the Tools menu, select Delete. A
message appears asking if you want
to delete the event.
5. Select OK. The memo is deleted.
Editing an Event
To edit an event, follow these steps:
1. On the Cover Story screen, highlight
and select the events on the bottom
right side of the screen. The Story of
the Day screen appears.
2. Highlight and select the event you
want to edit.
3. Select T Tools.
4. In the Tools menu, select Edit. The
Edit screen appears.
5. Edit the elements in the event in the
same fashion you first entered them.
6. To remove a photo, highlight the
photo, and then Select T Tools.
7. In the Tools menu, select Disconnect
Photos.
8. Highlight and select individual photos
or highlight and select Select All.
9. Highlight and select Delete. A
message appears asking if you want
to delete the photos. Select Yes.
10. When finished editing, highlight and
select Done at the bottom of the
page.
Functions on the Cover Story (Main) Screen
On the Cover Story screen, you can
launch a slide show, display individual
pictures, view memos, and view events.
Launching a Slide Show
1. On the Cover Story screen, highlight
and select the large Slide Show area.
This is the portion of the screen
that displays constantly changing
pictures. The slide show starts. The
slide show controls are displayed
momentarily, then disappear.
2. To stop or start the slide show and
to re-display the controls, press E
on your remote.
3. To view individual pictures, stop the
slide show, and then press the left or
right arrow button on your remote.
4. To change the speed of the slide
show, select the or button.
5. To end the slide show, select R
Return.
Viewing Individual Pictures
1. On the Cover Story screen, highlight
and select the strip of photos on
the bottom right. The Story of the
Day screen appears displaying the
individual photos.
2. Highlight and select a photo. The
individual photo is displayed.
To add a comment about the
photo, highlight and select the Add
Comment button or select b. The
Comment screen and keyboard
appear.
To watch a slide show that includes
the picture, highlight and select the
picture. The slide show begins.
To watch a slide show together
with another member of your group,
select {. This function lets you and
another member of your group watch
the same slide show on your own
TVs, even if you are thousands of
miles apart.
Viewing Individual Memos
1. On the Cover Story screen, highlight
and select the memos displayed
on the right side. The Story of the
Day screen appears displaying the
individual memos.
2. Highlight and select a memo. The
individual memo is displayed.
To add a comment about the
memo, highlight and select the
Add Comment button or select b.
The Comment screen and keyboard
appear.
Viewing Individual Events
1. On the Cover Story screen, highlight
and select the events displayed
on the right side. The Story of the
Day screen appears displaying the
individual events.
2. Highlight and select an event. The
individual event is displayed.
To add a comment about the
event, highlight and select the Add
Comment button or select b. The
Comment screen and keyboard
appear.
To watch a slide show of the pictures
saved in the event, highlight and
select the pictures at the bottom left
of the screen. The slide show begins.
The Tools Menu Functions
The Tools menu appears on most of
the Family Story screens. This section
provides a run down of all the Tools
menu functions by screen.
Tools Menu Functions on the Cover
Story Screen
Group Members: Lists the current group
members and the current prospective
members with invitations.
My groups: Lists the groups you are a
member of. Also lets you access your
groups.
Settings: Lets you edit your profile
information and set whether your group
will allow new content, new members,
new invitations, and issue event
reminders.
Logout: Logs you out of Family Story
and your Samsung account. Returns
you to the Smart Hub screen.
Create: Takes you to the Create screen
where you can create a photo album,
memo, or event record.
Updates: Lets you know if there is an
update for the Family Story application,
and lets you download and install it.
Tools Menu Functions on the Story of
the Day Screen
Filter: Lets you select what to view
on the Story of the Day screen by
category: All, Album, Memo, Event.
View by Member: Lets you view entries
(Albums, Memos, Events) by member.
The rest of the functions - Group
Members, My groups, Settings, Logout,
and Updates - are the same functions
as the Cover Story screen functions.
Other Functions on the Story of the
Day Screen
The Story of the Day screen also has
a date filter function on the bottom of
the screen.
Date Occurred / Date Uploaded: You
can sort the items on the Story of
the Day screen by Date Occurred or
Date Uploaded by highlighting and
then selecting the Date Occurred/Date
Uploaded slider button.
You can also quickly move to the
month certain items occurred or were
uploaded by selecting a highlighted
number on the monthly number bar.
You can also select a year, and then a
month. When you select a month, Family
Story displays the items that were
uploaded or occurred in that month.
Fitness
² Fitness
NDepending on the version of an
application, the instructions may
differ. In this case, please follow the
instructions on the screen.
The Fitness application provided by
Smart Hub lets you track and manage
a fitness and exercise program you
create.
NTo use Fitness, you should be logged
in to your Smart Hub account.
Read these notes before exercising...
NPlease warm-up or stretch before
exercising.
NStop exercising immediately if you
feel pain, or feel dizzy, exhausted, or
short of breath.
Create Your Profile
When you start Fitness for the first
time, you should create your own
profile. On the Fitness screen, select
Create Your Profile. A pop-up message
appears. Select Create Your Profile. The
Personal Trainer/Create Profile screen
appears.
1. To go to next step, press the right
arrow button on your remote. The
Name pop-up appears.
2. Select First Name. The Username
screen and keyboard appear. Enter
your name. When done, Select OK.
3. Select Last Name. The Username
screen and keyboard re- appear.
Enter your last name. When done,
Select OK.
4. Press the right arrow button on your
remote. The Gender pop-up appears.
5. Highlight and select your gender.
When you select your gender, you
will see a black dot appear in your
selection.
6. Press the right arrow button on your
remote until the Date of birth pop-up
appears.
7. Enter your birth date using your
remote. It will be used to personalize
some parameters for you.
8. Press the right arrow button on your
remote. The Unit pop-up appears.
9. Select your preferred units. The
selected units will be applied
throughout the Fitness app. Move to
the right again. The Height pop-up
appears.
10. Enter your height. This will be used
to calculate your body mass index
(BMI). Move to the right again. The
Weight pop-up appears.
11. Enter your weight. This will be used
to calculate your body mass index
(BMI). Move to the right again. The
application calculates your BMI.
12. The creation of your profile is
finished. The TV displays your profile
information and BMI. To start the
Fitness app, select Enjoy Fitness.
Using Fitness with categories
Exercise
Provides information on your exercise
goal, current status and recommended
contents.
Progress
Provide information on your basic body
profile, exercise progress, achievement
of your goals, etc.
Browse all
You can use all the exercise contents
more easily because the contents are
classified into groups such as Abs,
Strength, Yoga and so on by their
types.
Selecting Exercise Programs
Fitness displays a number of exercise
videos and programs you can use to
help you reach your fitness goals. Each
of these videos and programs must
be downloaded from Samsung Apps.
Videos labeled VOD (Video on Demand)
are part of a group of free exercise
videos. We suggest you download
those first.
To download a VOD program or video,
follow these steps;
1. On the Fitness screen, highlight and
select a program. A message appears
asking you if you want to go to
Samsung apps.
2. Select Yes. The Samsung Apps
screen appears.
NThis may take a few minutes.
3. If this is the first time you have
downloaded a VOD program or
video, you will be directed to
download the VOD video app that
lets you download and play all the
VOD exercise videos.
4. Follow the directions on the screen
to download the VOD video app.
5. After the video app has been
downloaded, press RETURNR several
times to go back to the Fitness
screen.
6. You can now select and play any of
the VOD videos.
NAs you play these videos, Fitness
notes the video you are using and
calculates the number of calories
you have burned, based on the
video.
Kids
² Kids
NDepending on the version of an
application, the instructions may
differ. In this case, please follow the
instructions on the screen.
The Smart Hubs Kids app provides a
quick app launcher and a recommended
list of kids and education-related
applications and contents your kids can
start easily and quickly. It also provides
management tools that let you control
what your kids can view in the app and
how long they can watch.
Using Kids with categories
Playground
Displays recommended contents and
applications. When you select an
application or content, the TV starts the
application or contents immediately.
NYou can add up to 40 items to the
recommended list. See "My Choice"
in this section.
NYou can edit the contents list. For
more detailed information, refer to
"My Choice" in this section.
NMost of the contents must be
downloaded from Samsung apps. To
download, follow the directions on
the screen. When the download is
complete, press RETURNR repeatedly
until the Kids app reappears. Start
the contents or app by highlighting
and then selecting it.
Sticker Book
Displays the Sticker Books with the
stickers your kids received. Also, it can
be shared with your Family Story.
How your kids can receive the stickers
By User (parent): You can present a
sticker using the Present Stickers
function in the Parents menu.
Automatically: The Kids app presents
a sticker while the child is watching
content.
Creating a Sticker Book
1. To create a new Sticker Book,
select Sticker Book on the top of
the screen, and then Create a New
Sticker Book at the bottom of the
screen. The Create a New Sticker
Book screen appears.
2. Enter the Sticker Book's name using
your remote. When done, select
Next.
3. Select a color for the Sticker Book.
When done, select Next.
4. Check the created sticker book. If
you want to change a name, select
Edit. If you want to change a color,
select Back.
5. When done, select Done. A new
Sticker Book is created.
NThe maximum number of books you
can create is 10.
NYou can check arrived stickers by
highlighting and selecting Get New
Stickers. Only ten new sticker types
are displayed in New Sticker at one
time.
Browse All
Displays the kids or education-related
applications list and all contents list.
NWhen you select an application
or contents, if the application or
contents has not been installed
on the TV, the TV displays the
corresponding download screen from
Samsung Apps.
To use Browse All, follow these steps:
1. On the Browse All screen, select
a character. The contents for that
character appears on the right.
2. Select the kind of contents you want.
3. The detailed information screen for
the selected contents appears. You
can play the contents, share the
contents with your Family Story, add
the contents to My Choice, and give
the contents a rating.
NIf you have purchased an item
already or the item is free, you
can play the contents. If you
have not purchased it, you can
download the contents from
Samsung Apps.
Parents
Lets you edit the Playground, give
stickers to your kids, check usage time,
and set the watching limit alarm.
My Choice
You can add or delete contents in the
Playground. The Playground displays
the added contents only.
To add or delete contents in the
Playground, follow these steps:
1. On the Parents screen, select My
Choice. The My Choice screen
appears.
NMy Choice contains content you
added through the Browse All
screen.
2. Select contents you want to add or
delete in the list. A pop-up message
appears.
3. Select Yes.
4. The selected contents is added or
deleted.
Present Stickers
When your kids do a good job today,
you can present a sticker to them.
To present a sticker to your kids, follow
these steps:
1. On the Parents screen, select Present
Stickers. The Present Stickers screen
appears.
2. Select a sticker you want to present.
A pop-up message appears.
3. Select Yes.
4. Select a sticker book you want to
put the sticker into, and then select
Present.
NIf you want to check a sticker
book, select Check Now. You can
check the stickers in the selected
sticker book.
5. The sticker is placed in the sticker
book you selected.
Viewing History
Lets you check how long your kids
have used the app through a graph.
Also, lets you check how long your
kids have used each video or content
item. Change a date or content title
using your remote.
Set Alarm
Lets you set how long your kids can
watch. When the time is up, the alarm
window appears.
To set the time your kids can watch,
follow these steps:
1. On the Parents screen, select Set
Alarm. The Set Alarm screen
appears.
2. Select Timer.
3. Select amount of time. The alarm is
set.
Web Browser
² Web Browser
(May not be available, depending on your
country.)
NDepending on the version of an
application, the instructions may
differ. In this case, please follow the
instructions on the screen.
Using this function provided by the
Smart Hub, you can surf the Internet on
your TV.
1. On the Smart Hub screen, select Web
Browser. The Web Browser screen
appears.
2. Surf the Internet in the same way as
on a PC.
Using the colored and function buttons
with the Web Browser
b Control Panel
Shows or hides the control panel at the
top of the screen.
{ Link Browsing / Pointer Browsing
You can change the cursor to Link
Browsing mode or Pointer Browsing
mode. In Pointer Browsing mode, you
use a pointer to select items on the
screen in the same way you use a
pointer on a computer. In Link Browsing
mode, you move a blue rectangle
from link to link on the screen by
pressing the directional keys on your
remote. Pointer Browsing is best if
you have a mouse attached to the TV.
Link Browsing only works if you are
browsing using your remote.
NWhen you select Pointer Browsing,
you cannot use the remote to select
items in the Tools Menu.
NIn Pointer Browsing Mode, you can
use the arrow keys on your remote
to move the pointer.
} PIP
Turns PIP on or off. With PIP on, you
can watch TV while using the Web
Browser.
T Tools
Displays the Tools menu.
Control Panel: Shows or hides the
control panel in the top of the screen.
Link Browsing / Pointer Browsing: You
can change the cursor to Link Browsing
mode or Pointer Browsing mode.
PIP: Turns PIP on or off.
PIP Settings: Lets you select where
the PIP window is displayed on the
screen and which sound source the TV
plays, sound from the main screen (the
browser) or sound from the sub screen
(the PIP window).
Add to Bookmark: Add the current
page to your Bookmarks.
Enable Grabbing / Disable Grabbing:
You can move a current web page in
the direction you choose. To move
a web page, select a page, and then
move it in the direction you want using
your remote.
NAvailable only when the cursor is set
to Pointer Browsing.
πµ Scroll up/down
You can scroll the page up or down.
R Return
Close the Web Browser.
Using the Control Panel with Web Browser
The Web Browser has a series of icons
across the top of the screen which
provide a number of useful functions.
With these icons, you can easily
use the Web Browser. The icons are
described below, starting with the icon
on the far left of the screen.
Back
Moves to the previous web page.
NIf there is no previous web page, this
icon will not work.
Forward
Moves to the next web page.
NIf there is no next web page, this
icon will not work.
Refresh / Stop
Refreshes the current page or stops the
current connection from loading.
Home Page
Goes to the URL you specified as your
the home page.
Zoom
You can select a zoom level of 50%,
75%, 100%, 125%, 150%, 200%, 300%,
and Fit to screen.
Bookmarks
Displays the Bookmarks screen. You
can bookmark the current page or
select a favorite page to visit from the
bookmark list. You can also sort by
Date, Name, or Times Visited. To sort,
select Sort. When you select Enter URL,
you can enter in a new URL address
directly using your remote or mouse
and bookmark it.
When you highlight a bookmark, the
Option button appears on the right. In
the Option pop-up, you can edit the
selected page or delete the selected
page from the bookmark list.
By clicking the Text/Image button in
the upper right of the screen, you can
toggle the Bookmarks list between text
descriptions of bookmarked pages and
images of the bookmarked pages.
The Bookmarks screen can also
display your Browsing History and the
Windows list which contains a list of
the browser windows that are currently
active.
Using the Tools menu with Bookmarks
Delete All
Delete all bookmark lists.
Add to Bookmark
Bookmarks the current page.
Import bookmarks
You can import a bookmark file
saved on another device such as a
PC.
Export bookmarks
You can export a bookmark file from
your TV to another device connected
to your TV.
History
Displays the History screen. You can
select a web page to visit in the History
list. You can also sort by Date, Name,
or Times Visited. To sort, select Sort.
When you select Enter URL, you can
enter in a new URL address directly
using your remote or mouse.
When you highlight a page, the Option
button appears on the right. In the
Option pop-up, you can delete the
selected page from the history list or
add the selected page to bookmark.
NIf you want to delete all entries in
the history list, open the Tools menu,
and then select Delete All.
URL Field
Shows the URL of the current page. If
you select the URL field, the URL pop-
up appears. Using your remote, you
can enter a new URL directly.
Windows List
Displays a list or images of open
windows (the Windows List). You
can open a new window from the list
(using Open new window), select and
access a window in the list, select and
close a window in the list, or close
all windows. When you select Enter
URL, you can enter a new URL address
directly using your remote or mouse.
By clicking the Text/Image button in
the upper right of the screen, you can
toggle the Windows list between text
descriptions of open windows and
images of the open windows.
Using the Tools menu with Windows
List
Open new window
Open a new web browser window.
The new web browser page
automatically displays the home
page.
Close all windows
Close all the currently opened
windows listed in Windows List.
After closing all windows, the TV
opens a new web browser window
automatically. The new web browser
window automatically displays the
home page.
Search
Lets you search the web. When you
select the Search entry field, the Search
screen appears.
To search the web by word input,
follow these steps:
1. On the Search screen, select the
search engine.
2. Select Please enter a keyword.. The
keyboard screen appears.
3. Enter the word you want to use as
the keyword using your mouse or
remote. The TV searches using the
keyword and search engine you
selected.
Share
Share the current web page with your
Family Story.
Options
You can configure the Web Browser
settings.
Configuring the Web Browser Using Options
Move the cursor to the top of the
screen, and then select the Options
icon.
Reading Tools
Provides an easy-to-read page by
enlarging the main text. Reading Tools
is not available for all pages.
Approved Sites
Lets you restrict your children’s access
to inappropriate web pages by allowing
access only to the web sites you have
registered.
NEvery time you access Approved
Sites, the PIN screen appears. The
first time you access Approved Sites,
enter the default PIN, 0-0-0-0 using
the numbers keypad on your remote.
You can change the PIN using the
Reset password for the Approved
Sites function. See below.
Approved Sites feature: Turns the
Approved Sites function on or off.
Reset password for Approved Sites:
Change the Approved Sites password.
Add current site: Lets you add the
currently displayed web site to the
Approved Sites list.
Manage Approved Sites: Lets you key
in URLs to add to the Approved Sites
List and delete sites from the Approved
Sites list.
NIf you turn Approved Sites on and
have not added any sites to the
Approved Sites list, you will not be
able to access any Internet sites.
Private Browsing On / Private Browsing
off
Enable or disable the Privacy mode.
When the Privacy mode is enabled, the
browser does not retain the URLs of
sites you visit. If you want to enable
Privacy mode, select Yes.
If the Privacy mode is running, the
“Stop” icon appears in front of the URL
at the top of the screen. To disable
Privacy mode, select it again when
Privacy mode is enabled.
PIP Settings
Lets you configure the PIP function.
Position: Select a position for the PIP
sub-picture.
Sound Select: Select the audio source
you will hear - Main or Sub - when PIP
is on.
Web Browser Setting
You can configure Web Browser
options.
Set as homepage: You can set the
home page.
Most visited: Set the most frequently
visited URL as the home page.
Current Page: Sets the current page
as the home page.
Bookmarks: Sets the bookmarks URL
as the home page.
Enter URL: Lets you key in the URL
of the page you want for your home
page.
Pop-up Block: Turns the Pop-up Block
on or off.
Ad Block: You can determine whether
to block advertisements and select the
URLs for which advertisements are
blocked.
Ad Blocker: Turns the Ad Blocker on
or off.
Block current page: Adds the current
page to the blocked list.
Manage blocked sites: You can add
a website for which advertisements
will be blocked by directly keying in
the URL, or you can delete a website
from the list.
General: You can delete your personal
information.
Delete history: Deletes the website
history.
Delete browsing data: Deletes
Internet access information such as
cookies.
Reset Settings: Reset all web
browser settings to their factory
defaults.
Hide Menu: Turns the control panel
auto-hide on or off. If you select on,
the control panel on the top will be
hidden and only appear when you
move the pointer to the top of the
screen.
Encoding: You can set the Encoding
setting for web pages to Automatic or
Manual.
Auto select: Turns automatic
Encoding for web pages on or off.
The browser selects the appropriate
encoding format automatically.
Setting: Select an encoding format
from a list of encoding formats
manually. The format is applied to all
pages.
Pointer: You can set the speed of the
cursor when the cursor is set to Pointer
Mode.
Pointer Speed: Select a pointer
speed.
Browser Information: Displays the
version and copyright information for
the Web Browser.
Skype
² Skype
Skype created a little piece of software
that makes communicating with people
around the world easy and fun.
With Skype you can say hello or share
a laugh with anyone, anywhere. And
if both of you are on Skype, it’s free.
Communicate with people around the
world!
NTo use Skype, you need the Samsung
TV Camera (sold separately). Other
company’s TV Cameras are not
compatible with Skype on your TV.
NFor more information, download the
Skype user’s manual from “www.
samsung.com.”
[Legal Statement]
Due to the various capabilities of products featuring
the Samsung Smart Hub - Content Service, as well as
limitations in the available content, certain features,
applications, and services may not be available on all
devices or in all territories.
Some features on Smart Hub may also require
additional peripheral devices or membership fees that
are sold separately. Please visit http://www.samsung.
com for more information on specific device
information and content availability. The services and
availability of content through Smart Hub are subject
to change from time to time without prior notice.
Samsung Link
² Samsung Link
View or play photos, music, and movie
files located on a USB Mass Storage
Class (MSC) device, a PC, or a AllShare
device (a cell phone, for example) on
your TV.
NTo view content on a USB device,
you must plug the device into a USB
port on the TV.
NIf you want to use a USB HDD, we
recommend using a USB HDD that
has a power adapter.
NTo play content located on your
PC or on a AllShare compatible
cell phone, you must connect your
PC and the TV to your network
and download and then install the
AllShare network software on your
PC. In addition, to play content
located on a AllShare compatible
device, you must have a wireless
network.
Connecting a USB Device
1. Turn on your TV.
2. Connect a USB device containing
photo, music and/or movie files to
the USB port on the TV.
3. When a USB device is connected to
the TV, the New device connected.
window appears. Select a Contents
Type you want to play: Videos,
Photos or Music.
NThe TV may display the files on the
USB device automatically if it is the
only device connected.
4. The Samsung Link Music, Photos, or
Videos screen appears. If the USB
device has folders, the TV displays
a list of folders. Highlight and then
select a folder. If the USB device
does not have folders, the TV will
display files or thumbnails.
5. Highlight and then select a file to
view or play.
NTo select a different Content Type
or Device Type, press the RETURNR
button repeatedly until the Samsung
Link main screen appears, and then
select.
NFor more information about playing
back files, see the section of this
manual starting with "Video playback
control buttons".
Disconnecting a USB Device
Method 1: Using the SOURCEs
button.
1. Press the SOURCEs button.
2. Select a desired USB device, and
then press the TOOLST button. The
Tools menu appears.
3. Select Safely Remove USB, and then
wait until the selected USB device is
disconnected. You can remove a USB
device from the TV.
Method 2: Using the Samsung Link
home screen.
1. Go to Samsung Link home screen.
(²Samsung Link)
2. Select any category except My List,
and then press the E button.
3. Select a desired USB device, and
then press the TOOLST button. The
Tools menu appears.
4. Select Safely Remove USB, and then
wait until the selected USB device is
disconnected. You can remove a USB
device from the TV.
NTo remove a USB device from the TV,
we recommend use Safely Remove
USB function.
Read this information before using
Samsung Link with a USB device.
Restrictions and Cautions
Before connecting your device to the
TV, please back up your files ensure
against file damage or data loss.
SAMSUNG is not responsible for any
data file damage or data loss.
Connect a USB HDD to the dedicated
USB (HDD 5V 1A) port.
Do not disconnect a USB device
while it is being read by the TV.
If you connect a USB device with a
USB extension cable, the TV may not
recognize the USB device or read the
files on the device.
If a USB device you connect to the
TV is not recognized, the files on the
device are corrupted, or a file in the
list is not played, connect the USB
device to a PC, format the device,
re-copy the files to the device, and
then try playing again.
If a file you deleted from the PC is
still found when you run Smart Hub,
use the “Empty the Recycle Bin”
function on the PC to permanently
delete the file.
If your PC cannot construct a
functional database of saved files
on a USB device because there is no
free space on the USB device, you
may not be able to view any new
files you have added, even though
you have saved these files to the
USB device.
Supported Devices
Certain types of USB Digital camera
and audio devices may not be
compatible with this TV.
Samsung Link supports only USB
Mass Storage Class (MSC) devices.
MSC is a Mass Storage Class Bulk-
Only Transport device. Examples of
MSC include Thumb drives, Flash
Card Readers, and USB HDD (USB
HUB are not supported). Devices
should be connected directly to the
TV’s USB port.
More than 3TB USB HDD is not
supported.
If more than 2 PTP devices are
connected, you can only use one at
a time.
If more than two MSC devices are
connected, some of the devices may
not be recognized.
A USB device that requires high
power (more than 500mA or 5V)
may not be supported.
If the TV has no input during the
time set in Auto Protection Time, the
Screensaver will run.
The power-saving mode of some
external hard disk drives may be
turned off automatically when you
connect them to the TV.
File system and formats
The USB function might not work
properly with unlicensed multimedia
files.
MTP (Media Transfer Protocol) is not
supported.
The file system supports FAT16,
FAT32, and NTFS.
Samsung Link supports only the
Sequential jpeg format. It does not
support the Progressive jpeg format.
The higher the resolution of the
image, the longer it takes to display
on the screen.
The maximum supported JPEG
resolution is 15360 X 8640 pixels.
If a file is corrupted or the TV does
not support the file type, the Not
Supported File Format. message
appears.
If the files are sorted by Folder view,
the TV can display the names of up
to 1000 files in each folder.
If the number of files and folders
saved on a USB storage device is
over approximately 8000, some files
and folders may not appear and
some folders may be unopenable.
The TV cannot play MP3 files with
DRM that have been downloaded
from a for pay site. Digital Rights
Management (DRM) is a technology
that supports the creation,
distribution, and management of
digital content in an integrated
and comprehensive way, including
protecting the rights and interests of
content providers, preventing illegal
copying of contents, and managing
billings and settlements.
Even if a file you want to play is
encoded in a supported format, an
error message may appear due to a
sub container or profile problem.
Connecting to a PC through a network
You can play pictures, music, and
videos located on your PC through a
network connection using Samsung
Link.
NFor more information on how to
configure your TV and connect it to
your network, refer to “Setting up
the Network” in this manual.
NTo view content located on your
PC, you must have connected your
TV and your PC to your LAN and
downloaded and then installed
AllShare PC Software on your PC.
NWe recommend you locate both
your TV and PC in the same
network subnet. IP addresses have
four parts, separated by periods
(111.222.333.444). If your TV and PC
are in the same subnet, the first 3
parts of the TV IP address and the
PC IP address (111.222.333) will be
the same and only the last part (the
host address) will be different.
The following Samsung Link functions
are not supported when you are playing
media from a PC connected through a
network:
NThe Background Music and
Background Music Setting functions.
NSorting files by preference in the
Photos, Music, and Videos folders.
The or function while a movie
is playing.
Additional Notes
NDivX DRM is not supported.
NSet your PC firewall program so that
AllShare PC Software is a permitted
program.
NDepending on the Internet server,
when you use Samsung Link through
a network connection:
The sorting method may vary.
The Scene Search function may
not be supported.
The Resume function, which
resumes playing of a video, may
not be supported.
The Resume function does
not support multiple users. (It
memorizes only the point where
the most recent user stopped
playing a video.)
The search function may not
work depending on the content
information.
NYou may experience file stuttering
while playing a video in Samsung
Link through a network connection.
Using the Samsung Link
Samsung Link enables you to enjoy the
following services. You need to log in
to your Samsung account to use web
storage or social services.
Samsung Link can play various
contents in three ways:
Using USB Device: You can play
videos, photos, or music from a
connected USB device.
Using AllShare or Web storage:
You can play various contents from
devices connected to your home
network or web storage.
Using Social Services: You can play
some content from social services
such as Family Story, Facebook or
Picasa.
NBefore using Facebook or Picasa, it
should be installed in the Smart Hub.
NTo use SugarSync, Facebook,
or Picasa, you should log in
to corresponding application.
Alternatively, you can register your
application account in to your
Samsung account. To register
your application account, refer to
"Configuring the Smart Hub with
Settings" in the Smart Hub section.
NTo use Family Story, you should log
in to your Samsung account. Before
using Family Story, you should join a
group at least one more.
NYou can transfer a desired content to
other device connected to the TV.
Contents Type Supported transfer device
USB AllShare, SugarSync,
Family Story, Picasa,
Facebook
Camera AllShare
AllShare USB
SugarSync USB
Family Story USB
Picasa USB
Facebook USB
Mobile device USB
My List (In Samsung Link)
² Samsung Link My List
Using this function, you can access
content easily and quickly.
Recently Played
Displays a list of recently played video,
photo, or music files. If you have a file
you want to play again, use this list.
NWhen you try to play a file from the
Recently Played list, and the USB
device is not connected or the file
is not found, the "Cannot find the
file you're looking for." message
appears.
NThe Recently Played list can have up
to 48 files. The files are arranged so
that the most recently played files
are at the top of the list.
NRecently Played files located on a
mobile phone may not play.
What's New
Displays newly saved videos, photo,
or music files on a connected USB
device or your PC. If you have a newly
updated file you want to play, use this
category.
Playlist
Displays the Playlist files saved on the
USB device or your PC. If you want to
play a playlist, select the playlist. The
selected playlist plays immediately.
NYou can create up to 12 playlists.
NYou can add up to 100 files to a
single playlist.
NYou can only add one type of
content to a single playlist. For
example, you can only add music
files to a playlist that includes music
files.
Creating a Playlist
1. On the Samsung Link main screen,
select Videos, Photos, or Music on
the left side of the screen.
2. On the right side of the screen,
highlight and select the device that
has the files you want in the playlist.
Samsung Link displays the folders
and/or files on the device.
3. If Samsung Link is displaying
folders, highlight and select the
folder that contains the files you
want. If it is only displaying files, go
to Step 4.
4. Highlight a file, and then open the
Tools menu using your remote,
5. Highlight and select Add to Playlist.
6. Highlight and select a file you want
to add. A c mark appears in the
check box.
7. Repeat Step 6 to select additional
files.
NTo select all the files in the list,
select Select All. To cancel a
selection, select the file again.
8. When done, select Add. The Add to
Playlist screen appears.
9. Select Create New. The Create a new
playlist screen appears.
10. Enter the playlist name using your
remote or accept the default name.
11. When finished, Select Done. The new
playlist is created. The Added pop-
up appears.
12. Select Play to play now or OK to
play later.
To add files to a playlist, follow these
steps:
1. On the Samsung Link main screen,
select Videos, Photos, or Music on
the left side of the screen.
NYou must select the kind of
content that is already in the
playlist. For example, if you want
to add files to a music playlist,
you must select Music.
2. On the right side of the screen,
highlight and select the device that
has the files you want in the playlist.
Samsung Link displays the folders
and/or files on the device.
3. If Samsung Link is displaying
folders, highlight and select the
folder that contains the files you
want. If it is only displaying files, go
to Step 4.
4. Highlight a file, and then open the
Tools menu using your remote,
5. Highlight and select Add to Playlist.
6. Highlight and select a file you want
to add. A c mark appears in the
check box.
7. Repeat Step 6 to select additional
files.
NTo select all the files in the list,
select Select All. To cancel a
selection, select the file again.
8. When done, select Add. The Add to
Playlist screen appears.
9. Highlight and select the playlist you
want to add the files to. The Added
pop-up appears.
10. Select Play to play now or OK to
play later.
To delete one or more files in a Playlist,
follow these steps:
1. On the Samsung Link main screen,
select My List.
2. In the Playlist area at the bottom of
the screen, highlight the playlist you
want to edit.
3. Open the Tools menu using your
remote, and then select Edit Playlist.
The Edit Playlist screen appears.
4. Select a file you want to delete. A c
mark appears in the check box.
5. Repeat Step 4 to select additional
files.
NTo select all the files in the list,
select Select All. To cancel a
selection, select the file again.
6. When done, select Remove. A pop-
up message appears.
7. Select Yes. The selected file(s) has
been removed from the playlist.
Videos (In Samsung Link)
² Samsung Link Videos
You can play video files saved on USB
devices and/or your PC.
NFor more information about the
subtitle formats and codec formats,
refer to "Supported Subtitle and
Samsung Link file formats" in the
Other Information section.
Playing a Video
1. On the Samsung Link screen, select
Videos.
2. Highlight and select the device you
want to play.
3. If Samsung Link displays folders,
highlight and select the folder that
contains the file you want, then go
to Step 4. If Samsung Link displays
files only, go directly to Step 4.
4. Highlight and select the desired video
on the file list screen.
NIf you stop the video while it is
playing, you can play the video later
from the point where you stopped it.
NThe file name appears on the top
of the screen with the video's
playing time.
NIf video time information is
unknown, the playing time and
progress bar are not displayed.
NPress and hold the rewind or fast-
forward button for 3 seconds
while a video is playing to move
to the next video.
Video playback control buttons
/
Each time you select or using
your remote, the playback speed
change as follows. ( 1 / 2 / 3 /
1 / 2 / 3)
l r
Jump backward or forward from the
current position.
Pause the scene.
For Slow Motion: In pause mode,
select . Each time you select
using your remote, the playback
speed is reduced in this order
1/8 / 1/4 / 1/2. The playback
speed is displayed in the upper
left corner.
For Step Mode: In pause mode,
select . Each time you select
using your remote, a new frame
will be appear.
NTo return to normal speed
playback, select using your
remote.
NThe product does not play sound
in Step mode or Slow Motion.
NSlow Motion and Step Mode
operate only in the forward
direction.
Using the Tools menu with Videos
On the file list screen, you can use the
following options:
View
Lets you sort the file list by one of
four sort criteria.
Selection Play
Lets you select one or more files to
play immediately.
Send
Lets you send your video files to
your Web storage or other devices.
NIf you want to use this function,
you must log in to Smart Hub.
Login / Logout
You can login to or logout of your
Smart Hub account.
Add to Playlist
Lets you create playlists. When you
create playlists, you can play a series
of videos that you want to watch
easily and quickly.
Go to Playlist
Moves to the Playlist screen.
Information
Displays detailed information about
the selected file.
During playback, you can use the
following options on the Tools menu:
Go to Videos List
Stops the video and takes you to the
file list screen.
Play from the Beginning
You can restart a video file from the
beginning.
Scene Search
You can use the Scene Search
function during playback to view or
start a movie from the scene of your
choice.
NIf the index information in the
file is damaged or the file does
not support indexing, you will not
be able to use the Scene Search
function.
Title Search
You can move directly to another
title.
Time Search
You can search the video using the
left and right arrow keys or input
a playing time directly using your
remote.
Repeat Mode
You can play a single movie file or
all the files on the play list screen
repeatedly.
Picture Size
Lets you adjust the picture size to
your preference.
Picture Mode
You can change the Picture Mode.
Sound Mode
You can change the Sound Mode.
Audio Language
You can listen to the video in one
of the supported languages. The
function is enabled only when you
play stream-type files which support
multiple audio formats.
Subtitle
Lets you view a video with language
subtitles. You can select a specific
language if the subtitle file contains
multiple languages.
Subtitle Settings
Displays the Subtitle Settings. You
can select subtitle options such as
color and transparency.
Information
Displays detailed information about
the selected file.
NThe functions available on the Tools
menu at one time depend on the
characteristics of the video you
are playing. All functions are not
necessarily available for all videos.
Using the View function with Video Files
NWhen you use the Samsung Link
function with your Web storage
rather than a USB device, View is not
supported.
1. To sort files in the file lists, select }
using your remote. The View screen
appears.
2. Select a sort criteria.
Folder view
Displays the folders on the device
in alphabetical order. To view the
file names and thumbnails, select a
folder.
Title
Sorts and displays the files by title
in Symbol / Number / Alphabet /
Special order.
Latest Date
Sorts and displays files by the latest
create date.
Earliest Date
Sorts and displays files by the
earliest create date.
Send your video files
Lets you send your video files to your
Web storage or other devices.
NTo use Send, you must be logged in
to Smart Hub.
1. Highlight a file, open the Tools menu
using your remote, and then select
Send.
2. Select a video file you want to send.
A c mark appears in the check box
on the left.
3. Repeat Step 2 to select additional
videos.
NTo select all the files in the list,
select Select All. To cancel a
selection, select the file again.
4. When done, select Send. The Send
screen appears.
5. Choose the destination device to
send, and then select Send.
6. From these steps, please follow the
instructions on the screen.
Photos (In Samsung Link)
² Samsung Link Photos
Viewing a photo (or slide show)
NFor more information about the
supported image file formats, refer
to "Supported Subtitle and Samsung
Link file formats" in the Other
Information section.
1. On the Samsung Link screen, select
Photos.
2. On the right side of the screen,
select the device that has the photos
you want to view.
3. If Samsung Link displays folders,
select the folder that contains the
photos you want, then go to Step
4. If Samsung Link displays photo
thumbnails, go directly to Step 4.
4. To start a slide show, select using
your remote.
NTo view another photo manually,
press the l or r button.
NDuring the slide show, all files in
the file list are displayed in order,
starting from the file you selected.
NWhen viewing a photo file or slide
show, you can add background
music if you have music files on
same device.
NIf you select the wrong
background music, you cannot
change the music until the BGM
has finished loading.
Photo playback control buttons
/
Changes the slide show speed as
follows: Slow, Normal, Fast. The
speed is displayed in the upper right
of the screen.
l r
Go to the previous or next photo.
Return to the file list screen.
Start the slide show.
Pause the slide show.
Using the Tools menu with Photos
To use the Tools menu with photos,
you must first highlight a photo file
on the file list screen. After you have
highlighted a photo on the file list
screen, you can use the following
options in the Tools menu:
View
Lets you sort the file list by one of
four sort criteria.
Selection Play
Lets you select one or more files to
play immediately.
Send
Lets you send your photos with your
Family Story account or to photo-
related applications.
NTo use Send, you must be logged
in to Smart Hub.
Login / Logout
You can login to or logout of your
Smart Hub account.
Add to Playlist
Lets you create playlists. When you
create playlists, you can play a series
of photos easily and quickly.
Go to Playlist
Moves to the Playlist screen.
Information
Displays detailed information about
the selected file.
When playing a photo file, you can use
the following options:
Go to Photos List
Moves to the file list screen.
Start Slide Show / Stop Slide Show
You can start or stop a slide show.
Alternatively, select to start a slide
show or to stop a slide show using
your remote.
Slide Show Speed
You can select the slide show speed
during the slide show. Alternatively,
select or using your remote.
Background Music On / Background
Music Off
You can turn background music on
or off.
Background Music Setting
You can set and select background
music when watching a photo file or
slide show.
Picture Mode
You can change the Picture Mode.
Sound Mode
You can change the Sound Mode.
NAvailable only when Background
Music is set to on.
Zoom
You can zoom into images in full
screen mode.
Rotate
You can rotate images.
Information
Displays detailed information about
the selected file.
Using the View function with Photo Files
NWhen you use the Samsung Link
function with Family Story, Facebook,
or Picasa rather than a USB device,
View is not supported.
1. To sort files in the file lists, select }
using your remote. The View screen
appears.
2. Select a sort criteria.
Folder view
Displays the folders on the device
in alphabetical order. To view the
file names and thumbnails, select a
folder.
Title
Sorts and displays the files by title
in Symbol / Number / Alphabet /
Special order.
Latest Date
Sorts and displays files by the latest
create date.
Earliest Date
Sorts and displays files by the
earliest create date.
Monthly
Sorts and displays photo files by
month.
Send your photos
Lets you send your photos with your
Family Story account or send files to
other devices.
NTo use Send, you must be logged in
to Smart Hub.
An example: Sending with your Family
Story
1. To send photo files in the file list,
highlight a file, open the Tools menu
using your remote, and then select
Send.
2. Select a photo file you want to send.
A c mark appears in the check box
on the left.
3. Repeat Step 2 to select additional
tracks.
NTo select all the files in the list,
select Select All. To cancel a
selection, select the file again.
4. When done, select Send. The Send
screen appears.
5. Choose the destination device to
send to.
6. Choose the family group to share
with. A pop-up window appears.
7. Enter a message to send to the
family group you selected.
NIf the QWERTY keyboard screen is
displayed, you can use a keyboard
connected to the TV to enter the
message.
8. When done, select Send.
Music (In Samsung Link)
² Samsung Link Music
Playing Music
NFor more information about the
supported music file formats, refer
to "Supported Subtitle and Samsung
Link file formats" in the Other
Information section.
1. On the Samsung Link screen, select
Music.
2. Select the device that contains the
files you want to play.
3. If Samsung Link displays folders,
highlight and select the folder that
contains the music files you want,
then go to Step 4. If Samsung Link
displays only files, go directly to
Step 4.
4. Select the desired music file in the file
list or select using your remote.
NTo move to a previous page, select
b using your remote. To move to
the next page, select { using your
remote.
NWhen the music is playing, you
can fast forward or fast rewind
the music file by selecting or
using your remote.
NIf the sound is abnormal when you
play MP3 files, adjust the Equalizer
in the Sound menu. (An over-
modulated MP3 file may cause a
sound problem.)
NPress and hold the rewind or fast-
forward button for 3 seconds while a
music file is playing to move to the
next music file.
Music playback control buttons
During playback, you can use the
additional functions at the bottom right
of the screen.
Play / Pause
You can start or pause a music file.
Alternatively, you can select or
using your remote.
Repeat Mode
You can play one or all the music
files shown in the file list repeatedly.
Shuffle Mode
You can play the music files
sequentially or randomly.
Sound Mode
You can change the Sound Mode.
Using the Tools menu with Music
To use the Tools menu with Music,
you must first highlight a music file
on the file list screen. After you have
highlighted a music file on the file
list screen, you can use the following
options in the Tools menu:
View
You can sort the file list by one of
four sort criteria.
Selection Play
Lets you select one or more files to
play immediately.
Send
Lets you send your music files to
your Web storage or other devices.
NTo use Send, you must be logged
in to Smart Hub.
Login / Logout
You can login to or logout of your
Smart Hub account.
Add to Playlist
Lets you create playlists. When you
create playlists, you can play a group
of music files easily and quickly.
Go to Playlist
Moves to the Playlist screen.
Encoding
You can select an encoding format
from the encoding format list.
Information
Displays detailed information about
the selected file.
Using Selection Play with music files
1. Highlight a music file in the file list.
2. Open the Tools menu using your
remote, and then select Selection
Play.
3. Select the track you want to add. A
c mark appears in the check box on
the left.
4. Repeat Step 3 to select additional
tracks.
NTo select all the files in the list,
select Select All. To cancel a
selection, select the file again.
5. When done, select Play. The selected
music files will play.
Using View with Music files
NWhen you use the Samsung Link
function with your Web storage
rather than a USB device, View is not
supported.
1. To sort files in the file lists, select }
using your remote. The View screen
appears.
2. Select a sort criteria you want.
Folder view
Displays the folders on the device
in alphabetical order. To view the
file names and thumbnails, select a
folder.
Title
Sorts and displays the files by title
in Symbol / Number / Alphabet /
Special order.
Artist
Sorts the music files by artist in
alphabetical order.
Album
Sorts the music files by album in
alphabetical order.
Genre
Sorts music files by the genre.
Send your music files
Lets you send your music files to your
Web storage or other devices.
NTo use Send, you must be logged in
to Smart Hub.
1. To send music files in the file list,
highlight a music file, open the Tools
menu using your remote, and then
select Send.
2. Select a music file you want to send.
A c mark appears in the check box
on the left.
3. Repeat Step 2 to select additional
tracks.
NTo select all the files in the list,
select Select All. To cancel a
selection, select the file again.
4. When done, select Send. The Send
screen appears.
5. Choose the destination device to
send, and then select Send.
6. From these steps, please follow the
instructions on the screen.
Using the AllShare Function
² Samsung Link
You can play media contents including
videos, photos, and music saved on
your mobile phones or the other devices
(such as your PC) by controlling them
on the TV via the network.
For more information, visit
“link.samsung.com” or contact the
Samsung call center. Mobile devices
may need additional software
installation. For details, refer to each
device’s user’s guide.
NIf your Samsung TV connects to
a non-Samsung AllShare server, a
compatibility issue may occur during
video playback.
NBy connecting your Samsung TV to
a network via Samsung Link, you can
use Samsung’s original functions as
follows:
Playback of various video formats
(DivX, MP4, 3GPP, AVI, ASF, MKV,
etc.)
Video thumbnail feature
Bookmark function (to resume
video playback)
Auto-chaptering (scene
navigation)
Digital content management
Compatibility with various subtitle
formats (SRT, SMI, SUB, TXT,
TTXT)
Search with file names
And many others
AllShare Settings
Menu Network AllShare Settings
Shows a list of mobile phones or
connected devices which have been set
up to use AllShare Settings with this
TV.
NThe AllShare Settings function is
available in all devices which support
AllShare.
Allowed / Denied: Allows/Blocks the
devices.
Delete: Deletes the devices from the
list.
NThis function only deletes the name
of the device from the list. If the
deleted device is turned on or tries to
connect to the TV, it may appear on
the list again.
To play the media contents on the devices
connected to the TV using the AllShare
function, follow these steps:
1. On the Samsung Link screen, select
the kind of content you want to play:
Videos, Photos, Music.
2. On the right side of the screen,
select AllShare. The TV displays the
list of devices connected using the
AllShare function.
3. Select a device. Samsung Link
displays the accessible files or
folders on the device.
4. Select a file in the file list. The
selected file will play.
Playing media contents saved on AllShare
devices
1. Connect the mobile phone or other
devices which support Samsung Link
function.
2. Play media contents on the device. A
popup screen appears on the bottom
of your TV.
3. Select Allow to accept the connected
device. The media contents of the
device can now play on your TV.
NYou can find the allowed devices
on AllShare Settings.
NAn alarm window appears informing
you that media contents (videos,
photos, music) sent from a mobile
phone will be displayed on your
TV. The contents are played
automatically 3 seconds after the
alarm window appears.
If you close the alarm window
using your remote when the
alarm window appears, the media
contents are not played.
NThe first time a device accesses your
TV through the media function, a
warning pop up window appears.
Select Allow. This permits the phone
to access the TV freely and use the
Media function to play content.
NTo turn off media contents
transmissions from a mobile phone,
set the device to Denied in the
AllShare Settings.
NContents may not play on your TV
depending on their resolution and
format.
NSome buttons may not work
depending on the type of media
content.
NUsing the mobile device, you can
control the media play. For details,
refer to each device’s user’s guide.
Anynet+ (HDMI-CEC)
Menu System Anynet+ (HDMI-CEC)
Anynet+ is a function that enables
you to control all connected Samsung
devices that support Anynet+ with your
Samsung TV’s remote. The Anynet+
system can be used only with Samsung
devices that have the Anynet+ feature.
To be sure your Samsung device
has this feature, check if there is an
Anynet+ logo on it.
NYou can only control Anynet+
devices using the TV’s remote
control, not the buttons on the TV.
NThe TV remote control may not work
under certain conditions. If this
occurs, reselect the Anynet+ device.
NThe Anynet+ functions do not
operate with other manufacturers’
products.
NFor instructions explaining how to
connect Anynet+ external devices,
refer to the device’s user manual.
You must connect an Anynet+ device
using an HDMI cable. Some HDMI
cables may not support Anynet+
functions.
NAnynet+ works when the AV device
supporting Anynet+ is in the standby
or on status.
NAnynet+ supports up to 12 AV
devices in total. Note that you can
connect up to 3 devices of the same
type.
NHowever, you can connect only one
Anynet+ Home Theater. To connect
an Anynet+ Home Theater, connect
the Home Theater to the TV using an
HDMI cable then:
To hear sound from the Home
Theater’s front, left and right
speakers and the subwoofer only,
connect a digital optical cable
between the DIGITAL AUDIO OUT
(OPTICAL) port on your TV and the
Digital Audio Input on the Home
Theater.
To hear 5.1 channel audio, connect
HDMI cables to your Anynet+ DVD
player, satellite box, etc. Then,
connect the DIGITAL AUDIO OUT
(OPTICAL) port on your DVD
player, Satellite Box, etc. (i.e.
Anynet+ Device 1 or 2) directly to
the Home Theater, not the TV.
Anynet+ (HDMI-CEC) Menu
The Anynet+ menu changes depending
on the type and status of the Anynet+
devices connected to the TV.
View TV
Change from Anynet+ mode to TV
broadcast mode.
Device List
Shows the Anynet+ device list.
(device_name) Menu
Shows the menu of the connected
device. E.g. if a DVD player is
connected, the disc menu of the DVD
player will appear.
(device_name) Tools
Shows the Tools menu of the
connected device. E.g. if a DVD
player is connected, the Tools menu
of the DVD player will appear.
NDepending on the device, this
menu may not be available.
(device_name) Title Menu
Shows the title menu of the disc in
the connected device. E.g. If a DVD
player is connected, the title menu
of the movie in the DVD player will
appear.
NDepending on the device, this
menu may not be available.
Receiver
Sound is played through the receiver.
Setting up Anynet+ (HDMI-CEC)
Anynet+ (HDMI-CEC)
To use the Anynet+ Function, Anynet+
(HDMI-CEC) must be set to On.
NWhen the Anynet+ (HDMI-CEC)
function is disabled, all the Anynet+
related operations are deactivated
Auto Turn Off
Set an Anynet+ Device to turn off
automatically when the TV is turned
of f.
NIf Auto Turn Off is set to Yes,
running external devices will turn off
at the same time as the TV powers
of f.
NMay not be enabled depending on
the device.
Receiver
You can listen to sound through a
receiver (i.e. Home Theater) instead of
the TV Speaker.
Switching between Anynet+ Devices
1. Open the Tools menu using your
remote, and then select Anynet+
(HDMI-CEC).
2. Select Device List. The Device List
screen appears.
NIf you cannot find a device you
want, select Refresh to refresh the
list.
3. Select a device, and then wait until
the switch to the selected device is
completed.
NThe Device List menu appears
only when you set Anynet+
(HDMI-CEC) to On in the System
menu.
NSwitching to the selected device
may take up to 2 minutes. You
cannot cancel the switching
operation while switching is in
progress.
NIf you have selected an Anynet+
device using the Source function,
you cannot use the Anynet+
function. Make sure to switch
to an Anynet+ device using the
Device List function.
Listening through a Receiver
You can listen to sound through a
receiver (i.e. Home Theater) instead
of the TV speakers. To listen to sound
through a receiver, go to the Receiver
screen (System Anynet+ (HDMI-
CEC) Receiver). Then select Receiver
and set to On.
NIf your receiver supports audio only,
it may not appear in the device list.
NThe receiver will work when you
have properly connected the optical
in jack of the receiver to the DIGITAL
AUDIO OUT (OPTICAL) port of the TV.
NWhen the receiver (i.e. Home Theater)
is set to On, you can hear sound
output from the TV’s Optical jack.
When the TV is displaying a DTV
(air) signal, the TV will send out 5.1
channel sound to the receiver. When
the source is a digital component
such as a DVD player and it is
connected to the TV via HDMI, you
will hear only 2 channel sound from
the receiver.
Using the ARC function
for LED 6100 ― 7150 Series and PDP TV
You can listen to sound from the TV
through a receiver connected using
an HDMI cable without connecting
a separate optical cable. To listen to
sound through a receiver using the ARC
function, go to the Receiver screen
(System Anynet+ (HDMI-CEC)
Receiver). Then select Receiver and set
to On.
NTo use the ARC function, a receiver
which supports the HDMI-CEC and
ARC features must be connected to
the HDMI IN 2 (ARC) port.
NTo disable the ARC function,
set the Receiver to Off. Even if
the TV transmits the ARC signal
continuously, the receiver will be
blocked from receiving the signal.
Troubleshooting
NTo view a list of all troubleshooting
items, go to e-Manual home screen
(Menu Support e-Manual Other
Information) or press the E-MANUAL
button, and then search a desired item
by selecting a chapter.
Menu Support Self Diagnosis
Troubleshooting
If the TV seems to have a problem,
first review this list of possible
Other Information
problems and solution. Also review
the Troubleshooting Section in the
e-Manual. If none of the troubleshooting
tips apply, visit www.samsung.com/
support or call Samsung customer
Service at 1-800-SAMSUNG (1-800-
726-7864).
Flickering and Dimming
If your Samsung Television is flickering
or dimming sporadically, you may need
to disable some of its energy efficient
features such as the Eco Sensor or the
Energy Saving feature. Follow the steps
below with your remote to turn these
features off or on.
Energy Saving: System Eco
Solution Energy Saving
Eco Sensor: System Eco Solution
Eco Sensor
NEco Sensor is not available for LED
6200 series.
Component Connections / Screen Color
If you find that the color on your
Samsung television’s screen is not
correct or black and white, first run a
Self Diagnosis on the TV to make sure
there are no device issues.
Self Diagnosis : Support Self
Diagnosis Picture Test
If the problem does not appear in the
Picture test, make sure:
Your connections are all consistent.
For example, if you’ve used the AV In
jack on your TV, make sure you have
used the AV Out jack on your video
source.
You have connected your devices to
the correct jacks. For example, if you
use the Component jacks, labeled
Pb, Pr, and Y, to connect your TV and
video source, make sure you have
connected the blue Pb jack on the
video source to the blue Pb jack on
the TV, the red Pr jack on the video
source to the red Pr jack on the TV,
and the green Y jack on the source
to the green Y jack on the TV.
Screen Brightness
If you find that the colors on your
Samsung TV are correct but just a little
too dark or bright, try adjusting the
following settings in the Picture option
in the Main menu:
Backlight for LED TV / Cell Light
for PDP TV , Contrast, Brightness,
Sharpness, Color, Tint (G/R) and so
on. Go to Picture on the user Menu,
and then try adjusting the options
mentioned above.
Blur for LED 6100 - 7150 Series
If you find that there is a blur or
“ghostlike” appearance to the images
on your television’s screen, you might
be able to correct the blurring using
Auto Motion Plus.
Auto Motion Plus: Picture Picture
Options Auto Motion Plus
Unwanted Powering Off
If your Samsung TV appears to turn off
by itself, there may be an issue with
either your Timer settings or your Eco
friendly No Signal Power Off feature.
First make sure Sleep Timer is not
accidentally set. The Sleep Timer turns
off the TV automatically after a certain
period of time has passed.
Sleep Timer: System Time
Sleep Timer
If the Sleep Timer is not activated, you
may have engaged the No Signal Power
Off or Auto Power Off feature.
No Signal Power Off: System Eco
Solution No Signal Power Off
Auto Power Off: System Eco
Solution Auto Power Off
Trouble Powering On
Before you turn the TV on, find the red light
on the right or left bottom of your TV. Press
the Power on button on the TV or remote.
The light should blink about 5 times before
the TV turns on.
If you find that you are having trouble
powering on your Samsung television,
there are a number of things to check
before making a call to the service
department.
If you’re sure your power cord, remote
control, and PC are functioning
properly, you may be having a cable
issue. If you have a cable or satellite
box, your TV may appear to be off
because the cable or satellite box is not
outputting a signal. To test the signal
output of your cable or satellite box,
press the guide or info button on the
cable or satellite box remote control. If
the screen displays the guide or info
data, the problem is caused by the box.
Stand Assembly
If you have any trouble assembling the
stand first, review "Install the Stand" in
the paper manual.
Cannot Find a Channel
Re-run Setup (Go to System Setup)
or run Auto Program. (Go to Channel
Auto Program).
NWatch the troubleshooting videos at
www.samsung.com/spsn
Picture (Troubleshooting)
First, perform the Picture Test to see if
your TV is properly displaying the test
image (go to Support Self Diagnosis
Picture Test).
If the test image is properly displayed,
the poor picture may be caused by the
source or signal.
The TV image does not look as good as it
did in the store.
Store displays are all tuned to digital,
HD (high definition) channels.
If you have an analog cable/set top
box, upgrade to a digital set top box.
Use HDMI or Component cables to
deliver HD (high definition) picture
quality.
NMany HD channels are up scaled
from SD (Standard Definition)
contents. Look for a channel that is
broadcasting true HD content.
Cable/Satellite subscribers: Try HD
channels from the channel line up.
Air/Cable Antenna connection: Try
HD channels after performing an
Auto Program.
Adjust the Cable/Sat box video output
resolution to 1080i or 720p.
The picture is distorted: macro block error,
small block, dots, pixelization
The compression of video contents
may cause picture distortion especially
in fast moving pictures such as those
in sports and action movies.
A weak or bad quality signal can cause
picture distortion. This is not a TV
issue.
Mobile phones used close to the TV
(within 3.3 ft) may cause noise in the
picture on analog and digital channels.
Color is wrong or missing.
If you’re using a Component
connection, make sure the component
cables are connected to the correct
jacks. Incorrect or loose connections
may cause color problems or a blank
screen.
The color is poor or the picture is not bright
enough.
Adjust the Picture options in the TV
menu (go to Picture Mode / Color /
Brightness / Sharpness)
Adjust the Energy Saving option in the
TV menu (go to System Eco Solution
Energy Saving)
Try resetting the picture to view the
default picture settings (go to Picture
Reset Picture).
There is a dotted line on the edge of the
screen.
If the Picture Size is set to Screen Fit,
change it to 16:9.
Change the cable/satellite box
resolution.
The picture is black and white.
If you are using an AV composite input,
connect the video cable (yellow) to the
green Y Component jack on the TV.
When changing channels, the picture
freezes or is distorted or delayed.
If the TV is connected to a cable box,
try to reset the box. (Disconnect and
then reconnect the AC cord and wait
until the cable box reboots. It may take
up to 20 minutes.)
Set the output resolution of the cable
box to 1080i or 720p.
Sound (Troubleshooting)
First, perform the Sound Test to
determine if your TV audio is operating
properly. (Go to Support Self
Diagnosis Sound Test).
If the audio is OK, the sound problem
may caused by the source or signal.
There is no sound or the sound is too low
at maximum volume.
Check the volume setting of the device
(Cable/Sat Box, DVD, Blu-ray etc.)
connected to your TV.
The picture is good but there is no sound.
Set the Speaker Select option to TV
Speaker in the Sound menu.
If you are using an external device,
check the device’s audio output option.
(Ex. You may need to change your
cable box’s audio option to HDMI if
you have the box connected to your TV
using an HDMI cable.)
If you are using a DVI to HDMI cable, a
separate audio cable is required.
If your TV has a headphone jack, make
sure there is nothing plugged into it.
If the TV is connected to an external
device, reboot the connected device by
disconnecting, and then reconnecting
the device’s power cable.
The speakers are making an inappropriate
noise.
Check cable connections. Make sure
a video cable is not connected to an
audio input.
For antenna or cable connections, check
the signal information. A low signal
level may cause sound distortion.
Perform a Sound Test. (Support Self
Diagnosis Sound Test)
Antenna (Air / Cable) Connection
(Troubleshooting)
The TV is not receiving all channels.
Make sure the coaxial cable is
connected securely.
Run Auto Program to add available
channels to the channel list. Go to
Channel Auto Program then select
Cable and make sure to select the
correct Cable TV signal type. There are
3 options, STD, HRC and IRC. Most
cable systems use STD. If you are
using an antenna, select Antenna or Air
instead.
Verify the antenna is positioned
correctly.
No caption on digital channels.
Check the Caption Setup menu. Try
changing Caption Mode Service1 to
CC1.
Some channels may not have caption
data.
The picture is distorted: macro block error,
small block, dots, pixelization.
The compression of video contents
may cause picture distortion, especially
with fast moving pictures such as those
in sports and action movies.
A weak signal can cause picture
distortion. This is not a TV problem.
PC Connection (Troubleshooting)
A Mode Not Supported message appears.
Set your PC’s output resolution so it
matches a resolution supported by the
TV.
The video is OK but there is no audio.
If you are using an HDMI connection,
check the audio output setting on your
PC.
Network Connection (Troubleshooting)
The wireless network connection failed.
Make sure the TV is connected to a
wireless IP router or modem.
Software Update over the network fails.
Run Network Status in the Network
menu to confirm the connection.
If you already have the latest Software
(SW) version, SW upgrade will stop.
Others (Troubleshooting)
Purple/green rolling horizontal bars and
buzzing noise from the TV speakers with a
Component cable connection.
Remove the left and right audio
connections from the Set-Top box. If
the buzzing stops, this indicates that
the Set-Top box has a grounding issue.
Replace the Component video cables
with an HDMI connection.
The picture won’t display in full screen.
HD channels will have black bars
on either side of the screen when
displaying upscaled SD (4:3) contents.
Black bars will appear on the top and
bottom of the screen when you watch
movies that have aspect ratios different
from your TV.
Adjust the picture size options on your
external device or the TV to full screen.
A Mode Not Supported message appears.
Check the supported resolution of the
TV, and adjust the external device’s
output resolution accordingly. Refer
to the resolution settings in the User
manual.
Caption on the TV menu is grayed out.
You cannot select the Caption menu if
you have selected a source connected
to the TV via HDMI or Component.
To view captions, you must turn on the
external device's Caption function.
There is a plastic smell from the TV.
This smell is normal and will dissipate
in a short time.
The TV Signal Information is unavailable in
the Self Diagnosis menu.
This function is only available for
digital channels the TV receives from
an Antenna / RF /Coax connection.
The TV is tilted to the side.
Remove the base stand from the TV
and reassemble stand.
The channel menu is grayed out
(unavailable).
The Channel menu is only available
when you select the TV source.
Your settings are lost after 30 minutes or
every time the TV is turned off.
If the TV is in the Store Demo mode,
it will reset audio and picture settings
every 30 minutes. Change the settings
from Store Demo mode to Home Use
mode using the Setup procedure. Select
TV in Source using your remote, and
go to System Setup.
You have intermittent loss of audio or
video.
Check the cable connections and
reconnect them.
Loss of audio or video can be caused
by using overly rigid or thick cables.
Make sure the cables are flexible
enough for long term use. If mounting
the TV to a wall, we recommend using
cables with 90 degree connectors.
You see small particles when you look
closely at the edge of the frame of the TV.
This is part of the product’s design and
is not a defect.
The PIP menu is not available.
PIP functionality is only available when
you are using an HDMI or Component
source.
POP (TV’s internal banner ad) appears on
the screen.
Select Home Use under Setup mode.
For details, refer to the Setup Feature.
The Plasma TV is making a humming noise.
for PDP TV Plasma TVs typically make
a soft humming sound. This is normal.
It’s caused by the electrical charges
that are used to create the images on
the screen.
If the humming sound is loud, you may
have set the brightness on the TV too
high. Try setting the brightness lower.
You can also have loud humming if the
back of your Plasma TV is too close to
a wall or other hard surface. Also, try
rerouting your connection cables.
An improperly installed wall mount can
also create excessive noise.
Image Retention (Burn In) Issue.
for PDP TV To minimize the possibility
of screen burn, this unit is equipped
with Pixel Shift screen burn reduction
technology. Pixel Shift lets you set the
picture so it moves slightly up and
down (Vertical Line) and side to side
(Horizontal Dot). The regular, slight
movement of the picture reduces screen
burn in.
3D (Troubleshooting)
for LED 6500 ― 7150 Series and PDP TV
The 3D Active Glasses are not working
correctly
Make sure the glasses are turned on.
The 3D Active Glasses may not work
properly if there is any other 3D
product or electronic devices turned on
near the glasses or TV.
If there is a problem, keep other
electronic devices as far away as
possible from the 3D Active Glasses.
The 3D images don’t look quite right.
The ideal viewing distance is three
times or more the height of the screen.
We also recommend sitting with your
eyes level with the screen.
The batteries in the 3D glasses don’t last
Turn off 3D glasses while not using
them. If you leave 3D glasses on,
battery lifespan is shortened.
Anynet+ (HDMI-CEC) (Troubleshooting)
Anynet+ does not work.
Check if the device is an Anynet+
device. The Anynet+ system supports
Anynet+ devices only.
You can connect only one receiver
(home theater).
Check if the Anynet+ device power
cord is properly connected.
Check the Anynet+ device’s Video/
Audio/HDMI cable connections.
Check whether Anynet+ (HDMI-CEC) is
set to On in the Anynet+ setup menu.
Check whether the TV remote control is
in TV mode.
Check whether the remote control is
Anynet+ compatible.
Anynet+ doesn’t work in certain
situations. (Searching channels,
operating Smart Hub or Setup, etc.)
If you have removed and then
reconnected the HDMI cable, please
make sure to search devices again or
turn your TV off and on again.
I want to start Anynet+.
Check if the Anynet+ device is properly
connected to the TV and check if the
Anynet+ (HDMI-CEC) is set to On.
(System Anynet+ (HDMI-CEC))
Open the Tools menu using your
remote and then select Anynet+ (HDMI-
CEC). Then select a menu you want.
I want to exit Anynet+.
Select View TV in the Anynet+ menu.
Go to the Source screen using your
remote and select a non-Anynet+
device.
The message Connecting to Anynet+ device
... appears on the screen.
You cannot use the remote control
when you are configuring Anynet+ or
switching to a view mode.
Use the remote control after the TV has
completed Anynet+ configuration or
has finished switching to Anynet+.
The Anynet+ device does not play.
You cannot use the play function when
Setup is in progress.
The connected device is not displayed.
Check whether or not the device
supports Anynet+ functions.
Check whether or not the HDMI cable is
properly connected.
Check whether Anynet+ (HDMI-CEC) is
set to On. (System Anynet+ (HDMI-
CEC))
Search Anynet+ devices again.
Anynet+ requires an HDMI connection.
Make sure the device is connected to
your TV with an HDMI cable.
Some HDMI cables may not support
Anynet+ functions.
If the connection is terminated because
there has been a power failure or the
HDMI cable has been disconnected,
please repeat the device scan.
The TV sound is not output through the
receiver.
Connect the optical cable between TV
and the receiver.
for LED 6100 ― 7150 Series and PDP TV The
ARC function enables digital output of
sound using the HDMI IN 2(ARC) port
and can only be operated when the TV
is connected to an audio receiver that
supports the ARC function.
Samsung Link (Troubleshooting)
This file may not be playable properly.
This may appear because of the
high bit rate of the content. Content
generally will play but could experience
some playability issue.
Smart Hub (Troubleshooting)
Some application contents only appear in
English. How can I change the language?
The Application content language may
be different from the application user
interface language.
The ability to change the language
depends on the service provider.
Some application services do not work.
Check with the service provider.
Refer to the help website for application
service provider information.
When a network error occurs, I can only use
the Settings menu.
If network connection doesn’t work,
your service might be limited, as all
functions except the Settings menu
need to connect to the Internet.
1. To open Web Browser, select Web
Browser in Smart Hub. Unlike a PC,
the Web Browser may be displayed
differently.
2. The Web Browser is not compatible
with Java applications.
3. When you attempt to download a
file, and the file could not be saved,
an error message will appear.
4. Access may be blocked to some
websites or to web browsers
operated by certain businesses.
5. Playback of Flash video may be
restricted.
6. E-commerce, for purchasing
products online, is not supported.
7. Scrolling a web page that allows
only part (and not all) of the page
to be scrolled may cause corrupted
characters.
8. ActiveX is not supported.
9. Some options cannot be accessed
in Link Browsing mode. (To access
such options, switch to Pointer
Browsing mode.)
10. Some text may appear corrupted
because the number of supported
fonts is limited.
11. The response to a command on the
remote or the screen display may be
delayed temporarily if a web page is
currently loading.
12. The loading of a web page may
be delayed or stopped with some
operating systems.
13. Copy and Paste are not supported.
14. When writing emails or posting
messages, some functions (such as
changing the size or colors) may not
be supported.
15. The number of bookmarks and logs
that can be saved is limited.
16. The maximum number of windows
that can open at the same time
may vary depending on browsing
conditions or the TV model.
17. The web browsing speed depends on
the network conditions.
18. PIP will automatically be deactivated
if a video is played in the browser.
Videos may not resume playback
after PIP interruption and you may
need to refresh the page.
19. The Web Browser can play MP3
audio files only.
20. The function for importing or
exporting bookmarks is compatible
with bookmark files in a particular
file format only. (Compatible format:
Netscape-bookmarkfile-1)
21. When you import or export
bookmarks, the folder tree is not
included.
22. If you export the bookmark file to
an USB device connected to the
TV, the bookmark file will be saved
in “Samsung SmartTV Bookmark”
folder.
23. If the time is not set in the menu
(System Time Clock), the
history information may not be
saved.
24. Visited web site history is saved
in chronological order and will be
removed from the list by oldest page
accessed.
25. Some video or audio content may
not play during Flash playback
depending on the video/audio codec
supported.
26. A sudden change in the picture
brightness inside the video window
may affect the brightness of the
surrounding stationary picture. for
PDP TV
27. If you use QWERTY keyboard screen
when you use Web Browser with PIP
function, the PIP function turns off
automatically except inputting a URL
address.
Supported Subtitle and Samsung Link file
formats
Subtitle
External
MPEG-4 timed text (.ttxt)
SAMI (.smi)
SubRip (.srt)
SubViewer (.sub)
Micro DVD (.sub or .txt)
SubStation Alpha (.ssa)
Advanced SubStation Alpha (.ass)
Powerdivx (.psb)
Internal
Xsub
Container: AVI
SubStation Alpha
Container: MKV
Advanced SubStation Alpha
Container: MKV
SubRip
Container: MKV
MPEG-4 timed text
Container: MP4
Supported image resolutions
File Extension Type Resolution
*.jpeg JPG 15360 x 8640
*.png PNG 1920 x 1080
*.bmp BMP 1920 x 1080
*.mpo MPO 15360 x 8640
Supported music file formats
File Extension Type Codec Comments
*.mp3 MPEG MPEG1 Audio Layer 3
*.m4a
*.mpa
*.aac
MPEG4 AAC
*.flac FLAC FLAC
The Seek (jump) function is not
supported.
Supports up to 2 channel
*.ogg OGG Vorbis Supports up to 2 channel
*.wma WMA WMA
WMA 9, 10 Pro supports up to 5.1
channel and M2 profile (except LBR
mode of M0).
Video Codec
File
Extension Container Video Codec Resolution Frame rate
(fps)
Bit rate
(Mbps) Audio Codec
*.avi
*.mkv
*.asf
*.wmv
*.mp4
*.3gp
*.vro
*.mpg
*.mpeg
*.ts
*.tp
*.trp
*.mov
*.flv
*.vob
*.svi
*.m2ts
*.mts
*.divx
AVI
MKV
ASF
MP4
3GP
VRO
VOB
PS
TS
DIVX
3.11/4.x/5.x/6.x
1920 x
1080
6 – 30
30
AC3
LPCM
ADMPCM(IMA,
MS)
AAC
HE-AAC
WMA
DD+
MPEG(MP3)
DTS Core
G.711(A-Law,
µ-Law)
MPEG4 SP/ASP
H.264 BP/MP/HP
Motion JPEG 640 x 480 8
Window Media
Video v9
1920 x
1080 30
MPEG2
MPEG1
VP6 640 x 480 4
*.webm WebM VP8 1920 x
1080 6 – 30 8 Vorbis
Other Restrictions
NVideo content will not play, or not
play correctly, if there is an error in
the content or the container.
NSound or video may not work if the
contents have a standard bit rate/
frame rate above the compatible
Frame/sec listed in the table above.
NIf the Index Table is damaged,
the Seek (Jump) function is not
supported.
NWhen you play video over a network
connection, the video may not be
played smoothly.
NThe menu may take longer to appear
if the video’s bit rate exceeds
10Mbps.
NSome USB/digital camera devices
may not be compatible with the
player.
Video decoder
Supports up to H.264, Level 4.1.
H.264 FMO / ASO / RS, VC1 SP / MP /
AP L4 are not supported.
For all Video codecs except VP8, VP6:
Below 1280 x 720: 60 frame max
Above 1280 x 720: 30 frame max
GMC is not supported.
Supports only SVAF Top/Bottom and
Side by Side.
Audio decoder
WMA 9, 10 Pro supports up to 5.1
channel and M2 profile (except LBR
mode of M0).
WMA lossless audio is not supported.
If Vorbis is only in Webm container,
supports up to 2 channel.
Anti-theft Kensington Lock
A Kensington Lock is a device you can
use to physically fix your TV in place
when using it in a public place.
You wrap the Kensington Lock’s cable
around a large, immobile object and
1
2
<TV Rear>
<Optional>
then attach the lock to the Kensington
slot on the back of the TV.
The appearance and locking method
may differ from the illustration below
depending on the manufacturer.
Refer to the manual provided with
the Kensington Lock for additional
information on proper use. The
Kensington Lock is not supplied by
Samsung.
NPlease find a “K” icon on the rear of
the TV. The Kensington slot is beside
the “K” icon.
To lock the product, follow these steps:
1. Wrap the Kensington Lock cable
around a large, stationary object
such as desk or chair.
2. Slide the end of the cable with the
lock attached through the looped
end of the Kensington Lock cable.
3. Insert the locking device into the
Kensington slot on the product.
4. Lock the lock.
NThese are general instructions. For
exact instructions, see the User
manual supplied with the locking
device.
NThe locking device has to be
purchased separately.
NThe location of the Kensington slot
may be different depending on the
TV model.
Licenses
DivX Certified® to play DivX® video up to HD 1080p,
including premium content.
DivX®, DivX Certified® and associated logos are
trademarks of Rovi Corporation or its subsidiaries and are
used under license.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a
subsidiary of Rovi Corporation. This is an official DivX Certified® device that
plays DivX video. Visit divx.com for more information and software tools to
convert your files into DivX videos.
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be
registered in order to play purchased DivX Video-on-Demand (VOD) movies.
To obtain your registration code, locate the DivX VOD section in your device
setup menu. Go to vod.divx.com for more information on how to complete
your registration.
Covered by one or more of the following U.S. patents: 7,295,673; 7,460,668;
7,515,710; 7,519,274
TheaterSound HD, SRS and symbol are trademarks of
SRS Labs, Inc.
TheaterSound HD technology is incorporated under license
from SRS Labs, Inc.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
Manufactured under license under U.S. Patent Nos:
5,956,674; 5,974,380; 6,487,535 & other U.S. and worldwide
patents issued & pending. DTS, the Symbol, & DTS and
the Symbol together are registered trademarks & DTS
2.0+Digital Out is a trademark of DTS, Inc. Product includes
software. © DTS, Inc. All Rights Reserved.
for LED 6100, 6500 series and above, PDP 6500 series (US)
for LED 6500 series and above, PDP 6500 series (Canada, Mexico)
The terms HDMI and HDMI High-Definition Multimedia
Interface, and the HDMI Logo are trademarks or registered
trademarks of HDMI Licensing LLC in the United States and
other countries.
Open Source License Notice
In the case of using open source software, Open Source Licenses are available
on the product menu.
Open Source License Notice is written only English.

Navigation menu
