Samsung MFP SCX-6345N

Digital Copier | Network Printer | Colour Scanner | Network Fax

imagine an office solution capable

of the highest workflow demands

Take a look at this one-stop digital solution that can manage your

entire printing workflow. An MFP copier that can match the output of

large contract-based A3 copiers, and can also scan, print and fax.

Add in high performance features like duplex, high capacity paper

trays and simple one touch operations and you have a solution capa-

ble of the highest workflow demands. With Samsung SCX-6345N, it's

not that hard to imagine.

04 Quick Overview

06 Product Concept & Positioning

07 Product Configuration

08 Why A4 Copier?

09 Why SCX-6345N?

10 Because it is Effortless

12 Because it is Effective

17 Because it is Economical

18 Because it is Enhanced

22 Samsung Printers Service

24 Product Line-up

28 Options & Supplies

30 Specifications

Quick Overview

Quick Overview

Standard Features

• 43cpm Copier Based MFP

• 2 Beam Laser Scanning Unit and Electro Photography

• 50 Sheet Duplex-ADF

• Duplex Copy / Print

• Ethernet 10/100 base TX

• Half VGA size touch screen pannel

• JAM-Trouble Shooting Animation Guide

• FCOT Less than 6.0 seconds

• 256MB memory (max 384MB available)

• 45ppm digital scanning speed at 600dpi

• 1-999 multiple copying (number keypad)

• 550-sheet cassette & 100 by pass tray

• Digital copier features such as Scan-Once - Copy-Many / ID Copying / Legal Size / Standard Duplex /

Auto-fit / Clone / Poster / N-up (up to 16) / Margin Shift / Book copy / Auto Suppress / Outline erased /

Cover / Transparent film / Booklet

• Internal 40Gbyte HDD

• Colour CCD Scan Type

• Standard PCL6, PostScript3 Emulation

• Foreign Device Interface

Optional Features

• Maximum 2,180-sheet input paper capacity

• Finisher (50-sheet stapler, offset catching)

• Maximum 384Mbyte Memory Capacity

• Colour Fax (If receiver’s fax available)

• Duplex Transmission and 2-sided printing

• JBIG Data Compression Method

• Super G3 Facsimile

• Advanced Fax Communication such as Secure Fax / Delay Fax / Toll-Saving Fax /

Priority Fax / Batch TX / Fax Forwarding / ECM (Error Correction Mode)

• Network Scan Kit Enable Kit

Product Concept & Positioning

Concept

Samsung Digital Multi Function Printer | 4+ 5

Product Concept

The SCX-6345N has been developed to expand Samsung’s copier-based

Laser MFP Line-up with SCX-6322DN/6122FN. In addition, this model is

designed to make inroads into A3 Copier markets.

The SCX-6345N fits into the general office environments, whatever the

department. As it comes with 43 PPM speed, an embedded network

card, Scalable paper handling Capacity(Max 2180 Sheet capacity), Simple

Finisher with staple and collation(Optional), Wide Touch Screen Panel,

network scan function that supports various OS, and device manage-

ment tool without installation, it can be easily installed in

any network environment. In the past, the entire office

had to use one centralized device. The needs of the

office environment have been changing and today

people what efficient and easy-to-use networked

multi-function product functionality.

Customers today will no longer hesitate to buy new Laser

MFPs because they are now more efficient and offer high per-

formance with economic device maintenance cost.

The Samsung SCX-6345N has a lower TCO and an easy to use

interface that can replace centralized A3 copiers in the office.

Moreover, one centric A3 copier can be easily replaced by one or more

SCX-6345N.

Product Positioning

Product Positioning Strategies

A) Cost Efficiency Approach

This A) positioning is based on speed and allows a much improved approach on cost efficiency. In this case the SCX-6345N has

advantages in Total Cost of Ownership.

B) Performance Efficiency approach

On the other hand, when applying the B) positioning the performance-efficiency can be promoted thanks to its various features

including speed.

All prices in this part are US retail averages price (June 2006)

Type

Benefit

Better Cost

- Lower Purchasing Cost

- Better TCO

- Easy to Install & Maintenance

Better Performance

- Speed : Copy and Print

- Easy to Use : User Interface

A - Positioning B - Positioning

Product Configuration

Configuration

Standard Feature

Optional Feature

SCX-6345N

• Printing Resolution : 600 x 600 dpi ( 1200 dpi class )

• Internal HDD : 40 GB Capacity

• Wide Touch Screen Panel (640 x 240)

• 50-sheet Duplex Auto Document Feeder Standard

• Standard Paper Cassettes (250 sheets)

• USB 2.0 & Ethernet 10/100 base TX

(SCX-D6345A) 20K

Toner

(SCX-R6345A) 60K

Drum

1

12

2

Optional Finisher Short StandOptional Cassette

SCX-DSK10S

Tall Stand

SCX-DSK10TSCX-S6345A

SCX-FIN10S

FDI Kit

SCX-KIT11S

N/W Scan Kit Optional Fax KitOptional Fax Kit

SCX-FAX101

Memory

256 MB MemorySCX-FAX100

SCX-FIN10S

Staple Cartridge

SCX-6320NA

Samsung Mono Laser MFP SCX-6345N

Just unpack and

get to work in no time!

1 Optional Cassette

520 sheets

Max 3 Optional Cassette

520 sheets X 3

Trays can be

interchangeable

Atype

Btype

Samsung Digital Multi Function Printer | 6+ 7

Positioning Configuration

The SCX-6345N is a digital multifunctional system designed as a console unit. It is ready for external expansion with vertical additions of paper-handling options.

In the past customers always considered they needed an A3 Copier However,

according to a recent report *, just 2.35% of the total page volume printed is on

A3 paper. Given that the average office worker produces 8,636 pages a year,

just 202 pages are A3, which is less than a page a day. Because people are

moving towards scanning and printing original documents, which can be

scaled to fit the paper size available, the need for A3 output has declined. In

addition, a few years ago there was no software such as Microsoft Office,

Acrobat Reader and several types of Internet Browsers. Just think. When is

the last time you copied or printed on an A3 Copier?

Office space is also a big issue. In general, A3 centric copiers

occupy more office space. Typically, the footprint of a mono A3

capable device is much larger than that of an A4 device, 70%*

larger by volume on average. An A3 device takes up a lot

of space with its console. But an A4 device only

needs the corner of your desk or room.

In terms of TCO then generally,

the A3 copier is more expensive

to purchase and maintain than an

A4 MFP. The premium is between

100% and 220%* depending on the man-

ufacturer. Also the cost of a maintenance

kit for an A3 copier is 26%* higher than

that of an A4.

Finally, an A3 capable MFP device

consumes more operating power

and cost as the fuser unit is 41%

larger.

It doesn’t matter if an A4 page is being

printed or an A3 page because the whole

fuser unit is heated up.

*Source:

UK Research Study 2006

“NewField IT” Report

Samsung Mono Laser MFP SCX-6345N

Why A4 Copier?

Why A4 Copier?

Because it is Enhanced

Because it is Economical

Because it is Effortless

Why choose the Samsung SCX-6345N among the many other A4 MFPs? In addition to its economical features

and A4 copying/printing capability, this model offers simple user interface and easy administration tool, mean-

ing that users don’t have to study in great detail the User’s Manual and IT managers don’t have to spend too

much time monitoring the device. The SCX-6345N can drastically decrease the cost of maintenance.

Because it is Effective

Samsung Digital Multi Function Printer | 8+ 9

Why SCX-6345N?

Why SCX-6345N?

Effortless

Because it is Effortless

Keyboard Network Scan

Main Menu Copy Setting Admin Setting

to Use

• Wide Touch Screen/UI design

Samsung’s exclusive 640 x 240 wide LCD touch screen and 3-dimen-

tional UI design can help users make selection simple and reduces time

spent learning user manuals and educating new staff members.

• Paper Handling

Additional paper trays can be added to provide up to 2,180 sheets of

paper on line, reducing the need to frequently refill with paper .

Also print job rescheduling manages the printing jobs based on FIFO

(First In First Out) order. So when the previous printing job mismatches

the property of the paper the next job can continue to print so reducing

working time and running on the system.

50-sheet DADF

100-sheet Bypass Tray

520-sheet CST Tray

520-sheet 2

nd

CST

Tray (Option)

• Customer Installable CRU Design

Easy to install Drum & Toner Cartridge

Slide-in Finisher

Easy to upgrade

memory & option Kit

Slide-in

Fax module

Samsung Digital Multi Function Printer | 10 + 11

to Maintain

• Paper Jam

If and when a paper jam occurs the device indicates the problem area on

the user display so you can simply, open the tray door to remove.

Interchangeable

• Interchangeable Second Trays

Expand online paper supply by adding 3 extra trays to give up to 2,180

sheets. Installation of the trays is simple and can be assembled in any

sequence unlike some traditional copier devices .

e-mail

Toner Low

Click the button “Order”

OR

Reseller’s Homepage Reseller’s E-mail

Procurement

Manager

to Install

• Set, Consumables and Options

While general A3 copier takes up 3.5 hours to complete installation, it only

takes approximately less than 30 minutes from unpacking the box to plug-

in for the device to be ready to operate. With a modular build system it’s

easy to install consumables or upgrade options such as the finisher or

memory as they can be simply slotted into the main device .

• Automatic Toner Ordering System(i-ATOS)

This innovative automatic toner ordering system allows for easy and con-

venient ordering of supplies such as toner cartridges for your MFP. Once

the i-ATOS application is installed, instant alerts to your designated supplier

can be made by e-mail or a direct link to their homepage for ordering at the

click of a button.

30min.

SCX-6345N

General

Copier

3.5hrs.

VS.

A3 Machine A4 Machine

Effective

to Use

Powerful Copier

Not only does the SCX-6345N’s produce 43 copies per minute in A4 size but its duplex copy speed

is almost as fast ~ 40 copies per minute when using the in built Document Feeder [DADF]. Moreover,

the SCX-6345N performs nearly all the copy functions that are generally operated on A3 copiers.

• ID Copying

Copy both sides of an ID, driver’s license, or passport and print both on

one side of the paper. This unique feature makes it easy to quickly copy

an ID, even while the client is waiting, without having to feed the paper

back into the copier several times.

• Duplex Copying

Create customized documents and save paper with a built-in duplex

function. Easy one-touch buttons and four standard copy formats of 1:1,

1:2, 2:1 and 2:2 provide the convenience and flexibility you require.

• Legal Size Copying

In an international business world, one paper size is not sufficient. The

SCX-6345N copies A3, letter and legal-sized documents using the DADF

(Duplex Automatic Feeder).

Because it is Effective Powerful Copier

Front Copy Memory

+

=

Back Copy 2-sides-in-1

2

1

+=

Front Back Duplex Copying

Samsung Digital Multi Function Printer | 12 + 13

• Auto-fit Copy

The SCX-6345N makes it easy to copy and distribute documents and flyers

in any size. Copy any size original and print on letter, legal, A4 or any size paper

in the paper tray.

• Clone Copy

Clone any image without word processing or digital editing software. Now you can

quickly copy any image and print multiple copies of it on one sheet of paper.

• Poster Copy

Create beautiful posters from any size original. The Poster Copy feature copies

the original and prints it on several sheets of paper to form one large poster.

Powerful Copier

?

A4

A4

A4

A4

300%

Auto-fit Clone Copy Poster Copy

Original

Copy

Left Page

Right Page

Both Pages

• Margin Shift

Another convenient built-in feature that makes copying easier. The Margin

Shift feature allows you to move the image on the paper when you copy

it to create an even border all around or to increase the margin to accom-

modate binder holes.

• Auto Suppress

Copy an article from a newspaper or magazine and remove its back-

ground image using the Auto Suppress feature. The result is a clean copy

read to distribute.

• Booklet Copy

Turn any document into a booklet. The Booklet Copy feature reduces

each page by 50% and prints two pages side by side, creating a book-

let. The pages are even copied in the correct order so the booklet can be

folded, stapled and distributed.

• Outline Erase Copy

Produce clean copies without lines or shadows from binder holes and

staples. The Outline erase copy feature compensates for blemishes in the

original and produces a crisp, clear copy.

• Cover Copy

Creating handouts and manuals was never so easy. Now you can copy

a large document and include a cover printed on different paper.

The SCX-6345N will print the manual from one paper tray and the cover

from another.

• Transparent Film Copy

Preparing for a presentation and copying transparencies is simple and

convenient with the Transparent film copy feature. You can even copy

blank pages or additional paper copies between the OHP film copies.

8

9

Fold here.

Cassette 2

Cassette 1

Cover

• Book Copy

Copy books simply without repositioning the book for each page. This

feature allows you to copy both pages, just the left or just the right.

Effective

Because it is Effective

2 Up 4 Up 6 Up 9 Up 16 Up

Powerful Printer

At 43 prints per minute (simplex) and 40 prints per minute (duplex) your workloads cab be

completed efficiently. And with many standard printing functions built in you can expand

the range of your printing jobs.

• Duplex Printing

The duplex printing feature provides double-sided print. Taking full advan-

tage of the double-sided print capability definitely saves time and paper.

• N-up Printing

N-up enables printing of more than one page on a single sheet. 1-up, 2-

up, or as many as 16-up printing on the same page. This environmental-

ly-friendly feature saves paper and toner consumption.

+=

Front Back Duplex Copying

to Use

Powerful Printer

• Booklet Printing

Booklet Printing reduces the size of each page by 50% and prints two pages

per side, giving you the option of printing any document into a compact, con-

venient format. The pages are printed in the correct order so the document

can be folded and stapled to form a booklet.

• Poster Printing

Poster Printing automatically resizes your document so it prints across

multiple sheets, 4, 9, or 16 sheet of paper, which can be joined together

to form a big poster. (2x2, 3x3 and 4x4)

• Overlay

An overlay is text or images stored on the computer hard disk drive as a

special file format that can be printed on any document. Overlays are

often used to take the place of preprinted forms and letterhead paper.

Rather than using preprinted letterhead, you can create an overlay con-

taining the same information that is currently on your letterhead. To print

a letter with your company’s letterhead, you need only tell the machine to

print the letterhead overlay on your document.

• Watermark

Watermark provides the ability to print text, such as “Draft” or “Confidential”

in the background of every page.

8

9

Fold here.

Samsung Digital Multi Function Printer | 14 + 15

A4

2 X 2

3 X 3

+

+

INVOICE

BILL TO:

TERMS: AMT. DUE

Item

Units Rate / Ea. Amount

Thank You!

Samsung Electronics

Digital Printing Division

Samsung Electronics U.K. Ltd.

1000 Hillswood Drive, Chertsey

Surrey, KT16 0PS, UK

Laser Printer

Laser MFP

Inv Out: 11/4/2004 7:19:32 PM

10.00 $30.00 $300.00

5.00 $20.00 $100.00

$400.00

Net 30 Days

INVOICE

BILL TO:

TERMS: AMT. DUE

Item

Units Rate / Ea. Amount

Thank You!

+

+

+

Samsung Electronics

Digital Printing Division

A.Client

456 Front Street

Someplace, FL 67890

Web page design

Scanning

Inv Out: 11/4/2004 7:19:32 PM

10.00 $30.00 $300.00

5.00 $20.00 $100.00

$400.00

Net 30 Days

Samsung Electronics

Digital Printing Division

A.Client

456 Front Street

Someplace, FL 67890

Web page design

Scanning

Inv Out: 11/4/2004 7:19:32 PM

10.00 $30.00 $300.00

5.00 $20.00 $100.00

$400.00

Net 30 Days

INVOICE

BILL TO:

TERMS: AMT. DUE

Item

Units Rate / Ea. Amount

Thank You!

Samsung Electronics

Digital Printing Division

Samsung Electronics U.K. Ltd.

1000 Hillswood Drive, Chertsey

Surrey, KT16 0PS, UK

Laser Printer

Laser MFP

Inv Out: 11/4/2004 7:19:32 PM

10.00 $30.00 $300.00

5.00 $20.00 $100.00

$400.00

Net 30 Days

+

+

+

INVOICE

BILL TO:

TERMS: AMT. DUE

Item

Units Rate / Ea. Amount

Thank You!

+

Forms Stored

on Printer

Data from PC Printed Output

+

=

Scan to E-mail

TIFF/JPEG/PDF

Mail server

FTP server

Scan to FTP

TIFF/JPEG/PDF

Scan to SMB

TIFF/JPEG/PDF

SCX-6345N

Powerful Printer/ Scanner

• Scan-to-Folder (Network Scanner)

The SCX-6345N can share scanned images throughout the network by

converting them to a PDF, TIFF, or JPEG file. Then it sends the file direct-

ly to a server, PC or anywhere on the network.

• Vivid Colour Scanner

The SCX-6345N’s enhanced scanning resolution (4,800 x 4,800 dpi) and

colour CCD method can help you deal with the finest quality for your doc-

ument production.

Scan and distribute Documents anywhere on the network or through e-mail. In addition,

using LDAP (Lightweight Directory Access Protocol), you will always have access

to your e-mail address book.

to Use

Powerful Colour Scanner

Effective

Because it is Effective

• Colour Fax : Receive and send colour faxes. Sending

colour faxes is only supported if the receiver's fax also sup-

ports colour transfer.

• Super G3 Facsimile : The fast transfer rate of

33.6 Kbps will increase productivity and reduce

charges for long distance transfers.

• Secure Fax : With the Secure Fax feature, all incoming

faxes are held in memory until you access them with your

password. Now you can feel secure about confidential fax

communications.

• Delay Fax : Take advantage of nighttime discounts

and non-peak transmissions times with the Delay Fax

feature. Transmissions can be programmed up to a

month in advance.

• Toll-Saving Fax : The Toll-Saving Fax feature allows

you to preset the transmission time so that the faxes in queue

are sent at the least expensive time.

• ECM (Error Correction Mode) : The ECM

(Error Correction Mode) provides error-free transmis-

sion of faxes by monitoring noise and distortion and

resending the fax without errors.

• JBIG Data Compression Method : The SCX-

6345N supports JBIG (Joint Bi-level Image Expert Group) data

compression, the industry standard. JBIG provides 20-80% effi-

ciency in compression, allowing faster transmission of faxes with

images and photographs.

Send Fax Office

To another fax

To mail

One Click

With the optional Fax kit installed you can experience a variety of functions such as speed dial up to 200 numbers, group

dial up to 100 groups (max. location per 1 group is 200), duplex send and receive, Fax-Email and etc. And because of

the Duplex function then received faxes can be printed out double sided to reduce your operating costs.

to Use

Powerful Fax (Option)

• Duplex Transmission

Using the Duplex Automatic Document Feeder (DADF), you can fax two-sided

copies and transmit without reinserting the paper. In addition, using Duplex

Printing mode, you can print out received faxes on both sides of the paper.

• Priority Fax

Faxes are transmitted in order of reservation. But when you have an

urgent fax to send, the Priority Fax feature allows you to move the prior-

ity fax to the beginning of the queue.

• Batch TX

Save time and dialing with the Batch TX feature. This convenient feature

groups all faxes going to the same location and send them in one batch.

• Fax Forwarding

Incoming faxes can be redirected to a dedicated fax number or an e-mail

account so you can securely retrieve your faxes without going to the fax

machine.

• Available when optional network kit is installed

+=

Front Back Duplex Transmission

Powerful Fax (Option)

Samsung Digital Multi Function Printer | 16 +17

5K

TCO

AMPV

10K 20K

Samsung

SCX6345N

A3 21 ppm

A3 35 ppm

A3 45 ppm

One Click

Save Toner & Energy

Economical

Because it is Economical

to Reduce

• TCO (Total Cost of Ownership)

When compared to the TCO of general A3 office copiers the Samsung

SCX-6345N’s TCO can result in one of the lowest running costs in its

class at an average of 10,000 prints per month[AMPV]

*Source: ❶ Set CPP: based on the vender’s websites

❷ Consumables CPP: based on the vender’s websites

❸PM Ports CPP ❹ Service cost CPP

• Space

SCX-6345N’s economical design takes up to 75% less space in your

office than general A3 copiers so you have more room around you.

• Toner and Energy

With the embedded “Toner Save Mode” in the Printer driver, users can

save toner by up to 30%. This is ideal for printing draft documents and

reports without seeing a dramatic reduction in print quality.

75% Less Space

to Manage

• Expanded Printing

- Capabilities with Hard Disk Solution

Because it is Enhanced

Enhanced

- Store Job : The Store Job feature allows you to store

documents in the printer and print them multiple times

without having to resend from the computer each time.

Files can be stored in a private folder or a shared folder.

- Delay Print : Delay Print stores print jobs until the

scheduled print time. Scheduling large print jobs to

non-peak times reduces strain on the printer and

maximizes printing efficiency.

- Confidential Print : Save time and paper with the Proof

Print feature. Print one copy to proof before you run the

entire print job. If errors are found, the entire file can be

deleted from the print queue to be edited and reprinted.

- Proof Print : Save time and paper with the Proof

Print feature. Print one copy to proof before you run

the entire print job. If errors are found, the entire file

can be deleted from the print queue to be edited

and reprinted.

Proof

- Collate Print : Collate Print determines the more effi-

cient way to print and collate the print job. If a hard drive

is installed, Collate Print is even more efficient because the

file is stored on the printer, reducing network traffic.

B

A

B

A

SCX-6345N

Other Vendor

• Discovery

• Device Management

• Status & Alerts

• Diagnostics

• Report Generation

Information

Control

SyncThruTM Web Admin Service

Samsung Digital Multi Function Printer | 18 + 19

SMTP Server

FTP Server

POP3 Server User PC with E-mail Client

User PC with Netscan Manager

Scan to E-mail

Scan to Network

Scan to FTP

Scan to SMB

SMB Server

• Scan to Anywhere

The SCX-6345N supports efficient distribution of scanned documents by

allowing you to send them through email, FTP, SMB, Client and USB.

• New Scan Management with LDAP

Scan to E-mail provides address book function using LDAP server. The LDAP

(Lightweight Directory Access Protocol) is a networking protocol for querying

and modifying directory services running over TCP/IP. If the user company has

adopted this, the most up-to-date e-mail address book will be always avail-

able. PDF, JPEG and TIFF file formats are supported for digital scanning and

settings for SMB, FTP and LDAP server should be executed through

SyncThru™ Web Service.

• SyncThruTM Web Admin Service

SyncThru™ Web Admin service allows IT managers to easily manage

and monitor all printers on the network. The powerful feature permits job

accounting, usage metering, authentication, storage management,

remote driver installation and modification settings.

Device

Discovery

Fleet Management

for Multiple

Network Printers

Email

Notification

Modify

Admin

Settings

Report Generation

Supported by

Plug-in

• SyncThruTM Web Service

It provides administrators with the ability to change network and individual

Printer settings, upgrade firmware and view network printer / MFP status.

Use Popular

Web Browser

without Installing

Extra Software

Remote

Configuration

and Monitoring

of Network Printer

Email

Notification

Modify

Admin

Settings

Report Generation

Supported by

Plug-in

• SmarThruTM Office

Document management and editing features are greatly enhanced for easy

and convenient use with Samsung MFP in offices with complicated net-

works and a variety of equipment. Also network scan is provided as default.

• SmarThruTM Workflow (Option)

SmarThru™ Workflow streamlines the document capture-process-route

system enabling easy document management.

This additional software is provided with the Samsung Network Scan Kit.

Store SearchEdit Binding Fax e-mail network OCR Application

Control

LAN

Status

Embedded

SyncThru Web Service

Keyboard Network Scan

Main Menu Copy Setting Admin Setting

What is Samsung Dr. Printer?

Samsung Dr.Printer (www.samsungdp.com)

• Dr. Printer is your online assistant for diagnosing any

problems with your Samsung printer.

• You can trust Dr. Printer to guide you through the steps

to solve printing problems and software updates.

Benefits of Samsung Dr. Printer

• Automatic Driver Installation/Reinstallation

• Update to the latest driver

• Automatic Driver Diagnosis

- Set a default printer

- Change a printer port

- Check a connection status of printer

- Delete pending jobs

- Set online status

- Diagnosis on network printer

• Easy to use through network

Be sure to wait 30 minutes

after turning off the printer,

and confirm that it is cool

before continuing.

Hold the blue knob, and slowly pull

the fusing unit out until the whole of

the green handle is visible.

Place the freen handle in the

fusing unit. Hold the new fus-

ing unit with both hands, and

keep the unit horizontal.

Open the bypass tray and

then open the duplex unit by

pushing the catch upwards.

There is an arrow sticker in

the bottom right side of the

cover, which is pointing to the

shaft.

While pressing down on the

corner of the transfer unit

indicated by the arrow, return

the green lever to its original

position to lock the transfer

unit in place.

Replacing the Fusing Unit

Replacing the Transfer Unit

Exclusive Service

Service Maintenance Kit

12 3

1 2

SCX-V6345A/SEE

Fuser Unit (JC96-03724A)

- Qty : 1

- Life Time : 200,000

Pickup Roller (JC97-02259A)

- Qty : 3

- Life Time : 200,000

SCX-V6345B/SEE

Transfer Roller (JC97-02287A)

- Qty : 5

- Life Time : 100,000

Maintenance Kit - A Type

Maintenance Kit - B Type

3

Samsung Printers Service

Service

1

1

2

2

Service Contact Point

SEA

STA

SECA

SEM

SEDA

SELA

SAMCOL

SAPL

SEAU

SAVINA

TSE

SEIN

SME

SEPCO

SIEL

SEUK

SEF

SEG

SESA

SEP

SEI

SEBN

SENA

SEPOL

SEH

SEAG

SBSC

SEHK

SET

SRSC

SEU

LATVIA

SGE

SSA

SJC

1-800-Samsung (7267864)

1-800-Samsung (7267864)

1-800-Samsung (7267864)

1-800-Samsung (7267864)

4004 0000

0800 124 421

Panama : 800-7267

Costa Rica : 0-800-507-7267

Ecuador : 1-800-10-7267

El Salvador : 800-6225

Guatemala : 1-800-299-0013

Jamaica : 1-800-234-7267

Puerto Rico : 1-800-682-3180

Republic Dominicana : 1-800-751-2676

Trinidad y Tobago : 1-800-SAMSUNG (7267864)

Venezuela : 0-800-100-5303

Argentina : 0-800-333-3733

Chile : 800-SAMSUNG (7267864)

01 8000 112 112

1 800-SAMSUNG (7267864)

1 300 362 603

1 800 588 889

1 800 293232

02 689 3232 (through mobile phone user)

800-112-8888 (Toll-Free)

21-791-77888

1-800-88-9999

1800-10-SAMSUNG (7267864)

3030-8282

1800 110011 (Toll-Free)

0870 242 0303

0825-08-65-65

(3260 + "SAMSUNG" Voice Recognition)

01805 121213

902 10 11 30

808 200 128

199 153 153

800048989 (TIM HHP)

800314278 (Samsung HHP)

Netherlands : (0) 900 20 200 88

Belgium : (0) 2 201 2418

Luxembourg : (0) 2 261 03710

Sweden : 08 585 36787

Denmark : 38 322 887

Norway : 231 627 22

Finland : 09 69379 554

0 801 801 881

Hungary : 06 40 985 985 (Local free)

Czech : 844 00 844

Slovakia : 0850 123 989

Austria : 800-SAMSUNG (7267864)

02233 701117 (for HHP)

Switzerland : 800-SAMSUNG (7267864)

800-810-5858

2862 6001

0800-329-999

Russia : 8-800-200-0-400

Kazahstan : 8 800 080 11 88

Uzbekistan : 140-1234

8-800-502-0000

800-7267

800 SAMSUNG (7267864)

0860-SAMSUNG (7267864)

0120-327-527

09:00 ~ 21:00 (Mon-Sun)

09:00 ~ 24:00 (Mon-Sun) - DTV

09:00 ~ 21:00 (Mon-Sun)

08:30 ~ 17:00 (Mon-Fri)

08:30 ~ 19:00 (Mon-Fri), 09:00 ~ 14:00 (Sat)

08:00 ~ 22:00 (Mon-Sat)

07:00 ~ 19:00 (Mon-Fri), 08:00 ~ 13:00 (Sat)

06:00 ~ 18:00 (Mon-Fri), 07:00 ~ 12:00 (Sat)

07:00 ~ 19:00 (Mon-Fri), 08:00 ~ 13:00 (Sat)

06:00 ~ 18:00 (Mon-Fri), 07:00 ~ 12:00 (Sat)

06:00 ~ 18:00 (Mon-Fri), 07:00 ~ 12:00 (Sat)

07:00 ~ 19:00 (Mon-Fri), 08:00 ~ 13:00 (Sat)

08:00 ~ 20:00 (Mon-Fri), 09:00 ~ 14:00 (Sat)

08:00 ~ 20:00 (Mon-Fri), 09:00 ~ 14:00 (Sat)

08:00 ~ 20:00 (Mon-Fri), 09:00 ~ 14:00 (Sat)

08:00 ~ 20:00 (Mon-Fri), 09:00 ~ 14:00 (Sat)

09:00 ~ 18:00 (Mon-Fri)

09:00 ~ 18:00 (Mon-Fri)

07:00 ~ 22:00 (Mon-Sat), 08:00 ~ 20:00 (Sun)

08:30 ~ 5:30pm (Mon-Fri), 8.30 ~ 12.30pm (Sat)

08:30 ~ 17:00 (Mon-Fri)

08:00 ~ 17:00 (Mon-Fri)

08:00 ~ 18:00 (Mon-Fri), 09:00 ~ 17:00 (Sat)

08:00 ~ 19:00 (Mon-Fri), 08:00 ~ 17:00 (Sat)

10:00 ~ 15:00 (Sun)

09:00 ~ 18:00 (Mon-Fri), 09:00 ~ 13:00 (Sat)

08:30 ~ 8:30 (Mon-Sun)

09:00 ~ 20:00 (Mon-Sat)

09:00 ~ 18:00 (Mon-Fri)

09:00 ~ 13:00 (Sat)

09:00 ~ 18:00 (Mon-Fri)

08:00 ~ 18:00 (Mon-Fri)

09:00 ~ 23:00 (Sat-Sun)

08:00 ~ 23:00 (Mon-Sun) - HHP

09:00 ~ 21:00 (Mon-Fri)

09:00 ~ 18:00 (Mon-Fri)

09:00 ~ 18:00 (Mon-Fri)

08:00 ~ 18:00 (Mon-Fri)

07:00 ~ 17:00 (Mon-Fri)

09:00 ~ 18:00 (Mon-Fri)

08:00 ~ 18:00 (Mon-Fri)

08:00 ~ 18:00 (Mon-Fri)

08:00 ~ 22:00 (Mon-Fri)

08:00 ~ 18:00 (Sat-Sun)

08:30 ~ 18:00 (Mon-Sat)

08:30 ~ 21:00 (Mon-Fri)

08:00 ~ 20:00 (Mon-Fri)

09:00 ~ 17:00 (Sat)

09:00 ~ 20:00 (Mon-Fri)

09:00 ~ 17:00 (Mon-Fri)

08:30 ~ 17:30 (Sat-Wed)

08:30 ~ 13:00 (Thur)

08:15 ~ 16:45 (Mon-Fri)

09:00 ~ 17:00 (Mon-Fri)

Region Sub. Contact Center # Operation Hours

North America

South East Asia

W.E. Asia

Europe

China

Middle East Asia

SJC

CIS

M & S America

Samsung Digital Multi Function Printer | 20 + 21

• Up to 43 ppm Print / Copy Speed in A4

• Printing Resolution : 600 x 600 dpi ( 1200 dpi class )

• FPOT : 8 Seconds (from Stand by)

• Scalable Capacity : Max 2180 Sheet capacity

(Including 3 more optional CST)

• Internal HDD : 40 GB Capacity

• Simple Finisher : Single staple type (50 sheets), Offset Catching

• High Product Life Cycle : 1,000 K or 5 years

(which ever occurs first)

• Wide Touch Screen Panel (640 x 240)

• Customer Installable CRU Design

• 50-sheet Duplex Auto Document Feeder Standard

• Direct Scan to e-mail & Network Scan (By Touch Screen Panel)

• High Toner Yield : 20K, Drum Yield : 60K

SCX-6345N

USB 2.0

Product Line-up

Product Line-up

An easy to use graphic user interface

with touch screen panel makes config-

uration and troubleshooting simple.

Users can easily select printing, scan-

ning and faxing with one-touch buttons

and a touch screen keyboard, even

without extensive training. And mainte-

nance and troubleshooting are so easy

you won’t have to send in an adminis-

trator to change toner or manage jams.

Unique Design and

Easy Graphic

User Interface

• 50-sheet Duplex Auto Document Feeder Standard

• Up to 22 ppm Print / Copy Speed in A4

(23ppm in Letter)

• Up to 1,200 dpi Effective Output

• Direct Scan to e-mail & Network Scan

(By embeded Qwerty board)

• 33.6 Kbps Super G3 Fax Modem

• Total 650 sheet Paper Input Capacity

(550-sheet Cassette Tray, 100-sheet MP Tray)

• Advanced Digital Editing Copy

- 2-sides-in-1 (ID copy), Poster, Auto-fit,

Clone, Auto Margin Shift, Book Copy

• 30% Toner Save Button

SCX-6322DN

Samsung Digital Multi Function Printer | 22 + 23

• 50-sheet Duplex Auto Document Feeder Standard

• Up to 20 ppm Print / Copy Speed

• 1,200 dpi Class Printing Resolution

• Direct Scan to e-mail & Network Scan,

enabled by Optional Network Kit

• 33.6 Kbps Super G3 Fax Modem

• Standard 650 sheet Total Paper Input Capacity

• Advanced Digital Editing Copy

- 2-sides-in-1 (ID copy), Poster, Auto-fit, Clone,

Auto Margin Shift, Book Copy

• 40% Toner Save Button

• Status Notification by LED Indicator

SCX-6320F

<< SCX-6345N Product

Product Line-up

Product Line-up

Digital Duplex Copier

High Quality Laser Printer

Smart Colour Scanner

Intelligent High-Speed FAX

SCX-6320F

• Breakthrough Direct USB Memory Connectivity

- Direct Scan-to-USB memory (JPEG, BMP, PDF, TIFF)

- USB Memory Printing (PDF, JPEG, PRN, BMP, TIFF)

• Up to 28 ppm Quick Printing / 28 ppm Quick Copying

• Various Digital Copy Features

- 2-sides-in-1 (ID copy), 2-up, 4-up, Collation, Auto-fit,

Clone, Poster, Zoom, Multi copy

• Colour Scanning at up to 4,800 x 4,800 dpi

high resolution

• Embedded Network

• 30 One-touch Dial / 240 Speed Dial

• 250-sheet Cassette tray plus

• 50-sheet Multi-purpose Tray with a large

50-sheet ADF + Optional Second Cassette

• High-speed USB 2.0 Interface

• High yield 8,000 page toner cartridge

SCX-5530FN

• Breakthrough Direct USB Memory Connectivity

- Direct Scan-to-USB memory, Direct USB Memory Printing

- Front USB Slot for Prompt Connection

• Fast 20 ppm Print / Copy Speed

• Various Copy Editing Functions

- 2-sides-in-1 (ID copy), 2-up, 4-up, Collation,

Auto-fit, Clone, Poster, Zoom, Multi copy

• Flatbed Colour Scanning at up to 4,800 x 4,800 dpi high resolution

• Embedded Network

• Quick 3 second Tx speed with 33.6 Kbps modem,

43 Hour Battery Back-up

• 40 One-touch Dial / 200 Speed Dial

• 250-sheet Cassette tray plus

50-sheet Multi-purpose Tray with a large 50-sheet ADF

• High-speed USB 2.0 Interface

• High yield 5,000 page toner cartridge

• Economical Saving Feature

- Toner Save button - Toll Save button

SCX-4720FN

USB 2.0

USB 2.0

Samsung Digital Multi Function Printer | 24 + 25

All in one Digital Multi Function Printer | 7+ 26

SCX-6345N SCX-6322DN SCX-6320F SCX-5530FN SCX-4720FN

16MB

32MB

64MB

128MB

256MB

PostScript

Second Cassette

Mechanical Counter

Network Kit

Cabinet Stand

Fax Kit

Short Stand

Tall Stand

Finisher

N/W Scan Kit

SmarThruTM Workflow

Staple Cartridge

-

-

-

-

-

-

OO( SCX-S6122A )

-

-

OO( SCX-6320G5 )

-

-

-

-

-

-

-

--

-

-

-

-

OO( SCX-6320PA )

OO( SCX-6320S5 )

OO( SCX-6320X1 )

OO( SCX-6320NA )

OO( SCX-6320G5 )

-

-

-

-

-

-

-

OO( ML-00MA )

OO( ML-00MB )

OO( ML-00MC )

OO( ML-00MD )

OO( ML-MEM140 )

-

OO( SCX-S5530A )

-

-

--

-

-

-

-

-

-

-

OO( ML-00MA )

OO( ML-00MB )

OO( ML-00MC )

OO( ML-00MD )

--

-

OO( SCX-4720S3 )

-

-

--

-

-

-

-

-

-

-

Memory PostScript

Second Cassette Finisher

Cabinet Stand Fax Kit

N/W Scan Kit

SmarThruTM Workflow

Staple Cartridge

-

-

-

-

OO( ML-MEM140 )

-

OO( SCX-S6345A )

-

-

-

OO( SCX-FAX100 / FAX101 )

OO( SCX-DSK10S )

OO( SCX-DSK10T )

OO( SCX-DSK10T )

OO( SCX-FIN10S )

OO( SCX-KIT11S )

OO( SCX-STP000 )

SCX-6320S5 SCX-S6122A SCX-4720S3 SCX-DSK10TSCX-S5530ASCX-S6345A

SCX-KIT11S

Mechanical Counter

SCX-6320X1SCX-STP000SCX-FIN10S

Network Kit

SCX-6320NA

SCX-FAX101SCX-FAX100

SCX-6320G5

Short Stand

SCX-DSK10S

Tall Stand

SCX-DSK10T

256MB : ML-MEM140 SCX-6320PA16MB : ML-00MA 32MB : ML-00MB 64MB : ML-00MC 128MB : ML-00MD

Options & Supplies

Options & Supplies

Memory

Samsung Digital Multi Function Printer | 26 + 27

SCX-4720FN

Yield > 3,000 pages @ ISO/IEC 19752 / 5,000 pages @ ISO/IEC 19752

Compatibility > SCX-4520 / 4720F / 4720FN

SCX-4720D3 (Toner) SCX-4720D5 (Toner)

SCX-D5530A (Toner) SCX-D5530B (Toner)

SCX-6320D8 (Toner) SCX-6320R2 (Drum)

SCX-6320D8 (Toner) SCX-6320R2 (Drum)

SCX-D6345A (Toner) SCX-R6345A (Drum)

SCX-5530FN

Yield > 3,000 pages @ ISO/IEC 19752 / 5,000 pages @ ISO/IEC 19752

Compatibility > SCX-4520 / 4720F / 4720FN

SCX-6320F

Yield > 3,000 pages @ ISO/IEC 19752 / 5,000 pages @ ISO/IEC 19752

Compatibility > SCX-4520 / 4720F / 4720FN

SCX-6322DN

Yield > 3,000 pages @ ISO/IEC 19752 / 5,000 pages @ ISO/IEC 19752

Compatibility > SCX-4520 / 4720F / 4720FN

SCX-6345N

Yield > 20,000 pages @ ISO/IEC 19752 (SCX-D6345A) / 60,000 pages @ ISO/IEC 19752 (SCX-R6345A)

Compatibility > SCX-6345N, SCX-6355N

All in one Digital Multi Function Printer | 7+ 28

Options & Supplies

Options & Supplies

Hardwares

Consumables

CLP-500/500N/

550/550N

CLP-510/510N

CLP-600/600N/

CLP-650/650N/

CLP-300/300N

CLX-3160N/3160FN

ML-1010

ML-

1210/1220M/

1250

ML-1430

ML-4500

ML-4600

ML-1520

ML-1610/1615

ML-1500/1510

ML-1710/1710P/

1750

ML-1740

ML-2010

2010P/2015

ML-2510

2570/2571N

ML-

6040/6060/

6060N/6060S

ML-1440/1450/

1451N

ML-1650/1650P/

1650S/1651N

ML-2150/2151N/

2152W

ML-

2250/2251N/

2251NP/2252W

ML-2550/2551N/

2552W

ML-7300/7300N

ML-3050/3051N/

3051ND

ML-3550/3550N

ML-3560/3561N

3561ND

ML-4550/4551N/

4551ND

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

Mono

LBP

•••••••

•••••••

••••••

••••••

••••••

CLP-500D7K Yield@5% : 7,000 pages

CLP-500D5C Yield@5% : 5,000 pages

CLP-500D5M Yield@5% : 5,000 pages

CLP-500D5Y Yield@5% : 5,000 pages

CLP-500RT B/W : 50,000 / Colour : 12,500

CLP-500RB B/W : 50,000 / Colour : 12,500

CLP-500WB B/W : 12,000 / Colour : 3,000

CLP-510D7K/CLP-510D3K Yield@5%:7,000 / 3,000 page

CLP-510D5C/CLP-510D2C Yield@5%:5,000 / 2,000 page

CLP-510D5M/CLP-510D2M Yield@5%:5,000 / 2,000 page

CLP-510D5Y/CLP-510D2Y Yield@5%:5,000 / 2,000 page

CLP-510RB B/W : 50,000 / Colour : 12,500

CLP-510RT B/W : 50,000 / Colour : 12,500

CLP-K600A

Yield@5% Coverage 4,000 pages

CLP-C600A

Yield@5% Coverage 4,000 pages

CLP-M600A

Yield@5% Coverage 4,000 pages

CLP-Y600A

Yield@5% Coverage 4,000 pages

CLP-T600A

Yield@5% Coverage 35,000 pages

CLP-F600A 110V 50,000 pages

CLP-F600B 220V 50,000 pages

CLP-F650A 110V/220V 50,000 pages

CLP-K300A Yield@5% : 2,000 pages

CLP-C300A Yield@5% :1,000 pages

CLP-M300A Yield@5% :1,000 pages

CLP-Y300A Yield@5% :1,000 pages

CLP-R300A B/W : 20,000 / Colour :12,500

CLP-W300A B/W : 5,000 / Colour :1,250

ML-1210D3 Yield@5% : 2,500 pages

ML-4500D3 Yield@5% : 2,500 pages

ML-1520D3 Yield@5% : 3,000 pages

ML-1610D2 Yield@ ISO/IEC 19752 :2,000 pages

ML-1710D3 Yield@5% : 3,000 pages

ML-2010D3 Yield@ ISO/IEC 19752 : 3,000 pages

ML-6060D6 Yield@5% : 6,000 pages

ML-1650D8 Yield@5%: 8,000 pages

ML-2150D8 Yield@5% : 8,000 pages

ML-2250D5 Yield@5% : 5,000 pages

ML-2550DA Yield@ ISO/IEC 19752 : 10,000 pages

ML-7300DA Yield@5% :10,000 pages

ML-D3050A Yield@5% : 4,000 pages

ML-D3050B Yield@ ISO/IEC 19752 : 8,000 pages

ML-3550DF Yield@5% : 25,000 pages

ML-3550R2 Yield@5% : 50,000 pages

ML-3560D6 Yield@ ISO/IEC 19752 : 6,000 pages

ML-D4550B Yield@ ISO/IEC 19752 : 20,000 pages

ML-D4550A Yield@ ISO/IEC 19752 : 10,000 pages

ML-3560DB Yield@ ISO/IEC 19752 : 12,000 pages

•••••••

Samsung Digital Multi Function Printer | 28 + 29

IPP-4640G ribbon cartridge+glossy photo paper : 40 pages

IPP-46120G ribbon cartridge+glossy photo paper : 120 pages


Printers

•

•

•

•

Hardwares

Consumables

SF-5100D3 Yield@5%: 2,500 pages

SF-550D3 Yield@5%: 3,000 pages

SF-6800D6 Yield@5%: 6,000 pages

SCX-4100D3 Yield@5%: 3,000 pages

SCX-D4200A Yield@ISO/IEC 19752 : 3,000 pages

SCX-4216D3 Yield@5%: 3,000 pages

SCX-4521D3 Yield@ ISO/IEC 19752 : 3,000 pages

SCX-5312D6 Yield@5%: 6,000 pages

SCX-5315R2 Yield@5% :15,000 pages

SCX-D5530A Yield@ISO/IEC 19752 : 4,000 pages

SCX-D5530B Yield@ ISO/IEC 19752 : 8,000 pages

SCX-6320D8 Yield@5% : 8,000 pages

SCX-6320R2 Yield@5% : 20,000 pages

SCX-D6345A Yield@ ISO/IEC 19752 : 20,000 pages

SCX-R6345A Yield@ ISO/IEC 19752 : 60,000 pages

SCX-4720D3 Yield@ ISO/IEC 19752 : 3,000 pages

SCX-4720D3 Yield@ ISO/IEC 19752 : 5,000 pages

SCX-D4725A Yield@5% ISO/IEC 19752 : 3,000 pages

SCX-6320D8 Yield@5% : 8,000 pages

SCX-6320R2 Yield@5% : 20,000 pages

SF-5800D5 Yield@5% : 5,000 pages

SF5556DRTD Yield@5% : 8,000 pages

SF6061DRTD Yield@5% : 5,000 pages

SF+7020R7 Yield@5% : 5,000 pages

INK-M10 Yield@4% : 1,000 pages

INK-C10 Yield@15% : 275 pages

INK-M40 Yield@4% : 750 pages

INK-M55 Yield@4% : 1,000 pages

INK-M50 Yield@5% : 600 pages

INK-C60 Yield@15% : 275 pages

•

•

•

•

•

Ink

FAX

MFP

SF-5100/5100P

Msys5100P

SF-530/531P

SF-515

SF-550/555P

SF-730

SF-6800/6800P

SF-6900

SCX-4100

SCX-4200

SF-560/565P

SF-750/755P

SCX-4016/4116/4216F

SCX-4321/4521F

SCX-5112/5115

SCX-5312F/5315F

SF-830/835P

SCX-5330N/5530FN

SCX-6220/6320F

SCX-4520/4720F/4720FN

SCX-4725FN/4725F

SCX-6122FN/6322DN

SCX-6345N

SF-5800/5800P

SF-5905P

SF-5500/5600/5700

Msys5500/5600

SF-6000

SF-6100

SF-7000

SF-7020

SF-3100/3100T

SF-3100P

SF-3200/3200T

SF-3200P

SF-330/331P/335T

SF-340/341P/345TP

SF-350

SF-360/361P/365TP

SF-430

SCX-1100/1150F

SPP-2020/2020R/2020B

SPP-2040/2040S/2040B

•

•

•

•

•

•

Mono

Laser

FAX

MFP

•

•

•

••

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

•

SCX-6345N SCX-6322DN

Print

Copy

Scan

FAX

Paper Handling

General

Consumables

Speed *

Resolution

First Page Out Time

Emulation

Duplex Print

Speed **

Resolution (Optical)

Resolution (Enhanced)

First Copy Out Time

Zoom Rate

Multiple copy

Duplex Copy

Compatibility

Method

Resolution (Optical)

Resolution (Enhanced)

Gray Scale

Compatibility

Applicable line

Modem Speed

Transmission Speed ***

Compression Mode

Scan Speed ****

Resolution

Memory

Auto Dial

Input Capacity and Types

Output Capacity and Types

Media Size (for Print)

Media Size (for Fax and Copy)

ADF Capacity

Dimension (W x D x H)

Weight with Consumables

LCD

System Memory

Interface

OS Compatibility *****

Warm-up Time

Type

Yield

Code

Up to 22 ppm in A4 (23 ppm in Letter) Duplex Printing Speed: Up to 12.5 ipm in A4 (13 ipm in Letter)

Up to 1200 dpi Effective Output

Less than 12 seconds (from Standby mode)

PCL6, PostScript 3

Standard

Up to 22 cpm in A4 (23 cpm in Letter)

600 x 600 dpi Text, Text/Photo mode : 600 x 300 dpi

Photo mode : 600 x 300 dpi (Platen), 600 x 600 dpi (DADF)

-

10 seconds (from Standby mode)

25~400% (platen), 25~100% (ADF)

1~999 pages

Standard (1:2, 2:2)

Twain Standard, WIA Standard

Colour CCD

600 x 600 dpi

Max. 4,800 x 4,800 dpi

256 Levels

ITU-T Group 3

Public Switched Telephone Network (PSTN) or behind PABX

33.6 Kbps

Approx. 3 seconds per page

MH / MR / MMR (ECM Mode) /JBIG/JPEG

2.5sec / A4 @ 203x98dpi, DADF (Scan Time) 3.2sec / A4 @ 203 x 98 dpi,

DADF (Multi Page Scan Time)

Standard : 203 x 98dpi Fine : 203 x 196dpi

Super Fine : 203 x 391dpi, 300 x 300dpi, 406 x 392dpi

8 MB (Approx. 640 pages at ITU-T #1 Chart)

1-touch dial : 40 Locations Speed dial : 240 Locations (including 1-touch dial)

550-sheet Cassette Tray (75 g/m2, 20 lbs), 100-sheet MP Tray

250-sheet Face Down (75 g/m2, 20 lbs)

Main Tray : A4, Letter, Legal, Folio, Oficio MP Tray: A4. Letter, Legal, Folio,

Executive, Envelope, #10, DL,C5, B5, Oficio, A5, C6 Env. Monach Env.,

A6, Custom (Min : 76x127mm (3.00x5.00 inch), Max : 216x356 mm(8.50 x 14.00 inch)

for Fax : Letter, A4, Legal

DADF 50 sheets ( 20lb, 75 g/m2)

560 x 430 x 495 mm (22" x 16.9" x 19.4")

25.65 Kg (56.5 lbs)

2 line x 20 characters

64 MB

USB 2.0 (High Speed), IEEE 1284 parallel, Ethernet 10/100 base Tx

Windows 98 / Me / NT4.0 / 2000 / XP (32/64bit)

- Various Linux OS (via USB interface only) including Red Hat 8 ~ 9, Fedora Core 1~4,

Mandrake 9.2~10.1, and SuSE 8.2~9.2 -Mac OS 10.3, 10.4

Less than 25 seconds (from sleep mode)

2-piece Cartridge

Standard Toner : 8,000 pages @ ISO/IEC 19752 / Drum : 20,000 pages @ ISO/IEC 19752

(Ships with standard 8,000 pages toner and 20,000 page Drum)

SCX-6320D8 (Toner), SCX-6320R2 (Drum)

Up to 43 ppm in A4 (45 ppm in Letter) Duplex Printing Speed: Up to 40 ipm in A4 (42 ipm in Letter)

Up to 1,200x1,200dpi Effective Output

8 seconds (from Standby mode)

PCL6, PostScript 3

Standard

Up to 43 cpm in A4 (45 cpm in Letter)

Scan: up to 600 x 300 (text, text/photo) up to 600 x 600 (photo using platen)

up to 600 x 300 (photo using DADF) Print: up to 600 x 600 (text, text/photo, photo)

-

Less than 5 seconds

25~400% (platen), 25~200% (ADF)

1~999 pages

Standard (1:2, 2:2, 2:1)

Twain standard, WIA standard

Colour CCD

600 x 600 dpi

Max. 4,800 x 4,800 dpi

256 Levels

ITU-T G3, Super G3

PSTN / PABX

33.6 Kbps

Approx. 3 seconds per page

MH / MR / MMR / JBIG / JPEG

Platen : 3.76 sec / A4 * Scan time: 1.16sec / A4 @ 203 x 98 dpi * Scan setup time : 2.6 sec

ADF : 4.27 sec / A4 * Scan time: 1.16sec / A4 @ 203 x 98 dpi * Scan setup time : 3.11 sec

Standard : 203 x 98dpi Fine : 203 x 196dpi

Super Fine : 203 x 391dpi, 300 x 300dpi, 406 x 392dpi

16 MB

Speed dial : 200 Locations

Main Tray : Up to 520-sheets (75g/m2) MP Tray : 100sheets

500-sheet Face Down (75 g/m2, 20 lbs)

Letter, Legal, Oficio, Folio, A4, JIS B5, ISO B5, Executive, A5, Statement, A6,

PostCard 4x6, Envelope B5, Envelope Monarch, Envelope COM-10,

Envelope DL, Envelope C5, Envelope C6, Custom

for Fax : Letter, A4, Legal

DADF 50 sheets ( 20lb, 80 g/m2, 0.1mm)

637.4 x 489 x 616 mm

44.5kg

1/2 VGA (640 x 240)

256 MB

Hi-Speed USB 2.0, Ethernet 10/100 base TX

Windows 98 / Me / 2000 / XP (32/64bit) / 2003 Server (32/64bit),

Various Linux OS including Red Hat 8~9, Fedora Core 1~4,

Mandrake 9.2~10.1 and SuSE 8.2~9.2 Mac OS 10.3~10.4

Less than 35 sec from sleep mode

2-piece Cartridge

Toner : Average Cartridge Yield 20,000 standard pages.

Declared yield value in accordance with ISO/IEC 19752 Drum : 60,000 Pages

Toner : SCX-D6345A Drum : SCX-R6345A

* Print speed will be affected by Operating system used, computing performance, application software, connecting method, media type, media size and job complexity.

** Copy Speed is based on Single Document Multiple Copy *** Condition: Standard resolution, MMR(JBIG), Maximum modem speed, Phase"C" by ITU-T No.1 Chart, Memory Tx, ECM

**** Condition: ITU-T No.1 Chart, Standard Resolution ***** Please visit www.samsungprinter.com to download the latest software version.

Specifications

Specifications

Samsung Digital Multi Function Printer | 30 + 31

SCX-6320F SCX-5530FN SCX-4720FN

Print

Copy

Scan

FAX

Paper Handling

General

Consumables

Speed *

Resolution

First Page Out Time

Emulation

Duplex Print

Speed **

Resolution (Optical)

Resolution (Enhanced)

First Copy Out Time

Zoom Rate

Multiple copy

Duplex Copy

Compatibility

Method

Resolution (Optical)

Resolution (Enhanced)

Gray Scale

Compatibility

Applicable line

Modem Speed

Transmission Speed ***

Compression Mode

Scan Speed ****

Resolution

Memory

Auto Dial

Input Capacity and Types

Output Capacity and Types

Media Size (for Print)

Media Size (for Fax and Copy)

ADF Capacity

Dimension (W x D x H)

Weight with Consumables

LCD

System Memory

Interface

OS Compatibility *****

Warm-up Time

Type

Yield

Code

---

Up to 20 ppm in A4 (22 ppm in Letter)

Up to 1,200 dpi Effective output

9 seconds (from Standby mode)

PCL6

Standard

Up to 20 ppm in A4 (22 ppm in Letter)

600 x 600 dpi Text, Text/Photo mode : 600 x 300 dpi

Photo mode : 600 x 600 dpi (Platen), 600 x 600 dpi (ADF)

600 x 600 dpi

8 seconds (from Standby mode)

25~400% (platen), 25~100% (ADF)

1~999 pages

Standard (1:1, 1:2, 2:1, 2:2)

Twain standard, WIA standard

Colour CCD

600 x 600 dpi

Max. 4,800 x 4,800 dpi

256 Levels

ITU-T Group 3, ECM

Public Switched Telephone Network (PSTN) or behind PABX

33.6 Kbps

Approx. 3 seconds per page

MH / MR / MMR (ECM Mode) / JBIG / JPEG

Platen : Approx. 1.4 seconds per page

ADF : Approx. 1.5 seconds per page

Max. 400 x 400 dpi Standard: 203 x 98 dpi Fine: 203 x 196 dpi Super Fine: 203 x

391 dpi, 300 x 300 dpi, 406 x 392 dpi Photo: 300 x 300 dpi Colour: 200 x 200 dpi

16 MB (Approx. 1,280 pages at ITU-T #1 Chart)

1-touch dial : 40 Locations, Speed dial : 200 Locations

550-sheet Cassette Tray (75 g/m2, 20 Ibs), 100-sheet MP Tray

250-sheet Face Down

Tray: A4,Letter,Legal, Folio Manual Tray: A4. Letter, Legal, Folio,

Executive, Envelope6 3/4, 7 3/4,#9, #10,DL,C5,B5

Manual Tray: A4. Letter, Legal, Folio, Executive, Envelope 6 3/4, 7 3/4, #9, #10, DL, C5, B5

50-sheets (Letter / A4, 20 lb / 75 g/m2)

540 x 441 x 488 mm (21.3" x 174" x 19.2")

24.6 Kg (54.1 lbs)

2 line x 20 characters (Backlight)

48 MB

USB 2.0 (High Speed), IEEE 1284 Parallel

Windows 98 / Me / NT4.0 / 2000 / XP,

Various Linux OS (via USB interface only) including Red Hat,

Caldera, Mandrake, Slackware, SuSE and Turbo Linux

Less than 25 seconds (from sleep mode)

2-Piece Cartridge

Standard Toner : 8,000 pages @ ISO/IEC 19752 / Drum : 20,000 pages @ 5%

coverage (Ships with standard 8,000 pages toner and 20,000 page Drum)

SCX-6320D8 (Toner), SCX-6320R2 (Drum)

Up to 28 ppm in A4 (30 ppm in Letter) / Duplex Printing Speed : Up to 19 ipm in A4 (21 ipm in Letter)

Up to 1200 dpi Effective Output

8.5 seconds (from Standby mode)

PCL6, PostScript 3

Standard

Up to 28 ppm in A4 (30 ppm in Letter)

600 x 600 dpi, Text, Text/Photo mode : 600 x 300 dpi,

Photo mode : 600 x 600 dpi (Platen), 600 x 300 dpi (ADF)

-

8.5 seconds (from Standby mode)

25~400% (platen), 25~100% (ADF)

1~99 pages

Standard (1:1, 1:2)

Twain standard, WIA standard

Colour CCD

600 x 1200 dpi

Max. 4,800 x 4,800 dpi

256 Levels

ITU-T Group 3

Public Switched Telephone Network (PSTN) or behind PABX

33.6 Kbps

Approx. 3 seconds per page

MH / MR / MMR (ECM Mode) / JBIG / JPEG

2.5 sec / letter @ 203 x 98 dpi

Max. 400 x 400 dpi, Standard : 203 x 98 dpi Fine : 203 x 196 dpi,

Super Fine : 300 x 300 dpiPhoto : 203 x 196 dpi, Colour : 200 x 200 dpi

6 MB (Approx. 480 pages at ITU-T #1 Chart)

1-touch dial : 30 Locations / Speed dial : 240 Locations (including 1-touch dial)

250-sheet Cassette Tray (75 g/m2, 20 lbs), 50-sheet MP Tray

150-sheet Face Down (75 g/m2, 20 lbs), 1-sheet Face Up

Main Tray : A4, A5, Letter, Legal, Executive, Folio, Oficio, ISO B5, JIS B5, A6 /

Manual Tray: A4, A5, Letter, Legal, Executive, Folio, Oficio, ISO B5, JIS B5, A6, Envelope

B5/Monarch/Com-10/DL/C5/C6 ,76 x 127 mm (3 " x 5 ") ~ 215.9 x 356 mm (8.5" x 14")

for Fax : Letter, A4, Legal

50 sheets (Letter / A4, 20 lb / 75 g/m2)

466 x 435.4 x 458 mm (18.35" x 17.1" x 18")

18.5 Kg (40.78 lbs)

2 line x 16 characters

96 MB (64 MB on board + 32 MB DIMM)

USB 2.0 (High Speed), IEEE 1284, Ethernet 10/100 base Tx

Windows 98 / Me / NT4.0 / 2000 / XP Various Linux OS

(via USB interface only) including Red Hat 8~9, Fedora Core 1~3,

Mandrake 9.2~10.1, and SuSE 8.2~9.2, Mac OS 10.3, 10.4

Less than 20 seconds (from sleep mode)

Single Cartridge

Standard : 4,000 pages @ ISO/IEC 19752 / High Yield : 8,000 pages @

ISO/IEC 19752 (Ships with 4,000 pages Standard Toner Cartridge)

Standard Toner(4K) : SCX-D5530A, High Yield Toner(8K) : SCX-D5530B

Up to 28 ppm in A4 (30 ppm in Letter) / Duplex Printing Speed : Up to 19 ipm in A4 (21 ipm in Letter)

Up to 1200 dpi Effective Output

8.5 seconds (from Standby mode)

PCL6, PostScript 3

Standard

Up to 28 ppm in A4 (30 ppm in Letter)

600 x 600 dpi, Text, Text/Photo mode : 600 x 300 dpi,

Photo mode : 600 x 600 dpi (Platen), 600 x 300 dpi (ADF)

-

8.5 seconds (from Standby mode)

25~400% (platen), 25~100% (ADF)

1~99 pages

Standard (1:1, 1:2)

Twain standard, WIA standard

Colour CCD

600 x 1200 dpi

Max. 4,800 x 4,800 dpi

256 Levels

ITU-T Group 3

Public Switched Telephone Network (PSTN) or behind PABX

33.6 Kbps

Approx. 3 seconds per page

MH / MR / MMR (ECM Mode) / JBIG / JPEG

2.5 sec / letter @ 203 x 98 dpi

Max. 400 x 400 dpi, Standard : 203 x 98 dpi Fine : 203 x 196 dpi,

Super Fine : 300 x 300 dpiPhoto : 203 x 196 dpi, Colour : 200 x 200 dpi

6 MB (Approx. 480 pages at ITU-T #1 Chart)

1-touch dial : 30 Locations / Speed dial : 240 Locations (including 1-touch dial)

250-sheet Cassette Tray (75 g/m2, 20 lbs), 50-sheet MP Tray

150-sheet Face Down (75 g/m2, 20 lbs), 1-sheet Face Up

Main Tray : A4, A5, Letter, Legal, Executive, Folio, Oficio, ISO B5, JIS B5, A6 /

Manual Tray: A4, A5, Letter, Legal, Executive, Folio, Oficio, ISO B5, JIS B5, A6, Envelope

B5/Monarch/Com-10/DL/C5/C6 ,76 x 127 mm (3 " x 5 ") ~ 215.9 x 356 mm (8.5" x 14")

for Fax : Letter, A4, Legal

50 sheets (Letter / A4, 20 lb / 75 g/m2)

466 x 435.4 x 458 mm (18.35" x 17.1" x 18")

18.5 Kg (40.78 lbs)

2 line x 16 characters

96 MB (64 MB on board + 32 MB DIMM)

USB 2.0 (High Speed), IEEE 1284, Ethernet 10/100 base Tx

Windows 98 / Me / NT4.0 / 2000 / XP Various Linux OS

(via USB interface only) including Red Hat 8~9, Fedora Core 1~3,

Mandrake 9.2~10.1, and SuSE 8.2~9.2, Mac OS 10.3, 10.4

Less than 20 seconds (from sleep mode)

Single Cartridge

Standard : 4,000 pages @ ISO/IEC 19752 / High Yield : 8,000 pages @

ISO/IEC 19752 (Ships with 4,000 pages Standard Toner Cartridge)

Standard Toner(4K) : SCX-D5530A, High Yield Toner(8K) : SCX-D5530B

November 2006

Distributed by Design and Specifications are subject to change without notice.

Trademarks of other companies mentioned in these publications are hereby recognized and acknowledged.
