This user manual includes detailed usage
instructions for your camera. Please read
this manual thoroughly.
Quick reference
Contents
Basic functions
Extended functions
Shooting options
Playback/Editing
Appendixes
Index
User Manual
SL820
Ä Click a topic
1
Health and safety information
Always comply with the following precautions and usage tips to avoid dangerous situations and ensure peak performance of your camera.
Warning—situations that could cause injury to yourself or
others
Caution—situations that could cause damage to your
camera or other equipment
Note—notes, usage tips, or additional information
Do not use your camera near flammable or explosive
gases and liquids
Do not use your camera near fuels, combustibles, or flammable
chemicals. Do not store or carry flammable liquids, gases, or
explosive materials in the same compartment as the camera or its
accessories.
Keep your camera away from small children and pets
Keep your camera and all accessories out of the reach of small
children and animals. Small parts may cause choking or serious
injury if swallowed. Moving parts and accessories may present
physical dangers as well.
Safety warnings
Prevent damage to subjects’ eyesight
Do not use the flash in close proximity (closer than 1 m/3 ft) to
people or animals. Using the flash too close to your subject’s
eyes can cause temporary or permanent damage.
Handle and dispose of batteries and chargers with care
Use only Samsung-approved batteries and chargers. t
Incompatible batteries and chargers can cause serious injuries
or damage to your camera.
Never dispose of batteries in a fire. Follow all local regulations t
when disposing of used batteries.
Never place batteries or cameras on or in heating devices, t
such as microwave ovens, stoves, or radiators. Batteries may
explode when overheated.
Handle and store your camera carefully and sensibly
Do not allow your camera to get wet—liquids can cause serious t
damage. Do not handle your camera with wet hands. Water
damage to your camera can void your manufacturer’s warranty.
Safety precautions
2
Health and safety information
Protect batteries, chargers, and memory cards from
damage
Avoid exposing batteries or memory cards to very cold or very t
hot temperatures (below 0º C/32º F or above 40º C/104º F).
Extreme temperatures can reduce the charging capacity of your
batteries and can cause memory cards to malfunction.
Prevent batteries from making contact with metal objects, as t
this can create a connection between the + and – terminals
of your battery and lead to temporary or permanent battery
damage.
Prevent memory cards from making contact with liquids, dirt, or t
foreign substances. If dirty, wipe the memory card clean with a
soft cloth before inserting in your camera.
Turn off the camera when inserting or removing the memory t
card.
Do not bend, drop, or subject memory cards to heavy impact t
or pressure.
Do not use memory cards that have been formatted by other t
cameras or by a computer. Reformat the memory card with
your camera.
Never use a damaged charger, battery, or memory card.t
Do not expose the camera to direct sunlight or high t
temperatures for an extended period of time. Prolonged
exposure to sunlight or extreme temperatures can cause
permanent damage to your camera’s internal components.
Avoid using or storing your camera in dusty, dirty, humid, or t
poorly-ventilated areas to prevent damage to moving parts and
internal components.
Remove the batteries from your camera when storing it for an t
extended period of time. Installed batteries may leak or corrode
over time and cause serious damage to your camera.
Protect your camera from sand and dirt when using it on t
beaches or in other similar areas.
Protect your camera from impact, rough handling, and t
excessive vibration to avoid serious damage.
Exercise caution when connecting cables or adapters and t
installing batteries and memory cards. Forcing the connectors,
improperly connecting cables, or improperly installing batteries
and memory cards can damage ports, connectors, and
accessories.
Do not insert foreign objects into any of your camera’s t
compartments, slots, or access points. Damage due to
improper use may not be covered by your warranty.
3
Exercise caution when using the camera in humid
environments
When transferring the camera from a cold environment to a warm
and humid one, condensation can form on the delicate electronic
circuitry and memory card. In this situation, wait for at least 1 hour
until all moisture has evaporated before using the camera.
Check that the camera is operating properly before use
The manufacturer takes no responsibility for any loss of files or
damage that may result from camera malfunction or improper
use.
Use only Samsung-approved accessories
Using incompatible accessories may damage your camera,
cause injury, or void your warranty.
Protect your camera’s lens
Do not expose the lens to direct sunlight, as this may discolor t
the image sensor or cause it to malfunction.
Protect your lens from fingerprints and scratches. Clean your t
lens with a soft, clean, debris-free lens cloth.
Allow only qualified personnel to service your camera
Do not allow unqualified personnel to service the camera or
attempt to service the camera yourself. Any damage that results
from unqualified service is not covered by your warranty.
Ensure maximum battery and charger life
Overcharging batteries may shorten battery life. After charging is t
finished, disconnect the cable from your camera.
Over time, unused batteries will discharge and must be t
recharged before use.
Disconnect chargers from power sources when not in use.t
Use batteries only for their intended purpose.t
Important usage information
Health and safety information
4
©2009 Samsung Electronics America, Inc.
Camera specifications or contents of this manual may be
changed without prior notice due to upgrade of camera
functions.
Copyright information
Microsoft Windows and the Windows logo are t
registered trademarks of the Microsoft Corporation.
HDMI, the HDMI logo and the term "High Definition t
Multimedia Interface" are trademarks or registered
trademarks of HDMI Licencing LLC.
QuickTimet ® and QuickTime® logo are trademarks or
registered trademarks of Apple Computer, Inc., used
under licence.
Organization of the user manual
Basic functions 10
Learn about your camera’s layout, icons, and basic
functions for shooting.
Extended functions 25
Learn how to take a photo by selecting a mode and
how to record a video or voice memo.
Shooting options 34
Learn about the options you can set in shooting mode.
Playback/Editing 51
Learn how to play back photos, videos, or voice
memos and edit photos or videos. Also, learn how to
connect your camera to your computer, photo printer,
TV, or HDTV.
Appendixes 72
Refer to settings, error messages, specifications, and
maintenance tips.
5
Indications used in this manual
Shooting mode Indication
Auto
a
Program
p
DUAL IS
d
Photo Help Guide
h
Beauty Shot
b
Scene
s
Movie
v
Smart Auto
S
Shooting mode icons
These icons indicate that a function is available in the
corresponding modes. The s mode may not support
functions for all scenes.
e.g.)
Available in the
Program, DUAL IS,
and Movie modes
Icons used in this manual
Icon Function
Additional information
Safety warnings and precautions
[ ] Camera buttons; for example: [Shutter] (represents the
shutter button)
( ) Page number of related information
The order of options or menus you must select to
perform a step; for example: Select Functions White
Balance (represents select Functions, and then White
Balance).
*Annotation
Abbreviations used in this manual
Abbreviation Definition
ACB Auto Contrast Balance
AEB Auto Exposure Bracket
AF Auto Focus
DIS Digital Image Stabilization
DPOF Digital Print Order Format
EV Exposure Value
OIS Optical Image Stabilization
WB White Balance
6
Expressions used in this manual
Pressing the shutter
tHalf-press [Shutter]: press the shutter halfway down
Press [t Shutter]: press the shutter all the way down
Half-press [Shutter] Press [Shutter]
Subject, background, and composition
Subjectt : the main object of a scene, such as a person, animal,
or still life
Backgroundt : the objects around the subject
Compositiont : the combination of a subject and background
Background
Subject
Composition
Exposure (Brightness)
The amount of light that enters your camera determines the
exposure. You can alter the exposure with shutter speed,
aperture value, and ISO speed. By altering the exposure, your
photos will be darker or lighter.
Normal exposure Overexposure (too bright)
7
Quick reference
Taking photos of people
s
t mode > Portrait, Children
f
27
b
t mode
f
29
Red-eye, Red-eye Fix (to prevent or correct red-eye) t
f
38
Face Detection t
f
42
Taking photos at night or in the dark
s
t mode > Night, Dawn, Firework
f
27
Flash options t
f
38
ISO speed (to adjust the sensitivity to light) t
f
39
Taking action photos
Continuous, Motion Capture t
f
48
Taking photos of text, insects, or
flowers
s
t mode > Close Up, Text
f
27
Macro, Auto Macro (to take close-up photos) t
f
40
White balance (to change the color tone) t
f
46
Adjusting the exposure (brightness)
ISO speed (to adjust the sensitivity to light) t
f
39
EV (to adjust exposure) t
f
45
ACB (to compensate for subjects against bright t
backgrounds)
f
45
Metering t
f
46
AEB (to take three photos of the same scene with t
different exposures)
f
48
Applying a different effect
Photo styles (to apply tones) t
f
49
Image adjustment (to adjust saturation, sharpness, or t
contrast)
f
50
Reducing camera shake
Optical Image Stabilization (OIS) t
f
21
d
t mode
f
30
Viewing files by category in t
Smart Album
f
53
Deleting all files on the t
memory card
f
54
Viewing files as a slide show t
f
56
Viewing files on a TV or HDTV t
f
63
Connecting your camera to a t
computer
f
65
Adjusting sound and volume t
f
74
Adjusting the brightness of t
the display
f
74
Changing the display t
language
f
74
Setting the date and time t
f
75
Formatting the memory card t
f
75
Troubleshooting t
f
83
8
Contents
Shooting options ................................................................... 34
Selecting a resolution and quality ...................................... 35
Selecting a resolution ........................................................... 35
Selecting image quality ........................................................ 35
Using the timer .................................................................. 36
Shooting in the dark .......................................................... 38
Preventing red-eye .............................................................. 38
Using the flash .................................................................... 38
Adjusting the ISO speed ...................................................... 39
Changing the camera’s focus ............................................ 40
Using macro ....................................................................... 40
Using auto focus ................................................................. 40
Adjusting the focus area ....................................................... 41
Using face detection ......................................................... 42
Detecting faces ................................................................... 42
Taking a self-portrait shot ...................................................... 43
Taking a smile shot .............................................................. 43
Detecting eye blinking .......................................................... 44
Adjusting brightness and color .......................................... 45
Adjusting the exposure manually (EV) .................................... 45
Compensating for backlighting (ACB) .................................... 45
Changing the metering option ............................................... 46
Selecting a light source (White balance) ................................. 46
Using burst modes ............................................................ 48
Improving your photos ...................................................... 49
Applying photo styles ........................................................... 49
Defining your own RGB tone ................................................ 49
Adjusting your photos .......................................................... 50
Basic functions ...................................................................... 10
Unpacking ......................................................................... 11
Camera layout ................................................................... 12
Icons ................................................................................. 14
Turning your camera on or off ........................................... 15
Selecting options ............................................................... 16
Setting the display and sound ........................................... 18
Changing the display type .................................................... 18
Setting the sound ................................................................ 18
Taking photos .................................................................... 19
Zooming ............................................................................. 20
Reducing camera shake (OIS) .............................................. 21
Using the Photo Help Guide mode .................................... 22
Tips for getting a clearer photo .......................................... 23
Extended functions .............................................................. 25
Shooting modes ................................................................ 26
Using the Smart Auto mode ................................................. 26
Using the Scene mode ........................................................ 27
Using the frame guide .......................................................... 27
Adjusting the exposure in the Night mode .............................. 28
Using the Beauty Shot mode ................................................ 29
Using the DUAL IS mode ..................................................... 30
Using the Program mode ..................................................... 30
Recording a video ............................................................... 31
Recording voice memos ................................................... 33
Recording a voice memo ..................................................... 33
Adding a voice memo to a photo .......................................... 33
9
Contents
Playback/Editing ................................................................... 51
Playing back ...................................................................... 52
Starting Playback mode ....................................................... 52
Viewing photos ................................................................... 56
Playing a video .................................................................... 57
Playing voice memos ........................................................... 58
Editing a photo .................................................................. 59
Resizing photos .................................................................. 59
Rotating a photo .................................................................. 59
Applying photo styles ........................................................... 60
Defining your own RGB tone ................................................ 60
Correcting exposure problems ............................................. 61
Creating a print order (DPOF) ................................................ 62
Viewing files on a TV or HDTV ........................................... 63
Transferring files to your computer .................................... 65
For Windows users ............................................................. 65
For Mac users ..................................................................... 70
Printing photos with a photo printer (PictBridge) ............... 71
Appendixes ............................................................................ 72
Camera settings menu ...................................................... 73
Accessing the settings menu ................................................ 73
Sound ................................................................................ 74
Display ............................................................................... 74
Settings .............................................................................. 75
Error messages ................................................................. 78
Camera maintenance ........................................................ 79
Cleaning your camera .......................................................... 79
About memory cards ........................................................... 80
About the battery ................................................................. 81
Before contacting a service center .................................... 83
Camera specifications ....................................................... 86
FCC notice ........................................................................ 90
Index ................................................................................. 91
Unpacking ………………………………………………… 11
Camera layout …………………………………………… 12
Icons ………………………………………………………… 14
Turning your camera on or off ………………………… 15
Selecting options ………………………………………… 16
Setting the display and sound ………………………… 18
Changing the display type ………………………………… 18
Setting the sound …………………………………………… 18
Taking photos ……………………………………………… 19
Zooming …………………………………………………… 20
Reducing camera shake (OIS) ……………………………… 21
Using the Photo Help Guide mode …………………… 22
Tips for getting a clearer photo ………………………… 23
Basic functions
Learn about your camera’s layout, icons, and basic functions
for shooting.
Basic functions
11
Unpacking
Check your product box for the following items.
Camera AC adapter/USB cable
(AD44-00143A)/(AD39-00166A)
Rechargeable battery
(4302-001221)
Strap
(Silver: AD63-02596A/
Black: AD63-02604A)
Software CD-ROM
(User manual included)
(AD46-00243B)
Quick Start Manual
(AD68-03879A)
The illustrations may differ from your actual items.
Optional accessories
Camera case Memory cards
A/V cable
(AD39-00163A)
Sold as a set
HDMI cradle manual
(AD68-03751A)
Remote control
(AD59-00164A)
Cradle
(for charging the battery and connecting
your camera to an HDTV or PC)
(AD61-04147A)
HDMI cable
(for viewing high-resolution images or
playing videos)
(AD39-00160A)
Basic functions
12
Camera layout
Before you start, familiarise yourself with your camera's parts and their functions.
Shutter button
POWER button
AF-assist light/timer lamp
Remote control sensor
Flash
Lens
Battery chamber cover
Insert a memory card and battery
USB and A/V port
Tripod mount
Speaker
Microphone
Basic functions
13
Camera layout
Display
Zoom button
Zoom in or out in Shooting mode.t
Zoom in on part of a photo or view files as thumbnails in Playback mode.t
Adjust volume in Playback mode.t
Mode dial
Icon Mode Description
a
Auto Take a photo quickly and easily with
minimal settings
p
Program Take a photo by setting options
d
DUAL IS Take a photo with options suitable for
reducing camera shake
h
Photo Help
Guide Get shooting tips and practice shooting
b
Beauty Shot Take a photo of a person with options to
hide facial imperfections
s
Scene Take a photo with options preset for a
specific scene
v
Movie Record a video
S
Smart Auto Take a photo by letting the camera select
a scene mode as it detects
Button Description
m
Access options or menus.
Navigation
In Shooting mode While setting
D
Change the display option Move up
M
Change the macro option Move down
F
Change the flash option Move left
t
Change the timer option Move right
o
Confirm the highlighted option or menu.
Playback Enter Playback mode.
Function Access options in Shooting mode.t
Delete files in Playback mode.t
Status lamp
Blinkingt : When saving a photo or video, being read by a computer
or printer, or out of focus
Steadyt : When connecting to a computer or in focus
Basic functions
14
B. Icons on the right
Icon Description
Flash
Timer
Auto focus
Photo style
Face detection
Optical Image Stabilization (OIS)
Face tone
Face retouch
Image adjustment
(contrast, sharpness, saturation)
Voice muted
C. Icons on the left
Icon Description
Exposure value
White balance
ISO speed
Photo resolution
Video resolution
Photo quality
Frame rate
Metering option
Long time shutter
Burst type
Icons
The icons displayed will change according to the mode you select or the options you set.
A. Information
Icon Description
Selected shooting mode
Zoom ratio
Available number of photos
Available recording time
Internal memory
Memory card inserted
t : Fully charged
t : Partially charged
t : Charging needed
Aperture and shutter speed
Voice memo
Auto focus frame
Camera shake
Current date and time
A
B
C
Basic functions
15
Turning your camera on or off
Learn how to start your camera.
Turning on your camera in Playback mode
Press [P]. The camera turns on and accesses Playback mode
immediately.
Press and hold [
P
] to mute camera sounds.
Press [POWER] to turn your camera on or off.
Basic functions
16
Selecting options
You can select options by pressing [m] and using the navigation buttons ([D], [M], [F], [t]).
You can also access shooting options by pressing [
f
] but some options are not available.
E.g. Selecting a white balance option in the P mode
Rotate the mode dial to
1
p
.
Press [
2
m
].
Functions
Sound
Display
Settings
EV
White Balance
ISO
Face Detection
Photo Size
Quality
ACB
Exit Change
In Shooting mode, press [
1
m
].
Use the navigation buttons to scroll to an option or
2
menu.
To move left or right, press [t
F
] or [
t
].
To move up or down, press [t
D
] or [
M
].
EV
Back Move
Press [
3
o
] to confirm the highlighted option or menu.
Going back to the previous menu
Press [m] again to go back to the previous menu.
Press [Shutter] to return to Shooting mode.
Basic functions
17
Selecting options
Press [
3
D
] or [
M
] to scroll to Functions and then
press [
t
] or [
o
].
Press [
4
D
] or [
M
] to scroll to White Balance and then
press [
t
] or [
o
].
EV
White Balance
ISO
Face Detection
Photo Size
Quality
ACB
Exit Back
Press [
5
F
] or [
t
] to scroll to a white balance option.
Daylight
Back Move
Press [
6
o
].
Basic functions
18
Setting the display and sound
Learn how to change the basic settings for the display and sound according to your preferences.
Setting the sound
Set whether your camera emits a specified sound when you
operate your camera.
In Shooting or Playback mode, press [
1
m
].
Select
2
Sound Beep Sound an option.
Option Description
Off
The camera does not emit any sounds.
1/2/3
The camera emits sounds.
Press [
3
m
] to return to the previous mode.
Changing the display type
Select a style of display for Shooting or Playback mode.
Press [
D
] repeatedly to change a display type.
Show all photographic
information.
Mode Description
Shooting
Display all information about shootingt
Hide information about shooting, except the t
available number of photos
Playback
Display all information about the current photot
Hide all information about the current filet
Display information about the current file, except the t
shooting settings and captured date
Basic functions
19
Taking photos
Learn basic actions to take photos easily and quickly in the Auto mode.
Rotate the mode dial to
1
a
.
Align your subject in the frame.
2
Half-press [
3
Shutter] to focus.
A green frame means the subject in focus.t
Press [
4
Shutter] to take a photo.
See page 23 for tips to get clearer photos.
Basic functions
20
Taking photos
Digital zoom
If the zoom indicator is in the digital range, your camera is using
the digital zoom. The picture quality may deteriorate when you
use the digital zoom.
Optical range Zoom indicator
Digital range
The digital zoom is not available when using t
S
,
d
,
b
,
s
(in some scenes), and
v
modes and when used with Face
Detection.
It may take longer to save a photo when using the digital zoom.t
Zooming
You can shoot close-up photos by adjusting the zoom. Your
camera has a 5X optical zoom and 5X digital zoom. By using
both, you can zoom in up to 25 times.
Push [Zoom] up to zoom in on your subject. Push [Zoom] down
to zoom out.
Zoom in
Zoom out
Zoom ratio
The zoom ratio available for videos differs.
Basic functions
21
Taking photos
OIS may not function properly when:t
you move your camera to follow a moving subject -
you use digital zoom -
there is too much camera shake -
the shutter speed is slow (e.g., when you select - Night in the
s
mode)
the battery is low -
you take a close-up shot -
If you use the OIS function with a tripod, your images may be blurred t
by the vibration of the OIS sensor. Deactivate the OIS function when
you use a tripod.
If the camera is impacted, the display will be blurry. In this case, turn t
off the camera and turn it on again to use the OIS function correctly.
Reducing camera shake (OIS)
Reduce camera shake optically in Shooting mode.
Before correction After correction
In Shooting mode, press [
1
m
].
Select
2
Functions OIS an option.
Option Description
Off: Deactivate the OIS function.
On: Activate the OIS function.
Basic functions
22
Using the Photo Help Guide mode
This mode provides various shooting tips. Learn how to get better photos and videos.
View a topic.
4
Press [t
D
] or [
M
] to display the previous or next screen.
Back Practice
Photo Help Guide
Press the Fn button.
Move to ISO using the up
and down buttons.
Press [
5
o
] to practice.
Press [t
D
] to return to the list.
Press [t
F
] to go back to the previous menu.
While practicing, you cannot set shooting options or menus.t
Rotate the mode dial to
1
h
.
Select a menu from the list.
2
Photo Help Guide
Change
Photo Help Guide
Features to use when the image is out of focus
Features to reduce camera shake
Features to use in low light conditions
Features to use when adjusting brightness
Features to use when adjusting colours
Select a submenu.
3
Basic functions
23
Tips for getting a clearer photo
Holding your camera correctly
Make sure nothing is
blocking the lens.
Half-pressing the shutter button
Half-press [Shutter] and adjust the
focus. Focus and exposure will be
adjusted automatically.
The aperture value and shutter
speed are automatically set.
Focus frame
Press [t Shutter] to take the photo
if displayed in green.
Change the frame and half-press t
[Shutter] again if displayed in red.
Reducing camera shake
Set the Optical Image Stabilization option to t
reduce camera shake optically. (p. 21)
Select the t
d
mode to reduce camera
shake both optically and digitally. (p. 30)
When is displayed
Camera shake
When shooting in the dark, avoid
setting the flash option to Slow
Sync or Off. The aperture remains
open longer and it may be harder
to hold the camera still.
Use a tripod or set the flash t
option to Fill in. (p. 38)
Set ISO speed options. (p. t 39)
Basic functions
24
Preventing your subject from being out of focus
It may be difficult to get your subject in focus when:
there is little contrast between the subject and background -
(When your subject is wearing a color of clothing that is similar to the
background)
the light source behind the subject is too bright
-
the subject is shiny -
the subject includes horizontal patterns, such as blinds -
the subject is not positioned in the center of the frame -
Use the focus lock
Half-press [Shutter] to focus. When the subject is in focus,
you can reposition the frame to change the composition.
When you are ready, press [Shutter] to take your photo.
When you take photos in low lightt
Turn on the flash.
(p. 38)
When subjects are moving fastt
Use the continuous
or motion capture
function. (p. 48)
Shooting modes …………………………………………… 26
Using the Smart Auto mode ……………………………… 26
Using the Scene mode ……………………………………… 27
Using the frame guide ……………………………………… 27
Adjusting the exposure in the Night mode ………………… 28
Using the Beauty Shot mode ……………………………… 29
Using the DUAL IS mode …………………………………… 30
Using the Program mode …………………………………… 30
Recording a video …………………………………………… 31
Recording voice memos ………………………………… 33
Recording a voice memo …………………………………… 33
Adding a voice memo to a photo ………………………… 33
Extended functions
Learn how to take a photo by selecting a mode and how to
record a video or voice memo.
Extended functions
26
Shooting modes
Take photos or record videos by selecting the best shooting mode for the conditions.
Icon Description
Appears when taking portraits at night.
Appears when taking photos of landscapes with
backlighting.
Appears when taking portraits with backlighting.
Appears when taking portraits.
Appears when taking close-up photos.
Appears when taking close-up photos of text.
Appears when the camera and subject are stable for a
while.
Appears when taking photos of actively moving subjects.
Half-press [
3
Shutter] to focus.
Press [
4
Shutter] to take the photo.
If the camera does not recognize a proper scene mode, t will not
change and the default settings will be used.
Even if there is a face detected, the camera may not select a portrait t
mode depending on the subject's position or lighting.
The camera may not select the correct scene depending on shooting t
environments, such as camera shake, lighting, and distance to the
subject.
Even if you use a tripod, the t mode may not be detected depending
on the subject's movement.
Using the Smart Auto mode
In this mode, your camera automatically chooses the appropriate
camera settings based on a defected type of scene. It will be
helpful if you are not familiar with the camera settings for various
scenes.
Rotate the mode dial to
1
S
.
Align your subject in the frame.
2
The camera selects a scene automatically. An appropriate t
mode icon will appear at the top left of the screen.
Icon Description
Appears when taking photos of landscapes.
Appears when taking photos of bright backgrounds.
Appears when taking photos of landscapes at night.
This is available only when the flash is off.
Extended functions
27
Shooting modes
Using the frame guide
When you want another person to take a photo of you, you can
compose the scene with the frame guide feature. The frame
guide will help the other person take a photo of you by showing
the part of the pre-composed scene.
Rotate the mode dial to
1
s
.
Select
2
Frame Guide.
Align your subject in the frame and press [
3
Shutter].
Transparent guides will appear on the left and right of the t
frame.
Cancel Frame: OK
Ask another person to take a photo.
4
The person must align the subject in the frame by using the t
guides, and then press [Shutter] to take the photo.
To cancel the guides, press [
5
o
].
Using the Scene mode
Take a photo with options preset for a specific scene.
Rotate the mode dial to
1
s
.
Select a scene.
2
Night
This mode is appropriate for shooting at
night (use of tripod is recommended).
To change the scene mode, press [t MENU] and select Scene
a scene.
For the Frame Guide mode, see “t Using the frame guide.”
For the Night mode, see “Adjusting the exposure in the Night t
mode” on page 28.
Align your subject in the frame and half-press [
3
Shutter]
to focus.
Press [
4
Shutter] to take the photo.
Extended functions
28
Shooting modes
Select an option.
6
If you select t AUTO the aperture value or shutter speed will be
adjusted automatically.
Align your subject in the frame and half-press [
7
Shutter]
to focus.
Press [
8
Shutter] to take the photo.
Use a tripod to prevent your photos from blurring.
Adjusting the exposure in the Night mode
In the Night mode, you can catch brief flashes of light as curved
streaks by extending the exposure. Use a slow shutter speed
to extend the time until the shutter closes. Increase the aperture
value to prevent overexposure.
Rotate the mode dial to
1
s
.
Select
2
Night.
Press [
3
m
].
Select
4
Functions Long Time Shutter.
Select the aperture value or shutter speed.
5
Aperture value
Shutter speed
Aperture
Back Move
Extended functions
29
Shooting modes
To hide
4
facial imperfections, press [
m
].
Select
5
Functions Face Retouch an option.
Select a higher setting to hide a greater number of t
imperfections.
Level 1
Back Move
Align your subject in the frame and half-press [
6
Shutter]
to focus.
Press [
7
Shutter] to take the photo.
The focus distance will be set to Auto Macro.
Using the Beauty Shot mode
Take a photo of a person with options to hide facial imperfections.
Rotate the mode dial to
1
b
.
2
To make the subject's skin tone appear lighter (face
only), press [
m
].
Select
3
Functions Face Tone an option.
Select a higher setting to make skin tone appear lighter.t
Level 2
Back Move
Extended functions
30
Shooting modes
Using the Program mode
Set various options (except for shutter speed and aperture value)
in the Program mode.
Rotate the mode dial to
1
p
.
Set options. (For a list of options, refer to
2
“Shooting
options.”)
Align your subject in the frame and half-press [
3
Shutter]
to focus.
Press [
4
Shutter] to take the photo.
Using the DUAL IS mode
Reduce camera shake and prevent blurred photos with Optical
and Digital Image Stabilization functions.
Before correction After correction
Rotate the mode dial to
1
d
.
Align your subject in the frame and half-press [
2
Shutter]
to focus.
Press [
3
Shutter] to take the photo.
The digital zoom will not work in this mode.t
The photo will be corrected optically only when taken with a light t
source that is brighter than fluorescent light.
If your subject is moving rapidly, the photo may be blurry.t
Set the Optical Image Stabilization option to reduce camera shake in t
different shooting modes. (p. 21)
Extended functions
31
Shooting modes
Press [
4
m
].
Select
5
Functions Voice a sound option.
Option Description
On: Record a video with sound. (While you are zooming,
sound recording will be interrupted.)
Off: Record a video without sound.
Set other options as desired.
6
(For options, refer to “Shooting options.”)
Press [
7
Shutter] to start recording.
Press [
8
Shutter] again to stop recording.
Recording a video
Record videos of up to 20 minutes in length in high definition.
The recorded video is saved as an H.264 (MPEG4.AVC) file.
H.264 (MPEG4 part10/AVC) is a high-compression video format t
established by international standard organizations ISO/IEC and ITU-T.
Some memory cards may not support high definition recording. In this t
case, set a lower resolution. (p. 35)
When the Optical Image Stabilization (t ) is activated, your video may
be recorded with the OIS operation sound.
Rotate the mode dial to
1
v
.
Press [
2
m
].
Select
3
Functions Frame Rate a frame rate (the
number of frames per second).
As the number of frames increases, action appears more t
natural, but the file size is increased.
60 FPS is available only when the video resolution is 320 x 240.
Extended functions
32
Shooting modes
To pause recording
The camera allows you to pause temporarily while recording a
video. With this function, you can record your favorite scenes as
a single video.
Press [o] to pause while recording. Press it again to resume.
Stop Pause
Extended functions
33
Recording voice memos
Learn how to record a voice memo that you can play back at any time. You can add a voice memo to a photo as a short reminder of
shooting conditions.
You will get the best sound quality when recording 40 cm away from the camera.
apdbs
Adding a voice memo to a photo
In Shooting mode, press [
1
m
].
Select
2
Functions Voice Memo.
Align your subject in the frame and take a photo.
3
You will begin recording a voice memo right after taking the t
photo.
Record a short voice memo (10 seconds maximum).
4
Press [t Shutter] to stop recording a voice memo.
Recording a voice memo
In Shooting mode, press [
1
m
].
Select
2
Functions Voice Record.
Press [
3
Shutter] to record.
Stop Pause
Press [t
o
] to pause or resume recording.
You can record voice memos of up to 10 hours in length.t
Press [
4
Shutter] to stop.
Press [t Shutter] again to record a new voice memo.
Press [
5
m
] to switch to Shooting mode.
Selecting a resolution and quality ………… 35
Selecting a resolution ………………………… 35
Selecting image quality ………………………… 35
Using the timer ……………………………… 36
Shooting in the dark ………………………… 38
Preventing red-eye …………………………… 38
Using the flash ………………………………… 38
Adjusting the ISO speed ……………………… 39
Changing the camera’s focus ……………… 40
Using macro …………………………………… 40
Using auto focus ……………………………… 40
Adjusting the focus area ……………………… 41
Using face detection ………………………… 42
Detecting faces ………………………………… 42
Taking a self-portrait shot ……………………… 43
Taking a smile shot …………………………… 43
Detecting eye blinking ………………………… 44
Adjusting brightness and color …………… 45
Adjusting the exposure manually (EV) ………… 45
Compensating for backlighting (ACB) ………… 45
Changing the metering option ………………… 46
Selecting a light source (White balance) ……… 46
Using burst modes ………………………… 48
Improving your photos ……………………… 49
Applying photo styles ………………………… 49
Defining your own RGB tone ………………… 49
Adjusting your photos ………………………… 50
Shooting options
Learn about the options you can set in shooting mode.
Shooting options
35
Selecting a resolution and quality
Learn how to change the image resolution and quality settings.
When recording a video:
In the
1
v
mode, press [
m
].
Select
2
Functions Movie Size an option.
Option Description
1280 X 720 HQ: Play back high-quality files on an HDTV.
1280 X 720: Play back on an HDTV.
640 X 480: Play back on a general TV.
320 X 240: Post on a web page.
Selecting image quality
Photos you take are compressed and saved in JPEG format.
Higher quality images will result in larger sizes.
In Shooting mode, press [
1
m
].
Select
2
Functions Quality an option.
Option Description
Super Fine
Fine
Normal
The options may differ depending on the shooting mode.
apdbs
Selecting a resolution
As you increase the resolution, your photo or video will include
more pixels, so it can be printed on larger paper or displayed on
a larger screen. When you use a high resolution, the file size will
also increase.
When taking a photo:
In Shooting mode, press [
1
m
].
Select
2
Functions Photo Size an option.
Option Description
4000 X 3000: Print on A1 paper.
3984 X 2656: Print on A2 paper in wide ratio (3:2).
3968 X 2232: Print on A2 paper in panorama ratio (16:9)
or play back on an HDTV.
3264 X 2448: Print on A3 paper.
2592 X 1944: Print on A4 paper.
2048 X 1536: Print on A5 paper.
1920 X 1080: Print on A5 paper or play back on an
HDTV.
1024 X 768: Attach to email.
apdbsvS
Shooting options
36
Using the timer
Learn how to set the timer to delay shooting.
apdbsvS
Option Description
Remote: Take a photo in 2 seconds each time you
press the shutter button on the remote control.
The options may differ depending on the shooting mode.
Press [
3
Shutter] to start the timer.
The AF-assist light/timer lamp blinks. The camera will t
automatically take a photo at the specified time.
Press [t
t
] to cancel the timer.
Depending on the selected face detection option, the timer is not t
available or some timer options are not available.
In Shooting mode, press [
1
t
].
Off
Select an option.
2
Option Description
Off: The timer is not active.
10 Sec: Take a photo in 10 seconds.
2 Sec: Take a photo in 2 seconds.
Double: Take a photo in 10 seconds and take another
in 2 seconds.
Motion Timer: Detect your movement and then take a
photo. (p. 37)
Shooting options
37
Using the timer
Pose for your photo while the AF-assist light/timer lamp
6
is blinking.
The AF-assist light/timer lamp will stop blinking just before the t
camera automatically takes a photo.
The motion timer may not work when:
you are more than 3 m away from the camerat
your movements are too subtlet
there is too much light or backlightt
Using the motion timer
1
In Shooting mode, press [
t
].
Select
2
.
Press [
3
Shutter].
Stand within 3 m from the camera within 6 seconds after
4
pressing [Shutter].
Make a motion, such as waving your arms, to activate
5
the timer.
The AF-assist light/timer lamp will start to blink rapidly when t
the camera detects you.
The detection range
of the motion timer
Shooting options
38
Shooting in the dark
Learn how to take photos at night or in low light conditions.
Using the flash
Use the flash when taking photos in the dark or when you need
more light on your photos.
In Shooting mode, press [
1
F
].
Auto
Select an option.
2
Option Description
Off:
The flash will not fire.t
Camera shake warning (t ) will be displayed when
shooting in low light.
Auto: The camera will select a proper flash setting for
the detected scene in the
S
mode.
apbsS
Preventing red-eye
If the flash fires when you take a photo of a person in the dark, a
red glow may appear in the eyes. To prevent this, select Red-eye
or Red-eye Fix.
apbs
Shooting options
39
Shooting in the dark
Flash options are not available if you set burst options or select t
Self-Portrait or Blink Detection.
Make sure that your subjects are within the recommended distance t
from the flash. (p. 86)
If there is reflected light or much dust in the air, tiny spots may appear t
on your photo.
Adjusting the ISO speed
The ISO speed is the measure of a film’s sensitivity to light as
defined by the International Organization for Standardization (ISO).
The higher ISO speed you select, the more sensitive to light your
camera becomes. With a higher ISO speed, you can get a better
photo without using the flash.
In Shooting mode, press [
1
m
].
Select
2
Functions ISO an option.
Select t to use an appropriate ISO speed based on the
brightness of the subject and lighting.
The higher ISO speed you select, the more image noise you may get.t
When t Motion Capture is set, ISO speed will be set to Auto.
When you set the ISO speed to 3200, you can select only 3M or t
lower resolution.
p
Option Description
Red-eye Fix*:
The flash fires when the subject or background is t
dark.
The camera corrects red-eyes through its advanced t
software analysis.
Slow Sync:
The flash fires and the shutter stays open longer.t
Select this when you want to capture ambient light to t
reveal more details in the background.
Use a tripod to prevent your photos from blurring.t
Fill in:
The flash always fires.t
Light intensity is adjusted automatically.t
Red-eye*:
The flash fires when the subject or background is t
dark.
The camera reduces red-eyes.t
Auto: The flash fires automatically when the subject or
background is dark.
The options may differ depending on the shooting mode.
* There is an interval between two bursts of the flash. Do not move until
the flash fires a second time.
Shooting options
40
Changing the camera’s focus
Learn how to adjust the camera's focus according to your subjects.
Using auto focus
To take sharp photos, select the appropriate focus according to
your distance from the subject.
In Shooting mode, press [
1
M
].
Normal (AF)
Select an option.
2
Option Description
Normal (AF): Focus on a subject farther than 80 cm.
Macro: Focus on a subject 5-80 cm (50-80 cm when
using zoom).
Auto Macro: Focus on a subject farther than 5 cm
(farther than 50 cm when using zoom).
The options may differ depending on the shooting mode.
apdv
Using macro
Use macro to take close-up photos of subjects, such as flowers
or insects. Refer to macro options in “Using auto focus.”
Try to hold the camera very still to prevent blurry photos.t
Turn off the flash if the distance to the subject is less than 40 cm.t
apdv
Shooting options
41
Changing the camera’s focus
Adjusting the focus area
You can get clearer photos by selecting an appropriate focus
area according to your subject’s location in the scene.
In Shooting mode, press [
1
m
].
Select
2
Functions Focus Area an option.
Option Description
Center AF: Focus on the center (suitable when subjects
are located in the center).
Multi AF: Focus on one or more of 9 possible areas.
The options may differ depending on the shooting mode.
apdbs
Shooting options
42
Using face detection
If you use face detection options, your camera can automatically detect a human face. When you focus on a human face, the camera
adjusts the exposure automatically. Take photos quickly and easily by using Blink Detection to detect closed eyes or Smile Shot to
capture a smiling face.
apdbs
Detecting faces
Your camera automatically detects human faces (up to 10 human
faces).
In Shooting mode, press [
1
m
].
Select
2
Functions Face Detection Normal.
The closest face appears in a white focus frame and the rest t
of the faces appear in grey focus frames.
The closer you are to the subject, the quicker your camera will detect faces.
Face detection may not be effective when:t
the subject is far from the camera (The focus frame will appear -
orange for Smile Shot and Blink Detection)
it is too bright or too dark -
the subject is not facing the camera -
the subject is wearing sunglasses or a mask -
the subject is in backlighting or the lighting condition is unstable -
the subject’s facial expression changes remarkably -
Face detection is not available when using a photo style or saturation.t
When you use the face detection option, the digital zoom will not work.t
Depending on the selected face detection option, the timer is not t
available or some timer options are not available.
The options may differ depending on the shooting mode.t
Shooting options
43
Using face detection
Taking a smile shot
The camera automatically releases the shutter when it detects a
smiling face.
In Shooting mode, press [
1
m
].
Select
2
Functions Face Detection Smile Shot.
When your subject smiles broadly, your camera can detect t
the smile more easily.
Taking a self-portrait shot
Take photos of yourself. The focus distance will be set to
close-up and your camera will emit a beep.
In Shooting mode, press [
1
m
].
Select
2
Functions Face Detection Self-Portrait.
When your hear a quick beep, press [
3
Shutter].
To turn the beep on or off, select Self-Portrait in the sound settings. (p. 74)
Shooting options
44
Using face detection
Detecting eye blinking
If your camera detects closed eyes, it will automatically take
2 photos in succession.
In Shooting mode, press [
1
m
].
Select
2
Functions Face Detection Blink
Detection.
Hold your camera still while t “Capturing” is displayed on the screen.
When blink detection fails, t “Picture taken with eyes closed.”
message appears. Take another photo.
Shooting options
45
Adjusting brightness and color
Learn how to adjust the brightness and color for better image quality.
Compensating for backlighting (ACB)
When the light source is behind your subject or there is high
contrast between your subject and the background, your subject
is likely to appear dark in the photo. In this case, set the Auto
Contrast Balance (ACB) option.
Without ACB With ACB
In Shooting mode, press [
1
m
].
Select
2
Functions ACB an option.
Option Description
Off: ACB is off.
On: ACB is on.
The ACB feature is always on in the t
a
mode.
You cannot set burst options when this feature is on.t
p
Adjusting the exposure manually
(EV)
Depending on the intensity of the ambient light, your photos
may be too bright or dark. In these cases, you can adjust the
exposure to get a better photo.
Darker (-) Neutral (0) Brighter (+)
In Shooting mode, press [
1
m
].
Select
2
Functions EV.
Select a value to adjust the exposure.
3
Once you adjust the exposure, the setting will remain the same. You t
may need to change the exposure value later to avoid overexposure
or underexposure.
If you cannot decide on an appropriate exposure, select t AEB (Auto
Exposure Bracket). The camera takes photos with different exposures:
normal, underexposed, and overexposed. (p. 48)
pdv
Shooting options
46
Adjusting brightness and color
Selecting a light source
(White balance)
The color of your photo depends on the type and quality of the
light source. If you want the color of your photo to be realistic,
select an appropriate lighting condition to calibrate the white
balance, such as Auto WB, Daylight, Cloudy, or Tungsten.
(Auto WB) (Daylight)
(Cloudy) (Tungsten)
pdv
Changing the metering option
The metering mode refers to the way in which a camera
measures the quantity of light. The brightness and lighting of your
photos will vary depending on the metering mode you select.
In Shooting mode, press [
1
m
].
Select
2
Functions Metering.
Option Description
Multi:
Your camera divides the scene into several areas, and t
then measures the light intensity of each area.
Suitable for general photos.t
Spot:
Your camera measures only the light intensity of the t
very center of the frame.
If a subject is not in the center of the scene, your t
photo may be improperly exposed.
Suitable for a subject with backlighting.t
Center–weighted:
Your camera averages the meter reading of the entire t
frame with emphasis placed on the center.
Suitable for photos with subjects in the center of the t
frame.
pdv
Shooting options
47
Adjusting brightness and color
Defining your own white balance
In Shooting mode, press [
1
m
].
Select
2
Functions White Balance
Measure: Shutter.
Aim the lens at a piece of white paper.
3
Press [
4
Shutter].
In Shooting mode, press [
1
m
].
Select
2
Functions White Balance an option.
Icon Description
Auto WB: Use automatic settings depending on the
lighting conditions.
Daylight: Select when taking outdoor photos on a
sunny day.
Cloudy: Select when taking outdoor photos on a cloudy
day or in shadows.
Fluorescent_H: Select when shooting under a daylight
fluorescent or three-way fluorescent light.
Fluorescent_L: Select when shooting under white
fluorescent light.
Tungsten: Select when taking indoor photos under
incandescent bulbs or halogen lamps.
Measure: Shutter (Custom setting): Use your
pre-defined settings.
Shooting options
48
Using burst modes
It can be difficult to take photos of fast-moving subjects or capture natural facial expressions and gestures of your subjects in photos. In
these cases, select one of the burst modes.
ps
Option Description
AEB:
Take 3 photos with different exposures: normal, t
underexposed, and overexposed.
Use a tripod to prevent blurry photos.t
The options may differ depending on the shooting mode.
You can use the flash, timer, and ACB only when you select t
Single.
When you select t Motion Capture, the resolution will be set to
VGA and the ISO speed will be set to Auto.
In Shooting mode, press [
1
m
].
Select
2
Functions Drive an option.
Option Description
Single: Take a single photo.
Continuous:
t While you are pressing [Shutter], the camera takes
photos continuously.
The maximum number of photos depends on the t
capacity of your memory card.
Motion Capture:
t While you are pressing [Shutter], the camera takes
VGA photos (6 photos per second; maximum of 30
photos).
The camera automatically shows you the photos just t
taken and then saves them.
Shooting options
49
Improving your photos
Learn how to improve your photos by applying photo styles or colors, or make some adjustments.
Defining your own RGB tone
In Shooting mode, press [
1
m
].
Select
2
Functions Photo Style Selector Custom
RGB.
Select a color (R: Red, G: Green, B: Blue).
3
Back Move
Adjust the amount of the selected color.
4
(-: less or +: more)
Applying photo styles
Apply a different photo style to your photos, such as Soft, Vivid,
or Forest.
Soft Vivid Forest
In Shooting mode, press [
1
m
].
Select
2
Functions Photo Style Selector an option.
Select t Custom RGB to define your own RGB tone.
Select t Normal if you want to use face detection options.
Depending on the selected photo style, some image adjustment t
options are not available.
apdsv
Shooting options
50
Improving your photos
Saturation option Description
-Decrease the saturation.
+Increase the saturation.
Select t 0 if you do not want to apply any effects. (suitable for printing)
Depending on the selected image adjustment option, some photo t
styles are not available.
Adjusting your photos
Adjust the contrast, sharpness, and saturation of your photos.
In Shooting mode, press [
1
m
].
Select
2
Functions Image Adjust.
Select an adjustment option.
3
Contrastt
Sharpnesst
Saturationt
Select a value to adjust the selected item.
4
Contrast option Description
-Decrease the color and brightness.
+Increase the color and brightness.
Sharpness option Description
-Soften the edges on your photos (suitable for
editing the photos on your computer).
+
Sharpen the edges to improve the clarity
of your photos. This may also increase the
noise on your photos.
p
Playing back ……………………………………………… 52
Starting Playback mode …………………………………… 52
Viewing photos ……………………………………………… 56
Playing a video ……………………………………………… 57
Playing voice memos ……………………………………… 58
Editing a photo …………………………………………… 59
Resizing photos …………………………………………… 59
Rotating a photo …………………………………………… 59
Applying photo styles ……………………………………… 60
Defining your own RGB tone ……………………………… 60
Correcting exposure problems …………………………… 61
Creating a print order (DPOF) ……………………………… 62
Viewing files on a TV or HDTV ………………………… 63
Transferring files to your computer …………………… 65
For Windows users ………………………………………… 65
For Mac users ……………………………………………… 70
Printing photos with a photo printer (PictBridge) …… 71
Playback/Editing
Learn how to play back photos, videos, or voice memos and
edit photos or videos. Also, learn how to connect your camera
to your computer, photo printer, TV, or HDTV.
Playback/Editing
52
Playing back
Learn actions to play back photos, videos, or voice memos, and managing files.
Display in Playback mode
Icon Description
Photo includes a voice memo
v
Video file
Print order has been set (DPOF)
Protected file
Folder name – File name
Starting Playback mode
View photos or play videos and voice memos stored in your
camera.
Press [
1
P
].
The most recent file you have taken or recorded will be t
displayed.
If the camera is off, it will turn on.t
Press [
2
F
] or [
t
] to scroll through files.
Press and hold [t
F
] or [
t
] to view files quickly.
If you want to view files stored in the internal memory, remove your memory
card.
Playback/Editing
53
Playing back
Press [
4
F
] or [
t
] to view files.
Press and hold [t
F
] or [
t
] to select a date, file type,
weekday, or color.
Press [
5
o
] to return to the normal view.
Viewing files as thumbnails
Scan thumbnails of files.
In Playback mode, push [Zoom] down to display 9
or 20 thumbnails (push [Zoom] up to return to the
previous mode).
Filter
To Do this
Scroll through files Press [
D
], [
M
], [
F
], or [
t
].
Delete files Press [
f
] and select Yes.
Viewing files by category in Smart Album
View and manage files by categories, such as date, file type, or
week.
In Playback mode, push [
1
Zoom] down.
Press [
2
m
].
Select a category.
3
Type
Date
Colour
Week
Back Set
Option Description
Type View files by the file type.
Date View files by the date they were saved.
Colour View files by the dominant color of the image.
Week View files by the weekday they were saved.
It may take some time for the camera to change the category and
recognize files.
Playback/Editing
54
Playing back
Deleting files
Delete single files or all files at once. You cannot delete protected
files.
To delete a single file,
In Playback mode, select a file and press [
1
f
].
Select
2
Yes to delete the file.
To delete multiple files,
In Playback mode, press [
1
f
].
Select
2
Multiple Delete.
Select files you want to delete and press [
3
o
].
Press [t
o
] again to cancel your selection.
Press [
4
f
].
Select
5
Yes .
To delete all files,
In Playback mode, press [
1
m
].
Select
2
File Options Delete All Yes .
Protecting files
Protect your files from accidental deletion.
In Playback mode, press [
1
m
].
Select
2
File Options Protect Select.
To protect all files, select t All Lock.
Select the file you want to protect and press [
3
o
].
Press [t
o
] again to cancel your selection.
Select Set
Press [
4
f
].
Playback/Editing
55
Playing back
Copying files to the memory card
You can copy files from the internal memory to a memory card.
In Playback mode, press [
1
m
].
Select
2
File Options Copy to Card.
Select
3
Yes to copy files.
Using the recycle bin
If you activate the recycle bin, files you delete will be sent to the
recycle bin instead of being deleted permanently. This applies to
single files or selected files only–if you choose to delete all files,
those files will not be sent to the recycle bin.
To activate the recycle bin,
In Playback mode, press [
1
m
].
Select
2
File Options Recycle Bin On.
To restore files from the recycle bin,
In Playback mode, press [
1
m
].
Select
2
File Options Recycle Bin Retrieve.
This function does not work for videos or voice memos.t
It may take longer to delete files when using the recycle bin function.t
If you format the internal memory, all files in the recycle folder will be t
deleted.
The recycle bin will hold up to 10 MB of files. Once you exceed the t
10 MB limit, the camera asks you whether to empty the recycle bin.
Select Yes to empty the recycle bin or No to delete only the current
file.
Playback/Editing
56
Playing back
Starting a slide show
You can apply effects and audio to your slide show.
In Playback mode, press [
1
m
].
Select
2
Multi Slide Show.
Select a slide show effect option.
3
Skip to step 5 to start a slide show with no effects.t
Option Description
Images
Set the photos you want to view as a slide show.
Allt : View all photos in a slide show.
Datet : View photos captured on a specific date in
a slide show.
Selectt : View selected photos in a slide show.
Effect Select a transition effect.t
Select t Off for no effects.
Interval
Set the interval between photos.t
This is available when t Off is selected in the effect
option.
When used with effect options other than t Off, the
interval will be set to 1 sec.
Music Select a background audio.
Viewing photos
Zoom in on part of a photo or view photos in a slide show.
Enlarging a photo
In Playback mode, push [Zoom] up to enlarge
a photo (push [Zoom] down to reduce a
photo).
The enlarged area and zoom ratio are indicated on the top of the
screen. The maximum zoom ratio may vary depending on the
resolution.
Trim
To Do this
Move the enlarged area Press [
D
], [
M
], [
F
], or [
t
].
Trim the enlarged photo Press [
o
] (it will be saved as a new file).
Playback/Editing
57
Playing back
Use the following buttons to control playback.
2
Press To
[
F
]Scan backward.
[
o
]Pause or resume playback.
[
t
]Scan forward.
[Zoom] up or down Adjust the volume level.
Trimming a video during playback
Press [
1
o
] at the point where you want the new video to
begin and push [Zoom] up.
Press [
2
o
] to resume playback.
Press [
3
o
] at the point where you want the new video to
end and push [Zoom] up.
Select
4
Yes .
The original video should be at least 10 seconds long.t
The edited video will be saved as a new file.t
Set the slide show effect.
4
Select
5
Start Play.
To loop the slide show, select t Repeat.
Press [t
o
] to pause or resume the slide show.
Playing a video
You can play a video, capture an image from a video, or crop a
video.
In Playback mode, select a video and press [
1
o
].
Pause
Playback/Editing
58
Playing back
Playing a voice memo added to a photo
In Playback mode, select a photo that includes a voice
memo and press [
o
].
Press [t o] to pause or resume playback.
Capturing an image during playback
Press [
1
o
] at the point where you want to save a still
image.
Press [
2
M
].
A captured image will have the same file size as the original video file and will
be saved as a new file.
Playing voice memos
Playing a voice memo
In Playback mode, select a voice memo and press [
1
o
].
Use the following buttons to control playback.
2
Press To
[
F
]Scan backward.
[
o
]Pause or resume playback.
[
t
]Scan forward.
[
M
]Stop playback.
[Zoom] up or down Adjust the volume level.
Playback/Editing
59
Editing a photo
Perform photo editing tasks, such as resizing, rotating, eliminating red-eyes, and adjusting brightness, contrast, or saturation.
Edited photos will be saved as new files.
Rotating a photo
In Playback mode, select a photo and press [
1
m
].
Select
2
Edit Rotate an option.
Back
Right 90°
Move
Depending on the original photo size, the rotated photo may be resized to a
lower resolution.
Resizing photos
In Playback mode, select a photo and press [
1
m
].
Select
2
Edit Resize an option.
Back Move
Select t to save the photo as a start image. (p. 74)
Available options differ depending on the size of the selected photo.t
Playback/Editing
60
Editing a photo
Defining your own RGB tone
1
In Playback mode, select a photo and press [
m
].
Select
2
Edit Photo StyleSelector Custom RGB.
Select a color (R: Red, G: Green, B: Blue).
3
Back Move
Adjust the amount of the selected color.
4
(-: less or +: more)
Applying photo styles
Apply a different photo style to the photo, such as Soft, Vivid, or
Forest.
Soft Vivid Forest
In Playback mode, select a photo and press [
1
m
].
Select
2
Edit Photo StyleSelector an option.
Select t Custom RGB to define your own RGB tone.
Back
Soft
Move
Playback/Editing
61
Editing a photo
Correcting exposure problems
Adjust ACB (Auto Contrast Balance), brightness, contrast, or
saturation; remove red-eye; hide facial imperfections; or add
noise to the photo.
Adjusting ACB (Auto Contrast Balance)
In Playback mode, select a photo and press [
1
m
].
Select
2
Edit Image Adjust ACB.
Removing red-eye
In Playback mode, select a photo and press [
1
m
].
Select
2
Edit Image Adjust Red-eye Fix.
Hiding facial imperfections
In Playback mode, select a photo and press [
1
m
].
Select
2
Edit Image Adjust Face Retouch.
Select a level.
3
As the number increases, the face becomes clearer.t
Adjusting brightness/contrast/saturation
In Playback mode, select a photo and press [
1
m
].
Select
2
Edit Image Adjust.
Select an adjustment option.
3
t : Brightness
t : Contrast
t : Saturation
Select a value to adjust the selected item.
4
(-: less or +: more)
Adding noise to the photo
In Playback mode, select a photo and press [
1
m
].
Select
2
Edit Image Adjust Add Noise.
Playback/Editing
62
Editing a photo
Press [
4
m
].
Select
5
File Options DPOF Size an option.
Option Description
Select Specify the print size for the selected photo.
All Specify the print size for all photos.
Reset Reset your settings.
If you select
6
Select, scroll to a photo and press [Zoom]
up or down to select the print size. Repeat for the
photos you want and press [
f
].
If you select t All, press [
D
] or [
M
] to select the print size
and press [
o
].
Printing photos as thumbnails
In Playback mode, press [
1
m
].
Select
2
File Options DPOF Index Yes .
If you specify the print size, you can print photos only with DPOF 1.1-compatible
printers.
Creating a print order (DPOF)
Select photos to be printed and set options, such as number of
copies or paper size.
The memory card can be taken to a print shop that supports DPOF t
(Digital Print Order Format) or you can print photos directly through a
DPOF-compatible printer at home.
Wide photos may print with the left and right edges cut off, so be t
aware of the dimensions of your photos.
You cannot set the DPOF for the photos stored in the internal memory.t
In Playback mode, press [
1
m
].
Select
2
File Options DPOF Standard an option.
Option Description
Select Print the selected photos.
All Print all photos.
Reset Reset your settings.
If you select
3
Select, scroll to a photo and press [Zoom]
up or down to select the number of copies. Repeat for
the photos you want and press [
f
].
If you select t All, press [
D
] or [
M
] to select the number of
copies and press [
o
].
Playback/Editing
63
Viewing files on a TV or HDTV
Play back photos or videos by connecting your camera to a TV using the A/V cable.
On some TVs, digital noise may occur or part of an image may not t
appear.
Images may not appear centered on the TV screen depending on t
your TV settings.
You can capture photos or videos while the camera is connected t
to a TV.
Viewing files on an HDTV
You can view high-quality and uncompressed photos or videos
on an HDTV using the optional HDMI cradle. HDMI (High Definition
Multimedia Interface) is supported by most HDTVs.
For details, see the “HDMI cradle manual.”
In Shooting or Playback mode, press [
1
m
].
Select
2
Settings HDMI Size.
Select an HDMI resolution.
3
Turn off your camera and HDTV.
4
Select a video signal output according to your country or
1
region. (p. 76)
Turn off your camera and TV.
2
Connect your camera to your TV using the A/V cable.
3
Video Audio
Turn on your TV and select the video output mode using
4
the TV remote control.
Turn on your camera and press [
5
P
].
View photos or play videos using the buttons on your
6
camera.
Playback/Editing
64
Viewing files on a TV or HDTV
Insert your camera into the cradle and plug the HDMI
5
cable into the HDTV and the cradle.
Disconnect the A/V cable if it is connected to the cradle.
HDMI cable
Turn on your camera.
6
The HDTV will be powered on automatically and the camera t
screen will be displayed.
View files using the buttons on your camera or a remote
7
control of your camera or HDTV.
If your HDTV supports the Anynet+(CEC) profile, turn the Anynet+ on in the
settings menu (p. 76) to control all connected Samsung A/V devices with the
TV remote control. For details, see the “HDMI cradle manual.”
Playback/Editing
65
Transferring files to your computer
Requirements for QuickTime Player 7.5
Intel Pentium 4, 3.2 GHz or higher/AMD Athlin 64FX, t
2.6 GHz or higher
Windows XP service pack2 or Vistat
Minimum 512 MB RAM (1 GB and above recommended)t
64 MB or greater video card (nVIDIA Geforce 7600GT or higher/ t
ATI X1600 series or higer recommended)
Using a self-assembled PC or a PC and OS that are not supported t
may void your warranty.
The programs may not work properly on 64-bit Edition of Windows t
XP and Vista.
Programs contained on the CD
Program Purpose
Samsung Master Edit photos and videos.
QuickTime Player 7.5 View videos (H.264 (MPEG4.AVC) files)
on a PC.
Adobe Reader View the user manual.
For Windows users
Transfer files by connecting your camera to your PC.
Installing programs
Hardware and software requirements
Item Requirements
CPU Pentium III 500 MHz or better
(Pentium III 800 MHz or better recommended)
RAM 256 MB or more (512 MB or more recommended)
OS Windows 2000/XP/Vista
Hard disk
capacity 250 MB or more (1 GB or more recommended)
Others
USB portt
CD-ROM drivet
1024 x 768 pixels, 16-bit color display compatible t
monitor (24-bit color display recommended)
Microsoft Direct X 9.0C or latert
Playback/Editing
66
Transferring files to your computer
Transferring files to your PC
Once you connect the camera to your PC, the camera will be
recognized as a removable drive.
The battery will be charged while the camera is connected to a PC with the
USB cable.
Connect your camera to your PC with the USB cable.
1
You must plug the end of the cable with the indicator light (S) into
your camera. If the cable is reversed, it may damage your files. The
manufacturer is not responsible for any loss of data.
Insert the installation CD in a compatible CD-ROM drive.
1
When the setup screen is displayed, click
2
Samsung
Digital Camera Installer to start installation.
Select programs to install and follow the onscreen
3
instructions.
Click
4
Exit to complete the installation and restart your
computer.
Playback/Editing
67
Transferring files to your computer
Disconnecting the camera (for Windows XP)
The way to disconnect the USB cable for Windows 2000/Vista
is similar.
If the status lamp on your camera is blinking, wait until
1
it stops.
Click
2
on the tool bar at the bottom right of your PC
screen.
Click the pop-up message.
3
Remove the USB cable.
4
Turn on the camera.
2
The computer recognizes the camera automatically.t
If the camera fails to connect, a pop-up window will appear. Select
Computer.
On your PC, select
3
My Computer Removable Disk
DCIM 100SSCAM.
Select the files you want and drag or save them to your
4
PC.
Playback/Editing
68
Transferring files to your computer
Click
2
Next and follow the onscreen instructions.

No. Description
Select a location for downloaded files.
Click to download the selected files.
Thumbnails of files; click an image to download.
Using Samsung Master
You can download files or edit photos or videos stored on your
PC. For details, see the Help menu.
This program does not support editing of video files (H.264 (MPEG4.
AVC)) on the camera.
Downloading files using Samsung Master
When you connect the camera to the PC, a window for
downloading files automatically appears.
Select the files you want to download.
1
Playback/Editing
69
Transferring files to your computer
No. Description
Toolbar
Menus
Click for more information about the program.
Click to enlarge or reduce the thumbnails in the list.
Change the mode.
t : View mode
t : Edit mode for photos
t : Edit mode for videos
Preview information about the selected file.
The photos in the selected folder; double-click to switch to
full-screen view.
Using the Samsung Master Interface
Playback/Editing
70
Transferring files to your computer
Turn on the camera.
2
The computer recognizes the camera automatically and a t
removable disk icon will be displayed.
Double-click the removable disk icon.
3
Transfer photos or videos to the computer.
4
For Mac users
When you connect the camera to a Macintosh computer, the
computer will recognize the device automatically. You can transfer
files directly from the camera to the computer without installing
any programs.
Requirements for QuickTime Player 7.5
1.8 GHz Power Mac G5/1.83 GHz Intel Core Duo or highert
Mac OS X version 10.3.9 or latert
Minimum 256 MB RAM (1 GB and above recommended)t
64 MB or greater video cardt
Connect your camera to a Macintosh computer with the
1
USB cable.
You must plug the end of the cable with the indicator light (S) into
your camera. If the cable is reversed, it may damage your files. The
manufacturer is not responsible for any loss of data.
Playback/Editing
71
Printing photos with a photo printer (PictBridge)
Print photos with a PictBridge-compatible printer by connecting your camera directly to the printer.
Configuring print settings
Images
Size
Layout
Type
Quality
Exit Print
: One Photo
: Auto
: Auto
: Auto
: Auto
Option Description
Images: Select whether to print the current photo or all
photos.
Size: Specify the size of the print.
Layout: Create thumbnail prints.
Type: Select the type of paper.
Quality: Set the printing quality.
Date: Set to print the date.
File Name: Set to print the name of the file.
Reset: Reset the print options.
Some options are not supported by some printers.
With the printer on, connect your camera to the printer
1
with the USB cable.
Turn on your camera.
2
The printer recognizes the camera automatically.t
If the camera fails to connect, a pop-up window will appear. t
Select Printer.
If your printer has the mass storage feature, you must first set the t
USB mode to Printer in the settings menu. (p. 77)
Press [
3
F
] or [
t
] to select a photo.
Press [t
m
] to set printing options. See “Configuring print
settings.”
Press [
4
o
] to print.
Printing starts. Press [t
F
] to cancel printing.
Camera settings menu …………………………………… 73
Accessing the settings menu ……………………………… 73
Sound ……………………………………………………… 74
Display ……………………………………………………… 74
Settings ……………………………………………………… 75
Error messages …………………………………………… 78
Camera maintenance …………………………………… 79
Cleaning your camera ……………………………………… 79
About memory cards ……………………………………… 80
About the battery …………………………………………… 81
Before contacting a service center …………………… 83
Camera specifications …………………………………… 86
FCC notice ………………………………………………… 90
Index ………………………………………………………… 91
Appendixes
Refer to settings, error messages, specifications, and
maintenance tips.
Appendixes
73
Camera settings menu
Learn about various options to configure your camera's settings.
Select an option and save your settings.
3
Volume
Start Sound
Shutter Sound
Beep Sound
AF Sound
Self-Portrait
Back Set
: On
Off
Low
Medium
High
Press [
4
m
] to return to the previous screen.
Accessing the settings menu
In Shooting or Playback mode, press [
1
m
].
Select a menu.
2
Functions
Sound
Display
Settings
Exit Change
Volume
Start Sound
Shutter Sound
Beep Sound
AF Sound
Self-Portrait
Menu Description
Sound: Set various camera sounds and volume.
(p. 74)
Display: Customise the display settings, such as
language and brightness. (p. 74)
Settings: Change the settings for the camera system,
such as memory format, default file name, and USB
mode. (p. 75)
Appendixes
74
Camera settings menu
Display
* Default
Item Description
Language Select a language for the display text.
Function
Description
Display a brief description of an option or menu.
(Off, On*)
Start Image
Set a start image to display when the camera turns
on.
Offt *: Display no start image.
Logot : Display a default image stored in the internal
memory.
User Imaget : Display the image you want. (p. 59)
Only one start image will be saved in the internal t
memory.
If you select a new photo as a start image or reset t
your camera, the current image will be deleted.
A wide image or image in 3:2 ratio cannot be set t
as a start image.
Display
Brightness
Adjust the brightness of the screen. (Auto*, Dark,
Normal, Bright)
Normal is fixed in Playback mode even if Auto is selected.
Quick View
Set the duration for reviewing a captured image or
video before returning to Shooting mode.
(Off, 0.5 sec*, 1 sec, 3 sec)
Power Save
If you perform no operations for 30 seconds, the
camera automatically switches to Power save mode
(press any button to deactivate the Power save
mode). (Off*, On)
Sound
* Default
Item Description
Volume Adjust the volume of any sound.
(Off, Low, Medium*, High)
Start Sound Select a sound to be emitted when turning on your
camera. (Off*, 1, 2, 3)
Shutter Sound Select a sound to be emitted when pressing the
shutter button. (Off, 1*, 2, 3)
Beep Sound Select a sound to be emitted when pressing the
buttons or switching modes. (Off, 1*, 2, 3)
AF Sound Set a sound to be emitted when half-pressing the
shutter button. (Off, On*)
Self-Portrait Set a sound to be emitted when the camera
detects your face. (Off, On*)
Appendixes
75
Camera settings menu
* Default
Item Description
File No.
Specify how to name files.
Resett : Set the file number to start from 0001 when
inserting a new memory card, formatting a memory
card, or deleting all files.
Seriest *: Set the file number to follow the previous
file number when inserting a new memory card,
formatting a memory card, or deleting all files.
The default name of the first folder is 100SSCAM t
and the default name of the first file is SDC10001.
The file number increases one by one from t
SDC10001 to SDC19999.
The folder number increases one by one from t
100SSCAM to 999SSCAM.
The maximum number of files that can be stored in t
one folder is 9999.
The camera defines file names according to the t
Digital rule for Camera File system (DCF) standard.
If you change the names of files intentionally, the
camera may not play back the files.
Settings
* Default
Item Description
Format
Format the internal memory and the memory card
(all files-including the protected files-will be deleted).
(Yes, No)
If you use a memory card used with cameras from
different manufacturers or a memory card reader, or one
formatted on a computer, your camera may read the
card incorrectly. Format the card before using it.
Reset
Reset menus and shooting options (date and time,
language, and video output settings will not be reset).
(Yes, No)
Date & Time Set the date and time and select a date format.
(dd/mm/yyyy, mm/dd/yyyy, yyyy/mm/dd, Off*)
Time Zone Select a region and set the daylight-saving time (DST).
Appendixes
76
Camera settings menu
* Default
Item Description
Video Out
Set the video signal output according to your
region.
NTSCt *: USA, Canada, Japan, Korea, Taiwan,
Mexico.
PAL t (supports only BDGHI): Australia, Austria,
Belgium, China, Denmark, Finland, Germany,
England, Italy, Kuwait, Malaysia, New Zealand,
Singapore, Spain, Sweden, Switzerland,
Thailand, Norway.
AF Lamp Set an assistant light to help you focus in dark
places. (Off, On*)
Anynet+
(HDMI-CEC)
Set to control the camera connected to a Samsung
HDTV that supports Anynet+(CEC) with the TV
remote control.
Ont *: Control the camera with an HDTV remote
control.
Offt : View files without using an HDTV remote
control.
* Default
Item Description
Imprint
Set whether to display the date and time on your
photos when printing. (Off*, Date, Date & Time)
The date and time will be displayed on the t
bottom-right corner of the photo in yellow.
The date and time may not be printed on some t
printer models.
If you selectt Text in the
s
mode, the date
and time will not be displayed.
Auto Power Off
Set the camera to automatically turn off when you
are not using it. (Off, 1 min, 3 min*, 5 min,
10 min)
Your settings will not change after replacing the t
battery.
The camera will not automatically turn off when:t
it is connected to a computer or printer -
you are playing a slide show or videos -
you are recording a voice memo -
Appendixes
77
Camera settings menu
* Default
Item Description
HDMI Size
Select the resolution of photos when playing back
files on an HDTV with the HDMI cradle.
(NTSC: 1080i*, 720p, 480p/
PAL: 1080i*, 720p, 576p)
If the HDTV does not support the selected resolution,
the HDTV automatically selects the next lower
resolution.
USB
Set the function to use via a USB connection with a
computer or printer.
Autot *: Set your camera to select a USB mode
automatically.
Computert : Connect your camera to a computer
for transferring files.
Printert : Connect your camera to a printer for
printing files.
Appendixes
78
Error messages
When the following error messages appear, try these remedies.
Error message Suggested remedies
Card Error
Turn off your camera and then turn it on again.t
Remove your memory card and insert it again.t
Format your memory card. (p. t 75)
Card Locked
Unlock the memory card.
DCF Full Error
File names do not match the DCF standard.
Transfer the files on the memory card to your
computer and format the card. (p. 75)
File Error Delete the damaged file or contact a service
center.
Low Battery Insert a charged battery or recharge the battery.
Low Light Turn on the flash. (p. 38)
Memory Full Delete unnecessary files or insert a new memory
card.
No Image File Take photos or insert a memory card that has
some photos.
Appendixes
79
Camera maintenance
Camera body
Wipe gently with a soft, dry cloth.
Never use benzene, thinners, or alcohol to clean the device. These t
solutions can damage the camera or cause it to malfunction.
Do not press on the lens cover or use a blower brush on the lens t
cover.
Cleaning your camera
Camera lens and display
Use a blower brush to remove dust and wipe the lens gently with
a soft cloth. If any dust remains, apply lens cleaning liquid to a
piece of cleaning paper and wipe gently.
Appendixes
80
Camera maintenance
Memory card capacity
The memory capacity may differ depending on shooting scenes
or shooting conditions. These capacities are based on a 1 GB
SD card:
Size Super
fine Fine Normal 60 FPS 30 FPS 15 FPS
P
h
o
t
o
s
142 274 389 - - -
162 302 426 - - -
195 355 509 - - -
204 361 518 - - -
327 547 764 - - -
514 774 1028 - - -
840 1104 1387 - - -
1420 1612 1807 - - -
*
V
i
d
e
o
s
----
Approx.
12’ 22’’
Approx.
22 min
----
Approx.
13’ 57’’
Approx.
25 min
----
Approx.
24min
Approx.
46 min
---
Approx.
49 min
Approx.
70 min
Approx.
91 min
* The recordable time may vary if you use the zoom.
Several videos were recorded in succession to determine the total
recording time.
About memory cards
Memory cards you can use
You can use SD (Secure Digital), SDHC (Secure Digital High
Capacity), or MMC (Multimedia Card) memory cards.
Terminal
Label (front)
Write-protect switch
You can prevent files from being deleted by using a write-protect
switch on the SD or SDHC card. Slide the switch down to lock or
slide it up to unlock. Unlock the card when shooting.
Appendixes
81
Camera maintenance
Battery life
Shooting time /
Number of photos
Shooting conditions
(when the battery is fully charged)
Photos Approx. 140 min/
Approx. 280
This is measured under the following
conditions: in the
a
mode, 12M
resolution, Fine quality, OIS on.
1. Set the flash option to Fill in, take a
single shot, and zoom in or out.
2. Set the flash option to Off, take a
single shot, and zoom in or out.
3. Perform steps 1 and 2 for 30
seconds and repeat for 5 minutes.
Then turn off the camera for
1 minute.
4. Repeat steps 1 to 3.
Videos Approx. 130 min Record videos at 640 x 480 resolution
and 30 fps.
The figures above are measured by Samsung’s standards and may differ t
depending on actual usage.
Several videos were recorded in succession to determine the total recording t
time.
About the battery
Use only Samsung-approved batteries.
Battery specifications
Mode SLB-10A
Type Lithium-ion battery
Cell capacity 1050 mAh
Voltage 3.7 V
Charging time
(when the camera is switched off) Approx. 150 min
Appendixes
82
Camera maintenance
Notes about charging the battery
If the indicator light is off, make sure that the battery is inserted t
correctly.
Turn off your camera when charging.t
Turn on your camera after charging the battery for more than 10 t
minutes.
Using the flash or recording videos depletes the battery quickly. t
Charge the battery until the indicator light turns green.
If the indicator light blinks in red or does not illuminate, reconnect the t
cable, or remove the battery and insert it again.
If you charge the battery when it is warm, the indicator light may turn t
orange. Charging will start when the battery cools down.
Notes about charging with a computer connected
Use only the provided USB cable.t
The battery may not be charged when:t
you use a USB hub -
other USB devices are connected to your computer -
you connect the cable to the port on the front side of your -
computer
the USB port of your computer does not support the power output -
standard (5 V, 500 mA)
Appendixes
83
Before contacting a service center
If you are having trouble with your camera, try these troubleshooting procedures before contacting a service center. If you have attempted
the troubleshooting solution and are still having problems with your device, contact your local dealer or service center.
Situation Suggested remedies
Cannot take photos
There is no space on the memory card. t
Delete unnecessary files or insert a new
card.
Format the memory card. (p. t 75)
The memory card is defective. Get a t
new memory card.
The memory card is locked. Unlock the t
card. (p. 78)
Make sure that the camera is switched t
on.
Charge the battery.t
Make sure that the battery is inserted t
correctly.
The camera freezes Remove the battery and insert it again.
The flash does not work
The flash option may be set to t Off.
(p. 38)
You cannot use the flash in the t
d
,
v
, or some
s
modes.
The flash fires
unexpectedly
The flash may fire due to static electricity.
This is not a malfunction of the camera.
Situation Suggested remedies
Cannot turn on the
camera
Make sure that the battery is inserted.t
Make sure that the battery is inserted t
correctly.
Charge the battery.t
The power turns off
suddenly
Charge the battery.t
Your camera may be in Power save t
mode. (p. 74)
The camera may turn off to prevent the t
memory card from being damaged due
to an impact. Turn on your camera again.
The camera is losing
battery power quickly
The battery may lose power more quickly t
in low temperatures (below 0° C). Keep
the battery warm by putting it into your
pocket.
Using the flash or recording videos t
depletes the battery quickly. Recharge
if needed.
Batteries are consumable parts that must t
be replaced over time. Get a new battery
if the battery life is diminishing quickly.
Appendixes
84
Before contacting a service center
Situation Suggested remedies
The photo is too bright
Your photo is overexposed. Adjust the t
exposure value. (p. 45)
Turn off the flash. (p. t 38)
The TV does not
display your photos
Make sure that the camera is correctly t
connected to the external monitor with
the A/ V cable.
Make sure that your memory card t
contains photos.
Your computer does
not recognize your
camera
Make sure that the USB cable is t
connected correctly.
Make sure that your camera is switched t
on.
Make sure that you are using a t
supported operating system.
Your computer
disconnects the camera
while transferring files
The file transmission may be interrupted by
static electricity. Disconnect the USB cable
and connect it again.
Situation Suggested remedies
The date and time are
incorrect
Set the date and time in the display settings
menu.
The display or buttons
do not work Remove the battery and insert it again.
The memory card has
an error
The memory card has not been reset.
Format the card. (p. 75)
Cannot play back files
If you change the name of a file, your
camera may not play the file (the name of
the file should meet the DCF standard). If
you encounter this situation, play back files
on your computer.
The photo is blurry
Make sure that the focus option you set t
is suitable for close-up shots. (p. 40)
Make sure that the subject is within t
range of the flash. (p. 86)
Make sure that the lens is clean. If not, t
clean the lens. (p. 79)
The colors in the photo
do not match the actual
scene
An incorrect white balance can create
unrealistic color. Select the proper white
balance option to suit the light source.
(p. 46)
Appendixes
85
Before contacting a service center
Situation Suggested remedies
Your computer cannot
play videos
The codec installed in your computer may
not be compatible with the video files you
want to play. Use QuickTime
®
Player or
install Codec Pack Full.
Using QuickTimet
®
Player 7.5
1. Install QuickTime
®
Player 7.5 which
supports MP4 (H.264 (MPEG4.AVC)).
2. Play videos using QuickTime
®
Player.
Using Codec Pack Fullt
1. Install the latest version of Codec
Pack Full.
2. Play videos using the media player
(Media Player Classic or Windows
Media Player 11 recommended).
Install QuickTimet
®
Player 7.5 or K-Lite
Codec Pack Full on Windows XP SP2
or later.
Depending on your computer t
environment, the video playback may be
intermittent.
Appendixes
86
Camera specifications
Shutter speed
Auto: 1/8 - 1/2,000 sec.
t
Program: 1 - 1/2,000 sec. (AEB, Continuous: 1/4 - 1/2,000)t
Night: 8 - 1/2,000 sec.t
Firework: 4 sec.t
Exposure
Control Program AE
Metering Multi, Spot, Center-weighted
Compensation ±2EV (1/3EV steps)
ISO equivalent Auto, 80, 100, 200, 400, 800, 1600, 3200
Flash
Mode Off, Auto, Red-eye, Fill in, Slow Sync, Red-eye Fix
Range Wide: 0.3 m - 4.0 m (ISO Auto)
t
Tele: 0.5 m - 2.4 m (ISO Auto)t
Recharging time Approx. 5 sec. (depending on battery condition)
Shake reduction
DUAL IS [Optical Image Stabilization (OIS) +
Digital Image Stabilization (DIS)]
Image sensor
Type 1/2.33" (Approx. 1.09 cm) CCD
Effective pixels Approx. 12.2 mega-pixels
Total pixels Approx. 12.4 mega-pixels
Lens
Focal length Samsung lens f = 5 - 25 mm
(35 mm film equivalent: 28 - 140 mm)
F-stop range F3.4 (W) - F5.8 (T)
Digital zoom Still image mode: 1.0X - 5.0X
t
Play mode: 1.0X - 12.5X (depending on image size)t
Display
Type TFT LCD
Feature 3.0" (7.62 cm) 230K
Focusing
Type TTL auto focus (Multi AF, Center AF)
Range
Wide (W) Tele (T)
Normal 80 cm - infinity
Macro 5 cm - 80 cm 50 cm - 80 cm
Auto Macro 5 cm - infinity 50 cm - infinity
Appendixes
87
Camera specifications
Videos
Format: H.264 (Max recording time: 20 min) with
t
stereo recording
Size: 1280 x 720 (30 FPS, 15 FPS) High Quality,
t
1280 x 720 (30 FPS, 15 FPS) Standard Quality,
640 x 480 (30 FPS, 15 FPS), 320 x 240 (60 FPS,
30 FPS, 15 FPS)
3.6X Optical zoom with sound recording and mute
t
in zooming (sound is muted when operating the
zoom function)
Frame Rate: 60 FPS, 30 FPS, 15 FPS
t
Voice: Off, Ont
OIS: On, Offt
Video editing (embedded): Pause during recording, t
Still image capture, Time trimming
Playback
Type Single image, Thumbnails, Multi slide show,
Movie clip, Smart Album
Edit Resize, Rotate, Photo Style Selector, Image Adjust
Effect
Photo Style Selector: Normal, Soft, Vivid, Forest,
t
Retro, Cool, Calm, Classic, Negative, Custom RGB
Image Adjust: ACB, Red-eye Fix, Face Retouch,
t
Brightness, Contrast, Saturation, Add Noise
Voice recording
Voice Recording (Max 10 hours)
t
Voice Memo in a photo (Max. 10 sec.)t
Stereo recordingt
Effect
Shooting mode
Photo Style Selector: Normal, Soft, Vivid, Forest,
t
Retro, Cool, Calm, Classic, Negative, Custom RGB
Image Adjust: Sharpness, Contrast, Saturation
t
White Balance
Auto WB, Daylight, Cloudy, Fluorescent_H, Fluorescent_L, Tungsten,
Custom Set
Shooting
Photos
Modes: Smart Auto (Macro, Macro Text, White,
t
Landscape, Action, Tripod, Night, Night Portrait,
Backlight, Backlight Portrait, Portrait), Auto,
Program, DUAL IS, Beauty Shot, Movie, Photo Help
Guide, Scene (Night, Portrait, Children, Landscape,
Text, Close Up, Sunset, Dawn, Backlight, Firework,
Beach & Snow, Frame Guide)
Drive: Single, Continuous, Motion Capture, AEB
t
Timer: 10 sec, 2 sec, Double, Motion Timer, t
Remote
Appendixes
88
Camera specifications
Interface
Digital output
connector USB 2.0 (34 pin)
Audio output Mono (Internal speaker), Stereo (Microphone)
Video output AV: NTSC, PAL (selectable)
t
HDMI 1.2: NTSC, PAL (selectable)t
DC power input
connector 34 pin, 4.2V
Power source
Rechargeable
battery Lithium-ion battery (SLB-10A, 1,050 mAh)
The power source may differ depending on your region.
Dimensions (W x H x D)
94.5 x 58.9 x 22.5 mm
Weight
155 g (without battery and memory card)
Storage
Media
Internal memory: Approx. 76 MB
t
External memory (Optional)t
SD card (up to 4 GB guaranteed) -
SDHC card (up to 8 GB guaranteed) -
MMC Plus (up to 2 GB guaranteed, -
4 bit 20 MHz)
Internal memory capacity may not match these
specifications.
File format
Photo: JPEG (DCF), EXIF 2.21, DPOF 1.1,
t
PictBridge 1.0
Video: MP4 (H.264 (MPEG4.AVC))
t
Audio: WAVt
Image size
For 1GB SD
Super fine Fine Normal
4000 x 3000 142 274 389
3984 x 2656 162 302 426
3968 x 2232 195 355 509
3264 x 2448 204 361 518
2592 x 1944 327 547 764
2048 x 1536 514 774 1028
1920 x 1080 840 1104 1387
1024 x 768 1420 1612 1807
These figures are measured under Samsung’s standard
conditions and may vary depending on shooting conditions
and camera settings.
Appendixes
89
Camera specifications
Operating temperature
0 - 40˚ C
Operating humidity
5 - 85 %
Software
Samsung Master, QuickTime
®
Player 7.5, Adobe Reader
Specifications are subject to change without prior notice.
Appendixes
90
FCC notice
Declaration of Conformity t
Trade Name : Samsung Electronics America, Inc.
Model No. : Samsung SL820
Responsible Party : Samsung Electronics America, Inc.
Address : 105 Challenger Road Ridgefield Park NJ
Telephone No. : 1-800-SAMSUNG (726-7864)
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
NOTE:t
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of
the following measures:
- Reorientate, or relocate, the receiving antenna.
- Increase the distance between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
- Consult the dealer or an experienced radio / TV technician for
help.
CAUTION:t
Changes or modifications not expressly approved by the
manufacturer responsible for compliance could void the user’s
authority to operate the equipment.
Samsung Eco-mark
It is Samsung’s own symbol mark is used to
effectively communicate Samsung’s environmental
friendly product activities to the consumers. The
mark represents Samsung’s continuous effort on
development of environmental conscious products.
Appendixes
91
Index
A
ACB 45, 61
Adjusting
Brightness 61
Contrast
in Playback mode 61
in Shooting mode 50
Saturation
In Playback mode 61
in Shooting mode 50
Sharpness 50
Adobe Reader 65
AF Lamp 76
AF Sound 74
Anynet+ 76
Aperture 28
Auto Contrast Balance
(ACB) 45, 61
Auto mode 19
B
Battery
Charging 82
Life 81
Specifications 81
Beauty Shot mode 29
Blink detection 44
Burst
Auto Exposure Bracket
(AEB) 48
Continous 48
Motion capture 48
C
Camera shake 23
Capturing an image 58
Cleaning
Body 79
Display 79
Lens 79
D
Date and time 75
Deleting files 54
Digital Image Stabilization 30
Digital zoom 20
Disconnecting the device 67
Display brightness 74
Display type 18
DPOF 62
Dual IS mode 30
E
Editing 59
Enlarging 56
Error messages 78
Exposure 45
F
Face detection
Blink Detection 44
Normal 42
Self-portrait 43
Smile Shot 43
Facial brightness 29
Facial imperfections 29
Flash
Auto 39
Fill in 39
Off 38
Red-eye 39
Red-eye Fix 39
Slow Sync 39
Focus area
Center AF 41
Multi AF 41
Focus distance
Auto Macro 40
Macro 40
Normal (AF) 40
Appendixes
92
Index
Frame guide 27
Frame rate 31
Function button 13
Function description 74
H
Half-pressing 6
HDTV 63
I
Icons 14
Imprint 76
ISO speed 39
L
Light source
(White balance) 46
Long time shutter 28
M
Macro 40
Maintenance 79
Memory card
Capacity 80
MMC 80
SD 80
SDHC 80
MENU button 13
Metering
Center-weighted 46
Multi 46
Spot 46
Mode dial 13
Motion timer 37
Movie mode 31
Muting
Camera 15
Video 31
N
Navigation button 13
O
Optical Image Stabilization
(OIS) 21, 30
P
Photo Help Guide mode 22
Photo quality 35
Photo styles 49
Playback button 13, 15
Playback mode 52
Printing photos 71
Print order 62
Program mode 30
Protecting files 54
Q
QuickTime Player 65
Quick View 74
R
Recording
Video 31
Voice memo 33
Recycle bin 55
Red-eye 38
Reset 75
Resizing 59
Resolution
Photo 35
Video 35
RGB tone
in Playback mode 60
in Shooting mode 49
Rotating 59
Appendixes
93
Index
S
Samsung Master
Installing 65
Using 68
Scene mode 27
Self-portrait 43
Service center 83
Settings
Accessing 73
Camera 75
Display 74
Sound 74
Shooting mode
Auto 19
Beauty Shot 29
Dual IS 30
Movie 31
Photo Help Guide 22
Program 30
Scene 27
Smart Auto 26
Shutter speed 28
Slide show 56
Smart Album 53
Smart Auto mode 26
Smile shot 43
Start image 74
T
Timer 36
Transferring files
for Mac 70
for Windows 65
V
Video
Playing 57
Recording 31
Video Out 76
Viewing files
as thumbnails 53
by category 53
on TV 63
Slide show 56
Voice memo
Playing 58
Recording 33
Volume 74
W
White Balance 46
Z
Zoom button 13
Zooming 20
Please refer to the warranty that came with your product or
visit our website http://www.samsung.com/ for after-sales
service or inquiries.
The CE Mark is a Directive conformity
mark of the European Community (EC)

Navigation menu
