BN68-00487A-00

Owner’s Instructions

SPN4235

SERVICE DIVISION

400 Valley Road, Suite 201

Mount Arlington, NJ 07856

TEL : 1-800-SAMSUNG (1-800-726-7864)

www.samsungusa.com

Thank you for choosing Samsung! Your new Samsung product represents the latest in television

technology. We designed it with easy-to-use on-screen menus and closed captioning capabilities,

making it one of the best products in its class. We are proud to offer you a product that will provide

convenient, dependable service and enjoyment for years to come.

Important Safety Information

Always be careful when using your PDP. To reduce the risk of fire, electrical shock, and other injuries,

keep these safety precautions in mind when installing, using, and

maintaining your machine.

• Read all safety and operating instructions before operating your PDP.

• Keep the safety and operating instructions for future reference.

• Heed all warnings on the PDP and in the operating instructions.

• Follow all operating and use instructions.

• Unplug the PDP from the wall outlet before cleaning. Use a damp cloth; do not use liquid or aerosol

cleaners.

• Never add any attachments and/or equipment without approval of the manufacturer. Such additions

can increase the risk of fire, electric shock, or other personal injury.

• Do not use the PDP where contact with or immersion in water is a possibility, such as near bath tubs,

sinks, washing machines, swimming pools, etc.

• Do not place the PDP on an unstable cart, stand, tripod, bracket,

table, or floor where it can fall. A falling PDP can cause serious injury

to a child or adult, and serious damage to the appliance. Use only

with a cart, stand, tripod, bracket, or table recommended by the man-

ufacturer or sold with the PDP. Follow the manufacturer's instructions

when mounting the unit, and use a mounting accessory recommended

by the manufacturer. Move the PDP and cart with care. Quick stops,

excessive force, and uneven surfaces can make the unit and cart

unsteady and likely to overturn.

• Provide ventilation for the PDP. The unit is designed with slots in the cabinet for ventilation to protect it

from overheating. Do not block these openings with any object, and do not place the PDP on a bed,

sofa, rug, or other similar surface. Do not place it near a radiator or heat register. If you place the

PDP on a rack or bookcase, ensure that there is adequate ventilation and that you've followed the

manufacturer's instructions for mounting.

• Operate your PDP only from the type of power source indicated on the marking label. If you are not

sure of the type of power supplied to your home, consult your appliance dealer or local power com-

pany.

• Use only a grounded or polarized outlet. For your safety, this PDP is equipped with a polarized alter-

nating current line plug having one blade wider than the other. This plug will fit into the power outlet

only one way. If you are unable to insert the plug fully into the outlet, try reversing the plug. If

the plug still does not fit, contact your electrician to replace your outlet.

Warning! Important Safety Instructions

32

CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER

SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

This symbol indicates high voltage is present inside. It is dangerous to make any kind of contact

with any inside part of this product.

This symbol alerts you that important literature concerning operation and maintenance has been

included with this product.

Note to CATV system installer: This reminder is provided to call CATV system installer's attention to Arti-

cle 820-40 of the National Electrical Code (Section 54 of Canadian Electrical Code, Part I), that provides

guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the

grounding system of the building as close to the point of cable entry as practical.

Caution: FCC/CSA regulations state that any unauthorized changes or modifications to this equipment may

void the user's authority to operate it.

Caution: To prevent electric shock, match the wide blade of plug to the wide slot, and fully insert the plug.

Attention: pour eviter les chocs electriques, introduire la lame le plus large de la fiche dans la borne corre-

spondante de la prise et pousser jusqu'au fond.

Important: One Federal Court has held that unauthorized recording of copyrighted TV programs is an

infringement of U.S. copyright laws.

Certain Canadian programs may also be copyrighted and any unauthorized recording in whole or in part

may be in violation of these rights.

TO PREVENT DAMAGE WHICH MAY RESULT IN FIRE OR ELECTRIC SHOCK HAZARD, DO NOT EXPOSE THIS

APPLIANCE TO RAIN OR MOISTURE.

Thank You for Choosing Samsung

User Instructions

The Federal Communications Commission Radio

Frequency Interference Statement includes the fol-

lowing warning:

NOTE: This equipment has been tested and found

to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable

protection against harmful interference in a resi-

dential installation. This equipment generates,

uses, and can radiate radio frequency energy

and, if not installed and used in accordance with

the instructions, may cause harmful interference to

radio communications. However, there is no guar-

antee that interference will not occur in a particu-

lar installation .

If this equipment does cause harmful interference

to radio or television receptions, which can be

determined by turning the equipment off and on,

the user is encouraged to try to correct the inter-

ference by one or more of the following mea-

sures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment

and receiver.

• Connect the equipment into an outlet on a cir-

cuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV

technician for help.

User Information

Changes or modifications not expressly approved

by the party responsible for compliance could

void the user’s authority to operate the equipment.

If necessary, consult your dealer or an experi-

enced radio/television technician for additional

suggestions. You may find the booklet called How

to Identify and Resolve Radio/TV Interference

Problems helpful. This booklet was prepared by

the Federal Communications Commission. It is

available from the U.S. Government Printing

Office, Washington, DC 20402, Stock Number

004-000-00345-4 .

The party responsible for product compliance:

SAMSUNG ELECTRONICS CO., LTD

America QA Lab of Samsung

3351 Michelson Drive,

Suite #290, Irvine, CA92612 USA

Warning

User must use shielded signal interface cables to

maintain FCC compliance for the product.

Provided with this monitor is a detachable power

supply cord with IEC320 style terminations.

It may be suitable for connection to any UL Listed

personal computer with similar configuration.

Before making the connection, make sure the volt-

age rating of the computer convenience outlet is

the same as the monitor and that the ampere rat-

ing of the computer convenience outlet is equal to

or exceeds the monitor voltage rating.

For 120 Volt applications, use only UL Listed

detachable power cord with NEMA configuration

5-15P type (parallel blades) plug cap. For 240

Volt applications use only UL Listed Detachable

power supply cord with NEMA configuration

6015P type (tandem blades) plug cap.

IC Compliance Notice

This Class B digital apparatus meets all require-

ments of the Canadian Interference-Causing

Equipment Regulations of ICES-003.

Cet appareil Numérique de classe B respecte

toutes les exigences du Règlemont NMB-03 sur les

équipements produisant des interférences au

Canada.

Notice de Conformité IC

Cet appareil numérique de classe B respecte

toutes les exigences du Règlement ICES-003 sur

les équipements produisant des interférences au

Canada.

VCCI

This is a Class B product based on the standard

of the Voluntary Control Council for Interference

by Information Technology Equipment (VCCI). If

this is used near a radio or television receiver in a

domestic environment, it may cause radio interfer-

ence. Install and use the equipment according to

the instruction manual.

This Class B digital apparatus complies with

Canadian ICES-003.

Cet appareil num?ique de la classe B est con-

forme ?la norme NMB-003 du Canada.

5

• Protect the power cord. Power supply cords should be routed so that they won’t be walked on or pinched

by objects placed on or against them. Pay particular attention to cords at plugs, convenience recepta-

cles, and the point where they exit from the unit.

• Unplug the PDP from the wall outlet and disconnect the antenna or cable system during a lightning storm

or when left unattended and unused for long periods of time. This will prevent damage to the unit due to

lightning and power-line surges.

• Avoid overhead power lines. An outside antenna system should not be placed in the vicinity of overhead

power lines or other electric light or power circuits or where it can fall into such power lines or circuits.

When installing an outside antenna system, be extremely careful to keep from touching the power lines

or circuits. Contact with such lines can be fatal.

• Do not overload the wall outlet or extension cords. Overloading can result in fire or electric shock.

• Do not insert anything through the openings in the unit, where they can touch dangerous voltage points

or damage parts. Never spill liquid of any kind on the PDP.

• Ground outdoor antennas. If an outside antenna or cable system is connected to the PDP, be sure the

antenna or cable system is grounded so as to provide some protection against voltage surges and built-

up static charges. Section 810 of the National Electrical Code, ANSI/NFPA No.70-1984, provides infor-

mation about proper grounding of the mast and supporting structure, grounding of the lead-in wire to an

antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to

grounding electrodes, and requirements for the grounding electrode.

• Do not attempt to service the PDP yourself. Refer all servicing to qualified service personnel. Unplug the

unit from the wall outlet and refer servicing to qualified service personnel under the following conditions:

- when the power-supply cord or plug is damaged

- if liquid has been spilled on the unit or if objects have fallen into the unit

- if the PDP has been exposed to rain or water

- if the PDP does not operate normally by following the operating instructions

- if the PDP has been dropped or the cabinet has been damaged

- when the PDP exhibits a distinct change in performance

• If you make adjustments yourself, adjust only those controls that are covered by the operating instruc-

tions. Adjusting other controls may result in damage and will often require extensive work by a qualified

technician to restore the PDP to normal.

• When replacement parts are required, be sure the service technician uses replacement parts specified by

the manufacturer or those that have the same characteristics as the original part. Unauthorized substitu-

tions may result in additional damage to the unit.

• Upon completion of any service or repairs to this PDP, ask the service technician to perform safety checks

to determine that the PDP is in a safe operating condition.

• The PDP can properly operate in a temperature range of 32~104°F(0~40°C) and 80% humidity.

Do not use in a hot and humid place.

• Before moving the PDP equipped with speakers, separate the speakers from the PDP. If you move the PDP

with the speakers attached, it may result in damage or injury.

4

FCC Information

This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received, including interference that may cause

unesired operation.

This television receiver provides display of television closed captioning in accordance with

§15.119 of the FCC rules.

General Information

Your New Plasma Display Panel....................10

Remote Control Buttons ................................12

Wall Installation Instructions..........................14

Connections

Connecting VHF and UHF Antennas ..............20

Connecting Cable TV ..................................21

Connecting Speakers ..................................23

Connecting a VCR ......................................24

Connecting a Camcorder ............................25

Connecting a DVD Player ............................26

Connecting a DTV Receiver ..........................27

Operation

Turning the PDP On and Off ........................30

Memorizing the Channels ............................32

Setting Up Your Remote Control ....................37

Picture Control

Customizing the Picture ..............................40

Using Automatic Picture Settings ..................41

Selecting the Color Tone ..............................42

DNIe (Digital Natural Image engine) ............43

Viewing the Picture-in-Picture ........................44

Changing the Screen Size ..........................50

Freezing the Picture ...................................51

Sound Control

Customizing the Sound ................................54

Using Automatic Sound Settings ...................55

Choosing a Multi-Channel Sound (MTS)Soundtrack

......56

Using the Auto Volume ................................57

Using Dolby Virtual......................................58

Using a Subwoofer......................................59

Channel Control

Fine Tuning Channels ..................................62

LNA (Low Noise Amplifier) ..........................63

Connecting a PC and Operation

Connecting to a PC ....................................66

Adjusting the PC Screen ..............................70

Changing the Position of the Image................71

Changing the Size of the Image ..................72

Information ................................................73

Picture Quality Adjustment ..........................74

Time Setting

Setting the Clock ........................................78

Setting the Sleep Timer ................................79

Setting the Timers ........................................80

Setting the Preferred Channel and Volume Level

....82

Function Description

Selecting a Menu Language ........................84

Viewing Closed Captions ............................85

Digital Noise Reduction ..............................86

Setting Auto Power Off ................................87

Using the V-Chip..........................................88

Selecting the Film Mode ..............................94

Appendix

Troubleshooting ..........................................96

Care and Maintenance ................................97

Specifications..............................................98

7

Important Warranty Information

Regarding Television Format Viewing

User Instructions

Wide screen format PDP Displays (16:9,the aspect ratio of the screen width to height) are primarily

designed to view wide screen format full-motion video.The images displayed on them should primarily be

in the wide screen 16:9 ratio format,or expanded to fill the screen if your model offers this feature and con-

stantly moving. Displaying stationary graphics and images on screen, such as the dark side-bars on non-

expanded standard format television video and programming, should be limited to no more than 5% of the

total television viewing per week.

Additionally,viewing other stationary images and text such as stock market reports, video game

displays,station logos,web sites or computer graphics and patterns,should be limited as described above

for all televisions. Displaying stationary images that exceed the above guidelines can

cause uneven aging of PDP Displays that leave subtle,but permanent burned-in

ghost images in the PDP picture.To avoid this,vary the programming and images,

and primarily display full screen moving images,not stationary patterns or dark bars.

On PDP models that offer picture sizing features,use these controls to view different formats as a full screen

picture.

Be careful in the selection and duration of television formats used for viewing. Uneven PDP aging as a

result of format selection and use,as well as burned-in images, are not covered by your Samsung limited

warranty.

6

Table of Contents

Screen Image retention

Do not display a still image (such as on a video game or when hooking up a PC to this PDP) on the plasma

display panel for more than several minutes as it can cause screen image retention. This image retention is

also known as “screen burn”. To avoid such image retention, refer to page 40 of this manual to reduce the

degree of brightness and contrast of this screen when displaying a still image.

Cell Defect

The plasma display panel consists of fine cells. Although the panels are produced with more than 99.9

percent active cells, there may be some cells that do not produce light or remain lit.

Altitude

The PDP will not operate normally at altitudes above 6500 ft.

PLASMA DISPLAY PANEL

General Information

Your New Plasma Display Panel ....................................................10

Remote Control Buttons ................................................................12

Wall Installation Instructions ..........................................................14

Front Panel

11

Your New Plasma Display Panel

10

Rear Panel

ŒService jack

For service only.

´DVI Input jacks

Receives the digital video/audio signals

from a set top box or PC.

ˇPC(RGB) Input jacks(15pin)

Connect to the video/audio output jacks

on your PC.

¨S-Video Input jacks

Connect S-Video/audio signals from external

sources such VCRs or DVD players.

ˆVideo Input jacks

Connect video/audio signals from external

sources such VCRs or DVD players.

ØComponent Video/Audio Input jacks

(Y/Pb/Pr/Audio L/Audio R)

Connect to the audio and component output

jacks of a DVD player or Set-Top Box.

∏External Speaker Out jacks

Connect external speakers.

”Antenna jack

Connect to antenna.

’Sub-woofer speaker output jack

Connect to the Sub-woofer speaker jack.

˝Power Input jack

Connect the supplied power cord.

Remote Control

Signal Receiver

Aim the remote

control towards

this spot on the PDP.

Power Indicator

Power Off : LED Red

Power On (Timer On) : LED Green

Power On (Timer Off) : LED Off

Checking Accessories

Speakers

(optional)

SOURCE button

Press to display all of the available video sources

(ie., Video, S-Video, Component1, Component2, PC ).

MENU button

Displays the main on-screen menu.

VOL(+,-) button

Press to increase or decrease the volume. Also used

to select or adjust items on the on-screen menu.

CH(▼,▲) button

Press CH▲ or CH▼to change Channels.

Also used to move up or down in the On-screen menu.

POWER button

Press to turn the PDP on and off.

Remote Control/AAA Batteries

Antenna Cable Speaker Cables

Power Cord Owner’s Instructions

Ferrite Cores; 3EA

Once you have unpacked your PDP, check to make sure that you have all the parts shown here.

If any piece is missing or broken, call your dealer.

¸SURROUND button

Press the hear the Dolby surround effect.

˛MTS button

Press to choose stereo, mono or Separate Audio Pro-

gram (SAP broadcast).

◊AUTO PROG. button

The TV automatically cycles through all of the avail-

able channels and stores them in memory.

±ADD/DEL button

Press to add or delete channels in the TV’s memory.

≠DNIe button

Activates DNIe (Digital Natural Image engine).

–CAPTION button

Controls the caption decoder.

—SET button

Used during set up of this Samsung remote control,

so that it will work compatibly with other devices

(VCR, cable box, DVD)

÷PIP control buttons

SWAP : Exchanges the video signal that is currently

displayed on the main screen with the

signal in the PIP window.

SIZE : Press to make the PIP window Large, Small

or Double.

CH

▲,▼

: Displays the available channels in

sequence. (These buttons change channels

in the PIP window only).

®VCR, DVD control buttons

Controls VCR tape or DVD disc functions: Stop,

Rewind, Play/Pause, Fast Forward.

∑RESET button

If your remote control is not functioning properly, take

out the batteries and press the reset button for about

2~3 seconds. Re-insert the batteries and try using the

remote control again.

13

Remote Control Buttons

ŒPOWER button

Turns the PDP on and off.

´ASPECT button

Press to change the screen size.

ˇNumber buttons

¨+100 button

Press to select channels over 100. For example, to select

channel 121, press “+100”, then press “2” and “1.”

ˆMUTE button

Press to mute the PDP sound.

ØVOL (Volume) buttons

Use it to adjust volume.

∏SLEEP button

Press to select a preset time interval for automatic shutoff.

”MENU button

Displays the main on-screen menu.

’ENTER button

Confirms a selection.

˝PIP button

Activates picture in picture.

ÔSTILL button

Press to pause the current screen.

LED Display

When you press a button, ‘ ‘ appears along with

selected mode (TV, VCR, CATV, DVD or STB) and

remaining batteries on LED.

ÒP.MODE button

Adjust the PDP picture by selecting one of the preset

factory settings (or select your personal, customized

picture settings.)

ÚMODE button

Selects a target device to be controlled by the Samsung

remote control (ie., VCR, Cable, DVD players or STB).

If you change modes, the new mode is momentarily

displayed on LED.

ÆPRE-CH button

Tunes to the previous channel.

ıTV/VIDEO button

Press to display all of the available video sources

(ie., Video, S-Video, Component1, Component2, PC, DVI).

˜CH (Channel) buttons

Use it to switch channels.

¯INFO button

Press to display information on the PDP screen.

˘EXIT button

Press to exit the menu.

¿Up/Down Left/Right buttons

Control the cursor in the menu.

12

Remote Control

Installing the Batteries in Your Remote Control

1Slide the back cover

to open the battery

compartment of the

remote control.

3Slide the cover back into

place.

2Install two AAA size batter-

ies. Make sure to match the

“+” and “-” ends of the bat-

teries with the diagram

inside the compartment.

Remote Control Operation Range.

You can use your remote control within a distance of 23 feet and an angle of 30 degrees

from the left and right sides of the PDP’s remote control receiver.

1 Remove the screws on the rear of the PDP panel.

2 Connect Insulation holders to screws. (see the illustration below)

3 Tighten the screws connected to the Insulation holders on the rear of the PDP panel.

15

Wall Installation Instructions

1 Do not install the PDP in any location other than a vertical wall.

2 To protect the performance of the PDP and prevent problems, avoid the following

places.

• Do not install next to smoke and fire detectors.

• Do not install in an area subjected to vibration.

• Do not install in an area subjected to high voltage.

• Do not install near or around any heating apparatus.

3 Use only recommended parts and components.

14

Screws ; 4 EAInsulation holders ; 4 EA

Installation Notes

Parts (Wall attachment panel is sold separately. Check with your dealer)

Fixing the PDP panel to the wall attachment panel bracket

Removing four screws

Connecting four screws

Wall attachment panel

1716

4Put the 4 pegs on the PDP in the grooves of the wall mount bracket and pull down on

the PDP (Œ) to secure it to the wall mount bracket. (´) Tighten the screws as shown

(ˇ) so that the PDP cannot be separated from wall mount bracket.

1.Contact an authorized technician when installing the wall attachment panel.

2.After hanging the PDP panel on the wall attachment panel, make sure that

the Insulation holders are completely hung.

3.Be careful so that fingers are not caught.

4.Make sure the wall attachment panel brackets are tightened.

Otherwise, the PDP panel may fall down and you might be hurt.

How to Adjust Mounting Angle

Notice

Notice : Please secure the mounting bracket on the wall surface after setting its angle at 0°

Factory default

The wall mount bracket is delivered separately.Please tighten the captive screw in the direction of

the arrow after assembling the bracket.

1Secure the PDP to the wall mount

bracket.(Please refer to the following

instructions.)

2Set the angle by pulling the upper end of

the PDP attached to bracket in the direction

of the arrow.

3The angle can be adjusted from 0° to 20°

by ±2°.

Changeing the angle

PDP panel

Wall attachment

panel bracket

Wall

PLASMA DISPLAY PANEL

Connections

Connecting VHF and UHF Antennas ..............................................20

Connecting Cable TV....................................................................21

Connecting Speakers....................................................................23

Connecting a VCR........................................................................24

Connecting a Camcorder..............................................................25

Connecting a DVD Player..............................................................26

Connecting a DTV Receiver ..........................................................27

21

Connecting VHF and UHF Antennas Connecting Cable TV

You can connect different cable systems to your PDP, including cable without a cable box,

and cable with a cable box that descrambles some or all channels.

20

Antennas with 75-ohm Round Leads

If your antenna looks like this: it has 75-ohm round leads.

1Plug the antenna lead into the VHF/UHF terminal

on the PDP.

Use the Antenna Cable, an accessory included

in the product package.

Cable without a Cable Box

1 Plug the incoming cable into the VHF/UHF terminal on

the PDP.

Use the Antenna Cable, an accessory included

in the product package.

Cable with a Cable Box that Descrambles All Channels.

1 Find the cable connected to the ANTENNA OUT

terminal on your cable box. This terminal might be

labeled "ANT OUT", "VHF OUT", or simply "OUT".

2 Connect the cable to the VHF/UHF terminal on the

PDP.

Use the Antenna Cable, an accessory included

in the product package.

22 23

Connecting Speakers

External speakers are sold seperately. Check with your dealer.

Connect the speaker audio cable to the external speaker output jack on the PDP matching the

“+” and “-” ends of the cable with the diagram on the PDP.

How to Connect

Connecting PDP and Speakers

Fix the bracket onto the guide pole located on the rear of speaker and fasten the screws.

After removing the three screws on the PDP, clamp the speaker and the PDP together and

fasten the screws.

1

2

Speaker Audio Cable

✱External speakers MUST have a power handling

capability of 10 watts minimum (impedance 8 ohm).

Speaker AudioCable

Powered Subwooper

(Option)

Please use the speaker-built in amplified audio.

Guide

pole

Guide

pole

Cable with a Cable Box that Descrambles Some (But Not All) Channels

To complete this connection you will need a two-way splitter, an RF (A/B) switch, and four coaxial

cables (which you can buy from your Samsung dealer or any electronics store).

1Find and disconnect the cable that is con-

nected to the ANTENNA IN terminal of

your cable box.

This terminal might be labeled "ANT IN",

"VHF IN", or simply, "IN". Connect this

cable to a two-way splitter.

2Connect a coaxial cable between an OUT-

PUT terminal of the splitter and the IN termi-

nal of the cable box.

3Connect a coaxial cable between the

ANTENNA OUT terminal of the cable box

and the B-IN terminal of the A/B switch.

4Connect a coaxial cable between the

ANTENNA OUT terminal of the cable box

and the B-IN terminal of the A/B switch.

5Connect the last coaxial cable between the

OUT terminal of the RF (A/B) switch and

the VHF/UHF terminal on the PDP.

After you've made this connection, set the A/B switch to the "A" position for normal viewing.

Set the A/B switch to the "B" position to view scrambled channels. (When you set the A/B switch

to "B", you will need to tune your Set-Top Box to the cable box's output channel, which is usually

channel 3 or 4.)

25

Connecting a Camcorder

24

Connecting a VCR to the Video or S-Video/Audio jack

S-Video Cable

Audio Cable

Video Cable

Power Plug

Connect the Video/Audio cables between the AUDIO(L/R)/VIDEO jacks on the PDP and

AUDIO/VIDEO OUT jacks on the VCR. (Note: For better video, you can use an S-Video cable.)

Videotape Playback:

1. Turn on your PDP, and press the TV/VIDEO button on the remote control.

2. Press the UP or DOWN button to select “Video” or “S-Video”, then press the ENTER button.

3. Turn on your VCR, insert a videotape and press the play button.

How to Connect

The ferrite cores are used to attenuate undesired signals. When connecting the audio cable

(PC, DVI, S-Video, Video), attach one of these ferrite cores to the cable near the connector.

When you connect the audio cable (PC, DVI, S-Video, Video,

Component1, Component2) to the connectors, bind the ferrite core

around the cable to secure it.

Ferrite Cores

Connecting a VCR

Audio Cable

Video Cable

Power Plug

Connect a Video/Audio cable between the AUDIO(L/R)/VIDEO jacks on the PDP and the

VIDEO/AUDIO OUTPUT jacks on the camcorder.

Viewing Tapes

1. Turn on your PDP, and press the TV/VIDEO button on the remote control.

2. Press the UP or DOWN button to select the “Video”, then press the ENTER button.

3. Turn on your camcorder and set it to Video Mode. (For details, refer to your camcorder

owner's instructions.)

4. Set the IN/OUT switch on your camcorder to OUT.

5. Insert the tape into the camcorder and press the Play button.

How to Connect

Viewing camcorder tapes

PDP VCR

PDP

Camcorder

Ferrite Cores

Ferrite Cores

27

Connecting a DVD Player (480i, 480p)

This PDP displays the optimum picture in 720p mode.

26

Playing DVD

Audio Cable

Video Cable

Power Plug

Connect a Video Cable between the Y, Pb, Pr (COMPONENT1, 2) input jacks on the PDP

and Y/PB/PRoutput jacks on the DVD players.

Connect a Audio Cable between the AUDIO L/R(COMPONENT1, 2) input jacks on the PDP

and the AUDIO OUT jacks on the DVD player.

To Play DVD:

1. Turn on your PDP, and press the TV/VIDEO button on the remote control.

2. Press the UP or DOWN button to select “COMPONENT1” or “COMPONENT2”,

then press the ENTER button.

3. Turn on your DVD player, insert a DVD disc and press the Play button.

• For an explanation of Component video, see your DVD owner’s instructions.

How to Connect

1

2

PDP DVD Player

Watching DTV

Video Cable

Audio Cable

DVI Cable

or

Power

Plug

Connect the cable or antenna to the antenna input jack on the DTV.

Connect a Video cable between the Y, Pb, Pr (COMPONENT 1, 2) or DVI jack on the PDP

and the Y, PB, PR(VIDEO OUTPUT JACKS) on the DTV receiver.

Connect an Audio cable between the COMPONENT 1, 2 (L/R AUDIO) or DVI jacks on the

PDP and the AUDIO OUTPUT jacks on the DTV.

To Watch DTV:

1. Turn on your PDP, and press the TV/VIDEO button on the remote control.

2. Press the UP or DOWN button to select “COMPONENT1”, “COMPONENT2” or

“DVI”, then press the ENTER button.

3. Turn on your DTV receiver.

• For an explanation of Component video, see your DTV receiver owner’s instructions.

How to Connect

1

2

3

Connecting a DTV Receiver

(480p, 720p, 1080i)

This PDP displays the optimum picture in 720p mode.

Use the DVI-D connection cable. (sold separately)

PDP

DTV Receiver

Ferrite Cores

PLASMA DISPLAY PANEL

Operation

Turning the PDP On and Off ..........................................................30

Memorizing the Channels..............................................................32

Setting Up Your Remote Control ....................................................37

Turning the PDP On and Off

30 31

Turning the PDP On and Off

Press the Power button on the remote control.

The PDP will be turned on and you will be ready to use it’s

features.

You can also use the POWER( ) button on the front of the

PDP.

Notes:

• If your PDP isn’t turned on when the power button is

pressed: Press the

MODE

button to check if the TV mode

has been chosen ( ).

Viewing the Menus and Displays

Your PDP has a simple, easy-to-use menu system that appears on the PDP screen. This system makes it con-

venient and fast to use features on the PDP. Your PDP also lets you display the status of many of your PDP’s

features.

Viewing the Menus

1 With the power on, press the MENU button on the

remote control. The main menu appears on the screen.

The Picture menu is selected.

2Press the UP/DOWN buttons to move items in the menu.

Press the LEFT/RIGHT buttons to display, change, or use

the selected items.

Press the ENTER ( ) button to enter items in the menu.

On screen menus disappear from the screen

automatically after about thirty seconds, or you can

press the EXIT button on your remote control to exit

the menu.


Mode

Adjust

Color Tone

DNIe

Move Enter Menu

Custom

Normal

On

Displaying Status Information

Press the INFO button on the remote control. The PDP will

display the Picture mode, Sound mode, MTS, Signal and

Caption.

Press the INFO button on the remote control again.

The PDP will display the Clock.

Picture : Custom

Sound : Custom

MTS : Mono

Signal : Mono

Caption : Off

Ant 6

07 : 30 am

Memorizing the Channels

Your PDP can memorize and store all of the available channels for both “off-air” (antenna)

and cable channels. After the available channels are memorized, use the CH and CH

buttons to scan through the channels. This eliminates the need to change channels by entering

the channel digits. There are three steps for memorizing channels: selecting a broadcast

source, memorizing the channels (automatic) and adding and deleting channels (manual).

32 33

Selecting the Video Signal-source

Before your television can begin memorizing the available channels, you must specify the type of

signal source that is connected to the PDP (i.e., an antenna or a cable system).

1 Press the MENU button. Press the UP or DOWN

button to select “Channel”, then press the ENTER

button.

2 Press the LEFT or RIGHT button to select “Ant”,

“STD”, “HRC” or “IRC”.

•If you are connected to an antenna, leave "Ant"

displayed. If you connected cable, press the

LEFT or RIGHT button to the display the type of

cable system: "STD", "HRC", or "IRC".

(If you are not sure which type of cable system you

have, contact your cable company).

3 Press the MENU button to exit.

Note

• STD, HRC and IRC identify various types of cable TV systems. Contact your local cable company

to identify the type of cable system that exists in your particular area.

At this point the signal source has been selected. Proceed to “Storing Channels in Memory”

(next page).

Channel

Ant/ CATV

Auto Program

Fine Tune

LNA

Ch. Scan

Move Select Menu

Ant

Off

0

Channel

Ant/ CATV

Auto Program

Fine Tune

LNA

Ch. Scan

Move Select Menu

STD

Off

0

Storing Channels in Memory (Automatic Method)

1 First, select the correct signal source (Ant, STD, HRC,

IRC). See steps on previous page.

Press the MENU button. Press the UP or DOWN button

to select “Channel”, then press the ENTER button.

2 Press the UP or DOWN button to select “Auto Pro-

gram”, then press the ENTER button.

3The PDP will begin memorizing all of the available

channels.

After all the available channels are stored, the

Auto program menu reappears. Press the RIGHT

button to stop.

Note

• The PDP automatically cycles through all of the available channels and stores them in memory.

This takes about one to two minutes.

Channel

Ant/ CATV

Auto Program

Fine Tune

LNA

Ch. Scan

Move Select Menu

Ant

Off

0

Channel

Ant / CATV

Auto Program

Fine Tune

LNA

Ch. Scan

Move Enter Menu

Ant

Off

0

Ant 50

Auto Program

: Stop

➤

➤

Quick way to access the Automatic Channel Setting : Just press the

“AUTO PROG.” button on the remote control.

To View Memorized Channel (PIP Mode)

1Press the MENU button. Press the UP or DOWN

button to select “Channel”, then press the ENTER

button.

2Press the UP or DOWN button to select “Ch Scan”,

then press the ENTER button.

Only the memorized channels are chosen.

Press the RIGHT button to stop.

34 35

Adding and Erasing Channels (Manual Method)

1 Use the number buttons to directly select the channel that

will be added or erased.

Ex) Channel “4”

2 Press the ADD/DEL button:

Repeatedly pressing this button will alternate between

“Added” and “Erased.”

Note

• You can view any channel (including an erased channel) by using the number buttons on the remote

control.

Ant 4

Ant 4

Added

Channel

Ant/ CATV

Auto Program

Fine Tune

LNA

Ch. Scan

Move Select Menu

Ant

Off

0

Channel

Ant / CATV

Auto Program

Fine Tune

LNA

Ch. Scan

Move Enter Menu

Ant

Off

0

Ch. Scan

Ant 7

: Stop

36 37

Setting Up Your Remote Control

This PDP's remote control can operate almost any VCR, cable box or DVD. After it has been set up

properly, your remote control can operate in four different modes :TV, VCR, Cable or DVD.

Pressing the corresponding button on the remote control allows you to switch between these modes,

and control whichever piece of equipment you choose.

Note :

●

The remote control may not be compatible with all DVD Players, VCRs, Cable boxes.

●

The remote control can operate only on STB made by Samsung.

Setting Up the Remote to Operate Your VCR, Cable box or DVD player

1 Turn off your VCR. (or Cable box, DVD player)

2Press the MODE button. Mode is changed whenever

MODE button is pressed(New mode is displayed on

LED screen).

3 Press the SET button on your TV's remote control.

4Using the number buttons on your remote control,

enter three digits of the VCR (or Cable box, DVD

player) code listed on page 38 of this manual for

your brand of VCR (or CATV, DVD). Make sure you

enter three digits of the code, even if the first digit

is a "0".

(If more than one code is listed, try the first one.)

5Press the Power button on the remote control.

Your VCR (or CATV, DVD) should turn on if your

remote is set up correctly. If your VCR (or CATV,

DVD) does not turn on after setup, repeat steps

2, 3, and 4, but try one of the other codes listed for

your brand of VCR (or CATV, DVD).

If no other codes are listed, try each code, 000

through 089 (or Cable box: 000 through 077,

DVD player: 000 through 008).

Notes

• When your remote control is in “VCR” mode, the VCR control buttons (Stop, REW, Play/Pause, FF)

still operate your VCR.

• When your remote control is in “CATV” or “DVD” mode, the VCR control buttons (Stop, REW,

Play/Pause, FF) still operate your VCR.

Changing Channels

Using the Channel Buttons

Press the CH or CH buttons to change channels.

When you press the CH or CH buttons, the PDP changes channels

in sequence. You will see all the channels that the PDP has memorized.

(The PDP must have memorized at least three channels.)

You will not see channels that were either erased or not memorized.

Directly Accessing Channels

Press the number buttons to go directly to a channel. For example, to select

channel 27, press “2” then “7”. The TV will change channels when you

press the second number.

When you use the number buttons, you can directly select channels that were

either erased or not memorized. To change to single-digit channels (0~9) faster,

press “0” before the single digit. (For channel “4” press “0”, then “4”.

Using the Pre-CH button to select the previous channel

Press the PRE-CH button. The TV will switch to the last channel viewed.

To quickly switch between two channels that are far apart, tune to one

channel, then use the number button to select the second channel. Then,

use the PRE-CH button to quickly alternate between them.

Adjusting the Volume

Using the Volume Buttons

Press the VOL + or VOL – buttons to increase or decrease the volume.

Using Mute

Using the MUTE Buttons

At any time, you can temporarily cut off the sound using the MUTE button.

1 Press the MUTE button and the sound cuts off.

The word “Mute” will appear in the lower-left

corner of the screen.

2 To turn mute off, press the MUTE button again, or

simply press the VOL + or VOL – button.

Mute

38

PLASMA DISPLAY PANEL

Picture Control

Customizing the Picture ................................................................40

Using Automatic Picture Settings ....................................................41

Selecting the Color Tone................................................................42

DNIe (Digital Natural Image engine) ............................................43

Viewing the Picture-in-Picture..........................................................44

Changing the Screen Size ............................................................50

Freezing the Picture ......................................................................51

Remote Control Codes

VCR Codes

Cable Box Codes

DVD Codes

Customizing the Picture

You can use the on-screen menus to change the Contrast, Brightness, Sharpness, Color,

and Tint settings of your PDP.

41

1 Press the MENU button, then press the ENTER

button.

2 Press the LEFT or RIGHT button to select “Custom”,

“Dynamic”, “Standard” or “Movie” picture setting.

• You can select “High”, “Middle”, “Low” or

“Custom” in PC/DVI mode.

3 Press the MENU button to exit.

Using Automatic Picture Settings

Your PDP has automatic picture settings that allow you to adjust the video display easily.


Mode

Adjust

Color Tone

DNIe

Move Select Menu

Custom

Custom

On


Mode

Adjust

Color Tone

DNIe

Move Select Menu

Dynamic

Custom

On

40

1 Press the MENU button, then press the ENTER

button.

2Press the UP or DOWN button to select “Adjust”,

then press the ENTER button.

You will also see the items “Contrast”, “Brightness”,

“Sharpness”, “Color” and “Tint”.

3 Press the UP or DOWN button to select the item you

wish to change.

4 Press the LEFT or RIGHT button to change the value

of the item.

5 Press the MENU button to exit.

Note

• In the PC/DVI mode, you can’t adjust the Color and Tint.


Mode

Adjust

Color Tone

DNIe

Move Select Menu

Custom

Custom

On


Mode

Adjust

Color Tone

DNIe

Move Enter Menu

Custom

Normal

On

Adjust

Contrast

Brightness

Sharpness

Color

Tint R 50 G 50

Move Adjust Menu

80

50

50

50

82Contrast

➤

➤

Quick way to access the picture setting: Just press the “P.MODE”

button under the cover of the remote control.

42

Selecting the Color Tone

1 Press the MENU button, then press the ENTER

button.

2 Press the UP or DOWN button to select “Color

Tone”, then press the LEFT or RIGHT button to select

“Normal”, “Warm1”, “Warm2”, “Cool2” or

“Cool1”.

• You can select “Custom”, “Color1”, “Color2” or

“Color3” in PC mode.

• You can select “Color1”, “Color2” or “Color3” in

DVI mode.

3 Press the MENU button to exit.

.


Mode

Adjust

Color Tone

DNIe

Move Select Menu

Custom

Custom

On


Mode

Adjust

Color Tone

DNIe

Move Select Menu

Custom

Normal

On

DNIe (Digital Natural Image engine)

Samsung’ s New Technology brings you more detailed images with contrast and

white enhancement and 3D noise reduction.

1 Press the MENU button, then press the ENTER

button.

2 Press the UP or DOWN button to select “DNIe”,

then press the LEFT or RIGHT button to select

“On”, “Off” or “Demo”.

•On : Switches on the DNIe mode.

•Demo : The screen before applying DNIe

appears on the right and the screen after

applying DNIe appears on the left.

•Off : Switches off the DNIe mode.

3 Press the MENU button to exit.


Mode

Adjust

Color Tone

DNIe

Move Select Menu

Custom

Custom

On


Mode

Adjust

Color Tone

DNIe

Move Select Menu

Custom

Normal

On

43

➤

➤

Quick way to select DNIe : Simply press the “DNIe” button under

the cover of the remote control.

DNIe Demo

DNIe On DNIe Off

4544

Selecting an External Signal

You can use PIP to view a signal from an external source, such as a VCR.

1 Press the MENU button. Press the UP or DOWN

button to select “PIP”, then press the ENTER button.

2 Press the UP or DOWN button to select “Source”.

3 Press the LEFT or RIGHT button to cycle through

all of the available signal sources:

“TV”, “Video”, “S-Video”, “Component 1”,

“Component 2”, “PC” and “DVI”.

The signal from these inputs will not appear if you

have not connected any equipment to the PDP's

respective input jacks.

4 Press the MENU button to exit.

Note

• The PIP function operates in Wide screen.

• Using Multi-Screen in the Normal, Zoom1 or Zoom2 screen will change the size of the main screen

to Wide screen.

PIP

Select

Source

Swap

Size

Locate

Ant/CATV

Channel

Move Select Menu

On

TV

Large

Ant

Ant 5

PIP

Select

Source

Swap

Size

Locate

Ant/CATV

Channel

Move Select Menu

On

TV

Large

Ant

Ant 5

PIP

Select

Source

Swap

Size

Locate

Move Select Menu

On

Video

Large

Viewing the Picture-in-Picture

Selecting the PIP Screen

1 Press the MENU button. Press the UP or DOWN

button to select “PIP”, then press the ENTER button.

2Press the LEFT or RIGHT button to select “On”.

The PIP image will appear in the corner of the

screen.

•Pressing the LEFT or RIGHT button will alternate

between “On” and “Off.”

3 Press the MENU button to exit.

PIP Settings

PIP

Select

Select Menu

Off

PIP

Select

Source

Swap

Size

Locate

Ant/CATV

Channel

Move Select Menu

On

TV

Large

Ant

Ant 5

PIP screenMain screen TV Video S-Video Component 1 Component 2 PC DVI

TV

O

O

O

O

O

O

O

O

X

O

O

O

O

O

O

O

X

O

O

O

O

O

O

O

X

X

X

X

O

O

O

X

X

X

X

O

O

O

X

X

X

X

O

O

O

X

X

X

X

Video

S-Video

Component 1

Component 2

PC

DVI

O:

PIP and Swap Operate

X:

PIP doesn’t Operate

➤

➤

Quick way to access the PIP mode: Just press the “PIP” button on

the remote control.

4746

Changing the Size of the PIP Window

1 Press the MENU button. Press the UP or DOWN

button to select “PIP”, then press the ENTER button.

2 Press the UP or DOWN button to select “Size”.

3Press the LEFT or RIGHT button to select “Small”,

“Double” or “Large”.

4 Press the MENU button to exit.

PIP

Select

Source

Swap

Size

Locate

Ant/CATV

Channel

Move Select Menu

On

TV

Large

Ant

Ant 5

PIP

Select

Source

Swap

Size

Locate

Ant/CATV

Channel

Move Select Menu

On

TV

Large

Ant

Ant 5

PIP

Select

Source

Swap

Size

Locate

Ant/CATV

Channel

Move Select Menu

On

TV

Small

Ant

Ant 5

Swapping the Contents of the PIP Image and Main Image

1 Press the MENU button. Press the UP or DOWN

button to select “PIP”, then press the ENTER button.

2 Press the UP or DOWN button to select “Swap”,

then press the ENTER button.

•The image in the PIP window will appear on the

main screen, and vice versa.

3 Press the MENU button to exit.

PIP

Select

Source

Swap

Size

Locate

Ant/CATV

Channel

Move Select Menu

On

TV

Large

Ant

Ant 5

PIP

Select

Source

Swap

Size

Locate

Ant/CATV

Channel

Move Enter Menu

On

TV

Large

Ant

Ant 5

➤

➤

Quick way to access swapping: Just press the “SWAP” button under

the cover of the remote control.

➤

➤

Quick way to access the PIP size: Just press the “SIZE” button

under the cover of the remote control.

4948

Changing the PIP Channel

1 Press the MENU button. Press the UP or DOWN

button to select “PIP”, then press the ENTER button.

2

Press the UP or DOWN button to select “Ant/CATV”

.

Press the LEFT or RIGHT button to select “Ant”,

“STD”, “HRD” or “IRC”.

3

Press the UP or DOWN button

to select “Channel”.

Press the LEFT or RIGHT button to change the

channel that appears in the PIP window.

4 Press the MENU button to exit.

PIP

Select

Source

Swap

Size

Locate

Ant/CATV

Channel

Move Select Menu

On

TV

Large

Ant

Ant 5

PIP

Select

Source

Swap

Size

Locate

Ant/CATV

Channel

Move Select Menu

On

TV

Large

STD

STD 5

PIP

Select

Source

Swap

Size

Locate

Ant/CATV

Channel

Move Select Menu

On

TV

Large

STD

STD 9

Changing the Location of the PIP Image

1 Press the MENU button. Press the UP or DOWN

button to select “PIP”, then press the ENTER button.

2 Press the UP or DOWN button to select “Locate”.

3 Press the LEFT or RIGHT button to move the PIP

screen where you want.

4 Press the MENU button to exit.

PIP

Select

Source

Swap

Size

Locate

Ant/CATV

Channel

Move Select Menu

On

TV

Large

Ant

Ant 5

PIP

Select

Source

Swap

Size

Locate

Ant/CATV

Channel

Move Select Menu

On

TV

Large

Ant

Ant 5

PIP

Select

Source

Swap

Size

Locate

Ant/CATV

Channel

Move Select Menu

On

TV

Large

Ant

Ant 5

➤

➤

Quick way to change the PIP channel: Just press the “CH

▲

“

or

“CH

▼

” button under the cover of the remote control.

5150

Changing the Screen SizeChanging the Screen Size

W

Wide

ide

Sets the picture to 16:9 wide mode.

Panorama

Converts regular 4:3 aspect ratio screen to

wide screen.

Zoom1

The screen size when Wide screen is vertically

enlarged.

Zoom2

The screen size when the Zoom1 screen is

vertically enlarged.

Normal (4:3)

Sets the picture to 4:3 normal mode.

Notes

• In TV, VIDEO, S-VIDEO and Component(480i) modes, all screen modes can be selected.

(Wide ➝ Panorama ➝ Zoom1 ➝ Zoom2 ➝ Normal).

• In PC/DVI mode, only Wide & Normal modes can be selected.

• In Component(480p, 720p. 1080i) modes, Panorama mode can’t be selected.

• In Component(480p, 720p. 1080i) modes, you can move the picture on screen by pressing

the Up▲or Down▼button. (All screen modes)

• Changing the screen size to Normal, Zoom1 or Zoom2 during PIP mode will cause the PIP

window to disappear.

When you press the ASPECT button on the remote control, the PDP’s screen mode should appear in

sequence. The screen displays in this order: Wide, Panorama, Zoom1, Zoom2, Normal.

Note

• If you watch a still image or the Normal (4:3) mode for a long time (over 2 hours), an image may

be burned onto the screen. View the monitor in Wide or Panorama mode as much as possible.

Wide

Panorama

Normal

Zoom1 Up/Down

Zoom2 Up/Down

Still

Press the Still button on the remote control to freeze a

moving picture. Press again to cancel.

PLASMA DISPLAY PANEL

Sound Control

Customizing the Sound ................................................................54

Using Automatic Sound Settings ....................................................55

Choosing a Multi-Channel Sound (MTS)Soundtrack ..........................56

Using the Auto Volume..................................................................57

Using Dolby Virtual ......................................................................58

Using a Subwoofer ......................................................................59

55

1 Press the MENU button. Press the UP or DOWN

button to select “Sound”, then press the ENTER

button.

2Press the LEFT or RIGHT button to select “Adjust”,

“Standard”, “Music”, “Movie” or “Speech” sound

setting.

3 Press the MENU button to exit.

Sound

Mode

Adjust

MTS

Auto Volume

Dolby Virtual

Woofer

Move Select Menu

Custom

Mono

Off

Off

Sound

Mode

Adjust

MTS

Auto Volume

Dolby Virtual

Woofer

Move Select Menu

Music

Off

Off

54

Customizing the Sound

1 Press the MENU button. Press the UP or DOWN

button to select “Sound”, then press the ENTER

button.

2Press the UP or DOWN button to select “Adjust”,

then press the ENTER button.

You will also see the items “Bass”, “Treble” and

“Balance”.

3Press the UP or DOWN button to select the item you

wish to change.

4 Press the LEFT or RIGHT button to change the value

of the item.

5 Press the MENU button to exit.

Sound

Mode

Adjust

MTS

Auto Volume

Dolby Virtual

Woofer

Move Select Menu

Custom

Mono

Off

Off

Sound

Mode

Adjust

MTS

Auto Volume

Dolby Virtual

Woofer

Move Enter Menu

Custom

Mono

Off

Off

Adjust

Bass

Treble

Balance

Move Adjust Menu

50

50

R 50

L 50

82Bass

Using Automatic Sound Settings

57

1 Press the MENU button. Press the UP or DOWN

button to select “Sound”, then press the ENTER

button.

2Press the UP or DOWN button to select “Auto

Volume”.

3 Press the LEFT or RIGHT button to select “On”.

•Pressing the LEFT or RIGHT button will alternate

between “On” and “Off.”

4 Press the MENU button to exit.

Sound

Mode

Adjust

MTS

Auto Volume

Dolby Virtual

Woofer

Move Select Menu

Custom

Mono

Off

Off

Sound

Mode

Adjust

MTS

Auto Volume

Dolby Virtual

Woofer

Move Select Menu

Standard

Mono

Off

Off

Sound

Mode

Adjust

MTS

Auto Volume

Dolby Virtual

Woofer

Move Select Menu

Standard

Mono

On

Off

56

Choosing a Multi-Channel Sound (MTS)

Soundtrack

Depending on the particular program being broadcast, you can listen to stereo, mono,

or a Separate Audio Program. (SAP audio is usually a foreign-language translation.

Sometimes SAP has unrelated information like news or weather.)

1 Press the MENU button. Press the UP or DOWN

button to select “Sound”, then press the ENTER

button.

2Press the UP or DOWN button to select “MTS”.

3 Press the LEFT or RIGHT button to select “Mono”,

“Stereo” or “SAP”.

4 Press the MENU button to exit.

Sound

Mode

Adjust

MTS

Auto Volume

Dolby Virtual

Woofer

Move Select Menu

Custom

Mono

Off

Off

Sound

Mode

Adjust

MTS

Auto Volume

Dolby Virtual

Woofer

Move Select Menu

Standard

Mono

Off

Off

Sound

Mode

Adjust

MTS

Auto Volume

Dolby Virtual

Woofer

Move Select Menu

Standard

Stereo

Off

Off

• Choose Stereo

Stereo for channels that are broadcasting in stereo.

• Choose Mono

Mono for channels that are broadcasting in mono, or if you are having difficulty receiving

a stereo signal.

• Choose SAP

SAP to listen to the Separate Audio Program, which is usually a foreign-language translation.

Note

• The MTS function operates in TV mode only.

Using the Auto Volume

Each broadcasting station has its own signal conditions, which can make it necessary to

adjust the volume every time the channel is changed. “Auto volume” lets you automatically

adjust the volume of the desired channel by lowering the sound output when the modula-

tion signal is high or by raising the sound output when the modulation signal is low.

➤

➤

Quick way to access the MTS menu: Just press the “MTS” button on

the remote control.

59

1 Press the MENU button. Press the UP or DOWN

button to select “Sound”, then press the ENTER

button.

2Press the UP or DOWN button to select “Woofer”,

then press the ENTER button.

3 Press the LEFT or RIGHT button to select “On”.

•Pressing the LEFT or RIGHT button will alternate

between “On” and “Off.”

4Press the UP or DOWN button to select “Volume”,

then press the LEFT or RIGHT button to adjust the

value of the item.

This sets the volume for the subwoofer.

5Press the UP or DOWN button to select “Cutoff

Freq.”, then press the LEFT or RIGHT button to adjust

the value of the item.

This sets the cutoff frequency for the subwoofer.

For example, if you set the cutoff frequency at

130Hz, the subwoofer will reproduce frequencies

of 130Hz and lower.

6 Press the MENU button to exit.

Sound

Mode

Adjust

MTS

Auto Volume

Dolby Virtual

Woofer

Move Select Menu

Custom

Mono

Off

Off

Sound

Mode

Adjust

MTS

Auto Volume

Dolby Virtual

Woofer

Move Enter Menu

Standard

Mono

Off

Off

Woofer

Woofer

Volume

Cutoff Freq.

Move Select Menu

On

50

120Hz

Woofer

Woofer

Volume

Cutoff Freq.

Move Adjust Menu

On

50

120Hz

65Volume

Woofer

Woofer

Volume

Cutoff Freq.

Move Adjust Menu

On

50

130Hz

58

Using Dolby Virtual

This feature allows the PDP’s optional L/R speakers to provide a Home Theater-like Dolby

effect. The center and surround sounds are mixed into the L/R speakers.

1 Press the MENU button. Press the UP or DOWN

button to select “Sound”, then press the ENTER

button.

2Press the UP or DOWN button to select “Dolby

Virtual”.

3 Press the LEFT or RIGHT button to select “On”.

•Pressing the LEFT or RIGHT button will alternate

between “On” and “Off.”

4 Press the MENU button to exit.

Sound

Mode

Adjust

MTS

Auto Volume

Dolby Virtual

Woofer

Move Select Menu

Custom

Mono

Off

Off

Sound

Mode

Adjust

MTS

Auto Volume

Dolby Virtual

Woofer

Move Select Menu

Standard

Mono

Off

Off

Sound

Mode

Adjust

MTS

Auto Volume

Dolby Virtual

Woofer

Move Select Menu

Standard

Mono

Off

On

Using a Subwoofer

➤

➤

Quick way to access the Surround: Just press the “SURROUND”

button on the remote control.

PLASMA DISPLAY PANEL

Channel Control

Fine Tuning Channels....................................................................62

LNA (Low Noise Amplifier)............................................................63

63

Fine Tuning Channels

Use fine tuning to manually adjust a particular channel for optimal reception.

62

1Press the MENU button. Press the UP or DOWN

button to select “Channel”, then press the ENTER

button.

2 Press the UP or DOWN button to select “Fine

Tune”.

3 Press the LEFT or RIGHT button to adjust the fine

tuning.

4To store the fine tuning setting in the TV’s memory,

press the UP button.(A star icon<*>will appear.)

To reset the fine tuning to “0”, press the DOWN

button.

5 Press the MENU button to exit.

Channel

Ant/ CATV

Auto Program

Fine Tune

LNA

Ch. Scan

Move Select Menu

Ant

Off

0

Channel

Air / CATV

Auto Program

Fine Tune

LNA

Ch. Scan

Move Adjust Menu

Air

Off

0

Channel

Air / CATV

Auto Program

Fine Tune

LNA

Ch. Scan

Add/Erase Adjust Menu

Air

Off

+3

Channel

Air / CATV

Auto Program

Fine Tune

LNA

Ch. Scan

Add/Erase Adjust Menu

Air

Off

+3

LNA (Low Noise Amplifier)

If the TV is operating in a weak-signal area, sometimes the LNA function can improve

the reception (a low-noise preamplifier boosts the incoming signal).

1Press the MENU button. Press the UP or DOWN

button to select “Channel”, then press the ENTER

button.

2 Press the UP or DOWN button to select “LNA”.

3Press the LEFT or RIGHT button to select “On.”

•Pressing the LEFT or RIGHT button will alternate

between “On” and “Off.”

4 Press the MENU button to exit.

Channel

Ant/ CATV

Auto Program

Fine Tune

LNA

Ch. Scan

Move Select Menu

Ant

Off

0

Channel

Air / CATV

Auto Program

Fine Tune

LNA

Ch. Scan

Move Select Menu

Air

Off

0

Channel

Air / CATV

Auto Program

Fine Tune

LNA

Ch. Scan

Move Select Menu

Air

On

0

PLASMA DISPLAY PANEL

Connecting a PC and Operation

Connecting to a PC......................................................................66

Adjusting the PC Screen................................................................70

Changing the Position of the Image................................................71

Changing the Size of the Image ....................................................72

Information..................................................................................73

Picture Quality Adjustment ............................................................74

67

Connecting to a PC

Connection to a Macintosh computer may require in adapter.

66

Connect a PC (15pin) cable between the PC Output jack (or DVI jack) on the PC and the

RGB IN(or DVI IN) Input jack (15p D-SUB) on the PDP.

Connect a Audio cable between the Audio (RGB or DVI) on the PC and the Audio L/R (RGB

or DVI) input jacks on the PDP.

To watch the PC screen:

1. Turn on your PDP, and press the TV/VIDEO button on the remote control.

2. Press the UP or DOWN button to select “PC”, then press the ENTER button.

3. Turn on PC and check for PC system requirements. (Refer to pages 66 and 67

for PC system requirements.)

4. Adjust the PC screen. (Refer to pages 70 and 76.)

Connecting a PC to the PDP

Audio CablePC CableDVI Cable

Power Plug

1

2

Pin Configuration

D-Sub Cable

DVI-D Cable (Digital-Only Connector)

• 15Pin Signal Cable (based on protruded pin)

Setting up Your PDP (Plug and Play)

Our adoption of the new VESAPlug and Play solution eliminates complicated and time consuming

setup. It allows you to install your monitor in a Plug and Play compatible system, without the usual

setup hassles and confusion. Your PC system can easily identify and configure itself for use with your

display. This monitor automatically tells the PC system its Extended Display Identification data (EDID)

using Display Data Channel (DDC) protocols.

DVI jack

(The actual config-

uration on your PC

may be different,

depending on the

model.)

PDP

PC

or

Use the DVI-D

connection cable.

(sold separately)

Ferrite Cores

6968

How to Set up Your PC Software (Windows only)

The Windows display-settings for a typical computer are shown below. However, the actual screens

on your PC will probably be different, depending upon your particular version of Windows and your

particular video card. But even if your actual screens look different, the same, basic set-up information

will apply in almost all cases. (If not, contact your computer manufacturer or Samsung Dealer.)

On the windows screen, select in the following

sequence : Start ➝ Settings ➝ Control Panel.

When the control panel screen appears, click on

“Display” and a display dialog-box will appear.

Select the “Settings” tab in the display dialog-

box.

The two key variables that apply to the PDP-PC

interface are “resolution” and “colors”.

The correct settings for these two variables are:

• Size (sometimes called “resolution”)

:640 x 480 pixels.

• Color: “24-bit” color (might also be expre-

ssed as “16 million colors”)Shown at left is

a typical screen for “Display” dialog box.

If a vertical-frequency option exists on your

display settings dialog box, the correct value is

“60” or “60 Hz.” Otherwise, just click “OK”

and exit the dialog box.

Continued...

Notes:

Both screen position and size will vary, depending on the type of PC monitor and its resolution.

The table below shows all of the display modes that are supported:

• The interlace mode is not supported.

• The PDP operates abnormally if a non-standard video format is selected.

Notes:

• When this PDP is used as a PC display, 32-bit color is supported.

• Depending on the manufacturer, your PC display screen might appear different.

(and depending on your particular version of Windows).

Check your PC instruction book for information about connecting your PC to a PDP.

• If a vertical and horizontal frequency-select mode exists, select 60Hz (vertical) and 31.5kHZ

(horizontal).

• In some cases, abnormal signals (such as stripes) might appear on the screen when the PC power

is turned off (or if the PC is disconnected). If so, press the Source button to enter the VIDEO mode.

Also, make sure that the PC is connected.

• Connect only a PC monitor to the monitor output port while viewing the PC screen. (Otherwise,

random signals might appear).

Video signal Dot X Line

640 X 350

640 X 400

720 X 400

640 X 480

800 X 600

1024 X 768

70.086

85.080

85.080

70.087

85.039

59.940

72.809

75.000

85.008

56.250

60.317

72.188

75.000

85.061

60.004

70.069

75.029

84.997

31.469

37.861

37.861

31.469

37.927

31.469

37.861

37.500

43.269

35.156

37.879

48.077

46.875

53.674

48.363

56.476

60.023

68.677

N

N

P

P

P

N

N

N

N

N/P

P

P

P

P

N

N

P

P

P

P

N

N

N

N

N

N

N

N/P

P

P

P

P

N

N

P

P

Vertical

Frequency (Hz) Horizontal

Frequency (KHz) Vertical

polarity Horizontal

polarity

IBM PC / AT

Compatible

71

Adjusting the PC Screen

70

Adjusting the R.G.B

Preset:

•Press the TV/VIDEO button, then press the UP or DOWN button to select PC.

Press the ENTER button to select PC mode.

1 Press the MENU button, then press the ENTER

button.

2 Press the UP or DOWN button to select “Color

Tone”, then Press the LEFT or RIGHT button to select

“Custom”. When “Custom” is selected, the word

“Color Adjust” will appear on the screen.

3 Press the UP or DOWN button to select “Color

Adjust”, then press the ENTER button.

4Press the UP or DOWN button to select the item you

want to change, then press the RIGHT or LEFT

button to change the value of the item, using the

on-screen gauge as your guide.

5 Press the MENU button to exit.


Mode

Adjust

Color Tone

Color Adjust

DNIe

Move Select Menu

Custom

Custom

On


Mode

Adjust

Color Tone

Color Adjust

DNIe

Move Select Menu

Custom

Custom

On


Mode

Adjust

Color Tone

Color Adjust

DNIe

Move Enter Menu

Custom

Custom

On

Adjust

Red

Green

Blue

Move Adjust Menu

50

50

50

82Red

Changing the Position of the Image

After connecting the PDP to your PC, adjust the position of the screen if it is not well-aligned.

Preset:

•Press the TV/VIDEO button, then press the UP or DOWN button to select PC.

Press the ENTER button to select PC mode.

1 Press the MENU button. Press the UP or DOWN

button to select “PC”, then press the ENTER button.

2Press the MENU button, then adjust the screen posi-

tion by using the UP/DOWN/LEFT/RIGHT button.

3 Press the MENU button to exit.

PC

Position

Adjust

Scaling

Information

Auto Adjust

Move Enter Menu

Wide

Position

Move Move Menu

73

Changing the Size of the Image

72

Preset:

•Press the TV/VIDEO button, then press the UP or DOWN button to select PC.

Press the ENTER button to select PC mode.

1 Press the MENU button. Press the UP or DOWN

button to select “PC”, then press the ENTER button.

2 Press the UP or DOWN button to select “Scaling”.

3 Press the LEFT or RIGHT button to select “Wide”

or “Normal”.

4 Press the MENU button to exit.

PC

Position

Adjust

Scaling

Information

Auto Adjust

Move Enter Menu

Wide

PC

Position

Adjust

Scaling

Information

Auto Adjust

Move Select Menu

Wide

PC

Position

Adjust

Scaling

Information

Auto Adjust

Move Select Menu

Normal

Information

Preset:

•Press the TV/VIDEO button, then press the UP or DOWN button to select PC.

Press the ENTER button to select PC mode.

1 Press the MENU button. Press the UP or DOWN

button to select “PC”, then press the ENTER button.

2Press the UP or DOWN button to select “Informa-

tion”, then press the ENTER button.

The vertical, horizontal frequencies and resolution

appear.

3 Press the MENU button to exit.

PC

Position

Adjust

Scaling

Information

Auto Adjust

Move Enter Menu

Wide

PC

Position

Adjust

Scaling

Information

Auto Adjust

Move Enter Menu

Wide

Information

Resolution : 1024 * 768

H-Frequency : 48.52 KHz

V-Frequency : 60.21 Hz

Menu

75

Coarse Adjustment

Preset:

•Press the TV/VIDEO button, then press the UP or DOWN button to select PC.

Press the ENTER button to select PC mode.

1 Press the MENU button. Press the UP or DOWN

button to select “PC”, then press the ENTER button.

2 Press the UP or DOWN button to select “Adjust”,

then press the ENTER button.

3 Press the UP or DOWN button to select “Coarse”.

Remove picture noise (vertical stripes) on the screen

by pressing the LEFT or RIGHT button. (If Coarse is

not set properly, vertical stripes will appear on the

screen.)

4 Press the MENU button to exit.

PC

Position

Adjust

Scaling

Information

Auto Adjust

Move Enter Menu

Wide

PC

Position

Adjust

Scaling

Information

Auto Adjust

Move Enter Menu

Wide

Adjust

Corase

Fine

Move Adjust Menu

50

7

53Coarse

74

Picture Quality Adjustment

Picture Automatic Adjustment

Preset:

•Press the TV/VIDEO button, then press the UP or DOWN button to select PC.

Press the ENTER button to select PC mode.

1 Press the MENU button. Press the UP or DOWN

button to select “PC”, then press the ENTER button.

2 Press the UP or DOWN button to select “Auto

Adjust”, then press the ENTER button.

3The message “Auto Adjust” appears on the screen

and the picture adjustments are automatically

activated.

4 Press the MENU button to exit.

PC

Position

Adjust

Scaling

Information

Auto Adjust

Move Enter Menu

Wide

PC

Position

Adjust

Scaling

Information

Auto Adjust

Move Enter Menu

Wide

Auto Adjust

76

PLASMA DISPLAY PANEL

Time Setting

Setting the Clock.......................................................................78

Setting the Sleep Timer...............................................................79

Setting the Timers......................................................................80

Setting the Preferred Channel and Volume Level............................82

Fine Tuning (Fine)

Preset:

• Press the TV/VIDEO button, then press the UP or DOWN button to select PC.

Press the ENTER button to select PC mode.

1 Press the MENU button. Press the UP or DOWN

button to select “PC”, then press the ENTER button.

2 Press the UP or DOWN button to select “Adjust”,

then press the ENTER button.

3 Press the UP or DOWN button to select “Fine”.

Remove picture noise on the screen by pressing the

LEFT or RIGHT button. (If Fine is not set properly,

noise will appear on the screen.)

4 Press the MENU button to exit.

PC

Position

Adjust

Scaling

Information

Auto Adjust

Move Enter Menu

Wide

PC

Position

Adjust

Scaling

Information

Auto Adjust

Move Enter Menu

Wide

Adjust

Corase

Fine

Move Adjust Menu

50

7

53Fine

7978

Setting the Clock

You can set your PDP to automatically turn off after a preset interval.

1Press the MENU button. Press the UP or DOWN

button to select “Function”, then press the ENTER

button.

2 Press the UP or DOWN button to select “Time”, then

press the ENTER button.

3 Press the UP or DOWN button to select “Sleep”.

4Press the LEFT or RIGHT button to select the time

interval for the PDP to stay on. The interval ranges

from 10 to 180 minutes.

5 Press the MENU button to exit.

Setting the Sleep Timer

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Select Menu

English

Off

Off

Off

Time

Clock

On Time

Off Time

Sleep

On Time Volume

On Time Channel

Move Select Menu

10 : 30

am

- -

:

- -

am

- -

:

- -

am

Off

Off

Off

10

3

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Enter Menu

English

Off

Off

Off

Time

Clock

On Time

Off Time

Sleep

On Time Volume

On Time Channel

Move Select Menu

10 : 30

am

- -

:

- -

am

- -

:

- -

am

Off

Off

30

10

3

1Press the MENU button. Press the UP or DOWN

button to select “Function”, then press the ENTER

button.

2Press the UP or DOWN button to select “Time”, then

press the ENTER button.

3Press the LEFT or RIGHT button to select hour, then

press the UP or DOWN button to select the correct

hour.

4Press the LEFT or RIGHT button to select minute, then

press the UP or DOWN button to select the correct

minute.

5 Press the MENU button to exit.

Note

• Time setting will be reset when you pull out the Power cord if the PDP is ON.

(If you want to keep the time setting, turn the PDP off using the POWER button on the remote control

or the Front Panel.)

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Enter Menu

English

Off

Off

Off

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Select Menu

English

Off

Off

Off

Time

Clock

On Time

Off Time

Sleep

On Time Volume

On time Channel

Adjust Move Menu

10 :

- -

am

- -

:

- -

am

- -

:

- -

am

Off

Off

Off

10

3

Time

Clock

On Time

Off Time

Sleep

On Time Volume

On time Channel

Adjust Move Menu

10 : 30

am

- -

:

- -

am

- -

:

- -

am

Off

Off

Off

10

3

➤

➤

Quick way to access the sleep timer: Just press the “SLEEP” button

on the remote control.

8180

Setting the Timers

This PDP can be set to turn on or off automatically at specific times that you choose. Before

using the timers, you must set the PDP’s clock, as described previously.

6 Press the LEFT or RIGHT button to select “Off” or

“On”, then press the UP or DOWN button to select

“Off” or “On”.

7If you want to set Off Time, press the UP or DOWN

button to select the “Off Time”.

Set the “Off Time” just as you set “On Time”.

8 Press the MENU button to exit.

Note

• If you set to On Time or Off Time, the Power Indicator on the Front Panel is changed to Green.

Setting the On/Off Timer

1Press the MENU button. Press the UP or DOWN

button to select “Function”, then press the ENTER

button.

2 Press the UP or DOWN button to select “Time”, then

press the ENTER button.

3 Press the UP or DOWN button to select “On Time”.

4Press the LEFT or RIGHT button to select hour, then

press the UP or DOWN button to select the correct

hour.

5Press the LEFT or RIGHT button to select minute, then

press the UP or DOWN button to select the correct

minute.

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Select Menu

English

Off

Off

Off

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Enter Menu

English

Off

Off

Off

Time

Clock

On Time

Off Time

Sleep

On Time Volume

On time Channel

Move Select Menu

10 : 30

am

- -

:

- -

am

- -

:

- -

am

Off

Off

Off

10

3

Time

Clock

On Time

Off Time

Sleep

On Time Volume

On time Channel

Adjust Move Menu

10 : 30

am

7 :

- -

am

- -

:

- -

am

Off

Off

Off

10

3

Time

Clock

On Time

Off Time

Sleep

On Time Volume

On time Channel

Adjust Move Menu

10 : 30

am

7 : 30

am

- -

:

- -

am

Off

Off

Off

10

3

Time

Clock

On Time

Off Time

Sleep

On Time Volume

On time Channel

Adjust Move Menu

10 : 30

am

7 : 30

am

- -

:

- -

am

On

Off

Off

10

3

Time

Clock

On Time

Off Time

Sleep

On Time Volume

On Time Channel

Move Select Menu

12 : 00

am

7 : 30

am

- -

:

- -

am

On

Off

Off

10

3

Selecting a Menu Language .....................................................84

Viewing Closed Captions.........................................................85

Digital Noise Reduction ...........................................................86

Setting Auto Power Off ...........................................................87

Using the V-Chip .....................................................................88

Selecting the Film Mode...........................................................94

PLASMA DISPLAY PANEL

Function Description

82

Setting the Preferred Channel

and Volume Level

The preferred channel and volume can be set for when the timer automatically turns on the TV.

1Press the MENU button. Press the UP or DOWN

button to select “Function”, then press the ENTER

button.

2 Press the UP or DOWN button to select “Time”, then

press the ENTER button.

3Press the UP or DOWN button to select “On Time

Volume”.

Press the LEFT or RIGHT button to adjust volume

level.

4Press the UP or DOWN button to select “On Time

Channel”.

Press the LEFT or RIGHT button to select the channel.

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Select Menu

English

Off

Off

Off

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Enter Menu

English

Off

Off

Off

Time

Clock

On Time

Off Time

Sleep

On Time Volume

On Time Channel

Move Select Menu

- -

:

- -

am

- -

:

- -

am

- -

:

- -

am

Off

Off

Off

10

3

Time

Clock

On Time

Off Time

Sleep

On Time Volume

On Time Channel

Move Select Menu

- -

:

- -

am

- -

:

- -

am

- -

:

- -

am

Off

Off

Off

10

3

Selecting a Menu Language

8584

1Press the MENU button. Press the UP or DOWN

button to select “Function”, then press the ENTER

button.

2 Press the UP or DOWN button to select “Caption”,

then press the ENTER button.

3Press the LEFT or RIGHT button to turn closed cap-

tioning On/Off.

4Press the UP or DOWN button to select “Mode”,

then press the LEFT or RIGHT button to select

“Caption” or “Text.”

5Depending on the particular broadcast, it might be

necessary to make changes to “Channels” and

“Field”: Press the UP/DOWN/LEFT/RIGHT button

to make the changes. (Follow the same procedure

as in steps 3~4 above.)

Press the MENU button to exit.

Note

• Different channels and fields display different information: Field 2 carries additional information

that supplements the information in Field 1. (For example, Channel 1 may have subtitles in English,

while Channel 2 has subtitles in Spanish.

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Select Menu

English

Off

Off

Off

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Enter Menu

English

Off

Off

Off

Caption

Caption

Mode

Channel

Field

Move Select Menu

On

Caption

2

1

Caption

Caption

Mode

Channel

Field

Move Select Menu

On

Text

2

1

1Press the MENU button. Press the UP or DOWN

button to select “Function”, then press the ENTER

button.

2 Press the LEFT or RIGHT button to select the appro-

priate language : English, Français or Español.

3 Press the MENU button to exit.

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Select Menu

English

Off

Off

Off

Viewing Closed Captions

Your TV decodes and displays the closed captions that are broadcast with certain

TV shows. These captions are usually subtitles for the hearing impaired or foreign-

language translations. All VCRs record the closed caption signal from television

programs, so home-recorded video tapes also provide closed captions. Most pre-

recorded commercial video tapes provide closed captions as well. Check for the

closed caption symbol in your television schedule and on the tape’s packaging: .

Note: The Caption feature does not work with DVD or DTV signals.

1Press the MENU button. Press the UP or DOWN

button to select “Function”, then press the ENTER

button.

2 Press the UP or DOWN button to select “Auto

Power Off”.

3Press the LEFT or RIGHT button to select “On”.

4 Press the MENU button to exit.

Note

• If the Off timer is set, Auto Power Off will not function.

• The power will be turned off automatically after 15 minutes if the PDP is ON and there is no input

signal. (For instance, if you select a channel without a signal while in TV mode or when there is no

input signal after selecting an output signal)

8786

Digital Noise Reduction

If the broadcast signal received by your TV is weak, you can activate the Digital Noise

Reduction feature to help reduce any static and ghosting that may appear on the screen.

1Press the MENU button. Press the UP or DOWN

button to select “Function”, then press the ENTER

button.

2 Press the UP or DOWN button to select “NR”.

3Press the LEFT or RIGHT button to select “On”.

4 Press the MENU button to exit.

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Select Menu

English

Off

Off

Off

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Select Menu

English

Off

Off

Off

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Select Menu

English

On

Off

Off

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Select Menu

English

Off

Off

Off

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Select Menu

English

Off

Off

Off

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Select Menu

English

Off

On

Off

Setting Auto Power Off

The PDP can be set to turn off automatically if no buttons are pressed for 3 hours

after the PDP turns on via the On timer.

8988

Using the V-Chip

The V-Chip feature automatically locks out programs that are deemed inappropriate

for children. The user must enter a PIN (personal ID number) before any of the V-Chip

restrictions are set up or changed.

Note : When the V-chip feature is activated, the PIP and auto channel program features

do not function.

Setting Up Your Personal ID Number (PIN)

1Press the MENU button. Press the UP or DOWN

button to select “Function”, then press the ENTER

button.

2 Press the UP or DOWN button to select “V-Chip”,

then press the ENTER button.

3 The message "Enter Pin" will appear. Enter your

4-digit PIN number.

Note: The default PIN number of a new TV set is

“0-0-0-0.”

4The “V-Chip” screen will appear. Press the UP or

DOWN button to select “Change Pin,” then press

the ENTER button.

5The Change pin screen will appear. Choose any

4-digits for your PIN and enter them.

As soon as the 4 digits are entered, the “Confirm

New Pin” screen appears. Re-enter the same 4

digits. When the Confirm screen disappears, your

PIN has been memorized.

6 Press the MENU button to exit.

Note

• If you forget the PIN, press the remote-control buttons in the following sequence, which resets the pin

to 0-0-0-0 : Power Off ➔ Mute ➔8 ➔2 ➔4 ➔Power On.

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Select Menu

English

Off

Off

Off

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Enter Menu

English

Off

On

Off

V-Chip

Enter Pin

Enter Pin :

----

V-Chip

V-Chip Lock

TV GuideLines

MPAA Rating

Change Pin

No

Move Enter Menu

V-Chip

Change Pin

Enter New Pin :

----

V-Chip

Confirm New Pin

Confirm New Pin :

-

How to Enable/Disable the V-Chip

1Press the MENU button. Press the UP or DOWN

button to select “Function”, then press the ENTER

button.

2 Press the UP or DOWN button to select “V-Chip”,

then press the ENTER button.

3 The message "Enter Pin" will appear. Enter your

4-digit PIN number.

4The “V-Chip” screen will appear.

To enable the V-Chip feature, press the RIGHT button

so that the “V-Chip Lock” field is Yes.

(Pressing the left or right button will alternate

between “Yes” and “No”.)

5 Press the MENU button to exit.

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Select Menu

English

Off

Off

Off

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Enter Menu

English

Off

On

Off

V-Chip

Enter Pin

Enter Pin :

----

V-Chip

V-Chip Lock

TV GuideLines

MPAA Rating

Change Pin

Yes

Move Select Menu

9190

How to Set up Restrictions Using the “TV guidelines”

First, set up a personal identification number (PIN), and enable the V-Chip. (See previous section.)

Parental restrictions can be set up using either of two methods: The TV guidelines or the MPAA rating.

1Press the MENU button. Press the UP or DOWN

button to select “Function”, then press the ENTER

button.

2 Press the UP or DOWN button to select “V-Chip”,

then press the ENTER button.

3 The message "Enter Pin" will appear. Enter your

4-digit PIN number.

4The “V-Chip” screen will appear.

Press the UP or DOWN button to select “TV Guide-

Lines”, press the ENTER button.

5 The “TV GuideLines” screen will appear. Press the

UP or DOWN button to select one of the six age-

based categories:

TV-Y Young children

TV-Y7 Children 7 and over

TV-G General audience

TV-PG Parental guidance

TV-14 Viewers 14 and over

TV-MA Mature audience

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Select Menu

English

Off

Off

Off

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Enter Menu

English

Off

On

Off

V-Chip

Enter Pin

Enter Pin :

----

V-Chip

V-Chip Lock

TV GuideLines

MPAA Rating

Change Pin

No

Move Enter Menu

6At this point, one of the TV-Ratings is selected.

Press the RIGHT button : Depending on your existing setup, a letter “U” or “B” will start

blinking.

(U= Unblocked, B= Blocked)

While the “U” or ”B” is blinking, press the UP or DOWN button to block or unblock the

category.

Press the RIGHT button to save the TV guidelines. A TV-Rating will be selected,

and no letters will blink.

To select a different TV-Rating, press the UP or DOWN button and then repeat the process.

Note 1: The TV-Y7, TV-PG, TV-14 and TV-MA have additional options. See the next step to

change any of the following sub-ratings:

FV: Fantasy violence

D: Sexually Sugessive Dialog

L: Adult Language

S: Sexual situation

V: Violence

Note 2: The V-Chip will automatically block certain categories that are “more restrictive”.

For example, if you block “TV-Y” category, then TV-Y7 will automatically be blocked.

Similarly, if you block the TV-G category, then all the categories in the “young adult” group

will be blocked (TV-G, TV-PG, TV-14 and TV-MA). The sub-ratings (D, L, S, V) work together

similarly. (See next section.)

7How to set the FV, D, L, S and V sub-ratings.

First, select one of these TV-Ratings: TV-Y7, TV-PG, TV-14 or TV-MA (See Step 4, on

previous page).

Next, while the TV-Rating is selected, repeatedly press the RIGHT button.

This will cycle through the available sub-ratings (FV,L, S, D or V).

A blinking letter (“U” or “B”) will be displayed for each sub-rating. While the “U” or “B” is

blinking, press the UP or DOWN button to change the sub-rating.

Press the RIGHT button to save the TV guidelines. A TV-Rating will be selected and no

letters will select. To select a different TV-Rating, press the UP or DOWN button and then

repeat the process.

Note: The V-chip will automatically block certain categories that are “More restrictive”.

For example, if you block “L” sub-rating in TV-PG, then the “L” sub-ratings in TV-14 and

TV-MA will automatically be blocked.

8Press the MENU button to clear all the screens. (Or proceed to the next section, and set up

additional restrictions based on the MPAA codes).

Note

• Note: These categories consist of two separate groups: TV-Y and TV-Y7 (young children

through age 7), and TV-G through TV-MA (everybody else). The TV-Y and TV-Y7 categories

are colored blue.

The restrictions for these two groups work independently: If a household includes very young

children as well as young adults, the TV guidelines must be set up separately for each age

group. (See next step.)

TV GuideLines

B : Blocked

U : Unblocked

TV-Y

TV-Y7

TV-G

TV-PG

TV-14

TV-MA

All

U

U

U

U

U

U

FV

U

V

U

U

U

S

U

U

U

L

U

U

U

D

U

U

Move Select Menu

9392

How to Set up Restrictions using the MPAA Ratings: G, PG, PG-13, R, NC-17, X

The MPAA rating system uses the Motion Picture Association of America (MPAA) system, and its main application is

for movies. When the V-Chip lock is on, the TV will automatically block any programs that are coded with objection-

able ratings (either MPAA or TV-Ratings).

1Press the MENU button. Press the UP or DOWN

button to select “Function”, then press the ENTER

button.

2 Press the UP or DOWN button to select “V-Chip”,

then press the ENTER button.

3 The message "Enter Pin" will appear. Enter your

4-digit PIN number.

4

The “V-Chip” screen will appear.

Press the UP or

DOWN button

to select “MPAA Rating,”

press the

ENTER button

.

5

The “MPAA Rating” screen will appear. MPAA category.

Pressing the UP or DOWN button will cycle through the

MPAA categories:

While a particular category is selected, press the RIGHT button to activate it.

A selected letter (“U” or “B”) will be displayed. Press the UP or DOWN button to select “U” or ”B”.

Press the RIGHT button to save the settings.

Note: The V-Chip will automatically block any category that is “more restrictive. ”For example,

if you block the “PG-13” category, then “R”, “NC-17” and “X” will automatically be blocked also.

How to Reset the TV after the V-Chip Blocks a Channel (“Emergency Escape”)

If the TV is tuned to a restricted channel, the V-Chip will block it. The screen will go blank

and the following message will appear: “Excessive rating.”

To resume normal viewing, tune to a different channel using the number buttons.

Under certain conditions (depending on the rating of the local TV programs) the V-Chip might

lock out all the channels. In this case, use the V.Chip function for an “emergency escape”:

1 Press the MENU button.

2Press the UP or DOWN button to select “V-Chip”, then press the ENTER button.

3Enter your PIN number, and press the RIGHT button to temporarily disable the V-Chip

Lock.

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Select Menu

English

Off

Off

Off

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Enter Menu

English

Off

On

Off

V-Chip

Enter Pin

Enter Pin :

----

V-Chip

V-Chip Lock

TV GuideLines

MPAA Rating

Change Pin

No

Move Enter Menu

MPAA Rating

G

PG

PG-13

R

NC-17

X

NR

U

U

U

U

U

U

U

Move Enter Menu

B : Blocked

U : Unblocked

GGeneral audience (no restrictions).

PG Parental guidance suggested.

PG-13 PG-13 (Parents strongly cautioned).

R

R (Restricted. Children under 17 should be accompanied by an adult).

NC-17 No children under age 17.

XX (Adults only).

NR Not rated.

94

PLASMA DISPLAY PANEL

Appendix

Troubleshooting............................................................................96

Care and Maintenance ................................................................97

Specifications ..............................................................................98

Selecting the Film Mode

1 Press the MENU button. Press the UP or DOWN

button to select “Function”, then press the ENTER

button.

2 Press the DOWN button to select Film Mode, then

press the RIGHT or LEFT button to select “On” or

“Off”.

•On: Automatically senses and processes film

signals from all sources and adjusts the

picture for optimum quality.

•Off: Switches off the Film mode.

3 Press the MENU button to exit.

Note

• Film mode is supported in Video, S-Video, Component 480i.

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Select Menu

English

Off

Off

Off

Function

Language

Time

Caption

NR

Auto Power Off

V-Chip

Film Mode

Move Select Menu

English

Off

Off

On

9796

Troubleshooting

Problem

Poor picture.

Your Remote control does not

operate the PDP.

The PDP won’t turn on.

There is no screen image.

The image is too light or

too dark.

The image is too large or

too small.

Before you call a service technician, please scan this list of problems and possible solutions. It may save you

time and money.

Possible Solution

Check all wire connections.

Press the “Mode” button to put your remote control in the “TV”

mode.

Check if the power plug is connected.

Check to see that both the PDP and the source are plugged in

and turned on.

Adjust the Brightness or Contrast settings.

Adjust the Size settings.

With proper care, your PDP will give you many years of service. Please follow these guidelines to get

the maximum performance from your PDP.

Identifying Problems

• Do not put the PDP near extremely hot, cold, humid or dusty places.

• Do not put the PDP near appliances that create magnetic fields.

• Keep the ventilation openings clear.

• Do not place the PDP on a rough and slanted surface, such as cloth or paper.

Liquids

• Do not place liquids near or on the PDP.

Cabinet

• Never open the cabinet or touch the parts inside.

• Wipe your PDP with a clean, dry cloth. Never use water, cleaning fluids, wax, or chemicals.

• Do not put heavy objects on top of the cabinet.

Temperature

• If your PDP is suddenly moved from a cold to a warm place, unplug the power cord for at least two

hours so that moisture that may have formed inside the unit can dry completely.

Care and Maintenance

9998

MemoSpecifications

SPN4235

1027 (W) X 79 (D) X 630.5 (H) mm ; 40.43 (W) X 3.11 (D) X 24.82(H) inches

58 (W) X 21 (D) X 210 (H) mm ; 2.28 (W) X 0.83 (D) X 8.27 (H) inches

31 kg ; 68.34 lbs {37.6 kg ; 82.89 lbs (with stand)}

134g ; 0.295 lbs (including batteries)

120V~, 60Hz

370 Watts

852(H) x 480(V)

107 Cm/42 inches

VHF, UHF (75Ωunbalanced)

VIDEO

S-VIDEO

COMPONENT 1 - 480i / 480p / 720p / 1080i

COMPONENT 2 - 480i / 480p / 720p / 1080i

RGB : D-SUB 15P

DVI

VIDEO / S-VIDEO

COMPONENT 1

COMPONENT 2

PC (RGB)

DVI

10W + 10W (8 Ω)

Subwoofer (500mv RMS at 1KHz)

Model

Dimensions Display

Remote Control

Weight Display

Remote Control

Voltage

Power Consumption

Number of Pixels

Screen Size

ANTENNA input

VIDEO input

AUDIO input

AUDIO output

Exterior design and product specifications are subject to change without prior notice to improve

the performance of this product.

This PDP applies to Class B digital device.

(Note: Class B system is for home use.)

This PDP has been registered for residential use in terms of EMI. So it can be used in all areas as

well as residential areas.
