4G LTE SMARTPHONE
User Manual
Please read this manual before operating your
phone and keep it for future reference.
Applications and Development 166
Email
Email enables you to review and create email using most
email services. The device alerts you when you receive an
email message.
From the Home screen, tap (
Apps
)
(
Email
).
For more information, refer to “Using Email” on page 115.
Flipboard
This application creates a personalized digital magazine out
of everything being shared with you. Access news stories,
personal feeds and other related material. Flip through your
Facebook newsfeed, tweets from your Twitter account,
photos from friends and much more.
1. From the Home screen, tap (
Apps
)
(
Flipboard
).
2. Follow the on-screen instructions.
G+ Photos
This application provides a shortcut to the Photos tab inside
the Google+ app.
1. From the Home screen, tap (
Apps
)
(
G+ Photos
).
2. Follow the on-screen instructions.
Gallery
The Gallery is where you view photos and play back videos.
For photos, you can also perform basic editing tasks, view a
slideshow, set photos as wallpaper or caller image, and
share as a picture message.
From the Home screen, tap (
Apps
)
(
Gallery
).
For more information, refer to “The Gallery” on page 147.
167
Gmail
Google Mail (Gmail) is a web-based email service. Gmail is
configured when you first set up your device. Depending on
your synchronization settings, Gmail can automatically
synchronize with your Gmail account on the Web.
From the Home screen, tap (
Apps
)
(
Gmail
).
For more information, refer to “Using Google Mail” on page
126.
Creating a New Google Account
You should create a Google™ Account when you first use
your device in order to fully utilize the functionality. This
account provides access to several device features such as
Gmail™, Hangouts™, and the Google Play Store™
applications. Before you are able to access Google
applications, you must enter your account information. These
applications sync between your device and your online
Google account.
Signing into Your Google Account
1. Launch an application that requires a Google account
(such as Play Store or Gmail).
2. Click
Existing
.
3. Tap the
Email
and
Password
fields and enter your
information.
4. Tap (
Sign in
). Your device communicates with
the Google servers to confirm your information.
5. If prompted, you can enable the option to stay up to
date on news and offers, then tap
OK
.
Opening Gmail
1. From the Home screen, tap (
Apps
)
(
Gmail
).
2. Tap an existing email message.
Applications and Development 168
Google
Use Google Search to search the Web. Google Now® (a part
of the Google application) recognizes a user’s repeated
actions performed on the device (including access of
common locations, repeated calendar appointments, search
queries, etc.). This information is then used to display more
relevant information to the user in the form of “cards”. These
scrollable on-screen cards are displayed when the Google
Now application is launched.
These cards are not manually added. The service uses your
GPS, Google Search, and usage information to generate
these cards automatically.
From the Home screen, tap (
Apps
)
(
Google
) and enter the search text.
– or –
Tap on the Google Search bar and say the search
information.
To initially set up Google Now:
1. Press and hold (
Home
) and then tap
(
Google Now
).
– or –
From the Home screen, tap (
Apps
)
(
Google
).
2. Follow the on-screen instructions to review the
available information.
3. When prompted, agree to launch the application. Some
initial on-screen “cards” are shown. A default is the
Weather card that provides updated weather
information in your area.
To configure the Google Now settings:
1. From the Home screen, tap (
Apps
)
(
Google
).
2. Press and select
Settings
.
3. Access each desired Settings page and configure it as
desired.
When these condition are met, new card information will
begin to appear in the Google Now list of cards.
169
Note:
Google Now will recognize searches and display them
on your device, even if that search took place on your
home computer or on another device. These searches
are linked into your Google Account.
Google Settings
As Google has become more intertwined with other
applications, this menu provides a quick and ready access
point to configure preferences for Google+, Maps & Latitude,
Location, etc.. You can also use the Search function to
initiate a Google Search from this menu.
1. From the Home screen, tap (
Apps
)
(
Google Settings
) and select an on-screen option.
2. Select one of the available on-screen options.
Follow the on-screen prompts.
Google +
Google+ makes messaging and sharing with your friends a
lot easier. You can set up Circles of friends, visit the Stream
to get updates from your Circles, use Messenger for fast
messaging with everyone in your Circles, or use Instant
Upload to automatically upload videos and photos to your
own private album on Google+.
1. Sign on to your Google account. For more information,
refer to “Creating a Samsung Account” on page 276.
2. From the Home screen, tap (
Apps
)
(
Google+
).
3. Select the account you want to use to sign in to
Google+.
– or –
Tap
Add account
to create another account.
4. Follow the on-screen instructions to use Google+.
5. Visit
www.google.com/mobile/+/
for more information.
Google+ instant upload may resize your images in order to
reduce size.
Applications and Development 170
Group Play
This application lets you share documents, photos or music
in real-time with other connected friends.
Note:
Group Play is not the same as Screen mirroring which
requires a connection to a Wi-Fi capable Samsung TV or
via the use of the AllShare Cast Hub.
Important!
To share a Group Play, all users must be connected
to the same Wi-Fi access point.
1. From the Home screen, tap (
Apps
)
(
Group Play
).
2. Read the on-screen Disclaimer and tap
Agree
.
3. Follow the on-screen tutorials.
Creating a group
If you have media you want to share, create a group for other
users to join to and then share/collaborate with what you are
sharing.
The creator of the group is the leader and it the source of the
shared file. All other joined members can then interact with
the file being shared.
1. Connect to an active Wireless Access Point and confirm
your other participants are also connected to this same
Wi-Fi.
2. From the Home screen, tap (
Apps
)
(
Group Play
).
3. Tap the
Set group password
field to enable the function
which requires users to enter a password prior to
connecting to your new group.
4. Tap
Create group
. If previously selected, enter your
group password and tap
OK
. Mobile AP is enabled.
5. Tap one of the media items listed under the
Share and
play content
heading.
6. Tap to select the items you want to share (indicated by
a checkmark), then tap
Done
or
OK
.
171
7. Have your friends sign onto Group Play from their
devices (see below) and they can view your media
using you as a Mobile AP.
Joining a group
A joiner is the participant of an already created group. You
can only view and interact with media shared by the leader
of an existing group.
1. Connect to an active Wireless Access Point and confirm
your connection is this same Wi-Fi as the group leader.
2. From the Home screen, tap (
Apps
)
(
Group Play
).
3. Tap
Join group
. Your device then scans for available
groups for you to join.
4. Select a group to join. Once connected, you can then
select the shared content and interact with your
group’s shared media.
5. Press and select
Help
for additional information.
Hangouts
Previously known as Google Talk™, is an updated place to
hangout, share photos, and even video calls. This is a free
web-based application for instant messaging offered by
Google. Conversation logs are automatically saved to a Chats
area in your Gmail account. This allows you to search a chat
log and store them in your Gmail accounts.
Note:
Before using this application, you must first have an
active Gmail account available and be currently
logged in.
1. From the Home screen, tap (
Apps
)
(
Hangouts
).
Note:
Make sure you are logged into your Google account.
2. When prompted, read the on-screen information and
tap
OK
.
3. Confirm your phone number is correct before using the
application. Tap
Confirm
.
Applications and Development 172
Note:
Confirming your phone number does not make it publicly
available.
Help
Provides access to built-in Help information.
1. From the Home screen, tap (
Apps
)
(
Help
).
2. Select an on-screen topic and follow the built-in
navigations.
Internet
Your device is equipped with a Google browser to navigate
the mobile Web. This section explains how to navigate the
browser and use the basic features.
Accessing the Internet
To access the Browser:
From the Home screen, tap (
Apps
)
(
Internet
).
Navigating with the Browser
1. Tap an entry to select an item.
2. Sweep the screen with your finger in an up or down
motion to scroll through a website.
3. To return to a previous page, tap .
4. To move forward to a web page, tap .
Browser Options
1. From the top of the browser screen, select one of the
available options:
• Navigation
: use the forward and back buttons to navigate
through your browsing activity.
•Refresh
: reloads the current page.
•Windows
: displays a list of the windows you have open.
• Bookmarks
: provides access to the Bookmarks screen.
– or –
From the home page, press to access the
following options:
•New window
: launches a new browser window. By default,
this screen shows the web2go home page.
• Add bookmark
: allows you to add a URL to your bookmark list.
173
• Add shortcut
: allows you to add a shortcut to your Home
screen.
•Share via
: allows you to share the page using Add to Dropbox,
Bluetooth, ChatON, Copy to clipboard, Drive, Email, Flipboard,
Gmail, Google+, Hangouts, Messages, S Memo, or Wi-Fi
Direct.
• Find on page
: allows you to search in the current page.
• Desktop view
: allows you to assign the browser to display the
current page in the desktop view (to closely mimic the display
as it would appear on a Desktop computer).
• Save for offline reading
: allows you to store the current page
in memory so that it can be read later even if you loose your
Internet connection.
•Brightness
: allows you to assign a brightness level specifically
for the browser window. This is independent of the brightness
assigned within the device’s Settings menu.
•Downloads
: displays the download history.
•Print
: provides print access on compatible Samsung printers.
• Settings
: allows you to change the way you view your web
pages by changing these options. For more information, refer
to
“Browser Settings”
on page 177.
Entering a URL
You can access a website quickly by entering the URL.
Websites are optimized for viewing on your phone.
To enter a URL and go to a particular website:
From the homepage tap the URL field at the top of the
screen, enter the URL and tap .
Using Reader Mode
When activated, this feature restructures the current Web
page to provide a more reader-friendly experience. The text
size can be adjusted for easier reading.
1. From the Home screen, tap (
Apps
)
(
Internet
).
2. Navigate to a graphic heavy or content rich Web page.
3. If (
Reader Mode
) appears in the Address bar, tap it
to activate the feature.
4. Adjust the Font size or tap (
Share via
).
•Share via
: allows you to share the picture via Add to Dropbox,
Bluetooth, ChatON, Copy to clipboard, Drive, Email, Flipboard,
Gmail, Google+, Hangouts, Messages, S Memo, or Wi-Fi
Direct.
Applications and Development 174
Search the Internet
To perform an Internet search using keywords:
1. From within the Google search application, tap the
Google
search field, enter the keyword(s) to search
using the on-screen keypad.
2. Tap the entry from the list of search results that are
displayed.
3. Tap a link to view the website.
Adding and Deleting Windows
You can have several Internet windows open at one time.
To add a new window:
1. From your browser window, tap (
Window
)
(
New window
).
2. A new browser window displays.
Note:
The number of currently open windows is displayed at
the bottom of the WIndows screen.
3. Scroll across the screen to view the currently active
windows and tap an entry to launch the selected
Internet window.
To delete an existing window:
1. From your browser window, tap (
Windows
).
2. Scroll across the available windows and locate your
target window.
3. Tap next to the listing to delete the window.
Going Incognito
The incognito feature allows you to view Internet sites
outside of the normal browsing. Pages viewed in this
incognito window won’t appear within your browser history
or search history, and no traces (such as cookies) are left on
your device.
Note:
Any downloaded files will be preserved and will stay on
your device after you exit the incognito mode.
To add a new incognito window:
1. From your browser window, tap (
Windows
)
(
Incognito
).
2. A new browser window displays.
Note:
The new browser window appears grey while you are in
this mode.
175
To exit from the incognito window:
1. From your browser window, tap (
Windows
).
2. Scroll across the available windows and locate the
incognito window.
3. Tap next to the incognito listing to delete this
window.
Using Bookmarks
While navigating a website, you can bookmark a site to
quickly and easily access it at a future time. The URLs
(website addresses) of the bookmarked sites display in the
Bookmarks page. From the Bookmarks page you can also
view your Most visited websites and view your History.
1. From the webpage, tap (
Bookmarks
).
The
Bookmarks
page displays. Additional pages
include
History
and
Saved pages
.
2. Press to display the following options:
• List/Thumbnail view
: select
Thumbnail view
(default) to view
a thumbnail of the webpage with the name listed, or select
List view
to view a list of the bookmarks with Name and URL
listed.
• Create folder
: creates a new folder in which to store new
bookmarks.
• Change order
: rearranges the current bookmarks.
• Move to folder
: selected bookmarks are moved to a selected
folder.
•Delete
: erases selected bookmarks.
3. Tap a bookmark to view the webpage, or touch and
hold a bookmark for the following options:
•Open
: opens the webpage of the selected bookmark.
• Open in new window
: opens the webpage in a new window.
•Edit bookmark
: Allows you to edit the name or URL of the
bookmark. For more information, refer to
“Editing
Bookmarks”
on page 176.
•Add shortcut
: adds a shortcut to the bookmarked webpage to
your phone’s Home screen.
• Share link
: allows you to share a URL address via Add to
Dropbox, Bluetooth, ChatON, Copy to clipboard, Drive, Email,
Flipboard, Gmail, Google+, Hangouts, Messages, S Memo, or
Wi-Fi Direct.
• Copy link Web address
: allows you to copy the URL address to
use in a message.
Applications and Development 176
• Delete bookmark
: allows you to delete a bookmark. For more
information, refer to
“Deleting Bookmarks”
on page 176.
• Set as homepage
: sets the bookmark to your new homepage.
Adding Bookmarks
1. From the webpage, tap
Add bookmark
.
2. Use the on-screen keypad to enter the name of the
bookmark and the URL.
3. Select a storage location for your new bookmark.
4. Update the title of the Bookmark and confirm the URL.
5. Tap
Save
. The new save page now appears on the
Bookmarks page.
Editing Bookmarks
1. From the Bookmarks page, touch and hold the
bookmark you want to edit.
2. Tap
Edit bookmark
.
3. Use the on-screen keypad to edit the name of the
bookmark or the URL.
4. Tap the
Location
field to assign a new folder location.
5. Tap
Save
or
Cancel
to exit the operation.
Deleting Bookmarks
1. From the Bookmarks page, touch and hold the
bookmark you want to delete.
2. Tap
Delete bookmark
.
3. At the confirmation window, tap
OK
.
Emptying the Cookies
A cookie is a small file placed on your phone by a website
during navigation. In addition to containing some site-
specific information, a cookie can also contain some
personal information (such as a username and password)
which might pose a security risk if not properly managed.
You can clear these cookies from your device at any time.
1. From an active Web page, press and then tap
Settings
Privacy and security
Clear all cookie data
.
2. Tap
OK
to delete the cookies or tap
Cancel
to exit.
177
Using Web History
The History list displays a list of the most recently viewed
websites. These entries can be used to return to previously
unmarked web pages.
1. From the webpage, tap
History
tab.
2. Select a visited range category. Choose from: Today,
Yesterday, or Most visited.
3. Tap an entry to display the webpage.
– or –
Press and then tap
Clear history
to delete the
current History list.
Saved Pages
The Saved pages list provides you with a list of the websites
that you have saved.
1. From the webpage, tap
Saved pages
tab.
A list of your saved webpages is displayed with their
Name. The webpages that have been visited the most
will appear at the top.
2. Tap any entry to display the webpage.
Browser Settings
To configure browser settings:
1. From the Home screen, tap (
Apps
)
(
Internet
).
2. Press and then tap
Settings
.
3. Choose an option from the following categories:
General:
• Set home page
: sets the current home page for the Web
browser.
• Form auto fill
: allows you to fill in Web forms with a single tap.
• Auto fill text
: allows you to set the text used for the Web form
auto-fill feature.
Privacy and security:
• Clear cache
: deletes all currently cached data. Tap
OK
to
complete the process.
•Clear history
: clears the browser navigation history. Tap
OK
to
complete the process.
• Show security warnings
: notifies you if there is a security
issue with the current website. Remove the check mark to
disable this function.
Applications and Development 178
• Accept cookies
: allows sites, that require cookies, to save and
read cookies from your device.
• Clear all cookie data
: deletes all current browser cookie files.
• Remember form data
: allows the device to store data from
any previously filled out forms. Remove the check mark to
disable this function.
• Clear form data
: deletes any stored data from previously filled
out forms. Tap
OK
to complete the process.
• Turn on location
: allows websites to request access to your
location.
• Clear location access
: clears location access for all websites.
Tap
OK
to complete the process.
• Remember passwords
: stores usernames and passwords for
visited sites. Remove the check mark to disable this function.
• Clear passwords
: deletes any previously stored usernames or
passwords. Tap
OK
to complete the process.
• Turn on notifications
: enables notifications for all websites.
Select either: Always on, On demand (user driven), or Off.
• Clear notifications
: clears Web notification access for all
websites. Tap
OK
to complete the process.
Accessibility:
• Force zoom
: allows you to override a website’s zoom setting
and forces a zoom view.
• Text size
: allows you to manually adjust the size of the
on-screen text size (Scale text up and down), Zoom amount on
double tap, and minimum font size via the use of an on-screen
slider.
• Inverted rendering
: allows you to adjust the way a Web page
is displayed to make it easier to view or read. Enabling this
feature causes a page to rendered in reverse - Black becomes
white and vice versa. On-screen white text is displayed as
white text on a black background.
•Contrast
: allows you to adjust the on-screen contrast.
Note:
The Contrast feature is disabled until the Inverted
rendering function is active.
179
Advanced:
• Select search engine
: allows you to choose a default search
engine for your phone. Choose from:
Google
,
Yahoo!
, or
Bing
.
• Open in background
: new pages are launched in a separate
page and displayed behind the current one. Remove the check
mark to disable this function.
• Turn on JavaScript
: enables javascript for the current Web
page. Without this feature, some pages may not display
properly. Remove the check mark to disable this function.
• Allow multiple tabs per app
: provides the ability for different
applications to launch separate tabs.
• Turn on plug-ins
: allows the download of plug-ins such as
Adobe Flash.
•Default storage
: sets the default storage to Device or Memory
card.
• Website settings
: view advanced settings for individual
websites.
• Default zoom
: adjusts the zoom feature. Set to Far, Medium, or
Close.
• Open pages in overview
: displays an overview of recently
viewed web pages.
• Auto fit pages
: allows web pages to be resized to fit as much
of the screen as possible.
• Block pop-ups
: prevents popup advertisement or windows
from appearing on-screen. Remove the check mark to disable
this function.
• Text encoding
: adjusts the current text encoding.
• Reset to default
: clears all browser data and resets all settings
to default.
Bandwidth Management:
• Preload search results
: allows the browser to preload high
confidence search results in the background. If the device can
accurately guess your in progress search, it will preempt you by
beginning to load the matching Web page before you complete
the search request.
• Page preloading
: allows the browser to preload pages in the
background.
•Load images
: allows web page images to load along with the
other text components of a loaded website.
Applications and Development 180
Labs:
• Quick controls
: allows you to enable on-screen quick controls
via the use of Swype thumb actions.
• Full screen
: allows Web pages to be resized to fit as much of
the screen as possible.
KNOX
Samsung KNOX is a comprehensive enterprise mobile
solution for use with both work and play. With the increasing
use of smartphones in businesses, Samsung KNOX
addresses the mobile security needs of enterprise IT without
invading the privacy of its employees. This application must
be downloaded to the device before use.
For more information, go to:
www.samsung.com/knox
.
1. From the Home screen, tap (
Apps
)
(
KNOX
).
2. Tap
Install
and read the on-screen Terms and
Conditions, agree to the terms and tap
Confirm
.
3. Follow the on-screen instructions.
Maps
Google Maps allow you to track your current location, view
real-time traffic issues, and view detailed destination
directions. There is also a search tool included to help you
locate places of interest or a specific address. You can view
locations on a vector or aerial map, or you can view locations
at the street level.
Important!
Before using Google Maps you must have an active
data (3G/4G) or Wi-Fi connection. The Maps
application does not cover every country or city.
From the Home screen, tap (
Apps
)
(
Maps
).
Important!
For best results, it is recommended that you enable
all of your location services. For more information,
refer to “Location Services” on page 279.
181
Enabling a Location source
Before you use Google Maps and find your location or search
for places of interest, you must enable a location source. To
enable the location source you must enable the wireless
network, or enable the GPS satellites.
Important!
The more location determining functions are
enabled, the more accurate the determination will
be of your position.
1. From the main
Settings
page, tap
More
tab
Location
services
.
2. Tap
Access to my location
to enable sharing your
location with requesting applications.
3. Tap
Use GPS satellites
to enable the GPS satellite.
4. Tap
Use wireless networks
to allow apps to use data
from sources such as Wi-Fi and mobile networks to
provide a better approximation of your current location.
To receive better GPS signals, avoid using your device in the
following conditions:
•
inside a building or between buildings
•
in a tunnel or underground passage
•
in poor weather
•
around high-voltage or electromagnetic fields
•
in a vehicle with tinted windows
Opening Maps
1. From the Home screen, tap (
Apps
)
(
Maps
).
2. Tap
Accept & continue
from within the Welcome page.
3. Tap the bottom-right My location button to find your
location on the map with a blinking blue dot.
4. Locate the top row of the buttons to access additional
options.
Applications and Development 182
Messages
This application allows you to use the Short Message Service
(SMS) to send and receive short text messages to and from
other mobile phones.
You can also use the Multi Media Service (MMS) to create
multimedia messages to send and receive from other mobile
phones.
From the Home screen, tap (
Apps
)
(
Messages
).
For more information, refer to “Messages” on page 101.
Mobile HotSpot
Provides access to the Tethering and Mobile HotSpot menu
where you can use either the USB tethering or portable
HotSpot functionality.
1. From the Home screen, tap (
Apps
)
(
Mobile HotSpot
).
2. Activate the desired connection method.
For more information see either "USB Tethering"on page 234
or "Mobile HotSpot"on page 235.
Music
The Music player is an application that can play music files.
The music player supports files with extensions AAC, AAC+,
eAAC+, MP3, WMA, 3GP, MP4, and M4A. Launching the
Music Player allows you to navigate through your music
library, play songs, and create playlists (music files bigger
than 300 KB are displayed).
Playing Music
1. From the Home screen, tap (
Apps
)
(
Music
).
2. Tap a library category tab to select the music category:
Songs
,
Playlists
,
Albums
,
Artists
, or
Folders
.
3. Scroll through the list and tap an entry to begin
playback.
183
4. Use any of the following Music player controls:
Making a Song a Phone Ringtone
1. From within the
Music
application, tap the
Songs
tab.
2. Touch and hold a song from the list to reveal the
on-screen context menu.
3. Tap
Set as
Phone ringtone.
4. Select
Done
.
5. Additional Set as options include
Caller ringtone
and
Alarm tone
.
Music Options
The Music Settings menu allows you to set preferences for
the music player such as whether you want the music to play
in the background, sound effects, and how the music menu
displays.
With the Music player application displayed and
playing a song, press and select one of the
following options:
• Via Bluetooth
: scans for devices and pairs with a Bluetooth
headset.
• Play via Group Play
: allows you to share music with others via
the Group Play application. All users must be connected to the
same Wi-Fi.
Pause the song.
Start the song after pausing.
Press and hold to rewind the song. Tap to go to
previous song.
Press and hold to fast-forward the song. Tap to
go to next song.
Volume control and SoundAlive.
Plays the entire song list once.
Replays the current list when the list ends.
Repeats the currently playing song.
shuffles the current list of songs randomly.
songs play in order and are not shuffled.
lists the current playlist songs
Returns the user to the music category screen.
Assign the current song as a Favorite.
Streams the current music file to another device
via Samsung Link.
Applications and Development 184
•Add to playlist:
allows you to add the current music file to a
selected playlist.
•Set as
: allows you to set the current song as a Phone ringtone,
Caller ringtone, or Alarm tone.
•Settings
: allows you to change your music player settings.
•Details
: allows you to view media info such as Artist, Title,
Album, Track length, Genre, Track number, Format, Bit depth,
Sampling rate, Size, and Location.
•End
: closes the application.
Music Settings
The settings menu allows you to set preferences for the
music player such as whether you want the music to play in
the background, sound effects, and how the music menu
displays.
1. From within the
Music
application, press
Settings
.
2. Select one of the following settings:
• Music menu
: this menu allows you to select which categories
you want to display. Choices are: Albums, Artists, Genres,
Music square, Folders, Composers, Years, Most played,
Recently played, or Recently added. Tap each item that you
want to display in the Music menu.
•SoundAlive
: set a type of equalization such as Normal, Pop,
Rock, Dance, Jazz, Classic, etc.
• Play speed
: set the play speed anywhere between 0.5X and
2.0X using the slider.
• Music auto off
: when enabled, sets a timer for the Music
application to automatically turn off after a pre-selected amount
of time.
•Lyrics
: when activated, the lyrics of the song are displayed if
available.
• Smart volume
: when activated, automatically adjusts each
track’s volume to an equal level.
• Voice control
: when activated, allows you to use voice control
commands to control the music player.
185
Using Playlists
Playlists are used to assign music files into groups for
playback. These Playlists can be created using the Music
player on this device, or using a third-party application (such
as Windows Media Player) and downloading those files to an
SD card inserted into the device.
Creating a Playlist
1. From within the
Music
application, tap the
Playlists
tab.
2. Press and then tap
Create playlist
.
3. Delete the default playlist title and type a new name for
this playlist, then tap
OK
.
Adding Music to a Playlist
1. From within the
Music
application, tap the
Playlists
tab.
2. Tap the playlist name in which to add music.
3. Tap (
Add music
). This option is available within
user-created playlists.
Note:
If a playlist is empty, add a song by touching a holding a
song name from the main screen to open the context
menu. Select
Add to playlist
and choose the playlist.
4. Tap a music file, or tap
Select all
to add all the music
tracks to this playlist then tap
Done
.
Removing Music from a Playlist
1. From within the
Music
application, tap the
Playlists
tab.
2. Tap the playlist name in which to delete music.
3. Touch and hold a song to reveal the on-screen context
menu.
4. Tap
Remove
.
Editing a Playlist
Besides adding and removing music files in a playlist, you
can also share, delete, or rename the playlist.
Note:
Only those playlist you have created can be edited.
Default playlists can not be renamed.
1. From within the
Music
application, tap the
Playlists
tab.
2. Touch and hold a playlist entry to reveal the on-screen
context menu.
3. Tap
Edit title
.
4. Enter a new name for this playlist and tap
OK
.
Applications and Development 186
Transferring Music Files
Music files can be downloaded to the phone using one of two
methods:
1. Downloaded to the device from the Play Store.
Music files are directly stored on your phone.
2. Downloaded to the phone via a direct USB connection.
Music files are stored into a Music folder on the SD
card.
Removing Music Files
1. From within the
Music
application, tap the
Songs
tab.
2. Touch and hold a song entry to reveal the on-screen
context menu.
3. Tap
Delete
OK.
The music file(s) is deleted.
My Files
This application allows you to manage your sounds, images,
videos, Bluetooth files, Android files, and other memory card
data in one convenient location. This application allows you
to launch a file if the associated application is already on
your phone (ex: MP4).
From the Home screen, tap (
Applications
)
(
My Files
).
Note:
Navigation in this viewer works on a hierarchy structure
with folders, subfolders, etc.
Note:
The application lets you view supported image files and
text files on both your internal storage and microSD
card.
187
Opening and Navigating within Files
DCIM is the default location for pictures or video taken by the
device. These files are actually stored in the DCIM folder
location.
1. From the Home screen, tap (
Applications
)
(
My Files
).
2. Tap a folder and scroll down or up until you locate your
selected file.
•Home tab
allows you to back up to the root directory.
•Up tab
allows you to back up into a higher directory.
•
Press and then tap
View by
to change the way the files
are displayed on-screen. Choose from:
List
,
List and details
,
or
Thumbnail
.
3.
Press
for these additional options:
Select all
,
Create folder
,
Search
,
View by
,
Sort by
, and
Settings
.
To navigate:
1. Tap
All files
Device storage/SD memory card
to see
the contents of either device or your internal SD card.
2. The following folders may display:
•ShareShot
: displays the files shared via a group share shot
session.
•Alarms
: this folder contains any alarm files you may have.
•Android
: the Android folder stores files that are used in Android
applications.
• Bluetooth
: this folder stores files sent via a Bluetooth device.
•DCIM
: this is the default location for pictures and videos taken
by the device. Tap
DCIM
Camera
to view the picture or
video files.
•Download
: this folder contains downloads you have made.
•Movies
: this folder contains your Video and Movie files.
•Music
: this folder contains your Music files.
• Notifications
: this folder contains all of the notifications you
have received.
•Pictures
: this folder contains your photos.
•Podcasts
: this folder contains all of your podcasts.
Applications and Development 188
•Ringtones
: this folder contains any ringtones you have
purchased.
Note:
Different folders may appear depending on how your
phone is configured.
3. Once you have located your file, tap the file name to
launch the associated application.
Paper Artist
This graphic application provides a user with the ability to
start from either an empty canvas or by importing a picture
from your Gallery or as a new image.
1. From the Home screen, tap (
Apps
)
(
Paper Artist
).
2. Follow the on-screen instructions.
Phone
This application provides the ability to make or answering
calls, access the Contacts list, which is used to store contact
information.
From the Home screen, tap (
Phone
).
For more information, refer to “Call Functions and Contacts
List” on page 49.
Play Books
Formerly known as Google Books, this application allows you
to read over 3 million ebooks on the go.
Build your ebooks library in the cloud with Play Books: jump
right into a bestseller or select from nearly 3 million free
ebooks. Personalize the reader to your liking, pick up reading
where you left off on your phone or computer, and settle
down with a great book on your Android phone!
1. From the Home screen, tap (
Apps
)
(
Play Books
).
2. If prompted, tap
Turn sync on
. This synchronizes your
books you have previously selected between your
Books account and your device.
3. Tap to begin searching for both free and paid
ebooks.
4. Follow the on-screen prompts to download the ebook
to your device.
189
Play Games
This application takes you directly to the Play Store Games
area from where you can make purchases.
1. From the Home screen, tap (
Apps
)
(
Play Games
).
2. Accept the Mobile terms of service for Google+ by
tapping
Accept
.
3. Select from an available on-screen option.
Play Magazines
With Google Play Magazines, you can subscribe to your
favorite magazines and have them available to read on your
device at any time or any place.
1. From the Home screen, tap (
Apps
)
(
Play Magazines
).
2. Log on to your Google account if you have not already
done so. For more information, refer to “Creating a
Samsung Account” on page 276.
3. Tap
Read Now
to review available material.
4. Tap
My Library
to view material you have purchased.
5. Tap
Shop
to purchase new material.
6. Tap a magazine to see more information and
subscribe.
7. Follow the on-screen instructions to subscribe to a
magazine.
Applications and Development 190
Play Movies & TV
This application allows you to connect to the Play Store,
download a movie and then watch it instantly.
Choose from thousands of movies, including new releases and
HD titles in the Play Store and stream them instantly on your
Android device.
Movies, previously rented via the Play Store are automatically
added to your My Movies library across your devices.
Learn more about Google Play Movies at:
http://play.google.com/about/movies
.
1. From the Home screen, tap (
Apps
)
(
Play Movies & TV
).
2. Log on to your Google account if you have not already
done so. A list of videos sorted on the SD card displays
in the Video list.
3. Following the on-screen instructions for renting and
viewing movies.
4. Tap
Watch Now
to search through available categories
from this screen.
5. Tap
My Movies
to view movies you have rented.
6. Tap
My TV Shows
to view shows you have rented.
7. Tap
Shop
to purchase or rent material.
Play Music
Also known as Google Music, allows you to browse, shop,
and playback songs purchased from the Play Store. The
music you choose is automatically stored in your Google
Music library and instantly ready to play or download.
Access the new music tab from within your Play Store
application.
The Music application contains a music player that plays
music and other audio files that you copy from your computer.
1. From the Home screen, tap (
Apps
)
(
Play Music
).
The Music app searches both your online library and
your device’s internal storage for music and playlists;
this can take from a few seconds to several minutes,
depending on the amount of new music added since
you last opened the application. It then displays a
carousel view of your new and recent music, organized
by album.
2. If prompted to join the service, select either
Add
account
or
Not now
.
191
3. Follow the on-screen log in screens.
4. Return to the Library screen from most other screens
in the Music application by tapping the Music
application icon (
Music notification icon
) at the
top-left of the Application bar.
Searching for Music in Your Library
1. From within the
Play Music
application, tap
(
Search
) to search through your available songs.
2. Type the name of an artist, album, song, or playlist.
Matching songs are displayed in a list below the search
box.
3. Tap a matching song to play it, tap a matching album,
artist or playlist to view a list of its’ songs.
Tab Options
There are various options available from the various tabs:
From within the
Play Music
application, select one of
the following tabs and tap to access an available
option.
•GENRES:
Add to queue.
•ARTISTS:
Add to queue, Keep on device, Add to playlist.
•ALBUMS:
Add to queue, Keep on device, Add to playlist, or
Go to artist.
• SONGS:
Add to queue, Add to playlist, Go to artist, Go to album,
or Delete.
Playing Music
From within the
Play Music
application, tap a song in
your library to listen to it.
The
Now playing
screen opens and the song you
touched or the first song in the album or playlist starts
to play. The tracks in the current list play in order until
you reach the end of the list (unless you choose a
repeat option). Otherwise, playback stops only if you
stop it, even when you switch applications.
Note:
If you navigate away from the
Now playing
screen in the
Music application, the Now Playing bar appears at the
bottom of the screen.
Applications and Development 192
Displaying the Now Playing Screen
If you navigate away from the
Now playing
screen, to return
to the
Now playing
screen from other Music screens:
Tap the name of the current song in the Now Playing
bar.
– or –
In a single motion, touch and drag (
Music
notification icon
) down from the Status bar and tap the
song title from the Notifications area. You can also
pause and resume playback and skip to the next song
in the panel. For more information, refer to
“Notification Bar” on page 32.
Making Online Music Available Offline
In addition to playing the music that you add to your online
library, you can play music stored on your device’s internal
storage. Then you can listen to music when you have no
Internet connection. To do this, make some of your online
music available offline.
Tip:
You can also copy music directly from your computer to
your device.
To make your online music available offline on your device:
1. From within the
Play Music
application, change your
library view to Albums, Artists, or playlists.
2. Tap and then select
Keep on device
to make
available offline.
A blue pin indicates that the item is already
available offline.
Darker pins appear next to the items you can make
available offline. A bar at the bottom of the screen
shows how much space is available on your device for
music and other files.
Dim blue pins indicate songs or albums that you copied
directly from a computer to your device.
3. Tap the dark pin next to each item you want to make
available offline or tap a blue pin to stop making it
available offline. You can switch to other views of your
library to make other kinds of items available offline as
well.
4. Tap
Done
in the bar at the bottom of the screen. The
Music application starts downloading the items to your
device.
193
Play Store
Formerly known as the “Android Market”, this application
provides access to downloadable applications and games to
install on your phone. The Play Store also allows you to
provide feedback and comments about an application, or flag
an application that might be incompatible with your phone.
Before using the Play Store, you must have a Google
Account.
Accessing the Play Store
1. From the Home screen, tap (
Apps
)
(
Play Store
).
2. If not already logged in with your Google account, tap
Next
.
3. Tap
Existing
and enter your Google account
information.
4. Tap
Accept
to agree to the Play Store terms of service.
Downloading a New Google
Application
To download a new application, you will need to use your
Google account to sign in to the Play Store. The home page
provides several ways to find applications. The home page
features applications and includes a list of item applications
by category, a list of games, a link to search, and a link to My
apps.
1. From the Home screen, tap (
Apps
)
(
Play Store
).
2. Browse through the categories, find an application
you're interested in, and tap the name.
3. Read the application descriptions.
Applications and Development 194
Important!
If the selected application requires access to data
or control of a function on your device, the Play
Store displays the information the application will
access.
Tap
OK
if you agree to the conditions of the
application. Once you tap
OK
on this screen you are
responsible for using this application on the device
and the amount of data it uses. Use this feature
with caution.
4. Tap
INSTALL
ACCEPT
.
Note:
Use caution with applications which request access to
any personal data, functions, or significant amounts of
data usage times.
5. If prompted, follow the on-screen instructions to pay
for the application.
6. Check the progress of the current download by
opening the Notifications panel. The content download
icon appears in the notification area of the status
bar.
7. On the main Play Store screen, press and then
tap
My apps
, tap an installed application in the list, and
then tap
OPEN
.
Tip:
The newly downloaded applications display in the
applications list and are shown in alphabetical order if the
View Type is set to Alphabetical grid or Alphabetical list, or
at the end of the list if View type is set to Customizable
grid.
Note:
A data plan is required to use this feature. Charges may
apply. Please contact your service provider for further
details.
195
Launching an Installed Google
Application
1. From the Home screen, tap (
Apps
).
2. Tap the newly installed application. This application is
typically located on the last Applications page.
Unknown sources
This feature can be used for Android application
development. The feature allows developers to install
non-Play Store applications.
From the main
Settings
page, tap
More
tab
Security
Unknown sources
.
Unknown sources displays a check mark to indicate it
is active.
Note:
If Unknown sources is disabled, those applications
without a certificate will not be allowed to download to
your device.
Manage applications
This feature allows you to manage and remove installed
applications. You can also view the amount of memory or
resources used as well as the remaining memory and
resources for each of the applications on your device and
clear the data, cache, or defaults.
From the main
Settings
page, tap
More
tab
Application manager
.
Clearing application cache and data
1. From the main
Settings
page, tap
More
tab
Application manager
.
2. Tap an application in which to clear the cache or data.
3. Tap
Force stop
,
Turn off, Uninstall, Clear data
,
Clear
cache
, or
Clear defaults
.
Uninstalling third-party applications
You can uninstall any application you downloaded and
installed from the Play Store.
1. From the main
Settings
page, tap
More
tab
Application manager
DOWNLOADED
.
2. Tap the third-party application, and from the
App info
screen, tap
Uninstall
.
Applications and Development 196
S Memo
The S Memo application allows you to create memos using
the keypad, your finger, or both. You can add images, voice
recordings, and text all in one place.
Creating a New Memo
1. From the Home screen, tap (
Apps
)
(
S Memo
). The S Memo screen is displayed.
2. Tap an existing Memo to open it then tap the screen to
enter edit mode.
– or –
Tap to start a new memo in text mode with the
keypad displayed or tap to start a new memo in
drawing mode using your finger or a compatible
on-screen writing tool. You can change back and forth
in a memo to add text with the keypad and the pen. The icons that you see displayed on the screen are described
in the following table:
Saves the current memo and creates a new one.
Changes the view mode.
Allows you to add free-format drawing.
Toolbar
Secondary
Show/Hide
Add Page
Writing area
Secondary
Add Title
Writing
Modes
Keyboard
Toolbar
Toolbar
197
3. From within an active memo, press to access the
following options:
Note:
Depending on whether you have saved the memo, are in
keypad mode, or in handwriting mode, the options will
appear differently. The following is a list of the options
you may see.
•Rename
: allows you to change the current memo title.
•Share via
: allows you to share your memo (Image file (.jpg),
PDF file (.pdf) or Text), via Group Play, Wi-Fi Direct, Bluetooth,
ChatON, Add to Dropbox, Flipboard, Hangouts, Picasa, Paper
Artist, Google+, Messages, Gmail, Drive, or Email.
• Handwriting-to-text
: allows you to transcribe handwriting into
text.
•Export
: allows you to save the memo to your Gallery as either a
JPG or as a PDF.
• Save as
: allows you to save the memo with a different name.
• Add picture
: allows you to add an image to the current memo.
Choose from: Picture, Take picture, Clip Art, Clipboard, or Map.
•Add tag
: allows you to set tags to add in searches.
•Add as favorite
: allows you to tag the current memo as a
favorite.
• Change background
: allows you to set the background for
your memo. Swipe the screen to the left or right to select a
background and then tap
Done
.
• Link to Calendar
: allows you to link the memo to your
Calendar.
•Lock
: allows you to lock an email by using a PIN number.
Displays the keypad to you can add text.
Eraser tool allows you to erase marks and drawings.
Undo the last action.
Redo the last action that was undone.
Make a voice recording to add to the memo.
Hide the secondary toolbar.
Show the secondary toolbar.
Add an additional page to the memo.
Applications and Development 198
•Set as
: allows you to set a memo as a Contact icon, Home
screen wallpaper, Lock screen wallpaper, Home and lock
screens.
•Print
: allows you to print the screen or web page on a
Samsung printer using Wi-Fi.
When you are finished creating your memo, tap
Save
on the
top menu bar.
S Suggest
Provides on-screen recommendations for applications that
are specifically supported and made for use on your device.
Note:
Access to this feature requires that you already be
logged in to your Samsung account application. For
more information, refer to “Creating a Samsung
Account” on page 276.
1. From the Home screen, tap (
Apps
)
(
S Suggest
).
2. Read the terms and conditions.
3. Place a check mark in the
Agree
field then tap
Agree
.
4. Select an application from one of the available
categories (Picks, Categories, Games, Friends, and
Info).
5. Follow the on-screen download and installation
instructions.
S Voice
Launches your phone’s built-in voice recognition system that
allows you to initiate several common tasks without having
to touch the phone. Features include: Call, Text, Navigate,
Play music, Memo, and Driving mode.
Using S Voice
This is a voice recognition application used to activate a wide
variety of functions on your device. This is a natural language
recognition application.
This goes beyond the Google Search Voice Actions feature
that simply recognizes Google commands and search terms.
You can ask it questions (Is it raining in Dallas?) or give it
commands (Show my where to find cheap gas).
1. From the Home screen, tap (
Apps
)
(
S Voice
).
2. Read the on-screen disclaimer information and tap
Confirm
to continue.
199
3. Review the Terms of Service and tap
Agree
to continue.
4. Navigate through the following on-screen tutorial
screens by reading the information and tapping
Next
,
or tap
Skip
to continue without reading the information.
5. Wake up the application by repeating the phrase
Hi Galaxy
.
Note:
The wake-up command/phrase can be changed from
“Hi Galaxy” to anything else.
6. Tap (
Speak
) if the device does not hear you or
to give it a command.
Example 1:
•
I want to find the best pizza online.
•
Tap and say “Find me the best Pizza”. This launches
an Internet search.
Example 2:
•
I want to find the nearest gas station.
•
Tap and say “Navigate to Cambridge”. This launches
the Map application and indicates where this is in relation to
your current position.
Samsung Apps
Allows you to easily download an abundance of applications
that are directly compatible with your device. This includes
games, news, reference, social networking, navigation, and
more. Samsung Apps makes your Smartphone smarter.
Note:
Access to this feature requires that you already be
logged in to your Samsung account application. For
more information, refer to “Creating a Samsung
Account” on page 276.
1. From the Home screen, tap (
Apps
)
(
Samsung Apps
).
2. If prompted, read the Disclaimer, Terms and conditions,
and Privacy policy and tap
Accept
.
3. Tap
Accept
if prompted to allow Google to check your
currently installed application for unsafe behavior.
4. Follow the on-screen instructions.
Applications and Development 200
Samsung Hub
Samsung Hub makes it easy to find, sample, and purchase
movies, TV shows, books, games, and music, in one user-
friendly location. With hundreds of titles available,
entertaining your family on-the-go has never been easier.
You can rent or purchase your favorite content and watch
from any location. Samsung Hub is your gateway to mobile
entertainment.
You must have an active Samsung Account to purchase and
rent content via Samsung Hub.
Note:
Samsung Hub usage is based on service availability.
Important!
You must be using an active Wi-Fi/4G/LTE
connection to preview and download a media file.
The internal memory acts as a storage location for
your downloaded rental or purchase.
Important!
The Samsung account manages the access
information (username/password) to several
applications, such as Samsung Link, Chat On, and
Samsung Hub.
Creating a New Samsung Hub Account
Before you can rent or buy media, you must first log in using
your Samsung account. Enter the required information.
1. Confirm you have already logged in to your Samsung
account. There should be no icon in the
Notifications area of the screen.
2. From the Home screen, tap (
Apps
)
(
Samsung Hub
).
3. When prompted to connect via mobile networks, select
either
Cancel
or
Connect
.
4. If notified your Samsung account is not yet active or
verified, tap
OK
. You must be signed in to your
Samsung account to use the application’s various
features.
Tip:
In some cases it might be necessary to sign in to your
Samsung account via the application.
Press and then select
Sign in
.
5. Your Samsung Hub account is managed by the
Samsung account application. This application
manages your user profile information.
201
Using Samsung Hub
1. From the Home screen, tap (
Apps
)
(
Samsung Hub
).
•
The
OVERVIEW
screen (landing page) displays an main access
for all available categories and recently available content for
purchase or rental.
2. Scroll across the screen to select from the following
available pages:
•MUSIC
: displays featured Music content available for purchase/
stream from the Music store & Radio. This page also allows you
to search for new content, or navigate directly to the Music
store page by clicking on the "Music” link at the top of the
page.
•VIDEO
: displays featured film and TV content available for
purchase/rent from the video store. This page also allows you
to search for new content, or navigate directly to the Movie &
TV store page by clicking the "Video" link a the top of the page.
•BOOKS
: displays featured Book content available for purchase
from the Book store. This page also allows you to search for
new content, or navigate directly to the Book store page by
clicking the "Books" link a the top of the page.
•GAMES
: displays featured Game content available from the
Game store. This page also allows you to search for new
content, or navigate directly to the Game store page by clicking
the "Games" link a the top of the page.
3. To purchase or view featured content in more detail,
tap on any content (Thumbnail or text) to navigate to
the product detail page.
4. Depending on the content, you can either purchase,
rent, or stream the content directly from the product
detail page.
5. Choose a payment method, then follow the on-screen
instructions.
Applications and Development 202
Samsung Hub Notices
•
Any media item (Media Content) may be rented or purchased after
you create an account in Samsung Hub.
•
Media Content that is purchased and downloaded may be viewed
concurrently on up to five (5) devices with Samsung Hub (or “the
service”) that are also registered to the same account.
•
You may remove a device from your account no more than once
every 90 days.
•
You may remove Media Content from a device as many times as
you’d like. You will have the ability to re-download the Media
Content later subject to content re-download availability and
content provider permissions.
•
You may need network coverage to access Media Content you
have acquired through the Service.
•
You can use 3G, 4G, or Wi-Fi connectivity to download Media
Content.
•
Unlike purchased Media Content, rented Media Content will be
viewable on only 1 device in your account at a time.
•
Media Content is downloaded and saved to your authorized
device's SD card. No SD Card included out of box.
•
Your Media Content may pause/stop or not download in networks
where there is a weak signal.
•
You may begin watching downloaded Media Content as soon as a)
license acquisition has occurred and b) sufficient amount of the
Media Content has been buffered.
•
You must finish watching Media Content within the time limit set
out for each piece of content (which may be as short as 24
consecutive hours).
•
Stopping, pausing or restarting rented Media Content does not
extend the available viewing time.
•
In no event will rented Media Content be available for a period
of more than thirty (30) days (or shorter on a title-by-title basis)
after the Media Content has been rented (e.g., if you begin
viewing rented Media Content on the 29th day after the rental
transaction, but do not finish viewing the entire title, that rented
Media Content may not be available for the entire twenty-four
(24) consecutive hour period if such period would extend the
viewable time beyond the thirty (30) day rental window).
Unless otherwise restricted by the Content Providers, you can
download Media Content to your TV using HDMI connections;
otherwise, you cannot play Media Content downloaded from
your mobile device output. (4/1/2013)
203
Samsung Link
This application wirelessly synchronizes your Samsung
mobile phone with your TV, streams content and even keeps
tabs on who calls or sends text messages with real-time,
on-screen monitoring. Samsung’s Samsung Link makes
staying connected easy.
Allows users to share their in-device media content with
other external devices using DLNA certified™ (Digital Living
Network Alliance) Devices. These external devices must also
be DLNA-compliant. Wi-Fi capability can be provided to TVs
via a digital multimedia streamer.
Important!
You must first connect both of your communicating
devices to the same Wi-Fi and be using an
active/registered Samsung account prior to using
this application.
For more information, refer to “Wi-Fi Advanced
Settings” on page 220.
For more information, refer to “Creating a
Samsung Account” on page 276.
Samsung Link/
AllShare Play
This new feature builds on the
previous AllShare Play functionality. It
includes features such as Web storage
integration and social networking
integration. This is a Web service
that requires using a Samsung account.
Group Play
A subset feature of Samsung Link, this
allows you to mirror photos and
multimedia presentations with other
members of your current Wi-Fi
group. Users must be on the same
Wi-Fi and provide an access code to
join the group.
AllShare Cast
(with Hub
accessory)
This feature functions with an
external AllShareCast Hub to fully
mirror what is currently displayed on
your device to the external TV.
Applications and Development 204
Important!
The Samsung account manages the access
information (username/password) to several
applications, such as Samsung Link, Chat On, and
Samsung Hub.
1. Confirm you have already logged in to your Samsung
account.
2. From the Home screen, tap (
Apps
)
(
Samsung Link
).
3. If prompted with an on-screen notification about no
Wi-Fi detected, tap
Cancel
(to continue by using your
network connection) or
Connect
to continue.
4. Tap
Get started
.
5. Follow the on-screen prompts.
6. Tap and select a target device. Available tabs
include: Photos, Music, Video, or Document.
Configuring Samsung Link Settings
The Samsung Link™ application must first be configured
prior to its initial use. You must setup parameters such as
connected Wi-Fi, Items to share, source server address, and
external device acceptance rights.
1. From the Home screen, tap (
Apps
)
(
Samsung Link
).
2. Press and then tap
Settings
and configure the
following settings as desired:
•Registered storage
: allows you to add a Web storage location.
Without a storage service/location added, you will not be able
to use Samsung Link.
•Save to
: allows you to save your media to your internal phone
memory or to an SD card.
• Auto upload
: allows you to enable automatic upload of images
from your device to those storage locations specified within the
Web storage list. Move the slider to the on position to activate
the feature.
• Video optimization
: allows you to setup the video quality for
streamed video content. Move the slider to the on position to
activate the feature.
205
• Password lock
: allows you to restrict access to Samsung Link
by requiring a user enter the currently active and associated
Samsung account password. Move the slider to the on position
to activate the feature.
• My account
: displays Samsung account information.
• About this service
: displays application information.
Setting Up Web Storage
Web storage services allow you to use storage space to store
your files and share them on the “Cloud”.
Note:
If you are using another Web storage service, log into
that service first before using Samsung Link.
1. From the Home screen, tap (
Apps
)
(
Samsung Link
).
Note:
When adding storage, an N Drive is added.
2. Tap
Add storage
and choose from:
SugarSync, Dropbox, or SkyDrive.
– or –
3. Press and then tap
Settings
Registered storage
(
Add storage
).
4. Follow the on-screen instructions to register or log into
your cloud service.
5. Once the process is successfully completed, the Web
storage icon or name appears in the Web storage area
of the main screen.
6. From the main screen, select a connected device and
then tap on the media that you would like to share.
7. Once connected, select the media that you would like
to share.
•
A file with in the upper-left indicates it is stored remotely
on a Web storage location. Selecting this media causes your
device to access the file currently stored on your services’
servers.
Applications and Development 206
To de-register Web storage service:
1. From the Samsung Link application, press and
then tap
Settings
Registered storage
.
2. Select (
Delete
)
(
Delete
).
3. Select a current storage service and tap
OK
.
Sharing Media via Samsung Link to a Target
Device
Important!
Make sure all communicating devices are
connected to the same Wi-Fi.
1. Launch AllShare Play/Samsung Link on the target
device (such as an Internet TV, Samsung Tablet, etc..).
2. From the Home screen, tap (
Apps
)
(
Samsung Link
).
Note:
You must be signed in to your Samsung Account before
you can use this feature.
3. Tap and select your device name from the
Registered devices
area.
4. Tap an available category tab and select a file.
•
A file with in the upper-left indicates it is stored remotely
on a Web storage location. Selecting this media causes your
device to access the file currently stored on your services’
servers.
5. Tap (
Stream to connected devices
) and select an
available target device to begin streaming.
6. On a target device (ex: Internet TV) select the
on-screen
Allow
button to continue.
Note:
At this stage your device is requesting access to share
media with the external source.
7. Confirm (
Samsung Link Controller enabled
)
appears in the Notification area at the top of the device
to indicate you are using your device as the media
source.
207
Settings
This icon navigates to the sound and phone settings for your
phone. It includes such settings as: display, security,
memory, and any extra settings associated with your phone.
From the Home screen, tap (
Apps
)
(
Settings
).
– or –
From the Home screen, press and then tap
Settings
.
For more information, refer to “Changing Your Settings” on
page 216.
T-Mobile My Account
This application provides you online access to account
information such as your current activity, billing information,
service plans, downloads, and other information.
Note:
Wi-Fi connection must be disabled prior to use, this
application requires use of a T-Mobile network
connection.
1. From the Home screen, tap (
Apps
)
(
T-Mobile My Account
).
2. If prompted, follow the on-screen information for
what’s new in the app.
Note:
Some features may require you to log into your account.
3. The application screen provides several available
options:
• Account Info
provides access to account-specific features
such as: Notifications.
• Device Support
provides details about your current billing
summary.
Applications and Development 208
• Notifications
provides about both your current plan, other
available plans and other related services.
• [promotional]
provides promotional information.
T-Mobile Name ID
Allows you to modify the on-screen Caller ID information.
Name ID identifies unknown callers by Name, City, and State.
1. From the Home screen, tap (
Apps
)
(
T-Mobile Name ID
).
2. Choose an on-screen option.
T-Mobile TV
T-Mobile TV is an application that allows you to get live TV
and Video on Demand.
1. From the Home screen, tap (
Apps
)
(
T-Mobile TV
). The T-Mobile Terms and Conditions
page displays.
Note:
A data plan is required to use this feature. Charges may
apply. Please contact your service provider for further
details.
2. Tap
Accept
if you accept the Terms and Conditions.
– or –
Tap
Exit
to close the application.
Note:
T-Mobile TV must be initialized over a cellular network
before it can be used. During this initial registration
process, any Wi-Fi connections must be disabled.
3. Tap
Disable Wi-Fi
if you currently have an active Wi-Fi
connection.
209
4. Tap
Start Trial
to begin a free 30-day trial of the
service.
– or –
Tap
OK
to keep viewing the free content or
Purchase
Options
to buy the paid features.
5. Tap any of the following categories to begin viewing:
Home
,
Live TV
,
TV Shows
,
Favorites
,
Help
,
Search
,
More
Info
,
Browse
,
or
Live Channels
.
Video
Using Video
The Video application plays video files stored on the SD card.
This device is able to playback DivX videos.
1. From the Home screen, tap (
Apps
)
(
Video
). A list of available videos displays in the
Video list.
2. Tap a video file to begin viewing.
Sharing Videos
1. From the Home screen, tap (
Apps
)
(
Video
). After a few seconds, each
on-screen video begins to cycle through a preview of
the first five seconds of the clip.
2. Press and then tap
Share via
.
3. Select either individual videos or tap
Select all
.
4. Click
Done
to complete the process or
Cancel
to quit.
5. Select a sharing option. Choose from: Add to Dropbox,
Bluetooth, ChatON, Drive, Email, Gmail, Google+,
Messages, Picasa, Wi-Fi Direct, or YouTube.
Applications and Development 210
Using Picture-In-Picture
This feature can be used during playback of supported video
types via either the Gallery, Play Videos, or Video player.
Note:
Some applications might not allow this video to remain
active in the foreground (ex: Camera/Camcorder
screen).
This feature allows you to continue to view your video as a
background operation while you multi-task and do other
things, such as surf the Internet, access your Contacts list,
look for a picture, etc..
1. From the Home screen, tap (
Apps
).
2. Tap the desired video playback application.
3. Tap the desired video to begin playback.
Note:
The Picture-In-Picture feature only works when using
the Video player application. Other video players (ex:
YouTube), do not support this feature.
4. As playback is initiated, locate and tap
(
Picture-in-Picture
) from the bottom-right of the
playback screen. Your current video is then sent to
foreground of any new page and most application
screens.
5. The video disappears from the screen once it ends.
DivX Overview
This device is able to playback DivX videos. DivX Certified®
to play DivX® video up to HD 720p, including premium
content. If you try to play DivX VOD content not authorized for
your device, the message “Authorization Error” will be
displayed and your content will not play. Learn more at
www.divx.com/vod
.
Your device must first be registered to playback protected or
purchased DivX content. DRM-free or unprotected content
does not required DivX VOD registration.
Locating Your VOD Registration Number
1. From the main
Settings
page, tap
More
tab
About
device
Legal information
License settings
DivX® VOD
Register
.
2. Write down your Registration code.
3. Tap
OK
.
211
Visual Voicemail
Visual Voicemail enables users to view a list of people who
left a voicemail message, and listen to the any message they
want without being limited to chronological order.
1. From the Home screen, tap (
Apps
)
(
Visual Voicemail
).
2. Read the on-screen information and tap
Next.
3. Read the on-screen information and tap
Done
. A list of
the voicemail messages displays.
Important!
If this is your first time to access Visual Voicemail,
you may be prompted to enter a new PIN code and
tap
Next
to activate Visual Voicemail.
Note:
You must subscribe to Visual Voicemail service to use
this feature. Charges may apply. Please contact your
service provider for further details.
4. Tap an on-screen voicemail message to play it back.
To check Visual Voicemail messages:
1. From the Home screen, tap (
Apps
)
(
Visual Voicemail
).
2. Tap the voicemail message you want to play.
3. Tap (
Play
).
To delete Visual Voicemail messages:
1. From the Home screen, tap (
Apps
)
(
Visual Voicemail
).
2. Tap the voicemail message you want to delete.
3. Tap (
Delete
)
OK
.
Voice Recorder
The Voice Recorder allows you to record an audio file up to
one minute long and then immediately send it as a message.
1. From the Home screen, tap (
Apps
)
(
Voice Recorder
).
2. Tap (
List
) to display a list of current recordings.
3. Tap (
Recording quality
) to adjust the recording
quality. Choose from: Normal or High quality recording.
4. Tap (
Record
) to record an audio file.
Applications and Development 212
5. Tap (
Stop
) to stop recording. The file
automatically saves to the Voice list.
– or –
Tap (
Pause
) to pause the recording of an audio
file.
– or –
Tap (
Cancel
) to cancel the recording of an audio
file.
6. From the Recorded files page, press and then
select one of the following:
•Share via
and select a method in which to share this audio file.
Selections are: Add to Dropbox, Bluetooth, ChatON, Drive,
Email, Gmail, Messages, or Wi-Fi Direct. Refer to each specific
section, depending on the method you selected to send this
voice recording.
•Delete
: allows you to delete 1 or more voice recordings. Tap
the recordings to delete and tap
Delete
.
•Settings
: the following settings are available:
–
Storage
: allows you to choose where your recordings will be
saved. Select between Device or memory card.
–
Recording quality
: allows you to set the recording quality to
High or Normal.
–
Limit for multimedia messages
: allows you to select On or
Off. If you Limit for MMS by selecting On, you will be assured
that the recording can be sent in a message.
–
Contextual filename
: (requires GPS tagging) allows you to
adjust the filename based on contextual information such as
your current GPS location.
–
Default name
: allows you to choose the name prefix for your
recordings. For example, if your Default name is Voice, your
recordings would be named Voice 001, Voice 002, Voice 003,
etc.
–
Noise reduction
: allows you to activate/deactivate background
noise suppression.
–
Recording volume
: allows you to assign the ambient noise
quality of your current location so the device can better detect
audio. Choose from High or Low.
–
Skip interval
: allows you to assign a skip length.
•End
: allows you to exit the application.
213
Voice Search
Launches the Google Now application that is used for voice
to text Internet searching.
1. From the Home screen, tap (
Applications
)
(
Voice Search
).
2. When prompted, speak into the built-in microphone.
3. Use the on-screen options to find a matching search
term.
VPN Client
This is a full-featured VPN Client that provides support for the
latest IPSec VPN standards and provides interoperability with
support for all major VPN Gateways.
1. From the Home screen, tap (
Apps
)
(
VPN CLient
).
2. Follow the on-screen instructions to configure the VPN
Client.
•
Options include: Add VPN Connection or My VPN Connections.
YouTube
YouTube is a video sharing website on which users can
upload and share videos, and view them in MPEG-4 format.
1. From the Home screen, tap (
Apps
)
(
YouTube
).
2. Tap the search field to search for specific videos,
scroll down to browse through the main page
thumbnails, or scroll to the bottom to explore additional
options.
3. To view a video, tap an available preview thumbnail or
tap the title link.
To configure YouTube Settings:
Press and then tap
Settings
and configure the
following parameters:
• General
–
High quality on mobile
, when enabled, allows you to start all
videos in high quality mode while you are connected to a mobile
network.
–
Caption font size
allows you to set the font size used by
on-screen captions. Choose from: Small, Medium, Large, or
Huge.
Applications and Development 214
–
Uploads
specifies network preferences for uploads.
–
Content localization
allows you to prioritize channels and
videos from a specific country or region.
–
Improve YouTube
allows you to anonymously send YouTube
information to help improve the application.
–
New video notifications
allows you to receive notifications
when new videos are posted that meet your interest criteria.
• Connected TVs
–
Allows you to pair your device to a wireless TV running a
YouTube application. Options include Add a TV and Edit TVs.
•Search
–
Clear search history
allows you to clear previous YouTube
searches from showing up in the YouTube search box.
–
Never remember history
allows you to force YouTube to never
store search history information.
–
SafeSearch filtering
allows you to configure block settings for
videos containing restricted content. This option blocks these
videos from appearing within your search results. Choose from:
Don’t filter or Strict.
• Preloading
–
Preload subscriptions
allows you to preload (or go get videos
while on Wi-Fi and charging) your subscription videos.
–
Preload watch later
allows you to enable the preload function
on selected videos so you can watch them later. Read the data
usage information and tap
OK
to accept the terms.
Note:
Preloading YouTube videos will use some of your
device’s storage space and may result in additional
charges if your Wi-Fi plan is not unlimited.
• About
–
Help
provides answers to most YouTube questions.
–
Feedback
allows you to provide user feedback to YouTube.
–
Google Mobile Terms of Service
–
YouTube Terms of Service
–
Google Mobile Privacy Policy
–
YouTube Privacy Policy
–
Open source licenses
–
App version
displays the software version for the current
YouTube application.
215
To watch a high quality video:
Press and then tap
Settings
General
High
quality on mobile
.
Changing Your Settings 216
Section 10: Changing Your Settings
This section explains the sound and phone settings for your
device. It includes such settings as: display, security,
memory, and any extra settings associated with your device.
Accessing Settings
From the Home screen, tap (
Apps
)
(
Settings
).
– or –
Press and then tap
Settings
. The
Settings screen displays.
Settings Tabs - Overview
The Settings are divided into 4 main groups. When the
Settings screen displays, the following 4 tabs are located at
the top of the screen:
Connections
:
This tab allows you to see all of settings related
to the connection of your device to external
sources. Features include: Wi-Fi, Bluetooth, Data
usage, More networks (Airplane mode, Mobile
networks, Tethering and Mobile HotSpot, VPN, and
Wi-Fi Calling), NFC, S Beam, Nearby devices, and
Screen Mirroring.
My device
:
This tab provides access to device configuration
and customization features. Features include:
Lock screen, Display, LED indicator, Sound,
Home screen mode, Call, Blocking mode,
Hands-free mode, Power saving mode, Accessory,
Accessibility, Language and input, Motion, Smart
screen, and Voice control.
My device
My device
217
Note:
The settings for your device are described below using
the order in which they appear in the Settings menu.
Functions found under the Connections tab are listed
first, followed by My device, Accounts, and More.
Wi-Fi Settings
About Wi-Fi
Wi-Fi (short for "wireless fidelity") is a term used for certain
types of Wireless Local Area Networks (WLAN). Wi-Fi
communication requires access to an existing and accessible
Wireless Access Point (WAP). These WAPs can either be
Open (unsecured) as within most Hot Spots, or Secured
(requiring knowledge of the Router name and password).
Note:
After you complete a connection to an active Wi-Fi
network, the Wi-Fi Calling feature will automatically be
enabled.
Activating Wi-Fi
By default, your device’s Wi-Fi feature is turned off
(deactivated). Activating Wi-Fi allows your device to discover
and connect to compatible in-range WAPs (Wireless Access
Points).
1. From the Home screen, press and then tap
Settings
(
Connections
tab).
Accounts
:
This tab provides both the ability to create and
modify your accounts (ex: Samsung account, Email,
etc.), and access Backup and reset features.
More
:
This tab provides access to the remaining set of
device settings not listed under the other tabs.
These include Location services, Security,
Application manager, Battery, Storage, Date and
time, and About device.
Changing Your Settings 218
2. In a single motion touch and slide the
Wi-Fi
slider to the
right to turn it on . The device scans for
available in-range wireless networks and displays
them under Wi-Fi networks on the same screen.
Connecting to a Wi-Fi Network
1. From the main
Settings
page, tap
Connections
tab
Wi-Fi
.
The network names and security settings (Open
network or Secured with WEP) of detected Wi-Fi
networks display in the Wi-Fi networks section.
2. Tap the network you wish to connect to.
Note:
When you select an open network you are automatically
connected.
3. Enter a wireless password (if necessary).
4. Tap
Connect
.
Wi-Fi Status Indicators
The following icons indicate the Wi-Fi connection status:
Displays when Wi-Fi is connected, active, and
communicating with a Wireless Access Point
(WAP).
Displays when Wi-Fi is active and there is an
available open wireless network.
Displays when Wi-Fi Direct is active and
communicating
Displays when Wi-Fi is being used as a Mobile
HotSpot feature is active and communicating.
ON
ON
219
Manually Adding a Wi-Fi Network
1. From the main
Settings
page, tap
Connections
tab
Wi-Fi
Add Wi-Fi network
.
2. Enter the Network SSID (the name of your Wireless
Access Point).
3. Tap the
Security
field and select a security option. This
must match the current security setting on your target
WAP (Wireless Access Point).
4. Enter your WAP’s password if the WAP is secure.
5. Tap
Connect
to store the new information and connect
to the target WAP.
Note:
An SSID is a unique key which identifies a wireless LAN.
Its purpose is to stop other wireless equipment from
accessing your LAN — whether accidentally or
intentionally. To communicate, wireless devices must be
configured with the same SSID.
Deactivating Wi-Fi
1. From the Home screen, press and then tap
Settings
Connections
tab.
2. In a single motion touch and slide the
Wi-Fi
slider to the
left to turn it off.
– or –
Activate and Deactivate Wi-Fi from the Notification bar.
Note:
Use of wireless data connections such as Wi-Fi and
Bluetooth can reduce battery life and use times.
Manually Scan for a Wi-Fi Network
1. From the Home screen, press and then tap
Settings
Connections
tab
Wi-Fi
.
2. In a single motion touch and slide the
Wi-Fi
slider to the
right to turn it on.
3. Tap
Scan
.
Changing Your Settings 220
Wi-Fi Advanced Settings
The Wi-Fi settings - Advanced menu allows you to set up
many of the device’s Wi-Fi services, including:
•
Setting the Wi-Fi sleep policy
•
Check for Internet service
•
Viewing the device’s MAC Address
•
Configuring use of either a DHCP or Static IP
To access the Wi-Fi Advanced Settings menu:
1. From the Home screen, press and then tap
Settings
Connections
tab
Wi-Fi
.
2. Press and then tap
Advanced
.
Network Notification
By default, when Wi-Fi is on, you receive notifications in the
Status bar anytime your phone detects an available Wi-Fi
network. You can deactivate this feature if you do not want to
receive notifications.
1. From the main
Settings
page, tap
Connections
tab
Wi-Fi
.
2. Press and then tap
Advanced
.
3. Tap
Network notification
. A check mark displayed next
to the feature indicates Network notification is active.
4. Tap
Network notification
again to remove the check
mark and deactivate this feature.
Sorting your Wi-Fi Entry List
1. From the main
Settings
page, tap
Connections
tab
Wi-Fi
.
2. Press and then tap
Advanced
.
3. Tap the
Sort by
field and select either
Alphabet
or
Signal
strength
.
221
Wi-Fi During Sleep
By default, when your device enter a sleep mode, your Wi-Fi
connection stays on all the time. If the feature is Never
enabled during sleep that current data usage is taken over by
your SIM and its network connection.
1. From the main
Settings
page, tap
Connections
tab
Wi-Fi
.
2. Press and then tap
Advanced
Keep Wi-Fi on
during sleep
.
3. Select an available option:
•Always
: maintains your current active Wi-Fi connection even
during sleep.
• Only when plugged in
: maintains the active Wi-Fi connection
only when the device detects it is connected to a power supply.
This reduced the drain on your device’s battery.
• Never (increase data usage)
: shuts off the current Wi-Fi
connection during sleep and diverts any current data usage to
the cellular network connection.
Allow scanning
Allows the Google location service and other apps to scan for
networks, even when Wi-Fi is turned off.
1. From the main
Settings
page, tap
Connections
tab
Wi-Fi
.
2. Press and then tap
Advanced
.
3. Tap the
Always allow scanning
field to activate or
deactivate the feature.
Auto Network selection
Allows the device to automatically switch between Wi-Fi
network or cellular network.
1. From the main
Settings
page, tap
Connections
tab
Wi-Fi
.
2. Press and then tap
Advanced
.
3. Tap the
Auto network switch
to activate the feature that
would allow the device to connect to the best available
signal connection.
Changing Your Settings 222
Install certificates
1. From the main
Settings
page, tap
Connections
tab
Wi-Fi
.
2. Press and then tap
Advanced
.
3. Tap
Install certificates
and follow the on-screen
instructions.
Finding your WI-Fi Address Information
1. From the main
Settings
page, tap
Connections
tab
Wi-Fi
.
2. Press and then tap
Advanced
.
3. Locate the MAC Address and IP Address information at
the bottom of the screen.
•MAC address
: view your device’s MAC address, required
when connecting to some secured networks (not configurable).
•IP address
: view your device’s IP address.
WPS Push Button
The WPS (Wi-Fi Protected Setup) feature (sometimes
associated with a physical or on-screen button on most
WAPs) allows you to pair your device and WAP without the
need for entering a passcode. This process is similar to Wi-Fi
Direct pairing.
In this case, once the WPS feature is active on your WAP,
your device can then detect it and then immediately pair to it.
Note:
WPS-capable routers appear in the Wi-Fi list of available
devices with the term (
WPS available
) below their name.
To pair your device using WPS:
1. Follow the WPS activation instructions specific to your
Wireless Access Point.
2. From the main
Settings
page, tap
Connections
tab
Wi-Fi
.
3. Press then tap
WPS push button
.
4. Once the connection is complete, confirm the external
router now appears in the Wi-Fi list as connected.
223
WPS PIN Entry
If a WPS Push Button does not work, there is an alternative
WPS connection method where you would use a device
generated PIN number to establish the connection. This
number is then entered into your WAP’s WPS client PIN field
to complete the connection.
To pair your device using WPS PIN:
1. From the main
Settings
page, tap
Connections
tab
Wi-Fi
.
2. Press then tap
WPS PIN entry
.
3. Write down the generate PIN number and enter it into
your Wi-Fi Router’s client PIN field.
4. Once the connection is complete, confirm the external
router now appears in the Wi-Fi list as connected.
Wi-Fi Direct Setup and Settings
You can configure your device to connect directly with other
Wi-Fi capable devices. This is an easy way to transfer data
between devices. These devices must be enabled for Wi-Fi
direct communication. This connection is direct and not via a
HotSpot or WAP.
Displays when Wi-Fi Direct is active and
communicating
Note:
Activating this feature will disconnect your current Wi-Fi
network connection.
To activate your connection:
1. From the main
Settings
page, tap
Connections
tab.
2. In a single motion touch and slide the
Wi-Fi
slider to the
right to turn it on. The slider color indicates the
activation status.
3. Tap
Wi-Fi Direct
.
Changing Your Settings 224
4. Tap
Scan
and select the single device name to begin
the connection process to another Wi-Fi Direct
compatible device.
– or –
Tap
Multi connect
Scan
and select all the device
names to begin the connection process to these Wi-Fi
Direct compatible devices.
Note:
The target device must also have Wi-Fi Direct service
active and running before it can be detected by your
device.
5. Tap
Done
. The direct connection is then established.
Confirm appears in the Status bar.
6. When prompted to complete the connection, the
recipient should tap
OK
. Your status field now reads
“Connected” and your connected device is listed within
the Wi-Fi Direct devices listing.
Bluetooth settings
In this menu you can activate Bluetooth, view or assign a
device name, activate your phone so other Bluetooth devices
can discover it, or scan for other, available Bluetooth devices
with which to pair.
About Bluetooth
Bluetooth is a short-range communications technology that
allows you to connect wirelessly to a number of Bluetooth
devices, such as headsets and hands-free car kits, and
Bluetooth-enabled handhelds, computers, printers, and
wireless devices. The Bluetooth communication range is
usually up to approximately 30 feet.
Turning Bluetooth On and Off
To turn Bluetooth on:
1. From the Home screen, press and then tap
Settings
(
Connections
tab).
2. In a single motion touch and slide the
Bluetooth
slider
to the right to turn it on.
The slider color indicates the activation status. When
active, displays in the Status area.
225
To turn Bluetooth off:
1. From the Home screen, press and then tap
Settings
.
2. In a single motion touch and slide the
Bluetooth
slider
to the left to turn it off.
Note:
Bluetooth must be enabled prior to use.
Bluetooth Status Indicators
The following icons show your Bluetooth connection status
at a glance:
Displays when Bluetooth is active.
Displays when Bluetooth is connected (paired) and
communicating.
Bluetooth Settings
The Bluetooth settings menu allows you to set up many of
the characteristics of your device’s Bluetooth service,
including:
•
Entering or changing the name your device uses for Bluetooth
communication and description
•
Setting your device’s visibility (or “discoverability”) for other
Bluetooth devices
•
Displaying your device’s Bluetooth address
Changing the Device Name
1. From the Home screen, press and then tap
Settings
(
More
tab)
About device
.
2. Tap the
Device name
field and use the on-screen
keyboard to edit the current device name.
3. Tap to erase the current device name and enter
a new name for this device using the keyboard.
4. Tap
OK
to confirm your setting.
Changing Your Settings 226
Activating Visibility
1. From the main
Settings
page, tap
Connections
tab
Bluetooth
.
2. Verify your Bluetooth is active.
3. From the top of the Bluetooth settings page, toggle the
state of the visibility check mark. Activating this feature
enabled your device visible allows other devices to pair
and communicate.
Note:
Your device visibility is based on the time set within the
Visible time-out field (2 Minutes, 5 Minutes, 1 Hour, or
Never timeout). Press (
Menu
)
Visibility timeout
.
This value appears as a countdown within this
Visibility
timeout
field.
Scanning for Devices
This option allows you to scan for active Bluetooth devices so
you can pair with them.
1. From the main
Settings
page, tap
Connections
tab
Bluetooth
.
2. From the bottom of the Bluetooth settings page, tap
Scan
to search for visible external Bluetooth-
compatible devices such as headsets, devices,
printers, and computers.
Important!
Some Bluetooth devices are secured and require a
PIN number to confirm and pair with them.
3. Enter a PIN to pair with the device, if one is required,
and tap
OK
.
Review Received Files
1. From the main
Settings
page, tap
Connections
tab
Bluetooth
.
2. Verify Bluetooth is active.
3. From the Bluetooth settings page, press and then
tap
Received files
.
227
Pairing Bluetooth Devices
The Bluetooth pairing process allows you to establish trusted
connections between your device and another Bluetooth
device. When you pair devices, they share a passkey,
allowing for fast, secure connections while bypassing the
discovery and authentication process.
Note:
Pairing between two Bluetooth devices is a one-time
process. Once pairing is established the devices
continue to recognize their partnership and exchange
information without entering a passcode.
To pair your device with another Bluetooth device:
1. Verify Bluetooth is active.
2. From the Bluetooth settings page, tap the
Visibility
field
(shown by the device name).
Your device must be visible to successfully pair with an
external device. This is shown by a green check mark.
3. Tap
Scan
. Your device displays a list of discovered in-
range Bluetooth devices.
4. Tap a device from the list to initiate pairing.
5. Enter the passkey or PIN code, if needed, and tap
OK
.
6. The external device must accept the connection and
enter your device’s PIN code.
Once successfully paired to an external device,
displays in the Status area.
Note:
Due to different specifications and features of other
Bluetooth-compatible devices, display and operations
may be different, and functions such as transfer or
exchange may not be possible with all Bluetooth-
compatible devices.
Important!
If callers can not hear you during a call while using
a paired Bluetooth headset (with built-in
microphone), verify the
Call audio
option is enabled
within the entry’s Bluetooth Settings page.
Changing Your Settings 228
Configuring Bluetooth Device Settings
Some connected Bluetooth devices are capable of more than
just functioning as a headphone, but also have built in
microphones for picking up voice. Although both functions
are detected by the device and activated, there might be
times when you need to change or update these settings for
Phone and Media Audio:
•
I can hear the other person but they can’t hear me...
•
I want to use my Bluetooth device only as a headphone
1. Verify Bluetooth is active.
2. From the Bluetooth settings page, tap (
Settings
).
3. Toggle the
Call audio
field to activate/de-activate the
Bluetooth device’s on-board microphone.
4. Toggle the
Media audio
field to activate/de-activate the
Bluetooth device’s headset functions.
Note:
If callers can not hear you during a call while using a
paired Bluetooth headset (with built-in microphone),
verify the
Call audio
option is enabled within the entry’s
Bluetooth Settings page.
Disconnecting a Paired Bluetooth Device
Disconnecting a paired device breaks the connection
between the device and your phone, but retains the
knowledge of the pairing. At a later point when you wish to
reconnect the device, there is no need to setup the
connection information again.
1. Verify your Bluetooth is active.
2. From the Bluetooth settings page, tap the previously
paired device (from the bottom of the page).
3. Tap
OK
to confirm disconnection.
Note:
Disconnections are manually done but often occur
automatically if the paired device goes out of range of
your phone or it is powered off.
Deleting a Paired Bluetooth Device
Deleting a device from your list removes its “connection
record” and upon reconnection would require that you
re-enter all the previous pairing information.
1. Verify Bluetooth is active.
2. From the Bluetooth settings page, tap (
Settings
)
Unpair
to delete the paired device.
229
Sending Contacts via Bluetooth
Depending on your paired devices’ settings and capabilities,
you may be able to send pictures, Contact information, or
other items using a Bluetooth connection.
Note:
Prior to using this feature, Bluetooth must first be
enabled on both your phone and the external device, and
the recipient’s device must be visible.
1. Verify your Bluetooth is active and your phone is
visible.
2. From the Home screen, tap (
Contacts
).
3. Touch and hold the entry from the list to display the
on-screen context menu.
4. Tap
Share via
Bluetooth
and select a paired external
Bluetooth device.
Note:
The external Bluetooth device must be visible and
communicating for the pairing to be successful.
5. A Bluetooth share notification displays in your
notifications list.
Data Usage
Monitor and mange your device’s data usage capabilities.
Features include activation/deactivation or network data
usage, set mobile data usage for a set period of time, and
view application data usage.
From the Home screen, press and then tap
Settings
(
Connections
tab)
Data usage
.
To activate/deactivate Mobile data usage:
1. From the main
Settings
page, tap
Connections
tab
Data usage
.
2. Tap the
Mobile data
field to activate the feature. A
green check mark indicates the feature is active.
3. Tap the
Mobile data
field again to deactivate the
feature.
To set a mobile data limit:
1. From the main
Settings
page, tap
Connections
tab
Data usage
.
2. Place a check mark in the
Set mobile data limit
field.
3. Read the on-screen disclaimer info and tap
OK
.
Changing Your Settings 230
4. Touch and drag the far right ends of the Red or Orange
horizontal lines to manually adjust both the Warning
and Maximum data limits.
5. Touch and drag the bottom grey vertical lines to adjust
the time frames.
6. Tap the
Data usage cycle
button and select either the
current cycle or define your own by selecting
Change
cycle
.
7. Press and then select from the available on-
screen options:
• Data roaming
allows you to connect to your service provider’s
partner networks and access data services when you are out of
your service providers area of coverage. For more information,
refer to
“Data Roaming”
on page 231.
• Restrict background data
prevents background data usage.
This can help prevent over usage of your data minutes.
• Auto sync data
allows the device to automatically sync
information and updates with your various services.
• Show Wi-Fi usage
activates an additional Wi-Fi tab that shows
you your Wi-Fi data usage.
• Mobile hotspots
allows you to select available Wi-Fi networks
that can service as mobile hotspots. Place a check mark on
those entries you wish to use.
More Networks
This tab displays additional wireless and network
information.
From the Home screen, press and then tap
Settings
(
Connections
tab)
More
networks
.
Airplane Mode
This mode allows you to use many of your device’s features,
such as Camera, Games, and more, when you are in an
airplane or in any other area where making or receiving calls
or data is prohibited.
Important!
When your device is in Airplane mode, it cannot
send or receive any calls or access online
information or applications.
1. From the main
Settings
page, tap
Connections
tab
More networks
.
231
2. Tap
Airplane mode
. A check mark displayed next to the
feature indicates Airplane mode is active.
The Airplane mode icon is displayed at the top of
your screen.
Mobile networks
Before you use applications such as Google Maps and find
your location or search for places of interest, you must
enable the Mobile networks options.
From the main
Settings
page, tap
Connections
tab
More networks
Mobile networks
.
The following options display:
Use mobile data
Allows you to activate mobile data usage on your device.
From the main
Settings
page, tap
Connections
tab
More networks
Mobile networks
Mobile data
.
Data Roaming
Data roaming allows you to connect to your service
provider’s partner networks and access data services when
you are out of your service providers area of coverage.
1. From the main
Settings
page, tap
Connections
tab
More networks
Mobile networks
.
2. Tap
Data roaming
to connect to data services while
roaming outside your network.
– or –
Tap
Data roaming
again to remove the green check
mark and deactivate the feature.
Access Point Names
To access a wireless access point:
From the main
Settings
page, tap
Connections
tab
More networks
Mobile networks
Access Point
Names
. A list of the Access point names display. The
active access point displays a bright green, filled circle
to the right of the name.
Changing Your Settings 232
Network mode
You can configure your device to either automatically select
the LTE option (LTE/WCDMA/GSM (auto connect) [by default]),
WCDMA/GSM (auto connect), GSM only, or WCDMA only.
From the main
Settings
page, tap
Connections
tab
More networks
Mobile networks
Network mode
.
• LTE/WCDMA/GSM (auto connect)
is the default network
mode option. This selection allows the device to choose the
fastest connection from among the available connection
speeds, including LTE.
• WCDMA/GSM (auto connect)
allows you to exclude the LTE
network and choose from only 4G, 3G, and 2G networks.
• WCDMA only
restricts your connection to only the 3G network.
• GSM only
restricts your connection to only the 2G network.
Using the LTE Network Option
To confirm you are always using the fastest possible
connection, the device has an automatic detection method
where it finds both the fastest and most stable connection/
communication method from among this selected set
(LTE/4G/3G/2G).
1. From the main
Settings
page, tap
Connections
tab
More networks
Mobile networks
Network mode
.
2. Tap
LTE/WCDMA/GSM (auto connect)
. A selection
indicator displays next to this option to show that it is
active. This is the default mode for this device.
Using the WCDMA/GSM Option
If you wish to not use LTE but still require a fast connection
using the standard 3G/2G network speed, follow these
instructions to connect to these network types.
1. From the main
Settings
page, tap
Connections
tab
More networks
Mobile networks
Network mode
.
2. Tap
WCDMA/GSM (auto connect)
. A selection indicator
displays next to this option to show that it is active.
This is the default mode for this device.
233
Using the WCDMA - 3G Only Network
This option uses a 3G connection only.
1. From the main
Settings
page, tap
Connections
tab
More networks
Mobile networks
Network mode
.
2. Tap
WCDMA only
. A check mark displays next to this
option to indicate that it is active. Connecting to 3G
networks slows the data transfer speed and time.
Using the 2G - GSM Only Network
If you are not using applications that require a faster network
speed (any application that accesses the network or uses a
browser), using the 2G only (WCDMA) network saves battery
life.
1. From the main
Settings
page, tap
Connections
tab
More networks
Mobile networks
Network mode
.
2. Tap
GSM only
. A check mark displays next to this option
to indicate that it is active. Connecting to 2G networks
slows the data transfer speed and time.
Network Operators
Using this feature you can view the current network
connection. You can also scan and select a network operator
manually, or set the network selection to Automatic.
1. From the main
Settings
page, tap
Connections
tab
More networks
Mobile networks
.
2. Tap
Network operators
. The current network connection
displays at the bottom of the list.
Important!
You must deactivate data service prior to searching
for an available network.
3. Tap
Search now
to manually search for a network.
4. Tap
Select automatically
to automatically select a
network connection.
Note:
Connecting to 2G networks slows the data transfer
speed and time.
Changing Your Settings 234
Default Setup Options
Your device default is set to Automatic (to automatically
search for an available network. You can set this option to
Manual to select a network each time you connect.
1. From the main
Settings
page, tap
Connections
tab
More networks
Mobile networks
Network
operators
.
2. Tap
Default setup
.
3. Tap
Automatic
to allow the device to automatically
select a network.
– or –
Tap
Manual
to locate and connect to a network
manually.
Tethering and Mobile HotSpot
This option allows you to share your phone’s mobile data
connection via a direct USB connection between your phone
and computer. A wireless version of this same functionality
would be the Mobile AP feature.
Note:
You can not mount your device’s microSD card to your
computer while using the USB tethering feature.
If additional software or USB drivers are required,
navigate to: http://www.samsung.com/us/support/
downloads.
From the main
Settings
page, tap
Connections
tab
More networks
Tethering and Mobile HotSpot
.
USB Tethering
This option allows you to share your device’s mobile data
connection via a direct USB connection between your device
and a single computer. The Mobile HotSpot connectivity is a
wireless version of this same functionality and allows you to
provide Internet connectivity to multiple devices.
235
Note:
You can not mount your device’s microSD card to your
computer while using the USB tethering feature.
If additional software or USB drivers are required,
navigate to: http://www.samsung.com/us/support/
downloads.
To connect using USB Tethering:
1. From the Home screen, tap (
Apps
)
(
Mobile HotSpot
).
– or –
From the Home screen, press and then tap
Settings
(
Connections
tab)
More
networks
Tethering and Mobile HotSpot
.
2. Plug in the USB cable between your computer and your
device.
3. Tap
USB tethering
from the Tethering menu. This places
a green check mark next to the entry and activates the
feature. A Tethering or HotSpot active notification
briefly appears on the screen.
Look for the Tethering active icon in the Status
bar area of the screen.
4. Read the on-screen notification regarding data use and
tap
OK
.
To disconnect tethering:
1. From the Home screen, tap (
Apps
)
(
Mobile HotSpot
).
2. Tap
USB tethering
from the Tethering menu to remove
the check mark and deactivate the feature.
3. Remove the USB cable from the device.
Mobile HotSpot
This feature allows you to turn your device into a Wi-Fi
hotspot. The feature works best when used in conjunction
with 4G data services (although 3G service can also be
used).
The Mobile HotSpot connectivity is a wireless version of this
same functionality and allows you to provide Internet
connectivity to multiple devices.
Important!
The Mobile HotSpot service cannot be active when
device is connected to Wi-Fi. Please disconnect
your Wi-Fi connection prior to activating this
service.
Changing Your Settings 236
Note:
You must have a tethering plan on your account in order
to use the Mobile HotSpot.
To activate the Mobile HotSpot service:
1. From the Home screen, tap (
Apps
)
(
Mobile HotSpot
).
– or –
From the Home screen, press and then tap
Settings
(
Connections
tab)
More
networks
Tethering and Mobile HotSpot
.
2. In a single motion touch and slide the
Mobile HotSpot
slider to the right to turn it on.
3. Read the on-screen notification regarding data use and
tap
OK
.
4. Edit the
Network SSID
name and then write it down.
5. Enable the
Broadcast network name (SSID)
field if you
would like to broadcast your SSID name to nearby
devices.
6. Verify the
Security
field is set to
WPA2 PSK
.
7. Enter a new password then write it down.
–
Additional options include Show password and Show advanced
options.
8. Tap
Save
to store the new settings.
9. Confirm the Mobile HotSpot active icon appears
at the top of the screen.
Note:
By default, the connection is not secured.
Note:
Using your Mobile HotSpot drains your device’s battery
much faster. The best way to keep using the device as a
HotSpot is by connecting to a Charger.
To connect to the HotSpot:
1. Enable Wi-Fi (wireless) functionality on your target
device (laptop, media device, etc.).
2. Scan for Wi-Fi networks from the external device and
select your device’s Mobile HotSpot name from the
network list.
•
The SSID name for your device’s hotspot is determined by what
you entered into the
Network SSID
field.
237
•
You can change the name by tapping
Configure
Network
SSID
and changing the entry.
3. Select this HotSpot and follow your on-screen
instructions to complete the connection.
4. Launch your Web browser to confirm you have an
Internet connection.
To change the Portable HotSpot password:
1. From the Home screen, tap (
Apps
)
(
Mobile HotSpot
).
2. Tap
Mobile HotSpot
Configure
.
3. Tap the
Security
field and select
WPA2 PSK
.
4. With security enabled, delete the previous password
and enter a new one into the
Password
field.
Important!
The more complex the password, the harder it will
be for intruders to break your security. It is
recommended that you not use names, birthdays,
or other personal information.
5. Tap
Save
to store the new settings.
To manage connected devices:
This feature allows you to provide MAC filtering on your
device. This is similar to a “VIP list” where only device on the
list are allowed access.
1. From the Home screen, tap (
Apps
)
(
Mobile HotSpot
).
2. Tap
Mobile HotSpot
Allowed devices
.
3. Tap (
Add new device
) to add devices to the
allowed for connection list.
4. Enter the Device name and Mac address.
5. Tap
OK
to save the new device.
Changing Your Settings 238
VPN settings
The VPN settings menu allows you to set up and manage
Virtual Private Networks (VPNs).
Note:
Before using VPN, you must first set up a screen unlock
PIN or password. For more information, refer to
“Security” on page 280.
Adding a VPN
Before you add a VPN you must determine which VPN
protocol to use: PPTP, L2TP/IPSec PSK, L2TP/IPSec RSA,
IPSec Xauth PSK, IPSec Xauth RSA, IPSec Hybrid RSA.
Important!
Before you can use a VPN you must establish and
configure one.
1. From the main
Settings
page, tap
Connections
tab
More networks
VPN
.
2. If prompted, read the screen lock information and
follow the on-screen steps to setup an unlock PIN or
password.
3. Tap (
Add VPN network
).
4. In the form that appears, fill in the information provided
by your network administrator.
5. Tap
Save
.
Note:
Similar setup process can be used for all available VPN
types.
Connecting to a VPN
1. From the main
Settings
page, tap
Connections
tab
More networks
VPN
.
2. Tap the VPN entry you want to connect to.
3. Enter any requested credentials into the pop-up that
opens.
4. Tap
Connect
.
Edit a VPN
1. From the main
Settings
page, tap
Connections
tab
More networks
VPN
.
2. Touch and hold the VPN that you want to edit.
3. In the pop-up that opens, select
Edit network
.
4. Make the desired VPN setting changes.
5. Tap
Save
.
239
Delete a VPN
1. From the main
Settings
page, tap
Connections
tab
More networks
VPN
.
2. Touch and hold the VPN that you want to delete.
3. Tap
Delete network
within the pop-up that opens up.
Wi-Fi Calling
You can configure your device to make and receive calls over
an active Wi-Fi connection. Wi-Fi Calling is an excellent
solution for coverage issues in and around the home or
wherever cellular coverage is limited. Minutes used while
connected to the Wi-Fi network count against available rate
plan minutes.
For more information, refer to “Wi-Fi Calling” on page 58.
1. Ensure that the
Wi-Fi connected
icon displays on
the status bar.
2. From the main
Settings
page, tap
Connections
tab
More networks
.
3. In a single motion touch and slide the
Wi-Fi Calling
slider to the right to turn it on.
Wi-Fi Calling Settings
Important!
A compatible SIM card must be installed within the
device prior to using this feature. Wi-Fi must first
be active and communicating prior to launching
Wi-Fi Calling.
1. From the main
Settings
page, tap
Connections
tab
More networks
Wi-Fi Calling
.
2. Tap
Connection Preferences
and select a preference for
use of the Wi-Fi Calling feature:
• Wi-Fi Preferred
: Wi-Fi network is preferred over cellular
network when making calls. Calling requires you to stay in the
Wi-Fi range.
• Cellular Network Preferred
: The cellular network is preferred
over a Wi-Fi network when making calls.
• Never use Cellular Network
: Use only Wi-Fi for calls. Do not
use Cellular Network, even if available.
3. Tap
Help
from the main Wi-Fi Calling Settings page to
navigate through either an on-screen tutorial or review
the top 10 Wi-Fi Calling questions.
Changing Your Settings 240
Near Field Communication
This feature is used to read and exchange tags. When used
in conjunction with Android Beam, your device can be used
to beam application content when NFC-capable devices are
touched.
1. From the main
Settings
page, tap
Connections
tab.
2. Tap the
NFC
field and verify the feature is active
(indicated by ).
Android Beam
When Android Beam is activated, you can beam app content
to another NFC-capable device by holding the devices close
together. You can beam browser pages, YouTube videos,
contacts, and more.
1. From the main
Settings
page, tap
Connections
tab
NFC
Android Beam
.
2. Tap the
OFF / ON
icon to turn Android Beam on.
3. Touch the back of your device with another
NFC-capable device and the content is transferred.
S Beam
This feature (when activated via NFC) allows you to beam
large files directly to another compatible device that is in
direct contact. These files can be larger, such as Videos, HD
pictures, and other large files.You can beam images and
videos from your gallery, music files from your music player,
and more.
1. From the main
Settings
page, tap
Connections
tab.
2. Verify the NFC feature is active.
3. Tap
S Beam
and make sure the feature is turned on.
4. If not already active, in a single motion touch and slide
the
S Beam
slider to the right to turn it on.
5. Complete the transfer process between the two
NFC-enabled devices by placing them back to back.
This feature can come in very handy to quickly share
pictures between users with compatible S Beam devices. For
more information, refer to “Using S Beam to Share Pictures”
on page 143.
ON
ON
241
Nearby devices
This option allows you to share your media files with nearby
devices using DLNA and connected to the same Wi-Fi.
1. Connect to a Wi-Fi network.
2. From the main
Settings
page, tap
Connections
tab
NFC
.
3. Tap the
NFC
field to turn file sharing on. Once active,
(
Nearby devices
) appears at the top of the screen.
Note:
Turn NFC off by tapping the NFC field again.
4. At the Nearby devices prompt, tap
OK
.
5. Tap
Shared contents
, then check the media you would
like to share. Tap
OK
.
6. Tap
Allowed devices list
, then select the connected
devices you would like to allow.
7. Tap
Not-allowed devices list
, then select the connected
devices you would like to not allow.
8. Tap
Download to
, then select the destination of any
downloaded (shared) content. Choose from USB
storage (Device) or SD card.
9. Tap
Upload from other devices
, then select the actions
you’ll take when you upload content from other
devices. Choose from either Always accept, Always
ask, or Always reject.
Screen Mirroring
With feature enabled, you can wirelessly mirror what is
currently displayed on your device’s screen with an external
TV via devices such as the AllShare Cast Hub®.
Note:
Screen mirroring can only be done with a compatible
wireless TV or one enabled with the AllShare Cast Hub.
1. From the main
Settings
page, tap
Connections
tab
Screen Mirroring
.
2. In a single motion touch and slide the
Screen Mirroring
slider to the right to turn it on. The slider color indicates
the activation status.
Changing Your Settings 242
Note:
This feature allows a connection between your device
and the optional AllShare Cast Hub, via a shared Wi-Fi
Direct connection. The AllShare Cast Hub then allows
the communicating TV to mirror what is being shown on
the device's display.
For more information, refer to “AllShare Cast Hub” on page
148.
Lock Screen
This menu contains features that allows you to configure the
device’s security parameters.
Screen Unlock Pattern Overview
To secure data and limit phone access, set the phone to
require a screen unlock pattern each time you turn on the
device, or every time the phone wakes up from sleep mode
(when the screen automatically turns off).
From the Home screen, press and then tap
Settings
(
My device
tab)
Lock screen
Screen lock
.
The Screen lock menu allows to choose from a variety of
locking features such as:
•Swipe
: Swipe the screen to unlock it.
• Face unlock
: Look at your phone to unlock it.
• Face and voice
: Look at your phone and speak to unlock.
•Pattern
: A screen unlock pattern is a touch gesture you create
and use to unlock your device. Follow the prompts to create or
change your screen unlock pattern.
•PIN
: Select a PIN to use for unlocking the screen.
•Password
: Create a password for unlocking the screen.
•None
: No pattern, PIN, or password is required. The screen will
never lock.
Using Swipe
This feature is the least secure locking method and only
requires that a user swipe the screen to unlock the device.
1. From the main
Settings
page, tap
My device
tab
Lock screen
.
2. Tap
Screen lock
Swipe
.
My device
My device
243
Swipe options
1. From the main
Settings
page, tap
My device
tab
Lock screen
.
2. Configure one of the following options.
• Multiple widgets
allows you to display multiple widgets on
your lock screen. Appears as an options after a lock mode is
enabled.
• Lock screen widgets
allows you to lock the widgets that are
displayed on your home screens.
•Shortcuts
sets shortcuts to appear at the bottom of the Lock
screen. Touch and slide the slider to the right to turn it on.
• Unlock effect
sets the effect you receive when unlocking the
phone. You can select None, Ripple effect, or Light effect.
•Help text
shows help information on the Lock screen.
• Wake up in lock screen
requires that you say a command to
wake-up your phone.
• Set wake-up command
designates your wake-up
commands. Tap
Set wake-up command
and follow the
on-screen prompts to create a new verbal command.
Using Face Unlock
This feature used facial recognition to unlock your phone.
This feature is less secure than PIN, Pattern, and Password
locks and can be bypassed by someone else who looks
similar to you.
1. From the main
Settings
page, tap
My device
tab
Lock screen
.
2. Tap
Screen lock
Face unlock
.
3. Read the on-screen notification and tap
Next
.
4. From the About Face Unlock screen, tap
Set it up
Continue
.
5. Follow the on-screen instructions.
6. If your face is not recognized, choose an unlocking
method: Pattern or PIN.
Changing Your Settings 244
Face unlock options
Once Face unlock is enabled, additional options are
available:
• Lock screen widgets
allows you to lock the widgets that are
displayed on your home screens.
• Improve facial recognition
allows you to improve your
device’s face matching capability by capturing your face in
different lighting, with or without glasses, and bearded or
clean-shaven. Follow the on-screen instructions.
• Presence check
requires that you blink when using the Face
unlock feature. This will increase the security of the feature.
• Lock automatically
locks the screen 5 seconds after the
screen turns off.
• Lock instantly with power key
once enabled, instantly locks
the screen after pressing the power key.
Using Face and Voice Unlock
This feature used facial recognition to unlock your phone.
This feature is less secure than PIN, Pattern, and Password
locks and can be bypassed by someone else who looks
similar to you.
1. From the main
Settings
page, tap
My device
tab
Lock screen
.
2. Tap
Screen lock
Face and voice
.
3. Read the on-screen notification and tap
Next
.
4. From the About Face Unlock screen, tap
Set it up
Continue
.
5. Follow the on-screen instructions.
6. Once prompted to speak and unlock command, tap
and repeat the phrase four times.
7. Once complete, tap
Done
.
245
Setting an Unlock Pattern
Creating a screen unlock pattern increases security on the
phone. When you enable the User visible pattern field, you
will draw an unlock pattern on the screen whenever you
want to unlock the phone’s buttons or touch screen. When
you activate the User tactile feedback field, you feel vibration
as feedback while drawing the pattern.
The feature is now paired with a backup PIN code that acts
as a backup to the pattern lock. If you forget your pattern,
you can regain access to the device by entering a PIN code.
Note:
Make sure the Require Pattern field is activated.
1. From the main
Settings
page, tap
My device
tab
Lock screen
.
2. Tap
Screen lock
Pattern
.
3. Draw your pattern by touching your first on-screen
point. Then,
without removing your finger from the
screen, drag your finger over adjacent points until the
gray trace line overlaps each point
and they are
highlighted with a green circle.
4. When you have connected at least four dots in a
vertical, horizontal or diagonal direction, lift your finger
from the screen and tap
Continue
.
5. Confirm the new pattern by redrawing it and then
tapping
Confirm
. The Unlock pattern is set.
6. Enter the backup PIN code and tap
Continue
.
7. Reenter the PIN to reconfirm the previous entry and
tap
OK
.
Changing the Screen Lock Pattern
This feature allows you to change the previously stored
unlock pattern and update it if necessary. This process is
similar to changing your password from time to time.
1. From the main
Settings
page, tap
My device
tab
Lock screen
.
2. Tap
Screen lock
.
3. Retrace your current pattern on the screen.
4. Tap
Pattern
and repeat steps 3 - 7 from the previous
section.
Changing Your Settings 246
Deleting the Screen Lock Pattern
1. From the main
Settings
page, tap
My device
tab
Lock screen
.
2. Tap
Screen lock
.
3. Retrace your current pattern on the screen.
4. Tap
None
.
Pattern options
Once an unlock pattern is enabled, additional options are
available:
• Lock screen widgets
allows you to lock the widgets that are
displayed on your home screens.
• Make pattern visible
allows you to see the pattern as you
draw it.
• Lock automatically
allows you to set a time-out for lock
screen.
• Lock instantly with power key
allows you to lock the screen
by pressing .
What If I Forget my Pattern?
If you forget your device's lock pattern, you can unlock your
device or reset it using your Google™ Account credentials.
When you enter the wrong unlock pattern too many times,
you should see an option at the bottom of the screen that
says
Forgot pattern?
Follow these steps to use either your PIN
or email address.
Important!
You can only enter an incorrect lock pattern 5 times
before the device is locked.
Important!
If you are unsuccessful in retrieving your lock
pattern or unlocking your device, please contact
T-Mobile for assistance.
To unlock your device with a PIN code:
1. Tap
Backup PIN
(located at the bottom of the screen).
2. Tap
Done
.
3. If you have forgotten your current pattern, tap
Pattern
from the Screen unlock settings menu and follow the
procedures outlined in "Setting an Unlock Pattern" on
page 245 to create a new pattern.
247
To unlock your device using your Google account:
1. Tap
Forgot pattern?
(located at the bottom of the
screen).
2. Tap the
Username (email)
and
Password
fields, use the
on-screen keyboard to enter your Google Account
credentials, and tap
Sign in
to complete the login
process.
3. If you have forgotten your Google Account credentials,
visit the Google website to recover them. If you still
cannot get your Google Account credentials, contact
your wireless carrier for additional options.
PIN Lock and Unlock
1. From the main
Settings
page, tap
My device
tab
Lock screen
.
2. Tap
Screen lock
PIN
.
3. Enter a PIN number using the numeric keypad and
touch
Continue
to confirm the password.
4. Confirm the PIN by re-entering it and tap
OK
to confirm.
Your phone now requires you to enter this PIN number
in order to unlock the phone.
Password Lock and Unlock
1. From the main
Settings
page, tap
My device
tab
Lock screen
.
2. Tap
Screen lock
.
3. Tap
Password
.
4. Enter a password using the keypad and tap
Continue
to
confirm the password.
5. Confirm the password by re-entering it and tap
OK
to
confirm.
Changing Your Settings 248
Customizing Your Lock Screen Shortcuts
Your device also provides up to 4 application shortcuts that
can be used to quickly access an application right from the
lock screen.
Important!
To use these shortcuts, your Screen Lock feature
can only be set to either Swipe or None.
To open a shortcut from the lock screen:
In a single motion, swipe your finger over the
on-screen icon and towards the top of your device.
Your device will unlock and you will be taken
immediately to the application.
To edit these Lock screen shortcuts:
1. From the main
Settings
page, tap
My device
tab
Lock screen
Shortcuts
.
2. In a single motion touch and slide the
Shortcuts
slider
to the right to turn it on.
3. Tap the
Shortcuts
field to activate the menu.
4. Tap a shortcut icon you wish to replace.
5. From the select application menu, tap a replacement
application.
Display Settings
In this menu, you can change various settings for the display
such as the wallpaper, Multi window, brightness, orientation,
and screen timeout, and power saving mode.
Adjusting the Screen Display
1. From the Home screen, press and then tap
Settings
(
My device
tab)
Display
.
2. Configure the following screen display settings:
• Wallpaper
: allows you to set the Wallpaper for your Home
screen, Lock screen, or both.
• Notification panel
: allows you to set the brightness of your
notification panel and also select the quick setting buttons that
you want to display at the top of the notification panel.
•Multi window
: tap this option to enable/disable the automatic
Multi window feature.
• Page buddy
: allows context related pages to be created on the
Home screen. You can select Earphones page, Docking page,
and Roaming page. Tap Page buddy help for more information.
•Brightness
: adjusts the on-screen brightness level. For more
information, refer to
“Adjusting Screen Brightness”
on
page 249.
My device
My device
249
• Auto rotate screen
: when enabled, the phone automatically
switches from portrait to landscape orientation and vice versa.
When this setting is disabled, the phone displays in portrait
mode only.
• Screen timeout
: adjusts the delay time before the screen
automatically turns off. Selections are: 15 seconds,
30 seconds, 1 minute, 2 minutes, 5 minutes, and
10 minutes.
•Daydream
: allows you to control what your screen does when
your device is docked or sleeping. Tap the adjacent OFF / ON
icon to turn it on. Follow the on-screen instructions.
• Font style
: sets the fonts used on the LCD display. Selections
are:
Default font
,
Choco cooky
,
Cool jazz
,
Rosemary
,
Samsung Sans
or
Get fonts online
. Tap
Get fonts online
to
download additional fonts.
•Font size
: allows you to select which size of font is displayed.
• Touch key light duration
: allows you to adjust the delay before
the Touch key light automatically turns off.
• Show battery percentage
: to activate/deactivate the display of
battery charge percentage atop the battery icon at the top of
the screen.
• Auto adjust screen tone
: adjusts the phone’s LCD brightness
level to automatically adjust and conserve battery power.
Adjusting Screen Brightness
This feature configures the LCD Brightness levels.
1. From the main
Settings
page, tap
My device
tab
Display
Brightness
.
2. Tap
Automatic brightness
to allow the phone to
self-adjust and tap
OK
.
– or –
Touch and slide the on-screen slider to adjust the level
and tap
OK
.
Changing Your Settings 250
Assigning a Wallpaper
The Wallpaper settings option allows you to set the Wallpaper
for your Home screen, Lock screen, or both.
1. From the main
Settings
page, tap
My device
tab
Display
Wallpaper
.
2. Select an available option to change its current
wallpaper.
For more information, refer to “Managing Wallpapers” on
page 38.
LED Indicator
This option allows you to turn on your LED lights for charging,
missed events, and incoming notifications. The light will turn
on by default unless you turn them off.
1. From the Home screen, press and then tap
Settings
(
My device
tab)
LED indicator
.
2. Tap the following LED indicator options to turn them on
or off:
•Charging
: LED lights up when the device is connected to the
charger.
• Low battery
: LED lights up when the battery level is low.
• Notifications
: LED lights up when you have missed calls,
messages, or application events.
• Voice recording
: LED lights up when you are recording voice.
The LED only lights up when the screen is off.
Sound Settings
From this menu you can control the sounds on the phone as
well as configure the display settings.
From the Home screen, press and then tap
Settings
(
My device
tab)
Sound
.
The following options display:
Silent mode via Device Options Screen
Silent mode is convenient when you wish to stop the phone
from making noise, in a theater for example. In Silent Mode
the speaker is muted and the phone only vibrates to notify
you of incoming calls, or other functions that normally have a
defined tone or sound as an alert.
1. From the Home screen, press and hold
(
Power/End
) until the
Device options
screen displays.
2. Tap either
Mute
,
Vibrate
, or
Sound
from the Device
options screen to activate or deactivate these features
(the current mode displays).
My device
My device
My device
My device
251
Adjusting the Volume Settings
The Volume menu now provides access to various volume
settings within one on-screen popup menu.
1. From the main
Settings
page, tap
My device
tab
Sound
Volume
.
2. Touch and drag the on-screen slider to assign the
volume settings for any of the following volume levels.
• Music, video, games and other media
,
Ringtone
,
Notifications
or
System
.
3. Tap
OK
to assign the volume levels.
Vibration intensity
Vibration intensity allows you to select how intense the
vibration is for different options.
1. From the main
Settings
page, tap
My device
tab
Sound
Vibration intensity
.
2. Touch and drag the slider to adjust the Vibration
intensity for
Incoming call
,
Notification
, and
Haptic
feedback
.
3. Tap
OK
to assign the vibration levels.
Setup the Ringtones
This option allows you to set the ringtone.
1. From the main
Settings
page, tap
My device
tab
Sound
.
2. Tap
Ringtones
.
3. Tap a ringtone from the available list. The ringtone
briefly plays when selected.
4. Tap
Add
to locate a compatible media file that can be
used as a ringtone.
5. Tap
OK
to assign a ringer.
Setup the Vibration
This option allows you to set your device to vibrate and ring.
1. From the main
Settings
page, tap
My device
tab
Sound
.
2. Tap
Vibrations
.
3. Select a vibration pattern and tap
OK
.
– or –
Tap
Create
to then use an on-screen touch circle to
create your own custom vibration pattern. Tap
Save
to
store the new vibration pattern.
Changing Your Settings 252
Setting a Default Notification Ringtone
This option allows you to set the ringtone that will sound for
notifications and alarms.
1. From the main
Settings
page, tap
My device
tab
Sound
.
2. Tap
Default notification sound
.
3. Select a ringtone and tap
OK
.
Setting up Vibration When Ringing
This option allows you to enable your phone to vibrate when
a call is incoming.
1. From the main
Settings
page, tap
My device
tab
Sound
.
2. Tap the
Vibrate when ringing
field to activate the
feature.
Audible System Tone Settings
These options are used when you use the dialing pad, make
a screen selection, lock your screen, or tap the screen. Each
time you press a key or make a selection the selected tone
sounds.
1. From the main
Settings
page, tap
My device
tab
Sound
.
2. Tap
Dialing keypad tone
to activate a tone when you
use on-screen keys. A check mark displayed next to
these features indicates active status.
3. Tap
Touch sounds
to activate a tone when you touch the
screen. A check mark displayed next to this feature
indicates active status.
4. Tap
Screen lock sound
to activate a tone when you use
the Lock screen. A check mark displayed next to this
feature indicates active status.
5. Tap
Haptic feedback
to activate the a vibration when
you press soft keys on certain screens. A check mark
displayed next to the feature indicates this feature is
active.
253
6. Tap
Auto haptic
to enable the ability of the device to
vibrate automatically in response to sounds of
downloadable apps.
Samsung Keyboard
These options are used when you use the on-screen keypad.
1. From the main
Settings
page, tap
My device
tab
Sound
.
2. Tap
Key-tap sound
to activate a tone when you use
on-screen keys. A check mark displayed next to this
features indicates active status.
3. Tap
Key-tap vibration
to activate the a vibration when
you press on-screen keys. A check mark displayed
next to the feature indicates this feature is active.
Audio Output
This sound feature configures the audio output.
1. From the main
Settings
page, tap
My device
tab
Sound
Audio output
.
2. Choose from either Stereo or Surround.
Home Screen Mode
This application allows you to set your display to the
conventional layout of
Standard mode
or provide an easier
user experience for the first-time smartphone users using
Easy mode
.
1. From the Home screen, press and then tap
Settings
(
My device
tab) (
Home
screen mode
).
2. Select one of the following options:
• Standard mode
: provides conventional layout for the apps and
widgets on your home screens.
•Easy mode
: provides easier user experience for first-time
smartphone users on the home screens.
3. Tap
Apply
and give your device a few seconds to
update the device with the new look and feel.
My device
My device
Changing Your Settings 254
Call Settings
1. From the Home screen, tap (
Phone
).
2. Press and then tap
Call settings
.
– or –
From the Home screen, press and then tap
Settings
(
My device
tab)
Call
.
Configuring General Call Settings
Configure the general call settings using this option.
1. From the Home screen, tap (
Phone
).
2. Press and then tap
Call settings
and then tap one
of the following options:
• Call rejection
: allows you to manage your rejection mode and
rejection list.
–
Auto reject mode
: sets the phone to automatically reject
incoming calls.
–
Auto reject list
: provides access to current rejection entries
and numbers.
• Set up call rejection messages
: allows you to manage both
existing rejection messages and create new ones.
• Answering/ending calls
: allows you to manage the settings
for answering and ending calls.
–
The home key answers calls
allows you to press
to answer the phone.
–
Voice control
allows you to answer incoming voice calls using
voice.
–
The power key ends calls
allows you to press the power key
to end the current call.
• Turn off screen during calls
: allows you to force the screen to
turn off during an active call.
• Call alerts
: allows you to assign call alert tones and activate
call alerts and vibration.
–
Call vibrations
: vibrates the phone when the called party
answers. Choose from: Answer vibration or Call-end vibration.
–
Call status tones
: assigns sounds settings during the call.
Choose from: Call connect tone, Minute minder, and Call end
tone.
–
Alerts on calls
: selects whether alarm and message
notification is turned off during a call.
My device
My device
255
• Call accessories
: allows you to assign headset settings during
incoming calls.
–
Automatic answering
configures the device to automatically
answer and incoming call when a headset is detected.
–
Automatic answering timer
configures the time delay before
the device automatically accepts the incoming call.
–
Outgoing call conditions
configures the connected Bluetooth
device to make outbound calls within one of two settings: Even
when device locked or Only when device unlocked.
• Wi-Fi Calling
: Allows you to both activate/deactivate the Wi-Fi
Calling feature and configure its settings.
Note:
If the Wi-Fi Calling feature is active and connected, the
Call forwarding feature is greyed-out and inaccessible.
• Additional settings
: allows you to configure additional call
settings. For more information, refer to
“Configuring
Additional Voice Call Settings”
on page 257.
• Ringtones and keypad tones
: allows you to manage your
device’s ringtones and vibratory features. Choose from:
Ringtones, Vibrations, Vibrate when ringing, and Dialing keypad
tone
(used when the keypad is pressed).
• Personalize call sound
: allows you to enable the personalize
call sound function within an active call. You can adjust the
audio by enabling selecting an audio preset.
•Noise reduction
: allows you to enable suppression of
background audio.
• Increase volume in pocket
: enables the ringtone volume to be
increased when the device is in a pocket or bag.
• Voicemail service
: allows you to assign the service.
• Voicemail settings
: displays the settings for the voicemail.
•Sound
: assigns your device’s ringtone.
•Vibrate
: configures the vibrate settings.
• TTY mode
: allows you to configure the TTY settings. For more
information, refer to
“TTY Mode”
on page 262.
• Hearing aids
: allows you to enable/disable hearing aid
compatibility. For more information, refer to
“HAC Mode”
on
page 262.
Changing Your Settings 256
Call rejection
1. From the main
Call settings
page, tap
Call rejection
Auto reject mode
and tap one of the following options:
• All numbers
: to reject all calls.
• Auto reject numbers
: to reject all calls in your Reject list.
2. Tap
Auto reject list
.
3. Tap to manually add numbers to the Reject list.
4. Tap
Unknown
to create a check mark and automatically
reject all calls that are not in your Contacts list.
Set reject messages
1. From the main
Call settings
page, tap
Set up call
rejection messages
.
2. Tap to manually add a reject message.
– or –
Tap one of the pre-written messages to be displayed
when you want the call to be rejected. You can edit the
message if desired.
•
Tap
Save
to save the reject message.
Answering/ending calls
1. From the main
Call settings
page, tap
Answering/
ending calls
.
2. Select any of the following options:
• The home key answers calls
allows you to press to
answer the phone.
• Voice control
allows you to answer incoming voice calls using
voice.
• The power key ends calls
allows you to press the power key
to end the current call.
Turn off screen during calls
This option turns on the proximity sensor during calls so that
your phone will know to turn the screen off to save power.
From the main
Call settings
page, tap
Turn off screen
during calls
to create a check mark and enable the
feature.
257
Call alerts
1. From the main
Call settings
page, tap
Call alerts
.
2. Tap
Call vibrations
to enable your phone to vibrate
when the called party answers the phone.
–
Choose from: Answer vibration or Call-end vibration.
3. Tap
Call status tones
to set the sound settings during a
call then tap
OK
.
–
Choose from: Call connect tone, Minute minder, and Call end
tone.
4. Tap
Alerts on calls
to turn off alarm and message
notifications during a call.
Accessory settings for call
1. From the main
Call settings
page, tap
Call accessories
.
2. The following options are available:
• Automatic answering
: configures the device to automatically
answer and incoming call when a headset is detected.
• Automatic answering timer
: configures the time delay before
the device automatically accepts the incoming call.
• Outgoing call conditions
: allows you to make calls even when
the device is locked.
Wi-Fi Calling
Wi-Fi Calling is a free feature for T-Mobile customers using
this device with the new SIM card. Wi-Fi Calling is an
excellent solution for coverage issues in and around the
home or wherever cellular coverage is limited. Minutes used
while connected to the Wi-Fi network count against available
rate plan minutes.
For more information, refer to “Wi-Fi Calling” on page 58.
Configuring Additional Voice Call Settings
1. From the main
Call settings
page, tap
Additional
settings
.
2. Tap one of the following options:
•Caller ID
: chooses whether your number is displayed when
someone answers your outgoing call. Choose from: Network
default, Hide number, or Show number.
• Call forwarding
: configures the forwarding settings.
• Auto area code
: allows you to automatically prepend a specific
area code to all outbound calls.
• Call barring
: blocks specific types of calls (All outgoing calls,
International calls, etc..).
Changing Your Settings 258
• Call waiting
: notifies you of an incoming call while you are on
another call.
• Auto redial
: automatically redial the dialed number if it is
unable to connect or the call is cut off.
• Fixed dialing numbers
: manages fixed dialing numbers.
Configuring Call Forwarding
1. From the main
Call settings
page, tap
Additional
settings
Call forwarding
.
Important!
Call Forwarding is disabled when the Wi-Fi Calling
feature is enabled.
2. Tap an available option:
• Always forward
: incoming calls are re-routed to a secondary
number that you specify.
• Forward when busy
: forwards all your calls to voicemail when
your phone is busy.
• Forward when unanswered
: automatically forwards to your
voicemail number when the phone is not answered, and
otherwise allows you to enter a voicemail number.
• Forward when unreachable
: automatically forwards to your
voicemail number when the phone is not in service, or is turned
off.
Using Auto Area Code
This feature prepends an area code to all outbound calls.
When enabled, the designated prefix is always added before
your dialed numbers.
Ex: If you were using 999 as your area code, 555-5555
would be dialed as 999 - 555-5555.
1. From the main
Call settings
page, tap
Additional
settings
.
2. Tap
Auto area code
, enter a new prefix, and then tap
OK
.
Call Barring
Configures the device to barr (prevent) selected outbound
calls.
1. From the main
Call settings
page, tap
Additional
settings
.
259
2. Tap
Call barring
and select from the available settings.
Choose from: All outgoing calls, International calls, Intl’
calls except home, All incoming calls, or Incoming
when roaming.
Call Waiting
1. From the main
Call settings
page, tap
Additional
settings
.
2. Tap
Call waiting
to enable/disable the on-screen
notification of new incoming call during an active call.
Auto Redial
1. From the main
Call settings
page, tap
Additional
settings
.
2. Tap
Auto redial
to automatically enable/disable the
feature whereby the device redials the dialed number if
it is unable to connect or the call is cut off.
Fixed Dialing Numbers
Fixed Dial Number (FDN), allows you to restrict outgoing calls
to a limited set of phone numbers.
Enabling FDN
1. From the main
Call settings
page, tap
Additional
settings
Fixed dialing numbers
.
2. Tap
Turn on FDN
.
3. At the prompt, enter your PIN2 code and tap
OK
.
Important!
Not all SIM cards use a PIN2 code. If your SIM card
does not, this menu does not display.
The PIN2 code is provided by your carrier. Entering
an incorrect PIN2 code could cause the phone to
lock. Contact customer service for assistance.
Changing the PIN2 Code
1. From the main
Call settings
page, tap
Additional
settings
Fixed dialing numbers
.
2. Tap
Change PIN2
.
3. At the prompt, enter your old PIN2 code.
4. At the prompt, enter a new PIN2 code.
5. Confirm your PIN2 code.
Changing Your Settings 260
Important!
Not all SIM cards use a PIN2 code. If your SIM card
does not, this menu does not display.
The PIN2 code is provided by your carrier. Entering
the PIN2 incorrectly three times will cause the
device to lock. Contact customer service for
assistance.
Managing the FDN List
When this feature is enabled, you can make calls only to
phone numbers stored in the FDN list on the SIM card.
1. From the main
Call settings
page, tap
Additional
settings
Fixed dialing numbers
.
2. Tap
Turn on FDN
.
3. At the prompt, enter your PIN2 code and tap
OK
.
FDN is enabled.
4. Tap
FDN list
then press and then tap
Add contact
or edit the contacts that were stored.
Important!
Not all SIM cards use a PIN2 code. If your SIM card
does not, this menu does not display.
The PIN2 code is provided by your carrier. Entering
the PIN2 incorrectly three times will cause the
device to lock. Contact customer service for
assistance.
Ringtones and keypad tones
1. From the main
Call settings
page, tap
Ringtones and
keypad tones
.
2. Tap
Ringtones
, select a ringtone, and tap
OK
.
•
Tap
Add
to locate an audio file to create as a ringtone.
3. Tap
Vibrations
, select a vibration type, and tap
OK
.
•
Tap
Create
to begin creating your own custom vibration.
4. Tap
Vibrate when ringing
to create a check mark if you
want your phone to vibrate when a call is incoming.
5. Tap
Dialing keypad tones
to create a check mark if you
want tones to play when the keypad is pressed.
261
Personalize call sound
This option allows you to personalize the sounds you hear
during a call with and without earphones.
From the main
Call settings
page, tap
Personalize call
sound
and activate the feature by selecting an available
option.
Noise reduction
This option allows you to suppress background noise during
a call.
From the main
Call settings
page, tap
Noise reduction
to create a check mark and enable the feature.
Increase volume in pocket
This option increases the ringtone volume when the device is
in a pocket or a bag. It uses the proximity sensor to detect its
location.
From the main
Call settings
page, tap
Increase volume
in pocket
to create a check mark and enable the
feature.
Voicemail
You can view your voicemail number from this menu.
1. From the main
Call settings
page, tap
Voicemail service
.
2. If an additional voicemail service is in use (other than
carrier), tap
Voice settings
to now view your selected
voicemail number and information.
Sound - Voicemail Ringtone
This option allows you to assign your default voicemail
notification tone.
1. From the main
Call settings
page, tap
Sound
.
2. Select a voicemail notification tone and tap
OK
.
Vibrate
This option allows you to activate a vibration for an incoming
voicemail.
From the main
Call settings
page, tap
Vibrate
field to toggle
the feature on or off.
Changing Your Settings 262
TTY Mode
A TTY (also known as a TDD or Text Telephone) is a
telecommunications device that allows people who are deaf,
hard of hearing, or who have speech or language disabilities,
to communicate by telephone.
Your device is compatible with select TTY devices. Please
check with the manufacturer of your TTY device to ensure
that it is compatible with digital cell phones.
Your phone and TTY device will connect via a special cable
that plugs into your phone’s headset jack. If this cable was
not provided with your TTY device, contact your TTY device
manufacturer to purchase the connector cable.
1. From the main
Call settings
page, tap
TTY mode
.
2. Tap
TTY Full
,
TTY HCO
,
or
TTY VCO
to activate the
feature, or
TTY Off
to deactivate the feature. Off is the
default setting.
HAC Mode
This menu is used to activate or deactivate Hearing Aid
Compatibility for this device.
From the main
Call settings
page, tap the
Hearing aids
field to activate the feature (green check mark), or tap
it again to deactivate the feature. Off is the default
setting.
Blocking Mode
When Blocking mode is enabled, notifications for selected
features will be disabled. You will only receive notifications of
incoming calls from people on your allowed list.
1. From the Home screen, press and then tap
Settings
(
My device
tab).
2. In a single motion touch and slide the
Blocking mode
slider to the right to turn it on.
Confirm the Blocking mode active icon appears in
the Status bar.
3. Place a green check mark adjacent to those features
you would like to enable. Choose from: Block incoming
calls, Turn off notifications, Turn off alarm and timer,
Turn off LED indicator.
My device
My device
263
4. Configure a timeframe for these features to be active.
Remove the check mark from the
Always
field to
configure the
From
and
To
time fields.
5. Tap
Allowed contacts
to assign those contacts that are
exempted from these rules. Choose from None, All
contacts, Favorites, or Custom. Allowed contacts will
then appear in the
Allowed contact list
.
Hands-free Mode
When enabled, alarm and information will be read aloud.
1. From the Home screen, press and then tap
Settings
(
My device
tab)
Hands-free
mode
.
2. In a single motion touch and slide the
Hands-Free mode
slider to the right to turn it on.
Confirm the Hands-Free mode active icon
appears in the Status bar.
3. Enable any of the following options:
• Incoming call
: read out callers’ information when receiving
incoming calls.
• Message
: read out senders’ information when receiving
incoming calls.
•Alarm
: read out alarm information when alarms sound.
• Schedule
: read out scheduled alarm information when alarms
sound.
Power Saving Mode
This feature allows you both automatically set the phone to
use a power saving mode and configure additional power
saving options manually, all in an effort to conserve battery
power.
1. From the Home screen, press and then tap
Settings
(
My device
tab)
Power saving
mode
.
2. In a single motion touch and slide the slider to the right
to turn it on.
3. Tap the following options to create a check mark and
conserve power:
• CPU power saving
: allows you to limit the maximum
performance of the CPU.
• Screen power saving
: allows you to lower the screen power
level.
My device
My device
My device
My device
Changing Your Settings 264
• Turn off haptic feedback
: allows you to turn off vibration when
you tap or touch the screen.
4. Tap
Learn about Power saving
to learn about various
ways to conserve battery power.
Accessory
This menu allows you to assign external speakers when the
device is docked.
1. From the Home screen, press and then tap
Settings
(
My device
tab)
Accessory
.
2. Tap
Dock sound
to play sounds when inserting or
removing the phone from the dock.
3. Tap
Audio output mode
to use the external dock
speakers when the phone is docked.
4. Tap
Desk home screen display
if you wish to show the
desk home screen when the device is docked.
5. Tap
Audio output
to set your Audio output to Stereo or
Surround.
Accessibility Settings
This service lets you enable and disable downloaded
accessibility applications that aid in navigating your Android
device, such as TalkBack (uses synthesized speech to
describe the results of actions), KickBack (provides haptic
feedback for actions), and SoundBack (plays sounds for
various actions). Also lets you enable use of the power key to
end calls.
1. From the Home screen, press and then tap
Settings
(
My device
tab)
Accessibility
.
Note:
Initially, it might be necessary to download accessibility
applications from the Play Store.
2. Select the
Auto rotate screen
field to activate this
feature which automatically rotates an available
screen.
3. Tap
Screen timeout
to timeout the accessibility feature
after a defined amount of time.
4. Tap
Lock automatically
to lock the screen automatically
after a selected amount of time.
My device
My device
My device
My device
265
Note:
The Lock automatically function is only available if your
device is already using the screen lock feature.
5. Select the
Speak passwords
field to activate this
feature which reads out password information.
6. Select
Answering/ending calls
field to select the
methods you can use to answer and end a call.
7. Tap
Show shortcut
allows you to press and hold
(
Power/End
) to use the accessibility shortcut
under the Device options screen.
8. Tap
TalkBack
to activate the feature.
Note:
TalkBack, when installed and enabled, speaks feedback
to help blind and low-vision users.
Important!
TalkBack can collect all of the text you enter,
except passwords, including personal data and
credit card numbers. It may also log your user
interface interactions with the device.
9. Tap the
Font size
field to change the size of the fonts
used on the device within menus, options, etc..
Choose from: Tiny, Small, Normal, Large, or Huge.
10. Enable
Magnification gestures
to use exaggerated
gestures such as triple-tapping, double pinching, and
dragging two fingers across the screen.
11. Tap the
Negative colors
field to reverse the display of
on-screen colors from White text on a Black
background to Black text on a White background.
12. Tap
Accessibility shortcut
to allow you to quickly enable
accessibility features in 2 quick steps. Touch and slide
the slider to the right to turn it on. Follow the on-screen
instructions.
13. Tap the
Text-to-speech options
field to configure the
text to speech configuration parameters.
14. Use the
Sound balance
field to allow you to use the
slider to set the Left and Right balance when using a
stereo device.
15. Tap the
Mono audio
field to enable stereo audio to be
compressed into a single mono audio stream for use
with a single earbud/earphone.
Changing Your Settings 266
16. Tap the
Turn off all sounds
field to mute every sound
made by the device during taps, selections,
notifications, etc..
17. Tap the
Press and hold delay
field to select a time
interval for this action. Choose from: Short, Medium, or
Long.
Language and Input Settings
This setting allows you to configure the language in which to
display the menus. You can also set on-screen keyboard
options.
From the Home screen, press and then tap
Settings
(
My device
tab)
Language and
input
.
Language Settings
To set the language that the menus display on the phone:
1. From the main
Settings
page, tap
My device
tab
Language and input
Language
.
2. Select a language and region from the list.
Choose Input Method
1. From the main
Settings
page, tap
My device
tab
Language and input
Default
.
2. Select an input method.
– or –
Tap
Select input methods
to alter/modify the available
input methods.
Samsung Keyboard Settings
1. From the main
Settings
page, tap
My device
tab
Language and input
(adjacent to the
Samsung
keyboard
field).
– or –
From within an active text entry screen, touch and hold
(
Input Methods
), drag across the icons, and
select (
Settings
) to reveal the
Samsung keyboard
settings
screen.
2. Set any of the following options:
• Input languages
sets the input language. Tap a language from
the available list. The keyboard is updated to the selected
language.
My device
My device
267
•Predictive text
enables predictive text entry mode. This must
be enabled to gain access to the advanced settings. Touch and
hold to access the advanced settings.
• Auto replacement
automatically completes or replaces the
current word with the most probable word match after tapping
the space bar or entering a punctuation mark.
• Auto capitalization
automatically capitalizes the first letter of
the first word in each sentence (standard English style).
•Auto spacing
automatically inserts space between words.
• Auto punctuate
automatically inserts a full stop in a sentence
by tapping the space bar twice when using the on-screen
QWERTY keyboard.
•Keyboard swipe
: allows you to combine the Samsung
keyboard with an additional input method choose from:
–
None
leaves text input as only via the on-screen keyboard.
–
T9 Trace
like using Swipe, allows you to enter text by sliding
your fingers across the on-screen keyboard. This feature is
optimized for use with the on-screen QWERTY keyboard.
–
Cursor control
when enabled, allows you to control your
on-screen cursor by moving your finger across the keyboard.
• Key-tap feedback
provides feedback functions to be enabled
such as:
–
Sound
enables auditory feedback when you tap an
on-screen key.
–
Vibration
enables vibration feedback when you tap an
on-screen key.
–
Character preview
provides an automatic preview of the
current character selection within the text string. This is helpful
when multiple characters are available within one key.
•More settings
provides access to additional settings.
–
Tutorial
launches a brief on-screen help tutorial covering the
main concepts related to the Samsung keyboard.
• Reset settings
resets the keyboard settings back to their original
configuration.
Changing Your Settings 268
Predictive Text - Advanced Settings
The predictive text system provides next-letter prediction and
regional error correction, which compensates for users
pressing the wrong keys on QWERTY keyboards.
Note:
Only available when ABC mode is selected. Predictive
text advanced settings are available only if the Predictive
function is enabled.
1. From the main
Settings
page, tap
My device
tab
Language and input
(adjacent to the
Samsung
keyboard
field).
– or –
From within an active text entry screen, touch and hold
(
Input Methods
) (
Settings
) to reveal the
Samsung keyboard settings
screen.
2. In a single motion touch and slide the
Predictive text
slider to the right to turn it on.
3. Tap the
Predictive text
field and configure any of the
following advanced options:
• Personalized data
activate this feature to use the personal
language data that you have entered and selected to make
your text entry prediction results better. By enabling this feature
you can choose from the following personalization features:
• Learn from Gmail
: allows you to sign in to your existing Gmail
account from where your style and existing contact information
is added to your personal dictionary. Helps recognize familiar
names.
• Learn from Facebook
allows you to log into your current
Facebook account and add used text to your personal
dictionary.
• Learn from Twitter
allows you to sign into your existing Twitter
account and add used text to your personal dictionary.
• Learn from Messages
allows your device to learn your
messaging style by using your Messages information.
• Learn from Contacts
updates predictive style by learning your
Contacts style.
• Clear personal data
removes all personalized data entered by
the user.
269
4. Press to return to the previous screen.
Swype Settings
To configure Swype settings:
1. From the main
Settings
page, tap
My device
tab
Language and input
(adjacent to the
Swype
field).
2. Tap
Settings
on the left side of the screen to alter these
settings:
• Vibrate on keypress
: activates a vibration sensation as you
enter text using the keypad.
• Sound on keypress
: turns on sounds generated by the Swype
application.
• Pop-up on keypress
: displays the character above the key
when typing.
•Show complete trace
: once enabled, sets wether or not to
display the complete Swype path.
• Auto-capitalization
: automatically capitalizes the first letter of
a sentence.
•Auto-spacing
: automatically inserts a space between words.
When you finish a word, just lift your finger or stylus and start
the next word.
•Next word prediction
: once enabled, predicts the next word in
your text string based on your current text entries.
• Show Voice key
: once enabled, displays the Voice icon on
your Swype keyboard so you can use the Voice input option.
3. Tap
My Words
on the left side of the screen to access
the following options:
• Backup & Sync
: allows you to backup your Swype dictionary
and sync your Swype dictionary across multiple devices.
• Living Language
: when enabled, this feature automatically
updates your Swype dictionary with popular new words.
• Social integration
: allows you to learn information from your
Facebook, Twitter, and Gmail accounts to help you while using
Swype.
• Edit my dictionary
: allows you to edit your personal Swype
dictionary.
• Clear language data
: deletes all of your personal language
data, including your words.
• Contribute usage data
: when enabled, allows the Nuance
®
application to collect usage data for better word predictions.
Changing Your Settings 270
• Cellular data
: when enabled, activates cellular data usage by
the Swype application so it can receive program updates,
language downloads, and other related features via your
existing data connection.
4. Tap
Languages
on the left side of the screen to activate
and select the current text input language. Default
language is English. Touch
Download languages
, to
download additional languages.
5. Tap
Gestures
on the left side of the screen to view
helpful information on using gestures while using
Swype.
6. Tap
Help
on the left side of the screen to see the
following options:
•How to Swype
: provides tips on how to learn to use Swype.
• Show helpful tips
: once enabled, displays helpful tips and
hints as you are using Swype.
•Version
: displays the software version information.
7. Tap
Updates
on the left side of the screen to download
any new Swype updates. If an update is available, it
will display under the updates heading. If no updates
are displayed, then check back later to see any
available updates.
Configure Google Voice Typing
1. From the main
Settings
page, tap
My device
tab
Language and input
.
– or –
From a screen where you can enter text, in a single
motion, touch and drag the Status bar down to the
bottom of the screen, then select (
Select input
method
)
Set up input methods
.
2. Tap (adjacent to the
Google voice typing
field).
3. Select a language by tapping
Choose input languages
area.
4. Remove the check mark from the
Automatic
field. This
allows you to select additional languages.
5. Select the desired languages.
271
6. Activate
Block offensive words
to block recognition of
known offensive words or language. (A blue check
mark indicates the feature is active).
7. Tap
Offline speech recognition
to enable speech
recognition via locally stored files so that even if you
are not connected to a network you can still use the
service.
Configuring Voice Input Recognition
This feature allows the device to correctly recognize verbal
input.
1. From the main
Settings
page, tap
My device
tab
Language and input.
2. Tap
Voice search
to configure the following:
• Language
: choose a language for your voice input.
• Speech output
: Sets whether you will use speech output
always or only when using hands-free.
• Block offensive words
: enable or disable blocking of
recognized offensive words from the results of your voice-input
Google searches.
• Hotword detection
: enable to being able to launch voice
search by saying the word “Google”.
• Offline speech recognition
: enables voice input while offline.
• Bluetooth headset
: records audio through a connected
Bluetooth headset.
3. Press to return to the previous screen.
Configuring Text-to-speech
This feature allows the device to provide a verbal readout of
on-screen data such as messages and incoming caller
information. This action is called TTS (Text To Speech).
1. From the main
Settings
page, tap
My device
tab
Language and input
Text-to-speech options
.
2. Select a current Preferred TTS engine from the list of
available options. Select
Samsung text-to-speech
engine
or
Google Text-to-speech Engine
.
Changing Your Settings 272
3. Tap next to the preferred TTS engine configure
the following settings:
• Language
: allows you to set the language for spoken text.
• Settings for Google Text-to-speech Engine
: allows you to
view Open Source Licenses.
• Settings for Samsung text-to-speech engine
: allows you to
configure the General settings for the Samsung TTS.
• Install voice data
: allows you to install voice data for speech
synthesis.
4. Configure the General options to alter the settings
associated with this feature:
• Speech rate
: adjusts the rate at which on-screen text is
spoken by the device.
• Listen to an example
: plays a short example of what the text-
to-speech feature sounds like on your device when activated.
Configuring the Mouse-TrackPad
This feature allows you to configure the pointer speed for a
connected mouse or trackpad.
1. From the main
Settings
page, tap
My device
tab
Language and input
Pointer speed
.
2. Adjust the slider and tap
OK
.
Motion Settings
This feature allows you to assign specific functions to certain
phone actions that are detected by both the accelerometer
and gyroscope.
Caution!
Excessive shaking or impact to the device may cause
unintended results. To learn how to properly control
motions, tap (
Apps
)
Settings
My device
tab
Motion
. When tapped, each entry comes with an
on-screen tutorial.
To activate motion:
1. From the Home screen, press and then tap
Settings
(
My device
tab)
Motion
.
2. In a single motion touch and slide the
Motion
slider to
the right to turn it on.
Note:
If Motion activation is not enabled, all motion services
are greyed-out and disabled.
My device
My device
273
To activate different motion functions:
Tap the
Motion activation
field and activate the desired
on-screen motion option.
•Direct call
: Once enabled, the device will dial the currently
displayed on-screen Contact entry as soon as you place the
device to your ear.
•Smart alert
: Once enabled, pickup the device to be alerted and
notified of you have missed any calls or messages.
• Double tap to top
: Once enabled, double tap the top of the
device to be taken to the top of the current on-screen list.
• Tilt to zoom
: Once enabled, you must be on a screen where
content can be zoomed. In a single motion, touch and hold two
points on the display then tilt the device back and forth to zoom
in or out.
• Pan to move icon
: Once enabled, touch and hold a desired
application shortcut icon or widget on the screen. Once it
detaches, move the device left or right to migrate it to a new
location.
• Pan to browse images
: Once enabled, touch and hold a
desired on-screen image to pan around it. Move the device left
or right to pan vertically or up and down to pan horizontally
around the large on-screen image.
• Shake to update
: Once enabled, shake your device to rescan
for Bluetooth devices, rescan for Wi-Fi devices, Refresh a Web
page, etc.
• Turn over to mute/pause
: Once enabled, mute incoming calls
and any playing sounds by turning the device over display down
on a surface. This is the opposite of the pickup to be notified
gesture.
• Palm swipe to capture
: Once enabled, you can capture any
on-screen information swiping across the screen. In a single
motion, press the side of your hand on the screen and swipe
form left to right. The image is then copied to the clipboard.
• Palm touch to mute/pause
: Once enabled, you can pause any
on-screen video or mute any current sound by simply covering
the screen with your hand. Once you remove your hand from
the screen, the device goes back to normal by either continuing
to play the current video or unmuting the current sound.
Changing Your Settings 274
To adjust gesture sensitivity:
1. From the Home screen, press and then tap
Settings
My device
tab
Motion
Sensitivity
settings
.
2. Tap an available field to access the sensitivity settings
for the currently active gesture. Choose from:
• Tilt to zoom
: Allows you to zoom in or out when in the Gallery
or Internet.
• Pan to move icon
: Allows you to move an icon to another
page.
• Pan to browse images
: Allows you to move around an image
when zoomed in.
Note:
Sensitivity settings are only accessible if the gesture is
currently active.
Smart screen
The Smart screen options allow you to customize your
screen settings to make the screen more responsive and
easier to use.
1. From the Home screen, press and then tap
Settings
(
My device
tab)
Smart screen
.
2. Tap any of the following options to create a checkmark
and activate the features:
•Smart stay
: disables the screen timeout if your phone detects
that your face is watching the screen.
• Smart rotation
: disables the auto screen rotation by checking
the orientation of your face and the device.
My device
My device
275
Voice control
The Voice control settings allow you to set up voice
commands to control your device.
1. From the Home screen, press and then tap
Settings
(
My device
tab)
Voice control
.
2. Verify the feature is active by tapping at the
top of your screen to activate Voice control.
3. The following options are available. Tap an option to
create a checkmark and activate the feature.
• Incoming calls
: allows you to answer or reject calls using the
commands
Answer
and
Reject
.
•Alarm
: allows you to stop or snooze an alarm by using the
commands
Stop
and
Snooze
.
•Camera
: allows you to take pictures using the voice
commands
Smile
,
Cheese
,
Capture
, or
Shoot
.
•Music
: allows you to control your Music player using the voice
commands
Next
,
Previous
,
Pause
,
Play
,
Volume Up
, and
Volume Down
.
Note:
If you set the alert type for calls or alarms to vibration,
voice control will not be available.
Add Account
This menu allows you to set up, manage, and synchronize
accounts, including your Google and email accounts.
Adding an Account
1. From the Home screen, press and then tap
Settings
(
Accounts
tab).
2. Navigate to the
My accounts
area and then tap
Add
account
and select one of the account types.
3. Use the keyboard and follow the prompts to enter your
credentials and set up the account.
4. A green circle will appear next to the account type once
you have created an account. Your email account will
also be displayed in the
Accounts
section of the main
Settings menu.
My device
My device
ON
ON
Changing Your Settings 276
Removing an Account
Important!
Removing an account also deletes all of its
messages, contacts, and other data from the
device.
1. From the main
Settings
page, tap
Accounts
tab.
2. Navigate to the
My accounts
area and then tap the
account name.
3. From the Accounts area of the screen, tap the account
entry.
4. Tap
Remove account
, then tap
Remove
account
at the
prompt to remove the account and delete all its
messages, contacts, and other data.
Synchronizing a Accounts
By default, all managed accounts are synchronized. You can
also manually sync all current accounts.
1. From the main
Settings
page, tap
Accounts
tab.
2. Navigate to the
My accounts
area and then tap the
account name.
3. Tap the account name entry.
4. Tap
Sync now
to synchronize your account or tap
Sync
all
to synchronize all your accounts. Tap
Cancel sync
to
stop the synchronization.
5. Tap
Settings
to access your account settings.
Creating a Samsung Account
Just as important as setting up and activating a Google
account to help provide access to Play Store, etc.. An active
Samsung account is required to begin accessing applications
such as Samsung Hub.
Note:
The Samsung account application will manage your
access to the previously mentioned applications, and
there is no longer a need to remember different
passwords for each application.
277
1. From the main
Settings
page, tap
Accounts
tab.
2. Navigate to the
My accounts
area
and then tap
Add account
Samsung account
.
3. If you have previously created a Samsung account, tap
Sign in
.
– or –
If this is your first time, tap
Create new account
.
4. Follow the on-screen instructions.
Note:
You may be prompted to confirm your credentials via
email.
5. If prompted, follow the on-screen instructions to verify
your account via the provided email address.
Note:
Without confirming your email address and following the
documented procedures, related applications will not
function properly since it is Samsung account that is
managing their username and password access.
Back up and Reset
Location settings, backup configurations, or reset the phone
to erase all personal data.
From the Home screen, press and then tap
Settings
(
Accounts
tab)
Backup and
reset
.
Mobile Backup and Restore
The device can be configured to back up your current
settings, application data and settings.
1. From the main
Settings
page, tap
Accounts
tab
Backup and reset
.
2. Tap
Back up my data
to create a backup of your current
phone settings and applications.
3. Tap
Backup account
to assign the account being
backed up.
4. Tap
Automatic restore
to assist in the re-installation of
a previously installed application (including
preferences and data).
Changing Your Settings 278
5. Tap
Factory data reset
to reset your device and sound
settings to the factory default settings. For more
information, refer to “Factory Data Reset” on page
278.
6. Tap
Collect diagnostics
to collects diagnostic data for
troubleshooting use. For more information, refer to
“Collect Diagnostics” on page 279.
Prior to doing a Factory Reset
Before initiating a factory reset, it is recommended that you
backup your personal data prior to use.
To export a Contact list to your microSD card:
1. From the Home screen, tap (
Contacts
).
2. Press and then tap
Import/Export
.
3. Tap
Export to SD card
OK
. For more information,
refer to “Export/Import” on page 97.
Verify your images and videos are on your microSD card:
1. From the Home screen, tap (
Apps
)
(
Gallery
).
2. Verify the Gallery contains all of your pictures and
videos.
3. Remove both the back cover and remove the internal
microSD card prior to initiating the process.
Factory Data Reset
From this menu you can reset your device and sound settings
to the factory default settings.
1. From the Home screen, press and then tap
Settings
(
Accounts
tab)
Backup and
reset
Factory data reset
.
2. Read the on-screen reset information.
3. Tap
Reset
device.
4. If necessary, enter your password and tap
Delete all
.
The device resets to the factory default settings
automatically and when finished displays the Home
screen.
279
Collect Diagnostics
This feature only collects diagnostic data for troubleshooting
use.
1. From the main
Settings
page, tap
Accounts
tab
Backup and reset
Collect diagnostics.
2. Read the on-screen System Manager Application
information.
Note:
This software collects only diagnostic data from your
device so that T-Mobile technicians can better
troubleshoot issues with your device.
3. Choose to enable or disable the feature by placing a
check mark in the
Allow Diagnostics
field.
4. Select either
More info
(to read additional information)
or
Close
to close the message screen.
Important!
Selecting
Close
only closes the current description
scree and does not disable data collection.
To disable data collection, go to
Settings
Back
up and reset
Collect diagnostics
and turn off the
Allow Diagnostics
feature.
Location Services
The Location services allows you to configure the device’s
location services.
Important!
The more location determining functions are
enabled, the more accurate the determination will
be of your position.
1. From the Home screen, press and then tap
Settings
(
More
tab)
Location services
.
2. Tap any of the following options to create a checkmark
and activate the service:
• Access to my location
: allows apps that have asked your
permission to use your location information. Tap the ON/OFF
slider to turn it on.
• Use GPS satellites
: allows applications to use GPS to pinpoint
your location.
• Use wireless networks
: allows applications to use data from
mobile networks and Wi-Fi to help determine your location.
Changing Your Settings 280
Enabling the GPS Satellites
1. From the main
Settings
page, tap
More
tab
Location
services
.
2. Tap
Use GPS satellites
to enable the GPS satellite.
Using Wireless Networks
Before you use applications such as Google Maps and find
your location or search for places of interest, you must
enable the Use wireless networks option.
1. From the main
Settings
page, tap
More
tab
Location
services
.
2. Tap
Use wireless networks
to allow apps to use data
from sources such as Wi-Fi and mobile networks to
provide a better approximation of your current location.
Security
The Security settings allow you to determine the security
level for your device.
Encrypt Device
When enabled, this feature requires a numeric PIN or
password to decrypt your device each time you power it on
or encrypt the data on your SD card each time it is
connected:
1. From the Home screen, press and then tap
Settings
(
More
tab)
Security
.
2. Tap
Encrypt device
. For more information, read the
displayed help screen.
3. Tap
Encrypt external SD card
to enable the encryption
on SD card data that requires a password be entered
each time the microSD card is connected.
Tip:
Make sure your battery is charged more than 80 percent.
Encryption may take an hour or more.
281
Setting up SIM Card Lock
Prevent another user from using your SIM card to make
unauthorized calls or from accessing information stored on
your SIM card by protecting the information using a PIN code.
When enabled, your phone will ask for a PIN number each
time you use the phone. Using this option you can also
change your SIM PIN number.
1. From the main
Settings
page, tap
More
tab
Security
.
2. Tap
Set up SIM card lock
.
3. Tap
Lock SIM card
, enter your SIM PIN code, then tap
OK
.
Note:
You must activate Lock SIM card before you can change
your SIM PIN code.
To change an existing SIM Card PIN:
1. Tap
Change SIM PIN
.
2. Enter the old SIM PIN code and tap
OK
.
3. Enter the new SIM PIN code and tap
OK
.
4. Re-type the new SIM PIN code and tap
OK
.
Password Settings
When you create a phone password you can also configure
the phone to display the password as you type it instead of
using an asterisk (*).
1. From the main
Settings
page, tap
More
tab
Security
.
2. Tap
Make passwords visible
to activate this feature.
Device Administration
Activating this feature allows Google to administrate your
phone in a way similar to IT security settings on a corporate
PC. This would be beneficial in the case that your phone was
lost or stolen. The phone could be “deactivated” or
“restricted” (through administration) from a remote location.
1. From the main
Settings
page, tap
More
tab
Security
.
2. Tap
Device administrators
to begin configuring this
setting.
3. Select an administrator device and follow the prompts.
Changing Your Settings 282
Unknown Sources
Before you can download a web application you must enable
the Unknown sources feature (enables downloading).
Developers can use this option to install non-Play Store
applications.
1. From the main
Settings
page, tap
More
tab
Security
.
2. Tap
Unknown sources
to active this feature.
Verify Apps
Allows you to block or warn yourself before installing apps
that can cause harm.
1. From the main
Settings
page, tap
More
tab
Security
.
2. Tap
Verify apps
to active this feature.
Note:
Enabling this feature can prevent installation of some
applications from the Play Store.
Change Security Level
Allows you to change the current security level so that
threats that meet the selected criteria are blocked.
1. From the main
Settings
page, tap
More
tab
Security
.
2. Tap
Change security level
and select an available
option:
•High
: blocks all unauthenticated actions
•Normal
: blocks explicit threats.
Security Update Service
These options allow you to configure the way in which the
device checks for changes in available security policies and
the method used for the update.
1. From the main
Settings
page, tap
More
tab
Security
.
2. Tap
Auto update security
to automatically check for
changes to the security policy and then download any
updates automatically in order to improve security and
service.
3. Tap
Via Wi-Fi only
to only update the security policy
automatically once the device is connected to an active
Wi-Fi network.
283
Credential Storage
This option allows certain applications to access secure
certificates and other credentials. Certificates and
credentials can be installed to the SD card and password
protected.
1. From the main
Settings
page, tap
More
tab
Security
.
2. Tap
Storage type
to designate the backup storage
location for certificates.
3. Tap
Trusted credentials
to display only trusted CA
certificates. A check mark displayed next to the feature
indicates secure credentials.
4. Tap
Install from device storage
to install encrypted
certificates from the USB Storage location.
5. Tap
Clear credentials
to clear the device (SD card or
phone memory) of all certificate contents and reset the
credentials password.
Application Manager
This device can be used for Android development. You can
write applications in the SDK and install them on this device,
then run the applications using the hardware, system, and
network. This feature allows you to configure the device for
development.
Warning!
Because the device can be configured with system
software not provided by or supported by Google or
any other company, end-users operate these devices
at their own risk.
This menu allows you to manage installed applications. You
can view and control currently running services, or use the
device for application development.
You can also view the amount of memory or resources used
as well as the remaining memory and resources for each of
the applications on your phone and clear the data, cache, or
defaults.
From the Home screen, press and then tap
Settings
(
More
tab)
Application manager
ALL
.
Changing Your Settings 284
Clearing Application Cache and Data
Important!
You must have downloaded applications installed
to use this feature.
1. From the main
Settings
page, tap
More
tab
Application manager
.
2. Tap an application in which to clear the cache or data.
3. Tap
Force stop
,
Uninstall, Turn off, Clear data
,
Clear
cache
, or
Clear defaults
.
Uninstalling Third-party Applications
Important!
You must have downloaded applications installed
to use this feature.
1. From the main
Settings
page, tap
More
tab
Application manager
.
2. Tap the
DOWNLOADED
tab and select your desired
application.
3. Tap
Uninstall
(from within the top area of the
Application info page).
4. At the prompt, tap
OK
to uninstall the application.
5. Select a reason for uninstalling the application, then
tap
OK
.
Memory Usage
See how memory is being used by Downloaded or Running
applications.
1. From the main
Settings
page, tap
More
tab
Applications manager
.
2. Tap
DOWNLOADED
,
SD CARD
,
RUNNING
, or
ALL
to
display memory usage for that category of
applications.
The graph at the bottom of the Downloaded tab shows
used and free device memory. The graph at the bottom
of the Running tab shows used and free RAM.
Downloaded
Displays apps you have downloaded onto your device.
1. From the main
Settings
page, tap
More
tab
Applications manager
.
2. Tap the
DOWNLOADED
tab to view a list of all the
downloaded applications on your device.
285
3. To switch the order of the lists displayed in the
Downloaded tabs, press and select
Sort by size
or
Sort by name
.
4. Tap an application to view and update information
about the application, including memory usage, default
settings, and permissions.
Running Services
The Running services option allows you to view and control
currently running services such as Backup, Google Talk, SNS
(messaging), Swype, and more.
1. From the main
Settings
page, tap
More
tab
Application manager
.
2. Tap the
RUNNING
tab to view all currently active and
running applications. This tab also shows the total RAM
being used by these currently active applications.
3. Tap a process and select
Stop
to end the process and
stop it from running. When you stop the process the
service or application will no longer run until you start
the process or application again.
4. Tap
Show cached processes
to view additional cached
applications.
Important!
Stopping a process might have undesirable
consequences on the application.
Storage Used
This option allows you to view a list (on the current tab) of
current applications as sorted by size.
1. From the main
Settings
page, tap
More
tab
Application manager
.
2. Tap the
ALL
tab to display all available applications.
3. Press and then tap
Sort by size
to change the
current list to show items based on the amount of
storage they occupy.
Reset App Preferences
This feature provides you with the ability to reset all
preferences for the following features: Disabled apps,
Disabled app notifications, Default applications for actions,
and Background data restrictions.
1. From the main
Settings
page, tap
More
tab
Applications manager
.
2. Tap the
ALL
tab to display all available applications.
Changing Your Settings 286
3. Press and then tap
Reset app preferences
Reset apps
.
Important!
As an example, if you assigned your browser to
always launch YouTube links and want that
changed, you must reset the default actions.
Battery Usage
This option allows you to view a list of those components
using battery power. The amount of time the battery was
used also displays. Battery usage displays in percentages
per application.
1. From the Home screen, press and then tap
Settings
(
More
tab)
Battery
. The battery
level displays in percentage.
2. From the upper-right tap (
Refresh
) to update the
list.
– or –
Tap an entry to view more detailed information.
Note:
Other applications may be running that affect battery
use.
SD Card & Device Storage
From this menu you can view the memory allocation for the
memory card as well as mount or unmount the SD card.
To view the memory allocation for your external SD card:
From the Home screen, press and then tap
Settings
(
More
tab)
Storage
.
The available memory displays under the Total space
and SD card headings.
Important! DO NOT
remove a microSD card while the device is
accessing or transferring files. Doing so will result
in loss or damage of data. Make sure your battery
is fully charged before using the microSD card.
Your data may become damaged or lost if the
battery runs out while you are using the microSD
card.
287
Mounting the SD Card
To store photos, music, videos, and other applications. You
must mount (install) the SD card prior to use. Mounting the
SD card establishes a USB connection with your computer.
1. From the main
Settings
page, tap
More
tab
Storage
.
2. Tap
Mount
SD card
.
Unmounting the SD card
Unmounting the SD card prevents corruption and damage to
the SD card while removing it from the slot.
1. From the main
Settings
page, tap
More
tab
Storage
.
2. Tap
Unmount
SD card
OK
.
3. After the “
SD card will be unmounted
” message
displays and the
Mount SD card
now appears in the
menu list, remove the SD card.
Erasing Files from the SD card
To erase files from the SD card using the device:
1. Ensure the SD card is mounted.
2. From the main
Settings
page, tap
More
tab
Storage
Mount SD card
.
3. Tap
Format SD card
Format SD card
Delete all
to
format the SD card. The SD card formats and erases all
the data stored on it.
Changing Your Settings 288
Date and Time
This menu allows you to change the current time and date
displayed.
1. From the Home screen, press and then tap
Settings
(
More
tab)
Date and time
.
2. Tap
Automatic date and time
to allow the network set
the date and time.
Important!
Deactivate
Automatic date and time
to manually set
the rest of the options.
3. Tap
Set date
and use the arrow icons to set the
Month
,
Day
, and
Year
then tap
Set
.
4. Tap
Set time
and use the arrow icons, set
Hour
, and
Minute
and then tap
Set
.
5. Tap
Automatic time zone
to allow the network set the
time zone information automatically.
6. Tap
Select time zone
, then tap a time zone.
7. Tap
Use 24-hour format
. If this is not selected the device
automatically uses a 12-hour format.
8. Tap
Select date format
and select the date format type.
About Device
This menu contains legal information, system tutorial
information, and other phone information such as the model
number, firmware version, baseband version, kernel version,
and software build number.
To access phone information:
From the Home screen, press and then tap
Settings
(
More
tab)
About device
. The
following information displays:
• Software update
: allows you to connect to the network and
upload any new phone software directly to your device. The
device automatically updates with the latest available software
when you access this option.
•Status
: displays the battery status, the level of the battery
(percentage), the Network connection, Signal strength, Mobile
network type, Service state, Roaming status, Mobile network
state, My phone number, IMEI number, IMEISV, IP address,
Wi-Fi MAC address, Bluetooth address, Serial number, Up
time, and Device status.
289
• Legal information
: This option displays information about
Open source licenses, License settings, as well as Google legal
information. This information clearly provides copyright and
distribution legal information and facts as well as Google Terms
of Service, Terms of Service for Android-powered Phones, and
much more pertinent information as a reference.
Read the information and terms, then press to return to
the Settings menu.
Tip:
To find your device’s DivX® registration code and
information about registering your device to play DivX
protected video, tap
License settings
DivX® VOD
.
• Device name
: allows you to both display and edit the device’s
name.
• Model number
: displays the device’s model number.
• Android version
: displays the firmware version loaded on this
device.
•Baseband version
: displays the baseband version loaded on
this device.
•Kernel version
: displays the kernel version loaded on this
device.
• Build number
: displays the software, build number.
Note:
Firmware, baseband, kernel and build numbers are
usually used for updates to the handset or support. For
additional information please contact your T-Mobile
service representative.
• SE for Android status
: displays the Android SE status.
Software Update
The Software Update feature enables you to use your device
to connect to the network and upload any new software
directly to your device. The device automatically updates
with the latest available software when you access this
option.
The following icons show your Bluetooth connection status
at a glance:
Displays when the Software updated feature is
active.
Displays when the Software update feature is in
progress.
Changing Your Settings 290
To update your device:
1. From the Home screen, press and then tap
Settings
(
More
tab)
About device
Software update
.
2. Read the Software update information screen.
3. Select an available option:
Note:
You configure the device’s software update parameters.
•Cancel
: Tap this option to cancel the operation.
• Wi-Fi settings
: Enable this option to only download available
updates via an active Wi-Fi connection. If disabled, the device
will begin available downloads via its’ T-Mobile connection.
•OK
: Tap this option to connect to the remote server, detect if
there is an available update, the begin the download over your
existing data connection.
•
Software updates can include bug fixes, enhancements to
services, to the device or currently installed software.
291
Section 11: Health and Safety Information
This device is capable of operating in Wi-Fi
™
mode in the
2.4 and 5 GHz bands. The FCC requires that devices
operating within 5.15-5.25 GHz may only be used indoors,
not outside, in order to avoid interference with Mobile
Satellite Services (MSS). Therefore, this device is restricted
from being used outdoors when operating in frequencies
between 5.15-5.25 GHz.
This section outlines the safety precautions associated with
using your phone. The terms “mobile device” or “cell phone”
are used in this section to refer to your phone.
Read this
information before using your mobile device
.
Exposure to Radio Frequency (RF)
Signals
The U.S. Food and Drug Administration (FDA) has published
information for consumers relating to Radio Frequency (RF)
exposure from wireless phones. The FDA publication
includes the following information:
Do cell phones pose a health hazard?
Many people are concerned that cell phone radiation will
cause cancer or other serious health hazards. The weight of
scientific evidence has not linked cell phones with any health
problems.
Cell phones emit low levels of Radio Frequency (RF) energy.
Over the past 15 years, scientists have conducted hundreds
of studies looking at the biological effects of the radio
frequency energy emitted by cell phones. While some
researchers have reported biological changes associated
with RF energy, these studies have failed to be replicated.
The majority of studies published have failed to show an
association between exposure to radio frequency from a cell
phone and health problems.
The low levels of RF cell phones emit while in use are in the
microwave frequency range. They also emit RF at
substantially reduced time intervals when in the stand-by
mode. Whereas high levels of RF can produce health effects
(by heating tissue), exposure to low level RF that does not
produce heating effects causes no known adverse health
effects.
Health and Safety Information 292
The biological effects of radio frequency energy should not
be confused with the effects from other types of
electromagnetic energy.
Very high levels of electromagnetic energy, such as is found
in X-rays and gamma rays, can ionize biological tissues.
Ionization is a process where electrons are stripped away
from their normal locations in atoms and molecules. It can
permanently damage biological tissues including DNA, the
genetic material.
The energy levels associated with radio frequency energy,
including both radio waves and microwaves, are not great
enough to cause ionization of atoms and molecules.
Therefore, RF energy is a type of non-ionizing radiation.
Other types of non-ionizing radiation include visible light,
infrared radiation (heat), and other forms of electromagnetic
radiation with relatively low frequencies.
While RF energy does not ionize particles, large amounts can
increase body temperatures and cause tissue damage. Two
areas of the body, the eyes and the testes, are particularly
vulnerable to RF heating because there is relatively little
blood flow in them to carry away excess heat.
Research Results to Date: Is there a connection
between RF and certain health problems?
The results of most studies conducted to date say no. In
addition, attempts to replicate and confirm the few studies
that have shown a connection have failed.
The scientific community at large therefore believes that the
weight of scientific evidence does not show an association
between exposure to Radio Frequency (RF) from cell phones
and adverse health outcomes. Still the scientific community
has supported additional research to address gaps in
knowledge. Some of these studies are described below.
Interphone Study
Interphone is a large international study designed to
determine whether cell phones increase the risk of head and
neck cancer. A report published in the International Journal
of Epidemiology (June, 2010) compared cell phone usage for
more than 5,000 people with brain tumors (glioma and
meningioma) and a similar number of healthy controls.
Results of this study did NOT show that cell phones caused
brain cancer. In this study, most people had no increased risk
of brain cancer from using cell phones. For people with the
heaviest use of cell phones (an average of more than ½ hour
per day, every day, for over 10 years) the study suggested a
293
slight increase in brain cancer. However, the authors
determined that biases and errors prevented any conclusions
being drawn from this data. Additional information about
Interphone can be found at
http://www.iarc.fr/en/media-centre/pr/2010/pdfs/pr200_E.pdf.
Interphone is the largest cell phone study to date, but it did
not answer all questions about cell phone safety. Additional
research is being conducted around the world, and the FDA
continues to monitor developments in this field.
International Cohort Study on Mobile Phone Users
(COSMOS)
The COSMOS study aims to conduct long-term health
monitoring of a large group of people to determine if there
are any health issues linked to long-term exposure to radio
frequency energy from cell phone use. The COSMOS study
will follow approximately 300,000 adult cell phone users in
Europe for 20 to 30 years. Additional information about the
COSMOS study can be found at
http://www.ukcosmos.org/index.html
.
Risk of Brain Cancer from Exposure to Radio
Frequency Fields in Childhood and Adolescence
(MOBI-KIDS)
MOBI-KIDS is an international study investigating the
relationship between exposure to radio frequency energy
from communication technologies including cell phones and
brain cancer in young people. This is an international
multi-center study involving 14 European and non-European
countries. Additional information about MOBI-KIDS can be
found at
http://www.creal.cat/programes-recerca/en_projectes-creal/
view.php?ID=39.
Surveillance, Epidemiology, and End Results (SEER)
Program of the National Cancer Institute
The National Cancer Institute (NCI) actively follows cancer
statistics in the United States to detect any change in rates of
new cases for brain cancer. If cell phones play a role in risk
for brain cancer, rates should go up, because heavy cell
phone use has been common for quite some time in the U.S.
Between 1987 and 2005, the overall age-adjusted incidence
of brain cancer did not increase. Additional information about
SEER can be found at
http://seer.cancer.gov/
.
Health and Safety Information 294
Cell Phone Industry Actions
Although the existing scientific data do not justify FDA
regulatory actions, the FDA has urged the cell phone industry
to take a number of steps, including the following:
•
Support-needed research on possible biological effects of RF
for the type of signal emitted by cell phones;
•
Design cell phones in a way that minimizes any RF exposure to
the user; and
•
Cooperate in providing users of cell phones with the current
information on cell phone use and human health concerns.
The FDA also is working with voluntary standard-setting
bodies such as the Institute of Electrical and Electronics
Engineers (IEEE), the International Commission on
Non-Ionizing Radiation Protection (ICNIRP), and others to
assure that safety standards continue to adequately protect
the public.
Reducing Exposure: Hands-Free Kits and Other
Accessories
Steps to Reduce Exposure to Radio Frequency Energy
If there is a risk from being exposed to radio frequency
energy (RF) from cell phones - and at this point we do not
know that there is - it is probably very small. But, if you are
concerned about avoiding even potential risks, you can take
a few simple steps to minimize your RF exposure.
•
Reduce the amount of time spent using your cell phone;
•
Use speaker mode or a headset to place more distance between
your head and the cell phone.
Hands-Free Kits
Hands-free kits may include audio or Bluetooth® headsets
and various types of body-worn accessories such as
belt-clips and holsters. Combinations of these can be used to
reduce RF energy absorption from cell phones.
Headsets can substantially reduce exposure because the
phone is held away from the head in the user's hand or in
approved body-worn accessories. Cell phones marketed in
the U.S. are required to meet RF exposure compliance
requirements when used against the head and against the
body.
295
Because there are no known risks from exposure to RF
emissions from cell phones, there is no reason to believe that
hands-free kits reduce risks. Hands-free kits can be used for
convenience and comfort. They are also required by law in
many states if you want to use your phone while driving.
Cell Phone Accessories that Claim to Shield the Head
from RF Radiation
Because there are no known risks from exposure to RF
emissions from cell phones, there is no reason to believe that
accessories which claim to shield the head from those
emissions reduce risks. Some products that claim to shield
the user from RF absorption use special phone cases, while
others involve nothing more than a metallic accessory
attached to the phone.
Studies have shown that these products generally do not
work as advertised. Unlike “hands-free” kits, these so-called
“shields” may interfere with proper operation of the phone.
The phone may be forced to boost its power to compensate,
leading to an increase in RF absorption.
Children and Cell Phones
The scientific evidence does not show a danger to any users
of cell phones from RF exposure, including children and
teenagers. The steps adults can take to reduce RF exposure
apply to children and teenagers as well.
•
Reduce the amount of time spent on the cell phone;
•
Use speaker mode or a headset to place more distance between
the head and the cell phone.
Some groups sponsored by other national governments have
advised that children be discouraged from using cell phones
at all. For example, The Stewart Report from the United
Kingdom made such a recommendation in December 2000.
In this report, a group of independent experts noted that no
evidence exists that using a cell phone causes brain tumors
or other ill effects. Their recommendation to limit cell phone
use by children was strictly precautionary; it was not based
on scientific evidence that any health hazard exists.
Additional information on the safety of RF exposures from
various sources can be obtained from the following
organizations (updated 10/1/2010):
•
FCC RF Safety Program:
http://www.fcc.gov/oet/rfsafety/.
Health and Safety Information 296
•
Environmental Protection Agency (EPA):
http://www.epa.gov/radtown/wireless-tech.html.
•
Occupational Safety and Health Administration (OSHA):
http://www.osha.gov/SLTC/radiofrequencyradiation/
.
(Note: This web address is case sensitive.)
•
National Institute for Occupational Safety and Health (NIOSH):
http://www.cdc.gov/niosh/.
•
World Health Organization (WHO):
http://www.who.int/peh-emf/en/.
•
International Commission on Non-Ionizing Radiation Protection:
http://www.icnirp.de.
•
Health Protection Agency:
http://www.hpa.org.uk/Topics/Radiation/.
•
US Food and Drug Administration:
http://www.fda.gov/Radiation-EmittingProducts/
RadiationEmittingProductsandProcedures/
HomeBusinessandEntertainment/CellPhones/default.htm.
Specific Absorption Rate (SAR)
Certification Information
Your wireless phone is a radio transmitter and receiver. It is
designed and manufactured not to exceed the exposure
limits for Radio Frequency (RF) energy set by the Federal
Communications Commission (FCC) of the U.S. Government.
These FCC RF exposure limits are derived from the
recommendations of two expert organizations: the National
Council on Radiation Protection and Measurement (NCRP)
and the Institute of Electrical and Electronics Engineers
(IEEE). In both cases, the recommendations were developed
by scientific and engineering experts drawn from industry,
government, and academia after extensive reviews of the
scientific literature related to the biological effects of RF
energy.
The RF exposure limit set by the FCC for wireless mobile
phones employs a unit of measurement known as the
Specific Absorption Rate (SAR). The SAR is a measure of the
rate of absorption of RF energy by the human body
expressed in units of watts per kilogram (W/kg). The FCC
requires wireless phones to comply with a safety limit of 1.6
watts per kilogram (1.6 W/kg).
297
The FCC SAR limit incorporates a substantial margin of safety
to give additional protection to the public and to account for
any variations in measurements.
SAR tests are conducted using standard operating positions
accepted by the FCC with the phone transmitting at its
highest certified power level in all tested frequency bands.
Although the SAR is determined at the highest certified
power level, the actual SAR level of the phone while
operating can be well below the maximum reported value.
This is because the phone is designed to operate at multiple
power levels so as to use only the power required to reach
the network. In general, the closer you are to a wireless base
station antenna, the lower the power output of the phone.
Before a new model phone is available for sale to the public,
it must be tested and certified to the FCC that it does not
exceed the SAR limit established by the FCC. Tests for each
model phone are performed in positions and locations (e.g. at
the ear and worn on the body) as required by the FCC. For
body-worn operation, this phone has been tested and meets
FCC RF exposure guidelines when used with an accessory
that contains no metal and that positions the mobile device a
minimum of 1.0cm from the body.
Use of other accessories may not ensure compliance with
FCC RF exposure guidelines. The FCC has granted an
Equipment Authorization for this mobile device with all
reported SAR levels evaluated as in compliance with the FCC
RF exposure guidelines. This mobile phone has a FCC ID
number: A3LSGHT999L [Model Number: SGH-T999L] and the
specific SAR levels for this mobile phone can be found at the
following FCC website:
http://www.fcc.gov/oet/ea/
.
The SAR information for this device can also be found on
Samsung’s website:
http://www.samsung.com/sar
.
SAR information on this and other model phones can be
accessed online on the FCC's website through
http://
transition.fcc.gov/oet/rfsafety/sar.html
. To find information that
pertains to a particular model phone, this site uses the phone
FCC ID number which is usually printed somewhere on the
case of the phone. Sometimes it may be necessary to
remove the battery pack to find the number. Once you have
the FCC ID number for a particular phone, follow the
instructions on the website and it should provide values for
typical or maximum SAR for a particular phone. Additional
SAR information can also be obtained at
http://www.fcc.gov/encyclopedia/specific-absorption-rate-sar-
cellular-telephones
.
Health and Safety Information 298
FCC Part 15 Information to User
Pursuant to part 15.21 of the FCC Rules, you are cautioned
that changes or modifications not expressly approved by
Samsung could void your authority to operate the device.
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Note: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference
by one or more of the following measures:
•
Reorient or relocate the receiving antenna.
•
Increase the separation between the equipment and receiver.
•
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
•
Consult the dealer or an experienced radio/TV technician for help.
Commercial Mobile Alerting System
(CMAS)
This device is designed to receive wireless emergency alerts
from the Commercial Mobile Alerting System ("CMAS";
which may also be known as the Personal Localized Alerting
Network ("PLAN")). If your wireless provider has chosen to
participate in CMAS/PLAN, alerts are available while in the
provider's coverage area. If you travel outside your provider's
coverage area, wireless emergency alerts may not be
available. For more information, please contact your wireless
provider.
Smart Practices While Driving
On the Road - Off the Phone
The primary responsibility of every driver is the safe
operation of his or her vehicle.
299
Responsible drivers understand that no secondary task
should be performed while driving whether it be eating,
drinking, talking to passengers, or talking on a mobile phone
- unless the driver has assessed the driving conditions and is
confident that the secondary task will not interfere with their
primary responsibility.
Do not engage in any activity while
driving a moving vehicle which may cause you to take your
eyes off the road or become so absorbed in the activity that
your ability to concentrate on the act of driving becomes
impaired
. Samsung is committed to promoting responsible
driving and giving drivers the tools they need to understand
and address distractions.
Check the laws and regulations on the use of mobile devices
and their accessories in the areas where you drive. Always
obey them. The use of these devices may be prohibited or
restricted in certain areas. For example, only hands-free use
may be permitted in certain areas.
Before answering calls, consider your circumstances. Let the
call go to voicemail when driving conditions require.
Remember, driving comes first, not the call!
If you consider a call necessary and appropriate, follow these
tips:
•
Use a hands-free device;
•
Secure your phone within easy reach;
•
Place calls when you are not moving;
•
Plan calls when your car will be stationary;
•
Do not engage in stressful or emotional conversations;
•
Let the person with whom you are speaking know that you are
driving and will suspend the call if necessary;
•
Do not take notes or look up phone numbers while driving;
Notice regarding legal restrictions on mounting this device in
an automobile:
Laws in some states may prohibit mounting this device on or
near the windshield of an automobile. In other states, the law
may permit mounting this device only in specific locations in
the automobile. Be sure to consult the state and local laws or
ordinances where you drive before mounting this device in
an automobile. Failure to comply with these restrictions could
result in fines, penalties, or other damages.
Never mount this device in a manner that will obstruct the
driver's clear view of the street and traffic.
Health and Safety Information 300
Never use wireless data services such as text messaging, Web
browsing, or e-mail while operating a vehicle.
Never watch videos, such as a movie or clip, or play video
games while operating a vehicle.
For more information, go to
http://www.ctia.org
.
Battery Use and Safety
Important! Handle and store batteries properly to avoid injury or
damage
. Most battery issues arise from improper
handling of batteries and, particularly, from the
continued use of damaged batteries.
•
Do not disassemble, crush, puncture, shred, or otherwise
attempt to change the form of your battery
. Do not put a high
degree of pressure on the battery. This can cause leakage or an
internal short-circuit, resulting in overheating.
•
Do not let the phone or battery come in contact with liquids.
Liquids can get into the phone's circuits, leading to corrosion.
Even when the phone appears to be dry and appears to operate
normally, the circuitry could slowly corrode and pose a safety
hazard. If the phone and/or battery get wet, have them checked
by your service provider or contact Samsung, even if they appear
to be working properly.
•
Do not place your battery in or near a heat source
. Excessive
heating can damage the phone or the battery and could cause the
phone or the battery to explode. Do not dry a wet or damp battery
with an appliance or heat source such as a microwave oven, hair
dryer, iron, or radiator. Avoid leaving your phone in your car in
high temperatures.
•
Do not dispose of the phone or the battery in a fire
. The phone
or the battery may explode when overheated.
•
Do not handle a damaged or leaking battery
. Do not let leaking
battery fluid come in contact with your eyes, skin or clothing. For
safe disposal options, contact your nearest Samsung-authorized
service center.
301
•
Avoid dropping the cell phone
. Dropping the phone or the
battery, especially on a hard surface, can potentially cause
damage to the phone and battery. If you suspect damage to the
phone or battery, take it to a service center for inspection.
•
Never use any charger or battery that is damaged in any way
.
•
Do not allow the battery to touch metal objects
. Accidental
short-circuiting can occur when a metallic object (coin, key,
jewelry, clip, or pen) causes a direct connection between the +
and - terminals of the battery (metal strips on the battery), for
example when you carry a spare battery in a pocket or bag.
Short-circuiting the terminals may damage the battery or the
object causing the short-circuiting.
Important!
Use only Samsung-approved batteries, and
recharge your battery only with
Samsung-approved chargers which are
specifically designed for your phone.
WARNING!
Use of a non-Samsung-approved battery or charger may
present a risk of fire, explosion, leakage, or other hazard
.
Samsung's warranty does not cover damage to the phone
caused by nonSamsung-approved batteries and/or chargers.
•
Do not use incompatible cell phone batteries and chargers
.
Some websites and second-hand dealers not associated with
reputable manufacturers and carriers, might be selling
incompatible or even counterfeit batteries and chargers.
Consumers should purchase manufacturer or
carrier-recommended products and accessories. If unsure about
whether a replacement battery or charger is compatible, contact
the manufacturer of the battery or charger.
•
Misuse or use of incompatible phones, batteries, and
charging devices could result in damage to the equipment
and a possible risk of fire, explosion, or leakage, leading to
serious injuries, damages to your phone, or other serious
hazard
.
Samsung Mobile Products and
Recycling
Samsung cares for the environment and encourages its
customers to recycle Samsung mobile devices and genuine
Samsung accessories.
Proper disposal of your mobile device and its battery is not
only important for safety, it benefits the environment.
Batteries must be recycled or disposed of properly.
Health and Safety Information 302
Recycling programs for your mobile device, batteries, and
accessories may not be available in your area.
We've made it easy for you to recycle your old Samsung
mobile device by working with respected take-back
companies in every state in the country.
Drop It Off
You can drop off your Samsung-branded mobile device
and batteries for recycling at one of our numerous
Samsung Recycling Direct (SM) locations. A list of these
locations may be found at:
http://pages.samsung.com/us/recyclingdirect/
usactivities_environment_samsungrecyclingdirect_locations.
jsp
.
Samsung-branded devices and batteries will be accepted
at these locations for no fee.
Consumers may also recycle their used mobile device or
batteries at many retail or carrier-provided locations
where mobile devices and batteries are sold. Additional
information regarding specific locations may be found at:
http://www.epa.gov/epawaste/partnerships/plugin/cellphone/
index.htm
or at
http://www.call2recycle.org/
.
Mail It In
The Samsung Mobile Take-Back Program will provide
Samsung customers with a free recycling mailing label.
Just go to
http://fun.samsungmobileusa.com/recycling/index.jsp
and
follow the instructions to print out a free pre-paid postage
label and then send your old mobile device or battery to
the address listed, via U.S. Mail, for recycling.
Dispose of unwanted electronics through an approved
recycler.
To find the nearest recycling location, go to our website:
www.samsung.com/recyclingdirect
Or call, (877) 278-0799.
Follow local regulations regarding disposal of mobile
devices and batteries
Dispose of your mobile device and batteries in accordance
with local regulations. In some areas, the disposal of these
items in household or business trash may be prohibited. Help
us protect the environment - recycle!
Warning!
Never dispose of batteries in a fire because they may
explode.
303
UL Certified Travel Charger
The Travel Charger for this phone has met applicable UL
safety requirements. Please adhere to the following safety
instructions per UL guidelines:
FAILURE TO FOLLOW THE INSTRUCTIONS OUTLINED MAY
LEAD TO SERIOUS PERSONAL INJURY AND POSSIBLE
PROPERTY DAMAGE.
IMPORTANT SAFETY INSTRUCTIONS - SAVE THESE
INSTRUCTIONS.
DANGER - TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, CAREFULLY FOLLOW THESE
INSTRUCTIONS.
FOR CONNECTION TO A SUPPLY NOT IN NORTH
AMERICA, USE AN ATTACHMENT PLUG ADAPTOR
OF THE PROPER CONFIGURATION FOR THE
POWER OUTLET.
THIS POWER UNIT IS INTENDED TO BE
CORRECTLY ORIENTED IN A VERTICAL OR
HORIZONTAL OR FLOOR MOUNT POSITION.
Display / Touch-Screen
Please note the following information when using your
mobile device:
WARNING REGARDING DISPLAY
The display on your mobile device is made of glass or
acrylic and could break if your mobile device is
dropped or if it receives significant impact. Do not use
if screen is broken or cracked as this could cause
injury to you.
WARRANTY DISCLAIMER: PROPER USE OF A
TOUCH-SCREEN MOBILE DEVICE
If your mobile device has a touch-screen display,
please note that a touch-screen responds best to a
light touch from the pad of your finger or a non-metallic
stylus. Using excessive force or a metallic object when
pressing on the touch-screen may damage the
tempered glass surface and void the warranty. For
more information, please refer to the “Standard
Limited Warranty”.
Health and Safety Information 304
GPS & AGPS
Certain Samsung mobile devices can use a Global Positioning
System (GPS) signal for location-based applications. A GPS
uses satellites controlled by the U.S. Government that are
subject to changes implemented in accordance with the
Department of Defense policy and the 2008 Federal Radio
navigation Plan (FRP). Changes may affect the performance
of location-based technology on your mobile device.
Certain Samsung mobile devices can also use an Assisted
Global Positioning System (AGPS), which obtains information
from the cellular network to improve GPS performance. AGPS
uses your wireless service provider's network and therefore
airtime, data charges, and/or additional charges may apply in
accordance with your service plan. Contact your wireless
service provider for details.
Your Location
Location-based information includes information that can be
used to determine the approximate location of a mobile
device. Mobile devices which are connected to a wireless
network transmit location-based information. Additionally, if
you use applications that require location-based information
(e.g. driving directions), such applications transmit
location-based information. The location-based information
may be shared with third-parties, including your wireless
service provider, applications providers, Samsung, and other
third-parties providing services.
Use of AGPS in Emergency Calls
When you make an emergency call, the cellular network may
activate AGPS technology in your mobile device to tell the
emergency responders your approximate location.
AGPS has limitations and
might not work in your area
.
Therefore:
•
Always tell the emergency responder your location to the best of
your ability; and
•
Remain on the mobile device for as long as the emergency
responder instructs you.
Navigation
Maps, directions, and other navigation-data, including data
relating to your current location, may contain inaccurate or
incomplete data, and circumstances can and do change over
time. In some areas, complete information may not be
available. T
herefore, you should always visually confirm that
the navigational instructions are consistent with what you see
before following them. All users should pay attention to road
conditions, closures, traffic, and all other factors that may
impact safe driving or walking. Always obey posted road signs
.
305
Emergency Calls
This mobile device, like any wireless mobile device, operates
using radio signals, wireless and landline networks, as well
as user-programmed functions, which cannot guarantee
connection in all conditions, areas, or circumstances.
Therefore, you should never rely solely on any wireless
mobile device for essential communications (medical
emergencies, for example). Before traveling in remote or
underdeveloped areas, plan an alternate method of
contacting emergency services personnel. Remember, to
make or receive any calls, the mobile device must be
switched on and in a service area with adequate signal
strength.
Emergency calls may not be possible on all wireless mobile
device networks or when certain network services and/or
mobile device features are in use. Check with local service
providers.
To make an emergency call:
1. If the mobile device is not on, switch it on.
2. From the Home screen, tap .
3. Key in the emergency number for your present location
(for example, 911 or other official emergency number).
Emergency numbers vary by location.
4. Tap .
If certain features are in use (call blocking, for example), you
may first need to deactivate those features before you can
make an emergency call. Consult your User Manual and your
local cellular service provider. When making an emergency
call, remember to give all the necessary information as
accurately as possible. Remember that your mobile device
may be the only means of communication at the scene of an
accident; do not cut off the call until given permission to do
so.
Care and Maintenance
Your mobile device is a product of superior design and
craftsmanship and should be treated with care. The
suggestions below will help you fulfill any warranty
obligations and allow you to enjoy this product for many
years:
Health and Safety Information 306
Keep your Samsung Mobile Device away from:
Liquids of any kind
Keep the mobile device dry. Precipitation, humidity, and
liquids contain minerals that will corrode electronic
circuits. If the mobile device does get wet, do not
accelerate drying with the use of an oven, microwave, or
dryer, because this may damage the mobile device and
could cause a fire or explosion.
Do not use the mobile device with a wet hand. Doing so
may cause an electric shock to you or damage to the
mobile device.
Extreme heat or cold
Avoid temperatures below 0°C / 32°F or above 45°C /
113°F.
Microwaves
Do not try to dry your mobile device in a microwave oven.
Doing so may cause a fire or explosion.
Dust and dirt
Do not expose your mobile device to dust, dirt, or sand.
Cleaning solutions
Do not use harsh chemicals, cleaning solvents, or strong
detergents to clean the mobile device. Wipe it with a soft
cloth slightly dampened in a mild soap-and-water
solution. If the mobile device has a retractable camera
lens, do not use soap and water to clean the lens. Use a
blower or brush or lens cleaning paper dampened in a
lens cleaning solution.
Shock or vibration
Do not drop, knock, or shake the mobile device. Rough
handling can break internal circuit boards.
Paint
Do not paint the mobile device. Paint can clog the
device’s moving parts or ventilation openings and prevent
proper operation.
Responsible Listening
Caution! Avoid potential hearing loss
.
Damage to hearing occurs when a person is exposed to loud
sounds over time. The risk of hearing loss increases as
sound is played louder and for longer durations. Prolonged
exposure to loud sounds (including music) is the most
common cause of preventable hearing loss. Some scientific
research suggests that using portable audio devices, such as
307
portable music players and cell phones, at high volume
settings for long durations may lead to permanent
noise-induced hearing loss.
This includes the use of headphones (including headsets,
earbuds, and Bluetooth® or other wireless devices).
Exposure to very loud sound has also been associated in
some studies with tinnitus (a ringing in the ear),
hypersensitivity to sound, and distorted hearing. Individual
susceptibility to noise-induced hearing loss and potential
hearing problem varies. Additionally, the amount of sound
produced by a portable audio device varies depending on the
nature of the sound, the device settings, and the headphones
that are used. As a result, there is no single volume setting
that is appropriate for everyone or for every combination of
sound, settings, and equipment.
You should follow some common sense recommendations
when using any portable audio device:
•
Always turn the volume down before plugging the earphones into
an audio source.
•
Set the volume in a quiet environment and select the lowest
volume at which you can hear adequately.
•
Be aware that you can adapt to higher volume settings over time,
not realizing that the higher volume may be harmful to your
hearing.
•
When using headphones, turn the volume down if you cannot
hear the people speaking near you or if the person sitting next to
you can hear what you are listening to.
•
Do not turn the volume up to block out noisy surroundings. If you
choose to listen to your portable device in a noisy environment,
use noise-cancelling headphones to block out background
environmental noise. By blocking background environment noise,
noise cancelling headphones should allow you to hear the music
at lower volumes than when using earbuds.
•
Limit the amount of time you listen. As the volume increases, less
time is required before you hearing could be affected.
•
Avoid using headphones after exposure to extremely loud noises,
such as rock concerts, that might cause temporary hearing loss.
Temporary hearing loss might cause unsafe volumes to sound
normal.
Health and Safety Information 308
•
Do not listen at any volume that causes you discomfort. If you
experience ringing in your ears, hear muffled speech, or
experience any temporary hearing difficulty after listening to your
portable audio device, discontinue use and consult your doctor.
You can obtain additional information on this subject from the
following sources:
American Academy of Audiology
11730 Plaza American Drive, Suite 300
Reston, VA 20190
Voice: (800) 222-2336
Email: info@audiology.org
Internet:
http://www.audiology.org/Pages/
default.aspx
National Institute on Deafness and Other
Communication Disorders
National Institutes of Health
31 Center Drive, MSC 2320
Bethesda, MD 20892-2320
Email: nidcdinfo@nih.gov
Internet:
http://www.nidcd.nih.gov/
National Institute for Occupational Safety
and Health (NIOSH)
395 E Street, S.W., Suite 9200
Patriots Plaza Building
Washington, DC 20201
Voice: 1-800-35-NIOSH
(1-800-356-4674)
1-800-CDC-INFO (1-800-232-4636)
Outside the U.S. 513-533-8328
309
Operating Environment
Remember to follow any special regulations in force in any
area, and always switch your mobile device off whenever it is
forbidden to use it, or when it may cause interference or
danger. When connecting the mobile device or any accessory
to another device, read its user's guide for detailed safety
instructions. Do not connect incompatible products.
Using Your Mobile Device Near Other Electronic
Devices
Most modern electronic equipment is shielded from Radio
Frequency (RF) signals. However, certain electronic
equipment may not be shielded against the RF signals from
your wireless mobile device. Consult the manufacturer to
discuss alternatives.
Implantable Medical Devices
A minimum separation of six (6) inches should be maintained
between a handheld wireless mobile device and an
implantable medical device, such as a pacemaker or
implantable cardioverter defibrillator, to avoid potential
interference with the device.
Persons who have such devices:
•
Should ALWAYS keep the mobile device more than six (6) inches
from their implantable medical device when the mobile device is
turned ON;
•
Should not carry the mobile device in a breast pocket;
•
Should use the ear opposite the implantable medical device to
minimize the potential for interference;
•
Should turn the mobile device OFF immediately if there is any
reason to suspect that interference is taking place;
•
Should read and follow the directions from the manufacturer of
your implantable medical device. If you have any questions about
using your wireless mobile device with an implantable medical
device, consult your health care provider.
For more information see:
http://www.fcc.gov/oet/rfsafety/rf-
faqs.html#
.
Email: cdcinfo@cdc.gov
Internet:
http://www.cdc.gov/niosh/topics/noise/
default.html
1-888-232-6348 TTY
Health and Safety Information 310
Other Medical Devices
If you use any other personal medical devices, consult the
manufacturer of your device to determine if it is adequately
shielded from external RF energy. Your physician may be able
to assist you in obtaining this information. Switch your
mobile device off in health care facilities when any
regulations posted in these areas instruct you to do so.
Hospitals or health care facilities may be using equipment
that could be sensitive to external RF energy.
Vehicles
RF signals may affect improperly installed or inadequately
shielded electronic systems in motor vehicles. Check with
the manufacturer or its representative regarding your vehicle
before using your mobile device in a motor vehicle. You
should also consult the manufacturer of any equipment that
has been added to your vehicle.
Posted Facilities
Switch your mobile device off in any facility where posted
notices require you to do so.
Potentially Explosive Environments
Switch your mobile device off when in any area with a
potentially explosive atmosphere and obey all signs and
instructions. Sparks in such areas could cause an explosion
or fire resulting in bodily injury or even death. Users are
advised to switch the mobile device off while at a refueling
point (service station).
Users are reminded of the need to observe restrictions on the
use of radio equipment in fuel depots (fuel storage and
distribution areas), chemical plants, or where blasting
operations are in progress. Areas with a potentially explosive
atmosphere are often, but not always, clearly marked. They
include below deck on boats, chemical transfer or storage
facilities, vehicles using liquefied petroleum gas (such as
propane or butane), areas where the air contains chemicals
or particles, such as grain, dust, or metal powders, and any
other area where you would normally be advised to turn off
your vehicle engine. Vehicles using liquefied petroleum gas
(such as propane or butane) must comply with the National
Fire Protection Standard (NFPA-58). For a copy of this
standard, contact the National Fire Protection Association.
When your Device is Wet
Do not turn on your device if it is wet. If your device is
already on, turn it off and remove the battery immediately (if
the device will not turn off or you cannot remove the battery,
leave it as-is). Then, dry the device with a towel and take it
to a service center.
311
FCC Hearing Aid Compatibility (HAC)
Regulations for Wireless Devices
The U.S. Federal Communications Commission (FCC) has
established requirements for digital wireless mobile devices
to be compatible with hearing aids and other assistive
hearing devices.
When individuals employing some assistive hearing devices
(hearing aids and cochlear implants) use wireless mobile
devices, they may detect a buzzing, humming, or whining
noise. Some hearing devices are more immune than others
to this interference noise, and mobile devices also vary in the
amount of interference they generate.
The wireless telephone industry has developed a rating
system for wireless mobile devices to assist hearing device
users find mobile devices that may be compatible with their
hearing devices. Not all mobile devices have been rated.
Mobile devices that are rated have the rating on their box or
a label located on the box.
The ratings are not guarantees. Results will vary depending
on the user's hearing device and hearing loss. If your hearing
device happens to be vulnerable to interference, you may not
be able to use a rated mobile device successfully. Trying out
the mobile device with your hearing device is the best way to
evaluate it for your personal needs.
M-Ratings
: Wireless mobile devices rated M3 or M4 meet
FCC requirements and are likely to generate less interference
to hearing devices than mobile devices that are not labeled.
M4 is the better/higher of the two ratings. M-ratings refer to
enabling acoustic coupling with hearing aids that do not
operate in telecoil mode.
T-Ratings
: Mobile devices rated T3 or T4 meet FCC
requirements and are likely to generate less interference to
hearing devices than mobile devices that are not labeled. T4
is the better/higher of the two ratings. T-ratings refer to
enabling inductive coupling with hearing aids operating in
telecoil mode.
Hearing devices may also be rated. Your hearing aid
manufacturer or hearing health professional may help you
find this rating. Higher ratings mean that the hearing device
is relatively immune to interference noise.
Under the current industry standard, American National
Standards Institute (ANSI) C63.19, the hearing aid and
wireless mobile device rating values are added together to
indicate how usable they are together. For example, if a
Health and Safety Information 312
hearing aid meets the M2 level rating and the wireless
mobile device meets the M3 level rating, the sum of the two
values equals M5.
Under the standard, this should provide the hearing aid user
with normal use while using the hearing aid with the
particular wireless mobile device. A sum of 6 or more would
indicate excellent performance.
However, these are not guarantees that all users will be
satisfied. T ratings work similarly.
The HAC rating and measurement procedure are described in
the American National Standards Institute (ANSI) C63.19
standard.
HAC for Newer Technologies
This phone has been tested and rated for use with hearing
aids for some of the wireless technologies that it uses.
However, there may be some newer wireless technologies
used in this phone that have not been tested yet for use with
hearing aids.
It is important to try the different features of this phone
thoroughly and in different locations, using your hearing aid
or cochlear implant, to determine if you hear any interfering
noise. Consult your service provider or the manufacturer of
this phone for information on hearing aid compatibility. If you
have questions about return or exchange policies, consult
your service provider or phone retailer.
Restricting Children's Access to Your
Mobile Device
Your mobile device is not a toy. Do not allow children to play
with it because they could hurt themselves and others,
damage the mobile device, or make calls that increase your
mobile device bill.
Keep the mobile device and all its parts and accessories out
of the reach of small children.
M3 + M2 = 5
T3 + T2 = 5
313
FCC Notice and Cautions
FCC Notice
The mobile device may cause TV or radio interference if used
in close proximity to receiving equipment. The FCC can
require you to stop using the mobile device if such
interference cannot be eliminated.
Cautions
Any changes or modifications to your mobile device not
expressly approved by Samsung could void your warranty for
this equipment and void your authority to operate this
equipment. Only use approved batteries, antennas, and
chargers. The use of any unauthorized accessories may be
dangerous and void the mobile device warranty if said
accessories cause damage or a defect to the mobile device.
Although your mobile device is quite sturdy, it is a complex
piece of equipment and can be broken. Avoid dropping,
hitting, bending, or sitting on it.
Other Important Safety Information
•
Only qualified personnel should service the mobile device or
install the mobile device in a vehicle. Faulty installation or service
may be dangerous and may invalidate any warranty applicable to
the device.
•
Ensure that any mobile devices or related equipment installed in
your vehicle are securely mounted.
•
Check regularly that all wireless mobile device equipment in your
vehicle is mounted and operating properly.
•
When using a headset in dry environments, static electricity can
build up in the headset and cause a small quick static electrical
shock. To minimize the risk of electrostatic discharge from the
headset avoid using the headset in extremely dry environments or
touch a grounded unpainted metal object to discharge static
electricity before inserting the headset.
•
Do not store or carry flammable liquids, gases, or explosive
materials in the same compartment as the mobile device, its
parts, or accessories.
•
For vehicles equipped with an air bag, remember that an air bag
inflates with great force. Do not place objects, including installed
or portable wireless equipment near or in the area over the air
bag or in the air bag deployment area. If wireless equipment is
improperly installed and the air bag inflates, serious injury could
result.
Health and Safety Information 314
•
Switch your mobile device off before boarding an aircraft. The use
of wireless mobile devices in aircraft is illegal and may be
dangerous to the aircraft's operation. Check with appropriate
authorities before using any function of a mobile device while on
an aircraft.
•
Failure to observe these instructions may lead to the suspension
or denial of cell phone services to the offender, or legal action, or
both.
•
While using your device, leave some lights on in the room and do
not hold the screen too close to your eyes.
•
Seizures or blackouts can occur when you are exposed to flashing
lights while watching videos or playing games for extended
periods. If you feel any discomfort, stop using the device
immediately.
•
Reduce risk of repetitive motion injuries. When you repetitively
perform actions, such as pressing keys, drawing characters on a
touch screen with your fingers, or playing games, you may
experience occasional discomfort in your hands, neck, shoulders,
or other parts of your body. When using your device for extended
periods, hold the device with a relaxed grip, press the keys lightly,
and take frequent breaks. If you continue to have discomfort
during or after such use, stop use and see a physician.
•
If your device has a camera flash or light, do not use the flash or
light close to the eyes of people or pets. [122011]
315
Section 12: Warranty Information
Standard Limited Warranty
What is covered and for how long?
SAMSUNG TELECOMMUNICATIONS AMERICA, LLC
(“SAMSUNG”) warrants that SAMSUNG’s handsets and
accessories (“Products”) are free from defects in material
and workmanship under normal use and service for the
period commencing upon the date of purchase by the first
consumer purchaser and continuing for the following
specified period of time after that date:
*If applicable.
What is not covered?
This Limited Warranty is conditioned upon proper use of the
Product.
This Limited Warranty does not cover: (a) defects or damage
resulting from accident, misuse, abnormal use, abnormal
conditions, improper storage, exposure to liquid, moisture,
dampness, sand or dirt, neglect, or unusual physical,
electrical or electromechanical stress; (b) scratches, dents
and cosmetic damage, unless caused by SAMSUNG;
(c) defects or damage resulting from excessive force or use
of a metallic object when pressing on a touch screen;
(d) equipment that has the serial number or the
enhancement data code removed, defaced, damaged,
altered or made illegible; (e) ordinary wear and tear;
(f) defects or damage resulting from the use of Product in
conjunction or connection with accessories, products, or
ancillary/peripheral equipment not furnished or approved by
SAMSUNG; (g) defects or damage resulting from improper
testing, operation, maintenance, installation, service, or
adjustment not furnished or approved by SAMSUNG;
(h) defects or damage resulting from external causes such as
collision with an object, fire, flooding, dirt, windstorm,
lightning, earthquake, exposure to weather conditions, theft,
blown fuse, or improper use of any electrical source;
(i) defects or damage resulting from cellular signal reception
Device 1 Year
Battery(ies)* 1 Year
Case/Pouch/Holster* 90 Days
Other Device
Accessories*
1 Year
Warranty Information 316
or transmission, or viruses or other software problems
introduced into the Product; or (j) Product used or purchased
outside the United States. This Limited Warranty covers
batteries only if battery capacity falls below 80% of rated
capacity or the battery leaks, and this Limited Warranty does
not cover any battery if (i) the battery has been charged by a
battery charger not specified or approved by SAMSUNG for
charging the battery; (ii) any of the seals on the battery are
broken or show evidence of tampering; or (iii) the battery has
been used in equipment other than the SAMSUNG phone for
which it is specified.
What are SAMSUNG’s obligations?
During the applicable warranty period, provided the Product
is returned in accordance with the terms of this Limited
Warranty, SAMSUNG will repair or replace the Product, at
SAMSUNG’s sole option, without charge. SAMSUNG may, at
SAMSUNG’s sole option, use rebuilt, reconditioned, or new
parts or components when repairing any Product, or may
replace the Product with a rebuilt, reconditioned or new
Product.
Repaired/replaced cases, pouches and holsters will be
warranted for a period of ninety (90) days. All other repaired/
replaced Products will be warranted for a period equal to the
remainder of the original Limited Warranty on the original
Product or for ninety (90) days, whichever is longer. All
replaced Products, parts, components, boards and
equipment shall become the property of SAMSUNG. Except to
any extent expressly allowed by applicable law, transfer or
assignment of this Limited Warranty is prohibited.
What must you do to obtain warranty service?
To obtain service under this Limited Warranty, you must
return the Product to an authorized phone service facility in
an adequate container for shipping, accompanied by the
sales receipt or comparable proof of sale showing the
original date of purchase, the serial number of the Product
and the seller’s name and address.
To obtain assistance on where to deliver the Product, please
call SAMSUNG Customer Care at 1-888-987-4357. If
SAMSUNG determines that any Product is not covered by this
Limited Warranty, you must pay all parts, shipping, and labor
charges for the repair or return of such Product.
You should keep a separate backup copy of any contents of
the Product before delivering the Product to SAMSUNG for
warranty service, as some or all of the contents may be
deleted or reformatted during the course of warranty service.
317
What are the limits on SAMSUNG’s liability?
THIS LIMITED WARRANTY SETS OUT THE FULL EXTENT OF
SAMSUNG’S RESPONSIBILITIES, AND THE EXCLUSIVE
REMEDY REGARDING THE PRODUCTS.
ALL IMPLIED WARRANTIES, INCLUDING WITHOUT
LIMITATION, IMPLIED WARRANTIES OF MERCHANTABILITY
AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO
THE DURATION OF THIS LIMITED WARRANTY. IN NO EVENT
SHALL SAMSUNG BE LIABLE FOR DAMAGES IN EXCESS OF
THE PURCHASE PRICE OF THE PRODUCT OR FOR, WITHOUT
LIMITATION, COMMERCIAL LOSS OF ANY SORT; LOSS OF
USE, TIME, DATA, REPUTATION, OPPORTUNITY, GOODWILL,
PROFITS OR SAVINGS; INCONVENIENCE; INCIDENTAL,
SPECIAL, CONSEQUENTIAL OR PUNITIVE DAMAGES; OR
DAMAGES ARISING FROM THE USE OR INABILITY TO USE THE
PRODUCT. SOME STATES AND JURISDICTIONS DO NOT
ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, OR THE DISCLAIMER OR LIMITATION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS
AND DISCLAIMERS MAY NOT APPLY TO YOU.
SAMSUNG MAKES NO WARRANTIES OR REPRESENTATIONS,
EXPRESS OR IMPLIED, STATUTORY OR OTHERWISE, AS TO
THE QUALITY, CAPABILITIES, OPERATIONS, PERFORMANCE
OR SUITABILITY OF ANY THIRD-PARTY SOFTWARE OR
EQUIPMENT USED IN CONJUNCTION WITH THE PRODUCT, OR
THE ABILITY TO INTEGRATE ANY SUCH SOFTWARE OR
EQUIPMENT WITH THE PRODUCT, WHETHER SUCH
THIRD-PARTY SOFTWARE OR EQUIPMENT IS INCLUDED WITH
THE PRODUCT DISTRIBUTED BY SAMSUNG OR OTHERWISE.
RESPONSIBILITY FOR THE QUALITY, CAPABILITIES,
OPERATIONS, PERFORMANCE AND SUITABILITY OF ANY
SUCH THIRD-PARTY SOFTWARE OR EQUIPMENT RESTS
SOLELY WITH THE USER AND THE DIRECT VENDOR, OWNER
OR SUPPLIER OF SUCH THIRD-PARTY SOFTWARE OR
EQUIPMENT.
Nothing in the Product instructions or information shall be
construed to create an express warranty of any kind with
respect to the Products. No agent, employee, dealer,
representative or reseller is authorized to modify or extend
this Limited Warranty or to make binding representations or
claims, whether in advertising, presentations or otherwise,
on behalf of SAMSUNG regarding the Products or this Limited
Warranty.
This Limited Warranty gives you specific legal rights, and you
may also have other rights that vary from state to state.
Warranty Information 318
What is the procedure for resolving disputes?
ALL DISPUTES WITH SAMSUNG ARISING IN ANY WAY FROM
THIS LIMITED WARRANTY OR THE SALE, CONDITION OR
PERFORMANCE OF THE PRODUCTS SHALL BE RESOLVED
EXCLUSIVELY THROUGH FINAL AND BINDING ARBITRATION,
AND NOT BY A COURT OR JURY.
Any such dispute shall not be combined or consolidated with
a dispute involving any other person’s or entity’s Product or
claim, and specifically, without limitation of the foregoing,
shall not under any circumstances proceed as part of a class
action. The arbitration shall be conducted before a single
arbitrator, whose award may not exceed, in form or amount,
the relief allowed by the applicable law. The arbitration shall
be conducted according to the American Arbitration
Association (AAA) Commercial Arbitration Rules applicable to
consumer disputes. This arbitration provision is entered
pursuant to the Federal Arbitration Act. The laws of the State
of Texas, without reference to its choice of laws principles,
shall govern the interpretation of the Limited Warranty and all
disputes that are subject to this arbitration provision. The
arbitrator shall decide all issues of interpretation and
application of this arbitration provision and the Limited
Warranty.
For any arbitration in which your total damage claims,
exclusive of attorney fees and expert witness fees, are
$5,000.00 or less (“Small Claim”), the arbitrator may, if you
prevail, award your reasonable attorney fees, expert witness
fees and costs as part of any award, but may not grant
SAMSUNG its attorney fees, expert witness fees or costs
unless it is determined that the claim was brought in bad
faith. In a Small Claim case, you shall be required to pay no
more than half of the total administrative, facility and
arbitrator fees, or $50.00 of such fees, whichever is less, and
SAMSUNG shall pay the remainder of such fees.
Administrative, facility and arbitrator fees for arbitrations in
which your total damage claims, exclusive of attorney fees
and expert witness fees, exceed $5,000.00 (“Large Claim”)
shall be determined according to AAA rules. In a Large Claim
case, the arbitrator may grant to the prevailing party, or
apportion among the parties, reasonable attorney fees,
expert witness fees and costs. Judgment may be entered on
the arbitrator’s award in any court of competent jurisdiction.
This arbitration provision also applies to claims against
SAMSUNG’s employees, representatives and affiliates if any
such claim arises from the Product’s sale, condition or
performance.
319
You may opt out of this dispute resolution procedure by
providing notice to SAMSUNG no later than 30 calendar days
from the date of the first consumer purchaser’s purchase of the
Product. To opt out, you must send notice by e-mail to
optout@sta.samsung.com, with the subject line: “Arbitration
Opt Out.” You must include in the opt out e-mail (a) your name
and address; (b) the date on which the Product was purchased;
(c) the Product model name or model number; and (d) the IMEI
or MEID or Serial Number, as applicable, if you have it (the IMEI
or MEID or Serial Number can be found (i) on the Product box;
(ii) on the Product information screen, which can be found
under “Settings;” (iii) on a label on the back of the Product
beneath the battery, if the battery is removable; and (iv) on the
outside of the Product if the battery is not removable).
Alternatively, you may opt out by calling 1-888-987-4357 no
later than 30 calendar days from the date of the first consumer
purchaser’s purchase of the Product and providing the same
information. These are the only two forms of notice that will be
effective to opt out of this dispute resolution procedure. Opting
out of this dispute resolution procedure will not affect the
coverage of the Limited Warranty in any way, and you will
continue to enjoy the benefits of the Limited Warranty.
Severability
If any portion of this Limited Warranty is held to be illegal or
unenforceable, such partial illegality or unenforceability shall
not affect the enforceability of the remainder of the Limited
Warranty.
Precautions for Transfer and Disposal
If data stored on this device is deleted or reformatted using
the standard methods, the data only appears to be removed
on a superficial level, and it may be possible for someone to
retrieve and reuse the data by means of special software.
To avoid unintended information leaks and other problems of
this sort, it is recommended that the device be returned to
Samsung’s Customer Care Center for an Extended File
System (EFS) Clear which will eliminate all user memory and
return all settings to default settings. Please contact the
Samsung Customer Care Center
for details.
Important!
Please provide warranty information (proof of
purchase) to Samsung’s Customer Care Center in
order to provide this service at no charge. If the
warranty has expired on the device, charges may
apply.
Warranty Information 320
Samsung Telecommunications America, LLC
1301 E. Lookout Drive
Richardson, Texas 75082
Phone: 1-800-SAMSUNG
Phone: 1-888-987-HELP (4357)
No reproduction in whole or in part allowed without prior
written approval. Specifications and availability subject to
change without notice. [111611]
End User License Agreement for
Software
IMPORTANT. READ CAREFULLY: This End User License
Agreement ("EULA") is a legal agreement between you
(either an individual or a single entity) and Samsung
Electronics Co., Ltd. ("Samsung") for software, owned by
Samsung and its affiliated companies and its third party
suppliers and licensors, that accompanies this EULA, which
includes computer software and may include associated
media, printed materials, "online" or electronic
documentation in connection with your use of this device
("Software").
This device requires the use of preloaded software in its
normal operation. BY USING THE DEVICE OR ITS PRELOADED
SOFTWARE, YOU ACCEPT THE TERMS OF THIS EULA. IF YOU
DO NOT ACCEPT THESE TERMS, DO NOT USE THE DEVICE OR
THE SOFTWARE.
1.
GRANT OF LICENSE
. Samsung grants you the following
rights provided that you comply with all terms and conditions
of this EULA: You may install, use, access, display and run
one copy of the Software on the local hard disk(s) or other
permanent storage media of one computer and use the
Software on a single computer or a mobile device at a time,
and you may not make the Software available over a network
where it could be used by multiple computers at the same
time. You may make one copy of the Software in machine
readable form for backup purposes only; provided that the
backup copy must include all copyright or other proprietary
notices contained on the original.
Certain items of the Software may be subject to open source
licenses. The open source license provisions may override
some of the terms of this EULA. We make the applicable
open source licenses available to you on the Legal Notices
section of the Settings menu of your device.
321
2.
RESERVATION OF RIGHTS AND OWNERSHIP
. Samsung
reserves all rights not expressly granted to you in this EULA.
The Software is protected by copyright and other intellectual
property laws and treaties. Samsung or its suppliers own the
title, copyright and other intellectual property rights in the
Software. The Software is licensed, not sold.
3.
LIMITATIONS ON END USER RIGHTS
. You may not reverse
engineer, decompile, disassemble, or otherwise attempt to
discover the source code or algorithms of, the Software
(except and only to the extent that such activity is expressly
permitted by applicable law not withstanding this limitation),
or modify, or disable any features of, the Software, or create
derivative works based on the Software. You may not rent,
lease, lend, sublicense or provide commercial hosting
services with the Software.
4.
CONSENT TO USE OF DATA
. You agree that Samsung and its
affiliates may collect and use technical information gathered
as part of the product support services related to the
Software provided to you, if any, such as IMEI (your device’s
unique identification number), device number, model name,
customer code, access recording, your device’s current SW
version, MCC (Mobile Country Code), MNC (Mobile Network
Code). Samsung and its affiliates may use this information
solely to improve their products or to provide customized
services or technologies to you and will not disclose this
information in a form that personally identifies you. At all
times your information will be treated in accordance with
Samsung’s Privacy Policy, which can be viewed at:
http://account.samsung.com/membership/pp
.
5.
SOFTWARE UPDATES
. Samsung may provide to you or
make available to you updates, upgrades, supplements and
add-on components (if any) of the Software, including bug
fixes, service upgrades (parts or whole), products or devices,
and updates and enhancements to any software previously
installed (including entirely new versions), (collectively
“Update”) after the date you obtain your initial copy of the
Software to improve the Software and ultimately enhance
your user experience with your device. This EULA applies to
all and any component of the Update that Samsung may
provide to you or make available to you after the date you
obtain your initial copy of the Software, unless we provide
other terms along with such Update. To use Software
provided through Update, you must first be licensed for the
Software identified by Samsung as eligible for the Update.
After the Update, you may no longer use the Software that
formed the basis for your Update eligibility. The updated
Software version may add new functions and, in some
limited cases, may delete existing functions.
Warranty Information 322
While the Update will be generally available, in some limited
circumstances, the Software updates will only be offered by
your network carrier, and such Software updates will be
governed by your contractual relationship with your network
carrier.
With the “Automatic Update” function enabled (as in the
default setting in the System Update menu in the Setting),
your device downloads some Updates automatically from
time to time. Your device will, however, ask for your consent
before installing any Update If you choose to disable the
“Automatic Update” function, then you can check the
availability of new Updates by clicking on the “Check
Update” menu in the Setting. We recommend that you check
availability of any new Updates periodically for optimal use of
your device. If you want to avoid any use of network data for
the Update downloads, then you should choose the “Wi-Fi
Only” option in the Setting. (Regardless of the option you
choose, the “Automatic Update” function downloads Updates
only through Wi-Fi connection.)
6. Some features of the Software may require your device to
have access to the internet and may be subject to
restrictions imposed by your network or internet provider.
Unless your device is connected to the internet through Wi-Fi
connection, the Software will access through your mobile
network, which may result in additional charges depending
on your payment plan. In addition, your enjoyment of some
features of the Software may be affected by the suitability
and performance of your device hardware or data access.
7.
SOFTWARE TRANSFER
. You may not transfer this EULA or
the rights to the Software granted herein to any third party
unless it is in connection with the sale of the mobile device
which the Software accompanied. In such event, the transfer
must include all of the Software (including all component
parts, the media and printed materials, any upgrades, this
EULA) and you may not retain any copies of the Software.
The transfer may not be an indirect transfer, such as a
consignment. Prior to the transfer, the end user receiving the
Software must agree to all the EULA terms.
8.
EXPORT RESTRICTIONS
. You acknowledge that the
Software is subject to export restrictions of various countries.
You agree to comply with all applicable international and
national laws that apply to the Software, including all the
applicable export restriction laws and regulations.
9.
TERMINATION
. This EULA is effective until terminated. Your
rights under this License will terminate automatically without
notice from Samsung if you fail to comply with any of the
323
terms and conditions of this EULA. Upon termination of this
EULA, you must cease all use of the Software and destroy all
copies, full or partial, of the Software.
10.
DISCLAIMER OF WARRANTY
. UNLESS SEPARATELY STATED
IN A WRITTEN EXPRESS LIMITED WARRANTY
ACCOMPANYING YOUR DEVICE, ALL SOFTWARE PROVIDED
BY SAMSUNG WITH THIS MOBILE DEVICE (WHETHER
INCLUDED WITH THE DEVICE, DOWNLOADED, OR
OTHERWISE OBTAINED) IS PROVIDED "AS IS" AND ON AN
"AS AVAILABLE" BASIS, WITHOUT WARRANTIES OF ANY KIND
FROM SAMSUNG, EITHER EXPRESS OR IMPLIED. TO THE
FULLEST EXTENT POSSIBLE PURSUANT TO APPLICABLE
LAW, SAMSUNG DISCLAIMS ALL WARRANTIES EXPRESS,
IMPLIED, OR STATUTORY, INCLUDING, BUT NOT LIMITED TO,
IMPLIED WARRANTIES OF MERCHANTABILITY, SATISFACTORY
QUALITY OR WORKMANLIKE EFFORT, FITNESS FOR A
PARTICULAR PURPOSE, RELIABILITY OR AVAILABILITY,
ACCURACY, LACK OF VIRUSES, QUIET ENJOYMENT, NON
INFRINGEMENT OF THIRD PARTY RIGHTS OR OTHER
VIOLATION OF RIGHTS. SOME JURISDICTIONS DO NOT
ALLOW EXCLUSIONS OR LIMITATIONS OF IMPLIED
WARRANTIES, SO THE ABOVE EXCLUSIONS OR LIMITATIONS
MAY NOT APPLY TO YOU. NO ADVICE OR INFORMATION,
WHETHER ORAL OR WRITTEN, OBTAINED BY YOU FROM
SAMSUNG OR ITS AFFILIATES SHALL BE DEEMED TO ALTER
THIS DISCLAIMER BY SAMSUNG OF WARRANTY REGARDING
THE SOFTWARE, OR TO CREATE ANY WARRANTY OF ANY
SORT FROM SAMSUNG.
11.
THIRD-PARTY APPLICATIONS
. Certain third party
applications may be included with, or downloaded to this
mobile device. Samsung makes no representations
whatsoever about any of these applications. Since Samsung
has no control over such applications, you acknowledge and
agree that Samsung is not responsible for the availability of
such applications and is not responsible or liable for any
content, advertising, products, services, or other materials
on or available from such applications. You expressly
acknowledge and agree that use of third party applications is
at your sole risk and that the entire risk of unsatisfactory
quality, performance, accuracy and effort is with you. It is up
to you to take precautions to ensure that whatever you select
to use is free of such items as viruses, worms, Trojan horses,
and other items of a destructive nature. References on this
mobile device to any names, marks, products, or services of
any third-parties are provided solely as a convenience to you,
and do not constitute or imply an endorsement, sponsorship,
or recommendation of, or affiliation with the third party or its
products and services. You agree that Samsung shall not be
Warranty Information 324
responsible or liable, directly or indirectly, for any damage or
loss, including but not limited to any damage to the mobile
device or loss of data, caused or alleged to be caused by, or
in connection with, use of or reliance on any such third party
content, products, or services available on or through any
such application. You acknowledge and agree that the use of
any third-party application is governed by such third party
application provider's Terms of Use, License Agreement,
Privacy Policy, or other such agreement and that any
information or personal data you provide, whether knowingly
or unknowingly, to such third-party application provider, will
be subject to such third party application provider's privacy
policy, if such a policy exists. SAMSUNG DISCLAIMS ANY
RESPONSIBILITY FOR ANY DISCLOSURE OF INFORMATION OR
ANY OTHER PRACTICES OF ANY THIRD PARTY APPLICATION
PROVIDER. SAMSUNG EXPRESSLY DISCLAIMS ANY
WARRANTY REGARDING WHETHER YOUR PERSONAL
INFORMATION IS CAPTURED BY ANY THIRD PARTY
APPLICATION PROVIDER OR THE USE TO WHICH SUCH
PERSONAL INFORMATION MAY BE PUT BY SUCH THIRD
PARTY APPLICATION PROVIDER.
12.
SAMSUNG APPLICATIONS
. Certain Samsung applications
and services may be included with, or downloaded to, this
mobile device. Many of them require Samsung Services
membership registration (“Samsung Account”), and your
rights and obligations will be set forth in separate Samsung
Account terms and conditions and privacy policies. There are
non-Samsung Account applications and services that require
your consent to their separate terms and conditions and
privacy policies. You expressly acknowledge and agree that
your use of such applications and services will be subject to
the applicable terms and conditions and privacy policies.
13.
LIMITATION OF LIABILITY
. SAMSUNG WILL NOT BE LIABLE
FOR ANY DAMAGES OF ANY KIND ARISING OUT OF OR
RELATING TO THE USE OR THE INABILITY TO USE THE
SOFTWARE OR ANY THIRD PARTY APPLICATION, ITS
CONTENT OR FUNCTIONALITY, INCLUDING BUT NOT LIMITED
TO DAMAGES CAUSED BY OR RELATED TO ERRORS,
OMISSIONS, INTERRUPTIONS, DEFECTS, DELAY IN
OPERATION OR TRANSMISSION, COMPUTER VIRUS, FAILURE
TO CONNECT, NETWORK CHARGES, IN-APP PURCHASES,
AND ALL OTHER DIRECT, INDIRECT, SPECIAL, INCIDENTAL,
EXEMPLARY, OR CONSEQUENTIAL DAMAGES EVEN IF
SAMSUNG HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH
DAMAGES. SOME JURISDICTIONS DO NOT ALLOW THE
EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE EXCLUSIONS OR
LIMITATIONS MAY NOT APPLY TO YOU. NOTWITHSTANDING
325
THE FOREGOING, SAMSUNG ELECTRONIC CO.'S TOTAL
LIABILITY TO YOU FOR ALL LOSSES, DAMAGES, CAUSES OF
ACTION, INCLUDING BUT NOT LIMITED TO THOSE BASED ON
CONTRACT, TORT, OR OTHERWISE, ARISING OUT OF YOUR
USE OF THE SOFTWARE OR THIRD PARTY APPLICATIONS ON
THIS MOBILE DEVICE, OR ANY OTHER PROVISION OF THIS
EULA, SHALL NOT EXCEED THE AMOUNT PURCHASER PAID
SPECIFICALLY FOR THIS MOBILE DEVICE OR ANY SUCH
THIRD PARTY APPLICATION THAT WAS INCLUDED WITH THIS
MOBILE DEVICE. THE FOREGOING LIMITATIONS,
EXCLUSIONS, AND DISCLAIMERS (INCLUDING SECTIONS 10,
11, 12 AND 13) SHALL APPLY TO THE MAXIMUM EXTENT
PERMITTED BY APPLICABLE LAW, EVEN IF ANY REMEDY
FAILS ITS ESSENTIAL PURPOSE.
14.
U.S. GOVERNMENT END USERS RESTRICTED RIGHTS
. The
Software is licensed only with "restricted rights" and as
"commercial items" consisting of "commercial software"
and "commercial software documentation" with only those
rights as are granted to all other end users pursuant to the
terms and conditions herein. All Products are provided only
with "restricted rights" with only those rights as are granted
to all other end users pursuant to the terms and conditions
herein. All Software and Products are provided subject to
Federal Acquisition Regulation (FAR) 52.227.19.
15.
APPLICABLE LAW
. This EULA is governed by the laws of
the jurisdiction where you are a resident or, if a resident of
the United States, by the laws of the state of Texas, without
regard to its conflict of law provisions. This EULA shall not be
governed by the UN Convention on Contracts for the
International Sale of Goods, the application of which is
expressly excluded.
16.
DISPUTE RESOLUTION
.
(a) Non-United States residents. If a dispute, controversy or
difference arising in any way from this EULA or your use of
the Software is not amicably settled, it shall be subject to the
non-exclusive jurisdiction of the courts of the jurisdiction
where you are a resident. Notwithstanding the foregoing,
Samsung may apply for injunctive remedies (or an equivalent
type of urgent legal relief) in any jurisdiction.
(b) United States residents. ALL DISPUTES WITH SAMSUNG
ARISING IN ANY WAY FROM THIS EULA OR YOUR USE OF THE
SOFTWARE SHALL BE RESOLVED EXCLUSIVELY THROUGH
FINAL AND BINDING ARBITRATION, AND NOT BY A COURT OR
JURY. Any such dispute shall not be combined or
consolidated with any other person’s or entity’s claim or
dispute, and specifically, without limitation of the foregoing,
shall not under any circumstances proceed as part of a class
Warranty Information 326
action. The arbitration shall be conducted before a single
arbitrator, whose award may not exceed, in form or amount,
the relief allowed by the applicable law. The arbitration shall
be conducted according to the American Arbitration
Association (AAA) Commercial Arbitration Rules applicable to
consumer disputes. This arbitration provision is entered
pursuant to the Federal Arbitration Act. The laws of the State
of Texas, without reference to its choice of laws principles,
shall govern the interpretation of the EULA and all disputes
that are subject to this arbitration provision. The arbitrator
shall decide all issues of interpretation and application of this
arbitration provision and the EULA. For any arbitration in
which your total damage claims, exclusive of attorney fees
and expert witness fees, are $5,000.00 or less ("Small
Claim"), the arbitrator may, if you prevail, award your
reasonable attorney fees, expert witness fees and costs as
part of any award, but may not grant Samsung its attorney
fees, expert witness fees or costs unless it is determined that
the claim was brought in bad faith. In a Small Claim case,
you shall be required to pay no more than half of the total
administrative, facility and arbitrator fees, or $50.00 of such
fees, whichever is less, and Samsung shall pay the
remainder of such fees. Administrative, facility and arbitrator
fees for arbitrations in which your total damage claims,
exclusive of attorney fees and expert witness fees, exceed
$5,000.00 ("Large Claim") shall be determined according to
AAA rules. In a Large Claim case, the arbitrator may grant to
the prevailing party, or apportion among the parties,
reasonable attorney fees, expert witness fees and costs.
Judgment may be entered on the arbitrator's award in any
court of competent jurisdiction. This arbitration provision also
applies to claims against Samsung’s employees,
representatives and affiliates if any such claim arises from
the licensing or use of the Software. You may opt out of this
dispute resolution procedure by providing notice to Samsung
no later than 30 calendar days from the date of the first
consumer purchaser’s purchase of this device. To opt out,
you must send notice by e-mail to
optout@sta.samsung.com, with the subject line: "Arbitration
Opt Out." You must include in the opt out e-mail (a) your
name and address; (b) the date on which the device was
purchased; (c) the device model name or model number; and
(d) the IMEI or MEID or Serial Number, as applicable, if you
have it (the IMEI or MEID or Serial Number can be found (i) on
the device box; (ii) on the device information screen, which
can be found under "Settings;" (iii) on a label on the back of
the device beneath the battery, if the battery is removable;
and (iv) on the outside of the device if the battery is not
327
removable). Alternatively, you may opt out by calling
1-888-987-4357 no later than 30 calendar days from the
date of the first consumer purchaser's purchase of the
device and providing the same information. These are the
only two forms of notice that will be effective to opt out of
this dispute resolution procedure. Opting out of this dispute
resolution procedure will not affect your use of the device or
its preloaded Software, and you will continue to enjoy the
benefits of this license.
17.
ENTIRE AGREEMENT; SEVERABILITY
. This EULA is the
entire agreement between you and Samsung relating to the
Software and supersedes all prior or contemporaneous oral
or written communications, proposals and representations
with respect to the Software or any other subject matter
covered by this EULA. If any provision of this EULA is held to
be void, invalid, unenforceable or illegal, the other provisions
shall continue in full force and effect. [050113]
328
Index
Numerics
2G Network
Using Only 233
2-Sec Pause
Adding 52
A
ABC 72
Acces to My Location 181
Accessing
Voicemail 17
Accessory 264
Audio Output 264
Dock Sound 264
Accounts and Sync
Adding Contacts 95
Add 2 Sec Pause 55, 86
Add to Favorites 100
Adjusting
Call volume 61
Airplane Mode 231
Alarm
Deleting an Existing Alarm 161
Setting 160
Turning Off 161
Alerts
Presidential 111
Alerts on Call 254
Allow Diagnostics 16, 279
AllShare Cast Hub 27
Activation on Device 149
Connecting 149
Set Up Hardware 149
AllShare Play
see Samsung Link 203, 204
AllShareCast Hub 203
AMBER Alerts 111
Disable 112
Android Beam 240
Answering
Home Key 254, 256
Answering a call 52
Application cache and data
Clearing 195
Application Menus
Navigating through 48
Applications
Calculator 154
Camera 156
Email 166
Google Mail 167
Google Maps 180
Hide 152
KNOX 180
Messages 182
Sharing with Others 34
Show Hidden 152
Shutting Down 153
Storage Used 285
Using the Camcorder 136
Using the Camera 129
Voice Recorder 211
YouTube 213
Applications and Development 151
Apps
Adding 31
329
Reset Preferences 285
Apps Screen
Customizing 151
Area Code
Auto Assign 257
Audio
Output Mode 264
Audio Output 253
Auto Redial 258, 259
Auto Reject
Configuration 53
Auto Reject List 254
Auto Reject Mode 254
Auto Share Shot 133
Automatic Answering 255
Automatic Restore 277
B
Back up
My Account 277
My Data 277
Backup and Restore 277
Battery
Charging 12
Display Percentage 14
Extending Life 14
Installing 11
Low Battery Indicator 14
Removal 11
Show Percentage 249
Wall Charger 12
Battery Cover
Removal 8
Replace 11
Battery Life
Extending 14
Battery Usage 286
Battery Use & Safety 300
Bigger Font
Setting 265
Bing
Set Search Engine 179
Blocking Mode 262
On 262
Bluetooth 224
About 224
Changing Name 225
Configure Device Settings 228
Deleting a Paired Device 228
Disconnecting a Paired Device
228
Media Audio 228
Microhone Function 228
Off 225
On 224
Outgoing Headset Condition 255,
257
Paring Devices 227
Review Downloaded Files 226
Scanning for other Devices 226
Sending Contact Information 229
Sending Contacts Via 229
Sending Namecard 92
Settings 225
Status indicators 225
Switching to Headset during call
63
Turning on and off 224
Visibility 226
Visible Time-Out 226
Browser
Adding bookmarks 176
Deleting bookmarks 176
330
Easier to Read Pages 178
Emptying cookies 176
Entering a URL 173
Inverted Display 178
Navigation 172
Options 172
Quick Controls 180
Resetting Default Actions 286
Search Engine 179
Settings 177
Bubble
Options 108
Buddy Photo Share 131
Burst Shot 131
C
Calculator
Scientific Functions 154
Calendar
Creating an event 155
Settings 155
Sync Calendars 155
Call
Accessories 255
Settings 52, 53, 254
Call Alert
Call Vibrations 254, 257
Call Alerts 254
Call Answering/Ending 254
Call Barring 257, 259
Call Duration 69
Resetting Times 69
Call Forwarding 255
Configuring 258
Call Functions 49
Answering 52
Background Calling 50
Ending 50
Ending a Call 50
Ending via Status Bar 50
Making a Multi-Party Call 64
Pause Dialing 55
Redialing the last number 56
Vibrate 255
Wait dialing 55
Call Rejection 53, 254
Call Settings 254
Additional Settings 257
General 254
Call Sound
Adding More Volume 61
Personalize 61, 62
Call Status Tones 254
Call Vibration 254, 257
Call Volume
Adjusting 61
Call Waiting 66, 258, 259
Caller ID 257
Calling
Using Wi-Fi 58
Calls
Auto Reject 254
Making a 49
Multi-party 64
Muting 63
Camcorder 136
Options 137
Shooting Video 136
Camera 128
Best Photo 130
Burst Shot 131
Camera Options 130
Default Storage Location 133
331
Enabling Share Shot 141
Taking Pictures 129
Camercorder
Taking Pictures During Video 139
Care and Maintenance 305
Certificates
Install 222
Charging battery 12
ChatON 157
Adding a Buddy 158
Adding New Buddy 158
Buddy photo share 135
Chatting On 159
Deleting Bubble 159
Register Service 157
Children and Cell Phones 295
Chrome 159
Google 159
Clearing
Application cache and data 195
CMAS 111, 112
Commercial Mobile Alerting System
(CMAS) 298
Configuration
Initial 15
Connections
Accessing the Internet 172
Contact
Copying to microSD Card 93
Copying to SIM Card 93
Creating a New 80
Linking 89
New From Keypad 82
Photo 146
Contact Entry
Options 88
Contact List
Options 87
Contact Menus
Options 88
Contacts
Adding a Number to Existing 85
Adding a Pause or Wait 86
Adding Your Facebook Friends 96
Additional Options 97
Deleting 86
Display Options 94, 95, 97
Displaying Contacts by Name 97
Export List to microSD 278
First Name First 97
Groups 98
Last Name First 97
Merge with Samsung Account 87
Sending All 92
Setting Default Location 87
Settings 97
Sharing Settings 97
Sharing/Sending 91
Contacts List 49
Context Menus 85, 88
Navigation 48
Using 48
Contextual Awareness 248
Cookies
Emptying 176
Copying Contact 93
Create Folder
Group Apps 152
Creating a Playlist 185
Creating and sending
Messages 102
332
Customizing
Home screens 33
D
Data
Auto Sync Data 230
Restrict Background Data 230
Data Limit
Setting 229
Data Roaming 231
Activate/Deactivate 230, 231
Data Usage
Cycle 230
Limiting 229
Date
Selecting Format 288
Date and Time 288
Default Storage
Assigning 128
Camcorder 128, 138
Camera 128
Camera Storage 133
Deleting
Multiple Messages 108
Single Bubble 109
Single Message 108
Deleting a contact 86
Deregister
Web Storage 206
Desk Clock 160
Configuring 162
Device
Reset 278
Device Name
Edit 289
Device Options
Screen 250
Display
Icons 23
Settings 23
Status Bar 23
Using Negative Colors 265
Display / Touch-Screen 303
Displaying your phone number 49
DivX
Locating VOD Number 210
Overview 210
Registration Code 289
Do cell phones pose a health hazard?
291
Dock
Sound 264
Downloading
New application 193
Downloads 163
Draft Messages 103
Drive 164
Send Namecard 87
Dropbox 205
Uploading Picture 165
E
Easy Mode 253
EDGE Network 233
Edit Page 34
Email 115
Changing Signature 119, 125
Composing 117
Configuring Settings 118
Creating a Spam List 118, 124
Creating an Internet Account 116
Handwritten Signature 119, 125
Internet Email 116
333
Opening 117
Refreshing Messages 117
Sending 97
Wi-Fi Download of Attachments
120, 125
Emergency
Alert Preview 111
Alerts 111
Emergency Alert
Configuration 112
Emergency Alerts 111
AMBER 111
Imminent Extreme 111
Message Settings 111
Severe 111
Emergency Calls 305
Making 51
With SIM 51
Without SIM 51
Emoticons 104
Ending
A call 50
Entering Text 70
Using SWYPE 71
Erasing files from
Memory card 287
Exchange Email 121
Account Setup 121
Composing 123
Configuring Settings 124
Deleting Message 123
Opening 123
Refreshing Messages 123
Exposure to Radio Frequency (RF)
Signals 291
Extra Volume 61
Extreme Alert
Disable 112
F
Face Unlock 243, 244
Facebook
Personalize 268
Predictive Text 268
Facial Recognition 243
Factory Data Reset 278
Prior To 278
Favorites Tab 100
FCC Hearing Aid Compatibility (HAC)
Regulations for Wireless Devices 311
FCC Notice and Cautions 313
Fixed Dialing Numbers 259
Flipboard 166
Folder
Create 31
Font
Size 249
Style 249
Font Size
Caption 213
Changing 265
Minimum Setting 178
Forgot Pattern? 246
G
G+ Photos 166
Galaxy Gear 18
Gallery
Folder Options 144
Opening 148
Picture-In-Picture 210
Games
Volume 251
334
Gestures
Browse Image 41
Overview 41
Screen Capture 42
Sensitivity Settings 42, 274
Shake to Update 41
Tilt to Zoom 41
Getting Started 6
Battery 11
Battery Cover 8
Locking/Unlocking the Device 16
microSD card 10
SIM Card 9
Switching Device On/Off 15
Voicemail 17
Gmail 126, 167
Composing a Message 127
Creating an Additional Account
127
Opening 126, 167
Other Options 127
Personalize 268
Refreshing 127
Signing In 126
Viewing 127
Google
Set Search Engine 179
Settings 169
Signing into Your Account 167
Voice Typing 70
Google Books 188
Google Drive 92, 164
see Drive 164
Google Mail
see also Gmail 127
Google Maps
Enabling a location source 181
Opening a map 181
Google Music 190
Google Now 213
Adjust Settings 168
Google Talk
see Hangouts 171
Google Voice Typing
Configuring 270
Using 79
GPS
Tagging Images 133, 138
GPS & AGPS 304
GPS Tag 131, 137
Group
Joining 171
Group Play 170
Creating a Group 170
Joining a Group 171
Share Music 183
Sharing Pictures 170
Groups
Adding an Member to an Existing
Group 99
Creating a New Caller Group 98
Deleting 100
Deleting a Caller Group 100
Editing a Caller Group 99
Removing an Entry 99
Settings 99
H
Hands-Free Mode
On 263
335
Handwriting 76
Hangouts 171
Haptic
Auto 253
Haptic Feedback
Turn On/Off 264
Vibrate 252
Vibration Setting 251
HDR 131
Health and Safety Information 291
Hearing Aids 255
Help
In-Device 172
Hidden Applications
Show 152
Hold
Placing a Call on Hold 62
Home 29
Home Key 31
Home Screen
Assigning a New 34
Changing Wallpaper 38
Menu Settings 31
Overview 29
Home screens
Customizing 33
Homepage
Setting New 176
I
Icons
Description 23
Indicator 23
Status 23
Images
Assigning as a Contact icon 146
Assigning as wallpaper 146
Transferring 278
Verifying 278
Importing and Exporting
To micro SIM card 97
In Call
Options 61
In call
Options 63
Incognito 174
Create Window 174
Exit Window 175
Incoming Call
Vibration Setting 251
Indicator icons 23
International Call 54
International Calls
Making 54
Internet 172
Brightness Setting 173
Clear Cookies 178
Search 174
Set Home Page 177
Set New Homepage 176
Internet Email 115
IP Address 288
L
Language
Select 266
LDAP 87
Linking
Contact Information 89
Live Shooting 139
Live Wallpaper
Selecting 38
336
Lock Pattern
If I Forgot My Pattern 246
Lock Screen 242
Changing Wallpaper 39
Customizing Shortcuts 248
Say Wake-Up Command 243
Shortcuts 243
Using Shortcuts 248
Viewing Missed Calls 69
Logs 66
Accessing 67
Accessing from Notifications 67
Altering Numbers 68
Erasing 69
Low battery indicator 14
LTE
Network Mode 232
Selecting 232
LTE Network 232
M
Making
Emergency Calls 51
International Calls 54
New call 49
Managing Applications
Clearing Application Cache 284
Uninstalling Third-party
Applications 284
Market
see Play Store 193
Marking contact
As a default 91
Memory card
Erasing files from the 287
Merge Calls 64
Merge with Google 87
Message
Reply 159
Threads 107
Message Search 109
Message Threads 107
Messaging
Adding a Signature 111
Adding Attachments 105
Additional Text 106
Block Unknown Senders 112,
114
Composing Options 104
Creating and sending 102
Creating and Sending Text
Messages 102
Deleting a message 108
Draft 103
Google Mail 126
Icons on the Status Bar 101
Insert Smiley 104
Locked 103
Menu Options 103
Options 103
Read 106
Register a Number as Spam 107
Reply 107
Scheduled Messages 103
Settings 109
Signature 111
Signing into Google Mail 126
Spam 103
Text Templates 114
Thread Options 107
Types of Messages 101
Viewing new 106
337
micro SIM Card 9
Changing Existing PIN 281
Importing and Exporting 97
Insertion 9
Lock 281
Removal 10
Setting Up Lock 281
microSD Card
Insertion 10
Removal 11
Microsoft Exchange 81, 115
Missed Call
Viewing from Lock Screen 69
Mobile Data
Activate/Deactivate 229
Set Data Limit 229
Usage 231
Mobile HotSpot 235
Activating 236
Allowed Devices 237
Changing Password 237
Connecting 236
MAC FIltering 237
Mobile HotSpots
Detect and Connect 230
Mobile Networks 231
Data Roaming 231
Mobile Data 231
Mobile Web 172
Entering Text in the Mobile Web
Browser 173
Navigating with the Mobile Web
172
Using Bookmarks 175
Mono
Audio Setup 265
Motion
Function Activation 273
On 145, 272
Motion Settings 272
Mounting the SD card 287
Multi Window
Activate/Deactivate 43, 248
Close App 47
Customizing 45
Increase App Window Size 47
Maximize App 47
Rearrange Apps 45
Removing Apps 45
Restoring Apps 45
Running Multiple Apps 46
Switch Arrangement 47
Tab Repositioning 44
Using 43
Multi-Party Call 64
Dropping One Participant 65
Private conversation 65
Setting up 64
Multi-party calls 64
Multi-Tasking
Background Calling 50
Watching Videos 210
Music 182
Adding Music 185
Creating a Playlist 185
Editing a Playlist 185
Making a Song a Ringtone 183
Options 183
Playing Music 182
Removing Music 185
Using Playlists 185
338
Volume 251
Music App
Music Application 190
Now Playing Screen 192
Playing 191
Searching for Music 191
Tab Options 191
Music File Extensions
3GP 182
AAC 182
AAC+ 182
eAAC+ 182
M4A 182
MP3 182
MP4 182
WMA 182
Music Files
Removing 186
Transferring 186
N
Namecard
Sending 91
Sending All 92
Share Via 91
Navigating
Application Menus 48
Sub-Menus 48
Through Screens 39
Negative Colors 265
Network Mode
2G Network 232, 233
LTE 232
WCDMA/GSM 232
New applications
Downloading 193
NFC (Near Field Communication) 240
Noise Reduction 62
Non-Market Applications 195
Notification
Vibration Setting 251
Notification Bar 32
Using 32
Notification Panel
Customize 248
Notifications
Volume 251
O
On/Off Switch 15
Operating Environment 309
Organizer
Calculator 154
World Clock 161
Other Important Safety Information
313
Outlook 115
Overview
Home Screen 29
P
Page Buddy 248
Passwords
Make Visible 281
Pause
Adding to a Contact 86
Pause Dialing 55
Personal Localized Alerting Network
(PLAN) 298
Personalize
Call Sound 61
Phone
Icons 23
339
Switching on/off 15
Phone number
Finding 49
Phone Ringtone 251
Phone Vibration 251
Photo Editor
Download and Install 147
Photos
Change Player 134
Options 134, 135
Sharing 134, 135
Taking Using Voice 133
Set As 146
Streaming from Gallery 145
Picture-In-Picture 210
Pictures
Instant Sharing 141
Sharing 140, 143
Play Books 188
Play Store 193
Quick Access 151
Pointer Speed
Configuration 272
Power
Auto Adjust Screen Tone 249
Power Saving
CPU Power 263
Haptic Feedback 264
LCD Adjustment 249
Learning About 264
Screen Power 263
Power Saving Mode 263
Predictive Text
Activation 268
Prepend
Area Code 258
Primary Shortcuts 30
Adding and Deleting 36
Customizing 36
Replacing 36
Q
Quick Dialing 50
Quick Messaging 103
R
Reader Mode
Using 173
Redialing the last number 56
Reducing Exposure
Hands-Free Kits and Other
Accessories 294
Reject Call
Rejection Messages 254
Reject Calls
Managing 53
Reject List
Add To 54
Add to 68
Auto Reject 54
Rejection List
Assigning Multiple Numbers 54
Assigning Single Numbers 54
Rejection Messages
Set Up 254
Reset 278
Reset App Preferences 285
Reset Device 278
Responsible Listening 306
Restarting
Device 16
340
Restore 277
Restrict
Background Data 230
Restricting Children's Access to Your
Mobile device 312
Ringtone
Assigning 255
Assigning Voicemail 261
Device 251
Volume 251
S
S Beam 240
On 143, 240
Sharing Multiple Pictures 144
Sharing Pictures 143
S Memo
Creating a New Memo 196
S Voice 198
Set Wake-Up Command 243
Using 198
Samsung Account
Creating 276
Merge Contacts 87
Samsung Hub
Creating a New Account 200
Using 201
Samsung Keyboard 75
ABC Mode 77
Changing the Input Type 76
Enabling 75
Keyboard Swipe 267
Reset Settings 267
Settings 266
Sounds 253
Symbol/Numeric Mode 78
XT9 Advanced Settings 268
Samsung Keypad
Entering Symbols 78
Samsung Link
Configuring Settings 204
Deregister Storage 206
Sharing Media 206
Web Storage Setup 205
Samsung Mobile Products and
Recycling 301
Save a Number
From Keypad 82
Screen
Home 29
Navigation 39
Screen Capture 42
Taking a Screen Shot 145
Screen Lock
Set Up 245
Sounds 252
Screen Lock Pattern
Changing 245
Creating 245
Deleting 246
Forgot My Pattern 246
Screen Mirroring
Activate on Device 149
Activation 241
On 149, 241
Using AllShare Cast Hub 149
Screen Rotation
Auto-Rotate 249
Screen Timeout 249
Screen Unlock
Face and Voice Unlock 244
Face Unlock 243
341
Swipe 242
Screens
Adding and Deleting 34
Customizing 33
Rearranging 34
SD card
Mounting the 287
Unmounting 287
Search Engine 179
Security
Auto Update 282
Sending a Namecard 91
Sensitivity Settings 274
Setting an alarm 160
Setting Up
Voicemail 17
Settings 216
Accessing 216
Browser 177
Call 52
Contact list 97
Display 23
Enabling the GPS Satellites 280
Enabling Wireless Locations 280
Messaging 109
Tab Overview 216
Wallpaper 38, 39
Setup
Initial 15
Severe Alert
Disable 112
Share Applications 34
Share Shot 130, 141
Auto 133
Configuring 142
Enabling 142
Stop Sharing 142
Taking Images 142
Shortcuts
Adding from Application Screen
35
Adding from Home Screen 35
Deleting from a Screen 36
Managing 35
Primary 30
SIM
Micro 6, 9
see also micro SIM 9
SkyDrive 205
Smart Alarm 161
Smart Practices While Driving 298
Smart Switch 18
Snooze 161
Repeat 160
SNS 95
Social Network
Adding Facebook Contacts 96
Resync 96
Social Networking
Adding Contacts From 95
Software Update 288
Wi-Fi 290
Song
Set As 184
Sounds
Turn Off All 266
Spam 114
Accessing Your Spam Folder 114
Add a Phrase 111, 114
Add Number 104, 105, 107
Assigning Manually 113
Assigning Phone Numbers 113
342
Block Unknown Numbers 114
Block Unknown Senders 112,
114
Email Addresses 118, 124
Manually Add a Number 111, 113
Match Criteria 113
Registering a Phrase as Spam 113
Settings 111, 113
Spam Messages 103
Assigning 103
Speakerphone
Turning on and off 63
Specific Absorption Rate (SAR)
Certification Information 296
Speed Dial
Changing an entry 57
Making a call 57
Removing an entry 57
Setting up entries 56
Standard Limited Warranty 315
Standard Mode 253
Status Bar 23
Sub-Menus
Navigation 48
SugarSync 205
Switching to a Bluetooth
During a call 63
Swype 70
123ABC Mode 73
ABC Mode 72
Cellular Data 270
Entering Numbers 74
Entering Symbols 74
Entering Text 71
Keyboard Mode 72
Select Text Input Mode 72
Settings 269
SYM mode 72
System
Volume 251
System Manager 15, 279
System Tone
Settings 252
T
T9 Trace
Samsung Keyboard 267
Task Manger
Overview 153
Tethering 234
Active Icon 235
Disconnecting 235
see USB Tethering 234
Text
Adjusting Size 178
Minimum Font Size 178
Soom Amount on Double Tap 178
Text Input
Methods 70
Text Input Method
Selecting 70
Text Templates 114
Create Your Own 115
Text To Speech 271
Text-to-speech
Configuration 271
Third-Party Applications 284
Uninstalling 195
Time Zone
Selecting 288
Timer
Automatic Answering 255, 257
343
Tools
Camera 129
TrackPad
Configure 272
Transferring Large Files 143, 240
Transferring Music Files 186
TTS 271
TTY Mode 262
Twitter
Predictive Text 268
U
UL Certified Travel Charger 303
Understanding Your Device 18
Back View 22
Display 23
Features 18
Front View 20
Home 29
Side Views 22
Uninstalling
Third-party applications 195
Unknown Numbers
Blocking Messages 114
Unknown Sources 195
Unlock
Using Face 243
Using Voice 244
Unmounting
SD card 287
Usage
Battery 286
USB Connections
As Storage Device 150
USB Settings
As Storage Device 150
USB Tethering 234
Activating 234, 235
Use GPS Satellites 181, 280
Use Wireless Networks 181, 280
Using Favorites
Adding Favorites 176
V
Vibrate 255
Activate/Deactivate for Voicemail
261
Vibration
Create 260
Device 251
Intensity Setup 251
Video
Picture-In-Picture 210
Sharing Videos 209
Volume 251
Videos
Default Storage Location 138
Options 135
Voice Input
Recognition 271
Voice Search 213, 271
Voice Typing 70
Configuring 270
Using 79
Voicemail 261
Accessing 17
Accessing from Another Phone 17
Setting Up 17
Volume Settings
Adjusting 251
VPN
Adding 238
Settings 238
344
VPN Client 213
W
Wait 55, 86
Adding to a Contact 86
Wait dialing 55
Wallpaper
Assign Home 31
Home and Lock Screens 38
Wallpapers
Assigning from Gallery 135
Changing Home Screen 38
Changing Lock Screen 39
Changing via Settings Menu 38
Managing 38
Warranty Information 315
Web 172
History 177
Widget
Adding Widgets 31
Widgets
Adding and Removing 37
Moving to a Different Screen 37
Settings 207
Stopwatch 162
Wi-Fi
About 217
Activating 58, 217
Calling 58
Connecting to 218
Deactivating 219
Direct Connection 223
During Sleep 221
MAC Address 222
Manually Adding Network 219
Manually scan for network 219
Off 219
On 141, 218, 219
Settings 217, 220
Show Usage 230
Sorting Entries 220
Status icons 218
Wi-Fi Calling 9
Activating 59, 239
Connection Preferences 59, 239
Icons 60
Launching 60
On 239
Settings 59, 239
Wi-Fi Direct 223
Activate and Connect 223
On 141, 223
World Clock
DST Settings 162
WPA2 PSK 236, 237
WPS PIN
Pairing 223
WPS Push Button
Connect 222
Pairing 222
Y
Yahoo! 179
YouTube
High Quality 215
Settings 213

Navigation menu
