Sande Dacom Electronics G02S Bluetooth Headset User Manual
Shenzhen Sande Dacom Electronics Co., Ltd. Bluetooth Headset
User Manual
Function & Operation Function & Operation
Safety Precaution
Function & Operation
Power On:Long press MFB button for 2 seconds
while on power- off status, the blue light will flash
for 1 time and with voice prompt“power on”.
Power Off: Long press MFB button for 3 seconds
while on power- on status, the red light will be
bright for 2 seconds and then go out, with voice
prompt“power off”.
Pairing:Press and hold the MFB button until the red
and blue indicators flash alternately, when on
power- off status.
Bluetooth connection: Search“G02S”on cellphone
and click it then the earphone enter into the
pairing mode,then the earphone will connect to
the mobile.
Last number redial: Double click MFB button to call
the last number while standby status.
Incoming call answer: Short press MFB button to
answer the call while there is a incoming call.
Call hang up: Short press MFB button to hang up the
call while calling.
Incoming call reject: Long press V- button for 2
seconds to reject call.
Mute switch: press V- button for 2 seconds for call/
mute switch.
Audio transitions: Press Vol+ button for 2 seconds for
audio switch.
Low-power warning: The red light will flash 1 time
every 20 seconds ,voice prompt with“battery
low”every 60 seconds.
Low-power and turn off: Battery with low voltage and
automatic turn off.
Volume adjustment: Short press V+ or V- button, the
volume will increase or decease one bar.
Music pause: Short press MFB button while music
playing status.
Music play: Short press MFB button while music
pause status.
Previous song: Long press V- button for 2 seconds
while music playing status.
Next song: Long press V+ button for 2 seconds while
music playing status.
Voice dialing: Please long press the MFB button for
2 seconds and then release while standby
status.(Your cellphone shall support this
function).
Connect with two devices: 1. turn off the bluetooth
function after paired to the first cellphone; 2.
pair to the second cellphone; 3.Turn on the
bluetooth function on the first cellphone and
connect to the bluetooth by hand.
1.Do not tear down or modify the earphone.Or it might
be damaged or malfunctioned.Losses due to resort
are not under warranty.
2.Do not use in the environments where Ingress
Protection (IP) rating exceeds limitation or expose to
excess humidity.Damages resulting from liquid is not
under warranty.
3.Do not expose the earphone sin extreme weather
(below 0°C degree or above 45°C degree).
4.Keep the earphones indicating light away from
children or animal eyes.
5.Do not use the earphone in thunderstorm weather
which might cause malfunction and increase the risk
of electric shock.
Eliminate info:Long press MFB button 5 seconds to
remove the paired data from earphones while on
charging status.
Charge:Time for charge is about 1.5- 2 hrs ,the red
light will bright while on charging status, the blue
light will light when full- charged.
Battery Warning
The product contains built- in lithium battery. To avoid
explosion, please do not expose product under intense
sunlight, and keep it away from the fire. Dispose the
lithium battery according to your local laws and
regulations,do not dispose it as regular household
garbage.Unless a special instrument is given in your
manual or quick start manual,the lithium battery should
not be took out or replaced by the user, or the product
might be damaged and cause other dangers.
FCC Warning
Any Changes or modifications not expressly approved
by the party responsible for compliance could void the
user’s authority to operate the equipment.
Warranty card
small
meddium
big
www.ucomx.com
Package Contents Quick Guide
earphones USB charging cable
Rubber coversX6User Manual WingtipsX6
Please choose rubber covers with suitable size. User Interface
Place the suitable rubber cover to the proper position.
small medium big Multi- Function
Button(MFB)
Volume+(v+)
Volume- (v- )
Charging port
MIC
LED light
Multi- Function
Buttons(MFB)
LED light
Pairing: Long press the MFB button till the blue and
red light flash alternately to show the paring
status, the LED light will go out when the
bluetooth device is connected and paired
successfully。
Quick Guide
Lightsport (G02S)
Wireless earphonesUser Manual
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment.
This transmitter must not be co- located or operating
in conjunction with any other antenna or transmitter.
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and
receiver.
—Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/TV
technician for help.
Note: This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Shenzhen Sande Dacom Electronics Co., Ltd.
ADD: 2/4/5F, Building I, NO.10 East Area of ShangXue
Science&Technology Industrial Park, BanTian street
LongGang district, Shenzhen, China
Frequency range: 2402-2480MHz for
CE, 2402-2480MHz for
FCC output power: 6.22dBm for CE, 6.46dBm for FCC
