Sande Dacom Electronics G37 Sport Bluetooth Headset User Manual G37 V1
Shenzhen Sande Dacom Electronics Co., Ltd. Sport Bluetooth Headset G37 V1
user manual
http://www.china-dacom.com
运动蓝牙耳机
CH
非常感谢您选用运动蓝牙耳机，请在使用前，详
细阅读本说明书，正确操作使用，更好发挥产品优越
性能。我司蓝牙耳机外观设计时尚绚丽、小巧便携、
音质纯美、多功能一体化设计，全系列拥有外观设计
专利，系统上采用了行业领先电声技术，使您在居家
使用、户外旅行、商务工作中随时随地享受到卓越的
音响效果，为您的笔记本电脑、数码音乐播放器等视
听产品提供超值完美的音质，带您聆听美妙音乐，感
受健康快乐生活！
前 言
尊敬的用户:
大康 蓝牙耳机
Preface
注意事项 / 温馨提示
Precautions / Tips
注意事项：
请在常温环境中存放以及使用本产品；
请勿将本产品暴露在雨中或潮湿环境中；
请勿丢掷，避免因跌落造成产品损坏；
请勿自行拆解、修理和改造本产品；
请勿使用化学溶剂擦拭本产品；
如有需要,请使用输出电压DC5V的USB电源充电器来
充电；
请勿随意丢弃,或置于高温(温度高于60度)与火中，以
免引起危险！
产品描述
Product Description
产品名称：G37运动蓝牙耳机
蓝牙版本：V4.1
充电方式：电源适配器输入(DC4.8-6.0V 100mAh)
电池指标：高性能锂聚合物锂电池
蓝牙指标：Class 2
支持协议：Headset/Handsfree/A2DP/AVRCP
持续通话时长：约7小时
持续播放时长：约5小时
待机时长: 约200小时
产品示意图
Product schematic
功能介绍
Features
功能介绍
Features
功能介绍
Features
开机-在关机状态下，长按"MFB"键2秒，蓝灯闪一下。
关机-在开机状态下，长按"MFB"键3秒，红灯长亮约
1秒。
备注：两台手机同时使用一台蓝牙耳机，部分功能将受到限制。
按配对步骤，配对第一个手机后，将手机蓝牙功能
关闭，再配对第二个蓝牙手机；
打开第一个手机的蓝牙功能，手动连接第一部手机。
通话时，短按"MFB"键挂断当前电话，接通等待电话；
双击"MFB"键，接听第二个来电，以及两个通话之间
切换；
短按"MFB"键，可以逐一挂断电话。
一个耳机连接两个手机：
废弃电器和电子设备
本产品或附有如下标识的产品,寿命结束时不应与其它
家庭废物一起处理。
为了防止因废物受理不受控制而可能
使环境或人身健康受到损害，请将本
产品与其他类型的废物分开，并负责
任地回收本产品，以促进可持续地重复利用材料资源。
请与本产品的零售商或当地相关机构联系，了解家庭
用户对电子产品环保回收条例，进行适当的回收。
企业用户应与其供应商联系并检查采购合同的条款和
条件，本产品不应与其他商业废品混在一起处理。
客户服务时间：周一至周六9:00-18:00 (节假日除外)
关于售后服务的说明：
1.购机日期以本凭证或购机发票为准,不能提供有效证明的，
以生产日期为准。
2.质量问题不包括用户个人对音质、音色等主观差异。
3.外壳、说明书包装不在保修服务范围内。
4.已停产机型，本公司仅做功能性修复。
5.经销商向您做出的非本公司保证的承诺,本公司不承担任
何责任。
④ 无有效三包凭证和有效发票
(能证明产品确属服务期内者除外)。
⑤ 因不可抗拒如地震、火灾、水灾、雷击等导致的产品
故障或损坏。
⑥ 未经本公司许可，擅自拆卸、修理或改装。
售后服务条例：
1.咨询服务：用户在使用产品前，请仔细阅读本产品的使
用说明书。在使用过程中遇到的如何问题，均可与当地
经销商联系，或致电全国统一客服热线 400-881-0138
2.包换服务：包换期内(自购机之日起七日内)，正常使用
出现了非人为故障，请保持产品、配件和包装的完整(若
外观不损坏、作保修处理)经检测确认故障后，可选择换
货或维修，用户可到当地授权经销商处)联系并处理。
3.保修服务：保修期内，正常使用出现的非人为故障，均
可享受免费保修服务(主机一年内免费保修，若人为损坏，
作收费维修处理)。
4.收费维修服务：产品在自购机之日起一年到三年内，出
现故障可收费维修，用户需支付维修所产品的元件费、
运输费及人工费。
5.以下情况不在三包范围内，本公司提供有偿服务：
① 超过三包期限
② 涂改三包凭证，或序列号与产品本身不符
③ 意外因素或人为导致的产品损坏(如:未按使用说
明书操作、维护或保管,安装错误造成的故障，接入不
合适的电源、进水、摔坏等)
全国统一服务热线：
为了维护您的权益，请您认真填写，并妥善保管，作为维修时的认证
经销商信息
用户信息
产品型号 经销商名称
产品序列号 联系电话
联系电话
销售日期用户地址
通讯地址
E-mail
废弃电器处理
Handling of the Waste Electrical
售后服务条例与说明
Service Regulations and Explanation
Enjoy the freedom
Movement freely
接听电话-在来电状态下，短按一下“MFB”键
接听电话，每8秒蓝灯闪1下。
挂断电话-通话中或去电中，短按一下“MFB”键
挂断。
拒接电话-来电状态下，长按“V-”键2秒。
末号重拨-连机待机和听歌状态下,双击“MFB”键
自动重拨最后拔出的号码。（注：须手机
支持BLUETOOTH重拔模式）
音乐播放-在音乐播放状态下短按“MFB”键可进
行播放/暂停。
翻曲选择-播放中长按“V-”键约2秒进入上一曲
长按“V+”键2秒将会进入下一曲
音量调节-听歌和通话状态下，短按一下“V+”键
声音增大，短按一下“V-”键,声音减小。
全国统一服务热线：400-881-0138
蓝牙首次配对时，请将蓝牙耳机和手机的距离控制
在1米的范围内；
关机状态下长按"MFB"键直到红绿灯交替闪烁再松开；
开启手机蓝牙功能,搜索蓝牙设备;
选择“
G37
”耳机;
输入配对密码“００００”（有些手机需要密码配
对，有些手机不需要密码配对。）
配对失败后，请重复上述操作;
如果配对成功后，绿灯闪烁。
蓝牙配对步骤
当开机时，耳机会自动语音提示："Power on"。
当关机时，耳机会自动语音提示："Power off"。
当配对成功时，耳机会自动语音提示:
"Your headset is connected"。
当连接断开时，耳机会自动语音提示：
"Your headset is disconnected"。
当电量低时，耳机会自动语音提示：
"Battery low”。
语音提示
静音切换-通话中，按“V- ”键约2秒，关闭/打开
麦克风。
低电报警-开机状态中,当电池电压低于3.3V后每
隔60秒发出一次提示音并闪红灯。
低电关机-开机状态中,当电池电压低到3.1V时耳
机将自动关机。
充电指示-充电过程中亮红灯,电池充满时亮绿灯。
语音拔号-在连机待机状态下，长按"MFB"键约2秒释放。
（仅支持有语音拨号功能的手机）
通话转换-在通话过程中长按“V+”键2秒音频从
蓝牙切换到手机，再长按“V+”键2秒，
音频从手机切换回耳机。
备注：部分功能操作会因手机的不同而有所改变，请用户在实际
操作时留意
。
Enjoy the freedom
Movement freely
Enjoy the freedom
Movement freely
60MM
80MM
音量+
(V+)
咪孔 指示灯
产品型号:炫风
耳挂
多功能键
( MFB)
USB充电口
入耳式听筒
音量+
(V+)
咪孔
音量-
(V-)
指示灯
Preface
Dear Customer
Thank you for choosing Sport BluetoothHeadset.
Please read the user manual carefully for proper instruction
to maximize the advantage of our product. Our Bluetooth
headset are well designed,fashion, smart and portable,
pure acoustic and multi functional. We have patents for the
whole series of our Bluetooth headsets.Our Bluetooth
headsets are applied with the top advanced electro acoustic
technology, providing you the best enjoyment of music any
time at home, outdoor or business work, and provide the
perfect acoustic with your notebook and any digital
audio/visual devices.Lead you to wonderful music,enjoy
healthy & happy life.
Precautions / Tips
Cautions
Please keep or use this product at normal temperature;
Do not expose this product in rain or moisture;
Do not throw this product in case any damage thus made;
Do not disassemble, repair or reform this product;
Do not clean this product with any chemical solvents;
Please use USB power of DC5V for output when
needed;
Do not throw away or put it in fire to avoid any danger.
Product Description Product Schematic
Sport Bluetooth Headset Model NO.: Colorwind
Ear Bud Tip
Ear HookUSB Charging Socket
Multifunction Button
( MFB)
MIC Indicator
Light
Volume Down
(V-)
Volume Up
(V+)
Item: G37 Sport Bluetooth Headset
Bluetooth standard: V4.1
Charging means: power adapter output(4.8-6.0V 100mAh)
Battery: High-capability rechargeable lithium polymer battery
Bluetooth Operation: class 2
Profiles Supported: Headset/Handsfree/A2DP/AVRCP
Talk time: up to 7 hours
Playing time: up to 5 hours
Stand by time: up to 200 hours
Features Features
Handling of the Waste Electrical
The waste Electrical
This marking shown on the product or its literature indicates that it
should not be disposed with other household wastes at the end of its
working life.
Household user should contact either the retailer where they purchased
this product or their local government office, for details of where and
how they can take this item for environmentally safe recycling.
To prevent possible harm to the environment or human health from
uncontrolled waste disposal, please separate this from other types of
wastes and recycle it responsibly to promote the sustainable reuse of
material resources.
Business users should contact their supplier and check
the terms and conditions of the purchase contract.
This product be mixed with other commercial wastes
for disposal. should not
Service Regulations and Explanation
After service
(A) Service system
1.Consultancies: Please read this user manual carefully before using
this product. For any problem during using it, you can contact your
seller.
2.Exchange service: within exchange time limit, for any indeliberate
error during proper use, making sure the product as well as its
accessories and package are all not damaged (if the appearance
is damaged, it can only be repaired) you can either have it exchanged
for a new one or repaired after the error is tested and examined;
3.Warranty service: within the warranty time limit, for any indeliberate
error that occurs during proper use, warranty service is free for no
charge (the headphone has warranty service for free within one year;
for any deliberate damage, the warranty service should be paid).
4.Charged warranty service: within three years counting from one year
after the date the product was purchased, any error repair will be
charged; and user should pay the repair components, freight and
labor cost.
(B) Explanation of After Service:
1.The date of purchased should be in accordance with that of the
invoice, any failure to provide the valid proof, is subjected to the
production date.
2.Quality problem does not include user’s personal preference to tone
and timbre.
3.The shell and user manual package are exclusive to warranty service.
4.For the model that production has been stopped, we only provide
functional repair.
5.We are not responsible for any promises by retailer other than our
company.
5.Any of the below situation is not in the warranty service, but we
provide charged service:
Features
Power on: Long press the" MFB " button until the green
indicator light flashes.
Power off: With the headset power on, long press the
" MFB" button for 3 seconds,the red indicator light flashes
2 seconds and goes off.
Volume control: Volume will be up when short press
the " V+" and will be down when short press the " V-" .
Answering a call: Press the answer key on your phone
or short press the" MFB " button on your headset.
Charging: The red light reminds solid when charging,
red light turns green light, the charging is completed.
Ending a call: Press the end key on your phone or
short press the " MFB " button on your headset.
Rejecting a call: Press the end key on your phone or long
press the " V-" button for 2 seconds on your headset.
Redialing the last called number: Double press the
" MFB" button when headset is in standby mode.
Play/Pause: When you are listening to the music from
the headset, you can short press the " MFB " button to play
and pause.
Previous/Next Track: Previous Track when press the " V-"
2 seconds. Next Track when press the " V+" 2 seconds.
Microphone muting: During a call, press " V-" for about 2
seconds, microphone is muted; press " V-" again for
about 2 seconds it will work again.
Pair the bluetooth headset for the first time,the distance
between the Bluetooth headset and your Bluetooth phone
would be better within 1 meter when pairing.
When the headset is off, press and hold the " MFB " until
the red and green lights flash alternately.
Start mobile phone bluetooth function.
Search bluetooth device, choose " G37" .
Input pair code" 0000" (The password is required for some
phones.)
Repeat above-mentioned steps if the pairing was unsuccessful.
The green light will flash if paired successfully.
Pair to your Bluetooth Phone
Connect two Bluetooth mobile phones at the same time
After paired the first mobile phone, please turn off the
Bluetooth function of the first mobile phone, then pair to the
second Bluetooth mobile phone.
Open Bluetooth function of the first mobile phone, and
Manually get it connected.
During a call, short press the " MFB " to answer the incoming
call.
Double press the " MFB " to answer another incoming call
while the first call is held on , and can switch between the two
incoming call by double pressing the " MFB " .
Short press the "MFB" to cut off the incoming calls one by one.
Important:Different mobile phone brands or menu functions, the
usage will be different. Please read your phone's manual carefully.
Low power alarm: In the power on state, if the battery voltage
is lower than 3.3V, there will be issued a prompt and the red
indicator light flashes every 60 seconds.
Low power shutdown: In the power on state, if the battery
voltage is lower than3.1V, The headset will automatically
shutdown.
Call switching
:
During a call, long press“V+”for 2 seconds�
the audio will be switched from the Bluetooth headset to mobile
phone
.
Do it again
,
the audio will be switched from mobile phone
back to the Bluetooth headset
.
Voice Prompt
When the headset is on, there will be the automatic voice
prompt: power on
When the headset is off, there will be the automatic voice
prompt: power off
When being connected successfully, there will be automaic
voice prompt: your headset is connected
When being disconnected,there will be automatic voice
prompt: you headset is disconnected
When the battery is low,there will be voice prompt:battery low
Voice dialing-On the status of standby, long press " MFB"
for about 2 seconds.
The warranty date is expired;
The warranty card is altered, or the series number differs from
that of the product;
Accidental or deliberate damage is done to the product ( for
example: improper use against the user manual, improper set
up which causes error, plugging in unmatched power, exposed
to water, fallen etc.)
cannot provide valid warranty card or invoice ( other but can prove
that it is within the service limit);
Any error damage caused by force majeure such as earthquake,
fire, flood, lightning strike etc.
Deliberate assembling, repair or reform without permission from
our company.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment.
This equipment has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.
This equipment generate, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not expressly approved by the party responsible
compliance could void the user's authority to operate the equipment.
interference that may cause undesired operation.
Model NO.: G37
产品型号:炫风
