Sande Dacom Electronics M06 Mono Bluetooth Headset User Manual
Shenzhen Sande Dacom Electronics Co., Ltd. Mono Bluetooth Headset
user manual
PANTONE 877 C
PANTONE 877 C
B User Manualluetooth Headset
M06
Thank you for choosing“ " Bluetooth Headset.
Please read the user manual carefully for proper
instruction to maximize the advantage of our
product. Our Bluetooth headset are well designed,
fashion, smart and portable, pure acoustic and multi
functional. We have patents for the whole series of
our Bluetooth headsets. Our Bluetooth headsets are
applied with the top advanced electro acoustic
technology, providing you the best enjoyment of
music any time at home, outdoor or business work,
and provide the perfect acoustic with your notebook
and any digital audio/visual devices. Lead you to
wonderful music, enjoy healthy & happy life.
M06 Please keep or use this product at normal
temperature;
Do not expose this product in rain or moisture;
Do not throw this product in case any damage thus
made;
Do not disassemble, repair or reform this product;
Do not clean this product with any chemical solvents;
Please use USB power of DC5V for output when needed;
Do not throw away or put it in fire to avoid any danger.
Item: Bluetooth Headset
Bluetooth standard: V4.2
Charging means: USB charge DC5V
Battery: High-capability rechargeable lithium polymer
battery
Bluetooth Operation: class 2
Profiles Supported: Headset/Handsfree/A2DP/AVRCP
Talking time: About 4 hours
Playing time: About 4 hours
Standby time: About 100 hours
For the optimal audio experience,try each of the ear gels,
It should be tight and secure in your ear.
SL
Step 1
Step 2
MIC 1
MIC 2
Power on: Long press the"ON/OFF" button until the green
indicator light flashes.
Power off: With the headset power on, long press the
"ON/OFF" button for 3 seconds, the red indicator light
flashes 1 second and goes off.
Charging: The red light reminds solid when charging；red
light turns green light, the charging is completed.
Answering a call: Press the answer key on your phone or
short press the"MFB" button or short press "ON/OFF "
button on your headset.
Ending a call: Press the end key on your phone or short
press the " MFB " button or short press "ON/OFF " button
on your headset.
Rejecting a call: Press the end key on your phone or long
press the "MFB" button for 2 seconds on your headset.
Redialing the last called number: Double press the " MFB"
button when headset is in standby mode.
Play/Pause: When you are listening to the music from the
headset, you can short press the " MFB " button to play
and pause.
Previous/Next Track: Previous Track when press the " V+" 2
seconds. Next Track when press the "V-" 2 seconds.
Volume control: Volume will be up when short press the "
V+" and will be down when short press the " V-" .
Microphone muting: During a call, press " V-" for about 2
seconds, microphone is muted; press " V-" again for about
2 seconds it will work again.
Chinese/English voice prompt switch: Double click on the
“ MFB " button while in the pairing mode.
Pair the bluetooth headset for the first time,the
distance between the Bluetooth headset and your
Bluetooth phone would be better within 1 meter
when pairing.
When the headset is off, press and hold the " MFB "
until the red and green lights flash alternately.
Start mobile phone bluetooth function.
Search bluetooth device, choose "M06" .
Input pair code" 0000" (The password is required for
some phones.)
Repeat above-mentioned steps if the pairing was
unsuccessful.
The green light will flash if paired successfully.
When the headset is on, there will be the automatic
voice prompt: power on
When the headset is off, there will be the automatic
voice prompt: power off
When being connected successfully, there will be
automatic voice prompt: connected
When being disconnected, there will be automatic
voice prompt: device disconnected
When the battery is low, there will be voice prompt:
battery is low
Voice dailing: when in standby mode, short press the
power button one time followed by one beep, speak
"voice dial" to dial.
Low power alarm: In the power on state, if the battery
voltage is lower than 3.3V, there will be issued a prompt
and the red indicator light flashes every 60 seconds.
Low power shutdown: In the power on state, if the
battery voltage is lower than3.0V, The headset will
automatically shutdown.
Call switching: During a call, long press“V+”for 2
seconds，the audio will be switched from the
Bluetooth headset to mobile phone. Do it again，the
audio will be switched from mobile phone back to the
Bluetooth headset.
After paired the first mobile phone, please turn off the
Bluetooth function of the first mobile phone, then pair
to the second Bluetooth mobile phone.
Open Bluetooth function of the first mobile phone,
and manually get it connected.
During a call, short press the "MFB" to end the current
call and answer the incoming call.
Double press the "MFB" to answer another incoming
call and switch between the two incoming calls.
Short press the "MFB" to cut off the incoming calls one
by one.
This marking shown on the product or its literature
indicates that it should not be disposed with other
household wastes at the end of its working life.
To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please separate
this from other types of wastes and recycle it responsibly
to promote the sustainable reuse of material resources.
Household user should contact either the retailer where
they purchased this product or their local government
office, for details of where and how they can take this item
for environmentally safe recycling.
Business users should contact their supplier and check the
terms and conditions of the purchase contract. This
product should not be mixed with other commercial
wastes for disposal.
1、Consultancies: Please read this user manual carefully
before using this product. For any problem during using it,
you can contact your seller.
2、Exchange service: within exchange time limit, for any
indeliberate error during proper use, making sure the
product as well as its accessories and package are all not
damaged (if the appearance is damaged, it can only be
repaired) you can either have it exchanged for a new one
or repaired after the error is tested and examined;
3、Warranty service: within the warranty time limit, for any
indelibe- rate error that occurs during proper use,
warranty service is free for no charge (the headphone has
warranty service for free within one year; for any
deliberate damage, the warranty service should be
paid).
4、Charged warranty service: within three years counting
from one year after the date the product was purchased,
any error repair will be charged; and user should pay the
repair components, freight and labor cost.
5、Any of the below situation is not in the warranty
service, but we provide charged service:
a. The warranty date is expired;
b. The warranty card is altered, or the series number differs
from that of the product;
c. Accidental or deliberate damage is done to the product (
for example: improper use against the user manual,
improper set up which causes error, plugging in
unmatched power, exposed to water, fallen etc.)
d. Cannot provide valid warranty card or invoice ( other
but can prove that it is within the service limit);
e. Any error damage caused by force majeure such as
earthquake, fire, flood, lightning strike etc.
f. Deliberate assembling, repair or reform without
permission from our company.
Explanation of After Service:
1. The date of purchased should be in accordance with that
of the invoice, any failure to provide the valid proof, is
subjected to the production date.
2. Quality problem does not include user's personal
preference to tone and timbre.
3. The shell and user manual package are exclusive to
warranty service.
4. For the model that production has been stopped, we
only provide functional repair.
5. We are not responsible for any promises by retailer
other than our company.
Preface
Dear Customer
Cautions
Cautions
Features Features Features
Pair to your Bluetooth Phone
Connect two Bluetooth mobile phones at the same time
Voice Prompt
Important:Different mobile phone brands or menu
functions, the usage will be different. Please read
your phone's manual carefully.
Product Description
Handling of the Waste Electrical
The waste Electrical
Service Regulations and Explanation Service Regulations and Explanation
After service
Product Schematic
Volume Up (V+)
ON/OFF
Volume Down (V-)
Multifunction Button
( MFB)
Indicator Light
USB
Charging
Socket
HOW TO WEAR
SELECT THE CORRECT EARGEL SIZE
It has dual-mic noise reduction, which filters the
environmental noise intelligently, so this gives
you the peaceful mind and quietness.
背面
蓝牙耳机说明书
M06
非常感谢您选用 "M06" 商务蓝牙耳机 请在使用前
详细阅读本说明书，正确操作使用，更好发挥产品优越性
能。我司蓝牙耳机外观设计时尚绚丽、小巧便携、音质纯
美、多功能一体化设计，全系列拥有外观设计专利，系统上
采用了行业领先电声技术，使您在居家使用、户外旅行、商
务工作中随时随地享受到卓越的音响效果，为您的笔记本电
脑、数码音乐播放器等视听产品提供超值完美的音质，带您
聆听美妙音乐，感受健康快乐生活！
， ，
前 言
尊敬的用户:
请在常温环境中存放以及使用本产品；
请勿将本产品暴露在雨中或潮湿环境中；
请勿丢掷，避免因跌落造成产品损坏；
请勿自行拆解、修理和改造本产品；
请勿使用化学溶剂擦拭本产品；
如有需要,请使用输出电压DC5V的USB电源充电器来充电；
请勿随意丢弃,或置于高温(温度高于60度)与火中，以免引起
危险！
注意事项 / 温馨提示 产品描述
注意事项: 产品名称：商务蓝牙耳机
蓝牙版本：V4.2
充电方式：USB 充电 DC5V
电池指标：高性能锂聚合物锂电池
蓝牙指标：Class 2
支持协议：Headset/Handsfree/A2DP/AVRCP
持续通话时长：约4小时
持续播放时长：约4小时
待机时长: 约100小时
为了获得最佳的音频体验和舒适感, 请选择正确的耳塞尺寸进
行佩戴。
选择正确的耳塞尺寸
SL
如何佩戴
Step 1
Step 2
产品示意图
MIC 1
MIC 2
指示灯
充电口
开/关
多功能键 (MFB)
音量+
音量-
开机: 长按"开/关"键直到绿灯闪烁。
关机: 在开机状态下，长按"开/关"键3秒，红色指示灯亮
1秒后熄灭。
接听电话: 按手机接听键接听或短按耳机“MFB”键或短
按"开/关"键接听。
挂断电话: 按手机挂断键挂断或短按耳机“MFB”键或短
按"开/关"键挂断。
拒接电话: 按手机挂断键或长按“MFB”键约2秒。
末码拨号: 在耳机处于待机状态下双击“MFB”键针对最
后一个拔出的电话号码进行重拔（注：须手机支持
BLUETOOTH重拔模式）
音乐播放: 在音乐播放状态下短按“MFB”键可进行播放
/暂停。
翻曲选择: 播放中长按“V+”键约2秒进入上一曲，长按
“V-”键2秒将会进入下一曲。
音量调节: 短按“V+”键或“V-”键,对音量进行调节，每
按一次音量增加或减少一格。
静音切换: 通话中按“V-”键约2秒，禁掉咪功能，再按
“V- ”键约2秒恢复咪功能。
中英文切换：在配对状态下双击“MFB”键切换中英文。
语音“接听/忽略”语音命令: 来电时，播报“来电”之后
3-5秒空档内说接听/忽略可以接听或者拒接电话。
功能介绍 功能介绍 功能介绍
当开机时，耳机会自动语音提示："开机"。
当关机时，耳机会自动语音提示："关机"。
当配对成功时,耳机会自动语音提示:"已连接"。
当连接断开时，耳机会自动语音提示："已断开"。
当电量低时，耳机会自动语音提示："电量低"。
蓝牙首次配对时，请将蓝牙耳机和手机的距离控制在
1米的范围内
开启手机蓝牙功能，搜索蓝牙设备。
选择“M06”耳机。
输入配对密码“0000”（有些手机需要密码配对，有些
手机不需要密码配对。）
配对失败后，请重复上述操作。
如果配对成功后，绿灯闪烁。
。
关机状态下长按"MFB"键直到红绿灯交替闪烁再松开。
蓝牙配对步骤
语音提示
备注：部分功能操作会因手机的不同而有所改变，
请用户在实际操作时留意。
低电报警: 开机状态中,当电池电压低于3.3V后每隔60秒
发出一次提示音并闪红灯。
低电关机: 开机状态中,当电池电压低到3.0V时耳机将自
动关机。
通话转换: 在通话过程中长按“V+”键2秒音频从蓝牙
切换到手机，再长按“V+”键2秒，音频从手机切换回
耳机。
充电指示: 充电过程中亮红灯,电池充满时亮绿灯。
按配对步骤，配对第一个手机后，将手机蓝牙功能关
闭，再配对第二个蓝牙手机；
打开第一个手机的蓝牙功能，手动连接第一部手机；
通话时，短按"MFB"键挂断当前电话，接通等待电话；
双击"MFB"键，接听第二个来电，以及两个通话之间切
换；
短按"MFB"键，可以逐一挂断电话。
一个耳机连接两个手机：
备注：两台手机同时使用一台蓝牙耳机，部分功能将受到限制。
本产品或附有如下标识的产品,寿命结束时不应与其它家庭废
物一起处理。
为了防止因废物受理不受控制而可能
使环境或人身健康受到损害，请将本
产品与其他类型的废物分开，并负责
任地回收本产品，以促进可持续地重复利用材料资源。
请与本产品的零售商或当地相关机构联系，了解家庭用户对
电子产品环保回收条例，进行适当的回收。
企业用户应与其供应商联系并检查采购合同的条款和条件，
本产品不应与其他商业废品混在一起处理。
1. 咨询服务：用户在使用产品前，请仔细阅读本产品的使用
说明书。在使用过程中遇到的如何问题，均可与当地经销
商联系，或致电全国统一客服热线 400-881-0138
2. 包换服务：包换期内(自购机之日起七日内)，正常使用出现
了非人为故障，请保持产品、配件和包装的完整(若外观不
损坏、作保修处理)经检测确认故障后，可选择换货或维
修，用户可到当地授权经销商处)联系并处理。
3. 保修服务：保修期内，正常使用出现的非人为故障，均可
享受免费保修服务(主机一年内免费保修，若人为损坏，作
收费维修处理)。
4. 收费维修服务：产品在自购机之日起一年到三年内，出现
故障可收费维修，用户需支付维修所产品的元件费、运输
费及人工费。
5. 以下情况不在三包范围内，本公司提供有偿服务：
① 超过三包期限
② 涂改三包凭证，或序列号与产品本身不符
③ 意外因素或人为导致的产品损坏(如:未按使用说明书操作、
维护或保管,安装错误造成的故障，接入不合适的电源、进
水、摔坏等)
④ 无有效三包凭证和有效发票 (能证明产品确属服务期内者
除外)。
⑤ 因不可抗拒如地震、火灾、水灾、雷击等导致的产品故障
或损坏。
⑥ 未经本公司许可，擅自拆卸、修理或改装。
1. 购机日期以本凭证或购机发票为准,不能提供有效证明的，
以生产日期为准。
2. 质量问题不包括用户个人对音质、音色等主观差异。
3. 外壳、说明书包装不在保修服务范围内。
4. 已停产机型，本公司仅做功能性修复。
5. 经销商向您做出的非本公司保证的承诺,本公司不承担任何
责任。
废弃电器处理
废弃电器和电子设备
售后服务条例与说明 售后服务条例与说明
售后服务条例 关于售后服务的说明
客户服务时间：周一至周六 9:00-18:00 ( 节假日除外 )
全国统一服务热线：
具备双咪降噪功能，智能过滤环境噪音，如身临其境，
给您想要的安静。
正面
80.00 mm
130.00 mm
语音拔号: 在连机待机状态下，短按"开/关"键1下，提示音
后说“语音拔号”。
（仅支持有语音拨号功能的手机）
