Quick Start Guide
WirelessWireless
LabelWriter®
Wireless
Copyright
© 2017 Sanford, L.P. All rights reserved. Revised 6/17.
No part of this document or the software may be reproduced or transmitted in any form or by any means, or translated
into another language without the prior written consent of Sanford, L.P.
Trademarks
DYMO, LabelWriter, and DYMO Label are registered marks in the United States and other countries. All other trademarks
are the property of their respective holders.
FCC Compliance
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
1
For complete information on using your label printer, download the
DYMO LabelWriter User Guide from one of the following locations
Register at www.dymo.com/register
Registering your product ensures that you will receive any
news and updates. During the registration process, you will be
asked to enter the serial number for your label printer. The
serial number is located on the bottom of the printer.
Connecting the Power
From the User Guide link on the DYMO Label
software Help menu
Use the QR code at the left
From support.dymo.com
Plug the power cord into the power adapter and plug the
power adapter into the power connector on the back of the
printer.
Plug the other end of the power cord into a power outlet.
Press on the side of the printer to turn on the power.
Serial number on
bottom of label printer
Power cord
Power adapter
1
Power USB
WPSRESET
2
3
Quick Start Guide
2
Loading Labels
Lift to open the top cover.
Place the label roll on the spindle so that the labels feed
from underneath and the left edge of the label roll is firmly
against the side of the spool.
Press the spool guide tightly against the side of the label roll,
leaving no gap between the roll and the spool.
Insert the label spool into the slot in the printer with the
labels extending from underneath the roll.
Align the left edge of the label with the left edge of the label
feed slot and insert the label into the slot.
The printer automatically feeds the label, stopping at the
beginning of the first label.
Slide label guide against labels.
IMPORTANT! In order for the labels to feed properly:
Make sure the power is turned on.
Insert the label with the left edge against the left edge of the
label feed slot.
Press the label spool guide flush against the label roll,
leaving no gap.
2
3
4
5
6
1
2
3
4
5
6
3
Connecting the Printer to your Wireless Network
You can connect the printer to your network using the Wi-Fi Protected Setup (WPS) button or by
accessing the Quick Setup wizard on the printer. Refer to the documentation that came with
your router or access point to determine the connection methods supported.
Connecting the Printer using WPS
Many routers are WPS-enabled allowing you to easily connect the printer to a wireless network.
When the printer is connected successfully, the wireless status light will be solid.
Connecting the Printer using the Quick Setup Wizard
When the printer is connected successfully, the wireless status light will be solid.
Press the WPS button on the back of the printer.
The wireless status light on the side of the printer will glow.
Press the WPS button on your router within two minutes.
After the printer has been turned on for a few seconds, on your computer connect to the
wireless network named DYMOLWWxxxxxx. This unique printer name can be found on the
bottom of the printer.
In your browser, enter the following URL: http://192.168.58.1
Log in to the LabelWriter Web Configuration pages using the following:
Username: admin
Password: admin
Follow the configuration wizard to configure the printer on your wireless network.
1
2
1
2
3
4
4
Printing Labels
You can design and print labels using DYMO Label software on
your computer or the DYMO Connect app on your mobile
device.
Printing Labels from Your Computer
Before you can print labels, you must install DYMO Label
software and then add the network printer to your computer.
OS X If the printer is not shown in the printer list when the installation is complete, refer
to the DYMO Label ReadMe file located in the installation folder for instructions on how to
add the printer.
Download and install the latest version of DYMO Label
software from support.dymo.com.
Start the software and do one of the following:
If this is the first DYMO label printer installed, click
Ye s
when prompted by the software to
add the label printer as a wireless printer.
If a DYMO label printer is already installed, choose
Add Network Printer
from the
File
menu.
Follow the instructions in the Add Network Printer tool.
1
2
3
5
Printing Labels from your Mobile Device
You can design and print labels from a mobile device using the DYMO Connect
mobile app available on the Apple® App store or the Google Play™ store.
Refer to the Troubleshooting section of the DYMO LabelWriter User Guide if you have problems
connecting to the printer.
From your mobile device’s app store, search for DYMO Connect or use the
appropriate QR Code below.
Install DYMO Connect.
Tap to open the app and select the LabelWriter Wireless printer.
1
2
3
6
2-Year Limited Warranty for Your DYMO Electronic Product
Your electronic DYMO product is sold with a 2-year warranty from the date of purchase against defects in material and
workmanship. This commercial warranty applies in addition to any applicable statutory guarantee, but the warranty periods
will run coterminously. DYMO will repair or replace your product free of charge on the following conditions:
1Products returned under this warranty must be accompanied by a description of the defect together with a copy of the
product’s proof of purchase and your full contact and delivery details: name, telephone, complete address – street,
house number, postal code, city, country.
2Products returned to DYMO must be adequately packaged. DYMO will accept no liability for goods lost or damaged in
transit from the customer.
3Products must have been used strictly in accordance with operating instructions supplied. DYMO will have no liability
for defects caused by accident, misuse, alteration or neglect.
4DYMO accepts no liability for any consequential loss, damage or expense of any kind resulting from the machines or
accessories or the use thereof, save that liability for death or bodily injury caused by such products is not excluded and
any other liability that cannot lawfully be excluded.
5DYMO label printers are designed for use only with DYMO-branded labels. This warranty does not cover any
malfunction or damage caused by the use of third-party labels.
6This warranty does not affect your statutory rights as a consumer.
What to do if your product is defective?
DYMO offers you the following service options:
DYMO Web site: In most situations a visit to www.dymo.com will give you the right assistance. In the Customer Support
area, you will find information about your DYMO product, such as Frequently Asked Questions and solutions to known
problems. The User Guide also gives you additional information.
Dealer: Your DYMO dealer can help you to determine the exact nature of the problem and assist you further.
DYMO Help Desk: You can also contact the DYMO Help Desk where an associate will help you to determine the exact
nature of the problem and advise you what to do next:
US 877 724-8324 Intl +44 203 564 8356
Repair Center: You can send your defective product to a DYMO repair center (please see the above-mentioned
conditions 1 and 2 on how to replace a defective product). The address of your nearest DYMO repair center can be
found at www.dymo.com or you can contact the DYMO Help Desk.
7
Printing Postage with DYMO Stamps
To install DYMO Stamps and print postage, sign up for your
no-monthly-fee DYMO Stamps account with Endicia. Go to:
www.endicia.com/dymostamps
At the end of the sign up process, download and install the
DYMO Stamps software. Refer to the DYMO Stamps online
Help for more information about using the software.
NOTE You must have DYMO Label software and your
LabelWriter printer installed before installing the
DYMO Stamps software.
