24” CLASS LED-LCD HDTV
LED-LCD HDTV CATÉGORIE 24 PO
OWNER’S MANUAL
GUIDE D’UTILISATION
ATTENTION
ATTENTION
If you purchase a universal remote control from your local retailer, please contact the remote manufacturer for the
required programming code.
Si vous utilisez avec cet appareil une télécommande universelle (autre que celle vendue avec ce téléviseur),
consultez la documentation accompagnant la télécommande universelle afin de connaître le code numérique cor-
respondant au téléviseur.
AIR/CABLE MODE SELECTION
SÉLECTION DU MODE AIR/CABLE
When shipped from the factory, the Signal Type option is set to the “Cable” (Cable Television) mode.
If not using Cable TV, set this menu option to the “Air” position.
Lorsque l’appareil sort de l’usine, l’option Signal Type est en mode « Cable » (câblodistribution). Si vous
n’utilisez pas la câblodistribution, sélectionnez l’option « Air ».
Before operating the unit, please read this manual thoroughly.
Avant de faire fonctionner l’appareil, veuillez lire le présent guide attentivement.
IF CONTACT WITH CUSTOMER SERVICE IS REQUIRED
PLEASE HAVE THE MODEL NUMBER READY PRIOR TO THE CALL.
SI VOUS DEVEZ COMMUNIQUER AVEC LE SERVICE CLIENTÈLE, PRENEZ NOTE
DU NUMÉRO DE MODÈLE AVANT D’APPELER.
CUSTOMER SERVICE – 1-800-289-0980
SERVICE/SERVICE CLIENTÈLE: 1-800-289-0980
ORION WEBSITE
SITE WEB ORION
FOR INFORMATION ON OUR OTHER PRODUCTS, TO ORDER ACCESSORIES ONLINE,
OR FOR RECYCLING
INFORMATION, PLEASE VISIT OUR WEBSITE AT
POUR OBTENIR DES INFORMATIONS SUR NOS AUTRES PRODUITS, POUR COMMANDER DES ACCESSOIRES,
OU LE RECYCLAGE, VEUILLEZ VISITER NOTRE SITE WEB:
www.sansuiproducts.com
SLED2400
FRANÇAIS ENGLISH
J3NV0721A_EN.indd 1J3NV0721A_EN.indd 1 8/20/12 5:03:45 PM8/20/12 5:03:45 PM
EN 2
ENGLISH
Location of the required marking
The rating sheet and the safety caution are
on the rear of the unit.
The lightning flash with arrowhead
symbol, within an equilateral triangle
is intended to alert the user to the
presence of uninsulated dangerous
voltage within the product's enclosure
that may be of sufficient magnitude to
constitute a risk of electric shock.
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER
(OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
WARNING: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance with the
FCC Rules could void the user's authority to operate this equipment.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OPEN FLAMES AWAY
FROM THIS PRODUCT AT TIMES.
CAUTION: TO PREVENT ELECTRIC SHOCK. DO NOT USE THIS POLARIZED PLUG WITH AN
EXTENSION CORD, RECEPTACLE OR OTHER OUTLET UNLESS THE BLADES CAN BE
FULLY INSERTED TO PREVENT BLADE EXPOSURE.
Record the model number and serial number.
Model number _______________ Serial number _______________
FCC Declaration of Conformity Compliance Statement
(Part 15):
The Sansui SLED2400, LED-LCD HDTV complies with Part
15 of the FCC rules.
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2)
this device must accept any interference received, including
interference that may cause undesired operation.
The party responsible for compliance to these rules is:
ORION AMERICA,INC.
1105 SOUTH MAIN STREET PRINCETON, INDIANA
47670,U.S.A
Ph: 1-800-289-0980
J3NV0721A_EN.indd 2J3NV0721A_EN.indd 2 8/20/12 5:03:50 PM8/20/12 5:03:50 PM
3 EN
15) Apparatus should not be exposed to dripping or splashing, and objects filled with liquids, such as
vases, should not be placed on the apparatus.
16) An outside antenna system should not be located in the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall into such power lines or circuits. When installing an
outside antenna system, extreme care should be taken to keep from touching such power lines or
circuits, as contact with them might be fatal.
17) Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.
18) Do not push objects through any openings in this unit, as they may touch dangerous voltage points
or short out parts that could result in fire or electric shock. Never spill or spray any type of liquid into
the unit.
19) If an outside antenna or cable system
is connected to the unit, be sure the
antenna or cable system is grounded
to provide some protection against
voltage surges and built-up static
charges, Section 810 of the National
Electrical Code, ANSI/NFPA 70, provides
information with respect to proper
grounding of the mast and supporting
structure, grounding of the lead-in
wire to an antenna discharge unit, size
of grounding conductors, location of
antenna discharge unit, connection to
grounding electrodes, and requirements for the grounding electrode.
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
ANTENNA LEAD IN WIRE
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUND
CLAMP
ELECTRIC SERVICE
EQUIPMENT
NEC-NATIONAL ELECTRICAL CODE
S2898A
EXAMPLE OF ANTENNA GROUNDING AS PER THE NATIONAL ELECTRICAL CODE
IMPORTANT SAFETY INSTRUCTIONS
J3NV0721A_EN.indd 3J3NV0721A_EN.indd 3 8/20/12 5:03:51 PM8/20/12 5:03:51 PM
EN 4
IMPORTANT SAFETY INSTRUCTIONS
CHILD SAFETY:
It Makes A Difference How and Where You Use Your Flat Panel Display
Congratulations on your purchase! As you enjoy your new product, please keep these safety tips in mind:
THE ISSUE
The home theater entertainment experience is a growing trend and larger flat panel displays are popular
purchases. However, flat panel displays are not always supported on the proper stands or installed
according to the manufacturer’s recommendations.
Flat panel displays that are inappropriately situated on dressers, bookcases, shelves, desks, speakers,
chests or carts may fall over and cause injury.
THIS MANUFACTURER CARES!
The consumer electronics industry is committed to making home entertainment enjoyable and safe.
TUNE INTO SAFETY
One size does NOT fit all. Follow the manufacturer’s recommendations for the safe installation and use of
your flat panel display.
Carefully read and understand all enclosed instructions for proper use of this product.
Don’t allow children to climb on or play with furniture and television sets.
Don’t place flat panel displays on furniture that can easily be used as steps, such as a chest of drawers.
Remember that children can become excited while watching a program, especially on a “larger than life” flat
panel display. Care should be taken to place or install the display where it cannot be pushed, pulled over, or
knocked down.
Care should be taken to route all cords and cables connected to the flat panel display so that they cannot be
pulled or grabbed by curious children.
WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:
Use a mount that has been recommended by the display manufacturer and/or listed by an independent
laboratory (such as UL, CSA, ETL).
Follow all instructions supplied by the display and wall mount manufacturers.
If you have any doubts about your ability to safely install your flat panel display, contact your retailer about
professional installation.
Make sure that the wall where you are mounting the display is appropriate to support the weight of the unit/
product and wall mount. If you are unsure, contact a professional installer.
A minimum of two people are required for installation. Flat panel displays can be heavy.
20) When replacement parts are required, be sure the service technician uses replacement parts
specified by the manufacturer or those that have the same characteristics as the original part.
Unauthorized substitutions may result in fire, electric shock or other hazards.
21) Upon completion of any service or repairs to this unit, ask the service technician to perform safety
checks to determine that the unit is in proper operating condition.
22) When you connect the product to other equipment, turn off the power and unplug all of the
equipment from the wall outlet. Failure to do so may cause an electric shock and serious personal
injury. Read the owner's manual of the other equipment carefully and follow the instructions when
making any connections.
23) Sudden high volume sound may cause hearing or speaker damage. When you use headphones,
(if the unit is equipped with a headphone jack) keep the volume at a moderate level. If you use
headphones continuously with high volume sound, it may cause hearing damage.
24) Do not allow the product to output distorted sound for an extended period of time. It may cause
speaker overheating and fire.
25) This reminder is provided to call the cable TV system installer’s attention to Article 820-40 of the
NEC that provides guidelines for proper grounding and, in particular, specifies that the cable ground
shall be connected to the grounding system of the building, as close to the point of cable entry as
practical.
26) The socket-outlet must be installed near the unit and easily accessible.
J3NV0721A_EN.indd 4J3NV0721A_EN.indd 4 8/20/12 5:03:51 PM8/20/12 5:03:51 PM
5 EN
4 inches
Notes when mounting the TV on a wall
If the unit is to be mounted on the wall, contact the retailer where you
purchased the TV for advice, and have the equipment professionally
installed. Incomplete or improper installation may cause injury to you,
and/or damage to the TV.
Bracket holes: To attach a wall mounting bracket (not supplied) attach
where indicated in the drawing right.
This manufacturer recommends professional installation.
Utilize an appropriate bracket and fasteners, sufficient to
accommodate the size and weight of the unit.
Assure the wall to which the unit is to be mounted will safely support
the size and weight of the unit, using the bracket and fasteners you
have selected.
Keep cords and cables connected to this flat panel display out of
reach of children.
To hang the television on a wall, remove these screws and then
remove a stand. Before performing work spread cushioning over the
base area to lay the TV on.
Before wall-mounting, please check carefully the location of the TV’s
mounting-holes.
•
•
•
•
•
•
•
•
CONDENSATION
Moisture will form in the operating section of the unit if the unit is brought from cool surroundings into a warm
room or if the temperature of the room rises suddenly. When this happens, unit's performance will be impaired.
To prevent this, let the unit stand in its new surroundings for about an hour before switching it on, or make sure
that the room temperature rises gradually.
Condensation may also form during the summer if the unit is exposed to the breeze from an air conditioner. In
such cases, change the location of the unit.
HOW TO HANDLE THE LCD PANEL
Do not press hard or jolt the LCD panel. It may cause the LCD panel glass to break and injury may occur.
If the LCD panel is broken, make absolutely sure that you do not touch the liquid in the panel. This may cause
skin inflammation.
If the liquid gets in your mouth, immediately gargle and consult with your doctor. Also, if the liquid gets in your
eyes or touches your skin, consult with your doctor after rinsing for at least 15 minutes or longer in clean water.
Possible Adverse Effects on LCD Panel: If a fixed (non-moving) pattern remains on the LCD Panel for
long periods of time, the image can become permanently engrained in the LCD Panel and cause subtle but
permanent ghost images. This type of damage is NOT COVERED BY YOUR WARRANTY. Never leave your
LCD Panel on for long periods of time while it is displaying the following formats or images:
Fixed Images, such as stock tickers, video game patterns, TV station logos, and websites.
Special Formats that do not use the entire screen. For example, viewing letterbox style (16:9) media on
a normal (4:3) display (black bars at top and bottom of screen); or viewing normal style (4:3) media on a
widescreen (16:9) display (black bars on left and right sides of screen).
The following symptoms are not signs of malfunction but technical limitation. Therefore we disclaim any
responsibility for these symptoms.
LCD Panels are manufactured using an extremely high level of precision technology, however sometimes
parts of the screen may be missing picture elements or have luminous spots.
This is not a sign of a malfunction.
Do not install the LCD Panel near electronic equipment that produces electromagnetic waves. Some
equipment placed too near this unit may cause interference.
Effect on infrared devices – There may be interference while using infrared devices such as infrared cordless
headphones.
•
•
•
•
•
•
•
SAFETY PRECAUTIONS
The unit emits heat when in operation. Do not place any covers or blankets on the unit, this may cause overheating.
Do not block ventilation holes, or set up near radiators. Do not place in direct sunshine. When placing on a shelf leave 4 inches
(10 cm) free space around the entire unit.
Screws
IMPORTANT SAFETY INSTRUCTIONS
Bracket holes
4 inches
J3NV0721A_EN.indd 5J3NV0721A_EN.indd 5 8/20/12 5:03:52 PM8/20/12 5:03:52 PM
EN 6
How to attach the stand
NOTE:
• Unplug the AC cord.
• Before beginning this process, assure that the TV is laid on a clean, safe, and cushioned surface to avoid
any damage to the unit.
• Do not touch or press the TV-screen, glass might break under pressure.
Place the TV on its front onto a table.
Align the stand’s bottom-plate (supplied) as seen here.
It will fi t in only one direction.
Hold the unit and attach the stand slowly, as shown in Figure 1.
Finally secure the bottom-plate with 3 screws (supplied) (4x16mm(5/32 x 5/8 inches)) as indicated by the arrows
in Figure 2.
Be sure to follow the instructions. Insufficient tightening or incorrect installation of the stand will not support
your unit correctly, and could result in damage or injury from tip-over.
•
How to remove the stand
When you transport this product, remove the stand and pack fl at against the back of the unit in the carton. To
remove the stand, perform these steps in reverse order.
For wall mounting, the base must be removed. To disconnect the base/stand remove the three (3) screws from
the back (see page 5).
LCD PANEL FRONT
Figure 1
Figure 2
J3NV0721A_EN.indd 6J3NV0721A_EN.indd 6 8/20/12 5:03:53 PM8/20/12 5:03:53 PM
7 EN
Features
Integrated Digital Tuner - You can view digital broadcasts without using a Digital TV Set-Top Box.
Closed Caption Decoder With Full Text Mode - Displays text captions or full screen text on the screen for
hearing impaired viewers.
Picture Adjustments Using The Remote Control - The On-Screen display allows precise remote control
adjustment of BRIGHTNESS, CONTRAST, COLOR, TINT and SHARPNESS.
Programmable TV Sleep Timer - Operable from the remote control, the TV can be programmed for up to
120 minutes to turn off automatically.
V-Chip - The V-Chip function can read the rating of a broadcast program or movie content if the program is
encoded with this information. V-Chip will allow you to set a restriction level.
Digital Audio Jack (Coaxial) - When a component with a built-in Dolby Digital decoder is connected, Dolby
Digital sound can produce the effect of being in a movie theater or a concert hall.
HDMI/Component Video Jacks - A VCR, DVD player, satellite receiver or other audio/video component can
be connected to this unit.
On-Screen 3 Languages Display - You can select one of 3 languages, English, French or Spanish for on-
screen programming.
•
•
•
•
•
•
•
•
NOTE:
Never connect the AC line cord plug to other than the specified voltage (120V 60Hz).
Use the attached power cord only.
If the polarized AC cord does not fit into a non-polarized AC outlet, do not attempt to file or cut the blade.
It is the user’s responsibility to have an electrician replace the obsolete outlet.
If you cause a static discharge when touching the unit and the unit fails to function, simply unplug the unit from
the AC outlet and plug it back in. The unit should return to normal operation.
•
•
•
Power source
TO USE AC POWER SOURCE
Use the AC polarized line cord provided for operation on AC. Insert the AC cord plug into a standard 120V 60Hz
polarized AC outlet.
* Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of
Dolby Laboratories.
* The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
Wider Hole and Blade
Polarized AC Cord Plug
(One blade is wider than the other.)
AC Outlet
J3NV0721A_EN.indd 7J3NV0721A_EN.indd 7 8/20/12 5:03:54 PM8/20/12 5:03:54 PM
EN 8
Contents
Before using your unit
IMPORTANT SAFETY INSTRUCTIONS ...........3
SAFETY PRECAUTIONS .................................5
How to attach the stand ....................................6
How to remove the stand ..................................6
Features ............................................................7
Power source ....................................................7
Contents ...........................................................8
Parts and functions ...........................................9
Remote control ...............................................10
Antenna connections ......................................11
Cable TV connections .....................................11
Connections to other equipment .....................12
TV operation
Starting setup .................................................15
TV operation ...................................................15
Quick guide for menu operation ......................16
Convenience functions ...................................17
Memorizing channels ......................................18
Checking the digital signal strength ................19
Labeling channels ...........................................19
Labeling video inputs ......................................19
Setting the V-Chip ...........................................20
Closed Caption ...............................................21
CC advanced ..................................................21
Setting the picture size ....................................22
Time Shift ........................................................23
Additional information
Reception disturbances ..................................24
Troubleshooting ..............................................25
Specifications ................................................26
limited WARRANTY ........................................27
J3NV0721A_EN.indd 8J3NV0721A_EN.indd 8 8/20/12 5:03:54 PM8/20/12 5:03:54 PM
9 EN
Parts and functions
Right sideFront
To display the menu screen.
Press hold VOL (VOLUME) +/–
simultaneously about 1 second the
menu will be appear.
CH (CHANNEL) / buttons, VOL
(
VOLUME) +/– buttons and INPUT/
ENTER button can be used to select the
desired setting during the menu screen
operations.
Remote sensor
Power Indicator
Red: Standby
Green: On
POWER button
INPUT/ENTER button
VOL (VOLUME) +/–
/▶/◀
buttons, MENU button
CH (CHANNEL)
/ /▲/▼ buttons
Rear PC/DVI AUDIO IN jack
COMPONENT IN jacks
PC MONITOR IN jack
ANT. (RF) IN jack
HDMI/DVI IN jack
DIGITAL AUDIO
COAXIAL OUT jack
VIDEO IN jacks
(VIDEO/AUDIO (L/R))
USB INPUT
HEADPHONE jack
Right Side
J3NV0721A_EN.indd 9J3NV0721A_EN.indd 9 8/20/12 5:03:55 PM8/20/12 5:03:55 PM
EN 10
Remote control
HOW TO INSTALL BATTERIES
1. Open the battery compartment cover.
2. Install two “AAA” batteries (supplied).
3. Replace the battery compartment cover.
Before using the remote control, batteries must first be installed.
Use two “AAA” size batteries. The batteries may last
approximately one year depending on how much the
remote control is used. For best performance, it is
recommended that batteries should be replaced on a
yearly basis, or when the remote operation becomes
erratic. Do not mix old and new batteries or different
types.
BATTERY PRECAUTIONS
These precautions should be followed when using
batteries in this device:
Use only the size and type of batteries specified.
Be sure to follow the correct polarity when
installing the batteries as indicated in the battery
compartment. Reversed batteries may cause
damage to the device.
Do not mix different types of batteries together
(e.g. Alkaline, Carbon-zinc or Rechargeable) or old
batteries with fresh ones.
If the device is not to be used for a long period of
time, remove the batteries to prevent damage or
injury from possible battery leakage.
Do not try to recharge batteries not intended to be
recharged; they can overheat and rupture. (Follow
battery manufacturer’s directions.)
•
•
•
•
•
1. (POWER) Button - Use to turn the power on/off
to the TV.
2.Direct Channel Selection Buttons (0-9) - Allows
direct access to any channel of the TV.
3.– Button -This button is used when selecting
digital channels.
4.SLEEP Button - To set the TV to turn off after a
preset amount of time, use the SLEEP button on
the remote control.
5.CH (CHANNEL) + / – / CURSOR /
Buttons - Use to operate the menu functions of
the TV, and to change the channels of the TV.
6.MENU Button - Use to display the On-Screen
menu function.
7.AUDIO Button - Change soundtrack language.
8.INPUT SELECT Button - Use to change the
external input.
9.PICTURE SIZE Button - Use to change the
picture size.
10.RECALL Button - This button allows you to go
back to the previous channel selected by just
pressing the RECALL button. Press this button
again to return to the channel you were watching.
11.MUTE Button - To turn off the sound, press this
button once. The TV will be silenced and the
symbol “Mute” will appear on the screen. The
muting feature can be released by pressing the
MUTE button again or one of the VOL (VOLUME)
+ or – buttons.
12.VOL (VOLUME) + / – / CURSOR / Buttons
- Use to operate the menu functions of the TV.
Press the button to increase, or the button to
decrease the sound level.
13.ENTER Button - Use to enter or select
information for On-Screen operations.
14.EXIT Button - Press to remove setup menu.
15.CCD Button - Use to display the Closed Caption
menu screen.
16.DISPLAY Button - When you press this button,
the current information will be displayed on a
screen. To remove the display from the screen,
press this button again.
17.Time Shift control Buttons - See page 23.
2
10
5
1
614
4
3
8
9
7
11
12
13
15
16
17
J3NV0721A_EN.indd 10J3NV0721A_EN.indd 10 8/20/12 5:03:56 PM8/20/12 5:03:56 PM
11 EN
Antenna connections
If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your
antenna system. If you are using a Cable TV service, see “Cable TV connections”.
Combination VHF/UHF Antenna (Single 75 ohm cable)
Antenna
Jack
75 ohm
Coaxial
Cable
Connect the 75 ohm cable from the combination
VHF/UHF antenna to the Antenna Jack.
Cable TV connections
For basic Cable TV service not requiring a Converter/
Descrambler box, connect the 75 ohm Coaxial Cable directly
to the Antenna Jack on the back of the TV.
For subscribers to scrambled Cable TV service
If you subscribe to a Cable TV service which requires the use of a Converter/Descrambler box, connect
the incoming 75 ohm Coaxial Cable to the Converter/Descrambler box. Using another 75 ohm Coaxial
Cable, connect the output jack of the Converter/Descrambler box to the Antenna Jack on the TV. Follow the
connections shown below. Set the TV to the output channel of the Converter/Descrambler box (usually channel
3 or 4) and use the Converter/Descrambler box to select channels.
For subscribers to unscrambled Cable TV service with scrambled premium channels
If you subscribe to a Cable TV service in which basic channels are unscrambled and premium channels require
the use of a Converter/Descrambler box, you may wish to use a signal Splitter and an A/B Switch box (available
from the Cable TV company or an electronics supply store). Follow the connections shown below. With the
switch in the “B” position, you can directly tune any nonscrambled channels on your TV. With the switch in the
“A” position, tune your TV to the output of the Converter/Descrambler box (usually channel 3 or 4) and use the
Converter/Descrambler box to tune scrambled channels.
This TV has an extended tuning range and can tune most cable channels without using a Cable TV
Converter box. Some cable companies offer “premium pay channels” where the signal is scrambled.
Descrambling these signals for normal viewing requires the use of a descrambler device which is
generally provided by the Cable TV company.
For subscribers to basic Cable TV service
Incoming
75 ohm
Cable TV
Cable 75 ohm Cable to TV
Antenna
Jack
Converter/
Descrambler
Splitter B
A
Incoming
75 ohm
Cable TV
Cable A/B Switch 75 ohm Cable to TV
Converter/
Descrambler Antenna
Jack
Antenna
Jack
75 ohm
Coaxial
Cable
J3NV0721A_EN.indd 11J3NV0721A_EN.indd 11 8/20/12 5:03:58 PM8/20/12 5:03:58 PM
EN 12
or GAME CONSOLE
Y
Pb
Pr
The exact arrangement you use to interconnect various video and audio components to this unit is dependent
on the model and features of each component. Check the Owner’s Manual provided with each component for
the location of video and audio inputs and outputs.
To connect the TV to a VCR
Connections to other equipment
To connect the TV to a DVD player with Component Video Input
You can enjoy a high quality picture by connecting the unit’s COMPONENT VIDEO OUT jacks of your DVD
player with the component video cables (not supplied).
Right of the unit
To Video/Audio OUT
Video/Audio cord (not supplied)
To VIDEO/AUDIO IN
To Component OUT
Audio cord
(not supplied)
Component video cord
(not supplied)
To AUDIO IN
Right of the unit
To COMPONENT IN To Audio OUT
NOTE:
Component Video input of the unit are for use with a device which output 480i/1080i interlaced signals and
480p/720p progressive signals.
•
VCR
DVD
To connect the TV to a camcorder, or a game console
To playback from a camcorder, connect the camcorder to the unit as shown.
This unit can also be used as a display device for many video games. However, due to the wide variety of
signals generated by these devices and subsequent hook-up variations required, they have not all been
included in the suggested connection diagrams. You’ll need to consult each component’s Owner’s Manual for
additional information.
Right of the unit
Video/Audio cord (not supplied)
To VIDEO/AUDIO IN To Video/Audio OUT
Pr
Pb
Y
J3NV0721A_EN.indd 12J3NV0721A_EN.indd 12 8/20/12 5:03:58 PM8/20/12 5:03:58 PM
13 EN
Connections to other equipment
Using an AV Amplifier with built-in digital surround
If you are using an Amplifier with built-in digital surround sound, you can enjoy various audio systems including
Dolby Digital Surround audio that sounds just like the movie.
Connect an AV amplifier with built-in Dolby Digital decoder, etc. as shown below.
NOTE:
When you are viewing digital broadcast, this unit will not work in conjunction with DTS audio or MPEG audio.
There will be no sound output if connected to an AV amplifier with a built-in DTS decoder or MPEG decoder.
•
To connect the TV to a PC (Personal Computer)
BEFORE YOU CONNECT THIS TV TO YOUR PC, CHANGE THE ADJUSTMENT OF YOUR PC’S
RESOLUTION AND REFRESH RATE (60 HZ).
Connect one end of a (male to male) VGA cable to the video cord of the computer and the other end to the
VGA connector PC
MONITOR IN on the rear of the
TV
. Attach the connectors firmly with the screws on the plug.
In case of a Multimedia computer,
connect the audio cord to the audio output of your Multimedia computer and to the AUDIO IN connector of the PC/DVI AUDIO
IN jack of the TV. You can also connect the PC with HDMI cable. If you use HDMI cable, you don’t have to connect the audio
cord. If you use DVI-to-HDMI cable, please connect audio cord as same way as VGA cable.
Press INPUT SELECT on the remote control to select PC mode.
Switch on the computer. The TV can operate as the computer monitor.
Monitor Display modes
MODE Resolution Refresh rate
VGA 640x480 60/ 72/ 75 Hz
VGA 720x400 70Hz
SVGA 800x600 56/ 60/ 72/ 75 Hz
XGA 1024x768 60/ 70/ 75 Hz
WXGA 1280x768 60Hz
WXGA 1280x720 60Hz
WXGA 1360x768 60Hz
To return to normal mode
Press INPUT SELECT again.
NOTE:
The on-screen displays will have a different appearance in PC mode than in TV mode.
If there is no video signal from the PC when the unit is in PC mode, “No signal” will appear on the TV-screen.
•
•
Coaxial digital cable
(not supplied)
AV Amplifier with built-in digital surround decoder
Center Speaker
To DIGITAL AUDIO
COAXIAL OUT
To Coaxial
Digital Audio Input
Rear of the unit
Front
Speaker
(Left)
Front
Speaker
(Right)
Subwoofer
Surround
Speaker (Left) Surround
Speaker
(Right)
TV
HDMI cable (not supplied)
Rear and right of the unit
Audio cord (not supplied)
To HDMI/DVI IN
To PC
MONITOR
IN
To PC/DVI
AUDIO IN
VGA cable (not supplied)
J3NV0721A_EN.indd 13J3NV0721A_EN.indd 13 8/20/12 5:03:59 PM8/20/12 5:03:59 PM
EN 14
To connect a HDMI or a DVI device to the unit
The HDMI input receives digital audio and uncompressed video from a HDMI device or uncompressed digital
video from a DVI device.
When you connect to a DVI device with a HDMI-to-DVI adapter cable, it transfers only video signal. Separate
analog audio cords required.
Connections to other equipment
NOTE:
When using HDMI/DVI IN to connect your HDMI or DVI devices, you must select the corresponding
audio input source (HDMI or DVI) on the menu screen (see page 17). Otherwise you will only see the
image with no sound.
•
Rear and right of the unit
HDMI - to - DVI adapter cable
(HDMI type A connector)
(not supplied)
Audio cord (not supplied)
HDMI cable (type A connector)
(not supplied)
To DVI output
To HDMI output
HDMI device
DVI device
To HDMI/DVI IN
To PC/DVI AUDIO IN
or
J3NV0721A_EN.indd 14J3NV0721A_EN.indd 14 8/20/12 5:04:00 PM8/20/12 5:04:00 PM
15 EN
Starting setup
The Auto Setup menu appears the first time you
turn on the TV, and assists you to specify the
Air/Cable setting, and program your channels
automatically.
IMPORTANT: Make sure that the antenna or cable
TV system connection is made!
1
To turn on the TV, press POWER. (POWER
indicator on the front of the unit changes green. It
may take approx. 10 seconds for a picture to appear
on screen.) The Auto Setup function begins.
2
Press or to select “TV Location”, then press
or to select “Store” or “Home”. This product qualifies
for ENERGY STAR in Home mode default setting.
NOTE:
This unit has been preset to STORE brightness.
This setting does not qualify under ENERGY STAR.
To reduce brightness and energy consumption,
change setting to ‘HOME’. This setting does qualify
under ENERGY STAR.
The device may not conform to the ENERGY
STAR standard after “Reset” is performed or the
“Backlight” is adjusted.
•
•
3Press or to select “Signal Type”, then press
or to select “Cable” or “Air”.
4Press or to select “Automatic Search”, then
press or ENTER.
5“Auto Setup” will begin. After the Auto Setup is
completed, the TV channel appears on the screen.
Depending on the reception condition, it may
take up to 30 minutes to complete memorizing
digital cable channels. Please allow the process to
complete without interruption.
•
NOTE:
If you press EXIT in the process of “Auto Setup”,
the Auto Setup stops and changes to the normal
screen.
When you make a menu selection, your changes
occur immediately. You do not have to press EXIT to
see your changes.
TV operation
1To turn on the TV, press
POWER
. (POWER
indicator on the front of the unit changes green.
It may take approx. 10 seconds for a picture to
appear on screen.)
2Adjust the volume level by pressing VOL + or – .
The volume level will be indicated on the screen
by green bars. As the volume level increases, so
do the number of bars. If the volume decreases,
the number of green bars also decreases.
•
•
3Set the Signal Type option to the appropriate
position (see “Air/Cable selection” on page 18).
4Press the Direct Channel Selection (0-9, –)
buttons to select the channel.
(If you press only channel number, channel
selection will be delayed for a few seconds.)
TO SELECT ANALOG CHANNELS
1-9: Press 1-9 as needed. Example, to
select channel 2, press 2, then press
ENTER.
10-99: Press the 2 digits in order. Example,
to select channel 12, press 1, 2, then
press ENTER.
100-135: Press the 3 digits in order. Example, to
select channel 120, press 1, 2, 0, then
press ENTER.
TO SELECT DIGITAL CHANNELS
Press the first 1-3 digits, then press the – button,
followed by the remaining number.
Example, to select channel 15-1, press 1, 5, –, 1,
then press ENTER.
If a channel is selected with only audio content,
“Audio only” will be displayed on the screen.
If a channel is selected with a weak digital
signal, “Digital channel signal strength is low”
will be displayed on the screen.
The same program may be available on either
an analog channel or a digital channel. You may
choose to watch either format.
If a channel is selected to which you have not
subscribed,
“Digital channel is encrypted” will
be displayed on the screen.
•
•
•
VHF/UHF/CABLE CHANNELS
Air Cable
VHF
2-13 VHF
2-13
UHF
14-69 STD/HRC/IRC
14-36 (A) (W)
37-59 (AA) (WW)
60-85 (AAA) (ZZZ)
86-94 (86) (94)
95-99 (A-5) (A-1)
100-135 (100) (135)
01 (4A)
NOTE:
If a channel with no broadcast is selected, the
sound will automatically be muted.
It may take a few seconds for a digital channel
picture to appear on screen after being selected.
To select the video input source
To view a signal from another device connected
to your TV, such as a VCR player, press INPUT
SELECT, then press or or corresponding
Number buttons (0-4), then press ENTER.
Input Select
0.TV
1.Video
2.Component
3.HDMI
4.PC
[0-4]:Select
•
•
Auto Setup
Automatic Search Start
TV Location Store
Signal Type Cable
J3NV0721A_EN.indd 15J3NV0721A_EN.indd 15 8/20/12 5:04:00 PM8/20/12 5:04:00 PM
EN 16
CH +/
-
Press and release CH + / –. The channel
automatically stops at the next channel set into
memory.
For proper operation, before selecting channels, they
should be set into the memory. See “Memorizing
channels” on page 18.
DISPLAY
Press DISPLAY to display the current information on
the screen.
When the TV receives a digital signal, the digital
information will appear.
62-1 HDTV_Moving_Picture...
CH-1 TV-MA
Digital Air
No Program Information is available
Sleep Timer
Off
English
Full
1080i
USB Memory Information
Play Time
Message : Now Live View
: --:--:--
USB Memory is unplugged
Channel number• Station name•
Channel label (if preset)•
Broadcast program name
•
V-Chip rating• Signal type•
Sleep timer• Audio language•
Program guide• Picture size•
Resolution• Time Shift display•
When the TV receives an analog signal, the analog
information will appear.
Analog Cable
Sleep Timer
Off
Mono
Full
480i
G
14
Channel number• Channel label (if preset)•
V-Chip rating• Signal type•
Sleep timer• Picture size•
Audio information
(Stereo, SAP or Mono)
• Resolution•
Press DISPLAY again to clear the call display.
NOTE:
After a few seconds, DISPLAY screen will return to
normal TV operation automatically.
SLEEP
To set the TV to turn off after a preset amount of time,
press SLEEP on the remote control. The clock will
count up 10 minutes for each press of the SLEEP but-
ton (Off, 0h 10m, 0h 20m, ..., 2h 0m). After the sleep
time is programmed, the display will appear briefly
every ten minutes to remind you that the sleep timer
is operating. To confirm the sleep timer setting, press
SLEEP and the remaining time will be displayed for a
few seconds. To cancel the sleep timer, press SLEEP
repeatedly until the display turns to Off.
•
Quick guide for menu
operation
Call menu and for example: Select Language.
1Press INPUT SELECT to select TV mode.
2Press MENU. The TV menu screen will appear.
Audio
Channel
Lock
Setup
Main Menu
Picture >>
ENTER :Set:Select
CH
3Press or to select “Setup”, then press or
ENTER.
4Press or to select “Language”, then press
or to select the desired language.
…on the following pages the menu can be called
in the same way as here.
5Press EXIT to return to the normal screen.
NOTE:
If no buttons are pressed for more than about 60
seconds, the menu screen will return to normal
operation automatically.
•
J3NV0721A_EN.indd 16J3NV0721A_EN.indd 16 8/20/12 5:04:02 PM8/20/12 5:04:02 PM
17 EN
Convenience functions
You can change the default settings by pressing the MENU button on your remote, then select the one of the icons at the left
of the menu - follow the On-Screen prompts to set your preferences.
Icon Selected Items Setup hint
Picture Picture
Preference Sports Bright and dynamic picture (factory-set)
Standard Standard picture quality (factory-set)
Movie Movie-like picture setting (factory-set)
Memory Your personal preferences (set by you; see “Picture Setting”)
Picture Setting Brightness /Contrast /
Sharpness / Color / Tint You can adjust the picture quality to your preference.
Color Temperature Cool (Bluish) / Standard (Neutral) / Warm (Reddish)
Backlight*2The Backlight feature adjusts the screen brightness for improved
picture clarity.
DBC On/Off
Use this feature to change the Black level automatically according to the
brightness of an image. The Black level will become dark in a dark scene.
Picture Size See page 22.
Film Mode On/Off A smoother motion may be obtained by setting the Film Mode to “On”
(480i only).
PC Setting Hor Position /
Ver Position
To adjust the horizontal / vertical position of the image on the PC monitor
screen. Each video standard will require a different value for this setting.
Clock
To minimize any vertical bars or stripes visible on the screen background.
Phase
This must be adjusted after the frequency has been set optimize picture quality.
Auto Adjust To adjust the all PC settings automatically.
DNR On/Off DNR (Digital Noise Reduction) can reduce the roughness of the picture.
Audio
Equalizer Mode
Standard/Music/Movie/
News/Memory/Flat You can adjust the Equalizer Mode to your preference.
Audio Setting Bass/Treble You can adjust the sound quality to your preference. (Flat mode only)
Equalizer Setting
100Hz/250Hz/500Hz/1kHz/2kHz/4kHz/10kHz (Not available in Flat mode)
Balance You can adjust the sound quality to your preference.
MTS Stereo / SAP / Mono The multi-channel TV sound (MTS) feature provides high-fidelity
stereo sound. MTS also can transmit a second audio program (SAP)
containing a second language or other audio information.
When the TV receives a stereo or SAP broadcast, the word “Stereo” or
“SAP” displays on-screen every time you press DISPLAY.
Surround On/Off The dynamic presence and sound created offers a thoroughly
enjoyable listening experience.
Auto Volume On/Off Volume level can be adjusted automatically by the sound level.
Audio Language
When two or more audio languages are included in a digital signal, you can select
one of the audio languages. (This function is available only for digital broadcast.)
HDMI Audio HDMI When you connect the HDMI device to the TV, select this setting.
DVI When you connect the DVI device to the TV with analog audio cords,
select this setting.
Channel Add / Delete See page 18.
DTV Signal See page 19.
Auto Ch Memory See page 18.
Ch Label See page 19.
Lock See page 20.
Setup Closed Caption See page 21.
Language
You can choose from three different languages (English, Français (French) and
Español (Spanish)) for the on-screen displays.
Select the language you prefer first, then proceed with the other menu options.
Video Label See page 19.
On Timer Off / 0h30m / 1h00m
/ 1h30m / 2h00m /
3h00m⋅⋅⋅12h00m
You can set the On Timer to automatically turn on the TV. To cancel the
On Timer select “Off”.
Auto Shut Off
*1On/Off If the Auto Shut Off feature is On, a station being viewed stops
broadcasting and the TV is not operated, the TV will automatically shut
itself off after 15 minutes.
Auto Setup See page 15.
Power On LED
On/Off
When you turn on the TV, Power indicator on the front of the TV will light.
PC Standby On/Off
In PC mode, if no signal is received or no operation performed for 1
minute, the TV will turn to standby mode automatically (LED light will
flash red). When an input signal is received or an operation performed
on the PC, the TV will return to the on mode.
Reset*2
The Reset function returns your Picture/Audio settings to the factory settings.
“Picture Size”, “MTS” , “Audio Language” and “HDMI Audio” cannot be
reset by this function.
NOTE:
*
1
If there is no input signal in the PC mode, after 1 minute Auto Shut Off will be activated. In PC mode the “PC Standby”
setting takes precedence.
*
2
The device may not conform to the Energy Star standard after Reset is performed or the Backlight is adjusted.
J3NV0721A_EN.indd 17J3NV0721A_EN.indd 17 8/20/12 5:04:03 PM8/20/12 5:04:03 PM
EN 18
Memorizing channels
This TV is equipped with a channel memory
feature which allows channels to skip up or down
to the next channel set into memory, skipping
over unwanted channels. Before selecting
channels, they must be programmed into the
TV’s memory. To use this TV with an antenna, set
the Signal Type option to the Air mode. When
shipped from the factory, this menu option is in
the Cable mode.
Air/Cable selection
1Select “Channel ⇒ Auto Ch Memory ⇒ Signal
Type”.
2Press or to select “Air” or “Cable”.
Air - VHF/UHF channels
Cable - CABLE TV channels
Automatic Search Start
Auto Ch Memory
Signal Type Cable
CH
NOTE:
It may take a few seconds for a digital channel
picture to appear on screen after being selected.
Automatic Search
1Select “Channel ⇒
Auto Ch Memory
⇒ Automatic
Search”, then press or ENTER.
Auto Ch Memory
Signal Type Cable
Automatic Search Stop
CH
2The TV will begin memorizing all the channels
available in your area.
It may take from 15 minutes to 30 minutes to
complete memorizing digital cable channels.
Depending on the reception condition, a bar
display may not advance for several minutes,
please be patient.
•
NOTE:
Memorizing channels is best accomplished during
evening “PRIMETIME” hours, as more stations are
broadcasting digital signals. Memorizing channels can
only be accomplished while a station is broadcasting
a digital signal to set that channel into memory.
If you are unsure of the digital channels available
in your area, you may visit www.antennaweb.org to
receive a list based on your address or zip code.
Should you require further assistance you may call
our toll-free customer service line at 1-800-289-0980.
New digital channels may be added to your area
periodically, it is recommended to perform the
“Automatic Search” procedure regularly.
•
•
•
•
Adding Channel
If you find a new digital channel unregistered, you can
add the new channel into the channel memory.
1Tune in the new channel.
2Select “Channel ⇒ Add/Delete ⇒ Adding
Channel”, then press or ENTER.
Add/Delete
Adding Channel >>
Clear All >>
Add/Delete >>
CH
3The new channel will be added into the channel
memory.
Add/Delete channel
You can select the channel that you want to skip.
1Select “Channel ⇒ Add/Delete ⇒ Add/Delete”,
then press or ENTER.
2Press or to select the channel that you
want to skip.
CH Signal
2 Analog
3
3-1
3-2
Analog Add
Digital Delete
Digital Add
4 Analog Delete
Add/Delete
Add
CH
3Press or to select “Add” or “Delete”, whichever
function you want to perform.
4Repeat steps 2 - 3 for other channels you want to
add or delete.
Clear All
All channels are deleted from the channel memory.
Select “Channel ⇒ Add/Delete ⇒ Clear All”, then
press or ENTER.
Add/Delete
Adding Channel >>
Clear All >>
Add/Delete >>
CH
J3NV0721A_EN.indd 18J3NV0721A_EN.indd 18 8/20/12 5:04:03 PM8/20/12 5:04:03 PM
19 EN
Checking the digital
signal strength
This TV will allow you to view the digital signal
meter for digital channels.
1Select “Channel ⇒ DTV Signal”, then press or
ENTER.
2The digital signal strength screen will appear.
If necessary, adjust the direction of the antenna to
obtain the maximum signal strength.
Signal Level
0 50 100
DTV Signal
CH
NOTE:
Signal meter feature is not available for analog
channels.
After 240 seconds, DTV Signal screen will return to
normal TV operation automatically.
•
•
Labeling channels
Channel label appear with the channel number
display each time you turn on the TV, select a
channel, or press DISPLAY.
You can choose any four characters to identify a
channel.
To create channel labels
1Select “Channel ⇒ Ch Label”, then press or
ENTER.
2Press or to select a channel you want to label,
then press .
Ch Label
Label Clear
>>
Ch Label
Channel Number
15-1
CH-1
CH
3Press or repeatedly until the character you
want appears in the first space.
Label Clear >>
Ch Label
Channel Number 15-1
Ch Label CH-1
CH
The characters rotation as follows:
SPACE
-
, () @ / + =
-
If the character which you desire appears, press
ENTER.
Repeat this step to enter the rest of the characters.
If you would like a blank space in the label name,
you must choose the empty space from the list of
characters.
4Repeat steps 2-3 for other channel. You can
assign a label to each channel.
5When you finish inputting the label name, press
EXIT to return to the normal screen.
To clear a Ch Label
After step 2 above, press or to select “Label
Clear”, then press or ENTER.
NOTE:
The channel labels will be reset after “Automatic
Search” on page 18.
Labeling video inputs
The Video Label feature allows you to label each
input source for your TV.
1Select “Setup ⇒ Video Label”, then press or
ENTER.
2Press or to select an input which you want
to label.
3Press or to select the desired label for that
input source.
Component -
HDMI -
Video Label
Video -
PC -
– / VCR / DVD / STB / Cable / Satellite / Receiver /
Game / Camcorder / PC / DVI PC / Blu-ray
•
J3NV0721A_EN.indd 19J3NV0721A_EN.indd 19 8/20/12 5:04:05 PM8/20/12 5:04:05 PM
EN 20
Setting the V-Chip
An age limitation can be set to restrict children from
viewing or hearing violent scenes or pictures that you
may choose to exclude. The restriction applies to “TV
Rating” and “Movie Rating” if this data is transmitted.
You may set this restriction separately. To use the
V-Chip function, you must register a password.
To register a password
1Select “Lock”, then press or ENTER.
2Select and enter your password (4 digits) using
Number buttons (0-9), then press ENTER.
Lock
New Password * * *_
“ ” appears instead of the number.
3Enter the same password again to confirm, then
press ENTER.
The password is now registered.
NOTE:
If you forget the password, contact Customer
Service at 1-800-289-0980 for assistance.
Your original remote control will be required.
To avoid forgetting the password, write it down and
keep in a safe place.
How to enter the V-Chip menu
1Select “Lock” menu, then press or ENTER.
2Use Number buttons (0-9) to enter your
password, then press ENTER. The V-Chip menu
will appear.
To set the V-Chip
1In the V-Chip menu, press or to set “V-Chip”
to “On”.
2Press or to select “V-Chip Set”, then press
or ENTER.
The V-Chip Set menu will appear.
3Press or to select which rating will be
used, then press or ENTER. Each rating below
will appear.
TV Rating
TV Rating
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
You can set the rating using age level and genre.
Age:
TV-Y : All children
TV-Y7 : 7 years old and above
TV-G : General audience
TV-PG : Parental guidance
TV-14 : 14 years old and above
TV-MA : 17 years old and above
•
•
When you select TV-Y7, TV-PG, TV-14 or TV-MA,
press DISPLAY to explain the rating.
Genre:
D : Dialogue
L : Language
S : Sex
V : Violence
FV : Fantasy Violence
Movie Rating
Movie Rating
G
PG
PG-13
R
NC-17
X
G : All ages
PG : Parental guidance
PG-13 : Parental guidance
less than 13 years old
R : Under 17 years old parental guidance
suggested
NC-17 : 17 years old and above
X : Adult only
4Press / to select the desired rating, then
press ENTER.
5
Press EXIT to return to the normal screen.
V-Chip function is activated now.
NOTE:
The V-Chip function is activated only on programs
and input sources that include a rating signal.
To change the password
1In the V-Chip menu, press or to select
“Change Password”, then press or ENTER.
The Change Password screen will appear.
2Enter a new password using Number buttons
(0-9), then press ENTER.
3Enter the same password again to confirm, then
press ENTER.
The password is now registered.
Downloading the additional V-Chip rating system
As a supplement to the standard V-Chip rating
system, your television will be able to download an
additional rating system, if such a system becomes
available in the future.
To download the additional V-Chip rating system
(when available)
1In the V-Chip menu, press or to set “V-Chip”
to “On”.
2Press or to select “V-Chip Set (DTV)”, then
press or ENTER.
3If the TV is not storing the additional rating
system, the TV will begin downloading it, which
may take some time to be completed.
4Set your preferred content rating limits for the
additional rating system.
5You also need “Update” procedure to update
rating information.
•
J3NV0721A_EN.indd 20J3NV0721A_EN.indd 20 8/20/12 5:04:07 PM8/20/12 5:04:07 PM
21 EN
NOTE:
You can only download the additional V-Chip rating
system when your TV is receiving a digital signal.
When you download the additional rating system, it
may take some time for the download to occur.
The V-Chip rating information and system are not
determined or controlled by the TV.
The standard V-Chip rating system is available
whether your TV is receiving a digital signal or not,
and will block both analog and digital programs. To
set the restriction level using the standard V-Chip
rating system, select “V-Chip Set” in step 2.
The downloadable V-Chip rating system is an
evolving technology, and availability, content, and
format may vary.
You cannot select this feature if the TV is not
receiving a digital signal for the current station.
To clear the all V-Chip settings
1In the V-Chip menu, press or to select “V-
Chip Clear”, then press or ENTER.
The V-Chip Clear screen will appear.
2Use Number buttons (0-9) to enter your
password, then press ENTER. All of your settings
return to the factory settings.
Closed Caption
WHAT IS CLOSED CAPTIONING?
This television has the capability to decode and
display Closed Captioned television programs.
Closed Captioning will display text on the screen
for hearing impaired viewers or it will translate and
display text in another language.
Captions: This Closed Caption mode will display
text on the screen in English or another language.
Generally, Closed Captions in English are transmitted
on C1 and Closed Captions in other languages are
transmitted on C2.
Text: The Text Closed Caption mode will usually fill
1/2 of the screen with a programming schedule or
other information.
1Select “Setup ⇒ Closed Caption”, then press or
ENTER.
2Press or to set “CC Setting” to “On”.
On: Captions will be displayed on the screen.
Off: Captions will not be displayed on the screen.
3Press or to select “Analog Caption” or
“Digital Caption”.
When you select “Analog Caption”, you can
choose from C1, C2, C3, C4, T1, T2, T3 and T4.
When you select “Digital Caption”, you can
choose from CS1, CS2, CS3, CS4, CS5 and CS6.
4Press or to select the desired Closed
Caption
mode for both Digital and Analog Caption.
5Press or to select “CC Priority”, then press
or to select “Digital CC” or “Analog CC”.
•
•
•
•
•
•
NOTE:
Depending on the broadcast signal, some
Analog Captions will function with a Digital
broadcast signal. This step prevent that two
kind of captions are overlapping.
•
NOTE:
If the program or video you selected is not closed-
captioned, no captions will display on-screen.
If text is not available in your viewing area, a black
rectangle may appear on-screen. If this happens,
set the CC Setting to “Off”.
When selecting Closed Captions, the captioning will
be delayed approx. 10 seconds.
If no caption signal is received, no captions will appear,
but the television will remain in the Caption mode.
Misspellings or unusual characters may
occasionally appear during Closed Captioning.
This is normal with Closed Captioning, especially
with live programs. This is because during live
programs, captions are also entered live. These
transmissions do not allow time for editing.
When Captions are being displayed, on-screen
displays, such as volume and mute may be seen
but may interfere with Closed Captions.
Some cable systems and copy protection systems
may interfere with the Closed Captioned signal.
If using an indoor antenna or if TV reception is very
poor, the closed caption decoder may not appear or
may appear with strange characters or misspelled
words. In this case, adjust the antenna for better
reception or use an outdoor antenna.
Closed Caption menu also can be displayed by
pressing CCD on the remote control.
CC advanced
When you have selected “Custom” as the display
method, you can adjust the various setting listed
below as follows:
This feature is designed to customize Digital Caption
only.
1Select “Setup ⇒ Closed Caption”, then press or
ENTER.
2Press or to set “CC Setting” to “On”.
3Press or to select “Digital CC Preset”, then
press or to select “Custom”.
4Press or to select “CC Advanced”, then
press or ENTER.
The CC Advanced menu will appear.
5Press or to select the desired item, then
press or to change the setting.
CC Advanced
Tex t S i ze Au t o
Text Type Auto
Text Edge Auto
Text Color Auto
Text Opacity Auto
Background Color Auto
Background Opacity Auto
•
•
•
•
•
•
•
•
•
J3NV0721A_EN.indd 21J3NV0721A_EN.indd 21 8/20/12 5:04:09 PM8/20/12 5:04:09 PM
EN 22
You can select from among the following items
and parameters.
Text Size: Auto, Small, Standard, Large
Text Type: Auto, Style1, Style2, Style3, Style4,
Style5, Style6, Style7
Text Edge: Auto, None, Raised, Depressed,
Uniform, Left Shadow, Right
Shadow
Text Color: Auto, Black, White, Red, Green,
Blue, Yellow, Magenta, Cyan
Text Opacity: Auto, Solid, Transparent,
Translucent, Flashing
Background
Color: Auto, Black, White, Red, Green,
Blue, Yellow, Magenta, Cyan
Background
Opacity: Auto, Solid, Transparent,
Translucent, Flashing
NOTE:
You cannot set both “Text Color” and “Background
Color” as a same color.
You cannot set both “Text Opacity” and “Background
Opacity” to “Transparent”.
Setting the picture size
You can change to a variety of picture sizes—
Natural, Cinema Wide1, Cinema Wide2, Cinema
Wide3, Full and Native.
Selecting the picture size
1Select “Picture ⇒
Picture Size
”, then press or
ENTER
to display “Picture Size” menu
.
2
Press or or corresponding Number buttons
(0-4) to select the desired picture size, as described
below.
Picture Size
1.Cinema Wide1
2.Cinema Wide2
0.Natural
4.Full
3.Cinema Wide3
NOTE:
Selectable picture sizes may vary depending on the
input source or broadcast signal.
Picture Size menu also can be displayed by
pressing PICTURE SIZE on the remote control.
•
•
Natural
In some cases, this image will
display the size of standard
4:3 with a black side bar.
•
•
Cinema Wide1 (for 4:3 format programs)
To fill the screen, the right and left edges are
extended, however; the center of the picture remains
near its former ratio.
The top and bottom edges of the picture may be hidden.
Cinema Wide2 (for letter box programs)
The entire picture is uniformly enlarged—it is
stretched the same amount both wider and taller
(retains its original proportion).
The top and bottom edges of the picture may be hidden.
Cinema Wide3 (for letter box programs with
subtitles)
To fill the width of the screen, it is extended
horizontally. However; it is only slightly extended at the
top and the bottom.
The top and bottom edges of the picture may be hidden.
A B C D E F G - - - - - - - - - - - - - - - -
A B C D E F G - - - - - - - - - - - - - - - - - - - - - - - - - -
Full (for 16:9 source
programs)
Full will display the picture at the
maximum size.
Native (for PC mode only)
Detects the resolution of the
signal of the image and it will be
shown on the screen with same
amount of pixels.
NOTE:
Some High Definition and/or Digital broadcasts may
not allow you to change the picture size.
In HDMI or COMPONENT mode with a scanning
rate of 720p, 1080i or 1080p (HDMI only) only the
Cinema Wide2 and Full picture size feature are
available.
In PC mode, only the Natural, Full and Native
picture size features are available. In PC mode
(WXGA), only the Full and Native picture size
features are available.
•
•
•
J3NV0721A_EN.indd 22J3NV0721A_EN.indd 22 8/20/12 5:04:12 PM8/20/12 5:04:12 PM
23 EN
Time Shift
You can record a digital program by using the
USB memory drive. This function is for your
convenience, and allows you to pause/record a
live program for a period of time based on the
size of the USB drive inserted.
Note: The connected USB device must;
Have a minimum approx. 100 MB of memory (32 GB
max.).
Formatted as FAT16/32.
Have a write speed higher than 40Mb/sec.
Contain no other files.
Do not use USB extension cable.
Preparation:
Plug-in an external storage device into USB port.
To start recording, press (PAUSE). The recording
will start and the picture will be paused.
To view a live program press (STOP). The paused
picture goes back to a live program and recording
continues.
To stop recording, press ■ (STOP) again during
viewing a live program with recording.
To start playback, press (PLAY). The recorded
program starts playback.
If you want to watch the program while recording,
press (PLAY).
You can watch the recorded program while
recording the current program.
To pause the playback picture, press (PAUSE).
To stop the playback, press (STOP).
To fast forward or fast reverse, press (SKIP) or
(SKIP).
USB status display
Press DISPLAY while watching a DTV channel, or
press the Time Shift operation buttons. The status
display will appear.
USB Memory Information
●
▶ Delay Time : 00:02:09
Message: Now Play View
Playback status :
(PLAY), (STOP), (PAUSE),
(SKIP), (SKIP)
Recording
Delayed time from the current program
or Playing time in the play mode.
If there are no recorded program in
the USB memory, --:--:-- will appear
•
Message display
Now Live View... Viewing live program
Now Play View... Viewing recorded program
Now Pause View... Pausing the program
Not Available... Inhibited function
USB Memory is full...Caution of available USB memory
less than 100MB (Insufficient USB free space...will show
when (PAUSE) is pressed).
No Data... When you press (PLAY) and there are no
data recorded in the USB memory
USB Memory is unplugged... USB memory is not connected
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
To delete the recorded program
Disconnect the USB memory, record another
program, or turn off the TV.
Note:
Time shift does not work for ATV or external inputs. If you
change the signal while recording a program, it will stop.
During Play view mode, ATV channel select or input select
will not work.
Time shift recordable time is approximately 10 minutes
per 1 GB for HD or 30 minutes for SD (depending on the
programs).
You cannot watch the recorded program on a PC or other
device.
All of the USB memory may not be able to be used.
We will accept no responsibility whatsoever for loss of files
on USB devices caused by connection to this unit.
•
•
•
•
•
•
J3NV0721A_EN.indd 23J3NV0721A_EN.indd 23 8/20/12 5:04:13 PM8/20/12 5:04:13 PM
EN 24
GHOSTS
Ghosts are caused by the television signal following two paths. One is the
direct path and the other is reflected by tall buildings, hills or other large
objects. Changing the direction or position of the antenna may improve
the reception.
SNOW
If the TV is located far from the TV station, in a fringe reception area where
the signal is weak, small dots may appear in the picture.
If the signal is extremely weak, the installation of a larger external antenna
may be necessary.
RADIO FREQUENCY INTERFERENCE (RFI)
Caused by two-way radios, this type of interference produces moving
ripples or diagonal streaks in the picture. Some cases may cause a loss of
contrast in the picture. Changing the direction and position of the antenna
or installing an RFI filter may improve the picture.
PICTURE SIZE VARIATION
A slight picture size variation is normal when you adjust the CONTRAST or
BRIGHTNESS settings.
Most types of television interference can be remedied by adjusting the height and position of the VHF/
UHF antenna. Outdoor antennas are recommended for best results. The most common types of television
interference are shown below. If one of these symptoms appear when the TV is connected to a Cable TV
system, the disturbance may be caused by the local Cable TV company broadcast.
CARE AND MAINTENANCE
To prevent fire or shock hazard, disconnect the TV from the power source before cleaning.
The finish on the cabinet may be cleaned with mild soap and a soft, damp cloth and cared for as other furniture.
Use caution when cleaning or wiping the plastic parts.
IGNITION
Black spots or horizontal streaks may appear, the picture may flutter or
drift. Usually caused by interference from automobile ignition systems,
neon lamps or AC powered tools and appliances such as drills or hair
dryers.
Reception disturbances
J3NV0721A_EN.indd 24J3NV0721A_EN.indd 24 8/20/12 5:04:14 PM8/20/12 5:04:14 PM
25 EN
Troubleshooting
SYMPTOMS POSSIBLE SOLUTIONS
Digital
broadcasting
screen
problem.
Check digital signal strength.•
No CATV
reception.
Check all Cable TV connections.
Set Signal Type menu option to the
Cable mode.
Station or Cable TV system problems,
try another station.
•
•
•
Horizontal or
diagonal bars
on screen.
Check antenna connections, adjust or
re-direct antenna.
Check for sources of possible
interference.
•
•
No reception
above
channel 13.
Make sure Signal Type option is in the
appropriate mode.
If using antenna, check UHF antenna
connections.
•
•
No Remote
operation.
Batteries are weak, dead or inserted
incorrectly.
Remote is out of range, move closer to
TV (within 15 feet).
Make sure Remote is aimed at sensor.
Confirm there are no obstructions
between the Remote and the TV.
Make sure the power cord is plugged in.
•
•
•
•
•
TV shuts off. Sleep Timer is set.
Power interrupted.
•
•
Closed
Caption is not
activated.
TV station experiencing problems or
program tuned is not closed captioned.
Try another channel.
Check Cable TV connection or VHF/UHF
antenna, reposition or rotate antenna.
Set closed caption decoder in the menu.
•
•
•
TV is not
shown in your
language.
Select proper language in the menu
options.
•
Use the following checklist for troubleshooting if you have problems with your TV. Consult your local dealer or
service outlet if problems persist. Be sure all connections are properly made when using with other units.
SYMPTOMS POSSIBLE SOLUTIONS
TV does not
operate.
Make sure the power cord is plugged in.
Try another AC outlet.
Power is off, check fuse or circuit breaker.
Unplug unit for an hour, then plug it back
in.
•
•
•
•
Poor sound
or no sound.
Station or Cable TV experiencing
problems, tune to another station.
Check sound adjustments (VOL +/- or
MUTE).
Check for sources of possible
interference.
•
•
•
Poor picture
or no picture.
Station or Cable TV experiencing
problems, tune to another station.
Make sure channels are set into memory.
Check antenna or Cable TV
connections, adjust antenna.
Check for sources of possible
interference.
Check picture control adjustments.
•
•
•
•
•
Poor
reception on
some
channels.
Station or Cable TV experiencing
problems, tune to another station.
Make sure channels are set into memory.
Station is weak, adjust antenna to
receive desired station.
Check for sources of possible
interference.
•
•
•
•
Poor color or
no color.
Station or Cable TV experiencing
problems, tune to another station.
Make sure channels are set into memory.
Check picture control adjustments.
Check antenna or Cable TV
connections, adjust antenna.
Check for sources of possible
interference.
•
•
•
•
•
wobbles or
drifts.
Station or Cable TV experiencing
problems, tune to another station.
Make sure channels are set into memory.
Cable TV company is scrambling signal.
Adjust antenna.
•
•
•
•
FOR CUSTOMER SERVICE, ADDITIONAL SET-UP AND OPERATING ASSISTANCE, OR TO ORDER ACCESSORIES PLEASE CALL:
1-800-289-0980
WHEN CALLING CUSTOMER SERVICE – PLEASE HAVE YOUR MODEL NUMBER READY
OR WRITE TO:
ORION SALES, INC.
3471 N. UNION DR.
OLNEY, ILLINOIS 62450
FOR INFORMATION ON OUR OTHER PRODUCTS, TO ORDER ACCESSORIES ONLINE,
OR FOR RECYCLING INFORMATION, PLEASE VISIT OUR WEBSITE AT
www.sansuiproducts.com
BLOCK NOISE / PICTURE FREEZE
Block noise or picture freeze may appear on the screen caused by weak signals, interference from automobile
ignition systems, neon lamps or AC powered tools and appliances such as drills or hair dryers.
J3NV0721A_EN.indd 25J3NV0721A_EN.indd 25 8/20/12 5:04:15 PM8/20/12 5:04:15 PM
EN 26
GENERAL
Power supply: AC 120V, 60Hz
Power consumption: Operation: 37W
Stand by: 0.3W
Weight: 3.6 kg (8.0 lbs)
Dimensions: Width: 550mm (21-21/32 inches)
Height: 361mm (14-15/64 inches)
Depth: 137mm (5-25/64 inches)
Operating temperature: 5˚C - 40˚C
Operating humidity: Less than 80% RH
Type: 599.4mmV (class 24 inches/23.6 inches diagonal)
Display method: Transmission TFT color LCD panel
Number of Pixels: 1366 (H) × 768 (V)
Broadcasting system: US System M
ATSC standard (8VSB), QAM
Receiving channels: VHF 2-13
UHF 14-69
CATV 14-36 (A)-(W)
37-59 (AA)-(WW)
60-85 (AAA)-(ZZZ)
86-94 (86)-(94)
95-99 (A-5)-(A-1)
100-135 (100)-(135)
01 (4A)
Tuner type: Frequency synthesized
Inputs: Video: (RCA) 1 V (p-p), 75 ohms
Audio: (RCA) –8 dBm/50k ohms
Component video: (Y) 1 V (p-p), 75 ohms
(Pb)/(Pr) 0.7 V (p-p), 75 ohms
HDMI: HDMI compliant (type A connector)
HDCP compliant
E-EDID compliant
Suggested scan rates: 480i, 480p, 720p,1080i,1080p
HDMI Audio: 2-channel PCM
32/44.1/48 kHz sampling frequency
16/20/24 bits per sample
PC Monitor: Mini-Dsub 15pin
Antenna: VHF/UHF In 75 ohms coaxial
Output: Digital audio out: 0.5 V (p-p), 75 ohms terminated
Speakers: 25.4 mm × 68.6 mm (1 inch × 2-11/16 inches), 8 ohms × 2
Audio output power: 2.0W + 2.0W
ACCESSORIES Remote control
Batteries (AAA) × 2
Stand
Screws 4×16mm(5/32 × 5/8 inches) × 3
Specifications
Designs and specifications are subject to change without notice.
J3NV0721A_EN.indd 26J3NV0721A_EN.indd 26 8/20/12 5:04:15 PM8/20/12 5:04:15 PM
27 EN
ORION warrants this product to be free from manufacturing defects in material and workmanship under
normal use and conditions for a period of 1 year from date of original purchase in the United States.
Should service be necessary under this warranty for any reason due to a manufacturing defect or
malfunction during the first 12 months from date of original purchase, ORION will provide carry-in service only by
an ORION authorized Independent Service Center at no charge. Also, if an original part fails due to manufacturing
defect in material and workmanship within one year from date of original purchase we will replace the defective
part, provided the defect or malfunction is verified along with dated proof of purchase.
There are ORION authorized Independent Service Centers located throughout the country. For the one
nearest you, DIAL TOLL FREE: 1-800-289-0980 or visit our website at www.sansuiproducts.com. ORION will not
be liable for damages incurred in shipment of the unit. If there are no ORION authorized Independent Service
Centers in your area please call - 1-888-296-7466 for assistance.
Note: This warranty is void if the product is:
(a) Damaged through negligence, misuse, abuse, or accident.
(b) Used in a commercial application or rentals.
(c) Modified or repaired by anyone other than an Independent Service Center authorized by ORION to effect
warranty repairs to the class of product or by the ORION Factory Service Center.
(d) Damaged because it is improperly connected to the equipment of other manufacturers.
This warranty does not cover:
(a) Damage to equipment not properly connected to the product.
(b) Costs incurred in the shipping of the product to an ORION authorized Independent Service Center or
ORION Factory Service Center.
(c) Damage or improper operation of unit caused by customer abuse, misuse, negligence, or failure to follow
operating instructions provided with the product.
(d) Ordinary adjustments to the product which can be performed by customer as outlined in the owner’s
manual.
(e) Signal reception problems caused by external antenna or cable systems.
THIS WARRANTY IS NON TRANSFERABLE AND APPLIES ONLY TO THE ORIGINAL PURCHASER
AND DOES NOT EXTEND TO SUBSEQUENT OWNERS OF THE PRODUCT. ANY APPLICABLE IMPLIED
WARRANTIES, INCLUDING THE WARRANTY OF MERCHANTABILITY, ARE LIMITED IN DURATION TO A
PERIOD OF THE EXPRESS WARRANTY AS PROVIDED HEREIN BEGINNING WITH THE DATE OF ORIGINAL
PURCHASE AT RETAIL AND NO WARRANTIES, WHETHER EXPRESS OR IMPLIED SHALL APPLY TO THIS
PRODUCT THEREAFTER. ORION MAKES NO WARRANTY AS TO THE FITNESS OF THE PRODUCT FOR
ANY PARTICULAR PURPOSE AND USE.
UNDER NO CIRCUMSTANCES SHALL ORION BE LIABLE FOR ANY LOSS, DIRECT, INDIRECT,
INCIDENTAL, SPECIAL, OR CONSEQUENTIAL DAMAGE ARISING OUT OF OR IN CONNECTION WITH THE
USE OF THIS PRODUCT.
THIS WARRANTY IS VALID ONLY IN THE UNITED STATES OF AMERICA. THIS WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS, HOWEVER, YOU MAY HAVE OTHER RIGHTS WHICH MAY VARY FROM STATE
TO STATE. SOME STATES DO NOT ALLOW LIMITATION ON IMPLIED WARRANTIES OR EXCLUSION OF
CONSEQUENTIAL DAMAGE, THEREFORE THESE RESTRICTIONS MAY NOT APPLY TO YOU.
ORION SALES, INC.
3471 N. UNION DR.
OLNEY, ILLINOIS 62450
limited
WARRANTY
24” CLASS LED-LCD HDTV
J3NV0721A_EN.indd 27J3NV0721A_EN.indd 27 8/20/12 5:04:15 PM8/20/12 5:04:15 PM

Navigation menu
