Santok STKR45I Mobile Phone User Manual Content

Santok Limited Mobile Phone Content

User Manual

-1-
User manual
R45i
Brand: STK
-2-
Content
1 General Information .............................................................................................................................. 4
1.1 Profile ................................................................................................................................................ 4
1.2 Safety Information ............................................................................................................................. 4
1.3 Safety warning and Attentions .......................................................................................................... 4
2 Your phone ............................................................................................................................................ 8
2.1 Phone overview ................................................................................................................................ 8
2.2 Functions of Keys ............................................................................................................................. 8
2.3 Technical specifications .................................................................................................................... 9
3 Getting started .................................................................................................................................... 10
3.1 Installing the SIM Cards and the Battery ........................................................................................ 10
3.2 Installing Memory Card ................................................................................................................... 12
3.3 Charging the Battery ....................................................................................................................... 12
3.4 Powering On/Off the Mobile Phone ................................................................................................ 15
3.5 Linking to the Network .................................................................................................................... 15
3.6 Dialing Calls .................................................................................................................................... 16
3.7 Using the Headset .......................................................................................................................... 16
-3-
4 Input method ....................................................................................................................................... 17
4.1 Icons for Input Methods .................................................................................................................. 17
5 Using the Menus ................................................................................................................................. 18
5.1 Fun & Games .................................................................................................................................. 18
5.2 Contacts .......................................................................................................................................... 19
5.3 Call logs .......................................................................................................................................... 19
5.4 Camera ........................................................................................................................................... 21
5.5 NEO ................................................................................................................................................ 21
5.6 Message ......................................................................................................................................... 21
5.7 Profiles ............................................................................................................................................ 22
5.8 Multimedia ....................................................................................................................................... 23
5.9 Internet ............................................................................................................................................ 24
5.10 Application ...................................................................................................................................... 24
5.11 My files ............................................................................................................................................ 25
5.12 Settings ........................................................................................................................................... 26
6 Appendix ............................................................................................................................................. 29
-4-
1 General Information
1.1 Profile
Please read this pamphlet carefully in order to make your phone in perfect condition.
Our company may change this mobile phone without prior written notice and reserves the final
right to interpret the performance of this mobile phone.
Due to different software and network operators, display on your phone may be different, refer to
your phone for details.
1.2 Safety Information
If your phone has lost or been stolen, notify the telecommunication office the SIM card is
disabled (network support is required). This can avoid economic loss caused by unauthorized use.
Please take measures as following to avoid your phone being unauthorized used:
· Set PIN code of SIM card
· Set phone password
1.3 Safety warning and Attentions
-5-
Safety warning
ROAD SAFETY COMES FIRST
Do not use a hand-held phone while driving. Use hands-free fittings when calls are unavoidable
while driving. In some countries, dialing or receiving calls while driving is illegal!
SWITCH OFF IN AIRCRAFT
Wireless devices can cause interference in aircraft. Using a mobile phone in flight is illegal and
risky.
Please make sure that your mobile phone is powered off in flight.
SWITCH OFF BEFORE ENTERING RISKY AREAS
Strictly observe the relevant laws, codes, and regulations on the use of mobile phones in risky
areas. Turn off your mobile phone before entering a place susceptible to explosion, such as an oil
station, oil tank, chemical plant or a place where a blasting process is under way.
OBSERVE ALL SPECIAL REGULATIONS
Follow any special regulations in force in any area such as hospitals and always switch off your
phone whenever it is forbidden to use it or, when it may cause interference or danger. Properly use
your mobile phone near medical apparatuses, such as pacemakers, hearing aids and some other
electronic medical devices, as it may cause interference to such apparatus.
Follow any special regulation in force in any area such as hospital and always switch off your
phone whenever it is forbidden to use it or, when it may cause interference or danger. Properly use
your mobile phone near medial apparatuses, such as pacemakers, hearing-aids and some other
electronic medical devices, as or may cause interference to such apparatuses.
-6-
INTERFERENCE
The conversation quality of any mobile phone may be affected by radio interference. An
antenna is built inside the mobile phone and located below the microphone. Do not touch the
antenna area during a conversation, lest that the conversation quality deteriorate.
QUALIFIED SERVICE
Only qualified personnel may install or repair phone equipment. Installing or repairing the
mobile phone on your own may bring great danger and violate the warranty rules.
ACCESSORIES AND BATTERIES
Use only approved accessories and batteries.
USE SENSIBLY
Use only in a normal and proper manner.
EMERGENCY CALLS
Ensure the phone is switched on and in service, enter the emergency number, e.g. 112, then
press the Dial key. Give your location and state your situation briefly. Do not end the call until told to
do so.
Note: Just like all other mobile phones, this mobile phone does not necessarily support all the
features described in this manual due to network or radio transmission problems. Some networks
even do not support the emergency call service. Therefore, do not rely solely on the mobile phone
for critical communications such as first aid. Please consult the local network operator. Just like all
other mobile phones, this mobile phone does not necessarily support all the features described in
this manual due to network or radio transmission problems. Some network even do not support the
emergency call service
-7-
Precaution
This mobile phone is well designed with fine art. Please exercise special care when using it. The
following suggestions will help your mobile phone survive the warranty period and extend its service
life:
Keep the mobile phone and all its fittings beyond children's reach.
Keep the mobile phone dry. Keep away from rain, moisture, liquid or other substances that may
corrode electronic circuits.
Do not use or store the mobile phone in dusty place, lest that active parts of the mobile phone be
damaged.
Do not store the mobile phone in a high-temperature place. High temperature will shorten the life
of electronic circuits and damage the battery and some plastic parts.
Do not store the mobile phone in a chilly place. Otherwise, moisture will be formed inside the
mobile phone to damage electronic circuits when the mobile phone is moved to a constant
temperature place.
Do not throw, knock or shock the mobile phone, as that will destroy the internal circuit and high
precision components of the mobile phone.
-8-
2 Your phone
2.1 Phone overview
2.2 Functions of Keys
Dial key
Press it to originate a call by entering the called number or selecting a contact from the
phonebook; or press it to receive an incoming call; or press it in standby state to show the latest
call records.
End key
Press it to end a call being dialed or end an ongoing call; or press it to exit the menu and return
to the standby state. You can hold it for two or three seconds can power on/off the mobile phone
OK key
Press it to confirm a selection.
Number keys, * key and # key
Press number keys 0 through 9 to input or edit state to input numbers and characters;
In idle screen, you can press end key to lock keypad. When the keypad is locked, you can slide
arrowhead right to unlock it.
Press two times the * key to input "+" in standby interface. When the symbol "+" appears,
Press the * key quickly to input "P" or "W","P" and "W" are used for calling the extension; "+"
-9-
are used for dialing an international call.
2.3 Technical specifications
Phone
Dimensions (W×H):
Weight:
Lithium battery
Rated capacity:
Continuous standby duration: (Relates to network status)
Continuous conversation duration: (Relates to network status)
Please refer to their labels for other data related to the battery and the charger.
-10-
3 Getting started
3.1 Installing the SIM Cards and the Battery
A SIM card carries useful information, including your mobile phone number, PIN (Personal
Identification Number), PIN2, PUK (PIN Unlocking Key), PUK2 (PIN2 Unlocking Key), IMSI
(International Mobile Subscriber Identity), network information, contacts data, and short messages
data.
Note:
After powering off your mobile phone, wait for a few seconds before removing or inserting a SIM
card.
Exercise caution when operating a SIM card, as friction or bending will damage the SIM card.
Properly keep the mobile phone and its fittings such as the SIM cards beyond children's reach.
Installation
Hold the End key for a while to power off the mobile phone.
Take the back cover above the battery away.
Take the battery away.
Insert the SIM card into the SIM card slot lightly with the corner cutting of the card aligning to
the notch of the slot and the gold plate of the card facing download, till the SIM card cannot be
further pushed in.
With the metallic contacts of the battery facing the metallic contacts in the battery slot, press
the battery down until it locks into place.
Using code
-11-
The mobile phone and the SIM cards support sorts of passwords, in order to prevent the phone
and the SIM cards from being misused. When you are prompted to input any of the codes
mentioned below, just input the correct code and then press the OK key. If you input a wrong code,
clear it and then input the correct code.
Phone lock code
The phone lock code may be set to prevent your mobile phone from being misused. In general,
this code is provided along with the mobile phone by the manufacturer. The initial phone lock code is
set to 1234 by the manufacturer. If the phone lock code is set, you need to input the phone lock code
when powering on the mobile phone.
PIN
The PIN (Personal identification number, 4 to 8 digits) code prevents your SIM card from being
used by unauthorized people. In general, the PIN is supplied with SIM card by the network operator.
If PIN check is enabled, you need to input the PIN each time when you power on your mobile phone.
The SIM card will be locked if you input wrong PIN code for three times.
Unlocking methods as follows:
-Input the correct PUK according to the screen tips to unlock the SIM card.
-Then input the new PIN and press the OK key.
-Input the new PIN again and then press the OK key.
-If the input PUK is correct, the SIM card will be unlocked and the PIN will be reset.
Note: The SIM card will be locked if you input wrong PIN code for three times. To unlock the
SIM card, you need to input the PUK. In general, the PUK can be obtained from the network
operator.
-12-
PUK
The PUK code (Personal Unlocking Key) is required to change a blocked PIN. It is supplied with
SIM card. If not, contact your network operator. If you input wrong PUK code for 10 times, SIM card
will be invalid. Please contact the network operator to replace the SIM card.
Barring code
A barring code is required for setting the call barring function. You can obtain this code from the
network operator to set the call barring function.
3.2 Installing Memory Card
The Memory card is a pluggable mobile storage card inside the mobile phone.
To install the Memory card, place its indented side downward, insert the card into the card slot.
To remove the Memory card, take the card out.
Note:
1. The mobile phone cannot automatically identify the Memory card being inserted when the
mobile phone is powered on. You must power off the mobile phone and then power it on, so that the
phone can identify the Memory card.
2. The Memory card is a miniature object. Keep it out of the reach of children for fearing that
children swallow it!
3.3 Charging the Battery
The lithium battery delivered with the mobile phone can be put into use immediately after being
unpacked.
Battery level indication:
-13-
Your mobile phone can monitor and display the battery state.
Normally the remaining energy of the battery is indicated by the battery level icon at the upper
right corner of the display screen.
When the battery energy is insufficient, the mobile phone prompts "Battery low". If you have
set an alert tone, an alert tone will be given off when the battery level is too low.
A charging animation appears when the battery is being charged. When the charging is
complete, the animation disappears.
Using a travel adapter:
Install the battery into the mobile phone before charging the battery.
Connect the adapter of the travel charger with the charging slot in the mobile phone. Ensure
that the adapter is fully inserted.
Insert the plug of the travel charger to an appropriate power outlet.
During the charging, the battery level grid in the battery icon keep flickering till the battery is
fully charged.
It is normal when the battery becomes hot during the charging period.
The battery icon does no longer flicker when the charging process ends.
Note:
Ensure that the plug of the charger, the plug of the earphone, and the plug of the USB cable are
inserted in the right direction. Inserting them in a wrong direction may cause charging failure or other
problems.
Before the charging, ensure that the standard voltage and frequency of the local mains supply
match the rated voltage and power of the travel charger.
-14-
Using the Battery
The performance of a battery is subject to multiple factors: radio network configuration, signal
strength, ambient temperature, chosen functions or settings, phone fittings, and the voice, data or
other application mode you choose to use.
To guarantee the optimal performance of your battery, please stick to the following rules:
Use only the battery provided by the vendor. Otherwise, damages or even injuries could be
caused during the charging.
Power off the mobile phone before removing the battery.
The charging process lasts a longer time for a new battery or a battery not in use for long. If
the battery voltage is too low to enable the mobile phone to be powered on, charge the battery
for a longer time. In this case, the battery icon does not flicker until a long time after the battery
enters the charge status.
During the charging, ensure the battery is placed in a room temperature environment or in an
environment close to room temperature.
Immediately stop using the battery if the battery produces odor, overheat, cracks, distort or
has other damage, or if the electrolyte leaks.
The battery wears out with use. A longer charging time is required as the battery is put into use
for a long time. If the total conversation duration decreases but the charging time increases
even though the battery is properly charged, purchase a standard battery from the OEM or use
a battery approved by our company. Using any poor-quality fittings will cause harm to your
mobile phone or even incur danger!
Note: To guarantee your personal safety and protect the environment, do not litter the battery!
-15-
Return the old battery to the mobile phone manufacturer or place it in specified battery reclamation
areas. Do not litter any battery with other rubbish.
Warning: Short-circuits of the battery may cause explosion, fire, personal injury or other severe
consequences!
3.4 Powering On/Off the Mobile Phone
Hold the End key for a while to power on the mobile phone. A power-on animation appears on
the display screen.
Input the phone lock code and press the OK key if the mobile phone prompts you to input the
phone lock code. The original code is 1234.
Input the PIN and press the OK key if the mobile phone prompts you to input the PIN. The PIN
is provided by the network operator for new opening SIM card.
Enter the standby interface.
To power off the mobile phone, hold the End key for a while.
3.5 Linking to the Network
After the SIM card and the mobile phone are successfully unlocked, the mobile phone
automatically searches for an available network. After finding a network, the mobile phone enters
the standby state. When the mobile phone is registered in the network, the name of the network
operator is displayed on the screen. Then you can dial or receive a call.
-16-
3.6 Dialing Calls
In the standby interface, press Dial-pad enter virtual dial pad, press number keys to input the
area code and the telephone number, and then press the dial key to dial a call.
3.7 Using the Headset
It would enter headset mode automatically when you insert headset to the slot. Make sure of
inserting it at the bottom of the slot, or you cant use it normally.
-17-
4 Input method
This mobile phone provides English input, smart English input and numeric input method. You
can use these input methods when editing the phonebook, short messages, files and greeting text.
4.1 Icons for Input Methods
After you enter an edit window such as a window for editing the phonebook, short messages or
the memorandum, an icon is displayed to indicate the current input method:
Numeric input:“123”
English input in upper case:“ABC”
English input in lower caseabc”
-18-
5 Using the Menus
5.1 Fun & Games
Link game
A game was embedded in the phone, for more specification, please refers to Help in the game.
Detik
You can log on Detik through this access.
Facebook
You can log on Facebook through this access.
Yahoo
You can log on Yahoo through this access.
Twitter
You can log on Twitter through this access.
Ebuddy
You can log on Ebuddy through this access.
Google
You can log on Google through this access.
-19-
5.2 Contacts
The mobile phone can store up to 300 telephone numbers. The number of telephone numbers
that an SIM card can store depends on the storage capacity of the SIM card. The telephone
numbers stored in the mobile phone and in the SIM cards form a phonebook.
After selecting a telephone number in the phonebook, select Options to perform the following
operations:
New: Create new contact.
Write message: sent text message or multimedia message to the selected number.
Call: call the current number of the SIM1 or SIM2.
Delete: Delete the telephone number from the phonebook.
Delete multiple: Delete multiple telephone number from the phonebook.
Import/Export: You can import/export contacts through this function.
Send vCard: Select and send contacts information to other recipients via text message,
multimedia message or Bluetooth.
Others: To view own number, service number and memory status through this function.
5.3 Call logs
Missed Calls
You can view a list of the latest missed calls.
Note: When the mobile phone indicates that some calls are missed, you can select Read to enter
the missed calls list. Navigate to a missed call and then press the Dial key to dial the number that
-20-
originated that call.
Dialed Calls
You can view the latest dialed calls. Choose dialed calls and then select a dialed call to delete,
save, dial, or edit (or send a short message to it).
Received Calls
You can view the latest received calls. Choose received calls and then select a received call to
delete, save, dial, or edit (or send a short message to it).
Rejected Calls
You can view the latest rejected calls. Choose rejected calls and then select a rejected call to
delete, save, dial, or edit (or send a short message to it).
Delete all
You can delete all the latest call records.
Call timers
Choose Call timers to view the last call time, the total time of all dialed calls, the total time of all
received calls and the total time of call history, and/or to reset all the time.
GPRS counter
You can view the data of last sent, last received, all sent and all received.
-21-
5.4 Camera
The phone is provided with a camera, which supports the photographing functions. In the capture
interface, you can press up or down direction icon to zoom in and zoom out, Roll the phone to align
the camera to the picture and then press OK key to capture photos. Pictures will be saved in the file
system of the phone or the memory card.
5.5 NEO
You can log on NEO through this access.
5.6 Message
If the short message memory is full, a blinking message icon appears on the top of the screen. To
normally receive short messages, you need to delete some of the existing short messages.
If the destination user has received the short message you sent and the short message delivery
report function is activated, the phone will give off a message report alert tone.
Write message
Access this menu to create a text message or multimedia message.
Inbox
Received Messages are listed in this menu.
Outbox
The messages which are sent failed are stored in the Outbox.
-22-
Drafts
Draft messages are listed in this menu.
Sent box
Sent messages are listed in this menu.
Security inbox
You can move messages into security inbox to protect your privacy.
Templates
You can create pre-defined messages in this interface.
Broadcast Message
This network service enables you to receive a variety of text messages, such as broadcast
messages about weather forecast or road conditions. At present, few networks provide this service.
Please consult the network operator.
Voice mail server
You can set voice mail through this function.
5.7 Profiles
The mobile phone provides multiple user profiles, so that you can customize some settings to adapt
to the specific events and environments.
Customize the user profiles according to your preference and then activate the user profiles. The
-23-
user profiles fall into five scenarios: Normal, Silent, Indoor, Earphone and Bluetooth.
When you insert an earpiece to the mobile phone, the mobile phone automatically enters the
Headset mode. There is no option for activating the Headset mode on the screen.
5.8 Multimedia
Camera
The phone is provided with a camera, which supports the photographing functions. In the capture
interface, you can press up or down direction icon to zoom in and zoom out, Roll the phone to align
the camera to the picture and then press OK key to capture photos. Pictures will be saved in the file
system of the phone or the memory card.
DV
This function enables you to record dynamic pictures. In the capture interface, press OK key to
capture videos clip.
You can view the pictures or images through this function.
Audio
You can use this function to play audio files. By pressing the direction key can you control the
playing process of audio player: play/pauseOK key, switch to last song/next song press left or
right direction icon, fast forward (press and hold right direction icon) and rewind (press and hold left
direction icon). In audio player interface, you can press volume icon.
-24-
Video
Use this function to play video files. By pressing the direction key can you control the playing
process of video player: play/pauseOK key, fast forward (press and hold right direction icon) and
rewind (press and hold left direction icon). In video player interface, you can press volume icon.
Recorder
The phone support WAV and AMR. The AMR takes the compression algorithm. So in the same
memory condition, it has longer recording time than WAV.
FM radio
You can use the application as a traditional FM radio with automatic tuning and saved channels. In
FM radio interface, left or right direction icon to search channels manually, ok key to play/pause the
playing process of the current channel.
5.9 Internet
This function enables you to view the internet. Your phone will ask you with existed way. You can
start to view only by starting corresponding way.
Note: Consulting the local network operator for related fee and specific setup.
5.10 Application
Calculator
The calculator can add, subtract, multiply and divide.
-25-
Calendar
Once you enter this menu, there is a monthly-view calendar for you to keep track of important
appointments, etc. Days with events entered will be marked.
Clock
You can set alarm through this function.
STK
STK service is the tool kit of SIM card. This phone supports the service function .The specific items
are depended by SIM card and network. Service menu will be auto added to the phone menu when
supported by network and SIM card.
Bluetooth
You can transfer data, such as music to other device using Bluetooth. Search the device and
accept/transfer data. The received data is automatically stored in the directory.
5.11 My files
The phone supports the memory card. The capacity of the memory card is selectable. You can
use the file manager to conveniently manage various directories and files on the memory card.
Choose My files to enter the root directory of the memory. The root directory will list the default
folders, new folders and user files. When the mobile phone is powered on for the first time or when
you have not changed the directory, the root directory contains the default folders only.
-26-
5.12 Settings
Call Settings
Dual-SIM: You can set standby mode, reply by original SIM, set SIM name and Set dual SIM
call divert through this function.
Call divert: this network function enables you to forward incoming calls to another number you
have previously specified.
Call waiting: After you choose Activate, the mobile phone will contact the network. A moment
later, the network will make a response and send a message to acknowledge your operation. If
the call waiting function is activated, the network will alert you and the mobile phone screen will
display the incoming call number if others are calling you while you are already in a
conversation.
Call barring: The call barring function enables you to bar calls as needed. When setting this
function, you need to use a network barring code, which can be obtained from the network
operator. If the code is wrong, an error message will be prompted on the screen. After selecting
a call barring option, continue to select Activate or Deactivate. The mobile phone will prompt you
to input the call barring code and then contact the network. A moment later, the network will
make a response and send the operation results to the mobile phone.
Hide ID: You can select hide ID, display own ID and or display ID by network.
Others: You can set IP prefix, call time minute reminder, auto redial, vibration when connected,
reply SMS after reject and auto record voice call through this function.
-27-
Phone Settings
Date & Time: set the date format, the time format, and detail time of the location.
Note: If you remove the battery from the mobile phone or if the battery energy was exhausted a long
time ago, you may need to reset the date and time when re-inserting the battery or powering on the
mobile phone after recharging.
Language settings: Select the display language for the mobile phone.
Input method settings: Select preferred input method as needed.
Adjust touch screen: You can calibrate your phone through this function, following the
instruction on screen.
Auto power on/off: Set the time when the mobile phone will be automatically powered on or off.
Alert: Before entering an area where the use of mobile phones is forbidden, make sure that the
scheduled power-on function is deactivated to avoid accidents.
Power management: You can view battery remain power through this function.
Restore factory Settings: Use this function to restore factory settings. The preset password is
1234.
Display
Users can access this item to set Animation effect, wallpaper, screen saver, Contrast, Backlight,
Keypad backlight time, auto keypad lock etc.
Security
This function provides you with related settings about safety use
PIN: To activate PIN lock, you need to input the correct PIN code. If you set PIN lock to On, you
-28-
need to input the PIN each time you power on the mobile phone. In the case you input a wrong
PIN for three consecutive times; you need to input the PIN Unblocking Key (PUK). The PUK is
used to unlock and change the locked PIN. To obtain the PUK, contact the network operator.
Modify PIN2: To change PIN2 code of PIN code.
Phone locked: The function enables you to lock/unlock the phone. Entering password to switch
on or off the phone. Password is required when the phone is locked. The initial password is
1234.
Modify the cell phone password: to change phone password.
Privacy: You can set password to protect your privacy, the initial password is 1234.
Lock screen by end-key: You can select to turn on/off this function.
Guard-lock: You can set password to protect your cell phone.
Fixed dialing: You can select to turn on/off this function and set fixed dialing number through
this function.
Blacklist: The number which you add to blacklist cannot call you.
Profiles
The mobile phone provides multiple user profiles, so that you can customize some settings to adapt
to the specific events and environments.
Customize the user profiles according to your preference and then activate the user profiles. The
user profiles fall into five scenarios: Normal, Silent, Indoor, Earphone and Bluetooth.
When you insert an earpiece to the mobile phone, the mobile phone automatically enters the
Headset mode. There is no option for activating the Headset mode on the screen.
-29-
Connections
Contact the network operator to obtain the following network services:
Network account: You can manage network account through this function.
GPRS Service: You can select to turn on/off this function.
Data connection settings: The default setting is connecting when needed.
Network selection: Set Network selection mode to Automatic or Manual. Automatic is
recommended. When Network selection mode is set to Automatic, the mobile phone will prefer
the network where the SIM card is registered. When Network selection mode is set to Manual,
you need to select the network operator's network where the SIM card is registered.
6 Appendix
Appendix 1Troubleshooting
If you find exceptions when operating the mobile phone, restore the factory settings and then refer
to the following table to solve the problem. If the problem persists, contact the distributor or service
provider.
Fault
Cause
Solution
SIM card
error
The SIM card
is damaged.
Contact your network service provider
The SIM card
is not in
position.
Check the SIM card
-30-
The metal
face of the
SIM card is
polluted.
Clean the SIM card with a clean cloth
Poor received
signal quality
Signals are
obstructed.
For instance,
radio waves
cannot be
effectively
transmitted
nearby a
high building
or in a
basement.
Move to a place where signals can be effectively
transmitted
Line
congestions
occur when
you use the
mobile phone
in high-traffic
hours
Avoid using the mobile phone in high-traffic hours
-31-
The mobile
phone cannot
be powered
on
The battery
energy is
exhausted.
Charge the battery
Calls cannot
be dialed
Call barring
is activated
Cancel call barring
The mobile
phone cannot
connect the
network
The SIM card
is invalid
Contact your network service provider
-32-
The mobile
phone is not
in a service
area of the
GSM
network
Move to the network operator's service area
The signal is
weak
Move to a place where the signal quality is high
The battery
cannot be
charged
The charging
voltage does
not match the
voltage
range
indicated on
the charger
Ensure the charging voltage matches the voltage range
indicated on the charger
An improper
charger is
used
Use the charger specially designed for the mobile phone
Poor contact
Ensure the charger plug is in good contact with the
mobile phone
-33-
CE Maintenance
1.Use careful with the earphone maybe excessive sound pressure from earphones and headphones can cause
hearing loss.
2.Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the
instructions.
3.The product shall only be connected to a USB interface of version USB2.0.
4.Adapter shall be installed near the equipment and shall be easily accessible.
5.EUT operatiing temperature: -20 to +40.
6.Adapter
The plug considered as disconnect device of adapter
Input: AC 100-240V, 50/60Hz,150mA
Output: 5V 500mA
7.The device complies with RF specifications when the device used at 5mm from your body.
8.To prevent possible hearing damage. Do not listen at high volume levels for long periods.
Declaration of Conformity
Shenzhen Guowei Electronics Co., LTD hereby declares that this Mobile Phone is in compliance with the essential
requirements and other relevant provisions of Directive 1999/5/EC.a copy of the original declaration of conformity
may be found or obtained at http://www.sgwglobal.com.cn/
-34-
FCC Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the condition that this device does not
cause harmful interference.
Any Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
-35-
Specific Absorption Rate (SAR) information:
This Mobile Phone meets the government's requirements for exposure to radio waves. The guidelines are based
on standards that were developed by independent scientific organizations through periodic and thorough
evaluation of scientific studies. The standards include a substantial safety margin designed to assure the safety of
all persons regardless of age or health.
FCC RF Exposure Information and Statement
The SAR limit of USA (FCC) is 1.6 W/kg averaged over one gram of tissue. Device types: R45i (FCC ID:
2AE7RSTKR45I) has also been tested against this SAR limit. The highest SAR value reported under this standard
during product certification for use at the ear is 0.747W/kg and when properly worn on the body is 0.912W/kg. This
device was tested for typical body-worn operations with the back of the handset kept 10mm from the body. To
maintain compliance with FCC RF exposure requirements, use accessories that maintain a 10mm separation
distance between the user's body and the back of the handset. The use of belt clips, holsters and similar
accessories should not contain metallic components in its assembly. The use of accessories that do not satisfy
these requirements may not comply with FCC RF exposure requirements, and should be avoided.
Body-worn Operation
This device was tested for typical body-worn operations. To comply with RF exposure requirements, a minimum
separation distance of 10mm must be maintained between the user’s body and the handset, including the antenna.
Third-party belt-clips, holsters, and similar accessories used by this device should not contain any metallic
components. Body-worn accessories that do not meet these requirements may not comply with RF exposure
requirements and should be avoided. Use only the supplied or an approved antenna.

Navigation menu
