Sarotech MRE-461U USB Multi Card Reader User Manual

Sarotech Co., Ltd. USB Multi Card Reader

User Manual

User Manual
Contents of Alio
1) Case(Alio) 2) Driver Installation CD
3) USB extension cable 4) Manual
Description and
names of each part
For SMC, SD, MMC, make the upper part of the Media to the upside like the picture.
For CF, MD, MS turn the below part of the Media to the upside like the picture.
Check out the upper part and below part of the Media when you
fix it to the slot.
Circumstances of use
586 Pentium or greater and MAC
USB port should be possible to use
Include the CD-ROM or the driver should be possible to be downloaded
from internet
Caution
Be careful not to have any slight impact
Do not keep it in high temperature places It can make some troubles
Do not keep it in humid places
Special feature of the product
1. 6 in 1 type multimedia
Alio is the 6 in 1 type flash card recorder that is supporting completely
all kinds of the Digital camera, MP3 player, Extension of PDA, and Digital
media [Compact Flash(CF)/ Multimedia card(MMC)/ Smart media card
(SMC)/ Secure digital card(SD)/ Micro drive(MD)/ Memory stick(MS)]
which are on sale in overseas and domestic.
2. No need of any other power
As it use USB power, the other power is not needed
How to install the driver
1. Driver installation for Windows 98/ME/2000/XP
1) Do not connect the product
2) Insert the offered driver CD to CD-ROM drive
3) Choose "Install Windows Driver" among the menu and then install the drive
If you find out any message when you install the driver, please click "Next"
4) Re-booting the computer
5) Connect the Alio to the USB port of the computer
2. Driver installation for MAC(MAC OS 9.0 or greater)
Can be recognized automatically without any special driver
The cautions for using product
1. When you using the Alio and fining out the "red LED", do not remove it
because of loss of data.
2. Windows ME/2000/XP can be recognized without driver but the name of the
memory card that is connected to Slot is not marked exactly.
So we recommended you to install the driver with driver installation CD.
3. If you want to seperate the Alio from the computer or want to remove the media,
make sure if the Access LED is put out and also check if the data is transfered
completly.
After checking, please remove it.
4. Static electricity and strong magnetic materials can make the troubles.
INFORMATION TO THE USER
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one more of the following measures:
-. Reorient or relocate the receiving antenna.
-. Increase the separation between the equipment and receiver.
-. Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
-. Consult the dealer or an experienced radio/TV technician for help.
WARNING
Changes or modifications not expressly approved by the manufacturer
could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operations.
