Savant Technologies GE Lighting a Savant A19-CSLP-II LED LAMP User Manual

GE Lighting LED LAMP

User Manual

GE Connected A19 CSLEEP A19, input 120Vac, frequency was 60Hz,
high efficiency, safety & stability output. Use Bluetooth 4.1 chip
technology to realize the far distance control. Through the APP to
control the PWM signal to dim and even control the switch on & off of
the bulb.
Product features:
1. Controlled by Bluetooth 4.1 to realize the far distance control.
2. CCT range is 2000K-7000K, default CCT is 2700K.
3. With advanced chips to make sure the bulb with high efficiency, low
consumption and stability.
4. Internal constant current output to make sure the high power
conversion efficiency and stability output.
Product Name LED LAMP
Brand Name GE
Model No. CLEDA199S2@
@ rates for package information, maybe
1P~10P
Working Voltage 120Vac
Bluetooth Specification Version 4.1
Frequency Range 2400- 2483.5MHz
Channel Number 40
Channel Separation 2MHz
Type of Modulation GFSK
Data Rate 1Mbps(GFSK)
Antenna Type PCB Antenna
Peak Antenna Gain 0dBi
For additional help, regulatory and safety Information, please go to:
Federal Communications Commission (FCC) Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including
interference that may cause
undesired operation.
The grantee is not responsible for any changes or modifications not
expressly approved by the party responsible for compliance. Such
modifications could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more
of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed and
operated with minimum distance of 20 cm between the radiator and your
body.
CAUTION:
- DO NOT USE WITH STANDARD DIMMERS, SEE
INSTRUCTIONS
-NOT FOR USE IN TOTALLY ENCLOSED LUMINAIRES
-SUITABLE FOR DAMP LOCATIONS
-THIS DEVICE IS NOT INTENDED FOR USE WITH EMERGENCY
EXITS
Only use the control provided with or specified by these instructions to
control this lamp. This lamp will not operate properly when connected to
a standard (incandescent) dimmer or dimming control
IC Statement
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may cause undesired
operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes :
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
IC 20cm RF
This equipment complies with IC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance of 20 cm
between the radiator and your body.
Cet équipement est conforme aux limites dexposition aux rayonnements de la IC établies pour un
environnement non contrôé. Cet équipement doit être installé et fonctionner à au moins 20 cm de
distance dun radiateur ou de votre corps.
