Savi Technology 650MR-V5 SMR-650 User Manual SMR 650 216 FCCstmtA

Savi Technology Inc SMR-650 SMR 650 216 FCCstmtA

Compliance Sheet

Savi Mobile Reader SMR-650-216
U.S. Regulatory Approvals - Compliance Notice
Keep This Document
Savi P/N 805-05803-901 (Rev. A)
Published December 2008
Federal Communications
Commission (FCC) Notice
The Federal Communications Commission has established
technical standards regarding radio frequency energy
emitted by computer devices. This equipment has been
tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may
cause harmful interference with radio/TV reception.
Operation of this equipment in a residential area is likely to
cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Hazardous Location Safety
Conforms to STD UL1604 for use in Division 2, Class I
Groups A, B, C, D, Class II, Groups F, G, Class III
Hazardous (Classified)
Location
Class I, Division 2, Groups A, B, C, D
Class II, Division 2, Groups F, G
Class III, Division 2
The installation must be in accordance with the National
Electric Code, NFPA 70, Articles 504 and 505, and
ANSI/ISA-RP12.06.01.
Warning:
EXPLOSION HAZARD. Do not disconnect
while the circuit is live or unless the area is known to be
free of ignitable concentrations.
The following additional warnings must be observed for
the safety of the operator and others in potentially
hazardous locations:
◆The SMR-650-216 may not be connected to any of
its available accessories while in potentially hazardous
locations. All allowed connections must be made
while outside of the potentially hazardous location.
◆Any connector cover removed while in ordinary
locations must be reinstalled prior to entering a
potentially hazardous location.
Federal Communications
Commission (FCC)
Label Statement
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following conditions:
◆This device may not cause harmful interference, and
◆This device must accept any interference received,
including interference that may cause undesired operation.
The label statement corresponds to the following devices:
Warning:
Changes or modifications to this equipment
that are not expressly approved by Savi Technology could
void the warranty and the authority to operate this
equipment.
Savi Technology is not responsible for radio/TV
interference caused by using unauthorized cable or by
making unauthorized changes to this equipment.
Product Safety
AC adapter: UL approved (UL 60950)
Savi Technology
351 E. Evelyn Avenue
Mountain View, CA 94041-1530
Phone: (650) 316-4700
Fax: (650) 316-4750
E-mail: help@savi.com
Web site: www.savi.com
Copyright © 2008, Savi Technology. All rights reserved.
Copyright protection claimed includes all forms and matters of copyrightable
material and information, now allowed by statutory or judicial law or hereinafter
granted. Information in this guide is subject to change without notice and does not
represent a commitment from the vendor.
Savi is a registered trademark of Savi Technology, Inc. Other product names
mentioned in this guide may be trademarks or registered trademarks of their
respective owners and are hereby acknowledged.
Device Model FCC ID
Radio mobile reader SMR-650-216 KL7-650MR-V5
Savi Mobile Reader SMR-650-216
U.S. Regulatory Approvals Compliance Notice
FCC Registration Requirement for Operation Under Rule 15.240
Radio transmissions from the Savi Mobile Reader SMR-650-216 are governed in the USA by FCC Part 15 rules, and in
Canada by corresponding Industry Canada regulation RSS-210. Other regulations apply in other countries.
The Savi Mobile Reader SMR-650-216 is shipped with the default mode of operation corresponding to FCC Part 15.231.
All prior Savi equipment complies with FCC Part 15.231. Equipment operating under this rule does not require FCC
registration.
However, operation according the FCC Rule 15.240 offers some advantages in throughput and flexibility for applications
involving containerized cargo. The Savi Mobile Reader SMR-650-216 can be configured for operation under this rule, but
only by a qualified technician.
There are restrictions in the geographical locations where such equipment may be deployed so as to maintain a 40 km
separation from five long-range USAF radar installations in the continental USA and Alaska. For this reason, the FCC
requires notification of the locations where Part 15.240 operating equipment is to be installed.
Savi Technology, Inc. notifies the FCC of the initial shipping destination, but it is the responsibility of the end user to mail
a notice of installation, as described in the form provided below, to the FCC. This must be done at the initial installation and
again if the equipment is relocated.
Mail this form to:
Experimental Licensing Branch, OET
Federal Communications Commission
445 12th Street, SW
Washington, DC 20554
ATTN: RFID registration
Selected text from FCC Rule 15.240 operation in the 433.5 - 434.5 MHz band:
a. Operation under this section is restricted to devices that use radio frequency energy to identify the contents of
commercial shipping containers. Operations must be limited to commercial and industrial area such as ports, rail
terminals, and warehouses.
b. To prevent interference to Federal Government radar systems, operation under the provisions of this section is not
permitted within 40 kilometers of the following locations:
DoD Radar Installation Latitude Longitude
Beale Air Force Base 39º08’10”N 121º21’04”
Cape Cod Air Force Base 41º45’07”N 070º32’17”
Clear Air Force Base 64º55’16”N 143º05’02”
Cavalier Air Force Base 48º43’12”N 097º54’00”
Eglin Air Force Base 30º43’12”N 086º12’36”
Savi Mobile Reader SMR-650-216
U.S. Regulatory Approvals Compliance Notice
FCC RFID Registration Form In Compliance with FCC Rule 15.240
Experimental Licensing Branch, OET
Federal Communications Commission
445 12th St., SW
Washington, DC 20554
ATTN: RFID Registration
Subject: Registration for Savi Technology, Inc. Savi Mobile Reader SMR-650-216
The following information concerning the end user and installation location is hereby submitted as required by
FCC Rule 15.240:
End User Company Name: _______________________________________
Contact Person: _______________________________________
Mailing Address of Contact: _______________________________________
_______________________________________
_______________________________________
Street Address of Contact: _______________________________________
_______________________________________
_______________________________________
Contact Telephone Number: _______________________________________
Contact Email Address: _______________________________________
Street Address of
Equipment Installation: _______________________________________
_______________________________________
_______________________________________
Latitude: _______________________________________
Longitude: _______________________________________
FCC Equipment ID: KL7-650MR-V5
Contact Signature: _______________________________________
Date: _______________________________________
COPY FOR USE
KEEP THIS DOCUMENT
Savi Mobile Reader SMR-650-216
U.S. Regulatory Approvals Compliance Notice
