Savox Communications BHS-318 BHS-318 Bluetooth headset User Manual Users manual
Savox communications Oy Ab BHS-318 Bluetooth headset Users manual
Users manual
Quick Guide
Sales package content
Sales package contains the following items:
a. Headset
b. Earhook
c. 3 ear plugs S, M, L (size S plug on headset)
d. Mains charger
e. Mini CD (user guide)
f. Quick Guide
Call functions
Before you can start using the headset, you must first charge the battery
and pair the headset with one compatible device. For the latest compatibility
information please visit www.iqua.com.
Operation Instruction
Power on
When the headset is powered off, press and hold the
Multifunction button until the green light ashes once.
(If the pairing list is empty, the product will automatically
enter the pairing mode)
Power off When the headset is powered on, press the Multifunction
button until the red light ashes once and then turns off.
Paring
When the headset is powered off, press and hold the
Multifunction button until the green and red lights begin
ashing alternately. Follow the instructions in the phone’s user
guide. Pass code is 0000. The device name displayed on
the phone screen is “T-Mobile Orsa”.
Making calls Make a call from your mobile phone in the usual way. The
call will be automatically connected to your headset.
Answering calls Press the Multifunction button lightly; you will hear a tone
once the call is answered.
Ending calls Press the Multifunction button lightly; you will hear a tone
when the call has ended.
Rejecting calls Press the Multifunction button twice and you will hear a
tone indicating that the call has been rejected.
Redialling the last
dialled number
(if supported)
Press the Multifunction button twice when no call is in
progress; you will hear a tone when the redialled call
begins.
Voice dialling
(if supported)
Press the Multifunction button lightly. When you hear a
tone, clearly enunciate the recipient’s name/voice tag to
activate the voice dialling function.
Volume control Use your mobile phone’s volume control to adjust volume.
Call waiting
(if supported)
If you receive a new call during another call, press the
multifunction button lightly to answer the incoming call
and to put the current call on hold. You can switch between
the two calls by pressing the multifunction button lightly.
When you wish to end one of the calls and switch back to
the other, press the Multifunction button twice.
Transferring calls
(if supported)
To transfer an active call between the headset and your
mobile phone, press the Multifunction button until you
hear a tone and then release the button. The call is then
transferred. Alternatively, follow the instructions in the user
guide for your mobile phone’s user guide to transfer calls.
Light indicators
The T-Mobile Orsa has red and green LED lights .
Power on / off Green LED ashes once/ Red LED ashes
once and then turns off.
Standby but no Bluetooth
connection Green LED ashes slowly
Connection active Green LED ashes very slowly
Pairing mode Green and red LED ash alternately
Battery charging Red LED is on continuously
Battery charging complete Red LED turns off and Green LED turns on
Federal Communications Commission (FCC) Statement
You are cautioned that changes or modications not expressly approved by
the part responsible for compliance could void the user’s authority to operate
the equipment.
NOTE: This device has been tested and found to comply with the limits for
a Class B digital device, pursuant to part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this device does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to
the following two conditions:
1. This device may not cause interference and
2. This device must accept any interference, including interference
that may cause undesired operation of the device.
Radiation Exposure Statement:
This device complies with FCC radiation exposure limits set forth for an
uncontrolled environment. End users must follow the specific operating
instructions for satisfying RF exposure compliance. To maintain compliance
with FCC RF exposure compliance requirements, please follow operation
instruction as documented in this manual.
This device must not be co-located or operating in conjunction with any other
antenna or transmitter.
DECLARATION OF CONFORMITY
We, Iqua Ltd., declare under our sole responsibility, that the product,
BHS-318, conforms with the provisions of the following Council Directive:
1999/5/EC. A copy of the Declaration of Conformity can be found at http://
www.iqua.com/declaration_of_conformity.
The Bluetooth word mark and logos are owned by Bluetooth SIG, Inc. and
any use of such marks by Iqua is licensed. Other trademarks and trade
names belong to their respective owners.
Under no circumstances does Iqua assume any liability for loss of or damage
to or corruption of data, for any loss of profit, loss of business, revenues,
contracts, anticipated savings increased costs or expenses or for any
indirect, special, incidental or consequential damages howsoever caused.
Copyright © 2009 Iqua Ltd
Overview of product
The headset contains the following parts:
1. Multifunction button Power on/off, answer/end call
2. Charging connector
3. Indicator light Status indicator with green and red LEDs
4. Earpiece
5. Microphone
6. Earhook holder
Iqua for T-Mobile – Orsa Bluetooth® headset
ab
f
c
de
FCC ID: TUFBHS-318
0560
