Overview

Schlage AD Series locks seamlessly integrate with C • CURE 9000 to provide a cost

eective and scalable access control solution to meet your security needs.

Schlage AD Series locks combine the components typically found around the door,

such as the door position switch and the request to exit switch, into one unit which

simplies installation and saves money. And since they are designed to be modular,

Schlage AD Series locks can easily be upgraded in the future to meet your changing

security and technology requirements.

The AD Series is available in both hardwired and wireless congurations to suit the

requirements of the facility. AD Series wireless locks provide many of the key benets

of a hardwired system including real-time monitoring, audit trails, centralized

lockdown and instant access control management. In retrot applications the Schlage

AD Series wireless locks and devices, which eliminate the need to run wires direct to

each opening, can help you extend the reach of your access control system.

AD-301 and AD-401 FIPS 201-1 Compliant solutions available using FMK reader.

Please contact Software House to conrm they are able to support your FIPS 201

credential format.

System Capabilities

Summary

§AD-400/401 Wireless

− Secure 900 MHz wireless communication,

AES-128 encrypted

− Real time access control and monitoring

− Patent pending wireless lockdown /unlock

feature via PIM400 10 seconds or less

(preserves up to 2 year battery life)

− Powered by four (4) standard o-the-shelf

AA batteries

§AD-300/301 Hardwired

− Field congurable fail safe/fail secure

§Additional details on readers supported and

chassis types available on page 3 and 4

§Weather Resistant, Exterior Operating

Temperature: -31° to 151°F (-35° to 66°C)

§Additional wireless products also available

− Wireless Portable Reader (WPR400)

for muster stations, buses, etc.

− Wireless Reader Interface (WRI400)

eliminates running wires to remote doors,

gate, and elevator applications

§ANSI/BHMA A156.25, ANSI/BHMA Grade 1,

UL 294, UL 10C

Integrated

security solution

with AD-300/301 Hardwired,

AD-400/401 Wireless devices

and C•CURE 9000

For additional information contact Software House: http://www.swhouse.com/products/readers_Schlage_Electronic_Locks.aspx

§iSTAR Pro and eX Controllers support up to 16

readers

− Each connected PIM400-485 can support

up to 16 AD-400/401 wireless devices

− Each connected PIM400-TD2 can support

up to 2 AD-400/401 wireless devices

§New ISTAR Ultra Controller has 2 RS-485

ports. Each port can support up to 16 AD-400

locks on up to 16 PIM400-485 and a

maximum of 32 AD-400 locks total.

§iSTAR Pro supports wake on radio and pin

functionality with CCURE 9000 2.10R2P1

and rmware 5.2.1.19705

§Wireless range up to 200’ in typical building

construction, up to 1000’ clear line of sight

§iSTAR Controllers support up to 16 readers

− When connected directly can support up to

16 AD-300/301 wired devices; daisy chained

− Each connected PIB300-2D can support up

to 2 AD-300/301 wired devices

§New ISTAR Ultra Controller has 2 RS-485 ports.

Each port can support up to 16 AD-400 locks

on up to 16 PIM400-485 maximum of 32

AD-400 locks total.

Note:

Please refer to AD-300, AD-301, PIB300-2D, AD-400, AD-401, PIM400-485, PIM400-TD2, and Relay Board RLBD data sheets for complete AD Series specications.

C•CURE 9000

PIM400-485

Panel interface module

PIM400-TD2 + RLBD

Panel interface module

and relay board

Schlage

protocol

GCM

(iSTAR Pro)

Wiegand or Clock

and Data protocol

RS-485

AD-400/401

Wireless devices

AD-400/401

Wireless devices

Ethernet

900 MHz

900 MHz

Rev

v2.40 or higher

iSTAR Pro,

controllers

(rev 5.9

or higher)

iSTAR eX

(rev 6.2

or higher)

iSTAR Ultra

(rev 6.2 and

higher)

iSTAR eX, Edge controllers

(rev 6.2 or higher)

apC8x and apC/L

controllers Rev x.7ZB

iSTAR Pro Controller

(rev 5.9 or higher)

iSTAR Classic Controller

(rev 4.4.A.12523 or higher)

iSTAR Ultra Controller

(rev 6.2 or higher)

AD-400/401 via RS-485 and/or Wiegand with

C • CURE 9000 and iSTAR Controllers

AD-300/301 via RS-485 and/or Wiegand with

C • CURE 9000 and iSTAR Controllers

C•CURE 9000

PIB300-2D + RLBD

Panel interface module

and relay board

Schlage

protocol

RSI protocol

GCM

(iSTAR Pro)

Wiegand or Clock

and Data protocol

RS-485

RS-485

AD-300/301

Hardwired devices

AD-300/301

Hardwired devices

Ethernet

iSTAR Pro,

controllers

(rev 5.9

or higher)

iSTAR eX

(rev 6.2

or higher)

iSTAR Ultra

(rev 6.2 and

higher)

iSTAR eX, Edge controllers

(rev 6.2 or higher)

apC8x and apC/L

controllers Rev x.7ZB

iSTAR Pro Controller

(rev 5.9 or higher)

iSTAR Classic Controller

(rev 4.4.A.12523 or higher)

iSTAR Ultra Controller

(rev 6.2 or higher)

Rev v2.40

or higher

For additional information contact Software House: http://www.swhouse.com/products/readers_Schlage_Electronic_Locks.aspx

Proximity cards (125 kHz):

§AWID®

§GE/CASI®

§HID®

§Schlage®

§XceedID®

Please contact

Software House for

additional details on

integrated features and

credentials supported.

1 75 bit format output default. Congurable to other output formats.

2 Wake-up on Radio over PIM400-TD2 on up to 2 doors requires conguration at PIM via HHD

3 FIPS 201 compliant option available: The AD Series can be used in applications which require approval by the U.S. Federal Government under HSPD-12 for FIPS 201 compliance. Specic

components are required, please see the AD-401 data sheet or AD-301 data sheet for complete details. Contact Software House to conrm they are able to support your FIPS 201-1

credential format.

4 iStar Ultra

Supported card formats

Smart cards (13.56 MHz):

§aptiQ™ MIFARE Classic

§aptiQ™ MIFARE DESFire™ EV1

§PIV and PIV-I compatible 3

Smart cards (13.56 MHz) -

reads card serial number only:

§HID iCLASS®

§DESFire®

§MIFARE®

§MIFARE DESFire™ EV1

System capabilities:

AD-400/401

PIM400-485

AD-400/401

PIM400-TD2 + RLBD

AD-300/301

Direct RS485

AD-300/301

PIB300-2D + RLBD

Features

Maximum number of readers supported by

controller/PIM/PIB

16 /32416 16 /32416

Maximum number of readers

per PIM400/PIB300

16 2 N/A 2

Maximum number of PIM400s and/or

AD-300s per RS-485 port

Up to 16 n/A Up to 16 N/A

Access control decision made by

host or by lock database

Host Host Host Host

Remote Linking capability via Host No No N/A N/A

Readers - see supported card

formats below

Keypad only Yes Ye s Yes Yes

Magnetic stripe card Ye s Yes Yes Yes

Multi-technology - 125 kHz proximity

and 13.56 MHz smart card

Yes (smart cards

up to 32 bits)

Yes (smart cards

up to 32 bits)

Yes (smart cards

up to 32 bits)

Yes (smart cards

up to 32 bits)

PIV & PIV-I card compatible1, 3 Yes Ye s Yes Yes

Card + PIN Yes Ye s Yes Yes

Status monitors

Request to exit Yes Yes Yes Yes

Door position Yes Ye s Yes Yes

Mechanical key override Yes Ye s Yes Yes

Request to enter No No No No

Low battery status Yes Ye s N/A N/A

Communication status: RF/RS-485 Yes /Yes Ye s/ Yes Yes/ Yes Yes /Yes

Remote lockdown/unlock Yes (<10 sec) Yes (<10 sec) 2Yes Yes

Deadbolt position No No No No

Interior push button Ye s Yes Ye s Yes

Lock functions

Classroom/storeroom Yes Yes Yes Yes

Privacy Yes Yes Ye s Yes

Allegion (NYSE: ALLE) is a global pioneer in safety and security, with leading brands

like CISA®

, Interflex®

, LCN®

, Schlage® and Von Duprin®

. Focusing on security around the

door and adjacent areas, Allegion produces a range of solutions for homes, businesses,

schools and other institutions. Allegion is a $2 billion company, with products sold in

almost 130 countries. For more, visit www.allegion.com.

About Allegion

© 2015 Allegion

009834, Rev. 08/15

www.allegion.com/us

Available AD Series reader modules

The AD Series exit trims are exclusively

compatible with exit devices made by Allegion

when using the low current request to exit switch

(RX-LC part # 050281 for Von Duprin 98/99 &

Von Duprin 22/22F Rim/SVR devices and part

number 650359 for Falcon 25 Rim devices).

Allegion, the Allegion logo, Schlage, the Schlage logo, Von Duprin, Falcon, and aptiQ are trademarks of Allegion plc, its subsidiaries

and/or aliates in the United States and other countries. All other trademarks are the property of their respective owners.

For additional information contact Software House: http://www.swhouse.com/products/readers_Schlage_Electronic_Locks.aspx

Mortise Lock

(AD-300/301-MS)

(AD-400/401-MS)

Cylindrical Lock

(AD-300/301-CY)

(AD-400/401-CY)

Exit Device Trim

(AD-300/301/400/401-993)

Magnetic stripe

(insertion)

Multi-technology

§Proximity

§Smart card

Handheld device

(HHD)

Used to initialize,

congure, and test

AD Series Devices

Magnetic stripe

(swipe)

Multi-technology

§Proximity

§Smart card

KEYPAD

+

FIPS 201-1 compliant

option available (FMK)

Magnetic stripe

(swipe)

KEYPAD

Magnetic stripe

(insertion)

KEYPAD

+ +

605

Bright brass

606

Satin brass

612

Satin bronze

643e

Aged bronze

619

Satin nickel

626

Satin chrome

626AM

Satin chrome with

antimicrobial

625

Bright chrome

Finishes

Warm tone nishes Cool tone nishes

Lever styles

Standard cylinders shown, SFIC and FSIC also available.

Sparta Rhodes

Athens Tubular

Compatibility

AD Series electronic locks from Schlage

are built from the ground up to provide

more options, more functionality and more

compatibility than any other solution on

the market today. Designed to suite with

the most popular lever styles and nishes,

Schlage AD Series locks can be congured to

accept most major key systems. See lever and

cylinder compatibility data sheet (010432).
