Schlage Residential 2018 Multi Family Price Book MULTIFAMILY Q2

2018 Schlage Multi-Family Price Book SCHLAGE_MULTIFAMILY_Q2_2018 Price Book

User Manual: Schlage Residential 2018 Schlage Multi-Family Price Book Price Book

Open the PDF directly: View PDF PDF.
Page Count: 157 [warning: Documents this large are best viewed by clicking the View PDF Link!]

Marketing Bulletin
!
Page!2:!Boardwalk!and!Longitude!lever!options!added.!!
Page!10:!Schlage!Control!Certifications!updated;!approved!for!use!where!the!exterior!escutcheon!only!is!
exposed!to!the!outdoors.!!
Page!11:!Measurement!correction!for!Part!No.!47244555!(for!doors!between!1-3/4”!and!2-1/4”!!
Page!72:!5800!e-strike!obsoleted!from!book.!!
!
!
!
!
!
!
Brand/product
MultiFamily, Price Book 5, Effective August 2017, Rev. 7/18
Date
June 4, 2018
Subject
Quarterly Price Book Update (July 2018)
Contact
Megan Mills
Click next for quick tips on
how to navigate Allegion
Price Books quicker!
Effective January 8, 2018 • Rev 4/18
Multi-family
Price Book 5
Where residential and commercial
lever styles meet
Schlage, Falcon, and Von Duprin locks and exit lever designs allow for residential and
common areas to match in style, whether that is contemporary, to transitional, to
traditional. While the lever and trim names may differ between the various series below,
you can have confidence that each lever design will coordinate into one of the lever suiting
styles. Coordinate the lever designs below to create seamless transitions between
residential and commercial areas.
Contemporary Contemporary /
Transitional Transitional /Traditional Traditional
Residential area locks
Schlage Control Smart Interconnected Lock - Grade 2 Latitude Broadway Jupiter, Jazz Neptune Elan
Schlage F Series cylindrical lock - Grade 2 Latitude Broadway Jazz Jazz Elan
Schlage J Series lock - Grade 3 Solstice -Dover Dover Marin
Common area locks
Schlage LE mortise wireless lock - Grade 1 Latitude M52 07 17 06
Schlage L Series mortise lock - Grade 1 Latitude M52 07 17 06
Schlage NDE cylindrical wireless lock - Grade 1 Latitude Broadway Athens Sparta Rhodes
Schlage ND Series cylindrical lock - Grade 1 Latitude Broadway Athens Sparta Rhodes
Schlage CS210 interconnected lock - Grade 2 Latitude Broadway Jupiter Neptune Saturn
Falcon MA Series mortise lock - Grade 1 Latitude Broadway Avalon Quantum Dane
Falcon T Series cylindrical lock - Grade 1 Latitude Broadway Avalon Quantum Dane
Falcon W Series cylindrical lock - Grade 2 Latitude Broadway Avalon Quantum Dane
Falcon H2 Series interconnected lock - Grade 2 Latitude Broadway Avalon Quantum Dane
Commercial exit devices and trim
Von Duprin 98/99 Series wide stile pushpad - Grade 1 Latitude M52 07 17 06
Falcon 25 Series wide stile pushpad - Grade 1 Latitude Broadway Avalon Quantum Dane
Falcon 24 Series narrow stile pushpad - Grade 1 Latitude Broadway Avalon Quantum Dane
Note: Not all levers and trim are listed for the products mentioned in this price book.
For the complete offering, contact your sales consultant.
Contemporary
Minimalist lever design
with clean lines
Contemporary/Transitional
Rounded, high-style lever design
Transitional/Traditional
Curved, tapered lever design
Traditional
Simplistic return-to-
door lever design
Latitude, Longitude,
Solstice
Broadway, Boardwalk,
M52
Jazz, Jupiter, Athens,
Dover, Avalon, 07
Quantum, Sparta,
Neptune, 17
Rhodes, Saturn,
Marin, Elan, Dane, 06
Price Book 5 | Effective January 8, 2018 | 800.847.1864 3
Multi-family
Contents
Terms and Conditions ................................................................................................... 4-7
Locks
Residential Electronic Locks
Schlage Control FE410 Smart Interconnected Locks - Grade 2 ....................... 8-9
Schlage Control BE467 Smart Deadbolts - Grade 2 ......................................... 10-11
Schlage Control Multi-Family Residential Electronic Locks - Top Sellers.........12
Schlage Programmable Electronic Deadbolt (BE367) ....................................13-15
Schlage Programmable Electronic Interconnected (FE210) ..........................16-17
Interconnect Lever Designs ........................................................................................... 18
Deadbolt Strikes ...............................................................................................................19
i-Button Credentials .......................................................................................................20
Access Management Software Systems ....................................................................21
Residential Mechanical Locks
Schlage F Series - Grade 1 ..............................................................................................23
Schlage J Series - Grade 3 .......................................................................................24-25
B and J Series Deadbolts..........................................................................................26-31
Schlage LE Mortise Wireless Locks - Grade 1 ..................................................... 32-33
Commercial Wireless Electronic/Electried Locks, Readers and Devices
Schlage LE Mortise Wireless Locks - Grade 1 ..................................................... 34-37
Schlage NDE Cylindrical Wireless Locks - Grade 1 ............................................ 38-41
Schlage CTE Single Door Controller ........................................................................... 42
Schlage MT11/15-485 Credential Readers ........................................................ 43-44
Commercial Mechanical and Electried Locks - Schlage and Falcon
Schlage B500 - Single Cylinder Deadbolt Series ................................................. 45
Schlage CS210 Interconnect Lock - Grade 2 ..................................................... 45-46
Schlage L Series Mortise Locks - Grade 1 ............................................................47-56
Schlage ND Series Cylindrical Locks - Grade 1 ................................................... 57-59
Schlage AL Series Cylindrical Locks - Grade 2 .................................................. 60-62
Falcon MA Series Grade 1 Mortise Lock .............................................................. 63-66
Falcon T Series Grade 1 Cylindrical Lock .............................................................67-69
Falcon W Series Grade 1 Cylindrical Lock ............................................................ 70-73
Falcon D200 Grade 2 Medium Duty Deadbolt ................................................. 74-76
Falcon H2 Series Grade 2 Interconnected Lock .................................................77-78
Falcon Cylinders ................................................................................................................79
Falcon Conventional Cylinders ....................................................................................80
Falcon Interchangeable Cores ...................................................................................... 81
Falcon IC Cylinders ........................................................................................................... 81
Falcon Conventional Keys and Blanks ...................................................................... 82
IC Keys and Key Blanks, Disposable Construction Core ........................................ 83
Falcon Keys & Keying Construction Core Program ................................................84
Exits
Von Duprin
Von Duprin 22 Series ...................................................................................................... 85
Von Duprin 22 Series Trim .............................................................................................86
Von Duprin Auxiliary Parts .............................................................................................87
Von Duprin Electronics e-Strike...................................................................................88
Von Duprin 98 Series ......................................................................................................89
Von Duprin Device Options ........................................................................................... 90
Von Duprin Device Accessories ..................................................................................... 91
Von Duprin Dummy Touch Bars ................................................................................... 91
Falcon
Falcon 24 Series .........................................................................................................92-97
Falcon 25 Series .......................................................................................................98-103
Falcon 19 Series......................................................................................................104-109
Falcon 1690 Series ..........................................................................................................110
Falcon 1790 Series ............................................................................................................111
Falcon 1990 Series .......................................................................................................... 112
Falcon 2090 Series ......................................................................................................... 113
Door Closers
LCN
LCN 1250 Series Surface Door Closers .......................................................................114
LCN 1260 Series Surface Door Closers ....................................................................... 114
LCN 1450 Series Surface Door Closers ....................................................................... 114
LCN 1460 Series Surface Door Closers .......................................................................115
LCN 4040XP Series Surface Door Closers ................................................................ 115
LCN 4050 Series Surface Door Closers .....................................................................115
LCN Parts and Components .........................................................................................116
Automatic Operators ..................................................................................................... 117
Falcon
Falcon Surface Door Closers ................................................................................. 118-119
Falcon SC60A Series .....................................................................................................120
Falcon SC70A Series .......................................................................................................121
Falcon SC80A Series ..................................................................................................... 122
Falcon SC90A Series ..................................................................................................... 123
Architectural Hardware
Ives
Architectural Hinges ...................................................................................................... 124
Continuous Hinges ......................................................................................................... 124
Pivots ................................................................................................................................. 125
Floor Stops ....................................................................................................................... 126
Wall Stops .........................................................................................................................127
Pulls and Protection Plates ........................................................................................128
Vandal Resistant Trim ..................................................................................................129
Flush Bolts and Strikes .................................................................................................129
Coordinators, Lock Guards, and Surface Bolts .......................................................130
Latches and Catches ...................................................................................................... 131
Miscellaneous Hardware ..............................................................................................132
Schlage
Schlage Barn Door Hardware .............................................................................133-134
Overhead Holders and Stops
Glynn-Johnson
70 Series Heavy Duty Surface Mount ...................................................................... 135
81 Series Heavy Duty Surface Mount .......................................................................135
90 Series Heavy Duty Surface Mount ......................................................................135
100 Series Heavy Duty Concealed Mount ...............................................................136
410 Series Medium Duty Concealed Mount ............................................................136
450 Series Medium Duty Surface Mount ................................................................136
510 Series Adjustable Heavy Duty Concealed Mount ...........................................137
550 Series Adjustable Heavy Duty Surface Mount ...............................................137
How to Order
Locks
Schlage Residental ........................................................................................................138
Schlage Commercial .....................................................................................................139
Commercial Wireless Electronic/Electried Locks, Readers and Devices
Schlage LE Series ................................................................................................... 140-141
Schlage NDE ............................................................................................................142-143
Schlage CTE Series ........................................................................................................144
Commercial Mechanical Locks
Schlage ND Series ..........................................................................................................145
Schlage L Series ..............................................................................................................146
Schlage AL Series ........................................................................................................... 147
Exits
Von Duprin Exits .............................................................................................................148
Falcon Exits ......................................................................................................................149
Falcon Trim.......................................................................................................................150
Closers
LCN ...................................................................................................................................... 151
Falcon ........................................................................................................................152-154
Accessories
Glynn-Johnson ................................................................................................................155
Price Book 5 | Effective January 8, 2018 | 800.847.1864
4
Terms and Conditions
1. GENERAL/ACCEPTANCE. (a) This Agreement contains the only terms and conditions by
which Company will quote and sell Deliverables to Customer; (b) The terms “purchase order”
or “order” for the purposes of this Agreement include the term “request for quotation,” as
appropriate; (c) This Agreement supersedes all pre-printed or boilerplate terms and conditions
set forth in any purchase order issued by Customer; (d) No reference herein to Customer’s
purchase order will in any way incorporate different or additional terms and conditions, all
of which Company hereby expressly objects to; (e) ANY ACCEPTANCE BY COMPANY OF
CUSTOMER’S PURCHASE ORDER IS EXPRESSLY CONDITIONED ON THE CUSTOMER’S
ASSENT TO AND ACCEPTANCE OF THE TERMS AND CONDITIONS CONTAINED IN
THIS AGREEMENT; (f) Company reserves the right to decline any order, in whole or in part,
for any reason.
2. ORDERS.
a. Order Processing. When Customer wishes to place an order for Deliverables, it will
deliver to Company a purchase order. All such purchase orders must (i) be in a written format
acceptable to Company, (ii) be legible, (iii) include a purchase order number, (iv) include
Customer’s account number, invoice address, ship to address, shipping method, shipper’s
letter of instruction for international shipments, part number, pricing, and designated contact
information, (v) include, if applicable, any special configuration ID numbers, necessary
programming information, special factory instructions, and requested specifications regarding
a particular finish, handing, design, backset, or strike, (vi) reference any applicable pricing
discounts under an ongoing buying program or based on a written quote from Company,
along with the applicable buying program number or quotation number, and (vii) not combine
buying program and quoted product on the same order.
b. Minimum Orders. In the event the order value does not meet any required minimum
net Deliverable value, Company may, at its sole discretion, (i) increase the quantity of items
in the order to meet the minimum net Deliverable value requirement; (ii) apply a minimum
order charge; (iii) reject the order, or (iv) waive the requirement, provided that the waiver of
a requirement for one order shall not constitute a waiver of the requirement for any future
orders.
c. Acceptance of Purchase Orders. Company will endeavor to (i) acknowledge receipt
of each purchase order issued in accordance with this Agreement, and (ii) notify Customer
whether Company accepts or rejects the purchase order. If Company fails to accept or reject
a purchase order within a reasonable time period, such failure to respond will be deemed a
rejection of the entire order.
Orders that combine buying program and quoted product on the
same order will be routed back to your local SSC office in order to review subject purchase order.
d. Changes to Order/ Cancellation of Orders. Additional terms and conditions regarding
order changes and cancellations are available on the Allegion customer website, WHICH
TERMS ARE EXPRESSLY INCORPORATED HEREIN BY REFERENCE. Unless otherwise
provided herein, Customer acknowledges that (i) requesting a Change Order may cause
a delay in the scheduled shipment date, a longer lead time or result in a new scheduled
shipment date; (ii) Orders may not be changed after 48 hours of Company’s order
acknowledgment; (iii) After 48 hours of Company’s order acknowledgment, all changes
to an accepted purchase order will be subject to a Change Order charge of 25% of the net
Deliverable value, plus the cost of labor and fabrication or raw material that Company incurred
prior to the receipt of the Change Order from Customer, or that may be required due to the
Change Order; (iv) the requested change may result in additional charges for labor, fabrication,
and raw material, and (v) if Customer cancels an order or portion of an order that includes
Deliverables that have been manufactured and prepped for shipping, a 45% restocking fee
will apply. Notwithstanding the foregoing, Customer cannot change or cancel credential
orders, reader orders, biometrics orders or any non-cataloged, special, Custom or nonstandard
items once they have been placed. All cancelled orders for a Non Recurring Expense (NRE),
credential orders, reader orders, biometrics orders, and/or Custom orders will be subject to a
cancellation charge of 100% of the acknowledged price.
e. Add-ons. Add-on orders will not be accepted. Additions to orders will be entered as
separate stand-alone orders and must qualify for all terms of sale, including discounts, on an
individual basis.
f. Fast-Track Orders. No changes or cancellations will be accepted on the 24-Hour Fast
Track Program. For 3-day Fast Track orders, changes and cancellations may only be requested
by Customer within 24 hours of Company’s order acknowledgment if the order has not
shipped. For 5-Day Fast Track orders, changes and cancellations may only be requested by
Customer if the order has not shipped and if the request is made to Company within 48 hours
of Company’s order acknowledgment. Return Material Authorization (RMA) for Deliverables
must be processed through Fast Track Customer Service.
g. Steelcraft Orders. For all Steelcraft orders, changes or cancellations are allowed without
penalty only if made within 48 hours of Company’s order acknowledgment, and provided that
the order has not shipped. Some exceptions do apply – please consult the factory. Changes
are not allowed on Rapid Program orders after the order has been entered and acknowledged.
After 48 hours of Company’s order acknowledgment, all changes or cancellations are subject
to a charge of 25% of the order. Unless otherwise specified by Company in writing, any
changes to orders acknowledged by Company that affect the delivery date will be deemed
a new order and will require acknowledgement by Company as provided in this Section.
Additional products, features, terms and conditions regarding the Rapid Program are available
on the Allegion customer website, WHICH TERMS ARE EXPRESSLY INCORPORATED
HEREIN BY REFERENCE.
3. PRICES, INVOICES AND PAYMENT.
a. Prices. The prices in Company’s Price Book are subject to change at any time, without
notice to Customer. Company may charge Customer additional amounts if Customer requests
special packing, marking, shipment, product modification, or engineering services. Oral prices
specified by Company are null and void. Quote numbers must be referenced on Customer’s
purchase order in order for the Company’s quoted pricing to apply. Orders that do not
reference a quote number will receive buy program pricing or book net pricing. Quoted prices
are for those specific products quoted for a specified job, and are subject to the Price Book in
effect at the time Company receives the order.
b. Taxes. Prices do not include any present or future federal, state or local property, license,
privilege, sales, use, excise, gross receipts or other like taxes or assessments which may result
from transactions or any services performed in connection therewith. Any taxes, charges,
or duties imposed by any governmental authority on the sale of Deliverables will be paid by
Customer, in addition to the selling price specified by Company.
c. Payment Terms. Company will deliver to Customer an invoice with each shipment of
Deliverables hereunder. Customer will pay all invoiced amounts within 35 days of the invoice
date (subject to any early pay discounts that may be offered to Customer by Company in
its sole discretion). Customer will make all payments in United States dollars. Past due
invoices will be subject to a late payment service charge of 1.5% per month on any overdue
unpaid balance, equivalent to 18% per annum, or the maximum rate permitted by law,
whichever is less. Customer shall reimburse Company for all costs of collection, including,
without limitation, reasonable attorneys' fees, for any overdue amount owed by Customer to
Company, and such collection costs shall also be subject to interest charges.
4. QUOTATIONS.
a. Project Quotations. Project or new construction quotes are restricted to the specific
project quoted for the quantities, finishes, and series of Deliverables referenced on the quote.
Company reserves the right to require proof of sale of Company products for any quoted
project.
b. Stock Quotations. Deliverables fulfilling stock quotations may only be used for the
following: i) Stocking of the Customer’s shelves for small, quick-turn, discretionary projects, or
ii) Sale to a general contractor or installer for new construction. Stock quotations may not be
used for any project containing any Company no-substitution, specified products. Deliverables
purchased under Stock Quotations cannot be redistributed to other Customer branch locations
or re-sold to other resellers or used for aftermarket sales, end-user annual contracts or sold
over the counter to any walk in trade.
c. General. All quotes are subject to this Agreement, unless otherwise specified by
Company, and are subject to change at any time prior to Company’s acceptance of a purchase
order referencing the applicable quote number. Company, its representatives and employees
reserve the right, in their sole discretion and for any reason, to refuse a Customer’s request
to quote a price other than the standard list price, regardless of whether Company or its
representatives or employees have previously quoted discounted prices to the Customer on
some or all of its orders. Customer’s failure to comply with this Section 4 will be considered
a material breach of this Agreement, and will entitle Company to immediately terminate any
purchase orders and/or Customer’s ability to distribute Company’s products.
5. SECURITY INTEREST. Customer grants Company, and Company retains, a purchase
money security interest and lien on any and all of Customer’s rights, title and interest in
each Deliverable sold by Company to Customer, wherever located, until the invoice for the
applicable Deliverable(s) is paid in full, including any late charges and costs of collection.
Customer authorizes Company to, and will assist Company in, taking all necessary steps to
perfect and maintain Company’s interest in such Deliverables.
6. CREDIT TERMS. . Unless Customer pre-pays all of its purchase orders in advance, its
purchase orders will be subject to the credit limit and other terms of credit (“Credit Terms”)
set forth in Company’s credit application, which Credit Terms Customer acknowledges are
subject to change by Company at any time. Company reserves the right to request payment in
advance of shipment or any order or to request adequate assurances for Customer’s payment
of an order and may withhold or stop shipment, without any liability to Company, until
Customer submits payment or adequate assurance of payment.
7. RESALE OF DELIVERABLES. Customer agrees and warrants that it will offer Company
products in support of Company-written specifications and will maintain sufficient inventory
to adequately support End Users, installers, and/or general contractors’ needs. Company may
implement an MSRP or a resale pricing programs at any time in its sole discretion. Failure
to comply with such program(s) will be considered a material breach of this Agreement,
and will entitle Company to immediately terminate any purchase order and/or Customer’s
ability to distribute Company’s products. Customer shall, at its own expense, gain and
maintain sufficient knowledge of the industry and products competitive with Deliverables so
as to be able to (a) explain in detail to End Users, installers, and/or general contractors the
differences between the Deliverables and competing products, (b) ensure that an adequate
number of trained, capable and qualified technical personnel with sufficient knowledge of the
Deliverables and who have obtained all necessary licenses and permits are available to assist
End Users, installers, and/or general contractors, and (c) respond to such End Users, installers,
and/or general contractors with respect to the general operation and use of the Deliverables
including, but not limited to, (1) acting as a liaison between the End Users, installers and/or
general contractors and Company in matters requiring Company participation, (2) providing
general product information and configuration support on standard protocols and features,
(3) collecting relevant technical problem identification information, and (4) posting and
distributing any warranty information concerning the Products in accordance with Company’s
instructions. Customer is responsible for all service and support resulting from the re-sale
of any Deliverable to End-Users, installers and/or general contractors, examples of which
may include, but are not limited to, support activities such as installation, initialization,
software set-up, training, trouble-shooting, technical support and field service. In the event
Customer is unwilling or unable to perform said support activities, Company reserves the right
to recover from Customer any and all expenses incurred by Company to resolve the afore-
mentioned End-User, installer and/or general contractor issues. Technical product training is
recommended for Customer in order to fully service and support Deliverables purchased from
Company that are resold to End-Users, installers and/or general contractors.
8. DEFAULT. If Customer is in default of payment or otherwise with respect to any purchase
order or other contract with Company, Company shall have the right, in addition to all other
legal remedies and without prejudice to any of its right hereunder, to defer further shipments
under that or any other purchase order until such default is corrected and to declare all
outstanding bills of Customer to be immediately due and payable.
9. INSPECTION AND DELIVERY.
a. Inspection. Customer will inspect all Deliverables immediately after receiving them.
Customer will be deemed to have accepted the Deliverables unless Customer notifies
Company in writing of any nonconformance within 10 days of delivery and provides Company
written evidence reasonably documenting that nonconformance. Inspection of Deliverables at
Company’s facility is not permitted.
b. Delivery. Delivery schedules for Deliverables are based upon current production
capacities, material or component availability, and inventory, and may be changed by
Company as conditions require. Delivery schedules for services are based upon Company’s
prompt receipt of, and prompt access to, Customer’s equipment and all information necessary
to complete the services. In no event will any delivery date be construed as falling within the
meaning of “time is of the essence.” Partial delivery shall be accepted by Customer and paid
for at the price and on the terms stated herein. Any partial delivery shall constitute a separate
sale, and payment shall be separately made when due. If any part of a delivery hereunder is
not delivered by Company in accordance with Customer’s purchase order, this Agreement shall
not be affected thereby.
10. TITLE & RISK OF LOSS. Unless otherwise specified by Company, (i) where the Customer
is located in the United States, all Deliverables will be sold “Uniform Commercial Code, FOB
Origin, Company’s factory”; and (ii) where the Customer is located outside of the United
States, all Products will be sold “Ex-works, Company’s factory (Incoterms 2010).” In either
instance, title and risk of loss will pass to Customer upon delivery to the carrier at Company’s
Allegion General Terms and Conditions of Sale and Service
Price Book 5 | Effective January 8, 2018 | 800.847.1864 5
factory, provided, however, as set forth herein, Company shall retain a security interest in the
Deliverables until full payment has been made therefore, and Customer agrees, upon request,
to do all things and acts necessary to protect Company’s interest by adequately insuring
the Deliverables against loss or damage from any cause and to have Company named as
an additional insured. Customer will promptly provide Company with a copy of the relevant
certificate of insurance upon Company’s request.
11. SHIPPING.
a. Freight Charges. Company will ship all Deliverables in accordance with Company’s
freight shipment guidelines, which are set forth on the My Allegion Portal (“Freight Shipping
Guidelines”), WHICH TERMS ARE EXPRESSLY INCORPORATED HEREIN.
b. Rush Charges. Expedited order options are available as set forth in Company’s Freight
Shipping Guidelines.
c. Packing and Marking. Company will pack, mark, and ship Deliverables according to its
standard procedures for shipment, unless the parties agree, in writing, that Company will
comply with any special instructions provided by Customer. Special instructions may result in
an increased price.
d. International Shipments. For all international orders, a Shipper’s letter of instruction
must be submitted in writing with the order. Failure to do so will result in the order being
rejected. Complete adherence to this order requirement will be strictly enforced. Company
will not be held liable for any charges resulting from delays due to lack of complete required
information being supplied.
e. Once received by the Company, a purchase order cannot be combined with any other
order to increase average order size as it relates to Company’s Freight Shipping Guidelines.
However, for orders placed under Company’s FastTrack 24 Hour/5 Day Program (available for
Schlage, Von Duprin, LCN and Glynn-Johnson products); ii) FastTrack 24 Hour/3 Day Program
(available for Ives products); or ProExpress (available for specific product lines stated in the
ProExpress price book for Falcon, Ives, Glynn Johnson, LCN, Schlage and Von Duprin prod-
ucts), the applicable brands or product categories may, subject to certain order requirements
identified by Company, be combined on a single order to increase average order size used in
Company’s Freight Shipping Guidelines.
12. CLAIMS. All claims must be submitted in writing to Company as follows: (i) All claims
for prices must be submitted within thirty (30) days from the date of invoice; (ii) All claims
regarding Deliverable quantity or incorrect orders must be submitted within ten (10) days
from the date of delivery; (iii) All claims for damage to Deliverables (while in the care,
custody, and control of Company) must be submitted within thirty (30) days from the date
of invoice; (iv) All claims for loss or damage to Deliverables while in the care, custody, and/
or control of a carrier will be the responsibility of Customer, unless otherwise agreed by the
parties.
13. PRODUCT CHANGES. Company’s product policy is one of ongoing update and revision,
and accordingly, Company reserves the right to change, without notice, the design of, or the
process of manufacturing, the Deliverables covered by this Agreement.
14. PRODUCT USAGE LIMITATION. Customer agrees: (i) not to sell or use a Deliverable in
any manner contrary to the manner in which the Deliverable is intended to be used; and/or
(ii) not to modify the design of any Deliverable for use with another product without the prior
written consent of Company.
15. PRODUCT RETURNS. Unless otherwise agreed by the parties in writing, Deliverables
that are correctly furnished by Company per the purchase order may not be returned
unless Customer receives written authorization from Company. If returns are authorized
by Company, a return merchandise authorization (“RMA”) number must be provided by
Company. Deliverables identified under such RMA must be returned to Company within 90
days of issuance of the RMA. Such RMA number and any accompanying RMA documents, the
original invoice number, and a written explanation for the return must be included with the
returned Deliverables in order for Company to inspect and approve a credit for the return. For
warranty returns, a credit in the amount of the original purchase price will only be issued
if, after Company’s receipt and inspection of the returned Deliverables, Company confirms, in
its sole discretion, the defect is valid and approves the return. For non-warranty returns/
convenience returns, in the event Company approves such a return, in its sole discretion, the
following shall apply: (a) the total amount of Deliverables requested to be returned shall be
a minimum of $250.00; (b) a credit will be made to Customer’s account in the amount of the
original purchase price less freight and a handling charge of 45% of the net material on the
original invoice; and (c) only Deliverables that are new, current, standard, non-obsolete, non-
specially manufactured, unused, in their original condition as at the time of sale by Company
to Customer, in their original packaging and in Customer’s inventory less than 180 days from
the date of shipment by the Company, and not ordered as part of a master key solution
may be considered by Company for return. Such credit will only be issued if, after Company’s
receipt and inspection of Deliverables, Company approves the return. The amount of final
credit will be determined upon receipt at the factory and following Company’s inspection and
analysis of the condition of the returned material. Company retains the right to deny credit to
anyone for any reason.
16. CONFIDENTIAL INFORMATION.
a. Non-Use And Non-Disclosure. Customer shall not use the Confidential Information of
the Company except for the purpose of performing its obligations under this Agreement or
exercising the rights granted herein (the “Purpose”). Customer shall protect Confidential
Information of the Company from disclosure and unauthorized use in the same manner that
it protects its own Confidential Information, but in no event shall such standard of care be
less than reasonable care. Customer may disclose Confidential Information of the Company
only to its employees who require such information for the Purpose and who are subject to
confidentiality obligations at least as protective as those set forth herein.
b. Proprietary Information and Advice. (a) All designs, data, and specifications provided by
Company are proprietary and may not be disclosed or reused by Customer without the prior
written consent of Company; (b) Company assumes no obligation or liability for any advice
given by Company, the results obtained, or damages incurred as a result of such advice, and
all such advice is given and accepted at Customer’s risk.
c. Return. Upon the termination or expiration of a purchase order or this Agreement
or upon the request of the Company, the Customer agrees to end all further use of, to
immediately return to the Company the original version of, and to delete or destroy all copies
of, any and all Confidential Information of the Company.
17. TRADEMARKS. Except as agreed to by Company in writing, Customer agrees not to (a)
use Company’s name in any form of publicity; or (b) use, create, register or market, directly or
indirectly, in whole or in part, Company’s names, logos, brands, or any other trademarks, or
names that are now or may hereafter be owned by Company, as part of Customer’s corporate
or business name, as part of an internet domain name, uniform resource locator (URL), or
in any way connected with Customer’s business, trade address or other designations. Upon
termination of this Agreement or upon the request of company for any reason, any use of
Company’s trademarks or names will be immediately discontinued.
18. LIMITED WARRANTY.
COMPANY MAKES NO OTHER WARRANTIES EXCEPT THOSE STATED IN
COMPANY’S LIMITED WARRANTY IN EFFECT ON THE DATE COMPANY ACCEPTS
EACH APPLICABLE PURCHASE ORDER (“LIMITED WARRANTY”). THE LIMITED
WARRANTY MAY BE FOUND IN THE APPLICABLE PRICE BOOK AND ON THE
ALLEGION CUSTOMER WEBSITE, WHICH TERMS ARE EXPRESSLY INCORPORATED
HEREIN BY REFERENCE. COMPANY WILL MAIL CUSTOMER A HARD COPY OF
THIS WARRANTY UPON CUSTOMER’S WRITTEN REQUEST. IN THE EVENT THAT
CERTAIN DELIVERABLE WARRANTIES ARE NOT FURNISHED BY THE COMPANY TO
CUSTOMER, COMPANY WARRANTS ONLY TO CUSTOMER THAT THE DELIVERABLES
WILL BE FREE FROM DEFECTS IN MATERIAL AND WORKMANSHIP FOR A
PERIOD OF 12 MONTHS FROM THE DATE OF SHIPMENT OF THE DELIVERABLES.
COMPANY’S SOLE OBLIGATION UNDER THIS WARRANTY IS LIMITED TO REPAIRING
OR REPLACING, AT COMPANY’S OPTION, THE DEFECTIVE DELIVERABLE,
PROVIDED WRITTEN NOTICE OF THE DEFECT OR NONCONFORMANCE IS
PROVIDED BY CUSTOMER WITHIN 30 DAYS OF DISCOVERY OF THE DEFECT OR
NONCONFORMANCE. COMPANY DISCLAIMS ALL OTHER WARRANTIES, EXPRESS
OR IMPLIED, WITH RESPECT TO THE DELIVERABLES, INCLUDING BUT NOT LIMITED
TO, ANY IMPLIED WARRANTIES OF NON-INFRINGEMENT, MERCHANTABILITY, OR
FITNESS FOR A PARTICULAR PURPOSE.
a. Exclusions. The provisions of this Limited Warranty do not apply to Deliverables that:
(A) are not the proper size for the application; (B) are not installed in accordance with
Company’s published installation instructions; (C) are installed with improper or incorrect
parts and/or are used for purposes for which they are not designed or intended; (D) have
been repaired or altered without the Company’s prior written consent; (E) have been
subjected to misuse, abuse, negligence or accident; (F) have been improperly stored, installed,
maintained or operated; (G) have been used in violation of written instructions provided by
Company to Customer; (H) have been subjected to improper temperature, humidity, or other
environmental conditions, or (I) have been affected by normal wear and tear. In addition,
the provisions of this Limited Warranty do not apply to any defects or issues with the design
or performance of equipment or products not manufactured by Company, nor does it apply
to any code compliance or permit requirements for the assembly, installation, erection or
construction of any goods. Company is not responsible for loss or damage resulting from
use of Deliverables in conjunction with parts or systems not manufactured by Company.
Accessories or products furnished by the Company, but manufactured by others, shall carry
whatever warranty the manufacturers have conveyed to the Company and which can be
passed to Customer.
b. Services. Company warrants that its services will be free from defects in material
and workmanship for a period of 12 months from the date of completion of the particular
items of service. Company’s sole obligation under this service warranty is limited to repair
or reperformance, at its option of the service, provided however, if repair or reperformance
is either impractical or impossible, the Company will refund to Customer that portion of the
price paid to Company for any defective service, provided written notice of the defect or
nonconformance is provided by Customer within 30 days of discovery of the nonconformance.
c. Notification. Customer agrees to immediately notify Company in writing if any claim is
made against Customer for any damages caused by any modules, parts, products, service or
other Deliverables which may be the direct result of any defect in the manufacture of such
aforementioned products. Customer agrees to cooperate with Company and its counsel in
the defense of such claim and Customer agrees not to settle such claim without Company’s
written consent. If Customer fails to notify Company of such claim or fails to cooperate in
such defense as aforesaid, then Company shall be discharged from any obligations under this
Section and shall have no further liability to Customer.
d. Exceptions. The following costs and expenses are not covered by the provisions of these
limited warranties: (i) labor costs for the removal and reinstallation of Deliverables or other
manufacturer’s products; (ii) shipping and freight expenses required to return Deliverables
to Company; (iii) normal maintenance; and (iv) economic losses. In addition, the provisions
of this warranty are not applicable to anything other than defects in Company’s material
(products only) or workmanship.
19. LIMITATION OF REMEDIES.
CUSTOMER’S EXCLUSIVE AND SOLE REMEDY ON ACCOUNT OF, OR IN RESPECT
OF, THE FURNISHING OF NON-CONFORMING DELIVERABLES, SHALL BE TO (A)
SECURE REPAIR OR REPLACEMENT OF THE PRODUCTS; OR (B) SECURE REPAIR
OR RE-PERFORMANCE OF THE SERVICES OR TO OBTAIN A REFUND OF THE
PRICE PAID FOR THE DEFECTIVE SERVICE, ALL AT COMPANY’S OPTION. IN NO
EVENT WILL THE COMPANY’S MAXIMUM LIABILITY EXCEED THE SELLING PRICE
FOR THE DELIVERABLE. THE WARRANTY, OBLIGATIONS AND LIABILITIES OF
COMPANY (INCLUDING ITS SUPPLIERS) AND THE RIGHTS AND REMEDIES OF
CUSTOMER ARE EXCLUSIVE AND ARE IN LIEU OF AND CUSTOMER HEREBY WAIVES
AND RELEASES ALL OTHER WARRANTIES, OBLIGATIONS, REPRESENTATIONS
OR LIABILITIES EXPRESS OR IMPLIED ARISING BY LAW, IN CONTRACT, TORT
(INCLUDING NEGLIGENCE OR STRICT LIABILITY) OR OTHERWISE, INCLUDING BUT
NOT LIMITED TO (I) ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE OR ANY WARRANTY IMPLIED THROUGH COURSE
OF PERFORMANCE, COURSE OF DEALING, OR USAGE OF TRADE OR (II) CLAIMS
ARISING OUT OF THE NEGLIGENCE OF COMPANY OR COMPANY’S SUPPLIERS OR
(III) ANY OTHER CLAIM ARISING OUT OF, CONNECTED WITH, OR RESULTING FROM
THE PERFORMANCE OF COMPANY OR FROM THE DESIGN, MANUFACTURE, SALE,
REPAIR, LEASE OR USE OF THE DELIVERABLE, OR ANY COMPONENT THEREOF,
DELIVERED OR RENDERED HEREUNDER OR OTHERWISE.
20. INDEMNIFICATION AND LIMITATION OF LIABILITY. a. Customer shall indemnify,
defend and hold Company, and its officers, directors, employees, customers, Affiliates,
suppliers, users and agents, (collectively the “Indemnitees”) harmless from and against any
and all damages, claims, losses, expenses, costs, obligations, liabilities, including without
limiting the generality of the foregoing, liabilities for court costs and attorneys’ fees, suffered
directly or indirectly by an Indemnitee by reason of, or arising out of any injury, death or loss to
any person, or injury to any property (collectively, “Damages”), received
or sustained by any person(s) or property, arising out of, occasioned by, attributable or related
to i) any breach of any representation or warranty made by Customer, its officers, directors,
employees, affiliates, users, agents, representatives or customers to Company or any third
party, (ii) any failure by Customer to perform or fulfill any of its covenants, acts and/or
omissions to Company or to any third party, or (iii) any litigation, proceeding or claim by any
Terms and Conditions
Price Book 5 | Effective January 8, 2018 | 800.847.1864
6
third party relating in any way to the obligations of Customer and/or the Deliverables sold by
Company to Customer hereunder. Customer shall not consummate any settlement of any
indemnified claim without the Indemnitees’ prior written consent. Customer’s obligation to
indemnify Indemnitees will continue in full force and effect notwithstanding the termination
or expiration of any order under this Agreement. In any claim against an Indemnitee by an
employee of Customer or any subcontractor or anyone directly or indirectly employed by any
of them or anyone for whose acts they may be liable, the indemnification obligations set
forth in this Section shall not be limited in any way by or for Customer or any subcontractor
under any applicable worker’s compensation act, disability or other employee benefit act, or
insurance coverage. This provision shall survive termination of any order or Agreement. IN
NO EVENT WILL COMPANY, ITS OFFICERS, DIRECTORS, EMPLOYEES, CUSTOMERS,
AFFILIATES, USERS AND AGENTS, (NOR COMPANY’S SUPPLIERS) BE LIABLE FOR
ANY INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES
OF ANY KIND OR NATURE UNDER ANY CIRCUMSTANCES INCLUDING, BUT NOT
LIMITED TO, LOSS OF USE OF THE PRODUCTS, SERVICE INTERRUPTION, LOSS
OF PROFITS, LOSS OF REVENUE, LOSS OF INTEREST, LOST GOODWILL, LOSS OF
DATA, WORK STOPPAGE, IMPAIRMENT OF OTHER GOODS, LOSS BY REASON OF
SHUTDOWN OR NON-OPERATION, INCREASED EXPENSES OF OPERATION, OR
CLAIMS OF CUSTOMER’S CUSTOMERS, OR ANY OTHER LOSSES OR DAMAGES
ARISING OUT OF ANY LACK OR LOSS OF USE OF THE DELIVERABLES WHETHER
BASED ON CONTRACT, WARRANTY, TORT (INCLUDING, BUT NOT LIMITED TO,
STRICT LIABILITY OR NEGLIGENCE), PATENT INFRINGEMENT, OR OTHERWISE,
EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
b) INTELLECTUAL PROPERTY INDEMNITY. Company makes no representation or
warranty to the Customer that the Deliverables shall not infringe any intellectual property
rights including, without limitations, claims arising from patent, copyright, trademark, trade
secret, or other intellectual property infringement. Customer agrees to hold Company
harmless from and defend the Company against any such claim of intellectual property
infringement, including any Damages resulting from that claim, the cost of complying
with any preliminary or permanent injunction, and all other costs of defense (including the
attorneys’ fees and costs), in connection with the foregoing.
c) To the extent that applicable law does not permit any limitations set out in this
Agreement, such limitation shall not be applied or invoked. Nothing in this Agreement will
be interpreted to disclaim liability of Company or the Indemnitees for gross negligence or
willful misconduct. The limitations of remedy and liability herein shall not be interpreted to
affect Company’s obligations, if any, for claims for (i) property damage, (ii) personal injury,
or (iii) wrongful death asserted by persons who are not parties to or beneficiaries of this
Agreement. Further, the limitations of remedy and liability herein shall not be interpreted
to limit Company’s or Customer’s right, if permitted by applicable law, to assert a claim for
contribution among joint tortfeasors in connection with a claim by a person who is not a party
to this Agreement.
21. CERTIFICATIONS. Certification of Deliverables for compliance with UL and ANSI
standards are tested and performed by third-party independent laboratories. Any field
modification or alteration of certified Deliverables will void certification and Company is not
liable to Customer to certify any modified or altered Deliverable.
22. TERM FOR CLAIMS. NO ACTION ARISING OUT OF ANY CLAIMED BREACH OF THIS
AGREEMENT BY COMPANY MAY BE BROUGHT BY CUSTOMER MORE THAN ONE (1)
YEAR AFTER THE CAUSE OF ACTION HAS ARISEN.
23. CONSUMER PRODUCTS
WITH RESPECT TO “CONSUMER PRODUCTS” AS DEFINED UNDER THE MAGNUSON-
MOSS WARRANTY ACT (“MMWA”), THE FOLLOWING STATEMENTS ARE MADE. (A)
SOME STATES OR LOCAL LAWS DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT APPLY TO YOU;
(B) IF ANY IMPLIED WARRANTY IS PROVIDED UNDER THE MMWA, IT IS LIMITED
TO THE DURATION OF THE WARRANTY PROVIDED IN SECTION 18 ABOVE. (C)
SOME STATES OR LOCAL LAWS DO NOT ALLOW THE EXCLUSION OR LIMITATION
OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION
OR EXCLUSION MAY NOT APPLY TO YOU; AND (D) THIS WARRANTY GIVES YOU
SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY
FROM STATE TO STATE OR LOCATION TO LOCATION.
24. FORCE MAJEURE/EXCUSABLE DELAY. Any delay or failure of Company to perform its
obligations hereunder will be excused to the extent that it is caused by an event or occurrence
beyond Company’s control such as, by way of example and not by way of limitation, acts
of God, acts by any governmental authority (whether valid or invalid), governmental laws
and regulations not presently in effect, fires, floods, windstorms, explosions, riots, natural
disasters, wars, sabotage, accidents, labor problems (including, without limitation, lockouts,
strikes, and slowdowns) at Company’s facility, its source plant or their suppliers, inability
to obtain power, material, labor equipment, or transportation, or court injunction or order.
The delivery date will be extended for a time equal to that of the delay and the schedule for
Company’s performance will be deemed adjusted to that effect.
25. ENTIRE AGREEMENT AND AMENDMENT. This Agreement, together with the
attachments, exhibits, webpages, or supplements specifically referenced and incorporated
herein, constitute the entire agreement between Company and Customer with respect to
the matters contained herein and supersede all previous communications, representations,
or agreements, either oral or written between Company and Customer. No agreement or
understanding varying or expanding this Agreement will be binding upon either party unless it
is in writing and signed by a duly authorized representative of each party hereto.
26. CONFLICTS. In the event of any conflict or inconsistency between the terms of any
agreement, or any part of an agreement or the various documents (including, but not
limited to, electronic documents) between Company and Customer, unless the parties
agree otherwise in writing, the various components of the agreements shall be given the
following precedence (in descending order of precedence): a) any master agreement or long
term agreement between Company and Customer; b) any specific terms, conditions and/
or warranties of the individual products or Deliverables; c) the terms and conditions of this
Agreement, and d) any purchase order.
27. UNSATISFACTORY CREDIT/TERMINATION FOR INSOLVENCY OR DEFAULT.
Customer shall furnish Company with statements evidencing Customer’s financial condition
as Company may, from time to time, reasonably request, and shall notify Company
immediately of any and all events that may have a material adverse effect on Customer’s
business or financial condition. If Company determines, in its sole discretion, that Customer’s
financial condition or creditworthiness is inadequate or unsatisfactory, then in addition to
Company’s other rights, Company may without liability or penalty, take any of the following
actions: (i) modify the payment terms for any outstanding and/or future purchases; (ii)
cancel any previously accepted orders; (iii) delay any further shipment of Deliverables to
Customer; or (iv) any combination of the above.
Company may immediately terminate an order from Customer by giving written notice to
Customer in the event of the happening of any of the following or any other comparable
event: (i) insolvency of the Customer; (ii) filing of a petition in bankruptcy by or against the
Customer; (iii) appointment of a receiver or trustee for the Customer; (iv) execution of an
assignment for the benefit of creditors by the Customer, all of which will allow Company to
demand reclamation of all affected orders; (v) Customer ceases or threatens to cease to
trade; (vi) Company determines that Customer does not meet or no longer meets the credit
requirements of Company or Customer’s credit account is closed; (vii) any Customer violation
of law, specifically including, without limitation, those laws set forth in this Agreement.
In the event of termination in accordance with this section, Company will not be obligated
to accept any existing or additional orders from Customer and Company will be released
from its obligation to deliver under orders accepted prior to such termination. The rejection
or termination of any order by Company will not entitle Customer to any termination or
severance compensation, or to any payment in respect to any goodwill established by
Customer, or render Company liable for damages on account of the loss of prospective
profits, or on account of any loss, expenditure, investment or obligation incurred or made by
Customer.
No action taken under this Section 27 by Company (nor any failure of Company to act under
this Section 27) will constitute a waiver by Company of any of its rights to enforce Customer’s
obligations, including the obligation of Customer to make payments as required under this
Agreement. Upon termination of any order, all amounts owed by Customer to Company will
become immediately due and payable, whether or not otherwise then due or payable.
28. CREDIT RISK ON RESALE OF DELIVERABLES. Customer is responsible for all credit
risks with respect to, and for collecting payment for, all Deliverables sold to third parties
(including End Users, installers, and/or general contractors) whether or not Customer has
made full payment to Company for such Deliverables. The inability of Customer to collect
payment for any Deliverable shall not affect Customer’s obligation to pay Company for any
Deliverable.
29. GOVERNING LAW; VENUE; AND EXPENSES. Any dispute or claim relating to this
Agreement shall be governed by and construed according to the laws of the State of Indiana
(excluding its conflict of laws principles); and not by the provisions of the 1980 United Nations
Convention on the International Sale of Goods. Any disputes or claims shall be instituted
and maintained in the courts of the State of Indiana. Customer consents to the exercise of
jurisdiction over it by such courts and agrees that Indiana is not an inconvenient forum for any
action arising from or relating to this Agreement. Customer agrees to pay for all expenses
(including, but not limited to, collection costs, court costs and attorneys’ fees) incurred by
Company in enforcing the obligations of Customer under this Agreement.
30. RELATIONSHIP OF THE PARTIES. Nothing in this Agreement or any other document
creates an employment, partnership, joint venture, or agency relationship between Company
and Customer, including that of franchisee/franchisor. No party will have any power or
authority to enter into any commitment on behalf of or otherwise bind the any other party
on any matter. No employee of Customer will be deemed to be an employee of Company.
If any provision of this Agreement is deemed to create a franchise relationship or business
opportunity between the Parties, then Company may terminate any purchase order or this
Agreement or the Parties shall negotiate in good faith to modify this Agreement so as to
effect the original intent of the Parties as closely as possible in a mutually acceptable manner
in order that the transactions contemplated hereby are consummated as a reseller agreement
and not a franchise or business opportunity agreement.
31. SETOFF. Customer does not have the right to setoff or to back charge against any
amounts which become payable to Company under this Agreement or otherwise. Company
will not accept responsibility for backcharges for the cost of material or labor by Customer or
any third party.
32. ELECTRONIC COMMUNICATIONS AND ELECTRONIC SIGNATURES. Both parties
expressly agree to electronic transactions and acknowledge that documents they sign
electronically will bind them to the same extent as a paper signature. Customer represents
and warrants to Company that only employees authorized to bind Customer legally shall
electronically sign any document under this Agreement. Customer shall comply with any
method of electronic communication/payment processing specified by Company, including
electronic funds transfer, pay-on-receipt processes/systems, order transmission, releases,
electronic signature, and electronic communication systems, including, without limitation, the
use of electronic data interchange (“EDI”) portals. Notwithstanding the foregoing, e-mails,
even those containing a signature block of one of Company’s representatives, shall not
constitute a signed writing.
33. COMPLIANCE WITH APPLICABLE LAWS.
a. General. Company and Customer will comply with all applicable federal, state and
municipal laws, regulations, codes, ordinances and orders that pertain to the Deliverables,
including but not limited to full compliance with any applicable provisions of The Health
Insurance Portability and Accountability Act. Where the Customer is located outside the
United States, or where the customer intends to ship the product outside the United States,
the Customer shall be responsible for compliance with all U.S. export laws, and for filing all
U.S. Electronic Export Information, as applicable.
b. The Customer acknowledges and agrees that: (i) it shall not violate applicable laws
and regulations in performing its duties under this Agreement; (ii) it does not and shall not
engage in any conduct that shall violate any applicable anti-bribery or anti-corruption laws
or regulations; (iii) it (and its owners, officers, directors, employees and agents) shall not
pay, offer, promise or authorize the payment of, either directly or indirectly, anything of value
(including but not limited to cash, gifts and entertainment) to (a) any government official
or employee of any government; (b) any official or employee of any department, agency, or
instrumentality of a government; (c) any employee of any corporation or entity owned or
controlled by a government; (d) any family member of such officials or employees; (e) any
political party, party official, or political candidate; or (f) any other persons, owners, officers,
directors, employees and agents of any corporation or entity; to improperly or illegally assist
in obtaining or retaining business (including but not limited to any contracts, avoidance
of duties or reduction of tariffs, reduction of taxes or to obtain money owed, or to obtain
regulatory approval) or for the purpose of causing, soliciting or inducing the sale and purchase
Terms and Conditions
Price Book 5 | Effective January 8, 2018 | 800.847.1864 7
of the Deliverables by any party, and (iv) it has full knowledge of and will comply with the
Company’s Code of Conduct for Business Partners as set forth on the Allegion customer
website, WHICH IS HEREBY INCORPORATED BY REFERENCE.
c. The Customer shall indemnify and hold the Company harmless from any claim, demand,
expense or cost arising from any breach of this Article.
d. The Customer shall permit the Company to conduct an audit or review of the Customer’s
financial books and records and business operations at such other times that the Company
considers it necessary to confirm compliance with this provision. Such audit may be
conducted by representatives of the Company or, at the Company’s sole discretion, by a
certified public accounting firm selected by the Company. The Customer shall cooperate with
any inquiries from the Company’s Ethics & Compliance Group.
e. A violation of this provision constitutes a material breach of this Agreement and the
Company may terminate any purchase order or this Agreement immediately, with no
opportunity to cure, in accordance with Section 27 of this Agreement.
f. Notwithstanding the foregoing provisions of this Section 33, (i) Company is not responsible
for obtaining or maintaining any permits for the performance of services or the verification
or compliance with any code requirements relative to the performance of services, (ii) to the
extent any sale of Deliverables pursuant to this Agreement may require approval of the U.S.
Government, Company’s obligations under this Agreement are conditioned upon the grant of
such approval and upon compliance by Customer with any restrictions imposed by the U.S.
Government in connection with such approval, and (iii) in the event the Deliverables are to
be used in a nuclear facility, the Customer shall, prior to such use, arrange for insurance or
governmental indemnity protecting Company against liability. The Customer hereby releases
and agrees to indemnify Company and its suppliers for any nuclear damage including, but not
limited to, loss of use, in any manner arising out of the nuclear incident, whether alleged to be
due, in whole or in part by Company or its suppliers.
g. No Inducements. Each party represents to each other that neither it nor any person
acting on its behalf has, in contravention of any applicable law, given or offered to give or will
give or offer to give, any sum of money or other material consideration to any person, directly
or indirectly, as an inducement to obtain business hereunder or to influence the granting
of licenses or other governmental permissions to enter into this Agreement or perform
obligations hereunder.
h. Equal Employment Opportunity. Company is a U.S. federal contractor that complies
with Executive Order 11246, as amended, and applicable regulations in 41 CFR Parts 60-1
through 60-60, 29 U.S.C. § 793 and applicable regulations in 41 CFR § 60-741; and 38 U.S.C.
§ 4212 and applicable regulations in 41 CFR Part 60-250 and 60-300. THE FOLLOWING
PROVISIONS ARE INCORPORATED HEREIN BY REFERENCE: Executive Order 11246, as
amended by Executive Order 13672, and 41 CFR § 60-4.3(a); Executive Order 11701 and 41 CFR
§§ 60-250.5(a), 60-300.5; Executive Order 11758 and 41 CFR § 60-741.5(a); U.S. immigration
laws, including the L-1 Visa Reform Act of 2004 and the H-1B Visa Reform Act of 2004; and
Executive Order 13496.
i. Ethical Business Conduct. Customer shall adopt and comply with Company’s Business
Partner Code of Conduct which is EXPRESSLY INCORPORATED HEREIN BY REFERENCE.
34. REPRESENTATIONS AND WARRANTIES. Customer represents, warrants and
covenants to Company that: (a) it has the right, power, and authority to enter into this
Agreement and fully perform its obligations hereunder; (b) it has all necessary rights in and
to its respective Content and Marks for use within the scope of this Agreement, including
the licenses granted herein; and (c) it complies, and at all times shall comply, with all laws,
rules, and regulations in effect that are applicable to its performance under this Agreement,
including obtaining all such approvals and/or permits as may be required hereunder.
35. NO THIRD-PARTY BENEFICIARY. Each party is entering into this Agreement solely
based on the representations contained herein for its own purposes and not for the benefit of
any third party.
36. NOTICES AND CHANGE OF ADDRESS. All notices or other communications under
this Agreement shall be in writing and delivered in person, or sent by receipted courier,
express mail, e-mail, or postage prepaid certified or registered mail, addressed to the party
for whom it is intended, at the addresses set forth in this Agreement. Either party may
change its address for notice by giving written notice to the other party. Any notice or other
communication shall be deemed given no later than the date actually received. Notice by
courier, express mail, certified mail, or registered mail shall be deemed given on the date it
is officially recorded as delivered and, in the absence of such record of delivery, it shall be
rebuttably presumed to have been delivered on the third Business Day after it was deposited.
Notices sent by e-mail require tangible confirmation of receipt from addressee.
37. ASSIGNMENT. Customer may not assign this Agreement without the prior written
consent of Company. Company may assign its rights and delegate its duties under this
Agreement, without the prior consent of Customer, to an Affiliate, or to a third party in the
event of a spin-off, merger, business combination, consolidation or sale of all, or substantially
all, of its assets or business that are related to this Agreement. The rights and duties in this
Agreement shall bind and inure to the benefit of any such assignee.
38. SEVERABILITY. If any provision of this Agreement is held to be invalid, illegal, or
unenforceable under any statute, regulation, ordinance, executive order, or other rule of law,
that provision will be deemed severed to the extent necessary to comply with such statute,
regulation, ordinance, order, or rule. In the event such provision is deemed severed, the parties
will negotiate in good faith to arrive at an alternative arrangement approximating the original
business objective of the parties. The remaining terms and conditions of this Agreement will
remain in effect.
39. NO IMPLIED WAIVER. The failure of either party at any time to require performance by
the other party of any provision of this Agreement will in no way affect the right to require
such performance at any time thereafter, nor will the waiver of either party of a breach of any
provision of this Agreement constitute a waiver of any succeeding breach of the same or any
other provision.
40. MISCELLANEOUS. (a) This Agreement does not make either party the agent or legal
representative of the other party. Neither party is authorized to create any obligation on
behalf of the other party including, but not limited to, the obligation for payment of any
service or warranty obligation hereunder; (b) The rights and remedies herein reserved to
Company are cumulative and additional to any other rights and remedies provided at law or
equity; (c) The official text of this Agreement is in the English language. If this Agreement is
translated into another language, the English text will govern any question with respect to
interpretation; (d) The headings in this Agreement are for convenience of reference only and
do not affect the meaning of this Agreement in any manner.
DEFINITIONS.
Capitalized terms have the meanings set forth in this Section, or in the Section in which they
first appear in this Agreement.
“Agreement” means these Allegion Terms and Conditions of Sale and Service, together with
any applicable Country Supplement or Region Supplement provided by Company, and all of
the documents referenced herein or therein.
“Affiliate” means any Person that directly or indirectly, through one or more intermediaries,
controls, is controlled by, or is under common control with, the Company. The term
“control” (including the terms “controlled by” and “under common control with”) means
the possession, directly or indirectly, of the power to direct or cause the direction of the
management and policies of a Person, whether through the ownership of voting securities, by
contract or otherwise.
“Business Day” means any day except Saturday, Sunday or any other day on which
commercial banks located in the United States are authorized or required by Law to be closed
for business.
“Company” means Schlage Lock Company, LLC or any subsidiary or affiliate thereof selling
products that are part of the Allegion product portfolio. Schlage Lock Company and/or its
subsidiary or affiliates will be severally but not jointly liable under the Agreement.
“Company Marks” refers to the Marks of Company.
“Confidential Information” shall mean any and all information provided by either party
to the other party pertaining to the disclosing party’s business. Confidential Information
shall include, but not be limited to, any bitting lists, formulae for products, manufacturing
processes, production techniques, packaging processes, methods, research materials, ideas,
marketing plans and related materials, quality standards, test results and data, apparatus,
engineering drawings, contract documents, computer software, hardware, or firmware,
business activities information such as financial information, reports, projections, books
and records, customer and supplier information, and operations, customer and supplier lists
and data, specifications, know how, and other Proprietary Information or Trade Secrets (as
defined herein) that either party may furnish to the other party. Confidential Information
shall not include information that: (a) is or becomes publicly known if such public knowledge
or disclosure is not the result of any act or failure to act on the part of the receiving party;
(b) is, at the time of disclosure, already known to the Receiving Party without utilizing the
Confidential Information; (c) is information disclosed to the Receiving Party by a third party
which is not to the Receiving Party’s knowledge, after inquiry of the third party, under a duty
of confidentiality to the Disclosing Party; or (d) is independently developed by the Receiving
Party without the use of Confidential Information. The Receiving Party shall have the burden
of proof as to prior knowledge and absence of breach. Confidential Information may be
furnished in any tangible or intangible form including, but not limited to, writings, drawings,
computer and other electronic media, logic diagrams, component specifications, graphs,
prototypes, samples, or verbal communications and regardless of whether such information
is marked or designated as “confidential.” For the avoidance of doubt, all information,
knowledge or data disclosed by Company to Customer, regardless of whether disclosed in
written, tangible, oral, visual or other form, including, without limitation, sample products,
equipment, software, or other objects or material, provided by Company to Customer, and all
information, knowledge or data which was obtained by Customer from visits to Company’s
facilities, shall be considered “Confidential Information” under this Agreement.
“Content” means all information (including without limitation any text, music, sound,
photographs, video, graphics, data or software), in any medium, on a particular Company
Web page or Website or in Marketing Materials.
“Customer” means the purchaser of Deliverables from Company.
“Deliverables” means any good or service or both purchased by Customer from Company
under these General Terms and Conditions of Sale and Service.
“End Users” means the purchaser that (a) has acquired a Deliverable from Customer for (i)
its own and its Affiliate’s/Affiliates’ internal use and not for resale, remarketing or distribution
or (ii) incorporation into its own products and (b) is an individual or entity, other than any
federal, state or local agency, office or division.
“IP” means all intellectual property and industrial property rights comprising or relating to/
of the following: (a) Patents; (b) Trademarks; (c) internet domain names, whether or not
Trademarks, registered by any authorized private registrar or Governmental Authority, web
addresses, web pages, website and URLs; (d) works of authorship, expressions, designs and
design registrations, whether or not copyrightable, including copyrights and copyrightable
works, software and firmware, application programming interfaces, architecture, files, records,
schematics, data, data files, and databases and other specifications and documentation; (e)
Trade Secrets; and (f) all other intellectual property and industrial property rights, and all
rights, interests and protections that are associated with, equivalent or similar to, or required
for the exercise of, any of the foregoing, however arising, in each case whether registered or
unregistered and including all registrations and applications for, and renewals or extensions
of, such rights or forms of protection pursuant to the Laws of any jurisdiction throughout in
any part of the world.
“Marketing Materials” means all marketing brochures, buckslips, pamphlets, emails, text,
call scripts or other material, whether in printed format, audio or audiovisual format, or in
any other format, that contain any (i) Content relating to the Company Deliverables or (ii)
Company Marks.
“Marks” means collectively the domain names, trademarks, trade names, service marks,
trade dress, logos, and the like used or provided by either party for use in connection with this
Agreement.
“Patents” means all patents (including all reissues, divisionals, provisionals, continuations
and continuations-in-part, re-examinations, renewals, substitutions and extensions thereof),
patent applications, and other patent rights and any other Governmental Authority-issued
indicia of invention ownership (including inventor’s certificates, petty patents and patent
utility models).
“Person” means a person or entity.
“Price Books” mean Company’s current Price Book in effect for the applicable Deliverable
being purchased by Customer.
“Trade Secrets” means and includes business or technical information of either party,
including processes, formulas, devices, techniques, compilations and other material that
a party attempts to maintain in secret and that derive commercial value for such party
from not being generally known to the public or readily ascertainable through independent
development or reverse engineering.
Terms and Conditions
8
Multi-family Residential Electronic Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
1. Select Lock Model
Part No. Description Price (ea.)
FE410F Schlage Control Smart Interconnect, UL Listed, 90 minutes $640.00
2. Select Design Style
Style/Description Price (ea.)
(ADD) Addison n/c
(GRW) Greenwich n/c
3. Select Interconnect Type
Style Description Price (ea.)
4" For doors with 4" bore hole spacing (40) n/c
5-1/2" For doors with 5-1/2" bore hole spacing (55) n/c
Standard Features
n Keyless, no cylinder design — 100% bump and pick-proof
n Modern credentials — smart credential and/or phone as key
n Wireless freedom — control and program by phone
n Up to 500 users per lock
n Audit trail reports up to 1,000 events
n Fits standard door prep
n 1.5-year battery life
n Full suiting with Schlage mechanical locks
n Single motion egress
n ADA compliant design
n Uses ENGAGE™ Technology
n See page 27 for information on the MT20W Credential Enrollment Reader
Schlage Control™ Smart Interconnect Locks
FE410 with Greenwich trim
with Broadway Lever
FE410 withwith Addison trim
with Accent lever
Specications
Latch: 1" x 2-1/4" square and round corner faceplate
(square corner standard, round corner included
in package) 1" edge bore required
Strikes: 1-1/8" x 2-3/4", square corner, no box, latch strike
Backset: Adjustablebackset,ts2-3/8"to2-3/4"
backsets
Door Range: 1-3/8" to 1-3/4" (thick door kit available - up 2")
Battery: 4-AA batteries included, (If loss of battery
power occurs, a 9V battery can be used to
jump start the lock and provide access with an
assigned credential.)
Construction: All-metal chassis and escutcheons
Bore: 2-1/8"
Credentials: Supports aptiQ MIFARE classic, aptiQ DESFire EV1
(sold separately). Please refer to the Credential
Section of the Allegion Electronic Security Price Book.
Stile Width: Minimum 4-1/2" stile for 2-3/8" backset, minimum
5" stile for 2-3/4"
Return to Door: Saturn (SAT), Neptune (NEP), Boardwalk (BRK)
and Longitude (LON) are return to door code
compliant
Center to Center: Fits 4" or 5-1/2" center to center door preps
-orderable options (Please specify when ordering)
Certications: 90-minute UL Listed A 156.12 Grade 2 ANSI/BHMA
certied;CanadaUL20-minutewooddoorrated.
Approved for use where the exterior escutcheon
only is exposed to the outdoors.
FINISH CODES & DESCRIPTIONS*
619 622 625 626 716
Satin Nickel
(US15)
Matte Black
(US19)
Bright Chrome
(US26)
Satin Chrome
(US26D)
Aged Bronze
(643e)
*Non-Standardnishesarenotavailable.
Availableinsplitnishand/orsplitlever
options for no additional charge.
Price Book 5 | Effective January 8, 2018 | 800.847.1864 9
Multi-family Residential Electronic Locks
4. Design - Select Lever Style And Finish
Style / Description 619 - Satin Nickel 622 - Matte Black 625 - Bright Chrome 626 - Satin Chrome 716 - Aged Bronze
ACC / Accent n/c n/c n/c n/c n/c
VLA / Avila n/c Not Available n/c n/c n/c
BIR / Birmingham n/c Not Available n/c Not Available n/c
BRW / Broadway n/c n/c n/c n/c n/c
BRK / Boardwalk n/c n/c n/c n/c n/c
ELA / Elan n/c n/c n/c n/c n/c
JAZ / Jazz n/c n/c n/c n/c n/c
JUP / Jupiter n/c n/c n/c n/c n/c
LAT / Latitude n/c n/c n/c n/c n/c
LON / Longitude n/c n/c n/c n/c n/c
MNH / Manhattan n/c Not Available n/c n/c Not Available
NEP / Neptune n/c n/c n/c n/c n/c
NBK / Northbrook n/c Not Available Not Available Not Available Not Available
SAC / Sacramento n/c Not Available n/c n/c n/c
SAT / Saturn n/c n/c n/c n/c n/c
Latch
Part No. Description Price (ea.)
12-356 Combo latch, Dual option (sq + rd), Non UL bolt, UL latch - STANDARD Not Sold Separately
Handing Price (ea.)
Left STANDARD-CanbechangedtoRighthandedintheeld n/c
Deco Trim Price (ea.)
06-219 STANDARD - ADD or GRW depending on which style is selected above n/c
Strike Combinations
Part No. Description Price (ea.)
10-121 STANDARD - Combo Strike, Square Corner (10-094 & 10-026) n/c
10-109 10-094 & 10-001 n/c
10-122 10-116 & 10-027 n/c
10-123 10-092 & 10-027 n/c
10-124 10-095 & 10-027 n/c
Deadbolt Strike Options
Part No. Description Price (ea.)
10-094 1-1/8" Square Corner Strike, 1 3/8" - 2 1/4" - STANDARD $12.20
10-092 1/4" Radius round corner, full lip, no box, 1 5/8" x 2 1/4" 7.90
10-095 Square corner, full lip, no box, 1 5/8" x 2 1/4" 7.90
10-112 Metal dust box with screws 10.70
Deadlatch Strike Options
Part No. Description Price (ea.)
10-026 Square corner, full lip, no box, 1 5/8" x 2 1/4" - STANDARD $7.60
10-001 Square corner, T-strike, box, 1 1/8" x 2 3/4" 6.50
10-027 1/4" Radius round corner, full lip, no box, 1 5/8" x 2 1/4" 7.60
Thick Door Kit
Part No. Description Price (ea.)
47244555 For doors between 1 3/4" and 2" $24.90
The Schlage Control Interconnect Lock uses the same Thick Door Kit as the Deadbolt. However, due to the latch assembly it should only be used on doors between 1 3/4" and 2".
Screw Packs
Part No. Description Price (ea.)
47250323 Security Screws - Optional Security torx screws $7.20
47244558 FE410 screw pack 7.20
ForScrewPacks,specifynishoption(619,622,625,626or716)
10
Multi-family Residential Electronic Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Product Identication
BE 467 F
Lock Function 90 Minute UL
Specications
Latch: 1" x 2-1/4" square and round corner faceplate (round
corner standard, square corner included in package)
1" edge bore required
Strikes: 1-1/8" x 2-3/4", round corner, no box, latch strike
Backset: Adjustablebackset,ts2-3/8"to2-3/4"backsets
Door Range: 1-3/8" to 1-3/4" (thick door kit available - up 2-1/4")
Hole Distance: Minimum 4" center-to-center distance between
cross bore holes
Battery: 4-AA batteries included, (If loss of battery power
occurs, a 9V battery can be used to jump start
the lock and provide access with an assigned
credential.)
Construction: All-metal chassis and escutcheons
Bore: 2-1/8"
Credentials: Supports aptiQ MIFARE classic, aptiQ DESFire
EV1 (sold separately). Please refer to the
Credential Section of the Allegion Electronic
Security Price Book.
Stile width: Minimum 4-1/2" stile for 2-3/8" backset,
minimum 5" stile for 2-3/4"
Certications: 90-minute UL Listed A 156.12 Grade 2 ANSI/
BHMAcertied;CanadaUL20-minutewood
door rated. Approved for use where the exterior
escutcheon only is exposed to the outdoors.
Standard Features
n Keyless, no cylinder design — 100% bump and pick-proof
n Modern credentials — smart credential and/or phone as key
n Wireless freedom — control and program by phone
n Up to 500 users per lock
n Audit trail reports up to 1,000 events
n Fits standard door prep
n 1.5-year battery life
n Full suiting with Schlage decorative mechanical locks
n ADA compliant design
n Uses ENGAGE™ Technology
n See page 27 for information on the MT20W
Credential Enrollment Reader
Schlage Control™ Smart Deadbolts
BE467
Greenwich
(GRW)
BE467
Addison
(ADD)
FINISH CODES & DESCRIPTIONS*
619 622 625 626 716
Satin Nickel
(US15)
Matte Black
(US19)
Bright Chrome
(US26)
Satin Chrome
(US26D)
Aged Bronze
(643e)
*Non-Standardnishesarenot
available.Availableinsplitnish
options for no additional charge.
Price Book 5 | Effective January 8, 2018 | 800.847.1864 11
Multi-family Residential Electronic Locks
1. Select Lock Model
Part No. Description Price (ea.)
BE467F Schlage Control Smart Deadbolt, UL Listed, 90 minutes $432.00
2. Select Design Style
Style/Description Price (ea.)
(ADD) Addison No Charge
(GRW) Greenwich No Charge
3. Select nish style
Finish/Description Price (ea.)
619 / Satin Nickel No Charge
622 / Matte Black No Charge
625 / Bright Chrome No Charge
626 / Satin Chrome No Charge
716 / Aged Bronze No Charge
Latch
Part No. Description Price (ea.)
12-398 BE467F 90 Min UL Deadbolt Latch Dual Option (sq+rd) - STANDARD Not Sold
Separately
BE467F Strike Options
Part No. Description Price (ea.)
10-116 1-1/8" Round Corner Strike, 1-3/8" - 2-1/4" - STANDARD n/c
10-094 1-1/8" Square Corner Strike, 1-3/8" - 2-1/4" n/c
10-095 Square Corner Full Lip Strike, 1-3/8" - 1-3/4" n/c
10-092 Round Corner Full Lip Strike, 1-3/8" - 1-3/4" n/c
Thick Door Kit
Part No. Description Price (ea.)
47244555 For doors between 1 3/4" and 2-1/4" $24.90
The Schlage Control Deadbolt uses the same Thick Door Kit as the Interconnect. However, due to the differences in latch assemblies, the Deadbolt can
accommodate doors up to 2-1/4" in thickness.
Screw Packs
Part No. Description Price (ea.)
47250323 Security Screws - Optional Security torx screws $7.20
47244557 BE467 screw pack 7.20
ForScrewPacks,specifynishoption(619,622,625,626or716)
12
Multi-family Residential Electronic Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Electronic Locking Systems
Schlage Control™ Smart Locks
Product Finish Latch Strike Lever Style Price Each
BE467F GRW 619 12-398 10-116 N/A $432.00
BE467F GRW 626 12-398 10-116 N/A 432.00
BE467F ADD 619 12-398 10-116 N/A 432.00
BE467F ADD 626 12-398 10-116 N/A 432.00
FE410F GRW 619 12-356 10-121 Latitude 640.00
FE410F GRW 626 12-356 10-121 Latitude 640.00
FE410F ADD 619 12-356 10-121 Latitude 640.00
FE410F ADD 626 12-356 10-121 Latitude 640.00
Note: FE410 locks are 5.5" center-to-center.
Schlage Smart Credentials using MIFARE® Classic
Product Type Description Price (ea.) Min. Order
9651 Keyfob aptiQ™ MIFARE Smart Card 1K bit Keyfob $7.40 100
9651T Thin Keyfob aptiQ™ MIFARE Smart Card 1K bit thin Keyfob $7.60 100
Multi-Tech Technology: Proximity and Schlage Credentials using MIFARE® Classic
Product Type Description Price (ea.) Min. Order
9691T Thin Keyfob Proximity and aptiQ™ Smart Card combo 1K byte/8K bit ISO thin Keyfob $9.95 100
Greenwich Addison
Price Book 5 | Effective January 8, 2018 | 800.847.1864 13
Multi-family Residential Electronic Locks
Programmable Electronic Deadbolt
PRODUCT IDENTIFICATION
BE 367 F20
Lock Series Function 20-minute UL Listed
FINISH CODES & DESCRIPTIONS*
619 625 626 716
Satin Nickel
(US15)
Bright
Chrome
(US26)
Satin
Chrome
(US26D)
Aged Bronze
(643e)
*Non-Standardnishesarenotavailable.
BE367F20
Specications
Latch: 1” x 2-1/4” round corner faceplate
1” housing diameter - requires 1” edge bore
1” throw with Triple-Option™ square corner,
radius corner and circular drive-in faceplates
Strikes: 1-1/8” x 2 3/4”, round corner, no box, latch strike
Backset: Adjustablebackset,ts2-3/8”to2-3/4”
backsets
Cylinder: 5-pin solid brass, keyed 5-pin, C keyway, keyed
different (KD)
Door Range: 1 3/8”to 1 3/4”
Keys: Nickel silver cut keys, 5-pin, C-section
Hole Distance: Minimum 5 1/2” center-to-center distance
between cross bore holes
Battery: 9-volt battery included with average three-year
battery life
Construction: All-metal chassis and escutcheons
Button: Silicone rubber, wear-resistant with LED
backlight
Available 20 minute UL Listed
A 156.5-2001 Grade 2 auxiliary locks or Grade 2 ANSI/BHMA certied
Standard Features
n Time and date controlled access
n Battery powered – no wiring required
nEasytoinstall–tsonstandardresidentialdoorpreps
n Average 3 year battery life
n Vandal resistant free-spinning deadbolt turn
n 100-day low cycle warning
n Up to 500 users
n iButton credential required, sold separately
n Up to 1,000 audit trail reports n Concealed back-up
mechanical key override
14
Multi-family Residential Electronic Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
1. Select Lock Model
Part No. Description Price (ea.)
BE367F20* Programmable Electronic Deadbolt, UL Listed, 20 minutes $412.00
Replacement Cylinder Caps
Part No. Description Price (ea.)
40-182 Replacement Cylinder Caps (50 pack) Seepricingbynish
2. Select Design Style
Style/Description Price (ea.)
(CAM) Camelot n/c
(PLY) Plymouth n/c
3. Select Key Cylinder Option
Style/Description Price (ea.)
(KD) Keyed Different n/c
(KA) Keyed Alike n/c
Select Finish Style
505 605 609 613 619 620 621 622 625 626 716
Finish nnnn$36.00 nnn$36.00 $36.00 $46.00
4. Select Finish Style
505 605 609 613 619 620 621 622 625 626 716
Finish nnnnn/c nnnn/c n/c n/c
* iButton credentials must be ordered separately (see page 20)
* Programmable Electronic Deadbolts require supported access control software, which must be ordered separately (see page 13)
Price Book 5 | Effective January 8, 2018 | 800.847.1864 15
Multi-family Residential Electronic Locks
Triple Option Latch
Part No. Description Price (ea.)
12-287 BE367 Deadbolt Latch with Triple Option Faceplates
contents: (1) B302-590 (1) B590-308 (2) C604-246 (1) B590-310*
$39.20
*Only option for BE367
UL Latches
Part No. Description Price (ea.)
12-319 BE367 20 Min UL Deadbolt Latch with Round Corner Faceplate - STANDARD Not Sold Separately
12-320 BE367 20 Min UL Deadbolt Latch with 1-1/8” wide Square Corner Faceplate Not Sold Separately
12-318 BE367 20 Min UL Deadbolt Latch with Square Corner Faceplate Not Sold Separately
BE 367 Strike Options
Part No. Description Price (ea.)
10-116* 1-1/8” Round Corner Strike, Standard, 1 3/8” - 2 1/4” No Charge
10-094 1-1/8” Square Corner Strike, 1 3/8” - 2 1/4” No Charge
10-095 Square Corner Full Lip Strike, 1 3/8” - 1 3/4” No Charge
10-092 Round Corner Full Lip Strike, 1 3/8” - 1 3/4” No Charge
Note: Strikes listed above are for standard, UL 20 minute and UL 3 hour rated products
Thick Door Kit
Part No. Description Price (ea.)
02.007 BE367DeadboltThickDoorKit(ts17/8”–21/2”thickdoors)
contents: (1) B520-629 (1) B520-630 (1) B520-631 (1) B520-632 (2) B520-633 (2) B520-634 (1) P515-
681
$24.90
Cylinders
Part No. Description Price (ea.)
22-000 Deadbolt Cylinder for BE367
contents: (1) 23-035 (1) B520-606 (1) B520-607 (1) B520-608 (1) B520-628
$47.30
Screw Packs
Part No. Description Price (ea.)
B220-278* BE367 Deadbolt Latch and Strike Screw Pack contents: (4) C604-246 (3) R525-256 $5.40
B220-279 BE367 Deadbolt Mounting Screw Pack contents: (2) B520-621 (2) B600-100 $9.20
* Specify nish when ordering
16
Multi-family Residential Electronic Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
PRODUCT IDENTIFICATION
FE 210 F
Lock Series Function 3-hour UL Listed
Programmable Electronic Interconnect
FE210F
n Time and date controlled access
n Up to 1,000 audit trail reports
nEasytoinstall–tsonstandardresidentialdoorpreps
n Battery powered – no wiring required
n Interconnect mechanism is adjustable
n Average 3 year battery life
nLevertrimisnon-handedandeldreversable
n iButton credential required, sold separately
n Vandal resistant free-spinning deadbolt turn
n Concealed back-up mechanical key override
n Up to 500 users
Standard Features
FINISH CODES & DESCRIPTIONS*
619 625 626 716
Satin Nickel
(US15)
Bright
Chrome
(US26)
Satin
Chrome
(US26D)
Aged Bronze
(643e)
*Non-Standardnishesarenotavailable.
Specications
Latch: UL latch comes with 1” x 2 1/4” square and
round corner faceplate (square corner
standard, round corner included in package)
1” edge bore required
Strikes: 1 1/8” x 2 3/4”, square corner, no box, latch
strike
Backset: Adjustablebackset,ts23/8”to23/4”
backsets
Stile Width: Minimum 4 1/2” for 2 3/8” backset,
minimum 5” stile for 2 3/4”
Cylinder: 5-pin solid brass, keyed 5-pin, C keyway,
keyed different (KD)
Door Range: 1 3/8” to 1 3/4”, thicker than 1 3/4” to 2”
mustbespecied
Keys: Nickel silver cut keys, 5-pin, C-section
Center to Center: Fits 4” or 5 1/2” center to center door preps*
Battery: 9-volt battery included with average three-
year battery life
Construction: All-metal chassis and escutcheons
Button: Silicone rubber, wear-resistant with LED
backlight
Certications: 3hr. UL Listed
A 156.12-2002: Grade2ANSI/BHMAcertied
* 5 1/2” center to center default set up from factory
Price Book 5 | Effective January 8, 2018 | 800.847.1864 17
Multi-family Residential Electronic Locks
1. Select Lock Model
Part No. Description Price (ea.)
FE210F Programmable Electronic Deadbolt, UL Listed, 3 hours $623.00
2. Select Design Style
Style/Description Price (ea.)
(CAM) Camelot n/c
(PLY) Plymouth n/c
3. Select Lever Style*
Price (ea.)
See page 165 for Lever Design Option n/c
*Specify handing - Right Hand is standard
4. Select Key Cylinder Option
Style/Description Price (ea.)
(KD) Keyed Different - STANDARD n/c
(KA) Keyed Alike n/c
5. Select Finish Style
505 605 609 613 619 620 621 622 625 626 716
Finish nnnnn/c nnnn/c n/c n/c
18
Multi-family Residential Electronic Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
*Handing must be specied for split nishes and/or designs. Right Hand is standard.
Accent (ACC) Avanti (AVA) Avila (VLA) Elan (ELA) Flair (FLA)
Jazz (JAZ) Manhattan (MNH) Callington (CLT) Champagne (CHP) Merano (MER)
Jupiter (JUP) Lattitude (LAT) St. Annes (STA) Saturn (SAT) Neptune (NEP)
Plymouth (PLY) Camelot (CAM)
Available Finishes
619 625 626 716
Accent nnnn
Avanti n n n
Avila nnnn
Callington nnnn
Champagne nnnn
Elan nnn
Flair nnnn
Jazz n n
Jupiter nnn
Latitude nnnn
Manhattan nnnn
Merano nnnn
Neptune nnn
Saturn nnn
St. Annes nnnn
Interconnect Lever Designs
Price Book 5 | Effective January 8, 2018 | 800.847.1864 19
Multi-family Residential Electronic Locks
10-094 10-092 10-095 10-112 10-001 10-026 10-027
Deadbolt Strikes
Part No. Specify Finish Description Lip Length Price
10-094 nSquare corner, 1 1/8” x 2 3/4” - Standard n$12.20
10-092 n1/4” Radius round corner, full lip, no box, 1 5/8” x 2 1/4” 1 1/8” 7.90
10-095 nSquare corner, full lip, no box, 1 5/8” x 2 1/4” 1 1/8” 7.50
10-112 nMetal dust box with screws n11.10
Deadlatch Strikes
Part No. Specify Finish Description Lip Length Price
10-026 nSquare corner, full lip, no box, 1 5/8” x 2 1/4” - Standard 1 1/8” $7.60
10-001 nSquare corner, T-strike, box, 1 1/8” x 2 3/4” 1 1/8” 6.50
10-027 n1/4” Radius round corner, full lip, no box, 1 5/8” x 2 1/4” 1 1/8” 7.60
Deadbolt & Deadlatch combinations
Part No. Specify Finish Description Backset Price
12-337 nCombo Latch, Dual Option, 1” x 2-1/4”, FE210 only 2 3/8” or 2 3/4” Not sold separately
Strikes Combinations
Deadbolt
Strike
Deadlatch
Strike
Specify
Combo No.
Add to
Lock Price
10-094 10-001 10-109 n/c
10-094 10-026 10-121 - STANDARD n/c
10-116 10-027 10-122 n/c
10-092 10-027 10-123 n/c
10-095 10-027 10-124 n/c
20
Multi-family Residential Electronic Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Proximity Credential and iButton iButton Only
iButton Credentials (For use with BE367 and FE210 electronic locks)
Part No. Description Price
Programming Credentials
48-515 Programming iButton on Red Key FOB (single pack) $11.50
Construction Credentials
48-517 Construction iButton on Yellow Key FOB (10 pack) 85.30
Proximity Credentials
IBF-110 Combo Key FOB, 125 kHz Proximity and iButton, user Gray (minimum order is 50) 13.35
IBWB-110 Combo Key FOB, 125 kHz Proximity without iButton (minimum order is 50) 7.05
IBF-120 Combo Key FOB, 125kHz Proximity and iButton, user Blue (minimum order is 50) 18.50
IBF-130 Combo Key FOB, 125khz Proximity and iButton, Vendor Access (Orange) (10-pack) 203.60
7610 Proximity Key FOB, 125 kHz (minimum order is 50) 5.90
When ordering any of the above credentials, please specify Bit Format, Facility Code, and starting Card ID Number
If these are not specied, the default Bit Format (26 Bit) and facility code (202) and the next available Card Number will be used
Price Book 5 | Effective January 8, 2018 | 800.847.1864 21
Multi-family Residential Electronic Locks
Access Management Software systems
Schlage delivers powerful software solutions to managing access points in multi-family properties that meet your current access control
requirements and expand to meet your growing business needs, all while satisfying your budget.
Schlage Express™ Software Price (ea.)
56-063 (SXPR-SFT-1)ExpressOfineLockSoftware(Includesoneclientlicense.Supportsofinelocks) $410.00
Recommended for ofine locks of fewer than 1000 users and/or 100 access points. Reporting of last 1000 events capability will retrieve audit trails
Must be installed on a computer that meets the minimum requirements (refer to software datasheet)
M204-215 Vendor Access Management Software, see a Schlage Authorized Dealer/Distributor for download instructions. n/c
Schlage Express™ Software version 4.4.3 or higher required. Requires 48-539 iButton reader and either 48-538 or IBF-130 credentials (sold
separately). Compatible only with 500 user BE367 deadbolts or FE210 interconnects.
Access Management Accessories Price (ea.)
HH-2PIN SERIAL
Serial Cable. Used to connect current model HHD (BM170) directly to legacy serial products without the need of a CIP
$131.00
HHD KIT-USB
Handheld Device Kit. Includes Handheld Device pre-loaded with SUS Application and HHD-USB Cable. Used to initialize,
manage and test AD and CO Series Devices.
1178.00
HHD-USB
USB Replacement Cable. Used to connect Handheld Device to USB locks and accessories.
53.30
HH-Serial
Serial Cable. Used to connect previous model HHD (BM150) with CIP to program serial products.
117.00
56-035 (P101203) CIP with iButton Reader.
Used to program serial products using HH-SERIAL Serial Cable.
319.00
56-036 (P394548) Female to Female Serial Cable
Used to connect Computer Interface Module (P101203) to a laptop/PC
59.20
48-539 iButton Reader with USB Adapter (Blue), Required for Vendor Access Software only
Used to read and write data to 48-538 or IBF-130 Vendor Access iButtons
115.43
CRP2 Proximity Credential Reader
Used to read proximity data for enrollment into Schlage Express™ Software database
521.00
MT20W Credential Enrollment Reader
Used to read and write to smart credentials within the ENGAGE™ Technology access control platform
(For use with Schlage Control™ Smart Locks)
547.00
Access Management Systems
22
Multi-family Residential Electronic Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Notes
23
Multi-family Residential Mechanical Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Elan (ELA) Jazz (JAZ) Latitude (LAT)
Schlage Residential Locks
Residential F Series
F - Lock
Broadway (BRW) Boardwalk (BWK) Longitude (LON)
Function Description Lever Style Finish Latch Strike Cylinder Price Each
F10 Passage ELA 619 16-080 10-027 N/A $57.00
F40 Privacy ELA 619 16-080 10-027 N/A 60.00
F170 Dummy ELA 619 N/A N/A N/A 29.00
F10 Passage ELA 622 16-080 10-027 N/A 57.00
F40 Privacy ELA 622 16-080 10-027 N/A 60.00
F170 Dummy ELA 622 N/A N/A N/A 29.00
F10 Passage ELA 625 16-080 10-027 N/A 57.00
F40 Privacy ELA 625 16-080 10-027 N/A 60.00
F170 Dummy ELA 625 N/A N/A N/A 29.00
F10 Passage ELA 626 16-080 10-027 N/A 57.00
F40 Privacy ELA 626 16-080 10-027 N/A 60.00
F170 Dummy ELA 626 N/A N/A N/A 29.00
F10 Passage ELA 716 16-080 10-027 N/A 57.00
F40 Privacy ELA 716 16-080 10-027 N/A 60.00
F170 Dummy ELA 716 N/A N/A N/A 29.00
F10 Passage JAZ 619 16-080 10-027 N/A 57.00
F40 Privacy JAZ 619 16-080 10-027 N/A 60.00
F170 Dummy JAZ 619 N/A N/A N/A 29.00
F10 Passage JAZ 622 16-080 10-027 N/A 57.00
F40 Privacy JAZ 622 16-080 10-027 N/A 60.00
F170 Dummy JAZ 622 N/A N/A N/A 29.00
F10 Passage JAZ 625 16-080 10-027 N/A 57.00
F40 Privacy JAZ 625 16-080 10-027 N/A 60.00
F170 Dummy JAZ 625 N/A N/A N/A 29.00
F10 Passage JAZ 626 16-080 10-027 N/A 57.00
F40 Privacy JAZ 626 16-080 10-027 N/A 60.00
F170 Dummy JAZ 626 N/A N/A N/A 29.00
F10 Passage JAZ 716 16-080 10-027 N/A 57.00
F40 Privacy JAZ 716 16-080 10-027 N/A 60.00
F170 Dummy JAZ 716 N/A N/A N/A 29.00
F10 Passage LAT 619 16-080 10-027 N/A 57.00
F40 Privacy LAT 619 16-080 10-027 N/A 60.00
F170 Dummy LAT 619 N/A N/A N/A 29.00
F10 Passage LAT 622 16-080 10-027 N/A 57.00
F40 Privacy LAT 622 16-080 10-027 N/A 60.00
F170 Dummy LAT 622 N/A N/A N/A 29.00
F10 Passage LAT 625 16-080 10-027 N/A 57.00
F40 Privacy LAT 625 16-080 10-027 N/A 60.00
F170 Dummy LAT 625 N/A N/A N/A 29.00
F10 Passage LAT 626 16-080 10-027 N/A 57.00
F40 Privacy LAT 626 16-080 10-027 N/A 60.00
F170 Dummy LAT 626 N/A N/A N/A 29.00
F10 Passage LAT 716 16-080 10-027 N/A 57.00
F40 Privacy LAT 716 16-080 10-027 N/A 60.00
F170 Dummy LAT 716 N/A N/A N/A 29.00
F10 Passage BRW 619 16-080 10-027 N/A 57.00
F40 Privacy BRW 619 16-080 10-027 N/A 60.00
F170 Dummy BRW 619 N/A N/A N/A 29.00
F10 Passage BRW 622 16-080 10-027 N/A 57.00
F40 Privacy BRW 622 16-080 10-027 N/A 60.00
F170 Dummy BRW 622 N/A N/A N/A 29.00
F10 Passage BRW 625 16-080 10-027 N/A 57.00
F40 Privacy BRW 625 16-080 10-027 N/A 60.00
F170 Dummy BRW 625 N/A N/A N/A $29.00
F10 Passage BRW 626 16-080 10-027 N/A 57.00
F40 Privacy BRW 626 16-080 10-027 N/A 60.00
F170 Dummy BRW 626 N/A N/A N/A 29.00
F10 Passage BRW 716 16-080 10-027 N/A 57.00
F40 Privacy BRW 716 16-080 10-027 N/A 60.00
F170 Dummy BRW 716 N/A N/A N/A 29.00
24
Multi-family Residential Mechanical Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Dover (DOV) Marin (MAR) Solstice (SOL) Solstice (SOL)
Collins Rose
Broadway (BRW) Broadway (BRW)
Collins Rose
Schlage Residential Locks (continued)
Function Description Lever Style Finish Latch Strike Cylinder Price Each
B60 Deadbolt SGL CYL 619 12-321 10-116 5 Pin C Keyway KA4 $62.00
B60 Deadbolt SGL CYL 622 12-321 10-116 5 Pin C Keyway KA4 62.00
B60 Deadbolt SGL CYL 625 12-321 10-116 5 Pin C Keyway KA4 62.00
B60 Deadbolt SGL CYL 626 12-321 10-116 5 Pin C Keyway KA4 62.00
B60 Deadbolt SGL CYL 716 12-321 10-116 5 Pin C Keyway KA4 62.00
B - Lock
Function Description Lever Style Finish Latch Strike Cylinder Price Each
J10 Passage SOL 619 16-254 10-101 N/A $40.00
J40 Privacy SOL 619 16-254 10-101 N/A 43.00
J170 Dummy SOL 619 N/A N/A N/A 20.00
J10 Passage SOL 622 16-254 10-101 N/A 40.00
J40 Privacy SOL 622 16-254 10-101 N/A 43.00
J170 Dummy SOL 622 N/A N/A N/A 20.00
J10 Passage SOL 625 16-254 10-101 N/A 40.00
J40 Privacy SOL 625 16-254 10-101 N/A 43.00
J170 Dummy SOL 625 N/A N/A N/A 20.00
J10 Passage SOL 626 16-254 10-101 N/A 40.00
J40 Privacy SOL 626 16-254 10-101 N/A 43.00
J170 Dummy SOL 626 N/A N/A N/A 20.00
J10 Passage SOL 716 16-254 10-101 N/A 40.00
J40 Privacy SOL 716 16-254 10-101 N/A 43.00
J170 Dummy SOL 716 N/A N/A N/A 20.00
J10 Passage SOL/COL 619 16-254 10-101 N/A 45.00
J40 Privacy SOL/COL 619 16-254 10-101 N/A 48.00
J170 Dummy SOL/COL 619 N/A N/A N/A 23.00
J10 Passage SOL/COL 622 16-254 10-101 N/A 45.00
J40 Privacy SOL/COL 622 16-254 10-101 N/A 48.00
J170 Dummy SOL/COL 622 N/A N/A N/A 23.00
J10 Passage SOL/COL 625 16-254 10-101 N/A 45.00
J40 Privacy SOL/COL 625 16-254 10-101 N/A 48.00
J170 Dummy SOL/COL 625 N/A N/A N/A 23.00
J10 Passage SOL/COL 626 16-254 10-101 N/A 45.00
J40 Privacy SOL/COL 626 16-254 10-101 N/A 48.00
J170 Dummy SOL/COL 626 N/A N/A N/A 23.00
J10 Passage SOL/COL 716 16-254 10-101 N/A 45.00
J40 Privacy SOL/COL 716 16-254 10-101 N/A 48.00
J170 Dummy SOL/COL 716 N/A N/A N/A 23.00
J10 Passage BRW 619 16-254 10-101 N/A 45.00
J40 Privacy BRW 619 16-254 10-101 N/A 48.00
J170 Dummy BRW 619 N/A N/A N/A 23.00
J10 Passage BRW 622 16-254 10-101 N/A 45.00
J40 Privacy BRW 622 16-254 10-101 N/A 48.00
J170 Dummy BRW 622 N/A N/A N/A 23.00
J10 Passage BRW 625 16-254 10-101 N/A $45.00
J40 Privacy BRW 625 16-254 10-101 N/A 48.00
J170 Dummy BRW 625 N/A N/A N/A 23.00
J10 Passage BRW 626 16-254 10-101 N/A 45.00
J40 Privacy BRW 626 16-254 10-101 N/A 48.00
J170 Dummy BRW 626 N/A N/A N/A 23.00
J10 Passage BRW 716 16-254 10-101 N/A 45.00
J40 Privacy BRW 716 16-254 10-101 N/A 48.00
J170 Dummy BRW 716 N/A N/A N/A 23.00
J10 Passage BRW/COL 619 16-254 10-101 N/A 50.00
J40 Privacy BRW/COL 619 16-254 10-101 N/A 53.00
Residential J Series
J - Lock
25
Multi-family Residential Mechanical Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Schlage Residential Locks (continued)
Residential J Series
J - Lock (continued)
Function Description Lever Style Finish Latch Strike Cylinder Price Each
J170 Dummy BRW/COL 619 N/A N/A N/A 25.00
J10 Passage BRW/COL 622 16-254 10-101 N/A 50.00
J40 Privacy BRW/COL 622 16-254 10-101 N/A 53.00
J170 Dummy BRW/COL 622 N/A N/A N/A 25.00
J10 Passage BRW/COL 625 16-254 10-101 N/A 50.00
J40 Privacy BRW/COL 625 16-254 10-101 N/A 53.00
J170 Dummy BRW/COL 625 N/A N/A N/A 25.00
J10 Passage BRW/COL 626 16-254 10-101 N/A 50.00
J40 Privacy BRW/COL 626 16-254 10-101 N/A 53.00
J170 Dummy BRW/COL 626 N/A N/A N/A 25.00
J10 Passage BRW/COL 716 16-254 10-101 N/A 50.00
J40 Privacy BRW/COL 716 16-254 10-101 N/A 53.00
J170 Dummy BRW/COL 716 N/A N/A N/A 25.00
J10 Passage MAR 619 16-254 10-101 N/A 36.00
J40 Privacy MAR 619 16-254 10-101 N/A 39.00
J170 Dummy MAR 619 N/A N/A N/A 18.00
J10 Passage MAR 622 16-254 10-101 N/A 36.00
J40 Privacy MAR 622 16-254 10-101 N/A 39.00
J170 Dummy MAR 622 N/A N/A N/A 18.00
J10 Passage MAR 625 16-254 10-101 N/A 36.00
J40 Privacy MAR 625 16-254 10-101 N/A 39.00
J170 Dummy MAR 625 N/A N/A N/A 18.00
J10 Passage MAR 626 16-254 10-101 N/A 36.00
J40 Privacy MAR 626 16-254 10-101 N/A 39.00
J170 Dummy MAR 626 N/A N/A N/A 18.00
J10 Passage MAR 716 16-254 10-101 N/A 36.00
J40 Privacy MAR 716 16-254 10-101 N/A 39.00
J170 Dummy MAR 716 N/A N/A N/A 18.00
J10 Passage DOV 619 16-254 10-101 N/A 36.00
J40 Privacy DOV 619 16-254 10-101 N/A 39.00
J170 Dummy DOV 619 N/A N/A N/A 18.00
J10 Passage DOV 622 16-254 10-101 N/A 36.00
J40 Privacy DOV 622 16-254 10-101 N/A 39.00
J170 Dummy DOV 622 N/A N/A N/A 18.00
J10 Passage DOV 625 16-254 10-101 N/A 36.00
J40 Privacy DOV 625 16-254 10-101 N/A 39.00
J170 Dummy DOV 625 N/A N/A N/A 18.00
J10 Passage DOV 626 16-254 10-101 N/A 36.00
J40 Privacy DOV 626 16-254 10-101 N/A 39.00
J170 Dummy DOV 626 N/A N/A N/A 18.00
J10 Passage DOV 716 16-254 10-101 N/A 36.00
J40 Privacy DOV 716 16-254 10-101 N/A 39.00
J170 Dummy DOV 716 N/A N/A N/A 18.00
JD60 Deadbolt SGL CYL 619 16-068 10-267 5 Pin C Keyway KA4 30.00
JD60 Deadbolt SGL CYL 622 16-068 10-267 5 Pin C Keyway KA4 30.00
JD60 Deadbolt SGL CYL 625 16-068 10-267 5 Pin C Keyway KA4 30.00
JD60 Deadbolt SGL CYL 626 16-068 10-267 5 Pin C Keyway KA4 30.00
JD60 Deadbolt SGL CYL 716 16-068 10-267 5 Pin C Keyway KA4 30.00
26
Multi-family Residential Mechanical Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
PRODUCT IDENTIFICATION
B 60 N F
Lock
Series
Function N - 5-pin cylinder
N6 - 6-pin cylinder
R6 - 6-pin cylinder with FSIC
F - UL Listed, available with B60,
B80, B61 and B60R6
J - Less full sized construction
T - Full sized construction core core
PRODUCT IDENTIFICATION
JD 60 F
Lock
Series
Function F - UL Listed, available with JD81
FINISH CODES & DESCRIPTIONS*
505 605 608 609 613 618 619 620 621 622 626 716
Lifetime
Bright
Brass
Bright
Brass
(US3)**
Satin
Brass
Antique
Brass
(US5)
Oil-
Rubbed
Bronze
(US10B)
Polished
Nickel
Satin
Nickel
(US15)**
Antique
Pewter
(US15A)
Distressed
Nickel
Matte
Black
(US19)
Satin
Chrome
(US26D)**
Aged
Bronze
(643e)**
* Non-Standard nishes are not available
** B60R available nishes
Specications
Grade 1 Deadbolts
Models: B60, B62, B80, B81
Certication: ANSI/BHMA A156.36, 2010, Grade 1
Deadbolt: 1” x 2 1/4”, radius corner, 1” housing diameter, 1” throw, latch number 12-321
Strike: 1 1/8” x 2 3/4”, 1/4” radius corner, strike number 10-116
Backset: Adjustable for 2 3/8” or 2 3/4”
Cylinder: 5-pin, keyed 5-pin, C keyway, keyed alike (KA)
Door Range: 1 3/8” - 1 3/4”
Keys: Two cut keys per lock, 5-pin, C section
Reinforcement: Door frame strike reinforcer with 3” screws
Grade 2 Deadbolts with full-size interchangeable core
Models: B60R6
Certication: ANSI/BHMA A156.36, 2010, Grade 2
Deadbolt: 1” x 2 1/4”, radius corner, 1” housing diameter, 1” throw, latch number 12-321
Strike: 1 1/8” x 2 3/4”, 1/4” radius corner, strike number 10-116
Backset: Adjustable for 2 3/8” or 2 3/4”
Cylinder Core: Grade 2, 6-pin keyed 6-pin, C keyway, keyed different (KD)
Door Range: 1 3/8” - 1 3/4”
Keys: Two user keys, 6-pin, C section, control key ordered separately
Reinforcement: Door frame strike reinforcer with 3” screws
Locks are furnished with standard features unless otherwise specied. To order locks with non-standard features specify non-standard feature desired
B Series Deadbolts
27
Multi-family Residential Mechanical Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
B60 B62 B60R6
B SERIES
Standard Features
n BHMA Grade 1 product performance (B60, B62, B80, B81)
n BHMA Grade 2 product performance (B60R6)
n Increased latch/bolt size offers maximum kick-in resistance
n Exclusive patented Schlage design
n Anti-pick shield
n Full-size Interchangeable Core B60R6
n Schlage Limited Lifetime Mechanical and Finish Warranty
n Finishes that feature ultraviolet (UV) resistance up to 4 times the BHMA standard: Satin Nickel, Bright Brass,
Antique Brass, and Antique Pewter
n Contoured edges for added style convenience
n Larger thumb turn for easy grip
GRADE 1 DEADBOLT STANDARD FEATURES/CONFIGURATIONS
Models: B60, B62, B80, B81
Certication: ANSI/BHMA A156.36, 2010, Grade 1
Deadbolt: 1” x 2 1/4”, radius corner, 1” housing diameter, 1” throw, latch number 12-321
Strike: 1 1/8” x 2 3/4”, 1/4” radius corner, strike number 10-116
Backset: Adjustable for 2 3/8” or 2 3/4”
Cylinder: 5-pin, keyed 5-pin, C keyway, keyed alike (KA4)
Door Range: 1 3/8” - 1 3/4”
Keys: Two keys per lock, 5-pin, keyed 5-pin, C section
Reinforcement: Door frame strike reinforcer with 3” screws
*Locks are furnished with standard features unless otherwise specied
To order locks with non-standard features specify non-standard feature desired
28
Multi-family Residential Mechanical Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
J Series Deadbolts
JD60 JD81 JD62
JD-SERIES
Standard Features
n Strongest locks in the opening price point category
n Largest knobs and levers in its class
n Fits standard door preps
n Easy to install
n Available with Schlage C keyway standard
n Dual or triple option latches available
n Available UL options (JD81)
n Dexter designs suite with many popular designs from Schlage
JD62
GRADE 3 DEADBOLTS STANDARD FEATURES
Models: JD60, JD62, JD81
Certication: ANSI/BHMA A156.36, 2010, Grade 3
Deadbolt Latch: Triple Option: 1” x 2 1/4”, square corner and 1/4” round faceplates, drive-in latch,
1” housing diameter, 1” throw
Strike: 1” x 2 1/4” round corner and radius corner, full lip
Backset: Adjustable for 2 3/8” or 2 3/4”
Cylinder: 5-pin, C keyway, keyed alike (KA4)
Door Range: 1 3/8” - 1 3/4”
Keys: Two keys per lock, 5-pin, keyed 5-pin, C section
29
Multi-family Residential Mechanical Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
B Series Deadbolts
J Series Deadbolts
B Series Deadbolts FINISHES
Function Packaging 605 505 608 609 618 619 620 621 622 625 626 716 613
B60 Single Cylinder Box/Vis $56 $62 $62 $62 $62 $62 $62 $62 $62 $62 $62 $62 $71
B62 Double Cylinder Box/Vis 81 87 87 87 87 87 87 87 87 87 87 87 96
B80 One-sided Box 38 n44 44 44 44 44 44 44 44 44 44 53
B81 One-sided w/trim Box 40 47 47 47 47 47 47 47 47 47 47 47 55
B60R6
Single Cylinder
Interchgbl. Core-6 Pin
Box n161 nnn159 nnnn159 161 n
List Price Adders:
UL Latch - add $6 to list price (B60, B80, B81 and B60R6)
J Series Deadbolts FINISHES
Function Packaging 605 609 619 625 626 630 620 716
JD60 Single Cylinder Deadbolt Box $28 $30 $30 $30 $30 $30 $30 $30
JD80 One-Sided Cylinder Deadbolt Box 22 26 26 nnn26 26
JD81 One-Sided Deadbolt with trim Box 22 26 26 nnn26 n
JD60F Single Cylinder UL Version Box 34 36 36 36 36 36 36 36
JD60 Single Cylinder Deadbolt Vis 31 33 33 nnn33 33
JD62 Double Cylinder Deadbolt Vis 38 43 43 nnn43 43
30
Multi-family Residential Mechanical Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Full-size Construction Core Program
Temporary construction cores may be ordered with full size interchangeable core locks, mortise cylinders
and rim cylinders
These cores may also be ordered separately. All construction cores are assessed a non-refundable
handling charge (50-231)
See Terms & Conditions for more information
Features:
n 5 or 6 Pin C keyway
n Constructioncoreshaveatwo-toneface:thefaceplateisaatblacknish(622)andtheplugis
  unnishedbrass
n Backofeachcoreismarkedwiththeletterthatidentiesthekeyedalikegroup:A,BorC
n Construction cores are furnished with no keys (NCK). Cut keys must be ordered separately
n A control key is required to install and remove construction cores. Control keys must be ordered separately
If a control key is not ordered, one will be supplied at a charge of $14.10
n Construction cores may be returned for credit. Contact your Schlage representative for return authorization
Credit is issued upon receipt of cores at our factory
CONTROL
C
Section
23-030-ICX 48-101-ICX 48-056-ICX
31
Multi-family Residential Mechanical Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
B Series Deadbolts
Notes:
1) To order mortise and rim cylinders with full-size construction cores for a new job, sufx ICX to non-Primus cylinder number
Example: 30-008 ICX. For existing construction core combinations, specify ICA, ICB, or ICC
2) Construction cores for a given project are keyed alike to one of a limited number of combinations nationwide
Other Schlage projects in the same area using the same or different contractors may use the same key
Example:
For construction core charges and credits: distributor XYZ ordered 150 construction cores with 20 keys and one control key
The following charges apply to this order:
1. 23-030-ICX construction cores (150 units)
2. 48-101-ICX cut keys (20 units)
3. 48-056-ICX cut control key (1 unit)
4. 50-231 non-refundable handling charge (150 units-one per core ordered)
Upon return of the cores to the factory the distributor will be credited for the following:
1. 23-030-ICX construction cores (150 units)
There is no credit for the keys or handling fee
Full-size Construction Core Program
Part No. Description Specify Price (ea.)
23-030-ICX Construction core New jobs: Specify “ICX”
Existing jobs: Specify “ICA” “ICB”
or “ICC”
$67.00
48-101-ICX Cut key for construction phase (order separately) 7.50
48-056-ICX Cut control key (order separately) 14.80
50-231 Non-refundable handling charge (per core) 9.50
KEY STAMPING (VKC)
Part No. Description Price (ea.)
50-217 Visual key control that allows for visual matching of user and control keys
to appropriate cylinders
$2.50
per key
Bitting List
Part No. Description Price (ea.)
50-123 Bitting List for factory master keyed products
(requires written authorization from end-user)
$212.00
Cylinder Stamping (CKC)
Part No. Description Price (ea.)
50-216 Visual cylinder control that allows for visual matching of cylinders to appropriate user and
control keys. Must specify VKC for face marking of CKC for side of cylinder marking per cylinder
When ordering keys/cylinders marked for ID purposes (VKC & CKC) both PN 50-216 and 50-
217 must be ordered as separate items
$6.20
per cylinder
32
Multi-family Residential Mechanical Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
877-671-7011
Customer Service: Technical Support:
Order Status, Credit Returns of Non-Defective
Products, General Sales Questions
Technical Questions/Issues, Returns of
Defective Products, Repairs
Email Orders To:
Order_Entry_Schlage_Commercial@allegion.com
Contact For Technical Assistance:
Electronic_Lock_TechProdSupport@allegion.com
CONTACT INFORMATION FOR LE SERIES LOCKS & DEVICES
Payment Address: Schlage Electronic Security
15934 Collections Center Drive
Chicago, IL 60693
LE • Introduction
Finish Codes and Descriptions
Code Description
619 (US15) Satin Nickel
622 (US19) Matte Black
625 (US26) Bright Chrome
626 (US26D) Satin Chrome
643E (US11) Aged Bronze
Standard Features
Certication ANSI/BHMACertiedA156.25-2013(Indoor/Outdoor),ANSI/BHMACertied
A156.13-2012, Series 1000, Grade 1
UL 294, ULC S319, UL 10C 3-hour rated
Case Size 4-7/16" x 6-1/16" x 1"
Armor Front 1-1/4" x 8"
Deadbolt 1" throw stainless steel
Latchbolt 3/4" throw stainless steel with anti-friction tongue
Strike 1-1/4" x 4-7/8", square corner, 1-3/16" lip with box and DPS
Backset 2-3/4"
Cylinder 6-Pin solid brass, keyed 6-pin, S123 keyway, keyed different (KD)
Door Range 1-3/4" door thickness standard (can be ordered to accommodate doors 1-3/4" to 2-1/4" thick)
Keys Two nickel silver cut keys per lock, 6-pin, S123 section
07 (Athens) 17 (Sparta)
M52 (Broadway) M81 (Boardwalk)
LAT (Latitude)06 (Rhodes)
LON (Longitude)
33
Multi-family Residential Mechanical Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Function Addison Escutcheon Shown
MS - Mortise with LED Indicator
Storeroom
Lockset is normally secure. Inside lever always allows free egress.
Valid toggle credentials on the exterior may be used to change to
a passage or secured status. A mechanical key will momentarily unlock
the door.
MB - Mortise with Interior Push Button and LED
Ofce
Lockset is normally secure. Inside lever always allows free egress. Interior
pushbutton on inside housing may be used to select a passage or secured
status. Meets need for lockdown function for safety and security.
NOTE: Valid toggle credentials on the exterior may also be used to change status.
Has interior pushbutton (IPB).
Privacy
Lockset is normally secure. Inside lever always allows free egress. Interior
pushbutton on inside housing may be used to select a privacy status. The
interior pushbutton will disable normal electronic access from the exterior.
Opening the door or pressing the interior pushbutton a second time on the
inside housing deactivates the privacy status. Has interior pushbutton (IPB).
Apartment
Lockset is normally secure. Inside lever always allows free egress. Interior
pushbutton on inside housing may be used to select a passage or secured
status. Opening the door or pressing the interior pushbutton causes the
lockset to toggle unsecured. While toggled unsecured, the lockset can only
be secured while the door is closed by pressing the interior pushbutton or
using a normal credential on the exterior. Normal electronic access from the
exterior is always allowed. Has interior pushbutton (IPB).
MD - Mortise Deadbolt with LED
Privacy
Lockset is normally secure from exterior. Inside lever always allows free
egress (if deadbolt is extended, inside knob/lever will simultaneously retract
latchbolt and deadbolt). The deadbolt may be used to select a privacy
status. With deadbolt extended, normal electronic access from the exterior
will be disabled. Opening the door or retracting deadbolt deactivates the
privacy status.
Apartment
Lockset is normally secure from exterior. Inside lever always allows free
egress (if deadbolt is extended, inside knob/lever will simultaneously retract
latchbolt and deadbolt). The deadbolt may be used to select a passage
or secured status. Opening the door or retracting the deadbolt causes the
lockset to toggle unsecured. While toggled unsecured, the lockset can only
be secured while the door is closed by extending the deadbolt from inside
or using a normal credential on the exterior reader. Normal electronic access
from the exterior is always allowed.
LED
Handing
RH Right Handed: Hinges on Right Opens Inward
LH Left Handed: Hinges on left Opens Inward
RHR Right Handed Reverse: Hinges on Right Opens Outward
LHR Left Handed Reverse: Hinges on Left Opens Outward
LE Wireless Lock Functions
34
Multi-family Commercial Wireless Electronic/Electrified Locks, Readers & Devices
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Outside MS with LED MS Deadbolt
with LED
MB with Interior push
button and LED
LE Wireless Lock - Greenwich Mortise/Mortise Deadbolt
4. Select Cylinder Type
Note: Maximum door thickness with SFIC Cylinder is 2", otherwise compatible with 1-3/4" to 2-1/4" doors.
P ÅrMortise cylinder, Schlage 6-Pin (Everest 29 S123 standard)
Also available in formats to support residential customers (5-Pin cylinder with C keyways).
N/C
Z ÅMortise cylinder, Schlage Everest SL, 7-Pin (factory master keyed only) N/C
L Less mortise cylinder DEDUCT $74.00
R ţ FSIC with cylinder, Schlage 6-Pin (Everest 29 S123 standard) $67.00
J Less FSIC, Schlage, 6-Pin N/C
T FSIC construction core $67.00
GD ţ SFIC with cylinder, Schlage 7-Pin (Everest 29R standard) (factory master keyed only) $77.00
BD Less SFIC, Schlage, Falcon, competitive OEM's, 7-Pin N/C
HD SFIC construction core $40.00
BDC SFIC disposable N/C
50-231 Construction core handling charge (non-refundable) $9.50
Å Master keyed cylinders will be shipped in lock package. To specify, send Master Keying System Summary form (page 295 of SES price book)
with order or go to kss.allegion.com.
r For master keying, an additional charge of $18.30 each applies. Specify line item 50-210.
£ Control keys for installation/removal of interchangeable cores are not furnished and must be ordered separate.
For additional assistance on Master Keying as well as restricted keyways please contact customer service.
5. Select Outside Lever
Note: Reference page 16 to see style option images.
06 Suites with Rhodes style N/C
07 Suites with Athens style N/C
17 Suites with Sparta style N/C
LAT Latitude N/C
LON Longitude N/C
M52 Suites with Broadway $30.00
M81 Suites with Boardwalk $30.00
Note: Tactile warning as well as additional lever and knob designs are available; consult your Allegion representative for details
6. Select Outside Finish
626 Satin Chrome N/C
619 Satin Nickel $63.00
622 Matte Black $63.00
625 Bright Chrome $63.00
643e Aged Bronze $63.00
Note:additionalnishesareavailable;consultyourAllegionrepresentativefordetails
7. Select Outside Rose
00A 2-1/8" (54 mm) diameter STANDARD
00B 2-9/16" (65 mm) diameter N/C
00C 2-5/8"(66mm)diameterwithbevel(Notavailablein612nish) N/C
Outside
MD - Deadbolt
with LED
MB with interior push
button and LED
MS with LED
Outside
MD - Deadbolt
with LED
MB with interior push
button and LED
MS with LED
Outside
MD - Deadbolt
with LED
MB with interior push
button and LED
MS with LED
Outside
MD - Deadbolt
with LED
MB with interior push
button and LED
MS with LED
1-3. Select Chassis/Function/Style
Note: Check with access control software provider to verify function is supported by software.
Part No. Description Price Each
LEMS-GRW Mortise with LED indicator: Storeroom function $1,185.00
LEMB-GRW MortisewithpushbuttonandLED:Privacy,Ofce,Apartmentfunctions $1,215.00
LEMD-GRW Mortise Deadbolt with LED: Privacy, Apartment functions $1,284.00
35
Multi-family Commercial Wireless Electronic/Electrified Locks, Readers & Devices
Price Book 5 | Effective January 8, 2018 | 800.847.1864
8. Select Inside Lever
Note: Specify only if different from Outside Lever.
Standard options 06 (Rhodes), 07 (Athens), 17 (Sparta), LAT, LON N/C
M Collection options* M52 (Broadway), M81 (Boardwalk) $30.00
* $30 price adder for M Collection levers only applies if outside lever is Standard.
9. Select Inside Finish
Note: Specify only if different from Outside Finish.
See options in section 6. 63.00*
*Upchargeonlyappliesifoutsidenishis626andyouarespecifyingadifferentinsidenish.
10. Select Inside Rose
Note: Specify only if different from Outside Rose.
See options in section 7. N/C
11. Select Handing
(Field reversible)
RH Right Handed STANDARD
LH Left Handed N/C
RHR Right Handed Reverse N/C
LHR Left Handed Reverse N/C
12. Select Strike Lip Length
10-136 1-3/16" lip length (MS and MB only) STANDARD
10-136-112 1-1/2" lip length (MS and MB only) N/C
10-136-134 1-3/4" lip length (MS and MB only) 27.10
10-072 1-3/16" lip length (MD only) STANDARD
10-072-112 1-1/2" lip length (MD only) N/C
10-072-134 1-3/4" lip length (MD only) 28.50
13. Select Door Thickness
134 1-3/4" STANDARD
200 2" 51.10
214 2-1/4" 51.10
14. Select Keying Type
Open Keyway Families (Mortise cylinder or FSIC)2
S123 Everest 29 S (Key in Lever or FSIC) STANDARD
C Everest N/C
C/CE/E/EF/F/FG/G Classic Obverse N/C
Restricted Keyway Families (Mortise cylinder or FSIC)1,2,3
29T Everest 29 T 16.00
D Everest D 16.00
29R Everest 29 R (Everest SL) 16.00
B Everest 29 B (Everest SL) 16.00
Classic Restricted Quad, Numbered, Reverse 16.00
Restricted Keyway Families (SFIC)3
29R Everest 29 R N/C
B Everest B N/C
1. Everest Restricted Keyways require a Letter of Authorization submitted with the order. See sample Letter of Authorization, page 297 of SES price book.
2. Full size key systems (Everest 29 S & T, Everest C & D, Obverse & Quad) are available in Primus and Primus XP key system and must be ordered separately.
Lock should be ordered less cylinder and Primus cylinder should be a separate line item.
3. For restricted keyways please see terms and conditions.
LE Wireless Lock - Greenwich Mortise/Mortise Deadbolt (continued)
Control,NDE, LE and CTE require the use of Allegion's ENGAGE application for electronic access or one of our approved Software Alliance Members.
Please consult the Alliance section at us.allegion.com for a full listing of Software Alliance Members.
36
Multi-family Commercial Wireless Electronic/Electrified Locks, Readers & Devices
Price Book 5 | Effective January 8, 2018 | 800.847.1864
LE Wireless Lock - Addison Mortise/Mortise Deadbolt
4. Select Cylinder Type
Note: Maximum door thickness with SFIC Cylinder is 2", otherwise compatible with 1-3/4" to 2-1/4" doors.
P ÅrMortise cylinder, Schlage 6-Pin (Everest 29 S123 standard)
Also available in formats to support residential customers (5-Pin cylinder with C keyways).
N/C
Z ÅMortise cylinder, Schlage 7-Pin (Everest SL standard) (factory master keyed only) N/C
L Less mortise cylinder DEDUCT 74.00
R ţ With FSIC with cylinder, Schlage 6-Pin (Everest 29 S123 standard) 67.00
J Less FSIC, Schlage, 6-Pin FSIC N/C
T With FSIC construction core 67.00
GD ţ With SFIC with cylinder, Schlage 7-Pin (Everest 29R standard) (factory master keyed only) 77.00
BD Less SFIC, Schlage, Falcon, competitive OEM's, 7-Pin N/C
HD With SFIC construction core 40.00
BDC With SFIC disposable N/C
50-231 Construction core handling charge (non-refundable) 9.50
Å Master keyed cylinders will be shipped in lock package. To specify, send Master Keying System Summary form (page 295 of SES price book)
with order or go to kss.allegion.com.
r For master keying, an additional charge of $18.30 each applies. Specify line item 50-210.
£ Control keys for installation/removal of interchangeable cores are not furnished and must be ordered separate.
For additional assistance on Master Keying as well as restricted keyways please contact customer service.
1-3. Select Chassis/Function
Note: Check with access control software provider to verify function is supported by software.
LEMS-ADD Mortise with LED indicator: Storeroom function $1,225.00
LEMB-ADD MortisewithpushbuttonandLED:Privacy,Ofce,Apartmentfunctions 1,255.00
LEMD-ADD Mortise Deadbolt with LED: Privacy, Apartment functions 1,324.00
5. Select Outside Lever*
Note: Reference page 16 to see style option images.
06 Suites with Rhodes style N/C
07 Suites with Athens style N/C
17 Suites with Sparta style N/C
LAT Latitude N/C
LON Longitude N/C
M52 Suites with Broadway 30.00
M81 Suites with Boardwalk 30.00
Note: Tactile warning as well as additional lever and knob designs are available; consult your Allegion representative for details
6. Select Outside Finish
626 Satin Chrome N/C
619 Satin Nickel 63.00
622 Matte Black 63.00
625 Bright Chrome 63.00
643e Aged Bronze 63.00
Note:additionalnishesareavailable;consultyourAllegionrepresentativefordetails
7. Select Outside Rose
(Not applicable to Addision)
8. Select Inside Lever
Note: Specify only if different from Outside Lever.
Standard options 06 (Rhodes), 07 (Athens), 17 (Sparta), LAT, LON N/C
M Collection options* M52 (Broadway), M81 (Boardwalk) 30.00
* $30 price adder for M Collection levers only applies if outside lever is Standard.
Outside
MD - Deadbolt
with LED
MS with LED
Indicator
MB with interior push
button and LED
Outside
MD - Deadbolt
with LED
MS with LED
Indicator
MB with interior push
button and LED
Outside
MD - Deadbolt
with LED
MS with LED
Indicator
MB with interior push
button and LED
Outside
MD - Deadbolt
with LED
MS with LED
Indicator
MB with interior push
button and LED
Outside MS with LED MS Deadbolt
with LED
MB with Interior push
button and LED
37
Multi-family Commercial Wireless Electronic/Electrified Locks, Readers & Devices
Price Book 5 | Effective January 8, 2018 | 800.847.1864
9. Select Inside Finish
Note: Specify only if different from Outside Finish.
See options in section 6. $63.00*
*Upchargeonlyappliesifoutsidenishis626andyouarespecifyingadifferentinsidenish.
10. Select Inside Rose
(Not applicable to Addision)
11. Select Handing
(Field reversible)
RH Right Handed STANDARD
LH Left Handed N/C
RHR Right Handed Reverse N/C
LHR Left Handed Reverse N/C
12. Select Strike Lip Length
10-136 1-3/16" lip length (MS and MB only) STANDARD
10-136-112 1-1/2" lip length (MS and MB only) N/C
10-136-134 1-3/4" lip length (MS and MB only) 27.10
10-072 1-3/16" lip length (MD only) STANDARD
10-072-112 1-1/2" lip length (MD only) N/C
10-072-134 1-3/4" lip length (MD only) 28.50
13. Select Door Thickness
134 1-3/4" STANDARD
200 2" 51.10
214 2-1/4" 51.10
14. Select Keying Type
Open Keyway Families (Mortise cylinder or FSIC)2
S123 Everest 29 S (Key in Lever or FSIC) STANDARD
C Everest N/C
C/CE/E/EF/F/FG/G Classic Obverse N/C
Restricted Keyway Families (Mortise cylinder or FSIC)1,2,3
29T Everest 29 T 16.00
D Everest D 16.00
29R Everest 29 R (Everest SL) 16.00
B Everest 29 B (Everest SL) 16.00
Classic Restricted Quad, Numbered, Reverse 16.00
Restricted Keyway Families (SFIC)3
29R Everest 29 R N/C
B Everest B N/C
1. Everest Restricted Keyways require a Letter of Authorization submitted with the order. See sample Letter of Authorization, page 297.
2. Full size key systems (Everest 29 S & T, Everest C & D, Obverse & Quad) are available in Primus and Primus XP key system and must be ordered separately. Lock should be ordered less cylinder
and Primus cylinder should be a separate line item.
3. For restricted keyways please see terms and conditions.
Control, NDE ,LE and CTE require the use of Allegion's ENGAGE application for electronic access or one of our approved Software Alliance Members.
Please consult the Alliance section at us.allegion.com for a full listing of Software Alliance Members.
LE Wireless Lock - Addison Mortise/Mortise Deadbolt (continued)
38
Multi-family Commercial Wireless Electronic/Electrified Locks, Readers & Devices
Price Book 5 | Effective January 8, 2018 | 800.847.1864
NDE • Introduction
Finish Codes and Descriptions
Code Description
619 (US15) Satin Nickel
622 (US19) Matte Black
625 (US26) Bright Chrome
626 (US26D) Satin Chrome
643E (US11) Aged Bronze
Standard Features
Certification ANSI/BHMA Certified A156.25-2013, A156.2-2011, Series 4000, Grade 1, UL 294,
UL 10C
Latch 1 1/8" x 2 1/4", Square corner faceplate, 1" housing diameter, 1/2" throw
Strike 1 1/4" x 4 7/8", ANSI Square corner, with DPS magnets, no box
Backset 2 3/4"
Cylinder 6-Pin solid brass, keyed 6-pin, S123 keyway, keyed different (KD)
Door Range Comes set for 1-3/4" thick doors. Can be field adjusted for doors 1-5/8"-2" thick.
Keys Two nickel silver cut keys per lock, 6-pin, S123 section
877-671-7011
Customer Service: Technical Support:
Order Status, Credit Returns of Non-Defective
Products, General Sales Questions
Technical Questions/Issues, Returns of
Defective Products, Repairs
Email Orders To:
Order_Entry_Schlage_Commercial@allegion.com
Contact For Technical Assistance:
Electronic_Lock_TechProdSupport@allegion.com
CONTACT INFORMATION FOR NDE SERIES LOCKS & DEVICES
Payment Address: Schlage Electronic Security
15934 Collections Center Drive
Chicago, IL 60693
07 (Athens) 17 (Sparta)
M52 (Broadway) M81 (Boardwalk)
LAT (Latitude)06 (Rhodes)
LON (Longitude)
39
Multi-family Commercial Wireless Electronic/Electrified Locks, Readers & Devices
Price Book 5 | Effective January 8, 2018 | 800.847.1864
NDE Wireless Lock Functions
ANSI/BHMA Certied A156.25-2013, A156.2-2011,
Series 4000, Grade 1, UL 294, UL 10C
Keyed Locks
SCHLAGE ANSI
NDE80PD F86 Storeroom Lock with Vandlgard
Lockset is normally secure with outside
lever disengaged. Valid credential or key
momentarily unlocks door. Valid credential
may be used to change to a passage or
secured state. Inside lever always allows
free egress.
40
Multi-family Commercial Wireless Electronic/Electrified Locks, Readers & Devices
Price Book 5 | Effective January 8, 2018 | 800.847.1864
NDE Wireless Lock - Cylindrical
1-2. Select Chassis/Function
Part No. Description Price Each
NDE-80 Cylindrical Storeroom Lock with Vandlgard $860.00
3. Select Cylinder Type
PD ÅWith Cylinder, Schlage - (Everest 29 S123, 6 Pin KIL standard) N/C
ZD ÅWith Cylinder, Schlage - Everest SL, 7 Pin KIL (factory master keyed only) N/C
LD Less Cylinder, Schlage, Falcon, 6 Pin KIL DEDUCT 58.00
RD ţ With Core, Schlage 6-Pin (Everest 29 S123 standard) FSIC 35.00
JD Less Core, Schlage, 6 Pin FSIC DEDUCT 32.00
T With FSIC construction core 35.00
GD ţ With Core, Schlage 7-Pin (Everest 29R standard) (factory master keyed only) 77.00
BD Less Core, Schlage, Falcon, Competitive OEM's, 7 Pin (SFIC) N/C
LD CO6 Less Cylinder, Corbin Russwin KIL, 6 Pin FSIC. Only available on ATH, RHO, SPA, OME, TLR DEDUCT 58.00
LD SAR 6Less Cylinder, Sargent (10L + 11L), 6 Pin KIL . Only available on ATH, RHO, SPA, OME, TLR DEDUCT 58.00
JD SAR 6Less Core, Sargent 6300, 6 Pin FSIC. Only available on ATH, RHO, SPA, OME, TLR DEDUCT 32.00
JD CO6 6Less Core, Corbin 8000, 6 Pin FSIC . Only available on ATH, RHO, SPA, OME, TLR DEDUCT 32.00
JD CO7 Less Core, Corbin 8000-7, 7 Pin FSIC. Only available on ATH, RHO, SPA, OME, TLR DEDUCT 32.00
JD MED Less Core, Medeco 32*0201, 6 Pin FSIC. Only available on ATH, RHO, SPA, OME, TLR DEDUCT 32.00
JD YA6 6Less Core, Yale 1210 or Medeco 31*0100, 6 Pin FSIC. Only available on ATH, RHO, SPA, OME, TLR DEDUCT 32.00
JD YA7 Less Core, Yale 1220, 7 Pin FSIC. Only available on ATH, RHO, SPA, OME, TLR DEDUCT 32.00
HD With SFIC construction core 40.00
BDC With SFIC disposable N/C
50-231 Construction core handling charge (non-refundable) 9.50
Å MasterKeyedcylinderscanbespeciedandwillbeshippedinlockpackaging.ForMasterKeyingSystemSummaryformwhichshouldaccompanythemasterkeyedorder,seeSESPriceBook.
r For Master Keying, additional line item 50-210 is required $18.30 each.
£ Control Keys for installation/removal of interchangeable cores are not furnished and must be ordered separate.
For additional assistance on Master Keying as well as restricted keyways please contact customer service.
6 Extendedleadtimeonallnishesexcept626
4. Select Outside Lever*
SPA Sparta N/C
RHO Rhodes N/C
ATH Athens N/C
LAT Latitude N/C
LON Longitude N/C
BRW Broadway N/C
BRK Boardwalk N/C
Note: Tactile warning and additional lever designs are available; consult your Allegion representative for details
5. Select Outside Finish
626 Satin Chrome N/C
619 Satin Nickel 64.00
622 Matte Black 64.00
625 Bright Chrome 64.00
643e Aged Bronze 64.00
Note:additionalnishesareavailable;consultyourAllegionrepresentativefordetails
6. Select Inside Lever*
(Specify only if different from Outside Lever)
SPA Sparta N/C
RHO Rhodes N/C
ATH Athens N/C
LAT Latitude N/C
LON Longitude N/C
BRW Broadway N/C
BRK Boardwalk N/C
NDE-80 Small Format
Interchangeable Core
GD BD
Full Size
Interchangeable Core
RD JD JD SAR JD CO6 JD YA6
Full Cylinder
PD LD LD SAR
41
Multi-family Commercial Wireless Electronic/Electrified Locks, Readers & Devices
Price Book 5 | Effective January 8, 2018 | 800.847.1864
NDE Wireless Lock - Cylindrical (continued)
7. Select Inside Finish
(Specify only if different from Outside Finish)
626 Satin Chrome N/C
619 Satin Nickel 64.00*
622 Matte Black 64.00*
625 Bright Chrome 64.00*
643e Aged Bronze 64.00*
*Chargeonlyappliesifoutsidenishis626andyouarespecifyingadifferentinsidenish.
8. Select Backset & Latchbolt
LLL Less Latch DEDUCT 32.10
13-247 2-3/4" Backset, Deadlatch, Square corner, 1-1/8" x 2-1/4" STANDARD
14-042 2-3/4"Backset,DeadlatchAnti-frictionredoorlatch,Squarecorner, 165.00
14-047 2-3/8" Backset, Deadlatch Square corner, 1-1/8" x 2-1/4" N/C
14-048 2-3/8" Backset, Deadlatch Square corner, 1" x 2-1/4" N/C
9-10. Select Strike Plate and Strike Lip Length
10-130* 1-3/16" Lip, ANSI, DPS magnets, no box, 1-1/4" x 4-7/8" STANDARD
10-131* 1-3/16" ANSI, DPS magnets, Standard box, 1-1/4" x 4-7/8" N/C
10-132**†1-1/8" Lip, Square Corner, T-strike, DPS magnets, box, 1-1/8" - 2-3/4" N/C
10-133 †1-1/8"Lip,SquareCorner,T-strike,DPSmagnets,deepbox,redoorlatch 15.20
K510-066 BoxforANSIstrike(Mustbespecic) N/C
* 1-3/8" Lip available, must specify 1-3/8" Lip $13.70, 1-1/2" Lip available, must specify 1-1/2" Lip $13.70
** 1-1/2" Lip available, must specify 1-1/2" Lip $7.50
† DPS magnet requires prep and install beneath strike
11. Select Keying Type
Open Keyway Families: KIL or FSIC2
S123 Everest 29 S (Key in Lever or FSIC) STANDARD
C Everest C N/C
C/CE/E/EF/ F/ FG/ G Classic Obverse N/C
Restricted Keyway Families: KIL or FSIC1, 2
29 T Everest 29 T 16.00
D Everest D 16.00
29R Everest 29 R (Everest SL) 16.00
B Everest B (Everest SL) 16.00
Classic Restricted Quad, Numbered, Reverse 16.00
Restricted Keyway Families: SFIC3
29R Everest 29 R N/C
B Everest B N/C
1. Everest Restricted Keyways require a Letter of Authorization to be submitted with the order. See sample Letter of Authorization, see SES Price Book.
2. Full Size key systems (Everest 29 S & T, Everest C & D, Obverse & Quad) are available in Primus and Primus XP key system and must be ordered separately. Lock should be ordered less cylinder
and Primus cylinder should be a separate line.
3.MasterKeyedcylinderscanbespeciedandwillbeshippedinlockpackaging.ForMasterKeyingSystemSummaryformwhichshouldaccompanythemasterkeyedorder,seeSESPriceBook.
Control, NDE, LE and CTE require the use of Allegion's ENGAGE application for electronic access or one of our approved Software Alliance Members.
Please consult the Alliance section at us.allegion.com for a full listing of Software Alliance Members.
42
Multi-family Commercial Wireless Electronic/Electrified Locks, Readers & Devices
Price Book 5 | Effective January 8, 2018 | 800.847.1864
CTE Single Door Controller with Multi-Technology Reader Kit
The CTE is an ENGAGE™ enabled single opening controller that allows perimeter and common area openings to be managed in a
single system along with Schlage Control™ smart deadbolts, NDE cylindrical and LE mortise wireless locks. It is ideal for multi-family,
commercial mixed use, and retail store front applications.
The CTE kit comes with a Schlage®Multi-Technologycredentialreaderandisdesignedtointerfacewithanelectriedlock,
electromagnetic lock, electric strike, automatic operator or exit device to control an opening.
Certications
• UL 294 Indoor, FCC Part 15, NEMA Enclosure Indoor (Type 1, 4, and 4X), ULC S319 Indoor, RoHS
TITLE:
DRAWING TYPE: DWG NO: R EV
A
DRAWN/CHECKED B Y:
TYPE DATE DRAWN: REVISION DATE:
HARDWARE USED:
NOTES:
1) ALL LOW VOLTAGE WIRING TO BE STANDARD,
MULTI-CONDUCTOR COLOR CODED WITHOUT SPLICES.
2) WIRING TO CONFORM TO APPLICABLE NA TIONAL, STATE AND
LOCAL EL ECTRICAL CODES.
3) REFER TO SPE CIFIC PRODUCT I NSTALLATION INSTRUCTIONS
FOR SPECI FIC WIRING REQUIRE MENTS.
4) THIS DRAWING IS F OR GRAPHICAL REPRESENTATI ON OF
PRODUCTS DETA ILED IN THE HARDWARE SET ONLY.
5) ADDITIONAL WIRING WILL BE REQUIRED FROM ACP THAT IS NOT
SHOWN HERE. CONSULT PROV IDER FOR DETAILS.
BREND A DOVE
THIS DIAGRAM REPRESENTS A GENERIC CONFIGURATION. CUSTOM WIRING
DIAGRAMS CAN BE ACQ UIRED BY CON TACTING TE CHNICAL SUPPORT.
PoE+ CTE WITH 5100 ESTRIKE
BASIC CONFIGURATION
08-21-17
PoE+ CTE ACCESS
CONTROL WITH 51 00
ESTRIKE - BASIC
OPERATION:
SCHLAGE MT11-485 OR MT15-485 OR MTK15-485 READER TO RELEASE FSE 5100 ESTRIKE TO
ALLO W ENTRY.
CTE CAN BE USED WITH ENGAGE CLOUD OR SOFTWARE ALLIANCE MEMBER
(
SAM
)
SYSTEM
VERIFY PoE+ POWER SOURCE APPROPRIATE TO HANDLE LOAD AT OPENING. ADDITIONAL
WIRING WILL BE REQUIRED THAT IS NOT SHOWN HERE.
FREE EGRESS ALWAYS PERMITTED.
THIS IS NOT A FIRE RATED APPLICATION
1 CTE
1 MT11-485 OR MT15-485 OR
MTK15-485 SCHLAGE READER
1 VD 5100 ESTRIKE
1 PoE+ SWITCH
1 OPTION AL PS902
CTE
SCHLAGE MT11-485
OR MT15-485
READER PULL SIDE
110/240
VAC
2AMP
4x18 2x18
PoE+
SWITCH
OPTIONAL
PS902
2x18
FSE
5100
ESTRIKE
TO ENGAGETM CLOUD OR
INTEGRATED SOFTWARE
ALLIANCE MEMBER
(SAM) SYSTEM; WIFI OR
BLUETOOTH
BRENDA DOVE
TITL E:
DWG NO: REV
A
DRAWN/CHECK ED BY:
THIS DIAGRAM REPRESENTS A GENERIC CONFIGURATION. CUSTOM WIRING
DIAGRAMS CAN BE ACQUIRED BY CONTACTING TECHNICAL SUPPORT.
RX EL PANIC
DEVICE
EPT
10
PS914-2RS
24VDC
CTE
4x18
* 2x12
110/240
VAC
2AMP
4x18
OPERATION:
SCHLAGE MT11-485 OR MT15-485 READER TO SIGNAL EL TO RETRACT
THE ELECTRIC LATCH ON PANIC BAR THROUGH THE CTE TO ALLOW
ENTRY.
CTE TO COMMUNICATE TO ENGAGETM CLOUD OR SOFTWARE
ALLIANCE(SAM) SYSTEM
FREE EGRESS ALWAYS PERMITTED
THIS IS NOT A FIRE RATED APPLICATION
NOTE:
USE #12 GAUGE WIRE FOR DISTANCES UP TO 200' FROM EPT TO PS914.
USE #14 GAUGE WIRE FOR DISTANCES UP TO 100' FROM EPT TO PS914.
679-05
DPS
2x18
2x18
SCHLAGE MT11-485
OR MT15-485
READER PULL SIDE
TO ENGAGETM CLOUD OR
INTEGRATED SOFTWARE
ALLIANCE MEMBER (SAM)
SYSTEM; WIFI OR
BLUETOOTH
BREND A DOVE
TITL E:
DRAWING TYPE: DWG NO: REV
A
DRAWN/CHECK ED BY:
NOTES:
1) ALL LOW VOL TAGE WIRING TO BE STANDARD,
MULTI-CONDUCTOR COLOR CODED WITHOUT SPLICES.
2) WIRING TO CONF ORM TO APPLICA BLE NATIONAL , STATE AND
LOCAL E LECTRICAL CODES.
3) REFER TO SPECIFIC PROD UCT INSTALLA TION INSTRUCT IONS
FOR SPE CIFIC WI RING REQ UIREM ENTS.
4) THIS DRAWI NG IS FOR GRAPHICA L REPRESENT ATION OF
PRODUCTS DET AILED IN THE HA RDWARE SET ONLY.
5) * CONDUCTOR COUNT TO BE DETERM INED BY ACCESS
CONTROL PANEL PROVIDER.
TYPE DAT E DRA WN: REVI SION DATE:
HARDWARE USED:
RISER DIAGRAM
THIS DIAGRAM REPRESENTS A GENERIC CONFIGURATION. CUSTOM WIRING
DIAGRAM S CAN BE ACQUIRE D BY CONTA CTING TE CHNICAL SUPPORT.
RX QEL PANIC
DEVICE
EPT
10
PS902
24VDC
CTE
110/240
VAC
2AMP
4x18
MEMBER SAM SYSTEM
OPERATION:
SCHLAGE MT11-485 OR MT15-485 READER TO SIGNAL EL TO RETRACT THE ELECTRIC
LATCH ON VON DUPRIN RX QEL PANIC BAR AND ENABLE EXTERIOR ACTUATOR TO ALLOW
ENTRY. FREE EGRESS ALWAYS PERMITTED. INTERIOR ACTUATOR ALWAYS ACTIVE.
ADDITIONAL WIRING WILL BE REQUIRED THAT IS NOT SHOWN HERE.
CTE TO COMMUNICATE TO ENGAGETM CLOUD OR SOFTWARE ALLIANCE MEMBER (SAM)
SYSTEM
THIS IS NOT A FIRE RATED APPLICATION
CTE WITH QEL AND PS902 WITH 9500
SENIOR SWING AO
1 CTE
1MT11-485 OR MT15-485
SCHLAGE READER
1 VD QELPANIC
1EPT10
1PS902
1679-05DPS
1 9500SEN IOR SWING
2ACUTATORS
CTE ACCESS CONTROL
WITH QEL PANIC WITH
SENIOR SWING AO
09-12-17
679-05
DPS
2x18
4x18
SCHLAGE MT11-485
OR MT15-485
READER PULL SIDE
9500 SENIOR SWING
AC
INPUT
ACTUATORS
INTERIOR EXTERIOR
2x18
2x182x18
6x18
- TO ENGAGETM CLOUD
OR INTEGRATED
SOFTWARE ALLIANCE
MEMBER (SAM) SYSTEM;
WIFI OR BLUETOOTH
Operation: Presenting a valid credential to Schlage MT XX-485 reader
will cause fail secure 5100 electric strike to release for authorized
entrance. Free egress always.
Products: We offer a variety of electric strikes from Locknetics™ and
Von Duprin®,aswellasSchlagePowerSuppliestomeetthespecic
needs of the opening.
Operation: Presenting a valid credential to Schlage MT XX-485 will
cause EL panic device to retract for authorized entrance. Free non-
alarmed egress at all times.
Products: We offer a variety of Falcon® and Von Duprin exit devices,
andVonDuprinpowersuppliestomeetthespecicneedsofthe
opening.
Operation: Presenting a valid credential to Schlage MT XX-485 will
cause QEL panic device to retract for authorized entrance and enable
exterior actuator. Free non-alarmed egress at all times. Interior
actuator always active to retract QEL panic and open door.
Products: We offer a variety of hardware and accessories from Von
Duprin, LCN®,SchlageandLockneticstomeetthespecicneedsofthe
opening.
ENGAGE™ cloud
via mobile device
or Wi-Fi, or
Software Alliance
Member (SAM)
via Wi-Fi or GWE
with IP to host
ENGAGE™ cloud
via mobile device
or Wi-Fi, or
Software Alliance
Member (SAM)
via Wi-Fi or GWE
with IP to host
ENGAGE™ cloud
via mobile device
or Wi-Fi, or
Software Alliance
Member (SAM)
via Wi-Fi or GWE
with IP to host
The CTE single door controller with multi-technology reader kit can be used in a variety of applications; below are a few examples.
Please note; all components are sold separately.
CTE Kit Reader
CTE-MT11-485 CTE with Multi-Technology Mullion Reader Kit $1 230.00
CTE-MT15-485 CTE with Multi-Technology Single Reader Kit $1 230.00
43
Multi-family Commercial Wireless Electronic/Electrified Locks, Readers & Devices
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Residential Credential Enrollment Reader
Function Description Price Each
MT20W Schlage Credential Enrollment Reader; required for No-Tour Applications $547.00
Electromagnetic Locks
Model Description Price Each
M420 500lb maglock $509.00
M490 High security 1500lb maglock 637.00
M490P High security 1500lb maglock - plus 825.00
M492 Double mag lock 1500 lbs per leaf 1,334.00
450/490-ATS/LED Electromagnetic lock M450 582.00
M452P Double mag lock with 1000 lbs holding force per leaf with MBS, DPS and RTD 1,607.00
M490G Gate maglock 643.00
M450P N N SL 1000 lbs hold force single mag lock with MBS, DPS and RTD 774.00
M452P.ATS/LED/LED Double mag lock with 1000 lbs hold force per leaf with MBS, DPS and RTD 1,750.00
M490DEP High security 1500lb delayed egress maglock - plus 2,054.00
M490DE High security 1500lb delayed egress maglock 1,368.00
GF3000 Mortise shear maglock 1,020.00
Residential Electronics Accessories
44
Multi-family Commercial Wireless Electronic/Electrified Locks, Readers & Devices
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Electronics Accessories
Part Number Description Price Each
Scan II - W Motion Scanner/PIR - white $490.00
679-05 Wood Door and Frame door position switch 55.80
679-05HM Hollow Metal Door and Frame door position switch 77.20
679-05WD Wood Door and Metal Frame door position switch 92.30
7764 Concealed /Flush mount door position switch 186.00
7766 Surface mount door position switch 197.00
653-04 SF-626 Heavy duty SPDT maintained single direction keyswitch 256.10
653-05 SF-626 Heavy duty SPDT momentary single direction keyswitch 256.10
788C-18 18" x 3/8" Armored door cord with 26" 4-conductor wire 108.00
798-12 12" x 1/2" Armored Door Cord 69.90
798-18 18" x 1/2" Armored Door Cord 88.80
660-PB Surface mini box SPDT momentary pushbutton 130.00
701RD Entry level pushbutton, red 124.00
709RD EX ILL Entry level pushbutton, 2" square, Illuminated Red "Push to Exit" 145.00
709GR EX ILL Entry level pushbutton, 2" square, Illuminated Green "Push to Exit" 145.00
709BLH ILL Entry level pushbutton, 2" square, Illuminated Blue Handicapped Symbol 145.00
621RD EX SF-626 1-1/4" Heavy duty pushbutton, red "push to exit" 204.10
623RD EX SF-626 1-5/8" Heavy duty pushbutton, red "push to exit" 204.10
625RD EX SF-626 2-3/4" Heavy duty pushbutton, red "push to exit" 204.10
621GR EX SF-626 1-1/4" Heavy duty pushbutton, green "push to exit" 204.10
623GR EX SF-626 1-5/8" Heavy duty pushbutton, green "push to exit" 204.10
625GR EX SF-626 2-3/4" Heavy duty pushbutton, green "push to exit" 204.10
625BLH SF-626 2-3/4" Heavy duty pushbutton, blue handicapped symbol 204.10
Power Supply
Part Number Description Price Each
PS902 2A@12/24VDC-eldselectablepowersupply $249.00
PS904 4A@12/24VDC-eldselectablepowersupply 474.00
PS914 4A(16AInrush)@12/24VDC-eldselectablepowersupply 718.00
900-2RS 2 Relay EL/QEL Panic device control board 154.00
900-FA Emergencyinterfacerelayforrealarmoremergencypowercut 60.00
900-BBK Battery backup kit, includes PCB and 2 Batteries 238.00
Note: Power Supplies default to Schlage pricing and discount.
Networked Readers
Schlage Networked Readers
Function Description Price Each
MT15 Multi-Technology Reader - Wall Mount, Wiegand
Reads 125 kHz proximity and 13.56 MHz contactless smart credential technology in one reader
$327.00
MT11 Multi-Technology Reader - Mullion Mount, Wiegand
Reads 125 kHz proximity and 13.56 MHz contactless smart credential technology in one reader
327.00
MTK15 Multi-Technology Reader with Keypad - Wall Mount, Wiegand
Reads 125 kHz proximity and 13.56 MHz contactless smart credential technology in one reader
523.00
PR10 Proximity Reader - Mini-Mullion Mount, Wiegand
Reads 125 kHz proximity credentials
159.00
SM10 Smart Reader - Mini-Mullion Mount, Wiegand
Reads 13.56 MHz contactless smart credential technology
159.00
MT11-485 Multi-Technology Reader - Mullion Mount, RS-485
Reads 125 kHz proximity and 13.56 MHz contactless smart credential technology in one reader.
Note: required for use with CTE Single Door Controller.
327.00
MT15-485 Multi-Technology Reader - Wall Mount, RS-485
Reads 125 kHz proximity and 13.56 MHz contactless smart credential technology in one reader.
Note: required for use with CTE Single Door Controller.
327.00
Electronic Locking Systems
45
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
5. Select nish style
619 622 625 626 643e/716
Finish $12.00 $12.00 $12.00 n/c $12.00
CS210 Interconnect Series
1. Select Lock Model
Part No. Description Price Each
CS210-B500 Entrance with Commercial Spin Ring $365.00
CS210-B60 Entrance with Residential Spin Ring 365.00
2. Select Interior Design Style
Style/Description Price Each
(CAM) Camelot No Charge
(PLY) Plymouth No Charge
3. Select Lever Style
Price Each
See page MF-13 for Lever Design Options No Charge
*Specify handing - Right Hand is standard
4. Select Key Cylinder Option
Style/Description Price Each
(KD) Keyed Different - STANDARD No Charge
(KA) Keyed Alike No Charge
Mechanical Interconnect Functions
Functions
ANSI/BHMA Certieda156.12-2005,Grade2,ULListedfor3hourredoor
CS210: Entrance, Single Locking
n Deadbolt operated by key from outside or by turn unit from inside
n Bolt automatically deadlocks when fully thrown
n Latch retracted by lever from either side
n Turning inside lever retracts deadbolt and latch simultaneously for immediate exit
B500 - Single Cylinder Deadbolt Series
Product Finish Latch Strike Cylinder Price Each
B560B 626 12-287 10-094 B - Less SFIC $103.00
B560P 626 12-288 10-094 6-Pin (keyed 5) Schlage KD C 76.00
B560B 619 12-288 10-094 B - Less SFIC 109.00
B560P 619 12-287 10-094 6-Pin (keyed 5) Schlage KD C 82.00
46
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Handingmustbespeciedforsplitnishesand/ordesigns.RightHandisstandard.
Saturn (SAT) Elan (ELA) Jupiter (JUP) Jazz (JAZ) Neptune (NEP)
Lattitude (LAT) Boardway (BRW) Boardwalk (BRK) Longitude (LON)
Plymouth (PLY) Camelot (CAM)
Available Finishes
619 622 625 626 643e/716
Broadway nnnnn
Boardwalk* nnnnn
Elan nnnnn
Jazz n n n n
Jupiter nnnnn
Latitude nnnnn
Longitude* nnnnn
Neptune nnnnn
Saturn nnnnn
* Available late Q2 2018
Interconnect Lever Designs
47
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Product Identification
L/LV 9 4 53 P
Cylinder Suffix
P = 6-Pin Full Face Mortise
Cylinder with Schlage Logo*
L = Less Full Face Cylinder
R = Full Size Interchangeable
Core with Schlage Logo
J = Less Full Size
Interchangeable Core
F = Full Size Interchangeable
Core Less Schlage Logo
T =
Full Size Construction Core
BD = Less SFIC
BDC = Disposable SFIC
GD = Everest 29 Patented SFIC
HD = Construction SFIC
Function
0 = No Deadbolt
1 = Dummy Trim
4 = With Deadbolt
0 =
Dummy Trim without Lock Case
9 = Functions with Lock Case
Lock Series Prefix
L = Standard
LV = Vandlgard
SFIC = Small Format (Best® Style) Interchangeable Core
L Series • Introduction
Finish Codes and Descriptions
Code Description
619 (US15) Satin Nickel
622 (US19) Matte Black
625 (US26) Bright Chrome
626 (US26D) Satin Chrome
643E (US11) Aged Bronze
Standard Features
Certifications L/LV9000: ANSI/BHMA Certified A156.13-2012, Series 1000, Grade 1 Operational,
Grade 1 Security, UL Listed for 3-hour fire door (except L9076 and L9077).
With FSIC Interchangeable Core Cylinders: Grade 2 Security.
With SFIC Interchangeable Core Cylinders: Grade 3 Security.
L400: ANSI/BHMA Certified A156.36-2010, Grade 1, UL Listed for 3-hour fire door.
Case Size L/LV9000: 4 7/16" x 6 1/16" x 1"; L400: 4 7/16" x 3 5/8" x 1"
Armor Front L/LV9000: 1 1/4" x 8"; L400: 1 1/4" x 5 9/16"
Deadbolt 1" Throw stainless steel
Latchbolt 3/4" Throw stainless steel with anti-friction tongue
Strike L/LV9000: 1 1/4" x 4 7/8" Square corner, 1 3/16" lip, box; L400: 1 1/8" x 3 5/8" square corner, box
Backset 2 3/4"
Cylinder 6-Pin solid brass, keyed 6-pin, S123 keyway, keyed different (KD)
Door Range 1 3/4"
Keys Two nickel silver cut keys per lock, 6-pin, S123 section
48
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Mortise Locks Non-Keyed Mortise Locks Non-Keyed Dummy
SCHLAGE ANSI SCHLAGE ANSI
L9010 F01 Passage Latch
Latchbolt retracted by knob/lever from either
side at all times. Inside knob/lever is always
free for immediate egress.
L0170 Half Dummy Trim
Knob/leverononesidexedbymounting
bar. Not for use on wood doors, or with L
escutcheon recommend L9175.
L9040
LV9040
F22 Bath/Bedroom Privacy Lock
Latchbolt retracted by knob/lever from
either side unless outside is locked by inside
thumbturn.Turning inside knob/lever or
closing door unlocks outside knob/lever. To
unlock from outside, remove
emergency button, insert emergency
thumbturn(furnished) in access hole and
rotate. Inside knob/lever is always free for
immediate egress.
L0172 Full Dummy Trim
Knob/leveronbothsidesxedbymounting
bar.
L9044
LV9044
Privacy With Coin Turn Outside
Latchbolt retracted by knob/lever from
either side unless outside is locked by inside
thumbturn or outside coin turn. Operating
inside knob/lever, closing door, rotating
inside thumbturn or rotating outside cointurn
unlocks outside knob/lever. Specify per L283-
056 for Torx® screws. Available with rose trim
only.
L9175 Half Dummy Trim w/ Lock Case
Fixed knob/lever on one side inoperable.
Includes lock case and armored front. Options
same as L9176 below.
L9440
LV9440
F19 Privacy With Deadbolt
Latchbolt retracted by knob/lever from
either side. Deadbolt thrown or retracted by
inside thumbturn. Throwing deadbolt locks
outside knob/lever. Rotating inside knob/
lever simultaneously retracts deadbolt and
latchbolt, and unlocks outside knob/lever.
To unlock from outside, remove emergency
button, insert emergency thumbturn in access
hole and rotate. Inside knob/lever is always
free for immediate egress.
L9176 Full Dummy Trim w/ Lock Case*
Fixed knob/lever on both sides. Includes lock
case and blank armor front. May be ordered
with optional XL11-743 armored front with
cutout to receive deadbolt.
L9444
LV9444
Privacy With Deadbolt and Coin Turn
Outside
Latchbolt retracted by knob/lever from
either side. Deadbolt thrown or retracted
by inside thumbturn or outside coin turn.
Throwing deadbolt locks outside knob/lever.
Rotating inside knob/lever simultaneously
retracts deadbolt and latchbolt, and unlocks
outside knob/lever. Rotating outside coin turn
retracts deadbolt and unlocks outside knob/
lever. Specify per L283-056 for Torx screws.
Available with rose trim only. Inside knob/lever
is always free for immediate egress.
LV- Vandlgard function allows exterior lever to rotate freely down, while remaining
securely locked.
* In a double door application where the dummy will be used as the strike, order 10-091
Armored Front Strike separately.
180 degree messaging indicator available. See options section for details.
L • Functions
ANSI/BHMA Certied A156.13-2012, Series 1000, Grade 1 Operational, Grade 1 Security, UL Listed for 3-hour re door
(except L9076 and L9077).
Additional functions as well as Mortise Deadbolts are available; please consult your Allegion representative for details.
49
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Mortise Locks Keyed Mortise Locks-Keyed with Deadbolt
SCHLAGE ANSI SCHLAGE ANSI
L9050
LV9050
F04 Entrance/Ofce Lock
Latchbolt retracted by knob/lever from either
side unless outside is made inoperative by
key outside or by turning inside thumbturn.
When outside is locked, latchbolt is retracted
by key outside or by knob/lever inside. Outside
knob/lever remains locked until thumbturn
is returned to vertical or unlocked by key.
Auxiliary latch deadlocks latchbolt when door
is locked. Inside knob/lever is always free for
immediate egress.
L9453
LV9453
F20 Entrance/Ofce Lock with Deadbolt
Latchbolt retracted by knob/lever from either
side unless outside is locked by 20° rotation of
thumbturn. Deadbolt thrown or retracted by
90° rotation of thumbturn. When locked, key
outside or knob/lever inside retracts deadbolt
and latchbolt simultaneously. Outside
knob/lever remains locked until thumbturn
is restored to vertical position. Throwing
deadbolt automatically locks outside knob/
lever. Auxiliary latch deadlocks latchbolt when
door is locked. Inside knob/lever is always free
for immediate egress.
L9056
LV9056
F22 L9050 With Automatic Unlocking
Latchbolt retracted by knob/lever from either
side unless outside is made inoperative by
key outside or by rotating inside thumbturn.
Outside knob/lever unlocked by key outside,
thumbturn or closing door. Rotating inside
knob/lever simultaneously retracts latchbolt
and unlocks outside knob/lever. Auxiliary
latch deadlocks latchbolt when door is locked.
Inside knob/lever is always free for immediate
egress.
L9456
LV9456
F13 Corridor Lock
Latchbolt retracted by knob/lever from
either side. Deadbolt thrown or retracted by
key outside or inside thumbturn. Throwing
deadbolt locks outside knob/lever. Turning
inside knob/lever simultaneously retracts
deadbolt and latchbolt and unlocks outside
knob/lever. Inside knob/lever is always free for
immediate egress.
L9060
LV9060
F09 Apartment Entrance Lock
Latchbolt retracted by knob/lever from either
side unless outside is locked by key from
inside. When locked, latchbolt retracted by
key outside or knob/lever inside. Auxiliary
latch deadlocks latchbolt when door is locked.
Inside knob/lever is always free for immediate
egress.
L9465 Closet/Storeroom Lock
Latchbolt retracted by knob/lever from either
side. Deadbolt thrown or retracted by key
outside.
L9080
LV9080
F07 Storeroom Lock
Latchbolt retracted by key outside or by
knob/lever inside. Outside knob/lever
always inoperative. Auxiliary latch deadlocks
latchbolt when door is locked. Inside knob/
lever is always free for immediate egress.
L9466 F14 Store/Utility Room Lock*
Latchbolt retracted by knob/lever from either
side. Deadbolt thrown or retracted by key from
either side.
LV- Vandlgard function allows exterior lever to rotate freely down, while remaining
securely locked.
* Caution: Double cylinder locks on residences and any door in any structure which
is used for egress are a life safety hazard in times of emergency and their use is not
recommended. Installation should be in accordance with existing codes only.
180 degree messaging indicator available. See options section for details.
L9473 F21 Dormitory/Bedroom Lock
Latchbolt retracted by knob/lever from either
side. Deadbolt thrown or retracted by key
outside or thumbturn inside.
L9480
LV9480
Storeroom Lock With Deadbolt
Latchbolt retracted by key outside or by
lever or knob inside. Outside knob/lever
alwaysxed.Deadboltthrownorretracted
by key outside or thumbturn inside. Turning
inside knob/lever simultaneously retracts
both deadbolt and latchbolt. Auxiliary latch
deadlocks latchbolt when door is locked.
Inside knob/lever is always free for immediate
egress.
L • Functions
Additional functions as well as Mortise Deadbolts are available; please consult your Allegion representative for details.
50
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
L9090EL
L9090EU
Electrically locking/unlocking outside lever,
no cylinder
Outside knob/lever continuously locked (EL) or
unlocked (EU) by 12 or 24V DC. Inside lever always
free for immediate egress.
L9492EL
L9492EU
Electrically locking/unlocking outside lever, outside
cylinder, inside thumbturn, with deadbolt
Outside knob/lever continuously locked (EL) or unlocked
(EU) by 12 or 24V DC. Deadbolt thrown or retracted by key
outside or thumbturn inside. Turning inside knob/lever
retracts deadbolt and opens door. When unlocked, rotating
outside lever retracts deadbolt and opens door. Aux latch
deadlocks latchbolt when door is shut. Inside lever always
free for immediate egress.
L9091EL
L9091EU
Electrically locking/unlocking both levers, no
cylinder
Inside and outside knob/lever continuously locked
(EL) or unlocked (EU) by 12 or 24V DC.
L9493EL
L9493EU
Electrically locking/unlocking both levers, outside
cylinder, inside thumbturn, with deadbolt
Inside and outside knob/lever continuously locked (EL)
or unlocked (EU) by 12 or 24V DC. Deadbolt thrown or
retracted by key outside or thumbturn inside. When
unlocked, rotating inside or outside lever retracts deadbolt
and opens door. Aux latch deadlocks latchbolt when door
is shut.
L9092EL
L9092EU
Electrically locking/unlocking outside lever,
Outside cylinder (replaces L9080EL/EU)
Outside knob/lever continuously locked (EL) or
unlocked (EU) by 12 or 24V DC. Latchbolt retracted
by key outside or knob/lever inside. Aux latch
deadlocks latchbolt when door is locked. Inside
lever always free for immediate egress.
L9494EL
L9494EU
Electrically locking/unlocking outside lever, inside
and outside cylinders, with deadbolt
Outside knob/lever continuously locked (EL) or unlocked
(EU) by 12 or 24V DC. Deadbolt thrown or retracted by
key outside or inside. Turning inside knob/lever retracts
deadbolt and opens door. When unlocked, rotating outside
lever retracts deadbolt and opens door. Aux latch deadlocks
latchbolt when door is shut. Inside lever always free for
immediate egress.
L9093EL
L9093EU
Electrically locking/unlocking both levers,
Outside cylinder
Inside and outside knob/lever continuously
locked (EL) or unlocked (EU) by 12 or 24V DC.
Latchbolt retracted by key outside. EL is fail safe
(power failure allows either knob/lever to retract
latchbolt); EU is fail secure (power failure locks
both knobs/levers). Aux latch deadlocks latchbolt
when door is locked
L9495EL
L9495EU
Electrically locking/unlocking both levers, inside and
outside cylinders, with deadbolt
Inside and outside knob/lever continuously locked (EL)
or unlocked (EU) by 12 or 24V DC. Deadbolt thrown or
retracted by key outside or inside. When unlocked, rotating
inside or outside lever retracts deadbolt and opens door.
Aux latch deadlocks latchbolt when door is shut.
L9094EL
L9094EU
Electrically locking/unlocking outside lever,
Inside and outside cylinder
Outside knob/lever continuously locked (EL) or
unlocked (EU) by 12 or 24V DC. Latchbolt retracted
by key inside or outside or knob/lever inside. Aux
latch deadlocks latchbolt when door is locked.
Inside lever always free for immediate egress.
L9095EL
L9095EU
Electrically locking/unlocking both levers,
Inside and outside cylinder (replaces
L9082EL/EU)
Inside and outside knob/lever continuously locked
(EL) or unlocked (EU) by 12 or 24V DC. Latchbolt
retracted by key inside or outside. Aux latch
deadlocks latchbolt when dooris locked.
L909x EL/EU Electried Locks
All locks feature automatic detection and operation with 12 or 24V DC, and a case-mounted switch that allows customer selection
of EL (fail safe) or EU (fail secure) operation. Please specify lock function as EL or EU for default switch postion. Locks also come standard with
Allegion Connect molex connector with 3" lead. Allegion Connect is a molex connector system that allows rapid installation of locks when used
with Allegion Connect Harnesses (see page 193) and Allegion Connect Hinges (see Ives pricebook). For more information speak with your sales
representative. The molex connector can also be cut off so that the lock can be installed with traditional splicing.
Availableoptionsforelectriedfunctions:RequesttoExit specifyRXintheoptionstring
Latchbolt Monitor specify LX in the option string
Door Position Sensor specify DPS in the option string (non deadbolt models only)
Deadbolt Monitor specify DM in the option string (deadbolt models only)
Additional functions as well as Mortise Deadbolts are available; please consult your Allegion representative for details.
51
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Wrought Rose Designs
A B C
L • Complete Locks
Standard Lever Collection* A, B or C Rose Trim
Cast or Forged Lever Designs with Wrought Roses
Note: Above images shown with A Rose.
Note: A wide variety of additional lever designs are available; consult your Allegion representative for details
2¹⁄₂"
¹⁄₂"
4⁵⁄₈"2"
2⁷⁄₈"
4⁵⁄₈"
2
³⁄₈"
1³¹⁄₃₂"
¹⁄₂"
3"
4³⁄₄"
2¹⁵⁄₁₆"
2
⁹⁄₁₆
"
4³⁄₄"
2"
4.5"
2.2"
3"
4.5"
2.2"
3"
Not available with C Rose
07 (Athens) 17 (Sparta)
M52 (Broadway) M81 (Boardwalk)
LAT (Latitude)06 (Rhodes)
LON (Longitude)
2⁹⁄₁₆"
4⁷⁄₈
"
¹⁄₂"
4.8”
0.4”
2.9”
2.1”
4.8”
0.4”
2.9”
2.1”
52
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
L-Series (A, B or C Rose Trim) - Standard Collection levers
Function
Add $87 for Vandlgard Option
Add $889 MultiPoint Lock
Description
06 (Rhodes),
07 (Athens),
17 (Sparta), LAT (Latitude),
LON (Longitude)
M52
(Broadway),
M81 (Boardwalk)
626 619 622 625 643e 619, 622, 625,
626, 643e
Keyless Functions
L9010 •Passage $627 $639 $657
L9040 •Privacy 721 733 751
L9044 •Privacy w/ coin turn 783 795 813
L9090&91 EL&EU ElectriedLock(keyless) 1,009 1,021 1039
L9440 •Privacy w/ deadbolt 830 842 920
L9444 •Privacy w/ deadbolt and coin turn 890 902 920
L0170 Single dummy 224 230 240
L0172 Double dummy 455 467 485
L9175 Single dummy with case 336 342 352
L9176 Double dummy with case 554 566 584
Keyed Single Cylinder Functions
L9050P
•
•
Entrance/Ofce 804 816 834
L9056P
•
Entrance/Ofcewithautounlocking 878 890 908
L9080P
•
•
Storeroom 804 816 834
L9092P&93P
EL&EU ElectriedLock(outsidecylinder) 1,089 1,101 1,119
L9453P
•
Entrance w/ deadbolt
830 842 860
L9456P
•
Corridor w/ deadbolt
L9465P Closet/Storeroom w/ deadbolt
L9473P Dorm/Bedroom w/ deadbolt
L9480P
•
Storeroom w/ deadbolt 910 922 940
L9492P&93P
EL&EU
Electriedlock(outsidecylinder,insidethumbturn,
deadbolt) 1,113 1,125 1,143
Keyed Double Cylinder Functions
L9060P
•
Apartment entrance $884 $896 914
L9094P&95P
EL&EU ElectriedLock(Insideandoutsidecylinder) 1,169 1,181 1,199
L9466P Storeroom w/ deadbolt 884 896 914
L9494P&95P
EL&EU
Electriedlock(insideandoutsidecylinder,
deadbolt) 1,193 1,205 1,223
Notes: 1) For the Everest 29 T and Everest D family of restricted keyways (Quad, Numbered, Reversed) add $16.00. This does not apply to Primus families.
See Terms and Conditions for more information.
Complete Locks • L
53
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Cast/Forged (L) or Wrought (N)
L N
L • Complete Locks
Standard Lever Collection* Escutcheon Trim
Cast or Forged Lever Designs with Cast, Forged, or Wrought Escutcheons
Note: Above images shown with L Escutcheon.
Note: A wide variety of additional lever designs are available; consult your Allegion representative for details
07 (Athens) 17 (Sparta)
M52 (Broadway) M81 (Boardwalk)
LAT (Latitude)06 (Rhodes)
LON (Longitude)
2¹⁄₂"
¹⁄₂"
4⁵⁄₈"2"
2¹⁄₂"
¹⁄₂"
4⁵⁄₈"2"
2⁷⁄₈"
4⁵⁄₈"2³⁄₈"
1³¹⁄₃₂"
2⁷⁄₈"
4⁵⁄₈"2³⁄₈"
1³¹⁄₃₂"
¹⁄₂"
3"
4³⁄₄"
2¹⁵⁄₁₆"
¹⁄₂"
3"
4³⁄₄"
2¹⁵⁄₁₆"
2⁹⁄₁₆"
4³⁄₄"
2⁹⁄₁₆"
4³⁄₄
"
2"
4.5"
2.2"
3"
4.5”
3”
2.2”
Dimensions:
7 7/8" x 2 1/2" x 7/16"
(200mm x 64mm x 11mm)
Dimensions:
7 15/16" x 1 3/4" x 7/16"
(202mm x 44mm x 11mm)
2⁹⁄₁₆"
4⁷⁄₈"
¹⁄₂"
2⁹⁄₁₆"
4⁷⁄₈"
¹⁄₂
"
4.8”
0.4”
2.9”
2.1”
4.8”
0.4”
2.9”
2.1”
54
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
L • Complete Locks
L or N Escutcheon Trim
L-Series (L or N Escutcheon) - Standard Collection Levers
Function
Add $87 for Vandlgard Option
Add $889 MultiPoint Lock
Description
Lever or Knob Designs and Finishes
Standard Lead time
06 (Rhodes), 07 (Athens),
17 (Sparta), LAT (Latitude),
LON (Longitude)
M52
(Broadway),
M81
(Boardwalk)
Finishes
626 619 622 625
643e
619, 622, 625,
626, 643e
Keyless Functions
L9010 • Passage 654 666 684
L9040 • Privacy 748 760 778
L9044 • Privacy w/ Coin Turn and Outside Indicator (N Escutcheon Only) 910 922 940
L9444
• Privacy w/ Deadbolt, Coin Turn and Outside Indicator (N
Escutcheon Only) 1017 1029 1047
L9090&91
EL&EU ElectriedLock(keyless) 1,036 1,048 1,066
L9440 • Privacy w/ Deadbolt 857 869 887
L0170 Single Dummy (N Escutcheon Only) 251 263 267
L0172 Double Dummy 482 494 512
L9175 Single Dummy with Case 363 375 379.
L9176 Double Dummy with Case 581 593 611
Keyed Single Cylinder Functions
L9050P • • Entrance/Ofce 831 843 861
L9056P • Entrance/Ofcew/AutoUnlocking 905 917 935
L9080P • • Storeroom 831 843 861
L9092P&93P
EL&EU
ElectriedLock(outsidecylinder) 1,116 1,128 1,146
L9453P •Entrance/Ofcew/Deadbolt
857 869 887
L9456P • Corridor w/ Deadbolt
L9465P Closet/Storeroom w/ Deadbolt
L9473P Dorm/Bedroom w/ Deadbolt
L9480P • Storeroom w/ Deadbolt 937 949 967
L9492P&93P
EL&EU Electriedlock(outsidecylinder,insidethumbturn,deadbolt) 1,140 1,152 1,170
Keyed Double Cylinder Functions
L9060P • Apartment Entrance $911 $923 $941
L9094P&95P
EL&EU ElectriedLock(Insideandoutsidecylinder) 1,196 1,208 1,226
L9466P Storeroom w/ Deadbolt 911 923 941
L9494P&95P
EL&EU Electriedlock(insideandoutsidecylinder,deadbolt) 1,220 1,232 1,250
Notes: 1) For the Everest 29 T and Everest D family of restricted keyways (Quad, Numbered, Reversed) add $16.00. This does not apply to Primus families
See Terms and Conditions for more information.
2) L escutcheon available 1-3/8"- 2-1/2" doors non-Vandlgard functions, 1-3/4"-2-1/2" doors on Vandlgard functions. N escutcheon available 1-3/4" - 2-1/4" non-Vandlgard and
Vandlgard functions
55
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
L • Cylinder Options
Cylinder Adjustments
Specify Description Lock Price Adjustment
(per cylinder)
Full Size Interchangeable Core (FSIC)
RSufx Fullsizecore(furnished1-bittedw/two6-pinkeysunlessotherwisespecied) $67.00
JSufx Less full size core N/C
Full Size Construction Core
TSufx Full size construction core (assessed handing charge 50-231 per core) $67.00
Small Format Interchangeable Core (SFIC) (Not available with Hotel Functions L9485 or L9486)
GDSufx Everest patented core (specify key symbol; see Terms & Conditions for more details) $77.00
BDSufx Less small format core N/C
Small Format Construction Core & Disposable Core
HDSufx Small format construction core (assessed handing charge 50-231 per core) $40.00
BDCSufx Small format disposable core N/C
Construction Core Handling Charge
50-231 Handing charge for construction core (assessed per core, non-refundable) $9.50
Notes Control keys are not furnished with locks and must be purchased separately. See Keys & Keying. Interchangeable cores are not available with concealed cylinders.
Orderinginstructions:Addsufxtolockfunction.Ex:L9050J(L9050functionlessfullsizecore)
Shadeditemsarestandardcomponentsandarefurnishedwithlocksunlessotherwisespecied.
56
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Shadeditemsarestandardcomponentsandarefurnishedwithlocksunlessotherwisespecied.
L • Armor Fronts and Strikes
Armor Fronts, L9000
Specify Description Lock Price Adjustment
1 1/4" Wide (Standard armor size for 1-3/4" and larger door thicknesses)
09-661 Blank (L9175, L9176)
N/C
09-662 Latch only (L9010, L9040, L9044)
09-663 Latch x aux latch (L9050, L9056, L9060, L9070, L9071, L9080, L9082, L9090/91/92/93/95/95*)
09-713 Latch x aux latch (L9076, L9077)
09-664 Latch x deadbolt (L9440, L9444, L9456, L9457, L9465, L9466, L9473, L9496)
09-665 Deadbolt (L9460, L9462, L9463, L9464)
09-666 Latch x aux latch x deadbolt (L9453, L9458, L9480, L9485, L9486, L9492/93/94/95)
09-717 Deadbolt armor (L460, L462, L463, L464, L480, L496)
1 1/16" Wide (recommended armor size for doors thinner than 1-3/4", including 1 3/8" doors)
09-667 Blank (L9175, L9176)
N/C
09-668 Latch only (L9010, L9040, L9044)
09-669 Latch x aux latch (L9050, L9056, L9060, L9070, L9071, L9080, L9082, L9090/91/92/93/94/95*)
09-718 Latch x aux latch (L9076, L9077)
09-670 Latch x deadbolt (L9440, L9444, L9456, L9457, L9465, L9466, L9473, L9496)
09-671 Deadbolt (L9460, L9462, L9463, L9464)
09-672 Latch x aux latch x deadbolt (L9453, L9458, L9480, L9485, L9486, L9492/93/94/95)
*For L9090/91/92/93/94/95 with DPS use armor 09-666 (1-1/4" wide) or 09-670 ( 1-1/16 wide)
Ordering instructions: Specify on order only if requesting other than default.
10-072
L9000 Standard
10-073
L9000 Deadbolt Standard XL11-820 XL11-821
10-079
L400 Deadbolt Standard 10-078
Strikes, L9000
Specify Description Lock Price
Adjustment
Strikes, L9000 Series
10-072 1 1/4" x 4 7/8" square corner strike + box, 1 3/16" lip length, standard L9000 strike N/C
10-072 xx 1 1/4" x 4 7/8" square corner strike + box; specify lip length (xx) as 7/8", 1" or 1-1/2"
10-072 xx 1 1/4" x 4 7/8" square corner strike + box; specify lip length (xx) as 1-3/4" or 2" $28.50
10-073 Deadbolt lock strike, standard for L9460, L9462, L9463 and L9464 N/C
10-075 1/2" rabbeted strike 98.50
37-015 Doorframestrikereinforcer(nishnotapplicable) N/C
XL11-8206One hole strike for latching functions, RH & LHR doors 12.20
XL11-8216One hole strike for latching functions, LH & RHR doors
Strikes, L400 Series
10-078 1-1/4" x 4-7/8" square corner strike + box N/C
10-079 1-1/8" x 3-1/2" square corner strike + box, ANSI 115.5 prep, standard L400 strike
Ordering instructions: Specify on order only if requesting other than default.
57
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Non-Keyed Locks Keyed Locks
SCHLAGE ANSI SCHLAGE ANSI
ND10S F75 Passage Latch
Both levers always unlocked.
Inside lever is always free for
immediate egress. Also available with Request
to Exit (RX) function.
ND50PD F82 Entrance/Ofce Lock
Push-button locking. Push-button
locks outside lever until unlocked with key or
by turning inside lever. Inside lever is always
free for immediate egress.
ND40S F76 Bath/Bedroom Privacy Lock
Push-button locking. Can be opened
from outside with small screwdriver.
Turning inside lever or closing door
releases button. Inside lever is always free for
immediate egress.
ND53PD F109 Entrance Lock
Turn/push-button locking; pushing and
turning button locks outside lever, requiring
use of key until button is manually unlocked.
Push-button locking; pushing button locks
outside lever until unlocked by key or by
turning inside lever. Inside lever is always free
for immediate egress.
ND170 Single Dummy Trim
Dummy trim for one side of door.
Used for door pull or as matching
inactive trim.
ND80PD F86 Storeroom Lock
Outsideleverxed.Entrancebykeyonly.
Inside lever always unlocked for
immediate egress. Also available with Request
to Exit (RX) function.
ND80PDEL Electrically Locked (Fail Safe)
Outside lever continuously locked
electrically. Unlocked by key outside
or by switch or power failure.
Auxiliary latch deadlocks latchbolt
when door is closed. Inside lever always
unlocked for immediate egress. Also available
with Request to Exit (RX) function.
ND80PDEU Electrically Unlocked (Fail Secure)
Outside lever continuously locked
until unlocked by key or electric
current. Auxiliary latch deadlocks
latchbolt when door is closed. Inside lever
always unlocked for immediate egress. Also
available with Request to Exit (RX) function.
ND Levers • Functions
ANSI/BHMA Certied A156.2-2011, Series 4000, Grade 1, UL Listed for 3-hour re door.
58
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Strikes
ANSI Strike, 10-025 T Strike, 10-013
Square corner, T-strike, deep box,
re door latch, 10-016
Athens (ATH) Latitude (LAT) Sparta (SPA)Longitude (LON) Rhodes (RHO) Broadway (BRW) Boardwalk (BRK)
ND Levers • Complete Locks
Roses
Inside/Outside Rose, 03-042 RHO
Size: 3 7/16" dia.
Latches
Deadlatch, 13-247 Springlatch, 13-248 Anti-Friction Fire Door Deadlatch, 14-042 Backset Extension Link, 43-005
Note: tactile warning and additional lever designs are available; consult your Allegion representative for details
59
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
ND Levers • Complete Locks
ND Levers • Options
Function Decription
Designs and Finishes PRIMARY CYLINDER ADJUSTMENTS
AVAILABLE LEVERS
AVAILABLE FINISHES
ATH RHO SPA BRW BRK LAT LON
626 619 622
625 643e
Keyless LD
CD
RD
TD* JD BD
BDC GD HD*
ND10S Passage 398 410
ND40S Privacy 458 470 ATH LAT RHO SPA BRW LON BRK
ND170 Single dummy 171 177
Keyed, Single Cylinder
LD
CD
RD
TD* JD BD
BDC GD HD
ND50PD Entrance/Ofce
543 555
-58 35 -32 N/C 77 40
ND53PD Entrance
ND80PD Storeroom
ND80PD EL/
EU
Electrically locked or unlocked 727 739
ND96PD EL/
EU
Vandlgard® Electrically locked or
unlocked 798 810
* Temporary cores (TD and HD options) require non-refundable core handling charge (50-231) of $9.50 and will be added to the price of the lock.
AllelectriedfunctionsarecompatiblewiththeAllegionConnectharnesses.Foradditionaloptions,includingcompetitivecores,pleaseseetheSchlageMechanicalPriceBook
Latches
Part Number Backset - Description Lock Adjustment
Spring Latch*
13-248 2 3/4" - Square corner, 1-1/8" x 2-1/4" N/C
Deadlatch*
14-047 2 3/8" - Square corner, 1-1/8" x 2-1/4" N/C
14-048 2 3/8" - Square corner, 1 x 2-1/4" N/C
13-247 2 3/4" - Square corner, 1-1/8" x 2-1/4" N/C
* All latch extensions require reinforcement when used in hollow metal door applications
Non-Standard Door Thickness*
Description Specify Lock Adjustment
1-3/8" thick doors - 2 chassis spacers
(XN12-012) required; see ND-12
Door thickness and how door is extended.
Example: 3", EO
+54.10
* IfnotspeciedorderswilldefaulttoEE;RXandCompetitorCoresoptionsneedtobeorderedviaRFQ
Strikes
Part Number Lip Length - Description Lock Adjustment
10-013 1-1/8" - Square corner, T-strike, box, 1-1/8" x 2-3/4" N/C
1-1/2" - Square corner, T-strike, box, 1-1/8" x 2-3/4" +7.20
10-016 1-1/8"-Squarecorner,T-strike,deepbox,redoorlatch N/C
10-025
1-3/16" - ANSI, no box, 1-1/4" x 4-7/8" N/C
1-3/8" - ANSI, no box, 1-1/4" x 4-7/8" +13.20
1-1/2" - ANSI, no box, 1-1/4" x 4-7/8" +13.20
K510-066 BoxforANSIstrike,mustbespecied N/C
Shadeditemsarestandardcomponentsandarefurnishedwithlocksunlessotherwisespecied.
60
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Non-Keyed Locks Keyed Locks
SCHLAGE ANSI SCHLAGE ANSI
AL10S F75 Passage Latch
Both levers always unlocked.
AL50PD F82 Entrance/Ofce Lock
Push-button locking. Push-button
locks outside lever until unlocked
with key or by rotating inside lever.
AL40S F76 Bath/Bedroom Privacy Lock
Push-button locking. Can be unlocked from
outside with small screwdriver, not included.
Turning inside lever or closing door releases
button.
AL53PD F109 Entrance Lock
Turn/push-button locking; pushing
and turning button locks outside lever
requiring use of key until button is
manually unlocked. Push-button
locking; pushing button locks outside
lever until unlocked by key or by
turning inside lever.
AL170 Single Dummy Trim
Dummy trim for one side of door.
Used for door pull or as matching
inactive trim.
AL70PD F84 Classroom Lock
Outside lever locked and unlocked by
key. Inside lever always unlocked.
AL80PD F86 Storeroom Lock
Outsideleverxed.Entrancebykey
only. Inside lever always unlocked.
AL • Functions
ANSI/BHMA Certied A156.2-2011, Series 4000, Grade 2, UL Listed for 3-hour re door.
61
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Jupiter (JUP) Neptune (NEP) Omega (OME) Saturn (SAT)
AL • Complete Locks
Roses
Inside/Outside Rose - Rhodes
Levers: JUP, NEP, SAT
Size: 3-7/16" dia.
Inside/Outside Rose - Omega
Levers: OME
Size: 3-7/16" dia.
Strikes
10-001
10-025
Standard 10-027 10-058
Latches
11-068 11-088
11-096
Standard 11-104 11-116
62
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Function Decription
Designs and Finishes PRIMARY CYLINDER ADJUSTMENTS
AVAILABLE LEVERS
AVAILABLE FINISHES
JUP NEP OME SAT
626 619 622
625 643e
Keyless LD RD
TD*JD BD
BDC GD HD*
AL10S Passage 175 187
AL40S Privacy 199 211 ALL JUP NEP SAT
AL170 Single dummy 101 107
Keyed, Single Cylinder LD
CD RD
TD JD BD
BDC GD HD
AL50PD Entrance/Ofce
254 266 -58 35 -32 N/C 77 40
AL53PD Entrance
AL70PD Classroom
AL80PD Storeroom
* Temporary cores (TD and HD options) require non-refundable core handling charge (50-231) of $9.50 and will be added to the price of the lock.
AL • Complete Locks
Latches
Part Number Backset - Hsg Dia - Description Lock Adjustment
Spring Latch
11-068 2-3/8" - 7/8" - Square corner, 1" x 2-1/4"
N/C
11-069 2-3/8" - 7/8" - 1/4" Radius round corner, 1" x 2-1/4"
11-111 2-3/4" - 7/8" - Square corner, 1" x 2 1/4"
11-112 2 3/4" - 7/8" - 1/4" Radius round corner, 1" x 2-/4"
11-116 2-3/4" - 1" - Square corner, 1-1/8" x 2-1/4"
Deadlatch
11-085 2-3/8" - 7/8" - Square corner, 1" x 2-1/4"
N/C
11-088 2-3/8" - 7/8" - 1/4" Radius round corner, 1" x 2-1/4"
11-091 2-3/4" - 7/8" - Square corner, 1" x 2-1/4"
11-092 2-3/4" - 7/8" - 1/4" Radius round corner, 1" x 2-1/4"
11-096 2-3/4" - 1" - Square corner, 1 1/8" x 2 1/4"
Strikes
Part Number Lip Length - Description Lock Adjustment
10-001
1-1/8" - Square corner, T-strike, box, 1-1/8" x 2-3/4" N/C
1" - Square corner, T-strike, box, 1-1/8" x 2-3/4"
+13.50
1-1/4" - Square corner, T-strike, box, 1-1/8" x 2-3/4"
1-1/2" - Square corner, T-strike, box, 1-1/8" x 2-3/4"
1-3/4" - Square corner, T-strike, box, 1-1/8" x 2-3/4"
2" - Square corner, T-strike, box, 1-1/8" x 2-3/4"
10-004 1-1/8" - 1/4" Radius round corner, T-strike, box, 1-1/8" x 2-3/4" N/C
10-025
1-3/16" - ANSI, no box, 1-1/4" x 4-7/8" N/C
1-3/8" - ANSI, no box, 1-1/4" x 4-7/8" +14.30
1-1/2" - ANSI, no box, 1-1/4" x 4-7/8"
10-026 1-1/8" - Square corner, full lip, no box, 1-5/8" x 2-1/4"
N/C
10-027 1-1/8" - 1/4" Radius round corner, full lip, no box, 1 5/8" x 2 1/4"
10-058 Circular,adjustable,1-3/4"diameter-605and626nishesonly
K510-066 BoxforANSIstrike,mustbespecied
Shadeditemsarestandardcomponentsandarefurnishedwithlocksunlessotherwisespecied.
63
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
MA Series • Introduction
Product Identification
MA 501 P D
Latch Suffix
D = Deadlatch
Cylinder Suffix
B = Less SFIC
BB = With SFIC Core (Best)
BDC = Disp. Const. Core
G = With SFIC Core (Falcon)
H = With SFIC Keyed Const.
Core
L = Less 6-Pin Cylinder
P = 6-Pin Cylinder pinned
to 5 chambers
P6 = 6-Pin Cylinder pinned
to 6 chambers
P7 = 7-Pin Cylinder
to 7 chambers
Function
See 31
Lock Series
SFIC = Small Format (Best® Style) Interchangeable Core
Finish Codes and Descriptions
Code Description
619 (US15) Satin Nickel
622 (US19) Matte Black
625 (US26) Bright Chrome
626 (US26D) Satin Chrome
643E (US11) Aged Bronze
Standard Features - Furnished unless otherwise specified
Certification ANSI A156.13, Series 1000, Grade 1 Operation and Security, UL Listed for 3-Hour fire door
with SFIC Interchangeable Core Cylinders: Grade 3 Security
Latch 2 piece stainless steel anti-friction bolt 3/4" projection.
Strike 1-1/4" x 4-7/8", ANSI, Square corner, with dust box
Cylinder 6-Pin, Solid brass, Keyed 5-Pin, Falcon G keyway, Keyed different (KD)
Door Range 1-3/4" - 1-7/8" standard
Keys Two, Nickel silver cut keys per lock, Falcon G keyway
64 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
MA Series • Functions
ANSI A156.13 Series 1000 Grade 1 Operation
Mortise Mortise
FALCON ANSI FALCON ANSI
MA101 F01 Passage/Closet Latchset
Latchbolt retracted by knob/lever from
either side at all times. Inside knob/lever
is always free for immediate egress.
MA561 F05 Classroom Lock
Latchbolt operated by knob/lever from either
side except when outside knob/lever is locked
by key. When outside knob/lever is locked,
latchbolt is retracted by key from outside or
by operating inside knob/lever. Auxiliary latch
deadlocks latchbolt when door is closed. Inside
knob/lever is always free for immediate egress.
MA301 F02 Privacy Lock
Latch bolt operated by knobs/levers
either side, dead bolt operated by turn
from inside or by emergency release
outside.
MA441 F32 Classroom Security Lock
Latch bolt operated by knob/lever from
either side except when outside knob/
lever is locked from inside or outside by
key. When outside knob/lever is locked,
latch bolt is retracted by key from inside
or outside or by operating inside knob/
lever. Auxiliary dead latch. Inside knob/
lever is always free for immediate egress.
MA571 F13 Dormitory or Exit Lock
Latch bolt operated by knob/lever from either
side. Dead bolt projected by key from outside
and turn from inside. Operating inside knob/lever
retracts both bolts and unlocks outside. Inside
knob/lever is always free for immediate egress.
MA521 F04 Entry/Office Lock
Latch bolt operated by knob/lever from
either side except when outside knob/
lever is made inoperative by buttons
in face. When outside knob/lever is
locked, latch bolt is retracted by key from
outside or by operating inside knob/
lever. Auxiliary dead latch. Inside knob/
lever is always free for immediate egress.
MA581 F07 Storeroom Lock
Latch bolt operated by key from outside or by
operating inside knob/lever. Outside knob/lever
is always inoperative. Auxiliary dead latch. Inside
knob/lever is always free for immediate egress.
MA531 F20 Apartment Corridor Door Lock
Latch bolt operated by knob/lever from
either side, except when outside knob/
lever is made inoperative by buttons in
face. Dead bolt operated by key outside
or turn inside. Key outside operates
both bolts. Operating inside knob/lever
retracts both bolts and outside remains
locked. Latch bolt is deadlocked when
outside knob/lever is made inoperative
or when the dead bolt is projected. When
dead bolt is retracted, knob/lever is
unlocked by buttons in face. Inside knob/
lever is always free for immediate egress.
65
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
* Caution: Double cylinder locks on residences and any door, in any structure, which is used for egress are a life safety hazard in times of emergency and their use
is not recommended. Installation should be in accordance with existing codes only.
Grade 1 Mortise Locks with Cast/Forged or Heavy Wrought Trim
ANSI-A156.13, SERIES 1000, GRADE 1
MA-Series • Complete Locks
AG (Avalon-Gala) DG (Dane-Gala) LTG (Latitude-Gala)
QG (Quantum-Gala) BRG (Broadyway-Gala)
Note: 1) Specify 12 or 24VDC. Default is 12V.
PowersupplyPS902willbesufcienttooperateanindividuallockformultiplelockinstallation-seePowerSupplysection.
MA Lever/Rose Styles
Function Description
Designs and Finishes
DG, AG, QG, LG, BG
626 643E 619 622 625 630
Single Cylinder Functions
MA521P Entry/Ofce
$524.00 $536.00
MA561P Classroom
MA571P Dormitory Exit
MA581P Storeroom
MA531P Apartment Corridor 540.00 552.00
Double Cylinder Functions
MA441P Classroom Security 578.00 590.00
CAUTION: Double cylinder locks on residences and any door in any structure which is used for egress are a life safety hazard in times of emergency and their use is not recommended.
Installation should be in accordance with existing codes only.
Non-Keyed Functions
MA101 Passage $408.00 $420.00
MA301 Privacy 475.00 487.00
66 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Grade 1 Mortise Locks with Cast/Forged or Heavy
Wrought Trim ANSI-A156.13, SERIES 1000, GRADE 1
MA-Series • Complete Locks
Note: 1) Specify 12 or 24VDC. Default is 12V.
PowersupplyPS902willbesufcienttooperateanindividuallockformultiplelockinstallation-seePowerSupplysection.
AN (Avalon-Napa) DN (Dane-Napa) QN (Quantum-Napa)
MA Lever Escutcheon Styles
Function Description
Designs and Finishes
DG, AG, QG, LG, BG
626 643E 619 622 625 630
Single Cylinder Functions
MA521P Entry/Ofce
$565.00 $577.00
MA561P Classroom
MA571P Dormitory Exit
MA581P Storeroom
MA531P Apartment Corridor 574.00 586.00
Double Cylinder Functions
MA441P Classroom Security $621.00 $633.00
CAUTION: Double cylinder locks on residences and any door in any structure which is used for egress are a life safety hazard in times of emergency and their use is not recommended.
Installation should be in accordance with existing codes only.
Non-Keyed Functions
MA101 Passage $443.00 $455.00
MA301 Privacy 510.00 522.00
LTN (Latitude-Napa) BRN (Broadyway-Napa)
67
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
T Series • Introduction
Finish Codes and Descriptions
Code Description
619 (US15) Satin Nickel
622 (US19) Matte Black
625 (US26) Bright Chrome
626 (US26D) Satin Chrome
643E (US11) Aged Bronze
Standard Features - Furnished unless otherwise specified
Certification ANSI A156.2, Series 4000, Grade 1, UL Listed for 3-Hour fire door
Latch 1-1/8" x 2-1/4", Square corner faceplate, 1" housing diameter, 1/2" throw, 2-3/4" backset
Strike 1-1/4" x 4-7/8", ANSI, Square corner, no box
Cylinder 6-Pin, Solid brass, Keyed 5-Pin, Falcon G keyway, Keyed different (KD)
Door Range 1-3/4" - 2-1/8" standard
Keys Two, Nickel silver cut keys per lock, Falcon G keyway
Product Identification
T 501 P D
Latch Suffix
D = Deadlatch
S = Springlatch
Cylinder Suffix
B = Less SFIC
BB = With SFIC Core (Best)
BDC = Disp. Const. Core
G = With SFIC Core (Falcon)
H = With Keyed Const. Core
J = Less FSIC (designate
cylinder manufacturer)
L6 = Less 6-Pin Cylinder
L7 = Less 7-Pin Cylinder
P = 6-Pin Cylinder pinned
to 5 chambers
P6 = 6-Pin Cylinder pinned
to 6 chambers
P7 = 7-Pin Cylinder pinned
to 7 chambers
CP6 = 6-Pin Cylinder
Schlage C
Function
See 59
Lock Series
SFIC = Small Format (Best® Style) Interchangeable Core
68 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Key-In-Lever Locks
FALCON ANSI
T561 F84 Classroom Lock
Deadlocking latch bolt by levers. Outside lever
is locked by key in outside lever. Inside lever is
always free.
T581 F86 Storeroom Lock
Deadlocking latch bolt by lever inside or key
outside. Outside lever is inoperable. Inside lever
always free.
T12 Dummy Trim
Single Trim-surface mounted rigid lever.
ANSI A156.2 Series 4000 Grade 1
Key-In-Lever Locks
FALCON ANSI
T101 F75 Passage/Closet Latchset
Latch bolt by levers at all times.
T301 F76 Privacy Lock
Latch bolt by levers. Outside lever locked by
push button in inside lever. Rotating inside
lever or closing door releases push button.
Emergency release in outside lever unlocks
door.
T381 F88 Classroom Security Lock
Latchbolt operated by lever from either
side except when key from inside lever locks
outside lever. When outside lever is locked,
latchbolt retracted by key in outside lever or
by turning inside lever.
T511 F109 Entry/Office Lock
Turn/push button locking. Pushing and
turning button locks outside lever requiring
use of key until button is manually unlocked.
Push button locking. Pushing button locks
outside lever until unlocked by key or by
rotating inside lever. Inside lever always free.
Deadlocking latch bolt.
* Caution: Double cylinder locks on residences and any door, in any structure, which is used for egress are a life safety hazard in times of emergency and their use is
not recommended. Installation should be in accordance with existing codes only.
T Series • Functions
69
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
A (Avalon-Gala) LAT (Latitude-Gala) D (Dane-Gala) BRW (Broadway-Gala) Q (Quantum-Gala)
Key-In-Lever
Function Description
Designs and Finishes
D, A, Q, LAT, BRW
626 643E 619 622 625
Single Cylinder Functions
T351PD Closet
$392.00 $404.00
T511PD Entry/Ofce
T561PD Classroom
T581PD Storeroom
Double Cylinder Functions
T381PD Exit Security $459.00 $471.00
CAUTION: Double cylinder locks on residences and any door in any structure which is used for egress are a life safety hazard in times of emergency
and their use is not recommended. Installation should be in accordance with existing codes only.
Non-Keyed Functions
T101S Passage $281.00 $293.00
T301S Privacy
Dummy Trim
T12 Half Dummy $133.00 $145.00
Grade 1 Extra Heavy Duty Cylindrical Locksets
ANSI-A156.2, SERIES 4000, GRADE 1
T Series • Complete Locks
Notes:1)24Visstandard.PowersupplyPS902willbesufcienttooperateanindividuallockformultiplelockinstallation-seePowerSupplysection.
70 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
W Series • Introduction
Finish Codes and Descriptions
Code Description
619 (US15) Satin Nickel
622 (US19) Matte Black
625 (US26) Bright Chrome
626 (US26D) Satin Chrome
643E (US11) Aged Bronze
Standard Features-Furnishedunlessotherwisespecied
Certication  ANSIA156.2,Series4000,Grade2,ULListedfor3-Hourredoor
Latch 1-1/8" x 2-1/4", Square corner faceplate, 1" housing diameter, 1/2" throw, 2-3/4" backset
Strike 1-1/4" x 4-7/8", ANSI, Square corner, no box
Cylinder 6-Pin, Solid brass, keyed 5-pin, Falcon G keyway, Keyed different (KD)
Door Range 1-3/8" - 1-3/4" standard
Keys Two, Nickel silver cut keys per lock, Falcon G keyway
Product Identication
W 501 P D
Latch Sufx
D = Deadlatch
S = Springlatch
Cylinder Sufx
B = Less SFIC
BB = With SFIC Core (Best)
BDC = Disp. Const. Core
G = With SFIC Core (Falcon)
H = With Keyed Const. Core
L = Less 6-Pin Cylinder
P = 6-Pin Cylinder pinned
to 5 chambers
P6 = 6-Pin Cylinder pinned
to 6 chambers
CP6 = 6-Pin Cylinder
Schlage C
Function
See 105
Lock Series
SFIC = Small Format (Best® Style) Interchangeable Core
71
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Key-In-Lever Locks
FALCON ANSI &
Function
W561 F84 Classroom Lock
Deadlocking latch bolt by levers. Outside lever
is locked by key in outside lever. Inside lever is
always free.
W581 F86 Storeroom Lock
Deadlocking latch bolt by lever inside or key
outside. Outside lever is always locked. Inside
lever is always free.
W12/W18*Dummy Trim
Single or double available.
Single (W12)
Double (W18)
ANSI A156.2, Series 4000 Grade 2
Key-In-Lever Locks
FALCON ANSI &
Function
W101 F75 Passage Latchset
Latch bolt by levers at all times.
W161 F111 Communicating/Exit Latch
Deadlocking latch bolt by inside lever.
Non-removable blank plate outside.
W301 F76 Privacy Lock
Latch bolt by levers. Outside lever is locked
by push button in inside lever. Rotating inside
lever or closing door release push button and
frees outside lever. Inside lever is always free.
Emergency release in outside lever unlocks
door.
W511 F109 Entry/Office Lock
Deadlocking latch bolt by levers. Turn/push
button locking. Pushing and turning button
locks outside lever, requiring use of a key for
unlocking the door until button is manually
unlocked. Pushing button locks outside lever
until unlocked by key or by rotating inside
lever. Inside lever is always free.
W Series • Functions
* Functions are not available for small rose option
72 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
A (Avalon) LAT (Latitude) D (Dane) BRW (Broadway) Q (Quantum)
Grade 1 Extra Heavy Duty Cylindrical Locksets
ANSI-A156.2, SERIES 4000, GRADE 1
W Series • Complete Locks
Key-In-Lever Large Rose 3-3/8" Rose
Function Description
Designs and Finishes
D, A, Q, LAT, BRW
626 643E 619 622 625
Single Cylinder Functions
W501PD Entry
$104.00 $116.00
W511PD Entry/Ofce
W561PD Classroom
W571PD Dormitory/Corridor
W581PD Storeroom
W711PD Apartment Entry
Non-Keyed Functions
W101S Passage $95.00 $107.00
W161D Communicating/Exit
96.00 108.00 W201D Patio
W301S Privacy
Dummy Trim
W12 Half Dummy $55.00 $61.00
W18 Two Sided Dummy 110.00 122.00
ELI (Elite) HAN (Hana)
Key-In-Knob
Function Description
Designs and Finishes
E H
626 605 606 613 625
Single Cylinder Functions
W511PD Entry/Ofce
$60.00 $72.00
W561PD Classroom
W571PD Corridor
W581PD Storeroom
W711PD Apartment Entry
Non-Keyed Functions
W101S Passage $50.00 $62.00
W301S Privacy 51.00 63.00
Dummy Trim
W12 Half Dummy $37.00 $43.00
Note: 2) Not available with a small rose. Small rose option is for levers only.
Note: 1) New Finishes (643E, 619, 622) & New Levers (AVA, LAT, LON, BRW, BRK) are not available on W18 function.
73
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
SRD (Dane) SRQ (Quantum) SRBR (Broadway) SRA (Avalon) SRLA (Latitude)
Small Rose 2-9/16" (65mm)
Function Description
Designs and Finishes
SRD, SRA, SRQ, SRLAT, SRBR
626 643E 619 622 625
Single Cylinder Functions
W511 Entry/Ofce
$125.00 $137.00 W561 Classroom
W581 Storeroom
Non-Keyed Functions
W101 Passage $102.00 $114.00
W161 Communicating/Exit 104.00 116.00
W301 Privacy
Dummy Trim
W12 Single Dummy $59.00 $65.00
How to Order the Small Rose Option
Small Rose 2-9/16" (65mm)
Function
W511
Cylinder
PD
Trim
SRD
Finish
626
W-Series Small Rose • Levers Complete Locks
74 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
D200 Series • Introduction
Finish Codes and Descriptions
Code Description
619 (US15) Satin Nickel
622 (US19) Matte Black
625 (US26) Bright Chrome
626 (US26D) Satin Chrome
643E (US11) Aged Bronze
Standard Features - Furnished unless otherwise specified
Certification BHMA - ANSI A156.5, 2001, Grade 2 auxiliary lock, Available UL Listed for 3-Hour fire door
Deadbolt 1-1/8" x 2-1/4", Square corner faceplate, 1" housing diameter, 1" throw
Strike 1-1/8" x 2-3/4", lipless, with box
Cylinder 6-Pin, Solid brass, Keyed 5-Pin, Falcon G keyway, Keyed different (KD)
Door Range 1-3/8" - 2-1/4" standard cylinder or thumbturn only; 1-5/8" - 2" interchangeable core cylinder
Keys Two, Nickel silver cut keys per lock, Falcon G keyway
Reinforcement Metal dust box reinforcer with three - 3" screws
Trim Ring 1" Wrought brass or bronze, reinforced with security insert
Backset 2-3/8" and 2-3/4" adjustable
Product Identification
D 211 P F
UL Listing Suffix
F = UL Listed
Cylinder Suffix
B = Less SFIC
BDC = Disp. Const. Core
BB = With SFIC Core (Best)
G = With SFIC Core (Falcon)
H = With Keyed Const.
Core
L = Less 6-Pin Cylinder
P = 6-Pin Cylinder pinned
to 5 chambers
P6 = 6-Pin Cylinder pinned
to 6 chambers
P7 = 7-Pin Cylinder pinned
to 7 chambers
Function
See 115
Lock Series
SFIC = Small Format (Best® Style) Interchangeable Core
75
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
BHMA / ANSI A156.5, 2001, Grade 2
Bored Deadbolt Locks
FALCON ANSI &
Function
D261M E01112 Thumbturn, Inside x Rose
Deadbolt thrown or retracted by turn unit only.
Outside blank rose. Bolt automatically
deadlocks when fully thrown.
D271 Thumbturn x Occupancy Indicator
Deadbolt thrown or retracted by turn unit only.
Occupancy indicator on outside (reads either
in use or vacant with color coding). Bolt
automatically
deadlocks when fully thrown.
Note: This function is not UL Listed.
* Caution: Double cylinder locks on residences and any door, in any structure, which is used for egress are a life safety hazard in times of emergency and their use is not recommended.
Installation should be in accordance with existing codes only.
BHMA / ANSI A156.5, 2001, Grade 2
Bored Deadbolt Locks
FALCON ANSI &
Function
D211P E0172 Classroom Function
Deadbolt thrown or retracted by key from
outside. Inside turn will only retract bolt. Bolt
automatically deadlocks when fully thrown.
D241P E0152 Single Cylinder x Turn
Deadbolt thrown or retracted by key or by turn.
Bolt automatically deadlocks when fully
thrown.
D261 E0192 Thumbturn, Inside Only
Deadbolt thrown or retracted by turn unit only.
No outside trim. Bolt automatically deadlocks
when fully thrown.
D200 Series • Functions
76 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
D200-Series • Complete Locks
Notes: 1) Splitnishesarepricedatthehighestnishprice.
2) D271 Occupancy Indicator deadbolt is shipped with emergency key (61-509) and instructions.
3) ‘F’SufxmustbeaddedforULproduct
Outside Cylinder Trim Rose and Turn
Inside Cylinder Trim
D-200 Series
Function Description
Designs and Finishes
626 619 622 613 625 643e
Keyless
D261 Turn, Inside Only $50.00 $56.00
D261M Turn , Inside x Rose
D271 Turn, Inside x Occupancy Indicator 51.00 57.00
Single Cylinder Functions
D211P Classroom Function $68.00 $74.00
D241P Single Cylinder x Turn 65.00 71.00
77
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
H2 Series • Introduction
Finish Codes and Descriptions
Code Description
619 (US15) Satin Nickel
622 (US19) Matte Black
625 (US26) Bright Chrome
626 (US26D) Satin Chrome
643E (US11) Aged Bronze
Standard Features
Certification: ANSI/BHMA Certified A156.12-2013, Grade 2, UL listed for 3-hour fire door
With SFIC interchangable core cylinders: Grade 3 Security
Deadbolt: 1 X 2-1/4", dual option faceplate, (square corner standard, round corner included in package),
1" housing diameter, 1" throw
Latch 1" x 2-1/4" dual option faceplate (square corner standard, round corner included in package).
1" edge bore required
Strikes: 1-1/8" X 2-3/4", Square corner (deadbolt) and 1-5/8" X 2-1/4", Square corner, T-strike, box,
1 1/8" x 2 3/4" (Deadlatch)
Backset: Adjustable backset, fits 2-3/8" or 2-3/4"
Cylinders: 6-pin, solid brass, keyed 6-pin, G keyway, keyed different (KD)
Door Range: 1-3/4" to 2" standard (1-3/8" available, must be specified)
Keys: Nickel silver cut keys, 6-pin, G keyway
Center to Center: Fits 4" or 5 1/2" (factory default) center to center door preps
Product Identification
H2 2XX P D
Latch Suffix
D = Deadlatch
Cylinder Suffix
P = 6-Pin Cylinder pinned to
5 Chambers
L = Less 6-Pin Cylinder(s)
B = Less SFIC
BDC = Disposable SFIC
G = Falcon Patented SFIC
H = Construction Core
BB = Best SFIC
P6 = 6-Pin Cylinder pinned
to 6 Chambers
CP6 = Schlage C 6-Pin
Cylinder
Function
101 = Entry Lock
Lock Series
78 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
BHMA / ANSI A156.5, 2001, Grade 2
Bored Deadbolt Locks
FALCON ANSI
H2101 F95 Entrance Lock
Deadbolt operated by key from outside or by turn unit from inside. Bolt automatically deadlocks when
fully thrown. Latch retracted by lever from either side. Turning inside lever retracts deadbolt and latch
simultaneously for immediate exit.
H2 Series • Functions
H2 Series • Complete Locks
Q (Quantum) BRW (Broadway)
LON (Longitude)
D (Dane) LAT (Latitude)
BRK (Boardwalk)
A (Avalon)
Function Description Design and Finishes
Keyed, Single Cylinder
D, A, Q, LAT, LON, BRW, BRK
626 643E 619 622 625
H2101 Entrance Lock 270 282
Specify both outside and inside designs if split.
79
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Cylinders
Finish Codes and Descriptions
Code Description
619 (US15) Satin Nickel
622 (US19) Matte Black
626 (US26D) Satin Chrome
643E (US11) Aged Bronze
Standard Features - Furnished unless otherwise specified
Standard Cylinder Solid Brass housings and plugs. Standard Keyway is Falcon G keyway.
Keyed different furnished unless otherwise specified (additional charges may apply,
See page 140 for keying charges) with 2 nickel silver keys. Mortise cylinder standard lengths
are 1-1/8" for conventional cylinders and 1-3/8" for small format interchangeable core housings.
SFIC Furnished in A keyway unless otherwise specified. Combinated cores are provided with 2 keys.
Restricted Keyways Falcon has a varied selection of restricted keyways for conventional and SFIC cylinders based
on geographic restrictions for usage. Minimum cylinder purchase required. See your Security and Safety
Consultant for more information or availability.
80 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Conventional Cylinders
Non-IC Products
951
Available in:
619, 622, 626, 643e
985
Available in:
619, 622, 626, 643e
MA and M Series Conventional Rim and Mortise Cylinders
Pins Length Description Number 626 643e 619, 622
5 or 6 1-1/8 Mortise 985 $57.00 $59.00
1-1/4 986
5, 6, or 7 – Rim 951 57.00 59.00
Notes: 1) MA cam (5622-STD) provided.
2) Mortise and rim cylinders are not available in any competitor keyway, except Schlage C.
3) Conventional mortise cylinder with Schlage C keyway are available with 985, 986 and 951.
81
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
All prices are less core. Not available with C997.
IC Products
Small Format Interchangeable Rim and Mortise Core Housings Only
Cat. Number Length Pins Description 626 643e 619, 622, 625
C987 1-3/8" 6 or 7 Mortise $33.00 $35.00
C988 1-1/2" 6 or 7 Mortise
C953 N/A 6 or 7 Rim 35.00 37.00
Notes: 1) All mortise cylinders will be furnished with cam 5622-IC.
2) Whenorderingcylinderswithconstructioncores,includethesufx-7CCAor-6CCAaddedtothepartnumber.i.e.C987-6CCA626fora6pinsmallformatconstructioncoreincluded
withaC987cylinderin626nish
IC Cylinders
Rim
Available in:
619, 622, 626, 643e
Mortise
Available in:
619, 622, 626, 643e
C607
Available in:
605, 606, 613, 625, 622, 626, 643e
Interchangeable Cores
Pricing: Uncombinated cores have no pins, springs or keys. Combinated core prices include master keying.
Finishes: 606 and 626 standard.
Packaging: Uncombinated cores are packed 20 per box.
Keyways: The“A"keywayisstandardforICproductsandwillbesuppliedunlessotherwisespecied.
A, B, C, D, DD, E, F, G, H, J, K, L, M, N, Q, R, TB and TD are equivalent to Best and Arrow IC keyways of the same letter
designations. All other keyways are restricted. Add $10.10 list for all restricted keyways.
Logo: Cores and keys are supplied with the Falcon logo standard.
Combinated cores supplied without logo are furnished with plain (non-embossed) keys.
IC Products
Regular Core (sufx keyway to number)
Uncombinated Combinated
Description 6-Pin 7-Pin Price 6-Pin 7-Pin Price
Standard C646 C647 $32.00 C606 C607
$42.00
Best style capping CB846 CB847 CB806 CB807
No logo C648 C649 32.00 C608 C609
No logo, Best capping CB848 CB849 CB808 CB809
Notes: 1) For restricted keyways add $10.10 per core. See page iv for restricted keyway policies.
2) For temporary construction cores and policy, See page MF-59.
3) For 605, 613 and 625 add $2.80 per core. Minimum 250 pieces.
4) Keyingmustbespeciedoncombinatedcores.
82 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Conventional Keys and Blanks
Non-IC Products
Large BowPlain
(non-embossed)
Standard
Key Blanks
(Specifykeywayandorderinmultiplesof50exceptwherespecied)
Part. Number Description Qty./Wt. Each
KB573 Standard 5-pin 50/1 $2.20
KB577 Standard 6-pin
KB581 Standard 7-pin 35/1 2.50
KB751 Plain 5-pin (non-embossed) 50/1 2.20
KB761 Plain 6-pin (non-embossed)
KB771 Plain 7-pin (non-embossed) 35/1 2.50
KB544 Large bow - 5-pin 25/1 5.00
KB590 Large bow - 6-pin 25/1 5.90
Q330-215 6 Pin Schlage C Blank 1 3.00
Cut Keys
Part. Number Description Each
KB574 Standard 5 Pin
$7.00
KB578 Standard 6 Pin
KB582 Standard 7 Pin
KB794 Plain 5-pin (non-embossed)
KB797 Plain 6-pin (non-embossed)
KB799 Plain 7-pin (non-embossed)
KB545 Large bow - 5-pin (When furnished with lock - 2 keys) additional per lock 7.70
KB545 Large bow - 5-pin
KB591 Large bow - 6-pin (When furnished with lock - 2 keys) additional per lock 9.20
KB591 Large bow - 6-pin
330055 Schlage C - 6 pin 6.90
Q330-276 Schlage Split Key 6-pin 9.20
* Specify key section to key (blank) numbers.
Note: 1) Prices listed for key blanks and cut keys are for E, G and H sections only. For all other key sections add $0.80 list per key to prices shown. Letter of au tho ri za tion required for re strict ed
sections; not available to stock; shipped directly to the end user.
83
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
IC Products
Standard Plain
(non-embossed)
Standard
Key Tip
Best Key
IC Core Key Blanks
Standard Plain Both Sides Price
Standard KB628 KB718 $2.40
Stamped CONTROL KB608 KB744 4.70
IC Core Cut Keys
Standard Plain Both Sides
Price6-Pin 7-Pin 6-Pin 7-pin
Standard KB632-1 KB632-2 KB673-1 KB673-2 $7.00
CONTROL KB609-1 KB609-2 KB778-1 KB778-2 9.10
Notes: 1) Specify keyway
2) Order standard blanks in multiples of 50.
3) Prices for key blanks and/or cut keys are for single key sections only. Key blanks 50 min. Cut keys no minimum quantity
4) For double milled key (e.g. DE, EF, FG) add $3.20 each to prices shown,minimum order quantity of 50 keys.
5) Triple and quadruple milled keys add $3.70 each to price shown, minimum order quantity of 50 keys.
6) Letter of au tho ri za tion required for re strict ed sections; not available to stock; shipped directly to the end user.
Best® Style SFIC Core Key Blanks
Standard Plain Both Sides Price
Standard KB800* KB801* $2.50
* KB 800 & 801 are not available in multi milled keyways.
Best® Style SFIC Core Cut Keys
Standard Plain Both Sides Price
Standard 6-Pin KB807-1 KB809-1 $7.30
Stamped Control 6-Pin KB811-1 KB813-1 9.50
Standard 7-Pin KB807-2 KB809-2 11.10
Standard Control 7-Pin KB811-2 KB813-2 16.90
IC Keys and Key Blanks, Disposable Construction Core
84 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Commercial Mechanical & Electrified Locks - Schlage & Falcon
Keys & Keying Construction Core Program
C607CCA 1408
Construction Core Program
Part Number Description Specify Price
C606CCA Construction core 6-pin Specify"H"sufxwhenorderingwithLocks,Specify
CCA when ordering with Mortise and Rim Cylinders $42.00
C607CCA Construction core 7-pin
KB632-1CCA Cut key for construction core 6-pin 7.30
KB632-2CCA Cut key for construction core 7-pin
KB609-1CCA Cut control key 6-pin (order separately) 9.50
KB609-2CCA Cut control key 7-pin (order separately)
1408 Disposable construction core Specify“BDC”sufxwhenordering 5.20
50-231F Non-refundable handling charge per core 7.10
Notes: 1) Keyedandtemporaryconstructioncoreswillbeinstalledinlocksandcylindersautomaticallyunlessotherwisespeciedonorders.
2) Construction cores for a given project are keyed alike to one of a limited number of combinations nationwide. Different Falcon projects in the same area using the same or different
contractorsmayusethesamekey.Whereahigherdegreeofsecurityisdesired,orderasetofcoresin626nishkeyedaliketoarandomcombination.Specify“KS1.”Suchcoresarenot
returnable to Falcon but may be reused for other projects.
3) Temporary construction cores are an inexpensive alternative to interior keyed construction cores. This temporary is intended for use on interior door applications or where security on-site
is not a concern.
Construction Core Program
Keyed construction cores may be ordered with interchangeable core locks and cylinders. These cores may also be ordered
separately. All keyed construction cores are assessed a non-refundable handling charge (50-231). Standard payment terms apply.
Features:
• 6-pin A keyway.
• 7-pin A keyway.
• Construction cores are a flat black finish on the face. Other colors may be provided. Contact Customer Service for available colors.
• Construction cores are furnished with no keys (NCK). Cut keys must be ordered separately.
• A control key is required to install and remove construction cores. Control keys must be ordered separately.
• Construction cores may be returned for credit in working condition. Credit is issued upon receipt of cores at our factory.
A Return Material Authorization (RMA) must be issued, in order for cores to be returned.
Temporary Construction Core Program (Disposable)
Temporary construction cores may be ordered with interchangeable core locks and cylinders. These cores may also be ordered separately. Standard
payment terms apply.
Features:
 •Convenientlytsboth6&7-pinSFICapplications.
• No keys need to be issued.
• Disposable construction cores are not returnable.
• The disposable core is inserted in the lever or knob and is operated by a thumbturn, which retracts the latch bolt.
85
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Exits - Falcon & VonDuprin
Exits
22 Rim Panic Device
Trim Function Handing Finish Series
3' 4'
List Price
Exit Only - SP28 22-EO-SP28 $461.00 $472.00
Exit Only - SP313 22-EO-SP313 461.00 472.00
22-F Rim Fire Exit Hardware
Trim Function Handing Finish Series
3' 4'
List Price
Exit Only - SP28 22-EO-F SP28 $573.00 $584.00
Exit Only - SP313 22-EO-F-SP313 573.00 584.00
2227 Surface Vertical Rod Panic Device
Trim Function Handing Finish Series Door Height
3' 4'
List Price
Exit Only - SP28 2227-EO-SP28 7' $793.00 $804.00
Exit Only - SP313 2227-EO-SP313 7' 793.00 804.00
2227-F Surface Vertical Rod Fire Exit Hardware
Trim Function Handing Finish Series Door Height
3' 4'
List Price
Exit Only - SP28 2227-EO-F-SP28 7' $1,022.00 $1,033.00
Exit Only - SP313 2227-EO-F-SP313 7' 1,022.00 1,033.00
Von Duprin 22 Series
n UL listed for Panic Exit Hardware
n DevicesareANSIA156.3,2001Grade1Certied
n Twonishesavailable:SP28 = Powder-coated aluminum SP313 = Powder-coated dark bronze
86 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Exits - Falcon & VonDuprin
Trim
22 Series Trim
Series Lever Handing Finish List Price
210-DT - - SP28 $53.00
210-DT - - SP313 53.00
210-NL - - SP28 61.00
210-NL - - SP313 61.00
230-L 06 LHR SP28 235.00
230-L 06 RHR SP28 235.00
230-L 06 LHR SP313 235.00
230-L 06 RHR SP313 235.00
230-NL - - SP28 119.00
230-NL - - SP313 119.00
230-DT - - SP28 108.00
230-DT - - SP313 108.00
Von Duprin Series 22 Trim
n Finishes available:
SP28 = Powder-coated aluminum
SP313 = Powder-coated dark bronze
87
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Exits - Falcon & VonDuprin
Auxiliary Parts
Cylinders
Model No. Description Compatible Trim Series Finish List Price
3215 Mortise 1-1/4" 230L US26D $81.00
3216 Rim Cylinder 210NL, 230NL US26D 81.00
Extension Rods
Model No. Description Finish List Price
ER-22 36" Extension Rod for 2227 SP28 $26.00
ER-22 36" Extension Rod for 2227 SP313 26.00
Sex Bolts
Model No. Description Finish List Price
325 325 Sex Bolt 1/4 - 20 (pkg of 2) $22.00
425 425 Sex Bolt 10-24 (Pkg of 2) 22.00
88 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Exits - Falcon & VonDuprin
Electronics e-Strike
Description Finish Price Each
4211-US32D-12/24VDC-FSA/FSE 630 $176.00
4212-US32D-12/24VDC-FSA/FSE 630 211.00
6111 US32D 24VDC FSE 630 790.00
6112 US32D 24VDC FSE 630 739.00
6210 US32D 24VDC FSE 630 719.00
6210 US32D 12VDC FSE 630 719.00
6210 US32D 24VDC FSE DS 630 898.00
6210 US32D 24VDC FS 630 756.00
6211 FSE (MORT/CYL) 24VDC 630 630 678.00
6211 FSE 12VDC ELEC STRIKE 630 678.00
6211 FSE DS (MORT/CYL) 630 630 857.00
6211 US32D 24VDC FS 630 715.00
6211 US32D 24VDC FSE 630 678.00
6211AL US32D 24VDC FSE 630 704.00
6211WF US32D 24VDC FSE 630 685.00
6212 US32D 24VDC FSE 630 803.00
6223 FSE 24VDC ELEC STRIKE 630 756.00
5100 3FP 689 24VDC 689 228.00
6300 US32D 12/24VDC FSE 630 679.00
6400 US32D 12/24VDC FSE 630 478.00
Electronics e-Strike
89
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Exits - Falcon & VonDuprin
Von Duprin Exit Devices
98 Series
n 3' Devices are priced complete with standard trim and strike(s).
n 4' add $18 list.
Von Duprin 35A Series
n 3' Devices are priced complete with standard trim and strike(s).
n 4' add $18 list.
US26D US26 US15 643E 315
EXIT HARDWARE
98EO Rim Device $1,273.00 $1,482.00 $1,482.00 $1,482.00 $1,917.00
9827EO Surface Vertical Rod Device 1,841.00 2,101.00 2,101.00 2,101.00 2,457.00
9849EO Concealed Vertical Cable Device 1,950.00 2,136.00 2,136.00 2,136.00 2,533.00
FIRE EXIT HARDWARE
98EO-F Rim Device 1,417.00 1,672.00 1,672.00 1,672.00 2,027.00
9827EO-F Surface Vertical Rod Device 2,092.00 2,385.00 2,385.00 2,385.00 2,706.00
9849EO-F Concealed Vertical Cable Device 2,126.00 2,312.00 2,312.00 2,312.00 2,709.00
US26D US26 US15 643E 315
EXIT HARDWARE
35A-EO Rim Device $1,571.00 $1,646.00 $1,646.00 $1,646.00 $1,978.00
3549A-EO Concealed Vertical Cable Device 2,247.00 2,329.00 2,329.00 2,329.00 2,738.00
FIRE EXIT HARDWARE
35A-EO-F Rim Device 1,677.00 1,752.00 1,752.00 1,752.00 2,084.00
3549A-EO-F Concealed Vertical Cable Device 2,352.00 2,434.00 2,434.00 2,434.00 2,843.00
Concealed Vertical Cable (CVC) Reference:
Nominal Door Opening Height
72"-82" 6' - 6'10"
*>82"-96" *>6'10" - 8'
>96" -110" >8' - 9'2"
>110" -120" >9'2"-10'
* Default Door Opning Height. Specify height if other than default.
90 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Exits - Falcon & VonDuprin
Dogging Option
Prex List Add
LD Less Dogging $41.00
Weep Holes
Sufx List Add
WH Drainage (Weep) Holes in Mechanism Case $81.00
3' device will have 4 holes - 6" spacing, 4' device will have 6 holes - 6" spacing
Switches
Prex List Add
RX Request to Exit - available on all 35A and 98 Series Devices $227.00
Electric Latch Retraction
Prex List Add
QEL Quiet Electric Latch Retraction - available on all 35A and 98 Series Devices $887.00
Electric Unlocking List Add
E996
Electric Unlocking of outside E996 Trim - for 98 devices
$562.00Available with L or LBE functions only. Specify handing.
Specify FAIL SECURE (FSE) or FAIL SAFE (FS).
Device Options
Allegion Connect
Sufx List Add
CON Cross-categorysolutionusingcommoninterconnectcomponentsforelectriedoptions.
Available with RX switches, QEL, and E996.
N/C
NOTE: For wire harness options refer to Power Supply and Electronic Component Section.
91
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Exits - Falcon & VonDuprin
Device Accessories
Dummy Touch Bars
n 3' Devices are priced complete with sex bolts.
n 4' add $18 list.
Model No. Description US26D US26 US15 643E 315
350 35A/98 series device dummy touch bar $729.00 $729.00 $729.00 $729.00 $1,324.00
35A Series Trim
Model No. Description US26D US26 US15 643E 315
388 (NL-OP) Night Latch Cylinder Trim $275.00 $275.00 $275.00 $275.00 $275.00
Power Transfer
Model No. Description SP28
EPT10 Ten 24 guage wires 484.00
EPT10 CON Ten 24 guage wires with connectors 494.00
Lever Designs
Model No. Description
Standard 06 Lever Design - furnished standard.
Optional Lever Designs - Latitude (LAT),17, 07
Handing FieldreversibleandfurnishedRHRifnotspecied
98 Series Trim
Specify device type when ordering (example: 996L-R)
Model No. Description Device Type US26D US26 US15 643E SPLBLK
110MD-NL Night Latch Cyl. Assy, MD Dr – $117.00 $119.00 $119.00 $119.00 $119.00
996L Lever R&V 537.00 626.00 626.00 626.00 551.00
996L-BE Lever, Blank Escutcheon R&V 537.00 626.00 626.00 626.00 551.00
996L-NL Lever, Night Latch R&V 418.00 500.00 500.00 500.00 432.00
92
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
24-R Device Series
3' Devices are priced with standard trim and strikes, 4' add $19 list.
Cylinders are not included in the price.
EXIT HARDWARE
Rim Devices
(Includes 299 Strike)
Trim/Control US19* US26D US26 US11* US15*
* 24-R-EO 1244 1291 1405
* 24-R-NL-OP (Supplied as NL less trim) 1244 1291 1405
Delta Trim (handed and eld reversible)
24-R-DT 717DT 1478 1525 1639
24-R-DT 718DT 1496 1543 1657
* 24-R-NL 718NL* 1478 1525 1639
* 24-R-C 718C* 1423 1470 1584
Knob Control (handed and eld reversible)
24-R-K 711K 1523 1570 1684
24-R-K-BE 711K-BE 1523 1570 1684
24-R-K-NL 711K-NL 1523 1570 1684
Dane Lever Control (handed and eld reversible)
* 24-R-L 712L* 1588 1635 1749
* 24-R-L-BE 712L-BE* 1588 1635 1749
* 24-R-L-NL 712L-NL* 1588 1635 1749
* 24-R-L-DT 712L-DT* 1588 1635 1749
*Thesedevicesand712L,712L-BE,712L-NL,712L-DT,718C,718NLtrimsareavailableinUS11,US15andUS19nishes.
24 Series ordered in 313AN will be supplied with trims in SP313.
Handing:TrimsarefurnishedRHRwhenhandingisnotspecied.
24 Rim, comes with dead latching as a standard effective April 3, 2017.
Sex Bolts:
Optional Sex Bolts are recommended for center case mounting when device is used with hollow core wood,
composite or light gauge hollow metal doors. See chart below for quantities and list prices.
Application Sex Bolt 325
(Optional) Sex Bolt 425
(Optional) List Add
Hollow core wood, composite or light gauge hollow metal doors - EO (exit only device) 2 4 66
Hollow core wood, composite or light gauge hollow metal doors - Device with Trim Not Required 4 44
93
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
F-24-R Device Series
3' Devices are priced with standard trim and strikes, 4' add $19 list.
Cylinders are not included in the price.
Sex Bolts:
Sex Bolts are supplied for center case mounting when device is used with wood, composite or non-reinforced hollow metal doors.
Application Sex Bolt 325
(Optional) Sex Bolt 425
(Optional)
Wood, composite or non-reinforced hollow metal doors - EO (exit only device) 2 4
Wood, composite or non-reinforced hollow metal doors - Device with Trim Not Required 4
EXIT HARDWARE
Rim Devices
(Includes 299F Strike)
Trim/Control US19* US26D US26 US11* US15*
* F-24-R-EO 1446 1493 1607
* F-24-R-NL-OP (Supplied as NL less trim) 1446 1493 1607
Delta Trim (handed and eld reversible)
F-24-R-DT 717DT 1680 1727 1841
F-24-R-DT 718DT 1698 1745 1859
* F-24-R-NL 718NL* 1680 1727 1841
* F-24-R-C 718C* 1625 1672 1786
Knob Control (handed and eld reversible)
F-24-R-K 711K 1725 1772 1886
F-24-R-K-BE 711K-BE 1725 1772 1886
F-24-R-K-NL 711K-NL 1725 1772 1886
Dane Lever Control (handed and eld reversible)
* F-24-R-L 712L* 1790 1837 1951
* F-24-R-L-BE 712L-BE* 1790 1837 1951
* F-24-R-L-NL 712L-NL* 1790 1837 1951
* F-24-R-L-DT 712L-DT* 1790 1837 1951
*Thesedevicesand712L,712L-BE,712L-NL,712L-DT,718C,718NLtrimsareavailableinUS11,US15andUS19nishes.
24 Series ordered in 313AN will be supplied with trims in SP313.
Handing:TrimsarefurnishedRHRwhenhandingisnotspecied.
94
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
EXIT HARDWARE
Surface Vertical Rod Devices
(Includes 3788 and 2130 Strikes)
Trim/Control US19* US26D US26 US11* US15*
* 24-V-EO 1633 1697 1830
* 24-V-NL-OP (Supplied as NL less trim) 1633 1697 1830
Delta Trim (handed and eld reversible)
24-V-DT 717DT 1867 1931 2064
24-V-DT 718DT 1885 1949 2082
* 24-V-NL 718NL* 1867 1931 2064
* 24-V-C 718C* 1812 1876 2009
Knob Control (handed and eld reversible)
24-V-K 711K 1912 1976 2109
24-V-K-BE 711K-BE 1912 1976 2109
24-V-K-NL 711K-NL 1912 1976 2109
Dane Lever Control (handed and eld reversible)
* 24-V-L 712L* 1977 2041 2174
* 24-V-L-BE 712L-BE* 1977 2041 2174
* 24-V-L-NL 712L-NL* 1977 2041 2174
* 24-V-L-DT 712L-DT* 1977 2041 2174
*Thesedevicesand712L,712L-BE,712L-NL,712L-DT,718C,718NLtrimsareavailableinUS11,US15andUS19nishes.
Handing:24-VdevicesandnotedTrimsarehandedandeldreversible.TheDeviceandTrimsarefurnishedRHRwhenhandingisnotspecied.
Extension Rods: For door heights over 7'0" up to 8'0", 12" extension rods are furnished at no additional charge at the time of device order. For door heights over 8'0" up to 10'0" extension rods
are furnished at prices shown in parts section with the device at the time of order.
MUST specify door height on order line.
Sex Bolts:
Optional Sex Bolts are recommended for center case and latch mounting when device is used with hollow core wood,
composite or light gauge hollow metal doors. See chart below for quantities and list prices.
Application
Latches
Sex Bolt
2729
(Optional)
Device
Sex Bolt
425
(Optional)
Device
Sex Bolt
325
(Optional) List Add
Hollow core wood, composite or light gauge hollow metal doors - EO (exit only device) 6 2 2 92.00
Hollow core wood, composite or light gauge hollow metal doors - Device with Trim 6 2 Not Required 70.00
Hollow core wood, composite or light gauge hollow metal doors - EO (exit only device) LBR 3 2 2 68.00
Hollow core wood, composite or light gauge hollow metal doors - Device with Trim LBR 3 2 Not Required 46.00
24-V Device Series
3' Devices are priced with standard trim and strikes, 4' add $19, 2' add $123 list.
Cylinders are not included in the price.
95
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
F-24-V Device Series
3' Devices are priced with standard trim and strikes, 4' add $19, 2' add $123 list.
Cylinders are not included in the price.
FIRE EXIT HARDWARE
Surface Vertical Rod Devices
(Includes 3788 and 2130 Strikes)
Trim/Control US19* US26D US26 US11* US15*
* F-24-V-EO 1820 1884 2017
* F-24-V-NL-OP (Supplied as NL less trim) 1820 1884 2017
Delta Trim (handed and eld reversible)
F-24-V-DT 717DT 2054 2118 2251
F-24-V-DT 718DT 2072 2136 2269
* F-24-V-NL 718NL* 2054 2118 2251
* F-24-V-C 718C* 1999 2063 2196
Knob Control (handed and eld reversible)
F-24-V-K 711K 2099 2163 2296
F-24-V-K-BE 711K-BE 2099 2163 2296
F-24-V-K-NL 711K-NL 2099 2163 2296
Dane Lever Control (handed and eld reversible)
* F-24-V-L 7 12L* 2164 2228 2361
* F-24-V-L-BE 712L-BE* 2164 2228 2361
* F-24-V-L-NL 712L-NL* 2164 2228 2361
* F-24-V-L-DT 712L-DT* 2164 2228 2361
*Thesedevicesand712L,712L-BE,712L-NL,712L-DT,718C,718NLtrimsareavailableinUS11,US15andUS19nishes.
Extension Rods: For door heights over 7'0" up to 8'0", 12" extension rods are furnished at no additional charge at the time of device order.
For door heights over 8'0" up to 10'0" extension rods are furnished at prices shown in parts section with the device at the time of order.
MUST specify door height on order line.
Sex Bolts:
One 4122 Sex Bolt is supplied standard no charge for hinge side mounting. Sex Bolts are supplied for
center case and latch mounting when device is used with wood, composite or non-reinforced hollow metal doors.
Application
Latches
Sex Bolt 2729
(Supplied)
Device
Sex Bolt
425
(Supplied)
Device
Sex Bolt
325
(Supplied)
Wood, composite or non-reinforced hollow metal doors - EO (exit only device) 6 2 2
Wood, composite or non-reinforced hollow metal doors - Device with Trim 6 2 Not Required
Wood, composite or non-reinforced hollow metal doors - EO (exit only device) LBR 3 2 2
Wood, composite or non-reinforced hollow metal doors - Device with Trim LBR 3 2 Not Required
96
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Cylinder Dogging
Not for use with Fire Exit Hardware
Prex List Add
CD Cylinder Dogging available on all 24 series Panic Devices. 56
LD Less Dogging available on all 24 series Panic Devices. 25
Less Bottom Rod
Sufx List Add
LBR Less Bottom Rod available with UL Fire Label at no additional charge on F-24-V and F-24-C devices.
Fire rated LBR devices must be ordered in pairs of Vertical Rod Devices.
For Fire Rated Devices specify one device LBR and second device LBR-AFL.
Second device provided with a Fire Pin.
N/C
Electric Latch Retraction
Prex List Add
EL Electric Latch Retraction - Available on all 24 series Panic and Fire Devices.
Electrical Latch cannot be used in combination with CD, EA or KOR options.
482
REFERENCE NOTE:
PS914 is required for EL operation. See Power Supply section for more detail.
Device Monitoring
Prex List Add
RX Touch Bar Request to Exit Switch available on all 24 series devices.
RX device monitoring switch can be used in combination with a second DM or LM switch
(exceptfor24-Rpanicandre).
183
KOR Key Override - Override device monitoring on a door by use of a keyed cylinder.
KOR must be used in combination with a device monitoring switch.
51
Exit Alarm
Prex List Add
EA Exit Alarm available on 24-R and 24-V Panic and Fire Devices.
Price includes switch - “RX” is standard, “DC” is optional at no charge.
To order “Less Switch”, Deduct $174 list.
453
Allegion Connect
Sufx List Add
CON Cross-categorysolutionusingcommoninterconnectcomponentsforelectriedoptions.
Available with EL, RX, DM, LM, EA, RX-DM, RX-LM, EL-RX, EL-DM, EL-LM options.
N/C
NOTE: For wire harness options refer to Power Supply and Electronic Component Section.
24 Device Options
97
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
24 Series Trim
Cylinders are not included in price unless noted.
Athena Trim
Model No. Device Type Description US15 US26
US26D
715DT R, V Dummy Trim - 207
Control Trim
Model No. Device Type Description US15 US26
US26D
711K R, V Knob, Key Locks or Unlocks 222 279
711K C Knob, Key Locks or Unlocks 222 279
711K-BE R, V Knob, Blank Escutcheon 222 279
711K-BE C Knob, Blank Escutcheon 222 279
711K-NL R, V Knob, Night Latch 222 279
711K-NL C Knob, Night Latch 222 279
711seriestrimarehandedandeldreversible.TrimsarefurnishedRHRwhenhandingisnotspecied.
Delta Controls
Model No. Device Type Description US32D US26
US26D
717DT R, V Dummy Trim 200 234
717DT C Dummy Trim 200 234
717seriestrimarehandedandeldreversible.TrimsarefurnishedRHRwhenhandingisnotspecied.
Delta Controls
Model No. Device Type Description US15 US11* US19*,
US26 US26D
718DT C Dummy Trim 179 252
718NL* R, V Night Latch 200 234
718NL* C Night Latch 200 234
718C* R, V Night Latch Less Pull 163 179
718C* C Night Latch Less Pull 163 179
718TL C Turn Lever 511 511
718TL-BE C Turn Lever - Blank Escutcheon 530 530
* Available in US11 and US19.
718seriestrimarehandedandeldreversible.TrimsarefurnishedRHRwhenhandingisnotspecied.
Control Lever Trims
Model No. Device Type Description US15 US11* US19*,
US26 US26D
712L* R, V Dane Lever, Key Locks or Unlocks 321 344
712L* C Dane Lever, Key Locks or Unlocks 321 344
712L-BE* R, V Dane Lever, Blank Escutcheon 321 344
712L-BE* C Dane Lever, Blank Escutcheon 321 344
712L-NL* R, V Dane Lever, Night Latch 321 344
712L-NL* C Dane Lever, Night Latch 321 344
712L-DT* R, V Dane Lever, Dummy Trim 321 344
712L-DT* C Dane Lever, Dummy Trim 321 344
* Available in US11 and US19.
712seriestrimarehandedandeldreversible.TrimsarefurnishedRHRwhenhandingisnotspecied.
The Dane Lever is furnished standard. Optional lever designs Sutro, Quantum and Avalon are available at no additional charge.
24 Series ordered in US32D will be supplied with trims in US15.
98
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
EXIT HARDWARE
Rim Devices
(Price includes 299 Strike)
Trim/Control US19* US26D US26 US11* US15*
* 25-R-EO 965 1004 1129
* 25-R-NL-OP (Supplied as NL less trim) 965 1004 1129
Lever - Dane (handed and eld reversible)
* 25-R-L 510L* 1314 1359 1484
* 25-R-L-BE 510L-BE* 1314 1359 1484
* 25-R-L-NL 510L-NL* 1244 1330 1455
* 25-R-L-DT 510L-DT* 1244 1330 1455
VR Lever (handed and eld reversible)
* 25-R-L 511L* 1363 1411 1536
Thumbpiece (non-handed)
25-R-TP 512TP 1257 1347 1472
25-R-TP-BE 512TP-BE 1257 1347 1472
* 25-R-NL 512-NL* 1199 1280 1405
Knob (non-handed)
25-R-K 513K 1226 1310 1435
25-R-K-BE 513K-BE 1226 1310 1435
25-R-K-NL 513K-NL 1226 1310 1435
25-R-K-DT 513K-DT 1226 1310 1435
DT Pull (717 handed and eld reversible, 512 non-handed)
25-R-DT 717DT 1199 1238 1363
25-R-DT 512DT 1147 1280 1405
*Thesedevicesand510L,510L-BE,510L-NL,510L-DT,511L,512NLtrimsareavailableinUS11,US15,andUS19nishes.
Handing:25-RDeviceisnon-handed.TrimsarefurnishedRHRwhenhandingisnotspecied.
Sex Bolts:
Optional Sex Bolts are recommended for center case mounting when device is used with hollow core wood,
composite or light gauge hollow metal doors. See chart below for quantities and list prices.
Application Sex Bolt 425
(Optional) List Add
Hollow core wood, composite, or light gauge hollow metal doors - EO (exit only device) 8 88
Hollow core wood, composite, or light gauge hollow metal doors - Device x Trim 4 44
25 Device Series
3' Devices are priced with standard trim and strike, 4' add $19 list.
Cylinders are not included in the price.
99
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Device Series F-25-R
3' Devices are priced with standard trim and strike, 4' add $19 list.
Cylinders are not included in the price.
FIRE EXIT HARDWARE
Rim Devices
(Price includes 299F Strike)
Trim/Control US19* US26D US26 US11* US15*
* F-25-R-EO 1168 1207 1332
* F-25-R-NL-OP (Supplied as NL less trim) 1168 1207 1332
Lever - Dane (handed and eld reversible)
* F-25-R-L 510L* 1517 1562 1687
* F-25-R-L-BE 510L-BE* 1517 1562 1687
* F-25-R-L-NL 510L-NL* 1447 1533 1658
* F-25-R-L-DT 510L-DT* 1447 1533 1658
VR Lever (handed and eld reversible)
* F-25-R-L 511L* 1566 1614 1739
Thumbpiece (non-handed)
F-25-R-TP 512TP 1460 1550 1675
F-25-R-TP-BE 512TP-BE 1460 1550 1675
* F-25-R-NL 512-NL* 1402 1483 1608
Knob (non-handed)
F-25-R-K 513K 1429 1513 1638
F-25-R-K-BE 513K-BE 1429 1513 1638
F-25-R-K-NL 513K-NL 1429 1513 1638
F-25-R-K-DT 513K-DT 1429 1513 1638
DT Pull (717 handed and eld reversible, 512 non-handed)
F-25-R-DT 717DT 1402 1441 1566
F-25-R-DT 512DT 1350 1483 1608
*Thesedevicesand510L,510L-BE,510L-NL,510L-DT,511L,512NLtrimsareavailableinUS11,US15,andUS19nishes.
Handing:F-25-RDeviceisnon-handed.TrimsarefurnishedRHRwhenhandingisnotspecied.
Sex Bolts:
Sex Bolts are supplied for center case mounting when device is used with wood,
composite or non-reinforced hollow metal doors. See chart below for quantities.
Application Sex Bolt 425
(Supplied)
Wood, composite or non-reinforced hollow metal doors - EO (exit only device) 8
Wood, composite or non-reinforced hollow metal doors - Device x Trim 4
100
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
EXIT HARDWARE
Surface Vertical Rod Devices
(Includes 3788 & 2130 Strikes )
Trim/Control US19* US26D US26 US11* US15*
* 25-V-EO 1405 1464 1577
* 25-V-NL-OP (Supplied as NL less trim) 1405 1464 1577
Lever - Dane (handed and eld reversible)
* 25-V-L 510L* 1754 1819 1932
* 25-V-L-BE 510L-BE* 1754 1819 1932
* 25-V-L-NL 510L-NL* 1684 1790 1903
* 25-V-L-DT 510L-DT* 1684 1790 1903
VR Lever (handed and eld reversible)
* 25-V-L 511L* 1803 1871 1984
Thumbpiece (non-handed)
25-V-TP 512TP 1697 1807 1920
25-V-TP-BE 512TP-BE 1697 1807 1920
* 25-V-NL 512-NL* 1639 1740 1853
Knob (non-handed)
25-V-K 513K 1666 1770 1883
25-V-K-BE 513K-BE 1666 1770 1883
25-V-K-NL 513K-NL 1666 1770 1883
25-V-K-DT 513K-DT 1666 1770 1883
DT Pull (717 handed and eld reversible, 512 non-handed)
25-V-DT 717DT 1639 1698 1811
25-V-DT 512DT 1587 1740 1853
* These devices and 510L, 510L-BE, 510L-NL, 510L-DT, 511L, 512NL trims are available in US11, US15, and US19 nishes.
Handing:The25-VDeviceishandedandeldreversible.TrimsarefurnishedRHRwhenhandingisnotspecied.
Extension Rods: For door heights over 7'0" up to 8'0", 12" extension rods are furnished at no additional charge at the time of device order.
For door heights over 8'0" up to 10'0" extension rods are furnished at prices shown in parts section with the device at the time of order.
MUST specify door height on order line.
Sex Bolts:
Optional Sex Bolts are recommended for center case and latch mounting when device is used with hollow core wood,
composite or light gauge hollow metal doors. See chart below for quantities and list prices.
Application
Latches
Sex Bolt 2729
(Optional)
Device
Sex Bolt 425
(Optional) List Add
Hollow core wood, composite or light gauge hollow metal doors - EO (exit only device) 6 6 114.00
Hollow core wood, composite or light gauge hollow metal doors - Device x Trim 6 2 70.00
Hollow core wood, composite or light gauge hollow metal doors - EO (exit only device) LBR 3 6 90.00
Hollow core wood, composite or light gauge hollow metal doors - Device x Trim LBR 3 2 46.00
25-V Device Series
3' Devices are priced with standard trim and strikes, 4' add $19 list and 2' add $123 list.
Cylinders are not included in the price.
101
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
F-25-V Device Series
3' Devices are priced with standard trim and strikes, 4' add $19 list and 2' add $123 list.
Cylinders are not included in the price.
FIRE EXIT HARDWARE
Surface Vertical Rod Devices
(Includes 3788 & 2130 Strikes )
Trim/Control US19* US26D US26 US11* US15*
* F-25-V-EO 1593 1652 1765
* F-25-V-NL-OP (Supplied as NL less trim) 1593 1652 1765
Lever - Dane (handed and eld reversible)
* F-25-V-L 510L* 1942 2007 2120
* F-25-V-L-BE 510L-BE* 1942 2007 2120
* F-25-V-L-NL 510L-NL* 1872 1978 2091
* F-25-V-L-DT 510L-DT* 1872 1978 2091
VR Lever (handed and eld reversible)
* F-25-V-L 511L* 1991 2059 2172
Thumbpiece (non-handed)
F-25-V-TP 512TP 1885 1995 2108
F-25-V-TP-BE 512TP-BE 1885 1995 2108
* F-25-V-NL 512-NL* 1827 1928 2041
Knob (non-handed)
F-25-V-K 513K 1854 1958 2071
F-25-V-K-BE 513K-BE 1854 1958 2071
F-25-V-K-NL 513K-NL 1854 1958 2071
F-25-V-K-DT 513K-DT 1854 1958 2071
DT Pull (717 handed and eld reversible, 512 non-handed)
F-25-V-DT 717DT 1827 1886 1999
F-25-V-DT 512DT 1775 1928 2041
*Thesedevicesand510L,510L-BE,510L-NL,510L-DT,511L,512NLtrimsareavailableinUS11,US15,andUS19nishes.
Handing:TheF-25-VDeviceishandedandeldreversible.TrimsarefurnishedRHRwhenhandingisnotspecied.
Extension Rods: For door heights over 7'0" up to 8'0", 12" extension rods are furnished at no additional charge at the time of device order.
For door heights over 8'0" up to 10'0" extension rods are furnished at prices shown in parts section with the device at the time of order.
MUST specify door height on order line.
Sex Bolts:
Sex Bolts are supplied for center case mounting and latch mounting when device is used with wood,
composite or non-reinforced hollow metal doors. See chart below for quantities.
Application
Latches
Sex Bolt 2729
(Supplied)
Device
Sex Bolt 425
(Supplied)
Wood, composite or non-reinforced hollow metal doors - EO (exit only device) 6 6
Wood, composite or non-reinforced hollow metal doors - Device x Trim 6 2
Wood, composite or non-reinforced hollow metal doors - EO (exit only device) LBR 3 6
Wood, composite or non-reinforced hollow metal doors - Device x Trim LBR 3 2
102
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Cylinder Dogging Not for use with Fire Exit Hardware
Prex List Add
CD Cylinder Dogging available on all 25 series Panic Devices. 56
LD Less Dogging available on all 25 series Panic Devices. 25
Less Bottom Rod
Sufx List Add
LBR Less Bottom Rod available with UL Fire Label at no additional charge on F-25-V and F-25-C devices. Fire rated LBR devices
must be ordered in pairs of Vertical Rod Devices. For Fire Rated Devices specify one device LBR and second device
LBR-AFL. Second device provided with a Fire Pin.
N/C
Accessible Device
Sufx List Add
AX Accessible device compliant with the California Building Code (Section 11B-309.4) requirement for 5 lb. maximum operational
force. Available on 3' and 4' AX-25-R, AX-F-25-R, AX-25-V, AX-F-25-V, AX-25-V-LBR, AX-F-25-V-LBR/LBR-AFL, AX-25-C,
AX-F-25-C, AX-25-C-LBR, AX-F-25-C-LBR/LBR-AFL. Trim functions available EO, DT, NL, L, L-BE, L-NL, L-DT, NL-OP, and C.
Other device and trim options compatible with AX25 devices: EL, RX, DM, LM, CON, EA, FSA/FSE, CD, LD.
22
Hurricane Device Meets all FBC Hurricane Listings. Consult factory for specic Applications.
Prex List Add
HH Hurricane optionavailableon25-R,F-25-R,25-V,F-25-V.Prexdevice"HH".
Note: HH25-V and HH-F-25-V, will be supplied with twelve sexbolts. Add $132.00 LIST 25
Standard Devices 25-C, F-25-C, 25-M, F-25-M meet all FBC Hurricane listing requirements.
Consultfactoryforspecicapplications.Prex"HH"isnotrequiredonthesedevices.
N/C
Electric Latch Retraction
Prex List Add
EL Electric Latch Retraction - Available on all 25 series Panic and Fire Devices. Electric Latch cannot be used in combination
with CD, EA or KOR options.
482
REFERENCE NOTE: PS914 is required for EL operation. See Power Supply section for more detail.
Device Monitoring
Prex List Add
RX Touch Bar Request to Exit Switch available on all 25 series devices. RX dogging monitoring switch can be used in
combination with a second DM or LM switch.
183
DM Latch Bolt Monitor Switch (provide signal when latch bolt is fully extended) available on most 25 series devices.
DM device monitoring switch can be used in combination with a RX switch.
192
LM Latch Bolt Monitoring Switch (provide signal when latch bolt is fully retracted) available on most 25 series devices.
Not available on F-25-R devices, with dual LM switches or in combination with DM switch.LM device monitoring switch can be
used in combination with a RX switch.
183
KOR Key Override - Override device monitoring on a door by use of a keyed cylinder. KOR must be used in combination with a
device monitoring switch.
51
Allegion Connect
Sufx List Add
CON Cross-categorysolutionusingcommoninterconnectcomponentsforelectriedoptions.AvailablewithEL,RX,DM,LM,EA,
RX-DM, RX-LM, EL-RX, EL-DM, EL-LM options.Also available as an option on FSA and FSE options for the Falcon 25 series trim.
N/C
NOTE: For wire harness options refer to Power Supply and Electronic Component Section.
Exit Alarm
Prex List Add
EA Exit Alarm available on 25-R and 25-V Panic and Fire Devices. Price includes switch - "RX" is standard, "LM" is optional at no
charge. To order "Less Switch", Deduct $183 list. For vertical rod tampering monitoring on Surface Vertical Devices, specify
device with DM (Latch Bolt Monitor Switch). Add $192 list. 9 volt battery included.
453
Electric Lock or Unlock of Trims
Prex List Add
FSA Electric Lock/Unlock Trim, Fail Safe (unlocks when power is interrupted). 268
FSE Electric Lock/Unlock Trim, Fail Secure (locks when power is interrupted). 268
REFERENCE NOTES:
FSA/FSE available on all 25 series devices. Available with TP, K, or L functions only. Can be used in combination with EL, EA, or any device monitoring switch. Power supply PS902 is the
recommended power supply for use with FSA/FSE trim. If paired with an EL device, PS914 is required. See the power supply section for more information.
25 Device Options
103
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Lever Trim
Model No. Lever
Style Device Type Description US19* US26D US11* US15* US26
US32
510L Dane R,V,M,C Lever, Key Locks or Unlocks 349 355
510L-NL Dane R,V,M,C Lever, Night Latch 279 326
510L-DT Dane R,V,M,C Lever, Dummy Trim 279 326
510L-BE Dane R,V,M,C Lever, Blank Escutcheon 349 355
* US11, US15, US19 are available on the lever trim type listed above except Sutro.
510seriestrimarehandedandeldreversible.TrimsarefurnishedRHRwhenhandingisnotspecied.
The Dane Lever is furnished standard. Optional lever designs Broadway, Boardwalk, Danish, Latitude, Longitude, Sutro, Quantum and Avalon are available at no additional charge.
Electric Lock or Unlock option is available on 510L function only.
SufxFSAforFailSafeoperation,orFSE for Fail Secure operation, add $268 List.
Knurling on Dane lever, add $57 List. Contact factory for lead times.
Vandal Resistant Trim
Model No. Lever
Style Device Type Description US32D US19* US26D US3 US11*
US15* US26 US32
511L* Dane R,V,M,C Lever, Key Locks or Unlocks 398 407
* US11, US15, US19 are available on the lever trim type listed above except Sutro.
511seriestrimarehandedandeldreversible.TrimsarefurnishedRHRwhenhandingisnotspecied.
The Dane Lever is furnished standard. Optional lever designs Broadway, Boardwalk, Danish, Latitude, Longitude, Sutro, Quantum and Avalon are available at no additional charge.
Electric Lock or Unlock option is available on 511L.
SufxFSAforFailSafeoperation,orFSE for Fail Secure operation, add $268 List.
Night Latch and Thumbpiece Trim
Model No. Device Type Description US32D US19* US26D US3 US11* US15*
US26 US32
512NL* R,V,M,C Night Latch 234 276
512TP R,V,M,C Thumbpiece, Key Locks or Unlocks 292 343
512TP-BE R,V,M,C Thumbpiece, Blank Escutcheon 292 343
* Available in US11, US15, US19 on all Falcon Exit levers except for Sutro.
Electric Lock or Unlock option is available on 512TP function only.
SufxFSAforFailSafeoperation,orFSE for Fail Secure operation, add $268 List.
Knob Trim
Model No. Device Type Description US32D US26D US3 US26 US32
513K R,V,M,C Knob, Key Locks or Unlocks 261 306
513K-NL R,V,M,C Knob, Night Latch 261 306
513K-DT R,V,M,C Knob, Dummy Trim 261 306
513K-BE R,V,M,C Knob, Blank Escutcheon 261 306
Electric Lock or Unlock option is available on 513K function only.
SufxFSAforFailSafeoperation,orFSE for Fail Secure operation, add $268 List.
Pull Trim
Model No. Device Type Description US32D US26D US3 US26 US32
512DT R,V,M,C Dummy Trim 182 276
Delta Trim
Model No. Device Type Description SP313 US15
US32D US19* US26D US3,
US11* US26 US32
717DT R,V,M,C Dummy Trim 200 234
718C* C Night Latch Less Pull 163 179
* Available in US11 and US19.
717and718seriestrimarehandedandeldreversible.TrimsarefurnishedRHRwhenhandingisnotspecied.
25 Series Trims
Cylinders are not included in price.
104
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
19-R Device Series
3´ Devices are priced with standard trim and strikes, 4´ add $19 list.
Cylinders are not included in price unless noted.
EXIT HARDWARE SP28
SP313 US32D
Rim Devices (Includes F570 Strike)
Trim/Control
19-R-EO 282 499
Trident Trim (must specify handing)
19-R-DT 920DT 320 537
19-R-NL 920NL 349 566
Centron Trim (non-handed)
19-R-EO 930EO 316 533
19-R-DT 930DT 320 537
19-R-NL 930NL 335 552
19-R-C 930C 329 546
19-R-DT 917DT 312 529
Control Trim (non-handed)
19-R-DT 918DT 393 702
19-R-NL 918NL 393 702
Knob Control (handed and eld reversible)
19-R-K 911K 393 702
19-R-K-BE 911K-BE 393 702
19-R-K-NL 911K-NL 393 702
Dane Lever Control (handed and eld reversible)
19-R-L 912L 436 736
19-R-L-BE 912L-BE 436 736
19-R-L-NL 912L-NL 436 736
19-R-L-DT 912L-DT 436 736
Key in Lever (handed and eld reversible)
19-R-KIL 914-KIL-KD W/CYL 467 684
19-R-KIL-NL 914-KIL-NL-KD W/CYL 467 684
19-R-KIL-BE 914-KIL-BE 467 684
19-R-KIL-IC 914-KIL-IC W/CYL 510 727
REFERENCE NOTE:
930 series trimisavailableinSP313andUS32Dnishonly.19seriesdevicesorderinSP28pairedwith930trimaresuppliedwithUS32Dnishtrim.
Sex Bolts:
Three 4122 Sex Bolts are supplied standard no charge, one for hinge side mounting and two for center case mounting.
105
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
F-19-R Device Series
3' Devices are priced with standard trim and strike, 4' add $19 list.
Cylinders are not included in the price unless noted.
FIRE EXIT HARDWARE
Rim Devices (Includes F570 Strike) SP28
SP313 US32D
Trim/Control
F-19-R-EO 353 583
Trident Trim (must specify handing)
F-19-R-DT 920DT 391 621
F-19-R-NL 920NL 420 650
Centron Trim (non-handed)
F-19-R-EO 930EO 387 617
F-19-R-DT 930DT 391 621
F-19-R-NL 930NL 406 636
F-19-R-C 930C 400 630
F-19-R-DT 917DT 383 613
Control Trim (non-handed)
F-19-R-DT 918DT 464 786
F-19-R-NL 918NL 464 786
Knob Control (handed and eld reversible)
F-19-R-K 911K 464 786
F-19-R-K-BE 911K-BE 464 786
F-19-R-K-NL 911K-NL 464 786
Dane Lever Control (handed and eld reversible)
F-19-R-L 912L 507 820
F-19-R-L-BE 912L-BE 507 820
F-19-R-L-NL 912L-NL 507 820
F-19-R-L-DT 912L-DT 507 820
Key in Lever (handed and eld reversible)
F-19-R-KIL 914-KIL-KD W/CYL 538 768
F-19-R-KIL-NL 914-KIL-NL-KD W/CYL 538 768
F-19-R-KIL-BE 914-KIL-BE 538 768
F-19-R-KIL-IC 914-KIL-IC W/CYL 581 811
REFERENCE NOTE:
930 series trimisavailableinSP313andUS32Dnishonly.19seriesdevicesorderinSP28pairedwith930trimaresuppliedwithUS32Dnishtrim.
Sex Bolts:
Three 4122 Sex Bolts are supplied standard, one for hinge side mounting and two for center case mounting.
Two 2729 Sex bolts are supplied for additional center case mounting when device is used with wood,
composite or non-reinforced hollow metal doors.
Application Sex Bolt 2729 (Supplied)
Wood, composite or non-reinforced hollow metal doors 2
106
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
19-V Device Series
3' Devices are priced with standard trim and strikes, 4' add $19 list.
Cylinders are not included in the price unless noted.
EXIT HARDWARE
Surface Vertical Rod Devices
(Includes 3788 and 2130 Strikes ) SP28
SP313 US32D
Trim/Control
19-V-EO 434 831
Trident Trim (must specify handing)
19-V-DT 920DT 472 869
19-V-NL 920NL 501 898
Centron Trim (non-handed)
19-V-EO 930EO 468 865
19-V-DT 930DT 472 869
19-V-NL 930NL 487 884
19-V-C 930C 481 878
19-V-DT 917DT 464 861
Control Trim (non-handed)
19-V-DT 918DT 545 1034
19-V-NL 918NL 545 1034
Knob Control (handed and eld reversible)
19-V-K 911K 545 1034
19-V-K-BE 911K-BE 545 1034
19-V-K-NL 911K-NL 545 1034
Dane Lever Control (handed and eld reversible)
19-V-L 912L 588 1068
19-V-L-BE 912L-BE 588 1068
19-V-L-NL 912L-NL 588 1068
19-V-L-DT 912L-DT 588 1068
Key in Lever (handed and eld reversible)
19-V-KIL 914-KIL-KD W/CYL 619 1016
19-V-KIL-NL 914-KIL-NL-KD W/CYL 619 1016
19-V-KIL-BE 914-KIL-BE 619 1016
19-V-KIL-IC 914-KIL-IC W/CYL 662 1059
REFERENCE NOTES:
Handing:19-Vdevicesarehandedandeldreversible.DevicesandTrimsarefurnishedRHRwhenhandingisnotspecied.
Extension Rods: For door heights over 7'0" up to 8'0", 12" extension rods are furnished at no additional charge at the time of device order.
For door heights over 8'0" up to 10'0" extension rods are furnished at prices shown in parts section with the device at the time of order.
MUST specify door height on order line.
930 series trimisavailableinSP313andUS32Dnishonly.19seriesdevicesorderinSP28pairedwith930trimaresuppliedwithUS32Dnishtrim.
Sex Bolts:
Three 4122 Sex Bolts are supplied standard no charge, one for hinge side mounting and two for center case mounting.
Six 2729 Sex Bolts are recommended for latch mounting when device is used with hollow core, composite or light gauge hollow
metal doors. See chart below for quantities and list prices.
Application Sex Bolt 2729
(Optional) List Add
Hollow core, composite or light gauge hollow metal doors 6 48
107
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
FIRE EXIT HARDWARE
Surface Vertical Rod Devices
(Includes 3788 and 2130 Strikes
Trim/Control SP28
SP313 US32D
F-19-V-EO 548 936
Trident Trim (must specify handing)
F-19-V-DT 920DT 586 974
F-19-V-NL 920NL 615 1003
Centron Trim (non-handed)
F-19-V-EO 930EO 582 970
F-19-V-DT 930DT 586 974
F-19-V-NL 930NL 601 989
F-19-V-C 930C 595 983
F-19-V-DT 917DT 578 966
Control Trim (non-handed)
F-19-V-DT 918DT 659 1139
F-19-V-NL 918NL 659 1139
Knob Control (handed and eld reversible)
F-19-V-K 911K 659 1139
F-19-V-K-BE 911K-BE 659 1139
F-19-V-K-NL 911K-NL 659 1139
Dane Lever Control (handed and eld reversible)
F-19-V-L 912L 702 1173
F-19-V-L-BE 912L-BE 702 1173
F-19-V-L-NL 912L-NL 702 1173
F-19-V-L-DT 912L-DT 702 1173
Key in Lever (handed and eld reversible)
F-19-V-KIL 914-KIL-KD W/CYL 733 1121
F-19-V-KIL-NL 914-KIL-NL-KD W/CYL 733 1121
F-19-V-KIL-BE 914-KIL-BE 733 1121
F-19-V-KIL-IC 914-KIL-IC W/CYL 776 1164
REFERENCE NOTES:
Handing:F-19-Vdevicesarehandedandeldreversible.DevicesandTrimsarefurnishedRHRwhenhandingisnotspecied.
Extension Rods: For door heights over 7'0" up to 8'0", 12" extension rods are furnished at no additional charge at the time of device order.
For door heights over 8'0" up to 10'0" extension rods are furnished at prices shown in parts section with the device at the time of order.
MUST specify door height on order line.
930seriestrimisavailableinSP313andUS32Dnishonly.19seriesdevicesorderinSP28pairedwith930trimaresuppliedwithUS32Dnishtrim.
Sex Bolts:
Three 4122 Sex Bolts are supplied standard no charge, one for hinge side mounting and two for center case mounting.
Six 2729 are supplied for additional latch case mounting when device is used with wood, composite or non-reinforced hollow metal doors.
Application Sex Bolt 2729
(Supplied)
Wood, composite or non-reinforced hollow metal doors 6
F-19-V Device Series
3' Devices are priced with standard trim and strikes, 4' add $19 list.
Cylinders are not included in the price unless noted.
108
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
19 Device Options
Cylinder Dogging
Not for use with Fire Exit Hardware
Prex List Add
CD Cylinder Dogging available on all 19 series Panic Devices. 56
LD Less Dogging available on all 19 series Panic Devices 25
Less Bottom Rod
Sufx List Add
LBR Less Bottom Rod available with UL Fire Label at no additional charge on F-19-V devices.
Fire rated LBR devices must be ordered in pairs of Vertical Rod Devices.
For Fire Rated Devices specify one device LBR and second device LBR-AFL. Second device provided with a Fire
Pin.
N/C
* The 19-Series Exit Alarm option has been eliminated. Consult Customer Care for availability and warranty claims.
Accessible Device
Sufx List Add
AX Accessible device compliant with the California Building Code (Section 11B-309.4) requirement for 5 lb.
maximum operational force. Available on 3' and 4' AX-19-R, AX-F-19-R, AX-19-V, AX-F-19-V, AX-19-V-LBR, AX-
F-19-V-LBR/LBR-AFL. Trim functions available EO, DT, NL, L, L-BE, L-NL, L-DT, C, KIL, KIL-BE, KIL-NL,
and KIL-IC.
22
109
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
19 Series Trims
Cylinders are not included in price unless noted.
Trident Trim
Model No. Lever Style Description SP28, SP313 US32D
920DT - Dummy Trim 38 -
920NL - Night Latch 67 -
920seriestrimarehandedandnoteldreversible,specifyRHRorLHR.
Centron Trim
Model No. Lever Style Description SP28 US32D, SP313
917DT - Dummy Trim 30 30
930EO - Exit Only - 34
930DT - Dummy Trim - 38
930NL - Night Latch - 53
930C - Night Latch Less Pull - 47
930seriestrimareavailableinSP313andUS32Dnishonly.
Control Trim
Model No. Lever Style Description SP28, SP313 US15
918DT - Dummy Trim 111 203
918NL - Night Latch 111 203
911K - Knob, Key Locks or Unlocks 111 203
911K-BE - Knob, Blank Escutcheon 111 203
911K-NL - Knob, Night Latch 111 203
911seriestrimarehandedandeldreversible.TrimsarefurnishedRHRwhenhandingisnotspecied.
Lever Trim
Model No. Lever Style Description SP28, SP313 US15
912L Dane Lever, Key Locks or Unlocks 154 237
912L-BE Dane Lever, Blank Escutcheon 154 237
912L-NL Dane Lever, Night Latch 154 237
912L-DT Dane Lever, Dummy Trim 154 237
Optional lever designs Quantum and Sutro are available at no additional charge.
912seriestrimarehandedandeldreversible.TrimsarefurnishedRHRwhenhandingisnotspecied.
Key In Lever Trims
Model No. Lever Style Description US32D, SP313
914KIL-KD Dane Key in Lever, with Keyed Different Cylinder 185
914KIL-BE Dane Key in Lever, Blank Escutcheon 185
914KIL-NL-KD Dane Key in Lever, Night Latch with Cylinder 185
914KIL-IC Dane Key in Lever with IC Core Cylinder 228
914seriestrimarehandedandeldreversible.TrimsarefurnishedRHRwhenhandingisnotspecied.
914 KIL-KD, KIL-NL-KD come standard with a C keyway and 914 KIL-IC come standard with a A keyway.
Consult factory if other keyways are desired to order separately.
110
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
1690 Concealed Vertical Rod Pushpad Exit Devices
Devices are priced for 30", 36" x 7',
Aluminum or Hollow Metal Doors.
Hex Bottom Latch furnished standard.
(Price includes PB48 Strike)
Model No. US26 US26D Standard Trim
1690EO 558 538 –
1691DT 903 882 9970 Pull
1692NL-OP/HB-OP 639 618 169CA w/Rim Cylinder
1694NL-P/HB-P 984 963 9970 Pull 169CA
w/Rim Cylinder
REFERENCE NOTES:
Devicesaresupplied36"x7'standard,ifnotspecied.
Rim cylinder supplied standard with NL and HB options is C keyway.
Extra Length List Add
42" 19.00
48" 27.00
Door Heights over 7' List Add
Up to 8' 58.00
Up to 9' 75.00
Up to 10' 85.00
Optional Latches
Sufx List Add
RL Rod Bottom Latch 25.00
PL Pullman Bottom Latch 25.00
ES Top Latch for use with Electric Strikes
Device Furnished LBR (Less Bottom Rod and Less Strike) deduct $22 List
29.00
Less Rods Forretrotof1990crossbardevice,deduct $44 List
Device Options List Add
RX Switch BaseExitDeviceunitmodiedRequesttoExitSwitchmonitoringpushpad.
Prex device "RX".
191.00
Electric Latch Retraction BaseExitDeviceunitmodiedwithElectricLatchRetraction.
Prex device "EL".
TheELoptionisnoteldreplaceableonthismodel.
513.00
(One PS914 x 900-2RS is the minimum requirement to power one or two EL devices.
See Power Supply Section for requirements and options.)
Electric Dogging BaseExitDeviceunitmodiedwithElectricDogging
Prex device "ED".
513.00
HH Hurricane device. Available up to 8' device only. Prex device "HH".
HH is for a Hurricane device for all door manufactures other than YKK.
102.00
HHYKK Hurricane device. Available up to 8' device only. Prex device "HHYKK".
HHYKK is for a Hurricane device for door manufacture YKK.
102.00
REFERENCE NOTES:
For EL1690 Door widths other than the standard size (30", 36", 42" or 48"), please specify exact door width. For non-standard widths, the price of the next widest standard size will apply.
HH(Hurricane)1690devicesarehurricaneratedbyspecicdoormanufacturers.ConsultyourdevicemanufacturertoassuretheHH1690ishurricaneratedwiththeirdoorsolution.
111
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Model No. US26 US26D Standard Trim
1790EO 518 499 –
1791DT 863 844 9970 Pull
1792NL-OP/HB-OP 599 580 179CA w/Rim Cylinder
1794NL-P/HB-P 944 925 9970 Pull 179CA
w/Rim Cylinder
REFERENCE NOTES:
Devicesaresupplied36"x7'standard,ifnotspecied.
Rim cylinder supplied standard with NL and HB options is C keyway.
Lever Control
P28
P13
P35 US15
179L Lever Control 313 349
179L-BE Lever Control, Blank Escutcheon 313 349
179L-NL Lever Control, Night Latch 313 349
REFERENCE NOTES:
Lever Controls are Handed. Specify handing RHR or LHR.
179LTrimsareeldretrottablewithall1790SeriesDevices.
For initial installation requiring lever trim, the 1790EO is the suggested device to order with the 179L trims.
179L and L-NL require a 1 1/8" mortise cylinder with straight cam, sold separately.
1790 Series Rim Type Pushpad Exit Devices
Devices are priced for 30" and 36",
Aluminum or Hollow Metal Doors.
(Price includes TD35 Strike)
Extra Length List Add
42" 19.00
48" 27.00
Device Options List Add
RX Switch BaseExitDeviceunitmodiedRequesttoExitSwitchmonitoringpushpad.
Prex device "RX".
191.00
Electric Latch Retraction BaseExitDeviceunitmodiedwithElectricLatchRetraction.
Prex device "EL".
TheELoptionisnoteldreplaceableonthismodel.
513.00
(One PS914 x 900-2RS is the minimum requirement to power one or two EL devices.
See Power Supply Section for requirements and options.)
Electric Dogging BaseExitDeviceunitmodiedwithElectricDogging
Prex device "ED".
513.00
REFERENCE NOTES:
For EL1790 Door widths other than the standard size (30", 36", 42" or 48"), please specify exact door width.
For non-standard widths, the price of the next widest standard size will apply.
112
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
1990 Concealed Vertical Rod Crossbar Exit Devices
Devices are priced for 3'8" x 7',
Aluminum or Hollow Metal Doors.
Hex Bottom Latch furnished standard.
(Price includes PB48 Strike)
Model No. US26D Standard Trim
1990EO 1123 –
1991DT 1468 9970 Pull
1992NL-OP/HB-OP 1204 Rim Cylinder only
1993NL/HB 1549 9970 w/Rim Cylinder
REFERENCE NOTES:
Rim cylinder supplied standard with NL and HB options is C keyway.
Optional Latches
Sufx List Add
RL Rod Bottom Latch 25.00
PL Pullman Bottom Latch 25.00
ES Top Latch for use with Electric Strikes
Device Furnished LBR (Less Bottom Rod and Less Strike) deduct $22.00 List
29.00
Door Heights over 7'
List Add
Up to 8' 58.00
Up to 9' 75.00
Up to 10' 85.00
Crossbar
Crossbar furnished 41" standard - Easily Cut for Job Fitting List Add
ExtraLengthCrossbar-48"(FitsDoorWidthupto51")-P28,P13,P35nishes 19.00
ExtraLengthCrossbar-48"(FitsDoorWidthupto51")-Architecturalnishes
Less Crossbar, deduct $106 List
27.00
REFERENCE NOTES:
Specify if Door Material other than Aluminum. Not recommended for use on wood doors.
113
Multi-family Exits - VonDuprin & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
2090 Rim Type Crossbar Exit Devices
Devices are priced for 3'8",
Aluminum or Hollow Metal Doors.
(Price includes SD36 Strike)
Model No. US26D Standard Trim
2090EO 1043 –
2091DT 1388 9970 Pull
2092NL-OP/HB-OP 1124 Rim Cylinder only
2093NL/HB 1468 9970 w/Rim Cylinder
REFERENCE NOTES:
Rim cylinder supplied standard with NL and HB options is C keyway.
Crossbar
Crossbar furnished 41" standard - Easily Cut for Job Fitting List Add
ExtraLengthCrossbar-48"(FitsDoorWidthupto51")-P28,P13,P35nishes 19.00
ExtraLengthCrossbar-48"(FitsDoorWidthupto51")-Architecturalnishes
Less Crossbar, deduct $106 List
27.00
REFERENCE NOTES:
Specify if Door Material other than Aluminum. Specify Handing RHR or LHR. Not Reversible.
114 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Door Closers - LCN & Falcon
Notes: AL=Aluminumnish(689);DKBRZ=Darkbronzenish(695);Rw/PA = Regular arm with parallel arm bracket
Hw/PA=Holdopenarmwithparallelarmbracket(PleasenoteholdopenarmcongurationsarenotULlisted.)
c
L
1261-18
12
305 mm
2
11/16
68 mm
1
1/4
32 mm
3
3/8
86 mm
10
254 mm
101 - 120
121 - 180
5
9/16
141 mm
3
76 mm
=
=
To 100
6
9/16
167 mm
=
A
2
7/8
73 mm
A
101 - 120
121 - 180
11
5/8
295 mm
9
1/8
232 mm
=
=
To 100
12
5/8
321 mm
=
B
B
1250 Series Surface Door Closers
Surface Door Closers
1450 Series Surface Door Closers
1260 Series Surface Door Closers
n Light duty cast aluminum door closer
n Adjustable sizes 1-5
n ANSI/BHMA156.4,Grade1certied
n CloserswithoutHold-OpenarmsareUL10Crerated
n Medium duty cast aluminum door closer
n Adjustable sizes 1-6
n ANSI/BHMA156.4,Grade1certied
n CloserswithoutHold-OpenarmsareUL10Crerated
n Light-medium duty cast iron door closer
n Adjustable sizes 1-5
n ANSI/BHMA156.4,Grade1certied
n CloserswithoutHold-OpenarmsareUL10Crerated
Series Arms Finish Handing Cylinder Assembly Cover Price Ea.
1250 Rw/PA AL - Std None $190.00
1250 Rw/PA AL - Std Slim 205.00
1250 Hw/PA AL - Std None 220.00
1250 Hw/PA AL - Std Slim 235.00
1250 Rw/PA DKBRZ - Std None 190.00
1250 Rw/PA DKBRZ - Std Slim 205.00
1250 Hw/PA DKBRZ - Std None 220.00
1250 Hw/PA DKBRZ - Std Slim 235.00
Series Arms Finish Handing Cylinder Assembly Cover Price Ea.
1450 Rw/PA AL - Std Slim $257.00
1450 Rw/PA AL - Std Full 267.00
1450 Hw/PA AL - Std Slim 287.00
1450 Hw/PA AL - Std Full 297.00
1450 Rw/PA DKBRZ Std Slim 257.00
1450 Rw/PA DKBRZ Std Full 267.00
1450 Hw/PA DKBRZ Std Slim 287.00
1450 Hw/PA DKBRZ Std Full 297.00
Series Arms Finish Handing Cylinder Assembly Cover Price Ea.
1261 Rw/PA AL - Std None $255.00
1261 Hw/PA AL - Std None 285.00
1261 Rw/PA DKBRZ - Std None 255.00
1261 Hw/PA DKBRZ - Std None 285.00
115
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Door Closers - LCN & Falcon
1460 Series Surface Door Closers
Surface Door Closers (continued)
4040XP Series Surface Door Closers
4050 Series Surface Door Closers
n Medium duty cast iron door closer
n Adjustable sizes 1-6
n ANSI/BHMA156.4,Grade1certied
n CloserswithoutHold-OpenarmsareUL10Crerated
n Heavy duty cast iron door closer
n Adjustable sizes 1-6
n ANSI/BHMA156.4,Grade1certied
n CloserswithoutHold-OpenarmsareUL10Crerated
n Heavy duty cast aluminum door closer
n Adjustable sizes 1-6
n ANSI/BHMA156.4,Grade1certied
n CloserswithoutHold-OpenarmsareUL10Crerated
Series Arms Finish Handing Cylinder Assembly Cover Price Ea.
1461 Rw/PA AL - Std Slim $325.00
1461 Rw/PA AL - Std Full 335.00
1461 Hw/PA AL - Std Slim 355.00
1461 Hw/PA AL - Std Full 365.00
1461 Rw/PA DKBRZ - Std Slim 325.00
1461 Rw/PA DKBRZ - Std Full 335.00
1461 Hw/PA DKBRZ - Std Slim 355.00
1461 Hw/PA DKBRZ - Std Full 365.00
Series Arms Finish Handing Cylinder Assembly Cover Price Ea.
4040XP Rw/PA AL - Std Full $467.00
4040XP Hw/PA AL - Std Full 522.00
4040XP EDA AL - Std Full 507.00
4040XP Cush AL - Std Full 537.00
4040XP SCUSH AL - Std Full 587.00
4040XP Rw/PA DKBRZ - Std Full 467.00
4040XP Hw/PA DKBRZ - Std Full 522.00
4040XP EDA DKBRZ - Std Full 507.00
4040XP Cush DKBRZ - Std Full 537.00
4040XP SCUSH DKBRZ - Std Full 587.00
Series Arms Finish Handing Cylinder Assembly Cover Price Ea.
4050 Rw/PA AL - Std Full $377.00
4050 Hw/PA AL - Std Full 417.00
4050 EDA AL - Std Full 407.00
4050 Cush AL - Std Full 432.00
4050 SCUSH AL - Std Full 487.00
4050 Rw/PA DKBRZ - Std Full 377.00
4050 Hw/PA DKBRZ - Std Full 417.00
4050 EDA DKBRZ - Std Full 407.00
4050 Cush DKBRZ - Std Full 432.00
4050 SCUSH DKBRZ - Std Full 487.00
Notes: ALUM=Aluminumpaintednish(689);DKBRZ=Darkbronzenish(695);Rw/PA = Regular arm with parallel arm bracket
Hw/PA=Holdopenarmwithparallelarmbracket(PleasenoteholdopenarmcongurationsarenotULlisted.)
EDA = Extra Duty Parallel Arm; CUSH = Cush-n-stop; SCUSH = Spring cush-n-stop
116 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Door Closers - LCN & Falcon
Parts and Components
Series Number Product Description Finish List Price
1250 18 Drop Plate ALUM $42.00
1250 18PA Drop Plate - PA ALUM 42.00
1250 18 Drop Plate DKBRZ 42.00
1250 18PA Drop Plate - PA DKBRZ 42.00
1260 18 Drop Plate ALUM 42.00
1260 18PA Drop Plate - PA ALUM 42.00
1260 18 Drop Plate DKBRZ 42.00
1260 18PA Drop Plate - PA DKBRZ 42.00
1450 18 Drop Plate ALUM 54.00
1450 18PA Drop Plate - PA ALUM 54.00
1450 18FC Drop Plate (for Full Cover) ALUM 54.00
1450 18PAFC Drop Plate - PA (for Full Cover) ALUM 54.00
1450 18 Drop Plate DKBRZ 54.00
1450 18PA Drop Plate - PA DKBRZ 54.00
1450 18FC Drop Plate (for Full Cover) DKBRZ 54.00
1450 18PAFC Drop Plate - PA (for Full Cover) DKBRZ 54.00
1460 18 Drop Plate ALUM 54.00
1460 18PA Drop Plate - PA ALUM 54.00
1460 18FC Drop Plate (for Full Cover) ALUM 54.00
1460 18PAFC Drop Plate - PA (for Full Cover) ALUM 54.00
1460 18 Drop Plate DKBRZ 54.00
1460 18PA Drop Plate - PA DKBRZ 54.00
1460 18FC Drop Plate (for Full Cover) DKBRZ 54.00
1460 18PAFC Drop Plate - PA (for Full Cover) DKBRZ 54.00
4050 18 Drop Plate ALUM 54.00
4050 18PA Drop Plate PA ALUM 54.00
4050 18 Drop Plate DKBRZ 54.00
4050 18PA Drop Plate PA DKBRZ 54.00
Notes: AL=Aluminumnish(689);DKBRZ=Darkbronzenish(695)
117
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Door Closers - LCN & Falcon
Automatic Operators
4600 Series Auto Equalizer
9100 Series Benchmark
9500 Series Senior Swing
n Heavy duty electro hydraulic automatic operator
n Used when door is operated manually most of the time with
occasional automatic opening
n ANSI/BHMA 156.19, UL 10C, UL 325
n Mediium duty electromechanical automatic operator
n Used when door is operated electronically most of the time
n ANSI/BHMA 156.19, UL 325
n Heavy duty electromechanical automatic operator
n Used when door is operated electronically most of the time
n ANSI/BHMA 156.19, UL 325, UL 10C
Series Mounting Arms Finish Handing Cylinder Assembly Cover List Price
4630 Track AL - Std Metal $5,179.00
4630 Track DKBRZ - Std Metal 5,179.00
4642 Reg AL - Std Metal 5,091.00
4642 Reg DKBRZ - Std Metal 5,091.00
Series Mounting Arms Finish Handing Cylinder Assembly Cover List Price
9130 Track AL - Std Metal $3,462.00
9130 Track DKBRZ - Std Metal 3,462.00
9140 Std AL - Std Metal 3,407.00
9140 Std DKBRZ - Std Metal 3,407.00
4642 Reg DKBRZ - Std Metal 5,091.00
Series Mounting Arms Finish Handing Cylinder Assembly Cover List Price
9530 Track AL RH Std Metal $4,340.00
9530 Track AL LH Std Metal 4,340.00
9530 Track DKBRZ RH Std Metal 4,425.00
9530 Track DKBRZ LH Std Metal 4,425.00
9540 Std AL RH Std Metal 4,340.00
9540 Std AL LH Std Metal 4,340.00
9540 Std DKBRZ RH Std Metal 4,340.00
9540 Std DKBRZ LH Std Metal 4,340.00
118
Multi-family Door Closers - LCN & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
General Closer Information
Surface Mount SC Series
Certifications and Listings
1. SC60A, SC70A and SC80A Series Closers are certified to meet the requirements of ANSI Standard A156.4, Grade 1.
2. SC90A Series Closers are certified to meet the requirements of ANSI Standard A156.4, Grade 3.
3. SC60A, SC70A, SC80A, and SC90A Series Closers without hold-open arms are UL10C fire rated.
4. SC61A, SC71A, SC81A, and SC91A Series are designed to meet the American Disabilities Act (ADA) and ANSI A117.1.
5. SC93A (spring size 3) and SC94A (spring size 4) Series do not meet ADA force requirements.
Covers and Hardware:
1. SC80A Series Closers ship with a standard SLIM cover unless an optional FULL (FC) cover is added to the order line.
2. SC60A Series Closers ship as LESS cover unless an optional SLIM cover is added to the order line.
3. SC90A Series Closers ship LESS cover unless an option SLIM cover is added to order line.
4. ALL SC60A/70A/80A/93A/94A closer series are furnished with TBWMS and Self-Reaming and Tapping Screws.
Master Cartons
1. SC60A and SC80A RWPA are packed with six (6) identical closers per master carton. SC60A and SC80A HWPA, DS,
DSHO, HD, SS, and SSHO arms are packed 4 per master carton.
2. SC70A Series Closers are packed with four (4) identical closers per master carton.
Closer Finishes
Finish Code BHMA Finish Color Description
MTBK 622 Matte Black
AL 689 Silver Painted (Resembles Aluminum Finish)
DKB 695 Dark Bronze Painted (Spray Duranodic)
Price Book 5 | Effective January 8, 2018 | 800.847.1864 119
Multi-family Door Closers - LCN & Falcon
Surface Closer (SC) Options
RwPA HwPA HDPA FA FAHO
DS DSHO SS SSHO
Cylinder Options
n STD – Standard Cylinder. Cylinder will provide consistent door control
throughout the opening & closing cycle. Independent backcheck, main speed
and latch speed are field adjustable regulation valves and incorporated into
the cylinder.
n DEL – Delay Action Cylinder. Cylinder will provide consistent door control
throughout the opening & closing cycle but includes an extra regulation valve
that allows the door to slowly close (delay) as it begins to sends the door
back to latch (approximately 70°). Independent backcheck, main speed and
latch speed are field adjustable regulation valves and incorporated into the
cylinder.
Cover Options
n STD – Standard Cover. Cover will enclose the cylinder body with the
exception of the unused pinion shaft. A shaft cover will be included to cover
the unused pinion shaft.
n SLIM – Slim Cover. Cover will enclose the cylinder body with the exception
of the unused pinion shaft. A shaft cover will be included to cover the unused
pinion shaft.
n FULL – Full Cover. Cover will enclose the entire cylinder body, including the
unused pinion shaft.
Arm Options
n Rw/PA – Regular Arm with Parallel Arm Bracket. Includes adjustable
forearm assembly to accommodate a variety of door types and frame
conditions. Parallel Arm (PA) bracket allows closer to be installed on the
‘push’ side of the door in a parallel arm type configuration.
n Hw/PA – Hold Open Arm with Parallel Arm Bracket. Includes adjustable
forearm assembly to accommodate a variety of door types and frame
conditions. Parallel Arm (PA) bracket allows closer to be installed on the
‘push’ side of the door in a parallel arm type configuration. Hold open
function adjustable at the arm shoe.
n HD/PA – Heavy Duty Arm with Parallel Arm Bracket. Includes a stamped
steel main arm and forearm for added durability in potentially high traffic
and/or abusive applications. Parallel Arm (PA) bracket is a permanent
feature, installation on ‘push’ side of the door in a parallel arm type
configuration
is required.
n FA – Forged Arm. Extra heavy duty arm with parallel arm bracket. Includes
a forged steel main arm and forearm for maximum durability in high traffic
and/or abusive applications. Parallel Arm (PA) bracket is a permanent
feature, installation on ‘push’ side of the door in a parallel arm type
configuration is required.
n FA/HO – Forged Arm with Hold Open. Extra heavy duty arm with parallel
arm bracket that incorporates a hold open feature. Includes a forged steel
main arm and forearm for maximum durability in high traffic and/or abusive
applications. Parallel Arm (PA) bracket is a permanent feature, installation
on ‘push’ side of the door in a parallel arm type configuration is required.
n DS – Dead Stop Arm. Heavy duty arm with parallel arm bracket that
incorporates a positive mechanical stop. Includes a stamped steel main arm
and forearm for added durability in potentially high traffic and or abusive
applications. Parallel Arm (PA) bracket is a permanent feature, installation
on ‘push’ side of the door in a parallel arm type configuration is required.
n DS/HO – Dead Stop Arm with Hold Open. Heavy duty arm with parallel
arm bracket that incorporates a positive mechanical stop and hold open
feature.Includes a stamped steel main arm and forearm for added durability
in potentially high traffic and or abusive applications. Parallel Arm (PA)
bracket is a permanent feature, installation on ‘push’ side of the door in a
parallel arm type configuration is required. Hold open function is manually
selected with a ‘thumb turn’ feature built into the main portion of the arm.
n SS – Spring-n-Stop Arm. Extra heavy duty arm with parallel arm bracket
that incorporates an integral spring stop. Includes a forged steel main
arm and forearm for maximum durability in high traffic and/or abusive
applications. Parallel Arm (PA) bracket is a permanent feature, installation
on ‘push’ side of the door in a parallel arm type configuration is required.
n SS/HO – Spring-n-Stop Arm with Hold Open. Extra heavy duty arm
with parallel arm bracket that incorporates an integral spring stop and hold
open feature. Includes a forged steel main arm and forearm for maximum
durability in high traffic and/or abusive applications. Parallel Arm (PA)
bracket is a permanent feature, installation on ‘push’ side of the door in a
parallel arm type configuration is required.
Fastener Pack Option
n TBWMS – Through Bolt, Wood & Machine Screws. Fasteners for installation
on wood, hollow metal or aluminum store front type doors. Through bolts
for installations on 1¾" thick, hollow core doors are included. SC60A/SC70A/
SC80A/SC93A/SC94A faster pack will contain TBWMS and Self-Reaming
and Tapping Screws
ADA Accessibility Requirements
n Product Information – Closers are preset for standard spring power or can be
adjusted in the field to generate the 5lbs. of opening force (36" wide, interior
door) requirements for ADA (Sections 4.13.10 and/or 4.13.11) and the ANSI
Standard A117.1 (Sections 4.13.10 and/or 4.13.11).
Falcon has several options to meet your unique application and/or installation needs. See the options section on each series page in the Falcon Closer price list for
available options by series. Please contact Falcon Closer Customer Care at (877) 671-7011 for additional information. As always, we appreciate your business!
120
Multi-family Door Closers - LCN & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
SC60A Series Closers
SC60A Series Light-Medium Duty
Model Arm Type Shipping
Weight
AL (689)
DKB (695)
MTBK (622)1
SC61A RwPA 7 146
SC61A HwPA 7 166
SC61A HDPA17 166
SC61A DS 9183
SC61A DSHO19 204
SC61A SS19242
SC61A SSHO19 258
REFERENCE NOTES:
1) SC61A HD, DS/HO, SS, and SS/HO are not available in matte black.
2) SC61A ships standard as LESS cover.
3) SC61A is fully adjustable 1-5
Closer Parts and Accessories
Model Description Shipping
Weight List
SC61A-3071 Standard Cylinder 9 90
SC60A-72 Slim Cover 1 15
SC60A-3077/PA Regular Arm w/ PA Bracket 3 56
SC60A-3049/PA Hold Open Arm w/ PA Bracket 3 76
SC60A-3077HD Heavy Duty Parallel Arm1 3 76
SC60A-3077DS Dead Stop Parallel Arm 5 93
SC60A-3049DS Hold Open Dead Stop Parallel Arm15114
SC60A-3077SS Spring N Stop Arm15152
SC60A-3049SS Hold Open Spring N Stop Arm15 168
SC60A-18 Mounting Plate - Top Jamb 2 29
SC60A-18PA Mounting Plate - Push Side 2 29
SC60A-30 Cush Shoe Support 1 19
SC60A-61 Blade Stop Spacer 1 21
SSC60A-62A Offset Auxiliary Shoe 1 24
REFERENCE NOTES:
1) SC61A, HD, DS/HO, SS, and SS/HO arms are not available in matte black.
2)MatteBlackandDarkBronzeCloserssharethesamescrewnish.
Closer Options
Sufx Description List Adder
SLIM SLIM Cover 15
60A Series
SC70-62A
SC60A-18
SC60A-18PA
SC60A-62A
Price Book 5 | Effective January 8, 2018 | 800.847.1864 121
Multi-family Door Closers - LCN & Falcon
SC70PA-18
SC70A Series Heavy Duty
Model Arm Type Shipping
Weight
AL (689)
DKB (695)
MTBK (622)1
SC71A RwPA 10 287
SC71A HwPA 10 307
SC71A HDPA 11 307
SC71A FA1 11 322
SC71A FAHO111 343
SC71A DS 11 324
SC71A DSHO112 345
SC71A SS112 383
SC71A SSHO112 399
REFERENCE NOTES:
1) SC71 FA, FA/HO, DS/HO, SS, and SS/HO are not available in matte black.
2) SC71 ships standard with a FULL Cover.
3) SC71 is fully adjustable 1-6
Closer Parts and Accessories
Model Description Shipping
Weight List
SC71A-3071 Standard Cylinder 12 216
SC71A-3071DEL Delay Cylinder112 246
SC70A-72 FULL Cover 1 15
SC70A-3077/PA Regular Arm w/ PA Bracket 3 56
SC70A-3049/PA Hold Open Arm w/ PA Bracket 3 76
SC70A-3077HD Heavy Duty Parallel Arm 3 76
SC70A-3077FA Forged Parallel Arm13 91
SC70A-3049FA Hold Open Forged Parallel Arm13112
SC70A-3077DS Dead Stop Parallel Arm 5 93
SC70A-3049DS Hold Open Dead Stop Parallel Arm15114
SC70A-3077SS Spring N Stop Arm15152
SC70A-3049SS Hold Open Spring N Stop Arm15 168
SC70A-18 Narrow Frame Back Plate 3 49
SC70A-18PA Narrow Top Rail Drop Plate 4 49
SC70A-30 Cush Shoe Support 1 19
SC70A-61 Blade Stop Spacer 1 21
SC70A-62A Offset Auxiliary Shoe 1 24
REFERENCE NOTE:
1) SC71A FA, FA/HO, DS/HO, SS, and SS/HO arms are not available in matte black.
2)MatteBlackandDarkBronzeCloserssharethesamescrewnish.
SC70A Series
SC70-62A
SC70A-18PA
SC70A-18
SC70-18
SC70A-62A
SC70A Series Closers
122
Multi-family Door Closers - LCN & Falcon
Price Book 5 | Effective January 8, 2018 | 800.847.1864
SC80A Series Closers
SC80A Series Medium Duty
Model Arm Type Shipping
Weight
AL (689)
DKB (695)
MTBK (622)1
SC81A RwPA 8 183
SC81A HwPA 8 203
SC81A HDPA110 203
SC81A DS 10 220
SC81A DSHO110 239
SC81A SS110 279
SC81A SSHO110 295
REFERENCE NOTES:
1) SC81A ships standard with a SLIM Cover.
2) SC81A is fully adjustable 1-6
Closer Parts and Accessories
Model Description Shipping
Weight List
SC81A-3071 Standard Cylinder 10 117
SC80A-72 Slim Cover 1 10
SC81A-72FC FULL Cover 1 15
SC81A-3077/PA Regular Arm w/ PA Bracket 3 56
SC81A-3049/PA Hold Open Arm w/ PA Bracket 3 76
SC81A-3077HD Heavy Duty Parallel Arm1 3 76
SC81A-3077DS Dead Stop Parallel Arm 5 93
SC81A-3049DS Hold Open Dead Stop Parallel Arm15114
SC81A-3077SS Spring N Stop Arm15152
SC81A-3049SS Hold Open Spring N Stop Arm15 168
SC81A-18 Mounting Plate - Top Jamb 2 29
SC81A-18FC Mounting Plate - Top Jamb for FULL Cover 2 29
SC81A-18PA Mounting Plate - PA 2 29
SC81A-18PAFC Mounting Plate - PA for FULL Cover 2 29
SC81A-30 Cush Shoe Support 1 19
SC81A-61 Blade Stop Spacer 1 21
SC81A-62A Offset Auxiliary Shoe 1 24
REFERENCE NOTE:
1) SC80A delay action, HD, DS/HO, SS, and SS/HO arms are not available in matte black.
2)MatteBlackandDarkBronzeCloserssharethesamescrewnish.
Closer Options
Sufx Description List Adder
FC FULL Cover 5
SC80A
(w/ full cover shown)
SC80A-18PA
SC80A-18
SC70-62A
SC80 A-62A
Price Book 5 | Effective January 8, 2018 | 800.847.1864 123
Multi-family Door Closers - LCN & Falcon
SC90A Series Light- Residential Duty
Model Arm Type Size
Shipping
Weight
AL (689)
DKB (695)
SC91A RwPA 1 5 107
SC91A HwPA 1 5 127
SC93A RwPA 3 5 107
SC93A HwPA 3 5 127
SC94A RwPA 4 5 107
SC94A HwPA 4 5 127
REFERENCE NOTES:
1) SC90 series ship standard as LESS Cover.
2) *Brass will not be available with SC91A/SC93A/SC94A.
Closer Parts and Accessories
Model Description Shipping
Weight List
SC90A-18 Mounting Plate - Top Jamb 2 29
SC90A-18PA Mounting Plate - Push Side 2 29
Closer Options
Sufx Description List Adder
STD StandardCover(Onlyts93and94models) 15
SC90A Series
SC90A-18PA
(SC93A/94A only)
SC90A-18
(SC93A/94A only)
SC90A Series Closers
124 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Architectural Hardware - Ives & Schlage
3CB1
Continuous Hinges
Number Description Finish Price Each
112HD 83" Continuous Geared, Heavy Duty 83" Length US28 $163.50
224HD 83" Continuous Geared with Edge Protector, Heavy Duty, 83" US28 174.50
700 83" Continuous Pin & Barrel, 83" US32D 488.50
700 95" Continuous Pin & Barrel, 95" US32D 565.50
705 83" Continuous Pin & Barrel, Full Wrap, 83" US32D 637.50
Architectural Hinges
Number Description Finish Price Each
3CB1 4.5x4.5 3 Knuckle Plain Bearing US26D (652) $7.30
3CB1 4.5x4.5 3 Knuckle Concealed Bearing US32D (630) 55.30
3CB1 4.5x4.5 NRP 3 Knuckle Concealed Bearing NRP US26D (652) 15.35
3CB1 4.5x4.5 NRP 3 Knuckle Concealed Bearing NRP US32D (630) 59.05
3CB1 HW 4.5x4.5 3 Knuckle Concealed Bearing Heavy Wt. US26D (652) 40.00
3CB1 HW 4.5x4.5 NRP 3 Knuckle Concealed Bearing Heavy Wt. NRP US26D (652) 43.75
3CB1 HW 4.5x4.5 NRP 3 Knuckle Concealed Bearing Heavy Wt. NRP US32D (630) 88.55
3CB1 HW 5x4.5 3 Knuckle Concealed Bearing Heavy Wt. US26D (652) 46.00
3SP1 4.5x4.5 3 Knuckle Spring US26D (652) 23.30
5PB1 4.5x4.5 5 Knuckle Plain Bearing US26D (652) 7.30
5PB1 4.5x4.5 NRP 5 Knuckle Plain Bearing NRP US26D (652) 11.05
5BB1 4.5x4 5 Knuckle Ball Bearing US26D (652) 14.40
5BB1 4.5x4 NRP 5 Knuckle Ball Bearing NRP US26D (652) 22.40
5BB1 4.5x4.5 5 Knuckle Ball Bearing US26D (652) 10.70
5BB1 4.5x4.5 5 Knuckle Ball Bearing US32D (630) 39.30
5BB1 4.5x4.5 5 Knuckle Ball Bearing USP (600) 9.60
5BB1 4.5x4.5 5 Knuckle Ball Bearing US10B (613) 40.10
5BB1 4.5x4.5 5 Knuckle Ball Bearing US15 (619) 40.10
5BB1 4.5x4.5 5 Knuckle Ball Bearing US3 (632) 16.70
5BB1 4.5x4.5 5 Knuckle Ball Bearing US4 (633) 10.70
5BB1 4.5x4.5 5 Knuckle Ball Bearing US10 (639) 13.30
5BB1 4.5x4.5 5 Knuckle Ball Bearing US10B (640) 16.70
5BB1 4.5x4.5 5 Knuckle Ball Bearing US15 (646) 20.30
5BB1 4.5x4.5 5 Knuckle Ball Bearing US26 (651) 16.70
5BB1 4.5x4.5 NRP 5 Knuckle Ball Bearing NRP US26D (652) 14.45
5BB1 4.5x4.5 NRP 5 Knuckle Ball Bearing NRP US32D (630) 43.05
5BB1 4.5x4.5 NRP 5 Knuckle Ball Bearing NRP USP (600) 13.35
5BB1 4.5x4.5 NRP 5 Knuckle Ball Bearing NRP US10B (613) 48.10
5BB1 4.5x4.5 NRP 5 Knuckle Ball Bearing NRP US15 (619) 48.10
5BB1 4.5x4.5 NRP 5 Knuckle Ball Bearing NRP US10B (640) 20.45
5BB1 4.5x4.5 NRP 5 Knuckle Ball Bearing NRP US15 (646) 24.05
5BB1 5x4.5 5 Knuckle Ball Bearing US26D (652) 22.50
5BB1 5x4.5 NRP 5 Knuckle Ball Bearing NRP US26D (652) 30.50
5BB1 5x4.5 NRP 5 Knuckle Ball Bearing NRP US32D (630) 58.00
5BB1 HW 4.5x4.5 5 Knuckle Ball Bearing Heavy Wt. US26D (652) 31.10
5BB1 HW 4.5x4.5 5 Knuckle Ball Bearing Heavy Wt. US32D (630) 64.30
5BB1 HW 4.5x4.5 NRP 5 Knuckle Ball Bearing Heavy Wt. NRP US26D (652) 34.85
5BB1 HW 4.5x4.5 NRP 5 Knuckle Ball Bearing Heavy Wt. NRP US32D (630) 68.05
5BB1 HW 4.5x4.5 NRP 5 Knuckle Ball Bearing Heavy Wt. NRP US10B (613) 74.80
5BB1 HW 4.5x4.5 NRP 5 Knuckle Ball Bearing Heavy Wt. NRP US15 (619) 69.90
5BB1 HW 5x4.5 5 Knuckle Ball Bearing Heavy Wt. US26D (652) 35.80
5BB1 HW 5x4.5 5 Knuckle Ball Bearing Heavy Wt. US32D (630) 75.10
5BB1 HW 5x4.5 NRP 5 Knuckle Ball Bearing Heavy Wt. NRP US26D (652) 43.80
5BB1 HW 5x4.5 NRP 5 Knuckle Ball Bearing Heavy Wt. NRP US32D (630) 83.10
5BB1 SC 4.5 5 Knuckle Ball Bearing Swing Clear US26D (652) 56.10
5BB1 HW BSC 4.5 5 Knuckle Ball Bearing Heavy Wt. Beveled Swing Clear Heavy Wt. US26D (652) 67.90
5BB1 HW BSC 5 5 Knuckle Ball Bearing Heavy Wt. Beveled Swing Clear Heavy Wt. US26D (652) 67.90
Architectural Door Hinges
Price Book 5 | Effective January 8, 2018 | 800.847.1864 125
Multi-family Architectural Hardware - Ives & Schlage
7253 Pivot Set
7253 Pivot Set
7253 91105F
7255 Pivot Set
7255 Pivot Set
7255
pocket_pivot_flush_bolt
Intermediate Pivot
7215-7226-7227 INT
7215F-7226F-7227F INT
7215-7226-7227 INT
Pocket Pivot
Number Description Finish Price Each
91105F Pocket Pivot, Fire Rated US32D $401.50
Note: Pocket pivots are sold individually.
Pivot Set
Number Description Handing Finish Price Each
7215 SET RH 3/4" Offset Pivot Set, 500 lb RH US26D $375.10
7215 SET LH 3/4" Offset Pivot Set, 500 lb LH US26D 375.10
7226 SET 3/4" Offset Pivot Set, 600 lb - US26D 358.80
7230F SET 3/4" Offset Pivot Set, 1000 lb, Fire Rated - US32D 669.90
7253 SET Center Hung Pivot Set, 300 lb - US26D 297.00
7255 SET Center Hung Pivot Set, 500 lb - US26D 327.40
Note: Set includes top-and-bottom pivots.
Intermediate Pivots
Number Description Handing Finish Price Each
7215-7226-7227 INT RH 3/4" Offset Intermediate Pivot for 7215, 7226 and 7227 RH US26D $202.80
7215-7226-7227 INT LH 3/4" Offset Intermediate Pivot for 7215, 7226 and 7227 LH US26D 202.80
7230F-7237F INT RH 3/4" Offset Intermediate Pivot for 7230F and 7237F, Fire Rated RH US32D 375.10
7230F-7237F INT LH 3/4" Offset Intermediate Pivot for 7230F and 7237F, Fire Rated LH US32D 375.10
Pivots
126 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Architectural Hardware - Ives & Schlage
FS436 FS18S FS40 FS441 FS444 FS446
FS452 FS544 FS1153 FS1154
Floor Stops, Dome Stops and Kick Downs
Number Description Finish Price Each
FS13 Dome Stop US26D $7.40
FS436 Dome Stop US26D 5.30
FS436 Dome Stop US3 6.30
FS436 Dome Stop US10B 7.30
FS436 Dome Stop US15 7.30
FS436 Dome Stop US26 6.60
FS436 Dome Stop US28 4.80
FS438 Dome Stop for use with Thresholds US26D 5.90
FS438 Dome Stop for use with Thresholds US10B 8.50
FS438 Dome Stop for use with Thresholds US15 10.80
FS438 Dome Stop for use with Thresholds US26 8.00
FS438 Dome Stop for use with Thresholds US28 5.80
R435-1/2 1/2" Riser for FS436 Dome Stop US27 6.00
FS18L Security Floor Stop, 3-1/2" Bumper - 15.50
FS18S Security Floor Stop, 1-1/2" Bumper - 11.00
FS434 Floor Stop, Angle US2C 8.50
FS441 Floor Stop US26D 21.20
FS441 Floor Stop US10B 23.40
FS441 Floor Stop US15 30.10
FS444 Floor Stop, Heavy-Duty, Masonry US26D 24.90
FS444 Floor Stop, Heavy-Duty, Masonry US10B 30.50
FS444 Floor Stop, Heavy-Duty, Masonry US15 33.10
FS448 Floor Stop, Heavy-Duty, Drywall/Wood US26D 29.00
FS448 Floor Stop, Heavy-Duty, Drywall/Wood US10B 28.10
FS40 Floor Stop w/ Automatic Holder, 1/2" Door to Floor Clearance US26D 58.40
FS446 Floor Stop w/ Manual Holder, Heavy-Duty, Masonry US26D 36.50
FS446 Floor Stop w/ Manual Holder, Heavy-Duty, Masonry US10B 45.60
FS446 Floor Stop w/ Manual Holder, Heavy-Duty, Masonry US15 47.50
FS450 Floor Stop w/ Manual Holder, Heavy-Duty, Drywall/Wood US26D 39.60
FS452-4" Kick Down Holder, 4" US26D 27.00
FS452-4" Kick Down Holder, 4" US15 38.40
FS452-5" Kick Down Holder, 5" US26D 33.50
FS452-5" Kick Down Holder, 5" US10B 38.90
FS452-5" Kick Down Holder, 5" US15 43.80
FS455-4" Kick Down Holder, 4" US26D 36.60
FS455-4" Kick Down Holder, 4" US3 30.50
FS455-4" Kick Down Holder, 4" US10B 36.60
FS455-4" Kick Down Holder, 4" US27 7.50
FS455-4" Kick Down Holder, 4" US3AL 7.50
FS544-4" Kick Down Holder, 4" SP28 11.30
FS544-4" Kick Down Holder, 4" SP4 11.30
FS555-5" Kick Down Holder, 5" SP28 12.00
FS544/555 Kick Down Holder - Rubber w/ Screw (Use P/N FSPART.1074 when ordering) 2.90
FS1153 Plunger-Type Door Holder — 1-5/8" Throw US28 45.60
FS1154 Plunger-Type Door Holder — 1-1/4" Throw US10 82.20
Floor Stops
Price Book 5 | Effective January 8, 2018 | 800.847.1864 127
Multi-family Architectural Hardware - Ives & Schlage
WS40 WS45 WS401/402CCV
WS401/402CVX WS404CVX WS406/407CCV WS406/407CVX WS445
Wall Stops
Number Description Screw Pkg. Finish Price Each
060F26D Residential, Flexible Door Stop, 3" F26D $1.10
060F10B Residential, Flexible Door Stop, 3" F10B 1.10
060F14 Residential, Flexible Door Stop, 3" F14 1.10
060F15 Residential, Flexible Door Stop, 3" F15 1.10
63F619E Residential, Flexible Door Stop, 3" 63F619E 1.00
63F716E Residential, Flexible Door Stop, 3" F716E 1.00
60A92 Residential, Solid Door Stop, 3-3/4" A92 3.30
61A92 Residential, Solid Door Stop, 3-1/8" A92 3.30
61A10B Residential, Solid Door Stop, 3-1/8" A10B 3.30
61A14 Residential, Solid Door Stop, 3-1/8" A14 3.30
61A15 Residential, Solid Door Stop, 3-1/8" A15 3.30
61A-W Residential, Solid Door Stop, 3-1/8" A-W 3.60
61B15 Residential, Solid Door Stop, 3-1/8" B15 15.60
60-5/062/70/430 Replacement Rubber Tips for 60, 61, 70 Stops (100/PKG) 79.50
69F14 Hinge Pin Door Stop (70-100 Degree Adjustment) F14 4.20
69F15 Hinge Pin Door Stop (70-100 Degree Adjustment) F15 4.20
70A92 Hinge Pin Door Stop (85-125 Degree Adjustment) A92 2.20
70A-716 Hinge Pin Door Stop (85-125 Degree Adjustment) A-716 2.50
70A10B Hinge Pin Door Stop (85-125 Degree Adjustment) A10B 2.50
70A15 Hinge Pin Door Stop (85-125 Degree Adjustment) A15 2.50
70B10B Hinge Pin Door Stop (85-125 Degree Adjustment) B10B 13.90
70B15 Hinge Pin Door Stop (85-125 Degree Adjustment) B15 13.90
WS401/402CCV Wall Bumper, Cast, Concave Drywall & Wood US26D 18.20
WS401/402CVX Wall Bumper, Cast, Convex Drywall & Wood US26D 6.60
WS404CVX Wall Bumper, Compact, Convex Drywall & Wood US26D 3.10
WS406/407-CCV Wall Bumper, Concave Drywall & Wood US32D 3.80
WS406/407-CCV Wall Bumper, Concave Drywall & Wood US3 4.30
WS406/407-CCV Wall Bumper, Concave Drywall & Wood US10 4.30
WS406/407-CCV Wall Bumper, Concave Drywall & Wood US10B 3.10
WS406/407-CVX Wall Bumper, Convex Drywall & Wood US32D 4.30
WS406/407-CVX Wall Bumper, Convex Drywall & Wood US10B 4.30
WS406/407-CVX Wall Bumper, Convex Drywall & Wood US15 4.30
411R-W Wall Bumper, Adhesive Back R-W 2.80
WS33 Wall Stop Drywall & Wood US26D 49.70
WS447 Wall Stop, Heavy-Duty Drywall & Wood US26D 37.00
WS445 Wall Stop w/ Manual Holder, Heavy-Duty Masonry US26D 64.60
WS40 Wall Stop w/ Automatic Holder Universal US26D 98.50
WS45 Wall Stop w/ Automatic Holder Universal US26D 137.10
FS495 Wall Stop w/ Automatic Holder US26D 79.70
CS115-20 Crash Stop --- US26D 46.10
Wall Stops
128 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Architectural Hardware - Ives & Schlage
83028200
Kick Plates
Number Size Finish Price Each
8400 8" x 34" B-CS US32D $33.41
8400 10" x 34" B-CS US32D 41.77
8400 10" x 35" B-CS US32D 44.23
Push Plates
Number Size Finish Price Each
8200 Push Plate 3.5x15 US32D $12.30
8200 Push Plate 3.5x15 US10B 26.30
8200 Push Plate 3.5x15 US15 26.30
8200 Push Plate 3.5x15 US28 10.00
8200 Push Plate 4x16 US32D 14.30
8200 Push Plate 4x16 US10B 29.80
8200 Push Plate 4x16 US15 29.80
8200 Push Plate 4x16 US26D 28.60
8200 Push Plate 4x16 US28 9.50
8200 Push Plate 6x16 US32D 19.50
8200 Push Plate 8x16 US32D 27.30
Pull Plates
Number Size Center to Center Finish Price Each
8302-6 8102 6" Pull and Plate 4x16 1-3/4" 6" US32D $44.40
8302-8 8102 8" Pull and Plate 3.5x15 1-3/4" 8" US32D 46.30
8302-8 8102 8" Pull and Plate 4x16 1-3/4" 8" US32D 48.20
8302-0 8102 10" Pull and Plate 3.5x15 1-3/4" 10" US32D 51.80
8302-0 8102 10" Pull and Plate 4x16 1-3/4" 10" US32D 53.70
8303-8 8103 8" Pull and Plate 4x16 1-3/4" 8" US32D 71.80
8303-0 8103 10" Pull and Plate 4x16 1-3/4" 10" US32D 78.60
Offset Door Pulls
Number Size Center to Center Finish Price Each
8190HD-0 90 Degree Offset 10" Pull, Heavy Duty, 1-3/4" 10" US32D $84.60
8190HD-0 90 Degree Offset 10" Pull, Heavy Duty, 1-3/4" 10" US10B 129.50
8190HD-0 90 Degree Offset 10" Pull, Heavy Duty, 1-3/4" 10" US15 134.90
8190HD-2 90 Degree Offset 12" Pull, Heavy Duty, 1-3/4" 12" US32D 91.20
8190HD-0 90 Degree Offset 10" Pull, Heavy Duty, 1-3/4" (Dec. Thru-Bolt) 10" US32D 112.60
8190HD-2 90 Degree Offset 12" Pull, Heavy Duty, 1-3/4" (Dec. Thru-Bolt) 12" US32D 119.20
9190HD-33-0 33" Pushbar/90 Degree Offset 10" Pull, Heavy Duty, 1-3/4" 33", 10" US32D 262.10
Pulls
Number Size Finish Price Each
221B26D Flush Pull, Large Circle B26D $4.20
221B10B Flush Pull, Large Circle B10B 4.20
221B15 Flush Pull, Large Circle B15 4.00
222B26D Flush Pull, Rectangular B26D 23.50
223B26D Flush Pull, Oval B26D 7.10
227B26D Flush Pull, Deep Well B26D 10.90
230B26D Sliding Door Edge Pull B26D 15.30
990B-613 Sliding Door Pull B-613 12.80
990B-619 Sliding Door Pull B-619 12.80
991B-613 Sliding Door Pull - Locking B-613 17.80
991B-619 Sliding Door Pull - Locking B-619 17.80
991B-716 Sliding Door Pull - Locking B-716 17.80
8103HD-0 Straight 10" Pull, Heavy Duty, 1" Diameter US32D 62.60
8103EZHD-0 Straight 10" Pull, ADA Compliant, Heavy Duty, 1" Diameter 32D-316 86.50
Pulls and Protection Plates
Price Book 5 | Effective January 8, 2018 | 800.847.1864 129
Multi-family Architectural Hardware - Ives & Schlage
Vandal Resistant Trim
Number Description Finish Price Each
VR910NL Vandal Resistant Trim 98/99 Rim or Vertical Rod, Horizontal Keyway US32D $264.60
VR910-DT Vandal Resistant Trim 98/99 Rim or Vertical Rod, Blank Trim US32D 264.60
Vandal Resistant Trim
Flush Bolts & Strikes
FB358 FB458 FB31P
fb61p–flush_bolts
fb61p–flush_bolts
FB61P DP1 DP2
Dust-Proof Strikes
Number Description Finish Price Each
DP1 Dust-Proof Strike — Threshold Only US26D $25,70
DP2 Dust-Proof Strike — Floor and/or Threshold US26D 32.40
DP2 Dust-Proof Strike — Floor and/or Threshold US10B 32.40
Flush Bolts
Number Description Door Type Finish Price Each
FB358 Manual Flush Bolt, Single Door Wood US26D $35.40
FB358 Manual Flush Bolt, Single Door Wood US10B 35.40
FB358 Manual Flush Bolt, Single Door Wood US15 35.40
FB457 Manual Flush Bolt, Single Door Metal US26D 26.20
FB458 Manual Flush Bolt, Single Door Metal US26D 20.70
FB458 Manual Flush Bolt, Single Door Metal US3 22.20
FB458 Manual Flush Bolt, Single Door Metal US15 22.20
FB31P Automatic Flush Bolt, Pair Metal US32D 182.10
FB41P Automatic Flush Bolt, Pair Wood US32D 190.40
FB51P Constant Latching Flush Bolt, Pair Metal US32D 182.10
FB61P Constant Latching Flush Bolt, Pair Wood US32D 192.20
262B26D Manual Flush Bolt B26D 31.60
262B3 Manual Flush Bolt B3 27.50
262B10B Manual Flush Bolt B10B 31.60
262B Manual Flush Bolt B15 31.60
FB256/7/8/457/8/0458-18" Manual Flush Bolt Rod - 18" (Use P/N 09-161 when ordering) 5.80
FB256/7/8/457/8/0458-24" Manual Flush Bolt Rod - 24" (Use P/N 09-162 when ordering) 5.80
FB256/7/8/457/8/0458-36" Manual Flush Bolt Rod - 36" (Use P/N 09-172 when ordering) 5.80
130 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Architectural Hardware - Ives & Schlage
Coordinators, Lock Guards, & Surface Bolts
LG1 SB453 SB1630BLG10 LG13CB1
Lock Guards
Number Description Finish Price Each
LG1 Lock Guard with Security Pin US32D $40.90
LG1 Lock Guard with Security Pin US2G 17.70
LG10 Lock Guard US32D 38.20
LG12 Lock Guard US32D 35.50
LG13 Lock Guard US32D 34.10
LG14 Lock Guard US32D 56.00
Coordinators and Accessories
Number Description Finish Price Each
COR52w/FL 20 Coordinator Bar, 52" Overall Length w/ 20" Filler Bar US28 $158.90
COR52 Coordinator Bar, 52" Overall Length US28 145.20
FL20 Filler Bar, 20" Overall Length US28 13.70
MB1 Mounting Bracket — Stops over 2-1/2" SP28 28.00
MB1 Mounting Bracket — Stops over 2-1/2" USP 19.60
MB2 Mounting Bracket — Stops up to 2-1/2" SP 28 31.60
MB2 Mounting Bracket — Stops up to 2-1/2" USP 23.10
CB1 Carry Bar USP 32.30
Surface Bolts
Number Description Finish Price Each
40-4 B26D 4" Decorative Surface Bolt, Light Duty B26D $17.50
054B26D Dutch Door Bolt B26D 46.00
SB360-12" 12" Surface Bolt, Heavy Duty, Universal Strike US2C 111.40
SB453-8"-TB 8" Surface Bolt, Top and Bottom Strikes US2C 40.60
SB1630B 8" Surface Bolt, Bottom Strike US2G 41.90
SB1630T 8" Surface Bolt, Top Strike US2G 46.50
SB1630TB 8" Surface Bolt, Top and Bottom Strikes US2G 55.10
Price Book 5 | Effective January 8, 2018 | 800.847.1864 131
Multi-family Architectural Hardware - Ives & Schlage
Latches & Catches
CL11 CL14 CL21A RL30 RL36 RL38 RL1152 SR64
Door Silencers
Number Description Finish Price Each
SR64 Door Silencers for Metal Frames, Bag of 100 Metal Gray $31.10
SR65 Door Silencer for Wood Frames, Bag of 100 Wood Gray 31.10
Roller Latches, Invisible Latches, and Ball-Type or Cabinet Catch
Number Description Finish Price Each
RL30 RollerLatch,Hightrafc US26D $63.90
RL32 Roller Latch, Light-Duty, Mortise US26D 86.40
RL36 Roller Latch, Light-Duty, Mortise US32D 48.70
RL38 Roller Latch, Light-Duty, Surface Mounted US32D 46.00
RL1152 Roller Latch with Angle Stop US26D 127.30
CL11 Invisible Latch, 7/16" x 1-1/4" x 1-7/8" US26D 32.90
CL12 Invisible Latch, 9/16" x 1-1/4" x 2-1/4" US26D 42.60
CL14 Invisible Latch Auxiliary Pusher US26D 37.10
CL21A Ball Catch, Four-Way, Full Size Doors US26D 34.50
CL22 Ball Catch, Three-Way, Smaller Doors US26D 23.30
325A92 Magnetic Catch, Light Duty, Single Magnet A92 2.90
326A92 Magnetic Catch, Heavy Duty, Two Magnet A92 8.10
327A92 Magnetic Catch, Heavy Duty, Four Magnet A92 13.80
335B10B Roller Catch, Adjustable B10B 16.40
336B15 Roller Catch Adjustable B15 16.40
347B26D Ball Catch, Square Corners B26D 13.60
347B10B Ball Catch, Square Corners B10B 13.00
347B15 Ball Catch, Square Corners B15 13.60
347B26 Ball Catch, Square Corners B26 13.60
349B26D Ball Catch, Round Corners B26D 14.20
349B3 Ball Catch, Round Corners B3 12.00
349B15 Ball Catch, Round Corners B26 14.70
2A92 Cabinet Catch, Elbow A92 4.00
2A3 Cabinet Catch, Elbow A3 4.00
42B10B Pocket Door Bolt B10B 15.20
42B15 Pocket Door Bolt B15 14.60
42B26 Pocket Door Bolt B26 15.20
132 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Architectural Hardware - Ives & Schlage
Miscellaneous Hardware
Door Guard
Number Description Finish Price Each
482 Door Guard, Solid Bar B26D $34.50
Window Lock
Number Description Finish Price Each
07B3 Window Lock B3 $16.40
07B15 Window Lock US15 20.70
Hooks
Number Description Finish Price Each
405 Coat & Hat Hook A92 $2.50
571 Coat & Hat Hook A92 1.20
571 Coat & Hat Hook A3 1.20
571 Coat & Hat Hook B10B 9.60
571 Coat & Hat Hook B15 10.20
572 Coat & Hat Hook B26D 13.40
580 Ceiling Hook A92 2.80
581 Wardrobe Hook A92 1.60
582 Double Wardrobe Hook A92 1.80
582 Double Wardrobe Hook B26D 8.70
Viewer
Number Description Finish Price Each
U696B26D One Way Viewer, UL Listed B26D $16.00
698 One Way Viewer, Wide Angle B26D 18.80
U698B26D One Way Viewer, Wide Angle, UL Listed B26D 22.50
U698B3 One Way Viewer, Wide Angle, UL Listed B3 22.50
700B26D One Way Viewer, Narrow Angle B26D 8.00
U700B26D One Way Viewer, Narrow Angle, UL Listed B26D 10.90
Handrail Bracket
Number Description Finish Price Each
059A92 Handrail Bracket A92 $3.40
059A-BLK Handrail Bracket A-BLK 4.60
059A-W Handrail Bracket A-W 4.60
59A3 Handrail Bracket A3 3.50
59A15 Handrail Bracket A15 4.50
59B15 Handrail Bracket B15 22.70
59A716 Handrail Bracket A716 4.50
HB159 Handrail Bracket US27 15.70
133
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Architectural Hardware - Ives & Schlage
Schlage Residential Barn Door Hardware
Top Mount
Description Finish Track Length SKU Price Special Order
SD10-6.6 619 TMNT N N SL, Satin Nickel Top Mount 619 6ft 6in 043156002788 $257.00
SD10-6.6 622 TMNT N N SL, Black Top Mount 622 6ft 6in 043156002795 $163.00
SD10-6.6 630 TMNT N N SL, Stainless Steel Top Mount 630 6ft 6in 043156002801 $324.00
SD10-6.6 716 TMNT N N SL, Aged Bronze Top Mount 716 6ft 6in 043156002825 $250.00
SD10-6.6- Dark Bronze (690) Top Mount 690 6ft 6in 043156002818 $163.00 Extended Lead Time
SD10-8.0 619 TMNT N N SL, Satin Nickel Top Mount 619 8ft 043156002986 $264.00
SD10-8.0 622 TMNT N N SL, Black Top Mount 622 8ft 043156002993 $167.00
SD10-8.0 630 TMNT N N SL, Stainless Steel Top Mount 630 8ft 043156003006 $331.00
SD10-8.0 716 TMNT N N SL, Aged Bronze Top Mount 716 8ft 043156003020 $248.00
SD10-8.0- Dark Bronze(690) Top Mount 690 8ft 043156003013 $169.00 Extended Lead Time
J-Strap
Description Finish Track Length SKU Price Special Order
SD10-6.6 619 JSTP N N SL, Satin Nickel J-Strap 619 6ft 6in 043156002634 $257.00
SD10-6.6 622 JSTP N N SL, Black J-Strap 622 6ft 6in 043156002641 $163.00
SD10-6.6 630 JSTP N N Sl, Stainless Steel J-Strap 630 6ft 6in 043156002658 $324.00
SD10-6.6 716 JSTP N N SL, Aged Bronze J-Strap 716 6ft 6in 043156002672 $250.00
SD10-6.6- Dark Bronze (690) J-Strap 690 6ft 6in 043156002665 $163.00 Extended Lead Time
SD10-8.0 619 JSTP N N SL, Satin Nickel J-Strap 619 8ft 043156002832 $264.00
SD10-8.0 622 JSTP N N SL, Black J-Strap 622 8ft 043156002849 $167.00
SD10-8.0 630 JSTP N N SL, Stainless Steel J-Strap 630 8ft 043156002856 $331.00
SD10-8.0 716 JSTP N N SL, Aged Bronze J-Strap 716 8ft 043156002870 $248.00
SD10-8.0- Dark Bronze (690) J-Strap 690 8ft 043156002863 $169.00 Extended Lead Time
134 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family Architectural Hardware - Ives & Schlage
Schlage Residential Sliding Door Hardware (continued)
I-Strap
Description Finish Track Length SKU Price Special Order
SD10-6.6- Satin Nickel (619) I-Strap 619 6ft 6in 043156002689 $257.00 Extended Lead Time
SD10-6.6- Black (622) I-Strap 622 6ft 6in 043156002696 $163.00 Extended Lead Time
SD10-6.6- Stainless Steel (630) I-Strap 630 6ft 6in 043156002702 $324.00 Extended Lead Time
SD10-6.6- Aged Bronze (716) I-Strap 716 6ft 6in 043156002726 $250.00 Extended Lead Time
SD10-6.6- Dark Bronze (690) I-Strap 690 6ft 6in 043156002719 $163.00 Extended Lead Time
SD10-8.0- Satin Nickel (619) I-Strap 619 8ft 043156002887 $264.00 Extended Lead Time
SD10-8.0- Black (622) I-Strap 622 8ft 043156002894 $167.00 Extended Lead Time
SD10-8.0- Stainless Steel (630) I-Strap 630 8ft 043156002900 $331.00 Extended Lead Time
SD10-8.0- Aged Bronze (716) I-Strap 716 8ft 043156002924 $248.00 Extended Lead Time
SD10-8.0- Dark Bronze (690) I-Strap 690 8ft 043156002917 $169.00 Extended Lead Time
Decorative Strap
Description Finish Track Length SKU Price Special Order
SD10-6.6- Satin Nickel (619) Decorative Strap 619 6ft 6in 043156002733 $257.00 Extended Lead Time
SD10-6.6- Black (622) Decorative Strap 622 6ft 6in 043156002740 $163.00 Extended Lead Time
SD10-6.6- Stainless Steel (630) Decorative Strap 630 6ft 6in 043156002757 $324.00 Extended Lead Time
SD10-6.6- Aged Bronze (716) Decorative Strap 716 6ft 6in 043156002771 $250.00 Extended Lead Time
SD10-6.6- Dark Bronze (690) Decorative Strap 690 6ft 6in 043156002764 $163.00 Extended Lead Time
SD10-8.0- Satin Nickel (619) Decorative Strap 619 8ft 043156002931 $264.00 Extended Lead Time
SD10-8.0- Black (622) Decorative Strap 622 8ft 043156002948 $167.00 Extended Lead Time
SD10-8.0- Stainless Steel (630) Decorative Strap 630 8ft 043156002955 $331.00 Extended Lead Time
SD10-8.0- Aged Bronze (716) Decorative Strap 716 8ft 043156002979 $248.00 Extended Lead Time
SD10-8.0- Dark Bronze (690) Decorative Strap 690 8ft 043156002962 $169.00 Extended Lead Time
Track Adapter
Description Finish SKU Price Special Order
SD10 619 ADPTR N N SL, Satin Nickel Track Adapter 619 043156003051 $13.50
SD10 622 ADPTR N N SL, Black Track Adapter 622 043156003068 $11.50
SD10 630 ADPTR N N SL, Stainless Steel Track Adapter 630 043156003075 $14.00
SD10 716 ADPTR N N SL, Aged Bronze Track Adapter 716 043156003099 $13.50
SD10 Dark Bronze (690) Track Adapter 690 043156003082 $11.50 Extended Lead Time
Price Book 5 | Effective January 8, 2018 | 800.847.1864 135
Multi-family Overhead Holders & Stops
Overhead Stops and Holders
70 Series
70 Series Description Function Finish Price Each
704H 70 Series Stop and Holder, Size 4 Hold-Open US26D $229.00
704S 70 Series Stop, Size 4 Stop-Only US26D 229.00
81 Series
81 Series Description Function Finish Price Each
814H 81 Series Stop and Holder, Size 4 Hold-Open US32D $319.00
814S 81 Series Stop, Size 4 Stop-Only US32D 279.00
90 Series
90 Series Description Function Finish Price Each
903H 90 Series Stop and Holder, Size 3 Hold Open US32D $315.00
904H 90 Series Stop and Holder, Size 4 Hold Open US32D 315.00
905H 90 Series Stop and Holder, Size 5 Hold Open US32D 315.00
906H 90 Series Stop and Holder, Size 6 Hold Open US32D 315.00
903S 90 Series Stop, Size 3 Stop Only US32D 315.00
904S 90 Series Stop, Size 4 Stop Only US32D 315.00
905S 90 Series Stop, Size 5 Stop Only US32D 315.00
906S 90 Series Stop, Size 6 Stop Only US32D 315.00
AJK90 Angle Jamb Bracket Kit – US26D 59.00
81 Series 90 Series70 Series
Price Book 5 | Effective January 8, 2018 | 800.847.1864
136
Multi-family Overhead Holders & Stops
100 Series
100 Series Description Function Finish Price Each
104H 100 Series Stop and Holder, Size 4 Hold Open US32D $305.00
105H 100 Series Stop and Holder, Size 5 Hold Open US32D 305.00
102S 100 Series Stop, Size 2 Stop Only US32D 305.00
103S 100 Series Stop, Size 3 Stop Only US32D 305.00
104S 100 Series Stop, Size 4 Stop Only US32D 305.00
104S 100 Series Stop, Size 4 Stop Only US10B 321.00
104S ADJ 100 Series Stop, Size 4 w/ ADJ Stop Only US32D 366.00
105S 100 Series Stop, Size 5 Stop Only US32D 305.00
106S 100 Series Stop, Size 6 Stop Only US32D 305.00
450 Series
450 Series Description Function Finish Price Each
454H 450 Series Stop and Holder, Size 4 Hold Open US32D $140.00
454H 450 Series Stop and Holder, Size 4 Hold Open 652 107.00
451S 450 Series Stop, Size 1 Stop Only US32D 140.00
451S 450 Series Stop, Size 1 Stop Only 652 107.00
452S 450 Series Stop, Size 2 Stop Only US32D 140.00
452S 450 Series Stop, Size 2 Stop Only 652 107.00
453S 450 Series Stop, Size 3 Stop Only US32D 140.00
453S 450 Series Stop, Size 3 Stop Only 652 107.00
454S 450 Series Stop, Size 4 Stop Only US32D 140.00
454S 450 Series Stop, Size 4 Stop Only 652 107.00
454S 450 Series Stop, Size 4 Stop Only US10B 154.00
454S 450 Series Stop, Size 4 Stop Only SP28 92.00
455S 450 Series Stop, Size 5 Stop Only US32D 140.00
455S 450 Series Stop, Size 5 Stop Only 652 107.00
410 Series
410 Series Description Function Finish Price Each
414H 410 Series Stop and Holder, Size 4 Hold Open US32D $113.00
413S 410 Series Stop, Size 3 Stop Only US32D 113.00
414S 410 Series Stop, Size 4 Stop Only US32D 113.00
414S 410 Series Stop, Size 4 Stop Only 652 96.00
450 Series100 Series 410 Series
Overhead Stops and Holders (continued)
Price Book 5 | Effective January 8, 2018 | 800.847.1864 137
Multi-family Overhead Holders & Stops
550 Series
Overhead Stops and Holders (continued)
510 Series Heavy Duty Concealed Adjustable Overhead Holder & Stop
550 Series Heavy Duty Surface Adjustable Overhead Holder & Stop
Item* Description Order
Multiple 630
(US32D) 652
(US26D)
510S-H 510 Series, Ajustable Arm, Stop and Hold 1$305 $221
61,773 1,284
Item* Description Order
Multiple 630
(US32D) 652
(US26D)
550S-H 550 Series, Ajustable Arm, Stop and Hold 1$315 $232
61,833 1,350
* One size works for door widths 24" - 48"
* One size works for door widths 24" - 48"
138
Multi-family How to Order - Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Thank you for your order and continuing business. In order to expedite order processing,
please include the following information on purchase orders:
n Schlage account number
n Product UPC numbers (if available)
n Quote number (if applicable)
n Specickeyingrequirements
Note: Line quantities of keyed products must be divisible by KA quantities.
Example: 20 locks ordered KA4 results in 5 groups of 4 locks keyed alike,
however, 20 locks ordered KA3 is not divisible and results in order
processingdelaysasSchlageseeksclarication
· Door handing
How to identify door handing:
Handing of all doors is determined from the exterior of the room’s entrance.
n If the hinge is on the left side of the door, the door is
“left hand” (LH)
n If the hinge is on the right side of the door, the door is
“right hand” (RH)
n To order a handed product, please specify LH or RH
n To order a handleset, handing is still determined from the
exterior of the door
n We will use that information to determine the handing for the
inside of the door
Schlage Residental: How to Order
LH
Left Hand
INSIDE
OUTSIDE
OUTSIDE
INSIDE
LR
Left Hand
Reverse
RH
Right Hand
RR
Right Hand
Reverse
Lever Handing Diagram
139
Multi-family How to Order - Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
How to Determine Hand of Parts (Handed Levers)
Schlage Commercial: How To Order
To order Schlage products, descriptive data should be in the same sequence as shown:
LINE OUTSIDE INSIDE DR
ITEM QTY PRODUCT DES FIN DES FIN HAND LATCH STRIKE THK EXT DIM ADDITIONAL DETAILS
1 2 3 4 5 6 7 8 9 10 11 12 13 14
How to Determine Hand of Door
1. LINE ITEM: Line item number
2. QTY: Quantity
3. PRODUCT: Complete lock product or part number
4. OUTSIDE DES: Outside design code
5. OUTSIDE FIN: Outside finish code
6. INSIDE DES: Inside design code. Leave blank if same as outside design code.
7. INSIDE FIN: Inside finish code. Leave blank if same as outside finish code.
8. HAND: Hand of door. Only one hand allowed per line item.
Example: RH=Right Hand, LH=Left Hand, RR=Right Reverse, LR=Left Reverse.
9. LATCH: Latch. Leave blank for standard or specify part number if non-standard latch is required. LLL=Less Latch.
10. STRIKE: Strike. Leave blank for standard or specify part number if non-standard strike is required. LLL=Less Strike.
11. DR THK: Door Thickness. Enter door thickness if non-standard. Example: 138=1 3/8", 214=2 1/4", 212=2 1/2".
12. EXT: Extension. Enter one of the following when doors 2" thick or greater are specified:
EE = Extended Equally
EI = Extended Inside
EO = Extended Outside
ED = Extended Differently
EI or EO assumes the latch will be centered on a 1 3/4" door, to which material has been added.
13. DIM: Enter dimension for non-standard strike lip length and mortise cylinder or blocking ring length.
012 = 1/8" 118 = 1 1/8"
018 = 3/16" 114 = 1 1/4"
025 = 1/4" 138 = 1 3/8"
031 = 5/16" 112 = 1 1/2"
037 = 3/8" 158 = 1 5/8"
050 = 1/2" 134 = 1 3/4"
078 = 7/8" 200 = 2"
100 = 1" 400 = 4"
14. ADDITIONAL DETAILS: Enter detail for keying information and for special requirements.
140 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family How to Order -Electrified Locks
LE - How to Order
Common Pricing Information
1. Locksarefurnishedwithstandardfeaturesunlessotherwisespecied.
2. Door thickness is 1 ¾"
3. Splitnishesanddesignswillbepricedatthehighestlistpriceofthedesignand/ornish.
4. Engineering specials are denoted by a part number beginning with “X” and are not subject to standard discounting.
5. 6 denotes a lock or part that requires an extended lead time.
6. Idenotesahandedproductandrequireshandingtobespecied.
7. For all restricted keyways (Everest B, D, 29R, and 29T, also, Quad, Numbered, and Reversed) add $16.00. This does not apply to
Primus cylinders. See Terms and Conditions for ordering information and requirements.
8. Locks, keys and cylinders containing restricted keyways require additional documentation to order. Please see Terms and Conditions for the
specicrequirements.
9. Keywaymustbespeciedforkeyedfunctionsandcylinders.Ifnotspecied,defaultkeywaywillbeS123forKA(keyedalike),KD(keyed
different) and 0-bitted product and S145 for factory managed masterkey systems.
10. Multiplekeyingoptionsareavailable.LocksandcylindersarefurnishedKDunlessotherwisespeciedorexceptedbynotation.
11. Control Keys for permanent and construction cores are not included with the lock or cylinder and must be ordered separately.
12. Locksspeciedwith“C”keywayandKDor0-bittedwillreceive6-pincylinders(keyed5)with5-pinkeys.
13. FullSizeInterchangeableCores(FSIC)arefurnished1-bittedunlessotherwisespecied.If0-bittedisselected,theorderwillbeenteredas
1-bitted. This does not apply to FSIC Primus® cores.
14. Conventional cylinders, Primus cylinders (conventional and FSIC) can be supplied 0-bitted. If 1-bitted is selected, the order will be entered
as 0-bitted.
15. Availableplugfacenishesare622,626,and643e.Forchrome,nickelorstainlesssteelnishcolors,theplugfacenishis626.
141
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family How to Order -Electrified Locks
LE - How to Order
REQUIRED FIELDS FACTORY DEFAULT AND OPTIONS
LE -MS -GRW -P-03 -626 -00A - – - 612 -–-LH -10-136 -134 -S123 - –
1. Series:
2. Chassis/Function:
MS Mortise with LED indicator
MB Mortise with push button and LED
MD Mortise Deadbolt with LED
3. Style:
GRW Greenwich sectional with rose
ADD Addison escutcheon
4. Cylinder Type:
P Mortise cylinder, Schlage 6-pin
For all options see LE ordering pages
5. Outside Lever:*
06 Suites with Rhodes
07 Suites with Athens
17 Suites with Sparta
BRW Broadway
BRK Boardwalk
LAT Latitude
LON Longitude
For all options see SES Price Book
*To add tactile warning, use prefix 8. Example: 806
6. Outside Finish:
626 Satin Chrome
619 Satin Nickel
622 Matte Black
625 Bright Chrome
643e Aged Bronze
7. Outside Rose: Specify only for Greenwich Trim
00A 2-1/8" (54 mm) diameter (Standard)
00B 2-9/16" (65 mm) diameter
00C 2-5/8" (66 mm) diameter with bevel
8. Inside Lever: Specify only if different from outside lever
3 Suites with Tubular style
LAT Latitude
For all options see LE ordering pages
9. Inside Finish: Specify only if different from outside finish
See options under 6 above
10. Inside Rose: Specify only for Greenwich Trim and only if different from Outside Rose
See options under 7 above
11. Handing:
RH Right Handed (Standard)
LH Left Handed
RHR Right Handed Reverse
LHR Left Handed Reverse
12. Strike Plate Lip Length:
10-136 1-3/16" lip length (Standard for MS/MB)
10-136-112 1-1/2" lip length
For all options see LE ordering pages
13. Door Thickness
134 1-3/4" (Standard)
Options available up to 2-1/4" thickness - see LE ordering pages
14. Keyway Type
S123 Everest 29 S (Standard)
For all options see LE ordering pages
15. Additional Options
142 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Common Pricing Information
1. Locksarefurnishedwithstandardfeaturesunlessotherwisespecied.
2. Door thickness is 1 ¾"
3. Splitnishesanddesignswillbepricedatthehighestlistpriceofthedesignand/ornish.
4. Engineering specials are denoted by a part number beginning with “X” and are not subject to standard discounting.
5. 6 denotes a lock or part that requires an extended lead time.
6. For all restricted keyways (Everest D, Everest 29 T, Quad, Numbered, Reversed) add $16.00. This does not apply to Primus cylinders.
See Terms and Conditions for ordering information and requirements.
7. Locks, keys and cylinders containing restricted keyways require additional documentation to order. Please see Terms and Conditions for the
specicrequirements.
8. Keywaymustbespeciedforkeyedfunctionsandcylinders.Ifnotspecied,defaultkeywaywillbeS123forKA,KDand0-bittedproduct
and S145 for Factory managed masterkey systems.
9. Multiplekeyingoptionsareavailable.LocksandcylindersarefurnishedKDunlessotherwisespeciedorexceptedbynotation.
10. Control Keys for permanent and construction cores are not included with the lock or cylinder and must be ordered separately.
11. Locksspeciedwith“C”keywayandKDor0-bittedwillreceive6pincylinders(keyed5)with5pinkeys.
12. FullSizeInterchangeableCores(FSIC)arefurnished1-bittedunlessotherwisespecied.If0-bittedisselected,theorderwillbeenteredas
1-bitted. This does not apply to FSIC Primus® cores.
13. Conventional cylinders, Primus cylinders (conventional and FSIC) can be supplied 0-bitted. If 1-bitted is selected, the order will be entered
as 0-bitted.
14. Availableplugfacenishesare622,626,and643e.Forchrome,nickelorstainlesssteelnishcolors,theplugfacenishis626.
Standard Features
Certification ANSI/BHMA Certified A156.25-2013, A156.2-2011, Series 4000, Grade 1, UL 294,
UL 10C
Latch 1 1/8" x 2 1/4", Square corner faceplate, 1" housing diameter, 1/2" throw
Strike 1 1/4" x 4 7/8", ANSI Square corner, with DPS magnets, no box
Backset 2 3/4"
Cylinder 6-Pin solid brass, keyed 6-pin, S123 keyway, keyed different (KD)
Door Range Comes set for 1-3/4" thick doors. Can be field adjusted for doors 1-5/8"-2" thick.
Keys Two nickel silver cut keys per lock, 6-pin, S123 section
NDE - How to Order
Multi-family How to Order -Electrified Locks
143
Price Book 5 | Effective January 8, 2018 | 800.847.1864
NDE - How to Order
REQUIRED FIELDS FACTORY DEFAULT AND OPTIONS
NDE –80 –PD –ATH –626 –SPA – — – 13-047 – 10-130 –138 –S123 – —
1. Series:
2. Function:
80 Storeroom with Vandlgard
3. Cylinder Type:
PD Schlage 6-pin Full Cylinder
For options see NDE ordering pages
4. Outside Lever:*
LLL Less interior and exterior levers
SPA Sparta
RHO Rhodes
ATH Athens
LAT Latitude
LON Longitude
BRW Broadway
BRK Boardwalk
*To add tactile warning, use prefix 8. Example: 8SPA
5. Outside Finish:
626 Satin Chrome
619 Satin Nickel
622 Matte Black
625 Bright Chrome
643e Aged Bronze
6. Inside Lever:* Specify only if different from outside lever
SPA Sparta
RHO Rhodes
ATH Athens
LAT Latitude
LON Longitude
BRW Broadway
BRK Boardwalk
*To add tactile warning, use prefix 8. Example: 8SPA
7. Inside Finish: Specify only if different from outside finish
626 Satin Chrome
619 Satin Nickel
625 Bright Chrome
643e Aged Bronze
8. Backset and Latchbolt:
13-047 2-3/4" Backset, Deadlatch, Square Corner, 1-1/8" x 2-1/4" (Standard)
For options see individual Class/Chassis page
9. Strike Plate:
10-130 1-3/16" Lip, ANSI, DPS magnets, no box, 1-1/4" x 4-7/8" (Standard)
For options see individual Class/Chassis page
10. Strike Lip Dimension: Specify only if different from options 10-130 or 10-132 dimensions
138 1-3/8" lip length option available on 10-130 and 10-131 strike plates (normally 1-3/16")
112 1-1/2" lip length option available on 10-132 strike plate (normally 1-1/8")
11. Keyway Type:
S123 Everest 29 S (Standard)
For options see individual Class/Chassis page
12. Additional Options
Multi-family How to Order -Electrified Locks
144 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family How to Order -Electrified Locks
CTE - How to Order
REQUIRED FIELDS Options
CTE -MT15-485 - B
1. CTE
2. Reader Type
MT15-485 Multi-Technology Single Gang Wall Mount
MT11-485 Multi-Technology Mullion Mount
3. Cover Color
B Black - default
G Grey
BN Brown
C Cream
1-2. Select CTE Kit Reader Option
CTE-MT11-485 ..............................CTE with Multi-Technology Mullion Reader Kit
CTE-MT15-485 ..............................CTE with Multi-Technology Single Reader Kit
3. Select Color
B ........................................................ Black – Default
G ........................................................ Grey
BN ..................................................... Brown
C ........................................................Cream
145
Multi-family How to Order - Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
ND Series
Ordering Procedures
To order Schlage products, descriptive data should be in the same sequence as shown below.
Common Pricing Information
1. Locksarefurnishedwithstandardfeaturesunlessotherwisespecied.
2. Doorthicknessis1-¾"unlessotherwisespecied.
3. Splitnishesanddesignswillbepricedatthehighestlistpriceofthedesignand/ornish.
4. 6 denotes a lock or part that requires an extended lead time.
5. Idenotesahandedproductandrequireshandingtobespecied.
6. For all restricted keyways (Everest D, Everest 29 T, Quad, Numbered, Reversed) add $16.00. This does not apply to Primus cylinders. See
Terms and Conditions for ordering information and requirements.
7. Locks, keys and cylinders containing restricted keyways require additional documentation to order. Please see Terms and Conditions for the
specicrequirements.
8. Keywaymustbespeciedforkeyedfunctionsandcylinders.Ifnotspecied,defaultkeywaywillbeS123forKA,KDand0-bittedproduct
and S145 for Factory managed masterkey systems.
9. Multiplekeyingoptionsareavailable.LocksandcylindersarefurnishedKDunlessotherwisespeciedorexceptedbynotation.
10. Control Keys for permanent and construction cores are not included with the lock or cylinder and must be ordered separately.
11. Locksspeciedwith“C”keywayandKDor0-bittedwillreceive6pincylinders.
12. FullSizeInterchangeableCores(FSIC)arefurnished1-bittedunlessotherwisespecied.If0-bittedisselected,theorderwillbeenteredas
1-bitted. This does not apply to FSIC Primus® cores.
13. Conventional cylinders, Primus cylinders (conventional and FSIC) can be supplied 0-bitted. If 1-bitted is selected, the order will be entered
as 0-bitted.
14. Availableplugfacenishesare606,622,626,643e.
15. Locks and cylinders will be furnished with 2 keys each as standard. Additional keys will be charge at the additional cut keys charge
appropriate for the cylinder/key type
Line
Item Qty Product
Outside Inside
Hand Latch Strike Dr Thk Ext DIM Additional
Details
DES FIN DES FIN
1 10 ND53PD RHO 622 OME – – 13-247 10-025 214 EE 138 KA
Standard Features
Certication ANSI/BHMACertiedA156.2-2011,Series4000,Grade1,ULListedfor3-hourredoor.
Latch 1-1/8" x 2-1/4", Square corner faceplate, 1" housing diameter, 1/2" throw
Strike 1-1/4" x 4-7/8", ANSI Square corner, no box
Backset 2-3/4"
Cylinder 6-Pin solid brass, keyed 6-pin, S123 keyway, keyed different (KD)
Door Range 1-5/8" – 2-1/8" for all functions except ND85; 1-3/4" – 2" for ND85
Keys Two nickel silver cut keys per lock, 6-pin, S123 section
Line Item: Line item number
Qty: Quantity
Product: Product function + Cylinder code
Outside Des: Outside lever design
Outside Fin: Outsidenish
Inside Des: Inside lever design: Specify only if different from the outside lever design
Inside Fin: Insidelevernish:Specifyonlyifdifferentfromtheoutsidenish
Hand: Hand of door: N/A for ND lock
Latch: Product latch: Leave blank for standard latch or specify part number if non-standard latch is required.
Strike: Product strike: Leave blank for standard strike or specify part number if non-standard strike is required.
Dr Thk: Door thickness: Enter door thickness if non-standard. Example: 138=1 3/8", 214=2 1/4"
Ext: Extension: Enter for doors 2 1/8" or greater. Example: EE=extended equally, EI=extended inside, EO=extended outside,
ED=extended differently
Dim: Dimension: Enter only for non-standard strike lip length
Additional
Details: Enter additional detail for keying information or special requirements
146 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family How to Order - Locks
Line Item: Line item number
Qty: Quantity
Product: Product function + cylinder code
Outside Des: Outside lever design + rose/escutcheon code
Outside Fin: Outsidenish
Inside Des: Inside lever design + rose/escutcheon code, specify only if different from the outside lever design
Inside Fin: Insidelevernish,specifyonlyifdifferentfromtheoutsidenish
Hand: Hand of door, specify only for handed lever designs or for LM9300 MultiPoint lock
Latch: Product armor front, leave blank for standard armor or specify part number if non-standard armor is required.
LLL = less armor front
Strike: Product strike, leave blank for standard strike or specify part number if non-standard strike is required. LLL = less strike
Dr Thk: Door thickness, leave blank for standard thickness (1-3/4") or specify if non-standard. Example: 138 = 1-3/8", 214 = 2-1/4"
Ext: Extension,enteroneofthefollowingwhendoorthicknesses2"orgreaterarespecied:EE=ExtendedEqually,EI=Extended
Inside, EO = Extended Outside
Dim: Dimension; for locks enter only for non-standard strike lip length, for parts enter for non-standard strike lip length, mortise
cylinder or blocking ring length
Additional
Details: Enter additional detail for keying information or special requirements
L Series
Ordering Procedures
To order Schlage products, descriptive data should be in the same sequence as shown below.
Common Pricing Information
1. Locksarefurnishedwithstandardfeaturesunlessotherwisespecied.
2. Doorthicknessis1-¾"unlessotherwisespecied.
3. Splitnishesanddesignswillbepricedatthehighestlistpriceofthedesignand/ornish.
4. 6 denotes a lock or part that requires an extended lead time.
5. Idenotesahandedproductandrequireshandingtobespecied.
6. For all restricted keyways (Everest D, Everest 29 T, Quad, Numbered, Reversed) add $16.00. This does not apply to Primus cylinders. See
Terms and Conditions for ordering information and requirements.
7. Locks, keys and cylinders containing restricted keyways require additional documentation to order. Please see Terms and Conditions for the
specicrequirements.
8. Keywaymustbespeciedforkeyedfunctionsandcylinders.Ifnotspecied,defaultkeywaywillbeS123forKA,KDand0-bittedproduct
and S145 for Factory managed masterkey systems.
9. Multiplekeyingoptionsareavailable.LocksandcylindersarefurnishedKDunlessotherwisespeciedorexceptedbynotation.
10. Control Keys for permanent and construction cores are not included with the lock or cylinder and must be ordered separately.
11. Locksspeciedwith“C”keywayandKDor0-bittedwillreceive6pincylinders.
12. FullSizeInterchangeableCores(FSIC)arefurnished1-bittedunlessotherwisespecied.If0-bittedisselected,theorderwillbeenteredas
1-bitted. This does not apply to FSIC Primus® cores.
13. Conventional cylinders, Primus cylinders (conventional and FSIC) can be supplied 0-bitted. If 1-bitted is selected, the order will be entered
as 0-bitted.
14. Availableplugfacenishesare606and626.Forbrassorbronzenishcolors,theplugfacenishis606.Forchrome,nickelorstainlesssteel
nishcolors,theplugfacenishis626.
15. Locks and cylinders will be furnished with 2 keys each as standard. Additional keys will be charge at the additional cut keys charge
appropriate for the cylinder/key type
Line
Item Qty Product
Outside Inside
Hand Latch Strike Dr Thk Ext DIM Additional
Details
DES FIN DES FIN
1 10 L9050P 12A 626 06B 613 RH 09-669 10-072 2 EE 134 KA
Standard Features
Certications L/LV9000:ANSI/BHMACertiedA156.13-2012,Series1000,Grade1Operational,
Grade1Security,ULListedfor3-hourredoor(exceptL9076andL9077).
With FSIC Interchangeable Core Cylinders: Grade 2 Security.
With SFIC Interchangeable Core Cylinders: Grade 3 Security.
L400:ANSI/BHMACertiedA156.36-2010,Grade1,ULListedfor3-hourredoor.
Case Size L/LV9000: 4-7/16" x 6-1/16" x 1"; L400: 4-7/16" x 3-5/8" x 1"
Armor Front L/LV9000: 1-1/4" x 8"; L400: 1-1/4" x 5-9/16"
Deadbolt 1" Throw stainless steel
Latchbolt 3/4" Throw stainless steel with anti-friction tongue
Strike L/LV9000: 1 1/4" x 4-7/8" Square corner, 1-3/16" lip, box; L400: 1-1/8" x 3-5/8" square corner, box
Backset 2 3/4"
Cylinder 6-Pin solid brass, keyed 6-pin, S123 keyway, keyed different (KD)
Door Range 1-3/4"
Keys Two nickel silver cut keys per lock, 6-pin, S123 section
147
Multi-family How to Order - Locks
Price Book 5 | Effective January 8, 2018 | 800.847.1864
AL Series
Ordering Procedures
To order Schlage products, descriptive data should be in the same sequence as shown below.
Common Pricing Information
1. Locksarefurnishedwithstandardfeaturesunlessotherwisespecied.
2. Doorthicknessis1¾"unlessotherwisespecied.
3. Splitnishesanddesignswillbepricedatthehighestlistpriceofthedesignand/ornish.
4. 6 denotes a lock or part that requires an extended lead time.
5. Idenotesahandedproductandrequireshandingtobespecied.
6. For all restricted keyways (Everest D, Everest 29 T, Quad, Numbered, Reversed) add $16.00. This does not apply to Primus cylinders. See
Terms and Conditions for ordering information and requirements.
7. Locks, keys and cylinders containing restricted keyways require additional documentation to order. Please see Terms and Conditions for the
specicrequirements.
8. Keywaymustbespeciedforkeyedfunctionsandcylinders.Ifnotspecied,defaultkeywaywillbeS123forKA,KDand0-bittedproduct
and S145 for Factory managed masterkey systems.
9. Multiplekeyingoptionsareavailable.LocksandcylindersarefurnishedKDunlessotherwisespeciedorexceptedbynotation.
10. Control Keys for permanent and construction cores are not included with the lock or cylinder and must be ordered separately.
11. Locksspeciedwith“C”keywayandKDor0-bittedwillreceive6pincylinders.
12. FullSizeInterchangeableCores(FSIC)arefurnished1-bittedunlessotherwisespecied.If0-bittedisselected,theorderwillbeenteredas
1-bitted. This does not apply to FSIC Primus® cores.
13. Conventional cylinders, Primus cylinders (conventional and FSIC) can be supplied 0-bitted. If 1-bitted is selected, the order will be entered
as 0-bitted.
14. Availableplugfacenishesare606,622,626,643e.
15. Locks and cylinders will be furnished with 2 keys each as standard. Additional keys will be charge at the additional cut keys charge
appropriate for the cylinder/key type
Line Item: Line item number
Qty: Quantity
Product: Product function + Cylinder code
Outside Des: Outside lever design
Outside Fin: Outsidenish
Inside Des: Inside lever design: Specify only if different from the outside lever design
Inside Fin: Insidelevernish:Specifyonlyifdifferentfromtheoutsidenish
Hand: Hand of door: N/A for AL lock
Latch: Product latch: Leave blank for standard latch or specify part number if non-standard latch is required.
Strike: Product strike: Leave blank for standard strike or specify part number if non-standard strike is required.
Dr Thk: Door thickness: Enter door thickness if non-standard. Example: 138=1 3/8", 214=2 1/4"
Ext: Extension: Enter for doors 1 7/8" or greater. Example: EE=extended equally, EI=extended inside, EO=extended outside,
ED=extended differently
Dim: Dimension: Enter only for non-standard strike lip length
Additional
Details: Enter additional detail for keying information or special requirements
Line
Item Qty Product
Outside Inside
Hand Latch Strike Dr Thk Ext DIM Additional
Details
DES FIN DES FIN
1 10 AL53PD SAT 626 NEP 619 - 11-096 10-025 200 EE - -
Standard Features
Certication ANSI/BHMACertiedA156.2-2011,Series4000,Grade2,ULListedfor3-hourredoor.
Latch 1-1/8" x 2-1/4", Square corner faceplate, 1" housing diameter, 1/2" throw
Strike 1-1/4" x 4-7/8", ANSI, Square corner, no box
Backset 2-3/4"
Cylinder 6-Pin solid brass, keyed 6-pin, S123 keyway, keyed different (KD)
Door Range 1-3/8" – 1-7/8"
Keys Two nickel silver cut keys per lock, 6-pin, S123 section
Indicates products that have EPD documentation available and meet LEED v4.
148 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family How to Order - Exits
Von Duprin: How to Order
Sequence Example 996/ 299F/
EL 98 27 L F — US26D 3’ RHR LBR US26D US26D 06 SNB HM
Prefixes
None Standard
AX Accessible Device
CD Cylinder Dogging - Panic Only
CX Chexit
E Electric Locking Mortise/Lever
EL Electric Latch Retraction
HH Huricane Device
LX Latch Bolt Monitoring
PL Pullman Latch
PN Pneumatic Latch Retraction
QEL Quiet Electric Latch Retraction
Device Series
22 Push Bar Device
33A/35A
Push Bar Device
55 Cross Bar Device
Device Type
None Rim Device
27 Surface Mounted Vertical Rod Device
47 Concealed Vertical Rod Device
47WDC
Concealed Vertical Rod Wood Door Device
48 Concealed Vertical Rod Device
49 Concealed Vertical Cable Device (see CVC how to order form)
50WDC
Concealed Vertical Cable Wood Door Device
57 Three-Point Latch Device
75 Mortise Lock Device
Trim Functions
XX AD Trim (to come from client)
DT Dummy Trim
EO Exit Only
HL Hospital Pull Trim
K Knob
K-BE Knob - Blank Escutcheon
K-DT Knob, Rigid - Dummy Trim
K-NL Knob, Rigid - Night Latch
L Lever (Classroom)
L-BE Lever - Blank Escutcheon
L-DT Lever, Rigid - Dummy Trim
Rating
F Fire Exit hardware
Sufx
-2 Double Cylinder
Finish
US3, US4, US10,US 15, US26, US26D, US26D-AM, US28, US32D, US32D-AM, 313, 315
Door Width
3’ Standard Default
4’
2’
Handing
RHR Right Hand Reverse
Less Bottom Rod/Cable
LBR Less Bottom Rod
LBL Less Bottom Cable
Trim Options/Finish
See trim options/nish for each series
Trim Options/Finish
See trim options for each series
Lever Style
06 Standard Default
Optional Levers available
Accessories
CYL Cylinder
GBK Glass Bead Kit
SNB Sex Bolts
Other Information
Touchbar Options BRAILLE (Vision impaired touchpad, Raised letter, and Braille), PUSH (Touchbar trim embossed “PUSH’)
RSS (Red silk-screened lettered touchbar trim), KN (Knurled Touchbar), SG (Safety Glow)
Miscellaneous CE (CE Labeled), LCP (Less Cover Plate), 10WDA (#10WDA Cover Plate), RAT REL (Ratchet Release Assy), WH (Weep Holes)
Door Material AL (Aluminum Door), HM (Hollow Metal), WD (Wood Door) , CP (Composite Door)
INS2 (Insulclad - 1/2"), INS4 (Insulclad - 1/4"), SC (Steelcraft, HH Device Only)
Door Application D (Double Egress), P (Pair of Doors) , S (Single Door)
Note: Not all options are listed. Not all options are available on all series. See the specic series pages for complete options available.
Please contact customer care for questions.
RX Request to Exit
RX2 Double Request to Exit
SD Special Dogging - Panic
Only
SS Signal Switch
WS Windstorm (FEMA rated)
Surface Vertical Rod Exit
Device
XP Heavy Protection - Rim
L-NL Lever, Rigid - Night Latch
NL Night Latch
NL-OP Night Latch Cylinder
Assembly, Optional Pull
TL Turn Lever
TL-BE Turn Lever - Blank
Escutcheon
TP Thumbpiece
TP-BE Thumbpiece - Blank
Escutcheon
Blank Panic Exit Hardware
-2SI Double Cylinder with Security Indicator
LHR Left Hand Reverse
LBR-AFL LBR with Fire Pin
LBL-AFL LBL with Fire Pin
SEC Security Screws
SLM SLM Blocking
Door Thickness
1-3/4" Standard
2-1/4" Optional
88 Cross Bar Device
94/95 Recessed Device
98/99 Push Bar Device
149
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family How to Order - Exits
Falcon: Exit Device - How to Order
How to Order Sequence Example
EL F 25 V L-DANE US3 3' LHR LBR SNB WD
Prefixes
AX Accessible Device (25 and 19 Series Only)
CD Cylinder Dogging
LD Less Dogging
RX Touchbar Request to Exit
DM Latchbolt Monitor Switch - when fully extended
LM Latchbolt Monitor Switch - when fully retracted
KOR Key Bypass Switch
EL Electric Latch Retraction
FSA Electric Lock or Unlock Trim-Fail Safe
(25 Series Only)
FSE Electric Lock or Unlock Trim-Fail Secure
(25 Series Only)
EA Exit Alarm
Rating
F Fire Exit Hardware
Blank Panic Exit Hardware
Device Series
19 Touch Bar Device, Narrow Stile
24 Touch Bar Device, Narrow Stile
25 Touch Bar Device
XX Crossbar Device
Device Type
R Rim C Concealed Vertical rod
V Surface Vertical Rod C-WDC Concealed Vertical rod
M Mortise Wood Door
Trim Function (see Trim pages for all functions)
EO Exit Only K Knob
DT Dummy Trim L Lever (Dane Standard)
NL Night Latch TL Thumb Lever
C Cylinder Trim Plate NL-OP Night Latch Pull by other
TP Thumbpiece KIL Key in Lever
Latch Option
DL Dead Locking
Finish
US3 US10 US15* US26 US32 SP28
US4 US11* US19* US26D US32D SP313 313AN
Door Width
3' Standard Default
4'
2'
Handing
RHR Right Hand Reverse
LHR Left Hand Reverse
Less Bottom Rod
LBR Less Bottom Rod
LBR-AFL LBR w/Auxiliary Fire Pin
Accessories
CYL Cylinder SNB Sex Bolts AMS All Machine Screws
SK Shim Kit SLM SLM Blocking
Other Miscellaneous Door Information
HMD Hollow Metal Door SCDC Steel Channel Door Construction _ Door Label (20 min, 45 min, 90 min 1-1/2 hr)
HMF Hollow Metal Frame _ Specify other Door or Frame _ Stile Width
WD Wood Door Material information _ Frame Stop Height
WDF Wood Frame _ Door Height SGL Single Door
ALD Aluminum Door _ Door Thickness PR Pair of Doors Swinging Same Direction
ALF Aluminum Frame _ Door Undercut DE Double Egress Doors
CPD Composite Door _ CON Allegion Connect
Door Thickness
1-3/4" Standard
2-1/4" Optional
150 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family How to Order - Exits
Falcon: Trim - How to Order
How to Order Sequence Example
510 L - R US26D LHR SUTRO FSE CYL
Trim Series
D24 Series D25 Series 19 Series
711 510 911
712 511 912
715 512 914
717 513 917
718 717 918
718 920
930
Trim Function (see Trim pages for all functions)
EO Exit Only
DT Dummy Trim
NL Night Latch
C Cylinder Trim Less Pull
TP Thumbpiece
K Knob
L Lever (Dane Standard)
KIL Key in Lever
TL Thumb Lever
Device Type
R Rim
V Surface Vertical Rod
M Mortise
C Concealed Vertical Rod (includes WDC)
Finish
US3 US10 US11* US19* US26D SP313
US4 US10B US15* US26 SP28 US32 US32D
Handing
RHR Right Hand Reverse
LHR Left Hand Reverse
Lever Style
DANE (DAN) supplied standard if not specified BROADWAY (BRW)* (available on 24 and 25 Series only)
SUTRO (SUT) DANISH (DSH)* (available on 24 and 25 Series only)
QUANTUM (QUA) LATITUDE (LAT)* (available on 24 and 25 Series only)
AVALON (AVA) (available on 24, 25 and xx Series only) LONGITUDE (LON)* (available on 24 and 25 Series only)
BOARDWALK (BRK)* (available on 24 and 25 Series only)
Trim Options
FSA Electric Lock or Unlock-Fail Safe (FSA device required)
FSE Electric Lock or Unlock-Fail Secure (FSE device required)
CON Allegion Connect
Other Information or Accessories
CYL Include Cylinder with Trim
KD Cylinder Keyed Different
Door Thickness
Specify door thickness other than 1-3/4"
*New finishes and levers are available on select 24 and 25 Series.
151
Price Book 5 | Effective January 8, 2018 | 800.847.1864
HOW TO ORDER CLOSERS, COMPONENTS, PARTS & ACCESSORIES
1. Identify the closer series; 1460, 2030, 4040XP, 4210T, 4310ME, 4640, 6030, etc.
2. Determine if any additional information is required, such as: handing, finish, spring size, voltage, etc.
3. Order the material using suffix number with the description and include all necessary information.
Examples: 4111 Closer x RH x CUSH x AL or 4040SE Closer x 24v x DKBRZ
4. For additional information on how to order specific closers, please see the ‘How to Order’ page in each individual closer
section of the LCN General Catalog or call LCN Customer Care.
SPECIAL NOTES
1. All RAL custom finishes will be powder coated and metal covers (list add $10 for most series, list add $30 for 1450 and
4050 series) will be substituted for standard covers for all closers except the 1460 series. 1460 series closers may be custom
finished but a DS cover (list add $30) must be selected.
2. LCN offers more than 180 RAL custom finishes. There is a list add of ($35) per closer for an RAL finish. Most series require
a metal cover (MC) ($10 add). LCN also offers a Brite Metallic (MTLPC) powder coat finish. There is a list add of ($60) per
closer for the MTLPC finish. Most series require a metal cover (MC) ($10 add).
3. LCN plated list prices already include -72MC (1460 includes -72DS). Disregard the additional list add for metal cover (MC).
4. LCN powder finishes exceed ANSI/BHMA standard A156.4 for corrosion resistance by at least a factor of four. LCN powder
coat finishes combined with the LCN Special Rust Inhibitor (SRI) pre-treatment exceed this standard even further.
5. Special Rust Inhibitor (SRI) is a pretreatment that is applied prior to the LCN powder coat finish and greatly exceeds
ANSI/BHMA Standard A156.4 for corrosion resistance. LCN requires an additional (list add $40) charge per closer,
component or part.
6. LCN plated finishes exceed ANSI/BHMA standard A156.4 for corrosion resistance.
7. Optional TORX security screw packs can be substituted for standard screw packs on most closers. See ‘Add for TORX Screw
Pack’ for additional charge. In some cases, not all fasteners can be provided as TORX, consult factory for details.
8.
LCN can mark individual closer boxes with door or opening #’s. Please specify ‘itemized’ when ordering. Markings (e.g., door number,
stock reference numbers) on individual product cartons will be provided with no charge.
9. Special Template (ST) pricing is available by contacting LCN Technical/Product Support or LCN Customer Care.
10. All closers conform to standards UL10C and UBC 7-2 (1997).
11. If an item or price is not listed in the LCN August 12, 2017 Price List, consult factory for availability & pricing.
12. Prices listed in the LCN August 12, 2017 Price List are subject to change without notice. The current ‘Terms of Sale’ applies. All pric-
es listed in the LCN August 12, 2017 are in US dollars.
Multi-family How to Order - Closers
152 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family How to Order - Closers
To order Falcon products, descriptive data should be in the same sequence as shown:
Line
Item Qty Product
Outside Inside
Hand Latch Strike Dr. Thk Ext DIM Additional DetailsDES FIN DES FIN
1 2 3 4 5 6 7 8 9 10 11 12 13 14
1. LINE ITEM: Line item number
2. QTY: Quantity
3. PRODUCT: Complete lock product or part number
4. OUTSIDE DES: Outside design code
5. OUTSIDE FIN: Outside finish code
6. INSIDE DES: Inside design code. Leave blank if same as outside design code.
7. INSIDE FIN: Inside finish code. Leave blank if same as outside finish code.
8. HAND: Hand of door. Only one hand allowed per line item.
Example: RH = Right Hand, LH = Left Hand, RHR = Right Reverse, LHR = Left Reverse.
9. LATCH: Latch. Leave blank for standard or specify part number if non-standard latch is
required. LLL = Less Latch.
10. STRIKE: Strike. Leave blank for standard or specify part number if non-standard strike is required. LLL =
Less Strike.
11. DR THK: Door Thickness. Enter door thickness if non-standard. Example: 138 = 1-3/8",
214 = 2 1/4", 212 = 2 1/2".
12. EXT: Extension. Enter one of the following when doors 2" thick or greater are specified:
EE = Extended Equally
EI = Extended Inside
EO = Extended Outside
ED = Extended Differently
EI or EO assumes the latch will be centered on a 1-3/4" door, to which material has been added.
13. DIM: Enter dimension for non-standard strike lip length and mortise cylinder or blocking ring length.
012 = 1/8" 118 = 1-1/8"
018 = 3/16" 114 = 1-1/4"
025 = 1/4" 138 = 1-3/8"
031 = 5/16" 112 = 1-1/2"
037 = 3/8" 158 = 1-5/8"
050 = 1/2" 134 = 1-3/4"
078 = 7/8" 200 = 2"
100 = 1" 400 = 4"
14. ADDITIONAL DETAILS: Enter detail for keying information and for special requirements.
How to Determine Hand of Door
RHR
LHR
153
Price Book 5 | Effective January 8, 2018 | 800.847.1864
SC70A Series
STD** SC71A Standard
DEL SC71A Delay
Full cover SC70A-72
RW/PA** Regular with parallel arm shoe
HW/PA** Hold open with parallel arm shoe
HD** Heavy duty arm
DS** Dead stop arm
DS/HO Dead stop hold open arm
SS Spring stop arm
SS/HO Spring stop hold open arm
FA Forged arm
FA/HO Forged arm with hold open
Matte black** 622
Aluminum 689
Dark bronze 695
Brass* 696
Sot shoe support SC70A-30
Blade stop spacer SC70A-61
Auxiliary shoe SC70A-62A
Top jamb plate SC70A-18
PA Plate SC70A-18PA
Full cover SC70A-72
Cylinder Cover Arm Finish Accessories
*Contact customer service at 1-877-671-7011 for lead time information.
**Matte Black (622) is only available on standard cylinders and RW/PA, HW/PA, DS and HD.
Note: SC71A models are adjustable sizes 1-6
Cylinder Cover Arm Finish Accessories
STD** SC81A Standard
DEL SC81A Delay
Slim cover SC80A-72
Full cover SC80A-72FC (optional, please specify)
RW/PA** Regular with parallel arm shoe
HW/PA** Hold open with parallel arm shoe
HD Heavy duty arm
DS** Dead stop arm
DS/HO Dead stop hold open arm
SS Spring stop arm
SS/HO Spring stop hold open arm
Matte black ** 622
Aluminum 689
Dark bronze 695
Brass* 696
Sot shoe support SC80A-30
Blade stop spacer SC80A-61
Auxiliary shoe SC80A-62A
Top jamb plate SC80A-18
Top jamb plate - full cover SC80A-18FC
PA Plate SC80A-18PA
PA Plate - full cover SC80A-18PAFC
Slim cover SC80A-72
Full cover SC80A-72FC
SC80A Series
* Contact customer service at 1-877-671-7011 for lead time information.
** Matte Black (622) is only available on standard cylinders and RW/PA, HW/PA, and DS.
Note: SC81A models have adjustable sizes 1-6
Multi-family How to Order - Closers
154 Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family How to Order - Closers
STD* Standard
LBC Less backcheck option
1 SC91A
3 SC93A
4 SC94A
Slim cover SC90A-72 (only available on SC93A/94A)
RW/PA Regular with parallel arm shoe
HW/PA Hold open with parallel arm shoe (only available on SC91A)
Sot shoe support SC90A-30
Blade stop spacer SC90A-61
Auxiliary shoe SC90A-62A
Aluminum 689
Dark bronze 695
Plate SC90A-18 (available with SC93A/94A only)
Plate PA SC90A-18PA (available with SC93A/94A only)
Slim cover SC90A-72 (available with SC93A/94A only)
SC90A Series
Cylinder Size Cover Arm Finish Accessories
SC60A Series
STD** SC61A Standard
Slim cover SC60A-72 (optional, available with SC61A only, please specify)
RW/PA** Regular with parallel arm shoe
HW/PA** Hold open with parallel arm shoe
HD Heavy duty arm
DS** Dead stop arm
DS/HO Dead stop hold open arm
SS Spring stop arm
SS/HO Spring stop hold open arm
Matte black** 622
Aluminum 689
Dark bronze 695
Brass 696
Sot shoe support SC60A-30
Blade stop spacer SC60A-61
Auxiliary shoe SC60A-62A
Top jamb plate SC60A-18
PA Plate SC60A-18PA
Slim cover SC60A-72
**Matte Black (622) is only available on standard cylinders and RW/PA, HW/PA, and DS arms.
Note: SC60A Series comes standard with less cover and all models have adjustable sizes 1-5.
Cylinder Cover Arm Finish Accessories
*STD comes with less cover and adjustable backcheck.
155
Price Book 5 | Effective January 8, 2018 | 800.847.1864
Multi-family How to Order - Accessories
Glynn-Johnson: Overhead Holders and Stops – How to Order
Example: 70 2 H - US26D - J
Overhead series (70, 79, 81, 90, 10, 41, 45)
Size (1, 2, 3, 4, 5, or 6)*
Function (H, F, HP, S or SE) For description of functions, refer to chart above.*
Finish (US3, US4, US10, US10B, US26, US26D, US32, US32D, 652, SP4, SP10,
SP28, SP313, SPBLK)
Option (ADJ, CJ, J, SHIM, SNB, SOC)*
*Please refer to individual Overhead Series price book pages for availability of finish, size, function and options.
Cylinder Cover Arm Finish Accessories
Allegion (NYSE: ALLE) creates peace of mind by pioneering safety and security.
As a $2 billion provider of security solutions for homes and businesses, Allegion
employs more than 7,800 people and sells products in more than 120 countries
across the world. Allegion comprises 23 global brands, including strategic
brands CISA®
, Interflex®
, LCN®
, Schlage® and Von Duprin®
.
For more, visit www.allegion.com
About Allegion
© 2018 Allegion
012057, Rev. 04/18
allegion.com/us

Navigation menu
