35006152 00

Communication Drivers

Installation manual

eng

Table of Contents

About the Book. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Part I General information on the installation of drivers . . . . . 9

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Chapter 1 General information concerning the Drivers . . . . . . . . . . . . . .11

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

The drivers and Unity Pro . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Part II Uni-Telway drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Chapter 2 Serial port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

How to install the driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Driver configuration screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

How to configure the driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Chapter 3 TSX SCP 114 card. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27

How to install the driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Driver configuration screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

Configuration of the Windows 98 operating system . . . . . . . . . . . . . . . . . . . . . . 32

Configuration of the Windows 2000\XP operating system . . . . . . . . . . . . . . . . . 33

Configuration of Win NT operating system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34

Part III FIP drivers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35

Chapter 4 TSX FPP 20 card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

How to install the driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38

How to install the driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40

Configuration of the Windows 98 operating system . . . . . . . . . . . . . . . . . . . . . . 41

Configuration of the Windows 2000\XP operating system. . . . . . . . . . . . . . . . . . 42

Configuration of the Windows NT operating system . . . . . . . . . . . . . . . . . . . . . . 43

Chapter 5 TSX FPC 10 ISA card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45

How to install the driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46

Driver configuration screen for Windows NT . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48

Driver configuration screen for Windows 98\2000\XP . . . . . . . . . . . . . . . . . . . . . 50

Configuration of the operating system using the TSX FPC 10 card . . . . . . . . . . 51

How to select the hardware type for Windows 98 . . . . . . . . . . . . . . . . . . . . . . . . 52

How to select the hardware type for Windows 2000\XP . . . . . . . . . . . . . . . . . . . 55

How to configure hardware parameters for Windows 98. . . . . . . . . . . . . . . . . . . 58

How to configure hardware parameters for Windows 2000\XP . . . . . . . . . . . . . . 60

How to adjust the ISA TSX FPC 10 card parameters . . . . . . . . . . . . . . . . . . . . . 63

Part IV ETHWAY driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .65

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65

Chapter 6 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67

How to install the driver for Windows 2000\XP . . . . . . . . . . . . . . . . . . . . . . . . . . 68

How to install the driver for Windows NT. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71

Driver configuration tool. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73

Part V XIP driver on TCP/IP . . . . . . . . . . . . . . . . . . . . . . . . . . . . .75

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75

Chapter 7 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77

How to install the driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78

Driver configuration screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80

How to configure the driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82

Part VI Drivers for Atrium Processors . . . . . . . . . . . . . . . . . . . . .85

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Chapter 8 ISAWAY driver for TPCX 57 processors . . . . . . . . . . . . . . . . . 87

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87

How to install the driver . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88

Configuration of the ISAWAY driver for Windows NT . . . . . . . . . . . . . . . . . . . . . 90

Configuration of ISAWAY driver for Windows 98\2000\XP . . . . . . . . . . . . . . . . . 95

Configuration of the operating system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96

How to select the hardware type for Windows 98 . . . . . . . . . . . . . . . . . . . . . . . . 97

How to select the hardware type for Windows 2000\XP . . . . . . . . . . . . . . . . . . 100

How to configure hardware parameters for Windows 98. . . . . . . . . . . . . . . . . . 103

How to configure hardware parameters for Windows 2000\XP . . . . . . . . . . . . . 105

How to adjust the ISA TPCX 57 card parameters. . . . . . . . . . . . . . . . . . . . . . . 108

Chapter 9 PCIWAY driver for TSX PCI 57 ••• processors . . . . . . . . . . . .111

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111

How to install the driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112

Configuring the PCIWAY driver for windows 2000\XP . . . . . . . . . . . . . . . . . . . 114

How to adjust the parameters of the TSX PCI 57 ••• card. . . . . . . . . . . . . . . . . 116

Part VII Modbus driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119

Chapter 10 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .121

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121

How to install the driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122

Driver configuration screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

Driver control screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 126

Driver debug screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128

Information screen. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 130

Part VIII USB driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Chapter 11 Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .133

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 133

How to install the driver. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134

Configuration screens for Win 2000\XP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137

State of the USB link. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 139

Part IX Drivers manager. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 141

Chapter 12 Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .143

Management of X-Way drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143

Appendices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 147

Appendix A The drivers of the TSX PCX 3030 cable . . . . . . . . . . . . . . . . .149

At a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 149

Installing the drivers of the TSX PCX 3030 cable . . . . . . . . . . . . . . . . . . . . . . . 150

Configuration screens for drivers using the TSX PCX 3030 cable.. . . . . . . . . . 154

Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 157

About the Book

At a Glance

Document Scope This document deals with the installation of communication drivers for Windows 98,

Windows 2000/XP and Windows NT operating systems.

These drivers are:

Uni-Telway:

on the serial port,

with a TSXSCP114 card.

Fip:

with a TSXFPC10 card,

with a TSXFPP20 card.

Ethway,

XIP on TCPIP,

drivers for Atrium:

Isaway for the ISA bus,

PCIWAY for the PCI bus.

Modbus,

USB.

Validity Note The data and illustrations found in this documentation are not binding. We reserve

the right to modify our products in line with our policy of continuous product

development.

The information in this document is subject to change without notice and should not

be construed as a commitment by Schneider Electric.

Documents Title of Documentation Reference Number

X-Way Driver TLX DI XIP M

About the Book

Product Related

Warnings Schneider Electric assumes no responsibility for any errors that may appear in this

document. If you have any suggestions for improvements or amendments or have

found errors in this publication, please notify us.

No part of this document may be reproduced in any form or by any means, electronic

or mechanical, including photocopying, without express written permission of

Schneider Electric.

All pertinent state, regional, and local safety regulations must be observed when

installing and using this product.

For reasons of safety and to ensure compliance with documented system data, only

the manufacturer should perform repairs to components.

When controllers are used for applications with technical safety requirements,

please follow the relevant instructions.

Failure to observe this product related warning can result in injury or equipment

damage.

User Comments We welcome your comments about this document. You can reach us by e-mail at

TECHCOMM@modicon.com

General information on the

installation of drivers

At a Glance

Subject of this

Part This part describes the installation principle of the various drivers using the

CD ROM.

What’s in this

Part? This part contains the following chapters:

Chapter Chapter Name Page

1 General information concerning the Drivers 11

General

General information concerning

the Drivers

At a Glance

Subject of this

chapter This chapter provides general information on the drivers.

What’s in this

Chapter? This chapter contains the following topics:

Topic Page

Installation 12

The drivers and Unity Pro 14

General information concerning the Drivers

Installation

At a Glance It is generally possible to launch the installation of all the drivers using the same

procedure.

Procedure The following procedure describes the installation principle of a driver using the

CD ROM.

Step Description

1 Insert the CD ROM in the CD ROM drive.

Result: the Install.htm file launches automatically.

2 Click on the link (in blue underlined text) that corresponds to the driver you wish

to install.

Result: the Downloading files window appears.

3 Choose Run this program from its current location.

Downloading a file

Cancel

OK Further info.

You have chosen to download a file from this location.

SETUP.EXE from D:\CD_Rom\Install.htm

What do you wish to do with this file?

Run this program from its current location

Save this program on the disk

Always ask before opening this type of file

General information concerning the Drivers

4 Then click on OK to confirm your choice.

Result: the Safety warning window appears.

5 Click on Yes to go ahead with the installation.

Result: the installation setup of the chosen driver is run.

6 Click on Next to go ahead with the installation.

7 Configure the driver.

8 Then click on OK to confirm the configuration.

9 Restart your computer.

Step Description

Security warning

Yes No Further info.

Do you wish to install and run "SETUP.EXE from

D:\ CDRom\UNITELWAY\Win2000-XP-Win 98-Me\disk1"?

Impossible to identify this editor for the following reasons:

The object to be verified is unknown to the supplier of

reliability certificates.

General information concerning the Drivers

The drivers and Unity Pro

Precautions To ensure correct operation of the drivers using the Unity Pro software range you

should install or reinstall the drivers using the CDROM version ≥ V2.0.

Drivers that normally operate using the Unity Pro software range should also be

installed using Windows XP or Windows 2000.

Uni-Telway drivers

At a Glance

Subject of this

Part This part describes how to install the drivers associated with Uni-Telway

communication for Windows 98, Windows 2000\XP and Windows NT operating

systems.

What’s in this

Part? This part contains the following chapters:

Chapter Chapter Name Page

2 Serial port 17

3 TSX SCP 114 card 27

Uni-Telway drivers

Serial port

At a Glance

Subject of this

Chapter This chapter describes installation of the Uni-Telway driver communicating in slave

mode on the serial port with a remote device.

Driver installation consists of two steps:

installation of files on the station,

configuration of the driver.

What’s in this

Chapter? This chapter contains the following topics:

Topic Page

How to install the driver 18

Driver configuration screens 20

How to configure the driver 24

Serial port

How to install the driver

At a Glance Driver installation is a standard installation. It can be launched either:

from the drivers’ CD-ROM,

or from disks if the station has no CD-ROM drive.

How to create a

set of disks Use the following procedure to create installation disks:

Preliminary

operations Before installing the new driver, you must check that no other version of this driver

exists on the station.

If a driver does exist, you must delete it before carrying out the new installation.

A previous version can be uninstalled using:

Drivers Manager software,

or the Control Panel → Add/Remove Programs.

Note: The installation disks are created from the CD-ROM.

Step Action

1 Use a station with a CD-ROM drive.

2 Insert the CD-ROM into the drive.

3 Access the directory of the driver to be copied onto disk.

4 Copy the contents of the DISK1 directory onto a disk. Repeat this step for each

DISK directory.

Note: it is advisable to number the disks.

Serial port

How to install the

driver To install the driver, carry out the following procedure:

Start of installation

Installation by

CD-ROM?

Insert CD-ROM in CD-ROM drive

Insert the 1st disk in the drive

Appearance

of the file

INSTALL.HTM

Click on the link which corresponds

to the driver to be installed

Access the directory of the driver

to be installed corresponding to

the PC’s operating system

Access the directory DISK1

Double click on the file

SETUP.EXE

Click on Next

Configure the driver then close the

configuration screen

End of installation

Yes

Choose Run this program from

its current location then confirm

by clicking on OK

Restart the computer

Choose Yes in the security warning

screen

Serial port

Driver configuration screens

At a Glance The configuration tool is used to link a driver configuration profile to a remote device

that communicates with the station.

Illustration The screen dedicated to the Uni-Telway driver looks like this:

Description This table describes the different areas which make up the configuration screen:

Uni-Telway Configuration

Station ID

Target Station:

Cancel Apply

[Default]

Add Modify Delete

Remote Password Ph

Station List

[Default] COM 1

Number Element

1 This field is used to display the active profile.

2 This list is used to display the driver profile associated with each remote device.

3 These buttons are used to select the driver profile.

4 This button is used to add new profiles to the list.

5 This button is used to modify the profile of the driver selected from the list.

6 This button is used to remove a profile from the list.

7 This button is used to make the profile selected with the cursor active.

Serial port

Uni-Telway

parameters The parameters are presented in the following manner:

The Station ID window is used to name the remote device associated with the

driver configuration.

The COM Port window is used to select the communication port used.

The Uni-telway Slave Address window is used to enter:

the standard slave address of the driver,

the number of slave addresses used by the driver.

The Modem Communication window is useful when the local station is

communicating via a modem. In this case, this window is used to enter:

the HAYES string to be sent to the modem in order to initialize it,

the call number of the remote device,

the password to be sent to the remote device, if it has been configured with a list

of callers with passwords (e.g. TSX MDM 10 card configured with passwords).

Link Parameters

Station ID

COM Port

Uni-telway Slaves address

Communication Modem

NumberBase

Hayes

Tel No.

Password

Advanced

Uni-Telway

Modem Used

Cancel

Parameters of the Station

[Default]

COM 1

Serial port

Line parameters The parameters are presented in the following manner:

This tab is used to configure the parameters linked to transmission:

Speed: transmission speed of between 300 and 115 200 bits/s,

Auto-Adaptation: self-adaptation of speed (time during which the driver tries to

connect at a given speed),

Data: specifies the size of the data exchanged over the line,

Parity: is used to set whether a parity bit is added or not, as well as its type,

Stop Bits: is used to enter the number of stop bits used for communication,

RTS/CTS Delay: enables the CTS signal to be used in the event of multidrop

communication.

The Default button is used to reset all these parameters to their default value.

Link Parameters

Speed

seconds

7 bits

Advanced

Uni-Telway

OK Cancel

Parameters of the Station

9600 bits/s

Auto-Adaptation 1

Valid

Use CTS

RTS/CTS Delay X 100 ms

Default

Data Content Parity Stop Bits

8 bits

1 bit

2 bits

Odd

Even

Without

Serial port

Advanced

parameters The parameters are presented in the following manner:

This tab is used to configure the line type:

PC: uses the driver to connect to a series 7 PLC terminal port,

Uni-Telway: default value, uses the driver to communicate in Uni-Telway,

Num PLC: uses the driver to connect to NUM PLCs.

RX/TX Delay: by default set to –1; is used to extend the return time (if the

station is too fast).

Link Timeout: by default set to –1; is used to set the maximum time for

detecting the right transmission speed.

Force Virtual Com Port: must be checked if the Unit-Telway driver uses a virtual

communication port except for use with the TSX PCX 3030 cable.

Link Parameters Advanced

Uni-Telway

OK Cancel

Parameters of the Station

TimeOut Link

RX/TX Delay

Type of link

Other

Uni-Telway

PCL No.

-1

Force Virtual Com Port

Serial port

How to configure the driver

At a Glance During driver installation, a default profile is proposed. This profile can be modified

or a new one created.

How to create a

new profile From the driver configuration screen.

Step Action

1 Click on the Add... button. see Uni-Telway parameters, p. 21.

2 Enter station name.

3 Select COM port.

4 Define the driver slave address.

5 If the driver uses a modem to communicate, select the Use modem box and

enter the different fields associated with it.

6 Select the Line parameters (See Line parameters, p. 22) tab.

7 Configure the transmission parameters according to the remote device (baud

rate, parity, data bits, etc.).

8 If the driver requires specific configuration, click on the Advanced (See

Advanced parameters, p. 23) tab and configure the parameters according to the

remote device.

9 Accept the configuration by clicking on Ok.

Result: the new configuration appears in the list.

Serial port

How to modify a

profile From the driver configuration screen.

How to remove a

profile From the driver configuration screen.

How to activate a

profile From the driver configuration screen.

Step Action

1 Select a configuration profile from the list.

Result: the cursor moves to the selected line.

2 Click on the Modifier button; see Uni-Telway parameters, p. 21.

3 Modify the parameters according to the remote device.

4 Select the Line parameters (See Line parameters, p. 22) tab and modify the

transmission parameters according to the remote device (speed, parity, data,

etc.).

5 If the driver requires specific configuration, click on the Advanced (See

Advanced parameters, p. 23) tab and modify the parameters according to the

remote device.

6 Accept the configuration by clicking on Ok .

Result: the new configuration appears in the list.

Step Action

1 Select a configuration profile from the list.

Result: the cursor moves to the selected line.

2 Click on Delete.

3 Press the Yes button to confirm your choice.

Result: the configuration is removed from the list.

Step Action

1 Select a profile from the list.

Result: the cursor moves to the selected line.

2 Click on the Apply button.

Serial port

TSX SCP 114 card

At a Glance

Subject of this

Section This chapter describes installation of the Uni-Telway driver communicating in slave

mode via the PCMCIA TSX SCP 114 card with a remote device.

Driver installation consists of three steps:

installation of files on the station,

configuration of the driver

configuration of the operating system to recognize the driver.

What’s in this

Chapter? This chapter contains the following topics:

Topic Page

How to install the driver 28

Driver configuration screens 30

Configuration of the Windows 98 operating system 32

Configuration of the Windows 2000\XP operating system 33

Configuration of Win NT operating system 34

TSX SCP 114 card

How to install the driver

At a Glance Driver installation is a standard installation. It can be launched either:

from the drivers’ CD-ROM,

or from disks if the station has no CD-ROM drive.

How to create a

set of disks Use the following procedure to create installation disks:

Note: The installation disks are created from the CD-ROM.

Step Action

1 Use a station which has a CD-ROM drive.

2 Insert the CD-ROM into the drive.

3 Access the directory of the driver to be copied onto disk.

4 Copy the contents of the DISK1 directory onto a disk. Repeat this step for each

DISK directory.

Note: it is advisable to number the disks.

TSX SCP 114 card

How to install the

driver To install the driver, carry out the following procedure:

Start of installation

Installation by

CD-ROM?

Insert CD-ROM in CD-ROM drive

Insert the 1st disk in the drive

Appearance

of the file

INSTALL.HTM

Click on the link which corresponds

to the driver to be installed

Access the directory of the driver

to be installed corresponding to

the PC’s operating system

Access the directory DISK1

Double click on the file

SETUP.EXE

Yes

Choose Run this program from

its current location then confirm

by clicking on OK

Click on Next

Configure the driver then close the

configuration screen

End of installation

Restart the computer

Choose Yes in the security warning

screen

TSX SCP 114 card

Driver configuration screens

At a Glance The configuration tool is used to configure the TSX SCP 114 card Uni-Telway driver.

Illustration The screen dedicated to the Uni-Telway driver looks like this:

Description This table describes the different areas which make up the configuration screen:

Link Parameters

Uni-Telway

OK Cancel

TSX SCP114 Configuration

Slave number (Ad0)

Slave

Apply

Number Element

1 This window is used to set the standard slave address (Ad0) used by the card.

2 This button is used to recognize the address.

3 This tab is used to access the configuration of transmission parameters.

TSX SCP 114 card

Line parameters The parameters are presented in the following manner:

This tab is used to configure the parameters linked to transmission:

transmission speed of between 300 and 19,200 bits/s,

Time-out,

Number of data bits: specifies the size of the data exchanged over the line,

parity: is used to set whether a parity bit is added or not, as well as its type,

number of Stop bits: is used to enter the number of stop bits used for

communication,

RTS/CTS delay: enables the CTS signal to be used in the event of multidrop

communication.

The Default button is used to reset all these parameters to their default value.

Link Parameters

Speed

7 bits

Uni-Telway

OK Cancel

Station Parameters

9600 bits/s

Delay 10

Default

RTS/CTS Delay X 100 ms

Default

Data Content Parity Stop Bits

8 bits

1 bit

2 bits

Even

Odd

Without

Cancel

Apply

TSX SCP 114 card

Configuration of the Windows 98 operating system

At a Glance After the driver installation and configuration phase, the operating system shall

recognize the TSX SCP 114 card and its driver.

How to configure

the operating

system

The following procedure describes how to configure the operating system:

Note: So that the driver is loaded when the card is inserted, it is essential that the

station is restarted to update the registry.

Step Action

1 Install and configure the driver.

2 Restart the station.

3 Insert the PCMCIA card into its slot.

Result:

The system automatically detects the card and the following window is

displayed:

4 Select the option Windows default driver.

5 Confirm using the Ok button.

New device detected ?

Cancel Help

Windows default driver

Driver supplied on hardware manufacturer diskette

Telemecanique-TSX SCP 114

Select which driver you want to install for your new hardware

Do not install a driver (Windows will not prompt you again)

Select from list of drivers

TSX SCP 114 card

Configuration of the Windows 2000\XP operating system

At a Glance After the driver installation and configuration phase, the operating system shall

recognize the TSX SCP 114 card and its driver.

How to configure

the operating

system

The following procedure describes how to configure the operating system:

Note: When configuring the system, it is not necessary to restart the station.

Step Action

1 Install and configure the driver.

2 Insert the PCMCIA card into its slot.

Result:

The system automatically detects the card and loads the card driver.

TSX SCP 114 card

Configuration of Win NT operating system

At a Glance After the driver installation and configuration phase, the operating system shall

recognize the TSX SCP 114 card and its driver.

How to configure

the operating

system

The following procedure describes how to configure the operating system:

Case in which

the driver does

not start

One possibility is that the default IRQ3 is busy, in which case another one must be

used:

Follow the steps below to detect an available IRQ:

Note: So that the driver is loaded when the card is inserted, it is essential that the

station is restarted to update the registry.

Step Action

1 Install and configure the driver.

2 Shutdown your machine.

3 Insert the PCMCIA card into its slot.

Result:

The system automatically detects the card and loads the driver.

Step Action

1 In the taskbar, select "Start ->Run".

2 enter the command "Winmsd"

3 Select the tab "Resources", choose an available IRQ and confirm with OK.

4 Edit the DSCP114.REG file and modify the value of "InterruptNumber"

5 In the taskbar, select "Start ->Run", enter the command "DSCP114" and

confirm.

6 Restart your machine.

III

FIP drivers

At a Glance

Subject of this

Part This part describes how to install the drivers associated with FIP communication for

Windows 98, Windows 2000\XP and Windows NT operating systems.

What’s in this

Part? This part contains the following chapters:

Chapter Chapter Name Page

4 TSX FPP 20 card 37

5 TSX FPC 10 ISA card 45

FIP drivers

TSX FPP 20 card

At a Glance

Subject of this

Chapter This chapter describes installation of the driver used to communicate in Fipway\Fipio

mode via the TSX FPP K200 connection kit with a remote device.

Driver installation consists of three steps:

installation of files on the station,

configuration of the driver,

configuration of the operating system to recognize the driver.

What’s in this

Chapter? This chapter contains the following topics:

Topic Page

How to install the driver 38

How to install the driver 40

Configuration of the Windows 98 operating system 41

Configuration of the Windows 2000\XP operating system 42

Configuration of the Windows NT operating system 43

TSX FPP 20 card

How to install the driver

At a Glance Driver installation is a standard installation. It can be launched either:

from the drivers’ CD-ROM,

or from disks if the station has no CD-ROM drive.

How to create a

set of disks Use the following procedure to create installation disks:

Note: The installation disks are created from the CD-ROM.

Step Action

1 Use a station which has a CD-ROM drive.

2 Insert the CD-ROM into the drive.

3 Access the directory of the driver to be copied onto disk.

4 Copy the contents of the DISK1 directory onto a disk. Repeat this step for each

DISK directory.

Note: it is advisable to number the disks.

TSX FPP 20 card

How to install the

driver To install the driver, carry out the following procedure:

Start of installation

Installation by

CD-ROM?

Insert CD-ROM in CD-ROM drive

Insert the 1st disk in the drive

Appearance

of the file

INSTALL.HTM

Click on the link which corresponds

to the driver to be installed

Access the directory of the driver

to be installed corresponding to

the PC’s operating system

Access the directory DISK1

Double click on the file

SETUP.EXE

Yes

Choose Run this program from

its current location then confirm

by clicking on OK

Click on Next

Configure the driver then close the

configuration screen

End of installation

Restart the computer

Choose Yes in the security warning

screen

TSX FPP 20 card

How to install the driver

At a Glance The configuration tool is used to configure the driver in Fipway or Fipio mode to use

the TSX FPP 20 card.

Illustration The screen dedicated to the card driver looks like this:

Description This table describes the different areas which make up the configuration screen:

Network Parameters

OK Annuler

TSXFPP20 Configuration

Network :

Station :

Network Type

Fipway

Fipio

Fipway (World FIP)

Fipio (WORLD FIP)

Appliquer

Number Element

1 This field is used to set the network address.

2 This field is used to set the station address.

3 This window is used to select the type of Fipway or Fipio connection.

TSX FPP 20 card

Configuration of the Windows 98 operating system

At a Glance After the driver installation and configuration phase, the operating system shall

recognize the TSX FPP 20 card and its driver.

How to configure

the operating

system

The following procedure describes how to configure the operating system:

Note: So that the driver loads up when the card is inserted, it is essential that the

station is restarted to allow Windows to update the registry.

Step Action

1 Install and configure the driver.

2 Restart the station.

3 Insert the PCMCIA card into its slot.

Result:

The system automatically detects the card and the following window is

displayed:

4 Select the option Windows default driver.

5 Confirm using the Ok button.

New device detected ?

Cancel Help

Windows default driver

Driver supplied on hardware manufacturer diskette

Telemecanique-TSX SCP 114

Select which driver you want to install for your new hardware

Do not install a driver (Windows will not prompt you again)

Select from list of drivers

TSX FPP 20 card

Configuration of the Windows 2000\XP operating system

At a Glance After the driver installation and configuration phase, the operating system shall

recognize the TSX FPP 20 card and its driver.

How to configure

the operating

system

The following procedure describes how to configure the operating system:

Note: When configuring the system, it is not necessary to restart the station.

Step Action

1 Install and configure the driver.

2 Insert the PCMCIA card into its slot.

Result:

The system automatically detects the card and loads the card driver.

TSX FPP 20 card

Configuration of the Windows NT operating system

At a Glance After the driver installation and configuration phase, the operating system shall

recognize the TSX FPP 20 card and its driver.

How to configure

the operating

system

The following procedure describes how to configure the operating system:

Case in which

the driver does

not start

One possibility is that the default IRQ3 is busy, in which case another one must be

used:

Follow the steps below to detect an available IRQ:

Note: When configuring the system, it is not necessary to restart the station.

Step Action

1 Install and configure the driver.

2 Shutdown your machine.

3 Insert the PCMCIA card into its slot.

Result:

The system automatically detects the card and loads the driver.

Step Action

1 In the taskbar, select "Start ->Run".

2 enter the command "Winmsd"

3 Select the tab "Resources", choose an available IRQ and confirm with OK.

4 Edit the DSCP114.REG file and modify the value of "InterruptNumber"

5 In the taskbar, select "Start ->Run", enter the command "DFPP20" and

confirm.

6 Restart your machine.

TSX FPP 20 card

TSX FPC 10 ISA card

At a Glance

Subject of this

Chapter This chapter describes installation of the driver communicating in Fipway/Fipio

mode via the ISA TSX FPC 10 card and a remote device.

Driver installation consists of three steps:

installation of files on the station,

configuration of the driver,

configuration of the operating system to recognize the driver.

What’s in this

Chapter? This chapter contains the following topics:

Topic Page

How to install the driver 46

Driver configuration screen for Windows NT 48

Driver configuration screen for Windows 98\2000\XP 50

Configuration of the operating system using the TSX FPC 10 card 51

How to select the hardware type for Windows 98 52

How to select the hardware type for Windows 2000\XP 55

How to configure hardware parameters for Windows 98 58

How to configure hardware parameters for Windows 2000\XP 60

How to adjust the ISA TSX FPC 10 card parameters 63

TSX FPC 10 ISA card

How to install the driver

At a Glance Driver installation is a standard installation. It can be launched either:

from the drivers’ CD-ROM,

or from disks if the station has no CD-ROM drive.

How to create a

set of disks Use the following procedure to create installation disks:

Preliminary

operations Before installing the new driver, you must check that there is no previous version on

the station.

If a driver does exist, you must delete it before carrying out the new installation.

The previous version of the driver can be uninstalled using:

Drivers Manager software,

or the Control Panel → Add/Remove Programs.

Note: The installation disks are created from the CD-ROM.

Step Action

1 Use a station which has a CD-ROM drive.

2 Insert the CD-ROM into the drive.

3 Access the directory of the driver to be copied onto disk.

4 Copy the contents of the DISK1 directory onto a disk. Repeat this step for each

DISK directory.

Note: it is advisable to number the disks.

TSX FPC 10 ISA card

How to install the

driver To install the driver, carry out the following procedure:

Start of installation

Installation by

CD-ROM?

Insert CD-ROM in CD-ROM drive

Insert the 1st disk in the drive

Appearance

of the file

INSTALL.HTM

Click on the link which corresponds

to the driver to be installed

Access the directory of the driver

to be installed corresponding to

the PC’s operating system

Access the directory DISK1

Double click on the file

SETUP.EXE

Yes

Choose Run this program from

its current location then confirm

by clicking on OK

Click on Next

Configure the driver then close the

configuration screen

End of installation

Restart the computer

Choose Yes in the security warning

screen

TSX FPC 10 ISA card

Driver configuration screen for Windows NT

At a Glance The configuration tool is used to configure the driver in Fipway or Fipio mode to use

a ISA TSX FPC 10 card.

Illustration The screen dedicated to the card driver looks like this:

Description This table describes the different areas and buttons which make up the configuration

screen:

Dfpway - Configuration FIP FPC SN

Save

Read

By default

Fipio Mode

Fipway address

Fipio connection point 0

Driver instance

Fipio address

Station

Network

Fipway mode FIP01

FIP02

Zone Description

Fipway address This area is used to define the network address of the station when the

driver is configured in Fipway mode.

Fipio address This area is used to define the connection point number when the driver

is configured in Fipio mode.

Driver instance This area is used to select the instance of the driver used (max. 2).

Save Used to save the configuration of the driver that has just been entered.

Read Used to read the configuration of the driver saved previously.

By default Allows default automatic entry of the driver configuration.

TSX FPC 10 ISA card

Advanced

configuration To access the advanced configuration screen use the commands

"File->Advanced Configuration" .

The following window is displayed:

The following table describes the different areas and buttons in the window.

Zone Description

I/O address Used to choose the address in the storage area with which the driver

can find the Fipway FPC10 module. This address must be included

between 100h and 3F0h and be identical to the address configured in

the module.

DMA channel Used to select the DMA resource shared by the driver and the module.

This information must be identical to that configured on the module.

Interrupt Used to select the interrupt shared by the driver and the communication

module. This information must be identical to that configured on the

module.

Mode Used to disable the driver by checking the "OFF" box. This is usually the

case for the second instance of the driver. (FIP02).

WorldFip Allows use of frames in WorldFip profile A format whose CRC

calculation complies with the IECSC65C105 standard.

Cancel button Used to return to the previous window.

By default button Used to configure the different areas with default parameters.

OK button Used to acknowledge the new configuration parameters.

Cancel

By default

PRUC

Configuration FIP FPC SN - Advanced

I/O address 210h

DMA channel

World FIP

Channel 5

Channel 6

Channel 7

Interrupt

IRQ 10

IRQ 11

IRQ 15

IRQ 3

IRQ 5

Mode

Off

TSX FPC 10 ISA card

Driver configuration screen for Windows 98\2000\XP

At a Glance The configuration tool is used to configure the driver in Fipway or Fipio mode to use

a ISA TSX FPC 10 card.

Illustration The screen dedicated to the card driver looks like this:

Description This table describes the different areas which make up the configuration screen:

Network Parameters

OK Cancel

TSXFPPC10 Configuration

Network:

Station:

Network Type

Fipway

Fipio

Fipway (World FIP)

Fipio (WORLD FIP)

Apply

Number Element

1 This field is used to set the network address.

2 This field is used to set the station address.

3 This window is used to select the type of Fipway or Fipio connection.

TSX FPC 10 ISA card

Configuration of the operating system using the TSX FPC 10 card

At a Glance After the driver installation and configuration phase, the operating system shall

recognize the ISA TSX FPC 10 card and its driver.

Installation

principles As this card is not automatically recognized by the operating system, the following

phases must be carried out:

Step Action

1 Select the hardware type:

for Win 98 see How to select the hardware type for Windows 98, p. 52,

for Win 2000/XP see How to select the hardware type for Windows 2000\XP,

p. 55,

for Win NT no operation is required.

2 Configure the parameters of the operating system to recognize the card:

for Win 98 see How to configure hardware parameters for Windows 98,

p. 58,

for Win 2000/XP see How to configure hardware parameters for Windows

2000\XP, p. 60,

for Win NT no operation is required.

3 Switch off the PC.

4 Adjust the card parameters (See How to adjust the ISA TSX FPC 10 card

parameters, p. 63):

the standard I/O address,

the IRQ interrupt address.

5 Connect the card to the ISA bus.

6 Turn the PC back on.

Result: the driver is operational.

TSX FPC 10 ISA card

How to select the hardware type for Windows 98

Procedure After having installed and configured the driver, carry out the following procedure to

select the hardware type.

Step Action

1 In the initial window which is displayed, click on Next.

Result

The following window appears:

Add new hardware Assistant ?

Next> Cancel

Windows can now search for hardware that is

incompatible with Plug-and-Play, or you can select the

hardware from a list.

When Windows detects a new hardware, it automatically

determines the current parameters for the peripheral and

correctly installs the pilot. It is therefore strongly

recommended that you allow Windows to detect the new

hardware.

Do you wish for Windows to automatically detect any

new hardware?

Yes (recommended)

No, I wish to select the hardware from a list.

< Previous:

TSX FPC 10 ISA card

2Answer No to the question Do you want Windows to search for your new

hardware?

Result

The following window appears:

3 Select FPC10 Device from the list then click on Next.

4 Select FPC10 WDM Device from the list then click on Next.

Result

The operating system suggests the hardware parameters that you must adjust

on the card.

Step Action

Add new hardware Assistant

Next> Cancel

< Previous:

Select the hardware type you wish to install.

Types of hardware:

Modem

Mouse

Multifunction adapter cards

Network cards

Other peripherals

PCMCIA extension

FPC10 Device

Ports (COM & LPT)

Printer

SCSI Controllers

< Previous:

Add new hardware Assistant

Next> Cancel

Windows can install your hardware using the following parameters:

Warning: your hardware cannot be configured for use with the resources

listed. You may use the Peripherals Manager to adjust the parameters before

restarting your computer. Click successively on the Start, Parameters,

Control panel, System, and Peripherals Manager tabs. To modify the

hardware parameters, consult the hardware documentation supplied.

To continue installing the software needed by your hardware, click Next.

Type of resource Parameter

Input/output range 0190-019F

Interrupt Request (IRQ) 10

Print...

TSX FPC 10 ISA card

5 Click on Next.

6Answer No to the question Do you want to restart your computer now?

Result

The following window appears and the card is shown in the station’s hardware

configuration.

7 Do you want to modify the parameters?

If yes, go to the procedure: how to modify hardware parameters (See How

to configure hardware parameters for Windows 98, p. 58),

If no, click on Ok then restart the station with the card.

Step Action

CancelOK

Computer

System Properties ?

General Peripherals Manager Hardware Profiles

Display peripherals by type Display peripherals by connection

Performance

CD-ROM

Disk drives

Graphics cards

Disk controllers

Hard disk controllers

Keyboard

Screens

Mouse

Network cards

FPC10 Device

FPC10 WDM Device

Ports (COM & LPT)

Sound, video and game controllers

System peripherals

USB bus controllers

Properties: Refresh Delete Print...

TSX FPC 10 ISA card

How to select the hardware type for Windows 2000\XP

Procedure After having installed and configured the driver, carry out the following procedure to

select the hardware type.

Step Action

1 In the initial window which is displayed, click on Next.

Result

The following window appears:

Add/Delete new hardware Assistant

CancelNext>< Previous

Uninstall/Disconnect a peripheral

Choose this option to uninstall a peripheral or to prepare your computer for the

disconnection of a peripheral.

Add/Troubleshoot a peripheral

Choose this option to add a new peripheral to your computer or if you have difficulty

operating an existing peripheral.

Select the task you wish to perform for your hardware, then click on next.

What task do you wish to perform on the hardware?

Select a task for the hardware

TSX FPC 10 ISA card

2 Select the option Add/Troubleshoot a peripheral then click Next.

Result

The following window appears:

3 Select the option Add a new peripheral then click Next.

4Answer No to the question Do you want Windows to search for your new

hardware?

Step Action

Add/Delete new hardware Assistant

CancelNext>< Previous

The following hardware is already installed on your computer. If you encounter

difficulty with one of these peripherals, select the peripheral and click Next.

What hardware peripheral do you wish to troubleshoot?

Selecting a hardware peripheral

If you try to add a peripheral and it doesn’t appear below,

select Add a new peripheral, then click Next.

Peripherals

Add a new peripheral

COMPAQ 171 FS

Disk drive

COMPAQ CRD-8320B

WDC AC36400L

ES1869 Control Interface (WDM)

ES1869 Plug and Play Audio Drive (WDM)

TSX FPC 10 ISA card

5 Click on Next.

Result

The following window appears:

6 Select FPC10 Device from the list then click on Next.

7 Select FPC10 WDM Device from the list then click on Next.

Result: an information window appears.

8 A window informs the user that the hardware parameters of the card must be

entered by the user. Click on OK and go to the next procedure: how to

configure hardware parameters (See How to configure hardware parameters

for Windows 2000\XP, p. 60).

Step Action

Add/Delete new hardware Assistant

CancelNext >

< Previous

Select the hardware type you wish to install.

Which hardware type do you wish to install?

Hardware type

Hardware types:

PCX57 Device

Port (COM & LPT)

Printers

SCSI and RAID controllers

Sound, video and game controllers

Systems peripherals

Tape drives

FPC10 Device

TSX FPC 10 ISA card

How to configure hardware parameters for Windows 98

Procedure When you want to modify the hardware parameters, carry out the following

procedure.

Step Action

1 Click on Properties.

Result

The following window appears:

2 Uncheck the box Use automatic settings.

3 Select Input/Output Range from the list.

Properties of the peripheral PCX57 WDM

OK Cancel

Peripheral PCX57 WDM

Type of resource Parameter

General Pilot Resources

Use automatic parameters

Input/output range 01A0-001AF

Interrupt Request (IRQ) 10

Modify the parameters...

No conflict.

List of peripheral in conflict:

Standard configuration 0

Parameters based on:

TSX FPC 10 ISA card

4 Click on Change settings.

Result

The following window appears:

5 From the Value list, select the non-conflicting address range.

Note: note the values because they must be coded onto the ISA card.

6 Confirm with OK.

7 Carry out steps 5 to 8 selecting Interrupt Request from the list.

8 Confirm with Ok then restart the station with the card connected.

Step Action

Modify input/output range

Enter the input/output range you wish to define for this

peripheral.

You can either enter a specific range and the closest valid

range will be automatically selected, or select a range using

the indicator arrows.

No peripherals in conflict.

Value:

The parameter you have chosen is not in conflict with

other peripherals.

01A0-01AF

OK Cancel

Information concerning conflicts

TSX FPC 10 ISA card

How to configure hardware parameters for Windows 2000\XP

Procedure After having selected the hardware type, carry out the following procedure to

configure the parameters.

Step Action

1 Click on the Resources button.

2 Click on Manual Configuration.

Result

The following window appears:

3 Uncheck the box Use automatic settings.

4 Select Input/Output Range from the list.

Add new hardware Assistant Properties

Standard configuration 0000

FPC10 WDM Device

Cancel

Modify the parameters...

Parameters based on:

List of peripherals in conflict:

No conflict.

Resource parameters:

Resources

Type of Resource Parameter

Use the automatic parameters

Input/output range ?

Interrupt Request (IRQ) ?

TSX FPC 10 ISA card

5 Click on Change settings.

Result

The following window appears:

6 From the Value list, select the non-conflicting address range.

Note: note the values because they must be coded onto the ISA card.

7 Confirm with OK.

Result: a confirmation window appears.

8 Confirm with Yes.

9 Carry out steps 4 to 8 selecting Interrupt Request from the list.

Step Action

Modify input/output range

Enter the input/output range you wish to define for this

peripheral.

You can either enter a specific range and the closest valid range

will be automatically selected, or select a range using the upper or

lower indicator arrows.

This resource is assigned to the following child peripherals:

Value:

The parameter you have chosen is not in conflict with other

peripherals.

OK Cancel

0210-021F

Information concerning conflicts

No peripherals in conflict

TSX FPC 10 ISA card

10 Accept the configuration with OK.

Result

The following window appears:

11 Click on Finish to confirm hardware configuration.

Step Action

Add / Remove Hardware Wizard

Cancel Finish<Back

End of Add/Delete hardware Assistant

The following hardware has been installed:

FPC10 WDM Device

Check the documentation of your hardware to know whether

you should configure the new hardware manually. To

operate the hardware you must restart the computer.

Resources

To display or modify the resources for this

peripheral, click Resources.

To close the Assistant, click on Finish.

TSX FPC 10 ISA card

How to adjust the ISA TSX FPC 10 card parameters

At a Glance Before installing the TSX FPC 10 card, you must adjust the following parameters:

the standard I/O address,

the IRQ interrupt address.

Illustration This card comprises the following elements:

Numbers and

elements The following table describes the different parameters to be adjusted:

12 3

Number Element

1 Jumpers (SW1) are used to select the DMA channel (Direct Access Memory)

(no object).

2 A jumper (SW2) is used to select the IRQ (Interrupt Request) level.

3 The micro-switches (SW3) are used to select the standard address of the card

in the I/O space.

TSX FPC 10 ISA card

Procedure To adjust the parameters, proceed in the following manner:

Example of IRQ

selection The interrupt address provided by the system is 10:

Example of

standard

address

selection

The standard address provided by the system is equal to 210 in hexadecimal:

Step Action

1 Set the IRQ interrupt jumper to comply with the address provided by the windows

98 (See How to configure hardware parameters for Windows 98, p. 58) or

2000/XP (See How to configure hardware parameters for Windows 2000\XP,

p. 60) operating systems.

2 Code the standard I/O address provided by the operating system windows 98

(See How to configure hardware parameters for Windows 98, p. 58) or 2000/XP

(See How to configure hardware parameters for Windows 2000\XP, p. 60) with

the micro-switches.

Note: The jumper must not be set in the IRQ position.

IRQ

12345678

200

100

ETHWAY driver

At a Glance

Subject of this

Part This part describes how to install the drivers associated with ETHWAY

communication for Windows 2000\XP and Windows NT operating systems.

What’s in this

Part? This part contains the following chapters:

Chapter Chapter Name Page

6 Installation 67

ETHWAY driver

Installation

At a Glance

Subject of this

Chapter This driver is used to communicate via an Ethernet card using the ETHWAY

protocol. Driver installation consists of two main steps:

installation of files on the station,

configuration of the driver.

What’s in this

Chapter? This chapter contains the following topics:

Topic Page

How to install the driver for Windows 2000\XP 68

How to install the driver for Windows NT 71

Driver configuration tool 73

Installation

How to install the driver for Windows 2000\XP

At a Glance The ETHWAY protocol is installed from:

from the drivers’ CD-ROM,

or from disks if the station has no CD-ROM drive.

How to create a

set of disks Use the following procedure to create installation disks:

Note: The installation disks are created from the CD-ROM.

Step Action

1 Use a station which has a CD-ROM drive.

2 Insert the CD-ROM into the drive.

3 Access the directory of the driver to be copied onto disk.

4 Copy the contents of the DISK1 directory onto a disk. Repeat step for each

DISK directory.

Note: it is advisable to number the disks.

Installation

How to install the

driver The ETHWAY driver is installed in accordance with the following procedure:

Step Action

1 Insert the CD-ROM or the first disk.

2 Access the Control Panel in Windows.

3 Double-click on the Network connections and Remote access icon.

4 Select the icon Local connection then by right-clicking select the command

Properties.

Result

The following window appears:

5 Click on the Install button.

Local Area Connection Properties

Uninstall

Connect using:

Properties

The selected components are used by this connection:

General

Display an icon in the Task bar once connected

3Com EtherLink XL PCI Combo NIC (3C900B-COMBO)

Configure

Install...

OK Cancel

Description

Enables you to access the resources on a Microsoft

network.

Client for Microsoft Networks

File and printer Sharing for Microsoft Networks

Internet Protocol (TCP/IP)

Installation

6 In the Select Network Component Type window, select the type Protocol

then click on Add.

Result

The following window appears:

7 Click on Have Disk.

8 Select the access path of the files to be installed from the CD-ROM or the disk

using the Browse button.

9 Click on Ok.

10 In this window select the ETHWAY Protocol then click on OK.

11 Select the ETHWAY protocol then click on Properties.

12 In the configuration screen (See Driver configuration tool, p. 73), configure the

protocol then click on OK.

13 Complete the installation by clicking on OK.

Step Action

Selection of network protocol

Manufacturers:

Disk supplied...

Click on the network protocol you wish to install and then click on OK.

If you have an installation disk for this component, click on the Disk

supplied.

OK Cancel

Network protocol:

Network supervisor pilot

DLC Protocol

NetBEUI Protocol

Transport Protocol compatible with NWLink

IPX/OSI-LAN Protocol

Microsoft

Schneider Corporation

Installation

How to install the driver for Windows NT

At a Glance The ETHWAY protocol is installed from:

from the drivers’ CD-ROM,

or from disks if the station has no CD-ROM drive.

How to create a

set of disks Use the following procedure to create installation disks:

Note: The installation disks are created from the CD-ROM.

Step Action

1 Use a station which has a CD-ROM drive.

2 Insert the CD-ROM into the drive.

3 Access the directory of the driver to be copied onto disk.

4 Copy the contents of the DISK1 directory onto a disk. Repeat step for each

DISK directory.

Note: it is advisable to number the disks.

Installation

How to install the

driver The ETHWAY driver is installed in accordance with the following procedure:

Step Action

1 Insert the CD-ROM or the first disk.

2 Access the Control Panel in Windows.

3 Launch the Networks icon.

4 Select the Protocols tab and click on Add.

5 In the protocol selection window click on Have Disk...

6 Confirm your choice of diskette or CD-ROM and then choose ETHWAY

Protocol. The driver files are copied onto the PC.

7 Select the Links tab and check the link of the ETHWAY protocol with the

Ethernet card(s) installed on the PC. ETHWAY can be linked selectively to 1 or

2 Ethernet cards.

8 Return to the Protocols tab, select ETHWAY Protocoland click on Properties.

9 Enter the ETHWAY Network-Station address in the Network and Station fields.

If 2 Ethernet cards are installed on the PC, repeat this operation for each entry

in the Adapter name list.

10 Confirm the ETHWAY parameters, the network window, then restart the

machine.

Installation

Driver configuration tool

At a Glance The configuration tool is used to configure the Ethernet card to communicate

according to the ETHWAY protocol.

Illustration The card configuration screen looks like this:

ETHWAY Protocol Properties

Default

Receive

el3c5891

128

512

256

1024

Buffers

Acknowledgement (ms)

Size

Send

Retry Period Filter Period

TE MAC Address

Network Station

Export Name

Adapter Name

ETHWAY01

063

800

3000

ETHWAY -Parameters

Installation

Description This table describes the different areas which make up the configuration screen:

Number Element

1 This field is used to select the Ethernet card (useful if there are several Ethernet

cards). This field cannot be modified under Windows 2000\XP.

2 This field is used to select the ETHWAY driver instance. This field cannot be

modified under Windows 2000\XP.

3 These windows are used to define the address {Network.Station} of the Ethernet

card used.

4 This box is used to replace the Ethernet card’s MAC address with the

SCHNEIDER MAC address (00 80 F4 Network Station).

5 This window is used to configure the reception acknowledgment by defining:

the retransmission period between two frames if the remote device is not

responding,

the storage time of a frame originating from the remote device (useful for

loaded networks).

Note: in general, storage time is three times the retransmission period.

6 This window is used to configure the transmission and reception buffer size in

bytes.

XIP driver on TCP/IP

At a Glance

Subject of this

Part This part describes how to install the drivers associated with X-Way communication

on TCP/IP for Windows 98, Windows 2000\XP and Windows NT operating systems.

What’s in this

Part? This part contains the following chapters:

Note: The installation of this driver is the same on all operating systems installed.

Chapter Chapter Name Page

7 Installation 77

XIP driver on TCP/IP

Installation

At a Glance

Subject of this

Chapter This driver is used to communicate via an Ethernet card using the X-Way protocol

on TCP/IP.

This chapter describes driver installation, which consists of two steps:

installation of files on the station,

configuration of the driver.

What’s in this

Chapter? This chapter contains the following topics:

Topic Page

How to install the driver 78

Driver configuration screen 80

How to configure the driver 82

Installation

How to install the driver

At a Glance Driver installation is a standard installation. It can be launched either:

from the drivers’ CD-ROM,

or from disks if the station has no CD-ROM drive.

How to create a

set of disks Use the following procedure to create installation disks:

Note: The installation disks are created from the CD-ROM.

Step Action

1 Use a station which has a CD-ROM drive.

2 Insert the CD-ROM into the drive.

3 Access the directory of the driver to be copied onto disk.

4 Copy the contents of the DISK1 directory onto a disk. Repeat this step for each

DISK directory.

Note: it is advisable to number the disks.

Installation

How to install the

driver To install the driver, carry out the following procedure:

Start of installation

Installation by

CD-ROM?

Insert CD-ROM in CD-ROM drive

Insert the 1st disk in the drive

Appearance

of the file

INSTALL.HTM

Click on the link which corresponds

to the driver to be installed

Access the directory of the driver

to be installed corresponding to

the PC’s operating system

Access the directory DISK1

Double click on the file

SETUP.EXE

Yes

Choose Run this program from

its current location then confirm

by clicking on OK

Click on Next

Configure the driver then close the

configuration screen

End of installation

Restart the computer

Choose Yes in the security warning

screen

Installation

Driver configuration screen

At a Glance The configuration tool is used to link a driver configuration profile to a remote device

that communicates with the station.

Illustration The screen dedicated to the XIP driver looks like this:

Delete

Add

Update

Schneider Automation CNFXIP

New connection

Profile Local connection

Installed connections

Ready

Station:

X-Way address:

IP address:

1 - 1

X-Way address:

Configuration Xip Test Help

Delete all

Save

XIP01

station1-2 DNS

1 - 2

84 - 0 - 1 - 2

station1-2 001.002 084.000.001.002

station2-* 002. * 084.000.001.002

station1-3 001.003 084.000.001.003

station PLC 000.001 139.160.065.100

Installation

Description This table describes the different areas which make up the configuration screen:

Number Element

1 All software functions can be accessed using this menu bar:

Configuration : creation or deletion of a profile

Xip : start, stop or reinitialize the driver

Test : test request transmissions with options

Aide : information on the software

2 The profile used by the driver is selected from this list.

3 The X-Way address of the station is configured from this window.

4 The new connections with remote devices associated with the driver are set from

this window.

5 Existing connections with remote devices can be viewed via this list.

6 Connections can be added, removed or redefined with these buttons.

7 This status bar is an operating indicator (driver stopped or started) with a

comment zone.

Installation

How to configure the driver

At a Glance During driver installation, a default configuration profile is proposed. You are able to

modify this profile or create a new one.

How to create a

new profile From the driver configuration screen,

How to remove a

profile From the driver configuration screen,

Note: If all the network connections are in use or if there are none on the station,

a profile cannot be created.

Step Action

1 Select the menu Configuration → Create a profile.

Result

The following window appears:

2 From the TCP/IP drop-down menu, select the TCP/IP connection to the

network.

3 Click Ok .

Creation of a new XIP profile

XIP01 OK

Cancel

ADAPTER01(139.160.67.39)

XIP XIP/IP

Step Action

1 Select the menu Configuration → Create a profile.

2 From the drop-down menu, select the profile to be removed.

3 Confirm deletion with Ok .

Installation

Example The architecture below describes the addressing of stations on Ethernet and Fipway

networks:

Access to

stations To directly access all the stations on the Ethernet 1 network from station A, enter the

X-Way address {1.*} and the IP address 84.0.1.1.

In order for station A to be able to access station B, enter for connection the X-Way

address {1.2} and the IP address 84.0.1.2.

In order for station A to be able to access station B, enter the X-Way address {2.3}

and the IP address of the bridge 84.0.1.2.

How to add a

connection From the configuration screen,

Ethernet (1)

Fipway (2)

Adresse X-Way {1.1}

Adresse IP 84.0.1.1 Station A

Adresse X-Way {1.2}

Adresse IP 84.0.1.2

Adresse X-Way {2.2}

Adresse IP 84.0.1.2

Adresse X-Way {2.3}

Adresse IP 84.0.1.2

Station C

Station D

Station B

Step Action

1 In the New connection window, enter:

the name of the remote station or bridge,

the address of the remote station or bridge,

the IP address of the remote station or bridge,

2 Click Add.

3 Click Save.

Note: the configuration is saved for the current profile.

Installation

How to remove a

connection From the configuration screen,

How to modify a

connection From the configuration screen,

XIP Instances Once installed, configure the XIP driver and reboot the computer. All XIP profile

instances are initialized.

For each XIP profile configured a corresponding icon appears in the task bar.

Step Action

1 In the Connections installed window, select the name of the remote station

to be removed.

2 Click Delete.

3 Click Save.

Note: the configuration is saved for the current profile.

Step Action

1 In the Installed Connections window, select the name of the remote station

to be modified.

2 In the New connection window, modify:

the name of the remote station or bridge,

the address of the remote station or bridge,

the IP address of the remote station or bridge,

3 Click Update.

4 Click Save.

Note: the configuration is saved for the current profile.

Drivers for Atrium Processors

At a Glance

Subject of this

Part This part describes how to install the drivers associated with the TPCX 57 and

TSX PCI 57 processors for operating systems.

These drivers are:

the ISAWAY driver for the TPCX 57 processors,

the PCIWAY driver for the TSX PCI 57 processors.

What’s in this

Part? This part contains the following chapters:

Chapter Chapter Name Page

8 ISAWAY driver for TPCX 57 processors 87

9 PCIWAY driver for TSX PCI 57 ••• processors 111

Drivers for Atrium Processors

ISAWAY driver for TPCX 57

processors

At a Glance

Subject of this

Chapter This driver makes it possible to use the TPCX 57 processor on the ISA bus.

Driver installation consists of two steps:

installation of files on the station,

configuration of the operating system so that it is recognized.

What’s in this

Chapter? This chapter contains the following topics:

Topic Page

How to install the driver 88

Configuration of the ISAWAY driver for Windows NT 90

Configuration of ISAWAY driver for Windows 98\2000\XP 95

Configuration of the operating system 96

How to select the hardware type for Windows 98 97

How to select the hardware type for Windows 2000\XP 100

How to configure hardware parameters for Windows 98 103

How to configure hardware parameters for Windows 2000\XP 105

How to adjust the ISA TPCX 57 card parameters 108

ISAWAY driver

How to install the driver

At a Glance Driver installation is a standard installation. It can be launched either:

from the drivers’ CD-ROM,

or from disks if the station has no CD-ROM drive.

How to create a

set of disks Use the following procedure to create installation disks:

Preliminary

operations Before installing the new driver, you must check that there is no previous version of

Windows NT4 on the station.

If a driver does exist, you must delete it before carrying out the new installation.

A previous version can be uninstalled using:

Drivers Manager software,

or the Control Panel → Add/Remove Programs.

Note: The installation disks are created from the CD-ROM.

Step Action

1 Use a station which has a CD-ROM drive.

2 Insert the CD-ROM into the drive.

3 Access the directory of the driver to be copied onto disk.

4 Copy the contents of the DISK1 directory onto a disk. Repeat this step for each

DISK directory.

Note: it is advisable to number the disks.

ISAWAY driver

How to install the

driver To install the driver, carry out the following procedure:

Start of installation

Installation by

CD-ROM?

Insert CD-ROM in CD-ROM drive

Insert the 1st disk in the drive

Appearance

of the file

INSTALL.HTM

Click on the link which corresponds

to the driver to be installed

Access the directory of the driver

to be installed corresponding to

the PC’s operating system

Access the directory DISK1

Double click on the file

SETUP.EXE

Yes

Choose Run this program from

its current location then confirm

by clicking on OK

Click on Next

Configure the driver then close the

configuration screen

End of installation

Restart the computer

Choose Yes in the security warning

screen

ISAWAY driver

Configuration of the ISAWAY driver for Windows NT

Access to the

configuration

tool

The configuration tool can be accessed from the taskbar "Start->Programs->

Schneider Electric->Drivers Manager ".

Select the tab "PCX57 Driver" to display the following window:

This window shows information on the version and STATUS of the driver installed.

Management properties of SCHNEIDER drivers

DRIVERS Manager UNITELWAY Driver SCP114 Driver MODBUS SERIAL Driver

PCX57 Driver FPC10 Driver XIP Driver MODBUS Test XWAY Test

PCX

Setting Up

Driver PCX57 ISAWAY V1.4 IE05

Status driver 1: Non operational

Status driver 2: Non operational

ISAWAY driver

Driver

configuration Press the Configuration button to display the following window:

The table below describes the different commands in the tab "Devices" :

Button Action

Add... Allows a T PCX 57 processor card with default parameters (IRQ =10,

base address I/O=H’220’, timer=500ms, buffer size=256 bytes) to be

added to the PC.

The maximum number of cards is 2.

Remove Allows a selected T PCX 57 processor card to be deleted.

Properties Allows the properties of a processor card to be defined, see:

Properties, p. 93.

Apply Allows configuration parameters to be applied; the tool saves the

parameters, then reinitializes the driver.

Cancel Allows the user to exit without acknowledging the modified parameters.

OK Allows the user to exit while acknowledging the modified parameters.

Devices Driver

PCX57 Configuration

PCX

Add... Remove Properties

OK Cancel Apply

List of PCX57 card configured:

[1] PCX57 Card

ISAWAY driver

Click the tab "Driver" to display the following window:

This window displays general information on the driver

PCX57 Configuration

PCX

Devices Driver

Manufacturer: Schneider Automation

Version: V1.4 IE05

Current Files: DISAWAY

The driver is stopped

Driver Status

Driver Information

OK Cancel Apply

ISAWAY driver

Properties Press the Properties button to display the following window:

The table below describes the different areas:

Area Description

I/O Base This is the address of the PCX57 card in hexadecimal, which should

correspond to the address configured on the processor card

Timer(ms) Represents the watchdog refreshment period, which is updated by the

driver.

Default Displays the default configuration of the card (IRQ=10, I/O

Base=H’220’, Timer=500ms).

Cancel Cancels a modification, and returns to the previous screen.

OK Validates the configuration; the parameters displayed are stored and

the previous screen is displayed.

I/O Base

[2] PCX57 Configuration

Hardware Datagram

0x0220

Timer (ms) 500

IRQ Level

IRQ10

IRQ11

IRQ5

IRQ3

IRQ15

Default

OK Cancel

ISAWAY driver

Click the Datagram tab to display the following window:

The table below describes the different areas:

Area Description

Input/Output

buffer

Allows the size of the buffers for the interface between the PCX57 card

and the driver to be configured. The size may be set at between 160

and 256 bytes.

Default Allows default selection of the card (256 bytes)

Cancel Cancels a modification, and returns to the previous screen.

OK Validates the configuration; the parameters displayed are stored and

the previous screen is displayed.

[2] PCX57 Configuration

Hardware Datagram

Input/Output Buffers

Default

OK Cancel

256 BytesSize (bytes)

ISAWAY driver

Configuration of ISAWAY driver for Windows 98\2000\XP

At a Glance The management tool tab is as follows:

Elements The Properties button is used to access the driver configuration screen for card 1

and card 2 respectively.

The Hardware Wizard button is used to add or remove an ISA TSX FPC 10 card

using the Add/Remove Hardware Wizard.

The Device Manager button activates the System Properties window and is used

to view or modify the card hardware parameters.

Management properties of XWAY drivers

DRIVERS Manager

PCX57 Driver FPC10 Driver XWayTest

UNITELWAY Driver

PCX57 Driver V1.1 IE06

[1] PCX57 Properties

Hardware Wizard Use Hardware Wizard to add or

remove a PCX57 card.

Driver 1 state: Non operational

Driver 2 state: Non operational

Device Manager Use Device Manager to

modify the hardware configuration

of PCX57 cards.

PCX57 Driver

PCX57 Device Manager

FPW

[2] PCX57 Properties

FPP20 Driver

XIP Driver

Note: a maximum of two cards can be connected.

ISAWAY driver

Configuration of the operating system

At a Glance After the driver installation and configuration phase, the operating system shall

recognize the TPCX 57 card and its driver.

Installation

principles As this card is not automatically recognized by the operating system, the following

phases must be carried out:

Step Action

1 Select the hardware type:

for Windows 98 see How to select the hardware type for Windows 98, p. 97,

for Windows 2000 see How to select the hardware type for Windows

2000\XP, p. 100,

for Windows NT no operation is required.

2 Configure the parameters of the operating system to recognize the card:

for Windows 98 see How to configure hardware parameters for Windows

98, p. 103,

for Windows 2000 see How to configure hardware parameters for Windows

2000\XP, p. 105,

for Windows NT no operation is required.

3 Switch off the station.

4 Adjust the card parameters: See How to adjust the ISA TPCX 57 card

parameters, p. 108.

the standard I/O address,

the IRQ interrupt address.

5 Connect the card to the ISA bus.

6 Turn the station back on.

Result: the driver is operational.

ISAWAY driver

How to select the hardware type for Windows 98

Procedure After having installed and configured the driver, carry out the following procedure to

select the hardware type.

Step Action

1 In the initial window which is displayed, click on Next.

Result

The following window appears:

Add new hardware Assistant ?

Next> Cancel

Windows can now search for hardware that is

incompatible with Plug-and-Play, or you can select the

hardware from a list.

When Windows detects a new hardware, it automatically

determines the current parameters for the peripheral and

correctly installs the pilot. It is therefore strongly

recommended that you allow Windows to detect the new

hardware.

Do you wish for Windows to automatically detect any

new hardware?

Yes (recommended)

No, I wish to select the hardware from a list.

< Previous:

ISAWAY driver

2Answer No to the question Do you want Windows to search for your new

hardware?

Result

The following window appears:

3 Select PCX57 Device from the list then click on Next.

4 Select PCX57 WDM Device from the list then click on Next.

Result

The operating system suggests the hardware parameters that you must

configure on the card.

Step Action

Add new hardware Assistant

Next> Cancel

< Previous:

Select the hardware type you wish to install.

Types of hardware:

Modem

Mouse

Multifunction adapter cards

Network cards

Other peripherals

PCMCIA extension

PCX57 Device

Ports (COM & LPT)

Printer

SCSI Controllers

< Previous:

Add new hardware Assistant

Next> Cancel

Windows can install your hardware using the following parameters:

Warning: your hardware cannot be configured for use with the resources

listed. You may use the Peripherals Manager to adjust the parameters before

restarting your computer. Click successively on the Start, Parameters,

Control panel, System, and Peripherals Manager tabs. To modify the

hardware parameters, consult the hardware documentation supplied.

To continue installing the software needed by your hardware, click Next.

Type of resource Parameter

Input/output range 0190-019F

Interrupt Request (IRQ) 10

Print...

ISAWAY driver

5 Click on Next.

6Answer No to the question Do you want to restart your computer now?

Result

The following window appears and the card is shown in the station’s hardware

configuration.

7 Do you want to modify the parameters?

If yes, go to the procedure: how to modify hardware parameters (See How

to configure hardware parameters for Windows 98, p. 103),

If no, click on OK then restart the station with the card connected.

Step Action

CancelOK

Computer

System Properties ?

General Peripherals Manager Hardware Profiles

Display peripherals by type Display peripherals by connection

Performance

CD-ROM

Disk drives

Graphics cards

Disk controllers

Hard disk controllers

Keyboard

Screens

Mouse

Network cards

FPC10 Device

PCX57 WDM Device

Ports (COM & LPT)

Sound, video and game controllers

System peripherals

USB bus controllers

Properties: Refresh Delete Print...

ISAWAY driver

100

How to select the hardware type for Windows 2000\XP

Procedure After having installed and configured the driver, carry out the following procedure to

select the hardware type.

Step Action

1 In the initial window which is displayed, click on Next.

Result

The following window appears:

Add/Delete new hardware Assistant

CancelNext>< Previous

Uninstall/Disconnect a peripheral

Choose this option to uninstall a peripheral or to prepare your computer for the

disconnection of a peripheral.

Add/Troubleshoot a peripheral

Choose this option to add a new peripheral to your computer or if you have difficulty

operating an existing peripheral.

Select the task you wish to perform for your hardware, then click on next.

What task do you wish to perform on the hardware?

Select a task for the hardware

ISAWAY driver

101

2 Select the option Add/Troubleshoot a peripheral then click Next.

Result

The following window appears:

3 Select the option Add a new peripheral. Then click on Next.

4Answer No to the question Do you want Windows to search for your new

hardware?

Step Action

Add/Delete new hardware Assistant

CancelNext>< Previous

The following hardware is already installed on your computer. If you encounter

difficulty with one of these peripherals, select the peripheral and click Next.

What hardware peripheral do you wish to troubleshoot?

Selecting a hardware peripheral

If you try to add a peripheral and it doesn’t appear below,

select Add a new peripheral, then click Next.

Peripherals

Add a new peripheral

COMPAQ 171 FS

Disk drive

COMPAQ CRD-8320B

WDC AC36400L

ES1869 Control Interface (WDM)

ES1869 Plug and Play Audio Drive (WDM)

ISAWAY driver

102

5 Click on Next.

Result

The following window appears:

6 Select PCX57 Device from the list then click on Next.

7 Select PCX57 WDM Device from the list then click on Next.

8 Go to the next procedure: how to configure hardware parameters (See How to

configure hardware parameters for Windows 2000\XP, p. 105).

Step Action

Add/Delete new hardware Assistant

CancelNext >

< Previous

Select the hardware type you wish to install.

Which hardware type do you wish to install?

Hardware type

Hardware types:

PCX57 Device

Port (COM & LPT)

Printers

SCSI and RAID controllers

Sound, video and game controllers

Systems peripherals

Tape drives

FPC10 Device

ISAWAY driver

103

How to configure hardware parameters for Windows 98

Procedure When you want to modify the hardware parameters, carry out the following

procedure.

Step Action

1 Click on Properties.

Result

The following window appears:

2 Uncheck the box Use automatic settings.

3 Select Input/Output Range from the list.

PCX57 WDM Device Properties

OK Cancel

PCX57 WDM Device

Resource type Setting

General Driver Resources

Use automatic settings

Input/Output Range 01A0-001AF

Interrupt Request 10

Change Setting...

No conflicts.

Conflicting device list:

Basic configuration 0

Settings based on:

ISAWAY driver

104

4 Click on Change Settings.

Result

The following window appears:

5 From the Value list, select the non-conflicting address range.

Note: note the values because they must be coded onto the ISA card.

6 Confirm using the Ok button.

7 Carry out steps 5 to 8 selecting Interrupt Request from the list.

8 Confirm with OK then restart the station with the card connected.

Step Action

To modify Input/Output Range

Enter the Input/Output range that you wish to configure for

this device.

You can either enter a specific range and the closest valid

range will be automatically selected, or select a range using

the arrow keys.

No devices are conflicting.

Value:

The setting you have chosen does not conflict with

any other devices.

01A0-001AF

OK Cancel

Conflict information

ISAWAY driver

105

How to configure hardware parameters for Windows 2000\XP

Procedure After having selected the hardware type, carry out the following procedure to

configure the parameters.

Step Action

1 Click on the Resources button.

2 Click on Manual Configuration.

Result

The following window appears:

3 Uncheck the box Use automatic settings.

4 Select Input/Output Range from the list.

Add new hardware Assistant Properties

Standard configuration 0000

FPCX57 WDM Device

Cancel

Modify the parameters...

Parameters based on:

List of peripherals in conflict:

No conflict.

Resource parameters:

Resources

Type of Resource Parameter

Use the automatic parameters

Input/output range ?

Interrupt Request (IRQ) ?

ISAWAY driver

106

5 Click on Change settings.

Result

The following window appears:

6 From the Value list, select the non-conflicting address range.

Note: note the values because they must be coded onto the ISA card.

7 Confirm with OK.

Result: a confirmation window appears.

8 Confirm with Yes.

9 Carry out steps 4 to 8 selecting Interrupt Request from the list.

Step Action

Modify input/output range

Enter the input/output range you wish to define for this

peripheral.

You can either enter a specific range and the closest valid range

will be automatically selected, or select a range using the upper or

lower indicator arrows.

This resource is assigned to the following child peripherals:

Value:

The parameter you have chosen is not in conflict with other

peripherals.

OK Cancel

0250-025F

Information concerning conflicts

No peripherals in conflict

ISAWAY driver

107

10 Accept the configuration with OK.

Result

The following window appears:

11 Click on Finish to confirm hardware configuration.

Step Action

Add / Remove Hardware Wizard

Cancel Finish<Back

End of Add/Delete hardware Assistant

The following hardware has been installed:

FPCX57 WDM Device

Check the documentation of your hardware to know whether

you should configure the new hardware manually. To

operate the hardware you must restart the computer.

Resources

To display or modify the resources for this

peripheral, click Resources.

To close the Assistant, click on Finish.

ISAWAY driver

108

How to adjust the ISA TPCX 57 card parameters

At a Glance Before installing the TPCX 57 card, you must adjust the following parameters:

the rack number and the processor position,

the standard I/O address,

the IRQ interrupt address.

Illustration This card comprises the following elements:

Numbers and

elements The following table describes the different parameters to be adjusted:

Number Element

1 The processor’s rack position can be coded with the micro-switches.

2 The address of the rack which contains the processor can be coded with the

micro-switches.

3 The standard address of the processor can be coded on the ISA bus with the

micro-switches.

4 The IRQ (Interrupt Request) level can be coded with the micro-switches.

ISAWAY driver

109

Procedure To adjust the parameters, proceed in the following manner:

Example of

standard

address

selection

The standard address provided by the system is equal to 250 in hexadecimal:

Example of IRQ

selection The interrupt address provided by the system is 10:

Step Action

1 Code the number of the rack which contains the processor.

2 Code the processor position.

3 Code the standard I/O address provided by the operating system with the

micro-switches.

4 Code the interrupt level provided by the operating system with the micro-

switches.

45678

Note: The jumper must not be set in the IRQ position.

IRQ

ISAWAY driver

110

111

PCIWAY driver for TSX PCI 57 •••

processors

At a Glance

Subject of this

Chapter This driver makes it possible to use TSX PCI 57 ••• processors on the PCI bus

Driver installation consists of two steps:

installation of files on the station,

configuration of the operating system so that it is recognized.

What’s in this

Chapter? This chapter contains the following topics:

Topic Page

How to install the driver 112

Configuring the PCIWAY driver for windows 2000\XP 114

How to adjust the parameters of the TSX PCI 57 ••• card 116

PCIWAY driver

112

How to install the driver

At a Glance Driver installation is a standard installation. It can be launched either:

from the drivers’ CD-ROM,

or from disks if the station has no CD-ROM drive.

How to create a

set of disks Use the following procedure to create installation disks:

Preliminary

operations You must have administrator access rights for the machine in order to install the

driver.

Note: The installation disks are created from the CD-ROM.

Step Action

1 Use a station which has a CD-ROM drive.

2 Insert the CD-ROM into the drive.

3 Access the directory of the driver to be copied onto disk.

4 Copy the contents of the DISK1 directory onto a disk. Repeat this step for each

DISK directory.

Note: it is advisable to number the disks.

PCIWAY driver

113

How to install the

driver To install the driver, carry out the following procedure:

Start of installation

Installation by

CD-ROM?

Insert CD-ROM in CD-ROM drive

Insert the 1st disk in the drive

Appearance

of the file

INSTALL.HTM

Click on the link which corresponds

to the driver to be installed

Access the directory of the driver

to be installed corresponding to

the PC’s operating system

Access the directory DISK1

Double click on the file

SETUP.EXE

Yes

Choose Run this program from

its current location then confirm

by clicking on OK

Click on Next

Configure the driver then close the

configuration screen

End of installation

Restart the computer

Choose Yes in the security warning

screen

PCIWAY driver

114

Configuring the PCIWAY driver for windows 2000\XP

Access to the

configuration

tool

The configuration tool can be accessed from the taskbar "Start->Programs->

Schneider Electric->Drivers Manager ".

Select the PCI 57 Driver tab to display the following window:

This window shows information on the version and STATUS of the driver installed.

Properties Management of SCHNEIDER drivers

DRIVERS Manager

PCX57 Driver FPC10 Driver XIP Driver MODBUS Test XWAY Test

PLC USB Driver UNITELWAY Driver PCI 57 Driver

[1] PCI Properties

[2] PCI Properties

Status driver 1: Running

Status driver 2: Non operational

Driver PCI 57 V1.0 IE 01

PCI

PCIWAY driver

115

Properties Press the PCI Properties button to display the following window:

The table below describes the different areas:

Area Description

Input/Output Buffer

Sizes

Allows the size of the buffers for the interface between the TSX

PCI 57 card and the driver to be configured. The size may be set

at between 160 and 256 bytes.

Watchdog period Represents the refresh period of the watchdog.

Cancel Cancels a modification, and returns to the previous screen.

OK Validates the configuration; the parameters displayed are stored

and the previous screen is displayed.

[1] PCI 57

Watchdog period: 500

256

Input/Output Buffer Sizes: Bytes

OK Cancel

PCIWAY driver

116

How to adjust the parameters of the TSX PCI 57 ••• card

At a Glance Before installing the TSX PCI 57 ••• card, you must:

install the PCI 57 driver,

code the rack number on the X Bus,

code the position of the processor in the rack.

Illustration This card comprises the following elements:

Numbers and

elements The following table describes the different parameters to be adjusted:

Number Element

1 The address of the rack on the X Bus can be coded with the micro-switches.

2 The processor’s rack position can be coded with the micro-switches.

PCIWAY driver

117

Procedure To adjust the parameters, proceed in the following manner:

Step Action

1 Code the number of the rack on the X-BUS.

2 Code the position of the processor in the rack.

PCIWAY driver

118

119

VII

Modbus driver

At a Glance

Subject of this

Part This part describes how to install the Modbus driver for the Windows 98,

Windows 2000\XP and Windows NT operating systems.

What’s in this

Part? This part contains the following chapters:

Chapter Chapter Name Page

10 Installation 121

Modbus driver

120

121

Installation

At a Glance

Subject of this

Chapter This chapter describes Modbus driver installation. This installation procedure can be

broken down into two steps:

installation of files on the station,

configuration of the driver.

What’s in this

Chapter? This chapter contains the following topics:

Topic Page

How to install the driver 122

Driver configuration screen 124

Driver control screen 126

Driver debug screen 128

Information screen 130

Installation

122

How to install the driver

At a Glance Driver installation is a standard installation. It can be launched either:

from the drivers’ CD-ROM,

or from disks if the station has no CD-ROM drive.

How to create a

set of disks Use the following procedure to create installation disks:

Note: The installation disks are created from the CD-ROM.

Step Action

1 Use a station which has a CD-ROM drive.

2 Insert the CD-ROM into the drive.

3 Access the directory of the driver to be copied onto disk.

4 Copy the contents of the DISK1 directory onto a disk. Repeat this step for each

DISK directory.

Note: it is advisable to number the disks.

Installation

123

How to install the

driver To install the driver, carry out the following procedure:

Start of installation

Installation by

CD-ROM?

Insert CD-ROM in CD-ROM drive

Insert the 1st disk in the drive

Appearance

of the file

INSTALL.HTM

Click on the link which corresponds

to the driver to be installed

Access the directory of the driver

to be installed corresponding to

the PC’s operating system

Access the directory DISK1

Double click on the file

SETUP.EXE

Yes

Choose Run this program from

its current location then confirm

by clicking on OK

Click on Next

Configure the driver then close the

configuration screen

End of installation

Restart the computer

Choose Yes in the security warning

screen

Installation

124

Driver configuration screen

At a Glance The configuration tool is not outside the driver, but constitutes an embedded graphic

interface in the driver.

This graphic interface is accessible from the Windows workstation

"Start ->Programs -> "Schneider Electric ->Drivers Manager->Modbus Serial

Driver".

Illustration The configuration screen dedicated to the Modbus driver looks like this:

DefaultUndoApply

Hide

3000

ASCII (7 bits)

RTU (8 bits)

2 Bits

1 Bit

Stop Bits

Mode (Data Bits)

Parity

Global TimeOut

Inter-Chart TimeOut

Automatic

Even Odd None

COM Port

Baud Rate

COM 1

9600

Configuration Runtime Debug About

Modbus Driver - Modbus01

Serial Port

FPW

Installation

125

Description This table describes the different areas which make up the configuration screen:

Modbus

Instances Once installed, configure the Modbus driver and reboot the computer. All Modbus

instances are initialized.

For each Modbus instance configured a corresponding icon appears in the task bar.

Area Element

Serial Port COM Port : provides a choice for the communication port to be used,

by default COM1.

Baud rate: provides a choice for transmission speed between 300

and 19200 bits/second, by default 9600b/s.

Stop bits Allows entry of the number of stop bits used for communication, by

default 1 stop bit.

Parity Is used to set whether a parity bit is added or not, as well as its type,

such as:

Even , for even parity (default selection),

Odd , for odd parity,

None , for no parity bit

Global TimeOut Allows Reception Time-Out to be defined (in milliseconds) while the

driver is waiting for the response from the polled Modbus slave.

Inter-Char TimeOut Allows quiet time to be defined (in milliseconds), permitting detection

of a Modbus end delimiter.

If the Automatic box is checked, the value is automatically

calculated according to speed (Baud Rate).

Mode (Data Bits) RTU : the characters are coded on 8 bits in binary.

This mode is the default mode.

ASCII: the characters are coded on 7 bits in ASCII.

Apply button Allows the configuration to be saved; the file ModbusConf.ini is

created.

Undo button Allows the latest modifications not to be acknowledged.

Default button Allows parameters to be set for the different fields with default values.

Hide button Allows configuration parameters to be acknowledged, and

represents the window by an icon.

Installation

126

Driver control screen

At a Glance This screen is used to view information concerning driver operation.

The refreshment period for this information is defined in a driver screen. See Driver

debug screen, p. 128.

Illustration The control screen dedicated to the Modbus driver looks like this:

Configuration Runtime Debug About

Communication

Connections

Frames Sent

Bytes Sent

Frames Received

Bytes Received

Number of Timeout

Checksum Errors

Mode RTU

Hide

Reset

Modbus Driver - Modbus01

Installation

127

Description This table describes the different information concerning driver operation:

Element Description

Mode Displays the driver operating mode:

RTU Mode,

Mode ASCII.

Connections Contains the number of clients using the driver

Frames Sent Contains the number of frames sent since the last Reset.

Bytes Sent Contains the number of bytes sent since the last Reset.

Frames Received Contains the number of frames received since the last Reset.

Bytes Received Contains the number of bytes received since the last Reset.

Number of TimeOut Contains the number of Time-Outs reached; the value is defined in the

"Global Delay" configuration screen.

Checksum Errors Contains the number of checksum errors detected.

Reset This button is used to reset the different counters in the control screen

to 0.

Hide This button allows the window to be represented as an icon.

Installation

128

Driver debug screen

At a Glance This screen is used to deactivate the saving of certain operations carried out by the

communication driver in a trace file.

Illustration The debug screen dedicated to the Modbus driver looks like this:

Configuration Runtime Debug About

0 s (fastest

Full

Hide

Browse

Modbus Driver - Modbus01

Thread Priority

Log File

Refresh Period (slowest) 1 s

D:\SNAPSHOTVIEWS\FPUI0...

Start Log

Empty

Low High

Installation

129

Description This table describes the different areas which make up the debug screen:

Area Description

Refresh Period Allows the screen refreshing period for the driver control screen to be

defined within a range of 0s to 1s.

Log File This area contains:

the description of the path where the trace file has been saved,

a bar graph showing the fill level of the trace file.

a button to start or stop saving in the trace file.

Thread Priority Adjusts the priority of the driver with regard to other tasks executed in

Windows.

The default setting is "Low" .

Hide This button allows the window to be represented as an icon.

Installation

130

Information screen

At a Glance This screen provides general information on the communication driver and on the

operating system installed.

Illustration The screen dedicated to the Modbus driver looks like this:

Description This table describes the different areas which make up the information screen:

Configuration Runtime Debug About

Hide

Modbus Driver - Modbus01

WINDOWS NT V5.0 (Build 2195)

Extended Info : Service Pack 2

WINDOWS Sockets V1.1 (V2.2 detected)

Modbus Driver Info

System Info

WIN 32 Modbus Serial Driver

Release Version 1.0 (IE02 - Build 6)

Modbus

Area Element

Modbus Driver Info This area contains:

the driver version,

the Schneider Electric Copyright.

System Info This area contains:

the Windows operating system version,

additional information,

the Winsock interface version.

Hide This button allows the window to be represented as an icon.

131

VIII

USB driver

At a Glance

Subject of this

Part This part describes how to install the USB driver for the Windows 2000\XP operating

systems.

What’s in this

Part? This part contains the following chapters:

Chapter Chapter Name Page

11 Installation 133

USB driver

132

133

Installation

At a Glance

Subject of this

Chapter This chapter describes USB driver installation. This installation procedure can be

broken down into two steps:

installation of files on the station,

configuration of the driver.

What’s in this

Chapter? This chapter contains the following topics:

Topic Page

How to install the driver 134

Configuration screens for Win 2000\XP 137

State of the USB link 139

Installation

134

How to install the driver

At a Glance Driver installation is a standard installation. It can be launched either:

from the drivers’ CD-ROM,

or from disks if the station has no CD-ROM drive.

How to create a

set of disks Use the following procedure to create installation disks:

Note: The installation disks are created from the CD-ROM.

Step Action

1 Use a station which has a CD-ROM drive.

2 Insert the CD-ROM into the drive.

3 Access the directory of the driver to be copied onto disk.

4 Copy the contents of the DISK1 directory onto a disk. Repeat this step for each

DISK directory.

Note: it is advisable to number the disks.

Installation

135

Checks When using Windows 2000\XP, you must check whether it is possible to install

unsigned drivers on the station.

To do this, perform the following actions:

Step Action

1 Right-click on My Computer and select "Properties".

2 In the "System Properties" window, select the "Hardware" tab.

3 Press "Driver Signing Options...".

The following window is displayed:

4 Select "Warn - Display...", then confirm by clicking OK.

Cancel OK

Verification of file signatures

To ensure their authenticity, all files of the Windows 2000 CD-ROM are

protected by a digital signature and automatically checked during the installation

process.

When you install a new software, the following verification parameters

will be used

Ignore: installs all files, regardless of their signatures

Warn: displays a warning message before installing an unsigned file

Forbid: prevents the installation of unsigned files

Define parameters as default parameters

Pilot signature option ?

Administrator option

Installation

136

How to install the

driver Before starting the installation, check that the USB cable is not connected to the

PLC.

To install the driver, carry out the following procedure:

Start of installation

Installation by

CD-ROM?

Insert CD-ROM in CD-ROM drive

Insert the 1st disk in the drive

Appearance

of the file

INSTALL.HTM

Click on the link which corresponds

to the driver to be installed

Access the directory of the driver

to be installed corresponding to

the PC’s operating system

Access the directory DISK1

Double click on the file

SETUP.EXE

Yes

Choose Run this program from

its current location then confirm

by clicking on OK

Click on Next

Configure the driver then close the

configuration screen

End of installation

Restart the computer

Choose Yes in the security warning

screen

Installation

137

Configuration screens for Win 2000\XP

At a Glance After rebooting the PC you will have to configure the USB driver, the USB cable

must be connected to the PLC, and then Windows will detect the PLC and install the

driver.

Perform the following actions:

Step Action

1 The following screen will be displayed:

2 Click on YES

USB Device

New Hardware Found

Digital Signature Not Found

Yes More Info

The Microsoft digital signature affirms that software has been

tested with Windows and that the software has not been altered

since it was tested.

The software you are about to install does not contain a

Microsoft digital signature. Therefore, there is no guarantee that

this software works correctly with Windows.

PLC USB Device

If you want to search for Microsoft digitally signed software, visit

the Windows Update Web site at http://

windowsupdate.microsoft.com to to see if one is available.

Do you want to continue the installation?

Installation

138

3 An icon is displayed in the task bar. Double clicking on it when the USB link with

the PLC is operational calls up the window.

Clicking on " Driver Manager " launches the tool.

Clicking on "OK" makes an icon appear in the task bar.

Step Action

Driver Manager

General

Period : 00.00.01

Status : On-line

PLC USB Driver

Activity

Installation

139

State of the USB link

At a Glance This window informs the user of the state of the driver:

Description:

Field Description

Virtual Port Name of the COM port used by the driver.

Line status Contains "In service" data if the driver is operating, otherwise it

contains "Non operational" data.

Remote IP\Local IP IP addresses used by the PC and PLC to communicate.

Log File Button allowing access to a *.log file containing connection/

disconnection events on the USB line.

Management Properties of SCHNEIDER drivers

PCX57 Driver FPC10 Driver FPP20 Driver MODBUS Test XWayTest

SCP114 DriverUNITELWAY DriverPLC USB DriverDRIVERS Manager

USB

Driver PLC USB V1.0 IE07

Log File

Virtual Port : COM8

Status : Operating

Remote IP : 90.0.0.1

Local IP : 90.0.01

Installation

140

141

Drivers manager

At a Glance

Subject of this

Part This part describes the Drivers manager tool that is used to configure the different

drivers installed on Windows 98, Windows 2000\XP and Windows NT.

What’s in this

Part? This part contains the following chapters:

Chapter Chapter Name Page

12 Functions 143

Drivers manager

142

143

Functions

Management of X-Way drivers

At a Glance The X-WAY drivers can be accessed using the Drivers Manager management tool.

This is used to install, update, configure and test the different drivers in a centralized

manner.

Accessing the

Drivers

Management tool

From the Start menu, go to "Start->Programs->Schneider Electric->Drivers

Manager".

The following window is displayed:

Drivers Manager

tab This tab (window above) is used to:

view the list of installed drivers,

install or update a driver,

delete a driver.

Management properties of SCHNEIDER drivers

MODBUS SERIAL Driver

PCX57 Driver UNITELWAY Driver

FPC10 Driver FPP20 Driver MODBUS Test XWay Test

Uni-Telway

Install/update

Uninstall this Driver

Drivers System info

Windows NY V4.0 (Build 1381)

Further information: Service Pack 5

Winsock:

DLLx X-Way: V6. 0. 20. 2:

There are 6 drivers installed

Driver Manager V2.0 IE 10

XIP Driver

CONFI

GURAT

DRIVERS Manager

Functions

144

X-Way Test tab This tab is used to test the basic operation of an X-Way driver:

The table below describes the different zones of the window:

Driver Group

Field Description

Name Name of driver to be used for the test (Uni-Telway, FPC10, etc).

Driver number Instance number of driver to be used for the test (usually 1).

Remote Address X-Way remote station address in the format "network.station.gate". The

address "0.254.0" is the default address (terminal port for example).

For a network connection, (such as Fipway), the user must complete

this field: "3.5.0" to address station 5 of network 3. Gate 0 corresponds

to the system server gate of the station in question.

Local Address Internal address used locally by the driver. The driver completes this

field automatically for information purposes when the connection

becomes effective.

Request Group

Field Description

Request Name of driver to be used for the test (Uni-Telway, FPC10).

Type Type of request. Different sizes of mirror requests are suggested, as

well as reading the PLC %S6 system bit.

Delay Wait timeout in ms for the response to the transmitted request (time

out).

Status Status of connection, " disconnected ", " connecting... " or

" connected ".

Management properties of SCHNEIDER drivers

MODBUS SERIAL Driver

PCX57 Driver UNITELWAY Driver

FPC10 Driver FPP20 Driver MODBUS Test XWayTest

MIRROR (3 bytes)

Request

Request:

XIP Driver

DRIVERS Manager

Uni-Telway

Driver

Name:

3000

Status: disconnected

Type:

Delay (ms)

Driver number:

0.254.0

Remote address:

Local Address:

Connect Launch Further information... Concerning

Functions

145

Modbus Test tab This tab is used to test the basic operation of a Modbus driver:

The table below describes the different zones of the window:

Command buttons

Object Description

Connect Opens an internal communication channel on the selected driver.

Launch Launch request transmission to the station defined in the Remote

address field of the Driver group.

Further

information...

Displays system information about the driver. This button is active in

online mode only.

Concerning Displays X-Way Manager version and copyright details.

Link Parameters Group

Field Description

Protocol Name of protocol used (USB, TCP, Serial Modbus, Modbus Plus).

Remote IP

address

If TCP is being used, then the IP address or machine name is shown

here

Slave No. If Serial Modbus protocol is being used, then the slave no. is shown

here.

Management properties of SCHNEIDER drivers

SCP114 Driver MODBUS SERIAL Driver PCX57 Driver

UNITELWAY DriverPLC USB DriverDRIVERS Manager

FPC10 Driver FPP20 Driver MODBUS Test XWayTest

RequestsLink Parameters

Connect Launch Concerning

USB

Protocol:

90.0.0.1

Remote IP address:

Slave no.:

Master Path : DM 0 0 00

Request:

Status: Disconnected

Functions

146

Other tabs The windows corresponding to these tabs are described in the description of the

configuration for each driver:

for the Uni-Telway driver tab:

if using a serial port see Driver configuration screens, p. 20,

if using a TSXSCP114 card see Driver configuration screens, p. 30,

for the FPC10 driver tab see Driver configuration screen for Windows NT, p. 48,

for the FPP20 driver tab see How to install the driver, p. 40,

for the XIP Driver see Driver configuration screen, p. 80,

for the PCX 57 Driver tab:

when using Windows NT see Configuration of the ISAWAY driver for Windows

NT, p. 90,

when using Windows 98\2000\XP see Configuration of ISAWAY driver for

Windows 98\2000\XP, p. 95,

for the PCI 57 driver tab see Configuring the PCIWAY driver for windows

2000\XP, p. 114,

for the USB Driver tab see State of the USB link, p. 139.

Master Path : DM If Modbus Plus protocol is being used, then the station address is

shown here.

Request Group

Field Description

Request

Status Status of connection, "disconnected", " connecting... " or "connected".

Command buttons

Object Description

Connect Opens an internal communication channel on the selected driver.

Launch Launch request transmission to the station defined in the Remote IP

address field of the Link Parameters group.

Concerning Displays X-Way Manager version and copyright details.

Link Parameters Group

Field Description

147

Appendices

At a Glance

Subject of this

Part This part describes the installation and configuration of drivers for the cable

TSX PCX 3030 with windows 2000\XP. This cable is a USB/RS-485 Serial link

converter.

What’s in this

Appendix? The appendix contains the following chapters:

Chapter Chapter Name Page

A The drivers of the TSX PCX 3030 cable 149

Appendices

148

149

The drivers of the TSX PCX 3030

cable

At a Glance

Subject of this

Chapter This Chapter describes the installation and configuration of drivers for the cable

TSX PCX 3030 with windows 2000\XP.

What’s in this

Chapter? This chapter contains the following topics:

Topic Page

Installing the drivers of the TSX PCX 3030 cable 150

Configuration screens for drivers using the TSX PCX 3030 cable. 154

TSXPCX3030

150

Installing the drivers of the TSX PCX 3030 cable

At a Glance The TSX PCX 3030 cable is a USB/RS485 link converter. It enables a device to be

connected to a PLC via the USB port using its terminal port.

The cable is "plug ’n’ play". When you connect the cable via the USB port,

Windows 2000 or XP finds a new device and tries to install the corresponding driver.

It is necessary to install two drivers:

the USB bus driver,

and the virtual serial port driver.

TSXPCX3030

151

Installation The following table describes the procedure to install both drivers required to use the

TSX PCX 3030 cable.

Step Action

1 Connect the cable to the USB port of your device.

Result: Windows detects the new hardware and displays the assistant for installing the hardware

driver.

2 Click on Next.

Result: The following window is displayed:

What task do you wish the Assistant to carry out?

Find a pilot adapted to my peripheral (recommended)

Display a list of known pilots for this peripheral, in order to choose a specific

pilot.

Next >< Previous Cancel

A peripheral pilot is a software program that enables the operation of a hardware

peripheral. Windows requires pilot files for your new peripheral. Click on Next to find

the pilot files and finish.

A peripheral pilot is a program that enables a hardware peripheral to be used by

an operating system.

The assistant will complete the installation of this peripheral:

USB Device

Installation of peripheral pilots:

Hardware Assistant detected

TSXPCX3030

152

3 Choose the Automatic driver search option and click on Next.

Result: The following window is displayed:

4 Before selecting the CDROM drive option, insert the CDROM Drivers in the CDROM drive.

if you have copied the content of the CD-ROM in a specific location, select the Specific location

option and indicate the location of the driver.

5 Click on Next.

Result: the bus driver has been found.

6 Click on Next.

Result: a window indicates that the installation has been successfully completed.

7 Click on Finish.

Result: a new window appears for installing the serial port driver.

8 Click on Next.

Result: the New hardware search assistant window appears.

9 Choose the Automatic driver search option and click on Next.

10 Before selecting the CDROM drive option, insert the CDROM Drivers in the CDROM drive.

if you have copied the content of the CD-ROM in a specific location, select the Specific location

option and indicate the location of the driver.

11 Click on Next.

Result: the bus driver has been found.

Step Action

Optional search locations:

The Assistant is searching for adapted pilots in the pilot database on your computer, as

well as in the location indicated by you above should you wish

Where do you want Windows to search for the pilot files?

Search for pilot files for the following hardware peripheral:

Serial < - > USB

Searching for pilot files

Hardware Assistant detected

To start the search, click on Next. If you carry out the search on a disk or CD-ROM drive,

insert the disk or CD-ROM before clicking on Next.

Disk drive

CD-ROM drive

Specific location

Microsoft Windows Update

Next >< Previous Cancel

TSXPCX3030

153

12 Click on Next.

Result: a window indicates that the installation has been successfully completed.

13 Click on Finish.

Result: installation of the drivers is completed.

Step Action

TSXPCX3030

154

Configuration screens for drivers using the TSX PCX 3030 cable.

At a Glance Once the drivers of the TSX PCX 3030 cable are installed, you must select the cable

with the drivers that can use it. The compatible drivers are:

Uni-Telway driver, version ≥ V1.5,

Modbus driver, version ≥ V1.1.

Uni-Telway

driver The following table describes the procedure for declaring the cable with a

Uni-Telway driver.

Step Action

1 From the Drivers Manager, select the Uni-Telway Driver tab.

2 Click on the Configuration button.

3 Click on the Edit button.

Result: the Station parameters window appears

4 Select from the Com Port zone, the communication port associated with the

cable. For example COM3 (TSXPCX3030 Cable).

Link Parameters

Station ID

COM Port

Uni-telway Slave address

Communication Modem

NumberBase

Hayes

Tel No.

Password

Advanced

Uni-Telway

Modem Used

Cancel

Parameters of the Station

[Default]

COM 3 (TSXPCX3030 Cable)

TSXPCX3030

155

Modbus Driver The following table describes the procedure for declaring the cable with a Modbus

driver.

Step Action

1 From the Drivers Manager, select the Modbus Serial Driver tab.

2 Click on the Configuration button.

Result: the Modbus Driver window appears

3 Select from the Serial Port zone, the communication port associated with the

cable. For example COM3 (TSXPCX3030 Cable).

Default Undo Apply

Hide

3000

ASCII (7 bits)

RTU (8 bits)

2 bits

1 bit

Stop Bits

Mode (Data Bits)

Parity

Global TimeOut

Inter-Chart TimeOut

Automatic

Even Odd None

COM Port

Baud Rate

COM 3 (TSXPCX3030 Cable)

9600

Setting Up Runtime Debug About

Modbus Driver - Modbus01

Serial Port

FPW

TSXPCX3030

156

157

Drivers Management

Management of X-Way drivers, 143

Ethway

Configuration, 73

Installation for Win 2000XP, 68

Installation for Win NT, 71

FIP with TSXFPC10 card

Adjustment of card parameters, 63

Configuration of hardware for Win

2000XP, 60

Configuration of hardware for Win 98, 58

Configuration screen, 48

Installation, 46

Selection of hardware for Win 2000XP,

Selection of hardware for Win 98, 52

FIP with TSXFPP20 card

Configuration of Win 2000XP, 42

Configuration of Win 98, 41

Configuration of Win NT, 43

Installation, 38, 40

FIP withTSXFPC10 card

Win 98/2000/NT configuration, 51

General

Drivers, 11

ISAWAY

Adjustment of ISA card parameters, 108

Configuration, 90

Configuration for Win 2000XP, 105

Configuration for Win 98, 103

Installation, 88

Selection of hardware for Win 2000XP,

100

Selection of hardware for Win 98, 97

Win 98/2000/NT configuration, 96

Modbus

Configuration screen, 124

Control screen, 126

Debug screen, 128

Information screen, 130

Installation, 122

PCIWAY

Adjustment of PCI card parameters, 116

Configuration, 114

Installation, 112

Index

158

TSX PCX 3030

Configuration screens, 154

Installation, 150

Uni-Telway on Serial port

Configuration screens, 20

How to configure the driver, 24

Installation, 18

Uni-Telway on TSXSCP114

Configuration of Win 2000XP, 33

Configuration of Win NT, 34

Configuration screens, 30

Installation, 28

Win 98 configuration, 32

USB

Configuration for Win 2000XP, 137

Installation, 134

State of the link, 139

XIPConfiguration, 82

Configuration screen, 80

Installation, 78

Schneider Electric Communication Drivers Users Manual

Communication Drivers to the manual 617afae3-d13e-4fb9-9718-ebab3f36c1ea

Navigation menu

Versions of this User Manual:

Views

Navigation
