Schrader Electronics KAW4 Kawasaki MB 315 MHz User Manual Kawasaki MB 315 Mhz
Schrader Electronics Kawasaki MB 315 MHz Kawasaki MB 315 Mhz
User Manual
TPS (Tire Pressure Sensor)
USER MANUAL
Equipment Name:-TYRE PRESSURE SENSOR (WIRELESS)
Model No:-KAWASAKI MB 315 Mhz
Schrader Sensor Overview.
The Schrader Electronics TPM (Tire Pressure Monitoring) Sensor is
designed to be used in a direct measurement TPM System. The TPM
Sensor is intended to interface to a receiver/decoder that has been
designed to accept the TPM sensor protocol.
The TPM Sensor is designed to monitor a vehicle's tyre pressure whilst
driving or stationary. An electronic unit inside each tyre (referred to as
the TPM Sensor or TPM transmitter) mounted to the valve stem,
periodically measures actual tyre pressure/temperature.
This pressure information is transmitted to a receiver/decoder by
means of an RF link. The incoming radio frequency signals are
decoded, and the data used to inform the driver of the tyre pressure
information via the vehicles TPM interface.
TPM Sensor main functions are:
• Regularly measure the tyre pressure.
• Monitor if the wheel is moving.
• Periodically transmit tyre pressure using an RF link and a specific
protocol.
• Notify the system if there are abnormal pressure variations (leak) in
the tyre.
• Monitor the transponder input for valid LF field
USER MANUAL LABELLING REQUIREMENTS
FCC ID:MRXKAW4 IC:2546A-KAW4
This device complies with Part 15 of the FCC Rules and with Licence exempt RSS
standards of Industry Canada.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may
cause
undesired operation.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:
(1) l'appareil ne doit pas produire de brouillage, et
(2) l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement.
WARNING: Changes or modifications not expressively approved by the party
responsible for
compliance could void the user's authority to operate the equipment. The term “IC:”
before the
radio certification number only signifies that Industry Canada technical specifications
were met.
