Scientific Toys 2188-24GR 2.408-2.460 GHz WIRELESS R/C DEVICE-TX PORTION User Manual

Scientific Toys Ltd 2.408-2.460 GHz WIRELESS R/C DEVICE-TX PORTION

User Manual

©2014 RadioShack Corporation.
All rights reserved. RadioShack is a trademark used by RadioShack Corporation.
Printed
in China
06A14
6001056, 6001071
General Motors trademarks used under license to Scientic Toys,Ltd.
Install Battery in the Transmitter
1. Turn othe transmitter.
2. Use a screwdriver to open the battery compartment cover.
3. Insert one 9V battery (not included), matching the
polarity symbols (+ and ) marked inside the battery
compartment. Replace the battery cover and secure it
with the screw.
Install Battery Pack in the Vehicle
1. Turn othe vehicle.
2. Use a screwdriver to open the battery cover, then
plug the jack of the 9.6V battery pack into the
battery socket. Make sure you t the battery and
battery cables neatly inside.
3. Replace the battery cover and
secure it with the screw.
1:12 RC
Dune Warrior
We hope you enjoy your RC Dune Warrior from
RadioShack. Please read this user’s guide before setting
up and using your vehicle.
What’s Included
RC Dune Warrior
Transmitter
Battery Pack
Charger
User’s Guide
Features
Digital Proportional Steering and Speed control
Up to 1000 feet (305m) per minute
CHOKING HAZARD! Small parts. Not for children
under 3 years.
Age 6+
ON/OFF
6001056,6001071_UG_EN_051214.indd 1 6/19/2014 10:14:26 AM
Specifications
Battery Charger .........................................................................
.............................................6001056 only: 120V AC, 60 Hz
.........................6001071 only: 100 – 240V AC, 50 – 60 Hz
Output ........................................................12 V DC, 350 mA
Speed .................................. up to 1000 ft/min (305m/min)
Control Distance ........................................... 130 ft (39.6m)
Climbing Angle .................................................................... 20°
Specications are subject to change and improvement
without notice. Actual product may vary from the images
found in this document.
Safety and Care
• Not recommended for children under 6 years of
age. Adult supervision is recommended at all times.
• A nearby CB radio can interfere with your
vehicle’s control. If this happens, move the
vehicle away from the CB radio.
• Never play with your vehicle in the street.
• Avoid high-impact collisions with people and
objects.
FCC Information
This equipment has been tested and found to
comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
o and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment
and receiver.
Connect the equipment into an outlet on a
circuit dierent from that to which the receiver is
connected.
Consult your local RadioShack store or an
experienced radio/TV technician for help.
If you cannot eliminate the interference, the FCC
requires that you stop using your equipment. Changes
or modications not expressly approved by the party
responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Limited Warranty
RadioShack warrants this product against defects
in materials and workmanship under normal use
by the original purchaser for ninety (90) days after
the date of purchase from a RadioShack-owned
store or an authorized RadioShack franchisee or
dealer. RADIOSHACK MAKES NO OTHER EXPRESS
WARRANTIES.
This warranty does not cover: (a) damage or failure
caused by or attributable to abuse, misuse, failure
to follow instructions, improper installation or
maintenance, alteration, accident, Acts of God (such
as oods or lightning), or excess voltage or current; (b)
improper or incorrectly performed repairs by persons
who are not a RadioShack Authorized Service Facility;
(c) consumables such as fuses or batteries; (d) ordinary
wear and tear or cosmetic damage; (e) transportation,
shipping or insurance costs; (f) costs of product
removal, installation, set-up service, adjustment or
reinstallation; and (g) claims by persons other than the
original purchaser.
Should a problem occur that is covered by this
warranty, take the product and the RadioShack sales
receipt as proof of purchase date to any RadioShack
store in the U.S. RadioShack will, at its option, unless
otherwise provided by law (a) replace the product with
the same or a comparable product, or (b) refund the
purchase price. All replaced products, and products
on which a refund is made, become the property of
RadioShack.
RADIOSHACK EXPRESSLY DISCLAIMS ALL
WARRANTIES AND CONDITIONS NOT STATED
IN THIS LIMITED WARRANTY. ANY IMPLIED
WARRANTIES THAT MAY BE IMPOSED BY
LAW, INCLUDING THE IMPLIED WARRANTY
OF MERCHANTABILITY AND, IF APPLICABLE,
THE IMPLIED WARRANTY OF FITNESS FOR A
PARTICULAR PURPOSE, SHALL EXPIRE ON THE
EXPIRATION OF THE STATED WARRANTY PERIOD.
EXCEPT AS DESCRIBED ABOVE, RADIOSHACK
SHALL HAVE NO LIABILITY OR RESPONSIBILITY
TO THE PURCHASER OF THE PRODUCT OR ANY
OTHER PERSON OR ENTITY WITH RESPECT TO ANY
LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY
OR INDIRECTLY BY USE OR PERFORMANCE OF THE
PRODUCT OR ARISING OUT OF ANY BREACH OF
THIS WARRANTY, INCLUDING, BUT NOT LIMITED TO,
ANY DAMAGES RESULTING FROM INCONVENIENCE
AND ANY LOSS OF TIME, DATA, PROPERTY,
REVENUE, OR PROFIT AND ANY INDIRECT, SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES,
EVEN IF RADIOSHACK HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES.
Some states do not allow limitations on how long an
implied warranty lasts or the exclusion or limitation of
incidental or consequential damages, so the above
limitations or exclusions may not apply to you. This
warranty gives you specic legal rights, and you may
also have other rights which vary from state to state.
You may contact RadioShack at:
RadioShack Customer Relations
300 RadioShack Circle
Fort Worth, TX 76102 02/14
www.RadioShack.com
Charge the Vehicle Battery Pack
1. Insert the charger’s connector securely into the battery pack’s connector.
2. Plug the battery charger into a standard AC outlet.
3. Allow 2 hours for each charge. The charging indicator ashes during
charging. It stops ashing and remains lit when charging is
complete.
4. Unplug the charger and separate the battery connectors when fully
charged. When fully charged, the vehicle can run about 18 minutes.
Caution:
• To avoid damage and personal injury, use only the supplied charger
to charge the battery pack.
• After playing, wait at least 20 minutes to let the battery pack cool
before charging it.
Battery Notes:
• Use only fresh batteries of the required size and recommended
type. Dispose of the old batteries promptly and properly. Do not burn or bury them.
• Do not disassemble the charger and battery pack. Incorrect assembly can result in risk of electric shock or re.
• If you do not plan to use the vehicle for a week or longer, remove the batteries from the transmitter and the
vehicle.
• Batteries should NEVER be left unattended while charging. Only adults should charge the batteries. Use caution
when using the charger to avoid electric shock.
Recycle Rechargeable Batteries
Recycle used rechargeable batteries at one of the many collection sites in the U.S. and Canada. To nd the
site nearest you, visit www.call2recycle.org or call 1-800-822-8837.
Steering
Turn right and
left; release to
drive straight.
LED
O - Power o/dead or no battery
On - Paired
Flash quickly - Searching
vehicle to pair
Flash slowly- Pairing failed
Trigger
Pull and push to go
forward and back;
release to stop.
Charging Indicator
2 hr
Steering Trim
If your vehicle pulls to
the left, turn this switch
toward R; if the vehicle
pulls to the right, turn
this switch toward L.
Neutral Trim
If your vehicle moves
backward when it stops,
turn this switch toward
F; if the vehicle moves
forward, turn this switch
toward R.
Pairing Your
Vehicle and the
Transmitter
Your vehicle operates at a
frequency of 2.4Ghz. Before
driving the rst time, you must
pair the transmitter and vehicle.
1. Place the transmitter and
the vehicle close to each
other within 3 feet (1m).
2. Turn on the transmitter
and the vehicle. The LED
on the transmitter ashes
quickly, and then lights
green after 30 seconds
when transmitter and
the vehicle are paired
automatically.
Note:
If the pairing failed, turn o
the controller and the vehicle,
move closer, and then try
again.
If playing with more than one
DP Dune Warrior at the same
time, pair each vehicle one by
one. Turn o your vehicle
when not in use.
Drive Your Vehicle
ON/OFF
6001056,6001071_UG_EN_051214.indd 2 6/19/2014 10:14:27 AM
