Scientific Toys 3800-24GR R/C Car User Manual OI 6379 98865 LAMBO

Scientific Toys Ltd R/C Car OI 6379 98865 LAMBO

User Manual

1
3
2
65
7
SIZE: 210MM X 297MM PN#65-6379-000-0100
Keep packaging as it contains important information.
CAUTION: To prevent battery leakage:
Be sure to insert batteries correctly and always follow the product and battery
manufacturers' instructions.
Never mix old and new batteries (replace all batteries at the same time).
Never mix Alkaline, standard (Carbon Zinc) or rechargeable batteries.
Only batteries of the same or equivalent type as recommended are to be used.
Do not use RECHARGEABLE batteries, unless specified.
Non-rechargeable batteries are not to be recharged.
Rechargeable batteries are to be removed from the product before being charged
(if removable).
Rechargeable batteries are only to be charged under adult supervision (if removable).
Always remove exhausted or dead batteries from the product.
Remove batteries from product before extended storage.
The supply terminals are not to be short-circuited.
Batteries are to be inserted with correct polarity.
Batteries may explode or leak if misused.
ATTENTION: Battery / Batteries should be installed by an adult only.
ATTENTION: User should remove the battery from the item before disposal.
AA/LR6 or AAA/LR03 Batteries may present a choking hazard - keep away from
young children.
Battery Chargers
WARNING:
After use, the battery pack will be hot! Wait until it cools before recharging.
Recharging a warm or hot battery (pack) will greatly shorten the battery’s life.
Unplug the charger from the electrical outlet if it is not going to be used for a long
period of time.
Battery charger must be operated by adults only.
Non-rechargeable batteries are not to be recharged.
Do not charge a battery (pack) that is hot, wet or shows signs of leakage or corrosion.
Do not expose to fire, as this may result in explosion.
Do not short circuit the battery (pack).
Rechargeable batteries must be charged with the recommended battery charger.
The battery charger is to be regularly examined for damage to the cord, plug
enclosure and other parts. In the event of such damage, the charger must not be
used until it has been repaired or replaced.
The battery charger is not a toy.
Prolonged charging will not improve the battery output, and could eventually damage
the battery (pack).
Do not disassemble the battery pack (if appropriate).
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
The WEEE symbol if present indicates that this item contains electrical or
electronic components which must be collected and disposed of separately.
Never dispose of electrical or electronic waste in general municipal waste.
Collect and dispose of such waste separately.
Make use of the return and collection systems available to you, or your local
recycling programme. Contact your local authority or place of purchase to
find out what schemes are available.
Electrical and electronic equipment contains hazardous substances which,
when disposed of incorrectly, may leak into the ground. This can contribute
to soil and water pollution which is hazardous to human health, and endanger
wildlife.
It is essential that consumers look to re-use or recycle electrical or electronic
waste to avoid it going to landfill sites or incineration without treatment.
FCC Information
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one
or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
If you cannot eliminate the interference, the FCC requires that you stop using your
equipment. Warning: Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
OPERATING INSTRUCTIONS
BATTERY PACK CARE / CAUTIONS:
1. If battery pack and/or connectors are wet, thoroughly dry before charging.
2. Unplug the battery pack if it is not going to be used for several days.
3. Do not charge battery pack that is hot, wet or shows signs of leakage or corrosion.
4. Do not expose to fire, as explosion may result.
5. Do not disassemble the battery pack.
KEEP PACKAGING AS IT CONTAINS IMPORTANT INFORMATION.
BATTERY INSTALLATION:
BATTERY LOADING
(THE RECHARGEABLE BATTERY PACK IS NOT CHARGED, PLEASE CHARGE
IT FOR 2 HOURS PRIOR TO USE)
1. Plug the wall pack battery charger into wall outlet. (See Diagram 1)
2. Click the battery pack into the charger. Make certain the battery pack is secure
in charger.
3. To disconnect, push the button of the charger (See Diagram 1) and
simultaneously slide battery pack out.
4. You should charge the battery pack for 2 hours the first two times. Then subsequent
charges will only require 2 hours.
5. After charging for 2 hours, the battery will be warm. This condition is normal for
fully charged batteries.
6. If the speed of the car slows down suddenly, it is time to recharge.
7. After use, the battery pack will be hot! Wait at least 20 minutes until it cools before
recharging. Recharging a warm or hot battery pack will greatly shorten the battery
life.
ATTENTION PARENTS
IT IS RECOMMENDED THAT THIS TOY AND ALL ACCESSORIES BE
PERIODICALLY EXAMINED FOR POTENTIAL HAZARDS AND THAT ANY
POTENTIALLY HAZARDOUS PARTS BE REPAIRED OR REPLACED.
CARE
Never drive the vehicle on a wet floor, on sand, grass, carpet, in mud, rain or snow.
These can cause damage to the vehicle.
Do not expose the vehicle to extreme temperatures.
To protect the vehicle’s wheel mechanisms from lint and hair, do not drive it on carpet.
Occasionally wipe the vehicle with a damp cloth remove any dirt/dust from wheels.
Do not use harsh chemicals to clean the vehicle.
Modifying or tampering with the vehicle or the transmitter’s internal components
can cause a malfunction.
HELPFUL HINTS
Running the vehicle continuously for long periods of time generates high levels of heat.
Heat causes wear and tear on the motor. When the vehicle’s battery pack goes
flat, let the vehicle cool at least 10 minutes before installing a newly charged battery
pack. This helps keep heat levels down. If the vehicle’s motor runs but does not
respond to the transmitter, move the transmitter closer to the vehicle and try again.
If a CB radio is used nearby, it might interfere with control of the vehicle. If this
happens, move the vehicle and transmitter away from the CB radio. The vehicle
cannot be operated near devices with transmitters that use the same frequency.
Check the packaging to see which frequency your vehicle uses. If the vehicle moves
slowly, and a recharged battery pack has been installed, check the wheel mechanisms
for lint, thread, hair or dust.
INSERTING BATTERIES
VEHICLE
A. Turn over the vehicle and push the ON/OFF to "OFF" position. (See Diagram 2)
B. Open the battery cover. (See Diagram 3)
C. Insert the 9.6V battery pack into battery compartment. (See Diagram 3)
D. Replace the battery cover.
TRANSMITTER
1. Unscrew to open the battery lid. Insert 2 x AA batteries. (See Diagram 4)
2. Replace battery cover.
Note: Remove battery after you have finished using your vehicle.
HOW TO PLAY
START TO PLAY
PAIRING TRANSMITTER WITH VEHICLE
1. Turn ON the vehicle (See diagram 5).
2. Install 2 x AA batteries battery in the transmitter, the pairing LED light on the
transmitter will flash.
3. If pairing success, the pairing LED light will turn OFF.
4. You must pair the transmitter with the vehicle within 45 seconds, after 45 seconds
you must push the control on the transmitter to pair again.
5. You must repeat this exercise again when the transmitter needs to replace new
batteries.
OPERATION
1. Operate the vehicle with the transmitter (See Diagram 6).
2. Turn OFF the vehicle and the transmitter after playing and remove all batteries
from the transmitter and the car.
FRONT WHEELS STEERING ADJUSTMENT
1. If the vehicle does not run straight forwards, adjust the lever for satisfactory
alignment on the underside of the vehicle. (See Diagram 7)
2. If the vehicle runs towards left, turn "Steering Alignment Lever" towards "R".
3. If the vehicle runs towards right, turn "Steering Alignment Lever" towards "L".
9.6V Battery Pack
Battery Charger
Press button on side of charger
to release battery pack
Wall outlet
© 2018 SCIENTIFIC TOYS LTD. 1108, TOWER B,
14 SCIENCE MUSEUM ROAD, TSIMSHATSUI, HONG KONG.
PRINTED IN CHINA
O.I. NO.6379
ENGLISH
Steering alignment lever
1
3
2. Stop
Vehicle
Transmitter
Forwards/Backwards
Left/Right
TRY ME UNIT:
Try Me button box is for demonstration purpose only.
Dispose of this unit by detaching the wires connecting to the car
before playing.
TRY ME
UNIT
4
Unscrew to open
2 X AA batteries
Unscrew to open
Battery cover
9.6V battery pack
ON/OFF switch
ON with sound
ON without sound
On
